FactoryLink 7
PowerSQL User Guide
FactoryLink 7.0
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Version 7.0
•
•
•
•
© Copyright 2000 United States Data Corporation. All rights reserved.
- NOTICE -
The information contained in this document (and other media provided herewith) constitutes confidential information of
United States Data Corporation (“USDATA”) and is protected by copyright laws and international copyright treaties, as well
as other intellectual property laws and treaties. Such information is not to be disclosed, used or copied by, or transferred
to, any individual, corporation, company or other entity, in any form, by any means or for any purpose, without the express
written permission of USDATA.
The information contained in this document and related media constitutes documentation relating to a software product and
is being provided solely for use with such software product. The software product was provided pursuant to a separate
license or other agreement and such information is subject to the restrictions and other terms and conditions of such
license or other agreement.
The information contained in this document and related media is subject to change without notice and does not represent a
commitment on the part of USDATA. Except for warranties, if any, set forth in the separate license or other agreement
relating to the applicable software product, USDATA makes no warranty, express or implied, with respect to such
information or such software product.
USDATA and FactoryLink are registered trademarks of United States Data Corporation in the United States and/or other
countries. Open Software Bus is a registered trademark licensed to United States Data Corporation. All other brand or
product names are trademarks or registered trademarks of their respective holders.
2 / FactoryLink / PowerSQL User Guide
Table Of Contents in this book
•
•
•
Table of Contents
•
Dynamic SQL User Guide
PowerSQL User Guide
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Structure of the PowerSQL User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PowerSQL at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 1 Principles of PowerSQL Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Principles of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Use of Logical Expressions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Configuring Program Arguments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chapter 2 Configuring PowerSQL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
PowerSQL Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
PowerSQL Information Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Stored Procedure Example for Oracle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Limitations and Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 3 PowerSQL Status Codes and Status Messages . . . . . . . . . . . . . . . . . . . . . . . 45
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
FactoryLink / PowerSQL User Guide / 3
•
•
•
•
4 / FactoryLink / PowerSQL User Guide
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Preface
P URPOSE
FactoryLink PowerSQL (Structured Query Language) works in conjunction with the
FactoryLink Historian task to allow an application to access data in an external relational
database through a result window. In addition, PowerSQL processes SQL statements that are
entered in a FactoryLink Message tag.
This guide presents the technical information necessary to install, configure, and administer
PowerSQL.
A UDIENCE
The primary audience of this guide is application developers, programmers, or administrators
who are involved in providing PowerSQL.
S TRUCTURE
OF THE
P OWER SQL U SER G UIDE
The FactoryLink ECS PowerSQL User Guide is an Additional Manual in the FactoryLink
Documentation Set. Refer to the Preface in FactoryLink ECS Fundamentals for the structure of
the entire set.
This guide consists of three chapters:
• Principles of PowerSQL Operation
• Configuring PowerSQL
• PowerSQL Status Codes and Status Messages
H OW
TO
U SE T HIS G UIDE
The material in this guide is presented sequentially in performance order. We recommend you
read the entire guide to familiarize yourself with the complete procedure before proceeding to
develop your application.
Valid Entry: standard tag name
Valid Data Type: analog
FactoryLink / PowerSQL User Guide / 5
•
•
Conventions
•
•
PowerSQL at a Glance
Located at the beginning of this guide is a section named “PowerSQL at a Glance.” This
section provides a quick key to locations to find information to perform the procedures detailed
in that part with hypertext links to those locations.
C ONVENTIONS
The material in the Documentation Set adheres to the guidelines published in The Digital
Technical Documentation Handbook by Schultz, Darrow, Kavanagh, and Morse; Developing
International User Information by Jones, Kennelly, Mueller, Sweezy, Thomas, and Velez; and
corporate style guidelines. FactoryLink ECS PowerSQL User Guide is also referred to as
PowerSQL User Guide in this documentation.
PowerSQL User Guide uses the following conventions.
Convention
Description
…
Horizontal ellipsis points indicate the omission of material
from an example. The information is omitted because it is
not important to the topic being discussed.
.
.
.
Vertical ellipsis points indicate the omission of information
from an example or command format. The information is
omitted because it is not important to the topic being
discussed.
italic type
Italic type is used to denote user-supplied variables in
command examples.
Italic type also sets off references to specific documents.
monospace type
Monospace type is used to denote command names and
code examples or example output.
bold monospace type
Bold monospace type is used in command examples to
indicate words that must be typed literally.
sans serif type
Sans Serif type is used to set off field names, button names,
and keys on the keyboard.
blue type
Blue type is used for headings and to call attention to
information within the text.
6 / FactoryLink / PowerSQL User Guide
PREFACE
Conventions
Convention
Description
press nnnnn
Press is used to denote a key on the keyboard. The key
name will appear in a sans serif type.
click nnnnn
Click is used to denote a button on the screen. The button
name will appear in a sans serif type.
Shift+F1
The + indicates the keys must be pressed simultaneously.
Shift+F1 indicates you hold down the Shift key while you
press another key or mouse button (indicated here by F1).
Other key combinations are presented in the same manner.
F1 F2 F3
The space between the key callouts indicates press and
release.
The key sequence F1 F2 F3 indicates you press and release
F1, then F2, and then F3.
Other key combinations are presented in the same manner.
File>Open
The > indicates a progression through a menu sequence.
File>Open indicates you choose Open from the File menu
to perform the required action.
Other menu sequences are presented in the same manner.
FLAPP\user\drw\mydrw.g
The \ indicates the directory structure for the listed file.
FLAPP\user\drw\mydrw.g indicates the drawing file
mydrw.g is located in the drw sub-directory of the user
sub-directory to the FLAPP directory.
Other directory structures are presented in the same
manner.
[]
Brackets indicate an optional argument. You can choose
none, one, or all of the options.
{ } and |
Braces indicate a choice. You must choose one of the
elements. The vertical bar separates choices within braces.
Example Syntax
Example syntax using these conventions is provided below:
command input_file [input_file…] {a|b} output_file
FactoryLink / PowerSQL User Guide / 7
•
•
Getting Help
•
•
where
command
is typed as it is displayed in the syntax.
input_file
indicates a variable the user supplies.
[input_file…]
{a|b}
output_file
indicates the user can optionally supply multiple input file names, each
name separated by a space.
indicates either the a or b must be specified as an argument.
indicates the user must specify an output file.
G ETTING H ELP
Contact your Sales or Customer Support Representative for help with troubleshooting
problems.
Also, help files are included for each configuration panel. Click Help on the panel menu bar to
access these files.
8 / FactoryLink / PowerSQL User Guide
•
•
•
•
PowerSQL at a Glance
Using PowerSQL User Guide
For details on performing the following steps...
Go to...
1. Read about the general operating principles of
PowerSQL User Guide
Chapter 1, “Principles of
PowerSQL Operation”
2. Read about the use of logical expressions with
PowerSQL User Guide
Chapter 1, “Principles of
PowerSQL Operation
3. Read about the use of program arguments with
PowerSQL User Guide
Chapter 1, “Principles of
PowerSQL Operation
4. Configure PowerSQL control panel
Chapter 2, “Configuring
PowerSQL
5. Configure PowerSQL information panel
Chapter 2, “Configuring
PowerSQL
6. Reference PowerSQL status codes and status
messages
Chapter 3, “PowerSQL
Status Codes and Status
Messages”
FactoryLink / PowerSQL User Guide / 9
•
•
•
•
10 / FactoryLink / PowerSQL User Guide
•
•
•
•
Chapter 1
Principles of PowerSQL
Operation
• Allows data in an external relational database to be manipulated from within FactoryLink
• Allows an application to send and retrieve data to and from external database tables,
including those created outside FactoryLink
• Allows you to define tags referenced by PowerSQL in arrays as well as individually
• Allows you to execute SQL statements generated in PowerVB or Math & Logic
• Allows you to execute database-stored procedures for database servers that support them
For information on PowerSQL Commit Logic, please refer to page 17 of this chapter.
P RINCIPLES
OF
O PERATION
This chapter introduces the operational concepts behind the principles of PowerSQL
operations. For information on procedures to configure PowerSQL, refer to Chapter 2,
“Configuring PowerSQL,” of this guide.
In DB2, as opposed to Oracle, the slightest variation of row uniformity, (two rows are detected
as being too similar in makeups, etc.), will result a negative status for all other rows.
PowerSQL is a Historian-client task that communicates with Historian through mailbox tags to
send and receive historical information stored in an external database using SQL.
PowerSQL retrieves data in a relational database by generating an SQL SELECT from the data
specified in a FactoryLink configuration table and placing it in a temporary table called a result
table. The FactoryLink application can view and modify the retrieved data in the result table
through a result window. A result window is a sliding window that maps data columns in a
relational database table to FactoryLink tags. The result window views selected portions of the
result table.
For example, if a graphic screen is used to display the result window, it can display as many
rows of data from the result table as there are tags in the two-dimensional tag array. If there are
FactoryLink / PowerSQL User Guide / 11
Principles of
PowerSQL Operation
The FactoryLink PowerSQL (Structured Query Language) task works in conjunction with the
FactoryLink Historian task to allow an application to access data in an external relational
database through a result window. In addition, PowerSQL processes SQL statements that are
entered in a FactoryLink Message tag. PowerSQL offers the following features:
1
•
PRINCIPLES OF POWERSQL OPERATION
•
Principles of Operation
•
•
more rows in the result table than in the result window, the operator can scroll through the
result table and see each row of the table in the result window.
PowerSQL modifies data in a relational database by generating UPDATE, DELETE, and
INSERT SQL statements from the data specified in a FactoryLink configuration table. The
PowerSQL task also executes SQL statements generated by the user in a FactoryLink message
tag.
The relationships among the external database, the result table, the result window, the real-time
database, and the graphic display are displayed below.
External database
External
database
table "car"
Col1 Col2 Col3 Col4
Result table
Result
window
Graphic Display
FactoryLink
real-time
database
19910126110000
1 15
black
19910126113000
19910126120000
1 16
1 17
black
19910126123000
19910126130000
1 18
1 19
white
19910126123000
1
18
blue
19910126130000
1
19
19910126133000
19910126140000
1 20
1 21
blue
white
white
white
blue
blue
Car#
Color
Car # Color
18 white
18 white
19 blue
19 blue
blue
Logical expression:
Col1 >19910126075959
and
Col1 < 19910126170001
and
Col2 = 1
and
Col3 > 14
and
Col3 < 22
PowerSQL can read from and write to an entire array of tags in one operation.
