Thermo PAL User Guide Version C

Thermo PAL User Guide Version C

Thermo PAL

for the PAL Autosampler

User Guide

XCALI-97169 Revision C April 2010

© 2010 Thermo Fisher Scientific Inc. All rights reserved.

Xcalibur is a registered trademark of Thermo Fisher Scientific Inc. in the United States.

The following are registered trademarks in the United States and other countries: Microsoft and Windows are registered trademarks of Microsoft Corporation. Teflon is a registered trademark of E.I. du Pont de Nemours &

Company.

Unimetrics is a registered trademark of Unimetrics Company. Tycoon is a registered trade mark of Saint-

Gobain Performance Plastics Company. Redone and the Redone logo are registered trademarks of Redone,

L.P., PAL is a trademark of CTC Analytics AG. Agilent is a registered trademark of Agilent Technologies Inc.

All other trademarks are the property of Thermo Fisher Scientific and its subsidiaries.

Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the product operation. This document is copyright protected and any reproduction of the whole or any part of this document is strictly prohibited, except with the written authorization of Thermo Fisher Scientific Inc.

The contents of this document are subject to change without notice. All technical information in this document is for reference purposes only. System configurations and specifications in this document supersede all previous information received by the purchaser.

Thermo Fisher Scientific Inc. makes no representations that this document is complete, accurate or errorfree and assumes no responsibility and will not be liable for any errors, omissions, damage or loss that might result from any use of this document, even if the information in the document is followed properly.

This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a purchaser. This document shall in no way govern or modify any Terms and Conditions of Sale, which Terms and Conditions of

Sale shall govern all conflicting information between the two documents.

Release history: Revision A released December 2005, Revision B released February 2009, Revision C released in April 2010

Software version: Xcalibur 2.0 or higher, Thermo PAL 1.0

Firmware Version: 2.4.0 for the PAL autosampler

For Research Use Only. Not for use in diagnostic procedures.

Regulatory Compliance

Thermo Fisher Scientific performs complete testing and evaluation of its products to ensure full compliance with applicable domestic and international regulations. When the system is delivered to you, it meets all pertinent electromagnetic compatibility (EMC) and safety standards as described in CTC Analytics PAL System User Manual.

Changes that you make to your system may void compliance with one or more of these EMC and safety standards.

Changes to your system include replacing a part or adding components, options, or peripherals not specifically authorized and qualified by Thermo Fisher Scientific. To ensure continued compliance with EMC and safety standards, replacement parts and additional components, options, and peripherals must be ordered from Thermo Fisher Scientific or one of its authorized representatives.

FCC Compliance Statement

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO

THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

CAUTION Read and understand the various precautionary notes, signs, and symbols contained inside this manual pertaining to the safe use and operation of this product before using the device.

Notice on Lifting and Handling of

Thermo Scientific Instruments

For your safety, and in compliance with international regulations, the physical handling of this Thermo Fisher

Scientific instrument requires a team effort to lift and/or move the instrument. This instrument is too heavy and/or bulky for one person alone to handle safely.

Notice on the Proper Use of

Thermo Scientific Instruments

In compliance with international regulations: Use of this instrument in a manner not specified by Thermo Fisher

Scientific could impair any protection provided by the instrument.

Notice on the Susceptibility to Electromagnetic Transmissions

Your instrument is designed to work in a controlled electromagnetic environment. Do not use radio frequency transmitters, such as mobile phones, in close proximity to the instrument.

For manufacturing location, see the label on the instrument.

WEEE Compliance

This product is required to comply with the European Union’s Waste Electrical & Electronic

Equipment (WEEE) Directive 2002/96/EC. It is marked with the following symbol:

Thermo Fisher Scientific has contracted with one or more recycling or disposal companies in each

European Union (EU) Member State, and these companies should dispose of or recycle this product.

See

www.thermo.com/WEEERoHS

for further information on Thermo Fisher Scientific’s compliance with these Directives and the recyclers in your country.

WEEE Konformität

Dieses Produkt muss die EU Waste Electrical & Electronic Equipment (WEEE) Richtlinie 2002/96/EC erfüllen. Das Produkt ist durch folgendes Symbol gekennzeichnet:

Thermo Fisher Scientific hat Vereinbarungen mit Verwertungs-/Entsorgungsfirmen in allen EU-

Mitgliedsstaaten getroffen, damit dieses Produkt durch diese Firmen wiederverwertet oder entsorgt werden kann. Mehr Information über die Einhaltung dieser Anweisungen durch Thermo Fisher

Scientific, über die Verwerter, und weitere Hinweise, die nützlich sind, um die Produkte zu identifizieren, die unter diese RoHS Anweisung fallen, finden sie unter

www.thermo.com/

WEEERoHS

.

Conformité DEEE

Ce produit doit être conforme à la directive européenne (2002/96/EC) des Déchets d'Equipements

Electriques et Electroniques (DEEE). Il est marqué par le symbole suivant:

Thermo Fisher Scientific s'est associé avec une ou plusieurs compagnies de recyclage dans chaque état membre de l’union européenne et ce produit devrait être collecté ou recyclé par celles-ci. Davantage d'informations sur la conformité de Thermo Fisher Scientific à ces directives, les recycleurs dans votre pays et les informations sur les produits Thermo Fisher Scientific qui peuvent aider la détection des substances sujettes à la directive RoHS sont disponibles sur

www.thermo.com/WEEERoHS

.

C

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix

Safety and Special Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix

Contacting Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Chapter 1 Getting Connected. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Setting Up an LC/MS System with the Autosampler. . . . . . . . . . . . . . . . . . . . . . 2

Connecting the Contact Closure Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Making Contact Closure with Thermo Scientific Devices . . . . . . . . . . . . . . . . 4

Connecting the Start Pump to the Sample Pump in a Dual Pump

System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Making Contact Closure with the Autosampler, an Agilent Pump, and an MS Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting the PAL to the Data System Computer . . . . . . . . . . . . . . . . . . . . . 14

Chapter 2 Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Adding the Autosampler to the Xcalibur Instrument Configuration . . . . . . . . . 15

Firmware Versions Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using the Autosampler Control Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the Tray Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Changing the Pulse Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Specifying the Instrument Method Parameters for the Autosampler . . . . . . . . . 24

Viewing the Method Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Chapter 3 Creating Custom Templates and Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Using the Template Editor to Create Custom Templates . . . . . . . . . . . . . . . . . 33

Testing a Custom Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Viewing the Template Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Standard Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Using the Macro Editor to Create Custom Macros . . . . . . . . . . . . . . . . . . . . . . 43

Defining Variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Thermo Scientific Thermo PAL User Guide

vii

Contents

Chapter 4 Using the Direct Controls to Operate the Autosampler . . . . . . . . . . . . . . . . . . . . .51

Opening the Direct Control Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Making Single Injections from the Tune Window. . . . . . . . . . . . . . . . . . . . . . . 53

Changing the Tray Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Specifying the Location of the Direct Control Methods . . . . . . . . . . . . . . . . . . 57

Wrapping Direct Control Injections with Additional Macros . . . . . . . . . . . . . . 60

Chapter 5 Using Dynamic Load and Wash (DLW) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Installing Cycle Composer Macros or ICC Cycles . . . . . . . . . . . . . . . . . . . . . . . 62

General Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Priming the Solvent Lines, Wash1 and Wash2 . . . . . . . . . . . . . . . . . . . . . . . 64

Standard DLW Injection Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Fast DLW Injection Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Operating Dynamic Load and Wash (DLW) . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Priming the Solvent Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Location of Solvent and Waste Bottles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

DLW Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

DLW Actuator/Solenoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

DLW Cycle Step-by-Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Cycle for Standard Injection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Additional Valve Toggle Step to DLW Standard Cycle . . . . . . . . . . . . . . . . . 86

Cycle for Fast Injection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107

viii

Thermo PAL User Guide Thermo Scientific

P

Preface

The CTC PAL™ autosampler manufactured by CTC Analytics is supplied by Thermo Fisher

Scientific as part of a solution for high-throughput LC/MS applications. Thermo Pal, one of the device drivers provided on the LC Devices software CD, is the device driver that enables

Xcalibur control of the autosampler.

This user guide provides you with information on how to connect the Thermo PAL autosampler to other devices in the LC/MS system and how to operate it from the Xcalibur™ data system. This manual is provided in electronic format only. You can access this manual by choosing the following from the computer desktop:

Start > All Programs > Thermo Instruments > Manuals > LC Devices > CTC > Thermo

PAL

To provide us with comments about this document, click the link below. Thank you in advance for your help.

Related Documentation

The Thermo PAL autosampler includes Help and this manual as a PDF file:

• Thermo PAL Autosampler User Guide

Safety and Special Notices

Make sure you follow the precautionary statements presented in this guide. The safety and other special notices appear in boxes.

Safety and special notices include the following:

Thermo Scientific Thermo PAL User Guide

ix

Preface

CAUTION Highlights hazards to humans, property, or the environment. Each CAUTION notice is accompanied by an appropriate CAUTION symbol.

IMPORTANT Highlights information necessary to prevent damage to software, loss of data, or invalid test results; or might contain information that is critical for optimal performance of the system.

Note Highlights information of general interest.

Tip Highlights helpful information that can make a task easier.

Contacting Us

There are several ways to contact Thermo Fisher Scientific for the information you need.

Y

To contact Technical Support

Phone

Fax

800-532-4752

561-688-8736

E-mail [email protected]

Knowledge base www.thermokb.com

Find software updates and utilities to download at mssupport.thermo.com

.

Y

To contact Customer Service for ordering information

Phone

Fax

E-mail

Web site

800-532-4752

561-688-8731 [email protected]

www.thermo.com/ms

Y

To copy manuals from the Internet

Go to mssupport.thermo.com and click Customer Manuals in the left margin of the window.

x

Thermo PAL User Guide Thermo Scientific

Preface

Y

To suggest changes to documentation or to Help

• Fill out a reader survey online at http://www.surveymonkey.com/s.aspx?sm=R7gKOvhLXn3NTkpK2BefHQ_3d_3d .

• Send an e-mail message to the Technical Publications Editor at [email protected]

.

Thermo Scientific Thermo PAL User Guide

xi

1

Getting Connected

The Thermo PAL is a high-throughput autosampler manufactured by CTC Analytics and supplied by Thermo Fisher Scientific. For high-throughput LC/MS applications, use the PAL, a Thermo Scientific or an Agilent liquid chromatography (LC) pump, and a Thermo

Scientific MS detector.

This chapter describes the contact closure connections between the PAL, one or two Thermo

Scientific LC pumps or an Agilent pump, a Thermo Scientific MS detector, and the Xcalibur data system computer. For information on setting up the PAL, refer to the CTC Analytics PAL

System User Manual.

CAUTION Follow all of the recommendations given in the Safety Information section of the CTC Analytics PAL System User Manual. The Safety Information section includes information on the PAL electrical hazards, lithium battery, and safety labels.

Contents

Ordering Information

Setting Up an LC/MS System with the Autosampler

Connecting the Contact Closure Cables

Connecting the PAL to the Data System Computer

Ordering Information

The Thermo PAL options that Thermo Fisher Scientific supplies include the serial communication cable that you use to connect the Thermo PAL to the data system computer and the contact closure cable that you use to connect the Thermo PAL to a Thermo Scientific

LC pump and a Thermo Scientific MS detector.

Thermo Scientific Thermo PAL User Guide

1

1

Getting Connected

Setting Up an LC/MS System with the Autosampler

Table 1 lists the Thermo PAL options that you can order from Thermo Fisher Scientific.

Table 1. Thermo PAL ordering information

Part number

OPTON 13008

OPTON 13009

OPTON 13010

Description

HTS PAL

HTC PAL

HTC PAL with the 98 × 2 mL tray holder

Table 2 lists the contact closure cables that you use to connect an Agilent pump to a Thermo

Scientific MS detector and an autosampler. You can order the DB15 × 15 wire cable from

Agilent or Thermo Fisher Scientific.

