Installation Guide
Com’X 200
DOCA0035EN-01 03/2014
Com’X 200
Metering and Data Acquisition System
Installation Guide
03/2014
www.schneider-electric.com
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein. This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications. It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof. Neither Schneider Electric nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.
No part of this document may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission of Schneider Electric.
All pertinent state, regional, and local safety regulations must be observed when installing and using this product. For reasons of safety and to help ensure compliance with documented system data, only the manufacturer should perform repairs to components.
When devices are used for applications with technical safety requirements, the relevant instructions must be followed.
Failure to use Schneider Electric software or approved software with our hardware products may result in injury, harm, or improper operating results.
Failure to observe this information can result in injury or equipment damage.
© 2014 Schneider Electric. All rights reserved.
2
DOCA0035EN-01 03/2014
Table of Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About the Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part I Data Acquisition System Presentation. . . . . . . . . . . . . . . . . . . . . .
Chapter 1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Com’X 200 Functionality Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Architecture Interfaces Characteristics and Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part II Wiring Rules and Recommendations . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2 Wiring Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24 Vdc Power Supply Category. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3 Wiring of the Modbus Communication Network . . . . . . . . . . . . . . . . . . .
Modbus Network Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Modbus Communication Port Wiring Terminal Characteristics . . . . . . . . . . . . . . . . . . . . . . .
Wiring the Modbus Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4 Wiring of the Ethernet Communication Network. . . . . . . . . . . . . . . . . . .
Ethernet Network Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet Network Port Wiring Terminal Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring the Ethernet Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part III Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 5 Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Networking Recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part IV Com’X 200 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 6 Com’X 200 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Com’X 200 Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Com’X 200 Installation in Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting on a DIN Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Com’X 200 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Access to the Login Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part V Devices Installation and Settings . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 7 Supported Devices Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
List of Supported Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 8 Wiring Monitoring Devices and Electrical Equipment . . . . . . . . . . . . . .
8.1 Wiring Diagrams for Electrical Pulse Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EM3502 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EN40P / iEM2010 / iEM2000T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iEM3110 / iEM3210 / PM3210. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ME1Zr / ME3Zr / ME4Zr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM9P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM200P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM5100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2 Electrical Modbus Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EM3550 / EM3555. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EM6400 / EM6433 / EM6434 / EM6436 / EM6438 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iEM3150 / iEM3155 / iEM3250 / iEM3255. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ION6200 / ION7300 / ION7330 / ION7350 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM9C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
DOCA0035EN-01 03/2014
4
PM210 / PM500 / PM710 / PM750 / PM800 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM1200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM3250 / PM3255 / PM5110 / PM5111 / PM5310 / PM5330 / PM5331 . . . . . . . . . . . . . . . .
PM5350 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.3 Electrical Ethernet Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM5320 / PM5340 / PM5341 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM5560 / PM5561 / PM5563 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4 Circuit Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CM3000 / CM4000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.5 Power Factor Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Varlogic NRC12 Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.6 Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NSX Micrologic and Masterpact. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 9 Wiring Acquisition Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acti 9 Smartlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SIM10M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 10 Wiring Gateways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EGX100 / EGX300 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PM8ECC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 11 Wiring Analog Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pt100 / Pt1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CWE CO2 Sensor 0–10 V and 4–20 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SHO100 and SHR100 Humidity Sensor 0–10 V and 4–20 mA . . . . . . . . . . . . . . . . . . . . . . .
STD300 and STO300 4–20 mA Temperature Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 12 Wiring Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4–20 mA to 0–10 V Zelio Converter (RMCL55BD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Pt100 to 0–10 V Zelio Converter (RMPT13BD) . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Pt100 to 0–10 V Converter (88 950 1••) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STAHL Interface for Gas Meter (9001/01-252-057-141) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix A Appendices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting List for Com’X 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DOCA0035EN-01 03/2014
Safety Information
Important Information
NOTICE
Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.
PLEASE NOTE
Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel.
No responsibility is assumed by Schneider Electric for any consequences arising out of the use of this material.
A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and its installation, and has received safety training to recognize and avoid the hazards involved.
DOCA0035EN-01 03/2014
5
6
BEFORE YOU BEGIN
Do not use this product on machinery lacking effective point-of-operation guarding. Lack of effective pointof-operation guarding on a machine can result in serious injury to the operator of that machine.
WARNING
UNGUARDED MACHINERY CAN CAUSE SERIOUS INJURY
Do not use this software and related automation equipment on equipment which does not have pointof-operation protection.
Do not reach into machinery during operation.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
This automation equipment and related software is used to control a variety of industrial processes. The type or model of automation equipment suitable for each application will vary depending on factors such as the control function required, degree of protection required, production methods, unusual conditions, government regulations, etc. In some applications, more than one processor may be required, as when backup redundancy is needed.
Only the user can be aware of all the conditions and factors present during setup, operation, and maintenance of the machine; therefore, only the user can determine the automation equipment and the related safeties and interlocks which can be properly used. When selecting automation and control equipment and related software for a particular application, the user should refer to the applicable local and national standards and regulations. The National Safety Council’s Accident Prevention Manual (nationally recognized in the United States of America) also provides much useful information.
In some applications, such as packaging machinery, additional operator protection such as point-ofoperation guarding must be provided. This is necessary if the operator’s hands and other parts of the body are free to enter the pinch points or other hazardous areas and serious injury can occur. Software products alone cannot protect an operator from injury. For this reason the software cannot be substituted for or take the place of point-of-operation protection.
Ensure that appropriate safeties and mechanical/electrical interlocks related to point-of-operation protection have been installed and are operational before placing the equipment into service. All interlocks and safeties related to point-of-operation protection must be coordinated with the related automation equipment and software programming.
NOTE: Coordination of safeties and mechanical/electrical interlocks for point-of-operation protection is outside the scope of the Function Block Library, System User Guide, or other implementation referenced in this documentation.
START-UP AND TEST
Before using electrical control and automation equipment for regular operation after installation, the system should be given a start-up test by qualified personnel to verify correct operation of the equipment. It is important that arrangements for such a check be made and that enough time is allowed to perform complete and satisfactory testing.
CAUTION
EQUIPMENT OPERATION HAZARD
Verify that all installation and set up procedures have been completed.
Before operational tests are performed, remove all blocks or other temporary holding means used for shipment from all component devices.
Remove tools, meters, and debris from equipment.
Failure to follow these instructions can result in injury or equipment damage.
Follow all start-up tests recommended in the equipment documentation. Store all equipment documentation for future references.
DOCA0035EN-01 03/2014
Software testing must be done in both simulated and real environments.
Verify that the completed system is free from all short circuits and grounds that are not installed according to local regulations (according to the National Electrical Code in the U.S.A, for instance). If high-potential voltage testing is necessary, follow recommendations in equipment documentation to prevent accidental equipment damage.
Before energizing equipment:
Remove tools, meters, and debris from equipment.
Close the equipment enclosure door.
Remove all temporary grounds from incoming power lines.
Perform all start-up tests recommended by the manufacturer.
OPERATION AND ADJUSTMENTS
The following precautions are from the NEMA Standards Publication ICS 7.1-1995 (English version prevails):
Regardless of the care exercised in the design and manufacture of equipment or in the selection and ratings of components, there are hazards that can be encountered if such equipment is improperly
operated.
It is sometimes possible to misadjust the equipment and thus produce unsatisfactory or unsafe operation. Always use the manufacturer’s instructions as a guide for functional adjustments. Personnel who have access to these adjustments should be familiar with the equipment manufacturer’s
instructions and the machinery used with the electrical equipment.
Only those operational adjustments actually required by the operator should be accessible to the operator. Access to other controls should be restricted to prevent unauthorized changes in operating characteristics.
DOCA0035EN-01 03/2014
7
8
DOCA0035EN-01 03/2014
About the Book
At a Glance
Document Scope
This document provides instructions for installing and setting up the metering and data acquisition system using a Com’X 200 as the main data aggregator of the system.
The instructions are presented in the order in which they are to be carried out. They supplement the assembly or installation documents supplied with the equipment and the specific installation guides for each product.
The installation guide presents general wiring rules, recommendations about wireless network, installation recommendations of the Com’X 200, and cabling schemes of devices connected to a Com’X 200:
monitoring devices and electrical equipment
Modbus RS 485 / Ethernet TCP/IP communication gateway
GPRS modem
Wi-Fi modem maintenance checklist troubleshooting and diagnostics
This guide is intended for the electrical contractor or integrator in charge of installing and configuring the energy management solution.
Validity Note
This user manual applies to the energy server Com’X 200 device.
The energy server Com’X 200 is a compact plug and play data logger. It collects and stores consumptions of WAGES (water, air, gas, electricity, and steam) and environmental parameters such as temperature, humidity, and CO
2
levels in a building. Data is securely transmitted as a report to StruxureWave Energy
Operation or any other Internet database server.
