OWNER’S MANUAL

DVD Micro Hi-Fi System

Please read this manual carefully before operating your set and retain it for future reference.

FB165DAB (FB165DAB, FBS166V)

P/NO : MFL67006432

2 Getting Started

1

Safety Information

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This lightning fl ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK

HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN

OR MOISTURE.

WARNING: Do not install this equipment in a confi ned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

CAUTION: This product employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Shall the unit require maintenance, contact an authorized service centre.

Use of controls, adjustments or the performance of procedures other than those specifi ed herein may result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specifi cation page of this owner’s manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous.

Any of these conditions could result in electric shock or fi re. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service centre. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

Getting Started 3

This device is equipped with a portable battery or accumulator.

Safety way to remove the battery or the

battery from the equipment: Remove the old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, fi re or the like.

CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects fi lled with liquids, such as vases, shall be placed on the apparatus.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the

European Directive 2002/96/EC.

2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, disposal service or the shop where you purchased the product.

Copyrights

It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyrighted material without permission. This product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. When recording and playing the pictures of these discs picture noise will appear. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

CONSUMERS SHOULD NOTE THAT NOT ALL

HIGH DEFINITION TELEVISION SETS ARE FULLY

COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE

ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN

CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE

PROBLEMS, IT IS RECOMMENDED THAT THE USER

SWITCH THE CONNECTION TO THE ‘STANDARD

DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS

REGARDING OUR TV SET COMPATIBILITY WITH THIS

MODEL 525p AND 625p UNIT, PLEASE CONTACT

OUR CUSTOMER SERVICE CENTER. You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players.

(Mastered/ Live File System : Disc format system for

Windows Vista)

 The appliance is not intended for use by young children or infi rm persons without supervision.

 Young Children should be supervised to ensure that they do not play with appliance.

 If the appliance is supplied from a cord extension set or an electrical portable outlet device, the cord extension set on electrical portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture.

1

4 Table of Contents

Table of Contents

6 – USB Direct Recording

6 – Full HD up-scaling

6 Accessories

7 Introduction

7 – About the “ 7” Symbol Display

7 – Symbols Used in this Manual

20 Adjust the setup settings

20 – OSD Initial language settings -

Optional

20 – To display and exit the Setup menu

22 – Lock (Parental Control)

2 Connecting

13 Attaching the speakers to the unit

13 Connections TV

14 – HDMI Out Connection

16 Video Output Resolution

16 Optional Equipment Connection

16 – AUDIO (PORT. IN) In Connection

16 – Listening to music from your portable player or external device

17 – OPTICAL In connection

17 – Home theatre speaker ez setup

18 – Playing the iPod

Table of Contents 5

4 Operating

24 Using the Home Menu

25 – Displaying Disc Information on-screen

25 – To display the DVD Menu

25 – To display the DVD title

25 – 1.5 times speed playback

25 – Starting play from selected time

26 – Changing subtitle code page

27 – Viewing a PHOTO fi le

28 – Last Scene Memory

28 – System Select - Optional

28 – Adjust the speaker level settings

29 – Setting the Clock

29 – Using your player as an alarm clock

5 Troubleshooting

33 Troubleshooting

6 Appendix

34 Area Code List

35 Language code List

36 Trademarks and Licenses

37 Specifi cations

39 Maintenance

39 – Handling the Unit

39 – Notes on Discs

1

2

3

4

29 – Turn off the sound temporarily

5

30 – Listening to the radio

30 – Presetting the Radio Stations

30 – Deleting all the saved stations

30 – Deleting a saved station

30 – Improving poor FM reception

30 – Listening to the DAB

30 – Aligning the service names

31 – Deleting all of the saved DAB scan stations

31 – Setting the surround mode

32 – Recording to USB

6

6 Getting Started

Unique Features

1

Portable In

Listens to music from your portable device. (MP3,

Notebook, etc)

USB Direct Recording

Records music from CD to your USB device.

Full HD up-scaling

Views Full HD picture quality with simple setup.

Accessories

Please check and identify the supplied accessories.

Remote control (1) Battery (1)

Video cable (1) FM antenna (1)

Getting Started 7

Introduction

Playable Discs

This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or

JPEG fi les. Some DVD±RW/DVD±R or CD-RW/

CD-R cannot be played on this unit due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software.

DVD-VIDEO (8 cm / 12 cm disc)

Discs such as movies that can be purchased or rented.

DVD±R (8 cm / 12 cm disc)

Video mode and fi nalized only.

DVD-RW (8 cm / 12 cm disc)

Video mode and fi nalized only.

DVD+R: Video mode only

Supports the double layer disc also.

DVD+RW (8 cm / 12 cm disc)

Video mode and fi nalized only.

Audio CD: Music CDs or CD-R/CD-

RW in music CD format that can be purchased.

About the “

7” Symbol Display

“7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specifi c media.

Symbols Used in this Manual

t

Audio CDs y

Video fi les contained in the

USB/Disc u

Audio fi les contained in the

USB/Disc i

Photo fi les

,

Note

Indicates special notes and operating features.

,

Tip

Indicates tip and hints for making the task easier.

>

Caution

Indicates cautions for preventing possible damages from abuse.

Regional Codes

This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labelled same as the rear of the unit or

“ALL”.

 Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your unit’s regional code or the disc cannot play.

 If you try to play a DVD with a diff erent regional code from your unit, the message “Check

Regional Code” appears on the TV screen.

1

1

8 Getting Started

Playable fi le

Requirement

MP3/ WMA music fi le requirement

MP3/ WMA fi le compatibility with this unit is limited as follows :

 Sampling frequency : within 32 to 48 kHz (MP3), within 32 to 48 kHz (WMA)

 Bit rate : within 32 to 320 kbps (MP3),

40 to 192 kbps (WMA)

 Support Version : v2, v7, v8, v9

 Maximum fi les : Under 999

 File extensions : “.mp3”/ “.wma”

 CD-ROM fi le format : ISO9660/ JOLIET

 We recommend that you use Easy-CD Creator, which creates an ISO 9660 fi le system.

 If there is impossible code to express in the

MP3/WMA fi le, it may be displayed as “ _ “ mark on the display.

