PRODUCT
GUIDE
It’s easy with an Earlex
Designed as an entry-level
paint spraying system
How does a SprayStation work?
The Earlex SprayStation® uses High Volume Low Pressure (HVLP) technology.
Used by professionals for decades, this technology makes it easy to set up,
easy to spray and easy to clean up. A much better quality finish can be
achieved by spraying than with a brush or roller and it’s faster too!
Benefits of a SprayStation®
How it works
Speed - Faster than a brush or roller.
HV1900
Less wastage - Less paint wastage
than with a brush or roller.
High quality finish - No brush or roller
marks and it’s quick and easy to
create a professional looking finish.
Greater versatility - Can be used
outdoors and indoors with a wide
variety of paints.
Detail - Great for all painting tasks nothing too big or small, from interior
walls and ceilings to fences, sheds
and decking as well as staircase
spindles, radiators etc.
Easy and quick to clean - Clean up is
faster than a paintbrush, roller or
airless gun.
The HV1900 SprayStation® is ideal for
the first time or occasional sprayer on a
limited budget.
This lightweight, versatile sprayer works
effectively on small to medium sized
projects inside and outside the home
with many thin to medium bodied
materials such as deck stains or
sealants. The HV1900 SprayStation® has
low overspray and can be quickly and
effortlessly cleaned up.
Technical specifications:
• Project spray gun
• 2.0mm brass needle
• 400 Watt
• 2.7m hose
• 50 DIN/sec thickness
Materials that can be sprayed with
the HV1900 SprayStation®
Low overspray ensures higher paint
transfer efficiency and means less
masking is required.
What paint you can spray?
All gloss, undercoat, primer,
emulsion, wood and fence
treatments, lacquers and
*smooth masonry paint (*not with Spraypack)
Ideal for thin to medium viscosity materials
such as:
• Thinned emulsions/latex paints
• Deck stains
• Stains and wood treatments
• Varnishes
• Lacquers/water sealants
Perfect homeowner/DIY for
medium to large projects
The HV3500 SprayStation® is a
multi-purpose sprayer that works
effectively with a variety of materials
for a large range of projects both inside
and outside the home.
With the new expert gun you’ll remain
in constant control, get a great finish,
make your materials go even further.
The clean up is faster than a brush or
roller with the HV3500 SprayStation®.
Technical specifications:
• Expert spray gun
• 2.0mm brass needle
• 500 Watt
• 2.7m hose
• On board storage for hose and spray gun
• 160 DIN/sec thickness
Materials that can be sprayed with the
HV3500 SprayStation®
The HV3900 SprayStation® is a
revolutionary high performance spray
system supplied with a 4L Spraypack
ideal for spraying large wood
treatments without refilling (80 square
metre coverage in 1 hour 20 mins from
just one fill).
HV3900
HV3500
The ideal homeowner system
for multiple tasks
Ideal for thin to medium viscosity materials
such as:
• Thinned emulsions/latex paints
• Thinned masonry paints
• Gloss
• Enamels
• Varnishes
• Stains and fence treatments
• Lacquers/water sealants
DIY
DIY
Technical specifications:
• Expert spray gun
• 2.0mm brass needle
• 4 Litre Spraypack ideal for
continuous painting
• 550 Watt
• 4m hose for freedom when painting
• On board storage for hose and
spray gun
• 180 DIN/sec thickness
Materials that can be sprayed with the
HV3900 SprayStation®
Ideal for thin to medium viscosity materials
such as:
• Thinned emulsions/latex paints
• Thinned masonry paints
• Primers
• Gloss
• Enamels
• Varnishes
• Oils
• Stains and fence treatments
• Lacquers/water sealants
NEW Product
GEMINI
TWIN TECHNOLOGY
TM
Up to 4 x Faster than standard
HVLP using revolutionary
technology, get large area’s
painted with speed and precision
for a superb professional finish.
GEMINI
TM
Quick Connect fittings
The worlds first
spray painting system
• Fast • Fine • Precise • Controlled • Easy • Efficient
How does it work?
