LW Scientific Catalog
P. 770.270.1394
F. 770.270.2389
Products Guide
LABORATORY MICROSCOPES
CENTRIFUGES
3
i5
30
C5
4
i4
31
C3 Select
5
M5
32
CxR
6
M2
33
Ultra
7
Revelation lll
34
E8
8
Inverted
35
Portafuge
9
Semen Evaluation
37
Combo V24
10
M2 Rheumatology
38
M24
11
Infinity Epi-Fluorescence
39
Zip Series
40
Digital Tachometer
EDUCATION
12
13
Student Advanced
ALStudent
MICROSCOPES
Standard
41
Water Bath
14
Mobi Jr.
42
Turbo Mixer
43
Incubator
44
Digital Rotator
INSPECTION
LABORATORY
15
Z2 Zoom
45
Diff Counter / Refractometer
16
Vision
46
Pipette Shaker
17
Flex Arm
47
Lumin™ i4
18
Video Systems
48
Lumin™
19
IS-4Z
20
Bend-e
21
Achiever / Paragon
22
Illuminators
CAMERA / VIDEO
24
OmniVID
25
BioVID
26
MiniVID
27
d-VID
29
TFT Screen
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
2
i5
The i5 modular series microscope features exceptional optical quality and
expandability for top-notch performance in the lab. Use the rotating head to adjust
the height for taller users. Infinity Plan optics with a 30-year anti-fungal coating
match quality with value within any clinic’s budget. The i5 microscope provides
comfort, durability, dependability and superior imaging for the lifetime of the
laboratory.
HEAD
Binocular (Seidentopf), Trinoc available
Digital cameras and adapters available
Diopter adjustment
Inclined 30°, rotates 360°
10X/20X Super WF HP eyepieces
Interpupillary distance range 55-75mm
NOSEPIECE
i5
Reverse quintuple nosepiece
Multiple ball bearing mounted
Model #
OBJECTIVES
Infinity Plan objectives
4X, 10X, 20X, 40XR, 100XR (oil)
50X (oil) objective is also available
Anti-fungal, parfocal, parcentric, color-coded
Description
I4M-B05A-IPL3
Binoc head, 4-10-20-40-100 Infinity Plan objectives
I4M-T05A-IPL3
Trinoc head, 4-10-20-40-100 Infinity Plan objectives
‡0HGLFDO*UDGH0LFURVFRSH
‡$QWL)XQJDO&RDWLQJRQ$OO/HQVHV
‡/('³GD\OLJKW´ORQJOLIHLOOXPLQDWLRQ
STAGE
Mechanical stage (140mm X 155mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 73mm x 43mm
Stage locking lever
Slow-close hydraulic slide finger
FOCUS
Coarse adjustment: range of 30mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
OPTIONS
Phase contrast, 50x oil objective, camera
attachments, Koehler illumination, and more.
WEIGHT AND DIMS
Height: 14.1” (352.5 mm)
Length: 10.7” (267.5 mm)
Width: 6.1” (152.5 mm)
Weight: 23.0 lbs. (10.43 kg)
ILLUMINATION
Moveable Abbe condenser, NA 1.25
Iris Diaphram
LED “daylight” long-life light source
Variable light adjustment: 0-20W output
90-240V / 50-60Hz automatic-switching
power cord
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
3
i4
The i4 modular series microscope features exceptional optical quality and
expandability for top-notch performance in the lab. Use the rotating head to adjust
the height for taller users. Infinity Plan and Semi-Plan optics with a 30-year
anti-fungal coating match quality with value within any clinic’s budget. The i4
microscope provides comfort, durability, dependability and superior imaging for the
lifetime of the laboratory. Accessories include: blue and green filters,dust cover,
immersion oil, manual and warranty card.
HEAD
Binocular (Seidentopf), Trinoc available
Digital cameras and adapters available
Diopter adjustment
Inclined 30°, rotates 360°
10X/18 WF Eyepieces
(10X/20X Super WF HP eyepieces available)
Interpupillary distance range 55-75mm
NOSEPIECE
Reverse quadruple nosepiece
Multiple ball bearing mounted
OBJECTIVES
Infinity Semi-Plan or Plan objectives
4X, 10X, 40XR, 100XR (oil)
50X (oil) objective is also available
Anti-fungal, parfocal, parcentric, color-coded
STAGE
Mechanical stage (140mm X 155mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 73mm x 43mm
Stage locking lever
Slow-close hydraulic slide finger
i4
Model #
Description
I4M-B04A-IPL3
Binoc head, 4-10-40-100 Infinity Plan objectives
I4M-T04A-IPL3
Trinoc head, 4-10-40-100 Infinity Plan objectives
I4M-B04A-ISL3
Binoc head, 4-10-40-100 Infinity Semi Plan objectives
I4M-T04A-ISL3
Trinoc head, 4-10-40-100 Infinity Semi Plan objectives
‡0HGLFDO*UDGH0LFURVFRSH
‡$QWL)XQJDO&RDWLQJRQ$OO/HQVHV
‡/('³GD\OLJKW´ORQJOLIHLOOXPLQDWLRQ
OPTIONS
Phase contrast, 50x oil objective, camera
attachments, and more.
FOCUS
Coarse adjustment: range of 30mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
ILLUMINATION
Moveable Abbe condenser, NA 1.25
Iris Diaphram
LED “daylight” long-life light source
Variable light adjustment: 0-20W output
90-240V / 50-60Hz automatic-switching
power cord
WEIGHT AND DIMS
Height: 14.1” (352.5 mm)
Length: 10.7” (267.5 mm)
Width: 6.1” (152.5 mm)
Weight: 23.0 lbs. (10.43 kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
4
M5
The highly versatile M5 LabScope is built to withstand the rigors of daily laboratory
use in the pathology, hematology, cytology and microbiology lab. The five-position
nosepiece allows for specialized objectives, including 50X oil Plan, 60X high dry
Plan, 2X Plan and Phase Contrast objectives. The oversized 10X/20 high point
Plan eyepieces combined with Infinity Plan or DIN Plan objectives offer high
resolution flat-field imaging over a larger specimen area. The M Series was
designed for comfort and ease of operation, with all controls located ergonomically
within a finger’s reach. The M5 sets a new laboratory standard in microscopy.
HEAD
Binocular (Seidentopf) head
Trinocular with C-mount or eye tube
35mm and digital camera adapters available
Diopter adjustment
Inclined 30° (45° available), rotates 360°
10X/20 high point eyepieces (10X/22 available)
Interpupillary distance range 50-75mm
NOSEPIECE
Reverse quadruple nosepiece
Multiple ball bearing mounted
OBJECTIVES
Infinity Plan or DIN Plan objectives, anti-fungal
4X, 10X, 20X, 40XR, 100XR (oil)
Parfocal, parcentric, color-coded
STAGE
Mechanical stage (160mm x 140mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 77mm x 50mm
Stage locking lever
Slow-close hydraulic slide finger
Dual slide holder
FOCUS
Coarse adjustment: range of 30mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
OPTIONS
Ceramic stage, dark field condenser, phase
contrast turret, polarization, 50x oil objective,
heated stage, camera, etc.
M5
Model #
Description
M2M-B05A-DPL3
Binoc head, 4-10-20-40-100 DIN Plan objectives
M2M-T05A-DPL3
Trinoc head, 4-10-20-40-100 DIN Plan objectives
M2M-B05A-IPL3
Binoc head, 4-10-20-40-100 Infinity Plan objectives
M2M-T05A-IPL3
Trinoc head, 4-10-20-40-100 Infinity Plan objectives
‡3UHPLXP/:6FLHQWLILF/DE0LFURVFRSH
‡3RVLWLRQ1RVHSLHFH
‡6WDQGDUG/(',OOXPLQDWLRQ
ILLUMINATION
Moveable Abbe condenser, NA 1.25
Iris diaphragm
LED illumination
Optional: Halogen light source (12V/20W bulb)
Variable light adjustment: 0-20W output
Input 90-240V / 50-60Hz automatic switching
Koehler illumination
WEIGHT AND DIMS
Height: 16 1/2” (420mm)
Length: 10 5/8” (270mm)
Width: 7 7/8” (200mm)
Weight: 19.5 lbs. (9kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
5
M2
The M2 modular series LabScope features exceptional optical quality and
expandability for top-notch performance in the lab. The 10X/20 high-point Plan
eyepieces on super-wide eyetubes offer an extremely broad field of view, with
ample eye relief for users who wear eyeglasses. Infinity Plan or DIN Plan optics
match quality with value within any clinic’s budget. The M2 LabScope provides
comfort, durability, dependability and superior imaging for the lifetime of the
laboratory.
HEAD
Binocular (Seidentopf) head
Trinocular with C-mount or eye tube
35mm and digital camera adapters available
Diopter adjustment
Inclined 30° (45° available), rotates 360°
10X/20 high point eyepieces (10X/22 available)
Interpupillary distance range 50-75mm
M2
NOSEPIECE
Reverse quadruple nosepiece
Multiple ball bearing mounted
OBJECTIVES
Infinity Plan or DIN Plan objectives
4X, 10X, 40XR, 100XR (oil)
Anti-fungal, parfocal, parcentric, color-coded
STAGE
Mechanical stage (160mm x 140mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 77mm x 50mm
Stage locking lever
Slow-close hydraulic slide finger
Dual slide holder
Model #
Description
M2M-B04A-DPH3
Binoc head, 4-10-40-100 DIN Plan objectives
M2M-T04A-DPH3
Trinoc head, 4-10-40-100 DIN Plan objectives
M2M-B04A-IPH3
Binoc head, 4-10-40-100 Infinity Plan objectives
M2M-T04A-DPH3
Trinoc head, 4-10-40-100 Infinity Plan objectives
‡/DERUDWRU\*UDGH
‡3RVLWLRQ1RVHSLHFH
‡;+LJK3RLQW(\HSLHFHV
OPTIONS
Ceramic stage, dark field condenser, phase
contrast turret, polarization, 50x oil objective,
heated stage, camera, etc.
FOCUS
Coarse adjustment: range of 20mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
ILLUMINATION
LED Illumination
Moveable Abbe condenser, NA 1.25
Dual Iris diaphragms
Halogen light source (12V/20W bulb)
Variable light adjustment: 0-20W output
Input 90-240V / 50-60Hz automatic switching
WEIGHT AND DIMS
Height: 16 1/2” (420mm)
Length: 10 5/8” (270mm)
Width: 7 7/8” (200mm)
Weight: 19.5 lbs. (9kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
6
Rev lll
The Revelation III professional-grade microscope is a best-seller into physician
and veterinarian clinics, as well as universities and medical schools. Equipped for
performance, its features include titanium-finished DIN achromatic or DIN Plan
optics and a 30-year anti-fungal coating. The Revelation III is the choice for
superior performance at a great value! Included accessories: three 0.5 amp fuses,
mirror attachment (for field use), blue and green filters, dust cover, immersion oil,
spare bulb, manual and warranty card.
