CQD-440/443

,..........

~~ --------

-

Q

CQD-440/443

High Performance Q-bus

FAST SCS!-2 Smart

H~st

Adapter

User's Manual

\ i

~U~CMD

§

ETECHNOLOGr~~~~~

~/NC.

CQD-440/443

High Performance Q-bus

FAST SCS!-2 Smart Host Adapter

User's Manual

MAN-000440-000

Rev. 1.0

CMD Technology, Inc.

] Vanderbilt

Irvine, CA 92718

(7] 4) 454-0800

Copyright

Disclaimer

FCC Notice

Warranty

This manual is copyrighted and all rights are reserved. No portion of this document may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior written consent from CMD Technology, Inc. (CMD).

CMD, CMD Technology, CQD-440 and CQD-443 are all trademarks of CMD Technology, Inc. All other product and company names are trademarks and registered trademarks of other manufacturers.

Copyright

©

CMD Technology, Inc. January 1992. All rights reserved.

CMD reserves the right to make changes to this manual and the equipment described herein without notice. CMD has made all reasonable efforts to insure that the information in this manual is accurate and complete. However, CMD shall not be liable for any technical or editorial errors or omissions made herein or for incidental, special, or consequential damage of whatsoever nature resulting from the furnishing of this manual, or operation and performance of equipment in connection with this manual.

Class A Computing Device:

This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cau~ harmful interference in which case the user will be required to correct the interference at his own expense.

BASIC WARRANTY In the absence of any optional warranty or continuing provisions by formal agreement, CMD warrants its products in accordance with the schedules listed below. Purchaser hereafter mentioned refers at all times to the customer who purchased CMD product(s).

HOST ADAPTER WARRANTY - CMD warrants Host Adapter products of its manufacture to be free from defect in material and workmanship for a period of one year from the date of shipment.

During this period, if the customer experiences difficulties with a CMD Host Adapter and is unable to resolve the problem via phone with CMD Technical Support, a Return Material Authorization (RMA) will be issued. Following receipt of an RMA, the Purchaser is responsible for returning the product to CMD, freight prepaid. CMD, upon verification of warranty, will repair or replace at its option the Host Adapter in question, and will then return the product to the Purchaser, freight prepaid.

CABLE WARRANTY - All CMD provided cables are warranted for ninety (90) days from the time of shipment. Questionable cables should be returned to CMD, freight prepaid, where they wil1 be repaired or replaced by CMD at its option and returned to the Purchaser, freight prepaid.

GENERAL TERMS - The above warranties shall not apply to expendable components such as fuses, bulbs, and the like, nor to connectors, adapters, and other items not a part of the basic product. CMD shall have no obligation to make repairs or to cause replacement required through normal wear and tear or necessitated in whole or in part by catastrophe, fault or negligence of the user, improper or unauthorized use of the product, or use of the product in such a manner for which it was not designed, or by causes external to the product, such as, but not limited to, power failure or air conditioning. CMD's sole obligation hereunder shall be to repair or replace any defective product, and, unless stated, pay return transportation costs within the United States of

America for such replacement. Purchaser shall provide labor for removal of the defective product, shipping charges for return to CMD and installation of its replacement. On-site services are not a part of this warranty. Above warranties are subject to change without notice.

RETURNED MATERIAL - Warranty claims must be received by CMD within the applicable warranty period. A replaced product, or part thereof, shall become the property of CMD and shall be returned to CMD at Purchaser's expense. All returned material must be accompanied by a Return Materials Authorization (RMA) number assigned by CMD. For RMA numbers call CMD at

(714) 454-0800.

THE EXPRESSED WARRANTIES SET FORTH IN THIS AGREEMENT ARE IN UEU OF ALL

OTHER WARRANTIES, EXPRESSED OR IMPUED, INCLUDING WITHOUT UMIT ATION,

ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,

AND ALL SUCH OTHER WARRANTIES ARE HEREBY DISCLAIMED AND EXCLUDED BY

CMD. THESE STANDARD EXPRESS WARRANTIES ARE IN LIEU OF ALL OBUGA nONS OR

LIABILITIES ON THE PART OF CMD FOR DAMAGES, INCLUDING BUT NOT LIMffiD TO

SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNEC-

TION WITH THE USE OR PERFORMANCE OF THE PRODUCT.

Return and

Repair Policy

WARRANTY PERIOD

The following warranty period is from the date of shipment:

CMD Host Adapter one year

Cable

Drive

90 days manufacturer's warranty

RETURN FOR CREDIT

The allowable period of return for credit from the date of shipment is as follows

CMD Host Adapter

Cable

Drive less than 90 days less than 60 days not applicable

RETURN FOR REPAIR

CMD Host Adapter

In-Warranty (Less then 1 year)

• CMD offers a 15

working day turnaround repair service

at the cost of parts only. Defective boards will be repaired and returned to the customer within 15 working days from the date of return to CMD.

• CMD also offers two

in-warranty

24

hour expediting

services:

24 Hour Turnaround Loaner Service:

Under this policy, CMD will ship a loaner in 24 hours during regular working days to the customer for a charge of $100.00 per loaner. Upon receiving the loaner, customer must return the defective board to CMD within seven

(7) days for repair. CMD will repair the defective board and return the board to the customer. Customer must then return the loaner in seven (7) days after the receipt of the repaired board. Approval for loaner service is based on credit verification.

24 Hour Turnaround Swap Service:

In the case that the defective board is within the first six (6) months of the warranty, CMD, at its own option, offers a 24 hour turnaround swap service. CMD will ship the same model of the board to customer within 24 hours during working days in exchange for the defective board. CMD will swap with a new board if board is not functional upon arrival.

For all other cases, swap will occur with either a new or refurbished board for a charge of

$200.00. CMD does not offer swap services for boards that are purchased more than six months from the date of shipment. Customer is responsible for returning the defective board to CMD within seven

(7) days after receipt of the swapped board.

• The remaining warranty period shall apply to the repaired or swapped board.

Out-of-Warranty (more than 1 year)

• CMD offers a 15

working day turnaround repair seroice

at a rate of $300.00 plus parts and freight for all out-of-warranty host adapter boards. Defective boards will be repaired and returned to customer within 15 working days starting with date of return to CMD.

• CMD also offers an

Out-of-Warranty

24

Hour Turnaround Loaner Service:

Under this policy, CMD will ship the same model loaner in the 24 hour time frame of working days to customer for an additional charge of $100.00 plus freight per loaner. The loaner is for use by the customer during the period that the defective board is being repaired. Customer is responsible for returning the defective board to CMD within seven days after the receipt of loaner and returning the loaner in seven

(7) days once the defective board is repaired and received. The approval of the loaner service is at CMD's option and based upon customer credit verification.

• CMD will extend warranty for a period of six (6) months on any out ofwarranty repaired board.

Cable

In-Warranty (90 days) - free swap.

Out-of-Warranty (90 days) - not applicable.

Drive

In-Warranty (per manufacturer) - manufacturer charge only.

Out-of-Warranty (per manufacturer) - manufacturer charge plus $100 CMD handling.

RETURN FOR UPGRADE/ UPDATE

CMD Host Adapter

In-Warranty (less than 1 year)

• CMD offers a 15

working day turnaround different function upgrade service

for boards that can be upgraded to a higher function; and a

free

15

working day turnaround ECa Field Upgrade

for all its boards. CMD will

upgrade

the hardware of its board to a higher function for a charge of the difference of list prices of the original and upgraded functions. CMD will al~ update its board to its latest firmware release at no charge to the customer. Boards will be upgraded/updated and returned to the customer within 15 working days from the date of return to.CMD.

• CMD also offers 24

hour turnaround loaner service

as stated in

"RETURN FOR REPAIR."

• The remaining warranty period shall apply to the updated board. For upgraded board~,

CMD will extend warranty for a period of six months.

Out-of-Warranty (More than 1 year)

• CMD offers a 15

working day turnaround different function upgrade service

for boards that can be upgraded to a higher function at a charge of the difference of list prices of two functions.

CMD also offers a

free

15

working day turnaround ECa Field Upgrade

for all its boards.

Boards will be upgraded/updated and returned to customer within 15 working days from the date of return to CMD.

• CMD also offers 24

hours turnaround Loaner Service

as stated in "RETURN FOR REPAIR."

• There will be no warranty extension for same function firmware update. For different function Hardware upgrade, CMD will extend warranty for a period of six (6) months.

Drive-same as in RETURN FOR REP AIR.

SHIPPING CHARGES

The following shipping charges apply to all REPAIR, SWAP, LOANER, and UPGRADE UNITS.

In-Warranty

• Domestic - freight from CMD to customer is to be paid by CMD; freight from customer to

CMD is to be paid by customer.

• International - all fees are to be paid by customer (including custom duty and broker fees).

Out-of Warranty

• Domestic - all fees are to be paid by customer.

• International - all fees are to be paid by customer (including custom duty and broker fees).

GENERAL CONDITIONS

All goods returned to CMD including returns for credit, swap returns, loaner returns, and evaluation returns shall remain in good condition. Any damage or alteration done by the customer will result in a rejection or additional charge to the customer.

Customer must consult CMD Technical Support for authorization of CMD not functional upon arrival boards and swap requests. CMD Sales personnel must be consulted for authorization of returned goods for credit and/ or evaluation.

Preface

The CQD-440/443 Rev 1.0 is an entirely new manual. Other revisions will describe changes to the previous manual in the Preface.

Preface

vii

viii

Preface

1

Introduction

How to Use this Manual

Conventions

2

Features and Specifications

Features

LED Indicators

Special Features

Multi-Hosting

Partitioning

Tape Monitor Utility

SCSlformat ON-LINE

Hardware Shadowing

Specifications

3

Installation

Determining CSR Address

Hardware Configuration

CSR Address Selection

Disk Auto Boot Selection

18- or 22-Bit Address Selection

Interrupt Level Selection

Block Mode DMA

Adaptive DMA

DMA Dwell Time

Adaptive DMA Dwell Time

Tape Fast Search Option

Table of Contents

1·1

1-1

1-2

2-1

2-1

2-3

2-4

. 2-4

2-4

2-4

2-5

2-5

2-6

3·1

3-6

3-6

3-7

3-7

3-1

3-3

3-3

3-6

3-8

3-8

3-9

Table of Contents

ix

x

Sync/ Async Mode Selection

Tape Monitor Utility and SCSlformat ON-LINE

Single-ended or Differential Mode Selection

Single-ended Active /Passive Termination

Eprom Size

Wait State for Eprom Cycles

Reset Switch

Installation

SCSI Host Adapter ID Selection

SCSI ID for Target Devices

CQD-440 Mounting Slot Selection

SCSI Bus Cabling

SCSI Bus Termination

SCSI Bus Terminator Power

Installation Procedures

4

Setup

On-Board Utility

Accessing the Utility Through the LSI or VAX System

Accessing the Utility Through the RS-232 Port

Changing L UN Offset

Formatting the Drive

Qualifying the Drive

Manually Replacing Bad Sectors

Additional Utilities

Completing Utility Functions

Unit Numbering For Devices

Multi-Hosting Configuration

Partitioning Configuration

Hardware Shadowing Configuration

Configuration Instructions

Detecting Shadowing Errors Using VMS

VMS Configuration

ULTRlX Configuration

CQD-440/TM

5

SCSI Basics

SCSI Glossary

SCSI Commands

Table of Contents

4·1

4-7

4-8

4-8

4-9

4-16

4-17

4-19

4-1

4-1

4-4

4-6

4-21

4-24

4-24

4-26

4-27

4-28

4-28

3-9

3-10

3-10

3-12

3-13

3-13

3-14

3-14

3-14

3-14

3-15

3-15

3-16

3-16

3-17

5·1

5-1

5-2

SCSI Status

SCSI Messages

SCSI Single-Ended Signals

Single-Ended Non-Shielded Connector

Single-Ended Shielded Connector

SCSI Differential Signals

Differential Non-Shielded Connector

Differential Shielded Connector

Appendices

A

Supported Devices and Operating Systems

SCSI Devices

Magnetic disk drives supported by CQD-440/TM

Erasable Optical disk drives supported by CQD-44 0 /TM

Erasable Optical disk cartridge manufacturers

CD ROM disk drives supported by CQD-440/TM

WORM drives supported by CQD-440/IM

Tape drives supported by CQD-440 /IM

Operating Systems

B

Troubleshooting

VMS Analyze/Error Utility

Cables

LED Indicators

CMD Technical Support

C

Jumper Settings

Pin Assignments

CSR Address Selections

D

VMS SYSGEN Connect Statement

A-1

A-I

A-I

A-2

A-2

A-2

A-2

A-2

A-3

8-1

B-1

B-3

B-3

B-4

C-1

C-l

C-6

D-1

5-3

5-4

5-4

5-4

5-6

5-8

5-8

5-9

Table of Contents

xi

xii

Table of Contents

2

Features and Specifications

2 -1: LED Indica tors

3

Installation

3-1: Example of SYSGEN Utility

3-2: Jumper block locations

3-3: Single-ended Mode Selection

3-4: Differential Mode Selection

3-5: Pin 1 location for single-ended termination

3-6: Eprom Setting

3-7: CQD-440 non-shielded cable connection

3-8: CQD-443 shielded connection

3-9: SCSI ID and Cabling

4

Setup

4-1: Utility CSR address

4-2: Main Menu

4-3: CQD-440 RS-232 Port

4-4: CQD-443 RS-232 Port

4-5: SCSI Host Adapter Utility

4-6: Utility Sub-menu

4-7: Current configuration, default

4-8: Configuration change

4-9: SCSI host adapter ID change

4-10: Disk and Tape Configuration Change

4-11: Current configuration

4-12: Configuration change

4-13: Partitioning example

List of Figures

2-3

3-3

3-5

3-11

3-11

3-12

3-13

3-18

3-18

3-19

4-10

4-11

4-13

4-14

4-21

4-22

4-22

4-3

4-4

4-5

4-5

4-6

4-9

List of Figures

xiii

4-14: Current configuration

4-15: Hardware Shadowing example

4-16: Current configuration

5

SCSI Basics

5-1: SCSI device non-shielded connector

5-2: SCSI device shielded connector

Appendices

C

Jumper Settings

C-1: Pin Locations for J6 (CQD-440) and J7

C-2: Pin Locations for J5 (CQD-443)

D

VMS SYSGEN Connect Statement

D-1: SYSGEN Config File

D-2: Unibus Address

C-1

C-1

D-2

D-3

4-23

4-25

4-26

5-4

5-6 xiv

List of Figures

List of Tables

2

Features and Specifications

2-1: CQD-440 Models

2-2: LED Indicators

2-3: Special Feature Support List

2-4: Controller Specifications

2-5: CSR Addesses

3

Installation

3-1: CQD-440 CSR jumper settings for disk

3-2: CQD-440 CSR jumper settings for tape

3-3: Disk Auto Boot Selection

3-4: Block Mode DMA

3-5: Adaptive DMA

3-6: DMA Dwell Time

3-7: Adaptive DMA

3-8: Tape Fast Search Option

3-9: Sync/ Async Mode Selection

3-10: Tape Moni tor Utility and SCSIformat ON-LINE Options

3-11: Single-ended or Differential Mode Selection

3-12: Single-ended or Differential Mode Selection

3-13: Eprom Size Selection

3-14: Wait State for Eprom Cycles

3-15: Reset or NMI Switch

3-16: Terminator Power Option

4

Setup

4-1: Disk CSR Addresses Plus 2 Configurations

4-2: Tape CSR Addresses Plus 2 Configurations

2-2

2-3

2-4

2-6

2-7

3-7

3-8

3-8

3-9

3-9

3-10

3-10

3-12

3-13

3-13

3-14

3-17

3-4

3-4

3-6

3-7

4-2

4-3

List of Tables

xv

4-3: Default for Unit Numbers

4-4: Host Adapter ID Selection

5

SCSI Basics

5-1: SCSI Commands (MSCP)

5-2: SCSI Commands (TMSCP)

5-3: SCSI Status

5-4: SCSI Messages

5-5: Single-Ended Non-Shielded Connector Pin Assignments 02)

5-6: Single-Ended Shielded Connector Pin Assignments 02)

5-7: Differential Non-Shielded Connector Pin Assignments (11)

5-8: Differential Shielded Connector Pin Assignments 01)

Appendices

A

Supported Devices and Operating Systems

A-I: Operating Systems Supported by CQD-440/443

C

Jumper Settings

C-l: Pin Assignments for RS-232 Utility Interface

C-2: Pin Assignments for Front Panel Interface J7

C-3: Host Adapter ID Selections

C-4: Switch Settings

C-5: CQD-440 Pin Assignments

C-6: CQD-440 Pin Assignments (continued)

C-7: CQD-440/TM CSR Addresses (Disk Only)

C-8: CQD-440 /TM CSR Address Selections (Tape Only)

4-17

4-19

5-2

5-3

5-3

5-4

5-5

5-7

5-8

5-9

A-3

C-2

C-2

C-3

C-3

C-4

C-5

C-6

C-7 xvi

List of Tables

1

Introduction

This User's Guide explains the basics of your CQD-440™. It includes information on setting up and configuring the system and the CQD-440 for use.