12 / FactoryLink / PowerSQL User Guide
PRINCIPLES OF POWERSQL OPERATION
Principles of Operation
An internal buffer stores the rows of the result table in RAM. An external buffer stores the
overflow of rows from the internal buffer on disk. This allows the operator to scroll back up
through the result table. The buffers are shown in the following illustration.
1
Principles of
PowerSQL Operation
In this example, as the operator scrolls through the result table, the rows of the result table flow
into the internal buffer to be stored in memory. Because, in this case, the result table consists of
25 rows and the internal buffer can store only 20 rows, when the internal buffer is full, the
excess rows in the internal buffer flow into the external buffer to be stored on disk.
FactoryLink / PowerSQL User Guide / 13
•
PRINCIPLES OF POWERSQL OPERATION
•
Use of Logical Expressions
•
•
U SE
OF
L OGICAL E XPRESSIONS
You use logical expressions to specify the data in a relational database to view or modify. For
the purposes of PowerSQL, a logical expression is a command containing a standard SQL
WHERE clause. To make a logical expression flexible at run time, use the name of a message
tag whose value is a WHERE clause. If viewing all data from a column in a relational database
table, you do not need to specify a logical expression.
You must know how to write a standard SQL statement to configure PowerSQL. For
information about writing SQL statements, refer to any SQL guide, such as Quick Reference
Guide to SQL and/or the user manual for the relational database in use.
To select data from a database table, a logical expression works in conjunction with the table’s
column name and logical operators to form an SQL WHERE clause. The WHERE clause
specifies which rows in a database table to place in the result table.
The following table represents part of a sample database table CAR.
TRANDATE
CONVEYOR
CARNUM
COLOR
19910126080000
1
9
yellow
19910126083000
1
10
red
19910126090000
1
11
red
19910126093000
1
12
red
19910126100000
1
13
silver
19910126103000
1
14
black
19910126110000
1
15
black
19910126113000
1
16
black
19910126120000
1
17
white
19910126123000
1
18
white
19910126130000
1
19
blue
19910126133000
1
20
blue
14 / FactoryLink / PowerSQL User Guide
PRINCIPLES OF POWERSQL OPERATION
Use of Logical Expressions
1
CONVEYOR
CARNUM
COLOR
19910126140000
1
21
blue
19910126143000
1
22
brown
19910126150000
1
23
burgundy
19910126153000
1
24
blue
19910126160000
1
25
blue
19910126163000
1
26
brown
19910126170000
1
27
burgundy
A sample WHERE clause referencing the previous table CAR is
TRANDATE > ‘19910126075959’ AND TRANDATE < ‘19910126170001’ AND CONVEYOR =
1 AND CARNUM > 14 AND CARNUM <22
In this example, the WHERE clause requests:
What colors cars 15 through 21 on conveyor 1 were painted between 8:00 A.M. and 5:00 P.M. on
January 26, 1991
From this WHERE clause, the relational database places the following values in a result table.
19910126110000
1
15
black
19910126113000
1
16
black
19910126120000
1
17
white
19910126123000
1
18
white
19910126130000
1
19
blue
19910126133000
1
20
blue
19910126140000
1
21
blue
FactoryLink / PowerSQL User Guide / 15
Principles of
PowerSQL Operation
TRANDATE
•
PRINCIPLES OF POWERSQL OPERATION
•
Configuring Program Arguments
•
•
If the view size of the result window is 2, the result window writes the values of the tags in two
rows to the real-time database. When the data reaches the real-time database, other
FactoryLink tasks can read it and write to it, and an operator can view the data on a graphics
screen.
PowerSQL performs five types of operations:
Select
Uses an SQL select statement to select and retrieve data from a relational
database to be displayed in a result table.
Update
Updates the data in the result table and external database. PowerSQL can
perform two types of update operations:
Positional—Updates the current row (row at which the cursor is currently
pointing) of data displayed in the result window.
Logical—Updates the data described by the logical expression.
Insert
Inserts a row of data in a database table. There are two types of insert
operations:
Auto Create flag—If this flag is true, an insert operation is executed when
an update operation modifies no rows in the database table.
Insert trigger—Inserts a row of data when the trigger is set.
Delete
Deletes a row from the result table and external database. PowerSQL can
perform two types of delete operations:
Positional—Deletes the current row (row at which the cursor is currently
pointing) of data displayed in the result window.
Logical—Deletes the data described by the logical expression.
Other SQL
statements
Via a message tag.
C ONFIGURING P ROGRAM A RGUMENTS
Configure the following system configuration program arguments to affect PowerSQL
functionality:
-L or -l
Enables logging of errors to the log file. By default, PowerSQL does not log
errors.
-N or -n
Notifies on the completion of a SELECT trigger that the query resulted in
an End of Fetch condition if the rows returned from the query do not equal
the rows defined in the Data Array Size field. By default, PowerSQL does
not report an End of Fetch condition for a SELECT until a move operation
advances the current row past the last row of the query.
16 / FactoryLink / PowerSQL User Guide
PRINCIPLES OF POWERSQL OPERATION
Configuring Program Arguments
-S[4-160] or
-s[4-160]
-V1 or -v1
Writes the SQL statements generated by PowerSQL to the log file.
PowerSQL must have logging enabled for this program switch to work. The
default is to not write the SQL statements to the log file.
-W[5-36000] or
-w[5-36000]
Sets the maximum timeout in seconds for PowerSQL to wait for a response
from the Historian task. The default is 30 seconds.
-C[0-2] or
-c[0-2]
In the previous version of the PowerSQL tasks, a COMMIT statement was
performed after all database accesses, except the SELECT statement, were
executed as a non-dynamic SQL statement. This included the execution of
stored procedures and dynamic SQL statements through the use of the SQL
tag. The execution of dynamic SQL statements, especially for stored
procedures, can result in very complex database operations that include
many separate steps. In such cases, the PowerSQL task does not have at its
disposal the necessary information to determine if a COMMIT should be
executed or whether a ROLLBACK is more appropriate. This has the
potential to COMMIT unwanted database updates in the case of execution
failures. Proper procedures would dictate that COMMIT/ROLLBACK
logic should be programmed into the stored procedures. Therefore, it has
been decided that procedurally the PowerSQL task should not execute a
COMMIT after the execution of dynamic SQL statements. However, since
this would have an impact on an existing application, the task has been
modified to accept a new program argument that will control the COMMIT
logic. The new argument (entered in the Program Arguments field of the
System Configuration table for the PowerSQL task) is:
-cN
where N is a modifier to select various levels of COMMIT logic. The
default action (no argument listed or “-c2”) will be COMMIT logic exactly
as in the previous version, and thus no modifications are required to
existing applications. The argument “-c1” will result in no COMMITs for
dynamic SQL statements. The non-dynamic SQL operations (traditional
insert, delete, and update statements) are followed by a COMMIT. The
argument “-c0” will result in no COMMITs for any statements executed,
except for a final COMMIT upon task shutdown.
Even though the default configuration is to continue to perform a COMMIT
after dynamic SQL statements, USDATA strongly recommends that
application be modified to use the “-c1” argument and that all stored
procedures be updated to include all necessary and appropriate
FactoryLink / PowerSQL User Guide / 17
1
Principles of
PowerSQL Operation
Sets the maximum number of SQL statements that PowerSQL will have
active at one time. The default is 160. For very large applications, this
program switch may have to be adjusted if the database server is unable to
allocate a resource to open a new SQL cursor.
•
PRINCIPLES OF POWERSQL OPERATION
•
Configuring Program Arguments
•
•
COMMIT/ROLLBACK logic. Of course, if all stored procedures currently
contain such logic, then the execution of a COMMIT by the PowerSQL task
has no effect, and negates the need to include the “-c1” argument.
Use of the “-c0” configuration is not particularly recommended, since
failure to COMMIT non-dynamic SQL statements could have an adverse
effect on the database server, but the configuration is included for
completeness. Since a COMMIT can be easily executed through the use of
the SQL tag, it does offer users the ability to take full responsibility for
COMMIT logic away from the PowerSQL task and make it become part of
the application design and control.
18 / FactoryLink / PowerSQL User Guide
•
•
•
•
Chapter 2
Configuring PowerSQL
This section provides a field-by-field description of the configuration panels used to configure
the PowerSQL task. PowerSQL uses one configuration table: the PowerSQL configuration
table, which consists of the following two panels:
• PowerSQL Control panel—Refer to “PowerSQL Control Panel” on page 20.
• PowerSQL Information panel—Refer to “PowerSQL Information Panel” on page 34.
These panels are configured in the SHARED or USER domain.
2
Configuring
PowerSQL
FactoryLink / PowerSQL User Guide / 19
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
P OWER SQL C ONTROL P ANEL
Perform the following steps to configure the PowerSQL Control panel:
1 Ensure the appropriate domain is selected in the Configuration Manager Domain Selection
box. PowerSQL is most commonly configured as a USER domain task, but it can also be
configured as a SHARED task.
2 Choose PowerSQL in the Configuration Manager Main Menu to display the PowerSQL
Control panel.
3 Specify the following information for this panel:
• Do not use Select, Update, or Delete Triggers for a control record using Insert Trigger.
• Use only either Select or Update Trigger for a control record using PowerSQL tag.
• Use the Select Trigger alone or with Update Trigger or Delete Trigger or with both Update
and Delete Triggers for a control record not using Insert Trigger or PowerSQL tag.
• Use Update Trigger and/or Delete Trigger for a control record not using Insert Trigger or
PowerSQL tag or Select Trigger.
Control Name
Alphanumeric string of 1 to 15 characters that specifies the
developer-assigned name of the control record.
Valid Entry: alphanumeric string of 1 to 15 characters
Select Trigger
Name of a tag that triggers a select operation. A select operation selects
specific data from a relational database table based on information specified
in the PowerSQL Information panel and places it in a result table for you to
view or manipulate.
20 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: digital, analog, longana, float, message
Update Trigger
Name of a tag that triggers an update operation. PowerSQL performs a
positional update if you defined a Select Trigger. When the value of this tag
changes during a positional update, PowerSQL reads the values in the
active row (the value of the Current Row tag) and updates the values in that
row of the result table and external database.
For a positional update to work, the database table must have a unique
index. This can be configured in Database Schema Creation or executed
externally to FactoryLink when the database table is created. For more
information on configuring the Database Schema Creation panel, refer to
FactoryLink ECS Configuration Guide Chapter 4, “Database Logger.” If
you need to create a unique index on a dBASE IV table that already exists,
refer to “Working with Tables” on page 327 of the Configuration Guide.
Consult the appropriate RDBMS user’s manual if you need to create a
unique index on a non-dBASE IV database table that already exists.
