hp psc 1310 series all-in-one user guide

hp psc 1310 series all-in-one

© Copyright 2004 Hewlett-Packard

Development Company, L.P.

The information contained herein is subject to change without notice.

Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws.

Adobe and the Acrobat logo are either registered trademarks or trademarks of Adobe

Systems Incorporated in the United States and/or other countries.

Portions Copyright © 1989-2003

Palomar Software Inc. The HP PSC

1310 Series includes printer driver technology licensed from Palomar

Software, Inc. www.palomar.com

Copyright © 1999-2003 Apple

Computer, Inc.

Apple, the Apple logo, Mac, Mac logo, Macintosh, and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

Publication number: Q5763-90152

First edition: February 2004

Windows

®

, Windows NT

®

, Windows

ME

®

, Windows XP

®

, and Windows

2000

®

are U.S.-registered trademarks of Microsoft Corporation.

Intel

®

and Pentium

®

are registered trademarks of Intel Corporation.

notice

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

The Hewlett-Packard Company shall not be liable for incidental or consequential damages in connection with, or arising out of the furnishing, performance, or use of this document and the program material which it describes.

Note: Regulatory information can be found in this User Guide.

It is not lawful in many places to make copies of the following items. When in doubt, check with a legal representative first.

• Governmental paper or documents:

- Passports

- Immigration papers

- Selective service papers

- Identification badges, cards, or insignias

• Governmental stamps:

- Postage stamps

- Food stamps

• Checks or drafts drawn on

Governmental agencies

• Paper currency, traveler’s checks, or money orders

• Certificates of deposit

• Copyrighted works

safety information

Warning!

To prevent fire or shock hazard, do not expose this product to rain or any type of moisture.

Always follow basic safety precautions when using this product to reduce risk of injury from fire or electric shock.

Warning!

Potential shock hazard

1 Read and understand all instructions in the Setup Poster.

2 Use only a grounded electrical outlet when connecting the device to a power source. If you do not know whether the outlet is grounded, check with a qualified electrician.

3 Observe all warnings and instructions marked on the product.

4 Unplug this product from wall outlets before cleaning.

5 Do not install or use this product near water or when you are wet.

6 Install the product securely on a stable surface.

7 Install the product in a protected location where no one can step on or trip over the line cord, and where the line cord will not be damaged.

8 If the product does not operate normally, see the online

Troubleshooting help.

9 No operator-serviceable parts inside. Refer servicing to qualified service personnel.

10 Use in a well-ventilated area.

contents

1 quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

front panel overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

PictBridge camera port overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 front panel status lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

use your hp psc with a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 load originals and load paper . . . . . . . . . . . . . . . . . . . . . . . . . . 11

load originals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

load an original photo on the glass . . . . . . . . . . . . . . . . . . . . . . . . . 12 load letter or A4 paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

load envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 load postcards, Hagaki cards, or 4 by 6 inch (10 by 15 cm) photo paper 14

recommended papers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 load other types of paper in the paper tray . . . . . . . . . . . . . . . . . . . . 15 set the paper type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

avoid jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3 print from a camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

connect a camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 print photos from your camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4 use the copy features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

make copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

perform special copy jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

stop copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5 use the scan features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

scan an original . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

stop scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6 order supplies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

order media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 order print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 order other supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

7 maintain your hp psc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

clean the glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 clean the lid backing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

clean the exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 work with print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

self-maintenance sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

8 get hp psc 1310 series support . . . . . . . . . . . . . . . . . . . . . . . . . 37

get support and other information from the Internet . . . . . . . . . . . . . . 37 hp customer support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

v

contents

prepare your hp psc for shipment . . . . . . . . . . . . . . . . . . . . . . . . . . .41

hp distribution center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

9 warranty information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

duration of limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

warranty service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

warranty upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

returning your hp psc for service . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

hewlett-packard limited global warranty statement . . . . . . . . . . . . . . . .46

10 technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

paper specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

environmental product stewardship program . . . . . . . . . . . . . . . . . . . .50

regulatory notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

11 hp instant share setup and use . . . . . . . . . . . . . . . . . . . . . . . . . . 55

use hp instant share in five easy steps (Windows) . . . . . . . . . . . . . . . .55

send a photo or image using your hp psc (Macintosh) . . . . . . . . . . . . .57

why should I register with hp instant share (Windows)? . . . . . . . . . . . .58

12 troubleshooting information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

installation troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

operational troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

vi hp psc 1310 series

get help

This User Guide contains information on using your HP psc and provides additional troubleshooting assistance for the installation process. The User Guide also contains information on how to order supplies and accessories, technical specifications, support, and warranty information.

The table below lists additional sources of information for your HP psc.

help description

Setup Guide The Setup Poster provides instructions for setting up and configuring your

HP psc. Make sure you use the correct setup information for your operating system (Windows or Macintosh).

HP Image Zone Help The HP Image Zone Help provides detailed information on using the software for your HP psc.

For Windows users

: Go to the

HP Director

, and click

Help

.

For Macintosh users

: Go to the

HP Director

, and click

Help

, then click

hp image zone help

.

User Guide The User Guide you have in your hands contains information on using your HP psc and provides additional troubleshooting assistance for the installation process. The User Guide also contains information on how to order supplies and accessories, technical specifications, support, and warranty information.

Troubleshooting help To access troubleshooting information:

For Windows users

: In the

HP Director

, click

Help

. Open the

Troubleshooting book in the HP Image Zone Help, then follow the links to general troubleshooting as well as links to Troubleshooting help that is specific to your HP psc. Troubleshooting is also available from the

Help

button that appears on some error messages.

For Macintosh users

: Open the Apple Help Viewer, click

hp image zone help

, then click

hp psc 1310 series

.

There is also a Troubleshooting chapter available in this User Guide.

Internet help and technical support

If you have Internet access, you can get more information from the

HP website at:

www.hp.com/support

The website also provides answers to frequently asked questions.

Readme file After you install your software, you can access the Readme file (if any) from either the HP PSC 1310 Series CD-ROM or the HP PSC

1310 Series program folder. A Readme file contains late-breaking information that does not appear in the User Guide or the online help.

vii

help

Dialog-box help

(Windows only)

description

For Windows

: Use one of the following ways to find information on a specific feature:

Right-click on the feature

Select the feature and press

F1

Select the

?

in the upper-right corner then click on the feature viii hp psc 1310 series

1

quick start

Your HP psc can be used for making copies and printing photos from a

PictBridge-compliant camera without turning on your computer. You can do more with your HP psc by using the HP Director software that you installed on your computer during the initial setup. The HP Director includes troubleshooting tips, product-specific help, and enhanced copy, scan, and photo functionality. For more information on the use of the

HP Director, see

use your hp psc with a computer

on page 6.

This section contains the following topics:

front panel overview

on page 1

PictBridge camera port overview

on page 3

front panel status lights

on page 3

use your hp psc with a computer

on page 6

front panel overview

Use the graphic and table below to become familiar with the front panel features of your HP psc.

Note:

The front panel cover must be attached to the HP psc by removing the adhesive backing and placing the cover in the appropriate location. The

HP psc will not operate unless the front panel cover is attached properly. If your HP psc is not operating properly, refer to the setup instructions for information about attaching the front panel cover.

1

chapter 1

6

7

8

9

10

1

3

4

5

2

feature

1

2

3

8

9

10

6

7

4

5

purpose

On/Resume

: turns the HP psc on and off. Also, resumes a copy or print job after a jam or other error. If the HP psc is in an error state, you can turn it off by pressing On/Resume for 3 seconds.

Warning!

When the HP psc is off, a minimal amount of power is still supplied to the device. Unplug the power cord to completely disconnect the power supply to the HP psc.

Check Paper

: lights up to indicate the need to load paper or remove a paper jam.

Check Print Cartridge

: lights up to indicate the need to reinsert or replace the print cartridge or close the print carriage access door.

Cancel

: stops a job or exits button settings.

Copies (1-9)

: changes the number of copies for a copy job.

Size

: changes the copy image size to either 100% or Fit to Page.

Paper Type

: changes the paper type to Plain or Photo.

Start Copy

,

Black

: starts a black-and-white copy.

Start Copy

,

Color

: starts a color copy.

Scan

: starts a scan of an original from the glass.

2 hp psc 1310 series

quick start

PictBridge camera port overview

Your HP PSC supports the PictBridge standard. The PictBridge port allows you to connect any PictBridge-compliant camera to the HP PSC with a USB cable and print your photos without using the computer.

Note:

Do not use this port to connect your HP PSC to your computer. Also, do not connect any other USB device, such as a mouse, keyboard, or photo card reader to this port.

For more information on printing from your PictBridge camera, see

print from a camera

on page 17.

front panel status lights

Status lights on the front panel provide information about tasks that your HP psc is currently performing or about maintenance tasks that you need to perform on the device. For example, you can tell if the device is on or off, if it is processing a black-and-white or color copy, if it is out of paper, or if there is a paper jam.

All status lights on the front panel are reset to the default display after two minutes unless there is an error.

Review the graphic and the table on the next page to become familiar with the front-panel status lights that provide information about tasks that your HP PSC is currently performing.

black copy area color copy area

on light

(green)

Light is off.

Light is on.

black copy area

(backlight) color copy area

(backlight) explanation what to do?

Light is off. Light is off.

Your HP PSC is turned off. Press the On/Resume button to turn your

HP PSC on.

Light is on. Light is on.

Your HP PSC is turned on and is ready for use.

Begin a scan, copy, or print job from the front panel or from the software.

user guide 3

chapter 1

on light

(green) black copy area

(backlight) color copy area

(backlight) explanation what to do?

Light is blinking.

Light is blinking.

Light is blinking.

Blinks faster for 3 seconds and then stays illuminated.

Light is on. Light is on.

Your HP PSC is processing a print, scan, or maintenance job.

Wait for your HP PSC to finish processing the job.

Light is blinking.

Light is on.

Your HP PSC is processing a black-and-white copy job.

Wait for your HP PSC to finish processing the job.

Light is on. Light is

Light is on or blinking.

blinking.

Light is on or blinking.

Your HP PSC is processing a color copy job.

Wait for your HP PSC to finish processing the job.

Your HP PSC is busy doing another task.

Wait for the current job to be completed before starting another job.

In addition to providing information about current tasks, the lights on the front panel can also indicate error conditions.

Review the graphic and the table below to become familiar with the front-panel status lights that provide information about error conditions that your HP PSC is currently experiencing.

On/Resume

Check Paper

Check Print Cartridge

Cancel

If the On light, Check Print Cartridge light, Check Paper light, and Start Copy,

Black and Start Copy, Color lights are all flashing, do the following:

1

Verify that the front-panel overlay is attached to the HP PSC.

2

Turn your HP PSC off and on by disconnecting the power cord and reconnecting.

on light

(green) check paper light check print cartridge light explanation

Rapid blinking for

20 seconds.

Light is off. Light is off. The HP psc is trying to scan and there is a communication problem.

what to do?

Verify that your computer is on and is connected to the

HP psc. Verify that the

HP psc software is installed.

4 hp psc 1310 series

quick start

on light

(green) check paper light check print cartridge light explanation what to do?

Light is on. Light is blinking.

Light is off. The paper tray is empty, the HP psc has a paper jam, or the paper size setting and paper in paper tray are not the same.

Load paper, or remove the paper jam.

Change paper in paper tray to correct size.

Change paper size on the computer software.

Then press On/ Resume to continue.

Light is on. Light is off. Light is blinking.

Print cartridge access door might be open.

Print cartridges might be missing or not installed properly.

