LABORATORY OVEN (G-030)

EN 932:5 • ASTM C127 • BS 1377

▪ Used for drying, conditioning and moisture determination.

▪ Equipped with a digital thermostat and an indicator with range of ambient to 200°C (392°F) fitted with overheat thermostat to prevent accidental over-temperature and to provide a safe working environment.

▪ Maximum temperature is regulated with the Proportional Integral Derivative (PID) control and goes to a maximum set value.

▪ Internal chamber is made of stainless steel and the exterior surface of the oven is powder coated (available in stainless steel). Mineral wool is used in between the internal chamber and the outer cabinet for insulation.

▪ Exhaust holes for moisture discharge and fast cooling.

▪ Air circulating fan provides forced convection airflow for uniformity of internal temperature mounted on the back wall.

▪ Supplied with grid shelves which allows air-flow that can be easily adjusted and/or removed.

www.alfatest.com.tr

27

LABORATORY OVEN (G-030)

EN 932:5 • ASTM C127 • BS 1377

G-030/400 - Powder Coated Exterior

SUPPLIED WITH

• Two Adjustable shelves (additional shelves can be ordered)

• Digital Thermostat & Indicator

• Overheat Thermostat

• Pilot light heat indicator

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator Fitted With overheat thermostat

• Temp max : 200°C (392°F) (PID control)

• Interior chamber

• Exterior

: Stainless Steel

: Powder Coated or Stainless Steel

• Insulation

• Airflow

• Power Supply

: Thick mineral wool

: Forced convection

: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

28 www.alfatest.com.tr

G-030/250 - Powder Coated Exterior

LABORATORY OVEN (G-030)

EN 932:5 • ASTM C127 • BS 1377

G-030/250-2 (2 Doors - Horizontal)

G-030/120 - Stainless Steel Exterior

Code

G-030/120

G-030/250

G-030/250-2

G-030/400

Capacity

# of

Doors

112.5 lt

4 cu. ft.

225 lt

8 cu. ft.

225 lt

8 cu. ft.

400 lt

14 cu. ft.

1

1

2

1

# of

Shelves

2

2

2

2

# of

Fans

1

External Cabinet

Dimensions

(W x L x H)

75 x 64 x 62 (h) cm

29.5” x 25.2” x 24.5”

1

2

2

70 x 70 x 127 (h) cm

27.5” x 27.5” x 50”

119 x 70 x 76 (h) cm

47” x 27.5” x 30”

98 x 82 x 126 (h) cm

38.5” x 32” x 49.6”

Internal Chamber

Dimensions

(W x D x H)

50 x 45 x 50 (h) cm

19.6” x 17.7” x 19.6”

50 x 45 x 100 (h) cm

19.6” x 17.7” x 39.2”

100 x 45 x 50 (h) cm

39.2” x 17.7” x 39.2”

68 x 56 x 107 (h) cm

26.8” x 22” x 42”

Approximate

Weight

67 kg

148 lb

90 kg

198 lb

105 kg

232 lb

130 kg

285 lb

Power

800 Watts

1200 Watts

1200 Watts

1200 Watts www.alfatest.com.tr

29

CLIMATIC CHAMBER (G-035)

▪ Used to subject the samples to a specific temperature and humidity.

▪ Inside chamber is made of stainless steel

▪ Cabinet is supplied with temperature control by a digital thermostat and the humidity inside the chamber can be controlled through the digital control panel.

▪ Supplied with adjustable shelves

▪ Equipped with circulating fan to assure homogeneous conditions through the inner chamber

TECHNICAL SPECIFICATIONS

• Capacity : 225 lt

• Made of Stainless Steel

• Temperature Range : -10°C to +60°C

• Humidity Range : 20% to 95%

• Equipped with

• Digital PID Thermo-Controller

• Air Circulation Fan providing airflow

• Supplied with adjustable shelves (2 ea)

(Additional shelves can be ordered)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Climatic Chamber (G-035)

MICROWAVE OVEN (G-030/MW)

• Used to heat/dry the materials by electromagnetic radiation causing the polarized molecules to rotate and build up thermal energy.

• Provides efficient and quick heat.

TECHNICAL SPECIFICATIONS

• Heat/dry using electromagnetic radiation.

• Quick heating process.

Microwave Oven (G-030/MW)

30 www.alfatest.com.tr

MUFFLE FURNACE (G-050)

▪ Used for high temperature heating and drying.

▪ Supplied with Proportion Integral Derivative (PID) temperature control.

▪ Covers a range of temperature from ambient to a desired temperature. The front loading to the furnace and the double coating provides easy access and cooler exterior surface.

▪ Heating elements are supported on ceramic tubes. Important advantage of this is that the element change is very easy and economic.

▪ Low thermal mass insulation leads to a very impressive heat up rate as well as efficient insulation.

▪ Door is provided with a safety lock that isolates the power once it is opened.

TECHNICAL SPECIFICATIONS

• Digital Thermostat and Indicator

• Temperature control by PID

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

G-050/10

G-050/11

G-050/12

Code Max Temperature

1000°C

1100°C

1200°C

Muffle Furnace (G-050)

Capacity

3 lt

6 lt

5 lt www.alfatest.com.tr

31

WATER DISTILLATION UNIT (G-045)

▪ Used to distill water for laboratory purposes with a capacity of 3 liters per hour

▪ The inner chamber is made of stainless steel

▪ The exterior casing is made of aluminuim with stoved enamel finish

▪ Equipped with a built-in manometer for pressure controll on the input water

TECHNICAL SPECIFICATIONS

• 3 lt of distilled water output capacity per hour

• Stainless steel cylinder heater

• Internal structure made of stainless steel

• Outer casing made of aluminium with stoved enamel finish

• Input water pressure controlled by built-in manometer

• Thermostatical safety system

32 www.alfatest.com.tr

Water Distillation Unit (G-045)

WATER BATH (G-040)

EN 12697:34 • ASTM D1559 • ASTM D5581 • AASHTO T245

▪ Used to cure specimens at constant temperature.

▪ Exterior is made of powder coated steel and the interior tank and the cover are corrosion-resistant stainless steel.

▪ Supplied with perforated stainless steel shelf which stands at the bottom of the tank to ensure uniform temperature.

▪ Equipped with digital thermoregulator with range of ambient to 82°C (180°F) and pilot light heat indicator.

▪ The tank is insulated from the outer cabinet with thick mineral wool to reduce thermal loss and to help maintain contstant temperature.

▪ Available in 2 different capacities and with/without water circulation options.

Water Bath (G-040/30)

SUPPLIED WITH

• Digital Thermostat & Indicator

• Stainless Steel Cover

• Base Shelf

• Pilot Lamp

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator

• Interior Stainless Steel

• Water circulation is optional (to be specified at the time of order)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Water Bath (G-040/60)

Code

G-040/30

G-040/60

External Dimensions (± 1 cm) Internal Dimensions (± 1 cm)

12” x 20” x 8”

305 x 508 x 203 mm

20” x 24-½” x 8”

508 x 622 x 203 mm

13-¾” x 21-½” x 15”

350 x 550 x 380 mm

21-½” x 31-½” x 15”

550 x 800 x 380 mm

Volume

7.93 gallons

30 liters

15.85 gallons

60 liters

Approximate Weight (kg)

15

30 www.alfatest.com.tr

33

SIEVE (B-040)

ISO 3310:1 • ASTM E11• BS 410

▪ All Sieves are made of stainless steel woven wire and frame that meet international specifications.

▪ The sieve aperture is clearly marked on the metallic label.

▪ Our sieves are of the highest quality to ensure consistent fit, accurate, specifications and durable construction.

▪ The sieves are available in two diameters (200 mm) and (300 mm).

▪ Cover and pan should be ordered separately.

Sieves (B-040)

TECHNICAL SPECIFICATIONS

• Frame and mesh made of stainless steel

• Aperture marked on a metal label

• Available in (Ø 200 mm) and (Ø 300 mm)

B-040/08

B-040/12

Code

34 www.alfatest.com.tr

Diameter (mm)

ø 200

ø 300

Dimensions (± 1 cm)

24 x 24 x 8 (h)

34 x 34 x 11 (h)

PARTICLE SIZE CONVERSION TABLE

ISO/BS

6.70

6.30

5.60

5.00

4.75

4.00

14.00

13.20

12.50

11.20

10.00

9.50

8.00

7.10

3.35

3.15

2.80

2.50

2.36

75.00

63.00

56.00

25.40

25.00

22.40

20.00

19.00

16.00

53.00

50.00

45.00

40.00

37.50

31.50

28.00

26.50

2.00

ASTM

0.265"

1/4"

3.5

-

4

5

-

0.530"

1/2"

7/16"

-

3/8"

5/16"

-

7

-

6

-

8

3"

2 1/2"

-

1"

-

7/8"

-

3/4"

5/8"

2.12"

2"

1 3/4"

-

1 1/2"

1 1/4"

-

1.06"

10

ISO/BS

0.106

0.100

0.090

0.080

0.075

0.063

0.300

0.250

0.212

0.200

0.180

0.160

0.150

0.125

0.053

0.050

0.045

0.040

0.038

0.025

1.70

1.60

1.40

1.25

1.18

1.00

0.850

0.800

0.710

0.630

0.600

0.500

0.425

0.400

0.355

0.315

ASTM

140

-

170

-

200

230

80

-

100

120

50

60

70

-

270

-

325

-

400

-

-

25

-

30

35

-

16

18

20

40

-

45

-

12

-

14 www.alfatest.com.tr

35

SIEVE SHAKER (B-041)

▪ Operated by electrical motor which provides a more elaborated and standardized sieving to ensure accurate results and eliminate personal errors involved in sieving.

▪ Accepts up to eight full height sieves.

▪ The shaker is available in two sizes:

▪(B-041/200) shaker that can be used for (20 cm) sieves

▪(B-041/300) shaker that can be used for (20 cm) and (30 cm) sieves

▪ Light weight, quiet operation, compact and portable design, fast clamping.

▪ Built-in timer (60 min) is incorporated to set the duration time.

▪ Sieves, pan and lid must be ordered separately

TECHNICAL SPECIFICATIONS

• Lightweight

• Quiet Operation

• Compact and portable

• Fast Clamping

• Built in Timer (60 min)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

B-041/20

B-041/30

Code Dimensions (cm)

Dia: 32 / h: 73

Dia: 42 / h: 73

Sieve Shaker (B-041)

Approximate Weight (kg)

20

35

36 www.alfatest.com.tr

ELECTROMECHANICAL SIEVE SHAKER (B-041/SV)

▪ Performs perfect sieving by having double-actions:

▪ Swinging motion

▪ Vibration motion

▪ The machine is capable of applying both motions at the same time (or one of the two)

▪ Suitable for both dry and wet sieving

▪ Automatic timer built-in for sieving time

TECHNICAL SPECIFICATIONS

• Performs perfect sieving by having double-actions:

• Swinging motion

• Vibration motion

• Available for:

• Ø 200 mm

• Ø 300 mm

B-041/SV-20

B-041/SV-30

• Ø 450 mm B-041/SV-45

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

MULTI-DECK GRADING MACHINE (M-042)

• Used specially in mining labs where large quantities of sieving is required.

• Two sieves with decks, each of 300 x 500 mm size, and the openings are

10 mm and 5 mm unless otherwise specified during the order.

• Plastic boxes, as collectors, are supplied for each deck.

TECHNICAL SPECIFICATIONS

• Equipped with pan at the bottom.

• Adjustable sieving angle.

• Equipped with powerful vibrating motor.

• Power Supply: 380 V (3 phase) www.alfatest.com.tr

37

PLATFORM SCALE (EB)

▪ The equipment frame and design is robust and strong.

▪ The scale has taring option.

▪ Available in 2 types depending on their capacity and readability.

TECHNICAL SPECIFICATIONS

• Strong and robust

• Push button taring facility

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

EB-060

EB-150

EB-300

Capacity (kg)

60

150

300

MECHANICAL BALANCE (MT)

• Available in three types depending on their capacity and readability.

• The balance can be used in laboratory and in field.

Platform Scale (EB)

Mechanical Balance (MT-0310)

Code

MT-20

MT-2610

MT-0310

38 www.alfatest.com.tr

Capacity (g)

20000

2610

310

Readability (g)

1.00

0.10

0.01

Mechanical Balance (MT-2610)

ELECTRONIC BALANCE

▪ The balance has capacity ranges from 30 kg to

200 g and with accuracy from 0.5 g to 0.001 g depending on the type and the purpose of it.

▪ Supplied with rechargeable batteries allowing the balance to be used in laboratory and in field.

▪ Provided with under weighing mechanism.

Electronic Balance

TECHNICAL SPECIFICATIONS

• Rechargeable battery

• Used both in labs and insitu

• Taring Facility

• Under Weighing mechanism

Code

Capacity

Readability

ET-30K ET-15K ET-06K ET-03K ET-600 HT-30K HT-06K HT-03K HT-600 HT-200

30 kg

0.5 g

15 kg

0.2 g

6 kg

0.1 g

3 kg

0.05 g

600 g

0.01 g

30 kg

0.1 g

6 kg

0.01 g

3 kg 600 g 200 g

0.01 g 0.001 g 0.1 mg www.alfatest.com.tr

39

DENSITY BASKET (TS-105)

▪ The basket is made from stainless steel.

▪ The diameter of the basket is 200 mm.

▪ Supplied as a complete piece with handle.

CRADLE (TS-106)

▪ Made of stainless steel.

▪ Can be used instead of the basket to hold the specimen

Density Basket (TS-105)

Cradle (TS-106)

40 www.alfatest.com.tr

SPECIFIC GRAVITY FRAME (TS-100)

ASTM C127

▪ The frame can be used to determine the specific gravity of solid materials

(concrete, aggregate .. etc)

▪ The system consists of a highly rigid frame, incorporating moving platform on its lower part, water tank and a density basket.

▪ The balance should be ordered separately.

Specific Gravity Frame (TS-100)

SUPPLIED WITH

• Moving Platform

• Water Tank

• Cradle

(TS-100/MP)

(TS-100/WT)

(TS-106)

TECHNICAL SPECIFICATIONS

• Can be used for specific gravity determination

• Balance should be ordered separately

Code

TS-100

TS-105

Dimensions

(± 1 cm)

57 x 46 x 105 (h)

Dia: 20 / h: 73

Weight

(kg)

28

0.8

www.alfatest.com.tr

41

SAMPLE SPLITTER (G-080)

ASTM C136 • AASHTO T27 • EN 933:3

▪ Designed to halve/divide aggregates, soils, sands and gravel into two representative halves.

▪ Made of powder coated enameled steel.

SUPPLIED WITH:

• Pans (2 ea)

Code

G-080/09

G-080/12

G-080/19

G-080/25

G-080/37

G-080/50

G-080/62

G-080/75

42 www.alfatest.com.tr

Chute Width (mm)

9.0

12.5

19.0

25.0

37.5

50.0

62.5

75.0

Sample Splitter (G-080)

Number of Chutes

12

12

8

8

8

10

10

8

UNIVERSAL SAMPLE SPLITTER (G-081)

ASTM C136 • AASHTO T27 • EN 933:3

▪ Used to halve/divide large amount of aggregates, soils, sands and gravel into two representative portions.

▪ The width of each chute bar is 1/2”.

▪ Equipped with lever and release hoppers.

▪ Made of heavy-duty steel.

▪ Supplied with two collecting pans

Universal Sample Splitter (B-081)

SUPPLIED WITH

• Collecting Pans (2 ea)

TECHNICAL SPECIFICATIONS

• Chutes: Adjustable, with: 1/2” each.

G-081

Code Dimensions (± 1 cm)

72 x 50 x 87 (h)

Approximate Weight (kg)

46 www.alfatest.com.tr

43

LOAD RING (LR)

• Made from steel.

• Used for load measurements.

• Supplied with dial indicator.

Code

Capacity

Code

Capacity

LR/01

10 kN

LR/01 D

10 kN

With Mechanical Dial

LR/03

30 kN

LR/05

50 kN

With Digital Dial

LR/03 D

30 kN

LR/05 D

50 kN

LR/10

100 kN

LR/10 D

100 kN

Load Ring (LR)

DIAL INDICATOR (DI)

Code

Travel

Graduation

Type

DI/D-12/0.001

12.70 mm

0.001

Digital

DI/D-25/0.01

25.00 mm

0.01

Digital

DI/M-10/0.01

10.00 mm

0.01

Mechanical

DI/M-30/0.01

30.00 mm

0.01

Mechanical

DI/M-50/0.01

50.00 mm

0.01

Mechanical

44 www.alfatest.com.tr

Digital Indicator (DI) Mechanical Dial Indicator (DI)

LOAD CELL (LC)

▪ Supplied with rechargeable batteries allowing the load cell to be used in the laboratory and insitu.

Load Cell (LC)

Load Cell (LC)

Code

Capacity

LC/0005 LC/0010 LC/0030 LC/0050 LC/0100 LC/0300 LC/0600 LC/1000 LC/2000 LC/3000

5 kN 10 kN 30 kN 50 kN 100 kN 300 kN 600 kN 1000 kN 2000 kN 3000 kN www.alfatest.com.tr

45

CONCRETE

46 www.alfatest.com.tr

INDEX CONCRETE

Item

Compression Tester

Flexure Apparatus for Concrete Beams

Flexural Testing Machine

Slab Testing Machine

Concrete Pipe Testing Machine

Cylinder Mould

Cylindrical Capping Set

Plastic Cube Mould

Steel Cube Mould

Beam Mould

Concrete Flow Table

Vebe Consistometer

Slump Set

L-Box Apparatus

V-Funnel Apparatus

U-Shape Box Apparatus

J-Ring Apparatus

Compacting Factor Apparatus

Concrete Penetrometer

Vibrating Table

Poker Vibrator

Airmeter

Plastic Curing Tank

Metal Curing Tank

Controlling Unit for Curing Tank

Drum-Type Mixer

Pan-Type Mixer

Concrete Water Impermeability Tester

Ferrodetector

Profoscope

Universal Cutting Machine

Cutting Machine

Coring Machine

Core Bits for Concrete

Digital Concrete Test Hammer

Testing Anvil

Concrete Test Hammer

Crack Detection Microscope

Ultrasonic Tester

B-063

B-061

B-061/x

B-110/D

B-117

B-110

B-250

B-048

B-320/B

B-140/P

B-140/M

B-140/CU

B-121

B-120

B-245

B-050/H

B-050/P

B-062

B-130

B-020

B-026

B-025

B-029

B-027

B-185

B-135

B-125

B-128

Code

B-001/LCD

B-003/BFA

B-003/LCD

B-004

B-001/PT

B-010

B-015

B-011/P

B-011/M

B-017

B-024

74

75

75

76

76

77

78

79

71

72

73

73

74

67

68

69

69

70

63

64

64

65

65

60

61

62

62

63

58

59

59

59

60

Page

49

55

56

56

57

58 www.alfatest.com.tr

47

48 www.alfatest.com.tr

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

▪ Used to test the compression strength of concrete cubes/cylinders of different sizes.

▪ The rigid design provides stability and strength for a better using experience.

▪ Equipped with an LCD unit that displays the data graphically of each test with the ability to save and recall the results of the tested specimens.

▪ The Data Acquisition Control provides real-time graphical indication.

▪ Automatically determines the load rate in accordance with the international standards upon sample type.

▪ With the AUTO-STOP function, the test will automatically stop.

▪ Fully automatic mode or manual mode in which the user gets the ability to adjust the load rate and period manually are available.

▪ The upper seating adjusts itself to apply homogeneous loading on the sample.

▪ Supplied complete with spacer discs.

Code

Capacity

B-001/LCD/1

1,125 kN

250,000 lb

B-001/LCD/2

2,000 kN

450,000 lb

B-001/LCD/3

3000 kN

650,000 lb

COMPONENTS www.alfatest.com.tr

49

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

TECHNICAL SPECIFICATIONS

• Fully Automatic.

• Graphical - LCD Data Acquisition Control System.

• Automatic Load Rate upon Sample Type.

• Stops Automatically, when Test is completed.

• Real time graph indication.

• Total Load and also Per Area are given.

• Test results can be transferred to computer to be printed or from the thermal printer.

• Different units are available (kN / kgf / lbf).

• Calibration done easily on 5 pts.

• Manual Control is available.

• If weight of sample entered, Unit Weight is determined.

• Rigid Frame.

• Upper and Lower Platens in accordance with international Specifications.

• Upper Seating for Homogeneous Loading.

• Distance Pieces included.

• Power Supply: 220 - 240 V / 50 - 60 Hz (110 V / 60 Hz is also available)

• Computer and printer are not included in the price

50 www.alfatest.com.tr

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

Capacity

Frame

Upper Platen

Dimension (A)

Lower Platen

Dimension (A)

Piston Stroke

(B)

Horizontal

Clearance (C)

Maximum Vertical

Clearance (D)

(F)

Height (H)

B-001/LCD/2

2000 kN

Welded, Rigid mono-block frame

Ø 300 mm

Ø 300 mm

50 mm

50 mm

330 mm

345 mm

185 mm

890 mm

B-001/LCD/3

3000 kN

Welded, Rigid mono-block frame

Ø 300 mm

Ø 300 mm

50 mm

50 mm

440 mm

345 mm

185 mm

940 mm

SAMPLE SIZES

• Cubes with side length of 100 mm, 150 mm, 200 mm or any other custom cube/prism size can be tested with the machine.

• Cylinders with diameter of 150 mm, 160 mm and height of 300 mm, 320 mm relatively or any other custom diameter and height can be tested with the machine.

NAVIGATING THROUGH THE LCD CONTROL UNIT

• Using the LCD control unit, to perform tests, to calibrate and to adjust the settings of the machine provides an easy and userfriendly experience.

www.alfatest.com.tr

51

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

PERFORMING THE TEST ACCORDING TO ASTM STANDARDS

• Simply navigate through the LCD control panel by selecting “TEST (ASTM)” from the main screen.

• Choose the diameter of the cylinder (in inches) or specify the custom dimensions of your sample.

• Choose the mode from the main screen by selecting either AUTOMATIC or MANUAL.

• Press “Start” to begin the test.

52 www.alfatest.com.tr

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

PERFORMING THE TEST ACCORDING TO EN STANDARDS

• Simply navigate through the LCD control panel by selecting “TEST (EN)” from the main screen.

• Choose the sample size (in millimeters) or specify the custom dimensions of your sample.

• Choose the mode from the main screen by selecting either AUTOMATIC or MANUAL.

• Press “Start” to begin the test.

www.alfatest.com.tr

53

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

THE DESIGN

• The rigid frame provides stability and firmness to the machine. Choosing the best components to build-up the machine gives the machine more strength and longer working-age.

CALIBRATING THE MACHINE

• Calibration can be easily done in 1 or 2 or … 5 points

• To view the Calibration Procedure, kindly navigate through the menu [MENU > CALIBRATION

MANUAL]

54 www.alfatest.com.tr

COMPRESSION TESTER (B-001/LCD)

ASTM C39 • EN 12390:4

▪ The tests and calibration can be done and monitored with a computer by connecting it to the machine. Using the state-ofthe-art software provided by ALFA with the machine will help performing and managing the tests in a very easy and fast way.

▪ By performing the tests via computer, the results can be saved and recalled when required. Reports can be generated automatically by the software and sent to printer.

FLEXURE APPARATUS for CONCRETE BEAMS (B-003/BFA)

▪ Used to perform flexural tests on concrete beams.

TECHNICAL SPECIFICATIONS

• Made of galvanized steel

• Can perform 3-points or 4-points flexural tests on the following concrete beam samples:

• 100 x 100 x 400 mm

• 100 x 100 x 500 mm

• 150 x 150 x 600 mm

• 150 x 150 x 750 mm www.alfatest.com.tr

55

FLEXURAL TESTING MACHINE (B-003/LCD)

▪ Used to test the flexural strength of the samples.

▪ The rigid design provides stability and strength to the machine for a better using experience.

▪ Equipped with an LCD unit that displays the data graphically of each test with the ability to save and recallthe results of the tested materials.

▪ The Data Acquisition Control provides a real-time graphical view for the sample.

▪ Automatically determines the load rate in accordance with the international standards upon sample type.

▪ With the AUTO-STOP function, the machine will automatically stop upon finishing the test.

▪ Can be made with different capacities and designs to serve varied purposes and to cover wider range of test samples such as:

▪ Tiles (with sizes up to 80 x 80 cm) (B-001/T)

▪ The capacity for the equipment is to be specified at the time of inquiry.

▪ The maximum size of sample is to be specified at the time of inquiry.

SLAB TESTING MACHINE (B-004)

56

▪ Fully Automatic

▪ Graphical Data Acquisiton Control System

▪ Two Pistons with Capacity of 100 kN each

▪ Flexure span is adjustable

▪ Flexure test for 3 or 4 points

▪ Hydraulic System

▪ Supplied with 2 deformation measurement systems www.alfatest.com.tr

CONCRETE PIPE TESTING MACHINE (B-001/PT)

▪ Supplied with a graphical LCD Data Acquisition

Control System and an ability to store and report the results.

▪ The calibration for the equipment can be easily done on 5 pts.

▪ Pipe length and diameter should be specified at the time of inquiry.

Code

Capacity

Pipe Diameter

Pipe Length

B-001/PT/0400

400 kN

40 ton

Min. 300 mm

Max. 1600 mm

Min. 1000 mm

Max. 2000 mm

Concrete Pipe Tester (B-001/PT)

B-001/PT/1000

1000 kN

100 ton

Min. 300 mm

Max. 2400 mm

Min. 1500 mm

Max. 3000 mm www.alfatest.com.tr

57

CYLINDER MOULD (B-010)

▪ Designed to be easily mounted and demounted.

▪ Available in two types; Metal and Plastic.

▪ Different sizes are available:

▪ Ø 10 x 20 cm (Ø 4” x 8”)

▪ Ø 15 x 30 cm (Ø 6” x 12”)

▪ Ø 16 x 32 cm

Cylinder Mould (B-010/M)

Code

B-010/M/10

B-010/M/15

B-010/M/16

B-010/P/10

B-010/P/15

TECHNICAL SPECIFICATIONS

• Capping pot:

• Thermally Controlled

• Double wall / isolated.

• Capping apparatus

Diameter / Height

Ø 10 x 20 cm

Ø 15 x 30 cm

Ø 16 x 32 cm

Ø 10 x 20 cm

Ø 15 x 30 cm

Cylinder Mould (B-010/P)

CYLINDRICAL CAPPING SET (B-015)

▪ Consists of a melting pot and a Capping Apparatus.

