386X/XE
OPERATIONS
GUIDE
386X/XE
OPERATIONS
GUIDE
GERMAN RFI DECLARATION FOR CLASS B SELF
CERTIFICATION
Hiermit wird bescheinigt, dass der TriGem 386X and 386XE in
Übereinstimmung mit den Bestimmungen der Vfg 1046/1984
funk-entstort ist.
Der Deutschen Bundespost wurde das Inverkehrbringen dieses
Gerätes angezeigt und die Berechtigung zur Überprüfung der
Serie auf Einhaltung der Bestimmungen eingeräumt.
TriGem Inc.
4 NaengChun-Dong, Seodaemun-Ku
Seoul, Korea
English translation:
We hereby certify that the TriGem 386X and 386XE complies
with the RFI suppression requirements of Vfg 1046/1984. The
German Postal Service was the notified that equipment is being
marketed. The German Postal Service has the right to re-test
the equipment and verify compliance.
Note: Replace 1046 with 1045 for household appliances tested
per VDE 0875.
ii
IMPORTANT NOTICE
DISCLAIMER OF WARRANTY
TriGem Computer, Inc. makes no representations or warranties
with respect to this manual, and shall not be held liable for
technical or editorial omissions made herein; nor incidental or
consequential damages resulting from the furnishing, performance, or
use of this manual. Further, TriGem Computer, Inc. reserves the
right to make changes in the specifications of the product described
within this manual at any time without notice and without
obligation of TriGem Computer, Inc. to notify any person of such
revision or changes.
COPYRIGHT NOTICE
Copyright (C) 1990 by TriGem Computer Inc., All rights are
reserved. No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise, without the prior written permission of TriGem
Computer, Inc.
iii
TRADEMARKS
TriGem is a registered trademark of TriGem Computer, Inc.
AMI BIOS is a trademark of American Megatrends Inc.
IBM, PC, PC/XT, PC/AT, MDA, Monochrome Display Adaptor,
EGA, Enhanced Graphics Adaptor, VGA, and Video Graphics
Array are trademarks of International Business Machines
Corporation.
Intel is a registered trademark of Intel Corp.
Intel 386 is a trademark of Intel Corp.
AMD is a registered trademark of Advanced Micro Devices, Inc.
EGA Wonder is a trademark of ATI Technologies, Inc.
HP LaserJet Series II is a product of HewlettPackard, Inc.
MS-DOS and GW-Basic are trademark of Microsoft Corporation.
Windows is a trademark of Microsoft Corporation.
Seagate is a registered trademark of Seagate Technologies, Inc.
Hercules is a registered trademark of Hercules Computer
Technology, Inc.
Norton SI is a trademark of Peter Norton Computing, Inc.
Apple is a registered trademark of Apple Computer, Inc.
CP/M and CP/M-86 are trademarks of Digital Research, Inc.
Western Digital is a registered trademark of Western Digital Inc.
MultiSync is a trademark of NEC information Systems, Inc.
MultiScan is a trademark of Sony Corporation.
iv
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference. by one or more of the following measures:
l
Reorient or relocate the receiving antenna.
l
Increase the separation between the equipment and receiver.
l
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
l
Consult the dealer or an experienced radio/TV technician for
help.
If you experience problems with radio and/or television reception
through the use of this product, the following booklet, published by
the FCC, may prove helpful:
How to identify and Resolve Radio-TV Interference Problems
(Stock No. 004-000-00398-5)
This booklet is available from the U.S. Government Printing Office,
Washington, D.C. 20402.
V
SAFETY
The following instructions pertain to the risk of fire, electric shock
or bodily injury. Please read all of these instructions carefully.
Follow all of the instructions and warnings marked on this
product or included in this manual.
Do not use this computer on an unstable cart, stand or table.
Slots and openings in the cabinet and the back have been
provided for ventilation. To ensure the reliable operation of your
computer, and to protect it from overheating, these openings
must not be blocked or covered. Don’t use this product on a
bed, sofa, rug, or other similar surface.
Never push objects of any kind into the computer through the
cabinet openings, as they may touch dangerous voltage points or
short out parts that could result in a fire or electrical shock.
This computer should only be connected to the AC power
source indicated on your computer system’s information label. If
you are not sure of the type of AC power available, consult your
dealer or local power company. Only connect this computer to a
power outlet that matches the power requirements of this
computer.
Do not allow anything to rest on the power cord. Do not locate
this product where people will walk on the cord.
If you have to use an extension cord with this computer, make
sure that the total amperage rating of all equipment plugged into
it does not exceed the amperage rating of the extension cord.
Also, make sure that the total of all products plugged into the
main AC power outlet does not exceed 15 amps.
Unplug your computer from the main electrical power outlet
before cleaning.
Do not use this computer near water,
vi
MAINTENANCE
Except as explained in Chapter 7, “Expanding Your System,” do
not attempt to modify or service this product yourself. Opening or
removing those covers that are marked “DO NOT REMOVE” may
expose you to dangerous voltage points or other risks. Refer all
servicing problems to qualified service personnel.
If the product does not operate normally, adjust only those controls
that are covered by the operating instructions. Improper adjustment
of other controls may result in damage and may require extensive
repair work to restore the product to normal operation.
Unplug this product from the main power outlet and call for service
under any of the following conditions:
If the power cord or plug is damaged or frayed
If liquid has been spilled into the product
If the product has been exposed to rain or water
If the product has been dropped or the cabinet has been
damaged
If the product exhibits a distinct change in performance,
indicating a need for service
vii
Stop!
If you ever have to remove the main system unit cover, observe the
following precautions:
The power supply cord must be unplugged before the main
system unit cover is removed. (Separe le cordon d’alimentation
et puis enleve le couvercle.)
Once removed, the cover must be replaced and screwed in
position before the power supply cord is plugged back in. (Apres
le couvercle a enleve, visse le couvercle en place et remettre le
cordon d’alimentation.)
RELATED READING
For more information about MS-DOS commands and GW-Basic
programming, please refer to the user’s manuals provided with this
computer.
viii
Wichtige Sicherheitsvorschriften
Unbedingt beachten!
Allgemeine Sicherheit
Die nachfolgenden Anweisungen betreffen die Gefahr von
Verletzungen durch elektrische Spannung, Feuer und mechanische
Einwirkung. Bitte lesen Sie diese Anweisungen sorgfältig.
Beachten Sie alle Hinweise, die am Gerät selbst angebracht oder
in den zugehörigen Handbüchern vermerkt sind.
Stellen Sie das Gerät an einem sicheren, stabilen Arbeitsplatz
auf.
Am Gerät angebrachte Öffnungen (Schlitze und sonstige
Öffnungen) dienen der Beluftung des Gerätes. Um ein
zuverlässiges Arbeiten des Geräts zu gewährleisten und um
Überhitzung zu vermeiden, müßen diese Öffnungen unbedingt
freigehalten werden. Betreiben Sie das Gerät nie auf Betten,
Sofas oder anderen, wiechen Unterlagen.
Stecken keine Gegegenstände (Schraubenzieher, Buroklammem
etc.) in die Öffnungen. Sie würden damit Kurzschlüsse
herbeiführen die zur Zerstörung des Geräts führen, sich der
Gefahr eines Stromschlages aussetzen oder das Gerät in Brand
setzen.
Das Gerät darf nur an vorschriftmäßige Steckdosen mit der auf
dem Gerät angegebenen Netzspannung angeschlossen werden.
Wenn Sie nicht sicher sind, welche Netzspannung richtig ist,
wenden Sie sich an den Lieferanten des Gerätes oder an das
zuständige Elektriziträtswerk. Bitte nur an genügend stark
abgesicherte Steckdosen anschließen, die der Leistungsaufnahme
des Gerätes entsprechen.
ix
Auf das Netzanschlußkabel dürfen keine Gegenstände gestellt
werden. Legen sie das Netzkabel so, daß niemand darauftreten
oder darüber stolpern kann.
Wenn Sie Verlängerungskabel benutzen, müßen Sie sicher sein,
daß die gesamte Leistungsaufnahme nicht größer ist als das
Verlängerungskabel zuläßt. Der gesamte Stromverbrauch aller
angeschlossenen Geräte darf nicht mehr als 15 A betragen.
Wenn Sie das Gerät reinigen, muß das Netzkabel aus der
Steckdose gezogen werden.
Das Gerät dürfen Sie nicht in der Nähe von Wasserleitungen
benutzen.
Wartung des Computers
Wenn der Computer nicht ordnungsgemäß arbeitet, dütfen Sie nur
die Finstellungen vornehmen, die im Handbuch genannt werden.
Andere Einstellungen oder Veränderungen können den Computer
beschädigen oder zerstören. Umfangreiche und kostspielige
Reparaturen würden notwendig werden, um das Gerät wieder
betriebsfähig zu machen.
Ziehen Sie den Netzstecker aus der Steckdose und verständigen Sie
den zuständigen Kundendienst bei folgenden Störungen:
netzkabel ist defekt oder strak abgenutzt.
Flüssigkeit ist in dassGerät geschüttet worden.
Das Gerät war Regen oder Leitungswasser aus-gesetzt.
Das Gerät ist heruntergefallen oder das Gehäuse ist beschädigt.
Das Gerät arbeit nicht mehr richtig.
ACHTUNG:
Wenn Sie das Gerät öfnen mößen (Abnahme der verschraubten
Haube), ist unbedingt folgendes zu beachten:
Das Netzkabel muß aus der Steckdose gezogen werden und zwar
bevor Sie das Gerät öffnen.
Die Haube muss wieder monitert und verschraubt werden. Erst
dann darf das Netzkabel wieder eingesteckt werden.
xi
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Chapter 1
1.
2.
3.
4.
5.
6.
7.
8.
9.
Setting Up Your System
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Choosing a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting a Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting a Printer, Mouse, or Modem . . . . . . . . . . . . . . .
Using the Parallel Interface . . . . . . . . . . . . . . . . . . . . . . .
Using the Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting the Keyboard Angle . . . . . . . . . . . . . . . . . . . . .
Turning On the Computer . . . . . . . . . . . . . . . . . . . . . . . . . .
The Command Prompt . . . . . . . . . . . . . . . . . . . . . . . . . .
Copying System Diskettes . . . . . . . . . . . . . . . . . . . . . . . . . .
Resetting Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
1-1
1-2
l-4
1-6
1-6
l-8
l-9
l-10
1-11
l-12
l-15
l-16
l-19
Running the Setup Program
Running Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identifying the type of BIOS . . . . . . . . . . . . . . . . . . . . . .
Memory Test Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Errors Reported by BIOS . . . . . . . . . . . . . . . . . . . . . . . . .
Entering Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CMOS Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CMOS Setup Option . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving the CMOS Setup . . . . . . . . . . . . . . . . . . . . . . . .
Extended CMOS Setup . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving the Extended CMOS Setup . . . . . . . . . . . . . . . .
2-3
2-3
2-4
2-4
2-5
2-6
2-7
2-8
2-10
2-10
2-16
Contents xiii
Chapter 3
Using Your Computer
Changing the Operating Speed . . . . . . . . . . . . . . . . . . . . . . . .
Special Keys on Your Keyboard . . . . . . . . . . . . . . . . . . . . . . . .
Stopping a Command or Program . . . . . . . . . . . . . . . . . . . . . .
Using Disks and Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . .
How Disks Store Data . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of Diskette Drives . . . . . . . . . . . . . . . . . . . . . . . . .
Caring for Diskettes and Diskette Drives . . . . . . . . . . . . .
Inserting and Removing Diskettes . . . . . . . . . . . . . . . . . .
Write-protecting Diskettes . . . . . . . . . . . . . . . . . . . . . . . .
Making Backup Copies . . . . . . . . . . . . . . . . . . . . . . . . . .
Using a Single Diskette Drive . . . . . . . . . . . . . . . . . . . . .
Using the Hard Disk Drive . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4
Using MS-DOS With Your Computer
Inserting Diskettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Drive Letters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting MS-DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Prompt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cursor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MS-DOS Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Function Keys and MS-DOS . . . . . . . . . . . . . . . . . . . . . . . . . .
BACKSPACE Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Default Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Copying Your MS-DOS Diskettes . . . . . . . . . . . . . . . . . . . . . .
Copying on Single Drive Systems . . . . . . . . . . . . . . . . . .
Copying on Dual Drive Systems . . . . . . . . . . . . . . . . . . . .
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
File Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filenames and Extensions . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The DIR Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
File Searches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
xiv Contents
3-1
3-2
3-5
3-5
3-6
3-8
3-10
3-12
3-14
3-15
3-16
3-17
.4-2
4-2
4-4
4-6
4-6
4-6
4-7
4-7
4-9
4-10
4-12
4-13
4-16
4-20
4-20
4-21
4-24
4-24
4-25
Multiple Disk Drive Systems . . . . . . . . . . . . . . . . . . . . . . 4-26
Wildcards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Application Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Chapter 5
Using Floppy Disks
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Floppy Disks Work . . . . . . . . . . . . . . . . . . . . . . . . .
Formatting Diskettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The FORMAT Command . . . . . . . . . . . . . . . . . . . . . . . .
Option Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wildcards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 6
Using Your Hard Disk
What is a Hard Disk Drive? . . . . . . . . . . . . . . . . . . . . . . . . . . .
Care of Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing Your Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing Your SETUP . . . . . . . . . . . . . . . . . . . . . . . . . .
Partitioning Your Hard Disk . . . . . . . . . . . . . . . . . . . . . .
Formatting Your Hard Disk . . . . . . . . . . . . . . . . . . . . . . .
Organizing Your Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backing Up Your Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . .
The BACKUP Command . . . . . . . . . . . . . . . . . . . . . . . .
How Many Diskettes? . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The RESTORE Command . . . . . . . . . . . . . . . . . . . . . . .
Chapter 7
5-l
5-2
5-3
5-4
5-6
5-10
5-12
6-1
6-2
6-3
6-4
6-6
6-9
6-l1
6-16
6-16
6-17
6-19
Expanding Your System
Connecting Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting Printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting Modems . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting External Disk Drives . . . . . . . . . . . . . . . . . . .
7-1
7-3
7-4
7-4
7-5
7-5
Contents xv
System Expansion & Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Opening and Closing the Cabinet . . . . . . . . . . . . . . . . . . 7-8
Installing Circuit Boards . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Disk Drive Compartments . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Internal Hard Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Appendix A
Specifications
Computer System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-l
System MotherBoard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-l
CPU Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
System Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
System I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
SystemTiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
I/O Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Appendix B
System MotherBoard
Hardware Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
Removing the MotherBoard . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Switches...............................................................B-3
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
Appendix C
Video Monitor Systems
Monitor System Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Video Controller Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-l
Monitor Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Appendix D
Connector Pinouts
I/OPorts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Expansion Slot Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . D-5
xvi Contents
Introduction
Your personal computer is powerful, versatile, and easy to use.
After setting up your system with the simple instructions in this
manual, you’ll soon be using your favorite software programs.
This computer is available in these configurations:
The system provides one or two diskette drive and an
optional 40MB (or 80MB) hard disk drive.
You can operate a lot of application programs very fastly
and efficiently with this system because it provides 64KB
(or 128KB) Cache memory.
This model comes with 1MB of internal memory, a total of
eight internal option slots, a System Motherboard, on board
FDC, IDE HDC, and built in serial and parallel interfaces.
Your computer comes with MS-DOS — the operating system
by Microsoft. In addition to the introduction to MS-DOS
provided in this manual, you’ll find a complete reference
manual for the operating system packed in the box with the
computer.
As your needs grow, so can your computer; you can expand your
system by adding a wide variety of options. You can install
most option cards compatible with the IBM Personal
Computer. If you use software that executes complex
mathematical calculations, you may want to install a 387™
math coprocessor or 3167 math coprocessor to speed up
processing.
Introduction 1
How to Use This Manual
This manual explains how to set up and care for your
computer.
It also describes how to use your computer.
The instructions in this manual apply to your system, except
where otherwise indicated.
You probably don’t need to read everything in this book; see
the following chapter summaries.
Chapter 1 provides simple step-by-step instructions for setting
up your computer.
Chapter 2 describes how to run the Setup program to setup
your computer’s configuration.
Chapter 3 covers some general operating procedures, including
how to use and care for your disks and disk drives.
Chapter 4 provides basic instructions for using MS-DOS with
your computer.
Chapter 5 takes you into the more advanced techniques of
floppy disk file manipulation, such as formatting and copying.
Chapter 6 shows you how to set up and use the vast storage
capabilities of this system device.
Chapter 7 contains “how-to” information on adding
components (such as additional disk drives or expansion
boards), to your computer.
At the end of this guide is a set of Appendices which contain
technical information for the advanced user or field technician.
2 Introduction
Chapter 1
Setting Up Your System
Setting up your personal computer is easy. Just follow the nine
steps in this chapter.
When you finish setting up
and follow the instructions
The Setup program updates
the computer and any time
1
n
your computer, go on to Chapter 2
there to run the Setup program.
the list of equipment installed in
options are added or changed.
Unpacking
As you unpack the different parts of your computer system, be
sure to inspect each piece. If anything is missing or looks
damaged, contact the place where it was purchased for missing
items or replacements. If you cannot obtain the necessary part
of parts, call your TriGem Computer dealer for assistance.
Please have the computer’s serial number ready when you call.
Figure l-l. Unpacking Your System
Setting Up Your System
l-1
Besides this manual, you should have the following:
The computer and power cord
The Keyboard with attached cable
MS-DOS
GW-BASIC
diskettes
diskette
MS-DOS User’s Guide
GW-BASIC User’s Guide
In addition to these items, you need a compatible monitor to
use with the computer.
Be sure to keep your packing materials. They provide the best
protection for your computer if you need to transport it later.
2
Choosing a location
Before you set up your computer, it is important to choose the
right location. Select a spot that provides the following:
A large, sturdy desk or table that can easily support the
weight of your system, including all of its components.
