Allen-Bradley
Bulletin 1203
Serial Communications
Module
(Series B)
RS232/422/483 (Using DF1 Protocol)
DH485
(Cat. No. 1203–GD2, –GK2, –GM2)
User
Manual
Important User Information
Solid state equipment has operational characteristics differing from
those of electromechanical equipment. “Safety Guidelines for the
Application, Installation and Maintenance of Solid State Controls”
(Publication SGI-1.1) describes some important differences between
solid state equipment and hard–wired electromechanical devices.
Because of this difference, and also because of the wide variety of
uses for solid state equipment, all persons responsible for applying
this equipment must satisfy themselves that each intended
application of this equipment is acceptable.
In no event will the Allen-Bradley Company be responsible or liable
for indirect or consequential damages resulting from the use or
application of this equipment.
The examples and diagrams in this manual are included solely for
illustrative purposes. Because of the many variables and
requirements associated with any particular installation, the
Allen-Bradley Company cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Allen-Bradley Company with
respect to use of information, circuits, equipment, or software
described in this manual.
Reproduction of the contents of this manual, in whole or in part,
without written permission of the Allen-Bradley Company is
prohibited.
Throughout this manual we use notes to make you aware of safety
considerations.
!
ATTENTION: Identifies information about practices
or circumstances that can lead to personal injury or
death, property damage, or economic loss.
Attentions help you:
• identify a hazard
• avoid the hazard
• recognize the consequences
Important: Identifies information that is especially important for
successful application and understanding of the product.
PLC, PLC–2, PLC–3, PLC–5, SLC, SLC 500, PanelView, RediPANEL, Data Highway Plus, and Dataliner are trademarks of
Allen-Bradley Company, Inc.
IBM is a registered trademark of International Business Machines, Incorporated.
Table of Contents
Preface
Who Should Use this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Purpose of this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents of this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Terms and Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firmware Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Device Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Allen–Bradley Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Local Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Product Assistance . . . . . . . . . . . . . . . . . . . . . . . .
Product Description
Chapter 1
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANport Device Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
P–1
P–1
P–2
P–2
P–3
P–3
P–3
P–3
P–4
P–4
P–4
P–4
1–1
1–1
1–2
1–6
Chapter 2
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Module Configuration Switches . . . . . . . . . . . . . . . . . . . . .
Switch SW1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1/DH–485 Address Selection . . . . . . . . . . . . . . . . . . . . . .
DF1 Address Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch SW2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch SW3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting the Serial Communications Module . . . . . . . . . . . . . . . . .
Enclosed Style Serial Communications Module Dimensions . . . . . .
Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1746-BAS Module Serial Connections . . . . . . . . . . . . . . . . . .
IBM PC Compatible Serial Connections . . . . . . . . . . . . . . . . .
1747–AIC Link Coupler Serial Connections . . . . . . . . . . . . . .
PLC5 Channel 0 Serial Connections . . . . . . . . . . . . . . . . . . .
SCANport Link Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1305 Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1336 PLUS and 1336 FORCE . . . . . . . . . . . . . . . . . . . . . .
1394 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SMP 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Supply Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1
2–1
2–3
2–4
2–5
2–6
2–8
2–10
2–12
2–13
2–13
2–14
2–14
2–15
2–16
2–16
2–17
2–17
2–17
2–18
ii
Table of Contents
SCANport Datalink
Operation
Chapter 3
Configuring and Interfacing
Chapter 4
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANport Datalinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Communications Module Data Table Structure . . . . . . . . . . .
Supported PCCC Command List . . . . . . . . . . . . . . . . . . . . . .
Data Table Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1 Messaging with a PLC–5/80 Example . . . . . . . . . . . . . . .
DF1 Messaging with a 1746–BAS Module Example . . . . . . . .
DH–485 Messaging with a SLC5/03 Interface . . . . . . . . . . . . .
Block Transfer Emulation
Instructions
Chapter 5
Troubleshooting
Chapter 6
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Block Transfer Status Word . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scattered Parameter Value Read . . . . . . . . . . . . . . . . . . . . . . . . .
Scattered Parameter Value Write . . . . . . . . . . . . . . . . . . . . . . . . .
Product ID Number Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter Read Full . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter Value Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter Value Write . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EE Memory Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fault Clear/Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fault Queue Entry Read Full . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fault Queue Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip Fault Queue Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED Troubleshooting Table . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications
3–1
3–1
4–1
4–1
4–2
4–3
4–9
4–9
4–11
4–13
5–1
5–1
5–2
5–4
5–6
5–8
5–11
5–12
5–13
5–15
5–16
5–18
5–19
6–1
6–1
6–2
Chapter 7
Chapter Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7–1
7–1
7–1
Preface
Preface
Read this preface to familiarize yourself with the rest of the manual.
This preface covers the following topics:
• who should use this manual
• the purpose of this manual
• terms and abbreviations
• conventions used in this manual
• safety precautions
• Allen–Bradley support
Who Should Use this
Manual
Use this manual if you are responsible for setting up and servicing
the Serial Communications Module. You must have previous
experience with and a basic understanding of communications
terminology, configuration procedures, required equipment, and
safety precautions.
To use this Serial Communications Module efficiently, you must be
able to program and operate serial communications devices, as well
as have a basic understanding of the parameter settings and functions
of the device to which you are communicating.
Purpose of this Manual
This manual is an installation and user guide for the Serial
Communications Module. The Serial Communications Module is
available for products that include the SCANport communications
port.
This manual provides you with the following:
• an overview of the Serial Communications Module
• the procedures you need to install, configure, and troubleshoot the
Serial Communications Module
For information on specific features of Allen–Bradley products
mentioned within this manual, refer to the user manual for that
product.
Important: You should read this manual in its entirety before
installing, operating, servicing, or initializing the Serial
Communications Module.
1203–5. 5 September 1995
P–2
Contents of this Manual
Chapter
Title
Contents
Preface
Describes the purpose, background, and scope of
this manual. Also specifies the audience for whom
this manual is intended.
1
Product Description
Explains the Serial Communications Module’s
features, configuration, and diagnostics.
2
Installation
Provides procedures for mounting, connecting
power, configuring switches, cabling, and
connecting hardware.
3
SCANport Datalink
Operation
Provides information for configuring SCANport
device datalinks and datalink operation.
4
Configuring and
Interfacing
Provides information about addressing, information
transfer, and sample programs.
5
Block Transfer Emulation
Instructions
Provides information for using the block transfer
emulation instructions.
6
Troubleshooting
Explains how to interpret and correct problems with
your Serial Communications Module.
7
Specifications
Provides environmental, electrical, and
communications specifications.
Related Documentation
The following documents contain additional information concerning
Allen–Bradley SLCt and PLC products. To obtain a copy, contact
your local Allen–Bradley office or distributor.
For
Read This Document
Document
Number
Data Highway/Data Highway Plus/DH–485
Communication Protocol and Command Set
1770–6.5.16
SLC 500 Modular Hardware Style
1747–NI002,
Series A
Allen–Bradley Publication Index
SD499
A glossary of industrial automation terms and abbreviations
Allen–Bradley Industrial Automation Glossary
AG–7.1
Information about the MSG block
Instruction Set Reference
6200–6.4.11
Information about configuring the PLC–5 channel 0 hardware
Hardware Installation Manual
1785–6.6.1
Information about configuring the PLC–5 channel 0 driver
Software Configuration and Maintenance
6200–6.4.6
Information about the DH–485 network
Additional information about setting up the DH–485 network on
your SLC 500
A complete listing of current Allen–Bradley documentation,
including ordering instructions. Also indicates whether the
documents are available on CD–ROM or in multi–languages.
1203–5.5 September 1995
Preface
Terms and Abbreviations
P–3
The following terms and abbreviations are specific to this product.
For a complete listing of Allen–Bradley terminology, refer to the
Allen–Bradley Industrial Automation Glossary, Publication Number
ICCG–7.1. In this manual, we refer to the:
• Variable Frequency AC Drive (Bulletin 1305, 1336 FORCE,
1336 PLUS, 1395, 1557, SMC, SMC Plus, or SMC dialog) as
the drive or SCANport device.
• Programmable Logic Controller as the Programmable Controller
or PLC.
• Earth Ground as GND.
Conventions
The following conventions are used throughout this manual:
• Bulleted lists such as this one provide information, not procedural
steps.
• Numbered lists provide sequential steps or hierarchical
information.
• Italic type is used for emphasis.
• Text in this font indicates words or phrases you should type.
Firmware Support
This manual supports communications module firmware versions
2.xx (the “xx” designator may vary). Features that work with
specific firmware versions will be denoted as such.
Safety Precautions
!
!
ATTENTION: Only personnel familiar with
SCANport devices and associated machinery should
plan or implement the installation, start–up,
configuration, and subsequent maintenance of the serial
communications module. Failure to comply may result
in personal injury and/or equipment damage.
ATTENTION: This module contains Electrostatic
Discharge (ESD) sensitive parts and assemblies. Static
control precautions are required when installing,
testing, servicing, or repairing this assembly.
Component damage may result if ESD control
procedures are not followed. If you are not familiar
with static control procedures, refer to Allen–Bradley
Publication 8000–4.5.2, Guarding Against Electrostatic
Damage or any other applicable ESD protection
handbook.
1203–5.5 September 1995
P–4
Serial Device Compatibility
Allen–Bradley Support
This Serial Communications Module is intended for use with devices
that communicate via the following protocols:
Hardware Standard
Communications Protocol
RS–232
DF1
RS–422
DF1
RS–485
DF1
DH–485
DH–485
Allen–Bradley offers support services worldwide, with over 75
Sales/Support Offices, 512 authorized Distributors, and 260
authorized Systems Integrators located throughout the United States
alone, plus Allen–Bradley representatives in every major country in
the world.
Local Product Support
Contact your local Allen–Bradley representative for:
• sales and order support
• product technical training
• warranty support
• support service agreements
Technical Product Assistance
If you need to contact Allen–Bradley for technical assistance, please
review the information in the Troubleshooting chapter first. Then
call your local Allen–Bradley representative.
1203–5.5 September 1995
Chapter
1
Product Description
Chapter Objectives
In this chapter, you will read about:
• Serial Communications Module features
• the location of configuration switches
Module Description
The Serial Communications Module is an optional interface device
designed to provide a direct digital link between serial
communications devices and any device that uses SCANport. The
current list of products that use SCANport includes: 1305, 1336
PLUS, 1336 FORCE, 1394, SMP3 controllers, and 1557 medium
voltage drives. The module connects to these products via
SCANport.
The Serial Communications Module is available in both Open style
(Figure 1.1) and Enclosed (Figure 1.2) type configurations. The
Open style module mounts inside certain drives, depending on drive
size. The Enclosed module mounts independently and can be used
with any SCANport device. The following table provides more
information about the Open and Enclosed styles.
