Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

The addition of this symbol to a Danger or Warning safety label indicates that an electrical hazard exists, which will result in personal injury if the instructions are not followed.

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

DANGER

DANGER indicates an imminently hazardous situation, which, if not avoided, will

result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous situation, which, if not avoided, can result in death, serious injury, or equipment damage.

CAUTION

CAUTION indicates a potentially hazardous situation, which, if not avoided, can result in injury or equipment damage.

33002196

Safety Information

PLEASE NOTE

Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Schneider Electric for any consequences arising out of the use of this material.

33002196

About the Book

At a Glance

Document Scope

This manual presents all information neccessary to configure the XMIT, XXMIT and the RTXMIT function blocks on all PLC platforms supporting the IEC languages.

Validity Note

The information contained in this book is valid for Concept version 2.6 Service release 1 and later.

Related

Documents

Title of Documentation

Concept Installation

Concept User Manual

Concept IEC Block Libraries

Reference Number

840 USE 502 00

840 USE 503 00

840 USE 504 00

You can download these technical publications and other technical information from our website at www.telemecanique.com

User Comments

We welcome your comments about this document. You can reach us by e-mail at [email protected]

33002196

About the Book

33002196

Introduction to XXMIT and RTXMIT

At a Glance

Overview

What's in this

Chapter?

This chapter gives a general overview on the transmit function block XXMIT and the transmit/receive function block RTXMIT.

This chapter contains the following topics:

Topic

XXMIT Functionality

RTXMIT Functionality

Page

33002196

Introduction

XXMIT Functionality

Function

Overview

Function

Description

The XXMIT (Transmit) function block enable the use of the PLCs serial ports for communication under the control of the application program.

The following communication types are supported: l l l l

Modbus as Master

Simple ASCII Input/Output

ASCII Input with one or two termination characters

Modem Communication

The Transmit blocks send Modbus messages from a "master" PLC to multiple slave

PLCs or sends ASCII character strings from the PLC's Modbus slave port #1 (on

Momentum PLCs also port #2 is supported) to ASCII printers and terminals. XXMIT sends these messages over telephone dialup modems, radio modems, or simply direct connections. The Transmit blocks perform general ASCII input functions in the communication mode including simple ASCII and terminated ASCII. You may import and export ASCII or binary data into your PLC. The block has builtin diagnostics that checks to make sure no other Transmit blocks are active in the PLC on the same port. Within the Transmit blocks, control inputs allows you to control the communications link between the PLC and DCE (Data Communication Equipment) devices attached to Modbus port #1 or port #2 of the PLC. The Transmit blocks do

NOT activate the port LED when transmitting data.

33002196

Introduction

RTXMIT Functionality

Function

Overview

Function

Description

The RTXMIT (Receive/Transmit) function block enable the use of the PLCs serial ports for full duplex communication under the control of the application program.

The following communication types are supported: l l

Simple ASCII Input/Output

ASCII Input with one or two termination characters

The RTXMIT Transmit block sends ASCII character strings from the PLC's Modbus slave port#1 (on Momentum PLCs also port#2 is supported) to ASCII printers, terminals or any other serial device. The Transmit blocks perform general ASCII input functions in the communication mode including simple ASCII and terminated

ASCII. You may import and export ASCII or binary data into your PLC. The RTXMIT block can send and receive characters at the same time (full duplex). The block has builtin diagnostics that checks to make sure no other Transmit blocks are active in the PLC on the same port. Within the Transmit blocks, control inputs allows you to control the communications link between the PLC and DCE (Data Communication

Equipment) devices attached to Modbus port #1 or port#2 of the PLC. The Transmit blocks do NOT activate the port LED when transmitting data.

33002196

Introduction

33002196

XMIT: Transmit (Momentum)

At a Glance

Introduction

What's in this

Chapter?

This chapter describes the XMIT function block.

This chapter contains the following topics:

Topic

Brief Description

Representation

Parameter Description

Description of Data Structure XMIT_SET

Description of Data Structure XMIT_CFG

XMIT ASCII Functions

XMIT Communication Functions

XMIT Modem Functions

XMIT Modbus Functions

FIFO and Flow Control

Run Time Errors

Application Example

Page

33002196

XMIT: Transmit (Momentum)

Brief Description

Function

Description

Using Modbus

Restrictions

Software and

Hardware

Required

The XMIT (Transmit) function block sends Modbus messages from a "master" PLC to multiple slave PLCs or sends ASCII character strings from the PLC's Modbus slave port #1 or port #2 to ASCII printers and terminals. XMIT sends these messages over telephone dialup modems, radio modems, or simply direct connection. XMIT performs general ASCII input functions in the communication mode including simple ASCII and terminated ASCII. You may import and export

ASCII or binary data into your PLC and convert it into various binary data or ASCII to send to DCE devices based upon the needs of your application. The block has builtin diagnostics that checks to make sure no other XMIT blocks are active in the

PLC on the same port. Within the XMIT block a control table allows you to control the communications link between the PLC and DCE (Data Communication

Equipment) devices attached to Modbus port #1 or port #2 of the PLC. The XMIT block does NOT activate the port LED when it is transmitting data.Remember, the

Modbus protocol is a "master/slave" protocol. Modbus is designed to have only one master polling multiple slaves. Therefore, when using the XMIT block in a network with multiple masters, contention resolution and collision avoidance is your responsibility and may easily be addressed through ladder logic programming.

EN and ENO can be configured as additional parameters

Remember, the Modbus protocol is a "master/slave" protocol. Modbus is designed to have only one master polling multiple slaves. Therefore, when using the XMIT block in a network with multiple masters, contention resolution and collision avoidance is your responsibility and may easily be addressed through user logic programming.

This function block controls Modbus port #1 and #2 of the Momentum CPUs. It can be used with the stripped exec only. The XMIT function block works just as its LL984 counterpart, but without ASCII string conversion, copy and compare functions and without the Port Status functions.

When using the Momentum PLCs the XMIT function block it is a builtin.

l l l

The following hardware is not supported by the XXMIT function block:

Soft PLC

Atrium 386 and Atrium-S908 PLCs

IEC Simulator

33002196

XMIT: Transmit (Momentum)

Representation

Symbol

Representation of the block

ANY

XMIT_SET

BYTE

BOOL

MSG_OUT

SET

PORT

START

ABORT

XMIT

MSG_IN

CFG

OP_ACT

NO_SUC

OP_SUC

Ext

ANY

XMIT_CFG

BOOL

DINT

Parameter

Description

Description of the block parameter

Parameters Data type

SET

MSG_OUT

PORT

XMIT_SET

ANY

BYTE

START

ABORT

MSG_IN

CFG

BOOL

ANY

XMIT_CFG

OP_ACT

NO_SUC

OP_SUC

Ext

BOOL

DINT

Meaning

Data structure for the XMIT configuration

Message to be sent (must be in 4x range)

Selection of communications interface

1: Starts XMIT operation

1: Aborts current XMIT operation

Incoming message (must be in 4x range)

Data structure with all components of the XMIT configuration, including the automatically set and not used variables. Only for display and must be in 4x range.

1: XMIT operation in progress

1: There is an error or the current XMIT operation is aborted.

1: XMIT operation successfully completed not presently in use

33002196

XMIT: Transmit (Momentum)

XMIT_SET Data

Structure

Description of data structure

Element

BaudRate

Data type

WORD

DataBits BYTE

Parity

StopBits

BYTE

Command

Word

WORD

MessageLen WORD

RespTimeOut WORD

RetryLimit WORD

XmStartDelay WORD

XmEndDelay WORD

Meaning

This component corresponds to the 4x+3 register

(data rate) of the LL984 XMIT instruction.

This component corresponds to the 4x+4 register

(data bits) of the LL984 XMIT instruction.

This component corresponds to the 4x+5 register

(parity) of the LL984 XMIT instruction.

This component corresponds to the 4x+6 register

(stop bits) of the LL984 XMIT instruction.

This component corresponds to the 4x+8 register

(command word) of the LL984 XMIT instruction.

This component corresponds to the 4x+10 register

(message length) of the LL984 XMIT instruction. (In case of a terminated ASCII receipt, this component will be set automatically.)

This component corresponds to the 4x+11 register

(response time-out (ms)) of the LL984 XMIT instruction.

This component corresponds to the 4x+12 register

(retry limit) of the LL984 XMIT instruction.

This component corresponds to the 4x+13 register

(start of transmission delay (ms)) of the LL984 XMIT instruction.

This component corresponds to the 4x+14 register

(end of transmission delay (ms)) of the LL984 XMIT instruction.

33002196

XMIT: Transmit (Momentum)

XMIT_CFG Data

Structure

Description of data structure

Element

FaultStatus

Data type

WORD

UserAvail_1 WORD

BaudRate

DataBits

Parity

StopBits

WORD

UserAvail_2 WORD

Command

Word

MessagePtr

WORD

MessageLen WORD

RespTimeOut WORD

RetryLimit WORD

XmStartDelay WORD

XmEndDelay WORD

CurrentRetry WORD

Meaning

This component corresponds to the 4x+1 register

(fault status) of the LL984 XMIT instruction.

This component corresponds to the 4x+2 register

(available to user) of the LL984 XMIT instruction.

This component corresponds to the 4x+3 register

(data rate) of the LL984 XMIT instruction.

This component corresponds to the 4x+4 register

(data bits) of the LL984 XMIT instruction.

This component corresponds to the 4x+5 register

(parity) of the LL984 XMIT instruction.

This component corresponds to the 4x+6 register

(stop bits) of the LL984 XMIT instruction.

This component corresponds to the 4x+7 register

(available to user) of the LL984 XMIT instruction.

This component corresponds to the 4x+8 register

(command word) of the LL984 XMIT instruction.

This component corresponds to the 4x+9 register

(message pointer) of the LL984 XMIT instruction.

This component corresponds to the 4x+10 register

(message length) of the LL984 XMIT instruction.

This component corresponds to the 4x+11 register

(response time-out (ms)) of the LL984 XMIT instruction.

This component corresponds to the 4x+12 register

(retry limit) of the LL984 XMIT instruction.

This component corresponds to the 4x+13 register

(start of transmission delay (ms)) of the LL984 XMIT instruction.

This component corresponds to the 4x+14 register

(end of transmission delay (ms)) of the LL984 XMIT instruction.

This component corresponds to the 4x+15 register

(current retry) of the LL984 XMIT instruction.

33002196

XMIT: Transmit (Momentum)

Parameter Description

MSG_OUT

SET

PORT

START

ABORT

MSG_IN

CFG

MSG_OUT contains the message data to be transferred, for example, ASCII characters for an ASCII transfer, definition of termination characters for terminated

ASCII input or Modbus templates for Modbus master messages.

The data type that must be assigned to the parameter has to be a data type WORD array. This array has to be assigned to a 4x register range. The field length must equal the length of the MSG_IN field. If the field is assigned to the range for

Unlocated variables, a runtime error message will be generated.

SET contains the configuration of the XMIT function block in form of the XMIT_SET data structure. This parameter may be assigned to an Unlocated variable.The data structure components have the same function as the components of the LL984

XMIT configuration. There is only one difference, the variables are set automatically by the system and the unused variables are not shown in this data structure. This means, a complete configuration requires that all components in this data structure have to be defined.

PORT specifies the communications interface. The only authorized values are 1 and

A 1-signal at START initiates the XMIT operation. The 1-signal must be applied until the operation has finished or until an error has occurred.

A 1-signal terminates the current XMIT operation and writes the abort code "121" to the "FaultStatus" component of the XMIT_CFG data structure at the CFG output.

MSG_IN contains the incoming message data, for example, terminated ASCII input or responses of a Modbus master command which was previously sent by the XMIT function block.The data type that must be assigned to the parameter has to be a data type WORD array. This array has to be assigned to a 4x register range. The field length must equal the length of the MSG_OUT field. If the field is assigned to the range for Unlocated variables, a runtime error message will be generated.

CFG contains an XMIT function block copy of the configuration defined on SET which has the form of data structure XMIT_CFG, it includes the automatically set and not used variables.The data structure components have the same function as the components of the LL984 XMIT configuration.This data structure has to be assigned to a 4x register range. If the data structure is assigned to the range for

Unlocated variables, a runtime error message will be generated. CFG is used to verify the actually applied configuration.

33002196

OP_ACT

NO_SUC

OP_SUC

EXT

XMIT: Transmit (Momentum)

A 1-signal indicates that an XMIT operation is in progress.

A 1-signal indicates that an error has occurred or that the current XMIT operation is terminated.

A 1-signal indicates that the XMIT operation has been completed successfully.

Presently not use. Do not connect

Description of Data Structure XMIT_SET

XMIT_SET

This data structure contains the particular configuration for the XMIT operation. This variable may be stored in the unlocated memory. The elements of this structure have the same meaning as the corresponding elements of the XMIT_CFG (see

Description of Data Structure XMIT_CFG, p. 20) structure. XMIT_SET is used to

configure the XMIT block. The values of this data structure are transfered to

XMIT_CFG.

Note: XMIT_SET does not contain the MessagePtr element. This is automatically set to the adress of the MSG_IN array and placed into XMIT_CFG.

33002196

XMIT: Transmit (Momentum)

Description of Data Structure XMIT_CFG

At a Glance

This data structure contains the actual configuration data the XMIT block uses. Do not write directly to this array, as the content is automatically generated or copied from XMIT_SET. The following is a detailed description of each of the (16) XMIT communication control table registers.

XMIT_CFG.Revis

ion Read Only

Displays the current revision number of XMIT block. This number is automatically loaded by the function block and over writes any other number entered into this register.

XMIT_CFG.Fault

Status Read

Only

This field displays a fault code generated by the XMIT block. A complete list is shown in the table below.

102

103

104

105

106

9 ... 99

100

101

Fault Code

107

108

109

110

Fault Description

Modbus exception - Illegal function

Modbus exception - Illegal data address

Modbus exception - Illegal data value

Modbus exception - Slave device failure

Modbus exception - Acknowledge

Modbus exception - Slave device busy

Modbus exception -Negative acknowledge

Modbus exception -Memory parity error

Reserved

Slave PLC data area cannot equal zero

Master PLC data area cannot equal zero

Coil (0x) not configured

Holding register (4x) not configured

Data length cannot equal zero

Pointer to message table cannot equal zero

Pointer to message table is outside the range of configured holding registers

(4x)

Transmit message time-out (This error is generated when the UART cannot complete a transmission in 10 seconds or less. This error bypasses the retry counter and will activate the error output on the first error).

Undefined error

Modem returned ERROR

Modem returned NO CARRIER

33002196

XMIT: Transmit (Momentum)

129

130

131

132

125

126

127

128

133

134

121

122

123

124

117

118

119

120

Fault Code

111

112

113

114

115

116

Fault Description

Modem returned NO DIALTONE

Modem returned BUSY

Invalid LRC checksum from the slave PLC

Invalid CRC checksum from the slave PLC

Invalid Modbus function code

Modbus response message time-out

Modem reply time-out

XMIT could not gain access to PLC communications port #1 or port #2

XMIT could not enable PLC port receiver

XMIT could not set PLC UART

User issued an abort command not used not used

Undefined internal state

Broadcast mode not allowed with this Modbus function code

DCE did not assert CTS

Illegal configuration (data rate, data bits, parity, or stop bits)

Unexpected response received from Modbus slave

Illegal command word setting

Command word changed while active

Invalid character count

Invalid register block

ASCII input FIFO overflow error

Invalid number of start characters or termination characters

XMIT_CFG.User

Avail_1

The XMIT block does not use this register. However, it may be used in the user logic as a pointer.

33002196

XMIT: Transmit (Momentum)

XMIT_CFG.Data

Bits

XMIT supports the following data bits: 7 and 8. To configure a data bit size, enter its decimal number into this element. Modbus messages may be sent in ASCII mode or RTU mode. ASCII mode requires 7 data bits, while RTU mode requires

8 data bits. When sending ASCII character message you may use either 7 or 8 data bits. When an invalid data bit is entered, the block displays an illegal configuration error (error code 127) in the XMIT_CFG.FaultStatus element. For more details on

Modbus message formats refer to Modicon Modbus Protocol Reference Guide

(PI MBUS 300).

XMIT_CFG.Parity

XMIT supports the following parity: none, odd and even. Enter a decimal of either:

0 = no parity, 1 = odd parity, or 2 = even parity. When an invalid parity is entered, the block displays an illegal configuration error (error code 127) in the

XMIT_CFG.FaultStatus element.

XMIT_CFG.Stop

Bits

XMIT supports one or two stop bits. Enter a decimal of either: 1 = one stop bit, or

2 = two stop bits. When an invalid stop bit is entered, the block displays an illegal configuration error (error code 127) in the XMIT_CFG.FaultStatus element.

XMIT_CFG.User

Avail_2

The XMIT block does not use this element. However, it may be used in the user logic as a pointer.

XMIT_CFG.

CommandWord

The XMIT interprets each bit of the command word as a function to perform. If bit 7 and 8 are on simultaneously or if any two or more of bits 13, 14, 15 or 16 are on simultaneously or if bit 7 is not on when bits 13, 14, 15, or 16 are on error 129 will be generated. Other restrictions apply. For more details refer to Command Word

Bits, p. 30. The individual bit definitions are shown in the table below.

Bit

Bit 1 (msb)

Definition

Reserved

Bit 2 Enable RTS/CTS modem control Set to 1 when a DCE connected to the PLC requires hardware handshaking using RTS/CTS control.

This bit may be used in conjunction with values contained in XMIT_CFG.XmStartDelay and

XMIT_CFG.XmEndDelay. Start of transmission delay keeps RTS asserted for (X mS) before XMIT sends message out of PLC port. Likewise, end of transmission delay keeps RTS asserted for (X mS) after XMIT has finished sending a message out of the PLC port. Once the end of transmission delay expires XMIT de-assert RTS.

Bit 3 Enable RS485 mode Set to 1 when the selected port should operate in

RS485 mode. Otherwise it defaults to 0, which is

RS232 mode.

33002196

XMIT: Transmit (Momentum)

Bit

Bit 4

Bit 5 Terminated ASCII input

Bit 6 Simple ASCII input

Definition

Reserved

Set to 1 to remove and discard all characters from

FIFO until the starting string is matched, then these starting characters and subsequent characters are written into the MSG_IN array until the terminator sequence is matched. The terminator string is also written into the MSG_IN array. Refer to chapter

"Terminated ASCII Input Function (see Terminated

ASCII Input Function, p. 27 )" for more details.

Set to 1 to remove the ASCII characters from FIFO for writing into the MSG_IN array. The Message pointer (XMIT_CFG.MessagePtr) is automatically set to the register address specified for the MSG_IN array. Refer to chapter "Simple ASCII Input

Function (see

Simple ASCII Input Function, p. 29 )"

for more details.

Bit 7 Enable ASCII string messaging Set to 1 when you want to send ASCII messages out of the PLC. XMIT sends ASCII strings up to 1024 characters in length. You program the ASCII message into the MSG_OUT array. Two characters allowed per register. Only use Bit 7 OR Bit 8, do not try to use both. Refer to chapter "ASCII String

Messaging (see

ASCII String Messaging, p. 29 ) " for

more details.

Bit 8 Enable Modbus messaging

Bit 9 Enable ASCII receive FIFO

Set to 1 when you want to send Modbus messages out of the PLC. Modbus messages may be in either

RTU or ASCII formats. When data bits=8, XMIT uses Modbus RTU format. When data bits=7, XMIT uses Modbus ASCII format. Only use Bit 7 OR Bit 8, do not try to use both.

Set to 1 to allow the XMIT block to take control over the selected port (1 or 2) from the PLC. The block begins to receive ASCII characters into an empty

512 byte circular FIFO. Refer to chapter "ASCII

Receive FIFO (see

ASCII Receive FIFO, p. 37

)" for

more details.

XMIT: Transmit (Momentum)

Bit

Bit 10 Enable back space

Definition

Set to 1 to allow special handling of ASCII back space character (BS, 8Hex). When using either

Simple ASCII Input (Bit 6) or Terminated ASCII Input

(Bit 5) each back space character is removed from

FIFO and may or may NOT be stored into the

MSG_IN array. Refer to chapter "Enable Back space (see

Enable Back space, p. 37

)" for more details.

Bit 11 Enable RTS/CTS flow control Set to 1 to allow full duplex hardware flow control using the RTS and CTS handshaking signals for

ASCII massaging. The RTS/CTS operates in both the input and output modes. Refer to chapter

"Enable RTS/CTS Flow Control (see Enable RTS/

CTS Flow Control, p. 38

)" for more details.

Bit 12 Enable Xon/Xoff flow control

Bit 13 Pulse dial modem

Set to 1 to allow full duplex software flow control using the ASCII Xon character (DC1, 11 Hex) and the ASCII Xoff character (DC3, 13 Hex). The Xon/

Xoff operates in both the input and output modes.

Refer to chapter "Enable Xon/Xoff Flow Control (see

Enable Xon/Xoff Flow Control, p. 39

)" for more details.

Set to 1 when using a Hayes compatible dial-up modem and you wish to pulse dial a telephone number. You program the phone number into the

MSG_IN array. The length of the message must be in XMIT_SET.MessageLen. Pulse dialed numbers are sent to the modem automatically preceded by

ATDP and with carriage return <CR> and line feed

<LF> appended. Since the dial message is an

ASCII string, bit 7 must be ON prior to sending the number to be dialed.

Bit 14 hangup modem Set to 1 when using a Hayes compatible dial-up modem and you want to hangup the modem. You must use ladder logic to turn this bit ON. Since the hangup message is an ASCII string, bit 7 must be

ON prior to sending the message. Hang up messages are sent to the modem automatically preceded by +++AT and with carriage return <CR> and line feed <LF> appended. XMIT looks for a correct disconnect response from the modem before it turns ON the OP_SUC output signal, noting a successful completion.

