EK-RQOX3-UG-001

............

XX:::::::.:::

XX:::::::.::

1

,

RQDX3

Controller Module

User's Guide

1st Edition, November 1985

© Digital Equipment Corporation 1985

All Rights Reserved

The material in this manual is for informational purposes and is subject to change without notice.

Digital Equipment Corporation assumes no responsibility for any errors that may appear in this manual.

FCC Notice: This equipment generates, uses, and may emit radio frequency energy. The equipment has been type tested and found to comply with the limits for a Class A computing device pursuant to SUbpart

J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such a commercial environment. Operation of this equipment in a residential area may cause interference, in which case the user, at his own expense, may be required to take measures to correct the interference.

Printed in U.S.A.

The manuscript for this book was created on a

VAX-11/780

system and, via a translation program, was automatically typeset by Digital's DECset Integrated Publishing System. The book w~s produced by Educational Services Development and

Publishing in Marlboro, MA.

The following are trademarks of Digital Equipment Corporation: mamaDmo™

DEC

DECmate

DECUS

DECwriter

DIBOL

MASSBUS

MicroPDP-ll

MicroVAX

PDP

PIOS

Professional

Rainbow

RSTS

RSX

RT

UNIBUS

VAX

VMS

VT

Work Processor

Contents

Preface

Chapter 1

RQDX3 Controller

INTRODUCTION ............................................................................................. 1-1

PHYSICAL DESCRIPTION .............................................................................. 1-2

RQDX3 Features .......................................................................................... 1-2

Performance Enhancements..................... .................................................... 1-4

Drives and Capacities Supported .................................................................. 1-4

Software Interface ........................................................................................ 1-4

M7555 Controller Specifications .................................................................. 1-5

FUNCTIONAL DESCRIPTION ............................................................... ......... 1-6

Multi-Port Memory Subsystem..................... .................... ........................... 1-8

Microprocessor Subsystem ........................................................................... 1-9

T-l1 Address Space ................................................................................. 1-11

T -11 Interrupt Functions.. ......................................... .................. ............ 1-11

Q-Bus Interface Subsystem .......................................................................... 1-12

Programmed I/O Section.............. .................... ........ ................ ............... 1-12

Q-Bus DMA Controller Section ................................................................ 1-13

Q-Bus Interrupt Section ........................................................................... 1-14

Disk Interface Subsystem ............................................................................. 1-14

Control of Communications ...................................................................... 1-15

Disk Drive Control and Status ................................................................. 1-15

Data Recovery and Separation ................................................................. 1-16

Write Precompensation ............................................................................ 1-16 iii

Contents

Chapter 2 Controller Configuration and Installation

INTRODUCTION ............................................................................................. 2-1

CONFIGURATION OF JUMPERS ................................................................... 2-1

Module Base Address............................................................ ....................... 2-2

Starting LUN ............................................................................................... 2-2

Jumper W23 ................................................................................................. 2-3

BA23 INSTALLATION .................................................................................... 2-4

Installing Three Drives........ ..... ... ............................................ ............ ........ 2-5

Installing Four Drives. .............. ... ................................................................ 2-6

BA123 INSTALLATION .................................................................................. 2-8

INTERRUPT VECTORS AND PRIORITY LEVELS ....................................... 2-9

DISK DRIVE CONFIGURATION .................................................................... 2-9

Chapter 3 Testing and Formatting

INTRODUCTION ............................................................................................. 3-1

DIAGNOSITCS SOFTWARE ............................................................................ 3-1

MicroPDP-11 User Diagnostics ................................................................... 3-1

MicroPDP-11 Field Service Diagnostics .................................................. 3-1

XXDP+ Formatting with an RQDX3 Controller ...................................... 3-2

Formatting Help ...................................................................................... 3-4

RD/RX Exerciser Procedure .................................................................... 3-5

Micro V AX II System Diagnostics... .... ........ .... ................ .......... ....... ............. 3-8

Customer Version......... ............. .... .............. ............. ........... ....... ............. 3-8

Service Version ........................................................................................ 3-8

Chapter 4 Glossary of MSCP and DUP Commands

MSCP COMMANDS ......................................................................................... 4-1

DUP COMMANDS ........................................................................................... 4-2 iv

Contents

Appendices

Appendix A

Appendix B

Appendix C

RQDX3 Backplane Pin Assignments

RQDX3 Controller Module Cable Signals

Supported Drive Geometries

FIGURES

1-1 RQDX3 Controller - Functional Partition ............................................ 1-7

1-2 Multi-Port Memory Subsystem Block Diagram .................................... 1-8

1-3 Microprocessor Subsystem Block Diagram .......................................... 1-10

1-4 T-ll Memory Map ............................................................................... 1-11

1-5 Q-Bus Interface Subsystem Block Diagram .......................................... 1-13

1-6 Disk Interface Subsystem Block Diagram ............................................ 1-15

2-1 Base Address Jumper Assignments ...................................................... 2-2

2-2 RQDX3 Jumper Installation Diagram ................................................... 2-3

2-3 BA23 Backplane Slots.......... ................................................................. 2-4

2-4 RQDX3 - BA23 Cabling Diagram ........................................................ 2-5

2-5 RQDX3/RQDXE - BA23-A/BA23-C Cabling Diagram ......................... 2-7

2-6 BA123 Backplane Slots ......................................................................... 2-8

2-7 RQDX3 - BA123 Cabling Diagram ...................................................... 2-9

A-I Dual Module Contact Finger Identification Diagram ............................ A-I

TABLES

1-1 Product Difference Matrix .... ............................. .................................. 1-3

1-2 Environmental Specifications ................................................................ 1-5

2-1 Typical Examples of Starting LUNs ..................................................... 2-2

2-2 W23 Installation .................................................................................... 2-3

2-3 Drive Assignment ............. .................................. .................................. 2-10

3-1 XXDP+ Diagnostic Programs ............................................................... 3-1

A-I RQDX3 Module Finger Connections .................................................... A-2

B-1 Jl Connector Pinouts ............................................................................ B-1

B-2 Description of Connector Signals ......................................................... B-2

C-l Supported Drive Matrix ....................................................................... C-l v

Preface

The RQDX3 (M7555) controller module is a dual-height module designed for both

MicroPDP-ll and Micro VAX II systems. The module interfaces up to four logical drive units to the system's Q22-Bus.

This manual defines the RQDX3 controller module and tells how to install it in both

BA23 and BA123 enclosures. This manual is designed for the following types of users.

1. Ones who may require an additional RQDXn disk controller

2. People who need advance knowledge about the RQDX3 controller module

3. Field Service personnel responsible for installing and maintaining RQDX3 controllers

Chapter 1 gives physical and functional descriptions of the RQDX3 controller. It explains what the controller is and what it does.

Chapter 2 provides installation instructions for the BA23 and BA123 enclosures. It also discusses how to configure RQDX3 jumpers for the following purposes.

1.

Standard base address

2. Starting ILogical Unit Numbers (LUNs)

3. Drive cable compatibility with RQDXl/RQDX2 controllers

Chapter 3 explains how to verify the operation of installed RQDX3 controller modules in the following manner. vii

Preface

Chapter 4 contains a glossary of MSCP and D UP commands supported by the

RQDX3 controller module.

1. What the RQDX3 controller self-test indications mean

2. What diagnostics are made available to the user and field engineer

3. How RD drive(s) are formatted and tested in a system that is using the

RQDX3 controller.

NOTE

This. document shows console displays for XXDP+ Diagnostics and MicroVAX Maintenance System - Diagnostic Release Version

1.06.

Backup data is given in Appendices A and B. Appendix C provides the geometry information of the drives supported at time of printing.

The following documents provide additional information and may be of interest to

RQDX3 controller module users.

