USER MANUAL
Alpha-Numeric Display Pager
MODEL : AL-924e
Control Buttons ........................................ 1
Features and Functions ............................. 2-3
LCD Display .............................................. 4
Function Operation..................................... 5-20
5
6
7
8
9
10
11
13
14
15
16
17
19
20
21
22
23
24
25
26
CONTENTS
Reading a Message .........................................
Locking Message .............................................
Unlocking Message ..........................................
Deleting .............................................................
Deleting All ........................................................
Add to Personal Memo ...................................
Setting Alert .......................................................
Pager On / Off ..................................................
Setting Auto Sleep ............................................
Setting Alarm .....................................................
Setting Time And Date ......................................
Setting Scroll ....................................................
Setting Zoom In Or Zoom Out ...........................
Reading The Mail Drop ....................................
Moving The Cursor ..........................................
Reading The Personal Message.......................
Reading The Full Message .............................
Backlighting / Duplicate ..................................
Error Message / Battery Gauge ........................
Set Mail Drop Alert .............................................
Control Buttons
MODEL:AL924e
Read Button
Select Button
Read Button
- to read message
- to turn on back-light
- to turn on power
- to activate the function
Select Button
- to move the cursor
- to read message by
cycles
Function Button
- to display the function
menu
- to adjust the time and date
change
- to enable the function
mode
Control Buttons
Function Button
1
Features and Functions
4-Line , 84 English Alpha Character Memory
Easy-To-Read Back-Lit Display
Up To Memory Capacitity 32,000 Characters.
16 Memory Slots + Message Full 10 sets
Personal Message Memory : 20 sets , Mail Drop Available
Show Time Of Day And Date
User Selectable 12 / 24 Hour Clock
Message Date And Time Stamping
Incomplete Massage-In Indication
Duplicate Message Indicator
Locks Important Message (Up To 10 Sets)
All Or Individual Message Delete
Unread Message Indicator , Reminder Alert
Features and Function
7
7
7
7
7
7
7
7
7
7
7
7
7
2
7
7
7
7
7
7
7
7
7
Low Battery Alert , Low Battery Indicator
Zoom The Display - To Enlarge Message For Easy
Read ability
Message Full Indication , Message Full Auto Storage
Message Preview For A Quick Look At Each Message
Message Move to Memo ( User selectable )
Service Area Indication
5 Built-In Alarm Clock
4 Beep Alerts / Silent Vibration / Silent then Beep / 8
Musical / Sleep Mode
Private Time - For The Ability To Turn Off All Pager
Alerts During Pre-Selected Times
Mail Drop Alerts
Save Message When Off And When Changing Battery
Features and Function
7
7
3
LCD Display
Message Status Symbols
Function Menu Symbols
POWER ON INDICATOR
MESSAGE IN MEMORY
UP OR ESCAPE
MUSIC ALERT
MESSAGE SELECTING
SET ALERT
BEEP ALERT
MESSAGE LOCK IN MEMORY
PAGER OFF
AUTO SLEEP INDICATOR
MESSAGE LOCK SELECTING
SET AUTO SLEEP
ALARM INDICATOR
PERSONAL MESSAGE
SET ALARM
AUTO SCROLL INDICATOR
FULL MESSAGE
SET TIME
BATTERY CAPACITY
PERSONAL MESSAGE SELECTING
SET SCROLL
OUT OF RANGE INDICATOR
FULL MESSAGE SELECTING
ZOOM IN / ZOOM OUT
ERROR MESSAGE
MAILDROP IN MEMORY
MESSAGE LOCK
DUPLICATE MESSAGE
MAILDROP SELECTING
MESSAGE DELETE
MAIL DROP MESSAGE
DELETE ALL
MEMO MESSAGE INDICATOR
MOVE TO MEMO
MAIL DROP ALERT
LCD Display
Pager Status Symbols
4
Receiving And Reading Your Message
A flashing symbol indicates you
have a message has not been
read.(The symbol of mail drop
shows on screen by flashing).
F
Press
once, to preview the
message.
F
Press
, to display your
message.,Press
once, to view
the next screen.
j
If you have set " Auto Scroll " ,
your pager will scroll through
your message screen by screen
automatically .
Reading Your Message
F
5
Locking Messages
F Press
, to move the cursor to
the desired flashing symbol. .
, press
once to select
the desired message to lock.
F Press , to lock the message. .
F The symbol
is displayed ,
indicating the status of the
message in memory.
Locking Message
F Press
6
Unlocking Messages
F Press
, to move the cursor to
select the message to unlock.
, then , press
once,
to " MESSAGE UNLOCK " Mode.
F Press
, to unlock the message.
Unlocking Message
F Press
7
Deleting Messages
F Press
F Press
, press
once , to
display " MESSAGE DELETE "
Mode.
F When " MESSAGE DELETE ? " is
displayed on the screen , press
to delete the message.
Deleting Message
, to move the cursor to
select the message you desire.
Press
to read the message.
8
Deleting All Messages
F When " DELETE ALL ? " is
displayed , Press
,all unlocked
and read messages are now
deleted.
Deleting All Message
( All unlocked and read messages )
F Press
, press
again , to "
DELETE ALL " Mode .
9
Move Message To Memo
, to move the cursor to
the desired storing message.
Press
to read the message.
F Press
, and press
once, to
move to " MOVE TO MEMO "
F Press
, to move the flashing
icon message automatically into
your personal mail .
Add Message To Memo
F Press
10
Setting The Alert
Press , then , press
once
to display " SET ALERT " Mode .
F
Press , to enable "SET
ALERT".
F
Press , to move the cursor to
the desired alarm mode .( Alert
/ Musical
/ Vibration
Sleep
are optional )
/
F
Press , to move to the cursor
to the desired tone or music .