Designation
Enclosure
Power Supply Source
Used With
Open Style
Open PC Board
Supplied by the drive
1336 PLUS*
1336 FORCE**
1394***
Enclosed
IP30
24V DC separately supplied or
120/240V AC separately supplied
1305
1336 PLUS
1336 FORCE
1394
SMP3
Other SCANport products
* 7.5HP and higher sizes only, excluding the AQF and BRF catalog number drives
** 7.5HP and higher sizes with Standard Adapter board only
*** analog 1394 only
1203–5.5 September 1995
1–2
Product Description
SCANport Device
Compatibility
The SCANport Serial Communications Module is compatible with
the following Allen–Bradley devices:
Device
Firmware Revision
1336 PLUS
All
1336 FORCE
All
1305 Micro Drive
2.0 or newer
SMC
SMP
1394
1557
1203–5.5 September 1995
Product Description
1–3
Figure 1.1
Open Style Communications Module
J4
SW1.1 – SW1.2 = Protocol select
SW1.3 – SW1.8 = Adapter address
1
2
3
4
5
6
7
8
SW2.1 – SW2.3 = Baud rate selection
SW2.4 = Parity enable
SW2.5 = Parity sense (even/odd)
SW2.6 = Stop bits
SW2.7 = Point-to-point/multi-drop
SW2.8 = CRC/BCC check
1
2
3
4
5
6
7
8
SW2
1
2
3
4
5
6
7
8
SW3
SW3.1 = Logic command/status and
reference/feedback
SW3.2 = Datalink A settings
SW3.3 = Datalink B settings
SW3.4 = Datalink C settings
SW3.5 = Datalink D settings
SW3.6 = Duplicate message detection
SW3.7, SW3.8 = Application timeout
default value
SW1
Serial
Communications
Module
J2
LED Indicators
TX (Adapter transmit) when flashing
Serial Status
1. LED off: adapter power removed
2. LED flashing green: link OK, off–line
3. LED solid green: link OK, on–line
4. LED flashing red: was on–line, now off–line
5. LED solid red: fault
SCANport Status
1. LED off: adapter power removed
2. LED flashing green: link OK, not connected
3. LED solid green: link OK, connected
4. LED flashing red: was connected, now not connected
5. LED solid red: fault
9-Pin D-shell
RX (Adapter receive)
when flashing
AB0394C
1203–5.5 September 1995
1–4
Product Description
Figure 1.2
Enclosed Style Serial-to-SCANport Communications Module
SCANport
connector
Serial channel
D-shell connector
Power
connection
Diagnostic
LEDs
RX
SCANport Status
1. LED off: adapter power removed
2. LED flashing green: link OK, not connected
3. LED solid green: link OK, connected
4. LED flashing red: was connected, now not connected
5. LED solid red: fault
TX
Serial Status
1. LED off: adapter power removed
2. LED flashing green: link OK, off–line
3. LED solid green: link OK, on–line
4. LED flashing red: was on–line, now off–line
5. LED solid red: fault
Switch SW3
– Logic command/status and
reference/feedback
– Datalink A, B, C, D settings
– Application timeout
Default value
– Duplicate message detection
O
Switch SW2
– Baud rate selection
– Parity enable
– Parity sense (even/odd)
– Stop bits
– Point-to-point/multi-drop
– CRC/BCC check
8 SW3 1
8 SW2 1
Bottom View
1203–5.5 September 1995
Switch SW1
– Protocol select
– Adapter address
8 SW1 1
O
AB0415B
Product Description
1–5
Figure 1.3
Typical Serial Communications/SCANport Device Interconnect
PLC
Open Style
Comm
Module
..
.
1336 PLUS
Serial port
1305
Micro
Drive
PC
SCANport
Serial communications link
Serial
Communications
Module
SLC 5/03
SLC 5/03 CPU
SMP 3
SCANport
Serial
Communications
Module
Other serial
devices
AB0396C
1203–5.5 September 1995
1–6
Product Description
Configuration Switches
The Serial Communications Module contains three DIP Switches:
SW1, SW2, and SW3 (Figure 1.1 and Figure 1.2). Switches are set
ON or OFF as shown in Figure 1.4. For a detailed explanation of
switch configuration, refer to Chapter 2.
Figure 1.4
Configuration Switches
Rocker switch
Side view of typical
switches
Open
Side switch
Open
Open (Off)
Open
Switch designation as
shown in this manual
Close (On)
Off
Open
On
AB0397A
1203–5.5 September 1995
Chapter
2
Installation
Chapter Objectives
In this chapter, you will learn how to:
•
•
•
•
•
set the module configuration switches
mount the Serial Communications Module
connect the cables
connect the SCANport link
connect the power supply
Read this chapter completely before you attempt to install or
configure your Serial Communications Module. Double check all
connections and option selections before you apply power.
Important: Switch selections take effect only on power–up. If you
change selections after power is applied, cycle the
power to use the new settings.
Setting Module
Configuration Switches
When making configuration changes to the Serial Communications
Module, use the addressing conventions of the PLC/SLC processor
or serial device through which you are communicating. In all cases,
each serial device must have a unique address that the target
processor can recognize.
!
!
!
ATTENTION: When changing the switch settings,
use a blunt, pointed instrument such as a ball point pen.
Do not use a pencil because the lead (graphite) of the
pencil may damage the switch assembly.
ATTENTION: Failure to check connections and
switch settings for compatibility with your application
when configuring the communications module could
result in personal injury and/or equipment damage due
to unintended or undesirable operation.
ATTENTION: It is recommended that when a system
is configured for the first time, you should disconnect
the motor from the machine or process during the
initial testing.
This publication describes switches as being either on or off. If the
switch assembly has the word OPEN printed on it, the word OPEN
corresponds to OFF (0).
"
If a switch is shown as gray, then that switch does not affect the
function being covered.
1203–5.5 September 1995
2–2
Installation
Factory Switch Settings
The following table shows the switch settings that are set at the
factory:
Switch
Setting
Communication Mode
SW3–8
SW3–7
Off
Off
Default application timeout disabled
SW3–6
Off
Duplicate message detection disabled
SW3–5
Off
Datalink D disabled
SW3–4
Off
Datalink C disabled
SW3–3
Off
Datalink B disabled
SW3–2
Off
Datalink A disabled
SW3–1
Off
Logic command/status and
reference/feedback disabled
SW2–8
Off
BCC checksum
SW2–7
Off
Point–to–point
SW2–6
Off
1 stop bit
SW2–5
Off
Even parity (if enabled)
SW2–4
Off
Parity disabled
SW2–3
On
9600 baud
SW2–2
On
SW2–1
Off
SW1–8
Off
SW1–7
SW1–6
SW1–5
SW1–4
SW1–3
Off
Off
Off
Off
On
SW1–2
Off
SW1–1
Off
Module address = 1
RS–232 (DF1 protocol)
These switches can be visually represented as follows:
SW3
O
–
8 7 6 5 4 3 2 1
1203–5.5 September 1995
SW2
O
–
SW1
O
–
8 7 6 5 4 3 2 1
8 7 6 5 4 3 2 1
Installation
2–3
Switch SW1
Switch SW1 is used to select:
• serial communications mode (RS–232/RS–422/RS–485/DH–485)
• Serial Communications Module address
SW1
O
F
F
O
N
8
7
6
5
4
3
Communications
Module Address
2
1
Protocol
Selection
AB0398B
Use SW1–1 and SW1–2 to select the communications protocol you
are using:
Switch Value
(Decimal)
0
SW1
O
–
Protocol
RS–232 (DF1 protocol)
8 7 6 5 4 3 2 1
1
O
–
RS–422 (DF1 protocol)
8 7 6 5 4 3 2 1
2
O
–
RS–485 (DF1 protocol)
8 7 6 5 4 3 2 1
3
O
–
DH–485
8 7 6 5 4 3 2 1
1203–5.5 September 1995
2–4
Installation
Use SW1–3, SW1–4, SW1–5, SW1–6, SW1–7, and SW1–8 to set
your address for the Serial Communications Module. The following
table provides the switch settings for selecting the serial device
addressing.
"
Note: If you are using the DH–485 communications mode, the
highest serial device address you can select is 31 (decimal).