33002196

XMIT_CFG.

MessagePtr

XMIT_CFG.

MessageLen

Bit

Bit 15 Tone dial modem

Bit 16 Initialize modem

XMIT: Transmit (Momentum)

Definition

Set to 1 when using a Hayes compatible dial-up modem and you wish to tone dial a telephone number. The the dial message must be placed in

MSG_OUT array and the length of the message in

XMIT_SET.MessageLen. Tone dial numbers are sent to the modem automatically preceded by ATDT and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be ON prior to sending the number to be dialed.

Set to 1 when using a Hayes compatible dial-up modem and you want to initialize the modem. You program the initialization message into the

MSG_OUT array and the length of the message

XMIT_SET.MessageLen. All messages are sent to the modem automatically preceded by AT and with a carriage return <CR> and line feed <LF> appended. Since the initialization message is an

ASCII string, bit 7 must be ON prior to sending the message.

This pointer is automatically handled by the XMIT block. It points to the beginning of the message table which is either the MSG_IN (see

MSG_IN, p. 18) array or the

MSG_OUT (see

MSG_OUT, p. 18) array depending on the chosen XMIT function.

Each array element (4x register) holds up to two ASCII characters. Each ASCII string may be up to 1024 characters in length. For example, when you want to send

10 ASCII messages out of the PLC, you must transfer the10 ASCII characters strings into the MSG_OUT array one after another after each successful operation of XMIT.

You enter the length of the current message. When XMIT is sending Modbus messages for function codes 01, 02, 03, 04, 05, 06, 08, 15 and 16, the length of the message is automatically set to five. When XMIT is receving Terminated ASCII input the length of the message must be set to five or an error results. When XMIT is sending Modbus messages for function codes twenty and twenty-one, the length of the message is automatically set to six. When XMIT is sending ASCII messages, the length may be 1 ... 1024 ASCII characters per message.

33002196

XMIT: Transmit (Momentum)

XMIT_CFG.Resp

TimeOut

You enter the time value in milliseconds (ms) to determine how long XMIT waits for a valid response message from a slave device (PLC, modem, etc.). In addition, the time applies to ASCII transmissions and flow control operations. When the response message is not completely formed within this specified time, XMIT issues a fault. The valid range is 0 ... 65535 ms. The timeout is initiated after the last character in the message is sent.

XMIT_CFG.Retry

Limit

You enter the quantity of retries to determine how many times XMIT sends a message to get a valid response from a slave device (PLC, modem, etc.). When the response message is not completely formed within this specified time, XMIT issues a fault and a fault code. The valid range is 0 ... 65535 # of retries. This field is used in conjunction with response time-out (4x + 11).

XMIT_CFG.Start

Delay

You enter the time value in milliseconds (ms) when RTS/CTS control is enabled, to determine how long XMIT waits after CTS is received before it transmits a message out of the PLC port #1. Also, you may use this register even when RTS/CTS is NOT in control. In this situation, the entered time value determines how long XMIT waits before it sends a message out of the PLC port #1. You may use this as a pre message delay timer. The valid range is 0 ... 65535 ms.

XMIT_CFG.Xm

EndDelay

XMIT_CFG.Xm

CurrentRetry

You enter the time value in milliseconds (ms) when RTS/CTS control is enabled, to determine how long XMIT keeps RTS asserted once the message is sent out of the

PLC port #1. After the time expires, XMIT deassert RTS. Also, you may use this register even when RTS/CTS is NOT in control. In this situation, the entered time value determines how long XMIT waits after it sends a message out of the PLC port

#1. You may use this as a post message delay timer. The valid range is

0 ... 65535 ms.

The value displayed here indicates the current number of retry attempts made by the XMIT block. This register is read only.

33002196

XMIT: Transmit (Momentum)

XMIT ASCII Functions

At a Glance

Terminated

ASCII Input

Function

33002196

The XMIT function block supports the following ASCII communication functions: l l l

Simple ASCII Input

Terminated ASCII Input

ASCII String Messaging

When XMIT_CFG.CommandWord, Bit 5 is actived for terminated ASCII Input messages, the MSG_OUT array has to contain the ASCII input definition table. The terminated ASCII definition table is five registers long. The message length

XMIT_CFG.MessageLen is automatically set. The terminated ASCII input definition table is shown in the table below.

Terminated ASCII Input Definition Table

Word High Byte Low Byte

MSG_OUT[1] Number of starting characters (allowed content = 0, 1, 2)

MSG_OUT[2] First starting character

Number of terminator characters

(allowed content = 1, 2)

Second starting character

MSG_OUT[3] First terminator character Second terminator character

MSG_OUT[4] Not used. Destination register is automatically set to MSG_IN

MSG_OUT[5] Counter: counts the number of received characters written into the 4x storage destination registers

During the process, MSG_OUT[5] holds a running count of characters written into the MSG_IN array. Once the terminated string is received the OP_SUC output on the XMIT block goes ON and MSG_OUT[5] holds the total length of the received string including the starting and terminator strings. At this point the XMIT block stills owns the port and continues to save newly received characters into the ASCII receive FIFO, because the enable ASCII receive FIFO XMIT_CFG.CommandWord,

Bit 9 is ON.Using program logic, you can clear the simple ASCII input Bit before the next scan, while leaving the enable ASCII receive FIFO Bit ON. Thus, MSG_IN is

NOT over written by newer FIFO data, which is still collected in the FIFO. Using program logic, you can clear both bits for enable ASCII receive FIFO ( Bit 9), and terminated ASCII input (Bit 5) to return port control back to the PLC. When too many characters are written into the MSG_IN array with NO terminator detected, or the

MSG_IN array is outside the allowed range for the configured PLC an error is reported in XMIT_CFG.FaultStatus. The character limit is the smaller of 1024 or two times the sizes of the MSG_IN array. We recommend you place the MSG_IN array for terminated ASCII input past all other 4x registers used in the application to avoid being over written by ASCII input in case the terminator is absent. Also, you could allocate 512 registers for the MSG_IN array.

XMIT: Transmit (Momentum)

Terminated

ASCII Example

Assume that XMIT is activated with the command word Bit 9 and 5 set. Enable

ASCII FIFO and terminated ASCII. The following ASCII string is received by the port: "AMScrlf$weight= 1245 GRAMScrlf$wei". Refer to the ASCII Input Definition

Table that shows the contents denoted by ( ) used in this example.

Terminated ASCII Input Definition Table Example (contents)

Word High Byte

MSG_OUT[1] Number of starting characters

(0x01)

MSG_OUT[2] First starting character ('$')

MSG_OUT[3] First terminator character ('cr')

Low Byte

Number of terminator characters

(0x02)

Second starting character (Not Used)

Second terminator character ('if'')

MSG_OUT[4] n.a.

n.a.

MSG_OUT[5] Counter: counts the number of received characters written into the 4x storage destination registers

The XMIT block becomes ACTIVE and then discards from the input FIFO the initial five characters, "AMScrlf", because they do not match the first starting character set to '$'. On the logic scan after the '$' is received, the XMIT block remains ACTIVE and it copies the '$' and subsequent characters into the MSG_IN array, updating

MSG_OUT[5] of the ASCII Input Definition Table with the count done so far, as the characters come in. After the final termination character is received the output

OP_SUC "Operation Successful" is activated and MSG_OUT[5] of the ASCII Input

Definition Table contains the total length equal to 0x0016. The MSG_IN array contains: "$w", "ei", "gh", "t", "=", "12", "45", "G", "RA", "MS", "cflf". On the scan that the output OP_SUC "Operation Successful" is activated, the already received characters from the next message, "$wei", that came in after the termination string, remains in the ASCII input FIFO. This gives the program logic the opportunity to turn off the Terminated ASCII input before the next scan solve of XMIT for this port, keeping those characters in the FIFO until the PLC completes processing the current message, that might take several scans.

33002196

Simple ASCII

Input Function

XMIT: Transmit (Momentum)

All incoming characters are placed into the MSG_IN array. Two characters are stored in each element. The first character transferred from FIFO is stored in the high byte of the first element. The second character is transferred from FIFO is stored in the low byte of the first element. The third character is stored in the high byte of the second element, and so on. The Message Length variable

(XMIT_CFG.MessageLen) contains the length of the message (1 ... 1024).

Therefore, the Message Length variable (XMIT_CFG.MessageLen) decreases as the characters are transferred from FIFO into the MSG_IN array. Once the entire message is transfered the Message Length variable (XMIT_CFG.MessageLen) restores its initial value and the XMITs Operation Successful output OP_SUC is activated. To enter the desired message length use the XMIT_SET.MessageLen element.

Note: When Simple ASCII Input (Bit 6) and ASCII Receive FIFO (Bit 9) remain set, new characters are constantously transferred from FIFO into the same MSG_IN array thus constantly over writing the previous characters stored into the MSG_IN array.

ASCII String

Messaging

When XMIT_CFG.CommandWord, Bit 7 is actived for String Messaging, the

MSG_OUT array has to contain the ASCII information to be transmitted. Two characters are stored in each element of the MSG_OUT array. The message length

XMIT_SET.MessageLen has to be set to the lenght of the message to be transmitted.

33002196

XMIT: Transmit (Momentum)

XMIT Communication Functions

XMIT Command

Word

The XMIT communication block performs six functions shown below. For each function certain bits of the command word (XMIT_CFG.CommandWord) must be set.

Command Word

Bits

XMIT_CFG.CommandWord Functions in Relation to Bits

XMIT_CFG.Command

Word Function

Command word bits that must be set to 1

Terminated ASCII input

(Bit 5=1) *

2,3,9,10,11,12

Simple ASCII input (Bit 6=1)

2,3,9,10,11,12

Simple ASCII output

(Bit 7=1)

2,3,9,10,11,12

Modem output (Bit 7=1) 2,3,13,14,15,16

2,3

Bits that MUST be set to = 0

6,7,8,13,14,15,16

5,7,8,13,14,15,16

5,6,8,13,14,15,16

5,6,8,9,10,11,12 (plus one, but

ONLY one, of the following bits is set to 1: 13,14,15 or 16, while the other three bits must be set to 0)

5,6,7,9,10,11,12,13,14,15,16 Modbus master messaging output (Bit 8=1)

Enable ASCII receive input

FIFO ONLY (Bit 9=1)

2,3,10,11,12 5,6,7,8,13,14,15,16

Note: * When using either of these functions you MUST set Enable ASCII receive

FIFO ( Bit 9) to 1.

33002196

XMIT: Transmit (Momentum)

XMIT Modem Functions

At a glance

The XMIT function block allows you to communicate to a Hayes compatible modem using the functions listed in the following table:

Modem Functions

Bit in Command Word

Bit 13

Bit 14

Bit 15

Bit 16

Function

Pulse dial modem

Hangup modem

Tone dial modem

Initialize modem

Initialize Modem

Set to 1 when using a Hayes compatible dial-up modem and you want to initialize the modem. You program the initialization message into the MSG_OUT array and the length of the message into XMIT_SET.MessageLen. All messages are sent to the modem automatically preceded by AT and with a carriage return <CR> and line feed <LF> appended. Since the initialization message is an ASCII string, bit 7 must be ON prior to sending the message.

Pulse Dial

Modem

Set to 1 when using a Hayes compatible dial-up modem and you wish to pulse dial a telephone number. You program the phone number into the MSG_IN array. The length of the message must be in XMIT_SET.MessageLen. Pulse dialed numbers are sent to the modem automatically preceded by ATDP and with carriage return

<CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit

7 must be ON prior to sending the number to be dialed.

Tone Dial Modem

Set to 1 when using a Hayes compatible dial-up modem and you wish to tone dial a telephone number. The the dial message must be placed in MSG_OUT array and the length of the message in XMIT_SET.MessageLen. Tone dial numbers are sent to the modem automatically preceded by ATDT and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be

ON prior to sending the number to be dialed.

Hangup Modem

Set to 1 when using a Hayes compatible dial-up modem and you want to hangup the modem. You must use program logic to turn this bit ON. Since the hangup message is an ASCII string, bit 7 must be ON prior to sending the message. Hang up messages are sent to the modem automatically preceded by +++AT and with carriage return <CR> and line feed <LF> appended. XMIT looks for a correct disconnect response from the modem before it turns ON the OP_SUC output signal, noting a successful completion.

33002196

XMIT: Transmit (Momentum)

XMIT Modbus Functions

At a Glance

The XMIT function block supports the following Modbus function codes: l l l l

01 ... 06

15 and 16

20 and 21

For Modbus messages, the MSG_OUT array has to contain the Modbus definition table. The Modbus definition table for Modbus function code: 01, 02, 03, 04, 05, 06,

15 and 16 is five registers long and you must set XMIT_SET.MessageLen to 5 for successful XMIT operation. The Modbus definition table is shown in the table below

Modbus

Function Codes

01...06

For Modbus messages, the MSG_OUT array has to contain the Modbus definition table. The Modbus definition table for Modbus function code: 01, 02, 03, 04, 05, 06,

15 and 16 is five registers long and you must set XMIT_SET.MessageLen to 5 for successful XMIT operation. The Modbus definition table is shown in the table below

Modbus Definition Table Function Codes (01 ... 06, 15 and 16)

Content

Modbus function code

(MSG_OUT[1])

Quantity

(MSG_OUT[2])

Slave PLC address

(MSG_OUT[3])

Description

XMIT supports the following function codes:

01 = Read multiple coils (0x)

02 = Read multiple discrete inputs (1x)

03 = Read multiple holding registers (4x)

04= Read multiple input registers (3x)

05 = Write single coil (0x)

06 = Write single holding registers (4x)

15 = Write multiple coils (0x)

16 = Write multiple holding registers (4x)

Enter the amount of data you want written to the slave PLC or read from the slave PLC. For example, enter 100 to read 100 holding registers from the slave PLC or enter 32 to write 32 coils to a slave PLC. There is a size limitation on quantity that is dependent on the PLC model. Refer to

Appendix A for complete details on limits.

Enter the slave Modbus PLC address. Typically the Modbus address range is 1 ... 247. To send a Modbus message to multiple PLCs, enter 0 for the slave PLC address. This is referred to as Broadcast Mode.

Broadcast Mode only supports Modbus function codes that writes data from the master PLC to slave PLCs. Broadcast Mode does NOT support

Modbus function codes that read data from slave PLCs.

33002196

XMIT: Transmit (Momentum)

Content

Slave PLC data area

(MSG_OUT[4])

Master PLC data area

(MSG_OUT[5])

Description

For a read command, the slave PLC data area is the source of the data.

For a write command, the slave PLC data area is the destination for the data. For example, when you want to read coils (00300 ... 00500) from a slave PLC, enter 300 in this field. When you want to write data from a master PLC and place it into register (40100) of a slave PLC, enter 100 in this field. Depending on the type of Modbus command (write or read), the source and destination data areas must be as defined in the Source and

Destination Data Areas table below.

(00016 ... 00032) located in the master PLC to a slave PLC, enter 16 in the field. When you want to read input registers (30001 ... 30100) from a slave

PLC and place the data into the master PLC data area (40100 ... 40199), enter 100 in this field. Depending on the type of Modbus command (write or read), the source and destination data areas must be as defined in the

Source and Destination Data Areas table below.

Source and Destination Data Areas for Function Codes (01 ... 06, 15 and 16)

Function Code

03 (Read multiple 4x)

04 (Read multiple 3x)

01 (Read multiple 0x)

02 (Read multiple 1x)

16 (Write multiple 4x)

15 (Write multiple 0x)

05 (Write single 0x)

06 (Write single 4x)

Master PLC Data Area

4x (destination)

0x (destination)

4x (source)

0x (source)

4x (source)

Slave PLC Data Area

4x (source)

3x (source)

0x (source)

1x (source)

4x (destination)

0x (destination)

4x (destination)

When you want to send 20 Modbus messages out of the PLC, you must transfer 20

Modbus definition tables one after another into MSG_OUT after each successful operation of XMIT, or you may program 20 separate XMIT blocks and then activate them one at a time through user logic.

XMIT: Transmit (Momentum)

Modbus

Function Code

(08)

The Modbus definition table for Modbus function code: 08 is five registers long and you must you must set XMIT_SET.MessageLen to 5 for For Modbus messages, the

MSG_OUT array has to contain the Modbus definition successful XMIT operation.

The Modbus definition table is shown in the table below.

Modbus Definition Table Function Codes (08)

Content

Modbus function code

(MSG_OUT[1])

Diagnostics (MSG_OUT[2])

Description

XMIT supports the following function code: 08 = Diagnostics

Slave PLC address

(MSG_OUT[3])

Diagnostics function data field content (MSG_OUT[4])

Enter the diagnostics subfunction code decimal value in this filed to perform the specific diagnostics function desired.

The following diagnostic subfunctions are supported:

Code Description

00 Return query data

01 Restart comm option

02 Return diagnostic register

03 Change ASCII input delimiter

04 Force listen only mode

05 ... 09 Reserved

10 Clear counters (& diagnostics registers in 384, 484)

11 Return bus messages count

12 Return bus comm error count

13 Return bus exception error count

14 ... 15 Not supported

16 Return slave NAK count

17 Return slave busy count

18 Return bus Char overrun count

19 ... 21 Not supported

Enter the slave Modbus PLC address. Typically the Modbus address range is 1 ... 247. Function code 8 dose NOT support Broadcast Mode (Address 0)

You must enter the decimal value needed for the data area of the specific diagnostic subfunction. For subfunctions 02,

04, 10, 11, 12, 13, 16, 17 and 18 this value is automatically set to zero. For subfunctions 00, 01, and 03 you must enter the desired data field value. For more details, refer to

Modicon Modbus Protocol Reference Guide (PI-MBUS-

300).

33002196

Content

Master PLC data area

(MSG_OUT[5])

XMIT: Transmit (Momentum)

Description

For all subfunctions, the master PLC data area is the destination for the data returned by the slave. You must specify a 4x register that marks the beginning of the data area where the returned data is placed. For example, to place the data into the master PLC data area starting at

(40100), enter 100 in this field. Subfunction 04 does NOT return a response. For more details, refer to Modicon

Modbus Protocol Reference Guide (PI-MBUS-300).

Modbus

Function Codes

(20, 21)

For Modbus messages, the MSG_OUT array has to contain the Modbus definition table. The Modbus definition table for Modbus function codes: 20 and 21 is six registers long and you must you must set XMIT_SET.MessageLen to 6 for successful XMIT operation. The Modbus definition table is shown in the table below.

Modbus Definition Table Function Codes (20, 21)

Content

Modbus function code

(MSG_OUT[1])

Quantity (MSG_OUT[2])

Slave PLC address

(MSG_OUT[3])

Slave PLC data area

(MSG_OUT[4])

Description

XMIT supports the following function codes: 20 = Read general reference (6x) 21 = Write general reference (6x)

Enter the amount of data you want written to the slave PLC or read from the slave PLC. For example, enter 100 to read

100 holding registers from the slave PLC or enter 32 to write

32 coils to a slave PLC. There is a size limitation on quantity that is dependent on the PLC model. Refer to Appendix A for complete details on limits.

Enter the slave Modbus PLC address. Typically the Modbus address range is 1 ... 247. Function code 20 and 21 do NOT support Broadcast Mode (Address 0).

For a read command, the slave PLC data area is the source of the data. For a write command, the slave PLC data area is the destination for the data. For example, when you want to read registers (600300 ... 600399) from a slave PLC, enter 300 in this field. When you want to write data from a master PLC and place it into register (600100) of a slave

PLC, enter 100 in this field. Depending on the type of

Modbus command (write or read), the source and destination data areas must be as defined in the Source and

Destination Data Areas table below. The lowest extended register is addressed as register "zero" (600000). The lowest holding register is addressed as register "one"

(400001).

33002196

XMIT: Transmit (Momentum)

Content

Master PLC data area

(MSG_OUT[5])

File number (MSG_OUT[6])

Description

For a read command, the master PLC data area is the destination for the data returned by the slave. For a write command, the master PLC data area is the source of the data. For example, when you want to write registers (40016

... 40032) located in the master PLC to 6x registers in a slave PLC, enter 16 in the filed. When you want to read 6x registers (600001 ... 600100) from a slave PLC and place the data into the master PLC data area (40100 ... 40199), enter 100 in this field. Depending on the type of Modbus command (write or read), the source and destination data areas must be as defined in the Source and Destination

Data Areas table below. The lowest extended register is addressed as register "zero" (600000). The lowest holding register is addressed as register "one" (400001).

Enter the file number for the 6x registers to be written to or read from. (1 ... 10) depending on the size of the extended register data area. 600001 is 60001 file 1 and 690001 is

60001 file 10 as viewed by the Reference Data Editor.

Source and Destination Data Areas for Function Codes (20, 21)

Function Code Master PLC Data Area

20 (Read general reference 6x) 4x (destination)

21 (Write general reference 6x) 4x (source)

Slave PLC Data Area

6x (source)

6x (destination)

When you want to send 20 Modbus messages out of the PLC, you must transfer 20

Modbus definition tables one after another into MSG_OUT after each successful operation of XMIT, or you may program 20 separate XMIT blocks and then activate them one at a time through user logic.

33002196

XMIT: Transmit (Momentum)

FIFO and Flow Control

At a Glance

ASCII Receive

FIFO

Enable Back

Space

The XMIT function block allows the the user to define the use of a receive FIFO buffer, flow control and the function of received back spaces.

