WLY User Manual
User Manual
Scales of Y series
Manual number:
ITKU-43-15-12-13-A
• WLY Scales
• WPY Scales
M AN UF ACT UR ER OF EL ECT RON IC
WEIGHING INSTRUMENTS
RADWAG Wagi Elektroniczne, 26–600 Radom, Bracka 28, POLAND
Phone +48 48 38 48 800, fax. +48 48 385 00 10
[email protected]
www.radwag.com
DECEMBER 2013
2
Table OF CONTENTS
1.
2.
3.
4.
INTENDED USE ..................................................................................................................................................9
PRECAUTIONARY MEASURES .......................................................................................................................9
WARRANTY CONDITIONS ................................................................................................................................9
UNPACKING AND MOUNTING .......................................................................................................................10
4.1. Scales of Y/C, Y/F1 series ..........................................................................................................................10
4.2. Scales of Y/2/D2 series ..............................................................................................................................11
5. SCALE STRUCTURE .......................................................................................................................................11
5.1. Main dimensions .........................................................................................................................................11
5.1.1. Scales of Y/F1 series ......................................................................................................................11
5.1.2. Scales of Y/C series ........................................................................................................................12
5.1.3. Scales of Y/2/D2 series ...................................................................................................................13
5.2. Description of connectors ...........................................................................................................................14
5.2.1. Connectors’ description in PUE 7 ...................................................................................................14
5.2.2. Connectors’ description in PUE 7P.................................................................................................14
5.2.3. Description of glands PUE 7P ........................................................................................................14
5.2.4. Connector with RS232 and I/O .......................................................................................................15
6. GETTING STARTED ........................................................................................................................................15
7. KEYPAD OVERLAY .........................................................................................................................................16
8. FUNCTIONS OF KEYS .....................................................................................................................................16
9. PROGRAM STRUCTURE ................................................................................................................................17
9.1. Main menu items.........................................................................................................................................17
9.2. Inventory of parameters ..............................................................................................................................18
9.2.1. Scale parameters - weighing ..........................................................................................................18
9.2.2. Working modes ...............................................................................................................................18
9.2.3. Communication ...............................................................................................................................24
9.2.4. Devices............................................................................................................................................25
9.2.5. Display.............................................................................................................................................27
9.2.6. Inputs / Outputs ...............................................................................................................................29
9.2.7. Authorization ...................................................................................................................................30
9.2.8. Units ................................................................................................................................................32
9.2.9. Other ...............................................................................................................................................32
9.2.10. User Adjustment ............................................................................................................................33
9.2.11. Info .................................................................................................................................................33
9.2.12. Update ...........................................................................................................................................34
10. INDICATING WINDOW ..................................................................................................................................34
10.1. Top bar .....................................................................................................................................................35
10.2. Weighing window ......................................................................................................................................35
10.3. Workspace ................................................................................................................................................35
10.4. Function keys............................................................................................................................................36
11. LOGGINGG IN ................................................................................................................................................36
11.1. Logging in - procedure..............................................................................................................................37
11.2. Logging out procedure..............................................................................................................................37
11.3. Authorization access levels ......................................................................................................................37
12. NAVIGATING WITHIN THE MENU ................................................................................................................39
12.1. Keys ..........................................................................................................................................................39
12.2. Return to weighing ....................................................................................................................................40
13. WEIGHING ......................................................................................................................................................40
13.1. Conditions of operational use ...................................................................................................................41
13.2. Zeroing ......................................................................................................................................................42
13.3. Tarring ......................................................................................................................................................42
13.4. Inscribing tare ...........................................................................................................................................43
13.5. Weighing for dual range scales ................................................................................................................43
13.6. Toggling between weighing units .............................................................................................................44
3
14. SCALE PARAMETERS ..................................................................................................................................44
14.1. Median filter ..............................................................................................................................................45
14.2. Filter ..........................................................................................................................................................45
14.3. Autozero ...................................................................................................................................................46
14.4. Minimum weight for different functions (LO) ............................................................................................46
14.5. Last digit ...................................................................................................................................................47
15. COMMUNICATION .........................................................................................................................................47
15.1. RS 232 settings ........................................................................................................................................48
15.2. ETHERNET setting ...................................................................................................................................48
15.3. TCP protocol setting .................................................................................................................................49
16. DEVICES .........................................................................................................................................................49
16.1. Computer ..................................................................................................................................................49
16.1.1. Computer port ................................................................................................................................50
16.1.2. Computer address .........................................................................................................................50
16.1.3. Continuous transmission ...............................................................................................................50
16.1.4. Weighing printout template............................................................................................................51
16.1.5. Cooperation with “E2R System” ....................................................................................................52
16.2. Printer .......................................................................................................................................................53
16.2.1. Printer port .....................................................................................................................................53
16.2.2. Printer code page ..........................................................................................................................53
16.2.3. Templates for printouts ..................................................................................................................54
16.3. Printouts activation ...................................................................................................................................56
16.4. Barcode scanner ......................................................................................................................................56
16.4.1. Port for barcode scanner ...............................................................................................................57
16.4.2. Prefix / Suffix .................................................................................................................................57
16.4.3. Field selection ................................................................................................................................58
16.4.4. Test ................................................................................................................................................59
16.5. Transponder card reader ..........................................................................................................................60
16.5.1. Com port for transponder card readers .........................................................................................60
16.5.2. Procedure of attributing the card number to an operator ..............................................................61
16.6. Additional display ......................................................................................................................................61
16.6.1. Additional display port ...................................................................................................................61
16.6.2. Communication protocol frame .....................................................................................................62
16.7. Advanced settings ....................................................................................................................................63
17. DISPLAY .........................................................................................................................................................63
17.1. Text strings ...............................................................................................................................................64
17.1.1. Display templates ..........................................................................................................................64
17.2. Function keys............................................................................................................................................66
17.3. Displaying platforms .................................................................................................................................71
17.4. Bargraph ...................................................................................................................................................71
17.4.1. Bargraph type ................................................................................................................................71
17.4.2. Bargraph “Quick weighing” ............................................................................................................72
17.4.3. Bargraph “Signalling of checkweighing ranges”............................................................................73
17.4.4. Bargraph type: „Linear” .................................................................................................................74
17.4.5. “Control” bargraph .........................................................................................................................75
18. INPUTS / OUTPUTS .......................................................................................................................................77
18.1. Configuration of inputs..............................................................................................................................77
18.2. Configuration of outputs ...........................................................................................................................78
19. AUTHORIZATION...........................................................................................................................................79
19.1. Anonymous Operator ...............................................................................................................................79
19.2. Date and time ...........................................................................................................................................79
19.3. Printouts ....................................................................................................................................................80
19.4. Databases edition .....................................................................................................................................80
19.5. Delete older data ......................................................................................................................................81
19.6. Set element from the database ................................................................................................................82
19.7. CPG ..........................................................................................................................................................82
20. UNITS ..............................................................................................................................................................83
20.1. Units accessibility .....................................................................................................................................83
20.2. Start unit ...................................................................................................................................................84
4
20.3. User defined units .....................................................................................................................................84
20.4. Acceleration of gravity ..............................................................................................................................85
21. OTHER PARAMETERS .................................................................................................................................85
21.1. Languages ................................................................................................................................................86
21.2. Setting date and time................................................................................................................................86
21.3. Sound signal .............................................................................................................................................87
21.4. Touch panel calibration ............................................................................................................................87
21.5. Screen brightness .....................................................................................................................................88
21.6. Cursor .......................................................................................................................................................88
21.7. Logging in required ...................................................................................................................................89
21.8. Start logo ..................................................................................................................................................89
21.9. Error information preview time .................................................................................................................90
22. USER ADJUSTMENT .....................................................................................................................................90
22.1. Adjusting procedure..................................................................................................................................90
22.2. Start mass adjustment ..............................................................................................................................92
22.3. Report from adjustment process ..............................................................................................................93
22.4. Adjustment track record............................................................................................................................93
23. SOFTWARE UPDATE ....................................................................................................................................94
23.1. ON-LINE updating ....................................................................................................................................94
23.2. Update from pendrive ...............................................................................................................................96
23.3. Changes in software .................................................................................................................................96
24. SPECIAL FUNCTIONS OF WORKING MODES ...........................................................................................97
24.1. Working modes accessibility ....................................................................................................................98
24.2. Save mode................................................................................................................................................99
24.3. Down-weighing .......................................................................................................................................100
24.4. Checkweighing .......................................................................................................................................100
24.5. Tare mode ..............................................................................................................................................100
24.6. Labelling mode .......................................................................................................................................101
24.6.1. Setting of the number of labels to print .......................................................................................102
24.6.2. Setting of the number of cumulative labels to print .....................................................................102
24.6.3. Setting of the number of CC labels to print .................................................................................102
24.6.4. Automatic triggering of cumulative labels....................................................................................103
24.6.5. Automatic triggering cumulative labels of cumulative labels.......................................................104
24.7. Statistics .................................................................................................................................................106
24.8. Differential weighing ...............................................................................................................................106
24.8.1. Local settings ...............................................................................................................................107
24.8.2. Reporting realized processes of differential weighing ................................................................107
24.9. Peak hold ................................................................................................................................................107
25. WORKING MODE - WEIGHING ...................................................................................................................108
25.1. Starting the working mode ......................................................................................................................108
25.2. Local setting of a working mode .............................................................................................................109
26. WORKING MODES – PARTS COUNTING .................................................................................................109
26.1. Starting the working mode ......................................................................................................................109
26.2. Local settings of the working mode ........................................................................................................110
26.2.1. Automatic correction of reference mass......................................................................................110
26.2.2. Minimum reference mass ............................................................................................................111
26.3. Setting a reference unit by entering known piece mass ........................................................................112
26.4. Setting a reference unit by weighing a sample ......................................................................................112
26.5. Setting the reference mass by entering single piece mass directly to the database .............................113
26.6. Inscribing the unit mass to the database................................................................................................114
27. WORKING MODES – PERCENT SETUP (DEVIATIONS) ..........................................................................114
27.1. Starting the operating mode ...................................................................................................................114
27.2. Local settings of the working mode ........................................................................................................115
27.3. Reference unit mass estimated by weighment ......................................................................................115
27.4. Rederence unit mass inscribing into the memory ..................................................................................115
28. WORKING MODES - DOSING .....................................................................................................................116
28.1. Starting the working mode ......................................................................................................................116
28.2. Dosing process structure ........................................................................................................................117
5
28.3. Local setting of a working mode .............................................................................................................117
28.4. Description of functions and setting dosing process ..............................................................................118
28.5. Creating a new dosing process ..............................................................................................................121
28.6. Instances of dosing processes ...............................................................................................................122
28.6.1. Instance 1 – Manual dosing process of 4 ingredients on 2 weighing platforms .........................122
28.6.2. Instance 2 – Automatic dosing of 2 ingredients on 2 weighing platforms...................................124
28.6.3. Instance 3 – Mixed dosing process .............................................................................................126
28.7. Reporting of completed dosing processes .............................................................................................129
29. WORKING MODES – FORMULATION .......................................................................................................130
29.1. Starting the working mode ......................................................................................................................130
29.2. Local setting of a working mode .............................................................................................................131
29.3. Creating a new formulation ....................................................................................................................132
29.4. Formula making process ........................................................................................................................135
29.5. Reporting from completed formula making processes...........................................................................137
30. WORKING MODE – CPG (CONTROL OF PREPACKED GOODS) ...........................................................138
30.1. Starting the working mode ......................................................................................................................139
30.2. Control settings mode window ...............................................................................................................140
30.3. Local setting of a working mode .............................................................................................................141
30.4. Editing a product to be controlled ...........................................................................................................141
30.5. Control start procedure ...........................................................................................................................144
30.6. Control aborting procedure .....................................................................................................................145
30.7. Loggingg out from a control process in progress ...................................................................................146
30.8. Non-destructive average tare control mode ...........................................................................................147
30.9. Performing non-distructive testing in mode Empty-Full .........................................................................154
30.10. Performing distructive testing in modes Empty-Full and Full-Empty ....................................................155
30.11. Control in accordance with internal criteria ...........................................................................................156
30.11.1. Abort of control - procedure ......................................................................................................158
30.11.2. Procedure of control completion ...............................................................................................159
30.12. Simultaneous carrying out two control processes ................................................................................159
30.13. Report from estimating average tare ....................................................................................................161
30.14. Report from product testing ..................................................................................................................162
31. WORKING MODES – DENSITY ..................................................................................................................165
31.1. Starting the working mode ......................................................................................................................165
31.2. Local setting of a working mode .............................................................................................................165
31.3. Carrying out density determination procedure .......................................................................................166
31.3.1. Determining density of liquids .....................................................................................................166
31.3.2. Determining density of solids ......................................................................................................168
31.3.3. Determining density of pycnometer .............................................................................................169
31.3.4. Determining density of a porous body.........................................................................................171
31.4. Reporting from completed density determination processes .................................................................173
31.5. Table of density parameter for water .....................................................................................................174
31.6. Table of density parameter for ethyl alcohol ..........................................................................................174
32. WORKING MODES – ANIMAL WEIGHING ................................................................................................175
32.1. Starting the operating mode ...................................................................................................................175
32.2. Local setting of a working mode .............................................................................................................175
32.3. Carrying out animals weighing procedure ..............................................................................................176
33. WORKING MODE – VEHICLE SCALE........................................................................................................176
33.1. Working mode activating procedure .......................................................................................................176
33.2. Working mode local settings ..................................................................................................................178
33.3. Vehicle transaction course .....................................................................................................................178
33.3.1. Entrance / Exit transaction ..........................................................................................................178
33.3.2. Control weighment transaction ....................................................................................................182
33.4. Open transactions table..........................................................................................................................184
33.5. Printout templates for an ongoing transaction .......................................................................................184
33.6. Executed transactions – reporting ..........................................................................................................186
34. DATABASES ................................................................................................................................................186
34.1. Database configuration...........................................................................................................................187
34.1.1. Databases accessibility ...............................................................................................................187
34.1.2. Categories ...................................................................................................................................188
6
34.1.3. Database variables operation......................................................................................................189
34.1.4. Change name of an extra variables database ............................................................................189
34.1.5. Change database records preview .............................................................................................190
34.1.6. Databases export / import ...........................................................................................................190
34.2. Searching databases ..............................................................................................................................191
34.2.1. Quick name search......................................................................................................................191
34.2.2. Quick code search .......................................................................................................................191
34.3. Adding new items in databases..............................................................................................................192
34.4. Deleting items in databases ...................................................................................................................192
34.5. Printing items from databases ................................................................................................................192
34.6. Context menu .........................................................................................................................................193
34.7. Database edit window ............................................................................................................................194
34.7.1. Operators’ database ....................................................................................................................194
34.7.2. Database of products ..................................................................................................................195
34.7.3. Database of clients ......................................................................................................................197
34.7.4. Database of dosing processes ....................................................................................................197
34.7.5. Database of formulations ............................................................................................................198
34.7.6. Database of vehicles ...................................................................................................................199
34.7.7. Identification processes database ...............................................................................................199
34.7.8. Database of packages .................................................................................................................200
34.7.9. Database of warehouses .............................................................................................................200
34.7.10. Database of labels .....................................................................................................................201
34.7.11. Database of universal variables ................................................................................................201
34.7.12. Extra variables database ...........................................................................................................202
34.7.13. Images database .......................................................................................................................202
35. REPORTS .....................................................................................................................................................203
35.1. Reports configuration .............................................................................................................................204
35.1.1. Reports accessibility ....................................................................................................................204
35.1.2. Configuration of a lot number ......................................................................................................205
35.1.3. Configuration of a batch number .................................................................................................205
35.2. Deleting older data .................................................................................................................................205
35.3. Weighment date search..........................................................................................................................206
35.4. Reports from weighment records ...........................................................................................................206
35.4.1. Filtering ........................................................................................................................................207
35.4.2. Report printout .............................................................................................................................208
35.4.3. Weighments chart........................................................................................................................208
35.4.4. Export a database to a file...........................................................................................................209
35.4.5. Counter of weighments records ..................................................................................................211
35.5. Reports preview ......................................................................................................................................212
35.5.1. Weighments / Alibi .......................................................................................................................212
35.5.2. Reports from dosing ....................................................................................................................213
35.5.3. Reports from recipes ...................................................................................................................214
35.5.4. Density reports ............................................................................................................................215
35.5.5. Controls reports ...........................................................................................................................216
35.5.6. Average tare reports ....................................................................................................................217
35.5.7. Report from vehicle scale ............................................................................................................218
35.5.8. Differential weighments reports ...................................................................................................219
36. IDENTIFICATION PROCESSES ..................................................................................................................220
36.1. Identification process – creation .............................................................................................................221
36.2. List of identification process functions ....................................................................................................222
36.3. Identification process – activation procedure .........................................................................................224
36.3.1. Activation by programmable button .............................................................................................224
36.3.2. Activation by operator logging .....................................................................................................225
36.3.3. Activation by product selection ....................................................................................................225
36.3.4. Example of process forming and its realization ..........................................................................226
37. COMMUNICATION PROTOCOL .................................................................................................................229
37.1. General information ................................................................................................................................229
37.2. List of RS commands .............................................................................................................................230
37.3. Respond message format ......................................................................................................................231
37.4. Command’s description ..........................................................................................................................231
37.4.1. Zeroing.........................................................................................................................................231
7
37.4.2. Tarring .........................................................................................................................................232
37.4.3. Get tare value ..............................................................................................................................232
37.4.4. Set tare value ..............................................................................................................................232
37.4.5. Send the stable result in basic unit .............................................................................................233
37.4.6. Send the result immediately in basic unit ....................................................................................233
37.4.7. Send immediate results from all platforms in basic units ............................................................234
37.4.8. Send the stable result in current unit...........................................................................................234
37.4.9. Send the result immediately in current unit .................................................................................235
37.4.10. Switch on continuous transmission in basic unit.......................................................................236
37.4.11. Switch off continuous transmission in basic unit.......................................................................236
37.4.12. Switch on continuous transmission in current unit ....................................................................236
37.4.13. Switch off continuous transmission in current unit ....................................................................237
37.4.14. Set lower threshold....................................................................................................................237
37.4.15. Set upper threshold ...................................................................................................................237
37.4.16. Read lower threshold ................................................................................................................237
37.4.17. Read upper threshold ................................................................................................................238
37.4.18. Simulation of pressing ENTER/PRINT key ...............................................................................238
37.4.19. Change platform ........................................................................................................................238
37.4.20. Send all implemented commands .............................................................................................239
37.5. Manual printouts / automatic printouts ...................................................................................................239
38. COOPERATION WITH PERIPHERAL DEVICES ........................................................................................240
39. DIAGRAMS OF CONNECTION CABLES ...................................................................................................240
40. TECHNICAL PARAMETERS .......................................................................................................................242
40.1. Scales of WLY series .............................................................................................................................242
40.2. Scales of WPY series .............................................................................................................................243
40.3. Scales of WLY/KTP series .....................................................................................................................244
40.4. Scales of WPY/KTP series .....................................................................................................................245
41. ERROR MESSAGES ....................................................................................................................................247
42. ADDITIONAL EQUIPMENT..........................................................................................................................247
43. APPENDIX A – Variables for printouts......................................................................................................248
43.1. Inventory of variables .............................................................................................................................248
43.2. Formatting variables ...............................................................................................................................255
43.3. Mathematical function.............................................................................................................................257
44. APPENDIX B – Functions of programmable buttons ..............................................................................259
45. APPENDIX C – Label template ...................................................................................................................265
45.1. Designing a label from the terminal level ...............................................................................................265
45.2. Designing a label on a computer ............................................................................................................266
45.3. Saving label templates in the scale ........................................................................................................270
45.4. Attributing a label to a product................................................................................................................270
45.5. Attributing a label to a client ...................................................................................................................271
45.6. Printing labels .........................................................................................................................................271
46. APPENDIX D - CITIZEN printer setting .....................................................................................................271
47. APPENDIX E - ZEBRA printer setting .......................................................................................................272
48. APPENDIX F - Communication with barcode scanners..........................................................................272
49. APPENDIX G – Computer Program „ViewerKTP” ...................................................................................273
8
1. INTENDED USE
Scales are the response for the market demands concerning simplicity
of operation and high functionality. They are intended for quick and precise
weighing in industrial and laboratory conditions. The state-of-the-art
weighing terminal with TFT 5.7” colourful graphic displays with touch
panels allows for intuitive operation without using keys.
Scales are equipped with 2 USB interfaces, 2 RS232 connectors, port
Ethernet and 4 inputs/4 outputs (digital). They can cooperate with barcode
scanners, receipt printers, label printers, transponder card readers (RFID)
and standard PC equipment: mouse, keyboard, pendrives (limited use).
2. PRECAUTIONARY MEASURES
A. Please, read carefully this user manual before and use the device
according to its intended use;
B. Weighed loads should be placed in possibly central part of scale pan;
C. Do not clean the device with agents causing corrosion;
D. Weighing pan should be loaded with goods having gross mass lower
than maximal capacity of the scale;
E. Do not leave loads on the pan for longer period of time ;
F. In case of failure, immediately disconnect scale power supply;
G. Devices that are to be withdrawn from usage should be utilized
according to the law.
3. WARRANTY CONDITIONS
A. RADWAG is obliged to repair or change those elements that appears
to be faulty because of production and construction reason,
B. Defining defects of unclear origin and outlining methods of elimination
can be settled only in participation of a user and the manufacturer
representatives,
C. RADWAG does not take any responsibility connected with destructions
or losses derives from non-authorized or inappropriate (not adequate
to manuals) production or service procedures,
9
D. Warranty does not cover:
• Mechanical failures caused by inappropriate maintenance of
the device or failures of thermal or chemical origin or caused
by atmospheric discharge, overvoltage in mains or other
random event,
• Inappropriate cleaning.
E. Forfeiture of warranty appears after:
• Access by an unauthorized service,
• Intrusion into mechanical or electronic construction
of unauthorized people,
• Installing another operating system,
• Removing or destroying protection stickers.
F. The detailed warranty conditions one can find in warranty certificate.
G. Contact with the central authorized service:
+48 48 384 88 00 ext. 106 or 107.
4. UNPACKING AND MOUNTING
4.1. Scales of Y/C, Y/F1 series
A. Take the device out of the package,
B. Put the scale on an even stiff ground,
C. Remove transport protection:
D. Scale should be levelled by turning regulation feet. Levelling is correct
if air bubble is situated in the central position:
10
4.2. Scales of Y/2/D2 series
A. Take the device out of the package,
B. Put the scale on an even stiff ground,
C. Fit the pan and the bracket under the device according to the drawing:
E. Scale should be levelled by turning regulation feet. Levelling is correct
if air bubble is situated in the central position:
5. SCALE STRUCTURE
5.1. Main dimensions
5.1.1. Scales of Y/F1 series
11
Y/F1/R series – main dimensions
Y/F1/K series – main dimensions
5.1.2. Scales of Y/C series
12
Y/C2/R series – main dimensions
Y/C2/K series – main dimensions
5.1.3. Scales of Y/2/D2 series
13
5.2. Description of connectors
5.2.1. Connectors’ description in PUE 7
1 – Ethernet RJ45
2 – RS232 (COM1)
3 – USB
1 – power supply socket
2 – I/O, RS232 (COM2)
5.2.2. Connectors’ description in PUE 7P
1 – Ethernet RJ45
2 – RS232 (COM1)
3 – USB
1 – I/O, RS232 (COM2)
5.2.3. Description of glands PUE 7P
1 – Supply cord gland
2 – Gland for platforms 1, 2
3 – Gland for platforms 3, 4
14
5.2.4. Connector with RS232 and I/O
RS232 - DB9/M (male),
top view:
Pin2 - RxD
Pin3 – TxD
Pin4 - +5 V DC
Pin5 - GND
I/O, RS232 DSUB15/F (female),
top view:
Pin1 - GNDWE
Pin2 - OUT1
Pin3 - OUT2
Pin4 - COMM
Pin5 - 6÷9VDC
Pin6 - IN4
Pin7 - IN3
Pin8 - TxD2
Pin9 - 5VDC
Pin10 - GNDRS
Pin11 - IN2
Pin12 - IN1
Pin13 - RxD2
Pin14 - OUT4
Pin15 - OUT3
6. GETTING STARTED
• After the terminal is connected to power the ON/LOAD
diode starts to light.
to start the operating system loading procedure.
• Press
Windows CE together with RADWAG software loading is signalled
by blinking the red diode ON/LOAD.
• When the loading procedure is completed the main software
window appears.
15
7. KEYPAD OVERLAY
8. FUNCTIONS OF KEYS
Key
Description
Turning on/off the scale
Zeroing
Tarring
Printing out the result or confirming some entered data
Function key (entering the menu)
Programmable key
Programmable key
Programmable key
16
9. PROGRAM STRUCTURE
The main menu has been divided into twelve functional groups.
In every group there are parameters of similar use.
9.1. Main menu items
Pictogram
Description
Scale
Databases
Reports
Working Modes
Communication
Devices
Display
Inputs / Outputs
Authorization
Units
Other
User Adjustment
Info
Update
17
9.2. Inventory of parameters
9.2.1. Scale parameters - weighing
Pictogram
Description
Value
Median Filter
0.5
Filter
Fast
Autozero
LO threshold
0.1
Last digit
Always
9.2.2. Working modes
Pictogram
Description
Value
Accessibility
-
Weighing
Parts counting
Percent setup
Dosing
Formulation
Animal weighing
Density
CPG
Vehicle scale
Weighing
-
Save Mode
Manual, each
stable
18
Down-weighing
Checkweighing
Tare mode
Single
Labelling mode
-
Number of labels
1
No. of cumulative labels
1
No. of CC labels
1
C label automatic triggering
-
Mode
None
Threshold
100
CC label automatic triggering
-
Mode
None
Threshold
100
Statistics
Global
Differential weighing
-
Activation
Batch portion type
Value
Charge
1
Peak hold
Parts counting
-
Automatic correction of reference mass
Minimum reference mass
10d
Save Mode
Manual, each
stable
19
Down-weighing
Checkweighing
Tare mode
Single
Labelling mode
-
Number of labels
1
No. of cumulative labels
1
No. of CC labels
1
C label automatic triggering
-
Mode
None
Threshold
100
CC label automatic triggering
-
Mode
None
Threshold
100
Statistics
Global
Percent setup
-
Save Mode
Manual, each
stable
Down-weighing
Checkweighing
Tare mode
Single
Labelling mode
-
Number of labels
1
No. of cumulative labels
1
20
No. of CC labels
1
C label automatic triggering
-
Mode
None
Threshold
100
CC label automatic triggering
-
Mode
None
Threshold
100
Statistics
Global
Dosing
-
Ask for multiplier
Ask for number of cycles
Confirm batching ingredients manually
No. of weighments for calculating the
correction
0
Global
-
Batching outputs
-
Output 1
0
Output 2
0
Output 3
0
Output 4
0
Bulk batching output
-
Output 1
0
Output 2
0
Output 3
0
21
Output 4
0
Correction
0
Maximum correctional value
0
Formulation
-
Ask for multiplier
Ask for number of cycles
Confirm batching ingredients manually
Automatic tare
Ingredient control
Portion weighing
Report printout
Animal weighing
-
Averaging time
5
Automatic mode
Checkweighing
Tare mode
Single
Labelling mode
-
Number of labels
1
No. of cumulative labels
1
No. of CC labels
1
C label automatic triggering
-
Mode
None
22
Threshold
100
CC label automatic triggering
-
Mode
None
Threshold
100
Statistics
Global
Density
-
Standard liquid
Water
Temperature
21
Standard liquid density
1
Sinker volume
0
Ask abort sample number
Pycnometer mass
0
Pycnometer density
0
Unit
g/cm
Save Mode
Manual, each
stable
3
Checkweighing
Tare mode
Single
Statistics
Global
CPG
-
Save Mode
Manual, each
stable
Number of accessible controls
1
Ask for batch number
23
Password required
Vehicle scales
-
Default transaction type
Entry
Selekt vehicle
From a list
Report printout
9.2.3. Communication
Pictogram
Description
Value
RS 232 (1)
-
Baud Rate
9600
Data bits
8
Stop bits
1
Parity
None
RS 232 (2)
-
Baud Rate
9600
Data bits
8
Stop bits
1
Parity
None
Ethernet
-
DHCP
IP Address
192.168.0.2
Subnet mask
255.255.255.0
24
Gateway
192.168.0.1
DNS
192.168.0.1
MAC Address
-
Tcp
-
Port
4001
9.2.4. Devices
Pictogram
Description
Value
Computer
Port
None
Address
1
Continuous transmission
Weighing Printout Template
-
E2R System
-
System is active
Lock selecting products
Printer
-
Port
RS 232 (1)
Code page
1250
Printouts
-
Weighing printout template
See ch. 16.2.3
25
Report From Weighments Printout
Template
See ch. 35.4.2
Cumulative printout template
See ch. 16.2.3
Cumulative printout template
for cumulative data
See ch. 16.2.3
Adjustment report printout template
See ch. 22.3
Dosing report printout template
See ch. 28.7
Formulation report printout template
See ch. 29.5
Printout Template of an Ingredient
in a Formulation
See ch. 16.2.3
CPG report printout pattern
(Control of Packacked Goods)
See ch. 30.14
Average tare report printout pattern
(Control of Packacked Goods)
See ch. 30.13
Entry Ticket Printout Template
See ch. 33.5
Exit Ticket Printout Template
See ch. 33.5
Control Weighment Ticket Printout
Template
See ch. 33.5
Report From Vehicle Scale Printout
Template
See ch. 33.5
Density printout template
See ch. 31.4
Product printout template
See ch. 16.2.3
Operator printout template
See ch. 16.2.3
Client printout template
See ch. 16.2.3
Warehouse printout template
See ch. 16.2.3
Package printout template
See ch. 16.2.3
Car printout template
See ch. 16.2.3
26
Barcode reader
-
Port
None
Prefix
01
Suffix
0d
Field selection
See ch. 16.3.3
Test
See ch. 16.3.4
Transponder card reader
-
Port
None
Additional display
-
Port
None
Template
See ch. 16.5.2
Advanced settings
-
Number of printers
1
9.2.5. Display
Pictogram
Description
Value
Text information
-
Displaying template
See ch. 17.1.1
Left displaying template
See ch. 17.1.1
Right displaying template
See ch. 17.1.1
Font
-
Type
Courier
27
Font size
Small
Bold
Tilt
Colour
Black
Background colour
Light grey
Set Default
-
Button functions
See ch. 17.2
Show all platforms
Bargraph
-
Bargraph type
None
Fast weighing
-
MIN, MAX thresholds working
mode
Unstable
OK threshold working mode
Unstable
Min threshold signalling colour
Red
OK threshold signalling colour
Intense green
Max threshold signalling colour
Red
Gradient
Background colour
Black
Frame colour
White
Signalling checkweighing ranges
-
MIN, MAX thresholds working
mode
Unstable
OK threshold working mode
Unstable
28
Min threshold signalling colour
Red
OK threshold signalling colour
Intense green
Max threshold signalling colour
Red
Gradient
Background colour
Black
Frame colour
White
Linear
-
Min threshold signalling colour
Red
OK threshold signalling colour
Green
Max threshold signalling colour
Red
Min Max range background colour
Turquoise
OK range signalling colour
Turquoise
Gradient
9.2.6. Inputs / Outputs
Pictogram
Description
Value
Inputs
-
Input 1
None
Input 2
None
Input 3
None
Input 4
None
29
Outputs
-
Output 1
None
Output 2
None
Output 3
None
Output 4
None
9.2.7. Authorization
Pictogram
Description
Value
Anonymous operator
Operator
Date & Time
Administrator
Printouts
Administrator
Databases edition
Products
Administrator
Clients
Administrator
Dosing processes
Administrator
Formulations
Administrator
Packages
Administrator
Vehicles
Administrator
Warehouses
Administrator
Labels
Administrator
Images
Administrator
30
Traceability process
Administrator
Weighing counter
Administrator
Delete older data
Advanced Operator
Set element from the database
-
Products
Administrator
Clients
Administrator
Dosing processes
Administrator
Formulations
Administrator
Packages
Administrator
Vehicles
Administrator
Warehouses
Administrator
Traceability process
Administrator
Lot number
Operator
Batch number
Operator
CPG
-
Batch number
Operator
Batch size
Operator
Sample quantity
Operator
Average Tare Estimation
Advanced operator
Tare
Operator
Density
Advanced operator
31
9.2.8. Units
Pictogram
Description
Value
Accessibility
-
g
ct
lb
oz
N
Start unit
None
Defined unit 1
-
Multiplier
0
Name
-
Defined unit 1
-
Multiplier
0
Name
-
Acceleration of gravity
9.80665
9.2.9. Other
Pictogram
Description
Value
Language
Polish
Date and Time
-
Set date and time
-
Date format
yyyy.MM.dd
32
Time format
HH:mm:ss
2013.07.29
11:10:09
Beep
Yes
Touch screen calibration
-
Screen brightness
-
Cursor
Log in required
Start logo
-
Error information preview time
Max
9.2.10. User Adjustment
An option only for non-verified scale
Pictogram
Description
Value
Setting of start mass
-
Adjustment
-
Report printout
Adjustment track record
9.2.11. Info
Pictogram
Description
Factory number
33
-
Software version
Version of weighing software
Memory usage
9.2.12. Update
Pictogram
Description
Value
Software version on server
Check version
Update from server
-
Update from pendrive
-
Changes in software
-
10. INDICATING WINDOW
Main view:
34
In the main application window one can see four separate parts:
•
•
•
•
Top bar,
Weighing window,
Workspace,
Function keys.
