Maintenance and Service Guide 2–11

Troubleshooting

Flowchart 2.2—No Power, Part 1

No power

(power LED is off).

Remove from

Port Replicator

(if applicable).

N N

Power up on battery power?

*Reset power.

Power up on battery power?

Go to

“Flowchart 2.3—No

Power, Part 2”

Y Y

N N

Power up on AC power?

*Reset power.

Power up on AC power?

Go to

“Flowchart 2.4—No

Power, Part 3”

Y Y

Power up in

Port

Replicator?

Done

*NOTES:

1. On some models, there is a separate reset button.

2. On some models, the notebook can be reset using the Standby switch and either the lid switch or the main power switch.

1. Reseat the power cables in the Port Replicator and at the AC outlet.

2. Ensure that the AC power source is active.

3. Ensure that the power strip is working.

Y N

Done

Power up in Port

Replicator?

Go to

2.8—Nonfunctioning

Port Replicator”

2–12 Maintenance and Service Guide

Flowchart 2.3—No Power, Part 2

Continued from

“Flowchart 2.2—No

Power, Part 1”

Visually check for debris in battery socket and clean if necessary.

Power on?

Check battery by recharging it, moving it to another notebook, or replacing it.

Power on?

Done

Replace power supply

(if applicable).

Power on?

Go to

“Flowchart 2.4—No

Power, Part 3”

Done

Troubleshooting

Maintenance and Service Guide 2–13

Troubleshooting

Flowchart 2.4—No Power, Part 3

Continued from

“Flowchart 2.3—No

Power, Part 2”

Plug directly into AC outlet.

Power LED on?

Reseat AC adapter in notebook and at power source.

Power on?

Power outlet active?

Replace power cord.

Power on?

Done

Try different outlet.

Internal or external AC adapter?

External

Internal

Go to

“Flowchart 2.5—No

Power, Part 4”

Replace external

AC adapter.

Power on?

Done

2–14 Maintenance and Service Guide

Flowchart 2.5—No Power, Part 4

Continued from

“Flowchart 2.4—No

Power, Part 3”

Open notebook.

Loose or damaged parts?

Close notebook and retest.

Power on?

Done

Reseat loose components and boards and replace damaged items.

Replace the following items (if applicable) in the order given. Check notebook operation after each of the following two replacement steps:

1. Internal DC to DC converter, processor, and system board*

2. Internal AC adapter

*NOTE: Replace these items as a set to prevent shorting out among components.

Troubleshooting

Maintenance and Service Guide 2–15

Troubleshooting

Flowchart 2.6—No Video, Part 1

No video.

Stand-alone or Port

Replicator?

Port

Replicator

Go to

“Flowchart 2.7—No

Video, Part 2”

*NOTE: To change from internal to external display, use the hotkey combination.

Stand-alone

Internal or external display*?

External

Adjust brightness.

Internal

Adjust brightness.

A

Video OK?

Done

Press lid switch to ensure operation.

Y Y

Video OK?

Done Video OK?

Done

Check for bent pins on cable.

Video OK?

Replace the following one at a time. Test after each replacement.

1. Cable between notebook and notebook display (if applicable)

2. Inverter board (if applicable)

3. Display

4. System board

Try another display.

Internal and external video OK?

Replace system board.

Done Done

2–16 Maintenance and Service Guide

Troubleshooting

Flowchart 2.7—No Video, Part 2

Continued from

“Flowchart 2.6—No

Video, Part 1”

Remove notebook from Port

Replicator, if connected.

Adjust display brightness.

Check brightness of external monitor.

Video OK?

Go to “A” in

“Flowchart 2.6—No

Video, Part 1”

Verify that notebook is properly seated in Port Replicator, and check for bent pins on cable and for secure monitor connection.

Video OK?

Done

Adjust external monitor display.

Video OK?

Try another external monitor.

Internal and external video OK?

Go to

go to “Flowchart 2.10—No OS Loading, Hard Drive,

2.8—Nonfunctioning

Port Replicator”

Done

Maintenance and Service Guide 2–17

Troubleshooting

Flowchart 2.8—Nonfunctioning Port Replicator

Nonfunctioning

Port Replicator.

Reseat power cord in Port

Replicator and power outlet.

Check voltage setting on Port

Replicator.

Reseat monitor cable connector at

Port Replicator.

Port

Replicator operating?

Remove notebook, reseat all internal parts, and replace any damaged items in

Port Replicator.

Done

Reinstall notebook into Port

Replicator.

Port

Replicator operating?

Done

Replace the following Port Replicator components one at a time. Check notebook operation after each replacement.

1. Power supply

2. I/O board

3. Backplane board

4. Switch box

5. Port Replicator motor mechanism

2–18 Maintenance and Service Guide

Flowchart 2.9—No OS Loading

No OS loading.*

Reseat power cord in Port

Replicator and power outlet.

No OS loading from hard drive,

Part 1”

Troubleshooting

No OS loading from diskette drive, go to

“Flowchart 2.13—No OS Loading, Diskette

Drive”

No OS loading from CD- or DVD-ROM drive, go to

“Flowchart 2.14—No OS Loading, CD- or

DVD-ROM Drive” .

No OS loading from network, go to

“Flowchart 2.20—No Network/Modem

Connection”

*NOTE: Before beginning to troubleshoot, always check cable connections, cable ends, and drives for bent or damaged pins.

Maintenance and Service Guide 2–19

Troubleshooting

Flowchart 2.10—No OS Loading, Hard Drive, Part 1

OS not loading from hard drive.

Nonsystem disk message?

Go to

“Flowchart 2.11—No

Drive, Part 2”

Reseat external hard drive.

OS loading?

Done

Boot from

CD?

Check the Setup utility for correct booting order.

Boot from diskette?

Go to

“Flowchart 2.13—No

OS Loading, Diskette

Drive”

Boot from hard drive?

Change boot priority through the Setup utility and reboot.

Done

Boot from hard drive?

Go to

2.17—Nonfunction ing Device”

2–20 Maintenance and Service Guide

Troubleshooting

Flowchart 2.11—No OS Loading, Hard Drive, Part 2

Continued from

“Flowchart 2.10—No

Drive, Part 1”

Reseat hard drive.

CD or diskette in drive?

1. Replace hard drive.

2. Replace system board.

Hard drive accessible?

Done

Remove diskette and reboot.

Run FDISK.

Boot from hard drive?

Done

Boot from diskette drive?

Go to

“Flowchart 2.13—No

OS Loading, Diskette

Drive”

Hard drive accessible?

Done

Go to

“Flowchart 2.12—No

Drive, Part 3”

Hard drive partitioned?

Create partition, then format hard drive to bootable

C:\ prompt.

Hard drive formatted?

Format hard drive and bring to a bootable

C:\ prompt.

Notebook booted?

Go to

“Flowchart 2.12—No

Drive, Part 3”

Load OS using

System Restore CD

(if applicable).

Maintenance and Service Guide 2–21

Troubleshooting

Flowchart 2.12—No OS Loading, Hard Drive, Part 3

Continued from

System files on hard drive?

Install OS and reboot.

Virus on hard drive?

Clean virus.

OS loading from hard drive?

Done

N N

Run SCANDISK and check for bad sectors.

Diagnostics on diskette?

Replace hard drive.

Can bad sectors be fixed?

Replace hard drive.

Run diagnostics and follow recommendations.

Fix bad sectors.

Boot from hard drive?

Replace hard drive.

Done

2–22 Maintenance and Service Guide

Troubleshooting

Flowchart 2.13—No OS Loading, Diskette Drive

OS not loading from diskette drive.

Reseat diskette drive.

OS loading?

Done

Nonsystem disk message?

Boot from another device?

Diskette drive enabled in the Setup utility?

Is diskette drive boot order correct?

Change boot priority using the Setup utility.

Go to

Bootable diskette in drive?

Install bootable diskette and reboot notebook.

Go to

Enable drive and cold boot notebook.

Clear CMOS.

Refer to

“Section

1.3 Clearing a

Password”

for instructions.

Check diskette for system files.

Try different diskette.

Nonsystem disk error?

1. Replace diskette drive.

2. Replace system board.

OS loading?

Done

Maintenance and Service Guide 2–23

Troubleshooting

Flowchart 2.14—No OS Loading, CD- or

DVD-ROM Drive

Y N

No OS loading from

CD- or

DVD-ROM Drive.

Disc in drive?

Bootable disc in drive?

Install bootable disc and reboot notebook.

Install bootable disc.

Try another bootable disc.

Boots from

CD or DVD?

Reseat drive.

Done

Boots from

CD or DVD?

Booting from another device?

Booting order correct?

Done

Go to

Clear CMOS.

Refer to

“Section

1.3 Clearing a

Password” for

instructions.

Correct boot order using the Setup utility.

Go to

2–24 Maintenance and Service Guide

Troubleshooting

Flowchart 2.15—No Audio, Part 1

No audio.

Turn up audio internally or externally.

Audio?

Done

Notebook in

Port Replicator

(if applicable)?

Go to

“Flowchart 2.16—No

Audio, Part 2”

Undock

Internal audio?

Go to

“Flowchart 2.16—No

Audio, Part 2”

Replace the following Port Replicator components one at a time, as applicable.

Check audio status after each change.

1. Port Replicator audio cable

2. Audio cable

3. Speaker

4. Port Replicator audio board

5. Backplane board

6. I/O Board

Go to

2.17—Nonfunction ing Device”

Audio?

Done

Maintenance and Service Guide 2–25

Troubleshooting

Flowchart 2.16—No Audio, Part 2

Continued from

“Flowchart 2.15—No

Audio, Part 1”

Audio driver in OS configured?

Reload audio drivers.

Correct drivers for application?

Load drivers and set configuration in OS.

Connect to external speaker.

Audio?

Replace audio board and speaker connections in notebook

(if applicable).

1. Replace internal speakers.

2. Replace audio board (if applicable).

3. Replace system board.

Done

2–26 Maintenance and Service Guide

Troubleshooting

Flowchart 2.17—Nonfunctioning Device

Nonfunctioning device.

Reseat device.

Clear

CMOS.

Reattach device.

Close notebook, plug in power, and reboot.

Unplug the nonfunctioning device from the notebook, and inspect cables and plugs for bent or broken pins or other damage.

Any physical device detected?

Fix or replace broken item.

Replace hard drive.

Go to

“Flowchart 2.9—No

OS Loading”

N N

Device boots properly?

Replace NIC.

If integrated NIC, replace system board.

Device boots properly?

Done

Replace diskette drive.

Done

Maintenance and Service Guide 2–27

Troubleshooting

Flowchart 2.18—Nonfunctioning Keyboard

Keyboard not operating properly.

Connect notebook to good external keyboard.

External device works?

Reseat internal keyboard connector

(if applicable).

OK?

Replace system board.

Replace internal keyboard or cable.

Done OK?

Replace system board.

