Advanced field calibrator and communicator

Advanced field calibrator and communicator

Advanced field calibrator and communicator

Beamex

®

MC6

More than a calibrator.

1

2

The impossible made possible: combining advanced functionality with ease-of-use.

Beamex

®

MC6 is an advanced, high-accuracy field calibrator and communicator. It offers calibration capabilities for pressure, temperature and various electrical signals. The

MC6 also contains a full fieldbus communicator for HART,

FOUNDATION Fieldbus and Profibus PA instruments.

The usability and ease-of-use are among the main features of the MC6. It has a large 5.7” color touch-screen with a multilingual user interface. The robust IP65-rated dust- and water-proof casing, ergonomic design and light weight make it an ideal measurement device for field use in various industries, such as the pharmaceutical, energy, oil and gas, food and beverage, service as well as the petrochemical and chemical industries.

The MC6 is one device with five different operational modes, which means that it is fast and easy to use, and you can carry less equipment in the field. The operation modes are: Meter,

Calibrator, Documenting Calibrator, Data Logger and Fieldbus

Communicator. In addition, the MC6 communicates with

Beamex

®

CMX Calibration Software, enabling fully automated and paperless calibration and documentation.

In conclusion, the MC6 is more than a calibrator.

MC6 Main Features

Accuracy

High-accuracy, advanced field calibrator and communicator.

Usability

Combines advanced functionality with ease-of-use.

Versatility

Versatile functionality beyond traditional calibration applications.

Communicator

Full multi-bus communicator for HART,

FOUNDATION Fieldbus and Profibus PA instruments.

Integration

Automates calibration procedures for paperless calibration management.

3

4

Accuracy

Accuracy

High-accuracy, advanced field calibrator and communicator

Unmatched accuracy

Today’s process instrumentation is becoming more and more accurate. Therefore, calibration equipment must also have improved accuracy. When Beamex develops new measurement equipment, it makes no compromises in terms of accuracy – it must be best-in-class. The MC6 makes no exceptions. Accuracy is one of the main features of the MC6.

It is among the most accurate, advanced field calibrators available on the market.

Accuracy that tolerates demanding conditions

Field calibrators and communicators must tolerate demanding environmental conditions, such as cold or warm weather, moisture and dust. The MC6 is designed to handle demanding and variable environmental conditions. All of the pressure, electrical and temperature ranges are temperature compensated, and therefore the accuracy of the calibrator is not jeopardized when used in given types of extreme environments.

Accredited calibration certificate as standard

Every MC6 calibrator is calibrated in the Beamex accredited laboratory before delivery. As proof of how accurate it is, each MC6 is delivered with a traceable, accredited calibration certificate as standard. The certificate includes calibration and uncertainty data from the calibration laboratory. The calibration laboratory’s Scope of Accreditation can be found on Beamex’s website (www.beamex.com).

Summary of accuracy figures

The MC6 has specifications for short-term accuracy and for

1-year total uncertainty.

Brief summary of the Accuracy figures:

• Pressure accuracy starting from

±(0.005 % FS + 0.0125% of reading).

• Temperature - RTD temperature measurement accuracy starting from ±0.011 °C.

• Electric - Current measurement accuracy starting from

±(0.75 µA + 0.0075% of reading).

5

6

Usability

Usability

Designed for field use

User-friendly interface

The MC6 has a large 5.7” color touch-screen with high resolution and an effective adjustable backlight. The buttons on the touch-screen have been designed large enough to use with bare fingers, so there is no need for a stylus – it can even be used with gloved hands! In addition, the MC6 has a membrane keypad. The multi-lingual user interface has been divided into different operational modes. A soft number keypad and alphabetical QWERTY text keypad will appear whenever necessary for easy number/text entries.

Automated procedures

Whenever a certain measurement or generation is selected, the user interface shows where to make the connections, which allows you to use a device with several connections. The MC6 is also a documenting calibrator and it communicates with the Beamex

®

CMX Calibration Software enabling fully automated and paperless calibration data management. This makes the calibration and documenting of calibration results automatic and much easier. Since the

MC6 is a measurement device that replaces several individual devices, there’s no need to carry several units in the field.

What’s more, the MC6 is also a fieldbus communicator, and therefore there is no need to carry an additional communicator.

Robust, lightweight and ergonomic design

The MC6 has the latest, rechargeable lithium-ion polymer batteries, which are durable and charge up quickly. The user interface keeps you up to date on the remaining operation time in hours and minutes, making it easy to follow how long the battery will last. Once the unit is switched on, it is ready to use in just a few seconds. The case is ergonomic and water-/ dust-proof (IP65). There are two types of cases available: a slim case when internal pressure modules are not needed and an extended version, which provides room for the internal pressure modules. The wrist strap makes it easy to hold the device in your hand, while the neck strap makes it easy to carry and use the device.

User-interface modes

The MC6 is a unique measurement device, as it combines advanced functionality with ease-of-use. How is it possible to combine these two features? The solution is that the MC6 contains various operational modes all in one device, each of which is optimized for different uses. The operational modes are Meter, Calibrator, Documenting Calibrator, Communicator and Data Logger.

7

8

User-interface modes

Meter

The Meter mode is designed for simple and easy measurement of signals. Oftentimes, you may need to measure something quickly and easily. Often a simple multi-meter is used for this purpose, as it is easy to use. Some multifunctional calibrators may be too slow and difficult to use, so it is easier to just choose the simpler meter.

The Meter mode in MC6 is optimized for this type of simple and easy metering.

Data Logger

The Data Logger is designed for logging various measurement results. Often in industry, there is a need to measure signals for shorter or longer periods and to save the results in a memory for later analysis. This may be related to trouble-shooting, surveillance or calibration. The Data Logger mode in MC6 is optimized for this type of use.

