Quick Start Guide

UD.6L0202B1941A01

Quick Start Guide of iVMS-4200

Quick Start Guide

COPYRIGHT © 2015 Hangzhou Hikvision Digital Technology Co., Ltd.

ALL RIGHTS RESERVED.

Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be

“Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.

About this Manual

This Manual is applicable to iVMS-4200 Client Software.

The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the company website

(

http://overseas.hikvision.com/en/

).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS

HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,

MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND

NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS,

EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR

1

Quick Start Guide of iVMS-4200

INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,

BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE

OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT

YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS

INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY

TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH

ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER

PREVAILS.

2

Quick Start Guide of iVMS-4200

1. Overview

This guide provides only brief instructions on the installation, uninstallation, and some basic operations such as the live view, record and playback of devices via iVMS-4200. For detailed information of how to use the software, please refer to the User Manual of iVMS-4200.

2. System Requirements

Operating System: Microsoft Windows XP /Windows 2003 (32-bit), Windows 7 / Windows 8 /

Windows 8.1 / Windows Server 2008 (32-bit or 64-bit), Windows Server 2008 R2 / Windows Server

2012 (64-bit)

CPU: Intel Pentium IV 3.0 GHz or above

Memory: 1G or above

Video Card: RADEON X700 Series or above

GPU: 256 MB or above

Note:

For high stability and good performance, these above system requirements must be met.

3. Deployment Schemes

iVMS-4200 can be used in the local area network (LAN) and the wide area network (WAN). In this document, only some of the connection deployment schemes are displayed.

Note:

In the real situation, the devices connected, such as the DVRs, NVRs, network cameras, etc., are scalable.

3

Quick Start Guide of iVMS-4200

3.1 In the Local Area Network

3.1.1 A Simplified Scheme in LAN

Application Scenario:

1. Only one or small quantities of clients need to get video stream from the devices.

2. The client and devices are in the same local subnet.

Hardware Required:

1. Network cameras, DVRs, etc.

2. PC installed with iVMS-4200 client.

3. Switch or router.

This deployment scheme is convenient and cost-effective. Only the iVMS-4200 client software is required and you can get direct access to the connected devices, such as the network cameras, DVRs, etc.

4

Quick Start Guide of iVMS-4200

3.1.2 A Complete Scheme in LAN

Application Scenario:

1. Multiple clients need to get video stream from the devices.

2. There is no hard disk on the device side or there are disks on the device side, but the record files need to be backed up for extra insurance.

Hardware Required:

1. Network cameras, DVRs, etc.

2. PCs installed with iVMS-4200 client, iVMS-4200 PCNVR, Stream Media Server and Storage Server.

3. Switch or router.

The DVR, HDVR, NVR, iVMS-4200 PCNVR can connect to and manage the cameras, speed domes, video encoders, etc., and the iVMS-4200 client can be used to manage the DVR, HDVR, NVR, PCNVR which provide relatively complete function of the management.

The stream media server can be adopted to forward the video stream so as to lower the network load of the devices. The record files can be stored on the HDDs of the local device, or on the remote storage server. You can also access the client through the web browsing and do some basic operations, including live view, playback, etc.

5

Quick Start Guide of iVMS-4200

3.2 In the Wide Area Network

3.2.1 Static IP in WAN

Application Scenario:

1. The devices need to be accessed in WAN.

2. Static IP addresses are assigned to the connected devices in WAN.

Hardware Required:

1. Network cameras, DVRs, etc.

2. PCs installed with iVMS-4200 client, iVMS-4200 PCNVR, Stream Media Server and Storage Server.

3. Switch or router.

Static IP address is assigned to the device in WAN and the iVMS-4200 client can access the device directly through the static IP address. It is costly when there are multiple devices connected.

You can adopt the router to connect to the Internet, assign the static IP address to the router, and then get access to the devices through the router static IP address and port No..

6

3.2.2 Dynamic IP in WAN

Quick Start Guide of iVMS-4200

Application Scenario:

1. The devices need to be accessed in WAN.

2. The devices can be accessed through device domain names (registered on DNS Server) in WAN.

Hardware Required:

1. Network cameras, DVRs, etc.

2. PCs installed with iVMS-4200 client, iVMS-4200 PCNVR, Stream Media Server and Storage Server.

3. Switch or router.

You can register domain names for the devices on the DNS server, such as Peanuthull, DynDNS,

HiDDNS, etc., and then get access to the devices through the device domain names.

When there are multiple devices connected to the Internet via the router, you can configure domain name on the router, and then get access to the devices through the router domain name and port No., thus to reduce the cost of the domain name.

4. Installation and Uninstallation

4.1 Installation

Insert the installation media into the appropriate computer.

