JProbe Installation Guide

JProbe
®
Installation Guide
8.1
© 2009 Quest Software, Inc. ALL RIGHTS RESERVED.
This guide contains proprietary information protected by copyright. The software described in this guide is furnished under a software license or nondisclosure agreement. This software may be used or copied only in accordance with the terms of the applicable agreement. No part of this guide may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording for any purpose other than the purchaser's personal use without the written permission of Quest Software, Inc.
If you have any questions regarding your potential use of this material, contact:
Quest Software World Headquarters
LEGAL Dept
5 Polaris Way
Aliso Viejo, CA 92656 www.quest.com
email: [email protected]
Refer to our Web site for regional and international office information.
Trademarks
Quest, Quest Software, the Quest Software logo, Aelita, Akonix, AppAssure, Benchmark Factory, Big Brother,
ChangeAuditor, DataFactory, DeployDirector, ERDisk, Foglight, Funnel Web, GPOAdmin, iToken, I/Watch, Imceda,
InLook, IntelliProfile, InTrust, Invirtus, IT Dad, I/Watch, JClass, Jint, JProbe, LeccoTech, LiteSpeed, LiveReorg,
MessageStats, NBSpool, NetBase, Npulse, NetPro, PassGo, PerformaSure, Quest Central, SharePlex, Sitraka,
SmartAlarm, Spotlight, SQL LiteSpeed, SQL Navigator, SQL Watch, SQLab, Stat, StealthCollect, Tag and Follow,
Toad, T.O.A.D., Toad World, vAMP, vAnalyzer, vAutomator, vControl, vConverter, vDupe, vEssentials, vFoglight, vMigrator, vOptimizer Pro, vPackager, vRanger, vRanger Pro, vReplicator, vSpotlight, vToad, Vintela, Virtual DBA,
VizionCore, Vizioncore vAutomation Suite, Vizioncore vEssentials, Xaffire, and XRT are trademarks and registered trademarks of Quest Software, Inc in the United States of America and other countries. Other trademarks and registered trademarks used in this guide are property of their respective owners.
Disclaimer
The information in this document is provided in connection with Quest products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of
Quest products. EXCEPT AS SET FORTH IN QUEST'S TERMS AND CONDITIONS AS SPECIFIED IN THE
LICENSE AGREEMENT FOR THIS PRODUCT, QUEST ASSUMES NO LIABILITY WHATSOEVER AND
DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL QUEST BE LIABLE FOR ANY
DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING,
WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION OR LOSS OF
INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF QUEST HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Quest makes no representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Quest does not make any commitment to update the information contained in this document.
Third Party Information
See Third_Party_Contributions.htm in your JProbe \doc installation directory.
Installation Guide
February 2009
Version 8.1
Table of Contents
Introduction to This Guide ..................................................................................................................7
Supported Platforms..........................................................................................................................15
4 JProbe
Installation Guide
Installing JProbe................................................................................................................................ 29
Licensing JProbe............................................................................................................................... 35
5
Index....................................................................................................................................................45
6 JProbe
Installation Guide
Introduction to This Guide
This chapter provides information about what is contained in the Installation Guide. It also provides information about the JProbe documentation suite and Quest Software.
This chapter contains the following sections:
8 JProbe
Installation Guide
About JProbe
JProbe is an enterprise-class Java profiler that provides intelligent diagnostics on memory usage, performance, and test coverage. It allows developers to quickly pinpoint and repair the root cause of application code performance and stability problems that obstruct component and integration integrity.
JProbe provides three types of analysis:
• Memory analysis allows a developer to identify and resolve Java memory leaks and object cycling to ensure optimal program efficiency and stability.
• Performance analysis allows a developer to identify and resolve Java bottlenecks and deadlocks to ensure optimal program performance and scalability.
• Coverage analysis allows a developer to identify unexecuted lines of code during unit testing to ensure test coverage and program correctness.
JProbe also offers an Eclipse plug-in that provides intelligent code performance analysis and problem resolution from within the Eclipse Java IDE.
About This Guide
This guide walks you through installing and licensing JProbe.
This guide is intended for Java developers who want to verify system requirements, install JProbe, and license JProbe.
How to Use This Guide
We recommend the following path through this guide:
1
Start with
Chapter 1, “Supported Platforms”
. This chapter lists all the required hardware and software by operating system. It also contains important notes that are critical to running JProbe successfully within your development environment.
2
3
To install JProbe on your Windows system or UNIX system, see
.
Finally, you need to license JProbe. Licensing options and procedures are
outlined in Chapter 3, “Licensing JProbe”
.
Introduction to This Guide
JProbe Documentation Suite
Where to Find Information Not in this Guide
The following table shows where you can find other types of information:
Information about: Refer to:
Configuring JProbe to run your application or application server
Running sessions from the
JProbe Console
Using JProbe Plugins for
Eclipse
• JProbe User Guide (PDF/online help)
• JProbe Plugins for Eclipse Guide
JProbe User Guide (PDF/online help)
• JProbe Plugins for Eclipse Guide
• JProbe User Guide (online help)
JProbe Reference Guide (PDF)
Automating JProbe analysis sessions using command line utilities
Adding JProbe to an Ant system
Known and resolved issues
JProbe Ant Task User Manual (HTML)
JProbe Release Notes (HTML)
JProbe Documentation Suite
The JProbe documentation suite is provided in a combination of online help, PDF, and
HTML.
