CheetaHub Classic-2041
Quick Installation Guide
EH2041S
E0898-R02
Copyright © 1998 by Accton Technology Corporation. All rights reserved.
No part of this document may be copied or reproduced in any form or by any means without the prior
written consent of Accton Technology Corporation.
CheetaHub Classic-2041
Accton makes no warranties with respect to this documentation and disclaims any implied warranties
of merchantability, quality, or fitness for any particular purpose. The information in this document is
subject to change without notice. Accton reserves the right to make revisions to this publication
without obligation to notify any person or entity of any such changes.
Smart Ethernet Hub with
16 10BASE-T (RJ-45) ports,
1 10BASE2 (BNC) port,
and 1 AUI port
International Headquarters
No. 1 Creation Road III,
Science-based Industrial Park
Hsinchu 300, Taiwan, R.O.C.
Phone: 886-3-5770-270
FAX: 886-3-5770-267
BBS: 886-3-5770-654
Internet: support@accton.com.tw
USA Headquarters
P.O. Box 51420
Irvine, CA 92619-1420
Phone Numbers Sales: 888-398-2101 or 949-707-4800
Support: 888-398-4101 or 949-707-4847
RMA:
888-398-3101 or 949-707-4828
FAX: 949-707-2460
Accton is a trademark of Accton Technology Corporation. Other trademarks or brand names mentioned
herein are trademarks or registered trademarks of their respective companies.
EH2041S
E0898-R02
CheetaHub Classic-2041
Quick Installation Guide
Contents
Introduction
The CheetaHub Classic-2041 includes 16 RJ-45 ports,
1 BNC port for connection to thin Ethernet (10BASE2), and 1
AUI port for connection to a variety of media types including
10BASE5 or fiber (using a suitable transceiver). With these
options, you can easily link the hub to a thin or thick Ethernet
backbone, or connect to a remote office. The hub also has an
indicator panel that includes utilization and link/traffic LEDs,
making it easy to monitor the hub. This guide contains all the
information required to install and operate the hub.
Introduction
1
Package Contents
1
Description of Hardware
1
Mounting the Hub
Stacking Hubs on a Flat Surface
Mounting Hubs in a Rack
1
2
2
Connecting the Hub System
Making a Connection via an MDI-X Station Port
Making a Connection via the MDI Daisy-Chain Port
Making a Connection to the BNC Port
Making a Connection to the AUI Port
2
2
3
3
3
•
•
•
•
Powering on the Hub
3
Description of Hardware
Verifying Hub Status
4
Applications
4
This hub consists of 16 RJ-45 10Mbps ports, 1 BNC port, and 1 AUI port. The
following figure shows the front and back panel of the hub:
Product Specifications
Base Unit
Network Criteria
4
4
5
Troubleshooting
Diagnosing Hub Indicators
Power and Cooling Problems
Installation
5
5
6
6
Port and Cable Assignments
RJ-45 Port Description
6
6
EMI Certification
FCC Class A (USA)
Class A (Canada Department of Communications)
Class A (Taiwan Bureau of Commodity Inspection)
Class A Compliance (Korea)
VCCI Class A Compliance (Japan)
CE Mark Declaration of Conformance for EMI and Safety (EEC)
6
6
7
7
7
7
7
Safety Compliance
Underwriters Laboratories Inc. (USA)
Wichtige Sicherheitshinweise (Germany)
8
8
8
Warranty
9
Package Contents
The package includes:
CheetaHub Classic-2041 (Model No. EH2041S)
Four rubber foot pads
• BNC connector
Rack mount bracket kit
• Quick Installation Guide
AC power cord
• Owner registration card
Mounting the Hub
This hub can be placed directly on your desktop, or mounted in a rack.
Before you start installing the hub, make sure you can provide the right operating
environment, including power requirements, sufficient physical space, and proximity
to other network devices that are to be connected. Verify the following installation
requirements:
• Power requirements: 100 to 240 VAC (± 10%) at 50 to 60 Hz (± 3Hz). The hub's
power supply automatically adjusts to the input voltage level.
• The hub should be located in a cool dry place, with at least 10 cm. (4 in.) of
space at the front and back for ventilation.
