Complete Datavideo Product Guide - AV

Complete Datavideo Product Guide - AV
SE-800 DV
SE-800 AV
Unit Dimensions/Weight
P
Width:
17 inches, 430 mm
Depth:
16.8 inches, 420 mm
Height:
4.72 inches, 120 mm
Net Weight:
14 lbs, 6.4 kgs
roducers can now shoot, mix, and edit their video all within the DV25 format while
controlling the SE-800’s dissolve, chroma key, and more than 50 built in effects with its
full size keypad, control panel, or remotely via PC.
SDI
Character
Generator
Video Inputs
DV (DV25), Component,
Y/C (S-Video), or
Composite Video.
Video Outputs
DV (DV25), Component,
Y/C (S-Video),
Composite and SDI.
SDI Character Generator
Use Datavideo CG-100,
SDI Character Generator.
SE-800DV Rear View
Component (Y/R-Y/B-Y)
Video Inputs (BNC)
Y/C (S-Video) Inputs
Composite Video Input
(BNC)
DV25 Out
SDI Out (BNC)
..........................................
SE-800 DV
SE-800 AV
Video Inputs
Component,
Y/C (S-Video), or
Composite Video.
Video Outputs
Component,
Y/C (S-Video),
Composite Video.
Audio Line Input, Channels A,B,C,D (RCA)
SDI Overlay In (BNC)
SDI Overlay Out (BNC)
Stereo Aux 1 Audio Input
Stereo Aux 2 Audio Input
Stereo Audio Outputs (RCA)
Monitor Output/
Composite Video
(BNC)
GPI Input
S-Video (Y/C) Out
Composite Video Out (BNC)
Black Burst Out (BNC)
DV Input (FireWire 6 Pin)
Component (Y/R-Y/B-Y) Video Out
(BNC)
Power Switch
RS-232 Control
DC Power Input: 15v @ 4.5a
www.datavideo.us
1
SE-800DV Included Accessories
SE-800AV Included Accessories
CA64 (2), 2266 6/6P, 1.8M (2), 2264 6/4P, 1.8M (2)
GPI Cable (1), Case, Power Cord, Power Supply 110/220
Y/C (S-Video) 4ft/1.22m (2), GPI Cable (1), Case, Power Cord,
Power Supply 110/220
Common Features for SE-800 DV and SE-800 AV
Audio Inputs
4 Stereo pairs and 2 Aux
- Unbalanced audio.
Audio Outputs
2 main and 1 earphone
with volume control.
Voice Sync.
Advance or delay the
audio to match the video.
Joystick
Control RGB or PIP.
Color Processor
Includes RGB adjustment
for white balance. Stores
last setup.
6 Channel Stereo Mixer
Unbalanced in/out.
Use BAC-03 accessory
for balanced audio.
50+ Digital Effects
Dissolve, Cut, Chroma
Key, Mosaic, PIP, Strobe,
Wipe, ect.
Programmable Playback
Save 30 transitions.
Playback by pressing a
single key.
RS-232 Control Protocol
Available on website.
GPI Input
Controls preprogrammed
EFX F01 to F30 in sequence.
FREE TRIAL
NO
GENLOCK
REQUIRED
Network PC Control
See website for details.
www.datavideo.us
No Genlock
Dual channel TBC and
4:2:2 frame synchronizer
built-in.
SE-800 Carrying Case
(Included)
CALL US (562) 696-2324
OR
E-MAIL: [email protected]
SE-800AV Rear View
Component (Y/R-Y/B-Y)
Video Inputs (BNC)
Y/C (S-Video) Inputs
Audio Line Input, Channels A,B,C,D (RCA)
Stereo Aux 1 Audio Input
Stereo Aux 2 Audio Input
Stereo Audio Outputs
(RCA)
Composite Video Input
(BNC)
GPI Input
S-Video (Y/C) Out
Composite Video Out (BNC)
Black Burst Out (BNC)
Component (Y/R-Y/B-Y) Video Out
(BNC)
Power Switch
RS-232 Control
DC Power Input: 15v @ 4.5a
www.datavideo.us
2
SE-800 Accessories
Character
Generator
CG-Software
PPT-100
PowerPoint to DV25 Software.
Use this PC program to convert
PowerPoint or other programs,
to DV25 for editing or as a
switcher source. (P/N PPT-100)
CG-100
This software combined with
a DeckLink card and a PC is a
high quality, easy to use CG.
(P/N CG-100)
TLM-70 LCD Monitor
7” portable LCD monitor with
DV25 and Composite Inputs.
Includes speakers.
(P/N TLM-70)
RMC-140
Next Source - Tally - Quad Split, POP or PIP Preview accessory.
Includes tally lights that mount on your camera.
SE-800 DV
SE-800 AV
MP-6000 DVD RW+Recorder
Burn DVD directly from the
SE-800. This recorder accepts
a DV25 input. (P/N MP-6000)
DV25 Hard Drive Recorder
Burn, Record up to 9 hours of
DV25 for archiving or future
storage. (P/N DN-100)
BAC-03
A powered, bi-directional audio
balanced /unbalanced converter
using active transformers for
best audio response.
(with FireWire)
(without FireWire)
RKM-4N7
6SHFL¿FDWLRQV6('9$9
TWO MODELS
SE-800DV
SE-800AV
DV25 INPUTS (VIDEO & AUDIO)
4
0
COMPOSITE INPUT
4
4
Y/C (S-VIDEO) INPUT
4
COMPONENT INPUT
VIDEO INPUTS
(NTSC and PAL B are separate models)
Color Processing
Brightness +/- 20%,
Contrast +/- 3 dB,
Color +/- 10 dB
4
Signal/Noise Ratio
Video > 55 dB, Audio > 65 dB
4
4
CG, DP
+/- 3%, 3 degree
Audio
THD < 1%
STEREO ANALOG FOR VIDEO (UNBALANCED)
4
4
STEREO (AUX)
2
2
GPI Control
Remote trigger controls preprogrammed
effects from F01 to F30 in sequence
DV25
1
0
Remote Control
RS-232, free PC interface available on
website www.datavideo.us
SDI
1
0
Power
COMPOSITE
1
1
Input: AC 90V to 240V auto sensing
Output: DC 15V/50W
Y/C (S-VIDEO)
1
1
COMPONENT
1
1
STEREO ANALOG (UNBALANCED)
2
2
EARPHONE
1
1
VIDEO MONITOR OUTPUTS COMPOSITE
4
4
AUDIO INPUTS
VIDEO OUTPUTS
AUDIO OUTPUTS
Dimensions/Weight SE-800
17” x 16.8” x 4.72”, 430mm x 420mm x 120mm, 14 lbs/6.4 kgs
SE-800 with TLM-404 and Holder
17” x 18” x 9”, 430mm x 457mm x 229mm, 21 lbs/6.4 kgs
www.datavideo.us
3
SE-800 FAQ
Q: Can it accept four DV25 sources?
A: The SE-800DV does. The SE-800AV
may be upgraded.
Q: Does it also accept four of any other
format?
A: Yes. Both the SE-800 and the SE-800AV
accept Component, Composite, and
Y/C (S-Video).
Q: Do we need TBC’s or Frame Synch’s?
A: No
Q: Is there a problem with audio/video
synch in DV?
A: No problem. You do have to set it.
The instruction book and web site
explain how.
Q: How do you use an external audio
mixer?
A: To use sound from an external audio
mixer, you must connect the mixer to
the A, B, C or D source audio input channels
on the SE-800. You will then need to
disable the DV25 audio stream from the
SE-800. Do not use the AUX input for
audio that you want to synchronize to
video.
Separate the DV25 audio from
the DV25 video so you can
use an external audio mixer.
Connect the mixer input to
channel A, B, C, or D but not
to aux inputs.
1. Press the INPUT FORMAT button. To select
channel A, B, C or D
3. Press the INPUT FORMAT button to exit
and save your current selection.
Note: Connect the output from your
mixing board to channels A, B, C, D only,
or your audio and video will not be in
SYNC. Do not connect it to the AUX input
on the mixer.
Q: What is the warranty?
A: One-year parts and labor. Extenuating
circumstances are always considered.
Q: Does the SE-800 have a Demo mode?
A: Yes. Press and hold the PLAY button to
activate it.
Q: What about HDV and 16:9 cameras?
A: These cameras also output (normal)
DV25. The SE-800 will work with DV25.
Q: Can we use the carrying case as a
shipping case?
A: No, please do not.
4'R\RXFKDUJHIRU¿UPZDUHXSGDWHV"
$1RFKDUJHIRU¿UPZDUHXSGDWHV
Q: How do I set up the audio on the
SE-800 so it does not change when
selecting different video sources?
A: * When the A/V button is not enabled the
audio source does not change when video
channels are changed.
* When a single audio input from a sound
board is used as an audio source, fade
in/out of video would not affect the audio.
In other words, the audio would stay active
and not fade.
* When you turn on the A/V button and
fade from “A” (Audio is present) to a
channel that does not have audio, you will
get a slow fade in the audio. It does not
matter if you fade to a color or fade to video,
the audio will fade out.