Photo fi le requirement

Photo fi le compatibility with this unit is limited as follows :

 Max pixel in width : 2 760 x 2 048 pixel

 Maximum fi les : Under 999

 Some discs may not operate due to a diff erent recording format or the condition of disc.

 File extensions: “.jpg”

 CD-ROM fi le format : ISO9660/ JOLIET

DivX fi le requirement

DivX fi le compatibility with this unit is limited as follows:

 Available resolution: within 800 x 600 (W x H) pixels.

 The fi le name of the DivX subtitle should be entered within 45 characters.

 If there is impossible code to express in the

DivX fi le, it may be displayed as “ _ “ mark on the display.

 Frame rate : less than 30 fps.

 If the video and audio structure of recorded fi les is not interleaved, either video or audio is outputted.

 Playable DivX fi le : “.avi”, “.mpg”, “.mpeg”, “.divx”

 Playable Subtitle format : SubRip (*.srt/ *.txt),

SAMI (*.smi), SubStation Alpha (*.ssa/ *.txt),

MicroDVD (*.sub/ *.txt), SubViewer 2.0 (*.sub/

*.txt), Vobsub (*.sub)

 Playable Codec format : “DIVX3.xx”, “DIVX4.xx”,

“DIVX5.xx”, “MP4V3”, “3IVX”.

 Playable Audio format : “AC3”, “PCM”, “MP3”, “WMA”.

 Sampling frequency : within 32 to 48 kHz (MP3), within 32 to 48 kHz (WMA)

 Bit rate : within 32 to 320 kbps (MP3), 40 to 192 kbps (WMA)

 For Discs formatted in Live fi le system, you can not it on this unit.

 If the name of movie fi le is diff erent from that of the subtitle fi le, during playback of a DivX fi le, subtitle may not be display.

 If you play a DivX fi le diff er from DivXspec, it may not operate normally.

Getting Started 9

Remote control

Battery Installation

Remove the battery cover on the rear of the Remote Control, and insert one (size AAA) battery with

4 and 5 matched correctly.

• • • • • • a • • • • •

P RADIO&INPUT: Changes input sources.

MARKER: Marks play list.

1 POWER: Switches the unit ON or OFF.

B OPEN/CLOSE

Insert or release a disc.

SLEEP: Sets the System to turn off automatically at a specifi ed time.

(Dimmer : The display window will be darken by half.) m INFO/DISPLAY: Accesses On-

Screen Display.

n HOME: Displays the [Home

Menu].

DISC MENU: Accesses the menu on a DVD disc.

• • • • • • d • • • • •

SPEAKER LEVEL: Sets the sound level of desired speaker.

SOUND EFFECT: Selects a sound eff ect mode.

VOL -/+ (Volume): Adjusts speaker volume.

OPTICAL: Changes input source to optical directly.

MUTE: Mutes the sound.

• • • • • • e • • • • •

0-9 numerical buttons: Selects numbered options in a menu.

CLEAR: Removes a number when setting the password.

REPEAT: Selects a play mode.

(Repeat/ Random)

• • • • • • b • • • • •

W/S/A/D (up/ down/ left/ right): Used to navigate on-screen displays.

PRESET +/-: Selects programme of Radio.

TUNING +/-: Tunes in the desired radio station.

b ENTER: Acknowledges menu selection.

Presetting the radio stations.

x RETURN: Moves backwards in the menu or exits the setup menu.

TITLE: If the current DVD title has a menu, the title menu appears on the screen. Otherwise, the disc menu may not appear.

• • • • • • c • • • • •

C/V SKIP: Goes to the next or previous chapter / track / fi le. c/v SCAN: Searches backward or forward.

Z STOP: Stops playback.

d PLAY, MONO/STEREO: Starts playback. Selects Mono/ Stereo.

M PAUSE/STEP: Pauses playback.

• • • • • • f • • • • •

TV Control buttons: Controls the

TV. (LG TV only)

- You can control the sound level, input source, and power switching of LG TVs as well.

Hold POWER (TV) and press PR/

CH (+/-) button repeatedly until the TV turns on or off .

X REC: USB Direct Recording.

?: This button is not available.

DAB INFO.:

- Search radio stations RDS (Radio

Data System) or DAB radio type.

- Changes the display information of DAB channel.

SORT/SCAN:

- Searches radio stations by radio type.

- Aligning the service names DAB band scanning.

1

1

10 Getting Started

Front panel

Getting Started 11

a Disc Slot b iPod dock c 1/! (POWER)

Switches the unit ON or OFF.

d Display window

Shows the current status of the unit.

e FUNC. (FUNCTION)

Changes the input source or function.

f USB Port

Connects an USB device.

g EQ

You can choose fi xed sound impression.

Confi rms the setting. Press DEMO in power off state to demonstrate the function on display window. To cancel it, press DEMO again.

TIMER

With the TIMER function you can turn USB, CD play and TUNER reception on or off at a desired time.

CLOCK

For setting the clock and checking the time.

h B (OPEN/CLOSE)

Insert or release a disc.

i C/V (Skip/Search):

Goes to next or previous fi le/track/chapter.

Searches backward or forward (Press and hold)

Tunes in the desired radio station.

d/M (PLAY / PAUSE)

Starts playback.

Pauses playback temporarily, press again to exit pause mode. j -/+ (VOLUME)

Adjusts speaker volume.

Z (STOP)

Stops playback.

k USB REC.

Recoding to USB.

l PORT. IN

Connects to a portable player with audio outputs.

PHONES

Headphone jack

1

1

12 Getting Started

Rear panel

a Antenna Connector

DAB - Connects the DAB antenna.

b OPTICAL IN

Connects to optical audio equipment.

c HDMI OUT

Connects to TV with HDMI inputs.

(Interface for digital audio and video) d Antenna Connector

FM- Connects the FM wired antenna.

e VIDEO OUT

Connects to a TV with video inputs.

f COMPONENT VIDEO (Y PB PR)OUTPUT

(PROGRESSIVE SCAN)

Connects to a TV with Y PB PR inputs.

g Speakers connectors

Connects the speaker cables.

h Cooling Fan i Power cord

Connecting 13

Attaching the speakers to the unit

Connections to Your

TV

To connect the cable to the unit, press each plastic fi nger pad to open the connection terminals on the unit. Insert the wire and release the fi nger pad.