•
Online Help:
You can open the online help by clicking the Help icon on the JProbe toolbar.
•
PDF:
The complete JProbe documentation set is available in PDF format on
SupportLink. The PDF documentation can also be found in the Documentation folder on the JProbe DVD. The default location of the documentation after an installation is <jprobe_home>/docs. Adobe
®
Reader
®
is required.
•
HTML:
Release Notes are provided in HTML and text format. The default location of this document after an installation is <jprobe_home>/docs.
9
10 JProbe
Installation Guide
The Ant Tasks User Manual is also provided in HTML format. The default location of this document after an installation is <jprobe_home>/automation/doc.
To open it, navigate to index.html.
Core Documentation Set
The core documentation set consists of the following files:
• Installation Guide (PDF)
• User Guide (PDF and online help)
• Reference Guide (PDF)
• Plugins for Eclipse Guide (PDF)
• Demos and Tutorials (PDF)
• Release Notes (HTML)
• Ant Tasks User Manual (HTML)
Feedback on the Documentation
We are interested in receiving feedback from you about our documentation. For example, did you notice any errors in the documentation? Were any features undocumented? Do you have any suggestions on how we can improve the documentation? All comments are welcome. Please submit your feedback to the following email address: [email protected]
Please do not submit Technical Support related issues to this email address.
Introduction to This Guide
Text Conventions
Text Conventions
The following table summarizes how text styles are used in this guide:
Convention Description
Code
Variables
Interface
Monospace text represents code, code objects, and commandline input. This includes:
• Java language source code and examples of file contents
• Classes, objects, methods, properties, constants, and events
• HTML documents, tags, and attributes
Monospace-plus-italic text represents variable code or command-line objects that are replaced by an actual value or parameter.
Bold text is used for interface options that you select (such as menu items) as well as keyboard commands.
Files, components,
and documents
Italic text is used to highlight the following items:
• Pathnames, file names, and programs
• The names of other documents referenced in this guide
11
About Quest Software, Inc.
Quest Software, Inc., a leading enterprise systems management vendor, delivers innovative products that help organizations get more performance and productivity from their applications, databases, Windows infrastructure and virtual environments.
Through a deep expertise in IT operations and a continued focus on what works best,
Quest helps more than 90,000 customers worldwide meet higher expectations for enterprise IT. Quest provides customers with client management as well as server and desktop virtualization solutions through its subsidiaries, ScriptLogic and Vizioncore.
Quest Software can be found in offices around the globe and at
www.quest.com
.
12 JProbe
Installation Guide
Contacting Quest Software
Web site
Quest Software, Inc.
World Headquarters
5 Polaris Way
Aliso Viejo, CA 92656
USA
www.quest.com
Refer to our Web site for regional and international office information.
Contacting Quest Support
Quest Support is available to customers who have a trial version of a Quest product or who have purchased a commercial version and have a valid maintenance contract. Quest
Support provides around the clock coverage with SupportLink, our web self-service.
Visit SupportLink at:
http://support.quest.com
.
From SupportLink, you can do the following:
• Quickly find thousands of solutions (Knowledgebase articles/documents).
• Download patches and upgrades.
• Seek help from a Support engineer.
• Log and update your case, and check its status.
View the Global Support Guide for a detailed explanation of support programs, online services, contact information, and policy and procedures. The guide is available at:
http://support.quest.com/pdfs/Global Support Guide.pdf
.
Quest Communities
Get the latest product information, find helpful resources, and join a discussion with the
JProbe Quest team and other community members. Join the JProbe community at:
http://jprobe.inside.quest.com/
.
Introduction to This Guide
Support for JProbe and JVMs
Support for JProbe and JVMs
This section describes the policies Quest Software has for supporting JProbe and various versions of JVMs.
13
Support for JProbe
Quest Software supports the currently shipping version of JProbe plus one major release back. If you need support for an earlier version, you may be able to arrange a special
support contract. For more information, see “ Contacting Quest Support ” on page 12.
Support for JVMs
Quest Software supports a selection of JVMs that have passed quality assurance testing
Functional Restrictions
Some of the supported JVMs may have problems running with one of the JProbe analysis tools. You can still use these JVMs if you observe the functional restrictions documented in the footnotes. For example, some significant known issues include:
• IBM SDK 1.4.2 stability issue with Memory
• BEA JRockit 5 slow response time with Memory
New Versions of Supported JVMs
As newer versions of supported JVMs are released, most will be supported automatically. Others may require an updated version of the JProbe JVM configuration file, jvminfo.xml. This file is available on SupportLink. Select Downloads & Updates
and specify JProbe as the product. For more information, see “ Contacting Quest
Previously Supported JVMs
Effective with the JProbe 8.1 release, Quest Software has retired support for versions
1.2.x and 1.3.x of the Java 2 JVMs that were supported in earlier versions of JProbe, as they have completed the vendor's End-of-Life process. Quest Software strongly recommends upgrading to a vendor-supported JVM version.
