Configuring the alarm parameters of the power meter . . . 182

Configuring and displaying the parameters of the source . 182

Display of results and command . . . . . . . . . . . . . . . . . . . . 183

Result of the measurement in progress . . . . . . . . . . . . . . . 183

Table of results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Commands of the power meter parameters . . . . . . . . . . . 184

Making a measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Power measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Optical link loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

FOX Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Configuration of the FOX automatic measurement . . . . . . 186

Acquisition parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Results screen parameters . . . . . . . . . . . . . . . . . . . . . . . . 187

File Storage parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Establishing a reference . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Establishing a reference for loss measurement . . . . . . . . . 189

Taking a side by side reference . . . . . . . . . . . . . . . . . . . . . 189

Taking the reference in a loop-back mode . . . . . . . . . . . . 190

Establishing a reference for an ORL measurement . . . . . . 191

ORL Emitted power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

ORL Zero adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Measurement acquisition . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Choosing the fiber to be tested . . . . . . . . . . . . . . . . . . . . . 193

Making the measurement . . . . . . . . . . . . . . . . . . . . . . . . . 193

Identifying the distant module . . . . . . . . . . . . . . . . . . . . . . 194

Displaying results for a FOX automatic measurement . . . . 194

User Manual 780000102/19 xv

Table of Contents

Chapter 12

Chapter 13

Chapter 14

Sending a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Manual ORL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Establishing a reference for an ORL manual measurement 197

Measurement acquisition . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Making the measurement . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Display of results for an ORL manual measurement . . . . . 198

File Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Storing results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Recalling files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Multi Test Access Unit 201

Function of the MTAU module . . . . . . . . . . . . . . . . . . . . . 202

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Manual mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Auto mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Configuration of the sequence of tests . . . . . . . . . . . . . . . . 205

Performing the sequence of tests . . . . . . . . . . . . . . . . . . . 206

Use of the Fiber Characterization script . . . . . . . . . . . . . 207

Connect the modules to the MTAU . . . . . . . . . . . . . . . . . . 207

Launching the Script . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Broadband source BBS 213

Function of the BBS module . . . . . . . . . . . . . . . . . . . . . . . 214

Activation process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

Remote interlock connector . . . . . . . . . . . . . . . . . . . . . . . 215

File management 217

File configuration menu . . . . . . . . . . . . . . . . . . . . . . . . . . 218

Managing tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218

File signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

xvi User Manual 780000102/19

Table of Contents

File information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Current directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Rules for naming files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Name of a file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

Auto store . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

File Type / Save Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

Fiber Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Fiber ID and Fiber Number . . . . . . . . . . . . . . . . . . . . . . . . 222

Color code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Fiber Nbr Increment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Link description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Extremities are different . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Cable Id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Origin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

End Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Cable structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Comment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

File export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Buttons on the right of the screen . . . . . . . . . . . . . . . . . . . 228

Explorer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Description of the explorer . . . . . . . . . . . . . . . . . . . . . . . . . 229

Storage media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Storage media built into the Base Unit . . . . . . . . . . . . . . . 230

External USB storage media . . . . . . . . . . . . . . . . . . . . . . . 230

Standard Compact Flash card (8000 platform only) . . . . . 232

Remote Base Unit and data transfer . . . . . . . . . . . . . . . . . 233

Abbreviations for storage media . . . . . . . . . . . . . . . . . . . . 233

Directory edit function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Selection of directories . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

Edition of directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

File editing function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

Format of files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Easy file selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Multiple selection of files . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Commands relating to files . . . . . . . . . . . . . . . . . . . . . . . . 236

Saving Files from the Explorer . . . . . . . . . . . . . . . . . . . . . . 237

User Manual 780000102/19 xvii

Table of Contents

Chapter 15

Chapter 16

xviii

Loading files and displaying traces . . . . . . . . . . . . . . . . . . 238

Simple loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Load with configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Load Trace + Info (with OTDR files only) . . . . . . . . . . . . . 239

Display of several traces in overlay . . . . . . . . . . . . . . . . . . 239

Link Manager Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Editing function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

CD-Rom burning (MTS / T-BERD 8000 only) . . . . . . . . . . 242

Macros 245

Calling the Macro function . . . . . . . . . . . . . . . . . . . . . . . . 246

Macro recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

Standard macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

File macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Adding interaction to your macro . . . . . . . . . . . . . . . . . . . . 248

Inserting a dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Inserting a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Inserting a pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Renaming a macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

The «Overwrite Config.» setting . . . . . . . . . . . . . . . . . . . . . 249

Replacing a macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Removing a macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Default macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

How to use the default macro . . . . . . . . . . . . . . . . . . . . . . 249

How to set a macro as default . . . . . . . . . . . . . . . . . . . . . . 249

Macro playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

Storing a macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Technical specifications 253

OTDR Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254

OTDR measurements characteristics . . . . . . . . . . . . . . . . 254

OTDR measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Distance Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258

WDM Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Typical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Dimensions and weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

PMD Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

User Manual 780000102/19

Chapter 17

Table of Contents

ODM Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

ODM MR Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

High Resolution Dispersion test solution . . . . . . . . . . . . 265

BBS Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

Information on «fiber» modules 82LFSM2 / 82LFSM4 . . 267

MTAU modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267

OFI modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Standalone power meter . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Options and accessories 271

References of measurement plug-ins . . . . . . . . . . . . . . . 272

OTDR Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

WDM / PMD Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274

ODM Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275

BBS Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275

MTAU Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275

OFI Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

Launch Fiber Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

User manual references . . . . . . . . . . . . . . . . . . . . . . . . . . 276

References of optical connectors and adapters . . . . . . . 276

References of result processing software . . . . . . . . . . . 278

Appendix A

Index

RoHS Information 279

Concerned products: 8100 modules series . . . . . . . . . . 280

Concerned products: OTDR 8100 Modules Series . . . . . 281

Concerned products: All OTDR VLR 8100 Modules Series .

282

Concerned products: PMD and WDM 8100 Modules Series

283

285

User Manual 780000102/19 xix

Table of Contents

xx User Manual 780000102/19

About this guide

The MTS/TBERD series of JDSU provides a portable, modular platform designed for the construction, validation and maintenance of optical fiber networks.

The modules described in this document are applicable for the following platforms:

– MTS 8000

– T-BERD 8000

– MTS 6000

– T-BERD 6000

The topics discussed in this chapter are as follows:

–

“Purpose and scope” on page xxii

–

“Assumptions” on page xxii

–

“Technical assistance” on page xxii

–

“Recycling Information” on page xxiii

–

“Conventions” on page xxiii

User Manual 780000102/19 xxi

About this guide

Purpose and scope

Purpose and scope

The purpose of this guide is to help you successfully use the MTS / T-

BERD features and capabilities. This guide includes task-based instructions that describe how to install, configure, use, and troubleshoot the

MTS / T-BERD. Additionally, this guide provides a complete description of JDSU’s warranty, services, and repair information, including terms and conditions of the licensing agreement.

Assumptions

This guide is intended for novice, intermediate, and experienced users who want to use the MTS / T-BERD effectively and efficiently. We are assuming that you are familiar with basic telecommunication concepts and terminology.

Technical assistance

If you need assistance or have questions related to the use of this product, call or e-mail JDSU’s Technical Assistance Center for customer support.

Table 1

Technical assistance centers

Region

Americas



Telecom Products

Europe, Africa, and

Mid-East

Asia and the Pacific

Southeast Asia, Australia, and New

Zealand

All others

Phone Number

866 228 3762



World Wide: 301 353 1550

+49 (0) 7121 86 1345



(Europe)

+33 (0) 1 30 81 50 60



(JDSU France)

+852 2892 0990



(Hong Kong)

+86 10 6833 7477



(Beijing-China)

866 228 3762 [email protected]

“Principle of reflectometry measurements” on page 2

xxii User Manual 780000102/19

About this guide

Recycling Information

During off-hours, you can request assistance by doing one of the following:

– leave a voice mail message at the Technical Assistance number in your region

– e-mail North American Technical Assistance Center, [email protected]

, or European Technical Assistance Center, [email protected]

– submit your question using our online Technical Assistance Request form at www.jdsu.com

Recycling Information

JDSU recommends that customers dispose of their instruments and peripherals in an environnmentally sound manner. Potential methods include reuse of parts or whole products and recycling of products components, and/or materials.

Waste Electrical and electronic Equipment (WEEE) Directive

In the European Union, this label indicates that this product should not be disposed of with household waste. Il should be deposited at an appropriate facility to enable recovery and recycling.

Conventions

This guide uses naming conventions and symbols, as described in the following tables.

Table 2

Typographical conventions

Description

User interface actions appear in this

typeface

Buttons or switches that you press on a unit appear in this

YPEFACE

Code and output messages appear in this typeface.

Example

On the Status bar, click

Start

Press the

switch.

All results okay

User Manual 780000102/19 xxiii

About this guide

Conventions

Table 2

Typographical conventions (Continued)

Description

Text you must type exactly as shown appears in this

typeface

Variables appear in this type-

face

Book references appear in this

typeface

A vertical bar | means “or”: only one option can appear in a single command.

Square brackets [ ] indicate an optional argument.

Slanted brackets < > group required arguments.

Example

Type:

a:\set.exe

in the dialog box.

Type the new hostname.

Refer to Newton’s Telecom

Dictionary

platform [a|b|e] login [platform name]

Table 3

Keyboard and menu conventions

Description

A plus sign + indicates simultaneous keystrokes.

A comma indicates consecutive key strokes.

A slanted bracket indicates choosing a submenu from menu.

Example

Press

Ctrl+s

Press

Alt+f,s

On the menu bar, click



Start > Program Files

Table 4

Symbol conventions

This symbol represents a general hazard.

xxiv User Manual 780000102/19

This symbol represents a risk of electrical shock.

About this guide

Conventions

NOTE

This symbol represents a Note indicating related information or tip.

This symbol, located on the equipment or its packaging, indicates that the equipment must not be disposed of in a land-fill site or as municipal waste, and should be disposed of according to your national regulations.

Table 5

Safety definitions

WARNING

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

User Manual 780000102/19 xxv

About this guide

Conventions

xxvi User Manual 780000102/19

Chapter 1

Principles of measurement

This chapter gives the principles of the measurements made by the reflectometer (OTDR) plug-ins, OSA spectrum analyzers (WDM technology) and PMD analyzers (Polarization mode dispersion).