F
Press
setting the alert is
completed.
Setting The Alert
F
11
Setting The Alert
The symbol is displayed if
the message receiver is in the
audible mode .
F
The symbol won't display
on screen if the receiver is in
the silent mode or sleep
mode.
Setting The Alert
F
12
Turning Your Pager Off
F Press
F Press
, till " PAGER OFF ? "
appears on the screen.
F Press , to turn the pager off .
F After turning your pager off , the
screen is empty.
F Press
on.
, to turn the pager power
Setting The Pager Off
, then , press
again
to " PAGER OFF " mode.
13
Setting Auto Sleep Mode
Press , then, press
Auto Sleep " mode.
to display "
F
Press , to enable " Auto Sleep Set
" Mode.
F
Press , to select "open" or "close"
(symbol or ) and adjust the
digits, press
for moving the cursor.
F
Press
setting auto sleep mode is
completed. The screen returns to
stand-by status.
F
is displayed when the Auto Sleep
mode is set.
F
The enable
symbol indicates
your pager is during setting status.
Setting Auto Sleep Mode
F
14
Setting The Alarm ( 5 alarms )
F Press
Setting The Alarm
, then , press
to
"SET ALARM "Mode.
F Press , to enable or disable
the alarm.
F Press , to move the cursor to
set the alarm status either alarm
enabled , alarm disabled or set
time.
F Press
setting the alarm is
completed.
15
Setting The Time And Date
, then , press once until
"SET TIME " Mode is displayed.
F Press
F Press
, to enable set time. .
, to move the cursor to the
hour / minute digit .Then , press ,
F to adjust each set of digits : AM/
PM/24 hr / month / day.
F Press
to activate the time and
date change.
Setting The Time And Date
F Press
16
Setting Scroll
Press
, then , press
SCROLL " Mode .
F
Press
, to enable scroll
automatically.
F
Press
scroll.
(1)
(2)
, to select the speeding of
-- slow.
-- normal.
(3)
(4)
, to " SET
-- rapid.
Setting Scroll
F
-- off
F
17
Setting Scroll
F
F
Press
to activate the function.
When the Auto scroll is set, the
symbol is displayed on screen.
Setting Scroll
18
Setting Zoom In / Zoom Out
Press
,then press
, to "ZOOM
IN".(symble
), Then, press
to
confirm..
F
The letters on screen enlarge and
become two lines to read.
F
Or press
to move the cursor
again to " ZOOM OUT " (symble
), and press
to complete.
F
The letters on screen change to four
lines to read.
Setting Zoom In / Out
F
19
Reading Mail Drop
Press
twice , to move the
flashing icon in the second row.
F
Press
, to read message or
press
, to move the icon to the
desired Mail drop.
j
The features allows 15 sets Mail
Drop
Reading Maildrop
F
20
Moving the Cursor
Press to move cursor to the
icon flashes,indicating the present
position of the message you are
going to read.
.
F
Press , the screen shows " UP
OR ESCAPE ".
F
Press once, the flashing icon can
be move to the top row or the
second row.,such like "MAIL DROP
AREA"or"MESSAGE AREA".
F
Press , the pager returns to
standby mode.
Moving the Cursor
F
21
Reading Personal Message
, to move the flashing
icon to the symbol.
F Press , to read message.
F When the symbol is shown in
the top left-hand corner of the
display , indicates the message
status as a personal message.
Reading Personal Message
F Press
22
Reading Full Message
, to move the flashing
icon to the
symbol.
F Press , to read message.
F When the
symbol is shown
in the top left-hand corner of the
display , indicates the message
status as a full message.
Reading Full Message
F Press
23
Backlighting
Duplicate Message
The pager automatically covers by
the latest messages if it is
received the same message.
The
symbol is shown in the
top left-hand corner of the display
, indicates the message status as
a "Duplicate Message".
Backlight / Duplicate
You can manually activate the back-lit at any time by pressing
and holding
for three seconds . If no other buttons are
pressed, the back-lit automatically turns off when the pager
returns to the standby mode .
24
If it is received the error message.
The
symbol is shown in the top
left-hand corner of the display ,
indicates the message status as a
Error message.
Battery Gauge
The battery indicator is located on the
status screen and keeps you inforned
of battery energy level. The three
indicators range from
(full),
(1/2),
(low). Whenever the low
battery shows on display, Please
replace the new battery in to make
sure the pager is in receivable
condition.
Error Message / Battery Gauge
Error Message
25
Set Mail Drop Alert
F To move the cursor to the Mail
Set Mail Drop Alert
Drop.
F Press
, to display the
function menu.
F Press
, to move the cursor to
set mail drop alert ( ).
F Press
, to activate the
function .Or press
, to exit
the function .
26
RADIO DEVICES FOR USE IN HAZARDOUS LOCATIONS
Apollo paging receivers, model number AL-924 is suitable for use in
hazardous locations, Class I, Division 2, Groups A, B, C, and D when one
self-contained 1.5V, "AAA" alkaline battery. Maximum Ambient - 60 °C .
UL Approval labels are attached to the AL-924 Pager to identify the unit
as being UL approval for use in hazardous locations.
Warning
Substitution of components may impair suitability for Class I,
Division 2.
Do not disconnect or change battery unless the area is known to
be Non-Hazardous. Contact sparking may occur while installing
or removing accessories and cause an explosion or fire.
Do not disassemble a UL Approval Product unit in any way that
exposes the internal electrical circuits of the unit.
Do not operate a UL Approval Product in a hazardous
atmosphere. If it has been physically damaged ( for example,
cracked housing). An explosion or fire may result.
* GL0 6 0 3 9 2 4 A2 4 *
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