Q: What are the sizes of the picture in
Picture Windows?
A: The Small PIP Window has a Width of 185
pixels and a Height of 147 pixels. The Large
PIP Window has a Width of 284 pixels and a
Height of 207 pixels.
Q
A
Q
A
Do we need Genlock?
No, you do not.
What are the frame
rates of the SE-800
dissolve speeds?
2. Press the “SPD” key to
toggle “N” and “Y” .
“Y” enables the DV25 audio on
each DV25 input . “N” disables
the DV25 audio on the DV25
input and enables the analog
line inputs.
A
The RS-232 protocol
is on the web site. We
will work with you.
Using an external audio mixer
Q: Long DV cables?
A: Datavideo guarantees the performance of our
cables when used with our DV25 repeaters,to
carry a DV25 video signal. In other words,
you can use these cables and repeaters to
put your DV25 source 20, 40, 60 meters or
more away from the switcher.
Q
What about RS-232
control via Crestron
or AMX?
Q: Is there a video delay?
A: Yes there is a DV25 delay. This means that
if you are doing I-MAG or projecting a
video image of the speaker, their video
DFWLRQVZLOOEHDERXW¿YHIUDPHVRUWK
of a second later than their real movements.
This is noticeable. There is less of a delay
with Y/C (S-Video) cameras.
Q: What is the advantage of the
Datavideo TLM-404 - 4 LCD display
over the others?
A: (1) Combined with the custom holder, the
Q: What is the advantage of the
Datavideo TLM-404 - 4 LCD display
over the others?
A: (1) Combined with the custom holder, the
Datavideo display is less expensive than
others and uses LCD panels with similar
VSHFL¿FDWLRQV
(2) The controls on the Datavideo
TLM-404 are “recessed” to prevent being
broken off.
(3) The TLM-404 has on/off switches on
the front. With the custom holder, the
monitors can be seen while operating the
controls of the SE-800. This is particularly
important to users who are not operating
this equipment every day.
Speed
Speed
Speed
Speed
Speed
Speed
Speed
Speed
Speed
1
2
3
4
5
6
7
8
9
=
=
=
=
=
=
=
=
=
84 Fr
45 Fr
32 Fr
26 Fr
18 Fr
11 Fr
6 Fr
5 Fr
4 Fr
www.datavideo.us
4
DV cameras were connected to the
SE-800 using 20 meter cables and DV
Repeaters. The camera operators used
headsets to communicate with the
director who was at the SE-800.
The action at this table was seen by
three cameras and edited live. Time
was saved because the emotions
of the moment were enhanced by
being able to see and control the
camera transitions in real time.
The TLM-70 monitor was used to view
program from the SE-800 so the
director, makeup and continuity people
could check everything.
The TLM-404 display with the SE-800 is
bright enough so you can see it outdoors in
a protected area. This allows the director to
see each of the camera outputs, speak with
the shooters and assemble the story as it
happens.
Before the matches begin, the director
reviews with each shooter what is
expected and h o w he w i ll be ma king
production decisions.
The result is a live cablecast delivered
on time and within budget.
www.datavideo.us
5
SE-800 What to Order
7KLVLVDOLVWRIPDQ\RIWKHWKLQJVQHHGHGWRVHWXSDVPDOOVWXGLR:HRIIHULWDVDVSHFL¿FOLVWRI
Datavideo products and a starting point in general.
PRODUCT
MSRP
CAMERAS
SE-800 DV This model accepts four DV or analog video inputs and it includes the SDI overlay card. It also includes
DV, SDI and analog outputs. Carrying case included.
US$ 4,600
SE-800 AV This model accepts four analog video inputs. It does not have the SDI overlay card, the DV input cards
or the DV and SDI output cards. The AV model is upgradable. Carrying case included.
US$ 2,600
SE-800AV Upgrade - SDI Overlay Card to use with the CG-100.
US$ 989
SE-800AV Upgrade – DV Input Card.
US$ 289
SE-800AV Upgrade – DV Output Card.
US$ 549
RKM-4N7 – Monitor Holder (included with the purchase of the TLM-404).
(incl)
TLM-404 –
4 x 4” LCD display will show you each of the inputs to the SE-800. and RKM-4N7 - This holder accommodates the TLM-404. It has included “bolt on” ears that will hold the TLM-702.
US$ 1,550
TLM-702 –
2 x 7” LCD display used with the RMC-140 this dual 7” LCD display will show you the “next” source as
well as the program out.
US$ 850
RMC-140 NextSource & Tally Accessory Accepts a looped video output from the TLM-404 and RS-232 from the SE-800 to select the next source
video and to illuminate up to four included LED tally lights which attach via velcro.
US$ 499
TDXT25 Tally Light Extention Cable 25 ft.
US$ 25
CA22644/6 DV cable
US$ 12
CA2066 - 20 meter DV Cable 6 pin.
US$ 75
VP-314 DV Repeater, self powered. This repeater operates on the 12VDC that is available when connected to the SE-800. Note: Each SE-800DV comes with four adapters that will allow you to connect a 6
pin DV cable to a 4 pin camera.
US$ 60
Analog Video Cables - Be sure to budget for these cables or DV cables.
CG-100 Character Generator Software & DeckLink Card The CG-100 works with a Blackmagic DeckLink card installed in a PC. The DeckLink card is a downstream keyer (DSK) that takes SDI out from the SE-800, keys text and graphics over it and then sends
it back to the SE-800. The website includes a free demo version. Both the website and the product guide
page specify minimum requirements for the computer.
US$ 1,149
PC - For the CG-100 – Don’t forget this item – see CG-100 page for minimum requirements.
ITC-1 - Intercom
This 8 channel cable connected intercom will let one central person contact each or all of up to 8
others. Basic kit includes all that you need for four users and home base. See web/product guide page
for details.
US$ 999
PD-1 - Power Distributor
No more wall warts . PD-1 powers everything around and including the SE-800. See web/product guide
page for details.
US$ 699
External Audio Microphone Mixer - estimated price.
US$ 600
DN-100 DV Bank Recorder We are making a new model of this one and I want you to have that - we’ll have to work out something
fair to both of us.
US$ 1,100
DVK-100 Chromakey - See web/product guide page for details.
US$ 1,200
Background - See web/product guide page for suggestions.
Production / Shipping Cases - See web/product guide page for details.
MP-6000 Direct to DVD burner
US$ 1,299
Datavideo U.S.A.
12300 East Washington Blvd., Suite U, Whittier, CA 90606
Tel: (562) 696-2324
Fax: (562) 698-6930
http://www.datavideo.us
www.datavideo.us 6
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
BAC-03
Balanced Audio Converter
The BAC-03 is a powered, bi-directional audio
level converter. For use with the SE-800 and
in other applications, the BAC-03 will convert
between balanced and unbalanced audio.
2
5.5 inches, 209.55 mm
4.4 inches, 209.55 mm
1.6 inches, 88.9 mm
2 lbs, 2.8 kgs
1
3
#1 – shield
#2 – signal plus
#3 – signal minus
Viewed from Solder Side of Plug / Socket
2
1
2
1
3
3
Plug
Front View
Socket
Rear View
Included Accessories
BAC-03 Audio Converter Unit
AC Adaptor DC 12 V 500MA
Two 5 ft unbalanced audio cable
(Red & White)
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
6.3 inches, 160 mm
3.93 inches, 100 mm
1.95 inches, 49.5 mm
5.36 lbs, 2.5 kgs
Tally Light
RMC-140
Preview / Tally
A next source and preview accessory for the
SE-800 switchers. The RMC-140 will display
your choice of Next Source, Quad Split with
colored indicators, PIP or POP.
The included Tally Lights are connected and
powered by mini phono plugs or via the
Tally Out DB15 connector.
RMC-140 Rear View
RMC-140 Front View
Power connector
(DV12V)
4 Composite Inputs
Display mode selects
(Quad, POP, PIP
and Next)
Tally Light output
Monitor output
Full screen next
source preview
output, Effect and
Tally Light indicators
RS-232 input from
SE-800
RS-232 Bypass
Included Accessories
RMC-140,
RS232 cable x 1
BNC 1.2m cable * 5,
AC/DC Power Adapter DC 12V 1.5 AMP
www.datavideo.us
7
CG-100
Character Generator
PC Minimum Requirements
•
•
•
•
•
•
D
CPU P4 3.0Ghz or above
Memory 512MB or above
Screen Display 1024x768/32 bits colors
OS Windows XP-SP2
DirectX 9.0c
DeckLink Card (for NTSC/PAL B system)
atavideo’s CG-100 software is an affordable CG for the PC with excellent SDI quality.
Based on the Blackmagic DeckLink card, it connects to the SDI Overlay/Graphics
input on the SE-800 or any video switcher that accepts SDI keyed graphics input.
Operation
System Diagram
With this CG software you compose pages before they are used.
)RUH[DPSOH³ORZHUWKLUGV´RUWLWOHV$QG\RXFDQFRPSRVH¿OHV
“off line”.