The topics discussed in this chapter are as follows:

–

–

“Principle of bi-directional measurement” on page 4

–

“Principle of WDM system testing” on page 5

–

“PMD principle” on page 7

–

“Principle of measurement of Chromatic Dispersion (CD ODM) using phase shift method” on page 9

–

“Principle of optical power and attenuation measurements (OFI)” on page 10

–

“Standards and l0 for different types of fiber” on page 11

User Manual 780000102/19 1

Chapter 1

Principles of measurement

Principle of reflectometry measurements

Principle of reflectometry measurements

Optical time domain reflectometry consists in injecting a light pulse into one end of the optical fiber to be analyzed and observing, at the same end, the optical intensity passing through the fiber in the opposite direction to the propagation of the pulse.



The signal detected is exponentially diminishing in form, typical of the phenomenon of backscattering, with superimposed peaks due to reflections from the ends of the fiber or other variations in the refractive index.

Fig. 1

Trace showing typical backscattering

Information yielded by the measurement

From a backscatter trace it is possible, in particular, to determine the position of a section of fiber within a link. The measurement result must reveal:

– the attenuation

– the location of faults, by their distance from a point of origin,

– attenuation with respect to distance (dB/km)

– the reflectance of a reflective event or a link.

User Manual 780000102/19

Chapter 1

Principles of measurement

Principle of reflectometry measurements

To locate faults, a reflectometer measures only time. Consequently, group velocity must be introduced in order to determine the distance of the location. This is done by introducing the refractive index of the fiber into the instrument.

Validity of

Measurement

UTI-T, in recommendations G.650, G.651 and G.652, give backscatter measurement as an alternative method for measuring attenuation, the method of reference being the cut fiber.

The field of application of backscatter is not limited, but the conditions for application of this method are nevertheless stipulated:

– injection conditions: Fresnel reflections must be limited at fiber input.

– a high-power source (laser) should be used.

– receiver bandwidth should be chosen to achieve a compromise between pulse rise time and noise level.

– backscatter power should be represented on a logarithmic scale.

Reflectance

Reflectance is a value with which the coefficient of reflection of a reflecting optical element can be quantified. It is defined as the ratio of the power reflected by the element over the incident power.

These reflections are due to variations in refractive index all along the optical link in certain telecommunications applications. If they are not controlled, they may degrade the performance of the system by perturbing the operation of the emitting laser (especially DFB lasers) or may generate interference noise in the receiver by multiple reflections.

The reflectometer is particularly well suited to the measurement of discrete reflectances on an optical fiber link. To calculate the coefficient of reflection, it is necessary to measure the total amplitude of the Fresnel reflection generated and then to apply a conversion formula to obtain the reflectance value.

This formula takes into account:

– the total amplitude of the reflection measured by the reflectometer.

– the pulse width used to measure the amplitude of the reflection (in nanoseconds)

– the backscatter coefficient of the fiber used:

User Manual 780000102/19 3

Chapter 1

Principles of measurement

Principle of bi-directional measurement

– typical values of the backscatter coefficient for a pulse of 1 ns and



- for a single-mode fiber:-79 dB to 1310 nm



-81 dB to 1550 nm and 1625 nm



- for a multi-mode fiber:-70 dB to 850 nm



-75 dB to 1300 nm

NOTE

To measure the widest range of reflection coefficient, it is necessary to insert a variable optical attenuator between the reflectometer and the link to be tested. This attenuator enables the level of the trace to be adjusted so as to avoid saturation of the reflectometer by the reflection to be evaluated.

Principle of bi-directional measurement

If fibers with different mode-field diameters (core size etc.) are joined, the resulting OTDR trace waveform can show a higher backscattering level.

This is due to the increased level of backscattered signal reflected back to the OTDR in the downstream fiber.

Fig. 2

Normal splice

This phenomenon can occur when jointing different types of fiber in multimode or 2 fibers with different backscattering coefficients.

4 User Manual 780000102/19

Chapter 1

Principles of measurement

Principle of WDM system testing

Fig. 3

Positive splice (A ->B) / Negative Splice (B -> A)

The sum gives the bi-directional or average splice loss value:

S =

S1 +

Bi-directionnal measurement consists in performing a measurement from the extremity of fiber A, then another measurement from the extremity of fiber B, finally get events of both traces and calculate the average for all slope, splice and reflectance measurements.

Principle of WDM system testing

WDM (Wavelength Division Multiplex) technology is a very effective means of increasing the transmission of fibers, as it demands neither the installation of new links, nor any increase in transmission speed. The data are transmitted along the fiber at different wavelengths, each wavelength (or channel) transmitting a signal. The channels are defined according to the the G-692 recommendations of the ITU-T.

This technology demands new measurements, since it is important, during the installation and maintenance of WDM systems, to check the following parameters:

Presence of the channels at the corresponding wavelengths, with no drift

Correct channel power levels, without power variation

Satisfactory signal-to-noise ratio (SNR): its value is obtained by measuring the ratio of channel peak power to the noise power level of the ASE

signal to the right and/or left of the carrier. As a general

1.Amplified Spontaneous Emission

User Manual 780000102/19 5

Chapter 1

Principles of measurement

Principle of WDM system testing

rule, the noise measurement point chosen is the calculated midpoint between two adjacent channels. The noise power level measured is converted to a standard bandwidth of 0.1 nm.

The most important item of equipment for carrying out these tests on

WDM systems is the optical spectrum analyzer (OSA). It can be connected at critical measurement points in the WDM system, to the ends of the links or to the amplifier locations.

Measurement results

The optical analyzer displays a spectrum representing all the channels.

The measurement results are shown in the form of a complete spectrum analysis and a table of the parameters relating to each carrier.

The optical spectrum analyzer performs automatic detection and measurements on each channel.

The results of a scanned spectrum (trace) are:

– the amount of automatec detected channels depend on a adjustable power threshold

– the total optical power (dBm or Watt) at the selected sweep range:

– the wavelength

– the wavelength spacing between channels

– the power level

– the noise at 0.1nm noise acquisition bandwidth

– the SNR signal-to-noise ratio

– the P/Pcomp

The sweep modes Statistics and Drift measure and report time depended changes at wavelength, power and SNR of the signal in a min-, maxtable.

To qualify signal and components special measurement types supports these characterisation: system data signals, EDFAs, DFB-Lasers, LEDsources, FP-Lasers.

Measurement types: WDM, DFB, EDFA, LED, FPL, filter/DROP

DFB analysis

In order to ensure the best BER ratio, it is sometimes necessary to be able to test DFB lasers, widely used in DWDM technology.

DFB measurements are the following :

6 User Manual 780000102/19

Chapter 1

Principles of measurement

PMD principle

–

SMSR

Mode Offset

Side mode Suppression Ratio : the amplitude difference between the main spectral component and the largest side mode.

Wavalength separation (expressed in nm) between the main spectral component and the

SMSR mode.

– Peak Amplitude The power level of the main spectral component of the DFB laser.

– Bandwidth Displayed bandwidth of the main spectral component of the DFB laser.

Peak of the main spectral component

Bandwidth

Side Mode Supression

Ratio

Fig. 4

Min offset

DFB measurements

Max offset

PMD principle

The transmission rate and range are two of the most important parameters of fiber optics paths and must therefore be optimized. And, since more and more paths (including those already installed) are being used for transmitting Wavelength Division Multiplex (WDM) signals or for bit rates of 10 Gbit/s, it is becoming all the more important to determine the

Polarization Mode Dispersion (PMD).

PMD, which is the basic property of single-mode fibers, in particular affects the magnitude of the transmission rate. It results from the difference in propagation times of the energy of a given wavelength, which is split into two polarization layers that are at right angles to each other (as

User Manual 780000102/19 7

Chapter 1

Principles of measurement

PMD principle

shown in the below diagram). The main causes of this birefringence are non-circularities of the fiber itself and external stress on the fiber (macrobending, micro-bending, twist and temperature variations).

Singl e-Mo de fib er sp an

DGD

Fig. 5

Example of a time delay between two polarization layers

The PMD is also referred to as mean value of all Differential Group

Delays (DGD) in picoseconds (ps) or as the DGD coefficient in ps/

km.

The mean DGD causes the transmission pulse to broaden when transmitted along the fiber, generating distortion, which in turns increases the bit-error-rate (BER) of the optical system. The consequence is that the

PMD limits the transmission bit rate on a link. It is then important to know the PMD values to calculate what are the bit rate limits of the links.

Method used to measure the

PMD

The method used to measure the PMD is based on the Fixed Analyzer

Method

which requires a broadband polarized source at one extremity, and a polarized (variable) Optical Spectrum Analyzer (OSA) at the other extremity.

Broadband light source

(SLED)

Fixed

Polarizer

Rotatable



Polarizer

Optical Spectrum

Analyser (OSA)

Link under test

Fig. 6

Fixed Analyzer Method used to measure the PMD

The method used to measure PMD is the Fast Fourier Transform Method

(FFT).

From the spectrum, the mean period of the amplitude modulation is measured.

1.This is standardized by the ANSI/TIA/EIA FOTP-113 Polarization Mode Disper-

sion Measurement for Single-Mode Optical Fibers by the Fixed Analyzer Method.

User Manual 780000102/19

Chapter 1

Principles of measurement

Principle of measurement of Chromatic Dispersion (CD ODM) using phase shift method

The Fast Fourier Transform Method into a time distribution will give a

Gaussian curve and the mean DGD value is determined from this curve

(for fiber links with strong mode coupling).

It is not necessary to modify the polarization angle of the analyzer when strong mode coupling is used. For weak mode coupling, an angle could be selected to get the maximum amplitude of the modulation.

The instrument should have a higher dynamic range than the link itself.

A 35 dB dynamic range is usually enough for most of the applications, and 45 dB should be used for very long distance networks.

The measurement range of the PMD should be linked with the transmission rate. For WDM applications, it should be between 0.1 ps to 60 ps so that measurement can be carried out for bit rates between 2.5 and 40

Gbit/s. The table below indicates the maximum permitted PMD values for various bit rates.

Bit rate (Gbit/s)

2.5

10Gbps Ethernet

Maximum PMD

(ps)

2.5

PMD coefficient (ps/

km)

400 km cable length

< 2

< 0.5

< 0.125

–

Tables at the end of chapter gives information about the appropriate

standards and limits.

Principle of measurement of Chromatic Dispersion (CD ODM) using phase shift method

The Phase shift method

A modulated broadband light is sent over the Fiber Under Test. The phase of the test signal is compared to the phase of the reference signal.

The measured value is the group delay, corresponding to a wavelength interval between the reference phase and the test wavelength phase. It is measured in the frequency domain, by detecting, recording and

User Manual 780000102/19 9

Chapter 1

Principles of measurement

Principle of optical power and attenuation measurements (OFI)

processing the phase shift of The modulated signals. The fibre chromatic dispersion is derived from the measurement of the relative group delay using an approximation formula.

