EZText Enhanced User Manual

Models: EZ-220, EZ-220V, EZ-220L,

EZ-420, EZ-220P, & EZ-220PV

Manual Part Number EZ-TEXT-M-E

This page intentionally left blank.

The Most Sensible Automation Products

Direct From the Factory

EZText Enhanced User Manual

Models: EZ-220, EZ-220V, EZ-220L,

EZ-420, EZ-220P, & EZ-220PV

Manual Part Number EZ-TEXT-M-E

WARNING!

Programmable control devices such as EZText Enhanced Panels are not fail-safe devices and as such must not be used for stand-alone protection in any application. Unless proper safeguards are used, unwanted start-ups could result in equipment damage or personal injury. The operator must be made aware of this hazard and appropriate precautions must be taken.

In addition, consideration must be given to the use of an emergency stop function that is independent of the programmable controller.

The diagrams and examples in this user manual are included for illustrative purposes only. The manufacturer cannot assume responsibility or liability for actual use based on the diagrams and examples.

CAUTION

Do not press the EZText Enhanced Panel pushbuttons with any sharp objects. This practice may damage the unit beyond repair.

Trademarks

This publication may contain references to products produced and/or offered by other companies.

The product and company names may be trademarked and are the sole property of their respective owners. EZAutomation disclaims any proprietary interest in the marks and names of others.

Manual P/N EZ-TEXT-M-E

© Copyright 2005, EZ Automation

All Rights Reserved

No part of this manual shall be copied, reproduced, or transmitted in any way without the prior written consent of EZAutomation. EZAutomation retains the exclusive rights to all information included in this document.

MANUFACTURED by AVG AUTOMATION

4140 Utica Ridge Rd. • Bettendorf, IA 52722-1327

MARKETED by EZAutomation

4140 Utica Ridge Rd. • Bettendorf, IA 52722-1327

Phone:

1-877-774-EASY

• Fax:

1-877-775-EASY

www.EZAutomation.net

EZ-TEXT-M-E

User’s Manual

TABLE OF CONTENTS

WARNING/Caution ................................................................... inside cover

Table of Contents ..........................................................................................i

EU Information .......................................................................................... iv

1 INTRODUCTION

Introduction to the EZText Panel .............................................................4

What you need to get started ..................................................................5

Need Help? ...........................................................................................5

Models ...........................................................................................6

PLCs Supported by EZText Panels .........................................................8

PLC and Programming Cable Part Numbers ..........................................9

Accessories and Optional Equipment .....................................................9

Data Entry (Keypad) Pushbuttons ............................................ 11

PLC Message LED ................................................................... 11

Control Pushbuttons .................................................................12

Function Pushbuttons ...............................................................12

Pushbutton LEDs .....................................................................12

Character LCD Display with LED Backlight ..............................12

EMI Noise Filter Installation ..................................................................18

Mounting .........................................................................................19

Models EZ-220, EZ-220V, & EZ-420 Outline

Dimensions and Mounting Template .......................................19

Models EZ-220P & EZ-220PV Outline Dimensions

DIN Clip Mounting ...........................................................................22

v

User’s Manual

EZ-220, EZ-220V & EZ-420 Rear View ..........................................24

EZ-220P & EZ-220PV Rear View ...................................................25

Connect a PLC ...............................................................................28

3 LEARNING THE FEATURES

Learning the Features ...........................................................................30

LEDs .........................................................................................31

PLC Messages and Local Messages ....................................................35

Displaying PLC Messages ..............................................................36

Local Message File Structure Example ..........................................40

Local Message Menu Structure Example .......................................41

4 TUTORIAL

EZText Enhanced Panel Setup .............................................................44

Installing EZText Enhanced Programming Software .............................45

Tutorial — Plan the Project using Application Worksheets ...................47

Tutorial — Create the Project using EZText Enhanced Programming

Tutorial — Confi gure a PLC ..................................................................60

5 CONFIGURATION

Connect to Panel, View Panel Status and Firmware Version ...............80

vi

User’s Manual

6 MAINTENANCE and TROUBLESHOOTING

Maintenance .........................................................................................86

Troubleshooting ....................................................................................89

Out of Warranty Repairs .......................................................................92

Appendix A ....................................................................................... A-1

EZText Enhanced Panel Application Worksheet ........................... A-2

Appendix B ....................................................................................... B-1

Siemens.................................................................................. B-8

Appendix C .......................................................................................C-1

PLC Driver Error Messages ..........................................................C-2

EZText Enhanced Panel Error Messages ...................................C-14

EZText Enhanced Programming Software Error Messages .......C-15

INDEX ........................................................................................ I-1 vii

EU INFORMATION

User’s Manual

EU Information

The EZText Enhanced Panel is manufactured in compliance with European Union (EU) Directives and carries the CE mark. The EZText Enhanced Panel has been tested under CE Test Standard

#EN55011, and is listed under UL File #E209355. The following information is provided to comply with EU documentation requirements.

Please NOTE: Products with CE marks perform their required functions safely and adhere to relevant standards as specifi ed by EU Directives provided they are used according to their intended purpose and that the instructions in this manual are adhered to. The protection provided by the equipment may be impaired if this equipment is not used in accordance with this manual. Only replacement parts supplied by EZAutomation or its agents should be used.

Technical

Support

If you need assistance, please call our technical support at 1-877-774-EASY or

FAX us at 1-877-775-EASY.

SELV Circuits

All electrical circuits connected to the communications port receptacle are rated as Safety Extra Low Voltage (SELV).

Environmental

Specifi cations

Operating Temperature ...................................................................0 to 45 °C

Storage Temperature ............................................................... –20 to +60 °C

Operating Humidity .........................................10–95% R.H., noncondensing

Air Composition ..............................................No corrosive gases permitted

Preventative

Maintenance and Cleaning

No preventative maintenance is required. The EZText Enhanced Panel overlay should be cleaned as needed with warm, soapy water. See Chapter 6, Maintenance and Troubleshooting, for a list of compatible/incompatible chemicals and compounds.

viii

Introduction

In this chapter....

— Introduction to the EZText Enhanced Panel

— What you need to get started

1

— PLCs Supported by EZText Enhanced

— Accessories and Optional Equipment

— PLC and Programming Cable Part Numbers

INTRODUCTION

User’s Manual

Manual Organization

Chapter

This manual is all you’ll need to get the EZText Enhanced Panel installed and confi gured. This manual covers models EZ-220, EZ-420, EZ-220L, EZ-220P, and two new models with Vacuum Fluorescent Display EZ-220V, EZ-220PV.

In this manual we will take you through the steps necessary to get your EZText

Enhanced Panel up and running in the shortest possible time. Although your familiarity with programmable operator interface devices will determine how quickly you move through the steps — it’s as easy as 1 — 2 — 3. This manual is arranged in chapters. A description of key information contained in each chapter is provided below.

Description

1

2

3

4

Introduction

Provides Manual Organization, and lists what you need to get started, hardware and software. Discusses how to get help with questions or problems you might encounter through Onscreen Help and Technical Support. Provides you with a table listing the various models, their part numbers and special features. Lists the important features of all EZText Enhanced Panels. Lists the PLCs supported by the panels, by brand, model and protocol. Lists the part numbers for PLC cables and the programming cable. Tells how to install programming software.

Hardware Installation

Provides instructions on how to install custom labels and the EMI Noise Filter.

Discusses two mounting techniques — stud mounting and DIN clip mounting. Provides Outline Dimensions and Mounting Template. Provides you with instructions on connecting the unit to power, a programming PC and a PLC.

Learning the Features

Provides an Overview of the panel features. Front Panel Features, including;

Function Pushbuttons/LEDs, Character LCD Display, PLC Message LED and

Control Pushbuttons are discussed. Local and PLC Messages are described, along with types of Messages and Embedded Data Variables (DATA 1, 2, and

3).

Tutorial

Provides instructions to create an example (or “demo”) project. Discusses how to confi gure a PLC ladder logic program to use with the demo project.

Takes you through the steps necessary to create an EZText Enhanced Panel project using the programming software and application worksheets. Shows you how to transfer a project to the panel.

Confi guration

2

EZ-TEXT-M-E

Chapter

5

6

A

B

C

INTRODUCTION

User’s Manual

Description

Step-by-step instructions for confi guring the EZText Enhanced Panel (new system) using the EZText Enhanced Programming Software are provided.

Maintenance and Troubleshooting

Instructions for maintaining the EZText Enhanced panels are provided, including; Fuse Reset, Precautions, Chemical Compatibility, Cleaning, and Gasket

Replacement. Troubleshooting section aids in diagnosing problems you might encounter when installing or operating the panel. Provides steps to take to isolate and correct problems.

Appendix A

Application Worksheets are provided to help you plan and implement your system confi guration.

Appendix B

Wiring diagrams for several PLC cables are provided.

Appendix C

Error Messages for PLC Drivers, EZText Enhanced Panel, and EZText Enhanced Programming Software.

EZ-TEXT-M-E

3

INTRODUCTION

User’s Manual

Introduction to the EZText Enhanced Panel

The EZText Enhanced Panels provide a man-machine interface to your PLC automation system. The panels provide features such as 5 user-defi ned

pushbuttons with LED indicators, arrow adjust buttons, and a built-in menu system. The panels communicate with a PLC using either RS-232C or RS-

422A/485A serial communication. Confi guration software and panel programming are covered in chapter 5 of this manual.

The panels allow you to confi gure up to 256 20-character text strings confi gured as PLC Messages and Local Messages. Local Messages are internal panel messages that the operator can scroll in a menu tree hierarchy. PLC Messages are displayed when prompted from the PLC program. A PLC Message LED illuminates whenever a PLC Message is being displayed. Either message type can have up to three embedded data variables, one of which can be edited by using the arrow adjust buttons.

The panels have sealed membrane function pushbuttons that allow you to trigger

PLC actions with the push of a button. These pushbuttons are used for input signals to the PLC. Each pushbutton can be confi gured to function as one of three switch types:

ALTERNATE—keeps its current state until the button is pushed again

PANEL SET AND PLC RELEASE —sets a bit in the PLC when pressed and is reset by either the PLC program or by pressing the button again.

The LCD display window supports two or four message lines that can display up to 20 characters each. The messages are programmed using the EZText

Enhanced Programming Software. The message control type may be either

static—text displays that have NO embedded data, dynamic —text messages that include embedded data (READ access only), or interactive —text messages that allow the operator to enter data, or change values that are stored in the PLC registers (READ/WRITE access).

The EZText Enhanced Panel is available in a variety of models to suit your application. Key features are provided on page 10.

4

EZ-TEXT-M-E

INTRODUCTION

User’s Manual

What you need to get started

Hardware

• EZText Enhanced Panel

(Models EZ-220, EZ-220V, EZ-220L, EZ-420, EZ-

220P, & EZ-220PV)

and separate serial port

recommended)

requirements

Software

®

Need HELP?

PLEASE NOTE: Chapter 6, Maintenance and Troubleshooting, should be able to help you with most problems you might encounter.

EZ-TEXT-M-E

Onscreen HELP

One of the most important features of the EZText Enhanced Programming

Software is the availability of context sensitive onscreen help. To access the

Help windows, simply press the F1 function key while on the topic where you need help. For example, if you need help while working with panel confi guration, hit the F1 function key when that dialog box is open and a pop-up HELP window will be displayed.

PLC HELP

If you need help with the PLC to EZText Enhanced Panel Interface, consult the

EZText Enhanced Programming Software Help. Each PLC Driver has a Help

Topic that lists the error messages and provides an explanation for each. Also provided are PLC to EZText Enhanced Panel wiring diagrams.

Technical Support

5

INTRODUCTION

User’s Manual

Although most questions can be answered with EZText Enhanced HELP or the manuals, if you are still having diffi culty with a particular aspect of installation or system design, technical support is available at 1-877-774-EASY, Monday through Friday, 6a.m. to Midnight CST, or FAX us at 1-877-775-EASY. Visit our

website at www.EZAutomation.net.

Models

The EZText Enhanced Panels provide a low-cost, easy-to-use operator interface alternative for your PLC system. With easy to confi gure Windows-based software and simple installation, you can be connected and running in minutes. If your application requires pushbuttons, LEDs, or text display, but your budget is low, check out the complete line of EZText Enhanced Panels. The following features are common to the EZText Enhanced Panel models shown below:

• stores up to 256 20-character messages

5 user-defi ned function pushbuttons and LEDs

• up to three embedded PLC data variables per message

6

Part Number

EZ-220P

2 line by 20 character LCD display

Five user-defi ned buttons and LEDs

Three tri-color LED annunciators

EMI fi ltered power supply reduces

External Dimensions are 10.018” x 5”

****

EZ-220PV

Above with Vacuum Flourescent

Display

FFFFFFEREBVEBEV

EZ-TEXT-M-E

User’s Manual

Part Number

EZ-220V

2 lines by 20 characters Vacuum Flourescent Display

Character height of 0.22” (5.55 mm)

External dimensions are 5” x 7.4” x 1.6”

EZ-220

Above with Vacuum with LCD Display

EZ-220L

2 lines by 20 characters LCD display

External dimensions are 5” x 10” x 1.6”

INTRODUCTION

EZ-420

4 lines by 20 characters display

Character height of 0.187” (4.75 mm)

External dimensions are 5” x 7.4” x 1.6”

EZ-TEXT-M-E

7

INTRODUCTION

User’s Manual

PLCs Supported by EZText Enhanced Panels

PLC Brand Model

MicroLogix 1000/1200/1500, SLC500, 5/03, /04, and PLC5

Allen Bradley

Aromat

PLC 5

Aromat

Control Techniques Unidrive 4-wire

Control Technology Corporation (CTC) CTC 2600, 2700, and 5100

EZAutomation

General Electric

Idec

Mitsubishi

Modicon

Omron

EZPLC

90/30 and 90/70 Versamax

Idec

FX Series (all)

984 CPU, Quantum 113 CPU, AEG

Modicon Micro Series 110, CPU: 311-xx

411-xx, 512-aa, 612-xx

C200, C500, CQM1, CPM1

Direct Logic

Siemens

Texas Instruments

DL05, DL06

DL105

DL205

DL305

D2-230

D2-240

D2-250/D2-250 - 1/260

D2-240/250/260 w/DCM

D3-330/330P

D3-340

D3-350

D3-350 w/DCM

D4-430

D4-440

D4-450 DL405

All with DCM

Entivity (Think-n-Do)

Siemens S7300/400 PLCs MPI Adaptor

TI5x5 Series, TI505, TI545-1102, TI545-1104

Protocols Supported

DF1 Hlaf Duplex; DF1 Full Duplex

DF1

Mewtocol COM

Binary

CTC Binary

EZ Protocol

SNPX

Computer Link

Direct

Modbus RTU

Host Link

K-Sequence; DirectNet;

Modbus (Koyo addressing)

K-Sequence

K-Sequence

K-Sequence; DirectNet

K-Sequence; DirectNet;

ModBus (Koyo addressing)

DirectNet

DirectNet

DirectNet

K-Sequence; DirectNet;

ModBus (Koyo addressing)

DirectNet

K-Sequence; DirectNet

K-Sequence; DirectNet

K-Sequence; DirectNet

ModBus (Koyo addressing)

DirectNet

ModBus RTU

3964R

TBP (Transparent Byte Protocol) or NITP (Non-

Intelligent Terminal Protocol)

8

EZ-TEXT-M-E

INTRODUCTION

User’s Manual

PLC Cables and Programming Cable Part Numbers

Part Number Cable Description

EZP-2CBL

EZP-2CBL-1

Direct Logic PLC RJ12 port, DL05, DL105, DL205, DL350 & DL450

(RS-232C)

Direct Logic (VGA Style) 15-pin port, DL250 (RS-232C)

EZP-3CBL

EZP-4CBL-1

Direct Logic PLC RJ11 port, DL340 (RS-232C)

Direct Logic PLC 15-pin Dsub port, DL405 (RS-232C)

EZP-4CBL-2

Direct Logic PLC 25-pin Dsub port, DL405, DL350, DL305 DCU, and all

DCM’s (RS-232C)

GE 90/30 and 90/70 15-pin Dsub port (RS-422A) EZP-90-30-CBL

EZP-SLC-232-CBL AB SLC 5/03/04/05 DF1 port (RS-232C)

EZ-TEXT-M-E

Accessories and Optional Equipment

Part Number Description

EZ-TEXTEDIT-E

EZ-TEXT-S-GSK

EZ-TEXT-L-GSK

EZ-BRK-2

EZ-TEXT-STUDS

EZText Enhnaced Programming Software

Standard Replacement Gasket (small)

Standard Replacement Gasket (large)

DIN Clips (package of 4)

Mounting Studs (package of 4)

9

INTRODUCTION

User’s Manual

Front Panel Features

In this section, we will describe the front panel features of the EZText Enhanced

Panel. Descriptions of the PLC Message LED, Pushbuttons, Pushbutton LEDs,

PLC Messages, and Local Messages are provided. To understand the Features, see Chapter 3, Learning the Features. For a demonstration of how to program the panel indicators and controls, please refer to Chapter 4, Tutorial.

Operator Controls and Indicators

Each EZText Enhanced Panel provides sealed membrane Pushbuttons for operator interface with a PLC. Pushbuttons may be used to begin events or tasks within the PLC, such as Start/Stop Control. Pushbutton inputs are monitored for ON/OFF conditions in your PLC ladder logic program. EZText Enhanced

Pushbuttons are Control Pushbuttons or Function Pushbuttons or Data Entry

Keypad pushbuttons available in two models (EZ-220P & EZ-220PV).

10

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

INTRODUCTION

Annunciator Lamps

The EZ-220P & EZ-220PV models contain 3 tri-color Annunciator Lamps above the LCD message window. Each of these lamps may be programmed to illuminate in green, amber, or red and may be labeled to fi t your application. The lamps are turned ON and OFF through your PLC ladder logic program. They are confi gured with EZText Enhanced Programming Software and may be confi gured to display status or the condition of any operation being controlled within the PLC.