DF1/DH–485 Address Selection
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
Module
Address
(Decimal)
0
1
Module
Address
(Octal)
SW1
0
O
–
1
O
–
O
F
F
O
N
Module
Address
(Decimal)
Module
Address
(Octal)
16
20
O
–
21
O
–
22
O
–
23
O
–
24
O
–
25
O
–
26
O
–
27
O
–
30
O
–
31
O
–
32
O
–
33
O
–
34
O
–
35
O
–
36
O
–
37
O
–
SW1
8 7 6 5 4 3 2 1
8 7 6 5 4 3 2 1
17
8 7 6 5 4 3 2 1
2
2
O
–
8 7 6 5 4 3 2 1
18
8 7 6 5 4 3 2 1
3
3
O
–
8 7 6 5 4 3 2 1
19
8 7 6 5 4 3 2 1
4
4
O
–
8 7 6 5 4 3 2 1
20
8 7 6 5 4 3 2 1
5
5
O
–
8 7 6 5 4 3 2 1
21
8 7 6 5 4 3 2 1
6
6
O
–
8 7 6 5 4 3 2 1
22
8 7 6 5 4 3 2 1
7
7
O
–
8 7 6 5 4 3 2 1
23
8 7 6 5 4 3 2 1
8
10
O
–
8 7 6 5 4 3 2 1
24
8 7 6 5 4 3 2 1
9
11
O
–
8 7 6 5 4 3 2 1
25
8 7 6 5 4 3 2 1
10
12
O
–
8 7 6 5 4 3 2 1
26
8 7 6 5 4 3 2 1
11
13
O
–
8 7 6 5 4 3 2 1
27
8 7 6 5 4 3 2 1
12
14
O
–
8 7 6 5 4 3 2 1
28
8 7 6 5 4 3 2 1
13
15
O
–
8 7 6 5 4 3 2 1
29
8 7 6 5 4 3 2 1
14
16
O
–
8 7 6 5 4 3 2 1
30
8 7 6 5 4 3 2 1
15
17
O
–
31
8 7 6 5 4 3 2 1
1203–5.5 September 1995
8 7 6 5 4 3 2 1
8 7 6 5 4 3 2 1
Installation
2–5
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁ
ÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
DF1 Address Selection
Module
Address
(Decimal)
Module
Address
(Octal)
32
40
–
41
O
–
SW1
O
F
F
O
N
Module
Address
(Decimal)
Module
Address
(Octal)
48
60
O
–
61
O
–
62
O
–
63
O
–
64
O
–
65
O
–
66
O
–
67
O
–
70
O
–
71
O
–
72
O
–
73
O
–
74
O
–
75
O
–
76
O
–
77
O
–
O
SW1
8 7 6 5 4 3 2 1
33
8 7 6 5 4 3 2 1
49
8 7 6 5 4 3 2 1
34
42
O
–
8 7 6 5 4 3 2 1
50
8 7 6 5 4 3 2 1
35
43
O
–
8 7 6 5 4 3 2 1
51
8 7 6 5 4 3 2 1
36
44
O
–
8 7 6 5 4 3 2 1
52
8 7 6 5 4 3 2 1
37
45
O
–
8 7 6 5 4 3 2 1
53
8 7 6 5 4 3 2 1
38
46
O
–
8 7 6 5 4 3 2 1
54
8 7 6 5 4 3 2 1
39
47
O
–
8 7 6 5 4 3 2 1
55
8 7 6 5 4 3 2 1
40
50
O
–
8 7 6 5 4 3 2 1
56
8 7 6 5 4 3 2 1
41
51
O
–
8 7 6 5 4 3 2 1
57
8 7 6 5 4 3 2 1
42
52
O
–
8 7 6 5 4 3 2 1
58
8 7 6 5 4 3 2 1
43
53
O
–
8 7 6 5 4 3 2 1
59
8 7 6 5 4 3 2 1
44
54
O
–
8 7 6 5 4 3 2 1
60
8 7 6 5 4 3 2 1
45
55
O
–
8 7 6 5 4 3 2 1
61
8 7 6 5 4 3 2 1
46
56
O
–
8 7 6 5 4 3 2 1
62
8 7 6 5 4 3 2 1
47
57
O
–
8 7 6 5 4 3 2 1
63
8 7 6 5 4 3 2 1
8 7 6 5 4 3 2 1
1203–5.5 September 1995
2–6
Installation
Switch SW2
Switch SW2 is used to select:
•
•
•
•
•
baud rate
parity
number of stop bits
point–to–point or multi–drop
checksum mode (CRC or BCC)
SW2
O
F
F
O
N
8
7
6
5
4
Parity
setting
3
2
1
Baud rate
selection
Stop bits
Point-to-point/multi-drop
Checksum mode
AB0399A
Use SW2–3, SW2–2, and SW2–1 to select the baud rate:
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁÁ
Switch Value
(Decimal)
0
SW2
Baud Rate
110
O
–
8 7 6 5 4 3 2 1
1
300
O
–
8 7 6 5 4 3 2 1
2
600
O
–
8 7 6 5 4 3 2 1
3
O
–
4
O
–
5
O
–
6
O
–
7
O
–
1200
8 7 6 5 4 3 2 1
2400
8 7 6 5 4 3 2 1
4800
8 7 6 5 4 3 2 1
9600
8 7 6 5 4 3 2 1
19200
8 7 6 5 4 3 2 1
"
1203–5.5 September 1995
Note: For DH–485, 1200, 2400, 9600, and 19200 are the allowed
baud rates. Selecting any other baud rate will cause the module to
indicate a fault. The module cannot operate in this state.
Installation
"
2–7
Note: If you are using the DH–485 communications mode, setting
switches SW2–4, SW2–5, SW2–6. SW2–7, and SW2–8 have no
effect because this information is selected within the software.
Use SW2–5 and SW2–4 to set the parity:
SW2
O
–
Function
Parity disabled
8 7 6 5 4 3 2 1
O
–
Even parity
8 7 6 5 4 3 2 1
O
–
Odd parity
8 7 6 5 4 3 2 1
Use SW2–6 to choose between 1 stop bit and 2 stop bits:
SW2
O
–
Function
1 stop bit
8 7 6 5 4 3 2 1
O
–
2 stop bits
8 7 6 5 4 3 2 1
Use SW2–7 to choose between point–to–point and multi–drop:
SW2
O
–
Function
Point–to–point
8 7 6 5 4 3 2 1
O
–
Multi–drop
8 7 6 5 4 3 2 1
Use SW2–8 to choose between BCC checksum mode and CRC
checksum mode:
SW2
O
–
Function
BCC Checksum
8 7 6 5 4 3 2 1
O
–
CRC Checksum
8 7 6 5 4 3 2 1
1203–5.5 September 1995
2–8
Installation
Switch SW3
Switch SW3 is used to select:
•
•
•
•
logic command/status and reference/feedback
datalinks (up to four datalinks)
duplicate message detection
application timeout default value
SW3
O
F
F
O
N
8
7
6
5
4
3
2
1
Datalink message
Application timeout
enables
default values
Logic command/
Duplicate message
status and reference/
detection
feedback
AB0400B
Use SW3–1 to enable and disable the logic command/status and
reference/feedback messaging:
SW3
O
–
Function
Disable logic command/status and reference/feedback messaging.
8 7 6 5 4 3 2 1
O
–
Enable logic command/status and reference/feedback messaging.
8 7 6 5 4 3 2 1
Use SW3–2 to enable and disable Datalink A messaging:
SW3
O
–
Function
Disable Datalink A messaging.
8 7 6 5 4 3 2 1
O
–
Enable Datalink A messaging.
8 7 6 5 4 3 2 1
Use SW3–3 to enable and disable Datalink B messaging:
SW3
O
–
Function
Disable Datalink B messaging.
8 7 6 5 4 3 2 1
O
–
Enable Datalink B messaging.
8 7 6 5 4 3 2 1
1203–5.5 September 1995
Installation
2–9
Use SW3–4 to enable and disable Datalink C messaging:
SW3
O
–
Function
Disable Datalink C messaging.
8 7 6 5 4 3 2 1
O
–
Enable Datalink C messaging.
8 7 6 5 4 3 2 1
Use SW3–5 to enable and disable Datalink D messaging:
SW3
O
–
Function
Disable Datalink D messaging.
8 7 6 5 4 3 2 1
O
–
Enable Datalink D messaging.
8 7 6 5 4 3 2 1
Use SW3–6 to enable and disable duplicate message detection:
SW3
O
–
Duplicate Message Detection
Disable duplicate message detection.
8 7 6 5 4 3 2 1
O
–
Enable duplicate message detection.
8 7 6 5 4 3 2 1
Use SW3–7 and SW3–8 to set the default application timeout value.
The default value is used for application timeout unless the user
writes a value to the application timeout address in the Serial
Communications Module data table. This address is N42:3. If
power is removed, the default value is reloaded during power–up.
SW3
O
–
Application Timeout Default Value
No timeout (disabled)
8 7 6 5 4 3 2 1
O
–
1 second
8 7 6 5 4 3 2 1
O
–
30 seconds
8 7 6 5 4 3 2 1
O
–
60 seconds
8 7 6 5 4 3 2 1
In DH–485 mode, the application timeout function is as follows:
• If the application timeout is set to zero, the module will not cause
the SCANport device to fault if DH–485 communications are
disrupted.
• If the application timeout is set to a non–zero value, the module
causes the SCANport device to fault if a DH–485 device that had
sent a message to data table N41 drops off the network.
1203–5.5 September 1995
2–10
Installation
Mounting the Serial
Communications Module
The Serial Communications Module can be provided in three
mounting configurations:
• Open style board, factory installed in a drive (not available for all
drives)
• Open style board as a separate kit
• Enclosed style for panel mount or DIN rail mount
This section provides mounting information for the Open style kit
and the Enclosed style.
Open Style Communications Module Mounting Location (1336 PLUS
7.5–500HP)
1336 PLUS Main Control Board
Human
Interface
Module
U44
Open Serial Communications
Module Mounts Here
Memory
Module
J3
U50
SCANport
Port 6
U54 U56
J4
L OPTION
J9
Mounting screws
& standoffs qty 4
J7
TB2
TB1
AB0404C
1203–5.5 September 1995
Installation
2–11
Enclosed Style Communications Module Mounting Location
(1336 FORCE and 1336 PLUS Drives)
1336 FORCE
ESC
SEL
JOG
Port Expander
SCANport 2
2
4
3
5
Optional
Male–Male
Cable
Communications
Module
Communications
Module
1203–5.5 September 1995
2–12
Installation
Enclosed Style Serial
Communications Module
Dimensions
44mm
(1.75)
Enclosed Style Serial Communications Module Dimensions
DIN
DINRail
Rail
Notes:
– The enclosure requires clearance at the top and bottom
for proper cooling. Additional space is required if you want
to access the DIP switches without removing the device.
– All dimensions are given in millimeters and (inches).
70mm
(2.7)
DIN Rail
45mm
(1.8)
DIN Rail
Mounting Clip
Top View
Back View
45mm
(1.8)
25mm
(1)
76mm
(3.0)
123mm
(4.8)
DIN
Rail
DIN Rail
Front View
25mm
(1)
Side View
AB0406A
1203–5.5 September 1995
Installation
Connecting Cables
2–13
This section provides information that you need to connect the cables
to your Serial Communications Module.
Important: When connecting your cables, you should make sure
that the network is properly terminated. You should
also ground the shield at the end furthest from the Serial
Communications Module.
1746-BAS Module Serial Connections
Serial Communications Module to 1746-BAS Module
PRT1, PRT2 RS–232 Mode Port Connection Diagram
Communications Module
9-Pin D-Shell
1
COM
N.C.
6
2
TX
N.C.
7
3
RX
N.C.
8
4
N.C.
N.C.
9
5
COM
1746-BAS Module
Port Connection
5
4
9
3
8
TX
2
7
RX
1
6
N.C.
COM
N.C.
DTR
CTS
RTS
DSR
AB0401B
GND
Serial Communications Module to 1746-BAS Module
PRT1, PRT2 RS–422 Mode Port Connection Diagram
Communications Module
9-Pin D-Shell
1
COM
RXD –
RXD +
N.C.
SHIELD
N.C.
TXD +
TXD –
COM
1746-BAS Module
Port Connection
5
6
2
4
7
3
4
5
N.C.
N.C.
7
2
9
TXD +
N.C.
8
3
8
COM
9
N.C.
RXD –
RXD +
TXD –
6
1
AB0402B
GND
Serial Communications Module to 1746-BAS Module
PRT1, PRT2 RS–485 Mode Port Connection Diagram
Communications Module
9-Pin D-Shell
1
COM
N.C.
N.C.
N.C.
SHIELD
N.C.
TXD/RXD +
TXD/RXD –
COM
2
3
4
5
1746-BAS Module
Port Connection
5
6
4
7
3
8
2
9
1
9
8
7
6
COM
TRXD +
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
TRXD –
AB0403B
GND
1203–5.5 September 1995
2–14
Installation
IBM PC Compatible Serial Connections
RS–485/RS–422/RS–232 Communications Adapter to IBM AT
Compatible Computer RS–232 Serial Port Connection Diagram
IBM AT Compatible
Personal Computer Computer Internal
RS232 Serial Port Jumper Connectors
Communications Module
9-Pin D-Shell
1
COM
N.C.