Done

2–28 Maintenance and Service Guide

Troubleshooting

Flowchart 2.19—Nonfunctioning Pointing Device

Pointing device not operating properly.

Connect notebook to good external pointing device.

External device works?

Reseat internal pointing device connector

(if applicable).

OK?

Replace system board.

Replace internal pointing device or cable.

Done OK?

Replace system board.

Done

Maintenance and Service Guide 2–29

Troubleshooting

Flowchart 2.20—No Network/Modem Connection

No network or modem connection.

Network or modem jack active?

Replace jack or have jack activated.

Digital line?

Connect to nondigital line.

NIC/modem configured in OS?

Reload drivers and reconfigure.

Disconnect all power from the notebook and open.

OK?

Replace NIC/modem

(if applicable).

Reseat NIC/modem

(if applicable).

OK?

Done

Replace system board.

2–30 Maintenance and Service Guide

Illustrated Parts Catalog

This chapter provides an illustrated parts breakdown and a reference for spare part numbers and option part numbers.

3.1 Serial Number Location

When ordering parts or requesting information, provide the notebook serial number and model number located on the bottom of the notebook.

Serial Number Location

Maintenance and Service Guide 3–1

Illustrated Parts Catalog

3.2 Notebook Major Components

3–2

Notebook Major Components

Maintenance and Service Guide

Illustrated Parts Catalog

Table 3-1

Spare Parts: Notebook Major Components

Spare Part

Number

Item Description

1 Display assemblies

15.0-inch, UXGA+, TFT

15.0-inch, SXGA+, TFT

15.0-inch, XGA, TFT

Miscellaneous Plastics Kit, includes:

Left and right display hinges

RTC battery

Mini PCI communications board shield

Bluetooth cover

Battery bezel

Hard drive cover

Not illustrated:

Notebook feet (4)

LED switch cover

Keyboards (include pointing stick)

Brazil

Czech

Republic

Denmark

Europe

France

French

Canada

Germany

Greece

Greece - Blk

Hungary

Iceland

International

Israel

Italy

341520-201

341520-221

341520-081

341520-A41

341520-051

341520-121

341520-041

378539-151

373646-151

341520-211

341520-DD1

341520-B31

341520-BB1

341520-061

Japan

Korea

Latin America

Norway

Portugal

Russia

Saudi Arabia

Slovenia

Spain

Sweden/Finland

Switzerland

Taiwan

Thailand

Turkey

United Kingdom

United States

Top cover (includes TouchPad and speaker)

345060-001

345059-001

345058-001

345066-001

345063-001

341520-291

341520-AD1

341520-161

341520-091

341520-131

341520-251

341520-171

341520-BA1

341520-071

341520-B71

341520-BG1

341520-AB1

341520-281

341520-141

341520-031

341520-001

345061-001

Maintenance and Service Guide 3–3

Illustrated Parts Catalog

3–4

Notebook Major Components (Continued)

Maintenance and Service Guide

Illustrated Parts Catalog

Table 3-1

Spare Parts: Notebook Major Components (Continued)

Item Description

Miscellaneous Cable Kit, includes:

Spare Part

Number

345056-001

Modem cable

Bluetooth cable

Modem board

Fan assembly

Heat sink (includes grease)

Memory expansion boards, 333-MHz

1024-MB (1.0-GB)

512-MB

256-MB

Processors (include thermal grease)

Intel Pentium M (Banias) processor, 1.7 GHz

Intel Pentium M (Banias) processor, 1.6 GHz

Intel Pentium M (Banias) processor, 1.5 GHz

Intel Pentium M (Banias) processor, 1.4 GHz

Intel Pentium M (Dothan) processor, 1.5 GHz

Intel Pentium M (Dothan) processor, 1.6 GHz

Intel Pentium M (Dothan) processor, 1.7 GHz

Intel Pentium M (Dothan) processor, 1.8 GHz

Intel Pentium M (Dothan) processor, 2.0 GHz

System boards (include thermal grease)

With 128 MB of video memory

With 64 MB of video memory

Trusted Platform Module (TPM)

Integrated smart card

*Not illustrated.

325521-001

345065-001

345067-001

336579-001

336578-001

336577-001

340165-001

319777-001

319776-001

319775-001

359636-001

356596-001

356597-001

345857-001

353395-001

349206-001

345064-001

345856-001

379336-001

Maintenance and Service Guide 3–5

Illustrated Parts Catalog

3–6

Notebook Major Components (Continued)

Maintenance and Service Guide

Illustrated Parts Catalog

Table 3-1

Spare Parts: Notebook Major Components (Continued)

Item Description

14 Mini PCI communications boards

Spare Part

Number

802.11a/b/g LAN NIC

802.11b/g LAN NIC

802.11b W500 modem board (for use in Japan)

802.11b wireless LAN (MOW)

802.11b wireless LAN (ROW)

802.11b/g wireless modem (MOW)

802.11b/g wireless modem (ROW)

Optical drives

24X Max DVD+RW/R and CD-RW Combo Drive

8X Max DVD-ROM Drive

24X Max DVD/CD-RW Combo Drive

24X Max CD-ROM Drive

MultiBay devices

1.44-MB diskette drive

24X Max CD-ROM Drive

8X Max Slim DVD+RW/R and CD-RW Combo Drive

4X Max Reg DVD+RW/R and CD-RW Combo Drive

Base enclosure (includes optical drive shield, hard drive shield, and four notebook feet)

Bluetooth board (includes Bluetooth cable, item 6b)

Hard drives (includes hard drive bezel and frame)

80-GB

60-GB

40-GB

60-GB

5400-rpm

7200-rpm

Battery pack, 8-cell, 4.4 Wh, Li-Ion

(all models)

(nw8000 only)

Battery pack, 8-cell, 4.8AHR

325525-001

325526-001

339742-291

345641-001

345640-001

368247-001

368248-001

349242-001

349241-001

349243-001

349240-001

241995-001

228746-001

251292-001

344256-001

345062-001

348277-001

345632-001

345631-001

345630-001

345855-001

338669-001

360663-001

Maintenance and Service Guide 3–7

Illustrated Parts Catalog

Table 3-1

Spare Parts: Notebook Major Components

Item Description

*Not illustrated.

Spare Part

Number

3–8 Maintenance and Service Guide

3.3 Miscellaneous Plastics

Kit Components

Illustrated Parts Catalog

Miscellaneous Plastics Kit Components

Table 3-2

Miscellaneous Plastics Kit Components

Spare Part Number 345066-001

Item Description

1 Left and right display hinges

RTC battery

Mini PCI communications board shield

Bluetooth cover

Battery bezel

Hard drive cover

Notebook feet (4)

* Integrated smart card bezel

*Not illustrated.

Maintenance and Service Guide 3–9

Illustrated Parts Catalog

3.4 Miscellaneous Cable Kit

Components

Miscellaneous Cable Kit Components

Table 3-3

Miscellaneous Cable Kit Components

Spare Part Number 345056-001

Item Description

Bluetooth cable

Modem cable

3–10 Maintenance and Service Guide

3.5 Mass Storage Devices

Illustrated Parts Catalog

Mass Storage Devices

Table 3-4

Mass Storage Devices

Spare Part Number Information

Item Description

1 Hard drives (includes hard drive bezel and frame)

80-GB 5400-rpm

60-GB 5400-rpm

40-GB 5400-rpm

60-GB 7200-rpm

(all models)

(nw8000 only)

Spare Part

Number

345632-001

345631-001

345630-001

345855-001

Maintenance and Service Guide 3–11

Illustrated Parts Catalog

Table 3-4

Mass Storage Devices

Spare Part Number Information (Continued)

Spare Part

Number Item Description

2 Optical drives

24X Max DVD+RW/R and CD-RW Combo Drive

8X Max DVD-ROM Drive

24X Max DVD/CD-RW Combo Drive

24X Max CD-ROM Drive

3 MultiBay devices

1.44-MB diskette drive

24X Max CD-ROM Drive

8X Max Slim DVD/R+W and CD-RW Combo Drive

4X Max Regular DVD/R+W and CD-RW Combo

Drive

349242-001

349241-001

349243-001

349240-001

135233-001

228746-001

251292-001

344256-001

3–12 Maintenance and Service Guide

Illustrated Parts Catalog

3.6 Miscellaneous

Table 3-5

Spare Parts: Miscellaneous (not illustrated)

Description

Spare Part

Number

AC adapters

90-W, PFC

65-W

Carrying cases

Leather top load, Samsung

Leather top load, SG

Nylon top load, Samsung

Nylon top load, SG

Nylon entry level

Port replicators

Advanced Port Replicator

Common Port Replicator

Power cords

239705-001

239704-001

325817-001

325817-002

325815-001

325815-002

325814-001

339096-001

339097-001

Australia

Brazil

Denmark

Europe/Middle

East/Africa

Israel

246959-011

246959-201

246959-081

246959-021

246959-BB1

Italy

Japan

Korea

Switzerland

United Kingdom

United States

246959-061

246959-291

246959-AD1

246959-AG1

246959-031

246959-001

Screw Kit (includes the following screws; refer to

Appendix C, “Screw Listing” for more information

on screw specifications and usage.)

■

Torx T8M2.0×6.0 screw

■

Torx T8M2.0×4.0 screw

■

Torx T5M2.5×4.0 screw

■

Torx T8M2.0×3.5 screw

345057-001

■

Phillips PM3.0×3.5 screw

■

Phillips PM1.5×4.0 screw

■

Phillips PM1.5×3.0 screw

■

M2.0×10.0 alignment pin

Maintenance and Service Guide 3–13

Illustrated Parts Catalog

3.7 Sequential Part Number Listing

Table 3-6

Spare Parts: Sequential Part Number Listing

Spare Part

Number

228746-001

239704-001

239705-001

241995-001

246959-001

246959-011

246959-021

246959-031

246959-061

246959-081

246959-201

246959-291

246959-AD1

246959-AG1

246959-BB1

251292-001

319775-001

319776-001

319777-001

325521-001

325525-001

Description

24X Max CD-ROM drive

65-watt AC adapter

90-watt, PFC, AC adapter

Diskette drive

3-wire power cord - United States

3-wire power cord - Australia

3-wire power cord - Europe, Middle East, Africa

3-wire power cord - United Kingdom

3-wire power cord - Italy

3-wire power cord - Denmark

3-wire power cord - Brazil

3-wire power cord - Japan

3-wire power cord - Korea

3-wire power cord - Switzerland

3-wire power cord - Israel

8X Max Slim DVD+RW/R and CD-RW combo drive

Intel Pentium M (Banias) processor, 1.4-GHz

Intel Pentium M (Banias) processor, 1.5-GHz

Intel Pentium M (Banias) processor, 1.6-GHz

Modem board (includes cable)

802.11a/b/g LAN board mini PCI communications board

3–14 Maintenance and Service Guide

Illustrated Parts Catalog

Table 3-6

Spare Parts: Sequential Part Number Listing (Continued)