▪ The melting pot is used to melt the capping compounds. The temperature of the pot is adjustable with the thermoregulator. Pilot lamp built-in the pot is used to indicate the heating status.

▪ The melting pot is made of double-walled frame.

Cylindrical Capping Set (B-015)

Code

B-015

Dimensions (± 1 cm) Approximate Weight (kg)

33 x 29 x 29 (h) 22

58 www.alfatest.com.tr

MOULDS (B-01x)

Code

B-011/M/10

B-011/P/10-2

B-011/M/15

B-001/P/15

B-011/M/20

B-017/40

B-017/50

B-017/60

B-017/75

Shape

Cube

Cube

Cube

Cube

Cube

Prism / Beam

Prism / Beam

Prism / Beam

Prism / Beam

Material

Steel

Plastic

Cast Iron

Plastic

Cast Iron

Steel

Steel

Steel

Steel

Type

Single Gang

Double Gang

Single Gang

Single Gang

Single Gang

Single Gang

Single Gang

Single Gang

Single Gang

Internal Dimensions

(mm)

100 x 100 x 100

100 x 100 x 100

150 x 150 x 150

150 x 150 x 150

200 x 200 x 200

100 x 100 x 400

100 x 100 x 500

150 x 150 x 600

150 x 150 x 750 www.alfatest.com.tr

59

CONCRETE FLOW TABLE (B-024)

• Used for determining the concrete workability

• Consists of flow table, cone and wooden tamper

SUPPLIED WITH

• Cone (Ø 130/200 mm - Height 200 mm)

• Wooden Tamper

VEBE CONSISTOMETER (B-130)

BS 12350 • BS 1881-104

• Consists of a vibrating table, a cylindrical pan, a slump cone, and a disc attached to a freemoving rod that serves as a reference end point.

• The cone is placed in the pan, filled with concrete, and removed. The disc is brought into position on top of the concrete cone, and the vibrating table is set in motion.

• The time required to remould the concrete, from the conical to the cylindrical shape, is a measure of the consistency and is reported as Vebe Seconds.

60

TECHNICAL SPECIFICATIONS

• EN 12350, BS 1881-104

• Fixed amplitude and frequency

• Supplied with:

• Acrylic Disc

Code

B-130

Dimensions (± 1 cm) Approximate Weight (kg)

56 x 30 x 87 (h)

• Slump Cone

• Tamping Rod

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

105 www.alfatest.com.tr

Vebe Consistometer (B-130)

SLUMP SET (B-020)

BS 12350 • BS 1881 • ASTM C143

▪ The consistency is a measure of the wetness of the concrete mixture, which is commonly evaluated in terms of slump. The test gives indication of the ease with which the concrete flows.

▪ Available in galvanized or stainless steel.

Slump Set (B-020/G)

Slump Cone

Base Plate

Item

Slump Cone Funnel

Tamping Rod (Ø16 mm x 600 mm)

Galvanized

(B-020/G)

B-020/G/C

B-020/G/BP

B-020/G/F

B-020/G/TR

Stainless Steel

(B-020/SS) *

B-020/SS/C

B-020/SS/BP

-

-

* With stainless steel slump set, the supplied slump cone funnel and tamping rod are made of galvanized steel. www.alfatest.com.tr

61

L-BOX APPARATUS (B-026)

• Used to determine the confined flowability of fresh Self-

Consolidating Concrete (SCC) and to evaluate the filling and passing ability

• Made of stainless steel

• Supplied with 2 different obstacles:

• 2 x Ø12 mm smooth bars having 59 mm gaps

• 3 x Ø12 mm smooth bars having 41 mm gaps

TECHNICAL SPECIFICATIONS

• Made of stainless steel

• Guillotine form gate

V-FUNNEL APPARATUS (B-025)

• Used in Flow-time determination for Self-Consolidating

Concrete (SCC)

• Out flow orifice is equipped with a valve that can be openned momentarely

• Supplied with bucket

TECHNICAL SPECIFICATIONS

• Made of stainless steel

• Stand-mounted

62 www.alfatest.com.tr

U-SHAPE BOX APPARATUS (B-029)

• Used to determine the confined flowability of Self-

Consolidating Concrete (SCC)

TECHNICAL SPECIFICATIONS

• Made of stainless steel

• Guillotine form gate

J-RING APPARATUS (B-027)

ASTM C1621

• Used to determine the passing ability of self-consolidating concrete (SCC).

• The apparatus consists of a rigid ring supported on sixteen 16 mm (5/8 in) diameter rods equally spaced on a 300 mm (12 in) diameter circle 100 mm (4 in) above a flat surface.

• Supplied with slump cone, tamping rod and base plate.

TECHNICAL SPECIFICATIONS

• Evenly distributed 16 rods, each with Ø 16 mm diameter

Vibrating Table (B-125)

Poker Vibrator (B-128) www.alfatest.com.tr

63

COMPACTING FACTOR APPARATUS (B-185)

▪ Consists of two conical hoppers attached on a cylinder, and everything is fixed on a robust steel frame.

▪ Each hopper is equipped with a hinge for a Quick Release mechanism.

▪ The apparatus is designed to perform the test in a more precise and accurate way.

▪ The compacting factor is the ratio between the weight of the concrete which is partially compacted in the cone to the weight of the fullycompacted concrete in the cylinder.

▪ Supplied with a tamping rod.

TECHNICAL SPECIFICATIONS

• Two conical hoppers

• A cylindrical mould fitted beneath the hoppers

• Supplied with:

• Tamping Rod

Code

B-185

Dimensions (± 1 cm)

55 x 35 x 130 (h)

CONCRETE PENETROMETER (B-135)

▪ Used to determine the setting time of mortar fraction in concrete mixes for samples with slump more than zero.

▪ Consists of a spring penetrometer and interchangeable stainless steel needles.

▪ Equipped with a sliding ring that indicates the load reached upon testing.

SUPPLIED WITH

• Carrying Case

64 www.alfatest.com.tr

Compacting factor apparatus (B-185)

Concrete Penetrometer (B-135)

VIBRATING TABLE (B-125)

▪ Designed from robust steel sheets and has a very steady frame.

▪ Used to compact the concrete specimens in the laboratory.

▪ The Vibrating Table size is 400 x 600 mm.

▪ Equipped with a vibrating motor.

▪ Supplied with a clamp Assembly for moulds.

TECHNICAL SPECIFICATIONS

• Vibrating Table :400x600 mm

• Clamp Assembly for moulds

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

B-125

Dimensions (± 1 cm) Approximate Weight (kg)

41 x 61 x 87 (h) 53

POKER VIBRATOR (B-128)

▪ The lab-type poker vibrator is used for internal compaction for the concrete specimens.

▪ The flexible shaft is 1 meter long.

TECHNICAL SPECIFICATIONS

• Lab Type

• 1 m. flexible shaft

• Direct Connection to the Motor

• Power Supply: 220 - 240 V / 50 or 60 Hz

Vibrating Table (B-125)

Poker Vibrator (B-128) www.alfatest.com.tr

65

66 www.alfatest.com.tr

AIRMETER (B-320/B)

ASTM C213 • BS 1881-106

▪ Used to determine the the volume change in a sample due to the application of pressure.

▪ The pressure gauge shows the direct percentage (to the nearest

0.1%) for the amount of air entrained.

▪ The capacity for the airmeter is 7 liters.

▪ The maximum aggregate size that can be used in this airmeter is

50 mm.

▪ The pump is built-in with the equipment.

▪ Supplied with a straight edge and a syringe.

SUPPLIED WITH

• Straight edge

• Syringe

• Plastic carrying case

TECHNICAL SPECIFICATIONS

• B Type Air Meter

• Capacity : 7 lt

• Air Content range : 0% - 100%

• Max Aggragate Size : 50 mm

• Built-in pump

Airmeter (B-320/B) www.alfatest.com.tr

67

CURING TANK - PLASTIC (B-140/P)

ASTM C31 • BS 1881-11

▪ Used to cure cylinders, cubes, beams and other samples that requres total immersion in water at a speficied constant temperature.

▪ Equipped with a digital thermostat and indicator.

▪ Supplied with a base rack and a water circulation pump.

Curing Tank - Plastic (B-140/P)

SUPPLIED WITH

• Digital Thermostat and indicator

• Base Rack

• Water Circulation Pump

Code

B-140/P

B-140/P-L

TECHNICAL SPECIFICATIONS

• Made of plastic

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Dimensions (± 1 cm)

150 x 100 x 80 (h)

200 x 100 x 80 (h)

Capacity (lt)

1200

1600 www.alfatest.com.tr

CURING TANK - METAL (B-140/M)

ASTM C31 • BS 1881-11

▪ Used to cure cylinders, cubes, beams and other samples that requres total immersion in water at a speficied constant temperature.

▪ Equipped with a digital thermostat and indicator.

▪ Supplied with a base rack and a water circulation pump.

Curing Tank (B-140/M)

SUPPLIED WITH

• Digital Thermostat and indicator

• Base Rack

• Water Circulation Pump

TECHNICAL SPECIFICATIONS

• Made of powder-coated metal

• Power Supply: 220 - 240 V / 50 or 60 Hz (110

V / 60 Hz is also available)

Code

B-140/M

Dimensions (± 1 cm) Approximate Weight (kg)

220 x 75 x 85 106

Controling Unit (B-140/M/CU) www.alfatest.com.tr

69

DRUM - TYPE MIXER (B-121)

▪ Used to create concrete mixes and specimens.

The drum-type mixers provides efficient and homogeneous mixtures.

▪ Equipped with a manual discharge placed at the side of the mixer for direct emptying for the drum.

TECHNICAL SPECIFICATIONS

• Capacity : 120 Lt

• Lightweight but sturdy

• Mixing blade built in

• Power Supply: 220 - 240 V / 50 or 60 Hz

Code

B-121

Dimensions (± 1 cm) Approximate Weight (kg)

75 x 125 x 66 (h) 70

Drum-Type Mixer (B-121)

70 www.alfatest.com.tr

PAN - TYPE MIXER (B-120)

▪ Used to create concrete mixes and specimens. The pan-type mixers provides efficient and homogeneous mixtures.

▪ Equipped with a manual discharge placed at the side of the mixer for direct emptying for the pan.

▪ The capacity of the pan is 100 lt, and the efficient mixing capacity is 56 lt.

TECHNICAL SPECIFICATIONS

• Pan Capacity: 100 lt.

• Efficient Capacity: 56 lt.

• Easy lifting mechanism

• Portable

• Rotated by a motor reducer

• Complete with blades

Code

B-120

Dimensions (± 1 cm) Approximate Weight (kg)

97 x 98 x 117 (h) 236

B-011/10M

Pan - Type Mixer (B-120) www.alfatest.com.tr

71

CONCRETE WATER IMPERMEABILITY TESTER (B-245)

EN 12390:8

▪ Used for determining the depth of penetration of water under pressure.

▪ Cubic, prismatic or cylindrical specimens having maximum dimensions of 200 x 200 x 200 mm can be tested.

▪ Once the concrete specimens clamped, the water under known pressure is applied.

▪ The water penetrated to the specimen is measured either by taking the reading through the graduated burette or by breaking the specimen.

▪ Monometer fixed on the front panel is supplied to check water pressure.

▪ Supplied less with air compressor. Air compressor should be ordered separately at the time of inquiry.

TECHNICAL SPECIFICATIONS

• Cubic, prismatic or cylindrical specimens

(max. 200 x 200 x 200 mm) can be tested.

• Monometer fixed on the front panel is supplied to check water pressure.

Code

B-245

Dimensions (± 1 cm) Approximate Weight (kg)

167 x 83 x 202 (h) 215

Concrete Water Impermeability Tester (B-245)

72 www.alfatest.com.tr

FERRODETECTOR (B-050/H)

▪ The ferrodetector is a very simple, easy-to-use bar detector.

Used to determine the position of the steel rebar in a wall, column, beam or any other construction section.

▪ The detection range for ferrous metals is 5-120 mm for rebar larger than Ø8 mm and 5-100 mm for rebar with Ø6 - Ø8 mm.

▪ The detection range for the non-ferrous metals is 5-80 mm for rebar larger than Ø10 mm.

▪ The detection accuracy for the rebar is ±10 mm.

▪ Works on batteries and lasts for around 10 hours. Hence it can be used in the laboratory or insitu.

Ferrodetector (B-050/H)

SUPPLIED WITH

• Carrying Case

• Marker

Code

Dimensions

(± 1 cm)

B-050/H 24 x 11 x 47 (h)

Approximate

Weight (kg)

0.4 g

TECHNICAL SPECIFICATION:

• Detetion Range:

• Ferrous Metals: > Ø8 mm (5-120 mm) / Ø6 - 8 mm (5-100 mm)

• Non-Ferrous Metals: > Ø10 mm (5-80 mm)

• Localization Accuracy: ±10 mm

• Battery Life: 10 hrs

• Operating Temperature: -15 to +50

• Relative Air Humidity: 95%

• Automatic Cut-out: 5 minutes

PROFOSCOPE - PROCEQ (B-050/P)

▪ A rebar detector with real-time visualization of the rebars beneath the instrument

▪ Visual indication of rebars in close proximity

▪ Rebar detector with the ability to identify the mid-point between rebars as well as the orientation of rebars

▪ Optical and acoustical indication of rebar location and minimum cover alert

▪ This rebar detector offers neighboring bar correction

SUPPLIED WITH

• Carrying Case

• Marker

TECHNICAL SPECIFICATION:

• Rebar detector

• Measurement of concrete cover

• Measurement of rebar diameter

• Checking for minimum cover

Profoscope - PROCEQ (B-050/P)

Code

B-050/P

Dimensions (± 1 cm) Approximate Weight (kg)

21 x 9 x 4 (h) 0.3 g www.alfatest.com.tr

73

UNIVERSAL CUTTING MACHINE (B-062)

▪ Used to cut construction materials.

It is equipped with a disc holder for a maximum diameter of 450 mm.

▪ Ideal for wet cutting.

▪ Supplied with precision linear guide bar system with dust proof aluminum cover and Automatic thermal overload protection.

SUPPLIED WITH

• Circulation pump for cooling purposes

TECHNICAL SPECIFICATIONS

• Disc diameter: Maximum 450mm.

• Power Supply: 220 - 240 V / 50 or 60 Hz

CUTTING MACHINE (B-063)

▪ Used to cut rocks, ores, consturction materials ... etc.

▪ Supplied with a disc holder and a disc having diameter of 350 mm

▪ Equipped with:

▪ Water inlet for wet cutting.

▪ Thermal overload protection.

TECHNICAL SPECIFICATIONS

• Disc Diameter: 350 mm

• Water Inlet for Wet Cutting

• Thermal Overload Protection

• Power Supply: 220 - 240 V / 50 or 60 Hz

74 www.alfatest.com.tr

CORING MACHINE (B-061)

▪ Used to take core samples from irregular rocks or to extrude the core from specimens for test purposes.

▪ Equipped with a 2-speed electrical motor and a water inlet (hose).

▪ Standard 1 ¼” thread

▪ Core Bits should be ordered separately

Coring Machine (B-061)

TECHNICAL SPECIFICATION:

• Electric Motor

• 2-Speed

• Water inlet (Hose)

• Standard 1 ¼” thread

• Power Supply: 220 - 240 V / 50 or 60 Hz

Code

B-061

Dimensions (± 1 cm) Approximate Weight (kg)

55 x 30 x 121 (h) 35

Code

Core Bit Diameter

B-061/4

4” (≈ 100 mm)

B-061/6

6” (≈ 150 mm)

Coring Machine (B-061/R)

Core Bits www.alfatest.com.tr

75

DIGITAL CONCRETE TEST HAMMER (B-110/D)

ASTM C805 • BS 1881-202

▪ Used to perform a non-destructive test on concrete structure.

▪ The hammer gives an immediate indication about the compressive strength of the structural element.

▪ The compressive strength range that can be read by the equipment is from 10 to 70 N/mm

2

.

SUPPLIED WITH

• Carborundum Stone

• Carrying Case

TECHNICAL SPECIFICATIONS

• Compressive strength: 10 - 70 N/mm

2

Digital Concrete Test Hammer (B-110/D)

TESTING ANVIL (B-117)

▪ Used to verify the calibration for the rebound test hammers for concrete.

▪ It’s made of a very robust stainless steel.

▪ The rebound value is 80 ± 2.

▪ Standards recommend the use of the Anvil before any sequence of test using the test hammers. Before and after every sequence of tests, anvil value should be recorded and

TECHNICAL SPECIFICATIONS

• Used for Test Hammers

• Rebound Value :80 ± 2

• Made of Stainless Steel

76

Code

B-117

Dimensions (± 1 cm)

Dia: 15 / h: 32 www.alfatest.com.tr

Approximate Weight (kg)

17

Testing Anvil (B-117)

CONCRETE TEST HAMMER (B-110)

ASTM C805 • BS 1881-202

▪ Used to perform a non-destructive test on concrete structure.

▪ The hammer gives an immediate indication about the compressive strength of the structural element.

▪ The compressive strength range that can be read by the equipment is from 10 to 70 N/mm

2

.

SUPPLIED WITH

• Carborundum Stone

• Carrying Case

TECHNICAL SPECIFICATIONS

• Compressive Strength :10-70 N /mm

2

Code

B-110

Dimensions (± 1 cm) Approximate Weight (kg)

35 x 18 x 16 (h) 2

Concrete Test Hammer (B-110) www.alfatest.com.tr

77

CRACK DETECTION MICROSCOPE (B-250)

▪ Used to measure the crack width in the concrete elements.

▪ Supplied with an adjustable light source and adjustable focus to have a better and clearer view for the crack.

▪ The measuring range for the microscope is 0 to 4 mm. with divisions of 0.2 mm and subdivisions of 0.02 mm.

▪ The magnification ability of the microscope is x50.

▪ The microscope is supplied with a wooden case and batteries.

SUPPLIED WITH

• Wooden case

• Battery

TECHNICAL SPECIFICATIONS

• Integral illumination

• Rotating eyepiece

• Focus adjustment

• Range 0 to 4 mm

• Sub –divisions: 0.02 mm

• Magnification: x50

• Supplied with:

• Wooden case

• Battery

78 www.alfatest.com.tr

Crack Detection Microscope (B-250)

ULTRASONIC TESTER (B-048)

ASTM C597 • BS 1881

▪ Used to determine the place for the cracks, voids or defects in the in-situ or precast concrete elements and for long-term observation for the structure which is subjected to all the environmental conditions.

▪ The data obtained from the machine gives an indication regarding the homogeneity of the structural element using the sound pulse and by measuring the time needed for the sound to travel within the element.

▪ Calibration tools are also provided to zero the reading.

▪ Supplied with:

▪ Two piezoelectric probes (55 KHz each) with connection cables

▪ Calibrating cylinder

▪ Contact paste

▪ Carrying case

TECHNICAL SPECIFICATIONS

• Measuring range

• Accuracy

• 2 outlets for connection to the oscilloscope

• 2 piezoelectric probes 55 KHz

• Calibration facility

: 0 - 3000 µs

: ± 0.1 µs

Ultrasonic Tester (B-048) www.alfatest.com.tr

79

STEEL REBAR TESTING

80 www.alfatest.com.tr

INDEX STEEL REBAR

Item

Universal Tensile and Compression Tester

Electromechanical Tensile Tester

Code

UTM-001

UTM-001/EM

Page

83

89 www.alfatest.com.tr

81

82 www.alfatest.com.tr

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

TENSILE TESTING

▪ Used to test the tensile strength of steel rebar.

▪ The grippers of the machine is hydraulically operated by 2 independent auxiliary cylinders controlled by separated hydraulic valves. Those grippers are designed to firmly hold the steel rebar and avoid any slipping that might happen during the test on the rebar.

▪ The upper mobile crosshead part of the machine is driven up/down by hydraulic piston. It is used to adjust the distance between upper and lower grippers to suite the length of the steel rebar.

▪ Designed with different capacities (upon user’s request) such as: 300 kN (30 tons) / 600 kN (60 tons) / 1000 kN (100 tons) / 2000 kN (200 tons)

▪ Capable of testing specimen with diameters ranging from 8 mm to 42 mm depending on the capacity.

▪ Provides easier and faster reporting with the printing facility for the results and graphs.

▪ The height is only 195 cm.

COMPRESSION TESTING

▪ Used to test the compression strength of concrete cubes/cylinders of different sizes.

▪ Equipped with an LCD unit that displays the data graphically of each test with the ability to save and recall the results of the tested materials.

▪ The Data Acquisition Control provides a real-time graphical view for the sample.

▪ Automatically determines the load rate upon sample type and in accordance with the international standards.

▪ With the AUTO-STOP functionality, the machine will automatically stop upon finishing the test.

▪ Upon user requirements, the machine can be either work in fully automatic mode or manual mode at which the user gets the ability to adjust the load rate and period manually.

▪ The upper seating adjusts itself to apply homogeneous loading on the sample.

▪ For faster experience while testing, the daylight distance between the upper and lower platens can be adjusted using the hydraulic piston in accordance with the sample height; this will give the machine the ability to test all varieties of samples with a very wide range of sizes.

www.alfatest.com.tr

83

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

TENSILE TESTING

▪ Fully Automatic - PC Controlled

▪ Hydraulically operated grippers by 2 independent auxiliary cylinders controlled by separated hydraulic valves

▪ Upper mobile crosshead driven up/down by a separated motor adjusting the distance between upper and lower grips with electronic distance meter

▪ Available models:

▪ 300 kN (30 tons)

▪ 600 kN (60 tons)

▪ 1000 kN (100 tons)

▪ 2000 kN (200 tons)

▪ Height: 210 cm only.

▪ Print of Stress/Strain Diagram and Test Results.

COMPRESSION TESTING

• Fully Automatic.

• Graphical - LCD Data Acquisition Control

System.

• Automatic Load Rate upon Sample Type.

• Stops Automatically, when Test is completed.

• Real time graph indication.

• Total Load and also Per Area are given.

• Test results can be transferred to computer to be printed or from the thermal printer.

• Different units are available.

Universal Tensile and Compression Tester (UTM-001)

• Calibration done easily on 5 pts.

• Manual Control is available.

• If weight of sample entered, Unit Weight is determined.

• Rigid Frame.

• Upper and Lower Platens in accordance with international Specifications.

• Upper Seating for Homogeneous Loading.

• Power Supply: 220 - 240 V / 50 - 60 Hz (110 V / 60 Hz is also available)

84 www.alfatest.com.tr

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

USING THE MACHINE

• The LCD control unit provides an easy, user-friendly experience with the machine. With the LCD unit, the user can control and monitor the tests/adjust the settings/calibrate the machine.

• Performing the tests are now the easiest ever. With the computer connected to the machine, all the tests/ monitoring/calibrating can be done via computer using the state-of-the-art ALFA software provided with the machine.

CAPACITY vs SAMPLE

Code

Capacity

Sample Diameter Range

UTM-001/LCD/030 UTM-001/LCD/060 UTM-001/LCD/100 UTM-001/LCD/200

300 kN 600 kN 1000 kN 2000 kN

Ø 8 - 28 mm Ø 8 - 32 mm Ø 10 - 36 mm Ø 12 - 42 mm www.alfatest.com.tr

85

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

PERFORMING THE TEST

▪ The test is performed through the computer using ALFA’s state-of-the-art software designed specially to ease the test and perform all the required calculations automatically.

APPLYING DIAMETER CORRECTION FACTOR

• When testing deformed reinforcement bars, it is usually difficult to measure the correct and effective diameter of the bar. To overcome this problem, ALFA is providing the diameter correction factor option within its software to automatically calculate the effective diameter by using the weight and the length of the tested bar.

86 www.alfatest.com.tr

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

TEST REPORT www.alfatest.com.tr

87

UNIVERSAL TENSILE AND COMPRESSION TESTER (UTM-001)

HAND-HELD POSITIONING UNIT

▪ This hand-held unit is used for positioning the upper cross-head, to suite the sample height, and to tighten the grippers on the sample before testing.

SAMPLE GRIPPERS

▪ The specially designed grippers are used to hold the sample hydraulically while testing. The grippers have 2 different groves to suite wide range of samples.

88 www.alfatest.com.tr

ELECTROMECHANICAL TENSILE TESTER (UTM-001/EM)

▪ Specially designed for testing components and for routine materials such as sheets, wires, strips, ropes, belts, screws, composites, nylon ribbon, rubber, geosynthetics, geotextiles ... etc

▪ Features precision guidance for mobing crosshead and a low wearball screw trouble-free tensile tests.

TECHNICAL SPECIFICATIONS

• Loading Capacity: 100 kN / 150 kN / 200 kN

• Sensitivity: >1%

• Speed Control by Servo-Motor

• Supplied with:

• Grip Sets for Bars and Metal Sheets

• Laptop & Software

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available) www.alfatest.com.tr

89

CEMENT

90 www.alfatest.com.tr

INDEX CEMENT

Item

Cement Compression and Flexural Tester

Compression Jig

Flexural Jig

Cement Compression Test Mould

Cement Flexural Test Mould

Blain Apparatus

Mud Balance

Marsh Funnel

Jolting Table

Cement Vibrating Machine

Vicat Apparatus

Automatic Vicat Apparatus

Motorized Flow Table

Flow Table

Cement Mixer

Mortar Mixer

Automatic Cement Mixer

Automatic Mortar Mixer

Le Chatelier Flask

Le Chatelier Mould

Le Chatelier Bath

C-125

C-126

C-090

C-090/A

C-021/M

C-021

C-050

C-050

C-050/A

C-050/A

C-022

C-023

G-040/06

Code

C-001/LCD

C-011/CJ

C-011/FJ

C-011

C-011/04

C-035

C-014

C-015

101

102

102

103

103

97

97

98

99

100

104

104

105

95

95

96

96

96

Page

93

94

94 www.alfatest.com.tr

91

92 www.alfatest.com.tr

CEMENT COMPRESSION & FLEXURAL TESTER (C-001/LCD)

▪ Designed to be fully automatic.

▪ Equipped with an LCD Data Acquisition Control System.

▪ The load rate is automatically controlled upon the samples.

▪ Provided with a double testing chamber. It performs flexure test for the size

(40 x 40 x 160 mm) and compression test on cubes of size (40 x 40 x 40 mm) and/or (50 x 50 x 50 mm).