Blackmagic
DeckLink Card
Installed in PC
The CG-100 can hold many pages, limited only by the
computer’s processor speed and RAM speed and size. If you
have 150-200 pages you will need a faster computer with
more storage than if you have 50 pages.Text positioning may
be done by mouse/eye or by X/Y pixel designation.
Package includes
CG-100 PC software. (Blackmagic card optional)
CG for use with other
switchers
The CG-100 will work with any switcher that accepts the SDI
video and key signal coming from the DeckLink card.
Driver notes
The CG-100 software requires use of the drivers included
with the software.
SDI Overlay Out
SDI Overlay In
SDI Overlay In
SDI Overlay Out
Font Selection
SE-800 Rear Panel
Trial software on website
www.datavideo.us
www.datavideo.us
8
CG-100 Functions
Cooking with Diana
Cooking with Diana
Cooking with Diana
1. Transfer text to CG function
D*HQHUDWHVVXEWLWOHIURPWH[W¿OHV
2. Number Tags for text objects
a. Number tag for each string helps verify
sequence of text samples in sample page
3.Mouse wheel to scroll CG pages
a. Perfect to display subtitles
4. Targa sequence
a. Export 3D animations or motion pictures
DVDVHTXHQFHRIWDUJD¿OHV
b. Prepare Targa sequence
c. Adjust size and position of Targa
sequence on screen
d. Set Targa sequence as background
e. Clear Targa sequence
f. Add Targa sequence
5. Clock
a. Insert a clock object on screen
b. Selectable time format
c. Adjust clock layout, text size, color and
position
6. Timer / Stop Watch
7. Logo Generator
a. a special plug-in application
b. Five independent layers of titles and graphics.
c. One CG sample page to allocate the positions
and colors of Targa sequence, logo, Roll
/Crawl strings
d. Twenty three CG backgrounds for Logos,
Titles or other Graphics
e. One upper layer of animated Targa sequence.
f. One upper layer of a still Targa graphic for
TV Channel’s logo
g. Two top layers of Roll/Crawl objects for
emergency messages
8. System Buttons
a. Zoom before play
b. Clean
c. Settings
d. On line help
e. Switch between Logo Generator and
CG-100 layout editing mode
9. Logo Pages
D6HHWKH¿UVWSDJHVDVLFRQVDIWHUD
9&*¿OHLVRSHQHG
10. Setup Templates
a. TV Channel’s logo
b. Still Targa or Targa sequences
13. Add background CG-100 pages
a. Set additional background CG pages
b. Add banner’s background, images,
wordings etc
c. Set different “animation boxes” to create
a background page
14. Commercial break
4XLFN/2*20RGL¿FDWLRQ
a. Directly edit the parameters of all Logo
page icons
11. Add Crawl
a. Two horizontal and two vertical crawls
12. Add a TV Channel’s logo
16. GPI Trigger
a. Set GPI to trigger animation objects like
wipe, push, fade etc
17. DL Renderer
Resident software for DeckLink card
18. Hot Keys
a. To edit CG pages conveniently
www.datavideo.us
9
FireWire
Out
PPT
100
PPT-100
Scan Converter Software
DV25 out from computer to
DV25 switcher
PC Minimum Requirements
•
•
•
•
•
CPU P4 3.0Ghz or above
Memory 512MB or above
Screen Display 1024x768/32 bits colors
OS Windows XP-SP2
DirectX 9.0c
PPT-100 is a Scan Converter software
that converts VGA display of your
computer to DV25 video. It works with
PowerPoint, Word, Excel, etc.
Note: Because this is a software only
solution, the speed and RAM of your
computer will affect performance.
We recommend that you test the trial
version on our web site.
www.datavideo.us
SE-800 Remote Control
Local & Network via PC
RS 232-L
RMC-120
The entire SE-800 is on your PC desktop.
Works with Window 2000 and XP.
This software only solution is available for
free. Please visit our website to download.
PC/NETWORK control of the SE-800. Works with
Window 2000 and XP.
Firmware upgrade may be needed. Available free.
Please visit our website for more details.
www.datavideo.us
10
7/06SHFL¿FDWLRQV
VIDEO I/O
VIDEO FORMATS
Composite Video
1.0Vp-p, 75 ohm/
Loop-through with
75 ohm self terminated,
1.0Vp-p output at
75 ohm load
Contrast, Brightness,
Color and Tint (NTSC only)
Composite Video
NTSC/PAL B
VIDEO STD NTSC/PAL B
TALLY
auto-sensing
Yes
LCD DISPLAY
4” TFT/LCD
Active Matrix
480 x 234 pixels.
VIDEO CONTROLS
TLM-404
LCD Monitor
The TLM-404 has four 4” TFT/LCD displays in a
2U, tilting, 19” rackmount. It can tilt +/- 30° and
lock in any position. Controls include: Contrast,
Brightness, Color, and Tint (NTSC only) Composite
Video.
RESOLUTION
VIEWING ANGLE
TLM-404 Tilts
TLM-404 Video Loop
Top:40°, Bottom:60°,
Left: 60°, Right: 60°.
[email protected]
POWER INPUT
Unit Dimensions/Weight
Included Accessories
Allen Wrench (1.5 mm)
Allen Wrench (2.5 mm)
Instruction Manual (1)
BNC Cable 4ft/1.22m (4)
Power Adapter (1)
Power Cord (1)
Width:
Depth:
Height:
Net Weight:
19 inches, 482.6 mm
3 inches, 76.2 mm
3.5 inches, 88.9 mm
4 lbs, 2.0 kgs
TLM-404
Power
Switch
Recessed Controls
SE-800 Monitor Out
Each video input module
has a Composite Output
that can connect to the
TLM-404
7/06SHFL¿FDWLRQV
VIDEO I/O
VIDEO CONTROLS
TLM-702
7” x 2 TFT LCD Monitor
The TLM-702 has four 4” TFT/LCD displays in a
4U, tilting, 19” rackmount. It can tilt +/- 30° and
lock in any position. Controls include: Contrast,
Brightness, Color, and Tint (NTSC only) Composite
Video.
VIDEO FORMATS
4* Composite Video
4:3, 16:9, Flip Mirror
Image, Source Select,
Brightness, Contrast,
Color, Tint (NTSC
ONLY)
NTSC/PAL B
VIDEO STD NTSC/PAL B
TALLY
auto-sensing
Yes
LCD DISPLAY
7” TFT LCD,
Active Matrix
1440 X 234 Pixels
500 CD/MX2
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
VIEWING ANGLE
POWER INPUT
300:1
Top:40°, Bottom:60°,
Left: 60°, Right: 60°.
DC12V/20W
(10.8 to 13.2 Volts)
Power: 12 VDC Input
Controls: Tally Lights
OPERATING ENVIRONMENT
0°C to 50°C, RH less than 90%.
Unit Dimensions/Weight
Included Accessories
Allen Wrench (1.5 mm)
Allen Wrench (2.5 mm)
Instruction Manual (1)
BNC Cable 4ft/1.22m (4)
Power Adapter (1)
Power Cord (1)
Width:
Depth:
Height:
Net Weight:
19 inches, 482.6 mm
2.5 inches, 63.5 mm
5.25 inches, 133.4 mm
5 lbs, 2.3 kgs
TLM-702 Tilts
Space saving connectors on the rear
Controls: Tint, Color,
Contrast, Brightness
www.datavideo.us 11
This part of the holder (P/N RKM-477) is
an included attachment that bolts on to
the main holder. It is suggested for use
with the TLM-702 dual 7” monitors.
RKM-4N7
RKM-572
TLM-350
TLM-350
TLM-350
TLM-350
7/06SHFL¿FDWLRQV
VIDEO I/O
2 x Composite Video / None
VIDEO CONTROLS
Source Select, Brightness, Mirror
VIDEO FORMATS
NTSC/PAL B
VIDEO STD NTSC/PAL B
auto-sensing
TALLY
No
Included Accessories
Ball Head (BH-05),
Li-Battery (1)
Battery charger,
Small battery bag
Carrying Case
Male to male DC cable
SUNSHADE
LCD DISPLAY
3.5” TFT LCD, Active Matrix
RESOLUTION
480 X 234 Pixels
BRIGHTNESS
250 CD/MX2
CONTRAST RATIO
350:1
VIEWING ANGLE
Top:15°, Bottom: 35°,
Left: 50°, Right: 50°.
POWER INPUT
DC12V/3.6W (10.8 to 13.2 Volts)
TLM-350
TFT LCD MONITOR
A small Composite Video monitor that tilts and
twists in any direction. Includes a sunshade,
12v battery, nylon carry case and a small ball
head that will mount in a camera shoe. It
operates on 12 VDC.
OPERATING ENVIRONMENT
Operating temperature From
0°C to 50°C, RH less than 90%.
Case and a BH-05 Ball head
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
3.5 inches, 88.9 mm
.88 inches, 22 mm
3.2 inches, 81.3 mm
.5 lbs, .23 kgs
www.datavideo.us 12
7/0'6SHFL¿FDWLRQV
VIDEO I/O
1394 DV25, Composite Video/
1394 DV25, Composite Video
( Looped or converted from DV25)
VIDEO CONTROLS
4:3, 16:9, Flip mirror Image,
Source Select, Brightness,
Contrast, Color, Tint (only in NTSC).
