P REFACE
Thank you for purchasing the TV-IP110WN Wireless N Internet Camera
Server, a powerful and high-quality image network camera. The camera
can be installed as a standalone system within your application
environment easily and quickly, and supports remote management
function so that you can access and control it using a Web browser on your
computer.
This guide will provide you more information of instruction and
illustrations on how to use your camera, which includes:
Chapter 1
Introduction to Your Camera describes the features of the
camera. You will also know the components and functions of
the camera.
Chapter 2
Hardware Installation helps you install the camera according
to your application environment. You can use this camera at
home, at work, at any where you want.
Chapter 3
Accessing the Camera lets you start using your camera
without problem. The camera can be set up easily and work
within your network environment instantly.
Chapter 4
Configuring the Camera guides you through the configuration
of the camera using the web browser on your PC.
Chapter 5
SecurView™ Pro shows you the detail instructions on
operating SecurView™ Pro software.
Chapter 6
How to Access the Camera Behind a Router provides the
instruction how to setup your DDNS.
Chapter 7
Appendix provides the specification of the camera and some
useful information for using your camera.
NOTE:
The illustrations and configuration values in this guide are for reference
only. The actual settings will depend on your practical application of the
camera.
Contents
PREFACE .............................................................................. 1
CHAPTER 1 ......................................................................... 4
INTRODUCTION TO YOUR CAMERA ............................ 4
1.1
1.2
1.3
1.4
CHECKING THE PACKAGE CONTENTS..............................................4
GETTING TO KNOW YOUR CAMERA...............................................5
FEATURES AND BENEFITS ............................................................7
SYSTEM REQUIREMENT ...............................................................8
CHAPTER 2 ......................................................................... 9
HARDWARE INSTALLATIO N .......................................... 9
2.1
2.2
2.3
INSTALLING THE CAMERA STAND ..................................................9
CONNECTING THE CAMERA TO LAN ............................................10
APPLICATIONS OF THE CAMERA ..................................................11
CHAPTER 3 ....................................................................... 12
ACCESSING THE CAMERA ............................................ 12
3.1
3.2
3.3
USING IP SETUP ......................................................................12
ACCESSING TO THE CAMERA ......................................................17
CONFIGURING THE IP ADDRESS OF THE PC ...................................20
CHAPTER 4 ....................................................................... 21
CONFIGURATION OF THE CAMERA ........................... 21
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
USING THE WEB CONFIGURATION ..............................................21
USING SMART WIZARD.............................................................22
BASIC SETUP ...........................................................................27
NETWORK SETTINGS ................................................................31
SETTING UP VIDEO ...................................................................40
EVENT SERVER CONFIGURATION.................................................43
MOTION DETECT .....................................................................47
EVENT CONFIG ........................................................................49
TOOLS ...................................................................................54
4.10 INFORMATION ........................................................................56
CHAPTER 5 ....................................................................... 57
SECURVIEW™ PRO SOFTW ARE ................................... 57
5.1
5.2
INSTALLATION .........................................................................58
USING SECURVIEW™ PRO.........................................................61
CHAPTER 6 ....................................................................... 92
HOW TO ACCESS THE CAMERA BEHIND A ROUTER .......... 92
CHAPTER 7 ....................................................................... 98
APPENDIX ......................................................................... 98
A.1 SPECIFICATION ........................................................................98
A.2 GLOSSARY OF TERMS..............................................................101
LIMITED WARRANTY ........................................................ 110
C HAPTER 1
I NTRODUCTION TO YOUR C AMERA
1.1 Checking the Package Contents
Check the items contained in the package carefully. You should have the
following:







1 x TV-IP110WN
1 x CD-ROM (Utility & User’s Guide)
1 x Multi-Language Quick Installation Guide
1 x External antenna
1 x 5V 2.5A power adapter
1 x Network Cable
1 x Camera Stand
NOTE: If there is any item damage or missing, please contact your local
authorized dealer for replacement.
1.2
Getting to Know Your Camera
Power LED: A steady orange light indicates the camera is powered
on.
Link LED: A flash green light indicates the camera’s network
connection correctly.
Lens: Adjust the focus by rotate outside of the Lens.
WPS button: A quick connection button to your encrypted
wireless network
Detachable Antenna:
Adjust the antenna position to get the maximum signal.
Camera Stand Connector: Connects the camera with the camera
stand.
Power Connector: Connects the power adapter in order to supply
the power to the camera.
LAN Port: Connects one end of the Network cable to LAN port and
connect the other end cable to your network
Reset Button: Press the reset button once to reset the current
setting. Press the reset button continuously for 5 seconds to
restore the camera to factory default setting.
1.3 Features and Benefits

Surveillance Supported
The camera supports enable motion detection and setup automated
email alerts and upload the still image into FTP.

Remote Control Supported
By using a standard Web browser or the included SecurView Pro
software application, the administrator can easily change the
configuration of the camera via Intranet or Internet. In addition, the
camera can be upgraded remotely when a new firmware is available.
The users are also allowed to monitor the image and take snapshots
via the network.

Multiple Platforms Supported
The camera supports multiple network protocols, including TCP/IP,
SMTP e-mail*, HTTP, and other Internet related protocols. Therefore,
you can use the camera in a mixed operating system environment,
such as Windows Vista and Windows 7.

Multiple Applications Supported
Through the remote access technology, you can use the cameras to
monitor various objects and places for your own purposes.
For example, babies at home, patients in the hospital, offices and
banks, and more. The camera can capture both still images and video
clips, so that you can keep the archives and restore them at any time.

WPS Supported
WPS (Wi-Fi Protected Setup) standard is a new solution that simplifies
the process of configuring Wi-Fi security settings, allowing you to
establish a secure wireless network by simply pressing a button.
Note: Support SSL with complimentary software
1.4 System Requirement

Networking
LAN:
10Base-T Ethernet or 100Base-TX Fast Ethernet,
Auto-MDIX
WLAN:
Based on IEEE 802.11n technology, IEEE 802.11g/b

Accessing the Camera using Web Browser
Platform:
Microsoft® Windows® 7/Vista/XP
CPU:
Intel Pentium III 800MHz or above
RAM:
512MB
Resolution:
800x600 or above
User Interface: Microsoft® Internet Explorer 6.0 or above

Accessing the Camera using SecurView Pro
Platform:
Microsoft® Windows® 7/Vista/XP
Hardware Requirement:
1 ~ 8 cameras:
Intel Core 2 Duo; 2GB RAM
9 ~ 32 cameras:
Intel Core 2 Quad; 4GB RAM
NOTE: It is higher recommended that using a high performance computer
to monitor multiple cameras.
C HAPTER 2
H ARDWARE I NSTALLATION
2.1 Installing the Camera Stand
The camera comes with a camera stand, which uses a swivel ball screw
head to lock to the camera’s screw hole. When the camera stand is
attached, you can place the camera anywhere by mounting the camera
through the three screw holes located in the base of the camera stand.
The Camera Stand
2.2 Connecting the Camera to LAN
Use the provided Ethernet cable to
connect the camera to your local area
network (LAN).
When you connect the power
adapter, the camera is powered on
automatically. You can verify the
power status from the Power LED
(amber) on the front panel of the
camera.
Once connected, the Link LED starts
flashing green light and the camera is
on standby and ready for use now.
If you use a wireless network in your
application environment, you need to
attach the included detachable
antenna to the camera.
If your wireless network has set
encryption, you can use WPS button
or configure the wireless connection
via a LAN connection.
NOTE: Please configure the wireless setting via the wire connection.
2.3 Applications of the Camera
The camera can be applied in multiple applications, including:

Monitor local and remote places and objects via Internet or Intranet

Capture still images and video clips remotely

Upload images or send email messages with the still images attached
The following diagram explains one of the typical applications for your
camera and provides a basic example for installing the camera.
*
C HAPTER 3
A CCESSING THE C AMERA
3.1 Using IP Setup
The camera comes with a conveniently utility, IP Setup, which is included
in the Installation CD-ROM, allowing you to search the camera on your
network easily.
1.
Insert the Installation CD-ROM into your computer’s CD-ROM drive to
initiate the Auto-Run program.
2.
Click the IP Setup from the Auto-Run menu screen. Then IP Setup
Wizard will appear. Click “Next” when the Welcome to the IPSetup
Setup Wizard appears.
3.
Click “Browse” to choose the desired destination location. By default,
the destination location is C:\Program Files\TRENDnet\IPSetup. Then
Click “Next”.
4.
Click “Next” to confirm the IPSetup software to be installed to the
computer.
5.
When the Installation Complete window appears, click “Finish”.
6.
After installing the IPSetup utility, the application is automatically
installed to your computer, and creates a folder in “Start
\Program\TRENDnet\IPSetup”.
7.
Click Start > Programs > TRENDnet > IPSetup, and then click IPSetup
8.
The IPSetup window will appear. It will search the Camera within the
same network.
Camera Display Area
-
Camera Display Area: It shows the connected camera(s) within the
same network. By default, the IP setting on the Camera is set up DHCP.
If you have DHCP server, the camera will automatic get the IP address
from DHCP server. If you do not have DHCP server on your network, it
will show the default IP as 192.168.10.30.
Double click the IP address; it will link to Camera’s Web Configuration
page.
-
Change IP: Click this button to bring up the following window. It
allows you to change the IP Address. You can select either Static IP or
click DHCP. Then, enter the Administrator ID & password. By default
ID/password is: admin. When complete, click “Change”.
-
Search: Click this button to search the connected camera in the
-
same network.”
Exit: Click this button to exit the program.
3.2 Accessing to the Camera
1.
Open the Web browser on your computer (example showed in the
User’s Guide is based on the Internet Explorer)
2.
Type the Camera IP address that DHCP server assigned in the web
browser URL (e.g. 192.168.10.30) and then press [Enter].
3.
When the login window appears, enter the default User name (admin)
and password (admin) and press OK to access to the main screen of
the camera’s Web Configuration.
NOTE:
If you are initially access to the camera, you will be asked to install
a new plug-in for the camera. Permission request depends on the
Internet security settings of your computer. Click Yes to proceed.
After you login into the Web Configuration of the camera, the main page
will appear as below:
Camera Information
Zoom In
Live View/ Setup
Function
Live View Image
The main page of the Web Configuration provides you with many useful
information and functions, including:

Camera Information – Display the camera’s location and the current
date & time. The information can be modified in the Web
Configuration.

Live View Image – Displays the real-time image of the connected
camera.

Zoom In – Click the buttons to zoom in the live view image by 1x, 2x,
and 3x.

Live View/Setup Switch – Click Setup to configure the camera. Please
refer to Chapter 4 for more information.

Function – Use these buttons to control the video functions.
Manual Record allows you to record and save a video clip.
Snapshot allows you to capture and save a still image.
Browse allows assign the destination folder to store the video
clips and still images.
NOTE: If you are using Microsoft 7/Vista platform, you may not be able
to find these recorded files that are stored by Snapshot or
Manual Record. You will need to disable the protected mode of
Security in the IE Browser before manual record video file or
taking a snapshot.
Please follow the below Steps:
1. Open IE Browser
2. Select ToolsInternet Options
3. Select Security
4. Uncheck the ”Enable Protected Mode” then press OK
3.3 Configuring the IP Address of the PC
If you are failed to access to the camera, please check the IP address of
your computer. When you connect the camera to your computer directly
to proceed with configuration of the camera, you need to set up the IP
addresses to be in the same segment for the two devices to communicate.
1.
On your computer, click Start > Control Panel to open the Control
Panel window.
2.
Double-click Network Connection to open the Network Connection
window.
3.
Right-click Local Area Connection and then click Properties from the
shortcut menu.
4.
When the Local Area Connection Properties window appears, select
the General tab.
5.
Select Internet Protocol [TCP/IP] and then click Properties to bring up
the Internet Protocol [TCP/IP] Properties window.
6.
To configure a fixed IP address that is within the segment of the
camera, select the Use the following IP address option. Then, enter an
IP address into the empty field.
7.
When you are finished, click OK.
C HAPTER 4
C ONFIGURATION OF THE
CAMERA
4.1 Using the Web Configuration
You can access and manage the camera through the Web browser and the
provided software application SecurView Pro. This chapter describes the
Web Configuration, and guides you through the configuration of the
camera by using the web browser.
To configure the camera, click Setup on the main page of Web
Configuration. The Web Configuration will start from the Basic page.
The Web Configuration contains the settings that are required for the
camera in the left menu bar, including Smart Wizard, Basic, Network,
Video, Event Server, Motion detect, Event Config, Tools, and Device Info.
4.2 Using Smart Wizard
The camera’s Smart Wizard lets you configure your camera easily and
quickly. The wizard will guide you through the necessary settings with
detailed instructions on each step.
To start the wizard, click Smart Wizard in the left menu bar.
The following screen will pop up.
Step 1. Camera Settings
Step 2. IP Settings
Step 3. Email Settings
Step 4. Wireless Networking
Step 5. Confirm Settings
This step shows the configuration of your camera. When you confirm the
settings, click Apply to finish the wizard and reboot the camera. Click Prev
to go back to the previous step(s) and change the settings; or click Cancel
to end the wizard and discard the changes.
4.3 Basic Setup
The Basic menu contains three sub-menus that provide the system settings
for the camera, such as the Camera Name, Location, Date & Time, and
User management.
Basic >> System


Basic
Camera Name: Enter a descriptive name for the camera.
Location: Enter a descriptive name for the location used by the
camera.
Indication LED
This item allows you to set the LED illumination as desired. There are
two options: Normal and OFF.
Basic >> Date & Time

Date & Time
TimeZone: Select the proper time zone for the region from the pulldown menu.
Synchronize with PC: Select this option and the date & time settings
of the camera will be synchronized with the connected computer.
Synchronize with NTP Server: Select this option and the time will be
synchronized with the NTP Server. You need to enter the IP address
of the server and select the update interval in the following two
boxes.
Manual: Select this option to set the date and time manually.
Basic >> User

Administrator
To prevent unauthorized access to the camera’s Web Configuration,
you are strongly recommend to change the default administrator
password. Type the administrator password twice to set and confirm
the password.

General User
User Name: Enter the user’s name you want to add to use the
camera.
Password: Enter the password for the new user.
When you are finished, click Add/Modify to add the new user to the
camera. To modify the user’s information, select the one you want
to modify from User List and click Add/Modify.
User List: Display the existing users of the camera. To delete a user,
select the one you want to delete and click Delete.

Guest
User Name: Enter the guest’s name you want to add to use the
camera.
Password: Enter the password for the new guest.
User List: Display the existing guests of the camera. To delete a user,
select the one you want to delete and click Delete.