How to Use this Manual

This guide has five chapters and four appendices. Each chapter explains a different aspect of preparing your CQD-440 for use. You may refer to the appendices for further configuration and troubleshooting information. The following descriptions summarize each section.

Chapter 1: Introduction explains the purpose of this guide and details the conventions used.

Chapter

2:

CQD-440 Features describes the CQD-440 and details its features, special features, and specifications.

Chapter 3: Installation describes hardware configuration and installation procedures for the CQD-440.

Chapter 4: Setup describes setting up and configuring the CQD-440 and your system for use; this chapter includes Multi-hosting, Partitioning, Shadowing,

VMS~, and ULTRIX® set up and configurations.

Chapter 5: SCSI Basics lists a glossary on SCSI terms, SCSI status and command codes for the CQD-440.

Appendix A: Supported Devices and Operating Systems lists the SCSI devices and operating systems compatible with the CQD-440.

Introduction 1-1

CQD-440

Appendix B: Troubleshooting gives some troubleshooting guidelines for the

CQD-440.

Appendix C: Jumper Settings lists the jumpers settings, pin assignments, and the CSR addresses for the present revision of the CQD-440.

Appendix D: VMS SYSGEN Connect Statement describes the proper use of the VMS SYSGEN Connect Statement.

Conventions

The following conventions are used in the CQD-440 User's Guide.

Keycaps-Characters in square brackets represent keys on your keyboard. For example, "Press

[ENTER]" means press the

[ENTER] key. When two or more keys are joined by a plus sign

(+), press those keys at the same time.

Commands-Italics text represents a command that can be used on a system, such

show dev duo

NOTE

Sometimes italics will be used for emphasis; at this time no action is necessary; for example,

do not remove jumper shunt W13.

Entering Text or Commands on Screen-Text or commands that must be entered on screen will be in italics and bold as show dev du; be sure to enter the text or command and press

[ENTER].

1-2 Introduction

2

Features and Specifications

The CQD-440 is an intelligent high performance quad-wide Q-bus singleended/ differential synchronous/ asynchronous (sync/ async) SCSI-2 Host

Adapter. The following sections describe the CQD-440 in more detail.

Features

The CQD-440 is fully compatible with the DEC Mass Storage Control Protocol

(MSCP) and Tape Mass Storage Control protocol (TMSCP).

The CQD-440 has one SCSI port which supports either single-ended or differential SCSI channels. You can use the single-ended SCSI channel for connecting up to 20-feet cable or the differential SCSI channel for connecting up to 80-feet cable.

The CQD-440 can be used with the LSI-11/[email protected], PDP-11/23+, Micro-PDP-

11/53®, 11/73, 11/83, 11/93,

MicroV~'

II, and MicroVAX III, VAX

4000~ and DECsystem® 5400 systems.

It supports RT-11®,

TS~,

[email protected],

[email protected],

RS~,

RSTS®, VMS, UNI:XE, ULTRIX, and other operating systems which use

DU/TU

drivers.

The CQD-440 has Adaptive Dwell for Q-bus; active termination for singleended channel to improve SCSI bus noise immunity; a polyswitch

(self-healing) fuses that do not need to be replaced.

The CQD-440 features 18-bit or 22-bit

Q~bus addressing, block mode and adaptive DMA transfer, virtual data buffer, command queuing, dynamic defect management, standard SCSI bus arbitration, disconnect and reconnect capability, multiple-host capability, and all required SCSI commands. Up to seven (either single-ended or differential) synchronous, asynchronous or

Features and Specifications 2-1

CQD-440

mixed SCSI devices can be connected to the CQD-440 with SCSI bus data transfer rate up to 10-MB/sec in synchronous mode (fast SCSI) and 7-MB/sec in asynchronous mode.

The CQD-440 supports a variety of Sync/ Async SCSI devices including magnetic disk, magnetic tape and optical disk drives. Table 2-1 lists the different models of the CQD-440 and their features.

Table 2-1 CQD-440 Models

CQD-440/TM

CQD-440/TMS

CQD-443 supports disk and tape drives Simultaneously supports disk and tape drives and hardware shadowing contains the CQD-440 models and a Micro V AX ill and V AX4000 adapter kit. A shielded

SCSI cable (with shielded connectors) is required to connect the CQD-443 to

SCSI devices.

NOTE

Unless otherwise specified, the CQD-440 will represent all of the variations through this manual and the

CQD-440 /TM will represent the CQD-44 0 /TMS variations.

The CQD-440 has an On-Board Utility for you to format and configure the

SCSI devices, scan bad blocks and replace them automatically.

For LSI systems only,

the CQD-440 contains a selectable bootstrap option which can boot up the system on power up or reset. The CQD-440 has an On-Board

Utility for you to boot up the system or exercise the tape drives.

The CQD-440 has an on-board non-volatile RAM (NOVRAM) to store the

Logical Unit Number (LUN) Offset and other important information of the controller configuration.

The CQD-440 SCSI host adapter provides you with a 10 pin connector

04)

for the On-Board RS-232 Utility. The CQD-443 provides you with a DEC compatible RJ-11/Modified Module 423 Jack (MMJ) for accessing the

On-Board RS-232 Utility. See Appendix C for pin assignments.

2-2 Features and Specifications

CQD-440

LED Indicators

The CQD-440 has three LED modules in the front of the board. The LED modules contain two LED's and are labeled DS1, DS2 and DS3 (see Figure 2-1).

Jl

Red LED

Agure 2-1: LED Indicators

Table 2-2 lists the LED indicators for CQD-440.

Table 2-2 LED Indicators

LED Color Location Indication

OS1 Green first left

Power-up OK and activity indicator. Upon power up, this LED is turned on when the CQO-440 succeeds in the self-diagnostic testing. During normal controller operation, this LED will blink to show controller activity.

Red second left Error condition occurred

053 Green third left J2 single-ended tenninator power pin is supplied with power.

Green right

052 Green left

Green right

}2 Single-ended SCSI channel enabled.

Jl differential terminator power pins is supplied with power.

Jl

Differential SCSI channel enabled.

Features and Specifications 2-3

CQD-440

Special Features

The CMD CQD-440 controller provides special features, such as multi-hosting, partitioning, hardware shadowing, Tape Monitor Utility(TMU), and on-line formatting (FMT). Table 2-3 lists the special features.

Table 2-3

Model

/TM

/TMS

Special Feature Support List

Multi-hosting Partitioning TMU

Yes Yes Yes

No No

Yes

FMT

Yes

Yes

Shadowing

No

Yes

Multi-Hosting

CMD's multi-host solution can support disk, tape, and optical devices including jukeboxes.

It· gives you the ability to completely share an array of disks and tapes between multiple VAX systems running VAX cluster software. Multi-hosting configuration instructions are given in Chapter 4.

Refer to Appendix A for supported disk and tape devices.

Partitioning

CQD-440 gives you the ability to partition devices. Partitioning makes one physical device appear as two or four equal sized logical devices. Partitioning is used for operating systems that do not support large devices such as RT-l1.

Partitioning configuration instructions are given in Chapter 4.

Tape Monitor Utility

The Tape Monitor UtilityTM (TMU) is an application software that works exclusively with CMD SCSI host adapters as an optional feature for

VAX/VMS systems.

This Tape Monitor UtilityTM displays the tape drive vendor identification, drive firmware revision, the remaining tape capacity, percentage/number of rewrites during writes or percentage/number of ECC retrys during reads (see manufacturer's documentation for returns whether percentages or numbers), and current tape operations such as read, write, write file mark, space, rewind,

etc. You can install multiple CQD-440's and tape drives in one site and observe all tape activity from any VAX terminal locally or across the network without any additional add-in hardware. You can also open a file to log all the information during unattended backup.

2-4 Features and Specifications

COD-440

To install the Tape Monitor Utility, follow the instructions given in the accompanying CMD Tape Monitor Utility User's Manual part number

MAN-DOOTMU-OOO and install jumper shunt as given in Chapter 3, subsection

"Tape Monitor Utility and SCSIformat ON-LINE."

SCSlformat ON-LINE

The SCSIformat ON-LINE (FMT) is an application software that works exclusively with CMD SCSI host adapters as an optional feature for

VAX/VMS systems. This SCSIformat ON-LINE allows you to format the disk drives without interfering with the other devices on the SCSI bus. To install

SCSIformat ON-LINE follow the instructions given in the accompanying

SCSIformat ON-LINE User's Manual and install jumper shunt as given in

Chapter 3, subsection "Tape Monitor Utility and SCSIformat ON-LINE."

Hardware Shadowing

The Super Shadow CQD-440/TMS is a hardware variation of the

CQD-440 /TM. Installation and setup of CMD shadowing host adapters are simplified with the CMD On-Board Utilities. This easy to use menu-driven utility allows you to quickly configure virtually any combination of disk shadow sets. See Chapter 4 for Hardware Shadowing Configuration.

The hardware disk shadowing on DEC computers enables simultaneous writing of data to two shadow set members. This provides an exact real-time duplicate data set that can be later retrieved by the user if data on primary disk becomes unaccessible.

The access performance benefits are derived from the ability to read data from a particular disk in the shadow set that responds faster. By adapting specific host adapter resident firmware algorithms, CQD-440/TMS provides incredible performance benefits with disk access time reduced 100% or more during reads.

The hardware-based shadowing technique also results in far less VMS overhead and much higher data availability than software solutions.

You can now configure complete SCSI drive failure tolerant subsystems built around Super Shadow host adapters. When used in conjunction with other

CMD exclusive features like Multi-Host capability, subsystem data availability can be increased substantially.

Features and Specifications 2-5

CQD-440

Specifications

Table 2-4 lists the controller specifications for the CQD-440.

Table 2·4 Controller Specifications

Emulation

Bus Interface

Addressing

Interrupt Priority

Interrupt Vector

Transfer Mode

DMA Dwell

Command Queuing

Data Buffer Capacity

Bootstrap

Defect Management

Software Supported

Multiple-Hosting

Formatting

Partitiorting

Shadowing

Optional Software

LED Indicators

Peripheral Interface

SCSI Transfer Rate:

SCSI Bus Parity

Devices Supported

System Performance

SCSI Driver /Receiver

SCSI Fuse

SCSI Termination

SCSI Cable Length

Operating Temperature

Relative Hwnidity

Power Requirement

MSCP

(DU

driver) / TMSCP

(TU

driver)

Standard Micro V AX or LSI -11 Q-bus

22-bit Addressing

Level

4

Software programmable

Normal or block mode DMA

Adaptive Dwell

Commands with optimized seek

Virtual data buffer (infinite size)

Auto bootstrap or utility bootstrap

Dynamic defect management

All standard DEC operating- systems

Support multiple-hosting for disks, optical drives and tapes.

On board format and bad block replacement (ISO standard for optical erasable disk format)

2 or

4 equally divided partitiOns for disk drives

Any two disk drives on the bus can form a shadow set (for /TMS version only)

Tape Monitor Utility (TMU)

SCSIfonnat ON-LINE (PMT)

Self test, error conditions

Small Computer System Interface (SCSI-2)

10-MB/sec in Synchronous mode (Fast SCSI)

7-MB/sec in Asynchronous mode

Odd parity

Up to

7

SCSI disk and tape devices

(single-ended or differential)

CQD-440/TM default = 4 disks/3 tapes

Support disconnect/reconnect capability and multiple-host configuration

Single-ended or differential

Self-healing, 1.5 A polyfuse

Single-ended=active termination (removable)

Differential=removable

Single-ended, up to 20-feet (6-meters)

Differential, up to SO-feet (25-meters)

50

C to 50

0

C

10% to 90% , Non-condensing

5V DC, 3.5 A

2-6 Features and Specifications

CQD-440

Table 2-5 lists the CSR addresses for the CQD-440. For complete CSR addresses, see Chapter 3 and Appendix C.

Table 2-5 CSR Addesses

CQD-440/TM (Disk only)

IC P44009A (U93)

CQD-440/TM (Tape only)

IC P44010A (U79)

772150,760334,760354,760374,760340,760344,

760350, 760360 and up to 30 CSR addresses

774500,760404,760444,760504,760544,760410,

760450, 760454 and up to 31 CSR addresses

Features and Specifications 2-7

CQD-440

2-8 Features and Specifications

3

Installation

This chapter instructs you on configuring the CQD-440 and installing it into the system. Follow the instructions in this chapter in the order presented.

Determining CSR Address

Before you install the CQD-440 SCSI host adapter under the VMS operating system you must determine the Control and Status Register (CSR) address for the CQD-440.

For the CQD-440/TM, two CSR addresses are required. The following proced ure shows one method of determining the new CSR address for the

CQD-440.

WARNING Do not install the new CQD-440 in the system at this time.

1 Boot the VMS system and log into the system manager account.

2 At the OCL $ prompt, enter

Me

SYSGEN.

3 At the prompt SYSGEN, enter SHOWICONFIG. The SYSGEN Utility will display all the device controllers installed in the system and their corresponding CSR addresses and vectors. Make a note of this list.

4 At the prompt SYSGEN, enter CONFIG. This will give you the DEVICE prompt

Installation 3-1

CQD·440

5

NOTE

At the prompt

DEVICE,

enter the following for your CQD-440: enter

UDA,

X and

TU8l,

Y where

X is the number of installed

UDA

type controllers plus 1 (for the new one being added).

Y is the number of installed

TUBl

type controllers plus 1 (for the new one being added).

Enter all devices on the Q-bus, not just the new device being added at present.

6 At the prompt

DEVICE,

enter

[CTRL]

+

Z.

The SYSGEN Utility will display the CSR ~ddresses for all the controllers. Make sure that no other vectors or CSR addresses have changed; if they have, make the appropriate changes to the devices.

The VMS mnemonic for MSCP disk controllers are PUA, PUB, PUC, etc.

The VMS mnemonic for TMSCP tape controllers are PTA, PTB, PTC, etc.

For other mnemonics, refer to VMS system manager's guide.

7

Use the corresponding CSR address to configure the CSR jumper

. settings of the CQD-440 (see

IJCSR

Address Selection").

At the prompt

SYSGEN,

enter

[CTRL]

+

Z

to exit the SYSGEN Utility.

NOTE

VMS will automatically program the CQD-440's interrupt vector register to match the vector assigned by the system. The vectors of DHV11 or other controllers might change when the CQD-440 is added to the system; see manufacturer's documentation to configure vectors and device CSR addresses if hardware selectable.

The example in Figure 3-1 explains the SYSGEN Utility procedure for installing the CQD-440 in VMS system. In this example, the CSR addresses of PUB and PTB should be used to configure the CSR jumpers of the CQD-440.

In the example, notice the CSR and vector changes for the DHV11.