10.1. Top bar
The top bar on the display contains the following data:
Pictogram and name of an active working mode
Logged user
Pictogram of an active connection with a computer
Date and time
10.2. Weighing window
The weighing window contains data on carried out weighing process:
10.3. Workspace
The workspace is located under the weighing window:
35
The workspace features three displaying templates. The upper section of the
workspace comprises a graphic information on which of the three templates
is enabled. Changing of the template is carried out by draging the workspace
to the right or left.
The data conatined in the workspace is optionally programmable for each of
the working modes. The default template format is described in point 17.1.1
of this user manual.
Caution:
An exception is an “initial workspace window” in the CPG mode, containing a
logo and non-editable anvigating line:
10.4. Function keys
Below the workspace area there is a set of on-screen function keys:
The on-screen function keys are editable in each of the available working
modes. The procedure of enabling/disabling function keys is described in
point 17.2 of this user manual.
11. LOGGINGG IN
In order to get full access to users parameters and to be able to edit database
the user must log as an <Administrator>.
36
Caution:
For each brand new scale there is a default <
Admin> operator with
<Administrator> authorization and no password. After the scales start the
user automatically logs in as a default operator. If default operator data have
been changed or if new operators have been added manual logging
procedure is required.
11.1. Logging in - procedure
• Press <Log in> sign to open operators database window, <Log in>
sign is located in the main window of an application at the top bar,
• Select a proper position and wait to see a screen keyboard with an edit
field for an operator password,
• Enter the password and confirm it with
button,
• Program returns to the main window, the logged in operator name is
displayed instead of <Log in> sign at the top bar of the main window.
11.2. Logging out procedure
• While in the main application window press the name of a logged
in operator in the top bar on the screen to open the database of
operators,
• Press Logging out button situated in the top bar of the operators’
database window:
• The program returns to the main window and in the top bar the
operators name is substituted by <Log in>.
11.3. Authorization access levels
There are four levels of authorization: Administrator, Advanced Operator,
Operator, None.
37
Access to user parameters, databases and working modes depending
on the authorization access level attributed:
Operator type
Access level description
None
No access to user parameters. No weighing can be confirmed.
Cannot start procedure „CPG”. Cannot enter the reference mass
unit and estimate the reference mase unit by weiging in „Counting
Pieces” and „Deviations”, density determination, carrying out
dosing and formulation making processes. No access to <Export
2)
the weighing database to a file> in menu <Reports> .
Operator
Access to parameters in submenu: <Weighing>, <Display>
1)
(excluding the group <Actions>), <Others> . Can start and
perform all weighing procedures. Access to <Export the
2)
weighing database to a file> in menu <Reports> .
Advanced
Operator
Access to parameters in submenus: <Weighing>, <Working
1)
1)
modes>, <Communication>, <Devices> , <Display> ,
1)
<Others> . Can start and perform all weighing procedures.
Access to <Export the weighing database to a file> in menu
2)
<Reports> .
2)
Access to all user parameters, functions and databases .
Can start and perform all weighing procedures.
Administrator
1)
1. Authorization level for editing functions:
• <
Printouts> in submenu „
• <
Sample> in submenu „
Devices /
Printer”,
Devices /
Additional display”,
• <
Displaying template> in submenu „
Display /
Text information”,
• <
Date and Time> in submenu <
Others>,
The functions are declared in submenu <
Authorizations>, which
is accessable only for users with the <Administrator> authorization
level (see ch. 19 of this manual).
38
2. A user logged in as <Administrator> in submenu
Authorizations> (see ch. 19 of this manual) can change
<
authorization levels for accessing different databases and functions:
<
Delete older data>, <
are database <
only”.
Weighing counter>. The exception
Weighings / Alibi>, that have the status „Read
12. NAVIGATING WITHIN THE MENU
Owing to the colour display with the touch panel navigating within the menu
is simple and intuitive.
12.1. Keys
Entering the main menu
Menu list „up”
Menu list „down”
Scrolling „up-down”
Enter (OK)
Abort
Add a new item in a database
Disabeling the formerly selected record e.g. Loggingg out the
operator
Searching a database by date
Searching a database by name
Searching a database by code
39
Printing on item from a database
Exporting reports from testing and average tare
(for testing prepackages mode CPG)
Clearing an editing field
Screen keyboard on / off
Reading a printout template from a *.lb file
(active after connecting a pendrive)
Saving printout template in a file format *.lb (option enabled
on plugging a portable data storage device to scale port)
Variables for a printout template
One level up
Immediate exit to the main window
12.2. Return to weighing
Changes made to the scale’s settings are automatically saved in the memory
on returning to the main software window. The scale provides two ways of
returning to the main window:
• By pressing
key for a few times until returning to the main window,
key in the top bar, which causes immediate returning to
• By pressing
displaying the main window.
13. WEIGHING
Put a load on the weight pan. When pictogram
indication is ready to read.
is displayed the
Caution:
A weighing can be saved after stabilising a measurement (pictogram
40
).
13.1. Conditions of operational use
In order to assure a long term operating period with appropriate
measurements following principles should be adhered to:
• Avoid applying mechanical shocks to the weight pan:
• Loads should be placed in the centre of the pan (eccentric errors
are outlined in PN-EN 45501 chapter 3.5 and 3.6.2):
• Do not apply concentrated forces (all load in one point):
• Avoid side loads, particularly side strokes:
41
13.2. Zeroing
In order to zero the indication choose a platform on the touch panel and
. After zeroing is performed the indication is equal zero and
press
and
.
following symbols usually appear:
Zeroing is possible only when the indication is stable.
Caution:
Zeroing is possible only within ±2% of full range around zero. If zeroing value
is not within ±2% of maximal capacity the following message will be displayed:
13.3. Tarring
In order to tare the scale choose a platform on the touch panel if necessary,
. You will see the indication
put a package on the pan and press
.
equal zero and following symbols usually appear: Net and
After placing a load on the weight pan net mass will be shown. Tarring is
possible within the whole range of the scale. After unloading the pan the
display shows the tarred value with minus sign.
You can also inscribe tare values to the product database. Every product has
a field “Tare”. In that case tare is automatically set to this value after selecting
the product.
Caution:
Tarring cannot be executed when a negative or zero value is being
displayed. In such case the following message will be displayed:
42
13.4. Inscribing tare
It is possible to inscribe a tare value.
Procedure:
• While in any work mode press
is displayed,
• Inscribe tare and press
, then the screen keyboard
,
• The program returns to weighing and the and the display shows
the entered value with the „–” sign provided there was zero before
on the display.
13.5. Weighing for dual range scales
Switching between the I range and the II range happens automatically
(exceeding Max of the I range).
Weighment in the second range is signalled by a pictogram in the top left
corner of the display
. Then weighment is done with the accuracy
)
of the II range to the moment of returning to zero (autozero range
where the scale switches back to the I range.
Switching between the II range and I range is automatic both in the
switching point the autozero zone. While in AUTOZERO – pictogram
appears. Then pictogram
is off and a scale returns to weighing in the
I range.
43
13.6. Toggling between weighing units
Operators can change the weight unit in two ways:
• Pressing the unit symbol on the screen,
• Pressing formerly defined button <
Change unit>.
Possible selection:
•
•
•
•
•
•
gram [g]
kilogram [kg]
carat [ct]
pound [lb]
ounce [oz] *
Newton [N] *
*) – weighing unit inaccessible in a verified scale
Caution:
1. The user can also declare the start unit and determine two custom
weighing units (user defined) – see point 20 of this user manual;
2. The procedure of attributing functions to buttons is described in ch.
17.2 of this manual.
14. SCALE PARAMETERS
Users can set the scale according to the ambient conditions (filtering level)
or own needs (autozero) and set the LO threshold for minimum load that
enables operation of some functions. This parameters are placed in
<
Weighing>.
In order to enter submenu <
„
Weighing>, press
and then:
Weighing”.
Caution:
Weighing parameters are directly related to a specific weighing platform,
so at the beginning the weighing platform should be selected for which
we want to set parameters.
44
Inventory of scale parameters:
Median Filter
Filter
Autozero
LO Threshold
Last digit
14.1. Median filter
The median filter is intended for eliminating short-lasting mechanical shocks.
Procedure:
• Enter <
<
Weighing> according to ch. 14 of the manual, select
Median Filter> and then set an appropriate value.
Accessible settings:
None - median filter is off
0.5, 1, 1.5, 2, 2.5 - filtering level to choose
14.2. Filter
This filter is intended to suppress continuous mechanical vibrations at the
cost of stabilization time.
Procedure:
• Enter <
<
Weighing> according to ch. 14 of the manual, select
Filter> and then set an appropriate value.
Accessible settings:
None, V.Fast, Fast, Average, Slow.
45
Caution:
The higher filtering level the longer stabilization time.
14.3. Autozero
The autozero function has been implemented in order to assure precise
indications. This function controls and corrects „0” indication.
While the function is active it compares the results continuously with
constant frequency. If two sequentional results differ less than the declared
value of autozero range, so the scale will be automatically zeroed and the
and
will be displayed.
pictograms
If AUTOZERO is disabled zero is not corrected automatically. However,
in particular cases, this function can disrupt the measurement process e.g.
slow pouring of liquid or powder on the weighing pan. In this case, it is
advisable to disable the autozero function.
Procedure:
• Enter <
<
Weighing> according to ch. 14 of the manual, select
Autozero> and then set an appropriate value.
Accessible settings:
-
Autozero off
Autozero on
14.4. Minimum weight for different functions (LO)
Parameter <LO THRESHOLD> is associated with automatic weighing.
Next weighing will not be saved until the indication goes under the
THRESHOLD LO (net).
Procedure:
• After entering <
Threshold Lo> according to ch. 14 of this manual
a keyboard is displayed,
• Inscribe LO and confirm by pressing
46
.
14.5. Last digit
The last digit option <
Last digit> is to switch off the last digit of
measured mass indication – the measurement is carried out with decreased
accuracy.
Procedure:
• Enter group of parameters <
Weighing> in accordance with ch.
14 of this user manual, select parameter <
its desired value.
Last digit> and set
Accessible settings:
Always
Never
When stable
-
Last digit always visible
Last digit always switched off
Last digit visible only on stable indication of mass
15. COMMUNICATION
The scale can communicate with external devices via different ports:
•
RS232 (1),
•
RS232 (2),
•
Ethernet,
•
Tcp.
The communication can be configured in parameters’ group
<
Communication>.
In order to enter <
„
Communication>, press
Communication”.
47
and then:
15.1. RS 232 settings
Procedure:
• Enter <
Communication> according to ch.15 of the manual, select
<
RS232 (1)> or <
value.
RS232 (1)>, and then set an appropriate
For RS 232 following parameters are accessible:
•
•
•
•
Baud Rate
Data bits
Stop Bit
Parity
- 4800, 9600, 19200, 38400, 57600, 115200 bit/s
- 5, 6, 7, 8
- No, 1, 1.5, 2
- No – Odd – Even – Mark – Space
15.2. ETHERNET setting
Procedure:
• Enter <
select <
Communication> according to ch.15 of the manual,
Ethernet> and then set an appropriate value.
Following settings are accessible for Ethernet:
•
•
•
•
•
•
DHCP
IP Address
Subnet Mask
Default gateway
DNS
MAC Address
Yes –
No
- 192.168.0.2
- 255.255.255.0
- 192.168.0.1
- 192.168.0.1
- ---
Caution:
1. The above settings are presented for information purpose only.
Transmission parameters have to be selected in accordance with
client’s local network settings.
2. Parameter <MAC Address> is automatically assigned to a device
and it is has <Read only> Attribute.
48
3. In case of declaring the <DHCP> parameter to value
and on device
restart, the other transmission parameters have <Read only> attribute.
• After making changes press
key, then a new message is displayed:
<Restart to apply the changes>,
• Go back to weighing and restart the device.
15.3. TCP protocol setting
TCP (Transmission Control Protocol) is a protocol for communication
between two computers. It operates in mode client-server. Server awaits
on connection iniciation on a specified port while client initiates connection
to the server. Scale software allows setting the port for the „Tcp” protocol.
Procedure:
• Enter <
Communication> parameter group as described
in chapter 16 of the manual,
Tcp /
Port” then you will see window <Port>
• Select: „
with the screen keyboard,
• Enter the required number and press
.
Caution:
The number of TCP port in RADWAG instruments is set to default value:
4001.
16. DEVICES
16.1. Computer
The scale can cooperate with a computer. Active connection scale-computer
is signalled by icon
in the top bar of the main window. In submenu
<
Computer> some settings needs to be configured for cooperation
with computers.
49
Enter submenu <
Computer>, press
„
Computer”.
Devices /
and then:
16.1.1. Computer port
Procedure:
• Enter parameters’ group <
manual,
Computer /
• Select „
Devices> according to ch. 16 of this
Port” and then set the appropriate option.
The scale can communicate with a computer via following ports:
• RS232 (1),
• RS232 (2),
• Tcp.
16.1.2. Computer address
Procedure:
• Enter <
Devices> parameter group as described in chapter
16 of the manual,
Computer /
Address” then the window <Address>
• Choose „
with the screen keyboard appears,
• Enter the required address and confirm it by pressing
.
16.1.3. Continuous transmission
Users can enable continuous transmission from the scale to a computer.
Setting parameter <
Continuous transmission> starts subsequent
sending data from <
Weighing Printout Template> set in submenu:
„Setup /
Template”.
Devices /
Computer /
50
Weighing Printout
Procedure:
• Enter parameters’ group <
manual,
Computer /
• Choose „
set an appropriate value.
Devices> according to ch. 16 of this
Continuous transmission” and then
Accessible settings:
-
Continuous transmission off
Continuous transmission on
16.1.4. Weighing printout template
Users in parameter <
Weighing Printout Template> can define
variables included in the printout from the scale to a computer.
Procedure:
• Enter <
Devices> parameter group as described in chapter
16 of the manual,
Computer /
Weighing Printout Template” then
• Choose „
the editing field <Weighing Printout Template> with the screen
keyboard appears,
• Modify the template if necessary and confirm the changes by pressing
.
Caution:
There are additional buttons in the bottom line of the screen keyboard.
They can be used while modifying a printout template.:
Screen keyboard on/off
Reading a printout template from a *.lb file (button active while
connecting a USB pendrive)
Saving printout template in a file format *.lb (option enabled
on plugging a portable data storage device to scale port)
List of variables for printout templates (see the list in APPENDIX A
of this manual)
51
Clear the editing field
16.1.5. Cooperation with “E2R System”
Scales can cooperate with computer software „E2R System” that is
a modular system for complex production supervising by monitoring
of weighments processes. In order to allow the cooperation with
„E2R System” enable parameter <
E2R System>.
Caution:
E2R System> can be activated by an authorized
The parameter <
service or the manufacturer.
Procedure:
• Enter <
Devices> parameter group as described in chapter
16 of the manual,
• Choose „
Computer /
E2R System /
and then set an appropriate value.
System is active”
Accessible settings:
-
System is not active
System is active
• If during cooperation with <
E2R System> product selection lock
is required for operators, go to parameter <
products> and set its value to
Lock selecting
.
• Active connection with the computer software is indicated by additional
information displayed in the top bar of the software:
52
Where:
- parameter active <
System is active>
- active connection with a computer software
16.2. Printer
In <
•
•
•
•
Printer> submenu users can:
Set communication with a printer,
Set code page of a printer,
Set templates of printouts,
Activate/deactivate printout of demanded standards.
To enter <
Printer>, press
and then: „
Printer”
16.2.1. Printer port
Procedure:
• Enter <
Devices> parameter group as described in chapter 16
of the manual, choose „
appropriate option.
Printer /
Port” and then select an
Printers can be attached to:
•
•
•
•
RS232 (1),
RS232 (2),
USB,
Tcp.
16.2.2. Printer code page
Procedure:
• Enter parameters <
of the manual,
Devices> as described in chapter 16
53
• Choose „
Printer /
will be displayed,
Code Page” then the screen keyboard
• Write the required code page and confirm by pressing
.
Caution:
The default value is 1250 – code page for Middle-East Europe.
16.2.3. Templates for printouts
Enter <
Printouts> to define printout templates.
Procedure:
• Enter parameter group <
Devices> as described in chapter
16 of the manual, then choose „
Printer /
Printouts”,
• After editing a template a memo box with the default content and the
screen keyboard,
• Modify the template according to your requirements and confirm it by
pressing
.
Caution:
There are additional buttons in the bottom line of the screen keyboard.
They can be used while modifying a printout template.:
Screen keyboard on/off
Reading a printout template from a *.lb file (button active while
connecting a USB pendrive)
Saving printout template in a file format *.lb (option enabled
on plugging a portable data storage device to scale port)
List of variables for printout templates (see the list in APPENDIX A
of this manual)
Clear the editing field
54
Default printouts’ settings:
Weighing Printout Template
{0}
Weighments Report Printout Template
See ch. 35.4.2
Cumulative Printout Template
N={15} SUM={16}
Cumulative of Cumulative Printout Template
N2={20} SUM2={21}
Dosing Report Printout Template
See ch. 28.7
Formulation Report Printout Template
See ch. 29.5
Printout Template of an Ingredient in a
Formulation
CPG Report Printout Template
(Control of Packaed Goods)
-
Average Tare Report Printout Template
(Control of Packaed Goods)
See ch. 30.13
Density Printout Template
See ch. 31.4
Enter Ticket Printout Template
See ch. 33.5
Exit Ticket Printout Template
See ch. 33.5
Control Weighing Ticket Printout Template
See ch. 33.5
Vehicle Scales Report Printout Template
See ch. 33.5
Product Printout Template
{50}
{51}
Operator Printout Template
{75}
{76}
Client Printout Template
{85}
{86}
Warehouse Printout Template
{130}
{131}
Package Printout Template
{80}
{81}
{82}
55
See ch. 30.14
Vehicle Printout Template
{210}
{211}
Adjustment report printout template
See ch. 22.3
16.3. Printouts activation
<
Printouts activation> submenu enables activation/deactivation of
demanded standards printout.
Procedure:
• Enter <
Devices> parameters group, following point 16 of this
manual select „
Printer /
Printouts activation”,
• Activate/deactivate demanded standard intended for printout.
Where:
- Inactive standard
- Active standard
16.4. Barcode scanner
The balance allows for cooperation with a barcode scanner. The scanner
can be used for quick search of:
•
•
•
•
•
•
•
•
•
Products,
Clients,
Packages,
Warehouses,
Dosing process,
Formulation,
Universal variables,
Lot number,
Batch number.
Configuration of communication can be configured in:
“
/
Devices /
Barcode reader”.
56
Caution:
Communication> set the baud rate (default 9600b/sec).
In submenu <
The detailed description of cooperation scale – barcode scanner can be
found in APPENDIX F in this manual.
16.4.1. Port for barcode scanner
Procedure:
• Enter <
„
Devices> according to ch.16 of the manual, choose
Barcode reader /
Port” and then set the appropriate value.
Barcode scanners can be connected to:
• RS232 (1),
• RS232 (2),
• USB.
16.4.2. Prefix / Suffix
Users can edit a prefix <
Prefix> or / and suffix <
Suffix> in order
to adjust the program to accept transmission frames from the scanner.
Caution:
A special protocol is required in order the code be received by RADWAG
equipment. It is required to program an appropriate prefix and suffix.
Prefix – one byte 01 hexadecimally, suffix one byte 0D hexadecimally.
The detailed description of cooperation scale – barcode scanner can
be found in APPENDIX F in this manual.
Procedure:
• Enter <
Barcode Scanner> according to ch.16.3 of the manual,
• Chose parameter <
Prefix> and then enter, using the screen
keyboard, a required value (hexadecimal) and confirm it by pressing
.
• Chose parameter <
Suffix> and then enter, using the screen
keyboard, a required value (hexadecimal) and confirm it by pressing
.
57
16.4.3. Field selection
This option is connected with selecting data which the program will search
after reading a barcode.
Procedure:
• Enter <
Devices> according to ch.16 of the manual,
• Chose „ Barcode Scanner /
the following list will be displayed:
Field selection” and then
Product
Client
Package
Source warehouse
Target warehouse
Dosing process
Formulation
Universal variable
Lot number
Batch number
• Select an item and then you can edit following parameters:
Filtering
Declaring an item, according to which searching
is supposed to be performed
Offset
Setting the first significant character in code from
which the comparison with items is performed during
searching. All preceding characters are skipped
Code length
Setting the number of characters to be taken for
the search procedure counting form Offset
Start marker
Start marker declaration
End marker
End marker declaration
58
Caution:
An exception from the above is <
additional submenu <
Formulation>, which features an
Ingredient> containing the following parameters:
Filtering
Declaring an item, according to which searching
is supposed to be performed (options: None, Code)
Offset
Setting the first significant character in code from
which the comparison with items is performed during
searching. All preceding characters are skipped
Code length
Setting the number of characters to be taken for
the search procedure counting form Offset
Start marker
Start marker declaration
End marker
End marker declaration
Inventory of items to be selected for filtering:
Record
Item for filtering
Product
None, Name, Code, EAN Code
Client
None, Name, Code
Package
None, Name, Code
Source warehouse
None, Name, Code
Target warehouse
None, Name, Code
Dosing process
None, Name, Code
Formulation
None, Name, Code
Universal variable
None, Code
Lot number
No,
Yes
Batch number
No,
Yes
16.4.4. Test
Operators, using parameter <
to the scale works properly.
Test>, can verify if a barcode connected
59
Procedure:
• Enter submenu <
manual,
Barcode Scanner> according to ch. 16.3 of this
Test> window <Test> is opened
• After entering parameter <
with an ASCII text box and HEX (hexadecimal) field,
• After scanning the code is entered to the ASCII field and HEX filed
and at the bottom of the window a test result is displayed.
When:
• <Prefix> and <Suffix> declared in settings are the same as
<Prefix> and <Suffix> in the read code then the test result is
<Positive>,
• <Prefix> and <Suffix> declared in settings are not the same as
<Prefix> and <Suffix> in the read code then the test result is
<Negative>.
16.5. Transponder card reader
Selecting operator (Loggingg in) can be done in two ways:
• Typing a password on a keyboard,
• Approaching a transponder card to the reader.
The card needs to be registerd first.
Caution:
In case of problems with reading transponder cards check the submenu
<
Communication> and set appropriate baud rate (default 9600b/s).
16.5.1. Com port for transponder card readers
Procedure:
• Enter group of parameters <
Devices> according to ch. 16
of this manual, select „ Transponder cards reader /
and set appropriate option.
60
Port”
The scale can communicate with the reader via following ports:
• RS232 (1),
• RS232 (2).
16.5.2. Procedure of attributing the card number to an operator
To use a transponder card to log on an operator the card needs to be
ascribed to the operator in the database of operators.
Procedure:
• Connect the transponder card reader to the required communication
port (RS 232 (1) or RS 232 (2)),
• Choose a communication port for the reader (see ch. 16.4.1 in this
manual),
Communication> set the baud rate to the same
• In submenu <
as in the reader (default 9600b/s),
• Enter the database of operators and edit the selected operator going
to the field <
Card Number>,
Card Number> you will see the editing
• After entering the field <
field <Card Number> with the screen keyboard,
• Having approached the card to the reader the program automatically
displays in editing field <Card Number> the number of read card,
and return to weighing.
• Confirm the number by pressing
16.6. Additional display
16.6.1. Additional display port
Procedure:
• Enter parameters group <
Devices> according to ch. 16
Additional display /
of this manual, select „
and then choose an appropriate option from the list.
61
Port”
Communication with additional displays can be performed via following
ports:
• RS232 (1),
• RS232 (2),
• Tcp.
16.6.2. Communication protocol frame
Scale with following displays:
• WD display,
• WWG display.
To start cooperation of scale with displays go to parameter
<
Sample> and define an appropriate communication protocol.
Procedure:
• Enter parameters’ group <
manual,
Devices> according to ch. 16 of this
Additional display /
Sample” then the editing field
• Choose „
<Sample> with the screen keyboard appears,
• Inscribe the required frame template using the screen keyboard or
.
choose the it from the list after pressing
Specified templates for displays:
{141}
-
Protocol template for WD displays
{142}
-
Protocol template for WWG display
.
• Confirm the changes by pressing
Caution:
In default settings parameter <
(display WD series).
Sample> has ascribed {141}
62
16.7. Advanced settings
<
Advanced settings> submenu enables declaration of printers
cooperation with scales, cooperation of 1-3 printers may be declared.
Procedure:
• Enter parameters’ group <
manual,
Devices> according to ch. 16 of this
Advanced settings /
Number of printers”, next set
• Select „
demanded number of printers (1, 2 or 3),
Devices> parameters group will automatically be extended with
• <
new positions.
17. DISPLAY
Users can adapt the main display and visible information to their needs.
All parameters of the display can be found in the parameters’ group
<
Display>. Entering <
• Pressing
Display> can be made in two ways:
and then: „
Display”,
• Direct pressing the workspace area of the main display (does not apply
to the “home screen” and “settings display” of the CPG (Control of
Prepacked Goods mode).
Inventory of parameters of the main display:
Text information
Buton functions *
Show all platforms
Bargraph
*) – In case of the working mode CPG, the function keys are separately defined for:
• Home screen,
• Settings screen,
• Process screen.
63
17.1. Text strings
In <
Text information> users can set:
Display template
Data displayed in the workspace.
Detailed description in point 17.1.1.
Left displaying template
Right displaying template
Font
Submenu on font settings.
Type
Changing font type for text data
displayed in the workspace. Available
fonts: Arial, Courier.
Font size
Declaring font size of text data displayed
in the workspace. Available font size:
Small, Medium, Large.
Bold font
Bolded font for text data displayed in the
worspace.
Tilt
Text data in the workspace in italics.
Colour
Font colour for text data in the
workspace. Available in 18 colours
palette.
Background colour
Colour of the workspace background.
Available in 18 colours palette.
Set Default
Default settings for “Text data”
submenu.
17.1.1. Display templates
The main window contains a workspace which displays optionally configured
data specified for each working mode.
The workspace comprises three displaying templates:
• Displaying template,
• Left displaying template,
• Right displaying template.
64
The upper section of the workspace comprises a graphic information on which
of the three templates is enabled. Changing of the template is carried out by
draging the workspace to the right or left.
Change of the displaying template is carried out in submenu:
“
/
Display /
Text information”.
Procedure:
• While in an optional weighing mode enter submenu <
in accordance with point 17 of this user manual,
Display>
Text information> and then a desired displaying
• Seelct option <
template, which is followed by displaying an editing field with is default
content and an on-screen keyboard,
• Edit the content of the selected displaying template and accept it by
pressing
key.
Caution:
There are additional buttons in the bottom line of the screen keyboard.
They can be used while modifying a display template. :
Screen keyboard on/off
Reading a template from a file with format *.lb (option enabled
on plugging a portable data storage device to scale port)
Saving printout template in a file format *.lb (option enabled
on plugging a portable data storage device to scale port)
Selecting variables for a template from a list (list of variables
is provided in the APPENDIX A of this user manual)
Clear the editing field
65
Default settings of a displaying template in each of the working
modes:
CPG
Product: {50}
Code: {51}
Weighing:
{40:Product:,-15}{50}
{40:Tare:,-15}{9}{11}
{40:Gross:,-15}{8}{11}
{40:Number:,-15}{15}
{40:Total:,-15}{16}{11}
Parts counting:
{40:Product:,-15}{50}
{40:Sample weight:,-15}{35}{11}
{40:Net:,-15}{7}{11}
{40:Tare:,-15}{9}{11}
Percent setup:
{40:Product:,-15}{50}
{40:Sample weight:,-15}{36}{11}
{40:Net:,-15}{7}{11}
{40:Tare:,-15}{9}{11}
Dosing:
Dosing process: {175}
Formulation:
{220}
{40:Ingredient:,-12}{230}/{231}[{226}]
{40:Portion:,-12}{228}{11}/{227}{11}
{40:Charge:,-12}{232}/{233}
{40:Completed:,-12}{225:F0}
Density:
Product: {50}
Animal weighing:
{40:Tare:,-15}{9}{11}
{40:Gross:,-15}{8}{11}
17.2. Function keys
In submenu <
Actions> users can set actions following keys:
function keys,
screen keys,
proximity sensors.
Function keys and proximity sensors are programmable specifically for each
working mode. If a button has been attributed then it is equal to activating a
function. If no function is assigned to a button or sensor then it remains
inactive.
66
Procedure:
• While in optional working mode go to submenu <
in accordance with point 17 of this user manual,
Display>
Button functions> and choose a required setting for
• Choose <
a choosen button: F1, F2, F3, 9 screen buttons or proximity sensors.
Default functions of buttons for working mode CPG:
Home screen
Settings screen
Process screen
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Set control
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 7
- Return to home screen
Screen button 8
- Start
Screen button 9
- Start
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 6
- Data on control in
progress
Screen button 7
- Change: Workspace /
chart
Screen button 8
- Stop
Screen button 9
- Stop
67
Default functions of buttons for other working modes:
Weighing:
Parts counting:
Percent setup:
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Set MIN and MAX
Screen button 3
- Choose package
Screen button 4
- Edit lot number
Screen button 5
- Edit batch number
Screen button 6
- C Statistics : Zero
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Choose package
Screen button 3
- Insert unit mass
Screen button 4
- Estimate unit mass
Screen button 5
- Ascribe standard
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Choose package
68
Dosing:
Recipes:
Density:
Screen button 3
- Insert mass of sample
Screen button 4
- Estimate mass of sample
F1 Button
- Select dosing process
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Select dosing process
Screen button 3
- Start
Screen button 4
- Stop
Screen button 5
- Emergency stop
F1 Button
- Select formulation
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Select formulation
Screen button 3
- Start
Screen button 4
- Stop
Screen button 5
- Emergency stop
Screen button 6
- Previous component
Screen button 7
- Next component
Screen button 8
- Give mass
Screen button 9
- Edit lot number
F1 Button
- Choose product
69
Animal
weighing:
Vehicle scale:
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Determine liquid density
Screen button 3
- Determine solid density
Screen button 4
- Stop
F1 Button
- Choose product
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Start
F1 Button
- Choose a vehicle
F2 Button
- Choose client
F3 Button
- Set tare
Screen button 1
- Local parameters
Screen button 2
- Choose transaction
Screen button 3
- Choose transaction
Screen button 4
- Choose product
Screen button 5
- Choose product
Screen button 6
- Choose client
Screen button 7
- Choose client
Screen button 8
- Stop
Screen button 9
- Stop
70
Caution:
The list of functions that can be attributed to keys or buttons is listed
in APPENDIX B of this manual.
17.3. Displaying platforms
If a scale is equipped with two platforms users can switch between platforms
in three ways:
• By pressing the platform number on the scale screen,
• By pressing a formerly defined button <
Change platform>.
• By activating in parameters all platforms that will be separately
placed in the main window of the program. In that case platforms
can be activated by pressing the area of this platform.
Caution:
The procedure of attributing functions to buttons is described in ch. 17.2
of this manual.
To activate all platforms press
Display /
-
, choose: „
Parameters /
Show all platforms”, and set appropriately.
Displaying all platforms disabled
Displaying all platforms enabled
17.4. Bargraph
A bargraph is a typical visualization procedure. It helps in quick weighing.
It requires less concentration to read if a weighing is between minimum
and maximum thresholds.
17.4.1. Bargraph type
To see the bargraph on the screen enable it in parameters.
Procedure:
• Enter submenu “
Display /
point 17 of this user manual,
Bargraph” in accordance with
71
• Select option <
Bargraph type> and set desired bargraph type.
Accessible bargraphs:
•
•
•
•
•
Quick weighing,
None (Bargraph is not displayed),
Signalling checkweighing ranges,
Linear,
Control *.
*) – Applies to the CPG mode only. In the CPG mode other bargraph types
are not accessible.
17.4.2. Bargraph “Quick weighing”
Setting of bargraph type “Quick weighing” are accessible in submenu
„
Display /
Bargraph /
MIN, MAX thresholds working
mode
OK threshold working mode
Quick weighing”:
Stable – signalling of MIN, MAX thresholds is
previewed on exceeding LO threshold and
reaching stable measurment result;
Unstable – signalling of MIN, MAX thresholds
is previewed on exceeding LO threshold
Stable – signalling of OK thresholds is
previewed on exceeding LO threshold and
reaching stable measurment result;
Unstable – signalling of OK thresholds is
previewed on exceeding LO threshold
Min threshold signalling colour
Colour selection for signaling MIN threshold.
18 colours palette available.
OK threshold signalling colour
Colour selection for signaling OK threshold.
18 colours palette available.
Max threshold signalling colour
Colour selection for signaling MAX threshold.
18 colours palette available.
Gradient
Enabling / Disabling filling effect “Gradient”
type.
Background colour
Colour selection of a bargraph background.
18 colours palette available.
Frame colour
Colour selection of bargraph frame.
18 colours palette available.
72
Means of operation:
• The bargraph consists of 8 red fields and three green fields.
• The green fields signal weighments between MIN and MAX
threshold, where:
MIN = the minimum threshold of acceptable weighment - LO
MAX = the maximum threshold of acceptable weighment - HI
• If a measurement is over the MIN (to the value of 1/3 of MIN-MAX) the
green field with a triangle on the left is visible. If the measurement is
between 1/3 and 2/3 of MIN-MAX the rectangular green field is visible.
If the measurement is between 2/3 of MIN-MAX and MAX a green field
with a triangle on the right is visible.
• If the mass value is below the MIN threshold red fields with red arrows
on the left are visible. The lower mass value the more red arrows are
visible.
• If the mass value is over the MAX threshold red fields with red arrows
on the right are visible. The higher mass value the more red arrows
are visible.
Thresholds MIN and MAX are on the borders between red and green
fields.