• Place the hub out of direct sunlight, and away from heat sources or areas with a
high amount of electromagnetic interference.
• If you intend to mount the hub in a rack, make sure you have all the necessary
mounting screws, brackets, bolts and nuts, and the right tools.
• Check if network cables and connectors needed for installation are available.
1
CheetaHub Classic-2041
Quick Installation Guide
Stacking Hubs on a Flat Surface
Making a Connection via the MDI Daisy-Chain Port
This hub can be stacked anywhere
there is a enough flat space, such as
on a table or desktop.
1. To make a direct connection to a compatible hub or switch, use the MDI daisychain port (Port 16). When connecting to this port, remember to set the port
selection switch to MDI. You can also connect any RJ-45 (MDI-X) port on the
hub to an MDI daisy-chain port on the other device.
1. Stick the self-adhesive rubber foot
pads (that come with this package)
on each of the 4 concave spaces located on the bottom of the first hub.
2. Place the first hub on a firm flat surface where you want to install the stack.
3. Repeat step 1 for each hub before stacking them. The rubber foot pads cushion
the hub against shock/vibrations and provide space between each hub for
ventilation.
Mounting Hubs in a Rack
Please comply with the following
instructions to ensure that your hub
is securely mounted in the rack.
1.
2.
3.
4.
Use a standard EIA 19-inch rack.
Use the brackets and screws supplied in the rack mounting kit.
Use a cross-head screwdriver to attach the brackets to the side of the hub.
Position the hub in the rack by lining up the holes in the brackets with the
appropriate holes on the rack, and then use the supplied screws to mount the
hub in the rack.
Connecting the Hub System
This hub has 16 RJ-45 ports, one of which also serves as an (MDI) daisy-chain
port. It also has one BNC port on the rear panel for connection to thin Ethernet
(10BASE2), and one AUI port for connection to thick Ethernet (10BASE5) or fiber
(10BASE-F).
Making a Connection via an MDI-X Station Port
You can connect any RJ-45 (MDI-X) station port on the hub to any device that uses
a standard network interface such as a PC or server, or to a network
interconnection device such as a bridge or router (depending on the port type
implemented).
1. Prepare the network devices you wish to network. Make sure you have installed
10BASE-T network interface cards for connecting to the hub's
RJ-45 (MDI-X) station ports. You also need to prepare straight-through shielded
or unshielded twisted-pair cables with RJ-45 plugs at both ends. Use 100W
Category 3, 4 or 5 cable for all RJ-45 connections.
2. Connect one end of the cable to the RJ-45 port of the network interface card,
and the other end to any available (MDI-X) station port on the hub. When inserting
an RJ-45 plug, be sure the tab on the plug clicks into position to ensure that it is
properly seated. Using the hub in a stand-alone configuration, you can network up
to 16 end nodes.
I Do not plug a phone jack connector into any RJ-45 port. This may damage the
hub. Instead, use only twisted-pair cables with RJ-45 connectors that conform
with FCC standards.
Notes: 1. Make sure each twisted-pair cable does not exceed 100 meters (328 feet).
2. When using Port 16 as an MDI-X port, set the port selection switch to 16MDI-X.
2
2. Prepare straight-through shielded or unshielded twisted-pair cables with RJ-45
plugs at both ends. Use 100W Category 3, 4 or 5 cable for all RJ-45
connections. When inserting an RJ-45 plug, be sure the tab on the plug clicks
into position to ensure that it is properly seated.
Notes: 1. To connect to another hub or switch, you may also attach to (MDI-X)
station ports at both ends if you use crossover cabling (see page 6).
2. When using Port 16 as an MDI port, set the port selection switch to 16MDI.
3. When connecting to another 10Mbps hub, you can cascade up to 4 hubs,
and use up to 100 meters (328 feet) for each inter-hub link.
4. To achieve a larger network diameter, you should use a switch to connect
several hubs (or stacks) together. Because a switch breaks up the path
for connected devices into separate collision domains, it has no
restrictions on cascade length.