3-2 Installation

CQD-440

$MC SYSGEN

SYSGEN> SHOW /CONFIG

System CSR and VECTOR on 2-JUN-19B9 04:10:43.30

Name: PUA Units:1 Nexus:O (UBA) CSR:772150 Vector:774

Name: PTA Units:1 Nexus:O (UBA) CSR:774500 Vector:260

Name: TXA Units:16 Nexus:O (UBA) CSR:760440 Vector:300

Vector2:0

Vector2:0

Vector2:304

SYSGEN> CONFIG

DEVICE> UDA,2

DEVICE> TUB1,2

DEVICE> DHV11,1

DEVICE> /\Z

Device: UDA

Device:

TUB1

Device: UDA

Device: TUB1

Device: DHV11

Name:PUA

Name: PTA

Name: PUB

Name: PTB

Name:TXA

CSR: 772150 Vector:l54

CSR: 774500 Vector:260

CSR: 760334* Vector:300*

CSR: 760404* Vector:304 *

CSR: 760500 Vector:310*

SYSGEN> /\Z

$

Support: Y

Support: Y

Support: Y

Support: Y

Support: Y

Rgure 3·1: Example of SYSGEN Utility

Hardware Configuration

Normally, you do not need to change the factory jumper settings of the

CQD-440 except for the CSR address jumper SW1 as shown in the following subsections.

CSR Address Selection

The CQD-440 jumpers allow you to select different CSR addresses. If you require other CSR addresses than listed, consult CMD Technology.

Installation 3·3

CQD-440

The CQD-440 with both the IC P44009A in U93 and the IC P44010A in U79 supports 30 disk and 31 tape CSR addresses. Only eight disk and tape CSR jumper settings are shown in Tables 3-1 and 3-2. Refer to Appendix C for the other CSR jumper settings.

WARNING

Be sure to wear anti-static wrist straps or equivalent to protect the CQ0-440 from electro-static damage.

Table 3-1

Address

1

2

3

4

5

6

7

8

LSI-II

17772150

17760334

17760354

17760374

17760340

17760344

17760350

17760360

CQD-440 CSR jumper settings for disk

MicroVAX

SWI-I SWI-2 SWI-3 SWI-4

SWl-S

20001468 ON ON

ON ON ON

200000DC ON ON ON ON OFF

200000EC ON ON ON

OFF ON

200000FC

200000EO

ON ON

ON ON

ON

OFF

OFF

ON

OFF

ON

200000E4 ON ON OFF ON OFF

200000E8

200000FO

ON ON OFF OFF ON

ON ON OFF OFF OFF

Table 3-2

Address

5

6

7

8

1

2

3

4

CQD-440 CSR jumper settings for tape

LSI-II

17774500

17760404

17760444

17760504

17760544

17760410

17760450

17760454

MicroVAX

20001940

20000104

20000124

20000144

20000164

20000108

20000128

2000012C

SWI-6 SWI-7 SWI-8 SWI-9 SWI-IO

ON ON ON ON ON

ON ON ON ON

OFF.

ON

ON

ON OFF ON

ON ON ON OFF OFF

ON ON OFF ON ON

ON ON OFF ON OFF

ON ON OFF OFF ON

ON ON OFF OFF OFF

Please refer to Figure 3-2 for jumper locations.

3-4 Installation

CQD-440

Rgure 3·2: Jumper block location.

Installation 3-5

CQD-440

Disk Auto Boot Selection

Disk Auto Boot Selection is used for the LSI-II processors only. The CQD-440 may be set to provide an auto-bootstrap at 773000 or 771000 on power up or whenever the "boot" switch is pressed. Disk drive 0 will be bootstrapped.

Table 3-3 lists Disk Auto Boot Selections.

Table 3-3

W24

W24

W23

W23

Disk Auto Boot Selection

1-2 IN

. 2-3 IN

IN

OUT

Note that (F) means factory setting.

Auto-Bootstrap disabled (F)

Auto-Bootstrap enabled

Auto-Bootstrap address

=

773000 (F)

Auto-Bootstrap address

=

771000

If there is an existing bootstrap ROM at 773000, you must set the CQD-440 auto-bootstrap address at 771000. To boot the CQD-440, type 771000G from

ODT instead of the normal 773000G.

18- or 22-Bit Address Selection

The CQD-440 is factory configured to 22-bit addressing which is used in systems with the MicroVAX, LSI-11/23/53/73/83/93 and Mentec MBO, M90,

M100 processors. 22-bit addressing can cause problems if used with an 18-bit processor such as the LSI-11/2. In this case, configure the board to 18-bit by cutting the etch between W32 1-2 (see Figure 3-2 for jumper block locations).

Interrupt Level Selection

Interrupt Level Selection allows you to select the priority of interrupting the

CPU for MSCP devices. The CQD-440 is shipped with interrupt level 4 selected; this is standard interrupt priority for MSCP devices. Interrupt at levelS can be achieved by cutting the etch between W31 1-2.

3-6 Installation

CQD-440

Block Mode DMA

Block Mode DMA allows the CQD-440 to transfer data in blocks rather than single word per memory address assertion. In a Block Mode Direct Memory

Access (DMA) transfer, the starting memory address is asserted, followed by data for that address, and data for consecutive addresses. Because the assertion of the address for other data words are eliminated, higher data throughput can be achieved. The CQD-440 is shipped with Block Mode DMA enabled as shown in Table 3-4.

Table 3-4 Block Mode DMA

W22

W22

1-2 IN

2-3 IN

Note that (F) means factory setting.

Block mode DMA enabled (F)

Block mode DMA disabled

Adaptive DMA

Adaptive DMA allows the CQD-440 to release the Q-bus after a block (eight words) transfer if other DMA devices assert DMA request. Otherwise, the

CQD-440 will continue the DMA transfer for an additional block then release the Q-bus. Adaptive DMA is implemented to utilize the Q-bus bandwidth.

The CQD440 is shipped with Adaptive DMA enabled as shown in Table 3:-5.

Table 3-5 Adaptive DMA

W20

W20

1-2 IN

2-3 IN

Note that (F) means factory setting.

Adaptive DMA enabled (F)

Adaptive DMA disabled

Installation 3-7

CQD-44

0

DMA Dwell Time

DMA Dwell Time is the relaxation period between DMA requests. Normally, if multiple DMA data transfers are performed, consideration must be given to the Q-bus for other system functions, such as communication multiplexer, network, etc. During the DMA dwell time, the CQD-440 will not arbitrate for the use of the Q-bus. You can select the period of the DMA Dwell Time by changing the jumper shunts listed in Table 3-6.

Table 3-6 DMA Dwell Time

W16-1

W16-2

W16-3

W16-4

OUT

OUT

IN

OUT

Note that (F) means factory setting.

O.S-us DMA dwell time

1.6-us DMA dwell time

3.2-us DMA dwell time (F)

6.4-us DMA dwell time

Adaptive DMA Dwell Time

When Adaptive DMA Dwell Time is enabled, the CQD-440 monitors the

DMA activity, if other devices are requesting the bus, the Dwell Time will be determined by W16 as shown in Table 3-6. If no other device is requesting the bus, the CQD-440 will request the bus immediately. This feature allows the

CQD-440 to be both fast and fair to other devices on the Q-bus. You can select

Adaptive Dwell DMA Time by changing the jumper shunts listed in Table 3-7.

Table 3-7 Adaptive DMA

W21

W21

1-2 IN

2-3 IN

Note that (F) means factory setting.

Adaptive Dwell DMA enabled (F)

Adaptive Dwell DMA disabled

3-8 Installation

CQD-440

Tape Fast Search Option

When set to the Tape Fast Search mode, the CQD-440 will enable high speed forward and reverse filemark search. VMS may use this mode if you do not attempt a standalone boot or run other programs that require the controller to keep track of the number of data records between filemarks. In VMS standalone boot application, this option needs to be disabled. For the

ISM-II operating system, this jumper shunt has to be installed. CMD recommends you use this option for ULTRIX and UNIX systems. Table 3-8 lists the jumper settings.

Table 3·8 Tape Fast Search Option

SW2-4

SW2-4

ON

OFF

Note that (F) means factory setting.

Enable tape fast search option

Normal operation (F)

Sync/ Async Mode Selection

The CQD-440 comes standard in synchronous (sync) mode. Most SCSI devices support to sync mode. In sync mode, CQD-440 will automatically communicate with each SCSI device connected to find out whether the sync mode is supported by the device.

In async mode, CQD-440 will communicate with the SCSI device asynchronously even if the SCSI device supports sync mode. Most of the sync

SCSI devices also support async. mode.

You can change the CQD-440 to async mode using the jumpers listed in Table

3-9; these jumpers control the overall sync/ async mode selection and will override the On-Board Utility sync mode set-up.

Table 3-9 Sync/Async Mode Selection

SW2-6

SW2-6

SW2-7

SW2-7

ON

OFF

ON

OFF

Note that (F) means factory setting.

Tape sync mode disabled

Tape sync mode enabled (F)

Disk sync mode disabled

Disk sync mode enabled (F)

Installation 3-9

CQD-44

0

Tape Monitor Utility and SCSlformat ON-LINE

As explained in Chapter 2, the Tape Monitor Utility will allow you to monitor tape devices on the SCSI bus; and the SCSI format ON-LINE will allow you to format SCSI devices through the CQD-440 and the software provided. To enable these features you must install the Tape Monitor Utility and

SCSIformat ON-LINE as explained in their respective User's Manuals and install jumper shunt in SW2-S as shown in Table 3-10. For any operating system other than VMS, this jumper must not be installed.

WARNING

Do not insert this jumper shunt if the TMU or FMT application software is not installed. The factory setting of

SW2-5 is in OUT position (disabled).

Table 3-10 Tape Monitor Utility and SCSlformat ON·UNE Options

SW2-5 ON

SW2-5

OFF

Tape Monitor Utility enableq.

(IT, ITM)

Disk SCSIformat ON-LINE enabled

(1M, ITM)

Tape Monitor Utility disabled

(F)

Disk SCSIformat ON-LINE disabled (F)

Note that (F) means factory setting.

Single-ended or Differential Mode Selection

The CQD-440 SCSI port comes with both single-ended and differential SCSI drivers and receivers. Jumpers are available for users to select the channel.

When jumper shunts shown in Table 3-11 are installed for single-ended channel, SCSI drivers and receivers are enabled and DS3 right green LED will be ON. When a jumper shunts shown in

Table 3-11 are installed for differential channel, differential SCSI drivers and receivers are enabled and

DS2 2nd-Left green LED will be ON. RP1, RP2, and RP3 single-ended

(active or passive) terminators must be installed at all times when using differenital channel. The factory setting is single-ended channel. Figure 3-3 shows single-ended, and Figure 3-4, differential channel.

Table 3-11 Single-ended or Differential Mode Selection

W8 to W9, Wll to W12, W4, W5 All IN Single-ended channel enabled

(F)

W9 to Wl0, W12 to W13

W4, W5

Note that (F) means factory setting.

IN

OUT

Differential channel enabled

3-10 Installation

J1

CQD-440

J2

o ~mtdmutl!J we

W9

W10 to

W9 IN

~

l ___

~

____________

~

W13

W I . . W 5 .

IN IN

Figure 3-3: Single-ended Mode

~Iection

J1

J2

~W9 to

W10 IN i5

r------,

L ___________________________________

.1

~W12 to

W13 IN

W13

Wit

E.3J

W5

OUT

D

OUT

Figure 3-4: Differential Mode Selection

Installation 3·11

CQD-440

Single-ended Active/Passive Termination

The CQD-440 has a new feature that allows you to select active or passive termination. Active termination contains resistor networks and a voltage regulator. Passive termination contains only resistor networks. Refer to "SCSI

Bus Termination" in this chapter for details on ohms. Table 3-12 details jumper settings for active/passive termination.

Table 3·12 Single-ended or Differential Mode Selection

W2

W2

. 1-2 IN

2-3 IN

Note that (F) means factory setting.

Active Termination enabled (F)

Passive Termination enabled

Active termination is factory configured, however, to change from active to passive follow these steps.

1

Remove RP1, RP2, RP3.

2 Place jumper shunt over W2 2-3.

3 Install all passive resistors into RP1, RP2, RP3; final numbers on the resistors must read 221331. All resistor pin l's must align

to the left

as shown in Figure 3-5. [Active resistor numbers end in 111 and pin l's align

to the right.]

Passive Termination pin

1

111

Screen

IPassive tjtXXjtjObDo:D

R P 1

1

Screen

111 ctive

RP2

RP3 k

I

XjOtjbdtX1d tx

X l( xi i iO¢b w4D

WSj

Active Termination pin

1

Figure 3·5: Pin 1 location for alngle-ended termination

3-12 Installation

Eprom Size

Eprom size is selectable by installing jumper shunt in W17. Table 3-13 illustrates the selection.

Table 3·13 Eprom Size Selection

W17

W17

1-2 IN

2-3 IN

Eprom Size 512-Kbit or 1-Mbit

Eprom 256-Kbit (F)

WARNING When removing and reinstalling Eproms, align Eproms with Ie sockets starting from pin 3. See Figure 3-6.

CQD-440

Pin

Rgure 3-6: Eprom setting

Wait State for Eprom Cycles

Wait state for Eprom cycles can be selected as shown in Table 3-14.

Table 3·14 Walt State for Eprom Cycles

W18

W18

OUT

IN o

Wait State for Eprom Cycles(F)

1 Wait State for Eprom Cycles

Installation 3·13

COD-44a

Reset Switch

Switch 3 on the CQD-440 can be selected to opertate as a reset switch or an

NMI (non-maskable interrupt for the diagnostic utility) switch. When W3 1-2 is IN, the CQD-440 will reset the board. When W3 2-3 is IN, the CQD-440 will return port errors to the SA register so the operating system will reset the board. NMI is factory configured but can be selected ~s a reset switch as shown in Table 3-15 .

.

Table 3·15 Reset or NMI Switch

W3

W3

1-2 IN

2-3 IN

Reset

NMI Port Error

(F)

Installation

This section gives you instructions for installing the CQD-440 into a system.

Remember to turn off the power of the system and SCSI devices while installing the SCSI cable and terminator.

SCSI Host Adapter 10 Selection

Each device on the SCSI bus requires a unique SCSI identification address

(0-7). SCSI ID 7 has the highest priority on the bus and SCSI ID 0 has the lowest priority. The CQD-440 SCSI Host Adapter is factory configured to SCSI

ID 7. Do not change this setting unless you are setting a multi-hosting configuration (see Multi-hosting in Chapter 4).

SCSI 10

for Target Devices

Each SCSI device (initiator or target) on the SCSI bus requires a unique SCSI

ID number. Since the CQD-440 has been set to SCSI ID 7 (initiator), target devices must be configured from SCSI ID 0 to 6. Factory configuration is four disk drives at SCSI ID

=

0 to 3 and three tape drives disks, SCSI ID

=

4 to 6.

If you have more than four disks drives or three tapes drives you

must

use the

On-Board Utility to change the configuration; otherwise,

do not

change the configuration.

3-14 Installation

CQO-440

CQD-440 Mounting Slot Selection

The CQD-440 can be installed in any slot of the standard Micro V AX or LSI-II

Q-Bus backplane as long as the Q-Bus interrupt acknowledge/DMA grant daisy chain is not broken.

SCSI Bus Cabling

Single-ended-The CQD-440 provides a 50-pin connector 02) to interface with external single-enged SCSI devices.

• When the CQD-440 and the SCSI devices are installed in the same cabinet which meets EMI/RFI shielding requirements, a 25-signal

twisted-pair cable

must be used for connecting the CQD-440 (2) and the SCSI devices.

• When the CQD-440 and the SCSI devices are installed in separated cabinets, the shielded SCSI cable should be used to meet FCC requirements.

• A minimum conductor size of 28-AWG must be used to minimize noise effects and ensure proper distribution of optional terminator power.

• The maximum cable length is 6.0-meters or 20-feet in single-ended channel.

