TIBCO iProcess Modeler Basic Design

TIBCO iProcess Modeler Basic Design

TIBCO iProcess

®

Modeler

Basic Design

Software Release 11.5

April 2015

Two-Second Advantage

®

Important Information

SOME TIBCO SOFTWARE EMBEDS OR BUNDLES OTHER TIBCO SOFTWARE. USE OF SUCH EMBEDDED

OR BUNDLED TIBCO SOFTWARE IS SOLELY TO ENABLE THE FUNCTIONALITY (OR PROVIDE LIMITED

ADD-ON FUNCTIONALITY) OF THE LICENSED TIBCO SOFTWARE. THE EMBEDDED OR BUNDLED

SOFTWARE IS NOT LICENSED TO BE USED OR ACCESSED BY ANY OTHER TIBCO SOFTWARE OR FOR

ANY OTHER PURPOSE.

USE OF TIBCO SOFTWARE AND THIS DOCUMENT IS SUBJECT TO THE TERMS AND CONDITIONS OF A

LICENSE AGREEMENT FOUND IN EITHER A SEPARATELY EXECUTED SOFTWARE LICENSE

AGREEMENT, OR, IF THERE IS NO SUCH SEPARATE AGREEMENT, THE CLICKWRAP END USER

LICENSE AGREEMENT WHICH IS DISPLAYED DURING DOWNLOAD OR INSTALLATION OF THE

SOFTWARE (AND WHICH IS DUPLICATED IN THE LICENSE FILE) OR IF THERE IS NO SUCH SOFTWARE

LICENSE AGREEMENT OR CLICKWRAP END USER LICENSE AGREEMENT, THE LICENSE(S) LOCATED

IN THE “LICENSE” FILE(S) OF THE SOFTWARE. USE OF THIS DOCUMENT IS SUBJECT TO THOSE TERMS

AND CONDITIONS, AND YOUR USE HEREOF SHALL CONSTITUTE ACCEPTANCE OF AND AN

AGREEMENT TO BE BOUND BY THE SAME.

This document contains confidential information that is subject to U.S. and international copyright laws and treaties. No part of this document may be reproduced in any form without the written authorization of TIBCO

Software Inc.

TIBCO, Two-Second Advantage, TIBCO ActiveMatrix BusinessWorks, TIBCO Business Studio, TIBCO

Enterprise Message Service, TIBCO Hawk, TIBCO iProcess, TIBCO iProcess Suite, and TIBCO Rendezvous are either registered trademarks or trademarks of TIBCO Software Inc. in the United States and/or other countries.

Enterprise Java Beans (EJB), Java Platform Enterprise Edition (Java EE), Java 2 Platform Enterprise Edition

(J2EE), and all Java-based trademarks and logos are trademarks or registered trademarks of Oracle Corporation in the U.S. and other countries.

All other product and company names and marks mentioned in this document are the property of their respective owners and are mentioned for identification purposes only.

THIS SOFTWARE MAY BE AVAILABLE ON MULTIPLE OPERATING SYSTEMS. HOWEVER, NOT ALL

OPERATING SYSTEM PLATFORMS FOR A SPECIFIC SOFTWARE VERSION ARE RELEASED AT THE SAME

TIME. SEE THE README FILE FOR THE AVAILABILITY OF THIS SOFTWARE VERSION ON A SPECIFIC

OPERATING SYSTEM PLATFORM.

THIS DOCUMENT IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY,

FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT.

THIS DOCUMENT COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL ERRORS.

CHANGES ARE PERIODICALLY ADDED TO THE INFORMATION HEREIN; THESE CHANGES WILL BE

INCORPORATED IN NEW EDITIONS OF THIS DOCUMENT. TIBCO SOFTWARE INC. MAY MAKE

IMPROVEMENTS AND/OR CHANGES IN THE PRODUCT(S) AND/OR THE PROGRAM(S) DESCRIBED IN

THIS DOCUMENT AT ANY TIME.

THE CONTENTS OF THIS DOCUMENT MAY BE MODIFIED AND/OR QUALIFIED, DIRECTLY OR

INDIRECTLY, BY OTHER DOCUMENTATION WHICH ACCOMPANIES THIS SOFTWARE, INCLUDING

BUT NOT LIMITED TO ANY RELEASE NOTES AND "READ ME" FILES.

Copyright © 1994-2015 TIBCO Software Inc. ALL RIGHTS RESERVED.

TIBCO Software Inc. Confidential Information

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

TIBCO iProcess Modeler Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Other TIBCO Product Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Typographical Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Connecting with TIBCO Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

How to Join TIBCOmmunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

How to Access TIBCO Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

How to Contact TIBCO Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

Chapter 1 Defining a Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Placing Procedure Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Selecting Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Editing Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Linking Procedure Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

A Normal Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

A Withdraw Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

A Deadline Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

A Deadline Withdraw Link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Routing the Business Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Assigning Addressees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Single-User Addressees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Multiple User or Group Addressees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Roles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Defining Step Status Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Enabling Steps to be Forwarded. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Enabling the Contents of a Form to be Copied. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Stop Work Items Being Deleted on Withdraw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Preventing a Case from Being Suspended. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chapter 2 Creating Fields and Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

About iProcess Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

What are Single Instance Fields? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

What are Array Fields? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

TIBCO iProcess Modeler Basic Design

|

iii

iv

| Contents

Defining Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Creating a Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Inserting Fields into Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Editing Marked Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Defining Field Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using Embedded and Ampersanded Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Marking Application Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Removing Fields From Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Using Conditional Text to Dynamically Change a Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Inserting a Use File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using Form Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Editing Your Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Changing the Form Type of a Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 3 Controlling Data Input On Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Using Field Validations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Copying Field Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Using Field Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Conditional Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Calculating Text Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Calculating the Case Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Using Delimiters and Key Words. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using iProcess Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Defining a Table Field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Marking Table Fields in your Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Chapter 4 Using Deadlines in Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Defining a Deadline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Drawing the Deadline Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Using Deadlines on a Sub-Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Dynamically Recalculating Deadlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Chapter 5 Using Conditional Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Defining a Conditional Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Chapter 6 Withdrawing Steps From the Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Example of Using a Withdraw Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Defining a Withdraw Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Defining a Deadline Withdraw Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Defining a Withdraw Action on a Sub-Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

TIBCO iProcess Modeler Basic Design

Contents |

v

Chapter 7 Defining Waits in the Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Example of Using a Wait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Defining a Wait Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

How the iProcess Engine Processes Waits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Viewing Step Status on the TIBCO iProcess Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Using Waits in Loops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Using Waits with Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Using Waits with Withdraw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Chapter 8 Making Procedures Easier to Follow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

Setting TIBCO iProcess Modeler Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Using Swim Lanes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Enabling Swim Lanes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Swapping Between Swim Lane Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Configuring Swim Lanes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Changing Step Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Annotating Procedures for Clarity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Changing the Object Label Position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Working with Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Setting Link Labels and Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Changing Link Styles and Animation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Using Routers to Simplify Visual Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Using Complex Routers to Simplify Procedure Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Using GOTOSTEP to Simplify the Procedure Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Zooming In and Out of a Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Changing Procedure Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Using the Snap-To Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Saving a Procedure as an Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Chapter 9 Customizing the Process Step Definer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115

Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Select Font. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Dynamic Scroll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Show Field Names. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Line Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Nesting Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

TIBCO iProcess Modeler Basic Design

vi

| Contents

Appendix A Troubleshooting Procedure Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

An Under Construction Symbol Appears on a Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Changing the Currency Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

TIBCO iProcess Modeler Basic Design

Preface

This guide explains and demonstrates the basic principles of procedure design using a combination of the following products:

• TIBCO iProcess

®

Workspace (Windows)

• TIBCO iProcess Modeler

|

vii

Topics

Related Documentation, page viii

Typographical Conventions, page x

Connecting with TIBCO Resources, page xiii

TIBCO iProcess Modeler Basic Design

viii

| Related Documentation

Related Documentation

This section lists documentation resources you may find useful.

TIBCO iProcess Modeler Documentation

The following documents form the TIBCO TIBCO iProcess Modeler and TIBCO iProcess Workspace (Windows) documentation set, which are supplied with the

TIBCO iProcess Workspace (Windows) software:

TIBCO iProcess Workspace (Windows) Installation Read this manual for

instructions on site preparation and installation.

TIBCO iProcess Workspace (Windows) Release Notes Read the release notes for a

list of new and changed features. This document also contains lists of known issues and closed issues for this release.

• TIBCO iProcess Suite Documentation This documentation set contains all the manuals for TIBCO TIBCO iProcess Modeler, TIBCO iProcess

®

Workspace

(Windows), and other TIBCO products in TIBCO iProcess

®

Suite. The manuals for TIBCO TIBCO iProcess Modeler and TIBCO iProcess Workspace

(Windows) are as follows:

— TIBCO iProcess Workspace (Windows) User’s Guide

— TIBCO iProcess Modeler Getting Started

— TIBCO iProcess Modeler Procedure Management

— TIBCO iProcess Modeler Basic Design

— TIBCO iProcess Modeler Advanced Design

— TIBCO iProcess Modeler Integration Techniques

— TIBCO iProcess Expressions and Functions Reference Guide

— TIBCO iProcess Workspace (Windows) Manager’s Guide

TIBCO iProcess Modeler Basic Design

Preface |

ix

If you are new to iProcess procedure development, you are advised to follow the reading path shown next. The documentation road map shows the relationships between the books and online references in this product’s documentation set.

Getting

Started

Procedure

Management

Basic Design

Advanced

Design

Integration

Techniques

Legend

PDF HTML Eclipse help Eclipse cheat sheet

Other TIBCO Product Documentation

You may find it useful to read the documentation for the following TIBCO products:

• TIBCO ActiveMatrix BusinessWorks™

• TIBCO Business Studio™

• TIBCO Enterprise Message Service™

• TIBCO Hawk

®

• TIBCO Rendezvous

®

TIBCO iProcess Modeler Basic Design

x

| Typographical Conventions

Typographical Conventions

The following typographical conventions are used in this manual.

Table 1 General Typographical Conventions

Convention

SWDIR

Use

TIBCO iProcess Engine installs into a directory. This directory is referenced in documentation as

SWDIR

. The value of

SWDIR

depends on the operating system.

For example,

• on a Windows server (on the

C:

drive) if

SWDIR

is set to the

C:\swserver\staffw_nod1

directory, then the full path to the swutil

command is in the

C:\swserver\staffw_nod1\bin\swutil directory.

• on a UNIX or Linux server if

SWDIR

is set to the

/swserver/staffw_nod1

directory, then the full path to the swutil

command is in the

/swserver/staffw_nod1/bin/swutil directory or the

$

SWDIR

/bin/swutil

directory.

Note

: On a UNIX or Linux system, the environment variable $

SWDIR

should be set to point to the iProcess system directory for the

root

and

swadmin

users. code font

bold code font

Code font identifies commands, code examples, filenames, pathnames, and output displayed in a command window. For example:

Use

MyCommand

to start the foo process.

Bold code font is used in the following ways:

• In procedures, to indicate what a user types. For example: Type

admin

.

• In large code samples, to indicate the parts of the sample that are of particular interest.

• In command syntax, to indicate the default parameter for a command. For example, if no parameter is specified,

MyCommand

is enabled:

MyCommand [enable | disable]

TIBCO iProcess Modeler Basic Design

Preface |

xi

Table 1 General Typographical Conventions (Cont?)

Convention

italic font

Use

Italic font is used in the following ways:

• To indicate a document title. For example: See TIBCO ActiveMatrix

BusinessWorks Concepts.

• To introduce new terms. For example: A portal page may contain several portlets. Portlets are mini-applications that run in a portal.

• To indicate a variable in a command or code syntax that you must replace.

For example:

MyCommand

PathName

Key combinations

Key name separated by a plus sign indicate keys pressed simultaneously. For example: Ctrl+C.

Key names separated by a comma and space indicate keys pressed one after the other. For example: Esc, Ctrl+Q.

The note icon indicates information that is of special interest or importance, for example, an additional action required only in certain circumstances.

The tip icon indicates an idea that could be useful, for example, a way to apply the information provided in the current section to achieve a specific result.

The warning icon indicates the potential for a damaging situation, for example, data loss or corruption if certain steps are taken or not taken.

Table 2 Syntax Typographical Conventions

Convention

[ ]

Use

An optional item in a command or code syntax.

For example:

MyCommand [optional_parameter] required_parameter

| logical

For example, you can select only one of the following parameters:

MyCommand param1 | param2 | param3

TIBCO iProcess Modeler Basic Design

xii

| Typographical Conventions

Table 2 Syntax Typographical Conventions (Cont?)

Convention

{ }

Use

A logical group of items in a command. Other syntax notations may appear within each logical group.

For example, the following command requires two parameters, which can be either the pair param1

and param2

, or the pair param3

and param4

.

MyCommand {param1 param2} | {param3 param4}

In the next example, the command requires two parameters. The first parameter can be either param1

or param2

and the second can be either param3

or param4

:

MyCommand {param1 | param2} {param3 | param4}

In the next example, the command can accept either two or three parameters.

The first parameter must be param1

. You can optionally include param2

as the second parameter. And the last parameter is either param3

or param4

.