Direct Video Stream Authentication:
- Enabled = Direct link to the video stream prompts for authentication.
- Disable = Direct link to video does not prompt for authentication for
ease of use when implementing or embedding the video stream into a
custom application or webpage.
Examples of the Direct Link to video:
MJPEG Mode
http://camera_ip_address:port number/jpgview.htm
NOTE:
The “General User” can access the camera and control the
Function buttons of the camera’s Web Configuration; the “Guest’
can only view the live view image from the main page of the Web
Configuration while accessing the camera. Only the
“Administrator” is allowed to configure the camera through the
Web Configuration.
4.4 Network Settings
The Network menu contains three sub-menus that provide the network
settings for the camera, such as the IP Setting, DDNS Setting, IP Filter, and
wireless network.
Network >> Network

IP Setting
This item allows you to select the IP address mode and set up the
related configuration.
DHCP: The default IP Setting mode was set as DHCP. Select this
option when your network uses the DHCP server. When the camera
starts up, it will be assigned an IP address from the DHCP server
automatically.
Static IP: Select this option to assign the IP address for the camera
directly. You can use IPSetup to obtain the related setting values.
IP
By the default setting, your camera IP address is
assigned from your DHCP server. If you do not
have a DHCP server in your network, the IP
address will be assigned to 192.168.10.30.
Subnet Mask
Enter the Subnet Mask of the camera. The
default setting is 255.255.255.0.
Default Gateway
Enter the Default Gateway of the camera.
Primary/
Secondary DNS
DNS (Domain Name System) translates domain
names into IP addresses. Enter the Primary DNS
and Secondary DNS that are provided by ISP.
PPPoE: Select this option when you use a direct connection via the
ADSL modem. You should have a PPPoE account from your Internet
service provider. Enter the User Name and Password. The camera
will get an IP address from the ISP as starting up.
NOTE: Once the camera get an IP address from the ISP as starting up, it
automatically sends a notification email to you. Therefore, when
you select PPPoE as your connecting type, you have to set up the
email or DDNS configuration in advance.

DDNS Setting
With the Dynamic DNS feature, you can assign a fixed host and
domain name to a dynamic Internet IP address. Please refer to
Chapter 6 for detail instruction.

UPnP
The camera supports UPnP (Universal Plug and Play), which is a set of
computer network protocols that enable the device-to-device
interoperability. In addition, it supports port auto mapping function so
that you can access the camera if it is behind an NAT router or firewall.
Select the Enable option to enable this feature.

Ports Number
HTTP Port: The default HTTP port is 80.
NOTE:
If the camera is behind an NAT router of firewall, the port number
is suggested in the range between 1024 to 65535.
Network >> IP Filter
The IP Filter setting allows the administrator of the camera to limit the
users within a certain range of IP addresses to access the camera.

Start/End IP Address
Assign a range of IP addresses that are not allowed to access the
camera by entering the Start IP address and End IP address. When you
are finished, click Add to save the range setting. You can repeat the
action to assign multiple ranges for the camera.
For example, when you enter 192.168.10.50 in Start IP Address and
192.168.10.80 in End IP Address, the user whose IP address located
within 192.168.10.50 ~ 192.168.10.80 will not be allowed to access
the camera.

Deny IP List
The list displays the range setting(s) of IP addresses that are not
allowed to access the camera. To clear the setting, select a range of IP
addresses from the list and click Delete.
Network >> Wireless Setting

Wireless
The camera supports WLAN while you use the wireless network. Select
the Enable option to enable this feature.
Network ID (SSID}: The default SSID setting is “TRENDnet”. To
connect the camera to a specified access point, set a SSID for the
camera to correspond with the access point’s ESS-ID. To connect the
camera to an
Ad-Hoc wireless workgroup, set the same wireless channel and SSID
to match with the computer’s configuration.
Click Site Survey to display the available wireless networks, so that
you can easily connect to one of the listed wireless networks.
Wireless Mode: Select the type of wireless communication for the
camera: Infrastructure or Ad-Hoc.
Channel: Select the appropriate channel from the list.
Authentication: Select the authentication method to secure the
camera from being used by unauthorized user: Open, Shared-key,
WPA-PSK, and WPA2-PSK. The following table explains the four
options:
Open
The default setting of Authentication mode, which
communicates the key across the network.
Shared-key
Allow communication only with other devices with
identical WEP settings.
WPA-PSK/
WPA2-PSK
WPA-PSK/WPA2-PSK is specially designed for the
users who do not have access to network
authentication servers. The user has to manually
enter the starting password in their access point or
gateway, as well as in each PC on the wireless
network.
If you select Open or Shared-key as the Authentication mode, you
need to complete the following settings:
Encryption: Select the WEP option to enable the data encryption
feature to secure the camera within the wireless network.
Format: Once you enable the Encryption feature, you need to
determine the encryption format by selecting ASCII or HEX. ASCII
format causes each character you type to be interpreted as an eightbit value. Hex format causes each pair of characters you type to be
interpreted as an eight-bit value in hexadecimal (base 16) notation.
Key Length: Select the WEP key length you use: 64 bits or 128 bits.
WEP Key 1/2/3/4: Enter the WEP key(s) in the following boxes.
If you select WPA-PSK or WPA2-PSK as the Authentication mode, you
need to complete the following settings:
Encryption: Select TKIP or AES. TKIP (Temporal Key Integrity Protocol)
changes the temporal key every 10,000 packets to insure much
greater security than the standard WEP security. AES (Advanced
Encryption Standard) is used to ensure the highest degree of security
and authenticity for digital information.
Pre-Shared Key: This is used to identify each other in the network.
Enter the name in the box, and this name must match the Pre-shared
key value in the remote device.
Network >> Wireless >> WPS Setting
WPS (Wi-Fi Protected Setup) sets a new standard of Wi-Fi security,
providing a simplified secure network setup solution for the end users.
Once the required settings have been completed, your wireless network
can be protected by simply pressing the WPS button on the camera.

PROTECTED SETUP
Press the Reset to Unconfigured button to reset the WPS
configuration of the camera.

WPS
PIN Mode: The PIN (Personal Information Number) mode builds the
connection by entering the PIN Code directly. Once you enter the
PIN Code of the camera on the router (or access point) that
supports WPS, you can directly build a WPS connection between the
camera and the device by simply pressing its WPS button.
PBC Mode: The PBC (Push Button Configuration) mode builds the
connection by scanning the devices in the wireless network. Once
you press the camera’s WPS button, it starts to scan the WPS
devices in the wireless network, and then you can build the WPS
connection by clicking the Connect button.

TIP
Device Status
Display the WPS configuration of the camera.
The Power LED indicates the WPS connection status by:
blinking 3 times when the connection is built successfully.
repeating 3 times of short-short-long blink when the connection
is failed.
4.5 Setting up Video
The Video contains two sub-menus that provide the video and settings for
the camera.
Video >> Camera

Image Setting
Brightness: Adjust the brightness level from 0 ~ 100.
Contrast: Adjust the contrast level from 0 ~ 100.
Saturation: Adjust the colors level from 0 ~ 100.
Click Default to restore the default settings of the three options
above.
Mirror: Select the Horizontal option to mirror the image
horizontally. Select the Vertical option to mirror the image vertically.
Light Frequency: Select the proper frequency according to the
camera’s location: 50Hz, 60Hz, or Outdoor.