7.5/ 0 IRE
Switchable
TLM-70D
7” DV Input LCD Monitor
The TLM-70D is a portable, DV25 input monitor
with removable stereo speakers and a small audio
amp. It includes a built in DV25/Analog converter
that will let you connect additional monitors or
test instruments.
Back View
Included Accessories
Power Supply 110/220 12VDC
BNC 4ft/1.22m (1)
2266 6/6p,1.8m(1)
2264 6/4p,1.8m(1)
Power Cord
Carrying Case
VIDEO STD NTSC/PAL B
auto-sensing
TALLY
Yes
AUDIO INPUTS
Unbalanced RCA, Audio in the DV25 stream.
AUDIO OUTPUTS
Unbalanced RCA, Audio in the DV25 stream,
Earphone, 1W additional speakers.
AUDIO CONTROLS
Earphone & speaker level.
LCD DISPLAY
7” TFT LCD, Active Matrix
RESOLUTION
480 X 234 Pixels
BRIGHTNESS
300 NITS
Removable sunshade
1/4x20
threaded
hole for
tripot screw
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
7.5
2.5
5.5
3.5
inches, 190.5 mm
inches, 63.5 mm
inches, 139.7 mm
lbs, 1.8 kgs
Tilting
handle
7/06SHFL¿FDWLRQV
Included Accessories
VIDEO I/O
2 x Composite Video / None
VIDEO CONTROLS
Source Select, Brightness, Mirror
Tint (only in NTSC)
VIDEO FORMATS
NTSC/PAL B
Power Supply 110/220 12VDC
BNC 4ft/1.22m (1)
Power Cord
VIDEO STD NTSC/PAL B
auto-sensing
TALLY
No
Removable Sunshade
TINT (only in NTSC)
TLM-700
LCD DISPLAY
3.5” TFT LCD, Active Matrix
RESOLUTION
480 X 234 Pixels
BRIGHTNESS
250 CD/MX2
The TLM-700 is a portable, analog input
monitor with two Composite Video inputs.
CONTRAST RATIO
350:1
VIEWING ANGLE
Top:15°, Bottom: 35°,
Left: 50°, Right: 50°.
7”TFT LCD Monitor
Back View
Carrying Case
POWER INPUT
DC12V/3.6W (10.8 to 13.2 Volts)
OPERATING ENVIRONMENT
Operating temperature from
0°C to 50°C, RH less than 90%
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
5 inches, 127 mm
1.5 inches, 38.1 mm
7.26inches, 184.4 mm
1.5 lbs, 0.8kgs
Tripod Screw
www.datavideo.us 13
DV
Cables
4 male/6 female adapter
0.3m/12 inches, P/N CA64,
4 male to 6 female
This cable will connect a 4 pin
jack on a camera or recorder
with a 6 pin cable.
FireWire Cables for 200 MBPS Video
1.8m/5.91 feet P/N CA2264, 4 male to 6 male
1.8m/5.91 feet P/N CA2266, 6 male to 6 male
10m/30 feet, P/N CA1066, 6 male to 6 male
20m/60 feet, P/N CA2066, 6 male to 6 male
Cable length is no longer
a reason for not shooting
FireWire. These cables are
rugged and guaranteed to
work with DV25. For extended lengths in harsh
environments, we suggest
covering the repeaters with
heat shrink tubing.
20M
20M
You may join Datavideo brand DV25 cables with
our DV Repeaters and separate your DV25
devices by hundreds of feet.
60m = 196.85 feet
20M
VP-314 DV Repeater
The VP-314 receives its power from another
device in the DV25 Stream. For example, the
SE-800 or all of the DAC format converters
add power through the 6 pin connector.
Cameras with 4 pin connectors do not add
power. Some cameras with 6 pin connectors
may add power.
Unit Dimensions/Weight
Width: 5.75 inches, 146 mm
Depth: 0.75 inches, 19 mm
Height: 1.375 inches, 35 mm
Net Weight: 4 ounces, 113 gr
DV
Repeaters
SE-800
Camera
DV Bank
TLM-70 DV Monitor
Computer
DN-100 DV Recorder
VP-332 DV Repeater
The VP-332 DV repeater must be used with one
DV25 input only. It will take a single input and
³UHVHQG´LWWRWKH¿YHRWKHUSRUWVRQWKHXQLW
Because it is expecting just one “source”, there
ZLOOEHDGHYLFHFRQÀLFWLI\RXFRQQHFWWZR
cameras or other devices that present
themselves as sources.
Unit Dimensions/Weight
Width: 4 inches, 98 mm
Depth: 2 inches, 52 mm
Height: .75 inches, 18 mm
Net Weight: 2.5 ounces, 70 gr
www.datavideo.us 14
Jog Wheel
will control the
DV Bank as
a VTR
0-17V DC
DC to DC Converter
lets the
DV- Bank work with
any battery from10
to 17 VDC
110 VAC
Power Supply
(included)
GPI Adapter
Record and Play
Intervalometer
Record time lapse
or single fRAMes
Video Editor
DN-100
DAC-100
DAC-10
Output DV Bank to
Composite Monitor
or VHS deck
DAC-30 Bi-Directional
DV25 to Betacam converters.
Optional SDI, balanced
audio, etc.
DV Recorder
Infrared
Remote
The DV Bank is an instant on, easy to use
FireWire video recorder/player with a built in
hard drive.
VTR-like controls with large, illuminated buttons,
and a two line backlit LCD display let the user
select play, record, rewind, fast forward, fast
UHYHUVHSDXVHIUDPHDGYDQFH¿OHVHOHFWLRQ
¿OHGHOHWHDQGORRSSOD\
Its FireWire (IEEE-1394) interface allows direct
capture from digital camcorders, other digital
sources.
Betacam Deck Mini DV
camera records
directly to
DV Bank
Record to DV Bank
from Hi 8 or S-VHS
Camera
DAC-100
Bi-Directional Analog to
DV25 to Analog video
converter Also can import
to DV25 or export to a
monitor or VCR
DV Bank
Infrared Remote
DC Stabilizer
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
6.7 inches, 170 mm
10 inches, 254 mm
2.8 inches, 70 mm
4.5 lbs, 2.0 kgs
Included Accessories
DAC-10
Download Cable (2), Power Cord,
2266 6/6P, 1.8M (1), 2264 6/4P, 1.8M (1)
Power Supply 110/220 12VDC
Remote Control
Compatible
Accessories
TL-1
Intervalometer
Time Lapse Controller
EZ Cut Edit
Software
ANALOG
DAC Format Converters All DAC’s are available for a
FREE DEMO call (562) 696-2324
E-mail: [email protected]
SMART DV
HOW MANY DV JACKS?
DAC-200
DAC-30
DAC-15
DAC-6
DAC-5
YES
YES
YES
NO
NO
2
3
2
2
2
Y/C (S-Video) & COMPOSITE IN & OUT
YES
YES
YES
OUT ONLY
OUT ONLY
COMPONENT (Y/R-Y/B-Y) I/O (BETACAM)
NO
YES
YES
OUT ONLY
OUT ONLY
COLOR PROCESSOR CONTROL
NO
YES
YES
NO
NO
AUDIO INPUT LEVEL CONTROL
NO
YES
YES
NO
NO
NTSC/PAL B SELECTABLE
YES
YES
YES
YES
YES
0/7.5 IRE SELECTABLE
YES
YES
YES
YES
YES
BALANCED AUDIO IN/OUT
NO
YES
NO
NO
NO
UNBALANCED AUDIO IN/OUT
YES
YES
YES
NO
OUT
AUDIO METERS
NO
YES
YES
NO
NO
TBC BUILT-IN
NO
YES
NO
NO
NO
SDI IN & OUT (SMPTE 259M)
NO
YES
NO
NO
YES
COLOR BAR GENERATOR
YES
YES
YES
NO
NO
RS-422 INTERFACE
NO
YES
YES
NO
NO
BLACK BURST OUT
NO
YES
YES
NO
YES
LOCKED/UNLOCKED AUDIO
YES
YES
YES
YES
YES
DC5V/6W
DC12V/18W
DC12V/10W
DC12V/6W
DC12V/12W
NO
DAC-30R MODEL
YES
NO
YES
6.15” X 6.0” X 1.6”
0.88 LBS
8” X 10.25” X 5.25”
7 LBS
8.25” X 8.25” X 3.5”
4 LBS
4” X 6.5” X 2”
1 LBS
8.25” X 8.25” X 3.5”
4 LBS
POWER
RACKMOUNT
UNIT DIMENSIONS/WEIGHT
Composite.
S-Video
Unbalanced Audio
Bidirectional
Unit Dimensions/Weight
DAC-200
Media Format Converter
Bi-Directional DV25/Analog Video – Y/C (S-Video),
Composite Video, NTSC/PAL B selectable, and
selectable audio sampling rate.
Width:
Depth:
Height:
Net Weight:
6 inches, 15.5 mm
6 inches, 15.5 mm
1.5 inches, 3.5 mm
.5 lbs, .4 kgs
Features
SELECTABLE VIDEO STANDARD
NTSC (525 lines / 60Hz),
PAL B (625 lines/50Hz)
Inputs
DV25, Y/C (S-Video), Composite.