17.4.3. Bargraph “Signalling of checkweighing ranges”
Settings of “Signalling checkweighing ranges” bargraph are accessible
Display /
in submenu “
checkweighing ranges”:
Bargraph /
MIN, MAX thresholds working
mode
“Signalling
Stable – signalling of MIN, MAX thresholds is
previewed on exceeding LO threshold and
reaching stable measurment result;
Unstable – signalling of MIN, MAX thresholds
is previewed on exceeding LO threshold
73
OK threshold working mode
Stable – signalling of OK thresholds is
previewed on exceeding LO threshold and
reaching stable measurment result;
Unstable – signalling of OK thresholds is
previewed on exceeding LO threshold
Min threshold signalling colour
Colour selection for signaling MIN threshold.
18 colours palette available.
OK threshold signalling colour
Colour selection for signaling OK threshold.
18 colours palette available.
Max threshold signalling colour
Colour selection for signaling MAX threshold.
18 colours palette available.
Gradient
Enabling / Disabling filling effect “Gradient”
type.
Background colour
Colour selection of a bargraph background.
18 colours palette available.
Frame colour
Colour selection of bargraph frame.
18 colours palette available.
Means of operation:
• This type of bargraph comprises one green and 2 red fields.
• The left red field – signals that the load on the pan is lower than
the minimum weighing threshold (Min threshold);
• The central green field – signals that the load on the pan is within the
set required interval for the weighed product (OK value between Min
and Max thresholds);
• The right red field – signals that the load on the pan is greater than
the maximum weighing threshold (Max threshold).
17.4.4. Bargraph type: „Linear”
Settings of “Linear” bargraph are accessible in submenu
“
Display /
Bargraph /
Linear”:
74
Min threshold signalling colour
Colour selection for signaling MIN
threshold. 18 colours palette available.
OK threshold signalling colour
Colour selection for signaling OK
threshold. 18 colours palette available.
Max threshold signalling colour
Min Max range background colour
OK range signalling colour
Colour selection for signaling MAX
threshold. 18 colours palette available.
Background colour selection for MIN,
MAX range of the bargraph.
17 colours palette available.
Background colour selection for OK
range of the bargraph.
18 colours palette available.
Enabling / Disabling filling effect
“Gradient” type.
Gradient
Means of operation:
The bar graph represents in a linear way the measuring range of a scale.
In addition, the bar graph can indicate weighing thresholds MIN, MAX,
if they have been determined:
• Signalization of mass below the value set in MIN threshold:
• Signalization of mass within MIN and MAX values of thresholds:
• Signalization of mass exceeding the value set in MAX threshold:
17.4.5. “Control” bargraph
The “Control” bargraph is operated only in the working mode <
75
CPG>.
Means of operation:
The bargraph features signalization points of:
•
•
•
•
•
•
Nominal mass Qn declated for a product,
MIN, MAX thresholds – if such are declared,
Mass value for Qn-T,
Mass value for Qn-2T,
Mass value for Qn+T,
Mass value for Qn+2T.
Where:
Qn – nominal mass
T – T error
2T – double T error
• Signalling mass below set value of Qn-2T:
• Signalling mass between the values of Qn-2T and Qn-T:
• Signaling mass between the value of Qn-T and Qn+T:
The bargraph field between the above values gets automatically rescaled
and it is additionally marked by a “magnifier” pictogram visible in
graph’s left corner.
• Signaling mass between the value of Qn+T and Qn-2T:
76
• Signaling mass above the set value of Qn+2T:
Caution:
In case of additional declaring the values for MIN, MAX limits, the “control”
bargraph refers to the MIN, MAX limits and the nominal mass, but without
displaying the errors for T and 2T.
Qn
MIN
MAX
18. INPUTS / OUTPUTS
Scale are equipped with 4 inputs / 4 outputs. To adjust software to the users
needs configure inputs outputs in the submenu
in the submenu <
•
•
Inputs / Outputs>:
indicator inputs,
indicator outputs.
In order to enter submenu <
and then: „
Inputs / Outputs>, press
Inputs / Outputs”.
18.1. Configuration of inputs
Procedure:
• Enter <
Inputs / Outputs> according to ch. 18 of this manual,
• Choose <
Inputs> and enter the selected input you will see
a list of functions to ascribe,
• Choose the required function from the list and return to weighing
saving the changes according to ch. 12.2 of this manual.
Caution:
The list of functions to ascribe to inputs are described in APPENDIX B
of this manual. By default inputs have no ascribed functions <None>.
77
18.2. Configuration of outputs
Ascribing a function to the output enables the output at the same time.
If an output has no ascribed function it is disabled.
Procedure:
• Enter <
Inputs / Outputs> according to ch. 18 of this manual,
• Choose <
Outputs> and enter the required output, then you
will see the list of functions:
None
Output disabled
Stabile
Stable weighing result over LO threshold value
MIN stable
Stable weighing result below the MIN threshold
MIN non-stable
Non-stable weighing result below the MIN threshold
OK stable
Stable weighing result between MIN and MAX
thresholds
OK non-stable
Non-stable weighing result between MIN and MAX
thresholds
MAX stable
Stable weighing result over the MAX threshold
MAX non-stable
Non-stable weighing result over the MAX threshold
Zero
Stable weighing result zero net
Confirmation of
cycle completion *
Signal that confirms that a cycle of dosing has been
completed (the defined amount)
Zero
Zero weighing result („zero” indication)
! OK unstable
Unstable weighing result ouside OK threshold
! OK stable
Stable weighing result ouside OK threshold
*) Not applicable to „Standard” software.
• Choose the required function from the list and return to weighing
saving the changes according to ch. 12.2 of this manual.
Caution:
By default all outputs have no function attributed – setting <None>.
78
19. AUTHORIZATION
The submenu <
Authorization> is accessible only while being logged
in as the Administrator. In this group of parameters access levels can be
outlined.
To enter submenu <
„
Authorization>, press
and then:
Authorization”.
19.1. Anonymous Operator
The program allows to attribute the authorization access level to an operator
who does not perform the log-in procedure (anonymous operator).
Procedure:
•
Enter <
Authorization> according to ch. 19 of this manual,
choose <
Anonymous Operator>, and then set the
authorization access level.
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
19.2. Date and time
Default settings allow a logged-in Administrator to change settings of date
and time. Software however allows to change the access level to this option:
Date and time>.
<
Procedure:
•
Enter parameters’ group <
Authorization> according to ch.
19 of the manual, choose <
the parameter.
Date and time>, and then set
79
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
Caution:
Setting <None> allows free access to settings of date and time
(without the need of Loggingg in).
19.3. Printouts
Default settings of the scale allows a logged on Administrator to edit
printout templates. Software allows to change the access level to option
Printouts>.
<
Procedure:
•
Enter parameter group <
Authorization> according to ch. 19
of this manual, choose <
Printouts>, and set appropreately.
Access levels to printouts that can be set:
None, Operator, Advanced Operator, Administrator.
Caution:
When you choose setting <None> printout templates can be changed
even without Loggingg on.
19.4. Databases edition
It is possible to set the access levels to the following databases:
•
•
•
•
•
•
•
•
Database of Products,
Database of Clients,
Database of Formulations,
Database of Dosing processes,
Database of Packages,
Database of Warehouses,
Database of Vehicles,
Database of Labels,
80
•
•
•
•
Database of Images,
Database of Identification processes,
Weighing counter,
Delete older data.
Procedure:
•
Authorization> according to ch. 19
Enter parameters’ group <
of the manual, choose <
parameter.
Databases edition>, and then set the
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
Caution:
Setting <None> allows free access to settings of date and time
(without the need of Loggingg in).
19.5. Delete older data
Scales default settings allow for cancellation of older data kept in <
Reports> submenu. To do it the user must log in as an Advanced Operator
(NOTE: the software allows for changing the access level to <
older data> option).
Delete
Procedure:
•
Enter parameters’ group <
Authorization> according to ch. 19
of the manual, choose: „
Databases edition /
data”, and then set the parameter.
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
81
Delete older
19.6. Set element from the database
The user may set authorization levels for scales operator when it comes to
selection of particular database positions by the operator:
•
•
•
•
•
•
•
•
•
•
Products,
Clients,
Formulas,
Dosing processes,
Packaging,
Warehouse,
Vehicles,
Identification processes,
Lot number,
Batch number.
Procedure:
•
Enter parameters’ group <
Access level> according to ch. 19 of this
manual, select <
Set element From the database> and then set the
appropriate option.
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
Caution:
Setting <None> allows free access to selection of a particular database
position (without the need of logging in).
19.7. CPG
The user may set authorization levels when it comes to modification of the
following local parameters values of <
•
•
•
•
•
•
CPG> operating mode:
Batch number,
Number of batches,
Number of samples,
Average tare estimation,
Tare,
Density.
82
Procedure:
•
Enter parameters group <
manual, select <
Access level>, according to ch. 19 of this
CPG> and then set a right option.
Accessible authorization levels:
None, Operator, Advanced Operator, Administrator.
20. UNITS
Scale, in submenu <
•
•
•
•
Units> enables selecting:
Declaring accessibility of the weighing untis,
Declaring the start unit,
Determining two user defined units (custom units),
Changing the value of g-cor (the value of gravitational acceleration
force).
To enter submenu <
Units>, press
and then: „
Units”.
20.1. Units accessibility
Submenu <
Accessibility> enables declaring weighing units that should
be accessible for selecting in the weighing window after pressing the weighing
unit pictogram.
Procedure:
• Enter submenu <
manual,
Units> in accordance with ch. 20 of this user
Accessibility> which opens a window with a list
• Select option <
of available weighing units with their accessibility attribute.
Where:
- Weighing unit enabled
- Weighing unit disabled
83
•
Set required accessibility criterion for the weighing units and exit to
weighing mode.
20.2. Start unit
Procedure:
• Enter submenu <
manual,
Units> in accordance with ch. 20 of this user
Start units> and choose a start unit from
• Select option <
displayed list of available weighing units.
Possible selection:
•
•
•
•
•
•
•
none
gram [g]
kilogram [kg]
carat [ct]
pound [lb]
ounce [oz] *
Newton [N] *
*) – weighing unit inaccessible in a verified scale
• Exit to main menu with procedure of saving changes,
• On restarting the scale, the instrument operates with enabled start unit.
20.3. User defined units
An option only for non-verified scale
Procedure:
• Enter submenu <
manual,
Units> in accordance with ch. 20 of this user
Defined unit 1> and determine the values of the
• Select option <
following parameters:
Multiplier
Multiplier of scale’s adjustment unit
Name
Unit name (Max 3 characters)
84
• Exit to main menu with procedure of saving changes,
• Press symbol of the new weighing unit visible in the weighing window,
which activates list of available weighing units with new custom unit
added at the end of the list.
Caution:
The procedure of defining the second custom unit <
is equal to the procedure described above.
Defined unit 2>
20.4. Acceleration of gravity
Parameter <
Acceleration of gravity> eliminates the changes of
gravitational acceleration force at different latitudes and altitudes in case
of weighing process with application of “Newton” [N] weighing unit.
Procedure:
• Enter submenu <
manual,
Units> in accordance with ch. 20 of this user
Acceleration of gravity> which opens an editing
• Select option <
window < Acceleration of gravity> with a numeric keyboard,
• Insert the new value of acceleration of gravity for the place of use and
accept it by pressing
key,
• Exit to main manu.
21. OTHER PARAMETERS
There is a group of parameters different from others which influence the
operation of the scale. They are gathered in group <
language, beep etc. To enter <
„
Others>, press
Others”.
85
Others> e.g.
and then:
21.1. Languages
Procedure:
• Enter submenu <
choose <
Others> according to ch. 21 of this manual,
Language> and set the parameter.
Accessible languages:
•
Polish, English, German, French, Russian, Spanish, Czech,
Hungarian, Estonian, Latvian, Italian, Greek, Turkish, Thai, China.
21.2. Setting date and time
Users can set date and time that are visible in the main window of the
display. Entering the edit window of date and time can be made in two ways:
• Pressing the field „date and time” in the top bar of the main screen,
• Enter: „
/
Others /
Date and Time /
Set date and time” submenu.
After entering the setting of date and time the screen keyboard appears.
Set year, month, day, hour, minutes and confirm by pressing
.
„
/
Others /
Date and Time” submenu contains additional
functions that serve for defining date and time format:
Icon
Name
Date format
Value
Description
yyyy.MM.dd *
Selection of date format. Possible values:
d.M.yy, d.M.yyyy, d/M/yy, dd.MM.yy,
dd.MM.yyyy, dd.MMM.yyyy, dd/MM/yy,
dd/MM/yyyy, dd-MMM-yy, dd-MM-yy,
M/d/yy, M/d/yyyy, MM/dd/yy, MM/dd/yyyy,
yy/MM/dd, yy-M-dd, yy-MM-dd,
yyyy.MM.dd, yyyy-M-dd, yyyy-MM-dd.
86
Time format
HH:mm:ss **
Selection of time format. Possible values:
H.mm.ss, H:mm:ss, H-mm-ss, HH.mm.ss,
HH:mm:ss, HH-mm-ss, H.mm.ss tt,
H:mm:ss tt, H-mm-ss tt, HH.mm.ss tt,
HH:mm:ss tt, HH-mm-ss tt, h.mm.ss tt,
h:mm:ss tt, h-mm-ss tt, hh.mm.ss tt,
hh:mm:ss tt, hh-mm-ss tt
2013.03.29
14:32:09
Date and time preview, declared formats
taken into account.
*) – For date format: y – year, M – month, d – day
**) – For time format: H – hour, m – minute, s – second
Caution:
Parameter <
Date and Time> is accessible in the scale menu depending
on the authorization access level set in the related parameter.
21.3. Sound signal
Procedure:
• Enter <
Others> according to ch. 21 of this manual, <
and set accordingly.
Beep>
Settings:
None
Buttons
Sensors
All
-
Sound for buttons and proximity sensors disabled
Sound for buttons enabled
Sound for proximity sensors enabled
Sound for buttons and proximity sensors enabled
21.4. Touch panel calibration
Touch panel calibration is required when inappropriate operation is
recognized. E.g. the reaction in a different place than the touching point.
Procedure:
• Enter submenu <
• Select <
appears,
Others> according to ch. 21 of this manual,
Touch Screen Calibration> and then an editing field
87
• Using a thin and soft pointer press (keep pressed for some time)
th
in the point where the cross appears, after indicating the 4 place
.
confirm changes by pressing
21.5. Screen brightness
Scale user can change brightness of the screen in the range between 0%
and 100%.
Caution:
The default screen brightness is set to 90%.
Procedure:
• Enter submenu <
manual,
Other> in accordance with point 21 of this user
• Select parameter <
Screen brightness> which opens an editing
window <Screen brightness> with a visible “slider” and percent value
of set brightness,
• Use the “slider” to set required brightness value and accept it by
key.
pressing
21.6. Cursor
In order to start working with a computer mouse enable parameter <Cursor>.
Procedure:
• Enter <
Others> according to ch. 21 of this manual, choose
parameter <
Cursor> and set an option.
Settings:
- Cursor disabled
- Cursor enabled
88
21.7. Logging in required
<
Logging in required> parameter must be active if a logging operation
is to be carried out by an operator after the device have been turned on.
Procedure:
• Enter submenu <
Others> according to ch. 21 of this manual, select
<
Logging in required> parameter and then set the appropriate
option.
Where:
- Inactive logging required
- Active logging required
21.8. Start logo
Submenu <
Start logo> allows to substitute a “start” graphic file of a
scale with another one located on a memory stick.
Procedure:
• Put a memory stick into USB port of a scale,
• Enter submenu: „
this manual,
• Enter <
Start logo” according to ch. 21 of
Others /
Start logo> to open content of a memory stick main folder,
• Chose the desirable graphic file and wait until scales program
automatically returns to the <
will be displayed.
Start logo> submenu. Chosen graphic
Set Default> option enables the user to get back to the default „Start
<
logo”.
Caution:
Maintained file formats are *.jpg, *.png, with optimal (max.) resolution of
640x480 pixels.
89
21.9. Error information preview time
Submenu <
Error information preview time> enables user to declare
for how long information about errors is to be displayed.
Procedure:
• Enter submenu <
Others> according to ch. 21 of this manual, select
parameter <
Error information preview time> and set the
appropriate option.
Where:
1 [s]
3 [s]
5 [s]
10 [s]
Max
-
Displaying an information about errors for 1 [s]
Displaying an information about errors for 3 [s]
Displaying an information about errors for 5 [s]
Displaying an information about errors for 10 [s]
Displaying an information about errors until it has been
confirmed with
button.
22. USER ADJUSTMENT
An option only for non-verified scale
Scales require to recalculate internal divisions to more suitable ones (e.g.
g, kg etc.). In order to do this they require an adjustment factor. It is adjusted
during the adjustment procedure using a mass standard. Adjustment should
be carried out if weighing a standard mass shows a different mass value.
To enter <
„
User Adjustment>, press
key and then:
User Adjustment”.
22.1. Adjusting procedure
• Enter submenu <
and select: “
User Adjustment > according to ch. 22
Adjustment”,
• After entering the parameter the following message box appears:
90
• Take the load off the pan of platform 1,
• Press button
. The following message appears during
adjusting start mass: „Evaluation of starting mass”,
• After the procedure has been completed the following message
box appears:
• Place determined mass on pan of platform 1 and then select
,
• After the procedure of adjustment factor determination following
command appears:
• Accept the message box by pressing
mode.
key and return to weighing
<
Setting of start mass> parameter allows to adjust
start mass of platform 1.
91
Caution:
The factory adjustment process for platforms 2, 3, 4 is analogical to the one
described above.
22.2. Start mass adjustment
It is possible to adjust only a start mass, it helps to correct the start zero
when the span does not change.
Procedure:
• Enter submenu <
and select: “
User Adjustment > according to ch. 22
Setting of start mass”,
• After entering the parameter the following message box appears:
• Take the load off the pan of platform 1,
• Press button
. The following message appears during adjusting
start mass: „Evaluation of starting mass”,
• After the procedure has been completed the following message
box appears:
• Accept the message box by pressing
mode.
92
key and return to weighing
22.3. Report from adjustment process
Parameter <
Report printout> enables activating the function of
automatic printout of a report from adjustment process on a printer plugged
to the scale.
Procedure:
• Enter submenu <
User Adjustment> in accordance with ch. 22
of this user manual, select parameter <
set its appropriate value.
Report printout> and
Where:
-
Automatic report printout switched off
Automatic report printout switched on
Caution:
Submenu: “
Devices /
Printer /
Printouts
/
Adjustment report Printout template” enables optional modification
of report template (see ch. 16.2.3 of this user manual).
22.4. Adjustment track record
Each completed adjustment process is automatically saved in scale’s
database in submenu <
Adjustment track record>.
In order to enter submenu <
Adjustment track record >, press
Adjustment track record”. Files
key, and: „ User Adjustment /
comprising reports have names with time and date when the process was
performed.
List of data for a carried out adjustment process:
Date
Data of carried out operation
Operator
Operator name
93
Nominal Mass
Mass of adjustment weight
Platform number
Platform number on which an operation was performed
key, located
The user can print data on a specific entry by pressing
in the top bar of software’s window.
23. SOFTWARE UPDATE
A user of the scale can carry out ON-LINE updating of the software version
using Ethernet network or an external data storage device connectable to
the USB port of the terminal.
Enter the submenu <
:“
Update> by pressing
key, and next press
Update”.
23.1. ON-LINE updating
Caution:
1. ON-LINE updating requires access to a global INTRANET network.
2. Before updating the software, go to scale’s submenu:
Communication /
Ethernet” and set transmission
“
parameters for compatible with the client’s local network.
Procedure:
• Enter submenu <
manual,
Update> in accordance with point 23 of this user
Software version on server> which reads
• Select parameter <
software version and its availability date on RADWAG server.
Caution:
In case of no connection with the global network Intranet or incorrect
settings of Ethernet parameters, the scale displays the following
message: “
No connection”.
94
• Go to parameter <
following message:
Update From server> which displays the
key which is followed by
• Accept the message by pressing
displaying the updating progress window:
• After downloading the update press an active
followed by displaying a message:
key which is
key. The terminal shall restart
• Accept the message by pressing
with update installing procedure.
95
23.2. Update from pendrive
Procedure:
• Copy file “update.pue7” containing the current software version onto
the external data storage device (to the main catalogue),
• Connect the data storage device to terminal’s USB port,
• Go to submenu <
manual,
Update> in accordance with point 23 of this user
Update From pendrive> which displays the
• Go to parameter <
following message: “Update?”,
Caution:
In case the data storage device is not connected to the terminal’s USB
port and/or there is no „update.pue7” file in the main catalogue of the
pendrive, the software displays the following message “Update error”.
• Accept the message by pressing
key which automatically starts
the updating process. On its completion the terminal displays the
following message:
key. The terminal shall restart
• Accept the message by pressing
with update installing procedure.
23.3. Changes in software
Parameter <
Changes in software> enables acquiring data on changes
present in the updated software version.
96
Procedure:
On completing the software updating procedure go to parameter
Changes in software> which opens an information window
<
<Changes in software>:
24. SPECIAL FUNCTIONS OF WORKING MODES
Scale can operate in following work modes:
Weighing
Counting pieces
Deviations
Dosing
Formulation
CPG
Density
Weighing animals
Vehicle scale
97
Work modes can be configured in <
To enter submenu <
„
Working Modes>.
and then:
Working Modes>, press
Working Modes”.
The settings of specific working modes provide access to special functions
adjusting operation of the instruments to client’s individual needs.
Caution:
(local settings) in the main window of
1. First left screen button
every working mode is ascribed to access settings of current mode.
2. The change in on mode results in the same change for other working
modes working modes.
Part of the special functions have global effect, i.e. they are applicable
to most of accessible working modes (except for working modes: Formulation,
Dosing, Vehicle scale), as presented on below table:
Weighing
Parts
counting
Percent
setup
Weighing
animals
Density
CPG
Save Mode
+
+
+
-
+
+
Down-weighing
+
+
+
-
-
-
Checkweighing
+
+
+
+
+
-
Tare mode
+
+
+
+
+
-
Labelling mode
+
+
+
+
-
-
Statistics
+
+
+
+
+
+
Differential
weighing
+
-
-
-
-
-
Peak hold
+
-
-
-
-
-
Other special functions are related directly to a specific working mode, and
they are described in further part of this user manual.
24.1. Working modes accessibility
Submenu <
Accessibility> enables declaring presence of scale’s
working modes in the user menu after pressing a pictogram with a working
mode located in the left corner of the top bar in the main window.
98
Procedure:
• Enter group of parameters <
Working modes> in accordance
with point 24 of the user manual,
Accessibility> which opens a list with available
• Select option <
working modes and their accessibility attribute.
Where:
- Working mode enabled
- Working mode disabled
•
Set accessibility attribute for each of the working modes and return
to weighing mode.
24.2. Save mode
Depending on setting parameter <
from the scale to an external device.
Save Mode> users can send data
Procedure:
Working modes> according
•
Enter parameters group <
to ch. 24 of this manual,
•
Enter the required mode and choose <
the required mode.
Save Mode> then choose
Accessible options:
Manual every stable
-
Manual printout of each stable weighing result for mass
measurement over -LO- threshold
Manual first stable
-
Manual printout of the first stable weighing result for mass
measurement over -LO- threshold
Automatic first stable
-
Automatic printout of the first stable weighing result for mass
measurement over -LO- threshold
Automatic last stable
-
Automatic printout of the last stable weighing result for mass
measurement below -LO- threshold
Semi-automatic every
stable
-
Manual printout of each weighing result for mass
measurement over -LO- threshold – awaiting for a stable result
Semi-automatic first
stable
Manual printout of the first weighing for mass measurement
over -LO- threshold – awaiting for a stable result
99
24.3. Down-weighing
Software allows to weigh in the “down-weighing” mode. It consist in putting
the load on the pan and taking off/removing portions of it with concurrent
saving weighments equal to the portions taken off the pan.
Procedure:
•
Enter parameters group <
to ch. 24 of this manual,
Working Modes> according
•
Enter the required working mode and choose <
and then set the required option.
Down-weighing>
Accessible options:
-
Traditional weighing
Down-weighing mode
24.4. Checkweighing
In case of enabling the checkweighing mode, printouts are performed only
when a weighing is between MIN and MAX thresholds that have been
defined before.
Procedure:
•
Enter parameters group <
of this manual,
Working Modes> according to ch. 24
•
Enter the required working mode and choose <
then set the required option.
Checkweighing>
Options:
-
Every weighing is recorded
Only weighments between MIN, MAX are recorded.
24.5. Tare mode
This function enables users to set parameters for tarring.
100
Procedure:
•
Enter parameters group <
of this manual,
Working Modes> according to ch. 24
•
Enter the required working mode and choose <
and then set the required option.
Tare mode>
Options:
Single
-
Basic tare mode. The set (chooden) tare value is
overwritten after entering a new value
Current sum
-
Summing up tare values of product and package together
with manually inscribed tare. After next setting of product
or package tare the entered tare value is disabled
Total sum
-
Summing up all subsequently entered tare values
Autotare
-
Automatic tare mode together with mode <Sum of all>
Each
measurement
-
Automatic tarring for each accepted measurement result.
24.6. Labelling mode
Labelling mode can be initiated together with every working mode. The
labelling system is intended to print labels for marking weighed goods e.g. a
packing process. The program can print standard labels for single products,
cumulative labels for sticking to bulk containers and cumulative labels for
cumulative labels for sticking to the large transport containers holding bulk
containers.
In submenu <
functions:
Labelling mode> there are accessible following special
Number of labels
No. of cumulative labels
No. of CC labels
C label automatic triggering
CC label automatic triggering
101
24.6.1. Setting of the number of labels to print
In the parameter <
Number of labels> user defines the amount
of labels. They are printed on the printer connected to the weight.
Procedure:
•
Enter parameters group <
to ch. 24 of this manual,
Working Modes> according
•
Enter the required working mode and choose: „
Labelling mode /
Number of labels” then the editing field <Number of labels>
with the screen keyboard is opened,
•
Choose the required number of labels and confirm by pressing
.
24.6.2. Setting of the number of cumulative labels to print
In the parameter <
No. of cumulative labels> define the amount
of sum labels. They are printed on connected printer.
Procedure:
•
Enter parameters group <
of this manual,
•
Enter the required working mode and choose: „
•
No. of cumulative labels”, then the editing field
<No. of cumulative labels> with the screen keyboard is opened,
Enter the required number od cumularive labels and confirm by
pressing
Working Modes> according to ch. 24
Labelling mode /
.
24.6.3. Setting of the number of CC labels to print
In the parameter <
No. of CC labels> define the amount of total sum
labels to print. They are printed on connected printer.
102
Procedure:
•
Enter parameters group <
of this manual,
•
Enter the required working mode and choose: „
•
No. of CC labels”, then the editing field <No. of CC labels>
with the screen keyboard is opened,
Enter the required number od cumularive labels and confirm
Working Modes> according to ch. 24
Labelling mode /
.
by pressing
24.6.4. Automatic triggering of cumulative labels
Users have access to the function of automatic triggering of printing
cumulative labels after setting parameters <
<
Mode> and
Threshold>.
Procedure:
•
Enter <
Working modes> parameter group as described
in chapter 24 of the manual,
•
Enter the required working mode and choose: „
C label automatic triggering /
required option:
None
-
-
Mode” and then set the
Cumulative label printout is initiated by pressing
or
Mass
Labelling mode /
*
,
Cumulative label printout is initiated by exceeding the
value set in parameter <
Threshold>. The value
is treated as the total from single weighments,
Number
-
Cumulative label printout is initiated by exceeding the
value set in parameter <
Threshold>. The value
is treated as the number of single weighment.
*) Manual printing of cumulative labels can be done in two ways
depending on the button used:
103
Printing followed by zeroing label counter or the total mass
Printing without zeroing label counter or the total mass
By default setting button
is accessible in the bottom part of the
can be done in submenu:
display but activating the button
/
Display /
Actions”
„
(see ch. 17.2 of the manual).
For automatic printout of cumulative labels counters and total mass
variables are always zeroed.
•
Confirm the changes by pressing
and go to parameter
<
Threshold> then <Threshold> window appears with the screen
keyboard,
•
Set the appropriate value for automatic triggering cumulative labels:
− If parameter <
Mode> is set to <Mass> then enter the required
value of total mass to exceed in order to print the C label,
− If parameter <
Mode> is set to <Number> use the screen
keyboard to enter the required counter value as a threshold to
trigger off printing C labels.
• Confirm the changes introduced by pressing
.
24.6.5. Automatic triggering cumulative labels of cumulative labels
Users have access to the function of automatic triggering of printing
cumulative labels of cumulative labels after setting parameters
Mode> and <
<
Threshold>.
Procedure:
•
Enter <
Working modes> parameter group as described
in chapter 24 of the manual,
104
Enter the required working mode and choose: „
•
Mode” and then set the
CC label automatic triggering /
required option:
-
None
Cumulative label of cumulative labels printout is initiated
by pressing
-
Mass
Labelling mode /
*
or
,
Cumulative label of cumulative labels printout is initiated by
exceeding the value set in parameter <
Threshold>.
The value is treated as the total from single weighments,
Number
-
Cumulative label of cumulative labels printout is initiated by
exceeding the value set in parameter <
Threshold>.
The value is treated as the number of single weighments,
*) Manual printing of cumulative labels can be done in two ways depending
on the button used:
Printing followed by zeroing label counter or the total mass
Printing without zeroing label counter or the total mass
By default setting button
is accessible in the bottom part of the
can be done in submenu:
display but activating the button
„
/
Display /
Actions” (see ch. 17.2).
For automatic printout cumulative labels of cumulative (CC)
labels counters and total mass variables are always zeroed.
•
Confirm the changes by pressing
and go to parameter
<
Threshold> then <Threshold> window appears with
the screen keyboard,
•
Set the appropriate value for automatic triggering CC labels:
− If parameter <
Mode> is set to <Mass> then enter the required
value of total mass to exceed in order to print the CC label,
105
− If parameter <
Mode> is set to <Number> use the screen
keyboard to enter the required counter value as a threshold to
trigger off printing CC labels.
• Confirm the changes introduced by pressing
.
24.7. Statistics
All statistics are continuously updated after each measurement is saved
in the scale memory. Statistics can be calculated globally (does not depend
on the selected product) or separately for every product from the product
database. It can be set in parameters <
Statistics>.
Procedure:
•
Enter <
Working modes> parameter group as described
in chapter 24 of the manual,
•
Enter the required working mode and choose <
and then set the required option.
Statistics>
Options:
Global
Product
-
global statistics,
statistics for every product.
Caution:
Statistics> set to <Product> bare in mind
In case of operation with <
that after restarting only statisics of the last weighed product are recovered.
24.8. Differential weighing
Function <
Differential weighing> enables analyzing mass changes of
one or more samples. To do it start mass of a sample must be estimated, next
the sample undergoes various processes during which some components of
the sample are subtracted or added. Finally the sample is weighed again
(differential weighing). The scales calculates the difference between two mass
values (weighment I and weighment II).
106
24.8.1. Local settings
Local settings for <
in submenu: „
weighing:
Differential weighing> function are to be accessed
Working modes /
Activation
Weighing /
Differential
Activation of differential weighing function
(
- function active,
- function inactive)
Batch portion
type
Batch type, for differential weighing:
Value – differential weighing is realized according to
declared as measuring series batch value. Filter –
differential weighing is realized according to filter and
batch value declared as a measuring series value.
Filtering
Filter type declaration, differential weighing is realized
according to this filter. Values: Product, Client, lot
number, batch number, source warehouse, target
warehouse, packaging. Parameter <Filtering> is not
accessed if <Batch portion type> parameter value is
set to <Value>.
Charge
Measuring series value for differential weighing
24.8.2. Reporting realized processes of differential weighing
Report of each realized process of differential weighing is saved to database
<
Differential weighments reports>, date and hour of an executed
process is the file name. To view list of data for a process of differential
weighing see point 35.5.8 of this manual.
24.9. Peak hold
The scale enables measuring the maximum force influencing the weighing
pan.
Procedure:
•
Enter <
Working modes> parameter group as described
in chapter 24 of the manual,
107
•
Enter the required working mode and choose <
set the required option.
Peak hold> and then
Where:
-
Scale operates in standard weighing mode
Scale operates with mode forcing lock of maximum indication
on the display, i.e. peak hold.
• On loading the weighing pan with changeable force, the displays locks
the indication of the maximum measured force. The locked value is
signalled by red colour of the displayed value.
• Remove load from the weighing pan.
• Before carrying out the following measurement press
button.
25. WORKING MODE - WEIGHING
The <
Weighing> mode is the standard working mode allowing
to perform weighments and saving them in the database
<
Weighings / Alibi>.
25.1. Starting the working mode
The <
Weighing> mode is the standard working mode. If a user
has changed the operating mode to another follow the actions below:
• While in the main window press the icon with mode name placed on
the top bar on the left then submenu comprising all accessible working
modes <Working Modes> opens,
• Choose <
Weighing>, program automatically returns to the main
window displaying icon
in the top bar.
108
25.2. Local setting of a working mode
Local setting of a working mode <
a hot key <
Weighing> are accessible on pressing
Local parameters>:
Save Mode
Detailed description in ch. 24.2 of the user manual
Down-weighing
Detailed description in ch. 24.3 of the user manual
Checkweighing
Detailed description in ch. 24.4 of the user manual
Tare mode
Detailed description in ch. 24.5 of the user manual
Labelling mode
Detailed description in ch. 24.6 of the user manual
Statistics
Detailed description in ch. 24.7 of the user manual
Differential weighing
Detailed description in ch. 24.8 of the user manual
Peak hold
Detailed description in ch. 24.9 of the user manual
26. WORKING MODES – PARTS COUNTING
Parts counting is working mode allowing to count pieces on the basis of the
standard unit mass of a single piece set on the scale or fetched from the
database.
Caution:
If parts counting is performed in an additional container it should be tarred.