Perform the following steps to install the iVMS-4200 client software.

1. Double-click the program file to enter the welcome panel of the InstallShield Wizard. Click

Next to start the InstallShield Wizard.

7

Quick Start Guide of iVMS-4200

2. Read the License Agreement. Click Print if you want to print the license agreement.

If you accept the terms of the license agreement, click I accept the terms of license agreement.

Click Next to continue.

Otherwise click I do not accept the terms of the license agreement, and then click Cancel to cancel the installation

3. On the next panel, you are prompted to select the function module to install.

8

Quick Start Guide of iVMS-4200

Storage Server: The storage server performs as a NVR installed on the PC and the record files can be stored on the storage server.

Stream Media Server: The video stream can be forwarded through the stream media server, thus to lower the network load of the device.

Set installation directory where the client software is to be installed. You can either accept the default directory that is displayed, or click Browse and select a different directory.

You can also click Disk Space to choose the disk drive to install the software, and check the space information of the disk on the panel.

Note:

The default directory is C:\Program Files\iVMS-4200 Station\iVMS-4200.

Click Next to continue.

4. Read the pre-install information and click Install to begin the installation.

5. A panel indicating progress of the installation is displayed. A percentage completion bar is updated as the installation progresses.

9

Quick Start Guide of iVMS-4200

6. Select the setup type according to your need.

You can check the checkbox Create Desktop for Client to create a shortcut icon on the desktop for the client software.

7. Read the post-install information and click Finish.

10

Quick Start Guide of iVMS-4200

4.2 Uninstallation

Double-click the program file again, select Remove, click Next and click Yes to uninstall the iVMS-4200 according to the prompts.

11

Quick Start Guide of iVMS-4200

5. Quick Start

5.1 User Registration and Login

For the first time to use iVMS-4200 client software, you need to register a super user for login.

Steps:

1. Input the super user name and password.

2. Confirm the password.

3. Optionally, check the checkbox Enable Auto-login to log in the software automatically.

4. Click Register. Then, you can log in the software as the super user.

A user name cannot contain any of the following characters: / \ : * ? “ < > |. And the length of

the password cannot be less than 6 characters.

For your privacy, we strongly recommend changing the password to something of your own

choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

When opening iVMS-4200 after registration, you can log in the client software with the registered user name and password.

Steps:

1. Input the user name and password you registered.

Note:

If you forget your password, please click Forgot Password and remember the encrypted string in the pop-up window. Contact your distributor or our technical support and send the encrypted string to him to reset your password.

2. Optionally, check the checkbox Enable Auto-login to log in the software automatically.

3. Click Login.

12

Quick Start Guide of iVMS-4200

5.2 Start Wizard

5.2.1 Wizard for Importing Device

The start wizard will pop up to guide you to go through the basic operations of the client software if you have not gone through it completely, such as adding devices, importing devices into groups, configuring record schedule, etc.

Perform the following steps to go through the wizard and study the operations provided.

Step 1: Start Guide

Click Device and Record Configuration to start the guide.

You can also click Close to exit the wizard.

Step 2: Adding Devices

Devices such as network cameras, encoders, decoders, DVRs, NVRs, should be added to the client for the remote configuration and management, such as live view, playback, alarm settings, video wall settings, etc.

13

Quick Start Guide of iVMS-4200

You can select adding encoding device or decoding device.

Encoding device includes DVR, encoder, NVR, IP camera, IP dome, iVMS-4200 PCNVR and iVMS-4200 encoding server, etc.

Decoding device includes decoder and iVMS-4200 decoding server.

You can add the device in the following ways:

 Adding Online Devices

 Adding Devices by IP Address/Domain

 Adding Devices by IP Segment

 Adding Devices by IP Server

 Adding Devices by HiDDNS

 Batch Adding Devices

Creating the Password

Purpose:

For some devices, you are required to create the password to activate them before they can be added to the software and work properly.

Note:

This function should be supported by the device.

Steps:

1. Enter the Device Management page.

2. On the Device for Management or Online Device area, check the device status (shown on

Security column) and select an inactive device.

14

Quick Start Guide of iVMS-4200

3. Click the Activate button to pop up the Activation interface.

4. Create a password in the password field, and confirm the password.

STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

5.

6.

7.

8.

Click OK to create the password for the device. A “The device is activated.” window pops up when the password is set successfully.

Click Modify Netinfo to pop up the Modify Network Parameter interface.

Note:

This function is only available on the

Online Device area. You can change the device IP address to the same subnet with your computer if you need to add the device to the software.

Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of DHCP.

Input the password set in step 4 and click OK to complete the network settings.

15

Quick Start Guide of iVMS-4200

Adding Online Devices

The active online devices in the same local subnet with the client software will be displayed on the

Online Device area. You can click the Refresh Every 15s button to refresh the information of the online devices.