MyCommand param1 [param2] {param3 | param4}

TIBCO iProcess Modeler Basic Design

Preface |

xiii

Connecting with TIBCO Resources

How to Join TIBCOmmunity

TIBCOmmunity is an online destination for TIBCO customers, partners, and resident experts. It is a place to share and access the collective experience of the

TIBCO community. TIBCOmmunity offers forums, blogs, and access to a variety of resources. To register, go to http://www.tibcommunity.com

.

How to Access TIBCO Documentation

You can access TIBCO documentation here: http://docs.tibco.com

How to Contact TIBCO Support

For comments or problems with this manual or the software it addresses, contact

TIBCO Support as follows:

• For an overview of TIBCO Support, and information about getting started with TIBCO Support, visit this site: http://www.tibco.com/services/support

• If you already have a valid maintenance or support contract, visit this site: https://support.tibco.com

Entry to this site requires a user name and password. If you do not have a user name, you can request one.

TIBCO iProcess Modeler Basic Design

xiv

| Connecting with TIBCO Resources

TIBCO iProcess Modeler Basic Design

Chapter 1

Defining a Procedure

This chapter describes the different types of procedure objects you can use to define your procedure and how to link them together. Each procedure object performs a specific task such as displaying a form for a user to fill out or updating information on an external system.

|

1

Topics

Placing Procedure Objects, page 2

Selecting Objects, page 5

Editing Objects, page 6

Linking Procedure Objects, page 7

Routing the Business Process, page 9

Defining Step Status Options, page 13

TIBCO iProcess Modeler Basic Design

2

| Chapter 1 Defining a Procedure

Placing Procedure Objects

The TIBCO iProcess Modeler Tool Bar shows the different objects that are available to the procedure definer. These are:

Object

Pointer

Router

Complex

Router

Step

Script

Event

Description

This is the default tool. It is used to select objects that have been added to a procedure.

After selecting, they can be moved or deleted.

Double-clicking an object in a procedure with the pointer tool displays the Step Definition dialog.

The router is used when you want a line to follow a particular route between two objects to improve clarity. When drawing a line between two objects, right-click to place a router at the cursor position. There is no toolbar icon for the router.

The complex router is a modeling object used to simplify complicated procedures. There are several ways of using the complex router. For more information see

Using Complex Routers to Simplify Procedure Logic on page 107

.

The Step is the most frequently used object. It allows you to define a step to display, specify an addressee to whom the step should be sent, and optionally a deadline by which the step

(work item) must be completed.

Scripts can be created and run from the business process definition. See “Using

Scripts” in TIBCO iProcess Modeler- Advanced

Design guide for more information about

creating scripts.

Events enable the flow of a case to be controlled and the data associated with it to be changed, externally to iProcess. For more information, see “Using Events” in the TIBCO

iProcess Modeler - Integration Techniques guide.

TIBCO iProcess Modeler Basic Design

Object

Condition

Wait

Stop

Annotation

Subprocedure

Dynamic

Sub-procedure

Placing Procedure Objects |

3

Description

A condition is a decision point in the business process. For example, in a form where approval has to be given or refused, the approval field can be interrogated and the business process will branch depending on the value of the field. For more information, see

Defining a Conditional Action on page 60

.

A wait is a synchronization point in a business process where parallel paths join together

again. For more information, see Defining a

Wait Action on page 71 .

A stop indicates the end of that branch of the procedure, or the end of a branch of the procedure. It is optional but does help to clarify the business process definition in the iProcess Modeler.

Selecting this object enables you to enter text to document your procedure.

The sub-procedure tool allows you to specify a call to a new or existing sub-procedure. For more information, see “Defining a Call to a

Static Sub-Procedure” in the

TIBCO iProcess

Modeler - Advanced Design

guide.

The dynamic sub-procedure tool is used to specify a call to one or more sub-procedures.

The sub-procedures that are run are only determined when a case of the procedure is run.

For more information, see “Defining a

Dynamic Call to Multiple Sub-Procedures” in the TIBCO iProcess Modeler - Advanced Design guide.

TIBCO iProcess Modeler Basic Design

4

| Chapter 1 Defining a Procedure

Object

Graft

EIS Report

Start

EAI Step

Align

Horizontal

Align

Vertical

Layout

Procedure

Snap

TIBCO iProcess Modeler Basic Design

Description

The graft tool is used when you want to start sub-procedures from an external application and attach them to the main procedure.

For more information, see the TIBCO iProcess

Modeler - Integration Techniques guide.

The EIS Report allows you to define a report based on the field values held in the cases of your procedure. See TIBCO iProcess Workspace

(Windows) Manager’s Guide

for more information.

The Start object is not on the tool bar but is always present when you open the TIBCO iProcess Modeler. It indicates the start of the procedure.

The Enterprise Application Integration (EAI) step enables you to interact with third party software systems such as relational databases or legacy systems. Different types of EAI step are used to interact with specific applications, for example, the SQL EAI step is used to interact with a SQL Server. Refer to “Using

EAI Steps” in the TIBCO iProcess Modeler -

Integration Techniques guide for more

information.

The Align horizontal tool horizontally aligns all selected objects with the currently focused object.

The Align vertical tool vertically aligns all selected objects with the currently focused object.

The Layout Procedure tool changes the chart orientation from left-to-right to top-down.

The Snap tool snaps the selected objects to the nearest grid square.

Selecting Objects |

5

Selecting Objects

You can click an object with the pointer tool to select a single object. To select multiple objects, lasso the objects by clicking and dragging the cursor over the objects. You can also select multiple objects using the CTRL key. Click an object, then hold the CTRL key while you click the next object. Both objects are selected.

TIBCO iProcess Modeler Basic Design

6

| Chapter 1 Defining a Procedure

Editing Objects

The following table contains a list of edit commands and descriptions.

Command

Copy

Cut

Paste

Move

Description

Select one or more objects in the procedure and click or

Edit > Copy

. The selected items are copied to the clipboard.

Select one or more objects in the procedure and click

Edit > Cut

. The selected items are removed from the procedure and placed on the clipboard.

or

After selecting the items and clicking or , click , then click the target location in a procedure and the selected items are pasted. To cancel the Paste operation, press Escape.

Depending on the number of steps being pasted and the type of conflicts that occur, a Wizard might be displayed to guide you through the Paste operation.

Select one or more objects in the procedure and drag the selected objects to the new location within the procedure. To cancel the Move operation, press Escape.

TIBCO iProcess Modeler Basic Design

Linking Procedure Objects |

7

Linking Procedure Objects

The link tool is automatically selected when you move the cursor near an object that supports links. To cancel a link operation, press Escape.

The way in which you link procedure objects dictates the action that is carried out in a procedure flow. In some circumstances, you might want a procedure map to flow from right-to-left or top-to-bottom instead of the default flow of left-to-right.

In a horizontal (left-to-right) procedure flow (unless the object side is already used for a different purpose):

• A release action link can be started from the right or left side of an object.

• A deadline action link can be started from the bottom or top of an object.

• A process step link can be ended on the left or right side of an object.

• A withdraw step link can be ended on the top or bottom of an object.

In a vertical (top-to-bottom) procedure flow (unless the object side is already used for a different purpose):

• A release action link can be started from the bottom or top of an object.

• A deadline action link can be started from the right or left of an object.

• A process step link can be ended on the top or bottom of an object.

• A withdraw step link can be ended on the left or top of an object.

When you move the cursor to the side of an object, the default link action appears as a tool tip (after a short delay). To override the default, press the ALT key. When ending a link, you can override the default end-of-link type by pressing the

SHIFT

key.

Each type of link is described fully in the following sections. See Working with

Links on page 101 for more information.

A Normal Link

In a normal link, the second step is an action that is carried out when the first step is released.

TIBCO iProcess Modeler Basic Design

8

| Chapter 1 Defining a Procedure

A Withdraw Link

A withdraw link means that the step being connected to will be withdrawn from the work queue. For example, you might have two steps that are sent out in parallel but only one needs to be actioned and released. In that instance you can

use a withdraw link to withdraw the second, now superfluous, step. See Defining a Withdraw Action on page 65 for more information.

A Deadline Link

When you have a step that a user must release by a certain date and time or within a specific time period, you can put a deadline on the step so that another

action (step) is carried out if the deadline expires. See Defining a Deadline on page 52 .

A Deadline Withdraw Link

Combining a deadline and a withdraw link allows you to withdraw a step when a deadline expires.

TIBCO iProcess Modeler Basic Design

Routing the Business Process |

9

Routing the Business Process

Routing the business process tasks is achieved by the use of addressees. There are different types of addressees that you can use to route the business process.

Every step that is to be delivered to a work queue must have an addressee. The addressee is the user who is responsible for completing the work item.

Assigning Addressees

For a detailed explanation of how to assign an addressee to a step, see the TIBCO

iProcess Modeler - Getting Started guide.

Single-User Addressees

A step can have a single addressee.

TIBCO iProcess Modeler Basic Design

10

| Chapter 1 Defining a Procedure

If you want a step to go to one specific user, enter a user name in the Users column. To see a list of all users on your iProcess installation, click List Users.

Highlight the user(s) you want to add to the list of addressees and click Add to

List

. An alternative is to use the special assignment of sw_starter. This will route a work item to the user who started that particular case.

Users must have been previously added to the iProcess installation. You can do this using the User Manager in the TIBCO iProcess Administrator. For more information, see “Managing iProcess Users” in TIBCO iProcess Workspace

(Windows) Manager’s Guide.

Multiple User or Group Addressees

If you have a step that you want to send to more than one user, you can either use groups or multiple users.

Like users, groups must have been previously added to the iProcess installation.

For multiple users, enter all the user names in the Users column. A copy of the step will be sent to each user listed. This can be a useful way of sending the same information to a number of people. Each user is responsible for releasing their copy of the work item and the procedure will only progress when all users have released the work item.

Alternatively, a group can be entered in the Users column and the work item will be sent to that group queue. For details on how to set up a group, see “Managing

Groups” in TIBCO iProcess Workspace (Windows) Manager’s Guide. When a work item goes to a group queue, any member of the group may open the work item, complete any input fields and release it. When the work item is open, it appears as a grayed out entry in the group queue of the other group members who are prevented from opening the item. Once the work item is released, it disappears from the other members’ group queues.

TIBCO iProcess Modeler Basic Design

Roles

Routing the Business Process |

11

A role is a job title or function and is unique to a particular user or group. A step can be addressed to a role as shown in the following example. Multiple roles can be entered in the Roles column.

It is often better to specify a role rather than a particular user name so that if a user leaves the company or is promoted, it is not necessary to amend the procedure as the work items will automatically be sent to the new user who holds that role. For information on how to assign roles to users, see “Managing Roles” in TIBCO iProcess Workspace (Windows) Manager’s Guide.

TIBCO iProcess Modeler Basic Design

12

| Chapter 1 Defining a Procedure

Fields

You can incorporate a field into your procedure so that the name of a user, group or role can be entered into the field at run time. That field can then be used as an addressee in subsequent steps to decide the routing of the business process. As for users and roles, multiple fields can be entered in the Fields column.

This is called dynamic routing, or variable addressees, as it gives you the flexibility to route a step based on case data instead of using hard-coded addressees.

A field can contain a comma-separated list of addressees.

TIBCO iProcess Modeler Basic Design

Defining Step Status Options |

13

Defining Step Status Options

The following sections describe the step status options you can configure for each step in your procedure:

Enabling Steps to be Forwarded on page 13

Enabling the Contents of a Form to be Copied on page 13

Stop Work Items Being Deleted on Withdraw on page 14

Preventing a Case from Being Suspended on page 14 .

Using Form Commands on page 34

.

Information about setting the step priority is described in “Setting Priority at Step

Level” in the TIBCO iProcess Modeler - Advanced Design guide.

Enabling Steps to be Forwarded

If you want to enable users to forward a step to other users, you need to enable the Forward permission for that step:

1. Right-click the Step and click Status.

2. In the Permissions group box, click Forward. Click OK.

When the Forward permission is checked, the user who receives this work item in their queue may forward it to another user. See “Forwarding Work Items from a

Queue” in TIBCO iProcess Workspace (Windows) User’s Guide and TIBCO iProcess

Workspace (Windows) Manager’s Guide

for more information on forwarding work items, and the QSUPERVISOR and USERFLAG attributes that need to be used to define the correct user permissions.

Enabling the Contents of a Form to be Copied

If you want to enable users to copy the entire contents of a form for a work item they receive, you need to enable the Edit permission for the step:

1. Right-click the Step and click Status.

2. In the Permissions group box, click Edit. Click OK.

Users can then copy the form contents (including field data) by choosing Copy

All

from the Form Edit menu.

TIBCO iProcess Modeler Basic Design

14

| Chapter 1 Defining a Procedure

Stop Work Items Being Deleted on Withdraw

Select the Don’t delete work items on withdraw option. If this option is selected, and the deadline on an outstanding step expires or it is withdrawn as an action

(release or deadline expire) of another step:

• the deadline actions are processed.