Fig. 7

CD ODM measurement using phase shift method

Principle of optical power and attenuation measurements (OFI)

Power measurement

A power meter, is all that is needed to measure emitted or received power:

– to measure emitted power, connect the power meter directly to the output of the optical emitter;

– to measure the power at the input of an optical receiver, the power meter is connected to the end of the fiber, at the point where the optical receiver would be connected.

Attenuation measurements

(optical link loss)

For measurement of the attenuation of power in a complete link or in elements such as sections of fiber, connections or optical components, a light source and a power meter are required.

This attenuation is usually deduced from the measurement of optical power at two points:

Laser light source of the

Base Unit

1 2

Power meter of the Base Unit

Reference fiber

Link under test

Attenuation A

(dB)

= P1

(dBm)

- P2

(dBm)

To perform accurate measurements, the following conditions are vital

User Manual 780000102/19

Chapter 1

Principles of measurement

Standards and l0 for different types of fiber

– Use one of the light sources of the LTS or a light source which is stable both in time and as a function of temperature.

– Make sure that all connections and fibers and the receiving cell are perfectly clean.

– Use a reference link between the laser source and the test subject.

If several measurements are to be made under identical light injection conditions, this reference fiber must not be disconnected during the period while measurements are taking place.

Insertion loss method

The power meter is first connected to the laser source via the reference fiber: P1 is measured.

Then the fiber to be tested is inserted between the reference fiber and the power meter: P2 is measured.

The difference between P2 and P1 gives the attenuation of the fiber under test.

It is preferable to use the same type of connector at both ends of the fiber being tested, to ensure the same connection conditions for measuring P1 and P2.

Standards and

0 for different types of fiber

Fibre

non-offset dispersion

Standard ITU/Y

Standard IEC

ITU-T G.652

IEC 60793-1-1

 type B1

Standard TIA/EIA Iva

Approximate



0 .

1310 nm

offset dispersion

ITU-T G.653

IEC 60793-1-1

 type B2

IVb

1550 nm

non-zero or homogeneous offset dispersion

ITU-T G.655

IEC 60793-1-1

 type B3

IVb

1500 nm or indefinite

Most suitable method of approximation according to trace zone

Single Mode Fiber Type ITU-T

Dispersion unshifted fiber

(standard fiber)

G.652

Wavelength Range

around 1310 nm

1550 nm region

Full wavelength range

(1260 - 1640 nm)

Approximation

3-term Sellmeier

Quadratic

5-term Sellmeier

User Manual 780000102/19 11

Chapter 1

Principles of measurement

Standards and l0 for different types of fiber

Single Mode Fiber Type ITU-T

Dispersion shifted fiber

Non-dispersion shifted fiber

Wideband NZDSF

Mixed fibers

Wavelength Range

G.653

G.655

G.656

1550 nm region

Full wavelength range

(1260 - 1640 nm)

1550 nm region

Full wavelength range

(1260 - 1640 nm)

Full wavelength range

(1260 - 1640 nm) including DCF 1550 nm region

Full wavelength range

(1260 - 1640 nm)

Approximation

Quadratic

5-term Sellmeier

Quadratic

5-term Sellmeier

Quadratic

5-term Sellmeier

12 User Manual 780000102/19

Chapter 2

Getting started

The topics discussed in this chapter are as follows:

–

“Unpacking the device - Precautions” on page 14

–

“Installing a plug-in in a receptacle and removing it” on page 14

–

“Universal connectors and adapters” on page 15

User Manual 780000102/19 13

Chapter 2

Getting started

Unpacking the device - Precautions

Unpacking the device - Precautions

We suggest that you keep the original packing material. It is designed for reuse (unless it is damaged during shipping). Using the original packing material ensures that the device is properly protected during shipping.

If another packaging is used (for returning the equipment for example),

JDSU cannot give warranty on good protection of the equipment.

If needed, you can obtain appropriate packing materials by contacting

JDSU Technical Assistance Center.

Installing a plug-in in a receptacle and removing it

A plug-in may be inserted into either of the two slots provided for the purpose.

When a slot is vacant, it is closed by means of a cover-plate fitted with two captive screws like those on the plug-ins.

Fig. 8

Captive screws securing the plug-in

Rear view of the Base Unit (example)

Inserting a plug-in into receptacle

The Base Unit must be switched off, and if it has a mains power supply, the adapter cable must be unplugged.

Slide the plug-in into its slot.

User Manual 780000102/19

Chapter 2

Getting started

Universal connectors and adapters

When it is fully home, press against the screen-printed surface of the plug-in while tightening the the securing screws. The screenprinted surface of the plug-in must be flush with that of the receptacle.

Make sure that the two large captive screws of the plug-in are screwed fully home.

NOTE

UHD plug-ins use very powerful lasers : they must be connected exclusively to optical connectors equiped with zirconium ferules.

Using connectors equiped with metallic ferrules could damage the plug-in connector.

Removing a plug-in from a receptacle

The Base Unit must be switched off, and if it has a mains power supply, the adapter cable must be unplugged.

Completely unscrew (up to the stop) the two captive screws securing the plug-in.

Carefully slide the plug-in out of its slot.

Universal connectors and adapters

Fiber Optic plug-ins may come equipped with a universal connector and adapter selected at time of order.

Adapter types

JDSU offers 5 different adapters, all compatible with this connector, allowing the user to switch from one adapter to another according to which fiber type he intends to work with.

Adapter types supplied are : FC, SC, DIN, ST and LC.

User Manual 780000102/19 15

Chapter 2

Getting started

Universal connectors and adapters

FC Adapter (EUFCAD)

DIN Adapter (EUDINAD)

LC Adapter (EULCAD)

Fig. 9

PC or APC Connector

ST Adapter (EUSTAD)

SC Adapter (EUSCAD)

5 different types of adapters may be mounted on the universal connector

Switching adapter type

In order to switch from an adapter to another, proceed as shown.

Pull out in the direction of the arrow in order to release the adapter from the lug holes

To place an adapter, position the handle as shown in order to engage with the the lugs, push hard and pull the handle down

Fig. 10

Removing and refitting an adapter

Cleaning the universal connector

Remove the adapter in order to access the ferrule and clean it using a cotton swab.

16 User Manual 780000102/19

Chapter 3

Graphical User Interface

This chapter describes the graphical user interface of the Base Unit used with the optical measurement plug-ins (OTDR, WDM, etc.).

The topics discussed in this chapter are as follows:

–

“Display screen” on page 18

–

“Using an external keyboard, mouse and screen touch (options)” on page 21

–

“Functions relating to display of a trace” on page 23

–

“Overlay trace function” on page 26

–

“Saving when the instrument is shut down” on page 29

User Manual 780000102/19 17

Chapter 3

Graphical User Interface

Display screen

Display screen

The display screen is divided into a number of different zones. Starting from the top, these are:

– a status bar in which various icons indicate the current functions:

– a bar displaying a scaled-down representation of the trace, showing the zoom zone and the parameters of the measurement on display

(signature of the measurement).

– the main part of the screen, displaying a menu or the page of results.

– tabs enabling the user to switch from one function to another

(OTDR, WDM, power meter, etc.), as required.

At the right-hand side of the screen, softkeys give access to the various commands. Their action depends on the current function and configuration.

Fig. 11

Example of display of results (with OTDR plug-in)

Top status bar

The top status bar on the screen shows, on the right, current date and time, and in the form of icons:

– the type of power supply: mains or battery, and if the power supply is on battery the level of charge (see Battery management in chapter 2 from the Base Unit manual)

User Manual 780000102/19

Chapter 3

Graphical User Interface

Display screen

– if the Talkset option is present and the telephone is activated, the

– if a remote screen is selected, the icon more are working on the same Base Unit).

(or

– if transfer of data is in progress, the icon

– if a printing process is in progress, the icon

if two users or

– if a data saving is in progress, the icon

– if the Web Browser application is active, the icon

– if a USB key is connedcted onto the Platform, the icon

Mini-trace

The

File

menu and the

Results

page can include a scaled-down representation of the trace which may show the location of the zoom zone corresponding to the main display. The part of the trace shown in the main display is boxed on the mini-trace.

This mini-trace will only appear if the trace originated from an Base Unit.

Other Bellcore files read on this instrument do not contain the information needed to display it.

Signature of the measurement

A status bar repeats the parameters of the measurement, and in some cases:

– the position of the cursors

– a comment

– the name of the file when the result is recalled from a memory.

Main display zone

The central zone of the screen can display the configuration of the instrument or the measurement, the memory explorer of the Base Unit, the measurement results, etc. Refer to the chapter dealing with the measurement in progress.

Tabs

When the instrument performs several different functions (OTDR, WDM,

Power Meter, etc.), the various configuration or results pages are accessible from tabs. To change from one tab to another, the button selecting the page must be pressed. To example:

– on the Results page, to change from one tab to the other, press the

ESULTS

button

– on the measurement configuration page, to change from one tab to the other, press the

ETUP

button

User Manual 780000102/19 19

Chapter 3

Graphical User Interface

Display screen

– On the file configuration page, to change from one tab to the other, press the

ILE

button.

NOTE

There is a tab for each different type of measurement: OTDR SM,

OTDR MM, OSA, Power Meter... The tab of a function is displayed if and only if a plug-in corresponding to this type of measurement has been inserted in the instrument, or if a file of the type of this measurement is open. If two plug-ins of the same measurement type are present, then only one plug-in is "active", so only one tab will appear for this measurement. To change the active plug-in, go to the SYSTEM screen and select it there.

A small icon may appear in the left corner of each tab, according to the status of the corresponding module.

The icon signification is the following :

– No icon : the function is used in a read-only mode (no module), or the module has not been selected.

– Gray icon : the function has been selected but the corresponding module does not currently perform an acquisition.

– Green icon : the function has been selected and the corresponding module currently performs an acquisition.

Soft keys

The 7 softkeys at the side depend on the current configuration and the context.

Their use is symbolized by an icon.

Icons

shows that the action is immediate when the key is pressed.

 shows that the key gives access to a sub-menu.

 shows that the key will quit the sub-menu.



(green direction keys) shows that the function selected by the key will be controlled by the direction keys.

(green confirmation key) shows that the function selected will be controlled by the confirmation key.

User Manual 780000102/19

Chapter 3

Graphical User Interface

Using an external keyboard, mouse and screen touch (options)

Selection keys

The selection may be exclusive (only one choice possible) or non-exclusive (more than one option available at the same time):

This key offers two exclusive options. The change of function occurs immediately, the first time the key is pressed.