Related Documents
Title of Documentation
Acti 9 Communication System User Manual
English, French, Italian, Portuguese, Spanish
Com’X 200 Instruction Sheet
English, French, Italian, Spanish
Com’X 200 Instruction Sheet
German, Dutch, Portuguese, Russian, Chinese
Com’X 200 User Guide
Chinese, English, French, German, Italian, Portuguese, Spanish
DigitAN EM6400 Series User Manual
English
EBXA-GPRS Instruction Sheet
English, French, Italian, Spanish, German, Dutch, Portuguese, Russian,
Chinese
EBXA-GPRS-SIM Instruction Sheet
English, French, Italian, Spanish, German, Dutch, Portuguese, Russian,
Chinese
EBXA-USB-WI-FI Instruction Sheet
English, French, Italian, Spanish, German, Dutch, Portuguese, Russian,
Chinese
Electrical Installation Guide (Wiki version)
EM3500 Series DIN Rail Meter Technical Data Sheet
English
Reference Number
DOCA0004
253534170
253537642
DOCA0036
DigitAN EM6400 Series_UserManual
253537613
253537621
253537634 www.electrical-installation.org
PLSED310037EN
9
DOCA0035EN-01 03/2014
10
Title of Documentation
EM3502, EM3550 Compact Power and Energy Meter Installation Guide
English
EN40P Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish
How to Assemble an Electrical Switchboard Technical Guide iEM2000T Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish iEM2010 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish iEM3110 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish iEM3150, iEM3155 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish iEM3210 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish iEM3250, iEM3255 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish
ME1ZR Instruction Sheet
Chinese, Czech, Danish, Dutch, English, Finnish, French, German,
Hungarian, Italian, Norwegian, Polish, Portuguese, Russian, Spanish,
Swedish
ME3ZR Instruction Sheet
Chinese, Czech, Danish, Dutch, English, Finnish, French, German,
Hungarian, Italian, Norwegian, Polish, Portuguese, Russian, Spanish,
Swedish
ME4ZR Instruction Sheet
Chinese, Czech, Danish, Dutch, English, Finnish, French, German,
Hungarian, Italian, Norwegian, Polish, Portuguese, Russian, Spanish,
Swedish
Modbus Communication for Circuit Breakers CompactNSX, CompactNS, and Masterpact NT/NW Circuit Breakers
English, French
PM9C Instruction Sheet
English, French, Italian, Spanish
PM9P Instruction Sheet
English, French, Italian, Spanish
PM710 Reference Manual
English
PM750 Installation Guide
English, French
PM3210 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish
PM3250, PM3255 Instruction Sheet
Chinese, English, French, Italian, Portuguese, Spanish
PM5100, PM5110, PM5111 Instruction Sheet
Chinese, English, French, German, Italian, Portuguese, Russian, Spanish
PM5310, PM5320, PM5330, PM5331, PM5340, PM5341 Instruction Sheet
Chinese, English, French, German, Italian, Portuguese, Russian, Spanish
PM5560 Instruction Sheet
Chinese, English, French, German, Italian, Portuguese, Russian, Spanish
PM5561 Instruction Sheet
Chinese, English, French, German, Italian, Portuguese, Russian, Spanish
PM5563 Instruction Sheet
Chinese, English, French, German, Italian, Portuguese, Russian, Spanish
Reference Number
ZL0092-0A
AAV74173
DESW043EN
S1A89364
S1B45381
S1B46581
S1B46583
S1B46598
S1B46602
0GHE40035A-03/1
0GHE40036A-03/1
0GHE40037A-03/1
COM-LVP38EN
COM-LVP38FR
GHE12248AC
GHE12246AC
63230-501-209
63230_507_200A1_EN
63230_507_202A1_FR
S1B46605
S1B46607
HRB32897-01
HRB69887-01
HRB14027-01
HRB14028-00
HRB16844-01
DOCA0035EN-01 03/2014
DOCA0035EN-01 03/2014
Title of Documentation
PowerLogic Ethernet Gateway EGX100 Installation Guide
Chinese, English, French, Spanish
Reference Number
63230-319-239 ZH
63230-319-200 EN
63230-319-202 FR
63230-319-201 ES
63230-319-204 PowerLogic EGX100 User Guide
English, French, Spanish
PowerLogic Ethernet Gateway EGX300 Installation Guide
Chinese, English, French, Spanish
63230-319-233 ZH
63230-319-212 EN
63230-319-214 FR
63230-319-213 ES
63230-319-216 PowerLogic Ethernet Gateway EGX300 User Guide
English, French, Italian, Spanish
PowerLogic ION6200 Power and Energy Meter Installation & Operation
Guide
English, French
PowerLogic ION7300 Series User Guide
English
PowerLogic PM500 Series Quick Reference Guide
English, French, Spanish
70002-0196-10
70002-0162-05
51112563AE_EN
51112563AE_FR
51112563AE_ES
3000DB0808 PowerLogic PM800 Series Quick Reference Guide
English
PowerLogic Power Meter 200 and 200P Installation Guide
English, French, Spanish
PowerLogic Power Meter 210 Reference Manual
English
PowerLogic Power Meter PM5350 User Guide
English
PowerLogic Series 800 Power Meter Ethernet Communications Card User
Guide
English, French, Spanish
PowerLogic Series 3000 Circuit Monitor Reference Manual
Chinese, English, French, Spanish
PowerLogic Series 4000 Circuit Monitor Reference Manual
Chinese, English, French, Spanish
PowerLogic System Catalog
English
Smart Interface Module Installation Guide
English
Varlogic NRC12 Power factor controller User manual
English
63230-510-209 EN
63230-510-210 FR
63230-510-211 ES
63230-510-205
63230-401-203
63230-506-204
63230-400-207A1 EN
63230-300-212B1 EN
PLSED309005EN
DOCA0025EN
3653493EN_01.indd
You can download these technical publications and other technical information from our website at www.schneider-electric.com.
11
12
DOCA0035EN-01 03/2014
Com’X 200
Data Acquisition System Presentation
DOCA0035EN-01 03/2014
Data Acquisition System Presentation
Part I
Data Acquisition System Presentation
DOCA0035EN-01 03/2014
13
Data Acquisition System Presentation
14
DOCA0035EN-01 03/2014
Com’X 200
Description
DOCA0035EN-01 03/2014
Description
Chapter 1
Description
What Is in This Chapter?
This chapter contains the following topics:
Topic
Com’X 200 Functionality Overview
Architecture Interfaces Characteristics and Limits
Page
DOCA0035EN-01 03/2014
15
Description
Com’X 200 Functionality Overview
Data Acquisition System
The data acquisition system (DAS) based on a Com’X 200 allows acquisition of WAGES (Water, Air, Gas,
Electric, Steam) data at customer site, and send them to a hosted platform such as Schneider Electric
StruxureWare Energy Operation.
The Com’X 200 can collect:
Consumption data from meters with pulse signal output directly connected to the Com’X 200 digital
inputs, via SIM10M (Modbus serial line connection) modules, or Smartlink (Modbus serial line.)
Status of contactors, impulse relays, or TOU (Time Of Use) contacts of a main electrical meter.
Data from devices connected to Modbus RS 485 network of the Com’X 200.
Data from devices connected to Modbus RS 485 network of the EGX100 or EGX300 (for large buildings).
Data from devices connected to Ethernet TCP/IP.
Environmental data (temperature, humidity, CO
2
, and so on) from sensors directly connected to the
Com’X 200 analog inputs, via SIM10M modules.
Logging and Sending Data
The Com’X 200 can log data at intervals from 1 to 60 minutes.
This data can be sent to Schneider Electric StruxureWare Energy Operation through:
Ethernet network
Wi-Fi
GPRS for isolated sites or sites where the IT administrator does not allow access to the network infrastructure.
16
DOCA0035EN-01 03/2014
Com’X 200 Connections
The graphic summarizes the connections presented above:
Description
DOCA0035EN-01 03/2014
17
Description
Architecture Interfaces Characteristics and Limits
Characteristics and Limits
Device
Com’X 200
Interface
Modbus port
(master)
Characteristic/Limit
Description
Max number of Modbus slaves
Max bus length
Transmission speed supported (bits/sec)
Parity
Stop bits
Values
20 including energy meters, SIM10M, Acti 9
Smartlink, Modbus gateways (M-Bus, TIC)
1200 m in daisy chain
1200
4800
9600
19200 (factory setting)
38400
57600
115200
Even (factory setting)
Odd
None
1 (factory setting)
2 (if non parity)
1...255 (1...10 by default) Auto-discovering address range
Ethernet ports Max number of devices attached
Transmission speed
Ethernet ports configurations supported
2 separate ports (1 IP address each)
Modbus and
Ethernet
Analog inputs
Digital inputs
2 switched ports (1 IP address for both)
Modbus TCP autodiscovering
Max number of devices attached through Modbus and
Ethernet mixed
Number of inputs
Input types supported
Equipment types supported
Number of inputs
Input type supported
Equipment types supported
20 Ethernet devices attached maximum including
Ethernet gateways
10/100 Mbits/s
2 separate ports (1 IP address each)
2 switched ports (1 IP address for both)
Upstream network DHCP client
Static IPV4 address
Downstream network DHCP server with fixed
IPV4 address (10.25.1.1) or static IPV4 address
DHCP client
DHCP client
Static IPV4 address
Automatic
Manual
60 devices
2
0...10 V, 4...20 mA, Pt100 and Pt1000
T ° sensor, Humidity sensor, CO2 sensor, Level, and Generic
6
Counter, Square, Status, and Run hours
Generic main meter, pulse meters, KYZ meters, contactor status, impulse relay status
18
DOCA0035EN-01 03/2014
Device
Ethernet gateways
SIM10M
TWIDO WAGES solution
Interface
Modbus port
(master)
Characteristic/Limit
Description
Max number of Modbus slaves
Transmission speed supported (bits/sec)
Digital inputs
Parity
Stop bits
Analog inputs
Digital inputs
Number of inputs
Input types supported
Number of inputs
Input type supported
Acti 9 Smartlink Digital inputs Number of inputs
Input type supported
Number of inputs
Input type supported
Description
Values
20 including energy meters, SIM10M, Acti 9
Smartlink, Modbus gateways (M-Bus, TIC)
2400
4800
9600
19200 (factory setting)
38400
Even (factory setting)
Odd
None
1 (factory setting)
2 (if non parity)
2
0...10 V externally powered
6
Pulse acquisition and On/Off detection by internal
3.6 Vdc power and pull-up resistors
22 (2 x 11)
Pulse counter, Status, and Run hours
12...44
Pulse counter
DOCA0035EN-01 03/2014
19
Description
20
DOCA0035EN-01 03/2014
Com’X 200
Wiring Rules and Recommendations
DOCA0035EN-01 03/2014
Wiring Rules and Recommendations
Part II
Wiring Rules and Recommendations
What Is in This Part?
This part contains the following chapters:
Chapter
2
3
4
Chapter Name
Wiring Rules
Wiring of the Modbus Communication Network
Wiring of the Ethernet Communication Network
Page
DOCA0035EN-01 03/2014
21
Wiring Rules and Recommendations
22
DOCA0035EN-01 03/2014
Com’X 200
Wiring Rules
DOCA0035EN-01 03/2014
Wiring Rules
Chapter 2
Wiring Rules
Safety Instructions
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
What Is in This Chapter?
This chapter contains the following topics:
Topic
Wiring Overview
24 Vdc Power Supply Category
Page
DOCA0035EN-01 03/2014
23
Wiring Rules
Wiring Overview
Wiring Rules
NOTICE
COMMUNICATION MALFUNCTION
Respect all the wiring and grounding rules to avoid communication malfunctions due to EMC disturbance.
Failure to follow these instructions can result in equipment damage.
The following wiring rules must be respected in order to reduce disturbance due to EMC on the behavior of the Com’X 200:
Keep a distance as large as possible between the communication cable and the power or control cables
(minimum 30 cm or 11.8 in.). If it is not possible, insulate communication cable with:
metallic tubing metallic trunking
Cross over the Ethernet cable and the power cables at right angles, if necessary.
Install the communication cables as close as possible to the grounded plate.
Do not bend or damage the cables. The minimum bending radius is 10 times the cable diameter.
Avoid sharp angles of paths or passage of the cable.
Use the recommended cables only.
Use shielded cables only:
The cable shield must be connected to a protective ground.
The connection of the cable shield to the protective ground must be as short as possible.
Connect together the shields, if necessary.
Perform the grounding of the shield with a collar.
Add filters on contactor coils for all contactors and relays.
Wire the bus between each connector directly, without intermediate terminal blocks.
The common polarity (0 V) must be connected directly to protective ground, preferably at 1 point only for the entire bus. In general, this point is chosen either on the master device or on the polarization device.
For more information, refer to the Electrical Installation Guide (available in English only), chapter
ElectroMagnetic Compatibility (EMC) and the How to Assemble an Electrical Switchboard Technical
Guide.
24
DOCA0035EN-01 03/2014
Wiring Rules
24 Vdc Power Supply Category
Selection of a 24 Vdc Power Supply in the Data Acquisition System
The 24 Vdc power supply must comply with the following criteria:
It must be located in the electrical cabinet.
It must be different from the Modbus network 24 Vdc power supply to maintain galvanic isolation
between the Modbus network (common to several electrical cabinets) and the 24 Vdc I/O.
It must be Safety Extra Low Voltage (SELV) type.
Galvanic isolation between the power supply input (AC voltage) and the power supply output (DC voltage) must be at least 4 kVAC at 50 Hz.
The rated AC voltage of the power supply input must be 240 Vac +15/-20%.
This power supply can be used to supply other products inside the electrical cabinet provided that these products are double insulated or with reinforced insulation to preserve the power supply SELV quality.