HEAD
Binocular (Seidentopf)
Inclined 30°, rotates 360°
Diopter adjustment
10X/18 wide field eyepieces (10X/20HP available)
Monocular, trinocular, dual binocular and
45° sliding heads available
Interpupillary distance range 55-75mm
NOSEPIECE
Quadruple forward-facing nosepiece
Multiple ball bearing mounted
OBJECTIVES
DIN Achromatic or DIN Plan
30 year anti-fungal coating
4X, 10X, 40X, 100XR (oil)
Parfocal, parcentric, color-coded
STAGE
Mechanical stage (140mm x 140mm)
Coaxial drive controls
Range of traverse is 73mm x 43mm
Stage locking lever
Slow-close hydraulic slide finger
Rev llI
Model #
Description
R3M-B04A-DAH3
Binoc head, 4-10-40-100 DIN Achromatic objectives
R3M-T04A-DAH3
Trinoc head, 4-10-40-100 DIN Achromatic objectives
R3M-B04A-DPH3
Binoc head, 4-10-40-100 DIN Plan objectives
R3M-T04A-DPH3
Trinoc head, 4-10-40-100 DIN Plan objectives
R3M-M04A-DAH3
Monoc head, 4-10-40-100 DIN Achromatic objectives
•Medical-Grade Microscope
•Anti-Fungal Coating on All Lenses
•Field-Ready Portable Options
OPTIONS
FOCUS
Coarse adjustment: range of 30mm
Fine adjustment: graduation of 2μm
Tension control knob
ILLUMINATION
Moveable Abbe condenser, NA 1.25, rack &
pinion
Iris diaphragm
110V/220V switchable electronics
12V DC battery input available
Light Options:
Variable halogen light source (12V/20W bulb)
Variable LED light source (7W bulb)
Dark field, phase contrast, soft carry case
WEIGHT AND DIMS
Height: 15” (380mm)
Length: 9” (230mm)
Width: 7” (178mm)
Weight: 14 lbs. (6.4kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
7
Inverted
The LW Scientific Inverted Microscope is able to perform intricate and varied
applications for vital tissue cultures. It is perfect for observation and education or for
professional research in a clinical lab. Pathologists, biologists and medical
researchers naturally choose this microscope. Accessories included: Green, blue
and neutral filters, dust cover, immersion oil, manual and warranty card.
HEAD
Trinocular head
Ideal for video/photography
Centering eyepiece for phase objective
EW 10X /22 extra wide field eyepieces
NOSEPIECE
Quintuple nosepiece
OBJECTIVES
Infinity Optical System
Objectives: Plan 4X and 40x,
Plan Phase 10x and 20x
STAGE
Stage, 160x260mm
Auxiliary stage, 70x180mm
Coaxial drive controls
Optional mechanical stage available:
X-Y Coaxial control
Range of traverse: 120x78mm
Inverted
Model #
L1M-T04A-DPH3
Description
Inverted Microscope
•Infinity Optical System
•Coaxial Drive Controls
•Centering Eyepiece for Phase Objective
OPTIONS
Multiple photo options
WEIGHT AND DIMS
FOCUS
Weight: 24.0 lbs.
Coarse adjustment: range of 37.7mm
Fine adjustment: 0.2mm per rotation
Vertical objective movement
ILLUMINATION
6V/30W halogen bulb
CONDENSER
Abbe condenser with 20X phase
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
8
Semen Evaluation
Perfect for veterinarians or fertility clinics, the Semen Evaluation LabScope is the
complete package for live specimen microscopy. Motility analysis should be
performed at 37 degrees Celsius to keep sperm active, and the heated stage has
a digital temperature control unit which can be set for any temperature between 25
and 50 degrees Celsius. The heated stage will maintain accurate and stable
temperatures within +/- 0.5 degrees during observation. Unplug the cord from the
stage, and this microscope looks and functions like a standard laboratory-grade
microscope. The Plan phase objectives and turret condenser allow flat-field,
high-contrast viewing of live, unstained specimens, and easy magnification
changes with the flip of the thumb.
APPLICATIONS
Semen evaluaton - motility analysis
Live biological specimen analysis
Functions as standard brightfield microscope as well
COMPLETE SYSTEM FEATURES
M2-P complete laboratory binocular microscope
10X/20 High-point, oversized WF eyepieces
Built-in heated stage with cord
X-Y mechanical stage for precise slide movements
Digital temperature control unit
DIN plan flat-field objectives
Phase 10x, Phase 40x, Phase 100x
Turret condenser with Phase, Darkfield, and
Brightfield
Variable halogen 20 watt Koehler illumination
110v or 220v AC power
Optional trinocular head with camera connections
HEATED STAGE SPECIFICATIONS
Variable digital temp. control from 25-50 degrees C
Set temperature in 1 degree increments
Displays actual temperature in 0.1 degree
increments
Accurate within 0.5 degrees C
Reaches temperature within 1-2 minutes
Switchable power input 110v or 220v AC
Semen Evaluation
Model #
M2S-SEB4-DPH3
Description
Complete Semen Evaluation Labscope
•Accurate temperatures within +/- 0.5 degrees
•10X/20 High Point Oversized Eyepieces
•Anti-fungal Coating on Optics
DIGITAL CONTROL UNIT DIMS
Height: 6.5” (153 mm)
Length: 9” (225 mm)
Width: 3.4” (84 mm)
Weight: 5.5 lb. (2.5 kg)
MICROSCOPE DIMS
Height: 16 1/2” (420 mm)
Length: 10 5/8” (270 mm)
Width: 7 7/8” (200 mm)
Weight: 20 lbs. (9 kg)
INCLUDES
Spare 2 amp fuse, spare 12v/20w halogen bulb,
blue-green-yellow filters, immersion oil, dust cover,
manual, and warranty card
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
9
M2 Rheumatology
The M2 Rheumatology LabScope is an essential tool for synovial fluid analysis.
Crystal-induced arthritis, such as gout or pseudogout, can be identified and
differentiated with the use of the polarizing attachment and red compensator lens.
The Rheumatology LabScope also functions as a flat-field, laboratory-grade
microscope for routine cytology, hematology, urinalysis, etc. This specialized
system was designed to combine high-resolution optics with functionality at an
affordable price for the Rheumatologist. Accessories included: one 2 amp fuse,
spare 12V/20W bulb, blue, green, and yellow filters, dust cover, immersion oil,
manual and warranty card.
HEAD
Binocular (Seidentopf)
Optional trinocular with C-mount or eye tube
35mm and digital camera adapters available
Diopter adjustment
Inclined 30° (45° available), rotates 360°
10X/20 high point eyepieces (10X/22 available)
Interpupillary distance range 50-75mm
M2
NOSEPIECE
Reverse quadruple nosepiece
Multiple ball bearing mounted
OBJECTIVES
DIN Plan flat-field objectives
4X, 10X, 40XR, 100XR (oil)
Anti-fungal, parfocal, parcentric, color-coded
STAGE
Mechanical stage (160mm x 140mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 77mm x 50mm
Stage locking lever
Slow-close hydraulic slide finger
Dual slide holder
Model #
Description
M2S-RHB4-DPH3
Binoc Rheumatology LabScope
M2S-RHB4-IPH3
Binoc Infinity Rheumatology LabScope
M2S-RHT4-IPH3
Trinoc Infinity Rheumatology LabScope
‡/DERUDWRU\*UDGH
‡3RVLWLRQ1RVHSLHFH
‡;+LJK3RLQW(\HSLHFHV
OPTIONS
Ceramic stage, dark field condenser, phase
contrast turret, polarization, 50x oil objective,
heated stage, camera, etc.
WEIGHT AND DIMS
FOCUS
Coarse adjustment: range of 20mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
Height: 16 1/2” (420mm)
Length: 10 5/8” (270mm)
Width: 7 7/8” (200mm)
Weight: 19.5 lbs. (9kg)
ILLUMINATION
Polarizing kit included
Moveable Abbe condenser, NA 1.25
Iris diaphragm
Halogen light source (12V/20W bulb)
Variable light adjustment: 0-20W output
Input 90-240V / 50-60Hz automatic switching
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
10
Infinity Epi-Fluorescence
The M2 LabScope with epi-fluorescence features a 100W HBO light system with
blue and green exciting light filters. This scope is an ideal tool for immunology and
other specialized applications. This system creates UV light at specific
wavelengths for exciting fluorochrome-stained specimens. The light housing is
mounted between the body and head of the microscope and includes a
variable-control transformer box. A convenient centering screen is built into the
front of the unit for fast and precise centering of the bulb. This unit can also be used
as a standard microscope by sliding the filter cube housing to the “O” (ordinary
light) position.
HEAD
Binocular (Seidentopf)
Trinocular with 35mm or C-mount camera tube available
Inclined 30 degrees
Rotates 360 degrees
10x/20 High Point eyepieces
Interpupillary distance range 50-75mm
NOSEPIECE
Reverse nosepiece
Quadruple—multiple ball bearing
Available with 5-objective nosepiece
Protective filter
OBJECTIVES
Infinity Plan objectives; Anti-fungal coating
4X infinity NA .10
10X infinity NA .25
40XR infinity NA .65 Retractable
100XR infinity NA 1.25 (oil) Retractable
20X infinity NA .40 (available on the M5 model only)
STAGE
160mm x 140mm stage
Coaxial drive controls
Range of traverse is 77mm x 50mm
Stage locking lever
Lateral and forward/reverse positioning
Slow-close hydraulic slide finger
WEIGHT AND DIMS
Width: 7 7/8" (200 mm)
Height: 16 1/2" (420 mm)
Length: 10 5/8" (270 mm)
Weight: 19.5 lbs. (9 Kg)
Infinity Epi-fluorescence
Model #
Description
M2M-BO4A-EPI3
Binoc head, epi-fluorescence (100w), 4 objectives
M2M-BO5A-EPI3
Binoc head, epi-fluorescence (100w), 5 objectives
•100W HBO Light System
•10X/20 High Point Oversized Eyepieces
•Anti-fungal Coating on Optics
ILLUMINATION
Moveable Abbe Condenser (NA 1.25)
Iris Diaphragm
Halogen light source (12v 20w bulb)
Variable light adjustment: 0 - 20 watt output
90-240 volt variable / 50-60 Hz
Epi-fluorescence:
20v 100w HBO superhigh pressure spherical
mercury lamp
2 exciting light waves (blue and green)
Exciting blue light spectrum: 450~480 nm
Exciting green light spectrum: 510~550 nm
FOCUS
Coarse adjustment: range of 30mm
Fine adjustment: graduation of 2μm
Tension control knob
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
11
Student Advanced
For the teacher that wants more than just the basic microscope for his classroom
this advanced model is an excellent choice. The 1.25 ABBE condenser allows the
addition of a100x oil immersion objective. The iris diaphragm allows precision
adjustments to the cool fluorescent light. Included accessories: dust cover, blue
and green filters, fuse, spare bulb.