Connect the black stripe of each wire to the terminals marked - (minus) and the other end to the terminals marked + (plus).

Make one of the following connections, depending on the capabilities of your existing equipment.

,

Note

 Depending on your TV and other equipment you wish to connect, there are various ways you could connect the player.

Use only one of the connections described in this manual.

 Please refer to the manuals of your TV,

Stereo System or other devices as necessary to make the best connections.

2

>

Caution

 The speakers contain magnet parts, so colour irregularity may occur on the TV screen or PC monitor screen. Please use the speakers far away from either TV screen or

PC monitor.

 Make sure while installing the speakers have assistants in order to prevent it from falling and causing injuries to the installer.

>

Caution

 Make sure the unit is connected directly to the TV. Tune the TV to the correct video input channel

 Do not connect your player via your VCR.

The image could be distorted by the copy protection system.

2

14 Connecting

Component Video Connection

Connect the COMPONENT VIDEO OUTPUT

(PROGRESSIVE SCAN) jacks on the unit to the corresponding input jacks on the TV using component cables.

You can hear the sound through the system’s speakers.

HDMI Out Connection

If you have a HDMI TV or monitor, you can connect it to this unit using a HDMI cable (Type A, High

Speed HDMI™ cable).

Connect the HDMI OUT jack on the unit to the

HDMI IN jack on a HDMI compatible TV or monitor.

Set the TV’s source to HDMI (refer to TV’s Owner’s manual).

Unit

Unit

TV

Green

Blue

Red

TV

,

Tip

 You can fully enjoy digital audio and video signals together with this HDMI connection.

 When you use HDMI connection, you can change the resolution for the HDMI output.

(Refer to “Resolution” on page 21.)

,

Note

 If a connected HDMI device does not accept the audio output of the unit, the HDMI device’s audio sound may be distorted or may not output.

 When you connect a HDMI or DVI compatible device make sure of the following:

- Try switching off the HDMI/DVI device and this unit. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this unit.

- The connected device’s video input is set correctly for this unit.

- The connected device is compatible with

720 x 480i (or 576i), 720 x 480p (or 576p), 1

280 x 720p, 1 920 x 1 080i or 1 920 x 1 080p video input.

 Not all HDCP-compatible HDMI or DVI devices will work with this unit.

- The picture will not be displayed properly with non-HDCP device.

- This unit does not playback and TV screen is changed to black or green screen or the snow noise may occur on the screen.

 If there is noise or lines on the screen, please check the HDMI cable and usea higher version cable than High Speed HDMI™ cable.

>

Caution

 Changing the resolution when the connection has already been established may result in malfunctions. To solve the problem, turn off the unit and then turn it on again.

 When the HDMI connection with HDCP is not verifi ed, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the the HDMI connection, or disconnect the

HDMI cable.

Connecting 15

Video Connection

Connect the VIDEO OUT jack on the unit to the video in jack on the TV using a video cable.

You can hear the sound through the system’s speakers.

Unit

TV

Yellow

2

16 Connecting

2

Resolution Setting

The unit provides several output resolutions for

HDMI OUT and COMPONENT VIDEO OUT jacks. You can change the resolution using [Setup] menu.

Optional Equipment

Connection

ENTER. The [Setup] menu appears.

AUDIO (PORT. IN) In

Connection

Connect an output of portable device (MP3 or PMP etc) to the AUDIO (PORT. IN) input connector.

D to move to the second level. then press D to move to the third level.

press b ENTER to confi rm your selection.

,

Note

If your TV does not accept the resolution you have set on the player, you can set resolution to 480p (or 576p) as follows:

Press Z STOP for more than 5 seconds.

MP3 player, etc...

Video Output

Resolution

Displayed resolution in display window and outputted resolution may diff erent according to connection type.

[HDMI OUT]: 1 080p, 1 080i, 720p and 480p (or

576p) and 480i (or 576i)

[COMPONENT VIDEO OUT]: 480p (or 576p) and 480i

(or 576i)

[VIDEO OUT]: The resolution of the VIDEO OUT jack is always outputted at 480i (or 576i) resolution.

Listening to music from your portable player or external device

The unit can be used to play the music from many types of portable player or external devices.

1. Connect the portable player to the

PORT.IN(PORTABLE IN) connector of the unit.

2. Turn the power on by pressing 1 (POWER).

3. Select the PORTABLE function by pressing

P RADIO&INPUT.

4. Turn on the portable player or external device and start it playing.

Connecting 17

USB Connection

Connect the USB port of USB Memory (or MP3 player, etc.) to the USB port on the front of the unit.

OPTICAL In connection

Connect an optical output of Unit (or Digital Device etc) to the OPTICAL IN connector.

Removing the USB Device from the unit

1. Choose a diff erent function mode or press

Z STOP twice in a row.

2. Remove the USB device from the unit.

 You can recharge your iPod through USB port.

To listen to music on iPod, refer to the page 18.

Compatible USB Devices

 MP3 Player : Flash type MP3 player.

 USB Flash Drive :

Devices that support USB2.0 or USB1.1.

 The USB function of this unit does not support some USB devices.

USB device requirement

 Devices which require additional program installation connected to a computer, are not supported.

 Do not extract the USB device while in operation.

 For a large capacity USB, it may take longer than a few minute to be searched.

 To prevent data loss, back up all data.

 If you use a USB extension cable or USB hub, the

USB device is not recognized.

 Using NTFS fi le system is not supported. (Only

FAT(16/32) fi le system is supported.)

 This unit is not supported when the total number of fi les is 1 000 or more.

 External HDD, Card readers, Locked devices, or hard type usb devices are not supported.

 USB port of the unit cannot be connected to PC.

The unit can not be used as a storage device.

To the digital optical output jack of your Digital device

Home theatre speaker ez setup

Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press OPTICAL, then power is on and automatically changed to AUX OPT mode.

1. Connect the unit’s OPTICAL IN jack to jack on optical out of your TV (or Digital Device etc.).

2. Select the AUX OPT by using the OPTICAL.

To select the AUX OPT directly.

3. Listen sound with 5.1(2.1 or 2)ch speaker.

4. To escape from AUX OPT by using the OPTICAL.

Function is retuned to previous one.

2

2

18 Connecting

Antenna Connection

Connect the supplied FM and DAB antenna for listening to the radio.