14 JProbe
Installation Guide
JVMs Provided with Supported Application Servers
Quest Software will support the Java SDK shipped with any application server that is supported for JProbe, with the caveat that certain operating system patches and/or minor
JVM upgrades may need to be applied, as recommended by the vendor and/or Quest
1
Supported Platforms
You can install JProbe on the following operating systems using this guide:
Caution
Updates to the lists of supported JVMs and application servers are available at:
www.quest.com/jprobe/release_information.aspx
16 JProbe
Installation Guide
Microsoft Windows
System Requirements
You need the following minimum system requirements:
• One of the following OS systems:
• Microsoft Windows XP Professional SP2 or later
• Microsoft Windows Server 2003 SP2 or later
• Microsoft Windows Server 2008
• Microsoft Windows Vista
• Intel Pentium IV @2.4 GHz
• 2 GB RAM
• 200 MB free disk space
Supported JVMs
The following development kits contain a supported JVM:
• JRockit 1.4.2
• JRockit 5.0
• JRockit 6.0
• IBM 32-bit SDK, Java 2 Technology Edition, Version 1.4.2, SR1 or later
Note
IBM JVMs are only supported for use with IBM WebSphere Application Server.
Note
IBM JDK 1.4.2 is not fully supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can take memory snapshots without a heap dump. You can also import an IBM heap dump.
• IBM 32-bit SDK, Java 2 Technology Edition, Version 1.5
• IBM 32-bit SDK, Version 1.6.0
• Sun Java 2 SDK, Standard Edition, 1.4.2
• Sun J2SE Development Kit 5.0
• Sun Java Platform, Standard Edition 6
Chapter 1: Supported Platforms
Microsoft Windows
17
Validated Application Servers
At time of release, the following application servers are tested and supported:
• Apache Geronimo 2.0.1 and 2.1.x
• Apache Tomcat 5.0, 5.5, and 6.0
• BEA WebLogic Server 8.1, 9.2, and 10.0
• BEA WebLogic Server Portal Server 8.1 and 9.2
• Caucho Resin 3.1 and 3.2
• IBM WebSphere Application Server Community Edition 2.0 and 2.1
• IBM WebSphere Portal Server 6.1
• IBM WebSphere Application Server 6.0.1+, 6.1, and 7.0
Note
On Windows XP and Windows Vista, IBM WebSphere Portal Server and IBM
WebSphere Application Server are only supported for development use.
• JBoss 4.0.x, 4.2.x, and 5.x
• Open Source GlassFish v2 UR2
• Oracle OC4J 10g 10.1.2 and 10.1.3
• Oracle Application Server 10g 10.1.3.x
• Oracle WebLogic Server 10.3
• Sun Java System Application Server 8.2 SE and 9.1 PE
Note
Sun Java System Application Server 9.1 PE is supported for Windows XP only.
• Sun Java System Web Server 6.1 and 7.0
Application servers are not supported on versions of Windows which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Windows.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
18 JProbe
Installation Guide
Sun Solaris
System Requirements
You need the following minimum system requirements:
• One of the following OS systems:
• Sun Solaris 8, 9, and 10 on Sun UltraSPARC processor (not SPARC Station or
Intel)
• Sun Solaris 10 on an x86 system
• 2 GB RAM
• 200 MB free disk space
Supported JVMs
The following development kits contain a supported JVM:
• JRockit 5 R26
Note
Vendor supports this version for Solaris 9 and 10 only.
• JRockit 6.0
• Sun Java 2 SDK, Standard Edition, 1.4.2, plus patches
Note
You can find patches on the Sun Microsystem Web site:
java.sun.com
.
• Sun J2SE Development Kit 5.0
• Sun Java Platform, Standard Edition 6
Validated Application Servers
At time of release, the following application servers are tested and supported:
• Apache Tomcat 5.0, 5.5, and 6.0
• BEA WebLogic Server 8.1, 9.2, and 10.0
• BEA WebLogic Server Portal Server 8.1 and 9.2
• IBM WebSphere Application Server 6.0.1+, 6.1, and 7.0
Note
Vendor supports IBM WebSphere Application Server versions 6.1 and 7.0 for Solaris
9 and 10 only.
Chapter 1: Supported Platforms
IBM AIX
19
• JBoss 4.0.x, 4.2.x, and 5.x
• Open Source GlassFish v2 UR2
• Oracle OC4J 10g 10.1.2 and 10.1.3
• Oracle Application Server 10g 10.1.3.x
• Oracle WebLogic Server 10.3
• Sun Java System Application Server 8.2 SE and 9.1 PE
Note
Vendor supports Sun Java System Application Server 8.2 SE for Solaris 8 and 9 only.
Note
Vendor supports Sun Java System Application Server 9.1 PE for Solaris 9 and 10 only.
• Sun Java System Web Server 6.1 and 7.0
Note
Vendor supports Sun Java System Web Server 6.1 for Solaris 8 and 9 only.
Note
Vendor supports Sun Java System Web Server 7.0 for Solaris 10 only.
Application servers are not supported on versions of Solaris which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Solaris.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
IBM AIX
Note
To run JProbe successfully on this platform, you need to ensure that the machine that
JProbe runs on has the required AIX level and fixes to run the IBM Java 6 JRE used by the
JProbe Console.
System Requirements
You need the following minimum system requirements:
• IBM AIX version 5.3 or 6.1
Note
JProbe on AIX require libC version 6, available from fileset xlC.aix50.rte version
6.0.0.0.
20 JProbe
Installation Guide
• IBM Power PC processor
• 2 GB RAM
• 200 MB free disk space
Supported JVMs
The following development kits contain a supported JVM:
• IBM 32-bit SDK for AIX, Java 2 Technology Edition, Version 1.4.2 SR1 or later, plus patches
Note
IBM JDK 1.4.x is not fully supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can take memory snapshots without a heap dump. You can also import an IBM text heap dump.