Title

Microcomputer Interface Handbook

Microcomputer Memory Handbook

MicroPDP-ll Illustrated Parts Breakdown*

MicroPDP-ll Illustrated Parts Breakdownt

MicroPDP-ll Systems Maintenance Guide

MicroPDP-ll Systems Technical Manual*

MicroPDP-ll Systems Technical Manualt

MicroVAX II Systems Owner's Manual*

Micro V AX II Systems Owner's Manualt

MicroVAX II 630QY, 630QZ Technical Manual*

MicroVAX II 630QB Technical Manualt

RD51 Disk Drive Technical Description

RD52 Disk Drive Technical Description

RD53 Disk Drive Technical Description

RQDXE Expander Module User's Guide

RX50 Diskette Drive Technical Description

*

BA23 Enclosure

t

BA123 Enclosure

Document

Number

EB-20175-20

EB-18451-20

EK-OLCP5-IP

EK-BA123-IP

EK-MICII-SG

EK-MICII-TM

AZ-GLHAA-MC

AZ-FE05A-TN

AZ-FE08A-TN

AZ-GLOAA-MN

AZ-GLBAA-MN

EK-RD51A-TD

EK-RD52A-TD

EK-RD53A-TD

EK-RQDXE-UG

EK-RK50-TD

viii

RQDX3 Controller

INTRODUCTION

This chapter provides both physical and functional descriptions of the RQDX3 controller module. The physical description describes the attributes of the RQDX3 module by discussing the following.

1. Features

2. Comparison with the RQDXl and RQDX2 controller modules

3. Performance enhancements

4. Supported drives

5. Physical and environmental specifications

The functional description explains the RQDX3 module's functions in terms of four subsystems.

1. Multi-port memory subsystem

2. Microprocessor subsystem

3. Q-Bus interface subsystem

4. Disk interface subsystem

1-1

RQOX3 Controller

PHYSICAL DESCRIPTION

The RQDX3 controller is a dual-height module that interfaces up to four logical drive units to the Q22-Bus. It uses a multi-port memory architecture that permits the following operations in parallel.

• Host data transfers

• Disk data transfers

• Microprocessor access to local data structures

Most of the data path functions are contained in two CMOS gate array devices, which contain the hardware functions required to:

• Implement the 3-port memory system

• Provide the host processor interface

• Provide support logic for the on-board microprocessor

• Provide digital logic for the disk data separator

RQDX3 Features

The RQDX3 controller module offers these features.

1. A dual-size module

2. Self-test capability

3. Q-Bus blockmode DMA data transfers in 16-, 18-, or 22-bit addressing modes

4. No sector interleave on hard disk drives for maximum data transfer rate

5. Various disk access performance optimizations

6. Hard disk geometry information stored on the disk surface, not in the controller (this allows the support of future hard disk drives without microcode changes).

1-2

RQDX3 Controller

Table 1-1 compares features common to the RQDXl, RQDX2, and RQDX3 controller modules.

Table 1-1 Product Difference Matrix

Feature

Elevator seek algorithm

RQDXl

Yes

Controllers

RQDX2

Yes

RQDX3

Yes

Buffered seeks

Overlapped seeks

Error Correction Code (ECC)

RX50 floppy support

Supports greater than 33 Mbyte fixed disks

Number of logical units supported

Yes

No

No

Yes

No

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

4

Number of hard disks supported

Sector interleave

4

2

3:1

4

4

3:1

4

1:1

Q-Bus slot independent No No

Quad

Yes

Module size

LBNs/Track for hard disks

Quad

18

18

Dual

17

Location of disk geometry information Controller's Controller's Disk microcode microcode surface

1-3

RQOX3 Controller

Performance Enhancements

The 3-port architecture optimizes RQDX3 controller operation, allowing these performance enhancements.

1. Elimination of hard disk sector interleave

2. Overlapped seeks

3. Error correction

For RD52 and RD53 hard disks, the RQDX3 controller allows a 1:1 sector interleave on disk surfaces, reducing the average transfer time from 3.5 to 1.5 revolutions per track. For RD51 hard disks, the RQDX3 controller allows a 2:1 sector interleave.

When multiple hard disks are attached to the controller, the seek pulses for each drive are sent without waiting for a seek complete indication from the drive. The drives are then polled for the first seek completion, at which time that data transfer operation is performed. This allows a percentage of the seek time to be overlapped with data transfers on another drive.

The controller performs retries to eliminate soft data errors. If a reasonable number of command specific retries cannot correct the data, then it is considered a hard data error. For hard disk drives, an attempt will be made to correct this error with an ECC algorithm. The algorithm is capable of detecting up to an II-bit burst within a sector, but limits corrections to single bit errors.

On hard disk drives, sectors with hard errors indicating that the sector is defective are automatically replaced with available replacement blocks. The total number of replacement blocks on a drive is specified at format time and depends upon the drive capacity.

Drives and Capacities Supported

The RQDX3 controller is capable of supporting four logical disk units with up to 16 surfaces per unit and 2048 tracks per surface. The module contains enough logic to support a system front panel for four hard disk drives. For floppy disks there is no front panel support.

Software Interface

The RQDX3 controller identification number returned to the host processor upon interrogation is decimal 19.

1-4

RQOX3 Controller

M7555 Controller Specifications

This listing presents physical and operational specifications regarding the RQDX3 module while Table 1-2 describes the environmental specifications.

Overall dimensions

Height:

Width:

Length:

26.56 cm (10.46 in)

1.27 cm (0.5 in)

22.70 cm (8.94 in)

Power requirements

+5 Vdc ±5% at 2.48 A (typ.) 2.9 A (max.)

+12 Vdc ±5% at 0.06

A

(typ.) 0.1

A

(max.)

Bus Loads

AC

DC

1.9

0.5

Up to four logical units

Drives per controller

LSI-II bus-addressable registers

2

Base drive address

(standard) 17772150 (octal) for 22-bit addressing

Vector Set by operating system software

Table 1-2 Environmental Specifications

Specifications Operating Non-Operating

Temperature

Relative humidity

(noncondensing)

Maximum altitude

5°C-60°C (41°F-140°F)

10% to 95%

2.4

km

(8,000 feet)

-40°C-66°C (-40°F-151°F)

10% to 95%

9.1

km

(30,000 feet)

1-5

RQOX3 Controller

FUNCTIONAL DESCRIPTION

The RQDX3 module is a microprocessor-based peripheral controller operating subordinate to a host processor. It responds to commands originated by its host and executes a number of functions including the following.

• Self-initializing

• Performing internal diagnostics

• Decoding of host command packets

• Encoding of controller response packets

• Controlling all disk operations

• Transferring data on the Q-Bus via DMA cycles

Digital's proprietary Mass Storage Control Protocol (MSCP) defines communications between the host processor and the RQDX3 controller. The host originates the communications handshake by sending command packets to the RQDX3 module.

It

completes the communications handshake by returning response packets to the host.

The RQDX3 controller uses two sequential locations to form a communications port with the host.

1. Initialization and Poll (lP) register - the RQDX3 controller's standard base address (17772150)

2. Status and Address (SA) register - the next sequential address (17772152)

RQDX3 controller functions are described in terms of multi-port memory, microprocessor, Q-Bus interface, and disk interface subsystems. Refer to Figure

1-1 for a functional partition of the RQDX3 controller module.

1-6

RQDX3 Controller

t

DATA

+ t

CONTROL

INFORMATION

~

..

MSCP

PACKETS

.,

AND

WORKSPACE

CONTROL

,

INFORMATION

~

8

FRONT PANEL BUS

MR-16580

Figure 1-1 RQDX3 Controller - Functional Partition

1-7

RQDX3 Controller

Multi-Port Memory Subsystem

The multi-port memory subsystem is a 3-port RAM structure providing buffers for data communicated between the various RQDX3 controller subsystems. It consists of an 8 K

X

16 static RAM, a memory controller, three ports, and various other logic as shown in Figure 1-2. The RAM provides the following.