▪ The test results can be transferred to a computer (should be ordered separately) or a thermal printer (should be ordered separately).

• User-friendly 5-Points calibration

TECHNICAL SPECIFICATIONS

• Capacity : 15 kN / 200 kN (Flexure / Compression)

• Rigid 2-Column frame

• Used for flexure and compression tests on cement samples

• Full Automatic

• LCD Graphical Data Acquisiton Control System

• Stops Automatically upon test completion

• Real time graph indication

• Maximum load and stress are shown

• Unit selection available (kN, kgf, lbf)

• User-friendly 5-Points calibration (password protected)

• Supplied with Jigs to perform:

• Compression Tests on either 40 mm or 50 mm cube samples

• Flexure Tests on 40 x 40 x 160 mm prism samples

• Power Supply: 220 - 240 V / 50 - 60 Hz (110 V / 60 Hz is also available)

Code

C-001/LCD

Dimensions (± 1 cm) Approximate Weight (kg)

95 x 60 x 140 (h) 323 www.alfatest.com.tr

93

COMPRESSION JIG (C-011/CJ)

▪ Used for cement compression for the cubes of sizes 40 or

50 mm (to be specified at the time of order).

▪ The platens have hardness of 60 HRC and the upper one is seat-ball assembled.

▪ Rust-protected by cadmium.

Code

C-011/CJ/40

C-011/CJ/50

Samples to be tested Dimensions (± 1 cm) Approximate Weight (kg)

40 x 40 x 40 mm cubes

40 x 40 x 40 mm and

50 x 50 x 50 mm cubes

Dia: 15 / h: 19

Dia: 15 / h: 19

12

12

Compression Device (C-011/CJ)

FLEXURAL JIG (C-011/FJ)

▪ The distance between the lower bearers is 100 mm and one of them has a spherical seat.

▪ Provided with rust protection with the cadmium plating.

▪ Used for flexure tests of 40 x 40 x 160 mm specimen.

Code

C-011/FJ

Dimensions (± 1 cm) Approximate Weight (kg)

Dia: 15 / h: 19 11

Flexure Device (C-011/FJ)

94 www.alfatest.com.tr

CEMENT COMPRESSION TEST MOULD (C-011)

▪ Used to prepare samples for cement compression tests.

▪ The mould is available in two sizes:

▪ 50.0 x 50.0 x 50.0 mm (3-gang)

▪ 70.7 x 70.7 x 70.7 mm

(C-011/05)

(C-011/07)

Code

C-011/05

C-011/07

Dimensions (± 1 cm) Approximate Weight (kg)

20 x 8 x 6 (h) 4.0

28 x 13 x 8.5 (h) 10

CEMENT FLEXURAL TEST MOULD (C-011/04)

▪ The 3-gang mould is used to prepare samples for cement flexure tests.

▪ The internal size for the mould is (40 x 40 x 160 mm).

Cement Compression Test Mould (C-011/05)

Code

C-011/04

Dimensions (± 1 cm) Approximate Weight (kg)

23 x 37 x 6 (h) 11.2

Cement Flexure Test Mould (C-011/04) www.alfatest.com.tr

95

BLAINE APPARATUS (C-035)

ASTM C204 • BS 4359:2

▪ Used to determine the fineness of the cement.

▪ Supplied with:

U-shaped tube, filter papers, plunger, stainless-steel cell and perforated disc.

TECHNICAL SPECIFICATIONS

• Comprising:

• SS Cell

• Perforated disc

• Plunger

• U-Tube Glass Manometer

• Filter Paper

MUD BALANCE (C-014)

▪ Used to determine the density of the mud.

▪ Consists of a graduated arm with a cup, lid, knife edge, counter weight and carrying case.

Mud Balance (C-014)

TECHNICAL SPECIFICATIONS

Code

C-014

Dimensions

(± 1 cm)

58 x 14 x 12 (h)

96 www.alfatest.com.tr

Approximate Weight

(kg)

2.0

Blaine Apparatus (C-035)

MARSH FUNNEL (C-015)

▪ Used to determine the viscosity of the drilling mud and other fluid materials.

▪ Consists of a funnel and graduated cup. Both made from a very strong and break-resistant plastic.

Marsh Funnel (C-015)

TECHNICAL SPECIFICATIONS

Code

C-015

Dimensions

(± 1 cm)

16 x 16 x 37 (h)

Approximate Weight

(kg)

0.3

JOLTING TABLE (C-125)

▪ Used to compact cement mortar prisms in the moulds.

▪ The 3-gang mould is placed on a table which is mounted above a cam. The rotating cam is driven by a gearbox at 60 rpm.

▪ Equipped with digital programmable counter for cycle counting.

▪ Designed to have a very rigid structure for stability purposes.

▪ The table drop height for Designed to be 15.0 mm.

▪ The motor and gearbox assembly is enclosed in a protective housing; therefore, there are no moving parts in the body outside the housing.

TECHNICAL SPECIFICATIONS

• Used to compact 40 x 40 x 160 mm cement specimens.

• Digital programmable Counter for cycle.

• Rigid structure for stability.

• Table drop height is 15.0 mm.

• Easily mounted and demounted.

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

C-125

CEMENT VIBRATING MACHINE (C-126)

▪ Used to vibrate cement mortar cube sample in the

70.7 mm cube moulds.

▪ Mould to be ordered separately

Jolting Table (C-125)

Dimensions (± 1 cm)

120 x 38 x 46 (h)

TECHNICAL SPECIFICATIONS

• Vibration Frequency: 12000

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available) www.alfatest.com.tr

97

VICAT APPARATUS (C-090)

ASTM C187 • ASTM C191 • BS 4550

▪ The reaction between cement and water are the primary causes of the setting of concrete. The setting time for cement and concrete is determined using the Vicat Apparatus.

▪ By measuring the setting time for concrete/cement via the penetration resistance method (Vicat Apparatus), the time the concrete/cement can stay fresh can be determined. This time indicates the period the mix can stay in the mixer before pouring it into the moulds/ frameworks.

▪ Complete with the frame, mould, initial setting time needle, consistency plunger, glass thermometer and the base glass plate.

TECHNICAL SPECIFICATIONS

• Set comprises:

• Vicat Frame

• Vicat Mould

• Initial Needle

• Consistency Plunger

• Glass Thermometer

(C-090/F)

(C-090/M)

(C-090/IN)

(C-090/CP)

(GTC)

Code

C-090

Dimensions (± 1 cm)

13 x 18 x 33 (h)

Approximate Weight (kg)

3.5

98 www.alfatest.com.tr

Vicat Apparatus (C-090)

AUTOMATIC VICAT APPARATUS (C-090/A)

ASTM C187 • ASTM C191 • EN 196-3

▪ The reaction between cement and water are the primary causes of the setting of concrete. The setting time for cement and concrete is determined using the Vicat Apparatus.

▪ By measuring the setting time for concrete/cement via the penetration resistance method (Vicat Apparatus), the time the concrete/cement can stay fresh can be determined. This time indicates the period the mix can stay in the mixer before pouring it into the moulds/frameworks.

▪ Designed to be fully automatic with very precise and reputable result.

▪ Test results can be easily printed on any incorporated printer.

▪ Guiding menu is available in multi-languages (English, French, German and Italian).

▪ Equipped with a large LCD display to show the test results data. The test will automatically print a report with all data.

TECHNICAL SPECIFICATIONS

• Fully automatic, equipped with LCD display

Code

C-090/A

Dimensions (± 1 cm) Approximate Weight (kg)

40 x 20 x 47 (h) 13

Automatic Vicat Apparatus (C-090/A) www.alfatest.com.tr

99

MOTORIZED CEMENT FLOW TABLE (C-021/M)

▪ The test gives indications about the consistency of the cement mortars which is one of the most important characteristics for the mortars in the engineering aspects.

▪ The test is done by placing the specimen in the mould. After specifying the number of drops and running the machine, the plate will raise and drop along with the mould in a specific range for a specified number of times (entered by the user using the digital counter) depending onthe test needs.

▪ Supplied with the testing mould.

TECHNICAL SPECIFICATIONS

• Used for determining the consistency of cement mortars.

• Supplied with mould.

Motorized Cement Flow Table (C-021/M)

100 www.alfatest.com.tr

CEMENT FLOW TABLE (C-021)

▪ The test gives indications about the consistency of the cement mortars which is one of the most important characteristics for the mortars in the engineering aspects.

▪ The test is done by placing the specimen in the mould.

By turning the handle, the mould will raise and drop in a specific range for a specified number of times depending on the test needs.

▪ Supplied with the testing mould.

TECHNICAL SPECIFICATIONS

• Used for determining the consistency of cement mortars.

• Supplied with mould.

Code

C-021

Dimensions (± 1 cm) Approximate Weight (kg)

34 x 26 x 32 (h) 13.8

Cement Flow Table (C-021) www.alfatest.com.tr

101

CEMENT/MORTAR MIXER (C-050)

▪ Used to assure an efficient mixing for the cement and the mortars.

▪ Can take a capacity up to 5 liters.

▪ Equipped with a planetary mixing mechanism for better performance.

▪ The beater speed is adjustable between 140 rpm and 285 rpm.

TECHNICAL SPECIFICATIONS

• Bowl Capacity: 5 Lt.

• Planetary mixing action.

• Beater Speeds: 140 rpm / 285 rpm.

• Power Supply: 380 V (3 phase)

Code

C-050

Dimensions (± 1 cm) Approximate Weight (kg)

45 x 56 x 58 (h) 78

Cement/Mortar Mixer (C-050)

102 www.alfatest.com.tr

AUTOMATIC CEMENT/MORTAR MIXER (C-050/A)

▪ Used to assure an efficient mixing for the cement and the mortars.

▪ Can take a capacity up to 5 liters.

▪ The mixer is equipped with a planetary mixing mechanism for better performance.

▪ The beater speed is adjustable between 140 rpm and

285 rpm.

▪ The mixer automatically add the sand at the correct time depending on the selected standard.

TECHNICAL SPECIFICATIONS

• Automatic mixing

• Bowl Capacity: 5 Lt.

• Planetary mixing action.

• Beater Speeds: 140 rpm / 285 rpm.

• Power Supply: 380 V (3 phase)

Code

C-050/A

Dimensions (± 1 cm) Approximate Weight (kg)

56 x 56 x 70 (h) 95

Automatic Cement/Mortar Mixer (C-050/A)

MIXING TIME

EN 196-1

Mixing Water & Cement

At low speed for 30 sec.

Mixing Water & Cement

At low speed for 90 sec.

Mixing Sand & Cement

At low speed for 30 sec.

Adding Sand

For 30 sec.

Mixing

At high Speed for 30 sec.

EN 196-3

Waiting

For 30 sec.

EN 196-9

Adding Water Manually

User should press “OK” after finishing

Mixing

Waiting for 90 sec

At low speed for 60 sec.

Mixing

At high speed for 60 sec.

Mixing

At high speed for 90 sec.

Mixing

At high speed for 60 sec.

www.alfatest.com.tr

103

LE CHATELIER FLASK (C-022)

▪ Used to determine the relative density (the specific gravity) for the hydraulic cement and the lime.

▪ The measurement is done by taking an empty flask, filling it with cement then adding polar liquid and measure the weight of the flask at each step and using it in the related formula.

▪ The flask neck comes graduated from 0 to 1 ml. and from 18 to 24 ml.

▪ The accuracy for the graduation on the neck is 0.05 ml.

TECHNICAL SPECIFICATIONS

• Graduation (0-1) & (18-24) ml. with 0.05 ml. accuracy.

Code

C-022

Dimensions (± 1 cm)

9 x 9 x 29 (h)

Approximate Weight (kg)

0.1

LE CHATELIER MOULD (C-023)

▪ Designed to have an internal diameter of 30 mm for the split cylinder and a height of 30 mm.

▪ The mould is equipped with two stems.

▪ Used to determine the soundness for cement in either hot or cold water.

TECHNICAL SPECIFICATIONS

• Split cylinder 30 mm internal diameter x 30 mm high with two indicator stems.

Code

C-023

Dimensions (± 1 cm)

104 www.alfatest.com.tr

18 x 3 x 3 (h)

Approximate Weight (kg)

0.02

Le Chatelier Flask (C-022)

Le Chatelier Mould (C-023)

LE CHATELIER BATH (G-040/06)

▪ Used with the Le Chatelier Moulds (to be ordered separately) to determine the soundness of the cement.

▪ Made from stainless steel interior, and equipped with a stainless steel cover and base shelf.

▪ Equipped with a digital thermostat and indicator.

Le Chatelier Bath (C-040/06)

SUPPLIED WITH

• Stainless Steel Cover

• Base Shelf

Code

C-040/06

Dimensions (± 1 cm)

35 x 20 x 31 (h)

Approximate Weight (kg)

6.5

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator.

• Interior stainless steel.

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available) www.alfatest.com.tr

105

AGGREGATE

106 www.alfatest.com.tr

INDEX AGGREGATE

Item

Sample Splitter

Universal Sample Splitter

Flakiness Sieve Set

Thickness / Flakiness Gauge

Length Gauge

Grid Sieve Set

Aggregate Shape Gauge

Sand Equivalent Shaker

Sand Equivalent Set

Organic Impurities Set

Methylene Blue Set

Los Angeles Abrasion Tester

Noise Reduction Cabinet for AG-191

Abrasive Charges for AG-191

Abrasion Tester for Concrete Tiles and Natural Stones

Dorry Abrasion Tester (Böhme)

Skid Resistance Tester

Sand Absorption Cone and Tamper

Micro-Deval Testing Machine

Aggregate Crushing Value

Aggregate Impact Value

G-080

Code

G-081

AG-030

AG-032

AG-034

AG-038

AG-036

AG-040/SS

AG-040

AG-240

AG-041

AG-191

AG-191/SPC

AG-191/AC

AG-197

AG-199

AG-190

AG-200

AG-195

AG-210

AG-220

119

120

121

122

122

113

114

115

117

119

123

124

125

Page

108

109

109

110

110

111

111

112 www.alfatest.com.tr

107

SAMPLE SPLITTER (G-080)

ASTM C136 • AASHTO T27 • EN 933-3 • EN 933-3

▪ The sample splitter equipment is designed to halve/divide aggregates, soils, sands and gravel into two representative halves.

▪ Made of powder coated enameled steel.

SUPPLIED WITH:

• Pans (2 ea)

Code

G-080/09

G-080/12

G-080/19

G-080/25

G-080/37

G-080/50

G-080/62

G-080/75

108 www.alfatest.com.tr

Chute Width (mm)

9.0

12.5

19.0

25.0

37.5

50.0

62.5

75.0

Sample Splitter (G-080)

Number of Chutes

12

8

8

8

12

10

10

8

UNIVERSAL SAMPLE SPLITTER (G-081)

▪ Used to halve/divide large amount of aggregates, soils, sands and gravel into two representative portions.

▪ The width of each chute bar is 1/2”.

▪ Equipped with lever and release hoppers.

▪ Made of heavy-duty steel.

▪ Supplied with two collecting pans

SUPPLIED WITH:

• Collecting Pans (2 ea)

TECHNICAL SPECIFICATIONS

• Chutes: Adjustable, Width: 1/2” each.

FLAKINESS SIEVE SET (AG-030)

▪ Used to determine whether the aggregate particle is flaky or not, that is to determine whether the thickness of the particle is less than 60% of its nominal size or not.

The sieve is made from robust stainless steel.

Code

G-081

Dimensions (± 1 cm) Approximate Weight (kg)

72 x 50 x 87 (h) 46

TECHNICAL SPECIFICATIONS

• Model of Steel

Code

AG-030

Dimensions (± 1 cm) Approximate Weight (kg)

26 x 45 x 7.5 (h) 2.4

▪ The sieve sizes for the set are:

▪ 4.90 mm x 30.00 mm

▪ 7.20 mm x 40.00 mm

▪ 10.20 mm x 50.00 mm

▪ 14.40 mm x 60.00 mm

▪ 19.70 mm x 80.00 mm

▪ 26.30 mm x 90.00 mm

▪ 33.90 mm x 100.00 mm www.alfatest.com.tr

109

THICKNESS / FLAKINESS GAUGE (AG-032)

▪ Used to determine whether the aggregate if flaky or not, that is to state whether its thickness is less than

60% of its nominal size.

▪ Made of a heavy-duty stainless steel.

TECHNICAL SPECIFICATIONS

• Used for determining the thickness

• Made of stainless steel

Code

AG-032

Dimensions (± 1 cm) Approximate Weight (kg)

38 x 16 0.8

LENGTH GAUGE (AG-034)

• Used to determine the amount of elongation occurred on the aggregate sample.

• Supplied with a wooden base.

TECHNICAL SPECIFICATIONS

• Used for determining the length

• Supplied with:

• Wooden Base

Thickness / Flakiness Gauge (AG-032)

Length Gauge (AG-034)

Code

AG-034

Dimensions (± 1 cm) Approximate Weight (kg)

40 x 8 x 2 (h) 0.3

110 www.alfatest.com.tr

GRID SIEVE SET (AG-038)

EN 993-3

• Used to determine the flakiness index for the aggregate particles and determine the particle shape.

• The sieve is made from robust frame with stainless steel bars.

• Consists of 14 sieves with openings as the following (mm):

• 50.00 - 40.00 - 31.50 - 25.00 - 20.00 - 16.00 - 12.50 - 10.00 -

8.00 - 6.30 - 5.00 - 4.00 - 3.15 - 2.50

Grid Sieve Set (AG-038)

TECHNICAL SPECIFICATIONS

• Metal frame

• Stainless steel parallel bars

• Set of 14 sieves (mm):

• 50.00 - 40.00 - 31.50 - 25.00 - 20.00 - 16.00 -

12.50 - 10.00 - 8.00 - 6.30 - 5.00 - 4.00 - 3.15

- 2.50

Code

AG-038

Dimensions (± 1 cm) Approximate Weight (kg)

39 x 35 x 8 (h) 3.5

AGGREGATE SHAPE GAUGE (AG-036)

EN 993-4 • DIN 4226

▪ Used to measure the ratio between the length to the thickness of any individual particle.

Aggregate Shape Gauge (AG-036)

TECHNICAL SPECIFICATIONS

• Made of steel

Code

AG-036

Dimensions (± 1 cm) Approximate Weight (kg)

40 x 15 0.5

www.alfatest.com.tr

111

SAND EQUIVALENT SHAKER (AG-040/SS)

▪ Provides a constant, uniform and precise shaking for the sand sample.

▪ The stroke of the shaker is 200 mm ± 10 mm. and the rate of shaking is 175 stroke per minute.

▪ Equipped with a digital stroke indicator.

TECHNICAL SPECIFICATIONS

• Stroke

• Rate

: 200 mm ± 10 mm

: 175 str/min

• Digital Stroke Indicator

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

AG-040/SS

Dimensions (± 1 cm)

45 x 35 x 45 (h)

Sand Equivalent Shaker (AG-040/SS)

SAND EQUIVALENT TEST SET (AG-040)

EN 933-8 • ASTM D2419 • AASHTO T-176

▪ The test is used to determine the relative portion of undesirable clay-like or plastic fines and dusts that occur in granular soils and fine aggregates passing the No. 4 sieve.

TECHNICAL SPECIFICATIONS

• Measuring Cylinder ( 4 ea )

• Rubber Stopper ( 2 ea )

• Measuring Can

• Plastic Bottle

• Irrigator Tube

• Syphon assembly jar

• Weighted Foot

• Funnel

• Ruler

• Stock Solution

• Case

• Sand Equivalent Shaker to be ordered separately

Sand Equivalent Test Set (AG-040) www.alfatest.com.tr

113

ORGANIC IMPURITIES SET (AG-240)

▪ Used to determine the impurities and their amount in the soil and the fine particles of aggregates.

▪ Equipped with organic color scale and organic impurities bottle.

TECHNICAL SPECIFICATIONS

• Set comprises:

• Organic Color Scale

• Organic Impurities Bottle

(AG-240/CS)

(AG-240/TB)

114 www.alfatest.com.tr

Organic Impurities Set (AG-240)

METHYLENE BLUE SET (AG-041)

EN 933-9

▪ Used to determine the amount of clay in the fine proportions of aggregates.

TECHNICAL SPECIFICATIONS

• 50 cc burette x stopcock

• Support base x clamp

• Glass Rod and filter discs

• 3000 ml plastic beaker

• Methylene blue 250 gr

• Kaolinite 1000 gr

• Mixer 400 - 700 rpm

• Impeller: 75 mm dia

• Power Supply: 220-240 v/50 Hz.

Methylene Blue Set (AG-041) www.alfatest.com.tr

115

116 www.alfatest.com.tr

LOS ANGELES ABRASION TESTER (AG-191)

EN 1097-2 • ASTM C131 • ASTM C535

▪ Used to measure the degradation of mineral aggregates of standard gradings resulting from a combination of actions including abrasion or attrition, impact, and grinding in a rotating steel drum containing a specified number of steel spheres.

▪ Consists of a hollow steel cylinder, with a wall thickness of 12 mm (1/2”) closed at both ends having an inside diameter of

711 mm (28”), and an inside length of 508 mm (20”).

▪ The drum rotates at 31 – 33 rpm.

▪ Supplied with an automatic digital counter that shows the number of revolutions for the drum.

www.alfatest.com.tr

117

LOS ANGELES ABRASION TESTER (AG-191)

EN 1097 - 2 • ASTM C131.

DRUM DIMENSIONS

A

B

C

D

G

H

(Drum Width)

Ø

(Drum Diameter)

1/4”

6 mm

1/2”

12 mm

1”

25 mm

3 1/2”

90 mm

7 1/2”

190 mm

20”

510 mm

28”

711 mm

SUPPLIED WITH

• Material catch pan

TECHNICAL SPECIFICATIONS

• Automatic digital counter

• The drum rotates at 31 - 33 rpm

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

AG-191

AG-191/SPC

Dimensions

44” x 35” x 40”

110 x 88 x 100 (h) cm

51” x 45” x 44”

128 x 113 x 110 (h) cm

118 www.alfatest.com.tr

Approximate Weight

830 lb

376 kg

305 lb

138 kg

NOISE REDUCTION CABINET (AG-191/SPC)

▪ The cabinet is to decrease the noise.

▪ AG-191/SPC should be ordered separately.

Noise Reduction Cabinet (AG-191/SPC)

ABRASIVE CHARGES (AG-191/AC)

▪ Abrasive charges are used with the Los Angeles Abrasion

Tester to measure the abrasive-resistance for the aggregate particles.

▪ Standards (ASTM or EN) should be specified at the time of order.

Abrasive Charges (AG-191/SS) www.alfatest.com.tr

119

ABRASION TESTER for NATURAL STONES and CONCRETE TILES (AG-197)

▪ Used to determine the abrasion-resistance of the natural stones and tiles.

▪ Equipped with abrasion disc of 70 mm thickness.

▪ Designed with “Automatic Revolution” selection feature for accurate and better results.

▪ Supplied with pack of white corundum.

Abrasion Tester for Natural Stones and Concrete Tiles (AG-197)

TECHNICAL SPECIFICATIONS

Code

• Testing machine for Natural Stones and Tiles

• Abrasion Disc is 70 mm thick

AG-197

• Automatic Revolution Selection

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Dimensions (± 1 cm)

90 x 60 x 130 (h)

120 www.alfatest.com.tr

DORRY ABRASION TESTER - BÖHME (AG-199)

▪ Used to determine the abrasion-resistance of the aggregate particles.

▪ Supplied with a horizontal abrasion disc with a diameter of 750 mm.

▪ Automatic revolution selection for better and accurate results.

▪ Equipped with sample holder, beam-loading device, and a pack of white corundum.

Dorry Abrasion Tester - Böhme (AG-199)

TECHNICAL SPECIFICATIONS

Code Dimensions (± 1 cm)

• Horizontal Abrasion Disc Ø 750 mm

• Automatic Revolution Selection

AG-199 174 x 102 x 114 (h)

• Sample holder - beam loading device & weight

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Approximate Weight (kg)

374 www.alfatest.com.tr

121

SKID RESISTANCE TESTER (AG-190)

ASTM E-103 • BS 812-144 • EN 1097

▪ Used to determine the surface friction of the curved aggregates, polished surfaces, concrete pavements and natural rocks.

▪ Suitable to measure the skid resistance for asphalt pavement.

▪ The mechanism is based on the energy loss from the rubber piece while sliding over the specimen. The amount of resistance is measured and transferred to a nearlyfriction-less pointer. This helps providing precise and accurate results.

▪ Supplied with 6 pieces of rubber sliders and a specimen holder.

SUPPLIED WITH

• 6 rubber sliders

• Specimen Holder

TECHNICAL SPECIFICATIONS

• Measuring Surface Friction

• Free fall of pendulum arm

• Rubber Sliders

Skid Resistance Tester (AG-190)

SAND ABSORPTION CONE & TAMPER (AG-200)

BS 812

• Made of a very rigid and strong steel.

• Used to determine the specific gravity for the required specimens.

TECHNICAL SPECIFICATIONS

• Made of Steel

Sand Absorption Cone And Tamper (AG-200)

Code

AG-200

Dimensions (± 1 cm) Approximate Weight (kg)

9 x 9 x 16 (h) 0.4

122 www.alfatest.com.tr

MICRO-DEVAL ABRASION TESTER (AG-195)

EN 1097-1

▪ Used to determine the abrasion-resistance of the aggregate particles.

▪ The machine is made of a rigid steel frame on which one of the following combinations can be mounted:

▪ 4 cylinders (Ø 200 mm x 154 mm)

▪ 2 cylinders (Ø 400 mm x 154 mm)

▪ 2 cylinders (Ø 200 mm x 154 mm) and 1 cylinder (Ø 400 mm x 154 mm)

▪ Transparent safe guard is fixed on the machine to increase the safely level and insure fault-less environment.

▪ Equipped with automatic digital counter.

▪ Supplied with:

▪ 2 cylinders (Ø 200 mm x 154 mm)

▪ Abrasive Charges - Ø 10 mm (20 kg)

TECHNICAL SPECIFICATIONS

• Rigid Steel Frame

• Stainless Steel Drums Ø 200 mm x 154 mm (2 ea)

• Safety Guard, Transparent

• Automatic Digital Counter

• Abrasive Charges - Ø 10 mm (20 kg)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

AG-195

Micro-Deval Testing Abrasion Tester (AG-195)

Dimensions (± 1 cm)

142 x 47 x 46 (h) www.alfatest.com.tr

123

AGGREGATE CRUSHING VALUE (AG-210)

BS 812-110

• Used to determine the crushing value for the aggregate particles.