• the step remains outstanding (the step remains in the work queue or the sub-procedure case is not purged).

• when the step is released (or the sub-procedure case completes) the normal release actions are not processed but the case field data associated with the release step (e.g. the field values set in a normal step whilst in a work queue or the output parameters of a sub-case) is applied to the main case data.

Preventing a Case from Being Suspended

The Ignore Case Suspend check box determines whether or not the step is still processed when a case is suspended by an iProcess Objects or SAL application:

• If Ignore Case Suspend is not checked (the default option), the step is not

processed while the case is suspended. This means that:

— work items generated by the step are marked as unavailable and cannot be opened (until the case is re-activated).

— deadlines on work items generated by the step are not processed. The date and time at which deadlines are due is not affected, and deadlines continue to expire. However, no actions are processed when a deadline expires.

When the case is re-activated, any expired deadlines are immediately processed.

• If Ignore Case Suspend is checked, the step is still processed as normal while the case is suspended. This means that:

— work items generated by the step can still be opened.

— deadlines on work items generated by the step are still processed.

Cases can only be suspended and re-activated from an iProcess Objects or SAL application. Audit trail messages indicate whether a case is active or suspended. Refer to the iProcess Objects documentation for more information about suspending cases.

TIBCO iProcess Modeler Basic Design

Chapter 2

Creating Fields and Forms

This chapter describes how to use and create fields in iProcess and then use the

Process Step Definer to create forms.

|

15

Topics

About iProcess Fields, page 16

Defining Fields, page 18

Creating a Form, page 21

TIBCO iProcess Modeler Basic Design

16

| Chapter 2 Creating Fields and Forms

About iProcess Fields

Fields are used in iProcess to store business data related to a case of a procedure such as customer names, order values and stock items. The data can be manipulated by iProcess as the case progresses - for example, adding fields together to get a total price of an order or concatenating the contents of a surname field and a forename field.

There are a number of iProcess system fields already defined (such as

SW_STARTER and SW_CASEDESC) but you need to create fields that are relevant to the information you need to capture in your process. For example, if you are capturing order details, you will need to create fields for the customer’s name, account number, delivery address, order value, and so on.

These fields can be added to a form which the user completes when they receive the work item in their work queue. After releasing the work item, the data stored in the field is saved.

There are two types of field you can use: single instance or array. A single instance field is a field that contains just one element of data - for example, a name. An array field can contain multiple elements of data - for example, 10 names.

What are Single Instance Fields?

For the majority of fields you create, you will use single instance fields. This means that just one data element will be stored in the field. For example, in a field that you have defined called CUSTNAME, a name of Jane Doe could be stored in one case. You can use expressions and functions to manipulate field data, for example, concatenating data or summing totals.

What are Array Fields?

Array fields are defined in the same way as single instance fields but they enable you to store more than one piece of data in them. For example, an array field called CUSTNAME could store the names of several customers instead of just one.

When using dynamic sub-procedure calls and graft steps, you need to use array fields to provide the multiple data elements required for each sub-case that will be started. For example, you might have a procedure in which a separate sub-procedure needs to be run for each type of account the customer has. During a case of the procedure, the customer indicates that they have three accounts so the ACCOUNT array field will be populated with the names of the three accounts.

TIBCO iProcess Modeler Basic Design

About iProcess Fields |

17

If a dynamic sub-procedure call has been defined so that one sub-procedure is run for each account that a user holds, three sub-cases will be started. Each sub-case is passed a unique account number from the ACCOUNT array field.

Refer to “Using Array Fields” in the TIBCO iProcess Modeler - Advanced Design guide for more detailed information about array fields.

TIBCO iProcess Modeler Basic Design

18

| Chapter 2 Creating Fields and Forms

Defining Fields

A field must be defined before you can use it in forms, scripts, EAI steps, etc. You can either define your fields from the TIBCO iProcess Modeler before creating individual steps in your procedure, or you can create fields as you need them when creating forms. To define a field:

1. Click Field > Definition in the TIBCO iProcess Modeler (or Field > Define from the Process Step Definer).

The Field Definition dialog is displayed showing the Single Instance tab.

To define single instance fields, continue to step 2. To define array fields, click the Array tab before continuing to step 2.

2. In the Field Name box, enter a name for the field. Please note the following:

— Field names can be up to 15 characters long and can contain letters, digits and underscore characters but they must start with a letter. Field names are converted to uppercase irrespective of how they are originally entered.

— Array field names can be up to 8 characters. When you set the length value this determines the length for each array element. Refer to “Using Array

TIBCO iProcess Modeler Basic Design

Defining Fields |

19

Fields” in the TIBCO iProcess Modeler - Advanced Design guide for more information about using arrays.

— Do not create a field with the same name as a system field (e.g.

SW_CASEREF). iProcess does not allow you to select the new field or use it in your form as it will always default to the original system field.

It is not possible to change an existing field between single instance and array.

3. Select a Field Type. The available options are:

Field Type

Text

Numeric

Comma

Separated

Numeric

Date

Time

Memo

Description

Any characters can be entered up to the length you select (maximum 255 characters).

Any number, positive or negative, up to the length and number of decimals you select (maximum length 18 including decimals, decimal point and sign, with no more than 8 decimals).

As numeric but iProcess automatically displays commas to separate the thousands, for example 1,234,567.89.

A date, defaulting to the format dd/mm/yyyy although this can be changed by your iProcess Administrator.

CAUTION - You must make changes to the date format before cases are started.

Doing so while the system has live case data will corrupt the data.

A time (24 hour clock) in the format hh:mm

Large amounts of text (stored in a separate file).

TIBCO iProcess Modeler Basic Design

20

| Chapter 2 Creating Fields and Forms

Field Type

Composite

Description

The field refers to an iProcess Table, which is selected in the Tables box. (Creating a composite field creates an instance of that table’s record definition within the procedure, from which table sub-fields can be accessed.)

4. If you want to change the field length, click in the Length box at the bottom of the window.

5. Click Add. The field details you entered are saved and you can define another field.

The length of a numeric field includes the decimal point and decimal places, for example, a length of 8 with 2 decimal places gives us 00000.00.

6. Click OK when you have finished adding fields.

TIBCO iProcess Modeler Basic Design

Creating a Form |

21

Creating a Form

You can find detailed information on how to create a basic form in the TIBCO

iProcess Modeler - Getting Started guide.

This section looks in more detail at the functionality available to you as the form designer, including:

• inserting fields into forms

• editing marked fields

• defining field help

• using embedded and ampersanded fields

• application fields

• removing fields from forms

• using conditional text

• inserting use files

• using form commands

• editing forms

Inserting Fields into Forms

To insert a field in a form:

1. In the Step Definer, place the cursor where you want the field to appear.

2. Click Field > Insert.

TIBCO iProcess Modeler Basic Design

22

| Chapter 2 Creating Fields and Forms

The Mark Field dialog is displayed.

3. Select the field type you want to use from the Field list.

4. Select the Origin of the field. The origin defines how the field is going to be used in the form. The origins are:

Origin

Required

Optional

Display

Calculated

Meaning

The user must fill in this field. If a

Required field is not completed the form cannot be released. In TIBCO iProcess

Workspace (Windows) required fields appear on the form in red.

The user can enter information into this field but does not have to. The form can be released without an optional field being filled in. Optional fields appear in blue (white at run time).

The current value for the field is displayed in the form but it cannot be changed.

A value for the field is calculated and displayed based on a specified calculation.

TIBCO iProcess Modeler Basic Design

Creating a Form |

23

Origin

Hidden

Embedded

Meaning

A value is calculated but not displayed in the form.

Displays the value of the field (but not any remaining spaces up to the length of the field). This origin is often used in letters as at run time it appears as part of the form body rather than a field. See

Using Embedded and Ampersanded

Fields on page 24

.

5. Depending on the field origin you have selected, click the following buttons:

Validations, which allows you to limit the data the user can input for

Required or Optional fields. See

Using Field Validations on page 38

.

Calculations, which allows you to define the calculation used to calculate the value of a Calculated or Hidden field. See

Using Field Calculations on page 41

.

Field Help, which allows you to define help text that the user can display

to help them fill in the field. See Defining Field Help on page 23

.

6. If you want to define a command that will run when the field is opened, enter it in the Command section.

If you also click the Auto Open check box, the command is run automatically when the user presses ENTER or moves off the field after changing its value.

7. Click OK when you have finished. The field is displayed at the cursor position.

Editing Marked Fields

To edit a marked field from the Step Definer, do the following:

1. Click Field > Modify or double-click the field box.

The Mark Field dialog is displayed.

2. Make any changes required and click OK.

Defining Field Help

When you add a field that is either Required or Optional you can enter help text that the user can display for assistance when they are filling in the field.

TIBCO iProcess Modeler Basic Design

24

| Chapter 2 Creating Fields and Forms

1. From the Process Step Definer, click Field > Insert (or Field > Modify if you have already inserted your field).

2. In the Mark Field dialog, click Field Help.

The Mark Field - Field Help dialog is displayed.

3. Enter your Help text and click OK.

The field is displayed on the form with a Help button time, the user can click this button to display the Help text.

at the end of it. At run

Using Embedded and Ampersanded Fields

Within your procedure you might want to include a memo to a colleague, or a letter to a customer or supplier. You might want to include some of the information that is held in the fields of your procedure, but you don’t want it to appear as a form. In this circumstance you can use embedded fields.

To use embedded fields in your form:

1. In the Step Definer, click Field > Insert.

2. Select the field and choose an origin of Embedded.

On selecting Embedded, an additional pop-up allows you to select the style option.

TIBCO iProcess Modeler Basic Design

The options available to you will depend on the field type:

Field Type

Standard

Long

Textual: /L

Padded: /P

Monetary

Numeric: /M

Simple

Numeric: /N

Description

All types: appears like Display but without padding or justification.

The following types are available:

• Numeric: 120 is shown as one hundred

and twenty

• Date: 31/03/2000 is shown as 31st March,

2000

• Time: 23:30 is shown as 11:30 pm

The following types are available:

• Text: Left justified

• Numeric: Right justified

Numeric only: 12.34 is shown as twelve

pounds and thirty four pence

(or with different currency units according to your system configuration)

See Changing the Currency Unit on page 127

for more information.

Numeric only: 120 is shown as one two zero

Creating a Form |

25

TIBCO iProcess Modeler Basic Design

26

| Chapter 2 Creating Fields and Forms

As an alternative to marking an embedded field you can type the field name within ampersands (&). You can use the style options by typing / and the style abbreviation, for example /P for padded.

In the example above we have three ampersanded fields, customer, date and item1.

When you re-open the form after saving it you will see that iProcess has converted any field names you typed in to red field names in square brackets.This is how embedded fields appear.

TIBCO iProcess Modeler Basic Design

At run time, the form will appear as follows:

Creating a Form |

27

In this example, the fields Customer, Date and Item1 contain the values of Mrs

Millard, 3rd June 2001 and Filing Cabinet, which all appear as if they have been typed directly into the letter.

Marking Application Fields

You use Application Fields when you want the user to be able to launch a program from within a form. When you mark an Application Field, you specify the program to be run and the text that will appear on the button. When the user clicks the button, the program is run.

1. On your form, place the cursor where you want the Application Field to be displayed.

2. Click Field > Insert Application Field.

TIBCO iProcess Modeler Basic Design

28

| Chapter 2 Creating Fields and Forms

The Mark Application Field dialog is displayed.

3. In the Type of command to run section, choose:

Application Command Line, if you want to run a program.

iProcess Expression, if you want to run an iProcess expression or script.

4. In the Command to run dialog, enter the name of the program, iProcess expression or iProcess script that you want to run.

If you are entering the name of a program, you can:

— Enter a full pathname. The icon that will appear on the button is displayed to the right of the pathname.

— Enter a simple filename. The program must exist on the Windows search path.

— Insert an iProcess field value in the command, by entering the field name in ampersand (&) characters. For example, the command Notepad.exe

TIBCO iProcess Modeler Basic Design

Creating a Form |

29

&myfile&

would, at run time, open the file defined by the value of the

MYFILE field.

— Click to select a program by browsing through your folders.

This will open the Application Field Command window that enables you to browse through your computer’s file structure to locate the program you want to run.

When you have located the program you want to run, click Open and you are returned to the Mark Application Field dialog.

The path to the program you want to run is displayed in the Command to

run

dialog.

TIBCO iProcess Modeler Basic Design

30

| Chapter 2 Creating Fields and Forms

5. You can now enter any Description Text you want displayed on the application field button so that the user knows which program will be run.

6. Click OK. The Application Field button now appears on your form.

Application Field Button

TIBCO iProcess Modeler Basic Design

Creating a Form |

31

Removing Fields From Forms

To remove a field from a form, click on the field and press Delete.

This does not delete the field from the list of defined fields. It only deletes this particular field marking. If you want to remove a field from the field definition list, you need to open the Field Definition dialog and delete it from there - see

Inserting Fields into Forms on page 21 for information about the field definition

dialog.