Setting this bit to 0 ends this function. When the FIFO receives 512 characters an internal overflow is set. When this occurs all subsequent characters are discarded, all ASCII input operations (simple and terminated) are ended, and the block returns an error until you toggle (Bit 9). When (Bit 9) is toggled, all data in the FIFO is discarded, both ASCII input control bits are ignored (Simple ASCII (Bit 6),

Terminated ASCII (Bit 5)), and when no ASCII output controls are selected then the control of the port (1 or 2) is returned back to the PLC. You need to set either

Terminated ASCII (Bit 5) or Simple ASCII (Bit 6) to remove the ASCII characters from FIFO for processing. No more than one of the following three bits can be set simultaneously: Terminated ASCII (Bit 5), Simple ASCII (Bit 6), or ASCII Output (Bit

7). Full duplex operation may be achieved by setting both ASCII Receive FIFO (BIT

9), and ASCII Output (Bit 7). This allows simple ASCII transmission out of the PLC while still receiving ASCII characters into FIFO. This is useful when working with dumb terminals. When ASCII Receive FIFO (Bit 9) is set none of the following ASCII output controls are allowed: Modbus Master Messaging (Bit 8), Pulse Dial Modem

(Bit 13), Hangup Modem (Bit 14), Tone Dial Modem (Bit 15) and Initialize Modem

(Bit 16).

When a BS is detected it is NOT stored into the MSG_IN array, in fact it deletes the previous character and thus decreases the Terminated (Bit 5) Character Counter

(MSG_OUT[5]) of the ASCII Input Definition Table. In contrast, when a regular

ASCII character is detected it is stored into the MSG_IN array and the Terminated

(Bit 5) Character Counter of the ASCII Input Definition Table is increased.

Note: Back spaces CANNOT delete characters from an empty MSG_IN array, thus the Terminated (Bit 5) Character Counter of the ASCII Input Definition Table never goes below 0.

This special back space functionality along with internal echo enabled at the terminal are very useful for dealing with dumb terminals. A single Terminated ASCII Input

XMIT block searching for "cr" is activated with ASCII Receive FIFO (Bit 9) and back space (Bit 10) set. No additional ladder logic is required while the you type and edit characters using the back space on the fly. When you type "cr" XMIT activates the bottom output "Operation Successful", and the corrected data is all lined up properly in the MSG_IN array.

33002196

XMIT: Transmit (Momentum)

Enable RTS/CTS

Flow Control

The following pertains to the output mode. The XMIT state goes to BLOCKED receiving when the receiving device indicates it cannot process additional characters by setting CTS to OFF. Likewise, The XMIT state goes to UNBLOCKED when CTS is ON and the receiving devices indicates it CAN process additional characters. When transmission is UNBLOCKED and Simple ASCII Output (Bit 7) and RTS/CTS Flow Control (Bit 11) are set then the transmit output data is sent out in 16 byte packets. After all output packets are sent then the OP_SUC output on the

XMIT block goes ON "Operation Successful".If during a transmission it suddenly becomes BLOCKED, only the remaining characters in the current output packet are sent, never exceeding 16 characters, and the XMIT block remains ACTIVE indefinitely. Only when the CTS in ON will the ASCII output resume sending all remaining output packets. The following pertains to the input mode. Since RTS is an output signal, it can be used independently of the ASCII output transmit process, to BLOCK or UNBLOCK sending devices. When ASCII Receive FIFO (Bit 9) is set the RTS/CTS Flow Control works in the input mode. When ASCII Receive FIFO (Bit

9) is set and neither of the two ASCII inputs are set, Simple ASCII Input (Bit 6) or

Terminated ASCII Input (Bit 5), the received characters will fill the FIFO in which they are inserted. Mean time the RTS Flow Control (Bit 11) is ON allowing the sending device to proceed. When the FIFO is more than three quarters full with characters the RTS Control Flow (Bit 11) is cleared to BLOCK the sending device. The RTS

Control Flow (Bit 11) remains cleared until either Simple ASCII Input (Bit 6) or

Terminated ASCII Input (Bit 5) have removed enough characters from the FIFO whereby reducing it to less than one quarter full of characters at which point the RTS

Control Flow (Bit 11) is tuned ON.

Note: The RTS/CTS Flow Control algorithm is different from RTS/CTS Modem

Control. The former is related to full duplex receive buffer overflow. The latter deals with the transmit process gaining access to a shared transmission medium.

Therefore, it is illegal to simultaneously request both of these RTS/CTS algorithms.

Note: You CANNOT select any type of RTS/CTS Flow Control (Bit 11) handshaking when the port is in RS 485 Mode (Bit 3) because these signals do

NOT exist in RS 485 mode.

33002196

XMIT: Transmit (Momentum)

Enable Xon/Xoff

Flow Control

The following pertains to the output mode. The XMIT state goes to BLOCKED when

Xoff character is received. Likewise the XMIT state goes to UNBLOCKED when

Xon character is received. In neither case will Xon or Xoff be inserted into the

FIFO.When transmission is UNBLOCKED and Simple ASCII Output (Bit 7) and Xon/

Xoff Flow Control (Bit 12) are set then the transmit output data is sent out in 16 byte packets. After all output packets are sent then the bottom output on the XMIT block goes ON "Operation Successful".If during a transmission it suddenly becomes

BLOCKED, only the remaining characters in the current output packet are sent, never exceeding 16 characters, and the XMIT block remains ACTIVE indefinitely.

Only when the next Xon character is received will the ASCII output resume sending all remaining output packets. The following pertains to the input mode. Xon/Xoff may be used to BLOCK or UNBLOCK sending devices. When ASCII Receive FIFO

(Bit 9) is set the Xon/Xoff Control Flow (Bit 12) works in the input mode. When ASCII

Receive FIFO (Bit 9) is set and neither of the two ASCII inputs are set, Simple ASCII

Input (Bit 6) or Terminated ASCII Input (Bit 5), the received characters will fill the

FIFO in which they are inserted.When the FIFO is more than three quarter full with characters and additional characters are received the FIFO state variable is set to send XOFF character out the serial port after a delay of up to 16 character times

BLOCKING the sender and clearing the FIFO state variable. When all ASCII output functions are (Bits 8,13,14,15, and 16) OFF and the Xon/Xoff Flow Control (Bit 12) is ON the delay time defaults to 1 character time. In contrast, when all ASCII output functions are (Bits 8,13,14,15, and 16) ON and the Xon/Xoff Flow Control (Bit 12) is

ON then the ASCII output is broken up into 16 byte packets. Thus, pending Xoff characters DO NOT have to wait more than 16 character times before BLOCKING the sender. Once the sender has stopped transmission, the PLC eventually removes the characters form the FIFO using either Simple ASCII Input (Bit 6) or

Terminated ASCII Input (Bit 7). When FIFO becomes less than one quarter full with characters the FIFO state variable is set to send XON. Thus, sending a Xon character out the serial port to UNBLOCK the sender.

Note: To prevent lockup due to a disconnected cable or other intermittent communication errors, when the sender is BLOCKED and did NOT receive the Xon character correctly we use the following algorithm. When FIFO becomes empty and no characters are subsequently received, then a steady stream of Xon characters are transmitted at the rate of once every 5 seconds.

33002196

Note: The Xon/Xoff Flow Control (Bit 12) is different from the RTS/CTS Control

Flow (Bit 11). The former uses transmitted Xon and Xoff characters to prevent receive buffer overflow in full duplex mode. The latter uses hardware shaking signals to accomplish the same goal. Therefore, it is illegal to simultaneously request both of these flow control algorithms because RTS/CTS Flow Control (Bit

11) Modem Control implies a half duplex network while Xon/Xoff Flow Control (Bit

12) implies a full duplex network.

XMIT: Transmit (Momentum)

Run Time Errors

Error Messages

In case of error, the XMIT function block will generate the following runtime error:

ILLEGAL_CONFIG_DATA

This will be displayed in the Online Event dialog.

Subject to the value of the first error message parameter, the error message may have various origins.

l l l

One or more variables linked to MSG_OUT, MSG_IN or CFG are not within the

4x register range

An invalid value for the communications interface was selected at the PORT input. Authorized values are "1" and "2"

The wrong message length was selected.

The message length defined in the "MessageLen" component of data structure

XMIT_SET at the SET input is greater than the length of the variable attached at the MSG_OUT output.

33002196

XMIT: Transmit (Momentum)

Application Example

Description

IEC Section

The following program is a short demo application which allows to easily switch between the four main functions of the XMIT block: l l l l

ASCII Message Out (0)

Simple ASCII In (1)

Terminated ASCII In (2)

Modbus Master (3)

To select the function enter the appropriate number into the ModeSelection variable.

A rising signal on X_Trigger activates the XMIT block by setting the Start variable 1.

Start remains 1 until the function has been performed or an error occured.

Selection of configuration data

.1.14 (2)

MUX_UINT

K Mode Selection

MessageAsciiOut

MessageSimple AsciiIn

MessageTermAsciiIn

MessageModbus

DirectMessageOut

Mode Selection

XmitSetForAsciiOut

XmitSetForSimpleAsciiIn

XmitSetForTermAsciiIn

XmitSetForModbus

.1.15 (3)

MUX_UINT

DirectXmitSet

33002196

XMIT: Transmit (Momentum)

XMIT function block

DirectMessageOut

DirectXmitSet

Port

Start

Abort

FBI_1_1 (1)

XMIT

MSG_OUT

SET

PORT

START

ABORT

MSG_IN

CFG

OP_ACT

NO_SUC

OP_SUC

EXT

DirectMessageIn

DirectXmitConfig opActive opError opDone

Keeps Start "on" until command finished or an error occurs

X_Trigger

FBI_1_25 (5)

R_TRIG

CLK Q

.1.26 (7)

R opDone opError

.1.27 (6)

OR_BOOL

Start

33002196

Variable

Declarations

XMIT: Transmit (Momentum)

The following tables show the variables used in this example

Variable table

Variable Name

Start

Abort opActive opError opDone

Port

DirectMessageOut

DirectXmitSet

DirectMessageIn

DirectXmitConfig

X_Trigger

ModeSelection

Message AsciiOut

MessageSimpleAsciiIn

MessageTermAsciiIn

BOOL

BYTE

WordArr256 400257

XMIT_SET 400513

WordArr256 400001

XMIT_CFG 400523

BOOL

UINT

WordArr256

MessageModbus WordArr256

XmitSetForAsciiOut XMIT_SET

XmitSetForSimpleAsciiIn XMIT_SET

XmitSetForTermAsciiIn XMIT_SET

XmitSetForModbus

Data Type

BOOL

XMIT_SET

Address Description

Must remain ON until the XMIT has been finished

Aborts XMIT operation

Indicates XMIT Status

Select port 1 or 2

Actual configuration data or data to be transmitted

Actual configuration data

Data received by ASCII In functions

Actual configuration data

Triggers the XMIT function

Select the requested function 0..3

Message to be transmitted by ASCII

Out

(no content needed)

Configuration data for Terminated

ASCII In

Configuration data for Modbus

Configuration data for ASCII Out

Configuration data for Simple ASCII

Configuration data for Terminated

ASCII In

Configuration data for Modbus

33002196

XMIT: Transmit (Momentum)

Înitial Values

The following tables show the initial values for the different arrays used:

Content of XmitSetForAaciiOut Data Structure

Element Name

BaudRate

DataBits

Parity

StopBits

CommandWord

MessageLen

Data Type

WORD

BYTE

WORD

Address

9600

512

Comment

Bit 7 set

Transmits the first 16 Characters from MessageAsciiOut array

RespTimeOut

RetryLimit

XmStartDelay

XmEndDelay

WORD

100

Content of XmitSetForSimpleAsciiIn Data Structure

Comment Element Name

BaudRate

DataBits

Parity

StopBits

CommandWord

MessageLen

Data Type

WORD

BYTE

WORD

Address

9600

1152

Bits 6 and 9 set opDone is set to 1 after receiving 16 characters

RespTimeOut

RetryLimit

XmStartDelay

XmEndDelay

WORD

100

33002196

XMIT: Transmit (Momentum)

Content of XmitSetForTermAsciiIn Data Structure

Comment Element Name

BaudRate

DataBits

Parity

StopBits

CommandWord

MessageLen

Data Type

WORD

BYTE

WORD

Address

9600

2176

Bits 5 and 9 set

The DirectXmitSet.MessageLen element will be automatically set to 5 independent of this entry

RespTimeOut

RetryLimit

XmStartDelay

XmEndDelay

WORD

100

Content of XmitSetForModbus Data Structure

Element Name

BaudRate

DataBits

Parity

StopBits

CommandWord

MessageLen

Data Type

WORD

BYTE

WORD

Address

9600

256

Comment

RTU Mode

Bit 8 set

For Function Codes 01...06, 15 and

RespTimeOut

RetryLimit

XmStartDelay

XmEndDelay

WORD

1000

100

XMIT: Transmit (Momentum)

Content of MessageAsciiOut Data Structure

Element Name

MessageAsciiOut[2]

MessageAsciiOut[3]

MessageAsciiOut[4]

MessageAsciiOut[5]

MessageAsciiOut[6]

MessageAsciiOut[7]

MessageAsciiOut[8]

MessageAsciiOut[...]

Data Type

WORD

Address

17220

17734

18248

18762

19276

19790

20304

...

Comment

'CD' to be transmitted)

'EF'

'GH'

'IJ'

'KL'

'MN'

'OP'

Content of MessageTermAsciiIn Data Structure

Element Name

MessageAsciiOut[1]

Data Type

WORD

Address

258

MessageAsciiOut[2]

MessageAsciiOut[3]

WORD

9216

3338

Comment

0x0102 1 starting and 2 termination characters

0x2400 First starting character '$'

0x0D0A Termination characters

[CR][LF]

Content of MessageModbus Data Structure

Element Name

MessageAsciiOut[1]

MessageAsciiOut[2]

MessageAsciiOut[3]

MessageAsciiOut[4]

MessageAsciiOut[5]

Data Type

WORD

Address

101

701

Comment

Read multiple holding registers (4x)

Read 32 registers

Slave PLC modbus address

Start with register 40101

Data destination is register 40701

33002196

XXMIT: Transmit (Compact,

Momentum, Quantum)

At a Glance

Introduction

What's in this

Chapter?

This chapter describes the XXMIT function block.

This chapter contains the following topics:

Topic

Brief Description

Representation

Detailed Parameter Description

XXMIT Communication Functions

XXMIT ASCII Functions

XXMIT Modem Functions

XXMIT Modbus Functions

FIFO and Flow Control

Run Time Errors

Application Example

Page

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Brief Description

Function

Description

The XXMIT (Transmit) function block sends Modbus messages from a "master" PLC to multiple slave PLCs or sends ASCII character strings from the PLC's Modbus slave port#1 (on Momentum PLCs also port#2 is supported) to ASCII printers and terminals. XXMIT sends these messages over telephone dialup modems, radio modems, or simply direct connections. XXMIT performs general ASCII input functions in the communication mode including simple ASCII and terminated ASCII.

You may import and export ASCII or binary data into your PLC. The block has builtin diagnostics that checks to make sure no other XXMIT blocks are active in the PLC on the same port. Within the XXMIT block control inputs allows you to control the communications link between the PLC and DCE (Data Communication Equipment) devices attached to Modbus port #1 or port#2 of the PLC. The XXMIT block does

NOT activate the port LED when it is transmitting data.

Note: EN and ENO should NOT be used with the XXMIT, otherwise the output parameters may freeze.

Restrictions

The following restrictions apply to the XXMIT function block:

XXMIT does not support:: l l l

ASCII string conversion copy and compare functions

Port Status functions

Note: Momentum only supports one Stopbit.

Note: Port 2 only supported by Momentum PLCs

33002196

Software and

Hardware

Required

Memory

Requirements

XXMIT: Transmit (Compact, Momentum, Quantum)

Software

l l

The XXMIT function block requires the following software

A minimum of Concept 2.2 Service Release 2

IEC exec version

Hardware

l l l l

The following hardware is not supported by the XXMIT function block:

PLCs which do not support IEC languages

Soft PLC

All Atrium PLCs

IEC Simulator

The usage of one or more XXMIT EFBs in an IEC application consumes approximately 15.5 KByte program (code) memory.For each instance of this EFB included in the user program, additional data memory between 2.5 and 3 Kbyte is allocated.

Representation

Symbol

BOOL

WORD

ANY

INT

BYTE

INT

BYTE

INT

Representation of the Block

Start

Command

MsgOut

MsgLen

Port

Bauderate

Databits

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

XXMIT

Active

Done

Error

MsgIn

ReoCount

Status

Retry

BOOL

ANY

INT

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Parameter

Description

Description of the block parameter

Parameters Data type

Start BOOL

Command

MsgOut

WORD

ANY

MsgLen

Port

Baudrate

Databits

INT

BYTE

INT

BYTE

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

Active

BYTE

INT

BOOL

Done

Error

MsgIn

RecCount

Status

Retry

BOOL

ANY

INT

Significance

Value of 1 starts XXMIT operation

Specifies the command to be performed

Message to be sent

Message length of output message

Selection of communications interface

Baudrate

Databits

Stopbits

Parity

Time to wait for a valid response

Number of retries until receiving a valid response

Waiting time before message transmit.

Waiting time after message transmit

Value of 1 indicates that an XXMIT operation is in progress

Value of 1 indicates that the XXMIT operation has been completed successfully

Value of 1 indicates that an error has ocured or that the current XXMIT operation is terminated

Incoming message

Displaythe number of received characters

Display a fault code generated by the XXMIT block

Indicates the current number of retry attempts made by the XXMIT block

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Detailed Parameter Description

Start

Command

A rising edge at Start triggers the XXMIT operation. The value of 1 must be applied until the operation has finished or until an error has occurred.

The XXMIT interprets each bit of the command word as a function to perform. If bit

7 and 8 are on simultaneously or if any two or more of bits 13, 14, 15 or 16 are on simultaneously or if bit 7 is not on when bits 13, 14, 15, or 16 are on error 129 will be generated. For more details refer to

XXMIT Communication Functions, p. 58.

The individual bit definitions are shown in the table below.

Command Word Layout

Bit

1 msb

7 8 9 16 lsb

XXMIT Command Word Bit Definitions

Bit

Bit 1 (msb)

Bit 2 Enable RTS/

CTS modem control

Set to 1 when a DCE connected to the PLC requires hardware handshaking using RTS/CTS control. This bit may be used in conjunction with values contained in StartDly and EndDly. Start of transmission delay keeps RTS asserted for the time in StartDly (ms) before XXMIT sends a message out of PLC port. Likewise, end of transmission delay keeps RTS asserted for the time in EndDly (ms) after

XXMIT has finished sending a message out of the PLC port. Once the end of transmission delay expires XXMIT de-assert RTS.

Bit 3 Enable

RS485 mode

Definition

Reserved

Set to 1 when the selected port should operate in RS485 mode.

Otherwise it defaults to 0, which is RS232 mode. When using port 2 of a

Momentum PLC in RS485 mode with Modbus Messaging, make sure to use exactly the same parameters (baudrate, databits, stopbits, parity) for the XXMIT block as configured for that port.

Reserved Bit 4

Bit 5 Terminated

ASCII input

Set to 1 to remove and discard all characters from FIFO until the starting string is matched, then these starting characters and subsequent characters are written into MsgIn until the terminator sequence is matched. The terminator string is also written into the MsgIn. Refer to

Terminated ASCII Input Function, p. 59 for more details.

Bit 6 Simple

ASCII input

Set to 1 to remove the ASCII characters from FIFO for writing into MsgIn array. Refer to

Simple ASCII Input Function, p. 61 for more details.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Bit

Bit 7 Enable

ASCII string messaging

Bit 8 Enable

Modbus messaging

Bit 9 Enable

ASCII receive

FIFO

Bit 10 Enable back space

Bit 11 Enable

RTS/CTS flow control

Bit 12 Enable

Xon/Xoff flow control

Bit 13 Pulse dial modem

Bit 14 hangup modem

Definition

Set to 1 when you want to send ASCII messages out of the PLC. XXMIT sends ASCII strings up to 1024 characters in length. You program the

ASCII message into the MsgOut. Only use Bit 7 OR Bit 8, do not try to use both.

Set to 1 when you want to send Modbus messages out of the PLC.

Modbus messages may be in either RTU or ASCII formats. When data bits=8, XXMIT uses Modbus RTU format. When data bits=7, XXMIT uses Modbus ASCII format. Only use Bit 7 OR Bit 8, do not try to use both.

Set to 1 to allow the XXMIT block to take control over the selected port

(1 or 2) from the PLC. The block begins to receive ASCII characters into an empty 512 byte circular FIFO. Refer to

ASCII Receive FIFO, p. 73 for

more details.

Set to 1 to allow special handling of ASCII back space character (BS,

8Hex) when using either Simple ASCII Input (Bit 6) or Terminated ASCII

Input (Bit 5). If Bit 10 is set, each back space character will NOT be stored into MsgIn. Refer to

Enable Back space, p. 73

for more details.

Set to 1 to allow full duplex hardware flow control using the RTS and

CTS handshaking signals for ASCII massaging. The RTS/CTS operates in both the input and output modes. Refer to Enable RTS/CTS Flow

Control, p. 74

for more details.

Set to 1 to allow full duplex software flow control using the ASCII Xon character (DC1, 11 Hex) and the ASCII Xoff character (DC3, 13 Hex).

The Xon/Xoff operates in both the input and output modes. Refer to

Enable Xon/Xoff Flow Control, p. 75

for more details.

Set to 1 when using a Hayes compatible dial-up modem and you wish to pulse dial a telephone number. You program the phone number into the

MsgOut. The length of the message must be in MsgLen. Pulse dialed numbers are sent to the modem automatically preceded by ATDP and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be ON prior to sending the number to be dialed.

Set to 1 when using a Hayes compatible dial-up modem and you want to hangup the modem. You must use user logic to turn this bit ON.

Since the hangup message is an ASCII string, bit 7 must be ON prior to sending the message. Hang up messages are sent to the modem automatically preceded by +++AT and with carriage return <CR> and line feed <LF> appended. XXMIT looks for a correct disconnect response from the modem before it turns ON the Done output signal, noting a successful completion.