The SprayStation Gemini has an
innovative design combining a hybrid
spray system and a new patented
nozzle assembly allowing for fine and fast
painting direct from the can, perfect for
all jobs inside and out.
Benefits
Hose storage
•
•
•
•
•
Fast high quality results for large area’s
Providing a fine finish for intricate jobs
Maximum control and minimal overspray
Easy to set up and easy to use
User friendly with auto cleaning
functionality
• Time efficient - no need to thin most latex
coatings
Auto Clean Functionality
Features
Semi-Pro
*BS standard no. - BS1262
*Fine & fast application
*
• Auto-clean functionality • Direct feed from paint tin with 5L capacity* • 600W 2 stage motor
• 4m Hose • Onboard storage & 10L capacity • Variable flow adjuster
Materials that can be sprayed with the Gemini SprayStation®
Fast: Water based paints • Emulsions • Latex • Fence treatments • Thinned masonry paints • Soft sheen • Gloss • Primers • Undercoats
Fine: Solvent based materials • Varnishes • Oils • Stains •Automotive paints • Heat resistant paints
Designed as a professional-level
paint spraying system
The HV5500 SprayStation® is ideal for
use in the workshop, around the home
or on the job site.
The professional gun and powerful
turbine make the HV5500 SprayStation®
a perfect tool to achieve that
showroom finish on cabinets, furniture
and even cars.
The professional HV6900 & HV7000
SprayStations® are industrially rated,
portable, paint spraying systems
designed specifically for spraying large
and intricate jobs.
Technical specifications:
• Professional spray gun
• Teflon® coated paint container with quick
release lever
• 2.0mm stainless steel needle
• 600 Watt
• 4m hose for freedom when painting
• Carry handle for easy portability
• On board storage for hose and spray gun
• 160 DIN/sec thickness
Materials that can be sprayed with the
HV5500 SprayStation®
• Thinned emulsions/latex paints
• Thinned masonry paints
• Primers
• Gloss
• Enamels
• Varnishes
• Oils
• Stains and fence treatments
• Lacquers/water sealants
Semi-Pro
HV6900/7000
HV5500
The ideal semi-pro system
for multiple tasks
HV6900/ 7000 Technical specifications:
• Professional spray gun
• Teflon® coated paint container with quick
release lever
• 2.0mm stainless steel needle
• 1100 Watt
• 4.5m hose for freedom when painting
• Carry handle for easy portability
• 250 DIN/sec thickness
HV7000 Technical specifications:
• 9m hose for freedom when painting or
when up ladders
• The main turbine unit and carrier stand
are easily separated to allow for easy
storage and portability
Materials that can be sprayed with the
HV6900/ 7000 SprayStation®
• Thinned emulsions/latex paints
• Thinned masonry paints
• Primers
• Gloss
• Enamels
• Varnishes
• Oils
• Stains and fence treatments
• Lacquers/water sealants
Professional
Spray guns - perfect for different
coatings or if you have different
colours on one job.
For a multitude of indoor, outdoor
and detailed projects
Interior walls/
ceilings
Exterior
woodwork
Staircase
spindles
Radiator
Garage
door
Garden
fence/
trellis
HV1900
HV3500
HV5000
HV6900
HVACC3R
HVA0007
n/a
n/a
Use the 1.0mm tip/needle for an
extra fine finish with thin materials.
HVACC10R
HVACV1
HV5ACC10R
HV5ACC10R
The 1.5mm tip/needle is ideal for
fine finishes and medium to thick
materials.
HVACC15R
HVACV15
HV5ACC15R
HV5ACC15R
The 2.0mm tip/needle for a quality
finish and medium to thick
materials.
HVACC20R
HVACV2
HV5ACC20R
HV5ACC20R
The 2.5mm/3.0mm tip/ needle is
great with medium to thick viscosity materials for a coarse finish.
HVACC25R
HVACV3
HV5ACC25R
HV5ACC25R
Garden
gate
1litre paint containers - good to
store unused or pre-mixed paints
as well as different colours of paint.