Using Conditional Text to Dynamically Change a Form

You can change how the form appears to the user dynamically, based on the information that is entered into the fields. For example, on a loan application form, if the salary of the first applicant is not sufficient for the mortgage requested, then a second applicant’s details must be entered. At run time, the section asking for the second applicant details will only be visible if the condition equates to true.

To enter a text condition on your form:

1. Click Conditions > Insert menu, then click IF.

2. Enter the condition and the label in the dialog box and click OK.

TIBCO iProcess Modeler Basic Design

32

| Chapter 2 Creating Fields and Forms

Any valid expression can be entered. For more information about expressions, please see “Using Expressions” in TIBCO iProcess Expressions and Functions

Reference Guide.

3. Enter into the form all of the text and fields that you want the user to see if the expression evaluates to true.

4. You can also enter an ELSE from the Conditions menu if you want to show alternative text and fields to the user if the condition evaluates to false. The construct would then look like this:

5. Finally, you must close the condition by choosing ENDIF from the Conditions menu.

You can nest IF.....ENDIF or IF.....ELSE.....ENDIF conditions one inside the other up to a maximum of 20 deep.

As nested conditions can become quite complex to follow, you can display the

nesting levels at the side of the Step Definer form. See Nesting Level on page 122

for instructions on how to do this.

TIBCO iProcess Modeler Basic Design

Creating a Form |

33

Inserting a Use File

Use

files are text files that reside in a specific area on the TIBCO iProcess Engine and can be read into a form of a procedure whenever and wherever they are required. This means that the text can be created once in a word processor and read into as many forms as you like. It also means that the text only needs to be updated once and the latest version will always be used in the forms which makes the maintenance of procedures much easier and more cost effective.

To insert a Use File, do the following:

1. From the Step Definer, click Use File > Insert.

2. Choose the file you want from the dialog and click OK.

To add another file to the list displayed, you need to Import it. Click Import and you can browse through your directory structure for the file you want.

If you want to look at the contents of a file before inserting it into your form, highlight the file in the list box and click View.

When you have inserted your Use file, it will appear in your form as follows:

At run time the contents of the file are displayed.

Use Files must be ASCII (plain text), can be up to 250 lines in length, and you can

only show fields in the text by using Ampersanded Fields. See Using Embedded and Ampersanded Fields on page 24 .

TIBCO iProcess Modeler Basic Design

34

| Chapter 2 Creating Fields and Forms

Using Form Commands

Form Commands are instructions to iProcess to execute a specific command at a given point in the procedure. As indicated by their name, Form Commands are attached to the form and there are three kinds.

Command

Type

Initial

Keep

Release

Description

This command is run when the work item form is opened from the user’s Work Queue.

This command is run when the form is returned to the user’s Work Queue.

This command is run when the form is released.

You define a Form Command in the Step Status dialog.

Select the Step that you want to put a form command on and choose Status from the Step Definition dialog.

This example has a Release Command specified that calls a third-party application. An iProcess Command can be any iProcess expression, but will usually be one of the following:

TIBCO iProcess Modeler Basic Design

Creating a Form |

35

• A function call to run an external program (as above), such as SERVERRUN to run a program on the Server, or WINRUN to run a program on the iProcess

Workspace. See “Functions to Call External Programs” in TIBCO iProcess

Expressions and Functions Reference Guide for more information.

• A call to an iProcess script in the format CALL (script1). See “Calling Scripts” in the TIBCO iProcess Modeler - Advanced Design guide and “CALL” in TIBCO

iProcess Expressions and Functions Reference Guide for more information.

• An assignment expression to give a new value to a field, for example:

FIELD2 := SUBSTR (FIELD1, 1, 2)

This would assign part of FIELD1 to FIELD2 when the command is run. See

“Using Expressions” in TIBCO iProcess Expressions and Functions Reference

Guide for further information on assignment expressions.

Editing Your Form

You can edit text in a form by using the standard Cut, Copy and Paste features.

The selected text can include fields and can be copied either within a form or to another form window. If you copy the selected text to another application such as a word processor, any fields will be converted to fieldnames.

Using the Copy All option from the Edit menu enables you to copy the entire form so that you can paste it into another form either as part of the existing procedure or a different procedure.

You can copy and paste forms between different procedures. If fields marked in the source form do not already exist in the destination procedure they are automatically created. If fields already exist but have conflicting types, a warning dialog is displayed and the field will not be marked in the copy.

Changing the Form Type of a Step

If you change the form type of an existing step from iProcess Form to Formflow

form (FORMFLOW)

or vice versa, then the existing form definition is lost.

To change the form type of a step:

1. Right-click on the step and click Properties. The Step Definition dialog is displayed.

TIBCO iProcess Modeler Basic Design

36

| Chapter 2 Creating Fields and Forms

2. From the Form Type drop-down list, select a new form type and click OK or

Edit

, depending on your requirements. The following warning is displayed:

Click Yes to save the step with a new form type or No to return to the Step

Definition

dialog.

TIBCO iProcess Modeler Basic Design

Chapter 3

Controlling Data Input On Forms

This chapter explains how to control data input on your forms.

Topics

Using Field Validations, page 38

Using Field Calculations, page 41

Using Delimiters and Key Words, page 46

Using iProcess Tables, page 48

|

37

TIBCO iProcess Modeler Basic Design

38

| Chapter 3 Controlling Data Input On Forms

Using Field Validations

When you define a field that is either Required or Optional, you can enter validations so that the information the user enters is limited to certain options that are selected from a drop-down list.

From the Mark Field dialog, choose Validations.

In the example above, two possible values have been entered, “Approved” and

“Declined”.

When a user receives this step in their queue, the form will look like this:

The button next to the field enables you to open and close the drop-down list. Use the arrow keys to move up and down the list and when the choice you want is highlighted, press Return to select it.

TIBCO iProcess Modeler Basic Design

Using Field Validations |

39

As well as entering text values (which must be entered in double quotes) in the

Values and Fields

column, you can also enter iProcess Expressions or Field names. Each must equate to the same type as the field, for example, Text or

Numeric. VLDFILE and VLDQUERY functions can be used to add items from an external database to the list. Special values such as SW_ANYTHING or

SW_BLANK can also be used. See TIBCO iProcess Expressions and Functions

Reference Guide for more information.

In the Lists column you can enter the name of an iProcess list. If you have imported the sample procedures supplied with iProcess, the list YESNO will have been defined. Entering this in the Lists column will give you a drop-down list at run time with the values of YES and NO. Other lists may be defined through the

List Manager

in the iProcess Administrator.

Note that the list YESNO will not be present unless you have imported a procedure that uses it.

If you add a new list or make any changes to existing lists in the TIBCO iProcess

Administrator, you need to log out of iProcess and log back in again before the changes you have made will be visible in the TIBCO iProcess Modeler.

Each column can contain up to 10 items. If there are entries in both columns, they will all be displayed in the drop-down list.

If the field that has the validation on it is a composite key field then by entering the word TABLE in the lists section, a drop-down list of the tables key field values

is displayed at run time. See Using iProcess Tables on page 48 for more

information.

TIBCO iProcess Modeler Basic Design

40

| Chapter 3 Controlling Data Input On Forms

Copying Field Values

You can copy the value of one field to another by entering the name of a field in the Values and Fields column of the Validations dialog. The value of the field appears in a drop-down list at run time. If you enter more than one field, you can see the values of all of them in the drop-down list and can select from them.

TIBCO iProcess Modeler Basic Design

Using Field Calculations |

41

Using Field Calculations

You can use calculations to determine the value of a field. For example, in an ordering procedure you might want to calculate the value of all the items ordered.

Or, you might need to calculate the delivery date of an item based on the order date and the known lead time for that item.

Field calculations are carried out on opening the form and every time a dependent field is changed.

Self-referential calculated or hidden fields (for example,

field1=field1+1

) can be evaluated multiple times. This is because forms are rebuilt several times as a work item is processed and the calculation is evaluated every time the form is rebuilt. Therefore, using the example above, this means that 2 could be added to

field1

. To overcome this, use self-referential calculated fields in an initial or release command. This way the calculation is only executed on an initial or release of the form.

A calculated or hidden field has the option of Calculations instead of Validations.

The calculation is entered in the left column and you can optionally enter a condition so that the calculation is only carried out if the condition is met, see

Conditional Calculations on page 43 .

The following table shows you the operations that can be carried out by iProcess calculations.

Operation

+

-

Definition

add (when adding two text fields, the values are concatenated).

subtract

TIBCO iProcess Modeler Basic Design

42

| Chapter 3 Controlling Data Input On Forms

<=

>=

()

<

>

=

<>

Operation

*

/

^ or ** date

Definition

multiply divide to the power of time

To calculate the number of days between two dates:

DATE1 - DATE2

The following formula can be used in date calculations:

@days/weeks/months/[email protected]

For example, to add one year to the DATE1 field:

DATE1 + @0/0/0/[email protected]

To calculate the number of minutes between two times:

TIME1 - TIME2

For example, to add 15 minutes to the TIME1 field:

TIME1 + 15

Comparison operators

Compare the value of one field to another

equals does not equal. For example: DATE1 <> DATE2 less than. For example: FIELD1 < FIELD2 greater than less than or equal to greater than or equal to parentheses

TIBCO iProcess Modeler Basic Design

Operation

AND

or

OR

Using Field Calculations |

43

Definition

logical operators. For example:

(FIELD1 < FIELD2) AND (DATE1 <> DATE2)

Conditional Calculations

Conditional calculations are ones that are only carried out if a particular condition is met. The conditions are entered in the right side of the Mark Field -

Calculations

dialog. In the following example, the first calculation is only performed if the value of the field Quantity is less than 10; if it is greater than or equal to 10, then the second calculation is performed.

The operators that you can use are:

>

<=

>=

Operator Description

= equal to

<>

< not equal to less than greater than less than or equal to greater than or equal to

TIBCO iProcess Modeler Basic Design

44

| Chapter 3 Controlling Data Input On Forms

Up to five calculations with conditions may be entered. iProcess looks at each in turn and acts upon the first condition that is met. Any remaining calculations and conditions are disregarded. The final calculation can be left without a condition so that if the first 4 conditions fail, the final calculation will be carried out.

If there are no conditions, then only one calculation should be entered.

Calculating Text Fields

It is not just numeric fields that can be calculated: text fields can also be calculated.

The example below shows how a field calculation can be the sum of two other fields.

In the form at run time this gives the customer name followed by the customer reference. For example:

Calculating the Case Description

This method of calculation can also be used to calculate fields such as

sw_casedesc

, the case description.

To calculate the case description rather than entering it when you start a case, do the following:

1. Click Procedure > Status.

2. Click Hidden for Case Description at Start.

TIBCO iProcess Modeler Basic Design

Using Field Calculations |

45

iProcess does not allow a case description to be entered at case start when

Hidden

is selected.

3. In the first form of the procedure use Field > Insert to place the sw_casedesc field on the form (probably as a hidden field) and then add a calculation as described above.

The calculated case description is displayed for each subsequent work item in the work queues. It will not initially be available to the first step as the iProcess

Engine will not be updated with the case description until the form is either kept or released.

TIBCO iProcess Modeler Basic Design

46

| Chapter 3 Controlling Data Input On Forms

Using Delimiters and Key Words

If you want to compare a field value with a real value, you must enclose the real value within delimiters appropriate to the field type as shown below:

Field

Type

Delimiters

Numeric None

Text

Date

Time

“ “ Quotes

! ! Exclamation marks

# # Hashes

Example

NUM = 2

Name = “Fred”

Effective_Date>!07/10/99!

Time = #08:00#

Key words, or system values, are special iProcess words that have particular values and meanings. These words can be used as fields and are always present in the Field Definition dialog. The following table details each of the key words.

Key Word

SW_CASEDESC

SW_CASENUM

SW_CASEREF

SW_DATE

SW_HOSTNAME

SW_NODENAME

SW_PRODESC

SW_PRONAME

SW_STEPDESC

Meaning

The case description of the current case as entered by the user starting the procedure or can be calculated, see

Calculating Text Fields on page 44 .

The case number of the current case, allocated sequentially by iProcess.

The case reference number of the current case in the format x-yy, where x is the number of the procedure and yy is the number of the case.

The system date.

The name of the host node for the procedure.

The name of the iProcess Engine.

The description of the procedure (up to 24 characters).

The name of the procedure (up to 8 characters).

The description of the step (up to 24 characters).

TIBCO iProcess Modeler Basic Design

Using Delimiters and Key Words |

47

Key Word

SW_STEPDESC2

SW_STEPNAME

SW_TIME

Meaning

An extra value for adding further description about the current step.

The name of the step (up to 8 characters).

The system time on the iProcess Engine.

There are also certain key words that apply just to sub-procedures. These are:

Key Word

SW_MAINCASE

SW_MAINPROC

SW_MAINHOST

SW_PARENTCASE

SW_PARENTPROC

SW_PARENTHOST

SW_PARENTREF

Meaning

The top level procedure’s case number.

The top level procedure’s name.

The host where the top level procedure resides.