This key offers two non-exclusive options. Pressing the key repeatedly modifies the choice.

Color of the keys

When a selection key is associated with direction keys or the confirmation key:

– if the function is not selected, the key is dark blue.

– pressing the key once selects the function. The key turns lighter in color to show the user that the direction keys are assigned to it.

Pressing more times will modify the choice made using the key.

Using an external keyboard, mouse and screen touch

(options)

The external keyboard facilitates input of:

– alphanumerical configuration parameters

– comments in the File menu

– notes in the table of results

– editing characters

The mouse can be used instead of the direction keys to scroll through menus and make a selection.

Connect the keyboard and mouse to the USB connectors.

The external keyboard delivered with MTS/T-BERD 8000/6000/

6000A is a QWERTY keyboard.

Virtual control buttons bar

It is possible to emulate hard keys with Virtual Control buttons

To display these buttons, click once on the top of the screen in the status bar, at the same height than the date and time.

User Manual 780000102/19 21

Chapter 3

Graphical User Interface

Using an external keyboard, mouse and screen touch (options)

Fig. 12

Virtual control buttons bar

The virtual control buttons bar is displayed during a few seconds. You may click on any of these buttons to obtain exactly the same results than using the real buttons in the front panel of the Base Unit.

The virtual control buttons bar can not be displayed within desktop applications (see the User Manual of the Base Unit).

NOTE

This virtual control buttons bar is especially useful when the Base Unit screen is exported on a remote PC (see the User Manual of the Base

Unit).

Equivalence between external keyboard and

Base Unit

Although it is intended primarily to replace the Edit menu of the Base

Unit, the external keyboard can replace all the buttons and keys of the

Base Unit except the

button

– The menu keys to the right of the screen are replaced by the function keys

– The buttons below the screen are equivalent to

Ctrl +

a letter (see table below).

– The direction keys have the same function on the external keyboard and on the Base Unit.

Function on the Base Unit

SYSTEM

SET-UP

FILE

RESULTS

START/STOP

SCRIPT (Macro)

Menu keys 1 to 7 (from top to bottom)

External keyboard

Ctrl + Y

Ctrl + U

Ctrl + P

Ctrl + F

Ctrl + R

Ctrl + S

Ctrl + M



 F7

User Manual 780000102/19

Chapter 3

Graphical User Interface

Functions relating to display of a trace

Function on the Base Unit

AVE AND QUIT

XIT

)

UIT WITHOUT SAVING

BORT

)

External keyboard

Entrée/Enter

Escape/Echap.

1. The print key is not available on the MTS/T-BERD 6000, however the function is available on the Platform by pushing simultaneously left and right arrow keys.

Editing text using the external keyboard

To use the external keyboard to insert a name or identification in the setup menus, or a Note in the table of results:

– press

Enter

to go into the Edit menu

– type the text

– press

Enter

to leave the Edit menu.

Pressing the

Esc

key will close the Edit menu without saving the text.

Functions relating to display of a trace

The trace acquired or recalled from a memory is displayed on the Results page: see example on

Figure 11 on page 18 .

Various functions common to many plug-ins (OTDR, OSA etc.) can be used to modify the display of the trace (Cursors, Zoom/Shift, Event/

Trace, Trace/Table, Full scale, etc.). The role of the direction keys and the confirmation key will depend on the function chosen.

Display of the results on the trace

Each event (OTDR measurement) or channel (WDM measurement) detected is represented under the trace by a serial number.

The results of the measurements can be written on the trace.

Depending on the options chosen in the

ETUP

menu on

Result Screen

> Results On Trace

, it is possible to show on the trace, for an OTDR measurement:

– "No" results,

– or "All" the results (value and position)

– or only the markers showing the position of the events measured

User Manual 780000102/19 23

Chapter 3

Graphical User Interface

Functions relating to display of a trace

When there is saturation for a reflective event (OTDR measurement), the maximum value measured is displayed with the sign >. This shows that the actual reflectance is greater than the value shown (for example, if

R >-29.5 dB is displayed, the reflectance could be -18 dB)

The reflectance of a ghost event (OTDR measurement) is displayed in brackets on the trace.

Cursors

The vertical cursors A and B are used in the Zoom and Shift functions to position or delete markers.

The cursors A and B are represented by vertical lines of different colors:

– in a solid line if the cursor is selected.

– in a dotted line if the cursor is not selected.

Positioning the cursor

When a trace is displayed, the key <Cursor A/Cursor B> can be used to select one or both cursors.

The direction keys

and move the selected cursor(s) along the trace.

Above the trace are shown the co-ordinates of the points of intersection of the cursors A and B with the trace, together with the distance between the two points.

When a selected cursor touches the right or left-hand edge of the screen, the trace starts to scroll horizontally to maintain display of this cursor.

If an unselected cursor has been moved off-screen by a zoom, it can be brought back on to the screen by selecting it and then pressing one of the direction keys

or It will then appear on whichever edge of the screen is closest to its position.

When the cursor function is selected, the keys

and move the trace vertically.

Selection of the type of cursor

(OSA)

Two types of cursors can be defined:

Cursor on X: only a vertical bar is present.

Cursor on X and Y: there is a vertical bar and a horizontal bar. The intersection between these two bars is placed on the trace.

To display the type of cursor selected, click on

Advanced

. Then select the key

CursorX/CursorY

to modify the current choice. Each click on this key will alternatively insert or delete the check mark against

Cursor Y

24 User Manual 780000102/19

Chapter 3

Graphical User Interface

Functions relating to display of a trace

Zoom and Shift functions

Zoom function

The Zoom function is used to analyze part of the trace in greater detail.

In association with Event (OTDR) or Channel (WDM) it enables rapid checking of a succession of events or channels.

The zoom is centred on the cursor selected. If the two cursors A and B are selected, the zoom is centred midway between the two cursors.

The position of the section of trace displayed with respect to the complete trace is represented by a red rectangle on the mini-trace at the top lefthand corner of the screen.

To define a zoom on the trace:

– select cursor A or B and center it on the zone to be examined

– on the

Shift/Zoom

key, select the

Zoom

function.

– use the





key to increase or reduce the zoom factor.

Zooming on the different events in succession (OTDR)

– Zoom on one of the events detected as shown above.

– On the

Trace/Event

key, select the

Event

function

– Use the and

 keys to move the zoom on to the successive events.

Zooming on the different channels in succession (OSA)

– Zoom on one of the channels as shown above.

– On the

Trace/Channel

key, select the

Channel

function

Use the and

 keys to move the zoom on to the successive channels.

Shift function

The Shift function is used to displace the displayed section of the trace by pressing the direction keys.

The horizontal shift is performed maintaining the point of intersection between the trace and the selected cursor at the same level, scrolling the trace horizontally while following it vertically, so that it never goes off the screen.

To use this function:

– Select the zoom factor as described above.

– Choose cursor and cursor position.

User Manual 780000102/19 25

Chapter 3

Graphical User Interface

Overlay trace function

– On the

Zoom/Shift

key, select

Shift

– Use the direction keys to shift the trace in the desired direction.

NOTE

For a Chromatic Dispersion curve, click on

Config

in order to display the zoom and shift functions.

Zoom Auto (OTDR)

The

Zoom Auto

key alows to go to an optimized display of the trace.

Full scale (OSA /

PMD / AP)

To display the entire trace, with no zoom or displacement:

– either press the

Full Scale

key

– or, with

Trace

selected on the

Trace/Event

key, press the button.

Overlay trace function

This very useful function enables up to eight traces to be displayed on the screen at once:

– either to compare traces acquired on a number of different fibers in the same cable,

– or to observe changes over time in traces taken of one and the same fiber.

– or to compare both curves get for each way of propagation in the o/

Back mode.

For this purpose, the Base Unit possesses an overlay memory which can store:

– the current trace, for comparison with further traces to be acquired subsequently,

– or reference traces previously saved on floppy disk or CD-ROM or in the internal memory, for comparison with the current trace,

– or traces of different wavelengths for comparative purposes

(OTDR).

26 User Manual 780000102/19

Chapter 3

Graphical User Interface

Overlay trace function

Fig. 13

Example of overlaid traces

Overlaying several traces stored in memory

To display up to 8 traces from the memory, deleting the current trace or traces already loaded:

Press the

ILE

button.

On the

Menu/Explorer

key, select

Explorer

Select the files of the traces for display (see

"Multiple selection of files" page 235

Press the

Load

key .

Press View trace(s) or

Load traces + config

: as the traces are loaded, they cease to be highlighted in the list of files.

When loading is complete, the

Results

screen appears: the first trace selected is the active trace, the other traces being overlaid.

Display of traces in overlay

– The traces are shown in different colors (the active trace is green).

– Their serial numbers are repeated at the top of the screen.

– The OTDR markers are referenced on the active trace by the symbol , and on the other traces by vertical dashes.

User Manual 780000102/19 27

Chapter 3

Graphical User Interface

Overlay trace function

Adding traces in overlay

With OTDR traces

With one or more traces already displayed, to add further traces to the display (the number of traces displayed cannot exceed 8):

– Click on the key Set/Reset Ref. or Set/Reset All Ref. to define the selected trace or all traces displayed as reference trace(s) (see

"Reference Trace function" page 71 )..

– Press the

ILE

button, and in the Explorer menu, select the files of

the traces to be added (see "Multiple selection of files" page 235 ).

– Press the

Load

key

– Press the

View Trace(s)

Load trace + config

key: as the traces are loaded, they cease to be highlighted in the list of files.

– When loading is complete, the new traces are displayed in overlay with those that were already there.

NOTE

If the number of files selected exceeds the display capacity, a message gives warning that loading will be incomplete: only the trace or traces selected first will be displayed, up to the permitted limit of 8 traces.

Overlaying the current trace (with

OSA traces)

To copy the current trace into the overlay memory, proceed as follows:

– On the

ESULTS

page

, press the

Advanced

key, then

Overlay

, then

Set New Trace

The current trace is copied into the overlay memory: represented in a different color, it is automatically offset with respect to the new trace.

– A new acquisition can then be started.

NOTE

In the case of Multi-trace display with multiple wavelength acquisition: when the

TART

key is pressed, all the traces displayed are deleted to leave room for the new acquisitions.

Swapping overlay traces

Measurements can only be made on the active trace and not on overlaid traces. To make measurements on a trace in overlay, it must first be swapped with the active trace. To do this, press the

Trace

key, then the

and keys, as many times as necessary.

