• F2A55-M LK
• F2A55-M LK PLUS
Motherboard
F2A55-M LK Series
E7617
First Edition
August 2012
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from http://support.asus.com/download
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notification to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).
ii
Contents
Safety information....................................................................................................... vi
About this guide......................................................................................................... vii
F2A55-M LK Series specifications summary............................................................ ix
Package contents........................................................................................................ xi
Chapter 1:
1.1
1.1.1
Product highlights............................................................................ 1-1
1.1.3
ASUS Exclusive Features................................................................ 1-2
1.1.2
1.2
1.3
1.5
Motherboard overview.................................................................................. 1-5
1.3.1
Placement direction......................................................................... 1-5
1.3.3
Motherboard layout.......................................................................... 1-6
1.3.4
1.4.1
1.4.2
1.9
APU heatsink and fan assembly installation.................................... 1-9
Overview........................................................................................ 1-11
1.5.3
Installing a DIMM........................................................................... 1-17
Memory configurations................................................................... 1-12
Expansion slots........................................................................................... 1-18
1.6.1
Installing an expansion card.......................................................... 1-18
1.6.3
PCI slot.......................................................................................... 1-18
1.6.5
Configuring an expansion card...................................................... 1-18
PCI Express x1 slot........................................................................ 1-18
PCI Express x16 slot...................................................................... 1-18
Jumpers....................................................................................................... 1-20
Connectors................................................................................................... 1-22
1.8.1
1.8.2
Rear panel ports............................................................................ 1-22
Internal connectors........................................................................ 1-23
Software support......................................................................................... 1-29
1.9.1
1.9.2
Chapter 2:
2.1
APU installation................................................................................ 1-8
1.5.1
1.6.4
1.8
Layout contents................................................................................ 1-7
System memory........................................................................................... 1-11
1.6.2
1.7
Screw holes..................................................................................... 1-5
Accelerated Processing Unit (APU)............................................................. 1-7
1.5.2
1.6
ASUS DIGI+ VRM............................................................................ 1-2
Before you proceed....................................................................................... 1-4
1.3.2
1.4
Product introduction
Special features............................................................................................. 1-1
Installing an operating system....................................................... 1-29
Support DVD information............................................................... 1-29
BIOS information
Managing and updating your BIOS.............................................................. 2-1
2.1.1
ASUS Update utility......................................................................... 2-1
iii
2.1.2
ASUS EZ Flash 2............................................................................. 2-2
2.1.4
ASUS BIOS Updater........................................................................ 2-4
2.1.3
2.2
2.3
BIOS setup program...................................................................................... 2-6
Main menu.................................................................................................... 2-10
2.3.1
System Language [English]........................................................... 2-10
2.3.3
System Time [xx:xx:xx].................................................................. 2-10
2.3.2
2.4
2.3.4
2.4.1
2.4.3
Ai Overclock Tuner [Auto].............................................................. 2-13
Memory Frequency [Auto].............................................................. 2-13
APU Multiplier [Auto]...................................................................... 2-13
NB Frequency [Auto]...................................................................... 2-13
2.4.6
GPU Boost [Auto]........................................................................... 2-14
2.4.7
2.4.8
2.4.9
2.4.10
2.4.11
2.4.12
2.4.13
2.4.14
2.4.15
EPU Power Saving Mode [Disabled]............................................. 2-13
OC Tuner....................................................................................... 2-14
DRAM Timing Control.................................................................... 2-14
CPU Voltage [Offset Mode]............................................................ 2-14
DRAM Voltage [Auto]..................................................................... 2-15
SB 1.1V Voltage [Auto].................................................................. 2-15
1.1VSB Voltage [Auto]................................................................... 2-15
APU1.2V Voltage [Auto]................................................................. 2-15
VDDA Voltage [Auto]...................................................................... 2-15
DIGI+ VRM..................................................................................... 2-15
Advanced menu........................................................................................... 2-17
2.5.1
CPU Configuration......................................................................... 2-17
2.5.3
USB Configuration......................................................................... 2-19
2.5.2
2.5.4
2.5.5
2.5.6
2.5.7
SATA Configuration........................................................................ 2-18
NB Configuration............................................................................ 2-19
Onboard Devices Configuration..................................................... 2-19
APM............................................................................................... 2-21
Network Stack................................................................................ 2-22
Monitor menu............................................................................................... 2-23
2.6.1
CPU Temperature / MB Temperature [xxxºC/xxxºF]...................... 2-23
2.6.3
CPU Q-Fan Control [Enabled]....................................................... 2-23
2.6.2
2.6.4
2.6.5
iv
Security.......................................................................................... 2-10
2.4.4
2.4.5
2.6
System Date [Day xx/xx/xxxx]........................................................ 2-10
Ai Tweaker menu......................................................................................... 2-12
2.4.2
2.5
ASUS CrashFree BIOS 3 utility....................................................... 2-3
CPU / Chassis fan Speed [xxxx RPM] or [Ignore] / [N/A]............... 2-23
CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage................... 2-24
Anti Surge Support [Enabled]........................................................ 2-24
2.7
Boot menu.................................................................................................... 2-25
2.7.1
Bootup NumLock State [On].......................................................... 2-25
2.7.3
Fast Boot [Enabled]....................................................................... 2-26
2.7.2
2.7.4
2.7.5
2.7.6
2.7.7
2.7.8
2.7.9
2.7.10
2.7.11
2.8
2.7.12
Post Delay Time [3 sec]................................................................. 2-26
Wait for ‘F1’ If Error [Enabled]........................................................ 2-26
Option ROM Messages [Force BIOS]............................................ 2-27
Next boot after AC Power Loss [Normal Boot]............................... 2-27
CSM Parameters........................................................................... 2-27
Security Boot parameters.............................................................. 2-27
Setup Mode [EZ Mode].................................................................. 2-29
Boot Option Priorities..................................................................... 2-29
Boot Override................................................................................. 2-29
Tools menu................................................................................................... 2-30
2.8.1
ASUS EZ Flash 2 Utility................................................................. 2-30
2.8.3
ASUS O.C. Profile.......................................................................... 2-30
2.8.2
2.9
Full Screen Logo [Enabled]............................................................ 2-25
ASUS SPD Information.................................................................. 2-30
Exit menu..................................................................................................... 2-31
Appendices
Notices...................................................................................................................... A-1
ASUS contact information....................................................................................... A-3
Safety information
Electrical safety
•
•
•
•
•
•
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
•
•
•
•
•
•
vi
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
Place the product on a stable surface.
If you encounter technical problems with the product, contact a qualified service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and configuring the
motherboard.
How this guide is organized
This guide contains the following parts:
•
•
Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1.
2.
ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
Optional documentation
Your product package may include optional documentation, such as warranty flyers,
that may have been added by your dealer. These documents are not part of the
standard package.
vii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task
IMPORTANT: Instructions that you MUST follow to complete a task..
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text
Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key>
Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3>
viii
If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
F2A55-M LK Series specifications summary
APU
FM2 socket for AMD® A-Series accelerated processors (APU) with AMD
Radeon™ HD 7000 Series graphics, up to 4 CPU cores
AMD® Turbo Core Technology 3.0 support
Microsoft® DirectX® 11 support
• The AMD® Turbo Core Technology 3.0 support depends on the APU types.
• Refer to www.asus.com for the AMD® APU support list.
Chipset
AMD® A55 FCH
Memory
2 x 240-pin DIMM slots support maximum 32GB unbuffered non-ECC
DDR3 2400(O.C.) / 2250(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.C.) /
1866 / 1600 / 1333 / 1066 MHz memory modules
Dual-channel memory architecture
•The maximum 32GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
•When you install a total memory of 4GB capacity or more, Windows® 32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows® 32-bit operating
system.
Graphics
Integrated AMD® Radeon™ HD 7000 series graphics in Trinity APU
Supports DVI-D and D-Sub ports
Supports DVI with max. resolution [email protected]
Supports D-Sub with max. resolution [email protected]
Supports Microsoft® DirectX 11
Expansion slots
1 x PCIe 2.0 x16 slot
2 x PCIe 2.0 x1 slots
1 x PCI slot
Storage / RAID
AMD® A55 FCH:
LAN
Realtek® 8111F PCIe Gigabit LAN controller
Audio
ALC887 8-channel High Definition Audio CODEC
USB
AMD® A55 FCH:
-6 x Serial ATA 3.0Gb/s connectors support RAID 0, RAID 1, RAID 10
and JBOD configurations
• Use a chassis with HD audio module in the front panel to support an 8-channel
audio output.
-10 x USB 2.0/1.1 ports (6 ports at the mid-board, 4 ports at the back
panel)
(continued on the next page)
ix
F2A55-M LK Series specifications summary
ASUS unique
features
ASUS DIGI+ VRM
ASUS 3+2 Phase Power Design
Network iControl
ASUS EPU
ASUS AI Suite II
ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
ASUS TurboV
ASUS Anti-Surge Protection
ASUS Fan Xpert
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
Special features
100% All high quality conductive polymer (F2A55-M LK PLUS only)
Back Panel I/O
ports
1 x PS/2 mouse port (green)
1 x PS/2 keyboard port (purple)
1 x DVI-D port
1 x D-Sub output port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
8-channel audio I/O ports (3-jack)
Internal I/O
connectors /
buttons / switches
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1 ports
6 x SATA 3.0Gb/s connectors
1 x COM connector
1 x LPT connector
1 x CPU fan connector (4-pin)
1 x Chassis fan connector (3-pin)
1 x Front panel audio connector
1 x S/PDIF output connector
1 x System panel connector
1 x Speaker connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM
BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFreen BIOS 3, F12 Printscreen function, F3 Shortcut function and
ASUS DRAM SPD (Serial Presence Detect) memory information
Support DVD
Drivers
ASUS Update
ASUS utilities
Anti-Virus software (OEM version)
Form factor
uATX form factor: 9.6 in x 8.2 in (24.4 cm x 20.8 cm)
Specifications are subject to change without notice.
Package contents
Check your motherboard package for the following items.
20.8cm(8.2in)
KBMS
CPU_FAN
DIGI
+VRM
LAN_USB12
CHA_FAN
F2A55-M LK PLUS
AUDIO
24.4cm(9.6in)
EATXPWR
DDR3 DIMM_B1 (64bit, 240-pin module)
COM
DDR3 DIMM_A1 (64bit, 240-pin module)
USB34
SATA3G_5 SATA3G_6
VGA
SOCKET FM2
KBPWR
USBPW1-4
DVI
ATX12V
SB_PWR
PCIEX16
RTL
8111F
SATA3G_4
PCIEX1_1
Lithium Cell
CMOS Power
AMD®
A55
Super
I/O
PCIEX1_2
SATA3G_3
SATA3G_2
ALC
887 SPDIF_OUT
AAFP
PCI1
LPT
USB910
64Mb
BIOS
USBPW5-10
USB78
USB56
SATA3G_1
CLRTC
SPEAKER F_PANEL
ASUS F2A55-M LK Series motherboard
2 x Serial ATA 3.0 Gb/s
cables
ide
User Gu
1 x I/O Shield
User Guide
Support DVD
•����������������������������������������������������������������������
F2A55-M LK Series motherboards include F2A55-M LK PLUS and F2A55-M LK
models. The package contents vary from models.
•
If any of the above items is damaged or missing, contact your retailer.
•
The illustrated items above are for reference only. Actual product specifications may
vary with different models.
xi
xii
Product introduction
1.1
Special features
1.1.1
Product highlights
1
AMD A-series accelerated processors with AMD® Radeon™ HD 7000 series
graphics
®
This motherboard supports AMD® A-series accelerated processor with AMD® Radeon™
HD 7000 series graphics. This revolutionary APU (Accelerated Processing Unit) combines
processing power and advanced DirectX 11 graphics in one small, energy-efficient design to
enable accelerated performance and an industry-leading visual experience. It features Dualchannel DDR3 memory support and accelerates data transfer rate up to 5GT/s.
AMD® A55 FCH chipset
AMD® A55 FCH is designed to support up to 5GT/s interface speed and 6 x SATA 3.0Gb/s
ports.
Dual-Channel DDR3 2400(O.C.) / 2250(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.
C.) / 1866 / 1600 / 1333 / 1066 MHz Support
The motherboard supports the dual-channel DDR3 memory that features data transfer rates
of DDR3 2400(O.C.) / 2250(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.C.) / 1866 / 1600 /
1333 / 1066 MHz to boost the system’s performance, and to meet the higher bandwidth
requirements of 3D graphics, multimedia, and Internet applications.
8-channel high definition audio
The onboard 8-channel HD audio (High Definition Audio, previously codenamed Azalia)
CODEC enables high-quality 192KHz/24-bit audio output and jack-detect feature that
automatically detects and identifies what types of peripherals are plugged into the audio
I/O jacks and notifies users of inappropriate connection, which means there will be no more
confusion of Line-in, Line-out, and Mic jacks.
Gigabit LAN solution
The onboard LAN controller is a highly integrated Gb LAN controller. It is enhanced with an
ACPI management function to provide efficient power management for advanced operating
systems.
100% All High-quality Conductive Polymer Capacitors (F2A55-M LK PLUS
only)
This motherboard uses all high-quality conductive polymer capacitors for durability, improved
lifespan, and enhanced thermal capacity.