Make sure the surface is hard and flat. Soft surfaces like
beds and carpeted floors can generate static electricity,
which may erase data on your disks and damage the
computer’s circuitry. Soft surfaces also prevent proper
ventilation.
Good air circulation. Air must be able to move freely
under the system as well as behind it. Leave several inches
of space around the computer to allow ventilation.
1-2
Setting Up Your System
Moderate environmental conditions. Protect your computer
from extremes in temperature, direct sunlight, or any other
source of heat. High humidity also hinders operation, so
select a cool, dry area. Avoid dust and smoke, which can
damage disks and disk drives and cause you to lose valuable
data.
Appropriate power sources. To prevent static charges,
connect all your equipment to three-prong, grounded
outlets. You need one outlet for the computer, one for the
monitor, and additional outlets for a printer and any other
peripherals.
If it has the appropriate power cord, you can plug the
monitor into the auxiliary power outlet on the back panel
of the computer, reducing the number of wall outlets you
need. (The current required by the peripheral must not
exceed 1 amp.) If you need more outlets, you may want to
buy a power strip-available at any electronics store-to
provide extra outlets. A power strip with surge suppression
is recommended.
No electromagnetic interference. Locate your system away
from any electrical device, such as a telephone, that
generates an electromagnetic field.
Setting Up Your System
1-3
3
Connecting a Monitor
The video display monitor is the device used by the computer
to communicate with you. Your software will use the screen to
display information, such as prompts, text, graphics (charts and
pictures), etc.
Several types of monitor are available as options. A typical
video display system provides a high resolution monochrome
(green or amber screen) screen display. Your computer can be
used with either monochrome, color video monitors, EGA or
VGA monitors.
In addition to the display monitor itself, the video system
includes a video controller board. This board generates the
letters, numbers, and graphics symbols displayed on the
monitor screen.
Connectors are provided for the display type that is supported
by the board (monochrome, RGB color, high resolution EGA,
VGA etc.). Certain boards support more than one type of
display, and may provide a switch to select either color or
monochrome modes.
The procedure you use to connect your monitor to the
computer depends on the type of monitor you have. See your
monitor manual for detailed instructions, or follow these
general guidelines:
1.
1-4
Place your monitor on top of or near the computer. It is
easiest to connect the monitor cable if you are facing the
back panels of both the monitor and the computer.
Setting Up Your System
2.
If necessary, connect the monitor cable to the monitor.
(Some monitors come with permanently attatched cables.)
3.
Connect the monitor cable to the video connector on the
back of the computer, as shown below. If the plug has
retaining screws, tighten them securely.
Figure 1-2. Connecting the Monitor
4.
Plug the other end of monitor’s power cord into an
electrical outlet.
Setting Up Your System
1-5
4
Connecting a Printer, Mouse, or Modem
The computer has a parallel interface and two serial interfaces
on the back panel, so you can easily connect a printer or other
type of device with either type of interface.
For example, you can use the parallel port to connect a parallel
printer (most printers have a parallel interface). You can use
the serial port to connect a serial printer, a serial mouse, or an
external modem.
Follow the steps in this section to connect a printer or other
peripheral device to either the parallel or serial interface.
Using the Parallel Interface
The parallel interface on your computer is Centronics
compatible and uses a 25-pin connector. To connect a parallel
printer to your computer, you need an IBM-compatible printer
cable. If you are not sure which one you need, or whether you
have the right one, check with the store where you purchased
the printer.
Once you have the correct printer cable, follow these steps to
connect the printer to the parallel interface on the computer.
1-6
1.
Place the printer next to your computer.
2.
One end of the printer cable has a 25-pin, male connector.
Connect this end to the parallel port on the back panel of
the computer, as shown below. If the plug has retaining
screws, tighten them securely.
Setting Up Your System
Figure l-3. Connecting the Printer
3.
Connect the other end of the cable to the printer, as
shown below. If the printer has retaining clips on each side
of the printer port, squeeze the clips together to secure the
cable.
4.
Plug the printer’s power cord into an electrical outlet.
Setting Up Your System
1-7
Using the Serial Interface
If you have a serial printer, modem, mouse, or any other
peripheral with a serial interface, you can connect it to one of
two serial (RS-232C) ports on the back of the computer. Your
computer uses IBM-compatible, 9-pin, male connector, so be
sure you have the proper cable. If you are not sure which one
you need, or whether you have the right one, check with the
store where you bought the cable.
To connect a serial device, follow the same steps outlined
above for a parallel device, but connect the cable to the serial
port, shown below.
Figure l-4. Serial Port
Setting up the serial port for a printer
If you are using a serial printer but your software does not
support a serial printer, you must do two things before you can
print:
1-8
Setting Up Your System
Set up the data transmission parameters for the serial port.
Tell the computer to redirect printer data from the parallel
port to the serial port.
5
Connecting the Power Cord
Follow these steps to connect the power cord:
1.
Insert the power cord into the AC inlet on the computer’s
back panel, as shown below. To avoid an electric shock, be
sure to plug the cord into the computer before plugging it
into the wall socket.
Figure l-5. AC Power Connections
2.
Plug the other end of the power cord into a three-prong,
grounded electrical outlet.
Setting Up Your System
1-9
Note
The socket outlet should be installed near the equipment
and should be easily accessible.
Die Verbindung zwischen Steckdose sollte mölichst Kurz
sein. Die steckdose sollte frei zugäglick sein.
For units to be installed in European countries, a power
supply cord of type HAR, with H05VV-F should be used.
Für Geräte, die in europäischen Ländern eingesetzt werden,
sollte ein Netzkabel Typ HAR mit der Nummer H05VV-F
benutzt werden.
6
Connecting the Keyboard
Your keyboard has only one cable to connect.
This simply plugs into the keyboard connector located at the
bottom of the main system unit’s rear panel. This connector is
designed to prevent insertion if the pins don’t line up, so it
may be necessary to rotate the cable connector until it plugs in
easily.
Figure l-6. Connecting the Keyboard
1-10
Setting Up Your System
Adjusting the Keyboard Angle
You can change the angle of the keyboard by adjusting the legs
on the bottom. Turn the keyboard over and lift each leg
upward until it locks into place, as shown below. You lock the
legs into a low or high position, or leave them flat.
Figure 1-7. Adjusting the Keyboard Angle
Setting Up Your System
1-11
7
Turning On the Computer
Before you turn on your computer, read the following safety
rules to avoid accidentally damaging the computer or injuring
yourself:
Do not unplug cables from the computer when the power
switch is on.
Never turn off or reset your computer while a disk drive
light is on. This can destroy data stored on disk or make an
entire disk unusable. Similary, never remove a diskette
from a diskette drive while the drive light is on.
Always wait at least five seconds after you switch off the
power before you switch it on again. Turning the power off
and on rapidly can damage the computer’s circuitry.
Do not leave a beverage on top of or next to your system
or any of its components. Spilled liquid can damage the
circuitry of your equipment.
Do not attempt to dismantle any part of the computer.
Only remove the cover to install and remove optional
devices.
Note
If you ever have to remove the main system unit cover,
observe the following precautions:
1-12
l
The power supply cord must be unplugged More- the
main system unit cover is removed (Separe le cordon
d’alimentation et puis enleve le couvercle.)
l
Once removed, the cover must be replaced and screwed
in position before the power supply cord is plugged back in,
(Apres le couvercle a enleve, visse le couvercle en place
et remettre le cordon d’alimentation,)
Setting Up Your System
Follow these steps to turn on your system:
1.
Turn on the monitor, printer, and any other peripheral
devices connected to the computer.
2.
To turn on the computer, press the power switch.
Figure l-8. Power Switch
Setting Up Your System
1-13
The power indicator on the front panel lights up. After a few
seconds, the computer starts to perform an internal self test.
This is a series of checks the computer completes each time
you turn it on to make sure everything is working correctly. If
anything is wrong, an error message appears on the screen.
After the self test is complete, you see a message on the screen
smiliar to this:
386-BIOS (c) 1989 American Megatrends Inc.
(c) 1989 TriGem Coporation
XXXX KB OK
press <ESC> to bypass MEMORY test
(c) American Megatrends Inc,.
XXXX-XXXX-XXXXXX-KB
The computer continually updates this display as it tests its
memory. This test takes about 15 seconds to complete.
You may see a message similar to this:
XCMOS Checksum Failure
CMOS battery low
CMOS system option not set
Run Setup Utility
Press <Fl> to RESUME
This means that the computer is not yet set up for the
equipment you have installed and you must run the Setup
program, described in Chapter 2. For now, press the Fl key on
1-14
Setting Up Your System
the upper left comer of the keyboard to acknowledge the
message and continue.
If you cannot see the screen display clearly, use the controls on
you monitor to adjust the brightness and contrast until
characters on the screen are clear and bright.
The computer then loads MS-DOS, the operating system, from
the hard disk into memory. MS-DOS must be in the
computer’s memory before you can run any program, such as a
word processing program or a spreadsheet program.
The Command Prompt
After the computer has loaded MS-DOS from the hard disk,
you see the MS-DOS command prompt on the screen:
The command prompt tells you that your computer is ready to
receive instructions. It also identifies the current operating
drive: A or C, for example. The command prompt appears on
the screen whenever you load MS-DOS, complete an MS-DOS
command, or exit an application.
In your computer, the diskette drive is A and the hard disk is
drive C. If you have an optional second diskette drive, MS-DOS
identifies it as B.
Setting Up Your System
1-15
8
Copying System Diskettes
Now that you have started your system and loaded MS-DOS, it
is important that you make copies of your MS-DOS diskettes
right away. Use the copies (called working copies) as they are
needed and store the originals in a safe place.
Each of the system diskettes is formatted for 360KB.
(Formatting prepares a diskette to store data and is described in
Chapter 3 and Chapter 5.)
To copy them, you need seven 360KB doubledensity, 5¼-inch
diskettes.
Note
If you do not have any 360KB diskettes, you can use
unformatted 1.2MB diskettes. When copying from 360KB
diskettes, the DISKCOPY program formats the 1.2MB
diskettes for 360KB.
Follow these steps:
1.
The C > prompt should be on the screen. If not, type C:
and press Enter.
2.
Type the following and press Enter:
DISKCOPY A: A:
The screen displays this message:
Insert SOURCE diskette in drive A:
Press any key to continue...
3.
1-16
Insert the MS-DOS diskette in drive A, as shown below.
Hold the diskette with the label facing up and the
read/write slot into the drive.
Setting Up Your System
Figure l-9. Inserting a Floppy Disk
4.
Press any key. The DISKCOPY program copies the
contents of the MS-DOS diskette to the computer’s
memory, and then you see the following:
Insert TARGET diskette in drive A:
Press any key to continue. . .
Setting Up Your System
1-17
5.
Remove the MS-DOS diskette and insert a blank diskette
(which is to be the target diskette) in drive A. Then press
any key.
If the diskette is not formatted, the DISKCOPY program
formats it. Then the program begins copying the data from
the computer’s memory to the formatted diskette. When
the copy is complete, you see this prompt:
6.
Press Y so you can make a copy of another MS-DOS diskette.
Again, you see the prompt to insert the source diskette.
7.
Remove the copy of the MS-DOS diskette which you just
made and insert the another MS-DOS diskette into drive A.
Then press any key. Follow the prompts on the screen to
make a copy off this diskette as you did for the first MS-DOS
diskette.
8.
When you finish copying the last diskette and the
prompt appears, press N to return to the MS-DOS
command prompt C >.
After you have copied the MS-DOS diskettes, be sure to label
them carefully so you know which one is which. Write on the
labels before you attach them to the diskettes in order to
prevent damaging the diskettes. Store the originals in a safe
place and use the copies as they needed.
1-18
Setting Up Your System
9
Resetting Your Computer
If your computer system should “lock-up”, it may be necessary
to reset the computer. Resetting the computer causes the CPU
to clear its instruction set and the system memory. This ensures
there is no “garbage” left in memory to interfere with new
program information.
There are two basic ways to reset your computer. They are:
CONTROL-ALT-DEL (Keyboard Reset)
Press the CONTROL key and the ALT key at the same
time. While holding these keys down, press the DELETE
key, then release all three keys. This will reset your
computer without running the full self-test diagnostics.
The POWER Switch
Turn the main system POWER switch off, wait ten
seconds, then turn it back on. The computer will then run
the complete self-test diagonistic routine.
Caution!
Any time you RESET your computer, the memory will be
cleared. This will erase any software programs loaded into
the system RAM. You may lose important data or have
problems using your &are after the system re-boots.
Only RESET your system if you are sure that all of your
data has been saved to disk, or there is no other way to
escape a “lockup” condition.
You should now be able to reset your computer if you run into
trouble. At this point, you can complete the installation of
your system by running the SETUP program. For detailed
information on the SETUP program, see the following chapter.
Setting Up Your System
1-19
Chapter 2
Running the Setup Program
The first time you use your computer after setting up, you need
to run the Setup program. The Setup program lets you update
the following for your computer.
The internal clock’s time and date
The number and capacity of diskette drives
The number and type of fixed disks
Availability and type of primary video adapter
Availability of keyboard
The type of scratch RAM
The setup program should be run when any of the preceding
parameters has changed due to a system configuration change.
You probably do not need to change all these
change the ones that apply to your computer.
you have added no extra equipment and have
monitor, you would use the Setup program to
clock’s time and date.
settings; just
For example, if
a color graphics
set the internal
Your computer stores the information you enter with the Setup
program in a special memory area, called CMOS RAM, which
is backed up by a battery. When you turn the computer off, the
computer stores the Setup information in this memory. When
you turn the computer on, it searches the CMOS RAM to
obtain the correct configuration information. If there is a
Running the Setup Program
2-1
difference between the information in CMOS RAM and the
actual configuration, you see a prompt to run the Setup
program.
Whenever a configuration change has been made to the system
and power subsequently applied, the BIOS (Basic Input/Output
System) will generally generate the invalid configuration
message. Pressing Fl after an invalid configuration message is
displayed will cause the system to boot up with a minimum
default system. This will result in the system not being able to
operate with its full potential.
If POST detects an error, you are prompted “Press <Fl> to
RESUME”
The setup program performs the following operations:
Displays date, time, and the screen the list current values
for system options.
Allows you to accept current (default) values or enter
different values for time, date, and system options.
Provides help information about each of the options.
Provides instructions on re-booting the system so that the
new setting can take effect.
Whenever the system is booted, POST always rechecks the
stored setup information against the hardware configuration.
If the data does not agree, the invalid configuration message
will be displayed.
2-2
Running the Setup Program
Running Setup
If your system is off, turn it on now. After a moment, you will
see a message similar to this:
386-BIOS (c) 1989 American Megatrends Inc.
(c) 1989 TriGem Coporation
XXXX
KB
OK
Press <ESC> to bypass MEMORY test
(c) American Megatrends Inc,.
XXXX-XXXX-XXXXXX-KB
Identifying the type of BIOS
Please note the Reference number at the bottom of the screen.
Make a note of this number before you call Customer Support
at AMI for assistance with the BIOS. The Reference number
in your BIOS will let you know the type of BIOS on your
system. The Reference number is displayed in the following
format:
ABBB-NNNN-MMDDYY-KX
Where
A could be
= D for BIOS with Diagnostics
= S for BIOS with Setup program
= E for BIOS with Extended Setup program
BBB could be = C&T for C&T 386 chipset
= NET for C&T NEAT chipset
= 286 for standard 286, VLSI, G2 286 boards
= SUN for suntac 286 boards
Running the Setup Program
2-3
= PAQ for Compaq compatible 386 board
= INT for Intel compatible 386 board
= AMI for AMI 386 motherboard
= G23 for G2 386 board
MMDDYY
is the BIOS release date in Month/Day/Year
format
KX
is the AMI Keyboard BIOS version number
Memory Test Bypass
The BIOS performs diagonostics of the system and displays the
size of the memory being tested.
Note
Note that you can bypass the memory test by pressing the
<ESC> key. This option would be useful when the
memory on the system is quite large. you should hit the
<ESC> key when the following message appears on the
screen.
Press <ESC> to bypass MEMORY test
Using Setup
Immediately after the memory test, you will get the following
prompt on the screen depending upon the type of BIOS you
have:
2-4
Running the Setup Program
Hit < DEL > key to get into the Setup mode
Note
<DEL > key will get you into the setup mode, only when
the above message is displayed on the screen.
If you hit < DEL > key, a menu appears on the screen giving
you the option of
EXIT FOR BOOT
RUN CMOS SETUP
RUN XCMOS SETUP
Use < Up > and <Down
> keys to set the reverse video
cursor on the option you want to select and use < Enter > to
get into the option.
Errors Reported by BIOS
You may also see the error prompts in the first screen if your
system has detected errors while comparing the configuration
settings on the system main board with the parameters stored
in its internal configuration RAM. In this case, you will see a
message similar to this:
XCMOS Checksum Failure
CMOS battery low
CMOS system option not set
Run Setup Utility
Press <Fl> to RESUME
Press <Fl> to ignore the error prompt and boot the system
automatically.
Running the Setup Program
2-5
Note
If your system’s start-up message does not show any errors
and proceeds to try to load software from the floppy disk
drive, you see the following message:
Entering SETUP
To enter the setup program, hit < DEL > key at the time the
following prompt is displayed on the screen immediately after
the memory test.
Press <DEL> if you want to run SETUP/EXTD-SET
If you hit <DEL> key, you will see a menu like as following
EXIT FOR BOOT
RUN CMOS SETUP
RUN XCMOS SETUP
This means that the SETUP program options have been set at
the factory. Since there were no errors detected, the computer
tried to load MS-DOS from the floppy disk drive, before you
have inserted the MS-DOS main system diskette. For now
ignore this message.