Data Entry (Keypad) Pushbuttons

The EZ-220P & EZ-220PV also feature a numeric keypad.

Use this keypad to enter or change embedded data values.

To update or enter a data value, the enter button must be pressed to select the data value. Then you may use the numeric keypad or the UP Arrow (increment) or DOWN

Arrow (decrement) to adjust the value. For the PLC to acknowledge the change in value, you must press enter again (sends the updated value to the PLC.) The CE

( Clear Entry) button is used to clear, or set back to zero, the current value.

PLC Message LED

This LED will illuminate to indicate that the PLC has triggered a message that will be displayed in the LCD window. The pushbuttons are disabled for 3 seconds after a PLC message is displayed to ensure that the operator sees the message. The LED will turn OFF when the operator presses the escape pushbutton, thereby acknowledging message received.

11

INTRODUCTION

User’s Manual

12

LEDs

Function Pushbuttons

Control Pushbuttons

There are 4 Control Pushbuttons on the front panel. These buttons consist of an esc ( escape), ( UP Arrow), ( DOWN Arrow), and enter pushbutton. The arrow buttons are used to scroll through local messages or to change a value within an interactive message. As the operator presses the buttons, the numeric value will increment or decrement, respectively. As it is adjusted, the value

WILL NOT BE UPDATED in the PLC data register until the enter pushbutton is pressed. When completed, the operator will press the enter pushbutton and the value will be written to the PLC. Press esc to abort or cancel the adjustment without writing the value to the PLC.

Function Pushbuttons

There are 5 Function Pushbuttons that are user-defi ned. They may be confi gured as one of three “ switch” types; Alternate, Momentary, or Panel Set & PLC

Release (described on page 69.) They are confi gured as discrete input signals to the PLC. These pushbuttons are labeled F1 through F5 or may be custom

labeled to suit their function or application.

Pushbutton LEDs

There are LEDs located above each of the user-defi ned pushbuttons. These

LEDs can indicate if the pushbutton status condition is ON or OFF, or it can be controlled independently by a PLC. You may choose the type of LED Control while confi guring your panel (see Confi guration, Chapter 5). There are three different controls— By Button, By Button & Flash, or By PLC, that will determine

LED response when the pushbuttons are pressed.

Character LCD Display with LED

Backlight

Messages display in the Character

LCD Display Window with LED

Backlight. The LCD window supports two line by twenty characters (EZ-

220, EZ-220V, EZ-220PV, EZ-220P,

& EZ-220L models), or four line by twenty character (EZ-420 models) messages.

EZ-TEXT-M-E

INTRODUCTION

User’s Manual

Messages

PLC Messages can be programmed to display PLC register values and allow the operator to change a PLC register value. Up to 3 data variables can be programmed to display in each message. The messages are entered using EZText

Enhanced Programming Software. Up to 256 PLC Messages may be confi gured and stored in the EZText Enhanced Panel. PLC Messages are numbered 1 to

256. The message control type may be static text, dynamic, or interactive. The

PLC logic program controls which messages are displayed. The PLC Message

LED illuminates when a PLC generated message is being displayed.

Local Messages are also displayed in the LCD Display Window. Local Messages provide pertinent information or instructions to the operator and are displayed in a menu hierarchy. They can also be programmed to display values from a

PLC register that the operator may change using the EZText Enhanced control buttons. You may create Folders to group messages pertaining to the same topic.

Local Messages and Folders can be grouped in up to 3 levels using the EZText

Enhanced Programming Software. The fi rst character in a Folder message display is a “+” or “–” indicating folder status (closed or open). The next 19 characters of the display are for the Folder text (Messages do not have a + or -, so all 20

Rear Panel Indicators

TXD LED

This LED will toggle “on” and “off” to signal activity on the transmission line.

RXD LED

This LED will toggle “on” and “off” to signal activity on the receive line.

EZ-TEXT-M-E

13

INTRODUCTION

User’s Manual

Specifi cations

Part Number

Description

Display Type

Character Height

Viewing Angle

Keypad Overlay

Service Power

Power

Consumption

Enclosure

Agency Approval

Operating

Temperature

Storage

Temperature

Humidity

Electrical Noise

Withstand Voltage

Vibration

Shock

Burn-in

LED/LCD Life

Serial

Communications

EZText Panel Specifi cations

EZ-220

2x20 LCD display, fi ve user defi ned pushbuttons, fi ve

LEDs

EZ-220L

2x20 LCD display, large characters, fi ve user defi ned pushbuttons, fi ve

LEDs

EZ-420

4x20 LCD display, fi ve user defi ned pushbuttons, fi ve

LEDs

Character LCD, 2 lines by 20 characters w/LED backlight

5.55mm (0.22”)

Character LCD,

4 lines by 20 characters w/LED backlight

8.06mm (0.316”) 4.75mm (0.187”)

+ or - 15 degrees horizontal

EZ-220P

2x20 LCD display, numeric keypad, fi ve user defi ned pushbuttons, three tri-color LED annunciators

Character LCD,

2 lines by 20 characters w/LED backlight

Five user defi ned pushbuttons and four control pushbuttons

4 Watts @ 24 VDC

4.5 Watts @ 24

VDC

Numeric keypad, fi ve user defi ned pushbuttons and four control pushbuttons

24 VDC (20-30VDC operating range)

4 Watts @ 24 VDC

5.5 Watts @ 24

VDC

NEMA 4, 4X (indoor)

UL, CUL, CE

EZ-220V

2x20 LCD display, fi ve user defi ned pushbuttons, fi ve

LEDs

Character VFD (Vacuum Fluorescent

Display), 2 lines by 20 characters w/LED backlight

5.55mm (0.22”)

6 Watts @ 24 VDC

EZ-220PV

2x20 VFD display, numeric keypad, fi ve user defi ned pushbuttons, three tri-color LED annunciators

+ or - 60 degrees horizontal

Five user defi ned pushbuttons and four control pushbuttons

Numeric keypad, fi ve user defi ned pushbuttons and four control pushbuttons

8.5 Watts @ 24

VDC

0 to 45 °C (32 to 113 °F)

-20 to 60 °C (-4 to 140 °F)

10 - 95% R.H., (non-condensing)

NEMA ICS 2-230 showering arc ANSI C3790a-1974 SWC Level C Chattering Relay Test

1000 VDC (1 minute) between power supply input terminal and protective ground (FG)

5 - 55Hz 2 G for 2 hours in the X, Y, and Z axes

10 G for under 12 ms in the X, Y, and Z axes

Temperature cycled 96 hours and then fully functional tested

100,000 hours

Download/Program/PCS Port TS-232/RS422/RS485 15-pin D-sub (female)

Dimensions

Weight (lbs)

7.418 x 5.00

(188.419 x

126.9989)

.65

10.018 x 5.00

(254.458 x

126.998)

.85

7.418 x 5.00

(188.419 x

126.9989)

.65

10.018 x 5.00

(254.458 x

126.998)

.85

7.418 x 5.00

(188.419 x

126.9989)

.65

10.018 x 5.00

(254.458 x

126.998)

.85

14

EZ-TEXT-M-E

Hardware Installation

In this chapter....

— EMI Noise Filter Installation

— DIN Clip Mounting

Connections Wiring

2

User’s Manual

Custom Labels

Create Custom Labels

You may create custom labels for the EZText Enhanced Function Pushbuttons that are particular to their function within your application. The labels slide into an existing slot in the panel overlay so that the text or numbers you have printed will rest over the pushbuttons.

A Microsoft Word® document ( EZ-TEXT_INSERTS.doc) is installed in the

EZText Enhanced Program folder on your computer when you installed your programming software. You must have Word installed on your computer

to open this document. This document will help you create your labels. Two sheets of cover stock have also been shipped with your panel.

Install Custom Labels

A 1/2-inch x 4-inch fl at metal tool ( ramp tool) is shipped with each unit to

aid in the installation of the label inserts.

To install the pushbutton labels into the slots, perform the following steps.

1. Carefully remove rubber trim mold from panel front to access label slots. (The trim has a barbed retaining rib that is pressed securely into a channel in the front panel housing.) The ramp tool can be used to help lift the trim (see illustration #1).

16

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

2. The recessed slot(s) where the labels are inserted should now be visible.

3. Remove the factory installed label insert.

4. Use the corner of the ramp tool to lift the top layer of the overlay (shown in illustration #3), just enough to place the custom label into the slot. Hold the overlay up with the ramp tool and start the custom label into the slot (illustration #4).

5. Once the label has been placed into the slot, move the ramp tool behind the label insert and use as a ramp to guide the label insert into the slot until properly

6. Push label tab down into trim channel with the ramp

7. Replace the rubber trim by fi rmly pressing the barbed rib into the molded channel in the front panel housing.

17

User’s Manual

EMI Noise Filter Installation

EZText Enhanced Panels are supplied with two ferrite cores that should be attached to the cables prior to installation of the EZText Enhanced Panel. These cores are required to suppress EMI emissions that are conducted through the

Power Cable and the Communications Cable. The fi gure, below, shows the ferrite cores properly installed. Attach the cores within one inch of the EZText

Enhanced connector. The cable should be snugly wrapped once around the core, providing two passes through the core.

The Power Cable Core is a solid ferrite cylinder. The Power Cable should pass once through the core, be looped around and pass through a second time. Pull the excess cable so that it rests snugly against the outside of the core.

The Communications Cable Core is a snap-together, split, ferrite core. This core can be installed on a fi nished cable. Lift the latch to open the core. Wrap the wire through the core center, snugly around the outside, and again through the center. Close the core until the latch snaps. Ensure that the cable jacket is not pinched between the two halves of the core. The fi nished cable should look similar to the drawing shown below.

18

EZ-TEXT-M-E

User’s Manual

Mounting

EZText Enhanced Panels can be mounted in two different ways: Stud

Mounting and DIN Clip Mounting. The panel comes with all the necessary mounting hardware required for stud mounting. DIN Clips (P/N EZP-BRK-2) must be ordered separately.

Models EZ-220, 200V, & 420 Outline

Dimensions and Mounting Template

STUD Mounting:

Use the 4 studs and 4 nuts with captive washers to secure the unit to the mounting surface. Requires a

5/16” wrench.

Mounting Studs (4 total)

EZ-TEXT-M-E

Mounting Template

19

20

User’s Manual

Model EZ-220P/EZ-220PV

Outline Dimensions

STUD Mounting:

Use the 4 studs and 4 nuts with captive washers to secure the unit to the mounting surface. Requires a 5/16”

wrench.

Mounting Studs (4 total)

EZ-TEXT-M-E

User’s Manual

Model EZ-220L Outline

Dimensions and Mounting Template

STUD Mounting:

Use the 4 studs and 4 nuts with captive washers to secure the unit to the mounting surface. Requires a

5/16” wrench.

Mounting Studs (4 total)

EZ-TEXT-M-E

Mounting Template

21

User’s Manual

DIN CLIP Mounting

DIN Clips (P/N EZ-BRK-2) are metal brackets that attach to the panel and secure the front bezel to a mounting surface with a screw. They provide an alternative to bolting the panel into the mounting surface. There are 4 square holes in the chassis (two on the top and two on the bottom). Insert the clip fl ange into this hole and secure the EZText Enhanced Panel by tightening the DIN CLIP screw until the front bezel is fi rmly pressed to the mounting surface.

22

EZ-TEXT-M-E

Connections and Wiring

User’s Manual

EZ-TEXT-M-E

23

User’s Manual

EZ-220, EZ-220V & EZ-420 Connections and Wiring

Power Connector

Block style connector is used to connect an external 24VDC power supply. See Power Connector Pinout on page 27.

Serial Port Communication LEDs

These LEDs illuminate to show whether the unit is sending or receiving data. See page 91.

24

Serial Port

This port may be used to connect the

programming computer or a PLC (see page 27). Use programming cable P/N

EZTEXT-PGMCBL to connect the PC. See

PLC Cable Part Number table, page 9 for the appropriate PLC cable used by your application. Block style connector is used to connect an external 24VDC power supply. See Power Connector Pinout on page 27.

EZ-TEXT-M-E

User’s Manual

EZ-220P & EZ-220PV Connections and Wiring

Serial Port Communication LEDs

These LEDs illuminate to show whether the unit is sending or receiving data. See page 91.

Power Connector

Block style connector is used to connect an external 24VDC power supply. See Power Connector Pinout on page 27.

EZ-TEXT-M-E

Serial Port

This port may be used to connect the programming

computer or a PLC (see page 27). Use programming cable

P/N EZTEXT-PGMCBL to connect the PC. See PLC Cable

Part Number table, page 9 for the appropriate PLC cable used by your application. Block style connector is used to connect an external 24VDC power supply. See Power

Connector Pinout on page 27.

25

EZ-220L Connections and Wiring

User’s Manual

Serial Port Communication LEDs

These LEDs illuminate to show whether the unit is sending or receiving data. See page 91.

Power Connector

Block style connector is used to connect an external 24VDC power supply. See Power Connector Pinout on page 27.

26

Serial Port

This port may be used to connect the programming com-

puter or a PLC (see page 27). Use programming cable P/N

EZTEXT-PGMCBL to connect the PC. See PLC Cable Part

Number table, page 9 for the appropriate PLC cable used by your application. Block style connector is used to connect an external 24VDC power supply. See Power Connector Pinout on page 27.

EZ-TEXT-M-E

User’s Manual

Power

Connector

This block style connector is used to connect an external 24 VDC power supply.

The connector with screw terminals is provided with your EZText Enhanced Panel and allows you to plug into the power receptacle. A pinout is shown below.

An external power supply is adapted to supply operating voltage to the EZText

Enhanced Panel. The power supply must deliver a range of 20 to 30 VDC.

In multi-panel applications, if separate power supplies are used, please ensure the electrical ground common does not have a great potential difference. In a multi-panel application, the power supply must maintain the specifi ed voltage and current consumption under all conditions (this includes powerup) for each of the individual units. Please refer to the specifi cations on page 14 for the individual units.

Connect (+) on the unit to the (+) lead of your power source; (-) on the unit is connected to the (-) lead; and chassis

GND (on the unit) is connected to the chassis ground of the cabinet. It is recommended you use a regulated power source isolated from relays, valves, etc.

Serial Port

EZ-TEXT-M-E

The Serial Port may be used to connect your panel to a programming computer (PC) or a Programmable Logic Controller (PLC). You will only need to connect to a PC when you initially confi gure and program the EZText

Enhanced Panel. The Serial Port is then available for connection to the PLC.

When you power up the EZText Enhanced Panel, it will come up in RUN Mode.

While in RUN Mode the Serial Port will only communicate with a PLC. To program the panel and have the Serial Port communicate with a PC, you will have to enter the SETUP Mode (see following paragraph).

Connect a Programming PC

To program the EZText Enhanced Panel, you must put the panel into SETUP

Mode. When the panel is powered up, it will be operating in the RUN Mode.

To enter the SETUP Mode, you must press and hold the UP Arrow button while simultaneously pressing the DOWN Arrow button. ( Please Note: While in the

SETUP Mode you may also adjust the screen contrast by pressing the UP or

DOWN Arrow buttons—ensure that you are in SETUP Mode!)

The EZText Enhanced Panel is confi gured using a PC running the EZText Enhanced Programming Software. When you are ready to download the program, connect the programming cable (P/N EZTEXT-PGMCBL) to the serial port of the panel and the serial port of the PC. A wiring diagram follows.

27

28

User’s Manual

P/N EZTEXT-PGMCBL

Connect a PLC

Connect your PLC to the EZText Enhanced Panel with one of the cables listed below.

EZ-TEXT-M-E

Learning the Features

In this chapter....

— Learning the Features

— Memory Mapping/PLC Data Registers

— PLC Message

— PLC and Local Messages

— Displaying PLC Messages

— PLC Messages LED

— Local Message File Structure Example

— Local Message Menu Structure Example

3

User’s Manual

Learning the Features

In this section, we will help you to learn and understand the Features of the EZText

Enhanced Panels. Details for using pushbuttons, LEDs, PLC messages, and

Local Messages are discussed. We recommend that you read this chapter well before you attempt to confi gure and use the EZText Enhanced Panel features and controls. As you proceed through this section, relate the topics discussed with how you will implement your panel.

Regardless of the PLC product type, the concepts discussed here are applicable.

DirectLogic PLCs are used in any examples of addressing and ladder logic, but the principles can be applied to any type PLC. Once again, this section is showing “concepts” for using the panel features. For complete DirectLogic examples and other PLC solutions, such as Allen-Bradley, please refer to the

PLC manufacturer’s manual.

NOTE: Features

Memory Mapping/PLC Data Registers

Pushbuttons Register in models EZ-220P

Annunciator

& 220PV.

PLC Message Registers

Embedded Data Registers

PLC and Local Messages

— Embedded Data

— Message Types

Static

Dynamic

Interactive

Passwords*

Displaying PLC Messages • Arrow Adjustment Entry*

PLC Messages LED • Numeric Keypad Entry*

Displaying Local Messages • Annunciator LEDs*

30

Memory Mapping/ PLC Data Registers

The EZText Enhanced Panels communicate with the PLC through user-defi ned

PLC data registers. PLC registers are assigned during confi guration using the EZText Enhanced Programming Software. For discrete operations, such as pushbuttons and LEDs, the register bits are accessed by the PLC control program. The following page shows how the pushbuttons and LEDs are assigned to the PLC bit registers.

EZ-TEXT-M-E

User’s Manual

Pushbuttons

Pushbuttons use one 16-bit register. All bit designations are in octal (0–7 and

10–17), used by DirectLogic PLCs. Use bits 0 through 15 for PLCs using decimal numbering. Address used here must be READ/WRITE.

BUTTONS (BIT WRITE) PLC WORD — (FROM PANEL)

F1–F5 = Function Pushbuttons 1–5

Please NOTE:

A n y u n u s e d b i t address should not

ENT = Enter

= Arrow UP/DOWN

ACK F1–F5 = Panel acknowledge of PLC button release

NA = not used (Do not use for other PLC program addresses)

PLC program. The panel will control the unused bits.

for the corresponding Function Pushbutton and the Release Bit for that button is set by the PLC in the LED (BIT READ) PLC WORD.