Add One Online Device

Steps:

1. Select the devices to be added from the list.

Note:

For the inactive device, you need to create the password for it before you can add the device properly. For detailed steps, please refer to Section Creating the Password.

2. Click Add to Client to open the device adding dialog box.

3. Input the required information.

Nickname: Edit a name for the device as you want.

Address: Input the device’s IP address. The IP address of the device is obtained automatically in this adding mode.

Port: Input the device port No.. The default value is 8000.

User Name: Input the device user name. By default, the user name is admin.

Password: Input the device password.

The password strength of the device can be checked by the software. For your privacy, we strongly recommend changing the password to something of your own choosing

(using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

4. Optionally, you can check the checkbox Export to Group to create a group by the device name. All the cameras under the device will be imported to the corresponding group by default.

5. Click Add to add the device.

Note:

If you want to add an offline device, you can check the checkbox Add Offline Device and

16

Quick Start Guide of iVMS-4200 enter the number of cameras and alarm inputs of the device.

Add Multiple Online Devices

If you want to add multiple online devices to the client software, click and hold Ctrl key to select multiple devices, and click Add to Client to open the device adding dialog box. In the pop-up message box, enter the user name and password for the devices to be added.

Add All the Online Devices

If you want to add all the online devices to the client software, click Add All and click OK in the pop-up message box. Then enter the user name and password for the devices to be added.

Modify Network Information

Select the device from the list, click Modify Netinfo, edit the network parameters of the device, e.g.,

DHCP, IP address, port No. and gateway, input the admin password of the device and click OK to save the settings.

Reset Password

According to the different devices, the software provides three different methods for restoring the default password or resetting the password.

Select the device from the list, click Reset Password.

Option 1:

If the window with security code field pops up, input the security code, and then you can restore the default password of the selected device.

Note:

The security code is returned after you send the data and serial No. of the device to the manufacturer.

Option 2:

If the window with import file and export file buttons pops up, perform the following steps to restore the default password:

1. Click Export to save the device file on your PC.

2. Send the file to our technical engineers.

3. Click Import and select the file received from the technical engineer.

4. Click OK to restore the default password of the device.

17

Quick Start Guide of iVMS-4200

The default password (12345) for the Admin account is for first-time log-in purposes only. You

must change this default password to better protect against security risks, such as the unauthorized access by others to the product that may prevent the product from functioning properly and/or lead to other undesirable consequences.

For your privacy, we strongly recommend changing the password to something of your own

choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

Option 3:

If the window with import file and export file buttons, password and confirm password field pops up, follow the steps below to reset the password:

1. Click Export to save the device file on your PC.

2. Send the file to our technical engineers.

3. Click Import and select the file received from the technical engineer.

4. Input new password in text fields of Password and Confirm Password.

5. Click OK to reset the password.

The password strength of the device can be checked by the software. For your privacy, we strongly recommend changing the password to something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

For details of other device adding methods, please refer to the User Manual of iVMS-4200.

Click Next to continue. You can also click Home Page to return to the home page of the wizard, or click

Finish to exit.

Step 3: Importing Devices into Groups

The added devices need to be organized into groups for a convenient management. You can get the live view, play back the record files, and do some other operations of the devices through the group.

18

Quick Start Guide of iVMS-4200

Steps:

1. Click to open the Add Group dialog box, input a group name as you want and click OK.

2. Click Import on right panel, and then click the Encoding Channel tab to open the Import Encoding

Channel interface.

3. Select the thumbnails/names of the cameras in the thumbnail/list view.

4. Select a group from the group list.

5. Click Import to import the selected cameras to the group.

You can also click Import All to import all the cameras to the selected group.

6. Click to back to the group management interface.

Note:

Up to 64 cameras can be added to one group.

The following buttons are available on the Import Encoding Channel interface:

List View

View the camera in list view.

Thumbnail View

View the camera in thumbnail view.

Refresh

Refresh the latest information of added cameras.

Import

Create a group named as device name-Encoding Channel

19

Quick Start Guide of iVMS-4200

(Alarm Input) and import the device to group.

Collapse/Expand Collapse/Expand the thumbnails of cameras.

Click Next to continue.

Step 4: Configuring the Record Schedule

The video files can be recorded on the HDDs, Net HDDs, SD/SDHC cards on the local device, or the storage server connected.

Steps:

1. Select the camera from the Camera Group list.

2. Check the checkbox Record Schedule to enable device local recording.

3. Select the record schedule template from the drop-down list.

4. Click Advanced Settings to set the recording parameters.

5. Optionally, click Copy to… to copy the record schedule settings to other cameras.

6. Click Save to save the settings.

Step 5: Wizard Finished

The wizard is complete. Click Finish to close the wizard.