• Contains the standard Aggregate Crushing Value pieces.

• The cylinder supplied with the set is made of a heavy-duty steel to resist the impacts during the test.

• Includes a plunger, tamping rod and a base plate.

Aggregate Crushing Value (AG-210)

TECHNICAL SPECIFICATIONS

AG-210/075

Used for aggregate passing 9.5 mm sieve

Steel Cylinder (Ø 75 mm)

Plunger

Tamping Rod (Ø 8 mm x 300 mm)

Measure (Ø 57 mm x 90 mm)

Base Plate

AG-210/150

Used for aggregate passing 12.7 mm and retaining on 9.5 mm sieve (Ten Percent Fines Value Test)

Steel Cylinder (Ø 150 mm)

Plunger

Tamping Rod (Ø 16 mm x 600 mm)

Measure (Ø 115 mm x 180 mm)

Base Plate

124 www.alfatest.com.tr

AGGREGATE IMPACT VALUE (AG-220)

BS 812

▪ Used to determine the aggregate particle resistance to impact.

▪ Contains the standard Aggregate Impact Value pieces.

▪ Supplied with automatic blow counter.

▪ Supplied with a sample cylinder, measuring cylinder and a tamping rod.

TECHNICAL SPECIFICATIONS

• Standard AIV set

• Measure of resistance to impact

• Automatic counter of Blows

• Sample cylinder

• Cylindrical measure

• Tamping Rod

Aggregate Impact Value (AG-220)

Code

AG-220

Dimensions (± 1 cm) Approximate Weight (kg)

22 x 44 x 82 (h) 42 www.alfatest.com.tr

125

SOIL

126 www.alfatest.com.tr

INDEX SOIL

Item

Motorized Liquid Limit Device - Casagrande Apparatus

Liquid Limit Device - Casagrande Apparatus

Cone Penetrometer

Plastic Limit Set

Shrinkage Limit Set

Pocket Penetrometer

Dial Penetrometer

Soil Penetrometer

Hand Vane Tester

Lightweight Dynamic Penetrometer

TRL Dynamic Penetrometer

Balloon Density Apparatus

Compaction Determination Apparatus

Sand Cone Set

Calibration Container for T-061

Standard Proctor Set

Modified Proctor Set

Automatic Soil Compactor

Moisture / Temperature Tester

Water Level Indicator

Universal Carbide Tester (Speedy Moisture Tester)

Nuclear Density / Moisture Gauge

Electrical Density Gauge

Laboratory CBR Tester - LCD

Field CBR Tester

Conversion Frame for Field CBR

Laboratory CBR Tester - Digital

CBR Equipment

Sample Extruder

Universal Extruder

Constant Head Permeability Set

Falling Head Permeability Set

Digital Plate Load Set

Oedometer - Consolidation

Uniaxial tester

Direct Shear Tester

Triaxial Tester

EZ-121

EDG

T-001/LCD

T-005

T-005/L

T-001/D

T-01x

T-020

T-025

T-250/CH

T-250/FH

T-063

T-210

T-201/D

T-220

T-5001/A

T-067

T-065

T-061

T-061/x/CC

T-050/S

T-050/M

T-055

T-462

T-470

T-068

Code

T-030/M

T-030

T-090

T-035

T-037

T-304

T-308

T-310

T-175

T-300/LW

T-300/TRL

149

150

151

151

152

143

145

147

148

148

152

153

154

155

156

159

138

139

140

140

141

135

135

136

136

138

132

133

133

134

134

Page

128

129

130

131

131

132 www.alfatest.com.tr

127

MOTORIZED LIQUID LIMIT DEVICE - CASAGRANDE APPARATUS (T-030/M)

ASTM D4318 • BS 1377 • AASHTO T89

▪ Equipped with a motor that perform the drop cycles automatically in a constant speed.

▪ Used to determine the moisture content at which soil pass from plastic to liquid state. This feature is very important in specifying the type of the soil, moreover, in determining the other parameters that relay on the soil type.

▪ Includes a cup that drops on a hard rubber base. It is also equipped with a drop counter.

▪ The grooving tool is supplied with the equipment

(Testing standard is to be specified at the time of order).

Motorized Liquid Limit Device (T-030/M)

SUPPLIED WITH

• Blow Counter

• Grooving Tool (T-030/GT)

TECHNICAL SPECIFICATIONS

• Motorized

• Comprising of:

• Hard rubber base

• Brass cup

Code

T-030/M

Dimensions (± 1 cm)

26 x 16 x 13 (h)

• Cam mechanism

• Blow counter

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Approximate Weight (kg)

3.1

128 www.alfatest.com.tr

LIQUID LIMIT DEVICE - CASAGRANDE APPARATUS (T-030)

ASTM D4318 • BS 1377 • AASHTO T89

▪ Used to determine the moisture content at which soil pass from plastic to liquid state. This feature is very important in specifying the type of the soil, moreover, in determining the other parameters that relay on the soil type.

▪ Includes a cup that drops on a hard rubber base. It is also equipped with a drop counter.

▪ The grooving tool is supplied with the equipment

(Testing standard is to be specified at the time of order).

Liquid Limit Device (T-030)

SUPPLIED WITH

• Blow Counter

• Grooving Tool (T-030/GT)

TECHNICAL SPECIFICATIONS

• Comprising of:

• Hard rubber base

• Brass cup

• Cam mechanism

• Blow counter

Code

T-030

Dimensions (± 1 cm)

22 x 15 x 13 (h)

Approximate Weight (kg)

2.5

ASTM Grooving Tool (T-030/GT/ASTM)

AASHTO Grooving Tool (T-030/GT/AASHTO) www.alfatest.com.tr

129

CONE PENETROMETER (T-090)

▪ Used to determine the moisture content while soil passing from plastic to liquid state by measuring the penetration of standard cone free falling into the soil under controlled conditions.

▪ Designed with auto-zeroing mechanism and a release button is equipped to the machine for easier using experience.

Digital Cone Penetrometer (T-090)

T-090 Hand-operated model with a digital indicator to be used with a stopwatch.

Semi-Automatic Digital Cone Penetrometer (T-090/SA)

T-090/SA Semi-Automated model with a digital indicator. It releases and stops the plunger automatically and shows the penetration measurements on a digital indicator.

SUPPLIED WITH

• Penetration Cone (T-090/PC)

• Length: 35 mm

• Angle: 30°

• Sample Cup (T-090/SC)

130 www.alfatest.com.tr

PLASTIC LIMIT SET (T-035)

ASTM D4318 • BS 1377-2 • AASHTO T-90

▪ Used to determine the plastic limit (lowest moisture content) at which a sample can be rolled into threads 3 mm diameter without breaking and/or cracking.

▪ Consists of a 300 x 300 mm glass plate, stainless steel rod, 6 pieces of moisture tins, mixing dish and a spatula.

SUPPLIED WITH

• Stainless steel rod (Ø 3 mm)

• Glass plate (30x30 cm)

• Moisture tin (6 ea)

(GL-38)

(GL-20)

• Mixing (GPP)

SHRINKAGE LIMIT SET (T-037)

ASTM D427 • AASHTO T-92

▪ Used to determine the maximum amount of moisture in the sample at which the soil will not shrink while drying.

▪ Consists of crystallizing dish, shrinkage prong plate, evaporating dish, spatula and a graduated cylinder.

SUPPLIED WITH

• Crystallizing Dish

• Shrinkage Prong Plate (w/ 3 Prongs)

• Graduated Cylinder - 25 ml (GCM/0025)

Plastic Limit Set (T-035)

Shrinkage Limit Set (T-037) www.alfatest.com.tr

131

POCKET PENETROMETER (T-304)

▪ Used to determine the classification of cohesive soil based on its consistency, shear strength and the approximate unconfined compressive strength.

▪ The range is (0 – 5) kgf/cm

2

▪ Equipped with a peak value indicator and supplied with a carrying case.

Pocket Penetrometer (T-304)

SUPPLIED WITH

• Case

TECHNICAL SPECIFICATIONS

• Range: 0-5 kgf / cm 2

• Peak Value Indicator

Code

T-304

Dimensions (± 1 cm)

Dia: 2 / h: 17

Approximate Weight (kg)

0.2

DIAL PENETROMETER (T-308)

▪ Used to determine the angle of friction, the cohesion index and the approximate unconfined compressive strength.

▪ Can be used on the foundation soil from clayey soil to sandy soil.

▪ The diameter of the dial is 60 mm, and equipped with a peak value holder.

▪ The Zero Setting for the equipment can be done by pushing the reset button.

▪ Consists of 5 different plungers to meet the required need, with diameters as follows:

▪ 6.35 - 10 - 15 - 20 - 25 mm diameter

TECHNICAL SPECIFICATIONS

• Dial Diameter : 60 mm

• Peak Value Holder

• Zero Setting by Push Button

• 5 Different Plungers:

• 6.35-10-15-20-25 mm diameter

132 www.alfatest.com.tr

Dial Penetrometer (T-308)

Code Dimensions (± 1 cm) Approximate Weight (kg)

T-308 7.0 x 14.5 x 3.5 (h) 0.2

SOIL PENETROMETER (T-310)

▪ Used to determine the relationship between the moisture content and penetration resistance of fine-grained soils.

▪ Consists of a special spring dynamometer with pressure indicating scale on the stem of the handle.

▪ The maximum pressure obtained by the test is indicated by the sliding ring on the steam.

SUPPLIED WITH

• Carrying Case

Soil Penetrometer (T-310)

HAND VANE TESTER (T-175)

ASTM D2573

▪ Used to determine the shear strength of the soil either in the laboratory or in the field (in-situ). It is very easy to use and gives the result directly in kPa.

TECHNICAL SPECIFICATIONS

• Can be used in the laboratory or in the field

Hand Vane Tester (T-175) www.alfatest.com.tr

133

LIGHTWEIGHT DYNAMIC PENETROMETER (T-300/LW)

▪ Used to determine the structural properties of the pavement, roads or any other existing construction areas with boundless materials.

SUPPLIED WITH

• Sounding rods - Ø 20 mm x 1 m (11 ea)

• Lifting device

• Grooved rod for sample extraction (1 ea)

• Hammer (10 kg) falling from 500 mm height

Dynamic Penetrometer (T-300/LW)

• Anvil

• Coupling

• Drive point 90° x 500 mm² (1 ea)

• Drive point 90° x 1000 mm² (1 ea)

TRL DYNAMIC PENETROMETER (T-300/TRL)

• Used to determine the structural strength of pavement layers in the field.

SUPPLIED WITH

• Hammer (8 kg) falling from 575 mm fixed height

• Driving rod (16 mm)

• Disposable cone tip (Ø 20 mm / 60°)

• Coupler assembly

• Carrying case

134 www.alfatest.com.tr

BALLOON DENSITY APPARATUS (T-067)

▪ Used to determine the inplace density and unit weight of compacted or firmly bonded soil.

▪ Suitable for use as a means of acceptance for compacted fill or embankments constructed of fine-grained soils or granular soils without appreciable amounts of rock or coarse material.

▪ Also may be used for the determination of the inplace density and unit weight of undisturbed or in situ soils, provided the soil will not deform under the pressures imposed during the test.

SUPPLIED WITH

• Rubber balloons

• Base plate

COMPACTION DETERMINATION APPARATUS (T-065)

▪ Used to determine the compaction percentage for the soil sample.

▪ Consists of a 12” diameter ring and supplied with complete accessories needed to perform the test.

Code

T-065

Dimensions (± 1 cm) Approximate Weight (kg)

41 x 31 x 25 (h) 8.0

Compaction Determination (T-065) www.alfatest.com.tr

135

SAND CONE SET (T-061)

ASTM D1556 • AASHTO T-191

▪ Used to determine the in-situ density of the fine grain compacted soil. The test consists of making a hole in the compacted soil layer, filling it with known-density soil sample from the container (plastic jar/ sand pouring cylinder), then measuring the soil weight along with the water content.

▪ Contains a sand cone and a base plate that has an opening designed for the cone to sit into. The set also contains a container (plastic jar/sand pouring cylinder) to be used during the test.

CALIBRATION CONTAINER (T-061/x/CC)

▪ Used for taking reference measurement for the Sand Replacement test.

136 www.alfatest.com.tr

SAND CONE SET (T-061)

ASTM D1556 • AASHTO T-191

Sand Density Cone Set - Ø 6.5”

(T-061/6)

Sand Cone - Ø 6.5”

(T-061/6/C)

Base Plate

(T-061/6/BP)

Plastic Jar

(T-061/6/PJ)

-

Sand Replacement Set - Ø 200 mm

(T-061/8)

Sand Cone - Ø 200 mm

(T-061/8/C)

Tray

(T-061/8/BP)

Sand Pouring Cylinder

(T-061/8/SPC)

Calibration Container

(T-061/8/CC)

Sand Density Cone Set - Ø 12”

(T-061/12)

Sand Cone - Ø 12”

(T-061/12/C)

Base Plate

(T-061/12/BP)

Sand Pouring Cylinder

(T-061/12/SPC)

www.alfatest.com.tr

137

STANDARD PROCTOR SET (T-050/S)

ASTM • BS • AASHTO

▪ Used to determine the relationship between the moisture content and the density for the compacted soil sample.

Specifying this relationship will help detecting the optimum moisture contact of the compacted soil sample along with its maximum dry density.

Item

Code

Diameter

Standard Proctor

Mould (ASTM)

Standard Proctor

Rammer (ASTM)

Standard Proctor

Mould (EN)

Standard Proctor

Rammer (EN)

Standard Proctor

Mould (BS)

Standard Proctor

Rammer (BS)

T-050/S-M/ASTM

4” (101.6 mm)

Height (Drop) 4.584” (116.4 mm)

Weight -

T-050/S-R/ASTM

2” (50.8 mm)

12” (304.8 mm)

5.5 lb (2.495 kg)

T-050/S-M/EN

100 mm

120 mm

-

T-050/S-R/EN

50 mm

305 mm

2.50 kg

T-050/S-M/BS

105 mm

115.5 mm

-

T-050/S-R/BS

50 mm

300 mm

2.50 kg

MODIFIED PROCTOR SET (T-050/M)

ASTM • BS • AASHTO

▪ Used to determine the relationship between the moisture content and the density for the compacted soil sample. Specifying this relationship will help detecting the optimum moisture contact of the compacted soil sample along with its maximum dry density.

Item

Code

Diameter

Modified Proctor

Mould (ASTM)

Modified Proctor

Rammer (ASTM)

T-050/M-M/ASTM

6” (152.4 mm)

Height (Drop) 4.584” (116.4 mm)

Weight -

138 www.alfatest.com.tr

T-050/M-R/ASTM

2” (50.8 mm)

18” (457.2 mm)

10 lb (4.5364 kg)

Modified Proctor

Mould (EN)

Modified Proctor

Rammer (EN)

T-050/M-M/EN

150 mm

T-050/M-R/EN

50 mm

120 mm

-

457 mm

4.50 kg

Modified Proctor

Mould (BS)

Modified Proctor

Rammer (BS)

T-050/M-M/BS

N/A

T-050/M-R/BS

50 mm

N/A

N/A

450 mm

4.50 kg

AUTOMATIC SOIL COMPACTOR (T-055)

ASTM • BS • AASHTO

• Used to determine the relationship between molding water content and dry unit weight of soil.

• Specifying this relationship will help detecting the optimum moisture contact of the compacted soil sample along with its maximum dry density.

• Can perform both standard and modified compactions on soil samples assuring uniform and precise practice.

• Safety transparent door eliminates risks and allows observation.

• Equipped with automatic digital counter which stops at the required number of blows.

• The compactor can be used to compact samples in both standard and modified proctor moulds.

Item

Diameter

Drop Height

Weight

Diameter

Drop Height

Weight

Automatic Proctor

(ASTM)

2” (50.8 mm)

12” (304.8 mm)

5.5 lb (2.495 kg)

Circular: 2” (50.8 mm)

Sector: 2.9” (73.7 mm)

18” (457.2 mm)

10 lb (4.5364 kg)

Automatic Proctor

(EN)

50 mm

305 mm

2.50 kg

50 mm

457 mm

4.50 kg

Automatic Soil Compactor (T-055) www.alfatest.com.tr

139

MOISTURE / TEMPERATURE TESTER (T-462)

▪ Used to determine the moisture percentage and the temperature of the soil samples and the fine aggregates with maximum particle diameter of 10 mm.

▪ It measures upto 1000 mm depth.

▪ The range of the moisture content that can be detected by the equipment is between 0% (Dry condition) to 35% with sensitivity of (0.5%).

▪ The temperature ranges between (-20°C) to (+60°C) with reading sensitivity of 0.5°C.

TECHNICAL SPECIFICATIONS

• Specially for Sand, Aggregate

• Depth: 1 m Depth

• Moisture: 0-35% (0.5 %)

• Temperature : -20 / +60 (0.5°C)

WATER LEVEL INDICATOR (T-470)

▪ Used for determining the level of water in boreholes, wells or any other ground opening.

▪ Pilot lamp is activated when the probe touches the surface of the water.

▪ Custom length can be manufactured upon request.

AVAILABLE MODELS

• Length: 50 m

• Length: 100 m

• Length: 200 m

(T-470/050)

(T-470/100)

(T-470/200)

140 www.alfatest.com.tr

Water Level Indicator (T-470)

UNIVERSAL CARBIDE TESTER (Speedy Mositure Tester) (T-068)

▪ Used to determine the moisture in the soil, sand and aggregate particles. The machine gives quick and accurate results. The tester is suitable for both lab and field work.

▪ The mechanism carried out by the machine is through measuring the gas emission from the reaction between water and calcium carbide.

▪ The tester is equipped with a portable electronic balance, steel balls and a carrying case.

SUPPLIED WITH

• Calibrated Pressure Bottle

• Moisture Meter

• Precise Digital Scale

• Spherical balls

• Sample Cups (2 ea)

• Hammer

• Chisel

• Sampling Spoon

• Sample Grinding Bowl

• Set of 25 ampoules of Calcium Carbide

• Digital Timer/Stopwatch

• Calibration set

• Cleaning Brush

• Carrying Case www.alfatest.com.tr

141

142 www.alfatest.com.tr

NUCLEAR DENSITY / MOISTURE GAUGE (EZ-121)

▪ Used to determine density and the moisture content of the sample in a very short period with very accurate results.

▪ The testing time can be chosen from the control panel as 15 seconds, 1 minute and 4 minutes.

▪ The depth range that can be measured by this equipment is 12” (30 cm), with 1” measurement increment.

▪ Supplied with all the necessary accessories to perform the test.

TECHNICAL SPECIFICATIONS

• Used for rapid fiend tests.

• Test time: 15 sec / 1 min / 4 min

• Depth Range up to 12” (30 cm)

• Increment: 1” (2.5 cm)

• With Accessories

Nuclear Density / Moisture Gauge (EZ-121)

Code

EZ-121

Dimensions (± 1 cm)

Gauge : 40 x 22 x 14 (h)

Reference Standard : 35 x 20 x 8 (h)

Transit Case

Accessory Case

: 79 x 36 x 50 (h)

: 50 x 25 x 13 (h)

Approximate Weight (kg)

41 www.alfatest.com.tr

143

144 www.alfatest.com.tr

ELECTRICAL DENSITY GAUGE (EDG)

ASTM D7698

▪ The Electrical Density Gauge (EDG) is a nuclear-free alternative for determining the moisture and density of compacted soils used in road beds and foundations.

▪ The EDG is a portable, battery-powered instrument capable of being used anywhere without the concerns and regulations associated with nuclear safety.

▪ Its user-friendly, step-by-step menu guides the user through each step of the testing procedure and cautions the user when values do not correspond to established curves for the material being tested.

▪ Easy-to-use, the EDG can be used as a construction aid to monitor day-to-day compaction operations by providing performance and measurement results highly comparable to those achieved with traditional methods, including the nuclear gauge and/or a sand-cone and oven moisture test combination.

▪ When conducting a test, the EDG measures and displays the results for wet and dry density, gravimetric moisture content and percent compaction.

TECHNICAL SPECIFICATIONS

• Portable, battery powered.

• Step-by-step menu guide throughout the test.

• Power: Li-ion Battery

Code

EDG

Dimensions (± 1 cm)

53 x 43 x 20 (h)

Electrical Density Gauge (EDG)

Approximate Weight (kg)

7 www.alfatest.com.tr

145

146 www.alfatest.com.tr

LABORATORY CBR TESTER - LCD (T-001/LCD)

ASTM 1883 • BS 1377:4 • EN 13286:47

▪ The California Bearing Ratio (CBR) is a penetration test carried out to evaluate the mechanical strength of road subgrades and base-coarse layers.

▪ Equipped with an LCD Data Acquisition System to view/perform the test and show the CBR index automatically upon finishing the test.

▪ Has a capacity of 50 kN and automatically performs the test, with an automatic stop after finishing the test and returning to initial position.

▪ The LCD screen shows the Loading versus Penetration in a real time graph during the test.

▪ Equipped with output port to RS 232 or normal printer.

▪ Equipped with a memory that has the ability to save 1000 test results. Old test results can be recalled and observed on the LCD monitor.

SUPPLIED WITH

• Load cell: 50 kN cap

• Penetration Piston

TECHNICAL SPECIFICATIONS

• Capacity: 50 kN

• Graphical LCD Data Acquisition system

• Two loading rate: (1 mm/min) and (1.27 mm/min)

• Automatic stop when test complete

• Loading vs. Penetration is shown graphically

• CBR index is given automatically

• RS 232 or output to printer is available

• 1000 test data can be stored

• Old tests can be recalled

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

T-001/LCD

Laboratory CBR Tester (T-001/LCD)

Dimensions (± 1 cm) Approximate Weight (kg)

42 x 75 x 100 (h) 110 www.alfatest.com.tr

147

FIELD CBR TESTER (T-005)

ASTM 1883 • BS 1377:7 • AASHTO T-193

▪ The California Bearing Ratio (CBR) is a penetration test carried out to evaluate the mechanical strength of road subgrades and basecoarse layers.

▪ Designed with a capacity of 50 kN and suitable for field works.

▪ Equipped with a mechanical jack (2-speed), and a load ring.

▪ Includes a penetration piston specially designed for CBR Apparatus, penetration dial (2 pieces), dial holder, extension rods and a surcharge weight.

TECHNICAL SPECIFICATIONS

• Capacity : 50 kN

• Mechanical Jack - 2 Speed

• Load Ring

• Set Includes:

• CBR Penetration Piston

• Penetration Dial (2ea)

• Dial Holder

• Extension Rods

• Surcharge Weight

CONVERSION FRAME FOR FIELD CBR TESTER (T-005/LF)

ASTM 1883 • BS 1377:4 • EN 13286:47

Field CBR Tester (T-005)

▪ This frame cannot be used alone, the frame is used to convert the field CBR (T-005) in order to use it in the laboratory.

Field CBR (T-005) with Conversion Frame (T-005/LF)

148 www.alfatest.com.tr

LABORATORY CBR TESTER - DIGITAL (T-001/D)

ASTM 1883 • BS 1377:4 • EN 13286:47

▪ The California Bearing Ratio (CBR) is a penetration test for evaluation of the mechanical strength of road subgrades and base-courses.

▪ Has a capacity of (50 kN) and the machine is suitable to be used in laboratories.

▪ Equipped with a digital load indicator.

▪ Supplied with a CBR penetration piston and a penetration dial.

TECHNICAL SPECIFICATIONS

• Lab Type - Digital

• Capacity : 50 kN

• Load Indicator : Digital Load Cell

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

SUPPLIED WITH

• Penetration Piston

• Dial Indicator for Penetration (25 mm / 0.01 mm)

Laboratory CBR Tester - Digital (T-001/D)

Code

Dimensions (±

1 cm)

T-001/D 42 x 70 x 100 (h)

Approximate

Weight (kg)

110 www.alfatest.com.tr

149

CBR EQUIPMENT (T-01x)

T-013

T-010

T-016

T-015

T-014

T-017

TECHNICAL SPECIFICATIONS

Code

T-010

T-011

T-012

T-013

T-014

T-014

T-015

T-016

T-017

T-018

T-019

Item

CBR Mould

Solid Base Plate

Perforated Base Plate

Spacer Disc with T-Handle

Slotted Surcharge Weight

Split Surcharge Weight

Annular Surcharge Weight

Swell Plate with Stem

Tripod

Dial Indicator

Soaking Tank

150 www.alfatest.com.tr

ASTM

(T-01x/ASTM)

Ø 6” x 7”

Solid

Perforated

Ø 5 15/16” x 2.416”

5 lb (2270 g)

N/A

5 lb (2270 g)

Steel

Cast Iron

10 / 0.01 mm

Plastic

BS

(T-01x/BS)

Ø 152 mm x 127 mm

Solid

Perforated

Ø 150 mm x 50 mm

N/A

2000 g

2000 g

Steel

Cast Iron

25 / 0.01 mm

Plastic

EN

(T-01x/EN)

Ø 150 mm x 120 mm

Solid

Perforated

Ø 149.5 mm x 36 mm

N/A

2000 g

2000 g

Steel

Cast Iron

10 / 0.01 mm

Plastic

SAMPLE EXTRUDER (T-020)

▪ Used to extract the sample from its mould. It can be used with proctor test moulds, CBR test moulds, Marshall test moulds and other moulds having the diameter 100 mm/4” to 150 mm / 6”.

▪ The machine is actuated using a manual hydraulic jack.

Sample Extruder (T-020)

TECHNICAL SPECIFICATIONS

• Manual-Hydraulic Type

• Used for 100 mm /4” to 150 mm / 6” diameter samples

• Can be used with Proctor, CBR, Marshall moulds

Code

T-020

Dimensions (± 1 cm) Approximate Weight (kg)

Dia: 30 / h: 60 35

UNIVERSAL EXTRUDER (T-025)

▪ Used to extract the sample out of Shelby moulds, proctor moulds and CBR moulds.

▪ Controlled by a hydraulic jack having 400 mm stroke.

▪ Supplied with all the needed adaptors to meet the need of the user, to be specified at the time of inquiry.

