Samsung 2252W - Printer - B/W User`s guide

Samsung 2252W - Printer - B/W User`s guide
This manual is provided for information purposes only. All information included herein
is subject to change without notice. Samsung Electronics is not responsible for any
changes, direct or indirect, arising from or related to the use of this manual.
© 2004 Samsung Electronics Co., Ltd. All rights reserved.
• ML-2250, ML-2251N, ML-2252W and Samsung logo are trademarks of Samsung
Electronics Co., Ltd.
• PCL and PCL 6 are trademarks of Hewlett-Packard company.
• IBM and IBM PC are trademarks of International Business Machines Corporation.
• Microsoft, Windows, Windows 9x, Windows Me, Windows 2000, Windows NT and
Windows XP are registered trademarks of Microsoft Corporation.
• PostScript 3 is a trademark of Adobe System, Inc.
• All other brand or product names are trademarks of their respective companies or
organisations.
i
Contact SAMSUNG WORLD
WIDE
If you have any comments or questions regarding Samsung products, contact
the SAMSUNG customer care center.
Country
ii
Customer Care Center
Web Site
CANADA
1-800-SAMSUNG (7267864)
www.samsung.com/ca
MEXICO
01-800-SAMSUNG
(7267864)
www.samsung.com/mx
U.S.A
1-800-SAMSUNG (7267864)
www.samsung.com
ARGENTINE
0800-333-3733
www.samsung.com/ar
BRAZIL
0800-124-421
www.samsung.com/br
CHILE
800-726-7864 (SAMSUNG)
www.samsung.com/cl
COSTA RICA
0-800-507-7267
www.samsung.com/latin
ECUADOR
1-800-10-7267
www.samsung.com/latin
EL SALVADOR
800-6225
www.samsung.com/latin
GUATEMALA
1-800-299-0013
www.samsung.com/latin
JAMAICA
1-800-234-7267
www.samsung.com/latin
PANAMA
800-7267
www.samsung.com/latin
PUERTO RICO
1-800-682-3180
www.samsung.com/latin
REP.
DOMINICA
1-800-751-2676
www.samsung.com/latin
TRINIDAD &
TOBAGO
1-800-7267-864
www.samsung.com/latin
VENEZUELA
1-800-100-5303
www.samsung.com/latin
BELGIUM
02 201 2418
www.samsung.com/be
CZECH
REPUBLIC
844 000 844
www.samsung.com/cz
DENMARK
38 322 887
www.samsung.com/dk
FINLAND
09 693 79 554
www.samsung.com/fi
FRANCE
08 25 08 65 65
(€ 0,15/min)
www.samsung.com/fr
GERMANY
01805 - 121213
(€ 0,12/min)
www.samsung.de
Country
Customer Care Center
Web Site
HUNGARY
06 40 985 985
www.samsung.com/hu
ITALIA
199 153 153
www.samsung.com/it
LUXEMBURG
02 261 03 710
www.samsung.lu
NETHERLANDS
0900 20 200 88
(€ 0,10/min)
www.samsung.com/nl
NORWAY
231 627 22
www.samsung.com/no
POLAND
0 801 801 881
www.samsung.com/pl
PORTUGAL
80 8 200 128
www.samsung.com/pt
SLOVAKIA
0850 123 989
www.samsung.com/sk
SPAIN
902 10 11 30
www.samsung.com/es
SWEDEN
08 585 367 87
www.samsung.com/se
U.K
0870 242 0303
www.samsung.com/uk
RUSSIA
8-800-200-0400
www.samsung.ru
UKRAINE
8-800-502-0000
www.samsung.com/ur
AUSTRALIA
1300 362 603
www.samsung.com/au
800-810-5858
www.samsung.com.cn
CHINA
010- 6475 1880
HONG KONG
2862 6001
www.samsung.com/hk
INDIA
3030 8282
www.samsung.com/in
1600 1100 11
INDONESIA
0800-112-8888
www.samsung.com/id
JAPAN
0120-327-527
www.samsung.com/jp
MALAYSIA
1800-88-9999
www.samsung.com/my
PHILIPPINES
1800-10-SAMSUNG
(7267864)
www.samsung.com/ph
SINGAPORE
1800-SAMSUNG (7267864)
www.samsung.com/sg
THAILAND
1800-29-3232
www.samsung.com/th
02-689-3232
TAIWAN
0800-329-999
www.samsung.com/tw
VIETNAM
1 800 588 889
www.samsung.com/vn
SOUTH AFRICA
0860 7267864 (SAMSUNG)
www.samsung.com/za
U.A.E
800SAMSUNG (7267864)
www.samsung.com/mea
iii
CONTENTS
Chapter 1:
INTRODUCTION
Special Features .................................................. 1.2
Printer Components ............................................. 1.5
Front View ..................................................... 1.5
Rear View ...................................................... 1.6
Understanding the Control Panel ............................ 1.7
On Line/Error and Toner Save LEDs ................... 1.7
Cancel button ................................................. 1.8
Chapter 2:
SETTING UP YOUR PRINTER
Unpacking .......................................................... 2.2
Selecting a Location ........................................ 2.3
Installing the Toner Cartridge ................................ 2.4
Loading Paper ..................................................... 2.7
Changing the Paper Size in the Paper Tray ......... 2.9
Connecting a Printer Cable ................................... 2.11
For Local Printing ........................................... 2.11
For Network Printing ...................................... 2.13
Turning the Printer On ......................................... 2.15
Printing a Demo Page .......................................... 2.16
Installing Printer Software ...................................
Printer Driver Features ...................................
Installing Printer Software in Windows ..............
Changing the Display Language .......................
Reinstalling Printer Software ...........................
Removing Printer Software ..............................
2.17
2.18
2.19
2.21
2.22
2.23
Viewing the User’s Guide ..................................... 2.24
iv
Chapter 3:
USING PRINT MATERIALS
Choosing Paper and Other Materials ....................... 3.2
Sizes and Capacities ....................................... 3.3
Guidelines for Paper and Special Materials .......... 3.4
Selecting the Output Location ................................ 3.5
Printing to the Top Output Tray (Face down) ...... 3.5
Printing to the Rear Output Tray (Face up) ......... 3.6
Loading Paper ..................................................... 3.7
Using Tray1 or the Optional Tray2 ..................... 3.8
Using the Multi-Purpose Tray ............................ 3.8
Using the Manual Feed Mode ........................... 3.12
Printing on Envelopes .......................................... 3.14
Printing on Labels ............................................... 3.17
Printing on Transparencies ................................... 3.19
Printing on Card Stock or
Custom-sized Materials ....................................... 3.21
Printing on Preprinted Paper ................................. 3.23
Chapter 4:
PRINTING TASKS
Printing a Document ............................................
Cancelling a Print Job ......................................
Using a Favorite Setting ..................................
Using Help .....................................................
4.2
4.5
4.6
4.6
Setting Paper Properties ....................................... 4.7
Using the Toner Save Mode ................................... 4.9
Printing Multiple Pages on One
Sheet of Paper (N-Up Printing) ............................. 4.11
Printing a Reduced or Enlarged Document .............. 4.12
Fitting Your Document to a Selected Paper Size ...... 4.13
Printing Posters .................................................. 4.14
Using Watermarks ..............................................
Using an Existing Watermark ...........................
Creating a Watermark ....................................
Editing a Watermark ......................................
Deleting a Watermark ....................................
4.15
4.15
4.16
4.17
4.17
Using Overlays ...................................................
What is an Overlay? .......................................
Creating a New Page Overlay ..........................
Using a Page Overlay .....................................
Deleting a Page Overlay .................................
4.18
4.18
4.18
4.20
4.21
v
Setting Graphic Properties ................................... 4.22
Using Output Options .......................................... 4.25
Using the Status Monitor .....................................
Installing Status Monitor .................................
Reinstalling Status Monitor ..............................
Removing Status Monitor ................................
Opening the Troubleshooting Guide ..................
Changing the Status Monitor Program Setting ....
4.26
4.26
4.27
4.27
4.27
4.28
Setting Up a Locally Shared Printer ....................... 4.29
In Windows 9x/Me ......................................... 4.29
In Windows NT 4.0/2000/XP ........................... 4.30
Chapter 5:
MAINTAINING YOUR
PRINTER
Maintaining the Toner Cartridge ............................. 5.2
Redistributing Toner ........................................ 5.3
Replacing the Toner Cartridge .......................... 5.5
Cleaning the Printer ............................................. 5.5
Cleaning the Outside ....................................... 5.5
Cleaning the Inside ......................................... 5.5
Printing Configuration Pages ................................. 5.8
Consumables and Replacement Parts ..................... 5.9
Chapter 6:
SOLVING
PROBLEMS
Troubleshooting Checklist ..................................... 6.2
Solving General Printing Problems .......................... 6.3
Clearing Paper Jams ............................................. 6.7
In the Paper Feed Area .................................... 6.7
Around the Toner Cartridge ............................. 6.11
In the Paper Exit Area .................................... 6.12
Tips for Avoiding Paper Jams When Printing
on the A5-sized Paper .................................... 6.13
Tips for Avoiding Paper Jams ........................... 6.14
Solving Print Quality Problems .............................. 6.15
Troubleshooting Error Messages ........................... 6.20
Common Windows Problems ................................ 6.21
Troubleshooting PS Errors .................................... 6.22
Common Linux Problems ..................................... 6.23
vi
Appendix A:
USING WINDOWS POSTSCRIPT DRIVER
Installing PS Drivers ............................................
Installing PS Drivers ........................................
Reinstalling PS Drivers ....................................
Removing PS Drivers .......................................
A.2
A.2
A.3
A.3
Using PS Printer Driver Features ............................ A.4
Accessing Printer Properties ............................. A.4
Appendix B:
USING YOUR PRINTER
IN
LINUX
Installing the Printer Driver ...................................
System Requirements .....................................
Installing the Printer Driver ..............................
Changing the Printer Connection Method ............
Uninstalling the Printer Driver ...........................