The parent procedure’s case number.

The parent procedure’s name.

The host where the parent procedure resides.

Internal information on the parent given in a text string as follows: pname^pnum count^ccrnum^step name^step description^call depth

These fields are read-only and are added to all new sub-procedures. If a main procedure is changed to a sub-procedure, these fields will be added to the procedure by the TIBCO iProcess Modeler.

Any of these special iProcess words can be used in your forms by selecting them in the Mark Field dialog. Alternatively, they can be used to calculate the value of a field.

In addition, SW_GROUP, SW_USER and SW_STARTER can be used in conjunction with any of their attributes, for example,

SW_STARTER:DESCRIPTION will give the description of the user who started the case of the procedure. See “Expressions” in TIBCO iProcess Expressions and

Functions Reference Guide for more information.

TIBCO iProcess Modeler Basic Design

48

| Chapter 3 Controlling Data Input On Forms

Using iProcess Tables

iProcess tables can be accessed from all procedures and are easily referenced from the form. iProcess tables should only be used for static information that does not need to be updated very often. As iProcess tables are not automatically updated when new data is entered into a form, they are not suitable for uses such as a customer database.

Structually, iProcess tables are similar to database tables. Table records are associated with fields, and one key field value serves as a unique identifier for each record. For example, a user enters a value in the key field. If this value corresponds to a record in the table, the values of the other fields in the table will automatically display.

Tables are created and stored on the iProcess Engine. For information on how to create tables, see “Managing iProcess Tables” in TIBCO iProcess Workspace

(Windows) Manager’s Guide.

To use a table in a form, you must first define it and then

mark it.

Defining a Table Field

To define a table field in your form, do the following:

1. Click Field > Define and enter the name you want to call your field.

2. Click Composite for the field type.

3. From the drop-down list of tables, choose the table you require.

TIBCO iProcess Modeler Basic Design

4. Click Add.

Using iProcess Tables |

49

Marking Table Fields in your Form

To mark a table field in your form, do the following:

1. Click Field > Insert and choose the table field you want to insert.

The table field you defined will be shown in the list of fields several times, once for each field in the table, as shown below.

2. Select the field you want, choose the origin and click OK.

TIBCO iProcess Modeler Basic Design

50

| Chapter 3 Controlling Data Input On Forms

3. In your form, mark the key field in the table and then mark the remaining table fields as required.

At run time, when the key field is entered, the remaining table fields will automatically be completed with the values from the table.

TIBCO iProcess Modeler Basic Design

Chapter 4

Using Deadlines in Procedures

Deadlines can be placed on a step to ensure that a work item is completed within a specified time period. If the deadline expires, the deadline actions will be processed. Deadlines can, if required, be reset on outstanding work items.

|

51

Topics

Defining a Deadline, page 52

Using Deadlines on a Sub-Procedure, page 55

Dynamically Recalculating Deadlines, page 56

TIBCO iProcess Modeler Basic Design

52

| Chapter 4 Using Deadlines in Procedures

Defining a Deadline

1. From the Step Definition dialog, click Deadlines. You can select a step and right-click to access the Deadlines tab.

The Deadline tab is displayed.

Choose deadline period or expression

Enter the deadline period here.

2. Select whether your deadline is to be based on a Period, such as 2 weeks, or on an Expression, then enter the deadline period or expression.

When considering how to define a deadline, you should bear in mind whether or not the deadline may need to change after the step has been sent out. See

Dynamically Recalculating Deadlines on page 56 for more information.

TIBCO iProcess Modeler Basic Design

Defining a Deadline |

53

If you select Expression, this section will automatically change to allow the input of the expression, as shown below.

Enter the deadline expression here.

In this example, a date expression has been defined as the date of application plus two weeks using the formula of @days/weeks/months/[email protected]. The expression is evaluated at the time the step is sent out. For more information on expressions, see TIBCO iProcess Expressions and Functions Reference Guide.

If working days are set, and you want the deadline to use them you need to be aware of the following:

— If you set a time expression or specify a date such as SW_DATE, the deadline does not take into account working days. For example, if working days are set to Monday to Friday and you are testing the procedure on a

Sunday, the deadline will be set for Sunday rather than the first working day (Monday).

— If you specify a Date calculation such as SW_DATE + @0/0/0/[email protected], the deadline uses working days and therefore the deadline will be set to

Monday.

TIBCO iProcess Modeler Basic Design

54

| Chapter 4 Using Deadlines in Procedures

3. (Optional) Select the Withdraw form from queue on expiry check box if you require the work item with the deadline to be withdrawn from the work queue when the deadline expires (unless the work item is open at the time of expiry). The deadline actions will be processed. This feature is often used in situations where an escalation process is used.

4. (Optional) Enter any deadline conditions required. You can set a deadline to only take effect if a certain condition is true. For example, a deadline could be set if the anticipated completion date for the property purchase is less than 4 weeks after the application date. This condition is evaluated when the step is sent out.

Drawing the Deadline Link

When you have created the step(s) that are to be actioned on expiry of the deadline you can draw the deadline link(s). The link must be drawn from the bottom of the first step (S1 in the example below) to the left of the second (S3 in the example below).

TIBCO iProcess Modeler Basic Design

Using Deadlines on a Sub-Procedure |

55

Using Deadlines on a Sub-Procedure

A deadline can be set on a sub-procedure object in the same way as any other step. Once the deadline expires, the deadline actions are performed and if

Withdraw form from queue on expiry

is selected, then the sub-case (and any child sub-cases it has initiated) will be closed. In this instance, the output data is not copied back into the parent procedure’s case data.

CONFIRM CHECKSTATUS DISPATCH

REMIND

A deadline set on a call to a sub-procedure will not be seen as a deadline in the

Work Queue Manager for the sub-procedure, as the steps within a sub-procedure can have their own deadlines.

TIBCO iProcess Modeler Basic Design

56

| Chapter 4 Using Deadlines in Procedures

Dynamically Recalculating Deadlines

A deadline (with or without a condition) is evaluated and/or calculated when a work item is sent out. It then remains in force until either the work item is released or the deadline expires.

In some situations, however, you may want to reset a deadline on a work item while it is still outstanding. For example, you may have used a deadline to set a review date for a customer’s case in 6 months’ time, but then for some reason want to bring that review date forward to 3 months’ time.

You can force the iProcess Engine to re-calculate its deadlines on all outstanding work items for a case by triggering an event on a particular step of the case. The event must:

1. update one or more field values used in setting the deadline - either in the expression that is used to calculate the deadline, or in an expression that is used to determine whether a deadline is set.

2. set a flag that informs the iProcess Engine that it should recalculate deadlines for the case.

To trigger such an event, you can use any of the following methods:

• the SWDIR\bin\swutil EVENT or SWDIR\util\swbatch EVENT commands. See "Issue an Event" in TIBCO iProcess swutil and swbatch Reference

Guide for more information about these commands.

• the TRIGGEREVENT function. See TIBCO iProcess Expressions and Functions

Reference Guide

for a detailed description of this function.

• iProcess Objects. See the relevant iProcess Objects Programmer’s Guide and help system for more information.

When the iProcess Engine detects the event, it recalculates the deadlines on all outstanding work items, as shown in the following table

.

Condition Type

No condition

Condition now evaluates as true

Condition now evaluates as false

Expression deadline is...

Period deadline is...

Re-evaluated and set to the new value.

Not recalculated.

Re-evaluated and set to the new value.

Removed.

Calculated as a period from

the original date that the work item was sent out

.

Removed.

TIBCO iProcess Modeler Basic Design

Dynamically Recalculating Deadlines |

57

You cannot use an event in this way to recalculate a Period deadline that is not triggered by a condition, because no field values are involved in the deadline’s calculation. The only way to force a re-calculation of such a deadline is to build logic into your procedure allowing you to withdraw the step and then resend it with the new deadline. However, if you do this any changes made to the work item while it has been in the user’s queue will be lost.

TIBCO iProcess Modeler Basic Design

58

| Chapter 4 Using Deadlines in Procedures

TIBCO iProcess Modeler Basic Design

Chapter 5

Using Conditional Actions

Within most business processes there is a point at which a decision has to be made and different paths followed depending on the outcome of the decision. For example, an application for a mortgage is approved or rejected, an item is in stock or out of stock. A conditional action is the point in the process where the decision is automatically made by iProcess according to the rules you specify.

|

59

Topics

Defining a Conditional Action, page 60

TIBCO iProcess Modeler Basic Design

60

| Chapter 5 Using Conditional Actions

Defining a Conditional Action

To define a conditional action:

1. Click the condition object from the Toolbar, place it on the TIBCO iProcess Modeler chart and click.

The Condition Definition dialog appears.

If case prediction is enabled on your procedure, you can use the Predicted

Condition settings. See “Using Case Prediction to Forecast Outstanding Work

Items” in the TIBCO iProcess Modeler - Advanced Design guide for more information.

2. Enter the condition and click OK.

See TIBCO iProcess Expressions and Functions Reference Guide for more information on how to enter a valid condition expression.

Any fields that you use in this expression must already be defined.

You will also need to define the step(s) to be actioned if the condition proves true and those to be actioned if the condition proves false.

TIBCO iProcess Modeler Basic Design

Defining a Conditional Action |

61

3. Draw a link from the right side of the preceding step to the left side of the condition object. Then:

— For when the condition evaluates to True, draw a line from the right side of the condition to the left side of the next step(s) as indicated by the check mark on the object.

— For actions to be taken when the condition evaluates to False, draw a line from the bottom of the condition to the left side of the next step(s).

REVIEW APPROVE

DECLINE

A condition can have more than one action following each of its true and false branches. A condition can also be directly followed by another condition.

TIBCO iProcess Modeler Basic Design

62

| Chapter 5 Using Conditional Actions

TIBCO iProcess Modeler Basic Design

Chapter 6

Withdrawing Steps From the Procedure

|

63

If you have steps that become redundant during the running of a case, you can define the procedure so that they are withdrawn from the work queues. You do this by defining a withdraw action on the step. An example of where this can be used is when you have two steps sent out in parallel, but if one is released, the other becomes unnecessary and can be withdrawn from the work queue.

Topics

Example of Using a Withdraw Action, page 64

Defining a Withdraw Action, page 65

Defining a Deadline Withdraw Action, page 66

Defining a Withdraw Action on a Sub-Procedure, page 67

TIBCO iProcess Modeler Basic Design

64

| Chapter 6 Withdrawing Steps From the Procedure

Example of Using a Withdraw Action

In the following example, if step S2 is released before S3, then S3 will automatically be withdrawn from the work queue.

S1

S2

S4

S3

Here there are 2 withdraw actions. If S2 is released first then S3 will be withdrawn but if S3 is released first then S2 will be withdrawn.

S1

S2

S4

S3

TIBCO iProcess Modeler Basic Design

Defining a Withdraw Action |

65

Defining a Withdraw Action

Draw a link from the right side of the step to the top of the step to be withdrawn.

A message box appears asking you to confirm that you want to define a withdraw action. Click Yes.

TIBCO iProcess Modeler Basic Design

66

| Chapter 6 Withdrawing Steps From the Procedure

Defining a Deadline Withdraw Action

Draw a link from the bottom of the step with a deadline to the top of the step to be withdrawn. A message box appears asking you to confirm that you want to define a withdraw action. Click Yes.

In the following example, S1 actions S2 and S3. S2 has a deadline on it, which if it expires, will withdraw S3 and action S4.

S1

S2

S4

S3

TIBCO iProcess Modeler Basic Design

Defining a Withdraw Action on a Sub-Procedure |

67

Defining a Withdraw Action on a Sub-Procedure

If a sub-procedure case is withdrawn by the parent procedure case it will be closed immediately. In the diagram below, if step S2 is released before the sub-procedure called by SUB1 is completed, then S2 will withdraw SUB1 causing the sub-procedure case to be terminated prematurely.

S1 S2

S3

SUB1

When a sub-procedure case is terminated prematurely, no data is transferred back to the parent procedure and if the sub-procedure calls any further sub-procedures, these will also be closed.

TIBCO iProcess Modeler Basic Design

68

| Chapter 6 Withdrawing Steps From the Procedure

TIBCO iProcess Modeler Basic Design

Chapter 7

Defining Waits in the Procedure

You can insert a wait into your procedure to pause the flow of a case until a number of steps have finished. You do this by inserting a Wait object on your procedure. You can use Waits to synchronize multiple concurrent paths within the procedure. A Wait:

begins when the step which precedes it is released. (This is the step which has

a line drawn from its right edge to the Wait object’s left edge.)

finishes when the steps which it is waiting for are released or withdrawn.

(These are the steps which have lines drawn from their right edges to the top or bottom of the Wait object.)

• must be the only action following a step.

|

69

Topics

Example of Using a Wait, page 70

Defining a Wait Action, page 71

TIBCO iProcess Modeler Basic Design

70

| Chapter 7 Defining Waits in the Procedure

Example of Using a Wait

In the following example, the Wait begins when step S3 is released, and finishes when S2 and S4 are also released:

1. When S3 is released, the Wait is processed.

2. The procedure waits until S2 and S4 have also been released.

3. This means that E2 will not be processed until S2, S3 and S4 have been released.

S4

S1

S2

E2

S3

It is important to realize that the Wait is not processed until S3 is released. If S2 or

S4

are released before S3, E2 is not processed, because the Wait has not yet been processed.