TECHNICAL SPECIFICATIONS

• Used for:

• Shelby, proctor moulds, CBR mould

• Piston stroke 400 mm

• Supplied with adaptors

Universal Extruder (T-025)

Universal Extruder (T-025) www.alfatest.com.tr

151

CONSTANT HEAD PERMEABILITY SET (T-250/CH)

▪ Used to determine the permeability of granular-grained soils

▪ Consists of:

▪ Permeameter stand

▪ Constant-head permeability cell

▪ Manometer tubes/valves

▪ Constant-head tank

TECHNICAL SPECIFICATIONS

• Permeameter Stand with 3 tubes

• Constant-head permeability cell - Ø 75 mm (1 ea)

FALLING HEAD PERMEABILITY SET (T-250/FH)

▪ Used to determine the permeability of fine-grained soils

▪ Consists of:

▪ Permeameter stand

▪ Constant-head permeability cell

▪ Manometer tubes/valves

▪ Constant-head tank

TECHNICAL SPECIFICATIONS

• Permeameter Stand with 3 tubes

• Constant-head permeability cell - Ø 114 mm (1 ea)

152 www.alfatest.com.tr

DIGITAL PLATE LOAD SET (T-063/D)

ASTM D1194 • ASTM D1195 • BS 1377:9

▪ Used to determine the bearing capacity of soil layers in road constructions, foundations, highways, airport and subgrades and sub-layers of soil.

▪ Includes a hydraulic loading device, digital indicator, a manual pump, datum bar, dial holder and two dials each with sensitivity of 0.01 mm.

▪ Also includes two pieces of circular plates, having diameters of 300 mm and 450 mm.

Digital Plate Load Set (T-063/D)

TECHNICAL SPECIFICATIONS

• Hydraulic loading

• Capacity : 100 kN

• Equipped with digital manometer

SUPPLIED WITH

• Ø 300 mm bearing plate

• Ø 450 mm bearing plate

• Datum bar

• Dial holder

• Dial 50 / 0.01 mm

(3 ea)

(3 ea) www.alfatest.com.tr

153

OEDOMETER - CONSOLIDATION (T-210)

ASTM D2435 • BS 1377-6

▪ Used to determine the behavior of the soil sample upon certain loading in a specified period of time. It indicates the settlement characteristics of the soil which is known as

Consolidation.

▪ The loading ratio for the device is 10:1 and designed as front loading type. The rear weight is used for balancing the device.

▪ The device has a support for a screw jack and supplied with a dial and its holder, consolidation cell, two porous discs and weight set.

▪ Fixed on a frame and can be ordered as 1, 2 or 3 devices on the same frame.

SUPPLIED WITH

• Dial Indicator : 12.7 / 0.002 mm

• Dial Holder

• Consolidation Cell

• Porous Discs (2 ea)

• Weight Set (4 x 10 kg, 1 x 5 kg, 1 x 2 kg, 2 x 1 kg,

1 x 0.5 kg, 2 x 0.25 kg)

TECHNICAL SPECIFICATIONS

Code

T-210/1

T-210/2

T-210/3

Dimensions (± 1 cm)

50 x 80 x 135 (h)

90 x 80 x 135 (h)

130 x 80 x 135 (h)

Approximate Weight (kg)

84

163

242

• Front Loading Type

• Load Ratio = 10:1

• Rear Balancing Weight

• Screw Jack Support

• Oedometers can be ordered as one (T-063/1), two (T-063/2) or three (T-063/3) devices on the same frame.

154 www.alfatest.com.tr

UNIAXIAL TESTER (T-201/D)

▪ The test is also known as “Unconfined Compression Strength

Test (UCS)”.

▪ Used to determine the material behavior and characteristics under axial loading up to failure point. It can also determines the local deformation of the soil sample upon loading.

▪ Has a capacity of 50 kN and equipped with a load cell and digital indicator.

▪ The digital indicator has a “Peak Hold” function that shows the maximum load.

TECHNICAL SPECIFICATIONS

• Capacity : 50 kN

• Load Cell & Digital Indicator

• “Peak Hold” function for max. Load

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

T-201/D

Code Dimensions (± 1 cm)

50 x 90 x 115 (h)

Uniaxial Tester (T-201/D)

Approximate Weight (kg)

120 www.alfatest.com.tr

155

DIRECT SHEAR TESTER (T-220)

ASTM D3080 • BS 1377-7

▪ Used to determine the resistance of soil against shear forces applied on it.

▪ The device is equipped with a KIOSK type touch screen, load cell with a capacity of 5 kN.

▪ The loading speed varies from 9 – 0.00001 mm/min.

▪ Supplied with vertical and horizontal dials, beam loading device, shear box (either 60 mm diameter or 60x60 mm square box) and weight set.

156 www.alfatest.com.tr

DIRECT SHEAR TESTER (T-220)

ASTM D3080 • BS 1377-7

SUPPLIED WITH

• Software

• Electronic Deformation Sensor (Vertical and Horizontal)

• Beam Loading Arm

• Shear Box 60 mm dia. or 60 mm square (To be specified at the time of order)

• Weight Set (4 x 10 kg, 1 x 5 kg, 1 x 2 kg, 2 x 1 kg, 1 x 0.5 kg, 2 x 0.25 kg)

TECHNICAL SPECIFICATIONS

• LCD Graphical System

• Shear force measurement by Load Cell

• Maximum Shear Force: 5000 N

• Maximum Vertical Load: 500 N / 5000 N (using 10:1 loading arm)

• Speed Range: 0.00001 - 5.00000 mm/min

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available) www.alfatest.com.tr

157

158 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

▪ Used to perform large range of Triaxial tests on soil samples to determine the strength parameters and the mechanical properties.

▪ Capable of performing:

▪ Standard Triaxial Tests:

▪ UU Test (Unconsolidated Undrained Test)

▪ CU Test (Isotropically Consolidated Undrained Test)

▪ CD Test (Isotropically Consolidated Drained Test)

▪ Wide range of advanced Triaxial tests (ie, K

0

consolidation, custom stress paths, extension tests … etc)

▪ Capacity:

▪ Frame

▪ Load Cell

▪ Cell

▪ Pressure Transducer

▪ Water Tank

▪ Ram travel

: 200 kN (20 tons)

: 20 kN (2 tons)

: 2000 kPa

: 25 bar

: > 30 lt

: 50 mm

▪ Sample Dimensions

▪ Triaxial Tests : 35 – 70 mm

▪ Flexible Wall Permeability : 35 – 90 mm

▪ The load cell is installed inside the cell to eliminate the piston friction calculations from the test and provide very precise measurements, which is directly applied on the sample. The water-proof load cell is made completely of stainless steel.

www.alfatest.com.tr

159

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

▪ The load is applied by servo-motor, which allows sensitive control on loading speed ranging from 0.00001 – 9.99999 mm/ min.

▪ The cell is made of high-strength plexiglass specially designed for this particular device with thickness of 10 mm.

▪ Equipped with 2 PVAs (Pressure-Volume Actuator) which controls and measures both pressure change volume change in the cell and the sample. The PVA is completely controlled from computer with the supplied software.

▪ The pressure is measured using very precise pressure transducer that sends the data to the equipped acquisition system.

▪ The acquisition system gathers the data from all the sensors (load cell, pressure transducers, electronic position indicators

… etc), analyses it and sends it to the computer via USB.

▪ The water tank is fitted with a magnetic stirrer to de-air the water before pumping it into the system. Adding this feature significantly reduces the time required to saturate the sample and provide air-free water during the test to the whole system.

▪ The LCD indicator at the front of the system shows the readings from all the sensors and the position of the PVA pistons with the amount of water left in each one simultaneously.

▪ The tests are all performed from computer with the help of ALFA’s state-of-the-art Triaxial Control software (refer to appendix

A for more details).

▪ The device is supplied with all the required accessories to perform Triaxial Tests, Uniaxial UCS Tests, Permeability Tests, and all the tools for proper sample preparation.

SUPPLIED WITH

160 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE

▪ The software provides full control on ALFA’s Triaxial Tester (T-5001/A). It consists of different tabs with selfexplanatory notes and guides taken from the international standards and based on the findings of reliable researchers and universities in the world.

▪ Each tab guides the user to what should be done in very simple step-by-step progress. The top part of the software is constant that provides quick access to some important control functions on the software and the machine like proceeding to next stage, changing the data recording method for the report, emergency stop for the machine … etc.

www.alfatest.com.tr

161

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE

File Menu

• Start New Test

• Continue Old Test

• Save

• Save As

• Reporting

• Data Export

• Exit

Tools Menu

• Preferences

• Calibration

• LCD Monitor

Used to start new test from beginning

Used to continue an old test and merge the data of sets together for comparison

Saves the current test

Saves the current test to different file

Adjust the report settings and what to include in it

Export the data to third-party applications like Excel

Closes the software

Adjust test preferences like units, connections … etc

Perform / check the sensors’ calibration

Turn ON and OFF the LCD monitor

Help Menu

• Check for Updates

• User Manual

• About

Check if there is any update available for the software

(requires internet connection)

Views the user manual

Gives information about the software and its version

162 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Preliminary Information Tab

Sample Owner Information:

▪ To be filled with the sample owner’s information. These information are used in the final report.

Testing Laboratory Information:

▪ To be filled with the testing laboratory or institute’s information. These information are used in the final report.

Specimen Properties:

▪ Specimen number, depth, coefficient of consolidation, water table, soil type, diameter, height, area correction method … etc are all selected and specified from this section. These information are crucial and to be used in further calculations and to decide the behavior of the equipment based on the sample properties.

Vertical Strips:

▪ Specifying whether the vertical strips are used or not, with its properties.

Membrane Properties:

▪ Specify the correction method for the membrane and specify is properties.

www.alfatest.com.tr

163

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Test Type Tab

Test Type Selection:

▪ Select whether to have simplified menu (for standard tests) or advanced menu (for custom tests).

Perform Standard Test:

▪ Choose the test type from simplified selections.

Perform Advanced Test:

▪ Choose the test from stage-by-stage selection. This option gives the ability to perform any custom test on the sample from very wide range of functions based on international standards and findings of reliable researchers and institutes.

Test Stages:

▪ Select between single-stage or multi-stage tests. This option gives the ability to obtain 3 mohr circles and determine the strength parameters from a single Triaxial soil sample.

Selected Test:

▪ Displays the chosen test type.

164 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Initialization Tab

Proper Flushing Instructions:

▪ Some instructions to perform proper flushing for the setup to avoid having air bubbles left over.

Initial Readings / Positions:

▪ Shows and controls the initial positions of each piston/motor to avoid over-travelling or running out of water during the test.

Vacuum Application:

▪ Gives the ability to include the vacuum calculations to the software if applied (used for sand samples).

Stage Automation Control:

▪ Gives the option to select which stage to start automatically.

www.alfatest.com.tr

165

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Consolidation Tab

Consolidation Method:

▪ Gives the ability to select which method to follow in order to consolidate the sample.

Target Pressures:

▪ Gives the option to target 3 consolidation pressures in multi-stage mode to obtain the strength parameters from single sample.

Specimen Response:

▪ Shows the consolidation value and the K0 value.

Graphs:

▪ Axial Strain vs σ1

▪ σ3 vs σ1

▪ Volumetric strain vs time (for t50 and t100 calculations)

166 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Shear Tab

Shear Parameters:

▪ Displays the target pressure for each stage and gives the ability to draw any custom path for the sample. The strain rate is also specified in this section.

Stage Limits:

▪ Gives the option to end the test with any desired limitations..

Graphs:

▪ Mohr Circle graphs and calculations

▪ q vs p

▪ q vs p’

▪ Deviator stress vs mean stress

▪ Pore pressure vs deviator stress www.alfatest.com.tr

167

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Flow/Permeability Tab

Flow Parameters:

▪ Displays the target pressure for each stage and gives the ability to draw any custom path for the sample. The strain rate is also specified in this section.

Graphs:

▪ Flow vs time

▪ Flux vs hydraulic gradient

168 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Results & Graphs Tab

Readings and Calculations:

▪ Shows the readings from all the sensors and the calculated values for each parameter simultaneously.

Graphs:

▪ B-Value vs Pore Water Pressure (kPa)

▪ a-Value vs Time (hours)

▪ Volume Change vs Log Time (sec)

▪ Volume Change vs Root Time (sec)

▪ Axial Strain vs Log Time (sec)

▪ Axial Strain vs Root Time (sec)

▪ Deviator Stress (kPa) vs Axial Strain

▪ Axial Stress (kPa) vs Axial Strain

▪ Volumetric Strain vs Axial Strain

▪ Shear (kPa) vs Total Normal Stress (kPa) (Mohr Circle)

▪ Shear (kPa) vs Effective Normal Stress (kPa) (Mohr Circle)

▪ q (kPa) vs p (kPa) (Top of Mohr Circle)

▪ q (kPa) vs p’ (kPa) (Top of Mohr Circle)

▪ Deviator Stress (kPa) vs Mean Stress (kPa)

▪ Deviator Stress (kPa) vs Effective Mean Stress (kPa)

▪ Pore Pressure (kPa) vs Deviator Stress (kPa) www.alfatest.com.tr

169

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Mohr Circle Tab

Mohr Circle

▪ The software allows the user to combine and compare tests from different samples together in one single report, draw the corresponding mohr circles and calculate the related soil characteristics.

170 www.alfatest.com.tr

FULLY AUTOMATIC TRIAXIAL TESTER (T-5001/A)

ASTM D2850 • D4767 • D7181

TRIAXIAL SOFTWARE : Manual Control Tab

▪ Provides manual control on each motor/PVA.

Ending Test Tab:

▪ Gives instructions on how to end the test properly and empty the cell from water … etc.

www.alfatest.com.tr

171

ASPHALT/BITUMEN

172 www.alfatest.com.tr

INDEX ASPHALT / BITUMEN

Item

Marshall Stability Tester – LCD

Marshall Stability Tester – Digital

Marshall Mould

Automatic Marshall Compactor

Hi-Low Detector – Travelling Beam

Sample Extruder

Bitumen Penetrometer

Marshall Water Bath

Bitumen Content Oven – Ignition Method

Rolling Thin Film Oven

Asphalt Oven with Rotating Shelves

Coring Machine – Trailer Mounted

Core Bit

Coring Machine – Portable

Flash Point Apparatus

Ring and Ball Softening Point Apparatus

Reflux Extractor

Centrifuge Extractor

Filter Paper

Asphalt Heater

Marshall Mixer

Nuclear Density / Moisture Gauge

Saybolt Viscometer

Kinematic Viscometer

Ductility Tester

Ductility Mould

Emulsion Distillation Unit

Particle Charge Tester

Vacuum Pycnometer

Code

A-001/LCD

A-001/D

A-010

A-015

A-069

A-020

A-090

G-040

A-030/IGN

A-030/RTFO

A-030/TFO

A-065

A-065/x

A-066

A-470

A-472

A-035

A-031

FP

A-050/H

A-050

EZ-121

A-430

A-435

A-440

A-440/M

A-450

A-460

A-490

185

186

186

187

187

181

182

183

184

184

Page

175

176

176

177

178

178

179

180

192

193

193

194

194

195

188

188

189

191

192 www.alfatest.com.tr

173

174 www.alfatest.com.tr

MARSHALL STABILITY TESTER (A-001/LCD)

ASTM D1559 • EN 12697-34 • AASHTO T-245

▪ Used to determine the stability of the bituminous mix materials and capability of resistance against plastic deformation and flow value of the materials.

▪ Equipped with an LCD Data Acquisition System control the test and display the results in a very easy and simple way and, a memory to store up to 1000 test results to recall them in the future.

▪ Has a capacity of 50 kN and a loading rate of 2”/minute (50.8 mm/ min).

▪ Fully automatic and to stop the test by itself when finishes and return to its initial position.

▪ Equipped with RS 232 port for computer connection and thermal printer

(which should be ordered separately) to report the results quickly and directly from the machine.

▪ Supplied with load cell that has a capacity of 50 kN and flow-meter.

SUPPLIED WITH

• Load cell: 50 kN capacity

• Breaking Head

• Software

TECHNICAL SPECIFICATIONS

• Capacity : 50 kN

• High Precision Load Cell

• Electronic Measure of Flow

• Peak Hold of load and Flow

Code Dimensions (± 1 cm)

A-001/LCD 45 x 60 x 110 (h)

• Equipped with LCD Indicator

• Load Rate: 50.8 mm/min (2”/ min)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Marshall Stability Tester (A-001/LCD)

Approximate Weight (kg)

90 www.alfatest.com.tr

175

MARSHALL STABILITY TESTER - DIGITAL (A-001/D)

ASTM D1559 • EN 12697-34 • AASHTO T-245

▪ Used to determine the stability of the bituminous mix materials and capability of resistance against plastic deformation and flow value of the materials.

▪ Has a capacity of 50 kN and equipped with a digital indicator that shows the load. The digital indicator displays the maximum load during the test via Peak Hold function.

▪ Supplied with a digital indicator and a stability mould.

TECHNICAL SPECIFICATIONS

• Capacity: 50 kN

• High Precision Load Cell

• Electronic Measure of Flow

Marshall Stability Tester - Digital (A-001/D)

• Peak Hold of load and Flow

• Stability Mould

Code

A-001/D

Dimensions (± 1 cm)

• Complete with Digital Indicator

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

42 x 55 x 90 (h)

Approximate Weight (kg)

88.5

MARSHALL MOULD (A-010)

▪ The sample, moulded in this equipment, can be used in Marshall

Stability Tester.

▪ The Ø 4” mould is made of a heavy-duty steel and protected against corrosion.

▪ The mould is supplied with base plate and collar.

TECHNICAL SPECIFICATIONS

• Mould (Ø 4”)

• Base Plate

• Collar

176 www.alfatest.com.tr

Marshall Mould (A-010)

Code

A-010

Dimensions (± 1 cm)

Dia: 12.5 / h: 15.5

Approximate Weight (kg)

3.8

AUTOMATIC MARSHALL COMPACTOR (A-015)

ASTM D6926 • AASHTO T 245 • EN 12697

▪ Used to determine the resistance of the asphalt sample to plastic flow. The test is performed in a fully automatic mechanism and programmed to stop automatically at the required number of blows.

▪ Supplied with the standard height and rammer weight according to ASTM/EN standards.

▪ Equipped with a blow counter, wooden pedestal and quick action clamping.

TECHNICAL SPECIFICATIONS (EN)

• Equipped with safety guard

• Blow Rate: 60 ± 5 blows per minute

• Rammer Weight: 4535 g ± 10 g

• Drop Height: 457 ± 5 mm

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

ASTM Model (A-015/ASTM)

TECHNICAL SPECIFICATIONS (ASTM)

• Blow Rate: 55 ± 5 blows per minute

• Rammer Diameter: 100.33 mm ± 0.25 mm (3.955” ± 0.005”)

• Rammer Weight: 4536 g ± 9 g (10 lb ± 0.02 lb)

• Drop Height: 457.205 mm ± 0.635 mm (18” ± 0.025”)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

EN Model (A-015/EN) www.alfatest.com.tr

177

HI-LOW DETECTOR - TRAVELLING BEAM (A-069)

▪ Used for checking planeness/irregularities in concrete and bituminous road surfaces.

▪ The travelling beam is 3 meters long.

▪ Deviation of the surface is shown on a scale;

▪ in increments of 2 mm from 0 - 10 mm

▪ in increments of 5 mm from 10 - 25 mm

TECHNICAL SPECIFICATIONS

• Length : 3 m

• Equipped with scale (up to 25 mm)

SAMPLE EXTRUDER (A-020)

▪ Used to extract the sample from its mould. It can be used with proctor test moulds, CBR test moulds, Marshall test moulds and other moulds having the diameter 100 mm to 6”.

▪ The machine is actuated using a manual hydraulic mechanism.

TECHNICAL SPECIFICATIONS

• Manual-Hydraulic Type

• Used for 100 mm to 6” diameter samples

• Can be used with the moulds of Proctor, CBR,

Marshall Tests

178 www.alfatest.com.tr

Sample Extruder (A-020)

Code

A-020

Dimensions (± 1 cm) Approximate Weight (kg)

Dia: 30 / h: 60 35

BITUMEN PENETROMETER (A-090)

▪ Used to determine the moisture content while soil passing from plastic to liquid state by measuring the penetration of standard cone free falling into the soil under controlled conditions.

▪ Designed with auto-zeroing mechanism and a release button is equipped to the machine for easier using experience.

Digital Penetrometer (A-090)

A-090 Hand-operated model with a digital indicator to be used with a stopwatch.

Semi-Automatic Digital Penetrometer (A-090/SA)

A-090/SA Semi-Automated model with a digital indicator. It releases and stops the plunger automatically and shows the penetration measurements on a digital indicator.

SUPPLIED WITH

• Sample Cup (Ø 55 mm x 35 mm)

• Transfer Dish (Ø 127 mm x 23 mm)

(A-090/SC)

(A-090/TD) www.alfatest.com.tr

179

MARSHALL WATER BATH (G-040)

EN 12697:34 • ASTM D1559 • ASTM D5581 • AASHTO T245

▪ Used to cure specimens at constant temperature.

▪ Exterior is made of powder coated steel and the interior tank and the cover are corrosion-resistant stainless steel.

▪ Supplied with perforated stainless steel shelf which stands at the bottom of the tank to ensure uniform temperature.

▪ Equipped with digital thermoregulator with range of ambient to 82°C (180°F) and pilot light heat indicator.

▪ The tank is insulated from the outer cabinet with thick mineral wool to reduce thermal loss and to help maintain contstant temperature.

▪ Available in 2 different capacities and with/without water circulation options.

Water Bath (G-040/30)

SUPPLIED WITH

• Digital Thermostat & Indicator

• Stainless Steel Cover

• Base Shelf

• Pilot Lamp

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator

• Interior Stainless Steel

• Water circulation is optional (to be specified at the time of order)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Water Bath (G-040/60)

Code

G-040/30

G-040/60

External Dimensions (± 1 cm) Internal Dimensions (± 1 cm)

12” x 20” x 8”

305 x 508 x 203 mm

20” x 24-½” x 8”

508 x 622 x 203 mm

13-¾” x 21-½” x 15”

350 x 550 x 380 mm

21-½” x 31-½” x 15”

550 x 800 x 380 mm

180 www.alfatest.com.tr

Volume

7.93 gallons

30 liters

15.85 gallons

60 liters

Approximate Weight (kg)

15

30

BITUMEN CONTENT OVEN – IGNITION METHOD (A-030/IGN)

▪ Used to determine the bitumen/binder content in the asphalt and hotmix samples.

▪ “After Burner” unit is installed at the top of the oven to reduce the gas emission during the test.

▪ The maximum temperature for the oven chamber is 600°C.

▪ The maximum temperature for the After-Burner unit is 950°C.

▪ The bottom of the innerchamber is made of insulating bricks with high strength against abrasion and impacts. The sides of the inner chamber with the ceiling lid are made of fiber board to provide better thermal insulation.

▪ The outer case is made of galvanized steel.

▪ The 7” True-Flat-Touch control panel is very user friendly and programmed to display the results graphically and in real-time during the test.

▪ Equipped with a sample plate and holder made of Nichrome.

▪ Weighing system (Capacity: 4 kg / Readability: 0.1 kg) is integrated in the oven.

▪ The oven is equipped with a thermal printer for faster/easier result reporting.

SUPPLIED WITH

• After-Burner Unit.

• 7” Touch LCD Control Panel.

• Thermal Printer.

• Built-in Weighing System (Capacity: 4 kg /

Readability: 0.1 kg).

• Sample Plate & Sample Holder.

Bitumen Content Oven – Ignition Method (A-030/IGN)

Code

A-030/IGN

Dimensions (± 1 cm)

63x60 x 112 (h)

Approximate Weight (kg)

95

TECHNICAL SPECIFICATIONS

• Chamber Maximum Temperature: 600°C.

• After-Burner Maximum Temperature: 950°C.

• Inner made of insulating bricks &fiber board.

• Outer made of galvanized steel.

www.alfatest.com.tr

181

ROLLING THIN FILM OVEN (A-030/RTFO)

ASTM D2872 • AASHTO T240

▪ Used to determine the effects of heat and air on a moving film of semi-solid asphaltic materials. The effects of this treatment are determined from measurements of the selected properties of the asphalt before and after the test.

▪ Internal chamber and external frame are made of stainless steel. Double wall insulation is made of fiberglass and the door is double glazed.

▪ The door has large glass for inspection during the test.

▪ Equipped with safety thermostat to prevent accidental over-heating.

▪ Clear, transparent, heat-resistant glass containers are supplied with the oven.

▪ Should be connected to a suitable air pressure supply

(can be ordered separately).

SUPPLIED WITH

• Digital thermostat to maintain 163°C (325°F) temperature

• Control thermometer

• Ventilation device

• Glass containers / sample bottles (8 ea)

• Safety thermostat

• Pilot light heat indicator

TECHNICAL SPECIFICATIONS

• Made of Stainless Steel

• Door with Large Window for Inspection

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

A-030/RTFO

Dimensions (± 1 cm)

62 x 91 x 62 (h)

Approximate Weight (kg)

55

182 www.alfatest.com.tr

Rolling Thin Film Oven (A-030/RTFO)

ASPHALT OVEN WITH ROTATING SHELVES (A-030/TFO)

ASTM D1754 • EN 12607:2 • EN 13303 • AASHTO T179

▪ Used to determine the effects of heat and air on a film of semisolid asphaltic materials. The effects of this treatment are determined from measurements of selected asphalt properties before and after the test.

▪ Internal chamber and external frame all made of stainless steel, double wall insulation with fiberglass, double-glazed door.

▪ Equipped with a digital thermostat and an indicator with operating temperature up to 180°C (356°F) fitted with overheat thermostat to prevent accidental over-temperature and to provide a safe working environment. The maximum temperature is regulated with the Proportional Integral

Derivative (PID) control and goes to a maximum set value.

▪ The plate rotates at 5.5 ± 1.0 rpm.

Asphalt Oven With Rotating Shelves (A-030/TFO)

SUPPLIED WITH

• Digital thermostat to maintain 180°C (356°F) temperature

• Control thermometer

• Ventilation device

• Containers (2 ea + 9 ea)

• Safety thermostat

TECHNICAL SPECIFICATIONS

• Made of Stainless Steel

• Rotates at 5.5 ± 1.0 rpm

• Door with Large Window for Inspection

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

A-030/TFOT

Dimensions (± 1 cm)

46 x 45 x 70 (h)

Approximate Weight (kg)

40 www.alfatest.com.tr

183

CORING MACHINE - TRAILER MOUNTED (A-065)

▪ Used to take core samples from the asphalt.