TX
N.C.
RX
N.C.
N.C.
N.C.
COM
2
3
4
5
6
7
8
9
5
4
9
3
8
2
1
7
6
COM
RI
DTR
CTS
TX
RTS
RX
DSR
DCD
AB0409D
GND
1747–AIC Link Coupler Serial Connections
Serial Communications Module to 1747–AIC Link Coupler
PRT1, PRT2 DH–485 Mode Port Connection Diagram
Communications Module
9-Pin D-Shell
1
COM
N.C.
N.C.
N.C.
SHIELD
N.C.
TRXD+
TRXD–
COM
1203–5.5 September 1995
2
3
4
5
6
7
8
9
Phoenix 6–Point Connector
1747–AIC Link Coupler
TERM
A
B
COMMON
SHLD
CHS GND
Installation
2–15
PLC5 Channel 0 Serial Connections
Serial Communications Module to PLC5 RS–232
Serial Port Connection Diagram
PLC5/20, 5/40, 5/60, 5/80
Channel 0
Communications Module
9-Pin D-Shell
1
2
1
COM
N.C.
TX
N.C.
RX
N.C.
N.C.
N.C.
COM
2
3
4
5
3
6
4
7
5
8
6
9
7
8
C.GND
N.C.
14
TXD
15
RES
RXD
16
N.C.
RTS
17
RES
CTS
18
RES
DER
19
N.C.
SG.GND
DTR
DCD
RES
RES
N.C.
N.C.
N.C.
RES
RES
RES
RES
N.C.
20
21
9
22
10
23
11
24
12
25
13
AB0486B
SLC 5/03 Port 1 Serial Connections
Communications Module
9-Pin D-Shell
1
COM
N.C.
TX
N.C.
RX
N.C.
N.C.
N.C.
COM
2
3
4
5
6
7
8
9
SLC 5/03 RS–232 Port
5
4
9
COM
N.C.
DTR
3
8
2
1
7
6
CTS
TX
RTS
RX
DSR
DCD
AB0411B
1203–5.5 September 1995
2–16
Installation
SCANport Link
Connection
Cable Requirements
SCANport cables are available in either male–to–male or male–to–
female configuration. You can connect cables of up to 10 meters (33
feet) from the master to the SCANport device (A in the figure
below). If you use a Port Expander (as shown in the figure below),
you need to subtract the cable length from the master to the Port
Expander from the cable length used to connect the device to the
expander (B1 + C = a maximum of ten meters).
1305 Drive
An Allen-Bradley SCANport link cable is used to connect the Serial
Communications Module to the drive (as shown below).
SCANport Connection on Serial Communications Module
1305 Drive
Port Expander
Port 2
C
Port 1
A
Optional
Male–Female
Cable
Human Interface
Module
2
4
3
5
B1
Communications
Module
B2
Optional
Male–Male
Cable
Communications
Module
AB0407B
Important: The maximum cable distance between any two devices
cannot exceed 10 meters (33 feet) of cable.
For example:
1203–5.5 September 1995
A + B1 + C ≤ 10 meters
A + B2 + C ≤ 10 meters
B1 + B2 ≤ 10 meters
Installation
2–17
1336 PLUS and 1336 FORCE
Refer to the product manual for connection information. On larger
horsepower 1336 PLUS and FORCE drives with an open Serial
Communications Module mounted in the drive, you do not need a
separate SCANport cable connection.
Connection information for the 1336 PLUS and 1336 FORCE is
shown on page 2–11.
Important: The maximum cable distance between any two devices
cannot exceed 10 meters (33 feet) of cable.
1394
Refer to the product manual for connection information.
SMP 3
An Allen-Bradley SCANport cable is used to connect the Serial
Communications Module to an SMP3.
Important: The maximum cable distance between any two devices
cannot exceed 10 meters (33 feet) of cable.
SCANport Connection on Serial Communications Module
SMP3
Connection
Port 1
SMP 3
Port 2
Human Interface
Module
Enclosed
Communications Module
AB0408B
1203–5.5 September 1995
2–18
Installation
Power Supply
Connections
The Enclosed Communications Module is powered from a separate
24V DC or 115/230V AC power supply (as shown below). With the
Open Style Communications Module board mounted in the drive, no
separate power supply connections are required.
Typical Power Supply Connection
115/230V
Typical
Connection
115V AC Hi
115V AC Low
L
N
G
GND
Enclosed
Communications Module
24V DC
Typical
Connection
24V
DC
Power
Supply
+
_
+
–
G
GND
Enclosed
Communications Module
AB0413B
1203–5.5 September 1995
Chapter
3
SCANport Datalink Operation
Chapter Objectives
In this chapter, you will read about SCANport Datalinks.
SCANport Datalinks
A Datalink is a type of pointer function used by some SCANport
devices to transfer parameter values to and from the SCANport
device. The Datalink function transfers parameters on a regular
schedule. Reading a parameter using the Datalink function (data
table N41) requires less time than reading a parameter using the
Parameter Value Read data table addresses (data tables N10 – N19 or
N50 – N89) because the module is kept updated on the parameter
value.
SCANport devices that support this function have a group of
parameters for Datalink configuration. These parameters are
identified as Datalink In and Datalink Out parameters. To enable the
Datalink functions, you need to:
1. Set the correct switch to Enable on SW3 of the Serial
Communications Module.
2. Configure the Datalink In and Datalink Out parameters in the
SCANport device.
Each Datalink consists of two 16-bit words of input and two 16-bit
words of output. You can configure each of the two input words to
write to a different destination parameter within the SCANport
device by setting the two Datalink In parameters for that Datalink to
the desired destination parameters. Similarly, you can configure each
of the two output words by setting the two Datalink Out parameters
for that Datalink.
Each Datalink switch on SW3 can enable or disable one Datalink.
• If a Datalink is enabled, the value of the parameters set into the
Datalink Out parameters is transferred to the Serial
Communications Module and the data sent by the Serial
Communications Module for the Datalink is transferred into the
parameters set into the Datalink In parameters.
• If a Datalink is not enabled, the data transferred to the SCANport
device for that Datalink is zero and the Serial Communications
Module ignores any data sent by the SCANport device.
If no Datalink In parameter is configured for an input word, that
word is ignored. If no Datalink Out parameter is configured for an
output word, the output word is undefined (usually set to zero).
1203–5.5 September 1995
3–2
SCANport Data Link Operation
1203–5.5 September 1995
Chapter
4
Configuring and Interfacing
Chapter Objectives
This chapter provides you with information on how the Serial
Communications Module communicates with a serial device. The
following topics are explained:
• Serial Communications Module data table structure
• configuration examples
!
Serial Communications
Module Data Table
Structure
ATTENTION: When you configure a system for the
first time, you should disconnect the motor from the
machine or the process during the initial testing.
The Serial Communications Module maintains a data table that
allows the module to communicate with serial devices using standard
PCCC commands.
1203–5.5 September 1995
4–2
Configuring and Interfacing
Supported PCCC Command List
The Serial Communications Module supports the following PCCC
Commands:
CMD Code
FNC Code
01h
n/a
Unprotected read
PLC–2 address
06h
00h
Echo
n/a
01h
Read diagnostic counters
Variable (modified PLC–2 addresses)
02h
Set variables (#ENQs, #NAKs, TIMEOUT)
n/a
03h
Identify host and some status
n/a
04h
Set timeout
n/a
05h
Set #NAKs
n/a
06h
Set #ENQs
n/a
07h
Reset diagnostic counters
n/a
09h
Read link parameters
Logical address
0Ah
Set link parameters
Logical address
08h
n/a
Unprotected write
PLC–2 address
0Fh
67h
Typed write
System address (4 possibilities)
68h
Typed read
System address (4 possibilities)
A1h
Protected typed logical read with two
address fields
File number/type/element number
A2h
Protected typed logical read with three
address fields
File number/type/element
number/sub–element number
A9h
Protected typed logical write with two
address fields
File number/type/element number
AAh
Protected typed logical write with three
address fields
File number/type/element number/
sub–element number
ABh
Protected typed logical write with four
address fields
File number/type/element number/
sub–element number/bit mask
1203–5.5 September 1995
Command Name
PLC Addressing Method
Configuring and Interfacing
4–3
Data Table Structure
The Serial Communications Module provides the following data
table structures for DF1 and DH–485.
The following table is the drive control table (binary file).
"
File
Address
Description
File
Address
Description
B3:0
Logic Command
B3:10
Logic Status
B3:1
Reference
B3:11
Feedback
B3:2
Datalink A1 In (to Drive)
B3:12
Datalink A1 Out (from Drive)
B3:3
Datalink A2 In (to Drive)
B3:13
Datalink A2 Out (from Drive)
B3:4
Datalink B1 In (to Drive)
B3:14
Datalink B1 Out (from Drive)
B3:5
Datalink B2 In (to Drive)
B3:15
Datalink B2 Out (from Drive)
B3:6
Datalink C1 In (to Drive)
B3:16
Datalink C1 Out (from Drive)
B3:7
Datalink C2 In (to Drive)
B3:17
Datalink C2 Out (from Drive)
B3:8
Datalink D1 In (to Drive)
B3:18
Datalink D1 Out (from Drive)
B3:9
Datalink D2 In (to Drive)
B3:19
Datalink D2 Out (from Drive)
Note: If you write to B3:0 through B3:9, you will write data to the
drive. If you read from B3:0 through B3:9, you will return the data
being currently sent to the drive. If you read from B3:10 through
B3:19, you will read data from the drive. If you write to B3:10
through B3:19, you will receive an error.
The following table is the drive control table (integer file).
"
File Address
Description
N41:0
Logic Command/Status
N41:1
Reference/Feedback
N41:2
Datalink A1
N41:3
Datalink A2
N41:4
Datalink B1
N41:5
Datalink B2
N41:6
Datalink C1
N41:7
Datalink C2
N41:8
Datalink D1
N41:9
Datalink D2
Note: If you write to any location in N41, you will write data to the
drive. If you read from any location in N41, you will read data from
the drive.
1203–5.5 September 1995
4–4
Configuring and Interfacing
Important: The following two tables list the typical control and
status structure. You should refer to your drive manual
for the actual control and status structures for your
device.