2-6
Running the Setup Program
CMOS SETUP
Set the reverse video cursor on the “RUN CMOS SETUP”
using <Up ↑ > and < Down ↓ > and press < ENTER >.
Then the screen will be replaced by the following.
This screen is the SETUP MENU. This lists the parameters
you can change with the SETUP program. A solid cursor bar
highlights the parameter currently available to be changed. You
can use the following key conventions.
< Enter > . . . . . . . . . . . . . . . moves the selection bar
< ← > < → > . . . . . . . . . . . moves the selection bar
< PgUp > < PgDn >. . . . . . . scrolls allowable settings
< E S C > . . . . . . . . . . . . . . . . exit and save CMOS
register
< Ctrl > < Alt > < Del > . . . exit without save
Running the Setup Program
2-7
CMOS Setup Option
Note
The Setup option is available even after a soft reset.
Date and Time Setup
The first entry in the Setup screen is current date.
A calendar has been provided for the user to facilitate him in
this procedure. Again, simply press the < PgUp > or
< PgDn > keys to select the appropriate value for the month,
date and year.
The procedure for setting the time is similar to that of setting
the date. The time here is 24-hour time so don’t be alarmed
when hour 13 shows up on the screen. Simply highlight either
the hours, minutes, or the seconds and press the <PgUp> I
< PgDn > keys to step through the numbers.
Floppy Disk Drive Setup
Drives a: and / or b: may be one of the following types:
Allowable Drive Types
360KB
1.2MB
720KB
1.44KB
not installed
5 ¼"
5 ¼"
3 ½"
3 ½"
Hard Disk Drive Setup
Drives c: and d: are the hard disk drives in the system. 46 drive
types have been defined by AMI. If for some reason or other
your particular drive is not one of the 46 pre-defined types,
2-8
Running the Setup Program
simply scroll down to type 47 and enter the following drive
specifications: cylinders, heads, WPcom, LZone, and sectors.
Please consult the documentation received with the drive for
the specific values that will give you optimum performance.
Display Type Setup
The next option is primary display selection. The options are
as follows:
Type of Display Allowed
Monochrome
Color 40 x 25
Color 80 x 25
VGA or EGA
Not Installed
Keyboard Setup
The keyboard Setup is the next option for the user. You may
either choose to enable or disable the Keyboard test during
Power On Self Test by setting keyboard as “Installed” or “Not
Installed”.
Scratch RAM Option
The next option is the setting of the scratch RAM. The
purpose of this element is to
(1) Save the user definable drive type 47
(2) Translate 80386 Loadall function for programs like
OS/2, RAMDRIVE etc.
If Shadow RAM is not enabled, the parameters of the drive
must be stored in normal RAM, but the integrity of the data
must be maintained. The options you have are the following:
Running the Setup Program
2-9
1. The BIOS to use 100 bytes at 30h:O
2. The BIOS to reduce the size of the base memory by 1KB.
The default is 1. If you are not using Drive type 47 or not
running programs like OS/2, RAMDRIVE this RAM will
never be used by so you may leave the value as 1.
Leaving the CMOS Setup
When you have completed the changes, press the < ESC >
key. The SETUP program will display the message:
Write data into CMOS and exit (Y/N)?
If you have made any mistakes, press N for No, then move the
cursor back up to the beginning and verify each parameter,
making any corrections necessary. When you are satisfied with
the option settings, press the < ESC > key, then press Y to
write the new settings into the configuration RAM. Your
computer will run through the self test diagnostics again and
try to read a diskette in the first floppy disk drive.
As mentioned above, you may see an error message if you don’t
have a system diskette inserted into the floppy disk drive.
Extended CMOS SETUP
The Extended CMOS Setup program can be used to program
the Chipset Extended CMOS with user defined values which
will be used by the BIOS to program the Chipset registers
during system boot up.
To enter the Extended CMOS SETUP program, set the reverse
video cursor on the “RUN XCMOS SETUP” using Up and
Down arrow key and press < ENTER> on the following
message.
2-10
Running the Setup Program
RUN CMOS SETUP
RUN XCMOS SETUP
The screen will be replaced by the following.
This is Extended CMOS Setup Menu screen. Extended CMOS
Setup lets you select additional features of system for better
performances.
RAM/CACHE/BUS CONTROLLER SETUP
You may select the option “RAM/CACHE/BUS
CONTROLLER SETUP” by pressing < Enter > on the screen
like above, then the next screen will appear like below.
Running the Setup Program
2-11
This screen is the system performance setup. This lists the
parameters you can change with Extended Setup program. A
solid cursor bar highlights the parameters currently available to
be changed. You can use the following key conventions.
←↑→↓
< PgUp/PgDn >
<Esc>
: Moves the selection bar
: Scrolls available settings
: Exit to Main Menu
Start-up Speed
This parameter lets you select the speed of the system at boot
time. After boot, you may change the system speed through
keyboard or BIOS service INT 15H call.
2-12
Running the Setup Program
Cache
If the Cache Memory option is not what you want, use the
< PgUp > or < PgDn > key to change the option value. The
options are:
Enabled : The memory cache is enabled. This is the
recommended option. You can operate your
work more rapidly and efficiently with this
system using cache memory.
Disabled : The memory cache is disabled. This is the lowerperformance option. You should select it only if
your programs have difficulty running with the
cache enabled.
System BIOS Shadow
System BIOS Shadow Option copies BIOS from ROM to
RAM. By enabling this option, BIOS service will be accessed
from RAM which is faster than accessing from ROM.
Video BIOS Shadow
Video BIOS shadow option copies video BIOS from ROM to
RAM. By enabling this option Video BIOS services will be
accessed from RAM which is faster than accessing from ROM.
Remap 256K RAM
Remap 256K RAM option copies 256K from ROM to RAM.
You can use Extended memory more sufficiently by enabling
this option.
Running the Setup Program
2-13
MULTI I/O CONTROLLER SETUP
Set the reverse video cursor on the “MULTI I/O
CONTROLLER SETUP” of the Extended SETUP Main
menu using Up and Down arrow key and press < ENTER > .
The screen will be replaced by the following.
This screen is the system communication setup. This lists the
parameters you can change with EXTENDED SETUP program.
A solid cursor bar highlights the parameters currently available
to be changed.
2-14
Running the Setup Program
Serial Port #1
If you’d like to the on board serial port 1 for COM l, set this
option “COM l”.
But, when you install the external card to use another serial
port, you should select “Disable” on this option to disable the
on board serial port.
Serial Port #2
Set this parameter to “COM2” when you use serial port #2 for
“COM2”. You should also disable this option when you install
the external card to use another serial port for COM2.
Parallel Port
If you use on board parallel port, select LPTl for this
parameter. However if you want to use another parallel port
using external I/O card, you should disable this option.
Hard Disk Controller
The system has on board IDE type HDC. If you’d like to
another type of HDC (for example, SCSI, or ESDI etc.),
disable this option and install your HDC Card to the
expansion slot.
Running the Setup Program
2-15
Leaving the Extended CMOS Setup
When you’d like to exit the Extended CMOS setup program,
you can select one of two exit methods.
If you have completed the changes and made sure the current
settings, set the reverse video cursor on “WRITE CMOS
REGISTERS AND EXIT” exist on the Extended Setup Main
menu and press < Enter >. But in any case, when you don’t
want to accept the changes, select “DO NOT WRITE CMOS
REGISTER AND EXIT” on the Main menu.
After you exit the Extended setup program, you may see the
following message.
Then, your computer will run through the self test diagnostics
again and try to read a diskette in the first floppy disk drive.
2-16
Running the Setup Program
Chapter 3
Using Your Computer
This chapter covers the following basic procedure for using
your computer:
Changing the operating speed
Using special keys on the keyboard
Stopping a command or program
Using disks and disk drives.
Changing the Operating Speed
Your computer can operate two speeds: if you have TriGem
386X, the system can operate 25MHz or 8MHz, and if your
system is TriGem 386XE, it can operate 33MHz or 8MHz.
At 25MHz or 33MHz, the computer performs all tasks faster,
and almost all programs may be run at 25MHz or 33MHz.
However, some option cards and application programs require
the lower speed. See your option card or application program
manual to make sure that you can use the higher speed before
selecting it.
Keyboard Method
The following keystroke sequences can be used to set the
processor clock speed.
l
Ctrl-Alt- < - >
Hold down the <Ctrl> and <Alt>
keys and press < - > on the numeric
keypad to place the system in low speed
mode.
Using Your Computer 3-1
l
Ctrl-Alt- < + >
Hold down the < Ctrl > and < Alt >
keys and press < + > on the numeric
keypad to place the system in high
speed mode.
Changing the operating speed may be performed with the
TriGem Utility TGSS.COM. This program is located on the
MS-DOS diskette supplied with the system. You can find the
detailed description of TGSS.COM in your MS-DOS User’s
Guide.
Special Keys on your Keyboard
Certain keys on your keyboard serve special functions when
your computer is running programs. The illustration below
shows the TriGem keyboard, and the table that follows
describes the special keys.
Figure 3-1. Keyboard (101 key)
3-2
Using Your Computer
Key
Purpose
F1-F12
Perform special functions within application program
(Some keys also function with MS-DOS. See your
MS-DOS Reference Manual for more information.)
Tab
Moves the cursor one table to the right in normal
mode (and one tab the left in shift mode when using
some application programs.)
Ctrl
Works with other key to perform special (control)
function, such as editing operations.
Shift
Produces uppercase characters or the top symbols
on the keys when used with the main character keys.
Produces lowercase characters when Caps Lock is
on.
Alt
Works with other keys to enter alternate character
codes or functions.
Backspace
Moves the cursor back one space, deleting the
character to the left of the cursor
Enter
Ends a line of keyboard input or executes a
command (may be called the Return key In some
application program manuals).
Caps Lock
Changes the letter keys from lower-to uppercase;
changes back to lowercase when pressed again.
The numeric/symbol keys on the top row of the
keyboard are not affected.
Esc
Cancels the current command line or operation in
MS-DOS. Esc can also have special uses in
application programs.
Num Lock
Changes the function of the keys on the
numeric/cursor keypad from numeric entry to cursor
positioning; changes back when pressed again.
Scroll Lock
Controls scrolling in some application programs.
Break
When pressed with the Ctrl key (hold down Ctrl and
press Break), sends a break signal to the computer
to terminate the current operation.
Using Your Computer 3-3
Key
Purpose
Sys Req
Produces the system request function in certain
applications.
PrtSc
Prints the screen display on a dot-matrix printer
Home, End,
PgUp, PgDn
←↑→↓
Control cursor location in some applications, such as
word processors, game programs, and
spreadsheets.
Ins
Turns the insert function on and off in some
application programs.
Del
Deletes the character at the cursor position
The Num Lock, Scroll Lock, and Caps Lock keys work as
toggles; press the key once to turn on a function and again to
turn it off. When the function is enabled, the corresponding
light on the top right comer of the keyboard is on. When the
function is disabled, the light is off.
Figure 3-2. Keyboard LED
3-4
Using Your Computer
Stopping a Command or Program
You may sometimes need to stop a command or program while
it is running. Many application programs provide a command
you can use to stop or even cancel (undo) an operation. If you
have entered an MS-DOS command that you want to stop, try
one of the following commands:
Hold down the Ctrl key and press C
Hold down the Ctrl key and press Break
These methods may also work in your application program.
If you cannot stop a particular operation, however, you may
need to reset the computer, as described in the following
section.
Caution
It is best not to run off the computer to stop a program or
command. If you have created new data that you have not
yet stored, it will be erased if you turn off the computer.
Your computer stores data in its memory until you save it;
but the memory area is erased each time you turn off or
reset the computer.
Using Disks and Disk Drives
The disk drives in your computer allow you to store data on
disk and retrieve it when you want it.
This section explains how disks work and tells you how to do
the following:
Choose diskettes
Using Your Computer 3-5
Care for your diskettes and diskette drives
Insert and remove diskettes
Write-protect diskettes
Make backup copies of your diskettes
Use a single diskette drive
Use a hard disk drive
How Disks Store Data
The diskette you insert in your computer’s diskette drive is
made of flexible plastic, coated with magnetic material. It is
enclosed in a square jacket. Your computer stores data on the
diskette by recording on the magnetic surface.
Unlike a diskette, a hard disk is rigid and fixed in place. It is
sealed in a protective case to keep it free from dust and dirt. A
hard disk stores data the same way that a diskette does, but it
works faster and has much larger storage capacity.
All disks are divided into data storage compartments by sides,
tracks, and sectors. Double-sided diskettes — like the ones you
use in your computer — store data on both sides. On your disk
there are concentric rings, called tracks, in which a disk can
store data. Double-density diskettes (such as 360KB diskettes)
have 40 tracks, and highdensity diskettes (such as 1.2MB or
1.44MB diskettes) have 80 tracks. But 720KB double density
diskette has 80 tracks.
A hard disk consists of two or more magnetically-coated
platters stacked on top of one another, so it has four or more
sides with many more tracks than a diskette.
3-6
Using Your Computer
A disk is further divided by sectors. To understand what a
sector is, picture the spokes on a bicycle wheel radiating from
the center of the wheel to the tire. The space between one
spoke and the next is like a sector on a diskette. (See the figure
below.) Each track on a 1.2MB diskette has 15 sectors, and
each sector holds 512 bytes.
Figure 3-3. Sectors and Tracks
Your computer uses the read/write heads in a disk drive to store
and retrieve data on a disk. There is one head above the
diskette and one below, so the drive can write to both sides of
the diskette. To write to a disk, the computer spins it in the
drive to a position where one of the read/write heads can access
the diskette through the read/write slot. The read/write slot on
a diskette exposes the diskette’s magnetic surface so the
read/write head can write on the appropriate area.
Because data is stored magnetically, you can retrieve it, record
over it, and erase it — just as you play, record, and erase music
on a cassette tape.
Using Your Computer
3-7
Types of Diskette Drives
You computer has at least one 1.2MB diskette drive. With this
drive, use 5¼-inch, double-sided, high-density, 96 TPI, 1.2MB
diskettes. These diskettes contain 80 tracks per side, 15 sectors
per track, and hold up to 1.2MB of information, which is
approximately 500 pages of text. You can also format these
diskettes for 360KB — see your MS-DOS Reference Manual for
more information.
In addition, you may have a diskette drive of a different type.
The following list describes the types of optional diskette drives
you can use in your computer and which diskettes you should
use with them:
360KB drive — With this drive, use 5¼-inch, doublesided, doubledensity, 48 TPI (tracks per inch), 360KB
diskettes. (You can also use single-sided, 160KB or 180KB
diskettes). These diskettes contain 40 tracks per side, 8 or 9
sectors per track, and hold up to 360KB of information,
which is approximately 150 pages of text. (With 8 sectors
per track, a diskette holds up to 360KB.)
720KB drive — With this drive, use 3½-inch, doublesided, double-density, 135 TPI, 720KB diskettes. These
diskettes contain 80 tracks per side, 9 sectors per track, and
hold up to 720KB of information - approximately 300
pages of text.
1.44MB drive — With this drive, use 3½-inch, doublesided, high-density, 135 TPI, 1.44MB diskettes. These
diskettes contain 80 tracks, per side, 18 sectors per track,
and hold up to 1.44MB of information, which is
approximately 600 pages of text.
If your computer has more than one type of these drives or if
you use diskettes from other computers, you need to be aware
of certain incompatibilities between the drives and the
diskettes they use.
3-8
Using Your Computer
Note
You must format new diskettes before you can use them
with an operating system. Formatting erases all the data on
a diskette and prepares it to receive new data, so be sure to
format only new blank diskettes or diskettes that contain
data you want to erase. See Chapter 5 for instructions on
formatting diskettes.
Drive and diskette incompatibilities
Because of the size difference, you cannot use 3½-inch
diskettes in a 5¼-inch drive or vice versa. There are also
certain limitations on using diskettes that are the same size as
the drive but have different capacities. The following tables
summarize the possiblities and limitations.
5¼-inch drive/diskette compatibility
Drive type
Diskette types it can read from and write to
360KB
1.2MB
180KB, or 360KB
180KB, 360KB. or 1.2MB
3½-inch drive/diskette compatibility
Drive type
Diskette types it can read from and write to
720KB
1.44MB
720KB
720KB, or 1.44MB
Warning
If you write to a 360KB (or 180KB) diskette while it is in a
1.2MB drive, you may not be able to read it or write to it
in a 360KB drive later.
Using Your Computer 3-9
Because of these incompatibilities, you should indicate the
density and diskette type when you label your diskettes.
(Usually this information appears on the manufacturer’s label.)
If you have any combination of the above drives (360KB,
1.2MB, 720KB, or 1.44MB), you can copy files from one drive
to another - using the COPY or XCOPY command - as long
as the correct diskette type is in each drive. You can use these
commands to copy files between the hard disk and any type of
diskette. You cannot use the DISKCOPY to copy from one
drive to another if the two drives are not the same type.
Caring for Diskettes and Diskette Drives
Follow these basic precautions to protect your diskette and
avoid losing data:
Do not remove a diskette from the diskette drive or turn
off the computer while the drive light is on. This light
indicates that the computer is copying data to or from a
diskette. If you interrupt this process, you can destroy data.
Remove all diskettes before you turn off the computer.
Keep diskettes away from dust and dirt. Small particles of
dust or dirt can scratch the magnetic surface and destroy
data. Dust can also ruin the read/write heads in a diskette
drive.
Never wipe, brush, or try to clean diskettes in any way.
Keep diskettes in a moderate environment. They work best
at normal room temperature and in normal humidity. Do
not leave your diskettes sitting in the sun, or in extreme
cold or heat.
3-10 Using Your Computer
Keep diskettes away from magnetic fields. (Remember that
diskettes store information magnetically.) There are many
sources of magnetism in your home or office, such as
electrical appliances, telephones, and loudspeakers.
DO not place diskettes on top of your monitor or near an
external disk drive.
