ISL91110IR

DATASHEET

High Efficiency Buck-Boost Regulator with 5.4A

Switches

ISL91110IR

The ISL91110IR is a high-current buck-boost switching regulator for systems using new battery chemistries. It uses Intersil’s proprietary buck-boost algorithm to maintain voltage regulation while providing excellent efficiency and very low output voltage ripple when the input voltage is close to the output voltage.

The ISL91110IR is capable of delivering at least 2A continuous output current (V

OUT

= 3.3V) over a battery voltage range of 2.5V to

4.35V. This maximizes the energy utilization of advanced single-cell

Li-ion battery chemistries that have significant capacity left at voltages below the system voltage. Its fully synchronous low

ON-resistance 4-switch architecture and a low quiescent current of only 35µA optimize efficiency under all load conditions.

The ISL91110IR supports standalone applications with a fixed 3.3V or 3.5V output voltage or adjustable output voltage with an external resistor divider. Output voltages as low as 1V or as high as 5.2V are supported.

The ISL91110IR requires only a single inductor and very few external components. Power supply solution size is minimized by its

2.5MHz switching frequency, allowing small size external components.

Features

• Accepts input voltages above or below regulated output voltage

• Automatic and seamless transitions between buck and boost modes

• Input voltage range: 1.8V to 5.5V

• Output current: up to 2A (PVIN = 3.4V, V

OUT

= 5V)

• Output current: up to 2A (PVIN = 2.5V, V

OUT

= 3.3V)

• Burst current: up to 3A (PVIN = 2.9V, V

OUT t = 4.6ms)

= 3.3V, t

ON

< 600µs,

• High efficiency: up to 95%

• 35µA quiescent current maximizes light load efficiency

• 2.5MHz switching frequency minimizes external component size

• Fully protected for short-circuit, over-temperature and undervoltage

• Small 4mmx4mm 20 Ld TQFN package

The ISL91110IR is available in a 4mmx4mm, 20 Ld TQFN package.

TABLE 1. KEY DIFFERENCES BETWEEN FAMILY OF PARTS

PART NUMBER ADJ or FIXED V

OUT

ISL91110IRNZ-T 3.3

ISL91110IRNZ-T7A 3.3

ISL91110IR2AZ-T 3.5

ISL91110IR2AZ-T7A 3.5

ISL91110IRAZ-T ADJ

ISL91110IRAZ-T7A ADJ

Applications

• Smartphones and tablet PCs

• Wireless communication devices

• Optical modules networking equipment

Related Literature

UG022 , “ISL91110IRx-EVZ Evaluation Boards User Guide”

V

IN

=

1.8V TO 5.5V

C

1

2x10µF

PVIN

ISL91110IRNZ

LX1

VIN

EN

LX2

VOUT

MODE

FB

L

1

1µH

V

OUT

= 3.3V

UP TO 3A

C

2

2x22µF

100

95

90

V

IN

= 4.2V

85

V

IN

= 3.6V

80

V

IN

= 3.3V

75

V

IN

= 3V

70

1 10 100

LOAD CURRENT (mA)

1000

FIGURE 2. EFFICIENCY: V

OUT

= 3.3V, T

A

= +25°C

April 17, 2015

FN8709.0

FIGURE 1. TYPICAL APPLICATION: V

OUT

= 3.3V

1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

|

Copyright Intersil Americas LLC 2015. All Rights Reserved

Intersil (and design) is a trademark owned by Intersil Corporation or one of its subsidiaries.

All other trademarks mentioned are the property of their respective owners.

ISL91110IR

Block Diagram

4

LX1

5

LX2

1 2

6

7

PVIN

8

9

Q1

EN

11

VIN 10 VREF

EN

EN

Q2

VIN

MONITOR

THERMAL

SHUTDOWN

Q4

GATE

DRIVERS

AND

ANTI-SHOOT

THRU

Q3

+

CONTROL

VOUT

CLAMP

CURRENT

DETECT

EN

EN

OSC

+

COMP

-

ERROR

AMP

-

+

REF

VOLTAGE

PROG.