B.2
B.2
B.2
B.6
B.7
Using the Configuration Tool ................................. B.8
Changing LLPR Properties .................................... B.10
Appendix C:
PRINTING FROM DOS APPLICATIONS
About the Remote Control Panel ............................ C.2
Installing the Remote Control Panel ....................... C.2
Reinstalling Remote Control Panel ..................... C.3
Removing Remote Control Panel ....................... C.3
Selecting Print Settings ........................................ C.4
Starting the Remote Control Panel .................... C.4
Using the Remote Control Panel Tabs ................ C.5
Appendix D:
INSTALLING PRINTER OPTIONS
Precautions When Installing Printer Options ............ D.2
Installing Memory and PostScript DIMMs ................. D.3
Removing the Memory or PS DIMM ................... D.6
Installing a Network Card ..................................... D.7
Installing an Optional Paper Tray ......................... D.11
vii
Appendix E:
SPECIFICATIONS
Printer Specifications ............................................ E.2
Paper Specifications ............................................. E.3
Overview ....................................................... E.3
Supported Sizes of Paper ................................. E.4
Guidelines for Using Paper ............................... E.5
Paper Specifications ........................................ E.6
Paper Output Capacity ..................................... E.6
Printer and Paper Storage Environment ............. E.7
Envelopes ...................................................... E.8
Labels .......................................................... E.10
Transparencies .............................................. E.10
viii
Important Precautions and Safety Information
When using this machine, these basic safety precautions should always be followed
to reduce risk of fire, electric shock, and injury to people:
1 Read and understand all instructions.
2 Use common sense whenever operating electrical appliances.
3 Follow all warnings and instructions marked on the machine and in the literature
accompanying the machine.
4 If an operating instruction appears to conflict with safety information, heed the
safety information. You may have misunderstood the operating instruction. If
you cannot resolve the conflict, contact your sales or service representative for
assistance.
5 Unplug the machine from the AC wall socket before cleaning. Do not use liquid or
aerosol cleaners. Use only a damp cloth for cleaning.
6 Do not place the machine on an unstable cart, stand or table. It may fall, causing
serious damage.
7 Your machine should never be placed on, near or over a radiator, heater, air
conditioner or ventilation duct.
8 Do not allow anything to rest on the power cable. Do not locate your machine
where the cords will be abused by persons walking on them.
9 Do not overload wall outlets and extension cords. This can diminish
performance, and may result in the risk of fire or electric shock.
10 Do not allow pets to chew on the AC power or PC interface cords.
11 Never push objects of any kind into the machine through case or cabinet
openings. They may touch dangerous voltage points, creating a risk of fire or
shock. Never spill liquid of any kind onto or into the machine.
12 To reduce the risk of electric shock, do not disassemble the machine. Take it to a
qualified service technician when repair work is required. Opening or removing
covers may expose you to dangerous voltages or other risks. Incorrect
reassembly could cause electric shock when the unit is subsequently used.
ix
13 Unplug the machine from the PC and AC wall outlet, and refer servicing to
qualified service personnel under the following conditions:
• When any part of the power cord, plug, or connecting cable is damaged or
frayed.
• If liquid has been spilled into the machine.
• If the machine has been exposed to rain or water.
• If the machine does not operate properly after instructions have been followed.
• If the machine has been dropped, or the cabinet appears damaged.
• If the machine exhibits a sudden and distinct change in performance.
14 Adjust only those controls covered by the operating instructions. Improper
adjustment of other controls may result in damage, and may require extensive
work by a qualified service technician to restore the machine to normal
operation.
15 Avoid using this machine during a lightning storm. There may be a remote risk of
electric shock from lightning. If possible, unplug the AC power for the duration of
the lightning storm.
16 If you continuously print multiple pages, the surface of the output tray may
become hot. Be careful not to touch the surface, and keep children away from
the surface.
17 SAVE THESE INSTRUCTIONS.
x
Environmental and Safety Consideration
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR,
chapter 1 Subchapter J for Class I(1) laser products, and elsewhere, is certified as a
Class I laser product conforming to the requirements of IEC 825.
Class I laser products are not considered to be hazardous. The laser system and
printer are designed so there is never any human access to laser radiation above a
Class I level during normal operation, user maintenance, or prescribed service
condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/
Scanner assembly. The reflected beam, although invisible, can damage your eyes.
When using this product, these basic safety precautions should always be followed to
reduce risk of fire, electric shock, and injury to persons:
xi
Ozone Safety
During normal operation, this machine produces ozone. The
ozone produced does not present a hazard to the operator.
However, it is advisable that the machine be operated in a well
ventilated area.
If you need additional information about ozone, please contact
your nearest Samsung dealer.
Power Saver
This printer contains advanced energy conservation technology that reduces power
consumption when it is not in active use.
When the printer does not receive data for an extended period of time, power
consumption is automatically lowered.
Recycling
Please recycle or dispose of the packaging material for this
product in an environmentally responsible manner.
Radio Frequency Emissions
FCC regulations
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reposition the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the equipment.
xii
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the interference-causing equipment standard
entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
United States of America
Federal Communications Commission (FCC)
Intentional emitter per FCC Part 15
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your printer
system. This section is only applicable if these devices are present. Refer to the
system label to verify the presence of wireless devices.
Wireless devices that may be in your system are only qualified for use in the United
States of America if an FCC ID number is on the system label.
The FCC has set a general guideline of 20 cm (8 inches) separation between the
device and the body, for use of a wireless device near the body (this does not include
extremities). This device should be used more than 20 cm (8 inches) from the body
when wireless devices are on. The power output of the wireless device (or devices),
which may be embedded in your printer, is well below the RF exposure limits as set
by the FCC.
This transmitter must not be collocated or operated in conjunction with any other
antenna or transmitter.
Operation of this device is subject to the following two conditions:(1) This device may
not cause harmful interference, and(2) this device must accept any interference
received, including interference that may cause undesired operation of the device.
Wireless devices are not user serviceable. Do not modify them in any
way. Modification to a wireless device will void the authorization to use
it. Contact manufacturer for service.
FCC Statement for Wireless LAN use:
“While installing and operating this transmitter and antenna combination
the radio frequency exposure limit of 1mW/cm2 may be exceeded at
distances close to the antenna installed. Therefore, the user must
maintain a minimum distance of 20cm from the antenna at all times.
This device can not be collocated with another transmitter and
transmitting antenna.”
xiii
Declaration of Conformity (European Countries)
Approvals and Certifications
The CE marking applied to this product symbolises Samsung
Electronics Co., Ltd. Declaration of Conformity with the following
applicable 93/68/EEC Directives of the European Union as of the
dates indicated:
January 1, 1995: Council Directive 73/23/EEC Approximation of the laws of the
member states related to low voltage equipment.
January 1, 1996: Council Directive 89/336/EEC (92/31/EEC), approximation of the
laws of the Member States related to electromagnetic compatibility.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and
telecommunications terminal equipment and the mutual recognition of their
conformity.
A full declaration, defining the relevant Directives and referenced standards can be
obtained from your Samsung Electronics Co., Ltd. representative.
EC Certification
Certification to 1999/5/EC Radio Equipment & Telecommunications
Terminal Equipment Directive (FAX)
This Samsung product has been self-certified by Samsung for pan-European single
terminal connection to the analogue public switched telephone network (PSTN) in
accordance with Directive 1999/5/EC. The product has been designed to work with
the national PSTNs and compatible PBXs of European countries.
In the event of problems, you should contact the Euro QA Lab of Samsung Electronics
Co., Ltd. in the first instance.
The product has been tested against TBR21 and/or TBR 38. To assist in the use and
application of terminal equipment which complies with this standard, the European
Telecommunication Standards Institute (ETSI) has issued an advisory document (EG
201 121) which contains notes and additional requirements to ensure network
compatibility of TBR21 terminals. The product has been designed against, and is fully
compliant with, all of the relevant advisory notes contained in this document.
European Radio Approval Information
(for products fitted with EU-approved radio devices)
This Product is a printer; low power, Radio LAN type devices (radio frequency (RF)
wireless communication devices), operating in the 2.4 GHz band, may be present
(embedded) in your printer system which is intended for home or office use. This
section is only applicable if these devices are present. Refer to the system label to
verify the presence of wireless devices.
xiv
Wireless devices that may be in your system are only qualified for use in the
European Union or associated areas if a CE mark
with a Notified Body
Registration Number and the Alert Symbol is on the system label.
The power output of the wireless device or devices that may be embedded in your
printer is well below the RF exposure limits as set by the European Commission
through the R&TTE directive.
European States qualified under wireless approvals:
EU
Accept EU
Austria, Belgium, Denmark, Finland, France (with frequency
restrictions), Germany, Greece, Ireland, Italy, Luxembourg,
The Netherlands, Portugal, Spain, Sweden, and the United Kingdom
Iceland, Liechtenstein, Norway, and Switzerland
European States with restrictions on use:
EU
In France, the frequency range is restricted to 2446.5-2483.5 MHz
for devices above 10 mW transmitting power such as wireless
Accept EU
No limitations at this time.
Regulatory Compliance Statements
Wireless Guidance
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4 GHz Band, may be present (embedded) in your printer
system. The following section is a general overview of considerations while operating
a wireless device.
Additional limitations, cautions, and concerns for specific countries are listed in the
specific country sections (or country group sections). The wireless devices in your
system are only qualified for use in the countries identified by the Radio Approval
Marks on the system rating label. If the country you will be using the wireless device
in, is not listed, please contact your local Radio Approval agency for requirements.
Wireless devices are closely regulated and use may not be allowed.
The power output of the wireless device or devices that may be embedded in your
printer is well below the RF exposure limits as known at this time. Because the
wireless devices (which may be embedded your printer) emit less energy than is
allowed in radio frequency safety standards and recommendations, the manufacturer
believes these devices are safe for use. Regardless of the power levels, care should
be taken to minimize human contact during normal operation.
As a general guideline, a separation of 20 cm (8 inches) between the wireless device
and the body, for use of a wireless device near the body (this does not include
extremities) is typical. This device should be used more than 20 cm (8 inches) from
the body when wireless devices are on and transmitting.
xv
This transmitter must not be collocated or operated in conjunction with any other
antenna or transmitter.
Some circumstances require restrictions in wireless devices. Examples of common
restrictions are listed below:
Radio frequency wireless communication can interfere with equipment
on commercial aircraft. Current aviation regulations require wireless
devices to be turned off while traveling in an airplane. 802.11B (also
known as wireless Ethernet) and Bluetooth communication devices are
examples of devices that provide wireless communication.
In environments where the risk of interference to other devices or
services is harmful or perceived as harmful, the option to use a wireless
device may be restricted or eliminated. Airports, Hospitals, and Oxygen
or flammable gas-laden atmospheres are limited examples where use of
wireless devices may be restricted or eliminated. When in environments
where you are uncertain of the sanction to use wireless devices, ask the
applicable authority for authorization prior to use or turning on the
wireless device.
Every country has different restrictions on the use of wireless devices.
Since your system is equipped with a wireless device, when traveling
between countries with your system, check with the local Radio Approval
authorities prior to any move or trip for any restrictions on the use of a
wireless device in the destination country.