HEAD
Standard monocular head
Bearing mounted, rotates 360°
10X/18 wide field eyepiece
Locked-in eyepiece with pointer installed
Teaching head available
CONSTRUCTION
Heavy cast alloy
Acid and reagent resistant finish
All metal gearing
Student Advanced
Model #
OBJECTIVES
Four position nosepiece
DIN Achromatic 4X, 10X, 40XR (retractable)
Optional 100x oil objective
Parfocal and parcentric
Color coded
STAGE
Pre-drilled and tapped for optional mechanical
stage
Spring-loaded slide clips included
Stage size: 110mm x 110mm
ILLUMINATION
NA 1.25 ABBE condenser
Iris Diaphragm
5w fluorescent
Input 110V (220V optional)
Optional Rechargeable LED base available
ADJUSTMENT CONTROLS
Coaxial coarse and fine focus
Adjustable stage stop
Description
EDM-M03A-DAF1
Monoc head, 4X, 10X, 40X objectives
EDM-M04A-DAF1
Monoc head, 4X, 10X, 40X, 100X objectives
EDM-M03A-DALP
Monoc head, 4-10-40 objectives, LED illumination, cordless
EDM-M04A-DALP
Monoc head, 4-10-40-100 objectives, LED illumination, cordless
•Iris Diaphragm
•Optional 100x objective
•Coaxial Focus Knobs
DIMENSIONS AND WEIGHT
Height: 14” (356mm)
Length: 7.0” (178mm)
Width: 5.25” (134mm)
Weight: 6.1 lbs. (2.8kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
12
Student Scope
This student microscope has everything necessary for the middle school or high
school classroom. This is a proven design with student proof features such as
locked-in eyepieces, and a durable disk diaphragm. Clear DIN optics, coarse and
fine focus, illumination and stage options make this scope a guaranteed winner.
Included accessories: Dust cover, one fuse, spare bulb, manual and warranty card.
HEAD
Standard monocular head
Bearing mounted, rotates 360°
10X/18 wide field eyepiece
Locked-in eyepiece with pointer installed
Teaching head available
CONSTRUCTION
Heavy cast alloy Head Objectives
Acid and reagent resistant finish
All metal gearing
Student Scope
Model #
OBJECTIVES
Triple nosepiece
DIN Achromatic 4X, 10X, 40XR (retractable)
Parfocal and parcentric
Color coded
EDM-M03D-DAF1
Description
Monoc head, 4X, 10X, 40X, fluorescent illumination
‡&RVW(IIHFWLYH%LG6FRSH
‡'LVN'LDSKUDJP
‡7ULSOH1RVHSLHFH
WARRANTY
STAGE
Pre-drilled and tapped for optional mechanical
stage
Spring-loaded slide clips included
Stage size: 110mm x 110mm
ILLUMINATION
NA 0.65 condenser
Five position disk diaphragm
Standard 5w fluorescent
Optional 20w tungsten and
Rechargeable LED bases available
Input 110V (220V optional)
One year on materials and workmanship
One year on electronic components
DIMENSIONS AND WEIGHT
Height: 14” (356mm)
Length: 7.0” (178mm)
Width: 5.25” (134mm)
Weight: 6.1 lbs. (2.8kg)
ADJUSTMENT CONTROLS
Coarse and fine focus with tension adjustment
Adjustable stage stop
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
13
Mobi, Jr
The MOBI, Jr. microscope is designed for elementary and junior high classroom
use. The LED light source combines a rechargeable battery with a bright, white
LED bulb for up to 40 hours of use on a single charge. Standard features include a
disk diaphragm, three hole nosepiece, and a 10x widefield eyepiece.
CONSTRUCTION
Heavy cast alloy
Acid and reagent resistant finish
HEAD
Standard monocular head
Bearing mounted, rotates 360°
45° inclined head
10X/18 wide field eyepiece
Locked-in eyepiece with pointer
Mobi, Jr
OBJECTIVES
Achromatic
4X, 10X, 40XR
Parfocal and parcentric
Three-position forward nosepiece
STAGE
Spring-loaded slide clips included
Optional mechanical stage
Stage size: 90mm x 90mm
Model #
EDM-M03D-DALP
Description
MOBI Jr. Cordless LED Scope
‡%ULJKW/('EXOE
‡5HFKDUJHDEOHEDWWHU\
‡[[DQG[REMHFWLYHV
POWER SUPPLY
Rechargeable nickel metal hydride battery
Up to 40+ hours per charge
Battery life of 500 cycles
Recharges in approximately 8 hours
3 AA NiMH Batteries
ADJUSTMENT CONTROLS
Medium focus
Adjustable stage stop
ILLUMINATION
NA 0.65 single lens condenser
Five-position disk diaphragm
Bright white LED illumination
Bulb life of 100,000 hours
WEIGHT AND DIMS
Height: 11.5”
Length: 6.25”
Width: 4.75
Weight: 3.4 lbs.
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
14
Z2 Zoom
Starting with CAD design techniques, we have manufactured the new Z2 to exceed
the clarity and quality of any zoom microscope available today. The depth of focus,
field flatness, zoom parfocality and long working distance improve inspection
accuracy and flexibility. The high point eyepieces offer ergonomic comfort and
allow users to wear eyeglasses. The mechanical two-finger operation is smooth
and easy to use, reducing hand strain and improving productivity.The Z2 is the
premium choice for industrial inspection or laboratory dissection.
CONSTRUCTION
Aluminum alloy construction
Acid and scratch resistant finish
HEAD
Inclined 45°, rotates 360°
10X/20 WF high point eyepieces with rubber eyeguards
Interpupillary distance 47-78mm
Trinocular available with three eye tubes live
OBJECTIVES
0.65X to 4.5X hard-coated zoom objectives
Standard magnification range is 6.5X to 45X
Maximum magnification 225X
FOCUS
Large dual focusing knobs with metal rack & pinion
Metal pinion gear zoom mechanism
Maximum height 10" (250mm)
ILLUMINATION
Dual illuminators with independent switches
Variable halogen incident light: 12V/20W (MR-11)
Fluorescent transmitted light: 110V/5W
STAGE
Frosted glass stage plate
Black & white contrast plate included
POWER
110V AC (220V optional), 2 amp fuse
OPTIONS
Boom stands, fiber optic illumination, high power lenses
Z2 Zoom
Model #
Description
Z2M-BZM7-7FH1
Binoc head, pole base stand, halogen / fluorescent illumination (top/bottom)
Z2M-TZMC-7FH1
Trinoc head, pole base stand, halogen / fluorescent illumination (top/bottom)
Z2M-BZM7-BM77
Binoc head, boom stand, optional illumination
Z2M-TZMC-BM77
Trinoc head, boom stand, optional illumination
• Industrial/Laboratory Grade
• Zoom Magnification from 6.5X to 45X
• Trinocular Head Boasts “All Three Live”
WARRANTY
Lifetime on materials and workmanship
One year on electronic components
DIMENSIONS AND WEIGHT
Height: 15”(380mm)
Length: 11”(280mm)
Width: 8”(203mm)
Weight: 12 lbs. (5.4kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30045
LWScientific.com
15
Vision
The Vision is an industrial grade, dual-magnification stereo microscope designed
IRU³KDQGVXQGHU´RSHUDWLRQ7KHORQJZRUNLQJGLVWDQFHDQGH[WUDZLGHILHOGRIYLHZ
make ultra-fine details easy to detect and manipulate. The pole mount, variable
halogen light and wide base give your workspace plenty of flexibility, while the
optional ring light offers shadow-free illumination. The objectives rotate internally
with a convenient control knob. The Vision is an economical choice where superior
optical quality is a must, but zoom capability is not required.
CONSTRUCTION
Aluminum alloy construction
Acid and scratch resistant finish
HEAD
Binocular, inclined 45°, rotates 360°
10X/22 WF high point eyepieces with rubber eyeguards
Interpupillary distance 50-95mm
30mm eyetube
OBJECTIVES (3 CHOICES)
Choose from 1X/2X, 1X/3X, or 2X/4X paired objectives
Objectives rotate internally by dual selector knob
FOCUS
Large dual focusing knobs with metal rack & pinion
Height adjustment with bottom stop
Maximum height 10" (250mm)
ILLUMINATION
Dual illuminators with independent switches
Variable halogen incident light: 12V/20W
Fluorescent transmitted light: 110V/5W
STAGE
Frosted glass stage plate
Black & white contrast plate included
POWER
110V AC (220V optional), 2 amp fuse
OPTIONS
Boom stands, fiber optic illumination, high power lenses
Vision
Model #
Description
VSM-S12N-7FH1
10x / 20x magnification, pole base stand, halogen / fluorescent illumination
VSM-S13N-7FH1
10x / 30x magnification, pole base stand, halogen / fluorescent illumination
VSM-S24N-7FH1
20x / 40x magnification, pole base stand, halogen / fluorescent illumination
VSM-S12N-BM77
10x / 20x magnification, boom stand, optional illumination
VSM-S13N-BM77
10x / 30x magnification, boom stand, optional illumination
VSM-S24N-BM77
20x / 40x magnification, boom stand, optional illumination
‡'XDO0DJQLILFDWLRQ&KRLFHV;WR;
‡3HUIHFWIRU³+DQGV8QGHU´:RUN
‡6XSHULRU&ODULW\DQG'HSWKRI)LHOG
WEIGHT AND DIMS
Height: 15”(380mm)
Length: 11”(280mm)
Width: 8”(203mm)
Weight: 9.9 lbs. (4.5kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
16
Flex Arm
9,6,21)/(;$50
7KH9LVLRQ)OH[$UPODERUDWRU\JUDGHVWHUHRVFRSHRIIHUVWKHZLGHVWYLHZDQGILQHVW
UHVROXWLRQ RI DQ\ GXDOPDJQLILFDWLRQ VWHUHRVFRSH DYDLODEOH IRU LQVSHFWLRQ
WHFKQLFLDQV 7KH )OH[ $UP VWDQG KDV VSULQJORDGHG KLQJH MRLQWV ZLWK IULFWLRQ
DGMXVWPHQWVWRKROGDQ\SRVLWLRQDQGFDQEHHDVLO\URWDWHGƒZKHQQRWLQXVH
0RXQW LW ZLWK WKH &&ODPS RU VFUHZ LW GLUHFWO\ RQ WKH FRXQWHU WRS 7KH 9LVLRQ¶V
ODUJHURSWLFVSURGXFHLQFUHDVHGZLGWKZRUNLQJGLVWDQFHDQGGHSWKRIIRFXV7KH
REMHFWLYHV URWDWH LQWHUQDOO\ ZLWK D FRQYHQLHQW FRQWURO NQRE ZKHQ FKDQJLQJ
PDJQLILFDWLRQ 7KH RSWLRQDO ; VXSSOHPHQWDU\ OHQV GRXEOHV \RXU ILHOG RI YLHZ
H[SDQGV \RXU PDJQLILFDWLRQ RSWLRQV DQG H[WHQGV \RXU ZRUNLQJ
GLVWDQFH WR RYHU LQFKHV IRU KDQGVXQGHU ZRUN VSDFH 7KH
EXOE /(' YDULDEOH ULQJ OLJKW IRFXVHV VKDGRZIUHH LOOXPLQDWLRQ
GLUHFWO\ RQWR \RXU ZRUN 7KH 9LVLRQ )OH[ $UP LV WKH EHVW TXDOLW\
GXDOPDJ VFRSH LQ WKH GHQWDO HOHFWURQLF DQG LQGXVWULDO PDUNHWV
0D[LPXPDUPUHDFKLQFKHVPP
Flex Arms
3$5$*21)/(;$50
Model #
7KH 3DUDJRQ )OH[ $UP VWHUHRVFRSH H[FHHGV WKH
SHUIRUPDQFH GHPDQGV RI GHQWDO LQGXVWULDO DQG
ODERUDWRU\WHFKQLFLDQVDWDQLQGXVWU\OHDGLQJSULFH
7KH)OH[$UPVWDQGKDVVSULQJORDGHGKLQJHMRLQWV
ZLWK IULFWLRQ DGMXVWPHQWV WR KROG DQ\ SRVLWLRQ DQG
FDQEHHDVLO\URWDWHGGHJUHHVZKHQQRWLQXVH
0RXQWLWZLWKWKH&FODPSRUVFUHZLWGLUHFWO\RQWKH
FRXQWHUWRS
7KH
3DUDJRQ¶V
ZLGHILHOG
GXDOPDJQLILFDWLRQ RSWLFV RIIHU KLJK UHVROXWLRQ DQG
FODULW\ DFURVV D EURDG ILHOG RI YLHZ 7KH RSWLRQDO
Description
VSM-S12N-FA77
Vision on Flex Arm, 10x / 20x magnification
VSM-S13N-FA77
Vision on Flex Arm, 10x / 30x magnification
VSM-S24N-FA77
Vision on Flex Arm, 20x / 40x magnification
APM-S12N-FA77
Paragon on Flex Arm, 10x / 20x magnification
APM-S13N-FA77
Paragon on Flex Arm, 10x / 30x magnification
APM-S24N-FA77
Paragon on Flex Arm, 20x / 40x magnification
;VXSSOHPHQWDU\OHQVGRXEOHV\RXUILHOGRIYLHZ
H[SDQGV \RXU PDJQLILFDWLRQ RSWLRQV DQG H[WHQGV
Vision Flex Arm
\RXU ZRUNLQJ GLVWDQFH WR RYHU LQFKHV IRU
‡,GHDOIRU'HQWDO,QGXVWULDODQG(OHFWURQLF,QVSHFWLRQ
‡/DERUDWRU\*UDGH'XDO0DJQLILFDWLRQ
‡&ODPSRU7DEOH0RXQW5RWDWHVƒ
‡6SULQJORDGHG+LQJHG$UP5HDFKHV)HHW
KDQGVXQGHU ZRUN VSDFH 7KH RSWLRQDO ZDWW
YDULDEOHIOXRUHVFHQWULQJOLJKWJLYHVGHJUHHVRI
VKDGRZIUHHLOOXPLQDWLRQ7KH3DUDJRQ)OH[$UPLV
WKH LGHDO FRPELQDWLRQ RI TXDOLW\ HFRQRP\ DQG
Paragon Flex Arm
IOH[LELOLW\
‡,GHDO&RPELQDWLRQRI4XDOLW\(FRQRP\DQG)OH[LELOLW\
‡'XDO0DJQLILFDWLRQ:LGH)LHOG/RQJ:'
‡&ODPSRU7DEOH0RXQW5RWDWHVƒ
‡/RZHVW&RVW,QVSHFWLRQ6\VWHP)URP/:6
P 770.270.1394
F 770.270.2389
0DUDWKRQ3DUNZD\
/DZUHQFHYLOOH*$
/:Scientific.com
17
Video Systems
The Video Zoom is a complete system for dental or industrial inspection. The Video
Zoom produces 3-D images through the eyepieces while displaying your work on the
screen. Two systems are available, featuring different cameras and illuminators.