TIBCO iProcess Modeler Basic Design

Defining a Wait Action |

71

Defining a Wait Action

To add a wait to your procedure, do the following:

1. Click the Wait icon from the SPD Toolbar.

2. Place the Wait object at the appropriate place on your procedure. This depends on how you require the wait action to work - see:

Using Waits in Loops on page 72

Using Waits with Conditions on page 79

Using Waits with Withdraw on page 80 .

How the iProcess Engine Processes Waits

The iProcess Engine maintains its own record of the current status of each step in an active case. A step can be:

Withdrawn

. The step has been withdrawn.

Outstanding

. The step has been sent out to a queue (or external system).

Released

. The step has been released by a user (or external system).

Not Processed

. The step has not yet been processed by the server.

The server uses this step status value to control when Waits begin and finish.

Viewing Step Status on the TIBCO iProcess Engine

You can use the following command (on the TIBCO iProcess Engine) to view the current status of each step in each active case for a procedure:

SWDIR\util\plist -D [nodename] procname

where

SWDIR is the iProcess system directory, where the TIBCO iProcess Engine is

installed.

nodename is the name of the iProcess Engine node (optional).

procname is the name of the procedure (main procedure or sub-procedure) you

want to view.

TIBCO iProcess Modeler Basic Design

72

| Chapter 7 Defining Waits in the Procedure

The status of each step in each active case for procedure procname is shown. Status is shown by one of the following characters:

O

R

Character

W

.

(Period)

Status

Withdrawn

Outstanding

Released

Not Processed

The following example shows the output of this plist command for the procedure shown on

page 70 :

• Step names are shown vertically.

• The case number is shown at the beginning of the final line.

• The status of each step (R for released or O for outstanding) is shown on the final line under the step name.

A single case (case number 1) is active. S1 and S3 have been released, but S2 and

S4 are Outstanding (in a work queue). Note that E2 has not been processed yet.

C:\swserver\staffw_nod1\util>plist -D waituse3

Diractive Status Listing for procedure: WAITUSE3

Case : $$SS

S

E

S

PP12

3

4

4

AA

NN

II

CC

12

==============

1

: ..RO

R

.

O

Using Waits in Loops

There are many ways of using Waits to control the flow of your procedure. For example, you can use them in loops,

Consider the example procedure shown below.

• When step S1 is released, two parallel flows are triggered (step S2 and EAI step E1, step S3 and EAI step E2).

TIBCO iProcess Modeler Basic Design

S1

Defining a Wait Action |

73

• Each flow displays a form and, when the form is released, runs an EAI step.

• A Wait is triggered when E2 is released. The procedure waits until E1 has also been released.

S4

is then sent out, and asks the user if they want to stop or continue.

• If the user opts to continue, S1 is sent out again. (The loop can continue in this way until the user opts to stop.)

S2

E1

Prompt-stop or continue?

S3

E2

S4

1. Suppose that a case is started and processed through. The user, on S4, chooses to continue. When the condition is processed, the procedure loops back to S1,

TIBCO iProcess Modeler Basic Design

74

| Chapter 7 Defining Waits in the Procedure which has status Outstanding. All other steps still have status Released from the first pass through.

S1

S2

E1

S3

E2

S4

Prompt-stop or continue?

Step names are color coded as follows:

Released

Outstanding

2. The case now runs through the procedure again. When S1 is released, S2 and

S3

are sent out and their status is changed to Outstanding. Note that E1 and E2

TIBCO iProcess Modeler Basic Design

Defining a Wait Action |

75

still have status Released, because they have not yet been processed on this second

pass through the procedure.

S1

S2

E1

S3

E2

S4

Prompt-stop or continue?

TIBCO iProcess Modeler Basic Design

76

| Chapter 7 Defining Waits in the Procedure

3. If S2 and E1 are processed and released, but S3 is still Outstanding, the procedure waits. This is because the Wait is not processed until E2 has been processed and released.

S1

S2

E1

S3

E2

S4

Prompt-stop or continue?

However, the situation is different if S3 and E2 are processed and released while S2 is still Outstanding. In this case the Wait is processed when E2 is released and, although the procedure should wait because E1 has not yet been processed, E1 still has status Released from the first pass through. Because

TIBCO iProcess Modeler Basic Design

Defining a Wait Action |

77

both E1 and E2 have status Released, the Wait is released and S4 is sent out - which is not the desired result.

S1 S2

E1

S3

E2

S4

Prompt-stop or continue?

Using SETSTEPSTATUS to Control the Loop

If you want to use Waits in a loop in this way you should use the

SETSTEPSTATUS function. You do this by inserting an extra, parallel condition after S4 which uses the following condition expression:

SETSTEPSTATUS(“E1,E2”,0)

TIBCO iProcess Modeler Basic Design

78

| Chapter 7 Defining Waits in the Procedure

When S4 is released, the condition is processed and the server resets the status of steps E1 and E2 to Outstanding. This ensures that when S3 is released, the Wait will process in the desired fashion, and S4 will only be sent out when E1 and E2 have been released.

SETSTEPSTATUS("E1,E2",0)

S1

S2

E1

S3

E2

S4

Prompt-stop or continue?

Step names are color coded as follows:

Released

Outstanding

TIBCO iProcess Modeler Basic Design

Defining a Wait Action |

79

Using Waits with Conditions

In the following example the intention is that when step S3 is released, the procedure should wait until either S2 or S4 have been released. However, the Wait can never be triggered because one of the steps will never be sent out by the server. Its status will always be Not Processed.

S1

S4

S2

S3

Step names are color coded as follows:

Released

E1

Using SETSTEPSTATUS to Control the Wait

You can use the SETSTEPSTATUS function to control the Wait and ensure that it gets triggered, as follows:

• Insert a condition after S4, which uses the following condition expression:

SETSTEPSTATUS (“S2”,1)

If S4 is released, this condition is evaluated and the status of S2 is set to

Released

. The Wait is therefore triggered and E1 is processed.

• Insert another condition after S2, which uses the following condition expression:

SETSTEPSTATUS (“S4”,1)

TIBCO iProcess Modeler Basic Design

80

| Chapter 7 Defining Waits in the Procedure

If S2 is released, this condition is evaluated and the status of S4 is set to

Released

. The Wait is therefore triggered and E1 is processed.

SETSTEPSTATUS (“S2”,1)

S1

S4

S2

SETSTEPSTATUS (“S4”,1)

E1

S3

Using Waits with Withdraw

In the following example it is intended that S4 will be withdrawn after S3 is released but this doesn’t happen and the step is never withdrawn. This is because iProcess expects a Wait to be the only action on a step.

S1

S2

S3

S5

S4

TIBCO iProcess Modeler Basic Design

Defining a Wait Action |

81

The solution is to add a complex router R1 between S3 and the Wait. This allows the Wait to be the only action after the Complex Router and the Withdraw is actioned correctly.

S1

S2

S3

R1

S5

S4

TIBCO iProcess Modeler Basic Design

82

| Chapter 7 Defining Waits in the Procedure

TIBCO iProcess Modeler Basic Design

Chapter 8

Making Procedures Easier to Follow

A small procedure can be very simple to follow but larger and more complex procedures are more difficult to read and edit in the TIBCO iProcess Modeler.

This chapter describes some tools and techniques that you can use to make procedures easier to follow and understand:

|

83

Topics

Setting TIBCO iProcess Modeler Options, page 84

Using Swim Lanes, page 85

Changing Step Icons, page 97

Annotating Procedures for Clarity, page 98

Changing the Object Label Position, page 100

Working with Links, page 101

Setting Link Labels and Icons, page 102

Changing Link Styles and Animation, page 104

Using Routers to Simplify Visual Layout, page 106

Using Complex Routers to Simplify Procedure Logic, page 107

Using GOTOSTEP to Simplify the Procedure Routing, page 110

Zooming In and Out of a Procedure, page 111

Changing Procedure Orientation, page 112

Using the Snap-To Grid, page 113

Saving a Procedure as an Image, page 114

TIBCO iProcess Modeler Basic Design

84

| Chapter 8 Making Procedures Easier to Follow

Setting TIBCO iProcess Modeler Options

To view the TIBCO iProcess Modeler options, click Options on the Menu Bar.

In addition to the Printing options described in “Printing a Procedure” in TIBCO

iProcess Modeler - Procedure Management, there are the following options:

Display Text

. You can choose to display the name, description, extended description, and/or link labels with objects and links.

Link Styles

. You can choose the type of link, the line width, and the type of

start and end cap for the link. For more information on links see Working with

Links on page 101 ,

Setting Link Labels and Icons on page 102

, and

Changing

Link Styles and Animation on page 104 .

Link Animation

. You can choose to animate the links and the speed of the animation. You can also select the link points (round, arrow, and multiple).

For more information on link animation, see Changing Link Styles and

Animation on page 104 .

Show Default Icons

. iProcess has standard icons it uses for each type of step, but you can change these icons to something more representative. Selecting this option will display the default icons and de-selecting the option will return the display to the changed icons. Showing default icons is not maintained between TIBCO iProcess Modeler sessions.

Confirm Withdraw Connections

. Selecting this option displays a confirmation screen when you draw a withdraw link connection. De-selecting the option allows you to draw a withdraw link without displaying the confirmation screen.

TIBCO iProcess Modeler Basic Design

Using Swim Lanes |

85

Using Swim Lanes

Swim lanes are a visual tool that enable you to organize how you display your iProcess Engine procedure objects. Swim lanes can be vertical or horizontal. By specifying category labels when you create your swim lanes, you can group procedure objects into categories of your choice.

You can choose whether to use swim lanes or not, depending on your requirements. This section describes:

Enabling Swim Lanes on page 85

Swapping Between Swim Lane Types on page 89

Configuring Swim Lanes on page 90

Enabling Swim Lanes

To enable swim lanes:

1. From the iProcess Modeler, click Swim Lanes.

2. Select one of the following from the drop-down list:

— None

. If you have swim lanes already enabled, you can select None if you want to disable them.

If you disable swim lanes then the procedure objects are de-categorized.

TIBCO iProcess Modeler Basic Design

86

| Chapter 8 Making Procedures Easier to Follow

— Horizontal

. Select Horizontal if you want horizontal swim lanes.

TIBCO iProcess Modeler Basic Design

— Vertical

. Select Vertical if you want vertical swim lanes.

Using Swim Lanes |

87

3. The Swim-Lane Properties: dialog is displayed.

TIBCO iProcess Modeler Basic Design

88

| Chapter 8 Making Procedures Easier to Follow

The following table describes the properties that you can set for a swim lane.

Property

Label

Lane Color

Text Color

Description

The name of the category to be used for this swim lane. The name can be up to 128 characters.

The color to be used for the swim lane.

The color to be used for the label text.

Once you have configured the properties of your swim lane, click OK. If you selected a swim lane type, a single swim lane is created. All the procedure objects are moved below the new swim lane.

TIBCO iProcess Modeler Basic Design

Using Swim Lanes |

89

4. Depending on your requirements, drag and drop your procedure objects to the swim lane you have just created.

5. To add more swim lanes, see

Adding Swim Lanes on page 90 .

6. See Configuring How Swim Lanes are Displayed on page 96

for information on how to configure how your swim lanes are displayed.

Swapping Between Swim Lane Types

Depending on your requirements, you can swap between swim lane types. For example, you can swap from horizontal to vertical and vice versa.

If you swap between horizontal and vertical swim lane types, the top-down layout mode is swapped.

If you swap from a swim lane type to no swim lanes:

• the procedure objects are de-categorized.

• any extra space around the objects is automatically compressed.

TIBCO iProcess Modeler Basic Design

90

| Chapter 8 Making Procedures Easier to Follow

Configuring Swim Lanes

The following section describes how to edit the swim lanes. It describes:

Adding Swim Lanes

Creating Child Swim Lanes

Selecting Swim Lanes

Resizing Swim Lanes

Deleting Swim Lanes

Editing Swim Lane Properties

Configuring How Swim Lanes are Displayed

Adding Swim Lanes

To add a new swim lane:

1. Right-click the header of the chosen swim lane.

Depending on your requirements, select either:

Insert Swim-Lane Above...

— Insert Swim-Lane Below...

TIBCO iProcess Modeler Basic Design

Using Swim Lanes |

91

The Swim-Lane Properties dialog is displayed.

2. See step 3 in

Enabling Swim Lanes

for information on how to configure the swim lane properties. Click OK. A new swim lane is inserted.