ASUS F2A55-M LK Series
1-1
1.1.2
ASUS DIGI+ VRM
DIGI+POWER CONTROL: Digital Power Design for the APU*
ASUS motherboards using the AMD® A55 chipset employ precise digital voltage regulation
for the APU, called DIGI+ VRM (Voltage Regulation Modules) digital power design. The APU
voltage is adjusted via either carefully developed automated modes, or by using user-defined
profiles. The effect is that DIGI+ VRM technology ensures greater energy efficiency and the
most precise power delivery. Boosted by world-renowned ASUS quality, it creates an ideal
computing platform for a diverse range of applications, from gaming to multimedia or office
work and heavy multitasking. Engineered and tested to assure unmitigated performance,
ASUS A55 boards with DIGI+ VRM remain efficient and accurate, for reliable application in
every scenario.
* DIGI+ VRM functions also available in FM2 socket compatible CPUs
1.1.3
ASUS Exclusive Features
Network iControl
Network iControl is an intuitive one-step network control center that makes it easier for you to
manage your bandwidth and allows you to set, monitor, and schedule the bandwidth priorities
for your network programs. It allows you to automatically connect to a PPPoE network for a
more convenient online experience.
*The ASUS Network iControl feature does not support Windows® XP/Vista operating systems.
ASUS UEFI BIOS (EZ Mode)
ASUS UEFI BIOS, a UEFI compliant architecture, offers the first mouse-controlled intuitive
graphical BIOS interface that goes beyond the traditional keyboard-only BIOS controls,
providing you with more flexibility, convenience, and easy to navigate EFI BIOS than the
traditional BIOS versions. It offers you with dual selectable modes and native support for hard
drives larger than 2.2 TB.
ASUS UEFI BIOS includes the following new features:
•
F12 BIOS snapshot hotkey
•
F3 Shortcut for most accessed information
•
ASUS DRAM SPD (Serial Presence Detect) information detecting faulty DIMMs, and
helping with difficult POST situations.
ASUS TurboV
With its user-friendly interface, ASUS TurboV offers you the adrenaline rush of real-time
overclocking without exiting or rebooting the OS. It also provides you with the ASUS OC
profiles for the best overclocking settings in different scenarios.
EPU
EPU (Energy Processing Unit), the world’s first real-time system power-saving chip,
automatically detects the current system load and intelligently moderates power usage.
It offers a total system-wide energy optimization, reduces fan noise, and extends the
component’s lifespan.
1-2
Chapter 1: Product introduction
ASUS Anti-Surge Protection
This special design protects expensive devices and the motherboard from damage caused
by power surges from switching power supply unit (PSU).
AI Suite II
With its user interface, ASUS AI Suite II integrates several ASUS utilities and allows you to
launch and operate these utilities simultaneously. It allows you to configure the overclocking
settings, adjust the frequencies and related voltages, remotely control the system via a
mobile device, and other easy-to-use helpful utilities.
ASUS Fan Xpert
ASUS Fan Xpert intelligently allows you to adjust the CPU fan speed based on different
ambient temperatures, resulting to a quiet and cool computing environment.
ASUS EZ Flash 2
ASUS EZ Flash 2 is a user-friendly utility that allows you to update the BIOS without using a
bootable floppy disk or an OS-based utility.
ASUS MyLogo2™
Turn your favorite photos into 256-color boot logos to personalize your system.
ASUS CrashFree BIOS 3
ASUS CrashFree BIOS 3 allows you to restore a corrupted BIOS file from a USB storage
device that contains the BIOS file.
C.P.R. (CPU Parameter Recall)
The BIOS C.P.R. feature automatically restores the CPU default settings when the system
hangs due to overclocking failure. C.P.R. eliminates the need to open the system chassis and
clear the RTC data. Simply shut down and reboot the system, and the BIOS automatically
restores the CPU parameters to their default settings.
ErP ready
The motherboard is European Union´s Energy-related Products (ErP) ready, and ErP
requires products to meet certain energy efficiency requirements in regards to energy
consumptions. This is in line with ASUS vision of creating environment-friendly and energyefficient products through product design and innovation to reduce carbon footprint of the
product and thus mitigate environmental impacts.
ASUS F2A55-M LK Series
1-3
1.2
Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
•
Unplug the power cord from the wall socket before touching any component.
•
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
•
Hold components by the edges to avoid touching the ICs on them.
•
Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
•
Before you install or remove any component, switch off the ATX power supply and
detach its power cord. Failure to do so may cause severe damage to the motherboard,
peripherals, or components.
Standby Power LED
The motherboard comes with a standby power LED that lights up to indicate that the system
is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down
the system and unplug the power cable before removing or plugging in any motherboard
component. The illustration below shows the location of the onboard LED.
SB_PWR
F2A55-M LK PLUS
ON
Standby Power
OFF
Powered Off
F2A55-M LK PLUS Onboard LED
1-4
Chapter 1: Product introduction
1.3
Motherboard overview
1.3.1
Placement direction
1.3.2
Screw holes
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
Place six screws into the holes indicated by circles to secure the motherboard to the chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
Place this side towards
the rear of the chassis.
F2A55-M LK PLUS
ASUS F2A55-M LK Series
1-5
1.3.3
Motherboard layout
F2A55-M LK Series motherboards include F2A55-M LK PLUS and F2A55-M LK models.
The package contents vary from models. The layout illustrations in this user guide are for
F2A55-M LK PLUS only.
1
2
3
4
5
6
20.8cm(8.2in)
KBMS
CPU_FAN
DIGI
+VRM
LAN_USB12
CHA_FAN
F2A55-M LK PLUS
AUDIO
SB_PWR
PCIEX16
5
24.4cm(9.6in)
EATXPWR
3
SATA3G_5 SATA3G_6
COM
DDR3 DIMM_B1 (64bit, 240-pin module)
USB34
16
DDR3 DIMM_A1 (64bit, 240-pin module)
VGA
SOCKET FM2
KBPWR
USBPW1-4
DVI
ATX12V
7
8
RTL
8111F
SATA3G_4
PCIEX1_1
Lithium Cell
CMOS Power
AMD®
A55
Super
I/O
PCIEX1_2
SATA3G_3
SATA3G_2
PCI1
ALC
887 SPDIF_OUT
LPT
USB910
64Mb
BIOS
USBPW5-10
USB78
USB56
1-6
SATA3G_1
CLRTC
AAFP
2
7
SPEAKER F_PANEL
15 14
13
12
11
10
9
Chapter 1: Product introduction
1.3.4
Layout contents
Connectors/Jumpers/Slots/LED
Page
2. USB device wake-up (3-pin USBPW1-4, 3-pin USBPW5-10)
1-21
1.Keyboard power (3-pin KBPWR)
3. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
4. AMD FM2 socket
5. CPU and chassis fan connectors (4-pin CPU_FAN and 3-pin CHA_FAN)
6. DDR3 DIMM slots
7. SATA 3.0Gb/s connectors (7-pin SATA3G_1~6)
8. Standby power LED (SB_PWR)
9. System panel connector (10-1 pin F_PANEL)
10. Speaker connector (4-pin SPEAKER)
11. Clear RTC RAM (3-pin CLRTC)
12. USB 2.0 connectors (10-1 pin USB56, USB78, USB910)
13. LPT connector (26-1 pin LPT)
14. Digital audio connector (4-1 pin SPDIF_OUT)
15. Front panel audio connector (10-1 pin AAFP)
16. Serial port connector (10-1 pin COM)
1.4
1-21
1-24
1-7
1-23
1-11
1-25
1-4
1-26
1-26
1-20
1-28
1-25
1-27
1-27
1-28
Accelerated Processing Unit (APU)
This motherboard comes with an FM2 socket designed for AMD® A-series accelerated
processors with AMD® Radeon™ HD 7000 series graphics.
Ensure that you use a APU designed for the FM2 socket. The APU fits in only one correct
orientation. DO NOT force the APU into the socket to prevent bending the pins and
damaging the APU!
F2A55-M LK PLUS
F2A55-M LK PLUS APU socket FM2
ASUS F2A55-M LK Series
1-7
1.4.1
1
3
1-8
APU installation
2
4
Chapter 1: Product introduction
1.4.2
APU heatsink and fan assembly installation
Apply the Thermal Interface Material
to the APU heatsink and APU before
you install the heatsink and fan if
necessary.
To install the APU heatsink and fan assembly
1
2
3
4
ASUS F2A55-M LK Series
5
1-9
To uninstall the APU heatsink and fan assembly
1
3
2
4
5
1-10
Chapter 1: Product introduction
1.5
System memory
1.5.1
Overview
This motherboard comes with two Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched
differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for
better performance with less power consumption.
DIMM_A1
DIMM_B1
The figure illustrates the location of the DDR3 DIMM sockets:
Channel
F2A55-M LK PLUS
Channel A
Channel B
Sockets
DIMM_A1
DIMM_B1
F2A55-M LK PLUS 240-pin DDR3 DIMM sockets
ASUS F2A55-M LK Series
1-11
1.5.2
Memory configurations
You may install 1GB, 2GB, 4GB, and 8GB unbuffered non-ECC DDR3 DIMMs into the DIMM
sockets.
•
You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel configuration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
•
We recommend that you install the memory modules from the blue slots for better
overclocking capability.
•
Always install DIMMs with the same CAS latency. For optimal compatibility, we
recommend that you install memory modules of the same version or date code (D/C)
from the same vendor. Check with the retailer to get the correct memory modules.
•
Due to the memory address limitation on 32-bit Windows® OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
-Install a maximum of 3GB system memory if you are using a 32-bit Windows®
OS.
-Use a 64-bit Windows® OS if you want to install 4GB or more memory on the
motherboard.
•
This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less.
•
The maximum 32GB memory capacity can be supported with 16GB or above DIMMs.
ASUS will update the memory QVL once the DIMMs are available in the market.
•
The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked
or at a higher frequency, refer to section 2.4 Ai Tweaker menu for manual memory
frequency adjustment.
•
For system stability, use a more efficient memory cooling system to support a full
memory load (2 DIMMs) or overclocking condition.
F2A55-M LK Series Motherboard Qualified Vendors Lists (QVL)
DDR3 2400 (O.C.) MHz capability
Vendors
Part No.
Size
SS/DS Chip Brand
G.SKILL F3-19200CL9D-4GBPIS(XMP) 4GB(2x 2GB) DS
KINGMAX FLLE88F-C8KKAA HAIS(XMP) 2GB
SS
Team
TXD34096M2400HC9N-L
4GB
DS
Chip NO.
Timing
9-11-9-28
10-11-10-30
SEC 128 HCH9 K4B2G0846D 9-11-11-28
DIMM socket
Voltage support (Optional)
1 DIMM 2 DIMMs
1.65V
•
1.8V
•
1.65V
•
•
DDR3 2250 (O.C.) MHz capability
1-12
Vendors
Part No.
Size
SS/DS
Chip Brand Chip NO.
Timing
Voltage
KINGSTON
KHX2250C9D3T1K2/4GX(XMP)
4GB(2x 2GB)
DS
-
-
1.65V
-
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
•
•
Chapter 1: Product introduction
DDR3 2200 (O.C.) MHz capability
Vendors
Part No.
Size
SS/DS Chip Brand
Chip NO. Timing
Voltage
GEIL
GEIL
KINGMAX
KINGMAX
GET34GB2200C9DC(XMP)
GET38GB2200C9ADC(XMP)
FLKE85F-B8KJAA-FEIS(XMP)
FLKE85F-B8KJA FEIH(XMP)
2GB
4GB
2GB
4GB(2 x 2GB)
DS
DS
DS
DS
-
1.65V
1.65V
1.5V-1.7V
-
9-10-9-28
9-11-9-28
-
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
•
•
•
•
•
DDR3 2133 (O.C.) MHz capability
Vendors
Part No.
Size
SS/ Chip
DS Brand
Chip NO.
A-DATA
CORSAIR
CORSAIR
CORSAIR
CORSAIR
G.SKILL
GEIL
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
AX3U2133GC2G9B-DG2(XMP)
CMT16GX3M4X2133C9(XMP 1.3)
CMT4GX3M2A2133C9(XMP)
CMT4GX3M2B2133C9(XMP)
CMT8GX3M2B2133C9(XMP)
F3-17000CL9Q-16GBZH(XMP1.3)
GU34GB2133C9DC(XMP)
KHX2133C11D3T1K2/16GX(XMP)
KHX21C11T1BK2/16X(XMP)
KHX2133C9AD3T1K2/4GX(XMP)
KHX2133C9AD3T1K4/8GX(XMP)
KHX2133C9AD3T1FK4/8GX(XMP)
KHX21C11T1BK2/16X(XMP)
KHX21C11T1BK2/8X(XMP)
2GB
16GB(4GB x 4)
4GB(2 x 2GB)
4GB(2 x 2GB)
8GB(4GB x 2)
16GB(4GB x 4)
4GB(2 x 2GB)
16GB(8GB x 2)
16GB(8GB x 2)
4GB(2 x 2GB)
8GB(4 x 2GB)
8GB(4 x 2GB)
16GB(8GB x 2)
8GB(4GB x 2)
SS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
-
Team
TXD34096M2133HC9N-L
4GB
128
DS SEC
HCH9
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
9-11-9-27 1.55~1.75V
•
•
9-11-10-27 1.50V
•
•
9-10-9-24 1.65V
•
•
9-10-9-27 1.50V
•
•
9-11-9-27 1.50V
•
•
9-11-10-28 1.65V
•
•
9-9-9-28
1.65V
•
•
1.6V
•
•
1.6V
•
•
1.65V
•
•
9-11-9-27 1.65V
•
1.65V
•
•
1.6V
•
•
1.6V
•
•
Timing
Voltage
K4B2G0846D 9-11-11-28 1.65V
•
•
DDR3 2000 (O.C.) MHz capability
Vendors
Part No.