Spare Part

Number

325526-001

325814-001

325815-001

325815-002

325817-001

325817-002

336577-001

336578-001

336579-001

338669-001

339096-001

339097-001

339742-291

340165-001

341520-001

341520-031

341520-041

341520-051

341520-061

341520-071

341520-081

341520-091

Description

802.11b/g LAN board mini PCI communications board

Nylon, entry level

Nylon, top load, Samsung

Nylon, top load, SG

Leather, top load, Samsung

Leather, top load, SG

Memory expansion board, 333 MHz, 256-MB DDR

Memory expansion board, 333 MHz, 512-MB DDR

Memory expansion board, 333 MHz, 1024-MB DDR

Battery pack, 8-cell, 4.4 Wh, Li-ion

Advanced Port Replicator

Simple Port Replicator

802.11b W500 modem board (for use in Japan) mini PCI communications board

Intel Pentium M (Banias) processor, 1.7-GHz

Keyboard (including pointing stick) - United States

Keyboard (including pointing stick) - United Kingdom

Keyboard (including pointing stick) - Germany

Keyboard (including pointing stick) - France

Keyboard (including pointing stick) - Italy

Keyboard (including pointing stick) - Spain

Keyboard (including pointing stick) - Denmark

Keyboard (including pointing stick) - Norway

Maintenance and Service Guide 3–15

Illustrated Parts Catalog

Table 3-6

Spare Parts: Sequential Part Number Listing (Continued)

Spare Part

Number

341520-121

341520-131

341520-141

341520-161

341520-171

341520-201

341520-211

341520-221

341520-251

341520-281

341520-291

341520-A41

341520-AB1

341520-AD1

341520-B31

341520-B71

341520-BA1

341520-BB1

341520-BG1

341520-DD1

344256-001

345056-001

345057-001

Description

Keyboard (including pointing stick) - French Canada

Keyboard (including pointing stick) - Portugal

Keyboard (including pointing stick) - Turkey

Keyboard (including pointing stick) - Latin America

Keyboard (including pointing stick) - Saudi Arabia

Keyboard (including pointing stick) - Brazil

Keyboard (including pointing stick) - Hungary

Keyboard (including pointing stick) - Czech Republic

Keyboard (including pointing stick) - Russia

Keyboard (including pointing stick) - Thailand

Keyboard (including pointing stick) - Japan

Keyboard (including pointing stick) - European

Keyboard (including pointing stick) - Taiwan

Keyboard (including pointing stick) - Korea

Keyboard (including pointing stick) - International

Keyboard (including pointing stick) - Sweden/Finland

Keyboard (including pointing stick) - Slovenia

Keyboard (including pointing stick) - Israel

Keyboard (including pointing stick) - Switzerland

Keyboard (including pointing stick) - Iceland

4X Max Reg DVD+RW/R and CD-RW combo drive

Miscellaneous Cable Kit

Misc Screw Kit

3–16 Maintenance and Service Guide

Illustrated Parts Catalog

345063-001

345064-001

345065-001

345066-001

345067-001

345630-001

345631-001

345632-001

345640-001

345641-001

345855-001

345856-001

345857-001

348277-001

349206-001

349240-001

349241-001

Table 3-6

Spare Parts: Sequential Part Number Listing (Continued)

Spare Part

Number

345058-001

345059-001

345060-001

345061-001

345062-001

Description

Display assembly, 15.0-inch, XGA, TFT

Display assembly, 15.0-inch, SXGA+, TFT

Display assembly, 15.0-inch, UXGA+, TFT

Top cover (includes TouchPad and speaker)

Base enclosure (includes optical drive shield, hard drive shield, and four notebook feet)

LED switch cover

System board (includes 64-MB discrete video memory)

Fan assembly

Misc Plastics Kit

Heat sink

40-GB (5400-rpm) hard drive

60-GB (5400-rpm) hard drive

80-GB (5400-rpm) hard drive

802.11b wireless LAN (ROW) Wireless LAN card

802.11b wireless LAN (MOW) Wireless LAN card

60-GB (7200-rpm) hard drive (nw8000 only)

Trusted Platform Module (TPM)

Intel Pentium M (Dothan) processor, 1.8 GHz

Bluetooth wireless communications board

System board (includes 128-MB discrete video memory)

24X Max CD-ROM Drive

8X Max DVD-ROM drive

Maintenance and Service Guide 3–17

Illustrated Parts Catalog

Table 3-6

Spare Parts: Sequential Part Number Listing (Continued)

Spare Part

Number

349242-001

349243-001

353395-001

356596-001

356597-001

359636-001

360663-001

365438-001

368247-001

368248-001

373646-151

378539-151

379336-001

Description

24X Max DVD+RW/R and CD-RW combo drive

24X Max DVD/CD-RW combo drive

Intel Pentium M (Dothan) processor, 2.0 GHz

Intel Pentium M (Dothan) processor, 1.6 GHz

Intel Pentium M (Dothan) processor, 1.7 GHz

Intel Pentium M (Dothan) processor, 1.5 GHz

Battery pack, 8-cell, 4.8AHR

60-GB (7200-rpm) hard drive (includes bezel and frame)

802.11b/g modem board (MOW) mini PCI communications board

802.11b/g modem board (ROW) mini PCI communications board

Keyboard (including pointing stick) - Greece Bk

Keyboard (including pointing stick) - Greece

Integrated smart card

3–18 Maintenance and Service Guide

Removal and Replacement

Preliminaries

This chapter provides essential information for proper and safe removal and replacement service.

4.1 Tools Required

You need the following tools to complete the removal and replacement procedures:

■

Magnetic screw driver

Phillips P0 screw driver

Torx8 screw driver

Torx7 pin bit screw driver

✎

Some computer models have two Torx7 with pin security screws

(M2.0×4.0) securing the Mini PCI communications board to the computer. A T7 pin bit screw driver is required to remove the

Mini PCI communications board on these computer models.

Refer to Section 5.12, “Mini PCI Communications Board,” for more information on removing Mini PCI communications boards.

■

5.0-mm socket for system board standoffs

Flat-bladed screwdriver

Maintenance and Service Guide 4–1

Removal and Replacement Preliminaries

4.2 Service Considerations

The following sections include some of the considerations that you should keep in mind during disassembly and assembly procedures.

✎

As you remove each subassembly from the notebook, place the subassembly (and all accompanying screws) away from the work area to prevent damage.

Plastic Parts

Using excessive force during disassembly and reassembly can damage plastic parts. Use care when handling the plastic parts.

Apply pressure only at the points designated in the maintenance instructions.

Cables and Connectors

Ä CAUTION: When servicing the notebook, ensure that cables are placed in their proper locations during the reassembly process.

Improper cable placement can damage the notebook.

Cables must be handled with extreme care to avoid damage.

Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Ensure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables tear easily.

4–2 Maintenance and Service Guide

Removal and Replacement Preliminaries

4.3 Preventing Damage to

Removable Drives

■

Removable drives are fragile components that must be handled with care. To prevent damage to the notebook, damage to a removable drive, or loss of information, observe the following precautions:

■ Before removing or inserting a hard drive, shut down the notebook. If you are unsure whether the notebook is off or in hibernation, turn the notebook on, then shut it down.

■ Before removing a diskette drive or optical drive, ensure that a diskette or disc is not in the drive. Ensure that the optical drive tray is closed.

■ Before handling a drive, ensure that you are discharged of static electricity. While handling a drive, avoid touching the connector.

■ Handle drives on surfaces that have at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.

■ Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective packaging and label the package “FRAGILE: Handle With Care.”

Maintenance and Service Guide 4–3

Removal and Replacement Preliminaries

4.4 Preventing Electrostatic Damage

Many electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases the discharge contains enough power to alter device parameters or melt silicon junctions.

A sudden discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.

Often the spark is neither felt nor heard, but damage occurs.

An electronic device exposed to electrostatic discharge might not be affected at all and can work perfectly throughout a normal life cycle. Or the device might function normally for a while, then degrade in the internal layers, reducing its life expectancy.

4–4 Maintenance and Service Guide

Removal and Replacement Preliminaries

4.5 Packaging and Transporting

Precautions

Use the following grounding precautions when packaging and transporting equipment:

■ To avoid hand contact, transport products in static-safe containers, such as tubes, bags, or boxes.

■ Protect all electrostatic-sensitive parts and assemblies with conductive or approved containers or packaging.

■ Keep electrostatic-sensitive parts in their containers until the parts arrive at static-free workstations.

■ Place items on a grounded surface before removing them from their containers.

■ Always be properly grounded when touching a sensitive component or assembly.

■ Store reusable electrostatic-sensitive parts from assemblies in protective packaging or nonconductive foam.

■ Use transporters and conveyors made of antistatic belts and roller bushings. Ensure that mechanized equipment used for moving materials is wired to ground and that proper materials are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate electric charges.

Maintenance and Service Guide 4–5

Removal and Replacement Preliminaries

4.6 Workstation Precautions

■

Use the following grounding precautions at workstations:

■ Cover the workstation with approved static-shielding material (refer to

Table 4-2

■ Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and equipment.

■ Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

■ When using fixtures that must directly contact dissipative surfaces, use only fixtures made of static-safe materials.

■ Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and Styrofoam.

■ Handle electrostatic-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these items only at static-free workstations.

Avoid contact with pins, leads, or circuitry.

Turn off power and input signals before inserting or removing connectors or test equipment.

4–6 Maintenance and Service Guide

Removal and Replacement Preliminaries

4.7 Grounding Equipment and

Methods

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

■ When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times. On grounded mats with banana-plug connectors, connect a wrist strap with alligator clips.

■ When standing, use foot straps and a grounded floor mat.

Foot straps (heel, toe, or boot straps) can be used at standing workstations and are compatible with most types of shoes or boots. On conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one-megohm resistance between the operator and ground. To be effective, the conductive strips must be worn in contact with the skin.

■

Other grounding equipment recommended for use in preventing electrostatic damage includes

■

Antistatic tape.

Antistatic smocks, aprons, and sleeve protectors.

Conductive bins and other assembly or soldering aids.

Nonconductive foam.

Conductive tabletop workstations with ground cords of one-megohm resistance.

■ Static-dissipative tables or floor mats with hard ties to the ground.

Field service kits.

Static awareness labels.

Material-handling packages.

Nonconductive plastic bags, tubes, or boxes.

Metal tote boxes.

Electrostatic voltage levels and protective materials.

Maintenance and Service Guide 4–7

Removal and Replacement Preliminaries

Table 4-1 shows how humidity affects the electrostatic voltage levels generated by different activities.

Table 4-1

Typical Electrostatic Voltage Levels

Event

Walking across carpet

Walking across vinyl floor

Motions of bench worker

Removing DIPS from plastic tube

Removing DIPS from vinyl tray

Removing DIPS from Styrofoam

Removing bubble pack from PCB

10%

35,000 V

Relative Humidity

40% 55%

15,000 V 7,500 V

12,000 V

6,000 V

2,000 V

11,500 V

14,500 V

26,500 V

5,000 V

800 V

700 V

4,000 V

5,000 V

20,000 V

3,000 V

400 V

2,000 V

3,500 V

7,000 V

Packing PCBs in foam-lined box 21,000 V

✎

A product can be degraded by as little as 700 V.

