Operating instructions

Migo

GB, IE

2.3

3

3.1

3.2

3.3

3.4

4

4.1

4.2

4.3

4.4

4.5

4.6

4.7

1

1.1

1.2

1.3

2

2.1

2.2

Contents

Contents

Safety .................................................................... 3

Action-related warnings ......................................... 3

Intended use .......................................................... 3

General safety information .................................... 4

Notes on the documentation .............................. 5

Observing other applicable documents ................. 5

Storing documents................................................. 5

Applicability of the instructions .............................. 5

Product description............................................. 5

Design of the product............................................. 6

Display ................................................................... 6

Information on the identification plate.................... 6

CE label ................................................................. 7

Operation.............................................................. 7

Starting up the product .......................................... 7

Preventing malfunctions ........................................ 7

Checking and setting the room temperature ......... 7

Installing the app.................................................... 8

Establishing a wireless connection........................ 8

Restoring the connection....................................... 9

Comfort protection mode ....................................... 9

6

6.1

7

7.1

8

9

9.1

4.8

4.9

4.10

5

Checking the battery charge condition ................ 10

Replacing batteries .............................................. 11

Start screen ......................................................... 11

Troubleshooting ................................................ 12

Care and maintenance ...................................... 12

Caring for the product .......................................... 12

Decommissioning.............................................. 12

Permanently decommissioning the product......... 12

Recycling and disposal..................................... 12

Guarantee and customer service..................... 13

Guarantee............................................................ 13

9.2

Customer service................................................. 13

Appendix .............................................................................14

A

Faults Overview .............................................. 14

B Legal note........................................................... 14

2

Operating instructions Migo 0020212897_01

1 Safety

1.1

Action-related warnings

Classification of action-related warnings

The action-related warnings are classified in accordance with the severity of the possible danger using the following warning signs and signal words:

Warning symbols and signal words

Danger!

Imminent danger to life or risk of severe personal injury

Danger!

Risk of death from electric shock

Warning.

Risk of minor personal injury

Caution.

Risk of material or environmental damage

Safety 1

1.2

Intended use

In the event of inappropriate or improper use, damage to the product and other property may arise.

The Glow-worm Migo controller controls a heating installation with a Glow-worm boiler with eBUS interface in a way that is weathercontrolled and time-dependent.

In addition, the hot water generation from a connected domestic hot water cylinder can be controlled.

Operation is permissible with the following components and accessories:

– Domestic hot water cylinder (conventional)

Intended use includes the following:

– observance of the operating instructions included for the product and any other system components

– compliance with all inspection and maintenance conditions listed in the instructions.

0020212897_01 Migo Operating instructions

3

1 Safety

Intended use also covers installation in accordance with the IP class.

The use of the product in vehicles, such as camper vans and caravans, is not classed as intended use. Units that are not classed as vehicles are mobile homes or those that are installed in a fixed and permanent location

(known as "fixed installation").

Any other use that is not specified in these instructions, or use beyond that specified in this document shall be considered improper use. Any direct commercial or industrial use is also deemed to be improper.

Caution.

Improper use of any kind is prohibited.

1.3.2 Danger caused by improper operation

Improper operation may present a danger to you and others, and cause material damage.

Carefully read the enclosed instructions and all other applicable documents, particularly the "Safety" section and the warnings.

1.3

General safety information

1.3.1 Installation by competent persons only

Only an approved competent person is permitted to carry out installation, inspection, maintenance and repair work on the product.

4

Operating instructions Migo 0020212897_01

Notes on the documentation 2

2 Notes on the documentation

2.1

Observing other applicable documents

You must observe all operating instructions enclosed with the system components.

2.2

Storing documents

Keep this manual and all other applicable documents safe for future use.

2.3

Applicability of the instructions

These instructions apply for the following only:

Description

Migo

Article number

0020197229

Conditions: Heating

You can use the product and associated app to set a desired temperature for a room for different times of the day and for different days of the week.

The product is a weather compensator.

The product receives the current outside temperature via the

Internet connection. When the outside temperature is low, the product increases the flow temperature of the glow worm heating installation.