Tape might not have been removed from the print cartridges.

There might be a problem with the print cartridge.

1

2

3

Remove the print cartridges and make sure the tape has been removed.

Re-insert the print cartridges and make sure they are properly seated.

Close the access door.

If the light continues to blink, one of the print cartridges is defective. Do the following:

1

Remove the black (or photo) print cartridge.

2

Close the access door.

If the light blinks, the tri-color print cartridge is defective and must be replaced. If the light does not blink, the black

(or photo cartridge) is defective.

For more information on this condition, click the HP psc status icon in the system tray on your computer (Windows only).

Light is on. Light is blinking.

Light is blinking.

The print carriage is stalled.

Open the print carriage access door and make sure the carriage is not obstructed.

user guide 5

chapter 1

on light

(green)

Light is blinking.

check paper light

Light is blinking.

check print cartridge light explanation

Light is blinking.

what to do?

An error caused the

HP psc to stop functioning.

1

Turn the HP psc off and then on.

2

Restart your computer.

3

If the problem is not corrected, unplug the

HP psc and plug it in again.

If the problem persists, contact HP.

use your hp psc with a computer

If you installed the HP psc software on your computer according to the Setup

Poster, you can access all the features of the HP psc using the HP Director.

This section contains the following topics:

open the hp director for Windows users

on page 6

open the hp director for Macintosh users

on page 8

open the hp director for Windows users

1

Do one of the following to open the HP Director:

Double-click the

HP Director

icon on the desktop.

In the Windows taskbar, click

Start

, point to

Programs

or

All Programs

(XP)

, point to

HP

, then select

HP Director

.

2

In the

Select Device

box, click to see a list of installed HP devices supported by this software.

3

Select

HP PSC 1310 Series

.

Note:

The HP Director graphic below might appear differently on your computer. The HP Director is customized based on the HP device that is selected. If your device is not equipped with a particular feature (such as fax capability), then the icon for that feature will not display in the HP Director on your computer. Some HP devices might show additional buttons that are not shown below.

Tip:

If the HP Director on your computer does not contain any icons, an error might have occurred during the software installation. To correct this, use the Control Panel in Windows to completely uninstall the HP Director software, and then reinstall the

HP Director.

6 hp psc 1310 series

1

2 3 4 quick start

12 user guide

5 6 7 8 9 10 11

feature purpose

1

2

3

4

5

6

7

8

9

10

11

12

Status

: select this feature to display the current status of your HP psc.

Settings

: select this feature to view or change various settings for your

HP psc, such as print, scan, or copy.

Help

: select this feature to access the HP Image Zone Help, which provides software help, a product tour, troubleshooting information for your HP psc, and HP psc product-specific help.

Select Device

: use this feature to select the device you want to use from the list of installed HP devices.

Scan Picture

: use this feature to scan an image and display it in the

HP Image Zone.

Scan Document

: use this feature to scan text and display it in the selected text editing software program.

Make Copies

: use this feature to display the

Copy

dialog box where you can select the copy quality, number of copies, color, size, and then start a copy.

HP Image Zone

: use this feature to display the HP Image Zone, where you can view and edit images, print photos in multiple sizes, make and print a photo album, share images through e-mail or a website, or make a multimedia CD.

Creative Ideas

: use this feature to learn about creative ways to use your HP psc.

HP Shopping

: use this feature to shop for HP products.

Software Update

: use this feature to check for software updates for your HP psc.

Click this

arrow

to display tool tips that explain each of the

HP Director options.

7

chapter 1

open the hp director for

Macintosh users

Use one of the following methods to launch or access the HP Director, depending on which Macintosh OS you are using.

open the hp director (all-in-one) using Macintosh OS X

If you are using Macintosh OS X, the HP Director (All-in-One) is launched automatically during the HP Image Zone software installation, and causes the

HP Director (All-in-One) icon to be created in the Dock for your device. Access the device capabilities via the HP Director menu that is associated with the

HP Director (All-in-One) icon.

Tip:

If you do not want the HP Director to launch automatically each time you start your Macintosh, you can change this setting in the HP Director Settings menu.

To display the HP Director menu:

!

In the Dock, click the HP Director (All-in-One) icon for your device.

The HP Director menu appears as shown below. Refer to the legend for a brief description of the HP Director features.

Note:

If you install more than one HP device, an HP Director icon for each device is appears in the Dock. For example, if you have an HP scanner and an HP psc installed, two HP Director icons are present in the Dock, one for the scanner, and one for the HP psc. However, if you installed two of the same kind of device (for example, two HP psc devices) only one HP Director icon is displayed in the Dock to represent all devices of that kind.

8

1

2

3

4

5

6

7

8

feature purpose

1

2

3

Scan Picture

: use this feature to scan an image and display it in the HP Gallery.

Scan document

: use this feature to scan text and display it in the selected destination text editing software program.

Make Copies

: use this feature to make a copy in black and white or color.

hp psc 1310 series

quick start

6

7

feature purpose

4

5

8

HP Gallery

: use this feature to display the HP Gallery to view and edit images.

More Applications

: use this feature to select other applications on your computer.

HP on the Web

: use this feature to select an HP website.

HP Help

: use this feature to select a source for help with your

HP psc.

Settings

: use this feature to change device settings.

open the hp director using Macintosh OS 9

In Macintosh OS 9, the HP Director is launched automatically during the

HP Image Zone software installation, and the HP Director appears as an alias on the desktop. Use one of the following methods to launch the HP Director.

!

Double-click the

HP Director

alias on the desktop.

!

Double-click

HP Director

in the Applications:Hewlett-Packard:HP Image

Zone Software:HP Director folder.

The HP Director displays only the icons that pertain to the selected device. For more information, see the onscreen hp image zone help that came with your software.

The following figure shows some of the features available through the HP Director for Macintosh OS 9. Consult the legend for a brief explanation of specific features.

Note:

The HP Director graphic below might appear differently on your computer. The HP Director is customized based on the HP device that is selected. If your device is not equipped with a particular feature (such as fax capability), then the icon for that feature will not display in the HP Director on your computer. Some HP devices might show additional buttons that are not shown below.

user guide

1 2 3 4 5

6

feature purpose

1

Scan Picture

: use this feature to scan an image and display it in the HP Gallery.

9

chapter 1

feature purpose

2

3

4

5

6

Select Device

: use this pull-down list to select the HP device you want to use.

Scan document

: use this feature to scan text and display it in the selected destination text editing software program.

Make Copies

: use this feature to make a copy in black and white or color.

HP Gallery

: use this feature to display the HP Gallery to view and edit images.

Settings

: use this pull-down list to provide access to device settings.

10 hp psc 1310 series

2

load originals and load paper

You can copy and scan originals loaded on the glass. You can also print and copy onto a variety of paper types and paper sizes. It is important that you choose the right paper and make sure that it is loaded correctly and not damaged.

This section contains the following topics:

load originals

on page 11

load an original photo on the glass

on page 12

load letter or A4 paper

on page 12

load envelopes

on page 14

load postcards, Hagaki cards, or 4 by 6 inch (10 by 15 cm) photo paper

on page 14

recommended papers

on page 15

load other types of paper in the paper tray

on page 15

set the paper type

on page 15

avoid jams

on page 16

load originals

Review the procedure below for loading originals on the glass of your HP psc.

Note:

Some copy options, such as Fit to Page, will not work correctly if the glass and lid backing are not clean. For more information, see

clean the glass

and

clean the lid backing

on page 31.

1

To load an original, lift the lid and place the original face down on the left front corner of the glass with the sides of the original touching the left and bottom edges.

lid

Top edge of original

2

Close the lid.

For information on making a copy, see

make copies

on page 19. For more

information on scanning a document, see

scan an original

on page 23.

11

chapter 2

load an original photo on the glass

You can make a copy of an original photo from the glass of your HP psc. It is important that you load the original photo on the glass properly to get the best possible copy.

1

Load your original photo face down on the left front corner of the glass.

Position the photo on the glass so the long edge of the photo is along the front edge of the glass.

2

Close the lid.

For more information on special copy jobs, or making borderless copies of photos, see

perform special copy jobs

on page 20.

load letter or A4 paper

The following describes the basic procedure for loading letter or A4 paper into the HP psc. For best results, adjust the paper settings each time you change

paper types or paper sizes. For more information, see

set the paper type

on page 15, and

avoid jams

on page 16.

Note:

There are specific considerations for loading certain types of paper, postcards, and envelopes. After you review the procedure for loading letter

and A4 paper, see

load envelopes

on page 14, and

load postcards,

Hagaki cards, or 4 by 6 inch (10 by 15 cm) photo paper

on page 14, and

load other types of paper in the paper tray

on page 15.

1

Lower the paper tray, and if necessary, slide the paper-width guide to the outermost position.

2

Fold out the paper-tray extender to catch paper as it exits the device.

Tip:

For best results when loading legal-size paper, fold in the paper-tray extender before loading the paper to avoid a paper jam.

12 hp psc 1310 series

user guide load originals and load paper

3

Tap the stack on a flat surface to align the edges of the paper, and then check the paper for the following:

Make sure it is free of rips, dust, wrinkles, and curled or bent edges.

Make sure all the paper in the stack is the same size and type.

4

Insert paper into the paper tray with the print side down until it stops. To avoid bending the paper, make sure you do not push the paper in too far, or push too hard. If you are using letterhead, insert the top of the page first.

Do not use too much paper. Check that the stack of paper contains several sheets but is no higher than the top of the paper-width guide.

Note:

Forcing the paper too far into the HP psc might cause multiple sheets of paper to be fed through the print mechanism, or cause a paper jam.

5

Slide the paper-width guide in until it stops at the edge of the paper. Make sure that the paper stack lies flat in the paper tray and fits under the tab of the paper-width guide.

13

chapter 2

load envelopes

Use the print feature of your word processing software to print to envelopes with your HP PSC. Use envelopes for printing only; copying on to an envelope is not recommended. Do not use shiny or embossed envelopes, or envelopes that have clasps or windows. You can load the paper tray with one or multiple envelopes.

Note:

Consult the help files in your word processing software for details on how to format text for printing on envelopes.

1

Remove all paper from the paper tray.

2

Slide an envelope into the tray, with the envelope flap up and to the left

(print side down), until it stops. Do not force the envelope in too far.

3

Adjust the paper-width guide against the envelope.

Be careful not to bend the envelope.

Do not overload the paper tray when loading multiple envelopes. Make sure the stack of envelopes is no higher than the top of the paper-width guide.

load postcards, Hagaki cards, or 4 by 6 inch (10 by 15 cm) photo paper

The following is the procedure for loading postcards, Hagaki cards, or 4 by 6 inch (10 by 15 cm) photo paper.

1

Remove all paper from the paper tray, and then slide a stack of cards into the tray until it stops. Insert the short edge of the card into the HP psc first.

Make sure the print side faces down.

Note:

If you are using photo paper with perforated tabs, load the photo paper so that the tabs face out towards you.

14

2

Adjust the paper-width guide against the cards until it stops.

Make sure the cards fit within the tray. Do not overload it. The stack should be no higher than the top of the paper-width guide.

hp psc 1310 series

load originals and load paper

recommended papers

For the best print quality, use HP papers. Paper that is too thin, paper that has a slick texture, or paper that stretches easily can cause paper jams. Paper that has a heavy texture or does not accept ink can cause printed images to smear, bleed, or not be filled in completely. For more information about HP papers, check our website at:

www.hp.com/support

load other types of paper in the paper tray

The following table provides guidelines for loading nonstandard types of paper.