33002196

MsgOut

XXMIT: Transmit (Compact, Momentum, Quantum)

Bit

Bit 15 Tone dial modem

Bit 16 Initialize modem

Definition

Set to 1 when using a Hayes compatible dial-up modem and you wish to tone dial a telephone number. You program the phone number into the

MsgOut. The length of the message must be in MsgLen. Tone dial numbers are sent to the modem automatically preceded by ATDT and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be ON prior to sending the number to be dialed.

Set to 1 when using a Hayes compatible dial-up modem and you want to initialize the modem. You program the initialization message into

MsgOut and the length of the message into MsgLen. All messages are sent to the modem automatically preceded by AT and with a carriage return <CR> and line feed <LF> appended. Since the initialization message is an ASCII string, bit 7 must be ON prior to sending the message.

MsgOut contains the message data to be transferred, for example, ASCII characters for an ASCII transfer, definition of termination characters for terminated ASCII input or Modbus templates for Modbus master messages.

The data type that must be assigned to the parameter has to match the requirements of the function to be performed. The data type of the MsgOut parameter must be equal to the data type of the MsgIn field.

Note: MsgOut and MsgIn are of Data Type ANY. It is preferrable to use a Byte

Array. Different from the XMIT Block, ASCII messages are stored in byte order, allowing for easy handling, for example, through assigning a string as an initial value.

Note: For Modbus Messaging MsgOut must be a field of words. The minimum size of the array is WordArr9

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

MsgLen

You must enter the length of the current message according to the selected XXMIT function.

The following table gives an overview for Modbus and ASCII functions:

XXMIT function

Modbus Messaging

Subfunction

01, 02, 03, 04, 05, 06, 08,

15, 16

20, 21

Message Length

Modbus Messaging

Terminated ASCII Input

Simple ASCII Input

ASCII String Messaging

1...1024.

1...1024. The selected length must match the size of the array assigned to MsgOut. Otherwise you get error 129.

Port

Baudrate

Databits

Stopbits

Parity

Port specifies the communications interface. The only authorized values are the values 1 and 2. Port 2 is only available on the Momentum PLC.

XXMIT supports the following data rates: 50, 75, 110, 134, 150, 300, 600, 1200,

1800, 2000, 2400, 3600, 4800, 7200, 9600, 19200. To configure a data rate, enter its decimal number. When an invalid data rate is entered, the block displays an illegal configuration error (error code 127) in the XXMIT Status element.

XXMIT supports the following data bits: 7 and 8. To configure a data bit size, enter its decimal number into this element. Modbus messages may be sent in ASCII mode or RTU mode. ASCII mode requires 7 data bits, while RTU mode requires 8 data bits. When sending ASCII character message you may use either 7 or 8 data bits. When an invalid data bit is entered, the block displays an illegal configuration error (error code 127) in the XXMIT Status element. For more details on Modbus message formats refer to Modicon Modbus Protocol Reference Guide (PI MBUS

300).

XXMIT supports one or two stop bits. Enter a decimal of either: 1 = one stop bit, or

2 = two stop bits. When an invalid stop bit is entered, the block displays an illegal configuration error (error code 127) in the XXMIT Status element.

XXMIT supports the following parity: none, odd and even. Enter a decimal of either:

0 = no parity, 1 = odd parity, or 2 = even parity. When an invalid parity is entered, the block displays an illegal configuration error (error code 127) in the XXMIT Status element.

33002196

RespTout

RetryLmt

StartDly

EndDly

Retry

Active

Done

XXMIT: Transmit (Compact, Momentum, Quantum)

You enter the time value in milliseconds (ms) to determine how long XXMIT waits for a valid response message from a slave device (PLC, modem, etc.). In addition, the time applies to ASCII transmissions and flow control operations. When the response message is not completely formed within this specified time, XXMIT issues a fault. The valid range is 0 ... 32767 ms. The timeout is initiated after the last character in the message is sent.

You enter the quantity of retries to determine how many times XXMIT sends a message to get a valid response from a slave device (PLC, modem, etc.). When the response message is not completely formed within this specified time, XXMIT issues a fault and a fault code. The valid range is 0 ... 32767 # of retries. This field is used in conjunction with RespTout.

You enter the time value in milliseconds (ms) when RTS/CTS control is enabled, to determine how long XXMIT waits after CTS is received before it transmits a message out of the PLC port. Also, you may use this register even when RTS/CTS is NOT in control. In this situation, the entered time value determines how long

XXMIT waits before it sends a message out of the PLC port. You may use this as a pre message delay timer. The valid range is 0 ... 32767 ms.

You enter the time value in milliseconds (ms) when RTS/CTS control is enabled, to determine how long XXMIT keeps RTS asserted once the message is sent out of the PLC port. After the time expires, XXMIT deassert RTS. Also, you may use this register even when RTS/CTS is NOT in control. In this situation, the entered time value determines how long XXMIT waits after it sends a message out of the PLC port. You may use this as a post message delay timer. The valid range is

0 ... 32767 ms.

Note: On RS 485 communication the transmit signal is held to ’1’ during the EndDly time. On 2-wire connections any characters coming from the communication partner will be lost.Therefore set EndDly to 0 ms if this function is not needed.

The value displayed here indicates the current number of retry attempts made by the

XXMIT block. This element is read only.

A value of 1 indicates that an XXMIT operation is in progress.

A value of 1 indicates that the XXMIT operation has been completed successfully.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Error

MsgIn

RecCount

Status

A value of 1 indicates that an error has occurred or that the current XXMIT operation is terminated.

MsgIn contains the incoming message data, for terminated ASCII input or simple

ASCII input.

The data type that must be assigned to the parameter has to match the requirements of the function to be performed. The data type must be equal to the type of the MsgOut field.

This element displays the number of received characters.

This element displays a fault code generated by the XXMIT block.

A complete list is shown in the table below.

Fault Status

108

109

110

111

9 ... 99

100

101

102

103

104

105, 106

107

Fault Code Fault Description

1 Modbus exception - Illegal function

Modbus exception - Illegal data address

Modbus exception - Illegal data value

Modbus exception - Slave device failure

Modbus exception - Acknowledge

Modbus exception - Slave device busy

Modbus exception -Negative acknowledge

Modbus exception -Memory parity error

Reserved

Slave PLC data area cannot equal zero

Master PLC data area cannot equal zero

Coil (0x) not configured

Master PLC 4x Holding Register area not configured

Data length cannot equal zero

Reserved

Undefined error

Modem returned ERROR

Modem returned NO CARRIER

Modem returned NO DIALTONE

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

130

131

132

133

126

127

128

129

134

135...149

150

122

123

124

125

118

119

120

121

Fault Code

112

113

114

115

116

117

151

152

153

Fault Description

Modem returned BUSY

Invalid LRC checksum from the slave PLC (see Note below)

Invalid CRC checksum from the slave PLC (see Note below)

Invalid Modbus function code

Modbus response message time-out (see Note below)

Modem reply time-out

XXMIT could not gain access to PLC communications port #1 or port #2

XXMIT could not enable PLC port receiver

XXMIT could not set PLC UART

Reserved

Invalid Port

Reserved

Undefined internal state

Broadcast mode not allowed with this Modbus function code

DCE did not assert CTS

Illegal configuration (data rate, data bits, parity, or stop bits)

Unexpected response received from Modbus slave (see Note below)

Illegal command word setting

Command word changed while active

Invalid character count

Reserved

ASCII input FIFO overflow error

Invalid number of start characters or termination characters

Reserved

Either configured port already taken by another instance of the XXMIT or the configured port is not supported on that PLC

MsgOut is smaller than 12 Byte while 'Modbus Master Messaging' function is selected

Variable connected to MsgOut is smaller than the value of the MsgLen parameter while 'ASCII String Messaging' is selected

Variable connected to MsgIn is smaller than the value of the MsgLen parameter while either 'Terminated ASCII Input' or 'SimpleASCII Input' is selected

XXMIT: Transmit (Compact, Momentum, Quantum)

Note: This fault code does happen if the Modbus slave responds too fast.

In case the used Modbus slave is a Modicon PLC , please check the Modbus Port

Setup

of that PLC’s configuration.

XXMIT Communication Functions

XXMIT Command

Word

The XXMIT communication block performs six functions shown below. For each function certain bits of the Command word must be set.

Command Word

Bits

Command Word Functions in Relation to Bits

Function Command word bits that may be set to 1

2,3,9,10,11,12

Bits that MUST be set to = 0

6,7,8,13,14,15,16 Terminated ASCII input

(Bit 5=1)

Simple ASCII input

(Bit 6=1) *

Simple ASCII output

(Bit 7=1)

Modem output (Bit 7=1)

2,3,9,10,11,12

2,3,13,14,15,16

5,7,8,13,14,15,16

5,6,8,13,14,15,16

Modbus master messaging output (Bit 8=1)

2,3

5,6,8,9,10,11,12 (plus one, but

ONLY one, of the following bits is set to 1: 13,14,15 or 16, while the other three bits must be set to 0)

5,6,7,9,10,11,12,13,14,15,16

Note:

When using either of these functions you MUST set Enable ASCII receive

FIFO ( Bit 9) to 1. Bit 1 (MSB) and Bit 4 are reserved. (See Table

Command, p. 51)

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

XXMIT ASCII Functions

At a Glance

Terminated

ASCII Input

Function

The XXMIT function block supports the following ASCII communication functions l l l

Terminated ASCII Input

Simple ASCII Input

ASCII String Messaging

When Bit 5 of the Command Word is activated for terminated ASCII Input messages, the MsgOut array has to contain the ASCII input definition table.

Depending of which datatype you selected for MsgOut, the terminated ASCII definition table consists of three words or 6 byte. The terminated ASCII input definition table is shown in the table below.

Terminated ASCII Input Definition Table (Datatype WordArray)

Word

MsgOut[1]

MsgOut[2]

MsgOut[3]

High Byte Low Byte

Number of starting characters (allowed content = 0, 1, 2)

First starting character

Number of terminator characters

(allowed content = 1, 2)

Second starting character

First terminator character Second terminator character

Terminated ASCII Input Definition Table (Datatype ByteArray)

Byte

MsgOut[1]

MsgOut[2]

MsgOut[3]

MsgOut[4]

MsgOut[5]

MsgOut[6]

Function

length of termination string (1 or 2) length of start string (0 or 1 or 2)

2nd start character

1st start character

2nd termination character

1st termination character

During the process, RecCount holds a running count of characters written into the

MsgIn array. Once the terminated string is received the Done output on the XXMIT block goes ON and RecCount holds the total length of the received string including the starting and terminator strings. At this point the XXMIT block still owns the port and continues to save newly received characters into the ASCII receive FIFO, because the enable ASCII receive FIFO Command Word, Bit 9 is ON.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Terminated

ASCII Example

Using program logic, you can clear the simple ASCII input Bit before the next scan, while leaving the enable ASCII receive FIFO Bit ON. Thus, MsgIn is NOT over written by newer FIFO data, which is still collected in the FIFO. Using program logic, you can clear both bits for enable ASCII receive FIFO ( Bit 9), and terminated ASCII input (Bit 5) to return port control back to the PLC.

When too many characters are written into the MsgIn array with NO terminator detected, or the MsgIn array is outside the allowed range for the configured PLC an error is reported in Status. The character limit is the smaller of 1024 or two times the sizes of the MsgIn array.

Assume that XXMIT is activated with the command word Bit 9 and 5 set. Enable

ASCII FIFO and terminated ASCII. The following ASCII string is received by the port: "AMScrlf$weight = 1245 GRAMScrlf$wei". Refer to the ASCII Input Definition

Table that shows the contents denoted by ( ) used in this example.

Terminated ASCII Input Definition Table (content Datatype Byte Array)

Byte

MsgOut[1]

MsgOut[2]

MsgOut[3]

MsgOut[4]

MsgOut[5]

MsgOut[6]

Content

Number of starting characters (0x01)

Number of terminator characters (0x02)

Second starting character (Not Used)

First starting character ('$')

Second terminator character ('lf'')

First terminator character ('cr')

33002196

Simple ASCII

Input Function

XXMIT: Transmit (Compact, Momentum, Quantum)

Terminated ASCII Input Definition Table Example (content for Datatype Word Array)

Word

MsgOut[1]

MsgOut[2]

MsgOut[3]

High Byte

Number of starting characters (0x01)

First starting character ('$')

First terminator character ('cr')

Low Byte

Number of terminator characters

(0x02)

Second starting character

(Not Used)

Second terminator character ('lf'')

The XXMIT block becomes ACTIVE and then discards from the input FIFO the initial five characters, "AMScrlf", because they do not match the first starting character set to '$'. On the logic scan after the '$' is received, the XXMIT block remains ACTIVE and it copies the '$' and subsequent characters into the MsgIn array, updating

RecCount with the count done so far, as the characters come in. After the final termination character is received the output Done is activated and MsgLen contains the total length equal to 22 characters (0x0016). The MsgIn array contains: "$weight

= 1245 GRAMScrlf" as Byte Array (or: "$w", "ei", "gh", "t ", "= ", "12", "45", " G", "RA",

"MS", "crlf" if using a Word Array). On the scan that the output Done is activated, the already received characters from the next message, "$wei", that came in after the termination string, remains in the ASCII input FIFO. This gives the program logic the opportunity to turn off the Terminated ASCII input before the next scan solve of

XXMIT for this port, keeping those characters in the FIFO until the PLC completes processing the current message, that might take several scans.

All incoming characters are placed into the MsgIn array. If MsgIn is defined as Byte

Array (as recommended), the incomming characters are simply stored first character into first array element, second character into second and so on.If MsgIn is defined as WordArray, two characters are stored in each element. The first character is stored in the high byte of the first element. The second character is stored in the low byte of the first element. The third character is stored in the high byte of the second element, and so on. The Message Length variable (MsgLen) contains the length of the message (1 ... 1024 characters).

Note: When Simple ASCII Input (Bit 6) and ASCII Receive FIFO (Bit 9) remain set, new characters are continuously transferred from FIFO into the same MsgIn array thus constantly over writing the previous characters stored into the MsgIn array.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

ASCII String

Messaging

Transmit -

Receive

Transition

When Command Word, Bit 7 is activated for String Messaging, the MsgOut array has to contain the ASCII information to be transmitted. The message length MsgLen has to be set to the length of the message to be transmitted.

As mentioned in

Detailed Parameter Description, p. 51, MsgOut may be of any

datatype. For ASCII String Messaging the type ByteArray reflects best the nature of strings: First Byte contains first character and so on. (See

Simple ASCII Send, p. 81)

If your application requires to receive an answer from another device after transmitting a message (request - response), you need the XXMIT function block to switch from transmit mode to receive mode in order to read the communication partner’s response. The earliest point in time to switch the XXMIT function block from transmit to receive is the cycle following the transmit operation. It is the responsibility of the user to ensure that the response is delayed by at least one cycle time of the requesting PLC to avoid communication failure.

The transmit delay on the communication partner’s side is especially important in cases of long cycle times on the requester’s side and fast communication partners.

Timing considerations for the Partner Delay-time:

Requester Scan-time

Transmit Receive

Transmission-time min Partner Delay-time

Partner Scan-time

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

From the above figure (not to scale) you can estimate the influence of the three different times Requester Scan-time, Transmission-time and Partner Scan-time on the required Partner Delay-time. As the requester’s and partner’s scans are asynchronous, the Partner Scan-time should not be taken into account. The transmission-time depends on telegram length and baud rate. A message with 18 characters at 9600 baud takes 14 ms. The main contribution obviously comes from the Requester Scan-time. So even the minimum Partner Delay-time could be less than the Requester Scan-time, we recommend to use the Requester Scan-time as the minimum Partner Delay-time to ensure a sound communication..

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

XXMIT Modem Functions

At a glance

The XXMIT function block allows you to communicate to a Hayes compatible modem using the functions listed in the following table:

Modem Functions

Bit in Command Word

Bit 13

Bit 14

Bit 15

Bit 16

Function

Pulse dial modem

Hangup modem

Tone dial modem

Initialize modem

Initialize Modem

Set Bit 16 of the command word to 1 when using a Hayes compatible dial-up modem and you want to initialize the modem. You program the initialization message into the MsgOut array and the length of the message into MsgLen. All messages are sent to the modem automatically preceded by AT and with a carriage return <CR> and line feed <LF> appended. Since the initialization message is an ASCII string, bit 7 must be ON prior to sending the message

Pulse Dial

Modem

Set Bit 13 of the command word to 1 when using a Hayes compatible dial-up modem and you wish to pulse dial a telephone number. You program the phone number into the MsgOut array. The length of the message must be in MsgLen. Pulse dialed numbers are sent to the modem automatically preceded by ATDP and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be ON prior to sending the number to be dialed.

Tone Dial Modem

Set Bit 15 of the command word to 1 when using a Hayes compatible dial-up modem and you wish to tone dial a telephone number. You program the phone number into the MsgOut array. The length of the message must be in MsgLen. Tone dialed numbers are sent to the modem automatically preceded by ATDT and with carriage return <CR> and line feed <LF> appended. Since the dial message is an ASCII string, bit 7 must be ON prior to sending the number to be dialed.

33002196

Hangup Modem

XXMIT: Transmit (Compact, Momentum, Quantum)

Set Bit 14 of the command word to 1 when using a Hayes compatible dial-up modem if you want to hangup the modem. You must use program logic to turn this bit ON.

Since the hangup message is an ASCII string, bit 7 must be ON prior to sending the message. Hang up messages are sent to the modem automatically preceded by

+++AT and with carriage return <CR> and line feed <LF> appended. XXMIT looks for a correct disconnect response from the modem before it turns ON the Done output signal, noting a successful completion.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

XXMIT Modbus Functions

At a Glance

The XXMIT function block supports the following Modbus function codes:.

l l l

01 ... 06 and 15 ... 16

20 and 21

Note: When using port 2 of a Momentum PLC in RS485 mode with Modbus

Messaging, make sure to use exactly the same parameters (baudrate, databits, stopbits, paritty) for the XXMIT block as configured for that port.

33002196

Transmit -

Receive

Transition

XXMIT: Transmit (Compact, Momentum, Quantum)

Except broadcast messages all Modbus functions require the XXMIT function block to switch from transmit mode to receive mode in order to read the slave’s response.

The XXMIT function block switches from transmit to receive in the cycle following the transmit operation. It is the responsibility of the user to ensure that the slave’s response is delayed by at least one cycle time of the master to avoid communication failure.

The transmit delay on the slave side is especially important in cases of long master cycle times and fast slaves.

Timing considerations for the Slave Delay-time:

Master Scan-time

Transmit Receive

Transmission-time min Slave Delay-time

33002196

Slave Scan-time

From the above figure (not to scale) you can estimate the influence of the three different times Master Scan-time, Transmission-time and Slave Scan-time on the required Slave Delay-time. As the master and slave scans are asynchronous, the

Slave Scan-time should not be taken into account. The transmission-time depends on telegram type, baud rate and protocol. A standard Read request at 9600 baud using ASCII protocol for example takes 14 ms. The main contribution obviously comes from the Master Scan-time. So even the minimum Slave Delay-time could be less than the Master Scan-time, we recommend to use the Master Scan-time as the minimum Slave Delay-time to ensure a sound communication.

XXMIT: Transmit (Compact, Momentum, Quantum)

Note: For Quantum, Compact and Momentum PLCs you can specify the delay time in the Modbus Port Settings dialog. The delay time can be specified between

10 and 1000 ms, which will automatically be rounded up to be divisible by 10.

You must enter the required delay-time plus 10 ms. For example to have a 110 ms delay you must enter 120 in this field.

Modbus

Function Codes

(01 ... 06,

15 and 16)

For Modbus messages, the MsgOut array has to contain the Modbus definition table. This has to be defined as a field of words. The Modbus definition table for

Modbus function code: 01, 02, 03, 04, 05, 06, 15 and 16 is five registers long and you must set MsgLen to 5 for successful XXMIT operation. The Modbus definition table is shown in the table below.

Modbus Definition Table Function Codes (01 ... 06, 15 and 16)

Content

Modbus function code

(MsgOut[1])

Quantity

(MsgOut[2])

Description

XXMIT supports the following function codes:

01 = Read multiple coils (0x)

02 = Read multiple discrete inputs (1x)

03 = Read multiple holding registers (4x)

04= Read multiple input registers (3x)

05 = Write single coil (0x)

06 = Write single holding registers (4x)

15 = Write multiple coils (0x)

16 = Write multiple holding registers (4x)

Appendix A for complete details on limits.

Slave PLC address

(MsgOut[3])

Broadcast Mode only supports Modbus function codes that writes data from the master PLC to slave PLCs. Broadcast Mode does NOT support

Modbus function codes that read data from slave PLCs.

Slave PLC data area

(MsgOut[4])

For a read command, the slave PLC data area is the source of the data.

Destination Data Areas table below.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Content

Master PLC data area

(MsgOut[5])

Description

(00016 ... 00032) located in the master PLC to a slave PLC, enter 16 in the field. When you want to read input registers (30001 ... 30100) from a slave

Source and Destination Data Areas table below.

Source and Destination Data Areas for Function Codes (01 ... 06, 15 and 16)

Function Code

03 (Read multiple 4x)

04 (Read multiple 3x)

01 (Read multiple 0x)

02 (Read multiple 1x)

16 (Write multiple 4x)

15 (Write multiple 0x)

05 (Write single 0x)

06 (Write single 4x)

Master PLC Data Area

4x (destination)

0x (destination)

4x (source)

0x (source)

4x (source)

Slave PLC Data Area

4x (source)

3x (source)

0x (source)

1x (source)

4x (destination)

0x (destination)

4x (destination)

When you want to send 20 Modbus messages out of the PLC, you must transfer 20

Modbus definition tables one after another into MsgOut after each successful operation of XXMIT, or you may program 20 separate XXMIT blocks and then activate them one at a time through user logic.