LEDs

LEDs use one 16-bit register. All bit designations are in octal (0–7 and 10–17), used by DirectLogic PLCs. Use bits 0 through 15 for PLCs using decimal numbering.

EZ-TEXT-M-E

LED (BIT READ) PLC WORD — (TO PANEL)

LED1–LED5 = Only used when By PLC has been chosen.

REL F1–REL F5 = Used by PLC to release a button that is set by the

panel.

31

32

User’s Manual

Example when using Panel Set & PLC Release Option for a Function

Pushbutton:

Operator Presses Button:

F1 is set by the Panel (Bit 0 in Button Word).

This is a maintained pushbutton to the PLC.

PLC Releases Button:

REL F1 is set by the PLC (Bit 10 in LED Word).

The PLC resets the panel button by setting this bit in the ladder program.

Panel Acknowledge Button Release:

ACK F1 is set by the Panel (Bit 10 in Button Word).

This is the panel acknowledging to the PLC that it has reset the button.

Annunciator Lamps

Annunciator Lamps use one 16-bit register. All bit designations are in octal (0–7 and 10–17), used by DirectLogic PLCs. Use bits 0 through 15 for PLCs using decimal numbering.

ANNUNCIATOR (BIT READ) PLC WORD — (TO PANEL)

(BITS)

LAMP 1 = Left Lamp, Bits 0 and 1

LAMP 2 = Center Lamp, Bits 2 and 3

LAMP 3 = Right Lamp, Bits 4 and 5

NA = not used (DO NOT use for other PLC program addresses)

To have the lamps illuminate in a particular color, or not to illuminate at all, set the bits in your PLC Ladder Logic as follows:

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

PLC Message Registers

The EZ-220, EZ-220V, EZ-220L, EZ-420, EZ-220P, and EZ-220PV panels have 2 or 4 lines of PLC Message display. Each message line references a user-defi ned register in the PLC. The registers are assigned using the EZText

Enhanced Programming Software. The panel monitors each register for a value

(message number) and displays the message associated with the value (i.e., a value of 3 displays message 3).

Embedded Data Registers

Each message can have up to three embedded data values, DATA 1, DATA 2, and DATA 3. Embedded data registers are user-defi ned.

DATA 1 (16-Bit Register, READ/WRITE)

This is a PLC register that contains the fi rst of three possible embedded data values on a line for the message displayed. DATA 1 can be set as a READ/

WRITE Register allowing the operator to change a data value. It can also be set to READ ONLY. This is the only data value that has this option.

33

User’s Manual

PLC CONTROLLED DECIMAL POINT (16-Bit Register)

This is a register in the PLC for controlling a decimal point within an embedded data value (DATA 1 only). One register holds the value and the other controls the decimal point. The register addresses are assigned from the Message

Edit screen as shown above. No ASCII characters are allowed in DATA 1 with a PLC controlled decimal point.

DATA 2 (16-Bit Register, READ ONLY)

This is a PLC register that contains the second of three possible embedded data values on a line for the message displayed. You may manually insert a decimal point. The PLC Address and Data Type are assigned from the Message Edit screen, shown above.

DATA 3 (16-Bit Register, READ ONLY)

This is a PLC register that contains the third of three possible embedded data values on a line for the message displayed. You may manually insert a decimal point. The PLC Address and Data Type are assigned from the Message Edit screen, shown above.

34

EZ-TEXT-M-E

User’s Manual

PLC Messages and Local Messages

Embedded Data

The user message contains the ASCII characters and optional embedded data to be displayed. The embedded data can be up to 3 different values — DATA

1, DATA 2, and DATA 3.

Special characters in the message determine where the embedded data from the registers should go. When programming, each character for DATA

1 values will be represent by a “1” for up to fi ve digits. For example, if you want to display a fi ve digit value from the

PLC, you will press Ctrl + 1 or F5, fi ve times, and “11111” will display in your message (in red) representing the fi ve digit value.

Please NOTE:

When selecting BCD

Data Type, only a 4digit value can be used (0–9999).

Only DATA 1’s embedded value can be Interactive (READ/WRITE register), meaning that data values will display and can be changed from the message.

DATA 2 and DATA 3 are Dynamic (READ ONLY register) meaning that they will display a value, but the value cannot be changed from the message. DATA

2 values are entered into the message by pressing Ctrl +2 or F6, and are represented by a “2” for each numeric digit, displayed in blue. DATA 3 values are entered into the message by pressing Ctrl +3 or F7, and are represented by a “3” for each numeric digit, displayed in green. Again, these values can be up to fi ve digits. Data values are only represented by a “1,” “2,” or “3” when you are programming the message. The actual values will be displayed on the EZText

Enhanced Panel LCD Display window, or will be blank if no value is present.

( Password Protection is only available with EZText Enhanced Panel Models

EZ-220P and EZ-220PV.)

For DATA 1, you can select a minimum and maximum range for the embedded data value. The Maximum is to test for the upper limit for the data value and

Minimum is to test for the lower limit for the data value. This will let the user update the value between the ranges. Data values are incremented or decremented with the UP/DOWN Arrow Buttons.

Also for DATA 1, you can choose to have the Decimal Point in the value controlled by the PLC, or you can manually insert it in the message.

EZ-TEXT-M-E

35

36

User’s Manual

Message Types

There are three types of messages: Static, Dynamic, and Interactive identify the different message types.

Static Messages

Static Messages are text displays that have NO embedded data. The Static

Message may be displayed when an event or condition becomes true. You will enter

SYSTEM RUNNING the messages using the EZText Enhanced Programming Software.

Dynamic Messages

Dynamic messages are text messages that include embedded data. These messages are used to display values from the PLC

(READ only access to a PLC register). This data is information that helps the operator closely monitor and/or control the machine or process.

Zone1 Temp. : 753

Data Value update from

PLC register

Embedded Data Values in messages can be of two types — BCD or Binary. DATA 1 can have a decimal point controlled by the PLC or manually inserted. DATA 2 and DATA 3 allow you to manually insert a decimal point. The maximum number of data values per message is three. Data type and decimal points are programmed when confi guring the message from the Message Edit screen.

Interactive Messages

(With an embedded DATA 1 value, only). An

Interactive Message is commonly used for operator data entry. This type of message is used for changing values that are stored in the PLC registers (READ/WRITE access).

These values are typically; Setpoint, Upper and Lower Limits, etc. Interactive Messages may be confi gured to enter data using the

UP/DOWN Arrow buttons.

Enter New Temp. = 300

Data value entered by operator

Displaying PLC Messages

PLC Messages are triggered by the PLC. The PLC Message LED will illuminate to let you know that the PLC has generated the message. You cannot press the esc key to exit the PLC Message mode until 3 seconds after the message has been triggered. This delay is to ensure that the message has been seen

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

by the operator. After the 3 seconds, press the esc key and you will return to

Local Message mode. If you press the esc key again, the last PLC Message will be redisplayed.

Static Message Operation

To display a Static PLC message, you simply put the message number (1–256) in the appropriate PLC register. These messages are text only, no embedded data.

Dynamic Message Operation

Dynamic messages are text messages that include embedded data. These messages present the operator with important PLC data. You may program message numbers 1–256 to be used as dynamic messages. Dynamic messages may be displayed on either the top or bottom line. The maximum number of digits that may be displayed is fi ve (if Binary data format or four if BCD). Use the EZText Enhanced Programming Software to confi gure Dynamic messages.

See Section 7, Confi guration, for more information.

Interactive Message Operation

An interactive message is a text display that allows operator data entry. Use these messages to enter or change values that are stored in PLC registers. When the interactive message is displayed, the operator can enter data. Check the PLC product user manual to verify which data formats are supported. Depending on the PLC, the data format will be either Binary or BCD ( Binary Coded Decimal).

Five digits may be entered in a 16-bit register using Binary data format. Four digits may be entered in a 16-bit register using BCD data format.

Interactive messages are confi gured within the EZText Enhanced Programming

Software by embedding a DATA 1 value in a PLC message. An interactive message requires that you defi ne the Format (Binary or BCD), and Decimal Point

Position. There are two types of decimal point placements — PLC controlled and

fi xed placement (decimal point entered between characters when confi guring the message). A PLC controlled decimal is only allowed in DATA 1. DATA 2 and

DATA 3 allow you to enter a fi xed point (manually inserted). Two PLC registers are used to store PLC controlled decimal point values, one for the data value and the other for decimal point control. When the decimal point is PLC controlled it must be confi gured in your PLC logic program. For more information, see Chapter 5,

Confi guration, or your PLC Confi guration Manual.

Arrow Adjustment Entry

Arrow adjust is often used when minimum and maximum setpoint ranges are required or a setpoint value requires only minor adjustment. These arrow adjustments are only possible using the UP or DOWN Arrow pushbuttons.

37

User’s Manual

As you press the UP and DOWN Arrow pushbuttons, the numeric value will increment (up) or decrement (down) one count at a time. When the UP/DOWN

Arrow buttons are used to increment or decrement a value, the cursor is disabled and will not be visible again until you press enter, esc, or return from an error or

PLC message. Also, the longer you hold the key down, the faster the count will increase. When the adjustment is complete, press the enter pushbutton, and the value will be placed in the data register for display and the bit is set.

*Numeric Keypad Entry

Numeric Keypad entry is used when a decimal point is being used and is the preferred method for data entry instead of arrow adjust. The decimal point button must be used when entering a decimal value.

*Annunciator Lamps

There are three tri-color lamps located above the LCD Message Display. They can be illuminated as red, amber or green through the PLC program.

PLC Message LED

The PLC Message LED will illuminate any time a PLC message is being displayed.

Press the esc key to exit the PLC message and return to Local Messages. Press

esc again to re-display the last PLC message.

*These features are only available in models EZ-220P and EZ-220PV.

38

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

Displaying Local Messages

In a Local Message, the fi rst message ( root level) or folder in the hierarchy is displayed on the top line at start up and the following message or folder is displayed on the second line.

A plus (+) is displayed in front of a folder’s or subfolder’s name if it is closed.

If a folder or subfolder is open, a minus (–) is placed in front of the name. Any messages within that folder will be displayed below it.

+Local Folder 1

+Local Folder 2

–Local Folder 2

Local Message 2.1

Therefore, a folder is limited to 19 characters after the + or -, a message allows

20 characters. (The EZText Enhanced Programming Software only allows 19 characters for folder text when you are confi guring the Local Messages.)

You may use the UP/DOWN Arrow buttons to scroll down to the next message in that folder. At the end of the messages for that folder, you can press the esc button to move to the previous folder or level.

The Local Message menu hierarchy can only extend three levels deep (after the root level) but each folder (level 1 and level 2) may have many subfolders or messages on that level. Folder level 3 may have many messages, but no folders.

Messages can contain up to three embedded data values. See the following examples of a menu tree and how it may appear from within the EZText Enhanced

Programming Software and how it may appear on your display.

39

User’s Manual

Local Message File Structure Example

(as seen when confi guring messages in the EZText Enhanced Programming Software)

Level 0

(Root Level)

This is not displayed on the panel

You cannot change this. It is the

Root Level. All messages and folders stem from here.

Level 1

Folder A is allowed multiple Messages and subfolders

Level 2

Folder B is allowed multiple Messages and subfolders

Level 3

Folder C is only allowed multiple

Messages

Folder D is only allowed multiple

Messages

Folder E is allowed multiple Messages and subfolders

Basic Structure

“Local Messages” is just a place holder and always appears in the configuration software menu tree.

40

In this example of the Local Message programming window:

Folder 1 would be displayed on Line 1 of the EZText Enhanced Panel display,

Folder 2 would be displayed on Line 2 of the display.

A plus (+) is displayed in front of the folder icon

if it is closed. If a folder is open, a minus

(–) is placed next to the folder ic n , and any message in that folder will be displayed.

EZ-TEXT-M-E

User’s Manual

Local Message Menu Structure Example

(as would be seen on the EZText Enhanced Display, except that Levels are indented here to make them easier to see.)

Viewing the menu from the root (A folder is also counted as a message.)

Local Messages ( Root)

Message 1 (Root message)

Message

+Folder

Message

Message

+Folder

Message

Viewing the menu from open Folder A

A (Folder is open and it contains 3 messages and one subfolder with 3 messages)

with 3 messages)

Viewing the menu from open Folder B

When a folder is opened, a minus sign “–” appears before the folder name. A “+” sign indicates that the folder is closed.

Local Messages (Root)

Message

(Root message)

2 (Root message)

–Folder

Message 11 (Folder C message)

Message 14 (Folder A message)

Message

Message

+Folder

Message

EZ-TEXT-M-E

41

User’s Manual

This page intentionally left blank.

42

EZ-TEXT-M-E

Tutorial

4

In this chapter....

— EZText Enhanced Panel Setup

— Installing EZText Enhanced Programming Software

Plan the Project using Application Worksheets

Create a Project with EZText Enhanced

Confi gure a PLC

User’s Manual

EZText Enhanced Panel Setup

SETUP Mode

In order to download the program to the

EZText Enhanced Panel using the EZText

Enhanced Programming Software, you must be in the Setup Mode. Setup Mode is also where you will adjust the display contrast of the EZText Enhanced Panel.

SETUP MODE

DRV. REV.:

The EZText Enhanced Panel will start up in the RUN Mode. To access the SETUP

Mode, follow these steps:

44

the DOWN Arrow Pushbutton to enter the SETUP Mode.

2. At any time you may press the Escape (esc) button to go back to RUN

Mode. You will be taken back to the start of the Local Message menu

(cursor is placed at root level when you return from setup).

Adjust Display Contrast

You may only adjust the Display Contrast when in Setup Mode. To adjust the display contrast use the UP and DOWN arrows to increase or decrease the contrast.

Internal Software and Hardware Revisions

While in SETUP Mode the Panel Hardware Revision, Driver Revision, Boot

Revision, and Exec (Firmware) Revision numbers will display on the panel.

Preparing for Confi guration

If you prepare and plan ahead of time, your use of the EZText Enhanced

Programming software will be successful. Below are a few important steps to take to prepare to program your application.

Prepare your personal computer and ensure proper installation of the EZText Enhanced Programming Software

Know your operator interface requirements. Determine the type of

EZText Enhanced and the number of EZText Enhanced Panels required by your application

Know your PLC type and available resources, such as, programming

Verify type of communications port, as well as protocol used.

Determine the CPU link(s) available for connecting an EZText

(RS-232/RS-422, baud rate, parity, stop bits.)

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

Determine how the pushbuttons, LEDs, PLC Messages, and Local

Messages will be assigned in your panels with respect to your

machine process.

To prepare your application, use the application worksheets provided in appendix A of this manual. The example worksheets will help you understand how the EZText Enhanced program is confi gured.

Blank worksheets can be used in planning, implementing, and using your EZText Enhanced Panels.

Installing EZText Enhanced Programming Software

EZText Enhanced Panels are confi gured with software running on an IBM or compatible personal computer. This software is available through EZAutomation, part number EZ-TEXTEDIT-E. The software is used to download your confi guration before connecting the panel and communicating with a PLC. Help

Topics are provided to help you confi gure your panel. You design and confi gure your EZText Enhanced program off-line and save it to disk. The program may then be transferred to the EZText Enhanced Panel. To install EZText Enhanced

Programming Software, perform the following steps:

Place CD into your CD ROM Drive. click Start Button, and then click on

Run from the menu. The Run dialog box will pop up.

• At prompt type D:\ (or your CD Drive)\setup.exe or click

EZText Enhanced Programming Software.

• Click OK button to begin the installation. The

EZText Enhanced Programming Software Installation

• Follow onscreen prompts to load the software.

45

Installation Screens

User’s Manual

This icon will appear on your

desktop after installation.

EZText Enhanced

Programming

Software Icon

46

This is the fi nal installation screen. Here you select the destination folder where your software program will be installed.

The default destination location is C:\

Program Files\EZText Enhanced. If you wish to select another destination, click on the Browse button.

To complete the installation, click on

Next> button. That’s all there is to it! The

EZText Enhanced Icon shown above will appear on your desktop. Simply click on it to open the Programming Software!

EZ-TEXT-M-E

User’s Manual

Tutorial — Plan the Project using Application Worksheets

The following is a project tutorial. It will take you through the process of creating a new project, confi guring buttons, creating messages, and transferring a project to the EZText Enhanced Panel. This should help familiarize you with the EZText

Enhanced Programming Software.

Let’s start by fi lling out the application worksheet found in Appendix A. For tutorial purposes, we have already fi lled in the information. For your project, make copies of the forms in Appendix A. Follow steps 1 through 4 as shown below to fi ll out the application worksheet for the EZText Enhanced Demo Project.

EZText Enhanced Application Worksheet

EZ-TEXT-M-E

47

User’s Manual

This is a copy of page 30 from Chapter 3, Learning the Features. Shown here are the bit addresses for the Button PLC Word (V40600) and LED PLC Word

(V40601) in this tutorial.

Please note that any unused bit address SHOULD NOT BE USED in your

PLC program. The EZText Enhanced Panel will control the unused bits.

48

EZ-TEXT-M-E

User’s Manual

For the next part of our project planning, we’ll create four Local Messages using the Local Message Worksheet. These messages will be confi gured later in our

EZText Demo Project using the EZText Enhanced Programming Software.

EZ-TEXT-M-E

49

User’s Manual

The last part of our project planning is creating three PLC Messages using the

PLC Message Worksheet. These messages will be confi gured later in our EZText

Demo Project using the EZText Enhanced Programming Software.

50

EZ-TEXT-M-E

User’s Manual

Tutorial — Create the Project using EZText Enhanced

Programming Software

Let’s assume you have the programming software installed on your PC (if you don’t, go back to page 45 and install now). Connect the EZText Enhanced Panel to your PC using the P/N EZTEXT-PGMCBL cable. Apply 24 VDC to the panel power connector.