5.2.2 Wizard for Video Wall

The iVMS-4200 software provides video wall wizard to guide you to go through the basic operations of video wall settings, such as adding decoding devices, linking output with video wall, etc.

20

Quick Start Guide of iVMS-4200

Perform the following steps to go through the wizard and configure the video wall.

Step 1: Edit Video Wall

Click Help in the menu bar and select Open Video Wall Wizard to open it.

The software provides a default video wall view which is 3X3.

You can right-click the Default Video Wall tab and select Modify Video Wall to modify the view as desired.

In the pop-up dialog box, edit the name, row number, column number and proportion for the video wall. Click Modify to save the settings and back to the video wall settings wizard.

In the video wall settings wizard, click Next to continue.

Step 2: Add Decoding Resource, Link Decoding Resource with Video Wall

Steps:

1. Click in the Decoding Output panel and the adding decoding device dialog box pops up.

2. Select the device type, adding mode, and edit the corresponding information.

 For decoder, 2 adding modes are selectable.

21

Quick Start Guide of iVMS-4200

IP/Domain: Add the device by IP address or Domain name. You need to enter the nickname,

IP address or domain name, port No., user name and password of the device.

IP Segment: Add the devices whose IP addresses are among the IP segment. You need to enter the start IP address, end IP address, port No., user name and password of the devices.

 For cascading server, you can add the device by IP address. Enter the nickname, IP address, port No., user name and password of the device.

3. Click Add to add the device.

4. In the decoding output area, drag a decoding output or the device to the video wall view to link them.

Note:

The decoding output can only be related to one monitor.

Click Done to finish the wizard.

5.3 Control Panel

iVMS-4200 provides user-friendly GUI for the convenient and effective operation of the software. The main control panel of the software is shown below:

22

Quick Start Guide of iVMS-4200

Menu Bar:

File

System

View

Tool

Open Captured picture

Open Video File

Open Log File

Exit

Lock

Search and view the captured pictures stored on local PC.

Search and view the video files recorded on local PC.

View the backup log files.

Exit the iVMS-4200 client software.

Lock screen operations. Log in the client again to unlock.

Switch User

Switch the login user.

Import System Config File

Import client configuration file from your computer.

Export System Config File

Export client configuration file to your computer.

1024*768

1280*1024

1440*900

1680*1050

Display the window at size of 1024*768 pixels.

Display the window at size of 1280*1024 pixels.

Display the window at size of 1440*900 pixels.

Display the window at size of 1680*1050 pixels.

Maximize

Control Panel

Main View

Remote Playback

Display the window in maximum mode.

Enter Control Panel interface.

Open Main View page.

Open Remote Playback page.

E-map

Open E-map page.

Auxiliary Screen Preview

Open Auxiliary Screen Preview window.

Device Management

Event Management

Storage Schedule

Open the Device Management page.

Open the Event Management page.

Open the Storage Schedule page.

Account Management

Log Search

System Configuration

Open the Account Management page.

Open the Log Search page.

Open the System Configuration page.

23

Quick Start Guide of iVMS-4200

Help

Broadcast

Device Arming Control

I/O Control

Batch Wiper Control

Batch Time Sync

Player

Message Queue

Open Wizard

Open Video Wall Wizard

User Manual (F1)

About

Language

Select camera to start broadcasting.

Set the arming status of devices.

Turn on/off the alarm output.

Batch starting or stopping the wipers of the devices.

Batch time synchronization of the devices.

Open the player to play the video files.

Display the information of Email message to be sent.

Open the guide for the client configuration.

Open the guide for the video wall configuration.

Click to open the User Manual; you can also open the User

Manual by pressing F1 on your keyboard.

View the basic information of the client software.

Select the language for the client software and reboot the software to activate the settings.

The iVMS-4200 client software is composed of the following function modules:

The Main View module provides live view of network cameras and video encoders, and supports some basic operations, such as picture capturing, recording, PTZ control, etc.

The Remote Playback module provides the search, playback, export of record files.

The Video Wall module provides the management of decoding device and video wall and the function of displaying the decoded video on video wall.

The E-map module provides the displaying and management of E-maps, alarm inputs, hot regions and hot spots.

The Device Management module provides the adding, modifying and deleting of different devices and the devices can be imported into groups for management.

The Event Management module provides the settings of arming schedule, alarm linkage actions and other parameters for different events.

The Storage Schedule module provides the schedule settings for recording and pictures.

The Account Management module provides the adding, modifying and deleting of user accounts and different permissions can be assigned for different users.

The Log Search module provides the query of system log files and the log files can be filtered by different types.

The System Configuration module provides the configuration of general parameters, file saving paths, alarm sounds and other system settings.