11,000 V 5,000 V

Table 4-2 lists the shielding protection provided by antistatic bags and floor mats.

Material

Antistatic plastic

Carbon-loaded plastic

Metallized laminate

Table 4-2

Static-Shielding Materials

Use

Bags

Floor mats

Voltage Protection Level

1,500 V

7,500 V

5,000 V

4–8 Maintenance and Service Guide

Removal and Replacement

Procedures

This chapter provides removal and replacement procedures.

There are 62 screws in eight different sizes that must be removed, replaced, and loosened when servicing the notebook. Make note of each screw size and location during removal and replacement.

Refer to Appendix C, “Screw Listing” for detailed information on

screw sizes, locations, and usage.

Maintenance and Service Guide 5–1

Removal and Replacement Procedures

5.1 Serial Number

Report the notebook serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the notebook.

Serial Number Location

5–2 Maintenance and Service Guide

Removal and Replacement Procedures

5.8

5.9

5.10

5.11

5.12

5.13

5.4

5.5

5.6

5.7

5.14

5.15

5.16

5.17

5.18

5.19

5.2 Disassembly Sequence Chart

Use the chart below to determine the section number to be referenced when removing notebook components.

Section

5.3

Disassembly Sequence Chart

Description

# of Screws

Removed

Preparing the notebook for disassembly

Battery pack

Hard drive

1 to remove

4 screws and

2 alignment pins to disassemble

Notebook feet 0

MultiBay device

Bluetooth board

Integrated smart card

Optical drive

Keyboard

Memory expansion board

Modem board

Mini PCI communications board

Heat sink

Processor

LED switch cover

RTC battery

Security Module (TPM)

Display assembly

Top cover

Maintenance and Service Guide 5–3

Removal and Replacement Procedures

Section

5.20

5.21

5.22

5.23

Disassembly Sequence Chart (Continued)

Description

Speaker

TouchPad

Fan assembly

System board

# of Screws

Removed

5–4 Maintenance and Service Guide

Removal and Replacement Procedures

5.3 Preparing the Notebook for

Disassembly

Before you begin any removal or installation procedures:

1. Save your work, exit all applications, and shut down the notebook. If you are not sure whether the notebook is off or in hibernation, briefly press the power button. If your work returns to the screen, save your work, exit all applications, and then shut down the notebook.

2. Disconnect all external devices connected to the notebook.

3. Disconnect the power cord.

Maintenance and Service Guide 5–5

Removal and Replacement Procedures

Spare Part Number Information

Battery pack, 8-cell, 4.4 Wh, Li-Ion

Battery pack, 8-cell, 4.8AHR

338669-001

360663-001

4. Remove the battery pack by following these steps: a.

Turn the notebook upside down with the front facing you.

Slide and hold the battery release latch 1 toward the back of the notebook.

Use the notch in the battery pack to slide the battery pack to the right 2.

d. Remove the battery pack.

5–6

Removing the Battery Pack

Maintenance and Service Guide

Removal and Replacement Procedures

5. Remove the battery bezel by sliding it down and off of the battery pack.

✎

The battery bezel is included in the Miscellaneous Plastics Kit, spare part number 345066-001.

Removing the Battery Bezel

Reverse the above procedure to install the battery pack and battery bezel.

Maintenance and Service Guide 5–7

Removal and Replacement Procedures

6. Remove the hard drive by following these steps:

Spare Part Number Information

Hard drives (includes hard drive bezel and frame)

80-GB 5400-rpm

60-GB 5400-rpm

40-GB 5400-rpm

60-GB 7200-rpm

(all models)

(nw8000 only)

345632-001

345631-001

345630-001

345855-001 a.

Turn the notebook upside down with the front facing you.

Remove the T8M2.0×6.0 hard drive cover screw 1.

Slide and hold the tab on the hard drive cover to the left 2.

d. Swing the right edge of the hard drive cover up and to the left 3.

✎

The hard drive cover is included in the Miscellaneous Plastics

Kit, spare part number 345066-001.

5–8

Removing the Hard Drive Cover

Maintenance and Service Guide

Removal and Replacement Procedures e.

Use the Mylar tab 1 to slide the hard drive to the right 2 to disconnect it from the system board.

Lift the hard drive straight up to remove it 3.

Removing the Hard Drive

Maintenance and Service Guide 5–9

Removal and Replacement Procedures g. Remove the two T5M2.5×4.0 screws 1 and the two PM3.0×3.5 screws 2 that secure the hard drive to the hard drive frame.

h. Use a 4.0-mm socket to remove the two M2.0×10.0 alignment pins 3 that secure the hard drive to the hard drive frame.

Remove the hard drive 4 from the hard drive frame.

Remove the hard drive connector 5 from the hard drive.

5–10

Disassembling the Hard Drive

Reverse the above procedure to assemble and install the hard drive.

Maintenance and Service Guide

Removal and Replacement Procedures

5.4 Notebook Feet

The notebook feet are adhesive-backed rubber pads. The feet are included in the Miscellaneous Plastics Kit, spare part number

345066-001. The feet attach to the base enclosure as illustrated below.

Notebook Feet Locations

Maintenance and Service Guide 5–11

Removal and Replacement Procedures

5.5 MultiBay Device

Spare Part Number Information

1.44-MB diskette drive

24X Max CD-ROM Drive

8X Max DVD+RW/R and CD-RW Combo Drive

24X Max DVD+RW/R and CD-RW Combo Drive

135233-001

228746-001

251292-001

344256-001

1. Prepare the notebook for disassembly (refer to

2. Turn the notebook upside down with the left side facing you.

3. Slide and hold the MultiBay release latch toward you 1.

4. Use the notch in the MultiBay device to slide the device out of the MultiBay 2.

5. Remove the MultiBay device.

5–12

Removing a MultiBay Device

Reverse the above procedure to install a MultiBay device.

Maintenance and Service Guide

Removal and Replacement Procedures

5.6 Bluetooth Board

Spare Part Number Information

Bluetooth board (includes cable) 348277-001

1. Prepare the notebook for disassembly (refer to

2. Turn the notebook upside down with the left side facing you.

3. Remove the T8M2.0×6.0 screw 1 that secures the Bluetooth cover to the notebook.

4. Lift the cover straight up to remove it 2.

✎

The Bluetooth cover is included in the Miscellaneous Plastics Kit, spare part number 345066-001.

Removing the Bluetooth Cover

Maintenance and Service Guide 5–13

Removal and Replacement Procedures

5. Disconnect the Bluetooth cable from the Bluetooth board 1 and the system board 2.

✎

The Bluetooth cable is included with the Bluetooth board and is also included in the Miscellaneous Cables Kit, spare part number

345056-001.

6. Remove the two PM1.5×3.0 screws 3 that secure the

Bluetooth board to the Bluetooth cover.

7. Remove the board from the cover 4.

5–14

Removing the Bluetooth Board

Reverse the above procedure to install the Bluetooth board.

Maintenance and Service Guide

Removal and Replacement Procedures

5.7 Integrated Smart Card

Spare Part Number Information

Integrated smart card 379336-001

✎

The integrated smart card is located in the bottom PC Card slot.

1. Prepare the notebook for disassembly (refer to

2. Remove any PC Card or spacer from the top PC Card slot.

3. Using a flat-bladed tool, pry the smart card bezel off of the notebook 1. The bezel releases from the notebook with a small amount of force.

4. Remove the bezel from the notebook 2.

Removing the Smart Card Bezel

Maintenance and Service Guide 5–15

Removal and Replacement Procedures

✎

The integrated smart card bezel is included in the Miscellaneous

Plastics Kit, spare part number 345066-001.

5. Eject the smart card from the notebook using a flat-bladed tool to press the small metal eject tab 1 to the left of the smart card.

6. Remove the card from the slot 2.

5–16

Removing the Smart Card

Reverse the above procedure to install the integrated smart card.

Maintenance and Service Guide

Removal and Replacement Procedures

5.8 Optical Drive

Spare Part Number Information

24X Max DVD+RW/R and CD-RW Combo Drive

8X Max DVD-ROM Drive

24X Max DVD/CD-RW Combo Drive

24X Max CD-ROM Drive

349242-001

349241-001

349243-001

349240-001

1. Prepare the notebook for disassembly (refer to

2. Turn the notebook upside down with the right side facing you.

3. Remove the T8M2.0×6.0 screw 1 that secures the optical drive to the notebook.

4. Insert a paper clip or similar tool into the optical drive release hole to open the optical drive tray 2.

5. Use the optical drive tray to remove the optical drive 3.

Removing the Optical Drive

Reverse the above procedure to install the optical drive.

Maintenance and Service Guide 5–17

Removal and Replacement Procedures

5.9 Keyboard

Spare Part Number Information

Keyboards (include pointing stick)

Brazil

Czech Republic

Denmark

Europe

France

French Canada

Germany

Greece

Greece - Blk

Hungary

Iceland

International

Israel

Italy

Japan

341520-201

341520-221

341520-081

341520-A41

341520-051

341520-121

341520-041

378539-151

373646-151

341520-211

341520-DD1

341520-B31

341520-BB1

341520-061

341520-291

Korea

Latin America

Norway

Portugal

Russia

Saudi Arabia

Slovenia

Spain

Sweden/Finland

Switzerland

Taiwan

Thailand

Turkey

United Kingdom

United States

341520-AD1

341520-161

341520-091

341520-131

341520-251

341520-171

341520-BA1

341520-071

341520-B71

341520-BG1

341520-AB1

341520-281

341520-141

341520-031

341520-001

1. Prepare the notebook for disassembly (refer to

2. Turn the notebook upside down with the front facing you.

5–18 Maintenance and Service Guide

Removal and Replacement Procedures

3. Remove the T8M2.×6.0 screw that secures the keyboard to the notebook.

Removing the Keyboard Screw

Maintenance and Service Guide 5–19

Removal and Replacement Procedures

4. Turn the notebook right-side up with the front facing you.

5. Open the notebook.

6. Slide the four tabs 1 on the top edge of the keyboard toward you.

7. Lift the rear edge of the keyboard up and swing it toward you 2 until it rests on the palm rest.

Releasing the Keyboard

5–20 Maintenance and Service Guide

Removal and Replacement Procedures

8. Release the zero insertion force (ZIF) connector 1 to which the pointing stick cable is attached and disconnect the cable 2.

9. Release the ZIF connector 3 to which the keyboard cable is attached and disconnect the cable 4.

Disconnecting the Keyboard Cables

10. Remove the keyboard.

Reverse the above procedure to install the keyboard.