Phaseo ABL8MEM240xx (OVC II) or ABL7RM24025 (OVC II) modular power supplies and their accessories comply with the above recommendations. These accessories provide the redundancy and backup power supply functions and can eliminate micro-cuts on the line.The upstream and downstream protection functions of the Phaseo power supply must be installed as indicated in their respective manuals.
If overvoltage category IV or III is needed in the installation, we recommend using:
Either power supplies (limited to 1 A) in the ULP (Universal Logic Plug) system with product references
54440 to 54445. See the User’s Manual, ULP Connection System, product reference TRV99100.
Or use the Phaseo power supply recommended above, protecting it with an isolating transformer from the Phaseo Optimum (ABL6TS) range or the Universal (ABT7PDU) range.
NOTE: Refer to the respective manuals for each of these power supplies.
DOCA0035EN-01 03/2014
25
Wiring Rules
26
DOCA0035EN-01 03/2014
Com’X 200
Wiring of the Modbus Communication Network
DOCA0035EN-01 03/2014
Wiring of the Modbus Communication Network
Chapter 3
Wiring of the Modbus Communication Network
Overview
This section describes how to connect a Com’X 200 on a RS 485 Modbus network with an RJ45 or an open-style connector.
It presents 2 possible network topologies.
What Is in This Chapter?
This chapter contains the following topics:
Topic
Modbus Network Characteristics
Modbus Communication Port Wiring Terminal Characteristics
Wiring the Modbus Network
Page
DOCA0035EN-01 03/2014
27
Wiring of the Modbus Communication Network
Modbus Network Characteristics
Overview
The Modbus over Serial Line Specification and Implementation Guide, published on www.modbus.org, defines the characteristics of the Modbus protocol over serial line. The Com’X 200 complies with this specification.
Modbus Network Standard Diagram
The standard diagram corresponds to the Modbus specification on the www.modbus.org site and in particular to the 2-wire multidrop serial bus diagram.
The simplified diagram is as follows:
28
DOCA0035EN-01 03/2014
Wiring of the Modbus Communication Network
Characteristics for Connection to the RS 485 Bus
The RS 485 standard allows variants of some characteristics:
polarization line terminator
number of slaves bus length
Characteristics
Maximum number of slaves
(without repeater)
Type of trunk cable
Standard Value
32 slaves
Single, shielded, twisted-pair cable, with
120
Ω characteristic impedance, and at least a third conductor
Maximum bus length 1,300 m (4,300 ft) at 19,200 Baud
Maximum length of tap-offs Depends on the transmission rate
Bus polarization
A 450...650
Ω pull-up resistor at the
5 V
A 450...650
Ω pull-down resistor at the common
Com’X 200 Value
20 slaves
Same as standard value
1,000 m (3,300 ft) at 115 kBaud
20 m (66 ft) for 1 tap-off
40 m (131 ft) divided by the number of tap-offs on the multiple junction box
510
Ω pull-up resistor at the 5 V
510 Ω pull-down resistor at the common
NOTE: These polarization resistors are integrated in the Com’X 200
DOCA0035EN-01 03/2014
29
Wiring of the Modbus Communication Network
Characteristics
Line terminator
Common polarity
Standard Value
Line terminator at both ends of the bus
(R or RC)
Com’X 200 Value
A 120
Ω resistor +/- 5% at both ends of the bus
The common polarity is connected to the protective ground in at least 1 point on the bus.
Same as standard value
30
DOCA0035EN-01 03/2014
Wiring of the Modbus Communication Network
Modbus Communication Port Wiring Terminal Characteristics
General
The main physical characteristics of a Modbus port are:
Physical interface
Connector
Polarization
Multipoint 2-wire RS 485 - electrical networking
Terminal block and RJ45
Integrated
Physical Interface and Connectors
Refer to the Com’X 200 physical description for connectors layout. (
RJ45 Connector Pinout
The Com’X 200 is connected to the Modbus network with a shielded RJ45 connector in compliance with the following wiring:
Front view
The RJ45 wiring layout is:
Pin no.
1
2
3
6
7
4
5
8
–
–
Signal
–
–
–
D1+
D0-
0VL
Description
Not connected
Not connected
Not connected
Transceiver terminal 1
Transceiver terminal 0
Not connected
Not connected
Signal and power supply common
Open-Style Connector
Connect the Com’X 200 to the Modbus network with an open style connector in compliance with the following plug-in terminals and pin assignments.
Plug-in terminals
Pin assignments
Signal
0V
D0-
D1+
Description
Signal and power supply common
Modbus shield pin
Transceiver terminal 0
Transceiver terminal 1
DOCA0035EN-01 03/2014
31
Wiring of the Modbus Communication Network
Wiring the Modbus Network
Overview
It is recommended to connect a Com’X 200 to a Modbus network on the RS 485 bus with the female shielded RJ45 connector.
This section describes 2 typical cases of connection of the Com’X 200 to the bus:
With an open-style connector.
With an RJ45 connector.
Modbus Wiring Rules
Apply all general wiring rules (
NOTICE
COMMUNICATION MALFUNCTION
Place a line terminator at each end of the bus to avoid malfunctions on the communication bus.
Respect all the wiring and grounding rules in order to avoid communication malfunctions due to EMC disturbance.
Failure to follow these instructions can result in equipment damage.
NOTE: A line terminator is integrated in the Com’X 200 and can be activated through the web interface if the Com’X 200 is located at 1 end of the Modbus line.
For more information, refer to the Electrical Installation Guide (available in English only), chapter
ElectroMagnetic Compatibility (EMC).
Open-Style Connector Wiring Rules
NOTE: Add a heat-shrink sleeve at the end of the stripped cable shield to regroup metallic strands.
32
DOCA0035EN-01 03/2014
Wiring of the Modbus Communication Network
Connection of the Com’X 200 via its RJ45 Connector
The wiring diagram for connecting the Com’X 200 installed in an enclosure to the RS 485 bus via the RJ45 connector is as follows:
DOCA0035EN-01 03/2014
1 Master (PLC, PC, or communication module) with line terminator
2 Modbus shielded cable with 2 RJ45 connectors
3 Grounding of the Modbus cable shield
4 Modbus T-junction boxes VW3 A8 306 TF•• (with cable)
5 Grounding of the Modbus T-junction boxes
6 Line terminator for RJ45 plug VW3 A8 306 R (120
Ω)
33
Wiring of the Modbus Communication Network
Connection of the Com’X 200 via the Open-Style Connector
The wiring diagram for connecting the Com’X 200 installed in an enclosure to the RS 485 bus via the open style connector is as follows:
Inverting pin A, –, Tx–, Rx–, D0
Non-inverting pin B, +, Tx+, Rx+, D1
Reference pin SC, G
Shield sh, shld
List of Modbus Accessories
Designation
T-junction boxes
Line terminator for RJ45 connector
Line terminator for open-style connector
Description
Box with 2 RJ45 female connector for trunk cable and an integrated 0.3 m
(1 ft) cable with 1 RJ45 male connector for tap-off
Box with 2 RJ45 female connector for trunk cable and an integrated 1 m
(3.2 ft) cable with 1 RJ45 male connector for tap-off
R = 120
Ω
R = 120
Ω
Reference Number
VW3 A8 306 TF03
VW3 A8 306 TF10
VW3 A8 306 R
VW3 A8 306 DR
List of Modbus Cables
Designation
Shielded cable for Modbus bus, with 2 RJ45 connectors
Shielded cable for Modbus bus, with 1 RJ45 connectors and 1 stripped end
Shielded cable for Modbus bus, with 2 stripped ends
Belden cable or equivalent
Length
0.3 m (1 ft)
1 m (3.2 ft)
3 m (9.8 ft)
3 m (9.8 ft)
100 m (320 ft)
200 m (640 ft)
500 m (1,600 ft)
305 m (1,000 ft)
305 m (1,000 ft)
305 m (1,000 ft)
Reference Number
VW3 A8 306 R03
VW3 A8 306 R10
VW3 A8 306 R30
VW3 A8 306 D30
TSX CSA 100
TSX CSA 200
TSX CSA 500
3107A
7201A
9842
34
DOCA0035EN-01 03/2014
Com’X 200
Wiring of the Ethernet Communication Network
DOCA0035EN-01 03/2014
Wiring of the Ethernet Communication Network
Chapter 4
Wiring of the Ethernet Communication Network
Overview
This section describes how to connect a Com’X 200 to an Ethernet network using an RJ45 connector.
It presents 2 possible connection modes.
What Is in This Chapter?
This chapter contains the following topics:
Topic
Ethernet Network Characteristics
Ethernet Network Port Wiring Terminal Characteristics
Wiring the Ethernet Network
Page
DOCA0035EN-01 03/2014
35
Wiring of the Ethernet Communication Network
Ethernet Network Characteristics
Overview
The Com’X 200 complies with the Ethernet standard specification.
Characteristics for Connection to the Ethernet Network
Characteristics
Type of cable
Standard Value Com’X 200 Value
Depends on the transmission rate Straight or crossed category 5 shielded twisted-pair
Maximum cable length 100 m (328 ft)
Transmission speed 10 MB/100 MB
Same as standard value
Same as standard value
36
DOCA0035EN-01 03/2014
Wiring of the Ethernet Communication Network
Ethernet Network Port Wiring Terminal Characteristics
General
The main physical characteristics of an Ethernet port are:
Physical interface
Connector
Ethernet 10/100BASE-T
RJ45
Physical Interface and Connectors
Refer to the Com’X 200 physical description for connectors layout. (
DOCA0035EN-01 03/2014
37
Wiring of the Ethernet Communication Network
Wiring the Ethernet Network
Overview
This section describes 2 typical cases for connecting a Com’X 200 with the RJ45 connectors:
connection in the switch mode connection in the upstream/downstream mode
The Com’X 200 uses Ethernet as defined by the IEEE 802.3 standard.
NOTE: You cannot set up a loop configuration because the Com’X 200 does not support STP/RSTP protocol.
Connection of the Com’X 200 in the Switch Mode
The wiring diagram for connecting the Com’X 200 to an Ethernet network in the switch connection mode via the RJ45 connector is as follows:
38
NOTE: The IP addresses are provided as example. These values depend on your network configuration.
DOCA0035EN-01 03/2014
Wiring of the Ethernet Communication Network
Connection of the Com’X 200 in the Upstream/Downstream Mode
The wiring diagram for connecting the Com’X 200 to an Ethernet network in the upstream/downstream connection mode with the RJ45 connectors is as follows:
NOTE: The IP addresses are provided as example. These values depend on your network configuration.
DOCA0035EN-01 03/2014
39
Wiring of the Ethernet Communication Network
40
DOCA0035EN-01 03/2014
Com’X 200
Wireless Network
DOCA0035EN-01 03/2014
Wireless Network
Part III
Wireless Network
DOCA0035EN-01 03/2014
41
Wireless Network
42
DOCA0035EN-01 03/2014
Com’X 200
Wireless Network
DOCA0035EN-01 03/2014
Wireless Network
Chapter 5
Wireless Network
Wireless Networking Recommendations
Wireless Networking Recommendations
To ensure good operation of the GPRS modem, you have to conform to the following recommendations:
The Com’X 200 shall be installed preferably at a height of 1 meter from the floor.
Use the following GPRS modem and Wi-Fi USB stick references, which have been selected to run efficiently with the Com’X 200:
EBXA-GPRS or EBXA-GPRS-SIM for the GPRS modem.