User Manual 780000102/19

Chapter 3

Graphical User Interface

Saving when the instrument is shut down

Changing the traces position

(OSA)

Once a trace is displayed in overlay, the traces can be adjusted according to the Y axis:

–

Y Reset

: all traces are on the the same level at the intersection with the active cursor.

–

Y Shift

: Each trace is shifted from 5 dB from the other.

–

Y Exact

: the traces displayed are on the same position according to their injection level.

Trace resulting from the difference between two traces (OSA)

It is possible to obtain the trace corresponding to the point-by-point difference between the current trace and the trace in overlay (if only two traces are displayed simultaneously).

To do this, press the

2 Traces Diff.

key. The screen will then display the two traces in overlay and the trace resulting from the "Difference".

Removing a trace

Removing the current trace in overlay

It is possible to remove a trace displayed. To do this, first select it (see previous paragraph), then press

Remove Current Trace

Removing all the the traces in overlay

To remove all the traces except the current trace, press the key

Remove

Other Traces

Quitting the overlay menu

To quit the overlay menu, press the

Exit

key.

Saving when the instrument is shut down

When the instrument is switched off, all the parameters and all the traces are saved, and will all be recalled at the next start-up.

User Manual 780000102/19 29

Chapter 3

Graphical User Interface

Saving when the instrument is shut down

30 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Pressing the

TART

TOP

key is all that is needed to start or stop a measurement. However, it is necessary to configure the measurement and the type of results desired.

This chapter describes the different stages in a reflectometry measurement made using an OTDR plug-in and the OTDR function of a 5083CD plug-in.

The topics discussed in this chapter are as follows:

–

“Selecting the function” on page 32

–

“Configuring the reflectometry test” on page 32

–

“Traffic Detection and connection quality indicator” on page 43

–

“Acquisition in Real Time mode” on page 45

–

“Acquisition in Fault Locator mode” on page 47

–

“Acquisition in Quick Link Test mode” on page 49

–

“Acquisition in Expert mode” on page 51

–

“Results page in Fault Locator mode” on page 53

–

“Result page in Expert and Quick Link test mode” on page 55

–

“Advanced functions in Expert mode” on page 61

–

“Reference Trace function” on page 71

–

“File Management” on page 73

User Manual 780000102/19 31

Chapter 4

Reflectometry measurements

Selecting the function

Selecting the function

Press the

YSTEM

button. If the instrument is equipped with several plugins or if the sole module performs several functions:

– use the direction keys and to select the function: the icon under the mouse pointer is surrounded with a green frame.

– select the function by pressing : the icon turns orangy-yellow.

In the case a Singlemode/Multimode SRL Module is used, two icons can be selected on the System Page: multimode use.

for singlemode use or for

Fig. 14

Example of S

YSTEM

Page with OTDR SRL Module

Configuring the reflectometry test

To call up the test configuration window, press the

ETUP

button.

Dialog boxes on one and the same screen enable selection of measurement parameters, and display of results and fiber parameters.

1.if an OTDR module is installed

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

Fig. 15

OTDR SETUP screen

In these windows, the parameter selected is in video inverse. Select this parameter by means of the direction keys and .

The available choices then appear on the screen; they depend on the function selected. Make the choice by means of the direction keys

Acquisition parameters

You can choose the following acquisition parameters, whatever the type of measurement displayed on the trace.

Those measurement parameters are only linked to the next acquisition.

If the acquisition parameters are not accessible, check that the OTDR function has really been selected (see

"Selecting the function" on page

–

Mode

Choose the mode of detection of events:

- Expert: the acquisition parameters are accessible by the user. This mode can be configured either automatically or manually by the user (select Auto or

Manual in the Acquisition line - see page 34 )

User Manual 780000102/19 33

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

- Quick Link Test:the MTS/T-BERD 8000 starts an acquisition with an automatic configuration making the best compromise for Pulse/Range/Resolution. When acquisition is complete, a measurement is made and the results are displayed.

- Fault Locator the Fault locator mode allows to detect the end of fiber distance from the origin and, by consequence,

to detect a possible break of this fibre (see "Principle of the Fault Locator mode" on page 47 ). It also

allows to display the total loss.

NOTE

The mode selected is always displayed on the upper banner of the screen when the OTDR module is selected in the System page.

–

Laser

The acquisition will be carried out on the wavelength selected (for multiple-wavelength modules): the possible values depend on the modules.



All: the acquisition will be carried out on all available wavelengths.

According to the module you are using, the laser source mode is selectable using the softkey LASER SOURCE at the bottom of the OTDR setup screen, or selecting the icon Source on the System page (for more details about this mode, see

Chapter 5 “Source option of the OTDR

Modules’ on page 75

The Laser Source mode is not available with the UHD and SR(e) modules.

When the Laser Source key is available on the Setup screen, press the key and select the laser wavelength.

–

Acquisition

Select the kind of acquisition to be performed:

This parameter is only available in Expert mode

Manual

Auto

The acquisition parameters Pulse / Range / Resolu-

tion

can be set by user.

The acquisition parameters Pulse / Range / Resolu-

tion

are defined by default and cannot be modified

The Measurement time will be set to Auto, but can be modified.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

Pulse

This depends on the type of OTDR module.



This parameter is exclusively configurable in Expert mode> Manual.

In the case of a multi wavelength acquisition:

– you can define a pulse for each wavelength:

select each wavelength in the Laser line and define a pulse

Once all lasers are configrued, go back to the pulse line and select Multi.

– you can define a pulse for all lasers:

select All on the Laser line

select a pulse, which will be comon to all lasers

See "Typical specifications of OTDR plug-ins" on page 276 .

–

Range

This depends on the type of OTDR module. The possible range depends on the pulse length selected.

This range is given for each pulse length in the paragraph "Ranges" on page 279 . This parameter is exclusively configurable in Expert mode> Manual.

– The Auto parameter allows to detect automatically the range.

In Auto mode, the range is selected as a function of the end of the fiber.

–

Resolution

From 4 cm to 160 m according to module.



No calibration of the measurement. The choice offered depends on the range and pulse selected.



In Auto mode, resolution is selected automatically according to the last two parameters above.

High Resolution: the highest resolution is applied

High Dynamic: the highest dynamic is applied

This parameter is exclusively configurable in Expert mode>

Manual

– Acquisition time

- Real time: the MTS/T-BERD 8000 performs up to ten acquisitions per second and displays the resulting trace in real time together with an indicator of the state of the connection. This mode makes it possible to analyze a fiber quickly without any memory effect, and thus to check the establishment and quality of the connections.

User Manual 780000102/19 35

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

NOTE

Whatever is the acquisition mode selected, an acquisition in real time mode can be launched maintaining the

TART

TOP

button pushed for about 2 seconds.

- Manual:

- Predefined Select one of the acquisition time predefined: 10 seconds / 20 seconds / 30 seconds / 1 minute / 2 minutes / 3 minutes.

- Auto

Enter the acquisition time wished (from 5 s. to 5 minutes max).

This mode is only available in Expert Mode, when

Auto

configuration is selected.

– Short Acquisition

This parameter allows to launch a short acquisition before the standard one. It is available in Expert mode only.

With Short Acq.

: a first short acquisition is performed, with a range of 5 km and a short pulse width, in order to minimize the Dead zone value, before the standard one, which will maximize the dynamic value..

Without Short Acq.

: the standard acquisition is directly launched .

Test Auto

The

Test Auto

key imposes the following parameters:

– Acquisition parameters:

Laser: All

Acquisition: Auto

Acquisition time: Auto

–

Saving parameters (see Chapter 14 “File management’ on page

217 ):

File naming:



Fiber[Cable] [Cable_Id][Fiber_Num] _[Lambda][direction]

Increment Fiber number: Yes

Auto Store: yes

Factory default settings

The

Factory Defaults

key imposes the parameters for acquisition, measurement and display of results defined as default settings in factory.

36 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

Measurements parameters

You can select the following measurement parameters, in the

Measurements

field.

Those parameters are valid for all traces present on the screen.

Detection

Choice of events to be detected:

NOTE

The two following parameters are not available in Fault Locator mode.

–

Otdr Connector test

: this parameter allows to choose if a test of the connector must be performed when acquisition is launched.

: the OTDR connector is not tested



Yes & Continue

: the OTDR connector is tested, and even if the state is not good, the acquisition continues.

Yes & Abort

: the OTDR connector is tested, and if the state is bad, the acquisition stops.

This parameter cannot be applied for the current trace open. If this parameter must be configured to Yes, a new acquisition must be launched.

–

Otdr Connector Measurement

: this parameter allows to choose if a measurement of the start connector must be performed during the acquisition.

: in the results table, the first line corresponds to the first event detected.



Yes

: in the results, the first result correpond to the start connector measurement, at 0 meter (estimated value).

This parameter can be applied for the current trace open. If this parameter is modified for the current trace open, then the results will automatically be modified according to the configuration.

Splice

(Expert mode only):

All

: all splices will be detected



None

: no splice will be detected

 or choose the threshold from which splices will be detected between

User Manual 780000102/19 37

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

0.01 dB and 1.99 dB in steps of 0.01 dB.



Factory default value: Auto.

–

Reflectance

(Expert mode only):

All: all reflections will be detected



None: no reflection will be detected

 or choose the threshold from which reflections will be detected between -98 and -11 in steps of 1 dB.



Factory default value: All.

NOTE

If no result is displayed after a measurement, make sure that the parameter

All

is selected for the detection of splices and reflections.

–

Ghost

(Expert mode only):

Choice (Yes / No / No Analysis) of whether information relating to ghosts is to be displayed. If ghosts are displayed, the reflection icon in the table of results appears dotted and the reflection value is displayed in brackets on the trace, for example «(R:-50 dB)».

Factory default value: No.

NOTE

Ghosts are detected only during an automatic measurement.

–

Fiber end

–

Auto

(recommended) option in which the MTS/T-BERD 8000 automatically detects the end of a fiber.

– 3 to 20 dB (in steps of 1 dB): threshold of detection of end of fiber.

Factory default value:

Auto

– Event After Fiber End

(Expert mode only):

If yes, the events after the end of the link are detected.

Factory default value: No.

–

Total Loss

(Expert mode only)

–

Before evt

: for a given line on table, the total loss result does not include the splice/connector loss of the corresponding line

–

After evt

: on the table, for a given line, the total loss measurement on the table does include the splice/connector loss of the corresponding line.

–

Bend

: Select the bend value (in dB), using the direction keys and or the numeric keypad.

38 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

With any dual or triple-wavelength measurement module, the user will have access to the macro bend detection function in the test setup. Each event of the selected wavelengths will then be compared.

Factory default value: Auto

Index of refraction

Choice of group refraction index of the whole fiber.