Maintenance and Service Guide 5–21

Removal and Replacement Procedures

5.10 Memory Expansion Board

Spare Part Number Information

1024 MB (1.0 GB), 333 MHz

512 MB, 333 MHz

256 MB, 333 MHz

336579-001

336578-001

336577-001

1. Prepare the notebook for disassembly (refer to

3. Spread the retaining tabs 1 that secure the memory expansion board to the socket. The free end of the board rises.

4. Pull the board away from the socket at a 45-degree angle 2.

5–22

Removing a Memory Expansion Board

Reverse the above procedure to install a memory expansion board.

Maintenance and Service Guide

Removal and Replacement Procedures

5.11 Modem Board

Spare Part Number Information

Modem board 325521-001

1. Prepare the notebook for disassembly (refer to

1. Prepare the notebook for disassembly (refer to Section 5.3).

3. Remove the two T8M2.0×4.0 screws 1 that secure the modem board to the notebook.

4. Lift up on the right side of the modem board 2 to disconnect the board from the system board.

Removing the Modem Board Screws

Maintenance and Service Guide 5–23

Removal and Replacement Procedures

5. Turn the modem board upside down 1.

6. Disconnect the modem cable 2 from the modem.

Disconnecting the Modem Board Cable

7. Remove the modem board.

Reverse the above procedure to install the modem board.

5.12 Mini PCI Communications Board

Spare Part Number Information

802.11a/b/g LAN NIC

802.11b/g LAN NIC

802.11b W500 modem board (for use in Japan)

802.11b wireless LAN (MOW)

802.11b wireless LAN (ROW)

802.11b/g wireless modem (MOW)

802.11b/g wireless modem (ROW)

325525-001

325526-001

339742-291

345641-001

345640-001

368247-001

368248-001

2. Release the keyboard (refer to Section 5.9).

5–24 Maintenance and Service Guide

Removal and Replacement Procedures

✎

Some computer models have two Torx7 with pin security screws

(M2.0×4.0) securing the Mini PCI communications board to the computer. A T7 pin bit screw driver is required to remove the

Mini PCI communications board on these computer models.

3. Remove the two T8M2.0×4.0 screws 1 that secure the Mini

PCI communications board shield to the notebook.

4. Lift up on the left side of the shield 2 and slide it to the left 3 to remove it.

✎

The Mini PCI communications board shield is included in the

Miscellaneous Plastics Kit, spare part number 345066-001.

Removing the Mini PCI Communications Board Shield

Maintenance and Service Guide 5–25

Removal and Replacement Procedures

5. Disconnect the two antenna cables 1 from the board.

Make note of which cable connects to which terminal.

6. Spread the retaining tabs 2 that secure the Mini PCI communications board to the socket. The free end of the board rises.

7. Pull the board away from the socket at a 45-degree angle 3.

5–26

Removing the Mini PCI Communications Board

8. Remove the Mini PCI communications board.

Reverse the above procedure to install the Mini PCI communications board.

Maintenance and Service Guide

Removal and Replacement Procedures

5.13 Heat Sink

Spare Part Number Information

Heat sink (includes grease) 345067-001

1. Prepare the notebook for disassembly (refer to

3. Remove the five T8M2.0×4.0 screws 1 that secure the heat sink to the notebook.

4. Lift the front edge of the heat sink 2 to unseat the adhesive grip of the thermal grease on the processor.

5. Swing the heat sink in a counterclockwise motion 3 until the back of the heat sink 4 clears the notebook.

Removing the Heat Sink

6. Remove the heat sink.

Maintenance and Service Guide 5–27

Removal and Replacement Procedures

✎

Carefully clean any thermal grease residue from the heat sink 1 and processor surfaces 2 each time you remove the heat sink.

Apply new thermal grease to both surfaces.

Removing the Thermal Grease From the Heat Sink and Processor

Reverse the above procedure to install the heat sink.

5–28 Maintenance and Service Guide

Removal and Replacement Procedures

5.14 Processor

Spare Part Number Information

Processors (include grease)

Intel Pentium M (Banias) processor, 1.7 GHz

Intel Pentium M (Banias) processor, 1.6 GHz

Intel Pentium M (Banias) processor, 1.5 GHz

Intel Pentium M (Banias) processor, 1.4 GHz

Intel Pentium M (Dothan) processor, 1.5 GHz

Intel Pentium M (Dothan) processor, 1.6 GHz

Intel Pentium M (Dothan) processor, 1.7 GHz

Intel Pentium M (Dothan) processor, 1.8 GHz

Intel Pentium M (Dothan) processor, 2.0 GHz

340165-001

319777-001

319776-001

319775-001

359636-001

356596-001

356597-001

345857-001

353395-001

1. Prepare the notebook for disassembly (refer to

3. Remove the heat sink (refer to

Section 5.13

Maintenance and Service Guide 5–29

Removal and Replacement Procedures

4. Use a flat-bladed screwdriver to turn the processor locking screw one-quarter turn counterclockwise 1.

5. Remove the processor from the system board socket 2.

✎

Note that the gold triangle 3 on the processor should be aligned in the front left corner when you install the processor.

5–30

Removing the Processor

Reverse the above procedure to install the processor.

Maintenance and Service Guide

Removal and Replacement Procedures

5.15 LED Switch Cover

LED switch cover

Spare Part Number Information

345063-001

1. Prepare the notebook for disassembly (refer to

2. Turn the notebook upside down with the rear facing you.

3. Remove the T8M2.0×6.0 screw that secures the LED switch cover to the notebook.

Removing the LED Switch Cover Screw

Maintenance and Service Guide 5–31

Removal and Replacement Procedures

4. Turn the notebook right-side up with the front facing you.

5. Open the notebook.

6. Lift the left 1 and right 2 sides of the LED switch cover to disengage the cover from the notebook.

7. Remove the LED switch cover.

5–32

Removing the LED Switch Cover

Reverse the above procedure to install the LED switch cover.

Maintenance and Service Guide

Removal and Replacement Procedures

5.16 RTC Battery

✎

The RTC battery is included in the Miscellaneous Plastics Kit, spare part number 345066-001.

1. Prepare the notebook for disassembly (refer to

2. Remove the LED switch cover (refer to

3. Disconnect the RTC battery cable 1 from the system board.

4. Slide the RTC battery out of the clips in the top cover 2 and remove the battery.

Removing the RTC Battery

Reverse the above procedure to install the RTC battery.

Maintenance and Service Guide 5–33

Removal and Replacement Procedures

5.17 Security Module (TPM)

Spare Part Number Information

Security Module (TPM) 345856-001

1. Prepare the notebook for disassembly (refer to

2. Remove the LED switch cover (refer to

3. Remove the PM3.5×3.0 screw 1 that secures the security card to the system board.

4. Lift the security module straight up 2 to disconnect it from the system board.

5–34

Removing the TPM Security Module

Reverse the above procedure to install the security card.

Maintenance and Service Guide

Removal and Replacement Procedures

5.18 Display Assembly

Spare Part Number Information

15.0-inch, UXGA, TFT

15.0-inch, SXGA+, TFT

15.0-inch, XGA, TFT

345060-001

345059-001

345058-001

1. Prepare the notebook for disassembly (refer to

2. Remove the keyboard (refer to Section 5.9

3. Disconnect the wireless antenna cables from the Mini PCI

wireless communications board (refer to Section 5.12

4. Remove the LED switch cover (refer to

5. Disconnect the display cable 1 from the system board.

6. Remove the wireless antenna cables from the opening 2 and the clips 3 in the top cover.

Disconnecting the Display Cables

Maintenance and Service Guide 5–35

Removal and Replacement Procedures

7. Position the notebook with the rear facing toward you.

8. Remove the two T8M2.0×6.0 screws 1 that secure the display hinge covers to the notebook.

9. Remove the two T8M2.0×6.0 screws 2 that secure the display assembly to the notebook.

Removing the Display Screws

5–36 Maintenance and Service Guide

Removal and Replacement Procedures

10. Lift the display assembly straight up 1 to remove it from the notebook.

11. If necessary, remove the display hinge covers 2 from the display assembly.

✎

The display hinge covers are included in the Miscellaneous

Plastics Kit, spare part number 345066-001.

Removing the Display Assembly

Reverse the above procedure to install the display assembly.

Maintenance and Service Guide 5–37

Removal and Replacement Procedures

5.19 Top Cover

Spare Part Number Information

Top cover (includes TouchPad and speaker) 345061-001

1. Prepare the notebook for disassembly (refer to

2. Remove the keyboard (refer to Section 5.9

3. Remove the LED switch cover (refer to

4. Remove the display assembly (refer to

Section 5.18

5. Turn the notebook upside down with the front facing you.

6. Remove the 17 T8M2.0×6.0 screws that secure the top cover to the notebook.

5–38

Removing the Top Cover Screws

Maintenance and Service Guide

Removal and Replacement Procedures

7. Turn the notebook right-side up with the front facing you.

8. Remove the TM2.0×4.0 screw 1 near the fan that secures the top cover to the notebook.

9. Lift the front edge of the top cover 2 until the speaker cable 3, TouchPad cable 4, and microphone cable 5 are accessible.

Releasing the Top Cover

Maintenance and Service Guide 5–39

Removal and Replacement Procedures

10. Disconnect the speaker 1 and microphone cables 2.

11. Release the ZIF connector 3 to which the TouchPad cable is attached and disconnect the TouchPad cable 4 from the system board.

5–40

Disconnecting the Top Cover Cables

12. Remove the top cover.

Reverse the above procedure to install the top cover.

Maintenance and Service Guide

Removal and Replacement Procedures

5.20 Speaker

✎

The speaker is included with the top cover, spare part number

345061-001.

1. Prepare the notebook for disassembly (refer to

and remove the following components:

❏

Keyboard (refer to

)

2. Turn the top cover upside down with the rear facing you.

3. Remove the five T8M2.0×4.0 screws 1 and one T8M2.0×6.0 screw 2 that secure the speaker to the top cover.

4. Remove the speaker 3 from the top cover.

Removing the Speaker

Reverse the above procedure to install the speaker.

Maintenance and Service Guide 5–41

Removal and Replacement Procedures

5.21 TouchPad

✎

The TouchPad and bracket are included with the top cover, spare part number 345061-001.

1. Prepare the notebook for disassembly (refer to

Keyboard (refer to Section 5.9

and remove the following components:

❏

Speaker (refer to

)

2. Remove the three Torx T8M2.0×3.5 screws 1 that secure the TouchPad and bracket to the top cover.

3. Lift the left side of the bracket 2, then slide the bracket to the left.

5–42

Removing the TouchPad Bracket

Maintenance and Service Guide

Removal and Replacement Procedures

4. Remove the bracket.

5. Remove the TouchPad 1 from the top cover.

6. Release the ZIF connector 2 to which the TouchPad cable is attached and disconnect the cable 3.

Removing the TouchPad

Reverse the above procedure to install the TouchPad and bracket.