Size
SS/DS Chip
Brand
Chip NO. Timing
Voltage
CORSAIR
CORSAIR
G.SKILL
G.SKILL
GEIL
KINGSTON
KINGSTON
KINGSTON
CMZ4GX3M2A2000C10(XMP)
CMT6GX3M3A2000C8(XMP)
F3-16000CL9D-4GBFLS(XMP)
F3-16000CL6T-6GBPIS(XMP)
GUP34GB2000C9DC(XMP)
KHX2000C9AD3W1K2/4GX(XMP)
KHX2000C9AD3W1K3/6GX(XMP)
KHX2000C9AD3T1K3/6GX(XMP)
4GB(2 x 2GB)
6GB(3 x 2GB)
4GB(2 x 2GB)
6GB(3 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
SS
DS
DS
DS
DS
DS
DS
DS
-
1.50V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
-
10-10-10-27
8-9-8-24
9-9-9-24
6-9-6-24
9-9-9-28
-
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DDR3 1866 MHz capability
DIMM socket
Voltage support (Optional)
1 DIMM 2 DIMMs
9-9-9-24
1.65V
•
•
9-9-9-24
1.65V
•
•
9-10-9-27 1.50V
•
•
9-10-9-28 1.5V
•
•
10-11-10-30 1.5V
•
•
9-10-9-28 1.5V
•
•
9-9-9-24
1.6V
•
•
1.65V
•
•
1.65V
•
•
1.5V
•
•
1.65V
•
•
Vendors
Part No.
Size
SS/DS Chip
Brand
Chip NO. Timing
CORSAIR
CORSAIR
CORSAIR
G.SKILL
G.SKILL
G.SKILL
G.SKILL
KINGSTON
KINGSTON
KINGSTON
KINGSTON
CMT4GX3M2A1866C9(XMP)
CMT6GX3MA1866C9(XMP)
CMZ8GX3M2A1866C9(XMP)
F3-14900CL9Q-16GBZL(XMP1.3)
F3-14900CL10Q2-64GBZLD(XMP1.3)
F3-14900CL9D-8GBXL(XMP)
F3-14900CL9Q-8GBXL(XMP)
KHX1866C9D3K4/16GX(XMP)
KHX1866C9D3T1K3/6GX(XMP)
KHX1866C11D3P1K2/8G
KHX1866C9D3K2/8GX(XMP)
4GB(2 x 2GB)
6GB(3 x 2GB)
8GB(2 x 4GB)
16GB(4GB x 4)
64GB(8GB x 8)
8GB(2 x 4GB)
8GB(2GB x 4)
16GB(4GB x 4)
6GB(3 x 2GB)
8GB(4GB x 2)
8GB(4GB x 2)
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
-
ASUS F2A55-M LK Series
-
1-13
DDR3 1600 MHz capability
1-14
DIMM socket
support
(Optional)
1 DIMM 2 DIMMs
Vendors
Part No.
Size
SS/ Chip
DS Brand
Chip NO.
Timing
Voltage
A-DATA
AM2U16BC2P1
2GB
SS
A-DATA
-
-
•
A-DATA
AM2U16BC4P2
4GB
DS
A-DATA
-
-
•
•
A-DATA
A-DATA
AX3U1600GC4G9-2G(XMP)
AX3U1600XC4G79-2X(XMP)
8GB(2 x 4GB)
8GB(2 x 4GB)
DS
DS
9-9-9-24
7-9-7-21
1.55V-1.75V
1.55V-1.75V
•
•
•
•
Apacer
78.B1GE3.9L10C
4GB
DS
-
-
•
•
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
CORSAIR
Crucial
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
G.SKILL
GEIL
GEIL
CMD12GX3M6A1600C8(XMP)
CMZ32GX3M4X1600C10(XMP)
CMP4GX3M2A1600C8(XMP)
CMP4GX3M2A1600C9(XMP)
CMP4GX3M2C1600C7(XMP)
CMX4GX3M2A1600C9(XMP)
CMX4GX3M2A1600C9(XMP)
TR3X6G1600C8 G(XMP)
TR3X6G1600C8D G(XMP)
TR3X6G1600C9 G(XMP)
CMP8GX3M2A1600C9(XMP)
CMZ8GX3M2A1600C7R(XMP)
CMX8GX3M4A1600C9(XMP)
BL25664BN1608.16FF(XMP)
F3-12800CL7D-4GBRH(XMP)
F3-12800CL7D-4GBECO(XMP)
F3-12800CL7D-4GBRM(XMP)
F3-12800CL8D-4GBRM(XMP)
F3-12800CL9D-4GBECO(XMP)
F3-12800CL9D-4GBRL(XMP)
F3-12800CL9T-6GBNQ(XMP)
F3-12800CL7D-8GBRH(XMP)
F3-12800CL8D-8GBECO(XMP)
F3-12800CL9D-8GBRL(XMP)
GET316GB1600C9QC(XMP)
GV34GB1600C8DC(XMP)
12GB(6 x 2GB)
32GB(8GB x 4)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
8GB(2 x 4GB)
8GB(2 x 4GB)
8GB(4 x 2GB)
6GB(3 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
6GB(3 x 2GB)
8GB(2 x 4GB)
8GB(2 x 4GB)
8GB(2 x 4GB)
16GB(4 x 4GB)
2GB
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
SS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
Apacer
KZZC
-
8-8-8-24
10-10-10-27
8-8-8-24
9-9-9-24
7-8-7-20
9-9-9-24
9-9-9-24
8-8-8-24
8-8-8-24
9-9-9-24
9-9-9-24
7-8-7-20
9-9-9-24
7-7-7-24
7-7-8-24
7-8-7-24
8-8-8-24
9-9-9-24
9-9-9-24
9-9-9-24
7-8-7-24
8-8-8-24
9-9-9-24
9-9-9-28
8-8-8-28
1.65V
1.50V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
1.65V
1.50V
1.65V
1.6V
XMP 1.35V
1.6V
1.60V
XMP 1.35V
1.5V
1.5V~1.6V
1.6V
XMP 1.35V
1.5V
1.6V
1.6V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HYNIX
HMT351U6CFR8C-PB
4GB
DS
HYNIX
-
-
•
•
KINGMAX
KINGMAX
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
FLGE85F-B8KJ9A FEIS(XMP)
FLGE85F-B8MF7 MEEH(XMP)
KHX1600C9D3P1K2/4G
KHX1600C9D3K3/12GX(XMP)
KHX1600C9D3T1BK3/12GX(XMP)
KHX1600C9D3K4/16GX(XMP)
KHX1600C10D3B1K2/16G
KHX16C9K2/16
KHX1600C9AD3/2G
2GB
2GB
4GB(2 x 2GB)
12GB(3 x 4GB)
12GB(3 x 4GB)
16GB(4GB x 4)
16GB(8GB x 2)
16GB(8GB x 2)
2GB
DS
DS
SS
DS
DS
DS
DS
DS
DS
-
7
9-9-9-27
9-9-9-27
-
1.5V
1.65V
1.65V
1.65V
1.5V
1.5V
1.65V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
KINGSTON KVR1600D3N11/2G-ES
2GB
DS
KTC
11-11-11-28 1.35V-1.5V
•
•
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
KINGSTON
Super
Talent
KHX1600C7D3K2/4GX(XMP)
KHX1600C8D3K2/4GX(XMP)
KHX1600C8D3T1K2/4GX(XMP)
KHX1600C9D3K2/4GX(XMP)
KHX1600C9D3LK2/4GX(XMP)
KHX1600C9D3X2K2/4GX(XMP)
KHX1600C9D3T1K3/6GX(XMP)
KHX1600C9D3K3/6GX(XMP)
KHX1600C9D3T1BK3/6GX(XMP)
KHX1600C9D3K2/8GX(XMP)
KHX1600C9D3P1K2/8G
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB(2 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
6GB(3 x 2GB)
8GB(2 x 4GB)
8GB(2 x 4GB)
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
DS
-
3CCD-1509A
EL1126T
3CCD-1509A
EL1126T
AM5D5908D
EQSCK
H5TQ2G83
CFR PBC
D1288JPN
DPLD9U
-
8
8
9
9
9-9-9-27
9
9-9-9-27
9-9-9-27
-
1.65V
1.65V
1.65V
1.65V
XMP 1.35V
1.65V
1.65V
1.65V
1.65V
1.65V
1.5V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WA160UX6G9
6GB(3 x 2GB)
DS
-
-
9
-
•
•
SanMax
SMD-4G68HP-16KZ
4GB
DS
HYNIX
-
-
•
•
Apacer
78.B1GE3.9L10C
4GB
DS
H5TQ2G83
BFR PBC
Apacer
AM5D5908
KZZC
DEQSCK
Elixir 1213 N2CB4G8
BOBN-DG
-
-
•
•
-
1.5V
1.5V
•
•
•
•
-
-
•
•
KINGSTON KHX1600C10D3B1K2/16G
KINGSTON KHX16C9K2/16
16GB(8GB x 2) DS
16GB(8GB x 2) DS
Elixir
8GB
M2X8G64CB8HB5N-DG(XMP)
DS
•
Chapter 1: Product introduction
DDR3 1333 MHz capability
Vendors
Part No.
Size
SS/ Chip Brand Chip NO.
DS
A-DATA
A-DATA
A-DATA
AD3U1333C2G9
AM2U139C2P1
AX3U1333C2G9-BP
2GB
2GB
2GB
SS
SS
SS
A-DATA
AXDU1333GC2G9-2G(XMP)
A-DATA
A-DATA
A-DATA
Apacer
Apacer
Apacer
Apacer
CORSAIR
CORSAIR
CORSAIR
AD63I1C1624EV
AM2U139C4P2
SU3U1333W8G9-B
78.A1GC6.9L1
78.A1GC6.9L1
AU02GFA33C9NBGC
78.B1GDE.9L10C
TR3X6G1333C9 G
CMD24GX3M6A1333C9(XMP)
TW3X4G1333C9D G
CORSAIR
CORSAIR
CORSAIR
Crucial
Crucial
Timing
A-DATA
ADATA
-
3CCD-1509HNA1126L 3CCD-1509A EL1127T -
4GB(2 x 2GB) SS
-
-
9-9-9-24
4GB
4GB
8GB
2GB
2GB
2GB
4GB
6GB(3x 2GB)
24GB(6x4GB)
4GB(2 x 2GB)
DS
DS
DS
DS
DS
DS
DS
SS
DS
DS
A-Data
ADATA
ELPIDA
Apacer
Apacer
Apacer
Apacer
-
9
9-9-9-24
9-9-9-24
9-9-9-24
CM3X4GA1333C9N2
4GB
DS
CORSAIR
CMX4GX3M1A1333C9
CMD8GX3M4A1333C7
CT25664BA1339.16FF
BL25664BN1337.16FF (XMP)
4GB
8GB(4 x 2GB)
2GB
6GB(3 x 2GB)
DS
DS
DS
DS
Micron
-
3CCA-1509A
3CCD-1509A EL1127T
J4208BASE-DJ-F
AM5D5808DEWSBG
AM5D5808FEQSBG
AM5D5808APQSBG
AM5D5908CEHSBG
256MBDCJGELC040
1136
9KF27D9KPT
-
ELPIDA
EBJ21UE8EDF0-DJ-F
2GB
DS
ELPIDA
J1108EDSE-DJ-F
-
G.SKILL
G.SKILL
F3-10666CL8D-4GBECO(XMP) 4GB(2 x 2GB) DS
F3-10666CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS
-
-
8-8-8-24
7-7-7-21
GEIL
GG34GB1333C9DC
4GB(2 x 2GB) DS
GEIL
GL1L128M88BA12N
9-9-9-24
GEIL
GEIL
Hynix
GV34GB1333C9DC
GVP34GB1333C7DC
HMT325U6BFR8C-H9
4GB(2 x 2GB) DS
4GB(2 x 2GB) DS
2GB
SS
Hynix
H5TQ2G83BFRH9C
9-9-9-24
7-7-7-24
-
Hynix
HMT125U6TFR8A-H9
2GB
DS
Hynix
H5TC1G83TFRH9A
-
4GB
2GB
2GB
2GB
2GB
4GB
4GB
2GB
2GB
DS
SS
SS
SS
DS
DS
DS
SS
SS
Hynix
KINGMAX
KINGMAX
KINGMAX
KINGMAX
KINGMAX
KINGMAX
Hynix
Micron
H5TQ2G83BFRH9C
KFC8FMFXF-DXX-15A
KFC8FNLXF-DXX-15A
KFC8FNMXF-BXX-15A
KKB8FNWBFGNX-26A
KFC8FNLXF-DXX-15A
KFC8FNMXF-BXX-15A
H5TQ2G83AFRH9C
IID77 D9LGK
2GB
SS
ELPIDA
2GB
2GB
2GB
DS
DS
DS
ELPIDA
KTC
ELPIDA
2GB
DS
KTC
2GB
DS
4GB(2 x 2GB)
4GB(2 x 2GB)
4GB
4GB
4GB
4GB
DS
DS
DS
DS
DS
DS
ELPIDA
ELPIDA
KTC
Hynix
4GB
2GB
2GB
2GB
4GB
4GB
2GB
2GB
2GB
4GB
2GB
4GB
6GB(3x 2GB)
2GB
Hynix
KINGMAX
KINGMAX
KINGMAX
KINGMAX
KINGMAX
KINGMAX
KINGSTON
KINGSTON
HMT351U6BFR8C-H9
FLFE85F-C8KF9 CAES
FLFE85F-C8KL9 NAES
FLFE85F-C8KM9 NAES
FLFE85F-B8KL9 NEES
FLFF65F-C8KL9 NEES
FLFF65F-C8KM9 NEES
KVR1333D3N9/2G(low profile)
KVR1333D3S8N9/2G
KINGSTON KVR1333D3S8N9/2G-SP(low
profile)
KINGSTON KVR1333D3N9/2G(low profile)
KINGSTON KVR1333D3N9/2G
KINGSTON KVR1333D3N9/2G
KINGSTON KVR1333D3N9/2G-SP(low
profile)
KINGSTON KVR1333D3N9/2G-SP(low
profile)
KINGSTON KHX1333C7D3K2/4GX(XMP)
KINGSTON KHX1333C9D3UK2/4GX(XMP)
KINGSTON KVR1333D3N9/4G(low profile)
KINGSTON KVR1333D3N9/4G(low profile)
KINGSTON KVR1333D3N9/4G
KINGSTON KVR1333D3N9/4G
KINGSTON KVR1333D3N9/4G-SP(low
profile)
Micron
MT8JTF25664AZ-1G4D1
Micron
MT8JTF25664AZ-1G4M1
Micron
MT16JTF25664AZ-1G4F1
Micron
MT16JTF51264AZ-1G4D1
NANYA
NT4GC64B8HG0NF-CG
PSC
AL8F8G73F-DJ2
SAMSUNG M378B5773DH0-CH9
SAMSUNG M378B5673FH0-CH9
SAMSUNG M378B5273CH0-CH9
Super Talent W1333UB2GS
Super Talent W1333UB4GS
Super Talent W1333UX6GM
KINGSTEK KSTD3PC-10600
ASUS F2A55-M LK Series
Voltage
1.25V1.35V(low
voltage)
1.50V
1.60V
1.50V
DIMM socket
support
(Optional)
1 DIMM 2 DIMMs
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
9-9-9-24 -
•
•
9-9-9-24
7-7-7-20
9
7-7-7-24
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
9
-
1.50V
1.60V
1.65V
1.35V(low
voltage)
XMP 1.35V
1.5V
1.3V(low
voltage)
1.5V
1.5V
1.35V(low
voltage)
1.5V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
J2108BCSE-DJ-F
-
1.5V
•
•
J1108BFBG-DJ-F
D1288JPNDPLD9U
J1108BDSE-DJ-F
9
9
9
1.5V
1.5V
1.5V
•
•
•
•
•
•
D1288JEMFNGD9U
-
1.5V
•
•
KINGSTON D1288JPSFPGD9U
-
1.5V
•
•
J2108BCSE-DJ-F
J2108BCSE-DJ-F
D2568JENCNGD9U
H5TQ2G83AFR
7
9
9
-
1.65V
XMP 1.25V
1.5V
1.5V
1.5V
-
•
•
•
•
•
•
•
•
•
•
•
•
DS
KINGSTON D2568JENCPGD9U
-
1.5V
•
•
SS
SS
DS
DS
DS
DS
SS
DS
DS
DS
DS
DS
SS
Micron
MICRON
Micron
Micron
NANYA
PSC
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
Micron
MICRON
9
9
9-9-9-24
-
1.5V
-
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
OJD12D9LGK
IJM22 D9PFJ
9KF27D9KPT
OLD22D9LGK
NT5CB256M8GN-CG
A3P1GF3FGF
K4B2G0846D
K4B1G0846F
K4B2G0846C
K4B1G0846F
K4B2G0846C
0BF27D9KPT
PE911-125E
1-15
DDR3 1066 MHz capability
Vendors
Part No.