Outputs
DV25, Y/C (S-Video), Composite.
Selectable video level, at 0 IRE or 7.5 IRE.
9LGHR FRPE ¿OWHU IRU KLJK TXDOLW\ YLGHR
Video input source auto-detection.
AUDIO SAMPLING RATE
Selectable 32KHz (12-bit) or 48 KHz
(16-bit) for unbalanced audio.
COMPUTERS
Macs, Windows 98 / ME / 2000 and XP.
Included Accessories
2264 6/4P, 1.8m (1)
RCA 5ft/1.52m (1)
Power Supply 110/220 5VDC
S-Video 4ft/1.22m (1)
Analog Audio
Output
audio RCA
connectors.
Composite
Video
Output
FireWire Input/Output
S-Video
Output
S-Video Input
Dip
Switches
FireWire
Input/Output
Composite Video Input
School Studio
Rationale:
Support for schools:
www.datavideo.us 16
SDI
Bidirectional
AES/EBU Audio
Analog Audio
Component Out
Unbalanced Audio (Monitor)
Unit Dimensions/Weight
DAC-5
SDI to/from DV Digital
Video Converter
Width:
Depth:
Height:
Net Weight:
8.25 inches, 209.55 mm
8.25 inches, 209.55 mm
3.5 inches, 88.9 mm
6 lbs, 2.8 kgs
12 Bit or 16
Bit Audio
SDI or DV25 Input
Component
Output (YUV)
Digital Audio I/O
DAC–5 converts SDI video and AES/EBU audio
to and from FireWire DV25 audio/video. The
DVITC timecode in the output signal respects
the same standard as the one in the input
signal.
Included Accessories
2264 6/4P, 1.8m (1),
2266 6/4P, 1.8m (1)
BNC 4ft/1.22m (4),
RCA 5ft/1.52m (1),
AES Adaptor (1),
Y/C (S-Video) 4ft/1.22m (1),
Power Supply 110/220 12VDC
Blackburst
Output
Dip Switches
PAL B/NTSC,
0/7.5 IRE
Digital: DV I/O
Video & Audio Monitoring
IN
Digital: SDI I/O
Composite Out
Component Out
S-Video Out
Unbalanced Stereo Audio Out
Unit Dimensions/Weight
DAC-6
Width:
Depth:
Height:
Net Weight:
4 inches, 101.6 mm
6.5 inches, 165.1 mm
2 inches, 50.8 mm
1 lbs, 0.45 kgs
Y/C (S-Video)
Output
Audio
One way DV to Analog
Video Converter
Included Accessories
Component
Output
RCA 5ft/1.52m (1)
Y/C (S-Video) 4ft/1.22m (1)
BNC 4ft/1.22m (3)
2266 6/4P, 1.8m (1)
Power Supply 110/220 12VDC
Composite Output
www.datavideo.us 17
Composite
Y.U.V.
S-Video
Unbalanced Audio
Bidirectional
Unit Dimensions/Weight
DAC-15
Media Format Converter
Width:
Depth:
Height:
Net Weight:
8.25 inches, 209.55 mm
8.25 inches, 209.55 mm
3.5 inches, 88.9 mm
6 lbs, 2.8 kgs
Color Adjustment
Works on all
formats Audio
Input Level
Push Buttons to
Select Video
Input & Output
Bi-Directional DV25/Analog Video – YUV Y/C (SVideo), and Composite Video features: Audio Level,
Video Color Adjustments, Blackburst Generator,
NTSC/PAL B selectable and more.
Analog Video
Blackburst Output
Digital:
DV25 (IEEE 1394)
I/O
Component Video
(Y/R-Y/B-Y) I/O
RS-422 control
Included Accessories
2264 6/4P, 1.8m (1)
2266 6/4P, 1.8m (1)
BNC 4ft/1.22m (4)
RCA 5ft/1.52m (1)
Y/C (S-Video) 4ft/1.22m (1)
Power Supply 110/220 12VDC
Composite Video I/O
Y/C (S-Video) I/O
Unbalanced Audio I/O
Bidirectional
Rackmount for Two DAC-10’s
Component
Composite
S-Video
SDI
Balanced Audio
Unbalanced Audio
DAC-30 Unit Dimensions/Weight
DAC-30
Media Format Converter
Bi-Directional DV25/Analog Video - SDI, YUV Y/C
(S-Video), and Composite with Balanced Audio.
Features: Audio Level Adjustment, Video Color
Adjustments, Black Burst Generator, NTSC/PAL B
selectable, RS422 and more. Available in rackPRXQWRUGHVNWRSFRQ¿JXUDWLRQ
Included Accessories
2264 6/4P, 1.8m (1), 2266 6/4P, 1.8m (1)
BNC 4ft/1.22m (4), RCA 5ft/1.52m (1)
Y/C (S-Video) 4ft/1.22m (1), Power Cord,
Power Supply 110/220 12VDC
Digital AES Adaptor (1), Serial 9PIN (1)
Width:
Depth:
Height:
Net Weight:
8 inches, 205 mm
9.8 inches, 250 mm
5.2 inches, 132 mm
6 lbs, 2.8 kgs
DAC-30R Unit Dimensions/Weight
Width:
17 inches, 431.8 mm
Depth:
11.37 inches, 288.93 mm
Height:
3.5 inches, 88.9 mm
Net Weight:
8 lbs, 3.8 kgs
Audio Input Level
Meters
Analog & Digital
Video Input
Color Adjustment
Audio Input Level
RS-232 Control
AES/EBU
Audio: Balanced Audio I/O,
Unbalanced Audio I/O
DAC-30R
Composite Video
I/O, Y/C (S-Video)
Component Video
output (Y/R-Y/B-Y)
Black Burst Output
Component Video
Input (Y/R-Y/B-Y)
SDI I/O
www.datavideo.us 18
6(6SHFL¿FDWLRQV
VIDEO IN
4 Composite or Y/C (S-Video)
VIDEO OUT
2 Composite and 1 Y/C (S-Video)
VIDEO MONITOR OUT
1 Quad preview
SE-500
4 Input Switcher
Everything you need to switch and monitor four
Composite or Y/C (S-Video) sources. Sophisticated monitor functions show you quad, split,
next source and next effect. This small, rugged
switcher is ideal for educational and security
applications.
Included Accessories
VIDEO OUT OPTION
Two Composite Video outputs.
The monitor out may be reassigned as
a component (Y/R-Y/B-Y) output
VIDEO TALLY OUT
DB15 connector
RS232 CONTROL
DB9 connector
AUDIO IN
2 line level, unbalanced,
2 microphone 1/4”
AUDIO OUT
2 line level, unbalanced
Wipe Patterns
No Genlock Required
Dual channel TBC and
4:2:2 frame synchronizer
built-in.
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
15.7 inches, 400 mm
9.8 inches, 250 mm
3.2 inches, 80 mm
4.4 lbs, 2.0 kgs
QUAD
B.G.
SPLIT
BORDER
PIP
PREVIEW
FREEZE
Y/C (S-Video) 4ft/1.22m (1) BNC to RCA (2)
BNC to RCA Connector (2)
RCA Stereo (1) YUV Cable (1)
Power Supply 110/220 12VDC
Preview Out
Source Status:
Program=Red,
Next=Yellow
Effect:
Select Effect,
BKG:
Selected Color
Digital Effects
A/B Roll, A/B Dissolve, Quad,
Freeze, Split, PIP with Borders.
Two PIP size with borders:
Small PIP: 243(W) x 162 (H)
Large PIP: 288(W) x 194 (H)
Accessories
DAC-6
RS-232 Control
Tally Out
MIDI Control
Microphone Inputs
Audio I/O
12V DC in 1.5 amp
Preview out, Selects
between Sub
Source or Effect
4 Inputs Composite Video or
S-Video
DVK-100
RKM-572
3 Outputs, 1 Y/C (S-Video),
2 Composite, Preview
and Composite Outputs
may be assigned as
(Y/R-Y/B-Y)
Component Out
TLM-702
Y/C (S-video)
Cables
TB-5
Tally box for SE-500
includes 4 LED tally lights
that attach to any camera
SE-500 Rear View
4 Inputs -Composite Video or
Y/C (S-Video)
Preview out Selects between
Sub Source or Effect
Preview and Composite Outputs
may be assigned as (Y/R-Y/B-Y)
Component Out
12 V DC in 1.5 amp
Audio I/O
Use the DVK-100 to make video of an imaginary motorcycle ride and
include an introductory video at the beginning of the DVD.
BACKGROUND
VIDEO SOURCE
INTRODUCTORY VIDEO
MESSAGE SOURCE
MO
N
MOT ITOR F
OR
OCY
TO
SEE CLE R
IDE
CAMERA
RS
DVK-100 CHROMA KEY
SE-500, TLM-702,
RKM-572
MP-6000 DVD RECORDER
TO RECORD FINAL PRODUCT
www.datavideo.us 20
SE-500 What to Order
7KLVLVDOLVWRIPDQ\RIWKHWKLQJVQHHGHGWRVHWXSDVPDOOVWXGLR:HRIIHULWDVDVSHFL¿FOLVWRI
Datavideo products and a starting point in general.