Table 2. Contact closure cables used to connect an Agilent pump

Part number

CBL 7890

00012-27716

G1103-61611

Supplier

CTC Analytics

Description

PAL Interface Cable for APG Remote

DB15 connector × DB9 connector cable

Thermo Fisher Scientific DB15 connector × 15 wire cable

Agilent DB15 connector × 15 wire cable

Setting Up an LC/MS System with the Autosampler

Typical pentop setups include placing the autosampler on top of the MS detector, on top of the two pumps in a dual-pump setup, and to the left of the MS detector. Ensure that the pentop area for the autosampler is level, and provide adequate space behind the autosampler for system cables.

CAUTION To prevent damage to the injection unit during operation, place the autosampler on a level surface.

For information on assembling the PAL and connecting the solvent lines, refer to the CTC

Analytics PAL System User Manual supplied in hard copy format with the autosampler. During the installation of a Thermo Scientific MS detector, a Thermo Fisher Scientific field service engineer connects the LC system to the MS detector.

2

Thermo PAL User Guide Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Figure 1

shows a front view of the Thermo PAL. During installation, a Thermo Fisher

Scientific field service engineer connects the solvent lines between the injection valve and the

LC pump and between the injection valve and the Thermo Scientific mass spectrometer.

Figure 1.

PAL autosampler

Injection unit

Control terminal

Syringe

Courtesy of CTC Analytics

Connecting the Contact Closure Cables

During an injection cycle, the PAL sends and receives electrical signals. To start an injection cycle, the autosampler must receive an electrical signal from the LC pump. When the autosampler completes an injection cycle, it sends an electrical signal to the LC pump. For more information on interfacing the PAL with other devices, refer to the CTC Analytics PAL

System User Manual (Interfacing the PAL to Other Devices section).

This section describes how to hardwire one or two LC pumps and a Thermo Scientific MS detector to the PAL for contact closure.

To make the contact closure connections, follow the procedure for your LC/MS system:

Making Contact Closure with Thermo Scientific Devices

Thermo Scientific Thermo PAL User Guide

3

1

Getting Connected

Connecting the Contact Closure Cables

Connecting the Start Pump to the Sample Pump in a Dual Pump System

Dual-pump setup with two Accela Pumps

Making Contact Closure with Thermo Scientific Devices

The accessory kit supplied by Thermo Fisher Scientific contains the contact closure cables that you need to connect the PAL to an LC/MS system with one or two Thermo Scientific LC pumps and a Thermo Scientific MS detector

Figure 2

shows the Thermo Single Configuration cable assembly that you use to connect one

LC pump and a Thermo Scientific MS detector to the autosampler. The cable assembly consists of a DB15 connector with two 2-pin legs. One leg connects to the LC pump, and the other leg connects to the MS detector. During the installation of the LC/MS system, a

Thermo Fisher Scientific field service engineer uses the appropriate mini comb icon connectors to complete the contact closure cable assembly, and then connects the assembly to the appropriate pins on the LC pump or LC pumps and the MS detector.

Figure 2.

Contact closure cable for LC/MS with one Thermo Scientific LC Pump

300 cm

(10 ft)

Clear

Cbl Thermo Single Config.

4

Thermo PAL User Guide

Y

To connect the contact closure cable to the LC pump and the MS detector

1. Plug the DB15 connector of the contact closure cable into the 15-pin receptacle on the back of the autosampler.

The receptacle label depends on the autosampler model (see

Table 3 ).

Table 3. PAL contact closure receptacle

PAL model

HTC, LC

HTS

Receptacle label

Interface

Interface 1

2. Using an 8-pin combicon connector, connect one leg of the contact closure cable to the

appropriate pins on the back panel of the Thermo Scientific LC pump ( Table 4

).

Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Table 4.Contact closure cable connection to Thermo Scientific pump

Pump type

Surveyor LC Pump Plus

Surveyor MS Pump Plus

Accela Pump

Clear wire

PROG. START (pin 4)

GRAD START (pin 8)

GRAD START (pin 4)

Black wire

GND

GND

GND

3. Using a 2-pin combicon connector, connect the other leg of the contact closure cable to the Start in pins of the Thermo Scientific MS detector.

Figure 3

and Figure 4 show the contact closure connection between the Thermo PAL and a

Thermo Scientific LC pump and the contact closure connection between the autosampler and

a Thermo Scientific MS detector. Figure 3

is for firmware 2.5.2 and Figure 4

is for firmware

4.1.0.

Thermo Scientific Thermo PAL User Guide

5

1

Getting Connected

Connecting the Contact Closure Cables

Figure 3.

Contact closure connections to a Thermo Scientific LC pump and an MS detector (firmware 2.5.2)

TSQ Series

Surveyor MSQ Plus

LTQ Series

OR OR

+30V Max

Start In

Start

+ -

Start In +

Start In -

To MS detector

INTERFACE

DB15

To LC pump

AUX

Autosample

INTERFACE

WASH

STATION

POWER

LED BUZZER

SER3 SER2 SER1

RS232 1 2 3 4 5 6 7 8 USB

Accela Pump

6

Thermo PAL User Guide

1 2 3 4 5 6 7 8 RS232 I/O

Surveyor MS Pump Plus

RS232 UNIT ID ENET

Surveyor LC Pump Plus

Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Figure 4.

Contact closure connections to a Thermo Scientific LC pump and an MS detector (firmware 4.1.2)

TSQ Series

Surveyor MSQ Plus

LTQ Series

OR OR

+30V Max

Start In

Start

+ -

Start In +

Start In -

To MS detector

INTERFACE 1

DB15

To LC pump

Autosampler

TERMINAL SER1 LAN MODBUS

BUZZER L

E

D

WASH

STATION

INTERFACE 1 INTERFACE 2 AUX 1 AUX 2 POWER FUSE

RS232 1 2 3 4 5 6 7 8 USB 1 2 3 4 5 6 7 8 RS232 I/O RS232 UNIT ID ENET

Accela Pump Surveyor MS Pump Plus Surveyor LC Pump Plus

Connecting the Start Pump to the Sample Pump in a Dual Pump System

Thermo Scientific Thermo PAL User Guide

7

1

Getting Connected

Connecting the Contact Closure Cables

In a dual-pump system, the start pump triggers the sample pump.

To connect the start pump to the sample pump, you can use the contact closure cable that

CTC Analytics supplies, or you can use one insulated electrical wire to connect the ground pins and one insulated electrical wire to connect the GRAD START or PROG. START pins.

Figure 5

shows the contact closure cable that you can order from CTC Analytics.

Figure 5.

Contact closure cable (supplied by CTC Analytics) used to connect two LC pumps

100 cm

(39 inches)

Cbl Thermo Dual Config.

Y

To make contact closure for a dual- pump system

1. Connect the DB15 connector of the Thermo Single Config cable to the INTERFACE 1 or INTERFACE receptacle on the back panel of the Thermo PAL.

2. Connect on of the two pin legs of Thermo Single Config cable to the start pump.

3. Connect the other two pin leg of the Thermo Single Config cable to the Thermo

Scientific MS detector.

4. Connect the start pump to the sample pump:

• Connect the start pump ground pin to the sample pump ground pin.

• Connect the Grad Start or Prog. Start pin on the start pump to the Grad Start or

Prog. Start on the sample pump.

Table 4 on page 5

lists the pin assignments of the Accela Pump, Surveyor MS Pump

Plus, and the Surveyor LC Pump Plus.

Figure 6

shows two Accela Pumps connected together for contact closure.

8

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Figure 6.

Dual-pump setup with two Accela Pumps

INTERFACE 1

To the autosampler

To the MS detector

Start pump

355 River Oaks Parkway

San Jose, CA 95134 U.S.A.

Model:

Accela Pump

Serial No:

Part No:

Options/Firmware:

60057-60010

12472

CAUTION

DISCONNECT INPUT

POWER BEFORE

OPENING COVER.

REFER ALL SERVICE

TO QUALIFIED

PERSONNEL ONLY.

61010 - 1

This device complies with FCC Rules, Part 15.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

This product is manufactured under, and covered by, one or more of the following U.S. patents:

5,653,876

6,248,157B1

355 River Oaks Parkway

San Jose, CA 95134 U.S.A.

Model:

Accela Pump

Serial No:

Part No:

Options/Firmware:

60057-60010

12472

CAUTION

DISCONNECT INPUT

POWER BEFORE

OPENING COVER.

REFER ALL SERVICE

TO QUALIFIED

PERSONNEL ONLY.

61010 - 1

This device complies with FCC Rules, Part 15.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

This product is manufactured under, and covered by, one or more of the following U.S. patents:

5,653,876

6,248,157B1

Sample pump

Thermo PAL User Guide

9

1

Getting Connected

Connecting the Contact Closure Cables

Making Contact Closure with the Autosampler, an Agilent Pump, and an MS

Detector

To make contact closure between the autosampler and an Agilent pump and between an

Agilent pump and a Thermo Scientific MS detector, you must have the following cables:

• PAL interface cable (supplied by CTC or Agilent) for an Agilent pump (see Figure 7 )

• External contact trigger cable supplied by Thermo Fisher Scientific (see

Figure 8

)

Y

To make contact closure between the autosampler, an Agilent Pump, and a Thermo

Scientific MS detector

1. Using the PAL interface cable (see

Figure 7

), connect the Agilent pump to the CTC PAL:

• Connect the DB15 connector to the INTERFACE (HTC) or INTERFACE 1 (HTS)

receptacle on the back panel of the PAL (see Figure 9 and

Figure 10

).

• Connect the DB9 connector to the REMOTE receptacle on the back panel of the

Agilent pump (see Figure 9 and

Figure 10 ).

Figure 7.

PAL interface cable for an Agilent pump (supplied by CTC Analytics)

170 cm

Cbl 7890

Connect to the a utosampler

Connect to the Agilent pump

2. Using the external contact trigger cable (see Figure 8 ), connect the Agilent pump to the

MS detector:

• Connect the DB15 connector to the RELAY CONTACTS receptacle on the back panel of the Agilent pump (see

Figure 9

and Figure 10 ).

For information on installing the external contact board, refer to the Agilent Getting

Connected Guide (1100 Series or 1200 Series) that is provided as a PDF with LC

Devices.

• Connect the white wire to the Start In pin and the brown wire to ground on the MS

detector (see Figure 9 and

Figure 10 ). Secure the remaining 13 wires to the cable with

duct tape.

10

Thermo PAL User Guide Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Figure 8.

External contact trigger cable (supplied by Thermo Fisher Scientific)

Connect to the MS detector Connect to the Agilent pump

Thermo Scientific Thermo PAL User Guide

11

1

Getting Connected

Connecting the Contact Closure Cables

Figure 9.

Contact closure with an Agilent pump, the autosampler, and a Thermo Scientific MS detector (firmware 2.5.2)

Surveyor

MSQ Plus

TSQ Series

LTQ Series

Start In +

Start In -

+30V Max

Start In

Start

In

+ -

AUX 1 AUX 2

VALVE IN

Autosampler

External contact trigger cable supplied by

Thermo Fisher Scientific

INTERFACE 1 INTERFACE 2 POWER

SER3 SER2 SER1

RELAY CONTACTS

Agilent pump

ANALOG

REMOTE

VIAL- # -OUTPUT RELAY CONTACTS

RS-232 CAN CAN CONFIG

INTERFACE 1

REMOTE

Cbl 7890

12

Thermo PAL User Guide

DB15 to DB9 cable supplied by CTC Analytics

Thermo Scientific

1

Getting Connected

Connecting the Contact Closure Cables

Figure 10. Contact closure with an Agilent pump, the autosampler, and a Thermo Scientific MS detector (firmware 4.1.2)

Surveyor MSQ Plus

TSQ Series

LTQ Series

OR OR

Start In +

Start In -

+30V Max

Start In

Start

+ -

Thermo Scientific

External contact trigger cable supplied by

Thermo Fisher Scientific

Autosampler

RELAY CONTACTS

TERMINAL SER1 LAN MODBUS BUZZER L

E

D

WASH

STATION

INTERFACE 1 INTERFACE 2 AUX 1 AUX 2 POWER FUSE

INTERFACE 1

DB15 to DB9 cable supplied by

CTC Analytics

Cbl 7890

ANALOG

REMOTE

VIAL- # -OUTPUT RELAY CONTACTS

RS-232

CAN CAN CONFIG

REMOTE

Agilent pump

Thermo PAL User Guide

13

1

Getting Connected

Connecting the PAL to the Data System Computer

Connecting the PAL to the Data System Computer

Y

To connect the PAL to the data system computer

Using the serial cable that is supplied with the autosampler, connect the SER 1 port on the back panel of the autosampler to the serial port on the back panel of the data system

computer (see Figure 11 and Figure 12 ).