For best results, adjust the paper settings each time you change the paper type or paper size. For more information, see

set the paper type

on page 15.

Note:

Some paper types might not be available in your country/region.

Note:

Photo paper might curl when you remove it from the box. If this occurs, curl the paper the opposite way to flatten it before inserting it into the HP psc.

paper

HP papers

Labels

(works only with printing)

tips

HP Premium Paper: locate the gray arrow on the nonprinting side of the paper, and then load paper with the arrow side facing up.

HP Greeting Card Paper, HP Glossy Greeting Card Paper, or

HP Textured Greeting Cards: insert a small stack of greeting cards with the print side down, into the paper tray until it stops.

Always use letter or A4 label sheets designed for use with HP inkjet products (like Avery Inkjet Labels), and make sure that the labels are not over two years old.

Fan the stack of labels to make sure none of the pages are sticking together.

Place a stack of label sheets on top of standard paper in the paper tray, print side down. Do

not insert labels one sheet at a time.

set the paper type

If you want to use a different type of paper, load that paper in the paper tray.

You should then change the paper type settings to ensure the best print quality.

This setting refers to copy settings only. If you want to set the paper type for printing, set the properties from the Print dialog box in the software program on your computer.

The following procedure describes how to change the paper type setting on your

HP psc.

1

Load paper into the HP psc.

2

Press

Paper Type

on the front panel to change the setting to

Plain

or


. user guide 15

chapter 2

avoid jams

To avoid jams, remove papers from completed print or copy jobs frequently from the paper tray. Excessive amounts of paper from completed print or copy jobs in the paper tray might back up into the HP psc and cause a paper jam. Also, for best results, use recommended papers, and load paper correctly. For more information see,

recommended papers

on page 15, and

load letter or A4 paper

on page 12.

16 hp psc 1310 series

3

print from a camera

This HP psc supports the PictBridge standard, which allows you to connect any

PictBridge-compliant camera and print photos without using your computer.

Check your camera’s user guide to see if it supports PictBridge capability.

This section contains the following topics:

connect a camera

on page 17

print photos from your camera

on page 17

connect a camera

After you take photos with your PictBridge-compliant camera, you can print them immediately. We recommend you connect your camera’s power cable to the camera to conserve battery power.

1

Turn on your camera and be sure it is in PictBridge mode. Refer to your camera’s user guide.

2

Connect the PictBridge-compliant camera to the front USB port of the

HP PSC by using the USB cable that came with your camera.

When the camera is connected correctly, the Read Status LED is illuminated. The Read Status LED next to the card slots blinks green when printing from the camera.

If the camera is not PictBridge-compliant or is not in PictBridge mode, the

Photo Error LED blinks amber. Disconnect the camera, correct the problem on the camera and reconnect.

Read Status

LED

Photo Error

LED

print photos from your camera

After you successfully connect your PictBridge-compliant camera to the HP PSC, you can print your photos. Print functionality is managed by the camera settings, if any. Refer to your camera’s user guide for more information.

17

chapter 3

If your camera does not allow you to make settings, your HP PSC uses the following default settings:

Paper type is set to photo paper. Use letter or A4,or 4 by 6 inch (10 by

15 cm) tabbed photo paper when printing from the PictBridge port.

Paper size is detected by the HP PSC.

Number of images printed on each page is 1.

Refer to your camera’s user guide for more information.

18 hp psc 1310 series

4

use the copy features

The HP psc enables you to produce high-quality color and black-and-white copies on plain paper. You can enlarge or reduce the size of an original to fit a specific paper size, including 4 by 6 inch (10 by 15 cm) photo paper.

This section contains the following topics:

make copies

on page 19

perform special copy jobs

on page 20

stop copying

on page 22

make copies

You can make copies by using the front panel of your HP psc or by using the

HP Director software on your computer. Copy features are available through either method. However, the software offers additional copy features that are not available from the front panel.

All copy settings that you select on the front panel are reset

two minutes after the

HP psc completes the copy.

This section contains the following topics:

make a copy

on page 19

adjust copy speed or quality

on page 20

set the number of copies

on page 20

make a copy

1

Load your original face down on the left front corner of the glass.

If you are copying a photo, position the photo on the glass so the long edge of the photo is along the front edge of the glass. For more information, see

load originals

on page 11.

2

Press

Start Copy

,

Black

or

Start Copy

,

Color

.

The HP psc makes an exact copy of your original using Best quality mode.

Tip:

You can also use the Paper Type and Scan buttons to make

Fast draft-quality copies or you can use the Size button to reduce or enlarge an original to fit a specific paper size.

For more information on these options, see the following topics:

– adjust copy speed or quality

on page 20

– reduce or enlarge an original to fit the paper loaded

on page 21

19

chapter 4

adjust copy speed or quality

The HP psc automatically copies in Best mode. This produces the highest quality copies for all paper. However, you can manually override this setting to copy in

Fast mode. This produces copies more quickly and saves ink. The text is of comparable quality to copies produced using Best mode, but the graphics might be of lower quality.

to make a copy from the front panel using the fast setting

1

Load your original face down on the left front corner of the glass.

2

Press the

Paper Type

button to select

Plain

.

Note:

In order to make a copy using Fast mode, you must select Plain as the

Paper Type. If the Paper Type is set to Photo, the HP psc will always copy in

Best mode.

3

Press and hold down the

Scan

button, and then press

Start Copy

,

Black

or

Start Copy

,

Color

.

set the number of copies

1

Load your original face down on the left front corner of the glass.

2

Press

Copies

to increase the number of copies, up to a maximum of 9, and then press

Start Copy

,

Black

or

Start Copy

,

Color

.

perform special copy jobs

In addition to standard copying, your HP psc can copy photos and automatically enlarge or reduce your original to fit a specific paper size.

This section contains the following topics:

make a 4 by 6 inch (10 by 15 cm) borderless copy of a photo

on page 20

reduce or enlarge an original to fit the paper loaded

on page 21

For information on copy options that are available in the HP Director, see the onscreen

hp image zone help

that came with your software.

make a 4 by 6 inch (10 by 15 cm) borderless copy of a photo

For the best quality when copying a photo, load photo paper in the paper tray, and then use the Paper Type button to select Photo. You might also want to use the photo print cartridge for superior print quality. With the tri-color and photo print cartridges installed, you have a six-ink system. See

use a photo print cartridge

on page 36 for more information.

1

Load your original photo face down on the left front corner of the glass.

Position the photo on the glass so the long edge of the photo is along the front edge of the glass.

20 hp psc 1310 series

use the copy features

2

Load 4 by 6 inch (10 by 15 cm) tabbed photo paper print side down in the paper tray, with the tab facing out towards you.

3

If your original is not 4 by 6 inches (10 by 15 cm), press the

Size

button to select

Fit to Page

.

The HP psc will resize the original to 4 by 6 inches (10 by 15 cm) to create a borderless copy.

4

Press the

Paper Type

button to select


.

This tells the HP psc that you have photo paper loaded in the paper tray.

When printing onto photo paper, the HP psc automatically copies your original in Best quality mode.

5

Press

Start Copy

,

Black

or

Start Copy

,

Color

.

reduce or enlarge an original to fit the paper loaded

Use Fit to Page when you want to automatically enlarge or reduce your original to fill the printable area of the paper size loaded in the paper tray.

For example, you can use Fit to Page to enlarge a small photo to fit within the margins of a full-size page (as shown below), reduce an original to prevent unwanted cropping of text or images around the margins, or reduce or enlarge an original to create a borderless 4 by 6 inch (10 by 15 cm) photo.

user guide

1

Make sure that the glass and lid backing are clean.

2

Load your original face down on the left front corner of the glass.

If you are copying a photo, position the photo on the glass so the long edge of the photo is along the front edge of the glass, as shown below.

21

chapter 4

3

Press the

Size

button to select

Fit to Page

.

4

Press

Start Copy

,

Black

or

Start Copy

,

Color

.

stop copying

!

To stop copying, press

Cancel

on the front panel.

The HP psc immediately stops printing and releases the paper.

22 hp psc 1310 series

5

use the scan features

Scanning is the process of converting pictures and text into an electronic format for your computer. You can scan photos and text documents.

Because the scanned image or text is in an electronic format, you can bring it into your word processor or graphics software program and modify it to suit your needs. You can do the following:

Scan photos of your kids and e-mail them to relatives, create a photographic inventory of your house or office, or create an electronic scrapbook.

Scan text from an article into your word processor and quote it in a report, saving you a lot of retyping.

To use the scan features, your HP psc and computer must be connected and turned on. The HP psc software must also be installed and running on your computer prior to scanning. To verify that the HP psc software is running on a

Windows PC, look for the hp psc 1310 series icon in the system tray at the lower right side of your screen, next to the time. On a Macintosh, the HP psc software is always running.

You can start a scan from your computer or from your HP psc. This section explains how to scan from the front panel of the HP psc only.

For information about how to scan from the computer, and how to adjust, resize, rotate, crop, and sharpen your scans, see the onscreen

hp image zone help

that came with your software.

Note:

Bright direct sunlight on your HP PSC, or halogen desk lamps placed close to your HP PSC, might affect the quality of scanned images.

Note:

High resolution scanning (600 dpi or higher) requires a large amount of hard disk space. If there is not enough hard disk space available, your system might stall.

This section contains the following topics:

scan an original

on page 23

stop scanning

on page 24

scan an original

1

Load your original face down in the left front corner of the glass.

2

Press

Scan

.

A preview image of the scan appears in the HP Scan window on the computer, where you can edit it.

For more information about editing a preview image, see the onscreen

hp image zone help

that came with your software.

23

chapter 5

3

Make any edits to the preview image in the

HP Scan

window. When you have finished, click

Accept

.

The HP psc sends the scan to the HP Gallery, which automatically opens and displays the image.

The HP Gallery has many tools that you can use to edit your scanned image. You can improve the overall image quality by adjusting the brightness, sharpness, color tone, or saturation. You can also crop, straighten, rotate, or resize the image.

When the scanned image looks just the way you want it, you can open it in another application, send it via e-mail, save it to a file, or print it. For more information about using the HP Gallery, see the onscreen

hp image zone help

that came with your software.

stop scanning

!

To stop scanning, press

Cancel

on the front panel.

24 hp psc 1310 series

6

order supplies

You can order print cartridges, recommended types of HP paper, and HP psc accessories online from the HP website.

This section contains the following topics:

order media

on page 25

order print cartridges

on page 25

order other supplies

on page 25

order media

To order media such as HP Premium Paper, HP Premium Inkjet Transparency Film,

HP Iron-On Paper, or HP Greeting Cards, go to:

www.hp.com

Choose your country/region, and then select Buy or Shopping.

order print cartridges

The following table lists the print cartridges that are compatible with your HP psc.

Use this information to determine which print cartridge to order.

print cartridges

HP 27 black inkjet print cartridge, 10 ml

HP 28 tri-color inkjet print cartridge, 8 ml

HP 56 black inkjet print cartridge, 19 ml

HP 57 tri-color inkjet print cartridge, 17 ml

HP 58 photo inkjet print cartridge, 17 ml

hp reorder number

C8727AN

C8728AN

C8756AN

C8757AN

C8758AN

Get more information about print cartridges from the HP website:

www.hp.com

Choose your country/region, and then select Buy or Shopping.

order other supplies

To order other supplies such as HP psc software, a copy of the printed User

Guide, a Setup Poster, or other customer-replaceable parts, call the appropriate number.

In the U.S. or Canada, dial 1-800-HP-INVENT (1-800-474-6836).

In Europe, dial +49 180 5 290220 (Germany) or +44 870 606 9081

(U.K.).