Size
SS/DS Chip Brand
Chip NO.
Timing
Voltage
Crucial
CT12864BA1067.8FF
1GB
SS
Micron
9GF22D9KPT
7
ELPIDA
EBJ21UE8EDF0-AE-F
2GB
DS
ELPIDA
J1108EDSE-DJ-F
-
KINGSTON KVR1066D3N7/1G(low profile) 1GB
KINGSTON KVR1066D3N7/4G
4GB
SS
DS
ELPIDA
Hynix
J1108BFSE-DJ-F
H5TQ2G83AFR
7
7
1.35V(low
voltage)
1.5V
1.5V
DIMM socket support
(Optional)
1 DIMM
2 DIMMs
•
•
•
•
•
•
•
•
Side(s): SS - Single-sided DS - Double-sided
DIMM support:
•
1 DIMM: Supports one module inserted into any slot as Single-channel memory
configuration.
•
2 DIMMs: Supports two modules inserted into both the blue slots as one pair of Dualchannel memory configuration.
Visit the ASUS website at www.asus.com for the latest QVL.
1-16
Chapter 1: Product introduction
1.5.3
Installing a DIMM
1
2
3
To remove a DIMM
B
A
A
ASUS F2A55-M LK Series
1-17
1.6
Expansion slots
In the future, you may need to install expansion cards. The following sub‑sections describe
the slots and the expansion cards that they support.
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
1.6.1
Installing an expansion card
To install an expansion card:
1.
Before installing the expansion card, read the documentation that came with it and
make the necessary hardware settings for the card.
2.
Remove the system unit cover (if your motherboard is already installed in a chassis).
3.
Remove the bracket opposite the slot that you intend to use. Keep the screw for later
use.
4.
Align the card connector with the slot and press firmly until the card is completely
seated on the slot.
5.
Secure the card to the chassis with the screw you removed earlier.
6.
Replace the system cover.
1.6.2
Configuring an expansion card
After installing the expansion card, configure it by adjusting the software settings.
1.
Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for
information on BIOS setup.
2.
Assign an IRQ to the card.
3.
Install the software drivers for the expansion card.
When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that
the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI
groups, making the system unstable and the card inoperable.
1.6.3
PCI slot
1.6.4
PCI Express x1 slot
1.6.5
PCI Express x16 slot
The PCI slot supports cards such as a LAN card, SCSI card, USB card, and other cards that
comply with PCI specifications.
This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that
comply with the PCI Express specifications.
This motherboard supports one PCI Express x16 graphics card that complies with the PCI
Express specifications.
1-18
Chapter 1: Product introduction
IRQ assignments for this motherboard
A
B
C
D
E
F
G
H
PCIEx16_1
–
–
shared
–
–
–
–
–
PCIEx1_1
shared
–
–
–
–
–
–
–
PCIEx1_2
–
shared
–
–
–
–
–
–
OnChip IGP
–
shared
–
–
–
–
–
–
–
shared
shared
–
PCI1 slot
Realtek LAN controller
HD audio
SATA controller
Onboard USB2.0 controller
ASUS F2A55-M LK Series
–
–
–
–
shared
–
–
–
–
–
–
–
–
–
–
–
–
–
–
shared
–
–
–
–
–
–
–
–
shared
–
–
–
–
–
–
–
1-19
1.7
1.
Jumpers
Clear RTC RAM (CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system passwords.
CLRTC
F2A55-M LK PLUS
1
2
2
3
Normal
(Default)
Clear RTC
F2A55-M LK PLUS Clear RTC RAM
To erase the RTC RAM:
1.
Turn OFF the computer and unplug the power cord.
2.
Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5~10 seconds, then move the cap back to pins 1-2.
3.
Plug the power cord and turn ON the computer.
4.
Hold down the <Del> key during the boot process and enter BIOS setup to
reenter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
1-20
•
If the steps above do not help, remove the onboard battery and move the jumper
again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the
battery.
•
You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the CPU Parameter Recall (C.P.R) feature.
Shut down and reboot the system so the BIOS can automatically reset parameter
settings to default values.
Chapter 1: Product introduction
2.
Keyboard power (3-pin KBPWR)
This jumper allows you to enable or disable the keyboard wake-up feature. When you
set this jumper to pins 2–3 (+5VSB), you can wake up the computer by pressing a key
on the keyboard. This feature requires an ATX power supply that can supply at least 1A
on the +5VSB lead, and a corresponding setting in the BIOS.
2 3
1
2
KBPWR
F2A55-M LK PLUS
+5V
(Default)
+5VSB
F2A55-M LK PLUS Keyboard power setting
3.
USB device wake-up (3-pin USBPW1-4, 3-pin USBPW5-10)
Set these jumpers to +5V to wake up the computer from S1 sleep mode (CPU stopped,
DRAM refreshed, system running in low power mode) using the connected USB
devices. Set to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU,
DRAM in slow refresh, power supply in reduced power mode).
1
2
2 3
USBPW1-4
+5V
F2A55-M LK PLUS
+5VSB
(Default)
USBPW5-10
1
2
+5V
(Default)
2 3
+5VSB
F2A55-M LK PLUS USB device wake-up
•
The USB device wake-up feature requires a power supply that can provide 500mA on
the +5VSB lead for each USB port; otherwise, the system would not power up.
•
The total current consumed must NOT exceed the power supply capability (+5VSB)
whether under normal condition or in sleep mode.
ASUS F2A55-M LK Series
1-21
1.8
Connectors
1.8.1
Rear panel ports
1
2
10
9
8
7
6
3 4
5
1.
PS/2 Mouse port (green). This port is for a PS/2 mouse.
2.
LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub.
LAN port LED indications
Activity/Link LED
Status
Description
OFF
No link
ORANGE
Linked
BLINKING
Data activity
Speed LED
Status
Description
OFF
10Mbps connection
ORANGE 100Mbps connection
GREEN
1Gbps connection
ACT/LINK SPEED
LED
LED
LAN port
3.
Line In port (light blue). This port connects to the tape, CD, DVD player, or other
audio sources.
4.
Line Out port (lime). This port connects to a headphone or a speaker. In the 4, 6, and
8-channel configurations, the function of this port becomes Front Speaker Out.
5.
Microphone port (pink). This port connects to a microphone.
Refer to the audio configuration table below for the function of the audio ports in 2, 4, 6, or
8-channel configuration.
Audio 2, 4, 6, or 8-channel configuration
Headset
4-channel
6-channel
2-channel
Light Blue (Rear panel)
Line In
Rear Speaker Out Rear Speaker Out
Lime (Rear panel)
Line Out Front Speaker Out Front Speaker Out
Pink (Rear panel)
Mic In
Mic In
Bass/Center
Lime (Front panel)
—
—
—
Port
8-channel
Rear Speaker Out
Front Speaker Out
Bass/Center
Side Speaker Out
To configure an 8-channel audio output:
1-22
Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
Chapter 1: Product introduction
6.
USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports are for USB
2.0/1.1 devices.
7.
USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are for USB
2.0/1.1 devices.
8.
Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
9.
DVI-D port. This port is for any DVI-D compatible device. DVI-D can’t be converted to
output RGB Signal to CRT and isn’t compatible with DVI-I.
10. PS/2 Keyboard port (purple). This port is for a PS/2 keyboard.
1.8.2
1.
Internal connectors
CPU and chassis fan connectors (4-pin CPU_FAN, and 3-pin CHA_FAN)
Connect the fan cables to the fan connectors on the motherboard, ensuring that the
black wire of each cable matches the ground pin of the connector.
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CPU_FAN
CHA_FAN
Rotation
+12V
GND
F2A55-M LK PLUS
F2A55-M LK PLUS Fan connectors
DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside
the system may damage the motherboard components. These are not jumpers! DO NOT
place jumper caps on the fan connectors.
•
The CPU_FAN connector supports a CPU fan of maximum 2A (24 W) fan power.
•
Only the CPU_FAN connector support the ASUS Fan Xpert feature.
ASUS F2A55-M LK Series
1-23
2.
ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
These connectors are for an ATX power supply. The plugs from the power supply are
designed to fit these connectors in only one orientation. Find the proper orientation and
push down firmly until the connectors completely fit.
GND
GND
ATX12V
F2A55-M LK PLUS
+12V DC
+12V DC
PIN 1
EATXPWR
+3 Volts
+12 Volts
+12 Volts
+5V Standby
Power OK
GND
+5 Volts
GND
+5 Volts
GND
+3 Volts
+3 Volts
GND
+5 Volts
+5 Volts
+5 Volts
-5 Volts
GND
GND
GND
PSON#
GND
-12 Volts
+3 Volts
PIN 1
F2A55-M LK PLUS ATX power connectors
1-24
•
We recommend that you use an ATX 12V Specification 2.0‑compliant power supply
unit (PSU) with a minimum of 300W power rating. This PSU type has 24-pin and 4-pin
power plugs.
•
If you intend to use a PSU with 20-pin and 4-pin power plugs, ensure that the 20-pin
power plug can provide at least 15 A on +12 V and that the PSU has a minimum
power rating of 300W. The system may become unstable or may not boot up if the
power is inadequate.
•
DO NOT forget to connect the 4-pin ATX +12V power plug. Otherwise, the system will
not boot up.
•
We recommend that you use a PSU with higher power output when configuring a
system with more power-consuming devices or when you intend to install additional
devices. The system may become unstable or may not boot up if the power is
inadequate.
•
If you are uncertain about the minimum power supply requirement for your system,
refer to the Recommended Power Supply Wattage Calculator at http://support.asus.
com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details.
Chapter 1: Product introduction
3.
Serial ATA 3.0 Gb/s connectors (7-pin SATA3G 1~6)
These connectors are for the Serial ATA 3.0 Gb/s signal cables for Serial ATA hard
disk drives and optical disc drives. If you installed Serial ATA hard disk drives, you can
create a RAID 0, RAID 1, or RAID 10 configuration through the onboard controller.