If the outside temperature increases, the product lowers the flow temperature. The product therefore responds to the fluctuations in the outside temperature and uses the flow temperature to ensure that the room temperature remains constantly at the set desired temperature.

Conditions: Hot water generation

3 Product description

The product controls the heating installation in a way that is weather-controlled and time-dependent using a Glow worm boiler with an eBUS interface and the hot water generation of a connected domestic hot water cylinder.

You can use the product and associated app to set the temperature and time period for the hot water generation.

The heat generator heats the water in the domestic hot water cylinder until it reaches the set temperature.

The time period defines when hot water should be ready in the domestic hot water cylinder.

0020212897_01 Migo Operating instructions

5

3 Product description

3.1

Design of the product

10 1 2 3

3.2

Symbol

Display

Meaning

Connection between the thermostat and communication unit is being established

Connection has been established; normal operation

Connection has been broken

3

4

1

2

9 8

7 and buttons

Small wall socket: Thermostat

Wall socket: Communication unit

Bluetooth button/comfort protection mode button

6

5

6

7

Status LED

Communication unit

Display

8

9

Thermostat

Product stand

10 Large wall socket:

Thermostat

4

5

3.3

Information on the identification plate

The identification plate is mounted on the rear of the communication unit and the thermostat in the factory.

Information on the identification plate

Meaning

Barcode with serial number (on the communication unit only),

7th to 16th digit = product article number

(on the communication unit only)

6

Operating instructions Migo 0020212897_01

Information on the identification plate

Meaning

→ "CE label" section

Migo

V mA

3.4

CE label

Product description

Operating voltage and current consumption

→ "Recycling and disposal" section

Operation 4

4 Operation

4.1

Starting up the product

Only start up the product once the casing has been completely closed.

4.2

Preventing malfunctions

1.

Ensure that the room air can freely circulate around the thermostat and that the thermostat is not covered by furniture, curtains or other objects.

2.

In the rooms in which the thermostat is installed, open the radiator valves completely.

4.3

Checking and setting the room temperature

The CE label shows that the products comply with the basic requirements of the applicable directives as stated on the identification plate.

The declaration of conformity can be viewed at the manufacturer's site.

The manufacturer hereby declares that the type of radio equipment used in the product complies with directive

2014/53/EU. The complete text of the EU declaration of conformity can be viewed at the manufacturer's site.

1

2

1.

Check the display of the current room temperature (1) and the set target temperature (2) in the display.

0020212897_01 Migo Operating instructions

7

4 Operation

2.

If required, use the and buttons to set the set target temperature (2) to the required value.

4.4

Installing the app

1.

You can use your smartphone or tablet to apply any settings beyond the basic functions.

2.

Use your mobile device to download the app from

http://migo.glow-worm.co.uk. Alternatively, search for

Migo on Google Play™ or in the App Store™.

3.

Install the relevant app on your mobile device.

4.

When first setting up the connection, establish a

Bluetooth connection between the product and your device (→ Page 8). Configure the WLAN settings for the product via the Bluetooth connection.

5.

Observe the additional instructions in the app.

4.5

Establishing a wireless connection

1

2

1.

Activate the Bluetooth connection on your mobile device.

2.

Press and hold the Bluetooth button/comfort protection mode button (1) on the communication unit (for at least five seconds).

◁ The status LED (2) flashes blue on the communication unit.

3.

Use the app to implement the WLAN settings. To do this, observe the instructions in the app.

– For security reasons, only connect the product to an encrypted WLAN. Note that Wi-Fi Protected Setup

(WPS) is not supported.

8

Operating instructions Migo 0020212897_01

4.6

Restoring the connection

Operation 4

4.7.1

Activating/deactivating comfort protection mode

1

2

▶ If the above display view is shown, reduce the distance between the thermostat and the communication unit in order to restore the connection.

4.7

Comfort protection mode

If the product has no connection to the Internet, the product's operating mode cannot be set using the app.

In this case, comfort protection mode can be activated directly on the communication unit.