Note
IBM requires that you install AIX patches to run Java correctly. Patches should be automatically installed when you install a supported IBM Developer Kit.
• IBM 32-bit SDK for AIX, Java 2 Technology Edition, Version 5 or later
Note
This version requires at least AIX 5L 5.3.0.30.
• IBM 32-bit SDK for AIX, v5. Java Technology Edition, Version 6
• IBM 64-bit SDK for AIX, Java 2 Technology Edition, Version 1.4.2
• IBM 64-bit SDK for AIX, Java 2 Technology Edition, Version 5
• IBM 64-bit SDK for AIX, v5. Java Technology Edition, Version 6
Validated Application Servers
At time of release, the following application servers are tested and supported:
• Apache Tomcat 5.0, 5.5, and 6.0
• BEA WebLogic Server 9.2 and 10.0
• IBM WebSphere Application Server 6.0.1+, 6.1, and 7.0
Note
IBM WebSphere Application Server 7.0 requires AIX 6.1 with Recommended
Maintenance package 6100-00-04, or AIX 5L 5.3 with Service Pack 5300-07-01.
• IBM WebSphere Portal Server 6.1
Note
IBM WebSphere Portal Server 6.1 requires AIX V6.1 with Service Pack 4, or AIX
V5L V5.3 with Service Pack 5300-04-01.
• JBoss 4.x and 5.x
Chapter 1: Supported Platforms
Linux x86
21
Application servers are not supported on versions of AIX which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of AIX.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
Linux x86
System Requirements
You need the following minimum system requirements:
Note
While Quest Software only supports some versions of Linux, JProbe should work with any Linux distribution that includes glibc 2.3.4 or later.
• One of the following OS systems:
• Red Hat Enterprise Linux (RHEL) 4.0, 5.0, 5.1, 5.2, and 5.3
• Novell SUSE Linux Enterprise Server (SLES) 9.0, 10.0, and 10.3
• CentOS 5.x
• Intel ia32 (x86) architecture machine
• 2 GB RAM
• 256 MB free disk space
Novell SUSE Linux Enterprise Server (SLES)
The following sections list the supported Java developer kits and application servers for
SLES 9.0, 10.0, and 10.3.
Supported JVMs
• JRockit 1.4.2
• JRockit 5.0
• JRockit 6.0
• Sun Java 2 SDK, Standard Edition, 1.4.2 or later
22 JProbe
Installation Guide
• Sun J2SE Development Kit 5.0 plus patches
Note
You can find patches on the Sun Microsystem Web site:
java.sun.com
.
• Sun Java Platform, Standard Edition 6
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 1.4.2, SR1 or later
Note
IBM JDK 1.4.2 is not supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can import an IBM heap dump.
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 5
• IBM 32-bit SDK for Linux on Intel architecture, Java Technology Edition,
Version 6
Validated Application Servers
• Apache Geronimo 2.0.1 and 2.1
• Apache Tomcat 5.0, 5.5, and 6.0
• BEA WebLogic Server 8.1, 9.2, and 10.0
• IBM WebSphere Application Server 6.0.1+, 6.1, and 7.0
Note
IBM WebSphere Application Server 7.0 requires at least SLES 9 SP4 or SLES 10 update 1.
• JBoss 4.0.x, 4.2.x, and 5.x
• Oracle OC4J 10g 10.1.2 and 10.1.3.x
• Oracle Application Server 10g 10.1.3
• Oracle WebLogic Server 10.3
Application servers are not supported on versions of Linux which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Linux.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
Chapter 1: Supported Platforms
Linux x86
23
Red Hat Enterprise Linux
The following sections list the supported Java developer kits and application servers for
RHEL 4.0 and 5.x.
Supported JVMs
• JRockit 1.4.2
• JRockit 5.0
• Sun Java 2 SDK, Standard Edition, 1.4.2 or later
• Sun J2SE Development Kit 5.0 plus patches
Note
You can find patches on the Sun Microsystem Web site:
java.sun.com
.
• Sun Java Platform, Standard Edition 6
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 1.4.2, SR1 or later
Note
IBM JDK 1.4.2 is not supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can import an IBM heap dump.
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 5
• IBM 32-bit SDK for Linux on Intel architecture, Java Technology Edition,
Version 6
Validated Application Servers
• Apache Geronimo 2.0.1 and 2.1
• Apache Tomcat 5.0, 5.5, and 6.0
• BEA WebLogic Server 8.1, 9.2, and 10.0
Note
Vendor supports BEA WebLogic Server version 9.2 for Red Hat Enterprise Linux only.
• BEA WebLogic Server Portal Server 9.2
Note
Vendor supports this version for Red Hat Enterprise Linux only.
• IBM WebSphere Application Server Community Edition 2.0 and 2.1
• IBM WebSphere Application Server 6.0.1+, 6.1, and 7.0
Note
IBM WebSphere Application Server 7.0 requires at least RHEL 4 Update 6 or RHEL
5 update 1.
24 JProbe
Installation Guide
• JBoss 4.0.x, 4.2.x, and 5.x
• Open Source GlassFish v2 UR2
• Oracle OC4J 10g 10.1.2 and 10.1.3
• Oracle Application Server 10g 10.1.3.x
• Oracle WebLogic Server 10.3
• Sun Java System Application Server 9.0 PE and 9.1
Note
Vendor supports Sun Java System Application Server 9.0 PE for Red Hat Enterprise
Linux only.