• Data buffers

• Command and response buffers

• Microprocessor workspace

TO/FROM Q-BUS INTERFACE

T-11 DATA/ADDRESS BUS

T-11

ADDR

TO/FROM

MICRO-

PROCESSOR

SUBSYSTEM

1-8

DISK

DMA

ADDRESS

POINTER

15 MHz

TO/FROM

DISK CONTROLLER

SUBSYSTEM

TO/FROM

DISK CONTROLLER

SUBSYSTEM

TO/FROM

DISK CONTROLLER

SUBSYSTEM

Figure 1-2 Multi-Port Memory Subsystem Block Diagram

MR-16581

RQOX3 Controller

The memory controller receives requests from the three ports and performs the memory cycle for the highest priority requesting port. During a memory cycle, the highest priority port is allowed to write or read the 8 K static RAM. The memory controller sends port select signals (SEL) that grant priority to ports in accordance with the following protocol.

• Disk port - first priority

• Q-Bus port - second priority

• T -11 port - third priority

Each port receives addresses and data from its corresponding RQDX3 subsystem.

These addresses and data are held temporarily in port registers until the memory controller grants that port access to the static RAM. The three ports interconnect with the other RQDX3 subsystems as shown in Figure 1-2.

Microprocessor Subsystem

The microprocessor subsystem (Figure 1-3) is the central point of control.

It

supervises control of the following functions.

• Self-Test diagnostics

• MSCP command decode and response encode

• Supervision of Q-Bus and disk subsystems

• Performance optimization

• Interface to the host's front panel which provides switches and status indicators

1-9

RQOX3 Controller

As shown in Figure 1-3, the microprocessor subsystem is made up of aT-II microprocessor chip, address latches, an EPROM memory, a fn>fit panel interface, and priority granting interrupt logic.

TO/FROM

Q-BUS

INTERFACE

SUBSYSTEM

TO/FROM

T-11 PORT'

TO/FROM

DISK

CONTROLLER

SUBSYSTEM

T-11 DATA/ADDRESS BUS

------.

7.5 MHz

TO PLL LOGIC

SELRX

SELHDEN

'PART OF MULTI-PORT

MEMORY SUBSYSTEM.

FRONT

PANEL

INTERFACE

1 + - - - -

TO/FROM

CONNECTOR

J1

Figure 1-3 Microprocessor Subsystem Block Diagram

1-10

RQOX3 Controller

T -11 Address Space -

T -11 address space consists of 32 K words that are mapped as follows and as shown in Figure 1-4.

1.

16 K words dedicated to EPROM memory for the microcode

2. 8 K words set aside for RAM space

3. 8 K words set aside for the I/O page

177777

I/o

PAGE REGISTERS

140000

8K X 16 RAM

100000

16K X 16 EPROM

FIRMWARE

000000

MR-16766

Figure 1-4 T -11 Memory Map

The T -11 front panel interface connects the RQDX3 controller module to switches and status indicators in the host's manual control panel. (See connector 11 and the

50-wire flat cable shown in Figure 1-3.) Manual control panels of push-button switches, status LEDs, and associated circuitry are provided with host systems.

Signals output from the T -11 front panel interface are buffered with open collector inverters. Signals returned from the host's manual control panel are routed to the

T -11 microprocessor via front panel status logic which are also part of the T -11 front-panel interface.

T -11 Interrupt Functions -

The T -11' s interrupt logic handles one non-maskable power fail interrupt and seven maskable interrupts. Power fail interrupts have highest priority. Maskable interrupts have lower priorities (descending from 7 to 1).

1-11

RQDX3 Controller

Q-Bus Interface Subsystem

The Q-Bus interface subsystem is made up of three sections.

1. The programmed I/O section, made up of the IP and SA logic

2. The Q-Bus DMA controller section

3. The Q-Bus interrupt section

Programmed

1/0

Section -

The programmed I/O section of the RQDX3 controller includes IP and SA logic. The IP logic allows the host processor to create two independent control strobes on the RQDX3 controller module: the IP WRITE and the IP READ strobes. An IP WRITE to the base address (17772150) initializes the

RQDX3 controller module and interrupts the T -11 microprocessor. An IP READ signals the module, allowing the DMA controller to begin a polling sequence of host memory for command packets.

NOTE

Instructions for selecting the standard base address (17772150) are included in Chapter 2.

The SA logic passes status and address information between the T -11 microprocessor and the host processor during the port initialization sequence. As shown in

Figure 1-5, the SA logic consists of SA READ and SA WRITE registers.

The SA READ register is written into by the T -11 microprocessor and read from by the host processor. The SA WRITE register is written into by the host processor and read from by the T -11 microprocessor. This register passes MSCP command buffer addresses and the interrupt vector to the T -11 during initialization.

The programmed I/O section also provides PIO control logic, Q-Bus transceivers

(XCVRs), and internal buses that allow two-way communication with the host processor via the Q-Bus.

1-12

RQDX3 Controller rn-;;,s

;E~P;--"1

I

SECTION

I

I I

I

I

I

I

L_

a-BUS

PIO ADDR

DETECT

0-22

ADDRESS

POINTER

PIO

ADDR

JUMPERS

15 MHz

T-11 DATA/ADDRESS BUS

TO/FROM

ADDR

REGISTERS

TO/FROM a-BUS PORT

TO/FROM

T-11

MR-16583

Figure 1-5 Q-Bus Interface Subsystem Block Diagram

Q-Bus DMA Controller Section -

The Q-Bus DMA controller section incorporates a DMA controller state machine and data path logic to perform the following functions.

• 22-bit Q-Bus DMA addressing

• 16-bit DMA word counting

• Q-Bus memory parity detection

• Implementation of blockmode transfers

• Timing to regulate Q-Bus activities

1-13

RQDX3 Controller

Q-Bus DMA transfers are started under program control by the T -11 microprocessor. The data path logic which supports Q-Bus DMA controller operations consists of the following.

• A DMA CTRL/Status register

• A DMA word counter

• A Q-22 address pointer

The following conditions cause the DMA controller to stop performing DMA data transfers.

• Word counter reaches zero

• Non-existent memory errors reported

• Q-Bus memory parity errors occur

• IP WRITE

• Q-Bus initialization sequence

• Transfer halted by microprocessor

Q-Bus Interrupt Section -

The Q-Bus interrupt logic consists of the vector register and interrupt control logic shown in Figure 1-5.

During the interrupt sequence, the contents of the interrupt vector register are gated to the Q-Bus as a vector. The MSCP initialization function supplies the T-ll microprocessor with the vector number and the microprocessor loads this number into the vector register.

Disk Interface Subsystem

The disk controller subsystem provides control and data path functions for both floppy and hard disk drives. It is made up of the following functional elements which are also shown in Figure 1-6.

1. Disk controller chip

2. Drive control and status logic

3. Data recovery circuit

4. Write pre compensation logic

1-14

TO/FROM

DISK

DMA

ADDRESS

POINTER

RQOX3 Controller

TO/FROM

T-ll PORT

TO/FROM

T-l1

MICROPROCESSOR

DISK CONTROLLER

CHIP

14---,--10 MHz

STATUS

I

CONr

ROL

CONNECTOR Jl

Figure 1-6 Disk Interface Subsystem Block Diagram

Control of Communications -

The disk controller chip permits the T -11 microprocessor to supervise control of communications between attached disk drives and the RQDX3 controller module. The disk controller chip sequentially executes a number of RQDX3 functions.

To implement the following operations and functions, the disk controller chip executes sequences that are queued by the T -11 microprocessor.

• DMA data transfers between the on-board sector buffers and attached disk drives

• Error detection

• Interruption of the T -11 microprocessor upon completion of current operation, or when errors are detected

Disk Drive Control and Status -

As shown in Figure 1-6, the disk controller chip interconnects with the drive control and status logic via the AUX bus. The drive control logic passes control signals which are routed to the disk drives. The drive status logic returns drive status signals to the disk controller chip via the

AUX bus.

1-15

RQDX3 Controller

Data Recovery and Separation -

The RQDX3 data separator has been designed to receive and convert the MFM encoded data stream into an NRZ data stream and a READ CLK. Received data comes from the disk and converted data and the

READ CLK go to the disk controller chip. The RQDX3 data separator is designed to operate at the following data frequencies.