If your system came equipped with an internal embedded wireless
device, do not operate the wireless device unless all covers and shields
are in place and the system is fully assembled.
Wireless devices are not user serviceable. Do not modify them in any
way. Modification to a wireless device will void the authorization to use
it. Please contact manufacturer for service.
Only use drivers approved for the country in which the device will be
used. See the manufacturer System Restoration Kit, or contact
manufacturer Technical Support for additional information.
xvi
xvii
MEMO
xviii
1
INTRODUCTION
Congratulations on the purchase of your printer!
This chapter includes:
• Special Features
• Printer Components
• Understanding the Control Panel
Special Features
Your new printer is equipped with special features that improve
the print quality, giving you a competitive edge. You can:
Print with excellent quality and high speed
• You can print at up to 1200 dpi effective output.
See page 4.22.
• Your printer prints up to 22 pages-per-minute (Letter
size), up to 20 pages-per-minute (A4 size).
Handle paper flexibly
• A 50-sheet Multi-Purpose Tray supports letterhead,
envelopes, labels, transparencies, custom-sized materials,
postcards, and heavy paper.
• Standard 250-sheet input tray (Tray1) and optional
250-sheet input tray (Tray2) supports all standard sizes
of paper.
• Two output tray; select either the top output (facedown) or the rear output tray (face-up) for the most
convenient access.
• Straight-through paper path capability from the
Multi-Purpose Tray to the rear output tray.
Create professional documents
Dear ABC
Regards
WORLD BEST
1.2
INTRODUCTION
• You can customise your documents using Watermarks,
such as “Confidential”. See page 4.15.
• Print Posters. The text and pictures of each page of your
document are magnified and printed across the selected
sheet of paper. After the document has printed, trim off
the white edges of each sheet. Tape the sheets together to
form a poster. See page 4.14.
Save time and money
• This printer allows you to use Toner Save mode to save
toner. See page 4.9.
• You can print multiple pages on one single sheet of paper
to save paper (N-Up printing). See page 4.11.
• Preprinted forms and letterheads can be printed on plain
paper. See “Using Overlays” on page 4.18.
• This printer automatically conserves electricity by
substantially reducing power consumption when not
printing.
Print in various environments
• You can print in Windows 95/98/Me/NT 4.0/2000/XP.
• Your printer is compatible with Linux.
• Your printer comes with both Parallel and USB interfaces.
• You can print in a network environment. The ML-2251N
and ML-2252W come with a built-in network interface, 10/
100 Base TX. The ML-2252W also has a wireless network
interface. However, you need to add the optional network
interface card to the ML-2250 for network printing.
Expand printer capacity
• This printer has 16 MB of memory which can be expanded
to 144 MB.
• An optional PostScript 3 Emulation with 136 fonts (PS)
DIMM adds PS printing.
• Network interface enables network printing. You can add
the optional network interface card to the ML-2250.
The ML-2251N and ML-2252W come with a built-in
network interface, 10/100 Base TX. The ML-2252W also
has a wireless network interface.
* PostScript 3 Emulation
(c) Copyright 1998-2003 Zoran Corporation. All
rights reserved. Zoran, the Zoran logo, IPS/PS3 and
OneImage are trademarks of Zoran Corporation.
* 136 PS3 fonts
Contains UFST and MicroType from Agfa Monotype Corporation.
INTRODUCTION
1.3
1
Printer Features
The table below lists a general overview of features supported
by your printer.
(S: Standard, O: Option)
Features
ML-2250
ML-2251N
ML-2252W
IEEE 1284 Parallel
S
S
S
USB 2.0
S
S
S
Network Interface
(Ethernet 10/100 Base TX)
O
S
S
Wireless LAN
(802.11b Wireless LAN)
O
O
S
PostScript Emulation
O
O
O
1.4
INTRODUCTION
Printer Components
1
Front View
Output Support
Front Cover
Top Output Tray
(Face down)
Control Panel
Control Board
Cover
Toner Cartridge
Tray1
(250-sheet
paper feeder)
Optional Tray 2
(250-sheet paper
feeder)
Multi-Purpose Tray
Power
Switch
Paper Level Indicator
INTRODUCTION
1.5
Rear View
Top Output Tray
(Face down)
Rear Output Tray
(Face up)
Control Board Cover
(Open to install optional
accessories.)
Power
Receptacle
Network Port
(ML-2250:Option
ML-2251N, ML-2252W: Standard)
Wireless Network
Antenna Port
(ML-2250, ML-2251N:Option
ML-2252W:Standard)
USB Port
Parallel Port
Optional Tray2
Cable Connector
*The figure above shows a ML-2252W.
1.6
INTRODUCTION
Understanding the Control Panel
1
On Line/Error and Toner Save LEDs
LED
Description
If the On Line/Error lights green, the printer is ready to
print.
If the On Line/Error lights red, the printer is experiencing
an error, such as jammed paper, no paper, open cover, or
uninstalled toner cartridge. See “Troubleshooting Error
Messages” on page 6.20.
If you press the Cancel button while the printer is receiving
data, the On Line/Error LED blinks red to cancel printing.
In Manual Feed mode, if there is no paper in the Multi-purpose
tray, the On Line/Error LED blinks red. Load paper into the
Multi-purpose tray and the LED stops blinking.
If the printer is receiving data, the On Line/Error LED slowly
blinks green.
If the printer is printing the received data, the On Line/
Error LED blinks green fast.
If you press the Cancel button for 0.5 second in Ready mode,
this LED lights and the Toner Save mode is enabled.
If you press this button once again, this LED turns off and the
Toner Save mode is disabled.
INTRODUCTION
1.7
LED
Description
If the On Line/Error and Toner Save LEDs blink, your
system has some problem. To solve the problem, see
“Troubleshooting Error Messages” on page 6.20.
Cancel button
Function
Printing demo page
Printing configuration
sheets
Description
In Ready mode, press and hold this button for about 2
seconds until all LEDs blink slowly, and release.
In Ready mode, press and hold this button for about 6
seconds until all LEDs blink fast, and release.
If your printer has a network card, the network
configuration sheet prints out with a printer
configuration sheet.
Network card Default
Setting (When you use
the Network card)
In Ready mode, press and hold this button for about
20 seconds until all LEDs blink slowly, and release.
This item restores the factory default of the network
configuration. This setting will only take effect after
you have reset the printer.
Manual Feeding
Press this button each time you load paper in the
Multi-purpose tray, when you have selected Manual
Feed for Source from your software application. For
detailed information, see “Using the Manual Feed
Mode” on page 3.12.
Cleaning inside printer
In Ready mode, press and hold this button for about
10 seconds until all LEDs turn on, and release. After
cleaning the printer, one “cleaning sheet” (see
page 5.7) is printed.
Canceling print job
Press this button during printing. The On Line/Error
LED blinks while the print job is cleared from both the
printer and the computer, and then the printer returns
to Ready mode. This may take some time depending
on the size of the print job.
Toner Save mode on/
off
In Ready mode, press this button to turn the Toner
Save mode on or off.
For detailed information, see “Using the Toner Save
Mode” on page 4.9.
1.8
INTRODUCTION
2
SETTING UP YOUR PRINTER
This chapter provides step by step information on setting up
your printer.
This chapter includes:
• Unpacking
• Installing the Toner Cartridge
• Loading Paper
• Connecting a Printer Cable
• Turning the Printer On
• Printing a Demo Page
• Installing Printer Software
• Viewing the User’s Guide
Unpacking
1 Remove the Printer and all accessories from the packing
carton. Make sure that the printer has been packed with the
following items:
Toner Cartridge
Power Cord
CD-ROM
Quick Install Guide
NOTES:
• If any items are missing or damaged, notify your dealer
immediately.
• Components may differ from one country to another.
• The CD-ROM contains the printer driver, the User’s Guide, and
the Adobe Acrobat Reader programme.
2 Carefully remove all of the packing tape from the printer.
2.2
SETTING UP YOUR PRINTER
Selecting a Location
Select a level, stable place with adequate space for air
circulation. Allow extra space for opening covers and tray(s).
The area should be well-ventilated and away from direct sunlight
or sources of heat, cold, and humidity. See the image below for
clearance space. Do not place the printer close to the edge of
your desk or table.
100 mm
(3.9 in.)
(3.9 in.)
482.6 mm(19 in.)
100 mm
1034.6 mm(40.7 in.)
(3.9 in.)
100 mm
Clearance Space
558 mm(22 in.)
•Front: 482.6 mm (enough space so that tray(s) can be
removed)
•Back: 100 mm (enough space to allow opening of the rear
out tray)
•Right: 100 mm (enough space for ventilation)
•Left: 100 mm
SETTING UP YOUR PRINTER
2.3
2
Installing the Toner Cartridge
1 Grasp the front cover and pull it toward you to open.
NOTE: Because the printer is very light, it may move when you
use it; for example, when opening/closing the tray or installing/
removing the toner cartridge. Be careful not to move the printer.
2 Remove the toner cartridge from its bag and remove the
paper covering the cartridge.
Don’t use a knife or other sharp object as it might scratch
the drum of the cartridge.
2.4
SETTING UP YOUR PRINTER
3 Gently shake the cartridge from side to side to distribute
the toner evenly inside the cartridge.
2
CAUTIONS:
• To prevent damage, do not expose the toner cartridge to light for
more than a few minutes. Cover it with a piece of paper if left
exposed for more than a few minutes and keep it in a flat and
clean place.
• If toner gets on your clothing, wipe it off with a dry cloth and
wash clothing in cold water. Hot water sets toner into fabric.
4 Locate the cartridge slots inside the printer, one on each
side.
SETTING UP YOUR PRINTER
2.5
5 Grasp the handle and insert the cartridge into the printer
until it snaps into place.
6 Close the front cover. Make sure that the cover is securely
closed.
NOTE: When printing text at 5% coverage, you can expect a toner
cartridge life of approximately 5,000 pages.
2.6
SETTING UP YOUR PRINTER
Loading Paper
You can load approximately 250 sheets of paper in the tray.
2
1 Pull the tray out of the printer.
2 Prepare a stack of paper for loading by flexing or fanning
the paper back and forth. Straighten the edges on a level
surface.
3 Load paper with the print side facing down.
SETTING UP YOUR PRINTER
2.7
You can load previously printed paper. The printed side
should be facing up with an uncurled edge on top. If you
experience problems with paper feed, turn the paper
around.
Make sure that all four corners are flat in the tray.
NOTE: If you want to change the paper size in the tray, see
“Changing the Paper Size in the Paper Tray” on page 2.9.