Application servers are not supported on versions of Linux which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Linux.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
CentOS 5.x
The following sections list the supported Java developer kits and application servers for
CentOS 5.x.
Supported JVMs
• JRockit 1.4.2
• JRockit 5.0
• Sun Java 2 SDK, Standard Edition, 1.4.2 or later
• Sun J2SE Development Kit 5.0 plus patches
Note
You can find patches on the Sun Microsystem Web site:
java.sun.com
.
• Sun Java Platform, Standard Edition 6
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 1.4.2, SR1 or later
Note
IBM JDK 1.4.2 is not supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can import an IBM heap dump.
• IBM 32-bit SDK for Linux on Intel Architecture, Java 2 Technology Edition,
Version 5
Chapter 1: Supported Platforms
Linux EM64T/AMD64
25
• IBM 32-bit SDK for Linux on Intel architecture, Java Technology Edition,
Version 6
Validated Application Servers
• Apache Geronimo 2.0.1 and 2.1
• Apache Tomcat 5.0, 5.5, and 6.0
• JBoss 4.0.x, 4.2.x, and 5.x
Application servers are not supported on versions of Linux which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Linux.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
Linux EM64T/AMD64
System Requirements
You need the following minimum system requirements:
• One of the following OS systems:
• Red Hat Enterprise Linux (RHEL) AS 4.0 or 5.x
Note
While Quest Software only supports some versions of Linux, JProbe should work with any Linux distribution that includes glibc 2.3.4 or later. 32-bit compatibility libraries may also need to be installed.
• SUSE Linux Enterprise Server (SLES) 9.0 or 10.0
Note
While Quest Software only supports some versions of Linux, JProbe should work with any Linux distribution that includes glibc 2.3.4 or later. 32-bit compatibility libraries may also need to be installed.
• CentOS 5.x
• 2 GB RAM
• 200 MB free disk space
26 JProbe
Installation Guide
Supported JVMs
• JRockit 1.4.2
• JRockit 5.0
• IBM 64-bit SDK for Linux on Intel, Java 2 Technology Edition, Version 1.4.2,
SR1 or later
Note
IBM JDK 1.4.2 is not supported with Memory due to severe problems with the heap dump provided by the JVM profiling interface (JVMPI). Workaround: You can import an IBM heap dump.
• IBM 64-bit SDK for Linux on AMD64/EM64T, Java 2 Technology Edition,
Version 5.0
• IBM 64-bit SDK for Linux on AMD64/EM64T, Java Technology Edition,
Version 6
• Sun Java 2 SDK, Standard Edition, 1.4.2 or later
• Sun J2SE Development Kit 5.0 for Linux 64-bit AMD64/EM64T Processors plus patches
Note
You can find patches on the Sun Microsystem web site:
java.sun.com
. Support for
AMD64 / EM64T 64-bit mode for Linux was introduced in J2SE 5.0 Update 2. Before
Update 2, J2SE 5.0 supported AMD Opteron (64) Linux.
Validated Application Servers
At time of release, the following application servers are tested and supported:
• Apache Tomcat 5.5 and 6.0
• BEA WebLogic Server 9.2 and 10.0
Note
Vendor supports BEA WebLogic Server 9.2 version for Red Hat Enterprise Linux only.
• IBM WebSphere Application Server 6.1 and 7.0
Note
IBM WebSphere Application Server 7.0 requires at least RHEL 5 Update 1 or SLES
10 Update 1.
• JBoss 5.x
• Oracle Application Server 10g 10.1.3.x
• Oracle WebLogic Server 10.3
Chapter 1: Supported Platforms
Linux EM64T/AMD64
27
Application servers are not supported on versions of Linux which are not officially supported by the application server vendor. Listed application servers may not be tested on every supported version of Linux.
In some cases, additional versions of the validated platforms are also supported, however these are typically older releases which are not formally validated. Other application servers may be available on request.
28 JProbe
Installation Guide
2
Installing JProbe
This chapter contains the following sections:
30 JProbe
Installation Guide
Before You Begin
Before you begin the installation, review the following steps:
1
2
Locate your license number for JProbe. If you downloaded the software from the
Quest Software web site, the license number was mailed to the email address you specified. If you received a product CD, the license number is on the product packaging.
Ensure that you can run use cases/test cases on your application without JProbe installed. JProbe can help you diagnose programming inefficiencies, but it cannot help with issues related to how your application or application server is set up within your environment.
3
4
Note
You may need to install a supported Java Virtual Machine.
You are now ready to install JProbe.
Preview of the Installed Directory Structure
The following diagram shows the directory structure for the installed JProbe. The current version number (in the form #.#.#) is included as part of the installed directory name.
Chapter 2: Installing JProbe
Where to Install JProbe
31
JProbe #.#.# automation bin config demos doc lib modules
src
Uninstall
Installation log
Ant build files for running automated sessions
Program executables and supporting files
License file, configurations files
Analysis tool-specific J2EE and J2SE examples
Guides, Release Notes, and license text
JAR files including online help
Supported application servers
Source code for third-party open source JARs
Uninstall JProbe
Where to Install JProbe
Start by running the installer on the computer where your application resides. Both the
JProbe Engine and JProbe Console are installed. If you are running only local sessions, you are done.
If you want to run your application and the JProbe Analysis Engine on one computer and monitor it from another computer (for example, your workstation), you also need to install JProbe on the second computer. The second computer does not have to run the same operating system as the first. In fact, many remote sessions are heterogeneous, with the application under analysis running on a UNIX system while the JProbe
Console runs on Windows. You can choose to use the JProbe Console from either computer, though not simultaneously.