The following are the bit definitions for B3:0 or writes to N41:0:
Bit
Description
Bit
Description
00
Stop
10
Acceleration time
01
Start
11
Acceleration time
02
Jog
12
Deceleration time
03
Clear faults
13
Deceleration time
04
Direction
14
Reference select
05
Direction
15
Reference select
06
Local
16
Reference select
07
MOP increment
17
MOP decrement
The following are the bit definitions for B3:10 or reads from N41:0:
1203–5.5 September 1995
Bit
Description
Bit
Description
00
Enabled
10
At speed
01
Running
11
Local
02
Command direction
12
Local
03
Actual direction
13
Local
04
Accelerating
14
Reference select
05
Decelerating
15
Reference select
06
Alarm
16
Reference select
07
Faulted
17
Reference select
Configuring and Interfacing
4–5
The following is the data table structure for PLC–2 style addressing:
Parameter
Number
1 – 7039
1 – 7039
"
PLC–2 Style Address
Decimal (Octal)
512 + Parm #
(1000 to 16577)
(16600 to 167770
Description of Location’s Purpose
Parameter value read
Status of last parameter write
7680 + Parm #
(17000 to 34577)
(34600 to 34677)
Block transfer emulation area
(34700)
Logic command/status
(34701)
Reference/feedback
(34702)
Datalink A1
(34703)
Datalink A2
(34704)
Datalink B1
Parameter read full
(34705)
Datalink B2
(34706)
Datalink C1
(34707)
Datalink C2
(34710)
Datalink D1
(34711)
Datalink D2
(34712)
#ENQs
(34713)
#NAKs
(34714)
Message TIMEOUT (mS)
(34715)
Application TIMEOUT (seconds)
(34716)
Adapter series number (2=B)
(34717)
Adapter firmware version (201=FRN2.01)
(34720)
Maximum node address (DH–485)
(34721 to 37677)
Reserved area for future expansion
(37700 to 37777)
System area
Note: The address locations shown in this table are not limited to
PLC–2 commands and may be used by any device that can generate
them.
1203–5.5 September 1995
4–6
Configuring and Interfacing
The following is the data table structure for the Serial
Communications Module:
Parameter Number
File Addresses
Description of Location’s Purpose
1 – 999
1000 – 1999
N10:1 – 999
N11:0 – 999
Parameter
–
–
value
8000 – 8999
N18:0 – 999
read or write
9000 – 9999
N19:0 – 999
1 – 249
N50:1 – 249
250 – 499
N51:0 – 249
–
–
value
9500 – 9749
N88:0 – 249
read or write
9750 – 9999
N89:0 – 249
N20:0 – 127
"
1203–5.5 September 1995
Parameter
Status of last parameter write
1–999
N30:1 – 999
1000 – 1999
N31:0 – 999
Parameter
–
–
read
8000 – 8999
N38:0 – 999
full
9000 – 9999
N39:0 – 999
1 – 249
N90:1 – 249
250 – 499
N91:0 – 249
Parameter
–
–
read
9500 – 9749
N128:0 – 249
full
9750 – 9999
N129:0 – 249
N40:0 – 63
Block transfer emulation area
N41:0
Logic command/status
N42:0
#ENQs
N42:1
#NAKs
N42:2
Message TIMEOUT (mS)
N42:3
Application TIMEOUT (Seconds)
N42:4
Adapter series number (2 = B)
N42:5
Adapter firmware version (201=FRN2.01)
N42:6
Maximum node address (DH–485)
System File 0
(or N200:1 – 63)
Station name (DF1)
SLC compatible system file (DH–485)
Note: Some devices cannot access an element number over 254.
The files from N50 to N129 are intended for use with those devices.
Configuring and Interfacing
4–7
The data tables have up to eight areas, each having a different
purpose.
1. Parameter Value Read or Write (N10 – N19, N50 – N89).
Reading data from files in this area will cause the Serial
Communications Module to read parameter values from the
SCANport device and send those values as the response to the
read message. Writing data to files in this area will cause the
Serial Communications Module to write that data into SCANport
device parameters.
2. Status of Last Parameter Write (N20). This area is read-only.
When read, the data returned contains status information from the
last parameter write that was performed by the Serial
Communications Module. If no errors occurred during the write,
all of the data returned will be zeros. Read this area beginning at
element number zero.
3. Parameter Read Full (N30 – N38, N90 – N129). This area is
read-only. When read, the data returned consists of 20 words (40
bytes) of information about each parameter including scaling,
parameter text, units text, minimum, maximum, and default
values. When reading this area, set the number of elements to
twenty times the number of parameters to be read.
4. Block Transfer Emulation Area (N40). This area provides a
method for sending and receiving SCANport messages to and
from the SCANport device. This allows you to perform every
SCANport command the device supports. Chapter 5 provides
information about the block transfer emulation functions
available for use with the Serial Communications Module.
To send a SCANport message, write data into this area beginning
with element number zero. Allow sufficient time for the
SCANport device to respond to the message and then read the
response message from this area beginning with element number
zero.
5. Producer/Consumer Emulation Area (N41). Each element in
this area has a different function. Refer to the DIP switch
configuration tables in Chapter 3 for more information.
– Logic Command/Status. Writing sends a Logic Command
to the drive. Reading supplies the SCANport device Logic
Status. Refer to the manual supplied with the SCANport
device for more information.
– Reference/Feedback. Writing sends a reference to the
SCANport device. Reading supplies feedback from the
SCANport device. The meaning of the reference and
feedback values depend on the type of SCANport device.
1203–5.5 September 1995
4–8
Configuring and Interfacing
– Datalink A1. Writing to Datalink A1 sends a value to the
parameter pointed to by the DataIn A1 parameter of the
SCANport device. Reading from Datalink A1 reads the
value of the parameter pointed to by the DataOut A1
parameter of the SCANport device.
– Datalink A2 through Datalink D2 function the same as
Datalink A1.
6. Serial Communications Module Parameters (N42). Each of
the four elements in this area can be read or written and affects
the operation of the Serial Communications Module as follows:
– Number of ENQ’s. The number of ENQ’s sent by the
module before giving up on receiving ACK or NAK. The
default is 3.
– Number of NAK’s. The number of times the module will
resend a message if the response is always NAK. The
default is 3.
– Message Timeout. The number of milliseconds the module
will wait before sending an ENQ. The default is 100mS.
– Application Timeout. The number of seconds the module
will wait between messages before faulting the SCANport
device it is connected to. The default is set by the
configuration DIP switches.
– Adapter Series Number. The series letter of the 1203
Serial Communications Module expressed as a number.
For example, 1=A, 2=B, and so forth.
– Adapter Firmware Version. The firmware version number
of the 1203 Serial Communications Module. For example,
201=FRN2.01, 202=FRN2.02, and so forth.
– Maximum Node Address. When in DH–485 mode, this
parameter sets the maximum node address that the adapter
will attempt to communicate with. The default value is 31
(decimal).
7. Reserved for Future Expansion. If you try a read or write to
any address in this area, the Serial Communications Module will
respond with an error message.
8. System Area. Performing a read from this area will cause the
Serial Communications Module to respond with a 22-character
string. This string is set at power-up to contain the Product Text
String from the SCANport device with /1203 appended to it.
Writing to this area changes the characters contained in the string.
Cycling power returns the string to its original text.
1203–5.5 September 1995
Configuring and Interfacing
4–9
Configuration Examples
DF1 Messaging with a PLC–5/80 Example
This example reads parameters 1 through 50.
Ladder rung example for Gx2 manual
Rung 2:0
| I:000 MG20:0
B3
+MSG––––––––––––––––––––+
|
+––] [–––]/[–––[ONS]––––––––––––––––––––––––––––+SEND/RECEIVE MESSAGE
+–(EN)–+
|
00
EN
2
|Control block
MG20:0+–(DN) |
|
|
+–(ER) |
|
+–––––––––––––––––––––––+
|
Data Table Report
MESSAGE INSTRUCTION DATA MONITOR FOR CONTROL BLOCK MG20:0
Communication Command:
PLC–5 Data Table Address:
Size in Elements:
Local/Remote:
Remote Station:
Link ID:
Remote Link Type:
Local Node Address:
Destination Data Table Address:
Port Number:
PLC–5 TYPED READ
N30:0
ignore if timed–out:
50
to be retried:
LOCAL
awaiting execution:
N/A
continuous:
N/A
error:
N/A
message done:
001
message transmitting:
N10:1
message enabled:
00
0
0
0
0
0
0
0
0
TO
NR
EW
CO
ER
DN
ST
EN
Error Code: 0000 (HEX)
1203–5.5 September 1995
4–10
Configuring and Interfacing
Notes:
• I:000/00 is any application–related conditioning logic.
• MG20:0.EN is the enabled status bit from the message block.
• B3/2 is a one-shot that causes the message to be resent each time
•
•
•
•
•
1203–5.5 September 1995
the message block completes or errors (as long as I:000/00 is
true).
The DF1 address of the PLC-5 is the same as its DH+ address (set
by DIP switch SW1 on the PLC-5).
Refer to Publication 6200–6.4.11, Instruction Set Reference, for
information on the MSG block.
Refer to Publication 1785–6.6.1, Hardware Installation Manual,
for information on configuring the PLC-5 Channel 0 hardware.
Refer to Publication 6200–6.4.6, Software Configuration and
Maintenance, for information on configuring the PLC-5 Channel
0 driver.
Only one message may be active to a Serial Communications
Module at any time. When you write the PLC program, you must
ensure this requirement.
Configuring and Interfacing
4–11
DF1 Messaging with a 1746–BAS Module Example
This example accepts a parameter number and a value from a user
terminal and writes the data out to a SCANport–compatible device.
100
101
102
103
104
105
110
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
360
370
380
390
400
410
420
430
440
450
460
461
470
475
480
481
490
500
510
520
530
540
REM _____________________________________________________________
REM __
This program inputs a parameter number and a value
rem __ from a user terminal and writes it out to a scanport
rem __ compatible device.
rem __ for 1746–BAS and 1203–GD2 modules
rem _____________________________________________________________
STRING 512,127
REM
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
REM Setup port 1 to 9600 baud, no parity, 8 bits, 1 stop bit,
REM software handshaking, and battery backed ram data storage.
REM
!!!!REMEMBER TO SET TERMINAL TO MATCH!!!!
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
MODE (PRT1,9600,N,8,1,S,R)
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
REM
REM Setup port 2 to 300 baud, no parity, 8 bits, 1 stop bit,
REM software handshaking, and battery backed ram data storage.