1. 5 MHz MFM ENCODED DATA from ST412 Winchester disks, type RDxx

2. 500 kHz MFM ENCODED DATA from high-speed, high-density floppy disks

3. 250 kHz MFM ENCODED DATA from standard, double-density floppy disks

Write Precompensation -

The precomp block (see Figure 1-6) represents a delay line and a multiplexer used by the disk controller chip to provide write pre compensation for hard disks.

Write pre compensation for floppy disk drives is provided internally by the disk controller chip.

1-16

Controller Configuration and Installation

INTRODUCTION

This chapter discusses how to configure RQDX3 jumpers and provides installation instructions for the BA23 and BA123 enclosures. It also includes information regarding interrupt vectors, priority levels, and disk drive configurations.

CONFIGURATION OF JUMPERS

RQDX3 controller jumpers are installed as required to assign the following.

• The module base address

• Starting LUN

• Drive cable compatiblity with RQDXl/RQDX2 Oumper W23)

NOTE

All MSCP devices (including the RQDX3 controller) have the same standard base address (17772150). If a conflict exists between the RQDX3 and a second MSCP device, the base address of either one of them, the RQDX3 or the other MSCP device, must be changed to a system-specific value in the floating address space.

2-1

Controller Configuration and Installation

Module Base Address

The module base address is configured by installing jumpers W02, W04, W05,

W09, and W11 and removing jumpers W01, W03, W06, W07, W08, and W10 as shown in Figure 2-1. Address bits 13-15 are always asserted high because they are jumpered permanently by hard wire connections.

15 14 13 12 11 10 09 08 07

06 05 04 03 02 01 00

I

1

I

1

I

1 1

I o

I

1

I o

I

0 1 1 0

I

1 0

I I o

I I I

~ ~ ~ ~

+

~ ~

W11 W10 W09 W08 W07 W06 W05 W04 W03 W02 W01

I x

JUMPERS

I x I

1 :;::: JUMPER INSTALLED

0:;::: JUMPER REMOVED

X:;::: DON'T CARE CONDITION

MR·16767

Figure 2-1 Base Address Jumper Assignments

Starting LUN

The starting LUN equals the binary number represented by jumpers W12 (LSB) through W17 (MSB) multiplied by 4. When jumpers W12 through W17 are removed as shown in Figure 2-2, a starting LUN of 0 is selected. Refer to Table

2-1 for typical examples.

Table 2-1 Typical Examples of Starting L

UN s

Starting

LUN o

4

8

12

16

Jumpers

Installed

None*

W12 (LSB)

W13

W13 and W12

W14

Jumper Representations

Binary Decimal

000000

000001

000010

000011

000100 o

1

2

3

4

*

Factory configuration

2-2

Controller Configuration and Installation

J1

(COMPONENT SIDE)

RQDX3 CONTROLLER

(M7555)

A

LED

W23

10 0 ...... 1

432 1

W12 W13

10' 01

~

[]O

W14

W15

0 0 o

0

W16

W17

0 0

W02

W04

WOO

W08

W10 o o

0 o

0 o o

.....

0

W01

......

.....

0

0 o

0

W03

W05

W07

WOg

W11

MR·16713

Figure 2-2 RQDX3 Jumper Installation Diagram

Jumper

W23

Jumper W23 is installed as specified in Table 2-2.

Table 2-2

Points

1 2

W23

0 0

W23

Installation

3 o

4 o

Remarks

The factory configuration; it allows the

HEADSEL 3 (L) and REDUCWRTI (L) signals to be tied to the saine connector pin (pin 22 of J1).

W23

0 0 o o

W23 connected between points 2 and 3 ties the

HEADSEL 3(L) signal to pin 9 of J1, and the

REDUCWRTI (L) signal to pin 22 of J1.

B

2-3

Controller Configuration and Installation

BA23 INSTALLATION

The RQDX3 controller module plugs into any available slot on the BA23 backplane except the CD positions of slots 1-3 as shown in Figure 2-3. Slots 1-3 are reserved for CPU and memory modules. For backplane pin assignments (mating pins AAI-A

VI

and BAI-BVl), refer to Appendix A.

BACKPLANE

SLOT

3

4

1

2

5

6

7

8 a

O-BUS

O-~US

I

O-BUS

J.

O-s'US

BACKPLANE ROWS b c d

CD INTERCONNECT

CD INTERCONNECT

CD INTERCONNECT

O-~US o-lus

O-~US o-Jus

O-BUS

I

O-B~S

O-BUS

I o-BLs

O-BUS

NOTES:

1. PRIORITY INTERRUPTS AND DMA BUS GRANT D.l\ISY CHAIN

SHOWN BY ARROWS.

2. THE RODX3 CAN PLUG INTO ANY UNUSED O-BUS SLOT AS LONG

AS THE DAISY CHAIN REMAINS INTACT.

MR·16768

Figure 2-3 BA23 Backplane Slots

2-4

Controller Configuration and Installation

Installing Three Drives

Figure 2-4 shows typical cabling for one disk and two diskette drives. As shown, connector J1 on the RQDX3 controller interconnects with connector J3 on the

BA23-A distribution panel via a ribbon cable. The BA23-A distribution panel is part of the interface allowing the RQDX3 module to run one disk and two diskette drives, which are installed in ports 0 and 1 of the BA23 enclosure. For BA23 installation details, refer to the appropriate MicroPDP-11 manual.

BC02D-1O

(RIBBON

CABLE)

RQDX3

(M7555)

Figure 2-4 RQDX3 - BA23 Cabling Diagram

2-5

Controller Configuration and Installation

Installing Four Drives

Figure 2-5 shows typical cabling for two disk and two diskette drives. The RQDX3 module is interconnected with the RQDXE expander module, and the RQDXE module is interconnected with both the BA23 and the BA23-C distribution panels via separate cables. Point-to-point interconnections are as follows.

• RQDX3

J1

to RQDXE J2 via cable BC02D-01

• RQDXE

J1

to BA23-A distribution panel connector J3 via cable BC02D-1D

The BA23-A distribution panel is part of the interface allowing the RQDX3 module to run one disk and two diskette drives, which are installed in ports 0 and 1 of the BA23-A.

• RQDXE J3 to BA23-C distribution panel connector J3 via cable BC02D-04

Connector J3 on the RQDXE interconnects with the BA23-C distribution panel via cable BC02D-04. This allows the RQDX3 to drive a second disk which is installed in port 0 of the BA23-C expansion box.

For a pinout of connector

J1

on the RQDX3 controller, refer to Appendix

B.

2-6

Controller Configuration and Installation

RQDX3

BC02D-1D t

FRONT PANEL

PORT 1 (BLANK)

RD5 n

Figure 2-5 RQDX3/RQDXE - BA23-A/BA23-C Cabling Diagram

2-7

Controller Configuration and Installation

BA123 INSTALLATION

The RQDX3 controller module plugs into any available Q-Bus slots on the BA123 backplane except the CD positions of slots 1-4 and slot 13 as shown in Figure 2-6.

BACKPLANE

SLOTS

1

2

3

4

5-12

13 a

Q-BUS

Q-BUS

BACKPLANE ROWS b c d

CD INTERCONNECT

CD INTERCONNECT

Q-BUS

CD INTERCONNECT

Q-BUS

CD INTERCONNECT

Q-BUS

Q-BUS

RESERVED

FOR

FUTURE USE

SIGNAL

DISTRIBUTION

BOARD

MR-16769

Figure 2-6 BA123 Backplane Slots

Refer to the appropriate Micro VAX II Technical Manual for BA123 backplane configuration rules. These rules specify plug-in priorities for BA123 backplane modules. Connector

J1

on the RQDX3 controller interconnects with a connector on the

BA123 signal distribution board via a ribbon cable as shown in Figure 2-7. Refer to

Appendix B for the

J1

pinout.

The BA123 system box is designed such that separate drive slots are permanently connected to a specific DRVSELn signal. This is done to eliminate the need to configure the disk drives to respond to different DRVSELn signals. Please refer to the MicroPDP-11 or the Micro VAX II 630QB technical manuals for full descriptions of the BA23 and the BA123 system boxes.