Differential-The CQD-440 also provides a 50-pin connector (1) to interface with external differential SCSI devices.

• When the CQD-440 and the external SCSI devices are installed in the same cabinet which meets EMI/RFI shielding requirements, a

25-signal

twisted-pair cable

must be used for connecting the CQD-440

(1) and the external SCSI devices.

• When the CQD-440 and the external SCSI devices are installed in separated cabinets, the shielded SCSI cable should be used to meet

FCC requirements. A 25-signal

twisted-pair cable

must be used to eliminate the crosstalk between adjacent signals causing spurious pulses on differential signals which will occur even at slow data transfer rates and short cable distances. Each pair should be connected to the same signal, one wire to the positive and the other wire to the negative signal.

• Cables should consist of conductors of 26-AWG or 28-AWG.

• The maximum cable length is 25-meters or 80-feet in differential channel.

Installation 3-15

CQD-440

SCSI Bus Termination

The CQD440 can be installed in any position of the SCSI cable. If the

CQD-440 is installed in either end of SCSI cable, on-board terminators should remain on board. If the CQD-440 is in the middle of the SCSI bus, on-board terminators should be removed.

Single-ended Active-The

CQD-440 uses active removable terminators for single-ended SCSI. Active termination provides greater noise immunity and more closely matches the cable impedance. The part number for the sips are xxxIII (9 by 110-ohms). They are located in the RP1, RP2, and RP3. See

Figure 3-5 for details.

Single-ended Passive-If

passive termination is desired, the SCSI bus signals should be terminated with 220-ohms to +5-volts and 330-ohms to ground at each end of the cable. The CQD-440 provides on-board removable terminators, for locations RP1, RP2, and RP3. The sips extension numbers must end in 221331. See "Single-ended Active/Passive Termination."

Differential-Every

differential signal pair should be terminated with

330-ohms resistor between the negative signal and +5-volts, 330-ohms between the positive signal and ground, and 150-ohms between the positive and the negative signal at each end of the SCSI cable. The

~QD-440 provides on-board removable terminators (U1 and U2) which are next to the connector J1. RPl, RP2, and RP3 single-ended (active or passive) terminators must be installed at all times when using differenital channel.

SCSI Bus Terminator Power

Any SCSI terminator (on-drive or external) needs to be powered by at least one SCSI device, otherwise the SCSI signals will be pulled down. Typically an initiator (SCSI host adapter) provides the power to the on-board terminator, external SCSI terminator and on-drive terminator when the drive is powered off. Anytime an external SCSI terminator (instead of the on-drive SCSI terminator) is used, the SCSI terminator power option of the CQD-440 has to be enabled, i.e. install jumper shunt at WI or W 6.

A minimum conductor size of 28-AWG shall be employed to minimize noise effects and ensure proper distribution of optional terminator power. The

CQD-440 supplies terminator power to the TERMPWR pin

02, pin 26; J1, pin

25 and 26) and the CDQ-443

02,

pin 38; J1, pin 13 and 38), through a fuse, a diode and jumper block WI for differential and W6 for single-ended (see

Table 3-15).

3-16 Installation

CQD-44

0

Table 3·16 Terminator Power Option

Wl

Wl

W6

W6

IN

OUT

IN

OUT

Note that (F) means factory setting.

Differential SCSI terminator power enabled (F)

Differential SCSI terminator power disabled

Single-ended SCSI terminator power enabled (F)

Single-ended SCSI te~tor

Installation Procedures

1

Determine the CSR address for the CQD-440 as explained in

"Determining CSR Address."

WARNING Be sure to wear anti-static wrist straps or equivalent to protect the CQD-440 from electro-static damage.

2 Configure the hardware as explained in "Hardware Configuration."

3 Set the CQD-440 and Device SCSI ID's as explained in "SCSI Host

Adapter ID Selection" and "SCSI Device ID Selection."

4 Choose a proper slot to place the CQD-440; and install it into that slot

(see "CQD-440 Mounting Slot Selection").

Installation 3-17

CQD-440

5 Connect SCSI cable to

Jl for differential or

J2 for single-ended of the

CQD-440 using cable specifications given in "SCSI Bus Cabling." For the

CQD-440, connector will be non-shielded, see Figure 3-7.

WARNING

In order to prevent accidental grounding or misconnection of terminator power, make sure that the ·pin 1 mark of

SCSI cable matches with the pin 1 mark of SCSI device's connector before turning on the power.

>::::»)<:):):::::#-_ _ _ _

.-c ..• :::.::: :.:.::: ••••.• >.::

»

Internol Coble

Red stripe designates pin 1

Rgure 3·7: CQD-440 non-shielded cable connection

For the CQD-443, the connector will be shielded, see Figure 3-8.

CQD-443

J2 Slngle~nded

Jl Differential

'flmTIES~

External Cable

3-18 Installation

Rgure 3-8: CQD-443 shielded connection

CQD-440

6 Continue SCSI cabling to connect up to seven SCSI devices to the

CQD-440. See the example in Figure 3-9.

Host

SCSI device

OUAO

SCSI device

DUA1

SCSI device

DUA2

SCSI device

OUA3

SCSI device

OUA4

SCSI device

OUAS

J1 or J2 10=7 T

SCSI Bus Cable

Figure 3-9: SCSI 10 and Cabling

T shows termination of

SCSI bus

7 Terminate the SCSI bus at each

physical

end; see "SCSI Bus Termination."

If TERMPWR is needed for the bus, place jumper shunt on WI or W6 as explained in "SCSI Bus Terminator Power" (see the example in

Figure 3-8).

8 Power up the system and execute On-Board Utility to scan for the SCSI devices and assure that all devices are seen and functioning properly

(see Chapter 4 for On-Board Utility).

9 Boot the system and test with the operating system.

Installation 3-19

CQD-440

3-20 Installation

4

Setup

This chapter will assist you in setting up the CQD-440 and your system for use.

On-Board Utility

The CQD-440 SCSI host adapter comes with a general purpose On-Board

Utility for all systems. The On-Board Utility can test the system slot, SCSI cable, and SCSI devices connected to the CQD-440. Accessing the Utility can be done through LSI or VAX system or the RS-232 Port. Be sure to complete utility functions, explained at the end of this chapter.

Accessing the Utility Through the LSI or VAX System

The On-Board Utility Program can be accessed by means

ot

an ODT command for LSI and V AX systems. One example is shown with the SCSI host adapter set to the first disk CSR address. Because the formats and features of the On-Board Utilities for LSI-II systems and MicroV AX systems are similar (except different start up procedures), the MicroV AX utility will be described.

Instructions for using the Disk Utility with LSI-11 Systems are listed below:

1 Halt the processor.

2 Hit the Boot Switch.

3 Enter the CSR address plus 2 (in Octal), a slash, and 123456. For example, for CSR address 17772150 enter:

17772152/005400123456.

CSR addresses can be found in Chapter 3 or Appendix C.

Setup

4-1

CQD-44

0

4 Enter CSR address plus 2 (in Octal), a slash, and 100 to load the utility to the system memory. For example, for CSR address 17772150 enter:

177721521001000 100.

5 Enter 5000G. The Utility program will begin executing.

Instructions for using this utility with VAX Systems are listed below:

1 Halt the CPU.

2 At the prompt

»> enter

U

to unlock the CPU.

3 At the prompt

»> enter

I to initialize the CPU.

4 At the prompt

»> enter DIPIW 20001F40 20 to enable Q-bus memory access.

5 At the prompt

»> enter DIL 20088008 80000002 to set up Q-bus map.

6 At the prompt

»> enter DIW YYYYYYYY A72E to deposit to the base

CSR address plus 2 (in Hex). CSR addresses can be found in Chapter 3 or Appendix C.

Where

yyyyyyyy-the

CSR address plus 2 (in Hex). See Table

4-1 for disk and

Table

4-2 for tape.

Table 4-1

CSR Reference

772150

760334

760354

760374

760340

760344

760350

760360

Disk CSR Addresses Plus 2 Configurations

CSR Addresses CSR Addresses Plus 2:

YYYYYYYY

20001468

200000DC

2000146A

200000DE

200000EE

200000EC

200000FC

200000EO

200000E4

200000E8

200000FO

200000FE

200000E2

200000E6

200000EA

200000F2

CQD-44

0

Table 4-2 Tape CSR Addresses Plus 2 Configurations

CSR Reference

774500

760404

760444

760504

760544

760410

760450

760454

CSR Addresses CSR Addresses Plus

2:

YYYYYYYY

20001940

20000104

20000124

20000144

20000164

20000108

20000128

2000012C

20001942

20000106

20000126

20000146

20000166

2000010A

2000012A

2000012£

7

At the prompt »> enter D '" 100 to load the utility to system memory.

This command deposits 100 to current address.

8 At the prompt »> enter S 400 to start the utility. The utility will display as shown in Figure 4-1:

SCSI UTILITY PROGRAM

DISK

1 = 772150

2 = 760334

3 = 760354

4 = 760374

5 = 760340

6 = 760344

7 = 760350

8 = 760360

SELECT CSR ADDRESS

Figure 4·1: Utility CSR address

TAPE

A = 774500

B

= 760404

C

=

760444

0=760504

E = 760544

F = 760410

G = 760450

H = 760454

Setup 4·3

CQO-440

9 Enter the corresponding CSR address for the CQD-440. The Main Menu will appear as shown in Figure 4-2.

CSR=772150 (20001468) MAIN MENU

1

2

3

4

7

=

HALT SYSTEM

=

CONFIGURE LUN OFFSET

=

FORMAT DRIVE

=

QUALIFY DRIVE

=

ADDITIONAL SCSI COMMANDS

SELECT OPTION:

Figure 4-2: Main Menu

NOTE

LSI systems will display this Main Menu differently as item 1

=

Boot Drive.

If the message appears

"CONTROLLER NOT PRESENT," make sure CSR address is correct.

10 From the Main Menu only select option 1 or 7. 1 will halt the system and

7 will bring you to the SCSI Host Adapter Utility.

(

Accessing the Utility Through the RS-232 Port

To access the utility from the RS-232 port, follow the instructions below.

1 Connect a terminal to the CQD-440's RS-232 port (10 pin connector) or to the CQD-443's RS-232 port (DEC compatible RJ-11/Modified Module

423 Jack connector). See Figures 4-3 and 4-4.

4-4 Setup

CQD-440

CQD-440

J6

RS-232 Port

Pin 1

RS-232 Cable Pin 1

Jl

Agure 4-3: CQD-440 RS-232 Port

To Terminal

Agure 4-4: CQD-443 RS-232 Port

2 Set the terminal baud rate to 9600 (8-bit data, l-stop bit, no parity) jump scroll.

Setup 4-5

CQD-440

3 Halt the system's CPU, reset the system, and hit carriage return on the terminal. The SCSI Host Adapter Utility will display as shown in

Figure 4-5.

SCSI HOST ADAPTER UTILITY (REV. YYYxZZ)

[DISK]

1

=

LOGICAL UNIT NUMBER OFFSET

2

=

FORMAT DRIVE

3

=

QUALIFY DRIVE

4

5

=

MANUALLY REPLACE BAD BLOCKS

=

ADDITIONAL UTILITIES

[TAPE]

6 = LOGICAL UNIT NUMBER OFFSET

7

=

ADDITIONAL UTILITIES

SELECT OPTION ?

Figure 4·5: SCSI Host Adapter Utility

4

Once the SCSI Host Adapter Utility shows up, you can key in the number to select the desired option. Press

[CTRL] + C at any time to return to the main menu.

Refer the next subsections for configurations. When completed, unplug the terminal, reset the system, and boot. DO NOT use the

On-Board Utility while the system is running.

NOTE

The following sections will illustrate the On-Board Utility from the RS-232 Port. There may be some variation in the Main Menu and the SCSI Host Adapter Utility

Menu.

If you are accessing from the Main Menu, simply chose the correct number for each option.

Changing LUN Offset

When a system has a HSC or in a VAX cluster it will be necessary to change the LUN (Logical Unit Number) offset. Each MSCP drive requires a different Unit Number so that the unit numbers are not duplicated. If there are no other MSCP controllers in the system, the LUN offset can be O.

If there exists another MSCP controller with four drives (0 to 3) in a VAX cluster configuration, then the LUN offset should be four or above. In the case that LUN offset is equal to 10, SCSI ID

°

will be DUBIO and SCSI ID I will be

DUBIL The drives will show up as such DUAO, DUAl, DUA2, DUA3,

DUBIO, DUBll (see section, "SCSI 10 for Target Drives" in Chapter 3 for explanation).

4-6 Setup

CQD-440

Follow these procedures to configure LUN offset.

1 Select option

1 from the SCSI Host Adapter Utility for disk drives; 6 for tape drives.

2 Enter the new value for L UN offset at the statement:

LUN OFFSET IS 0,

ENTER NEW V ALOE:

3 At the statement:

SAVE NEW VALUE (Y or N)? enter Y.

4 The monitor will display

FORMAT COMPLETE when finished executing.

Formatting the Drive

This section details formatting a drive. The CQD-440 issues Format Unit

Command to the selected SCSI disk drive and requests it to map out the defects on the Manufacture Defect List (MDL). Remember formatting a drive will rewrite all the sectors of that drive.

CMD recommends that you format all new drives. To format a drive, follow the steps below:

1 Select option 2 from the SCSI Host Adapter Utility.

2 Enter the device number from 0 to 6 in the statement:

DEVICE NUMBER?

<0 TO 6> DEV X.

3 Answer Y to the question

FORMAT DRIVE

X, ARE

YOU SURE? if you want to continue.

4 At the statement:

WARNING DATA WILL BE DESTROYED,

ARE

YOU SURE? enter Y if you want to continue.

5 The monitor displays

WAIT while the drive is executing the format process.

6 The monitor will display

COMPLETE when finished executing.

Setup 4-7

CQD-440

Qualifying the Drive

After formatting the device, CMD recommends you qualify devices by running this procedure at lease once without errors detected. The qualify program writes different patterns to the drive and then verifies the data. If there are any bad sectors, the sectors will automatically be replaced and the statement

XX XXXXXXXX BAD BLOCK REPLACED will appear. Follow the instructions below for qualifying a drive.

1

Select option 3 from the SCSI Host Adapter Utility.

2 Enter the device number at the statement:

DEVICE NUMBER? DEV <0 TO 6>

DEVX.

3 At the statement,

READY TO TEST DEVICE X, ARE YOU SURE enter Y if you want to continue.

4 At the statement: ototot

WILL DESTROY DATA ON THIS DEVICE, ARE YOU SURE? enter Y if you want to continue.

5

The monitor will display

QUALIFY STARTED <SEQUENTIAL WRITE & READ>!

<HIT <Break> TO ABORT>.

6 The monitor will display

TESTING LOOP COUNT & BLOCK NUMBER:

7

Press

[BREAK]

to exit back to the SCSI Host Adapter Utility after you are satisfied with the qualifying process.

Manually Replacing Bad Sectors

This option allows you to replace bad sectors manually. The controller supports dynamic defect management which replaces defective sectors on-line so there is no need to manually replace bad sectors. However, if you wish to replace bad sectors manually follow these instructions; remember that any data in the sector will be lost:

1

Select option

4 from the SCSI Host Adapter Utility.

2 Enter the device number at the statement:

DEVICE NUMBER? DEV <0 TO 6>

DEVX:

4-8

Setup

CQD-440

3 Enter the logical block number in HEX at the statement:

READY TO TEST DEVICE X,

ENTER THE BAD BLOCK NUMBER <HEX> : xxxxx

4 The monitor will display

--BAD BLOCK REPLACED-when finished executing.

Additional Utilities

To access additional utilities for disk drives, select option 5 from the main menu. To access additional utilities for tape drives, select option 7 from the main menu. The additional utilities menu will display as shown in Figure 4-6.

