Joybee GP3
Mini Projector
User Manual
Table of contents
Important safety
instructions ................... 3
Introduction.................. 7
Projector features.....................................7
Shipping contents ......................................8
Projector exterior view.........................10
Controls and functions ..........................11
Positioning your
projector ..................... 18
Obtaining a preferred projected image
size..............................................................18
Connection ................. 20
Connecting the power...........................20
Connecting a computer.........................25
Connecting Video source devices.......27
Connecting an HDMI source device ..28
Connecting a Component Video source
device.........................................................29
Connecting a Composite Video source
device.........................................................30
Connecting an iPhone/iPod device......31
Connecting an external speaker..........32
Connecting a wireless dongle ..............32
Connecting to an external memory
device.........................................................33
Playing sound through the projector..35
Operation ................... 36
Starting up the projector ......................36
Switching input signal .............................36
Adjusting the projected image .............37
Hiding the image......................................39
Securing the projector...........................39
Selecting the aspect ratio ......................41
2
Table of contents
Optimizing the image............................. 41
Operating in a high altitude
environment............................................. 44
Adjusting the sound ............................... 44
Firmware upgrade .................................. 46
Personalizing the projector menu
display........................................................ 46
Playing files with iPhone/iPod............... 47
Using iPhone/iPod pop-up menus....... 55
Displaying images with PC and Video
source devices......................................... 58
Using PC/ Video pop-up menus .......... 59
Displaying files with internal memory,
USB Drive and SD card......................... 62
Using USB Streaming ............................. 71
Using Wireless Streaming..................... 73
Settings menu .......................................... 82
Shutting down the projector ............... 90
Maintenance ............... 91
Care of the projector............................ 91
Troubleshooting......... 93
Specifications.............. 94
Projector specifications......................... 94
Dimensions .............................................. 96
Timing chart............................................. 96
Supported timing for HDMI input ...... 97
Warranty and Copyright
information................. 99
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that
you follow the instructions mentioned in this manual and marked on the product.
Safety Instructions
1.
Please read this manual before
you operate your projector. Save
it for future reference.
2.
Do not look straight at the
projector lens during operation.
The intense light beam may damage
your eyes.
3.
4.
In some countries, the line voltage is
NOT stable. This projector is
designed to operate safely within a
mains voltage of 19 volts DC, but
could fail if power cuts or surges of
±10 volts occur. In areas where the
mains voltage may fluctuate or
cut out, it is recommended that
you connect your projector
through a power stabilizer, surge
protector or uninterruptible
power supply (UPS).
5.
Do not block the projection lens with
any objects when the projector is
under operation as this could cause
the objects to become heated and
deformed or even cause a fire.
Refer servicing to qualified
service personnel.
Important safety instructions
3
Safety Instructions (Continued)
6.
Never replace any electronic
components unless the projector is
unplugged.
9.
10.
4
7.
Do not place this product on an
unstable cart, stand, or table. The
product may fall, sustaining serious
damage.
8.
Do not attempt to disassemble this
projector. There are dangerous high
voltages inside which may cause
death if you should come into
contact with live parts. Refer
servicing only to suitably qualified
professional service personnel.
Important safety instructions
When the projector is under
operation, you may sense some
heated air and odor from its
ventilation grill. It is a normal
phenomenon and not a product
defect.
Do not place this projector in any
of the following environments.
- Space that is poorly ventilated or
confined. Allow at least 50 cm
clearance from walls and free flow of
air around the projector.
- Locations where temperatures may
become excessively high, such as the
inside of a car with all windows rolled
up.
- Locations where excessive humidity,
dust, or cigarette smoke may
contaminate optical components,
shortening the projector's life span
and darkening the image.
Safety Instructions (Continued)
- Locations near fire alarms
13.
- Locations with an ambient temperature
above 40°C / 104°F
- Locations where the altitudes are higher
than 3000 m (10000 feet).
Do not stand the projector on end
vertically. Doing so may cause the
projector to fall over, causing injury or
resulting in damage to the projector.
3000 m
(10000 feet)
0m
(0 feet)
11.
14.
Do not step on the projector or place
any objects upon it. Besides probable
physical damage to the projector,
doing so may result in accidents and
possible injury.
15.
Do not place liquids near or on the
projector. Liquids spilled into the
projector may cause it to fail. If the
projector does become wet,
disconnect it from the power supply's
wall socket and call BenQ to have the
projector serviced.
Do not block the ventilation holes.
- Do not place this projector on a blanket,
bedding or any other soft surface.
- Do not cover this projector with a cloth
or any other item.
- Do not place inflammables near the
projector.
12.
If the ventilation holes are seriously
obstructed, overheating inside the
projector may result in a fire.
Always place the projector on a level,
horizontal surface during operation.
Important safety instructions
5
Safety Instructions (Continued)
16.
Precautions for handing the battery.
- Do not use an unapproved battery. It may
explode. Only battery approved by
BenQ can be applied to this product.
- Do not apply a strong force to the
battery or attempt to make a hole in the
battery.
- Neither heat the battery nor store it in a
place with a high temperature, such as a
car interior in the summer.
- Do not leave battery directly under
sunshiner.
- Do not let the battery get wet.
- Do not let your chlid or pet suck or hold
the battery in his mouth.
- Do not let the charging terminal of the
battery contact any metal object.
6
Important safety instructions
Introduction
Projector features
The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.
The projector offers the following features.
•
•
•
•
•
•
•
Advanced LED light source
Long lasting LEDs provides a longer life span than traditional lamps.
Optical engine with DLP technologies
WXGA resolution and a bright picture.
Various useful features
Supports iPhone/iPod player, multimedia player, document viewer, internal memory, SD
card, USB flash drive, USB display, an optional removable and rechargeable battery, PC
Display, and Stream to me.
Easy to carry
The projector is small and light, making it useful for business trips and leisure activities.
You can view documents, videos and photos anywhere.
Multiple input ports
Multiple input ports, including PC, AV, HDMI, USB, and SD card provide flexible
connectivity with peripheral devices.
Audio input & output
Equipped with 2W x 2 speakers with RCA & mini-jack input ports and phone jack
output port
Convenient menu items
Friendly menu is used for all types of inputs, making the projector easy to use.
•
The apparent brightness of the projected image will vary depending on the ambient lighting
conditions, selected input signal contrast/brightness settings, and is proportional to
projection distance.
•
The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.
Introduction
7
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these items
are missing, please contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those illustrated.
*The warranty card is only supplied in some specific regions. Please consult your dealer for
detailed information.
Projector & dock
cover
Power cord
Multi-input cable
AC adapter
User manual CD
Warranty card*
Joybee GP3
Mini Projector
User Manual
Safety manual
Quick start guide
Pull the tab before using the remote
control.
8
Projector carrying
bag
Remote control
with battery
mini HDMI adapter
Wireless dongle
Introduction
Optional accessories
Battery
Introduction
9
Projector exterior view
1.
2.
Front/upper side
1
2
4
3
6
7
5
3.
4.
5.
6.
7.
8.
9.
10.
11.
Rear/lower side
9 10 11 12
8
12.
13.
14.
15.
16.
17.
18.
13
14
iPhone/iPod docking station
External control panel
(See "Projector" on page 11 for
details.)
Vent (heated air exhaust)
Front IR remote sensor
Internal Speakers
Focus ring
Projection lens
SD card slot
Type A USB jack (for USB drive/
Wi-Fi dongle)
Mini-B USB jack
Multi-input socket
RGB (PC)/Component video
(YPbPr/ YCbCr) /Composite video/
Audio input (L/R)
Mini HDMI input jack
Tripod socket
Adjuster foot
Audio input jack
Audio output jack (for iPod dock /
internal memory / SD card / USB
Drive / multi-input cable RCA audio
in)
AC adapter inlet
Battery latch
15 16 17 18
Do not block the ventilation openings. Blocking the ventilation openings can cause your
projector to overheat and may cause it to fail.
10
Introduction
Controls and functions
Projector
3.
6
7
1
2
8
3
4
5
9
4.
5.
1.
2.
Power
Toggles the projector between standby
mode and on.
See "Starting up the projector" on page 36
and "Shutting down the projector" on page
90 for details.
Left key
When the On-Screen Display (OSD) menu
is on:
6.
- Navigate left to select the desired menu
items.
- Make adjustments. (e.g. brightness,
contrast...)
When the On-Screen Display (OSD) menu
is off: (Only applied to SD card, internal
memory and USB Drive)
- Play previous video and audio file.
- Press and hold to rewind video and audio
file.
I
I
OK/Blank
Short press:
- Confirms a selected function when a
menu is displayed.
- Plays or pauses a video, music, photo
slideshow. (Only applied to SD card,
internal memory and USB Drive)
Long press (3 seconds):
Toggles the Blank.
Menu
Turns on the Pop-up setting menu.
Down/Volume down key
When the On-Screen Display (OSD)
menu is on:
- Navigate to down to select the desired
menu items.
- Make adjustments. (e.g. manual
keystone...)
When the On-Screen Display (OSD)
menu is off: (Only applied to SD card,
internal memory and USB Drive)
- Reduces the volume level.
Up/Volume up key
When the On-Screen Display (OSD)
menu is on:
- Navigate up to select the desired menu
items.
- Make adjustments. (e.g. manual
keystone...)
When the On-Screen Display (OSD)
menu is off: (Only applied to SD card,
internal memory and USB Drive)
- Magnifies the volume level.
Introduction
11
7.
8.
9.
12
Home
Directly returns to home screen from
lower level of OSD.
Exits application/pop-up message and back
to home screen directly.
Right key
When the On-Screen Display (OSD) menu
is on:
- Navigate right to select the desired menu
items.
- Make adjustments. (e.g. brightness,
contrast...)
When the On-Screen Display (OSD) menu
is off: (Only applied to SD card, internal
memory and USB Drive)
- Play next video and audio file.
- Press and hold to fast forward video and
audio file.
Back
Goes back to previous OSD menu, exits
and saves menu settings.
Introduction
Remote control
4.
1
7
2
8
3
9
4
10
5
11
6
12
5.
1.
2.
3.
I
I POWER
Toggles the projector between standby
mode and on. See "Starting up the
projector" on page 36 and "Shutting down
the projector" on page 90 for details.
6.
Blank
Toggles Blank on and off. See "Hiding the
7.
image" on page 39 for details.
Up/Volume up key
When the On-Screen Display (OSD)
menu is on:
- Navigate up to select the desired menu
8.
items.
- Make adjustments. (e.g. manual
keystone...) See "Correcting keystone" on
page 38 for details.
When the On-Screen Display (OSD)
menu is off: (Only applied to SD card,
internal memory and USB Drive)
- Magnifies the volume level.
Left key
When the On-Screen Display (OSD)
menu is on:
- Navigate left to select the desired menu
items.
- Make adjustments. (e.g. brightness,
contrast...)
When the On-Screen Display (OSD)
menu is off: (Only applied to SD card,
internal memory and USB Drive)
- Play previous video and audio file.
- Press and hold to rewind video and
audio file.
Down/Voume down key
When the On-Screen Display (OSD)
menu is on:
- Navigate to down to select the desired
menu items.
- Make adjustments. (e.g. manual
keystone...)
When the On-Screen Display (OSD)
menu is off: (Only applied to SD card,
internal memory and USB Drive)
- Reduces the volume level.
Menu
Turns on the Pop-up setting menu.
Mute/unmute
Turns on/off volume during video or
music playback. (Only applied to SD card,
USB Drive, internal memory, iPhone and
iPod)
Auto
Automatically determines the best
picture timings for the displayed
computer image. See "Auto-adjusting the
image" on page 37 for details.
Introduction
13
9.
OK
Confirms a selected function when a menu
is displayed.
Plays or pauses a video, music, photo
slideshow. (Only applied to SD card,
internal memory and USB Drive)
10. Right key
When the On-Screen Display (OSD) menu
is on:
- Navigate right to select the desired menu
items.
- Make adjustments. (e.g. brightness,
contrast...)
When the On-Screen Display (OSD) menu
is off: (Only applied to SD card, internal
memory and USB Drive)
- Play next video and audio file.
- Press and hold to fast forward video and
audio file.
11. .Home
Directly returns to home screen from
lower level of OSD.
Exits application/pop-up message and back
to home screen directly.
12. Back
Returns to upper level of OSD.
Closes pop-up setting menu of OSD.
Leave current application of OSD.
14
Introduction
3.
5
1
6
2
3
4
4
7
iPhone/iPod
Remote control over iPhone or iPod is not only
workable in power-on mode but also standby
mode in which GP3 acts as a docking speaker.
1.
2.
Menu/Back key
<Projector in turn-on mode>
Get back to upper level of file videos or
music browser.
<Projector in standby mode>
PRJ act as a docking speaker:
i. Switch between sub-menu within
“Music” or “Videos” menu in iPhone/
iPod home screen.
ii. Get back to upper level of any submenu in “Music” or “Videos” menu in
iPhone/iPod home screen.
OK key
<Projector in turn-on mode>
Press to confirm and start to playback a
desired video or music.
<Projector in standby mode>
Press to confirm and start to playback a
desired video or music in file list of
“Music” or “Videos" menu in iPhone/iPod
home screen.
4.
Down key
<Projector in turn-on mode>
Press to scroll down to select a video or
music in file browser.
<Projector in standby mode>
PRJ act as a docking speaker:
Press to scroll down to select a video or
music within a file list of “Music” or
“Videos” menu in iPhone/iPad home
screen.
Previous/Next keys
<Projector in turn-on mode>
i. During video projection
- Press to skip to the beginning of
the current/next video.
- Press and hold to rewind/fastforward the current video.
ii. During music playback within “iPod”
menu:
- Press to skip to the beginning of
the current/next music.
- Press and hold to rewind/fastforward the current music.
<Projector in standby mode>
Projector act as a docking speaker./
During music playback:
i. Press to “Skip to the beginning of the
Current/Next” music.
ii. Press and hold to “Rewind/Fastforward the current” music.
During video projection or music
playback within “iPod” menu:
i. Press to “Skip to the beginning of the
Current/Next” music.
ii. Press and hold to “Rewind/Fastforward the currently playing music”.
Introduction
15
5.
6.
7.
16
Up Key
<Projector in turn-on mode>
Press to scroll up to select a video or
music in file browser.
<Projector in standby mode>
PRJ act as a docking speaker:
Press to scroll down to select a video or
music within a file list of “Music” or
“Videos” menu in iPhone/iPad home
screen.
Volume up/down keys
Press to adjust iPhone/iPod volume.
Play/pause key
<Projector in turn-on mode>
i. In iPhone/iPod home screen or during
music playback within “Music” menu,
press to play/pause music directly.
ii. During video projection, press to play/
pause a “Video”.
<Projector in standby mode>
Projector act as a docking speaker:
In iPhone/iPod home screen or during
music playback within “Music” menu, press
to play/pause music directly.
Introduction
Remote control effective range
Infra-Red (IR) remote control sensor is located
on the front of the projector. The remote
control must be held at an angle within 15
degrees perpendicular to the projector's IR
remote control sensor to function correctly. The
distance between the remote control and the
sensor should not exceed 7 meters (~ 23 feet).
Appr
ox. 1
5°
Make sure that there are no obstacles between
the remote control and the IR sensor on the
projector that might obstruct the infra-red beam.
Replacing the remote control battery
1.
Pull out the battery holder.
Please follow the illustrated instructions. Push and
hold the locking arm while pulling out the battery
holder.
2.
3.
Insert the new battery in the holder. Note
the positive polarity should face outward.
Push the holder into the remote control.
•
Avoid excessive heat and humidity.
•
There may be battery damage if the battery is
incorrectly replaced.
•
Replace only with the same or equivalent type recommended by the battery manufacturer.
•
Dispose of the used battery according to the battery manufacturer’s instructions.
•
Never throw a battery into a fire. There may be danger of an explosion.
•
If the battery is dead or if you will not be using the remote control for a long time, remove
the battery to prevent damage to the remote control from possible battery leakage.
Introduction
17
Positioning your projector
Obtaining a preferred projected image size
The distance from the projector lens to the screen, the zoom setting (if available), and the
video format each factors in the projected image size.
16:10 is the native aspect ratio of this projector.
4:3 aspect image in a 16:10
aspect display area
16:10 aspect image scaled to a 4:3 aspect
display area
The projector should always be placed horizontally level (like flat on a table), and
positioned directly perpendicular (90° right-angle square) to the horizontal center of the
screen. This prevents image distortion caused by angled projections (or projecting onto
angled surfaces).
The modern digital projector does not project directly forward (like older style reel-toreel film projectors did). Instead, digital projectors are designed to project at a slightly
upward angle above the horizontal plane of the projector. This is so that they can be
readily placed on a table and will project forward and upwards onto a screen positioned so
that the bottom edge of the screen is above the level of the table (and everyone in the
room can see the screen).
You can see from the diagram on page 19, that this type of projection causes the bottom
edge of the projected image to be vertically offset from the horizontal plane of the
projector.
If the projector is positioned further away from the screen, the projected image size
increases, and the vertical offset also increases proportionately.
When determining the position of the screen and projector, you will need to account for
both the projected image size and the vertical offset dimension, which are proportional to
the projection distance.
BenQ has provided a table of screen size to assist you in determining the ideal location for
your projector. Refer to "Projection dimensions" on page 19 depending on the projector
you are using. There are two dimensions to consider, the perpendicular horizontal distance
from the center of the screen (projection distance), and the vertical offset height of the
projector from the horizontal edge of the screen (offset).
18
Positioning your projector
Projection dimensions
Refer to "Dimensions" on page 96 for the center of lens dimensions of this projector
before calculating the appropriate position.
1280:800 screen diagonal
Screen
Center of lens
Projection distance
Feet
Inches
mm
Recommended projection distance from screen
in mm
Average
2.00
3.33
4.67
6.00
6.66
24
40
56
72
80
610
1016
1422
1829
2032
621
1034
1448
1862
2069
1280:800 screen diagonal
All measurements are approximate and may vary from the actual sizes.BenQ recommends that
if you intend to permanently install the projector, you should physically test the projection size
and distance using the actual projector in situ before you permanently install it, so as to make
allowance for this projector's optical characteristics. This will help you determine the exact
mounting position so that it best suits your installation location.
Positioning your projector
19
Connection
In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 8). They are commercially available from electronics stores.
Connecting the power
Using the provided AC adapter or an optional Lithium-ion rechargeable battery.
The projector must be used with the provided AC adapter. Damage caused by the use of an
incorrect adapter is not covered under the warranty.
Using the AC adapter
1.
2.
3.
Insert the plug from the AC adapter into the DC IN terminal.
Insert the appropriate end of the power cord into the AC adapter.
Insert the plug on the power cord into a wall outlet. Check that the Power LED
indicator on the projector lights orange when using the AC adapter.
1
3
2
Using the optional battery
The projector must be used with specified Lithium-ion rechargeable battery. Charge the
battery before using the projector for the first time use. Using the projector for charging
the battery. You may also use the projector when charging the battery. Please turn off
the projector before attaching the battery.
Charging the battery
When you use the battery, please observe the safety precautions.
1.
Move the battery latch to the open side.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
20
Connection
2.
3.
Position the projector on the battery.
When the battery capacity is between 10% and
100 % , the battery LED indicator turns off. When
the battery capacity is lower than 10%, the
battery LED indicator blinks red, and the system
will shut down.
Match the battery carefully until it fits in
place.
1
3
2
4.
5.
6.
Insert the plug from the AC adapter into the DC IN terminal.
Insert the appropriate end of the power cord into the AC adapter.
Insert the plug on the power cord into a wall outlet. The battery LED indicator
blinks orange when charging is started and turns into solid orange when charging is
completed.
Removing the battery
Slide the battery lock switches on the two sides to remove the battery from the projector.
Connection
21
Battery LED indicator behavior
•
Battery + Adaptor
Status
In charge
Charging completed
Condition
Power on / Standby mode
Power on / Standby mode
LED color
Blue blinking
Blue solid on
•
We recommend that you keep the battery connected to the projector even when the
projector is connected to a wall outlet.
•
The battery needs to be charged for about 3.5 hours if fully discharged.
•
While connecting to battery, LED Mode in Settings will be set to Eco, you can play a
video from any sources for about 2.5 hours at 150AL when the battery is fully charged. (If
you set LED Mode in Settings to Normal, the battery life will be shortened to about 1
hour at 300AL.)
•
ECO mode is suggested for longer time of projection when the unit is operated only with
battery.
•
The charging time and capacity of the battery differ depending on the battery status,
operating condition, and duration of use. The battery consumes power even when the
device is not in use. Over time, the maximum operating time gradually shortens.
•
The battery can be charged for about 300 times. The battery life differs depending on the
personal habit of use.
Instructions and requirement for handling the battery
•
Recommending usage
Please read the battery instructions and the label on its surface before use.
Use the battery indoors under normal condition, temperature: (25±3)°C ,absolute humidity: 65±20%
When in use, the battery shall be kept out of heat, high voltage and avoided children's touching. Do not
drop the battery.
Use the compatible charger. Do not put the battery into the charger over 24 hours.
Do not contact contactor together. Do not demolish or disassembly the battery by yourself. Do not put
the battery in the damp place to avoid danger.
Do not wrap it with conduct material to avoid the damage caused by the direct contact between the
metal and battery. Keep the battery in day places.
Well disposed the disused battery. Do not put it into fire or water.
•
Hazard warning
•
Forbid disassemble batteries
The battery has protective component and circuit internally to avoid danger. Mishandling such as
improper disassembly will destroy its protective function and make it heat, smoke, distort or burning.
•
Forbid short-circuit batteries
Do not touch the plus and minus contactor with metals. Do not put the battery with metal element
together in either storage or movement. If the battery is short-circuit, it carries magnified current, which
will cause damage and make the battery heat, smoke, distort or burning.