Therefore, drives installed in the BA123 enclosure and connected via the signal distribution board are configured automatically, and it is not necessary to configure the drive select jumpers on these drives.

2-8

Controller Configuration and Installation

*

PLUGS INTO SLOT 13, ROWS C-D, OF BA 123 BACKPLANE.

Figure 2-7 RQDX3 - BA123 Cabling Diagram

INTERRUPT VECTORS AND PRIORITY LEVELS

Interrupt vectors for MSCP controllers are set under program control. When the

RQDX3 controller is the first MSCP device installed in the system, it is assigned a fixed interrupt vector of 154. If more MSCP devices are installed, they will be assigned floating interrupt vectors.

The RQDX3 controller's interrupt priority level is 4.

DISK DRIVE CONFIGURATION

The disk drives connected to the RQDX3 controller must be configured so each drive responds to a different DRVSELn output signal from the controller.

The RQDX3 assigns LUNs to the physical drives based upon the drive select jumper in the disk drive and the number of drives in the system. The controller looks for disk drives in the following order of drive select settings.

1.

DRVSEL3

2. DRVSEL4

3. DRVSEL1

4. DRVSEL2

2-9

Controller Configuration and Installation

Starting with the LUN base address set with the jumpers, responding drives are assigned the next available LUN. Because of this action, there will be no gaps in the LUN numbering of drives connected to the controller.

As an example, consider a system with an RD52 disk drive set to respond to drive select 3 and a dual floppy RX50 diskette drive set to respond to drive selects 1 and

2. The drives on this system would be assigned as specified in Table 2-3.

Table 2-3 Drive Assignment

Disk

RD52

RX50

RX50

Assignment

(Binary LUN jumper setting)

(Binary L UN jumper setting)

(Binary L UN jumper setting)

*

4

+

0

*

4

+

1

*

4

+

2

For hard disk drives, configuration is usually performed via a set of four push-on jumpers or breakable metallic strips. One jumper is installed, or a metallic strip is not broken, to connect the drive to a specific DRVSELn signal. Refer to the appropriate drive manual for a description of how to configure the specific drive in question.

The RX50 floppy disk drive is factory configured to respond to the DRVSELI and

DRVSEL2 signals. This leaves the DRVSEL3 and DRVSEL4 signals available for hard disk drive selection.

CAUTION

Systems incorrectly configured to allow multiple drives to respond to the same DRVSELn signal will cause unpredictable results and possible loss of data and format information from the disk surface.

2-10

Testing and Formatting

INTRODUCTION

The RQDX3 controller module tests itself when it is powered up and when initialized by the host system. This testing capability verifies operation of the RQDX3 module's internal functional elements. A successful test takes 7-10 s. During host initialization, test time is shorter (less than 1 s).

At the beginning of testing, the RQDX3 module's LED is lit.

If the test is successful, the LED goes OFF.

DIAGNOSTICS SOFTWARE

User diagnostics and Field Service diskettes are used to verify system operation.

These diskettes usually isolate faults to Field Replaceable Units (FRUs). FRUs include the RQDX3 (M7555) controller and any connected disk or diskette drives.

MicroPDP-11 User Diagnostics

User diagnostics detect system errors and isolate errors to FRUs. They do not isolate errors below the FRU level. The user diagnostics are visible to the user as two diskettes. Use of these diskettes does not require familarity with XXDP+ diagnostic supervisor software.

1. User Test 1 - Detect System Errors

2. User Test 2 - Isolate Error to FRUs

MicroPDP-11 Field Service Diagnostics -

A set of five Field Service diskettes provide the XXDP+ diagnostic programs (Table 4-1) required to test the RQDX3 controller module as well as format disks using the RQDX3 module.

Table 3-1

Program

ZRQC??

ZRQA??

XXDP+ Diagnostic Programs

Title

RQDX3 formatter

RD /RX exerciser

3-1

Testing and Formatting

XXDP+ Formatting with an RQDX3 Controller -

The following formatting procedure is an example of formatting a MicroPDP-ll system with an RQDX3 controller module. Procedures for other systems may differ.

NOTE

New drives or drives originally formatted with an RQDX1 or

RQDX2 controller must be re-formatted using the RQDX3 controller.

CAUTION

Formatting an RD5n fixed disk destroys any files that are present on the disk. If you think that files exist, make a backup copy before you proceed. Write-protect any other fixed disk drives that are present. Refer to your software documentation for instructions.

To format a RD disk drive with the RQDX3 formatter program and the RQDX3 controller, perform the following procedural steps. This procedure assumes that the

RQDX3 module is the first installed MSCP device.

NOTE

Please be advised that your console displays may differ from those shown herein because you may be using updated diagnostics.

1. Install the Field Service diskette 4 (CZXD4DO) into the appropriate RX50 slot.

2. When the console displays or prints the XXDP+ prompt (.) type R ZRQC?? and press the

Return key.

3. When the console displays or prints

DR> type START and press the Return key.

4. When the console displays or prints

CHANGE HW (L)

? type Y and press the Return key.

5. When the console displays or prints

#

UNITS (D)? type the digit 1 (for one unit) and press the Return key.

3-2

Testing and Formatting

6. When the console displays or prints

IP ADDRESS (0) 172150

? press the Return key

if

the RQDX3 module is the first MSCP device.

7. When the console displays or prints

VECTOR ADDRESS (0) 154 press the Return key if the RQDX3 controller is the first MSCP device.

8. When the console displays or prints

AUTO FORMAT MODE (L) Y ? type Y (yes) and press the Return key.

9. When the console displays or prints

LOGICAL DRIVE (0-255) (D) 0

? press the Return key

if

the RQDX3 controller is the first MSCP device.

10. When the console displays or prints

DRIVE SERIAL NUMBER (1-32000) (D)

? type your serial number (XXXXx.) and press the Return key.

11. When the the console displays or prints

WARNING ALL DATA ON THIS DRIVE WILL BE DESTROYED followed by

PROCEED TO FORMAT THE DRIVE (L) N

? type Y and then press the Return key to begin the drive format if all user data is backed up.

12. When the console displays or prints

MSCP CONTROLLER MODEL# :19

MICROCODE VERSION #

FORMAT BEGUN wait about 35 min to allow the formatting to be completed.

13. When the console displays or prints

FORMAT COMPLETED remove the diskette.

3-3

Testing and Formatting

Formatting Help -

For formatting help and information, refer to the following list of the most commonly reported error messages generated by the formatter program.

(1) DUP PROTOCOL ERROR, UNEXPECTED MESSAGE

This is a hardware error indicating a problem with the disk drive or its configuration. Insure the proper configuration.

(2) CONTROLLER DOES NOT EXECUTE LOCAL PROGRAMS OR NON STD

DUP DIALOG PROGRAM

This can be either a hardware or software error. Check for proper controller configuration or for a defective controller.

(3) CONTROLLER IN AN UNEXPECTED ACTIVE STATE

This can be a wrong microcode version or a defective disk drive being used.

Re-run the formatting procedure and if the same error message is displayed, check the new controller for ECOs or microcode.

(4) CONTROLLER NEVER ADVANCED TO NEXT STEP

This is a controller initialization error. Check the controller

IP

address and insure that no other device has the same address.

(5) CONTROLLER INITIALIZED TIMEOUT

The controller is defective or the Q-Bus is not operating. Re-run the formatter.

(6) WRONG MODEL NUMBER ON CONTROLLER

The wrong formatter is being used. Check the title of the diskette inserted in the

RX50 diskette drive.

(7) NXM TRAP AT THE CONTOLLER IP ADDRESS

Wrong configuration controller

IP

address. Check the jumpers on the controller.

(8) UNEXPECTED OR DELAYED CONTROLLER INTERRUPT

Controller being interrupted by a system device. Re-run the formatter program.

3-4

Testing and Formatting

(9) FATAL SA ERROR CTLR OFFLINE

Controller error. Check controller configuration and re-run the formatter. If this error occurs during re-run, then the controller is defective.