ADDITIONAL UTILITIES (REV. YYYXZZ) SN

=

1278

D

S

=

DISPLAY SCSI DEVICE AND SET UP CONFIGURATION

=

SEND SCSI COMMAND TO THE DEVICE

T

R

=

TEST SCSI DEVICE

=

FORMAT RCT BLOCK

SELECT OPTION?

Figure 4-6: Utility Sub-menu

Displaying SCSI Device and Setting Up Configuration

Selection 'D' can be used to change the controller default configurations such as those listed below:

• reset to default

• number of disk and tape devices supported

• SCSI reset enable / disable

• SCSI disconnect enable / disable

• sync/ async mode selection

• tape buffer mode enable/disable

• prevent medium removal enable/ disable

• disk write with verify enable / disable

• remote density mode enable/disable

• default tape enable/disable

• reconfigure device

• autoboot start from floppy enable/disable

Setup 4-9

CQO-440

• write protect from controller jumper setting

• truncate disk size for volume shadowing

• eject removable disk cartridge after dism"ount

This utility can also scan/display the SCSI devices attached to the CQD-440.

The CQD-440/TM will be shown as an example in the following display. To display SCSI devices and set up configuration follow the procedures below.

1 Select option D at the sub-menu (Figure 4-6), the following current configuration is displayed as shown in Figure 4-7.

DEVO DUO, SCSI 10 0, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV1 DU1, SCSI ID 1, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV2 DU2, SCSI ID 2, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV3 DU3, SCSI ID 3, LUN a

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV4 MUO, SCSI ID 4, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV5 MU1, SCSI ID 5, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV6 MU2, SCSI ID 6, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV7 SCSI ID 7, HOST ADAPTER SCSI Reset ON, Density Mode ON, Default Tape OFF

Boot Floppy OFF, Jumper Write Protect OFF, Eject Disk ON, Truncate Size OFF

NOTE

Rgure 4-7: Current configuration, default

If Truncate Size is toggled, "Truncate Mode ON" will display under each disk device options and at the bottom when configuration is displayed.

4-10 Setup

CQD-440

2 To change the configuration, enter Y at the statement:

CHANGE

CONFIGURATION?

(y

IN)

The menu shown in Figure 4-8 will display.

NOTE

See subsection, "Unit Numbering" before trying to reconfigure dey ices.

R = Toggle SCSI Reset

D = Toggle Disconnect

M = Toggle Density Mode

B

=

Toggle BufferlTruncate Mode (Tape/Disk)

S = Toggle Sync/Async W = Toggle Write WNerity (Disk only)

C = Reconfigure Device

U

=

Toggle Default Tape (Tape Only)

A

=

Autoboot Start From Floppy Drive

P

=

Toggle Prevent Medium Removal (Disk only)

N

= Write Protect from Controller Jumper Setting

V

=

Truncate Disk Size for Volume Shadowing

E

=

Eject Disk after Dismount

T

=

Reset All Device Modes to Default

Z = Reset Controller to Default Configurtation

Agure 4·8: Configuration change

The following list is an explanation of the selections in Figure 4-8.

R

=

Toggle SCSI reset-Choosing this option will toggle the controller's ability to issue SCSI resets. This should be turned off when multi-hosting is desired.

D

=

Toggle Disconnect-This option allows you to configure on a device basis the ability to disconnect or not. If enabled the controller will indicate its ability to disconnect during the SCSI identify message.

S

=

Toggle Synd Async-This option allows you to configure each device for synchronous or asynchronous operations. If synchronous is selected, the controller will attempt a synchronous message exchange with the device. If the device accepts the message exchange, they will transfer data synchronously, otherwise they will transfer asynchronously.

C = Reconfigure Device-This option allows you to reconfigure the device at any time.

U = Toggle Default Tape-This option allows you to force the presence of a tape unit to the operating system even if one does not exist. This is needed for some operating systems when the controller is connected to

Setup

4·11

CQD-44

0 devices with a long self test procedure after power-up. If it is disabled, only units connected to the controller are seen by the operating system.

A = Autoboot Start From Floppy Drive-This option allows you to set the system to boot directly from the first floppy drive; if no floppy drive is present, the system will begin to boot from the first device.

N

=

Write Protect from Controller Jumper Setting-This option may be used when jumper setting for write protect is IN to enable further write protection to the disk. If the jumper is OUT, write protect will not be enabled. v

= Truncate Disk Size for Volume Shadowing-This option allows the size of the disk to be truncated to multiples of 126 blocks to allow

VMS volume shadowing copy process to reach higher performance. The message

"**

WARNING

**

Truncate Size ON/OFF will be toggled, Are you sure?" will display before truncate switch can be toggled. If this feature is used on a disk that contains valid data, the data must be removed and later restored after turning this feature ON.

E = Ej ect Disk after Dismount-This option allows you to specify whether the removable disk cartridges will eject from the drive after' dismount.

T

=

Reset all Device Modes to Default-These modes are--disconnect, synchronous, Prevent Medium Removal, Write with Verify, and Buffer modes.

Z = Reset Controller to Default Configuration-This option allows the you to set the controller to its factory default configuration. This will set the CQD-440 /TM to support four disk drives, three tape drives; disconnect, SCSI reset, synchronous communication, buffer mode, prevent medium removal and density selection enabled; write with verify and default tape disabled. Use this feature ALWAYS before you reconfigure the board.

M

=

Toggle Density Mode-This option allows you to configure the controller for remote density selection. If enabled, remote density selection may take place.

If enabled, the controller reports itself as a

'TUBI.' If disabled, it reports itself as a 'TKSO.'

4-12 Setup

CQD-440

B = Toggle BufferlTruncate Mode (Tape/Disk)-For tape devices, this option allows the controller to configure each individual tape device for write caching.

If enabled, the tape device will send command complete message and good status to the controller once the data as been transferred to the tape device's internal buffers. If disabled, such message and status will be sent when the data is actually written to the tape. For disk devices, you may toggle truncate disk size, see "V = Truncate Disk Size for Volume Shadowing" for explanation.

W = Toggle Write W/Verify-This option will allow the SCSI command

Write with Verify to be issued for MSCP write with verify modifier.

When set to

OFF, the normal write command will be issued.

P

=

Prevent Medium Removal-This option is for removable disk drives only. When set to

ON, a "Prevent Medium Removal" will be issued to a drive when it is mounted by VMS. This will disable the eject media push-button in front of the drive. An "Allow Medium Removal" will be issued when the drive is dismounted by VMS and the pushbutton will be enabled. This features can be disabled and the media can be ejected at anytime.

3 To reconfigure the device select option C and the screen will prompt you to answer the next series of questions as shown in Figure 4-9.

Number of Disks? (0-7) 4

DUO to be Reconfigured ? (YIN) N

DU 1 to be Reconfigured ? (YIN) N

DU2 to be Reconfigured ? (YIN) N

DU3 to be Reconfigured ? (YIN) N

Number of Tapes? (0-3) 3

MUO to be Reconfigured? (YIN) N

MU1 to be Reconfigured? (YIN) N

MU2 to be Reconfigured? (YIN) N

Rgure 4-9: SCSI host adapter 10 change

Setup 4-13

CQD-440

4

NOTE

Enter the number of disk and/or tapes. Default configuration is four disks, and three tapes; it is not necessary to configure if running less than four disks and three tapes.

If zero is selected for the number of disks or tapes disable the corresponding CSR address as shown in Tables

3-1 to 3-4.

Do not use 0 disk andlor 0 tape configuration in the above setup.

Answer Y or N to reconfigure each of the disks or tapes. If you answer

Y, the screen will prompt you with these questions:

J

(DUX SCSI ID? <0-7>

Rgure 4-10: Disk and Tape Configuration Change

NOTE

This L UN is SCSI L UN; it is normally O. This is used only for devices that support multiple LUNs.

5 When you have completed these instructions the display will show your current configuration and prompt you again with the question

CHANGE

CONFIGURA nON?

(Y

IN).

Enter N; this will cause the CQD-440 to scan the

SCSI bus.

The utility will display your current configuration with manufacturer's name, model number, and firmware revisions for each device. Record this information for future use.

Sending SCSI Commands

To

The Device

Selection '5' can be used to send SCSI commands to the selected disk/ tape drives directly.

This option is used to send a 6-, 10-, or 12-byte command to a SCSI device.

Follow these procedures to send SCSI cqmmands to the device:

1

Enter S from the

I I

Additional Utilities" Menu. (Be sure you have correctly selected either 5 from the SCSI Host Adapter Utility for disk drives, or 7 for tape drives.)

4-14 Setup

CQD-440

2

At the question

DEVICE NUMBER? DEV <0-6> DEV enter the device number.

3 Enter the command sequence at the statement:

READY TO TEST DEVICE X

EDIT CDB <HEX> ...... <ESC> TO TERMINATE EDITING .......

BYTE

0000=

00

If a 6- or lO-byte command is used, press

[ESC]

to terminate command editing. If a l2-byte command is used, command editi~g is terminated automaticall y.

4 At the statement

WRITE DATA TO THE DEVICE? <Y OR N> enter N to immediately send the command if SCSI command does not require a data out phase.

Or enter Y to send data to the device after the command phase if SCSI command requires a data out phase. Enter the data and enter

[ESC]

to terminate editing. The statement

SAVE EDITED DATA IN BUFFER?

<Y OR N> will appear. Enter Y to save data in the buffer; or enter

N

to erase edited data after the command is sent.

Testing SCSI Device

Selection 'T' can be used to read only, write and read selected disk drive, and/or write and read selected tape drive continuously. This is a diagnostic tool to help with installation and testing. Follow the procedures below to test the SCSI device.

1

Enter T from the

1/

Additional Utilities" menu. (Be sure you have correctly selected either 5 from the SCSI Host Adapter Utility for disk drives, or 7 for tape drives.)

2 At the question

DEVICE NUMBER? DEV <0-6> DEV enter the device number.

3 When testing for disk devices, at the statement

READY TO TEST DEVICE X,

00 YOU WANT TO READ ONLY? <Y OR N> enter Y to read only.

Enter N to write and read. The question

ARE YOU SURE?

will display.

Enter Y to write and read to the device.

WARNING

Nwill destroy all data on the device.

Setup 4-15

CQD-440

4

When testing for

tape devices,

the statement

ARE YOU SURE? will display.

Enter Y to test the device.

At the statement,

IS THIS FOR DUAL HOSTS QUALIFICATION TEST? <Y IN>, enter Y. Enter N for single host qualification.

The test will continue until you abort. Allow the test to continue for a few minutes for new devices and ten minutes for suspected bad devices.

Bad blocks will automatically be replaced and the following message will display.-

BAD BLOCK AT LOGICAL BLOCK XXXXXX REPLACED.

2

Press

[BREAK] or

[CTRl] + C

to abort and exit back to the SCSI Host

Adapter Utility.

Formatting

ReT

Block

Selection 'R' can be used to format the RCT blocks of the disk drive selected.

This command writes zeros in the last logical block of the device. If you try to skip the formatting process and directly use the drive, you

must

use this option to eliminate "unrecoverable bad RCT block." However, CMD recommends you format the drive. To format the RCT block follow these instructions:

1 Select

R

from the

II

Additional Utilities." (Be sure you have previously selected 5 from the SCSI Host Adapter Utility for disk drives.)

Enter device number at the statement:

DEVICE NUMBER? DEV

<~>

If device is off-line the following statement will appear,

DEVICE OFFLINE,

RESELECT OR PROCEED?

(RIP).

Enter R to reselect or P to proceed.

3

FORMAT COMPLETE will display when RCT block has been formatted.

Completing Utility Functions

The following proced ures should be completed when you have accessed the

On-Board Utility through the RS-232 port.

1 Use the On-Board Utility to verify SCSI cable and SCSI devices connected to the CQD-440 after installing the CQD-440 in the Q-bus slot.

4-16 Setup

CQD-440

2 After verifying the SCSI connections, disconnect RS-232 cable from the back panel, and reset the system.

NOTE

If the terminal is connected, this may cause the On-

Board Utility to be invoked during system operation and will take control of the Host Adapter from VMS.

The following procedures should be completed when you have accessed the

On-Board Utility t!'rr0ugh the Virtual Console of the LSI or VAX systems.

1 Use the On-Board Utility to verify the Q-bus slot seating, SCSI cable, and

SCSI devices connected to the CQD440 after installing the CQD-440 in the Q-bus slot.

2 After verifying the SCSI connections, reset the system.

Unit Numbering For Devices

This section explains configuring unit numbers. Unit numbers may be changed by using the "Configure LUN Offset" from the main menu. If you used the 'D' option from the" Additional Utilities" menu, the terminal will display the MU and/or DU numbers as shown in Table 4-3, factory default settings for unit numbers.

Table 4-3

CQD-440fTM

Default for Unit Numbers

SCSI 10

0

1

2

3

4

5

6

On-Board Utility Operating System Unit N~.

DUO

0

DUl

DU2

DU3

MUO

MUl

MU2

1

2

3

0

1

2

Setup

4-17

CQO-440

An example below is given for each type of controller to show how the unit numbers can be determined. Refer to Figure 4-7 if necessary.

CQD-4401TM-Default is four disk drives and three tape as shown in Table

4-3. If you have more than four disk drives or three tape drives, follow these guidelines-disk drives must start at SCSI ID 0 and tape drives must start after the last disk drive's SCSI ID number and reconfigure the CQD-44 0 /TM

(see subsection, "Displaying SCSI Devices and Setting Up Configuration").

Note the example .below:

SCSI ID 0 disk

SCSI ID 1 disk

SCSI ID 2 disk

SCSI ID 3 disk

SCSI ID 4 disk

SCSI ID 5 tape

SCSI ID 6 tape

SCSI ID 7 is initiator (CQD-440/TM)

The MU and DU numbers are the unit numbers mapped back to the operating system. If the CQD-440 /TM is configured following these guidelines, you can apply this formula to determine the unit number mapped back to the operating system:

+

=

SCSI ID of the disk drive the LUN offset for disk uni t number for disk

SCSI ID of tape drive number of disk drives

+

LUN offset for tapes

= unit number for tape

4-18 Setup

CQO-440

Multi-Hosting Configuration

The following is a list of software requirements for multi-hosting; refer to

Appendix A for supported multi-hosting devices:

• VMS version 5.3 or above

• VAX cluster software must be running on both systems with at least one of the DEC's interconnects operational

• Tape dri~es can only be mounted to one system at a time

• Allocation classes must be the same for all systems when installing disk drives (value must not equal 0).

Using VMS and the CQD-440/TM, you can multi-host by following the instructions below:

1 Configure the CQD-440 to SCSI ID 7 for the first computer; configure the

CQD-440 to SCSI ID 6 for the second computer. If you need to alter the

Host Adapter SCSI ID change the jumper settings as shown in Table 4-4.

Table 4-4

Host Adapter 10 Selection

SW2-1

ON

ON

ON

ON

OFF

OFF

OFF

OFF

SW2-2

ON

ON

OFF

OFF

ON

ON

OFF

OFF

Note that (F) means factory setting.

SW2-3

ON

OFF

ON

OFF

ON

OFF

ON

OFF

Initiator ID

Host adapter ID

=

7 highest priority

(F)

Host adapter 10

=

6

Host adapter 10

=

5

Host adapter 10

=

4

Host adapter 10

=

3

Host adapter 10

=

2

Host adapter 10

=

1

Host adapter ID

=

0, lowest priority

2 From the Additional Utilities Menu in the On-Board Utility, follow these instructions: a Select option D to display current configuration. b Answer Y to the statement:

CHANGE CONFIGURA nON? (YIN)

The menu shown in Figure 4-8 will display. c Select Z to reset configuration back to default. d Answer Y to reconfigure the adapter.

Setup 4-19

CQO-440

NOTE

If you ever reconfigure the board, you must reset the configuration to default using selection Z. e Select R to toggle SCSI reset. Then set the SCSI reset to

OFF.

Do this f for all SCSI host adapters to be multi-hosted.

Answer Y to reconfigure the adapter.

