Print Release Settings Guide

Print Release Settings Guide

TABLE OF CONTENTS

ABOUT THIS GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PRINT RELEASE FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

BEFORE USING THE PRINT RELEASE FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Settings required on the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 4

• Installing the printer driver of the primary unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 5

USING THE PRINT RELEASE FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

• Storing a job in the primary unit from your computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 6

• Printing/deleting a job stored in the primary unit from a secondary unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 8

ABOUT THIS GUIDE

This guide explains how to use the print release function.

Please note

• The explanations in this manual assume that you have a working knowledge of your Windows or Mac OS computer.

• For information on your operating system, please refer to your operating system manual or the online Help function.

• The explanations of screens and procedures in this manual are primarily for Windows

®

8 in Windows

®

environments, and Mac OS X 10.10 in Mac OS environments. The screens may vary depending on the version of the operating system.

• Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual, please contact your dealer or nearest authorized service representative.

• This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other problem is discovered, please contact your dealer or nearest authorized service representative.

• Aside from instances provided for by law, SHARP is not responsible for failures occurring during the use of the product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any damage that occurs due to use of the product.

Warning

• Reproduction, adaptation or translation of the contents of the manual without prior written permission is prohibited, except as allowed under copyright laws.

• All information in this manual is subject to change without notice.

• The display screens, messages, and key names shown in the manual may differ from those on the actual machine due to product improvements and modifications.

• The explanations in this manual are based on American English and the North American version of the software.

Software for other countries and regions may vary slightly from the North American version.

2

Print Release Settings Guide

PRINT RELEASE FUNCTION

When there are multiple machines that support the print release function on the same network, you can use the print release function to save data in the machine that is set as the primary unit and then print the saved data from secondary unit which you set (multiple secondary units can be set).

Computer

Primary Unit

Saving a job in the primary unit.

TCP/IP network

You can print a job saved in the machine (primary unit) from other machine

(secondary unit) on the same network.

Secondary Unit Secondary Unit

For the number of secondary units that can be controlled by one primary unit, consult your dealer.

• The memory area for saving print release jobs is 16 GB.

• When user authentication is enabled, only jobs of the logged-in user can be printed.

3

Print Release Settings Guide

BEFORE USING THE PRINT RELEASE

FUNCTION

This section explains settings that must be configured before you can use the Print Release function.

Settings required on the machine

The following settings must be configured on the machine in order to use the print release function. (Administrator rights are required.)

System settings

Tap the [Settings] key on the touch panel of the machine and log in with administrator rights. Tap [System Settings] >

[Printer Settings] > [Print Release Settings], and configure the settings.

For the system settings, refer to the User's Manual.

Item

• Print Release

• Connecting Code

• Primary Unit/Secondary Unit Setting

• Require Authentication when Storing (When

[Primary Unit] is selected)

Settings

Select [Enable].

Enter a code for authentication between the primary unit and secondary unit. Maximum of 32 alphanumeric characters. Be sure to enter the same code in both the primary unit and secondary unit.

Entry of a code can be omitted.

Select the machine in which print release jobs will be saved in [Primary

Unit]. Select the machine that will be used for printing in [Secondary Unit].

Select whether or not authentication is required to store a print release job in the machine that is functioning as the primary unit. If the user authentication setting of the primary unit is disabled, jobs will be saved without authentication even if [Enable] is selected.

Enter the IP address or host name of the primary unit.

• Address of Primary Unit (When [Secondary

Unit] is selected)

• Port Number Set the port number used for print release in the primary unit and in the secondary unit. Be sure to set the same number in both the primary unit and the secondary unit. (The default port number is "53000", and there is no particular need to change this.)

• Default Settings

• Print B/W

• Print and Delete the Data

• Delete Stored Data after Specified Time

• Days

• HDD Status

• Delete All (When [Primary Unit] is selected)

When [Enable] is selected, [Print B/W] is enabled in the print screen of the print release job.

When [Enable] is selected, [Print and Delete the Data] is enabled in the print screen of the print release job.

Select whether or not stored print release jobs are automatically deleted after a set time elapses. If you select [Enable], jobs that have been stored the number of days set in “Days” will be automatically deleted.

When “Delete Stored Data after Specified Time” is enabled, set the number of days jobs are stored.

Displays the usage status of the hard disk drive.

When the machine functions as the primary unit, select this to delete all stored print release jobs.

4

Print Release Settings Guide

Fixing the IP address of the machine

If the machine is used in a DHCP environment, the IP address of the machine may change. If this happens, you will not be able to send print release information to the machine.

Adding the print release icon to the Home screen

1

Perform these steps after you have enabled the print release function in settings mode (administrator).

System settings (page 4)

Tap [Edit Home] on the action panel.

