Nikon TE2000

fluorescence microscope

- User manual -

Table of content

Switching ON and OFF the system

The TE2000 pad

Starting the software and camera selection

Camera selection

Available objectives

Correction collar adjustment

Manual multichannel acquisition

Large image acquisition

Timelapse acquisition

Multipoint acquisition

Acquisition of a 3D image

Automated 5D multipoint acquisition

Brightfield filters

Köhler illumination

Increasing contrast

Adjusting phase contrast

Hoffmann modulation contrast

Polarization microscopy

Differential interference contrast (DIC)

Acquisition and analysis layout

Stage control

Shutter control

Autofocus

Scale bar

Saving data

File formats

Available fluorescence filters

Page 22

Page 23

Page 24

Page 25

Page 26

Page 27

Page 28

Page 29

Page 30

Page 12

Page 13

Page 14

Page 15

Page 16

Page 17

Page 18

Page 19

Page 20

Page 21

Page 1-2

Page 3

Page 4

Page 5

Page 6

Page 7

Page 8-9

Page 10-11

Hege 86698

• Endy 86007

Do you want to take images of your sample?

No, just observing

I will analyse some data yes

No need to start up the pc and software. Just make sure you are in «manual» mode on the stage control box (page 24)

Choose DS-U2 and turn on the fluorescent lamp.

If you need brightfield as well, check the Köhler

(page 17).

Start up the computer and choose

«no grabber»

Yes, I have fluorescing samples

Start up pc and software.

Log onto the server.

Focus your sample in the microscope. Will you need the fluorescent lamp?

No

Choose DS-U1 and check the Köhler (page 17). Do you need DIC or HMC?

Timelapse

Go to page

12.

Warm up stage

(30 min before).

Start the CO2 mixer.

Large scan

Go to page

10-11.

Multipoint imagaing

Go to page 13.

Initiate stage (page 24 )

Regular multichannel

imaging Go to page 8-9.

yes

Setting up DIC (page 22)

Setting up HMC (page 20)

Saving data from DS-U2. This camera takes 12 bit images. For quantification analysis, keep the 12 bit.

For localization observation, save as tiff or jpeg and change bit size to 8.

Saving data from DS-U1.

Choose any format as this is a 8 bit camera.

Hege 86698

• Endy 86007

Switch on the system

1. Turn on the main switch (A).

2. Start up the computer (B).

3. Log in with your user account at the PC.

– If you do not have a user account yet, ask MIC personnel to get one.

4. If you need the mercury lamp,

– check online in the booking system (F) and in the logbook (G) whether it has been used in the last 30 min (is it warm?).

– turn on the power switch (C) and press ignition (D).

– note the run time (E) in the logbook (G).

5. Start “NIS-AR” (H), the NIS-

Elements software.

A

D

C

G

E

B

H

F

Hege 86698

• Endy 86007

Switch off the system

A

1. Check online in the booking system whether there is a user coming after you (A).

– If yes, phone her/him and ask whether he/she needs the mercury lamp.

If nobody uses the mercury lamp for the following 30 minutes, switch it off at the power button (B).

2. Close the software and shut down the PC.

3. Fill out the logbook (C).

4. Turn off the main switch (D).

C

B

D

Hege 86698

• Endy 86007

Objective switch

The TE2000 pad

A

Halogen light control. The main switch on the power supply needs to be on (A). Regulate the intensity here (B). Halogen shutter (C).

E

D

Shutter for the UV light. The power supply needs to be on (D) and lamp ignited

(E).

Fluorescence filter positions. No.

6 is empty and used for imaging

BF, Ph, Pol, HMC, and DIC.

C

B

E

F G

Light path control. Eyepiece (E),

B/W-camera for fluorescence and

DIC (F), and colour camera (G).

Hege 86698

• Endy 86007

Starting the software

A

1. Double-click the “NIS-AR”button on the Desktop (A).

2. Select the camera control unit you want to use (B):

– For the colour camera, choose

“Nikon DS-U1”.

– For the B/W-camera, choose

“Nikon DS-U2/L2 USB”.