Never touch a diskette’s magnetic surface. The oils on your
fingertips can damage it. Always hold a diskette by its
protective jacket. If you are using a 3½-inch diskette, do
not slide the metal shutter; this exposes the diskette’s
surface.
Do not place anything on top of your diskettes and be sure
they do not get bent. A diskette does not rotate properly in
the drive if it has been damaged.
Carefully label your diskettes. Attach labels firmly but
gently, and only along the top of a diskette (next to the
manufacturer’s label). Do not stick several labels on top of
one another-too many labels can make it difficult to insert
the diskette into the drive.
It is best to write on the label before you attach it to the
diskette. If you need to write on a label that is already on a
diskette, use only a soft-tip pen, not a ballpoint pen or a
pencil. Always indicate the storage capacity and density
type on the label.
Store diskettes in a proper location, such as a diskette
container. Do not store diskettes flat or stack them on top
of each other. When you are not using them, keep your
diskettes in their protective envelopes.
Follow these additional precautions to protect your hard disk
drive and its data:
Using Your Computer
3-11
Never turn off the computer when the hard disk drive light
is on. This light indicates that the computer is copying
data to or from the hard disk. If you interrupt this process,.
you can lose data.
Never attempt to open the hard disk drive. The disk itself
is enclosed in a sealed container to protect it from dust.
Inserting and Removing Diskettes
To insert a diskette into the drive, hold it with the label facing
up and the read/write slot leading into the drive, as shown
below.
Figure 3-4. Inserting a Diskette (5¼”)
Slide the diskette into the slot until it is all the way in. Then
turn the drive latch down to lock it in a vertical position. This
keeps the diskette in place and enables the read/write heads in
the diskette drive to access the diskette.
3-12
Using Your Computer
If a diskette is in the drive but the latch is up (horizontal) and
you enter a command for that drive, the computer cannot tell
there is a diskette in the drive and displays an error message
such as:
Not ready error reading drive A
Abort, Retry, Fail?
Close the latch and press R.
To remove the diskette, turn the drive latch up until it is
horizontal and the edge of the diskette pops out. Carefully pull
out the diskette, place it in its protective envelope, and store it
in a proper location, such as a diskette container.
If you have an optional 3½-inch diskette drive, insert the
diskette with the label facing up and the metal shutter leading
into the drive, as shown below. Slide the diskette into the
drive until it clicks into place.
Figure 3-5. Inserting a Diskette (3½”)
Using Your Computer
3-13
To remove a 3½-inch diskette, press the release button to
release it. When the edge pops out of the drive, pull out the
diskette and store it properly.
Warning
Never remove a diskette or turn off the computer while the
drive indicator light is on. You could lose data. Also, be
sure to remove all diskettes before you turn off the
computer.
Write-protecting Diskettes
You can write-protect a diskette to prevent its data from being
altered. When a diskette is write-protected, you can read it and
copy data from it, but you cannot store new data on the
diskette or delete any files it contains. If you try to change data
stored on a write-protected diskette, MS-DOS displays an error
message.
To write-protect a 5¼-inch diskette, cover the small,
rectangular notch (shown below) with an adhesive write-protect
tab. Write-protect tabs usually come with new 5¼-inch
diskettes when you buy them.
Write Protect
Figure 3-6. 5¼” Diskettes & Write-Protect Tab
3-14
Using Your Computer
Note
Some program diskettes, such as your MS-DOS diskettes,
have no notch so they are permanently write-protected.
This protects them from being accidentally erased or
altered.
On a 3½-inch diskette, the write-protect device is a small
switch on the lower-right comer on the back, shown below. To
write-protect a 3½-inch diskette, slide the switch toward the
edge of the diskette until it clicks into position, exposing a hole
in the comer.
Write Protect
Figure 3-7. 3½” Diskette & Write-Protect SW
To remove the write protection, slide the switch toward the
center of the diskette so the hole is covered.
Making Backup Copies
It is important to make copies of all your data and system
diskettes. Copy all diskettes that contain programs, such as the
original MS-DOS diskettes that come with your computer, and
use only the copies. Store your original MS-DOS diskettes in a
safe place away from your working copies. Backup your data
diskettes regularly, whenever you revise them, to keep them
up-todate, and store them away from your originals.
Using Your Computer 3-15
Chapter 1 describes how to use DISKCOPY to copy your
MS-DOS diskette. For more detailed information to make
backups of other diskettes, refer to Chapter 4 “Using MS-DOS
with your computer”.
It is best to put most of the programs and data files you use
regularly on the hard disk. Keep backup copies of all your
program files on diskettes, however, and regularly copy
important data files to diskettes as well.
Using a Single Diskette Drive
The operating system expects the computer to have at least
two diskette drives, and it displays prompts and messages
accordingly. If the computer has only one diskette drive, MS-DOS
treats the one drive like two logical drives. This helps you
perform operations that normally require two diskette drives.
Usually, MS-DOS recognizes the first diskette drive (the top
drive) as drive A and the second diskette drive as drive B.
If you have only one diskette drive, MS-DOS recognizes it as
both A and B.
For example, if you give a command to copy from A to B,
MS-DOS copies data from the diskette you place in the single
drive (A) to the computer’s memory. Then MS-DOS
automatically prompts you to insert another diskette in the
same drive, which it now identifies as drive B. It copies the
data from memory to the new diskette. When the copying is
complete, MS-DOS identifies the drive as drive A again, and
you see a prompt to insert the original diskette into drive A.
You can load the operating system and application programs
from the hard disk, create and store your data there, and use
the diskette drive just for copying data to and from diskettes.
3-16
Using Your Computer
Note
If you only have one diskette drive and no hard disk, you
need to use that drive to load the operating system as well
as the application programs you are using. First load the
operating system; this copies it into the computer’s memory
(RAM) so you do not need to leave the diskette in the drive.
Then you can remove that diskette and insert the program
diskette you want to use, and load that into memory too.
See your application program manual for detailed
instruct ions.
Using the Hard Disk Drive
You can create and revise files on a hard disk just as you can
on a diskette. The hard disk, however, provides several
advantages:
The 20MB hard disk can store more data than 16x1.2MB
diskettes and the 40MB hard disk can store twice as much.
Your computer can perform all disk-related operations faster.
You can store all your frequency used programs and data
files on the hard disk, eliminating the inconvenience of
inserting and removing diskettes to access different files.
The added storage capacity makes it easy to move back and
forth between different programs and data files. However,
because it is so easy to add programs and files to your hard disk,
you may find yourself trying to organize hundreds of files.
MS-DOS lets you keep related files together in directories and
subdirectories so they are easier to find and use.
Using Your Computer
3-17
Backing up hard disk files
While the hard disk is very reliable, it is essential to back up
your hard disk files to diskettes in case you lose some data
accidentally. Make copies of all your system and application
program diskettes before copying the programs to the hard disk.
After you create data files on the hard disk, be sure to copy
them to diskettes whenever you revise them to keep your
backup diskettes up-to-date.
You can see the more detailed information of backing up hard
disk files on the Chapter 6.
Preparing the hard disk for moving
Before you move the computer, you need to secure the
read/write heads inside the hard disk drive. Securing the
read/write heads moves them to a region of the disk surface
that does not contain data, and locks them in position. This
prevents the disk from being damaged if it is bumped
accidentally.
To secure the read/write heads for moving, run the TGSHIP
program.
Follow these steps to run TGSHIP:
1. Exit any program you are using so the MS-DOS command
prompt is on the screen.
2.
Insert the MS-DOS diskette in drive A.
3.
Type the following and press Enter:
A:TGSHIP
3-18
Using Your Computer
You see a message on the screen that tells you the disk drive’s
read/write heads will remain locked until you reset the
computer or turn the power off and on again. The computer
locks the heads and disables the keyboard. You can now turn
off the computer and prepare to move it to the new location.
The TGSHIP command should be run whenever you are going
to move the main system unit. This command moves the
read/write heads inside the hard disk drive to a “safety zone,”
where they won’t accidentally scratch the surface of the drive
platters. TGSHIP.COM is a special DOS command file
included with your system. You should copy this file into the
root directory of your hard disk drive.
See MS-DOS reference manual for more information of
TGSHIP command.
Using Your Computer
3-19
Chapter 4
Using MS-DOS With Your Computer
Once you have your computer system “up-and-running,” you
may begin to work with MS-DOS.
Virtually all application software available for IBM PC/XT and
PC/AT-compatible computer systems runs “under” MS-DOS.
Therefore, in order to use these programs, you need to learn
how to use MS-DOS. This chapter will give you a basic
understanding of MS-DOS and provide you with the basic
tools you need run application software on your computer
system. For more detailed explanation of the MS-DOS
operating system, see your MS-DOS USER’S GUIDE.
MS-DOS is an acronym for Microsoft Disk Operating System.
The disk operating system is a collection of programs that allow
you to control all the elements of your computer. When
booting up, the MS-DOS command file is copied from the MSDOS main disk into your computer’s memory. From there, it
controls the rest of the system.
During a normal operating session, you will want your
computer system to boot up in MS-DOS. Before that can
happen, however, you may need to install MS-DOS on your
system.
If your system does not have a hard disk system, you must
perform the installation routine to configure MS-DOS for
floppy disk-based operation.
If you do have a hard disk drive, but MS-DOS has not been
installed you must perform the installation routine to configure
MS-DOS for use on the hard disk system.
Using MS-DOS With Your Computer
4-1
For complete instructions on installing MS-DOS, see your
MS-DOS User’s manual.
Inserting Diskettes
Your MS-DOS software package contains of the following
items:
One MS-DOS Install Diskettes
One MS-DOS Select Diskette
Three MS-DOS Operating Diskettes
One MS-DOS Shell Diskette
The MS-DOS User’s Guide & User’s Reference
The MS-DOS Shell User’s Guide
Begin the installation procedure by placing the MS-DOS
Install diskette in the A drive and turning your computer on.
Disk Drive Letters
The various disk drives on your computer are assigned letters.
As you work with MS-DOS, you will see that these letters are
used to identify which drive is to be used at any given time.
The microcomputer industry has standardized the use of letter
identification for MS-DOS-type machines as follows:
The first floppy disk drive is referred to as the “A:” drive.
The second floppy disk drive is referred to as the “B:”
drive.
4-2
Using MS-DOS With Your Computer
The first hard disk drive is referred to as the “C:” drive.
Note
For information on reassigning disk drive letters, refer to
sections regarding the ASSIGN command in your MS-DOS
USERS GUIDE.
To insert a diskette into the drive:
Open the drive door.
If you haven’t already done so, remove the protective
cardboard insert from the drive.
Gently insert the diskette into the drive entry slot with its
label facing up, and the write protect notch to the left.
When the diskette is all the way in, close the drive door by
turning the door latch handle down.
Caution!
If any resistance is felt when closing the drive door, stop
and reinsert the diskette.
To remove a diskette from a floppy disk drive:
Be sure the drive indicator light is off
Caution!
It is very important that you never remove a diskette from
an active drive. Doing so can destroy the information on
the diskette. If the computer system is “locked-up” with
the drive indicator light on, RESET the computer before
removing the diskette.
Using MS-DOS with Your Computer
4-3
Turn the door latch to open the drive.
Remove the diskette and insert it into its protective
envelope.
Starting MS-DOS
To start MS-DOS 4.01 on a floppy disk-based system (that is,
on without a hard disk drive), follow these steps given below.
For a detailed description of how to start MS-DOS 4.01,
consult the Getting Started section in your MS-DOS 4.01
User’s Guide.
Remove the MS-DOS Install diskette from its protective
envelope and insert it into the A drive.
Close the disk door and turn your computer on.
Remove the Install disk and insert the Select disk.
Press ENTER.
Remove the Select disk and insert the Install disk.
Press ENTER.
The Welcome screen appears. This screen contains information
about the number of disks required to install the operating
system.
Press ENTER
The Introduction screen appears. This screen contains
information about the function keys used to run the Select
program.
4-4
Using MS-DOS With Your Computer
Press ENTER
The first screen of the Select program appears. For more
information about the Select program, consult the Getting
Started section in your MS-DOS 4.01 User’s Guide.
If your computer has a hard disk drive, and MS-DOS has been
installed, simply turn your system on. Your computer will
perform its self-test diagnostics and display the DOS Shell
menu screen.
Notice that the words “Command Prompt” are highlighted by
a solid bar. This is a DOS Shell option that allows you to work
directly with MS-DOS.
Your computer system is now “running under DOS.”
For now, press ENTER to run the Command Prompt option.
Using MS-DOS with Your Computer
4-5
System Prompt
After you press the ENTER key to either accept the time
shown or enter a new one, MS-DOS will show a new prompt
on the monitor:
Microsoft (R) MS-DOS (R) Version X.XX
(C) Copyright Microsoft Corp 19XX-19XX
A>
This is the system prompt. When it is displayed, it means that
MS-DOS is waiting for you to tell it what to do. This is done
by typing a DOS command, then pressing the ENTER key.
Cursor
Following the system prompt, you will see a blinking underline
( _ ) character.
This is the “cursor.” The cursor shows you where the next
character you type will appear on the screen. As you can see
here, any command you type will appear immediately to the
right of the system prompt and on the same tine. Application
software often uses the cursor as well, allowing you to use the
cursor control keys to move the cursor around on the screen.
MS-DOS Commands
DOS commands instruct your computer to perform tasks such
as display a disk directory, copy a file, delete a program, etc.
4-6
Using MS-DOS With Your Computer
These are called internal commands and can be used anytime
after the system has loaded MS-DOS into memory. They do
not require the MS-DOS main system diskette to function.
More complex DOS commands are actually separate programs
that provide powerful features for your computer. These are
called external commands, and perform such tasks as
formatting a diskette, comparing files on different disks,
backing up a hard disk, etc. These commands require one or
more of the MS-DOS diskettes.
Hard disk system user’s can run any DOS command without
diskettes because the programs are stored on the hard disk
drive.
Case Sensitivity
MS-DOS does not differentiate between upper and lower case
letters in commands and filenames. This manual will show
commands in upper case for clarity, but you may enter them
either way. For example, both of these commands will generate
a directory listing of a diskette:
and
Function Keys and MS-DOS
As mentioned earlier, MS-DOS uses several of your keyboard’s
function keys to provide you with shortcuts. When you press
Using MS-DOS With Your Computer
4-7
the ENTER key after typing a command, MS-DOS copies the
command into a “buffer” memory. By using the function keys,
you can edit and reuse the command without having to retype
the entire line.
- Fl key
Copies one character at a time from the buffer to the command
line
- F2 key
Copies the entire buffer up to the next character you type
- F3 key
Copies the entire buffer to the command line
- F4 key
The opposite of F2, deletes all characters from the buffer up to,
but not including, the next character you type
- F5 key
Moves the current line you are typing into the buffer without
ENTERing it
- F6 key
Places an “end-of-file” marker when you copy from the
monitor to a disk file
- ESC key
Cancels the current command line without changing the buffer
- INS key
Inserts characters into the command line as you copy
characters from the buffer
- DEL key
Deletes characters from the buffer
4-8
Using MS-DOS With Your Computer
BACKSPACE Key
From time to time, you may make a typing error. This is not
usually a problem if you correct the error before you ENTER
the command. You can use the BACKSPACE key for this
purpose.
Note
Occasionally, you might happen to enter the wrong
command by mistake. If this incorrect command will result
in the loss of data, MS-DOS will usually warn you, and
give you a chance to change your mind.
The BACKSPACE key on your keyboard works just like a
backspace key on a regular typewriter: it moves the cursor back
one position. In addition, however, it erases the last character
typed. Press the BACKSPACE key as many times as necessary
to erase the typing mistake, then type out the command
correctly. For instance, type the following (but do not press
ENTER):
A>DRI
Press the BACKSPACE key twice to erase the I and the R.
Retype:
Then press the ENTER key. Your computer will respond by
producing the directory of the disk in the A drive. Now type
this:
Using MS-DOS With Your Computer
4-9
Then press the ENTER key. Your computer will respond:
Bad command or filename
A>
Default Drive
MS-DOS will only look at one disk drive at a time. Normally,
this is the “default” drive. You can tell which disk drive is the
current default drive by looking at the system prompt.
For example:
indicates that the “A” drive is currently the default drive.
Unless you specify otherwise, MS-DOS will direct any disk
activity to the “A” floppy disk drive.
You can easily change the default drive with an internal DOS
command. For instance, to change from the “A” drive (floppy
disk), to the C drive (hard disk), enter:
The computer will respond:
4-10
Using MS-DOS With Your Computer
As you can see, the system prompt has changed to show the
new default drive letter.
Note
If the computer responds:
Invalid Drive Specification
it may mean that tither there is no hard disk system
installed, or your Hard disk drive has not been configured
yet. See Chapter 6, “Using Your Hard Disk,” for
instructions.
From the A> prompt, try the command:
The computer will respond:
Press ENTER after you insert the diskette into the drive, then
the system prompt will be:
If you have a dual floppy disk drive system, the second, or “B”
drive is now the system default drive, as indicated by the new
system prompt. If performed on a single drive computer system,
Using MS-DOS With Your Computer
4-11
this command will still change the system prompt to B>, even
though there is only one physical drive present.
The BIOS “pretends” there are two disk drives present. It
routes all commands intended for the B drive back to the A
drive.
This feature is intended to allow owners of single drive systems
to use application software designed for dual drive systems.
Copying Your MS-DOS Diskettes
The first important task you must complete with your new
system is to make a “backup” copy of your MS-DOS diskettes.
To do this, you will need seven blank diskettes. It is a good
idea to prepare seven diskette labels at this time. Write the
following on those diskette labels, using a felt tipped pen:
MS-DOS MAIN SYSTEM DISKETTE
BACKUP COPY (Version #)
Write down the MS-DOS version number on each diskette
labels. This will avoid confusion later if you upgrade your
operating system to a new version. As you finish copying and
checking each MS-DOS master diskette, peel the correct label
off of the backing paper and place it on the upper left-hand
side of the front face of the new diskette.