From Welcome screen, click on the New System button.

in the File name fi eld. Click on Save. (If you don’t want your project saved to the default “Project” folder, navigate to the directory and/or folder where you want it to reside.)

EZ-TEXT-M-E

51

User’s Manual

Step 1, Select Panel, you will start your project by selecting the panel type you are using.

a. From the Main Confi guration Screen, click on the Select Panel

Type button.

b. The Select Panel dialog box will open. Under Panel Type, click on the panel type you are using to highlight it. A picture of the panel will appear under Panel Preview, and key features of the panel are displayed under Panel Attributes.

c. Click on the OK button to select and close the dialog box.

52

4. In Step 2, Select PLC, you will choose the type PLC you are using.

a. Click on the DOWN arrow next to the Select PLC fi eld to view the drop down menu of available PLCs. Click on the PLC Type to select.

EZ-TEXT-M-E

User’s Manual

b. Click on the Press for communication confi guration for Selected

PLC button.

c. The PLC Communications Attributes window will appear for the PLC you have selected. (In this case, DirectLogic K-Sequence.) Set the attributes to match those in the screen capture, below. Click on the

OK button.

Please Note:

The PLC communication attributes must match the

COM port settings for your

EZ-TEXT-M-E

5. Step 3 you will confi gure the Buttons/LEDs, Messages and Panel

System PLC Addresses.

on Buttons/LEDS button. The following screen will appear.

53

User’s Manual

LED Control

Button Action

LED PLC Word

Button PLC Word

a. Under LED Control, click on the down arrow to view control choices.

Select By Button for LED 1, LED 3 and LED 4. Select By PLC for LED 2, and By Button & Flash for LED 5 (selections should be as shown in the screen capture above).

b. Under Button Action, click on the down arrow to view control choices.

Select Alternate for F1 and F5, Momentary for F2 and F3, and

Panel Set & PLC Release for F4.

c. Assign a PLC Word for the LEDs and the Buttons. These PLC

Words should be a BIT Register.

d. Click on OK to accept and exit the screen.

*7. Click on the Annunciator button. The screen shown to the right will appear.

a. Assign a PLC Read Word (Bits). The PLC Word should be a BIT register.

b. Click on OK to accept and exit the screen.

*This step is only applicable to models EZ-220P & EZ-220PV.

54

EZ-TEXT-M-E

User’s Manual

8. N e x t , w e ’ l l s h o w y o u how to configure Local

Messages. Click on the

Messages button for Step

3 on the Main Confi guration

Screen. The following screen will appear.

EZ-TEXT-M-E

a. Click on the Add Local Folder button (Step 1). In the Message

Text fi eld (Step 2), type in “Process Control.” Click on the Press

to accept Message edit button (Step 3).

b. Click on the Process Control Folder to select it, and then click on the Add Local Message button.

c. Enter “Press F1 to Start Y0” in the Message Text fi eld and then click on the Press to accept Message edit button.

d. Next we’ll confi gure a dynamic message. Click on the Process

Control Folder, then click on Add Local Message and type in

“Zone 1 Temp =”. After Zone 1 Temp =, enter a space and press

F5 (or Ctrl +1) three times, type in a decimal point, then press F5

55

User’s Manual

again. Type in a “C” immediately after the “

111 .

1

”. (DATA 1 will appear as four, red ones in the message.)

e. Under the DATA 1 section of the screen shown above, type in

“V2010” in the PLC Address fi eld. The Data Type should be set to BCD, and Access should be Read Only.

f. Click on the Press to accept Message edit button.

g. The last Local Message to be confi gured will be an Interactive message (DATA 1).

h. Click on the Process Control

Folder, then click on Add Local

Message.

i. In the Message Text fi eld, type in “Load Part #”, leave a space, and then press F5, or Ctrl + 1, four times. (DATA 1 will appear in the Message Text fi eld as four, red ones.)

56

j. The DATA 1 confi guration area is now available (no longer grayed out.) Next to PLC Address, type in “V2011”. Data Type should be BCD. Access is Read/Write. Set the Min. value to “1200” and the Max. value to “1999” (settings are shown in the screen capture, above.) This will limit what value can be entered by the operator.

k. Click on the Press to accept Message edit button to save it.

EZ-TEXT-M-E

User’s Manual

EZ-TEXT-M-E capture above, perform the following steps:

a. Click on the Add next PLC Message button.

b. Type in the Message Text fi eld, “F3 Button Message”.

c. Click on the Press to accept Message edit button to save it.

d. Click on the Add next PLC Message button.

e. Type in the Message Text fi eld, “PLC Release Bit Ackn”.

f. Click on the Press to accept Message edit button to save it.

g. Click on the Add next PLC Message button.

h. Type in the Message Text fi eld, “ESC for Local Msgs”.

i. Click on the Press to accept Message edit button to save it.

9. You are now fi nished confi guring the messages for this tutorial, click on OK to exit the Message Edit screen.

is to configure the panel system PLC addresses. To confi gure PLC addresses, click on the Configure

P a n e l S y s t e m P L C

addresses button.

57

User’s Manual

settings as follows:

58

a. Type in “V3000” in the Line One fi eld. Select BCD as the DATA

Type. Type in “V3001” in the Line Two fi eld. Select BCD as the

DATA Type.

b. The panel beeper is defaulted to Yes. If you do not want to hear the beeper each time a button is pressed, select No under Enable

Beeper.

c. Click on the OK button to save and exit.

12. You are now ready to write the project to the EZText Enhanced

Panel.

Click Write to Panel button on the Main Configuration

Screen.

EZ-TEXT-M-E

User’s Manual

EZ-TEXT-M-E

Port selected and select the COM port on your PC that is connected to the EZText Enhanced Panel (COM1, COM2, COM3 or COM4).

15. Before preceding, ensure that the panel you are about to write to is in the

Setup Mode. To enter the Setup Mode, press the UP and DOWN arrows on the EZText Enhanced Panel simultaneously. The panel display will read

SETUP MODE on the fi rst line.

Click Start button on the Writing to Panel screen, as shown above.

progress

Write to

Panel process will be shown by a check mark placed in front of the items as the project is written to the panel. The status bar along the bottom portion of the screen will also show the progress.

18. Now that the panel is confi gured, let’s connect our PLC programming software to the PLC and write the ladder program.

59

User’s Manual

Tutorial — Confi gure a PLC

For the purposes of this tutorial, we will be using a DirectLogic® DL05 PLC.

To confi gure the PLC we are using DirectSOFT® Programming Software. The purpose of this part of the tutorial is to show you how to confi gure your PLC to communicate with an EZText Enhanced Panel.

1. Connect to the PLC with DirectSOFT.

2. Enter the following ladder logic.

60

EZ-TEXT-M-E

User’s Manual

EZ-TEXT-M-E

61

User’s Manual

3. Save the Program to the PLC and to disk (EZTextDemoProject).

4. Place the PLC in Run Mode.

The PLC is now confi gured and running. Now, to test our project, connect the

Panel to PLC communications cable (P/N EZP-2CBL), to the panel port and the

PLC port.

Local Message (folder), “+ Process Control”, will be displayed on the fi rst line.

F1 to Start Y0” will be displayed. Use the (arrow) buttons to scroll through the messages. Press the esc button to go back to the Folder

Level 1.

6. Press F4 to turn ON Y2. Either press F4 again to turn it OFF, or turn ON X0 in the PLC. If the PLC turns OFF F4, a message will be displayed.

CONGRATULATIONS! You have now successfully confi gured an EZText

Enhanced Panel!

62

EZ-TEXT-M-E

Confi guration

5

In this chapter....

—Confi gure New System

Step 1, Select Panel

Step 2, Select PLC

Step 3, Panel System PLC Address Setup

Confi gure Local and PLC Messages

—Connect to Panel, View Panel Status and Firmware Version

User’s Manual

This section will take you through the steps necessary to confi gure a new system, edit an existing system, view panel status, and upgrade the EZText Enhanced Panel fi rmware.

We recommend that you go through the tutorial in Chapter 4, page 43, before confi guring your EZText Enhanced Panel.

If you don’t already have the EZText Enhanced Programming

Software installed, go to Chapter 4, Tutorial, page 45.

Confi gure New System

1. Click on the EZText Enhanced Icon to open the EZText Enhanced

Programming Software. The following screen will appear.

64

EZ-TEXT-M-E

User’s Manual

Click New System button to confi gure the EZText Enhanced program. The following screen will appear.

EZ-TEXT-M-E

3. Enter a name for the project in the File name fi eld. Navigate to the directory and folder where you want to keep the fi le (or except default location), and click on the Save button to save. The following screen will appear.

65

User’s Manual

4. For Step 1, click on the Select Panel Type button. The following screen will appear. Under Panel Type, click on the model you are using. A

Panel Preview and Panel Attributes specifi c to the type of panel you have chosen will appear in this dialog box. Click on OK to enter your selection.

66

Arrow next to the Select PLC fi eld. Choose the PLC and

Protocol type you are using.

for Selected PLC button.

appear. Complete the communications information. After

selecting the PLC type, you must defi ne the remaining

protocol items, such as baud rate, parity, etc. The following

table provides the necessary information for most DirectLogic

controllers. When using another type PLC, consult that

product’s user manual to determine the port communications capabilities.

EZ-TEXT-M-E

User’s Manual

Table for DirectLogic PLC Attributes

EZ-TEXT-M-E

During confi guration, ensure that your address and communications parameters match the PLC port settings. There will be a selection for PLC timeout. When the panel sends a message to the PLC and does not receive a response or does not understand the response, it will wait the timeout period before sending the message again.

67

User’s Manual

68

button. The Panel System PLC Address Setup window will appear.

for Line One and Line Two (and Line Three and Line Four if using an

EZ-420 Model). Select the Data Type for the PLC. Select Yes or No to Enable Beeper. Click OK.

9. Next, click on the Buttons/

LEDs button (shown to the right) to confi gure the Panel

Functions. The following screen will appear.

If Password Protection, to restrict access to data entry, enter a Local Password (up to

5 digits, 0–65535). If you want to store the password in the PLC, enter a register address (PLC

Password Register) and select the Data Type for the PLC. Click

OK to exit the Setup screen.

*Password Protection is only available in models EZ-220P & 220PV.

EZ-TEXT-M-E

User’s Manual

EZ-TEXT-M-E select LED Control for the fi rst button LED, Bit 0. You may choose to have the LED controlled By Button, By Button & Flash, or By PLC. Make selections for Bit 0 through Bit 4. The LED function depends on the type of Button Action selected.

pressed.

By Button & Flash means that the LED illuminates and fl ashes when the button is pressed.

PLC.

may choose from Momentary, Alternate, or Panel Set and PLC

Release.

only turns OFF when the button is pressed again.

are ON when the button is pressed and turn OFF when pressed again or when turned off by the PLC.

or Bit 8 through Bit 12 (Decimal). If the button is ON, the

PLC can release the button by setting the corresponding

69

User’s Manual

through Bit 14 (Octal) or Bit 8 through Bit 12 (Decimal). The

Bits.

Word address.

This register controls

LEDs and PLC Button

Release (Read Only or

Read/Write address)

This register controls Buttons and Panel Acknowledge (must be READ/

WRITE address)

14. Now you are ready to confi gure

Local and PLC Messages.

Click on the Message button

(as shown to the right). The following screen will appear.

70

EZ-TEXT-M-E

User’s Manual

*15. Now you are ready to confi gure the Annunciator Lamps. Click on the

Annunciator Button, shown below.

The following screen will appear.

EZ-TEXT-M-E

*16. Enter a PLC address in the PLC Read Word (Bits) fi eld. When you confi gure the PLC ladder logic, use the bit assignments as shown in the dialog box above to control the three annunciator lamps. (White represents OFF.)

Click OK button to save the register address and exit the screen.

*18. Now you are ready to configure Local and PLC

Messages. Click on the

Message button (as shown to the right). The screen at the top of the following page will appear.

*These features available in models EZ-220P & EZ-220PV only.

71

User’s Manual

Messages are messages stored in the panel in a menu hierarchy and provide information and instructions to the operator. PLC Messages are triggered by a value in a PLC register. The PLC Message LED will illuminate to tell the operator that the PLC has triggered a message.

The buttons will not respond for 3 seconds after the PLC Message has been triggered to ensure that the operator has a chance to read the message. See step 16 (next step) to program a PLC Message. To program a Local Message, perform the following steps.

a. Next to Local Messages, click on the Add Local Folder button or the Add Local Message Button.

Click on this button to add a folder

Click on this button to add a message

NOTE: Folders can have up to 19 characters maximum.

b. Under Step 2, type in up to 20 characters in the Message Text fi eld.

c. Step 3, click on the Press to Accept Message Edit button. The message text you have typed in will appear in the Local Message fi eld.

1 Enter text here 2 Click here to accept text

72

3 Confi gured Message will appear here Total characters in current message is shown here d. If you want to embed data from a PLC register in a Local

Message, place the cursor in the message where you want the

EZ-TEXT-M-E

User’s Manual

value to appear and press F5 or ( CTRL+1) for DATA 1, F6 or

( CTRL+2) for DATA 2, or F7 or ( CTRL+3) for DATA 3. Each press of the function key will enter one data value digit. You may enter up to 5 characters (depending on the data type).

In the message, the data will be represented by red

1’s for DATA 1, blue 2’s for

DATA 2, and green 3’s for

DATA 3. (The actual

value will display in the message on your EZText

Enhanced Panel.)

e. Now you will need to confi gure the embedded data . If you have

embedded data, you will notice that the DATA 1, DATA 2, or DATA

3 fi eld is now available.

EZ-TEXT-M-E

f. You must fi rst enter the PLC Address where the value resides.

Select the Data Type ( format) for your PLC Type (either BCD or

Binary).

g. Select the Access for the PLC register. Will you want the message to display a register value (READ only)? Do you want the message

73

74

User’s Manual

to display a register value and allow the operator to change the value with the panel ARROW Keys (READ/WRITE)?

h. If you select READ/WRITE Access, you can enter a Minimum and

Maximum Range that the operator can write to the PLC.

i. You will notice that Password Protection is not available for the

EZText Enhanced Panel models covered by this manual. Password

Protection is only available in the EZ-220P model, that offers a keypad for numerical data entry.

j. You may confi gure DATA 1 to display a decimal point that is controlled by the PLC. The location of the decimal point must be confi gured in your PLC ladder logic program. Place a check mark in the box next to PLC Controlled Decimal Point and then enter the PLC Address where the control resides. (This is DATA

1 only — you cannot confi gure PLC Control for a DATA 2 or DATA

3 embedded value.)

If PLC control for the decimal point is enabled, the program will place a decimal point at the end of the characters representing the

data value in the Message Text fi eld —

1111.

in the fi gure above.

Then placing a value of 1–4 (BCD) or 1–5 (Decimal) in the PLC register will place the decimal in the appropriate location.

k. You may manually enter a decimal point in DATA 1, DATA 2 or

DATA 3, by placing your cursor in the message where you want it to appear in the value, and then insert the decimal point as shown below.

l. Create Folders to group messages relating to the same topic. The fi rst message or folder you program will appear on the fi rst line of the EZText Enhanced Panel display when it is in Run Mode.

(Second programmed message displays on second line, etc., up to four lines, depending on the type of panel you are using.) The

Local Message and Folder menu tree can have up to 3 levels as shown in the following example.

EZ-TEXT-M-E

User’s Manual

m. To add a folder, click on the Add Local Folder button.

n. To insert a Message or Folder between already configured messages, you must fi rst have a message or folder highlighted. click on Insert Folder or Insert Message. The inserted Message or

Folder will be placed above the highlighted Message or Folder.

o. To delete a Message or Folder, click on it to highlight it and then click on the Delete button.

p. To save your messages and exit the Message Edit window, click on the OK button at the bottom of the Message Edit window. To exit without saving, click on the Cancel button.

Message LED will illuminate to show the operator that the PLC has triggered the message. To program a PLC Message, click on the Add

Next PLC Message button.

EZ-TEXT-M-E

a. Type in text up to 20 characters in the Message Text fi eld. The

20 character maximum includes Data Items, also, if you choose to enter them. You will see the Message Length value change as

75

User’s Manual

you enter characters to let you know how many you have used. The current Message Number and Total Number of Messages (of

76

256) programmed are also displayed for your information.

b. If you want to embed data values from a PLC register in the message, press F5 or (Ctrl+1) for DATA 1, F6 or (Ctrl+2) for DATA 2, or F7

or (Ctrl+3) for DATA 3. Each press of the function key will enter 1

data value character. You may enter up to 5 characters depending on the data type you have selected.

c. You will confi gure Data 1, Data 2, and Data 3 values the same way as described in a Local Message.

d. If you have confi gured messages out of sequence and you want to insert a message between messages already programmed, click on Insert a PLC Message. Be aware that blank messages count in the Total Messages allowed.

EZ-TEXT-M-E

User’s Manual

For example:

You have programmed PLC Messages numbered 001, 002 and

004, skipping PLC Message number 003, as shown below.

Click on 004: PLC Message 4 in the message fi eld to highlight it, and then click on the Insert a PLC Message button. PLC Message

Number 003 will appear above PLC Message Number 004 and you may enter the new message.

Be aware that when programming messages out of sequence, that the “blank” messages are counted in the Total Messages allowed.

The following “ CAUTION” message will appear when you enter a message number higher than the next number in sequence.

EZ-TEXT-M-E

If you have skipped more than one message number (e.g., you have programmed messages 1 through 4, skipped messages 5, and 6, and then programmed 7), and highlight message 7 and click on

77

User’s Manual

Insert a PLC message, the following dialog box will appear asking you to enter the number (e.g., 5 or 6) of the message you want to insert.

e. To delete a message, click on it to highlight and then click on the Delete button.

21. To view the PLC Addresses you have programmed click on the Panel

PLC Address Database button. The following window will open.

78

Shown here will be the addresses mapped to the panel display lines

(Line one, Line two, etc.), the Bit Write (Buttons), Bit Read (LEDs), and the PLC Message Data Items. Items grayed out are not available for the EZText Enhanced Panel model you have selected. The PLC/

controller you have selected and the Project Name are also displayed, along with the Total Number of messages (OUT OF 256) programmed.