OPTICS
Z2S-VS3Z-AT7I
VS-3Z
Both feature the Z2 Zoom optical head, zooming
from 3.25x to 22.5x with included 1/2x reducing lens
(and even up to 45x if you need it). Trinocular head
provides live images to camera and eyepieces at the
same time.
STAND
Z2S-OS1Z-AT7I
DVS-1Z
The black articulating arm extends 3 1/2 feet and
includes the heavy table plate. Optional c-clamp,
wall flange, and table flange are also available.
Video Systems
Model #
CAMERA
DVS-1Z Digital 8mp
Description
Z2S-OS1Z-AT7I
Zoom, Boom stand, Fiber optic ring light, OmniVID camera, Software
Z2S-VS3Z-AT7I
Zoom, Boom stand, LED ring light, BioiVID camera, Software
BVP-UVCD-SFT3
* USB Video Adapter with software
The Omnivid is the first “All-in-One” comprehensive
microscope camera on the market. It features
built-in live video on a bright 2-inch LCD screen, 8
megapixel digital imaging, and MPEG4 video
directly onto the included SD memory card.
VS-3Z Live Video
The BioVID features BNC-RCA and S video outputs
as well as on-screen programming, allowing the
user to modify and improve the image.
LIGHT
DVS-1Z Digital 8mp
Fiber optic ring light provides super-bright 150
watt light, 360 degree ring of cool light to
virtually eliminate shadows.
*Add the USB-VA to bring the live video signal into
your computer.
VS-3Z Live Video
Variable LED ring light features 60 bulb 6400K
daylight color, for true matching.
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
18
IS-4Z
Starting with CAD design techniques, we have manufactured the new Z2 to exceed
the clarity and quality of any zoom microscope available today. The depth of focus,
field flatness, zoom parfocality and long working distance improve inspection
accuracy and flexibility. The high point eyepieces offer ergonomic comfort and
allow users to wear eyeglasses. The mechanical two-finger operation is smooth
and easy to use, reducing hand strain and improving productivity.The Z2 is the
premium choice for industrial inspection.
LED ring lights offer shadow-free cold illumination with super-long-life bulbs at a
reduced cost. Long thumb screws allow for easy attachment to almost any brand
of microscope with mounting rings from 35mm up to 61mm. Mounting rings are
available for all LW Scientific stereoscopes.
Z2
CONSTRUCTIO
CONSTRUCTION
C
ONSTRUCTION
Aluminum alloy construction
Acid and scratch resistant finish
HEAD
Inclined 45°, rotates 360°
10X/20 WF high point eyepieces with rubber
eyeguards
Interpupillary distance 47-78mm
Trinocular available with three eye tubes live
Model #
Z2S-IS4Z-7777
OBJECTIVES
0.65X to 4.5X hard-coated zoom objectives
Standard magnification range is 6.5X to 45X
Maximum magnification 225X
FOCUS
Large dual focusing knobs with metal rack & pinion
Metal pinion gear zoom mechanism
Maximum height 10" (250mm)
POWER
110V AC (220V optional), 2 amp fuse
Description
Zoom stereoscope, LED ring light
RING LIGHT
LED
60 bright white focused LED bulbs
110v / 220v auto-switching
Control box with dimmer
1 amp fuse
Fits 35mm-61mm mount rings
Boxed: 2 lb (0.9 kg)
10” x 8” x 2.5”
REDUCING LENS
1/2X supplementary lens
Extends working distance to over 6 inches
STAGE
Frosted glass stage plate
Black & white contrast plate included
Doubles field-of-view
Reduces magnification range in half
Range: 3.25X to 22.5X
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
19
Bend-e Systems
The Bend-e System from LW Scientific is the most ergonomic, economical, and
efficient inspection system available for the dental lab. With modular
“Quick-Connect” components any configuration is possible, and it’s light-weight
and portable too. System magnifications include 2x, 4x, 5x, and 10x with long
working distances, deep depths of field, and high-resolution optics...which means
working under this scope is a breeze. Whether waxing, checking margins, checking
impressions, constructing implants, or even setting up dentures, quality and
customer satisfaction will increase with the Bend-e System.
ARMS
Any of the Bend-e System arms are available for
individual purchase, and can be mounted to any
workstation
benchtop
or
mounted
equipment
directly
without
onto
taking
up
other
any
benchspace. The Bend-e Shield is an affordable
safety shield that will mount anywhere, with
flexibility and rotation allowing it to swing in and out
of view.
Bend-e Systems
LIGHT
The Bend-e Scope does not require additional light
because it gathers plenty of ambient light from the
room. Supercharge your Bend-e Scope by adding
a fluorescent ring light for shadow-free, white,
variable illumination or the Bend-e Lite which will
handle up to 100-watt light bulbs. Add the Bend-e
LiteLens to the Bend-e Lite for additional 2x/4x
magnifications.
The Bend-e Scope stereo-microscope produces
sharp three-dimensional images, with amazing
optics
Description
BDS-BD1A-7777
Bend-e 5x/10x scope, table base (no light)
BDS-BD1B-7771
Bend-e 5X/10x scope, fluorescent ring light, table base
BDS-BD2A-7771
Bend-e 5x/10x scope, fluorescent ring light, maglens, table base
‡ Optical Inspection for Dental Laboratories
‡ Impressive Quality at a Surprisingly Low Price
‡ Modular Components for Customization
0.5x LENS
MICROSCOPE
light-gathering
Model #
with
impressive
performance.
Attached:
5x magnification, 1.5” (39mm) field of view,
7.25” (185mm) working distance.
Removed:
10x magnification, .75” (20mm) field of view,
5” (130mm) working distance.
MOUNTS
The Bend-e System will mount almost anywhere.
Choose from table base, c-clamp, wall mount,
table flange, or magnet base to mount your arms
to any surface at any angle without giving up
valuable bench space.
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30045
LWScientific.com
20
Achiever / Paragon
The Achiever stereoscope exceeds the performance demands of educators and is
built to with-stand daily use by students or hobbyists. Its crisp 3-D optics, dual
illumination, and large viewing area are excellent for dissecting and inspecting.
Ready for use in the field, the Paragon’s wide-field optics gather ambient light for
use without powered illumination, while the pole mount base offers flexibility and
portability. The fluorescent and LED ring light options give the Paragon a 360
degree flood of light for shadow-free illumination of irregular surfaces.
CONSTRUCTION
Aluminum alloy construction
Acid and reagent resistant finish
HEAD
Binocular, inclined 45°, rotates 360°
10X/20 WF eyepieces
30.5mm eye tube diameter
Interpupillary distance adjustment 55-80mm
Optional 15X eyepieces
Achiever / Paragon
OBJECTIVES (3 CHOICES)
1X/2X, 1X/3X, or 2X/4X paired objectives
0.5X supplementary lens available for Paragon
ADJUSTMENT CONTROLS
Helical rack & pinion focusing with tension
adjustment and slip clutch
Pole mount on Paragon allows for samples up to
170mm in height
ILLUMINATION
Achiever: 5W fluorescent illumination—
top and bottom dual independent rocker switches
Paragon: ambient light, optional ring lights
offer shadow-free illumination
STAGE
Achiever:frosted glass stage plate, 75mm diameter
Paragon: black and white reversible stage plate, 95mm
POWER
Achiever: 110V AC (220V optional)
2 amp fuse
Model #
Description
APM-S12N-7FF1
Achiever - 10X / 20X magnification, dual fluorescent illumination
APM-S13N-7FF1
Achiever - 10X / 30X magnification, dual fluorescent illumination
APM-S24N-7FF1
Achiever - 20X / 40X magnification, dual fluorescent illumination
APM-S12N-PL77
Paragon - 10X / 20X magnification, optional ring light illumination
APM-S13N-PL77
Paragon - 10X / 30X magnification, optional ring light illumination
APM-S24N-PL77
Paragon - 20X / 40X magnification, optional ring light illumination
•Best-Selling Educational Stereoscopes
•10X/20X, 10X/30X or 20X/40X Magnifications
•Proven Design and Performance
WEIGHT AND DIMS
Achiever:
Paragon:
Height: 12.8” (325mm)
Length: 9” (229mm)
Width: 6.5” (165mm)
Weight: 9 lbs (4.1kg)
Height: 15” (381mm)
Length: 9” (229mm)
Width: 5.9” (150mm)
Weight: 6 lbs. (2.7kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
21
Illuminators
Fluorescent and LED ring lights offer shadow-free cold illumination with
super-long-life bulbs at a reduced cost. Long thumb screws allow for easy
attachment to almost any brand of microscope. The newly-redesigned fluorescent
ring light is the most affordable option, and the LED models produce the most
intense, focused illumination with 10,000-hour white LED bulbs. The economical
48-bulb LED ring light features variable intensity control, and the new 60-bulb LED
ring light is variable and programmable for segmented quadrants to cast shadows
when necessary.