25

chapter 6

To order HP psc software in other countries/regions, call the phone number for your countries/regions. The numbers listed below are current as of the publication date of this guide. For a list of current ordering numbers, go to the following website and choose your own country/region or language:

www.hp.com/support

country/region

Asia Pacific

Australia

New Zealand

South Africa

U.S. and Canada

number for ordering

65 272 5300

61 3 8877 8000

0800 441 147

+27 (0)11 8061030

1-800-HP-INVENT (1-800-474-6836)

26 hp psc 1310 series

7

maintain your hp psc

The HP psc requires little maintenance. Sometimes you might want to clean the glass and lid backing to remove surface dust and ensure that your copies and scans remain clear. You might also want to replace, align, or clean your print cartridges from time to time. This section provides instructions for keeping your

HP psc in top working condition. Perform these simple maintenance procedures as necessary.

This section contains the following topics:

clean the glass

on page 27

clean the lid backing

on page 27

clean the exterior

on page 28

work with print cartridges

on page 28

self-maintenance sounds

on page 36

clean the glass

Dirty glass from fingerprints, smudges, hair, and so on slows down performance and affects the accuracy of features such as Fit to Page.

1

Turn off the HP psc, unplug the power cord, and raise the lid.

2

Clean the glass with a soft cloth or sponge slightly moistened with a nonabrasive glass cleaner.

Caution!

Do not use abrasives, acetone, benzene, or carbon tetrachloride on the glass; these can damage it. Do not place or spray liquids directly on the glass. They might seep under it and damage the HP psc.

3

Dry the glass with a chamois or cellulose sponge to prevent spotting.

clean the lid backing

Minor debris can accumulate on the white document backing located underneath the lid of the HP psc. This can cause problems during scan or copy tasks.

1

Turn off the HP psc, unplug the power cord, and raise the lid.

2

Clean the white document backing with a soft cloth or sponge slightly moistened with a mild soap and warm water.

3

Wash the backing gently to loosen debris; do not scrub the backing.

27

chapter 7

4

Dry the backing with a chamois or soft cloth.

Caution!

Do not use paper-based wipes as these might scratch the backing.

5

If this does not clean the backing well enough, repeat the previous steps using isopropyl (rubbing) alcohol, and wipe the backing thoroughly with a damp cloth to remove any residual alcohol.

clean the exterior

Use a soft cloth or slightly moistened sponge to wipe dust, smudges, and stains off the case. The interior of the HP psc does not require cleaning. Keep fluids away from the interior of the HP psc as well as the front panel.

work with print cartridges

To ensure the best print quality from your HP psc, you will need to perform some simple maintenance procedures.

This section contains the following topics:

check the ink levels

on page 28

print a self-test report

on page 29

handle print cartridges

on page 29

replace the print cartridges

on page 30

use a photo print cartridge

on page 32

use a print cartridge protector

on page 32

align the print cartridges

on page 33

clean the print cartridge contacts

on page 35

check the ink levels

You can easily check the ink supply level to determine how soon you might need to replace a print cartridge. The ink level supply shows an approximation of the amount of ink remaining in the print cartridges. Checking the ink levels can only be done from the HP Director.

to check the ink level for Windows users

1

From the

HP Director

, choose

Settings

, choose

Print Settings

, and then choose

Printer Toolbox

.

2

Click the

Estimated Ink Levels

tab.

The estimated ink levels appear for the print cartridges.

to check the ink level for Macintosh users

1

From the

HP Director

, choose

Settings

, and then choose

Maintain Printer

.

2

If the

Select Printer

dialog box opens, select your HP psc, and then click

Utilities

.

3

From the list, select

Ink Level

.

The estimated ink levels appear for the print cartridges.

28 hp psc 1310 series

maintain your hp psc

print a self-test report

If you are experiencing problems with printing, print a Self-Test Report before you replace the print cartridges.

1

Press and hold down

Cancel

.

2

Press

Start Copy

,

Color

.

The HP psc prints a Self-Test Report, which might indicate the source of any problems you might be having.

Black bar

Color bars

Black and tri-color cartridges installed

Color blocks

Tri-color and photo cartridge installed

3

Check the color blocks for streaking or white lines.

Missing color blocks might indicate that the tri-color print cartridge is out of ink. You might need to clean or replace your print cartridges.

Streaks might indicate clogged nozzles or dirty contacts. You might need to clean the print cartridges. Do

not clean with alcohol.

For information on replacing ink cartridges, see

replace the print cartridges

on

page 30 and for information on cleaning print cartridges, see

clean the print cartridge contacts

on page 35.

handle print cartridges

Before you replace a print cartridge, you should know the part names and how to handle the print cartridge. user guide 29

chapter 7

Copper-colored contacts

Plastic tape with pink pull tab

(must be removed)

Ink nozzles under tape

Do not touch the copper-colored contacts or the ink nozzles

replace the print cartridges

The HP psc notifies you when you need to replace your print cartridges. Replace the print cartridges when you see faded text or if you experience print quality issues related to the print cartridges.

For more information on ordering replacement print cartridges, see

order print cartridges

on page 25.

1

Turn on the HP psc and then lower the paper tray to access the printcarriage access door.

2

Open the print-carriage access door by lowering the handle.

The print carriage moves to the center of the HP psc.

Push down

Paper tray

Print-carriage access door

3

After the carriage stops moving, push down on the print cartridge to release it, and then pull it toward you out of its slot.

30 hp psc 1310 series

maintain your hp psc

Note:

It is normal to see ink buildup in the print cartridge slots.

4

Remove the new print cartridge from its packaging and, being careful to touch only the bright pink plastic tab, gently remove the plastic tape to uncover the ink nozzles.

Caution!

Do not touch the copper-colored contacts or ink nozzles.

After you have removed the plastic tape, install the print cartridge immediately to prevent the ink from drying in the nozzles.

5

Hold the black print cartridge with the HP label on top. Slide the print cartridge at a slight angle into the

right side of the print carriage.

Press firmly until the print cartridge snaps into place.

Caution!

Do not attempt to push the cartridge straight into the slot.

It must slide in at a slight angle.

6

Hold the tri-color print cartridge with the HP label on top. Slide the print cartridge at a slight angle into the

left side of the print carriage.

Press firmly until the print cartridge snaps into place.

Caution!

Do not attempt to push the cartridge straight into the slot.

It must slide in at a slight angle.

user guide

Note:

You must install

both print cartridges in order for your HP psc to work.

31

chapter 7

You can also refer to the label that is located on the inside of the printcarriage access door for information on installing the print cartridges.

7

Close the print-carriage access door. Within a few minutes, a print cartridge alignment page prints. You will need to align the print cartridges.

For information on aligning the print cartridges, see

align the print cartridges

on page 33.

use a photo print cartridge

You can optimize the quality of the photos you print with your HP psc by purchasing a photo print cartridge. Remove the black print cartridge and insert the photo print cartridge in its place. With the tri-color print cartridge and photo print cartridge installed, you have a six-ink system, which provides enhanced quality photos. When you want to print regular text documents, swap the black print cartridge back in. Use a print cartridge protector to keep your print cartridge secure when it is not being used. For more information on using the print cartridge protector, see

use a print cartridge protector

on page 32 and for

more information on replacing print cartridges, see

replace the print cartridges

on page 30.

For more information on purchasing a photo print cartridge, see

order print cartridges

on page 25.

use a print cartridge protector

When you purchase a photo print cartridge, you will receive a print cartridge protector.

The print cartridge protector is designed to keep your print cartridge secure when it is not being used. It also prevents the ink from drying out. Whenever you remove a print cartridge from the HP psc, store it in the print cartridge protector.

!

To insert a print cartridge into the print cartridge protector, slide the print cartridge into the print cartridge protector at a slight angle and snap it securely into place.

32 hp psc 1310 series

maintain your hp psc

!

To remove the print cartridge from the print cartridge protector, press down and back on the top of the print cartridge protector to release the print cartridge, then slide the print cartridge out of the print cartridge protector.

align the print cartridges

After you install or replace a print cartridge, the HP psc automatically prints a print cartridge alignment sheet. This might take a few moments. You can also align the print cartridges at any time from the HP Director. For information on accessing the HP Director, see

use your hp psc with a computer

on page 6.

Aligning the print cartridges ensures high-quality output.

to align the print cartridges after installing a new print cartridge

1

Place the print cartridge alignment sheet face down on the left front corner of the glass. Make sure the top of the sheet is on the left side as shown below.

user guide

2

Press

Scan

.

The HP psc aligns the print cartridges.

Note:

During alignment the button LED blinks until the procedure is finished.

This takes about 30 seconds.

to align the print cartridges from the hp director for Windows users

1

From the

HP Director

, choose

Settings

, choose

Print Settings

, and then choose

Printer Toolbox

.

2

Click the

Device Services

tab.

3

Click

Align the Print Cartridges

.

A print cartridge alignment sheet is printed.

33

chapter 7

4

Place the print cartridge alignment sheet face down on the left front corner of the glass. Make sure the top of the sheet is on the left side as shown below.

5

Press

Scan

.

The HP psc aligns the print cartridges.

Note:

During alignment the button LED blinks until the procedure is finished.

This takes about 30 seconds.

to align the print cartridges from the hp director for Macintosh users

1

From the

HP Director

, choose

Settings

, and then choose

Maintain Printer

.

2

If the

Select Printer

dialog box opens, select your HP psc, and then click

Utilities

.

3

From the list, select

Calibrate

.

4

Click

Align

.

The HP psc prints a print cartridge alignment sheet. This might take a few moments.

5

Place the print cartridge alignment sheet face down on the left front corner of the glass. Make sure the top of the sheet is on the left side.

34

6

Press

Scan

.

The HP psc aligns the print cartridges.

Note:

During alignment the button LED blinks until the procedure is finished.

This takes about 30 seconds.

hp psc 1310 series

maintain your hp psc

clean the print cartridge contacts

Clean the print cartridge contacts only if the Self-Test Report shows streaks.

Caution!

Do not remove both print cartridges at the same time.

Remove and clean each print cartridge one at a time.

Make sure you have the following materials available:

Dry foam rubber swabs, lint-free cloth, or any soft material that will not come apart or leave fibers.

Distilled, filtered, or bottled water (tap water might contain contaminants that can damage the print cartridges).

Caution!

Do

not use platen cleaners or alcohol to clean the print cartridge contacts. These can damage the print cartridge or the

HP psc.

1

Turn the HP psc on and open the print-carriage access door.

The print carriage moves to the center.

2

After the print carriage has moved to the center, unplug the power cord from the back of the HP psc.

3

Push down on the print cartridge to release it, and then pull it out of its slot.

4

Inspect the print cartridge contacts for ink and debris buildup.

5

Dip a clean foam rubber swab or lint-free cloth into distilled water, and squeeze any excess water from it.

6

Hold the print cartridge by its sides.

7

Clean only the contacts. Do

not clean the nozzles.

Contacts

Nozzles - do not clean

8

Place the print cartridge back into the holder.

9

Repeat if necessary for the other print cartridge.

10

Close the door and plug in the HP psc.

Because you removed a print cartridge from its holder, the HP psc automatically prints a print cartridge alignment sheet.

user guide 35

chapter 7

11

Place the print cartridge alignment sheet face down on the left front corner of the glass. Make sure the top of the sheet is on the left side as shown below.

12

Press

Scan

.

The HP psc aligns the print cartridges.

Note:

During alignment the button LED blinks until the procedure completes.

This takes about 30 seconds.

self-maintenance sounds

During the life of your product you might hear various mechanical sounds. This is a normal part of your device’s self-maintenance.