To perform an update operation with multiple rows of values, the Current
Row Tag and Data Array Size fields must be configured, and the tags in the
PowerSQL information panel must be tag arrays large enough to hold
values determined by the Data Array Size field.
Before setting the Update Trigger, set the Current Row Tag to the number of
rows of values that are to be processed by the update statement. The Current
Row tag should contain an integer value between 1 and the data array size.
To perform an update operation that processes one row of values, set the
Data Array Size field to 1 and leave the Current Row Tag field blank. This
configuration causes PowerSQL to use only one row of values when the
update operation is executed.
Note: The batch/dynamic mode Update failure, such as duplicate row,
will ONLY set the first row’s complete status as a proper error code for
all Historians.
FactoryLink / PowerSQL User Guide / 21
Configuring
PowerSQL
PowerSQL performs a logical update if you have not defined a Select
Trigger to select specific data. During a logical update, PowerSQL
constructs the update SQL statement based on the information entered in
the PowerSQL Information panel. PowerSQL can process one row or
multiple rows of values when the update SQL statement is executed.
2
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
Note: The PowerSQL task supports a feature that permits arrayed
operations for updating a supported relational database. Instead of
providing a single set of data points to update a single row in a database,
this feature uses arrays of data points to perform multiple updates. The
batch mode is the most efficient and, at completion, is designed to update
an array of status tags for each set of data points (or each operation.) For
example, if a batch operation is triggered to “insert” 100 rows using 100
different sets of data with one data set results in a duplicate index key
error violation, the status tags should indicate 99 successful inserts and
the one error condition of duplicate index key. However, further testing
with various ODBC drivers behaves differently to this situation as noted
in the following list:
•
MS Access97 ODBC Driver—Inserts rows only until the error is encountered
and aborts the rest of the operation. Status information is only valid up to the row
that failed.
•
MS SQL Server 6.5 Driver—Inserted data is correct. Duplicate row is not
inserted. However, the driver does not return an error message that allows for
proper update of the status for that row.
•
Intersolv Sybase Driver—Same as MS SQL Server 6.5 Driver results.
•
Intersolv Oracle Driver—Works as desired.
•
Intersolv Informix Driver—Works as desired.
•
IBM Database2 2.1.2 Driver and 5.0 Driver—Once an error is encountered, it
aborts the entire set of operations. The failure status is properly returned for all
rows.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: digital, analog, longana, float, message
Delete Trigger
Name of a tag that triggers a delete operation. PowerSQL performs a
positional delete if you defined a Select Trigger. PowerSQL deletes the
active row in the result window from the result table and external database
when the value of this tag changes during a positional delete.
The database table must have a unique index for a positional delete to work.
This can be configured in Database Schema Creation or when the database
table is created. For information on configuring the Database Schema
Creation panel, refer to FactoryLink ECS Configuration Guide Chapter 26,
“Defining Schemas.” For information on how to create a unique index on a
dBASE IV table that already exists, refer to FactoryLink ECS
22 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
Fundamentals Chapter 5, “Database Logging Task Definition.” For
information on how to create a unique index on a non-dBASE IV table that
already exists, consult the appropriate RDBMS user’s manual.
PowerSQL performs a logical delete if you have not defined a Select
Trigger to select specific data. During a logical delete, PowerSQL
constructs the delete SQL statement based on the information entered in the
PowerSQL Information panel. PowerSQL can process one row or multiple
rows of values when the delete SQL statement is executed.
To perform a delete operation with multiple rows of values, the Current
Row Tag and Data Array Size fields must be configured, and the tags in the
PowerSQL information panel must be tag arrays large enough to hold
values determined by the Data Array Size field. Before setting the Delete
Trigger, set the Current Row Tag to the number of rows to be processed by
the delete statement. The current row tag should contain an integer value
between 1 and the data array size.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: digital, analog, longana, float, message
*Insert Trigger
Auto Create
This field can be configured as an Insert Trigger or as an auto create field
that causes PowerSQL to insert a row in a database table when a logical
update operation modifies no rows.
To configure this field as an auto create switch, enter:
YES Insert a new row of data when logical update modifies no
rows.
NO Do not insert any new rows. This is the default.
If a tag is configured in this field, it acts as an Insert Trigger. Configuring a
Select Trigger with an Insert Trigger is an invalid configuration that is
reported at task startup. The Insert Trigger causes PowerSQL to construct
an insert SQL statement based on the information entered in the PowerSQL
Information panel. PowerSQL can insert one row or multiple rows of data
when the insert SQL statement is executed.
FactoryLink / PowerSQL User Guide / 23
2
Configuring
PowerSQL
To perform a delete operation that processes one row of values, set the Data
Array Size field to 1 and leave the Current Row Tag field blank. This
configuration causes PowerSQL to use only one row of values when the
delete operation is executed.
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
Note: The batch/dynamic mode Insert failure, such as duplicate row, will
ONLY set the first row’s complete status as a proper error code for
odbchist/mssql and odbchist/ibmdb2.
To perform an insert operation with multiple rows of values, the Current
Row Tag and Data Array Size fields must be configured, and the tags in the
PowerSQL information panel must be tag arrays large enough to hold
values determined by the Data Array Size field. Before setting the Insert
Trigger, set the Current Row Tag to the number of rows to be processed by
the insert statement. The current row tag should contain an integer value
between 1 and the data array size.
To perform an insert operation that processes one row of values, set the
Data Array Size field to 1 and leave the Current Row Tag field blank. This
configuration causes PowerSQL to use only one row of values when the
insert operation is executed.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: YES or NO or standard tag name
Valid Data Type: digital, analog, longana, float, message
Move Trigger
(Requires use of the Select Trigger.) Name of an analog tag whose value
causes PowerSQL to do a relative move based on the active row. If the
Move Trigger contains a negative number, the active row is decreased by
this value. If the Move Trigger contains a positive number, the active row is
increased by this value. When this operation is completed, the current row
tag reflects the position of the active row in the result window. The
PowerSQL task scrolls the data rows in the result window to reflect the new
position of the active row.
For example, if the value of the Move Trigger tag is 3 and the Current Row
tag is 0 (active row is the first row in the result window) and the result
window size (data array size) is five rows, the current row tag is changed to
3 and the data in the result window is not scrolled. If the Move Trigger tag
is 8, the current row tag is again 3, but the data is scrolled, because the
number of rows moved is greater than the result window size.
The scrolling of the data in the result window is controlled by the Move
Trigger and by the internal cache size. If the internal cache size is not
configured, the active row can only scroll back (Move Trigger is negative)
to the row that is at the start of the result window. If the user attempts to
scroll back beyond the result window, PowerSQL generates an error and
sets the current row tag to 0. This is so because the data that was previously
scrolled off the result window was not cached and is no longer accessible by
PowerSQL. This configuration does not prevent you from scrolling forward
24 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
(Move Trigger is positive) to the end of the result table. This configuration
is the most efficient, since it uses less memory and disk space to scroll the
data in a result window.
Move operations can be performed only on result tables; therefore, move
operations cannot be performed unless you have defined and executed a
Select Trigger.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: analog, longana
2
Configuring
PowerSQL
Position Trigger
(Requires use of the Select Trigger field.) Name of a tag that moves the
result window to the specified row in the result table. The Current Row tag
reflects where the active row is positioned within the result window. For
example, if the value of this tag is 42, the result window displays row 42 of
the result table and the current row tag will reflect where row 42 is in the
result window.
The Internal Cache Size field works in conjunction with the Position
Trigger tag, also. If the internal cache size is not configured, the Position
Trigger tag cannot position the active row to rows that are less than the row
at the start of the result window. An attempt to do this causes PowerSQL to
generate an error and position the current row tag to 0. This is so because
the data that was previously scrolled off the result window was not cached
and is no longer accessible by PowerSQL. This configuration does not
FactoryLink / PowerSQL User Guide / 25
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
prevent you from setting the Position Trigger tag to rows that have not yet
been displayed in the result window. This configuration is the most
efficient, since it uses less memory and disk space to scroll the data in a
result window.
Position operations are performed only on result tables; therefore, position
operations cannot be performed unless you define and execute a Select
Trigger.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: analog, longana
Historian Mailbox
Name of a mailbox tag used for communication between PowerSQL and a
Historian. PowerSQL sends requests for information from the relational
database to this mailbox tag. The Historian task reads this tag and transfers
the request to the external database.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: mailbox
*Database.Table
Name
This field can be configured as a real-time database tag or as a string
constant. If a message tag is configured, the user can use this control record
to access multiple database tables with like table structures. To use this
feature, the message tag must contain the database alias name (defined in
the Historian task) and the name of the database table that is to be accessed.
Place a ‘.’ between the database alias name and the table name. Ensure that
this tag contains such a string before a Select, Update, Insert, or Delete
Trigger is set.
If the PowerSQL Tag field is configured, only the Database Alias Name is
used by PowerSQL and the rest of the string is ignored for this type of
operation. This is so because the SQL statement in the PowerSQL tag refers
to the database table that is to be accessed.
If the Database.Table Name field references a tag, PowerSQL checks
whether this tag has changed since the last select, logical update, logical
delete, or insert operation. If it has changed, PowerSQL closes all SQL
statements that are referenced by this control record, and creates new ones
based on the database table name specified in this tag. For a positional
update and a positional delete operation the check is ignored, since these
operations are controlled by the Select Trigger operation.
26 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
The user can choose to enter a string constant. If so, the string constant must
have a single quote ‘ as the first character and the database alias name
followed by the database table name. Place a “.” between the database alias
name and the database table name. If the PowerSQL Tag field is configured,
only the database alias name is required.
To fully qualify a database table name, the table name can contain more
than one period. Additional periods in the table name must be preceded by
the back slash character “\” for PowerSQL to parse this table name
correctly.
For example, analias.scott\.mytable. The table name scott\.mytable is
fully qualified and requires that the back slash precede the period between
scott and mytable. ‘analias’ is the database alias name that is configured in a
Historian task.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
2
Valid Entry: alphanumeric string of 1 to 63 characters or a standard
tag name
Valid Data Type: message
Name of a message tag that is used by the user to supply an SQL statement
that PowerSQL executes when either a Select Trigger or Update Trigger is
set. PowerSQL reads this tag only when a Select Trigger or Update Trigger
is set by the application. Configuring a delete or Insert Trigger is invalid
and results in an error at task startup. Only one trigger, a select or update,
can be configured when a PowerSQL tag is configured.