Figure 11. Data system connection (firmware 2.5.2)

Data system computer

Autosampler

AUX INTERFACE

WASH

STATION

POWER

LED BUZZER

SER3 SER2 SER1

14

Thermo PAL User Guide

Figure 12. Data system connection (firmware 4.1.2)

Autosampler

TERMINAL SER1 LAN MODBUS

BUZZER L

E

D

WASH

STATION

INTERFACE 1 INTERFACE 2 AUX 1 AUX 2 POWER FUSE

DB9 to DB9 serial cable

Data system computer

DB9 to DB9 serial cable

Thermo Scientific

2

Getting Started

This chapter describes how to add the autosampler to the Xcalibur instrument configuration, how to specify the available tray types from the PAL control terminal, and how to specify the injection parameters for the autosampler from the Xcalibur data system.

Contents

Adding the Autosampler to the Xcalibur Instrument Configuration

Using the Autosampler Control Terminal

Specifying the Instrument Method Parameters for the Autosampler

Adding the Autosampler to the Xcalibur Instrument Configuration

The Thermo Pal device driver provides control of the autosampler from the Xcalibur data system. To control the autosampler from Xcalibur, add the autosampler to the Xcalibur instrument configuration and specify the data system COM port that the autosampler is connected to.

Specifying the Configuration Options

This section provides information about how to specify configuration options for the autosampler.

Y

To specify the configuration options for the autosampler

1. Open the Instrument Configuration window from the computer desktop:

For Xcalibur 2.1.0 or higher, choose Start > All Programs > Thermo Foundation 1.0 >

Instrument Configuration.

The Unloading Device Drivers dialog box appears, followed by the Thermo Foundation

Instrument Configuration window (see

Figure 13

).

Thermo Scientific Thermo PAL User Guide

15

2

Getting Started

Adding the Autosampler to the Xcalibur Instrument Configuration

Figure 13. Thermo Foundation Instrument Configuration window

16

Thermo PAL User Guide

2. In the Device Types list, select All.

3. In the Available Devices list, double-click autosampler

A copy of the Thermo Pal icon appears in the Configured Devices list.

4. In the Configured Devices list, double-click (Thermo Pal).

The PAL Configuration dialog box appears (see Figure 14

).

Thermo Scientific

Figure 14. Pal Configuration dialog box

2

Getting Started

Adding the Autosampler to the Xcalibur Instrument Configuration

Thermo Scientific

5. Select the data system computer Com port that the autosampler is connected to: a. In the Com Port list, select the Com port that the autosampler is connected to. Or, click Auto Select.

Tip The autoselect feature works only if the autosampler is connected to the data system computer and turned on. b. If you have already connected the autosampler to the data system computer, click

Check to verify the connection.

6. To shorten the time between injections, select the Enable check box under Look Ahead

Injections. When you enable look ahead injections, the autosampler sets up for the next injection during the current run. The set up for the next injection involves carrying out the steps up to, but not including, the injection.

Note Do not modify or delete a sequence while the data system is running with the

Look Ahead Injections enabled. Use the stop function to finish the current injection before you modify or delete a sequence.

7. To make the Method Template and Macro Editor dialog boxes available in the

Instrument Setup window, select the Enable check box under Method Template\Macro

Editor.

Thermo PAL User Guide

17

2

Getting Started

Adding the Autosampler to the Xcalibur Instrument Configuration

8. In the Cycle Composer Macro Importer area, import the macros that you plan to use to create injection methods: a. In the Import Path box, type the location where the macros reside. Or, click Browse to locate the directory that contains the appropriate macros.

b. In the Overwrite existing macros list, make one of the following selections:

Never. The autosampler does not import the specified macro if it has the same filename as an existing macro.

Ask. The autosampler asks you if you want to overwrite existing macros.

Always. Imported macros overwrite existing macros.

c.

Click Import to import the macros.

9. In the Active Trays area, select the trays that you want to use. You can use trays that have a Yes in the Allow Use column. Clicking the tray name clears the Allow Use cell and removes the tray from the list of available trays in the Xcalibur data system.

IMPORTANT Use the autosampler control terminal to specify the tray information.

You can change the tray information when you are controlling the autosampler from the Xcalibur data system, but these changes are temporary. When you close and reopen the Xcalibur data system, the tray information resets to the autosampler control terminal settings.

10. To accept the configuration settings and close the Pal Configuration dialog box, click OK.

11. Configure the other instruments of your LC/MS system, such as the LC pump and the mass spectrometer.

12. In the (Thermo Foundation) Instrument Configuration window, click Done.

PAL Configuration Parameters

Use the PAL Configuration dialog box to select the PC Com port where the autosampler is connected, specify Macros to import, and select sample trays or stacks.

Table 5. PAL Configuration dialog box parameters (Sheet 1 of 2)

Parameter

Communications

Com Port

Description

Auto Select

Select the computer port where you plug the autosampler communication cable.

Instructs the system to automatically determine the computer port connected to the autosampler through the autosampler communication cable.

18

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

2

Getting Started

Adding the Autosampler to the Xcalibur Instrument Configuration

Table 5. PAL Configuration dialog box parameters (Sheet 2 of 2)

Parameter

Check

Description

Instructs the system to verify the computer port connected to the autosampler through the autosampler communication cable.

Look Ahead Injections

Enable Selecting this check box enables Look Ahead Injections. When

Look Ahead Injections is enabled, the autosampler sets up for the next injection during the current run. The set up for the next injection involves carrying out the steps up to, but not including, the injection.

Method Template\Macro Editor

Enable Select this check box when you want the Method Template and

Macro Editor to be accessed via Instrument Set Up. Ensuring the check box is clear prevents access to the Method Template and the Macro Editor.

Cycle Composer Macro Importer

Import Path Enter the path to the Cycle Macro to be imported.

Overwrite existing macros Choices are Never, Ask, Always. Uses chosen action to determine if existing macros are to be overwritten when a new macro is imported.

Import Import the chosen macro.

Search through files and folders to find a macro.

Browse

Active Trays

Tray Name

Stack

Allow Use

Hardware configured tray name.

Stack location of a given Tray Name.

Click to switch between YES and blank. YES means that a given tray IS accessible to the PAL system for obtaining samples

(use is allowed). A blank in this row means that the tray is NOT accessible to the PAL system for obtaining samples (use is NOT allowed).

Communications

Com Port

Auto Select

Select the computer port where you plug the autosampler communication cable.

Instructs the system to automatically determine the computer port where you plug the autosampler communication cable.

Thermo PAL User Guide

19

2

Getting Started

Using the Autosampler Control Terminal

Firmware Versions Supported

For Thermo PAL autosampler, the only supported firmware versions are 2.5.2 and 4.1.2.

Using the Autosampler Control Terminal

For general information on using the autosampler control terminal, refer to the CTC PAL

System User Manual.

To select the sample trays and to change the default pulse time setting to 4.0 seconds, follow these procedures:

Selecting the Tray Type

Changing the Pulse Time Setting

20

Thermo PAL User Guide Thermo Scientific

2

Getting Started

Using the Autosampler Control Terminal

Selecting the Tray Type

Y

To select the tray type

1. In the Job Queue screen, select the Menu screen by pressing the F1 key (see

Figure 15

).

Figure 15. Autosampler control terminal with the Job Queue screen displayed

JOB QUEUE

Thermo Scientific

Menu

Ins

Job

Del

Job

Pause

F1 F2

F3

F4

ESC STOP

Inner knob (button)

Outer knob

2. Open the Tray screen as follows: a. In the Menu screen, rotate the outer knob to move the cursor bar (highlight) to

Setup.

b. Press the inner knob (button) to select Setup.

c.

Rotate the outer knob to move the cursor bar to Objects.

d. Press the inner knob (button) to select Objects.

e.

Rotate the outer knob to move the cursor bar to Trays.

f.

Press the inner knob (button) to select the Trays screen.

Thermo PAL User Guide

21

2

Getting Started

Using the Autosampler Control Terminal

The Trays screen lists the available trays.

3. Select a tray as follows: a. Rotate the outer knob to move the cursor bar to the Tray to be selected.

b. Select the Tray by pushing the inner knob (button).

The screen now shows the Tray Type.

c.

Make the Tray Type active by pushing the inner knob (button).

The Tray Type is highlighted.

d. Rotate the outer knob to select the tray type. Select NONE if no tray is present

(rotate the outer knob until NONE appears as the Tray Type).

e.

Push the inner knob (button) to select this tray type.

4. Repeat

step 3

for all the trays to be used.

5. Return to the Job Queue screen by pushing the F4 key (Home).

Changing the Pulse Time Setting

To control LC systems with a Thermo Scientific LC pump and an autosampler from the

Xcalibur data system, you must change the default pulse time setting for the autosampler from

2 seconds to 4 seconds. The pulse time is the length of time that the autosampler sends an output signal after it makes an injection. The LC pump receives this output signal through the contact closure cable.

IMPORTANT If your LC system contains a Thermo Scientific LC pump and an autosampler, you must change the autosampler’s default pulse time setting. If you leave the default pulse time set to 2 seconds, the status of the LC pump remains at waiting for contact closure after you make an injection.

22

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

2

Getting Started

Using the Autosampler Control Terminal

Change the pulse time setting to 4.0 seconds from the Injected screen (see Figure 16 ).

Figure 16. Menu path to Injector screen

Menu

Setup

Objects

Out Signals

Injected

Injected

Destination

Pulse Time

SW-Out1

4.0 s

Oms...9.9s

Set

Deflt

Home

Y

To change the pulse time setting

1. Open the Injected screen: a. In the Job Queue screen, select the Menu screen by pressing the F1 key (see

Figure 15 ).

b. Rotate the outer knob to move the cursor bar (highlight) to Setup, and then press the inner knob (button). The Setup screen appears.

c.

Rotate the outer knob to move the cursor bar (highlight) to Objects, and then press the inner knob (button). The Objects screen appears.

d. Rotate the outer knob to move the cursor bar (highlight) to Out Signals, and then press the inner knob (button). The Out Signals screen appears.

e.

Rotate the outer knob to move the cursor bar (highlight) to Injected, and then press the inner knob (button). The Injected screen appears (see

Figure 16

).

2. Rotate the outer knob to move the cursor bar (highlight) to Pulse time, and then press the inner knob (button). The time cell is highlighted.

3. Rotate the out knob to change the pulse time to 4.0 seconds, and then press the inner knob (button) to set this selection as the default.

4. Return to the Job Queue screen by pushing the F4 key (Home).

Thermo PAL User Guide

23

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

Specifying the Instrument Method Parameters for the Autosampler

To inject a sample set automatically, you must create an instrument method that contains the chromatographic conditions and mass spectrometer data acquisition settings, and then create an acquisition sequence that specifies the instrument method and vial location for each run.

This section describes how to specify the basic instrument method parameters for the autosampler. For information about creating acquisition sequences, refer to the Sequence

Setup view Help.

Creating an Instrument Method

This section provides information about how to create an instrument method.

Y

To specify the instrument method parameters for the autosampler

1. Open Xcalibur from the computer desktop:

For Xcalibur version 2.1.0 or higher, choose Start > All Programs > Thermo Xcalibur >

Xcalibur.

The Roadmap Home Page appears.

2. Click (Instrument Setup).

The Instrument Setup window appears with the configured devices displayed in the view bar (see

Figure 17 ). By default, the view for first device is open. A bright-green triangle in

the lower-right corner of the device icon indicates that the view for the device is open.

Figure 17. Instrument Setup window

Bright-green triangle

24

Thermo PAL User Guide Thermo Scientific

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

3. In the view bar, click (Thermo Pal).

The Method Setup page for the autosampler appears (see Figure 18 ).