XXMIT: Transmit (Compact, Momentum, Quantum)

Modbus

Function Code

(08)

For Modbus messages, the MsgOut array has to contain the Modbus definition table. This has to be defined as a field of words. The Modbus definition table for

Modbus function code: 08 is five registers long and you must set MsgLen to 5 for successful XXMIT operation. The Modbus definition table is shown in the table below.

Modbus Definition Table Function Codes (08)

Content

Modbus function code

(MsgOut[1])

Diagnostics (MsgOut[2])

Slave PLC address

(MsgOut[3])

Diagnostics function data field content (MsgOut[4])

Description

XXMIT supports the following function code:

08 = Diagnostics

Enter the diagnostics subfunction code decimal value in this field to perform the specific diagnostics function desired. The following diagnostic subfunctions are supported:

Code

05 ... 09

14 ... 15

19 ... 21

Description

Return query data

Restart comm option

Return diagnostic register

Change ASCII input delimiter

Force listen only mode

Reserved

Clear counters

(& diagnostics registers in 384, 484)

Return bus messages count

Return bus comm error count

Return bus exception error count

Not supported

Return slave NAK count

Return slave busy count

Return bus Char overrun count

Not supported

Enter the slave Modbus PLC address. Typically the Modbus address range is 1 ... 247. Function code 8 does NOT support

Broadcast Mode (Address 0)

You must enter the decimal value needed for the data area of the specific diagnostic subfunction. For subfunctions 02, 04,

10, 11, 12, 13, 16, 17 and 18 this value is automatically set to zero. For subfunctions 00, 01, and 03 you must enter the desired data field value. For more details, refer to Modicon

Modbus Protocol Reference Guide (PI-MBUS-300) .

33002196

Content

Master PLC data area

(MsgOut[5])

XXMIT: Transmit (Compact, Momentum, Quantum)

Description

100 in this field. Subfunction 04 does NOT return a response.

For more details, refer to Modicon Modbus Protocol

Reference Guide (PI-MBUS-300) .

Modbus

Function Codes

(20, 21)

For Modbus messages, the MsgOut array has to contain the Modbus definition table. This has to be defined as a field of words. The Modbus definition table for

Modbus function codes: 20 and 21 is six registers long and you must set MsgLen to

6 for successful XXMIT operation. The Modbus definition table is shown in the table below.

Modbus Definition Table Function Codes (20, 21)

Content

Modbus function code

(MsgOut[1])

Quantity (MsgOut[2])

Slave PLC address

(MsgOut[3])

Slave PLC data area

(MsgOut[4])

Description

XXMIT supports the following function codes:

20 = Read general reference (6x)

21 = Write general reference (6x)

Enter the slave Modbus PLC address. Typically the Modbus address range is 1 ... 247. Function code 20 and 21 do NOT support Broadcast Mode (Address 0).

Depending on the type of Modbus command (write or read), the source and destination data areas must be as defined in the

Source and Destination Data Areas table below. The lowest extended register is addressed as register "zero" (600000). The lowest holding register is addressed as register "one" (400001).

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Content

Master PLC data area

(MsgOut[5])

Description

When you want to read 6x registers (600001 ... 600100) from a slave PLC and place the data into the master PLC data area

(40100 ... 40199), enter 100 in this field. Depending on the type of Modbus command (write or read), the source and destination data areas must be as defined in the Source and Destination

Data Areas table below. The lowest extended register is addressed as register "zero" (600000). The lowest holding register is addressed as register "one" (400001).

File number (MsgOut[6]) Enter the file number for the 6x registers to be written to or read from. (1 ... 10) depending on the size of the extended register data area. 600001 is 60001 file 1 and 69 0001 is 60001 file 10 as viewed by the Reference Data Editor.

Source and Destination Data Areas for Function Codes (20, 21)

Function Code Master PLC Data Area

20 (Read general reference 6x) 4x (destination)

21 (Write general reference 6x) 4x (source)

Slave PLC Data Area

6x (source)

6x (destination)

When you want to send 20 Modbus messages out of the PLC, you must transfer 20

Modbus definition tables one after another into MsgOut after each successful operation of XXMIT, or you may program 20 separate XXMIT blocks and then activate them one at a time through user logic.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

FIFO and Flow Control

At a glance

ASCII Receive

FIFO

Enable Back

Space

The XXMIT function block allows the the user to define the use of a receive FIFO buffer, flow control and the function of received back spaces.

Setting Bit 9 of the command word to 0 ends this function. When the FIFO receives

512 characters an internal overflow is set. When this occurs all subsequent characters are discarded, all ASCII input operations (simple and terminated) are ended, and the block returns an error until you toggle (Bit 9). When (Bit 9) is toggled, all data in the FIFO is discarded, both ASCII input control bits are ignored (Simple

ASCII (Bit 6), Terminated ASCII (Bit 5)), and when no ASCII output controls are selected then the control of the serial port (1 or 2) is returned back to the PLC.

You need to set either Terminated ASCII (Bit 5) or Simple ASCII (Bit 6) to remove the ASCII characters from FIFO for processing. No more than one of the following three bits can be set simultaneously: Terminated ASCII (Bit 5), Simple ASCII (Bit 6), or ASCII Output (Bit 7).

Full duplex operation may be achieved by setting both ASCII Receive FIFO (BIT 9), and ASCII Output (Bit 7). This allows simple ASCII transmission out of the PLC while still receiving ASCII characters into FIFO. This is useful when working with dumb terminals. When ASCII Receive FIFO (Bit 9) is set none of the following ASCII output controls are allowed: Modbus Master Messaging (Bit 8), Pulse Dial Modem

(Bit 13), Hangup Modem (Bit 14), Tone Dial Modem (Bit 15) and Initialize Modem

(Bit 16).

When a backspace (BS) is detected it is NOT stored into the MsgIn array, in fact it deletes the previous character and thus decreases the RecCount Character

Counter. In contrast, when a regular ASCII character is detected it is stored in the

MsgIn array and the RecCount Character Counter is increased.

Note: Back spaces CANNOT delete characters from an empty MsgIn array, thus the RecCount Character Counter never goes below 0.

This special back space functionality along with internal echo enabled at the terminal are very useful for dealing with dumb terminals. A single Terminated ASCII Input

XXMIT block searching for "cr" is activated with ASCII Receive FIFO (Bit 9) and back space (Bit 10) set. No additional program logic is required while you type and edit characters using the back space on the fly. When you type "cr" XXMIT activates the

Done output, and the corrected data is all lined up properly in the MsgIn array.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Enable RTS/CTS

Flow Control

The following pertains to the output mode. The XXMIT state goes to BLOCKED receiving when the receiving device indicates it cannot process additional characters by setting CTS to OFF. Likewise, The XXMIT state goes to UNBLOCKED when CTS is ON and the receiving devices indicates it CAN process additional characters.

When transmission is UNBLOCKED and Simple ASCII Output (Bit 7) and RTS/CTS

Flow Control (Bit 11) are set then the transmit output data is sent out in 16 byte packets. After all output packets are sent then the Done output on the XXMIT block goes ON to indicate "Operation Successful".

If during a transmission it suddenly becomes BLOCKED, only the remaining characters in the current output packet are sent, never exceeding 16 characters, and the XXMIT block remains ACTIVE indefinitely. Only when the CTS in ON will the

ASCII output resume sending all remaining output packets.

The following pertains to the input mode. Since RTS is an output signal, it can be used independently of the ASCII output transmit process, to BLOCK or UNBLOCK sending devices. When ASCII Receive FIFO (Bit 9) is set the RTS/CTS Flow

Control works in the input mode. When ASCII Receive FIFO (Bit 9) is set and neither of the two ASCII inputs are set, Simple ASCII Input (Bit 6) or Terminated ASCII Input

(Bit 5), the received characters will fill the FIFO in which they are inserted. In the mean time, the RTS Flow Control (Bit 11) is ON allowing the sending device to proceed.

When the FIFO (512 characters) is more than three quarters full with characters the

RTS Control Flow (Bit 11) is cleared to BLOCK the sending device. The RTS

Control Flow (Bit 11) remains cleared until either Simple ASCII Input (Bit 6) or

Terminated ASCII Input (Bit 5) have removed enough characters from the FIFO whereby reducing it to less than one quarter full of characters at which point the RTS

Control Flow (Bit 11) is turned ON.

Note: The RTS/CTS Flow Control algorithm is different from RTS/CTS Modem

Control. The former is related to full duplex receive buffer overflow. The latter deals with the transmit process gaining access to a shared transmission medium.

Therefore, it is illegal to simultaneously request both of these RTS/CTS algorithms.

Note: You CANNOT select any type of RTS/CTS Flow Control (Bit 11) handshaking when the port is in RS 485 Mode (Bit 3) because these signals do

NOT exist in RS 485 mode.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Enable Xon/Xoff

Flow Control

The following pertains to the output mode. The XXMIT state goes to BLOCKED when an Xoff character is received. Likewise the XXMIT state goes to

UNBLOCKED when an Xon character is received. In neither case will Xon or Xoff be inserted into the FIFO.

When transmission is UNBLOCKED and Simple ASCII Output (Bit 7) and Xon/Xoff

Flow Control (Bit 12) are set then the transmit output data is sent out in 16 byte packets. After all output packets are sent the Done output on the XXMIT block goes

ON.

The following pertains to the input mode. Xon/Xoff may be used to BLOCK or

UNBLOCK sending devices. When ASCII Receive FIFO (Bit 9) is set the Xon/Xoff

Control Flow (Bit 12) works in the input mode. When ASCII Receive FIFO (Bit 9) is set and neither of the two ASCII inputs are set, Simple ASCII Input (Bit 6) or

Terminated ASCII Input (Bit 5), the received characters will fill the FIFO in which they are inserted.

When the FIFO is more than three quarter full with characters and additional characters are received the FIFO state variable is set to send XOFF characters out the serial port after a delay of up to 16 character times BLOCKING the sender and clearing the FIFO state variable.

When all ASCII output functions (Bits 8,13,14,15, and 16) are OFF and the Xon/Xoff

Flow Control (Bit 12) is ON the delay time defaults to 1 character time. In contrast, when all ASCII output functions (Bits 8,13,14,15, and 16) are ON and the Xon/Xoff

Flow Control (Bit 12) is ON then the ASCII output is broken up into 16 byte packets.

Thus, pending Xoff characters DO NOT have to wait more than 16 character times before BLOCKING the sender.

Once the sender has stopped transmission, the PLC eventually removes the characters from the FIFO using either Simple ASCII Input (Bit 6) or Terminated

ASCII Input (Bit 7).

When FIFO becomes less than one quarter full with characters the FIFO state variable is set to send XON, thus, sending an Xon character out the serial port to

UNBLOCK the sender.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Note: The Xon/Xoff Flow Control (Bit 12) is different from the RTS/CTS Control

Flow (Bit 11). The former uses transmitted Xon and Xoff characters to prevent receive buffer overflow in full duplex mode. The latter uses hardware hand-shaking signals to accomplish the same goal. Therefore, it is illegal to simultaneously request both of these flow control algorithms because RTS/CTS Flow Control

(Bit 11) Modem Control implies a half duplex network while Xon/Xoff Flow Control

(Bit 12) implies a full duplex network.

Run Time Errors

Error Messages

In case of error, the XXMIT function block will generate the following runtime error:

E_EFB_WORLD_INTERFACE

This will be displayed in the Online Event dialog.

Subject to the value of the first error message parameter, the error message may have various origins.

l l l

An invalid communications interface was selected.

An invalid value for the communications interface was selected at the Port input.

Authorized values are 1 and 2 for Momentum PLCs, all other platforms only 1.

Selected port is already taken by another instance of XXMIT.

Either an invalid value for Baudrate/Stopbits/Databits has been used or the variables connected to MsgIn or MsgOut do not provide enough memory for the configured XXMIT operation.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Application Example

Description

The following program is a short demo application with four instances of the XXMIT block showing the four main functions: l l l l

Modbus Master

Simple ASCII In

ASCII Message Out

Terminated ASCII In

Modbus Master

l l

The following Modbus Master operation is a read request to a slave device connected to port 1 of the master:

Read slave's 4:0001 to 4:00010 into local 4:00011 to 4:00020 l l l l

The Slave must be set up with the following port parameters:

9600 baud

8 data bits

1 stop bit even parity (2)

The Master uses settings from the XXMIT function block

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Variable declaration for

Modbus Master

The following table shows the variables used in the Modbus Master example:

Variable Name

StartModbusMstr

ModbusMstrActive

ModbusMstrCommand

ModbusMstrDone

ModbusMstrError

ModbusMstrNode

ModbusMstrSettings

ModbusMstrSettings[1]

ModbusMstrSettings[2]

ModbusMstrSettings[3]

ModbusMstrSettings[4]

ModbusMstrSettings[5]

ModbusMstrSettings[6]

...

ModbusMstrStatus

ModbusMstrNode

INT

WORD

ModbusMstrErrorCounter INT

ModbusMstrDoneCounter INT

Data Type Initial

Value

BOOL

Comment

16#0100 Bit 8 set WORD

BOOL

WORD

WordArr9

Modbus Code: Read multiple registers

Amount of Registers to read

Slave Modbus address

Source register

Destination Register not used

Enter Slave address

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

IEC Section for

Modbus Master

Program the following in an FBD section:

Slave node address assignment

MOVE

ModbusMstrNode ModbubsMstrSettings[3]

Assignments to the XXMIT function block:

StartModbusMstr

ModbusMstrCommand

ModbusMstrSettings

9600

100

Start

Command

MsgOut

MsgLen

Port

Bauderate

Databits

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

XXMIT

Active

Done

Error

MsgIn

RecCount

Status

Retry

ModbusMstrActive

ModbusMstrDone

ModbusMstrError

ModbusMstrStatus

ModbusMstrRetryCounter

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Count errors and successes

ModbusMstrError

CTU

PV ModbubsMstrErrorCounter

CTU

ModbusMstrDone

PV ModbubsMstrDoneCounter

Simple ASCII

Receive

Variable declaration for

Simple ASCII

Receive

Receives whatever comes into port 1. The receive buffer's length is assigned as

'SimpleReceiveLength', which has an initial value of 10.

Received characters are in MsgIn array, number of received characters in

RecCount.

The following table shows the variables used in the Simple ASCII Receive example:

Variable Name

StartSimpleReceive

SimpleReceiveActive

Data Type Initial

Value

BOOL

SimpleReceiveCharCounter INT

SimpleReceiveCommand WORD 16#0480

Comment

Bits 6 and 9 set. FIFO enabled

SimpleReceiveDone

SimpleReceiveError

BOOL

SimpleReceiveLength INT

SimpleReceiveRetryCounter INT

SimpleReceiveStatus

SimpleRecMessage

INT

ByteArr12

SimpleReceiveDoneCounter INT

SimpleReceiveErrorCounter INT

33002196

IEC Section for

Simple ASCII

Receive

XXMIT: Transmit (Compact, Momentum, Quantum)

Program the following in an FBD section:

StartSimpleReceive

SimpleReceiveCommand

SimpleReceiveLength

9600

100

Start

Command

MsgOut

MsgLen

Port

Bauderate

Databits

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

XXMIT

Active

Done

Error

MsgIn

RecCount

Status

Retry

SimpleReceiveActive

SimpleReceiveDone

SimpleReceiveError

SimpleRecMessage

SimpleReceiveCharCount

SimpleReceiverStatus

SimpleReceiveRetryCounter

Count errors and successes

SimpleReceiveError

CTU

PV SimpleReceiveErrorCounter

SimpleReceiveDone

CTU

PV SimpleReceiveDoneCounter

Simple ASCII

Send

Sends a simple ASCII message out off port 1, the message is 'Hello World!!'

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Variable declaration for

Simple ASCII

Send

The following table shows the variables used in the Simple ASCII Send example:

Variable Name

StartSimpleSend

SimpleSendActive

SimpleSendCommand

SimpleSendDone

SimpleSendError

SimpleSendLength

SimpleSendMessage

SimpleSendMessage[1]

SimpleSendMessage[2]

SimpleSendMessage[3]

SimpleSendMessage[4]

SimpleSendMessage[5]

SimpleSendMessage[6]

SimpleSendMessage[7]

SimpleSendMessage[8]

SimpleSendMessage[9]

SimpleSendMessage[10]

SimpleSendMessage[11]

SimpleSendMessage[12]

SimpleSendMessage[13]

SimpleSendMessage[14]

SimpleSendRetryCounter

SimpleSendStatus

SimpleSendDoneCounter

SimpleSendErrorCounter

INT

Data Type Initial

Value

BOOL

Comment

16#0200 Bit 7 set WORD

BOOL

INT

ByteArr36

14 Number of characters to send

'Hello World !!'

16#48

16#65

16#6C

16#6F

16#20

16#57

16#6F

16#72

16#6C

16#64

16#20

16#21

33002196

IEC Section for

Simple ASCII

Send

XXMIT: Transmit (Compact, Momentum, Quantum)

Program the following in an FBD section:

StartSimpleSend

SimpleSendCommand

SimpleSendMessage

SimpleSendLength

9600

100

Start

Command

MsgOut

MsgLen

Port

Bauderate

Databits

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

XXMIT

Active

Done

Error

MsgIn

RecCount

Status

Retry

SimpleSendActive

SimpleSendDone

SimpleSendError

SimpleSendStatus

SimpleSendRetryCounter

Count errors and successes

CTU

SimpleSendError

PV SimpleSendErrorCounter

CTU

SimpleSendDone

PV SimpleSendDoneCounter

Terminated

ASCII Receive

After receiving the 'starting characters' "AB", the function block puts all received characters into the receive buffer MsgIn. The receiver will stop when the 'finishing characters' "CD" are received, whereby the "Done" output will be set, to indicate the successfull completion. The max. length of the receive buffer is assigned as

"TermReceiveLength", which is set to an initial value of 20 in this example.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Variable declaration for

Terminated

ASCII Receive

The following table shows the variables used in the Terminated ASCII Receive example:

Variable Name

StartTermReceive

TermReceiveActive

TermReceiveCharCounter

TermReceiveCommand

TermReceiveDone

TermReceiveError

TermReceiveLength

TermReceiveMessage

Data Type Initial

Value

BOOL

INT

WORD

BOOL

INT

ByteArr36

TermReceiveRetryCounter INT

TermReceiveSettings

TermReceiveSettings[1]

TermReceiveSettings[2]

TermReceiveSettings[3]

TermReceiveSettings[4]

TermReceiveSettings[5]

TermReceiveSettings[6]

ByteArr36

16#0880

16#02

16#41

16#42

16#43

16#44

Comment

Bits 5 and 9 set. FIFO enabled

Received characters length of termination string (1 or 2) length of start string (0, 1 or 2)

2nd start character

1st start character

2nd termination character

1st termination character

TermReceiveStatus INT

TermReceiveDoneCounter INT

TermReceiveErrorCounter INT

33002196

IEC Section for

Terminated

ASCII Receive

XXMIT: Transmit (Compact, Momentum, Quantum)

Program the following in an FBD section:

StartTermReceive

TermReceiveCommand

TermReceiveSettings

TermReceiveLength

9600

100

Start

Command

MsgOut

MsgLen

Port

Bauderate

Databits

Stopbits

Parity

RespTout

RetryLmt

StartDly

EndDly

XXMIT

Active

Done

Error

MsgIn

RecCount

Status

Retry

TermReceiveActive

TermReceiveDone

TermReceiveError

TermReceiveMessage

TermReceiveCharCounter

TermReceiveStatus

TermReceiveRetryCounter

Count errors and successes

CTU

TermReceiveError

PV TermReceiveErrorCounter

CTU

TermReceiveDone

PV TermReceiveDoneCounter

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Entering Strings as initial values

The Variable Editor of Concept allows you to easily enter Strings as initial values into byte arrays.

The following part gives a short describtion of how to define a variable 'DemoString' as 'ByteArr36' and enter a string 'My Text ! ' as initial value.

Open the Variable Editor

From the main menu select:

Project -> Variable Editor.

Variable Editor

Type

Variables Constants

Search/Paste

Search/Replace

Exp Variable Name

Demo String

Data Type

ByteArr36

Address InitValue Used

Set...

0 1

OK Cancel Help

Define new variable

Enter the new variables name in the 'Variable Name' field. As data type select

'ByteArrxx' (xx depends on the size of your message). In the 'InitValue' field a 'Set...' button appears.

Enter text as initial value

Click on the 'Set...' button and open the definition window. Double clicking into the value field brings up a cursor and allows you to enter your text.

33002196

XXMIT: Transmit (Compact, Momentum, Quantum)

Definition ByteArr

Definition ByteArr36

DemoString

Name

DemoString

Type

ByteArr36

Value

My Text!

33002196

OK Cancel Help

Look at Array Elements

Click on the '+' button in front of the variables name and open the view onto all array elements. The value column shows the ASCII code representation of the entered characters as hexadecimal numbers.

Elements of the Byte Array

Definition ByteArr36

DemoString

Name

DemoString

DemoString[1]

DemoString[2]

DemoString[3]

DemoString[4]

DemoString[5]

DemoString[6]

DemoString[7]

DemoString[8]

DemoString[9]

Type

ByteArr36

BYTE

Cancel

Value

16#4D

16#79

16#20

16#54

16#65

16#78

16#74

16#20

16#21

Help

XXMIT: Transmit (Compact, Momentum, Quantum)

33002196

RTXMIT: Full Duplex Transmit

(Compact, Momentum, Quantum)

At a Glance

Introduction

What's in this

Chapter?

This chapter describes the RTXMIT function block.

This chapter contains the following topics:

Topic

Brief Description

Representation

Parameter Description

Runtime Errors

Application Example

Page

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Brief Description

Function

Description

The function block provides full duplex communication through the local Modbus port. On Momentum PLCs the second local Modbus port is supported as well.