•
Forbid heat and burn the battery
If heating or burning the battery, it will caused the isolated element in the battery dissolved, protection
function stopped or the electrode burning, over heated, which will make the battery heat, smoke, distort
or burning.
•
To avoid use the battery near the heat
Do not use the battery near the fire and stove, or over 60°C, and over heating will cause the battery
internal short-circuit and make it heat, smoke, distort or burning.
22
Connection
•
Forbid bathing the battery
Do not dampen the battery, or even immerse it in the water, which will cause internal protection circuit
and its function lost or abnormal chemical reactions, which will lead to heating, smoking, distortion or
burning.
•
Avoid charging near fire or in the sunlight
Otherwise, it will cause internal protection circuit and its function lost or abnormal chemical reactions,
which will lead to heating, smoking, distortion or burning.
•
Danger in using non-indicated chargers in
Charging in abnormal condition, the battery will cause internal protection circuit and its function lost or
abnormal chemical reactions, which will lead to heating, smoking, distortion or burning.
•
Forbid damage battery
Do not allow damage the battery with the metals gouged, forged or dropped etc. otherwise, it will cause
over-heated, distort, smoke or burning, even in danger.
•
Forbid directly welding on the battery
Over-heated will cause the isolated element dissolved in the battery and losing protective function its
cycle life, even will cause over heated, distort, smoke or burning.
•
Forbid directly charging on the power socket or car kit cigarette.
High voltage and amplified current will damage the battery and reduce its cycle life, even will cause overheated, distort, smoke or burning.
•
Do not use this battery for other equipment
Impropriate usage will damage the battery and reduce its cycle life, even will cause over-heated, distort,
smoke or burning.
•
Do not touch the leaking battery
The leaking electrolyte will cause the skin uncomfortable. If it drops into eyes, do not rob the eyes but
wash in time, and go to hospital for treatment.
•
Warning
•
Do not mix with other battery
This battery cannot mix with deposal or twice- recycled batteries in use. Otherwise, for its abnormal
charge and discharge, it will cause over-heated, distort, smoke or burning.
Keep the battery out of children's area and prevent them biting or swallowing the battery.
Do not insert the battery onto the charger for a long time If charging beyond the normal time, the
battery is still in the charger, please stop charging. The abnormal charging will cause battery over-heated,
distort, smoke or burning.
Do not put into microwave stove or any other pressure apparatus Take the battery away from the cellular
phone or the charger if it is instant heated or leaking (or odors) and depose it. The bad battery will
causes over-heated, smoke or burning.
•
Cautions
•
Notice
The battery shall be prevented to be exposed in effulgence so as not to cause over-heated, distort, smoke
and weaken its performance and cycle life.
•
Electro static-free
There is a protective circuit inside the battery to prevent contingency. Do not use the battery in the
Electro static circumstances, (above 1000V), for it is easily destroyed the circuit board so that the battery
doses not work and causes over-heated, distort, smoke or burning.
•
Discharging temperature range
Recommended discharging temperature range is 0-60°C, beyond which it will result in decadence of the
battery performance and shortness of its life.
Connection
23
•
Read carefully the manual before use or whenever in need.
•
Charging method
•
First usage
Use the special chargers in the recommended charging method to charge the battery.
When you use the battery for its first time, do not put it into the equipment once you find it in unusual
conditions such as unclearness or odors. The battery should be returned to the vendor.
•
Children use
•
Avoid children's touch
When Children use the battery, they should be under their parents' instructions and superintend in use.
Battery should keep out of the area where children in reach. Prevent children taking the battery out of
the charger or the equipment to play.
To avoid the leak-out liquid be exposed to the skin or clothes. If touched, please wash by clean water so
as not to cause the skin uncomfortable
•
Consultation
When you buy the battery, please note how to contact with the vendors, so that you may get in touch
with vendors for consultation whenever in need.
•
Safety usage guarantee
If the battery is used on other instruments, please contact with your manufacturer for how to get the
best performance, at least consult its maximum current, fast charge and special application.
24
Connection
Connecting a computer
The projector provides a VGA input socket that allows you to connect it to both IBM®
compatibles and Macintosh® computers. A Mac adapter is needed if you are connecting
legacy version Macintosh computers.
To connect the projector to a notebook or desktop computer:
• Using a VGA cable
1.
Take the supplied multi-input cable and connect one end to the D-Sub output socket
of the computer.
2.
Connect the other end of the multi-input cable to the PC/AV socket on the
projector.
3.
If you wish to make use of the projector speaker, take a suitable audio cable and
connect one end of the cable to the audio output socket of the computer, and the
other end to the audio input sockets of the multi-input cable.
Notebook or desktop computer
Multi-input cable
Audio cable
or
Many notebooks do not turn on their external video ports when connected to a projector.
Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a
function key labeled CRT/LCD or a function key with a monitor symbol on the notebook. Press
FN and the labeled function key simultaneously. Refer to your notebook's documentation to find
your notebook's key combination.
Connection
25
• Using an HDMI cable
1.
Take an HDMI cable and connect one end to the HDMI output jack of the computer.
2.
Connect the other end of the HDMI cable to the mini HDMI jack on the projector.
HDMI
HDMI
• Using a USB cable
1.
Take a USB cable and connect the type A end to the USB output jack of the
computer.
2.
Connect the mini-B type end of the USB cable to the USB-DISPLAY jack on the
projector. When you connect the projector to a computer, you can display
computer’s image or transfer files from your computer to the internal memory of the
projector.
USB
USB
3.
4.
26
If you select USB Display, follow the on-screen message to install the USB driver in
your computer first.
If you select USB File Transfer, go to My Computer or Windows Explorer to access
the projector's files. The projector appears as a Removable Disk. Transfer the files
from your computer to the projector by dragging and dropping or copying and
pasting.
Connection
To disconnect the projector from a computer:
i. Click
on the Windows Taskbar.
ii. Click the pop-up message.
iii. Disconnect the USB cable only when the message says that it is safe to remove
the hardware.
•
Do not disconnect the USB cable while the files are being copied, as this could result in loss
of data or damage to the projector.
•
The connection will not end if you have projector files open on the computer. Close all
projector files and try again.
•
Other versions of Windows operate similarly. Follow the correct procedure for removing a
USB device from your computer safely for your version of Windows.
Connecting Video source devices
You need only connect the projector to a Video source device using just one of the above
connecting methods, however each provides a different level of video quality. The method
you choose will most likely depend upon the availability of matching terminals on both the
projector and the Video source device as described below:
Terminal name
Terminal appearance
Picture quality
Mini HDMI
Mini HDMI
Best
Component Video
VGA
Better
Video
Video
Good
If the selected video image is not displayed after the projector is turned on and the correct video
source has been selected, check that the Video source device is turned on and operating
correctly. Also check that the signal cables have been connected correctly.
Connection
27
Connecting an HDMI source device
The projector provides a HDMI input jack that allows you to connect it to an HDMI
source device like a Blu-Ray player, a DTV tuner or a display.
HDMI (High-Definition Multimedia Interface) supports uncompressed video data
transmission between compatible devices like DTV tuners, Blu-Ray player and displays over
a single cable. It provides pure digital viewing and listening experience.
Examine your Video source device to determine if it has a set of unused HDMI output
jacks available:
• If so, you can continue with this procedure.
• If not, you will need to reassess which method you can use to connect to the device.
To connect the projector to an HDMI source device:
1.
2.
Take an HDMI cable and connect one end to the HDMI output jack of the HDMI
source device.
Connect the other end of the HDMI cable to the mini HDMI jack on the projector.
2
1
1
2
28
•
The HDMI cable (shown in this example) for connection your video output device is not
supplied as standard.
•
The Apple Digital AV Adapter can be purchased from www.apple.com.
Connection
Connecting a Component Video source device
Examine your Video source device to determine if it has a set of unused Component Video
output sockets available:
•
•
If so, you can continue with this procedure.
If not, you will need to reassess which method you can use to connect to the device.
To connect the projector to a Component Video source device:
1.
2.
3.
4.
Take a Component Video to VGA (D-Sub) adaptor cable and connect the end with 3
RCA type connectors to the Component Video output sockets of the Video source
device. Match the color of the plugs to the color of the sockets; green to green, blue
to blue, and red to red.
Connect the other end of the Component Video to VGA (D-Sub) adaptor cable
(with a D-Sub type connector) to the D-Sub jack of the multi-input cable.
Connect the other end of the multi-input cable to the PC/AV socket on the
projector.
If you wish to make use of the projector speaker, take a suitable audio cable and
connect one end of the cable to the audio output sockets of the Video source
device, and the other end to the audio input sockets of the multi-input cable.
AV device
Audio cable
or
Component Video to VGA
(D-Sub) adaptor cable
•
When audio output jack is connected with the earphone or external speaker, the sound will
not come out from the projector speaker.
•
No sound will come out from the speaker or audio output jack if video signals are not input.
Besides, the sound cannot be adjusted either.
Connection
29
Connecting a Composite Video source
device
Examine your Video source device to determine if it has a set of unused composite Video
output sockets available:
•
•
If so, you can continue with this procedure.
If not, you will need to reassess which method you can use to connect to the device.
To connect the projector to a composite Video source device:
1.
2.
3.
4.
5.
Take a Video cable and connect one end to the composite Video output socket of
the Video source device.
Connect the other end of the Video cable to the Video jack of the multi-input cable.
Connect the other end of the multi-input cable to the PC/AV socket on the
projector.
Connect the multi-input cable to the PC/AV socket on the projector.
If you wish to make use of the projector speaker, take a suitable audio cable and
connect one end of the cable to the audio output sockets of the Video source
device, and the other end to the audio input sockets of the multi-input cable.
AV device
Multi-input cable
Audio cable
Video cable
You need only connect to this device using a composite Video connection if Component Video
input is unavailable for use. See "Connecting Video source devices" on page 27 for details.
30
Connection
Connecting an iPhone/iPod device
To connect the projector to an iPhone/iPod device:
1.
Dock your iPhone/iPod to fit the docking connector.
**The Universal Dock
Adapter can be purchased
from www.apple.com
•
See "Playing files with iPhone/iPod" on page 47 for details.
•
Please note that if your iPhone is covered with a
protective case, it may cause a bad connection
between the iPhone and the projector. When you
connect the iPhone to the projector and see the
error message displayed on the iPhone screen,
please remove the protective case and connect it
again. (Because of poor connection and pin
detection failure, it cause the command cannot be
communicated successfully.)
Connection
31
Connecting an external speaker
You can hear sound through an external speaker instead of the internal speakers built into
the projector.
To connect the projector to an external speaker source device:
1.
Connect an appropriate stereo cable to the external speaker and the audio output
jack on the projector.
When the audio cable is connected to the audio output jack, the speaker output is muted.
Connecting a wireless dongle
With the wireless dongle makes you project the images wirelessly.
Plug the USB storage device into the Type A USB socket and do some steps to set up. See
"Using Wireless Streaming" on page 73 for details.
Wireless dongle
32
Connection
Connecting to an external memory device
Connecting an SD card
To connect the projector to an SD card:
1.
Connect an SD card to the SD card slot on the projector.
SD CARD
•
The maximum memory capacity supported for an SD(HC) card is 16 GB. (The maximum
capacity supported for external memory is based on our factory test. Your experience may
differ depending on the manufacturer of the memory device.)
•
The projector may not be compatible with some SD cards.
Connecting a USB storage device
To connect the projector to a USB storage device:
1.
Plug the USB storage device into the Type A USB socket.
USB flash drive
•
This product supports USB memory device and HDD (Hard Disk Drive) . Only one and only
last one of partitions will be mounted. (The maximum capacity supported for external
memory is based on our factory test. Your experience may differ depending on the
manufacturer of the memory device.)
•
This product does not support multi-card readers.
•
This product does not work if the USB storage device is connected by a USB HUB.
•
Some products which do not comply with standard USB specifications might not operate
normally.
•
A USB storage device with an automatic recognition application or its own driver might not
operate normally.
•
A USB storage device that uses only a designated driver might not be recognized.
Connection
33
34
•
Recognition speed for USB storage device may vary by device.
•
Do not turn off the product or pull a connected USB storage device out while the USB
storage device is in use. Doing so may result in damage to the USB storage device or stored
file.
•
Use a USB storage device which contains normal files. Abnormal files can cause a
malfunction or the files may not play.
•
USB storages must be formatted in FAT16/FAT32/NTFS. FAT32 and NTFS are
recommended for HDD (Hard Disk Drive).
•
As the data in the USB storage device can be damaged, please back up important data to
avoid loss. The user is responsible for data management. BenQ shall not be held liable for
any data loss.
•
File tree in USB storage should be as simple as possible. Too many or too many layers of
folders will result in lag of access time.
•
If an external memory device does not operate after you’ve connected it to the projector,
try to connect it to a PC. If it still does not operate normally, contact the memory device’s
manufacturer service center or related customer center.
Connection
Playing sound through the projector
You can make use of the projector speaker in your presentations, and also connect
separate amplified speakers to the audio output jack of the projector.
The table below describes the connection methods for different devices, and where the
sound is from.
Device
Audio input jack
The projector can play the
sound from...
PC/Component video
Audio input (L/R)
AUDIO-IN
Audio input (L/R)
AUDIO-IN
Video
Audio input (L/R)
Audio input (L/R)
Audio output jack
•
The selected input signal determines which sound will be played by the projector speaker,
and which sound will be output from the projector when audio output jack is connected.
•
There’s no need to connect to an audio input jack because the projector can play the sound
from an HDMI, external memory and iPhone/iPod source device. However, you can connect
to an external device to play the sound.
•
USB display doesn’t support audio function.
Connection
35
Operation
Starting up the projector
1.
Connect the power using the AC adapter or optional battery. The Power LED
indicator turns into orange and flashes slowly.
2.
Press II Power on the projector or remote
control to start the projector. The Power, OK
and Ring LED indicators light orange when the
projector is on.
The start up procedure takes several seconds.
In the later stage of start up, a startup logo is
projected.
(If necessary) Rotate the focus ring to adjust
the image clearness.
If the projector is activated for the first time, select your OSD language following the
onscreen instructions.
If you are prompted for a password, press
the arrow keys to enter a six digit
password. See "Utilizing the password
function" on page 39 for details.
Switch all of the connected equipment on.
The projector will display the home screen.
3.
4.
5.
6.
If the frequency/resolution of the input signal
exceeds the projector's operating range, you will
see the message 'Out of Range' displayed on a blank
screen. Please change to an input signal which is
compatible with the projector's resolution or set the input signal to a lower setting. See "Timing
chart" on page 96 for details.
Switching input signal
The projector can be connected to multiple devices at the same time. However, it can only
display one full screen at a time.
You can manually cycle through the available
input signals. Press
/
on the projector or
remote control to select your desired input
signal.
36
•
The input signal type effects the options
available for the Picture Mode. See "Selecting
the aspect ratio" on page 41 for details.
•
The native display resolution of this projector is
in a 16:10 aspect ratio. For best display picture
results, you should select and use an input signal
which outputs at this resolution. Any other resolutions will be scaled by the projector
depending upon the 'aspect ratio' setting, which may cause some image distortion or loss of
picture clarity. See "Selecting the aspect ratio" on page 41 for details.
Operation
Adjusting the projected image
Adjusting the image height
The projector is equipped with 1 adjuster foot. This adjuster changes the image height. To
adjust the projector:
1.
Screw the adjuster foot to adjust the image
height.
To retract the foot, screw the adjuster foot in a
reverse direction.
If the projector is not placed on a flat surface or
the screen and the projector are not
perpendicular to each other, the projected image
becomes trapezoidal. To correct this situation, see
"Correcting keystone" on page 38 for details.
•
Do not look into the lens while the lamp is on. The strong light from the lamp may cause
damage to your eyes.
•
Be careful when you screw the adjuster foot as it is close to the exhaust vent where hot air
comes from.
Fine-tuning the image clarity
1.
Rotate the focus ring to sharpen the image.
Auto-adjusting the image
In some cases, you may need to optimize the picture quality.
• Using the remote control
Press Auto.
Within 3 seconds, the built-in Intelligent Auto
Adjustment function will re-adjust the values of
Frequency and Clock to provide the best picture
quality.
The current source information will be displayed
in the upper left corner of the screen for 3
seconds.
This function is only available when PC signal (analog
RGB) is selected.
Operation
37
Using build-in test pattern
You can adjust the image shape and focus status by observing the input signal content, or
using the test pattern build-in OSD manual from OSD or remote control for better
observe the shape changed.
1.
2.
3.
Press
/
until the Settings menu is highlighted and then press OK to enter.
Go to the Basic > Test Pattern menu and press OK to enter.
Select On and press OK. The Test
Pattern displays.
Correcting keystone
Keystoning refers to the situation where the projected image is noticeably wider at either
the top or bottom. It occurs when the projector is not perpendicular to the screen.
Correcting keystone when an image is displayed on the screen.
To correct this, besides adjusting the height of the
projector, you can follow one of these steps.:
• Using Auto Keystone:
1.
Make sure the projector is in one of the
computer, iPhone/iPod, composite video,
component and HDMI modes.
2.
Press
and then press
to highlight
Auto Keystone.
3.
Press
/
to select On to adjust the
keystoning of the image automatically.
• Using Keystone:
1.
Press
and make sure Auto Keystone is
Off.
2.
Press
to highlight Keystone. The
Keystone pop-up menu displays.
3.
Press
to correct keystoning at the top of
the image or press
to correct keystoning
at the bottom of the image.
Keystone can only be set when Auto Keystone is Off.
38
Operation
Press
/
.
Press
/
.
Hiding the image
In order to draw the audience's full attention to the presenter, you can:
• Using the remote control
Use Blank on the remote control to hide the
screen image. Press again Blank or any keys on
the remote control to restore the image.
• Using the projector
Press and hold Blank for 3 seconds on the
projector to hide the screen image. Press again
Blank or any keys on the projector to restore the
image.
Do not block the projection lens from projecting as
this could cause the blocking object to become
heated and deformed or even cause a fire.
Securing the projector
Utilizing the password function
For security purposes and to help prevent unauthorized use, the projector includes an
option for setting up password security. The password can be set through the Settings
menu.
You will be inconvenienced if you activate the power-on lock functionality and subsequently
forget the password. Print out this manual (if necessary) and write the password you used in this
manual, and keep the manual in a safe place for later recall.
Setting power on lock
•
Once a password has been set, the projector cannot be used unless the correct password is
entered every time the projector is started.
•
When setting a password for the projector that its password function is used for the first
time, enter the default password (1, 1, 1, 1, 1, 1) of the projector by pressing the arrow key
five times if you are prompted for a password.
1.
2.
3.
4.
5.
Press
/
until the Settings menu is highlighted and then press OK to enter.
Go to the Advanced > Security Settings > Change Security Settings menu.
Press OK. The message 'Input Current Password' displays.
As pictured to the right, the four arrow
keys ( ,
, , ) respectively
represent 4 digits (1, 2, 3, 4). Press the
arrow keys to enter six digits for the
password.
Once the correct password is set, the OSD
menu returns to the Change Security
Settings menu.
Operation
39
6.
7.
Highlight Power on Lock and press OK. The pop-up menu displays. Select On and
press OK to complete power on lock setting.
To leave the OSD menu, press
or .
If you forget the password
If the password function is activated, you will be
asked to enter the six-digit password every time
you turn on the projector. If you enter the wrong
password, the password error message displays
lasting for three seconds, and the message
'Input Password' follows. If you enter an
incorrect password 5 times in succession, the
projector will automatically shut down in a short
time.
Entering the password recall procedure
1.
2.
3.
Go to the Settings > Advanced >
Security Settings > Recall Password
menu or press OK for 3 seconds in
password input screen every time you turn
on the projector. The projector will display
a coded number on the screen.
Write down the number and turn off your
projector.
Seek help from the local BenQ service
center to decode the number. You may be required to provide proof of purchase
documentation to verify that you are an authorized user of the projector.
Changing the password
1.
2.
3.
4.
Go to the Settings > Advanced > Security Settings > Change password
menu.
Press OK. The message 'Input Current Password' displays.
Enter the old password.
•
If the password is correct, another message 'Input New Password' displays.
•
If the password is incorrect, the password error message displays lasting for three
seconds, and the message 'Input Current Password' displays for your retry.
You can press
to cancel the change or try another password.
Enter a new password.
The digits being input will display as asterisks on-screen. Write your selected password down
here in this manual in advance or right after the password is entered so that it is available to you
should you ever forget it.
Password: __ __ __ __ __ __
Keep this manual in a safe place.
40
Operation
5.
6.
7.
Confirm the new password by re-entering
the new password.
You have successfully assigned a new
password to the projector. Remember to
enter the new password next time the
projector is started.
To leave the OSD menu, press
or .
Disabling the password function
To disable password protection, go back to the Settings > Advanced > Security
Settings > Power on Lock menu. Select Off and press OK. The message'Input
Password' displays. Enter the current password.
•
If the password is correct, the OSD menu returns to the Security Settings
page with 'Off' shown in the row of Power on Lock. You will not have to enter
the password next time you turn on the projector.
•
If the password is incorrect, the password error message displays lasting for three
seconds, and the message 'Input Password' displays for your retry. You can
press
to cancel the change or try another password.
Though the password function is disabled, you need to keep the old password in hand should you
ever need to re-activate the password function by entering the old password.
Selecting the aspect ratio
The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and
computers are in 4:3 ratio, which is the default for this projector, and digital TV and DVDs
are usually in 16:9 ratio.
With the advent of digital signal processing, digital display devices like this projector can
dynamically stretch and scale the image output to a different aspect than that of the image
input signal.
To change the projected image ratio (no matter
what aspect the source is):
1.
2.
3.
Press
to open the pop-up menu in one
of the computer, iPhone/iPod, composite
video, component and HDMI modes.
