sp3800Guide.book Page 1 Monday, January 29, 2007 11:08 AM
Epson Stylus
®
Pro 3800
PRINTER GUIDE
sp3800Guide.book Page 2 Monday, January 29, 2007 11:08 AM
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed only for use with these Epson printers. Epson is not responsible for any use of this information as applied to other printers.
Trademarks
Epson and Epson Stylus are registered trademarks, and Epson UltraChromeK3 and Exceed Your Vision are trademarks of Seiko Epson Corporation.
UltraSmooth is a registered trademark, PhotoEnhance is a trademark, and Epson Preferred and Epson Store are service marks of Epson America, Inc.
General Notice : Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
The E NERGY S TAR emblem does not represent EPA endorsement of any product or service.
Legal Notices
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
© 2006 Epson America, Inc. 10/06 CPD-22652
2
sp3800Guide.book Page 3 Monday, January 29, 2007 11:08 AM
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC
Certification of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
For Canadian Users
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
3
sp3800Guide.book Page 4 Monday, January 29, 2007 11:08 AM
4
sp3800Guide.book Page 5 Monday, January 29, 2007 11:08 AM
Contents
Introduction
Warnings, Cautions, Notes, and Tips . . . . . . . . . . . . . . . . . . . . . . . . 9
Macintosh System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Windows System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Options and Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Ink Cartridge Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1 Setting Up the Printer On a Network
Connecting to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Configuring the Network Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing the Software for Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Adding the Printer in Mac OS X 10.4.x . . . . . . . . . . . . . . . . . . . . . 19
Adding the Printer in Mac OS X 10.3.9 . . . . . . . . . . . . . . . . . . . . . 20
Installing the Software for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adding the Network Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installing the Printer Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2 Handling Paper and Other Media
Selecting Media for Your Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Guidelines for Using Epson Media . . . . . . . . . . . . . . . . . . . . . . . . . 31
Choosing the Correct Paper Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Loading Paper in the Auto Sheet Feeder . . . . . . . . . . . . . . . . . . . . . . . . 35
Loading Paper Into the Rear Manual Feed Slot . . . . . . . . . . . . . . . . . . . 38
Loading Paper Into the Front Manual Feed Slot . . . . . . . . . . . . . . . . . . 40
Adjusting the Platen Gap for Thick or Thin Paper . . . . . . . . . . . . . . . . 44
Using Special Paper Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Creating a Paper Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Selecting a Paper Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5
5
sp3800Guide.book Page 6 Monday, January 29, 2007 11:08 AM
6 | Contents
3 Printing with Epson Drivers for Macintosh
Choosing Page Setup Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Choosing Basic Print Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Choosing Color Management and Paper Configuration Options . . . . . 55
Choosing Expansion Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Creating a Custom Preset and Printing . . . . . . . . . . . . . . . . . . . . . . . . . 58
Choosing Advanced Black and White Photo Settings . . . . . . . . . . . . . . 59
Managing Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Checking Ink and Maintenance Status . . . . . . . . . . . . . . . . . . . . . . . . . 62
4 Printing with Epson Drivers for Windows
Choosing Basic Print Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Choosing Paper and Layout Options . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Choosing Paper Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Choosing Layout Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Choosing Advanced Print Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Choosing Advanced Black and White Photo Settings . . . . . . . . . . . . . . 74
Managing Print Jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Managing Prints Using the Progress Meter . . . . . . . . . . . . . . . . . . . 76
Setting Monitoring Preferences and Optimizing Print Speed . . . . . 77
5 Maintaining and Transporting the Printer
Checking Printer Status and Part Life . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Printing Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Viewing Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Checking and Cleaning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . 84
Running a Power Cleaning Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Aligning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Replacing Ink Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Performing Additional Maintenance Tasks . . . . . . . . . . . . . . . . . . . . . . 93
Changing the Black Ink Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . 94
Changing the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Adjusting the LCD Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Using Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Replacing the Maintenance Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Cleaning the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
-6
sp3800Guide.book Page 7 Monday, January 29, 2007 11:08 AM
Contents | 7
Transporting or Storing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Preparing the Printer for Shipment . . . . . . . . . . . . . . . . . . . . . . . 101
Setting Up the Printer After Transportation . . . . . . . . . . . . . . . . . 101
Uninstalling and Reinstalling the Printer Driver . . . . . . . . . . . . . . . . . 102
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Updating Your Printer Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Downloading the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
6 Solving Problems
Diagnosing Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Checking Error Messages and Lights . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Improving Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Solving Operational Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Solving Miscellaneous Printing Problems . . . . . . . . . . . . . . . . . . . . . . 119
Solving Paper Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Paper Skews When Printing on Large Format Media . . . . . . . . . . 121
Paper Feed or Paper Jam Problems . . . . . . . . . . . . . . . . . . . . . . . . 121
A Specifications
Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Printable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Index
-7
sp3800Guide.book Page 8 Monday, January 29, 2007 11:08 AM
8 | Contents
-8
sp3800Guide.book Page 9 Monday, January 29, 2007 11:08 AM
9
Introduction
This Printer Guide provides basic information for using your printer.
It describes how to select and load paper, choose software settings for the best printing results, and install the printer software in a network environment. It also includes instructions for replacing your ink cartridges and performing other maintenance procedures, and how to troubleshoot problems.
•
•
•
For additional information, see the following:
The Start Here sheet explains how to set up your printer, install the software for a USB connection, and load paper. Be sure to follow these instructions to set up your printer correctly. If you are connecting the printer to a network, you also need to see Chapter 1 in this Printer Guide for software installation instructions.
The on-screen Network Guide on the CD-ROM describes how to set up and configure the printer for use on a network.
The on-screen User’s Guide on the CD-ROM provides complete information about your printer. You can read the guide using a web browser, such as Safari TM 1.0 or later, Mozilla ® FireFox ® 1.0 or later, or
Netscape ® Navigator ® or Microsoft ® Internet Explorer, versions 4.0 or later.
Warnings, Cautions, Notes, and Tips
These symbols are used in this book:
WARNINGS must be followed carefully to avoid bodily injury.
Cautions must be observed to avoid damage to your equipment.
Notes contain important information about your printer.
Tips contain additional hints on how to get the most out of your printer.
9
sp3800Guide.book Page 10 Monday, January 29, 2007 11:08 AM
10 | Introduction
Caution: Using an improperly shielded cable—especially a cable more than 10 feet long—may cause the printer to malfunction.
Note: USB 2.0 is required to allow the printer to run at full speed.
Macintosh System Requirements
•
•
•
•
•
•
•
To use your printer in either a stand-alone or peer-to-peer network environment, your Macintosh ® system should meet these requirements:
Mac OS X 10.3.9 to 10.4.x
PowerPC G5, Intel, or higher processor
At least 1GB of RAM (2GB or more recommended)
At least 100MB of free hard disk space to install the software and at least
30GB of free hard disk space for processing files
Quad-speed (4×) or faster CD-ROM or DVD drive for installing the printer software
For USB connection: a compliant USB Hi-Speed 2.0 port and a shielded USB “AB” cable from Series A (computer) to Series B (printer), up to 10 feet long
For network connection: Ethernet-equipped Macintosh and a compatible cable
Windows System Requirements
•
•
•
•
•
•
•
To use your printer in either a stand-alone or peer-to-peer network environment, your system should meet these requirements:
IBM ® -compatible PC with a Pentium ® 4, 2.1 GHz or higher processor recommended
Windows ® 2000, XP, or XP Professional x64 Edition
At least 1GB of RAM
At least 100MB of free hard disk space to install the software, and at least 20GB of free hard disk space for processing files
Quad-speed (4×) or faster CD-ROM or DVD drive for installing the printer software
For USB connection: a Windows-compliant USB Hi-Speed 2.0 port and a shielded USB “AB” cable from Series A (computer) to Series B
(printer), up to 10 feet long
For Ethernet connection: Ethernet-equipped PC and a compatible cable
10
sp3800Guide.book Page 11 Monday, January 29, 2007 11:08 AM
Introduction | 11
Tip: Check the Epson Pro
Graphics website at prographics.epson.com for accessories and options that are currently available.
Options and Supplies
Your Epson Stylus ® Pro 3800 offers these optional upgrades and supplies:
Option
One-year extended warranty
Two-year extended warranty
Replacement Ink Maintenance Cartridge
Ink cartridges
Photo Black
Cyan
Magenta
Yellow
Light Cyan
Light Magenta
Light Black
Matte Black
Light Light Black
Product code
EPP38B1
EPP38B2
T582000
T580100
T580200
T580300
T580400
T580500
T580600
T580700
T580800
T580900
You can purchase genuine Epson ® ink and paper from an authorized Epson reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766).
Or you can purchase online at www.epsonstore.com
(U.S. sales) or www.epson.ca
(Canadian sales).
11
sp3800Guide.book Page 12 Monday, January 29, 2007 11:08 AM
12 | Introduction
Tip: If you experience difficulty with the toll-free line or your
Unit ID number, call
(562) 276-1305.
Where To Get Help
Epson provides technical support and information on the installation, configuration, and operation of professional printing products through the
Epson Preferred Protection Plan. Dial (888) 377-6611, 6 AM to 6 PM ,
Pacific Time, Monday through Friday. Support hours and days are subject to change without notice.
Before you call, make sure you have your Unit ID number, which is included with the Epson Preferred Protection Plan information that came with your printer. You’ll also need your printer serial number and proof of purchase.
Epson also provides technical assistance 24 hours a day through the World
Wide Web. You can reach Epson’s support website at epson.com/support.
At this site, you can download drivers, firmware, and documentation, get
FAQs and troubleshooting advice, or e-mail Epson with your questions.
Important Safety Instructions
•
•
•
•
•
•
•
Before using your printer, read the following safety instructions to make sure you use the equipment safely and effectively.
The printer weighs about 43 pounds (20 kilograms) and should be lifted by two people.
When setting up the printer, make sure you leave enough space around it. You’ll need more space behind the printer if you print on large sheets of heavy stock or posterboard.
Place the printer on a flat, stable surface that is larger than the printer.
The printer will not operate properly if it is tilted or at an angle.
Avoid places subject to rapid changes in temperature and humidity. Also keep the printer away from direct sunlight, strong light, or heat sources.
Avoid places subject to shocks and vibrations.
Keep the printer away from dusty areas.
Place the printer near a wall outlet where the plug can be easily unplugged.
12
sp3800Guide.book Page 13 Monday, January 29, 2007 11:08 AM
Introduction | 13
Caution: Always turn off the printer using the
P Power button. When you press this button,
POWER OFF appears on the LCD panel. Do not unplug the printer or turn off the power to the printer until the panel shuts off. This ensures that the print head is safely capped.
•
•
•
•
•
•
•
•
•
•
•
•
If you use a stand for the printer, make sure it can support at least 43 lb
(20 kg)
Use only the type of power source indicated on the label.
Use only the power cord that comes with the printer. Use of another cord may result in fire or electric shock.
The printer’s power cord is designed for use with the printer only. Using it with other equipment may result in fire or electric shock.
Do not use a damaged or frayed power cord.
If you use an extension cord with the printer, make sure the total ampere rating of devices plugged into the extension cord does not exceed the cord’s ampere rating. Also, make sure the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet’s ampere rating.
Do not block or cover the openings in the printer’s case.
Do not put your hand inside the printer or touch the ink cartridges during printing.
Do not move the print head by hand; otherwise you may damage the printer.
Do not insert objects through the slots. Take care not to spill liquid on the printer.
Do not attempt to service the printer yourself.
Turn off the printer by pressing the P Power button, unplug the printer, and refer servicing to qualified service personnel under the following conditions:
The power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the cabinet damaged; the printer does not operate normally or exhibits a distinct change in performance.
13
sp3800Guide.book Page 14 Monday, January 29, 2007 11:08 AM
14 | Introduction
Caution: Do not shake cartridges that have been installed previously with too much force.
•
•
•
•
•
•
•
•
•
•
•
Ink Cartridge Safety Instructions
Keep ink cartridges out of the reach of children and do not drink the ink.
Store ink cartridges in a cool, dark place.
If ink gets on your skin, wash it off with soap and water. If ink gets in your eyes, flush them immediately with water.
Shake an ink cartridge well before installing it for best results.
Do not use an ink cartridge beyond the date printed on the cartridge carton.
Use up the ink cartridge within six months of installation for best results.
Do not dismantle the ink cartridges or try to refill them. This could damage the print head.
After bringing an ink cartridge inside from a cold storage site, allow it to warm up at room temperature for at least three hours before using it.
The IC chip on the ink cartridge retains a variety of cartridge information, which allows you to remove and reinsert it freely.
However, each time the cartridge is inserted, some ink is consumed because the printer automatically performs a reliability check.
If you remove an ink cartridge for later use, protect the ink supply area from dirt and dust, and store it in the same environment as this product.
Do not touch the ink supply port or its surrounding area and the green
IC chip on the side of the ink cartridge. Doing so may affect normal operation and printing.
14
sp3800Guide.book Page 15 Monday, January 29, 2007 11:08 AM
15
Chapter 1:
Setting Up the Printer On a Network
•
•
•
If you are using the printer on a network, follow the instructions in this chapter to:
Connect the printer to the network
Configure the network interface
Install the printer software
To connect the printer directly to your computer’s USB port, see the
Start Here sheet.
Connecting to the Network
Make sure you have the correct cable for connecting the printer. To connect to a network switch or hub, you need a standard RJ-45 “straight-through” network cable. To connect directly to your computer’s network interface, you need an RJ-45 crossover cable.
1. Turn off the printer.
2. Connect one end of the appropriate cable to the printer’s Ethernet port.
Then connect the other end to your network switch or hub or your computer’s Ethernet port.
3. Turn on the printer.
Once the printer is connected to your network, you need to configure it. See
“Configuring the Network Interface” on page 16 for instructions.
15
sp3800Guide.book Page 16 Monday, January 29, 2007 11:08 AM
16 | Setting Up the Printer On a Network
Note: If you don’t know which setting to use, see your network administrator for help configuring the printer’s IP settings.
Configuring the Network Interface
1. Make sure that the printer is turned on and the LCD displays READY .
2. Press the Menu r button on the printer’s control panel to enter the printer’s menu system.
3. Press d to highlight NETWORK SETUP , then press r .
4. Press r then d to highlight ENABLE.
5. Press Enter. An asterisk appears next to ENABLE to show that it’s selected.
6. Press l then d to highlight IP ADDRESS SETTING .
7. Press r and then u or d to choose one of the following IP configuration settings:
• AUTO: Select this setting if your network uses a DHCP server to configure your network devices’ IP settings automatically.
• PANEL: Select this setting if you would like to configure the printer’s IP settings manually.
8. Press Enter. An asterisk appears next to the setting you selected.
9. Press l to go back. Then do one of the following:
•
•
If you selected AUTO as the IP ADDRESS SETTING, press the
+ Cancel button to exit the printer menu. Then continue with
If you selected PANEL as the IP ADDRESS SETTING, continue
10. Press d to highlight IP, SM, DG SETTING , then press r . The LCD displays the IP ADDRESS .
11. Press u or d to change each octet value, then press r to select the next octet. When you have changed the value of the last octet, press r . The
LCD displays the SUBNET MASK .