4 Pay attention to the paper limit mark on the left inside wall
of the tray. Paper overloading may cause paper jams.
5 Slide the tray back into the printer.
2.8
SETTING UP YOUR PRINTER
Changing the Paper Size in the Paper Tray
To load longer sizes of paper, you need to adjust the paper
guides to extend the paper tray.
1
2
Pressing and unlatching the guide lock, slide the paper
length guide out completely to extend the paper tray to its
full length.
After inserting paper into the tray, slide in the guide until it
lightly touches the end of the paper stack.
SETTING UP YOUR PRINTER
2.9
2
For the paper smaller than Letter, adjust the front paper
length guide.
3
Pinching the paper width guide as shown, move it toward
the stack of paper until it lightly touches the side of the
stack.
NOTES:
• Do not push the paper width guide far enough to cause the
materials to warp.
• If you do not adjust the paper width guide, it may cause paper
jams.
2.10 SETTING UP YOUR PRINTER
Connecting a Printer Cable
For Local Printing
To print from your computer in a local environment, you need to
connect your printer to the computer with either a parallel
interface cable or a Universal Serial Bus (USB) cable.
Using a Parallel Cable
NOTE: To connect the printer to the parallel port of the computer
requires a certified parallel cable. You will need to buy an
IEEE1284 compliant cable.
1 Make sure that both the printer and the computer are
turned off.
2 Plug the parallel printer cable into the connector on the
back of the printer.
Push the metal clips down to fit inside the notches on the
cable plug.
3 Connect the other end of the cable to the parallel interface
port on your computer, and tighten the screws.
See your computer User’s Guide, if you need help.
SETTING UP YOUR PRINTER 2.11
2
Using a USB Cable
NOTE: Connecting the printer to the USB port of the computer
requires a certified USB cable. You will need to buy a USB 2.0
compliant cable that is within 3 m in length.
1 Make sure that both the printer and the computer are
turned off.
2 Plug the USB printer cable into the connector on the back of
the printer.
3 Connect the other end of the cable to the USB port on your
computer.
See your computer User’s Guide, if you need help.
NOTE: For using a USB cable, you must be running Windows 98/
Me/2000/XP.
2.12 SETTING UP YOUR PRINTER
For Network Printing
You can attach your ML-2251N or ML-2252W printer to a
network using an Ethernet cable (UTP cable with RJ.45
connector).
The ML-2252W also has a network antenna which allows you to
use a wireless LAN interface.
If you are an ML-2250 user, you need to install the optional
network interface card. For an ML-2251N printer, you can
replace the network interface card with one supporting the
wireless LAN interface. For details about installing the card, see
page D.7.
1 Make sure that both the printer and the computer are
turned off.
2 Plug one end of the Ethernet cable into the Ethernet
network port on the Printer.
To the network LAN connection
3 Plug the other end of the cable into a network LAN
connection.
See your computer User’s Guide, if you need help.
SETTING UP YOUR PRINTER 2.13
2
Supported Operating Systems
Item
•
•
•
•
•
Requirements
Network Interface
10/100 Base-TX (standard for ML-2251N
and ML-2252W) or 802.11b Wireless LAN
(standard for ML-2252W)
Network Operating
System
• Novell NetWare 4.x, 5.x, 6.x
• Windows 95/98/Me/NT 4.0/2000/XP
• Unix AT&T, BSD4.3, HP-UX, SUN OS,
SOLARIS, SCO
• Various Linux OS
Network Protocols
• Netware IPX/SPX
• TCP/IP, DLC/LLC on Windows
• Port9100 on Unix, Linux
Dynamic Addressing
Server
• DHCP, BOOTP
IPX/SPX: Internet Packet exchange/Sequenced Packet eXchange
TCP/IP: Transmission Control Protocol/Internet Protocol
DLC/LLC: Data Link Control/Logical Link Control
DHCP: Dynamic Host Configuration Protocol
BOOTP: Bootstrap Protocol
NOTE: After connecting the printer, you need to configure the
network parameters. For information about configuring and using
the printer in a network environment, refer to the User’s Guide
provided with the network interface card.
2.14 SETTING UP YOUR PRINTER
Turning the Printer On
1 Plug the power cord into the power receptacle on the back
of the printer.
2 Plug the other end into a properly grounded AC outlet and
turn on the printer using the power switch.
To the AC outlet
CAUTIONS:
• The fusing area at the rear portion of the inside of your printer is
hot when powered. Be careful not to be burned when accessing
this area.
• Do not disassemble the printer when it is powered. Doing so may
give you an electric shock.
SETTING UP YOUR PRINTER 2.15
2
Printing a Demo Page
Print a demo page to make sure that the printer is operating
correctly.
1 Hold down the Cancel button for about 2 seconds to print a
demo page.
2 A demo page showing the printer’s features and capabilities
prints out.
2.16 SETTING UP YOUR PRINTER
Installing Printer Software
The supplied CD-ROM contains Windows printing software,
Linux printing software, DOS RCP, an on-line User’s Guide and
Acrobat Reader to view the User’s Guide.
If you are printing from Windows:
You can install the following printer software using the CD-ROM.
• Samsung Proprietary printer driver for Windows. Use
this driver to take full advantage of your printer’s features.
See page 2.19.
• PostScript Printer Description (PPD) file for Windows to
allow installation of the PostScript driver. For information
about installing the PostScript driver, refer to Appendix A
in the User’s Guide.
• Status Monitor appears when printing error occurs. See
page 4.26.
• Remote Control Panel for DOS applications.
For information about using the program, refer to
Appendix C in the User’s Guide.
If you are printing in Linux:
For information about installing the Linux driver, refer to
Appendix B in the User’s Guide. To view the User’s Guide, see
page B.2.
SETTING UP YOUR PRINTER 2.17
2
Printer Driver Features
Your printer drivers will support the following standard features:
• Paper source selection
• Paper size, orientation and media type
• number of copies
The table below lists a general overview of features supported
by your printer drivers.
Samsung Proprietary
printer driver
Driver Feature
PostScript
Win
2000/XP
Win 9x
Win
NT4.0
Win
2000/XP
Win 9x
Win
NT4.0
Toner Save
Y
Y
Y
Y
Y
Y
Print quality
option
Y
Y
Y
Y
Y
Y
Poster printing
Y
Y
Y
N
N
N
Multiple pages
per sheet (N-up)
Y
Y
Y
Y
Y
Y
Scale printing
Y
Y
Y
Y
Y
Y
Fit to page
printing
Y
Y
Y
Y
Y
Y
Different source
for first page
Y
Y
Y
N
N
N
Watermark
Y
Y
Y
N
N
N
Overlay
Y
Y
Y
N
N
N
Print order
Y
Y
Y
Y
Y
Y
2.18 SETTING UP YOUR PRINTER
Installing Printer Software in Windows
System Requirements
Verify the following:
• At least 32 MB (Windows 9x/Me), 64 MB (Windows 2000/NT),
128 MB (Windows XP) or more of RAM is installed on your PC.
• There is at least 300 MB of free disk space on your PC.
• All applications are closed on your PC before beginning
installation.
• You are using Windows 95, Windows 98, Windows Me,
Windows NT 4.0, Windows 2000, or Windows XP.
• You are using at least Internet Explorer 5.0.
Installing Printer Software
All applications should be closed on your PC before beginning
installation.
NOTE: Cancel the “New Hardware Found” window when your
computer boots up.
1 Place the CD-ROM in the CD-ROM drive. Installation will
start automatically.
If the CD-ROM driver does not automatically run:
Select Run from the Start menu, type X:\Setup.exe in
the Open box (Where X is the drive letter for the CD-ROM
drive) and click OK.
NOTE: If your machine is not connected to the computer, the
following window will appear.
• After connecting the machine, click Next.
• If you want to skip the connection status, click Next, and No to
the following screen. Then the installation will start and the test
page will not be printed at the end of the installation.
SETTING UP YOUR PRINTER 2.19
2
2 Choose the installation type.
•Typical: Installs the common software for your printer,
such as printer driver, and User’s Guide. This is
recommended for most users.
•Custom: Allows you to choose the language of the
software and the components you want to install. After
selecting the language and the component(s), click Next.
•View User’s Guide: Opens Samsung ML-2250 Series
User’s Guide. If your computer doesn’t have Adobe
Acrobat, click on this option and it will automatically install
Adobe Acrobat Reader for you.
3 After the installation is finished, the window asking you to
print a test page appears. If you choose to print a test
page, select the check box and click Next.
4 When the test page prints out correctly, click Yes.
If not, click No to reprint it.
2.20 SETTING UP YOUR PRINTER
5 To register yourself as a user of Samsung Printers, select
the checkbox and click Finish. You are now accessed to the
Samsung web site.
2
NOTES:
• When you want to use your machine with the parallel cable,
remove the USB cable and connect the parallel cable. Then
reinstall the printer driver; select Start ➔ Programs ➔
Samsung ML-2250 Series ➔ Maintenance ➔ Repair ➔
Printer. If you have replaced the parallel cable with the USB
cable, do the same to reinstall the driver.
• If your printer doesn’t work properly, reinstall the printer driver.
Changing the Display Language
After installation of the software, you can change the display
language.
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series, and Language
Selection.
3 Select the desired language from the language selection
window, and click OK.
SETTING UP YOUR PRINTER 2.21
Reinstalling Printer Software
Repair is required if your installation fails.
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series, and then
Maintenance.
3 Select Repair.
NOTE: If your machine is not connected to the computer, the
following window will appear.
• After connecting the machine, click Next.
• If you want to skip the connection status, click Next, and No to
the following screen. Then the installation will start and the test
page will not be printed at the end of the installation.
4 Select the components you want to reinstall and click Next.
2.22 SETTING UP YOUR PRINTER
If you choose to repair the printer software, the window
asking you to print a test page appears. do as follows:
a. To print a test page, select the check box and click
Next.
b. When the test page prints out correctly, click Yes.
If not, click No to reprint it.
5 When the reinstallation is done, click Finish.
Removing Printer Software
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series, and then
Maintenance.
3 Select Remove.
Then you will see a component list so that you can remove
any of them individually.
If you want to uninstall the printer driver, check Printer.
If you want to uninstall the printer (PostScript) driver, check
Printer(PostScript).
If you want to uninstall the Status Monitor, check Status
Monitor.
If you want to uninstall the Remote Control Panel, check
Remote Control Panel.
4 Select the components you want to remove and then click
Next.
5 When your computer asks you to confirm your selection.
click Yes.
The selected driver and all of its components are removed
from your computer.