EBXA-USB-WIFI for the Wi-Fi USB stick.
NOTE: The good operation of GPRS and Wi-Fi is not guaranteed with other GPRS modem or Wi-Fi USB stick.
DOCA0035EN-01 03/2014
43
Wireless Network
44
DOCA0035EN-01 03/2014
Com’X 200
Com’X 200 Installation
DOCA0035EN-01 03/2014
Com’X 200 Installation
Part IV
Com’X 200 Installation
DOCA0035EN-01 03/2014
45
Com’X 200 Installation
46
DOCA0035EN-01 03/2014
Com’X 200
Com’X 200 Installation
DOCA0035EN-01 03/2014
Com’X 200 Installation
Chapter 6
Com’X 200 Installation
Safety Instructions
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
To verify device ratings compliance to maximum limits, see the technical data (
What Is in This Chapter?
This chapter contains the following topics:
Topic
Technical Data
Com’X 200 Physical Description
Com’X 200 Installation in Enclosure
Mounting on a DIN Rail
Com’X 200 Wiring
Access to the Login Page
Page
47
DOCA0035EN-01 03/2014
Com’X 200 Installation
Technical Data
Communication
Characteristics
2 Base 10/100 Ethernet RJ45 ports, DPWS ready
Protocols
1 Modbus RS485 serial port
Values
Eth1: PoE class 3 (802.3af), DHCP client
Eth2: DHCP client or server
IPv4, IPv6 - HTTP, HTTPS, Modbus TCP/IP
RJ45 and removable screw terminal connector (0V, Screen, D0, D1).
Both connectors are plugged into the same Modbus RS485 serial port
32 devices maximum
Inputs
Characteristics
6 digital inputs Pulse counting (minimum pulse width 20 ms)
Internal power supply for inputs
External power supply for inputs
2 analog inputs
Values
Conforming to IEC 62053-31 or Status
12 Vdc, 60 mA
10–30 Vdc
0–10 Vdc, 4–20 mA (accuracy 0.5%)
Pt100, Pt1000: 2-wire (accuracy 1%)
Power supply available for analog sensors: 24 Vdc (50 mA for each input)
Electrical Characteristics
Characteristics
Power supply
Power consumption
Values
100–230 Vac (±15%) OVCIII
Fuse protection: type T 0.63AE/250V (F1)
24 Vdc (±10%)
Fuse protection: type 3.15AL/250V (F1500)
100-230 Vac, 24 Vdc 26 W maximum
PoE 15 W maximum
USB 2.0 Host Ports
Characteristics
1 USB port on front face
2 USB ports behind the cover
USB1 port
USB2 port
Expansion Bus
Characteristics
Consumption on 24 Vdc
Consumption on 3.3 Vdc
Values
Maximum current: 500 mA
Maximum current: 500 mA
Maximum current: 100 mA
Values
160 mA maximum
110 mA maximum
48
DOCA0035EN-01 03/2014
Com’X 200 Installation
Memory
Characteristics
RAM
Flash memory
Mechanical Characteristics
Characteristics
Degree of protection Front face
Connectors
Weight
Environmental Characteristics
Characteristics
Operating temperature
Storage temperature
Humidity
Level of pollution
Altitude
Standards
Characteristics
Safety standards/regulations
United States
Canada
Europe
Marking
Characteristics
Marking
PC Specification for Configuration
Characteristics
Operating system
Web browsers
Values
128 Mb
256 Mb
Values
IP40
IP20
450 g (0.992 lb)
Values
–25
° C to +60 ° C (–13 ° F to +140 ° F)
–40
° C to +85 ° C (–40 ° F to +185 ° F)
5 to 95% relative humidity (without condensation) at 55 ° C (131 ° F)
Class 3
2,000 m (6,561 ft) maximum
Values
UL 508 cUL
EN 60950
Values
, UL, C-tick
Values
Windows 7 (recommended), Vista, XP
Latest version of Mozilla, Firefox, Chrome, or IE
DOCA0035EN-01 03/2014
49
Com’X 200 Installation
Com’X 200 Physical Description
Dimensions
Description
The Com’X 200 provides the following connections capabilities:
Communication
1 Modbus communication port
2 Ethernet ports, Ethernet port 1 with PoE (Power over Ethernet)
3 USB ports
6 digital inputs and 2 analog inputs
Power supply
100...230 Vac
24 Vdc
PoE
50
DOCA0035EN-01 03/2014
Connectors, indicators, and buttons layout:
Com’X 200 Installation
DOCA0035EN-01 03/2014
1 Power supply 100...230 Vac
2 Power supply 24 Vdc
3 RS 485 Modbus communication port
4 Ethernet communication port 1 PoE
5 Ethernet communication port 2
6 USB port (Backup, Wi-Fi)
7 Button/Backup indicator
8 Button/Wi-Fi indicator
9 Digital inputs
10 Analog inputs
11 Digital inputs indicator
12 Power supply indicator/State (Power LED)
13 Radio modem communication indicator (modem LED)
14 RS 485 communication indicator (LED RS 485)
15 Ethernet Communication indicators (Ethernet 1 LED, Ethernet 2 LED)
51
Com’X 200 Installation
16 GPRS modem connector
17 USB port
18 Digital/analog entries labeling
52
DOCA0035EN-01 03/2014
Com’X 200 Installation
Com’X 200 Installation in Enclosure
Installation Recommendations
Install the Com’X 200 in the lower third of the enclosure to achieve optimal ambient temperature for the device.
NOTE: When the enclosure is laying on the floor, it is recommended to keep a distance of 1 m between the floor and the antenna in order to ensure the correct functioning of the GPRS modem.
Com’X 200 Mounting in Enclosure
The operating temperature around the Com’X 200 must not exceed 60
° C (140 ° F).
NOTE: Do not mount the Com’X 200 vertically.
Equipment Separation
Install devices in an enclosure with respect to required spacing for each device. Devices that cause electrical disturbance should not be placed near devices that are sensitive to electrical disturbance.
DOCA0035EN-01 03/2014
53
Com’X 200 Installation
Mounting on a DIN Rail
Introduction
This section describes mounting and removing of the Com’X 200 on a DIN rail.
Installing the Com’X 200 on a DIN Rail
Step Action
1 Secure the DIN rail to a panel according to the DIN rail installation instructions.
2 Place the top groove of the Com’X 200 on the DIN rail and press the unit against the DIN rail until you hear the retaining clamp click into place.
Din Rail Shielding in Enclosure Class 2
Make sure the DIN rail is electrically connected to earth ground to maintain shielding continuity and prevent
EMC disturbances. Earth ground connection is typically terminated using a green/yellow cable.
Keep the green/yellow cable as short as possible.
Removing the Com’X 200 From a DIN Rail
Using a screwdriver, pull down the retaining clamp located on the bottom of the Com’X 200.
NOTE: Before re-installing the Com’X 200 on the DIN rail, push up the retaining clamp.
54
DOCA0035EN-01 03/2014
Com’X 200 Installation
Com’X 200 Wiring
Power Supplies
You can provide a backup power supply for the Com’X 200 by connecting a UPS to the 24 Vdc input. If power is interrupted on the 100...277 Vac input, the Com’X 200 power supply will automatically switch to the 24 Vdc input.
The order of priority for power supply is:
1 100...277 Vac
2 24 Vdc
3 PoE
Digital Inputs
Digital inputs powered by the Com’X 200:
Digital inputs externally powered:
DOCA0035EN-01 03/2014
55
Com’X 200 Installation
Analog inputs powered by the Com’X 200:
Analog inputs externally powered:
56
DOCA0035EN-01 03/2014
Com’X 200 Installation
Access to the Login Page
Access to the Com’X 200 Web Application Under Windows 7 / Vista Operating Systems
To access the user interface of the Com’X 200, follow this procedure:
Step
1
2
3
4
5
6
Action
Disconnect your local computer from any network.
Connect an Ethernet cable between your local computer and the Ethernet port 2 of the Com’X 200.
On your local computer, open Windows Explorer and click Network.
NOTE: The Com’X 200 appears in the list of devices (refer to troubleshooting if the Com’X 200 does not appear).
Double-click the Com’X 200, the login page automatically opens in your default web browser.
Type the user login (factory setting: admin) and the password (factory setting: admin).
NOTE: The login and password are case-sensitive.
Click OK.
Access to the Com’X 200 Web Application Under Windows XP Operating System
To access the user interface of the Com’X 200, follow this procedure:
Step
1
2
3
4
5
Action
Disconnect your local computer from any network.
Connect an Ethernet cable between your local computer and the Ethernet port 2 of the Com’X 200.
Open your web browser.
In the address field, type 10.25.1.1 and press the Enter key.
Type the user login (factory setting: admin) and the password (factory setting: admin).
NOTE: The login and password are case-sensitive.
Click OK.
6
The configuration of the Com’X 200 Web Application is described in the Com’X 200 User Guide.
DOCA0035EN-01 03/2014
57
Com’X 200 Installation
58
DOCA0035EN-01 03/2014
Com’X 200
Devices Installation and Settings
DOCA0035EN-01 03/2014
Devices Installation and Settings
Part V
Devices Installation and Settings
What Is in This Part?
This part contains the following chapters:
Chapter
7
8
9
10
11
12
Chapter Name
Supported Devices Overview
Wiring Monitoring Devices and Electrical Equipment
Wiring Acquisition Modules
Wiring Gateways
Wiring Analog Sensors
Wiring Converters
Page
DOCA0035EN-01 03/2014
59
Devices Installation and Settings
60
DOCA0035EN-01 03/2014
Com’X 200
Supported Devices Overview
DOCA0035EN-01 03/2014
Supported Devices Overview
Chapter 7
Supported Devices Overview
List of Supported Devices
Supported Devices
The Com’X 200 supports the following devices in its library, which are described in the next chapters:
Electrical pulse meters
EM3502
EN40P iEM2010, iEM2000T iEM3110, iEM3210
ME1ZR, ME3ZR, ME4ZR
PM9P, PM200P, PM3210, PM5100
Electrical Modbus meters
EM6400, EM3550, EM3555
EM6400, EM6433, EM6434, EM6436, EM6438
iEM3150, iEM3155 iEM3250, IEM3255
ION6200, ION7300, ION7330, ION7350
PM9C
PM210, PM500, PM710, PM750, PM800 series
PM1200
PM3250, PM3255
PM5110, PM5111, PM5310, PM5330, PM5331, PM5350
Ethernet meters
PM5320, PM5340, PM5341 single Ethernet port meters
PM5560, PM5561, PM5563 dual Ethernet port meters
Circuit monitors
CM3000, CM4000
Power Factor Controllers
Varlogic NRC12
Circuit breakers
Compact NSX 100...630 A with Micrologic A and E
Masterpact NT and NW with Micrologic H and P
Acquisition modules
Acti 9 Smartlink
SIM10M
Gateways
PM8ECC
PowerLogic EGX100 Ethernet Gateway
PowerLogic EGX300 Ethernet Gateway
DOCA0035EN-01 03/2014
61
Supported Devices Overview
Supported Wirings for Connection to the Com’X 200
You can connect the electrical pulse meters to the Com’X 200 through 3 ways:
Directly to the Com’X 200.
Through SIM10M acquisition module.
Through Acti 9 Smartlink acquisition module.
The direct connection to the Com’X 200 and the connection through SIM10M acquisition modules are documented in the following pages.