Calibrator

The Calibrator mode is designed for calibrating various process instruments. Oftentimes, you need to check and calibrate a certain process instrument/ transmitter. Transmitters typically have an input and an output.

So you either need to have two devices, or a device capable of doing two things simultaneously.

The Calibrator mode in MC6 is optimized for this type of use.

Communicator

The Communicator mode is designed to communicate with Fieldbus instruments.

In today’s process plants, smart instrumentation is being used to an increasing degree.

Therefore, engineers need to use communicators or configuration software. Most of this instrumentation is HART,

FOUNDATION Fieldbus or

Profibus PA. The Communicator mode in MC6 is optimized for communicator use.

Documenting calibrator

The Documenting Calibrator mode is designed for the process instrument calibration and documenting of the calibration results. In today’s process plant, calibrations often have to be documented. Without a Documenting Calibrator, documentation must be done manually, which takes a lot of precious time and is prone to error.

The Documenting Calibrator mode in MC6 is optimized for use as a documenting process calibrator.

Settings

The Settings mode allows you to edit the calibrator’s various settings.

9

10

Versatility

Versatile functionality beyond traditional calibration applications

The MC6 is an advanced field calibrator and communicator, which replaces several measurement devices. It offers extremely versatile and multifunctional calibration capability for pressure, temperature and various electrical signals.

It also includes a full Fieldbus communicator for HART,

FOUNDATION Fieldbus and Profibus PA instruments.

MC6 measurement, generation and simulation functions

• Pressure measurement

• Voltage measurement and generation

• Current measurement and generation

• Resistance measurement and simulation

• RTD measurement and simulation

• TC measurement and simulation

• Frequency measurement and generation

• Pulse counting and generation

• Switch state sensing

• Built-in 24 VDC Loop Supply

• Field communicator for HART, FOUNDATION Fieldbus and

Profibus PA

MC6 as a pressure calibrator

The MC6 can come with as many as 4 internal pressure modules (3 standard modules + a barometric module). There is also a connection for external pressure modules. All of the internal and external pressure modules up to 6 bar (90 psi) come with an internal returning relief valve that protects the module from accidental overpressure. Most of the pressure modules have a compound range, and therefore they can measure from full vacuum up to the module range. When a unit is equipped with the barometric module, all other modules can be used for measuring absolute pressure. This means that there is no need to purchase separate absolute and gauge pressure modules. This makes it more practical to use and saves money. The MC6 can communicate with Beamex

®

Automatic Pressure Controller POC6 enabling fully automatic calibration of pressure instruments.

MC6 as a temperature calibrator

The MC6 has two RTD channels, and therefore it is able to measure two RTD sensors simultaneously with great accuracy. You can program sensor correction coefficients into the MC6 if you need to compensate sensor error. It also has two thermocouple channels, so it can accurately measure two thermocouples simultaneously, and it has automatic internal compensation of the reference (cold) junction. Using external or manual reference junction compensation is also possible.

One thermocouple channel has a unique and very versatile connection block supporting the use of plain thermocouple wires, or any type of thermocouple connector. The MC6 supports a large number RTD and thermocouple sensors as standard, and there are several additional sensors available as optional sensors. The MC6 can communicate with temperature controllers (Dry Blocks) enabling fully automatic calibration of temperature sensors or temperature instruments with temperature sensor.

11

12

Field Communicator

Field Communicator

Full multi-bus field communicator for

HART, FOUNDATION Fieldbus and Profibus

PA instruments

Smart instrumentation is becoming more and more common in today’s process plants. The most widely used smart instrument protocols are HART, FOUNDATION Fieldbus and

Profibus PA. Therefore, in addition to a calibrator, an engineer often needs to use a field communicator. The MC6 combines these two; it’s a calibrator and a communicator.

Communicator

The Communicator mode is a full multi-bus communicator for

HART, FOUNDATION Fieldbus and Profibus PA instruments.

Therefore, it eliminates the need to carry a separate communicator with you. All of the communicator electronics for all protocols are built into the MC6, including internal loop power supply with various required impedances for different buses, which means there is no need to use any external loop supply or resistors. The connections are extremely easy to make - just connect two leads from the MC6 to the instrument.

Multi-bus Communicator

The MC6 communicator can be used with all types of Fieldbus instruments, not only pressure and temperature transmitters.

All 3 protocols can be simultaneously installed into an MC6, and therefore the very same device can be used as a HART,

FOUNDATION Fieldbus and Profibus PA communicator. With the MC6, you can access all parameters in all blocks of a

Fieldbus instrument. Its memory stores device descriptions for the Fieldbus instruments. When new instruments are introduced on the market, new device description files will be made available and can be easily downloaded into the memory. For example, the MC6 DD library supports approximately 1,000 different Device Descriptions for the

HART protocol.

Communicator and Calibrator

The MC6 is not only a communicator; it is also a multifunctional calibrator, which allows you to make traceable metrological calibration and trimming for Fieldbus instruments.

What’s more, the Fieldbus parameters can be configured, the variables logged into the Data Logger mode or measured in the Calibrator mode and calibrated and documented in the

Documenting Calibrator mode.

13

14

Seamless Integration.

Automate calibration procedures for paperless calibration management

According to some studies, instrument technicians use up to

50 % of their time doing paperwork, i.e. preparing calibration instructions, making notes of calibration results in the field and documenting and archiving calibration results.

All of the above tasks are extremely important and necessary, but doing them in the “Beamex way”, with seamlessly communicating documenting calibrators and calibration software, remarkably improves the quality, efficiency and accuracy of the entire calibration process and saves costs compared to traditional pen and paper systems or

“do-it-yourself” computer databases. The Beamex

®

MC6 communicates with Beamex

®

CMX Calibration Software enabling fully automated and paperless calibration and documentation! Beamex calibrators, workstations, calibration software and professional services form the most integrated, automated calibration system available.