SATA3G_6
GND
RSATA_RXP4
RSATA_RXN4
GND
RSATA_TXN4
RSATA_TXP4
GND
SATA3G_4
SATA3G_5
GND
RSATA_RXP3
RSATA_RXN3
GND
RSATA_TXN3
RSATA_TXP3
GND
SATA3G_3
GND
RSATA_RXP6
RSATA_RXN6
GND
RSATA_TXN6
RSATA_TXP6
GND
GND
RSATA_RXP5
RSATA_RXN5
GND
RSATA_TXN5
RSATA_TXP5
GND
GND
RSATA_RXP2
RSATA_RXN2
GND
RSATA_TXN2
RSATA_TXP2
GND
SATA3G_2
F2A55-M LK PLUS
GND
RSATA_RXP1
RSATA_RXN1
GND
RSATA_TXN1
RSATA_TXP1
GND
SATA3G_1
F2A55-M LK PLUS SATA 3.0Gb/s connectors
•
These connectors are set to AHCI mode by default. If you intend to create a Serial ATA
RAID set using these connectors, set the type of the SATA connectors in the BIOS to
[RAID]. See section 2.5.2 SATA Configuration for details.
•
You must install Windows® XP Service Pack 3 or later version before using Serial
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
Windows® XP SP3 or later version.
•
When using hot-plug and NCQ, set the type of the SATA connectors in the BIOS to
[AHCI]. See section 2.5.2 SATA Configuration for details.
4.
LPT connector (26-1 pin LPT)
The LPT (Line Printing Terminal) connector supports devices such as a printer. LPT
standardizes as IEEE 1284, which is the parallel port interface on IBM PC-compatible
computers.
AFD
ERR#
INIT#
SLIN#
GND
GND
GND
GND
GND
GND
GND
GND
LPT
PIN 1
STB#
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
ACK#
BUSY
PE
SLCT
F2A55-M LK PLUS
F2A55-M LK PLUS LPT connector
ASUS F2A55-M LK Series
1-25
5.
System panel connector (10-1 pin PANEL)
This connector supports several chassis-mounted functions.
F_PANEL
PWRBTN
PLED+
PLEDPWR
GND
PLED
HD_LED+
HD_LEDGround
Reset
PIN 1
F2A55-M LK PLUS
+HDLED
RESET
F2A55-M LK PLUS System panel connector
•
•
•
•
6.
System power LED (2-pin PLED)
This 2-pin connector is for the system power LED. Connect the chassis power LED
cable to this connector. The system power LED lights up when you turn on the system
power, and blinks when the system is in sleep mode.
Hard disk drive activity LED (2-pin +IDELED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable
to this connector. The IDE LED lights up or flashes when data is read from or written to
the HDD.
ATX power button/soft-off button (2-pin PWRBTN)
This 2-pin connector is for the system power button.
Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without
turning off the system power.
Speaker connector (4-pin SPEAKER)
The 4-pin connector is for the chassis-mounted system warning speaker. The speaker
allows you to hear system beeps and warnings.
+5V
GND
GND
Speaker Out
SPEAKER
F2A55-M LK PLUS
PIN 1
F2A55-M LK PLUS Speaker out connector
1-26
Chapter 1: Product introduction
Digital audio connector (4-1 pin SPDIF_OUT)
F2A55-M LK PLUS
SPDIFOUT
GND
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port.
+5V
7.
SPDIF_OUT
F2A55-M LK PLUS Digital audio connector
The S/PDIF module is purchased separately.
Front panel audio connector (10-1 pin AAFP)
AAFP
HD-audio-compliant
pin definition
NC
MIC2
MICPWR
Line out_R
NC
Line out_L
PIN 1
PORT1 L
PORT1 R
PORT2 R
SENSE_SEND
PORT2 L
F2A55-M LK PLUS
AGND
NC
NC
SENSE2_RETUR
This connector is for a chassis-mounted front panel audio I/O module that supports
either High Definition Audio or AC`97 audio standard. Connect one end of the front
panel audio I/O module cable to this connector.
AGND
NC
SENSE1_RETUR
8.
Legacy AC’97
compliant definition
F2A55-M LK PLUS Front panel audio connector
•
We recommend that you connect a high-definition front panel audio module to this
connector to avail of the motherboard high-definition audio capability.
•
If you want to connect a high definition front panel audio module to this connector, set
the Front Panel Type item in the BIOS to [HD]. See section 2.5.5 Onboard Devices
Configuration for details.
•
The front panel audio I/O module is purchased separately.
ASUS F2A55-M LK Series
1-27
USB 2.0 connectors (10-1 pin USB56, USB78, USB910)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specification that supports up to
480Mbps connection speed.
USB78
USB56
USB+5V
USB_P8USB_P8+
GND
NC
USB+5V
USB_P10USB_P10+
GND
NC
USB910
USB+5V
USB_P6USB_P6+
GND
NC
9.
F2A55-M LK PLUS USB2.0 connectors
PIN 1
USB+5V
USB_P5USB_P5+
GND
PIN 1
USB+5V
USB_P7USB_P7+
GND
PIN 1
USB+5V
USB_P9USB_P9+
GND
F2A55-M LK PLUS
Never connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
The USB 2.0 module is purchased separately.
10. Serial port connector (10-1 pin COM)
This connector is for a serial (COM) port. Connect the serial port module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
PIN 1
DCD
TXD
GND
RTS
RI
RXD
DTR
DSR
CTS
COM
F2A55-M LK PLUS
F2A55-M LK PLUS Serial port (COM) connector
The COM module is purchased separately.
1-28
Chapter 1: Product introduction
1.9
Software support
1.9.1
Installing an operating system
This motherboard supports Windows® XP / Vista / Windows® 7 / Windows® 8 Operating
Systems (OS). Always install the latest OS version and corresponding updates to maximize
the features of your hardware.
1.9.2
•
Motherboard settings and hardware options vary. Refer to your OS documentation for
detailed information.
•
Ensure that you install Windows® XP Service Pack 3 or later versions / Windows®
Vista Service Pack 1 or later versions before installing the drivers for better
compatibility and system stability.
•
BIOS and drivers updates are required to support Windows® 8.
Support DVD information
The Support DVD that comes with the motherboard package contains the drivers, software
applications, and utilities that you can install to avail all motherboard features.
The contents of the Support DVD are subject to change at any time without notice. Visit the
ASUS website at www.asus.com for updates.
To run the Support DVD
Place the Support DVD into the optical drive. If Autorun is enabled in your computer, the DVD
automatically displays the Specials screen. Click Drivers, Utilities, Make Disk, Manual, and
Contact tabs to display their respective menus.
The following screen is for reference only.
Click an icon to display
Support DVD/motherboard
information
Click an item to install
If Autorun is NOT enabled on your computer, browse the contents of the Support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the DVD.
ASUS F2A55-M LK Series
1-29
1-30
Chapter 1: Product introduction
BIOS information
2.1
Managing and updating your BIOS
2
Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to
restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update
utility.
2.1.1
ASUS Update utility
The ASUS Update is a utility that allows you to manage, save, and update the motherboard
BIOS in Windows® environment.
•
ASUS Update requires an Internet connection either through a network or an Internet
Service Provider (ISP).
•
This utility is available in the support DVD that comes with the motherboard package.
Installing ASUS Update
To install ASUS Update:
1.
Place the support DVD in the optical drive. The Specials menu appears.
2.
Click the Utilities tab, then click AI Suite II.
3.
Follow the onscreen instructions to complete the installation.
Quit all Windows® applications before you update the BIOS using this utility.
Updating the BIOS
To update the BIOS:
1.
From the Windows® desktop, click Start > Programs > ASUS > AI Suite II > AI Suite
II X.XX.XX to launch the AI Suite II utility. The AI Suite II Quick Bar appears.
2.
Click Update button from the Quick Bar, and then click ASUS Update from the popup
menu. The ASUS Update main screen appears. From the list, select either of the
following methods:
Chapter 2: BIOS information
2-1
Updating from the Internet
a.
Select Update BIOS from the Internet, then click Next.
b.
Select the ASUS FTP site nearest you to avoid network traffic, then click Next.
c.
From the FTP site, select the BIOS version that you wish to download then click Next.
The ASUS Update utility is capable of updating itself through the Internet. Always update
the utility to avail all its features.
Updating from a BIOS file
a.
Select Update BIOS from file, then click Next.
b.
Locate the BIOS file from the Open window, then click Open.
3.
Follow the onscreen instructions to complete the updating process.
2.1.2
ASUS EZ Flash 2
The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS‑based
utility.
Before you start using this utility, download the latest BIOS file from the ASUS website at
www.asus.com.
To update the BIOS using EZ Flash 2:
2-2
1.
Insert the USB flash disk that contains the latest BIOS file to the USB port.
2.
Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select
ASUS EZ Flash 2 Utility and press <Enter> to enable it.
3.
Press <Tab> to switch to the Drive field.
4.
Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS,
and then press <Enter>.
5.
Press <Tab> to switch to the Folder Info field.
6.
Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to perform
the BIOS update process. Reboot the system when the update process is done.
•
This function supports USB flash disks with FAT 32/16 format and single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent system
boot failure!
ASUS F2A55-M LK Series
2.1.3
ASUS CrashFree BIOS 3 utility
The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file
when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS
file using the motherboard support DVD or a USB flash drive that contains the updated BIOS
file.
•
Before using this utility, rename the BIOS file in the removable device into
F2A55MLK.CAP (for F2A55-M LK) or F2A55MKP.CAP (for F2A55-M LK PLUS).
•
The BIOS file in the support DVD may not be the latest version. Download the latest
BIOS file from the ASUS website at www.asus.com.
Recovering the BIOS
To recover the BIOS:
1.
Turn on the system.
2.
Insert the support DVD to the optical drive or the USB flash drive that contains the
BIOS file to the USB port.
3.
The utility automatically checks the devices for the BIOS file. When found, the utility
reads the BIOS file and enters ASUS EZ Flash 2 utility automatically.
4.
The system requires you to enter BIOS Setup to recover BIOS setting. To ensure
system compatibility and stability, we recommend that you press <F5> to load default
BIOS values.
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause
system boot failure!
Chapter 2: BIOS information
2-3
2.1.4
ASUS BIOS Updater
The ASUS BIOS Updater allows you to update BIOS in DOS environment. This utility also
allows you to copy the current BIOS file that you can use as a backup when the BIOS fails or
gets corrupted during the updating process.
The succeeding utility screens are for reference only. The actual utility screen displays may
not be same as shown.
Before updating BIOS
1.
Prepare the motherboard support DVD and a USB flash drive in FAT32/16 format and
single partition.
2.
Download the latest BIOS file and BIOS Updater from the ASUS website at
http://support.asus.com and save them on the USB flash drive.
NTFS is not supported under DOS environment. Do not save the BIOS file and BIOS
Updater to a hard disk drive or USB flash drive in NTFS format.
3.
Turn off the computer and disconnect all SATA hard disk drives (optional).
Booting the system in DOS environment
1.
Insert the USB flash drive with the latest BIOS file and BIOS Updater to the USB port.
2.
Boot your computer. When the ASUS Logo appears, press <F8> to show the BIOS
Boot Device Select Menu. Insert the support DVD into the optical drive and select the
optical drive as the boot device.
Please select boot device:
SATA: XXXXXXXXXXXXXXXX
USB XXXXXXXXXXXXXXXXX
UEFI: XXXXXXXXXXXXXXXX
Enter Setup
↑ and ↓ to move selection
ENTER to select boot device
ESC to boot using defaults
3. When the Make Disk menu appears, select the FreeDOS command prompt item by
pressing the item number.
4.
At the FreeDOS prompt, type d: and press <Enter> to switch the disk from Drive C
(optical drive) to Drive D (USB flash drive).
Welcome to FreeDOS (http://www.freedos.org)!
C:\>d:
D:\>
2-4
ASUS F2A55-M LK Series
Updating the BIOS file
To update the BIOS file using BIOS Updater
1.
At the FreeDOS prompt, type bupdater /pc /g and press <Enter>.
D:\>bupdater /pc /g
2.
The BIOS Updater screen appears as below.
ASUSTek BIOS Updater for DOS V1.30
Current ROM
BOARD: F2A55-M LK PLUS
VER: 0301
DATE: 07/13/2012
Update ROM
BOARD: Unknown
VER: Unknown
DATE: Unknown
PATH: A:\
F2A55MKP.CAP
A:
Note
3.
8390656 2012-07-13 17:30:48
[Enter] Select or Load
[Tab] Switch
[V] Drive Info
[Up/Down/Home/End] Move
[B] Backup
[Esc] Exit
Press <Tab> to switch between screen fields and use the <Up/Down/Home/End> keys
to select the BIOS file and press <Enter>. BIOS Updater checks the selected BIOS file
and prompts you to confirm BIOS update.
Are you sure to update BIOS?
Yes
4.
No
Select Yes and press <Enter>. When BIOS update is done, press <ESC> to exit BIOS
Updater. Restart your computer.
DO NOT shut down or reset the system while updating the BIOS to prevent system boot
failure!
•
For BIOS Updater version 1.30 or later, the utility automatically exits to the DOS
prompt after updating BIOS.
•
Ensure to load the BIOS default settings to ensure system compatibility and stability.
Select the Load Optimized Defaults item under the Exit menu. Refer to section 2.9
Exit menu for details.
•
Ensure to connect all SATA hard disk drives after updating the BIOS file if you have
disconnected them.
Chapter 2: BIOS information
2-5
2.2
BIOS setup program
Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS
screens include navigation keys and brief online help to guide you in using the BIOS Setup
program.
Entering BIOS Setup at startup
To enter BIOS Setup at startup:
•
Press <Delete> during the Power-On Self Test (POST). If you do not press <Delete>,
POST continues with its routines.
Entering BIOS Setup after POST
To enter BIOS Setup after POST:
•
Press <Ctrl>+<Alt>+<Del> simultaneously.