The Heat Map module provides the display of the heat map statistics.

The People Counting module provides the display of the people counting statistics.

The Counting module provides the display of the counting statistics.

The Road Traffic module provides the display of the road traffic data.

24

Quick Start Guide of iVMS-4200

VCA Search for Picture module provides the query of the picture of face, license plate number and behavior analysis.

Note:

The Video Wall module only displays when Decoding Device is enabled for adding to the client.

The function modules are easily accessed by clicking the navigation buttons on the control panel or by selecting the function module from the View or Tool menu.

You can check the information, including current user, network usage, CPU usage, memory usage and time, in the upper-right corner of the main page.

5.4 Live View

Purpose:

You can view the live video of the added cameras on the Main View page. And some basic operations are supported, including picture capturing, manual recording, PTZ control, etc.

Before you start:

A camera group is required to be defined for live view.

Click the icon on the control panel, or click View->Main View to open the Main View page.

Main View Page

1 View List

2 Camera List

3 PTZ Control Panel

4 Display Window of Live View

5 Live View Toolbar

Live View Toolbar:

25

Quick Start Guide of iVMS-4200

On the Main View page, the following toolbar buttons are available:

Save View

Save the new settings for the current view.

Save View as

Save the current view as another new view.

Stop Live View

Mute/Audio On

Stop the live view of all cameras.

Turn off/on the audio in live view

Resume/Pause

Auto-switch

Click to resume/pause the auto-switch in live view.

Show/Hide the configuration menu of auto-switch. Click again to

Show /Hide the Menu

hide.

Previous

Go for live view of the previous page.

Next

Window Division

Go for live view of the next page.

Set the window division.

Full Screen

Display the live view in full-screen mode. Press ESC to exit.

Starting Live View for One Camera

Steps:

1. Open the Main View page.

2. Optionally, click the icon in live view toolbar to select the window division mode for live view.

3. Click-and-drag the camera to the display window, or double-click the camera name after selecting the display window to start the live view.

Note:

You can click-and-drag the video of the camera in live view to another display window if needed.

Starting Live View for Camera Group

Steps:

1. Open the Main View page.

2. Click-and-drag the group to the display window, or double-click the group name to start the live view.

Note:

The display window number is self-adaptive to the camera number of the group.

Starting Live View in Default View Mode

Purpose:

The video of the added cameras can be displayed in different view modes. 4 frequently-used default view modes are selectable: 1-Screen, 4-Screen, 9-Screen and 16-Screen.

Steps:

1. Open the Main View page.

2. Click the icon to expand the default view list.

3. Click to select the default view mode, and the video of the added cameras will be displayed in a sequence in the selected view.

Note:

Click , and you can save the default view as a custom view.

Starting Live View in Custom View Mode

Purpose:

The view mode can also be customized for the video live view.

26

Quick Start Guide of iVMS-4200

Steps:

1. Open the Main View page.

2. Click the icon to expand the custom view list.

3. Click to create a new view.

4. Input the view name and click Add. The new view is of 4-Screen mode by default.

Optionally, click the icon in live view toolbar and select the screen layout mode for the new view.

5. Click-and-drag the camera/group to the display window, or double-click the camera/group name in custom view mode to start the live view.

6. Click the icon to save the new view.

Stopping the Live View

Steps:

1. Select the display window.

2. Click the icon that appears in the upper-right corner when the mouse pointer is over the display window, or click Stop Live View on the right-click menu to stop the live view of the display window.

You can also click the button in live view toolbar to stop all the live view.

5.5 Recording

Purpose:

Some local devices, including the DVRs, NVRs, and Network Cameras, provide storage devices such as the HDDs, Net HDDs and SD/SDHC cards for record files.

Before you start:

The newly installed storage devices need to be formatted. In the Device Management page, enter the remote configuration interface of the device, click Storage->General, select the HDD or SD/SDHC card, and click Format to initialize the selected storage device.

Click the icon on the control panel, or click Tool->Record Schedule to open the Record Schedule page.

27

Quick Start Guide of iVMS-4200

Steps:

1. Open the Record Schedule page.

2. Select the camera from the Camera Group list.

3. Check the checkbox Record Schedule to enable device local recording.

4. Select the record schedule template from the drop-down list.

All-day Template: for all-day continuous recording.

Weekday Template: for working-hours continuous recording from 8:00 AM to 8:00 PM.

Event Template: for the event triggered recording.

Template 01-08: fixed templates for specific schedules. You can edit the templates if needed.

Custom: can be customized as desired.

If you need to edit or customize the template, see Configuring Record Schedule Template.