The function block combines two main functions into one, these are simple message reception and simple message transmission.

Note: EN and ENO should NOT be used with the RTXMIT, otherwise the output parameters may freeze.

Restrictions

Software and

Hardware

Required

Memory

Requirements

The RTXMIT does not support Modbus protocol or modem functions.

Software

The RTXMIT function block requires the following software l l

A minimum of Concept 2.5 Service Release 2

IEC exec (delivered with Concept V2.5 SR2 or later)

Hardware

l l l l

The following hardware is not supported by the RTXMIT function block:

PLCs which do not support IEC languages

Soft PLC

All Atrium PLCs

IEC Simulator

The usage of one or more RTXMIT EFBs in an IEC application consumes approximately 5KByte program (code) memory. For each instance of this EFB included in the user program, additional data memory of 200 byte is allocated.

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Representation

Symbol

BOOL

ANY

UINT

BOOL

UINT

BOOL

BYTE

UINT

BYTE

BOOL

UINT

BYTE

BOOL

Representation of the Block

RTXMIT

TxStart

TxBuff

TxLength

RxStart

RxReset

RxLength

RxBckSpc

Port

BaudRate

DataBits

StopBits

Parity

EvenPari

FlowCtrl

FlowSoft

FlowBlck

BegDelt

BegDel1

BegDel2

EndDelCt

EndDel1

EndDel2

Echo

ActiveTx

ErrorTx

DoneTx

ActiveRx

ErrorRx

DoneRx

CountRx

AllCtRx

BuffRx

StatusTx

StatusRx

BOOL

UINT

UDINT

ANY

WORD

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Parameter Description

Parameter

Description

Description of the block parameter

Parameters Data type

TxStart BOOL

TxBuff

TxLength

RxStart

RxReset

RxLength

ANY

UINT

BOOL

UINT

Significance

On a rising edge (FALSE->TRUE) the EFB begins with the send operation. This operation would work concurrently to an ongoing reception. If this parameter transitions from TRUE to

FALSE an ongoing transmission will be aborted without any error being generated. After a transmission process completed

(with or without success) a new process won't be triggered before the next rising edge happening to TxStart.

A variable of any datatype, it contains the 'to be sent' character stream in Intel format.

This parameter specifies the full amount of characters to be sent from TxBuff. Without the use of data flowcontrol (RTS/

CTS or XON/XOFF), the amount of characters to be sent from

TxBuff may not exceed 1024. With data flow control being activated TxLength may go as high as 2^16, as FlowBlck specifies the number of characters being transmitted with one message frame.

On a rising edge (FALSE->TRUE) the EFB begins with the receive operation. This operation would work concurrently to an ongoing transmission. In case this parameter carries the value TRUE after the reception process completed (DoneTx =

TRUE), following characters being received won't be stored in

RxBuff anymore. A new reception process won't be triggerd before the next rising edge happing to RxStart.

If TRUE, the following stream of characters being received will be stored at the begin of BuffRx. Also output parameter

CountRx will be set to zero. At the same time current values of input parameters RxLength, Strt_Cnt, Strt_Dl1, Strt_Dl2,

End_Cnt, End_Dl1, End_Dl2, RxBckSpc will be used from then on.

Max. number of characters to be received. In case this value exceeds the size of BuffRx no error will be generated, but the size of BuffRx will be used instead. After the given number of characters has been received the output parameter DoneRx transitions to TRUE, and the receive operation will end at that time.

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Parameters Data type

RxBckSpc BOOL

Port

Baudrate

DataBits

StopBits

Parity

EvenPari

FlowCtrl

FlowSoft

BYTE

UINT

BYTE

BOOL

Significance

While this parameter is being set to TRUE a received character of value 8 (backspace) will cause the one character being received before the backspace to be overwritten by the character being received after the backspace. Also, in this mode the output CountRx will decrease its value with each backspace being received, till it's 0. The EFB will consider the value of RxBckSpc only while RxStart transitions from FALSE to TRUE or while RxReset is TRUE (whereby RxStart needs to be TRUE at that time).

Local port number (1 or 2)

The 2nd port is supported on Momentum PLCs only.

Note: On Momentum PLCs the EFB will switch to RS485 if the assigned port has been configured as such, otherwise the port will be run in RS232 mode.

Bits per second for transmission and reception, allowed values are: 50, 75, 110, 134, 150, 300, 600, 1200, 1800, 2000, 2400,

3600, 4800, 7200, 9600, 19200

Databits per transmitted and received character (8 or 7)

Stopbits per transmitted and received character (1 or 2)

If TRUE, parity check will be enabled (odd or even depends on

EvenPari).

If FALSE no parity check will be used.

If TRUE and Parity = TRUE, even parity check will be used.

If FALSE and Parity = TRUE, odd parity check will be used.

If TRUE, the next triggered transmission will consider either

RTS/CTS or XON/XOFF (depends on FlowSoft)for data flow control. Receive operations won't use data flow control, since the PLC internal buffer is big enough (512 byte) to avoid losing any character between two PLC scans.

If TRUE, the data flow of transmissions will be controled by using the XON/XOFF handshaking method.

RTXMIT: Transmit (Compact, Momentum, Quantum)

Parameters Data type

FlowBlck UINT

BegDelCt

BegDel1

BegDel2

EndDelCt

EndDel1

EndDel2

Echo

ActiveTx

ErrorTx

DoneTx

ActiveRx

ErrorRx

BYTE

BOOL

Significance

Used only if FlowCtrl equals TRUE!

This parameter specifies the number of characters being sent as one frame as soon as the transmitter obtains permission to sent through the selected data flow control mechanism.

If FlowBlck is set to 0 the EFB will internally use 1 instead, as this is the minimum amount of characters to be sent in one frame.

If FlowBlck is set to a higher value than TxLength the EFB will internally use TxLength instead, as this is the maximum amount of characters to be sent in one frame. In order to increase data throughput (only one frame can be transmitted per PLC scan) the value assigned to FlowBlck needs to be increased.

Number of start delimiter. This parameter assigns how many characters are being used for the start delimiter. Allowed values are: 0, 1, 2. In case the value exceeds 2 the EFB won't generate an error, but would use the max. of 2 instead.

This is the first (of max. 2) character of the start delimiter.

This is the second (of max. 2) character of the start delimiter.

Number of end delimiter. This parameter assigns how many characters are being used for the end delimiter. Allowed values are: 0, 1, 2. In case the value exceeds 2 the EFB won't generate an error, but would use the max. of 2 instead.

This is the first (of max. 2) character of the end delimiter.

This is the second (of max. 2) character of the end delimiter.

If TRUE, all characters being received during transmission will be discarded. In RS485 2-wire mode this parameter would need to be set TRUE, otherwise each just-transmitted character would be received immediately afterwards.

If TRUE, a previously initiated send operation is still ongoing.

If TRUE, a previously initiated send operation failed, StatusTx.

In such case StatusTx will carry an error code that helps to identify the reason for a failure.

If TRUE, a previously initiated send operation finsihed with success.

If TRUE, a previously initiated receive operation is still ongoing.

If TRUE, a previously initiated receive operation failed.

In such case StatusRx will carry an error code that helps to identify the reason for a failure.

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Parameters Data type

DoneRx BOOL

CountRx

AllCtRx

BuffRx

StatusTx

StatusRx

UINT

UDINT

ANY

WORD

Significance

If TRUE, a previously initiated receive operation finsihed with success.

Number of characters being received since last initiated receive operation.

This output parameter will be set back to 0 after RxReset has been set to TRUE. Also this number does decrease upon reception of a backspace character in case RxBckSpc is set to

TRUE.

Number of ALL characters being received since the last rising edge happened at RxStart.

This output will also stay at its value after RxReset has been set to TRUE.

A variable of any datatype, it is used to store the received characters in Intel format.

Will be 0 if there's no error for the send operation, otherwise error code (see

Runtime Errors, p. 96 ).

Will be 0 if there's no error for the receive operation, otherwise error code (see

Runtime Errors, p. 96 ).

Port-Parameters

New port parameters being assigned to input parameters Port, Baudrate, DataBits,

StopBits, Parity and EvenPari will only be used after both parts of the EFB (receiver and transmitter) have been shutdown (TxStart = FALSE and RxStart = FALSE) and at least one of them has been (re-)started again.

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Runtime Errors

Error code (at

StatusTx and

StatusRx)

Error code (at StatusTx and StatusRx)

Error Code

8003 (hex)

8304 (hex)

8305 (hex)

8307 (hex)

8308 (hex)

Description

No error, either EFB is turned off completely (TxStart and RxStart are

FALSE) or the ongoing process works properly.

The assigned Modbus port does not exist (>1 on Quantum and Compact,

>2 on Momentum).

Another EFB is using the assigned Modbus port already.

The assigned Modbus port is used by a 984-Loadable (like XXMIT).

Illegal baudrate being assigned.

Illegal number of data bits being assigned.

Illegal number of stop bits being assigned.

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Application Example

Description

The following program is a short demo application which shows the implementation of a full duplex transmission with RTXMIT in the Structured Text language. The message to be transmitted has to be in TxBuff, the received message is in

BuffRx

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Full Duplex

Transfer

Declaration of function block:

VAR send_receive : RTXMIT;

END_VAR;

Call of function block: send_receive (TxStart := TX_start,

TxBuff := tx_buffer,

(* start of sending *)

(* send buffer *)

TxLength := TX_length, (* length of a complete send telegram *)

RxStart := Rx_start, (* start of receiving *)

RxReset := FALSE,

RxLength := 40,

(* reset mode not activated *)

(* max length of a received telegram, inclusing STX/CR *

RxBckSpc := FALSE,

Port

(* no backspaces allowed *)

:= port_number, (* caution: for Quantum PLC only port 1 may be used! *

Baudrate := BAUDRATE, (* baudrate is fixed *)

Databits := 8, (* data format is fixed *)

Stopbits

Parity

:= 1,

:= FALSE,

(* number of stop bits is fixed *)

(* no parity *)

FlowCtrl := TRUE,

FlowSoft := FALSE,

FlowBlck := 40,

(* activate flow control *)

(* flow control by RTS/CTS *)

(* when flow control is active up to 40 character

per cycle will be sent *)

BegDel1 := 0,

BegDel2 := 0,

EndDel1 := 0,

Echo := FALSE, (* only required in mode RS485-2 wire mode *)

BuffRx => rx_buffer); (* special operator for allocation of RX_BUFF *)

TX_active := send_receive.ActiveTx;

TX_error

TX_done

:= send_receive.ErrorTx;

:= send_receive.DoneTx;

RX_active := send_receive.ActiveRx;

RX_error := send_receive.ErrorRx;

RX_done := send_receive.DoneRx; rx_cnt_uint := send_receive.CountRx; rx_cnt_udint := send_receive.AllCtRx;

TX_status := send_receive.StatusTx;

RX_status := send_receive.StatusRx;

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

Conversion of number of received characters from UDINT to UINT format:

RX_count := UDINT_TO_UINT (IN := rx_cnt_udint);

33002196

RTXMIT: Transmit (Compact, Momentum, Quantum)

100

33002196

Technical References for XXMIT

Function Block

At a Glance

Overview

What's in this

Chapter?

This chapter describes the Technical References for the XXMIT function block.

This chapter contains the following topics:

Topic

Modbus Query/Response Parameter Limits

XXMIT Configuration using Hayes Compatible Dial-Up Modems (Only)

Page

102

106

33002196

101

Tech.Ref.XXMIT

Modbus Query/Response Parameter Limits

Parameter Limits

Based on PLC

Type

The query/response parameters are limited based upon the type of PLC you are using. Refer to the applicable table below.

Quantum PLC Maximum Parameters table:

Function

Code

Description Query

Read Coil Status

Read Input Status

2000 Coils

2000 Inputs

Read Holding Registers 125 Registers

Read Input Registers 125 Registers

Force Single Coil 1 Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

1 Register

800 Coils

100 Registers

Read General References Maximum length of the entire message can

NOT exceed 256 bytes

Write General References Maximum length of the entire message can

NOT exceed 256 bytes

Response

2000 Coils

2000 Inputs

125 Registers

1 Coil

1 Register

800 Coils

100 Registers

Maximum length of the entire message can NOT exceed 256 bytes

Note: The 140 CPU 113 02 and the 140 CPU 113 03 do not support General

References.

102

33002196

Tech.Ref.XXMIT

884 PLC Maximum Parameters table:

Description

Function

Code

Read Coil Status

Read Input Status

Read Holding Registers

Read Input Registers

Force Single Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

Read General References

Write General References

Response

2000 Coils

2000 Inputs

125 Registers

1 Coil

1 Register

800 Coils

100 Registers

NOT Supported

584/984 PLC Maximum Parameters table:

Function

Code

Description

Read Coil Status

Read Input Status

Read Holding Registers

Read Input Registers

Force Single Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

Read General Refer ences (6x)

21 Write General Refer ences (6x)

Response

2000 Coils

2000 Inputs

125 Registers

1 Coil

1 Register

800 Coils

100 Registers

Maximum length of the entire message can NOT exceed 256 bytes

103

Tech.Ref.XXMIT

484 PLC Maximum Parameters table:

Description

Function

Code

Read Coil Status

Read Input Status

Read Holding Registers

Read Input Registers

Force Single Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

Read General Refer ences

Write General Refer ences

Response

512 Coils

512 Inputs

254 Registers

32 Registers

1 Coil

1 Register

800 Coils

60 Registers

NOT Supported

184/384 PLC Maximum Parameters table:

Function

Code

Description

Read Coil Status

Read Input Status

Read Holding Registers

Read Input Registers

Force Single Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

Read General Refer ences

Write General Refer ences

Response

800 Coils

800 Inputs

100 Registers

1 Coil

1 Register

800 Coils

100 Registers

NOT Supported

104

33002196

M84 PLC Maximum Parameters table:

Description

Function

Code

Read Coil Status

Read Input Status

Read Holding Registers

Read Input Registers

Force Single Coil

Force Single Register

Force Multiple Coil

Force Multiple Register

Response

64 Coils

64 Inputs

32 Registers

4 Registers

1 Coil

1 Register

64 Coils

32 Registers

Tech.Ref.XXMIT

105

Tech.Ref.XXMIT

XXMIT Configuration using Hayes Compatible Dial-Up Modems (Only)

Description

There are three commands that you need to become familiar with when interfacing dial-up modems to XXMIT.

These commands are: l l l

Initialize modem

Dial modem

Hangup modem.

Before an ASCII message or a Modbus message goes through the modem, you must first send an initialization string and then a dial string to the modem. Once the modem has dialed the telephone number and made a connection to the remote modem, you may send an unlimited number of ASCII messages or Modbus messages through the modem. To send multiple messages, you increment the message pointer to the next message after each successful XXMIT operation. When all messages are sent, you may then send the hangup string to the modem.

106

33002196

Initialization

Message

Tech.Ref.XXMIT

The initialization message is just like any other ASCII message and may be a maximum of 512 characters long, although 50 characters is usually more than enough to initialize a modem. You may implement any Hayes AT command as part of the initialization string. We recommend the following commands when initializing a modem for use with XXMIT.

Initialization Message for Dial-Up Modem

Initialization Message = AT&F&K0&Q0&D0V1Q0X0E1

AT=

Self-calibrate Modem

&F=

Recall factory configuration as active configuration

&K0=

&Q0=

Disable local flow control

Communicate in asynchronous mode

&D0=

Ignore status of DTR signal

V1=

Q0=

X4=

Display result codes as words

If V1 is not used or if modem is not capable of returning verbose responses the XXMIT block returns error 117 (modem replay time out).

Return result codes

Provide basic call progress result codes: Connect, No Carrier, and Ring

E1= Echo characters from the keyboard to the screen in command state

These parameters must always be part of the initialization string for XXMIT to function properly.

These parameters should be part of the initialization string for XXMIT to transmit a message to remote modem properly. Only a experienced modem user should change or not use these parameters.

Note: While some modem manufacturers state full compatibility with Hayes, they may still be slightly different. Therefore, we recommend using only those commands that have the same definition as those stated above.

The initialization message must always start with Hayes standard AT command. The

XXMIT block automatically precedes modem command messages with AT and appends the message with carriage return (0x0D) and line feed (0x0A) characters since these are required by all modem control messages. Other (non controlling)

ASCII messages do not have to end with a carriage return and line feed.

33002196

107

Tech.Ref.XXMIT

For example, a typical initialization message that XXMIT sends to the modem.

Message

(AT)&F&K0&Q0&D0V1X0Q0 (<CR><LF>)

Length

17 characters

Characters within parentheses are automatically sent.

For example, the initialization message may also be used to set S-registers of the modem.

Message

(AT)S0=1 (<CR><LF>)

Length

4 characters

Characters within parentheses are automatically sent.

To have XXMIT send an initialization message to the modem, bit 7 and bit 16 of the command word must be ON. When bit 16 is ON, bits 15 and 14 must not be ON or

XXMIT will not complete the operation successfully. To actually send the message,

Start input of XXMIT must come ON and stays ON until the operation is complete or an error occurs. When XXMIT determines the message was successfully sent to the modem, it turns ON the Done output. When an error occurs, the Error output comes

ON. The Active output is ON while the message is being sent to the modem.

Note: To eliminate some user logic programming, you may initialize the modem with parameters via a terminal program and not use XXMIT. Once the parameters are in the modem memory they may be saved to non-memory with an AT command, usually &W.

108

33002196

Dial Message

Tech.Ref.XXMIT

The dial message is used to send a telephone number to the modem. Only AT commands related to dialing a number should be included with the message.

Examples of typical dial messages used with XXMIT are shown below.

For example, dial telephone number using tone dialing.

Message

(AT)DT)6800326 (<CR><LF>)

Length

7 characters

Characters within parentheses are automatically sent.

For example, dial telephone number using pulse dialing.

Message

(AT)DP)6800326 (<CR><LF>)

Length

7 characters

Characters within parentheses are automatically sent.

For example, dial telephone number using tone dialing, wait to hear dial tone before dialing number, and pause before dialing the rest of the number.

Message Length

(AT)DT)W,6800326 (<CR><LF>)

9 characters

Characters within parentheses are automatically sent.

To have XXMIT send a tone dial message to the modem, bit 7 and bit 15 of the command word must be ON. When bit 15 is ON, bits 16 and 14 must not be ON or

XXMIT will not complete the operation successfully. To actually send the message, the Start input of XXMIT must come ON and stays ON until the operation is complete or an error occurs. When XXMIT determines the message was successfully sent to the modem, it turns ON the Done output. When an error occurs, the Error output comes ON. The Active output is ON while the message is being sent to the modem.

Note: Because it takes so long for a local modem to make a connection to a remote modem, the timeout value, in RespTout should be quite long when sending a dial message to a modem. For example, set the timeout for 30,000 mS when sending a dial message. When the timeout value is too short, XXMIT issues a message timeout. You may have to try several settings before finding the optimal time.

33002196

109

Tech.Ref.XXMIT

Hangup Message

The hangup message is used to hangup the modem. Only AT commands related to hanging up the modem should be used in this message. An example of a typical hangup message is shown below.

For example, hangup modem message.

Message

(+++AT)H0 (<CR><LF>)

Length

2 characters

Characters within parentheses are automatically sent.

When the hangup message is sent to a modem that is already connected to a remote modem, XXMIT must first set the local modem in command mode. XXMIT does this by sending a escape sequence +++ to the modem. XXMIT assumes that

+++ sets the modem in command mode. Some modem manufactures let the owner change this default escape sequence. For XXMIT to function properly the modem should be set to accept the +++ escape sequence.

To have XXMIT send a hangup message to the modem, bit 7 and bit 14 of the command word must be ON. When bit 14 is ON, bits 16 and 15 must not be ON or

XXMIT will not complete the operation successfully. To actually send the message, the Start input of XXMIT must come ON and stays ON until the operation is complete or an error occurs. When XXMIT determines the message was successfully sent to the modem, it turns ON the Done output. When an error occurs, the Error output comes ON. The Done output is ON while the message is being sent to the modem.

Note: Expert: Because it takes so long for a local modem to hangup once it receives the hangup command, the timeout value, in RespTout should quite long when sending a dial message to a modem. For example, set the timeout for 30,000 mS when sending a dial message. When the timeout value is too short, XXMIT issues a message timeout. You may have to try several settings before finding the optimal time.

110

33002196

Cabling Information

At a Glance

Overview

What's in this

Chapter?

This chapter describes cables and pinouts for the hardware components used with the Transmit function blocks.

This chapter contains the following topics:

Topic

Cable Pinouts

Cable Adapter Kits

Page

112

126

33002196

111

Cabling

Cable Pinouts

Interface Cable

Pinouts

You need to build an interface cable between your PLC and the modem or printer.

The actual cable is connected to the Port which is supported by the PLC and to the

RS232 port of the modem or printer, or direct to another PLC's Modbus port.

Because the XXMIT supports many modems and printers the pinouts are going to vary. Some pinouts are provided below.

For information on Momentum communication connections see TSX Momentum M1

Processor Adapter and Option Adapter User Guide.

112

33002196

9-pin (RS-232) to

25-pin (Modem) with no RTS/CTS

Control

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

Pin 1

9-pin Male

Front View

Pin 9

Pin 1

1 3

1 2

1 0

2 0

1 9

1 7

1 6

1 5

Pin 25

Front View

RXD

TXD

RTS

CTS

DSR

DTR

GND

Refer to the Connector Pinouts table.

Connector Pinouts

9-Pin Connector

Signal Name Pinout

7 Jumpered

8 Jumpered

4 Jumpered

6 Jumpered

Pinout

Connected To

...