Connect the FM Wire antenna to the FM antenna connector (F).

Connect the DAB antenna to the DAB antenna connector (D).

Playing the iPod

You can enjoy the sound with your iPod. For details about iPod, refer to the iPod User Guide.

1. Connect the iPod fi rmly.

(F)

(D)

,

Note

 Be sure to fully extend the FM wire antenna.

After connecting the FM wire antenna, keep it as horizontal as possible.

 When the broadcasting signal is weak:

- Check the condition of broadcasting reception. (check the QUALITY)

 When moving the unit to other areas.

- it could delete all of the saved DAB scan station.

If you turn this unit on, your iPod is automatically turned on and recharging starts.

on the remote control to select iPod function.

You can operate your iPod through an iPod’s display by using the supplied remote control and also control on your iPod.

To

ON UNIT

Do this

ON REMOTE

d/M d/M

Pauses or restart

Skip

Search

C/V C/V

Press and hold

C/V

Press and hold c/v

Move to the previous menu

Move to the desired item

-

A

W/S

Chooses a item

D

Compatible iPod

 We recommend installing the latest software version.

 The unit supports the models as follows/ iPod nano 1 G, 2 G, 3 G, 4 G, 5 G, 6 G/ iPod classic/ iPod 4 G, 5 G/ iPod touch 2 G, 3 G, 4 G/ iPhone 3 G, 4. For some models, the unit may not operate depending on the fi rmware version.

Connecting 19

,

Note

 If this unit displays an error message, follow the message. An error message “ERROR”.

- Your iPod is not connected fi rmly.

- This unit recognizes your iPod as an

unknown device.

- Your iPod is exceptionally low in power.

/ The battery needs to be charged.

/ If you charge the battery while iPod is extremely low in power, it may take longer to be charged.

 iPod does not support recording function when connected.

 Depending on your iPod’s software version, it may not be possible to control your iPod from this unit. We recommend installing the latest software version.

 If you use an application, make a call, or send and receive SMS text message, etc. on iPod touch or iPhone, disconnect it from iPod dock of this unit and then use it.

 If you have a problem with your iPod, please visit www.apple.com/support/ipod.

2

20 System Setting

3

Adjust the setup settings

By using the Setup menu, you can make various adjustments to items such as picture and sound.

You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 20 to 23.

OSD Initial language settings

- Optional

During the fi rst use of this unit, the initial language setup menu appears on your TV screen. You must complete initial language selection before using the unit. English will be selected as the initial language.

language setup menu will appear on the screen.

b ENTER.

The confi rm menu will appear.

To display and exit the Setup menu

Displays the [Home Menu].

2. Select an [Setup] by using A D.

Displays the [Setup].

[Setup] Menu.

About help menu for Setup

Menu

ws

Move

a

Move

d

Move

Buttons Operation

WS

A

D

Moving to another menu.

Moving to previous level.

Moving to next level or selecting menu.

x

Close

b

Select

x RETURN b ENTER

To exit the [Setup] menu.

To confi rm menu.

ENTER to fi nish the language setup.

System Setting 21

Language

Menu Language

Select a language for the Setup menu and then on screen display.

Disc Audio / Disc Subtitle / Disc

Menu

Select the language you prefer for the audio track

(disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the disc was recorded.

[Other]

To select another language, press numeric buttons and then b ENTER to enter the corresponding 4-digit number according to the language code list on the page 35. If you enter the wrong language code, press CLEAR.

[Off (for Disc Subtitle)]

Turn off Subtitle.

Display

TV Aspect

Select which screen aspect to use based on the shape of your TV screen.

[4:3]

Select when a standard 4:3 TV is connected.

[16:9]

Select when a 16:9 wide TV is connected.

Display Mode

The Display Mode setting works only when the TV

Aspect mode is set to 4:3.

[Letterbox]

Displays a wide picture with bands on the upper and lower portions of the screen.

[Panscan]

Automatically displays the wide picture on the entire screen and cuts off the portions that do not fi t. (If the disc/fi le is not compatible with

Pan Scan, the picture is displayed at Letterbox ratio.)

Resolution

Sets the output resolution of the Component and

HDMI video signal. Refer to “Resolution Setting” for details about the resolution (page 16).

[Auto]

If the HDMI OUT jack is connected to

TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV. If the COMPONENT

VIDEO OUT is only connected, this changes the resolution to 480i (or 576i) as default resolution.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[480p (or 576p)]

Outputs 480 (or 576) lines of progressive video.

[480i (or 576i)]

Outputs 480 (or (576) lines of interlaced video.

3

22 System Setting

3

Audio

DRC (Dynamic Range Control)

Make the sound clear when the volume is turned down (Dolby Digital only). Set to [On] for this eff ect.

Vocal

Select [On] to mix karaoke channels into normal stereo.

This function is eff ective for multi-channel karaoke

DVDs only.

HD AV Sync

Sometimes Digital TV encounters a delay between picture and sound. If this happens you can compensate by setting a delay on the sound so that it eff ectively ‘waits’ for the picture to arrive: this is called HD AV Sync. Use WS (on the remote control) to scroll up and down through the delay amount, which you can set at anything between 0 and 300m sec.

Lock (Parental Control)

Initial Setting the Area Code:

When you use this unit for the fi rst time, you have to set the Area Code.

1. Select the [Lock] menu and then press D.

To access the [Lock] options, you must input the password you have created. Input a password and press b ENTER. Enter it again and press b

ENTER to verify. If you make a mistake before pressing b ENTER, press CLEAR.

3. Select the fi rst character using W S buttons.

using W S buttons.

selection.

Rating

Blocks playback of rated DVDs based on their contents. Not all discs are rated.

1. Select [Rating] on the [Lock] menu then press

D.

2. Input a password and press b ENTER.

3. Select a rating from 1 to 8 using the WS buttons.

[Rating 1-8]

Rating one (1) has the most restrictions and rating eight (8) is the least restrictive.

[Unlock]

If you select unlock, parental control is not active and the disc plays in full.

System Setting 23

Password

You can enter or change password.

1. Select [Password] on the [Lock] menu and then press D.

3. Input a password and press b ENTER.

To change the password, press b ENTER when the [Change] option is highlighted. Input a password and press b ENTER. Enter it again and press b ENTER to verify.