3. Depending on your requirements, drag and drop your procedure objects to the swim lane you have just created.

TIBCO iProcess Modeler Basic Design

92

| Chapter 8 Making Procedures Easier to Follow

TIBCO iProcess Modeler Basic Design

Using Swim Lanes |

93

Creating Child Swim Lanes

You can nest swim lanes within other swim lanes, depending on your requirements. To do this, create a child swim lane in the swim lane where you want to nest other swim lanes. To create a child swim lane:

1. Right click the header of the swim lane you want to create a child swim lane from and select Add Child Swim-Lane.... The Swim-Lane Properties dialog is displayed.

2. See step 3 in

Enabling Swim Lanes

for information on how to configure the swim lane properties.

3. Click OK. The child swim lane is created.

TIBCO iProcess Modeler Basic Design

94

| Chapter 8 Making Procedures Easier to Follow

4. Repeat steps 1 -2 for each child swim lane that you want to create.

5. Depending on your requirements, drag and drop your procedure objects to the child swim lane(s) you have just created.

TIBCO iProcess Modeler Basic Design

Using Swim Lanes |

95

Selecting Swim Lanes

You can select a swim lane or multiple swim lanes, depending on your requirements, using CTRL + Click. This is useful, for example, if you want to delete more than one swim lane or you want to highlight particular procedure objects, as shown below.

You can also select all the procedure objects within a swim lane by right clicking the header of the swim lane whose procedure objects you want to select and clicking Select all objects.

To deselect a swim lane(s), press Escape or click on another swim lane.

Resizing Swim Lanes

You can resize a swim lane by dragging the separating lines between the swim lanes.

TIBCO iProcess Modeler Basic Design

96

| Chapter 8 Making Procedures Easier to Follow

Deleting Swim Lanes

You can only delete a swim lane if it is empty, unless it is the last child swim lane.

If it is the last child swim lane, the parent swim lane inherits the procedure objects.

To delete a swim lane:

1. Move the procedure objects from the swim lane you want to delete to another swim lane. This is because you cannot delete a swim lane if it contains procedure objects.

2. Right click the tab header of the swim lane you want to delete and select

Delete

. The swim lane is deleted.

If you are deleting multiple swim lanes, use the Delete key.

Editing Swim Lane Properties

To edit the properties of a swim lane:

1. Right-click the header of the swim lane whose properties you want to change and select Properties. The Swim-Lane Properties: dialog is displayed.

2. See step 3 in

Enabling Swim Lanes

for information on how to configure the swim lane properties.

Configuring How Swim Lanes are Displayed

To configure how your swim lanes are displayed, click Options > Swim Lanes.

You can select one of the following:

• Plain Style

. This is the default option when you enable swim lanes. Select this if you want to display your swim lanes as squares.

Tablet Style

. Select this if you want to display your swim lanes as tablets.

Border

. Select this if you want to display your swim lanes with a border.

Color Header Only

. Select this if you only want the swim lane header to be displayed with a color rather than the whole swim lane.

• Shadow

. Select this if you want to display your swim lanes with shadows.

TIBCO iProcess Modeler Basic Design

Changing Step Icons |

97

Changing Step Icons

iProcess has default icons that are used to represent the different types of steps, but you can change these to other icons. For example, you might want to use a word processing icon to represent a letter or a database icon where an external database is being interrogated by iProcess.

To change an icon:

1. Right click on the step you want to change, then click Change Icon.

The Select Object Icon dialog is displayed.

2. Enter the file name containing the icons or click Browse. Choose an icon from those displayed and click OK.

If you have already changed an icon and want to revert to the original icon, click

Use Default

and the default iProcess icon will be displayed.

TIBCO iProcess Modeler Basic Design

98

| Chapter 8 Making Procedures Easier to Follow

Annotating Procedures for Clarity

Annotating your procedures is an easy way to ensure clarity of your procedures.

To add an annotation:

1. Click the annotation tool your procedure.

and place it in the appropriate position on

2. Enter the text that you want displayed and click OK.

The annotation text appears with the symbol on your procedure. You can re-position the annotation text by clicking and dragging the symbol.

Annotation is frequently used alongside Conditional Actions to show the decision being taken. A Conditional Action can also have an annotation that displays in the hover pop-up.

Annotation can also be associated with a particular step.

1. Select the required step in your procedure and right click.

2. Click Annotations and enter the information.

TIBCO iProcess Modeler Basic Design

Annotating Procedures for Clarity |

99

Annotation that is specific to a step is not displayed on the TIBCO iProcess

Modeler procedure layout but can be accessed at any time by right-clicking on the object.

TIBCO iProcess Modeler Basic Design

100

| Chapter 8 Making Procedures Easier to Follow

Changing the Object Label Position

Text labels for objects display in the following default positions:

Object

Annotation

Condition

Start

Elbow

Wait

All other objects

Text Label Position

Right side. (You cannot reposition annotation text.)

Since conditions have at least one side that is not linked, the text label appears on the free side.

No text label.

No text label.

No text label.

Bottom side for left > right layout mode.

Right side for top > down layout mode.

You can override the default text position (except for annotation) by right-clicking on an object (or selected objects) and selecting Object Label Position, then selecting the text position. Selecting Automatic uses the text label default position. To choose which text displays (the object name, description, extended description, and link labels), select Option > Display Text.

TIBCO iProcess Modeler Basic Design

Working with Links |

101

Working with Links

Links between objects are selectable in their own right, just as objects are selectable. To select a link, you can click the link or label. To select multiple links, hold the CTRL key and click the additional links. This leaves the original links selected while selecting the additional links. Also, if you select a group of objects, any links between those objects are selected.

To move a link, click the link and drag it to the new position. (Note that moving a link adds a router to the link.) Press ESC to cancel the move.

To delete a link, select the link and press Delete.

You can right-click a link to access the following popup menu options:

Menu

Option

Description

Link Label Allows you to edit the link label parameters.

Add Router Inserts a router at the point the mouse was clicked.

Go To

Source

Selects the source object for the link and brings it into view (if not currently visible on screen).

Go To

Target

Reset Link

Styles

Selects the target object for the link and brings it into view (if not currently visible on screen).

Resets the link styles and color to those options currently selected on the link style toolbar.

Delete Link Deletes the link without deleting the selected objects.

If you select multiple links (with no objects selected) and right-click a selected link, a popup menu containing the following menu options appears:

Menu

Option

Description

Link Label Allows you to edit the link label parameters.

Reset Link

Styles

Delete

Link(s)

Resets the link styles and color to those options currently selected on the link style toolbar.

Deletes the link without deleting the selected objects.

TIBCO iProcess Modeler Basic Design

102

| Chapter 8 Making Procedures Easier to Follow

Setting Link Labels and Icons

You can assign a label to a link. The link label can consist of text and icons that identify the link type. The link type icons are:

Icon Type

Deadline

Condition True

Condition False

Withdraw

The link icon displays on the link line close to the link start point (or end point in the case of the withdraw link icon). If the object text label is positioned on the same side as the link, the link icon appears further along the link line to avoid overlaying the text. You can elect to hide the start and end link type icons using an option on the Link Label dialog.

TIBCO iProcess Modeler Basic Design

Setting Link Labels and Icons |

103

To access the Link Label dialog, double-click a link or right-click a link and select the Link Label menu option. The Link Label dialog appears.

The link label description text can be up to 128 characters. The text is truncated (or not displayed at all) if display space is limited. However, you can hover the cursor over the link and the full label text displays in a pop-up window.

TIBCO iProcess Modeler Basic Design

104

| Chapter 8 Making Procedures Easier to Follow

Changing Link Styles and Animation

You can select a variety of link styles by using the Link Styles toolbar (or by selecting Options > Link Styles).

Style

Convert

Flowchart

Straight

Curved

Line Width

Start-cap

Style

End-cap

Style

Normal

Deadline

Condition

True

Condition

False

Icon Description

Converts the selected links to the styles and colors currently selected on the toolbar.

Allows horizontal and vertical lines.

Allows diagonal lines.

Allows best-fit curved lines through routers.

Allows you to select the thickness of the lines by pixel.

Allows you to select a line start-cap style from a drop-down list. Your choices are

None, Round, Square, and two arrow styles.

Allows you to select a line end-cap style from a drop-down list. Your choices are None,

Round, Square, and two arrow styles.

Allows you to set the Normal link color.

Allows you to set the Deadline link color.

Allows you to set the Condition True link color.

Allows you to set the Condition False link color.

Animation Allows you to turn on/off link animation, select the type of points (dots or arrows), and select the animation speed.

TIBCO iProcess Modeler Basic Design

Changing Link Styles and Animation |

105

Changing a link style makes the change only for the selected link. To make the same changes to all links in a procedure, click or select Edit > Reset All

Link Styles

.

TIBCO iProcess Modeler Basic Design

106

| Chapter 8 Making Procedures Easier to Follow

Using Routers to Simplify Visual Layout

Routers are used to simplify the visual layout of a procedure. Using them allows you to define the route of the connecting line between two steps. Any number of routers can be placed anywhere on any type of link to give greater control over the layout.

When drawing a line between two steps, right-click to place a router at the cursor position. To add a router to an existing link, right-click the link and select Add

Router

or simply click and drag the link.

The following simple example shows first how the line would be automatically drawn by iProcess and then how it can be displayed when using a router.

TIBCO iProcess Modeler Basic Design

Using Complex Routers to Simplify Procedure Logic |

107

Using Complex Routers to Simplify Procedure Logic

A Complex Router is a step that is hidden to the user at run time and never appears in a work queue. The iProcess background process releases the Complex

Router and processes its actions without any input from the user.

Complex Routers can be useful in the following situations:

To simplify procedure layout. The following is an example:

A conditional action can only have one step leading to it, but it may be that two or more steps need to use the same condition to decide an action. In the example below, S1 processes either S2 or S3. Both of these steps process either

S4

or S5. When this happens, the resulting process is difficult to follow.

S1 S2 S4

S5

S3

TIBCO iProcess Modeler Basic Design

108

| Chapter 8 Making Procedures Easier to Follow

Using a Complex Router R1 in this situation makes the process visually simpler, as you can see below.

S1 S2

R1

S4

S3 S5

To make the case number available to the first step.

On the TIBCO iProcess Workspace, when the addressee (or one of the addressees) of the first step of a procedure is the same as the user starting the case, the form appears immediately. In this instance, the case number is not available to the first step as it is assigned by the iProcess background when the case start is processed and returned to the work queue.

By placing a complex router between the Start object and the first step you can overcome this problem. iProcess takes the Complex Router as being the first step, assigns the case number, then processes the next step which is the first step to be displayed to the user.

To provide conditional start steps.

Placing a Complex Router immediately after the Case Start object allows you to conditionally set the start step, depending on the value of case data. (A

Condition cannot be placed directly after the Case Start object.)

In the following example, as shown by the annotation, STEP1 is actioned if the case is started by the Manager user. If it is started by another user, STEP2 is actioned. (Note that STEP1 or STEP2 will be sent to the appropriate queue in

TIBCO iProcess Modeler Basic Design

Using Complex Routers to Simplify Procedure Logic |

109

the normal way - the case starter will not receive the form for either when starting the case.)

SW_STARTER:Name = “Manager”?

S1

S2

Complex Routers cannot have withdraw or deadline actions and do not have entries in the Audit Trail.

TIBCO iProcess Modeler Basic Design

110

| Chapter 8 Making Procedures Easier to Follow

Using GOTOSTEP to Simplify the Procedure Routing

You can alter the normal flow of your procedure using the GOTOSTEP expression. For example, if you want to jump to a specific step (perhaps for exception handling), you can jump directly to an exception handling step rather than trying to define the necessary workflow layout to do it (which can often get difficult to interpret).

On release of the current step, you can use GOTOSTEP to jump to another step.

You can choose to process the current step or not. The GOTOSTEP expression has a flag that can be used to specify if the current workflow processing is continued or stopped when the workflow jumps to the new step.

For example, if you have a step where a script is run and an exception is raised, you can use the GOTOSTEP to jump to an exception handling step rather than trying to define a complicated workflow to handle the various workflow routes.

Using this expression can cut down the amount of workflow “spaghetti” which can be created when defining a complicated procedure.

For more information and a detailed example about using the GOTOSTEP syntax, refer to “GOTOSTEP” in TIBCO iProcess Expressions and Functions Reference Guide.

TIBCO iProcess Modeler Basic Design

Zooming In and Out of a Procedure |

111

Zooming In and Out of a Procedure

For ease of use when viewing a procedure you can zoom in and out or choose a particular part of a procedure to view.

Toolbar Button Task

Enlarge the size of the procedure.

Reduce the size of a procedure.

Set zoom level.

Enlarge a particular section of a procedure.

Use on large procedures to give you a rectangular box which you can drag across your TIBCO iProcess

Modeler window. If you place it over a particular section of your procedure and click, that section is enlarged.

Display the default size.

Menu Option

View

> Zoom In

View

> Zoom Out

View > Zoom Level

View

> Map

View

> Normal

Spinning the mouse wheel while pressing CTRL will zoom the view in and out.