Figure 18. Method Setup page for the autosampler

Browse button

Thermo Scientific

4. Under Template Selection, click Browse and browse to the folder that contains the autosampler methods (*.pme).

For a standard installation, the folder that contains the autosampler method is located in

the following directory (see Figure 19 ):

C:\Thermo\Instruments\LC Devices\ThermoPAL\PAL\methods

Thermo PAL User Guide

25

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

Figure 19. Location of Thermo PAL autosampler templates

26

Thermo PAL User Guide

5. In the Template list, select a Template that represents the task that you want to do.

The autosampler comes with three templates: Single Step LC Injection.pme, Multi Step

LC Injection.pme, and Startup-Shutdown.pme.

For high-throughput applications, use Single Step LC Injection.pme. If your applications require more pre- and post-injection cleaning steps, use Multi Step LC Injection.pme.

The Startup-Shutdown.pme template is reserved for future use.

In addition to these templates, you can create your own custom templates (see “Using the

Template Editor to Create Custom Templates” on page 33 ). When you store a custom

template in the same folder as the standard templates, the template appears in the

Template list.

Figure 20 shows the macro sequence and the macro variables for the Single Step LC

Injection template.

Thermo Scientific

Figure 20. Method Setup page with LC-Inj template

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

Thermo Scientific

Macro sequence for the

Single Step LC Injection template

Variables list

When you select a template, the macros used by the template appear in the Macro

Sequence area. When you click on a macro listed in the Macro Sequence area, the variables used by the Macro appear in the Variables area.

6. In Variables area, keep the parameters set to the defaults or type the appropriate values for your application.

Thermo PAL User Guide

27

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

28

Thermo PAL User Guide

7. In the Syringe list, select the size of syringe that is installed in the autosampler.

The default variable settings for the Single Step LC Injection template and the default setting of 10 μL in the Recommended Injection Volume box are suitable for a 100 μL syringe. Changing the syringe size can change the allowable ranges for the recommended injection volume and the variables specified in the LC-Inj macro.

IMPORTANT Make sure that your syringe selection matches the size of the syringe that is installed in the autosampler.

• If the autosampler is set up to recognize the installed syringe size, an error message appears when you download methods that specify a different syringe size.

• If the autosampler is not set up to recognize the installed syringe and the specified syringe size does not match the actual syringe size, the autosampler does not inject the specified injection volume.

8. Under Recommended Injection Volume, in the Volume (μL) box, type the volume of sample that you want the autosampler to inject.

The allowable injection volume range is based on the syringe size.

IMPORTANT For partial loop injections (variable volume), make sure that the recommended injection volume is less than half the sample loop size.

9. Under Look Ahead Injections, if the Delay Time (mins) box is available, type the amount of time that you want the autosampler to wait after it completes the current injection before it starts the next injection.

During a look ahead injection, the autosampler aspirates the sample for the next injection and waits until the end of the current run to inject the sample into the valve. When you add a delay time, the autosampler does not begin the next injection cycle immediately after completing the current injection cycle. If you enter a delay time longer than the method run time, the autosampler begins the next injection at the end of the current run.

This means that adding a long delay time does not add additional run time to the method run time, but it does cancel the effect of using the Look Ahead Injection feature.

Note The Look Ahead Injections feature is available if you selected the Enable check box in the Look Ahead Injections area of the PAL Configuration dialog box.

10. Specify the acquisition parameters for the other devices of your LC or LC/MS instrument.

11. Save the method: a. From the Instrument Setup window menu bar, choose File > Save As.

The Save As dialog box appears.

b. Select an appropriate file location for the method.

c.

In the File name box, type an appropriate name for the method.

Thermo Scientific

d. Click Save. The File Summary Information dialog box appears.

e.

(Optional) In the Comment box, type additional information about the method.

f.

Click OK.

Xcalibur (or other Thermo Scientific data acquisition application such as LCquan) stores the method as a *.meth file in the specified file location.

Instrument Setup Parameters

Use the Method Setup page to specify instrument method parameters for the autosampler.

Table 6. Method Setup page parameters (Sheet 1 of 2)

Parameter

Template Selection

Template

Description

Method Folder

Browse

New Template

Template Description

Syringe

Macro Sequence

This box shows the names of the default method templates.

After you select a template, the Template box changes to a pane. This pane shows the path to the chosen method template file.

This pane shows the path to the default template folder location before a default method template is chosen. After a default method template is chosen (via the Template box) the

Method Folder label disappears, leaving the Template label next to a pane that shows the path to the chosen template.

The Browse button can be seen next to the Method Folder pane before the method template is chosen in the Template box. Click the browse soft button to browse through the computer file system for the method template of your choice.

When you select a method template, the window changes to show the path to the chosen template and the Browse button changes to the New Template button.

This soft button appears after a method template is chosen (in the Template box). Selecting this button brings back the

Template box, Method Folder pane, and Browse button.

These are used to find a new method template.

A description of the template chosen in the Template

Selection portion of the Method Setup page.

This list contains the allowed syringe volumes. Select the appropriate syringe volume.

Displays the sequence of macros that make up the method chosen in the Template window. Select a macro name to be displayed in the Macro area; its variables also appear in the

Variables area. (See table continuation.)

Thermo Scientific

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

Thermo PAL User Guide

29

2

Getting Started

Specifying the Instrument Method Parameters for the Autosampler

Table 6. Method Setup page parameters (Sheet 2 of 2)

Parameter Description

Recommended Injection Volume

Volume (μl) 1) When you select an instrument method for use to generate a new sequence (on the Xcalibur Home Page), the injection volume is set to what is entered in this box.

2) When "From AS" (From Auto Sampler) is specified in the

LCquan injection volume sequence cell, the CTC PAL autosampler uses the volume in this box when you submit the

LCquan sequence for acquisition.

Look Ahead Injections

Delay Time (mins)

Macro

Variables

Default All

Enter the Delay Time (in minutes) between injections when using the Look Ahead feature. You enable the Look Ahead

Injections option from the PAL Configuration dialog box.

When you enable this option, the next Look Ahead Injection is delayed the amount of time entered in this box. The delay time countdown begins at the completion of any post-injection steps. This prevents a sample from being held in the injection syringe for the duration of the current run. If the entered Delay Time is too long, or the current run ends prematurely, the entered Delay Time is canceled and the next injection commences in the normal manner.

The Macro area shows the name of the macro selected in the

Macro Sequence pane. The sequence number (x) of the selected macro out of the total number of macros (y) in the

Macro Sequence is also displayed next to the name of the selected macro (Macro "name", x of y). This area also lists the

Variables associated with the macro chosen in the Macro

Sequence pane.

The variable parameters used by the selected macro are displayed in this portion of the Macro area. Variables with specific allowed values (discrete variables) are displayed in lists. Continuous variables are displayed in panes. The allowed values of the discrete variables may be chosen from those presented in the list for the variable. The allowed values for continuous variables are displayed when you hover the cursor over the respective pane for the variable. The desired value for the continuous variable may be typed in its pane.

This button changes the variables, used in the selected Macro

Sequence, to their default values.

30

Thermo PAL User Guide Thermo Scientific

2

Getting Started

Viewing the Method Summary

Viewing the Method Summary

Y

To view a summary of your autosampler portion of an instrument method

1. Open the Instrument Setup view for the autosampler (see “Specifying the Instrument

Method Parameters for the Autosampler” on page 24 .

2. Choose File > Open and select the instrument method that you want to review.

3. Click the Method Summary tab.

The Method Summary page appears with a summary of the autosampler parameters for

the active instrument method (see Figure 21

).

Thermo Scientific Thermo PAL User Guide

31

2

Getting Started

Viewing the Method Summary

Figure 21. Method Summary page

Method Summary

Use the Method Summary page to view the details of the Macro Sequence that makes up a autosampler Method or Template.

The contents of the Method Summary/Template Summary page is read-only

32

Thermo PAL User Guide Thermo Scientific

3

Creating Custom Templates and Macros

This chapter describes how to create custom templates and macros.

Contents

Using the Template Editor to Create Custom Templates

Testing a Custom Template

Viewing the Template Summary

Standard Macros

Using the Macro Editor to Create Custom Macros

Defining Variables

Using the Template Editor to Create Custom Templates

Three standard templates are provided with the autosampler. To create a custom template, use the Template Editor dialog box.

Creating a Custom Template

This section provides information about how to create a custom template.

Y

To create a custom template

1. Open the Template Editor page:

a. Open the Instrument Setup view for the autosampler (see “Specifying the Instrument

Method Parameters for the Autosampler” on page 24 ).

b. From the menu bar, choose PAL Auto Sampler > Template \ Macro Editor.

The Template Editor page of the Pal Template \ Macro Editor window appears (see

Figure 22 ).

Thermo Scientific Thermo PAL User Guide

33

3

Creating Custom Templates and Macros

Using the Template Editor to Create Custom Templates

Figure 22. Template Editor page of the Pal Template \ Macro Editor window

34

Thermo PAL User Guide Thermo Scientific

3

Creating Custom Templates and Macros

Using the Template Editor to Create Custom Templates

2. (Optional) In the Template Description box, type a description of your custom template.

3. In the Syringe list, select the appropriate syringe size for the parameters to be specified in the template.

4. To add macros to the template: a. Under Macro, select a macro from the list.

The Insert Above and Insert Below buttons become available b. Click Insert Above or Insert Below.

The selected macro appears in the Macro Sequence list.

5. To delete macros from the Macro Sequence list: a. Select the macro that you want to delete from the Macro Sequence list.

b. Click Delete.

6. To replace a macro in the Macro Sequence list: a. Under Macro, select a macro from the list.

b. Select the macro that you want to replace in the Macro Sequence list.

c.

Click Replace.

7. To save the template: a. Click Save As.

The Save As dialog box appears.

b. Select a file location.

c.

In the File name box, type an appropriate name.

d. Click Save.

The autosampler saves the template with the file extension *.pme.

Template Editor Page

Use the Template Editor page of the Pal Template \ Macro Editor window to make a new template (a sequence of macros). Each macro in the sequence is made up of variables. You may also edit these variables on this page.

Table 7. Template Editor page parameters (Sheet 1 of 3)

Parameter

Template Description

Syringe

Description

Enter the method description in this box.

Select the syringe volume from this list.

Thermo Scientific Thermo PAL User Guide

35

3

Creating Custom Templates and Macros

Using the Template Editor to Create Custom Templates

Table 7. Template Editor page parameters (Sheet 2 of 3)

Parameter

Macro Sequence

Insert Above

Insert Below

Replace

Delete

Run

Step

Macro

Default All

Description

This box displays the macros chosen for the method being made in the Method Template Editor. The macros in this sequence are selected from the Macro list (see below). Double-clicking a macro in the Macro

Sequence box displays it in the Macro list as described later in this table, along with the variables that make up the macro (in the Variables area below the Macro list).

A Macro in the Macro list (see below) is placed above the macro selected in the Macro Sequence box

(highlighted in blue).

A Macro in the Macro list (see below) is placed below the macro selected in the Macro Sequence box

(highlighted in blue).

Replaces the macro (highlighted in blue) in the Macro

Sequence box with the macro that is in the Macro list

(see explanation below).

Deletes the macro that is selected (highlighted in blue) in the Macro Sequence box.

Automatically executes the macros that constitute the

Method (Macro Sequence).

Executes the Method (Macro Sequence) in a stepwise manner.

Individual PAL macros are chosen in this list. When you select a macro, it is highlighted in blue. Displayed at the top of the Macro list is the sequence number (x) of the chosen macro and the total number of macros

(y) in the Macro Sequence pane ("Macro x of y"). The chosen macro may be placed in the Macro Sequence box (see explanation above) by using the Insert Above,

Insert Below, or Replace buttons as appropriate (see corresponding explanations above).

Changes all of the Method Template Editor variables to their default values.

36

Thermo PAL User Guide Thermo Scientific

3

Creating Custom Templates and Macros

Testing a Custom Template

Table 7. Template Editor page parameters (Sheet 3 of 3)

Parameter

Variables

Save Template

Save As

Description

The variables that make up the macro in the Macro list are displayed in this area. Variables with specific allowed values (discrete variables) are displayed in lists.