36 hp psc 1310 series

8

get hp psc 1310 series support

Hewlett-Packard provides Internet and phone support for your HP psc.

This section contains the following topics:

get support and other information from the Internet

on page 37

hp customer support

on page 37

prepare your hp psc for shipment

on page 41

hp distribution center

on page 43

If you are unable to find the answer you need in the printed or onscreen documentation supplied with your product, you can contact one of the HP support services listed in the following sections. Some support services are available only in the U.S. and Canada, while others are available in many countries/regions worldwide. If a support service number is not listed for your country/region, contact your nearest authorized HP dealer for help.

get support and other information from the Internet

If you have Internet access, you can get more information from the HP website at:

www.hp.com/support

This website offers technical support, drivers, supplies, and ordering information.

hp customer support

Software programs from other companies might be included with your HP psc. If you experience problems with any of those programs, you will receive the best technical assistance by calling the experts at that company.

If you need to contact HP Customer Support, do the following before you call.

1

Make sure that: a. Your HP psc is plugged in and turned on.

b. The specified print cartridges are installed correctly.

c. The recommended paper is properly loaded in the paper tray.

2

Reset your HP psc: a. Turn off the HP psc by using the

On/Resume

button located on the front panel.

b. Unplug the power cord from the back of the HP psc.

c. Plug the power cord back into the device.

d. Turn on the HP psc by using the

On/Resume

button.

3

For more information, go to the HP website at:

www.hp.com/support

4

If you are still experiencing problems and need to speak with an HP Customer

Support Representative:

Have the specific name of your HP psc, as it appears on the device, available.

Have your serial number and service ID ready. To view your serial number and service ID, print a Self-Test Report, which contains this information. To print a

Self-Test Report, press and hold the

Cancel

button, and then press the

Start Copy

,

Color

button.

Be prepared to describe your problem in detail.

5

Call HP Customer Support. Be near your HP psc when you call.

37

chapter 8

call in North America during warranty

Call 1-800-HP-INVENT. US phone support is available in both English and Spanish languages 24 hours a day, 7 days a week (days and hours of support might change without notice). This service is free during the warranty period. A fee might apply outside the warranty period.

call hp Japan customer support call hp Korea customer support

38

support process for Western Europe

The HP support process works most effectively when looking for help in the following order:

1

Use

troubleshooting information

on page 59 to search for a solution.

2

Visit

www.hp.com/support

to:

Check for software updates

Access online support pages

Send HP an email message for answers to your questions.

hp psc 1310 series

get hp psc 1310 series support

Web and email support are available in the following languages:

Dutch

English

French

German

Italian

Portuguese

Spanish

Swedish

For all other languages, support information is available in English.

3

Contact your local HP dealer.

If your HP psc has a hardware failure, take it to your local HP dealer for a solution.

Service is free during the limited warranty period. After the warranty period, you will be quoted a service charge.

4

Call HP support.

To find the telephone number for your country/region, please go to

www.hp.com/ support

and choose your country/region and language.

support process for Eastern Europe, Middle East, and Africa

Follow these steps to troubleshoot the HP psc:

1

Use

troubleshooting information

on page 59 to search for a solution.

2

Visit

www.hp.com/support

to:

Check for software updates

Access online support pages

Send HP an email message for answers to your questions.

Web and email support are available in the following languages:

Dutch

English

French

German

Italian

Portuguese

Spanish

Swedish

For all other languages, support information is available in English.

3

Call HP support.

See the table of support information in

call elsewhere in the world

on page 39.

call elsewhere in the world

The numbers listed below are current as of the publication date of this guide. For a list of current international HP Support Service numbers, go to the following website and choose your own country/region or language:

www.hp.com/support

You can call the HP support center in the following countries/regions. If your country/ region is not listed, contact your local dealer or nearest HP Sales and Support Office to find out how to obtain services.

Support service is free during the warranty period; however, your standard long-distance phone charges will apply. In some cases, a flat fee per single incident will also apply.

For phone support in Europe, please check for the details and conditions of phone support in your country/region. Go to the following website:

www.hp.com/support

user guide 39

chapter 8

40

Alternatively, you can ask your dealer or call HP at the phone number provided in this booklet.

As part of our constant efforts to improve our phone support service, we advise you to check our website on a regular basis for new information regarding service features and delivery.

country/region

Algeria

*

Argentina

Australia

Austria

Bahrain (Dubai)

Belgium (Dutch)

Belgium (French)

Bolivia

Brazil (Grande São

Paulo)

Brazil (Demais

Localidades)

Canada during warranty

Canada post-warranty

(per-call charge)

Caribbean & Central

America

Chile

China

Colombia

Costa Rica

Czech Republic

Denmark

Ecuador (Andinatel)

Ecuador (Pacifitel)

Egypt

Finland

France

Germany

hp technical support

61 56 45 43

(54)11-4778-8380

0-810-555-5520

+61 3 8877 8000

1902 910 910 www.hp.com/support

800 171 www.hp.com/support

800-100247

(11) 3747 7799

0800 157751

(905) 206 4663

1-877-621-4722

1-800-711-2884

800-360-999

86-21-38814518

8008206616

01-800-114-726

0-800-011-0524

261307310 www.hp.com/support

999119+1-800-

7112884

1-800-225528+1-800-

7112884

2 532 5222 www.hp.com/support www.hp.com/support www.hp.com/support

country/region

Malaysia

Mexico

Mexico (Mexico City)

Morocco

*

Netherlands

New Zealand

Norway

Oman

Palestine

Panama

Peru

Philippines

Poland

Portugal

Puerto Rico

Qatar

Republica Dominicana

Romania

Russia, Moscow

Russia, St. Petersburg

Saudi Arabia

Singapore

Slovakia

South Africa (RSA)

hp technical support

1-800-805405

01-800-472-6684

(55)5258-9922

22 4047 47 www.hp.com/support

0800 441 147 www.hp.com/support

+971 4 883 8454

+971 4 883 8454

001-800-7112884

0-800-10111

632-867-3551

22 5666 000 www.hp.com/support

1-877-232-0589

+971 4 883 8454

1-800-7112884

21 315 4442

095 7973520

812 3467997

800 897 1444

(65) 272-5300

2 50222444

086 0001030 hp psc 1310 series

country/region

Greece

hp technical support

801 11 22 55 47

Greece, Outside Greece +30 210 6073603

country/region

South Africa, Outside

Republic

Spain get hp psc 1310 series support

hp technical support

+27 11 258 9301 www.hp.com/support

Greece (Cyprus)

Guatemala

Hong Kong

Hungary

India

Indonesia

Ireland

Israel

Italy

Jamaica

Japan

800 9 2649

1800-995-5105

+85 (2) 3002 8555

1 382 1111

1-600-112267

91 11 682 6035

62-21-350-3408 www.hp.com/support

(0) 9 803 4848 www.hp.com/support

0-800-7112884

0570 000 511

+81 3 3335 9800

Sweden

Switzerland

Taiwan

Thailand

Trinidad & Tobago

Tunisia

Turkey

*

Ukraine

United Arab Emirates

United Kingdom

Venezuela www.hp.com/support www.hp.com/support

+886-2-2717-0055

0800 010 055

+66 (2) 661 4000

1-800-7112884

71 89 12 22

216 579 71 71

(380 44) 4903520

800 4520 www.hp.com/support

01-800-4746.8368

Jordan

Korea

Kuwait

+971 4 883 8454

+82 1588 3003

+971 4 883 8454

Venezuela (Caracas)

Vietnam

(502) 207-8488

84-8-823-4530

W. Africa (for countries not already listed)

+351 213 17 63 80

Yemen +971 4 883 8454 Lebanon +971 4 883 8454

Luxembourg (French)

Luxembourg (German) www.hp.com/support

* This Call Center supports French-speaking customers from the following countries/regions:

Morocco, Tunisia, and Algeria.

call in Australia post-warranty

If your product is not under warranty, you can call 03 8877 8000. A per-incident, out-ofwarranty support fee of $27.50 (inc. GST) will be charged to your credit card. You can also call 1902 910 910 ($27.50 charged to your phone account) from 9:00 A.M. to

5:00 P.M. Monday through Friday. Charges and support hours are subject to change without notice.

prepare your hp psc for shipment

If after contacting HP Customer Support or returning to the point of purchase, you are requested to send your HP psc in for service, please follow the power off and re-package steps below to avoid further damage to the device.

user guide 41

chapter 8

Note:

When transporting your HP psc, make sure that the print cartridges have been removed, the HP psc has been properly shut down by pressing the On/Resume button, and you have allowed time for the print carriage to return to the home position and for the scanner to return to its parked position.

1

Turn on the HP psc.

Disregard steps 1 through 7 if your HP psc will not turn on. You will not be able to remove the print cartridges. Proceed to step 8.

2

Open the print-carriage access door.

The print carriage moves to the center of the HP psc.

3

Remove the print cartridges. See

replace the print cartridges

on page 30 for

information on removing the print cartridges.

Caution!

Remove both print cartridges. Failure to do so might damage your HP psc.

4

Place the print cartridges in an airtight bag so they will not dry out, and put them aside. Do not send them with the HP psc, unless instructed to by the HP customer support call agent.

5

Close the print-carriage access door.

6

Wait for the print carriage to park (stop moving) in the home position on the left side of the HP psc. This might take a few seconds.

7

Turn off the HP psc.

8

If available, pack the HP psc for shipment by using the original packing materials or the packaging materials that came with your exchange device.

42

If you do not have the original packaging materials, please use other adequate packaging materials. Shipping damage caused by improper packaging and/or improper transportation is not covered under the warranty.

9

Place the return shipping label on the outside of the box.

10

Include the following items in the box:

A brief description of symptoms for service personnel (samples of print quality problems are helpful).

A copy of the sales slip or other proof of purchase to establish the warranty coverage period.

Your name, address, and a phone number where you can be reached during the day.

hp psc 1310 series

get hp psc 1310 series support

hp distribution center

To order HP psc software, a copy of the printed User Guide, a Setup Poster, or other customer-replaceable parts, do one of the following:

In the U.S. or Canada, call 1-800-HP-INVENT (1-800-474-6836).

In Latin America, call the appropriate number for your country/region (see

call elsewhere in the world

on page 39).

Outside of this country/region, go to this website:

www.hp.com/support

user guide 43

chapter 8

44 hp psc 1310 series

9

warranty information

Your HP psc comes with a limited warranty that is described in this section. Information about how to obtain warranty service and how you can upgrade your standard factory warranty is also provided.

This section contains the following topics:

duration of limited warranty

on page 45

warranty service

on page 45

warranty upgrades

on page 45

returning your hp psc for service

on page 46

hewlett-packard limited global warranty statement

on page 46

duration of limited warranty

Duration of Limited Warranty (hardware and labor): 1 Year

Duration of Limited Warranty (CD media): 90 Days

Duration of Limited Warranty (print cartridges): Until the HP ink is depleted or the “end of warranty” date printed on the cartridge has been reached, whichever occurs first.

Note:

The services described in the

express service

and

warranty upgrades

sections

below might not be available in all locations.

warranty service

express service

To obtain HP express repair service, the customer must contact an HP service office or an

HP Customer Support Center for basic troubleshooting first. See

hp customer support

on page 37 for steps to take before calling Customer Support.

If a customer device needs a minor part replacement and these parts can normally be replaced by the customer, the customer-replaceable components might be serviced through expedited part shipment. In this event, HP will prepay shipping charges, duty and taxes; provide telephone assistance on replacement of the component; and pay shipping charges, duty, and taxes for any part that HP asks to be returned.