FLUORESCENT
Fluorescent Ring Light
10-watt, 6400K bulb
110v (220v) AC input
Spare bulb included
Fits 42mm-70mm mount rings
Boxed: 0.8 lb
13.5” x 7.5” x 2.5”
LED Ring Light
LED
48 bright white focused LED bulbs
110v / 220v auto switching
1 amp fuse
Adjustable dimmer
Fits 36mm-61mm mount rings
Boxed: 0.6 lb
9” x 8” x 2”
SEGMENTED LED
Variable Fluorescent and LED
Model #
Description
ILL-FLR7-1071
Fluorescent Ring Light 10w (non-variable)
ILL-LEDV-R483
LED ring light, variable, 48 bulb
ILL-LEDS-R603
Segmented Variable LED Ring Light - 60 bulb
Segmented Ring Light
Segmented quadrants for shadowing
60 bright white focused LED bulbs
110v / 220v auto switching
1 amp fuse
Adjustable dimmer
Fits 40mm-60mm mount rings
Boxed: 0.8 lb
9” x 8” x 2”
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
22
Illuminators
POLARIZING LED
LW Scientific LED ring light with Polarizing filters is perfect for glare-free
illumination under inspection microscopes. This polarizing LED light reduces glare
from reflective surface while allowing illumination from LEDs to pass through
polarizing filters to illuminate the object. Rotating the outer ring aligns the analyzer
with the polarizer and results in images with minimal glare and greater contrast.
The polarizing filter attachment can be removed to get maximum light intensity
from your LED light.
SPECIFICATIONS
60 bright white focused LED bulbs
110v / 220v auto-switching
Control box with dimmer
Polarizing filter assembly
Fits 27mm - 61mm mount rings
WEIGHT AND DIMS
Boxed: 2lbs (0.9kg)
Size: 10” x 8” x 2.5”
Polarizing LED
Model #
ILL-LEDV-POL3
Description
Polarizing Variable LED Ring Light
COMPARE
Without Polarizer
With Polarizer
FLUORESCENT
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
23
OmniVID
With
upgraded
MicroCap
software
Version
3.0
the
OmniVID
includes
comprehensive measuring capabilities with saved calibrations for multiple
microscopes. Connect to any size TV for training large groups, or connect to a PC
for capturing digital images or digital video in the easy-to-use MicroCap V2.0
measuring software. Use the wireless remote control to snap pictures or access the
menu and playback modes. The Omnivid mounts directly onto any microscope
trinocular head with C-Mount threading. The OmniVID camera on an LW Scientific
microscope is the ultimate microscopic imaging solution.
CAMERA
Sensor resolution: 3.1 megapixel
Maximum resolution: 8 megapixel
LCD screen size: 2 inch LTPS
Memory card: SD/MMC card
USB interface: Yes
TV output: NTSC/PAL
Controller: Remote and USB shutter
Power Supply: DC 12V 1.5A
Picture Format: JPEG
Video Format: MPEG4
Printer support: PictBridge and DPOF
Mount: C-Mount
Optional stage micrometer available
for calibrating multiple microscopes
OmniVID
Model #
OVC-8MP2-CMT3
Description
Omni-VID C-mount camera with built-in screen
SOFTWARE
MicroCap V2.0
ACCESSORIES
TV out Cable
USB Shutter Cable
USB Cable
Remote Controller
Power Adapter
SDG Card
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
24
BioVID
The BioVID features BNC-RCA and S video outputs as well as on-screen
programming, allowing the user to modify and improve the image. Connect the
camera to your trinocular microscope with a C- or CS-mount or use the included
macrolens and eyepiece adapter to work with a variety of optical equipment. The
BioVID camera will connect over the eyepiece of any monocular or binocular
microscope for live video microscopy. Optometrists and ophthalmologists can
connect the BioVID directly to their slit lamps for prediagnostic exams. The BioVID
is an excellent tool for demonstrations in medical, laboratory, and industrial
inspection applications.
TEXT DISPLAY
24 alphanumeric characters
(ON/OFF selectable)
BACKLIGHT COMP.
ON/OFF selectable
(6 sensing zones)
SPECIAL MENU
Gamma, color adjustment, sharpness, contrast,
brightness, flickerless and preset
LENS
C/CS mount
F1.2
8mm
Manual iris
POWER
DC12V~DC13V
2.5 Watt
OPERATING COND.
-10°C to +50°C (14°F to 122°F)
Less than 85% relative humidity
SIGNAL SYSTEM
NTSC or PAL available
OUTPUT
S video, BNC composite
HORIZONTAL RESOLUTION
470 TV lines
BioVID
Model #
BVC-CN13-CMT1
Description
BioVID video camera w/ lens and eyepiece adapter
•A “Must Have” for Microscope Owners
•Specialized Tools for Adjusting and Aligning
•Detailed Picture Instruction Manual
SENSITIVITY
0.8 lux
ELECTRONIC SHUTTER
Off/auto/manual
WHITE BALANCE
Selectable auto-tracking (ATW),
preset (AWC), and manual
WEIGHT AND DIMS
Height: 1.6” (41mm)
Length: 2.1” (51.6mm)
Width: 1.6” (41mm)
Weight: 0.31lbs. (140g)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
25
MiniVID
The MiniVID eyepiece camera is available with an RCA output or USB connection.
Plug it in to your TV, VCR, or computer. Then, attach it to any microscope for instant
video micrography. The innovative MiniVID camera slips into any standard
microscope eyepiece tube, in place of the eyepiece or fits onto any standard
threaded c-mount.
MINIVID USB
Image Sensor
3.1M pixel CMOS chip
Max Pixels
2048 X 1536 pixels
Interface
USB 2.0
Exposure
Automatic
MVC-U3MP-EMT3
Saved Picture File Format
BMP, JPG
System Requirement
Windows 98, 7, XP, or Vista
Software
Scopephoto Senior micro-image
analysis software
Mounting Requirements
Standard eyetube (23mm and 30mm)
Standard c-mount (threaded)
MiniVID
Model #
Description
MVC-U3MP-EMT3
MiniVID USB eyepiece / c-mount video camera
MVC-RN77-EMT1
MiniVID RCA eyepiece video camera
MINIVID RCA
Image Sensor
1/3 inch color CMOS chip
Output
6-foot cord with composite video (RCA)
Sensitivity
5 lux
Signal
NTSC or PAL available
Power
9V DC < 1amp
Includes 110V AC adapter, 220V available
MVC-RN77-EMT1
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
26
d-VID USB
An excellent, easy to use handheld digital microscope with USB output interface
High resolution magnification at your fingertips! Real examination of any sector
that you prefer. Included with each d-VID digital microscope is software, which
leads you to “capture” either a photograph, video time-lapsed video with a simple
click. Also included; user guide and stackable spacers.
SPECIFICATIONS
Image Sensor: 1.30 Mega pixels (1/4”)
Video Capture Resolution: 1280x1024, 640x480,
320x240
Still Image Capture Resolution: Max.1280x1024
Color: 24bit RGB
Lens: Dual Axis 27X & 100X microscope lens
Focus range: Manual focus from 10mm to infinity
Flicker frequency: 50Hz/60Hz
Frame rate: Max 30f/s under 600 Lux Brightness
Magnification ratio: 10X-60X, 230X(>=17” LCD
display); 60X-230X (recommend specific stand for
suitable study)
Shutter speed: 1 sec to 1 / 1000 sec.
Video format: AVI format
White balance: Automatic
Exposure: Automatic
Light source: 8 LED fine tuned white light
Model #
DVC-U1MP-HH73
Description
1.3 mega pixel, hand-held USB camera
(switchable and adjustable)
OSD language: Support multi-languages, English for
default
Power supply: 5V DC from USB port (No need for
INDUSTRIES
Hobbyist
Dental
Electronics
Dermatology
Industrial
Educational
external power)
Size: 102mm (L) X 30mm (R)
Image Editing and Measurement Software
SYSTEM REQUIREMENTS
OS: Windows XP, Vista and
Windows 7
CPU: Pentium IV 1.0G, Celeron,
AMD Athlon
CD-ROM
Available USB 2.0 port
256MB RAM
100MB available hard disk space
Graphic card: 16-bit
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
27
FEATURES
BENEFITS
High Magnification
Super clear, high-clarity, close-up
images for perfect detail when documenting margins, impressions,
waxing, dissections, amount of
reduction, etc.
Color
Though not recommended for shading. The d-VID produces vivid color.
Takes pictures and records videos
Labs and doctors can review the
case instantly through email or live
chat (Skype).
Easy to operate
Includes auto-load software
Installs in minutes
Plug it in and you are ready to go
Point and click for digital pictures
instantly
Hand-hold or mount on tripod
(included)
White LED light
8 LED light bulbs
Adjustable intensity
Shadow free
Measuring capability
Edit photos, draw arrows, add text,
measure from point A to point B
Radius circle, diameter circle, three
point circle, rectangle angle, polygon, line, text.
Cost
Affordable to any size lab
Similar quality and higher resolution
than cameras costing $400-$500
28
5“ TFT Screen
The TFT Screen is our next generation monitor designed for education, inspection,
demonstration and day–to–day use inconjunction with video cameras. It features
brightness control, volume control, audio and video input. Ideal for teachers,
doctors or other professionals who use a video camera on a regular basis.
DIMENSIONS
Height: 5.6”
Width: 6.5”
Depth: 1.8”
Weight: 1 lb. 2 oz
CONTROLS
Volume
Color
Contrast
Brightness (270 CD/m2)
Normal / Reverse image switch
5” TFT Screen
CABLES
RCA plug video input connection
RCA plug audio input connection
Power cord
Model #
VIP-MN55-TFT1
Description
5“ Color TFT Screen
•Ideal for instructional use
•Space-saving design
CONNECTIONS
Power In / Video In / Audio In
MOUNTING STAND
Built–in incline support stand
Tripod screw mount in base
POWER
DC 12 volt 1 Amp
Center positive
110 or 220 volt adapter available
2 Amp replaceable fuse
VIDEO SIGNAL
NTSC or PAL – Automatic switching
SCREEN
5” – measured diagonally from corner to corner
960 horizontal X 240 vertical = 230,400 pixels
TFT active matrix
55 degree view angle left and right
Full color
AUDIO SIGNAL
Built–in speaker / Earphone output
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
29
C5
+RUL]RQWDO VHSDUDWLRQ RIIHUV PDQ\ DGYDQWDJHV RYHU WUDGLWLRQDO IL[HGDQJOH
separations, including tighter straight-line gel separations to reduce re-spins and
re-mixes. The C5 spins test tubes, up to 17.5 x 128mm, at speeds up to 5,000 rpm,
with microprocessor speed control. Simply program the digital time and speed and
the C5 will lock the lid and spin the load. G-forces up to 4,000g’s will produce
SODWHOHWSRRUSODVPD LQ PLQXWHV 7KH ]HURUSP LQWHUORFNLQJ PHWDO OLG ZLOO VWD\
locked until the rotor has come to a stop, to ensure safety. The all-metal rotor and
tube shields are built for strength and durability, and the wide-mouth metal bowl
DOORZV IRU HDV\ FOHDQXS 7KH ZKLVSHUTXLHW KHDY\GXW\ EUXVKOHVV '& PRWRU FDQ
handle high volume use and high-speed full loads for years to come.