▪ Installed on a trailer for easy transportation.

▪ Equipped with a petrol engine, four stabilizing feet, 100 lt water tank.

▪ Core Bits for the machine should be ordered separately

v

TECHNICAL SPECIFICATIONS

• Trailer Mounted

• Petrol Engine

• Stabilizing Feet (4 ea)

• Water Tank (100 Lt)

• Core Bits should be ordered separately

Code

A-065

Dimensions (± 1 cm)

130 x 141 x 140 (h)

Approximate Weight (kg)

260

Code

Core Bit Diameter

A-065/4

4” (≈ 100 mm)

A-065/6

6” (≈ 150 mm)

184 www.alfatest.com.tr

Coring Machine - Trailer Mounted (A-065)

Coring Bits

v

CORING MACHINE - PORTABLE (A-066)

▪ Used to take core samples from the asphalt and concrete.

▪ The machine is designed to be portable and easily carried in a pick-up car.

▪ Equipped with a petrol engine, four stabilizing screw stands and a vertical screw feed.

▪ Suitable for Easy Single Person Operation.

▪ Core Bits for the machine should be ordered separately

TECHNICAL SPECIFICATIONS

• Portable unit.

• Petrol engine

• Four stabilizing screws.

• Vertical screw feed.

• Water inlet

• Engine Configuration : Vertical Shaft

• Engine Fuel

• Starter

• Bit Capacity

: Gasoline

: Rewind

: Up to 6” (150 mm) diameter bits

Portable Coring Machine (A-066) www.alfatest.com.tr

185

FLASH POINT APPARATUS (A-470)

▪ Used to determine the maximum temperature the bitumen can be safely heated without the danger of instantaneous flash in the presence of an open flame.

▪ Equipped with electronic heater, thermoregulator, two thermometers, and a sample cup.

SUPPLIED WITH

• Electric heater

• Thermoregulator

• Two Thermometers

• Sample Cup

Flash Point Apparatus (A-470)

RING AND BALL SOFTENING POINT APPARATUS (A-472)

▪ Used to determine the temperature at which a phase-change occur in the asphalt cement (bitumen) via “Softening Point Test”, that is to define the temperature at which an asphalt cement (bitumen) cannot support the weight of the steel ball and starts flowing.

▪ Comprises all the necessary parts to perform the test such as speedcontrolled heater, magnetic stirrer, temperature probe, glass beaker, Ring and

Ball support and test rings.

SUPPLIED WITH

• Hot plate with magnetic stirrer

• Glass thermometer

• Glass beaker, ring and ball support, test rings

Ring and Ball Softening Apparatus (A-472)

186 www.alfatest.com.tr

REFLUX EXTRACTOR (A-035)

ASTM D2172 • AASHTO T-164

▪ Used to determine the percentage of bitumen in the asphalt pavement mixtures.

▪ Equipped with a glass cylinder, two wire mesh cones and brass condenser.

▪ Filter Papers should be ordered separately

TECHNICAL SPECIFICATIONS

• Capacity: 1000 g / 4000 g

• Glass Jar Cylinder

• Wire mesh Cone (2 ea)

• Thermometer

• Hotplate

• Brass Condenser

CENTRIFUGE - EXTRACTOR (A-031)

ASTM D2172 • AASHTO T-164

▪ Used to determine the bitumen percentage in the asphalt mixtures.

▪ The extractor is available in two capacities (1500 g and 3000 g), and it is equipped with a speed control knob.

▪ Filter Papers should be ordered separately

Code

A-035/1

A-035/4

Reflux Extractor (A-035)

Capacity (g)

1000

4000

TECHNICAL SPECIFICATIONS

• Capacity: 1500 g / 3000 g

• Speed control knob

• Brake for fast stopping

• Filter Papers should be ordered separately

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

Capacity

A-031/15

1500 g

Centrifuge - Extractor (A-031)

A-031/30

3000 g www.alfatest.com.tr

187

FILTER PAPER (FP)

▪ A-031/1500/FP Used for Centrifuge: 1500 g

▪ A-031/3000/FP Used for Centrifuge: 3000 g

▪ C-035/FP

▪ A-035/FP

Used for Blaine Apparatus

Used for Reflux Extruder

▪ T-010/FP

▪ A-010/FP

Used for CBR Mould

Used for Marshall Mould

Filter Paper (FP)

ASPHALT HEATER (A-050/H)

▪ Used to heat the asphalt and make it within the standard range of temperature for mixing.

▪ Equipped with a thermostat to control the temperature of the mix.

188 www.alfatest.com.tr

Asphalt Heater (A-050/H)

MARSHALL MIXER (A-050)

▪ Used to mix the samples with bituminous materials.

The mixer provides uniform and quick mixing process.

▪ The beaters in the mixer rotates in both planetary and spindle ways to provide the best and the most efficient mixing state.

▪ Equipped with a stainless steel bowl and beater.

TECHNICAL SPECIFICATIONS

• Capacity: 5 lt (A-050/05)

10 lt (A-050/10)

• Rotates Planetary & Spindle

• Stainless Steel Bowl

• Beater

• Power Supply: 380 V (3 phase)

Marshall Mixer (A-050/05) with Heater (A-050/H) www.alfatest.com.tr

189

190 www.alfatest.com.tr

NUCLEAR DENSITY / MOISTURE GAUGE (EZ-121)

▪ Used to determine density and the moisture content of the sample in a very short period with very accurate results.

▪ The testing time can be chosen from the control panel as 15 seconds, 1 minute and 4 minutes.

▪ The depth range that can be measured by this equipment is 12” (30 cm), with 1” measurement increment.

▪ Supplied with all the necessary accessories to perform the test.

TECHNICAL SPECIFICATIONS

• Used for rapid fiend tests.

• Test time: 15 sec / 1 min / 4 min

• Depth Range up to 12” (30 cm)

• Increment: 1” (2.5 cm)

• With Accessories

Nuclear Density / Moisture Gauge (EZ-121)

Code

EZ-121

Dimensions (± 1 cm)

Gauge : 40 x 22 x 14 (h)

Reference Standard : 35 x 20 x 8 (h)

Transit Case

Accessory Case

: 79 x 36 x 50 (h)

: 50 x 25 x 13 (h)

Approximate Weight (kg)

41 www.alfatest.com.tr

191

SAYBOLT VISCOMETER (A-430)

ASTM D88 • AASHTO T-72

▪ Used to determine the viscosity of the petroleum products at a specified temperature.

▪ Equipped with a digital thermostat and indicator to control the temperature.

▪ The body of the machine is made from a very strong and rigid stainless steel.

▪ Also equipped with a mixer to ensure the homogeneity while testing, copper coil for quick cooling and sample cup with orifice.

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator

• Stainless Steel Body

• Mixer for Homogeneity

• Copper coil for cooling

• Sample Cup and Orifice

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

A-030

Saybolt Viscometer (A-430)

Dimensions (± 1 cm) Approximate Weight (kg)

41 x 45 x 60 (h) 15

KINEMATIC VISCOMETER (A-435)

ASTM D2170

▪ Used to determine the kinematic viscosity of the bitumen and road oil.

▪ Equipped with electronic thermostat, thermometer and a heating unit.

▪ Equipped with water circulating unit to provide homogeneous/constant temperature all over the bath.

TECHNICAL SPECIFICATIONS

• Viscosity Tube(s) in accordance with ASTM D2170 (To be specified at the time of inquiry).

• Digital Thermostat & Indicator with accuracy of 0.02°C.

192 www.alfatest.com.tr

Kinematic Viscometer (A-435)

DUCTILITY TESTER (A-440)

ASTM D113 • AASHTO T-51

▪ Used to determine the ductility of a bituminous materials by measuring the distance to which it will elongate before breaking when two ends of a briquet specimen of the material are pulled apart at a specified speed and temperature.

▪ Unless otherwise specified, the test shall be made at a temperature of 25°C ± 0.5°C and with a speed of 50 mm/min ± 5.0 %.

▪ The internal bath and external body are made of stainless steel, with double wall fiberglass insulation.

▪ Equipped with thermoregulator to maintain the test temperature during the test.

▪ In hot areas, upon request, refrigerating unit can be also equipped with the machine (A-440/CU).

▪ Equipped with circulation motor used to maintain a constant temperature.

▪ Supplied with ductility mould and plate (set of 2).

SUPPLIED WITH

• Ductility Mould (A-440/M)

TECHNICAL SPECIFICATIONS

• Digital Thermostat & Indicator

• Interior Stainless Steel

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Ductility Mould (A-440/M) www.alfatest.com.tr

193

EMULSION - DISTILLATION UNIT (A-450)

ASTM D402 • AASHTO T-78

▪ Used to determine the amount of water in the bitumen and petroleum products. The mechanism of the test is done via distilling the specimen with a water immiscible (volatile solvent).

▪ Comprises distillation flask, condenser, ring burner and two thermometers.

TECHNICAL SPECIFICATIONS

• Distillation Flask

• Condenser

• Ring Burner

• Thermometer (2ea)

Emulsion - Distillation Unit (A-450)

PARTICLE CHARGE TESTER (A-460)

ASTM D224

▪ Used to determine the particle charge (cationic) for the asphalt cement

(bitumen) emulsion.

▪ Equipped with milliammeter, variable resistor, rechargeable batteries and two stainless steel electrodes.

TECHNICAL SPECIFICATIONS

• Identify cationic emulsions

• Supplied with:

• Milliammeter

• Variable Resistor

• Rechargeable Battery

• 2 electrodes (ss)

194 www.alfatest.com.tr

Particle Charge Tester (A-460)

VACUUM PYCNOMETER (A-490)

ASTM D204 • EN 12697:5 • AASHTO T-209

▪ Used to rapidly determine the asphalt content, bulk specific gravity of aggregates, the specific gravity of bituminous compacted road mixtures and the percent air voids in the sample.

▪ Vacuum pump must be ordered separately.

TECHNICAL SPECIFICATIONS

• Minimum vacuum required: 30 mm/Hg

• Vacuum pump must be ordered separately.

Vacuum Pycnometer (A-490) www.alfatest.com.tr

195

ROCK MECHANICS

196 www.alfatest.com.tr

INDEX ROCK MECHANICS

Item

Rock Classification Hammer

Digital Point Load Apparatus

Slake Durability Tester

Core Cutting Machine

Code

RM-110

RM-120

RM-130

RM-063

Page

199

200

200

201 www.alfatest.com.tr

197

198 www.alfatest.com.tr

ROCK CLASSIFICATION HAMMER (RM-110)

▪ Used to determine the rock classification.

▪ The impact energy of the equipment is 0.74 Nm

▪ The core that is going to be tested is placed horizontally and the impact is applied on it.

▪ Supplied with a carrying case.

▪ Rock Cradle should be ordered separately.

SUPPLIED WITH

• Carrying Case

TECHNICAL SPECIFICATIONS

• Similar to Concrete Test Hammer

• Impact Energy : 0.74 Nm

• Core is positioned horizontally

Code

RM-110

Dimensions (± 1 cm)

35 x 18 x 16 (h)

Approximate Weight (kg)

2

Rock Classification Hammer (RM-110) www.alfatest.com.tr

199

DIGITAL POINT LOAD APPARATUS (RM-120)

▪ Used to determine the strength value of the rock specimens either in the field or in the laboratory.

▪ Designed to be light and easily ported from place to another.

▪ Consists of two-column crosshead frame and a hand operated hydraulic jack, and the load is measured by a pressure transducer with a digital display unit.

▪ The samples to be tested do not need to be regular in shape since the equipment can perform the test on irregular specimens too.

▪ Equipped with a digital indicator to measure the result.

▪ Provided with manual-hydraulic loading.

TECHNICAL SPECIFICATIONS

• Light and portable

• Can test irregular shaped samples

• Digital indicator

• Manual - Hydraulic Loading

Code

RM-120

Digital Point Load Apparatus (RM-120)

Dimensions (± 1 cm)

27 x 33 x 70 (h)

Approximate Weight (kg)

60

SLAKE DURABILITY TESTER (RM-130)

▪ Used to determine the durability of the rock specimens to weakening and disintegrating when subjected to the climatic slaking effects.

▪ Equipped with a motorized drive unit that rotates two drums. Drums rotate at 20 rpm inside acrylic water tank.

▪ The drums are made of stainless steel mesh.

TECHNICAL SPECIFICATIONS

• Motorized Drive Unit

• Rotates 2 drums

• Rotates at 20 rpm

• Acrylic Water Tank

• Drums of Stainless Steel Mesh

• Drum Size : Ø 140 mm x 100 mm

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

200 www.alfatest.com.tr

Slake Durability (RM-130)

CORE CUTTING MACHINE (RM-063)

▪ Used to cut core samples.

▪ Equipped with a disc holder for a maximum diameter of 230 mm.

▪ The distance of the disc is adjustable according to the user’s needs.

▪ Supplied with a water pump for cooling the materials while cutting.

Core Cutting Machine (RM-063)

TECHNICAL SPECIFICATIONS

• Used for cutting core samples.

• Disc diameter: Maximum 230 mm.

• Supplied with water pump for cooling.

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V /

60 Hz is also available)

RM-063

Code Dimensions (± 1 cm)

110 x 65 x 125 (h)

Approximate Weight (kg)

57 www.alfatest.com.tr

201

MINING

COAL

IRON & STEEL

202 www.alfatest.com.tr

INDEX MINING / COAL / IRON & STEEL

Item

Jaw Crusher

Cylindrical Crusher

Hammer Crusher

Shredder Machine

Disc Mill

Vibratory Disc Mill

Planetary Disc Mill

Universal Cutting Machine

Cutting Machine

Core Cutting Machine

Laboratory Oven

Sample Splitter

Sieve

Sieve Shaker

Electromechanical Sieve Shaker

Multi-Deck Grading Machine

Flotation Machine

Pressure Filter

Magnetic Separator

Pellet Press

Pellet Strength Tester

Grinding and Weighing System

Hammer Crusher

Shatter Indices Tester

Hardgrove Grindability Index Tester

Abrasion and Crumbling Index Tester

Universal Tensile and Compression Tester

Compression Tester for Iron/Steel

Steel Sheet Sampling Machine

Aluminum Sampling Machine

Pellet Press

Pellet Strength Tester

Electronic Balance

Platform Scale

Specific Gravity Frame

M-043

M-062

M-002

M-003

ET

EB

TS-100

M-07x

M-002

M-003

M-041/ETS

M-440

M-015

M-195

M-191

UTM-001

M-001

B-063

RM-063

G-030

G-080

B-040

B-041

B-041/SV

M-042

M-050

M-053

G-412

G-415

M-440

Code

M-407

G-420

G-430

M-434

B-062

218

219

219

220

221

215

216

216

217

218

222

223

224

224

225

225

225

213

213

213

214

214

210

210

211

212

212

Page

204

205

206

206

207

208

209

210 www.alfatest.com.tr 203

JAW CRUSHER (G-412)

▪ Used to crush samples with medium-hard, hard, brittle and tough materials. Efficiency and safety makes it ideal for sample preparation in laboratories and industrial plants.

▪ Application examples are so wide such as construction materials, glass, granite, minerals, quartz, rocks, silicon, slag, coal, oxide ceramics … etc.

▪ The materials after crushing have high degree of size reduction and high fineness.

▪ Jaw Dimensions: 100 x 350 mm, made of

(16%-18% Mn + 1.5% Cr).

▪ Double action of jaws that opens/closes from the bottom and the crushing mechanism is from top to bottom.

▪ Supplied complete with electrical motor.

TECHNICAL SPECIFICATIONS

• Material feed size < 50 mm

• Jaws dimension: 100 x 350 mm

• Jaws are made of (16-18% Mn) + (1.5% Cr)

• Double Action of jaws:

• Opening /closing at bottom

• Crushing form up to bottom

• Jaw opening at the bottom is adjustable.

• Power Supply: 380 V / 50 Hz

Code

G-412

Dimensions (± 1 cm)

110 x 65 x 115 (h)

204 www.alfatest.com.tr

Jaw Crusher (G-412)

Approximate Weight (kg)

300

CYLINDRICAL CRUSHER (G-415)

▪ Made of hardened steel cylinders. The distance between the cylinders is adjustable.

▪ The materials feed size is < 20 mm, and it is supplied with overload protection with 2 springs.

▪ Supplied with feed hopper and collector.

▪ Supplied complete with the electrical motor.

TECHNICAL SPECIFICATIONS

• Material feed size < 20 mm

• Cylinders are steel and hardened.

• Distance between cylinders is adjustable

• Overload protection with 2 springs

• Feed hopper and collector

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

Code

G-415

Dimensions (± 1 cm)

55 x 60 x 50 (h)

Cylindrical Crusher (G-415) www.alfatest.com.tr

205

HAMMER CRUSHER (M-440)

▪ Used to crush medium-hard materials and specially coal and coke

▪ Material feed size is < 50 mm

▪ Final fineness is maximum 3 mm (with 3 mm sieve installed)

▪ Capacity: 250 – 700 kg/hr

▪ Supplied with feed hopper and collector

▪ Automatic cut-off electricity if the

▪ Sieves (3 … 9 mm) upon request (to be specified at the time of order)

▪ Easy to clean

▪ Complete with motor

TECHNICAL SPECIFICATIONS

▪ Material feed size is < 50 mm

▪ Final fineness is maximum 3 mm (with 3 mm sieve installed)

▪ Capacity: 250 – 700 kg/hr

SHREDDER MACHINE (M-407)

▪ Used to shred medium-hard minerals, ores, coal, coke, hard plastic, wood, paper, tires and brittle materials

▪ Shredding Discs: 150 - 200 mm in diameter

▪ Capacity: Depending on material to be shredded, 50 - 250 kg/hr

▪ Heavy-Duty constuction

▪ Low horsepower, energy efficient

▪ Auto-reversing mechanism to avoid damagin shredding units

▪ 380 V / 50 Hz

TECHNICAL SPECIFICATIONS

▪ Shredding Discs: 150 - 200 mm in diameter

▪ Capacity: Depending on material to be shredded, 50 - 250 kg/hr

▪ Heavy-Duty constuction

▪ Auto-reversing mechanism

▪ 380 V / 50 Hz

206 www.alfatest.com.tr

DISC MILL (G-420/S)

▪ Used under rough conditions for grinding of hard, medium-hard, brittle and tough materials

▪ Required few minutes to achieve the desired grind size, and work continuously

▪ Application examples: minerals, ores, bauxite, clinkers, chalk, chamotte, concrete, construction materials, soil samples, gypsum … etc.

▪ Dust preventing O-Ring on the body

▪ Discharge opening between discs is adjustable

▪ Supplied with collector (25 x 20 x 8 cm)

TECHNICAL SPECIFICATIONS

▪ Capacity : 20 – 100 kg/hr depending on material and final size

▪ Disc diameter : 170 mm

▪ Feeding size : < 10 mm

▪ Final fineness : 50 – 200 microns

DISC MILL (G-420/L)

▪ Used under rough conditions for grinding of hard, medium-hard, brittle and tough materials

▪ Required few minutes to achieve the desired grind size, and work continuously

▪ Application examples: minerals, ores, bauxite, clinkers, chalk, chamotte, concrete, construction materials, soil samples, gypsum … etc.

▪ Dust preventing O-Ring on the body

▪ Discharge opening between discs is adjustable

▪ Supplied with collector (25 x 20 x 8 cm)

TECHNICAL SPECIFICATIONS

• Capacity : 40 – 200 kg/hr depending on material and final size

• Disc diameter : 205 mm

• Feeding size : < 15 mm

• Final fineness : 50 – 200 microns www.alfatest.com.tr

207

VIBRATORY DISC MILL (G-430)

▪ Used for quick grinding, assuring that no sample loss can be experienced.

▪ It has a very wide range grinding and finishes the job in an extremely short time.

▪ The maximum materials feed size is 15 mm and grinds to a final fineness of 50 micron.

▪ The jar size that is supplied with the equipment is 100 ml.

208 www.alfatest.com.tr

TECHNICAL SPECIFICATIONS

• Suitable for quick grinding

• No sample loss

• Wide range grinding

• Extremely short grinding time

• Material feed size < 15 mm

• Final Fineness < 50 mic

• Jar Size 100 ml

PLANETARY DISC MILL (M-434)

▪ Used whenever highest fineness is required

▪ Robust model with 4 grading stations

▪ Short grinding time assured b centrifugal force of planetary mixing

▪ Jars are made of hardened steel (also available in stainless steel upon request)

▪ Used for grinding minerals, ores, coal, coke, alloys, bentonite, bones, cement clinkers, concrete, glass, gypsum, limestone, polymers, seeds ... etc.

▪ Feed size is < 10 mm

▪ Final fineness is < 10 microns

▪ Speed control for required applications

▪ Automatic cut-off energy if the cover is opened

TECHNICAL SPECIFICATIONS

• Robust model with 4 grading stations

• Feed size is < 10 mm

• Final fineness is < 10 microns

• Speed control for required applications

• Automatic cut-off energy if the cover is opened www.alfatest.com.tr

209

UNIVERSAL CUTTING MACHINE (B-062)

▪ Used to cut construction materials.

It is equipped with a disc holder for a maximum diameter of 450 mm.

▪ Ideal for wet cutting.

▪ Supplied with precision linear guide bar system with dust proof aluminum cover and Automatic thermal overload protection.

TECHNICAL SPECIFICATIONS

• Disc diameter: 450mm.

• Circulation pump for cooling

CUTTING MACHINE (B-063)

▪ Used to cut rocks, ores, consturction materials ... etc.

▪ Supplied with a disc holder and a disc having diameter of 350 mm

TECHNICAL SPECIFICATIONS

• Disc Diameter: 350 mm

• Water Inlet for Wet Cutting

• Thermal Overload Protection

CORE CUTTING MACHINE (RM-063)

▪ Used to cut core samples.

▪ The distance of the disc is adjustable according to the user’s needs.

TECHNICAL SPECIFICATIONS

• Disc diameter: Maximum 230 mm.

• Supplied with water pump for cooling.

210 www.alfatest.com.tr

LABORATORY OVEN (G-030)

Laboratory Oven - 8000 lt (G-030/8000)

TECHNICAL SPECIFICATIONS

▪ Digital Thermostat & Indicator Fitted With overheat thermostat

▪ Temp max

▪ Interior chamber

: 200°C (392°F) (PID control)

: Stainless Steel

▪ Exterior

▪ Insulation

▪ Airflow

▪ Power Supply is also available)

: Powder Coated or Stainless Steel

: Thick mineral wool

: Forced convection

: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz

Laboratory Oven - 250 lt (G-030/250)

Laboratory Oven - 400 lt (G-030/400) www.alfatest.com.tr

211

SAMPLE SPLITTER (G-080)

▪ Eesigned to halve/divide aggregates, soils, sands and gravel into two representative halves.

▪ Made of powder coated enameled steel.

TECHNICAL SPECIFICATIONS

• Please see pages 42, 108

SIEVE (B-040)

ISO 3310:1 • ASTM E11• BS 410

▪ All Sieves are made of stainless steel woven wire and frame that meet international specifications.

▪ The sieve aperture is clearly marked on the metallic label.

▪ Our sieves are of the highest quality to ensure consistent fit, accurate, specifications and durable construction.

▪ The sieves are available in two diameters (200 mm) and (300 mm).

▪ Cover and pan should be ordered separately.

TECHNICAL SPECIFICATIONS

• Frame and mesh made of stainless steel

• Aperture marked on a metal label

• Available in (ø 200 mm) and (ø 300 mm) diameters

212 www.alfatest.com.tr

SIEVE SHAKER (B-041)

▪ Operated by electrical motor which provides a more elaborated and standardized sieving to ensure accurate results and eliminate personal errors involved in sieving.

▪ Available in two sizes:

▪(B-041/200) shaker that can be used for (20 cm) sieves

▪(B-041/300) shaker that can be used for (20 cm) and (30 cm)

TECHNICAL SPECIFICATIONS

• Lightweight

• Quiet Operation

• Compact and portable

• Built in Timer (60 min)

ELECTROMECHANICAL SIEVE SHAKER (B-041/SV)

• Performs perfect sieving by having double-actions: (Swinging motion

& Vibration motion)

▪ Capable of applying both or one of the motions

▪ Suitable for both dry and wet sieving

▪ Automatic timer built-in for sieving time

TECHNICAL SPECIFICATIONS

• Performs perfect sieving by having double-actions: (Swinging motion &

Vibration motion)

• Available for Ø 200 mm / Ø 300 mm / Ø 450 mm (to be specified at the time of order)

• Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

MULTI-DECK GRADING MACHINE (M-042)

• Used specially in mining labs where large quantities of sieving is required.

• Two sieves with decks, each of 300 x 500 mm size, and the openings are

10 mm and 5 mm unless otherwise specified during the order.

• Plastic boxes, as collectors, are supplied for each deck.

TECHNICAL SPECIFICATIONS

• Equipped with pan at the bottom.

• Adjustable sieving angle.

• Equipped with powerful vibrating motor.

• Power Supply: 380 V (3 phase) www.alfatest.com.tr

213

FLOTATION MACHINE (M-050)

▪ DENVER design (similar to D-12)

▪ Stirrer can be infitely variable between 50 – 2600 rpm, supplied with digital indicator for speed

▪ Mechanism to lower/lift the stirring head

▪ Two flotation stirrers are supplied with the machine:

▪ Stainless steel stirrer

▪ Polymer stirrer

▪ Flotation cells are made of stainless steel with capacities 1, 2, 3 and 4 liters

▪ The base and support column are made of cast aluminum

▪ Capable of working with 250 – 2000 g of sample

TECHNICAL SPECIFICATIONS

▪ Adjustable stirring Frequency (50 - 2600 rpm)

▪ Capable of working with 250 – 2000 g of sample

▪ Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available)

PRESSURE FILTER (M-053)

▪ DENVER type Pressure Filter

▪ Made of stainless steel with a volume of

▪ Maximum Pressure: 8 kg/cm

2

▪ Supplied with air pressure regulator, gauge, valve and filter pack

TECHNICAL SPECIFICATIONS

▪ Made of stainless steel

▪ Maximum Pressure: 8 kg/cm2

214 www.alfatest.com.tr

MAGNETIC SEPARATOR : DAVIS TUBE TYPE (M-074)

▪ Consisting of a powerful electromagnetic field intensity

▪ The angle of the table is adjutable

▪ Tube moves forward and backward while rotating

▪ Supplied with collector

TECHNICAL SPECIFICATIONS

▪ Wet magnetic separation method

▪ Adjustable angle

MAGNETIC SEPARATOR : DRUM TYPE TYPE (M-075)

▪ Used to concentrate the fine material with high magnetism

▪ Consisting of a frame, magnetic drum, mineral box, watering pipe and feeding box.