,

Note

If you forget your password, you can clear it using the following steps:

1. Select the [Setup] menu on the [Home

Menu].

2. Input the 6-digit number “210499” and press b ENTER. The password is cleared.

Others

DivX VOD

We provide you with the DivX® VOD (Video On

Demand) registration code that allows you to rent and purchase videos using the DivX® VOD service.

For more information, visit www.divx.com/vod.

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the deactivation code.

,

Note

All the downloaded videos from DivX VOD can only be played back on this unit.

3

Area Code

Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 34.

1. Select [Area Code] on the [Lock] menu then press D.

2. Input a password and press b ENTER.

3. Select the fi rst character using W S buttons.

using W S buttons.

selection.

24 Operating

Using the Home Menu

To Do this

4

Displays the [Home Menu].

2. Select an option by using AD.

[Music] – Displays [MUSIC] menu.

[Movie] – Start video media’s playback or displays the [MOVIE] menu.

[Photo] – Displays [PHOTO] menu.

[Setup] – Displays the [Setup] menu.

,

Note

You can not select the [Music], [Movie] or

[Photo] option when the USB device is not connected or a disc is not inserted.

Basic Operations

1. Insert the disc by using the B OPEN/CLOSE or

Connect the USB device to the USB port.

Displays the [Home Menu].

3. Select an option by using AD.

If you select the [Movie], [Photo] or [Music] option when you connect up to two devices, it appears as below. Select a media then press b

ENTER.

,

Note

 For the most Audio CD and DVD-ROM discs, playback starts automatically.

 The unit plays only music fi le contained in the USB storage device or disc automatically.

Playback

Press

d PLAY, MONO/

STEREO.

Pause

Frame-by-

Frame playback

Press M PAUSE/STEP.

Press M PAUSE/STEP repeatedly to play title Frameby-Frame. (DVD, DivX only)

Skipping to the next/ previous chapter/ track/ fi le

During playback, press

C/

V SKIP to go to the next chapter/ track/ fi le or to return to the beginning of the current chapter/ track/ fi le.

Press C SKIP twice briefl y to step back to the previous chapter/ track/ fi le.

Locating a point quickly by playing a fi le in fast forward or fast reverse

During playback, press c/ v SCAN repeatedly to select the required scan speed.

To return to normal speed, press d PLAY, MONO/

STEREO.

Playing repeatedly or randomly

Press REPEAT repeatedly, and the current title, chapter or track will be played back repeatedly or randomly.

- DVD : Chapter/ Title/ Off

- DivX : Title/ All/ Off

- Audio CD/ MP3/ WMA : Track/

All/ Random/ Off

Slowing down the playing speed

In the pause mode, press

SLOW (c or v) to select the required speed. (DVD, DivX only) The DivX fi le cannot be slow down reverse playback.

Operating 25

Other Operations

Displaying Disc Information on-screen

You can display various information about the disc loaded on-screen.

playback information.

The displayed items diff er depending on the disc type or playing status.

2. You can select an item by pressing WS and change or select the setting by pressing AD.

Title – Current title number/ total number of titles.

Chapter – Current chapter number/ total number of chapters.

Time – Elapsed playing time.

Audio – Selected audio language or channel.

Subtitle – Selected subtitle.

Angle – Selected angle/ total number of angles.

,

Note

If any button is not pressed for a few seconds, the on-screen display disappears.

To display the DVD title

y

When you play a DVD which contains several title, you can select the title you want using the Menu.

The disc’s title appears.

2. Select the menu by pressing WSAD.

1.5 times speed playback

y

The 1.5 speed allows you to watch the pictures and listen to the sound quicker than playing at a normal speed.

1. During playback, press d PLAY, MONO/

STEREO to play at 1.5 times speed. “dX1.5” appears on the screen.

To display the DVD Menu

y

When you play a DVD which contains several menu, you can select the menu you want using the Menu.

The disc’s menu appears.

2. Select the menu by using WSAD.

Screen Saver

The screen saver appears when you leave the unit in Stop mode for about fi ve minutes.

Starting play from selected time

y

To start playing at any chosen time on the fi le or title.

“--:--:--” appears.

3. Input the required start time in hours, minutes, and seconds from left to right. If you enter the wrong numbers, press CLEAR to remove the numbers you entered. Then input the correct numbers.

For example, to fi nd a scene at 1 hour, 10 minutes, and 20 seconds, enter “11020” by using numerical buttons.

the selected time.

4

26 Operating

Resume playback

yut

The unit records the point where you pressed the

Z STOP depending on the disc.

If “MZ (Resume Stop)” appears on the screen briefl y, press d PLAY, MONO/STEREO to resume playback

(from the scene point).

If you press Z STOP twice or unload the disc,

“Z”(Complete Stop) appears on the screen. The unit will clear the stopped point.

,

Note

The resume point may be cleared when a button is pressed (for example; 1 (POWER),

B OPEN/CLOSE, etc).

Marked Playback

ut

The mark function enables you to store your favourite fi les from any disc or USB device in the unit memory.

1. Select [Music] on the [Home Menu].

Returning to the upper folder.

(MP3/ WMA only)

File information will be displayed according to the ID3TAG information on the appropriate music fi le. (MP3 only)

4

Changing subtitle code page

y

If the subtitle is not displayed properly, you can change the subtitle code page to view the subtitle fi le properly.

1. During playback, press m INFO/DISPLAY to display the On-Screen display.

Selecting all tracks/ fi les.

Deselecting all tracks/fi les.

Moving to the previous or next fi le list.

2. Select a desired music on the [List] by using the

WS then press MARKER to appears the mark on the list.

b ENTER or d PLAY, MONO/STEREO.

Displays the play mode.

4. Select the play mode by using the WS and press b ENTER.

[Mark Play]

Marked playback.

[Current Play]

Normal playback.

,

Note

If you want to select all fi les on the list, select

[Select All] and press b ENTER.

Operating 27

To delete a Marker

WS to select the track that you wish to erase from the marked fi le.

To delete all Markers

Use WSAD to select [Deselect All] then press b

ENTER in program edit mode.

,

Note

The markers are also cleared when the disc or

USB device is removed, the unit is switched to power off or the function is switched to others.

Viewing a PHOTO fi le

i

This unit can play discs with photo fi les.