6 After the software is removed, click Finish.
SETTING UP YOUR PRINTER 2.23
2
Viewing the User’s Guide
After installing the printer software, you can view User’s Guide
in PDF format at any time from your Windows desktop.
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series and View User’s
Guide.
Adobe Acrobat automatically runs and then the User’s Guide
opens.
NOTE: If your computer doesn’t have Adobe Acrobat, selecting
the View User’s Guide option automatically installs Adobe
acrobat for you. After installing is complete, repeats step 1 and 2.
2.24 SETTING UP YOUR PRINTER
3
USING PRINT MATERIALS
This chapter will help you understand types of paper you
can use with your printer and how to properly load paper in
the different paper trays for the best print quality.
This chapter includes:
• Choosing Paper and Other Materials
• Selecting the Output Location
• Loading Paper
• Printing on Envelopes
• Printing on Labels
• Printing on Transparencies
• Printing on Card Stock or Custom-sized Materials
• Printing on Preprinted Paper
Choosing Paper and Other Materials
You can print on a variety of print materials, such as plain paper,
envelopes, labels, transparencies, and so on. See “Paper
Specifications” on page E.3. To get the best possible print
quality, use only high-quality copier-grade paper.
When you choose print materials, consider the following:
• Desired outcome: The paper you choose should be
appropriate for the project.
• Size: You can use any size paper that fits easily within the
paper adjusters of the paper tray.
• Weight : Your printer supports paper weight as follows:
-16~24 lbs (60~90 g/m2) bond for the Tray1 or optional
Tray2
-16~43 lbs (60~163 g/m2) bond for the Multi-Purpose Tray
• Brightness: Some papers are whiter than others and
produce sharper, more vibrant images.
• Surface smoothness: The smoothness of the paper affects
how crisp the printing looks on the paper.
CAUTION: Using a material that does not conform to the
specifications listed in the paper specification can cause problems
that may require service. This service is not covered by the
warranty or service agreements.
3.2
USING PRINT MATERIALS
Sizes and Capacities
Input Source/Capacity*a
Size
Tray1 or optional
Tray2
Multi-Purpose
Tray
250
250
250
250
250
250
250
250
250
-
50
50
50
50
50
50
50
50
50
50
-
5
5
5
5
5
-
5
5
Letter (216 x 279 mm)
A4 (210 x 297 mm)
-
5
5
Card stocks*b
-
5
Bond*b
-
5
Plain Paper
Letter (216 x 279 mm)
Legal (216 x 356 mm)
Executive (184 x 267 mm)
Oficio (216 x 343 mm)
Folio (216 x 330 mm)
A4 (210 x 297 mm)
JIS B5 (182 x 257 mm)
ISO B5 (176 x 250 mm)
A5 (148 x 210 mm)
A6 (105 x 148 mm)
3
Envelopes
No.10 (105 x 241 mm)
Monarch (98 x 191 mm)
C5 (162 x 229 mm)
DL (110 x 220 mm)
C6 (114 x 162 mm)
Labels*b
Letter (216 x 279 mm)
A4 (210 x 297 mm)
Transparencies*b
*a Depending on paper thickness, the maximum capacity may be reduced.
*b If you are experiencing excessive jamming, feed one sheet at a time through the
Multi-Purpose Tray.
USING PRINT MATERIALS
3.3
Guidelines for Paper and Special Materials
When selecting or loading paper, envelopes, or other special
materials, keep these guidelines in mind:
• Attempting to print on damp, curled, wrinkled, or torn paper
can cause paper jams and poor print quality.
• Use cut-sheet paper only. You cannot use multi-part paper.
• Use only high-quality, copier grade paper for the best print
quality.
• Do not use paper that has already been printed on or that has
been fed through a photocopier.
• Do not use paper with irregularities, such as tabs or staples.
• Do not attempt to load any tray during printing and never
overfill the tray. This could cause a paper jam.
• Avoid paper with embossed lettering, perforations, or texture
that is too smooth or too rough.
• Coloured paper should be of the same high quality as white
photocopy paper. The pigments must withstand the printer’s
fusing temperature of 400°F (205°C) for 0.1 second without
deterioration. Do not use paper with a coloured coating that
was added after the paper was produced.
• Preprinted forms must be printed with nonflammable, heatresistant inks that do not melt, vaporize, or release hazardous
emissions when subject to the printer’s approximately 400°F
(205°C) fusing temperature for 0.1 second.
• Store paper in its ream wrapper until ready to use. Place
cartons on pallets or shelves, not on the floor.
• Do not place heavy objects on top of the paper, whether it is
packaged or unpackaged.
• Keep paper away from moisture, direct sunlight, or other
conditions that can cause it to wrinkle or curl.
NOTE: Do not use carbonless paper or tracing paper. They are
unstable at the fusing temperature and can give off fumes, or
cause damage to the paper.
3.4
USING PRINT MATERIALS
Selecting the Output Location
The printer has two output locations; the rear output tray and
the top output tray.
Top output tray
Rear output tray
3
To use the top output tray, be sure that the rear output tray is
closed. To use the rear output tray, open it.
NOTES:
• If paper coming out of the top output tray has problems, such as
excessive curl, try printing to the rear output tray.
• To avoid paper jams, do not open or close the rear output tray
while the printer is printing.
Printing to the Top Output Tray
(Face down)
The top output tray collects paper face-down, in the order in
which it was printed. The top output tray should be used for
most print jobs.
NOTE: If you continuously print many pages, the surface of the
output tray may become hot. Be careful not to touch the surface,
and especially keep children away from the surface.
USING PRINT MATERIALS
3.5
Printing to the Rear Output Tray
(Face up)
The printer always prints to the rear output tray if it is open.
Paper comes out of the printer face-up, and each time a sheet
of paper comes out, it falls down from the printer.
Printing from the Multi-Purpose Tray to the rear output tray
provides a straight paper path. Opening the rear output tray
might improve the output quality with the following:
• envelopes
• labels
• transparencies
To open the rear output tray:
1 Open the rear door by pulling it down. The cover functions
as the output tray.
CAUTION: The fusing area at the rear portion of the inside of
your printer is hot when powered. Be careful not to be burned
when accessing this area.
3.6
USING PRINT MATERIALS
2 If you do not want to use the rear output tray, close the
tray. The pages will stack on the top output tray.
3
Loading Paper
Proper paper loading helps prevent paper jams and ensure
trouble-free printing. Do not remove the paper tray while a job
is printing. Doing so may cause a paper jam. See “Sizes and
Capacities” on page 3.3 for acceptable paper size and capacities
for each tray.
The paper level bar on the front of the paper tray(s) shows the
amount of paper currently left in the tray. When the tray is
empty, the indicator drops to the bottom.
Paper full Paper empty
USING PRINT MATERIALS
3.7
Using Tray1 or the Optional Tray2
Tray1 and the optional Tray2 can hold up to 250 sheets of paper.
See “Sizes and Capacities” on page 3.3 for acceptable paper size
and capacities of each tray.
Tray1
Optional Tray2
Load a stack of paper into the tray and print. For details about
loading paper in Tray1 or the optional Tray2, see “Loading
Paper” on page 2.7.
Using the Multi-Purpose Tray
The multi-Purpose Tray is located in the front of your printer. It
can be closed when you are not using it, making the printer
more compact.
Multi-Purpose Tray
The Multi-Purpose Tray can hold several sizes and types of
paper, such as transparencies, cards, and envelopes. You may
also want to use the Multi-Purpose Tray for single page print jobs
on letterhead, coloured paper for use as separator sheets, or
other special materials that you do not normally keep in the
paper tray. You can load approximately 50 sheets of plain paper,
5 envelopes, 5 transparencies, 5 sheets of card stock or 5 labels
at a time.
3.8
USING PRINT MATERIALS
• Load only one size of print material at a time in the
Multi-Purpose Tray.
• To prevent paper jams, do not add paper when there is still
paper in the Multi-Purpose Tray. This also applies to other
types of print materials.
• Print materials should be loaded face up with the top edge
going into the Multi-Purpose Tray first and be placed on the
centre of the tray.
• Do not place objects on the Multi-Purpose Tray. Also avoid
pressing down or applying excessive force on it. The tray may
fall from the printer.
To load paper in the Multi-Purpose Tray:
1 Pull the Multi-Purpose Tray down towards you.
3
2 Unfold the extender to extend the tray to its full-length to
hold longer paper.
USING PRINT MATERIALS
3.9
3 Prepare a stack of paper for loading by flexing or fanning
the paper back and forth. Straighten the edges on a level
surface.
4 Place paper on the centre of the tray with the print side
face up. Pay attention to the paper limit mark on the left
inside wall of the tray. Paper overloading may cause paper
jams.
If you want to print on previously printed paper from the
Multi-Purpose Tray, the printed side should be facing down
with an uncurled edge to the printer. If you experience
problems with paper feed, turn the paper around.
NOTE: Make sure that you have not loaded too much print
material. The print material buckles if you load a stack that is too
deep or push it in too far.
3.10 USING PRINT MATERIALS
5 Slide the paper width guide and adjust it against the stack
of print material without bending.
3
NOTE: Your printer cannot automatically detect the size of paper
loaded in the Multi-Purpose Tray. Loading the Multi-Purpose Tray
with the correct paper size allows you to select paper by size rather
than paper source when you print from your software application.
You do not have to check which paper is loaded in the Multipurpose Tray before printing.
6 When you print a document, select the paper source and
type in the software application.
7 After printing, push the extender back to its place and close
the Multi-Purpose Tray.
USING PRINT MATERIALS 3.11
Using the Manual Feed Mode
If you select Manual Feed in the Source option when changing
print settings, you can manually load a sheet of print material in
the Multi-Purpose Tray. Manually loading paper can be helpful
when you want to check the print quality after each page is
printed.
This loading procedure is almost the same as the procedure for
loading in the Multi-Purpose Tray, except you load paper sheetby-sheet in the Tray, send print data to print the first page, and
press the Cancel button on the control panel to print each
following page.
1 Load a sheet of print material on the centre of the MultiPurpose Tray with the print side up.
2 Slide the paper width guide and adjust it against the
material without bending.
3.12 USING PRINT MATERIALS
3 Open the rear output tray.
4 When you print a document, you must select Manual Feed
for Source from the software application, and then select
the correct paper size and type.
5 Press the Cancel button on the printer to start feeding.
6 Printing is started.
7 If you are printing multiple pages, load the next sheet after
the first page prints out, and press the Cancel button.
Repeat this step for every page to be printed.