26.1. Starting the working mode
Procedure:
in the top bar, then you will
• While in the main window press
see a submenu <Working Modes> comprising a list of modes,
• Choose <
Parts counting >, program automatically returns
in the top bar,
to the main window displaying icon
• The weight unit is automatically changed to „pcs” and two screen
buttons on the right side appear:
109
Enter part mass
Estimate part mass
26.2. Local settings of the working mode
Local settings of the working mode <
pressing a hot key <
Parts counting > are accessible on
Local parameters>:
Save Mode
Detailed description in ch. 24.2 of the user manual
Down-weighing
Detailed description in ch. 24.3 of the user manual
Checkweighing
Detailed description in ch. 24.4 of the user manual
Tare mode
Detailed description in ch. 24.5 of the user manual
Labelling mode
Detailed description in ch. 24.6 of the user manual
Statistics
Detailed description in ch. 24.7 of the user manual
Automatic correction
of reference mass
Detailed description in ch. 25.2.1 of the user manual
Minimum reference mass
Detailed description in ch. 25.2.2 of the user manual
26.2.1. Automatic correction of reference mass
It concerns the <
Working mode <
Parts counting> working mode
Parts counting> comprises a special function
Automatic correction of reference mass>, that can be used for
<
correcting the unit mass <SMP>. To enable the function in parameters you
need to:
• Enter parameter group <
Working modes> according to ch.
Parts counting /
Automatic
24 of this manual, choose: „
correction of reference mass” and set appropriate option.
110
Options:
Function <
Automatic correction of reference mass disabled
Automatic correction of reference mass enabled
Automatic correction of reference mass> in mode
Parts counting > is enabled at the moment of estimating the sample
<
quantity and signalled by displaying <PCS> and <SMP> (single part/piece
mass) on the top part of the display.
There are four criteria of working “Automatic correction of reference
mass” function:
1. equilibrium should be reached,
2. quantity of parts/pieces should be increased,
3. added quantity of parts/pieces should not be greater than double
number of parts/pieces on the pan,
4. the new sample can be different from the old sample by ± 0.3
of pcs (absolute value),
If a user recognises that the sample quantity is adequate the unit mass
(single piece mass) can be saved (see ch. 26.6 of this manual)
.
and disable the function by pressing
Caution:
While the parts counting function is active the functionality of
is changed. Pressing
weighments.
button
does not result in printing and saving
26.2.2. Minimum reference mass
It concerns the <
Parts counting > working mode
Users before beginning the procedure of single piese mass evaluation can
declare “minimum reference mass” i.e. minimum total weight of all pieces
put on the scale pan expressed in reading divisions.
Procedure:
• Enter parameter group <
24 of this manual,
Working modes> according to ch.
111
• Choose „
Parts counting /
Minimum reference mass”
and then set an appropriate value.
Accessible settings: 1 d, 2 d, 5 d, 10 d.
Caution:
While the procedure of evaluation the mass of single piece the the mass
of all pieces put on the pan is lower than the value declared in parameter
Minimum reference mass”, the following warning message will
„
be displayed: < Too low sample mass>.
26.3. Setting a reference unit by entering known piece mass
Procedure:
• Enter mode <
of this manual,
Parts counting> according to ch. 26.1
(enter piece mass), then an editing field is displayed
• Press
<Reference Unit> with the screen keyboard,
• Enter a value and confirm it by pressing
<
, which causes starting
Parts counting > with automatic setting the reference unit.
Caution:
1. In case of entering a reference unit higher then the maximum weighing
range of the main scale the program will display a message box:
<Value too high>,
2. In case of entering the single piece mass lower than 0.1 d, the
program will display a message box: <Value to small>.
26.4. Setting a reference unit by weighing a sample
Procedure:
• Enter mode <
of this manual,
Parts counting> according to ch. 26.1
• If pieces are weighed in a container it needs to be put on the pan
and tarred,
112
• Press
(estimate piece mass), then the editing field is displayed
<Reference Quantity> together with the screen keyboard,
• Enter a value and confirm it by pressing
, then the following
message is displayed: <Put pieces: xx> (where xx – the value
entered before),
• Put the declared quantity of pieces on the pan and when the result
) confirm it by pressing
.
is stable (symbol
• The program automatically calculates reference unit mass and
causes starting <
Parts counting >.
Caution:
• The total mass of all pieces put on the weight pan cannot be greater
than the weighing range;
• The total mass of all pieves put on the weight pan cannot be less than
the value declared in parameter „Minimum reference mass” (see
section 26.2.2). If the condition above is not fulfilled the scale dispalays
the message <Too low sample mass>;
• The mass of one unit may not be less than 0.1 of reading division
of the scale. If this condition is not fulfilled the scale dispalays the
message: <Too low piece mass>.
26.5. Setting the reference mass by entering single piece mass directly
to the database
After selecting a product from the product database a mass of single
piece from the field <Mass> is used.
Procedure:
• While in <
• Using
Parts counting > press
or
,
choose a product and confirm it by pressing
Caution:
The selected product has to have declared unit mass (single piece mass).
113
.
26.6. Inscribing the unit mass to the database
The unit mass can be described a unit mass the following way:
a) Estimate the unit mass (see 26.2 and 26.3),
,
b) Enter the products database
c) Keep the finger pressed on the required position then a context
menu is displayed,
d) Choose option <Ascribe standard>, then the standard unit mass
is attributed to the product in the field <Mass>.
Caution:
Attributing a standard to a selected product is also possible by
programmable button. Setting programmable buttons is described in ch.
17.2 of this manual The list of functions is described in APPENDIX B
of this manual.
27. WORKING MODES – PERCENT SETUP (DEVIATIONS)
The program allows to check weighments in deviations (in %) around an
outlined standard mass. The standard mass can be outlined by weighing
or entering it by a user.
27.1. Starting the operating mode
Procedure:
• While in the main window press
in the top bar of the window then
you will see a submenu <Working Modes> comprising a list of modes,
• Choose mode <
Deviations>, the program will automatically
returns to the main window displaying icon
in the top bar,
• The weight unit is automatically changed to „%” and two screen
buttons on the right side appear:
Enter reference mass
Estimate reference mass
114
27.2. Local settings of the working mode
Local settings of the working mode <
on pressing a hot key <
Deviations> are accessible
Local parameters>:
Save Mode
Detailed description in ch. 24.2 of the user manual
Down-weighing
Detailed description in ch. 24.3 of the user manual
Checkweighing
Detailed description in ch. 24.4 of the user manual
Tare mode
Detailed description in ch. 24.5 of the user manual
Labelling mode
Detailed description in ch. 24.6 of the user manual
Statistics
Detailed description in ch. 24.7 of the user manual
27.3. Reference unit mass estimated by weighment
Procedure:
• Enter <
Deviations> according to ch. 27.1 of this manual,
• If the standard is to be weighed in a container, the container needs
to be put on the pan and tarred,
(Estimate standard mass), then a message is displayed:
• Press
<Put standard>,
• Put the load on the pan. After stabilization the result is taken
as a standard (symbol
). Confirm it by pressing
,
• At the same time the weight unit is changed to (w %).
27.4. Rederence unit mass inscribing into the memory
Procedure:
• Enter <
Deviations> according to ch. 27.1 of this manual,
115
• Press
(Give piece mass), then an editing field is displayed
<Give piece mass> together with the screen keyboard,
• Enter a value and confirm by pressing
,
• At the same time the weight unit is changed to (w %).
28. WORKING MODES - DOSING
<
Dosing> mode enables carrying out filling and dosing processes of
goods on scales featuring a terminal PUE 7 series. The working mode
enables manual and automatic dosing on a single or simultaneously
on many weighing platforms.
28.1. Starting the working mode
Procedure:
• While in main window of the software, press
on-screen key,
located in the top bar of the window, which opens submenu <Working
Modes> containing the list of available working modes,
• Select working mode <
Dosing>, the software automatically returns
to displaying the main window, and the top bar indicates the pictogram of
a selected working mode
,
• Automatically the following on-screen key are enabled:
Local parameters
Select dosing process
Start dosing process
Stop dosing process
Emergency stop
116
28.2. Dosing process structure
All activities related to the dosing process can be carried out from
> contains:
the level of scale. Each dosing process <
•
Its name <
•
code <
•
assigned weighing platforms <
>,
>,
> defined on a terminal.
Each of the weighing platforms can have its specific dosing process. The
database of dosing processes has the same searching mechanisms for a
specific record in a database as other terminal databases.
A dosing process can be searched in a database by:
•
the name of a dosing process <
•
the code of a dosing process <
>
>
Processes carried out on different weighing platforms operated by the same
terminal, can also be dependant on each other, e.g.: dosing on weighing
platform 2 can be initiated only on completing dosing on weighing platform 1,
which is confirmed by a signal from appropriate sensor.
28.3. Local setting of a working mode
Local settings for the working mode <
on pressing a hot key <
Dosing> are accessible
Local parameters>:
Ask for multiplier
Causes setting a question for dosing
process multiplier, i.e. the number which is
used to multiply the values of mass of all
components.
Ask for number of cycles
Causes setting a question on number of
dosing process cycles, i.e. number of
repetitions of the same process.
Confirm batching
ingredients manually
No. of weighments for
calculating the correction
117
Causes enabling manual confirmation by
pressing “Enter/Print” key on terminal’s
keyboard for each weighing process.
Determines the number of recent
measurements which are analyzed for
calculating automatic correction in dosing
Global
Global settings of doisng process
Batching outputs
Enables setting the outputs for dosing (fine
dosing in case of two-step dosing process)
Bulk batching output
Enables setting outputs for bulk dosing in
case of two-step dosing process
Correction
Enables determining global value of
correction for all weighing platforms
Maximum correctional
value
Enables detemining maximal value of
correction, which can be automatically
determined for all weighing platforms
<
Global> settings are dedicated for the process of creating simple
dosing processes, e.g.: dosing a single ingredient on all weighing platforms.
28.4. Description of functions and setting dosing process
While creating dosing process, the user has access to the following
functions:
Icon
Short
cut
Function
Description
[DH]
Dose manually
Function recalling manual weighment of
dosing process ingredient (manual dosing)
Mass
Mass of an ingredient to be dosed
Min
MIN threshold for dosing process ingredient
Max
MAX threshold for dosing process ingredient
Product
Dosing process ingredient uploaded from
Products database
Enables switching on checkweiging mode
(weighing on minus)
Function enabling automatic weighment
(automatic dosing). The function enables
controlling outputs dedicated for dosing
process.
Down-weighing
[DA]
Automatic batching
Mass
Mass of an ingredient to be dosed
Mass for fast dosing
Mass of an ingredient for bulk dosing
(in case of two-step dosing process)
118
Product
Down-weighing
[O]
Outputs
Dosing process ingredient uploaded from
Products database
Enables switching on checkweiging mode
(weighing on minus)
Function enabling setting the status of
terminal’s outputs for controlling peripheral
devices plugged to those outputs. Accessible
settings: None – output disabled; “0” – output
with low status; “1” – output with high status.
Delay
Function determining interval between carrying
out the following dosing process steps. The
function determines pending time for the
following step counted in seconds.
Time
Determination of pending time counted in
seconds
Description
Text description of an interval displayed on
terminal’s touch panel
[Z]
Zero
Zeroing the weighing platform, equal to
operation of the 0 function key on the
terminal’s front panel
[T]
Tare
Tarring the weighing platform, equal to
operation of the T function key on the
terminal’s front panel
[TI]
[ST]
Set Tare
[CM]
Weight condition
[CI]
Tare setting function, equal to operation of the
<Set tare> function key on the terminal’s front
panel
Weight condition function determining time in
which the following step of dosing process ona
weighing platform should be carried out, e.g.:
the following step is carried out if mass (net or
gross) placed on the weighing platform is below
the value set in threshold.
Threshold
Value of mass set in threshold for the condition
Mass
Kind of determined mass for threshold (net or
gross)
Weight condition
Weight condition – “>=” or “<”
Input condition
Conditional function, determining when the
followwing step should be carried out,
depending on status of terminal’s intput. Each
input can take the following status: None –
input disabled; „0” – input with low status; „1” –
input with high status; „/” – input with increasing
tendency (status change from low to high, e.g.:
the moment of pressing a key); „\” – input with
decreasing tendency (status change from high
to low, e.g.: the moment of releasing a key)
119
Give mass
Function activating a so called: “mass in hand”
– ingredient’s mass of a dosing process
supplied in ready packages with precisely
determined mass. The given mass is added to
weighed ingredient’s mass, e.g.: ingredient to
be weighed = 21,8 kg, weighed amount 1,8 kg
placed on the scale, and 20 kg inserted
manually.
Give number
of batching
repetitions
Function determining quantity of batches of
weighed ingredient, that is added to a dosing
process. Mass of a single batch is determined
in a product selected from the database
(Products database – field Mass). Product’s
mass is multiplied by a specific value, and such
determined mass is added to weighing process.
The function is applicable for weighing products
in batches.
Set flags
Function determining a condition (characteristic
point) in dosing process. The function enables
conditional carrying out another step in dosing
process. Setting the characteristic point (signal
flags) in connection with condition flags enables
mutual conditioning of different processes on
different weighing platforms.
[CF]
Flags condition
Conditional function determining criteria for
events, which have to occur in order to carry
out the following step in dosing process.
[DG]
Gravitational
dosing
Function activating operation of automatic
weighment (automatic dosing), with option of
dosed mass flow measurement.
Mass
Mass of a component which is to be dosed-out
Percent
Mass threshold, given as a percentage [%],
automatic dosing is realized within this
threshold
Product
Dosing process component selected from
product database
Time correction
Time correction ± of closing a valve during the
dosing process, given as [ms]
Insensibility
threshold
Permissible error ± of dosed-out mass, given
as a percentage [%]
Minimal flow
Minimal flow value given as [g/s] or [kg/s] for an
initiated algorithm of gravitational dosing
Weighing in minus
Allows for turning on weighing in minus mode
[EM]
[ET]
[F]
120
28.5. Creating a new dosing process
Creating a new dosing process is initiated by specifying its name and code,
followed by determining processes on each of the weighing platforms.
Procedure:
•
Press
key and select option <
menu  then select <
Databases> from main
Dosing processes>,
•
In order to create a dosing process, press <
Add> key, and
confirm creating a new record in dosing process database,
•
Specify name < > and code < > by pressing corresponding hot
keys, and inserting a name and a code using an on-screen keyboard,
•
Select weighing platform on which the dosing process is created,
e.g.: <
Platform 1>.
•
By pressing <
Add> key design a sequence of the dosing process
to be carried out on a weighing platform no. 1, and next select one of
available process functions (se table in point 28.4).
•
There is a possibility of modifying an already designed process –
adding or deleting a single step in a process, e.g.: in order to add an
element in a process, press and hold for 4 seconds an element before
which a new step should be added. Drop-down menu with available
options is displayed
Edit
Add
Delete
Cancel
•
Press “Add” and define new element of the process.
121
28.6. Instances of dosing processes
28.6.1. Instance 1 – Manual dosing process of 4 ingredients on 2
weighing platforms
Description:
A dosing process contains 4 ingredients, which are weighed on two weighing
platforms:
•
•
Weighing Platform 1: ingredients: Flour and Sugar
Weighing Platform 2: ingredients: Seasoning and Water
Dosing process includes a condition, according to which before adding an
ingredient “Water”, all other ingredients have to be dosed. The condition
is marked with signal flags, which determine dosing process between
the weighing platforms, in a way which orders dosing Water ingredient as
the last one. The whole process is described below in tables, separately
for each weighing platform.
Dosing process name: Instance 1
Dosing process code:
1111
Dosing process from a termial level:
Platform 1:
Icon
Step
Value
Description
1. [TI] Delay
[5s] Place empty
container
Pending for loading an empty container
for the first product
2. [CI] Input
condition
Input 1 – „/”
Input 1 has to take increasing tendency –
press function key confirming loading a
container
3. [T] Tare
Tare
Tarring the weighing platform no. 1
4. [DH] Dose
manually
1 kg [Flour]
Manual weighing of product “Flour” to
obtain 1 kg mass
5. [TI] Delay
[5s] Unload
container with
product
Pending for unloading the container with
weighed product from the weighing
platform
6. [CI] Input
condition
Input 4 – „/”
Input 4 has to take increasing tendency –
press function key confirming unloading a
container from the weighing platform
7. [Z] Zero
Zero
Zeroing the weighing platform no. 1
122
8. [TI] Delay
[5s] Place empty
container
Pending for loading an empty container
for the second product
9. [CI] Input
condition
Input 1 – „/”
Input 1 has to take increasing tendency –
press function key confirming loading a
container
10. [T] Tare
Tare
Tarring the weighing platform no. 1
11. [DH] Dose
manually
0,2 kg [Sugar]
Manual weighing product “Sugar” to
obtain 0,2 kg mass
12. [TI] Delay
[5s] Unload
container with
product
Pending for unloading the container with
weighed product from the weighing
platform
13. [CI] Input
condition
Input 4 – „/”
Input 4 has to take increasing tendency –
press function key confirming unloading
a container from the weighing platform
14. [Z] Zero
Zero
Zeroing the weighing platform no. 1
Set signal flag 1
Setting the characteristic point of the
process, which is a condition for carrying
out part of the process on the second
weighing platform
Output 1 – „1”
Input 1 takes the high status (“1”) – signal
confirming carrying out the dosing
process on the weighing platform no. 1
is lit up
15. [F] Set flags
16. [O] Outputs
Platform 2:
Icon
Step
Value
Description
1. [TI] Delay
[5s] Place empty
container
Pending for loading an empty container for
the third product (the first product on the 2
weighing platform)
2. [CI] Input
condition
Input 9 – „/”
Input 9 has to take increasing tendency –
press function key confirming loading a
container
3. [T] Tare
Tare
Tarring the weighing platform no. 2
4. [DH] Dose
manually
0,2 kg
[Seasoning]
[5s] Unload
container with
product
Manual weighing product “Seasoning”
to obtain 0,2 kg mass
5. [TI] Delay
Pending for unloading the container with
weighed product from the weighing platform
6. [CI] Input
condition
Input 12 – „/”
Input 12 has to take increasing tendency –
press function key confirming unloading a
container from the weighing platform
7. [Z] Zero
Zero
Zeroing the weighing platform no. 2
123
Signal flag 1 – „1”
Checking condition, whether signal flag 1
is set to value “1” – i.e. checking whether
desired part of the process has been already
realized on the weighing platform no. 1. If
Yes, then dosing process on the second
weighing platform shall continue.
9. [O] Outputs
Output 1 – „0”,
Output 12 – „1”
Output 1 is set to low status – the signal for
completing dosing process on the weighing
platfofrm no. 1 is switched off; output 12
takes the high status – the main water valve
is opened, for manual dosing of water
ingredient.
10. [DH] Dose
manually
2 kg [Water]
Manual weighing product “Water” to obtain
2kg mass
11. [O]
Outputs
Output 12 – „0”
Output 12 is set to low status – the main
water valve is closed
12. [TI] Delay
[5s] Unload
container with
product
Pending for unloading the container with
weighed product from the weighing platform
13. [CI] Input
condition
Input 12 – „/”
14. [O]
Outputs
Output 9 – „1”
8. [CF] Flags
condition
15. [TI] Delay
Input 12 can take increasing tendency –
press function key confirming unloading a
container from the weighing platform
Output 9 is set to high status („1”) – signal
confirming carrying out the dosing process
on the weighing platform no. 2 is lit up
[5s] Dosing
process completed
Displaying a text message on the terminal
confirming completion of dosing process.
Completing dosing process causes switching off all outputs of the terminal.
28.6.2. Instance 2 – Automatic dosing of 2 ingredients on 2 weighing
platforms
Description:
The dosing process consists of 2 ingredients which will be weighed on 2
weighing platforms:
•
•
Weighing Platform 1: ingredient Flour
Weighing Platform 2: ingredient Water
The dosing process is carried out automatically, and includes a condition,
that the dosing sequence is strictly determined – dosing of “Water” ingredient
can be initiated only on completing the dosing process of ingredient “Flour”.
124
The condition is marked with signal flags, which determine formulation making
process between the weighing platforms, in a way which orders dosing Water
ingredient as the second one. The whole process is described below in
tables, separately for each weighing platform.
Dosing process name: Instance 2
Dosing process code: 2222
Dosing process from a terminal level:
Platform 1
Icon
Step
Value
Description
1. [CM] Weight
condition
Gross<0.1 kg
Condition checking, unless the weighing
platform is loaded with a mass exceeding
100 g
2. [Z] Zero
Zero
Zeroing the weighing platform no. 1
3. [TI] Delay
[5s] Open
valve Flour
Pending for opening main valve of the
container with “Flour”
4. [DA] Automatic
batching
1,2 kg [Flour]
Automatic dosing of product „Flour” to
obtain 1 kg mass in bulk dosing mode
(bulk dosing and fine dosing valves are
opened – Outputs 1 and 2), and 0,2 kg
mass is dosed using fine dosing valcve
only –fine dosing valve is opened on
Output 1 (for two-step dosing process)
5. [TI] Delay
[3s] Close
valve „Flour ”
Pending for closing the main valve of the
container “Flour”
6. [O] Outputs
Output 11 – „1”
Output 11 takes high status („1”) – signal
confirming carrying out the dosing making
process on the weighing platform no. 1 is
lit up
7. [F] Set flags
Signal flag 1 –
„1”
Setting the characteristic point of the
process, which is a condition for carrying
out part of the process on the second
weighing platform
Dosing on the first weighing platform is carried out in two-steps, as for
ingredient „Flour” the outputs are set for two-step dosing – see Products
database.
125
Platform 2
Icon
Step
Value
Description
1. [CF] Flags
condition
Signal flag 1 –
„1”
Checking condition, whether signal flag 1
is set to value “1” – i.e. checking whether
desired part of the process has been
already realized on the weighing platform
no. 1. If Yes, then dosing process on the
weighing platform no. 2 shall start.
2. [CM] Weight
condition
Gross<0.1 kg
Condition checking, unless the weighing
platform is loaded with a mass exceeding
100 g
3. [Z] Zero
Zero
Zeroing the weighing platform no. 2
4. [TI] Delay
[5s] Open valve
Water
Pending for opening main valve of the
container with “Water”
5. [DA]
Automatic
batching
2,2 kg [Water]
Automatic dosing of ingredient “Water” to
obtain 2,2 kg mass in single-step dosing
mode – Output 6 controls the dosing valve
6. [TI] Delay
[5s] Close valve
Water
Pending for closing the main valve of the
container “Water”
7. [O] Outputs
Output 12 – „1”
Output 12 takes high status (“1”) – signal
confirming carrying out the dosing process
on the weighing platform no. 2 is lit up
8. [TI] Delay
[5s] Dosing
process
completed
Displaying a text message on the terminal
confirming completion of dosing process.
Additionally, in automatic dosing process, additional setting of dosing outputs
for dosed ingredients have to be made – see Products database settings.
28.6.3. Instance 3 – Mixed dosing process
Description:
A dosing process contains 4 ingredients, which are weighed on two weighing
platforms:
•
•
Weighing Platform 1: ingredients Flour, Sugar and Seasoning,
Weighing Platform 2: ingredients: Water
126
Dosing process is carried out manually and automatically, and it incudes a
condition that the dosing sequence is strictly determined – dosing of “Water”
ingredient can be initiated only on completing the dosing process of ingredient
“Flour” and “Sugar”. Ingredient “Seasoning” will be added as the last one to
the dosing process.
The condition is marked with signal flags, which determine formulation making
process between the weighing platforms, in a way which orders dosing
“Water” ingredient is dosed in an appropriate time. The whole process is
described below in tables, separately for each weighing platform.
Dosing process name: Instance 3
Dosing process code: 3333
Dosing process from a termial level:
Platform 1:
Icon
Step
Value
Description
1. [TI] Delay
[5s] Place container
Flour on the weighing
platform
Pending for loading container “Flour” on
the weighing platform no. 1
2. [CI] Input
condition
Input 1 – „/”
Input 1 has to take increasing tendency
– press function key confirming loading
a container
3. [T] Tare
Tare
Tarring the weighing platform no. 1
4. [DH] Dose
manually
1 kg [Flour]
Manual weighing product Flour to obtain
1 kg mass
5. [TI] Delay
[7s] Unload container
with product
Pending for unloading the container with
“Flour”
6. [CI] Input
condition
Input 4 – „/”
Input 4 has to take increasing tendency
– press function key confirming
unloading a container from the weighing
platform
7. [O] Outputs
Output 1 – „1”
Signal on completing dosing ingredient
“Flour”
8. [Z] Zero
Zero
Zeroing the weighing platform no. 1
9. [TI] Delay
[5s] Place container
Sugar on the weighing
platform
Pending for loading container “Sugar” on
the weighing platform no. 1
10. [CI] Input
condition
Input 1 – „/”
Confirm loading of container “Sugar”
127
11. [T] Tare
Tare
Tarring the weighing platform no. 1
12. [DH] Dose
manually
0,4 kg [Sugar]
Manual weighing product Sugar to
obtain 0,4 kg mass
13. [TI] Delay
[5s] Unload container
with product
Pending for unloading the container with
“Sugar”
14. [CI] Input
condition
Input 4 – „/”
Input 4 has to take increasing tendency
– press function key confirming
unloading a container from the weighing
platform
15. [O]
Outputs
Output 2 – „1”
Signal on completing dosing ingredient
“Sugar”
16. [Z] Zero
Zero
Zeroing the weighing platform no. 1
17. [CI] Input
condition
Input 5 – „1”
Confirm pouring ingredients to a mixer
18. [F] Set
flags
Signal flag 1 – „1”
Setting the characteristic point of the
process, which is a condition for carrying
out part of the process on the weighing
platform no. 2
19. [O]
Outputs
Output 5 – „1”
Lighting up a signaling device confirming
pouring the ingredients to the mixer
20. [CF] Flags
condition
Signal flag 1 – „1”
Signal flag 2 – „1”
Pending for automatic dosing of water
on the weighing platform no. 2
21. [TI] Delay
[5s] Place container
Seasoning on the
weighing platform
Pending for loading container
“Seasoning” on the weighing platform
no. 1
22. [CI] Input
condition
Input 1 – „/”
Confirm loading of container
“Seasoning”
23. [T] Tare
Tare
Tarring the weighing platform no. 1
24. [DH] Dose
manually
0,25 kg [Seasoning]
Manual weighing product Seasoning to
obtain 0,25 kg mass
25. [TI] Delay
[5s] Unload container
with product
Pending for unloading the container with
“Seasoning”
26. [CI] Input
condition
Input 4 – „/”
Input 4 has to take increasing tendency
– press function key confirming
unloading a container from the weighing
platform
27. [O]
Outputs
Output 3 – „1”
Signal on completing dosing ingredient
“Seasoning”
28. [TI] Delay
[10s] Dosing
completed
Displaying a text message on the
terminal confirming completion of dosing
process
128
Platform 2:
Icon
Step
1. [CF]
Flags
condition
2. [T]
Tare
3. [TI]
Delay
4. [DA]
Automatic
batching
6. [TI]
Delay
Value
Description
Signal flag 1 – „1”
Checking condition, whether signal flag 1 is set to
value “1” – i.e. checking whether desired part of the
process has been already realized on the weighing
platform no. 1. If Yes, then dosing process on the
weighing platform no. 2 shall start.
Tare
Tarring the weighing platform no. 2
[5s] Open valve
Water
Pending for opening main valve of the container with
“Water”
Automatic dosing of ingredient “Water” to obtain 2 kg
mass in single-step dosing mode – Output 6 controls
the dosing valve (set for Water in Products database)
Pending for closing the main valve of the container
“Water”
2 kg [Water]
[5s] Close valve
Water
7. [O]
Outputs
Output 12 – „1”
Output 12 akes high status (“1”) – signal confirming
carrying out the dosing process on the weighing
platform no. 2 is lit up
8. [F] Set
flags
Signal flag 1 – „1”
Signal flag 2 – „1”
Setting the characteristic point of the process, which is
a condition for carrying out part of the process on the
weighing platform no. 1
8. [TI]
Delay
[10s] Dosing
completed
Displaying a text message on the terminal confirming
completion of dosing process
An instance of mixed dosing (manual and automatic) has been extended by
signalling its corresponding phases to present the possibilities of the working
mode <Dosing>.
28.7. Reporting of completed dosing processes
On completing each dosing process, the terminal automatically generates
a report on that process.
Caution:
Devices /
Printer /
Printouts /
Dosing
Submenu: “
report printout template” enables optional modifying of the report
template (see ch. 16.2.3 of this user manual).
129
Default form of the report from dosing template:
---------------------------------------------Dosing process
---------------------------------------------{40:Start date:,-25}{180}
{40:End date:,-25}{181}
{40:Name:,-25}{175}
{40:Code:,-25}{176}
{40:Status:,-25}{182}
{40:Measurements:,-25}
---------------------------------------------{185:(50,-20) (7)(11)
(40:Nominal Mass:,-25)(186)(11)
(40:Difference:,-25)(187)(11)
---------------------------------------------}{40:Mass:,-25}{184}{11}
----------------------------------------------
The report from each completed process is simultaneously saved in the
Report from dosing>, where the files are named by their
database of <
date and hour of process execution and dosing process status. List
of data for the dosing process – see ch. 35.5.2 of this user manual.
29. WORKING MODES – FORMULATION
<
Formulation> is a working mode designed for creating formulations of
products on a scale.
29.1. Starting the working mode
Procedure:
• While in main window of the software, press
on-screen key, located
in the top bar of the window, which opens submenu < Working Modes>
containing list of available working modes,
• Select working mode <
Formulation >, the software automatically
returns to displaying the main window, and the top bar indicates the icon
of selected working mode
,
• Automatically the following on-screen keys are enabled:
130
Local parameters
Select formulation
Start formula making process
Stop formula making process
Select formulation ingredient from the list
Select previous formulation ingredient to to be processed
Select net formulation ingredient to be processed
Set “mass from hand” – mass of an ingredient supplied in ready
packaged and with determined mass
Edit lot number of an ingredient and/or sample of a formulation
ingredient
29.2. Local setting of a working mode
Local settings for the working mode <
on pressing a hot key <
Formulation > are accessible
Local parameters>:
Ask for multiplier
Ask for number
of cycles
Causes setting a question for formulation
multiplier, i.e. the number which is used to
multiply the values of mass of all formulation
components.
Causes setting a question on number of
formulation cycles, i.e. number of repetitions of
the same formulation.
Confirm batching
ingredients manually
Causes enabling manual confirmation by
pressing “Enter/Print” key on terminal’s keyboard
for each weighing process.
Automatic tare
Enable automatic tarring of mass at the moment
of process start and mass of each following
ingredient after the sampling process.
Ingredient control
Enable control mode of an ingredient being
part of a formulation. The “Ingredient control”
mode orders giving correct ingredient code
before its weighing process.
131
Portion weighing
Enable portion weighing mode of a formulation
for a random number of portions (samples) until
obtaining a target mass.
Report printout
Enable automatic printout of a formulation report
after completing the formula ma king process
29.3. Creating a new formulation
Procedure:
•
Press
key and select option <
Databases> from main
menu  then select < Formulation>,
•
Add> key, and confirm
In order to create a formulation, press <
creating a new record in formulation database.
List of data specified for a new formulation:
Name
Formulation name
Code
Formulation code
Ingredients
Defining formulation ingredients
Number of ingredients
Previewing number of ingredients in a
formulation
Formulation mass
Previewing total mass of a formulation
Type of charge *
Type of a measuring series for a formulation
Charge
A measuring series of a formulation
*) – the charge type is definable as one of three values:
None
Global
By ingredient
Function disabled
Charge is carried out globally for the complete
formulation
Charge is carried out sequantially for each ingredient
132
• After entering a selected weighing platform add the formulation ingredients
one by one by pressing <
Add> key.
List of data created for an ingredient of a formulation:
Name
Name of an ingredient in a formulation
Code
Code of an ingredient in a formulation
Product
An ingredient of a formulation selected from the
database of products
Mass
Mass of an ingredient
Deviation type
Declaring the deviation type: the measuring unit fo
an active weighing platform or the value in [%]
Low deviation
Low deviation of an ingredient’s mass
High deviation
High deviation of an ingredient’s mass
Dispensing
Enabling down-weighing (weighing to minus) mode
Platform
Assigning weighing platform number to an ingredient
Dispensing
Enabling down-weighing (weighing to minus)mode
1) – In case of selectng an ingredient from the database of products the
software displays the following message:
2) – in case of declaring mass of an ingredient, and when the mass exceeds
the maximum capacity of a weighing platform, the software displays the
following message:
133
3) – in case of declaring the value of the low deviation as greater than the
declared ingredient mass, the software displays the following message:
4) – in case the sum of ingredients mass and the value of high deviation
are exceeding the maximum capacity of a weighing platform, the software
displays the following message:
key which is equal to creating
• On entering the required data press
a new ingredient and adding it to the formulation composition.
• A created entry on the list comprises: the folowing number on the list,
ingredient’s name (selected from the database of products) and mass
to be weighed.
• The software enables modifying an existing list of ingredients, i.e. adding
or deleting an ingredient, e.g. in order to add an ingredient press and
hold for about 4 seconds an entry on the list before which the ingredient
should be added. The following menu with below content is displayed:
134
Edit
Add
Delete
Cancel
• Press “Add” and define a new ingredient of a formulation.
• After specifying all ingredients of a formulation go back to the main
window
by pressing
key.
29.4. Formula making process
Starting the formula making process requires that the authoriztion (access
level) of the logged user is sufficient to start the process.
Caution:
1. Starting the process requires that the logged user has access level at
least of an <operator>. If the logged user or anonymous operator have
access level set to <none> then on process start the software displays
a message: <Unauthorized access >.