Installing JProbe Using the GUI Installer
You can run the GUI version of the installer on Windows or UNIX systems, as long as you have a graphical display available. After you start the installer, follow the on-screen instructions. You can add your license at the end of the installation or you can wait until you launch JProbe for the first time.
32 JProbe
Installation Guide
To install the JProbe from a GUI:
1
2
3
Ensure you have administrator privileges for your operating system.
Do one of the following:
• If you have a product CD, insert the CD into a CD-ROM drive on your system.
On Windows platforms, if autorun is enabled for the CD-ROM drive, the setup program runs automatically. Otherwise, open the CD, browse to your platform, and then double-click the installer.
• If you downloaded the product from the Quest Software web site, navigate to the directory where you saved the downloaded file and double-click the installer file.
Follow the on-screen instructions. You need to agree to the license agreement before you can install the product.
4
At the end of the installation, you can set up your license. If you do not set up your license now, you are prompted to do so when you launch JProbe. For
information on types of licensing models and how to get licenses, see “ Licensing
The installation is complete. Click Done to exit the installer.
5
6
7
If errors were reported, check the installation log located in your installation directory.
Review the JProbe Release Notes for what’s new in this release and known issues. It is located in the <jprobe_home>/docs directory.
8
To configure your application to work with JProbe, see the JProbe User Guide.
Chapter 2: Installing JProbe
Installing JProbe from the Command Line
33
Installing JProbe from the Command Line
If you do not have a graphical display available on your system, you can install JProbe from the command line. UNIX system users can use the following procedure or request
TAR install files from Quest Support. For more information, see “ Contacting Quest
Note
For a list of arguments for this installer, include the argument:
-?
. Because the question mark is a special character in csh and derived shells, you may need to use "-?", '-?', or -\?
instead.
To install JProbe from the command line:
1
2
Ensure you have administrator privileges for your operating system.
3
4
Navigate to the directory where the JProbe installer is located.
Run the installer for your platform:
•
UNIX:
./jprobe810_install.bin -i console
• Windows:
jprobe810_install
You need to agree to the license agreement before installing the product.
Follow the on-screen prompts.
5
6
7
If errors are reported when the installer finishes, check the installation log located in your installation directory.
You can set up your license now or when you launch JProbe. For information on
types of licensing models and how to get licenses, see “ Licensing JProbe ” on page 35.
8
9
Review the JProbe Release Notes for what’s new in this release and known issues. It is located in the <jprobe_home>/docs directory.
To configure your application to work with JProbe, see the JProbe User Guide.
34 JProbe
Installation Guide
Installing JProbe Silently from the Command Line
You can choose to install JProbe with no user interaction. You specify the installation directory on the command line.
Note
For a list of arguments for this installer, include the argument:
-?
. Because the question mark is a special character in csh and derived shells, you may need to use "-?", '-?', or -\?
instead.
To install JProbe silently from the command line:
1
2
Ensure you have administrator privileges for your operating system.
Read and agree to the JProbe license agreement. The license is located at
www.quest.com/jprobe/
under the Review licensing info link.
Navigate to the directory where the JProbe installer is located.
3
4
Run the installer for your platform using the following syntax:
UNIX:
./jprobe810_install.bin -i silent -DUSER_INSTALL_DIR=<dir>
Windows:
jprobe810_install -i silent -DUSER_INSTALL_DIR=<dir> where
dir
is the directory where you want to install JProbe. If you omit the final argument, JProbe is installed to your user home directory on UNIX systems or
c:\Program Files on Windows systems.
5
6
If errors are reported when the installer finishes, check the installation log located in your installation directory.
You can set up your license now or when you launch JProbe. For information on
types of licensing models and how to get licenses, see “ Licensing JProbe ” on page 35.
7
8
Review the JProbe Release Notes for what’s new in this release and known issues. It is located in the <jprobe_home>/docs directory.
To configure your application to work with JProbe, see the JProbe User Guide.
3
Licensing JProbe
This chapter contains the following sections:
36 JProbe
Installation Guide
JProbe License Options
There are three types of licensing models available: node-locked, concurrent, and enterprise. For more information, review the JProbe licensing options on the Quest web site at:
http://www.quest.com/jprobe/licensing_info.aspx.
Node-Locked Licensing
A node-locked license allows JProbe to run on a predefined set of computers. The standard license is for a single developer. The license file contains the licensed host name and operating system, the type of license (purchase or evaluation), and the JProbe name, version, and license number. For evaluation (or leased) software, it also contains
the evaluation expiry date. For more information, see “ Requesting Node-Locked
Concurrent Licensing
Concurrent licensing offers flexibility in where JProbe is installed and who may use the product. Instead of having one node-locked license per developer, you purchase a number of licenses that are shared by the entire team via the Quest Software License
Server.
Note
Concurrent licensing is not available with evaluation versions of JProbe.
When you launch JProbe, the product checks to see if a license is available from the
License Server. If so, you can use the product; if not, you need to try again later. If developers consistently have trouble obtaining a license, you can increase the number of
licenses by contacting Quest Software. For more information, see “ Using Concurrent
Enterprise Licensing
Enterprise licensing allows your entire development team to use JProbe. This option is not covered in this guide. For more information, contact your Sales representative.
