Mitsubishi Electric Robot Seminar Textbook 2D Vision Sensors for Robots Owner's Manual

Industrial Robot
Robot Seminar Textbook
2D Vision Sensors for Robots
BFP-A3659-A
MELFA robot seminar schedule
Day 1
Agenda
Seminar introduction
Orientation
■ Fundamentals of 2D vision sensors
System architecture
■ Fixed downward-facing camera
Communication settings
Lens adjustments
Break
Day 2
Time
Agenda
■ Fixed downward-facing camera
Automatic operation
Time
1 hr
20
min
■ Hand eye
Tool settings
1 hr
20
min
10
min
Break
10
min
■ Fixed downward-facing camera
Tool settings
Calibration
■ Hand eye
Calibration
1 hr
1 hr
Lunch
Lunch
■ Vision sensor commands
Status variables
■ Hand eye
Create identification jobs
Teaching
■ Fixed downward-facing camera
Create identification jobs
Teaching
Break
1 hr
50
min
10
min
Break
10
min
■ Hand eye
Manual operation
Automatic operation
■ Fixed downward-facing camera
Manual operation
1 hr
35
min
1 hr
55
min
End
1 hr
40
min
End
Teaching of the robot should only be performed by individuals who have undergone special
safety training.
same applies to maintenance work with the robot power ON.)
→ Conduct safety education.
Prepare work regulations indicating robot operation methods and procedures, and measures to
be taken when errors occur or when rebooting robots. Observe these rules at all times.
(The same applies to maintenance work with the robot power ON.)
→ Prepare work regulations.
Only teach the robot after first equipping the controller with a device capable of stopping
operation immediately.
(The same applies to maintenance work with the robot power ON.)
→ Equip the controller with an Emergency Stop button.
Notify others that the robot is being taught by affixing a sign to the Start switch.
(The same applies to maintenance work with the robot power ON.)
→ Indicate that the robot is being taught.
Install fences or enclosures around robots to prevent contact between robots and workers
during operation.
→ Install safety fences.
Stipulate a specific signaling method to be used among related workers when starting
operation.
→ Operation start signal
Shut off the power when maintaining the robot. Notify others that the robot is under
maintenance by affixing a sign to the Start switch.
→ Indicate that maintenance work is being performed.
Before starting operation, conduct an inspection of robots, Emergency Stop buttons, and any
other related devices to ensure that there are no abnormalities.
→ Inspection before starting operation
The following precautions are taken from the separate Safety Manual.
Refer to the Safety Manual for further details.
Design interlocks such as individual device operation rights when operating the robot
automatically with multiple control devices (GOTs, programmable controllers and push-button
switches).
Only use robots within environments stipulated in the specifications.
Failure to observe this may result in decreased reliability or breakdown.
(Temperature, humidity, atmosphere, noise environment, etc.)
Only transport robots in the manner stipulated.
Failure to observe this may result in bodily injury or breakdown if the robot is dropped.
Caution Install and use the robot on a secure and stable platform.
Positional displacement or vibrations may occur if the robot is unstable.
Ensure that cables are kept as far apart from noise sources as much as possible.
Positional displacement or malfunction may occur if cables are close to noise sources.
Do not apply excessive force to connectors, or bend cables too much.
Failure to observe this may result in contact failures or wire damage.
Ensure that the weight of the workpiece, including the hand, does not exceed the rated load
or permissible torque.
Failure to observe this may result in alarms or breakdown.
Ensure that hands and tools are attached properly, and that workpieces are gripped securely.
Failure to observe this may result in bodily injury or property damage if objects are sent flying
or released during operation.
Ground the robot and controller properly.
Failure to observe this may result in malfunction due to noise, or even electric shock.
Ensure that the robot's operation status is displayed during operation.
Failure to display the robot's operating status may result in operators approaching the robot,
potentially leading to incorrect operation.
If performing teaching work inside the robot operation range, always ensure complete control
over the robot beforehand. Failure to observe this may result in bodily injury or property
damage if the robot is able to start with external commands.
Jog the robot with the speed set as low as possible, and never take your eyes off the robot.
Failure to observe this may result in collision with workpieces or surrounding equipment.
Always check robot movement in step operation before commencing auto operation following
program editing.
Failure to observe this may result in collision with surrounding equipment due to programming
mistakes, etc.
Ensure that the door of the safety fence locks or that the robot automatically stops if
someone attempts to open it during auto operation.
Failure to observe this may result in bodily injury.
Do not perform unauthorized modifications or use maintenance parts other than those
stipulated.
Failure to observe this may result in breakdown or malfunction.
When moving the robot arm by hand, never insert hands or fingers into openings. Depending
on the posture of the robot, hands or fingers may become jammed.
Do not stop the robot or perform an emergency stop by turning OFF the main power of the
robot controller.
Robot accuracy may be adversely affected if the main power of the robot controller is turned
OFF during auto operation. Furthermore, the robot arm may collide with surrounding
equipment if it falls or moves under its own inertia.
When rewriting internal robot controller information such as programs or parameters, do not
turn OFF the main power of the robot controller.
If the main power of the robot controller is turned OFF while rewriting programs or
parameters during auto operation, internal robot controller information may be corrupted.
Do not connect a Handy GOT when using this product's GOT direct connection function. The
Handy GOT can operate the robot automatically regardless of whether the operation rights are
enabled or disabled. This could lead to property damage or bodily injury.
Do not connect a Handy GOT to a programmable controller when using iQ Platform
compatible products with CR800-R or CR800-Q controllers. The Handy GOT can operate the
robot automatically regardless of whether the operation rights are enabled or disabled.
This could lead to property damage or bodily injury.
Do not disconnect SSCNET III cables when either the multi CPU system or the servo
amplifier is ON. Do not look directly at light emitted from the end of SSCNET III connectors
or SSCNET III cables. Doing so may cause discomfort. (SSCNET III employs a Class 1 or
equivalent light source as specified in JISC6802 and IEC60825-1.)
Do not disconnect SSCNET III cables while the controller is ON. Do not look directly at light
emitted from the end of SSCNET III connectors or SSCNET III cables. Doing so may cause
discomfort.
(SSCNET III employs a Class 1 or equivalent light source as specified in JISC6802 and
IEC60825-1.)
Replace the caps of SSCNET III connectors after they have been disconnected to prevent
them from being adversely affected by dust and foreign matter.
Take care not to wire devices incorrectly. Incorrect wiring may cause malfunctions such as the
inability to terminate an emergency stop.
After wiring devices such as the teaching pendant Emergency Stop switch, door switch and
any emergency stop devices prepared by the customer, ensure that they are functioning
correctly to prevent accidents from occurring.
Not all commercial devices such as computers and network hubs will function correctly when
connected to the controller's USB port. They may also be affected by temperatures and
electronic noise found in FA environments.
When using commercial devices, protection against EMI (Electric-magnetic interference) and
the use of ferrite cores etc. may be required to ensure devices function correctly. Mitsubishi
Electric does not guarantee commercial devices will be compatible with our products. Neither
will we carry out maintenance on them.
If needed, create a way to keep the robot system safe from unauthorized access from
external devices connected to the network.
In addition, implement a firewall to keep the robot system safe from unauthorized access from
external devices connected to the Internet.