Making a Connection to the BNC Port
Plug the BNC T-type connector (provided with the hub) into a BNC port on the
module. When connecting two devices via BNC ports, there should be at least 0.5
meters (1.64 feet) of coaxial cable between the two BNC ports. A thin Ethernet
coaxial cable segment can be extended up to 185 meters (607 feet) and can link up
to 30 nodes. If the unit is at the terminal end of a segment, connect a 50W
terminator to the open end of the "T" connector.
Making a Connection to the AUI Port
Thick Ethernet - Attach an AUI to 10BASE5 transceiver to the thick Ethernet trunk,
and then run an AUI drop cable (with 15-pin D-type connectors on both ends)
between the AUI port on the hub and the transceiver. Note that the maximum
length of an AUI drop cable is 50 meters (164 feet). A thick Ethernet segment can
be extended up to 500 meters (1640 feet) and can link up to 100 nodes.
Fiber - Attach a 10BASE-F fiber optic transceiver to the AUI port. Use 50/125µm or
62.5/125µm multi-mode fiber optic cabling with SC or ST-type connectors (depending
on the transceiver). Run cabling from the TX/RX ports on this hub to the RX/TX
ports on the other device. When inserting the cable, be sure the tab on the plug
clicks into position to ensure that it is properly seated. Note that 10Mbps fiber can
be extended up to 2 kilometers (1.24 miles).
Powering on the Hub
1. Plug the power cord into the power socket at the rear of the hub, and the other
end into a power outlet.
2. Turn on the power switch on the back of the hub.
3. Check the LED marked Power on the front panel to see if it is on. The unit
will automatically select the setting that matches the connected input voltage.
Therefore, no additional adjustments are necessary when connecting it to any
input voltage within the range marked on the rear panel.
Note: The unit supports a "hot remove" feature which permits you to connect/
disconnect RJ-45 or other media cables without powering off the hub and
without disrupting the operation of the devices attached to the hub.
3
CheetaHub Classic-2041
Quick Installation Guide
10BASE5 - thick Ethernet coaxial cable1,
10BASE-F - ST-type multimode fiber 1
Verifying Hub Status
Check each connection by comparing the indicators with the following table.
LED
Po we r
Co llis io n
State
On
Flas hing
Utiliz atio n
Partitio n
Link/Traffic
On
On
On
Flas hing
Indication
Hub re c e iving p o we r.
Two o r mo re d e vic e s atte mp te d to trans mit d ata at the
s ame time . (No rmal s ituatio n und e r Ethe rne t CSMA/CD.)
Ind ic ate s p e rc e ntag e o f LAN b and wid th utiliz e d .
Po rt p artitio ne d d ue to an ab no rmal ne two rk c o nd itio n.
Po rt has e s tab lis he d a valid ne two rk c o nne c tio n.
Po rt is re c e iving p ac ke ts ; b linking is p ro p o rtio nal to traffic .
Applications
Flexible Configuration - This hub is not only designed to provide network access
for 10Mbps connections, but also to provide a wide range of options in setting up
network connections. It can be used as a simple stand-alone hub or stacked up to
10 high; or can be cascaded to any compatible hub or switch. A sample
configuration diagram is shown in the following figure.
Number of Ports
Indicator Panel
Dimensions
Weight
Input Power
Power Consumption
Heat Dissipation
Temperature
Humidity
Certification
Emissions
Immunity
Safety
(1: via suitable AUI transceiver)
16 RJ-45 ports, 1 BNC port, and 1 AUI port
Power, utilization, collisions, partition, link/traffic
440 x 116 x 43 mm (17.32 x 4.58 x 1.69 in)
1.8 kg (3.97 lb)
110~240 VAC, 50/60 Hz (built-in full-range power module)
16 Watts maximum
54.6 BTU/hr
0°C to 50°C (32 to 122°F) Standard Operating
5% to 95% (Non-condensing)
CE Mark
FCC Class A, VCCI Class A, CISPR 22 Class A
IEC 801-2/3/4
UL, CSA, TÜV/GS
Network Criteria
Hub-to-Workstation Distance 100 meters maximum using twisted-pair cable
Inter-hub Distance (MDI Port) 100 meters using twisted-pair cable (4 hub cascade)
(100 meters = 328 feet)
Troubleshooting
Diagnosing Hub Indicators
The hub can be easily monitored through panel indicators to assist the network
manager in identifying problems. This section describes common problems you
may encounter and possible solutions.