1-16
sp3800Guide.book Page 17 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 17
12. Press u or d to change each octet value, then press r to select the next octet. When you have changed the value of the last octet, press r . The
LCD displays the DEFAULT GATEWAY .
13. Press u or d to change each octet value, then press r to select the next octet. When you have changed the value of the last octet, press Enter, then press the
+
Cancel button to exit the printer menu.
14. Turn the printer off then back on again.
15. Make sure that the printer displays READY and that you have at least three sheets of plain, letter-size paper loaded in the printer’s auto sheet feeder. Then press the Menu r button to enter the printer menu.
16. Press d to highlight TEST PRINT , then press r
.
17. Press d to highlight NETWORK STATUS SHEET , then press r
.
18. Press Enter to print the network status sheet and verify that the IP
address settings are correct. Then see “Installing the Software for
Macintosh” below, or “Installing the Software for Windows” on page 22.
Note: You can check for a newer version of your printer driver on the
Epson support site at epson.com/support.
Installing the Software for Macintosh
1. Turn on your Macintosh and your printer.
2. Insert the printer software CD-ROM. If necessary, double-click the
Epson CD-ROM icon to open its window.
3. Double-click the Epson installer icon.
1-17
sp3800Guide.book Page 18 Monday, January 29, 2007 11:08 AM
18 | Setting Up the Printer On a Network
4. Double-click User’s Guide and Network Guide and wait while the guides are installed.
5. Double-click Stylus Pro 3800 Driver .
6. Enter your password and follow the on-screen instructions to install your software.
7. Enter your password again and follow the on-screen instructions to install the EPSON LFP Remote Panel.
8. Enter your password again and follow the on-screen instructions to install EpsonNet Config.
9. Restart your Macintosh when prompted.
10. Click Exit to close the installer.
Remove the printer software CD-ROM and continue with the instructions
on page 19 for Mac OS X 10.4.x or page 20 for Mac OS X 10.3.9 to add
your printer.
1-18
sp3800Guide.book Page 19 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 19
Adding the Printer in Mac OS X 10.4.x
1. Open the Applications folder, then open the Utilities folder and start the Printer Setup Utility .
2. If you see a message like this, click Add , then skip to step 4.
3. Click the Add icon at the top of the Printer List window.
1-19
sp3800Guide.book Page 20 Monday, January 29, 2007 11:08 AM
20 | Setting Up the Printer On a Network
You see your printer in the Printer Browser:
Tip: If you want to rename the printer for easier identification, enter a new name for it in the
Name field on this screen.
Note: If your Macintosh cannot find the printer, click More Printers and select the appropriate interface.
4. Select your printer, then wait while your Macintosh finds the printer driver and the Add button becomes available. Then click the Add button.
Your printer appears in the Printer List window.
5. Close the Printer Setup Utility.
Adding the Printer in Mac OS X 10.3.9
1. Open the Applications folder, then open the Utilities folder and start the Printer Setup Utility .
2. If you see a message like this, click Add , then skip to step 4.
1-20
sp3800Guide.book Page 21 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 21
3. Click the Add icon at the top of the Printer List window.
4. Select EPSON AppleTalk in the pull-down menu. Your printer appears on the screen.
Pull-down menu
Tip: If you want to rename the printer for easier identification, select the printer name in the list and click Show
Info . Type a new name and click Apply Changes .
5. Select your printer, then click the Add button.
Your printer appears in the Printer List window.
6. Close the Printer Setup Utility.
1-21
sp3800Guide.book Page 22 Monday, January 29, 2007 11:08 AM
22 | Setting Up the Printer On a Network
Installing the Software for Windows
For Windows, you need to add the printer’s network port, then install the printer software.
Adding the Network Port
1. Turn on your computer and your printer.
2. Do one of the following:
• Windows XP: Click Start , Control Panel , Printers and Other
Hardware , and Printers and Faxes .
• Windows 2000: Click Start , Settings , and Printers .
You see the Printers and Faxes or Printers window:
1-22
sp3800Guide.book Page 23 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 23
3. Open the File menu and select Server Properties . You see a window like this one:
4. Click the Ports tab, then click Add Port .
1-23
sp3800Guide.book Page 24 Monday, January 29, 2007 11:08 AM
24 | Setting Up the Printer On a Network
5. Select Standard TCP/IP Port , then click New Port .
6. When you see this Port Wizard window, click Next .
1-24
sp3800Guide.book Page 25 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 25
7. Do one of the following:
• If your network uses a DHCP server to configure your network devices’ IP settings automatically, enter the printer’s Print Server
Name (shown on page two of the network status sheet) in the
Printer Name or IP Address text box. Then click Next .
• If you configured the Printer’s IP settings manually, enter the printer’s IP Address (shown on page one of the network status sheet) in the Printer Name or IP Address text box. Then click Next .
1-25
sp3800Guide.book Page 26 Monday, January 29, 2007 11:08 AM
26 | Setting Up the Printer On a Network
8. Make sure that Standard and Generic Network Card are selected, then click Next .
9. Verify that the Device matches the Print Server Name or IP Address shown on the network status sheet, then click Finish .
10. Click the Close button to close all the open windows on your screen.
Now continue with “Installing the Printer Software” on page 27.
1-26
sp3800Guide.book Page 27 Monday, January 29, 2007 11:08 AM
Setting Up the Printer On a Network | 27
Installing the Printer Software
1. Insert the printer software CD-ROM.
2. The installer starts automatically.
(If necessary, double-click My Computer or click Start , then
My Computer . Then double-click your CD-ROM icon to start the installer.)
3. Double-click Stylus Pro 3800 Driver for Ethernet .
4. When you see a window like this one, click Manual .
1-27
sp3800Guide.book Page 28 Monday, January 29, 2007 11:08 AM
28 | Setting Up the Printer On a Network
5. Select the network port you created for the printer, then click OK .
6. When you see a message that driver installation and printer configuration were completed successfully, click OK .
7. The EPSON LFP Remote Panel begins installing. Follow the on-screen instructions.
8. Double-click User’s Guide and Network Guide and wait while the guides are copied to your desktop.
9. Click Exit to close the installer, then remove the printer software
CD-ROM.
1-28
sp3800Guide.book Page 29 Monday, January 29, 2007 11:08 AM
Chapter 2:
Handling
Paper and
Other Media
The Epson Stylus Pro 3800 prints on a variety of cut-sheet media up to
17 inches wide. You can also use heavy stock, such as posterboard, up to
59 mil (1.5 mm) thick.
•
•
•
•
•
•
•
This chapter includes the following information:
Selecting media for your printer
Choosing the correct paper path
Loading paper in the auto sheet feeder
Loading paper in the rear manual slot
Loading paper in the front manual slot
Adjusting the platen gap
Creating special paper configurations
Selecting Media for Your Printer
You can print on most types of coated, glossy, and plain paper. The following table shows the Epson paper types and sizes you can use in your printer. You can also check the Epson Pro Graphics website
(prographics.epson.com) or your authorized Epson dealer for available media.
Paper type
Epson Presentation Paper Matte
Epson Photo Quality Ink Jet Paper
Size
8.3” × 11. 7”
8.5” × 11”
8.5” × 14”
11” × 17”
13” × 19”
16.5” × 23.4”
17” × 22”
Number of sheets
100
100
100
100
100
30
100
Part number
S041061
S041062
S041067
S041070
S041069
S041079
S041171
29
29
sp3800Guide.book Page 30 Monday, January 29, 2007 11:08 AM
30 | Handling Paper and Other Media
Paper type
Epson Premium Photo Paper Luster
Epson Premium Luster Photo Paper
Size
8.5” × 11”
11.7” × 16.5”
13” × 19”
Epson Premium Photo Paper Glossy
Epson Premium Glossy Photo Paper
17” × 22”
4” × 6”
Epson Premium Photo Paper Semi-gloss
Epson Premium Semigloss Photo Paper
5” × 7”
8” × 10”
8.5” × 11”
11” × 14”
11” × 17”
11.7” × 16.5”
13” × 19”
17” × 22”
4” × 6”
8.5” × 11”
13” × 19”
8.5” × 11” Epson Ultra Premium Presentation
Paper Matte
Epson Enhanced Matte Paper
11.7” × 16.5”
13” × 19”
Epson Proofing Paper Commercial
Semimatte
Epson Watercolor Paper - Radiant White
17” × 22”
13” × 19”
13” × 19”
20
20
50
250
20
20
25
40
50
50
100
50
100
Number of sheets
50
250
50
50
100
Part number
S041405
S041913
S041406
S041407
S041604
20
50
20
20
25
40
S042084
S041808
100 S041727
20 S041464
S041465
S041667
S041466
S041290
S041288
S041289
S042092
S041982
S041331
S041327
S041341
S041914
S041343
S041339
S041605
S041908
S041744
20 S041351
2-30
sp3800Guide.book Page 31 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 31
Paper type
Epson Velvet Fine Art Paper
Epson UltraSmooth ® Fine Art Paper
Epson Singleweight Matte Paper
Size
8.5” × 11”
13” × 19”
17” × 22”
13” × 19”
17” × 22”
13” × 19”
17” × 22”
Number of sheets
20
20
25
25
25
100
100
Part number
S041636
S041637
S042097
S041896
S041897
S041747
S041907
Always test samples of paper stock in the printer before purchasing large quantities or printing large jobs. When you use non-Epson paper or other media, you may need to adjust various settings or create special paper
configurations. (See page 45 for more information.)
Guidelines for Using Epson Media
•
•
•
•
Follow these guidelines, as well as those included in your paper package, when printing on Epson paper and other media:
Avoid touching the printable surface with your bare hands. Fingerprints may affect print quality. Handle media by the edges or use cotton gloves.
Always choose the correct Media Type setting in your printer driver
software before you send your job. See page 53 (Macintosh) or page 66
(Windows) for instructions.
Always select the correct paper source in both the printer driver software
and on the printer’s control panel. See page 50 (Macintosh) or page 68
(Windows) for instructions on selecting the paper source in your printer software.
Keep unused media in its original packaging and store it flat in a cool, dry place to maintain quality. Avoid storing your printouts where they will be exposed to high temperature, humidity, or direct sunlight.
2-31
sp3800Guide.book Page 32 Monday, January 29, 2007 11:08 AM
32 | Handling Paper and Other Media
Choosing the Correct Paper Path
•
The printer provides three paths for loading media:
Auto sheet feeder
(multiple sheets)
• Rear manual feed slot
(one sheet only)
• Front manual feed slot
(one sheet only)
It’s very important to use the correct paper path and to load the correct number of sheets. For example, you can load only one sheet at a time in the front and rear slots, and poster board can be inserted only in the front slot. If you need to make sure the paper stays flat, use the rear manual slot or the front slot.
2-32
sp3800Guide.book Page 33 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 33
Paper type
The following table shows which path to choose for the type of media you are using and the maximum number of sheets you can load for the different types of special Epson media. The letter A stands for the auto sheet feeder,
R stands for the rear manual feed slot, and F stands for the front manual feed slot.
Paper path Size
Plain paper
Epson Presentation Paper Matte
Epson Photo Quality Ink Jet Paper
Epson Premium Photo Paper Glossy
Epson Premium Glossy Photo Paper
Epson Premium Photo Paper Luster
Epson Premium Luster Photo Paper
Epson Premium Photo Paper Semi-gloss
Epson Premium Semigloss Photo Paper
A
A, R, F
A, R
A
A, R, F
A, R
A, R, F
A,R
A
A, R, F
8.5” × 11”
8.3” × 11. 7”
8.5” × 11”
8.5” × 14”
11” × 17”
13” × 19”
16.5” × 23.4”
17” × 22”
4” × 6”
5” × 7”
8” × 10”
8.5” × 11”
11” × 14”
11” × 17”
11.7” × 16.5”
13” × 19”
17” × 22”
8.5” × 11”
11.7” × 16.5”
13” × 19”
17” × 22”
4” × 6”
8.5” × 11”
13” × 19”
10
10
10
20
10
10
10
20
20
10
20
20
10
10
20
20
20
20
60
50
20
20
Auto sheet feeder loading capacity *
120
60
2-33
sp3800Guide.book Page 34 Monday, January 29, 2007 11:08 AM
34 | Handling Paper and Other Media
Paper type Paper path
Epson Ultra Premium Presentation
Paper Matte
Epson Enhanced Matte Paper
A, R, F
Epson Proofing Paper Commercial
Semimatte
Epson Singleweight Matte Paper
A, R
A, R, F
Epson Watercolor Paper - Radiant White
Epson Velvet Fine Art Paper
R
R
A, R, F
A, R
Epson UltraSmooth Fine Art Paper R
* Always load only 1 sheet at a time in the front or rear slot.
Size
8.5” × 11”
11.7” × 16.5”
13” × 19”
17” × 22”
13” × 19”
13” × 19”
17” × 22”
13” × 19”
8.5” × 11”
13” × 19”
17” × 22”
13” × 19”
17” × 22”
1
1
1
1
1
1
50
10
10
10
1
Auto sheet feeder loading capacity *
20
20
2-34
sp3800Guide.book Page 35 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 35
Loading Paper in the Auto Sheet Feeder
Using the auto sheet feeder, you can load up to 120 sheets of plain paper and varying amounts of special media types. Refer to the table starting on
page 33 to see how many sheets you can load for your paper type. Then
follow these steps:
1. Make sure the printer is turned on and READY appears on the LCD.
2. Flip up the paper guide and pull out as many of its extensions as you need to support your paper size.
3. Press the front cover to release it and open the output tray.
2-35
sp3800Guide.book Page 36 Monday, January 29, 2007 11:08 AM
36 | Handling Paper and Other Media
4. Use both hands to pull out and extend the output tray, lifting it slightly as you pull. Make sure the arrow marks on the tray and the printer are aligned.
5. Pull out the output tray extensions to accommodate your paper size.
6. Squeeze the left edge guide and slide it to the left so that it is slightly wider than the width of your paper.
7. If you are loading multiple sheets, thumb through the stack of paper, then gently tap it on a flat surface to even the edges.
2-36
sp3800Guide.book Page 37 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 37
If the paper is curled, flatten it before you load it. If it curls excessively
and jams frequently, see page 121 for solutions.
8. Load the paper against the right edge, face-up and short edge first. Insert it until it meets resistance. Slide the edge guide against the left side of the paper.
Caution: Do not leave paper in the printer for a long period of time; its quality will deteriorate.
Epson recommends that you remove the paper from the printer after printing.
You’re ready to print.
If the paper skews when you’re printing on large sheets, flip out the edge guide located on the right side of the auto sheet feeder to help the paper feed straight.
2-37
sp3800Guide.book Page 38 Monday, January 29, 2007 11:08 AM
38 | Handling Paper and Other Media
Loading Paper Into the Rear Manual Feed Slot
Use the rear manual slot to load special media one sheet at a time. (See the
table on page 33 for a list of papers you can load in the rear slot.)
1. Make sure the printer is on and READY appears on the LCD.
2. Attach the rear sheet guide to the back of the printer.
3. Slide the edge guide to the left so it is slightly wider than the width of your paper.
2-38
sp3800Guide.book Page 39 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 39
4. Insert one sheet face-up and short edge first into the rear sheet guide against the right edge guide.
5. Slide the edge guide against the left edge of the paper.
Note: If you want to remove the paper, press the d Paper feed button on the control panel to back out the sheet.