Benefits of an automated calibration system with seamlessly communicating documenting calibrators and calibration software:

• Preparing calibration schedules and documentation is fast and efficient.

• No more typing errors related to calibration documentation.

• Planning optimal interval for performing calibrations is easy.

• Quality and accuracy of calibration records are dramatically improved.

• Calibration data is easily accessible for audits.

• System integration with maintenance management systems is possible.

KUVA

BEAMEX

®

INTEGRATED CALIBRATION

SOLUTION, STEP-BY-STEP

The Beamex

®

CMX Calibration Software indicates what needs to be calibrated and when.

Download calibration procedures and instructions from the software to the MC6.

• Easy, fast and efficient

• No need to search archived paper files

Perform instrument calibration and data collection with the MC6.

• Fast procedure

• No pen, paper or notepads needed

Upload calibration results to the software.

• The MC6 replaces many individual measurement devices and calibrators

• Automated calibration is fast

Create, store and manage calibration information safely and efficiently with the software.

• Automatically download calibration results back to software

• Data transfer is fast and efficient, writing mistakes are eliminated

Integration to a maintenance management system.

• All calibration data is stored and managed in the CMX database

• Calibration certificates, reports and labels in electronic format, on paper or both

• All documentation in the CMX is in auditable and traceable

(e.g. ISO17025, cGMP, 21 CFR Part 11)

• Plant hierarchy and work orders are stored in MMS

(e.g. SAP ® , Maximo ® ) and from there transferred to the

CMX, which stores all calibration procedures, standards and results

• When calibration work has been performed, the CMX sends acknowledgement of the calibration back to MMS.

15

16

Additional Features

Feature

Scaling

Specification

A versatile programmable scaling function allows user to scale any measurement or generation unit into any other unit. Supports also rooting transfer function for flow applications. Also, custom units and custom transfer functions are supported.

Alarm

Leak test

Damping

Resolution

Step

Ramp

Quick access

Spinner

Additional info

An alarm that can be programmed with high or low limit, as well as slow rate or fast rate limit.

A dedicated function that can be used to analyse a change in any measurement. Can be used for pressure leak testing as well as any stability testing.

A programmable damping allows user to filter any measurement.

Possibility to change the resolution of any measurement by reducing or adding decimals.

A programmable step function for any generation or simulation.

A programmable ramp function for any generation or simulation.

Possibility to set four (4) quick access buttons in generation to easily generate the programmed values.

Possibility to easily step any digit in the generation value up or down.

Allow user to see additional information in the screen such as: Min, Max, Rate, Average, Internal temperature, RTD sensor’s resistance, thermocouple’s thermovoltage, range min/max, etc.

Function info

Connection diagrams

Displays more information on the selected function.

Displays a picture showing where to connect the test leads with the selected function.

Calibration references

Allows you to document the additional references that were used during the calibration and passes on the information to Beamex CMX calibration software.

Users

Custom pressure unit

Custom RTD sensor

Custom point sets

Possibility to create a list of persons in the documenting calibrator in order to easily select who did the calibration.

Large number of custom pressure units can be created.

Unlimited number of custom RTD sensors can be created using the Callendar van Dusen coefficients.

Unlimited number of custom point sets can be created in calibration of an instrument, or step generation.

Custom transfer function Unlimited number of custom transfer functions can be created in calibration of an instrument or in scaling function.

Note; All functions are not available in all user interface modes.

Specifications

General Specifications

Feature

Display

Touch Panel

Keyboard

Backlight

Weight

Dimensions

Battery type

Charging time

Charger supply

Battery operation

Operating temperature

Operating temperature while charging batteries

Storage temperature

Specifications valid

Humidity

Warmup time

Max. input voltage

Display update rate

Safety

EMC

Ingress protection

Drop

Vibration

Max altitude

Warranty

Value

5.7” Diagonal 640 x 480 TFT LCD Module

5-wire resistive touch screen

Membrane keyboard

LED backlight, adjustable brightness

Extended case: 1.5 ... 2.0 kg (3.3 ... 4.4 lb)

Flat case: 1.5 kg (3.3 lb)

Extended case: 200 mm × 230 mm × 70 mm (D × W × H) ( 7.87 in × 9.06 in × 2.76 in)

Flat case: 200 mm × 230 mm × 57 mm (D × W × H) ( 7.87 in × 9.06 in × 2.24 in)

Rechargeable lithium-ion polymer, 4200 mAh, 11.1V

Approximately 4 hours

100 ... 240 VAC, 50-60 Hz

10 ... 16 hours

-10 ... 45 °C (14 ... 113 °F)

0 ... 30 °C (32 ... 86 °F)

-20 ... 60 °C (-4 ... 113 °F)

-10 ... 45 °C, unless other mentioned

0 ... 80% R.H. non condensing

Specifications valid after a 5 minute warmup period.

30 V AC, 60 V DC

3 readings/second

Directive 2006/95/EC, EN 61010-1:2001

Directive 2004/108/EC, EN 61326-1:2006

IP65

IEC 60068-2-32. 1 meter (3.28 ft)

IEC 60068-2-64. Random, 2 g, 5 ... 500Hz.

3000 m (9842 ft)

Warranty 3 Years. 1 year for battery pack. Warranty extension programs are also available.