Overlay Setting
Includes Date & Time: Select this option to display the date & time
stamp on the live view image.
Enable Opaque: Select this option to set a black background to the
displayed date & time stamp.
Video & Audio >> Video

MJPEG
Video Resolution: Select the desired video resolution from the
three formats: VGA, QVGA and QQVGA. The higher setting (VGA)
obtains better video quality while it uses more resource within your
network.
Video Quality: Select the desired image quality from five levels:
Lowest, Low, Medium, High, and Highest.
Frame Rate: Select a proper setting depending on your network
status.
NOTE:The camera supports MJPEG compression. MJPEG capture the
images in JPEG format, which require higher bandwidth to view
smooth video. The administrator can control the bandwidth of
each connection well through the setting options above.
4.6 Event Server Configuration
The Event Server menu contains three sub-menus that allow you to send
notification to NVR, upload images to FTP or send images to emails.
When you complete the required settings of HTTP, FTP or Email, click Test
to verify the configuration. Once the camera connects to the server
successfully, click Apply.
Event Server Setting>> HTTP

HTTP Notify For Motion Trigger
Send the query parameter via an HTTP notification when an event is
triggered.
Host: Enter the IP of the HTTP server
Port: Enter the Port number of the HTTP server
User Name: Enter the username of the HTTP server
Password: Enter the password of the HTTP server
Query: Enter the query parameter for the request if necessary
Example:
Host: 192.168.10.1
Port: 80
Query: xxx.cgi?name1=value1&name2=value2
Ex: cgi/event.cgi?status=#s&time=#t&model=modelname
Result:
http://192.168.10.1:80/cgi/event.cgi?status=#s&time=#t&model=m
odelname
Event Server Setting>> FTP

FTP
Host Address: Enter the IP address of the target FTP server.
Port Number: Enter the port number used for the FTP server.
User Name: Enter the user name to login into the FTP server.
Password: Enter the password to login into the FTP server.
Directory Path: Enter the destination folder for uploading the
images. For example, /Test.
Passive Mode: Select the Enable option to enable passive mode.
Event Server Setting >> Email

Email
SMTP Server Address: Enter the mail server address. For example,
mymail.com.
Sender Email Address: Enter the email address of the user who will
send the email. For example, [email protected]
Sender User Name: Enter the user name to login the mail server.
Sender Password: Enter the password to login the mail server.
Receiver #1 Email Address: Enter the first email address of the user
who will receive the email.
Receiver #2 Email Address: Enter the second email address of the
user who will receive the email.
4.7 Motion Detect
The Motion Detect menu contains the command and option that allow you
to enable and set up the motion detection feature of the camera. The
camera provides two detecting areas.
To enable the detecting area, select Window 1 or 2 from the pull-down list,
and then select Enable. When the detecting area is enabled, you can use
the mouse to move the detecting area and change the area coverage.
Name: Assign a name to the detecting area.
Threshold: Move the slide bar to adjust the level for detecting
motion to record video. Click Save once done the
setting.
4.8 Event Config
The Event Config menu contains four sub-menus that provide the
commands to configure event profiles.
Event Configuration >> General Setting
Snapshot/Recording Filename Prefix: You can assign a given prefix
to each new captured file. Otherwise, leave this option blank to use
the default setting.
Event Configuration >> Arrange Schedule Profile
This sub-menu displays the scheduled profile(s). To customize the profile,
click Add and then enter a descriptive name for the profile in the prompt
dialog window.
After entering the profile name, click OK and the profile is added to the
Schedule Profiles list. Click the profile name again to display the schedule
profile page. To delete the profile, select the profile in the list and click
Delete.
Profile Name: Display the profile name that you select in the
Schedule Profiles list.
Weekdays: Select the weekday(s) that you want to separately assign
in the schedule profile. The weekday that has been assigned will be
displayed with green color.
Time List: Display the time period that you have assigned within the
selected weekday. To assign the same time period to every weekday,
click Add this to all weekdays; click Delete this from all weekdays
to remove the selected time period from every weekday. Click
Delete to remove the selected time period.
Start/End Time: Enter the start and end time and then click Add to
assign a time period within in the selected weekday.
Event Configuration >> Motion Detect Trigger
Select the Enable option to enable the trigger function of the camera, so
that you can send captured images within the detecting area to the FTP
server and email receiver. You have to configure corresponding settings,
such as FTP server and email server, to enable this feature.
Schedule Profile: Select a schedule profile from the pull-down list.
Action: Select the destination that the captured images will be sent to:
HTTP Notify, Send Email, or FTP Upload.
Event Configuration >> Schedule Trigger
You can separately configure the schedule for trigger function of the
camera by Email or FTP. Select the Enable option on each item, and then
select a Schedule Profile from the pull-down list and set the Interval time.
4.9 Tools
The Tools menu provides the commands that allow you to restart or reset
the camera. You can also backup and restore your configuration, and
upgrade the firmware for the camera.

Factory Reset
Click Reset to restore all factory default settings for the camera.

System Reboot
Click Reboot to restart the camera just like turning the device off and
on. The camera configuration will be retained after rebooting.

Configuration
You can save your camera configuration as a backup file on your
computer. Whenever you want to resume the original settings, you
can restore them by retrieving the backup file.
Backup: Click Get the backup file to save the current configuration
of the camera.
Restore: Click Browse to locate the backup file and then click
Restore.

Update Firmware
This item displays the current firmware version. You can upgrade the
firmware for your camera once you obtained a latest version of
firmware.
Select the firmware: Click Browse to locate the backup file (xxx.pck)
and then click Update. Factory reset and IP Setup are required after
firmware update.
NOTE: Make sure to keep the camera connected to the power source
during the process of upgrading firmware. Otherwise, the camera
might be damaged because of failure of upgrading firmware.
4.10 Information
The Information menu displays the current configuration and events log of
the camera.

Device Info
Display the Basic, Video, Network, and Wireless settings of the camera.

System Log
The Logs table displays the events log recorded by the system.
C HAPTER 5
S ECUR V IEW ™ P RO S OFTWARE
This chapter describes detailed instructions on using SecurView Pro, a
customized software application with a user-friendly interface that allows
you to access your cameras. The Software can monitor and record up to 36
cameras. It also let you change some basic settings of the camera, such as
schedule profiles and motion detecting areas. The SecurView Pro also
supports audio or Pan/Tilt function.
It is recommended to use a high performance computer if you want to
connect multiple cameras simultaneously.




Platform: Microsoft® Windows® 7/Vista/XP
Hard Disk: 80GB or above
Resolution: 1024x768 or above
Hardware Requirement
1 ~ 8 cameras:
Intel Core 2 Duo; 2GB RAM
9 ~ 32 cameras:
Intel Core 2 Quad; 4GB RAM
* For Windows Vista users: please go to User Accounts and Family Safety
> User Accounts > Turn User Account Control on or off, then uncheck
the checkbox of “Use User Account Control (UAC) to help protect your
computer”. Restart your computer to validate the setting. For additional
information of User Account Control, please go to
http://www.microsoft.com/windows/products/windowsvista/features/details/u
seraccountcontrol.mspx
* For Windows 7 users, please go to Control Panel > User Accounts >
Change User Account Control Setting to lower your notify setting. For
additional information of User Account Control, please go to
http://windows.microsoft.com/en-us/windows7/products/features/useraccount-control
5.1 Installation
1.
Insert the Installation CD-ROM into your computer’s CD-ROM
drive to initiate the Auto-Run program.
2.
Click the SecurView Pro from the Auto-Run menu screen.
NOTE:
To use SecurView Pro, you must have Microsoft .NET Framework
2.0 installed in the computer. The setup wizard will detect it and,
if the program is not installed yet, it will ask you to install it during
the process of installing SecurView™ Pro.
NOTE: Microsoft Windows Installer 3.0 or above is a required component
to install SecurView Pro. For more information of the required
component during installation, please visit the Microsoft support
Website.
3.
Then SecurView Pro Setup Wizard will appear. Click “Install”.
4.
Wait until the program finish the installation. By default, the
destination location is C:\Program Files\TRENDnet\SecurView Pro.
5.
Click “Finish” to finish the installation.
6.
After installing the SecurView Pro, the application is
automatically installed to your computer, and creates a folder in
“ Start \Program\TRENDnet\SecurView Pro ”.
5.2 Using SecurView™ Pro
5.2.1 Launch the Program
To start SecurView Pro, click Start > All Programs > TRENDnet >SecurView
Pro > SecurView Pro. You can also start the program by double-click the
SecurView Pro icon on your desktop.
On the login window, enter the User name/Password and click OK to login.
The default User name/Password is admin/admin. If you wish to save the
login information, please select Auto Login.
5.2.2 Main Window and Features
When you start and login to SecurView Pro, the Main window will display
as below:






The Main window provides you with the information on operating the
system, as well as the control panel such as the Quick Launch buttons, and
so on.
NOTE
For best result, it is higher recommended to configure resolution setting to
1024 x 768 or higher; otherwise, it cannot be displayed on the screen
when launching the program.
 Live View Window displays the live video of the connected camera(s).
 Quick Launch Buttons are located below the Live View Window,
providing you with the following quick-launch functions:
Button
Function
Logout : To log out the SecurView Pro program
Close: To close the SecurView Pro program
Restore Recording Type: Restore all recording type to current
camera’s setting
All Continuous Recording: Continuous recording on all
cameras
Stop All Recording: Stop recording on all cameras
View Setting: To configure eMap settings
eMap View: To view current maps
Camera Status: Display cameras status
Playback: Playback recorded files
Schedule: Display Schedule Configuration window
Event Server: Setup a SMTP server
Address Book: Add/Remove email address for event
notification
Event Trigger: Setup event trigger configuration
Device Setting : Set up the camera
Recording Setting: Set up the recording path
Account information: Setup administrator password
Version: Display software version
System Setting: Software settings
 Camera View Mode buttons in this area allow you to switch the
camera view mode.
Buttons
Functions
Display the connected camera(s) in a single camera view
mode.
Display the connected camera(s) in a quad view mode.
Display the connected camera(s) in a 3 x 3 grid view mode.
Display the connected camera(s) in a 13-camera view mode
using a split window. The first camera is displayed as the
major view.
Display the connected camera(s) in a 17-camera view mode
using a split window. The first camera is displayed as the
major view.
Display the connected camera(s) in a N x N grid view mode,
supporting up to 36 cameras.
Display the live view of the selected camera in full screen
mode. Click ESC on the keyboard to return to Main window.
Automatically switch the live view of each connected
cameras in single camera view mode by 30 seconds*. Click
once to start and click again to stop.
* The auto-switch time is set as 30 seconds by default, which
can be changed by clicking the
 System Setting and
then change the value from the pull-down list of the Auto
Switch time interval option.
 System Information displays the system information, including the
date and time, and the available storage space of the system.
 Live View Status provides the status of live view mode, including
Camera List and eMap.
 Camera List displays the status of the connected cameras. If
multiple cameras are connected, you can switch to the live
view of each camera by simply selecting the camera from the
list.
 eMap allows you to select the desired camera to the view
from the map easily. Please note that you have to set up the
eMap for monitoring in advance.
 Camera Control Buttons provides the control buttons that allow you
to control the selected camera.
Buttons
Functions
Talk On/Off. Click to enable/disable the speaker function
of the connected camera. This option is available only in
single camera view mode.
Listen On/Off. Click to enable/disable the microphone
function of the connected camera. This option is available
only in single camera view mode.
For Pan/Tilt cameras, use this control panel to set the
preset positions (up to 8 positions).
Use Navigation buttons to adjust camera position, and
then select the position number (1~8) from the Set
button.
To move to the preset position, simply select the position
number (1~8) from the Go button.
Navigation Buttons (Left/Right/Up/Down/Home). If the
connected camera has pan/tilt functions, the Navigation
buttons allow you to move the camera lens position.
Clicking the Home (center) button will move the camera
lens to the assigned home position.
/
The Patrol/Stop buttons are used to enable/disable the
patrol function of the camera. Click Patrol to start
patrolling through the preset positions once. Click Stop to
stop patrolling.
5.2.3 Manage the Cameras
Before adding the cameras, please setup the recording setting first.
 Configure Recording Settings
1.
Click the
button and then select Record Setting.
2.
Default path is C:\, click Browse and select the desire
directory then click Save to complete the configuration.
To change the time interval for recording, select time from
the pull-down menu.
NOTE: The system will automatically delete the oldest files (10%) when the size of
recorded files is up to 90% of the storage space.
 Add a Camera
1.
Click the
button and select Device Setting to display the
Device Setting window.
2.
Click New.
3.
Click on Search, all cameras that’s connected to your network
would appear.
4.
Select the camera you would like to add and then click Add.
5.
The information of the camera will display on the screen.
It will auto detect the IP address/port number and display the
stream type of the camera. Please type in the correct user
name and password, then select Preview to view live image.
6.
To setup recording style, select Yes on Record option. These
four recording types will appear. Select one of the recording
type, configure it then click Save.
Continuously:
Record the stream video continuously
Schedule:
Records stream video by schedule. You can setup the
schedule by click Add Schedule here.
Click on New to create a new schedule and select the time to
record. Click on Save when finish.
Motion:
Record video by Motion Detection. Motion detection
recording required to setup a motion detection area. If you
are adding a new camera, you must save the camera
information first before setup the motion detection area.
To use motion detection record, please enable the detection
areas first. Click on Motion detection area to setup
Enable motion detection windows, set up the senstivity and
click on Save.
Motion by Schedule:
same requirement as Motion & Schedule recording.
Digital Input:
Recording triggered when there I/O port is triggered.
After all recording methods are configured, click Save to
apply the settings.
7.
Camera list will appear with recording type notification.
8.
NOTE
Once you added all the cameras, click the close button “x” on
the Device Setting windows to return to the main windows.
The cameras will display here.
Divx/Xvid codec is required for viewing the image of camera. If the image
cannot be displayed in the Live View/Preview window normally, click the
following path to download and install the required component:
http://download.divx.com/divx/DivXInstaller.exe
 Edit / Delete a Camera
1.
To edit a camera: From the Device Setting window, highlight
the camera you would like to edit then click on Modify button.
2.
To delete a camera: select the desired one and then click
Remove. Click Yes to confirm.
 View Camera Image
Since you have added camera(s) to the system, the image of the
selected camera(s) will be displayed on the Live View Window
automatically. You can view a maximum of 36 cameras
simultaneously. Additionally, you can select one-camera or other
view mode to display the video from the Camera View Mode
buttons.
For example, if you use only one camera, select single camera
view mode (
), and the Live View Window will display the
view as below. You can select the other modes according to your
need.
The Information icon (
) on the top-right corner of the
window provides you with the options to connect/disconnect the
camera, select a camera to be displayed in the window, capture a
still image of the camera live video, or switch to eMap mode. Click
the Information icon to pop up the shortcut menu and select the
desired option.
 Playback the Recorded Files
1.
Click the
button to display the Playback window.
2.
On the Playback window, select the camera and setup the
begin/end date and begin/end time, then click Search. The
search result will be displayed in the Record File list.
3.
To playback the video clip, select the desired file and click
Play.
5.2.4 eMap Setup & Camera Status
 Manage eMap
Click the
button and select View Setting to manage eMap.
eMap refers to the geography and device scope in the SecurView
Pro, which visually presents the devices in your security system. It
uses a background of the area (e.g. a picture or a map) as the
interface for monitoring.
To add an eMap
1.
On the View Setting window, click New.
2.
Enter an eMap name.
3.
Click Browse to select a Picture File from your computer.
Picture will display in the Preview window.
4.
Click Save and click OK to apply the settings.
5.
Click Camera Location to assign the camera location.
6.
The following screen appears.
7.
Select the camera from the list and then click the position on
the map. The camera icon
will be displayed on map.
8.
Click Save when complete.
To modify/remove an eMap
1.
To edit the eMap: In the eMap List, select the map name from
eMap list, and click Modify.
The map’s information will display on the preview windows. After
changes the setting information, click Save to save the setting.
2.
To delete the eMap: In the eMap List, select the desired one and
click Remove. The selected map will be removed from the list.
 View eMap
a.
Click the
button and select eMap View.
b.