(10) BAD RESPONSE PACKET RETURN

A software controller error. Re-run the formatter.

(11) NO PROGRESS SHOWN AFTER A CMD HAD TIMED OUT

This can be either a hardware disk drive error or a drive with many revector blocks. Let the formatter program run a few more minutes to see if the error condition occurs again. If error condition does not reoccur, the disk drive is probably defective. If error condition reoccurs, the drive contains many revector blocks.

(12) GET DUST CMD TIME-OUT AFTER ANOTHER CMD TIME-OUT

Controller and host are out of sync. Check the controller for electrical interconnections (cables and backplane) and reboot the system.

RD/RX Exerciser Procedure -

This sample of the RD/RX procedure assumes a configuration that comprises four logical units, one RX50 disk drive and two RD disk drives.

NOTE

This procedure assumes all user data has been backed up. If only one drive needs to be tested, make sure all other drives are write-protected and off-line.

After successfully formatting the RD disk(s), select the exerciser program by typing R ZRQA?? after the XXDP+ prompt (.) and press the Return key. The console displays or prints the following.

DRSXM-AO

ZROA-G-O

RD/RX EXERCISER

UNIT IS RODX or

RUX50

RESTART ADDRESS 141656

DR>

3-5

Testing and Formatting

Remove the diagnostic diskette from the RXSO unit and replace it with the scratch diskettes. Run the exerciser program as follows.

1. When the console displays or prints the DRS prompt, type START and press the Return key.

2. When the console displays or prints

Change HW (L)

? type Y and press the

Return key.

3. When the console displays or prints

#

UNITS (D) ? type 4 and press the Return key.

4. When the console displays or prints unit 0

IP address

(0) 172150 ? press the Return key if the RQDX3 module is the first MSCP device.

5. When the console displays or prints

Vector (0) 154 ? press the

Return key if the RQDX3 module is the first MSCP device.

6. When the console displays or prints

BR level [usually 4-RQDX 5-RUX50]

(0) 4 ? press the Return key.

7. When the console displays or prints

Drive number (D) 0

? type 0 and press the Return key.

3-6

Testing and Formatting

8. When the console displays or prints

Also run DUP exerciser (L) N

? press the

Return

key.

9. When the console displays or prints

Test entire customer area of the disk (L) Y ? press the

Return

key.

10. When the console displays or prints

Write on customer data area of this disk unit (L)

? type Y and press the

Return

key.

11. When the console displays or prints

WARNING - CUSTOMER DATA AREA MAY BE

OVERWRITTEN ! ... CONFIRM (L) ? type Y and press the

Return

key.

The diagnostic will repeat the above procedure for units 1 to 3. Type in the same responses except for the drive number prompts which will be 1-3 respectively.

12. When the console displays or prints

Change SW (L)

? type N and press the

Return

key to select defaults. (Refer to diagnostic listings to change parameters

if

desired.)

13. When the console displays or prints

FUNCTIONAL TEST STARTED

EXERCISER STARTED the RQDX exerciser procedure is completed.

3-7

Testing and Formatting

MicroVAX II System Diagnostics

Micro VAX Maintenance System (MMS) diagnostics provide the programs necessary to verify operation of all Micro VAX system components, including the RQDX3 module. Two MMS versions are available.

1. Customer Version (MMS Menu 1)

2. Service Version (MMS Menu 2)

The main difference between the two versions is that the customer version supports system test, LIST, and EXIT commands only, while the service version supports all system commands.

Customer Version -

The customer version is loaded from diskettes which are supplied with the system. This version implements the MAIN MENU which checks out installation configurations. Incorrect installations are evident to system users when devices known to be physically installed are not found by the MAIN MENU.

Service Version -

The service version implements all menus and is loaded from diskettes purchased separately by the user. RQDX3 formatting programs and exerciser tests are run using the SERVICE MENU.

The SERVICE MENU permits the user to select both the RD/RX utility exerciser and the RQDX3 formatting programs. The following formatting procedure is an example of formatting a MicroVAX II system with an RQDX3 controller module.

Procedures for other systems may differ.

NOTE

New drives or drives originally formatted with an RQDX1 or

RQDX2 controller must be re-formatted using the RQDX3 controller.

CAUTION

Formatting an RD disk drive destroys any files that are present on the disk. If you think that files exist, make a backup copy before you proceed. Write-protect any other fixed disk drives that are present. Refer to your software documentation for instructions.

3-8

Testing and Formatting

To run the MDM formatting and utility testing programs for diagnostic release version 1.06 follow these steps.

NOTE

The console displays shown herein are typical examples only.

They may differ from your displays because you may be using updated MicroVAX maintenance diagnostics.

1.

Install service version diskette number 1 into the appropriate RX50 slot and boot the system.

2. The console displays or prints the following line.

MICROVAX MAINTENANCE SYSTEM - DIAGNOSTIC RELEASE 1.06

NOTE

After diskette 1 has been loaded, MOM will prompt you to load the remaining diskettes. Follow the instructions displayed or printed on the console until MOM says your system is ready for testing.

3. The MAIN MENU is displayed or printed.

,..

MAIN MENU

1 - Test the system

2 - Display System Configuration and Devices

3 - Display the Utilities Menu

4 - Display the Service Menu

5 - Exit MicroVAX Maintenance System

Type the number; then press the RETURN key.

>

MR· 17040

NOTE

System configuration won't show RD disk drives configured with an RQOX3 controller if the formatter has not been run successfully.

3-9

Testing and Formatting

4. When the MAIN MENU is displayed or printed, type 4 and press the Return key, enabling the user to enter the SERVICE MENU.

,..

SE:RVICE MENU

CAUTION: This menu is intended for use by qualified service personnel only. Misuse of the commands could destroy data.

1 - Set test and message parameters

2 - Exercise system continuously

3 - Display the device menu

4 - Enter system commands

Type the number; then press the RETURN keyortypeOand press the RETURN key to return to the main menu.

>

MR -17041

5. Set the test and message parameters by typing 1 and press the Return key, allowing· the following console display or printout.

SERVICE MENU

TEST AND MESSAGE PARAMETERS

PARAMETER

SETTING

1. - Display test progress messages ......................................... DISABLED

2. - Display detailed error messages ......................................... DISABLED

3. - Stop testing on error ............................................................. DISABLED

4. - Ring bell on error ............•...................................................... DISABLED

Type the number of the parameter and press the RETURN key to reverse the setting or type

0 and press the RETURN key to return to the previous menu.

>

MA -17042

NOTES a. To enable parameter 1, type

"1"

and return. b. To enable parameter 2, type

"2"

and return. The settings will now be displayed as enabled for parameters 1 and 2.

3-10

c. Return to service menu by typing

"0"

and return.

Testing and Formatting

6. To select the DEVICE MENU, type 3 and press the

Return

key, allowing the following console display or printout.

,..

SERVICE MENU

DEVICES

This menu lets you enable or disable testing for devices and perform functional and exerciser tests on a selected device

1 - CPUA - MicroVAX CPU

2 - MEMA - MicroVAX memory system

3 - RQDXA - Winchester/diskette controller

4 - TK50A - Cartridge tape controller

5 - DEQNAA - Ethernet controller

6 - DHVll A - 8 line asynchronous multiplexer

Type the number; then press the RETURN key or type 0 and press the RETURN key to return to the previous menu.>

...

17043

7. To select RQDXA functions, type 3 and press the

Return

key, allowing the following console display or printout.

,..

SERVICE MENU

DEVICES

RQDXA - Winchester/diskette controller

Testing is ENABLED

1 - Enable/disable testing for device

2 - Perform all functional tests

3 - Perform the exerciser test

4 - Display the device utilities menu

Type the number; then press the RETURN key or type 0 and press the RETURN key to return to the previous menu.>

MR

3-11

Testing and Formatting

8. To select the device utilities menu, type 4 and press the Return key, allowing the following console display or printout.

SERVICE MENU

DEVICES

RODXA - Winchester/diskette controller

UTILITY PROGRAMS AND TESTS

Utility selections are:

1 - Formatter for RD53, RD52 and RD51 Winchester.