Configure an Update Trigger when the SQL statement or stored procedure
modifies rows or inserts rows in a database table or drops or creates
database objects (tables, indexes, etc.) in a database server. Use a Select
Trigger when the SQL statement is a SELECT statement or when a stored
procedure returns a result table. If a result table is generated, the user can
configure a Move Trigger or Position Trigger. These triggers allow the user
to scroll through the result table.
The PowerSQL Tag can contain any valid SQL statement that is valid to the
database server that the Historian task is communicating with. The SQL
statement can reference input variables referenced by ‘?’ in the body of the
SQL statement. Each input variable must have an associated record in the
PowerSQL Information panel. The SQL statement can also generate a result
table and each result data column must also have an associated record in the
PowerSQL Information panel. See the description of the Column
FactoryLink / PowerSQL User Guide / 27
Configuring
PowerSQL
PowerSQL Tag
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
Expression field in the PowerSQL Information panel for more detail. For
SQL statements that do not require an input variable or generate a result
table, the PowerSQL Information panel can be left empty.
Note: You may use only the Select Trigger or Update Trigger to trigger
a stored procedure. Do not use the Delete Trigger or Insert Trigger for
this purpose. If there is a select statement in the stored procedure, then
use the Select Trigger to select the stored procedure; otherwise, use the
Update Trigger.
A special syntax is required to have PowerSQL execute a stored procedure.
To execute a database-stored procedure, the PowerSQL tag must contain an
ODBC-standard escape sequence for executing stored procedures. The
ODBC standard escape sequence syntax is
{ [?=] call proc-name [ ( [parameter][,[parameter]]… ) ] }
where
{ } (Required) brackets begin and end a call statement
?= (Optional) if stored procedure returns a value and you
want it stored in a tag, include this. The ? is a
substitution variable (place holder) for the return value.
call (Required) key word call
proc-name (Required) name of stored procedure to be executed
( ) (Required) parentheses begin and end the parameter list
for a stored procedure.
parameter list of parameters comma separated. A parameter is a
‘?’ substitution variable or a numeric constant or an
SQL string constant.
If the clause is enclosed in [ ], it is optional.
For example,
{ ? = call add_employee(1001, ‘John’, ‘Doe’, ‘Engineer’) }
{ ? = call add_employee(?,?,?,?) }
Note: When using the SQL TAG to execute an SQL statement and the
target database is Oracle, (whether using native Oracle Historian or ODBC
Historian,) do not include a “;” at the end of the SQL statement.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: message
28 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
Current Row Tag
Name of a real-time database tag. For select, move, or position operations,
this tag’s value indicates the position of the active row of data in a result
window. After PowerSQL performs a Select, Move, or Position operation,
PowerSQL writes the value indicated by the position of the active row to
this tag. The value of the current row tag in these operations is between 0
and the data array size – 1. For select, move, or position operations,
PowerSQL writes to the current row tag and the application should treat this
tag as read only.
If a Select Trigger is defined, PowerSQL performs all positional update and
positional delete operations on the row indicated by the current row tag.
For logical update, logical delete, and insert operations, the Current Row
tag value represents the number of rows of values to be processed. The
Current Row tag in these operations must be between 1 and the data array
size. The values in the array tags that are configured in the PowerSQL
Information panel must be contiguous, since PowerSQL reads the tag
specified in the information panel and the next current row tags in the tag
array when a Logical Update, Logical Delete, or Insert operation is
executed.
Valid Entry: standard tag name
Valid Data Type: analog
FactoryLink / PowerSQL User Guide / 29
Configuring
PowerSQL
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
2
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
Data Array Size
(Rows)
Number between 1 and 9999 that specifies the number of rows of data
contained in a result window or the maximum number of rows of values a
logical update, logical delete, or insert operation can process. The tags
specified in the Tag Name field of the PowerSQL Information panel must
be an array large enough to contain values determined by the Data Array
Size field. The Data Array Size (Rows) field controls how many rows of
data are to be fetched by PowerSQL when a select, move, or position
operation is executed.
If the Data Array Size (Rows) field is configured with a number that
exceeds the maximum message size that can be processed in a mailbox tag,
PowerSQL breaks this operation into several operations until all data rows
are processed.
For example, the number specified in this field is 1. Enter a large positive
value in the Move Trigger or Position Trigger field to scroll directly to the
end of the result table. Because only one row of data is requested at a time,
the operation for a large result table takes more time than if the value in this
field is larger.
Valid Entry: number between 1 and 9999
Internal Cache
Size (Rows)
Number between 0 and 9999 that specifies the number of rows of data in a
result table that are cached. This field makes sense only for select
operations that have a move and/or a Position Trigger configured. So if the
control record does not have a Select Trigger or has a Select Trigger but no
Move or Position Trigger, leave this field blank.
If a Select Trigger is defined with a Move or Position Trigger, the value in
this field affects the move and position operations. See “Move Trigger” on
page 24 and “Position Trigger” on page 25 of this chapter.
The internal cache is used to allow the user to scroll forward and backward
through the result table that is generated when a Select trigger is executed.
If this control record is used to simply load tags with information and only
scrolls forward, the Internal Cache Size field is not necessary and is
inefficient for this type of operation. If this control record is used as a table
grid for an operator to scroll backward and forward, configure this field so
that all rows in a result table are accessed and displayed to the operator.
Observe some guidelines for setting data array size and internal cache size:
if this control record is used for an operator viewing a table grid in a graphic
screen, do not set the data array size to more than 50, because it is difficult
to view more than 50 rows of information in a table grid. A data array size
of 50 or less and an internal cache size of 100 provides acceptable
performance for operator viewing.
30 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
If this control record is used as a way to quickly populate an array of tags
that is used to download information from a database table to a PLC, then it
makes sense to set data array size to a value larger than 50. For this
situation, setting the Internal Cache Size field slows down the operation,
since it copies data to memory (twice) and then to disk.
Valid Entry: numeric value of up to 9999
Completion Trigger
Name of a tag whose change-status flag is set when any operation
undertaken by this control record is completed.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: digital, analog, longana, float, message
Completion Status
The completion status tag can operate as a single status code or as an array
of status codes, depending on the operation executed by PowerSQL. If the
completion status tag is a message, PowerSQL updates this tag with a text
message. If the completion status tag is an analog tag, this tag displays
codes that are described in Chapter 3, “PowerSQL Status Codes and Status
Messages,” of this guide. If the completion status tag is a longana tag, it
displays codes generated by the database server that the Historian task is
accessing. So these status codes are dependent upon the database server that
is connected, and you will need to consult the database server for the
definition of the error codes.
If a logical update, logical delete, insert, or SQL operation accepts an array
of input values, the status tag can display an array of status codes (only if
the completion status tag is either an analog or longana tag type). If an array
of status codes is desired, the Completion Status tag must be a tag array and
be capable of storing values determined by the Data Array Size field.
You can configure this tag to work in conjunction with output objects in the
Application Editor task to display codes or messages on any graphics
screen. For information about defining output objects, refer to FactoryLink
ECS Application Editor Guide.
FactoryLink / PowerSQL User Guide / 31
2
Configuring
PowerSQL
Name of a tag whose value indicates the status of the last operation done by
this control record. The completion status tag is updated with status
information by PowerSQL. These status messages or status codes are
generated by PowerSQL or by the Historian task, depending on where the
failure takes place. For the codes and messages that can display in this tag,
refer to “PowerSQL Status Codes and Status Messages” on page 45 of this
chapter.
•
CONFIGURING POWERSQL
•
PowerSQL Control Panel
•
•
You can also configure Math & Logic to monitor this tag and respond to or
ignore errors that occur.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: analog, longana, message
The panel resembles the sample panel shown in the following illustration when you have
specified all information.
In this example, PowerSQL sends a request for select, update, delete, move, and position
operations to the Historian through the Historian mailbox tag HISTMBX. PowerSQL asks for
data from the table TANK in the relational database REFINERY.
32 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Control Panel
PowerSQL updates the value of the current row tag element CROWTAG1 when PowerSQL
performs a select, move, or position operation. The Completion Status element STATTAG1
contains status information about the operation just completed. The change-status flag for the
digital element COMTRG1 is set when an operation for this result window is complete.
Because the Auto Create Record? field indicates NO, PowerSQL does not create a new row
and the update operation is not performed whenever you do not find a row for the update
operation.
Because the Data Array Size is 12, the result window can display 12 rows of data from the
result table at a time. The internal cache can hold 100 rows of data from the result table.
4 Click Enter to save the information.
5 Click Next to get to the PowerSQL Information panel.
2
Configuring
PowerSQL
FactoryLink / PowerSQL User Guide / 33
•
CONFIGURING POWERSQL
•
PowerSQL Information Panel
•
•
P OWER SQL I NFORMATION P ANEL
Use the PowerSQL Information panel to configure the details of the SQL operation defined in
the PowerSQL Control panel. Specify the following information to configure the PowerSQL
Information panel:
Tag Name
Name of a tag that contains the values from a column of a relational
database table or the values of an SQL expression or the values for input
variables for an update, delete, insert, or stored procedure call. If the Data
Array Size field in the PowerSQL Control panel is greater than 1, the tag
must be an array of data array size or greater. Ensure all tags entered in the
Tag Name field can accommodate values determined by the Data Array
Size field.
If the tag specified in this field is not already defined, a Tag Definition
dialog is displayed when you click Enter. Select the appropriate data type.
Valid Entry: standard tag name
Valid Data Type: digital, analog, longana, float, message
34 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Information Panel
Logical Operator
The Logical Operator field is ignored for control records that have a
PowerSQL tag configured. The Logical Operator field is part of a WHERE
clause that specifies the conditional statement that restricts the rows
selected, updated, or deleted from a database table. This field works in
conjunction with the Column Expression and Logical Expression fields
(described below) to construct the WHERE clause. This can be one of the
following:
AND Specifies a combination of conditions in a logical
expression.
OR Specifies a list of alternate conditions in a logical
expression.
FactoryLink performs a sequential search through the database even if the
columns are indexed if you use the OR operator in a logical expression
when using the Historian for dBASE IV. This may result in a slower
response time if the database is large; therefore, we recommend you not use
OR operators in logical expressions so the Historian for dBASE IV can take
advantage of indices.
2
NOT Negates a condition in a logical expression.
conditions in a logical expression.
OR_NOT Specifies a list of alternate negated conditions in a logical
expression. (See examples in the following table.)
WHERE clause
Column
Expression
Description
Col2 = 3 AND Col4 > 4
PowerSQL selects all rows where
Col2 is equal to 3 AND Col4 is
greater than 4.
Col3 < 6 OR Col2 >= 19
PowerSQL selects all rows where
Col3 is less than 6 OR Col2 is
greater than or equal to 19.