Press
to highlight Aspect Ratio.
Press
/
to select an aspect ratio to
suit the format of the video signal and your
display requirements.
Optimizing the image
Selecting a picture mode
The projector is preset with several predefined picture modes so that you can choose one
to suit your operating environment and input signal picture type.
To select an operation mode that suits your need, you can follow one of the following
steps.
Operation
41
•
•
Make sure the input source is on computer,
iPhone/iPod, composite video, component
and HDMI mode and the projection screen is
displayed.
Press
to open the pop-up menu. Press
to select Picture Mode Settings and press
OK to enter. Select Picture Mode and
press
/
to select a desired mode.
The picture modes are listed below.
1.
2.
3.
4.
5.
Bright mode: Maximizes the brightness of
the projected image. This mode is suitable
for environments where extra-high
brightness is required, such as using the
projector in well lit rooms.
Standard mode (Default): Is designed
for presentations. The brightness is
emphasized in this mode.
Cinema mode: Is appropriate for playing colorful movies, video clips from digital
cameras or DVs through the PC input for best viewing in a blackened (little light)
environment.
Game mode: Is appropriate for playing games.
User mode: Recalls the settings customized based on the current available picture
modes. See "Setting the User mode" on page 42 for details.
Setting the User mode
There is one user-definable modes if the current available picture modes are not suitable
for your need. You can use one of the picture modes (except the User) as a starting point
and customize the settings.
1.
2.
3.
4.
Press
to open the pop-up menu.
Press
to select Picture Mode Settings and press OK to enter.
Select Picture Mode and press
/
to select User.
Press
to highlight Reference Mode.
This function is only available when User mode is selected in the Picture Mode sub-menu item.
5.
6.
7.
8.
Press
/
to select a picture mode that is closest to your need.
Press
to select a sub-menu item to be changed and adjust the value with
/ .
See "Fine-tuning the image clarity" below for details.
When all settings have been done, highlight Save Settings and press OK to store
the settings.
The confirmation message 'Setting Saved' displays.
Using Wall Color
In the situation where you are projecting onto a colored surface such as a painted wall
which may not be white, the Wall Color feature can help correct the projected picture’s
color to prevent possible color difference between the source and projected pictures.
To use this function, press
to open the pop-up menu in one of the computer, iPhone/
iPod, composite video, component and HDMI modes. Select Wall Color and press
/
42
Operation
to select a color which is the closest to the color of the projection surface. There are
several precalibrated colors to choose from: Light Yellow, Pink, Light Green, Blue, and
Blackboard.
Fine-tuning the image quality in user mode
According to the detected signal type, there are some user-definable functions available
when User mode is selected. Based on your needs, you can make adjustments to these
functions by highlighting them and pressing
/
on the projector or remote control.
Adjusting Brightness
The higher the value, the brighter the image. And
the lower the setting, the darker the image.
Adjust this control so the black areas of the
image appear just as black and that detail in the
dark areas is visible.
+30
+50
+70
-30
0
+30
Adjusting Contrast
The higher the value, the greater the contrast.
Use this to set the peak white level after you
have previously adjusted the Brightness setting
to suit your selected input and viewing
environment.
Adjusting Color
Lower setting produces less saturated colors. If the setting is too high, colors on the image
will be overpowering, which makes the image unrealistic.
Adjusting Tint
The higher the value, the more reddish the picture becomes. The lower the value, the
more greenish the picture becomes.
Adjusting Sharpness
The higher the value, the sharper the picture becomes. The lower the value, the softer the
picture becomes.
Selecting a Color Temperature
There are four options available for color temperature* settings vary according to the
signal type selected.
*About color temperatures:
There are many different shades that are considered to be "white" for various purposes.
One of the common methods of representing white color is known as the “color
temperature”. A white color with a low color temperature appears to be reddish white. A
white color with a high color temperature appears to have more blue in it.
Changing Color Space
In the unlikely event that you connect the projector to a DVD player via the projector's
HDMI input and the projected picture displays wrong colors, please change the color space
to YUV.
1.
2.
Press
to open the pop-up menu in one of the computer, iPhone/iPod, composite
video, component and HDMI modes.
Select Color Space Conversion and press
/
to select a suitable color space.
This function is only available when the mini HDMI input port is in use.
Operation
43
Operating in a high altitude environment
We recommend you use the High Altitude Mode when your environment is between
1500 m –3000 m above sea level, and ambient temperature is between 0°C–30°C. China
region only applies at altitude up to 2000m.
Do not use the High Altitude Mode if your altitude is between 0 m and 1499 m and ambient
temperature is between 0°C and 35°C. The projector will be over cooled, if you turn the mode
on under such a condition.
To activate the High Altitude Mode:
1.
2.
3.
4.
Hightlight Settings and press OK to enter.
Go to Advanced > High Altitude Mode and press OK.
Highlight On and press OK to confirm.
To leave the OSD, press
until the projector returns to the home screen, or press
to go back to the home screen directly.
Operation under "High Altitude Mode" may cause a higher decibel operating noise level
because of increased fan speed necessary to improve overall system cooling and
performance.
If you use this projector under other extreme conditions excluding the above, it may
display auto shut-down symptoms, which is designed to protect your projector from overheating. In cases like this, you should switch to High Altitude mode to solve these
symptoms. However, this is not to state that this projector can operate under any and all
harsh or extreme conditions.
Adjusting the sound
The sound adjustments made as below will have an effect on the projector speaker(s). Be
sure you have made a correct connection to the projector audio input. See "Connection"
on page 20 for how the audio input is connected.
Muting the sound
To temporarily turn off the sound, press
control, or:
1.
2.
3.
4.
5.
44
on the remote
Hightlight Settings and press OK to enter.
Go to Advanced > Audio Settings and
press OK to enter.
Highlight Mute and press OK to open the
pop-up menu.
Highlight On and press OK to confirm.
To leave the OSD, press
until the
projector returns to the home screen, or
press
to go back to the home screen
directly.
Operation
Adjusting the sound level
To adjust the sound level, press +/- on the projector or
on the remote control,
/
Setting the keypad tone
To set the keypad tone:
1.
2.
3.
4.
Repeat steps 1-2 in Muting the sound
section.
Highlight Keypad tone and press OK to
open the pop-up menu.
Highlight On and press OK to confirm.
To leave the OSD, follow step 5 in Muting the
sound section.
Setting the audio in standby mode
To set the audio in standby mode:
1.
2.
3.
4.
Repeat steps 1-2 on muting the sound
section.
Highlight Audio in Standby Mode and
press OK to open the pop-up menu.
Highlight iPhone& iPod and press OK to
confirm. After set on the Audio in Standby
Mode, the projector can act as a docking
speaker when music playback is in standby
mode.
To leave the OSD, follow step 5 in Muting the sound section.
If Settings > Advanced > Audio Settings > Audio in Standby Mode is set to iPhone/iPod, the
projector can act as a docking speaker when music playback is in standby mode.
Turning on/off SRS HD
To turn on/off SRS HD surround sound effects:
1.
2.
3.
4.
Repeat steps 1-2 on muting the sound
section.
Highlight SRS HD and press OK to open
the pop-up menu.
Highlight On/Off and press OK to confirm.
To leave the OSD, follow step 5 in Muting the
sound section.
Operation
45
Firmware upgrade
Follow below procedures to upgrade firmware version.
•
Only an SD Card is supported for a firmware update.
•
Do not remove the SD Card while an update is in progress.
•
Do not operate any buttons during the update.
•
Do not turn the projector off during the update.
•
To confirm that the firmware has been successfully updated, go to Settings > Information
> Firmware version.
Updating the firmware
1.
2.
3.
4.
5.
Connect the containing the latest firmware to the projector.
Select Settings > Advanced > Firmware Upgrade in the main menu page.
Select OK to begin.
After the firmware is updated, please turn off the projector.
Power on the projector and check the firmware version.
Personalizing the projector menu display
The On-Screen Display (OSD) menus can be set according to your preferences. The
following settings do not affect the projection settings, operation, or performance.
•
•
•
46
Menu Display Time in the Settings > Advanced menu sets the length of time the
OSD will remain active after your last key press. The time length ranges from 5 to 30
seconds in 5-second increments.
Language in the Settings > Basic menu sets your familiar language for the OSD
menus.
Splash Screen in the Settings > Basic menu sets a preferred logo screen to be
displayed during projector start-up.
Operation
Playing files with iPhone/iPod
The projector comes with an all-in-one iPhone/iPod dock which support video projection
and music playback not only in power-on mode but also in standby mode.
<In power-on mode>
Projecting videos or music
1.
2.
Use remote control to turn on the power of the projector.
Select the source of iPhone/ iPod in home screen.
3.
Dock your iPhone or iPod to fit the connector on the projector.
4.
5.
Select “Video” or “Music” and press OK to enter.
Select a video or music type in browser mode, select a video or music that you want
to play, and then press OK to play.
File browser
Videos
Music
Operation
47
File list
Videos
Music
Remote control operation
Video and
music file
browser status
OK
/
Up/down
Home
Back
Menu
Upper half keys
(Projector)
Lower half keys
(iPhone/iPod)
Select a file.
Move the cursor.
Exit file browser and
go back to home
screen.
Go back to upper
level of file browser.
Select a file
Move the cursor
N/A
N/A
N/A
Go back to upper
level of file browser.
File playing
Videos
48
Operation
Music
Remote control operation
Video playback
status
Upper half keys
(Projector)
Lower half keys
(iPhone/iPod)
OK
/
Play/pause
Volume up/down
N/A
N/A
N/A
Next/Previous video
(Fast forward/
Rewind)
Up/down
/
Next/Previous
(Fast forward/
Rewind)
Home
Back
Mute
/
Volume up/down
Exit playback status
and go back to home
screen
Exit playback status
and go back to upper
level of file browser.
Mute/unmute
N/A
N/A
N/A
N/A
Volume up/down
Open po-up settings
menu
Exit playback status
and go back to video
file browser.
Music playback
status
Upper half keys
(Projector)
Lower half keys
(iPhone/iPod)
OK
/
Up/down
N/A
N/A
/
Left/right
Play/pause
Volume up/down
Next/Previous music
(Fast forward/
Rewind)
Menu
/
Next/Previous
(Fast forward/
Rewind)
Home
Back
Mute
/
Volume up/down
Menu
N/A
Exit playback status
and go back to home
screen.
Exit playback status
and go back to upper
level of file browser.
Mute/unmute
N/A
Next/Previous video
(Fast forward/
Rewind)
N/A
N/A
N/A
N/A
Volume up/down
Open po-up settings
menu.
Exit playback status
and go back to music
file browser.
Operation
49
Projecting photos
Photo function provides photos in slideshow projection from iPhone/iPod.
Projecting photos
1.
2.
Select “Photos” and press OK.
Go to “Photos” > “Albums” in iPhone or iPod main menu. Photos can only be
projected as a slideshow. (Here take an example of iPhone 4)
3.
Choose the photo you want to project and start slideshow mode. After slideshow
start, you can enjoy photos on a big screen.
For more instructions on Photos, see "iPhone/iPod" on page 13 for details.
50
Operation
Remote control operation
Photo slideshow
playback status
Lower half keys
(iPhone/iPod)
/
Next/Previous
(Fast forward/Rewind)
Next/Previous photo
/
Volume up/down
Volume up/down
Operation
51
Projecting 3rd party apps
Apps function provides 3rd party apps projection from iPhone/iPod.
1.
2.
3.
Download and install an app that supports Apps TV-out function. (e.g., Youtube,
Netflix, TVOut genie)
Select “Apps” and press OK.
Launch the app and select your media type from your device and the app will be
automatically projected on a big screen. (Here take a example of Youtube)
For some apps such as games, additional steps may be required. Follow the on-screen
instructions of these apps.
Projecting a presentation
1.
2.
3.
4.
You must have a presentation app installed on your device that supports TV-out to
use this function. (e.g., Presentation Viewer )
Launch the presentation app and the app will be automatically projected on a big
screen.
For some presentation apps, the documents can only be viewed in slideshow mode.
Sart the slideshow and the presentation will be instantly projected on a big screen.
<In stand-by mode>
You can turn the projector into a docking speaker for your iPhone or iPod when it’s in
stand-by mode. Follow steps as below.
52
Operation
1.
Enter “Settings” menu in projector home screen.
2.
Set Advanced > Audio Settings > Audio in Standby Mode to iPhone/iPod.
3.
4.
Turn off the projector and it will become a docking speaker.
Dock your iPhone or iPod on the projector. Wait
until the OK/Blank ring LED light turns off and Power
LED light flashes slowly.
Select the Music icon in iPhone or iPod main menu.
(Here take an example of iPhone 4)
5.
Operation
53
6.
Press Menu on remote control to switch to music-related menu, use
select a music in file list and then press OK to start playing music.
/
to
If the iPhone or iPod is at the Main Menu, pressing Play/Pause will cause the iPhone or iPod to
start playing all of its music.
7.
When a song is playing, press
for Pause/Play.
Press / for replay or skip to next song. Have
long press on / to make the playing file rewind
or fast-forward. Press /
to control the
volume.
Operation iPhone or iPod during video or
music playback
You are allowed to use remote control to operate your
iPhone or iPod when the projector is in both of poweron and standby mode.
For more instructions on iPhone/iPod keys, see "iPhone/
iPod" on page 13 for details.
54
Operation
Using iPhone/iPod pop-up menus
The pop-up menu provides an on-screen display (OSD) for adjustments when playing
Videos, Photos and Apps.
Using the menu
1.
2.
3.
To open the OSD menu, press
on the projector or remote control when the
projection screen is displayed.
When the OSD is displayed, press / to select the desired item and adjust the
settings by using
/ .
To leave the OSD, press
again.
Menu system
Menu Item
Sub-menu
Options
Wall Color
Off/Light Yellow/Pink/Light Green/
Blue/Blackboard
Aspect Ratio
Auto/Real//4:3/16:9/16:10
Phase
H. Size
Color Space
Conversion
Auto/RGB/YUV
Auto Keystone
On/Off
Keystone
Picture Mode
Bright/Standard/Cinema/Game/User
Reference Mode
Bright/Standard/Cinema/Game
Brightness
Picture Mode
Settings
Contrast
Color
Tint
Sharpness
Color Temperature
Warm/Normal/Cool
Save Settings
Operation
55
Play Settings
Shuffle
On/Off
Repeat
On/Off
Source
Information
Resolution
Color System
Description of each menu
FUNCTION
DESCRIPTION
Wall Color
Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 42 for details.
There are four options to set the image's aspect ratio depending
on your input signal source. See "Selecting the aspect ratio" on
page 41 for details.
Adjusts the clock phase to reduce image
distortion.
Aspect Ratio
Phase
This function is only available when a
PC signal (analog RGB) is selected.
H. Size
Color Spance
Conversion
Auto Keystone
Keystone
56
Operation
Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog RGB)
is selected.
See "Changing Color Space" on page 43 for details.
This function is only available when the mini HDMI input port
is in use.
Auto corrects any keystoning of the image.
Corrects any keystoning of the image. See "Correcting keystone"
on page 38 for details.
This function is only available when Auto Keystone is Off.
Picture Mode
See "Selecting a picture mode" on page 41 for details.
Reference Mode
See "Setting the User mode" on page 42 for details.
This function is only available when User is selected.
Brightness
See "Adjusting Brightness" on page 43 for details.
Contrast
See "Adjusting Contrast" on page 43 for details.
Picture Mode
Settings
Color
See "Adjusting Color" on page 43 for details.
Tint
See "Adjusting Tint" on page 43 for details.
This function is only available the system format is NTSC.
Sharpness
See "Adjusting Sharpness" on page 43 for details.
Color Temperature
See "Selecting a Color Temperature" on page 43 for details.
Save Settings
Saves the settings made for User mode.
Shuffle
Lets you select whether to playback randomly.
Play Settings
Repeat
Lets you select whether to playback repeatly.
This function is not available when Apps is selected.
Source
Shows the current signal source.
Information
Resolution
Shows the native resolution of the input signal.
Color System
Shows input system format, NTSC, PAL, SECAM, or RGB.
Operation
57
Displaying images with PC and Video source
devices
You can connect your projector to a PC and various Video source devices. (e.g. HDMI,
composite video, component video) However, you need only connect the projector to an
input source device.
To display images:
1.
2.
3.
4.
58
Connect the projector to one of the above signal source.
Turn on the power of the projector and your source device. The projector displays
the home screen.
Press
/
on the projector or remote control to select the input signal and then
press OK to enter.
Press
Operation
or
to go back to home screen.
Using PC/ Video pop-up menus
The projector has a multilingual OSD that allows you to make image adjustments and
change a variety of settings. This menu is for the settings to be used in computer, iPhone/
iPod, composite video, component and HDMI modes.
Using the menu
1.
2.
3.
To open the OSD menu, press
on the projector or remote control when the
projection screen is displayed.
When the OSD is displayed, press / to select the desired item and adjust the
settings by using
/ .
To leave the OSD, press
again.
Menu system
Menu Item
Sub-menu
Options
Wall Color
Off/Light Yellow/Pink/Light Green/
Blue/Blackboard
Aspect Ratio
Auto/Real//4:3/16:9/16:10
Phase
H. Size
Color Space
Conversion
Auto/RGB/YUV
Auto Keystone
On/Off
Keystone
Picture Mode
Bright/Standard/Cinema/Game/User
Reference Mode
Bright/Standard/Cinema/Game
Brightness
Picture Mode
Settings
Contrast
Color
Tint
Sharpness
Color Temperature
Warm/Normal/Cool
Save Settings
Operation
59
Source
Information
Resolution
Color System
Description of each menu
FUNCTION
DESCRIPTION
Wall Color
Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 42 for details.
There are four options to set the image's aspect ratio depending
on your input signal source. See "Selecting the aspect ratio" on
page 41 for details.
Adjusts the clock phase to reduce image
distortion.
Aspect Ratio
Phase
This function is only available when a
PC signal (analog RGB) is selected.
H. Size
Color Spance
Conversion
Auto Keystone
Keystone
60
Operation
Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog RGB)
is selected.
See "Changing Color Space" on page 43 for details.
This function is only available when the mini HDMI input port
is in use.
Auto corrects any keystoning of the image.
Corrects any keystoning of the image. See "Correcting keystone"
on page 38 for details.
This function is only available when Auto Keystone is Off.
Picture Mode
See "Selecting a picture mode" on page 41 for details.
Reference Mode
See "Setting the User mode" on page 42 for details.
This function is only available when User is selected.
Brightness
See "Adjusting Brightness" on page 43 for details.
Contrast
See "Adjusting Contrast" on page 43 for details.
Picture Mode
Settings
Color
See "Adjusting Color" on page 43 for details.
Tint
See "Adjusting Tint" on page 43 for details.
This function is only available the system format is NTSC.
Sharpness
See "Adjusting Sharpness" on page 43 for details.
Color Temperature
See "Selecting a Color Temperature" on page 43 for details.
Save Settings
Saves the settings made for User mode.
Source
Shows the current signal source.
Information
Resolution
Shows the native resolution of the input signal.
Color System
Shows input system format, NTSC, PAL, SECAM, or RGB.
Operation
61
Displaying files with internal memory, USB
Drive and SD card
The projector can display files saved in internal memory or external storage like an SD
card or a USB Drive when you have connected to projector.
To display files:
1.
2.
3.
Turn on the power of the projector and the projector displays the home screen.
Connect the projector to one of the above external memory devices.
Press
/ to select SD card, USB Drive or internal memory.
4.
Storages are classified into Videos, Photos, Music, Documents menu in home
screen. Press / to select desired item and then press OK to enter different file
browser.
File browser
Videos
Music
Photos
Documents
•
You will only see relevant and supported files in each of file browser.
•
If you want to disconnect external storages, please select Safe remove icon. See "Supported
file formats" on page 70 for details.
•
If the file size is larger, the processing time will be longer and a loading icon will display on
the screen.
All file browser
Pressing
62
Operation
allows you to open a pop-up menu in one of the four file browser window.
Delete
Browse other storage
File playing
Videos
NAME
OK
/
Music
DESCRIPTION
Play/Pause
Volume
Prev
Plays or pauses a video or music.
Volume up/down.
Left:
• Plays the previous video or music.
• Press and hold to fast rewind the video or music.
Right:
Next
•
•
Plays the next video or music.
Press and hold to fast forward the video or music.
Menu
* Press and hold for 2 seconds to fast forward/fast rewind at
x2 speed. Toggle the
/ to switch the speed to x4, x8,
x16 while playing at x2 speed. To resume back to normal
speed, press OK.
Open/close video pop-up settings menu.
Operation
63
•
•
•
Return to upper level of OSD.
Close video pop-up setting menu.
Leave current video player and back to video file
browser.
Exit video player and go back to home screen.
Back
Home
Pop-up menu
The pop-up menu provides an on-screen display (OSD) for adjustments when playing
videos or music.
Videos
Music
Using the menu
1.
3.
To open the OSD menu, press
on the projector or remote control when the
projection screen is displayed.
When the OSD is displayed, press / to select the desired item and adjust the
settings by using
/ .
To exit the OSD, press
on the projector or remote control again.
•
See the table for supported subtitle file types. Refer to "Supported file formats" on page 70.
2.
Video menu system
Menu Item
Options
Wall Color
Off/Light Yellow/Pink/Light Green/
Blue/Blackboard
Aspect Ratio
Auto/Full Screen/4:3/16:9/16:10/
Real
Auto Keystone
On/Off
Keystone
64
Sub-menu
Operation
Picture Mode
Bright/Standard/Cinema/Game/User
Reference Mode
Bright/Standard/Cinema/Game
Brightness
Picture Mode
Settings
Contrast
Color
Tint
Sharpness
Color Temperature
Warm/Normal/Cool
Save Settings
Play Settings
Play Mode
All in folder/One video
Play Order
Normal/Shuffle
Repeat
On/Off
Description of each menu
FUNCTION
DESCRIPTION
Wall Color
Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 42 for details.
