Smart MatriX

USER MANUAL

version 4.00

THANK YOU

Thank you for choosing Analog Way. By following these simple steps, you should be able to operate the powerful

Smart MatriX (SMX200)

.

TABLE OF CONTENTS

1

INTRODUCTION

1-1. SMART MATRIX OPERATING MODE

1-2. USEFUL TERMS AND DEFINITIONS

HARDWARE INSTALLATION

2-1. SAFETY INSTRUCTION

2-2. UNPACKING AND INSPECTION

2-3. RACKMOUNT INFORMATION

2-4. CABLE & ADAPTOR INFORMATION

2-5. HARDWARE SPECIFICATIONS

Input specifications

Output specifications

Communication specifications

Environmental specifications

Pin outs

HDCP compliance

CONNECTING THE Smart MatriX

3-1. CONNECTING THE Smart MatriX

3-2. THE Smart MatriX REAR PANEL

Output #1 and #2

Inputs #1 to #6

DVI Inputs #1 and #2

SD/HD-SDI Inputs #1 and #2

Outputs #1 and #2

23

23

24

5

5

6

12

12

7

7

12

13

1

2

OPERATING THE Smart MatriX

4-1. THE Smart MatriX FRONT PANEL

Overview

On/Off button

Menu screen

Menu scroll knob

Control section

4-2. THE Smart MatriX MENU

Menu navigation

Home menu

4-3. WORKING WITH THE Smart MatriX

Operating modes

Reseting default values

Smart MatriX color codes

• Settings in Native Matrix Mode

Source Input selection

Input selection settings

Input Sync. Loss Function

Source Output selection

Output selection settings

Working with Native Matrix Mode

Working with Cut, Fade or Transitions

Working with Layers Functions

Opening transitions & closing Live Layers

Working with PIP

PIP with Transitions & Borders

Working with Mirror Mode

Working with Frames/Logos

Capturing still Frames

Working with Frames

Opening transitions & closing Still Layers

Memorizing Frames

Frame input setup menu

Frames as Layer

Layer transition & effects

Mixer functions

Capturing Logos

Capturing an animated Logo

Memorizing Logos

Logos input setup menu

Working with Logos

Logos as Layer

Working with Presets

Working with Audio

Audio configuration

Special Features

30

31

32

28

28

HOME MENU

REMOTE CONTROL SOFTWARE

5-1. THE Smart MatriX RCS

RCS presentation

How to use the RCS

Software installation

Software overview

Serial connection

Ethernet connection

5-2. WORKING WITH THE RCS

Source input configuration

Source output configuration

Working with PIPs

PIP configuration

Working with Frames

Memorizing Frames

Working with Logos

Memorizing Logos

Layer transitions & effects

Creating Presets

Working with Presets

Working with Audio

Audio configuration

OPTIONAL REMOTE CONTROL SYSTEMS

6-1. AXION 2- Ref. ARC200

6-2. ORCHESTRA - Ref. ORC50

6-3. TRK-800 - Ref. TRK-800

6-4. RK-300 - Ref. RK-300

50

56

56

59

64

64

65

66

67

3

4

EXAMPLES AND TIPS

7-1. ABOUT EXAMPLES

7-2. EXAMPLES

7-3. EXTERNAL PROGRAMMING

WARRANTY AND SERVICES INFORMATION

8-1. ANALOG WAY LIMITED WARRANTY

8-2. SERVICES AND RMA

CONTACT INFORMATION

HOW TO CONTACT US

INFORMATION ON DISPOSAL

71

71

71

70

70

70

68

68

68

69

INTRODUCTION

1-1. THE SMART MATRIX OPERATING MODE

Before you start setting up your

Smart MatriX (SMX200)

for the first time, be sure you know what you actually want to do with it. The

Smart MatriX

offers one operating mode, which results in a versatile video production tool for live event staging and fixed installation applications.

* NOTE * :

We recommend resetting the device to its default values every time you set up your shows or events (see the “

Operating The Smart MatriX

” chapter, p28).

Native Matrix Mode

This mode turns your

Smart MatriX

into a true 12 x 2 High End Scaled Matrix, while preserving seamless switching capabilities. Main and Preview outputs can be set to different resolutions and rates. Switching between any of the inputs can be done with the various effects (Cut, Fade, Slides…) and synchronized on both outputs.

5

6

1-2. USEFUL TERMS AND DEFINITIONS

BACKGROUND:

a “Background” is a source, typically originating from a computer.

Smart MatriX

enables you to work with live or still (frame) background sources - visually in back of all other sources.

LAYER:

a “Layer” is an image display element (such as a PIP window, Key, Logo(s) or Background) that has an associated visual priority — either in front (or in back) of another layer.

The

Smart MatriX

can simultaneously view no less than 4 layers (2 video, 1 frame & 1 logo, per output).

Smart MatriX

can insert up to 2 PIPs on a live background, plus 2 logos.

PIP:

a “PIP” (Picture In Picture), is a picture, typically of reduced size, which is positioned over another background image or PIP. PIPs can be reduced, enlarged and bordered. PIPs can overlap, depending on their visual priority.

Smart MatriX

allows for Dynamic PIP on the opening and closing of the sequence, vertically or horizontally. A

“Flying” PIP is also possible over the screen with vertical, horizontal or diagonal animation. A PIP is considered as a live layer.

FRAME:

a “Frame” is a full screen image which is selected from one of the eight still frames which you can capture with the

Smart MatriX

. A Frame can be flash captured and imported from any video or computer source plugged into the machine.

LOGO:

a “Logo” is a part of screen image that can be flash captured and imported from any Video or

Computer source, by keying or image cut-out.

Smart MatriX

can record up to 8 still logos. They can be positioned anywhere on the screen. An animated logo is also available on the eighth input.

KEYING:

a “Key” is an electronic process whereby an image is electronically superimposed over another source or background, by cutting out either a color (Chroma Key), or its brightness or luminance levels (luma

Key). Keys are typically used for titles, logos and special effects.

Smart MatriX

allows to use a live source with green or blue background and to key it over any other live input.

HARDWARE INSTALLATION

2-1. SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS

CAUTION:

All of the safety and operating instructions should be read before the product is operated and should be maintained for further reference. Please follow all of the warnings on this product and its operating instructions.

WARNING:

To prevent the risk of electric shock and fire, do not expose this device to rain, humidity, intense heat sources (such as heaters and direct sunlight). Slots and openings in the device are provided for ventilation and to avoid overheating. Make sure the device is never placed near a textile surface that could block the openings. Also keep away from excessive dust, vibrations and shocks.

POWER:

Only use the power supply indicated on the device of the power source. Devices equipped with a grounding plug should only be used with a grounding type outlet. In no way should this grounding be modified, avoided or suppressed.

POWER CORD:

The device is equipped with a main switch [On (I) /Off (O)]. The Switch ON and OFF is initiated by the main switch.

Caution:

The power cord constitute the only mean to totaly disconnect the equipment from the main power.

Apply the following guidelines :

- The equipment connected to the network must have a release system easily accessible and located outside the unit.

- Unplug the power cord, do not pull on the power cord but always on the plug itself.

- The outlet should always be near the device and easily accessible.

- Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them.

If the power supply cord is damaged, unplug the device. Using the device with a damaged power supply cord may expose your device to electric shocks or other hazards. Verify the condition of the power supply cords once in a while. Contact your dealer or service center for replacement if damaged.

CONNECTIONS:

All inputs and outputs (except for the power input) are TBTS defined under EN60950.

SERVICING:

Do not attempt to service this product yourself by opening or removing covers and screws since it may expose your device to electric shocks or other hazards. Refer all problems to qualified service personnel.

OPENINGS:

Never push objects of any kind into this product through the openings. If liquids have been spilled or objects have fallen into the device, unplug it immediately and have it checked by a qualified technician.

7

8

INSTRUCTIONS DE SECURITE

Afin de mieux comprendre le fonctionnement de cet appareil nous vous conseillons de bien lire toutes les consignes de sécurité et de fonctionnement de l’appareil avant utilisation. Conservez les instructions de sécurité et de fonctionnement afin de pouvoir les consulter ultérieurement. Respectez toutes les consignes marquées dans la documentation, sur le produit et sur ce document.

ATTENTION:

Afin de prévenir tout risque de choc électrique et d’incendie, ne pas exposer cet appareil à la pluie, à l’humidité et aux sources de chaleur intense.

INSTALLATION:

Veillez à assurer une circulation d’air suffisante pour éviter toute surchauffe à l’intérieur de l’appareil. Ne placez pas l’appareil sur ou à proximité d’une surface textile susceptible d’obstruer les orifices de ventilation. N’installez pas l’appareil à proximité de sources de chaleur comme un radiateur ou une poche d’air chaud, ni dans un endroit exposé au rayonnement solaire direct, à des poussières excessives, à des vibrations ou à des chocs mécaniques. Ceci pourrait provoquer un mauvais fonctionnement et un accident.

ALIMENTATION:

Ne faire fonctionner l’appareil qu’avec la source d’alimentation indiquée sur l’appareil.

Les appareils doivent être obligatoirement connectés sur une source équipée d’une mise à la terre efficace.

En aucun cas cette liaison de terre ne devra être modifiée, contournée ou supprimée.

CORDON D’ALIMENTATION:

Les appareils sont équipés d’un interrupteur général (Marche I / Arrêt

O), la mise en tension et la mise hors tension se fait en actionnant cet interrupteur général.

Attention:

le cordon d’alimentation constitue le seul moyen de débrancher l’appareil totalement de l’alimentation secteur. Pour être certain que l’appareil n’est plus alimenté, ce cordon doit être débranché de la prise murale.

Appliquer les consignes suivantes :

- Le matériel relié à demeure au réseau, doit avoir un dispositif de sectionnement facilement accessible qui doit être incorporé à l’extérieur de l’appareil.

- Débrancher le cordon d’alimentation de la prise murale si vous prévoyez de ne pas utiliser l’appareil pendant quelques jours ou plus.

- Pour débrancher le cordon, tirez-le par la fiche. Ne tirez jamais sur le cordon proprement dit.

- La prise d’alimentation doit se trouver à proximité de l’appareil et être aisément accessible.

- Ne laissez pas tomber le cordon d’alimentation et ne posez pas d’objets lourds dessus.

Si le cordon d’alimentation est endommagé, débranchez-le immédiatement de la prise murale. Il est dangereux de faire fonctionner un appareil avec un cordon endommagé; un câble abîmé peut provoquer un risque d’incendie ou un choc électrique. Vérifiez le câble d’alimentation de temps en temps. Contactez votre revendeur ou le service après-vente pour un remplacement.

CONNEXIONS:

Toutes les entrées et sorties (exceptée l’entrée secteur) sont de type TBTS (Très Basse

Tension de Sécurité) définies selon EN 60950.

RÉPARATION ET MAINTENANCE:

L’utilisateur ne doit en aucun cas essayer de procéder aux opérations de dépannage, car l’ouverture des appareils par retrait des capots ou de toutes autres pièces constituant les boîtiers ainsi que le dévissage des vis apparentes à l’extérieur, risquent d’exposer l’utilisateur à des chocs électriques ou autres dangers. Contactez le service après-vente, votre revendeur ou s’adresser à un personnel qualifié uniquement.

OUVERTURES ET ORIFICES:

les appareils peuvent comporter des ouvertures (aération, fentes, etc...), veuillez ne jamais y introduire d’objets et ne jamais obstruer ses ouvertures. Si un liquide ou un objet pénètre à l’intérieur de l’appareil, débranchez immédiatement l’appareil et faites-le contrôler par un personnel qualifié avant de le remettre en service.

INSTRUZIONI DI SECUREZZA

Allo scopo di capire meglio il funzionamento di questa apparecchiatura vi consigliamo di leggere bene tutti i consigli di sicurezza e di funzionamento prima dell’utilizzo. Conservare le istruzioni di sicurezza e di funzionamento al fine di poterle consultare ulteriormente. Seguire tutti i consigli indicati su questo manuale e sull’apparecchiatura.

ATTENZIONE:

Al fine di prevenire qualsiasi rischio di shock elettrico e d’incendio, non esporre l’apparecchiatura a pioggia, umidità e a sorgenti di eccessivo calore.

INSTALLAZIONE:

Assicuratevi che vi sia una sufficiente circolazione d’aria per evitare qualsiasi surriscaldamento all’interno dell’apparecchiatura. Non collocare l’apparecchiatura in prossimità o su superfici tessili suscettibili di ostruire il funzionamento della ventilazione. Non installate l’apparecchiatura in prossimità di sorgenti di calore come un radiatore o una fuoruscita d’aria calda, né in un posto esposto direttamente ai raggi del sole, a polvere eccessiva, a vibrazioni o a shock meccanici. Ció potrebbe provocare un erroneo funzionamento e un incidente.

ALIMENTAZIONE:

Far funzionare l’apparecchiatura solo con la sorgente d’alimentazione indicata sull’apparecchiatura. Le apparecchiature queste devono essere obbligatoriamente collegate su una sorgente fornita di una efficiente messa a terra. In nessun caso questo collegamento potrà essere modificato, sostituito o eliminato.

CAVO DI ALIMENTAZIONE:

Gli apparecchi con un interrutore (commutatore) generale

(Accesso I : Speuto 0), accendere ou spagnere l’apparecchio si fa usando l’interrutore.

Attenzione:

il cavo di alimentazione è il solo modo di disconnettere l’apparecchio dell’alimentazione.