Measurement, generation and simulation functions

• Pressure measurement

(internal/external pressure modules)

• Voltage measurement (±1 V and -1 ... 60 VDC)

• Current measurement (±100 mA)

(internal or external supply)

• Frequency measurement (0 ... 50 kHz)

• Pulse counting (0 ... 10 Mpulse)

• Switch state sensing (dry/wet switch)

• Built-in 24 VDC Loop Supply

(low impedance, HART impedance or

FF/PA impedance)

• Voltage generation ( ±1 V and -3 ... 24 VDC)

• Current generation (0 ... 55 mA)

(active/passive, i.e. Internal or external supply)

• Resistance measurement, two simultaneous channels (0 ... 4 kΩ)

• Resistance simulation (0 ... 4 kΩ)

• RTD measurement, two simultaneous channels

• RTD simulation

• TC measurement, two simultaneous channels

(universal connector/mini-plug)

• TC simulation

• Frequency generation (0 ... 50 kHz)

• Pulse queue generation (0 ... 10 Mpulse)

• HART Communicator

• FOUNDATION Fieldbus Communicator

• Profibus PA Communicator

(Some of the above functions are optional)

17

Pressure measurement

Internal

Modules

P B

External

Modules

EXT B

Unit Range

(3

Resolution Accuracy

(1

(±) 1 Year Uncertainty

(2

-

-

-

P10mD

P100m

P400mC

P1C

P2C

P6C

P20C

P60

P100

P160

EXT10mD

EXT100m

EXT400mC

EXT1C

EXT2C

EXT6C

EXT20C

EXT60

EXT100

EXT160

EXT250

EXT600

EXT1000

MPa bar psi

MPa bar psi

MPa bar psi

MPa bar psi kPa bar psi kPa bar psi

MPa bar psi kPa bar psi kPa bar psi kPa mbar iwc kPa bar psi kPa a mbar a psi a kPa diff mbar diff iwc diff kPa mbar iwc

70 to 120

700 to 1200

10.15 to 17.4

± 1

± 10

± 4

0 to 10

0 to 100

0 to 40

± 40

± 400

± 160

± 100

± 1

-14.5 to 15

-100 to 200

-1 to 2

-14.5 to 30

-100 to 600

-1 to 6

-14.5 to 90

-100 to 2000

-1 to 20

-14.5 to 300

0 to 6000

0 to 60

0 to 900

0 to 10

0 to 100

0 to 1500

0 to 16

0 to 160

0 to 2400

0 to 25

0 to 250

0 to 3700

0 to 60

0 to 600

0 to 9000

0 to 100

0 to 1000

0 to 15000

0.01

0.1

0.001

0.0001

0.001

0.0001

0.0001

0.001

0.001

0.001

0.01

0.001

0.001

0.00001

0.0001

0.001

0.00001

0.0001

0.01

0.0001

0.001

0.01

0.0001

0.001

0.1

0.001

0.01

0.0001

0.001

0.01

0.0001

0.001

0.01

0.001

0.01

0.1

0.001

0.01

0.1

0.001

0.01

0.1

0.3 mbar

0.05 % Span

0.015 % FS + 0.0125 % RDG

0.01 % FS + 0.0125 % RDG

0.007 % FS + 0.0125 % RDG

0.005 % FS + 0.01 % RDG

0.005 % FS + 0.01 % RDG

0.005 % FS + 0.01 % RDG

0.005 % FS + 0.0125 % RDG

0.005 % FS + 0.0125 % RDG

0.005 % FS + 0.0125 % RDG

0.007 % FS + 0.0125 % RDG

0.007 % FS + 0.01 % RDG

0.007 % FS + 0.01 % RDG

0.05 kPa

0.5 mbar

0.0073 psi

0.05 % Span + 0.1 % RDG

0.025 % FS + 0.025% RDG

0.02 % FS + 0.025% RDG

0.015 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.01 % FS + 0.025% RDG

0.015 % FS + 0.025% RDG

0.015 % FS + 0.025% RDG

0.015 % FS + 0.025% RDG

1)

Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2)

Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

3)

Every internal/external gauge pressure module’s range may be displayed also in absolute pressure if the Barometric Module (PB or EXT B) is installed/connected.

(±)

Maximum number of internal pressure modules is 3 gauge/differential pressure modules and one Barometric (PB) module in the extended case. The flat case has room for internal Barometric module only. Both cases have connection for external pressure modules.

External pressure modules are also compatible with Beamex MC2, MC4 and MC5 family calibrators.

Supported pressure units:

Pa, kPa, hPa, MPa, mbar, bar, gf/cm

2

, kgf/cm

2

, kgf/m

2

, kp/cm

2

, lbf/ft

2

, psi, at, torr, atm, ozf/in 2 , iwc, inH2O, ftH2O, mmH2O, cmH2O, mH2O, mmHg, cmHg, mHg, inHg, mmHg(0°C), inHg(0°C), mmH2O(60°F), mmH2O(68°F), mmH2O(4°C), cmH2O(60°F), cmH2O(68°F), cmH2O(4°C), inH2O(60°F), inH2O(68°F), inH2O(4°C), ftH2O(60°F), ftH2O(68°F), ftH2O(4°C).

Large number of user pressure units can be created.

Temperature coefficient:

<±0.001% RDG/°C outside 15 - 35 °C (59 - 95 °F).

P10mD / EXT10mD: < ±0.002% Span/°C outside 15 - 35 °C (59 - 95 °F)

Max overpressure:

2 times the nominal pressure. Except following modules;

PB/EXTB: 1200 mbar abs (35.4 inHg abs). P10mD/EXT10mD: 200 mbar (80 iwc).

EXT600: 900 bar (13000 psi). EXT1000: 1000 bar (15000 Psi).

Pressure Media:

Modules up to P6C/EXT6C: Dry clean air or other clean, inert, non-toxic, noncorrosive gases. Modules P20C/EXT20C and higher: Clean, inert, non-toxic, noncorrosive gases or liquids

Wetted Parts:

AISI316 stainless steel, Hastelloy, Nitrile rubber

Pressure connection:

PB/EXTB: M5 (10/32”) female.