The HP Customer Support Center might direct customers to designated authorized service providers who are certified by HP to service the HP product.

warranty upgrades

Upgrade your standard factory warranty to a total of three years with the

HP SUPPORTPACK. Service coverage begins on product purchase date and the pack must be purchased within the first 180 days after product purchase. If during your technical support call it is determined that you need a replacement product, then HP will ship you this product next business day free of charge. Available in U.S. only.

For more information, please call 1-888-999-4747 or visit the HP website:

www.hp.com/go/hpsupportpack

45

chapter 9

Outside the U.S., please call your local HP Customer Support office. See

call elsewhere in the world

on page 39 for a list of international Customer Support numbers.

returning your hp psc for service

Before returning your HP PSC for service, you must call HP Customer Support. See

hp customer support

on page 37 for steps to take before calling Customer Support.

hewlett-packard limited global warranty statement

extent of limited warranty

Hewlett-Packard (“HP”) warrants to the end-user customer (“Customer”) that each HP PSC product (“Product”), including related software, accessories, media, and supplies, shall be free from defects in material and workmanship for the duration, which begins on the date of purchase by the Customer.

For each software Product, HP’s limited warranty applies only to a failure to execute programming instructions. HP does not warrant that the operation of any Product shall be uninterrupted or error free.

HP’s limited warranty covers only those defects which arise as a result of normal use of a

Product, and does not cover any other problems, including those which arise as a result of

(a) improper maintenance or modification, (b) software, accessories, media, or supplies not provided or supported by HP, or (c) operation outside the Product’s specifications.

For any hardware Product, the use of a non-HP print cartridge or a refilled print cartridge does not affect either the warranty to the Customer or any HP support contract with the

Customer. However, if Product failure or damage is attributable to the use of a non-HP or refilled print cartridge, HP shall charge its standard labor and materials charges to service the Product for the failure or damage.

If HP receives, during the applicable warranty period, notice of a defect in any Product,

HP shall either repair or replace the defective Product, at HP’s option. Where labor charges are not covered by HP’s limited warranty, repairs shall be at HP’s standard charges for labor.

If HP is unable to repair or replace, as applicable, a defective Product which is covered by

HP’s warranty, HP shall, within a reasonable time after being notified of the defect, refund the purchase price for the Product.

HP shall have no obligation to repair, replace, or refund until the Customer returns the defective Product to HP.

Any replacement product may be either new or like-new, provided that it has functionality at least equal to that of the Product being replaced.

HP products, including each Product, may contain remanufactured parts, components, or materials equivalent to new in performance.

HP’s limited warranty for each Product is valid in any country/region or locality where HP has a support presence for the Product and where HP has marketed the Product. The level of warranty service may vary according to local standards. HP shall have no obligation to alter the form, fit, or function of the Product in order to make it operate in a country/region or locality for which the Product was never intended to operate.

limitations of warranty

TO THE EXTENT ALLOWED BY LOCAL LAW, NEITHER HP NOR ITS THIRD PARTY

SUPPLIERS MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER

EXPRESS OR IMPLIED, WITH RESPECT TO THE COVERED HP PRODUCTS, AND

46 hp psc 1310 series

warranty information

SPECIFICALLY DISCLAIM THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR

PURPOSE.

limitations of liability

To the extent allowed by local law, the remedies provided in this Limited Warranty

Statement are the Customer’s sole and exclusive remedies.

TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS

SPECIFICALLY SET FORTH IN THIS LIMITED WARRANTY STATEMENT, IN NO EVENT

SHALL HP OR ITS THIRD PARTY SUPPLIERS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT,

TORT, OR ANY OTHER LEGAL THEORY AND WHETHER ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES.

local law

This Limited Warranty Statement gives the Customer specific legal rights. The Customer may also have other rights which vary from state to state in the United States, from province to province in Canada, and from country/region to country/region elsewhere in the world.

To the extent this Limited Warranty Statement is inconsistent with local law, this Statement shall be deemed modified to be consistent with such local law. Under such local law, certain disclaimers and limitations of this Statement may not apply to the Customer. For example, some states in the United States, as well as some governments outside the United

States (including provinces in Canada), may:

Preclude the disclaimers and limitations in this Statement from limiting the statutory rights of a consumer (e.g. the United Kingdom);

Otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations; or

Grant the Customer additional warranty rights, specify the duration of implied warranties which the manufacturer cannot disclaim, or not allow limitations on the duration of implied warranties.

FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND, THE TERMS

IN THIS LIMITED WARRANTY STATEMENT, EXCEPT TO THE EXTENT LAWFULLY

PERMITTED, DO NOT EXCLUDE, RESTRICT, OR MODIFY, AND ARE IN ADDITION TO,

THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THE COVERED HP

PRODUCTS TO SUCH CUSTOMERS.

user guide 47

chapter 9

48 hp psc 1310 series

10

technical information

The technical specifications for your HP psc are provided in this section. Also, international regulatory information for your HP psc is supplied in this section.

This section contains the following information:

paper specifications

on page 49

physical specifications

on page 50

power specifications

on page 50

physical specifications

on page 50

environmental specifications

on page 50

environmental product stewardship program

on page 50

regulatory notices

on page 51

paper specifications

paper-tray capacity type paper weight

Plain paper

Legal paper

Cards

Envelopes

Transparency film

Labels

20 to 24 lb.

(75 to 90 gsm)

20 to 24 lb.

(75 to 90 gsm)

110 lb. index max

(200 gsm)

20 to 24 lb.

(75 to 90 gsm)

N/A

N/A

4 by 6 inch

(10 by 15 cm) Photo

* Maximum capacity

145 lb.

(236 gsm)

quantity

*

100

100

20

10

20

20

20

print margin specifications

top

(leading edge) sheet paper or transparency film bottom

(trailing edge)

* left right

U.S. (Letter, Legal) .06 inch (1.5 mm) .50 inch (12.7 mm) .25 inch (6.4 mm) .25 inch (6.4 mm)

ISO (A4) .07 inch (1.8 mm) .50 inch (12.7 mm) .13 inch (3.2 mm) .13 inch (3.2 mm)

Envelopes

Cards

.13 inch (3.2 mm)

.07 inch (1.8 mm)

.13 inch (3.2 mm)

.46 inch (11.7 mm)

.25 inch (6.4 mm)

.13 inch (3.2 mm)

.50 inch (12.7 mm)

.13 inch (3.2 mm)

49

chapter 10

* The writing area is offset from center by .21 inches (5.4 mm), which causes asymmetric top and bottom margins.

physical specifications

Height: 6.68 inch (16.97 cm)

Width: 16.76 inch (42.57 cm)

Depth: 10.20 inch (25.91 cm)

Weight: 10 lb. (4.53 kg)

power specifications

Power consumption: 80 W maximum

Input Voltage: AC 100 to 240 V ~ 1 A 50–60 Hz, grounded

Output Voltage: DC 32 V===940 mA, 16 V===625 mA

environmental specifications

Recommended Operating Temperature Range: 15º to 32º C (59º to 90º F)

Allowable Operating Temperature Range: 5º to 40º C (41º to 104º F)

Humidity: 15% to 85% RH non-condensing

Non-operating (Storage) Temperature Range: -4º to 60º C (-40º to 140º F)

In the presence of high electromagnetic fields, it is possible the output from the

HP psc might be slightly distorted

HP recommends using a USB cable less than or equal to 3 m (10 feet) in length to minimize injected noise due to potential high electromagnetic fields

environmental product stewardship program

protecting the environment

Hewlett-Packard is committed to providing quality products in an environmentally sound manner. This product has been designed with several attributes to minimize impacts on our environment.

For more information, visit HP’s Commitment to the Environment website at:

www.hp.com/hpinfo/globalcitizenship/environment/index.html

ozone production

This product generates no appreciable ozone gas (O3).

energy consumption

Energy usage drops significantly while in ENERGY STAR

®

mode, which saves natural resources, and saves money without affecting the high performance of this product. This product qualifies for ENERGY STAR, which is a voluntary program established to encourage the development of energy-efficient office products.

50 hp psc 1310 series

technical information

ENERGY STAR is a U.S. registered service mark of the U.S. EPA. As an ENERGY STAR partner, HP has determined that this product meets ENERGY STAR guidelines for energy efficiency.

For more information on ENERGY STAR guidelines, see the following web site:

www.energystar.gov

paper use

This product is suited for the use of recycled paper according to DIN 19309.

plastics

Plastic parts over 25 grams are marked according to international standards that enhance the ability to identify plastics for recycling purposes at the end of the product’s life.

material safety data sheets

Material safety data sheets (MSDS) can be obtained from the HP website at:

www.hp.com/go/msds

Customers without Internet access should contact their local HP Customer Support Center.

recycling program

HP offers an increasing number of product return and recycling programs in many countries, and partners with some of the largest electronic recycling centers throughout the world. HP also conserves resources by refurbishing and reselling some of its most popular products.

This HP product contains the following materials that might require special handling at endof-life:

Lead in solder

hp inkjet supplies recycling program

HP is committed to protecting the environment. The HP Inkjet Supplies Recycling Program is available in many countries/regions, and lets you recycle used print cartridges free of charge. For more information, see the following HP website:

www.hp.com/hpinfo/globalcitizenship/environment/recycle/inkjet.html

regulatory notices

The HP psc is designed to meet the regulatory requirements for your country/region.

regulatory model identification number

For regulatory identification purposes, your product is assigned a Regulatory Model

Number. The Regulatory Model Number for your product is SDGOB-0319. This regulatory number should not be confused with the marketing name (HP PSC 1310 Series) or product numbers (Q5765A, Q5766A, Q5767A, Q5768A, Q5769A, Q5770A, Q5771A,

Q5772A). user guide 51

chapter 10

FCC statement

The United States Federal Communications Commission (in 47 CFR 15.105) has specified that the following notice be brought to the attention of users of this product.

Declaration of Conformity: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class B limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Product Regulations Manager, Hewlett-Packard Company, San Diego, (858) 655-4100.

The user may find the following booklet prepared by the Federal Communications

Commission helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington DC, 20402.

Stock No. 004-000-00345-4.

Caution!

Pursuant to Part 15.21 of the FCC Rules, any changes or modifications to this equipment not expressly approved by the Hewlett-

Packard Company may cause harmful interference and void the FCC authorization to operate this equipment.

note à l’attention des utilisateurs Canadien/notice to users in Canada

Le présent appareil numérique n‘émet pas de bruit radioélectrique dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

This digital apparatus does not exceed the Class B limits for radio noise emissions from the digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

notice to users in Australia

This equipment complies with Australian EMC requirements

geräuschemission

LpA < 70 dB am Arbeitsplatz im Normalbetrieb nach DIN 45635 T. 19

52 hp psc 1310 series

technical information

notice to users in Japan (VCCI-2) notice to users in Korea declaration of conformity (European Union)

The Declaration of Conformity in this document complies with ISO/IEC Guide 22 and

EN45014. It identifies the product, manufacturer’s name and address, and applicable specifications recognized in the European community.

user guide 53

chapter 10

declaration of conformity

According to ISO/IEC Guide 22 and EN 45014

Manufacturer’s name and address:

Hewlett-Packard Company, 16399 West Bernardo Drive, San Diego, CA 92127-1899, USA

Regulatory model number:

SDGOB-0319

Declares that the product:

Product name: HP PSC 1310 Series (Q5763A)

Model number(s): PSC 1315 (Q5765A), 1315xi (Q5766A), 1315v (Q5767A),

1311 (Q5768A), 1312 (Q5769A), PSC 1317 (Q5770A), 1315 (Q5771A),

1318 (Q5772A)

Power adapters: 0950-4466

Conforms to the following product specifications:

Safety: IEC 60950:1999 3rd Edition

EN 60950:2000

UL1950/CSA22.2 No.950, 3rd Edition:1995

IEC 60825-1 Edition 1.2:2001 / EN 60825-1+A11+A2+A1: 2002

Class 1(Laser/Led)

EMC:

NOM 019-SFCI-1993, AZ / NZS 3260

GB4943: 2001

CISPR 22:1997 / EN 55022:1998, Class B

CISPR 24:1997 / EN 55024:1998

IEC 61000-3-2:1995 / EN 61000-3-2:1995

IEC 61000-3-3:1994 / EN 61000-3-3:1995

AS/NZS3548, CNS 13438: 1997, VCCI-2

FCC Part 15 - Class B/ICES-003, Issue 2

GB9254:1998

Supplementary Information:

The product herewith complies with the requirements of the Low Voltage Directive 73/23/EC, the EMC

Directive 89/336/EC and carries the CE marking accordingly.