2. The Loggingg procedure is described in point 11 of this user manual, and
the procedure of determining the access level for scale users is
described in point 19 of this user manual.
• Press an on-screen button
to select a required formulation.
• Enter to scale’s memory gerenal parameters on the working mode
(in accordance with point 29.2of this user manual),
• After returning to the main window of the <
press the on-screen function key
Formulation> mode
(process start),
• If the ingredient control mode is enabled, then the scale software opens
an editing window <Ingredient control> with a numeric keyboard and
an editing field for entering a correct code of the weighed ingredient
using a barcode scanner. Weighment of each following ingredient
requires giving its corresponding code.
135
In case when:
1. The inserted code of the current ingredient is incorrect, and the
ingredient is in formulation composition, the software displays the
following message: <Incorrect Ingredient Code. Ingredient already in
formulation content. Go to this ingredient?>. Accept this message by
key. The software goes to the weighing process of the
pressing
key is pressed, the software returns to displaying the
ingredient. If
editing window <Ingredient control > featuring the numeric keyboard for
entering the correct code of an ingredient.
2. The inserted code of the current ingredient is incorrect, and the
ingredient is not in the formulation composition. The software displays a
message: <No ingredient with specified code. Abort?>. On accepting
the message by pressing
key the software goes to another
key is pressed then the software returns
ingredient on the list. If
to displaying the editing window <Ingredient control> featuring the
numeric keyboard for entering the correct code of an ingredient.
3. If the inserted code of the current ingredient is correct, then the software
displays a message: <Correct Ingredient code> and goes to
ingredient’s weighing process.
• The workspace on the display indicates a bargraph denoting mass of
a weighed ingredient of a formulation and the following information:
Process in progress: Test formulation
Ingredient: 1 / 3 [ Ingredient 1 ]
Portion:
0 g / -500.0 g
Charge:
1 / 10
Completed: 0%
Where:
Process in progress:
Process status
Test formulation
Name of prepared formulation
Ingredient:
Number of weighed ingredient / Total number of
ingredients in a formulation
1/3
[ Ingredient 1 ]
Name of the weighed ingredient
Portion: 0 g
Current mass of the weighed ingredient
136
Portion: -500.0 g
Current deviation fro mthe reference mass
Charge:
Number of weighed charge / Total number of charges
1 / 10
Completed: 0%
Process progress
Caution:
• If on process start the weighing platform is loaded, the software will
indicate message <Load appropriate product> while trying to accept a
measurement.
• If a user tries to accept the following weighed mass wihtout chaging
mass of the load placed on the weighing platform, the software displayes
a message <Load appropriate product>,
• If a user tries to accept mass of a portion while the parameter <
Portion weighing> is disabled then the software displays the following
message <Load appropriate product>,
• If a user tries to accept an exceeded value of permissible ingredient
mass, then the software displays the following message <Permissible
value of ingredient mass exceeded. Recalculate ingredients?>. On
rejecting the message by pressing
key the software returns to the
key the
previous step. On accepting the message by pressing
software automatically recalculates mass of the ingredients proportionally
to the exceeded value of mass and returns to formulation making
process.
• If a user tries to accept an unstable mass indication, the software
displays a message <Measurements unstable>.
A user can abort the formula making process at optional moment by pressing
an on-screen function key
terminal’s display.
(process stop) located in the bottom bar of the
29.5. Reporting from completed formula making processes
On completing each formula making process, the terminal automatically
generates a report on that process.
137
Caution:
Devices /
Printer /
Printouts /
Formulation
Submenu: “
report printout template” enables optional modifying of the report
template (see ch. 16.2.3 of this user manual).
Default form of the report template from formula making process:
---------------------------------------------Formulation
---------------------------------------------{40:Start date:,-25}{240}
{40:End date:,-25}{241}
{40:Name:,-25}{220}
{40:Code:,-25}{221}
{40:Status:,-25}{242}
{40:Measurements:,-25}
---------------------------------------------{245:(50,-20) (7)(11)
(40:Nominal Mass:,-25)(246)(11)
(40:Difference:,-25)(247)(11)
---------------------------------------------}
---------------------------------------------{40:Mass:,-25}{244}
----------------------------------------------
The report from each completed formula making process is simultaneously
Reports From Formulation>, where the files
saved in the database of <
are named by their date and hour of process execution and formulation
status. List of data for the formula making process – see ch. 35.5.3 of this
user manual.
30. WORKING MODE – CPG (CONTROL OF PREPACKED GOODS)
Working mode <
CPG> enables carrying out a control of prepacked goods
(single stand of network) that is supported by database containing list of
products and operators. A control started from a scale is completed
automatically after checking an appropriate quantity of packages (samples).
The scale allows for connecting it with a PC computer featuring computer
software E2R SYSTEM and thus forming a multiposition (network) system.
Each scale in the network system is an independent weighing stand, and data
on the control process is sent to the computer software on the real time basis.
138
The computer software enables real time acquiring data from each connected
scale. The system allows for starting a control process from the scale or from
the level of computer software.
The acquired data allow for carrying out a quality control of manufactured
packaged goods for:
• Compatibility with the Regulation by the Central Office of Measures of 3
April 1997 on the requirements for a quality control of preapcked goods
– by random selecting measurement results and sending them to the
procedure of control of prepacked goods,
• Compatibility with an internal quality control system of an organization.
Caution:
Establishing a connection of a scale with the <
described in ch. 16.1.5 of this manual.
E2R System> is
30.1. Starting the working mode
Procedure:
on-screen key,
• While in main window of the software, press
located in the top bar of the window, which opens submenu <Working
Modes> containing the list of available working modes,
CPG>, the software switches to displaying the
• Select working mode <
home screen of the enabled working mode:
139
Where:
Entering control settings window
30.2. Control settings mode window
Caution:
Before entering the control settings mode carry out Loggingg procedure, as
described in ch. 11.1 of this manual.
button located at the bottom of the <
Press
which opens control settings window:
CPG> mode home screen
Where:
Selecting product from the database
Declaring number of the controlled batch
Working mode local settings
Returning to the working mode home
screen
Control start
140
30.3. Local setting of a working mode
Local settings of the working mode <
a hot-key <
CPG> are accessible on pressing
Local parameters> in the control settings window:
Save mode
Detailed description in ch. 24.1 of the
user manual
Number of accessible controls
Enabling simultaneous carrying out two
control processes (see ch. 30.12 of the
manual)
Ask for batch number
Function trigerring providing batch
number before the start of control
Password required
Enabling the parameter requires
Loggingg in to the scale before each
entering the mode settings window
30.4. Editing a product to be controlled
/
A product is edited in submenu “
Databases”.
Caution:
E2R System>
In case the scale cooperates with a computer software <
editing the databases from the scale level is blocked. Editing and exporting
product records to the scales is carried out from the level of computer
software.
Procedure:
• Enter submenu “
• Enter database <
/
Databases”,
Products> and press required product record.
141
List of data definable for a control:
Pictogram
Data name
Description
Name
Product name
Code
Product code
Mass
Product nominal mass
Tare
Product tare value (set automaticallz on
selecting a product from the database)
CPG
-
CPG mode
Control type: Non-destructive Average Tare,
Non-destructive Empty-Full, Destructive FullEmpty, Destructive Empty-Full
Lot size
Declaring quantity of a controlled batch
(Maximal value 999999)
Charge
Measuring series to be controlled: Nondestructive Empty-Full, Destructive Full-Empty,
Destructive Empty-Full
Unit
Product’s weighing unit: [g] or [ml]
Density
Product density (range of entered values has
3
3
to contain between 0,1g/cm and 5g/cm )
Quantity of
packages
Declaring quantity of packages to be controlled
for determining average tare (for control type
“non-destructive average tare”)
Cyclic
displaying of
average tare
/ turning off
an option of
Turning on
cyclic estimation of average tare for a product.
Interval of
average tare
determination
[h]
Value of time determining frequency of tare
control during a process of product control.
This means that estimation of average tare
for a product will be carried out in accord with
declared interval.
Internal control
Submenu for defining internal criteria of a
control (see table below)
142
• List of data for internal criteria
/ disabling
internal control
Internal control
Enabling
criteria
Sample quantity
Quantity of a product sample
Error value [- T]
Value of negative permissible error –T, set in
a weighing unit determined for the product.
Measurements below the Qn-T value will
be comprehended as defective.
Error value [+ T]
Value of positive permissible error +T set in
a weighing unit determined for the product.
Measurements above the Qn+T value will
be comprehended as defective.
Quantity of disqualifying
samples [Qn – 2T]
Number of recorded negative errors -2T in
a tested sample that disqualifies a control
Quantity of disqualifying
samples [Qn + 2T]
Number of recorded positive errors +2T in
a tested sample that disqualifies a control
Quantity of disqualifying
samples [Qn – T]
Number of recorded negative errors -T in
a tested sample that disqualifies a control
Quantity of disqualifying
samples [Qn + T]
Number of recorded positive errors +T in
a tested sample that disqualifies a control
Average limit value
Mode for calculating the average limit value
(constant or automatic)
Average limit value [ - ]
Average limit value (negative) for a tested
sample (refers to averge limit value as a
“constant”)
Average limit value [ + ]
Average limit value (positive) for a tested
sample (refers to averge limit value as a
“constant”)
Factor value [- Wk]
Standard deviation multiplier for the average
limit value (negative) determined in the
automatic mode
Factor value [+ Wk]
Standard deviation multiplier for the average
limit value (postive) determined in the
automatic mode
143
30.5. Control start procedure
To start testing:
• An operator needs to be logged on with the authorization access level
high enough to perform testing.
Caution:
The Loggingg on procedure is described in ch. 11. The procedure
of outlining the authorization level is described in ch. 19 of this manual.
• Select a product to be tested with correctly determined data for the
control process,
• Enter to scale memory general parameters on control mode (in
accordance with ch. 30.2 and 30.3 of the manual),
• Remove load fro mthe weighing pan,
• Press function hot-key
(control start) located in the bottom bar
of the settings window, which opens an information window on entered
data:
where:
Abort control start
Control start
144
Caution:
If before control start the operator:
• Does not remove a load from the weighing pan or other criteria for
zeroing are failed (e.g. unstable weighing result) the scale displays
a message: <Unable to start control. Zeroing error>,
• Does not log in or the logged operator is not authorized to carry out the
control, the scale displays a message: <No authorization >,
• Does not select a product from the database, the scale displays a
message: <Product not selected >,
• Does not declare batch quantity, the scale displays a message:
<Batch quantity not entered >.
30.6. Control aborting procedure
After control start an operator can abort the contol process in an optional
moment by pressing a function hot-key
bottom bar of the control process window.
Pressing the
Pressing
(control stop) located in the
(control stop) key is followed by displaying a message:
key causes reutining to the control process in progress.
key causes terminating the control and returning to settings
Pressing
of the CPG mode.
Simultaneously, a control report with status <Terminated> is added to the
database of <
Controls>.
145
30.7. Loggingg out from a control process in progress
Procedure:
• While in control mode perss pictogram with name of the logged operator
located in the bottom bar of the display,
• The operator is automatically logged out and simultaneously a window
<Insert Password> for Loggingg in is displayed with the name of the
previously logged operator:
• Enter correct password and press
the control process in progress,
• Pressing
mode:
key to automatically return to
key causes returning to the home screen of the CPG
146
where:
Restart control
- information for an operator on a possibility to
resume a control process in progress
- Control resuming button
• Pressing the
button causes displaying a Loggingg in window
<Insert Password> with the name of previously logged operator.
• After entering a correct password and accepting it by pressing
key the scale automatically returns to the control process in progress.
30.8. Non-destructive average tare control mode
Before starting the control process the user can determine average tare by
weighing packages. The option is enabled by activating a function <
Average Tare Estimation> in the CPG mode settings.
Tare control process is accompanied by below window:
Where:
Product
Code
- Product name
- Product code
147
- 0,25T criterion value in [g]
- Average tare of a packaging in [g]
- Standard deviation
- Characteristics of negative errors T1 in a sample
- Characteristics of negative errors 2T1 in a sample
Net
Tare
Status
Place packaging
-
Net mass of the controlled package
Packaging tare
Packaging control status
Command on control process with quantity of all
packages to be weighed
- Data on a control in progress
- Converting the workspace into a chart
- Control completion
Caution:
In order to carry out a product control using “non-destructive average tare”
mode, in accordance with the regulation on standard deviation “S”, the mass
of packages is determined from at least 10 measurements, and the standard
deviation cannot be greater than 0.25 of the maximum permissible negative
error T for nominal mass of a package.
If an operator carries out the last measurement of the packaging mass, the
software displays a summary of the process. Automatically, the system
generates a report is saved in the scale database:
Pressing
key causes moving to the control process without saving the
determined average mass of a packaging in product record in the database.
148
Pressing
key causes moving to the control process with simultaneous
saving the determined average mass of a packaging in product record in the
database.
During the control process in progress the software carries out real-time
updating of measurement results and displays them in the corresponding
fields for informing an operator on control result:
Where:
Product
-
Name of the controlled product
Code
-
Code of the controlled product
-
Nominal value of the controlled product
-
Average mass of the controlled product
-
Value of the disqualifying average
-
Characteristics of negative errors T in a sample:
-15g – value of the negative error T,
Max T – permissible number of the negative errors T,
n T – acutal number of the negative errors T
Characteristics of negative errors 2T in a sample:
-30g - value of the negative error 2T,
Max 2T - permissible number of the negative errors 2T,
n 2T - acutal number of the negative errors 2T
-
Net
-
Net mass of the controlled product
Tare
-
Tare of the packaging
149
Status
-
Control status: positive, negative
Put full
-
Commands on control process with quantity of all
measurements in a batch
-
Data on a control process in progress
-
Change of the workspace: numerical data / chart
-
Control completion
• Control status
Control status features a corresponding graphic interpretation:
- positive,
- negative (permitted to control sample 2)
- negative
In case of status marked with pictogram
field changes its colour to yellow:
a corresponding workspace
- Permissible number of netagive errors T1
exceeded, but control of sample 2 permitted
In case of status marked with pictogram
field changes its colour to red:
a corresponding workspace
- Average mass of the controlled product below
the value of the disqualifying average
• Data on control process in progress
Pressing
key displays data on a control process in progress:
150
Pressing
key causes returning to the control process in progress.
Pressing
weighments:
key causes moving to displaying a list of completed
In order to return to the control process in progress press
key.
• Change of the workspace
Pressing
key causes displaying the workspace in a form of
chart with measurement results:
151
Additionally, pressing the workspace area enables an operator to
change its format (from a line chart to a bar chart):
In order to disable the chart press
key for the second time.
After completing the control the scale generates a process summary, and
the accomplished control is automatically saved in the scale database:
152
Pressing
the scale.
key causes printing a report on a printer connected to
Pressing
key causes returning to settings window of the working
mode <
CPG> without printing a report.
Caution:
E2R System>
In case the scale cooperates with the computer software <
the message on process summary does not contain a option for printing a
report. The data on a control is automatically sent to the computer software
with possibility of printing the report from the computer level.
If the test result is that the number of errors T, according to the regulations,
requires expanding the sample. Operator is informed about it it the following
message box:
Press
and then some descriptions and boundary criteria are changed.
After the test has been completed the test is summarized and the results are
automatically saved in the database and the report can be printed on an
attached printer.
153
Caution:
A pattern and example of the report from testing products are described in ch.
30.14 of this manual. A pattern and example of the report from estimating
average tare are described in ch. 30.13 of this manual.
30.9. Performing non-distructive testing in mode Empty-Full
For mode „Non-destructive Empty-Full” a user sets the measurement
“charge” in the product data. According to the set „charge” a message
is shown that informs about putting empty packages first and then the
same packages after they have been filled up in the same sequence:
Where:
Product
Code
Net
-
Name of the controlled product
Code of the controlled product
Nominal value of the controlled product
-
Average mass of the controlled product
-
Value of the disqualifying average
-
Characteristics of negative errors T1 in a sample
(in accordance with ch. 30.6 of the manual)
-
Characteristics of negative errors 2T1 in a sample
(in accordance with ch. 30.6 of the manual)
-
Net mass of the controlled product
154
Tare
Status
Put Empty 1/10
(1/3)
-
Tare of the packaging
Control status (in accordance with ch. 30.6)
Commands on control process
Value of the measuring lot
Data on a control process in progress (in
accordance with ch. 30.6 of the manual)
Change of the workspace: numerical data / chart
(in accordance with ch. 30.6 of the manual)
Control completion
After the test has been completed the test is summarized (see ch. 30.8)
and the results are automatically saved in the database.
Caution:
A pattern and example of the report from estimating average tare are
described in ch. 30.14 of this manual.
30.10. Performing distructive testing in modes Empty-Full and
Full-Empty
“Destructive” control process complying with the resulation, and
independently on the batch size that exceeds 100 pcs., the size of a sample
accepted by the software for control process is 20 pcs. Other control criteria
are accepted as specified in the regulation.
After selecting from a list a product with set options for the destructive control
with determined measuring “lot”, and starting the control process, the
software will display messages facilitating the control process (as in the case
of control process described above).
Depending on the set control mode, the scale orders the following sequence
of weighing products: “empty-full” or “full-empty”.
Caution:
Remember to maintain the order for weighing products with packages and
empty packages. It is important to the software that carries out mass
calculations of products placed in a specific packaging.
155
After the test has been completed the test is summarized (see ch. 30.8)
and the results are automatically saved in the database.
Caution:
A pattern and example of the report from estimating average tare are
described in ch. 30.14 of this manual.
30.11. Control in accordance with internal criteria
Select a product with correctly determined parameters for carrying out the
control in accordance with the internal criteria (see ch. 30.4 of this manual).
After entering to scale memory general parameters of the working mode (in
accordance with ch. 30.2 and ch. 30.3 of this manual), start control process
by pressing
settings window.
key (control start) located in the bottom bar of the mode
The scale automatically displays a window with data on set control
parameters:
Accept the message box by pressing
key which causes moving to
the control process. During control process the software carries out real-time
monitoring of the measurement results and displays them it the coresponding
fields of the display for informing the operator on control result:
156
Where:
Product
Code
Put Full 1/30
Net
-
Name of the controlled product
Code of the controlled product
Nominal value of the controlled product
-
Average mass of the controlled product
-
Value of the negative disqualifying average
-
Value of the positive disqualifying average
-
Characteristics of negative errors T in a sample
(in accordance with ch. 30.6 of the manual)
-
Characteristics of negative errors 2T in a sample
(in accordance with ch. 30.6 of the manual)
-
Characteristics of positive errors T in a sample:
+15g - value of the positive error T,
Max T - permissible number of the positive errors T,
n T - acutal number of the positive errors T
-
Characteristics of positive errors 2T in a sample:
+30g - value of the positive error 2T,
Max 2T - permissible number of the positive errors 2T,
n 2T - acutal number of the positive errors 2T
-
Command on control process
Net mass of the controlled product
Data on a control process in progress (in accordance
with ch. 30.6 of the manual)
157
-
Change of the workspace: numerical data / chart
(in accordance with ch. 30.6 of the manual)
-
Abort of control
After the test has been completed the test is summarized (see ch. 30.8)
and the results are automatically saved in the database.
Caution:
A pattern and example of the report from estimating average tare are
described in ch. 30.14 of this manual.
30.11.1. Abort of control - procedure
User may abort a control that is being carried out with internal criteria.
(abort control) in any
It may be done by pressing function key
chosen moment. This key is located in the bottom part of a process window.
When the key is pressed the following message is displayed.
Pressing
key means getting back to the control in progress. Pressing
key means abort of the control. Abort of control results in getting back
to PGC mode setting window.
A report on control will be saved to <
<Terminated>.
Controls> database, report’s status -
158
30.11.2. Procedure of control completion
Completion of control realized in accordance with internal criteria may be
carried out in two ways:
• Automatically
All samples control – number of controlled samples accordant with
declared value in <Sample quantity> parameter. On completion of the
control a process summary is generated (see point 30.8 of this manual).
The control is automatically saved to database.
• Manually
Pressing beforehand defined key
(finish the control). When the
key is pressed the following message is displayed.
Pressing
key means getting back to the control in progress.
key means finish of the control. Finish of control results
Pressing
in getting back to PGC mode setting window.
Caution:
Pattern and example of a report on control is described in point 30.14 of this
manual.
30.12. Simultaneous carrying out two control processes
The scale enables carrying out two control processes at the same time.
The option is enabled in:
• Go to local mode settings and set parameter <
Number
of accessible controls> to value 2 (two controls),
159
• Change functions of the hot-keys for the following screens: home
screen, settings and process screens. Enable hot-keys:
<
Set control 1> and <
Set control 2> for the above screens.
Entering the “settings window” of a control causes displaying data
on a control identifying number of the enabled control:
Caution:
Platform>
With a multiplatform scale, an operator using the parameter <
ma has the option of assigning platform number to the current control.
After entering required data on a control and starting the control process,
the scale also displays data identifying the number of the enabled control:
160
Caution:
Processes:
• Control carrying out,
• Loggingg out during control in progress,
• Control termination,
are the same as in case of the above parts of the manual.
30.13. Report from estimating average tare
Report example:
Average Tare Report U/26/09/09/10/56/T
--------------------------------------RADWAG Wagi Elektroniczne
Balance Type:
WPY KTP
Max:
1.5/3 kg
d=e:
0.5/1 g
Factory Number:
123589
Date:
2009.09.26 10:56:30
Product:
AQUABA SAUCE
Tare:
7.9 g
Value 0.25T1:
3.75 g
Number of measurements: 10
Standard Deviation:
0.3162278
Test reault: Positive
Weighments:
1. 8.5 g
2. 7.5 g
3. 8.0 g
4. 8.0 g
5. 8.0 g
6. 7.5 g
7. 7.5 g
8. 8.0 g
9. 8.0 g
10. 8.0 g
........................................
----------------------------------------
161
Report pattern:
In submenu <
Printouts> users can edit the pattern of the average
tare report (see ch. 16.2.3). The default pattern is shown below:
Average Tare Report {301}
--------------------------------------RADWAG Wagi Elektroniczne
{40:Balance type:,-20}{44}
{40:Max:,-20}{34}
{40:d=e:,-20}{33}
{40:Factory number:,-20}{32}
{40:Date:,-20}{295}
{40:Product:,-20}{50}
{40:Tare:,-20}{54} g
{40:Value 0.25T1:,-20}{298} g
{40:Number of measurements:,-20}{299}
{40:Standard deviation:,-20}
{297}
{40:Result:,0}{296}
{40:Measurements:,-20}
{300}
.......................................
--------------------------------------{143:0c}
30.14. Report from product testing
Report example:
CPG Report U/26/09/09/10/59
---------------------------------------RADWAG Wagi Elektroniczne
Balance Type:
WPY KTP
Max:
1.5/3 kg
d=e:
0.5/1 g
Factory Number:
123589
Start date:
2009.09.26 10:55:28
End date:
2009.09.26 10:59:53
Operator:
Jan Kowalski
Product:
AQUABA SAUCE
Batch Number:
123/09
162
Nominal Mass:
520 g
Tare:
7.9 g
T1 error border:
15 g
2T1 error border:
30 g
Batch quantity:
100
Number of measurements: 30
Number of T1 errors: 0
Number of 2T1 errors: 0
Min:
518 g
Max:
529.5 g
Average:
519.9833 g
Total:
15599.5 g
Limit of the average: 518.9138 g
Standard Deviation: 2.159515
CPG mode:
Nondestructive Average Tare
Result: Positive
Measurements:
1. 518.0 g
2. 520.5 g
3. 529.5 g
4. 520.0 g
5. 521.0 g
6. 518.0 g
7. 519.0 g
8. 519.0 g
9. 519.0 g
10. 521.0 g
11. 521.0 g
12. 521.0 g
13. 521.0 g
14. 520.0 g
15. 521.0 g
16. 518.0 g
17. 518.0 g
18. 518.0 g
19. 518.5 g
20. 518.5 g
21. 518.5 g
22. 519.0 g
23. 519.0 g
24. 519.0 g
25. 519.0 g
26. 521.0 g
27. 521.0 g
28. 521.0 g
29. 521.0 g
30. 521.0 g
.......................................
---------------------------------------
163
Report pattern:
In submenu <
Printouts> users can edit the pattern of the average
tare report (see ch. 16.2.3). The default pattern is shown below:
CPG Report {279}
--------------------------------------RADWAG Wagi Elektroniczne
{40:Balance type:,-20}{44}
{40:Max:,-20}{34}
{40:d=e:,-20}{33}
{40:Factory number:,-20}{32}
{40:Start date:,-20}{261}
{40:End date:,-20}{262}
{40:Operator:,-20}{75}
{40:Product:,-20}{50}
{40:Batch number:,-20}{260}
{40:Nominal Mass:,-20}{53}{278}
{40:Tare:,-20}{54}g
{40:T1 error border:,-20}{266}{278}
{40:2T1 error border:,-20}{267}{278}
{40:Batch quantity:,-20}{264}
{40:Number of measurements:,-20}{265}
{40:Number of T1 errors:,-20}{268}
{40:Number of 2T1 errors:,-20}{270}
{40:Min:,-20}{272}{278}
{40:Max:,-20}{273}{278}
{40:Average:,-20}{274}{278}
{40:Total:,-20}{271}{278}
{40:Limit of the average:,-20}{275}{278}
{40:Standard deviation:,-20}{276}
{40:CPG mode:,-20}
{58}
{40:Result:,0}{263}
{40:Measurements:,-20}
{277}
.......................................
--------------------------------------{143:0c}
164
31. WORKING MODES – DENSITY
Working mode < Density> enables determining density of solids, liquids
and materials of high viscosity. The density is determined on basis of
Archimedes principle, according to which any floating object displaces its
own weight of fluid. The density mode also enables utilizing a pycnometer
for determining density of liquids.
31.1. Starting the working mode
Procedure:
on-screen key, located
• While in main window of the software, press
in the top bar of the window, which opens submenu <Working Modes>
containing list of available working modes,
• Select working mode < Density>, the software automatically returns
to displaying the main window, and the top bar indicates the icon of
selected working mode,
• Simultaneously, the workspace of the display indicates a message:
<Start estimating density>.
31.2. Local setting of a working mode
Local settings for the working mode <
on pressing a hot key <
Density> are accessible
Local parameters>:
Standard liquid
Function dedicated for determining the standard liquid.
There are three options: water, alcohol and other. If option
“other” is selected, then its density should be specified. In
case of the other two types of liquids, their ensity values
are implemented in the software
Temperature
Parameter of the standard liquid inserted by the scale
user. Declared temperature of the standard liquid
automatically determines its density based on a table of
liquid densities. In case of the liquid type “Other”, the
temperature parameter is not applicable, the density value
is inserted manually
Standard liquid
density
Parameter designed for manual determining the density
of standard liquid in [g/cm3]
Sinker volume
Parameter implemented for manual determining the
volume of a sinker expressed [cm3]
165
Ask about sample
number
Function ordering inserting number of a sample before
initaining the test procedure
Pycnometer mass
Parameter designed for manual determining mass of a
pycnometer expressed in [g]. If inserted value is equal
to „0” then on test procedure start, the pycnometer mass
shall be measured.
Pycnometer density
Parameter intended for manual determining volume
of the pycnometer expressed in [cm3]
Unit
Weighing unit set to read the measurement result. This
weighing unit is used for presenting measurement result,
data in reports, databases and summaries.
Save mode
Detailed description in ch. 24.2 of the user manual
Checkweighing
Detailed description in ch. 24.4 of the user manual
Tare mode
Detailed description in ch. 24.5 of the user manual
Statistics
Detailed description in ch. 24.7 of the user manual
31.3. Carrying out density determination procedure
Working mode < Density> enables determining density in 4 different
methods, depending on material which density should be measured.
Methods of density determination: Liquid, Solids, Pycnometer, Porous
material.
31.3.1. Determining density of liquids
Density of liquid is determined by measuring mass of a sinker with
determined volume. First, the sinker has to be weighed in the air, and
then in liquid of which the density should be measured.
The difference between the two measurements is displacement weight,
which is used by scale software to calculate the density of tested liquid.
Before starting the measurement, the sinker’s volume should be inserted
to scale’s memory. The sinker’s volume is given on its hook.
166
Process course:
•
Press <
Local parameters> key to enter the setting of local
parameters in density mode.
•
Press <
Sinker volume> in order to insert the volume of the
3
sinker (given in [cm ]) which is immersed in the tested liquid.
•
On specifying the parameters exit to main menu of the density
mode by pressing
•
key.
In order to start density determination of liquid, press
<
Determine liquid density> key, using a pre-defined hot
keys on terminal’s display.
Caution:
Ask about sample number> function
If in the local parameters, <
is enabled, then on initiating the process, the system asks for inserting
the number of tested sample. The inserted sample number is linked to
the process data and saved in the database.
•
The first phase of the density determination of liquid is measurement
of sinker’s mass in the air. Place the sinker on the scale’s weighing
platform. On obtaining stable measurement result, accept it by
pressing
•
key.
Next, place on scale’s weighing platform tested liquid with immersed
sinker. On obtaining stable measurement result, carry out the
measuring process, and accept it by pressing
•
On carrying out the second measurement, the scale determines
density of tested liquid and indicates the result on terminal’s display.
If the user needs a report from the density determination process, it
can be printed on a plugged printer by pressing
density determination process is then completed.
•
key.
key. The
A report from density determination of liquid is saved in <
Density> database. The report is named by process date.
167
31.3.2. Determining density of solids
Density of solids is determined by weighing a solid object in two different
medium: in the air and in auxiliary liquid with determined density. The
difference between the two measurements is displacement weight, which
is used by scale software to calculate the density of tested solid.
Before starting the measurement select <
Local parameters> menu
and choose < Standard liquid> to be utilized in the density determination
process. Also determine the temperature of the auxiliary liquid. Declaring the
temperature of the auxuliary liquid enables matching its density to a table of
liquid densities. In case of selecting liquid type “Other”, its density value
should be specified in parameter <
Standard liquid density>. Here, the
< Temperature> parameter is specified only for information purpose o
f the report.
Process course:
•
Press <
Local parameters> key to enter the setting of local
parameters in density mode.
•
Press < Standard liquid> key to select the auxiliary liquid used
for the density determination procedure. If the auxiliary liquid is other
than “Water” or “Alcohol”, then select “Other” from the available list.
•
Press <
Temperature> key and specify the temperature of the
auxiliary liquid [°C]. Accept inserted value by pressing
key.
•
If „Other” liquid has been selected, then press <
Standard liquid
density> and insert the density value of the auxiliary liquid expressed
3
in [g/cm ] for the specified temperature of the measurement.
•
On specifying the parameters exit to main menu of the density
mode by pressing
•
key.
In order to start density determination of a solid, press <
Determine solid density> key, using a pre-defined hot keys on
terminal’s display.
168
Caution:
Ask about sample number> function
If in the local parameters, <
is enabled, then on initiating the process, the system asks for inserting
the number of tested sample. The inserted sample number is linked to
the process data and saved in the database.
•
The first phase of the density determination of solid, is measurement
of the solid object in the air. Place the object on the scale’s weighing
platform. On obtaining stable measurement result, accept it by
key,
pressing
•
Next, in the auxiliary liquid place scale’s weighing platform with
immersed tested solid object. On obtaining stable measurement
result, carry out the measuring process, and accept it by pressing
key,
•
On carrying out the second measurement, the scale determines
density of tested solid and indicates the result on terminal’s display.
If the user needs a report from the density determination process, it
can be printed on a plugged printer by pressing
density determination process is then completed.
•
key. The
A report from density determination of solids is saved in <
Density> database. The report is named by process date.
31.3.3. Determining density of pycnometer
Pycnometer- it is a glass vessel which enables precise measurement of liquid
mass at a precisely determined volume. A measurement method applying a
pycnometer is one of the simplest means of determining density of liquids
(densimetric method).
The key component of a pycnometer is a ground-in stopper with dumped
capillary tube, which allows easy observation of the level of liquid contained
in the vessel. Before the measurement process, the pycnometer is
intentionally overfilled with tested liquid, then it is closed tightly with
a stopper and thermally stabilized.
169
The excess of liquid pouring through the capillary tube is removed with an
absorbent paper. Then, the vessel is immediately placed on a scale, and its
mass is determined as quickly as possible. During the mass measurement,
due to contraction of the volume of liquid its level usually Cautionably
decreases in the capillary tube, but this does not matter if at the time of
placing instrument on the scale, it was completely filled and had correct
temperature. Small diameter of the capillary tube prevents evapouration of
the liquid from the vessel, and therefore it does not affect the measurement
result.
Before starting the density determination using a pycnometer, data on its
volume and mass should be inserted to scale’s memory. If pycnometer’s
mass is not specified in the local parameters, than the process starts with
determining mass of an empty pycnometer.
Process course:
•
Press <
Local parameters> key to enter the setting of local
parameters in density mode.
•
Press <
Pycnometer mass> key to insert the mass of a
pycnometer used for determining density of tested liquid.
Pycnometer’s mass is expressed in grams [g]. Accept inserted
value by pressing
•
key.
Press <
Pycnometer volume> to specify the volume of the
pycnometer used for determining density of tested liquid. The volume
3
is expressed in grams [cm ]. Accept inserted value by pressing
key.
•
Press < Temperature> key and specify the temperature in which
the test of liquid density determination is carried out. The temperature
value is expressed in [°C]. Accept inserted value by pressing
key. The temperature serves here for information purpose, and it is
placed on reports from carried out processes.
•
On specifying the parameters exit to main menu of the density
mode by pressing
•
key.
In order to start density determination using a pycnometer, press
Determine pycnometer density> key, using a pre-defined
<
hot keys on terminal’s display.
170
Caution:
Ask about sample number> function
If in the local parameters, <
is enabled, then on initiating the process, the system asks for inserting
the number of tested sample. The inserted sample number is linked to
the process data and saved in the database.