3. Log on to the Biomic on the

“Skule” server

(- to be able to save images directly onto the server).

– Double-click the “biomic on

‘skule’ ” icon on the desktop

(C).

– Enter your UiB username in the following way: username: uib\username

, and then the password (D).

– If you do not have access to skule yet, contact Torstein

Ravnskog (

℡ 86323, room

6C133cA).

D

C

B

Hege 86698

• Endy 86007

Colour camera

DS-5Mc

Camera selection

BWcamera

DS-Qi1

A

Turn on the main switch

(A, colour camera; B, BWcamera) before use.

B

• histological sections

BF + phase contrast images

• classical stainings (Golgi,

Nissl etc.)

Pixels: 2560 x 1920 pixels; binning 2x2, 4x4

Cooling: Peltier cooling 20 ° below ambient

A/D conversion: 8-bit

Exposure time: 1/1000 – 600 s

Sensitivity: Equivalent to ISO 64

• fluorescence acquisition

DIC + HMC images timelapse imaging

Pixels: 1280 x 1024 pixels; binning 2x2, 4x4

Cooling: Peltier cooling 10 ° below ambient

A/D conversion: 12-bit

Exposure time: 1/1000 – 600 s

Sensitivity: Equivalent to ISO 800

Hege 86698

• Endy 86007

B

Correction collar adjustment

A

C

Some objectives have a correction collar

(A) to adjust for a cover slip thickness between 0 and 2 mm (B).

In order to adjust:

• look through the eyepiece at all times.

• turn the correction collar slightly

(might be somewhat stuck at the beginning).

• refocus (C).

• turn the correction collar again slightly.

• refocus again.

• repeat until you get a sharp, crisp image

(D).

D

Correction collar not adjusted

Correction collar adjusted

Hege 86698

• Endy 86007

Manual multichannel acquisition

1. Click Acquire

Capture Multichannel


Multichannel Setup.

2. Click into an empty line under Optical conf. (A) and select the channel you want to use. If the channels are already there, just tick the once you need.

3. For automated saving, tick «Save to File» (B), set the File Path (C) to an appropriate folder on the klient server, and give the data to be recorded a sensible name (D).

A

B

D

C

If your samples are bleaching a lot, it is adviced to select the longest wavelength first (CY5 or TRITC), then green and blue last.

Hege 86698

• Endy 86007

Manual multichannel acquisition (II)

A

B

In the “Split Channel” view (A), you can see during acquisition how the different channels built up. You can zoom in using the middle mouse button.

• After acquisition, use the LUTs to adjust the contrast for each channel individually. You can also try the automatic adjustment (B).

Hege 86698

• Endy 86007

Large image acquisition (I)

1. Initiate stage (Devices

Initiate stage).

2. Open the ND acquisition window (A)

(Applications

Define/Run ND

Application).

3. Define the channels you want to image (B).

4. The image will be saved automatically. Be sure to define where the image should be saved and give it a filename (C).

5. You need to define an editional command

(open the UV shutter) before the first channel

(D) or else your first image will be dark. Find the command (E):

Stg_OpenFirstShutter

B

C

D

A

E

Hege 86698

• Endy 86007

Large image acquisition (II)

5. Tick the «large scan» window and define the amount of images to be scanned (A), the first number indicating the x direction.

6. Move to the centre of your object and adjust for focus and exposure time (B).

7. If you want autofocus, you need to choose «define by steps» (C) either in lambda or timelapse mode.

8. Define the stepsize (D) and total z range (E).

A

B

D

E

C

Hege 86698

• Endy 86007

Timelapse acquisition

1. Open the ND acquisition window (Applications

Define/Run ND Application).

2. Define which channels you want to image under “lambda” flag

(A).

3. Check the “time” flag. Define the interval (B) at which the images should be taken. Define the “duration” of the experiment

(C).

4. You can define different loops of timelapse experiments. If you want to acquire faster imaging for an hour before doing a slower imaging, then define a second “phase” (D).

5. For long term experiments, use autofocus under “advanced” (E).

D

B

E

A

C

Hege 86698

• Endy 86007

Multipoint acquisition

1. Initialize the stage. Be careful to not use the joystick from now on!

2. Open the ND acquisition window (Applications

Define/Run ND Application).