Chapter 3: Licensing JProbe
Requesting Node-Locked Licenses
37
Requesting Node-Locked Licenses
You can obtain a node-locked license while installing JProbe, or you can skip this step and request a license when you launch JProbe. Alternatively, you can go to the Quest
Software SupportLink web site and request your license.
Requesting a License During Installation or from Within JProbe
This procedure assumes that you are working from the computer where your application and JProbe are installed, and that this computer has a graphical display and a connection to the Internet. When you request a license file, your hostname and number of CPUs is sent to Quest Software. This information is required for the license file.
Note
If the computer you want to license does not have Internet access, or if you want to request
If you want to run remote sessions, specify the second host name when the License
Details web site is displayed. The second host can only run the JProbe Console for the product, not the JProbe Analysis Engine. After you receive the license file, you register the same license file on both computers.
To request a node-locked license:
1
On the computer running your application and the JProbe Engine, do one of the following:
2
• To request the license while installing JProbe, select the Node Locked
Licenses tab in the Licensing Setup installation screen.
• To request the license after installation, launch JProbe and select the Node
Locked Licenses tab in the Manage JProbe Licenses dialog box.
Click Obtain License.
You are advised that your hostname and number of CPUs will be sent to Quest
Software. If you agree to transfer this information, continue with this procedure.
Otherwise, see “ Requesting a License via SupportLink ” on page 38
.
3
Click OK.
Your default browser opens. If the Quest Software license page does not display, ensure that cookies are enabled in your browser and try again.
4
Follow the instructions on the web site to request your license.
38 JProbe
Installation Guide
5
• If you are not subscribed, complete the subscription details.
• If someone else in your organization has subscribed with this license number, you may not be able to license JProbe on your computer.
• If you want to run remote sessions, be sure to add the host name of the second computer when prompted.
Tip
To find the host name of a computer, enter hostname in a command prompt or xterm session.
After you complete the instructions on the web site, your JProbe license file is sent to your email address. Save the license file to your computer.
6
Now you can register the node-locked license. See “ Registering a License During
Installation or from Within JProbe ” on page 39.
Requesting a License via SupportLink
You can request a JProbe license file using any computer that has Internet access. Go to the Get JProbe License page (URL below) and follow the online instructions. If the person who will be using this copy of JProbe has not subscribed, you need to complete the subscription details before you can receive a license file.
Alternatively, instead of following this procedure, you can contact Quest to request a
license file. For more information, see “ Contacting Quest Support ” on page 12.
To request a node-locked license:
1
2
3
Go to SupportLink at
http://support.quest.com
.
Select License Keys.
Follow the instructions on the web site to request your license.
• If you are not subscribed, complete the subscription details.
• If someone else in your organization has subscribed with this license number, you may not be able to license JProbe on your computer.
• When prompted, enter the host name of the computer running your application.
• If you want to run remote sessions, add the host name of the second computer from which you want to monitor JProbe sessions and review the collected data.
Tip
To find the host name of a computer, enter hostname in a command prompt or xterm session.
Chapter 3: Licensing JProbe
Registering Node-Locked Licenses
39
4
After you complete the instructions on the web site, your JProbe license file is mailed to the subscribed person’s email address. Save the license file to your computer.
5
Now you can register the node-locked license. See “ Registering a License During
Installation or from Within JProbe ” on page 39.
Registering Node-Locked Licenses
You can register a node-locked license while installing JProbe, or you can skip this step and register a license when you launch JProbe. Alternatively, you can run a command line tool to register JProbe.
Registering a License During Installation or from Within JProbe
This procedure walks you through registering a license file on the computer or computers named in the license file. It assumes that the computer has a graphical
display. If not, a command line utility is also available. For more information, see
“ Registering Licenses from the Command Line ” on page 41.
To register node-locked licenses:
1
On the computer running your application and the JProbe Engine, do one of the following:
2
• To register the license while installing JProbe, select the Node Locked
Licenses tab in the Licensing Setup installation screen.
• To register the license after installation, launch JProbe and select the Node
Locked Licenses tab in the Manage JProbe Licenses dialog box.
Click Add License, navigate to and select the saved license file, and click Open.
The license is installed to JPROBE_HOME/config/jprobe.licenses. Some of the details of the license are displayed in the table.
40 JProbe
Installation Guide
3
To view all the license details, select the license and click View.
The License Properties dialog opens with the details displayed.
4
5
Click OK to close the License Properties dialog box.
To save a back up of your license file in case you ever need to reinstall JProbe, click Save.
6
To end the license registration process, do one of the following:
• From the Licensing Setup installation screen, click Next.
• From the Manage JProbe Licenses dialog, click Close.
7
For a remote setup, go to the other computer that you specified when requesting the license file and repeat this procedure. If the license file is not accessible from the other computer, use FTP to put a copy of the license on the second computer.
8
You can now use JProbe.
Chapter 3: Licensing JProbe
Using Concurrent Licenses
41
Registering Licenses from the Command Line
You use the jplicense
utility to register node-locked licenses. You can also use this utility to list, view, replace, and delete licenses. For more information, see the JProbe
Reference Guide.
Note
To register node-locked licenses from the command line:
1
2
3
On the computer running your application and JProbe, open a command prompt.
Navigate to the JPROBE_HOME/bin directory.
To add one or more node-locked licenses, use the following syntax:
4
5
•
Windows:
jplicense add <license_file> [<license_file>...]