This is for information only—to edit the addresses, click on the EDIT

PANEL SYSTEM PLC ADDRESSES button.

Click Print button to print the database or the OK button to exit.

EZ-TEXT-M-E

User’s Manual

Confi gure Existing System

1. Click on the EZText Enhanced Icon to open the EZText Enhanced

Programming Software. The following screen will appear.

EZ-TEXT-M-E

Click Existing System button to edit an EZText Enhanced program. The following screen will appear.

3. Select the project you want to edit from the default program directory or navigate to where the project resides. Click on it to highlight, and then click on the Open button and the project you have selected will open to the Main Confi guration Screen.

4. Begin editing your project.

79

User’s Manual

Connect to Panel, View Panel Status and Firmware Version

80

Click on the Connect to Panel, View Panel

Status & Firmware Version button to view the panel status. The Panel Status window will open. An example is shown below.

Picture of the panel type you are connected to

Key features of the current panel

Panel and PLC information is displayed, including panel model,

Firmware Revision, Memory Size,

PLC Driver, and PLC Driver Revision number

EZ-TEXT-M-E

User’s Manual

Upgrade Firmware

There may be occasional upgrades to the EZText Enhanced internal software, also referred to as the Exec or Firmware. Check the EZAutomation web site periodically for information about software and fi rmware upgrades.

To Upgrade Firmware:

1. Place the panel in Setup Mode by pressing the UP/DOWN arrows on the EZText Enhanced Panel simultaneously.

screen will appear.

EZ-TEXT-M-E

3. Click on the Browse button. The window, shown to the right, will open to the default folder, Firmware (located in the EZText Enhanced

Program directory). If the fi rmware fi le has been downloaded from the

EZAutomation website to another location, navigate to the new fi rmware fi le (.hex fi le).

81

User’s Manual

There are fi ve types of fi rmware fi les (.hex) for the different types of

EZText Enhanced Panels: EZ220xy — for the EZ-220 & EZ-220V panels; EZ220Lxy — for the EZ-220L panel; EZ420xy — for the EZ-420 panel; EZ220Pxy — for EZ-220P & EZ-220PV panels (not covered in this manual); and the EZSPPxy —for the EZ-SP Set Point Panel (also, not covered in this manual). The “x” represents the major revision of the fi rmware (e.g., A). “y” represents the minor revision (e.g., 1). Make

sure that you select the correct fi rmware.hex fi le for your type panel, and send the upgrade to the panel.

4. Select the appropriate COM port under Port Selected (if necessary) and click on the Start button to begin downloading the fi rmware to the EZText Enhanced Panel. A status bar will let you know when the upgrade is complete. Click on Close when complete.

82

When you initialize the Upgrade Firmware process, the EZText Enhanced Panel

Message display will read SELF TESTING. When the download begins, the display will read LOADING EXEC. When the download is complete, the panel will enter the Run Mode.

If the message INCOMPATIBLE EXEC is displayed on the panel while the

Upgrade is in process, it means that the wrong fi rmware fi le has been sent to the panel. You will also receive an error message from the EZText Enhanced

Programming Software, as shown below. If this happens, do the following:

EZ-TEXT-M-E

User’s Manual

on OK button on the Error Message.

on Cancel button on the Downloading Firmware window.

select the correct fi rmware.hex fi le.

Upgrade Firmware, when you press the Start button, the panel will display SELF

TESTING while the upgrade is initializing.

When the download begins, the panel will display LOADING

EXEC.

I f y o u g e t t h e m e s s a g e ,

INCOMPATIBLE EXEC, you have sent the wrong fi rmware fi le. Exit all windows and start the Upgrade

EZ-TEXT-M-E

83

User’s Manual

This page intentionally left blank.

84

EZ-TEXT-M-E

Maintenance

& Troubleshooting

In this chapter....

Maintenance

— Fuse Reset

— Screen Overlay Cleaning

Troubleshooting

— Panel Confi guration Problems

— PLC Errors

— Warranty Repairs

— Out of Warranty Repairs

— Frequently Asked Questions (FAQs)

6

User’s Manual

Maintenance

Fuse Reset

The EZText Enhanced Panel features an AUTO-RESET fuse (0.65 Amp polyfuse). It is reset by removing power for 5 minutes and then reapplying power to the unit.

Precautions

To ensure the longevity and effectiveness of the EZText Enhanced Panel, please take note of the following precautions:

• Do not press sharp objects against the pushbuttons or screen overlay.

• Do not strike the panel with hard objects.

• Do not press the pushbuttons or screen overlay with excessive force.

• Once the panel is mounted and has power applied, do not place any objects over the ventilation slots. This will result in heat buildup and may damage the unit.

Screen Overlay/ Chemical Compatibility

The screen overlay has a polycarbonate surface. The following list is provided to make you aware of the general compatibility between chemicals that may be present in your work environment and the polyester surface of the overlay. Use the chart to determine those chemicals that are safe to use around your EZText

Enhanced Panel and those that may harm the overlay. The list rates these chemicals as E—Excellent, G—Good, F—Fair, and N—Not Recommended.

Because the ratings are for conditions at 134 °F (57°C), co

Screen Overlay Cleaning

CHEMICAL RATING

Acetaldehyde N

Acetamide N

Acetic Acid @ 5%

Acetic Acid @ 50%

G

G

Acetone N

Acetonitrile N

Acrylonitrile N

Adipic Acid E

Alanine N

Allyl Alcohol F

Alum. Hydroxide

Aluminum Salts

N

G

Amino Acids E

Ammonia N

Ammonium Acetate E

Ammonium Gloclate F

CHEMICAL RATING

Ammonium Hydroxide @ 5%

Ammonium Hydroxide @ 30%

Ammonium Oxalate

Ammonium Salts n-Amyl Acetate

Amyl Chloride N

Aniline N

Benzaldehyde N

Benzene N

Benzoic Acid G

N

N

E

G

N

Benzyl Acetate

Benzyl Alcohol

G

G

Bromine F

Bromobenzene N

Bromoform N

Butadiene N

86

EZ-TEXT-M-E

CHEMICAL RATING

n-Butyl Acetate n-Butyl Alcohol sec-Butyl Alcohol tert-Butyl Alcohol

Butyric Acid

Calcium Hydroxide

Calcium Hypochlorite

Carbazole N

Carbon Disulfi de N

Carbon Tetrachloride N

Cedarwood Oil

Cellosolve Acetate

F

N

N

F

F

F

N

N

N

Chlorine @ 10% in air

Chlorine @ 10% moist

Chloroacetic Acid p-Chloroacetophenone N

Chloroform N

G

F

N

Chromic Acid @ 10%

Chromic Acid @ 50%

Cinnamon Oil

Citric Acid @ 10% G

Cresol N

N

N

F

Cyclohexane G

Decalin N o-Dichlorobenzene N p-Dichlorobenzene N

Diethyl Benzene N

Diethyl ether

Diethyl Ketone

Diethyl Malonate

Diethylene Glycol

Diethylene Glycol Ethyl Ether

N

N

N

F

N

Dimethylformamide N

Dimethyl Sulfoxide N

1, 4-Dioxane F

Dipropylene Glycol F

Ether N

Ethyl Acetate

Ethyl Alcohol

Ethyl Alcohol @ 40%

Ethyl Benzene

Ethyl Benzoate

N

G

G

N

N

Ethyl Butyrate

Ethyl Chloride Liquid

Ethyl Cyanoacetate

Ethyl Lactate

Ethylene Chloride

Ethylene Glycol

Ethylene Glycol Methyl Ether

N

N

F

N

N

N

N

EZ-TEXT-M-E

User’s Manual

CHEMICAL RATING

Ethylene Oxide N

Fluorides E

Fluorine F

Formaldehyde

Formaldehyde @ 40% G

Formic Acid @ 3%

Formic Acid @ 50%

Formic Acid @ 99%

Fuel Oil G

Gasoline F

G

G

F

Glacial Acetic Acid N

Glycerin E n-Heptane G

Hexane N

Hydrochloric Acid @ 5% E

Hydrochloric Acid @ 20%

Hydrochloric Acid @ 35%

Hydrofl uoric Acid @ 5%

Hydrofl uoric Acid @ 48%

Hydrogen Peroxide @ 5%

F

N

F

N

E

Hydrogen Peroxide @ 30%

Hydrogen Peroxide @ 90%

Isobutyl Alcohol

Isopropyl Acetate

Isopropyl Alcohol

Isopropyl Benzene N

Kerosene E

Lactic Acid @ 3% G

Lactic Acid @ 85%

Methoxyethyl Oleate

G

N

E

E

G

N

E

Methyl Alcohol

Methyl Ethyl Ketone

Methyl Isobutyl Ketone

Methyl Propyl Ketone

Methylene Chloride

Mineral Oil

Nitric Acid @ 10%

Nitric Acid @ 50%

Nitric Acid @ 70% N

Nitrobenzene N

G

G

F

F

N

N

N

N n-Octane F

Orange Oil F

Ozone G

Perchloric Acid N

Perchloroethylene N

Phenol Crystals

Phosphoric Acid @ 5%

Phosphoric Acid @ 85%

Pine Oil

N

E

G

E

87

CHEMICAL RATING

Potassium Hydroxide @ 1%

Potassium Hydroxide conc.

Propane Gas

Propylene Glycol

Propylene Oxide

Resorcinol sat.

Resorcinol @ 5% F

Salicylaldehyde F

Salicylic Acid Powder G

Salicylic Acid sat.

Salt Solutions Metallic

G

E

N

N

N

F

F

F

Silver Acetate

Silver Nitrate

Sodium Acetate sat.

Sodium Hydroxide @ 1%

Sodium Hydroxide @ 50%+

Sodium Hypochlorite @ 15%

Stearic Acid Crystals

Sulfuric Acid @ 6%

Sulfuric Acid @ 20%

Sulfuric Acid @ 60%

F

G

E

G

F

G

E

G

N

N

User’s Manual

CHEMICAL RATING

Sulfuric Acid @ 98%

Sulfur Dioxide Liquid

Sulfur Dioxide dry

Sulfur Salts

Tartaric Acid

N

G

Tetrahydrofuran N

Thionyl Chloride N

G

N

G

Toluene N

Tributyl Citrate N

Trichloroethane N

Trichloroethylene N

Triethylene Glycol G

Tripropylene Glycol G

Turpentine N

Undecyl Alcohol F

Urea N

Vinylidene Chloride N

Xylene N

Zinc Stearate E

The EZText Enhanced Panel screen should be cleaned as needed with warm, soapy water.

Gasket Replacement

The gasket may need to be replaced if it becomes damaged or worn. To replace the gasket, use P/N EZ-TEXT-S-GSK for the small models, EZ-220 and EZ-420.

Use P/N EZ-TEXT-L-GSK for the large model (EZ-220L). To replace the gasket perform the following steps:

1. The gasket is removed and replaced from the back of the unit. Ensure that all pieces of old gasket have been removed from the panel enclosure surface where the gasket is affi xed.

2. Remove the new replacement gasket from its plastic bag.

3. Remove the temporary protective covering from the adhesive side of the gasket.

and press fi rmly.

88

EZ-TEXT-M-E

User’s Manual

Troubleshooting

In this section we will explain how to isolate potential problems. If you cannot isolate and remedy the problem using the procedures we have outlined below, call technical support. For a list of EZText Enhanced Panels, EZText Enhanced

Programming Software, and PLC Driver Error Messages, see Appendix C.

Panel Confi guration Problems

EZText Enhanced Programming Software is used to create panel applications and to download/upload panel programs. If you are online with the EZText Enhanced

Panel and communication fails, the following error message is displayed:

EZ-TEXT-M-E

If you receive this EZText Enhanced Programming Software error message, check the following:

1. On the rear panel of the unit, observe Serial Port Communication

TXD/RXD LEDs while attempting to Upload/Download a program.

Both LEDs should be slowly and alternately fl ashing to indicate that the programming PC and the panel are connected. If the TXD (transmitter)

LED is the only one fl ashing, or if the TXD/RXD LEDs are NOT alternating between fl ashes, check to ensure that the EZText Enhanced

Panel is set to the Setup (programming) Mode. (To enter the Setup

Mode, press and hold the UP Arrow Button while simultaneously pressing the DOWN Arrow button.)

2. Check to ensure that the programming cable (part number EZTEXT-

PGMCBL) is properly connected at both ends.

3. Check that the correct communications port is selected with the EZText

Enhanced Programming Software (i.e., COM1, COM2)

4. Check the 24 VDC power source and its connections.

5. After completing steps 1 through 4, above, repeat the procedure to

Upload/Download a program.

89

User’s Manual

PLC Errors

If you experience communication problems between the EZText Enhanced

Panel and your PLC, you will receive an error message that is unique to that particular PLC. Look in the Appendix C of this manual, or the EZText Enhanced

Programming Software Help for error messages for your type PLC. Each PLC

Help topic lists the error messages and provides an explanation for each PLC driver. To access the PLC Help topics, perform the following steps.

a. Run EZText Enhanced Programming Software.

b. From the Main Menu, click on Help > Help Topics.

Under Contents tab, fi nd the type PLC you are using (next to a closed book icon) and click on it to view help topics.

d. Click on Driver Errors Topic.

90

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

You may also notice that the Pushbuttons, Pushbutton LEDs, and/or Messages are not working, Check the following: are not steadily fl ashing or illuminated (depending upon the baud rate) check to ensure the proper communications cable is connected securely at both ends.

baud rate, parity, stop bits, and address number. Use the PLC manual to determine the proper settings.

3. If you have confi gured your own cable, verify cable pinout using the PLC

Wiring diagrams provided in Appendix B.

4. Check the 24 VDC power source.

5. If connected to a multiplexer, connect the panel directly to the PLC port.

6. Verify that the EZText Enhanced Panel registers are mapped correctly.

Does the EZText Enhanced Panel register exist in the PLC? Is the register Read Only? Is the register Write Only?

Still need Help?

You have two additional sources for more information other than this manual.

Visit our website at www.EZAutomation.net

Our web site contains all of this information, any new feature releases, technical support, plus much more ...

91

92

User’s Manual

Call our Technical Support Group Monday–Friday from 6 a.m. to Midnight CST at 1-877-774-EASY or FAX us at 1-877-775-EASY.

If you have any questions that you can’t fi nd an answer to, give us a call from 6 a.m. to Midnight CST at the number above and we will be glad to assist you.

Warranty Repairs

If your EZText Enhanced Panel is under warranty, contact EZAutomation @

1-877-774-EASY.

Out of Warranty Repairs

If your EZText Enhanced Panel is out of warranty, contact EZAutomation’s

Service Department for an evaluation of repair costs @ 1-877-774-EASY.

You can then decide whether it is more economical to proceed with factory repairs or purchase a new panel.

EZ-TEXT-M-E

User’s Manual

Frequently Asked Questions (FAQs) do format an address string when connecting to multiple

PLCs?

Add the PLC station number to the beginning of the address string. Ex:

PLC station is 3 and the address is V2000 the string would look like this, 3-V2000.

2. Can I convert a project from one EZText Enhanced Panel type to

another?

Yes, to do this simply change the panel type from one to another.

This will keep all address and message information intact. The only exception is switching from any of the panels to the Set Point panel.

This will cause all messages and addressing to be deleted. Note:

Switching panel types does not create a new project. If you wish to create a new project select NEW from the FILE menu.

Can connect multiple panels to a single PLC?

Yes, there are two methods of doing this. The fi rst would be to use the multiplexer (P/N EZ-MULTIDROP). You can connect up to fi ve panels per multiplexer, and one multiplexer per serial port. The second method is to connect one panel per serial port.

4. What is the maximum number of messages I can have in a

project?

The maximum amount of PLC and Local messages is 256.

EZ-TEXT-M-E

A Local Message is a text message that is used to provide instructions or information to the machine operator using a hierarchical fi le structure.

The operator can scroll through these messages using the arrow keys to fi nd information pertaining to a particular part of a process.

6. What are PLC Messages?

A PLC Message is a text message that can be triggered by the PLC to provide the operator with important instructions, information, or warnings. PLC Messages will be displayed for 3 seconds before they can be cleared in order to make sure the operator has a chance to read the message. The operator can also view the last PLC Message displayed by pressing the esc key.

7. How many characters can I have per message?

The maximum number of characters per message is 20. This is true for all messages except folder names. They are limited to 19 because of the plus “+” or minus “-” sign displayed at the beginning of the folder

93

94

User’s Manual

name. (When using the Set Point panel, the maximum number of characters per message is 16.)

8. I am using an EZ-220 panel and I can not access the password option. How do I do this?

The only panel that can have password protection is the EZ-220P. This is because the EZ-220P is the only panel that has a key pad usable for data entry.

9.

What is the maximum number of Embedded Data values I can have in a project?

10. How do I get my panel into Setup Mode?

To get the panel into Setup Mode press and hold the up arrow key while simultaneously pressing the down arrow key. To exit Setup Mode, press the ESC key.

11. How do I get my panel to display PLC Messages?

To display a PLC message, using your ladder logic, place the number of the PLC Message you wish to display into one of the PLC Message

Line Addresses (up to four if using the EZ-420). When the message number is placed in this register the panel will display the message corresponding with that number.

Example: I want to display PLC Message One on Line One of my panel display. Using the ladder logic, I write a value of 1 to register V2000, which is set as PLC Message Line Address One. The panel displays

PLC Message One on Line One of my panel display. The message will remain on the display until the ESC key is pressed.

12. Why won’t the panel display the same PLC Message twice in a row on the same message line?

This is because the message line must be reset by either setting the

Line Register to zero, or by changing the value in the Line Register to some unused PLC Message number.

The panel locks out all key presses for 3 seconds after a PLC Message is displayed in order to ensure the operator has a chance to read the message. Pressing ESC 3 seconds after the PLC Message is displayed will display the local message screen.