3. Use the XYZ Navigation window to move around your sample (A). You can go between coarse and fine (B)

4. Define your multipoint positions in the XY window with a tick into an empty square

(C).

5. Define where the data is going to be saved (D).

6. If you are doing a long timelapse, use autofocus.

7. Define which channels (E) you want to image and the interval of your timelapse (F).

F

C

A

B

E

D

Hege 86698

• Endy 86007

Brightfield filters

Neutral density filter. Use this when neither the voltage control of the halogen lamp nor the exposure time of the camera suffice.

Diffuser disc.

Keep this always in the light path.

It decreases the amount of uneven illumination caused by an extended light source (=tungsten wire).

NCB = neutral colour balance. Use this filter if the white balance is not satisfactory at low halogen voltage.

GIF = green interference filter.

Use this filter for phase contrast microscopy. This filter removes unwanted halo effects, since phase contrast is calculated for green light.

Hege 86698

• Endy 86007

Köhler illumination

Köhler illumination is imperative for all transmission microscopy techniques (brightfield, phase contrast, HMC,

DIC, polarisation … ).

Adjust also when changing the objective or replacing the sample.

1.

or

A

2.

B

C C

3.

4.

1. Close the field stop diaphragm (A) so that you can see the edges.

2. Move the condensor up and down (B) until you see a sharp image of the field stop diaphragm (with sharp edges).

3. Centre the image of the field stop diaphragm by using the knurled condensor centring screws (C).

4. Open the field stop diaphragm (A) until the edges lie just beyond the field of view.

Hege 86698

• Endy 86007

A

Increasing contrast

• After setting up the

Köhler illumination, close the aperture stop

(arrow).

• The contrast/depth of field will greatly increase.

• As you close the aperture stop, the resolution will decrease!

B C

Diatomee in brightfield with different contrast settings: A, aperture open; B, aperture halfway closed; C, aperture fully closed. Note that in A, only a small part of the Diatomee is in focus, whereas in C, you see all in focus, but also dirt in the image pathway.

Hege 86698

• Endy 86007

Adjusting phase contrast

D B

A1

C1

A2

C2

For the adjustment of phase contrast, (i) bring your object in focus and (ii) Köhler. (iii) Switch the condensor (B) to the position matching the objective‘s inscription. In case of correct alignment (C1), you will see phase contrast with homogeneous halo (C2). (iv) Check the alignment by switching the eyepiece optics to “B” (Bertrand-lens, arrow). The two rings you see (A1) have to overlap. If not, you will have strong artifacts (A2). In order to adjust, (v) move the condensor ring with an allen key(D).

Hege 86698

• Endy 86007

Hoffmann modulation contrast

A

B

C

D

Hoffman modulation contrast creates DIClike images with less effort, giving the objects a 3D appearance (B). In order to adjust for Hoffmann modulation contrast:

• focus and Köhler your object and lightpath (A).

• at the condensor, switch to the filter corresponding to the objective (MC1-3).

• at the eyepiece, switch from “O” to “B”.

• use either the knurled screw at the objective or at the condensor filter to make the two grey-shaded objects parallel (C and D).

• Use an allen key to adjust the distance between the two grey-shaded objects at the condensor filter. They should overlap slightly.

Hege 86698

• Endy 86007

Polarisation microscopy

A

B

C

D

Polarisation microscopy is particularly useful for imaging linear structures like crystals, and can also resemble dark field microscopy. To adjust,

• focus and Köhler your object and lightpath (C).

• set in the polariser (A), which is situated above the consensor.

• set in the analyser (B), which is situated below the filter revolver on the right hand side.

Make sure the filters are crossed (background is black).

• image your sample (D). move both filters out again after imaging, since each will take

50 % of the light!

Hege 86698

• Endy 86007

Differential interference contrast

A

C

D

In order to adjust for DIC,

• focus and Köhler your object and lightpath to get a nice brightfield image (A).

• insert the polariser above the condensor and the analyser below the filter revolver.