2 - Utility MSCP Exerciser

Type the number; then press the RETURN key or type 0 and press the RETURN key to return to the previous menu.

>

MA-17045

9. To select the formatter for Winchester drives, type 1 and press the Return key, allowing the following display or printout.

,..

RUNNING A UTILITY SERVICE TEST

To halt the test at anytime and return to the previous menu, type" C by holding down the CTRL key and pressing the C key.

RODXA Started

RODXA pass 1 test number 1 started.

WARNING, this utility will destroy any user data on the selected drive.

MR-17046

3-12

Testing and Formatting

10. When the console displays or prints

Do you want to continue [YES=1, (NO=O)] ? type 1 and press the

Return key, assuming user data is backed up.

11. When the console displays or prints

Do you want to use the "AUTOFORMAT" mode [(Yes=1), No=O]:= type 1 and press the Return key.

12. When the console displays or prints

What unit do you want to format (0-3) ? type 0, 1, 2 or 3, depending on whatever unit you wish to select and press the Return key.

13. When the console displays or prints

Is this the correct unit number? [(Yes=1), No=O] := type 1 and press the Return key.

14. When the console displays or prints

Please enter the date [MM-DD-YYYY] := type today's date and press the Return key.

15. When the console screen displays or prints

Please type in a six digit serial number := type in the serial number located on the disk drive and press the Return key.

16. When the console displays or prints

FORMAT BEGUN allow about 35 min for the formatting to be implemented successfully.

17. When the console displays or prints

The controller reported a successful termination of the format command

3-13

Testing and Formatting

If

a failure occurs during the time allowed for formatting, the following console display or printout is obtained.

- THE WINCHESTER DRIVE IS OFFLINE.

- THE WINCHESTER DRIVE IS WRITE PROTECTED.

- THE DRIVE IS DEAD.

- BAD BLOCK INFORMATION SHOULD NOT HAVE BEEN SPECIFIED.

- THE CABLES GOING TO THE DRIVE ARE NOT MAKING CONTACT.

- A NON-EXISTENT DRIVE HAS BEEN SPECIFIED.

- THE DRIVE SELECT SWITCHES ARE SET WRONG.

MA·17047

18. Mter formatting has been completed successfully on the RD drive(s), go back to the menu shown in Step 7, type .2 and press the Return key as required to select the functional tests. Allow the functional tests to run one pass with no errors.

19. Go back to the menu shown in Step 7, type 3 and press the Return key as required to select the exerciser tests. Allow the exerciser tests to run three passes with no errors.

20. Go back to the menu shown in Step 4, type 2 and press the Return key as required to exercise the system. Allow the system to complete system tests successfully.

Mter successful completion of the system tests, the customer can restore data and . bring up system software. However,

if

a drive problem is experienced while running the functional and exerciser tests, run the RQDX device utility to help isolate the fault. Perform Step 21 to do this.

21. Go back to the menu shown in Step 8, type 2 and press the Return key as required to select the utility MSCP exerciser. Answer the prompts as required to select the testing options you want. '

3-14

Glossary of MSCP and DUP Commands

MSCP COMMANDS

The RQDX3 module supports the following MSCP commands.

ABORT COMMAND

Aborts a command which is currently in progress.

ACCESS

Reads data from a unit starting at a given logical block number and discards the data obtained.

AVAILABLE

Returns a unit to the Unit-Available state.

COMPARE

Reads data from a unit starting at a given logical block number and compares it with data read from the host.

ERASE

Fills a buffer with Os and writes it to a unit starting at a given logical block number. .

GET COMMAND STATUS

Obtains information about the progress of a command.

GET UNIT STATUS

Obtains unit geometry and status information.

ONLINE

Brings a unit from the Unit-Available state to the Unit-Online state, so that it is ready to accept further commands.

4-1

Glossary of MSCP and DUP Commands

READ

Reads data from a unit, starting at a given logical block number, and copies it to the host.

SET CONTROLLER CHARACTERISTICS

Sets some controller operating characteristics.

SET UNIT CHARACTERISTICS

Sets some unit operating characteristics.

WRITE

Copies data from the host and writes it to a unit starting at a given logical block number.

DUP COMMANDS

The RQDX3 module supports the following DUP commands.

ABORT PROGRAM

Aborts a program which is currently in progress.

EXECUTE LOCAL PROGRAM

Begins running a program stored in ROM.

EXECUTE SUPPLIED PROGRAM

Loads a program into RAM and begins running it.

GET DUP STATUS

Obtains information about local DUP state.

RECEIVE DATA

Transfers data from the RQDX3 to the host.

SEND DATA

Transfers data from the host to the RQDX3.

These local programs can be invoked by the EXECUTE LOCAL PROGRAM command.

DIRECT

Transmits an ASCII directory of all available local programs to the host.

FORMAT

Formats a unit.

4-2

Appendix A

RQDX3 Backplane Pin Assignments

RQDX3 CONTROLLER

Digital's plug-in modules, including the RQDX3 controller all use the same contact

(pin) identification system (Table A-I). See Figure A-I for controller contact fingers.

M7555

FRONT SIDE

M7555

REAR SIDE

AAl

ROW A

BAl

BA2

ROW B

BV~

Figure A-I Dual Module Contact Finger Identification Diagram

MR-1"6585

A-1

RQOX3 Backplane Pin Assignments

BAI

BBI

BCl

BDI

BEl

BFl

BHl

BJI

BKI

BLI

BMI

BNl

BPI

BRI

BSI

BTl

BUI

BVI

Pin

AJI

AKI

ALl

AMI

ANI

API

ARI

ASI

ATI

AUI

AVI

AAI

ABI

ACI

ADI

AEI

AFI

AHI

Table A-I RQDX3 Module Finger Connections

Signal Name

(BIRQ5 L)*

(BIRQ6 L)

BDAL16 L

BDAL17 L

(SSPAREI or +5 B)

(SSPARE2)

(SSPARE3)

GND

(MSPAREA)

(MSPAREB)

GND

BDMRL

(BHALT L)

BREF L

(+12 B or +5 B)

GND

(PSPAREl)

(+5 B)

Pin

AJ2

AK2

AL2

AM2

AN2

AP2

AR2

AS2

AT2

AU2

AV2

AA2

AB2

AC2

AD2

AE2

AF2

AH2

(BDCOK H)

BPOKH

BDAL18 L

BDAL19 L

BDAL20 L

BDAL2l L

(SSPARE8)

GND

(MSPAREB)

(MSPAREB)

GND

BSACK L

(BIRQ7 L)

(BEVNT L)

(+12 B)

GND

(PSPARE2)

+5 Vdc

BJ2

BK2

BL2

BM2

BN2

BP2

BR2

BS2

BT2

BU2

BVI

BA2

BB2

BC2

BD2

BE2

BF2

BH2

*

Names in parentheses represent Q-Bus signals not used

A-2

Signal Name

+5 Vdc

(-12 Vdc)

GND

+12 Vdc

BDOUT L

BRPLY L

BDIN L

BSYNC L

BWTBT L

BIRQ4 L

BIAKI L

BIAKO L

BBS7 L

BDMGI L

BDMGO L

BINITL

BDALO L

BDALI L

+5 Vdc

(-12 Vdc)

GND

+12 Vdc

BDAL2 L

BDAL3 L

BDAL4 L

BDAL5 L

BDAL6 L

BDAL7 L

BDAL8 L

BDAL9 L

BDALIO L

BDALll L

BDAL12 L

BDAL13 L

BDAL14 L

BDAL151

Appendix B

RQDX3 Controller Module Cable Signals

CONNECTOR PINOUTS

Table B-1 lists the RQDX3 controller module signals on connector J1 (part number

12-13506-13).