– User

– Either: define for each wavelength (1310 SM, 1360-1510 SM,

1550 SM, 1625 SM) a refraction index of 1.30000 to 1.69999.

The selection of an index alters the value of the section AB

(actual distance between cursors A and B).

NOTE

With the CWDM Module, the selection is as follows:

– For lasers 1271, 1291, 1311, 1331 and 1351, select the line 1310

SM.

– For lasers 1371 to 1511, select the line 1360 - 1510 SM

– For lasers 1531, 1551 and 1571, select the line 1550 SM

– For lasers 1591 and 1611, select the line 1625 SM.

– or, if the actual distance between the cursors A and B is known, enter its value under Section AB to establish the index of the fiber. Selection of this distance causes the display of the indices.

The extreme distance values are given by the index values

(1.30000 à 1.70000).

– Predefined index

– It is possible to choose one of the predefined values given for certain cables. The corresponding indices given in the table below are repeated on the screen.

Wavelength (nm) 1310 SM

ATT SM

Corning SMF-28

Corning SMF-DS

Corning SMF-LS

Corning-LEAF

1.46600

1.46750

1.47180

1.47100

1.46890

1475 1480 1510 1550 1625 SM

1.46700

1.46810

1.47110

1.47000

1.46840

User Manual 780000102/19 39

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

Wavelength (nm) 1310 SM

Fitel Furukawa

Lucent Truewave

SpecTran SM

Litespec

1.47000

1.47380

1.46750

1.46600

Fig. 16

1475 1480 1510 1550 1625 SM

1.47000

1.47320

1.46810

1.46700

Predefined index values (Single Mode)

Wavelength (nm)

Corning 62.5

Corning 50

SpecTran 62.5

Generic 50

Generic 62.5

Fig. 17

850 MM

1.50140

1.48970

1.49600

1.49000

Predefined index values (Multi Mode)

1300 MM

1.49660

1.48560

1.49100

1.48600

1.48700

Scatter coefficient

(not available in Fault Locator mode)

– User Selects for each wavelength, the backscatter coefficient of

-99 dB to -50 dB by increments of 0.1dB. Modification of the backscatter coefficient K changes the measurements of reflectance and ORL.

With the CWDM Module, the selection is as follows:

- For lasers 1271, 1291, 1311, 1331 and 1351, select the line 1310 SM

- For lasers 1371 to 1511, select the line 1360 - 1510 SM

- For lasers 1531, 1551 and 1571, select the line 1550 SM

- For lasers 1591 and 1611, select the line 1625 SM.

– Auto Backscatter coefficients are selected automatically for each wavelength.

The default values are given in the paragraph

"Reflectance" on page 3

Launch cable End / Receive Cable Start

NOTE

The parameter "Receive Cable Start" is not available in Fault Locator mode.

– No All the results are displayed and referenced on the basis of the board of the plug-in.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

OTDR

– Evt 1, 2, 3 The results relating to the launch cable are eliminated from the table. Attenuation and distances are then measured on the basis of the marker Evt 1, 2 or 3 selected.

The parameter Launch Cable Start in Fault Locator mode, cannot be configured according to an event number.

– Distance Use the

Edit Number

key to enter the distance from the begining of the Launch cable until its end, and / or from the end of the Receive Cable until its start (= the

total length of the cable). See Figure 18 on page 41

Or affect the active cursor value, using the

Set Cursor

Distance.

Launch Cable Receive Cable

Fiber Under Test

Distance of the launch cable

Launch

Cable end

Receive

Cable start

Distance of the receive cable

Fig. 18

Launch Cable / Receive Cable

Defining the Launch Cable End parameter with an event number or a distance will automatically activate the corresponding parameter Include

Link End connector

. This parameters can be set to Yes if the budget must include the connector loss of the launch cable at end

Defining the Receive Cable Start parameter with an event number or a distance, will automatically activate the corresponding parameter

Include Link Start connector

. This parameters can be set to Yes if the budget must include the connector loss of the receive cable at start

If those parameters are set to No, the budget only displays the connector loss of the fiber under test.

Factory default value: No.

User Manual 780000102/19 41

Chapter 4

Reflectometry measurements

Configuring the reflectometry test

Result screen

Those parameters are valid for all the traces present on the screen.

–

Alarms > Threshold

None: The alarm function is not active.

Fail: This menu lists possible major alarm thresholds that the user could select. If results are above those thresholds, they will be highlighted in red in the table of results, and the icon

will appear at the top right of the screen.

Thresholds are can be configured for: Splice / Connector /

Reflectance / Slope / Fiber Length Min and Max / Total Loss

Min and Max / ORL.

Warning: This menu lists possible minor alarm thresholds that the user could select. If results are between those thresholds and the "fail" thresholds, they will be highlighted in yellow in the table of results, and the icon will appear at the top right of the screen.

Thresholds can be set for: Splice / Connector / Reflectance.

If all the results lie within the thresholds (no result is in red or yellow), results are displayed in green in the table and the icon will be .Notes

See "Table notes" on page 64

No: no display of notes

Notes: display of notes entered by the user

Uncertainty: display of indicators of the level of confidence in the measurement result.

Factory default value: No

–

Results on trace

No: the trace alone.

All: the trace with results and markers.

Graphics only: the trace with markers only.

Factory default value: All.

If «All» or «Graphics only» is selected, the reflectometry trace is displayed with a dotted vertical line set on the end of launch cable

(if the Launch Cable is defined in the

ETUP

menu) and a dotted vertical line on the end of fiber .

–

Grid

if Yes, the grid is present on the result screen



Factory default value: No.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Traffic Detection and connection quality indicator

–

Unit

Units of the distances displayed: km, kfeet, miles, metre, feet.

–

Colors (RGB)

When overlaying several traces (see

"Overlay trace function" on page 26

), you can change each trace color.

- Active curve: allows to change the active curve color

- Curve 1 to 8: allows to change the selected curve color (from trace 1 to 8)

NOTE

To get the default color for all traces, click on

Colors Default

When you change the trace color, the new color is displayed at the right side of its value.

Traffic Detection and connection quality indicator

Traffic

Detection

Traffic on the fiber under test can be detected and reported if the function

TD (Traffic Detection) has been selected on the System page .

If the fiber connected to the OTDR module is active, a message indicating a signal in the fiber under test is displayed.

Push any key to continue.

Press the

TART

TOP

key to begin the measurement. A message indicates there is traffic on the fiber and asks you if you wish to continue or not:

– If you click on

, the measurement is not launched.

– If you click on

, the measurement is performed, despite the traffic.

NOTE

If the measurement is validated despite the traffic (key

), the next measurement will be automatically performed, even if traffic is still detected on fiber.

If the measurement is cancelled (key

), and the

TART

TOP

pushed another time, the box asking if you wish to continue or not is displayed.

User Manual 780000102/19 43

Chapter 4

Reflectometry measurements

Traffic Detection and connection quality indicator

If the Traffic Detection function is not selected on the System page, then the message Signal Detected on fiber under test is displayed, but the acquisition is although performed once any key is pressed (no warning message asking you if the measurement must be performed or not is displayed).

Connection

Quality indicator

An indicator of the state of the connection (Good / Bad) is given at the beginning of an acquisition, whatever is the acquisition mode selected.

The connection quality indicator gives the following information:

State Connection

Good The connection is OK

Bad Possible causes of a bad result:

- There are several connectors close to the external connector of the MTS/T-BERD 8000.

- One of the connectors is dirty or badly connected. Replace the launch cable, make the connection again properly or clean the connector of the OTDR or of the jumper.

- No fiber is connected.

If the state of the connection is bad, it is still possible to carry out a measurement, but the results will not be very reliable.

NOTE

If the connection is bad, check and clean the connector / jumpers (see

“Cleaning the universal connector” on page 16

Battery saver

When running on battery, if no acquisition has been performed for two minutes, the power supply of the module is cut off to save the battery.

Client specific option: Fiber identification box (TR management for

Verizon - MTS/T-BERD 6000 only)

The TR box allows to automatically identify the number of the end of fiber.

If this number is not the same as the fiber detected, the user will be advised of this incoherence

44 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Acquisition in Real Time mode

Acquisition in Real Time mode

Principle of

Real Time mode

Acquisition in real time must not be used if a precise measurement is required because of the high noise level, but it is sufficient for rapid optimization of a connection and for observing a fiber in process of utilization.

Performing an acquisition in

Real Time mode

To carry out an acquisition in real time, after selection of the requisite acquisition parameters (see

"Acquisition parameters" on page 33 ):

– Hold the

TART

key down for about two seconds, to launch the acquisition in real time, whatever is the Acquisition mode selected in the Setup menu.

– or choose the Real time mode of acquisition in the

ETUP

menu, then press the

TART

TOP

key.

The red Testing indicator will go on to show that real time acquisition is in progress. The trace acquired is displayed in real time. An indicator of the state of the connection (

Good/Bad

) is displayed below the trace.

NOTE

If the connection is bad, check and clean the connector / jumpers.

Real time display

Once

TART

TOP

key is pressed, the acquisition in real time is launched.

User Manual 780000102/19 45

Chapter 4

Reflectometry measurements

Acquisition in Real Time mode

Fig. 19

Example of acquisition in real time

During an acquisition in real time, you can modify the acquisition parameters without returning to the

ETUP

menu. To do this, press the

Acquisition Param

key: you can then use display keys to scroll through the possible values of the various acquisition parameters.

In real time mode, only measurements relating to the cursors are possible, but as soon as acquisition stops, automatic measurement is possible.

During a real time acquisition, you can reach the end of the fiber under test at any time, using the Zoom to End key.

The real time mode allows to make Loss, ORL or Reflectance measurement using the A & B cursors and the key None / Loss / ORL / Reflect.:

Position A & B cursors on the trace

Click as many times as necessary to get the Loss / ORL / Reflectance measurement between A & B cursors

The result is displayed under the trace.

46 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Acquisition in Fault Locator mode

Fig. 20

Example of loss measurement between A & B cursors

To terminate or interrupt an acquisition in real time mode, press the

TART

TOP

key.

Multiwavelength acquisition

If the plug-in possesses several lasers, to perform successive acquisitions on all the wavelengths:

– In the

ETUP

select

All

menu, on the Laser line, choose several lasers or

– Start the acquisition by pressing the

TART

TOP

button.

– Once the acquisition for the first wavelength is finished or to stop it manually, click on Stop Wavelength to stop the measurement for this wavelength and automatically start the measurement for the following one..

The different traces appear in the same window and can be managed as

traces in overlay (see .

“Overlay trace function” on page 26 ).