• insert the DIC prisms matching the objective‘s inscription in the condensor revolver and below the objective (B) to get the typical

DIC-image (C). Control the

“shadow” by turning the polariser.

• For colour-DIC (D), insert the

λ

-plate below the polariser (E).

E

B

Hege 86698

• Endy 86007

Stage control

• If you want to use the microscope without acquiring images, set the stage control to

“MANUAL” (A).

• If you want to acquire images, set the stage control to “AUTO”.

• If the stage does not react after starting the software, go to Devices

Manage devices (B).

Click on “LSTEP/ECO-

STEP” (B) and on

“Connect” (C).

• If you need to invert the

XY axis on the joystick, open connection parameters (D) and reverse X and Y (E).

E

B

C

D

A

Hege 86698

• Endy 86007

Acquisition and analysis layout

Make your own favourite layout of the right PC screen.

Open useful windows in view acquisition controls and analysis controls. Save your layout in View Layout

Save current layout.

If some of your windows are gone next time, retrieve by going to View Layout Reload current layout.

Useful floating windows:

• Camera acquisition control

• ND acquisition

• TE2000 Pad

• LUTs

• XYZ navigation

Hege 86698

• Endy 86007

A

C

D

Shutter control

In order to avoid bleaching, the shutter has to be closed when no image is being acquired. To do so automatically in multidimensional experiments,

• untick “Close Active Shutter when Idle” (A).

• open “Advanced >>” (B).

• Select “Execute before Capture” (C) and

“Execute after Capture” (D).

B

• Click on the arrow to the right (E) and select

E

“Command List” (F).

• From the command list (G), select

“Stg_OpenFirstShutter()” (H) for “Execute

F before Capture”, and “Stg_CloseFirstShutter()” for “Execute after Capture”.

G

H

Hege 86698

• Endy 86007

Autofocus

Especially in timelapse experiments, the probe might move out of focus over time. To avoid this, NIS elements provides an autofocus function.

• Click “Advanced” (A) in order to access the autofocus settings.

• Choose either “Steps in Range” or “Adaptive” (B).

• Choose when the autofocus should be applied (C).

Click “Define” (D) and adjust the settings:

− in “Steps in Range”, you define the z-stack size (E), in which you expect the focal region, and the precision of the scanning (F).

F E

B

C

D

A

Hege 86698

• Endy 86007

A

B

C

G

Acquisition of a 3D image

In order to acquire a z-stack, you need to define its thickness and the distance of each slide.

• Go to “Applications Define/Run ND

Acquisition, and activate “Z Series”.

• Focus your sample and define a “top” (A) and

“bottom” (B).

Define the step size (C). The number of steps (D) will change accordingly. It also works vice versa.

Furthermore, you can take over the suggestion of the software for

F

E

D

Nyquist sampling (E).

• In addition, you can define the size of the image stack by moving to the centre of the stack and setting the size of the half-stacks (F).

Note that you cannot autofocus if you capture a z-stack.

The axial shifting of the objective is very fast; the inbuilt shutter is much slower, so that there is no need for closing during axial movement (G).

Hege 86698

• Endy 86007

Automated 5D multipoint acquisition

Using the ND acquisition (Applications Define/Run ND

Acquisition, you can set up experiments that include

• timelapse

Multipoint (XY)

• z-series

• Multichannel (lambda)

• large image

If you need multipoint/ large image, you have to initialise the stage first. Then, tick all the modules you need (A) and define as described on the previous pages. Do not forget to define the order of the experiment (B).

A progress window (C) will inform you about the progress.

Use “advanced” (D) to define autofocus and usefull commands for shutter control.

C

B

A

D

Hege 86698

• Endy 86007

Scale bar

With NIS Elements, you can add a scale bar to your images. Ask MIC personnel to calibrate the objective if required (is most cases, it is calibrated as you find it).

B A

Tick on the scale bar sign (A) on the right side of your recorded image; the scale bar will appear.

To change the default, go to scale properties (B).

„Burn scale“ onto image (right click on scalebar).