Maintenance and Service Guide 5–43

Removal and Replacement Procedures

5.22 Fan Assembly

Spare Part Number Information

Fan assembly 345065-001

1. Prepare the notebook for disassembly (refer to

and remove the following components:

❏

Keyboard (refer to

Heat sink (refer to

Memory expansion boards (refer to Section 5.10

)

5–44 Maintenance and Service Guide

Removal and Replacement Procedures

2. Disconnect the fan cable 1.

3. Remove the T8M2.0×4.0 screw 2 that secures the fan assembly to the notebook.

4. Remove the fan assembly 3 from the notebook.

5. Remove the three PM1.5×4.0 screws 4 that secure the fan to the fan housing.

6. Remove the fan 5.

Removing the Fan

Reverse the above procedure to install the fan.

Maintenance and Service Guide 5–45

Removal and Replacement Procedures

5.23 System Board

Spare Part Number Information

System board with 128 MB of video memory

System board with 64 MB of video memory

✎

Both system boards include thermal grease.

349206-001

345064-001

✎

When replacing the system board, ensure that the following components are removed from the defective system board and installed on the replacement system board:

■

Mini PCI communications board (refer to Section 5.12

Modem board (refer to

Section 5.11

)

Heat sink (refer to Section 5.13

Real time clock battery (refer to Section 5.16

Processor (refer to

Section 5.14

)

)

Security card (refer to Section 5.17

1. Prepare the notebook for disassembly (refer to

Keyboard (refer to Section 5.9

and remove the following components:

❏

Fan (refer to Section 5.22

Top cover (refer to

5–46 Maintenance and Service Guide

Removal and Replacement Procedures

2. Remove the four T8M2.0×4.0 screws that secure the system board to the notebook.

Removing the System Board Screws

Maintenance and Service Guide 5–47

Removal and Replacement Procedures

3. Flex and hold the front right corner of the base enclosure out 1 to allow the system board to clear the base enclosure.

4. Lift the front edge of the system board 2 until the board clears the base enclosure.

5. Slide the system board toward you 3 to remove it from the notebook.

Removing the System Board

5–48 Maintenance and Service Guide

Removal and Replacement Procedures

6. If necessary, disconnect the modem cable from the system board and remove the cable.

✎

The modem cable is included in the Miscellaneous Cables Kit, spare part number 345056-001.

Removing the Modem Cable

Reverse the above procedure to install the modem cable and system board.

Maintenance and Service Guide 5–49

Specifications

This chapter provides physical and performance specifications.

Table 6-1

Notebook

Dimensions

Height

Width

Depth

4.1 cm

32.6 cm

27.5 cm

1.61 in

12.83 in

10.83 in

Weight (with main battery pack and MultiBay weight saver)

2.95 kg 6.50 lb

Stand-alone power requirements

Nominal operating voltage (Li-Ion)

Maximum operating power

Peak operating power

14.4 VDC

60.0 W

65.0 W

Temperature

Operating (not writing optical drive)

Nonoperating

10°C to 35°C 50°F to 95°F

-20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

Operating

Nonoperating

10% to 90%

5% to 90%, 38.7°C (101.6°F) maximum wet bulb temperature

Maintenance and Service Guide 6–1

Specifications

Altitude (unpressurized)

Table 6-1

Notebook (Continued)

Operating (14.7 to

10.1 psia)

Nonoperating (14.7 to

4.4 psia)

Shock

0 to 3,048 m

0 to 9,144 m

0 to 10,000 ft

0 to 30,000 ft

Operating

Nonoperating

40 g, 2 ms, half-sine

240 g, 2 ms, half-sine

✎

Applicable product safety standards specify thermal limits for plastic surfaces. The notebook operates well within this range of temperatures.

6–2 Maintenance and Service Guide

Specifications

Dimensions

Height

Width

Diagonal

Number of colors

Contrast ratio

Brightness

Pixel resolution

Pitch

Format

Configuration

Backlight

Character display

Total power consumption

Viewing angle

Table 6-2

15.0-inch, UXGA, TFT Display

29.9 cm

22.8 cm

38.1 cm

Up to 16.8 million

250:1

140 nits typical

0.191 × 0.191 mm

1680 × 1200

RGB vertical stripe

Edge lit

80 × 25

6.5 W

11.8 in

9.0 in

15.0 in

+/- 85° horizontal, +15/-35° vertical typical

Maintenance and Service Guide 6–3

Specifications

Dimensions

Height

Width

Diagonal

Number of colors

Contrast ratio

Brightness

Pixel resolution

Pitch

Format

Configuration

Backlight

Character display

Total power consumption

Viewing angle

Table 6-3

15.1-inch, SXGA+, TFT Display

29.9 cm

22.8 cm

38.1 cm

Up to 16.8 million

150:1

150 nits typical

0.218 × 0.218 mm

1400 × 1050

RGB vertical stripe

Edge lit

80 × 25

5.75 W

11.8 in

9.0 in

15.0 in

+/- 35° horizontal, +15/-35° vertical typical

6–4 Maintenance and Service Guide

Specifications

Dimensions

Height

Width

Diagonal

Number of colors

Contrast ratio

Brightness

Pixel resolution

Pitch

Format

Configuration

Backlight

Character display

Total power consumption

Viewing angle

Table 6-4

15.0-inch, XGA, TFT Display

29.9 cm

22.8 cm

38.1 cm

Up to 16.8 million

150:1

150 nits typical

0.264 × 0.264 mm

1280 × 800

RGB vertical stripe

Edge lit

80 × 25

5.75 W

11.8 in

9.0 in

15.0 in

+/- 35° horizontal, +15/-35° vertical typical

Maintenance and Service Guide 6–5

Specifications

Table 6-5

Hard Drives

User capacity per drive

Dimensions

Height

Width

Weight

Interface type

Transfer rate

Synchronous (maximum)

Security

80-GB

80 GB

9.5 mm

70 mm

99 g

ATA-5

60-GB

60 GB

9.5 mm

70 mm

99 g

ATA-5

40-GB

40 GB

9.5 mm

70 mm

99 g

ATA-5

100 MB/s

ATA security

100 MB/s

ATA security

100 MB/s

ATA security

Seek times (typical read, including setting)

Single track

Average

Maximum

3 ms

13 ms

24 ms

3 ms

13 ms

24 ms

3 ms

13 ms

24 ms

156,280,320 117,210,240 78,140,160 Logical blocks

Disk rotational speed 5400 rpm 5400 rpm 5400 rpm

Operating temperature 5°C to 55°C

(41°F to

131°F)

5°C to 55°C

(41°F to

131°F)

5°C to 55°C

(41°F to

131°F)

1 GB = 1,073,741,824 bytes.

Actual drive specifications may differ slightly.

Certain restrictions and exclusions apply. Consult the HP Customer Support

Center for details.

6–6 Maintenance and Service Guide

Specifications

Table 6-6

External AC Adapter

Weight

AC adapter

Power cord

Power supply

Operating voltage

Operating current

Operating frequency range

Maximum transient

0.29 kg

0.13 kg

90 to 264 VAC RMS

1.6 A RMS

47 to 63 Hz AC

4/50 kV

0.65 lb

0.29 lb

Table 6-7

6-cell, Li-Ion Battery Pack

Dimensions

Height

Width

Depth

Weight

Energy

Voltage

Amp-hour capacity

Watt-hour capacity

Temperature

Operating

Nonoperating

Recharge time

System in Standby mode

System on (depending on system power consumption)

2.3 cm

6.3 cm

20.7 cm

0.39 kg

11.1 V

3.96 Ah

40 Wh

5°C to 45°C

-20°C to 60°C

2 to 3 hours

2 to 5 hours

0.90 in

2.48 in

8.15 in

0.86 lb

41°F to 113°F

-4°F to 140°F

Maintenance and Service Guide 6–7

Specifications

Table 6-8

24X Max DVD+RW/R and CD-RW Combo Drive

Applicable disc DVD-5, DVD-9, DVD-10

CD-ROM (Mode 1 and 2)

CD Digital Audio

CD-XA ready (Mode 2, Form 1 and 2)

CD-I ready (Mode 2, Form 1 and 2)

CD-R (read only)

CD Plus

Photo CD (single/multisession)

CD-Bridge

1.5 cm 0.59 in Center hole diameter

Disc diameter

Standard disc

Mini disc

Disc thickness

Track pitch

Access time

Random

Full stroke

Audio output level

Cache buffer

Data transfer rate

CD-R (24X)

CD-RW (10X)

CD-ROM (24X)

DVD (8X)

Multiword DMA mode 2

Startup time

Stop time

12 cm

8 cm

1.2 mm

0.74 µm

< 150 ms

< 225 ms

Line-out, 0.7 Vrms

128 KB/s

4.72 in

3.15 in

0.047 in

3,600 KB/s (150 KB/s at 1X CD rate)

1,500 KB/s (150 KB/s at 1X CD rate)

3,600 KB/s (150 KB/s at 1X CD rate)

10,800 KB/s (1,352 KB/s at 1X DVD rate)

16.6 MB/s

< 15 seconds

< 6 seconds

6–8 Maintenance and Service Guide

Specifications

Applicable disc

Table 6-9

24X Max DVD/CD-RW Combo Drive

DVD-5, DVD-9, DVD-10

CD-ROM (Mode 1 and 2)

CD Digital Audio

CD-XA ready (Mode 2, Form 1 and 2)

CD-I ready (Mode 2, Form 1 and 2)

CD-R (read only)

CD Plus

Photo CD (single/multisession)

CD-Bridge

1.5 cm 0.59 in Center hole diameter

Disc diameter

Standard disc

Mini disc

Disc thickness

Track pitch

Access time

Random

Full stroke

Audio output level

Cache buffer

Data transfer rate

CD-R (24X)

CD-RW (10X)

CD-ROM (24X)

DVD (8X)

Multiword DMA mode 2

Startup time

Stop time

12 cm

8 cm

1.2 mm

0.74 µm

< 150 ms

< 225 ms

Line-out, 0.7 Vrms

128 KB/s

4.72 in

3.15 in

0.047 in

3,600 KB/s (150 KB/s at 1X CD rate)

1,500 KB/s (150 KB/s at 1X CD rate)

3,600 KB/s (150 KB/s at 1X CD rate)

10,800 KB/s (1,352 KB/s at 1X DVD rate)

16.6 MB/s

< 15 seconds

< 6 seconds

Maintenance and Service Guide 6–9

Specifications

Applicable disc

Center hole diameter

Disc diameter

Standard disc

Mini disc

Disc thickness

Track pitch

Access time

Random DVD media

Full stroke DVD media

Random CD media

Full stroke CD media

Audio output level

Cache buffer

Data transfer rate

Max 24X CD

Max 8X DVD

Table 6-10

8X DVD-ROM Drive

DVD-5, DVD-9, DVD-10

CD-ROM (Mode 1 and 2)

CD Digital Audio

CD-XA ready (Mode 2, Form 1 and 2)

CD-I ready (Mode 2, Form 1 and 2)

CD-R (read only)

CD Plus

Photo CD (single/multisession)