P10mD/EXT10mD: Two M5 (10/32”) female threads with hose nipples included.

P100m/EXT100m to P20C/EXT20C: G1/8” (ISO228/1) female. A conical 1/8” BSP male with 60° internal cone adapter included for Beamex hose set.

P60, P100, P160: G1/8” (ISO228/1) female.

EXT60 to EXT1000: G ¼” (ISO228/1) male

18

TC measurement & simulation

TC1 measurement & simulation / TC2 measurement

Type

B

(3

R (3

S (3

E

(3

J

(3

K (3

N (3

T (3

U

(5

L (5

C (6

G

(7

D (6

Range (°C)

0 ... 1820

-50 ... 1768

-50 ... 1768

-270 ... 1000

-210 ... 1200

-270 ... 1372

-270 ... 1300

-270 ... 400

-200 ... 600

-200 ... 900

0 ... 2315

0 ... 2315

0 ... 2315

-210 ... -200

-200 ... 0

0 ... 1200

-270 ... -200

-200 ... 0

0 ... 1000

1000 ... 1372

-270 ... -200

-200 ... -100

-100 ... 0

0 ... 800

800 ... 1300

-270 ... -200

-200 ... 0

0 ... 400

-200 ... 0

0 ... 600

-200 ... 0

0 ... 900

0 ... 1000

1000 ... 2315

0 ... 60

60 ... 200

200 ... 400

400 ... 1500

1500 ... 2315

0 ... 140

140 ... 1200

1200 ... 2100

2100 ... 2315

Range (°C)

0 ... 200

200 ... 500

500 ... 800

800 ... 1820

-50 ... 0

0 ... 150

150 ... 400

400 ... 1768

-50 ... 0

0 ... 100

100 ... 300

300 ... 1768

-270 ... -200

-200 ... 0

0 ... 1000

Accuracy

(1

(8

1.5 °C

0.6 °C

0.4 °C

0.8 °C

0.6 °C

0.35 °C

0.3 °C

0.7 °C

0.6 °C

0.4 °C

0.35 °C

(8

0.05 °C + 0.04% RDG

0.05 °C + 0.003% RDG

(8

0.06 °C + 0.05% RDG

0.06 °C + 0.003% RDG

(8

0.08 °C + 0.07% RDG

0.08 °C + 0.004% RDG

0.012% RDG

(8

0.15% RDG

0.11 °C + 0.04% RDG

0.11 °C

0.06 °C + 0.006% RDG

(8

0.07 °C + 0.07% RDG

0.07 °C

0.07 °C + 0.05% RDG

0.07 °C

0.06 °C + 0.025% RDG

0.06 °C + 0.002% RDG

0.22 °C

0.018% RDG

(8

0.9 °C

0.4 °C

0.2 °C

0.014% RDG

0.3 °C

0.2 °C

0.016% RDG

0.45 °C

1 Year Uncertainty

(2

(±)

(4

2.0 °C

0.8 °C

0.5 °C

1.0 °C

0.7 °C

0.45 °C

0.4 °C

0.9 °C

0.7 °C

0.55 °C

0.45 °C

(4

0.07 °C + 0.06% RDG

0.07 °C + 0.005% RDG

(4

0.08 °C + 0.06% RDG

0.08 °C + 0.006% RDG

(4

0.1 °C + 0.1% RDG

0.1 °C + 0.007% RDG

0.017% RDG

(4

0.2% RDG

0.15 °C + 0.05% RDG

0.15 °C

0.07 °C + 0.01% RDG

(4

0.1 °C + 0.1% RDG

0.1 °C

0.1 °C + 0.07% RDG

0.1 °C

0.08 °C + 0.04% RDG

0.08 °C + 0.005% RDG

0.3 °C

0.027% RDG

(4

1.0 °C

0.5 °C

0.3 °C

0.02% RDG

0.4 °C

0.3 °C

0.024% RDG

0.65 °C

Resolution 0.01 °C.

With internal reference junction please see separate specification.

Also other thermocouple types available as option, please contact Beamex.

1)

Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2) Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

3)

IEC 584, NIST MN 175, BS 4937, ANSI MC96.1

4) ±0.007% of thermovoltage + 4 µV

5)

DIN 43710

6) ASTM E 988 - 96

7)

ASTM E 1751 - 95e1

8) ±0.004% of thermovoltage + 3 µV

Measurement input impedance

Simulation maximum load current

Simulation load effect

Supported units

Connector

> 10 MΩ

5 mA

< 5 μV/mA

°C, °F, Kelvin, °Ré, °Ra

TC1: Universal TC connector , TC2: TC Miniplug

19

RTD measurement & simulation

R1 & R2 measurement

Sensor Type Range (°C) Range (°C)

Pt50(385) -200 ... 850

-200 ... 270

270 ... 850

Pt100(375)

Pt100(385)

Pt100(389)

Pt100(391)

Pt100(3926)

Pt100(3923)

Pt200(385)

Pt400(385)

Pt500(385)

Pt1000(385)

Ni100(618)

Ni120(672)

Cu10(427)