There are four options to set the image's aspect ratio depending
on your input signal source. See "Selecting the aspect ratio" on
page 41 for details.
Auto corrects any keystoning of the image.
Aspect Ratio
Auto Keystone
Keystone
Corrects any keystoning of the image. See "Correcting keystone"
on page 38 for details.
This function is only available when Auto Keystone is Off.
Operation
65
Picture Mode
Pre-defined picture modes are provided so you can optimize your
projector image set-up to suit your program type.
Reference Mode
Selects a picture mode that best suits your need for the image
quality and further fine-tune the image based on the selections
listed on the same page below.
This function is only available when User is selected.
Brightness
Adjusts the brightness of the image.
Contrast
Adjusts the degree of difference between dark and light in the image.
Picture Mode
Settings
Color
Adjusts the color saturation level -- the amount of each color in a
video image.
Tint
Adjusts the red and green color tones of the image.
This function is only available the system format is NTSC.
Sharpness
Adjusts the image to make it look sharper or softer.
Color Temperature
Adjusts the color temperature. At higher color temperatures, the
screen looks colder; at lower color temperatures, the screen
looks warmer.
Save Settings
Saves the settings made for User mode.
Play Mode
Lets you choose to play one video or all videos in a folder.
Play Settings
Play Order
Lets you select the playback order of video files.
Repeat
Lets you select whether to repeat video playback.
66
Operation
Music menu system
Menu Item
Options
Play Mode
All in folder/One music
Play Order
Normal / Shuffle
Repeat
On/Off
Description of each menu
FUNCTION
DESCRIPTION
Play Mode
Lets you choose to play one music or all music in a folder.
Play Order
Lets you select the playback order of music files.
Repeat
Lets you select whether to repeat music playback.
Photo viewing
NAME
OK
DESCRIPTION
Play/Pause
Prev
Next
Menu
Back
Home
Plays or pauses a slideshow.
Previous photo.
Next photo.
Open/close photo pop-up settings menu.
• Return to upper level of OSD.
• Close photo pop-up setting menu.
• Leave current photo player and back to photo file
browser.
Exit photo player and go back to home screen.
Operation
67
Document viewing
NAME
DESCRIPTION
Zoom
OK
Zoom in the display at the intervals of 100%, 200%, 300%,
400%, 500%, 600%, 700%, 800%.
While page is not zoomed.
• Up/Left: Move to the previous page.
• Down/Right: Move to the next page.
While page is zoomed.
• Up: Move to the top side of the page.
• Left: Move to the left side of the page.
• Down: Move to the down side of the page.
• Right: Move to the right side of the page.
Open/close photo pop-up settings menu.
Up
Down
Left
Right
Menu
Back
Leave current document viewer and back to document file
browser.
Exit document viewer and go back to home screen.
Home
Pop-up menu
The pop-up menu provides an on-screen display (OSD) for adjustments when viewing
photos or documents.
Photos
Documents
Using the menu
1.
2.
68
To open the OSD menu, press
on the projector or remote control when the
projection screen is displayed.
When the OSD is displayed, press / to select the desired item and adjust the
settings by using
/ .
Operation
3.
To exit the OSD, press
on the projector or remote control again.
Photo menu system
Menu Item
Options
Slideshow Speed
Fast/ Normal/ Slow
Slideshow Mode
All in folder / One photo
Slideshow Order
Normal / Shuffle
Repeat
On/Off
Description of each menu
FUNCTION
DESCRIPTION
Slideshow
Speed
Lets you select slideshow speed.
Slideshow
Mode
Lets you choose to slideshow one photo or all photos in a folder.
Slideshow
Order
Lets you select the slideshow order of photo files.
Repeat
Lets you select whether to repeat slideshow.
Document menu system
Menu Item
Options
Page Navigation
Aspect Ratio
Fit to Width/Fit to Height
Description of each menu
FUNCTION
DESCRIPTION
Lets you go directly to a specific page.
Page
Navigation
Aspect Ratio
•
Enter a page number using the
/ / / buttons, check
the page number in the preview window of the screen, and
then press OK to move to that page.
Lets you choose the aspect ratio of the document.
•
•
•
Fit to Width: Displays a document so that it fits the screen
width.
Fit to Height: Displays a document so that it fits the screen
height.
Loading time may be longer for large files.
Operation
69
•
Document viewer may not work properly when a file does not comply with standards or it is
damaged.
•
Document viewer may not work when a file contains too much data to display on a screen.
(For example, too much data on one sheet in an Excel file.)
•
Document viewer supports only one font. If a screen uses other fonts, the image Media Play
displays may be different than the original screen.
•
For example:
•
1. The position of line breaks in a sentence might be dissimilar.
•
2. The position of page breaks in a MS Word document might be changed. In this case, the
document might be shown incompletely according to the Layout properties for Picture or
Shapes or Object in MS word . (Please refer to the manual of MS Word for more
information on the Layout properties.)
•
Some functions supported on your PC are not supported by the projector, such as these
PowerPoint functions: Animation, 3D, Smart Art, Hyper Link, and Transparency and
Gradation.
•
This product does not support encrypted files (DRM).
Supported file formats
•
Document, Photo, Music
ITEM
FILE EXTENSION
Adobe PDF 1.0~1.4 (PDF)
MS powePoint 97~2010 (ppt, pptx)
MS Excel 95~2010 (xls, xlsx)
MS Word 95~2010 (doc, docx)
JPG, BMP, PNG
MP3, MP2, APE, FLAC, OGG, WAV, M4A
Document
Music
•
Video, Subtitles
ITEM
FILE EXTENSION
DESCRIPTION
Video
AVI (H.263, Xvid, MJPEG),
MOV (H.263, Xvid, MJPEG),
MP4 (H.263, Xvid),
3gp/3g2 (H.263, Xvid),
FLV (Sorenson Spark)
Max 1920x1080 30fps
•
Subtitles
MKV build-in, SRT(.srt).
•
Subtitle files must be in same
directory as the video files.
The name of subtitle files shall be
the same as the name of video
files.
Bit rate range : If peak bit rate of a video file is larger than 10MB, it might cause video
playback lag.
Please visit BenQ.com to know more details about the latest supported formats.
70
Operation
Using USB Streaming
The projector supports USB streaming for USB Display and USB File Transfer.
USB Display
The projector can project computer screen via a USB cable instead of a VGA cable.
To use USB display:
1.
2.
3.
4.
5.
6.
7.
Connect the projector to a computer using a USB cable.
Turn on the power of the projector and
your source device. The projector displays
the home screen.
Press
/ to select USB Streaming.
Press / to select USB Display and
then press OK to enter.
If your computer can automatically install
USB driver, you can see computer’s screen.
If computer's screen can't be projected,
please go to "My Computer", find the “BenQUSB EZ Display” (same as using a flash
disk drive), then run the “Autorun.exe” file.
Press
or
to leave computer projection screen and back to projector home
screen.
•
If the Microsoft Windows system installed on your PC is Windows 7 or later version, you
need to install the driver manually. Just follow the on-screen instruction.
•
This function can't support Mac OS devices.
Win
2000
x
Win
XP SP2
32Bit
v
Win
XP
64Bit
x
Win
Vista
32 bit
v
Win
Vista
64 bit
v
Win7
32 bit
v
Win7
64bit
MAC
v
x
USB File Transfer
You can connect the projector to transfer files from your computer to the projetor. The
files will be saved in the internal menory, and you can project images from the projector.
To use USB file transfer:
1.
2.
3.
4.
5.
6.
Connect the projector to a computer using a USB cable.
Turn on the power of the projector and
your source device. The projector displays
the home screen.
Select USB Streaming.
Select USB File Transfer and then press
OK to enter.
If the connection is sucessful, you will see
“It is in USB file transfer mode.” message
on the screen.
Look for a new “removable disk” icon. This “removable disk” is actually the internal
memory in your projector.
Operation
71
7.
8.
Copy & Paste or Drag-N-Drop files from your computer to the removable disk.
If you want to display those files, use
/ to select Internal Memory. See
"Displaying files with internal memory, USB Drive and SD card" on page 62 for
details.
9.
Press
or
to leave USB File Transfer mode and back to projector home screen.
To disconnect the projector from a PC:
Make sure to end the connection properly to prevent damage to the projector or your
data.
72
1.
2.
3.
Click on the Windows Taskbar.
Click the pop-up message.
Disconnect the USB cable only when the message says that it is safe to remove the
hardware.
•
Do not disconnect the USB cable while the files are being copied, as this could result in loss
of data or damage to the projector.
•
The connection will not end if you have projector files open on the PC. Close all projector
files and try again.
•
Other versions of Windows operate similarly. Follow the correct procedure for removing a
USB device from your PC safely for your version of Windows.
•
This function can't support Mac OS devices.
Operation
Using Wireless Streaming
The wireless dongle that came with the product provides you with two functions to
project images wirelessly. One is PC Display; the other is Stream to me.
PC Display
If it is the first time to use PC Display, you need to download “BenQ GP3 EZ
QPresenter” application from GP3 and install on your computer first. Follow the steps
below to get it all set up in just a few minutes.
1.
2.
3.
4.
5.
Connect the wireless dongle to the USB
jack of the projector.
Turn on the power of the projector.
Go to Settings > Network > Wi-Fi
Mode to check your network settings.
i. Wi-Fi mode is set to AP Mode in
default, open computer’s wireless and
search “BenQ GP3” (Device Name
SSID) in wireless access point menu
and connect to it.
ii. If Wi-Fi mode is changed to Client Mode, you should connect both your
computer and projector to the same AP router.
Select Wireless Streaming from Home screen.
Select PC Display and then press OK to enter “PC Display Welcome Page” as
shown below.
AP Mode
6.
Client Mode
Follow the steps of “To install BenQ EZ QPresenter ” in PC Display Welcome
Page.
i. In AP Mode, start a web browser and
key in IP address 192.168.100.10 into
the address bar and press enter. In
Client Mode, start a web browser
and key in assigned IP address shown in
PC Display Welcome Page. You will be prompted to “BenQ GP3 EZ
QPresenter download page”.
Operation
73
ii. Select OS version and start downloading and installing BenQ GP3 EZ
QPresenter by following the on-screen instructions on you PC. After installation
finished, the BenQ GP3 EZ QPresenter icon will be displayed on your desktop.
7.
The way of using BenQ GP3 EZ QPresenter is slightly different when GP3 is in AP
mode or Client mode.
i. In AP Mode, execute BenQ GP3 EZ QPresenter and a AP list will pop up first.
Just choose “BenQ GP3 ” and press “Connect” to start projection.
ii. In Client Mode, please make sure GP3 connect to a Wi-Fi network first. After
that, execute BenQ GP3 EZ QPresenter and a AP list will pop up. Choose the
Wi-Fi network which GP3 connect to and press “Connect” to start projection.
iii. You can press the pause button in on-screen
control panel to freeze the projection screen
if necessary.
74
Operation
iv. More useful settings like adjusting projection quality or screen capture are
available in settings menu.
Operation
75
Frequently Asked Questions
•
•
•
•
•
•
Q: Why does my CPU become busier after launching the BenQ EZ
QPrensenter?
A: BenQ GP3 EZ QPresenter counts on your PC CPU to encode the screen images to
reduce the data that needs to be transferred to the receiver. Hence there will be some
overhead to your PC. In general, for a 4+ ranking PCs, it would need up to 30% of CPU
overhead to perform wireless display.
Q: Why can’t I project my screen?
A: BenQ GP3 EZ QPresenter needs to access the network connection at some point.
As a result, when your Anti-virus or network security software prompts you for
permission to allow the sender software to access the network, please grant access to
proceed, or choose “add rule” to the fire wall settings.
Q: Why does my display frame rate slow down?
A: BenQ GP3 EZ QPresenter needs to encode display content while sending massive
real-time data to the projector.
i. PC: A dual core PC (excluding Atom processors) or Mac is required to encode
the screen images at 30FPS (Frame Per Second) speed. However, if you would
like to increase the FPS speed, you can:
a. Use better media players, such as GOM player
b. Close all unused apps
c. Use a faster PC with Windows Experience Score higher than 4 (4+
recommended)
ii. Network:
Using 802.11n WiFi
a. Move your laptop closer to the projector
b. Disable the “Minimum Power Consumption” option from the “Advanced Tab” in
your WiFi network Adopter Property setting
c. Lower PC screen resolution
System Requirements for Wireless Display
Mac PC Requirements
CPU Grade
Graphics
Operating System
Recommended Models
Intel Dual Core 1.4 GHz or better (PowerPC not
supported)
nVIDIA or ATI graphic card with 64MB VRAM or above
Mac OS X 10.5+
MacBook after 2009-01-21
All series of MacBook Pro
MacBook Air after 2010-06-08
Windows PC Requirements
CPU Grade
Display Adaptor
Operating System
Wi-Fi
76
Operation
Dual Core 1.8 GHz or better (excluding atom processor)
nVIDIA or ATI graphic card with 64MB VRAM or above
Windows XP SP2/SP3 (32 and 64-bit) / Vista (32 and 64bit) / Windows 7 (32 and 64-bit)
802.11n
Wi-Fi Dongle Specifications
Model Name
Wireless Standard
Interface
Data Transfer Rate
Frequency Band
Security
Supported OS
Minimum PC System
Requirement
WDRT8192
IEEE 802.11 b/g/n
USB 2.0
up to 300Mbps
2.4GHz ISM Band
64 bit/128 bit WEP, TKIP, AES, WPA, WPA2
Windows 2000/XP/Vista/7
CPU: 200MHz or above
RAM: 64MB RAM or above, 128MB recommended
Stream to me
“Stream to Me” gives you an easy way to enjoy videos, pictures and music wirelessly from
DLNA certified or capable devices (e.g. PC, NAS, smartphone, tablet) on a HD-ready
quality big screen with friends and family. For example, download and install DLNA apps
(e.g. iMediaShare) from App store to make your iPhone or Android phone capable with
DLNA and able to stream favorite media to GP3 for sharing.
Stream local media in iPhone or Android phone to GP3
1.
2.
3.
Set GP3’s Wi-Fi mode to AP mode
Select “Wireless Streaming” from home screen.
Select “Stream to me” and then press OK to enter “Stream to Me Welcome
Page” (AP Mode) as below. Follow the instructions shown in welcome page.
Operation
77
i. Enable your iPhone or Android phone’s wireless and select “BenQ GP3” from
wireless access point menu to make connection between GP3 and iPhone/
Android phone.
ii. Open iMediaShare and choose the media type you want to share.
78
Operation
iii. Select the media file like video, music or photo stored in iPhone or Android
phone and send out to GP3.
Stream not only local media but also on-line video in iPhone or
Android phone to GP3
1.
2.
3.
4.
Set GP3's Wi-Fi mode to Client mode.
Connect both your iPhone/Android phone and GP3 to the same Wi-Fi network.
(connect to the same AP router)
Select "Wireless Streaming" from home screen.
Select "Stream to me" and then press OK to enter "Stream to Me Welcome
Page" (Client Mode) as below. Follow the instructions shown in welcome page.
Operation
79
5.
Open iMediaShare and choose on-line video channel you want to share..
6.
Select on-line video clip and send out to GP3.
Use iPhone or Android phone to select local media in PC/NAS and
strem to GP3
1.
2.
3.
80
Set GP3’s Wi-Fi mode to Client mode.
Make sure GP3, PC/NAS and iPhone or Android phone are all in the same wireless
network. (connect to the same AP router)
Select “Wireless Streaming” from home screen.
Operation
4.
Select “Stream to me” and then press OK to enter “Stream to Me Welcome
Page” (Client Mode). Press right or left to another Welcome Page as
below. Follow the instructions shown in welcome page.
5.
Open iMediaShare, choose “Local Network”, select local media in PC/NAS by
iPhone or Android phone and start streaming to GP3.
Operation
81
Settings menu
This menu is to set the projector’s operating environment.
Using the menu
1.
2.
3.
4.
5.
6.
7.
82
To open the OSD menu, press
/ to select Settings and press OK to enter.
When the OSD is displayed, press / to select any item in the main menu.
After selecting the desired main menu item, press OK or
to enter the feature
settings submenu.
Press / to select the desired item and press OK to open the pop-up menu.
Select the settings using / / / and press OK to confirm. Once the setting is
selected, the OSD menu returns to the selected item.
Press
or
to return to the main menu.
You may press
to go back to home screen directly.
Press
again to go back to home screen.
Operation
Menu system
Main menu
Sub-menu
Options
Language
1.
Basic
LED Mode
Normal/Eco
Wall Color
Off/Light Yellow/Pink/Light Green/
Blue/Blackboard
Auto Keystone
Off/On
Auto Power Off
Disable/5 min/10 min/15 min/20
min/25 min/30 min
Splash Screen
BenQ/ Black/Blue
Test Pattern
Off/On
High Altitude Mode
Audio Settings
Off/On
SRS HD
Off/On
Mute
Off/On
Keypad tone
Off/On
Audio in Standby
Mode
Off/iPhone/iPod
5 sec/10 sec/15 sec/20 sec/25 sec/
30 sec
Menu Display Time
Change Password
2.
Advanced
Recall Password
Security Settings
Change Security
Settings
Power On Lock
Front Table/Front Ceiling/Rear
Table/Rear Ceiling
Projector Position
Closed Caption
Off/On
Closed Caption
Enable
Off/Onf
Caption Version
CC1/CC2/CC3/CC4
Firmware Upgrade
Yes/No
Reset All Settings
Reset/Cancel
Operation
83
Wi-Fi Mode
3.
Network
AP Mode
Device Name
BenQ GP3
Security
None/WPA2/WPA/WEP
Encryption Key
xxxxxxxxx
Show Encryption Key
No/Yes
Wi-Fi Mode
Client Mode
Wi-Fi Connection
Configure
Manually assign IP
IP Address
Netmask
Gateway
DNS
Apply
Source
Picture Mode
Color System
4.
Information
Resolution
LED Lamp Lifetime
Internal Memory
SD Card
USB Drive
Firmware Version
84
Operation
Description of each menu
FUNCTION
Language
LED Mode
1. Basic menu
Wall Color
Auto
Keystone
Auto Power
Off
DESCRIPTION
Sets the language for the On-Screen Display (OSD) menus.
Choose Eco to dim the projector LED which will lower power
consumption, extend the LED life and reduce noise. Choose
Normal to return normal mode.
Corrects the projected picture’s color when the projection surface is
not white.
Auto corrects any keystoning of the image.
Allows the projector to turn off automatically if no input signal is
detected after a set period of time.
Allows you to select which logo screen will display during projector
Splash Screen start-up. Three options are available: BenQ logo, Black screen, or
Test Pattern
Blue screen.
Selecting OK enables the function and the projector displays the grid
test pattern. It helps you adjust the image size and focus and check
that the projected image is free from distortion.
Operation
85
FUNCTION
DESCRIPTION
High Altitude A mode for operation in high altitude areas. See "Operating in a high
altitude environment" on page 44 for details.
Mode
Allows you to enter the audio setting menu. See "Adjusting the
sound" on page 44 for details.
SRS HD
Turns on/off SRS HD surround sound effects.
2. Advanced menu
Mute
Sets the mute function.
Audio
Settings
Keypad tone
Sets the keypad tone function.
Audio in Standby Mode
The projector can play sound when it is in standby mode and the
corresponding jacks are correctly connected to devices. Press
/
to choose the source that you wish to use. See "Connection" on
page 21 for how to make the connection.
Enabling this function slightly increases the standby power
consumption.
Menu Display Sets the length of time the OSD will remain active after your last key
press. The range is from 5 to 30 seconds in 5-second increments.
Time
86
Security
Settings
See "Securing the projector" on page 39 for details.
Projector
Position
The projector can be installed on a ceiling or behind a screen, or with
one or more mirrors. See "Choosing a location" on page 15 for
details.
Operation
FUNCTION
DESCRIPTION
Closed Caption Enable
2. Advanced menu
Activates the function by selecting On when the selected input signal
carries closed captions.
•
Closed
Caption
Captions: An on-screen display of the dialogue, narration, and
sound effects of TV programs and videos that are closed
captioned (usually marked as "CC" in TV listings).
Set your screen aspect ratio to 4:3. This function is not available
when the aspect ratio is “16:9”, “16:10” or “Real.
Caption Version
Firmware
Upgrade
Reset All
Settings
Selects a preferred closed captioning mode. To view captions, select
CC1, CC2, CC3, or CC4 (CC1 displays captions in the primary
language in your area).
Updating the latest firmware are only allowed via an SD card.
Returns all settings to the factory preset values.
Operation
87
FUNCTION
Wi-Fi Mode
Device Name
Security
3. Network menu
Encryption
Key
Show
Encryption
Key
Wi-Fi Mode
Wi-Fi
Connection
Configure
DESCRIPTION
Displays AP Mode network settings.
See "Using Wireless Streaming" on page 73 for details.
Allows you to input total 30 characters (only a-z , A-Z , _ , - are
allowed) for the device name /SSID. Select Device Name and press
OK to open a virtual keyboard in full screen. Once Device Name is
set, select Enter in the virtual keyboard and press OK to return to
Network setting.
Allows you to set WPA or WPA2 security modes. Select one of the
two encryption modes, and set the encryption key accordingly.
Allows you to input 8-20 ASCII characters for WPA-PSK or WPA2PSK encryption mode. Select Encryption Key and press OK to open
a virtual keyboard in full screen. You can input the encryption key
using the virtual keyboard. Once Encryption Key is set, select Enter
in the virtual keyboard and press OK to return to Network setting.