USING PRINT MATERIALS 3.13
3
Printing on Envelopes
Guidelines
• Only use envelopes recommended for laser printers. Before
loading envelopes into the Multi-Purpose Tray, make sure
that they are undamaged and are not stuck together.
• Do not feed stamped envelopes.
• Never use envelopes with clasps, snaps, windows, coated
lining, or self-stick adhesives. These envelopes may severely
damage the printer.
1 Open the Multi-Purpose Tray and unfold the extender to its
full-length position.
2 Open the rear output tray.
3.14 USING PRINT MATERIALS
3 Flex or fan the edge of the envelope stack to separate the
pages before loading.
4 Load the envelopes onto the Multi-Purpose Tray with the
flap side down.
The stamp area is on the left side and the end of the
envelope with the stamp area enters the tray first.
3
5 Adjust the guide to the edge of the envelope stack.
USING PRINT MATERIALS 3.15
6 When you print on envelopes, select the appropriate paper
source, type, and size in the software application. For
details, see page 4.7.
7 After printing, close the Multi-Purpose Tray and the rear
output tray.
3.16 USING PRINT MATERIALS
Printing on Labels
Guidelines
• Only use labels recommended for laser printers.
• Verify that the labels’ adhesive material can tolerate fusing
temperature of 205°C (400°F) for 0.1 second.
• Make sure that there is no exposed adhesive material
between the labels. Exposed areas can cause labels to peel
off during printing, which can cause paper jams. Exposed
adhesive can also cause damage to printer components.
• Do not feed a sheet of labels through the printer more than
once. The adhesive backing is designed for one pass through
the printer.
• Do not use labels that are separating from the backing sheet
or are wrinkled, bubbled, or otherwise damaged.
1 Open the Multi-Purpose Tray and the rear output tray.
2 Load labels with the print side up.
USING PRINT MATERIALS 3.17
3
3 Adjust the guide to fit the width of the sheet of labels.
4 When you print on labels, select the appropriate paper
source, type, and size in the software application. For
details, see page 4.7.
5 After printing, close the Multi-Purpose Tray and the rear
output tray.
NOTE: To prevent labels from sticking, do not let the printed label
sheets stack up as they are printed out.
3.18 USING PRINT MATERIALS
Printing on Transparencies
Guidelines
• Only use transparencies recommended for use in laser
printers.
• Ensure that transparencies are not wrinkled, curled, or have
any torn edges.
• Hold the transparencies by the edges and avoid touching the
print side. Oils deposited on the transparency can cause print
quality problems.
• Be careful not to scratch or leave fingerprints on the print
side.
1 Open the Multi-Purpose Tray and the rear output tray.
2 Load transparencies with the print side up, and the top
with the adhesive strip entering the printer first.
USING PRINT MATERIALS 3.19
3
3 Adjust the guide to fit the width of the transparencies.
4 When you print on transparencies, select the appropriate
paper source, type, and size in the software application. For
details, see page 4.7.
5 After printing, close the Multi-Purpose Tray and the rear
output tray.
NOTES:
• If you print on thin transparencies to the rear output tray, they
can curl. In this case, use the top output tray. If the problem
persists, check if your transparencies meet the printer’s
specifications.
• To prevent transparencies from sticking, do not let the printed
sheets stack up as they are printed out.
• Place transparencies on a flat surface after removing them from
the printer.
3.20 USING PRINT MATERIALS
Printing on Card Stock or
Custom-sized Materials
Postcards, 3.5 by 5.83 in. (index) cards and other custom-sized
materials can be printed with your printer. The minimum size is
76 by 127 mm (3 by 5 in.) and the maximum size is 216 by
356 mm (8.5 by 14 in.).
Guidelines
• Always insert the short-edge into the Multi-Purpose Tray first.
If you want to print in landscape mode, make this selection
through your software. Inserting paper long-edge first may
cause a paper jam.
• Do not load more than 5 cards into the Multi-Purpose Tray at
a time.
• Do not print on media smaller than 76 mm (3 in.) wide or 127
mm(5 in.) long.
• Set margins at least 6.4 mm (0.25 in.) away from the edges
of the material in the software application
1 Open the Multi-Purpose Tray and the rear output tray.
2 Load print material with print side up and short edge first.
USING PRINT MATERIALS 3.21
3
3
Adjust the guide to fit the width of the material stack.
4 When you print, select the appropriate paper source, type,
and size in the software application. For details, see
page 4.7.
NOTE: If the size of your print material is not listed in the Size
box in the Paper tab of the printer driver properties, click the
Custom button and set the size manually. See page 4.7.
CAUTION: When you use 76 by 127 mm (3 by 5 in.) paper and it
is too thin, a paper jam may occur. Use card stock heavier than
105g/m2
5 After printing, close the Multi-Purpose Tray and the rear
output tray.
3.22 USING PRINT MATERIALS
Printing on Preprinted Paper
Preprinted paper is paper that has some type of printing placed
on it before it is sent through the printer (paper that has a
preprinted logo at the top of the page, for example).
Guidelines
• Letterheads must be printed with heat-resistant ink that will
not melt, vaporize, or release hazardous emissions when
subjected to the printer’s fusing temperature of 400 °F
(205 °C) for 0.1 second.
• Ink on letterheads must be non-flammable and should not
adversely affect any printer rollers.
• Forms and letterhead should be sealed in a moisture-proof
wrapping to prevent changes during storage.
• Before you load preprinted paper as forms and letterhead,
verify that the ink on the paper is dry. During the fusing
process, wet ink can come off preprinted paper.
1 Load letterhead into the tray you want to use, as shown in
the figures below. Adjust the guides to fit the width of the
paper stack.
Load with the design face
down, bottom edge
towards the printer.
Load with the design face
up, top edge towards the
printer.
USING PRINT MATERIALS 3.23
3
2 When you print, select the appropriate paper source, type,
and size in the software application. For details, see
page 4.7.
3.24 USING PRINT MATERIALS
4
PRINTING TASKS
This chapter explains printing options and common
printing tasks. This chapter includes:
• Printing a Document
• Setting Paper Properties
• Using the Toner Save Mode
• Printing Multiple Pages on One Sheet of Paper
(N-Up Printing)
• Printing a Reduced or Enlarged Document
• Fitting Your Document to a Selected Paper Size
• Printing Posters
• Using Watermarks
• Using Overlays
• Setting Graphic Properties
• Using Output Options
• Using the Status Monitor
• Setting Up a Locally Shared Printer
Printing a Document
The following procedure describes the general steps required for
printing from various Windows applications. The exact steps for
printing a document may vary depending on the application
programme you are using. Refer to the User’s Guide of your
software application for the exact printing procedure.
NOTE: For detailed information about printing from a Linux
system, see Appendix B, "Using Your Printer in Linux."
1 Open the document you want to print.
2 Select Print from the File menu. The Print window is
displayed (It may look slightly different depending on your
application).
The basic print settings are selected within the Print
window. These settings include the number of copies and
print range.
Make sure that your
printer is selected.
Windows 98
3 To take advantage of the printer features provided by your
printer, click Properties in the application’s print window
and go to Step 4.
If you see Setup, Printer, or Options, click that button
instead. Then click Properties in the next screen.
4.2 PRINTING TASKS
4 Now you see the Samsung ML-2250 Series Properties
window, which allows you to access all the information you
will need when using your printer.
The Layout tab is first displayed.
The preview image
shows the sample page
with the settings you
currently specified.
4
If necessary, select the Orientation option.
The Orientation option allows you to select the direction in
which information is printed on a page.
• Portrait prints across the width of the page, letter style.
• Landscape prints across the length of the page,
spreadsheet style.
• If you want to turn the page upside down, select 180 from
the Rotate drop-down list.
Landscape
Portrait
5 From the Paper tab, select the paper source, size and type.
For further details, see page 4.7.
6 Click other tabs on the top of the Samsung ML-2250 Series
Properties window to access other features, if needed.
PRINTING TASKS
4.3
7 When you complete setting the properties, click OK until
the Print window is displayed.
8 Click OK to start printing.
NOTES:
• Most Windows applications will override settings you specify in
the printer driver. Change all print settings available in the
software application first, and change any remaining settings
using the printer driver.
• The settings you change remain in effect only while you are
using the current programme. To make your changes
permanent, make them in the Printers folder. Follows this
procedure:
1. Click the Windows Start menu.
2. For Windows 95/98/Me/NT 4.0/2000, select Settings and
then Printers.
For Windows XP, select Printers and Faxes.
3. Select the Samsung ML-2250 Series printer.
4. Click the right mouse button on the printer icon and:
• In Window 95/98/Me, select Properties.
• In Windows 2000/XP, select Printing Preferences.
• In Windows NT 4.0, select Document Default.
5. Change the settings on each tab, and click OK.
4.4 PRINTING TASKS
Cancelling a Print Job
There are two ways to cancel a print job.
To stop a print job from the control panel:
Press the Cancel button on the control panel.
4
The printer will finish printing the page that is moving through
the printer and delete the rest of the print job. Pressing the
button cancels only the current job in the printer. If more than
one print job is in the printer memory, the button must be
pressed once for each job.
To stop a print job from the Printers folder:
1 From the Windows Start menu, select Settings.
2 Select Printers to open the Printers window, and
double-click the Samsung ML-2250 Series icon.
3 From the Document menu, select Cancel Printing
(Windows 9x/Me) or Cancel (Windows NT 4.0/2000/XP).
Windows 98
PRINTING TASKS
4.5
Using a Favorite Setting
The Favorites option, which is visible on each properties tab,
allows you to save the current properties settings for future use.
To save a Favorites item:
1 Change the settings as needed on each tab.
2 Enter a name for the item in the Favorites input box.
3 Click Save.
To use a saved setting, just select the item from the Favorites
drop down list.
To delete a Favorites item, select it from the list and click
Delete.
You can also restore the printer driver’s default settings by
selecting <Printer Default> from the list.
Using Help
Your printer has a help screen that can be activated by the Help
button in the printer’s properties window. These help screens
give detailed information about the printer features provided by
the printer driver.
You can also click
from the upper right hand corner, and then
click on any setting.
4.6 PRINTING TASKS
Setting Paper Properties
Use the following options to set the basic paper handling needs
when you access the printer properties. See page 4.2 for more
information about accessing printer properties.
Click the Paper tab to access various paper properties.
1
2
3
4
5
4
Property
Description
1 Copies
Copies allows you to choose the number of
copies to be printed. You can enter up to 999.
2 Size
The Size option allows you to choose the size
of paper loaded in the tray.