ADVANTAGES
Straight-line separation for accurate processing
Reduces high potassium results
Tighter gel line reduces re-mixing
Eliminates most re-spins
Very high g-forces for fast separation
Fast and accurate veterinary fecal flotations
Platelet-poor-plasma in minutes
C5
DESIGN FEATURES
Rubber feet to prevent slipping
Impact-resistant lid with view port
Zero-rpm interlocking lid
Wide mouth for easy clean-up
Metal rotor and tube shields
SPECIFICATIONS
800-4,000 rpm (2,500g)
Brushless DC motor (220V available)
Programmable time and speed
Two 5 amp/250 volt fuses
8 place test tube rotor (5,000 rpm/4,000g)
Optional rotors:
4 place 50ml tube rotor (5,000 rpm/4,000g)
24-place swing-out bucket rotor
Holds 24 2.5ml-10ml test tubes
Holds 8 2.5ml-15ml conical unrine tubes
CONTROLS
Touch-pad time and speed controls
4-character digital display screen
1-60 minute programmable timer
800-5,000 rpm programmable speed
Model #
Description
C5C-08SV-15T3
Swing-out, 8-place
C5C-04SV-50T3
C5 with 50ml, 4 place rotor
C5A-04CC-PR77
Crit Carrier for spinning hematocrits
C5C-BKSV-15T3
C5, 24-place
‡+RUL]RQWDOVZLQJRXWFHQWULIXJH
‡:KLVSHUTXLHWEUXVKOHVV'&PRWRU
‡(FRQRPLFDOO\SULFHGIRUFOLQLFV
INCLUDES
The economical way to
achieve your blood
samples STAT!
3-prong power cord
8 tube shields
8 tube cushions (for shorter tubes)
WEIGHT AND DIMS
Height: 12” (304.8mm)
Length: 15.5” (394mm)
Width: 13.75” (350mm)
Weight: 38.2 lbs (17.3kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
30
C3 Select
Horizontal separation offers many advantages over traditional fixed-angle
separations, including tighter straight-line gel separations to reduce re-spins and
re-mixes. Additionally, spun fecal floatations in the veterinary markets produce
much higher ova recovery results when spun with coverslips on top of the test tube.
The C3 Select spins 3ml-15ml test tubes, up to 17mm x 128mm, at speeds up to
3,000 rpm. Select either blood, urine, or fecals on the speed control, set the
30-minute timer, and the C3 Select will spin at the correct speed. The all-metal
rotor is built for strength and durability, and the wide-mouth metal bowl allows for
easy cleanup. The whisper-quiet, brushless, heavy-duty motor can handle high
volume use and high-speed full loads for years to come.
ADVANTAGES
Straight-line separation for accurate processing
Pre-calibrated blood, urine, and fecal speeds
Reduces high potassium results in blood
Tighter gel line reduces re-mixing
Veterinary fecals spin with coverslips on the tube
Much higher ova recovery than standing fecal tests
C3 Select
DESIGN FEATURES
Rubber feet to prevent slipping
Metal-framed lid with view port
Locking lid with push-button release
Lid safety shut-off switch
Wide mouth for easy clean-up
Metal rotor and bowl
SPECIFICATIONS
Selectable 3-position Speed Control
• 3,000 rpm for blood - 1,500 g
• 1,600 rpm for urines and semen - 400 g
• 1,300 rpm for fecals - 280 g
Front-access calibration panel
Brushless, maintenance-free 110V motor
(220V brushed motor available)
8 test-tube (3ml-15ml) capacity
4-place 50ml rotor available
Maximum tube size 17.5mm x 133mm
One 5amp / 250 volt fuse, plus a spare
Model #
Description
C3C-08SS-1501
Swing-out, 8-place, selectable-speed centrifuge
C3C-04SS-5001
C3 with 50ml, 4 place rotor
• Horizontal Swing-out Centrifuge
• Selectable Speeds for Blood, Urine, Fecals
• Economically priced for clinics
INCLUDES
3-prong power cord
8 tube shields
8 tube cushions (for shorter tubes)
WEIGHT AND DIMS
Height: 12” (305mm)
Length: 18” (457mm)
Width: 14.5” (368mm)
Weight: 33 lbs (15kg)
CONTROLS
1-30 minute mechanical timer
3-position speed control
On/off switch on back
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
31
CxR
Horizontal
centrifugation
offers
advantages
over
traditional
angled-rotor
centrifuges, such as tighter straight-line gel separations, fewer re-spins and
re-mixes, and fewer high-potassium results. The new CxR centrifuge delivers 1800
G-Force for quick spin down of serum-separator blood tubes. Low-maintenance
features: self contained rotor, whisper-quiet operation, brushless no-maintenance
motor, automatic braking, simple operation...set the timer and go!
ADVANTAGES
Low profile Saves Counter Space
Tight gel line separation
– easier reads, and reduced re-mixes
6 Tube Capacity (accommodates 3-15ml tubes)
Large 17.5mm x 125mm tube capacity
SPECIFICATIONS
Fixed speed - 3400rpms
1800 G-Force
Brushless maintenance-free motor
6 Place (3-15 ml tube) rotor
Horizontal spin down
Front access timer control knob
CxR
Model #
CXC-06SF-1501
CONTROLS
Description
6 place horizontal swing out centrifuge
‡Economically priced for reference labs!
15 minute mechanical timer
On/off switch on back
WEIGHT AND DIMS
Height: 8.75”
Length: 15”
Width: 13.5”
Weight: 23.6 lbs
Height w/ lid open: only 19.75”
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
32
Ultra
The 8-place Ultra centrifuge has a unique, space-saving triangle shape to fit easily
into a corner. This unit, made of sturdy aluminum alloy, accommodates most test
tubes from 3ml-15ml. The wide stance eliminates wobble, while the suction-cupped
feet prevent slipping. The brushless motor (110V only) is virtually maintenance-free
and the clear lid allows easy viewing of specimens while in use.
Choose from 2 different models to meet your laboratory separation needs.
ADVANTAGES
Accurate speeds for specific g-forces
Proper separations without cell damage
Ideal for blood, urine and other fluids
Quiet, vibration-free operation
Unique space-saving triangle design
FEATURES
8-tube capacity - 3ml to 15ml size tubes
Auto-off 30-minute timer with bell
Brushless motor (110V only) - maintenance free
Blue LED power indicator light
Suction-cupped feet prevent slipping
All-metal one-piece body
110V power (220V available)
ULTRA SELECT
Selectable 4-position Speed Control
• 3,300 rpm for blood - 1,350 g
• 1800 rpm for urines and semen - 400 g
• 1,500 rpm for fecals - 275 g
• 800 rpm for other tests - 80 g
Timer and lid safety shut-off switch
C3 Select
Ultra
Model #
Description
ULC-08AV-1501
Variable Speed
ULC-08AS-1501
4-speed Selectable
•All-Metal One-Piece Design
•2 Models to Meet Any Lab Need
•Locking Lid for Safety
WEIGHT AND DIMS
Height: 9” (230mm)
Length: 13” (330 mm)
Width: 13” (330mm)
Weight: 15.5 lbs (7kg)
ULTRA VARIABLE
3,300 rpm variable speed - blood, urines, etc.
Timer and lid safety shut-off switch
Maximum RCF=1,350 g
INCLUDES
Eight-place tube rotor
Eight 15ml tube sleeves (TS-15ml)
Eight 13x75mm tube sleeve inserts (TS-1375)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
33
E8
The 8-place E8 centrifuge is an economical fixed speed centrifuge designed to fit
any budget. This unit accommodates most test tubes from 3ml - 15ml. The wide
stance eliminates wobble, while the suction-cupped feet prevent slipping. The
brushless motor (110V only) is virtually maintenance-free and the lid port allows
easy viewing and tach-ing of specimens while in use.
Choose from 2 different models to meet your laboratory separation needs.
ADVANTAGES
Accurate speeds for specific g-forces
Proper separations without cell damage
Ideal for blood, urine and other fluids
Quiet, vibration-free operation
Unique space-saving triangle design
FEATURES
8-tube capacity - 3ml to 15ml size tubes
Auto-off 30-minute timer with bell
Brushless motor (110V only) - maintenance free
Blue LED power indicator light
Suction-cupped feet prevent slipping
110V power (220V available)
E8 VARIABLE
3,300 rpm variable speed - blood, urines, etc.
Timer and lid safety shut-off switch
Maximum RCF=1,350 g
C3 Select
E8
Model #
Description
E8C-08AV-1501
Variable Speed
E8C-08AF-1501
Fixed Speed
‡2QH3LHFH'HVLJQ
‡0RGHOVWR0HHW$Q\/DE1HHG
‡/RFNLQJ/LGIRU6DIHW\
WEIGHT AND DIMS
E8 FIXED
3,300 rpm fixed speed - for blood only
Auto-of 30-minute timer with bell
Maximum RCF=1,350 g
Height: 10” (254mm)
Length: 10” (254mm)
Width: 10” (254mm)
:HLJKWOEVNJ
INCLUDES
Eight-place tube rotor
Eight 15ml tube sleeves (TS-15ml)
Eight 13x75mm tube sleeve inserts (TS-1375)
P 770.270.1394
F 770.270.2389
0DUDWKRQ3DUNZD\
Lawrenceville GA 30046
LWScientific.com
34
Portafuge
The portable 8-place Portafuge is an economical fixed speed centrifuge designed
for spinning on the go*. This unit accommodates most test tubes from 3ml – 15ml.
This unit is virtually maintenance-free and the lid port allows easy viewing and
tach-ing for calibration. Simply insert the cigarette plug into your car’s power outlet
for quick blood separation at 3000+ rpm.
*Do not operate centrifuge while driving.
ADVANTAGES
Portable, 12 v unit, works in any car
Light weight
Quiet, vibration-free operation
Space-saving design
FEATURES
Rubber feet to prevent wobble
8-tube capacity - 3ml to 15ml size tubes
12v DC motor - maintenance free
Blue LED power indicator light
Suction-cupped feet prevent slipping
80 watt power requirement
Maximum RCF=1300-1500 g
3000-3500 rpm fixed speed - for blood only
(speed may vary by car model)
Auto-off 30 minute timer with bell
45° Angled rotor
Portafuge
Model #
E8C-08AF-150P
Description
Portafuge centrifuge, fixed speed
ACCESSORIES
INCLUDES
Eight-place tube rotor
Eight 15ml tube sleeves (TS-15ml)
Eight 13x75mm tube sleeve inserts (TS-1375)
Lid Safety Switch
WEIGHT AND DIMS
Height: 10” (254mm)
Length: 10” (254mm)
Width: 10” (254mm)
Weight: 11 lbs (5kg)
CNP-CBL7-BC12
12 volt battery clamps
E8P-ADWL-12V8
AC-DC power adapter
E8P-HLD7-CAR7
Car seat
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
35
Benefits of Mobile Centrifugation
Home-health nurses and medics often draw blood from patients to run lab tests.