The following procedures will show you how to make backup
copies of your MS-DOS master diskettes on both single and
dualdrive systems.
4-12
Using MS-DOS With Your Computer
Copying on Single Drive Systems
MS-DOS uses the external command DISKCOPY to copy
entire diskettes. DISKCOMP is used to compare the original
and backup diskettes to ensure that the copy is accurate.
To copy your master diskettes, first turn your computer on and
boot up MS-DOS. Choose the Command prompt option from
the DOS shell menu. The system prompt will appear. Enter the
following command:
The following message will be displayed:
The “SOURCE” diskette is the disk that you will be copying
from. Insert the MS-DOS master diskette into the A drive.
Press any key, such as the SPACEBAR. The floppy disk drive
will be activated, and your computer will display:
Copying xx tracks
x Sectors/Track, x Side(s)
The contents of the disk are being read into your computer’s
memory. After a few moments, the following message will
appear:
Using MS-DOS With Your Computer
4-13
When the drive indicator light goes out, remove the MS-DOS
master diskette from the floppy disk drive. Insert a new, blank
diskette into the drive. This is the “TARGET” diskette.
Caution!
Make sure the target diskette is blank. If there is any previous
data on the diskette, it will be erased by the DISKCOPY
routine.
Press the SPACEBAR key. The drive will turn on, indicating
that the computer formatting the new diskette, then writing
the copied information onto it. After a few moments, the drive
will turn off, and the system will display:
For now, type N. The system prompt will reappear. To
compare the backup diskette with the original, you will use the
DISKCOMP command. Enter the command at the system
prompt:
The computer will respond:
4-14
Using MS-DOS With Your Computer
Remove the backup diskette from the drive, and put it in its
protective jacket. Set it aside for a moment, making sure that
you don’t mix it up with the second blank diskette. Put the
original “master” MS-DOS main system diskette back into the
floppy disk drive, then press the SPACEBAR key. As with the
DISKCOPY command, your computer will read the entire
contents of the diskette into system memory, and will display:
When the computer is finished reading, the drive will turn off,
and the following message will appear:
Remove the master MS-DOS diskette from the floppy disk
drive, and put it in its protective envelope. Take out the
backup copy diskette, insert it into the disk drive, and press the
SPACEBAR key.
The computer will read the contents of the backup diskette,
and compare them with the copy of the master diskette that it
has stored in memory. If the information on the two diskettes
is identical, the computer will respond:
Using MS-DOS With Your Computer
4-15
Type N to return to the system prompt.
If there is a problem with the backup diskette, or if you put the
wrong diskette into the drive by mistake, the computer will
respond:
If the computer shows compare errors, start the copying
procedure over again at the beginning. The backup copy of the
MS-DOS diskette must be identical to the original. After you
have confirmed that the backup diskette is a good copy of the
master MS-DOS diskette, you may put your master diskette
away in a safe place. From now on, only use the master MS-DOS
diskette to make copies. For all other purposes, use the backup
copy of the MS-DOS diskette. By using the backup copy, you
ensure that any accidental erasures can be replaced.
Copying on Dual Drive Systems
To make backup copies of your MS-DOS diskettes on a dualdrive
system, follow the instructions below:
First, turn your computer on and boot up MS-DOS. Choose
the Command Prompt option from the DOS shell menu. The
system prompt will appear. Enter the following command:
4-16
Using MS-DOS With Your Computer
This command indicates to MS-DOS that you want to copy
the contents of a diskette in the A drive to a new diskette
located in the B drive.
The following message will be displayed:
The “SOURCE” diskette is the disk that you will be copying from.
The “TARGET” diskette is the one you will be copying to.
Put your master MS-DOS diskette in the A drive, and a new,
blank diskette in the B drive.
Warning!
If you have any doubts about which diskette goes in which
drive check them carefully. Make sure that the write
protect notch on the master MS-DOS diskette is covered
with a write protect tab.
Close both drive doors. Press any key, such as the
SPACE BAR. The A drive will be activated, and your
computer will display:
Using MS-DOS With Your Computer
4-17
The contents of the disk are being read into your computer’s
memory. After a few moments, the following message will
appear:
For now, type N. The system prompt will reappear. To compare
the backup diskette with the original, you will use the
DISKCOMP command. Enter the command at the system
prompt:
The computer will respond:
Since both diskettes are already in their correct locations, press
the SPACE BAR key. While the comparisons are being made,
the computer will display:
4-18
Using MS-DOS With Your Computer
When the computer is finished comparing the diskettes, the
drives will turn off, and the following message will appear:
Type N to return to the system prompt.
If there is a problem with the backup diskette or if you put the
wrong diskette into the drive by mistake, the computer will
respond:
After you have confirmed that the backup diskette is a good
copy of the master MS-DOS diskette, you may put your master
diskette away in a safe place and put the label on the backup
diskette. From now on, only use the master MS-DOS diskette
to make copies. For all other purposes, use the backup copy of
the MS-DOS diskette. By using the backup copy for everyday
computing, and saving the master diskette, you ensure that any
accidental erasures can be replaced.
From now on, when this manual refers to the “main system
diskettes,” use the backup MS-DOS diskette.
Using MS-DOS With Your Computer
4-19
FILES
In the same way that you can keep information grouped
together in manila folders, MS-DOS organizes data into files.
While you may store these folders in a cabinet, your computer
stores these files on disks. Separating information into files
allows you to work with that information more efficiently.
File Types
There are two basic file types:
Program files
Data files
Program files are files that perform a task. They manipulate the
computer and data files in order to achieve a result. MS-DOS is
a collection of program files, as are the control programs found
in application software.
Data files are files that contain the information (data) used by
program files. A file containing a list of names and addresses
would be a data file.
The two types of files are closely related. Program files usually
create data files. These may be the documents created by a
word processor, the numerical array created by a spreadsheet, or
some other collection of information.
A data file containing a written report can’t do anything by
itself. On the other hand, a word processor is useless without
documents to work on.
4-20
Using MS-DOS With Your Computer
Filenames and Extensions
Needless to say, each file on a disk must be uniquely
identifiable. To achieve this, MS-DOS requires that you name
every file you create, as you create it.
In order to be able to manipulate files easily, MS-DOS has
certain rules that you must follow when naming files. As you
will see, these rules leave you a great deal of freedom in your
selection of filenames.
Each filename can be up to eight characters long. To this eight
character name can be added an “extension.” Extensions
always begin with a period ( . ) which is followed by up to three
characters.
The format for a valid MS-DOS filename is:
ABCDEFGHJKL
Most of the characters and symbols on your keyboard are
available for use in filenames. These are:
The letters A through Z
The numbers 0 through 9
The following symbols:
!
(exclamation point)
@
(“at” sign)
#
(number sign)
$
(dollar sign)
%
(percent sign)
Using MS-DOS With Your Computer
4-21
&
(ampersand)
(and) (parenthesis)
-
(minus sign or hyphen)
[ and ]
(brackets)
-
(underline character)
The following are examples of allowable filenames:
JANUARY
CHAPTER.001
MEMO.APR
MAYSALES.%&$
$$.SALES.OCT
These filenames are valid because none of them are too long,
and only legal characters have been used. The following are
examples of illegal filenames, along with an explanation:
3RDQUARTER.SALES
This is too long. MS-DOS will accept this filename, but it
will be shortened to fit the size limits. The altered filename
would read 3RDQUART.SAL. As you can see, both the
filename and its extension have been shortened to the legal
length.
CHAPTER/4
The slash ( / ) is an illegal filename character. MS-DOS
will reject the filename and ask for another.
4-22
Using MS-DOS With Your Computer
NEW EMPL.LTR
This would be rejected by MS-DOS because of the space in
the filename.
Certain filename extensions have been set aside so that MS-DOS
can recognize program files. These are:
COM (for COMMAND file)
EXE
BAT
(for EXECUTABLE file)
(for
BATCH
file)
Program files should always have one of these three filename
extensions. Data files should never use these reserved
extensions. They can, however, use any other extension.
Filename extensions are optional with data files, so you can
leave them off entirely, if you want. Using filename extensions
with data files allows you to have many different variations for
a set of filenames. For instance, different chapters of a book
might be named:
CHAPTER.001
CHAPTER.002
CHAPTER.003
and so on.
Like MS-DOS commands, filenames and extensions can be
entered in either upper or lower case, but are always displayed
on the screen in upper case. However, since MS-DOS converts
lower case filenames into upper case, it is possible to
inadvertently erase an existing file by saving a new file with a
lower case name. To be safe, always make sure that you have
given a unique name to each file on a disk.
Using MS-DOS With Your Computer
4-23
Disk Directories
MS-DOS keeps track of the files stored on your disks by
maintaining a “directory” on each disk. These directories are
listings of the filenames and extensions, along with certain
information about the files themselves, such as when the file
was created or updated last.
The DIR Command
MS-DOS provides a simple command that allows you to look
at the directory of any particular disk. This is the DIR
command. Enter the command as follows:
The computer will display a listing similar to the following:
Some of the names and symbols may be different, but the
screen should show these five columns, and a similar last line.
4-24
Using MS-DOS With Your Computer
The information presented by the DIR command is as follows:
The filename & extension
The file size (in bytes)
The date the file was created or last updated
The time the file was created or last updated
The number of files listed in the directory
The number of unused bytes of space remaining on the disk
File Searches
You can also use the DIR command to search for specific files
on a disk. To do this, enter the DIR command in the following
format:
For instance, if you want to find the directory entry for a file
named “MAYSALES.RPT” on the diskette in drive A, enter
the command:
The computer will search the entire directory of the diskette
for a file named MAYSALESRPT. If a file is found, it will
appear as the only entry in the diskette’s directory. If there is
no MAYSALES.RPT file on the diskette, the computer will
display:
Using MS-DOS With Your Computer
4-25
Multiple Disk Drive Systems
The DIR command can be used to read the directories of other
drives in your system, if any are installed. For instance, to read
the directory of the B drive, when you are logged onto drive A,
enter the command:
The computer will display the directory of the diskette inserted
in the B drive. A similar command:
will cause the computer to display the directory of your hard
disk.
Note that in both examples, the A drive remains the default
drive. To change the default drive from A to B, and then
display a directory listing, enter the command series:
4-26
Using MS-DOS With Your Computer
The computer will display the B drive diskette’s directory, then
remain logged to the B drive.
Wildcards
Quite often, when dealing with disk files, you may find yourself
looking through directories for a particular file or group of files.
MS-DOS has a way to help you sort out those files you want
without having to read through the entire directory listing.
This is through the use of “wildcard” characters. Wildcard
characters are used to make a single command cover a number
of similarly named files.
While MS-DOS provides several wildcard characters, the most
one you will be using most often is the asterisk ( * ). The
asterisk matches any number of sequential characters in a
filename or extension.
For instance, to look at a listing of all the .EXE program files
on your main system diskette, enter the command:
This will produce a directory that looks like this:
Using MS-DOS With Your Computer
4-27
Application Software
Now that you know how to make backup copies of your
diskettes and how to work with MS-DOS, you can proceed to
use application software. Most software packages come with
detailed instructions for their set-up and use. These instructions
will often ask you to use the information in this chapter to find
specific files in the disk directories, or back up the master
diskettes provided with each package. Most software packages
can be backed up simply by using the MS-DOS DISKCOPY
command, as described above.
4-28
Using MS-DOS With Your Computer
Chapter 5
Using Floppy Disks
Description
Your computer works with a large electronic memory array
called RAM. This stands for Random Access Memory. Your
system’s RAM is actually an array of electronic circuits. As
long as the computer is powered up, this circuit array will
“remember” whatever is placed in it. When you turn the
power off, however, these circuits will “forget.” Therefore, you
need some way of retaining your programs and data after you
turn the system off. The most usual way of storing data, at least
on DOS-based computer systems, is on floppy disks.
Virtually all commercially available programs are distributed on
floppy diskettes. Before you buy an application software
package for your computer, you should make sure that it will
run under MS-DOS. Products labeled “for IBM PC,” “for IBM
PC/AT, ” “PC-compatible, ” or “MS-DOS-compatible” should
run properly. Products intended for other types of computer
operating systems, such as CP/M or Apple, will not run on
your system.
Note
If you should accidentally try to run CP/M or Apple
software, your computer will inform you that you are using
non-DOS diskettes. This will not damage your computer.
The most frequent use that you will have for diskettes is to save
the data, text, files, etc. that you create. You will use diskettes
to store your data between sessions on the computer, as well as
to back up your valuable software.
Using Floppy Disks
5-1
How Floppy Disks Work
Floppy disks, or diskettes, are made from a flexible plastic that
is coated with a magnetic oxide. The floppy disk drive encodes
this oxide with the data generated by the computer. After you
turn your system off, unlike electronic RAM, the encoded
oxide retains this data. Your data can then be read by the
floppy disk drive at a later time.
The magnetic oxide coating on the floppy disk will hold its
encoded data almost indefinitely unless you deliberately erase
it. This is done intentionally when you want to update the
information stored on the diskette.
The plastic disk is safely protected by a thin cardboard jacket.
The diskette spins inside this jacket, allowing the entire surface
of the diskette to be scanned by the drive’s circuitry. Data is
read from or written onto the diskette through the oval-shaped
slots in the jacket.
Normally, the computer will write new information onto the
unused space on the diskette. If there is no unused space, your
computer will inform you that the disk is full. You can instruct
the computer to write over the information that is already on
the diskette. You might do this to update an inventory file, or
change an address and phone number in a database.
Caution!
Updating, or overwriting, data stored on a diskette will
erase the old information. Under most circumstances you
cannot get it back.
5-2
Using Floppy Disks
Formatting Diskettes
When you get a new carton of diskettes, they are not yet ready
to be used. First, they must be prepared to accept data. This is
called “formatting” the diskette.
MS-DOS uses the same formatting method regardless of the
computer used. This is one of the keys to intermachine
compatibility. Since all PC-compatible computers use MS-DOS,
they can read all disks created by any other PC-compatible
machine.
Note
MS-DOS formats disks with a different "pattern" than
Apple-DOS or CP/M. This is why your computer system
cannot read these "foreign" disks.
To see what happens when you attempt to use an unformatted
disk, insert a new blank diskette into the A drive and close the
drive door. Then enter the following command:
Since the new disk hasn’t been formatted yet, your computer
cannot read it. After failing three times, your computer will
respond:
General Failure error reading drive A
Abort, Retry, Failure?
If you type R (fir Retry), the computer will attempt to read the
diskette again, and will finally display the same message.
Using Floppy Disks
5-3
When you type A (for Abort), or F (for failure) the computer
will automatically cancel the attempt and will return you to the
C > prompt.
Remove the unformatted disk from the drive.
The FORMAT Command
MS-DOS provides an external command program called
FORMAT.COM, that will format your blank diskettes. When
running this program, there are options available that allow
you to format several different types of diskette.
The following routines will show you how to use the
FORMAT command. These procedures assume that you are
formatting double-sided, highdensity, 1.2M-byte diskettes
(AT-compatible). Information on formatting 18OK-byte and
360K-byte diskette will be discussed under the /1 and /4 switch
options below.
First, if you have a hard disk installed MS-DOS on your system,
then enter:
C > FORMAT A:
The computer will load the FORMAT command file into
system memory, then will respond:
Insert new diskette for drive A:
and press ENTER when ready
Insert the new diskette to be formatted and press the ENTER
key.
5-4
Using Floppy Disks
The computer will display:
The formatting process takes a minute or two. The computer
will wait until the formatting process is complete, then display:
Press ENTER if you don’t want to have a label of your disk.
Then the screen will display the following message.
Don’t be concerned if the message displayed is slightly different
from this example. Enter N to return to the system prompt.
The new disk is now formatted and is ready for use. Remove it
from the disk drive and replace it in its protective envelope.
Using Floppy Disks
5-5
Option Switches
To format 180K-byte single-sided, single-density diskettes in the
computer’s high capacity disk drive, enter the FORMAT
command using the /1 and /4 option switch:
The computer will proceed to format the diskette. Upon
completion, you will see this message:
And the following screen will be appeared if you press ENTER.
(If you want to have a volume label, type the characters and
enter.)
Enter N to return to the system prompt. Remove the diskette
from the drive and place it in its protective envelope.
5-6
Using Floppy Disks
The /4 option switch is used to format 360K-byte double-sided,
double-density diskettes in the computer’s high capacity disk
drive. To do this enter the command:
The computer will proceed to format the diskette.
Upon completion, you will see this message:
Press ENTER not to have a label of your disk. Then the screen
will display;
XXXXXXX bytes total disk space
XXXXXXX bytes available on disk
XXX bytes in each allocation unit
XXXXX allocation units available on disk
Volume Serial Number is XXXX-XXXX
Format another (Y/N)?
Enter N to return to the system prompt. Remove the diskette
from the drive and place it in its protective envelope.
Using Floppy Disks
5-7
Caution!
36OK-byte diskettes formatted on l.2M-byte high density,
AT-style drives may not be reliable when used on some
360K-byte, XT-style drives. The /4 option switch is
primarily intended to permit the use of less expensive
diskettes with AT-compatible systems like this one.
If you need to have diskettes that can be safely read from
and written to by both styles of computer, you should
format the lower capacity diskettes on the XT-compatible
system where they will be used.
Formatting a diskette allows you to use it by providing
predetermined locations for certain files used by MS-DOS.
Once formatted, the disk directory space is created, as well as
additional areas reserved for use by MS-DOS. One of these
areas is the File Allocation Table, or FAT. This part of the
diskette contains a list of all of the files on the disk, and where
they are physically stored on the diskette.