-200 ... 850

-200 ... 600

-200 ... 850

-200 ... 850

-200 ... 850

-200 ... 850

-60 ... 180

-80 ... 260

-200 ... 260

-200 ... 0

0 ... 850

-200 ... 0

0 ... 600

-200 ... -80

-80 ... 0

0 ... 260

260 ... 850

-200 ... -100

-100 ... 0

0 ... 850

-200 ... -120

-120 ... -50

-50 ... 0

0 ... 850

-200 ... -150

-150 ... -50

-50 ... 0

0 ... 850

-60 ... 0

0 ... 180

-80 ... 0

0 ... 260

-200 ... 260

Accuracy

(1

0.025 °C

0.009% RDG

0.011 °C

0.011 °C + 0.009% RDG

0.011 °C

0.011 °C + 0.009% RDG

0.007 °C

0.016 °C

0.016 °C + 0.009% RDG

0.03 °C + 0.011% RDG

0.007 °C

0.015 °C

0.026 °C + 0.01% RDG

0.008 °C

0.013 °C

0.025 °C

0.025 °C + 0.01% RDG

0.007 °C

0.018 °C

0.022 °C

0.022 °C + 0.01% RDG

0.009 °C

0.009 °C + 0.005% RDG

0.009 °C

0.009 °C + 0.005% RDG

0.012 °C

1 Year Uncertainty

(2

(±)

0.03 °C

0.012% RDG

0.015 °C

0.015 ° + 0.012% RDG

0.015 °C

0.015 °C + 0.012% RDG

0.01 °C

0.02 °C

0.02 °C + 0.012% RDG

0.045 °C + 0.02% RDG

0.01 °C

0.02 °C

0.045 °C + 0.019% RDG

0.01 °C

0.02 °C

0.045 °C

0.045 °C + 0.019% RDG

0.008°C

0.03 °C

0.04 °C

0.04 °C + 0.019% RDG

0.012 °C

0.012 °C + 0.006% RDG

0.012 °C

0.012 °C + 0.006% RDG

0.16 °C

R1 Simulation

Sensor Type

Pt50(385)

Range (°C)

-200 ... 850

Range (°C)

-200 ... 270

270 ... 850

Accuracy

(1

0.055 °C

0.035 °C + 0.008% RDG

1 Year Uncertainty

(2

(±)

0.11 °C

0.11°C + 0.015% RDG

Pt100(375)

Pt100(385)

Pt100(389)

Pt100(391)

Pt100(3926)

-200 ... 850

-200 ... 0

0 ... 850

0.025 °C

0.025 °C + 0.007% RDG

0.05 °C

0.05 °C + 0.014% RDG

Pt100(3923)

Pt200(385)

Pt400(385)

Pt500(385)

Pt1000(385)

Ni100(618)

Ni120(672)

-200 ... 600

-200 ... 850

-200 ... 850

-200 ... 850

-200 ... 850

-60 ... 180

-80 ... 260

-200 ... 0

0 ... 600

-200 ... -80

-80 ... 0

0 ... 260

260 ... 850

-200 ... -100

-100 ... 0

0 ... 850

-200 ... -120

-120 ... -50

-50 ... 0

0 ... 850

-200 ... -150

-150 ... -50

-50 ... 0

0 ... 850

-60 ... 0

0 ... 180

-80 ... 0

0 ... 260

-200 ... 260

0.025 °C

0.025 °C + 0.007% RDG

0.012 °C

0.02 °C

0.02 °C + 0.006% RDG

0.03 °C + 0.011% RDG

0.01 °C

0.015 °C

0.027 °C + 0.01% RDG

0.008 °C

0.012 °C

0.026 °C

0.026 °C + 0.01% RDG

0.006 °C

0.017 °C

0.023 °C

0.023 °C + 0.01% RDG

0.021 °C

0.019 °C

0.021 °C

0.019 °C

0.26 °C

0.05 °C

0.05 °C + 0.014% RDG

0.025 °C

0.035 °C

0.04 °C + 0.011% RDG

0.06 °C + 0.02% RDG

0.015 °C

0.03 °C

0.05 °C + 0.019% RDG

0.015 °C

0.025 °C

0.05 °C

0.05 °C + 0.019% RDG

0.011 °C

0.03 °C

0.043 °C

0.043 °C + 0.019% RDG

0.042 °C

0.037 °C + 0.001% RDG

0.042 °C

0.037 °C + 0.001% RDG

0.52 °C Cu10(427) -200 ... 260

For Platinum sensors Callendar van Dusen coefficients can be programmed. Also other RTD types available as option, please contact Beamex.

20

RTD Measurement current

4-wire connection

3-wire measurement

Max resistance excitation current

Min resistance excitation current

Simulation settling time with pulsed excitation current

Supported units

Pulsed, bi-directional 1 mA (0..500 Ω), 0.2 mA (>500 Ω).

Measurement specifications valid

Add 10 mΩ

5 mA (0...650 Ω). Iexc * Rsim < 3.25 V (650...4000 Ω).

> 0.2 mA (0...400 Ω). >0.1 mA (400...4000 Ω).

< 1 ms

°C, °F, Kelvin, °Ré, °Ra

Internal Reference Junction TC1 & TC2

Range (°C)

-10 … 45 °C

Accuracy

(1

±0.10 °C

1 Year Uncertainty

(2

±0.15 °C

Specifications valid in temperature range: 15 ... 35 °C.

Temperature coefficient outside of 15 ... 35 °C: ±0.005 °C/°C.

Specifications assumes that calibrator has stabilized in environmental condition, being switched on, for minimum of 90 minutes. For a measurement or simulation done sooner than that, please add uncertainty of 0.15 °C.

In order to calculate the total uncertainty of thermocouple measurement or simulation with internal reference junction used, please add the relevant thermocouple uncertainty and the Internal Reference Junction uncertainty together as a root sum of the squares.