Continuous variables are displayed in boxes. You may choose the allowed values of discrete variables from those presented in the list for the variable. The allowed values for continuous variables are displayed when you hover the cursor over the respective box for the variable. The desired value for the continuous variable is then typed in its box.

Saves the Method Template under the current file name (overwrites the current file).

Saves the Method Template under a new file name or in a new location that you type in the Save As dialog box.

Testing a Custom Template

This section provides information about testing a custom template.

Using the Template Editor dialog to Test a Custom Template

You can test a custom template from the Template Editor dialog box.

Y

To test your new template step by step

1. If the Template Editor dialog box is closed, open it.

2. Open the template that you want to review by choosing File > Open Method

Template....

The default path to open a template is as follows:

C:\Thermo\Instruments\LC Devices\ThermoPAL\PAL\methods

Thermo Scientific Thermo PAL User Guide

37

3

Creating Custom Templates and Macros

Testing a Custom Template

3. Click Step.

The Run Auto Sampler Method In Step Mode appears (see Figure 23

).

Figure 23. Run Auto Sampler Method In Step Mode dialog box

4. Make the appropriate entries and selections:

• Under Trays, select the appropriate trays.

• Under Vial Index, type an appropriate vial location for this template you are testing.

• Under Volume, type the volume that you want to inject.

• In the Injection Per Vial box, type the number of injections that you want to make from each vial.

5. Click Run.

The autosampler performs the actions specified in the template step-by-step. At the completion of each step, The autosampler pauses the injection sequence and prompts you

with the Pal Method Editor dialog box (see Figure 24 ).

Figure 24. Pal Method Editor dialog box

38

Thermo PAL User Guide

6. Do one of the following:

• To continue stepping through the template, click Step.

Thermo Scientific

3

Creating Custom Templates and Macros

Testing a Custom Template

• To run the remaining portion of the template, click Run.

• To stop the run, click Stop Run.

Y

To run the complete sequence of macros in the template without pausing

1. If the Template Editor dialog box is closed, open it.

2. If you closed the custom template, choose File > Template > Open.

3. Click Run.

The Run Auto Sampler Method dialog box appears (see

Figure 25 ).

Figure 25. Run Auto Sampler Method dialog box

4. Make the appropriate entries and selections.

5. Click Run.

The autosampler executes the macros listed in the template.

Run Auto Sampler Method Dialog Box

Use the Run Auto Sampler Method dialog box to enter the Methods information required for the PAL to carry out autosampling.

Table 8. Run Auto Sampler Method dialog box parameters (Sheet 1 of 2)

Parameter

Vial Index

1

Description

2

In this box type the vial index to be used with the method (SL.index).

In this box type the vial index to be used with the method (SL.index2).

Thermo Scientific Thermo PAL User Guide

39

3

Creating Custom Templates and Macros

Viewing the Template Summary

Table 8. Run Auto Sampler Method dialog box parameters (Sheet 2 of 2)

Parameter

Trays

1

Description

2

From this list select the tray to be used with the method (SL.tray).

From this list select the tray to be used with the method (SL.tray2).

Injectors

1

2

From this list select the injector to be used with the method (SL.injector).

From this list select the second injector to be used with the method (SL.injector2).

Volume

1

2

In this box type the injection volume to be used with the method (SL.volume).

In this box type the second injection volume to be used with the method (SL.volume2).

Injections Per Vial

Run

Cancel

Type the number of replicate injections to be made from each vial.

Run the selected method.

Cancel any changes and close the page.

Viewing the Template Summary

Y

To view a summary of a template

1. Open the PAL Template \ Macro Editor window (see “Using the Template Editor to

Create Custom Templates” on page 33

.

2. Open the template that you want to review by choosing File > Open Method

Template....

The default path to open a template is as follows:

C:\Thermo\Instruments\LC Devices\ThermoPAL\PAL\methods

3. Click the Template Summary tab.

40

Thermo PAL User Guide Thermo Scientific

3

Creating Custom Templates and Macros

Viewing the Template Summary

The Template Summary page appears with a summary of the active template (see

Figure 26 ).

Figure 26. Template Summary page

Thermo Scientific Thermo PAL User Guide

41

3

Creating Custom Templates and Macros

Standard Macros

Standard Macros

Figure 27 shows the macros that are provided with a standard installation.

Figure 27. Standard macros

42

Thermo PAL User Guide Thermo Scientific

3

Creating Custom Templates and Macros

Using the Macro Editor to Create Custom Macros

Using the Macro Editor to Create Custom Macros

Macros are the building blocks that you use to create templates.

Creating a Custom Macro

This section provides information about how to create a custom macro.

Y

To create a custom macro

1. Open the Macro Editor dialog box: a. Open the Instrument Setup view for the autosampler.

b. From the menu bar, choose PAL Auto Sampler > Template \ Macro Editor. c.

Click the Macro Editor tab.

The Macro Editor page of the Pal Template \ Macro Editor window appears (see

Figure 28 ).

Thermo Scientific Thermo PAL User Guide

43

3

Creating Custom Templates and Macros

Using the Macro Editor to Create Custom Macros

Figure 28. Macro Editor page of the Template \ Macro Editor window

44

Thermo PAL User Guide

2. Under Macro, select a macro from the list.

The description of the selected macro appears under Macro Description and a list of macro variables appears under Macro Variables.

Thermo Scientific

3

Creating Custom Templates and Macros

Using the Macro Editor to Create Custom Macros

3. To add a variable to the macro, click Add.

The Variable Definition dialog box appears.

4. Define the variable (see

“Defining Variables” on page 48 ).

5. To save the macro: a. Click Save As.

The Save As dialog box appears.

b. Select a file location.

c.

In the File name box, type an appropriate name.

d. Click Save.

The autosampler saves the macro with the file extension *.pma.

PAL Template - Macro Editor Page

Use the Macro Editor page of the Pal Template \ Macro Editor window to create custom macros.

Table 9. Macro Editor page parameters (Sheet 1 of 3)

Parameter

Macro

Macro Description

Macro Variables

Add

Description

This list displays existing autosampler macros. Select the macro that you want to edit.

A description of the macro selected in the Macro list.

Variables used by the macro selected in the Macro list.

Adds a new variable to the macro variables. The new variable is defined in an Edit Parameter dialog box that opens when you click Add.

The Edit Parameter dialog box has a check box for the

Parameter Type (numeric or object). If you select a numeric Parameter Type, you see a pane in which you enter the new parameter name, a list for the parameter units, and panes in which you enter the default value for the parameter along with the lower and upper limits for the parameter. If you select an object

Parameter Type, you see a check list of objects that might be represented by the parameter.

Thermo Scientific Thermo PAL User Guide

45

3

Creating Custom Templates and Macros

Using the Macro Editor to Create Custom Macros

Table 9. Macro Editor page parameters (Sheet 2 of 3)

Parameter

Edit

Description

Edits an existing macro variable. The editing is carried out in an Edit Parameter dialog box that opens when you click Edit.

Delete

Command Sequence

Insert Above

Insert Below

Replace

Delete

The Edit Parameter dialog box has a check box for the

Parameter Type (numeric or object). If you select a numeric Parameter Type, you see a pane in which you enter the new parameter name, a list for the parameter units, and panes in which you enter the default value for the parameter along with the lower and upper limits for the parameter. If you choose an object

Parameter Type, you see a check list of objects that may be represented by the parameter.

Deletes the selected Macro Variable.

The sequence of commands that make up the macro selected in the Macro list. Double-clicking one of the commands highlights it in blue and causes it to be displayed in the Command area. In the Command area the command parameters are shown in both panes (continuous variables) and lists (discrete variables).

The command shown in the Command area is inserted above the command selected (highlighted in blue) in the Command Sequence pane.

The command shown in the Command area is inserted below the command selected (highlighted in blue) in the Command Sequence pane.

The command selected (highlighted in blue) in the

Command Sequence pane is replaced by the command shown in the Command area.

Deletes the command selected (highlighted in blue) in the Command Sequence pane.

46

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

3

Creating Custom Templates and Macros

Using the Macro Editor to Create Custom Macros

Table 9. Macro Editor page parameters (Sheet 3 of 3)

Parameter

Command

Description

Individual autosampler commands are displayed in a list. These individual commands make up the command sequence of a autosampler macro. Select the command by rolling the cursor over the command (no click is needed), highlighting each command in blue.

Clicking the command displays it in this list

(highlighted in blue). Simultaneously, the command parameters are displayed in the Parameters area below the Command list.

Parameters

Command Description

Save Macro

Save As

At the bottom of this area (below the Parameters area) is a pane that describes the function of the selected command.

The Parameters area displays the command parameters used by the autosampler command that you select in the Command list. Parameters with specific allowed values (discrete parameters) are displayed in lists. Continuous parameters are displayed in panes. The allowed values of discrete parameters may be chosen from those presented in the list for the parameter. The allowed values for continuous parameters are displayed when you place the cursor over the respective pane for the parameter.

The desired value for the continuous parameter may be typed in its pane. You can view other allowed continuous parameter values in a shortcut menu. This menu is activated by right-clicking the continuous parameter box of interest. The parameter you select from the shortcut menu appears in the box.

A description of the command displayed in the

Command list.

Saves the macro (command sequence) under the current filename (overwrites the current file).

Saves the macro (command sequence) under a new filename, in a new location, or with both a new filename and location that you type in the Save As dialog box.

Thermo PAL User Guide

47

3

Creating Custom Templates and Macros

Defining Variables

Defining Variables

Variables are the building blocks that you use to create macros.

Creating Custom Variables

This section provides information about how to create custom variables.

Y

To create custom variables

1. Open the Macro Editor dialog box: a. Open the Instrument Setup view for the PAL autosampler (see

“Specifying the

Instrument Method Parameters for the Autosampler” on page 24

).

b. From the menu bar, choose PAL Auto Sampler > Template \ Macro Editor. c.

Click the Macro Editor tab.

The Macro Editor page of the Pal Template \ Macro Editor window appears (see

Figure 28 ).

2. Click Add.

The Variable Definition dialog box appears (see Figure 29

).

Figure 29. Variable Definition dialog box

48

Thermo PAL User Guide

3. Select a variable type:

• To create a variable that is a numeric value, select the A Number Value option. Then go to

step 4

.

• To create an object variable, select the An Object option. A list of objects appears.

Go to step 5

.

Thermo Scientific

3

Creating Custom Templates and Macros

Defining Variables

4. To complete the definition of a numeric variable: a. In the Variable Name box, type an appropriate name.

b. In the Variable Units list, select a unit of measure.

c.

In the Default Value box, type a default value for the variable.

d. In the Lower Limit box, type a lower limit for the variable.

e.

In the Upper Limit box, type an upper limit for the variable.

f.

Click OK to save the variable and close the Variable Definition dialog box.

5. To complete the definition of an object variable: a. In the Variable Name box, type an appropriate name. b. Select the appropriate objects (see

Figure 30 ).

c.

Click OK to save the variable and close the Variable Definition dialog box.

Figure 30. Object variable selections

Thermo Scientific Thermo PAL User Guide

49

3

Creating Custom Templates and Macros

Defining Variables

Variable Definition Dialog Box

Use the Variable Definition dialog box to specify the details of a numerical or object Macro

Variable that you want to add or edit in the Macro Variables box.

Table 10. Variable Definition dialog box

Parameter

Variable Type

A Numeric Value

Description

An Object

Variable Name

OK

Cancel

Select this if the parameter is a numeric value. If you are editing an existing numerical parameter, this box is marked with a black dot.

Select this if the parameter is an object. If you are editing an existing object parameter, this box is marked with a black dot.

If you are editing an existing variable, this box shows the name of the variable. Type your choice for the name of the variable if you are adding a new one.

Accepts the new Variable Definition or accept the edits to an existing Variable Definition.

Deletes changes made in the Variable Definition dialog box.

Numeric Value Variable Type

Variable Units

Default Value

Lower Limit

Upper Limit

Object Variable Type

Please check what objects this variable may be

If you are editing an existing variable, this list shows the units for the selected variable. If you are adding a new variable, you may enter units appropriate for that variable. When you click the list arrow, you can select the appropriate units from the options in the list.