Select the map from the eMap Name list.
Camera Status Click the camera icon
, the camera Live
Monitor window will display live image on that camera.
5.2.5 System Info
 Account
Click the
System button and select Account to change the
administrator password of the system.
Enter the Current password, and then enter the new password
twice (in the Type new password and Retype password boxes).
Then click Save.
 Version
Click the
System button and select Version to view the
current firmware version of the system.
 System Setting
Click the
System button and select System Setting. Auto Scan
period can be set from 30 seconds to 100 seconds.
5.2.6 Event Settings
 Setting up Event Server
Click the
button and select Event Server to configure the
SMTP settings for email notification use.
Select the Enable SMTP option and configure the following
information correctly to start the email feature.

SMTP Server Address: Enter the mail server address.
For example, mymail.com or smtp.gmail.com or
smtp.live.com

Sender Email Address: Enter the email address of the user
who will send the email. For example, [email protected]

Authentication Mode: Select None or SMTP according to the
mail server configuration.

Sender User Name: Enter the user name to login the mail
server.

Sender Password: Enter the password to login the mail server.

Port Number: Enter the port number used for the email
server.

SSL: If the mail server requires an encrypted connection, you
should check the SSL option. For example, gmail users, please
select this option.
When completed, click Save and then select OK. The system will
automatically start the Event Service.
TIP The status of Event Service is indicated by the
icon in the system bar.
 Sending Notification to the User
Click the
button and select Address Book to assign the user
to the Address Book of the camera. The user will receive a realtime notification from the system while triggering out.
1.
On the Address Book window, click New.
2.
In the Address Book Information field, enter the Name and
Email of the user.
3.
When completed, click Save. The user will be displayed in the
Address Book List.
4.
To edit the user: In the Address Book List, select the desired
user and click Modify. The user’s information will be
displayed, where you can change the user’s information and
then click Save when completed.
5.
To delete the user: In the Address Book List, select the
desired user and click Remove. The selected user will be
removed from the list.
 Configuring Event Trigger
Click the
button and select Event Trigger to configure the
trigger out function of the camera.
1.
On the Event Trigger window, select the desired camera from
the Camera List.
2.
Do one of the following:
 SMTP: Select this option and enter the Subject and
Message, the system will send an email message to the
selected user(s) in the Address Book List.
 Play Sound: Select this option select a sound file from the
computer, so that the system will alarm by the sound
while triggering out.
 eMap Popup: Select this option and select the eMap
profile from the pull-down menu. The camera view of the
eMap will be displayed while triggering out.
5.2.7 Close Program
When you have finished operating, click the
button and select Logout
to logout the system or Close to exit the program.
C HAPTER 6
How to access the camera behind a Router
You can either setup the Dynamic DNS connection via camera itself or your
home router. An account from any of the listed DDNS providers is required
prior to this operation.
Configure DDNS on your Camera
1.
Go to Camera’s DDNS Setting page, click Enable to activate
the feature. Then select a DDNS provider from the list.
2.
Enter your DDNS’s the Host Name, User Name and Password.
3.
In the Port Number section, assign an HTTP port of the
camera. The default HTTP Port on the camera is 80. The
example shows above is using port number 9000.
4.
Open another web browser and go to your Router’s Web
Configuration page. (In the example, TRENDnet’s TEW-651BR
Wireless N router is used)
5.
Go to Virtual Server* section and create a new entry.
Enable: Click Enable
Name: Enter the application name (eg. CameraName)
Protocol: Select TCP
Private Port: The HTTP port that you assign on your Camera.
Public Port: The port used on remote side to access to your
Camera.
LAN Server: The local IP address of your Camera.
Then click Add to add the application.
* Please refer to your router’s user’s manual for detail Virtual
Server setting. Some router might use Port Forwarding or
Special applications for this function. The setup steps should
be very similar.
6.
Open another web browser and enter your DDNS domain and
camera’s port number.
http://yourDomainName:PortNumber
7.
Camera’s login page will appear.
Configure DDNS on your router
1.
Go to Camera’s DDNS  Ports Number section, assign a
HTTP port for your camera and click Apply.
2.
Login to your router’s web configuration page.
3.
Find the Dynamic DNS configuration section.
4.
Enable DDNS, fill out the following information and then click
Apply.
5.
Go to Virtual Server* section and create a new entry.
Enable: Click Enable
Name: Enter the application name (eg. Camera Name)
Protocol: Select TCP
Private Port: The HTTP port that you assign on your Camera.
Public Port: The port used on remote side to access to your
Camera.
LAN Server: The local IP address of your Camera.
Click Add to add the application.
* Please refer to your router’s user’s manual for detail Virtual
Server setting. Some router might use Port Forwarding or
Special applications for this function. The setup steps should
be very similar.
6.
Open another web browser and enter your DDNS domain and
camera’s port number.
http://yourDomainName:PortNumber
7.
The camera login page will appear.
C HAPTER 7
A PPENDIX
A.1 Specification
Camera
General
Image & Video
Hardware
Network
LED
Reset Button
Power
Consumption
Power
Dimension
Weight
Sensor: 1/4” color CMOS sensor
Resolution: 640 x 480 pixels
Board Lens
Focal Length: 4.6mm
Aperture (F/No): F2.6
Minimum illumination: 0.5 Lux
Diagonal viewing angle: 60 degrees
Compression: MJPEG
Exposure/white balance/Gain Control :
automatic
Resolution: up to 30ps for VGA (640x480), 30fps
for QVGA (320x240), 30fps for QQVGA (160x120)
IEEE 802.3u 10/100Mbps Fast Ethernet, AutoMDIX
Power, Link
Restore to factory default
6 Watts
5V, 2.5A external power adapter
70 x 100 x 57mm (2.7 x 3.9 x 3.0 in.)
Camera: 155g (5.5 oz.)
Stand: 135g (4.8 oz.)
Temperature
Humidity
Certifications
Requirement
Management
Interface
To Run
SecurView Pro
SecurView Pro
Network
Protocols
Wireless
Standard
Frequency
Antenna
Data Rate
(auto fallback)
Security
Output Power
Receiving
Sensitivity
Channel
Operating: 0C ~ 45C (32F ~ 113F)
Storage: -15C ~ 60C (5F ~ 140F)
Max. 85% (non-condensing)
CE, FCC
Internet Explorer 6.0 or above
Windows 7(32/64-bit), Vista(32/64-bit),
XP(32/64-bit)
Channel: supports up to 32 cameras
Record/Playback/Motion Detection
TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS,
SMTP, FTP, HTTP, PPPoE and UPnP
Based on IEEE 802.11n technology
IEEE 802.11g/b compliant
2.4 ~ 2.4835GHz
1 x 2dBi dipole antenna (Reverse-SMA
connector)
802.11n: up to 150Mbps
802.11g: up to 54Mbps
802.11b: up to 11Mbps
64/128-bit WEP, WPA/WPA2-PSK
802.11n: 15 + 1 dBm
802.11b: 15 + 1 dBm
802.11g: 18 + 1 dBm
802.11n HT20: -67dBm
802.11n HT40: -64dBm
802.11g: -70dBm
802.11b: -87dBm
1~11 (FCC), 1~13 (ETSI)
Management
Remote
Backup /
Restore
Settings
Video
Recording
Port Settings
Digital Zoom
Dynamic DNS
Time
SMTP
System log
Remote management supported
Save/retrieve configuration files
Brightness, contrast, saturation, flip, mirror
(horizontal/vertical)
Encoding type: MJPEG
Resolution: 640 x 480, 320 x 240, 160 x 120
Frame rate: 1~ 30 fps
Compression: 5 levels
Recording type: continuous, schedule or motion
detection with software
HTTP port: 80 (default)
3x
Yes
Synchronize with NTP server or set time/date
manually
SMTP mail supported up to 2 destination
accounts
100 entries
A.2 Glossary of Terms
NUMBERS
10BASE-T
10BASE-T is Ethernet over UTP Category III, IV, or V
unshielded twisted-pair media.
100BASE-TX
The two-pair twisted-media implementation of 100BASE-T is
called 100BASE-TX.
A
ADPCM
Adaptive Differential Pulse Code Modulation, a new
technology improved from PCM, which encodes analog
sounds to digital form.
AMR
AMR (Adaptive Multi-Rate) is an audio data compression
scheme optimized for speech coding, which is adopted as the
standard speech codec by 3GPP.
Applet
Applets are small Java programs that can be embedded in an
HTML page. The rule at the moment is that an applet can only
make an Internet connection to the computer form that the
applet was sent.
ASCII
American Standard Code For Information Interchange, it is the
standard method for encoding characters as 8-bit sequences