EZ-TEXT-M-E

EZ-TEXT-M-E

User’s Manual

14. Do the EZText Enhanced Panels support discrete addresses?

No, the EZText Enhanced Panels do not support discrete addresses.

All addressing for the EZText Enhanced Panels must be in Word format.

do insert a PLC Message?

In order to insert a PLC Message, there must be a gap in the message numbers. For example, I have PLC Message #1 and PLC Message

#3 programmed. If I click on PLC Message #3 and click the INSERT A

PLC MESSAGE button, PLC Message #2 will be inserted between PLC

Messages 1 and 3.

16. Can I renumber PLC Messages?

Yes, you can renumber PLC Messages; however, when changing a message number to a higher message number, all unused lower message numbers will be sent as “blank” messages when the project is transferred to the panel. Blank messages will count towards the maximum number of allowed messages in a project (256).

Yes, you can copy and paste messages. Currently, however, you can copy or paste only one message at a time.

18. It is hard to read the display on my panel. It’s too bright. Is there a

way to adjust the contrast?

Yes, to adjust the contrast on the display, simply place the panel into

Setup Mode. While in Setup Mode you can use the up and down arrow keys to adjust the contrast.

19. How do I enter new or change existing values on my EZText

Enhanced Panel?

To enter a new value, or change an existing value on the EZText

Enhanced Panel, simply move the cursor (using the arrow keys) to the message you want to edit. Once the cursor is on the message, press the ENTER key on your EZText Enhanced Panel. This will move the cursor to the data set and allow you to change the value. Once the value is changed, press the ENTER key again to accept the new value and move the cursor back to the beginning of the message.

95

User’s Manual

This page intentionally left blank.

96

EZ-TEXT-M-E

Appendix A

In this appendix....

—EZText Enhanced Panel Application Worksheets

A

User’s Manual

EZTEXT ENHANCED PANEL APPLICATION WORKSHEET

PROJECT NAME: _________________

________________________________

PLC CONFIGURATION:

PLC MANUFACTURER: _____________

PLC Model: _______________________

PLC Protocol: _____________________

PLC Address: _____________________

PLC Timeout: _____________________

PANEL TYPE: ____________________

Multi-Panel System Port Number:_____

(1–5 or N/A if Single Panel System)

Baud Rate: _______________________

Parity: ___________________________

Data Bits: _________________________

Stop Bits: _________________________

Checksum: _______________________

BUTTONS/LEDS

BUTTON ACTION/PANEL ACKNOWLEDGE (BIT WRITE) PLC WORD _______________

Button Action:

(PLC Address)

F1 ____________

F2 ____________

F3 ____________

F4 ____________

F5 ____________

Mom. Alt.

Pnl Set/

PLC Rel *

* Panel Acknowledge of PLC Release:

(PLC Address)

ACK F1 _______________

ACK F2 _______________

ACK F3 _______________

ACK F4 _______________

ACK F5 _______________

LED CONTROL/PLC BUTTON RELEASE (BIT READ) PLC WORD __________________

____________________________________

____________________________________

* PLC Button Release: LED Control:

(PLC Address)

LED1 __________

LED2 __________

LED3 __________

LED4 __________

Button & Flash PLC **

LED5 __________

(PLC Address)

REL F1 _______________

REL F2 _______________

REL F3 _______________

REL F4 _______________

REL F5 _______________

____________________________________

Line 1 ___________________________

____________________________________

Line 3 ________________ (EZ-420 only)

Line 2 ___________________________

Line 4 ________________ (EZ-420 only)

* Panel Acknowledge and PLC Button Release are only used when using

the Panel Set & PLC Release Button Action.

** LED Control by PLC is the only LED function that uses a PLC Address.

A-2

User’s Manual

EZTEXT ENHANCED PANEL APPLICATION WORKSHEET

LOCAL MESSAGES:

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

A-3

User’s Manual

EZTEXT ENHANCED PANEL APPLICATION WORKSHEET

LOCAL MESSAGES:

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Folder

Message

Level:

1 2 3 4

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

A-4

User’s Manual

EZTEXT ENHANCED PANEL APPLICATION WORKSHEET

PLC MESSAGES:

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

A-5

User’s Manual

EZTEXT ENHANCED PANEL APPLICATION WORKSHEET

PLC MESSAGES:

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

Message

No._________

DATA 1 __________________________

PLC Decimal ________

___________________

DATA 2 ________ DATA 3

Read Only

Read/Write

Min Max

A-6

Appendix B

In this appendix....

—Cable Wiring Diagrams for the following PLCs

B

Aromat

DeviceNet

Ethernet

Idec

Mitsubishi

Modicon

Omron

Siemens

Uni-Telway

User’s Manual

Wiring Diagrams

The following diagrams depict the wiring pinouts for the EZText

Enhanced Panel to PLC Cables. If EZAutomation provides the cable, the part number is included with the description. Wiring diagrams for some PLCs are provided so that you may construct your own cable.

Allen-Bradley SLC DF1 RS-232 ( P/N EZP-SLC-232-CBL)

Allen-Bradley PLC5 DF1 RS-232 ( P/N EZP-PLC5-232-CBL)

B-2

User’s Manual

Allen-Bradley Micrologix 1000/1200/1500 RS-232

( P/N EZP-MLOGIX-CBL)

DirectLogic PLC RJ-12, D05, DL105, DL205, DL350, and DL450, RS-232

( P/N EZP-2CBL)

B-3

User’s Manual

DirectLogic PLC 15-pin D-SUB, DL405 RS-232 ( P/N EZP-4CBL-1)

DirectLogic PLC VGA 15-pin , 250, RS-232 ( P/N EZP-2CBL-1)

B-4

User’s Manual

DirectLogic PLC RJ-11 , 340, RS-232 ( P/N EZP-3CBL)

DirectLogic PLC 25-pin D-SUB, DL405, 350, 305 DCU, and all DCMs RS-232

( P/N EZP-4CBL-2)

B-5

User’s Manual

General Electric 90/30 and 90/70 15-pin D-SUB RS-422

( P/N EZP-90-30-CBL)

Mitsubishi FX Series 25-pin RS-422 ( P/N EZP-MITSU-CBL)

B-6

User’s Manual

Mitsubishi FX Series 8-pin MINI-DIN RS-422 ( P/N EZP-MITSU-CBL-1)

Modicon ModBus 9-Pin D-SUB RS-232 (P/N EZP-MODRTU-CBL)

B-7

User’s Manual

Omron C200, C500 RS-232 ( P/N EZP-OMRON-CBL)

Siemens S7 MPI Adaptor (P/N EZP-S7MPI-CBL)

B-8

User’s Manual

Control Techniques Unidrive 4-wire, RS-422, D-Sub Female 9 position

(P/N EZP-CTRLUNI-CBL)

The hardware connection for the Control Techniques Unidrive PLCs is RS-422 (4-wire).

B-9

User’s Manual

Control Technology Corporation (CTC) PLC, RS232, RJ-12 Port

(P/N EZP-CTCBI-CBL)

The hardware connection for the CTC2600 and CTC2700 is RS-232C.

Texas Instruments 505 Series PLC, RS-232C, D-Sub Female 9 pin

(P/N EZP-TX505-CBL)

B-10

User’s Manual

Texas Instruments 545-1102 Series PLC, RS-422A, D-Sub Male 9 pin

(P/N EZP-TX545-CBL)

Texas Instruments 545-1104 Series PLC, RS-422A, D-Sub Female 9 pin

(P/N EZP-TX545-CBL1)

B-11

User’s Manual

Idec MicroSMART PLC, RS232, 8 pin Mini DIN Male

(P/N EZP-IDECS-CBL)

B-12

User’s Manual

Aromat PLC, RS232, Mini DIN 5-pin Male Connector

(P/N EZP-ARCOL-CBL)

EZAutomation EZPLC 9-Pin D-SUB RS-232 (P/N EZP-CBL)

B-13

B-14

User’s Manual

This page intentionally left blank.

Appendix C

In this appendix....

—PLC Driver Error Messages

—EZText Enhanced Panel Error Messages

—EZText Enhanced Programming Software

C

User’s Manual

PLC Driver Error Messages

ALLEN-BRADLEY PLCs

Driver Errors for Micrologix/SLC 500 with DF1 Half Duplex Protocol

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have incompatible revision.

0x0002 PLC error incorrect map size

This error occurs when an incompatible map is loaded into the unit. The driver will not attempt to communicate with the PLC when this occurs.

0x0004 Limit of elements per screen exceeded

This occurs when there are too many registers on the display that can be monitored.

0x0008 PLC MSG time-out CMD=X

This error occurs when the unit does not receive a reply to its command. The unit will retry a command and wait for the specifi c time-out period before reporting this command. The command ID causing this error is reported. CMD 0xAA=READ CMD 0XA2=WRITE.

0x0010 Invalid PLC attributes - using defaults

This will occur if the PLC driver receives an invalid set of attributes. The default attributes will be used when this occurs.

0x0020 PLC bad checksum CMD=X

This occurs when a reply with an invalid checksum is received by the unit. The command ID of the command that incurred the error is reported as part of the message. CMD 0XAA=Read CMD 0XA2=Write.

0x0040 PLC Error STS=XX EXTSTS=XX CMD=ZZ

This is reported when a controller responds to a command with an error. The error code is shown and can be looked up in the Allen-Bradley documentation. The command ID of the command causing the error is reported. CMD 0XAA=Read, CMD 0XA2=Write.

0x0080 PLC Nack Error

This error is reported when a controller responds to a command with a negative acknowledgment.

0x0100 PLC element read-only

This is reported when an attempt is made to write to an element with a read-only map entry. Read-only map entries are: input fi le, output fi le, and all discrete entries. The driver can only read discrete entries, it cannot write to a single bit within a word.

0x0200 PLC TX buffer full

The error is reported if the transmit buffer becomes full in the PLC driver.

C-2

User’s Manual

0x0400 PLC error no reply

This occurs when the DF1 modules indicate the PLC has no reply to the last message. It is usually displayed when the unit reestablishes communications after a PLC message time-out error. This can also occur when the panel message time-out is too short. If the PLC message time-out does not give the PLC enough time to respond to the message this error will be displayed.

0x0800 Error code xx

This is reported when the PLC driver encounters an unknown error. This should never occur.

Driver Errors for PLC5 with DF1 Protocol

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 PLC error incorrect map size

This error occurs when an incompatible map is loaded into the unit. The driver will not attempt to communicate with the PLC when this occurs.

0x0004 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to be monitored. The number of registers on the display must be reduced.

0x0008 PLC MSG Time-out CMD=X

This occurs when the unit does not receive a reply to its command. The unit will retry a command and wait for the specifi ed time-out period before reporting this command. The command ID causing the error is reported.

0x0010 Invalid PLC attributes - using defaults

This error is reported when the PLC driver receives an invalid set of PLC attributes. The default attributes will be used when this error occurs.

0x0020 PLC Bad checksum CMD=X

This error occurs when a reply with an invalid checksum is received by the unit. The command ID of the command that incurred the error is reported as part of the message.

0x0040 PLC Error STS=xx EXTSTS=yy CMD=zz

This error is reported if a controller responds to a command with an error. The error code is shown and can be looked up in the Allen-Bradley documentation. The command ID of the command causing the error is reported.

0x0080 PLC Nack Error

This error is reported if a controller responds to a command with a negative acknowledgment error.

C-3

User’s Manual

0x0100 PLC Element Read Only

This error is reported if an attempt is made to write to an element with a read only map entry. Read only map entries are: INPUT fi le, OUTPUT fi le, and the control word of TIMERS, COUNTERS, and CONTROL structures.

0x0200 PLC Transmit Buffer Full

The error is reported if the transmit buffer becomes full in the PLC driver.

0x8000 Error Code XX

This error is reported when the PLC driver encounters an unknown error. This should never occur.

Time-outs

This specifi es the amount of time the EZText Enhanced Panel will wait for a reply to a message before triggering an error. Each message sent to the PLC must be acknowledged by the PLC. The acknowledgment must be received within the time-out period. After the message has been sent twice with no response, the time-out message will be displayed.

Driver Errors for Micrologix/SLC 500 with DF1 Full Duplex Protocol

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have incompatible revision.

0x0002 PLC error incorrect map size

This error occurs when an incompatible map is loaded into the unit. The driver will not attempt to communicate with the PLC when this occurs.

0x0004 Limit of elements per screen exceeded

This occurs when there are too many register on the display that can be monitored.

0x0008 PLC MSG time-out CMD=X

This error occurs when the unit does not receive a reply to its command. The unit will retry a command and wait for the specifi c time-out period before reporting this command. The command ID causing this error is reported. CMD 0xAA=READ CMD 0XA2=WRITE.

0x0010 Invalid PLC attributes - using defaults

This will occur if the PLC driver receives an invalid set of attributes. The default attributes will be used when this occurs.

0x0020 PLC bad checksum CMD=X

This occurs when a reply with an invalid checksum is received by the unit. The command ID of the command that incurred the error is reported as part of the message. CMD 0XAA=Read CMD 0XA2=Write.

C-4

User’s Manual

0x0040 PLC Error STS=XX EXTSTS=XX CMD=ZZ

This is reported when a controller responds to a command with an error. The error code is shown and can be looked up in the Allen-Bradley documentation. The command ID of the command causing the error is reported. CMD 0XAA=Read, CMD 0XA2=Write.

0x0080 PLC Nack Error

This error is reported when a controller responds to a command with a negative acknowledgment.

0x0100 PLC element read-only

This is reported when an attempt is made to write to an element with a read-only map entry. Read-only map entries are: input fi le, output fi le, and all discrete entries. The driver can only read discrete entries, it cannot write to a single bit within a word.

0x0200 PLC TX buffer full

The error is reported if the transmit buffer becomes full in the PLC driver.

0x0400 PLC error no reply

This occurs when the DF1 modules indicate the PLC has no reply to the last message. It is usually displayed when the unit reestablishes communications after a PLC message time-out error. This can also occur when the panel message time-out is too short. If the PLC message time-out does not give the PLC enough time to respond to the message this error will be displayed.

0x0800 Error code xx

This is reported when the PLC driver encounters an unknown error. This should never occur.

DIRECTLOGIC PLCS

K-Sequence Protocol/Direct Logic PLC Models: DL05, DL105, D2-230, D2-240, D2-

250, D3-350, D4-430, D4-440, D4-450

0x0000 No Error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded.

This occurs when there are too many registers on the display to monitor.

0x0004 Invalid Checksum

This error occurs when a message with an invalid checksum is received by the unit. The unit is receiving invalid data.

C-5

User’s Manual

0x0008 Protocol Error

The driver has received a serial communications protocol error from the PLC. The driver is unable to communicate with the PLC when this error occurs.

0x0040 PLC Error Incorrect Map Size

An incompatible map has been loaded into the unit. The driver will not attempt to communicate with the

PLC when this error occurs.

0x0080 Invalid write to panel register nnn

A write was attempted to the panel’s internal register nnnn when that register is mapped to a read-only location in the PLC.

0x0100 PLC Communications Timeout

The panel is unable to communicate with the PLC.

0x0200 Invalid attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

DirectNet Protocol (except DL330/340)/ Direct Logic PLC Models: DL05, D2-240,

D2-250, D2-240/250 DCM, D3-350, D3-350 DCM, D4-430, D4-440, D4-450, DL405

Series all with DCM

0x0000 No Error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded.

This occurs when there are too many registers on the display to monitor.

0x0004 Invalid Checksum

This error occurs when a message with an invalid checksum is received by the unit. The unit is receiving invalid data.

0x0008 Protocol Error

The driver has received a serial communications protocol error from the PLC. The driver is unable to communicate with the PLC when this error occurs.

0x0040 PLC Error Incorrect Map Size

An incompatible map has been loaded into the unit. The driver will not attempt to communicate with the

PLC when this error occurs.

0x0080 Invalid write to panel register nnn

A write was attempted to the panel’s internal register nnnn when that register is mapped to a read-only location in the PLC.

0x0100 PLC Communications Timeout

The panel is unable to communicate with the PLC.

C-6

User’s Manual

0x0200 Invalid attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

ModBus (Koyo Addressing) RTU Protocol/Direct Logic PLC Models: DL05, D2-250,

D3-350, D4-450

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to monitor.

0x0004 Reply received from invalid slave nnn

If the driver received a message from a PLC with address nnn when one was not expected.

0x0008 Invalid Checksum Received

This error occurs when a message with an invalid checksum is received by the unit.

0x0010 Incorrect Reply

The driver received an incorrect or unexpected reply from the PLC with address nnn.

0x0020 Error - PLC nnn - <error>

The driver received a ModBus message exception code from the PLC. The <error> strings are:

The PLC received an invalid function code.

The address requested is not allowable for the PLC. This may appear instead of a time-out when a PLC is in bridge mode to a ModBus Plus network. The PLC that the Panel is communicating with will return this error if the message could not be passed on to the addressed PLC.

Illegal Data Value

The value in the data fi eld is not allowed for the PLC.

Slave Device Failure

An unrecoverable error occurred in the PLC.

Acknowledge

The PLC requires more time to process the message.

The PLC is processing a long command and is not ready for a new one.

The PLC cannot perform the function requested.

Memory Parity Error

An error was detected in the PLC memory.

C-7

User’s Manual

0x0040 Broadcast not allowed in read command

If a broadcast message to read was attempted.

0x0080 PLC time-out - PLC nnn

The EZText Enhanced Panel is unable to communicate with the PLC with address nnn. This may be corrected by increasing the time-out time or increasing the baud rate. An alternative may be to lower the number of registers or coils per message. This causes the panel to use smaller messages, that the PLC should be able to respond to at a faster rate.

0x0100 PLC reply length exceeded - PLC nnn

The driver received, or is receiving a message with a length exceeding the maximum allowed by ModBus protocol from the PLC with address nnn.

0x0200 Invalid write to panel register nnn

A write was attempted to the panel’s internal register nnnn when that register is mapped to a read-only location in the PLC.

0x0400 Invalid attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

DirectNet Protocol DL330, DL340/Direct Logic PLC Models: D3-330/330P, D3-340

0x0000 No Error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded.