The other area is the system area. On your MS-DOS main
system diskette, this area is occupied by the parts of MS-DOS
that are copied into your computer’s memory during the startup routine. During the start-up procedure, the BIOS program,
stored on the system motherboard, looks at this part of the
diskette to retrieve the active parts of the disk operating
system.
If these MS-DOS routines are not present in the system area of
a diskette, the BIOS cannot startup the computer. This is what
causes the error message:
DRIVE NOT READY ERROR
Insert BOOT diskette A:
Press any key when ready
5-8
Using Floppy Disks
You normally boot the system up from the MS-DOS main
system diskette. The DISKCOPY command copied these files
when you created the backup copy of the master diskette.
Sometimes, though, you may want to create a “boot disk” that
doesn’t have all of the external DOS commands on it. For
instance, you may want to make an “autoboot” copy of an
application software diskette.
To format a new diskette while placing the active MS-DOS
routines in the system area, enter the following command at
the system prompt:
The computer will load the FORMAT command file into
system memory, then respond:
Insert, new diskette for drive A:
and press ENTER when ready
Insert a new, blank diskette and press the enter key to start the
formatting process. After the new diskette is formatted the
active MS-DOS routines will be copied into its system area.
When the copying is finished the computer will display:
Format complete
Volume label (11 characters, ENTER for none)?
And the following screen will be appeared if you press ENTER.
(If you want to have a volume label, type the characters and
enter.)
Using Floppy Disks
5-9
XXXXXXX bytes total disk space
XXXXXXX bytes available on disk
XXX bytes in each allocation unit
XXXXX allocation units available on disk
Volume Serial Number is XXXX-XXXX
Format another (Y/N)?
Enter N to return to the system prompt. Then enter:
The directory listing should appear similar to the following:
Copying Files
If you have a dual drive system, it is easy to copy program and
data files from one diskette to another. This involves the
internal MS-DOS command, COPY.
5-10
Using Floppy Disks
Put the “source” diskette in drive A, and the “target” diskette
in drive B. At this time, you may want to check the directories
of both diskettes in order to make sure you will not overwrite a
file on the target diskette with the same name as the one you
want to copy.
Once you’re sure its safe to copy, enter the COPY command
with the following format:
A> COPY A:(filename) B:
For example, to copy the file “MAYSALES.RPT” from drive
A to drive B, enter the command.
A> COPY A:MAYSALES.RPT B:
When the copying process is done, the computer will display:
You can also enter this command without the default drive
letter, as:
A > COPY MAYSALES.RPT B:
When no drive letter is specified for the source drive, MS-DOS
assumes that you want to copy a file from the default drive.
Using Floppy Disks
5-11
To perform the operation in reverse, that is, to copy from the B
drive to the default drive, enter the command:
A > COPY B:MAYSALES.RPT
Note that this time, you were required to enter the source drive
letter before the filename. This is because, in this example,
drive B is not the default drive. However, since no drive letter
was specified for the target drive, MS-DOS copied the file onto
the default, or in this case, A drive.
It is also possible to copy a file between two disks when neither
one is the default drive. For instance:
A > COPY C:MAYSALES.RPT B:
will copy the MAYSALES.RPT file from the hard disk onto a
diskette ‘in the B drive. This time, note that both source and
target drive letters were used. This is because neither drive was
the system default drive.
Wildcards
Copying files using wildcards in the filenames can be efficient,
but it can also be dangerous. When using wildcards, always
make sure you won’t overwrite or erase another file. For
example:
A > COPY *SALES.RPT B:
5-12
Using Floppy Disks
will copy all of the files ending in SALES.RPT to the B drive.
The command:
A >COPY MAYSALES.*B:
will copy all files about MAYSALES to the B drive.
A final example:
A>COPY *.* C:
will copy all of the files on a diskette in the A drive to the
hard disk drive. This command is useful when backing up
diskettes containing data files.
Using Floppy Disks
5-13
Chapter 6
Using Your Hard Disk
Depending on the model, your computer system can be
expanded to include an optional hard disk drive. This chapter
will give you a basic understanding of its operation and show
you how to configure it. Information is also provided on how
MS-DOS works with your hard disk drive.
What is a Hard Disk Drive?
As mentioned in Chapter 5, “Using Floppy Disks,” your
computer uses an electronic memory array called RAM. This
memory is temporary and will only “remember” data as long as
the system power is on. When you turn off your computer, any
information stored in RAM is lost.
You have learned how to use floppy disks, or diskettes, to store
data and program files between computing sessions. It is more
convenient, however, to store your files on a hard disk drive.
The main reason for this is the speed of the hard disk drive.
Files are read off from the hard disk faster than from floppy
diskettes. Also, using a hard disk reduces the amount of time
spent inserting and removing diskettes from floppy disk drives.
A hard disk is very similar to a floppy disk. It is a plastic disk
that has been coated with a magnetic oxide. A hard disk will
store data indefinitely, until it is erased. Data is read from or
written onto a hard disk in the exactly same way as with a
floppy diskette.
There are differences between hard and floppy disks, though.
First of all, a hard disk is “non-removable.” Unlike a floppy
diskette, which can be taken out of its drive, the hard disk is
Using Your Hard Disk
6-1
permanently mounted inside the drive housing. Several hard
disk platters are stacked vertically in the drive housing and
sealed in a dustproof casing.
Second, a hard disk holds much more information than a
diskette. The “high-capacity” diskettes used in your computer
can only hold a little over one million bytes. The hard disk can
hold up much more data than floppy disk.
Finally, as mentioned above, a hard disk is much faster than a
floppy disk drive. The main reason for this is that the hard disk
platters are rigid, allowing them to be rotated at a much higher
rate than floppy diskettes, which have to move relatively slowly
so as to avoid damage.
Care of Hard Disk Drives
As you can see, hard disk drives are very precise devices. This
precision makes for a delicate mechanism. Even though your
hard disk drive is built to withstand the rigors of shipping, it
should be moved as little, and as gently, as possible. If you need
to move your computer system a short distance, be careful not
to drop or bump it. For greater protection, if you need to
transport the computer in a car, or ship it by truck or plane,
pack your system in its original shipping boxes.
The TGSHIP command should be run whenever you are going
to move the main system unit. This command moves the
read/write heads inside the hard disk drive to a “safety zone,”
where they won’t accidentally scratch the surface of the drive
platters. TGSHIP.COM is a special DOS command file
included with your system. You should copy this file into the
root directory of your hard disk drive. For information on hard
disk directory structures, see the “Organizing Your Hard Disk”
section of this chapter.
6-2
Using Your Hard Disk
Preparing Your Hard Disk
This section assumes that you have a hard disk drive system
physically installed in your main system unit. If you haven’t
installed your hard disk drive yet, see Chapter 7, “Expanding
Your System,” for information how to do this.
To begin, boot up your system using your MS-DOS as
explained in Chapter 4, “Using MS-DOS.” After setting the
date and time, enter this command:
A>C:
If the computer responds with:
C >
enter:
C > DIR
If a directory listing is displayed, even if there are no files
shown, it means that your hard disk system has already been
partitioned and formatted. You will see the
COMMAND.COM file at the top of the directory listing if the
MS-DOS active routines have been loaded onto the hard disk.
If your hard disk has been partitioned and formatted, skip this
section on installing your hard disk.
If the computer responded to the A > C: command with:
Invalid drive specification
Using Your Hard Disk.
6-3
it means that MS-DOS can’t “find” the hard disk drive. This
is either because the drive controller board has been incorrectly
set up, or more likely, the hard disk drive has not yet been
partitioned.
If the computer correctly executed the C: command, but failed
to display a directory, it probably means that the hard disk has
been partitioned, but not yet formatted. The next sections
describe how to partition and format your hard disk system.
Changing Your SETUP
Before you can partition and format your hard disk, you have
to let your computer know that you have one. This is done
with the SETUP program. Once you have determined that
your hard disk is “clean,” that is to say neither partitioned nor
formatted, you should enter the SETUP program.
Note
If you are not familiar with the SETUP program, take a
moment to review the information in Chapter 2,
“Running the Setup Program”
Turn your computer on. When you see the following message,
Press <DEL> if you want to run SETUP/EXTD-SET
Press < DEL > key. Move the cursor to the RUN SETUP
option and press Enter. The system displays the Setup Menu.
For now, look at the information on the left side of the screen.
6-4
Using Your Hard Disk
Move the screen cursor bar down to the Hard Disk C
parameter. Using the PgUp and PgDn keys, scroll through the
options to the disk type number matched with the hard disk
you have. If you select the type number 17 for 41MB hard disk,
it provides the following information under the right hand
headings:
This should match the information provided with your hard
disk drive. Other hard disk drives may require a different disk
type number. See the instructions provided with your hard disk
drive or call your dealer for assistance. After verifying the hard
disk drive type number, press the ESC key.
Using Your Hard Disk
6-5
The computer responds with:
Write data into CMOS and exit (Y/N)?
Press Y. The computer will update the information in its
configuration RAM, and will go through the start-up routine
again. Make sure MS-DOS is installed on floppy disk or hard
disk of your system, so the system will boot up in MS-DOS.
Note
Your system has an on board IDE type HDC and if you
want to install the another type of HDD except IDE, you
must disable the on board IDE HDC using the Extended
Setup Program. See Chapter 2 for the detailed information
of it.
Partitioning Your Hard Disk
After the DOS Shell screen appears, select the Command
Prompt option. At this point your are ready to partition your
hard disk drive.
To do this, enter the command:
A > FDISK
After loading the FDISK program, the computer will display
information on the hard disk drive installed in the system, as
follows:
6-6
Using Your Hard Disk
MS-DOS Version x.xx
Fixed Disk Setup Program
(C) Copyright Microsoft Corp. 19xx, 19xx
FDISK Options
Current fixed disk drive: 1
Choose one of the following:
1. Create DOS Partition or Logical DOS Drive
2. Set active partition
3. Delete DOS Partition or Logical DOS Drive
4. Display Partition information
5. Select Next fixed disk drive
Enter choice: [l]
Press ESC to exit FDISK
Note
If you only have one hard disk drive, option 5 will not be
displayed.
Press ENTER to choose the default selection, “Create a DOS
Partition.” The FDISK menu will disappear, and be replaced by:
Create DOS Partition or Logical DOS Drive
Current fixed disk drive: 1
Choose one of the following:
1. Create Primary DOS Partition
2. Create Extended DOS Partition
3. Create Logical DOS Drive(e) in the Extended DOS partition
Enter choice: [1]
Press ESC to return to FDISK options
Using Your Hard Disk
6-7
To create a single MS-DOS partition for your entire hard disk
drive, select the default option (#1) by pressing ENTER. The
Create Primary DOS partition menu appears next:
Create Primary DOS partition
Current Fixed Disk Drive: 1
Do you wish to use the maximum size
for a DOS partition and make the DOS
partition active (Y/N) . . . . . . . . .? (Y)
Press ESC to return to Fdisk Options
To reserve the entire hard disk for MS-DOS, press the ENTER.
FDISK now displays the following message:
System will now restart
Insert DOS diskette in drive A:
Press any key when ready...
It is common to use FDISK to create an MS-DOS partition
that takes up the entire hard disk drive and then make that
partition bootable. Now that you have completed these tasks,
you can restart your system using your MS-DOS Install
diskette.
Note
For information on the remaining FDISK menu selections,
see your MS-DOS User’s Guide.
6-8
Using Your Hard Disk
Make sure the MS-DOS install diskette is in the A drive, then
press the ENTER key. Your system will now reboot. It does this
to update the new partition information in its configuration
RAM. You may now format your hard disk, and load the MSDOS system files onto it.
Formatting Your Hard Disk
Now that your hard disk is partitioned, you need format it.
Note
If your hard disk drive has already been partitioned for MSDOS, it may have been formatted at the same time. Use
the DIR command to check the contents of the drive. If
your hard disk is formatted, there may be files stored on it
that you will need. Skip this section on formatting and
proceed to the next section, “Organizing Your Hard Disk.”
If your hard disk needs to be formatted, begin by selecting the
Command Prompt option from the DOS shell. Enter the
following command:
A > FORMAT C:/S/V
The floppy disk drive indicator will come on for a few seconds,
while the FORMAT command is into memory. When the
light goes out, the computer will display:
WARNING, ALL DATA ON NON-REMOVABLE DISK
DRIVE C: WILL BE LOST!
Proceed with Format (Y/N)?
Using Your Hard Disk
6-9
You should already have made sure that there is no information
stored on the hard disk that you want to save. Press Y to begin
formatting. The formatting process takes several minutes.
When it is completed, the system will display:
Formatting
System transferred
Volume label (11 characters, ENTER for none)?
Here, your computer is asking you to name your hard disk
drive. This is a result of the /V switch used with the FORMAT
command. A disk label can be useful when sorting directories,
so you may want to enter one now.
A volume label can use up to eleven characters. See Chapter
4, “Using MS-DOS,” for a list of valid label characters. When
you have entered the drive label, your computer will respond:
XXXXXXXX bytes total disk space
XXXXX bytes used by system
XXXXXXXX bytes available on disk
The /S switch in the FORMAT command caused the active
portions of MS-DOS to be loaded onto the system area of the
hard disk. At this point you can boot the system from the hard
disk.
6-10
Using Your Hard Disk
Organizing Your Hard Disk
This section provides you with a sample directory structure for
use with your hard disk. It will provide step-by-step instructions
that will create several files and subdirectories.
First, make sure your hard disk is formatted, and that the active
MS-DOS routines have been loaded into the system area of
your hard disk. The easiest way to check this is to boot the
system from the hard disk. Make sure that floppy drive A is
empty and turn your computer on. After going through the
start-up diagnostic routines, the computer will look at the A
drive to find the MS-DOS install diskette. Since the drive is
empty, it will then look at the hard disk drive. If the hard disk
drive is installed and formatted correctly, the system will boot
up and display MS-DOS shell screen.
If your system does not boot up from the hard disk, refer to the
previous section, “Formatting Your Hard Disk” for
instructions.
Assuming MS-DOS has booted correctly from the hard disk,
select the Command Prompt option from the DOS Shell
menu. When you see the system prompt:
c>
you are ready to begin.
First, you will create several subdirectories. These will be used
shortly to contain useful files. Begin by entering the command:
C>MD DOS4
Using Your Hard Disk
6-11
The MD command is a short form of MKDIR. This internal
DOS command creates a subdirectory under the directory you
are currently in. Since your computer boots up in the hard disk
root directory, the command you just entered created a
subdirectory named DOS4 under the root directory.
Note
If you don’t understand the term “root directory” refer to
your MS-DOS User’s Guide, “Files and Directories.”
When the computer displays the C> prompt again, enter:
C>DIR
to see what you have done. You should see a directory listing
similar to the following:
COMMAND COM XXXXX X-XX-XX X:XXX
FORMAT
EXE XXXXX X-XX-XX X:XXX
DOS4
X File(s)
<DIR>
x-xx-xx x:xxx
XXXXXXXX bytes free
c>
Just as MS-DOS commands usually look at the “current” disk
drive, they also look at the current directory. Since you can
change the current, “logged” disk drive, you would expect to
be able to change the current, logged directory. You can, using
the CD (CHDIR) command. Enter the command series:
6-12
Using Your Hard Disk
C>CDDOS
C>DIR
The directory listing displayed should look like this:
<DIR>
<DIR>
X File(s)
x-xx-xx
x:xxx
x:xxx
x-xx-xx
XXXXXXXX bytes free
c>
You have just moved to the DOS4 subdirectory. The two
< DIR > entries indicate that you are currently logged onto a
disk subdirectory. The period (.) entry represents the current
directory, while the double period (..) entry represents the
parent directory for the current subdirectory. These shorthand
entries allow you to move up and down through a directory
tree rapidly. To see how these shortcuts work, enter the
command series:
C>CD..
C>DIR
You will see that you are back in the hard disk root directory.
Now return to the DOS4 subdirectory by entering the
command:
C > CD DOS4
Using Your Hard Disk
6-13
Another way of moving through the directory tree quickly
involves the use of a similar command:
C>CD\
This command will take you directly to the root directory of
the current disk drive. This can be useful if you get “lost” in a
large directory tree.
The next step in organizing your hard disk involves copying
the external command files from the MS-DOS install diskette
into the DOS4 subdirectory on the hard disk. First, make sure
you are currently logged into the DOS4 subdirectory by
entering the command sequence:
C>CD\
C>CD DOS4
Insert the MS-DOS install diskette into the A drive. Close the
door, then enter:
C>COPY A:*.* C:
This command will copy the entire contents of the MS-DOS
install diskette into the DOS4 subdirectory on the hard disk.
When the copying process is complete, your computer will
display the following message:
xx File(s) copied
c>
6-14
Using Your Hard Disk
Using the DIR command, run a directory to verify that you
have copied the MS-DOS install diskette.
Remove the MS-DOS install diskette from drive A and replace
it with the MS-DOS Select diskette into the DOS4
subdirectory on the hard disk by entering the command
C >COPY A:*.* C:
When the copying process is done, carefully enter the following
series of commands:
C > DEL COMMAND.COM
This command will remove the COMMAND.COM file from
the DOS4 subdirectory. Since the file is available in your hard
disk root directory, it is not necessary to include it in the
DOS4 subdirectory. Later, as your hard disk gets filled up with
application software program and data files, the disk space
saved by deleting such duplicate files might become useful.
Repeat the copy procedure described above for the remaining
disks in the MS-DOS package.
Return to the root directory by entering:
C>CD C:\
You have now completed organizing your hard disk and
installing the MS-DOS files into subdirectories. As you can see,
the files have been placed in subdirectories according to the
type of activity you will doing when using them. As you add
application programs to the hard disk, it is a good idea to
create subdirectories to store them in, so as to keep different
program groups separated.
Using Your Hard Disk
6-15
For more information on directory and subdirectory
organization with MS-DOS, see your MS-DOS User’s Guide.