PRODUCT
MSRP
LIGHTS
SE-500
This model accepts four analog Composite or Y/C (S-Video) inputs (NTSC).
US$ 1,050
TLM-702 Monitor & Holder Kit SE-500
US$ 1,150
TLM-702 Monitor 2 x 7” LCD display used with the RMC-140 this dual 7” LCD display will show you the “next” source as
well as the program out.
US$ 850
CA22644/6 DV cable
US$ 12
CA2066 - 20 meter DV Cable 6 pin.
US$ 75
VP-314 DV Repeater, self powered. This repeater operates on the 12VDC that is available when connected to the SE-800. Note: Each SE-800DV comes with four adapters that will allow you to connect a 6
pin DV cable to a 4 pin camera.
US$ 60
Analog Video Cables - Be sure to budget for these cables or DV cables.
TB-5 Tally Box for SE-500
US$ 149
TDXT25 Tally Light Extention Cable 25 ft.
US$ 25
DAC-6 Converts DV to Y/C (S-Video) for input to SE-500
US$ 249
ITC-1 - Intercom
This 8 channel cable connected intercom will let one central person contact each or all of up to 8
others. Basic kit includes all that you need for four users and home base. See web/product guide page
for details.
US$ 999
PD-1 - Power Distributor
No more wall warts . PD-1 powers everything around and including the SE-800. See web/product guide
page for details.
US$ 699
DVK-100 Chromakey - See web/product guide page for details.
US$ 1,200
Background - See web/product guide page for suggestions.
Production / Shipping Cases - See web/product guide page for details.
CG-100 Character Generator Software & DeckLink Card The CG-100 works with a Blackmagic DeckLink PRO card installed in a PC. The system may be set up as
a downstream keyer (DSK) to take Y/C (S-Video) out from the SE-500 or as an upstream keyer to place
text over one incoming Y/C (S-Video) source.
US$ 1,499
PC - For the CG-100 - Don’t forget this item - see CG-100 page for minimum requirements.
MP-6000 Direct to DVD burner
US$ 1,299
www.datavideo.us 21
6SHFL¿FDWLRQV
Features
3 INPUTS:
* 2 camcorder inputs for foreground and
1 for background input.
* Key out background, color selectable
(Blue,Green, or luminance).
CAM-1/CAM-2 INPUT-For foreground use (FG)
BG INPUT-- For background use (BG)
DVK-100
Chroma Key
Can you believe it? US$ 1,200 for a Y/C
(S-Video) / Composite Chromakey. It’s
available for demo. Just ask your favorite
reseller.
Included Accessories
BNC 4ft/1.22m (1)
Y/C (S-Video) 4ft/1.22m (2)
Power Supply
EACH INPUT CAN SELECT COMPOSITE
OR Y/C (S-Video) SIGNAL:
Y/C (S-Video) in 4-pin 75 ohm DIN Connector Composite in 75 ohm RCA connector,
level: 1.0Vp-p
Output:
SIMULTANEOUS OUTPUT:
1 Y/C (S-Video) out
2 Composite out
OUTPUT MODE:
FG or FG with BG: Choose Chroma key ON or OFF
LOOP THROUGH OUT:
Composite out from Y/C (S-Video) in or
Composite in Y/C (S-Video) out from Y/C
(S-Video) in only
General
POWER INPUT DC:
12V/1.5A (AC adapter included)
RS-232 & GPI INTERFACE:
for remote control
AMBIENT HUMIDITY:
Less than 90%
*Key out level, adjustable to reduce
shadow after keying.
* Y/C (S-Video) and Composite input and
output.
:LQGRZDGMXVWDEOHWR¿WGLIIHUHQWVL]HV
of background screen.
* Built-in Shrink function (Reduce white
or black color edge on subject.)
* Built-in Spill function
(Adjust spill suppression.)
* Built in Density (Adjust selected color
key transparency.)
* Built-in Color Processor, Brightness,
Contrast, Color, and Tint adjustable
(Tint is NTSC only)
* Built in TBC
* RS-232 interface for control from other
RS232 devices.
* GPI trigger interface for switching two
different camera foreground sources.
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
8.25 inches, 210 mm
8.25 inches, 210 mm
3.5 inches, 88.9 mm
4 lbs, 2 kgs
Rear View
CB-2 Y/C (S-Video)
to BNC Adapter
Use two of these adapters
when you need a long
Y/C (S-Video) cable
run and want the best
quality.
Selectable
Background
Window Crop
Adjust the size of the
area that is cropped by
the chromakey.
Edge Halo Shrink
Function
Built in edge halo shrink
function (reduce white
or black color edge on
subject)
Uses Y/C (S-Video)
DV25 compresses and combines color and luminance
information into small data packages for convenient
transmission and storage. Decompressing for a
chromakey adds cost without quality. A component
video like “Y/C (S-Video)” is better for chromakey.
2 Camera Input and 1 Background Input
With two camera inputs, you can seamlessly cut
between a full shot and a close up while you keep
the background. This can make your video more
believable. Includes a GPI trigger to switch between
sources. The video signal loops through the
DVK-100 so you can monitor each camera before
cutting between them.
Selectable Background Colors
Uses standard BLUE, GREEN or BLACK backgrounds
RUVSHFLDORQHVZLWKUHWURUHÀHFWLYHVFUHHQVDQGOHG
rings around the lens.
Build in Color
Processor & TBC
Limited color tweak
capabilities and TBC.
Use DV Add a DAC-200
MSRP for the DAC-200
is US$200
www.datavideo.us 22
+
=
+
=
Using the Datavideo DVK-100
Chromakey can add a sense of
fun and interest to
any video presentation.
www.datavideo.us 23
Getting Optimum Chromakey Results
.
Background Types
Natural lighting for the people
A Chromakey works by recognizing a single video color (blue, green
or black and replacing those pixels with a background image.
We are used to seeing each other
ZLWK D PDLQ RU NH\ VRXUFH DQG D ¿OO
source. Flat lighting on the people
will appear less natural. You should
be able to light the people without
affecting the background.
BACKGROUND
BA
GRO
LIGHT
T
Paper
Paper is the easiest, least expensive and fastest temporary solution.
In the US, the primary manufacturer is Savage.
www.savagepaper.com
Paint
Paint is the easiest permanent solution.
The main US manufacturer is Rosco.
http://www.rosco.com
FILL LIGHT
The KEY LIGHT is about 2-3x
brighter than the FILL LIGHT
Balance the light levels
You will get better results if the light on the background and the
light on the subject are of similar brightness levels.
+RPH 6XSSO\ VWRUH SDLQW LV XVXDOO\ QRW RSWLPL]HG IRU ORZ UHÀHFWLRQ
Cloth
Regular cloth and foam backed cloth are available.
The regular cloth is a smaller package but requires that you remove
the wrinkles before use.
The foam backed material does not show wrinkles and is easy to use.
Cyclorama
$ IRUPHG EDFNJURXQG WKDW FXUYHV EHWZHHQ WKH ZDOOV DQG ÀRRU
This is a more permanent solution although portable ones are available.
5HWURUHÀHFWLYH %DFNJURXQGV
8VLQJ WKH VDPH WKHRU\ DV WUDI¿F VLJQV WKLV PDWHULDO UHÀHFWV OLJKW
back toward the source where it came from. With a ring of LED’s
surrounding the camera lens you can use a small amount of light
to illuminate just what the camera sees. Usually it will help if you
“back light” the subject(s) to make it easier for the chromakey to
distinguish between background and foreground.
Wide Angle lenses – yes or no?
Camera lens focal length will affect
the size of the background you
must use. A wide angle lens
requires a larger background.
Light brightness
Light brightness is like sound. The closer you are to the
source, the more there is.
Light spreads out rapidly with distance.
DISTANCE = 1 UNIT
DISTANCE = 2 UNITS
When the distance from the source to the subject is doubled,
the light on the subject is reduced to 1/4 or 25%.
With more light, the camera electronics will work less (theoretically)
the signal has less noise. Less expensive cameras can look
better with more light. More light also means that the lens is
VWRSSHG GRZQ PRUH DQG WKDW WKH GHSWK RI ¿HOG LV JUHDWHU LH±
more is in focus.
Light vocabulary
One footcandle is the illuminance at a point on a surface which is one
foot from, and perpendicular to, a uniform point source of one candela.
WIDE ANGLE LENS
Lighting
You can quickly get the best results by being able to measure and
control your lights. In general we suggest that more light is better
than less light but it must be well balanced, i.e. a bright background
and dim subject will not give optimum results.
How do you measure lighting?
Use a light meter. The idea is to get even illumination on the
background. Do not use your eyes to judge the evenness of
illumination.Once you have the best illumination you can get,
then you can adjust the Chromakey
to compensate for differences.
Flat lighting for the background.