6. Gently guide the paper into the slot until it meets resistance. Maintain a constant pressure; after a few seconds you’ll feel the printer pull the paper into printing position.
2-39
sp3800Guide.book Page 40 Monday, January 29, 2007 11:08 AM
40 | Handling Paper and Other Media
7. Use both hands to pull out and extend the output tray, lifting it slightly as you pull. Make sure the arrow marks on the tray and the printer are aligned.
Caution: Do not leave paper in the printer for a long period of time; its quality will deteriorate.
Epson recommends that you remove the paper from the printer after printing.
You’re ready to print.
Loading Paper Into the Front Manual Feed Slot
Use the front manual feed slot when you need to print on thick media
(1.2 to 1.5 mm), such as posterboard. Make sure there is enough space behind the back of the printer for the paper to feed without obstruction.
2-40
sp3800Guide.book Page 41 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 41
•
•
•
Also keep the following in mind when using the front slot:
Load only one sheet at a time and make sure the printable side is face-up.
If the paper is wider than 16.5 inches, use the auto sheet feeder or rear
slot if allowed for your paper type; see page 32 for details.
If PAPER SIZE CHECK is set to OFF on the LCD, you cannot load paper in the front manual feed slot. Use the printer’s menu system to turn this setting on. (See your on-screen User’s Guide for more information.)
1. Make sure the printer is on and READY appears on the LCD.
2. Press the front cover to release it and open the output tray.
3. Press the front tray as shown to pop it out.
2-41
sp3800Guide.book Page 42 Monday, January 29, 2007 11:08 AM
42 | Handling Paper and Other Media
4. Insert a single sheet of paper, short edge first and face-up into the front tray.
5. Position the right edge of the paper against the right side of the tray and align the paper’s bottom edge with the white line on the tray.
2-42
sp3800Guide.book Page 43 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 43
6. Press the d Paper feed button to feed the paper into printing position.
7. Use both hands to pull out and extend the output tray, lifting it slightly as you pull.
Caution: Do not leave paper in the printer for a long period of time; its quality will deteriorate.
Epson recommends that you remove the paper from the printer after printing.
You’re ready to print.
When you finish printing, push the front tray back in.
2-43
sp3800Guide.book Page 44 Monday, January 29, 2007 11:08 AM
44 | Handling Paper and Other Media
Caution: To avoid damaging the printer, do not select the Narrow setting when you print on heavy media.
Adjusting the Platen Gap for Thick or Thin Paper
When you print on unusually thick or thin paper, you may need to adjust the platen gap setting. Normally, the STANDARD setting allows the printer to adjust automatically. However, if print quality is not satisfactory when using very thin or very thick stock, you may need to change this setting using the printer’s menu system.
1. Press the Menu r button.
2. Press r to select the Printer Setup menu.
3. Press r to select PLATEN GAP . An asterisk appears next to the current setting, STANDARD .
4. Press u or d to select NARROW , WIDE , WIDER , or WIDEST .
5. Press the Enter button to save the setting. An asterisk appears next to the selected setting.
6. Press the + Cancel button to exit the menu.
When you switch media again, don’t forget to change the setting back to
STANDARD.
If you’re printing on non-Epson media, you may also need to create a paper configuration to optimize your results. See the next section for more information.
2-44
sp3800Guide.book Page 45 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 45
Tip: It’s a good idea to keep a list describing your paper configurations.
Note: If you’re using
Epson special media, select STANDARD for the platen gap to let the printer automatically determine the paper thickness.
Using Special Paper Configurations
When you choose a media type in your Epson printer software, the driver automatically determines the best settings for your paper. However, you may want to fine-tune how the printer handles certain media—especially if you use non-Epson paper or a paper not supported by the driver. For these situations, you can create a special configuration, or group of settings, for each paper type (up to ten types) and select the desired configuration whenever you print on that particular stock.
Creating a Paper Configuration
To create a configuration for a specific paper type, make sure the paper you want to configure is loaded in the printer. Then follow these steps:
1. Press the Menu r button, then press d until CUSTOM PAPER is highlighted.
2. Press r to display the PAPER NUMBER menu.
3. Press u or d to select a paper configuration number (1 to 10). Press
Enter to save the setting.
4. Press r and then u or d to select MATTE THICK , MATTE THIN ,
PHOTO PAPER , or FINE ART PAPER .
5. Press Enter to save the setting. An asterisk appears next to the selected paper type.
6. Press l and then d to select PLATEN GAP , then press r .
7. Press u or d to select NARROW, STANDARD, WIDE, or WIDER .
(The STANDARD setting is recommended for most paper types.) Then press Enter to save the setting. An asterisk appears next to the selected platen gap setting.
8. Press l and then d to select THICKNESS PATTERN .
2-45
sp3800Guide.book Page 46 Monday, January 29, 2007 11:08 AM
46 | Handling Paper and Other Media
9. Make sure the paper you are creating the configuration for is loaded in the correct paper path in the printer. Then press r and Enter to print a paper thickness pattern. The printer prints a pattern similar to the following:
Smallest gap
10. Examine the printed pattern for the most evenly overlapping lines, and choose that pattern number. (In the example shown above, the lines of pattern 4 are the most even.)
11. After printing the pattern, THICKNESS NUMBER is displayed. Press d or u to select the number that you noted in step 7. Then press Enter to save the setting.
12. Press l and then d to select PAPER FEED ADJUST A , then press r .
Adjusting this setting and the PAPER FEED ADJUST B can help eliminate banding.
13. Press u or d to set the paper feed amount for the printable area (labelled A in the illustration), and then press Enter. Choose a lower value if you see white lines on your prints, or a higher value if you see dark lines.
14. Press l and then d to select PAPER FEED ADJUST B , then press r .
2-46
sp3800Guide.book Page 47 Monday, January 29, 2007 11:08 AM
Handling Paper and Other Media | 47
15. Press d or u to set the paper feed amount for the bottom margin area that is 0.79 or 1.18 inches (2 or 3 cm) from the bottom of the paper (labelled
B in the illustration to the right). Then press Enter.
16. Press l and then d to select DRYING TIME , then press r .
17. Press d or u to select the number of seconds (from 1 to 10) that you want the print head to wait between passes to allow the ink to dry. Then press Enter to save the setting.
18. When you are finished, press + Cancel to exit the Menu.
You can also make similar settings using the printer driver software. For
instructions, see page 55 (Macintosh) or page 73 (Windows).
Selecting a Paper Configuration
Once you have created a paper configuration, follow these steps to select it when you are ready to print on that type of paper:
1. Press the Menu r button, then press d until CUSTOM PAPER is highlighted.
2. Press d to display PAPER NUMBER , then press r .
3. Press d or u to select the configuration number that you want to use. If you select STANDARD , the printer uses the driver settings. If you select a number from 1 to 10, the control panel settings override the driver settings.
4. Press Enter. The configuration number you selected is displayed on the LCD.
5. Press + Cancel to exit the menu.
2-47
sp3800Guide.book Page 48 Monday, January 29, 2007 11:08 AM
48 | Handling Paper and Other Media
2-48
sp3800Guide.book Page 49 Monday, January 29, 2007 11:08 AM
49
Chapter 3:
Printing with
Epson Drivers for Macintosh
Tip: Check the Epson
Pro Graphics website at prographics.epson.com for updated drivers and utilities that may become available.
Your Epson Stylus Pro 3800 comes with drivers and utilities that let you print and manage print jobs. ICC profiles for ColorSync ® are included, so you can use the color management features in Adobe ® Photoshop ® or other applications, or in the driver itself. A color-managed workflow using
Photoshop will produce the most accurate colors and best photographic output for color photos.
For the best black-and-white photography output, the Epson Stylus Pro
3800 driver offers Advanced Black and White mode.
You can create your own profiles if you have the required hardware and software, or you can have them created by a color specialist. Make sure any profiles you want to use are located in the correct folder for your operating system. When you install the Epson printer driver, the included profiles are automatically copied to the correct folder.
•
•
•
•
•
•
•
This chapter includes the following information for Macintosh:
Choosing page setup settings
Choosing basic print settings
Choosing advanced print settings, including color management, paper configuration settings, and expansion settings
Creating a custom preset and printing
Choosing Advanced Black and White mode settings
Managing print jobs
Checking the printer status
49
sp3800Guide.book Page 50 Monday, January 29, 2007 11:08 AM
50 | Printing with Epson Drivers for Macintosh
Note: Many application settings override the printer’s page setup options. Always verify settings to get the results you expect.
If you need more information about print options, click the ? button.
Choosing Page Setup Options
Before you print, make sure you have installed the Epson printer driver and utilities from the printer software CD-ROM. You also need to set up the printer in the Printer Setup Utility. For instructions on installing and configuring the printer driver, see the Start Here sheet.
1. Open the file you want to print in your application.
2. Open the File menu and click Page Setup . You see a screen like this one:
Select Stylus Pro 3800
Note: If your application has margin settings, make sure they’re turned off for borderless printing.
Borderless printing takes longer than normal printing.
Borderless printing is not available when you use the front manual feed slot.
3. Open the Format for pop-up menu and select Stylus Pro 3800 .
4. Click the Paper Size pop-up menu and choose a size and option, then go to step 4.
Select a paper size, then choose an option, if available
3-50
sp3800Guide.book Page 51 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 51
• The standard size setting prints with 0.12 in. (3.0 mm) margins all around.
• Borderless (Auto Expand) enlarges your image up to 3% to fit the paper without borders. If too much of your image’s edges are cut
off, you can adjust the expansion setting as described on page 57.
• Borderless (Retain Size) prints your image at the size you specify in your application. You need to size your image slightly larger than the paper to print without borders.
• Manual - Rear prints with 0.12 in. (3.0 mm) margins all around.
• Manual - Front prints with 0.12 in. (3.0 mm) left and right margins and 0.79 in. (20 mm) top and bottom margins.
If your paper size is not listed, select Manage Custom Sizes to create a custom paper size.
You see a window like this one:
Click + to create a new paper size
Tip: To ensure that the image is centered on the page, make the top and bottom margins the same.
Click + , double-click Untitled , give your paper size a name, and define its size and margins. Then click OK , and select the newly created paper size from the Paper Size pop-up menu.
5. Choose the correct Orientation and Scale settings as necessary.
6. Click OK . Then continue with the instructions in the next section to select additional settings for printing.
3-51
sp3800Guide.book Page 52 Monday, January 29, 2007 11:08 AM
52 | Printing with Epson Drivers for Macintosh
Choosing Basic Print Options
Once you have selected your page setup options, you need to select printing options. The Epson driver offers automatic settings that optimize print quality and speed when you’re using Epson media. You can also choose advanced settings for more control over your printer and color management
options, as described on page 55.
1. Open the File menu and select Print . You see a screen like this one:
Select Stylus
Pro 3800
2. Open the Printer pop-up menu and select Stylus Pro 3800 , if necessary.
3. Select Print Settings from the pop-up menu.
You see a screen like this one:
3-52
sp3800Guide.book Page 53 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 53
Note: Check the Epson
Pro Graphics website at prographics.epson.com or your authorized Epson dealer for other media that may be available.
4. Select the Media Type that corresponds to the paper you are printing on. If you are using a color-managed workflow, make sure you choose media type and resolution settings that match the ICC profile you are using.
If your paper is not listed, check the instructions included with the paper, or look on the Epson Pro Graphics website at prographics.epson.com. If you are using non-Epson paper, choose the closest setting. You may have to experiment with different settings to determine which one is best for the media you’re using.
5. For the Color setting, select Color for any type of photographic printing. Choose Advanced B&W Photo to print black-and-white
photos on certain paper types; see page 59. (For paper types that don’t
support this option, print black-and-white photos with the Color setting.) Select Black only if you’re printing line drawings or other non-photographic images.
6. Set the Mode option as follows:
• Select Automatic to have the printer driver analyze the contents of your image or file and make the appropriate printing adjustments. If a Quality/Speed slider appears in the Mode box, set it according to the priorities of your print job.
You can choose one of the mode settings shown at the left:
EPSON Vivid produces vivid blue and green tones in printouts.
Because this setting reproduces blue and green tones that cannot be displayed by your monitor, your printouts may differ from the screen images.
Charts and Graphs intensifies colors and lightens the midtones and highlights of an image. Use this setting for presentation graphics, such as charts and graphs.
EPSON Standard (sRGB) increases the contrast in images. Use this setting for most color photographs.
Adobe RGB matches image colors to the Adobe RGB color standard.
3-53
sp3800Guide.book Page 54 Monday, January 29, 2007 11:08 AM
54 | Printing with Epson Drivers for Macintosh
Note: The Print Quality settings available depend on the Media Type you selected. Choose lower print quality for faster printing, or SuperPhoto -
2880dpi for best quality.
• Select Custom to choose one of the settings shown at the left.
Advanced Photo 2880 lets you print at 2880 dpi, the highest resolution available.
ColorSync applies color management based on the printer’s ICC profile using the perceptual rendering intent. In most cases, you will get better results by applying color management in your application
instead of the printer driver. See page 55 for details.
7. Select Advanced Settings to access additional options, as described below.
8. Choose one of the following Print Quality settings:
• Draft
• Normal - 360dpi
• Fine - 720dpi
• SuperFine - 1440dpi
• SuperPhoto - 2880dpi
9. Choose any of the following advanced options:
• High Speed for fast, bidirectional printing. For higher quality, make sure this option is not selected.
• Finest Detail for sharper edges on vector-based data including text, graphics, and line art.
• Flip Horizontal for printing a mirror image of your file. Use with backlight film.
Continue with the instructions in the next section to select color management settings. If you are using the color management settings in
Photoshop or another application, it is very important to turn off color management in the printer driver.
3-54
sp3800Guide.book Page 55 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 55
Choosing Color Management and Paper
Configuration Options
Follow these instructions to use color management in the printer driver. If necessary, you can also control the ink density by using the paper
configuration settings, as described on page 56.
1. Select Printer Color Management from the pop-up menu. You see a screen like this one:
2. Select one of the following settings:
• Color Controls to choose from four Color Adjustment modes and three Gamma settings. Click the arrow next to Advanced Settings to specify individual values for Brightness, Contrast, Saturation, and
CMY inks.
• ColorSync for mapping colors to your printer’s profile. In most cases, you will get better results by applying color management in your application, rather than in the printer driver. If you choose this setting, you can choose ColorSync from the pop-up menu and choose filters or other settings.
• Off (No Color Adjustment ) to disable color management in the printer driver. Choose this setting when you use a color-managed
sp3800Guide.book Page 56 Monday, January 29, 2007 11:08 AM
56 | Printing with Epson Drivers for Macintosh
3. If you are using non-Epson media and you need to fine-tune its performance, select Paper Configuration from the pop-up menu. You see a window like this one:
Note: You may need to change the Color Density setting if your custom color profile was created to optimize D-max and color gamut.
4. Select the correct settings to match your ICC profile. These settings override any paper configuration settings you may have made using the printer’s control panel.
• Color Density lets you control the ink saturation level (for example, when you turn off color management in your printer software).
• Drying Time per Print Head Pass lets you print with non-Epson media and avoid smearing the ink. You can make the print head wait up to 5 seconds after each pass to allow ink to dry on the page.