•
The first phase of density determination process is weighing a
pycnometer (if its mass has been determined as “0” in the local
parameters) – place an empty pycnometer on scale’s weighing
platform. On obtaining stable measurement result, accept it by
key. If mass of a pycnometer has been determined
pressing
Pycnometer mass>, then this phase of the
in parameter <
process is omitted,
•
Then place on the scale’s weighing platform a pycnometer filled
with liquid. On obtaining stable measurement result, carry out the
measuring process, and accept it by pressing
key,
•
On carrying out the measurement of the pycnometer with tested
liquid, the scale determines the density of the liquid, and the density
determination result is indicated on terminal’s display. If the user
needs a report from the density determination process, it can be
printed on a plugged printer by pressing
determination process is then completed,
•
key. The density
A report from density determination using a pycnometer is saved
in <
Density> database. The report is named by process date.
31.3.4. Determining density of a porous body
Determining density of a porous body is carried out in three phases:
• Weighing a porous body in the air,
• Weighing in the air of a porous body impregnated with oil,
• Weighing in auxiliary liquid of a porous body impregnated with oil.
In case of porous objects, it is necessary to carry out an oil bath, which fills
and closes the pores of the material before its actual weighing in the auxiliary
liquid.
171
Process course:
•
Press <
Local parameters> key to enter the setting of local
parameters in density mode.
•
Press < Standard liquid> key to select the auxiliary liquid used
for the density determination procedure. If the auxiliary liquid is other
than “Water” or “Alcohol”, then select “Other” from the available list.
•
Press <
Temperature> i key and specify the temperature of the
auxiliary liquid [°C]. Accept inserted value by pressing
key.
•
If „Other” liquid has been selected, then press <
Standard liquid
density> insert the density value of the auxiliary liquid expressed in
3
[g/cm ] for the specified temperature of the measurement.
•
On specifying the parameters exit to main menu of the density
mode by pressing
•
key.
In order to start density determination of porous body, press <
Determine porous body density> key, using a pre-defined hot keys
on terminal’s display.
Caution:
Ask about sample number> function
If in the local parameters, <
is enabled, then on initiating the process, the system asks for inserting
the number of tested sample. The inserted sample number is linked to
the process data and saved in the database.
•
•
•
The first phase of the density determination of a porous body in the
air. Place the object on the scale’s weighing platform. On obtaining
key,
stable measurement result, accept it by pressing
Then immerse the tested porous body in oil to fill its pores. Place
the tested porous body impregnated with oil on scale’s weighing
platform. On obtaining stable measurement result, carry out the
key,
measuring process, and accept it by pressing
In the third step, weight the tested porous object impregnated with
oil in the auxiliary liquid. Place the tested object in the auxiliary liquid,
on scale’s weighing platform and immerse both in the auxiliaty liquid.
On obtaining stable measurement result, carry out the measuring
process, and accept it by pressing
172
key,
•
On carrying out the third measurement, the scale automatically
determines the density of the porous body, and indicates the result
on terminal’s display. If the user needs a report from the density
determination process, it can be printed on a plugged printer by
pressing
completed,
•
key. The density determination process is then
A report from density determination of a porous body is saved in
<
Density> database. The report is named by process date.
31.4. Reporting from completed density determination processes
On completing each density determination process, the scale’s software
automatically generates a report.
Caution:
Devices /
Printer /
Printouts /
Density
Submenu: “
printout template” enables optional configuration of report template
(see ch. 16.2.3 of this user manual).
Default form of the report from density determination template:
-------------------------------------------Density
-------------------------------------------{40:Operator:,-25}{75}
{40:Start date:,-25}{155}
{40:End date:,-25}{156}
{40:Standard liquid:,-25}{158}
{40:Method:,-25}{157}
{40:Weighing 1:,-25}{165}
{40:Weighing 2:,-25}{166}
{40:Density:,-25}{162}{163}
--------------------------------------------
The report from each completed density determination process is
Density Reports>, where
simultaneously saved in the database of <
the files are named by their date and hour of process execution. List of
data for the density determination process – see ch. 35.5.4 of this user
manual.
173
31.5. Table of density parameter for water
T/°C
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0.99973
0.99963
0.99953
0.99941
0.99927
0.99913
0.99897
0.99880
0.99862
0.99843
0.99823
0.99802
0.99780
0.99756
0.99732
0.99707
0.99681
0.99654
0.99626
0.99597
0.99567
0.99972
0.99962
0.99951
0.99939
0.99926
0.99911
0.99896
0.99879
0.99860
0.99841
0.99821
0.99800
0.99777
0.99754
0.99730
0.99704
0.99678
0.99651
0.99623
0.99594
0.99564
0.99971
0.99961
0.99950
0.99938
0.99924
0.99910
0.99894
0.99877
0.99859
0.99839
0.99819
0.99798
0.99775
0.99752
0.99727
0.99702
0.99676
0.99648
0.99620
0.99591
0.99561
0.99970
0.99960
0.99949
0.99937
0.99923
0.99908
0.99892
0.99875
0.99857
0.99837
0.99817
0.99795
0.99773
0.99749
0.99725
0.99699
0.99673
0.99646
0.99617
0.99588
0.99558
0.99969
0.99959
0.99948
0.99935
0.99922
0.99907
0.99891
0.99873
0.99855
0.99835
0.99815
0.99793
0.99771
0.99747
0.99722
0.99697
0.99670
0.99643
0.99614
0.99585
0.99555
0.99968
0.99958
0.99947
0.99934
0.99920
0.99905
0.99889
0.99871
0.99853
0.99833
0.99813
0.99791
0.99768
0.99744
0.99720
0.99694
0.99668
0.99640
0.99612
0.99582
0.99552
0.99967
0.99957
0.99946
0.99933
0.99919
0.99904
0.99887
0.99870
0.99851
0.99831
0.99811
0.99789
0.99766
0.99742
0.99717
0.99691
0.99665
0.99637
0.99609
0.99579
0.99549
0.99966
0.99956
0.99944
0.99931
0.99917
0.99902
0.99885
0.99868
0.99849
0.99829
0.99808
0.99786
0.99764
0.99740
0.99715
0.99689
0.99662
0.99634
0.99606
0.99576
0.99546
0.99965
0.99955
0.99943
0.99930
0.99916
0.99900
0.99884
0.99866
0.99847
0.99827
0.99806
0.99784
0.99761
0.99737
0.99712
0.99686
0.99659
0.99632
0.99603
0.99573
0.99543
0.99964
0.99954
0.99942
0.99929
0.99914
0.99899
0.99882
0.99864
0.99845
0.99825
0.99804
0.99782
0.99759
0.99735
0.99710
0.99684
0.99657
0.99629
0.99600
0.99570
0.99540
31.6. Table of density parameter for ethyl alcohol
T/°C
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0.79784
0.79699
0.79614
0.79530
0.79445
0.79360
0.79275
0.79190
0.79105
0.79020
0.78934
0.78849
0.78763
0.78678
0.78592
0.78506
0.78420
0.78334
0.78248
0.78161
0.78075
0.79775
0.79691
0.79606
0.79521
0.79436
0.79352
0.79267
0.79181
0.79096
0.79011
0.78926
0.78840
0.78755
0.78669
0.78583
0.78497
0.78411
0.78325
0.78239
0.78153
0.78066
0.79767
0.79682
0.79598
0.79513
0.79428
0.79343
0.79258
0.79173
0.79088
0.79002
0.78917
0.78832
0.78746
0.78660
0.78575
0.78489
0.78403
0.78317
0.78230
0.78144
0.78058
0.79758
0.79674
0.79589
0.79504
0.79419
0.79335
0.79250
0.79164
0.79079
0.78994
0.78909
0.78823
0.78738
0.78652
0.78566
0.78480
0.78394
0.78308
0.78222
0.78136
0.78049
0.79750
0.79665
0.79581
0.79496
0.79411
0.79326
0.79241
0.79156
0.79071
0.78985
0.78900
0.78815
0.78729
0.78643
0.78558
0.78472
0.78386
0.78299
0.78213
0.78127
0.78040
0.79741
0.79657
0.79572
0.79487
0.79402
0.79318
0.79232
0.79147
0.79062
0.78977
0.78892
0.78806
0.78720
0.78635
0.78549
0.78463
0.78377
0.78291
0.78205
0.78118
0.78032
0.79733
0.79648
0.79564
0.79479
0.79394
0.79309
0.79224
0.79139
0.79054
0.78968
0.78883
0.78797
0.78712
0.78626
0.78540
0.78454
0.78368
0.78282
0.78196
0.78110
0.78023
0.79725
0.79640
0.79555
0.79470
0.79385
0.79301
0.79215
0.79130
0.79045
0.78960
0.78874
0.78789
0.78703
0.78618
0.78532
0.78446
0.78360
0.78274
0.78187
0.78101
0.78014
0.79716
0.79631
0.79547
0.79462
0.79377
0.79292
0.79207
0.79122
0.79037
0.78951
0.78866
0.78780
0.78695
0.78609
0.78523
0.78437
0.78351
0.78265
0.78179
0.78092
0.78006
0.79708
0.79623
0.79538
0.79453
0.79368
0.79284
0.79198
0.79113
0.79028
0.78943
0.78857
0.78772
0.78686
0.78600
0.78515
0.78429
0.78343
0.78256
0.78170
0.78084
0.77997
174
32. WORKING MODES – ANIMAL WEIGHING
Working mode <
Animal weighing> enables weighing objects which
do not stabilize if placed on scale’s weighing platform and while carrying out
weighing process. Weighing process is achieved by implementing parameter
of time for stability of measurement, which is set in global parameters of the
working mode. This working mode is mainly utilized for weighing different
kinds of animals. The mode may be controlled automatically or manually – i.e.
the weighing process is triggered manually or automatically.
32.1. Starting the operating mode
Procedure:
• While in main window of the software, press
on-screen key, located
in the top bar of the window, which opens submenu <Working Modes>
containing list of available working modes,
Animal weighing >, the software
• Select working mode <
automatically returns to displaying the main window, and the top bar
of selected working mode,
indicates the icon
• Simulataneously, an additional hot key is activated on the far right side
of the bottom tool bar:
Start animal weighing process
32.2. Local setting of a working mode
Local settings for the working mode <
on pressing a hot key <
Animal weighing> are accessible
Local parameters>:
Checkweighing
Detailed description in ch. 24.4 of the user manual
Tare mode
Detailed description in ch. 24.5 of the user manual
Labelling mode
Detailed description in ch. 24.6 of the user manual
Statistics
Detailed description in ch. 24.7 of the user manual
175
Averaging time
Automatic mode
Declaration of process duration in seconds (from
1s to 90s) – measurements carried out in set time
interval are used to calculate mean value, which is
the result of the measurement
Operation mode, in which the scale automatically
begins the following measuring process, if the load
placed on scale’s weighing platform exceeds value
of mass set in LO threshold.
32.3. Carrying out animals weighing procedure
• Enter the working mode <
32.1 of this user manual,
Animal weighing> according to ch.
• Should the tested animal be weighed in a container, load the container
of scale’s weighing platform and tare its mass,
• On placing the tested animal on the scale’s weighing platform (in the
key (Process start), which displays a
tarred container), press
message box indicating course of the process,
• The message box contains data on:
o Progress bar indicated in %,
o Value of averaging time interval, set in loacal parameters,
o
key enabling aborting the process,
• On completing the measuring process, the value of measured result
is locked in the message box,
• Confirm completing the process by pressing
key.
33. WORKING MODE – VEHICLE SCALE
Working mode <
Vehicle Scale> enables weighing trucks, determining
mass of loads based on weighments carried out on entering and exiting a
weighbridge.
33.1. Working mode activating procedure
• When in the main software window press
pictogram located in the
top bar of the display which opens a submenu <Working modes>
containing list of available working modes,
176
• Select working mode <
Vehicle Scale>, the software automatically
returns to the main window:
Where:
Select a vehicle
Default transaction type
Local parameters of a working mode
Select an open transaction
Select a product
Select a client
Abort an ongoing transaction
177
33.2. Working mode local settings
The local settings of working mode <
by pressing an hot-key <
Vehicle Scale> are accessed
Local settings>:
Default transaction
type
Selecting a default transaction type. Available
settings: Entrance, Exit, Control weighment.
Select vehicle
Declaring the means for selecting a vehicle.
Available options: From list, From hand, By name,
By code.
Print report
Enabling automatic report printout on completing
a vehicle transaction.
33.3. Vehicle transaction course
Starting a vehicle transaction, requires that a logged operator features
appropriate access level for carrying out the transaction.
Caution:
In order to start a transaction, the access level of a logged user must be at
least <operator>. IF the logged user or anonymous user feature access level
<none> then on starting a transaction the software displays a message:
<No authorization>.
An operator can carry out three types of transactions:
• Entrance,
• Exit,
• Control weighment.
33.3.1. Entrance / Exit transaction
Changes of transaction type are carried out by pressing
Entrance transaction
Exit transaction
178
, where:
Procedures for carrying out an entrance transaction and an exit transaction
are the same, therefore the further part of the user manual contains
description of an entrance transaction only.
Before starting a transaction enter to scale memory general parameters
of the working mode (see point 33.2 of this user manual).
Procedure:
to select a required vehicle, which opens the
• Press hot-key
following window:
Where:
- A vehicle with saved registration number
PL 45332
- Transaction type (entrance)
Entry
Confirm weighing 1
- A message for an operator. The scale waits
for accepting the weighment on entrance
Caution:
1. Additionally, an operator can:
• Assign a product to a transaction by pressing
179
button,
• Assign a client to a transaction by pressing
button.
2. Before starting a transaction, first an operator should select a
vehicle to be weighed. Otherwise the scale displays a message
Vehicle not selected>.
<
• After the vehicle enters onto the weighbridge (entrance), and stabilizing
of the measuring result, accept the measurement by pressing
ENTER/PRINT button, which opens the following window:
Where:
PL 45332
8880 kg
2013.02.26 8:37
- A vehicle with saved registration number, accepted
mass on entrance and time and date of entrance
weighment
- Transaction type (exit)
Exit
Confirm weighing 2
- Message for an operator. The scale waits
for accepting the exit weighment
0 kg
- Mass of the load
• At the same time, a printer connected to the scale prints an
“Entrance ticket”.
180
Caution:
A default format of an „Entrance ticket” template is described in point
33.5 of this user manual.
• After the same vehicle enters onto the weighbridge (entrance) and
stabilizing of measurement result, accept the measurement by pressing
ENTER/PRINT button which opens a process summary window:
Caution:
The non-declared transaction items are represented by dashes,
correspondingly denoting:
• Missing code assigned to a vehicle,
• Missing product assigned to a transaction,
• Missing client assigned to a transaction.
• At the same time, a printer connected to the scale prints a ticket
“Exit ticket”.
Caution:
1. In case of declaring an automatic printout of a report, on completing
a vehicle transaction the scale orders printing a “Report from
Vehicle Scale” together with the printout of the “Exit ticket”.
2. A default format of the printout template of the “Exit ticket” and a
“Report from Vehicle Scale” are described in point 33.5 of this
user manual.
• After accepting the summary window of the “Report from Vehicle
Transaction” the software automatically returns to the main window.
181
33.3.2. Control weighment transaction
Changes of transaction type are carried out by pressing
, where:
Entrance
Exit
Control weighment
Before starting a transaction enter to scale memory general parameters
of the working mode (see point 33.2 of this user manual).
Procedure:
• Press hot-key
following window:
to select a required vehicle, which opens the
Where:
- A vehicle with saved registration number
PL 45332
- Transaction type (control weighment)
Control weighment
182
Confirm weighing 1
- A message for an operator. The scale waits
for accepting the control weighment
Caution:
Additionally, an operator should determine:
−
Assign a product to a transaction by pressing
−
Assign a client to a transaction by pressing
button,
button,
• After the vehicle enters onto the weighbridge (control weighment)
and stabilizing of the measuring result, accept the measurement by
pressing ENTER/PRINT button, which opens a window on process
summary:
Caution:
The non-declared transaction items are represented by dashes,
correspondingly denoting:
•
•
•
•
Missing code assigned to a vehicle,
Missing product assigned to a transaction,
Missing client assigned to a transaction,
Missing value of load mass.
• At the same time, a printer connected to the scale prints a ticket
“Control weighment ticket”.
Caution:
A default format of the printout template of the “Control weighment ticket”
is described in point 33.5 of this user manual.
183
• After accepting the summary window of the “Report from Vehicle
Transaction” the software automatically returns to the main window.
33.4. Open transactions table
A scale user is able to start an optional number of transactions at the same
time. All opened (unfinished) transactions are temporarily saved in the “table
of opened transactions”. A list of opened transactions to be completed is
accessed by pressing a hot-key
display.
located in the bottom bar of the scale
Caution:
If a user attempts to choose a vehicle for which a transaction is already
opened, then the software displays a message box:
33.5. Printout templates for an ongoing transaction
During ongoing vehicle transaction the user can print transaction tickets
(reports) with the use of a printer connected to the scales.
List of standard printouts for „Vehicle scales” operating mode
•
•
•
•
Entrance Ticket Printout Template
Exit Ticket Printout Template
Control Weighment Ticket Printout Template
Report from Vehicle Scale Printout Template:
184
Default content of printout templates:
Entrance Ticket Printout
Template:
Exit Ticket Printout
Template:
Control Weighment Ticket
Printout Template:
Report from Vehicle Scale
Printout Template:
---------------------------------------Entrance ticket
---------------------------------------{40:Date:,-20}{4}
{40:Vehicle:,-20}{210}
{40:Mass on entrance:,-20}{7}{11}
Signature.............................
------------------------------------------------------------------------------Exit ticket
---------------------------------------{40: Date:,-20}{4}
{40: Vehicle:,-20}{210}
{40: Mass on exit:,-20}{7}{11}
Signature.............................
------------------------------------------------------------------------------Control weighment ticket
---------------------------------------{40: Date:,-20}{4}
{40: Vehicle:,-20}{210}
{40: Mass:,-20}{7}{11}
Signature.............................
------------------------------------------------------------------------------Report from Vehicle Scale
---------------------------------------{40:Start date:,-20}{213}
{40:End date:,-20}{214}
{40:Vehicle:,-20}{210}
{40:Mass on entrance:,-20}{215}{11}
{40:Mass on exit:,-20}{216}{11}
{40:Mass of load:,-20}{217}{11}
Signature.............................
----------------------------------------
Caution:
/
Devices /
Printer /
Printouts” submenu user can
„
freely modify printout standards (see point 16.2.3 of this manual).
185
33.6. Executed transactions – reporting
Each completed transaction is automatically saved and stored in the database
of <
Reports from Vehicle Scale>.
Each database record features the following data:
• Vehicle registration number,
• Transaction type (entrance, exit or control weighment),
• Transaction status (loading or unloading).
Additionally, the type and status of a transaction are marked by
a corresponding colour:
Green
Yellow
Red
– Transaction completed successfully
– Transaction not completed
– Transaction aborted
Detailed list of data for an executed vehicle transaction – see point 35.5.7 of
this manual.
34. DATABASES
Scale databases hold different data:
Products
Operators
Clients
Dosing processes
Formulations
Vehicles
Identification processes
Packages
Warehouses
186
Labels
Universal variables
Extra variables
Images
In order to enter <
<
Databases>, press
and choose
Databases>.
34.1. Database configuration.
<
Databases configuration> submenu enables the user to:
• Set databases availability
• Categorize product
• Declare data operation for databases: product, operators, clients, extra
variables
• Change databases records preview
• Import databases from a memory stick to the scale
• Export databases to a memory stick
Caution:
Configuration can be executed by a user with “Administrator” authority.
34.1.1. Databases accessibility
<
Databases accessibility> submenu allows to declare databases which
are to be available for the user.
Procedure:
• Enter submenu: „ Databases /
according to ch. 34 of this manual,
• Choose <
databases.
databases configuration”,
Databases accessibility> to view a list of available
187
Where:
- Accessible database
- Inaccessible database
34.1.2. Categories
<
Categories> serves to divide product databases into folders
(categories) in order to optimally group particular records.
To operate product categories <
Product categories> parameter needs
to be activated. The parameter is located in „
/ categories” submenu.
Databases configuration
How to create databases categories – procedure:
• Enter „
Databases configuration/
Database of categories”,
/
• Press
Categories
button to see <Create new record?> message.
button to confirm, the program will automatically edit the
• Press
new position field.
• Edit the <
Name> position and write a desired name of the category.
Procedure of assigning a product to a category
• Following point 34 of this manual enter <
• Enter <
Databases>,
Products> database and choose a demanded record,
• Chose <
Category> position to open categories that have already
been created,
• Choose a demanded position and exit in order to start weighment.
Caution:
Product that haven’t been given a category are automatically located in a
Not assigned>.
folder <
188
34.1.3. Database variables operation
The user can turn on/off operation of database variables for:
• Product database,
• Operators database,
• Clients database.
Procedure:
• Enter <
Database configuration> submenu,
• Choose a demanded database to view a list of variables with
accessibility attribute.
Where:
- Accessilble variable
- Inaccessible variable
•
Set accessibility of a demanded variable and exit in order to start
weighment.
34.1.4. Change name of an extra variables database
The user can change a name of an extra variables chart (table) in the
following cases:
• When using programmable buttons <Choose an extra variable>,
• When using < Choose an extra variable from database> function
during an identification process.
Procedure:
• Enter submenu: „
Databases configuration /
Extra variables”,
• Assign to a demanded variable the name of a database which will be
shown when the above mentioned function is in use.
189
34.1.5. Change database records preview
<
Records preview> submenu allows to swap between two different
views of the displayed records: „list” or „tiles”.
Procedure:
• Enter submenu: „
preview”,
Databases configuration /
Records
• Change records view for a demanded database.
Where:
- List
- Tiles
34.1.6. Databases export / import
The user can export/import all databases with the use of a memory stick.
Database export procedure:
• Put a memory stick into USB port of a scale,
Database configuration /
Export” submenu to start
• Enter: „
automatic database export from scales to a memory stick.
• After the procedure has been completed a following message is
displayed „Operation completed successfully”.
Database import procedure:
• Put a memory stick into USB port of a scale,
Database configuration /
Import” submenu to start
• Enter: „
automatic database import from a memory stick.
• After the procedure has been completed a following message is
displayed „Operation completed successfully”.
190
34.2. Searching databases
Users can quickly search databases according to the following criteria:
•
Name,
•
Code.
34.2.1. Quick name search
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of the manual,
Products>,
, then an editing field appears <Search by name>
• Press
with the screen keyboard,
• Inscribe the name of a product or its part and press
.
• The program will automatically edit the required product.
34.2.2. Quick code search
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of the manual,
Products>,
, then an editing field appears <Search by code>
• Press
with the screen keyboard,
• Inscribe the name of a product or its part and press
• The program will automatically edit the required product.
191
.
34.3. Adding new items in databases
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter database <
• Press
Products>,
, then the message is displayed: <Create new record?>,
, the program automatically enters
• Confirm it by pressing
edit window of a new record.
Caution:
Adding new records in databases is possible only by logged-in
administrators.
34.4. Deleting items in databases
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of the manual,
Products>,
• Give a long press to the item, then the context menu is displayed,
• Press <Delete>, then a message is displayed:
<Are you sure you want to delete?>,
• Confirm it by pressing
.
Caution:
Deleting records in databases is possible only by logged-in administrators.
34.5. Printing items from databases
Users can print any record in databases.
Procedure:
• Enter the submenu <
• Enter <
Databases> according to ch. 34 of the manual,
Products> and press the required item,
192
• After editing the required record press
in the top bar of the display,
• If a printer is connected information about the selected product
is printed.
Caution:
Default printout templates for printing records from different databases
are described in ch. 16.2.3 of this manual.
34.6. Context menu
Context menu enables the user to a quick access to database functions.
Pressing a demanded database element (submenu) for about 2 seconds is
required in order to activate a context menu.
Context menu for each of the databases displays the following list of
functions:
Where:
Open
Opening a content of a folder
Import
Import of a database from a memory stick to a scale
Export
Export of a database to a memory stick
Delete all
Deleting all records of a particular database
Cancel
Cancelling (turning off) the context menu
The following list of functions will be displayed after activation of a context
menu for one of a given database records:
193
Where:
Edit record
Delete record
Printout of information about a record
Make a record copy
Cancel (turn off) the context menu
Edit
Delete
Print
Copy
Cancel
34.7. Database edit window
The database edition can be performed by an administrator.
34.7.1. Operators’ database
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Operators> and press the required position.
Record of operator:
Name
Operator name
Code
Operator code
Password
Password to log on (max. 16 characters)
Access level
Authorization access level
Card number
Transponder card reader for Loggingg on
194
Working modes
Assigning a working mode to an operator
Automatically
Automatic mode: Loggingg of a user
automatically enables a working mode recently
enabled by this user
Change working
mode
Permanent assigning a specific working mode
to a logged operator. Setting “None” disables
the function.
Identification
process
Assigning an identification process to a logging
operator
34.7.2. Database of products
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Products>and press the required position.
Product record:
Name
Product name
Code
Product code
EAN code
Product barcode
Mass
1)
Nominal product mass
Batching outputs
2)
Bulk batching output
Correction 1
2)
Correction 2
2)
Correction 3
2)
Correction 4
2)
Declaring numbers of outputs for fine dosing
2)
Declaring numbers of outputs for bulk dosing
Value of dosing correction for weighing
platform no. 1
Value of dosing correction for weighing
platform no. 2
Value of dosing correction for weighing
platform no. 3
Value of dosing correction for weighing
platform no. 4
195
Maximum correction
2)
value
Min
3)
Max
Maximal value of dosing correction
Minimum mass for checkweighing
3)
Maximum mass for checkweighing
Deviation type
4)
Low deviation
4)
High deviation
4)
Declaring deviation type: measuring unit of a
value in [%]
Low deviation from mass (mass of an
ingredient in a formulation)
High devition from mass (mass of an ingredient
in a formulation)
Tare
Tare value (it is preset automatically after
selecting a product)
Price
Unit price
Currency
Currency assigned to a product price
CPG mode
5)
Submenu with data declared in the working
mode CPG (see ch. 30.4 of the manual)
Number of validity
dates
Number of days to calculate expiry date
Additional days of
expiry period
Offset of number of days of assortment expiry
date
Date
Constant product date
VAT
Value Added Tax in [%]
Ingredients
Dialogue box for entering ingredients
Label
Basic label template attributed to a product
C Label
Cumulative label template attributed to a
product
CC Label
Cumulative of cumulative label template
attributed to a product
Category
Category assigned to a product
Graphic (image) assigned to a product
Identification process
Identification process assigned to a product
196
1) – Variable name dependant on an enabled working mode. In case of working
modes: Weighing, Dosing, Formulation, Density, Animal weighing the variable
takes the name: “Mass”. In case of the working mode “Parts counting” the
variable takes the name: “Part mass”. In case of the working mode “Percent
setup (Deviations)” the variable takes the name “Standard mass”.
2) – The variables accessible only in the working mode “Dosing”.
3) – The variable inaccessible for a product in the working mode “Formulation”.
4) – The variables accessible for a product only in the working mode “Formulation”.
5) – The variables accessible for a product only in the working mode “CPG”.
34.7.3. Database of clients
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Client> and press the required position.
Client records:
Name
Client’s name
Code
Client’s code
Tax ID
Client’s tax ID
Address
Client’s address
Postal code
Client’s postal code
City
Client’s Town/City
Discount
Client’s discount
Label
Client’s label template
34.7.4. Database of dosing processes
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
197
• Enter <
Dosing processes> and press the required position.
List of data for a selected dosing process:
Name
Dosing process name
Code
Dosing process code
Platform 1
Weighing platform no. 1 determined for a specific terminal
Platform 2 *
Weighing platform no. 2 determined for a specific terminal
Platform 3 *
Weighing platform no. 3 determined for a specific terminal
Platform 4 *
Weighing platform no. 4 determined for a specific terminal
*) – number of weighing platforms depends on determined data in the terminal settings
34.7.5. Database of formulations
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Formulations> and press the required position.
List of data for a specific formulations:
Name
Formulation name
Code
Formulation code
Ingredients
Defining ingredients of a formulation
Number of
ingredients
Previewing number of created ingredients in a formulation
Formulation
mass
Previewing total mass of a formulation
198
Type of charge
Type of measuring charge of a formulation
Charge
Measuring chanrge of a formulation
34.7.6. Database of vehicles
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
Vehicles> and press the required position.
• Enter <
List of data definable for a vehicle:
Name *
Name of a vehicle (registration number)
Code
Vehicle code
Tare
Vehicle tare value (set automatically when selecting
a vehicle record from the database)
Card no.
Transponder card number for selecting a vehicle
Description
Additional vehicle description
*) – When declaring means of selecting a vehicle “From hand”, entering a
new registration number causes automatic adding a new vehicle record
to the database with a name corresponding to the registration number.
34.7.7. Identification processes database
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Identification processes> and press the required position.
199
List of data for a selected identification process:
Name
Identification process name
Code
Identification process code
Process creator
Submenu used for defining (creating) an identification
process
34.7.8. Database of packages
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Packages> and press the required position.
Package record:
Name
Package name
Code
Package code
Mass
Package weight (set automatically after choosing
after choosing a package from the database)
34.7.9. Database of warehouses
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Warehouses> and press the required position.
Warehouse record:
Name
Warehouse name
Code
Warehouse code
Description
Additional warehouse description
200
34.7.10. Database of labels
The database comprises templates of labels which users can attribute
to products or clients to operate in labeling mode.
Procedure of editing databases:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Labels> and press the required position.
Label record:
*)
Name
Label name
Code
Label code
Label template*
Label printout template
Printer 1
Printer 1 printout declaration (default setting)
Printer 2
Printer 2 printout declaration
Printer 3
Printer 3 printout declaration
Ways of designing and sending templates to a scale can be found
in APPENDIX C of this manual.
34.7.11. Database of universal variables
The database includes templates of general purpose variables which user
can attribute to screen function buttons
,
,
,
enter any alphanumeric text intended to be printed.
,
in order to
Additionally values of three first universal variables
,
,
are stored
in scales storage. If edited they will be saved in a record of an executed
weighment.
201
Caution:
The procedure of attributing functions to buttons is described in ch. 17.2
of this manual.
Procedure of editing databases:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Universal variables> and press the required position.
Universal variable record:
Code
Universal variable code
Name
Universal variable name, used for printout and/or for a
weighment record
Value
Universal variable value used for printout and/or for a
weighment record
34.7.12. Extra variables database
The database includes templates of extra variables which user
,
,
can attribute to screen function buttons
enter any alphanumeric text intended to be printed.
,
,
in order to
Caution:
Procedure of defining screen function buttons is described in point 17.2 of this
manual.
34.7.13. Images database
The database contains graphics that can be assigned to particular records
of <
Products> database.
202
Creating a new record - procedure:
• Put a memory stick into USB port of a scale,
• Following point 34 of this manual enter: „
• Press
Database /
Images”,
button to see <Create new record?> message,
button to confirm, the program will automatically edit the
• Press
new position.
• Enter <
Name> field and give a demanded name to a graphic.
• Select <
Image> option to open the main folder of a memory stick,
Choose the demanded graphic file. The program will automatically return to
the previous submenu. The chosen graphic and name will be displayed in a
<
Image> field
Caution:
Maintained file formats are *.jpg, *.png, with the optimal (max.) resolution of
150x150 pixels, where:
• for a list record view an optimal resolution is 57x57 pixels;
• for a tile record view an optimal resolution is 133x133 pixels;
35. REPORTS
Software enables the following reports:
Weighments / Alibi
Reports from dosing
Reports from recipes
Controls Reports
Average tare reports
Vehicle scale reports
Density reports
203
Differential weighments reports
To enter <
Reports> menu press
button, which is located in the
window of the terminal, and choose <
Reports> option.
35.1. Reports configuration
Submenu <
Report configuration> allows for:
• declaration of reports, which are to be accessible for the user,
• configuration of a lot number,
• configuration of a batch number.
35.1.1. Reports accessibility
Submenu <
Reports accessibility> allows for declaration of reports that
are to be accessible for the user.
Procedure:
• Enter submenu <
Reports> according to ch. 35 of this manual,
• Select <
Reports accessibility> to view a list of reports with the
accessibility atribute.
Where:
- Accessible report
- Inaccessible report
204
35.1.2. Configuration of a lot number
Procedure:
• Enter submenu: „
Reports /
Reports configuration”
according to ch. 35 of this manual,
• Select <
Lot number> and carry out the configuration.
List of data definable for a lot number:
Name
Change of the lot number name
Template
Lot number template, allows using variables that are
intended for a printout
35.1.3. Configuration of a batch number
Procedure:
• Enter submenu: „ Reports /
Reports configuration”
according to ch. 35 of this manual,
• Select <
Batch number> and carry out the configuration.
List of data definable for a batch number:
Name
Change of the batch number name
Template
Batch number template, allows using variables that
are intended for a printout
35.2. Deleting older data
A user after Loggingg on as administrator can delete older position
in the database of weinghings <
Weighing / Alibi>.
Procedure:
• Enter the submenu <
Reports> according to ch. 35 of the manual,
205
• Enter <
Delete older data>, then an editing field is displayed
<Give year> with the screen keyboard,
• Give a date before which data need to be removed and confirm
it by pressing
,
Caution:
If a user enters a date from the protected period the program displays
a message box: <Wrong value>.
• After entering a date beside protected period the program displays
a message box: <Are you sure you want to delete?>,
the program will start removing data
• After it is confirmed by
and after completing it displays the number of deleted records,
• Press
to leave.