If you want to see the encryption key after input the encryption key,
you can select “Yes” in Show Encryption key item. By default, the
encryption key is not shown.
Displays Client Mode network settings.
See "Using Wireless Streaming" on page 73 for details.
Displays Wi-Fi connection status. Press OK to display AP list menu.
Displays IP configure pop-up menu. By default, it automatically
requests an IP address via DHCP. If you select “Yes” in Manually
assign IP, you can set IP Address, Netmask, Gateway and DNS
manually using a virtual keyboard in the screen.
The format of “IP address”, “Netmask”, “Gateway” and “DNS”
should follow 0-255.0-2550-255.0-255.
88
Operation
FUNCTION
Source
DESCRIPTION
Shows the current signal source.
Picture Mode Shows the selected mode.
Color System Shows input system format: RGB or YUV.
4. Information menu
Resolution
Shows the native resolution of the input signal.
LED Lamp
Lifetime
Displays the number of hours the lamp has been used.
Internal
Memory
Shows the Internal Memory capacity status: used memory size/total
memory size.
SD Card
Shows the SD Card capacity status: used memory size/total memory
size.
Shows the USB Drive capacity status: used memory size/total
memory size.
Shows firmware version: xx.xxx (Solomon)/xx.xxx (TI).
USB Drive
Firmware
Version
Operation
89
Shutting down the projector
1.
Press II Power and a confirmation message
displays prompting you.
If you don't respond in a few seconds, the
message will disappear.
2.
3.
Press II Power a second time.
The Power LED indicator flashes orange
slowly and fans stop.
Disconnect the power cord from the wall
socket if the projector will not be used in an extended period of time.
4.
90
Operation
Maintenance
Care of the projector
Your projector needs little maintenance. The only thing you need to do on a regular basis
is to keep the lens clean.
Never remove any parts of the projector. Contact your dealer if other parts need
replacing.
Cleaning the lens
Clean the lens whenever you notice dirt or dust on the surface.
•
•
Use a canister of compressed air to remove dust.
If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens
cleaner and gently wipe the lens surface.
Never rub the lens with abrasive materials.
Cleaning the projector case
Before you clean the case, turn the projector off using the proper shutdown procedure as
described in "Shutting down the projector" on page 90 and unplug the power cord.
•
•
To remove dirt or dust, wipe the case with a soft, lint-free cloth.
To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral pH
detergent. Then wipe the case.
Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the
case.
Storing the projector
If you need to store the projector for an extended time, please follow the instructions
below:
•
•
•
•
Make sure the temperature and humidity of the storage area are within the
recommended range for the projector. Please refer to "Specifications" on page 94 or
consult your dealer about the range.
Retract the adjuster feet.
Remove the battery from the remote control.
Pack the projector in its original packing or equivalent.
Transporting the projector
It is recommended that you ship the projector with its original packing or equivalent.
Maintenance
91
LED Indicators
LED indicators
Status / Problems
Standby
92
LED Behavior
Power
OK &
Ring
Key
Orange
Off
Off
Power LED slow flash
Light solid on sequence :
Power->Key->Ring & OK
Power on
Orange
Orange
White
Cooling
Orange
Off
Off
Power LED slow flash
Fan1 error
Off
Orange
White
Ring & OK LED flash and key
LED light solid
Temp error
Off
Orange
Off
Ring & OK LED flash
Maintenance
Troubleshooting
The projector does not turn on.
Cause
Remedy
Plug the AC adapter into the DC IN socket on the
projector, plug the power cord into the AC inlet
There is no power from the power cable. on the AC adapter, plug the power cord into the
power outlet. If the power outlet has a switch,
make sure that it is switched on.
Attempting to turn the projector on again Wait until the cooling down process has
during the cooling process.
completed.
No picture
Cause
Remedy
The source is not turned on or
connected correctly.
Turn the source on and check that the signal cable
is connected correctly.
The projector is not correctly connected
to the input signal device.
Check the connection.
The input signal has not been correctly
selected.
Select the correct input signal with the
on the projector or remote control.
/
key
Blurred image
Cause
Remedy
The projection lens is not correctly
focused.
Adjust the focus of the lens using the focus ring.
The projector and the screen are not
aligned properly.
Adjust the projection angle and direction as well
as the height of the unit if necessary.
Remote control does not work
Cause
Remedy
The battery is out of power.
Replace the battery with new one.
There is an obstacle between the remote
control and the projector.
Remove the obstacle.
You are too far away from the projector.
Stand within 7 meters (23 feet) of the projector.
The password is incorrect
Cause
Remedy
You do not remember the password.
Please see "Entering the password recall
procedure" on page 40 for details.
Troubleshooting
93
Specifications
Projector specifications
All specifications are subject to change without notice.
General
Product name
Model name
Mini Projector
GP3
Optical
Resolution
Display system
Lens F/Number
Lamp
Throw Ratio
1280 x 800 WXGA
1-CHIP DMD
F = 1.928
f = 26.95 mm
LED
1.16 (40" @ 1m)
Electrical
Power supply
Power consumption
Keystone Adjustment
AC100–240V, 3.42 A,
50-60 Hz (Automatic)
40/27W (Normal/Eco), <0.5W (Standby)
1D, Vertical +/- 40 degrees
Mechanical
Dimensions
Weight
140.3 mm (W) x 52.5 mm (H) x 129.8 mm (D)
590g ( battery : 482g)
Input terminal
Multi-input
Computer input
Component input
Video input
HDMI
Audio input
USB-A type
mini-B USB type
SD card slot
iPhone/iPod input
Internal memory
D-Sub 15-pin (female) x 1
Analog - D-Sub <-> Component RCA jack x 3 (through
RGB input)
HDMI Digital Video x1 (mini type)
RCA jack x 1
HDMI (v1.3) : x1 (mini type)
RCA jack x 2
3.5 mm stereo mini jack x 1
For USB flash drive/Wi-Fi dongle.
Supports videos/photos/music/documents/PC display/
Stream to me.
Supports USB display/USB file transfer
Supports videos/photos/music/documents
with embedded iPhone/iPod dock
2GB (900 MB for user usage)
Output terminal
Audio output
3.5 mm stereo mini jack x 1
Environmental Requirements
94
Specifications
Operating temperature
Operating relative humidity
Operating altitude
0°C-35°C at sea level
10%-90% (without condensation)
• 0–1499 m at 0°C–35°C
• 1500–3000 m at 0°C–30°C (with High Altitude
Mode on)
*China region only applies at altitude up to 2000m.
Specifications
95
Dimensions
140.3 mm (W) x 52.5 mm (H) x 129.8 mm (D)
33
22.8
Timing chart
Supported timing for PC input
Resolution
720 x 400
640 x 480
800 x 600
1024 x 768
1152 x 864
1024 x 576
1024 x 600
1280 x 720
1280 x 768
1280 x 800
1280 x 1024
1280 x 960
1360 x 768
1440 x 900
1680 x 1050
640 x 480
@67Hz
832 x [email protected]
96
Specifications
Mode
Vertical
Frequency (Hz)
Horizontal
Frequency (kHz)
720 x 400_70
VGA_60
VGA_75
VGA_85
VGA_72
SVGA_60
SVGA_75
SVGA_85
SVGA_56
SVGA_72
XGA_60
XGA_70
XGA_75
XGA_85
1152 x 864_75
BenQ Notebook
Timing
BenQ Notebook
Timing
1280 x 720_60
1280 x 768_60
WXGA_60
WXGA_75
WXGA_85
SXGA_60
SXGA_75
1280 x 960_60
1280 x 960_85
1360 x 768_60
WXGA+_60
1680 x 1050_60
70.087
59.940
75.000
85.008
72.809
60.317
75.000
85.061
56.250
72.188
60.004
70.069
75.029
84.997
75.00
31.469
31.469
37.500
43.269
37.861
37.879
46.875
53.674
35.156
48.077
48.363
56.476
60.023
68.667
67.500
60.0
35.820
64.995
41.467
60
59.870
59.810
74.934
84.880
60.020
75.025
60.000
85.002
60.015
59.887
59.954
45.000
47.776
49.702
62.795
71.554
63.981
79.976
60.000
85.938
47.712
55.935
65.290
MAC13
66.667
35.000
MAC16
74.546
49.722
1024 x
[email protected]
1152 x
[email protected]
MAC19
74.93
60.241
MAC21
75.06
68.68
Supported timing for HDMI input
PC timings:
Resolution
640 x 480
720 x 400
800 x 600
1024 x 768
1152 x 864
1024 x 576
1024 x 600
1280 x 720
1280 x 768
1280 x 800
1280 x 1024
1280 x 960
1360 x 768
1440 x 900
1400 x 1050
1680 x 1050
640 x [email protected]
832 x [email protected]
1024 x
[email protected]
1152 x
[email protected]
Mode
Vertical
Frequency (Hz)
Horizontal
Frequency (kHz)
VGA_60
VGA_72
VGA_75
VGA_85
720 x 400_70
SVGA_60
SVGA_72
SVGA_75
SVGA_85
XGA_60
XGA_70
XGA_75
XGA_85
1152 x 864_75
BenQ Notebook
Timing
BenQ Notebook
Timing
1280 x 720_60
1280 x 768_60
WXGA_60
WXGA_75
WXGA_85
SXGA_60
SXGA_75
1280 x 960_60
1280 x 960_85
1360 x 768_60
WXGA+_60
SXGA+_60
1680 x 1050_60
MAC13
MAC16
59.940
72.809
75.000
85.008
70.087
60.317
72.188
75.000
85.061
60.004
70.069
75.029
84.997
75.00
31.469
37.861
37.500
43.269
31.469
37.879
48.077
46.875
53.674
48.363
56.476
60.023
68.667
67.500
60.000
35.820
64.995
41.467
60
59.870
59.810
74.934
84.880
60.020
75.025
60.000
85.002
60.015
59.887
59.978
59.954
66.667
74.546
45.000
47.776
49.702
62.795
71.554
63.981
79.976
60.000
85.938
47.712
55.935
65.317
65.290
35.000
49.772
MAC19
75.020
60.241
MAC21
75.06
68.68
Specifications
97
Video timings:
Timing
480i*
480p
576i
576p
720/50p
720/60p
1080/24P
1080/25P
1080/30P
1080/50i
1080/60i
1080/50P
1080/60P
Resolution
Vertical
Frequency (Hz)
720 (1440) x 480
720 x 480
720 (1440) x 576
720 x 576
1280 x 720
1280 x 720
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
Horizontal
Frequency (kHz)
59.94
59.94
50
50
50
60
24
25
30
50
60
50
60
15.73
31.47
15.63
31.25
37.5
45.00
27
28.13
33.75
28.13
33.75
56.25
67.5
Supported timing for Component-YPbPr input
Timing
480i*
480p
576i
576p
720/50p
720/60p
1080/50i
1080/60i
1080/24P
1080/25P
1080/30P
1080/50P
1080/60P
Resolution
Vertical
Frequency (Hz)
720 x 480
720 x 480
720 x 576
720 x 576
1280 x 720
1280 x 720
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
59.94
59.94
50
50
50
60
50
60
24
25
30
50
60
Horizontal
Frequency (kHz)
15.73
31.47
15.63
31.25
37.5
45.00
28.13
33.75
27
28.13
33.75
56.25
67.5
Supported timing for Video input
Video mode
NTSC*
PAL
SECAM
PAL-M
PAL-N
PAL-60
NTSC4.43
98
Specifications
Vertical Frequency
(Hz)
60
50
50
60
50
60
60
Horizontal Frequency
(kHz)
15.73
15.63
15.63
15.73
15.63
15.73
15.73
Warranty and Copyright information
Patents
This BenQ projector is covered by the following patents:
U.S. patents 7,181,318; TW patents 202690; 205470; I228635; I259932; China Patents ( 中
国发明专利 ) ZL01143168.7; ZL03119907.0; ZL200510051609.2
Limited warranty
BenQ warrants this product against any defects in material and workmanship, under
normal usage and storage.
Proof of purchase date will be required with any warranty claim. In the event this product
is found to be defective within the warranty period, BenQ's only obligation and your
exclusive remedy shall be replacement of any defective parts (labor included). To obtain
warranty service, immediately notify the dealer from which you purchased the product of
any defects.
Important: The above warranty shall be void if the customer fails to operate the product in
accordance with BenQ's written instructions, especially the ambient humidity must be inbetween 10% and 90%, temperature in-between 0°C and 35°C, altitude lower than 4920
feet, and avoiding to operate the projector in a dusty environment. This warranty gives you
specific legal rights, and you may have other rights which vary from country to country.
For other information, please visit www.BenQ.com.
Copyright
© 2013 BenQ Corp. Specification may vary by region, please visit your local stores for
details. Actual product’s features and specifications are subject to change without notice.
This material may include corporate names and trademarks of third parties which are the
properties of the third parties respectively. Apple, the Apple logo, iPad, iPhone, iPod, iPod
classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in
the U.S. and other countries.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied,
with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Further, BenQ Corporation reserves
the right to revise this publication and to make changes from time to time in the contents
hereof without obligation to notify any person of such revision or changes.
*DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments. Others
are copyrights of their respective companies or organizations.
iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of
Apple Inc., registered in the U.S. and other countries.
is a trademark of SRS Labs, Inc.
WOW technology is incorporated under license from SRS Labs, Inc.
Warranty and Copyright information
99
Regulatory Statements
Battery Caution (if product includes remote control)
z
Do not put the remote control in the direct heat, humidity & Avoid fire.
z
Do not drop the remote control.
z
Do not expose the remote control to water or moisture, this could result in malfunction.
z
Confirm there is no object between the remote control and the remote sensor of the product.
z
When the remote control will not be used for an extended period, remove the batteries.
Battery safety notice (if product includes remote control)
The use of the wrong type of batteries may cause chemical leaks or explosion. Please note the following:
z
Always ensure that the batteries are inserted with the positive and negative terminals in the correct
direction as shown in the battery compartment.
z
Different types of batteries have different characteristics. Do not mix different types.
z
Do not mix old and new batteries. Mixing old and new batteries will shorten battery life or cause chemical
leaks from the old batteries.
z
When batteries fail to function, replace them immediately.
z
Chemicals which leak from batteries may cause skin irritation. If any chemical matter seeps out of the
batteries, wipe it up immediately using a dry cloth, and replace the batteries as soon as possible.
z
Due to varying storage conditions, the battery life for the batteries included with your product may be
shortened. Replace them within 3 months or as soon as you can after initial use.
z
There may be local restrictions on the disposal or recycling of batteries. Consult your local regulations or
waste disposal provider.
100
Warranty and Copyright information
FCC statement (for the United States only)
CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the distance between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Warranty and Copyright information
101
Accessibility Requirements for Rehabilitation Act of 1973, Section 508
BenQ's commitment to accessible products allows us to support government in making accessible technology
choices. BenQ's LCD monitors and projectors are compliant with Section 508 guidelines by including the
assistive features as below:
z
BenQ's monitors have colored "Power" indicators. While the indicator shows green, it means that the
monitor is using the full power. While the indicator shows yellow or amber, it means that the monitor is in
suspend or sleep mode and is using less than 2watts of electricity.
z
BenQ's monitors have a variety of settings of pre-programmed flicker-free timing to make the screen
shown on the monitor readily accessible. The default timing setting is automatically turned on every time
the monitor is powered up, and thus reduces the hassle of user intervention.
z
BenQ's monitors and projectors have options for brightness and contrast adjustments that text and
images could be displayed differently to meet the demands of the visually impaired. Other similar
adjustments are also available by using the On-Screen Display (OSD) controls on the products.
z
BenQ's multimedia monitors and projectors usually have one or two speakers for audio performance
which allow users (including hearing impaired) to interact with the computer systems connected. Speaker
controls are typically located on the front-panel.
z
Firmware of BenQ's monitors and projectors contain unique product information that helps computer
systems to identify BenQ products and activate their Plug-and-Play function when connected.
z
All BenQ's monitors and projectors are compatible with the PC99 standard. For example, connectors are
color-coded to help users easily connecting products to computer systems correctly.
z
Some models of BenQ's monitors and projectors contain additional USB and DVI ports for connection to
more devices such as a special headphone to assist the hearing impaired.
z
All BenQ monitors and projectors come with user manuals on compact discs which could be easily read
by commercial software such as Adobe Reader via a connected computer system. These documents are
also available on the BenQ's web site (www.BenQ.com). Other types of documents may be available
upon requests.
z
BenQ's customer service provides answers and assistance to all our customers through phone calls,
facsimiles, e-mails, or web sites.
102
Warranty and Copyright information
IC statement (for Canadian users)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numͼrique de la classe B est conforme ͳ la norme NMB-003 du Canada.
The device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions (If the product within RF function):
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device.
Ce dispositif est conforme a la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de
licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de
brouillage prejudiciable, et (2) ce dispositif doit accepter tout brouillage recu, y compris un brouillage
susceptible de provoquer un fonctionnement indesirable.
For UK only
z
The mains lead (power cable) on the equipment comes with a moulded plug incorporating a fuse.
z
The rating of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved
by ASTA or BSI to BS 1362 of the same rating must be used.
z
If the plug has a detachable fuse cover, remember to place the fuse cover back if you need to change the
fuse.
z
Do NOT use a plug without the fuse cover. If the fuse cover is missing, contact your nearest BenQ
Customer Service Center for assistance.
Warranty and Copyright information
103
CE DOC
English
DECLARATION OF CONFORMITY
The device complies with the requirements set out in the Council Directives on the Approximation of the Laws
of the Member States relating Electromagnetic Compatibility (2004/108/EC) and Low Voltage Directive
(2006/95/EC) and Radio and Telecommunications Terminal Equipment Directive (1999/5/EC), the Restriction
of The Use of Certain Hazardous Substances in Electrical And Electronic Equipment Directive (2011/65/EU),
Turkish EEE Directive; Turkish ErP (Decision 2010/643);the Commission Regulation (EC) No 1275/2008
implementing Directive 2005/32/EC of the European Parliament and of the Council with regard to eco-design
requirements for standby and off mode electric power consumption of electrical and electronic household and
office equipment, and the Directive 2009/125/EC of the European parliament and of the council establishing a
framework for the setting of eco-design requirements for energy-related products.
Français
DÉCLARATION DE CONFORMITÉ
Cet appareil est conforme aux exigences énoncées dans les directives du Conseil sur le rapprochement des
législations des États membres concernant la compatibilité électromagnétique (2004/108/CE) et la Directive
basse tension (2006/95/CE), la directive équipements radio et équipements terminaux de télécommunication
(1999/5/EC), la directive relative à la limitation de l'utilisation de certaines substances dangereuses dans les
équipements électriques et électroniques(2011/65/UE), la directive EEE turc, le règlement (CE) n° 1275/2008
mettant en œuvre la directive 2005/32/CE du Parlement européen et du Conseil en ce qui concerne les
exigences d’écoconception pour le mode veille et arrêt de la consommation d’énergie électrique d’appareils
électriques et électroniques et matériel de bureau, et de la Directive 2009/125/EC du Parlement européen et
du Conseil établissant un cadre pour la fixation d’exigences en matière d’écoconception applicables aux
produits liés à l’énergie.
Español
DECLARACIÓN DE CONFORMIDAD
Este dispositivo cumple con los requisitos establecidos en las Directivas del Consejo sobre la Aproximación
de las Leyes de los Estados Miembros en relación con la Directiva de Compatibilidad Electromagnética
(2004/108/EC) y Directiva de Bajo Voltaje (2006/95/EC) y la Directiva sobre equipos radioeléctricos y
terminales de comunicación (1999/5/EC), la Directiva sobre la restricción del uso de ciertas sustancias
peligrosas en equipos eléctricos y electrónicos (2011/65/UE), la directiva EEE turca, Reglamento (CE) nº
1275/2008 de la Comisión, por el que se desarrolla la Directiva 2005/32/CE del Parlamento Europeo y del
Consejo en lo concerniente a los requisitos de diseño ecológico aplicables al consumo de energía eléctrica
en los modos preparado y desactivado de los equipos eléctricos y electrónicos domésticos y de oficina y la
Directiva 2009/125/EC del Parlamento Europeo y del Consejo por la que se instaura un marco para el
establecimiento de requisitos de diseño ecológico aplicables a los productos relacionados con la energía.
104
Warranty and Copyright information
Deutsch
KONFORMITÄTSERKLÄRUNG
Dieses Gerät erfüllt die Voraussetzungen, welche in den Richtlinien zur Angleichung der Rechtsvorschriften
der Mitgliedstaaten in Bezug auf elektromagnetische Kompatibilität (2004/108/EC), Niederspannungsrichtlinie
(2006/95/EC), Richtlinie für Funkanlagen und Telekommunikations-Endeinrichtungen (1999/95/EC),
Beschränkung der Verwendung bestimmter gefährlicher Stoffe in Elektro- und Elektronikgeräten
(2011/65/EU), Türkische EEE-Direktive, Kommissionreglementierung (EC) Nr. 1275/2008 zur Ausführung der
Direktive 2005/32/EC des Europaparlamentes und des Rats für Öko-Design-Voraussetzungen für
Stromverbrauch im Standby- und Aus-Modus von Elektro- und Elektronikgeräten für den Heim- und
Bürogebrauch und die Direktive 2009/125/EC des Europaparlamentes und es Rats zu Etablierung eines
Rahmens zum Aufstellen von Voraussetzungen für Öko-Designs für Energie verbrauchende Produkte
aufgestellt wurden.
