Welcome

Thank You

Thank you for purchasing a JK Audio innkeeper 1x/1rx Digital Hybrid. Please read this guide for instructions on setting up and using your new product.

Getting Assistance

If you have technical or application questions:

In the US & Canada, call us toll free at: 800-552-8346

All other countries dial: 815-786-2929 (M-F 8:30-5:00pm Central Time Zone)

Email us at: [email protected]

Or, check out our FAQ section for answers to common questions.

Limited Warranty

The innkeeper 1x/1rx is covered by a 2 year warranty to be free from defective workmanship and materials. To obtain service, contact JK Audio by phone or email for return authorization. Once authorized, you will carefully pack and ship the faulty product and all accessories to us. You will pay for shipping to us and we will pay for return back to you.

This warranty does not cover damages due to accident, weather, fire, flood, earthquake, misuse, unauthorized repairs or modifications, or damages occurred in shipping, only defective workmanship or materials.

There are no expressed or implied warranties which extend beyond the warranty here made.

Warnings & Safety Precautions

• Read and keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Clean only with a soft dry cloth.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

• Do not defeat the safety purpose of the three-prong grounding type plug.

If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

• Do not use this unit if the electrical power cord is frayed or broken. The power cord should be routed so that it is not likely to be walked on or pinched by items placed upon or against it.

• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

• Refer all servicing to qualified service personnel.

ii innkeeper 1x/1rx™

Digital Hybrid

Contents

Overview

Getting to know your innkeeper 1x/1rx

2 Controls & Indicators

4 Inputs & Outputs

Getting Connected

Operation

Configuration

Optional Remote Control

Serial Port Interface

FAQs

Technical Information

Contents

1

2

11

12

13

14

6

8

9

Contents iii

Features

Features

16 bit DSP Technology

Auto-Answer (Switchable On/Off)

Proprietary Auto Null Algorithm

(50 dB null)

AGC, Ducking, Presence

1 kHz Tone Generator

Send XLR Line Input

Mic/Line Switch

Caller XLR Line Output

What’s in the Box?

Detachable North American

Power Cord

Mix Out XLR Line Output

Front Panel 1/4” Headphone Jack

Remote Control via Screw Terminals or RS-232

RIU-IP Remote IP Interface

Monitor Speaker Terminals

Send and Caller Signal Level LEDs

Send and Caller Volume Controls

CN081 Serial Port Cord

RJ11 Phone Cord

iv innkeeper 1x/1rx™

Digital Hybrid

Overview

Introducing the innkeeper 1x/1rx™

Innkeeper 1x and innkeeper 1rx will allow you to send and receive audio over analog telephone lines. While this may seem like a simple task that any telephone can do, the challenge is getting the best quality audio from such a miserable audio path.

What is a Digital Hybrid?

The innkeeper 1x/1rx digital hybrid connects audio signals to a standard analog telephone line without the variations in quality found with analog hybrids. The main function of a hybrid is to bring in the caller’s voice from the phone line as clear and clean as possible. In the real world, when you send your voice down the telephone line it has a tendency to bleed over into the caller’s audio. The hybrid must adapt to the phone line in order to properly separate transmit and receive audio. We use a 16 bit DSP (Digital Signal Processor) to continuously monitor the phone line and local audio signals to deliver excellent trans-hybrid loss, also known as separation. Our dual-convergence algorithm can achieve excellent separation, typically exceeding 50 dB.

Ready to go?

The innkeeper 1x/1rx controls and connectors are clearly marked and ready for operation. If this is your first exposure to a hybrid, we suggest that you read the entire manual to allow you to take advantage of all these features.

Any Questions?

Before you pick up the phone... Please thumb through the rest of this manual.

You might find those deep technical questions are covered on later pages.

Overview

1

Getting to Know Your innkeeper 1x/1rx

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17

2

Controls & Indicators

1.

Call Button

Takes the line off-hook; press this button to answer a call or you can direct a call from your aux phone through the hybrid.

2.

3.

4.

5.

6.

7.

Drop Button

Press this button to drop (hang up) a call.

Send Level

Adjusts the signal that you are sending down the telephone line.

Caller Level

Adjusts the level of the incoming caller’s audio as it is going out the output jacks. If the incoming caller level is too high and peaking the red -3 dB

LED, you may need to change the setting of an internal jumper. Please see

Optional Jumper Settings on page 9.

Send-to-Mix Level

Adjust the level of your audio that will be sent to the <Mix Out> jack.

Caller-to-Mix Level

Adjust the level of caller audio that will be sent to the <Mix Out> jack.

Headphones

The stereo headphone jack contains the signal you have created with the

<Send-to-Mix> and <Caller-to-Mix> level controls. Both left and right channels get the same signal.

innkeeper 1x/1rx™

Digital Hybrid

Getting to Know Your innkeeper 1x/1rx

Indicators Cont’d

8.

Mix Monitor

Adjusts the mix signal level sent to the headphone and rear panel speaker terminals.

9.

Power LED

Lit when unit is plugged in and receiving power.

10.

Ring LED

Flickers when you have an incoming call.

11.

OH LED

Lit when you are on line with a call (off-hook).