For connection of the electrical pulse meters through the Acti 9 Smartlink, refer to the Acti 9
Communication System User Manual.
Electrical Modbus meters, circuit breakers, acquisition modules, and gateways are connected directly to the Com’X 200.
62
DOCA0035EN-01 03/2014
Com’X 200
Monitoring Devices and Electrical Equipment
DOCA0035EN-01 03/2014
Wiring Monitoring Devices and Electrical Equipment
Chapter 8
Wiring Monitoring Devices and Electrical Equipment
Safety Instructions
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
NOTE: Refer to the manufacturer’s documentation for each device for complete installation instructions.
What Is in This Chapter?
This chapter contains the following sections:
Section
8.1
8.2
8.3
8.4
8.5
8.6
Topic
Wiring Diagrams for Electrical Pulse Meters
Electrical Modbus Meters
Electrical Ethernet Meters
Circuit Monitors
Power Factor Controllers
Circuit Breakers
Page
63
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Wiring Diagrams for Electrical Pulse Meters
Section 8.1
Wiring Diagrams for Electrical Pulse Meters
What Is in This Section?
This section contains the following topics:
Topic
EM3502
EN40P / iEM2010 / iEM2000T iEM3110 / iEM3210 / PM3210
ME1Zr / ME3Zr / ME4Zr
PM9P
PM200P
PM5100
Page
64
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
EM3502
Overview
The EM3502 is a compact power meter that includes pulse outputs of real and reactive energy consumption, plus a real-time alarm output. It provides standard measurements, including:
Power (3-phase total and per phase):
Real (kW)
Reactive (kVAR)
Apparent (kVA)
Present Power Demand:
Real (kW)
Reactive (kVAR)
Apparent (kVA)
Peak Power Demand:
Real (kW)
Reactive (kVAR)
Apparent (kVA)
Power Factor (3-phase average and per phase)
Current (3-phase average and per phase)
Voltage (3-phase average and per phase):
Line-Line
Line-Neutral
For more information on instructions or functions of the EM3502, refer to EM3502, EM3550 Compact
Power and Energy Meter Installation Guide.
EM3502 Wiring Diagram To Com’X 200
Electrical wiring to the Com’X 200:
DOCA0035EN-01 03/2014
65
Monitoring Devices and Electrical Equipment
EN40P / iEM2010 / iEM2000T
Overview
EN40P, iEM2010 and iEM2000T are 40 A single-phase kilowatt-hour meter.
The pulse weight of these meters cannot be changed, and equals to 10 Wh.
For more information on instructions or functions of:
EN40P, refer to EN40P Instruction Sheet.
iEM2010, refer to iEM2010 Instruction Sheet.
iEM2000T, refer to iEM2000T Instruction Sheet.
EN40P / iEM2010 / iEM2000T Wiring Diagram to Com’X 200 and SIM10M
Electrical wiring to the Com’X 200:
NOTE: The EN40P has polarized outputs.
Electrical wiring to SIM10M:
66
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
iEM3110 / iEM3210 / PM3210
Overview
The iEM3110, iEM3210, PM3210 are 3-phase + neutral kilowatt-hour meters with partial metering, reset, and remote transfer of metered pulses.
For more information on instructions or functions of the iEM3110, iEM3210, PM3210, refer to corresponding Instruction Sheet.
iEM3110 / iEM3210 / PM3210 Wiring Diagram to Com’X 200 and SIM10M
Electrical wiring to the Com’X 200:
Electrical wiring to SIM10M:
iEM3110 / iEM3210 / PM3210 Pulse Output Setup
Step
1
2
3
6
7
4
5
8
Action
Press simultaneously OK and ESC buttons to enter the Setup menu.
Enter password 0010.
Scroll to the Pulse menu and press OK.
Select the Pulse Freq/Constant menu and select the pulse weight in kWh.
Validate the Save change proposal by pressing the OK button.
Select the Pulse width menu, select the pulse duration in ms, and press OK.
Validate the Save change proposal by pressing the OK button.
Press 2 times on ESC button to exit the setup menu.
DOCA0035EN-01 03/2014
67
Monitoring Devices and Electrical Equipment
ME1Zr / ME3Zr / ME4Zr
Overview
ME1Zr is a 63 A single-phase kilowatt-hour meter with partial meter.
ME3Zr is a 63 A three-phase kilowatt-hour meter without neutral, and with partial metering.
ME4Zr is a 63 A three-phase + neutral kilowatt-hour meter with partial metering.
For more information on instructions or functions of:
ME1ZR, refer to ME1ZR Instruction Sheet.
ME3ZR, refer to ME3ZR Instruction Sheet.
ME4ZR, refer to ME4ZR Instruction Sheet.
Wiring Diagram
Electrical wiring to the Com’X 200
Electrical wiring to the SIM10M
68
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM9P
Overview
The PM9P is an electrical measurement and metering unit for 1Ph+N, 3Ph, and 3Ph+N low-voltage systems.
For more information on instructions or functions of the PM9P, refer to PM9P Instruction Sheet.
PM9P Wiring Diagram to the Com’X 200 and SIM10M
Electrical wiring to the Com’X 200:
Electrical wiring to SIM10M:
PM9P Pulse Output Setup
Step
1
Action
Press simultaneously the and the
2 Enter pass code: 0010.
button to enter the settings menu.
3 Press several times the OK button to scroll to PULS EnEr menu and select Wh to measure active energy.
4 Press OK to access to PULS UAL menu and select pulse weight in kWh.
5 Press OK to access to PULS dUr menu and select pulse duration in ms.
6 Press OK several times to exit settings menu.
DOCA0035EN-01 03/2014
69
Monitoring Devices and Electrical Equipment
PM200P
Overview
The PM200P is a 3-phase power meter, with 2 integrated digital pulse outputs.
Output connected on pins 7-8 is dedicated to active energy measurement.
Output connected on pins 9-10 is dedicated to reactive energy measurement.
The Com’X 200 digital inputs manages only pulses associated to active energy measurement.
For more information on instructions or functions of PM200P, refer to PowerLogic Power Meter 200 and
200P Installation Guide.
PM200P Wiring Diagram to Com’X 200 and SIM10M
Electrical wiring to the Com’X 200:
Electrical wiring to SIM10M:
PM200P Pulse Output Setup
Step
1
2
3
6
7
4
5
8
9
Action
Press --> to scroll to DIAGN menu.
Press DIAGN button.
Press SETUP button.
Press + button and validate password 0000 by pressing OK.
Press --> to scroll to PULSE menu.
Press PULSE button.
Select MSEC menu to select pulse duration in ms and press OK.
Select KWH/P menu to select pulse weight in kWh and press OK.
Press Return button several times to exit configuration mode and display measurements values.
70
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM5100
Overview
The PowerLogic PM5100 power meter provides:
a single digital pulse output
33 alarms power quality analysis up to the 15th harmonic
For more information on instructions or functions of PM5100, refer to , PM5100, PM5110, PM5111
Information Sheet.
PM5100 Wiring Diagram To Com’X 200
Electrical wiring to the Com’X 200:
DOCA0035EN-01 03/2014
71
Monitoring Devices and Electrical Equipment
Electrical Modbus Meters
Section 8.2
Electrical Modbus Meters
What Is in This Section?
This section contains the following topics:
Topic
EM3550 / EM3555
EM6400 / EM6433 / EM6434 / EM6436 / EM6438 iEM3150 / iEM3155 / iEM3250 / iEM3255
ION6200 / ION7300 / ION7330 / ION7350
PM9C
PM210 / PM500 / PM710 / PM750 / PM800 Series
PM1200
PM3250 / PM3255 / PM5110 / PM5111 / PM5310 / PM5330 / PM5331
PM5350
Page
72
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
EM3550 / EM3555
Overview
The EM3550 and EM3555 Modbus meters combine exceptional performance and easy installation to deliver a cost-effective solution for power monitoring applications. Each meter can be installed on standard
DIN rail or surface mounted.
Pulse output and phase alarms provide additional versatility. Modbus outputs offer added flexibility for system integration.
The data logging feature of the EM3555 helps protect data in the event of a power failure. Modbus, pulse output, and phase alarms are provided to suit a wide variety of applications.
For more information on meter functionality, refer to the EM3500 Series DIN Rail Meter Technical data
sheet.
EM35500 / EM3555 Wiring Diagram to Com’X 200
DOCA0035EN-01 03/2014
73
Monitoring Devices and Electrical Equipment
EM6400 / EM6433 / EM6434 / EM6436 / EM6438
Overview
The EM6400 series of meters are digital power meters that offer comprehensive three-phase electrical instrumentation and load management facilities in a compact and rugged package.
For more information on instructions or functions of EM6400 series, refer to Dietitian EM6400 Series User
Manual.
EM6400 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
EM6400 Series Communication Setup
Step
1
2
3
4
5
6
11
12
13
9
10
7
8
Action
From RMS menu, press the up arrow button: the display indicates CLR.
Press the up arrow button: the display indicates SET.
Press the right arrow button: the display indicates VIEW.
Press the down arrow button: the display indicates EDIT.CODE.
Press the right arrow button for 2 seconds: the display blinks, indicating CODE 2000.
To enter pass code 1000 (default setting), press the down arrow button: the display indicates CODE 1000 with blinking 1. Press Return once, and press the right arrow button 4 times to accept the new code value.
The display flashes PASS and then EDIT A.PRI 100.0 indicating successful entry in edit mode.
Press the right arrow button several times until the display indicates EDIT BAUD.
Select the correct Baud rate and press Return to validate.
Select the correct parity, the number of stop bit, and press Return to validate.
Select the correct Modbus address (ID) and press Return to validate.
Press the left arrow button: the display indicates SAVE YES with a blinking Y.
Press the left arrow button to save the new values: the display flashes PASS and then displays EDIT.
Press the left arrow button to go back to SET, and display the measurement values.
74
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
iEM3150 / iEM3155 / iEM3250 / iEM3255
Overview
iEM3150, iEM3155, iEM3255, and iEM3250 are 3-phase + neutral kilowatt-hour meter with partial metering and reset.
For more information on instructions or functions of:
iEM3150,iEM3155, refer to iEM3150,iEM3155 Instruction Sheet.
iEM3250, iEM3255, refer to iEM3250, iEM3255 Instruction Sheet.
iEM3x5x Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has t o be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
IEM3150 / iEM3250 Communication Setup
Step
1
2
3
4
5
6
Action
Press simultaneously the Esc and the OK buttons for 2 sec to enter in Setup mode.
Press Down arrow until you reach the Communication screen, and press OK.
Enter the Address parameter, and press OK.
Enter the Baud Rate parameter, and press OK.
Enter the Parity parameter, and press OK.
Press Down arrow to select Exit config item and press OK to confirm.
iEM3155 / iEM3255 Communication Setup
Step
1
2
3
4
5
6
7
Action
Press simultaneously the Esc and the OK buttons for 2 sec.
Enter pass code: 0010 to enter the Setup menu.
Press the Down arrow until you reach the Comm screen, and press OK.
Enter the Address parameter, and press OK.
Enter the Baud Rate parameter, and press OK.
Enter the Parity parameter, and press OK.
Press Down button to select Exit config, and press OK to confirm.
DOCA0035EN-01 03/2014
75
Monitoring Devices and Electrical Equipment
ION6200 / ION7300 / ION7330 / ION7350
Overview
The ION6200 is a power-monitoring unit, complete with four-quadrant power, demand, energy, power factor, and frequency measurements.