Edit Home

MFP Display Pattern

Setting

Change Text Color

On Home Screen

CLOUD PORTAL Easy

Copy

Easy

Scan

Operation

Guide

Enlarge

Display Mode

Settings Total Count LCD Control Job Status

2

Tap a place without a shortcut key in home edit mode.

3

Tap [Print Release].

Tray Settings

Folder

Registration

Operation

Guide

Received Data

List

Forward Error

Box

Easy

Scan

Print Release

Language

Setting

Enlarge

Display Mode

LCD Control

I-Fax Manual

Receive

Easy

Copy

Easy

Fax

Google Drive

4

Tap [Exit Home Edit Mode] on the action panel.

Home Edit Mode is exited and you return to the home screen.

Installing the printer driver of the primary unit

Install the printer driver of the primary unit on your computer. For the procedures for installing the printer driver, see the

Software Setup Guide.

5

Print Release Settings Guide

USING THE PRINT RELEASE FUNCTION

This section explains how to store jobs in the primary unit, and how to select and print jobs from a secondary unit.

Storing a job in the primary unit from your computer

When user authentication enabled in the machine, you must enter your user information (login name, password, etc.) in the settings screen of the printer driver in order to print.* For explanations of the settings, see printer driver help.

* The user information that is required varies depending on the enabled authentication method. Check with the machine administrator for this information.

In a Windows environment

1

(1)

(2)

Open the printer driver properties window.

(1) Select the printer driver of the Primary

Unit.

(2) Click the [Preferences] button.

2

(2)

(3)

(1)

Configure the print release function.

(1) Click the [Job Handling] tab.

(2) Select the [Print Release] checkbox .

(3) Enter user information as needed.

For more information, see the User's Manual.

(4) Select any print settings that are needed, and click the [OK] button.

(4)

• The print release function cannot be used at the same time as the document filing function.

• You can change the number of copies and color mode at the time of printing.

• To have the print release function be always enabled, select the [Print Release] checkbox in [Printing

Policy] on the [Configuration] tab of the printer driver.

• If less than 10 MB is free in the storage area of the primary unit, the job will not be stored. Delete unneeded jobs and print again.

3

Start printing.

6

Print Release Settings Guide

Check the paper size used for printing.

If you select a paper size larger than the maximum paper size of the machine, the image may be cut off.

In a Mac OS environment

1

In the application, select [Print] from the [File] menu. Make sure that the machine's printer name is selected.

2

(3)

(1)

(2)

(4)

(5)

Configure the print release function.

(1) Select [Job Handling].

(2) Click [Retention].

(3) Select the [Print Release] checkbox

.

(4) Click [Authentication] and enter your user information as needed.

If user authentication is not enabled, this step can be omitted.

For more information, see the User's Manual.

(5) Select any other print settings that are needed, and click the [Print] button.

• The print release function cannot be used at the same time as the document filing function.

• You can change the number of copies and color mode at the time of printing.

• If less than 10 MB is free in the storage area of the primary unit, the job will not be stored. Delete unneeded jobs and print again.

3

Start printing.

7

Print Release Settings Guide

Printing/deleting a job stored in the primary unit from a secondary unit

This section explains how to print and delete a stored job from a secondary unit.

1

Tap the [Print Release] key on the Home screen.

• A list of the jobs stored in the primary unit appears.

• If the main power of the primary unit is not on, a message will appear and you will not be able to view the stored jobs.

2

Select Job to Operate.

File Name

HDD_20150606_165828

A4_03P

Login Name

User1

User1

HDD_20150606_164042

HDD_20150606_163712

HDD_20150606_151132

User2

User2

User1

(1)

Date

10/10/2015

10/10/2015

10/10/2015

10/10/2015

10/10/2015

HDD_20150606_134726

HDD_20150606_135845

User1

User1

Select All

10/10/2015

10/10/2015

(3)

Delete

(2)

No. of

Prints

Change Number of Prints

1

( 1 - 9999)

Print B/W

Print and Delete the Data

Print

Print or delete the selected job.

(1) Tap the job you want to print or delete.

The checkbox is selected .

You can select more than one job.

You can select all jobs with the [Select All] key.

(2) Configure print settings.

• To delete the job from the primary unit after printing, select the [Print and Delete the Data] checkbox .

• If you are deleting the job, this step is not necessary.

(3) Start printing or deleting.

If you are deleting the job, a confirmation screen will appear. Select [Yes] to delete.

When user authentication is enabled, only the print jobs of the logged-in user appear.

• If you selected a setting such as stapling that cannot be executed because the secondary unit does not have the necessary option, the setting will be disregarded.

• If the selected job is a PS file, the job will only be printed if the secondary unit supports PS file printing.

8

2015K-EN1