REM
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
MODE (PRT2,300,N,8,1,S,R)
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
REM
REM Enable DF1 driver
REM (20 = Setup for Full Duplex, Auto–Detect Embedded Responses,
REM
Disable Duplicate Packet Detection, BCC error checking)
REM (200 = Wait 1 second for polling by Master)
REM (2
= 2 retries)
REM (0= No RTS on delay)
REM (0
= No RTS off delay)
REM (8
= 1746–BAS module address)
REM ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
PUSH 20
PUSH 200
PUSH 2
PUSH 0
PUSH 0
PUSH 8
CALL 108
REM __________________ end df1 config _____________________________
Print: print ”A negative parameter number exits the program ”
INPUT ”Offset (Parameter Number)? ”,PAR_NUM
IF (PAR_NUM<0) THEN GOTO 530
INPUT ”Control (parameter value)? ”,PAR_VALUE
REM encode the value as an ASCII hex string in order of LOW, HIGH
ASC($(1),1)=PAR_VALUE–(INT(PAR_VALUE/256)*256)
ASC($(1),2)=INT(PAR_VALUE/256)
GOSUB 550 : REM fire off the write instruction
GOTO 460
CALL 113
END
1203–5.5 September 1995
4–12
Configuring and Interfacing
550
560
561
562
563
565
570
580
600
610
620
630
640
650
660
670
680
690
700
710
720
730
750
760
REM ****************************************************************
REM *********
PLC TYPED READ Subroutine
*****
REM *********
inputs Parameter number in var
PAR_NUM
*****
REM *********
ASC coded hex string of value in $(1)
*****
REM *********
outputs:
failure message
*****
REM ****************************************************************
REM subroutine to do a typed write of a single parameter
PRINT ”Executing PLC Remote Write ”
PUSH 5 : REM PLC5 Typed Write
PUSH 1 : REM Communications Module Node Address
PUSH 10 : REM File Number ( atterss is N10:PAR_NUM)
PUSH ASC(N) : REM Communications Module File Type
PUSH PAR_NUM : REM Starting Word in File
PUSH 1 : REM Number of Words to Transfer (one parameter)
PUSH 50 : REM Command Time–out (x100ms)
PUSH 2 : REM Data Source (2 = Internal String)
PUSH 0 : REM Offset in M0 file (Not used in this example)
PUSH 1 : REM String # ASCII hex number order low, high
CALL 123 : REM Builds the message to be sent
POP S
PUSH 123 : REM sets up call 29
CALL 29 : REM send the message
RETURN
REM *********** End Write parameter subroutine *********
1203–5.5 September 1995
Configuring and Interfacing
4–13
DH–485 Messaging with a SLC5/03 Interface
The following example uses the DH–485 communications mode to
send a message from an SLC5/03 to the Serial Communications
Module.
Rung 2:0
If this is the first scan or the error bit is true, the MSG instruction’s control
byte is cleared and the done bit is set. This ensures that the program always
starts correctly and recovers from a MSG error.
|
First
|
|
Scan
|
|
Bit
|
|
S:1
+AND–––––––––––––––+
|
|–+––––] [–––––+––––––––––––––––––––––––––––––––––––––+–+BITWISE AND
+–+–|
| |
15
|
| |Source A
255| | |
| |
|
| |
| | |
| |
|
| |Source B
N15:0| | |
| |
|
| |
8192| | |
| |
|
| |Dest
N15:0| | |
| |
|
| |
8192| | |
| |
|
| +––––––––––––––––––+ | |
| | MSG Block |
| MSG Block
| |
| | Error (ER) |
| Done (DN)
| |
| | Bit
|
| Bit
| |
| |
N15:0
|
|
N15:0
| |
| +––––] [–––––+
+––––(L)–––––––––––––––+ |
|
12
13
|
Rung 2:1
When the MSG instruction is done, the TON provides a 2 second delay before another
message is sent. B3:0/0 represents user logic. The timer can be adjusted to
provide control over DH485 network loading.
| User
|MSG Block
|
| DH485
|Done (DN)
|
| Enable
|Bit
|
|
B3:0
N15:0
+TON–––––––––––––––+
|
|––––] [––––––––] [––––––––––––––––––––––––––––––––––+TIMER ON DELAY
+–(EN)–|
|
0
13
|Timer
T4:0+–(DN) |
|
|Time Base
0.01|
|
|
|Preset
200|
|
|
|Accum
156|
|
|
+––––––––––––––––––+
|
1203–5.5 September 1995
4–14
Configuring and Interfacing
Rung 2:2
When the timer is done, the MSG instruction is enabled.
| TON Done –
|
| Enable
|
| MSG Block
|
|
T4:0
+MSG––––––––––––––––––––+
|
|––––] [––––––––––––––––––––––––––––––––––––––––+READ/WRITE MESSAGE
+–(EN)–|
|
DN
|Type
PEER–TO–PEER+–(DN) |
|
|Read/Write
WRITE+–(ER) |
|
|Target Device
500CPU|
|
|
|Local/Remote
LOCAL|
|
|
|Control Block
N15:0|
|
|
|Control Block Length 14|
|
|
+–––––––––––––––––––––––+
|
Rung 2:3
|
|
|–––––––––––––––––––––––––––––––––––––+END+––––––––––––––––––––––––––––––––––––|
|
|
The following are the data tables used for this example:
Address
B3:0
Data (Radix=BINARY)
0000 0000 0000 0001
Address
T4:0
EN
1
TT
1
DN
0
Address
C5:0
CU
0
CD
0
DN
0
Address
N10:0
Data
(Radix=DECIMAL)
7
6
0
0
0
0
0
0
0
Address
N15:0
N15:10
Data (Radix=DECIMAL)
8192
3
9
0
0
0
10
0
137
5
0
224
10
M0:1
M0:2
M0:3
M0:4
File
File
File
File
Length:64
Length:0
Length:0
Length:0
M1:1
M1:2
M1:3
M1:4
File
File
File
File
Length:64
Length:0
Length:0
Length:0
1203–5.5 September 1995
Address
TIME BASE
.01 sec.
OV
0
UN
0
UA
0
Data
PRE
200
PRE
32767
(Radix=BINARY)
ACC
156
ACC
2778
0
Chapter
5
Block Transfer Emulation
Instructions
Chapter Objectives
This chapter contains the header and data configurations that you
need to set up the data files for the block transfer emulation
instructions. The header and data values depend on the operation
you want to perform.
Block Transfer Emulation
Status Word
When an operation is unsuccessful, header word 2 of the drive
response contains a negative value (bit 15 = 1).
In most cases, the drive also returns a status word to indicate the
reason for the failure. The location of the status word is typically
header word 4 in the drive response, but will depend on the message.
The following are valid status codes:
Value
Description
0
No error occurred.
1
The service failed due to an internal reason, and the drive could not perform
the request (some messages are read only or write only).
2
The requested service is not supported.
3
An invalid value in the block transfer emulation request header word 2.
4
An invalid value in the block transfer emulation request header word 3.
5
An invalid value in the block transfer emulation request header word 2.
6
The data value is out of range.
7
There is a drive state conflict. The drive is in an incorrect state to perform the
function. The drive cannot be running when you perform certain functions.
1203–5.5 September 1995
5–2
Scattered Parameter Value
Read
The Scattered Parameter Value Read function reads a scattered list of
parameters.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 5–63 words
Drive response instruction length: 5–63 words
Message Structure
PLC Request
Drive Response
Message Length
5–63
Header Word 1
PLC Decimal Value
3
Header Word 2
Number of Parameter
Values to Read
Data Word 3
Parameter Number
1
Data Word 4
0
Data Word 5
Parameter Number
2
1203–5.5 September 1995
Data Word 6
0
Data Word 7
Parameter Number
3
Data Word 8
0
Data Word 9
•
•
•
•
•
•
•
•
•
•
•
•
Parameter Number
30
Data Word 62
0
Data Word 63
Message Length
5 – 63
Header
Word 1
PLC Decimal Value
3 –– Message OK
–32765 –– Message Error
Header
Word 2
Number of Parameter
Values to Read
Data
Word 3
bit
15
Parameter Number
1
Parameter Value or
Status Word
1
bit
15
Parameter Number
2
Parameter Value or
Status Word
2
bit
15
Parameter Number
3
Parameter Value or
Status Word
3
•
•
•
•
•
•
bit
15
Parameter Number
30
Parameter Value or
Status Word
30
Data
Word 4
Data
Word 5
Data
Word 6
Data
Word 7
Data
Word 8
Data
Word 9
•
•
•
•
•
•
Data
Word 62
Data
Word 63
Block Transfer Emulation Instructions
5–3
Message Operation
Scattered Parameter Value Read reads a pre–defined group of
parameter values, in any order, from the device. You define the
number of parameters to read in word 3 of the request. The
parameters to be read and their order is defined starting with word 4.
An unused word is left between each parameter request, so the drive
can respond with the parameter value, as shown.
If an error has occurred in reading any of the parameters:
• Word 2 of the drive response returns a value of –32765.
• Bit 15 of the drive response word for the number of that
parameter is set.
• The drive response word for the value of that parameter returns a
status word instead of returning the parameter value.
Example
In this example, eight parameters were read from a 1336 PLUS
drive, as defined in word 3 of the request. The parameter numbers
requested were 5, 7, 8, 20, 18, 17, 19, and 36. The drive response
returned the values of these parameters in the data file. These values
are in drive units.
Data File Format
PLC request
0
1
N10:10
19
3
8*
5*
N10:20
0
18*
0*
17*
19
3
8*
5*
4096*
18*
4096*
17*
Drive response N10:90
N10:100
2
3
4
5
6
0
7*
0
0
19*
6*
7*
51*
19*
60*
7
8
9
8*
0
20*
0
36*
0
1000*
8*
1000*
36*
6144*
20*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–4
Scattered Parameter Value
Write
The Scattered Parameter Value Write function writes to a scattered
list of parameters and returns the status of each parameter. If any of
the states have errors, the parameter number is negative.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 5–63 words
Drive response instruction length: 5–63 words
Message Structure
PLC Request
Drive Response
1203–5.5 September 1995
Message Length
5–63
Header Word 1
PLC Decimal Value
–32765
Header Word 2
Number of Parameter
Values to Write
Data Word 3
Parameter Number
1
Data Word 4
Parameter Value
1
Data Word 5
Parameter Number
2
Data Word 6
Parameter Value
2
Data Word 7
Parameter Number
3
Data Word 8
Parameter Value
3
Data Word 9
•
•
•
•
•
•
•
•
•
•
•
•
Parameter Number
30
Data Word 62
Parameter Value
30
Data Word 63
Message Length
5 – 63
Header
Word 1
PLC Decimal Value
3 –– Message OK
–32765 –– Message Error
Header
Word 2
Number of Parameter
Values to Write
Data
Word 3
bit
15
bit
15
bit
15
Parameter Number
1
Data
Word 4
Status Word 1
Data
Word 5
Parameter Number
2
Data
Word 6
Status Word 2
Data
Word 7
Parameter Number
3
Data
Word 8
Status Word 3
bit
15
Data
Word 9
•
•
•
•
•
•
•
•
•
•
•
•
Parameter Number
30
Status Word 30
Data
Word 62
Data
Word 63
Block Transfer Emulation Instructions
5–5
Message Operation
The Scattered Parameter Value Write function writes data values to a
pre–defined group of device parameters in any order. You define the
number of parameters to write in word 3. The parameters to be
written to and their order is defined starting with word 4.