CD-Bridge

1.5 cm 0.59 in

12 cm

8 cm

1.2 mm

0.74 µm

< 150 ms

< 225 ms

< 110 ms

< 200 ms

Line-out, 0.7 Vrms

512 KB/s

4.72 in

3.15 in

0.047 in

Multiword DMA mode 2

Startup time

Stop time

3,600 KB/s (150 KB/s at 1X CD rate)

10,800 KB/s (1,352 KB/s at 1X DVD rate)

16.6 MB/s

< 10 seconds

< 3 seconds

6–10 Maintenance and Service Guide

Specifications

Applicable disc

Center hole diameter

Disc diameter

Standard disc

Mini disc

Disc thickness

Track pitch

Access time

Random

Full stroke

Audio output level

Cache buffer

Data transfer rate

Sustained (16X)

Variable

Multiword DMA mode 2

Startup time

Stop time

Table 6-11

24X CD-ROM Drive

DVD-5, DVD-9, DVD-10

CD-ROM (Mode 1 and 2)

CD Digital Audio

CD-XA ready (Mode 2, Form 1 and 2)

CD-I ready (Mode 2, Form 1 and 2)

CD-R (read only)

CD Plus

Photo CD (single/multisession)

CD-Bridge

1.5 cm 0.59 in

12 cm

8 cm

1.2 mm

1.6 µm

< 150 ms

< 300 ms

Line-out, 0.7 Vrms

128 KB/s

4.72 in

3.15 in

0.047 in

2,400 KB/s

1,500 to 3,600 KB/s (10X to 24X)

16.6 MB/s

< 8 seconds

< 4 seconds

Maintenance and Service Guide 6–11

Specifications

Table 6-12

System DMA

Hardware

DMA

DMA0

System

Function

Available for audio

DMA1* Entertainment audio

(default; alternate = DMA0, DMA3, none)

Diskette drive DMA2*

DMA3 ECP parallel port LPT1

(default; alternate = DMA0, none)

DMA controller cascading (not available) DMA4

DMA5*

DMA6

Available for PC Card

Not assigned

DMA7 Not assigned

*PC Card controller can use DMA 1, 2, or 5.

6–12 Maintenance and Service Guide

Specifications

Hardware

IRQ

IRQ0

IRQ9

IRQ10

IRQ11

IRQ12

IRQ13

IRQ14

IRQ1

IRQ2

IRQ3

IRQ4

IRQ5

IRQ6

IRQ7

IRQ8

System

Function

System timer

Table 6-13

System Interrupts

Keyboard controller

Cascaded

COM2

COM1

Audio (default)*

Diskette drive

Parallel port

RTC

Assigned by operating system

Internal point stick or external mouse

Infrared

Primary IDE interface

IRQ15 Secondary IDE interface

✎

PC Cards may assert IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10,

IRQ11, or IRQ15. Either the infrared or the serial port may assert IRQ3 or IRQ4.

*Default configuration; audio possible configurations are IRQ5, IRQ7, IRQ9,

IRQ10, or none.

Maintenance and Service Guide 6–13

Specifications

I/O Address

(hex)

000 - 00F

010 - 01F

020 - 021

022 - 024

025 - 03F

02E - 02F

040 - 05F

044 - 05F

060

061

062 - 063

064

065 - 06F

070 - 071

072 - 07F

080 - 08F

090 - 091

092

093 - 09F

0A0 - 0A1

Table 6-14

System I/O Addresses

System Function

(shipping configuration)

DMA controller 1

Unused

Interrupt controller 1

Opti chipset configuration registers

Unused

87334 “Super I/O” configuration for CPU

Counter/timer registers

Unused

Keyboard controller

Port B

Unused

Keyboard controller

Unused

NMI enable/RTC

Unused

DMA page registers

Unused

Port A

Unused

Interrupt controller 2

6–14 Maintenance and Service Guide

I/O Address

(hex)

Table 6-14

System I/O Addresses (Continued)

System Function

(shipping configuration)

0A2 - 0BF

0C0 - 0DF

Unused

DMA controller 2

0E0 - 0EF

0F0 - 0F1

0F2 - 0FF

100 - 16F

170 - 177

178 - 1EF

1F0 - 1F7

1F8 - 200

201

202 - 21F

220 - 22F

230 - 26D

26E - 26

278 - 27F

280 - 2AB

2A0 - 2A7

2A8 - 2E7

2E8 - 2EF

Unused

Coprocessor busy clear/reset

Unused

Secondary fixed disk controller

Unused

Primary fixed disk controller

Unused

Joystick (decoded in ESS1688)

Unused

Entertainment audio

Unused

Reserved serial port

Specifications

Maintenance and Service Guide 6–15

Specifications

I/O Address

(hex)

Table 6-14

System I/O Addresses (Continued)

System Function

(shipping configuration)

2F0 - 2F7

2F8 - 2FF

Unused

Infrared port

300 - 31F

320 - 36F

370 - 377

378 - 37F

380 - 387

388 - 38B

38C - 3AF

3B0 - 3BB

3BC - 3BF

3C0 - 3DF

3E0 - 3E1

3E2 - 3E3

3E8 - 3EF

3F0 - 3F7

3F8 - 3FF

CF8 - CFB

CFC - CFF

Unused

Secondary diskette drive controller

Parallel port (LPT1/default)

Unused

FM synthesizer—OPL3

Unused

VGA

Reserved (parallel port/no EPP support)

VGA

PC Card controller in CPU

Unused

Internal modem

“A” diskette controller

Serial port (COM1/default)

PCI configuration index register (PCIDIVO-1)

PCI configuration data register (PCIDIVO-1)

6–16 Maintenance and Service Guide

Connector Pin Assignments

Table A-1

RJ-45 Network Interface

Pin

Signal

Transmit +

Transmit –

Receive +

Unused

Pin

Signal

Unused

Receive –

Unused

Maintenance and Service Guide A–1

Connector Pin Assignments

Table A-2

RJ-11 Modem

Pin

Signal

TX+ (ISDN modem)

TX- (ISDN modem)

Tip (modem)

Pin

Signal

Ring (modem)

RX+ (ISDN modem)

RX- (ISDN modem)

Table A-3

Universal Serial Bus

Pin

Signal

+5 VDC

Data –

A–2

Pin

Signal

Data +

Ground

Maintenance and Service Guide

Connector Pin Assignments

Pin

Signal

Ground (Y)

Ground (C)

Table A-4

S-Video

4 3

Pin

Signal

Y-Luminance (Intensity)

C-Chrominance (Color)

Table A-5

External Monitor

Pin

Signal

Red analog

Green analog

Blue analog

Not connected

Ground

Ground analog

Maintenance and Service Guide

Pin

Signal

+5 VDC

Ground

Monitor detect

DDC 2B data

Horizontal sync

Vertical sync

DDC 2B clock

A–3

Connector Pin Assignments

Table A-6

Audio Line-Out

Pin

Signal

Ground

Left audio out

Right audio out

Table A-7

Microphone

Pin

Signal

Audio in

Pin

Signal

Ground

A–4 Maintenance and Service Guide

Table A-8

Parallel

Connector Pin Assignments

Pin

Signal

Strobe

Data bit 0

Data bit 1

Data bit 2

Data bit 3

Data bit 4

Data bit 5

Data bit 6

Data bit 7

Acknowledge

Busy

Paper end

Select

Pin

Signal

Auto linefeed

Error

Initialize paper

Select in

Ground

+5VS

PTF

EXTFDD_VCC (+5V)

Ground

Maintenance and Service Guide A–5

Connector Pin Assignments

Table A-9

Serial

Pin

Signal

Carrier detect

Receive data

Transmit data

Data terminal ready

Ground

Pin

Signal

Data set ready

Ready to send

Clear to send

Ring indicator

A–6 Maintenance and Service Guide

Power Cord Requirements

The wide range input feature of the notebook permits it to operate from any line voltage from 100 to 120 or 220 to 240 V AC.

The power cord included with the notebook meets the requirements for use in the country where the equipment is purchased.

Power cords for use in other countries must meet the requirements of the country where the notebook is used. For more information on power cord requirements, contact an HP authorized reseller or service provider.

Maintenance and Service Guide B–1

Power Cord Requirements

General Requirements

The requirements listed below are applicable to all countries:

■ The length of the power cord must be at least 1.5 m (5.00 ft) and a maximum of 2.0 m (6.50 ft).

■ All power cords must be approved by an acceptable accredited agency responsible for evaluation in the country where the power cord will be used.

■ The power cord must have a minimum current capacity of

10 amps and a nominal voltage rating of 125 or 250 V AC, as required by each country’s power system.

■ The appliance coupler must meet the mechanical configuration of an EN 60 320/IEC 320 Standard Sheet C13 connector for mating with the appliance inlet on the back of the notebook.

B–2 Maintenance and Service Guide

Power Cord Requirements

Country-Specific Requirements

Country

Australia

Austria

Belgium

Canada

Denmark

Finland

France

Germany

Italy

Japan

The Netherlands

Norway

Sweden

Switzerland

3-Conductor Power Cord Requirements

Accredited Agency

EANSW

OVE

Applicable Note

Number

CEBC

CSA

DEMKO

FIMKO

UTE

VDE

IMQ

METI

KEMA

NEMKO

SEMKO

SEV

Maintenance and Service Guide B–3

Power Cord Requirements

3-Conductor Power Cord Requirements (Continued)

Country

United Kingdom

United States

Accredited Agency

BSI

Applicable Note

Number

Notes

1. The flexible cord must be <HAR> Type HO5VV-F, 3-conductor, 1.0 mm

2 conductor size. Power cord fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country where it will be used.

2. The flexible cord must be Type SPT-3 or equivalent, No. 18 AWG,

3-conductor. The wall plug must be a two-pole grounding type with a

NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.

3. The appliance coupler, flexible cord, and wall plug must bear a “T” mark and registration number in accordance with the Japanese Dentori Law.

The flexible cord must be Type VCT or VCTF, 3-conductor, 1.00 mm

2 conductor size. The wall plug must be a two-pole grounding type with a

Japanese Industrial Standard C8303 (7 A, 125 V) configuration.

B–4 Maintenance and Service Guide

Screw Listing

This appendix provides specification and reference information for the screws used in the notebook. All screws listed in this appendix are available in the Miscellaneous Screw Kit, spare part number 345057-001.

Maintenance and Service Guide C–1

Screw Listing

Table C-1

Torx T5M2.5×4.0 Screw mm

Color Qty.

Length Thread

Silver 2 4.0 mm 2.5 mm

Where used:

Two screws that secure the hard drive to the hard drive frame

)

Head

Width

5.0 mm

Table C-2

Phillips PM3.0×3.5 Screw mm

Color Qty.

Length Thread

Silver 2 3.5 mm 3.0 mm

Where used:

2 Two screws that secure the hard drive to the hard drive frame

)

Head

Width

4.5 mm

Table C-3

M2.0×10.0 Alignment Pin mm

Color Qty.