Needle & tip options
ACCESSORIES
Kitchen
Cabinets
Other accessories
4 litre/ 1 gallon Spraypack (not suitable for HV1900 & HV7000)
The refill HVA0015 container with 4 litre/ 1 gallon back container is
great for large painting projects such as decks and fences.
Plant
protection
Garden
furniture
Decking
Interior
woodwork
Furniture
Stencils
Versatility
Exterior
walls
Interior/
exterior
doors
Window
shutters
Floor
paint
Iron
work
Arts and
crafts
The spray gun cleaning kit SGCK1 (use with all models) assures
preventative maintenance for a long life and perfect
performance every time.
DIY
WALLPAPER STRIPPER
Ideal for first time DIYers
Ideal for DIY enthusiasts
Wallpaper strippers are the fastest and
easiest way to remove all types of wall
coverings the first time, every time.
No chemicals are required, just clean
water. Set up and clean up are so easy
you will be removing wallpaper
coverings in hours not days.
Wallpaper steamers are the fastest and
easiest way to remove all types of
wall coverings the first time, every time.
No chemicals are required, just
water. Remove multi-layered or
painted wallpaper or other difficult
coverings in hours, not days.
Technical specifications/ includes:
• 4 litre tank
• 12 minute steam up time
• 70 minute usage time
• 3.65m ‘cool to touch’ hose
• 2000W element
• Exterior water level indicator
• Translucent steam plate
Technical specifications/ includes:
• 5 litre tank
• 14 minute steam up time
• 78 minute usage time
• 2300W element
• 3.65m ‘cool to touch’ hose
• Small steam plate
• Scraper
• Exterior water level indicator
SS77
SS125
WALLPAPER STRIPPER
Removes:
• Wallpaper
• Multi-layered wallpapers
• Painted wallpaper
• Artex®
• Textured coatings
Removes:
• Wallpaper
• Multi-layered wallpaper
• Painted wallpaper
• Artex®
• Textured coatings
DIY
HANDS-FREE
WALLPAPER STRIPPER
WALLPAPER STRIPPER
The perfect kit for all wallpapering
and steam cleaning solutions
Technical specifications/ includes:
• 5 litre tank
• 16 minute steam up time
• 90 minute usage time
• 2000W element
• 3.65m ‘cool to touch’ hose
• Small steam plate
• Scraper
• PLUS steam cleaning accessories
SS200
SC77
The complete steam cleaning and
wallpaper stripping solution for all
around the home. No chemicals are
required, just clean water. The steam
cleaning kit is ideal for cleaning and
disinfecting all around the home.
Perfect for cleaning carpets, work surfaces and cookers in addition to
defrosting freezers and frozen pipes
and cleaning windows and grouting.
Ideal for the homeowner enthusiast
with true innovation
Removes:
• Wallpaper
• Multi-layered wallpapers
• Painted wallpaper
• Artex®
• Textured coatings
DIY
The world’s first DIY Hands-Free Wallpaper Stripper has a revolutionary
hands-free steam plate which enables
fast and effortless task completion, the
steam plate sticks to the wall – no need
to hold. The system is very easy to use.
No chemicals are required, just clean
water. Set up and clean up are so easy
you will be removing wallpapering
coverings in hours not days.
Technical specifications/ includes:
• 5 litre tank
• 14 minute steam up time
• 78 minute usage
• 2300W element
• 3.65m ‘cool to touch’ hose
• On board storage
• Two on/off switches for steam and
vacuum
Removes:
• Wallpaper
• Multi-layered wallpaper
• Painted wallpaper
• Artex®
• Textured coatings
DIY
WET & DRY VACUUM
WET & DRY VACUUM
Designed for the rough and tumble of
everyday use both indoor and outdoor
Suitable for both indoor and
outdoor use with an efficient dust
extraction solution for around the
workshop/garage
DIY
Technical specifications:
• 1100W motor
• 20 litre capacity – 12 litre wet
• 1.8m hose
• Auto shut-off float
• Foam & paper filters
• 3m mains cable
• 4 castors
• On board storage for accessories
Features & benefits:
• For use around garage, garden,
workshop & home
• Cleans up dust, dirt and spills
• Empties ponds
• Blows away debris & leaves with
powerful blower
• Easy to change from suction to
blower function
• Minimum effort, no messy bags
WD1200
WD1000
This unit is a multi-purpose, highly
versatile Wet ‘n’ Dry vacuum and
blower. It is designed with unbeatable performance. This product can
be used for a multitude of tasks in the
garage, workshop, garden and within
the home.