•
Press the power button to turn the system off then back on. Do this option only if you
failed to enter BIOS Setup using the first two options.
•
Press the reset button on the system chassis.
Using the power button, reset button, or the <Ctrl>+<Alt>+<Del> keys to force reset from
a running operating system can cause damage to your data or system. We recommend to
always shut down the system properly from the operating system.
•
The BIOS setup screens shown in this section are for reference purposes only, and
may not exactly match what you see on your screen.
•
Ensure that a USB mouse is connected to your motherboard if you want to use the
mouse to control the BIOS setup program.
•
The default BIOS settings for this motherboard apply for most conditions to ensure
optimum performance. If the system becomes unstable after changing any BIOS
settings, load the default settings to ensure system compatibility and stability. Select
the Load Optimized Defaults item under the Exit Menu. See section 2.9 Exit Menu.
•
If the system fails to boot after changing any BIOS setting, try to clear the CMOS and
reset the motherboard to the default value. Refer to section 1.7 Jumpers on how to
erase the RTC RAM.
•
The BIOS setup program does not support the bluetooth devices.
BIOS menu screen
The BIOS setup program can be used under two modes: EZ Mode and Advanced Mode.
You can change modes from the Exit menu or from the Exit/Advanced Mode button in the
EZ Mode/Advanced Mode screen.
2-6
ASUS F2A55-M LK Series
EZ Mode
By default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ
Mode provides you an overview of the basic system information, and allows you to select
the display language, system performance mode and boot device priority. To access the
Advanced Mode, click Exit/Advanced Mode, then select Advanced Mode or press F7 hot
key for the advanced BIOS settings.
The default screen for entering the BIOS setup program can be changed. Refer to the
Setup Mode item in section� 2.7 Boot menu for details.
Selects the display language of
the BIOS setup program
Displays the CPU/motherboard temperature,
CPU/5V/3.3V/12V voltage output,
CPU/chassis fan speed
Exits the BIOS setup program without saving
the changes, saves the changes and resets
the system, or enters the Advanced Mode
UEFI BIOS Utility - EZ Mode
Exit/Advanced Mode
F2A55-M LK PLUS
English
BIOS Version : 0301
CPU Type : AMD A8-5600K APU with Radeon(tm) HD Graphics
Friday [10/08/2010]
Speed : 3300 MHz
Total Memory : 1024 MB (DDR3 1333MHz)
Temperature
Voltage
CPU
+113.0ºF/+45.0ºC
CPU
1.248V
5V
MB
+75.2ºF/+40.0ºC
3.3V
3.344V
12V
5.160V
Fan Speed
CPU_FAN
3325RPM
CHA_FAN
N/A
12.248V
System Performance
Quiet
Performance
Energy Saving
Normal
Boot Priority
Use the mouse to drag or keyboard to navigate to decide the boot priority.
Shortcut (F3)
Advanced Mode(F7)
Selects the Advanced
mode functions
Selects the boot
device priority
Boot Menu(F8)
Power Saving mode
Normal mode
Default(F5)
Loads optimized default
ASUS Optimal mode
Selects the boot device priority
Displays the system properties of the
selected mode on the right hand side
Displays the Advanced mode menus
•
The boot device options vary depending on the devices you installed to the system.
•
The Boot Menu(F8) button is available only when the boot device is installed to the
system.
Chapter 2: BIOS information
2-7
Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to configure
the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed configurations.
To access the EZ Mode, click Exit, then select ASUS EZ Mode.
Back button
Menu items
Submenu item
Menu bar
Configuration fields
Pop-up window
Scroll bar
General help
Navigation keys
Menu bar
The menu bar on top of the screen has the following main items:
Main
Ai Tweaker
For changing the overclocking settings
Advanced
For changing the advanced system settings
Monitor
For displaying the system temperature, power status, and changing the fan settings
Boot
For changing the system boot configuration
Tool
For configuring options for special functions
Exit
2-8
For changing the basic system configuration
For selecting the exit options and loading default settings
ASUS F2A55-M LK Series
Menu items
The highlighted item on the menu bar displays the specific items for that menu. For example,
selecting Main shows the Main menu items.
The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have
their respective menu items.
Back button
This button appears when entering a submenu. Press <Esc> or use the USB mouse to click
this button to return to the previous menu screen.
Submenu items
A greater than sign (>) before each item on any menu screen means that the item has a
submenu. To display the submenu, select the item and press <Enter> or double-click the
item.
Pop-up window
Select a menu item and press <Enter> to display a pop-up window with the configuration
options for that item.
Scroll bar
A scroll bar appears on the right side of a menu screen when there are items that do not fit on
the screen. Press the Up/Down arrow keys or <Page Up> / <Page Down> keys to display the
other items on the screen.
Navigation keys
At the bottom right corner of the menu screen are the navigation keys for the BIOS setup
program. Use the navigation keys to select items in the menu and change the settings.
General help
At the top right corner of the menu screen is a brief description of the selected item.
Configuration fields
These fields show the values for the menu items. If an item is user-configurable, you can
change the value of the field opposite the item. You cannot select an item that is not userconfigurable.
A configurable field is highlighted when selected. To change the value of a field, select it and
press <Enter> or click on it to display a list of options.
Chapter 2: BIOS information
2-9
2.3
Main menu
2.3.1
System Language [English]
2.3.2
System Date [Day xx/xx/xxxx]
2.3.3
System Time [xx:xx:xx]
2.3.4
Security
The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup
program. The Main menu provides you an overview of the basic system information, and
allows you to set the system date, time, language, and security settings.
Allows you to choose the BIOS language version from the options. Configuration options:
[English] [Français] [Español] [Deutsch] [Русский]
Allows you to set the system date.
Allows you to set the system time.
The Security menu items allow you to change the system security settings.
2-10
•
If you have forgotten your BIOS password, erase the CMOS Real Time Clock (RTC)
RAM to clear the BIOS password. See section 1.7 Jumpers for information on how to
erase the RTC RAM.
•
The Administrator or User Password items on top of the screen show the default
Not Installed. After you set a password, these items show Installed.
ASUS F2A55-M LK Series
Administrator Password
If you have set an administrator password, we recommend that you enter the administrator
password for accessing the system. Otherwise, you might be able to see or change only
selected fields in the BIOS setup program.
To set an administrator password:
1.
Select the Administrator Password item and press <Enter>.
2.
From the Create New Password box, key in a password, then press <Enter>.
3.
Confirm the password when prompted.
To change an administrator password:
1.
Select the Administrator Password item and press <Enter>.
2.
From the Enter Current Password box, key in the current password, then press
<Enter>.
3.
From the Create New Password box, key in a new password, then press <Enter>.
4.
Confirm the password when prompted.
To clear the administrator password, follow the same steps as in changing an administrator
password, but press <Enter> when prompted to create/confirm the password. After you clear
the password, the Administrator Password item on top of the screen shows Not Installed.
User Password
If you have set a user password, you must enter the user password for accessing the system.
The User Password item on top of the screen shows the default Not Installed. After you set
a password, this item shows Installed.
To set a user password:
1.
Select the User Password item and press <Enter>.
2.
From the Create New Password box, key in a password, then press <Enter>.
3.
Confirm the password when prompted.
To change a user password:
1.
Select the User Password item and press <Enter>.
2.
From the Enter Current Password box, key in the current password, then press
<Enter>.
3.
From the Create New Password box, key in a new password, then press <Enter>.
4.
Confirm the password when prompted.
To clear the user password, follow the same steps as in changing a user password, but press
<Enter> when prompted to create/confirm the password. After you clear the password, the
User Password item on top of the screen shows Not Installed.
Chapter 2: BIOS information
2-11
2.4
Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
EFI BIOS Utility - Advanced Mode
Main
Ai Tweaker
Exit
Advanced
Monitor
Target CPU Speed: 3600MHz
Boot
Tool
Select the target CPU frequency, and the
relevant parameters will be auto-adjusted.
Target DRAM Speed: 1333MHz
Ai Overclock Tuner
Auto
Memory Frequency
Auto
APU Multiplier
Auto
NB Frequency
Auto
EPU Power Saving Mode
Disabled
GPU Boost
Auto
> OC Tuner
> DRAM Timing Control
CPU Voltage
Offset Mode
CPU Offset Mode Sign
CPU Offset Voltage
1.362V
+
Auto
VDDNB Offset Mode Sign
VDDNB Offset Voltage
1.187V
+
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Auto
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Scroll down to display the following items:
DRAM Voltage
1.500V
Auto
SB 1.1V Voltage
1.100V
Auto
1.1VSB Voltage 1.100V
Auto
APU1.2V Voltage 1.200V
Auto
VDDA Voltage 2.500V
Auto
Digi + VRM
CPU Load Line Calibration
Auto
CPU/NB Load Line Calibration
Auto
CPU Current Capability
100%
CPU/NB Current Capability
100%
CPU Power Phase Control
Standard
CPU Voltage Frequency
Auto
CPU Power Duty Control
T.Probe
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
2-12
ASUS F2A55-M LK Series
Target CPU Speed : xxxxMHz
Displays the current CPU speed.
Target DRAM Speed : xxxxMHz
Displays the current DRAM speed.
2.4.1
Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking configuration options:
[Auto]Loads the optimal settings for the system.
[Manual]
Allows you to individually set overclocking parameters.
APU Frequency [XXX]
This item appears only when you set the Ai Overclock Tuner item to [Manual]. Use the <+>
and <-> keys to adjust the value. You can also key in the desired value using the numeric
keypad. The values range from 90.0MHz to 300.0MHz.
2.4.2
Memory Frequency [Auto]
Allows you to set the memory operating frequency. Configuration options: [Auto] [DDR3800MHz] [DDR3-1066MHz] [DDR3-1333MHz] [DDR3-1600MHz] [DDR3-1866MHz] [DDR32133MHz] [DDR3-2400MHz]
Selecting a very high memory frequency may cause the system to become unstable! If this
happens, revert to the default setting.
2.4.3
APU Multiplier [Auto]
2.4.4
NB Frequency [Auto]
2.4.5
EPU Power Saving Mode [Disabled]
Allows you to set the multiplier between the CPU Core Clock and the FSB Frequency. Use
the <+> and <-> keys to adjust the ratio. The valid value ranges vary according to your CPU
model.
Allows you to adjust the NB frequency. Use the <+> and <-> keys to adjust the value. You
can also key in the desired value using the numeric keypad.
Allows you to enable or disable the EPU power saving function. Configuration options:
[Disabled] [Enabled]
EPU Setting [Auto]
This item appears only when The EPU Power Saving Mode is set to [Enabled] and
allows you to set power saving mode. Configuration options: [Auto] [Light Power
Saving Mode] [Medium Power Saving Mode] [Max Power Saving Mode]
Chapter 2: BIOS information
2-13
2.4.6
GPU Boost [Auto]
[Auto]
[Turbo Mode]
[Extreme Mode]
[Manual Mode]
Automatic configuration.
Set to [Trubo Mode] to achieve better 3D performance.
Set to [Extreme Mode] for the excellent visual experience.
Set to [Manual Mode] if you want to manually select the desired GPU
Engine frequency.
The following item appears only when you set the GPU Boost item to [Manual Mode].
GPU Engine Frequency [Auto]
Allows you to set the GPU Engine Frequency. Configuration options: [Auto] [GPU O.C.
434MHz] [GPU O.C. 447MHz] [GPU O.C. 460MHz] [GPU O.C. 475MHz] ~ [GPU O.C.
1381MHz] [GPU O.C. 1520MHz] [GPU O.C. 1688MHz] [GPU O.C. 1900MHz]
2.4.7
OC Tuner
2.4.8
DRAM Timing Control
OC Tuner automatically overclocks the frequency and voltage of CPU and DRAM for
enhancing the system performance. Press <Enter> and select OK to start automatic
overclocking.
The sub-items in this menu allow you to set the DRAM timing control features. Use the <+>
and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard
and press <Enter>.
Changing the values in this menu may cause the system to become unstable! If this
happens, revert to the default settings.
2.4.9
CPU Voltage [Offset Mode]
[Offset Mode]
To offset the voltage by a positive or negative value.
CPU Offset Mode Sign [+]
[+]
[–]
To offset the voltage by a positive value.
To offset the voltage by a negative value.
CPU Offset Voltage [Auto]
Allows you to set the CPU Offset voltage. The values range from 0.00625V to 0.500V
with a 0.00625V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
VDDNB Offset Mode Sign [+]
[+]
[–]
2-14
To offset the voltage by a positive value.
To offset the voltage by a negative value.
ASUS F2A55-M LK Series
VDDNB Offset Voltage [Auto]
Allows you to set the VDDNB Offset voltage. The values range from 0.00625V to
0.500V with a 0.00625V interval.
2.4.10
DRAM Voltage [Auto]
2.4.11
SB 1.1V Voltage [Auto]
2.4.12
1.1VSB Voltage [Auto]
2.4.13
APU1.2V Voltage [Auto]
2.4.14
VDDA Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.35V to 2.00V with a 0.005V
interval.
Allows you to set the Southbridge 1.1V voltage. The values range from 1.1V to 1.4V with a
0.01V interval.
Allows you to set the 1.1VSB voltage. The values range from 1.1000V to 1.4000V with a 0.1V
interval.
Allows you to set the APU (Accelerated Processor Unit) 1.2V voltage. The values range from
1.2000V to 1.8000V with a 0.01V interval.
Allows you to set the VDDA voltage. The values range from 2.5000V to 2.8000V with a 0.1V
interval.
2.4.15
•
The values of the CPU Offset Voltage, VDDNB Offset Voltage, DRAM Voltage,
SB 1.1V Voltage, 1.1Vsb Voltage, APU1.2V Voltage, and VDDA Voltage items are
labeled in different color, indicating the risk levels of high voltage settings.