Chromakeys work best with lots
RI ÀDWHYHQ OLJKW ,W PD\ EH
GLI¿FXOW WR LOOXPLQDWH WKH ZKROH
background so it is even. The
DVK-100 may be adjusted to crop
out all except the area behind the
people or objects that you want to
separate (from the background).
KEY LIGHT
One lux is the illuminance at the same point at a distance of
1 meter from the source.
One lumen uniformly distributed over one square foot of surface
provides an illumination of 1 footcandle.
If you work in feet, your results will be in footcandles (1 footcandle = 1 lumen/square ft.)
If you work in meters, your results will be in lux (1 lux = 1 lumen/square meter)
The edge that separates the foreground from the colored
background.
We suggest that you experiment with the illumination ratios using
your particular screen and setup.
If the green/blue screen is brighter than the subject, what does the
edge look like?
If they are about equal, what does the edge look like?
How does lighting the back of the subject affect the edge?
DVK-100 Instruction book
We’ve given you concepts and ideas.
Please read the instruction book for the best results from
your Datavideo DVK-100.
www.datavideo.us 24
Functions
Features
* Real Time Stand Alone DVD Recorder/
Player.
* VTR Controls and Formats.
* Built in Video Processor with Color
Correction.
* Variable Bit Rate Recording.
* RS-232 Remote Interface.
* Direct to DVD Recording.
MP-6000
Automatic/Manual Chapter insertion,
Disc Write, Protection, Instant Content
Menu Access, Selectable Index Pictures.
Included Accessories
2264 6/4P, 1.8m (1)
2266 6/4P, 1.8m (1)
BNC 4ft/1.22m (4)
RCA 5ft/1.52m (1)
Y/C (S-Video) 4ft/1.22m (1)
Power Cord
Power Supply 110/220 12VDC
DVD+R/RW Recorder
The MP-6000 records DVD+R/RW DVD’s direct
from most A/V sources, including cameras and
analog VCR’s. Using a high performance MPEG2
codec, you can select the bit rate for higher
quality or more recording time. The created DVD
discs can be played in most existing DVD players.
Width:
Depth:
Height:
Net Weight:
AUDIO OUT
UNBALANCED (RCA)
BALANCED (XLR)
UNBALANCED (RCA)
BALANCED (XLR)
VIDEO IN
VIDEO OUT
DV25
DV25
COMPONENT
COMPONENT
COMPOSITE (ANALOG)
COMPOSITE (ANALOG)
Y/C (S-VIDEO)
Y/C (S-VIDEO)
AUDIO FORMATS - AUDIO PERFORMANCE
D/A=24 BIT, A/D=16 BIT
PAL
B/50HZ
NTSC/
60HZ
HQ
9.17 MBPS
720 X 576
720 X 480
60 MINUTES
SP
5.07 MBPS
720 X 576
720 X 480
120 MINUTES
LP
3.38 MBPS
480 X 576
480 X 480
180 MINUTES
EP
2.54 MBPS
360 X 576
360 X 480
240 MINUTES
SLP
1.69 MBPS
352 X 288
352 X 240
360 MINUTES
48 KHZ
4 HZ-22 KHZ
VIDEO CD
44.1 KHZ
4 HZ-20 KHZ
DISC TYPES
AUDIO CD
44.1 KHZ
4 HZ-20 KHZ
MPEG2,
MPEG1
DVD-VIDEO & DVD+R/RW
HORIZONTAL RESOLUTION
720 PIXELS
740 PIXELS
VERTICAL RESOLUTION
576 LINES
480 LINES
HORIZONTAL RESOLUTION
360 PIXELS
360 PIXELS
VERTICAL RESOLUTION
576 LINES
480 LINES
HORIZONTAL RESOLUTION
352 PIXELS
352 PIXELS
VERTICAL RESOLUTION
288 LINES
240 LINES
EST RECORDING
TIME ON
A 4.7GB DVD+R/
RW DISC
BIT RATE
4 HZ-44 KHZ
DVD, SVCD,
VCD
VIDEO RESOLUTION
H-PIXELS X V-LINES
MODE
96 KHZ
VIDEO FORMAT
Unbalanced Audio
I/O
MP-6000 DVD+R/RW DISC RECORDING SPEC:
DVD+R/RW
RECORDING
MODE
DVD
Balanced Audio
Input
DVD+RW Disc
User Manual
AC Adaptor
Video Cables
Stereo Audio Cable
IR Remote Control
11.75 inches, 190.5 mm
8 inches, 139.7 mm
5.5 inches, 63.5 mm
9 lbs, 4.2 kgs
AUDIO IN
Component
(Y/R-Y/B-Y) Input
MP-6000
Front View
More Accessories
Unit Dimensions/Weight
Component Video
(Y/R-Y/B-Y) and
Black Burst Output
PLAY
RECORD
DVD+RW
Y
Y
DVD+R
Y
Y
DVD-R
Y
N
DVD-RW/VIDEO
Y
N
DVD/VIDEO
Y
N
SUPER VCD
Y
N
VIDEO CD
Y
N
AUDIO CD
Y
N
CD-R
Y
N
CD-RW
Y
N
This MP-6000 is used by
Klasky Chewpo animation
(Los Ángeles) to make DVD
video work prints for their
animation customers.
DVD+RW (LP/EP)
VCD
www.datavideo.us 25
TBC’S
All TBC’s use an internal crystal to regenerate the video synch signals and stabilize
the video. There is no provision for external genlock. With black and white video, a
color reference signal (color burst) is required. Each TBC includes an internal full frame
memory buffer for synchronization.
Time Base Correctors
TBC 100
BUILT IN VIDEO AND AUDIO DA
TBC 1000
TBC 3000
YES
NTSC/PAL B AUTO DETECT
YES
YES
COMPOSITE VIDEO I/O
YES
YES
YES
Y/C (S-VIDEO) I/O
YES
YES
YES
1
1
2
CHANNELS
CHROMA KEY 16 COLORS/15 STEPS
VIDEO LEVEL CONTROLS
COLOR BAR & PATTERN GENERATOR
YES
FREEZE FRAME
VOLTAGE
5/12 VDC
POWER SUPPLY INCLUDED
12 VDC
9 VDC
YES
YES
6SHFL¿FDWLRQV
Wide bandwidth – Y/C (S-Video) 4.5MHz, Composite 3.5MHz,
8 bit, 4:2:2 sampling rate.
SN>50db
Time Base Correctors
TBC 4000
TBC 6000
TBC 7000
COMPOSITE VIDEO I/O
YES
YES
YES
Y/C (S-VIDEO) I/O
YES
YES
YES
4
3
3
FITS IN PC
BUILT IN VIDEO AND AUDIO DA
NTSC/PAL B AUTO DETECT
CHANNELS
CHROMA KEY 16 COLORS/15 STEPS
1
2
YES
YES
YES
YES
YES
9 VDC
9 VDC
9 VDC
YES
YES
YES
VIDEO LEVEL CONTROLS
COLOR BAR & PATTERN GENERATOR
FREEZE FRAME
VOLTAGE
POWER SUPPLY INCLUDED
VP-299 ANALOG AUDIO & VIDEO DISTRIBUTION AMPLIFIER
One in and four out, Stereo audio pairs, Y/C (S-Video) and Composite
video.
Note: Does not convert between Y/C (S-Video) and Composite Video.
Unit Dimensions/Weight
Width:
8.4 inches, 210 mm
Depth:
8.4 inches, 210 mm
Height:
2.2 inches, 55 mm
Net Weight:
2.5 lbs, 1.12 kg
www.datavideo.us 26
AC Input
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
110/220 VAC 1.5 amp
(or connect to the PD-1)
Includes Tally indication on the
beltpacks.
Includes chassis grounding screw
for a common audio ground.
19 inches, 482.6 mm
5 inches, 127 mm
1.5 inches, 38.1 mm
4 lbs, 2.8 kgs
ITC-1 Front View
ITC-100
Intercom
An innovative, 8 remote user and base station
intercom that can use low cost cell phone headsets
or high quality, professional units.
ITC-1 Rear View
Users are connected to the base station via belt
packs and 20 meter audio cables (5 pin XLR connectors) that may be extended up to 300 meters.
Optional Accessories
Included Accessories
Rack Mount Intercom (1),
Gooseneck MIC (1)
DJ lamp (1), 12V/1.5A Power Adaptor (1),
Belt packs (4), 20m cables (4),
Headsets (4),
XLR mount gooseneck microphone
XLR mount gooseneck light
p/n: CB-2 20m intercom & tally cable, p/n: CB-3 50m intercom & tally cable,
p/n: CB-4 100m intercom & tally cable, p/n: HP-1 Small Cell phone headset,
p/n: HP-2 Larger Cell phone headset, p/n: ITC-1 Additonal belt packs with
only 5 pin XLR, p/n: ITC-10S package of 1x beltpack, 1x 20m cable, 1x headset.
Belt packs
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
Cell phone headsets
Cable
19 inches, 482.6 mm
8.5 inches, 216 mm
1.5 inches, 38.1 mm
8.5 lbs, 2.5 kgs
Output
10 DC output connectors
2*4 pin XLR @ 12V/6 amps
3* AC output connectors
Input
1*4 pin XLR @ 12V/300W
PD-1 Front View
PD-1
PD-1 Rear View
Power Distributor
The PD-1 Power Distribution center eliminates
wall warts and dangling power supplies. It can be
powered by a DC supply (mobile) or by an AC
supply.
