Access line, 16 MHz STM8S 8-bit MCU, up to 8 Kbytes Flash, data

Access line, 16 MHz STM8S 8-bit MCU, up to 8 Kbytes Flash, data

STM8S103K3

STM8S103F3 STM8S103F2

Access line, 16 MHz STM8S 8-bit MCU, up to 8 Kbytes Flash, data EEPROM,10-bit ADC, 3 timers, UART, SPI, I²C

Features

Core

16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline

Extended instruction set

Memories

Program memory: 8 Kbytes Flash; data retention 20 years at 55 °C after 10 kcycles

Data memory: 640 bytes true data EEPROM; endurance 300 kcycles

RAM: 1 Kbytes

Clock, reset and supply management

2.95 to 5.5 V operating voltage

Flexible clock control, 4 master clock sources:

– Low power crystal resonator oscillator

– External clock input

– Internal, user-trimmable 16 MHz RC

– Internal low power 128 kHz RC

Clock security system with clock monitor

Power management:

– Low power modes (wait, active-halt, halt)

– Switch-off peripheral clocks individually

Permanently active, low consumption poweron and power-down reset

Interrupt management

Nested interrupt controller with 32 interrupts

Up to 27 external interrupts on 6 vectors

Timers

Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization

LQFP32 7x7 VFQFPN32 5x5

TSSOP20 UFQFPN20 3 x 3

16-bit general purpose timer, with 3 CAPCOM channels (IC, OC or PWM)

8-bit basic timer with 8-bit prescaler

Auto wake-up timer

2 watchdog timers: Window watchdog and independent watchdog

Communications interfaces

UART with clock output for synchronous operation, Smartcard, IrDA, LIN master mode

SPI interface up to 8 Mbit/s

I

2

C interface up to 400 Kbit/s

Analog to digital converter (ADC)

10-bit,

±

1 LSB ADC with up to 5 multiplexed channels, scan mode and analog watchdog

I/Os

Up to 28 I/Os on a 32-pin package including 21 high sink outputs

Highly robust I/O design, immune against current injection

Development support

– Embedded single wire interface module

(SWIM) for fast on-chip programming and non intrusive debugging

Unique ID

96-bit unique key for each device

June 2009 15441 Rev 3

www.st.com

1/95

1

3

4

1