Per assicurarsi che totalemente l’apparecchio non è più collegato, il cavo deve essere disconesso della presa murale.

Seguire le instruzioni seguenti:

- Il materiale collegato a residenza alla rete, deve avere un dispositivo di sezionamento facile da raggiongere eche deve essere inserito all’esterno del apparecchio.

- Disconnettere l’apparecchiatura dalla presa murale se si prevede di non utilizzarla per qualche giorno.

- Per disconnettere il cavo tirare facendo forza sul connettore.

- La presa d’alimentazione deve trovarsi in prossimità dell’apparecchiatura ed essere facilmente accessibile.

- Non far cadere il cavo di alimentazione né appoggiarci sopra degli oggetti pesanti.

Se il cavo di alimentazione é danneggiato, spegnere immediatamente l’apparecchiatura.

E’ pericoloso far funzionare questa apparecchiatura con un cavo di alimentazione danneggiato, un cavo graffiato puó provocare un rischio di incendio o uno shock elettrico. Verificare il cavo di alimentazione spesso. Contattare il vostro rivenditore o il servizio assistenza per una sostituzione.

CONNESSIONE:

Tutti gli ingressi e le uscite (eccetto l’alimentazione) sono di tipo TBTS definite secondo

EN 60950.

RIPARAZIONI E ASSISTENZA:

L’utilizzatore non deve in nessun caso cercare di riparare l’apparecchiatura, poiché con l’apertura del coperchio metallico o di qualsiasi altro pezzo costituente la scatola metallica, nonché svitare le viti che appaiono esteriormente, poiché ció puó provocare all’utilizzatore un rischio di shock elettrico o altri rischi.

APERTURE DI VENTILAZIONE:

Le apparecchiature possono comportare delle aperture di ventilazione, si prega di non introdurre mai oggetti o ostruire le sue fessure. Se un liquido o un oggetto penetra all’interno dell’apparecchiatura, disconnetterla e farla controllare da personale qualificato prima di rimetterla in servizio.

9

10

SICHERHEITSHINWEISE

Um den Betrieb dieses Geräts zu verstehen, raten wir Ihnen vor der Inbetriebnahme alle Sicherheits und Betriebsanweisungen genau zu lesen. Diese Sicherheits- und Betriebsanweisungen für einen späteren Gebrauch sicher aufbewahren. Alle in den Unterlagen, an dem Gerät und hier angegebenen

Sicherheitsanweisungen einhalten.

ACHTUNG:

um jegliches Risiko eines Stromschlags oder Feuers zu vermeiden, das Gerät nicht Regen,

Feuchtigkeit oder intensiven Wärmequellen aussetzen.

EINBAU:

Eine ausreichende Luftzufuhr sicherstellen, um jegliche Überhitzung im Gerät zu vermeiden.

Das Gerät nicht auf und in Nähe von Textiloberflächen, die Belüftungsöffnungen verschließen können, aufstellen. Das Gerät nicht in Nähe von Wärmequellen, wie z.B. Heizkörper oder Warmluftkappe, aufstellen und es nicht dem direkten Sonnenlicht, übermäßigem Staub, Vibrationen oder mechanischen

Stößen aussetzen. Dies kann zu Betriebsstörungen und Unfällen führen.

STROMVERSORGUNG:

Das Gerät nur mit der auf dem Gerät bezeichnete Stromquelle betreiben. Gerät mit geerdeter Hauptstromversorgung muss an eine Stromquelle mit effizienter Erdung angeschlossen werden. Diese Erdung darf auf keinen Fall geändert, umgangen oder entfernt werden.

NETZKABEL:

Da die Geräte über einen Hauptschalter (An I/ Aus 0) verfügen, erfolgt die Stromversorgung und -unterbrechung über diesen Hauptschalter.

Achtung

: Das Netzkabel stellt die einzige Möglichkeit dar, das Gerät vollständig vom Netzanschluss zu trennen. Um sicherzustellen, dass das Gerät nicht mehr versorgt wird, muss dieses Kabel aus der

Netzsteckdose ausgesteckt werden.

Bitte beachten Sie die folgenden Hinweise:

- Wenn Geräte dauerhaft am Netz bleiben, müssen sie über eine leicht zugängliche Trennvorrichtung verfügen, die außen am Gerät angebracht sein muss.

- Das Kabel mittels dem Stecker herausziehen. Niemals am Stromkabel selbst ziehen.

- Die Steckdose muß sich in der Nähe des Geräts befinden und leicht zugänglich sein.

- Das Stromkabel nicht fallen lassen und keine schweren Gegenstände auf es stellen.

Wenn das Stromkabel beschädigt ist, das Gerät sofort abschalten. Es ist gefährlich das Gerät mit einem beschädigten Stromkabel zu betreiben; ein abgenutztes Kabel kann zu einem Feuer oder Stromschlag führen. Das Stromkabel regelmäßig untersuchen. Für den Ersatz, wenden Sie sich an Ihren Verkäufer oder Kundendienststelle.

ANSCHLÜSSE:

Bei allen Ein- und Ausgängen (außer der Stromversorgung) handelt es sich, gemäß EN

60950, um Sicherheits Kleinspannunganschlüsse.

REPARATUR UND WARTUNG:

Der Benutzer darf keinesfalls versuchen das Gerät selbst zu reparieren, die Öffnung des Geräts durch Abnahme der Abdeckhaube oder jeglichen anderen Teils des Gehäuses sowie die Entfernung von außen sichtbaren Schrauben zu Stromschlägen oder anderen Gefahren für den

Benutzer führen kann. Wenden Sie sich an Ihren Verkäufer, Ihre Kundendienststelle oder an qualifizierte

Fachkräfte.

ÖFFNUNGEN UND MUNDUNGEN:

Die Geräte können über Öffnungen verfügen (Belüftung, Schlitze, usw.). Niemals Gegenstände in die Öffnungen einführen oder die Öffnungen verschließen. Wenn eine

Flüssigkeit oder ein Gegenstand in das Gerät gelangt, den Stecker herausziehen und es vor einer neuen

Inbetriebnahme von qualifiziertem Fachpersonal überprüfen lassen.

INSTRUCCIONES DE SEGURIDAD

Para comprender mejor el funcionamiento de este aparato, le recomendamos que le acuidadosamente todas las consignas de seguridad y de funcionamiento del aparato antes de usarlo. Conserve las instrucciones de seguridad y de funcionamiento para que pueda consultarlas posteriormente. Respete todas las consignas indicadas en la documentación, relacionadas con el producto y este documento.

CUIDADO:

Para prevenir cualquier riesgo de choque eléctrico y de incendio, no exponga este aparato a la lluvia, a la humedad ni a fuentes de calorintensas.

INSTALACIÓN:

Cerciórese de que haya una circulación de aire suficiente para evitar cualquier sobrecalentamiento al interior del aparato. No coloque el aparato cerca ni sobre una superficie textil que pudiera obstruir los orificios de ventilación. No instale el aparato cerca de fuentes de calor como radiador o boca de aire caliente, ni en un lugar expuesto a los rayos solares directos o al polvo excesivo, a las vibraciones o a los choques mecánicos. Esto podría provocar su mal funcionamiento o un accidente.

ALIMENTACIÓN:

Ponga a funcionar el aparato únicamente con la fuente de alimentación que se indica en el aparato. Los aparatos deben estar conectados obligatoriamente a una fuente equipada con una puesta a tierra eficaz. Por ningún motivo este enlace de tierra deberá ser modificado, cambiado o suprimido.

CABLE DE ALIMENTACIÓN:

Los equipos incluyan interruptor general de alimentación (Encender I /

Apagar 0), la puesta en marcha o desconexión se realiza por medio de este interruptor.

El cable de alimentación constituye el único medio de desconectar el aparato totalmente de la red eléctrica.

Para estar seguro de que el aparato no está más alimentado, este cable debe de ser desconectado de la toma de corriente.

Aplicar las siguientes consignas:

- El material conectado a residencia a la red informática, debe de tener un dispositivo de seccionamiento fácilmente accesible que debe de ser incorporado al exterior del aparato.

- Desconectar el aparato del enchufe mural si no piensa utilizarlo durante varios días.

- Para desconectar el cable, tire de la clavija. No tire nunca del cable propiamente dicho.

- El enchufe de alimentación debe estar cerca del aparato y ser de fácil acceso.

- No deje caer el cable de alimentación ni coloque objetos pesados encima de él.

Si el cable de alimentación sufriera algún daño, ponga el aparato inmediatamente fuera de tensión. Es peligroso hacer funcionar este aparato con un cable averiado, ya que un cable dañado puede provocar un incendio o un choque eléctrico. Verifique el estado del cable de alimentación de vez en cuando. Póngase en contacto con su distribuidor o con el servicio de posventa si necesita cambiarlo.

CONEXIONES:

Todas las entradas y salidas (excepto la entrada del sector) son de tipo TBTS (Muy Baja

Tensión de Seguridad) definidas según EN 60950

REPARACIÓN Y MANTENIMIENTO:

Por ningún motivo, el usuario deberá tratar de efectuar operaciones de reparación, ya que si abre los aparatos retirando el capó o cualquier otra pieza que forma parte de las cajas o si destornilla los tornillos aparentes exteriores, existe el riesgo de producirse una explosión, choques eléctricos o cualquier otro incidente. Contacte el servicio de posventa, a su distribuidor o dirigirse con personal cualificado únicamente.

ABERTURAS Y ORIFICIOS:

Los aparatos pueden contener aberturas (aireación, ranuras, etc.). No introduzca allí ningún objeto ni obstruya nunca estas aberturas. Si un líquido o un objeto penetra al interior del aparato, desconéctelo y hágalo revisar por personal cualificado antes de ponerlo nuevamente en servicio.

11

2-2. UNPACKING AND INSPECTION

1 x

Smart MatriX (SMX200)

1 x Power supply cord.

2 x DVI male to HD15 female and DVI-D female

Breakout Cable

1 x HD15 to 5 BNC cable

1 x Ethernet cross cable (for device update)

1 x Set of 11 audio 5 pin screw terminals

1 x RCS - Remote Control Software (PC only) *

1 x User Manual (PDF version) *

1 x Quick Start Guide (PDF version) *

*

Download on our website:

www.analogway.com

2-3. RACKMOUNT INFORMATION

WARNING !

If required, front handles of the device can be dismantled, but with caution.

The original screws removed must not be reintroduced to their location without handles in place.

Substantial damages can occur, including risk of elec tric shock from the mains voltage.

Only

M4x12mm

screws can be used.

(They are supplied with the unit)

Tabletop mounting: The

Smart MatriX

can be used directly on a table, the unit is equipped with 4 handy antislip rubber feet.

Rack mounting : The

Smart MatriX

is compatible with a 19” enclosure. Please follow the instructions below to install the device in a 19” rack.

Place the device in your rack. Attach the device to the rack by using 4 screws through the front panel holes

(screws not included).

Rear fixing is also recommended, in particular for permanent installations. The

Smart MatriX

is equipped with drill holes designed for compatibility with most rackmount braces.

Connect all of the cables of the device and attach them to the rack with the help of tie wraps.

-

-

-

IMPORTANT:

- The openings in the side and rear panels of the device are for cooling. Do not cover these openings to avoid cutting air circulation.

Be sure that no weight in excess of 2 kg (4.4 Lbs.) is added onto the

Smart MatriX.

The maximum ambient operating temperature should not exceed 40°C (104°F).

The rack and all mounted equipment in it must be reliably grounded according to national and/or local electrical standards.

!

Dismantling front handles of the device could invalidate warranty on after sales services of your

Smart MatriX

. It is strongly advised to avoid using front handles as rests for your

Smart MatriX,

they are designed for manipulation purposes only.

If required, front handles of the device can be dismantled, but with caution.The original screws removed must not be reintroduced to their location without handles in place. Substancial damages can occur, including risk of electric shock from the main voltage. Only M4x12mm screws can be used. They are supplied with the unit.

12

2-4. CABLE AND ADAPTOR INFORMATION

A large choice of cables and adaptors are compatible with the

Smart MatriX

. To find which are to be used in your setup, please refer to the Hardware Specifications chapter. Please contact your distributor for a list of available cables and connectors for your

Smart MatriX.

2-5. HARDWARE SPECIFICATIONS

Description of the input formats supported by the device.

• SDTV

Standard

NTSC

PAL

SECAM

Size

525/480i

625/576i

625/576i

Frame Frequency

59.94Hz / 60Hz

50Hz

50Hz

• EDTV

Standard

480p

576p

Size

525/480i

625/576i

• HDTV (RGB or YUV)

Standard

720p

1035i

1080i

1080p

1080sF

1080p

Size

1280x720

1920x1035

1920x1080

1920x1080

1920x1080

1920x1080

Frame Frequency

59.94Hz / 60Hz

50Hz

Line Frequency

15.735 KHz

15.625 KHz

15.625 KHz

Line Frequency

31.47 KHz

31.25 KHz

Frame Frequency

50Hz / 59.94Hz / 60Hz

59.94Hz / 60Hz

50Hz / 59.94Hz / 60Hz

Standard

SMPTE 296M

SMPTE 260M

SMPTE 274M

23.97Hz / 24Hz / 25Hz / 29.97Hz / 30Hz SMPTE 274M

50Hz / 59.94Hz/60Hz SMPTE 274M

50Hz / 60Hz HDTV

8

9

10

11

12

• INPUT FEATURES

4

5

6

2

3

Inputs

1

7

Format

SDTV

EDTV

HDTV

Computer

SDTV

EDTV

HDTV

Computer

SDTV

HDTV

Signal

Analog SDTV

Analog EDTV

Analog HDTV

Analog Computer

Digital SDTV (Except SDI)

Digital EDTV

Digital HDTV (Except SDI)

Digital Computer

Digital SDTV

(SDI only)

Digital HDTV

(SDI only)

Connector

HD15#1

HD15#2

HD15#3

HD15#4

DVI#1: ANALOG PART

DVI#2: ANALOG PART

DVI#1: DIGITAL PART

DVI#2: DIGITAL PART

BNC#1

BNC#2

BNC#3

BNC#4

YES

NO

NO

NO

NO

EDID

YES

YES

NO

NO

NO

NO

YES

13

14

• COMPUTER FORMATS

The

SMX200

recognizes the following computer formats (Subsampled formats will be displayed with a de graded quality. For a pixel clock > 165 MHz).