The nominal or center value of the variable.

The lowest acceptable value of the variable.

The highest acceptable value of the variable.

Select one or more objects that are described by the variable.

50

Thermo PAL User Guide Thermo Scientific

4

Using the Direct Controls to Operate the

Autosampler

This chapter describes how to operate the autosampler from the Direct Control dialog box.

Contents

Opening the Direct Control Dialog Box

Making Single Injections from the Tune Window

Changing the Tray Configuration

Specifying the Location of the Direct Control Methods

Wrapping Direct Control Injections with Additional Macros

Opening the Direct Control Dialog Box

The direct control pages for the autosampler are available from the Instrument Setup window and the Tune window.

Y

To open the Direct Control dialog box from the Instrument Setup window

1. In the view bar, click (Thermo Pal).

2. The Instrument Setup view for the autosampler appears.

3. From the menu bar, choose PAL Auto Sampler > Direct Control.

The Direct Control dialog box appears with the Methods page displayed (see Figure 31

).

Thermo Scientific Thermo PAL User Guide

51

4

Using the Direct Controls to Operate the Autosampler

Opening the Direct Control Dialog Box

Figure 31. Direct Control dialog box

52

Thermo PAL User Guide

Y

To open the Inlet Direct Control dialog box from the Tune window

1. From the menu bar, choose Setup > Inlet Direct Control.

2. Click the Thermo Pal tab.

The Inlet Direct Control dialog box for the autosampler appears with the Methods page displayed. The Inlet Direct Control dialog box has the same functionality as the Direct

Control dialog box shown in Figure 31

.

Thermo Scientific

4

Using the Direct Controls to Operate the Autosampler

Making Single Injections from the Tune Window

Making Single Injections from the Tune Window

You can make single injections from the Tune window.

Y

To make single injections from the Tune window

1. Open the Tune window for your mass spectrometer.

2. Open the Inlet Direct Control dialog box (see

“Opening the Direct Control Dialog Box” on page 51

).

3. Specify the location of the methods that you want to use (see

“Direct Control - Tray

Configuration Page” on page 57 ).

4. Specify the tray types that are loaded in the autosampler L tray holders (see

“Changing the Tray Configuration” on page 56

).

5. Click the Methods tab.

The Methods page appears. The Syringe area lists the size of the configured syringe. The

Device Status area lists the status of the autosampler.

6. In the Method list, select a method.

A description of the method appears in the Description box (see

Figure 32

). The method list depends on the file locations specified on the Direct Control Configuration page.

Thermo Scientific Thermo PAL User Guide

53

4

Using the Direct Controls to Operate the Autosampler

Making Single Injections from the Tune Window

Figure 32. Methods page of the Inlet Direct Control dialog box

54

Thermo PAL User Guide

7. Make the following selections and entries:

• Under Vial Index, type the location of the sample vial.

• Under Trays, select the tray where the sample vial is located.

• Under Volume, type the volume that you want the autosampler to inject.

8. Click the tab for the configured LC pump and start the solvent flow from the LC pump.

Note Thermo PAL only downloads the method parameters for the autosampler. It ignores the method parameters for the LC pump and the MS detector.

9. Return to the Methods page for the Thermo Pal, and click Run.

Thermo Scientific

4

Using the Direct Controls to Operate the Autosampler

Making Single Injections from the Tune Window

Direct Control - Methods Page

The Methods page of the Inlet Direct Control dialog box has the following parameters:

Table 11. Methods page parameters

Parameter

Method

Description

Syringe

Device Status

Vial Index

1

Description

Use this list to select a method file.

This box contains a description of the selected method.

This box displays the configured syringe.

This box displays the status of the PAL. Status states

2

In this box type the vial index to be used with the method (SL.index).

In this box type the vial index to be used with the method (SL.index2).

Trays

1

2

From this list select the tray to be used with the method (SL.tray).

From this list select the tray to be used with the method (SL.tray2).

Volume

1

2

In this box type the injection volume to be used with the method (SL.volume).

In this box type the second injection volume to be used with the method (SL.volume2).

Injectors

1

2

Injections Per Vial

Run

From this list select the injector to be used with the method (SL.injector).

From this list select the second injector to be used with the method (SL.injector2).

Type the number of replicate injections to be made from each vial.

Runs the selected method.

Thermo Scientific Thermo PAL User Guide

55

4

Using the Direct Controls to Operate the Autosampler

Changing the Tray Configuration

Changing the Tray Configuration

Use the Tray Configuration dialog box to specify the tray types to be used for direct control injections while you have the Direct Control dialog box open. The autosampler uses this tray information instead of the tray information specified in the autosampler Control Terminal.

IMPORTANT The autosampler does not store the tray configuration that you specify on the Tray Configuration page of the Direct Control dialog box. When you close the dialog box, the tray configuration resets to the autosampler Control Terminal settings.

Y

To change the tray configuration

1. Open the Direct Control dialog box (see “Opening the Direct Control Dialog Box” on page 51 ).

2. Click the Tray Configuration tab.

The Tray Configuration page appears (see

Figure 33

).

Figure 33. Tray Configuration page

56

Thermo PAL User Guide

3. In the Tray list, select the tray that you want to modify.

4. In the Type list, select the tray type.

Thermo Scientific

4

Using the Direct Controls to Operate the Autosampler

Specifying the Location of the Direct Control Methods

Direct Control - Tray Configuration Page

Use the Tray Configuration page in the Direct Control dialog box to enter the Tray

Configuration information required for the autosampler to carry out autosampling.

Table 12. Tray Configuration page parameters

Parameter

Tray

Type

Tray Holder

Vials in X Direction, Vials in Y

Direction

Description

From this list, select the tray location in the three drawer (deep drawer) configuration: tray 1 &

2=drawer #1, tray 3 & 4=drawer #2, tray 5 &

6=drawer #3. Up to six drawers and twelve trays are possible with the shallow drawer configuration.

From this list, select the tray type.

Stack 1 and Stack 2 are the allowed values. Tray holders can hold one or more trays. A Stack is a tray holder that is designed to hold microplates. The autosampler firmware determines the type and number.

Determined by choice of tray type.

Specifying the Location of the Direct Control Methods

Use the Direct Control Configuration dialog box to specify the location of the methods that you can open in the Methods page of the Direct Control dialog box.

Y

To specify the method folders

1. Open the Direct Control dialog box (see “Opening the Direct Control Dialog Box” on page 51 ).

2. Click the Direct Control Configuration tab.

The Direct Control Configuration page appears (see

Figure 34

). By default, the methods that appear in the Method list on the Method page are located in the following directory:

C:\Xcalibur\Methods

Thermo Scientific Thermo PAL User Guide

57

4

Using the Direct Controls to Operate the Autosampler

Specifying the Location of the Direct Control Methods

Figure 34. Direct Control Configuration page

58

Thermo PAL User Guide

3. To add additional file locations: a. In the Path box, type the folder location, or click Browse and browse to the appropriate folder to select it.

b. Click Add.

The new folder location appears in the box below the row of buttons.

4. To delete file locations: a. Select the file location in the box below the row of buttons.

b. Click Delete.

5. To reset the location of the methods files to the default folder, click Reset.

Thermo Scientific

4

Using the Direct Controls to Operate the Autosampler

Specifying the Location of the Direct Control Methods

Direct Control - Direct Control Configuration Page

Use the Direct Control Configuration page in the Direct Control dialog box to enter the

Direct Control Configuration information required for the autosampler to carry out autosampling.

Table 13. Direct Control Configuration page parameters

Parameter Description

Wrap each direct control method run with the following macros

Sequence Entry Exit

Method Entry Exit

Use this check box to wrap methods with the sequence list entry and exit macros (SLentry and

SLexit).

Use this check box to wrap methods with the method entry and exit macros (Method Entry and Method

Exit).

Method Search Paths

Path

Browse

Add

Delete

Reset text box

Firmware Version

Use this box to specify the extra path you want added to the method search routine.

Use this button to search for a path.

Use this button to add the current path to those searched.

Use this button to delete the currently selected path.

Use this button to remove all of the user added paths.

This text box displays the directories that the autosampler searches for methods.

Specifies the firmware version downloaded from the autosampler.

Thermo Scientific Thermo PAL User Guide

59

4

Using the Direct Controls to Operate the Autosampler

Wrapping Direct Control Injections with Additional Macros

Wrapping Direct Control Injections with Additional Macros

Use the Direct Control Configuration dialog box to specify whether the autosampler is to run the SL Entry and SL Exit, the Method Entry and Method Exit, or all of these macros before and after an injection.

Y

To specify the use of the SL Entry and SL Exit macros

Select the Sequence Entry Exit check box.

Y

To specify the use of the Method Entry and Method Exit macros

Select the Method Entry Exit check box.

60

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

This chapter describes how to use the Dynamic Load and Wash (DLW) option, which includes how to install the Cycle Composer Macros or ICC Cycles, how to operate the DLW, and a step-by-step illustration of the DLW cycles.

Contents

Overview

Installing Cycle Composer Macros or ICC Cycles

Operating Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Overview

This section contains an overview of the Dynamic Load and Wash (DLW) option.

Figure 35. Dynamic Load and Wash (DLW)

Thermo Scientific Thermo PAL User Guide

61

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

The DLW option represents a new wash station concept that combines an injection cycle with wash steps. The linked combination of the two steps, which are usually separate, minimizes cycle time and carryover.

There are two characterizing features for the DLW option:

• The sample solution never contacts the syringe itself; it is held between the holding loop.

• Wash solvents are pumped from back to front into the DLW system to intensely flush all critical parts that are in contact with the sample.

The DLW option consists of two self-priming micro pumps (mounted on a dedicated bracket), and the wetted parts are Ryton PPS and Kalrez (FFPM). The pump IN ports are connected to the wash solvent bottles and the OUT ports are connected to the DLW manifold, which is part of the assembly of the dedicated DLW syringe holder. A holding loop separates the syringe and the DLW actuator to avoid sample from contacting these parts.

The syringe and holding loop are preloaded with wash solvent #1 at the start. The sample is picked up and remains separated from wash solvent #1 by an air gap. After loading the loop and injection, wash solvent #1 is pushed into the system, followed directly by wash solvent #2 to flush the critical valve paths.

The DLW syringe assembly is moved to the wash station for further cleaning steps and for preparing the Syringe and holding loop for the next cycle.

For further details, refer to

“DLW Cycle Step-by-Step” on page 73

Installing Cycle Composer Macros or ICC Cycles

You can only operate the autosampler DLW option in combination with PAL control software, such as Thermo PAL driver for Xcalibur or Cycle Editor, for ICC interpretation in another data handling system software.

For software control, three macros or three cycles are provided.

The first of three macros covers the initial and daily priming of the solvent lines and covers a complete injection cycle, a second macro is used for Standard speed with optimized washing possibilities, and the last for a Fast cycle for optimized throughput and less focus on carryover.

See

Table 14

.

For detailed descriptions of all macros (or cycles), see Table 14

, Table 15 , and

Table 16 .

62

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

Table 14. The DLW macro definitions

Macro name

Standard Injection

Accela Open

Macro description

Priming Accela Open For initial and daily routine priming of the solvent lines and DLW manifold. The Clean Time for both wash solvents is a variable for the user to define the intensity of washing.

Standard injection cycle using all possibilities of the DLW option.

The injection valve inlet port and the needle are washed with both wash solvents (inside and out). You can add an extra Stator Wash for intensive washing of the injection valve (valve toggle).

Fast Injection Accela

Open

Tuned for speed and high-throughput application. It differs from the Standard DLW macro in that some steps are left out to shorten the cycle time.

Installing the Cycle Composer Macros or ICC Cycles

The autosampler is shipped with a CD-ROM containing various cycles for the DLW option.

Macros for Xcalibur are installed by the LC Devices 2.4 installer.

Copy these macros to your Thermo PAL driver method folder or corresponding folder for application within the integrated system.