TIBCO iProcess Modeler Basic Design

112

| Chapter 8 Making Procedures Easier to Follow

Changing Procedure Orientation

The default orientation for procedures is left-to-right (horizontal). However, for some procedures, a top-down (vertical) flow makes more sense. The button allows you to change the procedure orientation. Changing the orientation swaps the X and Y coordinates of each object and changes the link sides from right to bottom and from left to top. It also switches the default object side link types. See

Linking Procedure Objects on page 7

for more information.

TIBCO iProcess Modeler Basic Design

Using the Snap-To Grid |

113

Using the Snap-To Grid

The snap-to grid function allows you to align objects using a grid. When you move or place an object, the object is automatically snapped to the center of the nearest grid square. The following table contains the toolbar icons and a description of the toolbar functions:

Icon Description

Displays the snap-to grid.

Allows you to select the size of the grid.

Snaps the selected object to the center of the nearest grid square.

If a snap-to grid operation would cause objects to overlap, no objects are moved and you receive an error message.

TIBCO iProcess Modeler Basic Design

114

| Chapter 8 Making Procedures Easier to Follow

Saving a Procedure as an Image

You can save a procedure map as an image file by clicking Procedure > Save As >


. The Save File dialog appears. Specify the location, name, and type (JPEG,

BMP, or PNG) of the output image. Click Save to view the image in the specified file and format at the current zoom level.

There is a limitation on the size of in-memory bitmaps. If the procedure is very large in the current zoom level a warning message is displayed. You can decrease the zoom level to make the view smaller until the size is under the limitation.

TIBCO iProcess Modeler Basic Design

Chapter 9

Customizing the Process Step Definer

The Process Step Definer has a number of setup options that can be changed to suit your way of working.

Open the Step Definer, click Form > Setup and you have several options, which are described in this chapter.

|

115

Topics

Colors, page 116

Select Font, page 117

Dynamic Scroll, page 118

Show Field Names, page 119

Line Length, page 120

Tabs, page 121

Nesting Level, page 122

TIBCO iProcess Modeler Basic Design

116

| Chapter 9 Customizing the Process Step Definer

Colors

The colors that are used for the text and background in different parts of the form can be changed through the standard Windows Colors dialog.

Click Change to display the color palette, make your selection and click OK.

Changes are implemented across all procedures and are saved between TIBCO iProcess Modeler sessions.

TIBCO iProcess Modeler Basic Design

Select Font |

117

Select Font

Selecting this option takes you to the Font dialog allowing you to select the font you want and its style and size.

Changes made are per form and are saved between TIBCO iProcess Modeler sessions.

TIBCO iProcess Modeler Basic Design

118

| Chapter 9 Customizing the Process Step Definer

Dynamic Scroll

When Dynamic Scroll is on, the contents of the window move as you drag the scroll bar up or down. When it is off, the contents of the window will not move until you release the scroll bar.

Click on Dynamic Scroll to select it and a check mark appears to the left of the list. Click again to de-select it.

This option is per form and is not saved between editing sessions.

TIBCO iProcess Modeler Basic Design

Show Field Names |

119

Show Field Names

When Show Field names is selected the names of fields appear in the input fields in the Step Definer as shown below.

Click on Show Field names to select it and a check mark appears to the left of the list. Click again to de-select it.

This option is set across all procedures and is saved between TIBCO iProcess

Modeler sessions.

TIBCO iProcess Modeler Basic Design

120

| Chapter 9 Customizing the Process Step Definer

Line Length

Line length allows you to choose how long the lines in your form should be before they are wrapped.

Enter the line length you want (to a maximum of 128 characters) and click OK.

TIBCO iProcess Modeler Basic Design

Tabs

Tabs |

121

To change the distance in characters between tabs, select Setup > Tabs. Enter the distance you want and click OK.

The maximum tab length is 16 characters and the change is implemented across all procedures and is maintained between TIBCO iProcess Modeler sessions.

TIBCO iProcess Modeler Basic Design

122

| Chapter 9 Customizing the Process Step Definer

Nesting Level

When you use Conditional Text in your form (see

Using Conditional Text to

Dynamically Change a Form on page 31 ), you can nest up to 20 levels. To make it

easier to follow when working on your form, you can choose to show the nesting levels either numerically or graphically.

This option is per form and is not saved between TIBCO iProcess Modeler sessions.

TIBCO iProcess Modeler Basic Design

Nesting Level |

123

Select Nesting Level from the Setup menu on the form and choose Numeric or

Graphical

(or both).

Show the nesting level either graphically, numerically, or both.

TIBCO iProcess Modeler Basic Design

124

| Chapter 9 Customizing the Process Step Definer

TIBCO iProcess Modeler Basic Design

Appendix A

Troubleshooting Procedure Definitions

This appendix describes some typical problems you can encounter when defining and working with procedures.

|

125

Topics

An Under Construction Symbol Appears on a Step, page 126

Changing the Currency Unit, page 127

TIBCO iProcess Modeler Basic Design

126

| Appendix A Troubleshooting Procedure Definitions

An Under Construction Symbol Appears on a Step

Problem

One or more steps in your procedure definition show an Under Construction sign over the step icon.

Description

Solution

When defining procedures, you need to be aware that steps need to have a certain amount of basic information. If this information is not defined, iProcess warns you by placing an Under Construction sign on the step.

The following list describes the possible solutions you can try for each step type where you see a red question mark.

For a normal step

, select the step and right-click to select Addressees. Make sure an addressee has been entered for this step.

For a Sub-procedure call step

, select the step and right-click to select

Sub-Procedure

. Make sure a sub-procedure is chosen in the Sub-Procedure

Name

field.

For a Dynamic Sub-procedure call step

, select the step and right-click to select Dynamic Sub-Procedure. Make sure the Sub-Procedure Name Array field contains an array field and that all the required input fields are mapped.

For an EAI step

, select the step and right-click Description. Make sure a valid script definition has been entered and check that an EAI type has been selected.

For a Wait step

, make sure it is connected to 2 or more steps.

For a Condition step

, select the step and right-click Condition. Enter a valid condition.

TIBCO iProcess Modeler Basic Design

Changing the Currency Unit |

127

Changing the Currency Unit

Problem

Description

Solution 1

Solution 2

You need to change the currency unit.

The default currency unit for iProcess is pounds and pence. For different currency units, you must change the system configuration. The currency unit information is stored in the SWDIR/etc/ENGLISH.LNG/LONGNUM.FMT file. To change the currency units, you must change all the references to pounds and pence in the

LONGNUM.FMT

file to the currency unit you require. You can, either:

Solution 1

: Amend the original SWDIR/etc/LONGNUM.FMT file, or

Solution 2

: Create a copy of the SWDIR/etc/ENGLISH.LNG directory, rename it to the language whose currency unit you require and amend the

LONGNUM

.FMT file in the new SWDIR/etc/language.LNG directory.

The sections below describe the steps to perform for each solution:

Complete the following steps:

1. Create a back up copy of the SWDIR/etc/ENGLISH.LNG directory.

2. Open the SWDIR/etc/ENGLISH.LNG/LONGNUM.FMT file in a text editor, for example, Textpad.

3. Change all references to pounds and pence in the

SWDIR/etc/ENGLISH.LNG/LONGNUM.FMT file to the currency units

you require.

Complete the following steps:

1. In SWDIR/etc, create a directory named language.LNG where language is the name of the language whose currency unit you want to use. For example, if you wanted to change the currency unit to dollars, you could create a directory called USA.LNG.

2. Copy all the files from the SWDIR/etc/ENGLISH.LNG directory to the

language

.LNG directory you have just created.

3. Open the SWDIR/etc/language.LNG/LONGNUM.FMT file in a text editor, for example, Textpad.

4. Change all references to pounds and pence in the LONGNUM.FMT file to the currency units you require.

5. Open User Manager in the iProcess Administrator.

TIBCO iProcess Modeler Basic Design

128

| Appendix A Troubleshooting Procedure Definitions

6. For each user whose currency unit needs to change, change the user

LANGUAGE attribute to the value of the language.lng directory that you

created in step 1 . For example, if you created a directory called usa.lng, then

change the LANGUAGE attribute from english to usa.

7. Open Move SysInfo in the iProcess Administrator.

8. Click Move SysInfo to apply the changes.

TIBCO iProcess Modeler Basic Design

Index

A

Action conditional defining

60

deadline withdraw, drawing

66

wait, defining

71

withdraw drawing

65

using on sub-procedure

67

Addressee group

10

multiple user

10

single user

9

Ampersanded field

24

Annotation

98

Application field, marking

27

Array fields about

16

defining

18

Assigning addressee

9

C

Calculating case description

44

deadlines dynamically

56

text field

44

Calculation conditional

43

field

41

Case description calculating

44

ignore suspend flag

14

suspend

14

Changing colors in Step Definer

116

dynamic scroll setting, in Step Definer

118

font, in Step Definer

117

step icons

97

tabs in Step Definer

121

Colors, changing in Step Definer

116

Command, form

34

Complex router

107

Condition using waits with

79

Conditional action defining

60

calculations

43

text

31

Conditional actions using

59

Configuring

Process Step Definer

115

Copy objects

6

Copying field values

40

Copying form contents

13

Creating form

21

procedure

1

customer support

xiii

Cut objects

6

TIBCO iProcess Modeler Basic Design

|

129

130

| Index

D

Deadline defining

52

dynamic recalculation

56

link

8

drawing

54

on sub-procedure

55

withdraw action, drawing

66

link

8

Defining conditional action

60

deadline

52

field help

24

fields

18

roles

11

step status options

13

table field

48

wait action

71

waits

69

Deleting field

31

swim lanes

96

Delimiters

46

Drawing deadline link

54

withdraw action

66

withdraw action

65

Dynamic deadline recalculation

56

scroll setting

118

E

Editing form

35

marked fields

23

Editing form edit permission

13

Embedded field

24

TIBCO iProcess Modeler Basic Design

F

Field ampersanded

24

application

27

array

16

calculations

41

defining

18

deleting

31

embedded

24

names, showing in Step Definer

119

table

49

defining

48

text

44

using for dynamic routing

12

validations

38

values, copying

40

Field Definition dialog

Field Length

18

Field Name

18

Field type

18

Tables

18

Font, changing in Step Definer

117

Form commands

34

creating

21

editing

35

using conditional text to change dynamically

31

Forwarding steps

13

G

GOTOSTEP expression

110

Group addressee

10

H

Horizontal swim lanes

85

I

Icons, step, changing

97

Ignore suspend flag

14

iProcess iProcess Engine, viewing step status on

71

tables, using

48

L

Line length

120

Link deadline

8

withdraw

8

, 54

normal

7

withdraw

8

Link icons, setting

102

Link labels, setting

102

Linking objects

7

Loops using waits in

72

M

Mark Field - Field Help dialog

Field Help

24

Mark Field dialog

Command

22

Field

22

Origin

22

Marked field editing

23

Marking

49

application fields

27

table fields

49

Multiple user addressee

10

N

Nesting levels

122

Normal link

7

O

Object label position, changing

100

Objects linking

7

types of

2

Options, Process Definer

84

P

Paste objects

6

Placing procedure objects

2

Preventing deletion on withdraw

14

Procedure creating

1

logic, simplifying with complex routers

107

zooming in and out of

111

Process Definer options

84

Process routing

9

Process Step Definer configuring

115

R

Recalculating deadlines dynamically

56

Roles

11

Router using

106

Routing, process

9

Index |

131

TIBCO iProcess Modeler Basic Design

132

| Index

S

Showing field names in the Step Definer

119

Single instance fields about

16

Single user addressee

9

Status step

71

Step icons

97

status

71

Step Definer

119

colors

116

dynamic scroll setting

118

font

117

tabs

121

using

15 ,

37

Steps forwarding

13

withdrawing

63

Sub-procedure using deadlines on

55

withdraw action on

67

support, contacting

xiii

Suspend case

14

,

14

Swim lanes adding

90

configuring

90

deleting

96

displaying

96

editing properties of

96

enabling

85

nesting

93

resizing

95

selecting

95

swapping between types

89

types of

85

using

85

T

Table field defining

48

marking

49

iProcess

48

Tabs changing in Step Definer

121

technical support

xiii

Text condition, entering

31

field, calculating

44

Troubleshooting procedures

125

U

Under Construction symbol troubleshooting

126

Use files, inserting

33

Using ampersanded fields

24

complex routers to simplify procedure logic

107

conditional actions

59

conditional text

31

deadlines on a sub-procedure

55

deadlines in a procedure

51

embedded fields

24

field calculations

41

validations

38

form commands

34

iProcess tables

48

routers

106

Step Definer

15

,

37

swim lanes

85

waits in loops

72

with conditions

79

with withdraws

80

withdraw action on a sub-procedure

67

TIBCO iProcess Modeler Basic Design

Index |

133

Using GOTOSTEP

110

V

Validation, field

38

Vertical swim lanes

85

Viewing step status on the TIBCO iProcess Engine

71

W

Wait action

71

how iProcess processes

71

using in loop

72

with conditions

79

with withdraws

80

Waits defining

69

Withdraw action drawing

65

using on sub-procedure

67

link

8

using waits with

80

Withdrawing steps

63

Work items

14

Z

Zooming in and out of a procedure

111