25-Pin D-shell

Pinout

Yes

4 Jumpered

5 Jumpered

Yes

6 Jumpered

20 Jumpered

Signal Name

RXD

TXD

RTS

CTS

DSR

DTR

GND

Cabling

33002196

113

Cabling

9-pin (RS-232) to

25-pin (Modem) with RTS/CTS

Control

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

Pin 1

9-pin Male

Front View

Pin 9

Pin 1

1 3

1 2

1 0

2 0

1 9

1 7

1 6

1 5

Pin 25

Front View

RXD

TXD

RTS

CTS

DSR

DTR

GND

Refer to the Connector Pinouts table.

Connector Pinouts

9-Pin Connector

Signal Name Pinout

4 Jumpered

6 Jumpered

Pinout

Connected To

...

Yes

25-Pin D-shell

Pinout

6 Jumpered

20 Jumpered

5 Yes 7

Signal Name

RXD

TXD

RTS

CTS

DSR

DTR

GND

114

33002196

9-pin to 9-pin

(Null Modem)

Refer to the figure for Front Views of Connectors.

9-pin Male

Pin 9

Pin 1

Front View

RXD

TXD

RTS

CTS

DSR

DTR

GND

Refer to the Connector Pinouts table.

Connector Pinouts

9-Pin Connector

Signal Name Pinout

7 Jumpered

8 Jumpered

Pinout

Connected To

...

Yes

4 Jumpered

6 Jumpered

5 Yes

9-Pin Connector

Pinout Signal Name

7 Jumpered

8 Jumpered

4 Jumpered

6 Jumpered

TXD

RXD

RTS

CTS

DSR

DTR

GND

Cabling

33002196

115

Cabling

9-pin to 9-pin

(Modem)

Refer to the figure for Front Views of Connectors.

9-pin Male

Pin 9

Pin 1

Front View

TXD

RXD

RTS

CTS

DSR

DTR

GND

Refer to the Connector Pinouts table.

Connector Pinouts

9-Pin Connector

Signal Name Pinout

4 Jumpered

6 Jumpered

Pinout

Connected To

...

9-Pin Connector

Pinout Signal Name

Yes

4 Jumpered

6 Jumpered

TXD

RXD

RTS

CTS

DSR

DTR

GND

116

33002196

9-pin to 25-pin

(Null Modem)

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

Pin 1

9-pin Male

Pin 9

Front View

Pin 1

1 3

1 2

1 0

2 0

1 9

1 7

1 6

1 5

Pin 25

Front View

Refer to the Connector Pinouts table.

RXD

TXD

RTS

CTS

DSR

DTR

GND

Connector Pinouts

9-Pin Connector

Signal Name Pinout

7 Jumpered

8 Jumpered

4 Jumpered

6 Jumpered

25-Pin D-shell

Pinout

Connected To

...

Pinout

Yes

4 Jumpered

5 Jumpered

Yes

6 Jumpered

20 Jumpered

Siignal Name

TXD

RXD

RTS

CTS

DSR

DTR

GND

Cabling

33002196

117

Cabling

RJ45-(8x8) to

25-pin

(Null Modem)

110XCA20401

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

RJ45 connector

(8x8)

Pin 1

2 0

1 9

1 8

1 7

1 6

1 5

1 4

Pin 25

Pin 1

Front View

Refer to the Connector Pinouts table.

RXD

TXD

RTS

CTS

GND

DSR

Connector Pinouts

RJ45 Connector

Signal Name Pinout

Chassis

Ground

6 Jumpered

7 Jumpered

Pinout

Connected To

...

25-Pin D-shell

Pinout Signal Name

Yes

TXD

RXD

Yes

4 Jumpered

5 Jumpered

RTS

CTS

GND

DSR

DTR

Chassis

Ground

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

118

33002196

Cabling

RJ45-(8x8) to

9-pin

(Null Modem)

110XCA20301

Refer to the figure for Front Views of Connectors.

9-pin Male

RJ45 connector

(8x8)

Pin 1

Front View

Pin 9

RXD

TXD

RTS

CTS

GND

DSR

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout

6 Jumpered

7 Jumpered

Pinout

Connected

To ...

Yes

Chassis

Ground

8 Yes

9-Pin D-shell

Pinout Signal Name

TXD

RXD

7 Jumpered

8 Jumpered

RTS

CTS

GND

DTR

DSR

Case of the

Connector

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

33002196

119

Cabling

RJ45-(8x8) to

25-pin (Modem)

110XCA20401

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

RJ45 connector

(8x8)

Pin 25

Pin 1

1 3

1 2

1 1

2 3

1 0

2 0

1 7

1 6

Front View

RXD

TXD

RTS

CTS

GND

DSR

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout

Chassis

Ground

6 Jumpered

7 Jumpered

25-Pin D-shell

Pinout

Connected To

...

Pinout Signal Name

Yes

4 Jumpered

5 Jumpered

RXD

TXD

RTS

CTS

Yes

GND

DSR

DTR

Chassis

Ground

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

120

33002196

Cabling

RJ45-(8x8) to

25-pin (Modem)

110XCA20401

Refer to the figure for Front Views of Connectors.

25-pin Male Adapter

RJ45 connector

(8x8)

Pin 25

Pin 1

1 1

2 3

2 4

2 2

2 5

2 1

Front View

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout Pinout

Connected

To ...

RXD

TXD

RTS

CTS

GND

Yes

25-Pin D-shell

Pinout

6 Jumpered

20 Jumpered

Chassis

Ground

8 Yes 1

Signal Name

RXD

TXD

RTS

CTS

GND

DSR

DTR

Chassis

Ground

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

33002196

121

Cabling

RJ45-(8x8) to

RJ45-(8x8)

(Modem)

Refer to the figure for Front Views of Connectors.

9-pin Male

RJ45 connector

(8x8)

Pin 1

Pin 9

Pin 1

Front View

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout Pinout

Connected

To ...

RXD

TXD

RTS

CTS

GND

DSR

Chassis

Ground

Yes

RJ45 Connector

Pinout Signal Name

RXD

TXD

RTS

CTS

GND

DSR

Chassis

Ground

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

122

33002196

Cabling

9-pin to RJ45-

(8x8) (Modem)

110XCA20301

Refer to the figure for Front Views of Connectors.

RJ45 connector

(8x8)

9-pin Male

Pin 9

Pin 1

Front View

RXD

TXD

RTS

CTS

GND

DSR

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout

6 Jumpered

7 Jumpered

Pinout

Connected

To ...

Yes

Chassis

Ground

8 Yes

9-Pin Connector

Pinout Signal Name

7 Jumpered

8 Jumpered

RXD

TXD

RTS

CTS

GND

DSR

DTR

Case of the Connector

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

33002196

123

Cabling

9-pin to RJ45-

(8x8) (Modem)

110XCA20301

Refer to the figure for Front Views of Connectors.

RJ45 connector

(8x8)

9-pin Male

Pin 9

Pin 1

Front View

Refer to the Connector Pinouts table.

Connector Pinouts

RJ45 Connector

Signal Name Pinout

RXD

TXD

RTS

CTS

GND

Chassis

Ground

Pinout

Connected To

...

9-Pin Connector

Pinout Signal Name

Yes

RXD

TXD

Yes

RTS

CTS

6 Jumpered

4 Jumpered

GND

DSR

DTR

Case of the Connector

CAUTION

Danger of 5 V short circuit.

Pin1 of the RJ45 receives 5V from the PLC.

Failure to follow this instruction can result in injury or equipment damage.

124

33002196

9-pin Momentum

RS 485

Refer to the figure for Front Views of Connectors.

Pinouts table for the 9-pin D-Sub female Momentum RS 485 connector.

Pin

Signal Name

TXD +

RXD +

Signal Ground reserved reserved

TXD -

RXD reserved reserved

RS 485 Multidrop

Example

The following illustration shows a RS 485 2-wire multidrop wiring example

120

Ω

120

Ω

Cabling

33002196

125

Cabling

RJ 45 Momentum

RS 485

Refer to the figure for Front Views of Connectors.

Pin 1

Pinouts table for the RJ 45 Momentum RS 485 connector.

Pin

Signal Name

RXD -

RXD +

TXD + reserved

Signal Ground

TXD reserved screen

Cable Adapter Kits

Cable Adapter

Kits for RJ45

You may want to purchase Cable Adapter Kits for your RJ45 (8x8) requirements rather than make them. The table below provides a list of available kits.

Available Cable Adapter Kids

Description

RJ45-(8x8) to 25-Pin (Male)

RJ45-(8x8) to 9-Pin (Male)

RJ45-(8x8) to 9-Pin (Female)

RJ45-(8x8) to 25-Pin (Female)

Part Number

110XCA20401

110XCA20301

110XCA20302

110XCA20402

126

33002196

Glossary

A

active window

The window, which is currently selected. Only one window can be active at any given time. When a window is active, the color of the title bar changes, so that it is distinguishable from the other windows. Unselected windows are inactive.

current connected input / output parameters

actual parameters addresses

ANL_IN

ANL_OUT

ANY

33002196

(Direct) addresses are memory ranges on the PLC. They are located in the State

RAM and can be assigned Input/Output modules.

l l l l

The display/entry of direct addresses is possible in the following formats:

Standard Format (400001)

Separator Format (4:00001)

Compact format (4:1)

IEC Format (QW1)

ANL_IN stands for the "Analog Input" data type and is used when processing analog values. The 3x-References for the configured analog input module, which were specified in the I/O component list, are automatically assigned to the data type and should therefore only be occupied with Unlocated Variables.

ANL_OUT stands for the "Analog Output" data type and is used when processing analog values. The 4x-References for the configured analog output module, which were specified in the I/O component list, are automatically assigned to the data type and should therefore only be occupied with Unlocated Variables.

In the present version, "ANY" covers the BOOL, BYTE, DINT, INT, REAL, UDINT,

UINT, TIME and WORD elementary data types and related Derived Data Types.

127

Glossary

ANY_BIT

ANY_ELEM

ANY_INT

ANY_NUM

ANY_REAL application window argument

ASCII-Mode

Atrium

In the present version, "ANY_BIT" covers the BOOL, BYTE and WORD data types.

In the present version, "ANY_ELEM" covers the BOOL, BYTE, DINT, INT, REAL,

UDINT, UINT, TIME and WORD data types.

In the present version, "ANY_INT" covers the DINT, INT, UDINT and UINT data types.

In the present version, "ANY_NUM" covers the DINT, INT, REAL, UDINT and UINT data types.

In the present version, "ANY_REAL" covers the REAL data type.

The window contains the workspace, menu bar and the tool bar for the application program. The name of the application program appears in the title bar. An application window can contain several Document windows. In Concept the application window corresponds to a Project.

synonymous with actual parameters.

The ASCII (American Standard Code for Information Interchange) mode is used to communicate with various host devices. ASCII works with 7 data bits.

The PC based Controller is located on a standard AT board, and can be operated within a host computer in an ISA bus slot. The module has a motherboard (requires

SA85 driver) with two slots for PC104 daughter-boards. In this way, one PC104 daughter-board is used as a CPU and the other as the INTERBUS controller.

B

backup file

(Concept-EFB)

The backup file is a copy of the last Source coding file. The name of this backup file is "backup??.c" (this is assuming that you never have more than 100 copies of the source coding file). The first backup file has the name "backup00.c". If you have made alterations to the Definitions file which do not cause any changes to the EFB interface, the generation of a backup file can be stopped by editing the source coding file (Objects

→ Source). If a backup file is created, the source file can be entered as the name.

128

33002196

Glossary

base 16 literals base 2 literals base 8 literals

Base 16 literals are used to input whole number values into the hexadecimal system.

The base must be denoted using the prefix 16#. The values can not have any signs

(+/-). Single underscores ( _ ) between numbers are not significant.

Example

16#F_F or 16#FF (decimal 255)

16#E_0 or 16#E0 (decimal 224)

Base 2 literals are used to input whole number values into the dual system. The base must be denoted using the prefix 2#. The values can not have any signs (+/-).

Single underscores ( _ ) between numbers are not significant.

Example

2#1111_1111 or 2#11111111 (decimal 255)

2#1110_0000 or 2#11100000 (decimal 224)

Base 8 literals are used to input whole number values in the octosystem. The base must be denoted using the prefix 8#. The values can not have any signs (+/-). Single underscores ( _ ) between numbers are not significant.

Example

8#3_77 or 8#377 (decimal 255)

8#34_0 or 8#340 (decimal 224)

Connections between FFB outputs and inputs with the data type BOOL.

binary connections bit sequence

BOOL bridge

BYTE

A data element, which consists of one or more bits.

BOOL stands for the data type "boolean". The length of the data element is 1 bit

(occupies 1 byte in the memory). The value range for the variables of this data type is 0 (FALSE) and 1 (TRUE).

A bridge is a device which connects networks. It enables communication between nodes on two networks. Each network has its own token rotation sequence - the token is not transmitted via the bridge.

BYTE stands for the data type "bit sequence 8". Entries are made as base 2 literal, base 8 literal or base 16 literal. The length of the data element is 8 bits. A numerical value range can not be assigned to this data type.

33002196

129

Glossary

C

clipboard coil compact format

(4:1) constants contact

The clipboard is a temporary memory for cut or copied objects. These objects can be entered in sections. The contents of the clipboard are overwritten with each new cut or copy.

A coil is a LD element which transfers the status of the horizontal connection on its left side, unchanged, to the horizontal connection on its right side. In doing this, the status is saved in the relevant variable/direct address.

The first digit (the Reference) is separated from the address that follows by a colon

(:) where the leading zeros are not specified.

Constants are Unlocated variables, which are allocated a value that cannot be modified by the logic program (write protected).

A contact is a LD element, which transfers a status on the horizontal link to its right side. This status comes from the boolean AND link of the status of the horizontal link on the left side, with the status of the relevant variable/direct address. A contact does not change the value of the relevant variable/direct address.

D

data transfer settings data types

Settings which determine how information is transferred from your programming device to the PLC.

l l

The overview shows the data type hierarchy, as used for inputs and outputs of functions and function blocks. Generic data types are denoted using the prefix

"ANY".

l ANY_ELEM l

ANY_NUM

ANY_REAL (REAL) l

ANY_INT (DINT, INT, UDINT, UINT)

ANY_BIT (BOOL, BYTE, WORD) l

TIME

System Data types (IEC Extensions)

Derived (from "ANY" data types)

130

33002196

Glossary

DCP I/O drop

DDE (Dynamic

Data Exchange)

A remote network with a super-ordinate PLC can be controlled using a Distributed

Control Processor (D908). When using a D908 with remote PLC, the super-ordinate

PLC considers the remote PLC as a remote I/O drop. The D908 and the remote PLC communicate via the system bus, whereby a high performance is achieved with minimum effect on the cycle time. The data exchange between the D908 and the super-ordinate PLC takes place via the remote I/O bus at 1.5Mb per second. A super-ordinate PLC can support up to 31 D908 processors (addresses 2-32).

The DDE interface enables a dynamic data exchange between two programs in

Windows. The user can also use the DDE interface in the extended monitor to call up their own display applications. With this interface, the user (i.e. the DDE client) can not only read data from the extended monitor (DDE server), but also write data to the PLC via the server. The user can therefore alter data directly in the PLC, while monitoring and analyzing results. When using this interface, the user can create their own "Graphic Tool", "Face Plate" or "Tuning Tool" and integrate it into the system. The tools can be written in any language, i.e. Visual Basic, Visual C++, which supports DDE. The tools are invoked when the user presses one of the buttons in the Extended Monitor dialog field. Concept Graphic Tool: Configuration signals can be displayed as a timing diagram using the DDE connection between

Concept and Concept Graphic Tool.

declaration definitions file

(Concept-EFB) defragmenting

Mechanism for specifying the definition of a language element. A declaration usually covers the connection of an identifier to a language element and the assignment of attributes such as data types and algorithms.

The definitions file contains general descriptive information on the selected EFB and its formal parameters.

With defragmenting, unanticipated gaps (e.g. resulting from deleting unused variables) are removed from memory.

See also PLC Selection in the context help.

derived data type

Derived data types are data types, which are derived from Elementary Data Types and/or other derived data types. The definition of the derived data types is found in the Concept data type editor.

A distinction is made between global data types and local data types.

33002196

131

Glossary

derived function block (DFB)

A derived function block represents the invocation of a derived function block type.

Details of the graphic form of the invocation can be found in the "Functional block

(instance)". In contrast to the invocation of EFB types, invocations of DFB types are denoted by double vertical lines on the left and right hand side of the rectangularblock symbol.

The output side of a derived function block is created in FBD language, LD language, ST language, IL language, but only in the current version of the programming system. Derived functions can also not be defined in the current version.

A distinction is made between local and global DFBs.

DFB code

DFB instance data

DINT

The DFB code is the section's DFB code which can be executed. The size of the

DFB code is mainly dependent upon the number of blocks in the section.

The DFB instance data is internal data from the derived function blocks used in the program.

direct representation document window

DINT stands for the data type "double length whole number (double integer)".

Entries are made as integer literal, base 2 literal, base 8 literal or base 16 literal. The length of the data element is 32 bits. The value range for variables of this data type reaches from -2 exp (31) to 2 exp (31) -1.

A method of displaying variables in the PLC program, from which the assignment to the logical memory can be directly - and indirectly to the physical memory - derived.

A window within an application window. Several document windows can be open at the same time in an application window. However, only one document window can ever be active. Document windows in Concept are, for example, sections, the message window, the reference data editor and the PLC configuration.

DP = Remote Peripheral

DP (PROFIBUS) dummy

DX zoom

An empty file, which consists of a text heading with general file information, such as author, date of creation, EFB designation etc. The user must complete this dummy file with further entries.

This property enables the user to connect to a programming object, to monitor and, if necessary change, its data value.

132

33002196

Glossary

E

EFB code elementary functions/ function blocks

(EFB)

The EFB code is the executable code of all EFBs used. In addition the used EFBs count in DFBs.

Identifier for Functions or Function blocks, whose type definitions are not formulated in one of the IEC languages, i.e. whose body for example can not be modified with the DFB editor (Concept-DFB). EFB types are programmed in "C" and are prepared in a pre-compiled form using libraries.

EN / ENO (enable

/ error signal)

If the value of EN is equal to "0" when the FFB is invoked, the algorithms that are defined by the FFB will not be executed and all outputs keep their previous values.

The value of ENO is in this case automatically set to "0". If the value of EN is equal to "1", when the FFB is invoked, the algorithms which are defined by the FFD will be executed. After the error-free execution of these algorithms, the value of ENO is automatically set to "1". If an error occurs during the execution of these algorithms,

ENO is automatically set to "0". The output behavior of the FFB is independent of whether the FFBs are invoked without EN/ENO or with EN=1. If the EN/ENO display is switched on, it is imperative that the EN input is switched on. Otherwise, the FFB is not executed. The configuration of EN and ENO is switched on or off in the Block

Properties dialog box. The dialog box can be invoked with the Objects

→

Properties...menu command or by double-clicking on the FFB.

error

If an error is recognized during the processing of a FFB or a step (e.g. unauthorized input values or a time error), an error message appears, which can be seen using the Online

→ Event Viewer...menu command. For FFBs, the ENO output is now set to "0".

evaluation expression

The process, through which a value is transmitted for a Function or for the output of a Function block during Program execution.

Expressions consist of operators and operands.

F

FFB (functions/ function blocks)

Collective term for EFB (elementary functions/function blocks) and DFB (Derived function blocks)

33002196

133

Glossary

field variables

FIR filter formal parameters function (FUNC) function block

(Instance) (FB) function block dialog (FBD) function block type

A variable, which is allocated a defined derived data type with the key word ARRAY

(field). A field is a collection of data elements with the same data type.

(Finite Impulse Response Filter) a filter with finite impulse answer

Input / Output parameters, which are used within the logic of a FFB and led out of the FFB as inputs/outputs.

A program organization unit, which supplies an exact data element when processing. a function has no internal status information. Multiple invocations of the same function using the same input parameters always supply the same output values.

Details of the graphic form of the function invocations can be found in the definition

"Functional block (instance)". In contrast to the invocations of the function blocks, function invocations only have a single unnamed output, whose name is the same as the function. In FBD each invocation is denoted by a unique number via the graphic block, this number is automatically generated and can not be altered.

A function block is a program organization unit, which correspondingly calculates the functionality values that were defined in the function block type description, for the outputs and internal variable(s), if it is invoked as a certain instance. All internal variable and output values for a certain function block instance remain from one function block invocation to the next. Multiple invocations of the same function block instance with the same arguments (input parameter values) do not therefore necessarily supply the same output value(s).

Each function block instance is displayed graphically using a rectangular block symbol. The name of the function block type is stated in the top center of the rectangle. The name of the function block instance is also stated at the top, but outside of the rectangle. It is automatically generated when creating an instance, but, depending on the user's requirements, it can be altered by the user. Inputs are displayed on the left side of the block and outputs are displayed on the right side.

The names of the formal input/output parameters are shown inside the rectangle in the corresponding places.

The above description of the graphic display is especially applicable to the function invocations and to DFB invocations. Differences are outlined in the corresponding definitions.

One or more sections, which contain graphically displayed networks from Functions,

Function blocks and Connections.

A language element, consisting of: 1. the definition of a data structure, divided into input, output and internal variables; 2. a set of operations, which are performed with elements of the data structure, when a function block type instance is invoked. This set of operations can either be formulated in one of the IEC languages (DFB type) or in "C" (EFB type). A function block type can be instanced (invoked) several times.

134

33002196

Glossary

function number

The function number is used to uniquely denote a function in a program or DFB. The function number can not be edited and is automatically assigned. The function number is always formed as follows: .n.m

n = Number of the section (consecutive numbers) m = Number of the FFB object in the section (current number)

G

generic data type

A data type, which stands in place of several other data types.

generic literals

If the literal's data type is not relevant, simply specify the value for the literal. If this is the case, Concept automatically assigns the literal a suitable data type.

global data global derived data types global DFBs

Global data are Unlocated variables.