• Paper Feed Adjustment helps reduce banding. Choose a lower value if you see white lines on your prints, or a higher value if you see dark lines.
• Paper Thickness helps reduce vertical banding and creates a sharper image when printing on unusually thick or thin paper.
• Platen Gap lets you fine-tune the setting for unusually thick or thin paper.
3-56
sp3800Guide.book Page 57 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 57
Choosing Expansion Settings
If you need to adjust the amount of image enlargement when printing borderless photos, select an Auto Expand paper size and follow the steps below:
1. Select Expansion from the pop-up menu. You see a screen like this one:
2. If necessary, adjust the Expansion slider to choose the Min , Mid , or
Max setting.
The Min setting retains the entire image in your print, but there may be a small white border on the edges of the print. Max expands the image to ensure that there are no unprinted edges, but the edges of the image may be cropped.
3-57
sp3800Guide.book Page 58 Monday, January 29, 2007 11:08 AM
58 | Printing with Epson Drivers for Macintosh
Note: If you check each pop-up menu, go through them carefully from top to bottom. Avoid cycling through them repeatedly, or you may lose your settings.
Creating a Custom Preset and Printing
Once you’ve selected the correct settings for your print job, create a custom preset. This will save time when you use the same profile/printer/ink/media combination for future print jobs.
1. Select Summary from the pop-up menu.
2. After verifying that your settings are correct, select Save As from the
Presets pop-up menu.
You see the following screen:
Caution: Do not open and close the Presets pop-up menu without typing a name, or you will lose your settings.
3. Type a name for your custom preset, and click OK .
4. When you’re ready to print, click the Print button.
See page 61 for instructions on monitoring your print job.
3-58
sp3800Guide.book Page 59 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 59
Note: If you are printing from Photoshop, make sure you turn off
Photoshop’s color management when using
Advanced Black and
White mode. There are no profiles associated with this screening and color management technology.
Choosing Advanced Black and White Photo
Settings
Advanced Black and White Photo mode allows you to easily produce neutral and toned black-and-white prints using your Epson driver and offers an alternative black-and-white workflow. Whether your photo is color or grayscale, you can use this unique screening and color management technology to create stunning black-and-white prints. This mode is only available when printing on select media types.
1. Select Print Settings from the pop-up menu. You see a screen like this one:
2. Choose the Media Type setting for the paper you loaded in the printer.
3. Choose Advanced B&W Photo as the Color setting.
4. Uncheck High Speed for the best image quality.
3-59
sp3800Guide.book Page 60 Monday, January 29, 2007 11:08 AM
60 | Printing with Epson Drivers for Macintosh
5. Select Printer Color Management from the pop-up menu. You see a screen like this one:
Tone color circle
Note: The preview image will always be the same image and is not color managed. It is just to be used to give you a level of feedback as you make changes.
6. Choose the settings that are best for your photo. You can use the preview image on the screen as a guide.
• Color Toning allows you to add a tone (hue) to your black-and-white output. The default is Neutral , which produces a neutral tone scale print. You can also choose other popular presets such as Cool, Warm, and Sepia. The presets will affect the target color used in the Tone color circle.
• Tone allows you to easily change the entire tonal scale of your black-and-white output. While Darker is the default setting, you may see better results if you choose Dark .
• Brightness adjusts the overall lightness and darkness of your image.
• Contrast adjusts the difference between the light and dark areas of your image.
• Shadow and Highlight Tonality allow you to control tonality only in the shadow or highlight areas of your image.
• Max Optical Density adjusts the overall density or focus of the print. To create a soft focus print, set the density to lower.
3-60
sp3800Guide.book Page 61 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 61
• Highlight Point Shift helps reduce gloss differential by adding density to the highlights of images prone to gloss differential.
• Tone color circle lets you customize the tone (hue) you selected to add to your black-and-white print. Click an area in the circle or enter values in the Horizontal and Vertical fields to adjust the tone.
The closer you select to the edge of the wheel, the more color you will add to your black-and-white print.
Managing Print Jobs
After you click Print, you can monitor the progress of your print job.
1. Click the icon for your printer in the Dock. You see a screen like this one:
2. From here you can monitor the progress of your print job or do one of the following:
•
•
•
Click the print job, then click Delete to cancel the job
Click the print job, then click Hold to pause printing
Click a print job marked “Hold” and click Resume to resume printing
3. When you’re finished, close the screen.
3-61
sp3800Guide.book Page 62 Monday, January 29, 2007 11:08 AM
62 | Printing with Epson Drivers for Macintosh
Checking Ink and Maintenance Status
EPSON Printer Utility2 lets you check the status of ink in the printer and maintenance cartridge. (You can also run maintenance utilities from this
screen. See pages 84 to 88 for instructions.)
1. Open the Applications folder and double-click EPSON Printer
Utility2 .
2. Select Stylus Pro 3800 and click OK . You see the Epson Printer
Utility2 screen:
3. Click the EPSON StatusMonitor icon.
3-62
sp3800Guide.book Page 63 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Macintosh | 63
The software checks the status of ink in the printer and maintenance cartridge, and displays a screen like this one:
4. For information on individual cartridges, click a cartridge icon.
5. To recheck the ink levels, click the Update button.
6. To close the Status Monitor, click OK .
3-63
sp3800Guide.book Page 64 Monday, January 29, 2007 11:08 AM
64 | Printing with Epson Drivers for Macintosh
3-64
sp3800Guide.book Page 65 Monday, January 29, 2007 11:08 AM
65
Chapter 4:
Printing with
Epson Drivers for Windows
Tip: Check the Epson
Pro Graphics website at prographics.epson.com for updated drivers and utilities that may become available.
Your Epson Stylus Pro 3800 comes with drivers and utilities that let you print and manage print jobs. ICC profiles are included, so you can use the color management features in Adobe Photoshop or other applications, or in the driver itself. A color-managed workflow using Photoshop will produce the most accurate colors and best photographic output for color photos.
For the best black-and-white photography output, the Epson Stylus Pro
3800 driver offers Advanced Black and White mode.
You can create your own profiles if you have the required hardware and software, or you can have them created by a color specialist. Make sure any profiles you want to use are located in the correct folder for your operating system. When you install the Epson printer driver, the included profiles are automatically copied to the right folder.
•
•
•
•
•
This chapter includes the following information:
Choosing basic print settings
Choosing paper and layout settings
Choosing advanced print settings, including color management settings
Choosing Advanced Black and White mode settings
Managing print jobs
65
sp3800Guide.book Page 66 Monday, January 29, 2007 11:08 AM
66 | Printing with Epson Drivers for Windows
Choosing Basic Print Options
Before you print, make sure you have installed the Epson printer driver and utilities from the printer software CD-ROM. For instructions on installing the printer driver, see the Start Here sheet.
The driver offers automatic settings that optimize print quality and speed when you’re using Epson media. You can also choose advanced settings for more control over your printer and color management options, as described
1. Open the file you want to print in your application.
2. Open the File menu and click Print . You see the Print window.
3. Make sure your printer is selected, then click the Properties button.
Or, if you see a Setup , Printer , or Options button, click it instead, and click Properties on the next screen. You see a screen like this one:
This box shows you the current settings, but you can’t change them from here
Note: If you need more information about print options, you can click the Help button.
Check the website prographics.epson.com or your authorized Epson dealer for other media that may be available.
4. Select the Media Type that corresponds to the paper you are printing on. If you are using a color-managed workflow, make sure you choose media type and resolution settings that match the ICC profile you are using.
4-66
sp3800Guide.book Page 67 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 67
If your paper is not listed, check the instructions included with the paper, or check the Epson Pro Graphics website at prographics.epson.com. If you are using non-Epson paper, choose the closest setting. You may have to experiment with different settings to determine which one is best for the media you’re using.
5. For the Color setting, select Color for any type of photographic printing. Choose Advanced B&W Photo to print black-and-white
photos on select paper types; see page 74. (For paper types that don’t
support this option, print black-and-white photos with the Color setting.) Select Black only if you’re printing line drawings or other non-photographic images.
6. Set the Mode option as follows:
• Select Automatic to have the printer driver analyze the contents of your image or file and make the appropriate printing adjustments. If a Quality/Speed slider appears in the Mode box, set it according to the priorities of your print job.
You can choose one of the mode settings shown at the left:
EPSON Vivid produces vivid blue and green tones in printouts.
Because this setting reproduces blue and green tones that cannot be displayed by your monitor, your printouts may differ from the screen images.
Charts and Graphs intensifies colors and lightens the midtones and highlights of an image. Use this setting for presentation graphics, such as charts and graphs.
EPSON Standard (sRGB) increases the contrast in images. Use this setting for most color photographs.
Adobe RGB matches image colors to the Adobe RGB color standard.
• Select Custom to choose one of the settings shown at the left.
Advanced Photo 2880 lets you print at 2880 dpi, the highest resolution available.
PhotoEnhance TM allows you to correct noise and other problems common to digital camera images or choose special tone and effect settings.
4-67
sp3800Guide.book Page 68 Monday, January 29, 2007 11:08 AM
68 | Printing with Epson Drivers for Windows
7. Click Custom , then click the Advanced button that appears to turn off color management in the printer driver or access additional settings, as
8. When you’re finished, click the Paper tab and follow the instructions below for choosing paper size and layout options .
Note: Many application settings override settings in the printer driver.
Always verify settings to get the results you expect.
Choosing Paper and Layout Options
You can select a variety of settings for margins, orientation, sizing your image, and double-sided printing. Follow the instructions below to select paper settings.
Choosing Paper Options
1. On the Printing Preferences window, click the Paper tab. You see a window like this one:
2. Select the paper source you’re using ( Sheet , Manual - Rear , or
Manual - Front ) from the Paper Source list.
4-68
sp3800Guide.book Page 69 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 69
3. Select the Paper Size you loaded in the printer. If your paper size is not listed, select User Defined to create a custom paper size.
You see a window like this one:
Note: If your application has margin settings, make sure they’re turned off for borderless printing.
Borderless printing takes longer than normal printing.
Borderless printing is not available when using the front manual feed slot.
Type a name for your custom size, then enter the size in hundredths of an inch (or centimeters) and click Save , then click OK .
4. If you want to print to the edges of the page, click Borderless .
Click the Expand button, then choose one of the following:
• Auto Expand enlarges your image up to 3% to fit the size paper without borders. If too much of your image’s edges are cut off, you can adjust the expansion slider to choose Min , Mid , or Max . The
Min setting retains the entire image in your print, but there may be a small white border on the edges of the print. The Max setting expands the image to ensure that there are no unprinted edges, but the edges of the image may be cropped.
• Retain Size prints your image at the size you specify in your application. You need to size your image slightly larger than the paper if you want to print without borders.
5. Select the correct Copies and Orientation settings as necessary.
6. If you want to reduce or enlarge your image or print on both sides of the paper, click the Layout tab. See your on-screen User’s Guide for more information about double-sided printing.
7. If you’re ready to print, click OK .
4-69
sp3800Guide.book Page 70 Monday, January 29, 2007 11:08 AM
70 | Printing with Epson Drivers for Windows
Choosing Layout Options
Follow the instructions in this section to reduce or enlarge an image to fit on your loaded paper. You can print a poster-size image, even if your application does not support poster printing. For instructions on multi-page, poster, or double-sided printing, see your on-screen User’s Guide .
1. On the Printing Preferences window, click the Layout tab. You see a window like this one:
2. Click Reduce/Enlarge to have the driver resize your image. You can select Fit to Page and select the paper size you loaded in the Output
Paper Size list. Or select Custom and enter a percentage to scale your image.
3. If you are enlarging your image beyond the limits of your application program, click Optimize Enlargement . The driver will increase the image size up to 400% and decrease the output resolution to stay within the pixel limitations.
Depending on the resolution of your original image and the print size, you may see reduced quality in the print.
4-70
sp3800Guide.book Page 71 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 71
Choosing Advanced Print Options
The advanced settings give you complete control over your printing environment. If you are using color management settings in Photoshop or another application, it is very important to access the advanced settings and turn off color management in the printer driver, as described below. If necessary, you can also control the ink density by using the paper
configuration settings as described on page 72.
1. Access your printer driver and select your basic options as described
2. Click Custom , then click the Advanced button that appears. You see a window like this one:
These settings give you different options on the lower part of the screen
3. If necessary, you can change your Media Type and Color settings.
4-71
sp3800Guide.book Page 72 Monday, January 29, 2007 11:08 AM
72 | Printing with Epson Drivers for Windows
Note: The Print Quality settings available depend on the Media Type you selected. Choose lower print quality for faster printing, or SuperPhoto -
2880dpi for best quality.
Tip: If you turn off color management, you can still control the ink density, as described
4. Choose one of the following Print Quality settings:
• Draft
• Normal - 360dpi
• Fine - 720dpi
• SuperFine - 1440dpi
• SuperPhoto - 2880dpi
5. Choose any of the following advanced options:
• High Speed for fast, bidirectional printing. For higher quality, make sure this option is not selected.
• Flip Horizontal for printing a mirror image of your file. Use with backlight film.
• Finest Detail for sharper edges on vector-based data including text, graphics, and line art.
• Edge Smoothing to improve the quality of low-resolution images.
6. Choose one of the following Printer Color Management settings:
• Color Controls to choose from four Color Adjustment modes and three Gamma settings. You can also specify individual values for
Brightness, Contrast, Saturation, and CMY inks.
• PhotoEnhance allows you to correct noise and other problems common to digital camera images or choose special tone and effect settings.
• Off (No Color Adjustment) to disable color management in the printer driver. Choose this setting when using a color-managed workflow in Photoshop or other software applications.
• ICM to adjust colors based on the printer’s ICC profile, using the
Image Color Matching system and the printer’s Epson Standard profile. In most cases, you will get better results by applying color management in your application, rather than in the printer driver.
7. If you are using non-Epson media and you need to fine-tune its performance, click the Paper Config button.
4-72
sp3800Guide.book Page 73 Monday, January 29, 2007 11:08 AM
Note: You may need to change the Color Density setting if your custom profile was created to optimize D-max and color gamut.
Printing with Epson Drivers for Windows | 73
You see a window like this one:
8. Select the correct settings to match your ICC profile. These settings override any paper configuration settings you may have made using the printer’s control panel.
• Color Density lets you control the ink saturation level (for example, when you turn off color management in your printer software).
• Drying Time per Print Head Pass lets you print with non-Epson media and avoid smearing the ink. You can make the print head wait up to 5 seconds after each pass to allow ink to dry on the page.
• Paper Feed Adjustment helps reduce banding. Choose a lower value if you see white lines on your prints, or a higher value if you see dark lines.
• Paper Thickness helps reduce vertical banding and creates a sharper image when printing on unusually thick or thin paper.
• Platen Gap lets you fine-tune the setting for unusually thick or thin paper.
When you’re finished selecting Paper Configuration settings, click OK .
9. Click Save Settings if you want to have your advanced settings available for reuse. Then type a name for the group of settings and click
Save . The name is added to your list of custom settings.
10. When you’re finished setting advanced printer options, click OK .
4-73
sp3800Guide.book Page 74 Monday, January 29, 2007 11:08 AM
74 | Printing with Epson Drivers for Windows
Note: If you are printing from Photoshop, make sure you turn off
Photoshop’s color management when using
Advanced Black and
White mode. There are no profiles associated with this screening and color management technology.