35.3. Weighment date search
Procedure:
• Enter <
Reports> according to ch. 35 of the manual,
• Enter <
Weighing / Alibi>,
, then an editing field appears <Specify year>
• Press
with the screen keyboard,
• Inscribe: year, month, day, hour, minute of weighing and confirm
.
it by pressing
• The program will automatically display the list of weighments putting
at the top the position with the entered date.
35.4. Reports from weighment records
Submenu <
Reports from weighing records> allows for:
• preview of data for particular weighments,
• data filtering,
206
•
•
•
•
printout of a weighments report,
preview and a printout of weighments diagram,
export of weighments database to file,
preview and edition of global weighing counter.
Each weighment sent from scales to a printer or to a computer is saved in
weighments reports. The user may preview data of a particular weighment
(see point 35.5.1 of this manual).
35.4.1. Filtering
The user may filter reports form carried out weighments. The reports will be
printed with the use of a printer connected to scales.
Weighments reports may be filtered according to:
- start date,
- end date,
- operator name,
- product name,
- client name,
- packaging name,
- MIN value,
- MAX value,
- lot number,
- batch number,
- source warehouse name,
- target warehouse name,
- result control,
- platform number.
Procedure:
• Enter submenu: „
records /
Reports /
Reports From weighing
Filtering” according to ch. 35 of this manual,
• Enter a particular filter position and activate <Filtering> option.
Where:
- Active filtering
- Inactive filtering
207
35.4.2. Report printout
The user can print a report after executed weighing series. The reports will be
printed with the use of a printer connected to scales.
Procedure:
Reports /
Reports From weighing
• Enter submenu: „
records” according to ch. 35 of this manual,
• Entering <
Report printout> option enables automatic printout of a
weighments report. The report can be printed with the use of a printer
connected to scale.
Default value of a weighment report template:
---------------------------------------Report from weighments
---------------------------------------{40:Start date:,-20}{101}
{40:End date:,-20}{102}
Weighing records
{100:
(40:Date:,-10)(4)
(40:Mass:,-10)(6) (10)
}---------------------------------------{40:Number of weighments:,-20}{115}
{40:Totalized weighments:,-20}{116}{11}
Caution:
• Submenu: „
Devices /
Printer /
Printout /
Report
From Weighments Printout Template” allows for free modification of a
report template (see point 16.2.3 of this manual);
• If there is too much information printed (too many weighments) the
program displays the following message <Process in progress>.
Percentage (%) notification is added.
35.4.3. Weighments chart
For an executed weighment series <
Weighments chart> option
generates and displays a diagram of measurements distribution in a
measurement value / measurement coordinate system.
208
Example view of a diagram:
Available options, located below the diagram:
100% zoom of a diagram
Zoom out, the diagram gets back to its previous size
Display the previous window
Print the diagram, use a PCL type printer
Save the diagram as a *.bmp file, save it to a memory stick
connected to USB port
35.4.4. Export a database to a file
An operator after a series of weighments can export a database to a file
using a pendrive. Additionally, a user can select data to be exported.
Procedure:
• Connect a pendrive to USB,
• Enter submenu: “
Reports /
ch. 35 of this manual,
Weighing/Alibi” according to
209
• Enter submenu: “
Export database of weighments to a file /
Data selection”, which contains the following options:
Icon
Option
Default value
Automatically *
Date and Time
Mass
Tare
Lot number
Batch number
Operator
Product
Client
Package
Source warehouse
Target warehouse
Checkweighing
Platform number
Statistics: Number of
measurements
Weighing counter
Trade settlement
Vehicle
Universal variable
Extra variable
Custom variable: Value
210
Custom variable: Name
*) – Automatic selection of data to be exported (unfilled fields are omitted)
• After declaring data to be exported go back to the submenu
<
Export database of weighments to a file> and select option
<
Export>. The software automatically initiates exporting of the
database of weighments.
Caution:
Export database
In case a pendrive is not recognized after entering <
of weighments to a file> a message is displayed: <Operation failed>.
• After the operation has been completed: „Operation finished
successfully” is displayed together with the file name
(with extention *.txt) created on the pendrive,
Caution:
The file name consists of a database name and scale factory number,
e.g. <Weighments_239800.txt>.
• Disconnect the pendrive to USB.
File template:
The created file comprises a table with columns separated by tabulation
characters <Tab> in case to allow direct export to a spreadsheet <Excel>.
The table features all data on a completed weighment record declared in the
submenu: „
selection”.
Export database of weighments to a file /
Data
35.4.5. Counter of weighments records
The counter of weighments records contains global number of completed
weighments records carried out on the scale. The user can edit the counter
of weighments records.
211
Caution:
Weighing counter> is conditioned
Access to the editing of the <
by the accessibility settings for this parameter.
Editing procedure:
• Enter submenu <
manual,
Reports> in accordance with point 35 of the user
Weighing counter> which opens an editing window
• Enter option <
with the value of the counter of weighing records and an on-screen
numeric keyboard.
• Insert desired value and accept it by pressing
key.
35.5. Reports preview
35.5.1. Weighments / Alibi
Procedure:
• Enter <
Reports> according to ch. 35 of this manual,
• Enter <
Weighments / Alibi> and press the required position.
Weighment record:
Date
Weighment date
Mass
Weighment result
Tare
Tare value
Product
Product name
Operator
Operator name
Client
Client name
Lot number
Number of produced lot
Batch number
Number of produced batch
212
Source warehouse
Source warehouse name
Target warehouse
Target warehouse name
Package
Package name
Checkweighing
A weighment threshold (MIN, OK or MAX)
Platform number
Platform number to perform weighments
Statistics: Number
of measurements
Statistics: Current number of measurements
Weighing counter
Global counter of weighment records
<
Trade settlement> submenu will be created automatically in a
weighment record when a chosen product is being weighed.
List of <
Trade settlement> submenu data:
Mass
Weighment mass
Mass of the unit
Unit mass of the product
Price
Unit price of the product
VAT
Percent Vat value of the product [%]
Discount
Percent discount for the client [%]
Value
Net charge
Gross
Gross charge
35.5.2. Reports from dosing
Procedure:
• Enter <
Reports> according to ch. 35 of this manual,
213
• Enter <
Reports from dosing> and press the required position.
List of data for a selected report from dosing:
Status
Status of correctness for a completed dosing process
Start date
Start date of dosing process
End date
End date of dosing process
Dosing process
Name of completed dosing process
Operator
Operator preparing a dosing process
Client
Client for which the dosing process is prepared
Number of
Measurements
Number of measurements within a completed dosing
process
35.5.3. Reports from recipes
Procedure:
• Enter <
Reports> according to ch. 35 of this manual,
• Enter <
Report from formulation> and press the required position.
List of data for a specific report from a formulation:
Status
Status of correctness for a completed formulation
Start date
Start date of formula making process
End date
End date of formula making process
Formulation
Name of completed formulation
Operator
Operator preparing a formulation
214
Client
Client for which the formulation is prepared
Number of
Measurements
Number of measurements within a completed
formulation making process
35.5.4. Density reports
Procedure:
• Enter <
Reports> according to ch. 35 of this manual,
• Enter <
Density Reports> and press the required position.
List of data for a specific report from density determination process:
Sample number
Number of sample for which the density is
determined
Start date
Start date of density determination process
End date
End date of density determination process
Density
Value of determined density
Volume
Value of determined volume
Determination metod
Method used in process of determining density
Operator
Operator carrying out density determination
process
Product
Product for which density is determined
Standard liquid
Standard liquid utilized during density
determination process
Standard liquid
density
Density value assigned to the standard liquid
Temperature
Temperature of the density determination
process
Sinker volume
Value of sinker’s volume immersed in tested
liquid
215
Weighing 1
Mass value of the 1 measurement
Weighing 2
Mass value of the 2 measurement
Weighing 3
Mass value of the 3 measurement
Pycnometer mass
Value of pycnometer’s mass utilized during
density determination process
Pycnometer density
Value of pycnometer’s volume utilized during
density determination process
35.5.5. Controls reports
Every control procedure performed on the scale is sent to a printer and
Controls Reports>. Every saved control has its
saved in database <
unique number given at the moment it is completed.
Control number pattern:
X / y y / M M / d d / H H / m m / s s, where:
X - Controle mode:
U – regulation compliant control,
Z – control terminated by an operator,
yy – the last two digits of year,
MM - month,
dd - day,
HH - hour,
mm - minute of control complation,
ss - second of control complation.
Users can view data from subsequent controls.
Procedure:
• Enter submenu <
• Enter database <
Reports> according to ch. 35 of this manual,
Controls Reports> and choose a required one.
216
Inventory of fields in every control:
Batch number
Batch number of tested goods
Status
Control Status/Result
Start Date
Control beginning date
End Date
Control finishing date
Product
Tested product name
Operator
Operator performing the test
X
Average value of weighments
DX
Disqualifying average value
S
Standard deviation
Batch quantity
Number of products in a batch for which a sample
quantity is calculated
Sample quantity
Number of weighments to be performed
35.5.6. Average tare reports
Before starting control <Nondestructive Average Tare> it is possible to
perform the procedure of estimating average tare that consist in weighing
empty packages. Every such procedure is automatically saved in database
Average Tare Reports>. Every report saved in the database is given
<
a unique number after the procedure has been completed.
Report number pattern:
X / y y / M M / d d / H H / m m / s s / T, where:
X - Test mode:
U – regulation compliant test,
Z – test terminated by an operator,
217
yy – the last two digits of year,
MM - month,
dd - day,
HH - hour,
mm - minute of test complation,
mm - second of test complation,
T – average tare estimation.
Users can view data from subsequent average tare tests.
Procedure:
• Enter submenu <
• Enter database <
one.
Reports> according to ch. 35 of this manual,
Average Tare Reports> and choose a required
Inventory of fields in the average tare database:
Product
Product name which packages are tested
Status
Test Status/Result
Date
Date of performing procedure
Tare
The result
S
Standard deviation
0.25 T1
Condition to fulfill
Number of
measurements
Number of measurements of subsequent
packages
Operator
An operator name
35.5.7. Report from vehicle scale
Procedure:
• Enter submenu <
Reports> according to ch. 35 of this manual,
218
• Enter database <
one.
Vehicle Scale Reports> and choose a required
List of data for an individual report from vehicle scale:
Vehicle
Vehicle registration number
Status
Transaction status. Accessible values: Loading,
Unloading
Transaction type
Type of carried out transaction. Accessible values:
Entrance, Exit, Control weighment
Start date
Transaction start date
End date
Transaction end date
Load mass
Mass of load on weighed vehicle
Mass on entrance
Mass of weighed vehicle on entrance
Mass on exit
Mass of weighed vehicle on exit
Operator
Operator carrying out a transaction process
Client
Client assigned to a transaction
Product
Product assigned to a transaction
35.5.8. Differential weighments reports
Procedure:
• Enter submenu <
Reports> according to ch. 35 of this manual,
• Go to submenu <
Differential weighments reports> and press
appropriate position.
219
List of data definable for differential weighments report:
Start date
Start date of the differential weighing process
End date
End date of the differential weighing process
Weighing 1 *
List of data for an executed weighment 1
Weighing 2 *
List of data for an executed weighment 2
Difference
Difference (absolute value) between weighment 1
and weighment 2. In case of processes consisting
of more than two weighments this value is
inaccessible.
Statistics
Statistical data of a differential weighing process.
Submenu is available in case of a process
consisting of more than two weighments.
Weighing: Min
Weighing: Max
Average
Standard
deviation
Minimal weighment value, the lowest value out of
the whole series of measurement
Maximal weighment value, the highest value out
of the whole series of measurement
Average value out of the whole series of
measurement
Average standard deviation out of the whole
series of measurement
*) – in case of process consisting of more than two weighments the data will be
grouped in a folder <Weighing records>.
36. IDENTIFICATION PROCESSES
The user can create his own scales operation algorithm and at the same time
adjust the device to his needs (production department specific, production
line, etc…).
This allows the user to register detailed weighment report with unique data
being stored during the process. Through this it is possible to identify and
localize faulty products (lot of products) of chain manufacturing processes.
220
Identification processes can be carried out in the following working
modes:
• weighment,
• items counting,
• deviations.
Identification processes can be activated by:
• programmable button,
• operator logging,
• product selection.
36.1. Identification process – creation
Identification processes are designed in <
database.
Identification processes>
Caution:
Process identification database mechanisms of edition and record finding are
similar to other databases mechanisms.
Procedure:
• Enter submenu: „
• Press
• Press
position.
Databases /
, to see<Create new record?> message,
to confirm, the program will automatically edit the new
• Fill in the following process fields <
<
Identification processes”,
Name> and <
Code> and go to
Process design> submenu,
Add> and choose one
• To set the process operation algorithm press <
of the available functions of the process (see point 36.2 to view the
chart). Each of the functions is added one by one.
221
Caution:
It is possible to modify an already existing process. To add an element to the
existing process press and hold for about 2 seconds the element before which
the function is to be added. The following menu will be shown:
Edit
Add
Delete
Cancel
36.2. List of identification process functions
When designing the identification process the user can use the following
functions (steps of a process):
Icon
Function
Description
Select item from
database
Function enabling to select the database
demanded record
Databases
Database declaration procedure that allows to
choose a record: product, operator, client,
packaging, source warehouse, target warehouse,
universal variable
Selection mode
Position declaration procedure according to which
the search is to be done. Possible positions:
standard, name, code. In case of „ universal
variables” function is not available.
Assign to universal
variable
Assignment of a universal variable chosen during
the process to a particular universal variable of the
weighment database reports. Possible values
range from 1 to 5. Function available only in case
of “universal variables” database.
Initial position
Declaration of initial position of database chart. It is
displayed during the process of record searching.
Final position
Declaration of final position of database chart. It is
displayed during the process of record searching.
Setting 0 value results in display of the whole
database chart.
Set position taken
form database
Function sets a demended record taken from a
particular database.
Databases
Declaration of a database for setting a record:
product, client, packaging, source warehouse,
target warehouse, lot number, batch number.
222
Product
Selection of a demanded position out of product
chart (default database). This function is
dependent form declared database.
Execute weighments
series
Function inducing execution of a particular
weighments series.
Mode
Weighments series mode
Number – execution of a particular number of
weighments
Mass – weighing-out a determined mass.
Threshold
Declaration of either weighing number or mass
value, depending on the weighments series mode
Set MIN and MAX
Function setting MIN, MAX thresholds of
checkweighing
Zero
Function of platform zeroing, identical like 0
button of the terminal
Tare
Function of platform tarring, identical like T
button of the terminal
Edit lot number
Function editing a lot number
Edit batch number
Function editing a batch number
Information window
Function inducing freely designed information
window
Name
Information window name, located at the top bar of
the window
Description
Information window description
Information window image. Possible choices: <
Warning>, < Error>.
information>, <
Button
Declaration of buttons for an information window.
Possible choices: „Ok” or „Ok | Cancel”
Add custom variable
Function inducing a new custom variable. This
variable is automatically saved in a report
(weighments database) upon the end of a process.
Type of variable
Declaration of custom variable type. Possible
choices: text variable, numeric variable.
Name
Custom variable name.
Assign to universal
variable
Assigning of a custom variable to a proper
universal variable of the weighing database
reports. Possible values range from 1 to 255.
Edit product
Function inducing change (edition) of variables for
a given product. It is omitted if during previous
steps of the process the product has not been
chosen.
223
Type of variable
Declaration of type of product variable, which is to
be edited: mass, price, number of days left before
the expiry date, additional days of expiry period
Outputs
Function setting terminal outputs state, for control
of peripherals. Possible values: None: - inactive
output; „0” – low output state; „1” – high output
state.
Delay
Function setting intervals between steps of a
dosing process. Function defines amount of time
interval until the next step of a process, given in [s].
Input condition
Conditional function, determines when the next
step of a process is to be executed, it depends on
an input state of a terminal. Possible values: None
– inactive input; „0” - low input state; „1” – high
input state; „/” – rising edge on input (change from
low state to high state, eg.: the moment of pressing
a button); „\” – trailing edge (change from high
state to low state, eg.: the moment of releasing a
button)
36.3. Identification process – activation procedure
Identification processes may be activated by:
• Programmable button,
• Operator logging,
• Product selection.
36.3.1. Activation by programmable button
Submenu <
Button functions> allows for free configuration of
programmable buttons (see point 17.2 of this manual).
Procedure:
• For a chosen button set one of three functions:
Select an identification process
Select an identification process by name
Select an identification process by code
224
• Go back to the main window,
• Press programmable button and select an appropriate identification
process to activate it.
36.3.2. Activation by operator logging
User may assign an identification process to an operator. It results in
automatic start of a process right after the logging procedure has been carried
out.
Procedure:
• Enter submenu: „
Databases /
appropriate position,
Operators” and select an
• Go to <
Identification process> field and select a demanded
process, than go back to the main window.
• Log in as an earlier edited operator, and wait for an automatic activation
of an identification process assigned to this operator to proceed.
36.3.3. Activation by product selection
User may assign an identification process to a product. It results in automatic
start of a process right after a product has been selected out of a database.
Procedure:
• Enter submenu: „
Databases /
appropriate position,
Products” and select an
• Go to <
Identification process> field and select a demanded
process, than go back to the main window,
• Out of a database select an earlier edited product, and wait for an
automatic activation of an identification process assigned to this operator
to proceed.
225
36.3.4. Example of process forming and its realization
Description:
User must get through the following balance operation algorithm:
1. Carry out the operator logging process with the use of a transponder card,
2. Give a shift number,
3. Zero scales,
4. Information window „Prepare a product to be weighed” (message 60[s]),
5. Select a product by EAN code, use a barcode scanner,
6. Give a present price of a product,
7. Out of a list select „Country of origin”,
8. Select client code,
9. Out of a list select „Supplier country”,
10. Give a lot number,
11. Give a batch number,
12. Information window „Start a weighing process”.
Identification process forming:
• Create a new record <
36.1. of this manual,
• Go to submenu <
process:
Step
Identification process> according to point
Process creator> to create further steps of the
Function
Description
Variable type: numeric variable;
1. Add custom variable Name: shift number; assign to
universal variable 1
Displays „Shift number” dialog window
for edition with a numeric keyboard
2. Zero
Zero
Automatic zeroing
3. Delay
Time: 60s; Description: Prepare
a product to be weighed
Displays window „Prepare product to
be weighed” for 60 seconds
4. Select item from
database
Database: Product; selection
mode: Standard; start position:
1; end position: 0
Displays list of products. Configuration
and selection of data with the use of
barcode scanner is described in point
16.3 of this manual.
5. Edit product
Variable type: Price
Displays window: „Record edition:
product / price” with a numeric
keyboard
6. Select item from
database
Displays chart of universal variables
Database: universal variable;
from position 1 to 20. Naming chart:
assign to universal variable: 2;
“Country of origin” – see point 34.1.4 of
start position: 1; end position: 20
this manual
226
7. Select item from
database
Database: Client; selection mode:
Code; start position: 1; end
position: 0
Displays window: „Search by code”.
8. Select item from
database
Database: Universal variable;
Assign to universal variable: 3;
start position: 21; end position: 40
Displays chart of universal variables
from position 21 to 40. Naming chart:
“Supplier country” – see point 34.1.4
of this manual
9. Edit lot number
Edit lot number
Displaying „Lot number” dialog
window with numeric keyboard
10. Edit batch number
Edit batch number
Displaying „Batch number” dialog
window with numeric keyboard
Name: Information; Description:
Displaying „Start weighing process”
11. Information window start weighing; Image: Information;
information window
Button: OK
• Assign transponder card number to an appropriate operator, to do it
follow point 16.4.2 of this manual,
• Assign a created identification process to an appropriate operator to do it
follow point 36.3.2 of this manual,
• Log in with the use of a transponder card to automatically activate
identification process assigned to the given operator,
• After weighing all unique data edited during weighing process will be
saved to reports from weighing:
−
−
−
−
−
−
−
−
−
Mass,
Shift number,
Product name,
Product price,
Country of origin,
Client name,
Supplier country,
Lot number,
Batch number.
User may break the identification process or get back to its previous step.
227
In order to break identification process one must:
• Press
Press
Press <
button of the main window of a process to see amessage:
button to confirm and wait for the following window:
Abort> button.
• Press
button of an edit window or information window, press
button of database data chart to see the following window:
Press <
Abort> button.
228
In order to get back to a previous step of a process one must:
button of an edit window or information window, press
• Press
button of database data chart to see the following window:
• Press <
List of steps> button to see the list of carried out steps,
• Select a given position (step) out of the list and wait, the program will
automatically get back to a chosen step.
37. COMMUNICATION PROTOCOL
37.1. General information
A. Scales-terminal serial communication protocol serves for
communication between RADWAG scales and peripheral device,
it uses RS-232C and Ethernet interface;
B. It consists of commands sent from an external device to the scale
and a responses from a scale.
C. Responses are sent every time after receiving a command
(reaction for any command).
D. Using commands allows users to receive some information about
the state of scale and/or influence the operation e.g.: Requesting
weighing results, display control.
Caution:
Go to submenu: „
/
Computer /
of this manual),
Devices
Port” to declare communication port (see point 16.1.1
229
37.2. List of RS commands
Commands
Description of commands
Z
Zeroing
T
Tarring
OT
Get tare value
UT
Set tare value
S
Send the stable result in basic unit
SI
Send the result immediately in basic unit
SIA
Send immediate results from all platforms in basic units
SU
Send the stable result in current unit
SUI
Send the result immediately in current unit
C1
Switch on continuous transmission in basic unit
C0
Switch off continuous transmission in basic unit
CU1
Switch on continuous transmission in current unit
CU0
Switch off continuous transmission in current unit
DH
Set lower threshold
UH
Set upper threshold
ODH
Read lower threshold
OUH
Read upper threshold
SS
Simulation of pressing ENTER/PRINT key
P
Change platform
PC
Send all implemented commands
Caution:
1. Each command have to be terminated in CR LF;
2. The best Policy for communication is not sending another
command until the former answer has been received.
230
37.3. Respond message format
After sending a request message you can receive:
XX_A CR LF
command accepted and in progress
XX_D CR LF
command completed (appears only after XX_A)
XX_I CR LF
command comprehended but cannot be executed
XX _ ^ CR LF
command comprehended but time overflow error appeared
XX _ v CR LF
command comprehended but the indication below the
XX _ OK CR LF
Command done
ES_CR LF
Command not comprehended
XX _ E CR LF
error while executing command – time limit for stable result
exceeded (limit time is a descriptive parameter of the scale)
XX
_
- command name
- substitutes spaces
37.4. Command’s description
37.4.1. Zeroing
Syntax Z CR LF
Possible answers:
Z_A CR LF
Z_D CR LF
- command accepted and in progress
- command completed
Z_A CR LF
Z_^ CR LF
- command accepted and in progress
- command comprehended but zero range overflow appeared
Z_A CR LF
Z_E CR LF
- command accepted and in progress
- time limit for stable result exceeded
Z_I CR LF
- command comprehended but cannot be executed
231
37.4.2. Tarring
Syntax: T CR LF
Possible answers:
T_A CR LF
T_D CR LF
- command accepted and in progress
- command completed
T_A CR LF
T_v CR LF
- command accepted and in progress
- command comprehended but tare range overflow appeared
T_A CR LF
T_E CR LF
- command accepted and in progress
- time limit for stable result exceeded
T_I CR LF
- command comprehended but cannot be executed
37.4.3. Get tare value
Syntax: OT CR LF
Reply: OT_TARA CR LF – command executed
Frame format:
1
2
3
4-12
13
O
T
space
tare
space
Tare
Unit
-
14
15
16
unit
17
18
19
space
CR
LF
9 characters justified to the right
3 characters justified to the left
Caution:
Tare values are always send in adjustment unit.
37.4.4. Set tare value
Syntax: UT_TARE CR LF, where TARE – tare value
Possible replies:
UT_OK CR LF
UT_I CR LF
ES CR LF
- command completed
- command correct, but not accessible at the moment
- command incorrect (e.g. incorrect tare format)
232
Caution:
Use dots as decimal points in tare values.
37.4.5. Send the stable result in basic unit
Syntax: S CR LF
Possible answers:
S_A CR LF
S_E CR LF
- command accepted and in progress
- time limit for stable result exceeded
S_I CR LF
S_A CR LF
MASS FRAME
- command comprehended but cannot be executed
- command accepted and in progress
- mass value in basic unit is returned
Frame format:
1
2-3
4
5
6
7-15
16
S
space
stability
space
sign
mass
space
17
18
19
unit
20
21
CR
LF
Example:
S CR LF – computer command
S _ A CR LF - command accepted and in progress
S _ _ _ _ - _ _ _ _ _ _ 8 . 5 _ g _ _ CR LF – command done, mass value
in basic unit is returned.
37.4.6. Send the result immediately in basic unit
Syntax: SI CR LF
Possible answers:
SI_I CR LF
- command comprehended but cannot be executed at the moment
MASS FRAME
- mass value in basic unit is returned
Frame format:
1
2
3
4
5
6
7-15
16
S
I
space
stability
space
sign
mass
space
233
17
18
unit
19
20
21
CR
LF
Example:
S I CR LF – computer command
S I _ ? _ _ _ _ _ _ _ 1 8 . 5 _ k g _ CR LF - command done, mass value
in basic unit is returned immediately.
37.4.7. Send immediate results from all platforms in basic units
Syntax: SIA CR LF
Possible answers:
- command comprehended but cannot be executed at the moment
SIA_I CR LF
MASS FRAME „P1” CR LF
MASS FRAME „P2” CR LF - mass values are immediately returned from all
platforms in basic units
Frame format with mass from subsequent platforms as indicator reply:
1
2
3
4
5
6
7-15
16
P
n
space
stability
space
sign
mass
space
17
18
unit
19
20
21
CR
LF
n
- weighing platform number
mass - 9 characters justified to the right
unit - 3 characters justified to the left
Example:
Let us assume that both platforms are connected to scale.
S I A CR LF – computer command
P 1 _ ? _ _ _ _ _ _ 1 1 8 . 5 _ g _ _ CR LF
P 2 _ _ _ _ _ _ _ _ _ 3 6 . 2 _ k g _ CR LF - command done, mass values
from both platforms are returned in basic units
37.4.8. Send the stable result in current unit
Syntax: SU CR LF
Possible answers:
234
SU_A CR LF
SU_E CR LF
- command accepted and in progress
- timeout while waiting for stable results
SU_I CR LF
SU_A CR LF
MASS FRAME
- command comprehended but cannot be executed
- command accepted and in progress
- mass value in current unit is returned
Frame format:
1
2
3
4
5
6
7-15
16
S
U
space
stability
space
sign
mass
space
17
18
19
unit
20
21
CR
LF
Example:
S U CR LF – computer command
S U _ A CR LF - command accepted and in progress
S U _ _ _ - _ _ 1 7 2 . 1 3 5 _ N _ _ CR LF - command done, mass
value in current unit is returned.
37.4.9. Send the result immediately in current unit
Syntax: SUI CR LF
Possible answers:
SUI_I CR LF
- command comprehended but cannot be executed
MASS FRAME
- mass value in current unit is returned immediately
Frame format:
1
2
3
4
5
6
7-15
16
S
U
I
stability
space
sign
mass
space
17
18
unit
19
20
21
CR
LF
Example:
S U I CR LF – computer command
S U I ? _ - _ _ _ 5 8 . 2 3 7 _ k g _ CR LF - command executed and mass
returned
235
37.4.10. Switch on continuous transmission in basic unit
Syntax: C1 CR LF
Possible answers:
C1_I CR LF
- command comprehended but cannot be executed
C1_A CR LF
MASS FRAME
- command comprehended and in progress
- mass value in basic unit is returned
Frame format:
1
2
3
4
5
6
7-15
16
S
I
space
stability
space
sign
mass
space
17
18
19
unit
20
21
CR
LF
20
21
CR
LF
37.4.11. Switch off continuous transmission in basic unit
Syntax: C0 CR LF
Possible answers answers:
C0_I CR LF
- command comprehended but cannot be executed
C0_A CR LF
- command comprehended and executed
37.4.12. Switch on continuous transmission in current unit
Syntax: CU1 CR LF
Possible answers:
CU1_I CR LF
- command comprehended but cannot be executed
CU1_A CR LF
MASS FRAME
- command comprehended and in progress
- mass value in current unit is returned
Frame format:
1
2
3
4
5
6
7-15
16
S
U
I
stability
space
sign
mass
space
236
17
18
unit
19
37.4.13. Switch off continuous transmission in current unit
Syntax: CU0 CR LF
Possible answers:
CU0_I CR LF
- command comprehended but cannot be executed
CU0_A CR LF
- command comprehended and executed
37.4.14. Set lower threshold
Syntax: DH_XXXXX CR LF, where: XXXXX – mass format
Possible answers:
DH_OK CR LF
- command executed
ES CR LF
- command not comprehended (wrong mass format)
37.4.15. Set upper threshold
Syntax: UH_XXXXX CR LF, where: XXXXX – mass format
Possible answers:
UH_OK CR LF
- command executed
ES CR LF
- command not comprehended (wrong mass format)
37.4.16. Read lower threshold
Syntax: ODH CR LF
Possible answers: DH_MASA CR LF - command executed
Frame format:
1
2
3
4-12
13
D
H
space
mass
space
Mass
Unit
14
15
16
unit
- 9 characters justified to the right
- 3 characters justified to the left
237
17
18
19
space
CR
LF
37.4.17. Read upper threshold
Syntax: OUH CR LF
Possible answers: UH_MASA CR LF - command executed
Frame format:
1
2
3
4-12
13
U
H
space
mass
space
Mass
Unit
14
15
16
unit
17
18
19
space
CR
LF
- 9 characters justified to the right
- 3 characters justified to the left
37.4.18. Simulation of pressing ENTER/PRINT key
Syntax: SS CR LF
Sending a command S S CR LF to a scale causes automatic saving of a
weighing record in the database and simultaneous activating a declated
printout template.
Caution:
While sending the command to a scale, all criteria for successful
measurement execution have to be met, i.e. result control, stable mass
indication, etc.
37.4.19. Change platform
Syntax: PN CR LF, where N – number of platforms (1 to 4)
Possible answers:
PN_OK CR LF
- command completed
PN_I CR LF
- command correct, but not accessible at the moment
ES CR LF
- command incorrect (e.g. incorrect number of platforms)
238
37.4.20. Send all implemented commands
Syntax: PC CR LF
Possible answers:
PC A "Z,T,S,SI,SU,SUI,C1,C0,CU1,CU0,DH,ODH,UH,OUH,OT,UT,SIA,SS,
PC" – command executed, the indicator have sent all the implemented
commands.
37.5. Manual printouts / automatic printouts
Users can general manual or automatic printouts from the scale.
• Manual printouts can be performed after loading the pan
and stabilizing indication by pressing
.
• Automatic printouts can be performed only after loading
the pan and stabilizing indication.
Format frame:
1
2
3
4 -12
13
stability
space
sign
mass
space
14
15
unit
Stability character
[space] if stable
[?] if not stable
[^] if an indication over the range
[v] if fan indication below the range
sign
[space] for positive values or
[-] for negative values
9 characters justified to the right
3 characters justified to the left
3 characters justified to the left
mass
unit
command
16
17
18
CR
LF
Example:
_ _ _ _ _ _ 1 8 3 2 . 0 _ g _ _ CR LF – the printout generated from
the scale after pressing
.
239
38. COOPERATION WITH PERIPHERAL DEVICES
Scale can cooperate with the following devices:
•
•
•
•
•
•
Computer,
Receipt printer,
Label printer,
Additional display,
Barcode scanner,
Any peripheral device with the compatible ASCII protocol.
39. DIAGRAMS OF CONNECTION CABLES
Scale – computer cable
Scale – printer (CITIZEN, EPSON) cable
240
Scale – Kafka printer cable
Scale – ZEBRA printer cable
Scale – I/O cable
Caution:
Cable „scale – Ethernet” is a standard network cable with RJ45 connectors
on both sides.