Format

VGA

1366x768

DILA4/3

SWXGA+

SXGA+

900p RGB

1600x900

UXGA

WSXGA+

1080p RGB

WUXGA

1920x1440

2K

QXGA

800x480

SVGA

WVGA

XGA

1152x864

1280x600

720p RGB

WXGA

800p RGB

960p RGB

SXGA

SWXGA

1360x1024

Size

640x480

1366x768

1364x1024

1366x800

1400x1050

1440x900

1600x900

1600x1200

1680x1050

1920x1080

1920x1200

1920x1440

2048x1080

2048x1536

800x480

800x600

848x480

1024x768

1152x864

1280x600

1280x720

1280x768

1280x800

1280x960

1280x1024

1360x768

1360x1024

Reduced Blankings

YES

YES

YES

Subsampling

YES

YES

• EDID

The EDID is available on inputs #1 & #2 and #7 & #8. The user can modify the EDID choosing from a list of predefined formats and frequencies.

SETTINGS AND INPUT FUNCTIONS

Settings / Functions

Auto Settings

Auto Framing

Blanking Settings

Cropping

Optimization

Under/Overscan

Aspect Ratio Settings

Aspect Input Output

Color Settings

Advanced settings

2:2 Pulldown

3:2 Pulldown

1 2 3

Analog

4 5 6 7

DVI-D

8

YES YES YES YES YES YES YES YES

YES

1

YES

1

YES

1

YES

1

YES

1

YES

1

NO NO

YES YES YES YES YES YES NO NO

YES YES YES YES YES YES YES YES

YES

1

YES

2

YES

1

YES

2

YES

1

YES

2

YES

1

YES

2

YES

1

YES

2

YES

1

YES

2

NO

YES

2

NO

YES

2

YES YES YES YES YES YES YES YES

YES YES YES YES YES YES YES YES

YES YES YES YES YES YES YES YES

YES YES YES YES YES YES NO NO

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

YES

3

YES

4

1/ Analog Computer Input or Analog Video Input (EDTV or HDTV only)

3/ Only interlaced 50 Hz

9

N/A

YES

YES

YES

NO

YES

3

YES

4

NO

NO

YES

NO

YES

2

10

N/A

YES

YES

YES

NO

YES

3

YES

4

NO

NO

YES

NO

YES

2

2/ Only Vidéo Input

SDI

11

N/A

YES

YES

YES

NO

YES

3

YES

4

NO

NO

YES

NO

YES

2

4/ Only interlaced 59.94 Hz to 60 Hz

12

N/A

YES

YES

YES

NO

YES

3

YES

4

NO

NO

YES

NO

YES

2

Input specifications

• ANALOG COMPUTER

Connectors: Inputs #1 to #4: female HD15. Inputs #5-#6: female DVI-I

(analog pins).

Line frequency: Up to 130 kHz (165 MHz Max pixel rate).

Resolution:

Levels:

Sync. types: RGBHV, RGB/S, RGsB (Sync On Green).

Impedance:

Up to 1600x1200 @ 165Mhz, 1920x1200px

(RB, Max V size: 1200px, Max H size 2048px).

R, G, B = 0.7 Vp/p.

H & V Sync = TTL.

Composite Sync = TTL and 0.3 V (negative).

SOG (Sync On Green) = 0.3 V.

R, G, B = 75 ohms.

H = 75 ohms or Hi-Z.

V = Hi-Z.

• RGB/S - RGsB VIDEO

Connectors: Inputs #1 to# 4: female HD15. Inputs #5-#6: female DVI-I (analog pins).

Frequency:

Levels:

Impedance:

15.625 kHz - 50 Hz (625 lines).

15.734 kHz - 60 Hz (525 lines).

R, G, B = 0.7 Vp/p.

SYNC. = 0.3 Vp/p or TTL (negative).

RGB = 75 ohms.

SYNC. = 75 ohms or Hi-Z.

• COMPONENT

Connectors: Inputs #1 to #4: female HD15. Inputs #5-#6: female DVI-I (analog pins).

Frequency:

Levels:

Impedance:

Input #8: female HD15.

15.625 kHz - 50 Hz (625 lines).

15.734 kHz - 60 Hz (525 lines).

Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).

Cr / Pr & Cb / Pb = 0.7 Vp/p.

75 ohms.

or or or

• HDTV - HD-YUV

Connectors: Inputs #1 to #4: female HD15. Inputs #5-#6: female DVI-I

Formats:

Levels:

Sync.:

Impedance:

(analog pins).

720p/576p (60Hz), 1080i (50/60Hz), EDTV,

1080p (50/60Hz Reduce Blanking)

Y = 1 Vp/p (0.7 V + sync.).

Cr / Pr & Cb / Pb = 1 Vp/p (0.7 V + sync.).

Tri-level: ±0.3V (positive/negative).

Bi-level: 0.3V (negative).

75 ohms.

or

15

16

• AUDIO

Input

#

1

2

9

10

11

12

AUX

6

7

8

3

4

5

• S.VIDEO

Connectors: Inputs #1 to #4: female HD15. Inputs #5-#6: female DVI-I

Standard:

Levels:

Impedance:

(analog pins).

PAL/SECAM: 15.625 kHz - 50Hz - 625 lines.

NTSC (3.58 - 4.43 MHz): 15.734 kHz/60Hz/525 lines.

Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).

C = 0.3 Vp/p (Chroma Burst).

75 ohms.

• COMPOSITE VIDEO

Connectors: Inputs #1 to #4: female HD15. Inputs #5-#6: female DVI-I

(analog pins).

RCA.Standard: PAL / SECAM: 15.625 kHz - 50 Hz - 625 lines.

Level:

Impedance:

NTSC (3.58 - 4.43 MHz): 15.734 kHz/60 Hz/525 lines.

1 Vp/p (0.7 V Luma + 0.3 V Sync.).

75 ohms.

• DVI (Digital Video Interface)

Connector: DVI Inputs #1-#2: female DVI-I (digital pins).

Line frequency: Up to 130 kHz (165 MHz Max pixel rate).

Format:

Resolution:

Digital Visual Interface (DVI)-TMDS single link.

Up to 1600x1200 @ 165Mhz / 1920x1200px

(RB, Max V size: 1200px, Max H size 2048px).

• SD-SDI

Connector:

Format:

Data rate:

Impedance:

SDI Inputs #1 to #4: female BNC.

SMPTE 259M-C.

270 Mbps serial digital.

75 ohms.

• HD-SDI

Connector:

Formats:

Data rate:

Impedance:

SDI Inputs #1 to #4: female BNC.

720p @ 50 / 59.94 & 60 Hz.

1035i @ 50 / 59.94 & 60 Hz.

1080i @ 50 / 59.94 & 60 Hz.

1080p @ 23.97 / 24 / 25 / 29.97 / 30 / 50 & 60 Hz.

1080sF @ 50 / 59.94 & 60 Hz.

1.5 Gbps serial digital - SMPTE 292M.

2.97 Gbps serial digital - SMPTE 425M.

75 ohms.

Stereo

YES

Balanced Audio

YES

Connector

or or

Connectors Phoenix 5 pins

Non applicable (Embedded Audio SDI) Non applicable (Embedded Audio SDI)

YES Connectors Phoenix 5 pins

AUDIO SETTINGS

Settings

GAIN

Balanced Audio

Availability

YES: from -

to + 18dB

YES: Left and Right

• Connector:

Balanced or unbalanced mono/stereo inputs

(all pin MCO male connector).

8 audio stereo inputs + 1 auxiliary.

(all balanced / unbalanced).

Vi = +15dBV max.

Zi = 40 Kohms (Balanced).

MCO male connectors

Inputs #1 to #6: Balanced & unbalanced connection

Inputs DVI #1 to DVI #2: Balanced & unbalanced connection

Input AUX: Balanced & unbalanced connection

4

LEFT

L+

L-

GROUND

RIGHT

R+

R-

UNBALANCED

Output specifications

Outputs #1 to #2: Balanced & unbalanced connection

4

L+

L-

GROUND(S)

R+

R-

R+

R-

BALANCED

Reduced Blanking

• ANALOG OUTPUTS

Connector: Outputs #1 (

Main

) & #2 (

Preview

): female HD15, DVI-I (analog pins).

Resolutions:

FORMAT

640 x 480

800 x 600

848 x 480

1024 x 768

1280 x 720

1280 x 768

1280 x 800

1280 x 1024

1360 x 768

1366 x 800

1400 x 1050

1440 x 900

1600 x 1200

1680 x 1050

1920 x 1080

1920 x 1080 B

1920 x 1080 C

1920 x 1080 HD

1920 x 1200

2048 x 1080

RATIO

Available Refresh Rates

4 : 3 50Hz 60Hz 72Hz 75Hz

4 : 3

16 : 9

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

4 : 3

16 : 9

15 : 9

16 : 10

5 : 4

16 : 9

15 : 9

4 : 3

16 : 10

4 : 3

16 : 10

16 : 9

16 : 9

16 : 9

16 : 9

16 : 10

19 : 10

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

YES

YES

YES

YES

YES

YES or

Signals:

Levels:

Impedance:

RGBHV, RGBS and RGsB.

R, G, B = 0.7 Vp/p.

Sync. : Separate H & V = TTL (negative).

Composite = TTL (negative).

SOG = 0.3 Vp/p (negative).

R, G, B = 75 ohms.

17

• DVI (Digital Video Interface) OUTPUTS

Connector: Outputs #1 & #2: female DVI-I (digital pins).

Signal: Digital Visual Interface (DVI)-TMDS single link.

Resolutions:

Format

640 x 480

800 x 600

848 x 480

1024 x 768

1280 x 720

1280 x 768

1280 x 800

1280 x 1024

1360 x 768

1366 x 800

1400 x 1050

1440 x 900

1600 x 1200

1680 x 1050

1920 x 1080

1920 x 1080 B

1920 x 1080 C

1920 x 1080 HD

1920 x 1200

2048 x 1080

5 : 4

16 : 9

15 : 9

4 : 3

16 : 10

4 : 3

16 : 10

16 : 9

Ratio

4 : 3

4 : 3

16 : 9

4 : 3

16 : 9

15 : 9

16 : 10

16 : 9

16 : 9

16 : 9

16 : 10

19 : 10

Refresh Rate

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz 72Hz 75Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

50Hz 60Hz

Reduced Blanking

YES

YES

YES

YES

YES

YES

• AUDIO OUTPUT

Connector: Output #1 and #2: 2 Balanced or unbalanced mono/stereo outputs (on 5-pin MCO male connector).

Vo max: Unbalanced = +15dBu (at 300Ω load)

Balanced = +21dBu (at 600Ω load)

Zo = 600Ω balanced

Zo = 300Ω unbalanced

G = 0 dB nominal

Outputs #1 to #2: Balanced & unbalanced connection

4

GROUND(S)

R+

R-

BALANCED

L+

L-

R+

R-

18

The video output generates a SDI signal in which is embedded only one stereo audio stream.

Settings

Gain

Balanced Audio

Auxiliary Input Mixing

Adjusting Audio Delay

Availability

Yes: from ∞ to+18dB

Left and Right

Yes

Yes: from 0 to 80ms (Automaticaly or Manual)

• VIDEO OUT

Connector:

Impedance:

Formats:

Data rate:

1x BNC-F: SD/HD-SDI (with audio embedded).

3x BNC-F: Y_Cb_Cr.

1x Mini Din 4: S. Video.

1x BNC-F: Composition video PAL/NTSC.

75 ohms.

720p @ 50 / 59.94 & 60 Hz.

1035i @ 59.94 & 60 Hz.

1080i @ 50 / 59.94 & 60 Hz.

1080p @ 23.97 / 24 / 25 / 29.97 / 30 / 50 & 60 Hz.

270Mbps serial digital - SMPTE 259M-C.

1.54 Gbps serial digital - SMPTE 292M-A.

2.97 Gbps serial digital - SMPTE 425M-A.

Communication specifications

• COMMUNICATION PORTS

REMOTE RS-232

Connector: DB 9 female.

Protocol: RS-232.

Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control by default.

DTR & RTS needed for upgrade.

• LAN

Connector: RJ45.

Protocol:

Ethernet:

TCP (Transmission Control Protocol) or UDP.

(User Datagram Protocol).

Base 10/100.

19

20

Environmental specifications

Dimensions: W 480 x D 330 x H 88 mm

Weight:

19”W x 13”D x 3.50”H

5.4 kg / 10.90 lbs

(Compatible with a Standard 19” rack, Height = 2 U).

Cooling air flow from right side to left side.

Max ambient operating temperature: < +40°C (< 104°F).