If the required size is not listed in the Size
box, click Custom. When the Custom Page
Size window appears, set the paper and click
Ok. The size setting appears in the Size list
so that you can select it.
Enter the custom
name you want to
use.
Enter the paper
size.
PRINTING TASKS
4.7
Property
3 Source
Description
Make sure that Source is set to the
corresponding paper tray.
The Manual Feed source is used when
printing to special materials. You have to load
one sheet at a time into the Multi-Purpose
Tray. See page 3.12.
If the paper source is set to Auto Select,
the printer automatically picks up print
materials according to the following order:
Multi-Purpose Tray, Tray1, Optional Tray2.
4 Type
Make sure that Type is set to Printer
Default. If you load a different type of print
materials, select the corresponding paper
type. For more information on print
materials, refer to Chapter 3, "Using Print
Materials."
If you use cotton paper, set the paper type to
Thick for the best printing.
To use recycled paper, which weighs from
20lb to 24lb, or other colored paper, select
Color paper.
5 Different
Source
for First
Page
4.8 PRINTING TASKS
This property allows you to print the first
page using a different paper type from the
rest of the document. You can select the
paper source for the first page.
For example, load thick stock for the first
page into the Multi-Purpose Tray, and plain
paper into the Tray1. Then, select Tray1 in
the Source option and Multi-Purpose
Tray in the Different Source for First
Page option.
Using the Toner Save Mode
Toner Save mode allows the printer to use less toner on each
page. Using this mode will extend the life of your toner cartridge
and reduce your cost per page, but will reduce the print quality.
This setting is not available with the 1200 dpi setting.
There are two ways to enable the Toner Save mode:
From the Control Panel
Press the Cancel button on the control panel for 0.5 second.
The printer must be in Ready mode (On Line/Error green LED
is on).
4
• If the Toner Save LED is on, the mode is enabled and the
printer uses less toner to print a page.
• If the Toner Save LED is off, the mode is disabled and the
printer prints in the normal mode.
PRINTING TASKS
4.9
From the software application
1 When you change the print settings from your software
application, access the printer properties. See page 4.2.
2 Click the Graphics tab, and select the Toner Save option.
You can select from:
• Printer Setting: If you select this option, the Toner Save
feature is determined by the setting you’ve made on the
control panel of the printer.
• On: Select this option to allow the printer to use less
toner on each page.
• Off: If you don’t need to save toner to print a document,
select this option.
3 Click OK.
NOTE: The setting in the software application overrides that on
the control panel.
4.10 PRINTING TASKS
Printing Multiple Pages on One
Sheet of Paper (N-Up Printing)
1
2
3
4
You can select the number of pages to print on a single sheet of
paper. To print more than one page per sheet, the pages will
appear decreased in size and arranged on the sheet. You can
print up to 16 pages on one sheet.
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
2 From the Layout tab, choose Multiple Pages per Side in
the Type drop-down list.
3 Select the number of pages you want to print per sheet
(1, 2, 4, 9 or 16) in the Pages per Side drop-down list.
4
4 Select the page order in the Page Order drop-down list,
if necessary.
1
2
1
3
2
1
3
1
3
4
2
4
4
3
4
2
Right, Then
Down
Down, Then
Right
Left, Then
Down
Down, Then
Left
Check Print Page Border to print a border around each
page on the sheet. Print Page Border is enabled only if
the pages per sheet is 2, 4, 9, or 16.
PRINTING TASKS 4.11
5 Click the Paper tab and select the paper source, size, and
type.
6 Click OK and print the document.
Printing a Reduced or Enlarged
Document
You can scale your print job on a page.
1 When you change the print settings from your software
application, access the printer properties. See page 4.2.
2 From the Paper tab, select Scale Printing in the Type
drop-down list.
3 Enter the desired scaling rate in the Percentage input box.
You can also click the or button.
4 Select the paper source, size, and type.
5 Click OK and print the document.
4.12 PRINTING TASKS
Fitting Your Document to a Selected
Paper Size
A
This printer feature allows you to scale your print job to any
selected paper size regardless of the digital document size. This
can be useful when you want to check fine details on a small
document.
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
2 From the Paper tab, select Fit to Page in the Type
drop-down list.
3 Select the correct size from the Target Paper drop-down
list.
4
4 Select the paper source, size and type.
5 Click OK and print the document.
PRINTING TASKS 4.13
Printing Posters
This feature allows you to print a single-page document onto 4,
9 or 16 sheets of paper, for the purpose of pasting the sheets
together to form one poster-size document.
1 To change the print settings from your software application,
access the printer properties. See page page 4.2.
2 From the Layout tab, select Poster in the Type drop-down
list.
3 Configure the poster option:
You can select the page layout from 2x2, 3x3 or 4x4. If you
select 2x2, the output will be automatically stretched to
cover 4 physical pages.
2 x 2
3 x 3
4.14 PRINTING TASKS
Specify an overlap in millimeters or inches to make it easier
to reconstruct the resulting poster.
0.15 inches
0.15 inches
4 Click the Paper tab and select the paper source, size and
type.
5 Click OK and print the document. You can complete the
poster by reconstructing the resulting pages.
4
Using Watermarks
The Watermark option allows you to print text over an existing
document. For example, you may want to have large gray letters
reading “DRAFT” or “CONFIDENTIAL” printed diagonally across
the first page or all pages of a document.
There are several predefined watermarks that come with your
printer, and they can be modified or you can add new ones to
the list.
Using an Existing Watermark
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
PRINTING TASKS 4.15
2 Click the Extras tab, and select the desired watermark in
the Watermark drop-down list. You will see the selected
watermark in the preview image.
Preview
Preview
3 Click OK and start printing.
Creating a Watermark
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
2 Click the Extras tab, and click the Edit button in the
Watermark section. The Edit Watermarks window appears.
Preview
3 Enter the desired text message in the Watermark
Message box.
This will be displayed in the preview window. The preview
image is provided so that you can see how the watermark
will appear on the printed page.
If the First Page Only box is checked, the watermark will
be printed on the first page only.
4.16 PRINTING TASKS
4 Select the desired watermark options.
You can select the font name, style, and size, and grayscale
level from the Font Attributes section and set the angle of
the watermark from the Message Angle section.
5 Click Add to add a new watermark to the list.
6 When you finish editing, click Ok and start printing.
To stop printing the watermark, select <No Watermark> in the
Watermark drop-down list.
Editing a Watermark
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
2 Click the Extras tab, and click the Edit button in the
Watermark section. The Edit Watermarks window appears.
3 Select the watermark you want to edit in the Current
Watermarks list, and change the watermark message and
the options. Refer to “Creating a Watermark” on page 4.16.
4 Click Update to save the changes.
5 Click Ok.
Deleting a Watermark
1 To change the print settings from your software application,
access the printer properties. See page 4.2.
2 From the Extras tab, click the Edit button in the
Watermark section. The Edit Watermarks window appears.
3 Select the watermark you want to delete in the Current
Watermarks list and click Delete.
4 Click Ok.
PRINTING TASKS 4.17
4
Using Overlays
What is an Overlay?
Dear ABC
Regards
WORLD BEST
An overlay is text and/or images stored in the computer hard
disk drive (HDD) as a special file format that can be printed on
any document. Overlays are often used to take the place of
preprinted forms and letterhead paper. Rather than using
preprinted letterhead, you can create an overlay containing the
exact same information that is currently on your letterhead. To
print a letter with your company’s letterhead, you do not need
to load preprinted letterhead paper in the printer. You need only
tell the printer to print the letterhead overlay on your document.
Creating a New Page Overlay
To use a page overlay, you must create a new page overlay
containing your logo or image.
1 Create or open a document containing text or an image for
WORLD BEST
use in a new page overlay. Position the items exactly as you
wish them to appear when printed as an overlay. If needed,
save the file for later use.
2 To change the print settings from your software application,
access the printer properties. See page 4.2.
3 Click the Extras tab, and click Edit button in the Overlay
section.
4.18 PRINTING TASKS
4 In the Edit Overlays window, click Create Overlay.
5 In the Create Overlay window, type a name of up to eight
characters in the File name box. Select the destination
path, if necessary. (The default is C:\FormOver).
4
6 Click Save. You will see the name in Overlay List.
7 Click OK or Yes until you complete creating.
The file is not printed out. Instead it will be stored on your
computer HDD disk.
NOTE: The overlay document size must be the same as
documents you will print with the overlay. Do not create an overlay
with a watermark.
PRINTING TASKS 4.19
Using a Page Overlay
After an overlay has been created, it is ready to be printed with
your document. To print an overlay with a document:
1 Create or open the document you want to print.
2 To change the print settings from your software application,
access the printer properties. See page 4.2.
3 Click the Extras tab.
4 Select the desired overlay from the Overlay drop-down list
box.
5 If the desired overlay file does not appear in the Overlay
list, click the Edit button and Load Overlay, and select the
overlay file.
If you have stored the overlay file you want to use into an
external source, you can also load the file when you access
this Load Overlay window.
After you select the file, click Open. The file is now shown
in the Overlay List box and is available for printing. Select
the overlay from the Overlay List box.
4.20 PRINTING TASKS
6 If necessary, click Confirm Page Overlay When Printing.
If this box is checked, a message window will appear each
time you submit a document for printing, asking you to
confirm your wish to print an overlay on your document.
Answering Yes to the window means that the selected
overlay will be printed with your document. Answering No
to the window cancels overlay printing.
If this box is empty and an overlay has been selected, the
overlay will be automatically printed with your document.
7 Click OK or Yes until the printing starts.
The selected overlay will be downloaded with your print job
and printed on your document.
NOTE: The resolution of the overlay document must be the same
as that of the document you will print with the overlay.
4
Deleting a Page Overlay
You can delete page overlays that are no longer used.
1 In the printer properties window, click the Extras tab.
2 Click Edit in the Overlay section.
3 Select the overlay you want to delete from the Overlay
List box.
4 Click Delete Overlay.
5 Click OK until you exit the Print window.
PRINTING TASKS 4.21
Setting Graphic Properties
Use the following graphic options to adjust the print quality for
your specific printing needs. See page 4.2 for more information
about accessing printer properties.
Click the Graphics tab to display the properties shown below.
1
2
3
4
4.22 PRINTING TASKS
Property
Description
1 Resolution
You can select the printing resolution by
choosing from 1200 dpi (Best) or
600 dpi (Normal). The higher the setting,
the sharper the clarity of printed characters
and graphics. Higher settings may increase
the time it takes to print a document.
2 Toner Save
Selecting this option will extend the life of
your toner cartridge and reduce your cost
per page without a significant reduction in
the print quality. For detailed information
about this mode, see page 4.9.