▪ Supplied with collector

TECHNICAL SPECIFICATIONS

▪ Wet separation method www.alfatest.com.tr

215

PELLET PRESS (M-002)

▪ Used for forming high-quality pellets for XRF analysis

▪ Fully automatic with LCD indicator

▪ Controlling the pressure force, it also determines the time of build-up of force during pressing

▪ Even difficult materials are pressed perfectly performing pellets with smooth surface

▪ Capacity: 300 kN (30 tons)

▪ LCD indicator:

▪ Calibration function (password-protected)

▪ Maximum load and time are set

▪ Overload protection

▪ Application examples:

▪ Cement, gypsum, ores, raw materials, slag … etc.

TECHNICAL SPECIFICATIONS

▪ Fully automatic with LCD indicator

▪ Capacity: 300 kN (30 tons)

PELLET STRENGTH TESTER (M-003)

▪ Fully automatic, LCD indicator

▪ Used to test the strength of pellets

▪ Can test 60 pcs in a row

▪ The height is measured before the test

▪ The average of 60 tests is determined and the test results detects if failure described in the standards

▪ The graph of each pellet testing is available if required

TECHNICAL SPECIFICATIONS

▪ Fully automatic, LCD indicator

▪ Can test 60 pcs in a row

216 www.alfatest.com.tr

GRINDING and WEIGHING SYSTEM (M-041/ETS)

▪ Used wherever accepting the ore to the factory

▪ There are 4 functions in the system:

Lifting the sample:

▪ Capacity of the crane winch is 2000 kg

▪ Travel beam of the winch is limited by switchers

▪ Manual controlling device of the winch to be used by operator

Feeding:

▪ The bigbag is filled to the feeding tank by using the crane

▪ The feeding tank is carried on to the sieving system

▪ The bottom door is opened hydraulically by the operator

Grading:

▪ Grading is done by the 3 deck screening

▪ Each size is collected in the collector

Weighing:

▪ Different sizes of the materials are weighed by the platform scale

The system is complete with:

▪ Platform scale with 2000 kg capacity (digital)

▪ Crane winch and supporting system with control unit

▪ Three dech grading machine with each deck 1000 x 2000 mm size

▪ Feeding tank with capacity of 1500 kg with hydraulic bottom door

▪ Trolleys made of steel construction (4 pcs) www.alfatest.com.tr

217

HAMMER CRUSHER (M-440)

▪ Used to crush medium-hard materials and specially coal and coke

▪ Material feed size is < 50 mm

▪ Final fineness is maximum 3 mm (with 3 mm sieve installed)

▪ Capacity: 250 – 700 kg/hr

▪ Supplied with feed hopper and collector

▪ Automatic cut-off electricity if the

▪ Sieves (3 … 9 mm) upon request (to be specified at the time of order)

▪ Easy to clean

▪ Complete with motor

TECHNICAL SPECIFICATIONS

▪ Material feed size is < 50 mm

▪ Final fineness is maximum 3 mm (with 3 mm sieve installed)

▪ Capacity: 250 – 700 kg/hr

SHATTER INDICES TESTER (M-015)

▪ Used to determine the resistance to breakage after dropping the sample with specified conditions mentioned in standards

▪ The box has a lifting mechanism by pulleys and 2 door hinged lengthwise with a latch for rapid opening

▪ Rigid base plate with 4 sides preventing loss of coke

TECHNICAL SPECIFICATIONS

▪ Equipped with pulleys and hinged doors

▪ Rigid base plate with 4 sides preventing loss of coke

218 www.alfatest.com.tr

HARDGROVE GRINDABILITY INDEX TESTER (M-195)

▪ Used to determine the HGI (Hardgrove Grindability

Index) of coal

▪ Supplied with abrasive spheres (8 ea)

▪ Weight set is supplied with the machine

▪ Digital numerator for setting the revolution of the machine and automatically stopping after desired revolution

TECHNICAL SPECIFICATIONS

▪ Digital numerator for setting the revolution of the machine and automatically stopping after desired revolution

▪ Power Supply: 220 - 240 V / 50 or 60 Hz

ABRASION and CRUMBLING INDEX TESTER (M-191)

▪ Used to determine the resistance to abrasion and crumbing of the iron ores, such as pellet and sinter form

▪ The drum rotates 200 revolutions with 15 kg of sample

▪ Supplied with 2 test sieves

▪ Collector at the bottom to collect shredded materials

TECHNICAL SPECIFICATIONS

▪ The drum rotates 200 revolutions with 15 kg of sample

▪ Collector at the bottom to collect shredded materials www.alfatest.com.tr

219

UNIVERSAL TENSILE and COMPRESSION TESTER (UTM-001)

TENSILE TESTING

▪ Fully Automatic - PC Controlled

▪ Hydraulically operated grippers by 2 independent auxiliary cylinders controlled by separated hydraulic valves

▪ Upper mobile crosshead driven up/down by a separated motor adjusting the distance between upper and lower grips with electronic distance meter

▪ Available models:

▪ 300 kN (30 tons)

▪ 600 kN (60 tons)

▪ 1000 kN (100 tons)

▪ 2000 kN (200 tons)

▪ Height: 210 cm only.

▪ Print of Stress/Strain Diagram and Test Results.

COMPRESSION TESTING

▪ Fully Automatic.

▪ Graphical - LCD Data Acquisition Control

System.

▪ Automatic Load Rate upon Sample Type.

▪ Stops Automatically, when Test is completed.

▪ Real time graph indication.

▪ Total Load and also Per Area are given.

▪ Test results can be transferred to computer to be printed or from the thermal printer.

▪ Different units are available.

▪ Calibration done easily on 5 pts.

▪ Manual Control is available.

▪ If weight of sample entered, Unit Weight is determined.

▪ Rigid Frame.

▪ Upper and Lower Platens in accordance with international Specifications.

▪ Upper Seating for Homogeneous Loading.

▪ Power Supply: 220 - 240 V / 50 or 60 Hz (110 V

/ 60 Hz is also available)

220 www.alfatest.com.tr

COMPRESSION TESTER for IRON/STEEL (M-001/LCD)

▪ Used for determining the strength of iron/steel samples by compressing it vertically

▪ Fully automatic, controlled by computer

▪ Used to determine the length change by compression

▪ Built on 4 columns

▪ Special upper and lower platens

▪ Automatic cut-off in the door is opened

▪ The LCD indicator, during the test, shows the following:

▪ Load/ shortening graph

▪ Special application if shortening: 1/2 or 1/3

▪ The length change is readable with 0.01 mm

▪ Stopping at desired travel or force

▪ The data transferred to computer and all sample data is recorded

▪ Automatic stopping when test is completed

TECHNICAL SPECIFICATIONS

▪ Fully automatic, controlled by computer

▪ Built on 4 columns

▪ Special upper and lower platens

▪ Automatic stopping when test is completed

▪ Power Supply: 220 - 240 V / 50 or 60 Hz (110 V / 60 Hz is also available) www.alfatest.com.tr

221

STEEL SHEET SAMPLING MACHINE (M-043)

▪ Used to take samples from metal sheets up to 2 mm thick

▪ Hydraulic system with capacity of 1000 kN

▪ Supplied with two moulds that can take samples with diameters of 57.3 mm and 64.5 mm

▪ The system has a safety valve for overload

▪ Equipped with safety guard door that stops the machine once opened

TECHNICAL SPECIFICATIONS

• Capacity: 1000 kN

• Equipped with safety guard door

• Power Supply: 380 V (3 phase)

222 www.alfatest.com.tr

ALUMINUM SAMPLING MACHINE (M-062)

▪ Used to prepare circular samples from aluminum ingots for XRF analysis

▪ Fully automatic, with 3 functions:

▪ Drilling

▪ Polishing

▪ Cutting

▪ Ingot is placed on the support system and all the a/m functions are done automatically in a short time by an operator

▪ The sample taken has a desired diameter and thickness with smooth surface

TECHNICAL SPECIFICATIONS

▪ Fully automatic, with 3 functions:

▪ Drilling

▪ Polishing

▪ Cutting

▪ Ingot is placed on the support system and all the a/m functions are done automatically in a short time by an operator www.alfatest.com.tr

223

PELLET PRESS (M-002)

▪ Used for forming high-quality pellets for XRF analysis

▪ Fully automatic with LCD indicator

▪ Controlling the pressure force, it also determines the time of build-up of force during pressing

▪ Even difficult materials are pressed perfectly performing pellets with smooth surface

▪ Capacity: 300 kN (30 tons)

▪ LCD indicator:

▪ Calibration function (password-protected)

▪ Maximum load and time are set

▪ Overload protection

▪ Application examples:

▪ Cement, gypsum, ores, raw materials, slag … etc.

TECHNICAL SPECIFICATIONS

▪ Fully automatic with LCD indicator

▪ Capacity: 300 kN (30 tons)

PELLET STRENGTH TESTER (M-003)

▪ Fully automatic, LCD indicator

▪ Used to test the strength of pellets

▪ Can test 60 pcs in a row

▪ The height is measured before the test

▪ The average of 60 tests is determined and the test results detects if failure described in the standards

▪ The graph of each pellet testing is available if required

TECHNICAL SPECIFICATIONS

▪ Fully automatic, LCD indicator

▪ Can test 60 pcs in a row

224 www.alfatest.com.tr

ELECTRONIC BALANCE (ET / HT)

▪ The balance has capacity ranges from 30 kg to 200 g and with accuracy from 0.5 g to 0.001 g depending on the type and the purpose of it.

▪ It is supplied with rechargeable batteries allowing the balance to be used in the laboratory and insitu.

▪ The balance is provided with under weighing mechanism.

TECHNICAL SPECIFICATIONS

• Rechargeable battery

• Used both in labs and insitu

• Taring Facility

• Under Weighing mechanism

PLATFORM SCALE (EB)

▪ The equipment frame and design is robust and strong.

▪ The scale has the taring option.

▪ Available in 2 types depending on their capacity and readability.

TECHNICAL SPECIFICATIONS

• Strong and robust

• Push button taring facility

• Power Supply: 220 - 240 V / 50 Hz

SPECIFIC GRAVITY FRAME (TS-100)

▪ The frame can be used to determine the specific gravity of solid materials (concrete, aggregate .. etc)

▪ The system consists of a highly rigid frame, incorporating moving platform on its lower part, water tank and a density basket.

TECHNICAL SPECIFICATIONS

• Can be used for specific gravity determination

• Balance should be ordered separately www.alfatest.com.tr

225

LAB TOOLS

226 www.alfatest.com.tr

INDEX LAB TOOLS

Item

Compressor

Vacuum Pump

Scoop - Large

Air Dryer

Ph Meter

Stopwatch

Timer

Lab Trolley

Caliper

Steel Ruler

Hotplate

Trowel

Hammer

Rubber Mallet

Spoon

Tool Kit

Spatula

Wire Brush

Hair Brush

Moisture Tin

Sample Tray

Mixing Bowl

Calculator

Wash Bottle

Heat-Resistant Gloves

Pipette

Tape Meter

Hydrometer

Funnel

Shovel

231

231

231

232

232

230

230

230

230

231

Page

228

228

228

228

229

229

229

229

233

234

234

234

234

235

235

232

232

233

233

233

GL-09

GL-10

GL-11

GL-12

GL-13

GL-14

GL-15

GL-16

GL-17

GL-18

Code

GL-01

GL-02

GL-03

GL-04

GL-05

GL-06

GL-07

GL-08

GL-19

GL-20

GL-21

GL-22

GL-23

GL-24

GL-25

GL-26

GL-27

GL-28

GL-29

GL-30

Item

Glass Stirring Rod

Water Trompe

Chisel

Scissors

Specific Gravity Pycnometer

Feeler Strip Set

Tripod

Glass Plate

Rubber Gloves

Claw Hammer

Cross-Section Paper

Straight Edge

Evaporating Dish

Mortar and Pestle

Mixing Tray

Unit Weight Measures

Glass Beaker

Plastic Beaker

Specific Gravity Bottle / Pycnometer

Volumetric Flask

Desiccator

Test Bottle

Glass Measuring Cylinder

Plastic Measuring Cylinder

Dial Thermometer

Max-Min Thermometer

Non-Contact Infrared Thermometer

Glass Thermometer

Digital Thermometer

GHT

GNT

BAK

GCB

GPB

GL-39

GL-42

GL-43

GL-47

GPP

Code

GL-31

GL-32

GL-33

GL-34

GL-35

GL-36

GL-37

GL-38

GCP

GCBJ

GCD

GCS

GCM

GPM

GTI

GTMM

GTL

GTC

GTD

238

239

239

240

240

237

237

238

238

238

Page

235

235

236

236

236

236

237

237

243

244

244

244

245

245

241

241

242

242

243 www.alfatest.com.tr 227

COMPRESSOR (GL-01) VACUUM PUMP (GL-02)

Compressor (GL-01)

SCOOP (GL-03)

Vacuum Pump (GL-02)

AIR DRIER (GL-04)

Scoop (GL-03)

228 www.alfatest.com.tr

Air Drier (GL-04)

PH METER (GL-05) STOP WATCH (GL-06)

PH Meter (GL-05)

TIMER (GL-07)

Stop Watch (GL-06)

LABORATORY TROLLEY (GL-08)

Timer (GL-07) Laboratory Trolley (GL-08) www.alfatest.com.tr

229

CALIPER (GL-09) STEEL RULER (GL-10)

Code

Capacity

Readability

Type

GL-09/M/150 GL-09/D/150 GL-09/M/300

150 mm

0.01 mm

Mechanical

150 mm

0.01 mm

Digital

300 mm

0.01 mm

Mechanical

Caliper (GL-09) Steel Ruler (GL-10)

HOTPLATE (GL-11) TROWEL (GL-12)

Hotplate (GL-11)

230 www.alfatest.com.tr

Trowel (GL-12)

HAMMER (GL-13) RUBBER MALLET (GL-14)

Hammer (GL-13)

SPOON (GL-15)

Rubber Mallet (GL-14)

TOOL KIT (GL-16)

Spoon (GL-15) Tool Kit (GL-16) www.alfatest.com.tr

231

SPATULA (GL-17) WIRE BRUSH (GL-18)

Spatula (GL-17)

HAIR BRUSH (GL-19)

Wire Brush (GL-18)

MOISTURE TIN (GL-20)

Hair Brush (GL-19)

232 www.alfatest.com.tr

Moisture Tin (GL-20)

SAMPLE TRAY (GL-21) MIXING BOWL (GL-22)

Sample Tray (GL-21)

CALCULATOR (GL-23)

Mixing Bowl (GL-22)

WASH BOTTLE (GL-24)

Calculator (GL-23) Wash Bottle (GL-24) www.alfatest.com.tr

233

HEAT RESISTANT GLOVES (GL-25) PIPETTE (GL-26)

Heat Resistant Gloves (GL-25)

TAPE METER (GL-27)

Pipette (GL-26)

HYDROMETER (GL-28)

Tape Meter (GL-27)

234 www.alfatest.com.tr

Hydrometer (GL-28)

FUNNEL (GL-29) SHOVEL (GL-30)

Funnel (GL-29) Shovel (GL-30)

GLASS STIRRING ROD (GL-31) WATER TROMP (GL-32)

Glass Stirring Rod (GL31) Water Tromp (GL-32) www.alfatest.com.tr

235

CHISEL (GL-33) SCISSORS (GL-34)

Chisel (GL-33)

PYCNOMETER (GL-35)

Scissors (GL-34)

FEELER STRIP SET (GL-36)

Pycnometer (GL-35)

236 www.alfatest.com.tr

Feeler Strip Set (GL-36)

TRIPOD (GL-37) GLASS PLATE (GL-38)

Tripod (GL-37)

RUBBER GLOVES (GL-39)

Glass Plate (GL-38)

CLAW HAMMER (GL-42)

Rubber Gloves (GL-39) Claw Hammer (GL-42) www.alfatest.com.tr

237

CROSS-SECTION PAPER (GL-43) STRAIGHT EDGE (GL-47)

Cross-Section Paper (GL-43)

EVAPORATING DISH (GPP)

Straight Edge (GL-47)

MORTAR AND PESTLE (GHT)

Evaporating Dish (GPP)

238 www.alfatest.com.tr

Mortar and Pestle (GHT)

MIXING TRAY (GNT)

Code

GNT/S

GNT/M

GNT/L

Size

Small

Medium

Large

Mixing Tray (GNT)

UNIT WEIGHT MEASURES (BAK)

Code

BAK/01

BAK/03

BAK/05

BAK/07

BAK/10

BAK/14

BAK/15

BAK/28

BAK/30

Unit Weight Measures (BAK)

Capacity

1 lt

3 lt

5 lt

7 lt

10 lt

14 lt

15 lt

28 lt

30 lt www.alfatest.com.tr

239

GLASS BEAKER (GCB)

Code

Capacity

GCB/0100

100 ml

GCB/0250

250 ml

GCB/0600

600 ml

GCB/1000

1000 ml

Glass Beaker (GCB)

PLASTIC BEAKER (GPB)

Code

Capacity

GPB/0100 GPB/0250 GPB/0500 GPB/1000

100 ml 250 ml 500 ml 1000 ml

240 www.alfatest.com.tr

Plastic Beaker (GPB)

SPECIFIC GRAVITY BOTTLE / PYCNOMETER (GCP)

Code

Capacity

GCP/0025

25 ml

GCP/0050

50 ml

GCP/0100

100 ml

GCP/0500

500 ml

GCP/1000

1000 ml

GCP/2000

2000 ml

VOLUMETRIC FLASK (GCBJ)

Code

Capacity

GCBJ/0100 GCBJ/0250 GCBJ/0500 GCBJ/1000

100 ml 250 ml 500 ml 1000 ml

Volumetric Flask (GCBJ) www.alfatest.com.tr

241

DESICCATOR (GCD)

Code

GCD/210

Diameter 210 mm

GCD/240

240 mm

GCD/300

300 mm

GCD/210-V GCD/240-V GCD/300-V

210 mm 240 mm 300 mm

Vacuum Vacuum Vacuum Vacuum

TEST BOTTLE (GCS)

Code

GCS/0500

GCS/1000

GCS/2000

Capacity

500 ml

1000 ml

2000 ml

Test Bottle (GCS)

242 www.alfatest.com.tr

GLASS MEASURING CYLINDER (GCM)

Code

GCM/0050

GCM/0100

GCM/0250

GCM/0500

GCM/1000

GCM/2000

Capacity

50 ml

100 ml

250 ml

500 ml

1000 ml

2000 ml

PLASTIC MEASURING CYLINDER (GPM)

Code

GPM/0050

GPM/0100

GPM/0250

GPM/0500

GPM/1000

GPM/2000

Capacity

50 ml

100 ml

250 ml

500 ml

1000 ml

2000 ml

Glass Measuring Cylinder (GCM)

Plastic Measuring Cylinder (GPM) www.alfatest.com.tr

243

DIAL THERMOMETER (GTI) MAX-MIN THERMOMETER (GTMM)

GTI/300

Code

Range

Dial Thermomerter (GTI)

GTI/070

-40 to +70°C

GTI/070

GTI/300

O to 300°C

Code

Capacity

Max-Min Thermometer (GTMM)

GTMM/50

-50 to +50°C

NON-CONTACT (LASER) INFRARED

THERMOMETER (GTL)

THERMO-HYGROMETER (GTHM)

Non-Contact Infrared Thermometer (GTL)

244 www.alfatest.com.tr

Thermo-Hygrometer (GTHM)

GLASS THERMOMETER (GTC)

Code

Range

Graduation

GTC/100

0 to 100°C

1°C

GTC/200

0 to 200°C

1°C

GTC/300

0 to 300°C

1°C

GTC/360

0 to 360°C

1°C

DIGITAL THERMOMETER (GTD)

Code

Range

GTD/300

-50°C to +300°C

Glass Thermometer (GTC)

Digital Thermometer (GTD) www.alfatest.com.tr

245

MOBILE LAB

246 www.alfatest.com.tr

INDEX MOBILE LABORATORY

Item

Mobile Laboratory ML

Code Page

249 www.alfatest.com.tr

247

248 www.alfatest.com.tr

MOBILE LABORATORY (ML-001)

▪ We can offer a complete line of Mobile

Laboratory with special design to meet all possible environments such as cold or tropical climate.

The main tree types are:

▪ Container

▪ Trailer Mounted

▪ Van Mounted

FACILITIES

• Office / Bedroom section

• Lighting & Electric sockets

• Electric generator

• Air Conditioning / Aspirator Fan

• Water Tank, WC & Sink

Mobile Laboratory (ML-001) www.alfatest.com.tr

249

INDEX

250 www.alfatest.com.tr

INDEX INDEX

Item

Analytical Index

Code Index

Page

252

262 www.alfatest.com.tr

251

INDEX

ANALYTICAL INDEX

A

B

C

Item

Abrasion and Crumbling Index Tester

Abrasion Tester for Concrete Tiles and Natural Stones

Abrasion Tester, Dorry (Böhme)

Abrasion Tester, Los Angeles

Abrasion Tester, Micro-Deval

Abrasive Charges for AG-191

Aggregate Crushing Value

Aggregate Impact Value

Aggregate Shape Gauge

Air Dryer

Airmeter

Aluminum Sampling Machine

Asphalt Heater

Asphalt Oven with Rotating Shelves

Automatic Cement Mixer

Automatic Marshall Compactor

Automatic Mortar Mixer

Automatic Soil Compactor

Automatic Vicat Apparatus

Balance, Electronic

Balance, Mechanical

Balloon Density Apparatus

Basket, Density

Beaker, Glass

Beaker, Plastic

Beam Mould

Bitumen Content Oven - Ignition Method

Bitumen Penetrometer

Blain Apparatus

Böhme Abrasion Tester, Dorry

Brush, Hair

Brush, Wire

Cabinet for AG-191, Noise Reduction

Calculator

Calibration Container for T-061

Caliper

Capping Set, Cylindrical

Casagrande Apparatus - Liquid Limit Device

Casagrande Apparatus - Motorized Liquid Limit Device

CBR Equipment

CBR Tester, Field

252 www.alfatest.com.tr

58

129

128

150

148

232

119

233

136

230

181

179

96

121

232

135

40

240

240

59

103

139

99

39

38

223

188

183

103

177

124

125

111

228

67

Page

219

120

121

117

123

119

GL-18

AG-191/SPC

GL-23

T-061/x/CC

GL-09

B-015

T-030

T-030/M

T-01x

T-005

T-067

TS-105

GCB

GPB

B-017

A-030/IGN

A-090

C-035

AG-199

GL-19

M-062

A-050/H

A-030/TFO

C-050/A

A-015

C-050/A

T-055

C-090/A

ET, HT

MT

Code

M-191

AG-197

AG-199

AG-191

AG-195

AG-191/AC

AG-210

AG-220

AG-036

GL-04

B-320/B

ANALYTICAL INDEX

C

Item

CBR Tester, Laboratory - Digital

CBR Tester, Laboratory - LCD

Cement Compression and Flexural Tester

Cement Compression Test Mould

Cement Flexural Test Mould

Cement Flow Table

Cement Flow Table, Motorized

Cement Mixer

Cement Mixer, Automatic

Cement Vibrating Machine

Centrifuge Extractor

Chisel

Claw Hammer

Climatic Chamber

Compacting Factor Apparatus

Compaction Determination Apparatus

Compactor, Automatic Marshall

Compactor, Automatic Soil

Compression Jig

Compression Tester

Compression Tester for Iron/Steel

Compressor

Concrete Beams, Flexure Apparatus

Concrete Flow Table

Concrete Penetrometer

Concrete Pipe Testing Machine

Concrete Test Hammer

Concrete Test Hammer, Digital

Concrete Tiles Abrasion Tester

Concrete Water Impermeability Tester

Cone Penetrometer

Consistometer, Vebe

Consolidation - Oedometer

Constant Head Permeability Set

Controlling Unit for Curing Tank

Conversion Frame for Field CBR

Core Bits for Asphalt

Core Bits for Concrete

Core Cutting Machine

Coring Machine

Coring Machine - Portable

INDEX

B-130

T-210

T-250/CH

B-140/CU

T-005/L

A-065/x

B-061/x

RM-063

B-061

A-066

GL-01

B-003/BFA

B-024

B-135

B-001/PT

B-110

B-110/D

AG-197

B-245

T-090

GL-33

GL-42

G-035

B-185

T-065

A-015

T-055

C-011/CJ

B-001/LCD

M-001

Code

T-001/D

T-001/LCD

C-001/LCD

C-011

C-011/04

C-021

C-021/M

C-050

C-050/A

C-126

A-031

184

75

201

75

185

60

154

152

69

148

77

76

120

72

130

228

55

60

64

57

177

139

94

49

221

236

237

30

64

135

100

102

103

97

187

Page

149

147

93

95

95

101 www.alfatest.com.tr

253

INDEX

ANALYTICAL INDEX

C

D

E

Item

Coring Machine - Trailer Mounted

Crack Detection Microscope

Cradle

Cross-Section Paper

Crusher, Cylindrical

Crusher, Hammer

Crusher, Jaw

Crushing Value, Aggregate

Cube Mould, Plastic

Cube Mould, Steel

Curing Tank Controlling Unit

Curing Tank, Metal

Curing Tank, Plastic

Cutting Machine

Cylinder Mould

Cylindrical Capping Set

Cylindrical Crusher

Density Basket

Desiccator

Dial Indicator

Dial Penetrometer

Dial Thermometer

Digital Concrete Test Hammer

Digital Plate Load Set

Digital Point Load Apparatus

Digital Thermometer

Direct Shear Tester

Disc Mill

Disc Mill, Planetary

Disc Mill, Vibratory

Distillation Unit, Emulsion

Distillation Unit, Water

Dorry Abrasion Tester (Böhme)