The ION7300 series meters are intelligent metering and control devices suited to a wide range of applications. The meters can be used as stand-alone devices, but their extensive capabilities are fully realized when used as part of an enterprise energy management (EEM) system.
For more information on instructions or functions of ION6200, refer to PowerLogic ION6200 Power and
Energy Meter Installation & Operation Guide.
For more information on instructions or functions of ION7300 series, refer to PowerLogic ION7300 series
User Guide.
ION6200 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
Using the ION6200 Meter
With the meter front panel, you can view parameter values, configure parameters, perform demand resets, perform LED checks, and view meter information. Each of these functions can be accomplished by pressing the Up, Down, and Enter buttons on the front panel. These button actions achieve different results according to the meter mode:
Display mode (default): view parameter measurements.
Reset mode: reset demand measurements.
Configuration Select/Edit modes: configure a parameter.
Information mode: verify that the LED front panel display operates, and view meter information (for example, meter options, firmware version).
76
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Execute the following steps to access the configuration screen and configure the communications parameters:
Step
1
2
3
4
5
6
Action
Press simultaneously the Up and Down buttons for 2 seconds to enter the Configuration Select mode, and release the Up and Down buttons.
Press the Up or Down buttons until you reach the Protocol parameter in the communication section.
Press the Enter button to enter the configuration edit mode.
Press the Up or Down buttons to configure the Protocol parameter.
Press the Enter button to save the parameter value.
Repeat steps 2 to 5 to configure Baud Rate, and Unit ID.
Refer to PowerLogic ION6200 Power and Energy Meter Installation & Operation Guide for power meter use.
ION7300, ION7330, ION7350 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
Using the ION7300 Series Meter
Serial communications are available on COM1, and COM2. To enable communications through the meter serial ports, configure the applicable communications module.
The Protocol, Tran delay, Baud rate, and unit ID setup registers must properly match your system and can be set through the meter front panel or ION software.
To access the communications module, follow this procedure:
Step
1
2
3
Action
Press the round button to access the front panel main setup menu. The setup menu appears listing the meter front panel setup options.
Select Quick Setup to access the communications module.
Enter the appropriate values for Protocol, Baud Rate, and Unit ID.
NOTE: ION7330 is not consistant with the Com’X 200 default settings. Change the Com’X 200 settings to a configuration without parity.
DOCA0035EN-01 03/2014
77
Monitoring Devices and Electrical Equipment
PM9C
Overview
The PM9C is an electrical measurement and metering unit for 1Ph+N, 3Ph, and 3Ph+N low-voltage systems.
For more information on instructions or functions of PM9C, refer to PM9C Instruction Sheet.
PM9C Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
PM9C Communication Setup
Step
1
4
5
2
3
6
Action
Press simultaneously the and the
Enter pass code: 0010.
button to enter the settings menu.
Press the OK button several times to go to ADDR menu.
Set the Modbus address parameters and press OK.
Go to BAUD menu to set the Modbus Baud rate parameters and press OK.
Go to PAR menu to set the Modbus parity parameters and press OK.
78
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM210 / PM500 / PM710 / PM750 / PM800 Series
Overview
The PM210, PM500, PM710, PM750, and PM800 series meters offer all measurement capabilities required to monitor an electrical installation, associated to remote transfer of metering values by RS 485
Modbus communication network (2-wire connection).
For more information on instructions or functions of:
PM210, refer to PowerLogic Power Meter 210 Reference Manual.
PM500, refer to Power Meter PM500 Installation and User Manual.
PM710, refer to PM710 Reference Manual.
PM750, refer to PM750 Installation Guide.
PM800, refer to PowerLogic PM800 Series Quick Reference Guide.
PM210 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
PM210 Communication Setup
Step
1
2
3
6
7
4
5
8
9
10
Action
From Home menu, press ---> until you see DIAGN, and press Setup.
Enter pass code: 0000.
Press COM to have access to the Baud rate, address, and parity setup.
Enter address.
Press OK.
Enter Baud rate.
Press OK.
Enter parity.
Press OK.
Press the Return button several times to exit configuration mode, and display measurement values.
DOCA0035EN-01 03/2014
79
Monitoring Devices and Electrical Equipment
PM500 Wiring Diagram to Com’X 200
The graphic shows how to connect the PM500 Modbus option to the Com’X 200:
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
If the PM500 device is located at 1 termination of the Modbus line, flip switches 1 and 2 must be set on the
ON position.
PM500 Communication Setup
Step
1
2
3
6
7
4
5
10
11
8
9
12
Action
Press the Prog button for at least 3 sec to enter the programming mode.
Enter code 100.
Press the Return button to confirm the code.
Press the Down button until you reach the COM screen.
Enter the address, and confirm with the Return button.
Press the Down button to configure the Baud rate.
Enter the Baud rate, and confirm with the Return button.
Press the Down button to configure the parity.
Enter the parity, and confirm with the Return button.
Press the Down button to configure the stop bit.
Enter the stop bit, and confirm with the Return button.
Press the Prog button for at least 3 sec to exit the programming mode.
PM710, PM750 and PM800 Series Wiring Diagram to Com’X 200
80
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM710 and PM750 Communication Setup
Step
1
2
3
4
5
9
10
6
7
8
Action
From Home menu, press SETUP.
Enter pass code: 0000.
Press ---> until COM is visible.
Enter address.
Press OK.
Enter Baud rate.
Press OK.
Enter parity.
Press OK.
Press OK to return to the SETUP mode.
PM800 Communication Setup
10
11
8
9
12
13
Step
1
2
3
6
7
4
5
Action
From Home menu, press ---> until you see MAINT, and press Setup.
Enter pass code: 0000.
Press ---> until COMMS is visible.
Press COMM1.
Select the protocol.
Press OK.
Enter address.
Press OK.
Enter Baud rate.
Press OK.
Enter parity.
Press OK.
14
15
Press until you are asked to save your changes.
Press YES to save your changes.
Repeat steps 5 to 14 to configure other potential Modbus ports.
DOCA0035EN-01 03/2014
81
Monitoring Devices and Electrical Equipment
PM1200
Overview
The PM1200 power meter is easy-to-use, cost effective, and offers the basic measurement capabilities required to monitor an electrical installation.
For more information on instructions or functions of PM1200, refer to PowerLogic System Catalog.
PM1200 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
PM1200 Communication Setup
Step
1
2
3
4
5
6
11
12
13
9
10
7
8
Action
From RMS menu, press the up arrow button: the display indicates CLR.
Press the up arrow button: the display indicates SET.
Press the right arrow button: the display indicates VIEW.
Press the down arrow button: the display indicates EDIT.CODE.
Press the right arrow button for 2 seconds: the display blinks, indicating CODE 2000.
To enter the pass code 1000 (default setting), press the down arrow button: the display indicates CODE
1000 with blinking 1. Press Return once, and press the right arrow button 4 times to accept the new code value. The display flashes PASS and then EDIT A.PRI 100.0 indicating successful entry in edit mode.
Press the right arrow button several times until the display indicates EDIT BAUD.
Select the correct Baud rate and press Return to validate.
Select the correct parity, the number of stop bit, and press Return to validate.
Select the correct Modbus address (ID) and press Return to validate.
Press the left arrow button: the display indicates SAVE YES with a blinking Y.
Press the left arrow button to save the new values: the display flashes PASS and then displays EDIT.
Press the left arrow button to go back to SET, and display the measurement values.
82
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM3250 / PM3255 / PM5110 / PM5111 / PM5310 / PM5330 / PM5331
Overview
The PowerLogic PM3250 and PM3255Modbus power meters provide:
electrical parameters I, In, U, V, PQS, E, PF, Hz, THD min/max and time-stamped alarms
5 time-stamped alarms for PM3250
15 time-stamped alarms for PM3255
LED communications indicator
RS485 communications additional features of the :
2 digital inputs
2 digital outputs memory for load profile
Both the PowerLogic PM5110 and the PM5111 Modbus power meters provide:
a single digital pulse output
33 alarms power quality analysis up to the 15th harmonic
The PowerLogic PM5310, PM5330 and PM5331 Modbus power meters provide:
2 digital inputs
2 digital outputs
256K memory
35 alarms power quality analysis up to the 31st harmonic
For more information on instructions or functions of:
PM3250, PM3255, refer to PM3250, PM3255 Instruction Sheet.
PM5110, PM5111, refer to PM5110, PM5111 Instruction Sheet.
PM5310, refer to PM5310 Instruction Sheet.
PM5330, PM5331, refer to PM5330, PM5331 Instruction Sheet.
PM3250 / PM3255 / PM5110 / PM5111 / PM5310 / PM5330 / PM5331 Wiring Diagram to Com’X 200
DOCA0035EN-01 03/2014
1 If the current circulating in the shield is higher than 100 mA, the shield has t o be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
83
Monitoring Devices and Electrical Equipment
PM3250 / PM3255 Communication Setup
Step
1
2
3
4
5
6
7
Action
Press simultaneously the Esc and the OK buttons for 2 sec.
Enter pass code: 0010 to enter the Setup menu.
Press the Down arrow until you reach the Comm screen, and press OK.
Enter the Address parameter, and press OK.
Enter the Baud Rate parameter, and press OK.
Enter the Parity parameter, and press OK.
Press Down button to select Exit config, and press OK to confirm.
PM5110 / PM5111 / PM5310 / PM5330 / PM5331 Communication Setup
12
13
14
15
16
10
11
8
9
Step
1
2
3
6
7
4
5
Action
Scroll to Maint in the menu list.
Press Maint.
Press Setup.
Press Comm to enter the communications setup screen.
Press the down arrow to select Protocol, then press Edit.
Press + or - to scroll through the protocol options.
Press OK to set the protocol.
Press the down arrow to select Address, then press Edit.
Enter address.
Press OK to set the address.
Press the down arrow to select Baud Rate, then press Edit.
Press + or - to scroll through the Baud rate options.
Press OK to set the Baud rate.
Press the down arrow to select Parity, then press Edit.
Press + or - to scroll through the parity options.
Press OK to set the parity.
84
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM5350
Overview
The PowerLogic PM5350 power meter offers all the measurement capabilities required to monitor an electrical installation in a single 96 x 96 mm unit extending only 44 mm behind the mounting surface.
For more information on instructions or functions of PM5350, refer to PowerLogic Power Meter PM5350
User Guide.
PM5350 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
PM5350 Communication Setup
Step
1
2
3
10
11
8
9
6
7
4
5
12
13
14
15
16
Action
Scroll to Maint in the menu list.
Press Maint.
Press Setup and enter your setup password.
NOTE: The default password is 0000.
Press Comm to enter the communications setup screen.
Press the down arrow to select Protocol, then press Edit.
Press + or - to scroll through the protocol options.
Press OK to set the protocol.
Press the down arrow to select Address, then press Edit.
Enter address.
Press OK to set the address.
Press the down arrow to select Baud Rate, then press Edit.
Press + or - to scroll through the Baud rate options.
Press OK to set the Baud rate.
Press the down arrow to select Parity, then press Edit.
Press + or - to scroll through the parity options.
Press OK to set the parity.
DOCA0035EN-01 03/2014
85
Monitoring Devices and Electrical Equipment
Electrical Ethernet Meters
Section 8.3
Electrical Ethernet Meters
What Is in This Section?