241
40. TECHNICAL PARAMETERS
40.1. Scales of WLY series
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
OIML Class
Stabilization time
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WLY
1/D2
WLY
2/D2
-
-
1kg
0,01g
-1kg
0,03g
±0,03g
2kg
0,01g
-2kg
0,03g
±0,03g
WLY
6/D2
WLY
10/D2
WLY
20/D2
-
-
6kg
10kg
5g
0,1g
0,1g
1g
-6kg
-10kg
0,3g
0,3g
±0,3g
±0,3g
II
3s
195 x 195mm
+15°C to +30°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
2,7 / 3,6kg
490 x 300 x 150mm
20kg
0,1g
-20kg
0,3g
±0,3g
WLY
6/F1/R
WLY
12/F1/R
WLY
30/F1/R
WLY
60/C2/R
WLY
120/C2/R
Technical data:
WLY
6/F1/K
WLY
12/F1/K
WLY
30/F1/K
WLY
60/C2/K
WLY
120/C2/K
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
OIML Class
Pan size
Stabilization time
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
6kg
5g
0,1g
1g
-6kg
0,3g
±0,3g
II
12kg
0,2g
-12kg
0,6g
±0,6g
30kg
0,5g
-30kg
1,5g
±1,5g
360 x 290mm
-
60kg
120kg
50g
1g
2g
10g
-60kg
-120kg
1g
2g
±1g
±2g
II
400 x 500mm
3s
+15°C to +30°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
6,5 / 7,8kg
12,5 / 15kg
550 x 420 x 220mm
720 x 580 x 220mm
242
40.2. Scales of WPY series
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Pan size
Stabilization time
OIML Class
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WPY 0,6/D2
WPY 1,5/D2
WPY 3/D2
WPY 6/D2
0,6kg
4g
0,2g
0,2g
-0,6kg
0,2g
±0,2g
1,5kg
10g
0,5g
0,5g
-1,5kg
0,5g
±0,5g
3kg
20g
1g
1g
-3kg
1g
±1g
6kg
40g
2g
2g
-6kg
2g
±2g
2s
III
195 x 195mm
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
2,7 / 3,6kg
490 x 300 x 150mm
WPY
6/F1/R
WPY
15/F1/R
WPY
30/F1/R
WPY
30/C2/R
WPY
60/C2/R
WPY
6/F1/K
WPY
15/F1/K
WPY
30/F1/K
WPY
30/C2/K
WPY
60/C2/K
6kg
40g
2g
2g
-6kg
2g
±2g
15kg
100g
5g
5g
-15kg
5g
±5g
290 X 360mm
30kg
200g
10g
10g
-30kg
10g
±10g
30kg
60kg
200g
400g
10g
20g
10g
20g
-30kg
-60kg
10g
20g
±10g
±20g
400 × 500mm
2s
III
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
6,5 / 7,8kg
12,5 / 15kg
550 x 420 x 220mm
720 x 580 x 220mm
243
WPY 150/C2/K
WPY 300/C2/K
WPY 150/C3/K
WPY 300/C3/K
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WPY 150/C2/R
-
-
-
150kg
1kg
50g
50g
150kg
50g
±50g
300kg
2kg
100g
100g
-300kg
100g
±100g
150kg
1kg
50g
50g
150kg
50g
±50g
300kg
2kg
100g
100g
-300kg
100g
±100g
400 × 500mm
2s
III
500 × 700mm
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
12,5 / 15kg
20,5 / 26,8kg
720 x 580 x 220mm
820 x 640 x 260mm
40.3. Scales of WLY/KTP series
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WLY
0,6/1,2/KTP/D2
0,6 / 1,2kg
5g
0,1 / 0,2g
0,1 / 0,2g
-1,2kg
0,1 / 0,2g
±0,1 / 0,2g
WLY
1,2/3/KTP/D2
WLY
3/6/KTP/D2
WLY
6/12/KTP/D2
1,2 / 3kg
3 / 6kg
6 / 12kg
10g
25g
50g
0,2 / 0,5g
0,5 / 1g
1 / 2g
0,2 / 0,5g
0,5 / 1g
1 / 2g
-3kg
-6kg
-12kg
0,2 / 0,5g
0,5 / 1g
1 / 2g
±0,2 / 0,5g
±0,5 / 1g
±1 / 2g
3s
II
195 x 195mm
+15°C to +30°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
2,7 / 3,6kg
490 x 300 x 150mm
244
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WLY
6/12/KTP/F1/R
WLY
12/30/KTP/F1/R
WLY
60/KTP/C2/R
WLY
60/120/KTP/C2/R
WLY
6/12/KTP/F1/K
WLY
12/30/KTP/F1/K
WLY
60/KTP/C2/K
WLY
60/120/KTP/C2/K
6 / 12kg
50g
1 / 2g
1 / 2g
-12kg
1 / 2g
±1 / 2g
12 / 30kg
100g
2 / 5g
2 / 5g
-30kg
2 / 5g
±2 / 5g
60kg
0,5kg
10g
10g
-60kg
10g
±10g
60 / 120kg
0,5kg
10 / 20g
10 / 20g
-120kg
10 / 20g
±10 / 20g
360 x 290mm
3s
II
400 x 500mm
+15°C to +30°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
6,5 / 7,8kg
12,5 / 15kg
550 x 420 x 220mm
720 x 580 x 220mm
40.4. Scales of WPY/KTP series
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WPY
0,6/1,5/KTP/D2
0,6 / 1,5kg
4 / 10g
0,2 / 0,5g
0,2 / 0,5g
-1,5kg
0,2 / 0,5g
±1 / 2g
WPY
1,5/3/KTP/D2
WPY
3/6/KTP/D2
1,5 / 3kg
3 / 6kg
10 / 20g
40 / 40g
0,5 / 1g
1 / 2g
0,5 / 1g
1 / 2g
-3kg
-6kg
0,5 / 1g
1 / 2g
±1 / 2g
±1 / 2g
2s
III
195 × 195mm
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
2,7 / 3,6kg
490 x 300 x 150mm
245
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
WPY
3/6/KTP/F1/K
WPY
6/15/KTP/F1/K
WPY
15/30/KTP/F1/K
WPY
3/6/KTP/F1/R
WPY
6/15/KTP/F1/R
WPY
15/30/KTP/F1/R
3 / 6kg
20 / 40g
1 / 2g
1 / 2g
-6kg
1 / 2g
±1 / 2g
6 / 15kg
15 / 30kg
40 / 100g
100 / 200g
2 / 5g
5 / 10g
2 / 5g
5 / 10g
-15kg
-30kg
2 / 5g
5 / 10g
±2 / 5g
±5 / 10g
2s
III
290 × 360mm
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
6,5 / 7,8kg
550 x 420 x 220mm
WPY 15/30/KTP/C2/K
WPY 30/60/KTP/C2/K
WPY 15/30/KTP/C2/R
WPY 30/60/KTP/C2/R
15 / 30kg
100 / 200g
5 / 10g
5 / 10g
-30kg
5 / 10g
±5 / 10g
30 / 60kg
200 / 400g
10 / 20g
10 / 20g
-60kg
10 / 20g
±10 / 20g
Technical data:
Maximum capacity
Minimum capacity
Reading division [d]
Verification interval [e]
Tare range
Repeatability
Linearity
Stabilization time
OIML Class
Pan size
Operation temperature
Storage temperature
Atmospheric humidity
Ingress protection rating
Power supply
Display
Interfaces
Net / Gross weight
Package dimensions
2s
III
290 × 360mm
-10°C to +40°C
-25°C to +70°C
10÷85% RH no condensation
IP 54
110÷230VAC 50/60Hz – 10,5÷15VDC
5,7’’ touch screen
2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
6,5 / 7,8kg
550 x 420 x 220mm
246
41. ERROR MESSAGES
42. ADDITIONAL EQUIPMENT
Accessories:
•
•
•
•
•
•
•
•
•
•
KAFKA printer cable - P0136,
Computer cable - P0108,
EPSON printer cable - P0151,
Thermal printer - KAFKA,
Dot matrix printer - EPSON,
Label printer - CITIZEN,
Additional display in plastic casing - WD- 4/1,
Large size display (2”) - WWG-2,
Transponder card reader - CK-01,
Barcode scanner - LS2208,
247
• Current loop in plastic casing - AP2-1,
• Handle for measuring indicator in plastic casing - PUE-7-32,
• PC keyboard.
Computer programs:
•
•
•
•
•
•
“E2R System” computer program,
„ViewerKTP” computer program,
“LABEL EDITOR R02” computer program,
“DATABASE EDITOR PUE 7-HY” computer program,
"RAD-KEY" computer program,
"PW-WIN" computer program.
43. APPENDIX A – Variables for printouts
43.1. Inventory of variables
Caution:
Every variable needs to be included in brace brackets e.g. {x},
where x – variable number.
A list of variables accessible in the system for defining printout
templates and data displayed in the workspace of scale’s screen:
Symbol
Description
{0}
1)
{1}
{2}
{3}
{4}
{5}
{6}
{7}
{8}
{9}
{10}
{11}
{12}
Standard printout in adjustment unit
Standard printout in current unit
Date
Time
Date & Time
Mathematical function
Net mass in current unit
Net mass in adjustment unit
Gross mass
Tare
Current unit
Adjustment unit
Minimum threshold
1)
248
{13}
{14}
{15}
{16}
{17}
{18}
{19}
{20}
{21}
{22}
{23}
{24}
{25}
{26}
{27}
{28}
{29}
{30}
{31}
{32}
{33}
{34}
{35}
{36}
{37}
{38}
2)
{39}
{40}
{41}
{42}
{43}
{44}
{45}
{46}
{47}
{48}
{49}
{50}
{51}
{52}
{53}
{54}
Maximum threshold
Lot number
Statistics: Number
Statistics: Sum
Statistics: Average
Statistics: Minimum
Statistics: Maximum
Cumulative of Cumulative Statistics: Quantity
Cumulative of Cumulative Statistics: Sum
Cumulative of Cumulative Statistics: Average
Cumulative of Cumulative Statistics: Min
Cumulative of Cumulative Statistics: Max
Mass: lb
Checkweighing
Value to pay
C Value (cumulative amount to pay)
CC value (cumulative of cumulatives amount to pay)
Gross (amount to pay + VAT)
Platform number
Factory Number
Scale division
Range
Counting pieces: Sample weight
Deviations: Sample weight
Statistics: Standard deviation
CC Statistics: Standard deviation
Universal variable: Value
Text information
Batch number: Value
Statistics: Weighing counter
Platform mass
Balance type
Parts counting: Sample size
CC Statistics: Number of measurements
Statistics: Gross sum
CC Statistics: Gross sum
Universal variable: Name
Product: Name
Product: Code
Product: EAN Code
Product: Mass
Product: Tare
249
{55}
{56}
{57}
3)
{58}
{59}
{60}
{61}
{62}
3)
{63}
4)
{64}
{65}
{66}
{67}
{68}
{75}
{76}
{77}
{80}
{81}
{82}
{85}
{86}
{87}
{88}
{89}
{90}
{91}
{100}
{101}
{102}
{103}
{104}
{105}
{106}
{107}
{108}
{109}
{110}
{111}
{112}
{113}
{114}
Product: Unit price
Product: Min
Product: Max
Product: Testing Prepackages mode (CPG)
Product: Number of validity days
Product: VAT
Product: Date
Product: Expiry Date
Product: Density
Product: Ingredients
Product: Description
Product: Low deviation
Product: High deviation
Product: Category
Operator: Name
Operator: Code
Operator: Access level
Package: Name
Package: Code
Package: Mass
Client: Name
Client: Code
Client: Tax ID
Client: Address
Client: Postal code
Client: City
Client: Discount
Report From weighments: Measurements
Filter of weighments report: Start date
Filter of weighments report: End date
Filter of weighments report: Product
Filter of weighments report: Operator
Filter of weighments report: Client
Filter of weighments report: Package
Filter of weighments report: Min
Filter of weighments report: Max
Filter of weighments report: Lot number
Filter of weighments report: Batch number
Filter of weighments report: Target warehouse
Filter of weighments report: Source warehouse
Filter of weighments report: Checkweighing
Filter of weighments report: Platform number
250
{115}
{116}
{117}
{118}
{119}
{120}
{121}
{122}
{130}
{131}
{132}
{135}
{136}
{137}
{140}
{141}
{142}
{143}
{144}
{145}
{146}
{147}
{148}
{149}
{151}
{155}
{156}
{157}
{158}
{159}
{160}
{161}
{162}
{163}
{164}
{165}
{166}
Report From weighments: Number of weighments
Report From weighments: Totalized weighments
Report From weighments: Value
Report From weighments: Gross
Report From weighments: Average
Report From weighments: Min
Report From weighments: Max
Report From weighments: Vehicle scale
Source Warehouse: Name
Source Warehouse: Code
Source Warehouse: Description
Target warehouse: Name
Target warehouse: Code
Target warehouse: Description
Net mass in adjustment unit: Total
Additional display: WD
Additional display: WWG
Hex
Hex UTF8
Partial mass
Gross mass in current unit
Tare in current unit
Lot number: Value
Batch number: Value
Extra variable: Value
Density: Start date
Density: End date
Density: Method
Density: Standard liquid
Density: Standard liquid density
Density: Temperature
Density: Sinker volume
Density
Density: Unit
Density: Sample number
Density: Weighing 1
Density: Weighing 2
251
{167}
{168}
{169}
{170}
{175}
{176}
{177}
{178}
{180}
{181}
{182}
{183}
{184}
{185}
{186}
{187}
{205}
{206}
{209}
{210}
{211}
{212}
{213}
{214}
{215}
{216}
{217}
{218}
{219}
{220}
{221}
{222}
{223}
{224}
{225}
{226}
{227}
Density: Weighing 3
Density: Volume
Density: Pycnometer mass
Density: Pycnometer density
Dosing process: Name
Dosing process: Code
Dosing process: Cycle number
Dosing process: Number of cycles
Dosing report: Start date
Dosing report: End date
Dosing report: Result
Dosing report: Number of measurements
Dosing report: Total
Dosing report: Measurements
Measurements: Nominal mass
Measurements: Difference
Adjustment track record: Nominal Mass
Adjustment track record: Platform number
Vehicle: Operator
Vehicle: Name
Vehicle: Code
Vehicle: Description
Vehicle scale: Start date
Vehicle scale: End date
Vehicle scale: Entry mass
Vehicle scale: Exit mass
Vehicle scale: Load mass
Vehicle scale: Transaction type
Vehicle scale: Status
Recipe: Name
Recipe: Code
Recipe: Cycle number
Recipe: Number of cycles
Recipe: Process progress
Recipe: Process progress in %
Recipe: Ingredient name
Recipe: Difference
252
{228}
{229}
{230}
{231}
{232}
{233}
{234}
{235}
{236}
{237}
{240}
{241}
{242}
{243}
{244}
{245}
{246}
{247}
{248}
{260}
{261}
{262}
{263}
{264}
{265}
{266}
{267}
{268}
{269}
{270}
{271}
{272}
{273}
{274}
{275}
{276}
{277}
{278}
Recipe: Portion
Recipe: Nominal mass
Recipe: Number of current ingredient
Recipe: Number of ingredient
Recipe: Number of current manufacturing unit
Recipe: Number of manufacturing unit
Recipe: Status
Recipe: Low deviation
Recipe: High deviation
Recipe: Ingredient code
Recipe: report: Start Date
Recipe: report: End Date
Recipe: report: Result
Recipe: report: Number of measurements
Recipe: report: Total
Recipe: report: Measurements
Measurements: Nominal mass
Measurements: Difference
Recipe: report: Ingredient code
CPG Report: Batch Number
CPG Report: Start date
CPG Report: End date
CPG Report: Result
CPG Report: Lot quantity
CPG Report: Number of Measurements
CPG Report: T1 error border
CPG Report: 2T1 error border
CPG Report: Number of T1 errors
CPG Report: Acceptable number of T1 errors
CPG Report: Number of 2T1 errors
CPG Report: Total
CPG Report: Min
CPG Report: Max
CPG Report: Average
CPG Report: Limit of the average
CPG Report: Standard deviation
CPG Report: Measurements
CPG Report: Unit
253
{279}
{280}
{281}
{282}
{283}
{284}
{285}
{286}
{287}
{288}
{289}
{290}
{291}
{295}
{296}
{297}
{298}
{299}
{300}
{301}
{302}
{303}
{350}
{351}
{352}
{353}
{398}
CPG Report: Report Number
CPG Report: Value of T1 error [ + ]
CPG Report: Value of 2T1 error [ + ]
CPG Report: Number of T1 errors [ + ]
CPG Report: Permissible number of T1 errors [ + ]
CPG Report: Number of 2T1 errors [ + ]
CPG Report: Permissible number of 2T1 errors
CPG Report: Permissible number of 2T1 errors [ + ]
CPG Report: Navigating bar
CPG Report: Qualifying number of T1 errors
CPG Report: Tare
CPG Report: Average limit value [ + ]
CPG Report: Note
Average Tare Report: Date
Average Tare Report: Result
Average Tare Report: Standard deviation
Average Tare Report: 0.25T1
Average Tare Report: Number of Measurements
Average Tare Report: Measurements
Average Tare Report: Report Number
Average Tare Report: Average Tare
Average Tare Report: Note
EPSON paper cutting
EPSON polish signs
Additional display: PUE7
IP Address
Weighing
Caution:
Variables {0} and {1} is terminated by CR LF, i.e. the cursor
1)
is moved to the beginning of the next line by default,
In case of variable {39}, each position from the database (1,2-n)
2)
is formated as follows: Position 1 - {39:1}, Position 2 - {39:2}, etc.
In case of variable {64}, each line (L1-Ln) is formatted according
3)
to the template: Line 1 - {64:L1}, Line 2 - {64:L2}, etc.
254
43.2. Formatting variables
Users can format numeric, text and date variables intended for displaying
or printing out.
Different format commands:
•
•
•
•
•
•
•
Justification to the left,
Justification to the right,
Setting the number of characters for printout / display,
Declaration of the number of digital places for numeric variables,
Date&Time formatting,
Formatting numeric variables for EAN13 codes,
Formatting numeric variables and dates for EAN128/GS1-128 codes.
Format characters:
Character
Description
Example
,
Separates variables from
format strings
{7,10} – Net mass in adjustment unit situated
in 10-character string justified to the right.
-
Minus sign or justification to the
left
:
Precides formatting or
separates hours, minutes and
seconds
{7,-10} - Net mass in adjustment unit
situated in 10-character string justified to the
left
{7:0.000} - Net mass in adjustment unit
always with three decimal places ;
{3:hh:mm:ss} – Present time in the format :
hours : minutes : seconds
.
The first dot in the format string
determines the location of the
decimal separator in the
formatted value; any additional
dot characters are ignored.
{55:0.00} – Unit price always with two
decimal places;
{17:0.0000} – Average value form
weighments with four decimal places;
F
The number is converted to a
string of the form "-ddd.ddd…"
where each 'd' indicates a digit
(0-9). The string starts with a
minus sign if the number is
negative.
{7:F2} - Net mass in adjustment unit always
with two decimal places.
{7,9:F2} - Net mass in adjustment unit
always with two decimal places in 9character string justified to the right.
V
Formatting mass and
derivatives for EAN13 codes
{7:V6.3} - Net mass for EAN13 (6-character
code) with three decimal characters
T
Formatowanie masy i wielkości
pochodnych do masy w kodzie
EAN128
{7:T6.3} – Net mass for EAN128/GS1-128
with two decimal places.
255
/
Date separator between days,
months and years
{2:yy/MM/dd} – Present date formatted as:
year - month - day, where yy represents two
less significant digits of year.
\
„Escape” character removing
formatting function form next
character to allow it to be used as
a character in a text string.
{2:yy\/MM\/dd} – Present date formatted as
yesr / month / day; {2:yy\:MM\:dd} –Present
date formatted as: year : month : day. In case
of necessity of using „\” as literal it should be
preceded by another escape characterj “\\”.
Format examples:
Symbol
Description
{7:V6.3}
Net mass for EAN 13 (6-character code)
{7:V7.3}
Net mass for EAN 13 (7-character code)
{27:V6.3}
Net amount to pay for EAN 13 (6-character code)
{27:V7.3}
Net amount to pay for EAN 13 (7-character code)
{7:T6.3}
Net mass for EAN 128/GS1-128
{16:T6.3}
Cumulative net mass for EAN 128/GS1-128
{21:T6.3}
Cumulative of cumulative net mass for EAN 128/GS1-128
{25:T6.3}
Net mass in lb for EAN 128/GS1-128
{8:T6.3}
Gross mass for EAN 128/GS1-128
{55:T6}
Product price for EAN 128/GS1-128
{2:yyMMdd}
Date for EAN 128/GS1-128
{61:yyMMdd}
Product date for EAN 128/GS1-128
{62:yyMMdd}
Expiary date for EAN 128/GS1-128
{16:V6.3}
Cumulative net mass for EAN 13 (6-character code)
{16:V7.3}
Cumulative net mass for EAN 13 (7-character code)
{28:V6.3}
Total/cumulative amount to pay for EAN 13 (6-character code)
{28:V7.3}
Total/cumulative amount to pay for EAN 13 (7-character code)
{21:V6.3}
Cumulative of cumulative net mass EAN 13 (6-character code)
{21:V7.3}
Cumulative of cumulative net mass EAN 13 (7-character code)
{29:V6.3}
Total/cumulative of cumulative amount to pay EAN 13
(6-character code)
{29:V7.3}
Total/cumulative of cumulative amount to pay EAN 13
(7-character code)
256
43.3. Mathematical function
Extended functionality of the mathematical functions with use of a variable
<{5} Mathematical function> enables carrying out an optional operation on
numbers and variables available on the list. The basic available mathematical
functions are:
•
•
•
•
Adding (+)
Subtracting (-)
Multiplying (*)
Dividing (/)
The additional functionality provides using in the calculation the existing
variables, thus enabling acquiring mass from a specified weighing platform,
and its processing in a desired way.
An example:
{5: ([43:1] + [43:2]) / 2}
The above application of a variable <{43} Platform mass> causes acquiring
mass from a weighing platform determined in the formatter (:1 and :2), and
their dividing by 2 which enables taking the average mass from both weighing
platforms. Use of the brackets enables carrying out the operation in an
appropriate sequence and in accordance with basic matjematical principles.
Caution:
Variables in the structure of the mathematical operations are noted insquare
brackets [ ] and not as previously in { } brackets.
Additionally, a operator can use the advanced functions enabling extended
means of data modification. The advanced functions are used in a form of text
marker and arguments in brackets:
•
•
•
•
•
•
•
•
•
round (numeric value, rounding precision (number)) - rounding
abs (numeric value) – absolute value
sin (numeric value) - sine
cos (numeric value) - cosine
tan (numeric value) - tangent
sqrt (numeric value) - radical
pow (numeric value, power base (number)) - power
log (numeric value) – logarithm
log10 (numeric value) – logarithm base 10
257
Caution:
A numeric value is comprehended as an optional number or an optional
mathematical operation that returns a numeric value.
There are additional functions that modify the text values, and they can also
operate on numbers that are coverted to text:
• remove (“text value”, initial place (number), quantity of characters to be
removed (number)) – a return is a residue after deleting a part of the text
value, from the initial point to a determined quantity of characters. In
case the third parameter is not specified the text value will be deleted till
its end.
• substring (“text value”, initial place (number), quantity of characers to be
copied (number)) – a return is copied text value from the initial point to a
quantity of characters to be copied. In case the third parameter is not
specified the text value will be copied till the end.
• tolower (“text value”) – a return is a complete text value in small letters.
• toupper (“text value”) – a return is a complete text value in capital letters.
• replace (“text value”, old text, new text) – a return is a text with replaced
letters of parts of the text, determined in the second and their parameter.
Caution:
The text values are put in quotation marks “ ”.
Examples:
remove (“Text sample”,11) – the operation causes returning a text value:
“Text sample”.
toupper (“Text sample”) – the operation causes returning a text value
“TEXT SAMPLE”.
replace (“Text sample”, “text ”, “text”) - the operation causes returning
a text value “Text sample”.
replace (”2.000”,”0”,”1”) - the operation causes returning a text value
“2.111”. The value can be used for standard mathematical calculations,
where it will be converted “on the fly” in case the operation requires it.
258
44. APPENDIX B – Functions of programmable buttons
Icon
Function name
ENTER
Zero
Tare
Enter tare
Parameters
Local Parameters
Set MIN and MAX
Statistics (cumulative) : Print and zero
Statistics (cumulative) : Print
Statistics (cumulative) : zero
Statistics (cumulative of cumulative): Print and zero
Statistics (cumulative of cumulative): Print
Statistics (cumulative of cumulative): zero
Edit lot number
Edit batch number
Start
Stop
Choose an operator
259
Choose an operator by name
Choose an operator by code
Choose a product
Choose a product by name
Choose a product by code
Choose a package
Choose a package by name
Choose a package by code
Choose a client
Choose a client by name
Choose a client by code
Choose a source warehouse
Choose a source warehouse by name
Choose a source warehouse by code
Choose a target warehouse
Choose a target warehouse by name
Choose a target warehouse by code
Change working mode
Counting pieces: Specify piece mass
Counting pieces: Estimate piece mass
260
Counting pieces: Ascribe standard
Counting pieces: Quantity of sample - 5 pcs
Counting pieces: Quantity of sample - 10 pcs
Counting pieces: Quantity of sample - 20 pcs
Counting pieces: Quantity of sample - 50 pcs
Deviations: Specify sample mass
Deviations: Estimate sample mass
Emergency stop
Chute permission
Disable tare
Restore tare
Change unit
Change platform
Edit universal variable 1
Edit universal variable 2
Edit universal variable 3
Edit universal variable 4
Edit universal variable 5
Select universal variable – 1
261
Select universal variable – 2
Select universal variable – 3
Select universal variable – 4
Select universal variable – 5
Select dosing process
Select dosing process by name
Select dosing process by code
Select formulation
Select formulation by name
Select formulation by code
Ingredients
Determine liquid density
Determine solid density
Determine pycnometer density
Determine porous body density
Edit number of labels
Edit number of C labels
Edit number of CC labels
KTP – Change: Workspace / chart
262
KTP: Set control
KTP: Return to home screen
KTP: Data on control in progress
KTP: Edit note
Choose a vehicle
Choose a vehicle by name
Choose a vehicle by code
Choose a vehicle “manually”
Start entry transaction
Start exit transaction
Choose transaction
Choose traceability process
Choose traceability process by name
Choose traceability process by code
Print Screen
Select platform 1
Select platform 2
Select platform 3
Select platform 4
263
Choose an extra variable no 1
Choose an extra variable no 2
Choose an extra variable no 3
Choose an extra variable no 4
Choose an extra variable no 5
Zero platform 1
Zero platform 2
Zero platform 3
Zero platform 4
Tare platform 1
Tare platform 2
Tare platform 3
Tare platform 4
264
45. APPENDIX C – Label template
A label template can be created in 2 ways:
• From the terminal level using variables,
• Using PC software EDYTOR ETYKIET R02. A created project needs
to be saved as an „lb” file then copied on a pendrive that can be
connected to the terminal. Finally transfer the file to the database
in the scale.
While a label is in the database of labels it can be ascribed to products
or/and clients in order to work in labelling mode.
45.1. Designing a label from the terminal level
Procedure:
• Enter <
Databases> according to ch. 34 of this manual,
• Enter <
Labels> and press on the required position.
• After entering <
Label template> an editing field with the screen
keyboard appears
• Modify the existing template using the list of variables accessible
after pressing
,
.
• Confirm changes by pressing
Caution:
In the bottom line of the screen keyboard there are additional buttons that
help to modify a label template:
On-screen keyboard on / off
Read label templates from *.lb files (see – ch. 45.3)
Saving printout template in a file format *.lb (option enabled
on plugging a portable data storage device to scale port)
Select variables for the display template (inventory of variables
can be found in APPENDIX A)
Clearing the editing field
265
45.2. Designing a label on a computer
Example:
Let us create a label template for the label below:
Caution:
The installer of EDYTOR ETYKIET R02 is accessible to download
on website: www.radwag.com. on the overlap: Products / Measuring
indicators / PUE 7.
Procedure:
1. Run computer program LABEL EDITOR R02, then the main window
of the program is displayed:
266
Caution:
Prior to designing a label a new project needs to be created with initial
printer and label settings. A description of creating new projects can be
found in instruction manual „Label Editor R02” accessible in the program
menu: „Info / User manual”.
Text> from the list
2. In order to add a text to the label chose <
of objects and then click on the workspace of label, then window
<Text field settings> opens:
3. Type the required text in the box at the bottom of the window: PORK
CHARCUTERIE SMITH&SMITH Ltd and press
to confirm,
then the text is put automatically on the label,
4. In order to add a variable to the label chose <
Variable> from
the list of objects and then click on the workspace of label, then window
<Variable settings> opens:
267
5. From list <Variable> chose variable type „4 Date and time” and press
, then the variable is placed in the table of variables
show below.
6. Confirm it by pressing
placed on the label.
, then the variable is automatically
7. Place the rest of variables and constant texts on the label in the same
way,
8. In order to put an image on the label chose <
Image> from the list
of objects and then click on the workspace of label, then window
<Open> opens:
9. Chose one and press <Open>, then the image is placed on the label.
Caution:
Graphic images placed on the label can be printed only when they
are downoladed to the printer memory. It is described in the instruction
manual „Label Editor R02” accessible in the program menu on the
overlap: „Info / User manual”.
Barcode> and then
10. In order to add a barcode to the label chose <
click on the workspace of label, then window <Barcode settings>
opens:
268
11. Chose <Barcode> from the list e.g. EAN-13.
12. Chose from list <Variable> item „7 Net mass in adjustment unit”
, then the variable is placed in the table
and press
of variables show below.
13. In column <Formatter> type:V6.3 (mass in EAN13 as a 6-digit code
with 3 decimal places).
14. Confirm the entered item by pressing
is automatically placed on the label.
, then the barcode
15. Save the created pattern chosing from the menu „File / Export *.lb”.
Caution:
Recorded templates of labels in files with *.lb extension are not editable.
This is advisable to record designs of labels in files with *.lab extension
as well (software menu: File / Save as…) to use/edit the designs of
labels in the future.
269
45.3. Saving label templates in the scale
Procedure:
• A label template *.lb created in EDYTOR ETYKIET R02 needs
to be copied to a pendrive,
• Connect the pendrive to USB in the scale,
• Enter: „
/
Databases /
and press the required item,
Labels”
• Enter <
Label templates>, then an editing field and the screen
keyboard appears,
• Press
, to open a window showing files on the pendrive,
• Select the required *.lb file. It is automatically copied to the editing
field,
• Confirm the changes by pressing
.
Caution:
If a pendrive is not recognized by the system button
inactive.
will remain
45.4. Attributing a label to a product
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Products> and press the required item,
• Enter <
Label>, then the database of labels is open with the list
of all labels,
• Choose the required label. The program automatically ascribes the
label to the product.
270
45.5. Attributing a label to a client
Procedure:
• Enter <
• Enter <
Databases> according to ch. 34 of this manual,
Clients> and press the required item,
• Enter <
Label>, then the database of labels is open with the list
of all labels,
• Choose the required label. The program automatically ascribes the
label to the client.
45.6. Printing labels
Procedure:
• While in the main window choose a product (button
or a client (button
)
) that has attributed a label,
• Place a load on the pan and wait for
then press
,
• The label is printed on a printer connected to the scale.
Caution:
1. Labels can be attributed to products or/and clients. After pressing
a label is printed on a connected printer, provided
a selected client or product has an ascribed label.
2. Users can perform the test label printout – see ch. 34.5 of this
manual.
46. APPENDIX D - CITIZEN printer setting
Baud rate
Parity control
Number of data bits
Number of stop bits
Flow control
IEEE 1284
: 9600b/sec
: No
: 8bit
: 1 bit
: No
: ON
271
Information printed by the printer via RS232:
[Interface Menu]
RS-232C Baud rate
RS-232C Parity
RS-232C Length
RS-232C Stop bit
RS-232C X-ON
IEEE 1284
: 9600bps
: None
: 8 bit
: 1 bit
: No
: On
The way of generating the setup printout and setting CITIZEN printers are
described in manuals attached to printers or present on the website of the
manufacturer.
47. APPENDIX E - ZEBRA printer setting
Baud rate – 9600b/sec
Parity control – none
No of data bits – 8bit
No of stop bits – 1 bit
Information printed by the printer via RS232:
Serial port : 96, N, 8, 1
The way of generating the setup printout and setting ZEBRA (Eltron)
printers are described in manuals attached to printers or present
on the website of the manufacturer.
48. APPENDIX F - Communication with barcode scanners
1. For communication with barcode scanners RADWAG scales use RS232
interfaces and simplex transmission (one direction) without handshaking.
Only two wires are required for assuring such a transmission. Used
scanners should be equipped in such interface with disabled both
hardware and software handshaking.
2. Both scales and scanners have the possibility of setting of transmission
parameters. Both devices are required to have the same parameters set
: baud rate, number of data bits, parity control, stop bits. e.g. 9600,8,N,1
– baud rate 9600 bit/s, data 8-bits, no parity control, 1 stop bit.
272
3. Barcode scanners can send additional information apart from the
expected barcode e.g. symbology (type of barcode). It is advisable
to disable such information because RADWAG devices and
software do not use it.
4. Some RADWAG systems can omit unnecessary information by
using parameters that mark the beginning and the length of the
code required to analyse.
5. A special protocol is required in order the code be received by
RADWAG equipment. It is required to program an appropriate
prefix and suffix. Prefix – one byte 01 hexadecimally, suffix one
byte 0D hexadecimally.
6. Most barcode scanners allow to enable/disable different
symbologies (barcode types).
7. Programming of scanners is usually performed by reading
special barcodes or by using an external software tool.
8. Scanners marketed together with RADWAG systems are
always configured according to the rules above.
Barcode with required prefix and
suffix in hexadecimal format
Barcode without
required –fixes in
ASCII format
Code type
01 30 30 32 31 30 31 32 36 0D
00210126
EAN-8
01 30 31 32 33 34 35 36 37 38 39 0D
0123456789
2 of 5
01 43 4F 44 45 20 33 39 20 54 45 53 54 0D
CODE 39 TEST
CODE 39
01 31 31 30 31 32 33 34 35 36 37 38 39 31 0D
1101234567891
EAN-13
01 43 6F 64 65 20 31 32 38 20 54 65 73 74 0D
CODE 128 Test
CODE 128
49. APPENDIX G – Computer Program „ViewerKTP”
Computer program „ViewerKTP” is intended for viewing and printing reports
from controls and average tare tests.
Caution:
Installation program „ViewerKTP” is recorded on the CD connected to this
product.
273
Operation description:
• Run computer program „ViewerKTP”. It starts with opening
the following window:
Button functions:
Open a controls or average tares database
Print a report
View a report
Scroll the list of reports one position down
Scroll the list of reports one position up
Go to the last report
Go to the first report
• Press
, then window <Open> appears in which the wanted database
can be located (extention *.tdb),
• Mark a report and click on
,
• The program automatically returns to the main window and in the field
<Tests> the list of reports is displayed:
274
• Print the marked report on a connected printer by pressing
• Using button
view the selected report.
275
,
MANUFACTURER
OF ELECTRONIC W EIGHING INSTRUMENTS
RADWAG WAGI ELEKTRONICZNE
26 – 600 Radom, Bracka Street 28
POLAND
Phone +48 48 38 48 800, fax. + 48 48 385 00 10
e-mail: [email protected]
www.radwag.com
276
Was this manual useful for you? yes no
Thank you for your participation!