Italiano
DICHIARAZIONE DI CONFORMITÀ
Il dispositivo è conforme con i requisiti esposti nel Consiglio Direttivo in materia di Approssimazione delle
Leggi degli Stati Membri in relazione alla Compatibilità Elettromagnetica (2004/108/EC) e alla Direttiva basso
voltaggio (2006/95/EC) e alla Direttiva sugli Apparati Radio e Terminali di Telecomunicazione (1999/5/EC),
Direttiva sulla restrizione dell’uso di sostanze pericolose nelle apparecchiature elettriche ed elettroniche
(RoHS) (2011/65/UE), Direttiva EEE turca, Regolamento della Commissione (EC) No 1275/ 2008 che
implementa la Direttiva 2005/32/EC del Parlamento europeo e del Consiglio in merito ai requisiti di ecodesign
per il consumo di alimentazione elettrica in modalità standby e spento per le apparecchiature elettriche
domestiche e di lavoro, e la Direttiva 2009/ 125/EC del Parlamento europeo e del Consiglio che stabilisce la
struttura dell’impostazione dei requisiti di ecodesign per prodotti basati su energia.
Pyccɤɢɣ
ɁȺəȼɅȿɇɂȿ Ɉ ɋɈɈɌȼȿɌɋɌȼɂɂ
ɗɬɨ ɭɫɬɪɨɣɫɬɜɨ ɫɨɨɬɜɟɬɫɬɜɭɟɬ ɬɪɟɛɨɜɚɧɢɹɦ Ʉɨɦɢɫɫɢɢ ɧɚ ɨɫɧɨɜɟ ɡɚɤɨɧɨɜ ɝɨɫɭɞɚɪɫɬɜ-ɭɱɚɫɬɧɢɤɨɜ
ɨɬɧɨɫɢɬɟɥɶɧɨ ɷɥɟɤɬɪɨɦɚɝɧɢɬɧɨɣ ɫɨɜɦɟɫɬɢɦɨɫɬɢ (2004/108/EC), ɞɢɪɟɤɬɢɜɟ ɞɥɹ ɧɢɡɤɨɜɨɥɶɬɧɨɝɨ
ɨɛɨɪɭɞɨɜɚɧɢɹ (2006/95/EC) ɢ ɞɢɪɟɤɬɢɜɟ ɨ ɪɚɞɢɨ- ɢ ɬɟɥɟɤɨɦɦɭɧɢɤɚɰɢɨɧɧɨɦ ɬɟɪɦɢɧɚɥɶɧɨɦ
ɨɛɨɪɭɞɨɜɚɧɢɢ (1999/5/EC), Ⱦɢɪɟɤɬɢɜɵ ɩɨ ɨɝɪɚɧɢɱɟɧɢɸ ɢɫɩɨɥɶɡɨɜɚɧɢɹ ɧɟɤɨɬɨɪɵɯ ɨɩɚɫɧɵɯ ɜɟɳɟɫɬɜ ɜ
ɷɥɟɤɬɪɢɱɟɫɤɨɦ ɢɷɥɟɤɬɪɨɧɧɨɦ ɨɛɨɪɭɞɨɜɚɧɢɢ (2011/65/EU), Ɍɭɪɟɰɤɨɣ ɞɢɪɟɤɬɢɜɵ EEE, ɉɪɚɜɢɥ ɤɨɦɢɫɫɢɢ
(EC) No 1275/2008 ɨɛɟɫɩɟɱɢɜɚɸɳɟɣ ɜɵɩɨɥɧɟɧɢɟ Ⱦɢɪɟɤɬɢɜɵ 2005/32/EC ȿɜɪɨɩɟɣɫɤɨɝɨ ɉɚɪɥɚɦɟɧɬɚ ɢ
ɋɨɜɟɬɚ ɨɬɧɨɫɢɬɟɥɶɧɨ ɬɪɟɛɨɜɚɧɢɣ ɷɤɨɞɢɡɚɣɧɚ ɞɥɹ ɩɨɬɪɟɛɥɟɧɢɹ ɷɧɟɪɝɢɢ ɜɪɟɠɢɦɟ ɨɠɢɞɚɧɢɹ ɢ ɜ ɪɟɠɢɦɟ
ɨɬɤɥɸɱɟɧɢɹ ɛɵɬɨɜɵɦ ɷɥɟɤɬɪɢɱɟɫɤɢɦ ɢ ɷɥɟɤɬɪɨɧɧɵɦ ɨɛɨɪɭɞɨɜɚɧɢɟɦ ɢ ɨɮɢɫɧɨɣ ɬɟɯɧɢɤɨɣ, ɢ
Ⱦɢɪɟɤɬɢɜɨɣ 2009/125/EC ȿɜɪɨɩɟɣɫɤɨɝɨ ɩɚɪɥɚɦɟɧɬɚ ɢ ɫɨɜɟɬɚ, ɭɫɬɚɧɨɜɢɜɲɟɝɨ ɪɚɦɤɢ ɞɥɹ ɫɨɡɞɚɧɢɹ
ɬɪɟɛɨɜɚɧɢɣ ɷɤɨɞɢɡɚɣɧɚ ɞɥɹ ɷɥɟɤɬɪɨɩɪɢɛɨɪɨɜ.
Warranty and Copyright information
105
Svenska
KONFORMITETSDEKLARATION
Denna enhet uppfyller kraven i rådets direktiv om tillnärmning av medlemsstaternas lagstiftning om
elektromagnetisk kompatibilitet (2004/108/EG) och lågspänningsdirektiv (2006/95/EG) och direktivet om
radioutrustning och teleterminalutrustning (1999/5/EC), begränsning av användningen av vissa farliga ämnen
i elektriska och elektroniska produkter (2011/65/EU), turkiskt EEE-direktiv, kommissionsbestämmelse (EG) nr.
1275/2008 med implementering av direktiv 2005/32/EG i Europaparlamentet och rådet för att fastställa krav
på ekodesign för standby- och av-läge för strömförbrukning i elektriska och elektroniska hushålls- och
kontorsapparater, och Europaparlamentets och rådets direktiv 2009/125/EG om upprättande av en ram för att
fastställa krav på ekodesign för energirelaterade produkter.
Nederlands
VERKLARING VAN OVEREENSTEMMING
Dit apparaat voldoet aan de vereisten van de Richtlijn van de Raad betreffende de onderlinge aanpassing van
de wetgevingen van de lidstaten inyake elektromagnetische compatibiliteit (2004/108/EG) en de Richtlijn
betreffende Lage spanningen (2006/95/EG) en de Richtlijn betreffende Radio- en
telecommunicatieapparatuur (1999/5/EG), betreffende de beperkingen van het gebruik van bepaalde
gevaarlijke stoffen in elektrische en elektronische apparatuur (2011/65/EU), Turkse EEE Richtlijn,
Verordening (EG) nr. 1275/2008 tot vaststelling van uitvoeringsbepalingen van Richtlijn 2005/32/EC van het
Europees Parlement en de Raad, wat betreft voorschriften inzake ecologisch ontwerp voor het
elektriciteitsverbruik van elektrische en elektronische huishoud- en kantoorapparatuur in de stand-by-stand
en de uit-stand, en Richtlijn 2009/125/EC van het Europees Parlement en de Raad betreffende de
totstandbrenging van een kader voor het vastellen van eisen inzake ecologisch ontwerp voor
energiegerelateerde producten.
Polski
OĞwiadczenie zgodnoĞci
To urządzenie jest zgodne z wymaganiami ustalonymi Dyrektywą Rady o zbliĪeniu przepisów prawnych
paĔstw czáonkowskich dotyczących kompatybilnoĞci elektromagnetycznej (2004/108/EC), dyrektywą niskiego
napiĊcia (2006/95/EC), dyrektywą wsprawieurzČdzeŷradiowychikoŷcowychurzČdzeŷ
telekomunikacyjnych(1999/5/EC), dyrektywą ograniczenia stosowania niektórych niebezpiecznych
substancji w wyposaĪeniu elektrycznym ielektronicznym (2011/65/UE), turecką dyrektywą EEE,
rozpocządzeniem komisji (WE) nr 1275/2008 w sprawie wykonania dyrektywy 2005/32/WE Parlamentu
Europejskiego i Rady w odniesieniu do wymogów dotyczących ekoprojektu dla zuĪycia energii przez
elektryczne i elektroniczne urządzenia gospodarstwa domowego i urządzenia biurowe w trybie czuwania i
wyáączenia oraz dyrektywą 2009/125/EC, ustanawiającą ogólne zasady ustalania wymogów dotyczących
ekoprojektu dla produktów związanych zenergią.
106
Warranty and Copyright information
ýeština
PROHLÁŠENÍ O SHODċ
Toto zaĜízení odpovídá požadavkĤm stanoveným ve smČrnici Rady o sbližování právních pĜedpisĤ þlenských
státĤ týkajících se elektromagnetické kompatibility (2004/108/ES), ve smČrnici týkající se nízkonapČĢových
zaĜízení (2006/95/ES), ve smČrnici o rádiových zaĜízeních a telekomunikaþních koncových zaĜízeních
(1999/5/ES), ve smČrnici o omezení používání nČkterých nebezpeþných látek v elektrických a elektronických
zaĜízeních (2011/65/EU), v turecké smČrnici EEE, v naĜízení Komise (ES) þ. 1275/2008, kterým se provádí
smČrnice 2005/32/ES Evropského parlamentu a Rady týkající se požadavkĤ na ekodesign zhlediska spotĜeby
elektrické energie u elektrických a elektronických zaĜízení vpohotovostním režimu a ve vypnutém stavu
urþených pro domácnosti a kanceláĜe avesmČrnici Evropského parlamentu a Rady 2009/125/ES o stanovení
rámce pro urþení požadavkĤ na ekodesign výrobkĤ spojených se spotĜebou energie.
Türkçe
UYUM BEYANI
Bu aygıt Üye Ülkelerin Yasalarının Yakınlaútırılması ba÷lamında Konsey Direktifleri dahilinde getirilen
gereklilikler, Elektromanyetik Uyumluluk (2004/108/EC) ve Düúük Voltaj Direktifi (2006/95/EC) ve Radyo ve
Telekomünikasyon Terminal Ekipmanı Direktifi (1999/5/EC), Elektrikli ve Elektronik Aletlerde Tehlikeli
Maddelerin Kullanımıyla ølgili Sınırlamalar Direktifi (2011/65/EU) i Türkiye EEC Direktifi, Türk ErP (Karar
2010/643); Avrupa Parlamentosu ve Konseyinin elektrikli ve elektronik ev aletleri ve büro ekipmanlarının
bekleme ve kapalı moddayken elektrik tüketimleriyle ilgili eko-tasarım gereklilikleri ba÷lamında yayınlamıú
oldu÷u 2005/32/EC numaralı Direktifin uygulanmasıyla ilgili Komisyon Tüzü÷ü (EC) No 1275/2008 ve Avrupa
Parlamentosu veKonseyinin enerji sarfiyatıyla ürünlerin eko-tasarım gerekliliklerinin düzenlenmesi
ba÷lamında bir çerçeve çizen 2009/125/EC numaralı Direktifiyle uyumludur.
Português
DECLARAÇÃO DE CONFORMIDADE
O dispositivo está conforme aos requisitos definidos pelas Directivas do Conselho sobre a Aproximação das
Leis dos Estados-Membros relativamente à Compatibilidade Electromagnética (2004/108/CE) e Directiva de
Baixa Tensão (2006/95/CE) e a Directiva relativa aos equipamentos de rádio e equipamentos terminais de
telecomunicações (1999/5/CE), a restrição do uso de determinadas substâncias perigosas em equipamentos
eléctricos e electrónicos (2011/65/EU), Directiva Turca EEE, Regulamento da Comissão (EC) nº. 1275/2008
que implementa a Directiva 2005/32/EC do Parlamento Europeu e do Conselho relativamente aos requisitos
de eco-design para consumo de energia eléctrica no modo de suspensão e desligado de equipamentos
eléctricos e electrónicos domésticos e de escritório, e a Directiva 2009/125/EC do Parlamento Europeu e do
Conselho, que estabelece uma base para a definição dos requisitos de eco-design para produtos
relacionados com energia.
Warranty and Copyright information
107
Magyar
MEGFELELėSÉGI NYILATKOZAT
Az eszköz megfelel a Bizottság tagállamainak harmonizált jogszabályainak az elektromágneses
kompatibilitás (2004/108/EK) és a kisfeszültségĦ direktíva (2006/95/EK), a rádiófrekvenciás és
telekommunikációs végberendezések direktíva (1999/5/EK), továbbá az elektromos eszközök egyes
veszélyesanyag-felhasználását korlátozó direktíva (2011/65/EU),a török EEE direktíva, a 1275/2008 sz.
Bizottsági szabályozás (EK) (amely az Európai Parlament és a Bizottság 2005/32/EK sz. direktíváját vezeti be
az elektromos és elektronikus háztartási és irodai eszközök környezetbarát kialakításával, környezetbarát
készenléti és kikapcsolt állapotbeli fogyasztásával kapcsolatban) és az Európai Parlament ésa Bizottság
2009/125/EK sz. direktíva (amely az energiahasználó termékek környezetbarát kialakítási követelményeinek
keretrendszerét határozza meg) tekintetében.
Ȼɴɥɝɚɪɫɤɢ
ȾȿɄɅȺɊȺɐɂə ɁȺ ɋɔɈɌȼȿɌɋɌȼɂȿ
Ɍɨɜɚ ɭɫɬɪɨɣɫɬɜɨ ɨɬɝɨɜɚɪɹ ɧɚ ɢɡɢɫɤɜɚɧɢɹɬɚ, ɭɫɬɚɧɨɜɟɧɢ ɨɬ ɞɢɪɟɤɬɢɜɢɬɟ ɧɚ ȿɜɪɨɩɟɣɫɤɢɹ ɫɴɸɡ ɡɚ
ɯɚɪɦɨɧɢɡɢɪɚɧɟ ɧɚ ɡɚɤɨɧɨɞɚɬɟɥɫɬɜɚɬɚ ɧɚ ɞɴɪɠɚɜɢɬɟ-ɱɥɟɧɤɢ ɜ ɨɛɥɚɫɬɬɚ ɧɚ ɟɥɟɤɬɪɨɦɚɝɧɢɬɧɚɬɚ
ɫɴɜɦɟɫɬɢɦɨɫɬ (2004/108/EC), Ⱦɢɪɟɤɬɢɜɚɬɚ ɡɚ ɧɢɫɤɨ ɧɚɩɪɟɠɟɧɢɟ (2006/95/EC), Ⱦɢɪɟɤɬɢɜɚɬɚ ɡɚ ɪɚɞɢɨ ɢ
ɬɟɥɟɤɨɦɭɧɢɤɚɰɢɨɧɧɨ ɬɟɪɦɢɧɚɥɧɨ ɨɛɨɪɭɞɜɚɧɟ (1999/5/EC), Ⱦɢɪɟɤɬɢɜɚɬɚ ɡɚ ɨɝɪɚɧɢɱɚɜɚɧɟ ɧɚ
ɭɩɨɬɪɟɛɚɬɚ ɧɚ ɧɹɤɨɢ ɨɩɚɫɧɢ ɜɟɳɟɫɬɜɚ ɜɟɥɟɤɬɪɢɱɟɫɤɨɬɨ ɢ ɟɥɟɤɬɪɨɧɧɨɬɨ ɨɛɨɪɭɞɜɚɧɟ (2011/65/EC),
ɬɭɪɫɤɚɬɚ EEE Ⱦɢɪɟɤɬɢɜɚ, Ɋɟɝɥɚɦɟɧɬ ʋ 1275/2008 ɧɚ Ʉɨɦɢɫɢɹɬɚ (EC) ɩɨ ɢɡɩɴɥɧɟɧɢɟ ɧɚ Ⱦɢɪɟɤɬɢɜɚ
2005/32/EC ɧɚ ȿɜɪɨɩɟɣɫɤɢɹ ɩɚɪɥɚɦɟɧɬ ɢ ɧɚ ɋɴɜɟɬɚ ɨɬɧɨɫɧɨ ɢɡɢɫɤɜɚɧɢɹɬɚ ɩɨ ɨɬɧɨɲɟɧɢɟ ɧɚ
ɟɤɨɥɨɝɢɱɧɢɹ ɞɢɡɚɣɧ ɡɚ ɩɨɬɪɟɛɥɟɧɢɟ ɧɚ ɟɥɟɤɬɪɨɟɧɟɪɝɢɹ ɜ ɪɟɠɢɦ ɧɚ ɝɨɬɨɜɧɨɫɬ ɢ ɢɡɤɥɸɱɟɧɨ ɩɨɥɨɠɟɧɢɟ
ɨɬ ɟɥɟɤɬɪɨɧɧɢ ɢ ɟɥɟɤɬɪɢɱɟɫɤɢ ɞɨɦɚɤɢɧɫɤɢ ɭɪɟɞɢ ɢɨɮɢɫ ɨɛɨɪɭɞɜɚɧɟ ɢ Ⱦɢɪɟɤɬɢɜɚ 2009/125/EC ɧɚ
ȿɜɪɨɩɟɣɫɤɢɹ ɩɚɪɥɚɦɟɧɬ ɢ ɧɚ ɋɴɜɟɬɚ, ɤɨɢɬɨ ɭɫɬɚɧɨɜɹɜɚɬ ɪɚɛɨɬɧɚ ɪɚɦɤɚ ɡɚ ɫɴɡɞɚɜɚɧɟ ɧɚ ɢɡɢɫɤɜɚɧɢɹ ɡɚ
ɟɤɨɥɨɝɢɱɟɧ ɞɢɡɚɣɧ ɧɚɫɜɴɪɡɚɧɢ ɫ ɟɧɟɪɝɟɬɢɤɚɬɚ ɩɪɨɞɭɤɬɢ.
Hrvatski
DEKLARACIJA O USKLAĈENOSTI
Ureÿaj je u skladu sa zahtjevima navedenim u Direktivama komisije za usklaÿivanje zakona država þlanica u
svezi elektromagnetske kompatibilnosti (2004/108/EC) i Direktivom za niske napone (2006/95/EC) i
Direktivom za radio i telekomunikacijske terminalne ureÿaje (1999/5/EC), Direktivi o ograniþenju upotrebe
odreÿenih opasnih tvari uelektriþnoj i elektroniþkoj opremi (2011/65/EU), EEE direktivi Turske, Propisu
komisije (EC) br. 1275/2008 o implementiranju Direktive 2005/32/EC Europskog parlamenta iVijeüa po pitanju
ekodizajnerskih zahtjeva za elektriþnu potrošnju u mirovanju iiskljuþenom stanju elektriþne i elektroniþke
opreme u kuüanstvu i uredima, te Direktive 2009/125/EC Europskog parlamenta i Vijeüa koja uspostavlja
radni okvir za odreÿivanje ekodizajnerskih zahtjeva za energetske proizvode.
108
Warranty and Copyright information
Română
DECLARAğIE DE CONFORMITATE
Acest dispozitiv este în conformitate cu prevederile stabilite prin Directivele Consiliului privind apropierea
legislaĠiilor statelor membre cu privire la compatibilitatea electromagnetică (2004/108/CE) úi Directiva privind
joasa tensiune (2006/95/CE) úi Directiva privind echipamentele hertziene úi echipamentele terminale de
telecomunicaĠii (1999/5/CE),Directiva de RestricĠie a Utilizării Anumitor SubstanĠe Periculoase în
Echipamentele Electrice úi Electronice (2011/65/UE), Directive EEE pentru Turcia, Regulamentul Comisiei
(EC) Nr. 1275/2008 de implementare a Directivei 2005/32/EC a Parlamentului European úi a Consiliului cu
privire la elementele de design ecologic pentru pentru consumul energetic al echipamentelor electrice úi
electronice de uz casnic úi de birou înmodurile de aúteptare úi oprire úi Directiva 2009/125/EC a
Parlamentului European úi a Consiliului pentru stabilirea unui cadru de lucru în îndeplinirea cerinĠelor de
design ecologic al produselor cu consum energetic.