Global derived data types are available in each Concept project and are occupied in the DFB directory directly under the Concept directory.

global macros

Global DFBs are available in each Concept project. The storage of the global DFBs is dependant upon the settings in the CONCEPT.INI file.

Global macros are available in each Concept project and are stored in the DFB directory directly under the Concept directory.

groups (EFBs)

Some EFB libraries (e.g. the IEC library) are divided into groups. This facilitates locating the EFBs especially in expansive libraries.

H

host computer

Hardware and software, which support programming, configuring, testing, operating and error searching in the PLC application as well as in a remote system application, in order to enable source documentation and archiving. The programming device can also be possibly used for the display of the process.

33002196

135

Glossary

I

I/O map icon

The I/O and expert modules from the various CPUs are configured in the I/O map.

Graphical representation of different objects in Windows, e.g. drives, application programs and document windows.

IEC 61131-3

IEC program memory

International standard: Programmable Logic Controls - Part 3: Programming languages.

IEC format (QW1)

There is an IEC type designation in initial position of the address, followed by the five-figure address.

l l l l

%0x12345 = %Q12345

%1x12345 = %I12345

%3x12345 = %IW12345

%4x12345 = %QW12345

IEC name conventions

(identifier)

An identifier is a sequence of letters, numbers and underscores, which must begin with either a letter or underscore (i.e. the name of a function block type, an instance, a variable or a section). Letters of a national typeface (i.e.: ö,ü, é, õ) can be used, except in project and DFB names.

Underscores are significant in identifiers; e.g. "A_BCD" and "AB_CD" are interpreted as two separate identifiers. Several leading and multiple successive underscores are not allowed.

Identifiers should not contain any spaces. No differentiation is made between upper and lower case, e.g. "ABCD" and "abcd" are interpreted as the same identifier.

Identifiers should not be Keywords.

The IEC program memory consists of the program code, EFB code, the section data and the DFB instance data.

(Infinite Impulse Response Filter) a filter with infinite impulse answer

IIR filter initial step initial value

The first step in a sequence. A step must be defined as an initial step for each sequence. The sequence is started with the initial step when first invoked.

The value, which is allocated to a variable when the program is started. The values are assigned in the form of literals.

136

33002196

Glossary

input bits

(1x references)

The 1/0 status of the input bits is controlled via the process data, which reaches from an input device to the CPU.

Note: The x, which follows the initial reference type number, represents a fivefigure storage location in the user data memory, i.e. the reference 100201 signifies an output or marker bit at the address 201 in the State RAM.

input parameter

(input) input words

(3x references) instance name

upon invocation of a FFB, this transfers the corresponding argument

An input word contains information, which originates from an external source and is represented by a 16 bit number. A 3x register can also contain 16 sequential input bits, which were read into the register in binary or BCD (binary coded decimal) format. Note: The x, which follows the initial reference type number, represents a five-figure storage location in the user data memory, i.e. the reference 300201 signifies a 16-bit input word at the address 201 in the State RAM.

An identifier, which belongs to a certain function block instance. The instance name is used to clearly denote a function block within a program organization unit. The instance name is automatically generated, but it can be edited. The instance name must be unique throughout the whole program organization unit, and is not case sensitive. If the name entered already exists, you will be warned and you will have to choose another name. The instance name must comply with the IEC name conventions otherwise an error message appears. The automatically generated instance name is always formed as follows: FBI_n_m

instancing instruction (IL)

FBI = Function Block Instance n = Number of the section (consecutive numbers) m = Number of the FFB object in the section (current number) generating an instance

Instructions are the "commands" of the IL programming language. Each instruction begins on a new line and is performed by an operator with a modifier if necessary, and if required for the current operation, by one or more operands. If several operands are used, they are separated by commas. A character can come before the instruction, which is then followed by a colon. The comment must, if present, be the last element of the line.

33002196

137

Glossary

instruction

(LL984) instruction (ST)

When programming electrical controls, the user must implement operation-coded instructions in the form of picture objects, which are divided into a recognizable contact form. The designed program objects are, on a user level, converted to computer usable OP codes during the download process. The OP codes are decoded in the CPU and processed by the firmware functions of the controller in a way that the required control is implemented.

Instructions are "commands" of the ST programming language. Instructions must be completed by semicolons. Several instructions can be entered in one line (separated by semicolons).

instruction list

(IL)

INT integer literals

IL is a text language according to IEC 1131, which is shown in operations, i.e. conditional or unconditional invocations of Functions blocks and Functions, conditional or unconditional jumps etc. through instructions.

INT stands for the data type "whole number (integer)". Entries are made as integer literal, base 2 literal, base 8 literal or base 16 literal. The length of the data element is 16 bits. The value range for variables of this datatype reaches from -2 exp (15) to

2 exp (15) -1.

Integer literals are used to input whole number values into the decimal system. The values can have a preceding sign (+/-). Single underscores ( _ ) between numbers are not significant.

Example

-12, 0, 123_456, +986

INTERBUS (PCP)

The new INTERBUS (PCP) I/O drop type is entered into the Concept configurator, to allow use of the INTERBUS PCP channel and the INTERBUS process data preprocessing (PDV). This I/O drop type is assigned the INTERBUS switching module

180-CRP-660-01.

The 180-CRP-660-01 differs from the 180-CRP-660-00 only in the fact that it has a clearly larger I/O range in the control state RAM.

invocation

The process by which the execution of an operation is initiated.

J

jump

Element of the SFC language. Jumps are used to skip zones in the sequence.

138

33002196

Glossary

K

keywords

Keywords are unique combinations of characters, which are used as special syntactical components, as defined in Appendix B of the IEC 1131-3. All keywords which are used in the IEC 1131-3 and therefore in Concept, are listed in Appendix

C of the IEC 1131-3. These keywords may not be used for any other purpose, i.e. not as variable names, section names, instance names etc.

L

Ladder Diagram

(LD)

Ladder Diagram is a graphic programming dialog according to IEC1131, which is optically oriented to the "rung" of a relay contact plan.

Ladder Logic 984

(LL)

The terms Ladder Logic and Ladder Diagram refer to the word Ladder being executed. In contrast to a circuit diagram, a ladder diagram is used by electrotechnicians to display an electrical circuit (using electrical symbols), which should show the course of events and not the existing wires, which connect the parts with each other. A usual user interface for controlling the actions of automation devices permits a Ladder Diagram interface, so that electrotechnicians do not have to learn new programming languages to be able to implement a control program.

The structure of the actual Ladder Diagram enables the connection of electric elements in such a way that generates a control output, which is dependent upon a logical power flow through used electrical objects, which displays the previously requested condition of a physical electrical device.

In simple form, the user interface is a video display processed by the PLC programming application, which sets up a vertical and horizontal grid in which programming objects are classified. The diagram contains the power grid on the left side, and when connected to activated objects, the power shifts from left to right.

landscape language element library

Landscape means that when looking at the printed text, the page is wider than it is high.

Every basic element in one of the IEC programming languages, e.g. a step in SFC, a function block instance in FBD or the initial value of a variable.

Collection of software objects, which are intended for re-use when programming new projects, or even building new libraries. Examples are the libraries of the

Elementary function block types.

EFB libraries can be divided up into Groups.

33002196

139

Glossary

link literals local derived data types local DFBs local link local macros

A control or data flow connection between graphical objects (e.g. steps in the SFC

Editor, function blocks in the FBD Editor) within a section, represented graphically as a line.

Literals are used to provide FFB inputs, and transition conditions etc with direct values. These values can not be overwritten by the program logic (write-protected).

A distinction is made between generic and standardized literals.

Literals are also used to allocate, to a constant, a value or a variable, an initial value.

Entries are made as base 2 literal, base 8 literal, base 16 literal, integer literal, real literal or real literal with exponent.

Local derived data types are only available in a single Concept project and the local

DFBs and are placed in the DFB directory under the project directory.

Local DFBs are only available in a single Concept project and are placed in the DFB directory under the project directory.

The local network is the network, which connects the local nodes with other nodes either directly or through bus repeaters.

Local macros are only available in a single Concept project and are placed in the

DFB directory under the project directory.

The local node is the one which is currently being configured.

local network nodes located variable

A state RAM address (reference addresses 0x, 1x, 3x,4x) is allocated to located variables. The value of these variables is saved in the state RAM and can be modified online using the reference data editor. These variables can be addressed using their symbolic names or their reference addresses.

All inputs and outputs of the PLC are connected to the state RAM. The program can only access peripheral signals attached to the PLC via located variables. External access via Modbus or Modbus Plus interfaces of the PLC, e.g. from visualization systems, is also possible via located variables.

140

33002196

Glossary

M

macro

MMI multi element variables

Macros are created with the help of the Concept DFB software.

Macros are used to duplicate frequently used sections and networks (including their logic, variables and variable declaration).

A distinction is made between local and global macros.

l l l l l l l l l l l

Macros have the following properties:

Macros can only be created in the FBD and LD programming languages.

Macros only contain one section.

Macros can contain a section of any complexity.

In programming terms, there is no difference between an instanced macro, i.e. a macro inserted into a section and a conventionally created section.

DFB invocation in a macro

Declaring variables

Using macro-specific data structures

Automatic transfer of the variables declared in the macro.

Initial values for variables

Multiple instancing of a macro in the entire program with differing variables

The name of the section, variable names and data structure names can contain up to 10 different exchange marks (@0 to @9).

Man-Machine-Interface

Variables to which a Derived data type defined with STRUCT or ARRAY is allocated.

A distinction is made here between field variables and structured variables.

N

network network node node

A network is the collective switching of devices to a common data path, which then communicate with each other using a common protocol.

A node is a device with an address (1...64) on the Modbus Plus network.

Node is a programming cell in a LL984 network. A cell/node consists of a 7x11 matrix, i.e. 7 rows of 11 elements.

33002196

141

Glossary

node address

The node address is used to uniquely denote a network node in the routing path.

The address is set on the node directly, e.g. using the rotary switch on the back of the modules.

O

operand operator

An operand is a literal, a variable, a function invocation or an expression.

An operator is a symbol for an arithmetic or boolean operation which is to be executed.

output parameter

(output):

A parameter, through which the result(s) of the evaluation of a FFB is/are returned.

output/marker bits

(0x references) output/marker words

(4x references)

An output/marker bit can be used to control real output data using an output unit of the control system, or to define one or more discrete outputs in the state RAM. Note:

The x, which follows the initial reference type number, represents a five-figure storage location in the user data memory, i.e. the reference 000201 signifies an output or marker bit at the address 201 in the State RAM.

An output / marker word can be used to save numerical data (binary or decimal) in the state RAM, or to send data from the CPU to an output unit in the control system.

Note: The x, which follows the initial reference type number, represents a five-figure storage location in the user data memory, i.e. the reference 400201 signifies a 16 bit output or marker word at the address 201 in the State RAM.

P

Peer CPU

PLC portrait program

The Peer CPU processes the token execution and the data flow between the

Modbus Plus network and the PLC user logic.

memory programmable controller

Portrait means that the sides are larger than the width when printed.

The uppermost program organization unit. A program is closed on a single PLC download.

142

33002196

Glossary

program organization unit

A function, a function block, or a Program. This term can refer to either a type or an instance.

program redundancy system

(Hot Standby) project

A redundancy system consists of two identically configured PLC machines, which communicate with one another via redundancy processors. In the case of a breakdown of the primary PLC, the secondary PLC takes over the control check.

Under normal conditions, the secondary PLC does not take over the control function, but checks the status information, in order to detect errors.

General description for the highest level of a software tree structure, which specifies the super-ordinate project name of a PLC application. After specifying the project name you can save your system configuration and your control program under this name. All data that is created whilst setting up the configuration and program, belongs to this super-ordinate project for this specific automation task.

General description for the complete set of programming and configuration information in the project database, which represents the source code that describes the automation of a system.

project database

The database in the host computer, which contains the configuration information for a project.

prototype file

(Concept-EFB)

The prototype file contains all the prototypes of the assigned functions. In addition, if one exists, a type definition of the internal status structure is specified.

R

REAL real literals

33002196

REAL stands for the data type "floating point number". The entry can be real-literal or real-literal with an exponent. The length of the data element is 32 bits. The value range for variables of this data type extends from +/-3.402823E+38.

Note: Dependent on the mathematical processor type of the CPU, different ranges within this permissible value range cannot be represented. This applies to values that are approaching ZERO and for values that approach INFINITY. In these cases

NAN (Not A Number) or INF (INFinite) will be displayed in the animation mode instead of a number value.

Real literals are used to input floating point values into the decimal system. Real literals are denoted by a decimal point. The values can have a preceding sign (+/-).

Single underscores ( _ ) between numbers are not significant.

Example

-12.0, 0.0, +0.456, 3.14159_26

143

Glossary

real literals with exponents reference

Real literals with exponents are used to input floating point values into the decimal system. Real literals with exponents are identifiable by a decimal point. The exponent indicates the power of ten, with which the existing number needs to be multiplied in order to obtain the value to be represented. The base can have a preceding negative sign (-). The exponent can have a preceding positive or negative sign (+/-). Single underscores ( _ ) between numbers are not significant. (Only between characters, not before or after the decimal point and not before or after "E",

"E+" or "E-")

Example

-1.34E-12 or -1.34e-12

1.0E+6 or 1.0e+6

1.234E6 or 1.234e6

Every direct address is a reference that begins with an indicator, which specifies whether it is an input or an output and whether it is a bit or a word. References that begin with the code 6, represent registers in the extended memory of the state RAM.

0x range = Output/Marker bits

1x range = Input bits

3x range = Input words

4x range = Output registers

6x range = Register in the extended memory

Note: The x, which follows each initial reference type number, represents a fivedigit storage location in the user data memory, i.e. the reference 400201 signifies a 16 bit output or marker word at the address 201 in the State RAM.

register in the extended memory

(6x-reference) remote network

(DIO)

6x references are holding registers in the extended memory of the PLC. They can only be used with LL984 user programs and only with a CPU 213 04 or CPU 424 02.

RIO (Remote I/O)

Remote I/O indicates a physical location of the I/O point controlling devices with regard to the CPU controlling them. Remote inp./outputs are connected to the controlling device via a twisted communication cable.

RTU-Mode

Remote programming in the Modbus Plus network enables maximum performance when transferring data and dispenses with the need for connections. Programming a remote network is simple. Setting up a network does not require any additional ladder logic to be created. All requirements for data transfer are fulfilled via corresponding entries in the Peer Cop Processor.

Remote Terminal Unit

The RTU mode is used for communication between the PLC and an IBM compatible personal computer. RTU works with 8 data bits.

144

33002196

runtime error

Glossary

Errors, which appear during program processing on the PLC, in SFC objects (e.g.

Steps) or FFBs. These are, for example, value range overflows for numbers or timing errors for steps.

S

SA85 module scan section section code section data

The SA85 module is a Modbus Plus adapter for IBM-AT or compatible computers.

A scan consists of reading the inputs, processing the program logic and outputting the outputs.

A section can for example be used to describe the functioning mode of a technological unit such as a motor.

A program or DFB consists of one or more sections. Sections can be programmed with the IEC programming languages FBD and SFC. Only one of the named programming languages may be used within a section at any one time.

Each section has its own document window in Concept. For reasons of clarity, however, it is useful to divide a very large section into several small ones. The scroll bar is used for scrolling within a section.

Section Code is the executable code of a section. The size of the Section Code is mainly dependent upon the number of blocks in the section.

Section data is the local data in a section such as e.g. literals, connections between blocks, non-connected block inputs and outputs, internal status memory of EFBs.

Note: Data which appears in the DFBs of this section is not section data.

separator format

(4:00001)

The first digit (the reference) is separated from the five-digit address that follows by a colon (:).

sequence language (SFC) serial connections

The SFC Language Elements enable a PLC program organization unit to be divided up into a number of Steps and Transitions, which are connected using directional

Links. A number of actions belong to each step, and transition conditions are attached to each transition.

With serial connections (COM) the information is transferred bit by bit.

33002196

145

Glossary

source code file

(Concept-EFB)

The source code file is a normal C++ source file. After executing the Library

→

Create files menu command, this file contains an EFB-code frame, in which you have to enter a specific code for the EFB selected. To do this invoke the Objects

→

Source menu command.

The five-digit address comes directly after the first digit (the reference).

standard format

(400001) standardized literals

If you would like to manually determine a literal's data type, this may be done using the following construction: ’Data type name’#’value of the literal’.

state RAM state RAM overview for uploading and downloading

Example

INT#15 (Data type: integer, value: 15),

BYTE#00001111 (Data type: byte, value: 00001111)

REAL#23.0 (Data type: real, value: 23.0)

To assign the data type REAL, the value may also be specified in the following manner: 23.0.

Entering a comma will automatically assign the data type REAL.

The state RAM is the memory space for all variables, which are accessed via

References (Direct representation) in the user program. For example, discrete inputs, coils, input registers, and output registers are located in the state RAM.

Overview:

Concept Project database

Variables-

Editor

Variables

(Initial values)

State RAM-

Mirror (Image) for loading from and/or loading in Signalmemory

RDE

Editor

status bits

146

U3 D3

PLC-State RAM

0x / 1x / 3x / 4x

D2 U1

For every device with global inputs or specific inputs/outputs of Peer Cop data, there is a status bit. If a defined group of data has been successfully transferred within the timeout that has been set, the corresponding status bit is set to 1. If this is not the case, this bit is set to 0 and all the data belonging to this group is deleted (to 0).

33002196

step step name structured text

(ST) structured variables

SY/MAX

Glossary

SFC-language element: Situation, in which the behavior of a program, in reference to its inputs and outputs, follows those operations which are defined by the actions belonging to the step.

The step name is used to uniquely denote a step in a program organization unit. The step name is generated automatically, but it can be edited. The step name must be unique within the entire program organization unit, otherwise an error message will appear.

The automatically generated step name is always formed as follows: S_n_m

S = step n = Number of the section (consecutive numbers) m = Number of the step in the section (current number)

ST is a text language according to IEC 1131, in which operations, e.g. invocations of Function blocks and Functions, conditional execution of instructions, repetitions of instructions etc. are represented by instructions.

Variables to which a Derived data type defined with STRUCT (structure) is allocated.

A structure is a collection of data elements with generally different data types

(elementary data types and/or derived data types).

In Quantum control devices, Concept includes the preparation of I/O-map SY/MAX-

I/O modules for remote controlling by the Quantum PLC. The SY/MAX remote backplane has a remote I/O adapter in slot 1, which communicates via a Modicon

S908 R I/O System. The SY/MAX-I/O modules are executed for you for labeling and inclusion in the I/O map of the Concept configuration.

T

template file

(Concept-EFB)

TIME

The template file is an ASCII file with layout information for the Concept FBD Editor, and the parameters for code creation.

TIME stands for the data type "time". The entry is time literal. The length of the data element is 32 bits. The value range for variables of this data type extends from 0 to

2exp(32)-1. The unit for the data type TIME is 1 ms.

33002196

147

Glossary

time literals token

Permissible units for times (TIME) are days (D), hours (H), minutes (M), seconds (S) and milliseconds (MS) or combinations of these. The time must be marked with the prefix t#, T#, time# or TIME#. The "overflow" of the unit with the highest value is permissible, e.g. the entry T#25H15M is allowed.

Example t#14MS, T#14.7S, time#18M, TIME#19.9H, t#20.4D, T#25H15M, time#5D14H12M18S3.5MS

The network "token" controls the temporary possession of the transfer right via a single node. The token passes round the nodes in a rotating (increasing) address sequence. All nodes follow the token rotation and can receive all the possible data that is sent with it.

total IEC memory

The total IEC memory consists of the IEC program memory and the global data.

traffic cop

The traffic cop is an IO map, which is generated from the user-IO map. The traffic cop is managed in the PLC and in addition to the user IO map, contains e.g. status information on the I/O stations and modules.

transition

The condition, in which the control of one or more predecessor steps passes to one or more successor steps along a directed link.

U

UDEFB

UDINT

UINT

User-defined elementary functions/function blocks

Functions or function blocks, which were created in the C programming language, and which Concept provides in libraries.

UDINT stands for the data type "unsigned double integer". Entries are made as integer literal, base 2 literal, base 8 literal or base 16 literal. The length of the data element is 32 bits. The value range for variables of this data type extends from 0 to

2exp(32)-1.

UINT stands for the data type "unsigned integer". Entries are made as integer literal, base 2 literal, base 8 literal or base 16 literal. The length of the data element is 16 bits. The value range for variables of this data type extends from 0 to (2exp 16)-1.

148

33002196

unlocated variable

Glossary

Unlocated variables are not allocated a state RAM address. They therefore do not occupy any state RAM addresses. The value of these variables is saved in the internal system and can be changed using the reference data editor. These variables are only addressed using their symbolic names.

Signals requiring no peripheral access, e.g. intermediate results, system tags etc., should be primarily declared as unlocated variables.

V

variables

Variables are used to exchange data within a section, between several sections and between the program and the PLC.

Variables consist of at least one variable name and one data type.

If a variable is assigned a direct address (reference), it is called a located variable.

If the variable has no direct address assigned to it, it is called an unlocated variable.

If the variable is assigned with a derived data type, it is called a multi element variable.

There are also constants and literals.

W

warning

WORD

If a critical status is detected during the processing of a FFB or a step (e.g. critical input values or an exceeded time limit), a warning appears, which can be seen using the Online

→ Event Viewer...menu command. For FFBs, the ENO remains set to

"1".

WORD stands for the data type "bit sequence 16". Entries are made as base 2 literal, base 8 literal or base 16 literal. The length of the data element is 16 bits. A numerical value range can not be assigned to this data type.

33002196

149

Glossary

150

33002196