Length Thread

Silver 2 10.0 mm 2.0 mm

Where used:

Two alignment pins that secure the hard drive to the hard drive frame

)

Head

Width

4.0 mm

C–2 Maintenance and Service Guide

Screw Listing

Torx T5M2.5×4.0 Screw, Phillips PM3.0×3.5 Screw, and

M2.0×10.0 Alignment Pin Locations

Maintenance and Service Guide C–3

Screw Listing

Table C-4

Torx T8M2.0×6.0 Screw mm

Color Qty.

Length Thread

Black 27 6.0 mm 2.0 mm

Where used:

One screw that secures the hard drive cover to the notebook

(documented in Section 5.6

)

One screw that secures the Bluetooth cover to the notebook

)

One screw that secures the optical drive to the notebook

(documented in Section 5.8

)

One screw that secures the keyboard to the notebook

(documented in Section 5.9

)

One screw that secures the LED switch cover to the notebook

(documented in Section 5.15

notebook (documented in Section 5.18

Four screws that secure the display assembly and hinge covers to the

)

Head

Width

5.0 mm

C–4

Torx T8M2.0×6.0 Screw Locations

Maintenance and Service Guide

Screw Listing

Table C-4

Torx T8M2.0×6.0 Screw (Continued) mm

Color Qty.

Length Thread

Black 27 6.0 mm 2.0 mm

Where used:

Seventeen screws that secure the top cover to the notebook

(documented in

Section 5.19

Head

Width

5.0 mm

Torx T8M2.0×6.0 Screw Locations

Maintenance and Service Guide C–5

Screw Listing

Table C-4

Torx T8M2.0×6.0 Screw (Continued) mm

Color Qty.

Length Thread

Black 27 6.0 mm 2.0 mm

Where used:

One screw that secures the speaker to the top cover

(documented in

Section 5.20

Head

Width

5.0 mm

C–6

Torx T8M2.0×6.0 Screw Location

Maintenance and Service Guide

Screw Listing

Table C-5

Phillips PM1.5×3.0 Screw mm

Color Qty.

Length Thread

Black 3 3.0 mm 1.5 mm

Where used:

Two screws that secure the Bluetooth board to the Bluetooth cover

(documented in

Section 5.6

)

Head

Width

3.0 mm

Phillips PM1.5×3.0 Screw Locations

Maintenance and Service Guide C–7

Screw Listing

Table C-6

Phillips PM3.5×3.0 Screw mm

Color Qty.

Length Thread

Black 3 3.0 mm 1.5 mm

Where used:

One screw that secures the security card to the system board

(documented in

Section 5.17

(documented in Section 5.11

Head

Width

3.5 mm

C–8

Phillips PM3.5×3.0 Screw Location

Maintenance and Service Guide

Screw Listing

Table C-7

Torx T8M2.0×4.0 Screw mm

Color Qty.

Length Thread

Pewter 20 4.0 mm 2.0 mm

Head

Width

5.0 mm

Where used:

Two screws that secure the modem board to the system board

)

Two screws that secure the Mini PCI communications board and shield to

the system board (documented in Section 5.12

)

Five screws that secure the heat sink to the system board

(documented in Section 5.13

)

One screw that secures the top cover to the notebook

(documented in Section 5.19

)

Torx T8M2.0×4.0 Screw Locations

Maintenance and Service Guide C–9

Screw Listing

Table C-7

Torx T8M2.0×4.0 Screw (Continued) mm

Color Qty.

Length Thread

Pewter 20 4.0 mm 2.0 mm

Where used:

Five screws that secure the speaker to the top cover

(documented in

Section 5.20

Head

Width

5.0 mm

C–10

Torx T8M2.0×4.0 Screw Locations

Maintenance and Service Guide

Screw Listing

Table C-7

Torx T8M2.0×4.0 Screw (Continued) mm

Color Qty.

Length Thread

Pewter 20 4.0 mm 2.0 mm

Where used:

One screw that secures the fan assembly to the notebook

(documented in

Section 5.22

Head

Width

5.0 mm

Torx T8M2.0×4.0 Screw Location

Maintenance and Service Guide C–11

Screw Listing

Table C-7

Torx T8M2.0×4.0 Screw (Continued) mm

Color Qty.

Length Thread

Pewter 20 4.0 mm 2.0 mm

Where used:

Four screws that secure the system board to the notebook

(documented in

Section 5.23

Head

Width

5.0 mm

C–12

Torx T8M2.0×4.0 Screw Locations

Maintenance and Service Guide

Screw Listing

Table C-8

Torx T8M2.0×3.5 Screw mm

Color Qty.

Length Thread

Silver 3 3.5 mm 2.0 mm

Where used:

Three screws that secure the TouchPad and bracket to the top cover

(documented in

Section 5.21

Head

Width

5.0 mm

Torx T8M2.0×3.5 Screw Locations

Maintenance and Service Guide C–13

Screw Listing

Table C-9

Phillips PM1.5×4.0 Screw mm

Color Qty.

Length Thread

Black 3 4.0 mm 1.5 mm

Where used:

Three screws that secure the fan to the fan housing

(documented in

Section 5.22

Head

Width

3.0 mm

C–14

Phillips PM1.5×4.0 Screw Locations

Maintenance and Service Guide

Index

1394 connector

1–21

A

AC adapter spare part number

specifications

application key

audio line-out jack location

pin assignments

A–4

audio troubleshooting

2–25

B

base enclosure, spare part number

3–7

battery bay

, 1–30

battery bezel removal

5–7

battery light

battery pack release latch

removal

spare part number

specifications

Bluetooth board removal

5–13

spare part number

3–7 ,

5–13

Bluetooth cable illustrated

3–10

removal

5–14

Bluetooth compartment

1–30

Bluetooth cover removal

5–13

bottom components

1–29

C

cables, service considerations

caps lock key

caps lock light

carrying case, spare part numbers

3–13

CD-ROM Drive illustrated

spare part number

specifications

components bottom

front

keyboard

left-side

rear

right-side

top

Maintenance and Service Guide Index–1

Index

Computer Setup

Advanced Menu

File Menu

overview

Security Menu

connector pin assignments audio line-out jack

A–4

external monitor connector

microphone jack

modem jack

monitor connector

network jack

parallel connector

RJ-11 telephone jack

RJ-45 network jack

serial connector

S-Video connector

Universal Serial Bus (USB) connector

A–2

connectors, service considerations

cursor control keys

D

design overview

1–31

diagnostics configuration information

2–7

test information

2–8

Diagnostics for Windows

2–2 ,

2–7

disassembly sequence chart

5–3

diskette drive

OS loading problems

2–23

spare part number

3–7

5–12

display assembly illustrated

removal

spare part numbers

specifications

display lid switch

display release latch

DMA specifications

docking connector

drive light

drives, preventing damage

4–3

DVD+RW/R and CD-RW

Combo Drive illustrated

spare part number

specifications

DVD/CD-RW Combo Drive illustrated

spare part number

specifications

DVD-ROM Drive illustrated

spare part number

specifications

Index–2 Maintenance and Service Guide

Index

E

electrostatic discharge

4–4

4–8

external monitor connector location

pin assignments

A–3

F

f1 through f12 function keys

fan assembly illustrated

removal

spare part number

features

feet, locations

fn key

front components

G

grounding equipment and methods

4–7

H

hard drive connector

cover latch

disassembly

illustrated

location

OS loading problems

removal

spare part numbers

specifications

hard drive cover removal

heat sink removal

spare part number

hinge cover removal

I

I/O address specifications

6–14

infrared port

integrated smart card removal

spare part number

internal keypad

interrupt specifications

6–13

K

keyboard components

illustrated

removal

spare part numbers

troubleshooting

L

LED switch cover illustrated

removal

spare part number

left-side components

light

Maintenance and Service Guide Index–3

Index

Index–4

M

mass storage devices, spare part numbers

3–11

memory expansion board illustrated

removal

spare part numbers

microphone

microphone jack location

pin assignments

A–4

Mini PCI communications board illustrated

removal

shield removal

spare part numbers

Miscellaneous Cables Kit components

spare part number

Miscellaneous Plastics Kit components

spare part number

models

modem board illustrated

removal

spare part number

modem cable illustrated

removal

modem jack location

pin assignments

modem, troubleshooting

2–30

monitor connector location

pin assignments

MultiBay

MultiBay devices illustrated

removal

spare part numbers

mute button

N

network jack, pin assignments

A–1

network, troubleshooting

2–30

nonfunctioning device, troubleshooting

2–18

, 2–27

notebook feet, locations

5–11

notebook specifications

6–1

num lock key

num lock light

O

operating system loading, troubleshooting

2–19

optical drive location

removal

spare part numbers

Maintenance and Service Guide

Index

P

packing precautions

4–5

parallel connector location

pin assignments

A–5

password, clearing

1–16

PC Card eject buttons

PC Card slots

plastic parts

pointing device, troubleshooting

2–29

pointing stick

pointing stick buttons

port replicator spare part numbers

troubleshooting

power button

power connector

power cord, spare part numbers

3–13

power management features

1–17

power, troubleshooting

2–12

power/Standby light

processor illustrated

removal

spare part numbers

Q

Quick Launch buttons

R

real time clock battery illustrated

3–9

removal

5–33

Maintenance and Service Guide rear components

1–20

release latch

1–30

removal preliminaries

4–1

procedures

5–1

replacement preliminaries

4–1

procedures

5–1

right-side components

1–18

RJ-11 telephone jack location

pin assignments

A–2

RJ-45 network jack location

pin assignments

A–1

S

Screw Kit contents

spare part number

scroll lock light

Secure Digital (SD) slot

security cable slot

security card, illustrated

3–4 ,

3–6

security module removal

spare part number

serial connector location

pin assignments

serial number

service considerations

Index–5

Index smart card removal

spare part number

speaker, removal

specifications

AC adapter

battery pack

CD-ROM Drive

display

DMA

DVD+RW/R and CD-RW

Combo Drive

6–8

DVD/CD-RW Combo

Drive

DVD-ROM Drive

hard drive

I/O addresses

interrupts

notebook

static shielding materials

4–8

stereo speakers

S-Video connector location

pin assignments

A–3

system board illustrated

removal

spare part numbers

T

tools required

4–1

top components

1–25

, 1–27

top cover illustrated

removal

spare part number

TouchPad buttons

location

removal

TPM removal

spare part number

transporting precautions

4–5

troubleshooting audio

2–25

Computer Setup

2–2

Diagnostics for Windows

flowcharts

keyboard

modem

network

nonfunctioning device

2–18 ,

2–27

operating system loading

overview

pointing device

port replicator

power

video

Index–6 Maintenance and Service Guide

U

Universal Serial Bus (USB) connector location

1–21

pin assignments

A–2

V

vent

1–22 ,

video troubleshooting

2–16

volume control buttons

W

Windows logo key, location

wireless LAN, spare part numbers

3–7

wireless on/off light
