MC68LC302 Low Power Integrated Multiprotocol Processor

MC68LC302 Low Power Integrated Multiprotocol Processor
Freescale Semiconductor, Inc.
Freescale Semiconductor, Inc...
MC68LC302
Low Power Integrated
Multiprotocol Processor
Reference Manual
For More Information On This Product,
Go to: www.freescale.com
Freescale Semiconductor, Inc.
PREFACE
The complete documentation package for the MC68LC302 consists of the MC68LC302RM/
AD, MC68LC302 Low Power Integrated Multiprotocol Processor Reference Manual,
M68000PM/AD, MC68000 Family Programmer’s Reference Manual, MC68302UM/AD,
MC68302 Integrated Multiprotocol Processor User’s Manual, and the MC68LC302/D,
MC68LC302 Low Power Integrated Multiprotocol Processor Product Brief.
Freescale Semiconductor, Inc...
The MC68LC302 Low Power Integrated Multiprotocol Processor Reference Manual describes the programming, capabilities, registers, and operation of the MC68LC302 that differ
from the original MC68302; the MC68000 Family Programmer’s Reference Manual provides
instruction details for the MC68LC302; and the MC68LC302 Low Power Integrated Multiprotocol Processor Product Brief provides a brief description of the MC68LC302 capabilities.
The MC68302 Integrated Multiprotocol Processor User’s Manual is required, since the
MC68LC302 Low Power Integrated Multiprotocol Processor Reference Manual only describes the new features of the MC68LC302.
This user’s manual is organized as follows:
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
Section 7
Introduction
Configuration, Clocking, Low Power Modes, and Internal Memory Map
System Integration Block (SIB)
Communications Processor (CP)
Signal Description
Electrical Characteristics
Mechanical Data And Ordering Information
ELECTRONIC SUPPORT:
The Technical Support BBS, known as AESOP (Application Engineering Support Through
On-Line Productivity), can be reach by modem or the internet. AESOP provides commonly
asked application questons, latest device errata, device specs, software code, and many
other useful support functions.
Modem: Call 1-800-843-3451 (outside US or Canada 512-891-3650) on a modem that runs
at 14,400 bps or slower. Set your software to N/8/1/F emulating a vt100.
Internet: This access is provided by telneting to pirs.aus.sps.mot.com [129.38.233.1] or
through the World Wide Web at http://pirs.aus.sps.mot.com.
— Sales Offices —
For questions or comments pertaining to technical information, questions, and applications,
please contact one of the following sales offices nearest you.
iii
MC68LC302 REFERENCE MANUAL
For More Information On This Product,
Go to: www.freescale.com
MOTOROLA
Freescale Semiconductor, Inc.
Freescale Semiconductor, Inc...