Property
Description
Some printed characters or images appear to
have jagged or uneven edges. Set this
Image Mode option to improve the print
quality of your text and image, and make the
characters and images appear smoother.
3 Image
Mode
The Image Mode option is only available
when you select 600 dpi (Normal) in the
Resolution option.
• Normal: This setting prints images in the
normal mode.
• Text Enhance: This setting refines the
print quality of characters by smoothing
out jagged edges that can occur on the
angles and curves of each character.
• Image Enhance: This setting refines the
print quality of photo images.
You can set advanced settings by clicking
the Advanced Options button.
4 Advanced
Options
Darkness
Use this option to lighten or darken the
image appearance in your print.
• Normal: This setting is for normal
documents.
• Light: This setting is for bolder line
widths or darker gray-scale images.
• Dark: This setting is for finer line width,
higher definition in graphics, and lighter
gray-scale images.
When the Darken Text option is checked,
all text in your document is allowed to
print darker than a normal document.
PRINTING TASKS 4.23
4
Property
Description
TrueType Options
This option determines what the driver
tells the printer about how to image the
text in your document. Select the
appropriate setting according to the status
of your document.
4 Advanced
Options
(continued)
• Download as Bit Image: When this
option is selected, the driver will
download the font data as bitmap
images. Documents with complicated
fonts, such as Korean or Chinese, or
various other fonts, will print faster in
this setting.
• Print as Graphics: When this option is
selected, the driver will download any
fonts as graphics. When printing
documents with high graphic content and
relatively few TrueType fonts, printing
performance (speed) may be enhanced
in this setting.
Print All Text Black
When the Print All Text Black option is
checked, all text in your document is
allowed to print solid black, regardless of
the colour it appears on the screen. When
it is not checked, coloured text is allowed
to print in shades of gray.
4.24 PRINTING TASKS
Using Output Options
You can select options for output of your document.
See page 4.2 for more information about accessing printer
properties.
Click the Extras tab to access the Output Options feature.
4
Option
Description
You can set in what sequence the pages will
be printed. Select the required print order
from the drop-down list.
Print Order
Reprint When
Jammed
• Normal:Your printer prints in normal
order.
• Reverse All Pages:Your printer prints
all pages in reversed order. This setting is
helpful when you are using the rear output
tray.
• Print Odd Pages:Your printer prints
only the odd pages of the document.
• Print Even Pages:Your printer prints
only the even pages of the document.
When this option is checked, the printer
keeps the image for a printed page until the
printer signals that the page has
successfully exited the printer. When a
paper jam occurs, the printer reprints the
last page after you clear the jam.
PRINTING TASKS 4.25
Using the Status Monitor
If an error occurs while printing, the Status Monitor window
appears, showing the error.
NOTEs:
• The Status Monitor program can only be used if you connect the
printer to your computer with the USB cable, or on the network.
• You can use the Status Monitor in Windows 98/Me/NT 4.0/2000/
XP.
Installing Status Monitor
1 Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run and an maintenance
window appears.
If the maintenance window does not appear, click Start and
then Run. Type X:\Setup.exe, replacing “X” with the
letter of your drive and click OK.
NOTE: If your machine is not connected to the computer, the
following window will appear.
• After connecting the machine, click Next.
• If you want to skip the connection status, click Next, and No to
the following screen.
2 Click Custom.
If you have been installed the printer driver before, click
Repair.
3 Click Status Monitor and then click Next.
4 When the installation is completed, click Finish.
4.26 PRINTING TASKS
Reinstalling Status Monitor
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series, and then
Maintenance.
3 Click Repair.
4 Click Status Monitor and then click Next.
5 When reinstallation is done, click Finish.
Removing Status Monitor
1 From the Start menu, select Programs.
2 Select Samsung ML-2250 Series, and then
Maintenance.
3 Check Remove.
4 Click Status Monitor and then click Next.
5 When removing is completed, click Finish.
Opening the Troubleshooting Guide
Double click the Status monitor icon on the Windows task bar.
Double click this icon.
Or, from Programs from Start, Samsung ML-2250 Series,
and Troubleshooting guide.
PRINTING TASKS 4.27
4
Changing the Status Monitor Program
Setting
The following window opens when you click the Status monitor
icon on the Windows task bar and select Option.
• Display when job is finished for network printer shows
the Status monitor balloon when your job is complete.
• Display when error occurs during printing the Status
monitor balloon appears when an error occurs while printing.
• Schedule an automatic status checking every allows the
computer to update the printer status regularly. Setting the
value close to 1 second causes the computer to check the
printer status more frequently, thereby allowing a faster
response to any printer error.
NOTE: When the Status monitor balloon appears to indicate an
error, you can cancel the current print job or see the corresponding
solution. If you select Cancel Printing, turn the printer off and
then click OK. It may take several minutes. Note that this will lose
data which is being sent to the printer via network.
4.28 PRINTING TASKS
Setting Up a Locally Shared Printer
Locally-Shared Printer
You can connect the printer directly to a selected computer,
which is called the “host computer” on the network. The printer
can then be shared by other users on the network through a
Windows 9x/Me/XP/NT 4.0/2000 network printer connection.
Printing Across a Network
Whether the printer is locally connected or network-connected,
you need to install the ML-2250 series printer software on each
computer that will print documents to the printer.
In Windows 9x/Me
4
Setting Up the Host Computer
1 Start Windows.
2 From the Start menu, select Control Panel, and doubleclick on the Network icon.
3 Check the File and Print Sharing box, and click OK. Close
the window.
4 From the Start menu, select Printers from Settings and
double-click your printer name.
5 Select Properties in the Printer menu.
6 Click the Sharing tab and check the Shared As box. Fill in
the Shared Name field and click OK.
Setting Up the Client Computer
1 Right-click the Windows Start button and select Explorer.
2 Open your network folder in the left column.
3 Right-click the shared name and select Capture Printer
Port.
PRINTING TASKS 4.29
4 Select the port you want, check the Reconnect at log on
box, and click OK.
5 From the Start menu, select Settings and then Printers.
6 Double-click your printer icon.
7 From the Printer menu, select Properties.
8 From the Details tab, select the printer port and click OK.
In Windows NT 4.0/2000/XP
Setting Up the Host Computer
1 Start Windows.
2 For Windows NT 4.0/2000, select Settings, and Printers
from the Start menu.
For Windows XP, select Printers and Faxes from the Start
menu.
3 Double-click your printer icon.
4 From the Printer menu, select Sharing.
5 For Windows NT 4.0, check the Shared box.
For Windows 2000, check the Shared As box.
For Windows XP, check the Share this printer box.
6 For Windows NT 4.0, fill in the Share Name field and click
OK.
For Windows 2000/XP, fill in the Shared Name field and
click OK.
4.30 PRINTING TASKS
Setting Up the Client Computer
1 Right-click the Windows Start button and select Explorer.
2 Open your network folder in the left column.
3 Click the shared name.
4 For Windows NT 4.0/2000, select Settings and Printers
from the Start menu.
For Windows XP, select Printers and Faxes from the Start
menu.
5 Double-click your printer icon.
6 From the Printer menu, select Properties.
7 From the Ports tab, click Add Port.
4
8 Select Local port and click New Port.
9 Fill in the Enter a port name field, enter the shared name.
10 Click OK and click Close.
11 For Windows NT 4.0, click OK.
For Windows 2000/XP, click Apply and click OK.
PRINTING TASKS 4.31
MEMO
4.32 PRINTING TASKS
5
MAINTAINING YOUR PRINTER
This chapter provides suggestions for high-quality and
economical printing and information for maintaining the
toner cartridge and the printer.
This chapter includes:
• Maintaining the Toner Cartridge
• Cleaning the Printer
• Printing Configuration Pages
• Consumables and Replacement Parts
Maintaining the Toner Cartridge
Toner cartridge storage
To get the maximum results from the toner cartridge, keep the
following guidelines in mind.
• Do not remove the toner cartridge from its package until ready
for use.
• Do not refill the toner cartridge. The printer warranty does
not cover damage caused by using a refilled cartridge.
• Store toner cartridges in the same environment as the printer.
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes.
Toner cartridge life expectancy
The life of the toner cartridge depends on the amount of toner
that print jobs require. When printing text at 5% coverage, a
new toner cartridge lasts an average of 5,000 pages.
Saving toner
To save toner, press the Cancel button on the printer control
panel for 0.5 second. The button will be lit. You can also enable
the Toner Save in the printer properties. Refer to “Using the
Toner Save Mode” on page 4.9. Selecting this option will extend
the life of the toner cartridge and reduce your cost per page, but
will reduce the print quality.
5.2
MAINTAINING YOUR PRINTER
Redistributing Toner
When toner is low, faded or light areas may appear on a printed
page. You may be able to temporarily improve the print quality
by redistributing the toner. The following procedures may allow
you to finish the current print job before replacing the toner
cartridge.
1 Grasp the front cover and pull it toward you to open.
5
2 Pull the toner cartridge and remove it from the printer.
CAUTIONS:
• Avoid reaching too far into the printer. The fusing area may be
hot.
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of paper,
if left exposed for more than a few minutes and keep it in a flat
and clean place.
MAINTAINING YOUR PRINTER
5.3
3 Gently shake the toner cartridge from side to side five or six
times to redistribute the toner.
NOTE: If toner gets on your clothing, wipe it off with a dry cloth
and wash clothing in cold water. Hot water sets toner into fabric.
4 Reinsert the toner cartridge into the printer. Ensure that the
toner cartridge snaps into place.
5 Close the front cover. Make sure that the cover is securely
closed. If it is not firmly closed, printing errors may occur
when you print.
5.4
MAINTAINING YOUR PRINTER
Replacing the Toner Cartridge
If the print remains light after redistributing the toner (see
page 5.3), replace the toner cartridge.
Remove the old cartridge and install a new toner cartridge. See
“Installing the Toner Cartridge” on page 2.4.
Cleaning the Printer
To maintain print quality, follow the cleaning procedures below
each time the toner cartridge is replaced or if print quality
problems occur.
NOTE: While cleaning the inside of the printer, be careful not to
touch the transfer roller (located underneath the toner cartridge).
Oil from your fingers can cause print quality problems.
CAUTION: Cleaning the cabinet of the printer with surfactants
containing large amounts of alcohol, solvent, or other strong
substances can discolor or crack the cabinet.
Cleaning the Outside
Clean the cabinet of the printer with a soft, lint-free cloth. You
can dampen the cloth slightly with water, but be careful not to
let any water drip onto the printer or inside of