5. Click Advanced Settings to set the recording parameters.

6. Optionally, click Copy to… to copy the record schedule settings to other cameras.

7. Click Save to save the settings.

Parameters

Pre-record

Descriptions

Normally used for the event triggered record, when you want to record before the event happens

After the event finished, the video can also be recorded for a certain time.

Post-record

Keep Record Files for

The time for keeping the record files in the storage device, once exceeded, the files will be deleted. The files will be saved permanently if the value is set as 0.

Redundant Record

Save the video files not only in the R/W HDD but also in the redundant HDD.

Record Audio

Record the video files with audio or not.

Video Stream

Select the stream type for the recording.

Configuring Record Schedule Template

Perform the following steps to configure the record schedule template:

If Template 01-08 is selected from the drop-down list, start from step 1;

If Custom is selected from the drop-down list, start from step 2.

1. Click Edit to enter the Templates Management interface. Select the template to be set and you can edit the template name.

2. Set the time schedule for the selected template.

refer to normal schedule record. The schedule time bar is marked with .

28

Quick Start Guide of iVMS-4200 marked with

refers to the schedule record triggered by the event. The schedule time bar is

.

refers to the schedule record triggered by command. The schedule time bar is marked with .

Note:

Record triggered by command is only available for the ATM transactions when the ATM DVR is added to iVMS-4200.

When the cursor turns to , you can set the time period.

When the cursor turns to , you can move the selected time bar you just edited. You can also edit the displayed time point to set the accurate time period.

When the cursor turns to , you can lengthen or shorten the selected time bar.

3. Optionally, you can select the schedule time bar, and then click the icon to delete the selected time bar, or click the icon to delete all the time bars, or click the icon to copy the time bar settings to the other dates.

4. Click OK to save the settings.

You can click Save as Schedule Template on the Custom Schedule interface, and then the custom template can be saved as template 01--08.

Note:

Up to 8 time periods can be set for each day in the record schedule.

5.6 Playback

Purpose:

The record files stored on the local device or the storage server can be searched by camera or triggering event, and then can be played back remotely.

Click the icon on the control panel, or click View->Remote Playback to open the Remote Playback page.

29

Quick Start Guide of iVMS-4200

Remote Playback Page

1 Camera List

2 Display Window of Playback

3 Playback Control Buttons

4 Timeline

5 Calendars

6 Search Condition

5.6.1 Normal Playback

Purpose:

The record files can be searched by camera or group name for the Normal Playback.

Searching Record Files for Normal Playback

Steps:

1. Open the Remote Playback page.

2. Click-and-drag the camera or group to the display window, or double-click the camera or group to start the playback.

3. The found record files of the selected group or camera will be displayed on the right of the interface. You can filter the results through the Filter text field.

4. (Optional) Click the calendars icon

Select the date and set the accurate time.

to activate the calendars dialog box.

Click OK and the record files of the 7 days near to the configured date will be searched and displayed.

Note:

Up to 16 cameras can be searched simultaneously.

30

Quick Start Guide of iVMS-4200

Playing Back Record Files

After searching the record files for the normal playback, you can play back the record files in the following two ways:

Playback by File List

Select the record file from the search result list, and then click the icon on the record file, or double-click the record file to play the video on the display window of playback.

You can also select a display window and click the icon in the toolbar to play back the corresponding record file.

Playback by Timeline

The timeline indicates the time duration for the record file, and the record files of different types are color coded. Click on the timeline to play back the video of the specific time.

You can click or to scale up or scale down the timeline bar.

You can drag the timeline bar to go to the previous or the next time period.

You can use the mouse wheel to zoom in or zoom out on the timeline.

Normal Playback Toolbar:

31

Quick Start Guide of iVMS-4200

On the Normal Playback page, the following toolbar buttons are available:

Reverse Playback

Play back the record file reversely.

Pause/Start

Pause/Start the playback of the record files.

Playback

Stop Playback

Stop the playback of all cameras.

Single Frame

(Reverse)

Single Frame

Play back the record files frame by frame reversely.

Play back the record files frame by frame.

Slow Forward / Fast

Forward

Volume

Decrease / Increase the play speed of the playback.

Event Playback

Click to turn on/off the audio and adjust the audio volume.

Search the recordings triggered by event, such as motion detection, video loss or video tampering.

ATM Playback

VCA Playback

Window Division

Full Screen

Async/Sync

Playback

Download

Search the recordings of ATM devices.

Set the VCA rule to the searched record files that VCA event occurs, including VCA Search, Intrusion and Line Crossing.

Set the window division.

Display the video playback in full-screen mode. Press ESC to exit.

Click to play back the record files synchronously/asynchronously.

Download the record files of the camera and the record files are stored in the PC. You can select to download by file or by date.

Add default tag for the video file to mark the important

Tag

Filter

Date

video point. You can edit the tag or go to the tag position via the right-click menu.