Common serum tests are:
*CMP – Comprehensive Metabolic Profile, runs 14 different tests.
*BMP – Basic Metabolic Profile, runs 8 different tests.
Are you spinning down your tubes within one hour?
It is highly recommended that CMP and BMP tubes be spun within one hour
otherwise glucose test results may be falsely low, and potassium test results may
be falsely high. To solve this issue home-health nurses often travel out to a
home, back to the lab, out to the next home, back to the lab, etc. If centrifugation is not possible within 1 hour, the nurse may need to draw an additional
Sodium Fluoride preservative tube to attain accurate Glucose test results,
adding more time and expense.
WITHOUT A PORTABLE CENTRIFUGE EXPECT
Higher costs for additional reagents
Higher costs for more test tubes and supplies
Higher costs for additional lab testing
Higher travel expenses
Fewer home patient visits per day
Less accurate lab test results
WITH THE PORTAFUGE EXPECT
Twice the customers per day
Reduced miles
Lower costs for tubes and reagents
More accurate lab test results
More satisfied patients
Greater profit
Without Portafuge
With Portafuge
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
36
Combo V24
Accomplish both test tube and microhematocrit separations with the new Combo
centrifuge. Simply choose a box (with or without a digital tachometer) and choose
your rotors. The Combo spins either test tubes, capillary tubes or microtubes by
simply changing rotors — no tools required! Achieve hematocrit separations in less
than five minutes at 12,000 rpm; then accurately determine results with the
included reader disc. Other features include variable speed control, 30-minute
timer, rubber feet, and all-metal body construction.
ADVANTAGES
One unit for all centrifuge needs
Fast spin, fast stop, fast read
Variable speed
Optional tachometer
Quiet vibration-free operation
FEATURES
Suction-cupped feet to prevent slipping
Impact-resistant safe-view lid
All-metal body construction
Cooling fan for motor compartment
Heavy duty high-speed motor
Safety shut off switch in lid
Locking lid
Wide mouth for easy clean-up
SPECIFICATIONS
12,000 rpm on high speed setting, RCF=14,800g
0-4,000 rpm variable on low speed setting,
RCF=2,325g
Combo V24
Model #
Description
CMP-BX77-7701
Combo centrifuge box with variable speed dial, timer, and brake (no tachometer)
CMP-BX77-77T1
Combo centrifuge box with digital tachometer, variable speed dial, timer, and brake
‡6SLQ+HPDWRFULWRU7HVW7XEHV
‡(DV\&KDQJH5RWRUV
‡7DFKRPHWHU2SWLRQIRU([DFW)RUFHVV
CHOOSE THE ROTORS
CONTROLS
Illuminated power switch
Electric brake for quick stop
High/low speed setting switch
Auto-off 30 minute timer with bell
Variable speed control
WEIGHT AND DIMS
Height: 11” (277mm)
Length: 17” (432mm)
Width: 14” (355mm)
Weight: 31.3 lbs (14.2kg)
CMP-RT24-75HE
Spin standard 75mm capillary tubes
with the 24-place microhematocrit
rotor. Results can be read directly from
the rotor with the included reader disk.
CMP-RT24-02MT
The 24-place microtube rotor holds
1.5 to 2 ml sized tubes.
CMP-RT12-15TT
The 12-place test-tube rotor holds
3ml-15ml sized tubes with included tube
shields and inserts for smaller tubes. 24
place rotor also available.
CMP-RT24-15TT
The 24-place test-tube rotor holds 15ml
sized tubes with included tube shields
and inserts for smaller tubes. 12 place
rotor also available.
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
37
M24
The M24 centrifuge is a truly affordable microhematocrit centrifuge. This unit is
designed for its ease of use in the laboratory. Spin hematocrits in less than 5
minutes at 12,000 rpm. The M24 has a microhematocrit reader disk provided with
every unit. Read the tubes directly on the rotor without picking them up.
ADVANTAGES
Fast results in just five minutes
Spins 24 standard 75mm capillary tubes
Ready-to-use...no add-on costs
Quiet, vibration-free operation
Reader disk included
FEATURES
Impact-resistant safe-view lid
All-metal body construction
Cooling fan for motor compartment
Aluminum rotor for low heat transfer
Heavy duty high-speed motor
Safety shut-off switch in lid
Locking lid
Wide mouth for easy clean up
M24
Model #
HEC-24HF-7501
SPECIFICATIONS
12,000 rpm fixed speed
Nominal RCF=14,800 g
Brushed motor
110V AC (220V AC available)
CONTROLS
Illuminated power switch
Electric brake for quick stop
Auto-off 15-minute timer with bell
Description
Microhematocrit centrifuge
• 24-Place Microhematocrit Centrifuge
• Affordable
• Results in Less Than 5 Minutes
WEIGHT AND DIMS
Height: 10” (235mm)
Length: 13” (330mm)
Width: 12” (304mm)
Weight: 23 lbs. (10.4kg)
INCLUDES
24-place hematocrit rotor
Reader disk— read tubes directly on the rotor
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
38
Zip Series
ZIPSPIN
‡ Portable and compact microcentrifuge
‡ Perfect for medical missionaries or field
veterinarians
‡ 6-place rotor for 1.5 and 2ml microtubes
‡ 12-place rotor for 0.5ml microtubes
‡ Powered by maintenance-free brushless
motor
‡ Variable speed: 0-7,000 rpm
‡ RCF up to 2,800g
‡ Designed for:
Cell separations
‡ Microfiltration of HPLC samples
‡ DNA preparations
‡ Small footprint to conserve space
‡ Safety switch lid
‡ Strobe-through transparent lid for exact speed
‡ Ideal for cold room applications
‡ LED power indicator light
‡ Durable lightweight aluminum alloy construction
‡ DC 12V power (AC adapter power cord
included)
‡ Optional 12V DC car battery cables and
220V AC adapter power cord available
ZIPOCRIT
‡ Portable and compact microhematocrit
centrifuge
‡ Perfect for medical missionaries or
veterinary field work
‡ Spins four 75mm capillary tubes in angled
rotor
‡ Mylar-coated or plastic capillary tubes
recommended - vial
of 200 tubes included; Critoseal clay
available
‡ Powered by a maintenance-free brush
less motor
‡ Speed: 11,000 rpm
‡ RCF: 4,400g
‡ Fifteen minute timer - separations in five
minutes
‡ Designed with a small footprint to
conserve space
‡ Safety switch lid
‡ Strobe through transparent lid for exact
speed
‡ LED power indicator light
‡ Durable lightweight aluminum alloy
construction
‡ DC 12V power (AC adapter power cord
included)
‡ Optional 12V DC car battery cables and
220V AC adapter power cord available
Zip Series
Model #
Description
ZPC-06AV-0203
ZipSpin centrifuge
ZPC-04HF-PURC
Zipocrit centrifuge
DIMENSIONS AND WEIGHT
Height: 4.5” (114.3mm)
Length: 8” (203mm)
Width: 6” (152mm)
Weight: 3.3lbs. (1.5kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
39
Digital Tach
Test your centrifuge for accuracy using the LW Scientific handheld digital
tachometer. Be certain that you are spinning fluids at the correct CLIA
recommended speeds. How do you know your variable speed centrifuge is
spinning urines at 400 g’s? Spinning too slowly may give inadequate results...
spinning too fast may damage cell structures. This unit is easy to use with results
in only one second. The tachometer will work on any centrifuge with a clear port in
the lid allowing the strobe light to reflect off of the rotor.
SPEED RANGE
20-40,000rpm
ACCURACY
+/- 20 rpm
Digital Tachometer
DETECTION TIME
1 second
Model #
CNA-TACH-DHH7
DETECTIVE DISTANCE
50-400mm
DISPLAY
5 digits
WORKING TEMPERATURE
0-50 Degrees Celsius
Description
Hand-held strobe tachometer
•Fast and Accurate
•Large, Easy to Read Display
•Compatible with Most Centrifuges
INCLUDES
Carry case
35” of reflective tape
DIMENSIONS AND WEIGHT
Height: 7.0” (180mm)
Width: 3.0” (78mm)
Depth: 1.5” (38 mm)
Weight: 10.5 ounces (300 g)
POWER
4 AA batteries (included)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
40
:DWHU%DWK
7KH /: :DWHU %DWK FUHDWHV D FRQVWDQW WHPSHUDWXUH ZLWK DQ RSHQ UHVHUYRLU DQG
LPPHUVLRQ FLUFXODWRU LGHDO IRU KHDWLQJ WHPSHUDWXUHVHQVLWLYH VDPSOHV 7KH
VWDLQOHVVVWHHOUHVHUYRLULVVHDPOHVVHOLPLQDWLQJWKHSRVVLELOLW\RIUXVWDQGOHDNV
DQGWKHURXQGHGFRUQHUVDUHHDV\WRFOHDQ7KHFRQWUROXQLWDFKLHYHVWKHGHVLUHG
WHPSHUDWXUH TXLFNO\ DQG PDLQWDLQV D FRQVWDQW WHPSHUDWXUH WR SUHYHQW VDPSOH
RYHUKHDWLQJ6HOHFWGHVLUHGVHWWLQJZLWKWKHWRXFKSDGGLJLWDOFRQWUROOHUDQGYLHZ
WKHDFWXDOWHPSHUDWXUHRQWKHUHG/('GLVSOD\7KHFRPSDFWGHVLJQDQGVWDLQOHVV
VWHHOUHVHUYRLUPDNHWKLVSURGXFWDPXVWIRUHYHU\ODE
TANK
Capacity 20L or requested
Stainless steel reservoir, corrosion
resistant
TEMPERATURE SETTING
Digital
TEMPERATURE READOUT
:DWHU%DWK
LED
Model #
TEMPERATURE CONTROL
PID
TEMPERATURE SENSOR
00 oKP PlatinXP57D
TEMPERATURE RANGE
$PELHQWƒWRƒ&
67$%,/,TY
+/- 02
POWER SUPPLY
0V220V available
WEIGHT
OEVNJ
Description
:%L0LC-SSD
/LWHU
:%L-20LC-SSD
20 Liter
‡([FHOOHQW7HPSHUDWXUH&RQWURO
‡&RQYHQLHQW/DUJH%DWK2SHQLQJ
‡6WDLQOHVV6WHHO5HVHUYRLU
ACCESSORIES
/LGIODWRUJDEOHGWHVWWXEHUDFNV
DIMS
+HLJKW´PP
:LGWK´PP
'HSWK´PP
INTERNAL TANK DIMS
+HLJKW´PP
:LGWK´PP
'HSWK´PP
P F 0DUDWKRQ3DUNZD\
/DZUHQFHYLOOH*$
LW6FLHQWLILFFRP
41
Turbo Mixer
LW Scientific offers you two versions of the very popular Turbo Mixers. Ideal for the
quick and complete mixing of samples, our cup and platform models will bring
convenience and efficiency to your lab. They come with a variable speed control of
up to 3000 RPM and can be activated to vibrate continuously or by pressure to the
head. The high quality motor comes with a one year warranty and has been
designed to offer quiet and vibration free vortex mixing action.