Choosing Advanced Black and White Photo
Settings
Advanced Black and White Photo mode allows you to easily produce neutral and toned black-and-white prints using your Epson driver and offers an alternative black-and-white workflow. Whether your photo is color or grayscale, you can use this unique screening and color management technology to create stunning black-and-white prints. This mode is only available when printing on select media types.
1. On the Main tab, choose the Media Type setting for the paper you loaded in the printer.
2. Choose Advanced B&W Photo as the Color setting.
4-74
sp3800Guide.book Page 75 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 75
3. Click Custom , then click Advanced . You see a window like this one:
Tone color circle
Note: The preview image will always be the same image and is not color managed. It is just to be used to give you a level of feedback as you make changes.
4. Choose the settings that are best for your photo. You can use the preview image on the screen as a guide.
• Color Toning allows you to add a tone (hue) to your black-and-white output. The default is Neutral , which produces a neutral tone scale print. You can also choose other popular presets such as Cool, Warm, and Sepia. The presets will affect the target color used in the Tone color circle.
• Tone allows you to easily change the entire tonal scale of your black-and-white output. While Darker is the default setting, you may see better results if you choose Dark .
• Brightness adjusts the overall lightness and darkness of your image.
• Contrast adjusts the difference between the light and dark areas of your image.
• Shadow and Highlight Tonality allow you to control tonality only in the shadow or highlight areas of your image.
• Max Optical Density adjusts the overall density or focus of the print. To create a soft focus print, set the density to lower.
4-75
sp3800Guide.book Page 76 Monday, January 29, 2007 11:08 AM
76 | Printing with Epson Drivers for Windows
• Highlight Point Shift helps reduce gloss differential by adding density to the highlights of images prone to gloss differential.
• Tone color circle lets you customize the tone (hue) you selected to add to your black-and-white print. Click an area in the circle or enter values in the Horizontal and Vertical fields to adjust the tone.
The closer you select to the edge of the wheel, the more color you will add to your black-and-white print.
Managing Print Jobs
Your printer comes with utilities that let you check on your print jobs and cancel, pause, or restart them.
The Progress Meter opens each time you send a print job. Status Monitor 3, which appears on the taskbar when you print, lets you check the printer’s status and monitor print jobs.
Managing Prints Using the Progress Meter
After you send a print job, the Progress Meter window appears:
May not appear if you are printing over a network
Click to cancel printing
Click to pause/resume printing
You can use the buttons to cancel, pause, or resume your print job. You can also check your ink status and view printing tips.
If you don’t want the Progress Meter to appear, you can turn it off. See
4-76
sp3800Guide.book Page 77 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 77
Setting Monitoring Preferences and Optimizing Print
Speed
You can choose when and how you want to be notified of printing problems, whether you want a Status Monitor 3 icon to appear on your Windows taskbar, and whether you want to allow monitoring by other users who share the printer. You can also use the Speed & Progress utility to improve printing speed and override pixel limitations when you print large images.
1. Do one of the following:
• Windows XP: Click Start and select Printers and Faxes .
Right-click your printer icon and select Printing Preferences .
• Windows 2000: Click Start , point to Settings , then select
Printers . Right-click your printer icon and select Properties ,
Document Defaults , or Printing Preferences .
2. Click the Utility tab, then click the Speed & Progress button. You see the Speed & Progress window:
If you want to disable display of the Progress
Meter during printing, you can click the
Show Progress Meter checkbox to deselect it.
4-77
sp3800Guide.book Page 78 Monday, January 29, 2007 11:08 AM
78 | Printing with Epson Drivers for Windows
3. Select from the following options:
• High Speed Copies speeds up printing of multiple copies of the same document using hard disk space as a cache. If you have multiple hard drives, you can select a different drive to spool to.
• Show Progress Meter lets you control whether or not the Progress
Meter is displayed when you send a print job.
• Always spool RAW datatype lets you spool documents using the
RAW format instead of the EMF (metafile) format. Because the
RAW format requires fewer resources, printing is faster and you can avoid certain problems, such as insufficient memory or disk space.
• Page Rendering Mode speeds printing by rendering the entire page. Use this setting if print speed is extremely slow or the print head stops for a few minutes while printing. Printing will take longer to start.
• Coarse Rendering allows you to override the length or width limitations in applications (such as Photoshop) that restrict the number of pixels you can print.
• Print as Bitmap allows large or complex vector graphics to print faster in Adobe Acrobat ® or any other non-image based application.
4-78
sp3800Guide.book Page 79 Monday, January 29, 2007 11:08 AM
Printing with Epson Drivers for Windows | 79
4. Click the Monitoring Preferences button. You see the Monitoring
Preferences window:
5. Select the Notification options you want to use.
6. If you want to have the Status Monitor 3 icon appear in your Windows taskbar, click the Shortcut Icon checkbox. Then select the icon to use.
After you enable the shortcut, you can simply double-click the icon to open the Status Monitor 3 window or right-click it, then select
Monitoring Preferences in the pop-up menu.
7. Select Allow monitoring of shared printers if your printer is shared and you want to let other users monitor it.
8. Click OK to save your settings.
9. Click OK to close the Speed & Progress window and return to the
Utility menu. Then click OK again to exit the Printers utility.
4-79
sp3800Guide.book Page 80 Monday, January 29, 2007 11:08 AM
80 | Printing with Epson Drivers for Windows
4-80
sp3800Guide.book Page 81 Monday, January 29, 2007 11:08 AM
81
Chapter 5:
Maintaining and
Transporting the Printer
•
•
•
•
•
•
•
•
•
•
The Epson Stylus Pro 3800 requires little maintenance to keep working at its best. This chapter describes the following routine procedures:
Checking printer status and part life
Checking and cleaning the print head
Aligning the print head
Replacing ink cartridges
Performing additional maintenance tasks (changing the black ink cartridge, adjusting the date and time, adjusting the LCD contrast)
Replacing the maintenance cartridge
Cleaning the printer
Transporting or storing the printer
Uninstalling and reinstalling printer software
Updating the printer firmware
In addition to the features described in this chapter, you can also use the printer’s menu system to fine-tune a variety of printer settings. For more information, see the on-screen User’s Guide .
81
sp3800Guide.book Page 82 Monday, January 29, 2007 11:08 AM
82 | Maintaining and Transporting the Printer
Note: To test the print
instructions on printing a nozzle check.
Note: You can replace the ink cartridges and maintenance cartridge yourself. Other printer parts need to be replaced by an authorized Epson service technician.
Checking Printer Status and Part Life
Using the printer’s menu system, you can check the status of your ink cartridges, the total number of prints, and the status of your maintenance cartridge and other printer parts. You can either print out a status check or you can view the printer’s status on the LCD panel.
Printing Status Information
The status check sheet shows some of the current default settings, the status of the ink in each cartridge, the page count, and the status of various printer parts.
Follow these steps to print the status check sheet:
1. Make sure paper is loaded in the printer.
2. Press the Menu r button and then d to highlight TEST PRINT .
3. Press r then d to select STATUS SHEET .
4. Press r to select PRINT .
5. Press the Enter button to start printing.
The service life for each ink cartridge and the maintenance cartridge is indicated as follows:
E[*****]F
E[**** ]F
E[*** ]F
E[** ]F
E[* ]F
5-82
sp3800Guide.book Page 83 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 83
Note: Some status information is a projection based on the last print made.
Note: You can change the units of measurement from meters to inches and feet using the printer’s maintenance mode.
instructions.
Viewing Status Information
To view printer status information instead of printing it, follow these steps:
1. Press the Menu r button and then d until PRINTER STATUS is highlighted.
2. Press r to select VERSION .
3. Do one of the following:
• To check the firmware version, press r again. When done, press l .
•
•
•
•
To check the number of pages that can be printed with each ink cartridge, press d to select PRINTABLE PAGES , then press r . Press d or u to scroll through the ink cartridges and see approximately how many pages can be printed with each ink cartridge. When done, press l .
To check the ink status, press d to select INK LEVEL , then press r .
You see MATTE BLACK and the ink status for that cartridge. Press d or u to scroll through the ink cartridges and see their status.
When done, press l .
To check how much of the maintenance cartridge has been used, press d to select MAINTENANCE CART , then press r . You see how much capacity remains in the cartridge. When done, press l .
To check the total amount of ink used (in milliliters), press d to select USAGE COUNT , then press r . When done, press l .
You can clear this setting with the CLEAR USAGE COUNT option.
•
•
To check job history, press d to select JOB HISTORY , then press r . For the last 10 print jobs saved in the printer, you see the total ink used (in milliliters) and the paper size used most recently.
The most recent job is saved as No. 0. When done, press l .
To check the total number of prints, press d to select TOTAL
PRINTS , then press r . You see the total number of pages that have been printed. When done, press l .
4. Press the + Cancel button to exit the menu.
For more information about the Printer Status menu, see your on-screen
User’s Guide .
5-83
sp3800Guide.book Page 84 Monday, January 29, 2007 11:08 AM
84 | Maintaining and Transporting the Printer
Note: You can run a cleaning cycle by holding down the Menu button for three seconds. You can also use the printer’s menu to run a power cleaning cycle. See
Checking and Cleaning the Print Head
If your printed image shows a color shift or horizontal or vertical lines, you should check the print head to see if any nozzles are clogged.
You can automatically check and clean the print head using the Auto
Cleaning feature in your printer utility software. This enables the printer to print a nozzle check pattern, read it, and run a cleaning cycle if necessary.
1. Make sure several sheets of letter-size (or larger) paper are loaded in the auto sheet feeder.
2. Do one of the following to access the printer utilities:
• Macintosh : Open the Applications folder and double-click Epson
Printer Utility2 . Select Stylus Pro 3800 and click OK .
•
•
Windows XP : Click Start and select Control Panel . Double-click
Printers and Faxes . Right-click your printer icon and select
Printing Preferences . Click the Utility tab.
Windows 2000: Click Start , point to Settings , then select
Printers . Right-click your printer icon and select Printing
Preferences . Click the Utility tab.
You see a screen like the following:
5-84
sp3800Guide.book Page 85 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 85
3. Click the Nozzle Check icon.
4. Click Print to print the nozzle check pattern so you can see if the print head needs to be cleaned. Or click Auto if you want to run the nozzle check and have the printer automatically clean the print head if necessary.
Note: You must use at least a 10
×
eye loupe to check the pattern.
5. Examine the nozzle check pattern to make sure it has no gaps or lines.
• If the printout looks okay as shown below, you’re done. Click
Finish .
• If you see any gaps as shown below, click Clean to clean the print head and follow the on-screen instructions.
6. If the nozzles do not clear after a few cleaning cycles, run a Power
Cleaning Cycle, as described in the next section.
5-85
sp3800Guide.book Page 86 Monday, January 29, 2007 11:08 AM
86 | Maintaining and Transporting the Printer
Caution: Don’t run a power cleaning cycle while thick media is loaded in the printer.
Running a Power Cleaning Cycle
You can run a power cleaning cycle from the control panel if the normal cleaning process is not sufficient to clear the nozzles. However, the power cycle uses a large quantity of ink, so it is recommended only as a last resort.
The cartridges need to be at least 50% full to use power cleaning. You may need to replace a low cartridge to run the cleaning cycle. After cleaning, you can reinsert the old cartridge.
1. Print a nozzle check to make sure the print head needs cleaning, as
2. Make sure the printer is ready and the red B ink light is not on or flashing.
3. Press the Menu r button.
4. Press d until MAINTENANCE is highlighted, then press r .
5. Press d to select POWER CLEANING , then press r .
6. Press the Enter button to start the power cleaning.
7. When cleaning is finished and the P Power light stops flashing, print the nozzle check again to confirm that the head is clean.
For effective cleaning, always run a nozzle check between cycles.
If the pattern is still missing segments after a few power cleaning cycles, turn off the printer and let it sit overnight. Then clean the print head again the following morning with regular cleaning cycles. If you still see no improvement, contact Epson for assistance.
5-86
sp3800Guide.book Page 87 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 87
Aligning the Print Head
Aligning the print head is the most important thing you can do to ensure the best print quality. If banding appears on your prints, if they look grainy or blurry, or you see misregistration or “ghosting,” you need to align the print head.
Although you can align the print head using the printer utility software, it’s best to align from the printer’s control panel. This will do the most thorough job in the shortest time, and it’s all automatic.
If you haven’t already done so, it’s a good idea to run a nozzle check before
aligning the print head (see page 84). This ensures that the print head
alignment patterns print correctly.
Follow these steps to align the print head using the control panel:
1. Make sure the printer is turned on. Then load one of the following types of paper:
•
•
Epson Premium Glossy Photo Paper
Epson Premium Photo Paper Glossy
•
•
•
•
•
•
Epson Premium Luster Photo Paper
Epson Ultra Premium Photo Paper Luster
Enhanced Matte Paper
Epson Ultra Presentation Paper Matte
Epson Photo Quality Ink Jet Paper
Epson Presentation Paper Matte
2. Press the Menu r button.
3. Press d until HEAD ALIGNMENT is highlighted. Then press r .
4. Make sure Auto is highlighted and then press r .
5-87
sp3800Guide.book Page 88 Monday, January 29, 2007 11:08 AM
88 | Maintaining and Transporting the Printer
5. Press d or u to select the type of paper you loaded: PREM.
GLOSSY/LUSTER , P Q INK JET PAPER (Epson Presentation Paper
Matte), or ENHANCED MATTE PAPER (Ultra Premium Presentation
Paper Matte). Then press r .
6. Press Enter to start printing. After printing is complete, the printer starts aligning the print head.
It takes several minutes to run the head alignment. The printer’s white beam sensor reads the alignment pattern and adjusts the printer automatically. Make sure you don’t open the top cover or turn off the printer during this process.
If you want to verify or fine-tune the alignment process, you can perform a manual head alignment. See your on-screen User’s Guide for instructions.
Replacing Ink Cartridges
Before you begin a large print job, you should check your ink levels. If one of your cartridges is low, you can replace it before you start. Or you can wait until the ink cartridge needs to be replaced, and then continue the job without any loss of print quality. However, it is best to replace a low ink cartridge before starting a large print job.
The easiest way to check ink levels is from the control panel:
1 Matte Black
2 Photo Black
3 Light Black
4 Light Light Black
5 Cyan
9 Yellow
8 Light Magenta
7 Light Cyan
6 Magenta
5-88
sp3800Guide.book Page 89 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 89
Caution: You must use the Epson ink cartridges designed for your printer.
Other ink cartridges will not work and may cause damage not covered by your warranty.
Caution: Leave the low or expended cartridge in the printer until you are ready to replace it.
To prevent ink reporting errors, never replace the ink cartridges with the printer turned off.
When the red B ink light is flashing and INK LOW appears on the LCD panel, the indicated cartridge is low on ink. Make sure you have a replacement cartridge. When the light stays on and you see the LCD message REPLACE INK CARTRIDGE , the cartridge is expended. You must replace the cartridge before you can continue printing.