Typical Application
Included Accessories
35” 12V Locking Connectors (2)
42” 12V Locking Connectors (1)
23” 12V Locking Connectors (1)
4 Pin Male to Female Adaptor (1)
Power cord (1)
110/220 AC
PD-1 Power
Distributor
11-13V DC
The PD-1 can power all of these devices
at the same time
1–
1–
SE-800
MP-6000 DVD recorder and
eight more devices including
1–
TLM-404 (monitor)
1–
TLM-702 (monitor)
1–
RMC-140 next source preview
and Tally Box
$QG¿YHPRUHGHYLFHV
SE-800
MP-6000
TLM-404
TLM-702
RMC-140
DVK-100
DN-100
www.datavideo.us 27
Black Burst
Output
Component
Output
Composite
Video I/O
STC-100
Standards Converter
The STC-100 is a bi-directional video standards
converter between NTSC and PAL B (not PAL M- or
PAL N). It operates on 12 VDC and can be rack
mounted.
Included Accessories
1.2M BNC Cable (3)
Y/C (S-Video) (1)
12V DC Power Adaptor
(100-240V AC input - 12V 1.5 A output)
Unit Dimensions/Weight
Width:
Depth:
Height:
Net Weight:
8.25 inches, 210 mm
8.25 inches, 210 mm
3.25 inches, 21 mm
3.5 lbs, 1.6 kgs
Power
Component
Input
Input
Video
Composite, Y/C (S-Video), YUV
Audio
Stereo, Unbalanced, RCA
Output
Video
Composite, Y/C (S-Video),
Black Burst
Audio
Stereo, Unbalanced, RCA
Video Processing
Component
8-bit, 4:2:2, Y: 13.5MHz
Frame Synchronization
Full Frame TBC
Frequency Response (S input)
5 MHz +/-3dB
DG, DP
+/- 3%, 3°
S/N Ratio
>50 dB
DC In
6SHFL¿FDWLRQV
Video Correction
Brightness
+/- 10%
Contrast
+/- 3dB
Color
+3/-10dB
Tint
+/- 10°(NTSC only)
Audio level calibration
S/N Ratio
>60dB
THD
<0.1%
Analog Bandwidth 20Hz~20kHz, +/- 3dB
Ambient Temperature
32°- 131°F (0°- 55°C)
Ambient Humidity
Less than 90%
The following countries use the NTSC system
Antigua
Bahamas
Barbados
Barbuda
Belize
Bermuda
Bolivia
Burma
Cambodia
Canada
Cayman Islands
Chile
Colombia
Costa Rica
Cuba
Dominican Republic
El Salvador
Ecuador
Guam
Guatemala
Haiti
Honduras
Jamaica
Japan
Mexico
Midway Islands
Netherland Antilles
Nicaragua
North Mariana Island
Panama
Peru
Philippines
Puerto Rico
Saipan
Samoa
South Korea
Saint Kitts
Saint Lucia
Saint Vincent
Surinam
Taiwan
Tobago
Trinidad
United States
Venezuela
Virgin Islands
The following countries use the PAL system
Afghanistan
Albania
Algeria
Angola
Argentina
Australia
Azores Islands
Baharain
Bangladesh
Botswana
Brunei
Cameroon
Canary Islands
China
Cyprus
Denmark
Ethiopia
Faeroe Islands
Fiji
Finland
Ghana
Gibraltar
Guinea-Bissan
Germany
Holland
Hong Kong
Iceland
India
Indonesia
Ireland
Israel
Italy
Jordan
Kenya
Kuwait
Laos
Liberia
Madeire
Malaysia
Malta
Mozambique
Nepal
Netherland
New Guinea
New Zealand
Nigeria
North Korea
Norway
Oman
Pakistan
Paraguay
Portugal
Qutar
Romania
Singapore
Somalia
South Africa
Spain
Sri Lanka
Sudan
Swaziland
Sweden
Switzerland
Tanzania
Thailand
Turkey
Uganda
UAE
United Kingdom
Uruguay
Yemen
Yugoslavia
Zambia
Zimbabwe
www.datavideo.us
Input Video Card Choices
Composite / Component / YC,
DV25
SDI w/wo embedded audio
Character Generator
Designed to work with CG’s that use
their own DSK eg: Datavideo CG-100
and Blackmagic Design card.
Audio Inputs
A stereo analog audio input (line level)
will be embedded in the SDI and the DV
stream. The audio may be delayed to
match the DV25 video.
Remote Control
RS-422 or RS232.
Video Output
SDI, DV25, Component, Y/C (S-Video)
and Composite Video.
SE-900
Preliminary Product Description
8 VIDEO SOURCE
INPUT SWITCHER
WITH STEREO AUDIO
I/O
Audio Output
Program:
Two analog audio outputs (balanced XLR)
Source:
On each SDI & DV25 input
board there is one unbalanced out stereo pair.
Optional Boards
Composite / Component / YC input
DV input
SDI input w/ embeded audio
SDI input w/o embeded audio
Genlock in
Chromakey
SDI out w/ embeded audio
SDI out w/o embeded audio
Preview Output
Normal is next source preview. Pressing the “PREVIEW” key will
show the next effect.
Character Generator
(a) CG-100 Software and DeckLink Pro card
(b) CG-100 Software, DeckLink Pro card
and 2U Rackmount PC
Tally Output
8 tally low voltage/current contact
closures that can power LED’s or solid
state relays.
Estimated Delivery - 2007 1st QTR.
PRELIMINARY
A live production switcher for church,
corporate and educational production.
The SE-9Faudio inputs. The console portion
¿WVRQD´VKHOI
PIP Function
7KUHH¿[HGVL]HVDEOHWRPRYHRQRII
screen.
Datavideo U.S.A.
12300 E. Washington Blvd., Ste. U
Whittier, CA 90606 U.S.A.
Tel: (562) 696-2324
Fax: (562) 698-6930
http://www.datavideo.us
Datavideo Taiwan
10F, No. 176, Jian-Yi Road, Chung
Ho City, Taipei Hsien 235
Taiwan, R.O.C.
Tel. +886.2.8227.2888
http://www.datavideo.com.tw
Datavideo Europe
Californiedreef 26
3565 BL Utrecht
The Netherlands
Tel. +31.30.261.9656
http://www.datavideo.info
Datavideo United Kingdom
Unit 2 Waterside Business Park,
+DG¿HOG*ORVVRS'HUE\VKLUH
SK13 1BE United Kingdom
Tel. +44.1457.851000
http://www.datavideo.info
Datavideo China
2 F-D, No. 2 Lane 777, West
GuangZhong Road, Zhabei District,
Shang-Hai, China
Tel. +86.21.5603.6599
http://www.datavideo.cn
Datavideo Singapore
100 Lor 23, Geylang Road
# 01-03 D’Centennial
Singapore 388398
Tel. +65.6749.6866
http://www.datavideo.sg
www.datavideo.us 29
Datavideo
Taiwan
'DWDYLGHR2I¿FH/RFDWL
R2I
2I¿
2
I¿
¿FH
FH
FH/
/RFDWLRQV
Datavideo
U.S.A.
Datavideo
U.K.
Datavideo
Europe
Datavideo
China
Demo Datavideo Products in your facility!
No test is better than the one you make in your own facility.
Every Datavideo product is available for a period of up to two weeks for evaluation.
Please check our website http://www.datavideo.us for demo information.
Call us at (562) 696-2324 or ask your reseller.
Datavideo
Singapore
Datavideo
Hong Kong
Datavideo U.S.A.
12300 East Washington Blvd., Suite U
Whittier, CA 90606
Tel:
+1-562-696-2324
Fax: +1-562-698-6930
http://www.datavideo.us
Datavideo United Kingdom
Datavideo Europe
Datavideo Hong Kong
Unit 2 Waterside Business Park,
+DG¿HOG *ORVVRS 'HUE\VKLUH
SK13 1BE United Kingdom
Californiedreef 26
3565 BL Utrecht
The Netherlands
G/F.,26 CROSS LANE
WANCHAI
HK
Tel:
+44-1457-851000
http://www.datavideo.info
Tel:
+31-30-261-9656
http://www.datavideo.info
Tel:
+852-28331981
http://www.datavideohk.com
Datavideo China
Datavideo Singapore
Datavideo Taiwan
2 F-D, No. 2 Lane 777, West
GuangZhong Road, Zhabei District,
Shang-Hai, China
100 Lor 23, Geylang Road
# 01-03 D’Centennial
Singapore 388398
10F, No. 176, Jian-Yi Road, Chung
Ho City, Taipei Hsien 235
Taiwan, R.O.C.
Tel:
+86-21-5603-6599
http://www.datavideo.cn
Tel:
+65-6749-6866
http://www.datavideo.sg
Tel:
+886-2-8227-2888
http://www.datavideo.com.tw
www.datavideo.us 30
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