of binary numbers, allowing a maximum of 256 characters.
ARP
Address Resolution Protocol. ARP is a protocol that resides at
the TCP/IP Internet layer that delivers data on the same
network by translating an IP address to a physical address.
AVI
Audio Video Interleave, it is a Windows platform audio and
video file type, a common format for small movies and videos.
B
BOOTP
Bootstrap Protocol is an Internet protocol that can
automatically configure a network device in a diskless
workstation to give its own IP address.
C
Communication
Communication has four components: sender, receiver,
message, and medium. In networks, devices and application
tasks and processes communicate messages to each other
over media. They represent the sender and receivers. The
data they send is the message. The cabling or transmission
method they use is the medium.
Connection
In networking, two devices establish a connection to
communicate with each other.
D
DHCP
Developed by Microsoft, DHCP (Dynamic Host Configuration
Protocol) is a protocol for assigning dynamic IP addresses to
devices on a network. With dynamic addressing, a device can
have a different IP address every time it connects to the
network. In some systems, the device's IP address can even
change while it is still connected. It also supports a mix of
static and dynamic IP addresses. This simplifies the task for
network administrators because the software keeps track of
IP addresses rather than requiring an administrator to
manage the task. A new computer can be added to a network
without the hassle of manually assigning it a unique IP
address. DHCP allows the specification for the service
provided by a router, gateway, or other network device that
automatically assigns an IP address to any device that
requests one.
DNS
Domain Name System is an Internet service that translates
domain names into IP addresses. Since domain names are
alphabetic, they're easier to remember. The Internet
however, is really based on IP addresses every time you use a
domain name the DNS will translate the name into the
corresponding IP address. For example, the domain name
www.network_camera.com might translate to 192.167.222.8.
E
Enterprise network An enterprise network consists of collections of networks
connected to each other over a geographically dispersed area.
The enterprise network serves the needs of a widely
distributed company and operates the company’s missioncritical applications.
Ethernet
The most popular LAN communication technology. There are
a variety of types of Ethernet, including 10Mbps (traditional
Ethernet), 100Mbps (Fast Ethernet), and 1,000Mbps (Gigabit
Ethernet). Most Ethernet networks use Category 5 cabling to
carry information, in the form of electrical signals, between
devices. Ethernet is an implementation of CSMA/CD that
operates in a bus or star topology.
F
Fast Ethernet
Fast Ethernet, also called 100BASE-T, operates at 10 or
100Mbps per second over UTP, STP, or fiber-optic media.
Firewall
Firewall is considered the first line of defense in protecting
private information. For better security, data can be
encrypted. A system designed to prevent unauthorized access
to or from a private network. Firewalls are frequently used to
prevent unauthorized Internet users from accessing private
networks connected to the Internet, especially Intranets all
messages entering or leaving the intranet pass through the
firewall, which examines each message and blocks those that
do not meet the specified security criteria.
G
Gateway
A gateway links computers that use different data formats
together.
Group
Groups consist of several user machines that have similar
characteristics such as being in the same department.
H
HEX
Short for hexadecimal refers to the base-16 number system,
which consists of 16 unique symbols: the numbers 0 to 9 and
the letters A to F. For example, the decimal number 15 is
represented as F in the hexadecimal numbering system. The
hexadecimal system is useful because it can represent every
byte (8 bits) as two consecutive hexadecimal digits. It is easier
for humans to read hexadecimal numbers than binary
numbers.
I
Intranet
This is a private network, inside an organization or company
that uses the same software you will find on the public
Internet. The only difference is that an Intranet is used for
internal usage only.
Internet
The Internet is a globally linked system of computers that are
logically connected based on the Internet Protocol (IP). The
Internet provides different ways to access private and public
information worldwide.
Internet address
To participate in Internet communications and on Internet
Protocol-based networks, a node must have an Internet
address that identifies it to the other nodes. All Internet
addresses are IP addresses
IP
Internet Protocol is the standard that describes the layout of
the basic unit of information on the Internet (the packet) and
also details the numerical addressing format used to route the
information. Your Internet service provider controls the IP
address of any device it connects to the Internet. The IP
addresses in your network must conform to IP addressing
rules. In smaller LANs, most people will allow the DHCP
function of a router or gateway to assign the IP addresses on
internal networks.
IP address
IP address is a 32-binary digit number that identifies each
sender or receiver of information that is sent in packets across
the Internet. For example 80.80.80.69 is an IP address. When
you “call” that number, using any connection methods, you
get connected to the computer that “owns” that IP address.
ISP
ISP (Internet Service Provider) is a company that maintains a
network that is linked to the Internet by way of a dedicated
communication line. An ISP offers the use of its dedicated
communication lines to companies or individuals who can’t
afford the high monthly cost for a direct connection.
J
JAVA
Java is a programming language that is specially designed for
writing programs that can be safely downloaded to your
computer through the Internet without the fear of viruses. It
is an object-oriented multi-thread programming best for
creating applets and applications for the Internet, Intranet
and other complex, distributed network.
L
LAN
Local Area Network a computer network that spans a
relatively small area sharing common resources. Most LANs
are confined to a single building or group of buildings.
M
MJPEG
MJPEG (Motion JPEG) composes a moving image by storing
each frame of a moving picture sequence in JPEG
compression, and then decompressing and displaying each
frame at rapid speed to show the moving picture.
MPEG4
MPEG4 is designed to enable transmission and reception of
high-quality audio and video over the Internet and nextgeneration mobile telephones.
N
NAT
Network Address Translator generally applied by a router that
makes many different IP addresses on an internal network
appear to the Internet as a single address. For routing
messages properly within your network, each device requires
a unique IP address. But the addresses may not be valid
outside your network. NAT solves the problem. When devices
within your network request information from the Internet,
the requests are forwarded to the Internet under the router's
IP address. NAT distributes the responses to the proper IP
addresses within your network.
Network
A network consists of a collection of two or more devices,
people, or components that communicate with each other
over physical or virtual media. The most common types of
network are:
LAN – (local area network): Computers are in close distance to
one another. They are usually in the same office space, room,
or building.
WAN – (wide area network): The computers are in different
geographic locations and are connected by telephone lines or
radio waves.
NWay Protocol
A network protocol that can automatically negotiate the
highest possible transmission speed between two devices.
P
PCM
PCM (Pulse Code Modulation) is a technique for converting
analog audio signals into digital form for transmission.
PING
Packet Internet Groper, a utility used to determine whether a
specific IP address is accessible. It functions by sending a
packet to the specified address and waits for a reply. It is
primarily used to troubleshoot Internet connections.
PPPoE
Point-to-Point Protocol over Ethernet. PPPoE is a specification
for connecting the users on an Ethernet to the Internet
through a common broadband medium, such as DSL or cable
modem. All the users over the Ethernet share a common
connection.
Protocol
Communication on the network is governed by sets of rules
called protocols. Protocols provide the guidelines devices use
to communicate with each other, and thus they have different
functions. Some protocols are responsible for formatting and