ǼȜȜȘȞȚțȐ
ǻǾȁȍȈǾ ȈȊȂȂȅȇĭȍȈǾȈ
Ǿ ʌĮȡȠȪıĮ ıȣıțİȣȒ ıȣȝȝȠȡijȫȞİIJĮȚ ȝİ IJȚȢ ĮʌĮȚIJȒıİȚȢ ʌȠȣ ȠȡȓȗȠȞIJĮȚ ıIJȚȢ ȅįȘȖȓİȢ IJȠȣ ǼȣȡȦʌĮȧțȠȪ
ȈȣȝȕȠȣȜȓȠȣ ȖȚĮ IJȘȞ ʌȡȠıȑȖȖȚıȘ IJȦȞ ȞȠȝȠșİıȚȫȞ IJȦȞ ȤȦȡȫȞ-ȝİȜȫȞ ıȤİIJȚțȐ ȝİ IJȘȞ ǾȜİțIJȡȠȝĮȖȞȘIJȚțȒ
ȈȣȝȕĮIJȩIJȘIJĮ (2004/108/EȀ) țĮȚ IJȘȞ ȅįȘȖȓĮ ʌİȡȓ ȋĮȝȘȜȫȞ ȉȐıİȦȞ (2006/95/EȀ) țĮȚ IJȘȞ ȅįȘȖȓĮ ʌİȡȓ
ȉİȡȝĮIJȚțȠȪ İȟȠʌȜȚıȝȠȪ ȇĮįȚȠijȦȞȓĮȢ țĮȚ ȉȘȜİʌȚțȠȚȞȦȞȚȫȞ (1999/5/EȀ), ıIJȘȞ ĮʌĮȖȩȡİȣıȘ IJȘȢ ȤȡȒıȘȢ
ȠȡȚıȝȑȞȦȞ İʌȚțȓȞįȣȞȦȞ ȣȜȚțȫȞ ıIJȘȞ ȅįȘȖȓĮ ǾȜİțIJȡȚțȠȪ țĮȚ ȘȜİțIJȡȠȞȚțȠȪ İȟȠʌȜȚıȝȠȪ (2011/65/EE), ıIJȘȞ
ȉȠȣȡțȚțȒ ȠįȘȖȓĮ EEE, ıIJȠȞ ȀĮȞȠȞȚıȝȩ IJȘȢ ǼʌȚIJȡȠʌȒȢ (ǼȀ) ǹȡ. 1275/2008 ʌȠȣ İijĮȡȝȩȗİȚ IJȘȞ ȅįȘȖȓĮ
2005/32/ǼȀ IJȠȣ ǼȣȡȦʌĮȧțȠȪ ȀȠȚȞȠȕȠȣȜȓȠȣ țĮȚ IJȠȣ ȈȣȝȕȠȣȜȓȠȣ ȩıȠȞ ĮijȠȡȐ IJȚȢ ĮʌĮȚIJȒıİȚȢ ȠȚțȠȜȠȖȚțȠȪ
ıȤİįȚĮıȝȠȪ ȖȚĮ țĮIJĮȞȐȜȦıȘ ȡİȪȝĮIJȠȢ ıIJȘȞ ĮȞĮȝȠȞȒ țĮȚ ıIJȘȞ ĮʌİȞİȡȖȠʌȠȓȘıȘ IJȠȣ ȘȜİțIJȡȚțȠȪ țĮȚ
ȘȜİțIJȡȠȞȚțȠȪ İȟȠʌȜȚıȝȠȪ, ȠȚțȚĮțȠȪ İȟȠʌȜȚıȝȠȪ țĮȚ İȟȠʌȜȚıȝȠȪ ȖȡĮijİȓȠȣ țĮȚ IJȘȞ ȅįȘȖȓĮ 2009/125/ǼȀ IJȠȣ
ǼȣȡȦʌĮȧțȠȪ ȀȠȚȞȠȕȠȣȜȓȠȣ țĮȚ IJȠȣ ȈȣȝȕȠȣȜȓȠȣ ʌȠȣ İȖțĮșȚıIJȐ ȑȞĮ ʌȜĮȓıȚȠ ȖȚĮ IJȘ ȡȪșȝȚıȘ IJȦȞ ĮʌĮȚIJȒıİȦȞ
ȠȚțȠȜȠȖȚțȠȪ ıȤİįȚĮıȝȠȪ ȖȚĮ ʌȡȠȧȩȞIJĮ ʌȠȣ ȑȤȠȣȞ ıȤȑıȘ ȝİ IJȘȞ țĮIJĮȞȐȜȦıȘ İȞȑȡȖİȚĮȢ.
Danich
OVERENSSTEMMELSESERKLÆRING
Apparatet er i overensstemmelse med kravene i Rådets direktiver om indbyrdes tilnærmelse af
medlemsstaternes lovgivning om elektromagnetisk kompatibilitet (2004/108/EF) og lavspændingsdirektivet
(2006/95/EF) og radio-og teleterminaludstyr (1999/5/EF), begrænsning af anvendelsen af visse farlige stoffer
i elektrisk og elektronisk udstyr (2011/65/EU), Tyrkisk EEE direktiv, Kommissionens forordning (EF) nr.
1275/2008 om gennemførelse af direktiv 2005/32/EF af Europa-Parlamentets og Rådets direktiv med hensyn
til krav til miljøvenligt design for elforbrug i standbytilstand og slukket tilstand af elektrisk og elektronisk
husholdnings-og kontorudstyr, og direktiv 2009/125/EF af Europa-Parlamentet og Rådet om rammerne for
fastlæggelse af krav til miljøvenligt design af energiforbrugende produkter.
Warranty and Copyright information
109
Finnish
VAATIMUSTENMUKAISUUSVAKUUTUS
Laite täyttää sähkömagneettista yhteensopivuutta koskevan EMC-direktiivin (2004/108/EY),
pienjännitedirektiivin (2006/95/EY), radio- ja telepäätelaitedirektiivin (1999/5/EY) ja vaarallisten aineiden
käytön rajoittamista sähkö- ja elektroniikkalaitteissa koskevan direktiivin (2011/65/EU), turkkilaisen
EEE-direktiivin; komission asetuksen (EY) N:o 1275/2008 direktiivin 2005/32/EY täytäntöönpanosta
kotitalouksissa ja toimistoissa käytettävien sähkö- ja elektroniikkalaitteiden lepovirtakulutuksen ekologista
suunnittelua koskevien vaatimusten osalta sekä Euroopan parlamentin ja neuvoston direktiivin 2009/125/EY
energiaan liittyvien tuotteiden ekologiselle suunnittelulle asetettavien vaatimusten puitteista.
Norwegian
SAMSVARSERKLÆRING
Enheten er i samsvar med de angitte kravene i EU-direktivene om tilnærming av lovene i medlemslandene
angående elektromagnetisk kompatibilitet (2004/108/EC), lavspenning (2006/95/EC) og radio og
telekommunikasjonsutstyr (1999/5/EC), begrensningen i bruk av visse farlige substanser i EU-direktivet for
elektrisk og elektronisk utstyr (2011/65/EU), det tyrkiske EEE-direktivet, EU-kommisjonsforskrift nr.
1275/2008 som iverksetter EU-parlamentets og EU-rådets direktiv 2005/32/EC angående øko-designkrav til
strømforbruk i beredt og avslått elektrisk og elektronisk utstyr til hjem og kontor og EU-parlamentets direktiv
2009/125/EC som etablerer et rammeverk for etableringen av øko-designkrav for energirelaterte produkter.
110
Warranty and Copyright information
WEEE directive
English
Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in
private households in the European Union.
This symbol on the product or on the packaging indicates that this can not be disposed
of as household waste. You must dispose of your waste equipment and/or battery by
WEEE
handling it over to the applicable take-back scheme for the recycling of electrical and
electronic equipment and/or battery. For more information about recycling of this
equipment and/or battery, please contact your city office, the shop where you
purchased the equipment or your household waste disposal service. The recycling of
Battery
materials will help to conserve natural resources and ensure that it is recycled in a
manner that protects human health and environment.
Recycling information: See http://www.benq.com/support/recycle for details.
Français
Directive DEEE
Mise au rebut des déchets d’équipements électriques et électroniques et/ou des
piles par les particuliers dans l’Union Européenne.
Ce symbole figurant sur le produit ou l’emballage signifie que celui-ci ne peut pas être
jeté avec les ordures ménagères. Vous devez mettre vos déchets d’équipements et/ou
piles au rebut en le déposant dans un point de collecte prévu à cet effet afin que les
WEEE
équipements électroniques et électriques et/ou piles soient recyclés. Pour de plus
amples informations sur le recyclage de ce produit et/ou cette pile, veuillez prendre
contact avec l’organisme local compétent, le service d’élimination des déchets
ménagers ou le point de vente du produit.Le recyclage des matériaux aidera à
Pile
conserver les ressources naturelles et à s’assurer qu’ils seront recyclés d’une façon
que cela protège la santé humaine et l’environnement.
Recycling information: See http://www.benq.com/support/recycle for details.
Warranty and Copyright information
111
Español
Directiva WEEE
Residuos de aparatos eléctricos y electrónicos y/o batería por parte de los
usuarios domésticos privados en la Unión Europea.
El símbolo que muestra el producto o el embalaje indica que no puede ser desechado
como residuo doméstico. Para desechar el equipo siga las directrices aplicables para
WEEE
el reciclaje de equipo eléctrico y electrónico y/o batería.
Para obtener más información sobre el reciclaje de este equipo y/o batería, póngase
en contacto con el ayuntamiento, la tienda donde adquirió el equipo o el servicio de
recogida de basuras. Al reciclar materiales ayudamos a conservar el medio natural y a
Batería
garantizar el reciclaje de manera que proteja la salud y el medioambiente.
Recycling information: See http://www.benq.com/support/recycle for details.
Deutsch
WEEE-Richtlinie
Entsorgung von Elektro- und Elektronikgeräten bzw. Batterien in
Privathaushalten der Europäischen Union.
Das Symbol auf der Produktverpackung zeigt an, dass dieses Gerät nicht mit dem
normalen Hausmüll entsorgt werden darf. Sie sind verpflichtet, Ihre Altgeräte bzw.
Batterien entsprechend der geltenden Bestimmungen für die Wiederverwertung von
WEEE
Elektro- und Elektronik-Altgeräten bzw. Batterien zu entsorgen. Weitere Informationen
über das Recycling dieses Geräts bzw. Batterie erhalten Sie von Ihren örtlichen
Behörden, Ihrem Fachhändler oder der lokalen Rücknahmestelle. Fachgerechtes
Wertstoffrecycling spart nicht nur wertvolle Ressourcen, sondern schützt auch Umwelt
Batterie
und Gesundheit.
Recycling information: See http://www.benq.com/support/recycle for details.
Italiano
Direttiva WEEE
Smaltimento di apparecchi elettrici ed elettronici e/o batterie nell'Unione
Europea da parte di utenti privati.
Questo simbolo sul prodotto o sulla confezione indica che l'articolo non può essere
smaltito come i normali rifiuti domestici. È necessario smaltire le apparecchiature e/o
batterie secondo quanto previsto dagli schemi di recupero per il riciclaggio di
WEEE
apparecchiature elettriche e elettroniche e/o batterie. Per ulteriori informazioni sul
riciclaggio di questo apparecchio e/o batteria, contattare l’ente della propria città, il
negozio dove è stato acquistato l’apparecchio o il proprio servizio di smaltimento rifiuti
domestici. Il riciclaggio dei materiali contribuisce a ridurre il consumo di risorse naturali
Batteria
e assicura che i materiali siano riciclati tutelando la salute umana e l'ambiente.
Recycling information: See http://www.benq.com/support/recycle for details.
13
112
Warranty and Copyright information
Pyccɤɢɣ
Ⱦɢɪɟɤɬɢɜɚ WEEE
ɍɬɢɥɢɡɚɰɢɹ ɷɥɟɤɬɪɢɱɟɫɤɨɝɨ ɢ ɷɥɟɤɬɪɨɧɧɨɝɨ ɨɛɨɪɭɞɨɜɚɧɢɹ ɢ/ɢɥɢ
ɚɤɤɭɦɭɥɹɬɨɪɨɜ ɧɚɫɟɥɟɧɢɟɦ ɜ ȿɜɪɨɩɟɣɫɤɨɦ ɫɨɸɡɟ.
Ⱦɚɧɧɵɣ ɫɢɦɜɨɥ ɧɚ ɢɡɞɟɥɢɢ ɢɥɢ ɧɚ ɭɩɚɤɨɜɤɟ ɨɡɧɚɱɚɟɬ, ɱɬɨ ɞɚɧɧɨɟ ɢɡɞɟɥɢɟ ɡɚɩɪɟɳɚɟɬɫɹ
ɭɬɢɥɢɡɢɪɨɜɚɬɶ ɧɚɪɚɜɧɟ ɫ ɛɵɬɨɜɵɦɢ ɨɬɯɨɞɚɦɢ. ȼɵ ɞɨɥɠɧɵ ɫɞɚɜɚɬɶ ɜɫɟ ɩɪɢɲɟɞɲɢɟ ɜ
ɧɟɝɨɞɧɨɫɬɶ ɭɫɬɪɨɣɫɬɜɚ ɢ/ɢɥɢ ɚɤɤɭɦɭɥɹɬɨɪɵ ɞɥɹ ɭɬɢɥɢɡɚɰɢɢ ɧɚ ɫɩɟɰɢɚɥɶɧɵɣ
WEEE
ɩɭɧɤɬ ɫɛɨɪɚ ɷɥɟɤɬɪɢɱɟɫɤɢɯ ɢɥɢ ɷɥɟɤɬɪɨɧɧɵɯ ɭɫɬɪɨɣɫɬɜ ɢ/ɢɥɢ ɚɤɤɭɦɭɥɹɬɨɪɨɜ. Ⱦɥɹ
ɩɨɥɭɱɟɧɢɹ ɩɨɞɪɨɛɧɵɯ ɫɜɟɞɟɧɢɣ ɨ ɩɟɪɟɪɚɛɨɬɤɟ ɷɬɨɝɨ ɨɛɨɪɭɞɨɜɚɧɢɹ ɢ/ɢɥɢ
ɚɤɤɭɦɭɥɹɬɨɪɨɜ ɨɛɪɚɬɢɬɟɫɶ ɜ ɦɟɫɬɧɵɟ ɨɪɝɚɧɵ ɭɩɪɚɜɥɟɧɢɹ, ɦɚɝɚɡɢɧ, ɜ ɤɨɬɨɪɨɦ ɛɵɥ
ɩɪɢɨɛɪɟɬɟɧ ɩɪɨɞɭɤɬ, ɦɥɦ ɫɥɭɠɛɭ ɩɨ ɫɛɨɪɭ ɛɵɬɨɜɵɯ ɨɬɯɨɞɨɜ. ɉɟɪɟɪɚɛɨɬɤɚ
Ⱥɤɤɭɦɭɥɹɬɨɪ
ɦɚɬɟɪɢɚɥɨɜ ɩɨɦɨɠɟɬ ɫɨɯɪɚɧɢɬɶ ɩɪɢɪɨɞɧɵɟ ɪɟɫɭɪɫɵ ɢ ɨɛɟɫɩɟɱɢɬ ɛɟɡɨɩɚɫɧɨɫɬɶ ɞɥɹ
ɡɞɨɪɨɜɶɹ ɥɸɞɟɣ ɢ ɨɤɪɭɠɚɸɳɟɣ ɫɪɟɞɵ.
Recycling information: See http://www.benq.com/support/recycle for details.
Svenska
WEEE-direktiv
Riktlinjer för kassering av avfall som utgörs av eller innehåller elektriska eller
elektroniska produkter och/eller batteri, gällande hushåll i EU.
Den här symbolen kan finnas på produkten eller på förpackningen och betyder att
produkten inte kan kasseras som vanligt hushållsavfall. När du vill kassera produkten
WEEE
och/eller batteri måste du lämna in den på det ställe som avses för återvinning av
elektriska eller elektroniska produkter och/eller batteri. Om du vill ha mer information
om återvinning av den här typen av utrustning och/eller batteri kan du vända dig till din
kommun, ditt inköpsställe eller till den lokala sophämtningen. Genom att återvinna
Batteri
materialet i produkten kan vi spara på naturtillgångarna och försäkra oss om att
produkten återvinns på ett sätt som skyddar människors hälsa och miljön.
Recycling information: See http://www.benq.com/support/recycle for details.
Nederlands
WEEE-richtlijn
Wegwerpen van elektrische en elektronische apparatuur en/of accu's door
huishoudens in de Europese Unie.
Dit symbool geeft aan dat het product niet met het huishoudelijke afval kan worden
aangeboden. U moet afgedankte apparatuur en/of acccu's wegwerpen door ze in te
WEEE
leveren op de inzamelpunten voor elektrische en elektronische apparatuur en/of
accu's. Voor meer informatie over het hergebruik van deze apparatuur en/of de accu
neemt u contact op met uw gemeente, de winkel waar u de apparatuur hebt gekocht of
de milieudienst van de gemeente. Door het recyclen van de materialen worden
Accu
natuurlijke hulpbronnen behouden en helpt u de natuur en de volksgezondheid te
beschermen.
Warranty and Copyright information
113
Recycling information: See http://www.benq.com/support/recycle for details.
Polski
Dyrektywa WEEE
Utylizacja odpadów z urządzeĔ elektrycznych i elektronicznych lub baterii przez
uĪytkowników prywatnych w Unii Europejskiej.
Ten symbol na urządzeniu lub opakowaniu oznacza, Īe nie moĪe byü ono utylizowane
razem z odpadami domowymi. ZuĪyty sprzĊt lub baterie naleĪy przekazaü do
WEEE
odpowiedniego punktu zwrotu sprzĊtu elektrycznego i elektronicznego w celu wtórnego
przetworzenia. Szczegóáowe informacje dotyczące wtórnego przetwarzania tych
urządzeĔ lub baterii moĪna uzyskaü, kontaktując siĊ z lokalną administracją,
sprzedawcą lub lokalnym przedsiĊbiorstwem oczyszczania. Przetwarzanie wtórne
Bateria
materiaáów pomaga w zachowaniu surowców naturalnych i utylizacji w sposób
przyjazny dla ludzkiego zdrowia i Ğrodowiska.
Recycling information: See http://www.benq.com/support/recycle for details.
ýeština
SmČrnice WEEE
Likvidace vyĜazených elektrických a elektronických zaĜízení anebo baterií v
domácnostech uživatelĤ v Evropské unii.
Tento symbol na výrobku nebo na jeho obalu znamená, že dané zaĜízení nelze vyhodit
do bČžného domovního odpadu. VyĜazené elektrické nebo elektronické zaĜízení anebo
WEEE
baterii je nutno zlikvidovat odevzdáním k recyklaci v souladu s platným plánem
recyklace elektrických a elektronických zaĜízení anebo baterií. Další informace o
recyklaci tohoto zaĜízení anebo baterií získáte u místních úĜadĤ, v obchodČ, kde jste
výrobek zakoupili nebo u spoleþnosti, která se zabývá likvidací domovního odpadu.
Baterie
Recyklace materiálĤ pomáháchránit pĜírodní zdroje a zaruþuje likvidaci výrobku
zpĤsobem, kterýješetrný klidskému zdraví a životnímu prostĜedí.
Recycling information: See http://www.benq.com/support/recycle for details.
Türkçe
WEEE direktifi
Avrupa Birli÷i ülkelerinde özel ev eúyası kullanıcıları tarafından Elektrikli ve
Elektronik Cihazların ve/veya Pillerin Atılması.
Ürün yada ambalaj üzerindeki bu sembol, bunun evsel atık olarak iúlem görmemesi
gerekti÷ini ifade etmektedir. Atık cihazınızı ve/veya pilleri, elektrikli ve elektronik
WEEE
cihazların ve/veya pillerin geri dönüúümü için uygulanabilir geri alma úemasına göre ele
alarak atmalısınız. Bu cihazın ve/veya pillerin geri dönüúümü hakkında daha fazla bilgi
edinmek için lütfen cihazı satın aldı÷ınız yerel bayiye veya dükkana yada ev eúyası
uzaklaútırma servisine baúvurun. Materyallerin geri dönüúümü, do÷al kaynakların
Pil
korunmasını ve insan sa÷lı÷ına ve çevreye zarar verilmeksizin geri dönüútürülmesini
güvence etmektedir.
15
114
Warranty and Copyright information
Recycling information: See http://www.benq.com/support/recycle for details.
Português
Directiva REE
Eliminação de Resíduos de Equipamentos Eléctricos e Electrónicos e/ou
Baterias por particulares na União Europeia.
Este símbolo no produto ou na embalagem indica que não pode ser eliminado como
lixo doméstico. Deverá eliminar os resíduos dos seus equipamentos e/ou baterias
WEEE
entregando-os nos pontos de recolha aplicáveis para reciclagem de equipamentos de
equipamentos eléctricos e electrónicos e/ou baterias. Para mais informações sobre a
reciclagem destes equipamentos e/ou baterias, contacte a sua câmara municipal, a
loja onde adquiriu o equipamento ou serviço de recolha de lixo doméstico. A
Bateria
reciclagem de materiais contribuirá para a conservação dos recursos naturais e
assegura que são reciclados de forma a proteger a saúde humana e o ambiente.
Recycling information: See http://www.benq.com/support/recycle for details.
Magyar
WEEE irányelv
Az Európai Unióban a háztartások elektromos és elektronikus hulladékainak
és/vagy az akkumulátorok kezelésérĘl szóló irányelv.
A terméken vagy a csomagoláson ez a szimbólum azt jelzi, azt
aháztartásihulladékoktól külön kell kezelni. A készüléket és/vagy az akkumulátorokat
az elektronikus és elektromos hulladékokra és/vagy az akkumulátorokra érvényes
WEEE
újrahasznosítási rendszer keretein belül kell leadni újrahasznosításra. A készülék
és/vagy akkumulátorok újrahasznosítás céljára való begyĦjtésérĘl bĘvebb információt
kaphat a helyi önkormányzatnál, a vásárlás helyén vagy a háztartási hulladékot
elszállító szolgáltatójánál. Azanyagok újrahasznosításra való begyĦjtése hozzájárul a
Akkumulátor
természeti erĘforrások megĘrzéséhez és biztosítja, hogy a hulladékok szelektálása
azemberi egészséget és a környezetet védĘ módon történjék.
Recycling information: See http://www.benq.com/support/recycle for details.
Warranty and Copyright information
115
Ȼɴɥɝɚɪɫɤɢ
Ⱦɢɪɟɤɬɢɜɚ WEEE
ɂɡɯɜɴɪɥɹɧɟ ɧɚ ɨɬɩɚɞɴɱɧɨ ɟɥɟɤɬɪɢɱɟɫɤɨ ɢ ɟɥɟɤɬɪɨɧɧɨ ɨɛɨɪɭɞɜɚɧɟ ɢ/ɢɥɢ
ɛɚɬɟɪɢɢ ɨɬ ɩɨɬɪɟɛɢɬɟɥɢ ɜ ɱɚɫɬɧɢ ɞɨɦɚɤɢɧɫɬɜɚ ɜ ȿɜɪɨɩɟɣɫɤɢɹ ɫɴɸɡ.