Operating temperature: 0 to +40°C / +32°F to +104°F.

Storage temperature:

Operating humidity:

Input voltage range:

-25 to +85°C / -13°F to +185°F.

10 to 80% (non condensing).

100-240 VAC, 50/60 Hz.

Typical consumption: 90 W.

CE Compliancy, test following:

- EN 55022: 2006 / A1: 2007,

- EN 55024: 1998 / A1: 2001 / A2: 2003,

- EN 61000-3-2: 2006,

- EN 61000-3-3: 1995 / A1: 2001 / A2: 2005.

Safety, test following:

- IEC 60950-1: 2005,

- Ul 60950-1: 2007,

- CAN/CSA-C22.2 NO. 60950-1.

Power supply: IEC/EN/UL/CSA 60950-1, internal, autoswitching.

Mechanical (in carton): Vibration: IEC60068-2-64.

Free fall: IEC60068-2-32.

RoHS, WEEE.

Pin outs

• VGA

STANDARD VGA

1- Red

2- Green

3- Blue

4- ID Bit 2

5- Test (Gnd)

6- Red Return

7- Green Return

8- Blue Return

9- No Pin

10- Sync Return

11- ID Bit 0

12- ID Bit 1

13- H Sync

14- V Sync

15- ID Bit 3

• DIGITAL VISUAL INTERFACE DVI

Pin

1- TMDS Data 2- 7- DDC Data

2- TMDS Data 2+ 8- Analog Vertical Sync

3- TMDS Data 2 Shield 9- TMDS Data 1-

4- Not used

5- Not used

6- DDC Clock

10- TMDS Data 1+

11- TMDS Data 1 Shield 17- TMDS Data 0-

12- Not used

13- Not used

14- +5V (Power)

15- Ground for (+5V)

16- Hot Plug Detect.

18- TMDS Data 0+

C1- Analog Red Video (or Cr/Pr or C)

C2- Analog Green Video (or Y or Composite Video)

C3- Analog Blue Video (or Cb/Pb)

C4- Analog Horizontal Sync (or Composite Sync)

C5- Analog Common Ground Return

DDC = Display Data Channel

TMDS = Transition Minimized differential signal

• RS-232 CONNECTOR

Pin

1- NC

2- Transmit data to PC (Tx1)

3- Transmit data from PC (Rx1)

4- Receive data from display unit (Rx2)

5- Ground

6- NC

7- NC

8- NC (or +12V. dc)

9- Transmit data to display unit (Tx2)

• S-VIDEO (Y/C) CONNECTOR - 4-pin Mini Din

Pin

1- Y Ground

2- C Ground

3- Y Signal

4- C Signal

• VESA DDC

Pin

1- Red

2- Green

3- Blue

4- ID Bit 2 0

5- Test

6- Red Return

7- Green Return

8- Blue Return

9- DDC+5 Volt supply

10- Sync Return

11- ID Bit

12- Bi-directional data (SDA)

13- H Sync

14- V Sync

15- Data Clock (SCL)

19- TMDS Data 0 Shield

20- Not used

21- Not used

22- TMDS Clock Shield

23- TMDS Clock +

24- TMDS Clock-

21

22

HDCP compliance

If you want to use HDCP content from your sources, be sure pluging HDCP compliant screens or projectors.

If it’s not the case, the output image could be disabled.

When displaying HDCP protected sources on non HDCP compliant equipment, the following message will be displayed on the device VFD screen:

“Due to HDCP content, non HDCP screens cannot display protected sources”

Your screen will go to black without displaying the HDCP input image, or partially layer out non HDCP content.

Concerning the DVI inputs, a specific feature allows enable/disable the HDCP receiver for the input chosen.

It can be very useful especially when using a Mac:

Input Menu > DVI# > HDCP detection

The output status can provides you all information about the output in real time.

This feature is particularly needed when HDCP is used with long cable to be sure that the communication is well handled.

Don’t forget that HDCP content can be displayed only through Digital link like DVI.

The SDI and the HD15 output don’t support the HDCP protection.

!

NOTE :

as part of our policy of continuous improvement, Analog Way reserves the right to make design and specification changes for product improvements without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

CONNECTING THE SMART MATRIX

3-1. CONNECTING THE SMART MATRIX

The

Smart MatriX

can be set up with up to 12 different sources, and will drive up to 2 digital DVI-D sources,

2 SD-SDI sources and 8 analog computer/video sources simultaneously. The versatility of the

Smart MatriX

will allow for almost any event configuration and cater for all your projection needs.

The intuitive rear panel of the

Smart MatriX

will let you set up for the first time quickly and easily. Here is an example of a typical

Smart MatriX

setup.

23

3-2. THE SMART MATRIX REAR PANEL

Outputs #1 and #2

The

Smart MatriX

rear panel is equipped with 12 universal digital and analog inputs. Inputs #1 through #4

(3) are universal analog inputs. Inputs #5 & #6 share a DVI-D signal and a universal analog signal (plug the included Analog Way DVI/HD15 adaptor cable to use DVI-D and analog signals simultaneously).

The outputs (6) will allow for the

Smart MatriX

high resolution digital and analog signals to be viewed on screen and/or on a preview monitor (see also Output Specifications in this chapter).

The extra Video Out card installed on the

Smart MatriX

, can be used for recording, broadcasting or previewing purposes in a wide range of formats for maximum compatibility with industry viewing or recording equipment.

Finally, the audio in and output card will let users mix audio with any source, accurately balance or tweak sound sources and outputs.

1 : AC outlet and on/off switch

2 : IP-LAN connector

3 : Universal Computer/TV/HDTV inputs

4 : DVI-D inputs

5 : HD-SDI inputs

6 : Analog and DVI outputs #1 & #2

7 : SD-HD/SDI output

8 : SD/HDTV output

9 : Audio inputs

10 : Audio outputs

11 : RS-232 connector

12 : Serial #

12 2 9

5

7 8

24

1 11 3 4 6 10

Inputs #1 to #6

UNIVERSAL COMPUTER & VIDEO INPUTS:

Universal Inputs accept computer sources (RGBHV, RGBS, and RGsB (SOG) signals), standard TV/VIDEO sources

(Composite video, S.VIDEO), Component video (YUV,

RGBS & RGsB (SOG)), and HDTV sources (480p, 720p &

1080i).

HD15: 1x Universal Analog input on female HD15 connector.

Analog Computer Sources

COMPOSITE VIDEO SOURCES:

The Composite Video signal, usually called COMPOSITE or VIDEO, is available on most video equipment (VCR,

DVD, CAMCORDER…), but is also the lowest in picture quality. The video standard of this signal can be NTSC, PAL or SECAM. The signal is transmitted on a single coaxial cable, and is connected to the video equipment with an

HD15 connector.

For inputs #1 to #4: connect a 1x BNC from your composite source, to the HD15 input of the device.

G

S.VIDEO SOURCES:

The S.VIDEO signal, also called Y/C, HI-8™, or S.VHS™, is available on DVD players and high quality VCRs (S.VHS).

The S.VIDEO signal in which the Luminance (Y) and

Chrominance (C) information are separately transmitted, gives a higher quality picture than the Composite video signal. The S.VIDEO connector is usually a 4-pin Mini-DIN connector also called Oshiden™ connector.

For inputs #1 to #4: connect a 2x BNC from your S.VIDEO,

Y (G/Y) & C (R/R-Y), to the HD15 input of the device.

Composite Source

R G

COMPONENT VIDEO SOURCES:

The Component Video signal, also called YUV

(Y, Pr, Pb) or BETACAM™ is widely used in broadcasting and is available on high-quality DVD players. The COMPONENT signal is transmitted with

3 coaxial cables, and also has a better quality picture than

COMPOSITE and S.VIDEO signals. The COMPONENT connectors are usually RCA (x3), or BNC (x3).

For inputs #1 to #4: connect a HD15 to 3x BNC cable between the HD15 connector of the device and your

Component source.

R

S.Video Source

G B

Component (YUV) Source

25

COMPUTER SOURCES:

The device accepts the following computer signals: RGBHV,

RGB/S and RGsB on inputs #1 to #6.

RGBS VIDEO SOURCES:

This signal is widely used in broadcasting and is available on European DVD player. The RGB/S signal is transmitted with 4 coaxial cables, and also has a better picture quality than COMPOSITE and S.VIDEO signals. The RGB/S connectors are usually BNC connectors for Broadcasting equipment, and SCART connector for DVD players.

For inputs #1 to #4: connect a HD15 to 4x BNC cable between the HD15 connector of the device and your

RGB/S source.

R G B

S

RGBS Source

DVI Inputs #1 and #2

DVI & ANALOG SOURCES :

DVI Inputs # 1# 2 on the

Smart MatriX

accept up to 2 live sources in Digital format.

DVI-I: 1x digital (DVI) and 1x analog input on female DVI-I universal connector.

For analog sources, please use the breakout cable supplied.

Analog Computer Sources

26

SD/HD-SDI Inputs #1 and #2

SD/HD-SDI SOURCES :

SD/HD-SDI Inputs # 1- # 2 on the

Smart MatriX

accept up to 2 live sources in Digital formats.

SD/HD-SDI: 1x digital input on female BNC connector.

Outputs #1 and #2

OUTPUTS #1 and #2:

ANALOG: 1x analog output for the main display device on female HD15 connector.

DIGITAL/ANALOG: 1x main output on female DVI-I connector

(simultaneous analog and digital).

BNC

HD/SDI Source

VIDEO OUTPUT:

Video Output card provides SD or HDTV formats in various signals and connectors from Composite Video to

HDSDI. This output can be used to record your show by outputting the same content as the Main output in

Mixer Mode, or a choice between output 1 or 2 in Matrix Mode (see also

Smart MatriX

M ode, p.5).

As it’s a video output (Analog & Digital), the video output can not display HDCP content.

AUDIO SWITCHER:

Audio Stereo Switcher card features 12 inputs and 2 outputs. An additional auxiliary input can be mixed with any other input. Master Volume and individual input level can be adjusted. Each input and output offers balanced or unbalanced connections. It should be noted that the management of the audio output follows the selection of video layers. Two modes are available: Top Follow or Breakaway. In Top Follow Mode, the audio follows the topmost video layer (after having pressed TAKE). In Breakaway Mode, it is the selected audio layer input that is permanently diffused.

Video Output

Audio Switcher

Output #1

Output #2

27

OPERATING THE SMART MATRIX

4-1. THE SMART MATRIX FRONT PANEL

Overview

The highly intuitive front panel of the

Smart MatriX

was designed by Analog Way engineers to simply and quickly meet all of your event needs. Within minutes, you will be able to enjoy its full potential and easily parameter most of its functions, without having to be an expert audio-visual engineer, leaving room for what is most important to our users: concentrating on their event.

The

Smart MatriX

front panel is comprised of several sections, each carefully labelled and self explanatory, corresponding to all the machine’s versatile functions.

1 : Standby button

2 : Menu screen

3 : Menu scroll knob

4 : Control section

2 3

28

1 4

On/Off button

The STANDBY button allows users to put the

Smart MatriX

into sleep mode, and startup again. The STANDBY button does not replace the ON/OFF switch at the rear of the unit, and is implemented essentially for ease of use in rackmount situations.

--

> Hold for 3 seconds for stand-by mode

Menu screen

The Menu Screen of the

Smart MatriX

is the visual interface to your

Smart MatriX

menu. It gives users a constant indication of available menu options, parameters of any selected object, system information, and everything you need to know to control the device.

Menu scroll knob

The Menu scroll knob allows users to quickly scroll through menu items and increase or decrease any modifiable value in the

Smart

MatriX

menu. Simply scroll to the desired menu item, and press the

ENTER button to confirm your choice.

The

ENTER

Function is also available by pressing the scroll Knob.

Control section

The EXIT/MENU button and the ENTER button in the Control section of the

Smart MatriX,

allow users to respectively enter and exit the

Smart MatriX

menu, and confirm selected menu items.

29

4-2. THE SMART MATRIX MENU

Menu navigation

To access the

Smart MatriX

Menu, press the EXIT/MENU button in the control section (4). To highlight items in the menu which will appear on the VFD screen (2), turn the scroll knob (3) left or right to the desired menu item. When you have reached the desired menu item, press the ENTER button in the control section (4) to access that menu function. Pressing the ENTER button when a selection has been made sets the value to that selection in the

Smart MatriX

memory. When all settings have been made, press the EXIT/MENU button to exit sub-menus and return to the main menu.

!

Simply selecting a menu item will not set it to that value. Be sure to press the ENTER button when parametering the menu items or to push the scroll knob.

30

Home menu

Pressing the MENU button in the menu section of the

Smart MatriX

, will display and give you access to the following items on the menu VFD screen:

- INPUT: select to configure the 12 individual input types and resolutions.

- OUTPUT 1: in Matrix mode, select to set the output types and resolutions of Output # 1.

- OUTPUT 2: in Matrix mode, select to set the output types and resolutions of Output # 2.

- VIDEO OUT: select to configure Video output card settings.

- PRESET: select to store and use presets.

- AUDIO : select to access all audio input and output parameters.

- CONTROL: select to access device software information, LAN settings, reset factory settings, amongst

other user oriented functions.

4-3. WORKING WITH THE SMART MATRIX

Operating modes

The

Smart MatriX

offers 1 mode to work from: the Native Matrix mode , which turns your

Smart MatriX

into a true 12 x 2 scaled matrix with numerous Live effects and PIPs and logos.