Drum-Type Mixer

Ductility Mould

Ductility Tester

Durability Tester, Slake

Dynamic Penetrometer, Lightweight

Dynamic Penetrometer, TRL

Electrical Density Gauge

Electromechanical Sieve Shaker

254 www.alfatest.com.tr

200

134

134

145

37

32

121

70

193

193

156

207

209

208

194

244

76

153

200

245

205

40

242

44

132

69

68

74

58

58

Page

184

78

40

238

205

206, 218

204

124

59

59

69

G-045

AG-199

B-121

A-440/M

A-440

RM-130

T-300/LW

T-300/TRL

EDG

B-041/SV

GTI

B-110/D

T-063

RM-120

GTD

T-220

G-420

M-434

G-430

A-450

B-140/M

B-140/P

B-063

B-010

B-015

G-415

TS-105

GCD

DI

T-308

Code

A-065

B-250

TS-106

GL-43

G-415

M-440

G-412

AG-210

B-011/P

B-011/M

B-140/CU

ANALYTICAL INDEX

E

F

G

H

Item

Electromechanical Tensile Tester

Electronic Balance

Emulsion Distillation Unit

Evaporating Dish

Extractor, Centrifuge

Extractor, Reflux

Extruder, Sample (Asphalt)

Extruder, Sample (Soil)

Extruder, Universal

Falling Head Permeability Set

Feeler Strip Set

Ferrodetector

Field CBR Tester

Filter Paper

Flakiness / Thinkness Gauge

Flakiness Sieve Set

Flash Point Apparatus

Flask, Le Chatelier

Flask, Volumetric

Flexural Jig

Flexural Testing Machine

Flexure Apparatus for Concrete Beams

Flotation Machine

Flow Table, Cement

Flow Table, Concrete

Flow Table, Motorized Cement

Funnel

Glass Beaker

Glass Measuring Cylinder

Glass Plate

Glass Stirring Rod

Glass Thermometer

Gloves, Heat-Resistant

Gloves, Rubber

Grid Sieve Set

Grindability Index Tester, Hardgrove

Grinding and Weighing System

Hair Brush

Hammer

Hammer Crusher

Hammer, Rock Classification

INDEX

GTC

GL-25

GL-39

AG-038

M-195

M-041/ETS

GL-19

GL-13

M-440

RM-110

B-003/BFA

M-050

C-021

B-024

C-021/M

GL-29

GCB

GCM

GL-38

GL-31

Code

UTM-001/EM

ET, HT

A-450

GPP

A-031

A-035

A-020

T-020

T-025

T-250/FH

GL-36

B-050/H

T-005

FP

AG-032

AG-030

A-470

C-022

GCBJ

C-011/FJ

B-003/LCD

245

234

237

111

219

217

232

231

206, 218

199

235

240

243

237

235

55

214

101

60

100

186

104

241

94

56

73

148

188

110

109

178

151

151

152

236

Page

89

39

194

238

187

187 www.alfatest.com.tr

255

INDEX

ANALYTICAL INDEX

H

J

I

K

L

M

Item

Hand Vane Tester

Hardgrove Grindability Index Tester

Heater, Asphalt

Heat-Resistant Gloves

Hi-Low Detector - Travelling Beam

Hotplate

Hydrometer

Impact Value, Aggregate

Impurities Set, Organic

Iron/Steel Compression Tester

Jaw Crusher

Jolting Table

J-Ring Apparatus

Kinematic Viscometer

Lab Trolley

Laboratory CBR Tester - Digital

Laboratory CBR Tester - LCD

Laboratory Oven

L-Box Apparatus

Le Chatelier Bath

Le Chatelier Flask

Le Chatelier Mould

Length Gauge

Lightweight Dynamic Penetrometer

Liquid Limit Device - Casagrande Apparatus

Liquid Limit Device, Motorized - Casagrande Apparatus

Load Cell

Load Ring

Los Angeles Abrasion Tester

Magnetic Separator

Marsh Funnel

Marshall Compactor, Automatic

Marshall Mixer

Marshall Mould

Marshall Stability Tester - Digital

Marshall Stability Tester - LCD

Marshall Water Bath

Max-Min Thermometer

Measuring Cylinder, Glass

Measuring Cylinder, Plastic

Mechanical Balance

256 www.alfatest.com.tr

180

244

243

243

38

177

189

176

176

175

45

44

117

215

96

104

110

134

129

128

147

27

62

105

104

97

63

192

229

149

234

125

114

221

204

Page

133

219

188

234

178

230

A-015

A-050

A-010

A-001/D

A-001/LCD

G-040

GTMM

GCM

GPM

MT

C-023

AG-034

T-300/LW

T-030

T-030/M

LC

LR

AG-191

M-07x

C-015

C-125

B-027

A-435

GL-08

T-001/D

T-001/LCD

G-030

B-026

G-040/06

C-022

Code

T-175

M-195

A-050/H

GL-25

A-069

GL-11

GL-28

AG-220

AG-240

M-001

G-412

INDEX

ANALYTICAL INDEX

M

N

Item

Metal Curing Tank

Methylene Blue Set

Micro-Deval Abrasion Tester

Microwave Oven

Mixer, Automatic Cement / Mortar

Mixer, Cement / Mortar

Mixer, Drum-Type

Mixer, Marhsall

Mixer, Pan-Type

Mixing Bowl

Mixing Tray

Mobile Laboratory

Modified Proctor Mould

Modified Proctor Rammer

Modified Proctor Set

Moisture / Temperature Tester

Moisture Tin

Mortar and Pestle

Mortar Mixer

Mortar Mixer, Automatic

Motorized Cement Flow Table

Motorized Liquid Limit Device - Casagrande Apparatus

Mould, Beam

Mould, Cement Compression

Mould, Cement Flexural

Mould, Cylinder

Mould, Ductility

Mould, Le Chatelier

Mould, Marshall

Mould, Modified Proctor

Mould, Plastic Cube

Mould, Standard Proctor

Mould, Steel Cube

Mud Balance

Muffle Furnace

Multi-Deck Grading Machine

Natural Stones Abrasion Tester

Noise Reduction Cabinet for AG-191

Non-Contact Infrared Thermometer

Nuclear Density / Moisture Gauge (Asphalt)

Nuclear Density / Moisture Gauge (Soil)

T-030/M

B-017

C-011

C-011/04

B-010

A-440/M

C-023

A-010

T-050/M-M

B-011/P

T-050/S-M

B-011/M

C-014

G-050

M-042

AG-197

AG-191/SPC

GTL

EZ-121

EZ-121

ML

T-050/M-M

T-050/M-R

T-050/M

T-462

GL-20

GHT

C-050

C-050/A

C-021/M

Code

B-140/M

AG-041

AG-195

G-030/MW

C-050/A

C-050

B-121

A-050

B-120

GL-22

GNT

120

119

244

191

143

138

59

96

31

37

193

104

176

138

59

128

59

95

95

58

232

238

102

103

100

249

138

138

138

140

70

189

71

233

239

Page

69

115

123

30

103

102 www.alfatest.com.tr

257

INDEX

ANALYTICAL INDEX

O

P

Item

Oedometer - Consolidation

Organic Impurities Set

Oven, Laboratory

Oven, Microwave

Pan-Type Mixer

Particle Charge Tester

Pellet Press

Pellet Strength Tester

Penetrometer, Bitumen

Penetrometer, Conceret

Penetrometer, Cone

Penetrometer, Dial

Penetrometer, Lightweight Dynamic

Penetrometer, Pocket

Penetrometer, Soil

Penetrometer, TRL Dynamic

Permeability Set, Constant Head

Permeability Set, Falling Head

Ph Meter

Pipette

Planetary Disc Mill

Plastic Beaker

Plastic Cube Mould

Plastic Curing Tank

Plastic Limit Set

Plastic Measuring Cylinder

Plate Load Set, Digital

Platform Scale

Pocket Penetrometer

Point Load Apparatus, Digital

Poker Vibrator

Portable Coring Machine

Pressure Filter

Proctor Mould, Modified

Proctor Mould, Standard

Proctor Rammer, Modified

Proctor Rammer, Standard

Proctor Set, Modified

Proctor Set, Standard

Profoscope

Pycnometer, Specific Gravity

258 www.alfatest.com.tr

138

138

138

73

236

185

214

138

138

138

153

38

132

200

65

240

59

68

131

243

152

152

229

234

209

132

134

132

133

134

Page

154

114

27

30

71

194

216, 224

216, 224

179

64

130

A-066

M-053

T-050/M-M

T-050/S-M

T-050/M-R

T-050/S-R

T-050/M

T-050/S

B-050/P

GL-35

GPB

B-011/P

B-140/P

T-035

GPM

T-063

EB

T-304

RM-120

B-128

T-308

T-300/LW

T-304

T-310

T-300/TRL

T-250/CH

T-250/FH

GL-05

GL-26

M-434

Code

T-210

AG-240

G-030

G-030/MW

B-120

A-460

M-002

M-003

A-090

B-135

T-090

ANALYTICAL INDEX

P

R

S

Item

Pycnometer, Specific Gravity Bottle

Pycnometer, Vacuum

Rammer, Modified Proctor

Rammer, Standard Proctor

Reflux Extractor

Ring and Ball Softening Point Apparatus

Rock Classification Hammer

Rolling Thin Film Oven

Rubber Gloves

Rubber Mallet

Sample Extruder (Asphalt)

Sample Extruder (Soil)

Sample Splitter

Sample Tray

Sampling Machine, Aluminum

Sampling Machine, Steel Sheet

Sand Absorption Cone and Tamper

Sand Cone Set

Sand Equivalent Set

Sand Equivalent Shaker

Saybolt Viscometer

Scale, Platform

Scissors

Scoop - Large

Shaker, Electromechanical Sieve

Shaker, Sand Equivalent

Shaker, Sieve

Shape Gauge, Aggregate

Shatter Indices Tester

Shear Tester, Direct

Shovel

Shredder Machine

Shrinkage Limit Set

Sieve

Sieve Set, Flakiness

Sieve Set, Grid

Sieve Shaker

Sieve Shaker, Electromechanical

Skid Resistance Tester

Slab Testing Machine

Slake Durability Tester

INDEX

M-407

T-037

B-040

AG-030

AG-038

B-041

B-041/SV

AG-190

B-004

RM-130

EB

GL-34

GL-03

B-041/SV

AG-040/SS

B-041

AG-036

M-015

T-220

GL-30

Code

GCP

A-490

T-050/M

T-050/S

A-035

A-472

RM-110

A-030/RTFO

GL-39

GL-14

A-020

T-020

G-080

GL-21

M-062

M-043

AG-200

T-061

AG-040

AG-040/SS

A-430

36

37

122

56

200

206

131

34

109

111

36

111

218

156

235

38

236

228

37

112

151

42, 108

233

223

222

122

136

113

112

192

199

182

237

231

178

Page

241

195

138

138

187

186 www.alfatest.com.tr

259

INDEX

ANALYTICAL INDEX

S

T

Item

Slump Set

Softening Point Apparatus, Ring and Ball

Soil Compactor, Automatic

Soil Penetrometer

Spatula

Specific Gravity Bottle / Pycnometer

Specific Gravity Frame

Specific Gravity Pycnometer

Speedy Moisture Tester, Universal Carbide

Splitter, Sample

Splitter, Universal Sample

Spoon

Standard Proctor Mould

Standard Proctor Rammer

Standard Proctor Set

Steel Cube Mould

Steel Ruler

Steel Sheet Sampling Machine

Stirring Rod, Glass

Stopwatch

Straight Edge

Tape Meter

Temperature / Moisture Tester

Tensile Tester, Electromechanical

Test Bottle

Testing Anvil

Thermometer, Dial

Thermometer, Digital

Thermometer, Glass

Thermometer, Max-Min

Thermometer, Non-Contact Infrared

Thickness / Flakiness Gauge

Timer

Tin, Moisture

Tool Kit

Trailer Mounted Coring Machine

Travelling Beam - Hi-Low Detector

Triaxial Tester

Tripod

TRL Dynamic Penetrometer

Trowel

260 www.alfatest.com.tr

178

159

237

134

230

110

229

232

231

184

244

245

245

244

244

234

140

89

242

76

230

222

235

229

238

231

138

138

138

59

Page

61

186

139

133

232

241

41

236

141

42, 108

43, 109

GL-27

T-462

UTM-001/EM

GCS

B-117

GTI

GTD

GTC

GTMM

GTL

AG-032

GL-07

GL-20

GL-16

A-065

A-069

T-5001/A

GL-37

T-300/TRL

GL-12

GL-15

T-050/S-M

T-050/S-R

T-050/S

B-011/M

GL-10

M-043

GL-31

GL-06

GL-47

Code

B-020

A-472

T-055

T-310

GL-17

GCP

TS-100

GL-35

T-068

G-080

G-081

ANALYTICAL INDEX

U

V

W

Item

Ultrasonic Tester

Uniaxial Tester

Unit Weight Measures

Universal Carbide Tester (Speedy Moisture Tester)

Universal Cutting Machine

Universal Extruder

Universal Sample Splitter

Universal Tensile and Compression Tester

U-Shape Box Apparatus

Vacuum Pump

Vacuum Pycnometer

Vane Tester, Hand

Vebe Consistometer

V-Funnel Apparatus

Vibrating Machine, Cement

Vibrating Table

Vibratory Disc Mill

Vicat Apparatus

Vicat Apparatus, Automatic

Viscometer, Kinematic

Viscometer, Saybolt

Volumetric Flask

Wash Bottle

Water Bath

Water Bath, Marshall

Water Distillation Unit

Water Impermeability Tester, Concrete

Water Level Indicator

Water Trompe

Wire Brush

INDEX

T-175

B-130

B-025

C-126

B-125

G-430

C-090

C-090/A

A-435

A-430

Code

B-048

T-201/D

BAK

T-068

B-062

T-025

G-081

UTM-001

B-029

GL-02

A-490

GCBJ

GL-24

G-040

G-040

G-045

B-245

T-470

GL-32

GL-18

208

98

99

192

192

133

60

62

97

65

Page

79

155

239

141

74

151

43, 109

83

63

228

195

72

140

235

232

241

233

33

180

32 www.alfatest.com.tr

261

INDEX

CODE INDEX

A

A-450

A-460

A-470

A-472

A-490

AG-030

AG-032

AG-034

AG-036

AG-038

AG-040

AG-040/SS

AG-041

AG-190

AG-191

AG-191/AC

AG-191/SPC

AG-195

AG-197

AG-199

A-050/H

A-065

A-065/x

A-066

A-069

A-090

A-430

A-435

A-440

A-440/M

A-001/D

A-001/LCD

A-010

A-015

A-020

A-030/IGN

A-030/RTFO

A-030/TFO

A-031

A-035

A-050

Code

262 www.alfatest.com.tr

Description

Marshall Stability Tester – Digital

Marshall Stability Tester – LCD

Marshall Mould

Automatic Marshall Compactor

Sample Extruder

Bitumen Content Oven – Ignition Method

Rolling Thin Film Oven

Asphalt Oven with Rotating Shelves

Centrifuge Extractor

Reflux Extractor

Marshall Mixer

Asphalt Heater

Coring Machine – Trailer Mounted

Core Bit

Coring Machine – Portable

Hi-Low Detector – Travelling Beam

Bitumen Penetrometer

Saybolt Viscometer

Kinematic Viscometer

Ductility Tester

Ductility Mould

Emulsion Distillation Unit

Particle Charge Tester

Flash Point Apparatus

Ring and Ball Softening Point Apparatus

Vacuum Pycnometer

Flakiness Sieve Set

Thickness / Flakiness Gauge

Length Gauge

Aggregate Shape Gauge

Grid Sieve Set

Sand Equivalent Set

Sand Equivalent Shaker

Methylene Blue Set

Skid Resistance Tester

Los Angeles Abrasion Tester

Abrasive Charges for AG-191

Noise Reduction Cabinet for AG-191

Micro-Deval Testing Machine

Abrasion Tester for Concrete Tiles and Natural Stones

Dorry Abrasion Tester (Böhme)

119

119

123

120

121

113

112

115

122

117

109

110

110

111

111

194

194

186

186

195

179

192

192

193

193

188

184

184

185

178

182

183

187

187

189

Page

176

175

176

177

178

181

CODE INDEX

A

B

B-110/D

B-117

B-120

B-121

B-125

B-128

B-130

B-135

B-140/CU

B-140/M

B-041

B-041/SV

B-048

B-050/H

B-050/P

B-061

B-061/x

B-062

B-063

B-110

B-011/P

B-015

B-017

B-020

B-024

B-025

B-026

B-027

B-029

B-040

AG-200

AG-210

AG-220

AG-240

B-001/LCD

B-001/PT

B-003/BFA

B-003/LCD

B-004

B-010

B-011/M

Code Description

Sand Absorption Cone and Tamper

Aggregate Crushing Value

Aggregate Impact Value

Organic Impurities Set

Compression Tester

Concrete Pipe Testing Machine

Flexure Apparatus for Concrete Beams

Flexural Testing Machine

Slab Testing Machine

Cylinder Mould

Steel Cube Mould

Plastic Cube Mould

Cylindrical Capping Set

Beam Mould

Slump Set

Concrete Flow Table

V-Funnel Apparatus

L-Box Apparatus

J-Ring Apparatus

U-Shape Box Apparatus

Sieve

Sieve Shaker

Electromechanical Sieve Shaker

Ultrasonic Tester

Ferrodetector

Profoscope

Coring Machine

Core Bits for Concrete

Universal Cutting Machine

Cutting Machine

Concrete Test Hammer

Digital Concrete Test Hammer

Testing Anvil

Pan-Type Mixer

Drum-Type Mixer

Vibrating Table

Poker Vibrator

Vebe Consistometer

Concrete Penetrometer

Controlling Unit for Curing Tank

Metal Curing Tank

INDEX

65

60

64

69

69

76

76

71

70

65

75

75

74, 210

74, 210

77

36

37

79

73

73

62

62

63

63

34

59

58

59

61

60

55

56

56

58

59

Page

122

124

125

114

49

57 www.alfatest.com.tr

263

INDEX

CODE INDEX

B

C

D

E

F

G

G-030/MW

G-035

G-040

G-040/06

G-045

G-050

G-080

G-081

G-412

G-415

C-090/A

C-125

C-126

DI

EB

EDG

ET

EZ-121

FP

G-030

C-014

C-015

C-021

C-021/M

C-022

C-023

C-035

C-050

C-050/A

C-090

B-140/P

B-185

B-245

B-250

B-320/B

BAK

C-001/LCD

C-011

C-011/04

C-011/CJ

C-011/FJ

Code

264 www.alfatest.com.tr

Description

Plastic Curing Tank

Compacting Factor Apparatus

Concrete Water Impermeability Tester

Crack Detection Microscope

Airmeter

Unit Weight Measures

Cement Compression and Flexural Tester

Cement Compression Test Mould

Cement Flexural Test Mould

Compression Jig

Flexural Jig

Mud Balance

Marsh Funnel

Cement Flow Table

Motorized Cement Flow Table

Le Chatelier Flask

Le Chatelier Mould

Blain Apparatus

Cement / Mortar Mixer

Automatic Cement / Mortar Mixer

Vicat Apparatus

Automatic Vicat Apparatus

Jolting Table

Cement Vibrating Machine

Dial Indicator

Platform Scale

Electrical Density Gauge

Electronic Balance

Nuclear Density / Moisture Gauge

Filter Paper

Laboratory Oven

Microwave Oven

Climatic Chamber

Water Bath

Le Chatelier Bath

Water Distillation Unit

Muffle Furnace

Sample Splitter

Universal Sample Splitter

Jaw Crusher

Cylindrical Crusher

30

30

33, 180

105

32

31

42, 108

43, 109

204

205

99

97

97

44

38

145

39

143, 191

188

27

104

96

102

103

98

96

96

101

100

104

93

95

95

94

94

Page

68

64

72

78

67

239

CODE INDEX

G

GL-23

GL-24

GL-25

GL-26

GL-27

GL-28

GL-29

GL-30

GL-31

GL-32

GL-13

GL-14

GL-15

GL-16

GL-17

GL-18

GL-19

GL-20

GL-21

GL-22

GL-03

GL-04

GL-05

GL-06

GL-07

GL-08

GL-09

GL-10

GL-11

GL-12

G-420

G-430

GCB

GCBJ

GCD

GCM

GCP

GCS

GHT

GL-01

GL-02

Code

Hammer

Rubber Mallet

Spoon

Tool Kit

Spatula

Wire Brush

Hair Brush

Moisture Tin

Sample Tray

Mixing Bowl

Calculator

Wash Bottle

Heat-Resistant Gloves

Pipette

Tape Meter

Hydrometer

Funnel

Shovel

Glass Stirring Rod

Water Trompe

Description

Disc Mill

Vibratory Disc Mill

Glass Beaker

Volumetric Flask

Desiccator

Glass Measuring Cylinder

Specific Gravity Bottle / Pycnometer

Test Bottle

Mortar and Pestle

Compressor

Vacuum Pump

Scoop - Large

Air Dryer

Ph Meter

Stopwatch

Timer

Lab Trolley

Caliper

Steel Ruler

Hotplate

Trowel

INDEX

234

235

235

235

235

233

233

234

234

234

232

232

232

233

233

231

231

231

231

232

229

230

230

230

230

228

228

229

229

229

241

242

238

228

228

Page

207

208

240

241

242

243 www.alfatest.com.tr

265

INDEX

CODE INDEX

G

H

L

M

R

M-062

M-07x

M-191

M-195

M-407

M-434

M-440

ML

MT

RM-063

LR

M-001

M-002

M-003

M-015

M-041/ETS

M-042

M-043

M-050

M-053

GPB

GPM

GPP

GTC

GTD

GTI

GTL

GTMM

HT

LC

GL-33

GL-34

GL-35

GL-36

GL-37

GL-38

GL-39

GL-42

GL-43

GL-47

GNT

Code

266 www.alfatest.com.tr

Description

Chisel

Scissors

Specific Gravity Pycnometer

Feeler Strip Set

Tripod

Glass Plate

Rubber Gloves

Claw Hammer

Cross-Section Paper

Straight Edge

Mixing Tray

Plastic Beaker

Plastic Measuring Cylinder

Evaporating Dish

Glass Thermometer

Digital Thermometer

Dial Thermometer

Non-Contact Infrared Thermometer

Max-Min Thermometer

Electronic Balance

Load Cell

Load Ring

Compression Tester for Iron/Steel

Pellet Press

Pellet Strength Tester

Shatter Indices Tester

Grinding and Weighing System

Multi-Deck Grading Machine

Steel Sheet Sampling Machine

Flotation Machine

Pressure Filter

Aluminum Sampling Machine

Magnetic Separator

Abrasion and Crumbling Index Tester

Hardgrove Grindability Index Tester

Shredder Machine

Planetary Disc Mill

Hammer Crusher

Mobile Laboratory

Mechanical Balance

Core Cutting Machine

223

215

219

219

206

209

206, 218

249

38

201, 210

44

221

216, 224

216, 224

218

217

37, 213

222

214

214

244

244

244

39

45

240

243

238

245

245

237

237

238

238

239

Page

236

236

236

236

237

237

INDEX

CODE INDEX

M

T

T-220

T-250/CH

T-250/FH

T-300/LW

T-300/TRL

T-304

T-308

T-310

T-462

T-470

T-061

T-061/x/CC

T-063

T-065

T-067

T-068

T-090

T-175

T-201/D

T-210

T-030/M

T-035

T-037

T-050/M

T-050/M-M

T-050/M-R

T-050/S

T-050/S-M

T-050/S-R

T-055

RM-110

RM-120

RM-130

T-001/D

T-001/LCD

T-005

T-005/L

T-01x

T-020

T-025

T-030

Code Description

Rock Classification Hammer

Digital Point Load Apparatus

Slake Durability Tester

Laboratory CBR Tester - Digital

Laboratory CBR Tester - LCD

Field CBR Tester

Conversion Frame for Field CBR

CBR Equipment

Sample Extruder

Universal Extruder

Liquid Limit Device - Casagrande Apparatus

Motorized Liquid Limit Device - Casagrande Apparatus

Plastic Limit Set

Shrinkage Limit Set

Modified Proctor Set

Modified Proctor Mould

Modified Proctor Rammer

Standard Proctor Set

Standard Proctor Mould

Standard Proctor Rammer

Automatic Soil Compactor

Sand Cone Set

Calibration Container for T-061

Digital Plate Load Set

Compaction Determination Apparatus

Balloon Density Apparatus

Universal Carbide Tester (Speedy Moisture Tester)

Cone Penetrometer

Hand Vane Tester

Uniaxial tester

Oedometer - Consolidation

Direct Shear Tester

Constant Head Permeability Set

Falling Head Permeability Set

Lightweight Dynamic Penetrometer

TRL Dynamic Penetrometer

Pocket Penetrometer

Dial Penetrometer

Soil Penetrometer

Moisture / Temperature Tester

Water Level Indicator

132

132

133

140

140

156

152

152

134

134

141

130

133

155

154

136

136

153

135

135

138

138

138

138

139

128

131

131

138

138

148

150

151

151

129

Page

199

200

200

149

147

148 www.alfatest.com.tr

267

INDEX

CODE INDEX

T

U

Code

T-5001/A

TS-100

TS-105

TS-106

UTM-001

UTM-001/EM

Description

Triaxial Tester

Specific Gravity Frame

Density Basket

Cradle

Universal Tensile and Compression Tester

Electromechanical Tensile Tester

Page

159

41

40

40

83

89

268 www.alfatest.com.tr

NOTE

www.alfatest.com.tr

269

NOTE

270 www.alfatest.com.tr

NOTE

www.alfatest.com.tr

271

NOTE

272 www.alfatest.com.tr

16 www.alfatest.com.tr

PO Box 7000-516

Redondo Beach

CA 90277

USA

Tel : +1 310 987 52 52

Mail : [email protected]

Web : www.alfatestusa.com

Melih Gokcek Blv.

ALFA Plaza No: 113

Ivedik OSB

Ankara

TURKEY

Tel : +90 312 395 25 22

Fax : +90 312 395 25 27

Mail : [email protected]

Web : www.alfatest.com.tr

ALFA | Testing Equipment | M. Gokcek Blv. ALFA Plaza No: 113 Ivedik OSB - Ankara / TURKEY | Phone: +90 312 395 25 22 | www.alfatest.com.tr

16

ALFA | Testing Equipment | M. Gokcek Blv. ALFA Plaza No: 113 Ivedik OSB - Ankara / TURKEY | Phone: +90 312 395 25 22 | www.alfatest.com.tr

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
