SRN-473S
Preliminary version
SRN-473S
4CH Network Video Recorder with PoE Switch
SRN-473S
Display
Video
Inputs / Resolution
Protocols
Local Display
Multi Screen Display
Live
Performance
Performance
Operating System Embedded
Compression
Recording Bandwidth
Resolution
Mode
Recording
Search &
Playback
Storage
Back up
Sensor
Key Features
Audio
Network
• Up to 4CH 8M supported
• 32Mbps network camera recording
• Plug & play by 4 PoE/PoE+ ports
• Max. 1 HDD
• HDMI / VGA local monitor
Linux
H.264, MJPEG
32Mbps, 2M 4 camera real-time recording
CIF ~ 8M
Normal, Scheduled, Event (Pre / Post)
Alarm input (2), Video loss, Camera event (Alarm in, MD, Video analytics)
Event Trigger
VA event [Tampering, Enter/Exit, Passing (Virtual line, (Dis)Appear,
Face detection, Audio detection)]
Event Action
E-mail, PTZ preset, Alarm out, Buzzer, Monitor out
Playback Bandwidth
32Mbps (Max. 3 users)
Performance
Max. 32Mbps (TBD)
Mode
Date & Time (Calendar) / Event log list / Text Search (POS)
Simultaneous Playback [Local monitor] Up to 4CH, [Web, CMS] Up to 4CH
Resolution
CIF ~ 8M
Fish-eye Dewarping
Via Smartviewer
Playback Control
Fast forward / backward, Move one step up / down
Default Built-in
2TB
Internal
1 SATA (Fixed)
Max.Capacity
Internal (4TB = 1 x 4TB)
File Back up
[USB] : BU/Exe, [Web, CMS] : JPEG, AVI
Function
Max. 4CH play, Date-time/title display
Input / Output
2 / 1 (NO 1ea, NO/NC 1ea)
Input / Compression
4CH (Network) / G.711, G.726, AAC (16/48KHz)
Audio Communication 2-way
Protocol Support
DDNS
Transmission Bandwidth
Max. Remote Users
IP
Security
Language
GUI / Web
OS
Web Browser
Dimensions
Unit : mm (inch)
Viewer
Software
Functions
159.9
(6.3")
159.9
(6.3")
166.3(6.55")
(6.55")
166.3
Camera Setup
44.0(1.73")
(1.73")
44.0
48.7 (1.92")
(1.92")
48.7
360.0(14.17")
(14.17")
360.0
Type
CMS Support
Register
Setup Items
Camera Control PoE
Easy Configuration
PTZ
Control / Preset
OS
Smart phone
Control
System Control
Indicator / Interface
Indicator
Front
USB
HDMI / VGA
Audio
Connections
System
Log
General
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client),
PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S)
Samsung iPOLiS DDNS
Max. 64Mbps (TBD)
Search 3 / Live unicast 10 / Live multicast 20
IPv4 / IPv6
IP address filtering, User access log, 802.1x authentication,
Encryption (ID/PW, Recording, Transmission, Back up)
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch,
Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian,
Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai (GUI)
Supported OS : Window XP (Service pack 2 or above), Vista, 7, 8,
Mac OS X (10.7 or above)
Microsoft Internet Explorer (Ver. 8 ~ 10),
Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25),
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
SSM, Webviewer, SmartViewer, iPOLiS mobile viewer
SDK / CGI (SUNAPI)
PnP mode, Manual mode
1) IP address, Add profile edit, Bitrate, Compression, GOP, Quality
2) Camera event setup
- MD
- VA (Upgrade Aug. 2015) : Tampering, Enter/Exit, Passing (Virtual line),
(Dis)Appear, Face detection, Audio detection)
3) Video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS,
WDR, D&N, SSNR, Shutter, SSDR, DIS)
1) Monitor PoE power consumption 2) On/Off control for each PoE camera
3) Remote reset for each PoE camera
Setup Wizard (Date/Time, Network, Auto camera configuration)
Via GUI, Webviewer, SPC-2000 / 255
Android, iOS
Live (4CH) : (4 DIV) CIF monitoring, (4/1 DIV) 1.3M monitoring
Playback (1CH) : Up to 1.3M
Mouse, IR Remocon, Web, SPC-2000 (USB controller)
Alarm
Reset / Power Cord
Power status LED 1ea, Alarm status LED 1ea, Record status LED 1ea
2ea (Front 2ea)
1ea / 1ea
Out 1ea (RCA, Line)
4ea (PoE, 100Mbps) - 2 hPoE when 2 PoE ports aggregated to 1 port
- Each PoE port can be used as downlink port for camera / PoE Hub
1ea (LAN/WAN, 100Mbps) - WAN : Uplink to CMS
In 2ea (Terminal block) / Out 1ea (Terminal block)
Yes (Factory reset) / Included
Log List
Max. 20000 (System log, Event log each)
Ethernet
Input Voltage / Current
Power Consumption
Operating Temperature
Environmental
Operating Humidity
Color / Material
Mechanical
Dimensions (WxHxD)
Weight (Without HDD)
IR Remocon / Mouse
Viewer CD / IB
Accessories
Power Cord / Power Adaptor
Terminal Block
Electrical
Up to 4CH / CIF ~ 8M
Samsung, ONVIF
HDMI / VGA
[Local monitor] 1 / 4 / Auto sequence, [Web] 1 / 4 / Auto sequence
[Local monitor] 8M (30fps), 5M (60fps), 3M (90fps), 2M (120fps),
720p (240fps), D1 (120fps)
[Web] 5M (30fps), 3M (60fps), 2M (120fps), 720p (120fps), D1 (120fps) (TBD)
48V DC / 1.8A
Set : (TBD)W (NVR w/ 1x HDD), PSE : Total 50W (Average 12.5W per each PoE port)
+0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 85% RH
Black / Metal
360.0 x 44.0 x 159.9mm (14.17" x 1.73" x 6.3") (1U)
TBD
Included / Included
Backup Viewer, Installation Manual / Included
Included / Included
Included
* The latest product information / specification can be found at www.samsungsecurity.com
Preliminary