presenting and presenting data that will be transferred from
file server memory to the file server’s net work adapter
Others are responsible for filtering information between
networks and forwarding data to its destination. Still other
protocols dictate how data is transferred across the medium,
and how servers respond to workstation requests and vice
versa. Common network protocols responsible for the
presentation and formatting of data for a network operating
system are the Internetwork Packet Exchange (IPX) protocol
or the Internet Protocol (IP). Protocols that dictate the format
of data for transferors the medium include token-passing and
Carrier Sense Multiple Access with Collision Detection
(CSMA/CD), implemented as token-ring, ARCNET, FDDI, or
Ethernet. The Router Information Protocol (RIP),a part of the
Transmission Control Protocol/Internet Protocol (TCP/IP)
suite, forwards packets from one network to another using
the same network protocol.
R
RJ-45
RJ-45 connector is used for Ethernet cable connections.
Router
A router is the network software or hardware entity charged
with routing packets between networks.
RTP
RTP (Real-time Transport Protocol) is a data transfer protocol
defined to deliver live media to the clients at the same time,
which defines the transmission of video and audio files in real
time for Internet applications.
RTSP
RTSP (Real-time Streaming Protocol) is the standard used to
transmit stored media to the client(s) at the same time, which
provides client controls for random access to the content
stream.
S
Server
It is a simple computer that provides resources, such as files
or other information.
SIP
SIP (Session Initiated Protocol) is a standard protocol that
delivers the real-time communication for Voice over IP (VoIP),
which establishes sessions for features such as audio and
video conferencing.
SMTP
The Simple Mail Transfer Protocol is used for Internet mail.
SNMP
Simple Network Management Protocol. SNMP was designed
to provide a common foundation for managing network
devices.
Station
In LANs, a station consists of a device that can communicate
data on the network. In FDDI, a station includes both physical
nodes and addressable logical devices. Workstations, singleattach stations, dual-attach stations, and concentrators are
FDDI stations.
Subnet mask
In TCP/IP, the bits used to create the subnet are called the
subnet mask.
T
(TCP/IP)
Transmission Control Protocol/Internet Protocol is a widely
used transport protocol that connects diverse computers of
various transmission methods. It was developed y the
Department of Defense to connect different computer types
and led to the development of the Internet.
Transceiver
A transceiver joins two network segments together.
Transceivers can also be used to join a segment that uses one
medium to a segment that uses a different medium. On a
10BASE-5 network, the transceiver connects the network
adapter or other network device to the medium. Transceivers
also can be used on 10BASE-2 or 10BASE-T networks to attach
devices with AUI ports.
U
UDP
The User Datagram Protocol is a connectionless protocol that
resides above IP in the TCP/IP suite
User Name
The USERNAME is the unique name assigned to each person
who has access to the LAN.
Utility
It is a program that performs a specific task.
UTP
Unshielded twisted-pair. UTP is a form of cable used by all
access methods. It consists of several pairs of wires enclosed
in an unshielded sheath.
W
WAN
Wide-Area Network. A wide-area network consists of groups
of interconnected computers that are separated by a wide
distance and communicate with each other via common
carrier telecommunication techniques.
WEP
WEP is widely used as the basic security protocol in Wi-Fi
networks, which secures data transmissions using 64-bit or
128-bit encryption.
Windows
Windows is a graphical user interface for workstations that
use DOS.
WPA
WPA (Wi-Fi Protected Access ) is used to improve the security
of Wi-Fi networks, replacing the current WEP standard. It uses
its own encryption, Temporal Key Integrity Protocol (TKIP), to
secure data during transmission.
WPA2
Wi-Fi Protected Access 2, the latest security specification that
provides greater data protection and network access control
for Wi-Fi networks. WPA2 uses the government-grade AES
encryption algorithm and IEEE 802.1X-based authentication,
which are required to secure large corporate networks.
Limited Warranty
TRENDnet warrants its products against defects in material and
workmanship, under normal use and service, for the following lengths of
time from the date of purchase.
TV-IP110WN – 3 Years Limited Warranty
Camera’s motor, AC/DC Power Adapter, Cooling Fan, and Power Supply
carry 1 year warranty.
If a product does not operate as warranted during the applicable warranty
period, TRENDnet shall reserve the right, at its expense, to repair or
replace the defective product or part and deliver an equivalent product or
part to the customer. The repair/replacement unit’s warranty continues
from the original date of purchase. All products that are replaced become
the property of TRENDnet. Replacement products may be new or
reconditioned. TRENDnet does not issue refunds or credit. Please contact
the point-of-purchase for their return policies.
TRENDnet shall not be responsible for any software, firmware,
information, or memory data of customer contained in, stored on, or
integrated with any products returned to TRENDnet pursuant to any
warranty.
There are no user serviceable parts inside the product. Do not remove or
attempt to service the product by any unauthorized service center. This
warranty is voided if (i) the product has been modified or repaired by any
unauthorized service center, (ii) the product was subject to accident,
abuse, or improper use (iii) the product was subject to conditions more
severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet within the
applicable warranty period and providing a copy of the dated proof of the
purchase. Upon proper submission of required documentation a Return
Material Authorization (RMA) number will be issued. An RMA number is
required in order to initiate warranty service support for all TRENDnet
products. Products that are sent to TRENDnet for RMA service must have
the RMA number marked on the outside of return packages and sent to
TRENDnet prepaid, insured and packaged appropriately for safe shipment.
Customers shipping from outside of the USA and Canada are responsible
for return shipping fees. Customers shipping from outside of the USA are
responsible for custom charges, including but not limited to, duty, tax, and
other fees.
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT
OPERATE AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL
BE, AT TRENDNET’S OPTION, REPAIR OR REPLACE. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL
OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY
OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH
THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDNET’S
PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING
AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE
PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY
THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR
TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR MODIFY, OR ANY
OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY
ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW
TRENDNET ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY,
WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR
INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES
OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS,
LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT
OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE,
USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF
SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR
REFUND OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS
DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY
REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the
state of California.
Some TRENDnet products include software code written by third party
developers. These codes are subject to the GNU General Public License
("GPL") or GNU Lesser General Public License ("LGPL").
Go to http://www.trendnet.com/gpl or http://www.trendnet.com
Download section and look for the desired TRENDnet product to access to
the GPL Code or LGPL Code. These codes are distributed WITHOUT
WARRANTY and are subject to the copyrights of the developers. TRENDnet
does not provide technical support for these codes. Please go to
http://www.gnu.org/licenses/gpl.txt or
http://www.gnu.org/licenses/lgpl.txt for specific terms of each license.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