If an error occurs while writing to any of the parameters:
• Word 2 of the drive response returns a value of –32765.
• Bit 15 of the drive response word for that parameter’s number is
set.
• The drive response word for that parameter’s status word is
non–zero.
If no error has occurred:
• Word 2 of the drive response returns a value of 3.
• Each of the drive response’s parameter numbers are the same as
in the request.
• Each of the drive response status words returns a value of 0.
Example
In this example, six parameters were written to in a 1336 PLUS
drive. Word 3 of the request (N10:12) defines the number of
parameter values that are transferred. Each parameter number
followed by its value, are listed in the message beginning with word
4. The values are entered in device units.
The drive response (N10:90) returns the status of each parameter
write. If the request was successful, a zero is returned. If an error
has occurred, the response returns a status word code for the error.
Data File Format
PLC request
Drive response
0
1
2
3
4
5
6
7
8
9
1*
150*
4*
30*
20*
31*
150*
0*
30*
0*
31*
N10:0
N10:20
15
–32765
6*
90*
10*
10*
2*
12*
5*
N10:90
N10:100
15
0*
6*
0*
90*
12*
0*
0*
3
10*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–6
Product ID Number Read
The Product ID Number Read function returns the product ID of the
device to which the Serial Communications Module is connected.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 4 words
Message Structure
PLC Request
Drive Response
Message Length
3
Header Word 1
PLC Decimal Value
256
Header Word 2
0
Data Word 3
Message Length
6
Header
Word 1
PLC Decimal Value
Header
Word 2
256 –– Message OK
–32512 –– Message Error
0
Header
Word 3
Product ID Number
Data
Word 4
Product ID
Number
2
3
4
5
16
17
18
19
20
21
22
23
Description
1336F (PLUS Fractional)
1336F (PLUS)
1336G (FIBERS Fractional)
1336G (FIBERS)
1336T (FORCE)
1395
1394
1557
SMP
SMC
1304
1305
Message Operation
The Product ID Number Read function, through the drive response
message word 4, indicates the type of device the Serial
Communications Module is connected to. This value is defined in
the message response chart shown above.
If an error has occurred, word 2 of the response returns a negative
value of –32512.
1203–5.5 September 1995
Block Transfer Emulation Instructions
5–7
Example
In this example, the Product ID Number Read was requested. The
drive response contained a value of 3 in word 4 of its message
response, indicating a connection to a 1336 PLUS.
Data File Format
PLC request
Drive response
N10:0
N10:90
0
1
2
3
256
0
6
256
0
3
4
5
6
7
8
9
3*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–8
Parameter Read Full
The Parameter Read Full function provides all known attributes for
the parameters requested. This information includes the parameter’s
current value, descriptor, multiply and divide value, base value,
offset value, text string, group element reference, minimum value,
maximum value, default value, and unit text string.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 20 words
Message Structure
PLC Request
Drive Response
1203–5.5 September 1995
Message Length
3
Header Word 1
PLC Decimal Value
768
Header Word 2
Parameter Number
(See Drive List)
Data Word 3
Parameter Value
or Status Word
Data
Word 1
Descriptor
Data
Word 2
Multiply Value
Data
Word 3
Divide Value
Data
Word 4
Base Value
Data
Word 5
Offset Value
Data
Word 6
Parameter Text
Char 2
Char 1
Data
Word 7
Parameter Text
Char 4
Char 3
Data
Word 8
Parameter Text
Char 6
Char 5
Data
Word 9
Parameter Text
Char 8
Char 7
Data
Word 10
Parameter Text
Char 10
Char 9
Data
Word 11
Parameter Text
Char 12
Char 11
Data
Word 12
Parameter Text
Char 14
Char 13
Data
Word 13
Parameter Text
Char 16
Char 15
Data
Word 14
Block Transfer Emulation Instructions
5–9
Message Structure (Continued)
Drive Response
File, Group, Element
Data
Word 15
Minimum Value
Data
Word 16
Maximum Value
Data
Word 17
Default Value
Data
Word 18
Unit Text
Char 2
Char 1
Data
Word 19
Unit Text
Char 4
Char 3
Data
Word 20
Message Operation
Parameter Read Full retrieves the attributes of the specified
parameter. The attributes for each parameter include the data,
minimum and maximum values, and the parameter text. The
response message returns this information.
If an error has occurred in reading any of the values, word 1 contains
the status word.
The parameter text is returned with each data word containing two
ASCII characters per word. The first and second characters are in
opposite order.
Example
In this example, a Parameter Read Full was performed through block
transfer on a 1336 PLUS. N10:10 shows the header message for the
request. The data is returned in the response data file, starting with
word 1, for parameter 20. Word 1 shows the present value in drive
units. Word 2 through word 6 provide scaling information, used to
convert drive units to engineering units for the Human Interface
Module (HIM). Word 7 through word 14 provide the parameter
name.
1203–5.5 September 1995
5–10
This example shows the response message N10:90 through N10:112
in both binary and ASCII. Note the ASCII information beginning
with N10:99. The parameter name characters return in reverse order
for each word. N10:99 has the ASCII value of (aM). To read this,
invert the word to read (Ma). The next word (ix), inverted gives you
(xi). These words, along with the following two words, form the
word Maximum. You can see the parameter name Maximum Voltage
in word 7 through word 14 of the response message. In addition,
word 20, is also returned in this format. This word provides the units
the parameter is defined in. In this example it is vlts.
Word 15 contains the file, group, and element which are used to
reference the parameter.
Words 16–18 contain the minimum, maximum, and default values of
this parameter.
Data File Format
0
1
2
3
768
20*
1*
3
4
4096*
460*
5
PLC request
N10:10
Drive response
N10:90
4096*
355*
N10:100
28502*
29804*
26465* 8293*
1794*
\01 c
t l
\00\01
g a
\01\CC \00\00
07 02 04 00
Drive response
N10:90# \10\00
N10:100# o V
\10\00
e
0*
1024*
6
8
9
24909* 27000*
30061*
8301*
4915*
4096*
27734*
29556*
a M
\13 0
i x
\10\00
u
l
m
s t
* Example only – These values vary depending on parameters and products.
# ASCII Display values
1203–5.5 September 1995
7
m
V
Block Transfer Emulation Instructions
Parameter Value Read
5–11
The Parameter Value Read function reads the 16–bit parameter data
value for the selected parameter number.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 1 word
Message Structure
PLC Request
Drive Response
Message Length
3
Header Word 1
PLC Decimal Value
769
Header Word 2
Parameter Number
(See Drive List)
Header Word 3
Data
Word 1
Parameter Value or
Status Word
Message Operation
Parameter Value Read reads parameter values from the drive and
places that value (or an error code) in word 1 of the drive response
data file. The value is shown in device units. Device units are listed
in the user manual for the device you are using.
If an error occurs:
• Word 1 of the response contains the status code.
• The status area of the data file is non–zero.
Example
In this example, the value of parameter 20 was requested from a
1336 PLUS and a value of 4096 was returned. 4096 is the internal
drive unit value for the Maximum Rated Voltage Parameter. This
corresponds to a value of 100% Drive Rated Volts in Display Units.
Data File Format
PLC request
Drive response
N10:10
N10:90
0
1
2
3
769
20*
3
4
5
6
7
8
9
4096*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–12
Parameter Value Write
The Parameter Value Write message writes a 16–bit parameter data
value to the selected parameter number.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 1 word
Drive response instruction length: 4 words
Message Structure
PLC Request
Drive Response
Parameter Value
Data Word 1
Message Length
4
Header
Word 1
PLC Decimal Value
Header
Word 2
769 –– Message OK
–31999 –– Message Error
Parameter Number
Data
Word 3
Status Word
Data
Word 4
Message Operation
The Parameter Value Write function sends a new value to the
specified parameter. The value must be in device units. Units for
each parameter are listed in the device manual.
If an error has occurred, word 2 of the response returns a value of
–31999, and word 4 contains a status code.
Example
In this example, a value of 4096 was sent to Parameter 20. 4096 is
in drive units and indicates a value of 100% Drive Rated Volts, as
defined in P147, Drive Rated Volts.
Data File Format
PLC request
Drive response
N10:0
N10:90
0
1
2
3
4
–31999
20*
4096*
4
769
20*
0
4
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5
6
7
8
9
Block Transfer Emulation Instructions
EE Memory Functions
5–13
The EE Memory Functions message activates the specified EE
functions.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 4 words
Drive response instruction length: 3 words
Message Structure
PLC Request
Drive Response
Message Length
4
Header Word 1
PLC Decimal Value
–31998
Header Word 2
0
Header Word 3
Message Length
3
Header
Word 1
PLC Decimal Value
Header
Word 2
770 –– Message OK
–31998 –– Message Error
0
EE Command
Value
00
01
02
03
Header
Word 3
Header Word 4
EE Command
Not Used
EE Save
EE Recall
EE Default Initialize
Message Operation
The EE memory function allows three different message requests:
• EE Save saves parameter information from the working memory
or RAM to EEPROM.
• EE Recall retrieves the last saved data from EEPROM and places
it in the working memory or RAM.
• EE Default Initialize clears the RAM and EEPROM and sets all
parameter values to default.
If an error has occurred, word 2 of the response returns a value of
–31998.
1203–5.5 September 1995
5–14
Example
This example requests that an EEPROM Save function be
performed.
Data File Format
PLC request
Drive response
N10:10
N10:90
0
1
2
3
4
–31998
0*
1*
3
770
0*
4
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5
6
7
8
9
Block Transfer Emulation Instructions
Fault Clear/Reset
5–15
The Fault Clear/Reset message activates the Clear Fault, Clear Fault
Queue, and Drive Reset functions.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 4 words
Drive response instruction length: 4 words
Message Structure
PLC Request
Drive Response
Message Length
4
Header Word 1
PLC Decimal Value
–30976
Header Word 2
0
Header Word 3
Fault Command
Value
00
01
02
03
Message Length
4
Header
Word 1
PLC Decimal Value
Header
Word 2
1792 –– Message OK
–30976 –– Message Error
0
Data
Word 3
Status Word
Data
Word 4
Data Word 4
Fault Command
Not Used
Clear Fault
Clear Fault Queue
Drive Reset (1336 FORCE Only)
Message Operation
The specified fault Clear/Reset function sends a fault handling
request to the device.
• A Clear Fault request clears the last fault that occurred.
• A Clear Fault Queue clears the entire fault buffer. Certain
devices may store more than one fault.
• A Drive Reset is used with the 1336 FORCE drive product only.
This function resets the drive; it clears the fault queue and writes
the parameter information stored in EEPROM to RAM.