1. Select [Photo] on the [Home Menu] and press b ENTER.

Moving to the previous or next fi le list.

About help menu in the [Photo] menu

Menu Buttons Operation

d Slide

Show

d

PLAY, MONO/

STEREO

Viewing a slide show.

wsad

Move

b

Select

SWAD b ENTER

Moving to another fi le or content.

Viewing a particular fi le.

x

Close

Returning to the

[Home Menu].

About help menu in the full screen

Menu Buttons Operation

Menu

x RETURN m

INFO/

DISPLAY

Displaying the Option menu.

a/d

Prev./ Next

x

Close

A/D Moving to another fi le.

x

RETURN

Returning to the

[Photo] menu.

4

Returning to the upper folder.

ENTER.

3. If you want to view a slide show, press W S to highlight a fi le and press d PLAY, MONO/

STEREO.

28 Operating

Options while viewing a photo

You can use various options during viewing a photo in full screen.

1. While viewing a photo in full screen, press m INFO/DISPLAY to display the option menu.

2. Select an option using SWAD.

System Select - Optional

You must select the appropriate system mode for your TV system. Press and hold M PAUSE/STEP for more than fi ve seconds to be able to select a system in the [Home Menu].

,

Note

If the USB device is connected or a disc is inserted, this function is not operated.

4

a a Current photo/ Total number of photos

Use AD to view previous/next photo.

b Slide Show z/M– Press

ENTER to start or pause slide show.

c Speed x3/ x2/ x1 – Use

ENTER to select a delaying speed between photos in a slide show.

d Rotate – Press

ENTER to rotate the photo.

e Go to list – Press

ENTER to return [Photo] menu.

Last Scene Memory

y

This unit memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled.

Adjust the speaker level settings

You can adjust the sound level of each speaker.

desired speaker to set. selected speaker while the level setting menu is displayed on the display window.

3. Repeat and adjust the sound level of the other speakers.

Operating 29

Setting the Clock

1. Turn the unit on.

3. Choose time mode by pressing C/V.

- AM 12:00 (for an AM and PM display) or 0:00

(for a 24 hour display)

5. Select the hours by pressing C/V.

7. Select the minutes by pressing C/V.

Sleep Timer Setting

Press SLEEP repeatedly to select delay time between 10 and 180 minutes. After the delay time, unit will turn off .

To cancel the sleep function, press SLEEP repeatedly until “SLEEP 10” appears, and then press

SLEEP once again while “SLEEP 10” is displayed.

,

Note

 You can check the remaining time before the unit turns off .

 Press SLEEP. The remaining time appears in the display window.

 Sleep function will working after Dimmer.

Using your player as an alarm clock

1. Turn the unit on.

woken by is showing.

4. “ON TIME” will be displayed. This is your desired time to unit turns on. Press C/V to change the hours and minutes and press SET to save.

5. The “OFF TIME” will be displayed. This is your desired time to unit turns off .

minutes and press SET to save.

press SET to save. The clock icon “(“ shows that the alarm is set.

setting status.

,

Note

 If you set the clock time, you can check the time by pressing CLOCK even when the player is turned off .

 If you set the clock time and alarm, you can check the alarm icon “(“ by pressing

CLOCK even when the player is turned off .

 If you set the clock time and alarm, you can check the alarm icon “(“ and setting information by pressing TIMER even when the unit is turned off . Then this function will working in everyday.

Dimmer

Press SLEEP once. The display window will be darkening by half. To cancel it, press SLEEP repeatedly until dim off . If touch the buttons in

Sleep Timer mode, the buttons will be lightening for 5 seconds and darkening again.

Turn off the sound temporarily

Press MUTE to mute your unit.

You can mute your unit, for example, to answer the telephone, the “q” is displayed in the display window.

DEMO

In the power off state, it demonstrates the function on display window by pressing DEMO. To cancel the DEMO, press it again.

,

Note

While DEMO, this unit will keep DEMO status even if you unplug the power cord connection.

 You can enjoy other functions during the DEMO. Then the DEMO will pause to temporary.

- Without input key in 10 sec, the DEMO will play back automatically.

4

4

30 Operating

Radio Operations

Be sure that FM and DAB aerial is connected. (Refer to the page 18.)

Listening to the radio

appears in the display window.

The last received station is tuned in.

2. [FM]

Press and hold TUNING (-/+) for about two seconds until the frequency indication starts to change, then release. Scanning stops when the unit tunes in a station.

Or

[DAB]

Press TUNING (-/+) and press d PLAY.

3. Adjust the volume by rotating -/+ on the front panel or by pressing VOL (+/-)on the remote control repeatedly. In DAB function, press d

PLAY, MONO/STEREO to start.

Presetting the Radio Stations

You can preset 50 stations for FM or DAB.

Before tuning, make sure that you have turned down the volume.

appears in the display window.

2. [FM]

Select the desired frequency by using

TUNING (-/+).

[DAB]

Press TUNING (-/+) and press d PLAY.

the display window.

you want.

The station is stored.

6. Repeat the steps 2 to 5 to store other stations.

Deleting all the saved stations

1. Press and hold CLEAR for two seconds.

“ERASE ALL” will fl ash up on the unit display.

2. Press CLEAR to erase all saved of the radio stations.

Deleting a saved station

you want to delete.

display window.

preset number.

Improving poor FM reception

Press d PLAY, MONO/STEREO on the remote control. This will change the tuner from stereo to mono and usually improve the reception.

Listening to the DAB

You can change the display information of the currently broadcasting DABchannel. Press

DAB INFO. on the remote control repeatedly, the display changes in the following order,

SERVICE -> PTY NAME -> FREQ -> DLS -> QUALITY

-> ENSEMBLE

Select a display mode and then press C/V, the initials of the servicename are displayed.

SERVICE

Displays the Name of the channel for the current broadcast.

PTY NAME

Displays the Type of the channel for the current broadcast.

FREQ Displays the frequency of the channel for the current broadcast.

channel which is selected.

broadcast signal in Bar form.

for the current broadcast.

Aligning the service names

Press SORT/SCAN on the remote control to display the sorting mode of DAB broadcastings. Then, press the button once again to change the mode.

Default sort: The service names are aligned in a scanning order.

Name sort: The service names are aligned in an alphabetical order.