Use the following UltraChromeK3 TM Epson ink cartridges :
Cartridge
Photo Black
Cyan
Magenta
Yellow
Light Cyan
Light Magenta
Light Black
Matte Black
Light Light Black
Product code
T580100
T580200
T580300
T580400
T580500
T580600
T580700
T580800
T580900
You can purchase genuine Epson ink and paper from an authorized Epson reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766).
Or you can also purchase online at www.epsonstore.com
(U.S. sales) or www.epson.ca
(Canadian sales).
Before you start, make sure the printer is turned on. Then follow these steps to replace an ink cartridge:
1. Note the color of the cartridge whose icon and abbreviation is on or flashing. This is the cartridge you need to replace.
5-89
sp3800Guide.book Page 90 Monday, January 29, 2007 11:08 AM
90 | Maintaining and Transporting the Printer
2. If the red B ink light is on and REPLACE INK CARTRIDGE appears on the printer’s LCD, press the u Ink cover open button to unlock the ink cover. If the light is flashing and the LCD message is INK LOW , you need to hold down the button for 3 seconds to unlock the ink cover.
3. Lift the ink cover.
5-90
sp3800Guide.book Page 91 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 91
4. Press the ink eject button above the cartridge you need to replace. The ink cartridge slides out slightly.
WARNING : Do not shake the expended cartridge, or ink may leak out. If ink gets on your hands, wash them thoroughly with soap and water. If ink gets in your eyes, flush them immediately with water.
5. Carefully pull the cartridge straight out of the slot and dispose of it properly.
6. Make sure the replacement ink cartridge is the correct color, and then remove it from its package.
Caution: Do not touch the green chip on the top of the cartridge. Doing so may prevent normal operation and printing.
5-91
sp3800Guide.book Page 92 Monday, January 29, 2007 11:08 AM
92 | Maintaining and Transporting the Printer
7. Shake the ink cartridge well before installing it.
8. Hold the ink cartridge with the arrow mark facing up and pointing to the back of the printer, and then insert it into the slot until it clicks.
Arrow mark
The printer has a protection system to prevent improper cartridge insertion. If you cannot insert the ink cartridge easily or if you see the message INK CARTRIDGE ERROR on the LCD panel, the type of cartridge may be incorrect. Check the package and product code.
If the B ink light remains on, the ink cartridge may not be installed correctly. Remove the ink cartridge and then reinsert it as described above.
5-92
sp3800Guide.book Page 93 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 93
9. Close the ink cover and press it until it clicks.
When you see READY on the LCD, the printer is ready to print.
Performing Additional Maintenance Tasks
In addition to running a power cleaning cycle, you can use the Maintenance menu to switch between Matte Black and Photo Black, set the printer’s date and time, and adjust the contrast on the LCD screen.
The printer also provides a maintenance mode which lets you change the printer’s defaults and run special procedures.
5-93
sp3800Guide.book Page 94 Monday, January 29, 2007 11:08 AM
94 | Maintaining and Transporting the Printer
Changing the Black Ink Cartridge
You can use either Matte Black or Photo Black for printing. Both cartridges are installed all the time, and the printer knows which cartridge to use depending on the Media Type selected in the printer driver. You may sometimes need to switch cartridges as described below when using non-Epson media.
The Photo Black cartridge is ideal for printing photographic images on all media types. It is optimized for traditional photographic and ink jet-coated papers, such as Epson Ultra Premium Photo Paper Luster and Epson Photo
Paper Semi-gloss, etc.
The Matte Black cartridge is optimized for printing photographic images on matte or plain papers, such as Epson Ultra Premium Presentation Paper
Matte and Epson Velvet Fine Art Paper.
Generally, you should switch black ink cartridges only if you plan to run a large number of print jobs in the new mode. Since it takes several minutes to switch and consumes some ink, you shouldn’t switch cartridges more often than necessary.
Changing the black ink cartridge also consumes color ink, so you need to make sure that all of the cartridges contain enough ink before you begin.
Follow these steps to switch from one cartridge to the other:
1. Press the Menu r button.
2. Press d until MAINTENANCE is highlighted, then press r .
3. Press d to select BLACK INK CHANGE , then press r .
4. Press the Enter button. The printer charges the cartridge (this takes a few minutes) and you see PHOTO -> MATTE or MATTE -> PHOTO on the LCD.
When the change is complete, the LCD displays READY and the name of the current black cartridge.
5-94
sp3800Guide.book Page 95 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 95
Changing the Date and Time
Follow these steps to set the date and time:
1. Press the Menu r button.
2. Press d until MAINTENANCE is highlighted, then press r .
3. Press d to select CLOCK SETTING , then press r .
4. Use u or d to set each item in the date and time, displayed in the following format: MM/DD/YY HH:MM .
5. Press + Cancel when you finish.
Adjusting the LCD Contrast
Follow these steps to change the LCD contrast:
1. Press the Menu r button.
2. Press d until MAINTENANCE is highlighted, then press r .
3. Press d to select CONTRAST ADJUSTMENT , then press r .
4. Use u or d to increase or reduce the screen contrast.
5. Press + Cancel when you finish.
5-95
sp3800Guide.book Page 96 Monday, January 29, 2007 11:08 AM
96 | Maintaining and Transporting the Printer
Using Maintenance Mode
Maintenance mode allows you to change the language or units of measurements used in the printer’s menus and return all the menu settings to their default values.
Follow these steps to use maintenance mode:
1. Make sure the printer is turned off.
2. Press and hold the + Cancel button, then press the P Power button until the printer turns on. MAINTENANCE MODE appears on the
LCD panel.
3. Press u or d to select the settings described below. If you need to back up to the previous menu level, press the l button.
•
•
To change the language displayed on the LCD panel, select
LANGUAGE and press r . Press d until you see the language you want, then press Enter to select it. Press l to return to the menu or + Cancel to exit.
To change the units of measurement, select UNIT and press r .
Select METRIC or FEET/INCH and then press Enter to select it.
Press l to return to the menu or + Cancel to exit.
• To return all control panel settings to their default values, select
DEFAULT PANEL and press r . Press Enter to restore the printer’s defaults. Then press l to return to the menu or + Cancel to exit.
4. To exit maintenance mode, turn off the printer by pressing the P Power button. Press the P Power button again to turn on the printer in the normal operating mode.
5-96
sp3800Guide.book Page 97 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 97
Replacing the Maintenance Cartridge
The maintenance cartridge stores ink that gets flushed from the system during print head cleaning. When the cartridge is almost full, the message
MAINTENACE CARTRIDGE IS NEARLY FULL appears on the LCD panel. When the cartridge is completely full, the printer stops working and
REPLACE THE CARTRIDGE appears on the LCD.
You can check how much space remains in the maintenance cartridge by viewing its indicator on the control panel, as shown below. You can also
check its status using the printer’s menus (see page 83) or by printing a
nozzle check sheet (see page 84).
Maintenance cartridge indicator
(showing a new cartridge)
Replacement cartridges are available from Epson (product code T582000).
You can purchase replacement items for your printer from an authorized
Epson reseller. To find the nearest reseller, call 800-GO-EPSON
(800-463-7766). Or you can purchase online at www.epsonstore.com.
(U.S. sales) or www.epson.ca (Canadian sales).
Follow these steps to replace the maintenance cartridge:
1. Make sure the printer is not printing or performing any other operations
( READY or PAPER OUT should appear on the control panel).
2. Turn off the printer.
5-97
sp3800Guide.book Page 98 Monday, January 29, 2007 11:08 AM
98 | Maintaining and Transporting the Printer
3. Open the maintenance cartridge cover.
WARNING: If ink gets on your hands, wash them thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water.
4. Grasp the handle of the maintenance cartridge, then push it up while gently pulling it toward you.
5-98
sp3800Guide.book Page 99 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 99
Caution: Be careful not to tilt the used cartridge or spill ink from it when removing it. Hold it upright at all times and dispose of it carefully.
5. Remove the replacement cartridge from its package. Then put the used maintenance cartridge in the plastic bag provided and dispose of it properly.
Caution: Do not touch the green chip on the side of the maintenance cartridge. This may prevent normal operation.
6. Insert the new maintenance cartridge into the printer as far as it will go.
7. Close the maintenance cartridge cover.
8. Turn the printer back on.
5-99
sp3800Guide.book Page 100 Monday, January 29, 2007 11:08 AM
100 | Maintaining and Transporting the Printer
WARNING: Be careful not to touch the gears inside the printer.
To keep your printer working at its best, you should clean it several times a year.
Caution: To avoid damaging the components as well as the case, never use alcohol or thinners to clean the printer.
Be careful not to get water on the printer mechanism or on-screen components.
Cleaning the Printer
1. Make sure the printer is turned off, then unplug the power cord and disconnect the printer from your system. Let the printer sit for a minute.
2. If the outer case is dirty, clean it with a soft, clean cloth dampened with mild detergent. Keep the ink cartridge compartment closed to prevent water from getting inside.
3. If the front manual tray is extended, close it by pushing it in.
Don’t use a hard or abrasive brush.
Do not touch the ink absorption pads; otherwise, printouts may be soiled.
4. Open the top cover and then use a soft, lint-free cloth to carefully remove any dust or dirt inside the printer. If the back of a printout is soiled, carefully clean the plastic ribs using a soft, lint-free cloth wiping in the direction of the arrows.
Don’t spray the inside of the printer with lubricants; unsuitable oils can damage the mechanism. Contact
Epson if you think the printer needs lubrication.
Plastic ribs
If the problem still occurs, clean the area using a soft, lint-free, dampened cloth. Then wipe the inside of the printer dry with a dry, lint-free, soft cloth.
5-100
sp3800Guide.book Page 101 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 101
WARNING: The printer weighs about 43 lb (20 kg), and should be lifted by two people.
Transporting or Storing the Printer
If you are moving the printer a short distance (for example, in the same building), close any open extensions and covers and remove the rear sheet guide if installed.
To ship the printer, you must repack it using the original box and packing materials. If you do not have these items, contact Epson to request them.
Otherwise, the printer may be damaged beyond repair.
Caution: Do not remove the ink cartridges.
Caution: Do not turn off the printer by unplugging it or turning off a power strip. You will not be able to lock the print head, and ink may leak out of the reservoir, damaging the printer.
Preparing the Printer for Shipment
1. Turn the printer on and make sure the print head is in the home
(far right) position.
2. Turn off the printer.
3. Unplug the power cord and interface cable.
4. Close any paper tray extensions and covers, and remove the rear sheet guide if installed.
5. Insert the protective materials included with the printer and repack it using the original box and packing materials. If you do not have these items, contact Epson to request them. Otherwise, the printer may be damaged beyond repair.
Setting Up the Printer After Transportation
Setting up the printer after transporting it is almost identical to setting it up for the first time. See the Start Here sheet for instructions.
Keep in mind that the first time you start printing after moving the printer, the print head nozzles may be clogged—especially if the printer hasn’t been turned on for a long time. You may need to run a cleaning cycle
(see page 84) and realign the print head (see page 87) to ensure good print
quality.
5-101
sp3800Guide.book Page 102 Monday, January 29, 2007 11:08 AM
102 | Maintaining and Transporting the Printer
Tip: Check the Epson Pro
Graphics website at prographics.epson.com for updated drivers and utilities that may become available.
Uninstalling and Reinstalling the Printer Driver
If you need to uninstall and then reinstall the printer driver software for any reason, follow the instructions in the appropriate section below.
Macintosh
1. Open the Applications folder, then the Utilities folder.
2. Double-click Printer Setup Utility , select Stylus Pro 3800 , and then click Delete .
3. If you want to reinstall your printer software, restart your Macintosh.
Then follow the instructions on the Start Here sheet to install the printer software.
Windows
1. Do one of the following:
• Windows XP: Click Start , then Control Panel .
• Windows 2000: Click Start , Settings , and Control Panel .
2. Double-click Add/Remove Programs . Click Epson Printer
Software in the program list, then select your printer icon.
3. Click the Change/Remove or Add/Remove button and follow the on-screen instructions.
4. If you want to reinstall your printer software, restart your computer.
Then follow the instructions on the Start Here sheet to install the printer software or in Chapter 1 for network setups.
5-102
sp3800Guide.book Page 103 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 103
Updating Your Printer Firmware
You can check for a newer version of firmware on the Epson support site and update your printer, if necessary.
Downloading the Firmware
1. Navigate to epson.com/support in your browser.
2. Choose your printer.
3. Click Drivers and Downloads to find the newest firmware.
4. Choose the version for Macintosh or Windows and follow the instructions on the screen, then continue with the instructions below to update the firmware.
Note: Although the illustrations in this section show Macintosh screens, the procedure is the same in Windows.
Updating the Firmware
1. Double-click the firmware file to extract it.
2. Double-click the EPSON LFP Remote Panel icon on your desktop.
You see a window like this one:
Note: For more information on using the
LFP Remote Panel, click
Help to see the on-screen guide.
5-103
sp3800Guide.book Page 104 Monday, January 29, 2007 11:08 AM
104 | Maintaining and Transporting the Printer
3. Click the Firmware Updater icon. You see a window like this one:
4. Make sure your printer is on, its LCD is set to Ready , and it is connected to your computer. Then choose Stylus Pro 3800 in the
Printer list.
5-104
sp3800Guide.book Page 105 Monday, January 29, 2007 11:08 AM
Maintaining and Transporting the Printer | 105
Caution: Don’t turn off the printer while the firmware is updating.
5. Click Browse and find the firmware that you just downloaded and extracted. Select the file and click Choose .
6. If the firmware version of the file is newer, click Update to start the firmware update process. (If it is the same, you don’t need to update it.)
7. When the update is complete, close the Firmware Updater window and the LFP Remote Panel window.
5-105
sp3800Guide.book Page 106 Monday, January 29, 2007 11:08 AM
106 | Maintaining and Transporting the Printer
5-106
sp3800Guide.book Page 107 Monday, January 29, 2007 11:08 AM
Chapter 6:
Solving
Problems
107
•
•
•
•
•
•
If you experience a problem with your printer, try to solve it by following the guidelines in this chapter:
Diagnosing problems
Checking error messages and lights
Improving print quality
Solving operational problems
Solving miscellaneous printing problems
Solving paper problems, including clearing paper jams
Diagnosing Problems
•
•
•
•
The Epson Stylus Pro 3800 includes a number of ways to help you diagnose problems:
To identify the most common problems, check the messages on the
control panel. See page 108 for more information.
If you’re using the Epson printer driver and Status Monitor utility, check your software for error messages. See Chapter 4 or 5 for more information.
To determine whether the problem is caused by the printer itself, disconnect the printer from your computer and run a nozzle check from
the control panel. See page 84 for instructions.
If none of the suggested solutions in this chapter solve your problem,
contact Epson as described under “Where To Get Help” on page 12.
107
sp3800Guide.book Page 108 Monday, January 29, 2007 11:08 AM
108 | Solving Problems
Checking Error Messages and Lights
The control panel includes various lights and an LCD panel to indicate the status of the printer:
Power light
Paper light
Ink light
LCD
Back / l button
Ink cover open / u button
Menu / r button
Power button
Cancel button
Ink and maintenance cartridge status
Paper feed / d button
Enter button
When your ink is low or expended, or paper runs out, or a problem occurs, a message appears on the LCD, and the lights on the control panel come on or flash. The following table lists the messages in alphabetical order and includes instructions for correcting the problem.