Voltage measurement

IN (-1 … 60 V)

Range

-1.01 ... 1 V

1 ... 60.6 V

Resolution

0.001 mV

0.01 mV

Input impedance

Supported units

TC1 & TC2 (-1 … 1 V)

Range

-1.01 ... 1.01 V

Resolution

0.001 mV

Input impedance

Supported units

Connector

Accuracy

(1

3 µV + 0.003% RDG

0.125 mV + 0.003% RDG

> 2 MΩ

V, mV, µV

1 Year Uncertainty

(2

5 µV + 0.006% RDG

0.25 mV + 0.006% RDG

Accuracy

(1

3 µV + 0.004% RDG

1 Year Uncertainty

(2

4 µV + 0.007% RDG

> 10 MΩ

V, mV, µV

TC1: Universal TC connector , TC2: TC Miniplug

1)

Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2) Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

21

Voltage generation

OUT (-3 ... 24 V)

Range

-3 … 10 V

10 … 24 V

Resolution

0.00001 V

0.0001 V

Maximum load current

Short circuit current

Load effect

Supported units

TC1 (-1 ... 1 V)

Range

-1 … 1 V

Maximum load current

Load effect

Supported units

Resolution

0.001 mV

Current measurement

IN (-100 ... 100 mA)

Range

-25 … 25 mA

±(25 … 101 mA)

Resolution

0.0001 mA

0.001 mA

Input impedance

Supported units

Loop supply

Current generation

OUT (0 ... 55 mA)

Range

0 … 25 mA

25 … 55 mA

Internal loop supply

Max load impedance w. internal supply

Max external loop supply

Supported units

Resolution

0.0001 mA

0.001 mA

Accuracy

(1

0.05 mV + 0.004% RDG

0.05 mV + 0.004% RDG

10 mA

>100 mA

< 50 µV/mA

V, mV, µV

1 Year Uncertainty

(2

0.1 mV + 0.007% RDG

0.1 mV + 0.007% RDG

Accuracy

(1

3 µV + 0.004% RDG

5 mA

< 5 µV/mA

V, mV, µV

1 Year Uncertainty

(2

4 µV + 0.007% RDG

Accuracy

(1

0.75 µA + 0.0075% RDG

0.75 µA + 0.0075% RDG

1 Year Uncertainty

(2

1 µA + 0.01% RDG

1 µA + 0.01% RDG

< 10 Ω mA, µA

Internal 24 V ±10% (max 55 mA), or external max 60 VDC.

Accuracy

(1

0.75 µA + 0.0075% RDG

1.5 µA + 0.0075% RDG

1 Year Uncertainty

(2

1 µA + 0.01% RDG

2 µA + 0.01% RDG

24 V ±5%. Max 55 mA.

24 V / (generated current). 1140 Ω @ 20 mA, 450 Ω @ 50 mA

60 VDC mA, µA

1) Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2)

Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

22

Frequency measurement

IN (0.0027 … 51000 Hz)

Range

0.0027 … 0.5 Hz

0.5 … 5 Hz

5 … 50 Hz

50 … 500 Hz

500 … 5000 Hz

5000 … 51000 Hz

Resolution

0.000001 Hz

0.00001 Hz

0.0001 Hz

0.001 Hz

0.01 Hz

0.1 Hz

Input impedance

Supported units

Trigger level

Minimum signal amplitude

Accuracy

(1

0.000002 Hz + 0.001% RDG

0.00002 Hz + 0.001% RDG

0.0002 Hz + 0.001% RDG

0.002 Hz + 0.001% RDG

0.02 Hz + 0.001% RDG

0.2 Hz + 0.001% RDG

> 1 MΩ

Hz, kHz, cph, cpm, 1/Hz(s), 1/kHz(ms), 1/MHz(µs)

Dry contact, wet contact -1 … 14 V

1.0 Vpp (<10kHz), 1.2 Vpp (10 … 50 kHz)

1 Year Uncertainty

(2

0.000002 Hz + 0.002% RDG

0.00002 Hz + 0.002% RDG

0.0002 Hz + 0.002% RDG

0.002 Hz + 0.002% RDG

0.02 Hz + 0.002% RDG

0.2 Hz + 0.002% RDG

Frequency generation

OUT (0.0005 ... 50000 Hz)

Range

0.0005 … 0.5 Hz

0.5 … 5 Hz

5 … 50 Hz

50 … 500 Hz

500 … 5000 Hz

5000 … 50000 Hz

Resolution

0.000001 Hz

0.00001 Hz

0.0001 Hz

0.001 Hz

0.01 Hz

0.1 Hz

Maximum load current

Vawe forms

Output amplitude positive square wave

Output amplitude symmetric square wave

Duty Cycle

Amplitude accuracy

Supported units

Accuracy

(1

0.000002 Hz + 0.001 % RDG

0.00002 Hz + 0.001 % RDG

0.0002 Hz + 0.001 % RDG

0.002 Hz + 0.001 % RDG

0.02 Hz + 0.001 % RDG

0.2 Hz + 0.001 % RDG

10 mA

Positive square, symmetric square

0 ... 24 Vpp

0 ... 6 Vpp

1 ... 99%

< 5% of amplitude

Hz, kHz, cph, cpm, 1/Hz(s), 1/kHz(ms), 1/MHz(µs)

1 Year Uncertainty

(2

0.000002 Hz + 0.002% RDG

0.00002 Hz + 0.002% RDG

0.0002 Hz + 0.002% RDG

0.002 Hz + 0.002% RDG

0.02 Hz + 0.002% RDG

0.2 Hz + 0.002% RDG

Pulse counting

IN (0 ... 9 999 999 pulses)

Input impedance

Trigger level

Minimum signal amplitude

Max frequency

Trigger edge

> 1 MΩ

Dry contact, wet contact -1 … 14 V

1 Vpp (< 10 kHz), 1.2 Vpp (10 ... 50 kHz).

50 kHz

Rising, falling

1)

Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2)

Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

23

Pulse generation

OUT (0 ... 9 999 999 pulses)