Col4 > 7 AND_NOT Col4 = 20
PowerSQL selects all rows where
Col4 is greater than 7 AND_NOT
equal to 20.
Alphanumeric string of 1 to 63 characters that specifies:
FactoryLink / PowerSQL User Guide / 35
Configuring
PowerSQL
AND_NOT Specifies a combination of conditions and negated
•
CONFIGURING POWERSQL
•
PowerSQL Information Panel
•
•
(1) A character string representing the relational database column name
associated with the Tag Name tag. The Column Name field works in
conjunction with the Logical Operator and Logical Expression fields to
specify WHERE clauses with the following format:
([table.]column)
where
table is the relational database table name. Include table, if the
table name is different from the table name specified in the
*Database.Table Name field in the PowerSQL Control
panel.
column is the name of the column within the relational database
table. You can use the same column name in two rows of a
panel.
OR
(2) An SQL function, such as MAX (col_name) or COUNT (*). The result
of this function is written to the tag specified in the Tag Name field. SQL
functions are supported only in SELECT statements. SQL functions are not
supported in UPDATE statements or by the Historian for dBASE IV.
OR
(3) An SQL assignment, such as time_entered=SYSDATE, where
time_entered is a column name in a database table and SYSDATE is an
Oracle macro that supplies the current time stamp according to the Oracle
Server. This feature is valid only for UPDATE and INSERT statements and
allows the user to use database server macros or numeric constants or string
constants to be entered directly into columns instead of through
FactoryLink tags.
OR
(4) The reserved words $OUTPUT, $INPUT, and $INOUT. These reserved
words are valid only for control records that have a PowerSQL tag
configured in the control record. The reserved words tell PowerSQL how to
treat the tag referred to by Tag Name and the associated SQL statement in
the PowerSQL Tag message tag.
If Column Expression is $OUTPUT, the tag in the Tag Name field holds
values for a column in a result table generated by either a SELECT
statement or a stored procedure. If the Column Expression is $INPUT, the
tag in the Tag Name field holds the value for a substitution variable ‘?’
embedded in the body of the SQL statement. If the Column Expression is
36 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Information Panel
$INOUT, the tag in the Tag Name field holds the value for a substitution
variable in a stored procedure call statement and also updates the tag with
the value that is returned by the stored procedure in this variable.
Valid Entry: alphanumeric string of 1 and 63 characters
Maximum
Character Data
Size
Limits the maximum size in bytes that PowerSQL will write to a message
tag. This field is supplied because SQL expressions that result in a character
string may default to a large data size that will cause excessive memory in
the FactoryLink real time database to be allocated and wasted. If this field is
left blank, PowerSQL always writes to the message tag the default size that
is supplied by the database server for the associated column expression.
Valid Entry: numeric value between 1 and 256
Logical Expression
The Logical Expression field is ignored for control records that have a
PowerSQL Tag configured. The Logical Expression field is used to
generate a conditional statement that restricts the rows selected, updated, or
deleted from a database table. This field works in conjunction with the
Column Expression and Logical Operator fields to generate the WHERE
clause used in the SQL statement.
FactoryLink / PowerSQL User Guide / 37
Configuring
PowerSQL
Note: An embedded variable in PowerSQL is a FactoryLink tag name
preceded by a colon. The embedded variable can be used only in the
Logical Expression field. The embedded variable can be any FactoryLink
tag type except mailbox. If the tag is an array, specify the dimension (for
example, :tag_xyz[2]). The tag in the embedded variable is not detected
by Configuration Manager as a tag, so the user must define the tag
somewhere else in the application, such as in Math & Logic.
2
•
CONFIGURING POWERSQL
•
PowerSQL Information Panel
•
•
The conditional statement in a Logical Expression field can consist of
relational operators. The following is a list of relational operators that are
supported by the dBASE IV Historian.
=
is equal to
<
is less than
>
is greater than
<>
is not equal to
<=
is less than or equal to
>=
is greater than or equal to
is not null
is not a null value (for dBASE IV Historian
TRUE when database column is not all
spaces)
between X and Y
defines a range of values where X is the lower
limit and Y is the higher limit. This is equal to
COLNAME >= X and COLNAME <= Y
If using the dBASE IV Historian, limit the logical expressions to this list of
relational operators. If not using the dBASE IV Historian, consult the
RDBMS SQL Language user’s manual for more information.
The WHERE clause is generated by appending the Logical Operator,
Column Expression, and Logical Expression fields in the order displayed in
the PowerSQL Information panel. Punctuation is supplied by PowerSQL to
ensure correct SQL syntax. Any embedded variable found in the Logical
Expression field is replaced by a ‘?’, which SQL defines as a substitution
variable for a value to be supplied at execution time. The value supplied is
the tag’s value defined by the embedded variable.
The string generated by this is a WHERE condition. If the first word(s) in
this string is not SQL-reserved words such as ORDER BY, the reserved
word WHERE is attached to the start of this string. The user must ensure
that any placement of SQL clauses such as ORDER BY and GROUP BY is
properly ordered as defined by the SQL language for the targeted database
server.
38 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Information Panel
The ORDER BY clause is supported in the dBASE IV Historian, but only
to the extent that the columns listed in the ORDER BY clause must match
an index that was created for the database table. The dBASE IV Historian
does not build any temporary tables to reorder the rows, so make sure the
ORDER BY clause matches an index for the dBASE IV database table. If
an ORDER BY clause does not match an index, the dBASE IV Historian
returns an error.
If you define a Select Trigger in the PowerSQL Control panel, the WHERE
clause is used for the select statement. If a Select Trigger is not defined, the
WHERE clause is used for either the logical update operation or logical
delete operation or for both.
A logical expression can contain one of the following:
1. Character string of up to 79 characters containing an SQL expression:
OUTLETTVAL = 30 and TANKID = ‘BLUE001’
or an SQL clause:
2
ORDER BY TANKID
For example:
=:tagTANKID
where tagTANKID is a message tag of value: BLUE001
3. An embedded message variable only. This variable must be a message
tag. The message tag contains an SQL clause or SQL expression. The SQL
expression cannot contain an embedded variable and any string constants in
the SQL expression must be quoted in single quotes.
For example:
:tagSQLExpression
where
tagSQLExpression is a message tag
OUTLETVAL = 30 and TANKID = ‘BLUE001’
FactoryLink / PowerSQL User Guide / 39
Configuring
PowerSQL
2. Character string of up to 79 characters representing an SQL expression
that contains embedded variables. If the tag is a message tag, the character
data in the message tag should not be enclosed in single quotes. If the
PowerSQL Control record has no Select Trigger configured and the data
array size is greater than one, the tags referenced by the embedded variables
must be tag arrays large enough to contain values determined by the Data
Array Size field.
•
CONFIGURING POWERSQL
•
PowerSQL Information Panel
•
•
Note: Options 1 and 3 are different. The result is the same for both
options, but option 3 allows the user to change the tagSQLExpression tag
to a different expression before setting a Select, Update, or Delete Trigger,
thereby altering the rows selected, updated, or deleted. Option 1 is always
static and cannot be changed at run time. Option 2 allows the user to
change the value of tagTANKID, but the SQL expression is still the same.
Only the search criterion for the WHERE clause has changed.
PowerSQL substitutes embedded variables with the value of the tag defined
in the embedded variable when executing the select, update, or delete SQL
statement.
For example:
=:tagTANKID
generates the following WHERE clause:
where TANKID = ?
TANKID is the value of the Column Name field.
PowerSQL reads the value of the tag tagTANKID from the real-time
database and substitutes its value for the ‘?’ when it executes a select,
update, or delete SQL statement.
40 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
PowerSQL Information Panel
The panel resembles the following sample panel when complete.
2
• Values where the column named TANKID equals BLUE001
• The column named OUTLET is greater than or equal to the value of the tag OUTLETVAL.
PowerSQL writes these values to the tags contained in the tag arrays TANKID[3] and
OUTLET[3]. These values are then displayed in a result window.
Each Tag Name tag displays one column of values in a result window.
Because a Tag Name tag array has been defined for TANKID and OUTLET, the values in the
columns the logical expression is true for are displayed in the result window.
FactoryLink / PowerSQL User Guide / 41
Configuring
PowerSQL
Because the Select Trigger tag SELTAG1 (defined in the Control panel) is digital in this
example, the Historian returns the two following values to PowerSQL when the change-status
flag for SELTAG1 is set:
•
CONFIGURING POWERSQL
•
Stored Procedure Example for Oracle
•
•
S TORED P ROCEDURE E XAMPLE
FOR
O RACLE
-- echo Building Oracle Package PKGCSP03...
drop package PKGCSP03;
Create or replace package PKGCSP03 as
type char_array is table of varchar2(10)
index by binary_integer;
type int_array is table of integer(10)
index by binary_integer;
procedure updsel_trendtbl (
inrecs in integer,
key in integer,
newtime in string,
addsec in integer,
outtime out char_array,
outsec out int_array,
outrecs in out integer);
End PKGCSP03;
/
Create or replace package body PKGCSP03 as
cursor c1 (key in integer) is
select fltime, flsec from trendtbl where trendkey >= key;
procedure updsel_trendtbl (
inrecs in integer,
key in integer,
newtime in string,
addsec in integer,
outtime out char_array,
outsec out int_array,
outrecs in out integer) is
begin
update trendtbl set
fltime = newtime,
42 / FactoryLink / PowerSQL User Guide
CONFIGURING POWERSQL
Stored Procedure Example for Oracle
flsec = flsec + addsec
where trendkey = key;
commit work;
if c1%ISOPEN, then
close c1; -- close cursor if it is open
end if;
open c1(key); -- open cursor
outrecs: = 0; -- init rows found
for i in 1..inrecs loop
fetch c1 into outtime(i), outsec(i);
if c1%NOTFOUND, then
close c1; -- close cursor if no rows found
exit;
else
outrecs: = outrecs + 1; -- count row found
end if;
end loop;
2
End PKGCSP03;
/
commit;
Note: USDATA is not responsible for any changes in Oracle. Please refer
to the Oracle manual for any changes.
FactoryLink / PowerSQL User Guide / 43
Configuring
PowerSQL
end updsel_trendtbl;
•
CONFIGURING POWERSQL
•
Limitations and Problems
•
•
L IMITATIONS
AND
P ROBLEMS
This section lists some untested features, known problems, or limitations related to the use of
PowerSQL.
• IBM DB2 2.12 does not support stored procedures.
• Stored procedure execution using IBM DB2 version 5.0 ODBC Driver have not been tested
• MERANT ODBC drivers do not support the use of INOUT parameters in stored procedures.