FEATURES
Suction cup feet
Metal construction
Motor fan
Compact and durable design
Variable speed control
Vibration-free
High quality motor
MXL-TMV7-7RC1
MXL-TMV7-7PL1
Turbo Mixer
SPECIFICATIONS
Speed: 3000 RPM
110V / 60Hz (220V available)
CONTROLS
On / off / touch switch
Power on light
Model #
Description
MXL-TMV7-7RC1
Turbo Mixer - Cup
MXL-TMV7-7PL1
Turbo Mixer - Platform
• Vibration-free
• Variable Speed
• Continuous Operation or Touch Control
WEIGHT AND DIMS
Height: 170mm (6.7”)
Width: 160mm (6.3”)
Depth: 130mm (5.2”)
Weight: 3.2Kg (7lbs)
MXL-TMV7-7RC1:
Cup head dimensions: 50 x 50 x 25mm
(2 x 2 x 1 inches)
MXL-TMV7-7PL1:
Platform head: 100mm diameter x 25mm height
(4” x 1”)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
42
Incubator
The new incubators from LW Scientific are suitable for various applications such
DVFXOWXUHVHJJLQFXEDWLRQDQGRWKHUPLFURELRORJ\DQGELRORJ\XVHLQKRVSLWDOV
LQGXVWULHV DQG ODERUDWRULHV 7KH 3,' 7HPSHUDWXUH &RQWURO SURYLGHV DXWRPDWLF
FRPSHQVDWLRQDIWHUORDGFKDQJHVVHWWLQJFKDQJHVRUGRRURSHQLQJIRUH[FHOOHQW
DFFXUDF\ DQG LW¶V QDWXUDO FRQYHFWLRQ KHDW GLVWULEXWLRQ FRPELQHG ZLWK WKH
DGMXVWDEOH DLU YHQWV SURYLGH H[FHOOHQW XQLIRUPLW\ 'XUDEOH HDV\ WR FOHDQ DQG
FRUURVLRQUHVLVWDQWRXULQFXEDWRUVRIIHU\RXLQFRPSDUDEOHTXDOLW\DQGHIILFLHQF\IRU
a very reasonable price!
*Quality certification: ISO 9001, CE
CONSTRUCTION
Attractive and durable exterior powder coating
Corrosion resistant
Stainless steel interior
Adjustable shelves
Double walls
Full fiberglass insulation
Silicon rubber sealing around doors
Natural convection heat
Adjustable air vents
Double doors. Interior transparent door
Incubator
Model #
TEMPERATURE
Ambient + 5ºC ~ 70ºC
Temperature stability is +
- 0.3ºC at 37ºC
ºC
at 70ºC
-
CONTROLS
Description
ICL-030L-0101
30 liter
ICL-050L-0171
50 liter
ICL-00L-01
0 liter
‡7HPSHUDWXUHVWRƒ&
‡'RXEOH'RRUV7UDQVSDUHQW,QWHULRU'RRU
‡&DSDFLWLHVDQG/LWHUV
Simple key-pad input
Digital LED display
ALARM
Visual alarm alerts when actual internal
temperature exceeds programmed temperature
by 10 °C
Note: The difference between actual and
programmed temperatures that triggers the
alarm can be defined by the user
POWER
110V - 60Hz V - 50/60Hz available
P F 0DUDWKRQ3DUNZD\
/DZUHQFHYLOOH*$
LWScientific.com
43
Digital Rotator
The Serology Rotator is designed to give years of dependable service, even in the busiest
laboratory. It’s the ideal space-saving instrument for procedures that require constant or
timed rotation (mixing) such as RPR, VDRL, latex tests and for procedures that require a
nonstandard speed.
FEATURES
Widely used in VDRL, RPR, and EIA tests
Stable and quiet operation
Clear humidity tray
Variable speed, timer control, and
continuous operation
SPECIFICATIONS
Speed: 20-240rpm
Timer: 99 hours and 99 minute digital timer
Power supply: AC 110V 60Hz
(220V 50/60Hz available)
Load capacity: 4.4lbs at 20-150rpm
2.2lbs at 151-240rpm
Digital Rotator
Model #
WEIGHT AND DIMS
Platform: 9 x 9in (230 x 230mm)
Orbit diameter: 0.8in
Weight: 8.6 lbs (3.9kgs)
Width: 10in
Depth: 12in
Height: 5.5in
Description
RTL-BLVD-24T1
110v Digital Rotator
RTL-BLVD-24T2
220v Digital Rotator
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
44
Lab Equipment
DIFFERENTIAL COUNTERS
LW Scientific offers a five-key and an eight-key
model of blood cell differential counters. These
manual counters are durable and will provide years
of use; even in the most demanding laboratory
settings.
•Right and left reset knobs
•Bell alarm for 100th counted cell
•Non-slip bottom
•Strip chart of mature and immature forms
•Acid-resistant, high-impact plastic body
REFRACTOMETER
Achieve accurate, quantitative measurements of
specific gravity and protein determinations in bodily
fluids with our hand-held refractometer. Simply read
the numerical scales through the eyepiece. Rubber
grip and optical focus system allow for easy viewing
in
any
environment.
Automatic
Lab Equipment
temperature
compensation allows for immediate results, even
when sample temperatures vary.
Total protein/specific gravity:
•Range: 0-12g/dl; 1,000-1,040sg
•Resolution: 0.2g/dl; 0.002sg
•Dimensions: 1.18”x6.29” (30mmx160mm)
•Weight: 0.47 lbs. (215g)
•Includes: Carry case, screw driver, sample dropper
and cloth cover
Model #
Description
CTL-DIFM-05KY
5-Key Differential Counter
CTL-DIFM-08KY
8-Key Differential Counter
CTL-REFM-PRSG
Refractometer
CTL-HEMM-GLDR
Hemacytometer
HEMACYTOMETER
Our Hemacytometer is specially designed for
counting erythrocytes and leukocytes. Double
rulings are visible through a wide range of
illumination. Neubauer rulings are 0.1mm below
cover glass. The H-shaped moat offers two counting
areas. Fused rhodium on glass provides distinct
lines.
•High light transmission
•Brightly illuminated line
•Two special counting chamber cover glasses
•Light transmission between 29% and 32%
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
45
Pipette Shakers
LW Scientific pipette shakers easily achieve consistent results in specimen
separation and are especially effective for blood preparation. The LWS 6 place
shaker has the option of either continuous motion or timed motion using the 15
minute timer. Compact size and durability make the LW Scientific pipette shaker
convenient for any laboratory.
SPECIFICATIONS
Portable and compact
Capacity – 6 places
Fixed speed - 2500 rpm
15-minute timer
Suction-cupped feet
Space-saving design
LED indicator light
Durable construction
110v or 220v
One year warranty
Model #
SHL-PPF7-06F1
Description
Pipette shaker 6 places
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
46
Lumin i4
For users requiring a multi-purpose microscope for expanding health services, LW
Scientific introduces the new i4 Fluorescence Microscope. With integrated LED
technology for both bright field and epifluorescence microscopy, the Lumin i4
offers superior clarity and crisp imaging—all at a price that allows even labs on a
limited budget to benefit from the latest technological advances.
The Lumin epifluorescence module converts our standard i4 or i5 microscope to a
fully functional epifluorescence microscope. The resulting images rival those
obtained from traditional, expensive epifluorescence systems. The Lumin i4 and i5
are suitable for viewing a range of pathogens including those indicative of
respiratory diseases, autoimmune diseases such as lupus and arthritis, celiac
disease, tuberculosis, malaria, and for use in the fields of rheumatology, pathology,
gynecology, and nephrology.
HEAD
Binocular (Seidentopf), Trinoc available
Digital cameras and adapters available
Diopter adjustment
Inclined 30°, rotates 360°
10X/18 WF Eyepieces
(10X/20X Super WF HP eyepieces available)
Interpupillary distance range 55-75mm
NOSEPIECE
Reverse quadruple nosepiece
Multiple ball bearing mounted
Model #
Description
I4S-EPB4-ISL3
Binoc head, 4-10-40-100 Infinity Semi Plan objectives, epi module
I4S-EPT4-ISL3
Trinoc head, 4-10-40-100 Infinity Semi Plan objectives, epi module
I4S-EPB5-IPL3
Binoc head, 4-10-20-40-100 Infinity Plan objectives, epi module,
I4S-EPT5-IPL3
Trinoc head, 4-10-20-40-100 Infinity Semi Plan objectives, epi module
OBJECTIVES
Infinity Semi-Plan or Plan Achromat objectives
4X, 10X, 40XR, 100XR (oil)
20X and 50X (oil) objective also available
Anti-fungal, parfocal, parcentric, color-coded
ILLUMINATION
FOCUS
Coarse adjustment: range of 30mm
)LQHDGMXVWPHQWJUDGXDWLRQRIȝP
Tension control knob
STAGE
Brightfield:
Mechanical stage (140mm X 140mm)
Moveable Abbe condenser, NA 1.25
Coaxial drive controls, metal rack & pinion
Iris Diaphragm
Range of traverse: 73mm x 43mm
Transmitted LED long-life light source
Stage locking lever
90-240V / 50-60Hz automatic switching
Slow-close hydraulic slide finger
power cord
Epifluorescence:
LED long-life light source
Excitation spectrum: FITC standard
Other filter cubes available upon request
DIMENSIONS
Height: 18” (457.2mm)
Length: 10.7” (267.5 mm)
Width: 6.1” (152.5 mm)
Weight: 24 lbs (10.9 kg)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
47
Lumin
™
LW Scientific’s focus is to implement the Lumin™ as a primary component of
worldwide Tuberculosis diagnosis standard practices. We believe that providing
advanced fluorescence technology to health workers, doctors, and laboratory staff
in each of the estimated 60,000 worldwide TB labs will create a substantial impact
in the TB diagnosis rate. Doing so would accelerate the progress toward the
Tuberculosis control strategy.
ILLUMINATION
LED (proprietary) 50,000 hour use bulb
Safe light - No harmful UV emissions
No dark room required
POWER
Illuminator unit: 5~32 volts / 0.7amp., from
universal power supply 110~240 volts, or
battery
Model #
OPTIONS
20X Objective
40X Objective
60X Objective
100X Oil Objective
FEATURES
LMP-4951-L485
Description
Lumin™ illuminator
LMO-020X-DADR
20X universal objective
LMO-040X-DADR
40X universal objective
LMO-100X-DAOL
100X universal objective
LMS-040X-D480
Lumin™ kit (Illuminator and 40X universal objective)
Easy To Install
Lifetime Bulb
Fits Most Any Microscope
No Dark Room Required
Can Run on Battery Power
Safe Light – No Harmful UV Emissions
WEIGHT AND DIMS
The Lumin™ Kit - Less than 1 pound (<448
g), including dust and moisture resistant
case (50x60x30mm)
P 770.270.1394
F 770.270.2389
865 Marathon Parkway
Lawrenceville GA 30046
LWScientific.com
48
P. 770.270.1394
F. 770.270.2389
49
50
51
52
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