Symptom: Power indicator does not light up (green) after power on.
Cause:
Defective power outlet, power cord, or internal power supply.
Solution: Check the power outlet by plugging in another device that is functioning
properly. Check the power cord with another device. If these measures fail
to resolve the problem, have the unit's power supply replaced by a qualified
Accton distributor.
Symptom: Link indicator does not light up (green) after making a connection.
Cause:
Network interface (e.g., a network adapter card on the attached device),
network cable, or hub port is defective.
Solution: Verify that the hub and attached device are powered on. Be sure the cable is
plugged into both the hub and attached device. Check the adapter on the
attached device and cable connections for possible defects. See if your
cable is functioning properly by using it for another port and attached device
that displays valid indications when connected to the network. Replace the
defective adapter or cable if necessary. Also verify that you have not
exceeded specified limits for any attached media as summarized in the
following table:
Product Specifications
Base Unit
Access Method
Standards Conformance
Communication Rate
Media Supported
4
CSMA/CD, 10 Mbps
IEEE 802.3 10BASE-T, 10BASE2, 10BASE5
10 Mbps
10BASE-T - 100W Category 3,4,5 UTP/STP,
10BASE2 - thin Ethernet coaxial cable,
Media Type
Twis te d Pair
Thin Ethe rne t
Thic k Ethe rne t
Fib e r Op tic (10 Mb p s )
Max Length
100 me te rs (328 fe e t)
185 me te rs (607 fe e t)
500 me te rs (0.3 mile s )
2000 me te rs (1.24 mile s )
1 - Minimum d is tanc e b e twe e n no d e s .
2 - Max imum le ng th o f d ro p c ab le fro m AUI p o rt to trans c e ive r.
(0.5 me te rs = 1.64 fe e t; 50 me te rs = 164 fe e t)
Max Nodes
1000
30
500
link p air
Other
0.5 me te rs 1
50 me te rs 2
5
CheetaHub Classic-2041
Quick Installation Guide
Power and Cooling Problems
If the power indicator does not turn on when the power cord is plugged in, you may
have a problem with the power outlet, power cord, or internal power supply as
explained in the previous section. However, if the unit powers off after running for a
while, check for loose power connections, power losses or surges at the power
outlet, and verify that the fan on back of the unit is unobstructed and running prior
to shutdown. If you still cannot isolate the problem, then the internal power supply
may be defective. In this case, contact your Accton distributor for assistance.
Installation
Verify that all system components have been properly installed. If one or more
components appear to be malfunctioning (e.g., the power cord or network cabling),
test them in an alternate environment where you are sure that all the other
components are functioning properly.
operated in a commercial environment. Operation of this equipment in a residential
area is likely to cause interference, in which case the user, at his own expense, will
be required to take whatever measures are required to correct the interference.
You may use unshielded twisted-pair (UTP) for RJ-45 connections - Cat. 3 or greater.
Class A (Canada Department of Communications)
This digital apparatus does not exceed the Class A limits for radio noise emissions
from digital apparatus as set out in the interference-causing equipment standard
entitled "Digital Apparatus", ICES-003 of the Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables
aux appareils numériques de Classe A prescrites dans la norme sur le matériel
brouilleur: "Appareils Numérques", NMB-003 édictée par le ministère des
Communications.
Class A (Taiwan Bureau of Commodity Inspection)
Port and Cable Assignments
RJ-45 Port Description
RJ-45 station ports (MDI-X) can be attached to any devices which use a standard
network interface (e.g., a workstation, server, bridge or router). Similar networking
devices (e.g., another hub or switch) can be cascaded by connecting the hub’s
daisy-chain port (MDI) to an RJ-45 station port on the other device. Use 100W
Category 3, 4 or 5 twisted-pair cable: unshielded or shielded (UTP/STP) cable for
all RJ-45 connections on the front panel, and shielded (STP) cable for the stack
ports on the rear panel. Also be sure that the length of any twisted-pair connection
does not exceed 100 meters (328 feet).