• The PowerSQL task supports a feature that permits arrayed operations for updating a
supported relational database. Instead of providing a single set of data points to update a
single row in a database, this feature uses arrays of data to perform multiple updates. The
operation can be implemented in a batch or non-batch mode. The batch mode is the most
efficient. At completion, it is designed to update an array of status tags for each set of data
points (or each operation). For example, a batch operation is triggered to insert 100 rows
using 100 different sets of data. Suppose one data set results in a duplicate index key error
violation. Ideally, the status tags should indicate 99 successful inserts and one error
condition—duplicate index key.
However, testing with various ODBC drivers behave differently to this situation as noted in
the following list:
• Microsoft Access97 ODBC Driver—Inserts rows only until the error is encountered and
aborts the rest of the operation. Status information is only valid up to the row that failed.
• Microsoft SQL Server 6.5 Driver—Inserted data is correct. Duplicate row is not inserted.
However, the driver does not return an error message that allows for proper update of the
status for that row.
• MERANT Sybase Driver—Same as Microsoft SQL Server 6.5 Driver.
• MERANT Oracle Driver—Works as designed.
• IBM DB2 version 2.12 and 5.0 Drivers—Once an error is encountered, it aborts the entire
set of operations. The failure status is properly returned for all rows.
Other drivers not listed here may also yield results in an unexpected manner.
44 / FactoryLink / PowerSQL User Guide
•
•
•
•
Chapter 3
PowerSQL Status Codes and
Status Messages
When an error occurs at run time in PowerSQL, the Historian, or another Historian-client task,
FactoryLink sends a status code or status message for display to the Run-Time Manager screen
and to the Completion Status tag. FactoryLink also sends a longer, more descriptive message to
the log file if you created a log file. This section describes the error messages that can be
displayed on the Run-Time Manager screen for the PowerSQL task.
The codes and messages are displayed on a graphics screen if you define an output text object
to display them.
Code
Error
Cause
Action
100
Asynchronous error
from Historian
function.
An SQL COMMIT
operation failed within the
Historian.
Consult the database
administrator for the external
database in use.
101
Error from Historian
function.
A syntax error may have
been made or information
may not have been entered
in a required field in a
configuration table.
Correct the SQL statement
syntax error by modifying the
Information panel for the task
receiving the error. If the
information is correct, ensure
the database table exists.
102
No fields for select.
The task is trying to execute
a select operation, but no
tag names have been
defined to hold the data
from the select operation.
Define some tag names in the
Tag Name field in the
PowerSQL Information
panel.
FactoryLink / PowerSQL User Guide / 45
3
Configuring
PowerSQL
The following table lists status codes written to a numeric Completion Status tag defined in the
PowerSQL Control panel. The descriptive message is written to a message Completion Status
tag and may also be written to the Task Message tag in the System Configuration panel. For
status codes smaller than 100, refer to “Historian Messages” on page 253 of the FactoryLink
ECS Reference Guide. The Historian generates these codes, and they are returned to
PowerSQL when an Historian operation is executed.
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
103
No fields for insert.
The task is trying to execute
an insert operation, but no
tag names have been
defined to hold the data
from the insert operation.
Define some tag names in the
Tag Name field in the
PowerSQL Information
panel.
104
No fields for update.
Task is trying to execute an
update operation, but no tag
names have been defined to
hold the data from the
update operation.
Define some tag names in the
Tag Name field in the
PowerSQL Information
panel.
105
Update and delete
operations not
supported with
multi-table view.
Update and delete
operations cannot be
performed when using
multi-table view.
Do not perform update and
delete operations when using
multi-table view.
106
Cannot update until
select is performed.
A select trigger is defined, Execute a select operation
but a select operation has
and then retry the update
not executed. A select
operation.
operation must be executed
before an update operation.
107
Cannot delete until
select is performed.
A select trigger is defined, Execute a select operation
but a select operation has
and then retry the delete
not been executed. A select operation.
operation must be executed
before a delete operation.
108
Cannot move until
select is performed.
A select trigger is defined, Execute a select operation
but a select operation has
and then retry the move
not been executed. A select operation.
operation must be executed
before a move operation.
109
This row of data has
been deleted.
A delete operation
attempted on a nonexistent
row
110
A FactoryLink
function returned an
error.
FactoryLink PAK function Contact Customer Support.
encountered an unknown or
unexpected error.
46 / FactoryLink / PowerSQL User Guide
No action required.
POWERSQL STATUS CODES AND STATUS MESSAGES
A file function error
occurred.
System encountered an
unknown error while trying
to read or write to the
external buffer.
If there is enough disk space,
contact Customer Support. If
there is not enough space,
decrease the buffer size.
112
Bad tag in logical
expression.
Either a typographical error
exists or an undefined or
invalid tag name is entered
as an embedded variable tag
in a Logical Expression
field.
Correct typographical errors.
If you did not make a
typographical error, then
define the tag in a
FactoryLink task other than
PowerSQL.
113
Invalid use of tag in
logical expression.
Logical expression does not Correct typographical errors
contain a valid tag name.
and ensure the tag name is the
name of a valid tag.
114
HSDA structure too
small.
Invalid use of a tag in
logical expression.
115
Cannot open log file. Disk space too low.
If disk space is low, delete
unneeded files or programs;
otherwise, contact Customer
Support.
116
A request for memory Internal error.
failed.
Contact Customer Support.
117
Cannot find unique
index for table.
Define the tag used in the
logical expression in a
FactoryLink task other than
PowerSQL.
A positional update or
Create a unique index for the
delete operation occurred
table and retry the operation.
on a table without a unique
index.
FactoryLink / PowerSQL User Guide / 47
3
Configuring
PowerSQL
111
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
118
PowerSQL
Information record
has an invalid
configuration.
The information record has Change the information
an assignment statement,
record.
and the logical operator
and/or logical expression
are configured. The
assignment statement
references either a numeric
constant or a string literal,
and a tag is configured in
the Tag Name field. The
assignment statement has a
substitution marker with no
associated tag in the Tag
Name field.
119
Tag array is too small A tag referenced in the
for PowerSQL
information panel is not
operation.
large enough to contain
Data Array Size values.
Change the dimension for the
tag or enter another tag large
enough to contain Data Array
Size values.
One of the following messages is displayed to the right of SQLTASK on the Run-Time
Manager screen if an error occurs with PowerSQL or Historian at run time. The first three
letters in the message are a variable that indicates whether the message came from PowerSQL
or from the Historian (HIS). This variable’s three-letter prefix displays in the messages below
as nnn. Open the .LOG file to display the complete message if it is truncated on the Run-Time
Manager screen.
nnn-[BAD_SMBX] Bad send mailbox. Control name: name
Cause:
You entered the wrong mailbox tag name.
Action:
Look up the mailbox tag name for the Historian being used in the Historian
Mailbox field of the Historian Mailbox Information panel. Enter the
correct name in the Historian Mailbox field of the PowerSQL Control
panel.
nnn-[BAD_WHERE_TAG] Bad tag name for logical expression. Control name:
name
Cause:
Either you made a typographical error or entered an undefined or invalid
tag name as the embedded message tag in a logical expression.
Action:
Correct all typographical errors. Define the tag in a FactoryLink task other
than PowerSQL if you did not make a typographical error.
48 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
nnn-[CT_HDR] No sel, upd, or delete trigger defined. Control name: name
Cause:
None of the following triggers is defined:
- Select
- Delete
- Update
Action:
Define at least one of the triggers listed above.
nnn-[DBTBL_SYNTAX] The Database Table value is missing a ‘.’. Control name:
name
Cause:
You left the ‘.’ out of the entry in the Database Table Name field in the
PowerSQL Control panel.
Action:
Put a ‘.’ between the database name and the table name in the entry in the
Database Table Name field.
nnn-[FL_FUNC] Function ‘function’ returned error error code. Control name:
name
The FactoryLink PAK function encountered an unknown or unexpected
error.
Action:
Contact Customer Support.
nnn-[FL_FUNC] Function ‘FL_WRITE’ returned error 9. Control name: control
name
Cause:
The column type in the database that FactoryLink is trying to read from
does not match the column type defined in the Database Logging task
Schema Creation table.
Action:
Redefine the column type in the Column Type field of the Schema
Creation table to be the same as the column type in the database.
nnn-[HSCONNECT] Failed to connect to Historian
Cause:
You may have specified the wrong mailbox tag name.
Action:
Specify the Historian predefined mailbox tag name in the Historian
Mailbox field in the PowerSQL Control panel.
nnn-[HSDA_TOO_SMALL] HSDA structure too small. Control name: name
Cause:
You specified an invalid tag in a logical expression.
FactoryLink / PowerSQL User Guide / 49
Configuring
PowerSQL
Cause:
3
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
Action:
Define the tag used in the logical expression in a FactoryLink task other
than PowerSQL. The tag will then be valid in the logical expression.
nnn-[HSDBERROR] Historian database error: error message
Cause:
This message is accompanied by various other messages that describe the
cause of the error.
Action:
Read the accompanying message displayed on the Run-Time Manager
screen or in the .LOG file and correct the problem based on the instructions
in the message.
nnn-[HSDUPLICATE] Tried to insert a duplicate row
Cause:
You tried to insert a duplicate row into a result table.
Action:
No action required.
nnn-[HSENDOFETCH] Last row fetched or row not found
Cause:
The task could not find a row during an update operation because that row
does not exist. Or, during a move or position operation, you specified a
nonexistent row (for example, row 100 when the table has only 50 rows).
You attempted to go past the end or above the beginning of the result table.
Action:
No action required.
nnn-[HSFLDEXISTS] Tried to add an existing field
Cause:
You tried to add an existing field.
Action:
No action required.
nnn-[HSMAXOPENS] Too many open sessions
Cause:
You tried to open data from more than ten unique databases.
Action:
Reference fewer than ten unique databases in a configuration table.
nnn-[HSMEMORY] Memory error malloc failed
Cause:
Not enough memory is allocated for the Historian.
Action:
Allocate more memory for the Historian.
nnn-[HSNOFIELD] Tried to access a nonexistent field
Cause:
You tried to open a nonexistent field.
50 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
Action:
No action required.
nnn-[HSNOTABLE] Tried to access a nonexistent table
Cause:
You tried to open a nonexistent table.
Action:
No action required.
nnn-[HSPREPARE] Failed to prepare stmtid
Cause:
A nonexistent table name or field name is specified or a syntax error is
made in an SQL statement.
Action:
Ensure all entries in the PowerSQL table are correct, especially those for
the SQL statement.
nnn-[HSSTMTID] Invalid stmtid returned from Historian
The Historian shut down before PowerSQL or another Historian-client
task.