Acquisition in Fault Locator mode

Principle of the

Fault Locator mode

The Fault locator mode is used to detect the distance of the end of fiber from its origin. Consequently, il allows to detect a possible break of the fiber. It also allows to calculate the Total Loss.

User Manual 780000102/19 47

Chapter 4

Reflectometry measurements

Acquisition in Fault Locator mode

Performing an acquisition in

Fault Locator mode

Push the

ETUP

button

In the Acquisition parameters:

–

Select Fault Locator in the line Mode (see "Configuring the reflectometry test" on page 32 )

Configure the other acquistion parameters (see .

“Acquisition parameters” on page 33

) or click on Test auto to configure automatically the acquisition once the mode is selected or click on Factory Default to set the parameters defined in factory for this mode.

Push the

TART

TOP

button.

The test configuration starts automatically.

A baragraph indicates the quality of the connection (see "Connection Quality indicator" on page 44 )

Then, the elapsed averaging time and the number of averages calculated are displayed.

The acquisition can be stopped at any time pushing

TART

TOP

button.

Display of the acquisition mode selected

Fig. 21

Acquisition in Fault Locator mode

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Acquisition in Quick Link Test mode

Multi-wavelength acquisition

If the module possesses several lasers, to perform successive acquisitions on all the wavelengths:

– in the

ETUP

menu, check in Laser line, that selected or select All

several lasers are

– Start the acquisition by pressing the

TART

TOP

button.

The different traces appear in the same window and can be managed as traces in overlay (see

“Overlay trace function” on page 26

Acquisition in Quick Link Test mode

Principle of the

Quick Link Test mode

The fastest way of detecting faults in your optical fiber is to use automatic acquisition mode. The MTS/T-BERD 8000 then uses the acquisition parameters (pulse width, range and resolution, and acquisition time) best suited to the fiber to be tested.

NOTE

In Quick Link Test mode, since all the parameters have been reconfigured, overlay and marker locking are not possible during acquisition.

Performing an acquisition in

Quick Link Test mode

Press the

ETUP

button, then:

On the

Mode

line, select

Quick Link Test

On the

Laser

line, select the wavelength of the laser (if the MTS/T-

BERD 8000 uses a dual-wavelength plug-in) or select All.

Select the Measurement and Results Screen parameters wished.

You can automatically configure the Quick Link Test mode by pressing Test Auto key once the mode is selected, or configure it according to the parameters set in Factory by clicking on the

Factory Default

key.

Acquisition phases in Quick Link Test mode

When the

TART

TOP

key is pressed, an automatic configuration procedure selects the optimum parameters, after which acquisition is carried out in four phases:

User Manual 780000102/19 49

Chapter 4

Reflectometry measurements

Acquisition in Quick Link Test mode

– Phase 1: Choice of the best range to display the whole of the fiber under test.

– Phase 2: Choice of the ideal pulse width and of the acquisition time to qualify the fiber accurately; for example the one that gives the best resolution for a given dynamic.

–

Phase 3: Display of the quality of the connection (see "Connection

Quality indicator" on page 44 )

– Phase 4: The elapsed averaging time and the number of averages calculated are displayed. When the duration of acquisition has elapsed, the automatic measurement is carried out.

NOTE

The acquisition can be stopped at any moment by pressing the

TART

TOP

key. Then an automatic measurement is performed.

Elapsed acquisition time

Number of averages calculated

Elapsed time

Remaining acquisition time

Total acquisition time

Fig. 22

Example of automatic acquisition

At the end of Auto acquisition, the parameters are automatically updated in the Acquisition menu. Moreover, a beep is emitted in case of alarm.

Auto acquisition mode deactivates the

Set Event

function (see

"Memorization of the position of events" on page 70 ): the measurement is

then re-initialized.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Acquisition in Expert mode

Multi-wavelength acquisition

If the module possesses several lasers, to perform successive acquisitions on all the wavelengths:

– in the

ETUP

menu, check in Laser line, that selected or select All

several lasers are

– Start the acquisition by pressing the

TART

TOP

button.

The different traces appear in the same window and can be managed as traces in overlay (see

“Overlay trace function” on page 26

Acquisition in Expert mode

In this mode, the MTS/T-BERD 8000 carries out a number of averagings defined as a function of the maximum acquisition time specified in the

Acquisition menu, and then terminates the acquisition. The acquisition is carried out with the parameters previously selected in the Acquisition menu. It may be stopped at any time using the

TART

TOP

key.

Configuring the acquisition

To configure a manual acquisition of the fiber under test, follow the procedure described below, in the

ETUP

menu (see "Acquisition parameters" on page 33 ):

On the

Mode

line, select

Expert

Select the wavelength on the

Laser

line.

Select Manual or Auto on the line Acquisition.

If Manual has been previously selected, on the

Pulse

line, select the required pulse length from the values proposed.

If Manual has been previously selected, select the required

Range

from the values proposed.

If Manual has been previously selected, select the

Resolution

On the

Acquisition Time

line, select the duration of acquisition.

If you wish, select Short Acquisition if a first acquisition, on a range of 5 km and a small pulse width must be performed before the standard acquisition (see

“Short Acquisition” on page 36

User Manual 780000102/19 51

Chapter 4

Reflectometry measurements

Acquisition in Expert mode

Performing an acquisition in

Expert mode

Press the

TART

TOP

key to start the acquisition.

The red indicator goes on to show that the MTS/T-BERD 8000 is in process of acquisition and the screen displays the trace in process of acquisition.

The quality of the connection is displayed for a few seconds (see

"Connection Quality indicator" on page 44

) then a bar graph shows elapsed and remaining acquisition time.

Elapsed acquisition time

Number of averages calculated

Elapsed time

Remaining acquisition time

Total acquisition time

Fig. 23

Example of acquisition in Expert mode

If the parameter Short Acquisition has been defined to Yes in the Setup screen (see

“Short Acquisition” on page 36

), two acquisition will be performed (if one laser is selected).

At the end of the acquisition, the trace is displayed and an automatic measurement is started. If one short acquisition has been configureed, then 2 traces will be displayed at the end of acquisition.

NOTE

To stop the acquisition, the

TART

TOP

key may be pressed at any time. Then an automatic measurement is carried out, but some events cannot be detected (a manual measurement must then be made).

Multi-wavelength acquisition

If the module possesses several lasers, to perform successive acquisitions on all the wavelengths:

– in the

ETUP

menu, check in Laser line, that several lasers are selected or select All

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Results page in Fault Locator mode

– Start the acquisition by pressing the

TART

TOP

button.

The different traces appear in the same window and can be managed as

traces in overlay (see .

“Overlay trace function” on page 26 ).

Results page in Fault Locator mode

The trace acquired or recalled from a memory is displayed on the Results page.

Once the test is completed, the instrument measures the end of fiber distance and display it with the unit chosen. The Total Loss is also displayed.

Fig. 24

Fault Location

A number of different functions can modify the display of the trace

– Cursor A / Cursor B (see

“Cursors” on page 24

)

– Zoom/Shift (see

“Zoom and Shift functions” on page 25 )

–

Table/Summary (see "Table / Summary function" on page 54

)

User Manual 780000102/19 53

Chapter 4

Reflectometry measurements

Results page in Fault Locator mode

NOTE

If a problem occurs during acquisition, two types of message can be displayed on screen:

- Fiber End not found: fiber length is too long for the OTDR used etc.

- No fiber connected

Under the trace, in the blue line, are displayed:

– the ORL value of the link

– the Launch Cable length (if defined)

The

Cursor

and

Zoom

keys are available.

Table /

Summary function

To display a summary of the results for 2 traces or more in overlay, select

Summary

with the Table/Summary key.

Mode of acquisition selected

Fig. 25

Fault Locator: Summary page

An additional window is displayed, with issue highlighted in case of problem, including bend.

In Summary mode, there is neither access to other functions because the Summary function analyzes two traces at the same time. Go back to the Table function to have access to these functions.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

Result page in Expert and Quick Link test mode

Trace display functions

The trace acquired or recalled from a memory is displayed on the Results

page: see example Figure 27 on page 56

A number of different functions can modify the display of the trace

(Cursors, Zoom/Shift, Trace/Event, Trace/Table/Summary, Full Scale,

etc.). See page 23

See "Overlaying several traces stored in memory" on page 27

for overlay of traces.

Traces display in double acquisition mode

When a double acquisition has been performed, i.e. a short acquisition

preceeding a standard one (see “Short Acquisition” on page 36 ), two

traces are displayed in the same window.

End of the short acquisition (in blue) whereas the standard one continues

(in green)

Fig. 26

Traces display in double acquisition mode

The short trace is the one resulting from the short acquisition and stops while the standard one continues until the end of measurement.

Display of events on trace

Each event detected is referenced under the trace by a serial number.

NOTE

In Expert mode

, to display the results on the trace, make sure that the option selected in

Results on Trace

All

in the menu

ETUP

User Manual 780000102/19 55

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

NOTE

At the end of an acquisition, a beep is emitted in case of alarm.

The reflectometry trace is displayed with a dotted vertical line set on the end of launch cable (if the Launch Cable is defined in the

ETUP

menu) and a dotted vertical line on the end of fiber ..

In expert mode only, the results of the measurements of attenuation, reflectance and slope can be marked on the trace.

Depending on the choice made in the

ETUP

menu, on

Result Screen

> Results on Trace

, it is possible to show on the trace:

– "No" results,

– "All" results (value and position)

– or only the markers showing the position of the events measured

When there is saturation for a reflective event, the maximum value measured is displayed with the sign >.

This shows that the actual reflectance is greater than the value shown

(for example, if R >-29,5 dB is displayed, the reflectance could be -

18 dB)

The reflectance of a ghost event is displayed in brackets on the trace.

Fig. 27

Example of trace (in Expert mode)

User Manual 780000102/19

In Quick Link

Test mode, this

2 keys are not available

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

Trace/Event functions

The

Trace

function is useful in a multi-trace display, as the direction keys can then be used to select the active trace, which turns green

(see

"Overlay trace function" on page 26

The

Event

function of the MTS/T-BERD 8000 enables the cursor to be moved on to the faults that have been measured and the results of which are displayed on the screen.

After selecting the

Event

function on the

Trace/Event

key, pressing the keys , , or once will move the cursor from one event to the next. This function, in association with

Zoom

and

Cursor

, enables rapid analysis of the fiber.

NOTE

While moving from one event to another, the value of the zoom is conserved (unless this is impossible).

Criteria for display of an event

An event will be displayed if its attenuation or its reflectance exceeds the corresponding threshold selected in the

ETUP

menu (see "Acquisition parameters" on page 33

). Both results for an event will be displayed if they can be calculated. The following table gives some examples of detection of events for different threshold values.