Assignment
(Station Ports 1 - 16)
1
Inp ut Re ce ive Data +
2
Inp ut Re ce ive Data 3
Outp ut Transmit Data +
6
Outp ut Transmit Data 4,5,7,8 No t Use d
Pi n
Assignment (Daisy-Chain
Port, other device)
Outp ut Transmit Data +
Outp ut Transmit Data Inp ut Re ce ive Data +
Inp ut Re ce ive Data No t Use d
Schematics for both straight and crossover twisted-pair cable are shown below.
Straight-Through
(Hub )
(Ad ap te r)
1 IRD+
1 OTD+
2 IRD2 OTD3 OTD+
3 IRD+
6 OTD6 IRD-
(Hub )
1 IRD+
2 IRD3 OTD+
6 OTD-
Crossover
(Hub )
1 IRD+
2 IRD3 OTD+
6 OTD-
EMI Certification
FCC Class A (USA)
Warning: This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause
interference to radio communications. It has been tested and found to comply with
the limits for a Class A digital device pursuant to Subpart B of Part 15 of FCC Rules,
which are designed to provide reasonable protection against such interference when
6
Class A Compliance (Korea)
VCCI Class A Compliance (Japan)
CE Mark Declaration of Conformance for EMI and Safety (EEC)
This is to certify that this product complies with ISO/IEC Guide 22 and EN45014.
It conforms to the following specifications:
EMC:
EN55022(1988)/CISPR-22(1985)
class A
EN60555-2(1995)
class A
EN60555-3
IEC1000-4-2(1995)
4kV CD, 8kV AD
IEC1000-4-3(1995)
3V/m
IEC1000-4-4(1995)
1kV - (power line), 0.5kV - (signal line)
This product complies with the requirements of the Low Voltage Directive 73/23/EEC
and the EMC Directive 89/336/EEC.
Warning! Do not plug a phone jack connector in the RJ-45 port. This may damage
this device. Les raccordeurs ne sont pas utilisé pour le système téléphonique!
7
CheetaHub Classic-2041
Quick Installation Guide
Safety Compliance
Warranty
Underwriters Laboratories Inc. (USA)
Accton warrants to the original owner that the product delivered in this package will
be free from defects in material and workmanship for three years. For the warranty
to apply, you must register your purchase by returning the registration card
indicating the date of purchase and including proof of purchase. There will be a
minimal charge to replace consumable components, such as fuses, power
transformers, and mechanical cooling devices. The warranty does not cover the
product if it is damaged in the process of being installed.
Important! Before making connections, make sure you have the correct Cord Set.
Check it (read the label on the cable) against the following specification list.
Voltage
120 Vo lts
240 Vo lts
(No rth Ame rica)
240 Vo lts
(Euro p e o nly)
C ord Set Specifications
UL Liste d /CSA Ce rtifie d Co rd Se t
Minimum 18 AWG; typ e SVT o r SJT thre e co nd ucto r co rd
Maximum le ng th o f 15 fe e t
Paralle l b lad e , g ro und ing typ e attachme nt p lug rate d 15A, 125V
UL Liste d /CSA Ce rtifie d Co rd Se t
Minimum 18 AWG; typ e SVT o r SJT thre e co nd ucto r co rd
Maximum le ng th o f 15 fe e t
Tand e m b lad e , g ro und ing typ e attachme nt p lug rate d 15A, 125V
Co rd Se t with H05VV-F co rd having thre e co nd ucto rs with
minimum d iame te r o f 0.75 mm²
IEC-320 re ce p tacle ; male p lug rate d 10A, 250V
THE ABOVE WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, WHETHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO ANY
WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR
ANY WARRANTY ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE.
ACCTON SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
ACCTON NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY.
Wichtige Sicherheitshinweise (Germany)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine
Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen
könnte Beschädigungen hervorrufen.
7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor Überhitzung schützt.
Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte auch
nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz
trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in das Gerät
gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.
13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von
authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer
qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe
dieser Anleitung keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. Zum Netzanschluß dieses Gerätes ist eine geprüfte Leitung zu verwenden. Für einen
Nennstrom bis 6A und einem Gerätegewicht größer 3kg ist eine Leitung nicht leichter als
H05VV-F, 3G, 0.75mm2 einzusetzen.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder
weniger.
8
9