Display the record types as desired. E.g., you can select to display only the event recording.

The day that has record files will be marked with .

5.6.2 Event Playback

Purpose:

The recordings triggered by event, such as motion detection, VCA detection or behavior analysis, can be searched for Event Playback and this function requires the support of the connected device.

Searching Record Files for Event Playback

Steps:

32

Quick Start Guide of iVMS-4200

1. Open the Remote Playback page.

2. Select the camera and start the normal playback. Refer to Chapter 5.6.1 Normal Playback.

3. Click and the motion detection triggered recording will be search by default.

4. Select the event type from the drop-down list and the found record files will be displayed. You can filter the results through the Filter text field. Or you can click to go back to the normal playback.

5. (Optional) Click the calendars icon to activate the calendars dialog box.

Select the date and set the accurate time. Click OK and the record files of the 7 days near to the configured date will be searched and displayed.

6. Select the record file from the search result list, and then click the icon on the record file, or double-click the record file to play the video on the corresponding display window of playback.

Playing Back Record Files

After searching the recordings triggered by the event, you can play back the record files in the following two ways:

Playback by File List

Select the record file from the search result list, and then click the icon in the toolbar, or click the icon on the record file, or double-click the record file to play the video on the corresponding display window of playback.

Playback by Timeline

The timeline indicates the time duration for the record file. Click on the timeline to play back the video of the specific time.

You can click or to zoom in or zoom out the timeline bar.

You can drag the timeline bar to go to the previous or the next time period.

You can use the mouse wheel to zoom in or zoom out on the timeline.

Please refer to Chapter 5.6.1 Normal Playback for the description of the playback control toolbar.

Some icons may not available for event playback.

5.6.3 Synchronous Playback

Purpose:

In synchronous playback, the record files can be played back in synchronization.

Note:

Record files from up to 16 cameras can be played back simultaneously.

Steps:

1. Search the record files for the normal playback. At least two cameras are during playback.

2. Click in the toolbar to enable the synchronous playback. The camera under playback will start synchronous playback.

3. To disable the synchronous playback, click the icon .

33

Quick Start Guide of iVMS-4200

5.7 E-map

Purpose:

The E-map function gives a visual overview of the locations and distributions of the installed cameras and alarm input devices. You can get the live view of the cameras on the map, and you will get a notification message from the map when alarm is triggered.

Click the icon on the control panel, or click View->E-map to open the E-map page.

E-map Page

1 Group List

2 Map Display Area

3 E-map Toolbar

34

Quick Start Guide of iVMS-4200

5.7.1 Adding an E-map

Purpose:

An E-map needs to be added as the parent map for the hot spots and hot regions.

Steps:

1. Open the E-map page.

2. Select a group for which you want to add a map.

3. Click the icon in the Map Display Area to open the map adding dialog box.

4. Input a descriptive name of the added map as desired.

5. Click the icon and select a map file from the local path.

6. Click OK to save the settings.

Notes:

 The picture format of the map can only be *.png, *.jpg or *.bmp.

 Only one map can be added to a group.

The map added is displayed in the Map Display Area. Use the mouse wheel or click or , to zoom in or zoom out on the map. You can click-and-drag the yellow window in the lower-right corner or use the direction buttons and zoom bar to adjust the map area for view.

Click the button Edit Map or Map Preview in the E-map toolbar to enter the map editing mode or map preview mode.

35

Quick Start Guide of iVMS-4200

E-map Toolbar in Map Editing Mode:

E-map Toolbar in Map Preview Mode:

On the E-map page, the following toolbar buttons are available:

Modify Map

Modify the map information, including the map name and file path.

Delete Map

Add Camera

Delete the current map.

Add a camera as the hot spot on the map.

Add Alarm Input

Add an alarm input sensor as the hot spot on the map.

Add Hot Region

Add a map as the hot region on the current map.

Modify

Modify the information of the selected hot spot or hot region.

Delete

Delete the selected hot spot or hot region.

Clear Alarm Info

Clear the alarm information displayed on the map.

Back to Parent

Map

Go back to the parent map.

5.7.2 Hot Spot Function

Purpose:

The cameras and alarm inputs can be added on the map and are called the hot spots. The hot spots show the locations of the cameras and alarm inputs, and you can also get the live view and alarm information of the surveillance scenarios through the hot spots.

Adding Hot Spots

Adding Cameras as Hot Spots

Steps:

1. Click the Edit Map button in the E-map toolbar to enter the map editing mode.

2. Click the icon in the toolbar to open the Add Hot Spot dialog box.

3. Check the checkboxes to select the cameras to be added.

4. Optionally, you can edit hot spot name, select the name color and select the hot spot icon by double-clicking the corresponding field.