12.

Signal LEDs

Send LEDs represent the signal level going out to the telephone line.

Receive LEDs represent the signal level coming from the phone line, after the DSP.

13.

AGC - Automatic Gain Control

When enabled, automatically adjusts the gain of caller audio so all callers are received at an average level.

14.

Caller Ducking

When enabled, innkeeper 1x/1rx lowers the caller’s audio level by 9 dB when local audio is present.

15.

Presence

When enabled, this feature boosts the low end of the caller audio signal.

Presence is added to the caller audio signal only.

16.

1 kHz Tone Generator

Press button once to send a full scale 0 dB, maximum output level 1kHz tone down the phone line. Press again to send this signal out the Caller jack. Press a third time to turn off.

17.

Auto-Answer

When enabled, innkeeper automatically answers an incoming call and then disconnects after the caller hangs up. Auto answer will occur on the first ring.

Controls & Indicators

3

Getting to Know Your innkeeper 1x/1rx

1 2 3 4 5 6 7 8 9

Inputs & Outputs

1.

Phone Line

Connect to a standard, single line, analog telephone line.

2.

3.

Aux Phone

Connect a single line analog telephone for call setup / dialing, or producer call screening.

Caller Output

Male balanced XLR line-level output contains only the callers voice.

4.

5.

6.

Mix Output

Male balanced XLR line-level output contains a mix of send and receive audio determined by the <Send-to-Mix> and <Caller-to-Mix> level controls.

Mic / Line switch

Sets the front end sensitivity of the Send XLR jack. Set to <Mic> if you intend to connect a dynamic microphone directly to the <Send> jack. Set to

<Line> if you are connecting to the output of a mixer. This device does not provide phantom power for a condenser type microphone.

Send Input

Female balanced XLR input for signals going into the phone line.

Mic or line level input.

4 innkeeper 1x/1rx™

Digital Hybrid

Getting to Know Your innkeeper 1x/1rx

Inputs & Outputs Cont’d

7.

Remote Control Jack

10 pin RJ-50 modular jack for connection to:

A. RS-232 Cable (Included)

B. JK Audio RIU-IP Remote Interface

C. JK Audio Guest Module 1 Remote Keypad

D. JK Audio Concierge Switch Core

8.

9.

Remote Terminals

Screw terminals provide connections for a small speaker, remote LEDs, tape recorder control, or console call control switches.

1. Speaker (+)

2. Speaker (-)

3. Ring LED

Minimum 8 ohms, 1 watt max

Use together with terminal 1

Supplies +4.3 VDC,

40 mA pulse signal during incoming ring cycles.

4. Chassis Ground

5. OH LED

6. Call (NO)

7. Drop (NO)

Supplies +4.3 VDC,

40 mA steady signal during an active call.

Pull this pin to ground momentarily to simulate pressing the <Call> button.

Pull this pin to ground momentarily to simulate pressing the <Drop> button.

8. Reserved

Power Jack

Universal AC power input for 100-240 Volt, 50-60 Hz supply current.

Inputs & Outputs

5

Getting Connected

Setting Up

1. Connect the supplied RJ-11 phone line cable between the jack marked

<Line> and your wall jack. Be sure this jack supports standard single line analog telephone operation.

2. Connect to your mixer using the Mix-Minus method. See Figure 7a.

A mix-minus signal is an audio signal that contains a mix of your local microphones plus any other audio, minus the Caller’s own voice. Sending the Caller’s audio back to the innkeeper 1x/1rx will cause an echo, or feedback.

1. Connect a microphone or mixing console output XLR cable to the

<Send> jack on the innkeeper. Be sure to set the innkeeper <Mic/Line> switch to the proper position for your application.

2. Connect the <Caller> jack to a line level input on your mixing console.

For whichever input channel you have the <Caller> connected to on the mixer, turn the corresponding <Aux> control to minimum. All other

<Aux> controls should be set for audio sent to the phone line. Each

<Aux Send> bus is completely separate from all other outputs, so these Aux controls will not affect what is heard on the Main outputs or on any other Aux buses. We recommend using an <Aux Send> bus that is pre-fader, so you can use the fader controls to set the levels of each channel to the main output without affecting what is sent to the phone line. If your mixer does not have an <Aux Send> bus, you can use <Pan> controls with the Left and Right outputs. Pan all the microphones, etc. to the Left output and pan the Caller to the Right output. Then connect only the <Left> output to the innkeeper 1x/1rx

<Send>. Or, you may use an external Mix-Minus box that will create this signal for you.

3. Connect the supplied AC power cord to the back of the innkeeper and then to an AC power outlet.

Your innkeeper 1x/1rx is now ready to take calls. You may want to connect an auxiliary telephone to the innkeeper <Phone> jack so you can dial out and set up calls, or use the <Auto-Answer> feature to answer incoming calls.

Place a test call to a quiet location. Set the <Send> level control so that while you are speaking into the microphone, the Send LEDs on the hybrid light the -20 dB green LED consistently and flash the -9 dB green LED. If you flash the -3 dB red LED, lower the level. Set the <Caller> control for good recording level of the caller audio at the output jack.