Y

To copy cycles to your Cycle Composer

1. Navigate in Windows Explorer to the Thermo PAL driver folder. The usual folder location is as follows:

C:\Thermo\Instruments\LC Devices\ThermoPAL\PAL

2. If you wish to add the DLW option macros to an existing method folder, copy the macros

(*.pma) and the methods (*.pme) files from the DLW Option folder on the CD-ROM to the method folder.

3. If the PAL system is integrated in a data system software that controls the PAL using the

Cycle Editor for PAL ICC interpretation (for example, Analyst, ChemStation, Empower,

EZChrom, MassLynx, Xcalibur), an ICC Cycle is used and not the Cycle Composer

Macro, the cycle extension is *.cyx.

Note You can convert a Cycle Composer macro to a cycle (extension *.cyx) by using the

Cycle Editor software. Conversion is available starting with Cycle Editor version 1.4.0.4.

Note The provided macros are written for standard injection valve drives, which are controlled and activated through the AUX interface.

Thermo Scientific Thermo PAL User Guide

63

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

General Considerations

You must establish the duration of the wash steps for each configuration and application.

Consider factors such as the viscosity and surface tension of the individual wash solvent composition and the backpressure of the system.

Be aware that a higher backpressure builds up if the valve bore size (standard valve bore

0.25 mm) or the installed loop internal diameter is lower. Standard loop internal diameter

(ID) for Thermo-defined loops with a volume of 5, 10, and 20 μL is 0.25 mm. The loop with

2 μL content volume has an ID of 0.125 mm.

Keep the tubing internal diameters of the tubing in line with the valve dimensions, loop ID, and flow rate. For details, see “Tips & Hints for HPLC Technique.”

Priming the Solvent Lines, Wash1 and Wash2

This macro is used at installation to prime the entire system. Set the wash time to approximately 120 seconds for each solvent.

After installation, for best results prime the system before activating the first run. For daily preparation of the system, the wash time can be much shorter: approximately. 20 seconds.

The goal is an entire liquid system free of any air bubbles.

Macro Name: Priming Accela Open AS_Rev01

Table 15. Macro Priming Accela Open AS (Sheet 1 of 2)

Macro description

The injection unit moves to the DLW Wash

Station, position Wash1.

The injection unit moves to the DLW Wash

Station, position Wash2.

The DLW system is rinsed with Wash Solvent 1 in position Waste.

Macro variable

Clean Time solvent 1

Eject Speed DLW Syringe

Clean Time solvent 1

Eject Speed DLW Syringe

64

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

Table 15. Macro Priming Accela Open AS (Sheet 2 of 2)

Macro description Macro variable

The injection valve is cleaned first with the content of DLW syringe (Wash Solvent 1), followed by Wash Solvent 2 and finally, the last wash to prepare the system for injection cycle, rinsed with Wash Solvent 1 again.

Needle Gap is a parameter from Rinse Inj

Atom. The variable in this macro is:

Needle Gap Valve Clean.

The function of this parameter is to raise the needle in the injection port very little to allow rinsing around the needle tip. Remark: The Atom Rinse Inj is new, available starting with FW 4.1.x. The DLW actuator/solenoid is activated; the Wash Solvent

(pump), the Needle Gap and the Rinse Time are selectable.

The pressure of the spring-loaded balls in the DLW Syringe Holder assembly is released by moving approx 3 mm up

(default). This leaves a gap, between the needle tip and the valve bottom, of approximately. 1 mm to enable a flush at this contact point.

A Repeat-End loop enables adding an extra rinsing step, valve toggle.

Stator Wash:

Counter 0 = disable valve toggle steps

Counter 1 = enable valve toggle steps.

If the counter is set to 1, follow the described steps below. If the counter is set to 0, the macro finishes at this point.

The injection moves to the injection valve.

The valve is switched to the Active position.

The valve is rinsed with Wash Solvent 2, followed by Wash Solvent 1

Stator Wash Time Solvent 2

Stator Wash Time Solvent 1

Remark: The loop is filled with the last rinse with Wash Solvent 1. Verify the composition of Wash Solvent1. The solvent should have a lower elution power than the solvent gradient starting conditions or sample solvent composition. This is important for partial loop filling.

The injection valve is switched back to the

Standby position.

End of macro DLW Priming.

Thermo PAL User Guide

65

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

Standard DLW Injection Cycle

Macro Name: Standard Injection Accela Open_Rev03

Table 16. Macro Standard Injection Accela Open (Sheet 1 of 3)

Macro description

The PAL system waits first for the Sync Signal

Ready before the injection cycle is started.

The injection valve is brought in a defined

Standby position.

The Rear air segment is pulled into the Holding

Loop.

The sum of Rear-, Sample List-, and

Front-Volume is aspirated into the

Holding Loop.

Macro variable

Remark:

Sync Signal setting Start

Inject to

Standby

Airgap Volume

Filling Speed

Front Volume

Rear Volume

(SL.volume)

The Front air segment is aspirated.

Airgap Volume

Filling Speed

Pullup Delay

The injection unit moves to the DLW Wash

Station, Wash1 position.

The needle is inserted (dipped) for 1 second to wash the outer needle surface. No plunger movement at this step.

The injection unit moves to the specified injection valve.

The Front- and Airgap-Volume is ejected.

The PAL system waits for the data system.

The injection valve is switched to Active position.

The time Pre Inject Delay is awaited.

The loop is filled with the sample volume as specified in the sample List.

Inject to

Front Volume

Airgap Volume

Injection Speed

Wait for DS

Inject to

Pre Inject Delay

(SL.volume)

Injection Speed

The injection valve is switched to Standby position, the loop content is injected.

Timer 1 Delay Stator Wash is started and a Start signal to the HPLC system is sent.

Post Inject Delay

Timer 1

66

Thermo PAL User Guide Thermo Scientific

Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

Table 16. Macro Standard Injection Accela Open (Sheet 2 of 3)

Macro description Macro variable

The plunger of the DLW Syringe is pushed down to dispense the Rear Sample and Air Segment to

Waste. The Holding Loop is still filled with

Wash Solvent 1.

(Syr. Eject Speed)

The DLW Actuator/Solenoid is activated to deliver Wash Solvent 2 into the Holding Loop to clean the injection valve from Port 1 to Port 2.

Wash2

Inject to

Needle Gap Valve Clean

Valve Clean Time Solvent 2

For this step the needle tip is lifted, releasing the sealing pressure to enable rinsing around the tip sealing point.

Remark: For a detailed explanation of the Needle Gap Valve Clean, see DLW

Priming.

The injection unit is moved to the DLW Wash

Station, Wash2 position.

Wash2

(Syr.Eject Speed)

The needle is rinsed inside and out with Wash

Solvent 2.

The injection unit is moved back to the injection valve. The Inlet Port and engraving to waste Port are flushed with Wash Solvent 1 to prepare the valve for the next injection.

The injection unit is moved back to the DLW

Wash Station, Wash1 position to flush the syringe needle inside and out with Wash

Solvent 1.

Post Clean Time Solvent2

Wash1

Inject to

Needle Gap Valve Clean

Valve Clean Time Solvent 1

Wash1

Post Clean Time Solvent 1

This is a preparation step for next injection, and especially important for biofluid samples.

Cycle end for LC-Inj DLW Standard macro.

An optional cleaning step is attached to the DLW

Standard injection cycle: Stator Wash or valve toggle.

Stator Wash

Stator Wash count: 1 = Cleaning step active

Stator Wash count: 0 = Cleaning step disabled

A Repeat-End loop can be activated with the

Count.

If Stator Wash is activated, the following steps will be executed.

Thermo PAL User Guide

67

Table 16. Macro Standard Injection Accela Open (Sheet 3 of 3)

Macro description

The injection unit is moved to the injection valve. From the last step above, the Holding

Loop is filled with Wash Solvent 1.

Macro variable

Inject to

Delay Stator Wash

(Active)

Timer 1 is awaited to switch the valve (Toggle) into Active position (fill loop).

The DLW Actuator/Solenoid is activated to deliver Wash Solvent 2 to the Holding Loop and into the valve system.

Inject to

Wash2

Stator Wash Time Solvent 2

The first solvent flush arriving at the valve is

Wash Solvent 1 parked in the Holding Loop at the beginning, followed by Wash Solvent 2.

Wash Solvent is changed to Wash Solvent 1.

The injection valve is switched back to the

Standby position.

Inject to

Wash1

Stator Wash Time Solvent 1

Inject to

(Standby)

Fast DLW Injection Cycle

The Fast injection cycle differs from the Standard cycle as follows:

• The needle is not dipped in the Wash station Wash1 after sample pickup and before it moves to the injection valve.

• The wash steps after injection are reduced to Valve Clean with Wash Solvent 1 and Wash

Solvent 2. The DLW needle is flushed in the DLW Wash Station with Wash Solvent 1 only.

• Stator Wash (valve toggle) is not available.

Macro Name: Fast Injection Accela Open_Rev03

Table 17. Macro Fast Injection Accela Open (Sheet 1 of 3)

Macro description

The PAL system waits first for the Sync Signal

Ready before the injection cycle is started.

The injection valve is brought to a defined position: Standby.

The Rear air segment is pulled into the Holding

Loop.

Macro variable

Remark:

Sync Signal setting Start

Inject to

Standby

Airgap Volume

Filling Speed

Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

Installing Cycle Composer Macros or ICC Cycles

Table 17. Macro Fast Injection Accela Open (Sheet 2 of 3)

Macro description

The sum of Rear-, Sample List-, and

Front-Volume is aspirated into the

Holding Loop.

The Front air segment is aspirated.

The injection unit moves to the specified injection valve.

The Front- and Airgap-Volume is ejected to

Waste.

The PAL system waits for the data system

The injection valve is switched to Active position.

The Pre Inject Delay time is awaited.

Macro variable

Front Volume

Rear Volume

(SL.volume)

Airgap Volume

Filling Speed

Pullup Delay

Inject to

Front Volume

Airgap Volume

Injection Speed

Wait for DS

Inject to

Pre Injection Delay

The loop is filled with the sample volume as specified in the sample list.

(SL.volume)

The injection valve is switched to Standby position, the loop content is injected.

The plunger of the DLW Syringe is pushed down to dispense the Rear Sample and Air Segment to

Waste. The Holding Loop is still filled with

Wash Solvent 1.

Injection Speed

Post Inject Delay

Injection Speed

The DLW Actuator/Solenoid is activated to deliver Wash Solvent 2 into the Holding Loop to clean the injection valve from Port 1 to Port 2.

Inject to

Wash2

Needle Gap Valve Clean

Valve Clean Time Solvent 2

For this step the needle tip is lifted, releasing the sealing pressure to enable rinsing around the tip sealing point.

Remark: For complete details on the

Needle Gap Valve Clean, see DLW

Priming.

Wash Solvent 1 follows to prepare the valve for the next injection.

Wash1

Inject to

Needle Gap Valve Clean

Valve Clean Time Solvent 1

Thermo PAL User Guide

69

5

Using Dynamic Load and Wash (DLW)

Operating Dynamic Load and Wash (DLW)

Table 17. Macro Fast Injection Accela Open (Sheet 3 of 3)

Macro description Macro variable

The injection unit is moved back to the DLW

Wash station, Wash1 position to flush the syringe needle inside and out with Wash Solvent 1.

Wash1

Post Clean Time Solvent 1

This is a preparation step for the next injection, and is especially important for biofluid samples.

Cycle end for LC-Inj DLW Fast macro.

Operating Dynamic Load and Wash (DLW)

This section describes how to operate the Dynamic Load and Wash (DLW) option.

Priming the Solvent Lines

Location of Solvent and Waste Bottles

DLW Pumps

Priming the Solvent Lines

Note For trouble-free DLW operation, make sure the two solvent lines are free of air bubbles at all times. If the solvent lines are being connected for the first time or during a solvent change, you must prime the solvent lines properly until air bubbles are no longer visible. Solvent degassing is recommended.

In order to make the initial and daily priming efficient and controllable, the Open

Autosampler comes with a Cycle Composer macro, or ICC cycle.