5. Click OK to save the settings.

You can also click-and-drag the camera icons from the group list to the map directly to add the hot spots.

36

Quick Start Guide of iVMS-4200

Adding Alarm Inputs as Hot Spots

Steps:

1. Click the Edit Map button in the E-map toolbar to enter the map editing mode.

2. Click the icon in the toolbar to open the Add Hot Spot dialog box.

3. Check the checkboxes to select the alarm inputs to be added.

4. Optionally, you can edit hot spot name, select the name color and select the hot spot icon by double-clicking the corresponding field.

5. Click OK to save the settings.

You can also click-and-drag the alarm input icons from the alarm input list to the map directly to add the hot spot.

Modifying Hot Spots

You can modify the information of the added hot spots on the map, including the name, the color, the icon, etc.

Steps:

1. Click the Edit Map button in the E-map toolbar to enter the map editing mode.

2. Select the hot spot icon on the map and then click in the toolbar, or double-click the hot spot icon on the map to open the Modify Hot Spot dialog box.

3. You can edit the hot spot name in the text field and select the color, the icon and the linked camera or alarm input.

4. Click OK to save the new settings.

37

Quick Start Guide of iVMS-4200

To delete the hot spot, select the hot spot icon and click in the toolbar.

Previewing Hot Spots

Steps:

1. Click the Map Preview button in the E-map toolbar to enter the map preview mode.

2. Double-click the camera hot spots or right-click it and select Live View, and you can get the live view of the cameras.

3. If there is any alarm triggered, an icon will appear and twinkle near the hot spot. Click the alarm icon, and then you can check the alarm information, including alarm type and triggering time.

Note:

To display the alarm information on the map, the Alarm on E-map functionality needs to be set as the alarm linkage action.

5.7.3 Hot Region Function

Purpose:

The hot region function links a map to another map. When you add a map to another map as a hot

38

Quick Start Guide of iVMS-4200 region, an icon of the link to the added map is shown on the main map. The added map is called child map while the map to which you add the hot region is the parent map.

Note: A map can only be added as the hot region for one time.

Adding Hot Regions

Before you start:

Add a map to another group.

Steps:

1. Click the Edit Map button in the E-map toolbar to enter the map editing mode.

2. Select an added map as the parent map.

3. Click the icon in the toolbar to open the Add Hot Region dialog box.

4. Check the checkbox to select the child map to be linked.

5. Optionally, you can edit the hot region name, and select the hot region color and icon by double-clicking the corresponding field.

6. Click OK to save the settings. The child map icons are added on the parent map as the hot regions.

You can click-and-drag the child map icons to move the hot regions to the desired locations.

Modifying Hot Regions

Purpose:

You can modify the information of the hot regions on the parent map, including the name, the color, the icon, etc.

Steps:

1. Click the Edit Map button in the E-map toolbar to enter the map editing mode.

2. Select the hot region icon on the parent map and then click in the toolbar, or double-click the hot region icon to open the Modify Hot Region dialog box.

3. You can edit the hot region name in the text field and select the color, the icon and the linked child map.

4. Click OK to save the new settings.

To delete the hot region, select the hot region icon and click in the toolbar.

39

Quick Start Guide of iVMS-4200

Previewing Hot Regions

Steps:

1. Click the Map Preview button in the E-map toolbar to enter the map preview mode.

2. Click the hot region icon to go to the linked child map.

3. The hot spots can also be added on the hot regions.

4. You can click the icon in the toolbar to go back to the parent map.

You can also click the icon in the toolbar to clear the alarm information.

5.8 Web Browsing

Purpose:

iVMS-4200 client software can also be accessed through web browser. It provides the functionalities of live view, playback, device management, account management, system configuration, etc.

Before you start:

You should enable the web service for the software before you can access the software via web browser.

Note:

For setting the web service, please go to the System Configuration module. The new settings will take effect after restarting the software. For detailed configuration, please refer to the User

Manual of iVMS-4200.

Steps:

1. Input the IP address of the PC running the iVMS-4200 in the address bar of the web browser, and press the Enter key. The login window shows.

40

Quick Start Guide of iVMS-4200

Note: If you have changed the web server port No., you should input the address of the software in the format of http://IP address of PC:web server port No. (e.g., http:10.16.1.55:85).

2. Input the user name and password of iVMS-4200.

3. Optionally, check the checkbox Remember password to save the password.

4. Click Login.

Note:

You can set the language as desired in the upper-right corner of the login interface.

The home page of the web browser after you login is shown as below.

6. Exit System

Click File on the top menu and select Exit, or click on the upper-right corner of the main interface, and then a confirmation dialog box pops up. Click OK to exit iVMS-4200.

0203011050415

41

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