This section contains the following topics:
Topic
PM5320 / PM5340 / PM5341
PM5560 / PM5561 / PM5563
Page
86
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
PM5320 / PM5340 / PM5341
Overview
The PowerLogic PM5320, the PM5340, and the PM5341 Ethernet power meters provide:
a single Ethernet (Modbus TCP/IP) 10/100 port
256 K memory
2 digital inputs
2 digital outputs
35 alarms
Power quality analysis up to the 31st harmonic
For more information on instructions or functions of the PM5320, PM5340, and PM5341, refer to the
PM5310, PM5320, PM5330, PM5331, PM5340, PM5341 Instruction Sheet.
PM5320 / PM5340 / PM5341 Wiring Diagram To Com’X 200
To wire the Ethernet meter, connect the Ethernet port on the power meter to an Ethernet switch on the same network as the Com’X 200.
PM5320 / PM5340 / PM5341 Ethernet Communication Setup
4
5
6
2
3
Step
1
Action
Navigate to Maint → Setup.
Enter the setup password (default is 0000), then press OK.
Press Comm.
Move the cursor to point to the parameter you want to modify, then press Edit.
Modify the parameter as required, then press OK.
Move the cursor to point to the next parameter you want to modify, press Edit; make your changes; then press OK.
DOCA0035EN-01 03/2014
87
Monitoring Devices and Electrical Equipment
PM5560 / PM5561 / PM5563
Overview
The PowerLogic PM5560, the PM5561, and the PM5563 Ethernet power meters provide:
Dual Ethernet (Modbus TCP/IP) 10/100 ports
1.1 M memory
4 digital inputs
2 digital outputs
52 alarms
Power quality analysis up to the 63rd harmonic
For more information on instructions or functions of the:
PM5560, refer to PM5560 Instruction Sheet.
PM5561, refer to PM5561 Instruction Sheet.
PM5563, refer to PowerLogic PM5563 Instruction Sheet.
PM5560 / PM5561 / PM5563 Wiring Diagram To Com’X 200
To wire the Ethernet meter, connect any Ethernet port on the power meter to an Ethernet switch on the same network as the Com’X 200.
If you wish to create an Ethernet communication bus, connect the left Ethernet port on the power meter to an Ethernet switch on the same network as the Com’X 200 and use the right Ethernet port to continue the communication bus.
PM5560 / PM5561 / PM5563 Ethernet Communication Setup
3
4
5
Step
1
2
6
Action
Navigate to Maint
→ Setup.
Enter the setup password (default is 0), then press OK.
Press Comm
→ Enet.
Move the cursor to point to the parameter you want to modify, then press Edit.
Modify the parameter as required, then press OK.
Move the cursor to point to the next parameter you want to modify, press Edit; make your changes; then press OK.
88
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Circuit Monitors
Section 8.4
Circuit Monitors
CM3000 / CM4000
Overview
The Power Logic CM3000 and CM4000 circuit are high-performance circuit monitoring meters for mains or critical loads on both high voltage and low voltage networks. Both circuit monitors provide the following functionality:
Metering
Remote display
On-board logging
Waveform capture
Disturbance monitoring (standard on the CM4000; optional on the CM3000)
Revenue accuracy (class 0.5 for the CM3000; class 0.2 for the CM4000)
RS485 communication
The CM400 additionally provides:
Programmable logic
Field upgradable memory
Optional transient capture
RS232 communication
For more information on the:
CM3000, refer to the PowerLogic Series 3000Circuit Monitor Reference Manual
CM4000, refer to the PowerLogic Series 4000Circuit Monitor Reference Manual
CM3000 / CM4000 Wiring Diagram to Com’X 200
89
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Power Factor Controllers
Section 8.5
Power Factor Controllers
Varlogic NRC12 Controller
Overview
The Varlogic NRC12 controller measures and records the reactive power of the installation, and provides
12 step output contacts that control the connection and disconnection of capacitor steps in order to obtain the necessary power factor.
For more information on instructions or functions of the Varlogic NRC12, refer to Varlogic NRC12 Power
factor controller User manual.
Varlogic NRC12 Controller Wiring Diagram To Com’X 200
Electrical wiring to the Com’X 200:
Varlogic NRC12 Modbus Communication Setup
5
6
3
4
Step
1
2
Action
Select PARAMETERS from the main menu of VARLOGIC HMI.
Access to the parameters menu is locked. To unlock, press both arrow keys simultaneously for 2 seconds.
Select MODBUS SETUP.
Scroll to the Mode sub-menu, then select READ (Communication is read only).
Scroll to Address sub-menu and select the appropriate address.
Scroll to Bit/s sub-menu and select a communication baudrate.
NOTE: The Parity bit is fixed and is always equal to Even.
90
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Circuit Breakers
Section 8.6
Circuit Breakers
NSX Micrologic and Masterpact
Overview
Compact NSX is a 100...630 A circuit breaker range.
Masterpact is a 800...6,300 A circuit breaker range.
For power connections and more technical details on the Compact NSX and Masterpact, refer to Modbus
Communication for Circuit Breakers CompactNSX, CompactNS, and Masterpact NT/NW Circuit Breakers document.
NSX Micrologic or Masterpact Wiring Diagram to Com’X 200 Through the IFM
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
IFM Communication Setup
Use the 2 coding wheels on IFM front panel to set the Modbus address.
The IFM module automatically detects the Baud rate and parity when it is connected to the Modbus network.
91
DOCA0035EN-01 03/2014
Monitoring Devices and Electrical Equipment
Masterpact Wiring Diagram to Com’X 200 Through the BCM
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
Configuring the BCM with a Masterpact and Micrologic A, E, H and P
The Modbus address and communication parameters are defined using the keypad on the Micrologic P or
H trip unit.
Step
1
Action Micrologic P or H
2
Press to access the configuration menu.
Select Configure com then Parameter com. to display the Modbus Com screen.
3
Press the to confirm.
and keys to select the address setting, then press the key
4
5
Press the confirm.
and keys to define the address, then press the
Go back to step 3 to set the Baud rate, then the parity.
key to
92
DOCA0035EN-01 03/2014
Com’X 200
Acquisition Modules
DOCA0035EN-01 03/2014
Wiring Acquisition Modules
Chapter 9
Wiring Acquisition Modules
Safety Instruction
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
NOTE: Refer to the manufacturer’s documentation for each device for complete installation instructions.
What Is in This Chapter?
This chapter contains the following topics:
Topic
Acti 9 Smartlink
SIM10M
Page
DOCA0035EN-01 03/2014
93
Acquisition Modules
Acti 9 Smartlink
Overview
The Acti 9 Smartlink communication system is used to monitor, measure, and control electrical distribution boards via a Modbus communication network.
Refer to the Acti 9 Communication System User Manual for more details on Acti 9 Smartlink, and for connecting all the channels to the Acti 9 Smartlink.
Acti 9 Smartlink Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
Setting the Modbus Address Parameters
The Acti 9 Smartlink modbus addressing is performed using the 2 thumbwheels X10 and X1 located on the front side.
The left-hand thumbwheel sets the tens.
The right-hand thumbwheel sets the units.
The Acti9 Smartlink module automatically detects the Baud rate and parity when it is connected to the
Modbus network.
94
DOCA0035EN-01 03/2014
Acquisition Modules
SIM10M
Overview
Smart Interface Module (SIM) are IEDs (Intelligent Electronic Devices) used in energy efficiency applications that provide local physical interfaces with building WAGES (Water Air Gas Electricity Steam) meters, sensors, and actuators. They communicate through wired or wireless networks with remote monitoring and control systems.
For more information or instructions on SIM10M, refer to Smart Interface Modules Installation Guide.
SIM10M Wiring Diagram to Com’X 200
Electrical connection to the Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
SIM10M Communication Setup
The SIM10M is configured by a web server configuration tool. Once the SIM10M has been connected to the acquisition devices, the SIM10M node has to be configured.
Baud rate, parity, and address parameters are configured using the SIM_range_configuration_tool.
Pulse weight, unit, index value, and analog input scaling are managed through the Com’X 200 configuration screens.
Step
1
2
3
4
5
6
Action
Download the SIM_range_configuration_tool on a local PC.
Launch the configuration software.
Configure the SIM10M parameters: Baud rate, Parity, Address. The other parameters keep their default value.
Connect the SIM10M to the PC through a USB cable. The SIM10M LED turns yellow.
Select the virtual COM port according to the USB port affectation, and download configuration into the
SIM10M.
Disconnect the USB cable. The SIM10M turns green.
DOCA0035EN-01 03/2014
95
Acquisition Modules
96
DOCA0035EN-01 03/2014
Com’X 200
Gateways
DOCA0035EN-01 03/2014
Wiring Gateways
Chapter 10
Wiring Gateways
Safety Instruction
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
NOTE: Refer to the manufacturer’s documentation of each device for complete installation instructions.
What Is in This Chapter?
This chapter contains the following topics:
Topic
EGX100 / EGX300
PM8ECC
Page
DOCA0035EN-01 03/2014
97
Gateways
EGX100 / EGX300
Overview
The EGX100 / EGX300 are Ethernet-based devices providing a transparent interface between Ethernetbased networks and field devices. Field devices include meters, monitors, protective relays, and other devices that communicate using Modbus.
The EGX100 / EGX300 can be used to connect Modbus devices when you are too far from the Com’X 200 master Modbus port. This can be the case for large buildings or several buildings connected by the same
IP network or ADSL connection.
For power connections and more technical details on:
EGX100, refer to PowerLogic Ethernet Gateway EGX100 User Guide.
EGX300, refer to PowerLogic Ethernet Gateway EGX300 User Guide.
EGX100 / EGX300 Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
EGX100 Communication Setup
The EGX is delivered with 8 pre-installed web pages used for EGX setup and configuration:
Ethernet & TCP/IP
Serial Port
Device List
User Accounts
Web Page Access
Modbus TCP/IP Filtering
SNMP Parameters
System Access Point
This procedure describes the different steps for setting up the EGX100 Ethernet port and declaring the
Modbus devices connected below the EGX100.
98
DOCA0035EN-01 03/2014
DOCA0035EN-01 03/2014
Gateways
Before proceeding, please note:
Modbus product addresses
Modbus product Baud rates
Modbus product parity
EGX100IP address subnet mask where your EGX will be connected router IP address, if the EGX100 is not directly connected to the Com’X 200 network
Step
1
2
3
4
Description Action
First connection to EGX100
Connect your laptop to the connector on the top face of the EGX by an
RJ45 LAN crossover cable.
By default, the IP address of the EGX100 is 169.254.0.10 (User name:
Administrator, Pass code: Gateway).
Change the IP of your laptop to be on the same sub network as the
EGX100.
For example:
Laptop address: 169.254.0.9
Subnet mask: 255.255.255.0
Open an Internet Explorer window and type the default IP address of your EGX100.
Configuration of IP Network port
In the Setup menu on the top of the main window, select Ethernet &
TCIP/IP sub-menu.
Keep the Ethernet default parameters unchanged.
Configure the IP Address, the Subnet Mask, and the Default Gateway parameters.
(Ethernet default parameters: Frame format = Ethernet II, Media Type =
10T/100Tx Auto)
Configuration of Modbus serial port
In the Setup menu on the top of the main window, select Serial Port sub-menu.