Backing Up Your Hard Disk
It is highly recommended that you make back up copies of your
valuable hard disk files regularly. Because hard disk drives are
fragile, they can sometimes be damaged. It is also possible to
erase some or all hard disk files through the use of incorrect
FORMAT and COPY commands. Backing up your files is the
only way you can be sure that you don’t lose information you
may have spent months or even years gathering.
Two external command programs on your MS-DOS install
diskette will help you back up your hard disk. The first,
BACKUP, will copy files from the hard disk onto diskettes.
The other, RESTORE, allows you to use the diskettes created
by the BACKUP program to reload the files back onto the
hard disk, if necessary. The following sections describe how to
use these two command programs.
The BACKUP Command
This command backs up one or more files from your hard disk
onto floppy diskettes. The diskettes must be formatted by the
MS-DOS FORMAT command. Do not use the /S switch when
formatting these diskettes. Disk space taken up by the inclusion
of the active MS-DOS routines would be wasted with the
BACKUP command.
Note
For information on formatting diskettes, see Chapter 5,
“Using Floppy Disks.”
6-16
Using Your Hard Disk
When you back up your hard disk using BACKUP, the first
thing to do is to format enough blank disks to hold the backed
up files. Once you start the BACKUP routine, you won’t want
to stop the program to format more diskettes. BACKUP takes
time, even on a high speed computer. Stopping the BACKUP
command before completion usually means that you would
have to start the process over again. Therefore, make sure you
have enough formatted diskettes before you start.
How Many Diskettes?
The number of diskettes you will need depends on two things.
First, how much of the hard disk will you be backing up?
Second, what is the capacity of the diskettes you will be using?
The following table shows the approximate number of diskettes
needed to backup an entire hard disk.
HARD DISK
CAPACITY:
NUMBER OF DISKETTES:
360K
180K
10M-byte
63
125
185
250
20M-byte
30M-byte
40M-byte
32
63
95
125
1.2M
10
20
30
40
A few extra diskettes have been included in these numbers to
make sure there are enough. If your hard disk is not loaded to
capacity, or if you are only backing up part of your hard disk,
fewer diskettes will be needed.
As you format these disks, prepare labels for them that
identifies these diskettes as a hard disk backup archive. Also
put the date on each label and number each diskette. This is
very important, since the RESTORE command requires that
you use the diskettes in the same order that was used during
the BACKUP procedure.
Using Your Hard Disk
6-17
This file contains the BACKUP command program. As
mentioned above, this file is provided on your MS-DOS
install diskette. You can run the program from the floppy disk
drive or from the hard disk, if you have copied the file into a
subdirectory on the hard disk.
To back up the entire hard disk, start by changing the system
default drive to the hard disk. Enter:
A>C:
Next, make sure you are in the root directory of the hard disk.
Enter:
C>CD C:\
Now, make sure your diskettes are formatted and ready. If you
are running BACKUP from the MS-DOS install diskette, enter
the command:
C>A:BACKUP C:\A: /S
If you have set up your hard disk directories as described in the
“Organizing Your Hard Disk” section above, enter the
command:
C> BACKUP C:\DOS4 A: /S
In the first example, the A:BACKUP command tells MS-DOS
to search the A drive for the BACKUP.COM file. In the
second, the C:\DOS4 statement will automatically direct MSDOS to look in the C:\DOS4 subdirectory for the file.
6-18
Using Your Hard Disk
In both examples, the A: portion of the command tells MSDOS that you want to start the backup routine with the root
directory of the hard disk, and store the backup files on
diskettes in drive A. The final /S switch tells MS-DOS to back
up all of the subdirectories on the hard disk in addition to the
root directory.
For a more detailed explanation of the MS-DOS BACKUP
command, see your MS-DOS User’s Guide.
The RESTORE Command
MS-DOS provides the RESTORE command program to allow
you to copy files from the archive diskettes created by the
BACKUP command back onto the hard disk. You should only
have use the RESTORE command if:
Your hard disk has been damaged, then repaired or
replaced
Files have been accidentally erased from the hard disk
You have reformatted the hard disk
To use RESTORE, first make sure the hard disk is ready to
receive files. Boot your system up with the MS-DOS installed
diskette in drive A. When you get to the system prompt, enter:
A>C:
If the computer responds with:
c>
Using Your Hard Disk
6-19
enter:
If a directory listing is displayed, even if there are no entries, it
means that your hard disk system is ready to receive files. If the
active routines of MS-DOS have been loaded on to the hard
disk, you will see the COMMAND.COM file at the beginning
of the directory listing.
If the computer responded to the A > C: command with:
Invalid drive specification
it means that MS-DOS can’t “find” the hard disk drive. This
is either because the hard disk controller board has been
incorrectly set up, or more likely, the hard disk drive has not
yet been partitioned.
If the computer correctly executed the C: command, but failed
to run a directory, it probably means that the hard disk has
been partitioned, but not yet formatted.
Once you have made sure the hard disk is ready to receive files
you may proceed with the RESTORE procedure. The routine
described below should only be used to restore the entire
contents of the backup archive diskettes to an empty hard disk.
For information on partial backups to a hard disk drive
containing files, see the entry for the RESTORE command, in
your MS-DOS User’s Guide, “MS-DOS Commands.”
First, set the C drive directory to the root directory by entering
the command:
6-20
Using Your Hard Disk
Now set the system default drive letter back to drive A by
entering:
The computer will respond by displaying:
Make sure your MS-DOS install diskette is inserted into the A
drive. Enter the following command:
The RESTORE command file will be read from the MS-DOS
install diskette. The A: C:\ in the command tells MS-DOS that
you will be restoring files from diskettes in the A drive to the
hard disk root directory. The /S switch tells MS-DOS that you
want to restore the subdirectories as well as the root directory
files.
You will be prompted to insert the backup archive diskettes
into the A drive, one at a time. It is very important that you
insert these diskettes in order. The BACKUP command
program codes each archive diskette with an identification
number, which is read by the RESTORE program. The use of
this i.d. number ensures that your files are reassembled
properly, and loaded into the correct subdirectories.
Using Your Hard Disk
6-21
Chapter 7
Expanding Your System
As you get more familiar with your computer system, you will
probably want to add hardware to it. This can include
additional disk drives, printers, modems, etc. This chapter
addresses the installation of some of the most common devices.
Note
Because a wide variety of expansion products are available
for your system, and configuring them to communicate
over general purpose interfaces can be a complex task, it is
impossible far this manual to provide detailed instructions
for connecting these devices. Please follow the instructions
provided with your peripheral. If you should have problems
with the installation of a peripheral device, contact your
dealer for assistance.
Connecting Peripherals
Peripherals are devices that can be connected to your computer
system to increase its ability to communicate and process
information. The term “peripheral” is usually used to indicate
an externally mounted unit that is connected to your computer
with a cable. Peripherals available for your computer system
are :
Keyboards
Video monitor systems
Printers
Expanding Your System
7-1
Modems
External disk drives
Your computer is designed to communicate with peripherals by
way of the connectors on the rear panel of the main system
unit. The connectors are called “ports,” and allow information
to be sent back and forth between the system CPU and a
peripheral device.
Your keyboard and your video monitor connect to the main
system unit by way of two specialized ports. The keyboard is
connected to the “Keyboard port” on the rear panel of the
main system unit. If you have purchased a video monitor
system for your computer, the display monitor is connected to
the “video port” on the rear panel of the video controller card,
which is mounted inside your main system unit.
Since your system CPU must be in constant communication
with both the keyboard and the display monitor, specific
circuits connect them together. Since other peripheral devices
only communicate with the system CPU occasionally, they can
use general purpose ports.
Computerized data is composed of electronic words called
“bytes.” As an example, each letter or number that appears on
your display monitor has been sent from the main system unit
to the monitor itself in the form of a single byte. This byte is
made up of individual “bits.” in the same way that a word is
made up of letters. In order to keep things consistent for the
system CPU, bytes are made up of groups of eight bits. Using
eight-bit bytes results in 256 basic combinations, each of which
corresponds with a specific letter or number.
7-2
Expanding Your System
run the current application software.
Serial Ports
There are two basic kinds of general purpose I/O (Input/Output)
port. One kind is a “serial” port, where data bits are sent one
at a time along a single wire, in series. Additional wires are
used to send control signals between the transmitting and
receiving devices. These control signals allow the two
communicating devices to determine which of them will send
or receive the data, and when the first bit of a particular byte is
being sent, among other things.
Standardized “protocols” for these signals have been agreed
upon by the microcomputer industry so that the different
manufacturer’s machines can communicate with each other.
Your computer system uses the “RS-232C” asynchronous serial
communications interface. The serial port connector is the lefthand 9-pin “D-type” connector mounted on the rear pannel of
the system motherboard. Electrical information for the serial
port is in Appendix A “Specifications.” For details on the
serial port pin connections, see Appendix D, “Connector
Pinouts.”
MS-DOS uses labels to refer to the various I/O ports on your
computer. The RS-232C serial ports on the system
motherboard are assigned the “COM1” (Communications port
#l) label and the second port is "COM2" (Communications
port #2) label.
Expanding Your System
7-3
Parallel Ports
Unlike serial ports, parallel ports allow your computer to
communicate one entire byte at a time. Eight wires are
included in the cable to permit the transmission of each of the
eight data bits simultaneously. Extra wires are included in the
cable for control signals. Your Computer uses the industry
standard “Centronics-compatible” parallel printer port
interface.
MS-DOS uses the label “LPTl” (Line Printer #l) for the first
parallel port. Additional parallel ports can be added to your
computer through the use of multi-function boards. These ports
would be labeled LPT2, LPT3, etc.
Connecting Printers
Most, but not all, printers use the Centronics-compatible
parallel port.
To install this type of printer, connect an appropriate cable
between the parallel port connector on the rear panel of the
system motherboard in the main system unit and the input
connector on the printer. Information on the correct cable will
be found in your printer’s manual.
serial interface port. See the printer’s manual for complete
7-4
Expanding Your System
Connecting Modems
Modems are used to connect your computer to the telephone
line. Since the electronic requirements for the transmission of
your voice are different from those used by your computer, a
modem is used to “translate” your digital information to a
signal that can be sent over the telephone lines.
Internally mounted modems are attached to a circuit board
that will be installed inside your main system unit. These
modems can communicate directly with the system CPU
through your computer’s internal circuitry. The telephone line
is plugged into a socket located on the rear panel of the
modem.
External modems connect to your computer’s RS-232C serial
port. Connectors are provided on the modem itself for
attachment to the phone system.
Connecting External Disk Drives
At some point, you may decide to add an external disk drive.
This may become necessary if all of the internal drive
compartments are in use, or if you want to place your main
system unit away from your work area, while keeping a drive
next to your keyboard.
The floppy disk drive control port is provided on your system
motherboard. While the cabling for these ports has been
designed to be used inside the main system unit cabinet, it is
possible to route the connectors outside to an external drive by
using a longer cable. This cable can be routed outside the main
system unit by way of an unused expansion slot panel.
For installation instructions, refer to the manual provided with
your external disk drive.
Expanding Your System
7-5
Note
For instructions on opening the main system unit cabinet,
see the section “Opening and Closing the Case,” later in
this chapter,
System Expansion And Upgrades
This section deals with the addition of expansion boards and
products to your computer’s main system unit. Although most
expansion products are provided with detailed instructions for
their installation and use, it is recommended that you read
through this section in order to familiarize yourself with some
of the basic principles of expanding your computer.
Tools Required
To install most expansion products in your main system unit,
you will usually need the following tools:
a small/medium “Phillips-type” screwdriver
a small flat-blade screwdriver
General Precautions
In the interests of personal safety and product reliability, you
should review the following information:
Follow all of the instructions and warnings marked on this
product, or included in this manual.
Make sure you have enough room to work on the unit. If
necessary, disconnect any peripheral device cables
connected to the unit’s rear panel.
7-6 Expanding Your System
For additional information on safety and maintenance,
refer to the appropriate sections of this manual’s
introductory chapter.
Stop!
When you remove the main system unit cover, observe the
following precautions:
The power supply cord must be unplugged before the
main system unit cover is removed. (Separe le cordon
d’alimentation et puis enleve le couvercle.)
Once removed, the cover must be replaced and
screwed in position before the power supply cord is
plugged back in. (Apres le couvercle a enleve, visse le
couvercle en place et remettre le cordon d’alimentation.)
Warning;
Installing or removing circuit boards or plugging cables in
with the system AC power turned on can damage your
system.
Figure 7-1. Cover Mounting Screws
Expanding Your System
7-7
Opening and Closing the Cabinet
The procedure for opening the main system unit cabient is as
follows:
Unplug the video monitor AC power and signal cables
from their rear panel sockets. Set the monitor safely aside.
Unplug the keyboard and set it aside.
Unscrew the screws on the rear panel of the unit and set
them aside.
Carefully, slide the main system unit’s cover towards the
front of the unit. Continue sliding the cover forward until
it can be removed completely. Set the cover aside.
Figure 7-2. Removing the Cover
7-8
Expanding Your System
Later, to close the unit, follow these steps in order:
Make sure all the system and expansion boards are properly
seated in their connectors, and have had their mounting
screws tightened down.
Make sure all the internal cables have been properly
connected and arranged neatly. Wires should not be
pinched or caught between chassis parts or circuit boards.
Carefully slide the cover back onto the main system unit,
being careful not to damage the cables.
As you slide the cover onto the unit, adjust the alignment
to permit the cover to slide over the disk drive nosepieces.
When the cover is properly seated on the main system unit
chassis, replace and tighten down the screws on the rear
panel.
Reconnect the keyboard to its connector on the rear panel
of the main system unit.
Place the video monitor on top of the main system unit
and connect the AC power and signal cables to their
correct sockets on the rear panel.
Reconnect any peripheral device to their rear panel I/O
port connectors.
Plug the AC power cable into the socket on the rear panel
of the main system unit and the main AC power outlet.
Installing Circuit Boards
Most of the expansion products you will be installing into your
computer are circuit boards. Like the system boards installed at
Expanding Your System
7-9
the factory, expansion boards are plugged into the main system
unit’s mother board.
There are expansion boards available for a wide variety of
functions.- The most common expansion boards provide such
functions as extra I/O ports, high resolution video graphics and
system memory expansion.
The basic computer is shipped from the factory with only the
system motherboard installed. If you have purchased a system
with a video monitor or a hard disk system installed, the
necessary controller board(s) should also be installed. If you are
adding these systems to a basic computer, or expanding your
system by installing additional hardware, follow the procedure
below to install the circuit boards.
First, read all of the instructions provided with the expansion
product. Then, carefully unpack the circuit board(s) to be
installed.
Warning!
Most computer circuit boards have “static sensitive”
components on them. These parts can be damaged by
static electricity, which can be generated by rubbing your
hand across the exposed metal parts an the board. To
avoid this damage, always handle circuit boards by their
edges, being careful to avoid contact with the exposed edge
connectors and parts.
Following the instructions provided with the expansion board,
set any configuration switches and jumpers on the expansion
board.
Open the main system unit cabinet and set the configuration
jumpers on the system motherboard to match the new
hardware arrangement. You will be able to do this without
removing the system motherboard from the main system unit
7-10
Expanding Your System
chassis, although you may need to unplug the disk drive ribbon
cable from its connector to allow easy access to the jumpers.
The system boards contains eight expansion slots comprised of
two basic types as follows:
l
Two 8-bit slot for PC/XT boards
l
Six 16-bit slots for PC/AT boards or 8-bit PC/XT boards
Figure 7-3. Installing the Circuit Boards
Expanding Your System
7-11
Disconnect any internal cables that may be in the way. As you
do, make a note of their correct locations and orientations for
later reattachment. Unscrew the retaining screw for the slot
guard, and set it aside. Mount the expansion board into the
slot by gently sliding the board into the slot. If the board is
long enough to reach the card guide mounted on the front
panel support flange, slide the board down the center groove of
the guide.
Making sure the board is correctly aligned, carefully insert the
board’s edge contacts into the slot connector on the main
system unit’s motherboard. A gentle rocking motion is helpful
in getting the board started in the edge connector.
Once started, press the board into the motherboard connector
until it is seated completely. The tab at the bottom of the
mounting bracket should fit into the slot at the bottom rear of
the main system unit, and the bracket’s top flange should rest
directly on top of the rear panel support.
CORRECT
NO ELECTRlCAL OR
PHYSICAL RESTRICTIONS
INCORRECT
PHYSICAL RESTRICTIONS
7-12
Expanding Your System
INCORRECT
ELECTRlCAL
RESTRICTIONS
Figure 7-4. Installing the Option Card in an Expansion Slot
Check the board’s alignment to make sure it is straight and
level. If necessary, move the board slightly to align the hole in
the top of the mounting bracket over the screw hole in the
main system unit’s rear panel flange. Install the holddown
screw that you removed earlier.
Reconnect any internal cables that were disconnected earlier. If
you have a problem making the cables reach their connectors,
you may have to move the board you just installed to another
slot. If any external equipment is used with the expansion
board, connect it to the board’s rear panel connector(s),
following the instructions given with the product.
When the installation of the board is completed, close the
main system unit cabinet as described above.
Disk Drive Compartments
To install expansion devices such as additional floppy disk
drives into the main system unit’s disk drive compartments,
follow the procedure given below.
First, make yourself familiar with the specific installation
procedure for the expansion device by reading all of the
Expanding Your System
7-13
documentation provided. Then, remove the main system unit
cover as described above. Select the drive compartment where
you will install the expansion device. Remove the blank front
panel from the selected compartment by removing the
mounting screws.
Slide the expansion device into the compartment along the
side rails of the drive cage until it is all the way in. Replace the
hold down clamps and their mounting screws.