Action:
Shut down PowerSQL and all other Historian-client tasks running on the
system. Then, shut down the Historian and restart it, followed by
PowerSQL and all other Historian-client tasks.
nnn-[HSTBLEXISTS] Tried to create an existing table
Cause:
You tried to create an existing table.
Action:
No action required.
nnn-[HSTIMEDOUT] Historian not responding. Maximum timeout exceeded.
Cause:
A PowerSQL request did not get a response from Historian within the
timeout period.
Action:
If the timeout period is less than the time taken to serve the request, you
may increase the timeout, e.g., from -w300 to -w400.
nnn-[HSUNKNOWN] Unknown function request sent to Historian
Cause:
An error occurred within PowerSQL.
Action:
Contact Customer Support.
FactoryLink / PowerSQL User Guide / 51
3
Configuring
PowerSQL
Cause:
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
nnn-[INVUSE_WHERE_TAG] Invalid use of tag in logical expression. Control
name: name
Cause:
A logical expression contains an invalid tag name.
Action:
Correct all typographical errors and ensure the tag name is valid.
nnn-[MULTI-VIEW] Update and delete operations not supported with multi-table
view. Control name: name
Cause:
You tried to perform an update or delete operation while using multi-table
view.
Action:
Do not try to perform update or delete operations.
nnn-[NO_FLDS_INS] No fields for insert. Control name: name
Cause:
The task is trying to perform an insert operation but no tag names are
defined to hold the data from the insert operation.
Action:
Define some tag names in the Tag Name field of the PowerSQL
Information panel.
nnn-[NO_FLDS_SEL] No fields for select. Control name: name
Cause:
The task is trying to execute a select operation but no tag names are
defined to hold the data from the select operation.
Action:
Define some tag names in the Tag Name field of the PowerSQL
Information panel.
nnn-[NO_FLDS_UPD] No fields for update. Control name: name
Cause:
The task is trying to execute an update operation, but no tag names have
been defined to hold the data from the update operation.
Action:
Define some tag names in the Tag Name field of the PowerSQL
Information panel.
nnn-[NO_LOGICAL_EXPR] No logical expr. Control name: name. Column name:
name
Cause:
A logical operation was defined, but the logical expression was not
specified.
Action:
Either delete the operation or create a logical expression.
52 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
nnn-[NO_MEMORY] Out of RAM
Cause:
Not enough RAM is available to run this task.
Action:
Allocate more RAM for the PowerSQL task.
nnn-[NOTASSOC] Col name name not associated with Tag Name or Logical
Expression. Control name: name
Cause:
A non-existent or invalid tag name is specified. A column name is also
specified, but not a logical expression.
Action:
Define a tag in the Tag Name field of the PowerSQL Information panel
and/or specify a logical expression.
nnn-[NO_UNIQ_INDX] Cannot find unique index for table. Control name: name
Cause:
You attempted a positional update or delete operation on a table without a
unique index.
Action:
Create a unique index for the table and retry the operation.
Cause:
You attempted a delete operation on a deleted row.
Action:
No action required.
nnn-[NULL_TABLE] No data for this table. Control name: name
Cause:
You tried to perform an update, move, or delete operation on a result table
that contains no rows of data for either of two reasons: the select operation
resulted in no rows of data or you deleted all rows of data from the table.
Action:
No action required.
nnn-[OPEN_LOG] Cannot open .LOG file.
Cause:
The computer may have run out of disk space.
Action:
Delete any unnecessary files or programs. Contact Customer Support.
nnn-[SEL_B4_DEL] Cannot delete until select is performed. Control name: name
Cause:
A select trigger is defined, but a select operation was not executed. A
select operation must be executed before a delete operation can be
performed.
Action:
Execute a select operation and then retry the delete operation.
FactoryLink / PowerSQL User Guide / 53
Configuring
PowerSQL
nnn-[NULL_ROW] This row of data was deleted. Control name: name
3
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
nnn-[SEL_B4_MOVE] Cannot move until select is performed. Control name: name
Cause:
A select trigger is defined, but a select operation was not executed. A
select operation must be executed before a move operation can be
performed.
Action:
Execute a select operation and then retry the move operation.
nnn-[SEL_B4_UPD] Cannot update until select is performed. Control name: name
Cause:
A select trigger is defined, but a select operation was not executed. A
select operation must be executed before an update operation can be
performed.
Action:
Execute a select operation and then retry the update operation.
nnn-[SQL_ASYNC] Asynchronous failure to name. Error: error message.
Cause:
An SQL COMMIT operation failed within the Historian. For Oracle, it can
fail if you do not have enough disk space.
Action:
Consult the database administrator for the external database in use.
nnn-[SQL_SYNC] Historian function function failed. Error: error message Control
name: name
Cause:
A syntax error may have been made or there may not be any information in
a required field in a configuration table.
Action:
Modify the information in the PowerSQL Information panel to create a
correct SQL statement if the error is a syntax error. Ensure that the
database table exists if the panels are correct.
nnn-[UNSOL_MSG_RCVD] Unsolicited message received from tag number
Cause:
Another task wrote to PowerSQL’s mailbox tag (PowerSQL is not
expecting to hear from this task).
Action:
Determine which task is writing to PowerSQL’s mailbox tag by looking at
the X-reference list in the Configuration Manager Main Menu. Correct the
problem by changing the mailbox tag name of the task writing to
PowerSQL’s mailbox tag.
F_BAD_CT_SIZE Bad size for CT # CT number
Cause:
There is a discrepancy between the PowerSQL script file and the size. You
may have modified the PowerSQL .CTG file.
54 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
Action:
Copy the .CTG file from the Installation disk over the modified one.
Contact Customer Support if this cannot solve the problem.
F_BAD_RMBX Invalid global mailbox: mailbox name
Cause:
PowerSQL’s predefined mailbox tag is nonexistent in the GLOBAL.CT
file.
Action:
Contact Customer Support.
F_INIT Task initialization failed
Cause:
This message is preceded by another error message that explains the cause
of the error.
Action:
Examine the preceding message to determine the cause of the initialization
failure.
3
F_NO_CTS No valid tables in CT archive file name
The PowerSQL table has been configured.
Action:
Configure the PowerSQL table.
F_NO-DOMAIN_NAME No domain name for appl. directory directory
Cause:
No domain name is specified for the application directory.
Action:
Specify a domain name for the application directory.
F_OPEN_CT Cannot open CT archive file name
Cause:
A .CT file may have been deleted.
Action:
Use CTGEN to rebuild the .CT file.
F_READ_CT Cannot read CT # CT number in CT archive file name
Cause:
A .CT file is corrupt.
Action:
Rebuild the corrupt .CT file.
nnn-[HSENDOFETCH] Tried to move beyond the end of result table
Cause:
A move operation tried to place current row to a row beyond the result
table.
Action:
No action required.
FactoryLink / PowerSQL User Guide / 55
Configuring
PowerSQL
Cause:
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
nnn-[HSENDOFETCH] Tried to move beyond the top of result table or view
Cause:
A move operation tried to place current row to a row beyond the result
table.
Action:
No action required.
nnn-[HSENDOFETCH] Move operation failed due to an empty result table
Cause:
Cannot perform move operation on an empty result table.
Action:
No action required.
nnn-[HSENDOFETCH] Absolute move did not move to requested row because it
is deleted
Cause:
Absolute move cannot set active row to a deleted row.
Action:
No action required.
nnn-[HSENDOFETCH] Move operation failed because all rows deleted in desired
direction
Cause:
Cannot move in a certain direction because all rows have been deleted in
that direction.
Action:
No action required.
nnn-[INCORRECT_MODE] Record recnumber mode type does not match SQL
operation. Control name: name
Cause:
The SQL statement in Dynamic Tag does not match the mode type for the
PowerSQL information record. It must be a type of $INPUT, $OUTPUT,
or $INOUT.
Action:
Change the SQL statement in PowerSQL tag or change the information
record to the correct mode.
nnn-[INPUTROWS] Input rows must be between 1 and Data Array Size. Control
name: name
Cause:
The current row tag must be between 1 and Data Array Size.
Action:
Set current row tag to a value between 1 and Data Array Size and then
retry operation.
56 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
nnn-[DYNAMIC_COLUMNS] Only $OUTPUT, $INPUT, $INOUT column
expressions allowed. Control name: name
Cause:
A Column Expression field in information panel must contain $OUTPUT,
$INPUT, or $INOUT reserved words to execute SQL statement that is in
the PowerSQL tag.
Action:
Change the column expression field to $OUTPUT, $INPUT, or $INOUT.
nnn-[SQLTRIGGER] Only SELECT or UPDATE trigger allowed. Control name:
name
Cause:
Only a SELECT or UPDATE trigger can be configured to execute a
statement that is contained in a PowerSQL Tag.
Action:
Configure a SELECT or UPDATE trigger.
nnn-[INSERT_TRIG] SELECT or DELETE trigger not allowed. Control name: name
When an INSERT trigger is configured, a SELECT and/or DELETE
trigger cannot be configured.
Action:
Remove the SELECT and/or DELETE trigger in the control record.
nnn-[SQLEMPTY] SQL message tag is an empty string. Control name: name
Cause:
PowerSQL tag is empty.
Action:
Set the PowerSQL tag with a valid SQL statement.
nnn-[DESCRIBE] Only one $OUTPUT record allowed. Control name: name
Cause:
To use the DESCRIBE TABLE statement, only one information record is
allowed, the column expression must be $OUTPUT, and the Tag Name
must reference a message tag.
Action:
Change information record column expression field to $OUTPUT and
ensure that a message tag is placed in the Tag Name field.
nnn-[ARRAY_TOO_SMALL] TAG array in record recnumber is too small. Control
name: name
Cause:
The tag array is too small based upon the Data Array Size field value.
Action:
Enlarge the tag array to ensure that the Data Array Size values can be
stored in the tag array.
FactoryLink / PowerSQL User Guide / 57
3
Configuring
PowerSQL
Cause:
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
nnn-[TAG_TOO_SMALL] TAG tagname dimensions too small. Control name:
name
Cause:
The dimensions of the tag that is referenced in an information record Tag
Name or Logical Expression field is not large enough to store Data Array
Size values.
Action:
Change the dimensions of the tag to ensure the Data Array Size values that
can be stored in the tag array.
nnn-[DESCRIBE_TAG] Message TAG type required for output of a DESCRIBE
TABLE statement. Control name: name
Cause:
To use the DESCRIBE TABLE statement, only one information record is
allowed, the column expression must be $OUTPUT, and the Tag Name
must reference a message tag.