Data File Format
0
1
2
3
PLC request
N10:0
4
–30976
0
1,2,3
Drive response
N90:0
4
1792
0
0*
4
5
6
7
8
9
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–16
Fault Queue Entry Read
Full
This function reads the contents of the specified fault queue entry. A
message is returned which includes the fault text and fault code
associated with the specified fault queue entry. The 1336 FORCE
also returns the time stamp associated with the fault.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 12 or 16 words
Message Structure
PLC Request
Drive Response
Message Length
3
Header Word 1
PLC Decimal Value
1792
Header Word 2
Fault Queue
Entry Number
Header
Word 1
PLC Decimal Value
Header
Word 2
1792 –– Message OK
–30976 –– Message Error
Data Word 3
1336 FORCE
Drive Only
1203–5.5 September 1995
Message Length
18
Fault Queue
Entry Number
Header
Word 3
Fault Text
Char 2
Char 1
Data
Word 4
Fault Text
Char 4
Char 3
Data
Word 5
Fault Text
Char 6
Char 5
Data
Word 6
Fault Text
Char 8
Char 7
Data
Word 7
Fault Text
Char 10
Char 9
Data
Word 8
Fault Text
Char 12
Char 11
Data
Word 9
Fault Text
Char 14
Char 13
Data
Word 10
Fault Text
Char 16
Char 15
Data
Word 11
Fault Code Value
Data
Word 12
Clock Time
SES
REF
Data
Word 13
Clock Time
Hour
Minute
Data
Word 14
Clock Time
Date
Day
Data
Word 15
Clock Time
Year
Month
Data
Word 16
Block Transfer Emulation Instructions
5–17
Message Operation
Fault Queue Entry Read Full reads the contents of the fault queue
specified in word 3 of the request. The response returns the fault text
which can be ASCII text. The text will have every two characters in
reverse order. In addition, the 1336 FORCE returns a time stamp,
indicating the day and time the fault occurred.
If an error has occurred, word 2 of the response returns a negative
value.
Example
In this example, Fault Queue Entry number 3 was retrieved from a
1336 PLUS drive. The drive response returned the ASCII text Drive
Reset Flt, with each character reversed. The fault code for this
example is 22.
Data File Format
PLC request
Drive response
N10:0
N10:90
0
1
2
3
1792
3*
1792
3*
18
N10:100
8308*
N10:90#
\00\12
N10:100#
t
3
4
5
6
7
8
29252* 30313* 8293* 25938* 25971*
9
8308* 27718*
22*
\07\00
\00\16
\03\00
r
D
v
i
e
e
R
e
s
t
l
F
* Example only – These values vary depending on parameters and products.
# ASCII Display values
1203–5.5 September 1995
5–18
Fault Queue Size
The Fault Queue Size function gets the number of fault entries
allowed in the fault queue.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 4 words
Message Structure
PLC Request
Drive Response
Message Length
3
Header Word 1
PLC Decimal Value
1793
Header Word 2
0
Header Word 3
Message Length
5
Header
Word 1
PLC Decimal Value
Header
Word 2
1793 –– Message OK
–30975 –– Message Error
0
Data
Word 3
Fault Queue Size
Data
Word 4
Message Operation
The Fault Queue Size function reads back the size of the fault queue
available in the product. Each product may have a different number
of fault queue entries available for storage.
If an error has occurred, word 2 of the response returns a value of
–30975.
Example
In this example, a 1336 PLUS was used. This product has a fault
queue of four storage locations available to store faults. This value
is seen in word 4 of the response header message.
Data File Format
PLC request
Drive response
N10:0
N10:90
0
1
2
3
1793
0
6
1793
0
3
4
5
6
4*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
7
8
9
Block Transfer Emulation Instructions
Trip Fault Queue Number
5–19
The Trip Fault Queue Number provides the fault queue number of
the fault that caused the device to trip.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 4 words
Message Structure
PLC Request
Drive Response
Message Length
3
Header Word 1
PLC Decimal Value
1794
Header Word 2
0
Header Word 3
Message Length
4
Header
Word 1
PLC Decimal Value
Header
Word 2
1794 –– Message OK
–30984 –– Message Error
0
Header
Word 3
Number of Trip Fault
Header
Word 4
Message Operation
The Trip Fault Queue Number function provides the number of the
entry in the fault queue that tripped the device in word 4 of the drive
response. The Fault Queue Number is 0 when the device is not
faulted.
If an error has occurred in the block transfer, word 2 of the response
is negative.
Example
In this example, the device has stored a fault in the first entry of the
Fault Queue that caused the drive to trip. Word 4 of the response
indicates the entry number.
Data File Format
PLC request
Drive response
N10:0
N10:90
0
1
2
3
1794
0
6
1794
0
3
4
5
6
7
8
9
1*
* Example only – These values vary depending on parameters and products.
1203–5.5 September 1995
5–20
1203–5.5 September 1995
Chapter
6
Troubleshooting
Chapter Objectives
Use this chapter to help you troubleshoot your Serial
Communications Module system using the LED indicators on the
front of the device (as shown below). The Serial Communications
Module is a non-serviceable device that you should return to
Allen-Bradley for replacement when a major fault exists that is
attributable to the Serial Communications Module itself.
LED Locations
Front View Open Version
TX
Serial STS
SW3
SW2
SCANport STS
RX
SW1
J4
J2
Front View Enclosed Version
RX
SCANport STS
Serial STS
TX
AB0414C
1203–5.5 September 1995
6–2
Troubleshooting
!
!
ATTENTION: Servicing energized industrial control
equipment can be hazardous. Electrical shock, burns,
or unintentional actuation of controlled industrial
equipment may cause death or serious injury. Follow
the safety-related practices of NFPA 70E, Electrical
Safety for Employee Workplaces, when working on or
near energized equipment. Do not work alone on
energized equipment.
ATTENTION: Do not attempt to defeat or override
fault circuits. You must determine and correct the
cause of a fault indication before attempting operation.
Failure to correct a drive or system malfunction may
result in personal injury and/or equipment damage due
to uncontrolled machine system operation.
LED Troubleshooting Table
Indicator
Serial Sts
SCANport Sts
TX
RX
1203–5.5 September 1995
Color
Description
Recommended Action
Link OK, off–line
• Check configuration switch settings.
• Check for serial cable connection.
• Cycle Serial Communications Module power.
Green (steady)
Link OK, on–line
None, system functioning properly
Red (blinking)
Link was on–line and is now
off–line
Red (steady)
Faulted
• Check configuration switch settings.
• Check for serial cable connection.
• Cycle power, replace module.
Green (blinking)
Link OK, not connected
• Check configuration switch settings.
• Check for serial cable connection.
• Cycle power.
Green (blinking)
Green (steady)
Link OK, connected
Red (blinking)
Link was connected and is now
not connected
Red (steady)
Faulted
Off
No transmission occurring
Flash
Transmission occurring
Check for failed devices or link problems.
None
Check for failed devices or link problems.
• Check configuration switch settings.
• Check for serial cable connection.
• Cycle power, replace module.
• Send serial data again
None
Off
No transmission received
• Check data device to verify it is sending data
Flash
Characters being received
None
Chapter
7
Specifications
Chapter Objectives
This chapter provides you with background information and
specifications that you may need to install or apply your Serial
Communications Module.
Product Specifications
Catalog Number:
Open Style
Enclosed Style 115/230V
AC
Enclosed Style 24V DC
–GM2
–GD2
–GK2
Environmental:
Operating Temperature
Storage Temperature
0 to 50° C (32 to 122°F)
0 to 50° C (32 to 122°F)
0 to 50° C (32 to 122°F)
–40 to 85° C (–40 to 185°F)
–40 to 85° C (–40 to 185°F)
–40 to 85° C (–40 to 185°F)
Supplied by drive
85 to 264V AC, 1 phase
24V DC, ±10%
NA
45 to 63 Hz
NA
Electrical:
Input Voltage
Input Frequency
Input Current
SCANport Load
NA
35mA maximum
0.4 amps maximum
60mA DC
60mA DC
60mA DC
SCANport Peripheral
Interface
RS–232/RS–422/RS–485
(DF1)
DH–485
SCANport Peripheral
Interface
RS–232/RS–422/RS–485
(DF1)
DH–485
SCANport Peripheral
Interface
RS–232/RS–422/RS–485
(DF1)
DH–485
110, 300, 600, 1200, 2400,
4800, 9600, 19.2K
BCC or CRC
110, 300, 600, 1200, 2400,
4800, 9600, 19.2K
BCC or CRC
110, 300, 600, 1200, 2400,
4800, 9600, 19.2K
BCC or CRC
Communications:
SCANport Side
Serial Side
Baud Rates
Checksum
Dimensions:
Module Compatibility
Open (IP00)
NEMA Type 1 (IP30)
NEMA Type 1 (IP30)
NA
45w x 76h x 123d mm
(1.8 x 3.0 x 4.8 in.)
45w x 76h x 123d mm
(1.8 x 3.0 x 4.8 in.)
This module is intended for use with devices that communicate via
RS–232, RS–422, or RS–485 hardware standards using the DF1
protocol or the DH–485 standard. The Serial Communications
Module is intended to provide a means for transmitting messages
between these serial communications devices and Allen-Bradley
SCANport devices.
1203–5.5 September 1995
7–2
Specifications
1203–5.5 September 1995
Allen-Bradley, a Rockwell Automation Business, has been helping its customers improve
productivity and quality for more than 90 years. We design, manufacture and support a broad
range of automation products worldwide. They include logic processors, power and motion
control devices, operator interfaces, sensors and a variety of software. Rockwell is one of the
worlds leading technology companies.
Worldwide representation.
Argentina • Australia • Austria • Bahrain • Belgium • Brazil • Bulgaria • Canada • Chile • China, PRC • Colombia • Costa Rica • Croatia • Cyprus • Czech Republic •
Denmark • Ecuador • Egypt • El Salvador • Finland • France • Germany • Greece • Guatemala • Honduras • Hong Kong • Hungary • Iceland • India • Indonesia •
Ireland • Israel • Italy • Jamaica • Japan • Jordan • Korea • Kuwait • Lebanon • Malaysia • Mexico • Netherlands • New Zealand • Norway • Pakistan • Peru •
Philippines • Poland • Portugal • Puerto Rico • Qatar • Romania • Russia–CIS • Saudi Arabia • Singapore • Slovakia • Slovenia • South Africa, Republic • Spain •
Sweden • Switzerland • Taiwan • Thailand • Turkey • United Arab Emirates • United Kingdom • United States • Uruguay • Venezuela • Yugoslavia
Allen-Bradley Headquarters, 1201 South Second Street, Milwaukee, WI 53204 USA, Tel: (1) 414 382-2000 Fax: (1) 414 382-4444
Template revised June 23,
1203–5.5 September 1995
1995
1203–5.5 September 1995
74001–014–01(C)
Copyright 1995 Allen-Bradley Company, Inc. Printed in USA
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