Reseting default values

It is strongly recommended that you reset all of the default values of your

Smart MatriX

unit before setting up your shows and events. To do so, press the EXIT/MENU button and select

Control

in the menu by rotating the corresponding knob. Then press the ENTER button to enter the

Control

sub-menu. Select

Default Values

by rotating the scroll knob, and press the ENTER button to enter your choice to restart your

Smart MatriX

with its factory settings. This operation should take approximately 30 seconds.

Smart MatriX

color codes

Analog Way

engineers have developed a handy, user friendly way of identifying machine status on the front panel, via the use of color codes on the buttons of the machine. All new Analog Way machines use the same codes, for quick recognition of the status of any device of the range, at any given time.

Solid green:

Dim red:

Function available for modification

Stand-by button

31

SETTINGS IN NATIVE MATRIX MODE

The advanced features of SMX200 are available by the external remote control as:

-

-

-

-

-

Remote Control Sofware - Ref. RCS (supplied)

Remote Control Keypad - Ref. RK-300

Triple Remote Control Keypad - Ref. TRK-800

Orcherstra - Ref. ORC50

Axion2 - Ref. ARC200

Source Input selection

Plug your sources thanks to the 6 universal inputs, 2 DVI-I Inputs or 4 SDI inputs.

Don’t forget that the 2 DVI-I inputs can be used with DVI-D computer sources (DVI #1 & DVI #2) but also with a DVI-A adaptor for analog sources too (source #5 & # 6) shipped with your unit.

Be sure that all connectors are firmly attached using all available locking screws.

32

Input selection settings

To set up your inputs:

Input menu → Auto settings

You can also do it manually on each input# using the ENTER and the Knob button and set up the inputs type one by one.

You can also check your actual input configuration using the config status:

Input menu → Config Status

You can find several settings for each input (some settings are specific to some signal type):

-

-

-

-

-

-

Type:

EDID:

to set up your input type (Computer,

Enabled/disabled:

Audio input:

to enable/disable input#

to set up the EDID in terms of resolution and rate

Status:

to summarize the input status

V ideo etc..)

to set up the audio regarding the input

H Sync. load:

to change the load of the Sync. signal (Hi-Z, 75 ohms)

Concerning the DVI inputs, a specific feature allows enable/disable the HDCP receiver for the input chosen.

It can be very useful especially using a Mac:

Input menu → DVI # → HDCP detection

* NOTE * : The input status is available at any time in status input menu and can give you information about format rate and HDCP.

Input Sync. Loss Function

Allows to display a frame or a source in case of sync loss of the selected input. To set up the Sync. Loss function:

Menu → Control → Sync. Loss → Press Input# or Enabled

The selected input must be activated for being visible in case of sync loss.

Source output selection

Once your inputs all have been configured, the output settings of the

Smart MatriX

must be set according to the machines plugged on your

Smart MatriX

main and preview outputs (video projector, preview monitor...).

* NOTE * :

If you want to use HDCP content from your sources, be sure to attach HDCP compliant screens or projectors. If it’s not the case, the output image could be disabled.

Output selection settings

To set up the outputs, go in the

Output #1

or

Output

#

2

menu and choose first the appropriate format/resolution, and then the appropriate rate for your screens by using the knob button and the

Enter button.

Output# → Output Format → Output rate

Use the native resolution of your screens/projectors in order to obtain the best image quality.

In the

Output

#

2

menu, you can also synchronise all the changes from the

Output

#

1

to the

Output

#

2

by checking the case

Sync. w/Out 1

. It allows you to set up both outputs at the same time.

Output 2 → Sync. w/Out 1

Some other settings are available too:

- The Output synch polarity.

- The Gamma: use this feature to set up the output Gamma.

- Flicker Filter (

Video Out only): apply a flicker filter on your video output.

- Analog type: set up the type of synchronisation of your Analog output.

- DVI type: set up the type of color place of your Digital output.

- HDCP detection: set up to enable/disable the HDCP detection on the output.

- Background colour: add a background colour in place of the default black one.

- Test pattern: use test pattern on

M

ain or

Preview screen to configure your projectors.

*All changes have to be validated by pressing the

ENTER

button in order to be saved*

* NOTE *:

The output status can provide you all information about the output in real time. This feature is particularly needed when HDCP is used thanks to the HDCP status.

33

34

Video Out

In Matrix M ode, the menu “

Connection Mode

” appears. It allows you to choose recording Output # 1 or

Output # 2.

Display Mode Presentation

OUT #1

Availability

Output #1

YES

Output #2

YES

OUT #2

Display Mode

Output #1 & #2 side by side

Menu→ Video Out → Connection →

Output Titled Horizontally

Presentation

OUT #1

OUT #2

Availability

Matrix Mode only

Output #1 & #2 Top and Bottom

Menu→ Video Out → Connection →

Output Titled Vertically

OUT #1

Matrix Mode only

OUT #2

Working with Native Matrix Mode

T

o activate the N ative Matrix M ode:

Mode Menu → Native Matrix M ode Menu

You’ll find all menus from the Mixer M ode in the Main menu except some specific matrix functions added.

To work with native matrix mode, you have to use the Matrix # buttons first.

For instance, if you want to put the Frame #1 on the Output #1 and the Live source #3 on the Output #2:

Press Matrix #1 button → Press Background Frame button → Press input #1

Press Matrix #2 button → Press background L ive button → Press input #3

Press Take to view the result on both screens

Don’t forget to press the correct Matrix # button before pressing the Layer selection button, in order to be sure doing the manipulation on the correct output.

Working with Cut, Fade or Transitions

All the transitions (Cut, Fade or Transistions) are available in the native Matrix M ode. Although the Matrix

Mode is activated, you will be able to perform powerful transition effects seamlessly. It can depend on your configuration.

The

Smart MatriX

has 4 scalers, to understand how your effect will be performed, you need to know how many scalers are used on your outputs. Don’t forget that you always need one free scaler to perform clean transition. Example:

1 background live on each output → 2 scalers used → 2 seamless transitions

1 background line on each output + 1 PIP on output #1 → 3 scalers used → 1 seamless transition available only on output #2 but the output #1 with a background live + 1 PIP will not be seamless transition (ie: Fade through black)

1 background frame on each output + 2 PIP on each outputs → 4 scalers used →

NO

seamless transition (ie: fade through black)

The background Frame and the logos are not considerated as live layers and are not counted as using a scaler.

Working with Layers Functions

Once a source attached to a layer, you will have access to some layer settings in the layer menu or directly by pressing the layer button.

The settings available depend on the layer selected:

-

-

-

-

-

-

-

Layer adjusts:

Layer zoom:

Transparency:

Border:

Smooth move:

Status:

set up layer size and position.

set up layer zoom size and position.

adjust the Layer transparency.

choose the border and adjust its properties.

Opening and Closing effect: adjust the Open/Close effect type and duration.

enable/disable smooth move.

get the selected layer status.

*All changes have to be validated by pressing the Ok button in order to be saved*

Press Take to view the result on the main screen.

Settings available:

Settings

Position

Size

Zoom

Transparency

Border

Opening effects

Closing effects

Smooth Move

H Flip / V Flip

Background Live / PIP#1

YES

YES

YES

YES

YES

YES

YES

YES

YES

PIP#2

YES

YES

YES

YES

YES

YES

YES

YES

YES

PIP#3

YES

YES

YES

YES

YES

YES

YES

YES

YES

35

-

-

-

-

-

-

Even the Logo and Frame buttons can access to their own settings, but a source # has to be affected too.

The Main output can displayed simulteaneously up to 6 layers stacked from bottom to top as follows:

The Background Frame: One stored frame selected from 8 available,

The Background Live/PIP#1: One source selected from 12 inputs available,

The PIP#2: One source selected from 12 inputs available,

The PIP#3: One source selected from 12 inputs available,

The Logo#1: One stored logo selected from 8 available,

The Logo#2: One stored logo selected from 8 available.

Opening transitions and closing Live Layers

When transitioning live layers, depending on how many scalers are in use, the

SMX200

TAKE function will act in one of 3 different ways when transitioning the Next Preset (Preview) to the Current Preset (Main):

• Take 1- shot: Case #1

- There are enough scalers for making a transition

- All inputs are locked on to scalers

- There are no constraints for closing

before

the Take

- All opening and closing transitions can be performed simultaneously.

• Take 2- shot: Case #2

- There are enough scalers for making a transition

- All inputs are locked on to scalers before the Take

- There are no constraints for closing

during

the Take

- All the necessary closing transition are performed to free occupied scalers and then the

SMX200

performs all openings.

• Take sequenced- shot: Case #3

- There are not enough scalers for making a transition

- All inputs are not locked on to scalers

- All the necessary closing transitions are performed to free occupied scalers. The

SMX200

locks on to new sources and performs all openings.

36

Working with PIP

The PIPs are used in the same way as other units. A source has to be selected to activate the PIP settings.

Each PIP has its own settings, PIP 1 on output # 1 is not linked to PIP 1 on output # 2 in terms of settings.

* NOTE * :

Take a look at the blinking of the Matrix M ode button to always know on which output you are working on.

All PIP settings are available in the Layer menu once the PIP is selected.

PIPs with Transitions & Borders

Transitions:

All the settings are available in the

Layer Menu

after pressing the selected PIP.

The transition effects have some shortcut on the front panel too.

To Use it:

Press the selected PIP# → Press the Cut, Fade, User

#

1 or User

#

2 button

The effect will be immediately attached to the selected PIP.

Concerning the User 1 and User 2 button, they have to be set up before in the

Control menu → Prog. Keys

Fade

- Adjustable pre-timed fades or manual transition with T-Bar

- Fade between any input, computer or video

- Adjustable cross-fading duration

Wipe

- Numerous wipes can be selected horizontal and vertical, from the center or outside, in circle, Zoom in and out

- Horizontal: from left, center -or- vertical: from up, down, center

Slide

- Sliding of video or computer images during the transition

- Horizontal: from/to left, -or- vertical: from/to up, down

Working with Mirror Modes

The Mirror Matrix Mode is a specific Matrix M ode where the output # 2 will be the perfect mirror copy of the output # 1. In that way, each settings apply to output # 1 will be performed on the output # 2 too.

Mode Menu → Native Matrix mode menu → Mirror Mode

To use the Mirror Mode, just perform your setting and operation from the Matrix output # 1.

Nevertheless, you can do manipulation on the output # 2 at any time.

For a perfect use, set up the output format and rate for the output # 2 as for the output # 1 using the synchronise button:

Output

#

2 → Sync w/Out 1

37

38

Using the Matrix Mode, several configuration are available, the Simple M ode and the M irror M ode.

Using the Mirror Mode:

To use the M irror M ode, simply select the Matrix M ode through the M ain menu, then the M irror M ode can be activated layer by layer thanks to the layers menu.

Select the chosen layer and go in the layer menu, then select the “Layer Copy Mode” menu.

There are several mirror positioning options:

For the ❶, ❷, ❸ & ❹ modes:

Red case: Mirror

M

ode activated only for the PIP layer

Blue case: Mirror

M

ode activated for PIP layer and Background live Layer

1- No Copy:

this mode is the standard matrix mode, output # 1 and # 2 are independent...

OUTPUT #1 OUTPUT #2

OUTPUT #1 OUTPUT #2

2-

Clone mode:

The output #1 and #2 will be the same. All changes on the output #1 will be affected to the output #2. Layers will have the same position and size.

OUTPUT #1 OUTPUT #2 OUTPUT #1 OUTPUT #2

3-

Copy & H.pos Flip mode:

the output #2 will be exactly the same as the output #1 except the fact that the selected layer will have its H position flipped (standard Mirror mode).

OUTPUT #1 OUTPUT #2 OUTPUT #1 OUTPUT #2

4- Copy&H.Flip all modes:

the output #2 will be exactly the same as the output #1 except the fact that the selected layer will have its H position and data flipped.

OUTPUT #1 OUTPUT #2 OUTPUT #1 OUTPUT #2

*NOTE*:

Remember that to simplify the use of this feature, you need to manipulate the Output #1. While in mirror mode, the Output #2 will follow the desired steps.

*NOTE*:

Every change on the Output #2 will have an effect only on the Output #2, but remember that if a change occurs on the Output #1 after that, the Output #2 will update automatically to match output #1 (in mode 2/3/4).

39

40

Working with Frames/Logos

The Frame/Logo can be memorized from

Output #1 or #2

. To record a F rame/ logo, please refers to the chapter “Capturing still Frame/Logo” in the Mixer M ode.

To use a Frame/Logo, refer to “Working with Frame/Logo”.

As a source, each frame/logo can be used by both outputs, you just have to select the correct matrix# button first.

Capturing still Frames

To capture a frame, display the exact content you want to save on one of your output, at the exact resolution, you can use the freeze button if you want. Then follow this step (choose first the source to capture in the menu Logos/Frames --> capture sources):

Logos/Frames menu → record Frame menu→ Frame #

Select the frame number you want to save and wait until the unit finish saving. Your frame is now saved and you can use it through the background frame button.

The capture of frames can be done only under the following conditions:

-

-

-

The unit can be in Matrix Mode,

The capture can be done the Main output or the Preview output,

The disappearance of frames on the Preview and Main output is normal.

A frame captures the state of the specified output at the main output resolution, and must be recalled using the same output resolution. Resizing or other image manipulation of the captured frame is not possible.

The captured output is outlined by a white border and includes the pixels beneath the white border.