This unit is a highly versatile Wet ‘n’ Dry
vacuum and blower with on board
socket for electrical sanders, jigsaws,
circular saws and other power tools.
Features include a dust extraction
system with an automatic start up and
delayed shut off when used with a
power tool.
Technical Specs:
• 1200W motor
• Power tool socket
• Power tool adaptor
• 20 litre capacity - 12 litres wet
• 4m hose
• Auto shut off float
• Cartridge filter
• 5m mains cable
• 4 castors & outriggers
• On board storage for accessories
Features & benefits
• Onboard power tool socket with
auto start and run on
• Dust extraction facility & power tool
adaptor
• Cleans up dust, dirt and spills
• Empties ponds
• Easy to change from suction to blower
function
• Carry handle for easy manoeuvrability
DIY
HEAT GUN
HEAT GUN
Ideal for first time DIYers
Ideal for DIY enthusiasts
Suitable product for light work projects
in and around the home.
Ideal for projects in and around the
home with a range of nozzles supplied
for different shapes and surfaces.
• 1500W lightweight heat gun
• 2 heat settings 330˚C – 510˚C
• Includes:
- Concentrator nozzle
- Glass protector nozzle
• 2.25m mains cord
Removes paints and varnishes from a wide
range of surfaces and can be used for:
•
•
•
•
•
Paint stripping
Defrosting pipes
Heating charcoal
Heat shrinking
Bending pipes
Technical specifications:
HG2000
HG1500
Technical specifications:
• 2000W lightweight heat gun
• 2 heat settings 350˚C – 600˚C
• Includes:
- Concentrator nozzle
- Glass protection nozzle
- Deflector nozzle
- Paint scraper
- 3 shavehook blades & handle
- General purpose scraper
• 2.25m mains cord
• Storage case for the gun and
accessories
Removes paints and varnishes from a wide
range of surfaces and can be used for:
•
•
•
•
•
•
•
DIY
DIY
Paint stripping
Defrosting pipes
Removing flooring
Soldering
Heating charcoal
Heat shrinking
Bending pipes
Earlex are leaders in power decorating tools and equipment
for both DIY and Professional use. Established
in 1987, Earlex are dedicated to UK manufacturing.
• Earlex is a UK based manufacturing company with over 20 years
experience.
• Earlex are dedicated to manufacturing high quality products in the UK.
• Earlex has a full product range with depth and breadth in terms of design
and specification.
• Products are designed in house to deliver genuine innovation with
patented ideas.
• Earlex is the largest manufacturer and the No.1 brand worldwide in HVLP
paint sprayers and wallpaper strippers.
• Earlex is a global company with offices around the world.
Europe
Head Office
Earlex Ltd, 4B Opus Park,
Guildford, Surrey, GU1 1SZ
England UK
Tel: +44(0)1483 454666
North America
Earlex lnc, 8261 Highway 73
Suite F, Stanley,
North Carolina 28164 USA
Tel: +1 (0)704 827 7889
Earlex Sarl, 4 rue Léon
Béridot les jardins d’Epione,
38 500 Voiron FRANCE
Tel: +33 (0)4 76 67 18 46
China
Earlex Group China
Rm1408 Chongguang
Building 796 Baizhang Road
Jiangdong District, Ningbo
Zhejiang, China
Tel: +86 1387 312 001 6
Visit us at
www.earlex.com
PL60 09/11