When comfort protection mode is activated, the room temperature is regulated to the target value that is set on the thermostat, regardless of the time periods that are set. In addition, hot water is prepared, irrespective of the set time periods.

1.

Press the Bluetooth button/comfort protection mode button (1) briefly on the communication unit.

– You can only activate comfort protection mode if the

Internet connection is interrupted.

The status LED (2) lights up blue on the communication unit.

2.

Press the Bluetooth button/comfort protection mode button (1) again on the communication unit to deactivate the comfort protection mode.

0020212897_01 Migo Operating instructions

9

4 Operation

– The comfort protection mode is automatically deactivated as soon as the Internet connection is reestablished.

4.8

Checking the battery charge condition

1

If the (1) symbol appears in the thermostat display, the batteries are almost flat.

If the above display view appears on the thermostat, the batteries are flat.

▶ Replace the batteries in the thermostat.

10

Operating instructions Migo 0020212897_01

Operation 4

4.9

Replacing batteries 4.10

Start screen

A

B

1.

Remove the thermostat from the product bracket or remove the product stand from the thermostat.

2.

Insert three new batteries (they must all be the same type). Pay attention to the correct polarity.

3.

Only use AAA alkaline 1.5 V batteries. Do not use rechargeable batteries.

4.

Place the thermostat back onto the product bracket or place the product stand back onto the thermostat. The thermostat or product stand audibly click into place.

After you insert the batteries, the start screen is displayed.

The start screen shows that the thermostat is searching for the communication unit.

0020212897_01 Migo Operating instructions

11

5 Troubleshooting

If the communication unit is not found (e.g. the distance between the thermostat and the communication unit is too great), the above display view is shown.

7 Decommissioning

7.1

Permanently decommissioning the product

Have a competent person permanently decommission the product.

5 Troubleshooting

You can find an overview of the possible faults in the appendix.

Faults – Overview (→ Page 14)

8 Recycling and disposal

▶ The competent person who installed your product is responsible for the disposal of the packaging.

6 Care and maintenance

6.1

Caring for the product

Caution.

Risk of material damage caused by unsuitable cleaning agents.

▶ Do not use sprays, scouring agents, detergents, solvents or cleaning agents that contain chlorine.

Clean the surface of the product with a damp cloth and a little solvent-free soap.

If the product is identified with this symbol:

▶ In this case, do not dispose of the product with the household waste.

▶ Instead, hand in the product to a collection centre for old electrical or electronic appliances.

If the product contains batteries that are marked with this symbol, these batteries may contain substances that are hazardous to human health and the environment.

▶ In this case, dispose of the batteries at a collection point for batteries.

12

Operating instructions Migo 0020212897_01

9 Guarantee and customer service

9.1

Guarantee

For information on the manufacturer's guarantee, you can write to the contact address that is provided on the back page.

9.2

Customer service

For contact details for our customer service department, you can write to the address that is provided on the back page, or you can visit www.glow-worm.co.uk.

Guarantee and customer service 9

0020212897_01 Migo Operating instructions

13

Appendix

Appendix

A

Faults Overview

Symbol Meaning

Batteries almost flat.

Batteries flat.

No connection to the communication unit.

Remedy

Replace the batteries in the thermostat.

Replace the batteries in the thermostat.

Reduce the distance between the thermostat and the communication unit.

B Legal note

"Made for iPod", "Made for iPhone" and "Made for iPad" mean that an electronic accessory has been designed that was developed especially for the relevant connection to an iPod, iPhone or iPad, and for which the developer has certified that it complies with Apple's performance standards. Apple shall not be liable for the operation of this device or its compliance with the safety standards and regulations. Note that using this accessory with an iPhone may impair the radio performance.

14

Operating instructions Migo 0020212897_01

Publisher/manufacturer

GLOW-WORM

Nottingham Road Belper

Derbyshire DE56 1JQ

Telephone 016 34 29 23 00 – Fax 016 34 29 01 66

Technical helpline 084 4 736 00 59 – After sales service 017 73 82 81 00 www.glow-worm.co.uk

© These instructions, or parts thereof, are protected by copyright and may be reproduced or distributed only with the manufacturer's written consent.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