16 NC

ADJ

OUTPUT

FIXED

OUTPUT

15 FB

17

18

VOUT

19

20

3 PGND

13

14

SGND

12 MODE

FIGURE 3. BLOCK DIAGRAM

Submit Document Feedback

2

FN8709.0

April 17, 2015

Pin Configuration

LX2

1

LX2 2

PGND

3

LX1 4

LX1

5

ISL91110IR

(20 LD, 4X4 TQFN)

TOP VIEW

20 19 18 17 16

6 7

EPAD

8 9 10

15

FB

14 SGND

13

SGND

12 MODE

11

EN

ISL91110IR

Pin Descriptions

PIN #

6, 7, 8, 9,

PIN NAMES

PVIN

4, 5

3

1, 2

17, 18,

19, 20

12

10

11

13, 14

15

16

LX1

PGND

LX2

VOUT

MODE

VIN

EN

SGND

FB

NC

Epad

DESCRIPTION

Power input; Range: 1.8V to 5.5V. Connect

2x10μF capacitors to PGND.

Inductor connection, input side

Power ground for high switching current

Inductor connection, output side

Buck-boost regulator output; Connect

2x22μF capacitors to PGND for V

OUT and 3.5V applications, and 2x47µF

= 3.3V capacitors to PGND for V

OUT applications.

= 4.5V and 5V

Logic input, HIGH for auto PFM mode. LOW for forced PWM operation. Also, this pin can be used with an external clock sync input.

Range: 2.75MHz to 3.25MHz. Do not leave floating.

Supply input; Range: 1.8V to 5.5V.

Logic input, drive HIGH to enable device. Do not leave floating.

Analog ground pin

Voltage feedback pin, connect directly to the

VOUT pin for fixed output voltage versions.

No connect pin

Thermal pad, connect to PGND

Ordering Information

PART NUMBER

( Notes 1, 2, 3 )

ISL91110IRNZ-T

PART

MARKING

91110N

OUTPUT VOLTAGE

(V)

3.3

TEMP RANGE

(°C)

-40 to +85

PACKAGE

Tape and Reel

(RoHS Compliant)

20 Ld 4x4 TQFN

PKG.

DWG. #

L20.4X4C

ISL91110IRNZ-T7A

ISL91110IR2AZ-T

ISL91110IR2AZ-T7A

ISL91110IRAZ-T

91110N

911102

911102

91110A

3.3

3.5

3.5

ADJ

-40 to +85

-40 to +85

-40 to +85

-40 to +85

-40 to +85

20 Ld 4x4 TQFN

20 Ld 4x4 TQFN

20 Ld 4x4 TQFN

20 Ld 4x4 TQFN

20 Ld 4x4 TQFN

L20.4X4C

L20.4X4C

L20.4X4C

L20.4X4C

L20.4X4C

ISL91110IRAZ-T7A 91110A ADJ

ISL91110IRN-EVZ Evaluation Board for ISL91110IRNZ

ISL91110IR2A-EVZ

ISL91110IRA-EVZ

Evaluation Board for ISL91110IR2AZ

Evaluation Board for ISL91110IRAZ

NOTES:

1. Please refer to TB347 for details on reel specifications.

2. These Intersil Pb-free plastic packaged products employ special Pb-free material sets, molding compounds/die attach materials and 100% matte tin plate plus anneal (e3 termination finish, which is RoHS compliant and compatible with both SnPb and Pb-free soldering operations). Intersil Pb-free products are MSL classified at Pb-free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.

3. For Moisture Sensitivity Level (MSL), please see product information page for ISL91110IR . For more information on MSL please see techbrief TB363 .

Submit Document Feedback

3

FN8709.0

April 17, 2015

ISL91110IR

Absolute Maximum Ratings

PVIN, VIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 6.5V

LX1, LX2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 6.5V

FB (Adjustable Version) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 2.7V

FB (Fixed V

OUT

Versions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 6.5V

SGND, PGND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 0.3V

All Other Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to 6.5V

ESD Rating

Human Body Model (Tested per JESD22-A114E) . . . . . . . . . . . . . . . . 3kV

Machine Model (Tested per JESD22-A115-A) . . . . . . . . . . . . . . . . . 200V

Charge Device Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2kV

Latch-up (Tested per JESD-78B; Class 2, Level A) . . . . . . . . . . . . . . 100mA

Thermal Information

Thermal Resistance (Typical)

20 Ld 4x4 TQFN Package (

Notes 4 , 5

). . . .

JA

(°C/W)

JC

39

(°C/W)

4

Maximum Junction Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . .+125°C

Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . .-65°C to +150°C

Pb-Free Reflow Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see TB493

Recommended Operating Conditions

Ambient Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . -40°C to +85°C

Supply Voltage Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8V to 5.5V

Max Load Current (V