Resolution

Maximum load current

Output amplitude positive pulse

Output amplitude symmetric pulse

Pulse frequency range

Duty Cycle

Resistance simulation

R1 (0 ... 4000 Ω)

Range

0 … 100 Ω

100 … 400 Ω

400 … 4000 Ω

Resolution

0.001 Ω

0.001 Ω

0.01 Ω

Max resistance excitation current

Min resistance excitation current

Settling time with pulsed exitation current

Supported units

1 pulse

10 mA

0 … 24 Vpp

0 … 6 Vpp

0.0005 … 10000 Hz

1 … 99%

Resistance measurement

R1 & R2 (0 ... 4000 Ω)

Range

-1 ... 100 Ω

100 ... 110 Ω

110 ... 150 Ω

150 ... 300 Ω

300 ... 400 Ω

400 ... 4040 Ω

Resolution

0.001 Ω

0.001 Ω

0.001 Ω

0.001 Ω

0.001 Ω

0.01 Ω

Measurement current

Supported units

4-wire connection

3-wire measurement

Accuracy

(1

4.5 mΩ

0.0045% RDG

0.005% RDG

0.006% RDG

0.007% RDG

9 mΩ + 0.008% RDG

1 Year Uncertainty

(2

6 mΩ

0.006% RDG

0.007% RDG

0.008% RDG

0.009% RDG

12 mΩ + 0.015% RDG

Pulsed, bi-directional 1 mA (0..500 Ω), 0.2 mA (>500 Ω).

Ω, kΩ

Measurement specifications valid

Add 10 mΩ

Accuracy

(1

10 mΩ

5 mΩ + 0.005% RDG

10 mΩ + 0.008% RDG

1 Year Uncertainty

(2

20 mΩ

10 mΩ + 0.01% RDG

20 mΩ + 0.015% RDG

5 mA (0 ... 650 Ω). Iexc * Rsim < 3.25 V (650 ... 4000 Ω).

> 0.2 mA (0 ... 400 Ω). >0.1 mA (400 ... 4000 Ω).

< 1ms

Ω, kΩ

1) Accuracy includes hysteresis, nonlinearity and repeatability (k=2).

2)

Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity, repeatability and typical long term stability for mentioned period. (k=2)

24

Modularity, options and accessories

Modularity and options

• All electrical / temperature functions are included as standard

• Two case bottom choices:

- flat (no room for internal pressure modules, only Barometer)

- extended (room for internal pressure modules)

• Optional internal pressure modules (up to four internal pressure modules; three standard and one barometric)

• Optional user-interface modes:

- Documenting Calibrator

- Data Logger

- HART Communicator

- FOUNDATION Fieldbus Communicator

- Profibus PA Communicator

• Pressure / Temperature Controller Communications

Standard Accessories

• Accredited calibration certificate

• User guide

• Computer cable (USB)

• Battery charger / eliminator

• Internal LiPO battery pack

• Test leads and clips

• Appropriate pressure T-hose with internal low pressure modules

• CD-ROM with user manual, software tools and product information

Optional Accessories

• Soft Carrying Case

• Soft Accessory Case

• Hard Carrying Case

• Spare battery pack

• Adapter cables for the second RTD channel

• Cable for pressure and temperature controllers

25

Related products and services

Portable calibrators

Beamex’s range of portable MC-calibrators for field calibration is known for their accuracy, versatility and also for meeting both high and uncompromised quality standards.

Workstations

A workstation can be considered ideal when most of the maintenance and calibration tasks are performed in the workshop. Beamex’s workstation is a modular testing and calibration system designed for use in workshops and laboratories.

Temperature dry blocks

Beamex offers two different dry block series: the Beamex

®

FB Series Field Temperature Blocks and the Beamex

®

MB

Series Metrology Temperature Blocks. The dry blocks in the FB Series are lightweight, high-accuracy temperature dry blocks for industrial use. The dry blocks in the MB Series deliver bath-level accuracy for industrial applications as well.

Calibration software

Beamex

®

CMX Calibration Management Software

The Beamex ® CMX is calibration management software that assists in documenting, planning, analyzing and, finally, optimizing calibration work. The CMX’s scalable technology and user configuration allows you to integrate it easily into other systems for a one-of-kind calibration system that fits your specific needs completely. The CMX also helps to meet the regulatory requirements, whether your plant’s calibration system needs to comply with ISO 17025, cGMP or

21 CFR Part 11. By using the CMX, you will have all your calibration results in a traceable and auditable form, either printed on paper or stored in electronic format in a database.

Professional services

Recalibration and service

There are many benefits from using the services provided by Beamex’s accredited calibration laboratory on a regular basis. It ensures that the calibration equipment remains in excellent condition and you are also able to provide, if needed, up-to-date proof of the calibrator’s measurement accuracy. The Beamex Calibration Laboratory provides traceable calibration services in pressure, temperature, DC current, DC voltage, resistance and frequency.

Training and installation

Beamex provides worldwide services for installation and training. This way you are able to have your new calibration system up and running in no time. You also learn about the capabilities of Beamex calibration equipment, how to use it and how your organization will benefit the most from it.

Accessories

PG series of calibration pumps

The PG series includes hand-held, lightweight pressure and vacuum sources for field use. The PG series of hand pumps are ideal pressure/vacuum generators to be used as accessories for pressure and vacuum calibration.

External pressure modules

The external pressure modules introduce new configuration possibilities and add flexibility, as it is possible to calibrate even more pressure ranges with the same calibrator. This way, the Beamex calibration equipment meets your needs even better.

26

PORTABLE CALIBRATORS

WORKSTATIONS PROFESSIONAL SERVICES

CALIBRATION SOFTWARE

27

28

w w w . b e a m e x . c o m

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