The product was tested in a typical configuration.

European Contact for regulatory topics only: Hewlett Packard GmbH, HQ-TRE, Herrenberger Strasse

140, D-71034 Böblingen Germany. (FAX +49-7031-14-3143)

US Contact: Hewlett Packard Co. 16399 W. Bernardo Dr. San Diego, CA, USA 92127

54 hp psc 1310 series

11

hp instant share setup and use

HP Instant Share makes it easy to send photos that family and friends can view.

Just take a photo or scan an image, select the photograph or image, and use the software on your computer to forward the media to an e-mail destination. You can even upload your photos (depending on your country/region) to an online photo album, or an online photo finishing service.

With HP Instant Share, family and friends always get photos they can view—no more large downloads or images that are too big to open. An e-mail with thumbnail images of your photos is sent with a link to a secure Web page where your family and friends can easily view, share, print, and save your pictures.

Note:

Some operating systems do not support HP Instant Share, but you can still use your HP Director software to send a photo to family and friends as an e-mail attachment. (For more information, see

send a photo or image using your hp psc (Macintosh)

on page 57.)

This section contains the following topics:

use hp instant share in five easy steps (Windows)

on page 55

send a photo or image using your hp psc (Macintosh)

on page 57

why should I register with hp instant share (Windows)?

on page 58

use hp instant share in five easy steps (Windows)

HP Instant Share is easy to use with your HP PSC 1310 Series (HP psc)—simply:

1

Determine which photo on your Windows-based computer you want to send.

OR

Scan an image using your HP psc and send it to the HP Image Zone software.

2

From the

HP Image Zone

, select the photograph or image you want to send.

3

From the

HP Instant Share

tab, click

Start HP Instant Share

.

4

Create an e-mail destination within HP Instant Share.

Note:

You can also set up an Address Book to retain your e-mail addresses.

5

Send your e-mail message.

For specific information on how to use HP Instant Share, see the following procedures:

use a scanned image

on page 56

access hp instant share from the hp director

on page 56

Note:

Your computer must be connected to the Internet to use HP Instant

Share. If you are an AOL or Compuserve user, please connect to your

Internet service provider before attempting to use HP Instant Share.

55

chapter 11

use a scanned image

For information on scanning an image, see

use the scan features

on page 23.

1

Load your original face down in the left front corner of the glass.

2

Press

Scan

.

A preview image of the scan appears in the HP Scan window on the computer, where you can edit it.

For more information about editing a preview image, see the onscreen

hp image zone help

that came with your software.

3

Make any needed edits to the preview image in the

HP Scan

window.

When you have finished, click

Accept

.

The HP psc sends the scan to the HP Image Zone, which automatically opens and displays the image.

4

After you have edited the scanned image, select it.

Note:

The HP Image Zone has many editing tools that you can use to edit your image and achieve the results you want. For more information, see the onscreen

hp image zone help

that came with your software.

5

Click the

HP Instant Share

tab.

6

To use HP Instant Share, go to step 5 in

access hp instant share from the hp director

on page 56.

access hp instant share from the hp director

This section addresses how to use the HP Instant Share e-mail service. The terms photo and image are both referred to as image in this section. For more information on using the HP Director, see the onscreen

hp image zone help

that came with your software.

1

Open the

HP Director

.

2

From the

HP Director

, click

HP Image Zone

.

The HP Image Zone appears.

3

Select an image from the folder in which it is stored.

Note:

For more information, see the onscreen

hp image zone help

that came with your software.

4

Click the

HP Instant Share

tab.

5

In the

Control

area, click

Start HP Instant Share

.

The Go Online screen appears in the Work area.

6

Click

Next

.

The One-Time Setup—Region and Terms of Use screen appears.

7

Select your country/region from the drop-down list.

8

Read the

Terms of Service

, select the

I agree

check box, and click

Next

.

The Select an HP Instant Share Service screen appears.

9

Select

HP Instant Share E-mail

: send images through e-mail.

10

Click

Next

.

11

At the Create HP Instant Share E-Mail screen, complete the

To

,

From

,

Subject

, and

Message

fields.

56 hp psc 1310 series

hp instant share setup and use

Note:

To open and maintain an e-mail address book, click Address Book, register with HP Instant Share, and obtain a HP Passport.

Note:

To send your e-mail message to multiple addresses, click How to email multiple people.

12

Click

Next

.

The Add Captions screen appears.

13

Enter a caption for your digital image, and then click

Next

.

Your image is uploaded to the HP Instant Share services website.

After the image is uploaded, the Photos E-mailed screen appears.

Your e-mail is sent with a link to a secure Web page that stores your image for 60 days.

14

Click

Finish

.

The HP Instant Share website opens in your browser.

From the website, you can select an image, and choose from a number of processing options.

send a photo or image using your hp psc (Macintosh)

If your HP psc is connected to a Macintosh, you can send a photo or image to anyone with an e-mail account. You can initiate your e-mail message from an email application installed on your computer by pressing E-mail in the HP Gallery.

You open the HP Gallery from the HP Director.

This section contains the following topics:

use a scanned image

on page 57

access the e-mail option from the hp director

on page 58

use a scanned image

For information on scanning an image, see

use the scan features

on page 23.

1

Load your original face down in the left front corner of the glass.

2

Press

Scan

.

A preview image of the scan appears in the HP Scan window on the computer, where you can edit it.

For more information about editing a preview image, see the onscreen

hp image zone help

that came with your software.

3

Make any needed edits to the preview image in the

HP Scan

window.

When you have finished, click

Accept

.

The HP psc sends the scan to the HP Gallery, which automatically opens and displays the image.

4

After you have edited the scanned image, select it.

Note:

The HP Gallery has many editing tools that you can use to edit your image and achieve the results you want. For more information, see the onscreen

hp image zone help

that came with your software.

5

Click

E-mail

.

The e-mail program on your Macintosh opens.

user guide 57

chapter 11

You can now send the images as an e-mail attachment by following the prompts on your Macintosh.

access the e-mail option from the hp director

For more information on using the HP Director, see the onscreen

hp image zone help

that came with your software.

1

Open the

HP Director

and click

HP Gallery

(OS 9).

OR

Click

HP Director

in the Dock, and select

HP Gallery

from the

Manage and

Share

section of the

HP Director

menu (OS X).

The HP Gallery opens.

2

Select an image.

For more information, see the onscreen

hp image zone help

that came with your software.

3

Click

E-mail

.

The e-mail program on your Macintosh opens.

You can now send the images as an e-mail attachment by following the prompts on your Macintosh.

why should I register with hp instant share (Windows)?

With the HP PSC 1310 Series, HP Instant Share user registration is only required if you choose to use the Address Book. User registration is a separate log-on process from the HP product registration and is accomplished using the

HP Passport setup program.

If you choose to save e-mail addresses and create distribution lists in a HP Instant

Share Address Book, you will be prompted to register. Registration is required prior to configuring the Address Book and accessing the Address Book when addressing an HP Instant Share e-mail.

58 hp psc 1310 series

12

troubleshooting information

This section contains troubleshooting information for the HP PSC 1310 Series

(HP psc). Specific information is provided for installation and configuration issues. References to our online troubleshooting help are provided for operational topics.

This section contains the following:

installation troubleshooting

on page 59

operational troubleshooting

on page 65

installation troubleshooting

Installation and configuration troubleshooting tips are included in this section for some of the most common issues associated with HP psc software and hardware installation, and HP Instant Share.

This section contains the following topics:

hardware and software installation troubleshooting

on page 59

hp instant share setup troubleshooting

on page 65

hardware and software installation troubleshooting

If you encounter a software or hardware problem during installation, see the topics below for a possible solution.

During a normal installation of the HP psc software, the following things occur:

The HP psc CD-ROM runs automatically when the CD-ROM is inserted

The software installs

Files are copied to your hard drive

You are requested to plug in the HP psc

A green OK and check mark appear on an installation wizard screen

You are requested to restart your computer (might not occur in all cases)

The registration process runs

If any of these things do occur, there might be a problem with the installation. To check the installation on a PC, verify the following:

Start the director and check to make sure the following icons appear: scan picture, scan document, and hp image zone. For information about starting

HP Director, see

use your hp psc with a computer

on page 6. If the icons

do not appear immediately, you might need to wait a few minutes for the

HP psc to connect to your computer. Otherwise, see

Some of the icons are missing in the hp director

on page 62.

Open the Printers dialog box and check to see that the HP psc is listed.

Look at the task tray for an HP psc icon. This indicates that the HP psc is ready.

59

chapter 12

Task Tray

software installation troubleshooting

Use this section to solve any problems you might encounter while installing the

HP psc software.

problem

When I insert the CD-

ROM into my computer’s CD-ROM drive, nothing happens

possible cause and solution

follow these steps

1

From the Windows

Start

menu, choose

Run

.

2

In the Run dialog box, enter

d:\setup.exe

(if your CD-ROM drive is not assigned to drive letter d, use the appropriate drive letter), and then click

OK

.

The minimum system checks screen appears during installation

Your system does not meet the minimum requirements to install the software. Click

Details

to see what the specific problem is. Then correct the problem before attempting to install the software.

60 hp psc 1310 series

troubleshooting information

problem

A red X or yellow triangle appears on the USB connect prompt

possible cause and solution

do the following

1

Verify that the front panel cover is firmly adhered to the device, then unplug the HP psc and plug it in again.

For more information on how to attach the front panel cover, see

I received a message to attach the front panel cover

on page 64.

2

Verify that the USB and power cables are plugged in.

3

Verify that the USB cable is set up properly as follows:

Unplug the USB cable and plug it in again.

Do not attach the USB cable to a keyboard or non powered hub.

Verify that the USB cable is 3 meters or less in length.

If you have several USB devices attached to your computer, you might want to unplug the other devices during the installation.

4

Continue with the installation and reboot the computer when prompted. Then open director and check for the essential icons

(scan picture, scan document, and hp image zone [Windows] or hp gallery [Macintosh]).

If the essential icons do not appear, remove the software and then

reinstall it as described in

Some of the icons are missing in the hp director

on page 62.

I received a message that an unknown error has occurred

Try to continue with the installation. If that doesn’t work, stop and then restart the installation.

user guide 61

chapter 12

problem possible cause and solution

Some of the icons are missing in the hp director

If the essential icons do not appear, your installation might not be complete. The essential icons are scan picture, scan document, and hp image zone (Windows) or hp gallery (Macintosh).