This occurs when there are too many registers on the display to monitor.

0x0004 Invalid Checksum

This error occurs when a message with an invalid checksum is received by the unit. The unit is receiving invalid data.

0x0008 Protocol Error

The driver has received a serial communications protocol error from the PLC. The driver is unable to communicate with the PLC when this error occurs.

0x0040 PLC Error Incorrect Map Size

An incompatible map has been loaded into the unit. The driver will not attempt to communicate with the PLC when this error occurs.

0x0080 Invalid write to panel register nnn

A write was attempted to the panel’s internal register nnnn when that register is mapped to a read-only location in the PLC.

C-8

User’s Manual

0x0100 PLC Communications Timeout

The panel is unable to communicate with the PLC.

0x0200 Invalid attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

GENERAL ELECTRIC PLCS

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to monitor.

0x0004 PLC Time-out - X = YYYYY

This error results from a loss of communication with a PLC. The X shown stands for the PLC that timed out.

This will be a number one through 16 or default. The YYYYY stands for the actual SNP-X ID string entered for the PLC that timed out. If the SNP-X ID string is a null string, the space after the equal sign will be the last character in the error string.

0x0008 Invalid PLC Attributes - using default

The attributes passed from the program loader, or the existing attributes in memory do not match those expected by the driver. The default attributes will be used and normal operations will commence.

0x0010 Invalid Write to panel register xxx

There was an attempted write to panel internal register number xxx which is mapped to an address which has read-access only.

0x0020 PLC Message Error

A communications error occurred which resulted in an invalid message. It could also indicate that an address was requested which is out of the range limits of the PLC.

0x0040 Incorrect Map Size

This error occurs when a map is stored that is not the size the PLC expects.

MITSUBISHI PLCs

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have incompatible revision.

0x0002 Limit of elements per screen exceeded

This occurs when there are too many elements on the display to monitor.

C-9

User’s Manual

0x0004 Communications Error

This error occurs when there is an error involving communications between the panel and PLC. A communications error results from one of the following: no or bad physical connection between panel and

PLC, bad checksum in reply from the PLC, bad checksum in command from the panel, bad command from the panel, bad format of command from the panel, or unexpected reply from the PLC.

0x0010 Invalid Write - Panel register : xxxx

This error will occur when an attempt to write to a read only MFX element. The panel register xxxx contains the address of the MFX element that is read-only.

0x0020 PLC Message Time-out

This message occurs when the unit does not receive a reply to its command. The unit will retry a command and wait for the specifi ed time-out period before reporting this command.

0x0040 Invalid PLC attributes - using defaults

This error is reported when the PLC driver receives an invalid set of PLC attributes. The default attributes will be used when this error occurs.

Timeouts

The timeout time specifi es the amount of time the panel will wait for a reply to a message before triggering an error. Each message sent to the PLC must be acknowledged by the PLC. The acknowledgment must be received within the time-out period. If the acknowledgment is not received the driver will retry the command. After the message has been sent twice with no response, the time-out error message will be posted.

MODICON PLC WITH MODBUS RTU PROTOCOL

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to be monitored. The number of registers on the display must be reduced.

0x0004 Reply received from invalid slave nnn

If the driver received a message from a PLC with address nnn when one was not expected.

0x0008 Invalid Checksum Received

This error occurs when a message with an invalid checksum is received by the unit.

0x0010 Incorrect Reply

The driver received an incorrect or unexpected reply from the PLC with address nnn.

0x0020 Error - PLC nnn - <error>

The driver received a Modbus message exception code from the PLC. The <error> strings are:

C-10

User’s Manual

The PLC received an invalid function code.

The address requested is not allowable for the PLC. This may appear instead of a time-out when a PLC is in bridge mode to a Modbus Plus network. The PLC that the EZText Enhanced Panel is communicating with will return this error if the message could not be passed on to the addressed

PLC.

Illegal Data Value

The value in the data fi eld is not allowed for the PLC.

Slave Device Failure

An unrecoverable error occurred in the PLC.

Acknowledge

The PLC requires more time to process the message.

The PLC is processing a long command and is not ready for a new one.

The PLC cannot perform the function requested.

Memory Parity Error

An error was detected in the PLC memory.

0x0040 Broadcast not allowed in read command

If a broadcast message to read was attempted.

0x0080 PLC time-out - PLC nnn

The EZText Enhanced Panel is unable to communicate with the PLC with address nnn. This may be corrected by increasing the time-out time or increasing the baud rate. An alternative may be to lower the number of registers or coils per message. This cause the EZText Enhanced Panel to use smaller messages, which the PLC should be able to respond to at a faster rate.

0x0100 PLC reply length exceeded - PLC nnn

The driver received, or is receiving a message with a length exceeding the maximum allowed by Modbus protocol from the PLC with address nnn.

0x0200 Invalid write to Panel register nnn

A write was attempted to the EZText Enhanced Panel’s internal register nnnn when that register is mapped to a read-only location in the PLC.

0x0400 Invalid attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

OMRON HOST LINK PLCs

0x0000 No error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

C-11

User’s Manual

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to monitor.

0x0004 Incorrect Unit Response

This will occur when there are too many registers on the display to be monitored. The number of registers on the display must be reduced.

0x0008 PLC Invalid Checksum received

An invalid checksum was received in a message from the PLC.

0x0010 Incorrect reply received

The driver received an incorrect reply from a PLC.

0x0020 Response to an undefi ned command

The driver received the undefi ned command response.

0x0040 Command cc Error Response Code xx

This error occurs when a response code xx is returned to a PLC message command of cc.

0x0080 Incorrect Map Size

This error occurs when an incorrect map is stored that is not the correct map entry size the driver expects.

0x0100 Invalid Write to EZText Enhanced Panel register r

This error occurs when an attempt is made to write to a register r when r is mapped to read-only element.

0x0400 PLC Message Time-out

This error occurs when a no reply or error is seen within the time-out time in the EZText Enhanced Panel

PLC attributes. If the EZText Enhanced Panel is displaying time-out errors, the timeout may need to be increased.

0x2000 Invalid PLC attributes - using defaults

The driver received attributes it could not use. The default values for all PLC attributes will be used.

Siemens 7 MPI Adapter PLCs

Please Note: If the panel is disconnected from the HMI adapter, and then reconnected, it may take up to

70 seconds for the panel to regain communications and become synchronized with the adapter.

0x0000 No Error

0x0001 Incompatible Revision

This error will be displayed when the driver and exec have an incompatible revision.

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to monitor.

C-12

User’s Manual

0x0008 Protocol Error

The driver has received a serial communications protocol error from the PLC. The driver is unable to communicate with the PLC when this error occurs.

0x0040 PLC Error Incorrect Map Size

An incompatible map has been loaded into the unit. The driver will attempt to communicate with the PLC when this error occurs.

0x0080 Invalid Write to Panel register nnnn

A write was attempted to an internal Panel register number nnnn that has been mapped as a read-only location.

0x0100 PLC Communication Timeout

The Panel is unable to or has lost communication with the PLC.

0x0200 Invalid PLC Attributes - Using Defaults

The panel has received invalid attributes. The default attributes for all PLC attributes will be used.

0x1000 COMMAN_TRANS_ERROR

This error occurs when the PLC detects an error condition. Consult the PLC Communication Error

Responses List.

C-13

User’s Manual

EZText Enhanced Panel Error Messages

READ ONLY VALUE

This message indicates that the operator has tried to edit to a read only data item.

INVALID

This message indicates that the operator has entered an illegal password.

NO DATA SET

This message indicates that the operator has tried to enter a data item in a message that contains no data items.

OUT OF RANGE

This message indicates that the operator has entered a value in a data item that is out of range.

C-14

User’s Manual

EZText Enhanced Programming Software Error Messages

Error Codes are divided into categories and are numbered with prefi xes and 3 digits as follows:

PLC DLL Errors Pxxx

Communications Errors Cxxx

Tag Errors Txxx

Message Errors Mxxx

Errors

PLC DLL Error Messages:

Error P001: Load dll Procedure failed. Unable to validate PLC address. Possible reason:

Unable to locate correct PLC DLL.

Reason: A PLC .dll fi le has been moved or deleted from the program directory.

Solution: Reinstall the software.

Error P002: Unable to load library : PlcUtils.dll

Error P003: Unable to load PLC dll.

Error P004: Unable to unload PLC dll.

Error P005: PLC DLL load failed.

Reason: Unable to load selected PLC dl.

Solution: (1) Try closing all other applications and retry; (2) reboot the system; (3) reinstall the software.

Error P006: PLC1 is not compatible with PLC2. Do you want to change the PLC anyway?

Error P007: Unable to rebuild the address for new PLC.

Reason: When changing PLCs, check theaddressing in the PLC manuals to see if they are compatible

(same addressing type is followed in both PLCs). If they are not compatible, then the database is no longer valid and the addresses will have to be reentered.

Communication Error Messages:

Error C001: The panel connected to the PC is different from the confi gured one

Reason: When writing to the panel, if the panel type selected does not match the panel that the computer is physically connected to, the program loader will not upload the project.

Solution: Select appropriate panel type for the connected panel.

Error C002: Cannot Locate the Driver File

Reason: Driver fi le (*.plx) has been moved or deleted from the program directory.

Solution: Reinstall the software.

C-15

User’s Manual

Error C003: Error opening port

Reason: Either you have not selected a valid COM port available on your computer or some other program is using this port.

Solution: Select another available COM port or close the program that is using this COM port. If this does not work, reboot your system and try again.

Error C004: Error in setting communication attributes

Reason:Unable to set the attributes for the Panel to PC communciation.

Solution: Reboot the system.

Error C005: Unable to write to Panel. Possible cause: No local messages confi gured.

Reason: No local messages are confi gured. At least one local message should be confi gured before downloading the program to the panel.

Solution: Confi gure local messages.

Error C006: Error in reading the project from the panel. Project in the panel is corrupted.

Solution: Please upload the project from the computer to the panel. You cannot read the project from the panel.

Error C007: Invalid Length in Reply

Reason: Length of the panel reply buffer is less than the maximum replay length (70)

Solution: If you receive this error message consistently, please report it to technical support.

Standard reply error messages:

PLC Address Error Messages:

Error T001: PLC Address count exceeds maximum limit.

Solution: You cannot assign another PLC address. Only 300 PLC addresses can be defi ned. If you want to assign a new address, delete one or more addresses and try again.

C-16

User’s Manual

Error T002: Invalid Access Type

Reason: Access type of the specifi ed address is invald (e.g., entering a READ only address where a READ/

WRITE address type is expected.

Solution: Supply the correct address.

Error T02_1: Invalid Unit Number.

Error T02_2: Invalid Address Type.

Error T02_3: Invalid Address.

Error T02_4: Invalid Bit Number.

Error T02_5: Address in not Word Aligned (Even address is required).

Error T02_6: Address is not Word Aligned (Odd address is required).

Reason: Address entered for the PLC Address is not correct.

Solution: Specify a valid PLC address.

Error T003: The value entered is invalid.

Reason: The value entered for Minimum or Maximum fi eld is out of range.

Solution: Supply values in the range 0…9999 for BCD and 0…65535 for Binary

Error T004: Unable to open tag map fi le : <fi lename> Please choose the map fi le

Error T005: Unable to open map fi le <map fi le>

Reason: Think N Do map (.map) fi le not found.

Solution: Locate the correct map fi le.

Error T006: Error in reading PLC Addresses

Reason: Unable to generate PLC address while reading from the panel.

Solution: Project in the Panel is corrupted. Reload the project to the panel.

Error T007: Unknown access type specifi ed for PLC Address.

Reason: Invalid access type found while reading a project from disk.

Solution: Project in the Panel is corrupted. Reload the project to the panel.

Message Error Messages:

Error M001: Unable to add a new Message/Folder. Possible cause: All the available 256 messages have been programmed

Solution: Delete one or more messages or folders and try adding your message again.

Error M002: Invalid message number or this message number has already been confi gured.

Solution: Please change the message number to a valid message number and ensure that this message number was not programmed earlier.

Error M003: Cannot add a message with message number greater than 256.

Solution: Message numbers have to be numbered with the range of 1 to 256. Please enter a valid message number within this range.

Error M004: Invalid Message Number.

Solution: Valid range for message number is 1 to 256. Please enter a valid message number.

C-17

User’s Manual

Error M005: Message number is out of range.

Solution: Message number is out of range. Valid range is 1-256

Miscellaneous Error Messages:

Error Z001: Error in printing page.

Solution: (1) Check whether you have printer attached to the PC and set to Ready; (2) if still receiving this error, reboot the system and check printer to PC connection.

Error Z002: You are trying to read from an invalid fi le.

Reason: Either project fi le is corrupted or you are trying to open an non-EZText Enhanced fi le.

Solution: If the project fi le is corrupted, then, recreate the project.

Error Z003: The fi le may be corrupted.

Reason: The Exec fi le is corrupted.

Solution: If you receive this error message consistently, please report this to technical support.

Error Z004: Unable to open the PLC driver fi le.

Reason: Invalid PLC driver fi le.

Solution: If you receive this error message consistently, please report this to technical support.

Error Z005: The Maximum message length has exceeded.

Reason: Maximum message length exceeded.

Solution: Reduce length of message.

Error Z006: Unknown value type encountered while loading project. Known values are 0

(BCD) and 1 (Binary)

Reason: Invalid value type found while reading project from disk.

Solution: Project fi le in the panel is corrupted. Reload the project to the panel.

Error Z007: Discrete addresses are not allowed here.

Reason: Discrete addresses are not allowed in the EZText Enhanced Panel.

Solution: Use the correct address type.

Error Z008: Invalid Device Type

Reason: The connected equipment may not be an EZText Enhanced Panel.

Solution: Ensure that you are connected to an EZText Enhanced Panel.

Error Z009: Error in project fi le Line : <line number> Column : <column number> <fi lename>

Reason: The project fi le (XML version) is invalid.

Solution: Use a valid project fi le.

C-18

User’s Manual

AROMAT PLC WITH MEWTOCOL COM PROTOCOL

Error 0: NO_ERROR

Screen Message:

N/A

OCCUR

Error 1: INVALID_ATTRIBUTES

Screen Message:

INVALID PLC ATTRIBUTES - USING DEFAULTS

Condition: If attributes do not exist or there are less than the original

Error 2: MSG_ERR

Screen Message:

Condition:

INVALID PLC RESPONCE: Txxxxx[,xxx][/BB]

The Driver did not receive the reply from the PLC that it expected.

Error 3: PLC_TIMEOUT

Screen Message:

PLC TIMEOUT

Condition: The Driver did not receive a reply to a message in the allowed time.

Error 4: BCC_ERR

Screen Message:

Condition:

CHECKSUM ERROR

Command string was not sent from the Panel to the PLC correctly, or the checksum in the message was incorrect.

Error 5: FMT_ERR

Screen Message:

Condition:

FORMAT ERROR

Command string was missing characters or some were incorrect.

Error 6: NOT_ERR

Error 7: PRO_ERR

Condition:

Screen Message:

Condition:

Command from Panel does not exist on the PLC.

PROCEDURE ERROR

Command was sent to the PLC while it was still processing an

Error 8: WRONG_STN_ERR

Screen Message:

Condition:

WRONG STATION REPLIED TO MSG

The received message contained a different station number from the message the driver sent.

Error 9: CSUM_ERR

Condition:

Error 10: INVALID_DRIVER_STATE

Condition:

The received message from the PLC had a bad checksum.

NEVER SHOULD OCCUR.

C-19

User’s Manual

Error 2:

Error 3:

Error 4:

Error 5:

Error 6:

Error 7:

Error 11: GENERAL_ERROR

Screen Message:

ERROR CODE xxx

Condition: NEVER SHOULD OCCUR.

Error 12: LAST_ERROR

Screen Message:

N/A

Condition: NEVER WOULD OCCUR

CTC PLC WITH BINARY PROTOCOL

Error 0:

Error 1:

NO_ERROR

Screen Message:

N/A

Condition: Never occur

INVALID_ATTRIBUTES

Screen Message:

Condition:

INVALID PLC ATTRIBUTES - USING DEFAULTS

The error will be displayed if attributes do not exist or there are less than the original number of attributes.

RECEIVED_BAD_CHECKSUM

Condition:

SENT_BAD_CHECKSUM

This error will be displayed if a message received from the PLC has a bad checksum.

Condition:

ILLEGAL_REG_READ

This error will be displayed if the driver sent the PLC a message with a bad checksum.

Condition:

ILLEGAL_REG_WRITE

This error will be displayed if the PLC indicated that the driver attempted to read a register with an invalid address.

Condition:

VAL_OUT_RANGE

This error will be displayed if the PLC indicated that the driver attempted to write to a register with an invalid address.

This error will be displayed if the driver attempted to write to a value than was out of range.

Condition:

MSG_ERR

Condition: This error will be displayed if the driver did not receive the reply from the PLC that it expected.

C-20

User’s Manual

Error 8:

Error 9:

Error 10:

Error 14:

Error 15:

DT_ELEM_NOT_FOUND

Condition: This error will be displayed if the driver found a tag that does not exist on the data table. For example, the Row or Column number was out of the range of the PLC’s data table limits.

PLC_TIMEOUT

Condition: This error will display if the driver did not receive a reply to a message in the allowed time.

DT_STRING_OUT_BOUNDS

Condition: This error will display if the driver found a tag that does not exist on the data table. For example, the message string included a column number that was out of the range of the PLC’s data table limits.

INVALID_DRIVER_STATE

occur.

GENERAL_ERROR

occur.

LAST_ERROR Error 16:

occur.

IDEC PLC WITH COMPUTER LINK PROTOCOL

Error 1: INVALID PLC ATTRIBUTES - USING DEFAULTS

This error is reported when the PLC driver receives an invalid set of PLC attributes.

The default attributes will be used when this error occurs.

Error 2: PLC TIMEOUT

The Driver did not receive a reply to a message in the allowed time. Check the communication between panel and PLC.