Action:
Change information record column expression field to $OUTPUT and
ensure that a message tag is placed in the Tag Name field.
nnn-[INVTAG_SYNTAX] Invalid tag syntax: tagname
Cause:
Incorrect tag name syntax entered in the Logical Expression field of
information record.
Action:
Enter a valid tag name and ensure that the tag is defined in the application.
nnn-[NO_OBJ_CT] Cannot access OBJECT CT
Cause:
Internal error; cannot access the Tag Name database.
Action:
Contact Customer Support.
nnn-[NO_FIND_TAG] Cannot find tag: tagname
Cause:
The tagname referenced in the Logical Expression field of information
record cannot be found. Either the tag is misspelled, or the tag has not been
defined somewhere else in the application.
Action:
Check spelling or define the tag somewhere else in the application.
nnn-[TAG_WRONG_DOMAIN] Tag tagname cannot be referenced by domain
domain type.
Cause:
The tagname referenced in the Logical Expression field of information
record cannot be accessed by PowerSQL task because it is in the wrong
domain.
58 / FactoryLink / PowerSQL User Guide
POWERSQL STATUS CODES AND STATUS MESSAGES
Action:
Edit the tag so that it is accessible to PowerSQL, or enter a new tag with
the correct domain.
nnn-[INV_DIM_SPEC] Invalid dim specifiers for tag: tagname
Cause:
The tagname referenced in the Logical Expression field of information
record has an invalid dimension specifier.
Action:
Ensure that the dimensions of the tag are correct based on the tag
definition.
nnn-[UPDCOL_EXPR] Column assignment column expression cannot have other
fields configured. Control name: name
Cause:
Ensure that the Logical Operator and Logical Expression fields are empty
and make sure Tag Name field is correct for the column assignment
expression entered into the Column Expression field.
nnn-[FL_FUNC] Error reading tag. Error = error code. Control name: name
Cause:
The fl_read FactoryLink PAK function call encountered an unknown or
unexpected error.
Action:
Contact Customer Support.
nnn-[FL_FUNC] Error writing tag. Error = error code. Control name: name
Cause:
The fl_write FactoryLink PAK function call encountered an unknown or
unexpected error.
Action:
Contact Customer Support.
nnn-[INPUTS_TOO_SMALL] Not enough input records configured for SQL
operation. Control name: name
Cause:
The PowerSQL tag in the control record references more input variables
than what has been configured in the PowerSQL information panel.
FactoryLink / PowerSQL User Guide / 59
3
Configuring
PowerSQL
Action:
For column assignment:
1) The Logical Operator or Logical Expression fields in the information
record cannot be configured, or
2) The column assignment expression references a substitution variable
“?”, and no Tag Name field is configured, or
3) The Tag Name field is configured but the column assignment expression
in the Column Expression field does not contain a substitution variable
“?”.
•
POWERSQL STATUS CODES AND STATUS MESSAGES
•
•
•
Action:
Add more input records to the PowerSQL information panel, or change the
SQL statement in the PowerSQL tag.
nnn-[OUTPUTS_TOO_SMALL] Not enough output records configured for SQL
operation. Control name: name
Cause:
The PowerSQL tag in control record references more output result
columns than what has been configured in the PowerSQL information
panel.
Action:
Add more output records to the PowerSQL information panel, or change
the SQL statement in the PowerSQL tag.
nnn-[INPUTS_UNEQUAL] The number of input records does not match SQL
requirements. Control name: name
Cause:
The SQL statement generated by PowerSQL does not match what is
configured in the PowerSQL information panel.
Action:
Contact Customer Support.
nnn-[OUTPUTS_UNEQUAL] The number of output records does not match SQL
requirements. Control name: name
Cause:
The SQL statement generated by PowerSQL does not match what is
configured in the PowerSQL information panel.
Action:
Contact Customer Support.
60 / FactoryLink / PowerSQL User Guide
Index
Symbols
$INOUT 36, 37
$INPUT 36
$OUTPUT 36
*Database.Table Name field 26, 36
*Insert Trigger Auto Create field 23
A
active row 24
alternate conditions 35
alternate negated conditions 35
analog tag 31
AND 35
AND_NOT 35
Application Editor 31
B
back slash 27
buffer 13
C
cache 24, 30
change-status flag 31, 41
colon 37
column 34
column expression 37
Column Expression field 27, 35, 36, 38
column name 14
Column Name field 36
comma 28
Completion Status field 31
Completion Status tag 31, 45
message 45
numeric 45
Completion Trigger field 31
conditional statement 35, 38
conditions 35
alternate 35
alternate negated 35
negated 35
Configuration Manager Main Menu 20
constant
numeric 36
string 26, 28, 36, 39
Control Name field 20
control record 20, 26, 30, 31, 35, 36, 37, 39
copy 31
COUNT 36
curly brackets 28
Current Row tag 21, 24, 25
Current Row Tag field 21, 23, 24, 29
current time 36
D
data array size 24, 29, 30, 39
Data Array Size (Rows) field 16, 21, 23, 24, 30, 31,
34, 39
database alias name 26, 27
Database Browser Control panel
Index I-61
sample 32
Database Schema Creation 21, 22
database table 39
database table name 27
database-stored procedure 28
delete operation 12, 16, 22, 34
logical 16, 23, 26, 29, 30, 39
multiple rows 23
positional 16, 22, 26, 29
single row 23
delete trigger 26, 27, 40
Delete Trigger field 22
dimension 37
disk 31
domain
shared 19, 20
user 19, 20
download 31
Dynamic SQL Control panel 34, 36, 39
Dynamic SQL Information panel 21, 23, 29, 32, 34
Dynamic SQL tag 26, 28, 35
Dynamic SQL Tag field 27, 36
E
embedded variable 37, 38, 39
error codes 31
errors 32
escape sequence 28
expression, logical 14, 16
F
failure 31
function
COUNT 36
MAX 36
I-62 FactoryLink
G
graphics 16, 30, 31, 45
greater than 38
greater than or equal to 38
grid 30
GROUP BY 38
H
Historian 11, 17, 26, 27, 31, 36, 41, 45, 48
Historian Mailbox field 26
Historian, dBASE IV 22, 35, 36, 38, 39
I
index 21, 22, 27, 35, 39
input 31, 36
input variable 27, 28
insert operation 12, 16, 26, 29, 30, 31, 34, 36
multiple rows 23
one row 23
insert trigger 23, 26, 27
internal cache size 24, 30
Internal Cache Size (Rows) field 25, 30, 31
L
less than 38
less than or equal to 38
Local Operator field 38
log file 45
logical delete 16, 23, 26, 29, 30, 39
logical expression 14, 16, 35, 38, 39, 41
Logical Expression field 35, 36, 37, 38
logical operator 14
Logical Operator field 35, 36
logical update 16, 21, 23, 26, 29, 30, 31, 39
longana tag 31
M
macro 36
mailbox tag 11, 26, 30, 37
Math & Logic 11, 32, 37
MAX 36
Maximum Character Data Size field 37
memory 31
message size 30
message tag 11, 12, 16, 27, 31, 36, 37, 39
messages 31
move operation 29, 30
relative 24
move trigger 24, 27
Move Trigger field 24, 30
N
negated conditions 35
NOT 35
not equal to 38
null 38
numeric constant 36
O
ODB 28
operation
delete 12, 16, 22, 34
insert 12, 16, 26, 29, 30, 31, 34, 36
move 29, 30
position 29, 30
select 11, 14, 16, 29, 30, 35, 36
update 12, 16, 34, 36
operator
AND 35
AND_NOT 35
logical 14
NOT 35
OR 35
OR_NOT 35
relational 38
optional clause 28
OR 35
OR_NOT 35
ORDER BY 38, 39
output 31, 36
output text object 45
overflow 13
P
parentheses 28
period 27
PLC 31
position operation 29, 30
position trigger 27
Position Trigger field 25, 30
positional delete 16, 22, 26, 29
positional update 16, 21, 26, 29
Power VB 11
punctuation 38
back slash 27
brackets, curly 28
brackets, square 28
colon 37
comma 28
greater than 38
greater than or equal to 38
less than 38
less than or equal to 38
not equal to 38
parentheses 28
period 27
question mark 27, 28, 36, 38, 40
Index I-63
single quotation mark 27, 39
Q
question mark 27, 28, 36, 38, 40
quotation mark, single 27, 39
R
range of values 38
read only 29
relational operator 38
relative move 24
reserved word 36, 38
result table 11, 12, 13, 14, 15, 16, 20, 21, 22, 25,
27, 28, 30, 36
result window 11, 12, 16, 24, 25, 29, 30, 41
return value 28
Run-Time Manager screen 45
S
schema 21, 22
scrolling 24, 30
search 35
select operation 11, 14, 16, 29, 30, 35, 36
select trigger 22, 23, 25, 26, 27, 29, 30, 39, 40
Select Trigger field 20, 25
server 11, 17, 27, 31, 36, 37, 38
shared domain 19, 20
single quotation mark 27
square brackets 28
startup, task 23, 27
statement
conditional 38
statement, conditional 35
status codes 31, 45
status messages 31
I-64 FactoryLink
stored procedure 27, 28, 34, 36
string constant 26, 28, 36, 39
substitution marker 38
substitution variable 36
syntax 28, 38
System Configuration panel 45
T
table grid 30
table name 26, 27
tag
analog 31
array 11, 12, 21, 23, 24, 29, 30, 31, 34, 37, 39,
41
current row 21
longana 31
mailbox 11, 26, 30, 37
message 11, 12, 16, 27, 31, 36, 37, 39
tag array 11, 12, 21, 23, 24, 29, 30, 31, 34, 37, 39,
41
Tag Definition dialog 21, 22, 23, 24, 25, 26, 27, 28,
29, 31, 32, 34
Tag Name field 30, 34, 36
Tag Name tag 36, 41
Task Message tag 45
task startup 23, 27
time stamp 36
time, current 36
trigger
delete 22, 26, 27, 40
insert 23, 26, 27
move 24, 27, 30
position 25, 27, 30
select 20, 22, 23, 25, 26, 27, 29, 30, 39, 40
update 21, 26, 27, 40
U
update operation 12, 16, 34, 36
logical 16, 21, 23, 26, 29, 30, 31, 39
multiple rows 21
positional 16, 21, 26, 29
single row 21
update trigger 26, 27, 40
Update Trigger field 21
user domain 19, 20
V
variable
embedded 37, 38, 39
input 27, 28
substitution 36
W
WHERE clause 14, 15, 35, 36, 38, 39, 40
Index I-65