Connect any internal power cables to the correct pins on the
rear of the expansion unit. Connect any required control cables
to the device. Close the main system unit cabinet as described
above.
Note
Your main system unit is supplied with the cables necessary
to connect two floppy disk drives to the system
motherboard. Follow the instructions provided with the
expansion floppy disk drive for proper installation.
Figure 7-5. Mounting the Internal Hard Disk Drive
7-14
Expanding Your System
Internal Hard Disk Drive
If you are to mount the internal hard disk drive inside the main
system unit case, follow the steps below:
Remove the cover from the main system unit, as described
above.
Remove mounting plate by unscrewing the hold down
screws.
Attach the hard disk drive to the mounting plate by
installing the four mounting screws through the bottom of
the plate into the bottom of the drive frame.
Replace the mounting plate onto the mounting frame by
sliding the plate into the two openings provided in the
mounting frame.
Replace the hold down screws.
Connect the hard disk drive controller cables to the drive.
Replace the main system unit cover.
Note
Your system has an on board IDE type HDC and if you
want to install the another type of HDD except IDE, you
must disable the on board IDE HDC using the Extended
Setup Program. See Chapter 2 for the detailed information
of it.
Expanding Your System
7-15
Appendix A
Specifications
Computer System
Operating Temperature
: 41° to 95°F (5° to 35°C)
Storage Temperature
: -5° to 140°F (-15° to 60°C)
Operating Humidity
: 20% to 80% (no condensation)
Storage Humidity
: 10% to 90% (no condensation)
Compatibility
: IBM PC/AT
Power Supply
: 238W
110 Range: l00-125 VAC,
7.0 A, 50/6OHz
220 Range: 200-240 VAC,
4.5A, 50/60Hz
Keyboard
: 101 key keyboard
System MotherBoard
Firmware
: AMI Software BIOS
Operating System Support : MS-DOS
Bus Interface
: IBM PC/XT,
PC/AT-compatible
Specifications A-1
: 2ea 8-bit (62 pin connector)
6ea 16-bit (98 pin connector)
Expansion Slots
Dynamic RAM (with parity) : lM-bytes, expandable 16Mbytes on Motherboard
80ns, 2 wait state access
Floppy Disk Drive Support
: 2ea - 360K, 720K, 1.2M or
1.44M-byte
I/O Ports
: 2ea 9-pin RS-232C
asynchronous serial
communication port
lea 25pin Centronicscompatible parallel printer
port
l ea 5-pin Keyboard port
Audio Support
: 1 mini-speaker
Real Time Clock
CPU Logic
Main Central Processor IC
TriGem 386X
386-25’” microprocessor
TriGem 386XE
386-33” microprocessor
Math Coprocessor IC (optional):
TriGem 386X
TriGem 386XE
A-2 Specifications
Intel Series
Weitek Series
387-25™ coprocessor
WTL3167-25 coprocessor
387-33™ coprocessor
WTL3167-33 coprocessor
System Memory
Data Interface
: 32-bit memory access
Cache Memory
: 64KB or optional 128KB
Memory Bank Configurations
NO.
BANK 0
BANK 1
BANK 2
BANK 3
SIZE
1
2
3
4
5
6
7
8
9
10
11
12
13
256K
256K
256K
256K
1M
IM
1M
1M
1M
1M
IM
IM
1M
0
256K
256K
256K
256K
256K
256K
1M
1M
1M
1M
1M
1M
0
0
256K
256K
0
256K
256K
0
256K
256K
1M
1M
1M
0
0
0
256K
0
0
256K
0
0
256K
0
256K
1M
1M
2M
3M
4M
5M
6M
7M
8M
9M
10M
12M
13M
16M
BIOS ROM
: 64K-byte
CMOS RAM
: 128-byte
System I/0
DMA Channels:
8-bit operations - 4 channel
16-bit operations - 3 channel
Address space - 16MB
Programmable Timers: 3
Vectored Interrupt Levels: 15
Specifications A-3
System Timing
System Clock Speed:
CPU
l/O
High
33MHz (25MHz)
8MHz
LOW
8MH.z (8MHz)
8MHz
Speed
Clock Cycle Time:
125ns (8MHz)
40ns (25MHz)
30ns (33MHz)
I/O Address Map
Hex range
000-01F
120-03F
040 - 05F
060 - 06F
070 - 07F
080 - 09F
0A0 - 0BF
0C0 - 0DF
OF0
OF1
OF8 - OFF
378 - 37F
3F0 - 3F7
3F8 - 3FF
Device
DMA controller 1, 8237A-5
Interrupt controller 1, 8259A, Master
Timer, 8254-2
8042 (Keyboard)
Real-trme clock NMI mask
DMA page register, 74LS612
Interrupt controller 2, 8237A-5
DMA controller 2, 8237A-5
Clear math coprocessor busy
Reset math coprocessor
Math coprocessor
Parallel port on board
FDD control on board
Serial port on board
Note: I/O address hex 000 to FFF are reserved for the system board 110
Hex 100 to 3FF are available on the I/O channel.
A-4 Specifications
Appendix B
System Mother Board
Figure B-l. The System Motherboard
This appendix provides configuration and interface information
for this board. You may skip this appendix if you are not
installing expansion products that require changing the
motherboard’s configuration switch settings.
System MotherBoard
B-1
Hardware Settings
The system motherboard provides several switches to set the
system configuration. These are located at various points on
the board.
Note
If you have problems setting the system CPU configuration
headers, contact your dealer for assistance.
When you turn the system power on, the system CPU will
compare these settings with the information stored in its
configuration RAM as part of the diagnostic routines. If any
inconsistencies are found, they will be shown on the display
monitor before MS-DOS is loaded. At that time, you will be
prompted to run the SETUP program to change the options
stored in the configuration PAM. It is important that these
settings describe the actual equipment installed on your
computer system.
B-2 System MotherBoard
Removing The MotherBoard
In order to change the settings defined by these jumpers, it will
be necessary to remove the system motherboard from the
chassis. To do this, follow these steps, referring to Chapter 7,
“Expanding Your System,” where necessary:
Unplug all of the cables from the rear panel of the main
system unit.
Remove the main system unit cover.
Remove all expansion boards from their slot connectors on
the system motherboard, noting the location of each board
and any internal cable connections, for re-installation later.
Carefully unplug all of the cables connected to the system
motherboard, noting their locations for later.
Remove the several screws that attach the system
motherboard to the chassis.
Carefully slide the motherboad out of the chassis.
To re-install the motherboard, reverse this procedure.
Switches
Once the motherboard is out of the chassis, proceed to set the
configuration switches to match the changes in the system
hardware.
System MotherBoard B-3
The Table B-l lists the switch settings
- Table B-l. Hardware Switch -
Connectors
The system motherboard is provided with a number of
connectors for communication with other parts of the
computer system. These connectors are discussed below.
For pinout information on these connectors, see Appendix D,
“Connector Pinouts.”
The connectors provided on the system motherboard are for
signal/power in facing and the I/O ports, as follows:
B-4 System MotherBoard
- Table B-2 -
Expansion Slots - J7 to J14, J17 to J22
The system board contains eight expansion slots comprised of
two basic types as follows:
Two 8-bit slots for PC/XT boards
Six 16-bit slots for PC/AT boards
Caution!
Do not overload the system board power connector by
installing expansion boards that may draw excessive current.
Keyboard Port - J3
The keyboard connector J3, is a 5pin DIN connector for
keyboards that are compatible with the IBM AT Keyboard.
System MotherBoard B-5
Serial Port - J1 and J4
Connector Jl and J4 provide the standard AT-type RS-232C
serial interfaces.
Note
you can use the on board serial ports for COM 1 and COM
2. If you have external card for serial ports on your system,
you must disable the on-board serial port. when you’d like
to disable the on board serial ports, do the following;
1. Open the hardware jumper, JP3 and JP4.
2. Enter the Extended Setup Program and disable the
serial ports.
Refer to Chapter 2 for the detailed descriptions of Extended
Setup Program.
Parallel Port - J2
Connector J2 on the system board provides a standard
Centronics 25pin parallel interface.
Note
If you want to use external device for parallel port, you
should disable the on-board parallel ports. Like the case of
serial ports, do the following for disable the parallel ports.
For more instruction of Extended Setup Program, see
Chapter 2 in this manual.
1. Open the hardware jumper, JP2.
2. Enter the Extended Setup Program and disable the
serial ports.
B-6 System MotherBoard
Power Connector - J6, J15
The system board requires four DC voltage: + 12V, -12V,
+5V, and -5V.
The power connector respectively supply power to the system
board and to the six expansion slots.
Speaker - J25
Connector J25 provides a speaker connection for audible tone
generation. The connector is a two pin header.
IDE Interface connector - J24
You use this 40 pin connector with IDE type Hard disk drive.
Note
Your system has an on board IDE type HDC and if you
want to install the another type of HDD except IDE, you
must disable the on board IDE HDC using the Extended
Setup Program. See Chapter 2 for the detailed information
of it.
If you want to know the detailed pin assignment of those
I/O connectors, see Appendix D of this manual,
System MotherBoard
B-7
Appendix C
Video Monitor Systems
There are many video display systems available for use with
your computer system. This appendix will provide a brief
description of the most common video system types, and
discuss their applications.
Monitor System Resolution
The main difference between video monitor system types is
their screen resolution. The monitor’s resolution is important
because it determines the number of characters that can be
displayed on the screen at any one time, and the quality of any
screen graphics displayed.
The image displayed on the video screen is made up of a large
number of individual dots. This is true whether the displayed
screen image is made up of text or graphics, or is a mixture of
both. The higher the monitor’s resolution is, the smaller the
individual dots can be. Smaller dots means that more of them
can be displayed in the same space. If more dots are displayed,
then more text characters and better looking graphics can be
displayed.
Video Controller Boards
The video controller board controls the actual number of dots
sent to the screen. A video system’s resolution capability is
usually described as the number of dots that can be displayed
horizontally by the number of dots that can be displayed
vertically.
Video Monitor Systems
C-l
The personal computer industry has established several video
controller resolution and color standards. Some of these are
described below.
- Hercules Graphics Compatible (HGC):
HGC boards have become the video controller-of-choice
for basic personal computer video display monitor systems.
Providing dot resolutions up to 720x350, HGC boards
display good quality text and graphics, while using
shading to accommodate color software.
- Color Graphics Adaptor (CGA):
The original CGA boards featured very low resolution,
typically 320 x 200. This was because they were originally
intended home computers that were used for advanced
video games. Recently, however, CGA resolution has
been improved to 640 x 200. With the higher resolution,
CGA has gained acceptance in the office environment.
By using colored text screens and low-level graphics, a
number of software packages have been made easier to
use.
- Enhanced Graphics Adaptor (EGA):
EGA video systems provide high resolution (640 x 350
maximum) color graphics capabilities. These monitor
systems are often used in computer-aideddesign
workstations and other software applications requiring a
larger number of on-screen colors than CGA controllers
can provide.
- Video Graphics Array (VGA):
Recently, a new video standard has emerged to take
advantage of the features of the multi-sync monitors.
Providing up to 720x400 dot resolution, these systems
have been used in applications that require the highest
possible video resolution, such as desktop publishing,
computer-aideddesign (CAD/CAE), and broadcast quality
computer graphics.
C-2
Video Monitor Systems
The maximum screen resolutions of the different video
standards is summarized below, along with their color and
graphics features:
HGC:
maximum dot resolution:
720x350
maximum text display:
80 columns x 25 lines
colors:
monochrome green or amber
CGA:
dot resolution:
640 x 200
maximum text display:
80 columns x 25 lines
colors:
2 of 16 colors (640 x 200)
4 of 16 colors (320 x 200)
EGA:
dot resolution:
640x350
maximum text display:
80 columns x43 lines
colors:
16 of 64 colors
VGA:
dot resolution:
720x400 (text only)
640x480 (text and graphics)
maximum text display:
80 columns x50 lines
colors:
16 of 262, 144
256 of 262, 144 (320x200 res)
Video Monitor Systems
C-3
Note
EGA and VGA controller boards are available with higher
resolutions than the maximum defined by the standards.
The optional EGA video system for this computer provides
up to 1056x352 dot resolution for a text display of 132
columns x44 lines, and up to 800 x 600 resolution for color
graphics.
Monitor Types
There are many different types of video monitor available.
Some of the major ones are described below.
Composite Video:
With a 300 x 200 resolution, this type of monitor is
usually used with home computers. They are not
recommended for use with your system.
TTL Monochrome:
These monitors provide up to 1000x350 resolution,
with either a green or amber colored screen. Primarily
intended for text only applications, these monitors can
run Hercules-compatible graphics programs, although
applications requiring full CGA or EGA color
compatibility will be difficult, if not impossible, to use.
A TTL monochrome monitor and a Hercules compatible
controller board will meet your computer system’s basic
video display monitor needs.
RGB Color:
RGB stands for Red, Green and Blue, and indicates that
each of the primary colors are separately driven by the
video controller board. RGB monitors cover a broad
range of resolutions from 320 x 200 up to the higher
EGA ranges of 720 x 480. RGB color monitors are very
C-4
Video Monitor Systems
useful in applications that need good-looking graphics,
or higher resolution text, though they are limited in the
number of colors that can be displayed at a given time.
If you are going to be using software that requires color,
but not high resolution graphics, you should use an RGB
video display monitor, connected to a CGA video
controller board. If your software requires high resolution
graphics, use an EGA controller board instead.
Multi-sync:
Multi-sync monitors are so named because they are able
to adjust themselves to any standard video format.
Providing resolutions up to 1400 x 1200, multi-sync
video monitors are used with software that needs very
high resolution color graphics. Connecting your
computer to a multi-sync monitor by way of either an
EGA or VGA controller board provides one of the
highest resolution computer video systems available.
This type of system is used for such applications as very
high resolution CAD/CAE workstations, computer
graphics design and desktop publishing.
Video Monitor Systems
C-5
Appendix D
Connector Pinouts
I/O Ports
RS-232C Serial port
(9-pin subminiature “D” connector):
Pin #
I/O Type:
1
2
3
4
5
6
7
8
9
Input
Input
output
output
Ground
Input
Output
Input
Input
Signal Name:
Carrier Detect (CD)
Receive Data (RD)
Transmit Data (TxD)
Data Terminal Ready (DTR)
Singal Ground (GND)
Data Set Ready (DSR)
Request to Send (RTS)
Clear to Send (CTS)
Ring lndicator (RI)
Note
All signals conform to EIA Standard RS-232C.
Centronics-compatible parallel printer port
(25-pin subminiature “D” connector):
Pin #
I/O Type:
1
2
3
4
5
6
7
8
Input
output
output
output
output
output
output
output
Signal Name:
-Strobe
Data Bit 0
Data Bit 1
Data Bit 2
Data Bit 3
Data Bit 4
Data Bit 5
Data Bit 6
Connector Pinouts D-l
Note
1. All outputs are s&ware generated. All inputs are
real-time signals (not latched),
2. All signals are TTL compatible.
Keyboard Port
(6-pin mini “DIN’ connector)
D-2 Connector Pinouts
IDE Port
Connector Pinouts D-3
Power Supply Connector
(12-pin post header)
Signal Name
Pin #
Power Good Signal
+5v Volts
+ 12v Volts
- 12v Volts
Ground
Ground
Ground
Ground
- 5 Volts
+ 5v Volts
+ 5v Volts
+ 5v Volts
1
2
3
4
5
6
7
8
9
10
11
12
Figure D-l. Expansion Slot Connectors
D-4 Connector Pinouts
Expansion Slot Connectors
Your computer comes with industry standard IBM compatible
expansion slots. There are eight AT and XT-style expansion slot
connectors mounted on the back plane board. The charts
below show the pin numbering on the expansion slot
connectors.
Expansion Slot Connector Pinouts:
Pin
#
l/O
Type:
Signal
Name:
A-l
A-2
A-3
A-4
A-5
A-6
A-7
A-8
A-9
A-10
A-11
A-12
A-13
A-14
A-15
A-16
A-17
A-18
A-19
A-20
A-21
A-22
A-23
A-24
A-25
A-26
A-27
A-28
A-29
A-30
A-31
Input
l/O
I/O
I/O
l/O
I/O
I/O
I/O
I/O
Input
output
I/O
I/O
I/O
I/O
I/O
l/O
I/O
l/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
l/O
I/O
I/O
I/O
-I/O CH CK
SD7
SD6
SD5
SD4
SD3
SD2
SD1
SD0
-l/O CH RDY
AEN
SA19
SAI 8
SA17
SA16
SA15
SA14
SA13
SA12
SAl 1
SAlO
SA9
SA8
SA7
SA6
SA5
SA4
343
SA2
SAl
SAO
Connector Pinouts D-5
Expansion Slot Connector Pinouts
(continued):
Pin
#
l/O
Type:
B-l
B-2
B-3
B-4
B-5
B-6
B-7
B-8
B-9
B-IO
B-11
B-12
B-13
B-14
B-15
B-16
B-17
B-18
B-19
B-20
B-21
B-22
B-23
B-24
B-25
B-26
B-27
B-28
B-29
B-30
B-31
Ground
output
Power
Input
Power
Input
Power
Input
Power
Ground
output
output
I10
I/O
output
Input
output
Input
I/O
output
Input
Input
Input
Input
Input
output
output
output
Power
output
Ground
D-6 Connector Pinouts
Signal
Name:
GND
RESET DRV
+5 VDC
IRQ9
-5 VDC
DRQ2
-12 VDC
ows
+I2 VDC
GND
-SMEMW
-SMEMR
-IOW
-IOR
-DACK3
DRQ3
-DACKl
DRQl
-REFRESH
CLK
IRQ7
IRQ6
IRQ5
IRQ4
IRQ3
-DACK2
T-C
BALE
+5 VDC
osc
GND
Expansion Slot Connector Pinouts
(continued):
Connector Pinouts D-7