9 Select C to reconfigure the device. Then configure the CQD-440 for exact number of disks and tapes. This will inhibit scanning of other h host adapters (see Figure 4-9).

If other MSCP disks are in the cluster, follow the rules in the subsection "Changing LUN Offset" in liOn-Board Utility" so that each device has a unique unit number.

Exit out of the On-Board Utility.

NOTE

NOTE

In a multi-hosting system the

physical

disk device name must be identical on both systems.

3 Terminate both

physical

ends of the SCSI bus.

Single-ended-If

the CQD-440 is at either end of the SCSI bus, remove on-board terminators, RPI, RP2, RP3, and use a pass-through terminator as close to the board as possible. If the CQD-440 is in the middle of the SCSI bus, RPI, RP2, and RP3 terminators

must

be removed,

do not

use pass through terminators.

Differential-If

the CQD-440 is at either end of the SCSI bus, remove on-board terminators, UI, U2 and use a pass-through terminator as dose to the board as possible. If the CQD-440 is in the middle of the SCSI bus,

UI and U2 terminators

must

be removed,

do not

use pass through terminators.

In the event that one system becomes inoperable with only two nodes in the

VAX cluster, a quorum disk must be used to count as a vote; this keeps the other system running. Refer to VMS V AXcluster manual order number

AA-LA27A-TE to set up a quorum disk and a VAX cluster.

When running

cluster _config.com

on a system with only

Ethernet as a computer interconnect, answer

Yes

for the question,

"WILL THIS BE A SATELLITE NODE?"

4-20 Setup

CQD-44

0

Partitioning Configuration

You may partition a device into two or four sections under VMS or ULTRIX using the CQD-440/TM. To partition a device, follow the instructions below.

1 Configure the SCSI devices as explained in the section "Displaying SCSI

Device and Setting Up Configuration."

2

Select D from

II

Additional Utilities." The current configuration will display all physical devices as shown in the example in Figure

4-11:

DEVO DUO, SCSI ID 0, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV1 DU1, SCSI ID 1, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV2 DU2, SCSI ID 2, LUN

°

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV3 DU3, SCSI ID 3, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV4 MUO, SCSI ID 4, LUN

°

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV5 MU1, SCSI ID 5, LUN

°

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV6 MU2, SCSI ID 6, LUN

°

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV7 SCSI ID 7, HOST ADAPTER SCSI Reset ON, Density Mode ON, Default Tape OFF

Boot Floppy OFF, Jumper Write Protect OFF, Eject Disk ON, Truncate Size OFF

Figure 4-11: Current configuration

Setup

4-21

CQD-440

3 Answer Y to the question that appears on the screen:

CHANGE

CONFIGURATION (Y

IN)?

Figure 4-12 will display:

R = Toggle SCSI Reset M = Toggle Density Mode

D

= Toggle Disconnect

S

=

Toggle Sync/Async

C

U

A

=

Reconfigure Device

=

Toggle Default Tape (Tape Only)

=

Autoboot Start From Floppy Drive

B = Toggle BufferlTruncate Mode (Tape/Disk)

W

=

Toggle Write WNerify (Disk only)

P = Toggle Prevent Medium Removal (Disk only)

N = Write Protect from Controller Jumper Setting

V

= Truncate Disk Size for Volumn Shadowing

E

=

Eject Disk after Dismount

T

Z

=

Reset All Device Modes to Default

=

Reset Controller to Default Configurtation

Figure 4-12: Configuration change

4 Select Z to reset configuration back to default. Answer Y to reconfigure the adapter. This step is IMPERATIVE!

NOTE

If you ever reconfigure the board, you must reset the configuration to default using selection

Z.

5 Select Option C. Answer Y to the devices to be partitioned as shown in the example in Figure 4-13:

Number of Disks? (0-7) 4

DUO to be Reconfigured ? (YIN)

DUO SCSI ID ? (0-7)

0

Y

DUO LUN ? (0-3)

0

Number of Partitions ? (NONE, 2, 4)

Y

DU2 to be Reconfigured ? (YIN)

DU2 SCSI ID ? (0-7)

1

DU2 LUN ? (0-3) 1

Number of Partitions ? (NONE, 2, 4)

[total number of logical disks]

2 [N is the default]

2

[N is the default]

Number of Tapes? (0-3) 3

MUO to be Reconfigured? (YIN)

N

MU1 to be Reconfigured? (Y/N)

N

MU2 to be Reconfigured? (YIN)

N

Figure 4-13: Partitioning example

4-22 Setup

CQD-440

After you have completed configuration, the system will display device configuration as shown in the example in Figure 4-14:

DEVO DUO, SCSI 100, LUN 0 MICROP 1598-15MD1063303S1125

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV1 DU1, SCSI 10 0, LUN 0 MICROP 1598-15MD1063303S1125

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV2 DU2, SCSI 10 1, LUN 0 MICROP 1588-15MB10368101C09

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV3 DU3, SCSI 10 1, LUN 0 MICROP 1588-15MB10368101C09

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV4 MUO, SCSI 10 4, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV5 MU1, SCSI 105, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV6 MU2, SCSI 10 6, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV7 SCSI 10 7, HOST ADAPTER SCSI Reset ON, Density Mode ON, Default Tape OFF

Boot Floppy OFF, Jumper Write Protect OFF, Eject Disk ON, Truncate Size OFF

Rgure 4-14: Current configuration

6 Format RCT block for each partition of each device. See "Formatting

RCT Block" in

1/

Additional Utilities."

7 Exit out of the On-Board Utility.

NOTE

The system considers each partition as a device even though the location (LUN) is the same.

Setup 4-23

Hardware Shadowing Configuration

This section explains how to configure drives into shadow sets. A maximum of three shadow sets can be formed with each controller. For the purpose of this explanation, four disk drives will be divided into two shadow sets with three remaining tape drives as shown below:

DUO

DSO

DUl

DSI

MUO

MUl

MU2

=

SCSIID

0

Primary

=

SCSI ID

1

Shadow drive of DUO

=

SCSIID 2 Primary

=

SCSIID

3

Shadow drive of DUI

= SCSIID

4

=

SCSIID

5

= SCSIID

6

Configuration Instructions

Follow the instructions below for configuring shadow sets.

1 Select 5 from the SCSI Host Adapter Utility.

2 Select D from the

1/

Additional Utilities" to display current configuration.

3 Answer Y to the question:

CHANGE CONFIGURATION?

(YIN).

The menu shown in Figure 4-8 will display.

4 Select Z to reset configuration back to default. Answer Y to reconfigure the adapter. This step is

IMPERATIVE!

NOTE

If you ever reconfigure the board, you must reset the configuration to default using selection Z and then reconfigure.

4-24 .

Setup

5

Select C to reconfigure the device; see Figure 4-15 for instructions.

Number of Disks (including shadow units)? (0 - 7) 4 .

Number of Shadow sets? (0 - 2) 2

DUO to be Reconfigured ? (YIN)

Y

DUO SCSI 10 ? (0 - 7) 0

DUO LUN ? (0 - 3) 0

Shadow units exist? (YIN)

Y

DSO SCSI ID ? (0 - 7)

DSO LUN ? (0-3) 0

1

DU 1 to be RQconfigured ? (YIN)

Y

DU1 SCSI 10 ? (0 - 7) 2

DU1 LUN ? (0 - 3) 0

Shadow units exist? (YIN)

Y

DS1 SCSI ID ? (0 - 7) 3

DS1 LUN ? (0-3) 0

Number of Tapes? (0-3) 3

MUD to be Reconfigured? (YIN)

MUD SCSI ID ? (0 - 7) 4

MUD LUN ? (0 - 3)

0

MU1 to be Reconfigured? (YIN)

M U 1 SCS I I D ? (0 - 7) 5

MU1 LUN ? (0 - 3)

0

MU2 to be Reconfigured? (YIN)

MU2 SCSI ID ? (0 - 7) 6

MU2 LUN ? (0 - 3)

0

Y

Y

Y

Rgure 4-15: Hardware Shadowing example

CQD-440

Setup 4·25

COO-440

6 After you have completed configuration, the system will display device configuration as shown in the example in Figure 4-16:

OEVO DUO, SCSI ID 0, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

OEV1 DU1, SCSI 10 2, LUN 0

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV2 DSO, SCSI

10

1, LUN

°

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV3 DS1, SCSI 10 3, LUN

°

Disconnect ON, Sync Mode ON, Prevent Medium Removal ON, Write WNerify OFF

DEV4 MUO, SCSI

10

4, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV5 MU 1, SCSI

10

5, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV6 MU2, SCSI 10 6, LUN 0

Disconnect ON, Sync Mode ON, Buffer Mode ON

DEV7 SCSI ID 7, HOST ADAPTER SCSI Reset ON, Density Mode ON, Default Tape OFF

Boot Floppy OFF, Jumper Write Protect OFF, Eject Disk ON, Truncate Size OFF

Figure 4-16: Current configuration

7

Then answer N to the question:

CHANGE CONFIGURA nON? (y

IN)

and exit out of the On-Board Utility.

Detecting Shadowing Errors Using VMS

The following instructions will help you detect shadowing errors and shadowing drive failure.

1

At the system prompt, enter

show dev duo

2

Check the error count for shadowed disk drives.

3 If errors are detected, follow the instructions given in Appendix

C,

"Troubleshooting," to view "Controller Dependent Information."

4-26 Setup

CQD-440

Look for information describing which drive has failed such as given below:

4

lID xl

ILUNxl

IPORxI

Where:

x

is the variable used to represent the ID, LUN, and Port of the failed disk drive.

Back up the remaining good shadow set member.

Shut down the system.

5

6 Replace the drive.

7

Enter the On-Board Utility and follow these instructions: a Select option D. The current configuration will display. b Answer Y to the question:

DO YOU WANT TO CLEAR SHADOW FAILED

STATUS? <Y

IN>

c Answer

N

to the question:

CHANGE CONFIGURATION <Y

IN>

d Exit On-Board Utility.

8 Boot the system.

9 Initialize the specified shadow set in VMS.

10

Restore the backup copy to the specified shadow set.

11

Put the specified drives back on-line by mounting them to VMS.

VMS Configuration

If you followed procedures in "Determining CSR Address" in Chapter 3, VMS software will automatically configure new devices added. NO other configuration is required. If VMS does not, run Auto Configure as shown in

Appendix D.

Setup 4-27

CQD-440

UL TRIX Configuration

VAX and DEC systems using UL TRIX software must be manually configured to access the CQD-440 boards.

First, examine current configuration file to determine which controllers and devices are already connected to the system. Then refer to the respective sections for configuration procedures for the CQD-440/TM.

CQD-440ITM

Edit the configuration file by performing the following instructions for the

CQD-440/TM.

Note the CQD-440/TM must be configured with a higher

klesiu number,

higher

uq number,

and higher

tms numbers

than any other

klesiu

controller; and a higher

uda number,

higher

uq number,

and higher

ra number

than any other

uba

controller in the configuration file.

1

Make sure the following two lines are in the configuration file:

adapter uba& at nexus?

2

Where

?

= the system will fill in this variable (simply enter this? ).

&

= the node ID of the Q-bus adapter.

Connect the controller the Q-bus by entering the following line:

controller klesiui} at uba& csr XXXXXXXX vector uqintr

controller udal at uba& csr XXXXXXXX vector uqintr

3

Where i}

= the variable number that represents the CQD-440

/TM.

&

= the same number used in step

1.

XXXXXXXX = CSR address.

Tell ULTRIX what the name of the controller for the different functions will be:

controller uqV at klesiu

i}

controller uqt1 at udal

4-28 Setup

CQD-440

Where

V

= variable used to represent the controller.

~ t}

= variable used to represent the controller (unique from V above).

= the same number used in step 3 representing the controller.

#

= the same number used in step 3 representing the controller.

4 Name the tape drives and list drive unit by entering the following line:

tape tmsO at uq

V

driven tape tmsl at

uqV drive~

disk raO at uqt1 driven disk ral at uqt1

drive~

Where

V

= the same number used to represent the controller in step 4. t1 n

= variable used to represent the controller (unique from V above).

= the MU number in the On-Board Utility displays this configuration.

~

= the DU number in the On-Board Utility displays this configuration.

Setup 4-29

CQD-440

4-30 Setup

5

SCSI Basics

This chapter consists of a SCSI glossary, SCSI commands used by the

CQD-440 for MSCP and TMSCP emulation, SCSI status codes, SCSI messages,

SCSI single-ended and differential signals.

SCSI Glossary

The following is a glossary of frequently used SCSI terms.

Connect-The function that occurs when an initiator selects a target to start an operation.

Disconnect-The function that occurs when a target release control of the

SCSI bus, allowing it to go to the BUS FREE phase.

Initiator-A SCSI device (usually a host system) that requests an operation to be performed by another SCSI device.

LUN-Logic Unit Number.

Peripheral device-A peripheral that can be attached to a SCSI device (e.g., magnetic disk, magnetic tape, or optical disk).

Reconnect -The function that occurs when a target selects an initiator to continue an operation after a disconnect.

SCSI address-The octal representation of the unique address (0-7) assigned to an SCSI device. This address would normally be assigned and set in the

SCSI device during system installation.

SCSI Basics

5-1

COD-440

SCSI ID-The bit-significant representation of the

SCSI address referring to one of the signal lines DB (7-0).

SCSI device-A host computer adapter or a peripheral controller or an intelligent peripheral that can be attached to the

SCSI bus.

Target-A

SCSI device that performs an operation requested by an initiator.

SCSI Commands

SCSI commands used by the

CQD-440

/TM for

MSCP emulation are listed in

Table 5-1.

Table 5-1 SCSI Commands (MSCP)

17h lAh

IBh lEh

25h

28h

2Ah

2Bh

3Eh

3Fh

07h

08h

OAh

OBh

I2h

ISh

16h

Code

OOh

0Ih

03h

04h

Command Name

Test Unit Ready

Rezero Unit

Request Sense

Format Unit (1)

Reassign Block

Read

Write

Seek

Inquiry

Mode Select

Reserve Unit

Release Unit

Mode Sense

Start/Stop Unit

Prevent/ Allow Medium Removal

Read Capacity

Extended Read

Extended Write

Extended Seek

Read Long (2)

Write Long(2)

{1 )The Format Unit command is used by the On-Board Utility only.

(2)These commands are used if the drives support them.

5-2 SCSI Basics

CQD-440

SCSI commands used by the CQD-440/TM for TMSCP emulation are listed in

Table 5-2.

SCSI Commands (TMSCP) Table 5-2

12h

15h

16h

17h

19h

1Ah lBh

1Eh

Code

OOh

01h

03h

OSh

OAh

10h l1h

Command Name

Test Unit Ready

Rewind

Request Sense

Read

Write

Write Filemarks

Space

Inquiry

Mode Select

Reserve Unit

Release Unit

Erase

Mode Sense

Load/Unload

Prevent/ Allow Medium Removal

SCSI Status

The SCSI status codes used by CQD-440 are listed in Table 5-3.

Table 5·3

Code

OOh

02h

OSh

10h lSh

SCSI Status

Status Name

Good

Check Condition

Busy

Intennediate / Good

Reservation Conflict

SCSI Basics 5-3

CQD-440

SCSI Messages

The SCSI Messages used by CQD-440 are listed in Table 5-4.

SCSI Messages

Table 5·4

Code

OOh

01h

02h

03h

04h

OSh

06h

07h

08h

09h

80-FFh

Message Name

Command Complete

Extended Message

Save Data Pointer

Restore Pointer

Disconnect

Initiator Detected Error

Abort

Message Reject

No Operation

Message Parity Error

Identify

SCSI Single-Ended Signals

This section illustrates the CQD-440 pin assignments for the single-ended channel for non-shielded connector (]2) and the CQD-443 pin assignments for the single-ended shielded connector

02).

Single-Ended Non-Shielded Connector

Figure 5-1 illustrates the pin locations of the CQD-440 non-shielded SCSI device connector for

J2.