Working with Frames

It is possible to store up to 8 frames in the

SMX200

non volatile memory. Frames are mainly used as backgrounds in a typical show or event setup, and can be recorded from any of the

SMX200’

12 sources and called back at the press of a single button. To use a frame, be sure first that it is well saved, then:

Press Background Frame button → Press Frame # button

* NOTE * :

Frames may be used only one at a time and cannot be placed in a layer.

Opening transitions & closing Still Layers (Logos or Frames)

When transitioning still layers, depending on how many scalers are in use, the

SMX200

TAKE function will act in one of 2 different ways when transitioning the Next Preset (Preview) to the Current Preset (Main):

• Take shot: #1

- All still frames make an opening and closing phase.

- All sources of the same layer are completely different between the Current Preset and the Next Preset. The opening and closing effects of the layer are set to Cut.

• Take shot: #2

- One of the layer makes a change of source which be not in Cut.

- The opening and closing phases can be done with different effects.

- The still frame appears and disappears of the layer with the following effects: Cut, Fade, Slide or Wipe.

Memorizing Frames

The

SMX200

can memorize up to 8 frames from any resolution

(see Capturing Still Frames)

.

1. In the Input Selection section, press the source button ( # 1 to # 12) of the source you wish to record as a frame. The source button will start blinking. Press the TAKE button to display that source on the main display.

2. Select Logos/Frames in the menu by rotating the scroll knob, then press the ENTER button. Select the output you want to record in capture source menu.

3. Select

Record Frames

in the

Logo/Frames

menu by rotating the scroll knob, then press the ENTER button. A white rectangle will appear on your main display or your Preview, indicating the frame which will be captured. Select an empty frame memory (empty frames are indicated in the sub-menu) to store the frame into. Press the corresponding ENTER button.

4. The

SMX200

will display a progress status bar on the VFD screen. Your frame is stored when the menu reappears on the VFD screen.

5. Press the BACKGROUND FRAME button, select the frame number ( # 1 to # 8) you just recorded, and press the TAKE button. Your background frame will appear on your preview output.

Frame input setup menu

In the frame input setup menu, you have the possibility to save a frame, and the possibility to erase a stored frame to:

Logos/Frames menu → save Frame → Frame #

Logos/Frames menu → Erase → Frame #

41

42

Frames as Layer

The background frame is considered as a layer and has some settings available:

Transparency, Opening/Closing effect, Smooth move and Status.

Those settings have to be used as layer settings.

Press background frame button to have access to the Layer menu settings.

You can change frame or delete frame on the preview screen using the same way the layers do:

Delete: Press background frame button → Press Black

Change: Press background frame button → Press another Frame #

Press Take to view the result on the main screen.

Layer transitions & effects

The

SMX200

offers a wide variety of transitions between the scenes you create for your shows and

events. It allows for live recall of 4 user presets, each of which you can edit at any given time.

1.

Whether catering for complex event setups, or putting together intricate shows, your

SMX200

will also deliver some of what you could expect from a dedicated mixer, along with its switcher

and scaler capabilities.

2.

In the Layer Selection section, press the PIP1 button. The button will start blinking. On your Preview screen, PIP1 will appear as a color rectangle. The parameters of the layer will automatically

appear on your

SMX200

VFD menu screen.

3.

In the

Layer

Menu, make the position, size, border and transparency settings you like, then

select

Opening Effect

in the layer options, press the ENTER button and select

Type

. Select

Slide

Left - Right

for example, and press the ENTER button to confirm. Navigate to

Duration

in the

Opening Effect

sub-menu, and set the duration of your effect by rotating the SCROLL knob and pressing ENTER.

Repeat the procedure in the

Closing Effect

sub-menu to determine the way your layer will close. Try

Slide From Left - Right

for the closing type with a duration of 1.5 seconds for example.

Mixer functions

In Multi Layer Mixer Mode, the

SMX200

offers a variety of mixer type transitions, including wipes, fades, and cuts. The transitions, transition times and fade/wipe effects can all be setup through the

SMX200

layer menu.

Capturing Logos

To capture a Logo, display the exact content you want to save on the main screen, you can use the freeze button if you want. Then follow these steps:

Logos/Frames menu → Record Logo menu → Set up your logo →Store menu → logo#

To set up your logo you have several features available:

-

-

-

-

Position / Size Adjustment

Keying type

Luma / Chroma key

Cut out color.

Select the logo number you want to save and wait until the unit finish saving. Your logo is now saved and you can use it through the background logo button.

You can save up to 8 logos with the SMX200.

The capture of logos can be done only with the following conditions:

- The unit can be in Matrix Mode

- The capture can be done on the Main output or the Preview output

- The disappearance of logos on the Preview and Main output is normal.

The logos are captured with the same size that the Main output without any form of adjustment.

A logo captures the state of the defined area on the specified output at the Main output resolution, and must be recalled using the same output resolution. Resizing or other image manipulation of the captured logo is not possible.

The capture zone is outlined by a white rectangle and includes the pixels beneath the white border. The noncaptured area is reduced in brightness.

Logo capture is limited in the number of pixels being captured. When the logo capture area is resized, extending the horizontal size may reduce the vertical size to compensate.

Logos can also be captured and displayed with transparent areas. By adjusting the keyer in the logo capture menu, the portions of the captured area can be keyed away and captured as transparent.

The logo “Cut out color” can help display which portions of the image will be captured as tranparent.

* NOTE *:

The cut out color is only a visual tool to help identify the transparent areas of the logo. These colored regions will be captured and later displayed as transparent area.

* NOTE*:

Capturing a “logo” is limited to a small percentage of the output resolution. To capture and display a full screen image, use the still “Frame”.

43

44

Capturing an animated Logo

To capture animated Logo, display the exact content you want to save on the main screen, you can use the freeze button. Then follow this step:

Logos/Frames menu → Record Anim menu → Set up your Anim →Store menu → logo#

To set up your anim, you have several features available:

-

-

-

-

-

Position / Size Adjustment

Keying type

Luma / Chroma key

Recording time

Cut out color

Select the anim logo #8 and wait until the unit finishes saving. Your animation is now saved and you can use it through the background logo button.

Only one Animated logo can be saved in the SMX200.

Memorizing logos in the SMX200

1. In the Input Selection section, press the source button (#1 to #12) of the source you wish to record as a logo. The source button will start blinking.

2. Select the

Logos/Frames

menu by scrolling through the menu with the scroll knob, then pressing the

ENTER button.

3. Select

Record Logos

in the

Logos/Frames

menu by rotating the scroll knob, then pressing ENTER. A small white rectangle will appear on your main display, indicating the logo that will be captured.

4. Adjust logo size, position, and fine tune key attributes by rotating the scroll knob and pressing ENTER to memorize logo settings.

5. Select an empty logo memory (empty logos are indicated in the sub-menu) to store the logo into. Press the ENTER button. The

SMX200

will display a progress status bar on the VFD screen.

6. In the Layer Selection section, press the LOGO # 1 button, and select logo number (#1 to #8) you wish to use. Your logo will appear on the preview screen above any existing layer on screen.

Logos input setup menu

In the Logos/frames menu, the logos can be deleted in the erase menu:

Logos/Frames menu → Erase menu → Select Logo#

Working with Logos

A simple or animated Logo can be manipulated thanks to the front panel. On the front panel, the logo# are associated to the input# respectively. To affect a logo# to the logo layer:

Press Logo1 Layer button → Press Input#

Logos #1 to #6 are available directly by the input # button on the front panel. For logo #7 and #8, you have to use the Shift button first:

Press Logo1 Layer button → Press Shift button → Press Input#

(for logo #7 or #8 use Shift then Input# button)

You can change logos or delete logos on the preview screen using the same way the layers do:

Delete: Press Logo (#1 or #2) button → Press Black

Change: Press Logo (#1 or #2) button → Press another Input#

Logos as Layer

logos are under the layer rules, you will have access to settings directly by pressing the logo layer button.

You have 2 layers logo button available.

You can use the Pos/Size/Zoom adjustment button and the Effect button from the front panel too.

Working with Presets

The four user presets of the

SMX200

can be called back at any stage during your show or event.

1. Press the PRESET button, then press one of the four first Input Selection section buttons to choose which memory (#1 to #4) you wish to use. The preset will be displayed on your preview screen.

2. Once you have selected your preset, simply press the TAKE button to view the result on your main screen.

Creating Presets

The

SMX200

allows the creation of user defined presets very easily. Any setup you have configured on screen, can be stored into one of the 8 available user presets.

1. After having configured Layers, PIP transitions, logos... on your screen (see Working with the

SMX200

, p.31), go to the

Preset

menu by pressing the EXIT/MENU button, and select

Preset

by rotating the scroll knob. Then, press the ENTER button to enter the

Preset

sub-menu. Choose

Preset Copy

by scrolling with the corresponding knob, and press the ENTER button to access the sub-menu.

2. In the sub-menu, choose

Save From Main

or

Save From Preview

to determine which screen you want to memorize the preset from, then set the preset memory (#1 to #8) you wish to use as your “User Preset”

(by default, the

SMX200

will choose the next available preset in the

SMX200

memory).

3. By pressing the ENTER button, the

SMX200

will ask you to confirm. Select

Yes

, your screen is memorized as a preset.

Working with Audio

The

SMX200

allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 embedded SDI audio inputs

(via the SDI BNC connectors), all accessible via the

Audio

menu of the

SMX200

, and which can be affected to one or both of the 2 independant symetrical/asymetrical outputs of the device.

45

Audio configuration

To configure audio settings of the

SMX200

, plug all audio inputs into the device, and navigate to the

Audio

menu.

1. Choose the audio mode,

Break Away

or

Top Layer Follow

, which you wish the audio to work in.

* NOTE * :

the

Break Away

mode will route the selected audio source, while the

Top Layer Follow

mode will route audio from the topmost active layer of the

SMX200

.

2. Select

Source Settings

from the

Audio

M enu to select the audio source you wish to work with, then set levels and left/right balance for each input.

3. Select

Auxiliary Settings

to determine level and balance of the auxiliary input.

4. In Matrix Mode, all output parameters can be assigned separately to outputs #1 and #2.

5. In Matrix Mode, select

Out1 Prelist

or

Out2 Prelist

from the Audio menu to set audio pre-listen output parameters.

6. Select

Delay Mode

, to determine how the

SMX200

deals with audio delay. Select

Auto Adjust

to let the

SMX200

determine audio output delay. Select

Manual Adjust

to determine audio delay manually.

* NOTE * :

selecting

Manual Adjust

will give access to audio delay value (in milliseconds) of the main and

Prelist audio output M enus.

Special Features

Dynamic Fit

(automatically activates the Transparent Background)

- Dynamic & Automatic adjustment of the PIP to fit the source image borders (Black Stripe).

46

PIP

- Automatic adjustment of the PIP (Ratio) to fit the source image borders during a transition.

Transparent Background

- Transparent Background allows you to remove the black band on the sources in the background live layer in order to display behind a background frame or background color.

Background Frame

Image Live

Smooth Move effect

- Smooth Move (PIP) control the acceleration of the PIP. The time can be different between the opening and closing PIP.

47

48

Working with DSK (Chroma / Luma key)

DSK Mode must be used with remote controllers specifically designed to control the SMX200.

- SMX200 allows to use a live source with green or blue (or any color) background and to key it over another live input.

- Background is removed and replaced by another source.

- Title can be keyed (DSK) on Analog or Digital Sources.

+ =>

To use K eying, first select a source in the desired layer:

Layer button -

>

source number button

Then in the main menu, select the Keying/Titling menu.

You now have several choices to key your sources. The luma Key and the Chroma Key based on the luma pixel values and the Chroma pixel values and for both an additional Titling menu which can be useful to choose the transparency value of your keying.

Keying/Titling menu -

>

Type menu -

>

Select your keying type

Once your keying mode is selected, the

Smart MatriX

provides you some keying advance setting:

For Luma Key

:

Luma Keying is used to key from a particular luminous intensity. It produces a hard edged key based on intensity, which is most suitable for titling effects. You can choose to key things that are extremely dark or extremely bright and keep everything in between, or invert to key only things that are of a me dium intensity.

The black and white levels define where to begin the keying. In the range 0 to 255, 0 represents no luminance, or black and 255 represents full luminance, or white.

-

Level Black:

As the Black Level is changed from 0 to 255, things that are black are first keyed out, followed by dark grey, then light grey, and so forth, until the entire picture is keyed out at 255.

-

Level White:

As the White Level is changed from 255 to 0, things that are white are first keyed out, followed by light grey, then dark grey, and so forth, until the entire picture is keyed out at 0.

Non-Inverted Mode

Keyed Away

Visible Picture

Keyed Away

Black level White level

For Chroma Key

:

Chroma Keying is used to key from a particular color. It produces a soft-edged key which is most suitable for moving images and “weatherman” style applications.

Color grabber:

Select Chroma Key menu -

>

Select Color grabber menu

Using a crosshair, you can select a particular hue based on what is on screen. Once you have adjusted the crosshairs to a desired position, press set/enter to capture the color value at that instant. You can then adjust the other parameters such as Tolerance to further refine your key.

Manual Setting:

Select Chroma Key menu -

>

Manual Settings menu

R,G,B

:

These controls allow you to manually select a hue, defined by its Red, Green, and Blue values as you can find in Windows (Paint software).

Tolerance:

The Tolerance parameter allows you to expand your key color selection to include colors which are similar to the selected value. A tolerance of 1 will select only the desired hue, whereas a tolerance of

255 will select nearly all hues.