Operating 31

DAB scan

Press SORT/SCAN on the remote control for longer than 3 seconds, all ofthe DAB bands are scanned.

Then press it again, scanning will be cancelled.

Deleting all of the saved DAB scan stations

Press and hold DAB INFO. on the remote control for 3 seconds. “DAB INIT” will be displayed. Press

DAB INFO. to erase all the saved stations.

Sound adjustment

Setting the surround mode

This system has a number of pre-set surround sound fi elds. You can select a desired sound mode by using SOUND EFFECT.

You can change the SOUND EFFECT using A D arrow key while the sound eff ect information is displayed on.

The displayed items for the equalizer maybe diff erent depending on sound sources and eff ects.

On Display

NAT PLUS

NATURAL

Local specialization equalizer

AUTO EQ

Description

The NAT PLUS is Natural Plus sound eff ect. You can enjoy the natural sound eff ect same as a 5.1-channel.

You can enjoy comfortable and natural sound.

Regionally optimized sound eff ect. (FORRO/ FUNK/

SERTANEJO/ DANGDUT/

ARABIC/ PERSIAN/ INDIA/

REGUETON/ MERENGUE/

SAMBA/ SALSA/ CUMBIA/

AFRO)

Realizes the sound equalizer that is the most similar to the genre of which is included in the MP3 ID3 tag of song fi les.

On Display

POP

CLASSIC

JAZZ

ROCK

MP3 -- OPT

BASS BLAST

LOUDNESS

VIRTUAL

BYPASS

Description

This program lends an enthusiastic atmosphere to the sound, giving you the feeling you are at an actual rock pop, jazz or classic concert.

This function is optimized for compressible MP3, WMA fi le. It improves the treble sound.

During playback, reinforce the treble, bass and surround sound eff ect.

Improves the bass and treble sound.

You can enjoy more virtual surround sound.

You can enjoy the sound without equalizer eff ect.

,

Note

 In some of surround modes, some speakers, there’s no sound or low sound. It depends on the mode of surround and the source of audio, it is not defective.

 You may need to reset the surround mode, after switching the input, sometimes even after the sound track changed.

4

32 Operating

Advanced Operations

4

Recording to USB

You can record music or sound source to USB device by connecting in to the port on the unit.

1. Connect the USB device to the unit.

2. Select a mode in which you want to record.

Play back a sound source fi rst.

3. Start the recording by pressing X REC.

4. To stop recording, press Z STOP.

[All tracks/ fi les recording]

Record to USB in stop or play mode.

[Program list recording]

After marking desired fi le(s) and you can record it to USB (Refer to the page 26).

It’ll be stored as follows.

Audio CD

MP3/ WMA

The other sources (Tuner,

Portable)

* DAB is not available

,

Note

 You can check the recording percentage rate for the USB record on the screen during the recording. (Audio CD or MP3/ WMA CD only)

 During recording MP3/WMA, there is no sound.

 When you stop recording during playback, the fi le that has been recorded at that time will be stored. (Audio CD only)

 Do not remove the USB device or turn off the unit during USB recording. If not, an incomplete fi le may be made and not deleted on PC.

 Recording through microphones is not avaiable.

 If USB recording does not work, the message like “NO USB”, “ERROR”, “USB FULL” or “NO REC” is displayed on the display window.

 Multi card reader device or external HDD can not be used for USB recording.

 A fi le is recorded by 128 Mbyte (about 2 hours) when you record for a long term.

There are recorded less than 4 fi les.

 When you stop recording during playback, the fi le will not be stored.

 In the state CD-G, DTS disc USB record is not operated.

 The fi les in the sub-folders are not recorded during all track recording.

 You may not record more than 999 fi les.

 The numbering of the recording fi le is entered from the lowest number. So if you delete some of the recording fi les, the next recording fi le could be the lowest number among them.

The making of unauthorized copies of copyprotected material, including computer programs, fi les, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal off ense. This equipment should not be used for such purposes.

Be responsible

Respect copyrights.

Troubleshooting 33

Troubleshooting

PROBLEM

No power

No picture

There is little or no sound

CORRECTION

Plug the power cord into the wall outlet securely.

Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen.

Connect the video cables securely to both the TV and unit.

Select the correct input mode of the unit so you can hear the sound from the unit.

Connect the audio cables into the connection terminals correctly.

Replace with a new audio cable.

The DVD picture quality is poor

Clean the disc using a soft cloth with outward strokes.

A DVD/CD will not play

The remote control doesn’t work well / at all iPod does not work .

Insert a disc.

Insert a playable disc (check the disc type, colour system and regional code).

Place the disc on the disc slot correctly.

Enter your password or change the rating level.

Humming noise heard while a DVD or CD is playing

Clean the disc using a soft cloth with outward strokes.

Move unit and audio components further away from your TV.

Check the antenna connection and adjust its position.

Radio stations can’t be tuned in properly

Attach an external aerial if necessary.

Tune to the station manually.

Preset some radio stations, see page 30 for details.

The remote is not pointed directly at the unit.

Point the remote directly at the unit.

The remote is too far from the unit.

Use the remote within 23 feet (7m) of the unit.

There is an obstacle in the path between the remote control and the unit.

Remove the obstacle.

The battery in the remote control are fl at.

Replace the battery with new ones.

Check whether the player is connected to the unit correctly.

Connect it to the unit correctly.

5

34 Appendix

6

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF Fiji FJ Monaco MC Singapore SG