If your installation is incomplete you might need to uninstall and then reinstall the software. Do

not simply delete the HP psc program files from your hard drive. Be sure to remove them properly using the uninstall utility provided in the HP psc program group.

to uninstall from a Windows computer

1

Disconnect your HP psc from your computer.

2

On the Windows task bar, click

Start

,

Programs

or

All Programs

(XP),

HP

,

PSC All-In-One 1310 series

,

Uninstall

.

3

Finally, make sure that the print driver is installed.

4

Follow the directions on the screen.

Note:

Make sure the HP PSC is disconnected from your computer before continuing with uninstall procedure.

5

If you are asked whether you would like to remove shared files, click

No

.

Other programs that use these files might not work properly if the files are deleted.

6

After the software is uninstalled, restart your computer.

7

To reinstall the software, insert the HP PSC 1310 Series CD-ROM into your computer’s CD-ROM drive, and follow the onscreen instructions.

8

After the software is installed, connect the HP PSC to your computer. Turn on the HP PSC by pressing the On/Resume button.

To continue with the installation, follow the onscreen instructions and the instructions provided in the Setup Poster that came with your HP PSC.

After connecting and turning on your HP psc, you might have to wait several minutes for all of the Plug and Play events to complete.

When the software installation is complete, you will see a Digital

Imaging Monitor icon in the task tray.

9

To verify that the software is properly installed, double-click the

HP Director icon on the desktop. If the HP Director shows the essential icons, the software has been properly installed.

62 hp psc 1310 series

troubleshooting information

problem possible cause and solution

Some of the icons are missing in the hp director

(continued)

to uninstall from a Macintosh computer

1

Disconnect the HP psc from your computer.

2

Double-click the

Applications:HP All-in-One Software

folder.

3

Double-click

HP Uninstaller

.

4

Follow the onscreen instructions.

5

After the software is uninstalled, disconnect your HP psc, and restart your computer.

6

To reinstall the software, insert the HP PSC 1310 Series CD-ROM into your computer’s CD-ROM drive.

Note:

When reinstalling the software, follow the instructions on the

Setup Poster. Do not connect the HP psc to your computer until after you have completed the software installation.

7

On the desktop, open the CD-ROM, double-click

hp all-in-one installer

, and follow the onscreen instructions.

The registration screen does not appear

Launch the Product Registration program in the HP folder on the

Windows

Start

menu. Click

Start

,

Programs

or

All Programs

(XP),

HP

,

PSC All-In-One 1310 series

,

Product Registration

.

The Digital Imaging

Monitor does not appear in the Task

Tray

If the Digital Imaging Monitor does not appear in the Task Tray, wait several minutes. If it still doesn’t appear, start the director to check

whether or not essential icons are there. For more information, see

Some of the icons are missing in the hp director

on page 62.

The Task Tray normally appears in the lower-right corner of the Windows desktop.

Task Tray

HP Digital

Imaging Monitor icon

The installation stops when the additional setup instruction screen appears, even though the USB cable is plugged in.

The front panel cover might not be properly attached.

follow these steps

1

Check the front panel for an error message about attaching the front panel cover.

2

If necessary, attach the front panel cover. For more information, see

I received a message to attach the front panel cover

on page 64.

3

Turn off the product and then turn it back on again.

user guide 63

chapter 12

hardware installation troubleshooting

Use this section to solve any problems you might encounter while installing the

HP psc hardware.

problem possible cause and solution

I received a message to attach the front panel cover

The front panel cover is not attached, or it is attached incorrectly.

to attach the front panel cover

1

Remove the adhesive backing from the front panel cover. step 1 step 2

My HP psc does not turn on

2

Raise the lid of the HP psc. Place the front panel cover into the recess and stick it into place.

Note:

The HP psc will not work until you attach the front panel cover.

Make sure each of the power cords is firmly connected, and wait a few seconds for the HP psc to turn on. Also, if the HP psc is plugged in to a power strip, make sure the strip is turned on.

64 hp psc 1310 series

problem

The USB port is not connected troubleshooting information

possible cause and solution

Connecting your computer to your HP psc with a USB cable is straightforward. Simply plug one end of the USB cable into the back of your computer and the other into the back of the HP psc. You can connect to any USB port on the back of your computer.

hp instant share setup troubleshooting

HP Instant Share setup errors (such as might occur when setting up the Address

Book) are covered in the HP Instant Share screen-specific help. Specific operational troubleshooting information is provided in

operational troubleshooting

on page 65.

operational troubleshooting

The

hp psc 1310 series

troubleshooting section in the

hp image zone help

contains troubleshooting tips for some of the most common issues associated with your HP psc. To access the troubleshooting information from a Windows computer, go to the HP Director, click Help, and then choose Troubleshooting and Support. Troubleshooting is also available through the Help button that appears on some error messages.

To access troubleshooting information from the Macintosh (OS X), click the

HP Director (All-in-One) icon in the Dock, select HP Help from the HP Director menu, select HP Image Zone Help, and then click hp psc 1310 series troubleshooting in the Help Viewer.

If you have Internet access, you can get help from the HP website at:

www.hp.com/support

The website also provides answers to frequently asked questions.

user guide 65

chapter 12

hp instant share troubleshooting

Basic HP Instant Share troubleshooting topics are covered in the table below.

When you access the HP Instant Share website, online help is provided for any error messages encountered.

error message

Can’t connect to the

Internet

HP Instant Share

Service temporarily unavailable

possible cause and solution

Your computer is unable to connect to the HP Instant Share server after the Go Online screen appears.

Check your Internet connection and make sure you are online.

If you are behind a firewall, verify that your browser proxy settings are correct.

The HP Instant Share server is currently down for maintenance.

Try connecting again later.

PictBridge port troubleshooting

The functionality of the PictBridge port is managed by the PictBridge-compliant camera you connect. Most solutions will be found in your camera user guide.

Here are some problems you might encounter using the PictBridge port.

problem possible cause and solution

You connect a camera and nothing happens

The camera is not PictBridge-compliant or is not in PictBridge mode.

Disconnect your camera and refer to your camera’s user guide to determine if it is PictBridge-compliant. If it is, the user guide should tell you how to set the camera in PictBridge mode. If your camera is not PictBridge-compliant, you may need to connect your camera directly to your computer in order to print photos.

The camera is not responding

The HP PSC still recognizes the presence of the camera, but the camera is not responding. Disconnect the camera. Turn off the camera, then turn it on again. Be sure it is in PictBridge mode.

Reconnect the camera.

Printing stopped in the middle of a photo

The camera lost power or was disconnected. Some cameras turn themselves off after a few minutes if not connected to a power source. Reconnect power to the camera and be sure it is in PictBridge mode. Restart printing.

A photo is corrupted or not supported

No photos are printing

You are trying to print an image from the camera that has become corrupted or is not a supported image type on the HP PSC. Check the image on the camera and refer to your camera’s user guide for supported image types. The HP PSC accepts photos in jpeg format.

Refer to your camera’s user guide to set the image type for your photos.

You may need to select photos on your camera before you can print them. Refer to your camera’s user guide and select the photos you want to print.

66 hp psc 1310 series

Index

Numerics

4 by 6 inch (10 by 15 cm)

borderless copies, 20

photo paper, 14

A

align print cartridges, 33

B

best copy quality, 20

borderless photos

copy, 20

C

camera, PictBridge

connect, 17 print, 17

cancel

copy, 22

scan, 24

cartridges, 28

align, 33

clean contacts, 35

handle, 29

ink level, 28

order, 25

replace, 30

store, 32

clean

exterior, 28

glass, 27 lid backing, 27

print cartridge contacts, 35

copy

black-and-white originals,

19

borderless photos, 20

color originals, 19

enlarge, 21

number of copies, 20 photos, 20

photos onto letter paper, 21

quality, 20

reduce, 21

speed, 20

customer support, 37

Australia, 41

Eastern Europe, Middle East and Africa, 39

Japan, 38

Korea, 38

North America, 38

outside U.S., 39

web site, 37

Western Europe, 38

D

Digital Imaging Monitor icon,

63

E

enlarge copies, 21

envelopes

load, 14

environment

energy consumption, 50 environmental product stewardship program, 50

inkjet supplies recycling, 51 material safety data sheets,

51

ozone production, 50

paper use, 51 plastics, 51

protecting, 50

recycling program, 51

essential icons, 61, 62, 63

F

fast copy quality, 20

fit to page, 21

front panel

overview, 1

status lights, 3

G

glass cleaning, 27

greeting cards, load, 15

H

Hagaki cards, 14

help, vii

HP customer support, 37

HP Director

e-mail option (Macintosh),

58

HP Instant Share access

(Windows), 56

use your hp psc with a computer, 6

HP distribution center, 43

HP Instant Share

Address Book, 58

overview, 55 simplified approach, 55

use a scanned image, 56

HP Instant Share (Windows)

setup troubleshooting, 65

use troubleshooting, 66

I

ink cartridges, 28 ink level, 28

L

labels

load, 15

lid backing, clean, 27

lights, status, 3

load

A4 paper, 12

avoid paper jams, 16

envelopes, 14

greeting cards, 15

Hagaki cards, 14

HP Premium Paper, 15 labels, 15

letter paper, 12

originals, 11

postcards, 14

recommended papers, 15

M

maintenance

align print cartridges, 33

clean glass, 27

clean the exterior, 28

clean the lid backing, 27

ink level, 28

replace print cartridges, 30

self-test report, 29

sounds, 36

N

number of copies

copy, 20

67

Index

O

order

media, 25 other supplies, 25 print cartridges, 25

P

paper

load, 11

order, 25

recommended types, 15 set type, 15

phone numbers, customer support, 37

photos

borderless copies, 20

PictBridge

connect a camera, 17 print from a camera, 17

postcards, 14

print

from a camera, 17

self-test report, 29

print cartridges, 28

align, 33

clean contacts, 35

correct one for job, 32

handle, 29

ink level, 28

order, 25

protector, 32

replace, 30

store, 32 protector, print cartridge, 32

Q

quality

copies, 20

R

reduce copies, 21

regulatory notices, 51

Australian statement, 52

declaration of conformity

(European Union), 53

declaration of conformity

(U.S.), 54

FCC statement, 52 geräuschemission, 52

Korean statement, 53

notice to users in Canada,

52

regulatory model identification number, 51

VCCI-2 (Japan), 53

replace print cartridges, 30

report, self-test, 29

return your HP PSC, 41

S

scan

cancel, 24

from the front panel, 23

self-test report, 29

send a photo

Macintosh, 57 use a scanned image, 57

ship your HP PSC, 41

size

copies, 21

software

use your hp psc with a computer, 6

sounds from the HP PSC, 36

speed

copy, 20

status lights, 3

stop

copy, 22

scan, 24

support, 37

T

technical information

copy specifications, 50 environmental specifications, 50

paper specifications, 49

photo memory card specifications, 50 physical specifications, 50 power specifications, 50

print margin specifications,

49

telephone numbers, customer support, 37

troubleshooting

essential icons, 61, 62, 63

hardware and software installation, 59

hardware installation, 64

HP Instant Share

(Windows), 65, 66

installation, 59

operations, 65

software installation, 60

U

USB cable installation, 65

W

warranty

duration, 45 service, 45

statement, 46

upgrades, 45

68 hp psc 1310 series

Visit the hp psc information center

It has everything you need to get the most value from your HP psc.

Technical Support

Supplies and Ordering Information

Project Tips

Ways to Enhance Your Product www.hp.com/support

© Copyright 2004 Hewlett-Packard Development Company, L.P.

Printed on recycled paper.

Printed in [country].

*Q5763-90152*

*Q5763-90152*

Q5763-90152

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