Keep the Mode, the Physical Interface, the Transmission Mode, and the Response Timeout default parameters unchanged.
Configure the Baud Rate and Parity parameters, according to Modbus slaves Baud rate and parity possibilities. Most common values are Baud rate = 19200 and parity = even.
(Transmission Mode default parameters: Mode = Master, Physical
Interface = RS 485 2-wire, Transmission mode = Automatic, Response
Timeout = 3 s)
Modbus device declarations
In the Setup menu on the top of the main window, select Device List sub-menu.
Select the number of viewable devices (1 to 128).
Configure the Local ID according to the slaves addresses, and
Protocol parameters for each viewable device.
Set Protocol = Modbus for all the slaves.
99
Gateways
EGX300 Communication Setup
This procedure describes the different steps for setting up the EGX300 communication ports.
Before proceeding, please note:
the EGX300 IP address
the subnet mask where your EGX will be connected the router IP address, if the EGX300 is not directly connected to the Com’X 200 network the Modbus network characteristics: Baud rate and parity
Step
1
2
3
Description Action
First connection to EGX300
Connect your laptop to the connector on the top face of the EGX by an
RJ45 LAN crossover cable.
By default, the IP address of the EGX300 is 169.254.0.10 (User name:
Administrator, Pass code: Gateway).
Change the IP of your laptop to be on the same sub network as the
EGX300.
For example:
Laptop address: 169.254.0.9
Subnet mask: 255.255.255.0
Open an Internet Explorer window and write the default IP address of your EGX300.
Configuration of IP Network port
In the Setup menu on the top of the main window, select Ethernet &
TCIP/IP sub-menu.
Keep the Ethernet default parameters unchanged.
Configure the IP Address, the Subnet Mask, and the Default Gateway parameters.
(Ethernet default parameters: Frame format = Ethernet II, Media Type =
10T/100Tx Auto)
Configuration of Modbus serial port
In the Setup menu on the top of the main window, select Serial Port sub-menu.
Keep the Mode, the Physical Interface, the Transmission Mode, and the Response Timeout default parameters unchanged.
Configure the Baud Rate and Parity parameters, according to Modbus slaves Baud rate and parity possibilities. Most common values are Baud rate = 19200 and parity = even.
(Transmission Mode default parameters: Mode = Master, Physical
Interface = RS 485 2-wire, Transmission mode = Automatic, Response
Timeout = 3 s)
Refer to PowerLogic Ethernet Gateway EGX300 User Guide for more details on communication setup.
100
DOCA0035EN-01 03/2014
Gateways
PM8ECC
Overview
The PM8ECC is a communications add-on module for the Series 800 Power Meter that provides connectivity between Ethernet (Modbus TCP/IP) and serial line devices. It allows Modbus TCP/IP clients to access information from the host power meter and the serial slave devices.
For more information on instructions or functions of PM8Ecc, refer to PowerLogic Series 800 Power Meter
Ethernet Communications Card User Guide.
PM8ECC Wiring Diagram to Com’X 200
1 If the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, it has to be grounded at both ends.
PM8ECC Ethernet Configuration
Before configuring the PM8ECC, obtain a unique static IP address, subnet mask, and default gateway address from your network administrator. Use a web browser or the power meter display to configure the
PM8ECC with the information obtained from your network administrator.
Refer to PowerLogic Series 800 Power Meter Ethernet Communications Card User Guide for more details.
PM8ECC Communication Setup
After you set up the PM8ECC Ethernet parameters, you can access the PM8ECC over an Ethernet LAN using Internet Explorer 6.0 or higher.
The PM8ECC user interface for communication setup consists of multiple web pages.
To access the Setup web page links, click Setup on the PM8ECC menu bar.
Refer to PowerLogic Series 800 Power Meter Ethernet Communications Card User Guide for more details on each web page.
First connection to PM8ECC
Step
1
2
3
Action
Connect your laptop to your PM8ECC by an RJ45 LAN cable.
Change the IP of your laptop to be on the same sub network as the PM8ECC. For example: Laptop address: 169.254.0.9, subnet mask: 255.255.255.0. The factory setting for the IP address of the PM8ECC is 169.254.0.10 (User name: Administrator, Pass code: Gateway).
Open an Internet explorer window and type the default IP address of your PM8ECC to access the
PM8ECC home page.
NOTE: All PM8ECC have the same default login and password. To avoid unexpected access to the gateway, you have to change these parameters. Go to Setup
→ User accounts menu to change user name and password.
DOCA0035EN-01 03/2014
101
Gateways
Configuration of IP network port
Step
1
2
3
4
5
6
7
Action
Select Setup menu on the top of your window.
From the Setup menu, click Ethernet & TCPIP.
Select your frame format and media type. Contact your network administrator if you do not know the required configurations.
Enter your IP address, subnet mask, and default gateway address assigned to your PM8ECC by your network administrator.
Click Apply.
Click OK to validate the changes.
Click OK.
Configuration of Modbus serial port
Step
1
2
3
Action
From the Setup menu, click Serial Port.
Select your physical interface, transmission mode, Baud rate, parity, and response time-out.
Click Apply.
Modbus device declarations
Step
1
2
3
4
5
6
Action
From the Setup menu, click Device list.
Select the number of viewable devices (1 to 128).
In the Local ID text box, type the local ID (address) of the serial slave device.
Select the protocol.
Repeat steps 3 and 4 until all devices are entered.
Click Apply.
102
DOCA0035EN-01 03/2014
Com’X 200
Analog Sensors
DOCA0035EN-01 03/2014
Wiring Analog Sensors
Chapter 11
Wiring Analog Sensors
Safety Instruction
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
NOTE: Refer to the manufacturer’s documentation for each device for complete installation instructions.
What Is in This Chapter?
This chapter contains the following topics:
Topic
Pt100 / Pt1000
CWE CO2 Sensor 0–10 V and 4–20 mA
SHO100 and SHR100 Humidity Sensor 0–10 V and 4–20 mA
STD300 and STO300 4–20 mA Temperature Sensors
Page
103
DOCA0035EN-01 03/2014
Analog Sensors
Pt100 / Pt1000
Wiring Diagram
2 wires direct connection to the Com’X 200:
3 wires direct connection to the Com’X 200:
104
DOCA0035EN-01 03/2014
Analog Sensors
CWE CO2 Sensor 0–10 V and 4–20 mA
CWE CO2 Sensor 0–10 V and 4–20 mA Wiring Diagram
The wiring diagram is the same for both 0–10 V and 4–20 mA. You have to set the configuration switch of the sensor in the appropriate position to select the 0–10 V or 4–20 mA functioning mode.
CO2 sensor wiring diagram to Com’X 200:
CO2 sensor 0–10 V or 4–20 mA switch position:
DOCA0035EN-01 03/2014
105
Analog Sensors
SHO100 and SHR100 Humidity Sensor 0–10 V and 4–20 mA
SHO100 Humidity Sensor 0–10 V and 4–20 mA Wiring Diagram
SHO100 humidity sensor wiring diagram to the Com’X 200 in 0–10 V configuration:
SHO100 humidity sensor wiring diagram to the Com’X 200 in 4–20 mA configuration:
SHR100 Humidity Sensor 0–10 V and 4–20 mA Without External Power Supply Wiring Diagram
You have to set the configuration switch of the sensor in the appropriate position to select the 0–10 V or
4–20 mA functioning mode.
SHR100 humidity sensor wiring diagram to the Com’X 200 in 0–10 V configuration:
106
DOCA0035EN-01 03/2014
SHR100 humidity sensor wiring diagram to the Com’X 200 in 4–20 mA configuration:
Analog Sensors
SHR100 humidity sensor 0–10 V or 4–20 mA switch position:
DOCA0035EN-01 03/2014
107
Analog Sensors
STD300 and STO300 4–20 mA Temperature Sensors
STD300 and STO300 Temperature Sensors 4–20 mA Wiring Diagram
STD300 and STO300 temperature sensor wiring diagram to the Com’X 200.
108
DOCA0035EN-01 03/2014
Com’X 200
Converters
DOCA0035EN-01 03/2014
Wiring Converters
Chapter 12
Wiring Converters
Safety Instruction
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See
NFPA 70E in the USA or applicable local standards.
Turn off all power supplying this device before working on it.
Always use a properly rated voltage sensing device to confirm that all power is off.
Do not exceed the device’s ratings for maximum limits.
Failure to follow these instructions will result in death or serious injury.
NOTE: Refer to the manufacturer’s documentation for each device for complete installation instructions.
What Is in This Chapter?
This chapter contains the following topics:
Topic
4–20 mA to 0–10 V Zelio Converter (RMCL55BD)
Temperature Pt100 to 0–10 V Zelio Converter (RMPT13BD)
Temperature Pt100 to 0–10 V Converter (88 950 1••)
STAHL Interface for Gas Meter (9001/01-252-057-141)
Page
109
DOCA0035EN-01 03/2014
Converters
4–20 mA to 0–10 V Zelio Converter (RMCL55BD)
Wiring Diagram
Zelio converter connection to SIM10M:
110
DOCA0035EN-01 03/2014
Temperature Pt100 to 0–10 V Zelio Converter (RMPT13BD)
Wiring Diagram
Electrical connection to the Com’X 200:
Converters
A 2 wires connection type
B 3 wires connection type
C 4 wires connection type
Grounding shield (1): if the current circulating in the shield is higher than 100 mA, the shield has to be grounded at only 1 end. Otherwise, il has to be grounded at both ends.
Electrical connection to SIM10M:
DOCA0035EN-01 03/2014
111
Converters
Temperature Pt100 to 0–10 V Converter (88 950 1••)
Wiring Diagram
Electrical connection to the Com’X 200:
Electrical connection to SIM10M:
112
DOCA0035EN-01 03/2014
Converters
STAHL Interface for Gas Meter (9001/01-252-057-141)
Overview
The wiring of the interface for gas meter requires specific wiring instructions depending on the hazardous areas standard you wish to follow. Refer to the ATEX, NFPA 70, Article 504 or ANSI/ISA-12.01.01 standards for more information about hazardous areas requirements.
Wiring Diagram
Wiring example for the ATEX standard in a hydrocarbon gas environment (methane, butane, propane):
DOCA0035EN-01 03/2014
113
Converters
114
DOCA0035EN-01 03/2014
Com’X 200
DOCA0035EN-01 03/2014
Appendices
DOCA0035EN-01 03/2014
115
116
DOCA0035EN-01 03/2014
Com’X 200
Appendices
DOCA0035EN-01 03/2014
Appendices
Appendix A
Appendices
Troubleshooting List for Com’X 200
Troubleshooting
Troubleshooting table
If...
The Com’X 200 does not appear in the list of devices of the explorer
The login page does not correctly open in the Internet browser
Then ...
Check that there is no router between the Com’X 200 and the computer.
Check that your browser has a version level equal to or higher than the following versions:
Internet Explorer 8
Mozilla Firefox 15
Chrome 24
In Internet Explorer, open the Compatibility view settings window in the Tools menu, and check that the Display internal sites in compatibility view checkbox is unchecked.
DOCA0035EN-01 03/2014
117
DOCA0035EN-01
Schneider Electric Industries SAS
35, rue Joseph Monier
CS30323
F - 92506 Rueil Malmaison Cedex www.schneider-electric.com
As standards, specifications and designs change from time to time, please ask for confirmation of the information given in this publication.
03/2014
* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