49

1

50

Rgure 5·1: SCSI device non-shielded connector

5-4 SCSI Basics

2

CQD-440

Table 5-5 shows the CQD-440 non-shielded single-ended SCSI connector pin assignments for

02).

Table 5·5

Signal

-OB(O)

-OB(1)

-OB(2)

-OB(3)

-OB(4)

-OB(5)

-OB(6)

-OB(7)

-OB(P)

GROUNO

GROUND

GROUND

TERMPWR

GROUND

GROUND

-A TN

GROUND

-BSY

-ACK

-RST

-MSG

~a

-C/O

~m

~/O

Single-Ended Non-Shielded Connector Pin Assignments (J2)

36

38

40

42

M

46

~

50

26

28

W

32

~

Pin Number

2

4

6

8

10

12

14

16

18

~

n

24

NOTE

All odd pins except pin 25 are connected to ground. Pin

25 is left open. The minus sign next to the signal indicates active low.

SCSI Basics 5-5

CQD-440

Single-Ended Shielded Connector

Figure 5-2 illustrates pin locations for the single-ended CQD-443 SCSI device shielded connector.

25

50

Figure 5·2: SCSI deviCe shielded connector

26

Table 5-6 illustrates the CQD-443 shielded SCSI connector pin assignments.

5-6 SCSI Basics

Table 5·6 Single-Ended Shielded Connector Pin Assignments (J2)

TERMPWR

GROUND

GROUND

-A

TN

GROUND

~~

~CK

-RST

-MSG

~ll

~/O

-REQ

~/O

Signal

-OB(O)

-OB(1)

-OB(2)

-OB(3)

-DB(4)

-OB(5)

-DB(6)

-DB(7)

-OBW)

GROUND

GROUND

GROUND

46

~

~

49

50

M

35

36

37

Pin Number

26

27

28

29

30

31

32

33

38

39

~

41

~

~

«

45

NOTE

Pin 1 to pin 25 (except pin 13) are connected to ground.

Pin 13 is left open. The minus sign next to the signal indicates active low.

CQD-440

SCSI Basics

5-7

CQD-440

SCSI Differential Signals

This section illustrates the differential signals for the

CQD-440 non-shielded connector and pin assignments and CQD~443 shielded connector and pin assignments for J1.

Differential Non-Shielded Connector

Table 5-7 shows the

CQD-440 non-shielded differential SCSI connector pin assignments (see Figure 5-1 for pin locations of the non-shielded connector).

Table 5-7 Differential Non-Shielded Connector Pin Assignments (J1)

TERMPWR

GROUND

+ATN

GROUND

+BSY

+ACK

+RST

+MSG

+SEL

+C/D

+REQ

+1/0

GROUND

Signal

GROUND

+OB(O)

+OB(1)

+DB(2)

+DB(3)

+OB(4)

+OB(5)

+DB(6)

+DB(7)

+OB(P)

DIFFSENS

GROUND

Pin Number

1

3

5

7

9

11

13

15

17

19

21

23

25

27

29

31

33

35

37

39

41

43

45

47

49

Signal

GROUND

-OB(O)

-DB(1)

-OB(2)

-DB(3)

-DB(4)

-DB(5)

-DB(6)

-DB(7)

-DB(P)

GROUND

GROUND

TERMPWR

GROUND

-ATN

GROUND

-BSY

-ACK

-RST

-MSG

-SEL

·-C/D

-REQ

-I/O

GROUND

38

40

42

44

46

48

30

32

34

36

50

Pin Number

2

4

16

18

20

22

24

6

8

10

12

14

26

28

5-8 SCSI Basics

CQD-440

Differential Shielded Connector

Table 5-8 illustrates the CQD-443 shielded SCSI connector pin assignments for

J1 (see Figure 5-2 for pin locations of the shielded connector).

Table 5-8 Differential Shielded Connector Pin Assignments (J1)

Signal

GROUND

+DB(O)

+DB(1)

+DB(2)

+DB(3)

+DB(4)

+DB(5)

+DB(6)

+DB(7)

+DB(P)

DIFFSENS

GROUND

TERMPWR

GROUND

+ATN

GROUND

+BSY

+ACK

+RST

+MSG

+SEL

+C/D

+REQ

+1/0

GROUND

Pin Number

1

2

3

4

5

19

20

21

15

16

17

18

12

13

14

6

7

8

9

10

11

22

23

24

25

Signal

-A TN

GROUND

-BSY

-ACK

-RST

-MSG

-SEL

-C/D

-REQ

-I/O

GROUND

GROUND

-DB(O)

-DB(l)

-DB(2)

-DB(3)

-DB(4)

-DB(5)

-DB(6)

-DB(7)

-DB(P)

GROUND

GROUND

TERMPWR

GROUND

42

43

44

45

46

47

48

49

50

34

35

36

37

38

39

29

30

31

32

33

Pin Number

26

27

28

40

41

SCSI Basics 5-9

COD-440

5-10 SCSI Basics

Appendix A

Supported Devices and Operating Systems

SCSI Devices

The following subsections list devices supported by the CQD-440. Contact

CMD Technical Support for correct firmware revision for the drives listed; devices marked by the following symbols are qualified as follows:

italics

bold

bolded italics

indica tes new qualified device indicates device supports multi-hosting indicates new qualified device supporting multi-hosting.

Magnetic disk drives supported by

CQD-440ITM

SEAGATE WREN VI, SWIFT (3-1/2-inch) SABRE 8-inch,

WREN VII,

WREN VIII, ELITE

I & II

(5400 RPM)

CP-3100,

CP3200

CONNER

CITOH

DEC

FUJITSU

HITACHI

HP

YD-3042, YD3082

RZ23,RZ24,RZ56,RZ57

M2246SA Series,

M2263SA,

M2249SA, M2266SA

DK515C Series,

DK516C

IBM

MAXTOR

MICROPOLIS

QUANTUM

TEAC

97548S/D series, C2233, C2234, C2235, C3010, C3009,

C3007

320-MB,3-1/2-inch

XT -40005 Series, XT -80005 Series

1588-15, 1598

ProDrive 405/805

FD235HS (3-1/2-inch FLOPPY,

DEC

RX23 compatible)

FD55GS

(5

l/4-INCH FLOPPY,

DEC RX33

compatible)

More disk drives will be qualified soon.

Supported Devices and Operating Systems

A·1

Erasable Optical disk drives supported by

CQ0-440ITM

MAXOPTICS

SONY

RICOH

Tahiti 1, Tahiti 2

SMO-DS01, SMO-D502, SMO-ES01

RO-5030E, RO-5030E2

Erasable Optical disk cartridge manufacturers

SONY, RICOH, MAXOPTICS, POO, 3M.

CO

ROM disk drives supported by

CQ0-440ITM

DEC

LMS

TOSHIBA

RRD40 , RRD42

CM210, CM212

XM3200 series

WORM drives supported by

CQD-440ITM

1 With Ten X Technology Optical Conversion Unit

All WORM drives supported by the optical conversion unit.

2 With LASERDRIVE interface

LASERDRIVE Model 800 series

Tape drives supported by CQD-440ITM

1 8-mm helical scan tape drives

EXABYTE EXB-8200, EXB-8500

2 4-mm DAT drives (Digital Audio Tape)

Archive Python 4520 OAT

GIGATREND

HP

SONY

WangDat

1200 series OAT

35450A OAT, 35470A,35480A

SDT-1000 OAT

1300 OAT, 2600 OAT, 3200 OAT

Wangtek 6130 series OAT

3 VHS helical scan tape drives

Digidata

Metrum

4 IBM-3480 compatible I8-track cartridge tape drives

ASPEN

FUJITSU

L~S

Storage Tech

Cipher

System 480

M2480 series, 2680

Independence

4280 series (model Summit)

T480

A-2

Supported Devices and Operating Systems

CQD-440

5 9 track reel to reel tape drives

Cipher

HP

F880-Il, M990, M995

Model 88780B

KENNEDY

M4 data

STORAGE TECH

QUALSTAR

TELEX

Model 9612

Model 9914

Model 292S, 9914

Model 340

Model 9294

DEC

TSZ07

6 TKSO compatible tape drives

DEC . TZ30

Operating Systems

All DEC-compatible products designed by CMD Technology, Inc. implement

MSCP (Mass Storage Control Protocol)/TMSCP (Tape Mass Storage Control

Protocol). CMD supports its implementation of MSCP /TMSCP beginning with the indicated version of the DEC operating systems listed in Table A-l.

Table A-1

VMS®

ULTRIXTM

Unix/BerkeleyTM

RSX-11M

RSX-IIM-Plus

RSTS/E

RT-ll

DSM-ll

ISM-II

TSX+

VAXELN

AT&TUN~

Operating Systems Supported by CQD-440/443

4.0 to S.5

1.2 to 4.2

4.2 to 4.3

Disk 4.1-S.3, Tape 4.2-S.3

3.0-4.3

Disk 9.0-10.0, Tape 9.S-10.0

Disk S.1-S.5, Tape 5.4-5.5

3.3-4.1

3.4

(see RT-ll)

X.X

System V

Supported Devices and Operating Systems

A-3

CQD-44

0

A-4

Supported Devices and Operating Systems

Appendix B

Troubleshooting

VMS Analyze/Error Utility

The CQD-440 logs controller dependent information in

ERRLOG.SYS

file.

User can use the VMS' ANALYZE/ERROR Utility to open the file

ERRLOG.SYS

and display the error messages for troubleshooting. By including option switches such as

/SINCE=DATE

and

/lNCLUDE=MUBO,

you may define the time reference and device. To enter the ANALYZE/ERROR

Utility, log onto the system and enter the following command:

analerrlsince=ltimellinclude=ldevicel

Some examples are shown by the following:

To view all errors that VMS has logged, enter:

analerr

To view the errors only on tape devices, enter:

anal errl inc=tapes

To view the errors that have occured only on one tape unit (MUBO), enter;

analerrlinc=mubo analerrlinc=(ptb,mubo>

To view the MUBO errors that occured on April 20, 1990 since 14:22 (02:22

PM), enter:

analerrlsince=20-Apr-1989:14:22Iinc=mubo

Troubleshooting

B-1

CQD-440

One example of the error log message is shown in below:

BEGINING OF INTERVENING ENTRIES

*************************ENTRY 6.**************************

ERROR SEQUENCE 9.

ERL$LOGMESSAGE ENTRY

KA750

I/O SUB-SYSTEM, UNIT _MUAO:

0002

REV# 120.

LOGGED ON SID 02005F78

20-APR-1989 10:21:55.41

UCODE REV# 95.

TAPE MSCP MESSAGE

MSLG$L_CMD_REF 99730004

MSLG$W _SEQNUM 0001

MSLG$B_FORMAT

MSLG$B_FLAGS

MSLG$W _EVENT

SEQUENCE #1.

00

CONTROLLER ERROR

00

00E8 DATA ERROR

UNRECOVERABLE ECC ERROR

00340000

03090000

UNIQUE IENTIFIER, 000000340000

TAPE CLASS DEVICE

TK50P

CONTROLLER SOFTWARE VERSION #1.

CONTROLLER HARDWARE VERSION #1.

8-2 Troubleshooting

CQD-440

Controller Dependent Information: Listed below is the controller dependent information for the CQD-200.

;COMMENTS:

;SCSI COMMAND, 6 BYTES

LONGWORD 1.

LONGWORD2.

00000008 ;COMMAND BYTE 3 TO 0

1 .... 1

;(LEFf TO RlGHT, BYTE 3,2,1,0)

00000050 ;BYTE 7 TO 6 DONT CARE

LONGWORD3.

LONGWORD4.

LONGWORD5.

LON GWORD6.

LONGWORD7.

LONGWORD8.

LONGWORD9.

LONGWORD10

;COMMAND BYTE 5 TO 4

I

P ...

I

;EXTENDED SENSE, 26 BYTES

00030070 ;SENSE DATA BYTE 3 TO 0

IP ... I

;(LEFf TO RIGHT, BYTE 3,2,1,0)

12000000 ;SENSE DATA BYTE 7 TO 4

1 .... 1;

00000000 ;SENSE DATA BYTE 11 TO 8

1 .... 1;

00000000 ;SENSE DATA BYTE 15 TO 12

1 .... 1;

10000000 ;SENSE DATA BYTE 19 TO 16

1 .... 1;

04000000 ;SENSE DATA BYTE 23 TO 20

1 .... 1;

0000E202 ;SENSE DATA BYTE 26 TO 24

l.b .. l;

00000000 ;(RESERVED)

1 .... 1;

Refer to the SCSI tape drive manual for a description of the error reported by the tape drive or call CMD for more detailed information.

Cables

If the system does not recognize the CQD-440 or devices connected, check the cable connections. Make sure pin 1 on the cable is aligned with pin 1 on the

SCSI device or CQD-440. Make sure pins are

NOT

bent.

LED Indicators

When the Red LED is lit, turn system

"OFF" and reboot. If the Red LED is still lit, call CMD technical support at (800) 426-3832 or (714) 454-0800.

Troubleshooting

B-3

COD-44

0

CMD Technical Support

Having a CMD board entitles you to responsive technical support. Before you call CMD Technical Support, please gather the information listed below that pertains to your configuration. Make a note of any on-screen messages when a problem occurs and have this manual dose by.

CMD

SCSI

CMD product model number and serial number.

Firmware Rev. of CMD board as shown on Eprom on the

CQD-440 .with a blue CMD logo and copyright label.

Listing of jumper settings on the board.

Distributor company and contact.

SCSI devices model numbers and firmware Rev. as shown in the

On-Board Utility.

Settings o~ SCSI ID numbers of all devices.

Computer

Computer model.

Operating System version.

Complete listing of other controllers in computer backplane.

Specify multi-hosting or clustering.

Problem

Describe exact nature of problem.

Specify detailed error messages.

Specify any recent modification to the system.

Is this a new installation?

Does the problem occur consistently?

Does the problem occur when you do not use the board?

Does the problem occur with another system (if available)?

You may contact CMD Technical Support from 8:30 AM to 5:30 PM, Pacific

Standard Time, Monday through Friday, excluding major holidays, at:

(714) 454-0800 or

(800) 426-3832 or

(714) 455-1656 FAX

8-4 Troubleshooting

Appendix C

Jumper Settings

This chapter lists the jumper settings and CSR addresses for the CQD-440.

Pin Assignments

Figure C-l shows the physical pin number assignments and functions of the

J 6 RS-232 port for accessing the On-Board Utility and J7 Front Panel Interface.

For CMD's On-Board RS-232 Utility, only pin 2, 4, 9 and grounds are used.