Table B-1

Jl Pin

-1

-2

-3

-4

-5

-6

-7

-8

-9

-10

-11

-12

-13

-14

-15

-16

-17

-18

-19

-20

-21

-22

-23

-24

-25

Jl Connector Pinouts

Signal Name

MFMWRTDTI (H)

MFMWRTDTI (L)

GROUND

HEADSEL2 (L)

GROUND

SEEKCPLT (L)

DRVIRDY (H)

WRTFAUL T (L)

HEADSEL3 (L)*

HEADSELI (L)

DRVIRDY (H)

DRV3RDY (H)

DRVIWPT (L)

DRVSLOACK (L)

MFMRDDATO (H)

MFMRDDATO (L)

MFMWRTDTO (H)

MFMWRTDTO (L)

MFMRDDATI (H)

MFMRDDATI (L)

GROUND

REDUCWRTI (L)t

DRV3WPT (L)

DRVSEL4 (L)

GROUND

Jl Pin

-26

-27

-28

-29

-40

-41

-42

-43

-44

-45

-46

-47

-48

-49

-50

-30

-31

-32

-33

-34

-35

-36

-37

-38

-39

Signal Name

INDEX (L)

DRV4WPT (L)

DRVSELI (L)

DRVSEL2 (L)

DRVSEL3 (L),

DRV2RDY (H)

RXMOTORON (L)

GROUND

DIRECTION (L)

GROUND

STEP (L)

GROUND

RXWRTDATA (L)

GROUND

WRTGATE (L)

GROUND

TRACKOO (L)

DRV2WPT (L)

DRVSLIACK (L)

GROUND

RXRDATA (L)

GROUND

HEADSELO (L)

GROUND

READY (L)

* Connected to HEADSEL3 signal, left open or grounded via a jumper on module. t The HEADSEL3 signal may be ORed with the REDUCWRTI signal via a jumper on the module.

8-1

RQDX3 Controller Module Cable Signals

CONNECTOR SIGNALS DESCRIPTION

It is recommended that the output signals from this module be terminated at the far end of a 130 ohm impedance cable with a single 220/330 resistor divider network. The maximum allowable cable length when proper termination is used is

8 ft. It is the responsiblity of the system design engineer to insure the integrity of those output signals through proper cabling techniques.

The following is a description of the signals available on the drive interface connector

11.

The timing and electrical characteristics of these signals are compatible with signals specified in the RD51, RD52, RD53, and RX50 drive specifications.

Table B-2 Description of Connector Signals

Signal

Input

I

Output Description

DIRECTION (L) Output This signal controls the direction of head movement. When asserted, the direction of movement is toward the spindle (in).

DRV<4:1>RDY (H)

Input/Output

When one or more of these signals is asserted by the front panel (READY switch open), the controller will assume that the hard disk drive on the corresponding DRVSEL<4:1> line is ready for data transfers. When the controller performs a seek function on a hard disk drive, it will force this signal to an unasserted condition to turn off the

READY light on the front panel for the corresponding drive.

The controller will ignore the state of the appropriate DRV <4: 1> RDY when there is a floppy disk drive attached to a

DRVSEL<4:1> line.

B-2

RQDX3 Controller Module Cable Signals

Table B-2 Description of Connector Signals (Cont.)

Signal

DRV<4:1>WPT (L)

Input/

Output Description

Input/Output These signals, when asserted from the front panel (Write Protect switch closed), are used to indicate to the controller that hard disk drives connected to the corresponding DRVSEL<4:1> line are to be protected against write operations.

DRVSEL<4: 1> (L)

DRVSL<1:0>ACK (L)

Output

Input

The controller will assert a

DRV<4:1>WPT signal to indicate that the system software has write protected the hard disk on the corresponding

DRVSEL<4:1> line.

The controller will assert one of these signals to select one of four drives for operation.

These input signals are asserted by a hard disk drive to indicate that it has been selected. When either or both of these signals are asserted, the controller will assume that there is a hard disk drive connected to the currently active

DRVSEL<4:1> line.

GROUND

HEADSEL<3:0> (L)

INDEX (L)

Output

Input

The signal return path.

These signals are used to select one of up to sixteen surfaces on the currently selected drive.

This input signal informs the controller that the currently selected drive is at the beginning of a track.

8-3

RQDX3 Controller Module Cable Signals

Table B-2 Description of Connector Signals (Cont.)

Signal

Input!

Output

MFMRDDAT<1:0> (H) Input

MFMRDDAT <1:0> (L)

Description

Data from the hard disk drive surface will be transmitted to the controller on these differential pairs. The controller will assume that hard disk drives on

DRVSEL1 and DRVSEL3 will transmit their data on the MFMRDDATO differential pair and that hard disk drives on DRVSEL2 and DRVSEL4 will transmit their data on the MFMRDDA T1 pair.

MFMWRTDT <1:0> (H) Output

MFMWRTDT<1:0> (L)

These differential signal pairs will be used to transmit data to be written to the disk surface when the Write Gate signal is asserted. There are two sets of these differential pairs to allow two hard disk drives to be connected without external logic. Both pairs will be active at the same time.

READY (L)

Input This input signal from the drive will indicate the following.

• For hard disk drives, it will indicate that when SEEKCPL T is also asserted the drive is ready to read, write or seek.

• It will indicate that the drive is selected, the media door is closed and media is present for floppy disk drives.

8-4

RQDX3 Controller Module Cable Signals

Table B-2

Description of Connector Signals (Cont.)

Signal

Input

I

Output Description

REDUCWRTI (L) Output

This controller output can be asserted to force a disk drive to use a low value of write current if appropriate.

RXMOTORON (L)

Output This signal is asserted by the controller to turn on the floppy disk drive motor(s).

RXRDATA (L)

Input This input is the read data channel from floppy disk drives.

RXWDATA (L)

Output This output is the write data channel to floppy disk drives.

SEEKCPL T (L)

Input

STEP (L)

TRACKOO (L)

Output

Input

This input should be asserted when the currently selected hard disk drive has completed a seek function.

This output signal is used to step the head(s) of the currently selected floppy disk drive or hard disk drive.

This input signal from the currently selected hard disk drive or floppy disk drive will indicate that the drive's head(s) are positioned at track zero.

8-5

RQOX3 Controller Module Cable Signals

Table B-2

Description of Connector Signals (Cont.)

Signal

Input/

Output Description

WRTFAULT (L) Input For hard disk drives, this signal should be asserted when a condition exists in a selected drive which should cause writing to be inhibited. The signal should remain asserted until the error condition is corrected and/or the drive is de-selected.

Some of these error conditions include:

• Write current and no write gate, or write gate with no write current

• Multiple heads, no head, or improperly selected head

• DC voltages out of tolerance

• Write gate asserted and seek complete de asserted

WRTGATE (L) Output

For floppy disk drives, this signal is asserted when a write protected diskette is present.

When asserted, this controller output signal will turn on the write drivers of the currently selected drive.

8-6

Appendix C

Supported Drive Geometries

Table C-l Supported Drive Matrix

Description RD51 RD52 RD52 RD53 RX50

Sector interleave

Bytes/Sector

Sectors/LBN

LBNs/Track

Tracks/Group

Groups/Cylinder

Cylinders/Unit

Total LBNs/Unit

RBNs/Unit

RCT size (blocks)

RCT copies

DBNs/Unit

XBNs/Unit

User LBNs/Unit

User capacity (bytes)

Step pulsewidth VLsec)

Step rate

(~sec)

Write precomp (nsec)

Precomp cylinders

2:1

512

1:1

512

1

1:1

512

1

1:1

512

1

2:1

512

1

18

1

4

306

17

8

1

512

17

7

1

645

17

8

1

1024

1

10

80

1

1

22,032 69,632 76,755 139,264 800

144 168 168 280

Track

36 4 4 5

4

87

8

82

8

65

8

82

57 54 54 54

21,600 60,480 60,480 138,672

800

11.06 M 30.96 M 30.96 M 71.00 M 4096 K

11.2

17.6

10

11.2

17.6

10

11.2

17.6

10

11.2

17.6

224

8*

0-55t

56-77+

110-305 256-511 320-644 0

. * msec t

±110 nsec cylinders

:j: ±210 nsec cylinders

C-1

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