Black Level:

This option permits adjustment of the luminance levels of the keyed hue. The Black Level is the lumi nance lower bound. Colors in the selected hue range with a luminance brighter than the Black level but darker than the White level will be considered part of the key.

White Level:

This option permits adjustment of the luminance levels of the keyed hue. The White Level is the lumi nance lower bound. Colors in the selected hue range with a luminance brighter than the Black level but darker than the White level will be considered part of the key.

Titling alpha:

If you have selected one of the two Titling mode, the titling menu appears.

This option places a transparent black backdrop behind the entire layer to which the key is applied. This effect is useful for using bright titles on bright backgrounds, such as clouds.

Invert keying:

By default, this mode is disabled. When this mode is activated, the key selection will remain on screen, and all other portions of the image will be keyed away. For example, you would see the green screen behind the actor, while the actor would be keyed away.

49

50

HOME MENU

MATRIX MODE

[OUT 1]

Format : 1920 x 1080

Rate : 50Hz

lock : internal

| OUT 1 | OUT 2

---------+--------------+----------

logo1 | Logo #1

|

Logo #8

live | Input 1

|

SDI 4

Frame

| Frame 1 | Frame 8

[OUT 2]

Format : 1920 x 1080

Rate : 50Hz

lock : internal

INPUT

Config status

Autoset all

Synchronized

Input 1 Analog

Input 2 Analog

Input 3 Analog

Input 4 Analog

Input 5 Analog

Input 6 Analog

DVI 1

DVI 2

SDI 1

SDI 2

SDI 3

SDI 4

(i1) displayed when plug is not SDI

(i2) displayed when type is analog video

(i3) displayed when plug is analog

(i4) displayed for input ln1, ln2, ln8, DVI1

& DVI2

Analog Group 1

Analog Group 2

Analog Group 3

Type

(i11)

Autoset

(i11)

(i10) displayed when plug is not DVI-D

(i11) displayed when plug is analog

Input 1

Input 2

Input 3

Input 4

Input 5

Input 6

SDTV Composite

(i11)

SDTV Y/C

(i11)

SD/ED/HD RGBS

(i11)

SD/ED/HD RGsB

(i11)

SD/ED/HD YUV (i11)

Computer SOG

(i11)

Computer HV/C

(i11)

Computer RW

(i11)

Computer 0-255

(i10)

Computer 16-235

(i10)

DVI video RGB

(i10)

DVI video YUV

(i10)

Enabled

Auto

NTSC

PAL

PAL_M

Audio input

None

Audio Input 1

Audio Input 2

Audio Input 3

Audio Input 4

Audio Input 5

Audio Input 6

Audio DVI 1

Audio DVI 2

Audio SDI 1

Audio SDI 2

Audio SDI 3

Audio SDI 4

left

Right

VCR Mode

HDCP enable (i10)

H sync load

(i3)

EDID

(i4)

Status

Hi-Z

75 Ohms

Edit EDID

640x480

852x480

800x600

1280x720

1024x768

1280x768

1360x768

1200x800

1366x800

1440x900

1280x960

1280x1024

1364x1024

1400x1050

1680x1050

1920x1080

2048x1080

1600x1200

1920x1200

50Hz

60Hz

72Hz

75Hz

85Hz

Group A - Ch 1

Group A - Ch 2

Group A - Ch 3

Group A - Ch 4

Group B - Ch 1

Group B - Ch 2

Group B - Ch 3

Group B - Ch 4

Group C - Ch 1

Group C - Ch 2

Group C - Ch 3

Group C - Ch 4

Group D - Ch 1

Group D - Ch 2

Group D - Ch 3

Group D - Ch 4

51

52

OUTPUT 1

OUTPUT 2

Sync w/OUT 1

(o1)

Output status

Output format

Output rate

640x480

800x600

848x480

1024x768

1280x720

1280x768

1280x800

1280x1024

1360x768

1366x800

1400x1050

1440x900

1600x1200

1680x1050

1920x1080

1920x1080

1920x1080

1920x1080

1920x1200

2048x1080

Internal ref

15/9

4/3

16/10

4/3

16/10

16/9

HD

B

4/3

4/3

16/9

4/3

16/9

15/9

16/10

5/4

16/9

C

16/9

19/10

(o1) only for Preview out/Output2

(o2) depending on output format

(o3) computer & HDTV only

(o4) Interlaced output only

Follow x 1/2

Follow x1

Follow x2

Follow x3

23.97 Hz

(o2)

24 Hz

(o2)

25 Hz

(o2)

29.97 Hz

(o2)

30 Hz

(o2)

50 Hz

(o2)

59.94 Hz (o2)

60 Hz

(o2)

72 Hz

(o2)

75 Hz

(o2)

Frame lock from

Input 1 Analog

Input 2 Analog

Input 3 Analog

Input 4 Analog

Input 5 Analog

Input 6 Analog

DVI 1

DVI 2

SDI 1

SDI 2

SDI 3

SDI 4

Video out

Out Sync Polarity

H-, V-

H-, V+

H+, V-

H+, V+

Gamma

Flicker filter

(o4)

Analog Type

DVI Type

HDCP Detection

Background color

Test Pattern

RGB HV

RGBS

RGsB (SOG)

YUV

RGB full (0-255)

RGB (16-235)

YUV

Disabled

Automatic

Predefined color

Hue

Saturation

luma

OFF

V Grey scale

H Grey scale

V Color bar

H Color bar

Grid

SMPTE

Burst (o3)

Centering

VIDEO OUT Connection Output 1

Output 2

Output Tiled Horizontally

Output Tiled Vertically

Output status

Output format

SDTV PAL

SDTV NTSC

EDTV 480p

EDTV 576p

HDTV 720p

HDTV 1035i

HDTV 1080i

HDTV 1080p

HDTV 1080 sF

Output rate

23.97 Hz

(o2)

24 Hz

25 Hz

(o2)

(o2)

29.97 Hz

30 Hz

(o2)

(o2)

50 Hz (o2)

59.94 Hz

60 Hz

(o2)

(o2)

H Pos

V Pos

H Size

V Size

Gamma

Flicker Filter

Sharpness

Under/Overscan

Test Pattern

OFF

V Grey scale

H Grey scale

V Color bar

H Color bar

Grid

SMPTE

Burst

(o3)

Centering

PRESET

Preset mgmt

(p1) Both Outputs

Current Output

Output 1

Output 2

Step Back

Save Preset

Save from

Save to

Load Preset

Save from

Save to

(o1) available in near future

(o2) according to output format

(p1) available only on Matrix Mode

Main

Preview

Memory 1

Memory 2

Memory 3

Memory 4

Memory 5

Memory 6

Memory 7

Memory 8

Main

Preview

Memory 1

Memory 2

Memory 3

Memory 4

Memory 5

Memory 6

Memory 7

Memory 8

53

54

AUDIO Mode

Source settings

Breack away

Toplayer follow

Input 1

Input 2

Input 3

Input 4

Input 5

Input 6

DVI 1

DVI 2

SDI 1

SDI 2

SDI 3

SDI 4

Aux. setting

Audio Main

(m1)

Audio Out 1

(m2)

Audio Out 2

(m2)

level

Balance

Master Mute

Master Volume

Stereo

Audio Delay

OUT1 Prelist

(m2)

OUT2 Prelist

(m2)

Source

level

Balance

None

Input 1

Input 2

Input 3

Input 4

Input 5

Input 6

DVI 1

DVI 2

SDI 1

SDI 2

SDI 3

SDI 4

(m1) Available only on Mixer Mode

(m2) Available only on Matrix Mode

level

Balance

Delay Mode

Auto Adjust

Manual Adjust

CONTROL Versions

(L1) UDP only

(L2) Confirmation asked

(L3) Only for User 1 & User 2

(L4) Visible if Sync. Loss is activated

RS232/LAN

LAN setup

Vers.: 3.00 BETA

l1=xxxx l2=xxxx

l3=xxxx l4=xxxx

0=xxxx

MM K=xxxx

MF K=xxxx

CA V=xxxx

FA V=xxxx

TH V=xxxx

CS V=xxxx

RS232

LAN

TCP

UDP

Sync. loss

Enabled

Input 1

(l4)

Input 2

(l4)

Input 3

(l4)

Input 4

(l4)

Input 5 (l4)

Input 6

(l4)

DVI 1

(l4)

DVI 2

(l4)

SDI 1 (l4)

SDI 2

(l4)

SDI 3

(l4)

SDI 4

(l4)

Auto lock

Auto TAKE

Preset Toggle

V-TBar enable

Transp Backgr

Dynamic fit

Freeze mode

Key locking

Prog. Keys

Input freeze

Freeze all

All

Menus

Fade

User 1

User 2 lCD brightness

Key brightness

Standby

Baud rate

Set message ON

Set message OFF

Clear message ON

Clear message OFF

Standby

Reset Layers

Erase Memories

(l3)

Default values

(l3)

Device address...

Remote address

(l1)

Gateway address...

Device port...

(l1)

Remote port

Netmask...

Default setup (l2)

Type (l3)

Direction

(l3)

Effect duration

55

56

REMOTE CONTROL SOFTWARE

5-1. THE SMART MATRIX RCS

RCS presentation

The RCS will give you a powerful tool to exploit all the features of your

SMX200

at distance. By LAN, or RS-

232, you will be able to do exactly the same manipulation as you could do from the front panel. User-friendly and easy-to-use, you will take the hand quickly with it.

How to use the RCS ?

You have to install the software on a Computer and have a LAN board or RS-232 link to use the RCS. After the installation, launch the program and proceed to the network establishment.

Software installation

1. Connect you on

www.analogway.com

.

2. In the menu, select [ Technical Support ] menu, then click on [ Remote Control Software ], select the name of your device and click on [ Download ].

3. Click on [ Open with ] or [ Register the file ], select the

.exe

file.

4. Follow the Windows installation instructions.

Software overview

The RCS software for your

Smart MatriX

is composed of several easily identified sections. The tabs menu allows you to navigate through the equivalent of the

Smart MatriX

front panel menu items (see also “The

Smart MatriX

Menu” p.30). The green window of the RCS represents your Preview window, and can be used to parameter sources, frames, layers and logos directly by clicking on the corresponding button, then navigating through the different available tabs. The red window of the RCS represents your Main window, and can also be used much like the front panel of the

Smart MatriX.

Create user presets directly in the RCS main window by clicking on one of the four available Preset icons and setting up your preset in the Preview window. Clear unwanted steps with the clear button, reload a fresh copy of your screen via the Reload Main button, make smooth takes directly with your mouse or trackpad with the virtual

T-bar. The Take button will allow you to view any change made to your P review screen on your main screen.

Analog Way

engineers have even implemented a Stepback button to quickly move back to your previous setup in the case of a manipulation error. The status section allows for easy monitoring of the connection status.

The RCS software for your

Smart MatriX

can be viewed as the software version of the

Smart MatriX

front panel menu section. It allows you to quickly access all of the

Smart MatriX

functions via a single page interface, and easily edit your settings directly from your laptop or PC.

Before starting with the RCS software, you must establish a connection from your laptop to the

Smart MatriX

you wish to run.

57

58

Serial connection

1. Connect a RS-232 cable between the

Smart MatriX

and your PC, then power on your devices.

2. Click on the RCS program file on your PC to run the software.

3. Click on the “Connections” tab and select RS-232 as the connection type. In the drop-down menu, select the COM port number corresponding to the connected device (default is Port 1).

4. Click apply, and wait for devices to synchronize. The RCS will display the following connection message:

“Device Connected”.

5. Click on the “Connections” tab to return to the main screen.

Ethernet connection

1. Connect a crossed RJ45 cable between the

Smart MatriX

and your PC, then power on your devices.

Use straight RJ45 if connecting through a network switcher.

2. Click on the RCS program file on your PC to run the software.

3. Click on the “Connections” tab and select LAN as the connection type.

4. In the “Remote Address” field, enter the IP address of the

Smart MatriX

you wish to control (see also

“Working with the

Smart MatriX

”, p.31).

5. In the “Remote Port” field, enter the remote port number of the

Smart MatriX

you wish to control (see also “Working with the

Smart MatriX

”, p. 31).

6. Click Apply, and wait for devices to synchronize. The RCS will display a connection message.

7. Click on the “Connections” tab to return to the main screen.

5-2. WORKING WITH THE RCS

Source input configuration

Once your

Smart MatriX

is wired up to your PC, the first step in properly configuring your machine is to individually select and parameter your inputs.

1. Click on the “Inputs” tab of the RCS.

2. In the Plug column of the “Input” page, select the plug type by clicking the appropriate field.

3. Activate the input in the Enabled column if it is not.

4. In the scroll-down menu of the Type column, select the signal type connected to that plug.

5. Repeat steps 2 to 4 for all sources connected to the rear panel of your

Smart MatriX.

6. Click on the “Inputs” tab to return to the main screen.

Source output configuration

1. Click on the “Outputs” tab of the RCS.

2. Select the type of plug which is connected to outputs # 1 &

# 2 of your

Smart MatriX

by clicking in the appropriate field in

Analog Type or DVI Type for both Main and Preview outputs.

3. Select the appropriate output format and output rate.

4. Click on the “Outputs” tab to return to the main screen.

The

Output

menu also allows you to generate test patterns. The test patterns available through the

Output

menu let you quickly and reliably setup your projectors.

* NOTE * :

Be sure to turn the test pattern off to display your sources again.

59

60

Working with PIPs

The

Smart MatriX

allows users to manipulate 2 PIPs (Picture In Picture) which you can move, size, crop or zoom, apply transparency or transitions to.