Ɍɨɡɢ ɫɢɦɜɨɥ ɜɴɪɯɭ ɩɪɨɞɭɤɬ ɢɥɢ ɧɟɝɨɜɚɬɚ ɨɩɚɤɨɜɤɚ ɭɤɚɡɜɚ, ɱɟ ɧɟ ɦɨɠɟ ɞɚ ɛɴɞɟ
ɢɡɯɜɴɪɥɹɧ ɡɚɟɞɧɨ ɫ ɨɫɬɚɧɚɥɢɬɟ ɞɨɦɚɤɢɧɫɤɢ ɨɬɩɚɞɴɰɢ. Ɍɪɹɛɜɚ ɞɚ ɢɡɯɜɴɪɥɢɬɟ
ɨɬɩɚɞɴɱɧɨɬɨ ɨɛɨɪɭɞɜɚɧɟ ɢ/ɢɥɢ ɛɚɬɟɪɢɢ, ɤɚɬɨ ɝɨ ɩɪɟɞɚɞɟɬɟ ɜ ɩɨɞɯɨɞɹɳ ɩɭɧɤɬ ɡɚ
WEEE
ɫɴɛɢɪɚɧɟ ɢ ɪɟɰɢɤɥɢɪɚɧɟ ɧɚ ɟɥɟɤɬɪɢɱɟɫɤɨ ɢ ɟɥɟɤɬɪɨɧɧɨ ɨɛɨɪɭɞɜɚɧɟ ɢ/ɢɥɢ
ɛɚɬɟɪɢɢ. Ɂɚ ɩɨɜɟɱɟ ɢɧɮɨɪɦɚɰɢɹ ɨɬɧɨɫɧɨ ɪɟɰɢɤɥɢɪɚɧɟɬɨ ɧɚ ɬɨɡɢ ɭɪɟɞ ɢ/ɢɥɢ
ɛɚɬɟɪɢɢ, ɦɨɥɹ, ɫɜɴɪɠɟɬɟ ɫɟ ɫɴɫ ɫɴɨɬɜɟɬɧɢɹ ɨɮɢɫ ɜɴɜ ȼɚɲɢɹ ɝɪɚɞ, ɫ ɦɚɝɚɡɢɧɚ, ɨɬ
ɤɨɣɬɨ ɫɬɟ ɡɚɤɭɩɢɥɢ ɩɪɨɞɭɤɬɚ ɢɥɢ ɫ ɦɟɫɬɧɚɬɚ ɫɥɭɠɛɚ ɡɚ ɫɴɛɢɪɚɧɟ ɧɚ ɛɢɬɨɜɢ
Ȼɚɬɟɪɢɹ
ɨɬɩɚɞɴɰɢ. Ɋɟɰɢɤɥɢɪɚɧɟɬɨ ɧɚ ɦɚɬɟɪɢɚɥɢɬɟ ɳɟ ɫɩɨɦɨɝɧɟ ɡɚ ɡɚɩɚɡɜɚɧɟ ɧɚ
ɩɪɢɪɨɞɧɢɬɟ ɪɟɫɭɪɫɢ ɢ ɳɟ ɨɫɢɝɭɪɢ ɪɟɰɢɤɥɢɪɚɧɟ ɩɨ ɡɚɩɚɡɜɚɳ ɱɨɜɟɲɤɨɬɨ ɡɞɪɚɜɟ
ɢɨɤɨɥɧɚɬɚ ɫɪɟɞɚ ɧɚɱɢɧ.
Recycling information: See http://www.benq.com/support/recycle for details.
Hrvatski
WEEE direktiva
Odlaganje u otpad elektriþnih i elektroniþkih ureÿaja i/ili baterija iz kuüanstava
u Europskoj uniji.
Ovaj simbol na proizvodu ili pakiranju naznaþuje da se ovaj proizvod ne može odbaciti
s kuünim otpadom. Ureÿaje za otpad i/ili baterije trebate odložiti u otpad u skladu s
WEEE
pravilima povrata, zbrinjavanja i reciklaže elektriþnih i elektroniþkih ureÿaja i/ili baterija.
Više informacija o recikliranju ovog ureÿaja i/ili baeterije, potražite u vašem mjesnom
uredu, u trgovini gdje ste kupili proizvod ili u službi koja prikuplja vaš kuüni otpad.
Recikliranje materijala pomoüi üe oþuvanju prirodnih resursa i osigurati recikliranje na
Baterija
naþin koji štiti ljudsko zdravlje i prirodni okoliš.
Recycling information: See http://www.benq.com/support/recycle for details.
116
Warranty and Copyright information
Română
Directiva WEEE
Evacuarea deúeurilor echipamentelor electrice úi electronice úi/sau bateriilor de
către utilizatorii casnici din Uniunea Europeană.
Acest simbol de pe produs sau de pe ambalaj indică că acest produs nupoate fi
evacuat ca deúeu casnic. Trebuie să evacuaĠi deúeurile de echipamente úi/sau bateria
WEEE
prin predarea conform schemei de preluare pentru reciclare a componentelor electrice
úi electronice úi/sau a bateriilor. Pentru informaĠii suplimentare privind reciclarea
acestui echipament úi/sau a bateriei, contactaĠi primăria oraúului dvs., magazinul de
unde aĠi achiziĠionat echipamentul sau serviciul de salubritate pentru deúeuri menajere.
Baterie
Reciclarea acestor materiale va ajuta la păstrarea resurselor naturale úi asigură că
sunt reciclate într-o modalitate care protejează viaĠa úi mediul oamenilor.
Recycling information: See http://www.benq.com/support/recycle for details.
ǼȜȜȘȞȚțȐ
ȅįȘȖȓĮ WEEE
ǹʌȩȡȡȚȥȘ ȐȤȡȘıIJȠȣ ȘȜİțIJȡȠȜȠȖȚțȠȪ țĮȚ ȘȜİțIJȡȠȞȚțȠȪ İȟȠʌȜȚıȝȠȪ Ȓ/țĮȚ
ȝʌĮIJĮȡȚȫȞ Įʌȩ ȤȡȒıIJİȢ ıİ ȞȠȚțȠțȣȡȚȐ İȞIJȩȢ IJȘȢ ǼȣȡȦʌĮȧțȒȢ DzȞȦıȘȢ.
ȉȠ ʌĮȡȩȞ ıȪȝȕȠȜȠ ıIJȠ ʌȡȠȧȩȞ Ȓ IJȘ ıȣıțİȣĮıȓĮ ȣʌȠįȘȜȫȞİȚ ȩIJȚ ĮȣIJȩ įİȞ ȝʌȠȡİȓ ȞĮ
ĮʌȠȡȡȚijșİȓ ȝİ IJĮ ȠȚțȚĮțȐ ĮʌȠȡȡȓȝȝĮIJĮ. ȆȡȑʌİȚ ȞĮ ijȡȠȞIJȓȗİIJİ ȖȚĮ IJȘȞ ĮʌȩȡȡȚȥȘ IJȠȣ
ȐȤȡȘıIJȠȣ İȟȠʌȜȚıȝȠȪ ıĮȢ Ȓ/țĮȚ ȝʌĮIJĮȡȚȫȞ, ʌĮȡĮįȓįȠȞIJȐȢ IJĮ ıİ ĮȡȝȩįȚȠ ijȠȡȑĮ
WEEE
ʌĮȡĮȜĮȕȒȢ ȝİ ıțȠʌȩ IJȘȞ ĮȞĮțȪțȜȦıȘ ȘȜİțIJȡȠȜȠȖȚțȠȪ țĮȚ ȘȜİțIJȡȠȞȚțȠȪ İȟȠʌȜȚıȝȠȪ
Ȓ/țĮȚ ȝʌĮIJĮȡȚȫȞ. īȚĮ ʌİȡȚııȩIJİȡİȢ ʌȜȘȡȠijȠȡȓİȢ ıȤİIJȚțȐ ȝİ IJȘȞ ĮȞĮțȪțȜȦıȘ IJȠȣ
ʌĮȡȩȞIJȠȢ İȟȠʌȜȚıȝȠȪ Ȓ/țĮȚ ȝʌĮIJĮȡȚȫȞ, ʌĮȡĮțĮȜȠȪȝİ ĮʌİȣșȣȞșİȓIJİ ıIJȠ ĮȡȝȩįȚȠ
ȖȡĮijİȓȠ IJȠȣ įȒȝȠȣ, ıIJȠ țĮIJȐıIJȘȝĮ ȩʌȠȣ ĮȖȠȡȐıĮIJİ IJȠȞ İȟȠʌȜȚıȝȩ Ȓ ıIJȘȞ ȣʌȘȡİıȓĮ
ȂʌĮIJĮȡȓĮ
ĮʌȠțȠȝȚįȒȢ ȠȚțȚĮțȫȞ ĮʌȠȡȡȚȝȝȐIJȦȞ. Ǿ ĮȞĮțȪțȜȦıȘ IJȦȞ ȣȜȚțȫȞ șĮ ȕȠȘșȒıİȚ IJȘȞ
İȟȠȚțȠȞȩȝȘıȘ ijȣıȚțȫȞ ʌȩȡȦȞ țĮȚ șĮ įȚĮıijĮȜȓıİȚ ȩIJȚ ĮȣIJȐ ĮȞĮțȣțȜȫȞȠȞIJĮȚ ȝİ IJȡȩʌȠ
ʌȠȣ ʌȡȠıIJĮIJİȪİȚ IJȘȞ ĮȞșȡȫʌȚȞȘ ȣȖİȓĮ țĮȚ IJȠ ʌİȡȚȕȐȜȜȠȞ.
Recycling information: See http://www.benq.com/support/recycle for details.
G
Warranty and Copyright information
117
For Mexico only (for RF module only)
El manual de usuario contendrʹ las siguientes leyendas o su equivalente en una posiciΆn notoria: ʳ
ϘLa operaciΆn de este equipo estʹ sujeta a las siguientes dos condiciones: ʳ
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y ʳ
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la ʳ
que pueda causar su operaciΆn no deseada. ʳ
G
For Korea:
BClass
B ₆₆ (Ṗ㩫㣿 ⹿㏷䐋㔶₆₆)
㧊 ₆₆⓪ Ṗ㩫㣿(B )㦒⪲ 㩚㧦䕢㩗䞿❇⪳㦚 䞲 ₆₆⪲㍲ 㭒⪲ Ṗ㩫㠦㍲ ㌂㣿䞮⓪
ộ㦚 ⳿㩗㦒⪲ 䞮Ⳇ, ⳾✶ 㰖㡃㠦㍲ ㌂㣿䞶 㑮 㧞㔋┞┺.
G
䚐ạ㜄G 䚨␭G OymG ⯜◼㢨G 䔠䚜═G 㥐䖼㢌G ᷱ㟤PG
ʳ
ᣣᧄኾ↪ߢߔ
‫ٵ‬ධ圡圩ሽᄭ坴垹垊坼垄垉圹‫ء‬ᖲ‫א‬؆圸ሽ䲱ᖲᕴ圱ࠌ‫ش‬圱圗坈圥坝
8%%+
%.#55$
ߎߩⵝ⟎ߪ‫ࠬ࡜ࠢޔ‬㧮ᖱႎᛛⴚⵝ⟎ߢߔ‫ޔߪ⟎ⵝߩߎޕ‬ኅᐸⅣႺߢ૶↪ߔࠆߎߣࠍ⋡⊛ߣߒߡ޿߹
ߔ߇‫ࡦ࡚ࠫࡆ࡟࠹߿ࠝࠫ࡜߇⟎ⵝߩߎޔ‬ฃାᯏߦㄭធߒߡ૶↪ߐࠇࠆߣ‫ޔ‬ฃା㓚ኂࠍᒁ߈⿠ߎߔߎ
ߣ߇޽ࠅ߹ߔ‫ޕ‬
ขᛒ⺑᣿ᦠߦᓥߞߡᱜߒ޿ขࠅᛒ޿ࠍߒߡߊߛߐ޿‫ޕ‬
4(ࡕࠫࡘ࡯࡞ઃ߈ߩ⵾ຠߩ႐ว
118
Warranty and Copyright information
ႛᔞ‫؀࣍ش‬᨜‫چ‬೴ (ૉข঴‫ڶ‬WLAN/BT module)
㜓䔉⒨ⅎ␒䄈䷁㨈䴫˛勌婙䄈䷁㨈䴫㔖㏛5GHz 栢⸝, 5.15GHz~5.25GHz昷㖣⮋ⅎὦ䔏˛
ᾄḌ⅝䉅方㮠巹⫂⻥方㤝䩟䋄幤㮓奨㰩
䬓 12 㢄䵺❲⻶婴嬰⏯㠣Ḳἵ⊆䍮⯫栢曢㩆Ə杅䵺娘⏖Ə⅓⏟˚┭噆ㇽὦ䔏俬✮ᷴ⽾㒬凑孱㛛栢䍮˚⊇⤎⊆䍮ㇽ
孱㛛⎆娔姯Ḳ䉠『⎱⊆僤˛
䬓 14 㢄ἵ⊆䍮⯫栢曢㩆Ḳὦ䔏ᷴ⽾⽘柦棂刑⭰⅏⎱⹙㓥⏯㲼态Ὲƞ䵺䙣䏥㛰⹙㓥䏥屈㘩Əㆰ䪲⍚⁃䔏Əḍ㔠╫
凚䄈⹙㓥㘩㖠⽾乣乳ὦ䔏˛
∴柬⏯㲼态ῈƏ㋮ᾄ曢Ὲ㲼奶⮁ὃ㥔Ḳ䄈䷁曢态Ὲ˛
ἵ⊆䍮⯫栢曢㩆柯⾴⎾⏯㲼态Ὲㇽⷌ㥔˚䦸⭟⎱憒䘩䔏曢㳉弢⯫『曢㩆娔₀Ḳ⹙㓥˛
ḽ䏦方㬞䕂㮦⿍ᵉ曃 (䐴䏠⍿攂㗇弗㉥┦㔀)
曢㱇䙫ὦ䔏㖠⻶ㇽ❲噆⥩㞃挖媋Ə⏖僤㛪⯵凛⋽⭟䉐峑䙫㴐㻶ㇽ䇭䂟˛ 媲㳏ヶᷲ⇾Ṳ柬Ɲ
z
z
⭰壄曢㱇㘩Ə媲䢡婴曢㱇䙫㭊岇㥜ⷙᾄ䅎曢㱇⮋Ḕ㈧㨀䤡䙫㖠⏸㭊䢡⭰壄˛
ᷴ⏳⒨䈳凮桅❲䙫曢㱇(ὲ⥩䢚抬曢㱇凮湣『曢㱇)⅞㛰ᷴ⏳䙫䉠『˛ 媲⋦㷞⏯ὦ䔏ᷴ⏳⒨䈳凮桅❲䙫曢
㱇˛
z
䕝曢㱇曢憶䔏䛈㘩Ə媲⃿怆㛛㏂㖗曢㱇˛㏂㖗曢㱇㘩Ə媲⯮⅏惏曢㱇ᷧ㬈㏂㖗˛
z
敞㘩敺ᷴὦ䔏恀㎎♏㘩Ə媲⯮曢㱇⾅恀㎎♏Ḕ⎽⇡˛
z
媲⋦⯮㖗䙫⑳凱䙫曢㱇㷞⏯ὦ䔏˛ ⯮㖗曢㱇凮凱曢㱇㷞⏯ὦ䔏㛪㸂䟔曢㱇䙫ὦ䔏⣤⑤Əㇽ⯵凛⋽⭟㶙⾅ᷴ
剖䙫曢㱇Ḕ㴐㻶⇡Ὥ˛
z
曢㱇Ḕ㴐㻶⇡Ὥ䙫⋽⭟㶙⏖僤㛪∡㾧䚕冁ḍ儷圼憸ⱓ㎌滅˛ ‫‮‬ὦ㛰ỢἼ⋽⭟䉐峑⾅曢㱇Ḕ㻙㻶⇡ὭƏ媲䪲
⍚Ọṥⷪ㓍㋔ṥ㷏ḍ㛛㏂曢㱇˛
z
俾䛈䙫曢㱇媲ᾄ䅎䛟旃Ḳ恐䔏奶䫇⛅㔝ㇽḆ㢫˛婚䴗岮姱Ə媲偖乒䕝✗⻉㖀䮈䏭㩆旃˛
⏗䁊⻉曢㱇⛅㔝㨀婳
Warranty and Copyright information
119
䏳㬞⩇…㮦⿍ᵉ朷 (⸑ᵥ⍿攂㗇弣㉥┦㒴)
ὦ䔏攀寖䱢❲䙫䔜㱇⏖僤⯣凛⋽⭍䉐崏㲫㻶ㇽ䇭䂟˛寞恜⾑ᷲ⇾Ṳ桠Ɲ
z
⊈⾬㋰䅎䔜㱇ẺⅬ䙫㭊㝨⑳崆㝨㟮宗Ọ㭊䡕㖠⏸墬⅌䔜㱇˛
z
ᷴ⏳䱢❲䙫䔜㱇⅞㛰ᷴ⏳䙫䉠『˛寞⋦㷞䔏ᷴ⏳䱢❲䙫䔜㱇˛
z
寞⋦㷞䔏㖗㗎䔜㱇˛㷞䔏㖗㗎䔜㱇ἁ伐䟔䔜㱇ὦ䔏㗝旛ㇽ⯣凛㗎䔜㱇⋽⭍䉐崏㲫㻶˛
z
䔜㱇ᷴ僤㭊⸟ⷌὃ㗝Ə⹻䪲⍚㛛㍉⭪ồ˛
z
䔜㱇㲫㻶䙫⋽⭍䉐崏⏖僤∡䗂䚕傋˛⥩㞃䔜㱇㲫㻶⇡ỢἼ⋽⭍䉐崏Ə⹻䪲⍚䔏⹙ⷪ㓍㋔⹙↧Ə⹝Ⱔ⿒㛛㍉
䔜㱇˛
120
z
䔘ṵ⬿㔥㝈ờᷴ⏳Ə䔜妭晶昫䙫䔜㱇䙫ὦ䔏㗝旛⏖僤伐䟔˛✏3ḑ㛯Ⅼㇽ✏∄㬈ὦ䔏⏵Ⱔ⿒㛛㍉⭪ồ˛
z
俾Ⱔ䙫䔜㱇寞ᾄ䅎䛟⅚Ḳ忩䔏妫䫇⛅㔝ㇽḉ⻪˛寍亭ῈざƏ寞倻䳢⼺✗⺆㖀䮈䏭㜡⅚
Warranty and Copyright information
Ё೑RoHS
∬㗽₼⦌㟎ㄫ朗⺈ᇵ䟄⷟≰㋾ℶ❐㻰㩢㘶Ⓟ丰䚕┭㽤ᇶ⃉㘶Ⓟ✛⑞⺠䟄⷟≰㋾ℶ❐ㄮ㆒⚝⺈䘾⬒抯㒟䤓㻰㩢᧨
≒扪䞮ℶ✛枏➽⇝㻰㩢䟄⷟≰㋾ℶ❐᧨≬㔳䘾⬒✛ⅉ⇢⋴ㅆ᧨⅔㙟∪㦘␂㦻ℶ❐♾厌⚺㦘㦘㹡♙㦘⹂䓸德Ⱁ⚝᧶
㦘㹡㦘⹂䓸德㒥⏒侯
榅捷ↅ⚜䱿
杔᧤Pb᧥ 㻭᧤Hg᧥ 柘᧤Cd᧥
⏼ↆ杻
⮩䅃勣啾 ⮩䅃ℛ啾搩
᧤Cr6+᧥
᧤PBBs᧥ ᧤PBDEs᧥
⫠㠨⮥㫕
O
O
O
O
O
८㺉᫕Ე
X
O
O
O
O
O
O
䋾䄟
O
X
O
O
O
O
䟄䄟⪉㨎
X
O
O
O
O
O
⃊⪉㨎
X
O
O
O
O
O
㖘枽⪉㨎
X
O
O
O
O
O
柫⯃
X
O
O
O
O
O
歝㓖ʳ
X
O
O
O
O
O
䟄䄟兎
X
O
O
O
O
O
␅Ⅵ兎㧟
X
O
O
O
O
O
䟄㻯
O
O
O
O
O
O
㡯兎抑揜◰
O
O
O
O
O
O
O: 嫷䯉年㦘⹂䓸德⦷年捷ↅ㓏㦘⧖德㧟㠨₼䤓⚺摞⧖⦷ᇵ䟄⷟≰㋾ℶ❐₼㦘㹡㦘⹂䓸德䤓棟摞
尐㻑㪖⑕ᇶ屓⸩䤓棟摞尐㻑ⅴₚᇭ
X: 嫷䯉年㦘⹂䓸德咂⺠⦷年捷ↅ䤓㩟₏⧖德㧟㠨₼䤓⚺摞怔⒉ᇵ䟄⷟≰㋾ℶ❐₼㦘㹡㦘⹂䓸德
䤓棟摞尐㻑㪖⑕ᇶ屓⸩䤓棟摞尐㻑᧷⇕㢾ₙ嫷₼㓢“×”䤓捷ↅ᧨␅⚺摞怔⒉㢾⥯⃉䥽ⓜ₩䟛执㼰
㦘㒟䐮䤓♾㦎ⅲ䤓㔏㦾ᇭ
㦘␂₼⦌ᇵ䟄⷟≰㋾ℶ❐㻰㩢㘶Ⓟ丰䚕┭㽤ᇶ⃚䦇␂屓⸩庆♑劒≰㋾ℶ₩捷㓏⏻を⃚≰㋾ᇭ
WEEE ਐ‫( ח‬䩜ᇍЁ೑ഄऎ)
<䬙㥯䶣ᕴ䶣՗䣈঴‫گڃ‬㢊෻ጥ෻㦕ࠏ>ࢨ<China WEEE>
䣈঴䬙㥯㦍冉ٌ伲㣞‫ڶچ‬凹凝ऱ‫گڃ‬㧧‫ۯ‬㢊෻Ζ
<䬙䶣‫>ۃ‬
‫ء‬䣈঴ܶ‫ڶ‬䶣‫ۃ‬Δ䬙㥯㦍冉ٌ伲㣞‫ڶچ‬凹凝ऱ‫گڃ‬㧧‫ۯ‬㢊෻Ζ
22
Warranty and Copyright information
121
UAE
SINGAPORE
122
Warranty and Copyright information
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