Y

To prime the solvent lines

1. Load the macros and methods into the folder.

2. Start the corresponding macro for initial or daily priming.

3. Check the solvent lines and prime until air bubbles are no longer visible.

4. Press F4 forHome.

Location of Solvent and Waste Bottles

The DLW option contains self-priming membrane pumps. The solvent bottles can be placed either in the fast wash station holder or on the lab bench.

70

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

Operating Dynamic Load and Wash (DLW)

You must place the Waste bottle must be placed > 30 cm ( in.) below the injection valve.

Make sure that the waste liquid can flow into the waste bottle without restriction. Place the waste tubing above the level of the liquid. Ideally, the tube is fixed at the neck of the waste bottle.

Note Use good lab practice to avoid contaminating the wash solvents and the wash bottles. Avoid biological growth in pure water by either replacing it regularly or adding a small percentage of organic solvents, such as methanol or acetonitrile. Certain buffer solutions can decompose at room temperature when exposed to light. Filtering the wash solvents before filling the bottle, especially if salt buffers are used, is mandatory to avoid any clogging of the solvent paths.

DLW Pumps

From the control point of view, the DLW pumps respond in the same manner as the fast wash station. Power-out signals activate the pumps. Because the electric current setting for the

DLW is different, the corresponding PAL Firmware Objects must be loaded for the DLW wash station type.

The wetted parts in the pump are made from the following materials:

• Membrane: Kalrez (FFPM)

• Body, valves: Ryton PPS

The pumps are self priming with a suction lift of up to 3 m water column.

DLW Actuator/Solenoid

The DLW Actuator/Solenoid has the function of separating and completely shutting-off the lines in the direction of the syringe (sample loading) or the wash solvent lines.

After opening the DLW Actuator/Solenoid for the wash solvent lines, you can pump the desired wash solvent into the system by activating the corresponding DLW pump.

Figure 67 illustrates this functionality.

The wetted parts in the DLW Actuator Solenoid are made from the following materials:

• Solenoid body: PEEK

• Seal material: FFKM (Simriz)

Note PEEK exhibits excellent chemical resistance to most of the chemicals used.

However, the following solvents are not recommended for use with PEEK: DMSO, THF, methylene chloride (dichloromethane), nitric acid, or sulfuric acid. For more details refer to the compatibility tables provided by the manufacturer of PEEK material or components.

Thermo Scientific Thermo PAL User Guide

71

5

Using Dynamic Load and Wash (DLW)

Operating Dynamic Load and Wash (DLW)

Note Current applied from the actuator control PCB to the actuator/solenoid activates a green LED. This activation does not indicate that the solenoid opens or closes.

Figure 36. DLW Manifold and Actuator/Solenoid

Figure 37. Inserting DLW Flow Diverter

72

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

DLW Cycle Step-by-Step

This section provides illustrations to demonstrate a step-by-step DLW cycle.

Cycle for Standard Injection

Additional Valve Toggle Step to DLW Standard Cycle

Cycle for Fast Injection

Cycle for Standard Injection

Figure 38 to

Figure 51 illustrates a step-by-step cycle for the standard injection.

Figure 38. Standard: Cycle start

Thermo Scientific Thermo PAL User Guide

73

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 39. Standard: Step 1 – A spirate rear air segment

74

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 40. Standard: Step 2 – Get sample, aspirate rear, inject, and front volume

Thermo Scientific Thermo PAL User Guide

75

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 41. Standard: Steps 3 - 4 – A spirate front air segment

76

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 42. Standard: Steps 5 - 6 – Passive needle clean outside (dip) in wash position 1

Thermo Scientific Thermo PAL User Guide

77

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 43. Standard: Steps 7 - 8 – Dispense front air segment and front sample volume to waste

78

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 44. Standard: Steps 9 - 10 – Valve is switched to LOAD position, loop is filled with “Inject

Volume”

Thermo Scientific Thermo PAL User Guide

79

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 45. Standard: Step 11– Valve is switched to INJECT position, start chromatographic process

80

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 46. Standard: Step 12 – Rear sample volume and air segment are dispensed to waste

Thermo Scientific Thermo PAL User Guide

81

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 47. Standard: Steps 13 - 14 – Valve clean with Wash Solvent 2

82

Thermo PAL User Guide Thermo Scientific

Figure 48. Standard: Steps 15 - 16 – Active syringe needle wash with Wash Solvent 2

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Thermo Scientific Thermo PAL User Guide

83

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 49. Standard: Steps 17 - 18 – Valve clean with Wash Solvent 1

84

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 50. Standard: Steps 19 - 20 – Active syringe needle wash with Wash Solvent 1

Thermo Scientific Thermo PAL User Guide

85

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 51. Standard: Cycle end

Additional Valve Toggle Step to DLW Standard Cycle

This section contains information about additional steps that are necessary for a DLW

Standard Cycle.

86

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Considerations for Additional Stator Wash Cleaning Step

The DLW Standard Cycle has the built-in option for the user to toggle the injection valve at the end of the chromatographic run before equilibration of the column to the start conditions.

If the method variable “Stator Wash” is set to “1”, the extra cleaning process for the valve, with

“Valve Toggle”, is part of the standard cycle.

If the method variable is deactivated (setting “0”), the DLW Standard cycle ends as shown in

Figure 51 .

The macro (cycle) is written so that the optional valve toggle steps can be executed before re-equilibration of the column. You must synchronize the time to switch the valve with the chromatographic method using the method variable Delay Stator Wash. The two wash solvents are timed by the method variables Stator Wash Time Solvent 1 and Stator Wash Time

Solvent 2. After these wash times have elapsed, the valve is switched back to the start position.

Figure 52 illustrates the recommended retention time for Stator Wash or Valve Toggle times.

Figure 52. Timing for Stator Wash Step

Thermo Scientific

From the chromatographic point of view, the optional cleaning step is important to understand. Assuming that the valve stator between ports 1 and 6 (example standard

Cheminert valve) is contaminated and cannot be cleaned during the injection process, the valve toggle brings the engraving back between the two ports. Flushing the valve with both wash solvents eliminates remaining sample material located between stator ports 1 and 6.

What points must you consider when you use the Stator Wash or Valve Toggle option?

Observe the rules if biofluid samples are injected. First sample contact should always be with an aqueous solution to avoid protein precipitation. After washing with organic solvent (higher elution power) the system must be flushed again with wash solvent 1.

The first toggle near the end of the chromatographic cycle provides the advantage that the sample loop is already flushed out first with the mobile phase with a solvent of high elution power (assuming gradient application).

Thermo PAL User Guide

87

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

The second valve toggle time follows immediately after finishing the second solvent flush. A second switching time cannot be programmed. The waiting time for the second valve toggle should be long enough so that the entire system is flushed out by both wash solvents.

Consider the entire delay volume to determine the second valve switch. The DLW internal volumes are:

Manifold, 90 μL

Holding Loop,108 μL

Syringe Needle Gauge 22, 6.7 μL

Installed Injection Loop

Total delay volume: 205 μL + Loop content volume

Do the second valve toggle (back to starting condition) before the system equilibration time has started. The Loop content is ideally a solvent of a low elution power when switched back.

If isocratic chromatography is applied, the remaining contaminants might be washed into the system and can build up higher background noise for the column, the detector, or both over a longer period of time.

88

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Additional Cleaning Step Stator Wash or Valve Toggle Step-by-Step

Figure 53 to

Figure 58 illustrate additional cleaning steps for “Stator Wash”.

Stator Wash: End of Standard Injection Cycle

Figure 53. Start for additional cleaning step “Valve Toggle”

Thermo Scientific Thermo PAL User Guide

89

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 54. Stator Wash: Step 1 - 2 – Valve switched to Load Position (toggle), valve clean with

Wash Solvent 1

90

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 55. Stator Wash: Step 3 – Valve clean with Wash Solvent 2

Thermo Scientific Thermo PAL User Guide

91

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 56. Stator Wash: Step 4 – Wash Solvent 2 dispensed by Wash Solvent 1

92

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 57. Stator Wash: Step 5 – Second valve clean with Wash Solvent 1

Thermo Scientific Thermo PAL User Guide

93

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 58. Stator Wash: Step 6 – Valve switched back to Inject Position (toggle)

94

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Cycle for Fast Injection

Figure 59 to

Figure 70 illustrate a step-by-step cycle for the Fast Injection.

Figure 59. Fast: Cycle start

Thermo Scientific Thermo PAL User Guide

95

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 60. Fast: Step 1 – Aspirate rear air segment

96

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 61. Fast: Step 2 – Get sample, aspirate rear, inject, and front volume

Thermo Scientific Thermo PAL User Guide

97

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 62. Fast: Step 3 - 4 – Aspirate front air segment

98

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 63. Fast: Steps 5 - 6 – Dispense front air segment and front sample volume to waste

Thermo Scientific Thermo PAL User Guide

99

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 64. Fast: Steps 7 - 8 – Valve is switched to LOAD position, loop is filled with “Inject

Volume”

100

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 65. Fast: Step 9 – Valve is switched to INJECT position, start chromatographic process

Thermo Scientific Thermo PAL User Guide

101

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 66. Fast: Step 10 – Rear sample volume and air segment are dispensed to waste

102

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 67. Fast: Steps 11 - 12 – Valve clean with Wash Solvent 2

Thermo Scientific Thermo PAL User Guide

103

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 68. Fast: Steps 13 - 14 – Valve clean with Wash Solvent 1

104

Thermo PAL User Guide Thermo Scientific

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 69. Fast: Step 15 – Active syringe needle wash with Wash Solvent 1

Thermo Scientific Thermo PAL User Guide

105

5

Using Dynamic Load and Wash (DLW)

DLW Cycle Step-by-Step

Figure 70. Fast: Cycle end

106

Thermo PAL User Guide Thermo Scientific

I

Index

A

autosampler control terminal, using

20

C

cables

DB9 to DB9 serial cable

14

external contact trigger cable

10

PAL interface cable

10

Thermo Dual Configuration cable

8

Thermo Single Configuration cable

4

compliance

FCC

iii

regulatory

iii

computer Com port

17

contact closure connections for a Thermo Scientific LC pump

5

for a Thermo Scientific MS detector

5

for an Agilent pump

10

for two Thermo Scientific pumps

8

control terminal attached to the autosampler

20

cycle composer macros

62

cycle composer macros or ICC cycles, installing

62

Cycle Editor

62

D

delay time

28

Direct Control Configuration page

57

Direct Control dialog box, opening

51

DLW characterizing features

62

cycle

73

cycle for fast injection

95

cycle for standard injection

73

fast injection cycle

68

macro definitions

63

operating

70

overview

61

priming solvent lines

64

standard injection cycle

66

Thermo Scientific

DLW Actuator/Solenoid

71

DLW Pumps

71

E

electromagnetic compatibility

iii

external contact board for Agilent pump

10

external contact closure cable connections

5

F

FCC compliance

iii

file types instrument methods (*.meth)

29

macro (*.pma)

45

templates (*.pme)

35

I

ICC cycles

62

Injected screen on hand-held controller

23

Inlet Direct Control, opening

52

Instrument Configuration window

15

Instrument Setup window, opening

24

J

Job Queue screen

21

L

level surface, importance of

2

lithium battery

1

look ahead injections

17

M

Macro Editor enabling

17

opening

43

macros creating

43

Thermo PAL User Guide 107

Index: N importing

18

list of standard

42

Menu screen

21

method parameters, specifying

24

N

numeric variables

49

O

object variables

49

ordering information

2

output signal to LC pump

3

P

part numbers

2

priming solvent lines

64

pulse time of the out signals, setting

23

pumps, self-priming

62

R

Recommended Injection Volume box

28

regulatory compliance

iii

S

safety information

1

safety standards

iii

self-priming micro pumps

62

solvent lines, priming

64

solvent lnes, priming

70

syringe size, specifying

28

T

Template Editor enabling

17

opening

33

templates editing

33

Single Step LC Injection

26

testing

37

Thermo PAL driver for Xcalibur

62

Tray Configuration page

56

tray type, selecting with the PAL Control Terminal

21

Trays screen

21

Tune window, making single injections from

53

V

variables, defining

48

108

Thermo PAL User Guide

W

Waiting for contact closure status for LC pump

22

Thermo Scientific
