Guide to the Collection of
Digital Equipment Corporation PDP-1 Computer
Materials
Dates: 1960 – 1983 (bulk 1960 - 1976)
Extent: 9 linear feet
Collection number: X3602.2006
Accession number: 102660913
Processed by: Judith A. Strebel and Rebekah Kim, 2006
Collection of Digital Equipment Corporation PDP-1 Computer Materials
X3602.2006
Abstract
The Collection of Digital Equipment Corporation (DEC) PDP-1 Computer Materials is
comprised of program listings, manuals, technical papers, promotional materials, design
drawings and photographs regarding the PDP-1 digital computer spanning 1959 to 1983.
Administrative Information
Access Restrictions
The collection is open for research.
Publication Rights
The Computer History Museum (CHM) can only claim physical ownership of the
collection. Users are responsible for satisfying any claims of the copyright holder.
Permission to copy or publish any portion of the Computer History Museum’s
collection must be given by the Computer History Museum.
Preferred Citation
[Identification of Item], [Item Date], Collection of Digital Equipment Corporation
PDP-1 Computer Materials, Lot X3602.2006, [Box #], [Folder #], Computer
History Museum
Processing Notes
The processing of the Collection of DEC PDP-1 Computer Material was
undertaken as a result of the restoration of a PDP-1 computer at the Computer
History Museum and the subsequent online exhibit. The collection had partial
archival processing at CHM before its full processing by Judy Strebel and
Rebekah Kim during 2005 and 2006. No original order existed from the previous
processing or from its acquisition by CHM.
Provenance Notes
The provenance is unknown for the Collection of DEC PDP-1 Computer
Materials and most likely came from a variety of different sources. The nucleus of
the collection was originally acquired in the 1980s and 1990s when the Computer
History Museum was then known as the Computer Museum, located in Boston.
The Collection is a portion of the larger artificial Company Collection. Gwen Bell,
the Computer Museum’s first curator arranged documents by originating
institution or company. In 2005 and 2006 all the PDP-1 materials shelved as part
of the “Company Collection” were given the found in collection lot number of
X3602.2006 and processed.
Repository
Computer History Museum
1401 N. Shoreline Blvd.
Mountain View, CA 94043
USA
650-810-1010
www.computerhistory.org
Computer History Museum
Page 2 of 25
Collection of Digital Equipment Corporation PDP-1 Computer Materials
X3602.2006
Historical Note
In 1960 Digital Equipment Corporation (DEC) launched its first computer, the PDP-1
(Programmed Data Processor-1). The computer cost $120,000.00, and was 8 feet by 2 feet by 6
feet in size. The computer was designed in three and a half months by Ben Gurley. He based
his system on the Massachusetts Institute of Technology (MIT) Lincoln Laboratory TX-0 and TX2 computers and used DEC’s initial product, a series of interconnectable circuits known as
“Laboratory Modules,” to create the PDP-1.
The PDP-1 was the world's first commercial interactive computer, and was used for process
control, scientific research, and graphics applications, as well as to pioneer timesharing
systems. The PDP-1 also made it possible for smaller businesses and laboratories to have
access to much more computing power than ever before.
Though the PDP-1 was produced in relatively small quantities (just over 50) its impact was
significant. For DEC, it was the first in a long line of computers that focused on interactivity and
affordability. For the user, the PDP-1 represented an unprecedented freedom of humanmachine interaction, spurring the creation of hacker culture at MIT, Bolt Baranek and Newman
(BBN) and elsewhere. Inspired programmers created early debugging, text editing, music and
game programs - including the first computer video game, Spacewar!
Scope and Content Note
The Collection of Digital Equipment Corporation PDP-1 Computer Materials is composed of
program listings, manuals, technical papers, memorandums, promotional materials, logbooks,
specifications, design drawings, photographs and paper tape [software] spanning 1959 to 1976.
The records are divided into eight series and total 9 linear feet, in six record cartons, one
manuscript box, and one oversized box. All series are arranged alphabetically by folder title.
The first series, Program Listings, date from 1961 to 1976. Included in this series is the program
listing for Spacewar!, one of the earliest, if not the earliest video game, for digital computers.
The large group of program listings includes debugging programs, administrative routines, and
test programs.
The second series, Technical Notes, date from 1959 to 1975. This series contains technical
programming notes to all types of programs from Invisible Debugger to Expensive Typewriter.
Contained in this series are technical notes for the PDP-1 by the Digital Equipment Corporation
Users Society (DECUS), BBN, DEC, Itek Laboratories, and MIT.
The third series is Manuals, 1960 to 1967. The manuals cover hardware and programming
topics. This series contains manuals that focus on specific components as well as ones that
cover basic instructions and maintenance for the PDP-1. Included is an early Programmed Data
Processor-1 Handbook (1963).
The fourth series is Miscellaneous, 1960 to 1965. Contained in this series are a small number of
interoffice memoranda and promotional materials. Also included is a 1963 option and price list.
Of interest is an oral history transcript of Richard Best, an engineer who worked at MIT’s Lincoln
Laboratory and then at Digital Equipment Corporation.
Computer History Museum
Page 3 of 25
Collection of Digital Equipment Corporation PDP-1 Computer Materials
X3602.2006
The fifth series Specifications, is a small quantity of specifications dating from 1961 to 1973.
These include cable schedules, component lists, component diagrams, and wiring schematics.
The sixth series is Logbooks/ Records. This series consists of logbooks, 1962 to 1976, for the
PDP-1 computers at the MIT Research Laboratory of Electronics. Information recorded here
describes the programs that were run, maintenance issues, and failures. Also included is an
undated maintenance log on loose paper.
The seventh series is Design Drawings, 1959 to 1968. These are oversized schematics of the
PDP-1.
Arrangement
I.
Program listings (1961 – 1976)
II.
Technical Notes (1959 - 1975)
III.
Manuals (1960 – 1967)
IV.
Miscellaneous (1960 – 1965)
V.
Specifications (1961 - 1973)
VI.
Log Books/ Records (1962 – 1984)
VII.
Design drawings (oversized drawings) (1959 – 1968)
Subjects
Computer science. Computer architecture and design
Digital Equipment Corporation
Digital Equipment Computer Users Society
Electronic digital computers programmed instruction
Electronic digital computers
Massachusetts Institute of Technology. Dept. of Electrical Engineering and Computer Science
PDP computers
Spacewar computer game
Time-sharing computer systems
Separated Material
Photographs were removed from the collection. There were over 75 original photographs
covering, 1960 to 1983, of the PDP-1 Computer taken of the computer in use or for marketing
purposes. To view the photographs go to the CHM website at
http://archive.computerhistory.org/search.
Paper tapes were removed from the collection. There are 388 catalog records of various
software programs punched on paper tape for the PDP-1. The cataloging was done by
transcribing what was written on the paper tape and not by machine reading it to verify the
actual content of the tapes. To view the paper tape catalog records go to the CHM website at
http://archive.computerhistory.org/search.
Related Collections at CHM