Argentina

Australia

Austria

AR

AU

AT

Finland

France

Germany

FI

FR

DE

Mongolia

Morocco

Nepal

MN

MA

NP

Slovak Republic

Slovenia

South Africa

SK

SI

ZA

Belgium

Bhutan

Bolivia

Brazil

Cambodia

Canada

BE

BT

BO

BR

KH

CA

Great Britain

Greece

Greenland

Hong Kong

Hungary

India

GB

GR

GL

HK

HU

IN

Netherlands

Antilles

New Zealand

Nigeria

Norway

Oman

NL

AN

NZ

NG

NO

OM

South Korea

Spain

Sri Lanka

Sweden

Switzerland

Taiwan

SE

CH

TW

KR

ES

LK

Chile

China

Colombia

Congo

Costa Rica

Croatia

Czech Republic

Denmark

Ecuador

Egypt

El Salvador

Ethiopia

CL

CN

CO

CG

CR

HR

CZ

DK

EC

EG

SV

ET

Indonesia

Israel

Italy

Jamaica

Japan

Kenya

Kuwait

Libya

Luxembourg

Malaysia

Maldives

Mexico

ID

IL

IT

JM

JP

KE

KW

LY

LU

MY

MV

MX

Pakistan

Panama

Paraguay

Philippines

Poland

Portugal

Romania

Russian

Federation

Saudi Arabia

Senegal

PH

PL

PT

RO

PK

PA

PY

RU

SA

SN

Thailand

Turkey

Uganda

Ukraine

United States

Uruguay

Uzbekistan

Vietnam

Zimbabwe

TH

TR

UG

UA

US

UY

UZ

VN

ZW

Appendix 35

Language code List

Use this list to input your desired language for the following initial settings: [Disc Audio],

[Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368

Afrikaans

Albanian

Ameharic

Arabic

6570

8381

6577

6582

Frisian

Galician

Georgian

German

7089

7176

7565

6869

Macedonian

Malagasy

Malay

Malayalam

7775

7771

7783

7776

Singhalese

Slovak

Slovenian

Spanish

8373

8375

8376

6983

Armenian

Assamese

Aymara

Azerbaijani

Bashkir

Basque

7289

6583

6588

6590

6665

6985

Greek

Greenlandic

Guarani

Gujarati

Hausa

Hebrew

6976

7576

7178

7185

7265

7387

Maori

Marathi

Moldavian

Mongolian

Nepali

7773

7782

7779

7778

Nauru 7865

7869

Sudanese

Swahili

Swedish

Tagalog

Language

Tajik

8385

8387

8386

8476

Code

8471

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton

Bulgarian

Burmese

6682

6671

7789

Byelorussian

Chinese

Croatian

Czech

Danish

Dutch

6669

9072

7282

6783

6865

7876

English

Esperanto

Estonian

Faroese

Fiji

6978

6979

6984

7079

7074

Hindi

Hungarian

Icelandic

Indonesian

Interlingua

Irish

Italian

Japanese

Kannada

Kashmiri

Kazakh

Kirghiz

Korean

Kurdish

7273

7285

7383

7378

7365

7165

7384

7465

7578

7583

7575

7589

7579

7585

Laothian

Latin

7679

7665

Latvian, Lettish 7686

Lingala 7678

Norwegian

Oriya

Panjabi

7879

7982

8065

Pashto, Pushto 8083

Persian 7065

Polish

Portuguese

Quechua

8076

8084

8185

Rhaeto-Romance 8277

Rumanian 8279

Russian

Samoan

Sanskrit

Scots Gaelic

Serbian 8382

Serbo-Croatian 8372

Shona

8285

8377

8365

7168

8378

Tamil

Telugu

Thai

Tonga

Turkish

Turkmen

Twi

Ukrainian

Urdu

Uzbek

Vietnamese

Volapük

Welsh

Wolof

Xhosa

Yiddish

Yoruba

Zulu

8487

8575

8582

8590

8673

8679

6789

8779

8465

8469

8472

8479

8482

8475

8872

7473

8979

9085

Finnish 7073

6

36 Appendix

Trademarks and

Licenses

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc. “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifi cally to iPod or iPhone respectively, and has been certifi ed by the developer to meet Apple performance standards.

Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

Please note that the use of this accessory with iPod, iPhone may aff ect wireless performance.

DivX®, DivX Certifi ed® and associated logos are trademarks of DivX, Inc. and are used under license.

ABOUT DIVX VIDEO: DivX® is a digital video

DivX Certifi ed® device that plays DivX video.

Visit www.divx.com for more information and software tools to convert your fi les into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX

Certifi ed® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu.

Go to vod.divx.com for more information on how to complete your registration.

6

HDMI, the HDMI logo and High-Defi nition

Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC.

“DVD Logo” is a trademark of DVD Format/Logo

Licensing Corporation.

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

What is SIMPLINK?

Some functions of this unit are controlled by

TV’s remote control when this unit and LG TV with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop,

Power Off , etc.

 Refer to the TV owner’s manual for the details of SIMPLINK function.

 LG TV with SIMPLINK function has the logo as shown above.

 Use a higher version cable than High Speed

HDMI™ cable.

Specifi cations

General

Power requirements

Power consumption

Dimensions (W x H x D)

Net Weight (Approx.)

Operating temperature

Operating humidity

200 - 240 V ~ 50/ 60 Hz

55 W

135 X 295 X 315 mm without foot

3.45 kg

41 °F to 95 °F (5 °C to 35 °C)

5 % to 90 %

Inputs/ Outputs

VIDEO OUT

COMPONENT VIDEO OUT

HDMI OUT (video/audio):

DIGITAL IN (OPTICAL):

PORT. IN

System

Laser

Signal system

Frequency response

Signal-to-noise ratio

Harmonic distortion

Dynamic range

Bus Power Supply

1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

(Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

19 pin Type A, HDMI™ Connector

3 V (p-p), Optical jack x 1

0.5Vrms (3.5 mm stereo jack)

Semiconductor laser, wavelength: 650 nm

Standard NTSC/ PAL colour TV system

20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)

More than 80 dB

0.05 % at 1 W

More than 85 dB

USB DC 5 V 0 500 mA iPod DC 5 V 0 1 A

Amplifi er

Stereo mode

Tuner

FM Tuning Range

80 W + 80 W (4Ω at 1kHz)

87.5 to 108.0 MHz or 87.50 to 108.00 MHz

Appendix 37

6

6

38 Appendix

Front Speaker

Type

Impedance Rated

Input Power

Max. Input Power

Net Dimensions (W x H x D)

Net Weight

3 Way 4 speaker

4 Ω

80 W

160 W

126 X 295 X 315 mm

4.35 kg

Design and specifi cations are subject to change without notice.

Appendix 39

Maintenance

Handling the Unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

 Do not use volatile liquids such as insecticide spray near the unit.

 Wiping with strong pressure may damage the surface.

 Do not leave rubber or plastic products in contact with the unit for a long period of time.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished.

For details, please contact your nearest authorized service centre.

Notes on Discs

Handling Discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fi ngerprints do not get on the surface. Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the centre to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

6

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