E.g.

Value of the thresholds

Attenuat.(dB)

Reflect. (dB)

- 15

---

The MTS/T-BERD 8000 displays a value if the attenuation or the reflectance has one of the following values

Attenuation

> 1 dB

> 6 dB

Example: a value will be displayed at -43 dB.

Example: a value will be displayed at -14 dB but not at -20 dB.

Reflectance

> - 60 dB

>- 15 dB

The reflectance of an event is always measured except when the event causes a saturated Fresnel peak or if it is drowned out by noise. In this case, the MTS/T-BERD 8000 displays

to show that the actual reflectance exceeds the value displayed.

For example, to detect all the splices on a fiber having attenuation greater than 0.05 dB, select the different thresholds of the events to be detected in the menu called by the

ETUP

key, in the

Measurements >

Detection

window.

User Manual 780000102/19 57

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

Relative measurement

Relative measurements, using the 2 point method, can be carried out by means of the Event function in coordination with the two cursors. For example, you can analyze the total loss on a link with launch cable:

Place one of the cursors at the end of the launch cable.

Select the other cursor.

Use the Set Event function. The measurements displayed give the actual distance from the start of the link and the attenuation of the link plus the attenuation of the connection.

Table of results

NOTE

In Expert mode

, to display all the events, make sure that the detection threshold selection in the

ETUP

menu is

All

Two types of tables of results are possible with the MTS/T-BERD 8000:

– A table with a line displayed under the trace and giving the type and characteristics of the event nearest to the cursor.

– A table giving the type and the characteristics of all the events detected during the automatic measurements: the 8 lines displayed correspond to the 8 events nearest to the cursor. The line corresponding to the event nearest to the cursor is highlighted. This highlighting moves if the cursor is moved.

At the top of the table, a line shows the generic parameters of the fiber: numbers of events present, total ORL of the link, marker locking icon and launch cable length (if selected).

Change of table

To obtain the 8-line table, select the Table function on the

Trace/Table/

Summary

key. To return to display of a single line in the table, select the

Trace

function.

To scroll through the table, if it contains more than 8 lines:

– either select the

Cursors

function, and move the selected cursor along the trace using the keys and

– or select the

Event

function, and move the cursor through the table, using the keys and .

58 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

Fig. 28

Example of table of results

Information provided for each event detected

Each event is referenced under the trace by a serial number which is repeated in the first column of the table. The table then shows:

– an icon symbolizing the type of the event:



Measurement of the Otdr connector (see page 37 )

Non-reflecting attenuation (e.g. splice).



Event with reflection (e.g. connector).



Ghost reflection.



Slope of the fiber (when no fault follows the slope).



End of fiber



ORL measurement



Event marker when a measurement cannot be carried out. If the event to be added is too close to an existing event, the icon appears on the trace and the table, but no measurement is carried out: to obtain the results for this event, a manual measurement is necessary.

User Manual 780000102/19 59

Chapter 4

Reflectometry measurements

Result page in Expert and Quick Link test mode

End of launch cable: the attenuation and distances are measured on the basis of the corresponding marker.

– The distance of the event from the beginning of the fiber, in metres

(or kfeet or miles).

– The attenuation due to the event, in dB.

– The reflectance of the event, in dB (or the ORL result if an ORL measurement has been carried out).

– The slope before the event, in dB/km (dB/kft) if it can be measured.

– The length of the section, that is to say the distance between the marker of the event and the previous marker.

– The total attenuation of the fiber (total dB loss), in dB.

The table of results is interactive, and reflects the measurements in progress. Any operation carried out on the trace is immediately entered in the table, so that you can see the result.

Summary page

To display a summary of the results, for 2 traces or more in overlay, select the Summary function. An additional window is displayed, with issue highlighted in case of problem, including bend with singlemode, and including propagation delay in multimode.

Fig. 29

Summary Results and Bend Table

In Summary mode, there is neither access to the events function nor to the expert mode because the Summary function analyzes two traces at the same time. Go back to the Table or Trace function to have access to these functions.

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

Advanced functions in Expert mode

Automatic measurement and detection

Automatic mode enables rapid detection of all the faults in the trace. The faults detected are then measured and identified on the screen by markers. Only the results exceeding the detection threshold defined in the

ETUP

menu are displayed.

NOTE

Before starting an automatic measurement, make sure that the function

Lock Evts

(accessible by pressing

Advanced

), is not activated

(the icon trace).

must not be present in the left-hand corner under the

By means of this method of detection, you can quickly locate all the faults in the fiber under test.

If an automatic measurement does not detect all the events, additional manual measurements can be carried out.

To delete all the markers, press the

Advanced

key, then select

Del Res

When there have not been any measurements, to carry out an automatic measurement, press

Advanced

then select the function

Auto Mes.

The following procedure is recommended:

Fully automatic measurement: the instrument locates the events and proceeds to the measurements.

Addition of markers (see

“Addition of markers” on page 62

) in the cases of splices showing low attenuation and of close events. The

MTS/T-BERD 8000 then automatically measures the slope before and after the markers selected and measures the attenuation of the splice.

Addition of manual measurements if necessary (in the case of very close events). The MTS/T-BERD 8000 performs the measurements requested by the user.

To start an automatic measurement while a measurement is already in progress:

Press the

Advanced

key.

Select

Del Res.

Select

Auto Mes.

User Manual 780000102/19 61

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

Addition of markers

Addition of markers is a function only available in Expert Mode.

To carry out a measurement, it is advisable to go into the

ETUP

menu and:

– activate the alarm thresholds in

Result Screens > Alarms

– validate display of results on the trace in

Results on Trace = All

You can place markers of events on the trace at the exact position where you want to carry out automatic measurements.

You can also manually place markers in addition to those positioned automatically during automatic measurement. You can then start an automatic measurement to obtain the results on all the markers.

Representation of the markers

The markers are represented by the symbol : if they are set during automatic measurements (Advanced > Auto Meas.).

The markers are represented by the symbol if they are set during manual measurements using the

Set Event

key.

To add markers of events:

Select a cursor (A or B).

Use the direction keys to move the cursor to the place where you want to position a marker.

Press the key:

Set Event

An event marker is displayed at the position of the cursor and a measurement is carried out on the marker. Measurement of slope before the marker starts just after the previous event (or at the end of the dead zone at the beginning of the fiber); measurement of slope after the marker stops just before the next marker or at the end of the fiber.

Hints on the positioning of markers

– Do not add markers (with the

Set Event

key) after a manual measurement, as all the results will be recalculated automatically by the instrument.

62 User Manual 780000102/19

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

– If two markers are too close together, they will appear on the trace and the table but no measurement will be carried out on the second marker: to obtain results for this marker, a manual measurement is necessary.

– If you press the

Set Event

key when the cursor is very close to a marker, the latter will be deleted.

Deleting markers

To delete a marker, move the cursor on to the marker and press the

Set

Event

key. The marker selected will be deleted and a complete measurement, without this marker, will be carried out.

To delete several markers, use the

Event

key to move from one marker to the other, then press the

Set Event

key as many times as necessary.

The cursor will be automatically moved on to the successive markers.

Deletion of markers can cause incorrect measurement results.

Modifying types of events

The types of events are detected automatically as a function of their optical signature. This can sometimes lead the system astray, if reflection from a connector is too strong (end of fiber?), if a splice has a very low insertion loss (slope?), etc. Similarly, some types of events cannot be recognized automatically from their signatures (for example, couplers, multiplexers, etc.). For this reason, it is advantageous in some cases to be able to change the type of events.

To do this:

– In the

Advanced

menu select

Manual measurement

– Select the

Event Code

button.

Fig. 30

Buttons used to modify types of events

User Manual 780000102/19 63

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

New, more specific event types are then proposed:

Splice

Connector

Mux/Demultiplexer

Separator/Coupler

End of fiber

Ghost

– Position the cursor on the line for which modification of event type is desired.

– Click on the button corresponding to the required type of event.

Table notes

With each event, it is possible to associate:

– a note of no more than 40 characters, entered by the user

– an indicator of uncertainty qualifying the result displayed.

NOTE

This information appears in the table, under the line relating to the event, if it has been validated in the

ETUP

menu on the

Notes

line.

Notes

For each wavelength, a maximum of 16 notes is possible.



For each note, 40 characters can be entered.

NOTE

Each note is associated with an event. Consequently, if the event is deleted, the note will be deleted too.

To enter a note:

– in the menu:

ETUP

> Result Screens > Notes

, the Notes option must be selected

– on the

Results

page, in the table, select the event

– press

Advanced

– press

Notes

– enter the text of the note in the edit menu that appears

– press

Confirm

and then

Exit

User Manual 780000102/19

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

In the table of results, the user can display indicators to evaluate the uncertainty of the result. This function must be validated in the

ETUP

menu, on the

Notes

line.

The notes are displayed under the selected event, in the results table.

Uncertainty of results

The following cases are possible:

Indicators concerning attenuation measurements

2c manual

5c manual

Result of a manual measurement between the reference and the cursor using the

2-cursors method.

Result of a manual measurement using the 5-cursors method.

Global

Close evts

The attenuation displayed is a global result for Fresnel reflections which are not sufficiently separated.

As several events are too close together, only the attenuation of the last one is displayed.

Indicators concerning measurements of slope

Few pts

2 points

Measurement of slope by the least square approximation method without using many points of acquisition.

Measurement of slope by the 2-point method.

NOTE

The

ETUP

menu,

Notes

line, enables display of notes, of uncertainties or of neither the one nor the other. Notes cannot be displayed at the same time as uncertainties.

Modifying Link

Length

In Expert mode, once trace is displayed, you can modify the length of fiber.

Click on Advanced > Set Link Length.

A numeric keypad displays, with the current link length.

User Manual 780000102/19 65

Chapter 4

Reflectometry measurements

Advanced functions in Expert mode

Fig. 31

Expert mode: Link Length Modification

Enter the new length of the fiber.

Validate pushing the Entrer key.

The modification of the link length will automatically modify the

Index of Refraction of the fiber according to this new length value

(and by consequence, will modify the values of the events detected, in the results table).

Answer Yes or No to the message displayed, to keep or not this value for the link length for the future acquisitions

Manual measurements

As soon as you have made an acquisition, with or without automatic measurement, you can make manual measurements on any event on the trace by means of the cursors A and B, in association with the functions of slope, detection of splice and calculation of ORL.

The manual measurements are accessible in the Results page, after pressing the keys:

Advanced

, then

Manual Measurement

Measurements of slope

To make a manual measurement of slope, press the

ESULTS