•
The system may need better cooling system to work stably under high voltage
settings.
DIGI+ VRM
CPU Load Line Calibration [Auto]
Load-line Calibration is defined by AMD VRM specifications and affects CPU voltage. The
CPU working voltage will decrease proportionally to CPU loading. Higher load-line calibration
would get higher voltage and better overclocking performance, but increase the CPU and
VRM thermal. This item allows you to adjust the voltage range from the following percentages
to boost the system performance: 0% (Regular), 60% (Medium), 80% (High), and 100%
(Extreme). Configuration options: [Auto] [Regular] [Medium] [High] [Extreme]
The actual performance boost may vary depending on your CPU specifiation.
CPU/NB Load Line Calibration [Auto]
Allows you to select the CPU/NB Load-Line Calibration mode. Configuration options: [Auto]
[Regular] [High] [Extreme]
Chapter 2: BIOS information
2-15
CPU Current Capability [100%]
This item provides wider total power range for overclocking. A higher value brings a
wider total power range and extends the overclocking frequency range simultaneously.
Configuration options: [100%] [110%] [120%] [130%]
CPU/NB Current Capability [100%]
This item provides wider total power range for overclocking. A higher value brings a
wider total power range and extends the overclocking frequency range simultaneously.
Configuration options: [100%] [110%] [120%] [130%]
CPU Power Phase Control [Standard]
Phase number is the number of working VRM phase. Increasing phase number under heavy
system loading to get more transient and better thermal performance. Reducing phase
number under light system loading to increase VRM efficiency.
[Standard]
[Optimized]
[Extreme]
[Manual Adjustment]
Proceeds phase control depending on the CPU loading.
Loads the ASUS optimized phase tuning profile.
Proceeds the full phase mode.
Allows manual adjustment.
Manual Adjustment [Fast]
Select [Ultra Fast] for a faster response. The reaction time will be longer when [Regular] is
selected. Configuration options: [Ultra Fast] [Fast] [Medium] [Regular]
CPU Voltage Frequency [Auto]
Switching frequency will affect the VRM transient response and component thermal. Setting
a higher frequency gets faster transient response. Use the <+> and <-> keys to adjust the
value. The values range from 200k Hz to 350k Hz with a 50k Hz interval.
CPU Power Duty Control [T.Probe]
[T.Probe]
[Extreme]
Maintains the VRM thermal balance.
Maintains the VRM current balance.
Do not remove the thermal module while changing the DIGI+VRM related parameters. The
thermal conditions should be monitored.
2-16
ASUS F2A55-M LK Series
2.5
Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Be cautious when changing the settings of the Advanced menu items. Incorrect field values
can cause the system to malfunction.
EFI BIOS Utility - Advanced Mode
Ai Tweaker
Main
Advanced
> CPU Configuration
Exit
Monitor
Boot
Tool
CPU Configuration Parameters
> SATA Configuration
> USB Configuration
> NB Configuration
> Onboard Devices Configuration
> APM
> Network Stack
2.5.1
CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically
detects.
The items shown in submenu may be different due to the CPU you installed.
AMD PowerNow function [Enabled]
Enables or disables the AMD PowerNow function. Configuration options: [Enabled] [Disabled]
NX Mode [Enabled]
Enables or disables the No-execute page protection function. Configuration options:
[Enabled] [Disabled]
SVM [Enabled]
Enables or disables CPU virtualization. Configuration options: [Disabled] [Enabled]
CPB Mode [Auto]
Disables the CPB (Core Performance Boost) mode or set it to [Auto] for automatic
configuration. Configuration options: [Disabled] [Auto]
C6 Mode [Disabled]
Enables or disables C6 mode. Configuration options: [Enabled] [Disabled]
IOMMU [Disabled]
Set this item to [Enabled] to show IOMMU Mode. Configuration options: [Enabled] [Disabled]
Chapter 2: BIOS information
2-17
2.5.2
SATA Configuration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Not Present if no SATA device is installed to the corresponding SATA
port.
OnChip SATA Channel [Enabled]
Enables or disables onboard channel SATA port. Configuration options: [Disabled] [Enabled]
OnChip SATA Type [AHCI]
Allows you to set the SATA configuration.
[IDE]Set to [IDE] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[RAID]
Set to [RAID] when you want to create a RAID configuration from the SATA
hard disk drives.
[AHCI]Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advanced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
SATA Port 5 - Port 6 [AHCI]
This item only appears when OnChip SATA Type is set to [AHCI]. If SATA port 5
and port 6 are configured as [AHCI], the ports can only be used under OS with driver
installed. Set to [IDE] instead of [AHCI] to access devices on SATA port 5 and port 6
before entering OS. Configuration options: [AHCI] [IDE]
SATA Port 5 - Port 6 [RAID]
This item only appears when OnChip SATA Type is set to [RAID]. If SATA port 5
and port 6 are configured as [RAID], the ports can only be used under OS with driver
installed. Set to [IDE] instead of [RAID] to access devices on SATA port 5 and port 6
before entering OS. Configuration options: [RAID] [IDE]
Board SATA RAID ROM [Legacy ROM]
This item only appears when OnChip SATA Type is set to [RAID].
[Disabled]
Disables this function.
[Legacy ROM] Select this option when using legacy operating systems.
[UEFI DRIVER] Select this option when using UEFI operating systems.
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor system. When
read/write of your hard disk errors occur, this feature allows the hard disk to report warning
messages during the POST. Configuration options: [Enabled] [Disabled]
2-18
ASUS F2A55-M LK Series
2.5.3
USB Configuration
The items in this menu allow you to change the USB-related features.
The USB Devices item shows the auto-detected values. If no USB device is detected, the
item shows None.
Legacy USB Support [Enabled]
[Enabled]
[Disabled]
[Auto] Enables the support for USB devices on legacy operating systems (OS).
The USB devices can be used only for the BIOS setup program.
Allows the system to detect the presence of USB devices at startup. If
detected, the USB controller legacy mode is enabled. If no USB device is
detected, the legacy USB support is disabled.
EHCI Hand-off [Disabled]
[Enabled]
[Disabled]
2.5.4
Enables the support for operating systems without an EHCI hand‑off
feature.
Disables the function.
NB Configuration
IGFX Multi-Monitor [Disabled]
Enables or disables the Internal Graphics Device Multi-Monitor support for add-on VGA
devices. And the memory size of Internal Graphics Device will keep memory reserved.
Configuration options: [Disabled] [Enabled]
Primary Video Device [PCIE / PCI Video]
Selects the primary display device. Configuration options: [IGFX Video] [PCIE / PCI Video]
Integrated Graphics [Auto]
Enables the integrated graphics controller. Configuration options: [Auto] [Force]
UMA Frame Buffer Size [Auto]
This item appears only when you set the previous item to [Force]. Configuration options:
[Auto] [32M] [64M] [128M] [256M]
2.5.5
Onboard Devices Configuration
HD Audio Device [Enabled]
[Enabled]
[Disabled]
Enables the High Definition Audio Controller.
Disables the controller.
The following two items appear only when you set the HD Audio Device item to [Enabled].
Chapter 2: BIOS information
2-19
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or highdefinition audio depending on the audio standard that the front panel audio module supports.
[HD]
[AC97]
Sets the front panel audio connector (AAFP) mode to high definition audio.
Sets the front panel audio connector (AAFP) mode to legacy AC’97.
SPDIF Out Type [SPDIF]
[SPDIF]
[HDMI]
Sets to [SPDIF] for SPDIF audio output.
Sets to [HDMI] for HDMI audio output.
Realtek LAN Controller [Enabled]
[Enabled]
[Disabled]
Enables the Realtek LAN controller.
Disables the controller.
Realtek PXE OPROM [Disabled]
This item appears only when you set the Realtek LAN Controller item to [Enabled] and
allows you to enable or disable the Rom Help of the Realtek LAN controller. Configuration
options: [Enabled] [Disabled]
Serial Port Configuration
The sub-items in this menu allow you to set the serial port configuration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM). Configuration options: [Enabled]
[Disabled]
Change Settings [Auto]
Allows you to select the Serial Port base address. Configuration options: [Auto]
[IO=3F8h; IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
Parallel Port Configuration [Enabled]
The sub-items in this menu allow you to set the parallel port configuration.
Parallel Port [Enabled]
Allows you to enable or disable the parallel port (LPT/LPTE).
Configuration options: [Enabled] [Disabled]
Change Settings [Auto]
Allows you to select the Parallel Port base address.
Configuration options: [IO=378h; IRQ=5] [IO=378h; IRQ=5,6,7,9,10,11,12]
[IO=278h; IRQ=5,6,7,9,10,11,12] [IO=3BCh; IRQ=5,6,7,9,10,11,12]
Device Mode [Auto]
Allows you to set the Printer port mode. Configuration options: [STD Printer Mode]
[SPP Mode] [EPP-1.9 and SPP Mode] [EPP-1.7 and SPP Mode] [ECP Mode] [ECP
and EPP-1.9 Mode] [ECP and EPP-1.7 Mode]
2-20
ASUS F2A55-M LK Series
2.5.6
APM
Restore AC Power Loss [Power Off]
[Power On]
[Power Off]
[Last State]
The system goes into on state after an AC power loss.
The system goes into off state after an AC power loss.
The system goes into either off or on state, whatever the system state was
before the AC power loss.
Power On By PS/2 Keyboard [Disabled]
[Disabled]
[Space Bar]
[Ctrl-Esc]
[Power Key]
Disables the Power On by a PS/2 keyboard.
Sets the Space Bar on the PS/2 keyboard to turn on the system.
Sets the Ctrl+Esc key on the PS/2 keyboard to turn on the system.
Sets Power key on the PS/2 keyboard to turn on the system. This feature
requires an ATX power supply that provides at least 1A on the +5VSB lead.
Power On By PS/2 Mouse [Disabled]
[Disabled]
[Enabled]
Disables the Power On by a PS/2 mouse.
Enables the Power On by a PS/2 mouse. This feature requires an ATX
power supply that provides at least 1A on the +5VSB lead.
Power On By PME [Disabled]
[Disabled]
[Enabled]
Disables the PME to wake up by PCI/PCIE devices.
Allows you to turn on the system through a PCI/PCIE LAN or modem card.
This feature requires an ATX power supply that provides at least 1A on the
+5VSB lead.
Power On By Ring [Disabled]
[Disabled]Disables Ring to generate a wake event.
[Enabled]Enables Ring to generate a wake event.
Power On By RTC [Disabled]
[Disabled]
[Enabled]
Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
Minute/Second will become user-configurable with set values.
RTC Alarm Date (Days)
This item appears only when you set the previous item to [Enabled] and allows you to select
RTC alarm time (days). When you set the time to zero, the RTC alarms everyday. Use <+>
and <-> keys to adjust the time.
- Hour / - Mimute / - Second
Allows you to set the RTC alarm time. Use <+> and <-> keys to adjust the time.
Chapter 2: BIOS information
2-21
2.5.7
Network Stack
Network Stack [Disable Link]
This item allows user to disable or enable the UEFI network stack. Configuration options:
[Disable Link] [Enabled]
Ipv4 PXE Support [Enabled]
This item appears only when you set the Network Stack item to [Enabled]. When this item is
disabled, the IPV4 PXE boot option will not be created. Configuration options: [Disable Link]
[Enabled]
Ipv6 PXE Support [Enabled]
This item appears only when you set the Network Stack item to [Enabled]. When this item is
disabled, the IPV6 PXE boot option will not be created. Configuration options: [Disable Link]
[Enabled]
2-22
ASUS F2A55-M LK Series
2.6
Monitor menu
2.6.1
CPU Temperature / MB Temperature [xxxºC/xxxºF]
2.6.2
CPU / Chassis fan Speed [xxxx RPM] or [Ignore] /
[N/A]
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignore if you do not wish to display the detected temperatures.
The onboard hardware monitor automatically detects and displays the CPU / chassis fan
speeds in rotations per minute (RPM). If the fan is not connected to the motherboard, the field
shows N/A. Select Ignore if you do not wish to display the detected speed.
2.6.3
[Disabled]
[Enabled]
CPU Q-Fan Control [Enabled]
Disables the CPU Q-Fan control feature.
Enables the CPU Q-Fan control feature.
CPU Speed Low Limit [200 RPM]
This item appears only when you enable the CPU Q-Fan Control feature and allows
you to disable or set the CPU fan warning speed. Configuration options: [Ignore]
[200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
Chapter 2: BIOS information
2-23
CPU Profile [Standard]
This item appears only when you enable the CPU Q-Fan Control feature and allows
you to set the appropriate performance level of the CPU fan.
[Standard]Sets to [Standard] to make the CPU fan automatically adjust depending on
the CPU temperature.
[Silent]Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Turbo]
Sets to [Turbo] to achieve maximum CPU fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set CPU Profile to [Manual].
CPU_FAN Upper Temperature [70ºC]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values range
from 20ºC to 90ºC.
CPU_FAN Fan Max. Duty Cycle(%) [100%]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The values range from
40% to 100%. When the CPU temperature reaches the upper limit, the CPU fan will operate at
the maximum duty cycle.
CPU_FAN Lower Temperature [20ºC]
Displays the lower limit of the CPU temperature.
CPU_FAN Fan Min. Duty Cycle(%) [40%]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values range from
40% to 100%. When the CPU temperature is under the lower limit, the CPU fan will operate at
the minimum duty cycle.
2.6.4
CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
2.6.5
Anti Surge Support [Enabled]
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators. Select Ignore if you do not want to detect this item.