Error 3: DATA RANGE ERROR

This error occurs when response from PLC to read or write had a data range error.

Error 4: T/C PRESET CHANGE

This error occurs when response from plc for an invalid, present value is written to

Error 5: CALENDAR/CLOCK DATA

This error occurs when invalid data is sent to calendar or clock. Command was sent to the PLC while it was still processing an existing command.

C-21

User’s Manual

Error 6: WRONG STATION REPLIED TO MSG

The received message contains a different station number from the message that the driver sent from panel.

Error 7: INCORRECT CSUM FROM PLC

Error 8: BCC ERROR

The calculated Check sum from the panel did not match with the value that PLC received in a message.

Error 9: FRAME ERROR

Number of bits received by the PLC differs from the preset value (stop bit is 0 for example).

Error 10: DATA SEND/RECEIVE ERROR

Parity error or overrun error occurred on PLC.

Error 11: COMMAND ERROR

Unsupported request message is received

Error 12: PROCEDURE/DATA QUANTITY ERROR

Received request message for the panel does not match the expected data quantity of data).

TEXAS INSTRUMENTS PLC WITH SERIES 5x5 PROTOCOL

0x0000 No error

0x0002 Limit of elements per screen exceeded

This occurs when there are too many registers on the display to monitor.

0x0004 Invalid checksum received

An invalid checksum was received in a message from the PLC.

0x0008 PLC Error - Check PLC Status

The PLC has sent an error code to the Panel stating there was a problem with the program in the PLC or with the setup of the Panel.

0x0010 Communications time-out

This error will appear if there is a loss of communications. This error is based on time-out time entered in the PLC attributes.

0x0020 Panel Register xxxx is read only

This error will occur if there is an attempt to write to a read-only variable within the PLC.

0x0040 Register xxxx Address out of range

This error will occur if an attempt to read or write to a variable within the PLC that is out of range of the PLC memory.

0x0080 Register xxxx Data not found

This will occur if the data requested cannot be found within the PLC. This is an error sent by

0x0100 Invalid PLC attributes - using defaults

The driver received attributes that it could not use. The default values for all PLC attributes will be used.

C-22

User’s Manual

Index

Symbols

20-character messages, 6

20-character text strings, 4

24 VDC power, 27

24 VDC Power Supply, 5

A

abort, 12

Access, 73 access the password, 94

Accessories, 9

Accessories and Optional Equipment, 9

ACK, 31

Add Local Folder, 72

Add Local Folder button, 72

Add Local Message, 72

Add Local Message Button, 72 address, 67, 70 adhesive, 88

Adjust Display Contrast, 44 adjust the contrast, 95

Allen-Bradley PLC Cable Wiring Diagrams

Micrologix 1000/1200/1500 RS-232, B-3

PLC5 DF1 RS-232, B-2

SLC DF1 RS-232, B-2 alternate, 4, 12, 69

ANNUNCIATOR (BIT READ) PLC WORD — (TO

PANEL), 32

Annunciator Lamps, 32, 38 application, 44

APPLICATION WORKSHEET, A-2

Application Worksheets, 47

Arrow Adjustment Entry, 37, 38

Arrow buttons, 36, 39

Arrow pushbutton keys, 38

ASCII, 35

AUTO-RESET, 86

B

baud rate, 66

BCD, 36, 37, 73

Binary, 36, 73

Binary Coded Decimal, 37 binary data format, 37

Bit, 69 bit addresses, 48

EZ-TEXT-M blank messages, 77

Boot Revision, 44

Button Action, 69

Buttons (Bit Write) PLC Word, 70

BUTTONS (BIT WRITE) PLC WORD — (FROM

PANEL), 31

By Button, 12, 69

By Button & Flash, 12, 69

By PLC, 69

C

cable pinout, 91 cancel (pushbutton), 12 captive washers, 19, 20, 21

CAUTION, 77

CD ROM Drive, 5, 45 character maximum, 75

Character LCD Display with LED Backlight, 12 characters, 74, 75 per message, 93

Chemical Compatibility, 86

Cleaning, 88

Clear, 11

COM port, 82 communications, 66 parameters, 67 port, 44, 89

Communications Cable Core, 18

Confi guration, 44

Preparing for, 44 software, 4

Confi gure

Existing System, 79

New System, 64

Panel System PLC Addresses, 68

Confi gure Panel System PLC Addresses button, 68

Connect a PLC, 28 a Programming PC, 27 multiple panels, 93

Connect to Panel, View Panel Status and Firmware,

80 context sensitive onscreen help, 5

Control Keys, 73

Control Pushbuttons, 12 controls, 10, 30 convert a project, 93 copy and paste messages, 95 cover stock, 16

CPU, 44

I-1

User’s Manual

Create Custom Labels, 16

Ctrl + 1, 35, 73

Ctrl + 2, 35, 73

Ctrl + 3, 35, 73

Custom Labels, 12, 16

D

DATA 1, 73

(16-Bit Register, READ/WRITE), 33

DATA 2, 73

(16-Bit Register, READ Only), 34

DATA 3, 73

(16-Bit Register, READ only), 34 data entry, 38

Data Type, 36, 68, 73 data value, 11, 74 character, 73, 76 database, 78

Decimal Point, 34, 35, 74 fi xed placement, 37 fi xed point, 37 manually insert, 36, 74

PLC controlled, 37 value, 37 decrement, 12 default destination, 46

Delete, 75 delete a message, 78 desktop, 46 destination folder, 46

DIN Clips, 19, 22

Mounting, 22

DirectLogic controllers, 66

DirectLogic PLC, 30

Attributes, 67

DirectLogic PLC Cable Wiring Diagrams

15-pin D-SUB (P/N EZ-4CBL-1), DL40, B-4

25-pin D-SUB (P/N EZ-4CBL-2), B-5

RJ-11 (P/N EZ-3CBL), B-5

RJ-12 (P/N EZ-2-CBL), B-3, B-10

VGA 15-pin (P/N EZ-2CBL-1), 250 RS, B-4, B-13 discrete addresses, 95 input signals, 12 operations, 30

Display Contrast, 44 display PLC Messages, 94

Displaying Local Messages, 39

Displaying PLC Messages, 36

DOWN arrow, 12 download, 45

I-2

Driver Errors

ALLEN-BRADLEY PLCs, C-2

Micrologix/SLC 500 (DF1 Full Duplex), C-4

Micrologix/SLC 500 DH-485/AIC, C-2

PLC5 with DF1 Protocol, C-3

DirectLogic PLCs, C-5

DirectNet Protocol (except DL330/340), C-6

DirectNet Protocol DL330, DL340, C-8

K-Sequence Protocol, C-5

ModBus (Koyo Addressing) RTU Protocol, C-7

General Electric PLCs, C-9

MITSUBISHI PLCs, C-10

Modicon PLC (MODBUS RTU Protocol), C-10

OMRON HOST LINK PLCs, C-12

Siemens 7 MPI Adapter PLCs, C-13

Driver Revision, 44

Dynamic, 4, 13, 35, 36

Messages, 36

E

electrical ground common, 27 embed data, 72 embedded data, 35, 73 values, 33, 34, 76 embedded data value, 36

EMI emissions, 18 fi ltered power supply, 6

Noise Filter Installation, 18 enter pushbutton, 12 error message, 89, 90

Escape, 12, 44

Exec, 81

Revisions, 44

Existing System, 79 external power supply, 27

EZ Text Programming Software, 5

EZ-220, 2

EZ-220 and EZ-420 Connections and Wiring,

24, 25

EZ-220L, 2

EZ-220L-DEV, 2

EZ-220P/EZ-220P-DEV Outline Dimensions, 20

EZ-420, 2

EZ-420-DEV, 2

EZ-BRK-2, 19

EZ-TEXT_INSERTS.doc, 16

EZ-TEXTEDIT, 45

EZText Demo Project, 47

EZText Icon, 64, 79

EZTEXT PANEL APPLICATION WORKSHEET, A-2

EZ-TEXT-M

User’s Manual

LOCAL MESSAGES, A-3

PLC MESSAGES, A-5 project information, A-2

EZTEXT Panel APPLICATION Worksheet, A-5, A-6

EZText Panel Error Messages, C-14

EZText Panel model, 78

EZTEXT Panel PLC Message Worksheet, A-3, A-

4, A-5, A-6

EZText Panel Setup, 44

EZText Panel wiring diagrams, 5

EZText Programming Software Error Messages,

C-15

Communication Error Messages, C-15

Message Error Messages, C-17

Miscellaneous Error Messages, C-18

PLC Address Error Messages, C-16

PLC DLL Error Messages, C-15

EZText Programming Software Icon, 46

EZTEXT-PGMCBL, 28

EZTEXT2xy, 82

EZTEXT4xy, 82

EZTEXTSPxy, 82

EZTOUCH6-GSK, 88

EZTOUCH8-GSK, 88

F

F1 function key, 5

F5, 35, 73

F6, 35, 73

F7, 35, 73 factory repairs, 92 features, 4, 6, 30 ferrite cores, 18

File name, 65

Firmware, 81 fi xed placement, 37 folder, 39 icon, 40 status, 13

Folders, 13, 74 format, 73 format an address string, 93

Frequently Asked Questions (FAQs), 93 front panel features, 10 function key, 73

Function Pushbutton

Panel Set and PLC Release

Example, 32

Function Pushbuttons, 12

Fuse

EZ-TEXT-M

Reset, 86

G

Gasket

Replacement, 88 slot, 88

General Electric PLC Wiring Diagram, B-6

H

Hardware, 5

Revisions, 44

Help, 5, 91

Topics, 45 windows, 5 hierarchy, 39

I

IBM or compatible PC, 5 icon, 46

INCOMPATIBLE EXEC, 82 increment, 12 indicators, 10 input signals, 4

Insert a PLC Message, 76, 95

Folder, 75

Message, 75

Installation Screens, 46

Installing EZText Programming Software, 45 interactive, 4, 13, 35, 36

Interactive Message Operations, 37

Interactive Messages, 36

Internal Software, 44, 81 and Hardware Revisions, 44

INVALID, C-14

K

key information, 2

L

ladder logic program, 10 lamps color, 32

LCD message window, 11

LCD Display, 35 window, 4, 11

I-3

User’s Manual

Learning the Features, 30

LED

Control, 47, 69

LED (Bit Read) PLC Word, 70

LED (BIT READ) PLC WORD (TO PANEL), 31

Limits, 36

Line One, 68

LOADING EXEC, 82

Local Message, 35, 39, 72, 93

File Structure Example, 40

Menu Structure Example, 41

LOCAL MESSAGES, A-3

Lower Limit, 35

M

Main Confi guration Screen, 79 maintenance, 86 man-machine interface, 4 mapped, 91 maximum number of Embedded Data, 94 maximum number of messages, 93

Memory Mapping, 30 menu hierarchy, 39 menu tree, 74

Menu Worksheet, A-1

Menus, 13 message, 39 control type, 13

Edit, 34, 75

Length, 75

Number, 37, 76

Text, 72, 75

Types, 36

Worksheet, A-1

Message Text, 72

Messages, 12, 72

Microsoft Word® document (EZ-TEXT_INSERTS.

doc), 16 minus, 40

Mitsubishi FX Series 8-pin MINI-DIN RS-422 (P/N

EZ, B-7

Mitsubishi FX Series PLC Wiring Diagram, B-6, B-7

25-pin RS-422A, B-12

Model EZ-220 and EZ-420 EZ Text Outline Dimension, 19

Model EZ-220L Outline Dimensions and Mounting

Tem, 21

Models, 6

Models EZ-220L and EZ-220P Outline Dimensions,

21

Models EZ-220 and EZ-420 Outline Dimensions and

Mo, 19

I-4

Momentary, 69 momentary switch, 4

Mounting, 22 mouse, 5 multi-panel applications, 27

N

New System, 65

New System button, 65

NO DATA SET, C-14

NO embedded data, 36 numeric keypad, 11

Numeric Keypad Entry, 38 numeric value, 12, 38

O

octal, 31

Omron PLC Wiring Diagram, B-8

Onscreen HELP, 5 onscreen prompts, 45

Operator Controls and Indicators, 10 operator interface, 6, 10 requirement, 44

Optional Equipment, 9

OUT OF RANGE, C-14

Out of Warranty Repairs, 92

P

P/N EZTOUCH-PGMCBL, 51

Panel

Acknowledge, 47

Acknowledge of PLC Release Bits, 70

Attributes, 66

Hardware Revision, 44

PLC Address Database button, 78

PLC Connections, 27

Preview, 66

Programming (Confi guration) Problems, 89 set and PLC release, 4

Status, 80

System PLC Address Setup, 68

Panel Set and PLC Release, 31, 69

Panel System PLC Address Setup, 68

Panel to PLC Communications Problems, 90 parity, 66

Password Protection, 35, 74

PC requirements, 5 personal computer, 44

Plan the Project, 47

PLC, 10

EZ-TEXT-M

User’s Manual

Address, 68, 73

Attributes, 66 automation system, 4

Button Release Bits, 69

Cable, 5, 9, 28

Communication, 91

CONFIGURATION, A-2 control, 74 control program, 30

Controlled Decimal Point, 34, 74 data register, 12

Data Registers, 30 driver, 90

Errors, 90

HELP, 5 ladder logic, 74 ladder logic program, 10, 11, 13 logic program, 37

Message

Data Items, 78

Message LED, 11, 72, 75

Messages, 35, 72, 75

(Line Address) Setup, 68 port settings, 67 register, 72, 75 station number, 93 type, 66

Word, 47

PLC and Programming Cable Part Numbers, 9

PLC and Protocol type, 66

PLC Cable Part Numbers, B-1 - B-8

PLC Driver Error Messages, C-2

PLC Message LED, 38, 72

PLC MESSAGES, A-5, A-6

PLC Messages, 70, 72, 93

(Line Address) Setup, 68 not clearing, 94

PLC Registers, 72

Embedded Data, 33

LEDs, 31

Message Registers, 33

Pushbuttons, 31

PLC to EZText Panel Interface, 5

PLCs Supported by EZText Panels, 8 plus, 40 polycarbonate, 86 pop-up HELP, 5 port, 66 port communications, 66

Port Selected, 82

Power Cable Core, 18

Power Receptacle, 27

EZ-TEXT-M power source, 27

Power Supply Connections, 27

Precautions, 86

Preparing for Confi guration, 44

Press for Communication Confi guration for Selected

PLC, 66 to Accept Message Edit, 72

Print, 78 problems, 89

Programmable Logic Controller (PLC), 5 programmable operator interface devices, 2

Programming Cable, 5, 27

Programming Software, 27

Project, 47

Project Name, 78 project tutorial, 47 prompt, 45 protocol, 66 purchase a new panel, 92 pushbutton labels, 16

Pushbutton LEDs, 12 pushbutton type, 12

Pushbuttons, 4, 10

Q

questions, 92

R

ramp tool, 16

Range, 35, 74 ratings, 86

READ ONLY VALUE, C-14

READ/WRITE Access, 74

Rear Panel Indicators, 13 register bits, 30 registers, 30

REL, 31 renumber PLC Messages, 95 repair, 92 replacement gasket, 88

Root, 41 root level, 39

RS-232C, 4

RS-422A/485A, 4 rubber trim mold, 16

Run, 45

RUN Mode, 27, 44, 74

RxD LED, 13

I-5

User’s Manual

S

Save, 65

Screen Overlay, 86

Cleaning, 88 screw terminals, 27 scroll, 11, 39 sealed membrane pushbuttons, 4, 10

Select Panel Type, 66

Select PLC, 66

SELF TESTING, 82 serial communication, 4 serial port, 5, 27

Serial Port Communication LEDs, 89 set with release, 12 switch, 12

Setpoint, 36 ranges, 37 value, 37 setpoint ranges, 38 setpoint value, 38

SETUP, 44

SETUP Mode, 27, 44, 89, 94

Setup.exe, 45

Siemens S7 MPI Adaptor, B-8

RS-232C Wiring Diagram, B-10

Siemens S7 MPI Adaptor, RS-232C (P/N EZ-S7MPI-

CBL), B-10, B-11 skipped messages, 77

Software, 5, 6

Software Installation, 45

Special characters, 35

Standard reply error messages, C-16

Static, 36

Static Display, 37

Static Message Operation, 37

Static Messages, 36 static text, 4, 13 status bit, 38

Step 1, 66, 72

Project Information, 52

Step 2, 66, 72

Step 3, 68 subfolder, 39 supply operating voltage, 27 switch types, 4, 12

T

Technical Support, 6, 89 temporary protective covering, 88 timeout, 67

I-6

Total Number of messages, 78

Total Number of Messages (of 256) programmed,

76 tri-color, 38 triggered a message, 11, 72

Troubleshooting, 89

Tutorial, 47 bit addresses, 48

Button PLC Word, 48

Confi gure a PLC, 60

Create a Project, 47

Create the Project, 51 ladder logic, 60

LED PLC Word, 48

Local Message Worksheet, 49

PLC Message Worksheet, 50

Setup Mode, 59

Step 1, Select Panel, 52

Step 2, Select PLC, 52

Step 3

Annunciator, 54 confi gure a dynamic message, 55 confi gure Buttons/LEDs, 53 confi gure Local Messages, 55 confi gure the panel system PLC addresses,

57 create PLC Messages, 57 test project, 62

Writing to Panel, 59

TXD (transmitter) LED, 89

TXD and RXD LEDs, 91

TxD LED, 13

TXD/RXD LEDs, 89

U

unused bit address, 48

UP arrow, 12

Upgrade Firmware, 81

Upper Limit, 35 user-defi ned interaction, 13 user-defi ned pushbuttons, 12

V

value, 73 values, 35 variable point, 37

VGA display, 5

EZ-TEXT-M

W

Warranty Repairs, 92 website, 6, 91

Windows 98, 5 wiring diagram, 27

Worksheet, 45, 47, A-2, A-5, A-6 wrench, 19, 20

User’s Manual

EZ-TEXT-M

I-7

User’s Manual

This page intentionally left blank.

I-8

EZ-TEXT-M

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