6-108
sp3800Guide.book Page 109 Monday, January 29, 2007 11:08 AM
Solving Problems | 109
Message
CLEANING ERROR
PRESS THE
CANCEL/RESET
BUTTON
Explanation
BORDERLESS
ERROR
PRESS THE DOWN
BUTTON.
LOAD THE CORRECT
SIZE PAPER
The installed paper is not supported for borderless printing or the PAPER SIZE
CHECK setting is off.
The nozzles are still clogged.
Response
Press the d Paper feed button, and then load a different
size media. See “Choosing Paper Options” on page 68
CHECK in the printer’s menu system.
Press the + Cancel button, then run the Head Cleaning
utility. See “Checking and Cleaning the Print Head” on page 84.
Print head cleaning cannot be started because thick paper is loaded.
Remove the thick paper.
CLEANING ERROR
PRESS THE DOWN
BUTTON AND
REMOVE THICK
PAPER
COMMAND ERROR
CHECK DRIVER
SETTINGS
Damaged data was sent to the printer or the data has an incorrect command.
Stop printing and press the + Cancel button for
3 seconds.
The installed printer driver is not correct for the printer.
Stop printing and press the + Cancel button for
3 seconds. Then make sure that the installed printer driver is correct for the printer.
FRONT FEED SLOT
OPEN
CLOSE THE FRONT
MANUAL FEED SLOT
FRONT FEED SLOT
OPEN
LOAD MEDIA
PRESS THE DOWN
BUTTON
FRONT FEED SLOT
OPEN
PRESS THE DOWN
BUTTON AND
REMOVE PAPER
The front manual feed slot is open during operation.
The front manual feed slot is open, but no paper is loaded.
Close the front feed slot.
Load a sheet of paper in the front slot, and then press the d Paper feed button.
Paper is loaded in the front manual feed slot.
Press the d Paper feed button, then remove the paper from the front manual feed slot.
6-109
sp3800Guide.book Page 110 Monday, January 29, 2007 11:08 AM
110 | Solving Problems
Message
FRONT SLOT
CLOSED
OPEN THE FRONT
MANUAL FEED SLOT
Explanation
The front manual feed slot is closed during operation.
Response
Open the front slot by pushing it. If necessary, remove the paper.
INK CARTRIDGE
ERROR
CHECK CARTRIDGE
INK CARTRIDGE
ERROR
PRESS THE UP
BUTTON
REPLACE THE
CARTRIDGE
The wrong type of cartridge is installed.
An ink cartridge is installed incorrectly (perhaps in the wrong slot).
Remove the ink cartridge and install one that is
designed for your printer. See “Replacing Ink
INK CARTRIDGE
ERROR
PLEASE INSTALL THE
CORRECT
CARTRIDGE
An ink cartridge that cannot be used with this printer is installed.
Remove the ink cartridge and install one that can be
used in your printer. See “Replacing Ink Cartridges” on page 88.
Press the u Ink cover open button to open the ink cover. Then remove the ink cartridge and install it
correctly. See “Replacing Ink Cartridges” on page 88.
INK CARTRIDGE
ERROR
REPLACE
CARTRIDGE
INK CARTRIDGE
NON-GENUINE
CARTRIDGE MAY
NOT PERFORM AT
OPTIMUM.
CONTINUE?
<YES NO>
There is a problem with one of the ink cartridges. It may be installed in the wrong slot.
The wrong type of cartridge is installed or is installed in the wrong slot.
Remove the ink cartridge and reinstall it correctly. If this message appears after reinstalling the ink cartridge,
replace it. See “Replacing Ink Cartridges” on page 88.
Select NO (press the Menu r button) if you want to replace the ink cartridge with a genuine Epson ink
cartridge. See “Replacing Ink Cartridges” on page 88.
Otherwise, select YES (press the l button).
INK CARTRIDGE
PLEASE USE
GENUINE EPSON INK
CARTRIDGES
A non-genuine ink cartridge is installed.
Replace the ink cartridge with a genuine Epson ink
cartridge. See “Replacing Ink Cartridges” on page 88.
INK CARTRIDGE
REPLACE INK
CARTRIDGE
The ink cartridge is expended.
Install a new ink cartridge. See “Replacing Ink
6-110
sp3800Guide.book Page 111 Monday, January 29, 2007 11:08 AM
Solving Problems | 111
Message
INK CARTRIDGE
THIS MAY VOID
EPSON’S
WARRANTY.
DO YOU ACCEPT
THIS?
<ACCEPT DECLINE>
INK LOW
Explanation Response
A non-genuine ink cartridge is installed, and if you use it, may void Epson’s warranty.
Select DECLINE (press the Menu r button) to replace the ink cartridge with a genuine Epson ink cartridge.
Selecting ACCEPT (by pressing the l button) may void
Epson’s warranty.
MAINTENANCE
CARTRIDGE FULL
REPLACE THE
CARTRIDGE
MAINTENANCE
CARTRIDGE NEARLY
FULL
REPLACE THE
CARTRIDGE
MAINTENANCE
REQUEST NNNN
The ink cartridge is almost expended.
The maintenance cartridge is full.
The maintenance cartridge is almost full.
You need to replace the ink cartridge soon. Although you can continue printing when the INK LOW message appears, print quality may decline.
Replace the maintenance cartridge with a new one. See
“Replacing the Maintenance Cartridge” on page 97.
You need to replace the maintenance cartridge soon
with a new one. See “Replacing the Maintenance
MAINTENANCE
PLEASE USE
GENUINE EPSON
CARTRIDGES
A part used in the printer has nearly reached the end of its life. "NNNN" shows the product code for the part.
Note the code and contact Epson. See “Where To Get
A non-genuine maintenance cartridge is installed.
NO INK CARTRIDGE
INSTALL INK
CARTRIDGE
An ink cartridge is not installed.
PAPER EJECT ERROR The printer could not eject the printout.
PRESS THE DOWN
BUTTON AND
REMOVE PAPER
Replace the maintenance cartridge with a genuine
Epson maintenance cartridge. See “Replacing the
Maintenance Cartridge” on page 97.
Install any missing ink cartridges.
Press the printout.
d Paper feed button, then remove the
PAPER ERROR
LOAD PAPER
No paper is loaded in the printer.
Load paper correctly.
6-111
sp3800Guide.book Page 112 Monday, January 29, 2007 11:08 AM
112 | Solving Problems
Message
PAPER ERROR
PRESS THE DOWN
BUTTON.
LOAD PAPER
CORRECTLY
Explanation
The printer cannot detect the loaded media because it is wavy or curled.
The printer cannot detect the loaded media because the color of the paper is either transparent or black, like the platen color.
You have selected double-sided printing, but the printer cannot feed the paper correctly.
Response
Flatten the media.
Select OFF for PAPER SIZE CHECK using the printer’s menu system, or load the correct type of genuine
Epson paper.
PAPER FEED ERROR
LOAD PAPER
CORRECTLY
PRESS THE DOWN
BUTTON
Load the paper that has just been ejected, and then press the d Paper feed button.
PAPER JAM
REMOVE PAPER
PAPER REMOVE
REMOVE PAPER
FROM THE REAR
Paper is jammed.
Remove the jammed paper. See “Paper Feed or Paper
Jam Problems” on page 121 for details.
You need to remove the paper from the rear manual feed slot.
Remove the paper from the rear feed slot.
PAPER SENSOR
ERROR
PRESS THE +
BUTTON.
LOAD THE CORRECT
PAPER
The loaded paper is not the same as the paper type selected for the Automatic
Head Alignment.
Press the + Cancel button, and then load the paper that matches the type selected for the Automatic Head
Alignment. See “Aligning the Print Head” on page 87.
PAPER SENSOR
ERROR
PRESS THE +
BUTTON
LOAD DIFFERENT
PAPER
The loaded paper does not match the paper type selected.
Press the + Cancel button, and then load the paper that
matches the type of paper you selected. See “Aligning the Print Head” on page 87 for details.
6-112
sp3800Guide.book Page 113 Monday, January 29, 2007 11:08 AM
Solving Problems | 113
Message
PAPER SETTING
ERROR
CHECK PAPER
SOURCE IN THE
DRIVER SETTINGS
AND LOAD PAPER
CORRECTLY
Explanation
You are using the wrong paper path for the type of paper you’re using.
Response
Check the Paper Source setting in the printer driver, and
load the paper in the correct slot. See “Choosing the
Correct Paper Path” on page 32 and “Choosing Page
Setup Options” on page 50 for Macintosh or “Choosing
Paper and Layout Options” on page 68 for Windows.
PAPER SIZE ERROR
LOAD THE CORRECT
SIZE PAPER
The size of paper you loaded is not correct for the document/image you are printing.
Remove the paper and load media that is the correct size for what you are printing.
PAPER SKEW
PRESS THE DOWN
BUTTON.
LOAD PAPER
CORRECTLY
The paper is not loaded straight.
Press the d Paper feed button, and then load the paper straight. If you are using the auto sheet feeder, you can use the top edge guide to help feed the paper straight.
6-113
sp3800Guide.book Page 114 Monday, January 29, 2007 11:08 AM
114 | Solving Problems
Improving Print Quality
•
•
•
You can often improve print quality by doing the following:
Run a nozzle check and cleaning cycle. See page 84 for instructions.
Align the print head. See page 87 for instructions.
When you send a print job, make sure your print options are set correctly. For more information, see Chapter 3 (Macintosh) or
Chapter 4 (Windows).
If none of these suggestions help, try the solutions below.
Problem
Your print has horizontal or vertical banding.
Solution
◗ Check the ink indicators and light to see if you are low on ink. Replace ink
cartridges if necessary, as described on page 88.
◗
Run a nozzle check and cleaning cycle. See page 84 for instructions.
◗
Align the print head from the printer’s control panel, as described on page 87.
◗ Turn off High Speed in your Advanced settings.
◗ Make sure the Media Type setting in the printer software is correct for the media you’re printing on.
◗ Make sure the printable side of your media is loaded face-up.
◗ Choose a higher resolution, such as SuperPhoto - 2880dpi .
◗ If you’re using a third-party RIP and non-Epson media, see if the RIP provides a method for adjusting the paper feed.
Try adjusting your paper configuration settings (see page 56 for Macintosh or page 73
for Windows). Check these settings:
◗ Make sure the Paper Thickness setting is correct for the paper you’re printing on.
◗ Use the Paper Feed Adjustment
to eliminate banding (see page 46). Reduce the
value for white lines, or increase it for overlapping dark lines.
◗ If you’ve created a custom paper configuration, be sure to return the setting to
STANDARD
when you’re done using it. See page 47.
6-114
sp3800Guide.book Page 115 Monday, January 29, 2007 11:08 AM
Solving Problems | 115
Problem
Your print is grainy, or has misregistration or ghosting.
Solution
◗ Check the ink indicators and light to see if you are low on ink. Replace ink
cartridges if necessary, as described on page 88.
◗
Run a nozzle check and cleaning cycle. See page 84 for instructions.
◗
Align the print head from the printer’s control panel, as described on page 87.
◗ Make sure the Media Type setting in the printer software is correct for the media you’re printing on.
◗ Make sure the printable side of the paper is loaded face-up in the tray.
◗ Choose a higher resolution, such as SuperPhoto - 2880 .
◗ Turn off High Speed in your Advanced settings.
Try adjusting your paper configuration settings (see page 56 for Macintosh or page 73
for Windows). Check these settings:
◗ Make sure the Paper Thickness setting is correct for the paper you’re printing on.
◗ Use the Paper Feed Adjustment
to eliminate banding (see page 46). Reduce the
value for white lines, or increase it for overlapping dark lines.
◗ If you’ve created a custom paper configuration, be sure to return the setting to
STANDARD
when you’re done using it. See page 47.
Your print has gaps or appears faint.
◗ Make sure the Media Type setting in the printer software is correct for the media you’re printing on.
◗
Run a nozzle check and cleaning cycle. See page 84 for instructions.
◗ Check the ink indicators and light to see if you are low on ink. Replace ink
cartridges if necessary, as described on page 88.
◗ The Paper Thickness setting is not correct for the paper you’re printing on. Use
your printer software (see page 56 for Macintosh or page 73 for Windows) to
choose the correct setting.
◗ The platen gap setting is too wide. Use the printer’s menu system to change the setting to STANDARD , or to NARROW
if printing on very thin paper. See page 44
for instructions.
6-115
sp3800Guide.book Page 116 Monday, January 29, 2007 11:08 AM
116 | Solving Problems
Problem
Colors are incorrect or missing.
Your print appears blurry or smeared.
Solution
◗ Make sure the Media Type setting in the printer software is correct for the media you’re printing on.
◗ If you are using the color management features in Photoshop or another
application, you must turn off color management in the printer driver. See page 55
(Macintosh) or page 72 (Windows).
◗ Adjust the Color Density setting in the Paper Configuration utility.
◗ If you’re using a third-party RIP or non-Epson media, custom color profiles will give you the best color reproduction.
◗ Make sure the printable side of your media is loaded face-up.
◗
Run a nozzle check and cleaning cycle. See page 84 for instructions.
◗ Check the expiration date printed on each of the ink cartridges. If the cartridge is
too old, replace it as described on page 88.
◗ Check the ink indicators and light to see if you are low on ink. Replace ink
cartridges if necessary, as described on page 88.
◗ Make sure color settings in your application or printer software are correct.
◗ To produce sharper images with more vivid colors in Windows, select
PhotoEnhance in the Advanced menu. You can also select Color Controls in the
Advanced menu, and adjust the color, brightness, and other settings.
◗ For Macintosh, select Color Controls in the Printer Color Management section in
the Print window. See “Choosing Color Management and Paper Configuration
◗ Make sure the Media Type setting in the printer software is correct for the media you’re printing on.
◗ If you’re printing on non-Epson media, you may need to adjust the paper thickness
setting, drying time, or color density. Use your printer software (page 56 for
Macintosh or page 73 for Windows) to choose the correct setting.
◗ Your paper doesn’t meet the required specifications or wasn’t stored in a dry, humidity-free environment. Load new paper.
◗ Make sure the printable side of your media is loaded face-up.
◗ Ink has leaked into the paper path. Wipe the paper path area of the printer with a
soft, clean cloth. See page 100 for cleaning instructions.
◗ Turn off High Speed in your Advanced settings.
◗ The platen gap setting is too narrow. Use the printer’s menu system to change the setting to WIDE or WIDER
. See page 44 for instructions.
◗
Run a nozzle check and cleaning cycle. See page 84 for instructions.
6-116
sp3800Guide.book Page 117 Monday, January 29, 2007 11:08 AM
Solving Problems | 117
Problem
The bottom edge of your print is smeared.
Solution
◗ The paper is curled toward the printable side. Flatten it or curl it the other way.
◗ Make sure the Media Type setting in your printer software is correct for the media you’re printing on.
◗ If you’re printing on non-Epson media, you may need to adjust the paper thickness
setting or drying time. See page 44.
◗ If you’re printing on thick paper, the platen gap setting may be too narrow. Use the printer’s menu system to change the setting to WIDE or WIDER.
instructions.
Solving Operational Problems
•
•
•
•
•
If you can’t turn the printer on, if it stops printing unexpectedly, or if nothing prints, check the following:
The printer is turned on.