•
UNIX:
./jplicense add <license_file> [<license_file>...] where
license_file
is the fully qualified path to the JProbe license file(s).
To extract a node-locked license as a backup in case you need to reinstall JProbe, use the following syntax:
•
Windows:
jplicense extract <serial_number> <license_file>
•
UNIX:
./jplicense extract <serial_number> <license_file> where
serial_number
is the license to extract and
license_file
is the fully qualified path to the file where you want to save the extracted license. To get a list of serial numbers, use jplicense list
.
You can now use JProbe.
Using Concurrent Licenses
Concurrent licensing means that multiple people can start simultaneous JProbe analysis sessions on the same application. Each concurrent license permits a developer to run a
JProbe Analysis Engine and a JProbe Console. Two people cannot connect JProbe
Consoles to the same instance of a JProbe analysis session; a separate instance of the application is run under JProbe for each concurrent user.
Concurrent licenses are managed automatically. If you attempt to use JProbe while all licenses are in use, you are notified. You need to wait for an available license. If this
42 JProbe
Installation Guide
occurs frequently, you may want to contact Quest Software to increase your number of licenses.
The following procedures assume that you have completed these tasks:
Task Help on Task
1 Purchased JProbe for the operating system that your application runs on and asked for concurrent licensing.
To order, contact [email protected]
2 Downloaded the Quest Software
License Server from the Web page specified in the confirmation email that you received, and specified the host name and OS of the network server where it will run.
To download the License Server, follow the instructions in the confirmation email, the License Details Web page, and the License Server download Web page. You will be emailed your license file.
3 Installed and started the License Server on the network server you specified.
To install the License Server, run licensing <version>-platform
.
For example, questlicensing4.2.3-lnx.bin
.
To start the License Server, follow the instructions in the License Server documentation.
4 Added the license file to the License
Server via its Web interface. The license file was mailed to the email address provided when you downloaded the
License Server.
To open the home page for the License
Server, see the Readme file. To add a license, follow the on-screen instructions.
Tip
You can also launch the Web interface from the JProbe Concurrent Licenses tab by selecting View License Usage.
5 Installed JProbe on the computer that runs your application.
See “ Installing JProbe ” on page 29.
6 Installed JProbe on each of the developers’ workstations.
See “ Installing JProbe ” on page 29.
7 Ensured that all computers have access to the server running the License Server.
For help with network issues, see your
System Administrator.
Chapter 3: Licensing JProbe
Using Concurrent Licenses
43
Setting the License Server During Installation or from Within
JProbe
This procedure assumes that you are working from the computer running your application and the JProbe Analysis Engine. If you do not have a graphical display, see
“ Setting the License Server from the Command Line ” on page 43.
To set the license server for concurrent licensing:
1
2
On the computer running your application and the JProbe Analysis Engine, do one of the following:
• To set the license server while installing JProbe, select the Concurrent
Licenses tab in the Licensing Setup installation screen.
• To set the license server after installation, launch JProbe and select the
Concurrent Licenses tab in the Manage JProbe Licenses dialog box.
Type the fully qualified host name or IP address of the computer running the
License Server in the License Server Hostname field.
3
Click Test Server.
A message tells you whether or not the computer is available.
4
5
To set the specified host as your license server, click Set Server.
To view your license and the licenses currently in use, click View License Usage.
6
• The License Server home page opens in your default browser.
• For details on each screen, click the Help link.
• To close the License Server web interface, close your browser.
To end the license registration process, do one of the following:
7
8
• From the Licensing Setup installation, click Next.
• From the Manage JProbe Licenses dialog, click Close.
Repeat on each of the developer workstations.
You can run JProbe if a concurrent license available.
Setting the License Server from the Command Line
44 JProbe
Installation Guide
To set the license server for concurrent licensing from the command line:
1
2
3
From a command prompt, navigate to the JPROBE_HOME/bin directory.
To test that the license server is available, enter:
•
Windows:
jplicense test <license_server> <port> <application>
•
UNIX:
./jplicense test <license_server> <port> <application> where
license_server
is the name of the server running the Quest Software
License Server,
port
is the port number that the license server listens on, and
application
is the licensing application name. For example: jplicense test serve_lics 8133 licensing
To set the license server, use the following syntax:
Windows:
jplicense server <license_server> <port> <application>
UNIX:
./jplicense server <license_server> <port> <application> where
license_server
is the host running the Quest Software License Server,
port
is the port number that the license server listens on, and
application
is the licensing application name.
4
5
Repeat on each of the developer workstations.
You can run JProbe if a concurrent license available.
Index
A
about JProbe
about Quest Software
AMD64/EM64T
C
Cent OS 5.x
command line
installing
licensing
silent install
concurrent license
overview
using
contacting Quest
D
directory structure
documentation
core
feedback
suite
E
enterprise license
I
IBM AIX
install
from command line
from command line silently
from GUI
location
overview
prerequisites
installed directory structure
J
JVM support, policy for
L
license
options
overview
requesting
license server, setting
during installation
from command line
from JProbe
Linux 64-bit
Linux x86
M
Microsoft Windows
46 JProbe
Installation Guide
N
NLES
node-locked license
overview
registering
requesting
Novell Linux Enterprise Server
P
policies
R
Red Hat Enterprise Linux
remote environment
RHEL
S
setting license server
during installation
from command line
from JProbe
silent install
Sun Solaris
support
support policies
supported platforms
SupportLink, requesting a license
T
technical support
text conventions
* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