Hege 86698

• Endy 86007

Saving data

All data should be saved on “biomic”, and in the following two formats:

• “*.nd2” is the manufacturer’s format that contains all the

META-data. This is your raw data that you have to keep to be able to show what you have done.

• “TIFF” is the scientific format which can be used by almost all software, but is does not contain the full

META-data.

You can adjust parts of the

META-data in the “Image

Fields” dialogue.

The hugely popular

“JPEG/JPG” is lossy, produces artefacts, and is not recommended in science. Use it only for simple presentation purposes.

Hege 86698

• Endy 86007

File formats

Data generated on this microscope is 12 bit, which is more than the Windows Photo Viewer can handle properly! Apart from NIS elements, use the following programmes for image visualisation, and processing:

FIJI/ImageJ

MATLAB

• Imaris

• ImagePro

• …

In Photoshop, you will have to adjust brightness/contrast, and it cannot handle two channel TIFF without problems.

Hege 86698

• Endy 86007

Available objectives

Position M

1

2

3

4

10

20

Correction

Plan Fluor

Plan Fluor

ELWD Plan Fluor

NA

WD

(mm)

0,13 16,4

0,30 15,2

0,45 7,4

4

5

6 u. r.

u. r.

u. r.

40

10

20

ELWD Plan Fluor

HMC

HMC LWD

2

40

Plan Apo

HMC LWD

60 Plan Apo VC

0,60

0,25

0,40

0,1

0,55 2,7-1,7

1.4

3,7-2,7

6,2

3,1

8,5

0,13

Contrast method

PhL

Ph1

Ph1

Ph2

MC1

MC2 not recommended

MC3

DIC (N2)

Abbreviations: M, magnification; NA, numerical aperture; WD, working distance; Ph, phase contrast; ELWD, enhanced long working distance; HMC, Hoffmann modulation contrast; u. r., upon request; VC, violet-corrected (optimised for multi-colour-staining that includes DAPI and the visible spectrum), DIC, differential interference contrast. All objectives work in brightfield and with polarisation microscopy. All objectives except the ones dedicated for

HMC can be used for fluorescence microscopy.

Hege 86698

• Endy 86007

Name

DAPI

CFP

Available fluorescence filters

λλλλ

ex

340-

380

426-

446

λλλλ

em

435-

485

460-

600

Dye examples

Alexa Fluor 350, BFP, Coumarin DAPI, Indo-

1, Hoechst, Marina Blue

Acridine Orange, Alexa Fluor 430, eCFP,

Lucifer Yellow, PO-PRO

GFP

450-

490

LP500

Alexa Fluor 430/488, BCECF, Calcein, CFDA,

Di-8, eGFP, FDA, FITC, Fluo-4, Fluorescein,

FM 1-43, FM 4-64, Fura Red, LysoSensor

Green, MitoTracker Green, Rhodamine

110/Green, YO-PRO

FITC

YFP

TRITC

Cy5

465-

495

490-

510

528-

552

590-

650

515-

555

LP520

577-

632

662-

738

Alexa Fluor 488, BCECF, Cy2, DiO, eGFP,

FDA, FITC, Fluo-4, Fluorescein, FM 1-43,

MitoTracker Green, Nissl, Oregon Green 488,

Rhodamine 110/Green, YO-PRO, YOYO

Alexa Fluor 488, BCECF, BODIPY, Calcein,

CFDA, Calcium Green, eGFP, eYPF, FlAsH,

FITC, FM 1-43, Magnesium Green,

MitoTracker Green, Oregon Green 488/514,

Rhodamine 110/123/Green, TO-PRO, TOTO,

YO-PRO, YOYO

Alexa Fluor 555/610, BODIPY TMR-X,

Calcium Orange, dTomato, Ethidium

Bromide, evoglow-Bs1/Bs2/Pp1, Magnesium

Orange, Nile Red, PO-PRO-3, POPO-3,

Propidium Iodide, Rhodamine, TAMRA,

Tetramethylrhodamine, TRITC

Alexa Fluor 647/660, Atto 647, mPlum,

NileBlue/Red, Cy5, TO-PRO-3, TOTO-3

Hege 86698

• Endy 86007

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