Paper is loaded in the printer.
The printer is plugged securely into a working electrical outlet that’s not controlled by a switch or timer.
The interface cable is securely connected to the printer and your system.
The voltage supplied by the electrical outlet matches the voltage on the printer’s rating label. If not, turn off the power and unplug the power
cord immediately. Contact Epson for assistance (see page 12).
If none of these suggestions help, try the following solutions.
Problem
The printer stops printing unexpectedly.
The printer sounds as if it’s printing, but nothing prints.
Solution
◗ If the P Power light is flashing, the printer is performing a maintenance procedure or waiting for ink to dry. Check the display message and lights on the control panel.
Wait until the P Power light stops flashing.
◗ Check the display message and lights on the control panel to see if an error has
occurred. Follow the instructions for the messages beginning on page 108.
◗
Follow the instructions beginning on page 84 to clean the print head.
◗ Communication between the computer and printer may have been momentarily interrupted. Try restarting the computer and printing again.
6-117
sp3800Guide.book Page 118 Monday, January 29, 2007 11:08 AM
118 | Solving Problems
Problem
Nothing prints.
Solution
◗ Turn off the printer and computer. Make sure the interface cable is securely plugged in. Then restart the printer and computer.
◗
Make sure the interface cable meets the required specifications. See page 10 or 10.
◗ Your Epson printer is not selected as the default printer. Install the printer driver if it is not installed yet, and follow the instructions below to select your Epson printer as the default printer.
Windows XP: Click Start , Control Panel , Printers and Other Hardware , and then click Printers and Faxes . Right-click EPSON Stylus Pro 3800 and select Set As
Default Printer . Then close the window.
Windows 2000: click Start , Settings , and then click Printers . Right-click EPSON
Stylus Pro 3800 and select Set As Default . Then close the window.
Macintosh: Make sure the Stylus Pro 3800 printer driver is correctly added to the
Printer Setup Utility.
◗ The printer port setting doesn’t match the printer connection port (Windows).
Windows XP: Click Start , Control Panel , Printers and Other Hardware , Printers and Faxes . Right-click EPSON Stylus Pro 3800 , and select Properties . Click the
Ports tab and make sure your printer port is selected.
Windows 2000: Click Start , Settings , Printers . Right-click EPSON Stylus Pro
3800 , and select Properties . Click the Ports tab and make sure your printer port is selected.
◗
Follow the instructions beginning on page 102 to uninstall your printer software.
Then locate your printer software CD-ROM and reinstall the software. You can also download and install the latest driver for Macintosh or Windows from the Epson website at epson.com/support.
6-118
sp3800Guide.book Page 119 Monday, January 29, 2007 11:08 AM
Solving Problems | 119
Solving Miscellaneous Printing Problems
If your printouts are not what you expected, try the suggestions below:
Problem
Your print has incorrect or garbled characters.
Your print has incorrect margins.
Your image is inverted.
Blank paper is printed.
A ruled line on your print appears to shift.
Solution
◗ Make sure your software is installed correctly and the printer is selected in your application.
◗ Clear any stalled print jobs from the Printer Setup Utility.
◗ Turn off the printer and computer. Make sure the interface cable is securely plugged in at both ends.
◗ Check the page size or paper size settings in your application. Make sure they are within the printer’s printable area.
◗ Make sure the Paper Size and Borderless settings in your printer software are correct for the paper you’re using.
◗ Paper is loaded incorrectly. Follow the instructions in Chapter 2 to reload the paper.
◗ Turn off the Flip Horizontal
setting in your printer software. See page 54
(Macintosh) or page 72 (Windows) for instructions.
◗ Make sure your software is installed correctly and the printer is selected in your application.
◗ Make sure the Paper Size setting in your printer software is correct for the paper you’re using.
◗ Make sure the Paper Source setting in your printer software is correct.
Align the print head as described on page 87.
Color images print in black only.
Make sure Color is selected in your printer software.
The printer continues to feed paper after you have cancelled a job.
◗ Press the + Cancel button to clear any print job data in the printer’s buffer.
Then press and hold the + Cancel button to reset the printer.
6-119
sp3800Guide.book Page 120 Monday, January 29, 2007 11:08 AM
120 | Solving Problems
Problem
Printing is too slow.
Solution
◗ Turn on High Speed in your Advanced settings.
◗ Choose a lower resolution in your printer software for faster printing.
◗ Select Automatic mode and move the slider towards Speed (on the Main tab in Windows or in the Print Settings section of the Print window in Macintosh).
◗ Clear space on your hard drive or run a defragmentation utility.
◗ Don’t run too many applications at the same time.
◗ Turn off virtual memory.
◗ Add RAM to your system.
◗ Consider upgrading your system to support a faster connection to the printer, such as USB 2.0.
Solving Paper Problems
•
•
•
•
•
•
•
•
•
If paper feed or paper jam problems occur frequently, try one or more of the following solutions:
For heavy or thick media, follow the instructions on page 40 to load the
media correctly in the front slot.
Make sure the paper is not folded, wrinkled, or damp.
Make sure the printer’s environment falls within the required
temperature and humidity range (see page 126).
Make sure the paper is not too thick or too thin. See page 127 for paper
specifications.
Make sure no foreign objects are inside the paper path.
Make sure the printer isn’t located in a brightly lit area. The paper sensors may not operate correctly.
Make sure the Media Type and Paper Source settings in the printer software are correct.
Make sure the platen gap setting is correct for the paper or media you’re
printing on. See page 44 for more information.
If you’re not using Epson media, make sure you use a paper configuration to adjust for the paper’s thickness and drying time
6-120
sp3800Guide.book Page 121 Monday, January 29, 2007 11:08 AM
Solving Problems | 121
Paper Skews When Printing on Large Format Media
If your paper skews while feeding into the printer, use the edge guide on the right side of the auto sheet feeder to help the paper feed straight.
Paper Feed or Paper Jam Problems
•
•
•
•
•
•
•
•
•
If paper jams frequently while feeding or during printing, try one or more of these solutions:
Make sure the paper is not folded, wrinkled, or curled.
Make sure the printer is located in an environment that is within the
printer’s operational temperature range (see page 126).
Make sure the paper is not damp.
Store unused paper in its original package.
Make sure the paper is not too thick or too thin.
Make sure no foreign objects are inside the printer.
Check the Media Type setting in the printer software and make sure it is correct for the type of paper you are using.
Make sure the platen gap setting is correct for your paper (see page 44).
If you are using a custom paper configuration for non-Epson special
media, check the paper type selected in the printer’s menu (see page 47).
6-121
sp3800Guide.book Page 122 Monday, January 29, 2007 11:08 AM
122 | Solving Problems
Clearing a paper jam from the auto sheet feeder
1. Turn off the printer.
2. Carefully remove the jammed paper from the output tray.
If necessary, open the top cover, and remove any jammed paper from the area shown below.
6-122
sp3800Guide.book Page 123 Monday, January 29, 2007 11:08 AM
Solving Problems | 123
Clearing a paper jam from the front manual feed slot
1. Turn off the printer.
2. If necessary, press the d Paper feed button to eject the sheet.
3. Remove the jammed paper from the front or back of the printer.
Front
Back
6-123
sp3800Guide.book Page 124 Monday, January 29, 2007 11:08 AM
124 | Solving Problems
Clearing a paper jam from the rear manual feed slot
1. Make sure the printer is turned on.
2. Press the d Paper feed button to feed the paper backward.
3. Remove the jammed paper from the back.
6-124
sp3800Guide.book Page 125 Monday, January 29, 2007 11:08 AM
125
Appendix A:
Specifications
This appendix provides the basic specifications for your printer. For complete product information, see your on-screen User’s Guide .
Printing
Printing method Pressurized on-demand ink jet
Nozzle configuration Black: 180 nozzles × 3
(Photo Black or Matte Black, Light Black, Light Light
Black)
Color: 180 nozzles × 5
(Cyan, Magenta, Light Cyan, Light Magenta, Yellow)
Character mode Character pitch
10 characters per inch
Printing column
167
Raster graphic mode Horizontal
Resolution
Print direction
Control code
RAM
Character tables
Character sets resolution
360 dpi
720 dpi
1440 dpi
2880 dpi
Printable width
17.39 inches
(441.8 mm)
17.39 inches
(441.8 mm)
17.39 inches
(441.8 mm)
17.39 inches
(441.8 mm)
Available dots
6262
12524
25047
50094
Maximum 2880 × 1440 dpi
Bidirectional
ESC/P ® Raster
64MB
PC 437 (US, Standard Europe)
PC 850 (Multilingual)
Epson Courier 10 cpi
125
sp3800Guide.book Page 126 Monday, January 29, 2007 11:08 AM
126 | Specifications
Environmental
Specification
Temperature
Humidity
(without condensation)
Operation
50 to 95 °F
(10 to 35 °C)
Print quality guarantee:
59 to 77 °F
(15 to 25 °C)
20 to 80% RH
40 to 60% RH for optimum print quality
For optimal operation, humidity should be between 35 and 45% RH
Storage
–4 to 104 °F
(–20 to 40 °C)
5 to 85% RH
Electrical
Specification
Input voltage range
Rated frequency range
Input frequency range
Rated current
Power consumption
Description
90 V to 264 V
50 to 60 Hz
49 to 61 Hz
0.6 A at 120 V
0.3 A at 220 V
Approx. 25 W or less (ISO 10561 letter pattern)
5 W or less in low power mode
0.3 W or less in power off mode
Check the label on the back of your printer for voltage information.
Dimensions and Weight
Specification
Height
Width
Depth
Weight
Covers closed
10.28 inches (257 mm)
27.36 inches (684 mm)
14.88 inches (376 mm)
Covers open
22.8 inches (579 mm)
27.36 inches (684 mm)
37.87 inches (962 mm)
43.2 lb (19.6 kg) with cartridges installed
A-126
sp3800Guide.book Page 127 Monday, January 29, 2007 11:08 AM
Specifications | 127
•
•
Printer Interfaces
USB (1.1 and 2.0 compatible)
Ethernet (10/100 Base TX)
Safety Approvals
Safety standards
EMC
UL 60950-1, CSA 22.2 No. 60950-1
FCC part 15 subpart B, class B, CSA C108.8 class B
Media
Sizes
Weight range
3.5 × 5 inches
4 × 6 inches
5 × 7 inches
5.5 × 8.5 inches
8 × 10 inches
A4 (8.3 × 11.7 inches)
Letter (8.5 × 11 inches)
Legal (8.5 × 14 inches)
10 × 12 inches
B4 (JB4) (10.1 × 14.2 inches)
11 × 14 inches
30 × 40 cm (11.8 × 15.7 inches)
A3 (11.7 × 16.5 inches)
US B (11 × 17 inches)
Super A3/B (13 × 19 inches)
B3 (JB3) (14.2 × 20.3 inches)
16 × 20 inches
40 × 60 cm (15.7 × 23.6 inches)
A2 (16.5 × 23.4 inches)
US C (17 × 22 inches)
17 lb bond up to 24 lb posterboard
A-127
sp3800Guide.book Page 128 Monday, January 29, 2007 11:08 AM
128 | Specifications
Since the quality of any particular brand or type of paper may be changed by the manufacturer at any time, Epson cannot attest to the quality of any non-Epson brand or type of paper. Always test samples of paper stock before purchasing large quantities or printing large jobs.
Poor quality paper may reduce print quality and cause paper jams or other problems. If you encounter problems, switch to a higher grade of paper. Do not use curled, folded, or deckle-edge paper.
Printable Area
Default cut sheet margins are 0.12 inch (3 mm) top, right, and left, and
0.56 inch (15 mm) bottom.
The borderless printing feature allows edge-to-edge printing on some media.
Ink Cartridges
Cartridge life 2 years from production date if unopened; within
6 months after opening package, at 77 °F (25 °C)
Temperature
Capacity
Dimensions
–4 to 104 °F (–20 to 40 °C); 1 month at 104 °F
80 ml
Width: 1.19 inches (30.1 mm)
Depth: 3.68 inches (93.4 mm)
Height: 2.76 inches (70.2mm)
A-128
sp3800Guide.book Page 129 Monday, January 29, 2007 11:08 AM
Index
129
A
Advanced Black and White mode,
B
Black-and-white printing, 59 to 61,
Borderless printing
C
Cable
Canceling print jobs
see Ink cartridges
Cleaning
Color management
Component life, checking, 82 to 83
Configuration options, Windows,
-129
Control panel
changing language, 96 changing measurement units, 96
component life, checking, 82 to 83
ink levels, checking, 82 to 83, 88
messages, 108 to 113 monitoring printer, 108 to 113
restoring default settings, 96
Custom paper size
D
Deleting print jobs
sp3800Guide.book Page 130 Monday, January 29, 2007 11:08 AM
130 | Index
E
Electrical specifications, 126
Environmental specifications, 126
Epson
Error notification, Windows, 77 to 79
Ethernet interface
Expansion setting
F
Firmware, updating, 103 to 105
Flip Horizontal setting
H
High Speed Copies setting, Windows,
High Speed setting
Highlight Point Shift setting, 61, 76
Highlight Tonality setting, 60, 75
I
Ink
maintenance cartridge, 82 to 83
monitoring level, 62 to 63, 76
Ink cartridges
J
L
Layout
Lights, control panel, 108 to 113
-130
sp3800Guide.book Page 131 Monday, January 29, 2007 11:08 AM
M
Macintosh
Advanced Black and White mode,
paper configuration settings, 56
Maintenance cartridge
Margins
Max Optical Density setting, 60, 75
Media Type
Monitoring printer
Motors, checking status, 82 to 83
Index | 131
N
Network setup
O
Optimize Enlargement setting, 70
P
Page Rendering Mode setting, 78
Page setup options, Macintosh,
Paper
configuration settings, 72 to 73,
Paper paths, choosing, 32 to 34
Paper Size setting
Paper Source setting
Pausing print jobs
-131
sp3800Guide.book Page 132 Monday, January 29, 2007 11:08 AM
132 | Index
Print head
Print jobs
Print quality
Print speed, improving in Windows,
Printer
checking status, 62 to 63, 82 to 83
monitoring, 62 to 63, 76 to 79
motors, checking status, 82 to 83
setting up on network, 15 to 28
Printer menus
Problems
inverted image, 119 margin, 119
nothing prints, 118 operational, 117 to 118
R
Resolution
-132
sp3800Guide.book Page 133 Monday, January 29, 2007 11:08 AM
S
Safety
Setting up printer, on network,
Shadow Tonality setting, 60, 75
Software
installing in Macintosh, 17 to 18
installing in Windows, 22 to 28
Specifications
electrical, 126 environmental, 126
ink cartridges, 128 printable area, 128
Speed & Progress utility, 77 to 79
Status Monitor
T
Index | 133
U
UltraChromeK3 ink cartridges, 89
Utility menu
W
Windows
Advanced Black and White mode,
advanced print options, 71 to 73
monitoring preferences, setting,
77 to 79 optimizing print speed, 77 to 79
Speed & Progress utility, 77 to 79 status alerts, 79
-133
sp3800Guide.book Page 134 Monday, January 29, 2007 11:08 AM
134 | Index
-134