This item allows you to enable or disable the Anti Surge function. Configuration options:
[Disabled] [Enabled]
2-24
ASUS F2A55-M LK Series
2.7
Boot menu
The Boot menu items allow you to change the system boot options.
Scroll down to display the following items:
2.7.1
Bootup NumLock State [On]
2.7.2
Full Screen Logo [Enabled]
[On]
[Off]
[Enabled]
[Disabled]
Sets the power-on state of the NumLock to [On].
Sets the power-on state of the NumLock to [Off].
Enables the full screen logo display feature.
Disables the full screen logo display feature.
Set this item to [Enabled] to use the ASUS MyLogo 2™ feature.
Chapter 2: BIOS information
2-25
Post Report [5 sec]
This item appears only when the Full Screen Logo item is set to [Disabled] and allows you to
set the waiting time for the system to display the post report. Configuration options: [1 sec] [2
sec] [3 sec] [4 sec] [5 sec] [6 sec] [7 sec] [8 sec] [9 sec] [10 sec] [Until Press ESC]
2.7.3
Fast Boot [Enabled]
Enable or disable boot with initialization of a minimal set of devices to launch active boot
option. Configuration options: [Disabled] [Enabled]
The following three items appear only when you set Fast Boot to [Enabled].
USB Support [Partial Initial]
[Disabled]All USB devices will not be available until OS boot up for a fastest POST
time.
[Full Initial]All USB devices will be available during POST. This process will extend the
POST time.
[Partial Initial]For a faster POST time, only the USB ports with keyboard and mouse
connections will be detected.
PS/2 Keyboard and Mouse Support [Auto]
[Auto]For a faster BIOS POST time, PS/2 devices will only be available when
the system boots up. PS/2 devices will not be available and BIOS Setup
program will not be accessible via PS/2 devices when the system is
restarted.
[Full Initial]For full system control, PS/2 devices will be available during POST at any
circumstances. This process will extend the POST time.
[Disabled]All PS/2 devices will not be available until OS bootup for a fastest POST
time.
Network Stack Driver Support [Disabled]
[Disabled]The BIOS skips over the Network Stack Driver and tries to boot from the
next device.
[Enabled]
Allows the BIOS to boot from the Network Stack Driver.
2.7.4
Post Delay Time [3 sec]
2.7.5
Wait for ‘F1’ If Error [Enabled]
Allows you to set the POST Report wait time. This configuration only functions in Normal
Boot mode. Configuration options: [0 sec] [1 sec] [2 sec] [3 sec] [4 sec] [5 sec] [6 sec] [7 sec]
[8 sec] [9 sec] [10 sec]
When this item is set to [Enabled], the system waits for the F1 key to be pressed when error
occurs. Configuration options: [Disabled] [Enabled]
2-26
ASUS F2A55-M LK Series
2.7.6
Option ROM Messages [Force BIOS]
2.7.7
Next boot after AC Power Loss [Normal Boot]
[Force BIOS]
The third-party ROM messages will be forced to display during the boot
sequence.
[Keep Current] The third-party ROM messages will be displayed only if the third-party
manufacturer had set the add-on device to do so.
[Normal Boot]
[Fast Boot]
2.7.8
Returns to normal boot on the next boot after an AC power loss.
Accelerates the boot speed on the next boot after an AC power loss.
CSM Parameters
This option controls whether or not CSM (Compatibility Support Module) will be launched.
Launch CSM [Auto]
Configuration option: [Auto] [Enabled] [Disabled]
The following four items appear only when you set Launch CSM to [Enabled].
Boot Device Control [UEFI and Legacy OpROM]
Configuration option: [UEFI and Legacy OpRom] [Legacy OpROM only] [UEFI only]
Boot from Network Devices [Legacy OpROM first]
Configuration option: [Legacy OpROM first] [UEFI driver first] [Ignore]
Boot from Storage Devices [Legacy OpRom first]
Configuration option: [Both, Legacy OpROM first] [Both, UEFI driver first] [Legacy
OpROM first] [UEFI driver first] [Ignore]
Boot from PCIe/PCI Expansion Devices [Legacy OpROM first]
Configuration option: [Legacy OpROM first] [UEFI driver first]
2.7.9
Security Boot parameters
This option allows you to configure the Secure Boot related parameters.
OS Type [Windows 8 UEFI]
Configuration option: [Windows 8 UEFI] [Other Legacy & UEFI]
Secure Boot Mode [Standard]
This item appears only when you set the OS Type to [Windows 8 UEFI]. Configuration
option: [Standard] [Custom]
The following items appear when Secure Boot Mode is set to [Custom].
Key Management
Default Key Provisioning [Disabled]
Configuration options: [Enabled] [Disabled]
Chapter 2: BIOS information
2-27
Manage All Factory Keys (PK, KEK, DB, DBX)
Install default Secure Boot Keys
Configuration options: [Yes] [No]
Platform Key (PK)
Set PK from File
Configuration options: [Acpi (a0341d0, 0)\PCI (1212)\USB (2, 0)\]
Get PK to File
Configuration options: [OK]
Delete the PK
Configuration options: [Yes] [No]
Key Exchange Key Database (KEK)
Set KEK from File
Configuration options: [OK]
Get KEK to File
Configuration options: [OK]
Delete the KEK
Configuration options: [Yes] [No]
Append an entry to KEK
Configuration options: [OK]
Authorized Signature Database
Set DB from File
Configuration options: [OK]
Get DB to File
Configuration options: [OK]
Delete the DB
Configuration options: [Yes] [No]
Append an entry to DB
Configuration options: [OK]
Forbidden Signature Database
Set DBX from File
Configuration options: [OK]
Get DBX to File
Configuration options: [OK]
Delete the DBX
Configuration options: [Yes] [No]
Append an entry to DBX
Configuration options: [OK]
2-28
ASUS F2A55-M LK Series
2.7.10
Setup Mode [EZ Mode]
2.7.11
Boot Option Priorities
[Advanced Mode]Sets Advanced Mode as the default screen for entering the BIOS setup
program.
[EZ Mode]
Sets EZ Mode as the default screen for entering the BIOS setup program.
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
2.7.12
•
To select the boot device during system startup, press <F8> when ASUS Logo
appears.
•
To access Windows OS in Safe Mode, press <F8> after POST.
Boot Override
These items displays the available devices. The number of device items that appears on
the screen depends on the number of devices installed in the system. Click an item to start
booting from the selected device.
Chapter 2: BIOS information
2-29
2.8
Tools menu
The Tools menu items allow you to configure options for special functions. Select an item
then press <Enter> to display the submenu.
EFI BIOS Utility - Advanced Mode
Ai Tweaker
Main
Advanced
Exit
Monitor
Boot
Tool
Be used to update BIOS
> ASUS EZ Flash 2 Utility
> ASUS SPD Information
> ASUS O.C. Profile
2.8.1
ASUS EZ Flash 2 Utility
Allows you to run ASUS EZ Flash 2. Press [Enter] to launch the ASUS EZ Flash 2 screen.
For more details, see section 2.1.2 ASUS EZ Flash 2.
2.8.2
ASUS SPD Information
DIMM Slot # [DIMM_A1]
Displays the Serial Presence Detect (SPD) information of the DIMM module installed on the
selected slot. Configuration options: [DIMM_A1] [DIMM_B1]
2.8.3
ASUS O.C. Profile
This item allows you to store or load multiple BIOS settings.
The Setup Profile Status items show Not Installed if no profile is created.
Label
Allows you to input the label of the setup profile.
Save to Profile
Allows you to save the current BIOS settings to the BIOS Flash, and create a profile. Key in a
profile number from one to eight, press <Enter>, and then select Yes.
Load from Profile
Allows you to load the previous BIOS settings saved in the BIOS Flash. Key in the profile
number that saved your CMOS settings, press <Enter>, and then select Yes.
2-30
•
DO NOT shut down or reset the system while updating the BIOS to prevent the
system boot failure!
•
We recommend that you update the BIOS file only coming from the same memory/
CPU configuration and BIOS version.
ASUS F2A55-M LK Series
2.9
Exit menu
The Exit menu items allow you to load the optimal default values for the BIOS items, and
save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit
menu.
Exit
Load Optimized Defaults
Save Changes & Reset
Discard Changes & Exit
ASUS EZ Mode
Launch EFI Shell from filesystem device
Load Optimized Defaults
This option allows you to load the default values for each of the parameters on the Setup
menus. When you select this option or if you press <F5>, a confirmation window appears.
Select Yes to load the default values.
Save Changes & Reset
Once you are finished making your selections, choose this option from the Exit menu to
ensure the values you selected are saved. When you select this option or if you press <F10>,
a confirmation window appears. Select Yes to save changes and exit.
Discard Changes & Exit
This option allows you to exit the Setup program without saving your changes. ���������
When you
select this option or if you press <Esc>, a confirmation window appears. Select Yes to
discard changes and exit�.
ASUS EZ Mode
This option allows you to enter the EZ Mode screen.
Launch EFI Shell from filesystem device
This option allows you to attempt to launch the UEFI Shell application (shellx64.efi) from one
of the available devices that have a filesystem.
Chapter 2: BIOS information
2-31
2-32
ASUS F2A55-M LK Series
Appendices
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
•
•
This device may not cause harmful interference.
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
•
Increase the separation between the equipment and receiver.
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
IC: Canadian Compliance Statement
Complies with the Canadian ICES-003 Class B specifications. This device complies with RSS
210 of Industry Canada. This Class B device meets all the requirements of the Canadian
interference-causing equipment regulations.
This device complies with Industry Canada license exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Cut appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
Cet appareil est conforme aux normes CNR exemptes de licence d’Industrie Canada. Le
fonctionnement est soumis aux deux conditions suivantes :
(1) cet appareil ne doit pas provoquer d’interférences et
(2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer
un fonctionnement non souhaité de l’appareil.
ASUS F2A55-M LK Series
A-1
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
VCCI: Japan Compliance Statement
VCCI Class B Statement
KC: Korea Warning Statement
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards
for protecting our environment. We believe in providing solutions for you to be able to
responsibly recycle our products, batteries, other components as well as the packaging
materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling
information in different regions.
A-2
Appendices
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone Fax E-mail
Web site
Technical Support
Telephone Online support
15 Li-Te Road, Peitou, Taipei, Taiwan 11259
+886-2-2894-3447
+886-2-2890-7798
[email protected]
www.asus.com.tw
+86-21-38429911
support.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Address
Telephone
Fax
Web site
Technical Support
Telephone Support fax
Online support
800 Corporate Way, Fremont, CA 94539, USA
+1-812-282-3777
+1-510-608-4555
usa.asus.com
+1-812-282-2787
+1-812-284-0883
support.asus.com
ASUS COMPUTER GmbH (Germany and Austria)
Address
Fax
Web site
Online contact
Technical Support
Telephone
Support Fax
Online support
Harkort Str. 21-23, D-40880 Ratingen, Germany
+49-2102-959911
www.asus.de
www.asus.de/sales
+49-1805-010923*
+49-2102-9599-11
support.asus.com
* EUR 0.14/minute from a German fixed landline; EUR 0.42/minute from a mobile phone.
ASUS F2A55-M LK Series
A-3
A-4
Appendices
(510)739-3777/(510)608-4555
800 Corporate Way, Fremont, CA 94539.
Asus Computer International
Signature :
Date :
Representative Person’s Name :
Jun. 27, 2012
Steve Chang / President
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Supplementary Information:
FCC Part 15, Subpart B, Unintentional Radiators
Model Number : F2A55-M LK, F2A55-M LK PLUS
Conforms to the following specifications:
Product Name : Motherboard
hereby declares that the product
Phone/Fax No:
Address:
Responsible Party Name:
Per FCC Part 2 Section 2. 1077(a)
DECLARATION OF CONFORMITY
Ver. 120601
Manufacturer:
HARKORT STR. 21-23, 40880 RATINGEN
GERMANY
Address, City:
Country:
F2A55-M LK, F2A55-M LK PLUS
EN 60065:2002 / A12:2011
EN 60065:2002+A1:2006+A11:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.3.1(2002-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.1.1(2009-05)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.3.1(2006-05)
EN 302 623 V1.1.1(2009-01)
EN 55024:2010
EN 61000-3-3:2008
EN 55020:2007+A11:2011
Signature : __________
Position : CEO
Name :
Jerry Shen
(EC conformity marking)
EN 62301:2005
Regulation (EC) No. 278/2009
Declaration Date: Jun. 27, 2012
Year to begin affixing CE marking:2012
CE marking
EN 62301:2005
Regulation (EC) No. 642/2009
EN 62301:2005
Regulation (EC) No. 1275/2008
2009/125/EC-ErP Directive
EN 60950-1 / A12:2011
EN 60950-1 / A11:2009
2006/95/EC-LVD Directive
EN 300 328 V1.7.1(2006-10)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V4.2.1(2010-03)
EN 301 908-2 V3.2.1(2007-05)
EN 301 893 V1.4.1(2005-03)
EN 302 544-2 V1.1.1(2009-01)
EN 50360:2001
EN 50371:2002
EN 50385:2002
1999/5/EC-R &TTE Directive
EN 55022:2010
EN 61000-3-2:2006+A1:2009+A2:2009
EN 55013:2001+A1:2003+A2:2006
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
Model name :
Product name :
Ver. 120601
ASUS COMPUTER GmbH
Authorized representative in Europe:
Motherboard
TAIWAN
Country:
declare the following apparatus:
No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C.
Address, City:
ASUSTek COMPUTER INC.
EC Declaration of Conformity
We, the undersigned,
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