J6 & J7 cs

~~~~~ ~

10 8 6 4 2

Agure C-1: Pin Locations for J6 (CQD-440) and J7

Figure C-2 shows pin assignments for the RS-232 Port, J5, of the CQD-443.

J5

654321

Agure C-2: Pin Locations for J5 (CQD-443)

Jumper Settings

C-1

CQD-44a

Connector

J

6 for the CQD-440 and J5 for the CQD-443 pin assignments are listed in Table C-l shown when you are facing the connector from the controller's top edge.

Table C-1 Pin Assignments for RS-232 Utility Interface

J6 (CQD-440) J5 (CQD-443)

Pin 1 Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

Pin 9

Pin 10

Pin 2

Pin 6

Pin Assignments

No connect

Ground

TXD, transmit data for RS-232 application.

Ground

No connect

No connect

No connect

RXD, receive data for RS-232 application.

Ground

No connect

Table C-2 lists pin assignments for the Front Panel Interface (7).

Table C-2

Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

Pin 9

Pin 10

Pin Assignments for Front Panel Interface J7

Reserved

Ground

No connect

Ground

Drive 0 activity, output signal, active low.

Drive 1 activity, output signal, active low.

Drive 1 write protect, input signal, active low.

Drive 0 write protect, input signal, active low.

Ground

Reserved

C-2

Jumper Settings

CQD-440

Table C-3 lists the Host Adapter ID selections.

Table C-3

Host Adapter 10 Selections

SW2-1

ON

ON

ON

ON

OFF

OFF

OFF

OFF

SW2-2

ON

ON

OFF

OFF

ON

ON

OFF

OFF

Note (F) means factory setting.

SW2-3

ON

OFF

ON

OFF

ON

OFF

ON

OFF

Initiator

ID

Host adapter ID

=

7 highest priori ty (F)

Host adapter 1D

=

6

Host adapter 1D

=

5

Host adapter 1D

=

4

Host adapter ID

=,3

Host adapter 1D

=

2

Host adapter ID

=

1

Host adapter ID

=

0, lowest priority

Table C-4lists remaining switch settings.

Table C-4

SW2-4

SW2-4

SW2-5

SW2-5

SW2-6

SW2-6

SW2-7

SW2-7

SW2-8, SW2-9,

SW2-10

Switch Settings

ON

OFF

ON

OFF

ON

OFF

ON

OFF

OFF

Enable tape fast search option

Nonnal operation

(F)

Tape Monitor Utility enabled

(IT, ITM)

Disk SCSIfonnat ON-LINE enabled

(1M, ITM)

Tape Monitor Utility disabled

(F)

Disk SCSlfonnat ON-LINE disabled

(F)

Tape sync mode disabled

Tape sync mode enabled

(F)

Disk sync mode disabled

Disk sync mode enabled

(F)

Reserved

(F)

Jumper Settings

C-3

CQD-440

Table C-S and C-6 lists all the other jumper selections for the CQD-440.

Table C-5 CQD-440 Pin Assignments

WI

WI

W2

W2

W3

W3

W6

W6

W7

W8 to W9,

WI1 to W12

W4, W5

W9 to

WID

WI2 to W13

W4, W5

WI4

WI5

W16-1

W16-2

W16-3

W16-4

W17

W17

WIS

WI8

W19-1 to W19-3

W20

W20

W21

W2I

W22

W22

W23

W23

W24

W24

Note (F) means factory setting.

IN

OUT

1-2 IN

2-3 IN

OUT

IN

OUT

1-2 IN

2-3 IN

1-2 IN

2-3 IN

1-2 IN

2-3 IN

IN

OUT

1-2 IN

2-3 IN

IN

OUT

1-2 IN

Differential SCSI tenninator power enabled (F)

Differential SCSI tenninator power disabled

Single-ended Active Tennination

(F)

2-3 IN

1-2 IN Reset

.

2-3 IN NMI (F)

IN Single-ended SCSI tenninator power enabled (F)

OUT

OUT

IN

IN

IN

Single-ended Passive Tennination

Single-ended SCSI tenninator power disabled

Reserved

(F)

Single-ended channel enabled

(F)

IN

IN

OUT

Differential channel enabled

Reserved (F)

IN

1-2IN

OUT

OUT

Reserved (F)

D.S-us DMA dwell time

1.6-us DMA dwell time

3.2-us DMA dwell time

(F)

6.4-us DMA dwell time

Eprom Size 512-Kbit or 1-Mbit

(F)

Eprom Size 256-Kbit o

Wait State for Eprom Cycles (F)

1 Wait State for Eprom Cycle

Reserved

(F)

Adaptive DMA enabled

(F)

Adaptive DMA disabled

Adaptive DMA Dwell enabled (F)

Adaptive DMA Dwell disabled

Block mode DMA enabled

(F)

Block mode DMA disabled

Auto-Bootstrap address

=

773000 (F)

Auto-Bootstrap address

=

771000

Auto-Bootstrap disabled

(F)

Auto-Bootstrap enabled

C-4

Jumper Settings

CQD-440

Table C-6 CQD-440 Pin Assignments (continued)

W25, W26, W27,

W28, W29, W30

W31

W31

W32

W32

OUT

1-2

Cut

1-2

Cut

Note (F) means factory setting.

Reserved

(F)

Interrupt level 4 (F)

Interrupt level 5--<ut connection between 1-2

22-Bit addressing (F)

18-Bit addressing--cut the connection 1-2

Jumper Settings

C-S

CQD-44

0

eSR Address Selections

Table C-7 lists the 30 disk CSR addresses supported by the CQD-440/TM with the IC P44009A in U93.

Table C-7 CQD-4401TM CSR Addresses (Disk Only)

17

18

19

20

21

22

23

24

25

14

15

16

26

27

28

29

Address LSI-II

1

17772150

2

17760334

3

4

5

6

7

17760354

17760374

17760340

17760344

17760350

17760360

8

9

10

11

12

13

17760364

17760370

17760400

17760404

17760410

Micro VAX

SWI-I SWI-2 SWI-3 SWI-4 SWI-5

200001468 ON ON ON ON

ON

200000DC ON

200000£C

200000FC ON

200000£0

ON

200000£4

ON

200000£8

200000FO

'200000F4

200000F8

20000100

20000104

20000108

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

OFF

OFF ON

OFF ON

OFF

ON

OFF

ON

OFF

OFF OFF ON

OFF

OFF ON

OFF

OFF

ON

OFF

ON

ON

OFF

OFF

ON

ON

OFF

OFF

OFF OFF ON

OFF

ON

OFF

ON

OFF

ON

30

31

17760414 2000010C ON

17760420

20000110

ON

OFF OFF ON OFF

OFF OFF OFF

ON

17760424

17760430

20000114

20000118

ON

OFF

OFF OFF OFF OFF

ON

17760434 2000011C OFF ON

ON

ON

ON

ON

ON

OFF

17760440

20000120 OFF ON

17760444 20000124 OFF ON

17760450 20000128 OFF ON

17760454 2000012C OFF ON

17760460 20000130 OFF ON

ON

ON

OFF

OFF ON

ON

OFF OFF

OFF ON ON

OFF

OFF OFF ON

17760464 20000134

17760470 20000138

OFF

OFF

ON

OFF

OFF

ON

OFF

ON

OFF

ON

17760474

17760500

17760504

17760510

2000013C

20000140

OFF OFF

ON

20000144

OFF

OFF

OFF

OFF

ON

ON

ON

OFF

OFF

20000148 OFF OFF OFF

ON

OFF

ON

OFF

ON

17760514 2000014C OFF OFF OFF ON disable disk

OFF

OFF OFF OFF

OFF

OFF

C-6

Jumper Settings

CQD-440

Table C-8 lists the tape CSR addresses supported by the CQD-44 0 ITM with the IC P24010A in U79.

Table c-s

CQ[)"4401TM CSR Address Selections (Tape Only)

19

20

21

26

27

28

29

30

22

23

24

25

14

15

16

17

18

Address LSI-II

1 17774500

2

3

4

17760404

17760444

MicroVAX SWI-6 SWI-7 SWI-8

20001940

20000104

20000124

17760504. 20000144

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

ON

5

6

7

8

9

17760544

17760410

17760450

17760454

17760414

20000164

20000108

20000128

2000012C

2000010C

ON

ON

ON

ON

ON

ON

ON

ON

ON

OFF

OFF

OFF

OFF

OFF

ON

10

11

17760420

17760460

20000110

20000130

ON

ON

OFF

OFF

ON

ON

12

13

17760510

17760514

17760520

20000148

2000014C

20000150

20000168

ON

ON

ON

ON

OFF

OFF

OFF

OFF

ON

OFF

OFF

OFF 17760550

17760554

17760560

17760604

2000016C

20000170

20000184

ON

OFF

OFF

OFF

ON

ON

OFF

ON

ON

31

32

17760610

17760614

17760620

17760644

17760650

17760654

17760660

17760704

17760710

17760714

17760744

17760750

17760754 disable tape

20000188

2000018C

20000190

OFF

OFF

OFF

ON

ON

ON

200001A4

OFF ON

ON

ON

OFF

OFF

SWl-9

SWI-IO

ON ON

ON OFF

OFF

OFF

ON

ON

OFF

OFF

ON

ON

OFF

OFF

ON

ON

OFF

OFF

ON

ON

OFF

OFF

ON

ON

OFF

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON 200001A8 OFF

ON

200001AC

OFF ON

OFF

OFF OFF

200001BO

OFF OFF ON

200001C4

OFF OFF

ON

200001C8 OFF OFF

ON

200001CC

OFF OFF ON

ON

ON

OFF

ON

OFF

ON

OFF OFF

200001E4

200001E8

OFF

OFF

OFF

OFF

OFF

OFF

ON

ON

ON

OFF

200001EC

OFF OFF OFF OFF

ON

OFF OFF OFF

OFF

OFF

Jumper Settings

C-7

CQD-440

-8 Jumper Settings

Appendix D

VMS SYSGEN Connect Statement

To properly use the

CONNECT

statement in the SYSGEN Utility of VMS 5.0 and newer versions, the following rules must be followed.

1

Run the SYSGEN'Utility, from either terminal mode or through a command file by entering at the system prompt MC

SYSGEN.

2

It is recommended that you use

SYCONFIG.COM

if an automatic command file is used.

Issue the

CONNECT

statement to connect the controller by entering the following line at the

SYSGEN

prompt:

CONNECT aaaaIADAPTER=bbbICSR=%Occccccccl

VECTOR=%OdddIDR1VER=eeDR1VER

Where:

atUla-the

designation of the controller (no :) such as PTBO.

bbb-the

adapter number which can be found from the

SYSGEN

utility

SHOW/CONFIG

(the NEXUS number) in decimal. ccccccce-the CSR of the controller being added on the specified NEXUS preceeded by

0/00

(letter

0) in octal.

ddd-the VECTOR of the controller being added on the specified NEXUS preceeded by 0/00 (letter 0) in octal.

ee

-the name of the driver for the controller being connected.

VMS SYSGEN CONNECT Statement

D-1

CQD-440

3 Issue the next

CONNECT

statement to connect the drive by entering the following line at the

SYSGEN

prompt:

CONNECT ffffINOADAPTERISYSIDHIGH=%Xggggl

SYSIDLOW= %XhhhhhhhhIDRIVER=iiDRNER

Where:

ffff-the

designation of the drive (no :) such as MUBD.

gggg-the SYSIDHIGH

number which is 8000 plus the

NEXUS

number.

hhhhhhhh-the

SYSIDLOW

number which can be obtained after the controller is connected by using the

SYSGEN

utility

SHOW/UNIBUS.

The newly attached controller will be seen at the CSR address previously specified followed by the

SYSIDLOW

number seen in (hhhhhhhh).

[EXAMPLE] you may wish to connect a tape drive to a MicroVAX 3300.

This tape drive is the third MU: device to be added to the Q-bus. The

AUTOCONNECT

recommended CSR for this device will not be used but the CSR of 760444 will be used instead with a VECTOR of 340 on UBO.

3 View the configuration files by entering the following line at the system prompt:

MCSYSGEN

SHOWICONFIG

The screen displays the configuration as shown in Figure D-1:

System CSR and Vectors on 11-JAN-1990 10:43:47.59

Name: PUA Units: 1 Nexus:O (USA) CSR: 772150 Vector1 : 774 .. .

Name: PTA Units: 1 Nexus:O (USA) CSR: 774500 Vector1 : 260 .. .

Name: PUS Units: 1 Nexus:O (USA) CSR: 760334 Vector1 : 300 .. .

Name: TXA Units: 8 Nexus:O (USA) CSR: 760500 Vector1 : 310 .. .

Figure [)..1: SYSGEN Config File

Note the Nexus number

D

for the specified bus.

0:-2 VMS SYSGEN Connect Statement

4 Edit the configuration file to connect the devices by entering the following line at the SYSGEN prompt:

5

CONNECT PTCO/ADAPTER=UBO/CSR=% 0760444/

VECTOR=%0340/DRIVER=PUDRIVER

Find the address for the Q-bus by entering SHOW/UNIBUS

Figure D-2 shows the address:

CQD-440

Address 760444 (8002A924) responds with value 0020 (hex).

Figure D-2: Unibus Address

6 Note the SYSIDLOW value.

7

Calculate the SYSIDHIGH value by adding 8000 to the NEXUS 0 (which is 8000) and enter the following lines at the SYSGEN prompt:

CONNECT MUCO/NOADAPTERlSYSIDHIGH=%X8000/

SYSIDLOW=%X8002A924IDR1VER=TUDR1VER

*EXIT* (CONTROL

Z

to exit)

VMS SYSGEN CONNECT Statement 0-3

CQO-440

0-4 VMS SYSGEN Connect Statement

Index

A

Adaptive DMA 3-7

Adaptive DMA Dwell Time 3-8

18- or 22-bit addressing 2-1,2-6, 3-6

Asynchronous 3-9

F

Formatting RCT block 4-16

H

Hardware Shadowing 2-4

B

Block Mode DMA 2-1, 3-7

Bootstrap 2-6, 3-6

Initiator 5-1

Installation 3-14 to 3-16

Interrupt level 3-6

C

Changing LUN offset 4-6

Command Queuing 2-1, 2-6

Configuration

Configuration file 3-1, D-1 to D-3

Hardware 3-3 to

3-4, 3-6 to 3-9

Software 4-19,4-27 to 4-29

Conventions] 1-2

CQD-440 models 2-2

J

Jumper settings C-1, C-4, C-6 to C-7

L

LED indicators 2-3, 2-6, B-3

LUN 2-2,4-6,4-18,5-1

M

Mounting Slot Selection 3-14

CSR addresses 2-7,3-1 to 3-4, C-1, C-6 to C-7 MSCP 3-6,4-6,4-20, 5-1 to 5-2,

Multi-hosting 2-1, 2-4, 2-6, 4-19

A-3

D

Differential signals 5-7, 5-9

Disk Auto Boot 3-6

DMA Dwell Time 3-8

DMA transfer 2-1

DU lMU drivers 2-1, 2-6

DU lTU drivers D-3

Dynamic Defect Management 2-1,2-6

E

Eprom Size 3-13

N

NMI 3-13

Non-volatile RAM 2-2 o

On-Board Utility

Accessing 4-1, 4-6

Additional Utilities 4-9,4-11,4-13 to 4-18,

4-21

Change configuration 3-14

Index 1-1

COD-440

Completing 4-16.

Configuring LUN offset 4-6

Configuring the device 4-9,4-11,4-13 to

4-14,4-17

Ponnat Command 5-2

General Infonnation 2-2, 3-9, 4-1 to 4-26

Manually replacing bad sectors 4-8

Qualifying the drive 4-8

Operating temperature 2-6 p

Partitioning 2-4

R

Reset Switch 3-13

S

SCSI bus 2-2

SCSI bus termination 3-14 to 3-15, 3-19

SCSI cabling 3-14,3-17, B-3

SCSI commands 5-2

SCSI glossary 5-1

SCSI ID 3-14,4-18

Host Adapter 3-14, C-3

Target devices 3-14

SCSI status codes 5-3

SCSIfonnat ON-LINE 2-5 to 2-6, 3-10

Sending SCSI commands to the device 4-14

Shadowing 2-5 to 2-6

Single-ended Active/Passive Tennination

3-12,3-15

Single-ended mode 4-20

Single-ended signals 5-4 to 5-5, 5-8

Special Features 2-4

Specifications 2-6

Supported devices 2-6, A-I to A-2

Supported Operating Systems A-3

Synchronous/ Asynchronous 2-1 to 2-2, 3-9

SYSGEN Utility 3-1 to 3-3, 0-1 to 0-3

T

Tape Fast Search 3-9

Tape Monitor Utility 2-4 to 2-6, 3-10

Target 3-14,5-2

Technical Support B-4

Terminator power 3-16

Testing SCSI devices 4-15

TMSCP 5-1,5-3, A-3

Troubleshooting B-1 to B-4

U

ULTRIX 2-1,4-28 to 4-29, A-3

Unit Numbering 4-17 to 4-18

UNIX 2-1, A-3

V

Virtual data buffer 2-1,2-6

VMS 2-1,4-20, A-3, 0-1

VMS Analyze /Error Utility B-1 to B-3

W

Wait State 3-13

1-2 Index

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