PIP configuration

1. Click on the


tab of the RCS interface. The empty


screen will appear on screen.

2. By clicking on the drop-down menu in the Preview section, situated next to the layer you wish to use as a PIP, you will access the image parameters of the PIP source you select

( # 1 to # 12).

3. Set the desired PIP attributes (size, position, zoom, border, transparency...).

4. Click on the


tab to return to the main screen.

Working with Frames

It is possible to store up to 8 frames in the

Smart MatriX

non volatile memory. Frames are mainly used as backgrounds in a typical show or event setup, and can be recorded from any of the 8

Smart MatriX

sources and called back at the click of a single button.

* NOTE * :

To memorize a frame, select an input, and take it to the

Main screen. Once the frame is displayed on your Main output, it is then possible to store it to the

Smart MatriX

non volatile memory.

* NOTE * :

Frames may be used only one at a time. A frame may not be used as a live Background.

Memorizing Frames

1. In click the on

Input the

Selection source section, button

( # 1 to # 12) of the source you wish to record as a frame.

2. Click on the

Logos/Frames

tab of the RCS interface. Then click on the

Record Frame

button.

3. Click on the field next to the first free Frame to select it.

4. Click on the

Execute

button.

Working with Logos

It is possible to store up to 8 logos in the

Smart MatriX

non volatile memory. logos work in much the same way as frames, and can be recorded from any of the

Smart MatriX’

12 sources.

Logos have more attributes than frames. They can be sized, positionned, but also keyed via color cutout selection or luma Key.

Memorizing Logos

1. In the Input Selection section, click on the source button ( # 1 to # 12) of the source you wish to record as a logo.

2. In the

Logos/Frames

tab, click

Record Logo

, then select an empty logo memory slot ( # 1 to # 8) to record your logo into.

3. Adjust position, size and keying attributes for your logo.

4. Click on

Execute

to record your logo into the selected memory slot. The

Smart MatriX

RCS will display a progress bar while recording the logo.

5. In the Input Selection section, click the LOGO1 button, and select logo number ( # 1 to # 8) you wish to use.

Your logo will appear on the preview screen above any existing layer on screen.

6. Click on the TAKE button. Your logo will appear on the main display.

61

62

Layer transitions & effects

The

Smart MatriX

offers a wide variety of transitions between the scenes you create for your shows and events. It allows for live recall of 4 user presets, each of which you can edit at any given time.

1. In the Layer Selection section, click on the PIP1 button. On your Preview screen, PIP1 will appear as a color rectangle. The parameters of the layer will automatically appear in the RCS Preview section.

2. At the bottom of the Preview section, click on the

Transition

tab, then select the transition type from the left dropdown menu, and the effect behaviour from the right dropdown menu.

3. Determine effect duration by sliding the duration bar left (shorter) or right (longer), or by manually setting the value in the duration value box.

4. Repeat the procedure in the

Closing Effect

tab to determine the way your layer will close.

Creating Presets

The

Smart MatriX

allows the creation of user defined presets very easily. Any setup you have configured on screen, can be stored into one of the 4 available user presets.

1. After having configured layers, PIP transitions, logos... on your screen (see “Working with the

RCS” chapter, p. 59), click on one of the four available

Preset

buttons.

2. In the dropdown menu, choose

Save From Main

or

Save From Preview

to determine which screen you want to memorize the preset from.

3. By clicking one of the two options, the RCS will automatically load and preview the selected Preset.

4. Click on the Take button to view your preset on the Main screen.

Working with Presets

The four

Smart MatriX

user presets can be called back at any stage during your show or event.

1. Click on one of the four available

Preset

buttons to choose which memory you wish to use. Select

Load to Preview

from the dropdown menu, your preset will appear on the Preview screen.

2. Once you have selected your preset, simply click the

Take

button to view the result on your M ain screen.

Working with Audio

The

Smart MatriX

allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 embedded SDI audio inputs (via the SDI BNC connectors), all accessible via the

Audio

menu of the

Smart MatriX

, and which can be affected to one or both of the 2 independent symetrical/asymetrical outputs of the device.

Audio configuration

To configure audio settings of the

Smart MatriX

, plug all audio inputs into the device, and click on the

Audio

tab of the RCS home page.

1. Set the Main audio output level and delay

(accessible only if Delay Mode is set to Manual

Adjust), or click on the Mute button to mute Main audio output.

2. Repeat step 2 for the Prelist audio output.

3. Individual source settings (level and balance) for each audio input can be configured in the right hand section of the

Audio

tab.

63

OPTIONAL REMOTE CONTROL SYSTEMS

6-1. Axion2

Analog Way engineers have designed several remote controllers specifically made for easy control of the

Di-VentiX

II, Eikos, Eikos LE, OPS300, OPS200,

Pulse, Pulse LE, SmartVu and

SmartVu LE, Smart MatriX, Smart

MatriX LE, Smart Edge and Smart

Quad

.

Axion2:

The Axion2 is an ergonomic and reliable remote controller for rental

& staging/multi-venues at an optimal price/performance ratio. It controls simultaneously up to 6 screens in a single or multiple display configuration.

NOTE:

>> Event Controllers

www.analogway.com

Application Note #5-1

Triple Screen Presentation using the Axion2, 1 Di-VentiX II

(SEB Mode), 1 Smart MatriX and 1 SmartVu LE

64

76

USA, Canada, South America and The Carribeans

ANALOG WAY Inc.

Tel. 212 269 1902

Fax. 212 269 1943

Email: [email protected]

Europe, Middle East and Africa

ANALOG WAY SAS

Tel. 331 64 47 16 03

Fax. 331 64 47 14 73

Email: [email protected]

AN-5-1_Controllers-060910-V1

Asia Pacific

ANALOG WAY Pte Ltd

Tel.: 65 62 92 58 00

Fax.: 65 62 92 52 05

Email: [email protected]

6-2. ORCHESTRA

Analog Way engineers have designed several remote controllers specifically made for easy control of the

Di-

VentiX II, Eikos, Eikos LE, OPS300,

OPS200, Pulse, Pulse LE, Smart Vu and SmartVu LE, Smart MatriX,

Smart MatriX LE, Smart Edge and

Smart Quad

.

Orchestra:

The Orchestra is an ergonomic and reliable remote controller for rental & staging/multivenues at an optimal price/performance ratio. It controls simultaneously up to 6

>> Event Controllers

NOTE:

Application Note #4-2

4 Screen Presentation using the Orchestra with 2 Eikos LE

(in Seamless Matrix Mode) and

1 Di-VentiX II (1 in Embedded SEB Mode)

76

USA, Canada, South America and The Carribeans

ANALOG WAY Inc.

Tel. 212 269 1902

Fax. 212 269 1943

Email: [email protected]

Europe, Middle East and Africa

ANALOG WAY SAS

Tel. 331 64 47 16 03

Fax. 331 64 47 14 73

Email: [email protected]

AN-4-2_Controllers-060910-V1

Asia Pacific

ANALOG WAY Pte Ltd

Tel.: 65 62 92 58 00

Fax.: 65 62 92 52 05

Email: [email protected]

65

6-3. TRK-800

Analog Way engineers have designed several remote controllers specifically made for easy to control the

Eikos,

Eikos LE, OPS300, OPS200,

Pulse, Pulse LE, SmartVu and

SmartVu LE, Smart MatriX,

Smart MatriX LE, Smart Edge

and Smart Quad

.

TRK-800: Triple Remote Keypad designed to control up to 3 units.

> Powerful High End Remote Controller

>

>

>

>> Event Controllers

> Ethernet LAN RJ45 connector for easy connection

Application Note #6-1

NOTE:

Triple Screen Presentation using 1 Eikos LE (with Mosaic Preview), 1 SmartVu LE, 1 Smart MatriX LE controlled by the TRK-800 Remote Keypad

i

66

76

USA, Canada, South America and The Carribeans

ANALOG WAY Inc.

Tel. 212 269 1902

Fax. 212 269 1943

Email: [email protected]

Europe, Middle East and Africa

ANALOG WAY SAS

Tel. 331 64 47 16 03

Fax. 331 64 47 14 73

Email: [email protected]

i

AN-6-1_Controllers-060910-V1

Asia Pacific

ANALOG WAY Pte Ltd

Tel.: 65 62 92 58 00

Fax.: 65 62 92 52 05

Email: [email protected]

6-4. RK-300

Analog Way engineers have designed several remote controllers specifically made for easy control of the

Eikos,

Eikos LE, OPS300, OPS200,

Pulse, Pulse LE, Smart Vu and

Smart Vu LE, Smart MatriX,

Smart MatriX LE, Smart Edge

and Smart Quad

.

RK-300: Remote Control

Keypad designed to control Analog Way’s new Seamless Switchers

> Very User-friendly Remote Control Keypad

> Controls different Switchers

> Mini Joystick for easy element control

> Ethernet LAN RJ45 connector for easy connection

> Large VFD display offering high contrast menu

NOTE:

for further information concerning our optional remote controllers, please connect to our website on:

www.analogway.com

Preview

Monitor

67

68

APPLICATION NOTES AND TIPS

7-1. ABOUT APPLICATION NOTES

Application notes are intended to make the use of the

Smart MatriX

as easy as possible, by providing visual help in setting up your equipment. In an effort to make the use of our machines the most pleasant experience possible, the

Analog Way

team is constantly aiming to create easy to follow examples, update information, and furnish our website with useful user information.

Please check on

www.analogway.com

.

7-2. APPLICATION NOTES

7-3. EXTERNAL PROGRAMMING

If you need to use your own Software Control program from a PC or automation, the device allows communication through an ASCII code protocol. All commands can be found on the CD-Rom shipped with the

Smart MatriX

in the “External Programming” file.

All

Analog Way

products equipped with a RS-232 input are compatible with Crestron, AMX, Medialon, and most major control systems. TCP/IP control ports are also available on most Analog

Way products, as standard or as options.

To control a

Smart MatriX

with an External Remote Controller (PC

Software Control - Touch Pad Controller…) follow the indications below:

1. First establish a RS-232 communication between the Remote

Control Software and the

Smart MatriX

, in order to setup the

LAN parameters of the product.

2. In the “Control” - “

Smart MatriX

LAN Setup” menu, configure the connection of the

Smart MatriX

in UDP mode and setup the

Local and Remote Addresses as well as the Local and Remote

Ports in concordance with your Network.

3. Configure the TCP/IP address of your External Remote

Controller.

In example: 192.168.000.001

4. Setup the UDP connection of your External Remote Controller in concordance with your Network.

For example on the Remote Software in the “Control” - “RS232/

LAN Setup” - “LAN/Setup” menu :

5. Setup the LAN parameters in UDP mode in the “Console” - “LAN

Setup” menu.

For example: RK Address: 192.168.000.002

Remote Address: 192.168.000.010

Gateway Address:

RK Port:

Remote Port:

Netmask:

192.168.000.001

10500

10500

255.255.255.000

6. Select the LAN communication port in the remote controller console - “RS232/LAN port” menu.

7. You can now control your

Smart MatriX

with an External Remote

Controller.

69

70

WARRANTY

8-1. ANALOG WAY LIMITED WARRANTY

All

Analog Way

products have a 3 year warranty on parts and labor, back to factory. This warranty does not include faults resulting from user negligence, special modifications, electrical surges, abuse (drop/crush), and/or other unusual damage.

8-2. SERVICES AND RMA

In the unlikely event that a product is required to return for repair, please call the regional Maintenance center / Customer Service, and ask to receive a Return Material Authorization number (RMA). Three regional maintenance centers are available depending on your location. See map below for information on which regional maintenance center you depend on.

RMA Conditions :

1. Prior to returning any item, you must receive a Return Material Authorization (RMA) number.

2. All RMA numbers must appear on the return-shipping label.

3. All shipping and insurance charges on all RMAs must be prepaid by the customer.

HOW TO CONTACT US

Analog Way SAS

33 rue du Saule Trapu

Parc du Moulin

91300 Massy

France

Tel.: +33 1 64 47 16 03

Fax: +33 1 64 47 14 73 [email protected]

Analog Way Inc.

299 Broadway, Suite 1620

New York, NY 10007

United States of America

Tel.: +1 212 269 1902

Fax. +1 212 269 1943 [email protected]

Analog Way Pte Ltd.

No. 10 Ubi Crescent

#03-05 Ubi Techpark Lobby A

Singapore 408564

Tel.: +65 6292 5800

Fax: +65 6292 5205 [email protected]

For more documentation, general information, or simply to keep up to date with new releases and upcoming Analog Way products, please log on to

www.analogway.com

.

Before calling your regional maintenance center, please gather the following information :

- Serial number of the unit

- Firmware version (look in : CONTROL MENU/VERSIONS)

- Model reference (

SMX200

- Description of failure

)

INFORMATION ON UNIT DISPOSAL

In the European Union :

If the product is used for business purposes and you want to discard it :

Please contact your Analog Way dealer who will inform you about take-back of the product. You might be charged for the costs arising from take-back and recycling.

For Spain :

Please contact the established collection system or your local authority for take-back of your used product.

In other countries outside the EU :

If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.

71

Version: 4.00 - 07/12/2011

Code: 140122

Designs and specifications are subject to change without notice

The illustrations and screens described in this manual may be exaggerated or simplified for easy recognition and may be slightly different from the actual unit.

ANALOG WAY SAS

33 rue du Saule Trapu

Parc du Moulin

91300 Massy - France

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
