HP | Pavilion Slimline s5-1120 | HP Pavilion Data Sheet

HP Pavilion Slimline s5-1120 PC
Highlights:
•
•
•
•
•
•
•
•
•
Intel® Pentium® Processor G630(2)
Genuine Windows® 7 Home Premium 64-bit(1)
Get powerful 64-bit performance with 4GB DDR3 system memory(3)
1TB (Terabyte) hard drive(4) stores up to 222,000 songs or 178,000 photos(5)
SuperMulti DVD burner(6)
Intel® HD Graphics(16)
Wireless LAN 802.11b/g/n(19)
Front-panel 6-in-1 memory card reader
24 x 7 toll-free phone support, one-year HP limited warranty, lifetime use of
HP Support Assistant provide priceless peace of mind
HP recommends Windows® 7.
Performance anywhere you need it
The HP Slimline s5-1120 offers a powerful PC where space is at a premium. Perfect for a
small space or dorm room, it can handle all your computing needs, like e-mail, word
processing and more.(10) And the Slimline is flexible, so you can easily add or upgrade
features and functions. The all-new HP Pavilion Slimline series offers an elegant,
sophisticated look and feel that fits almost any environment.
Relax with 24x7 Support
HP Total Care provides award-winning service and support for your computer. Visit
www.hp.com/go/totalcare to learn about services and support options that supplement
or extend your standard coverage.
• Enjoy DVD movies and watch your favorite programs online in your living room
• Look up recipes and listen to music while cooking in your kitchen
• Handle all your essential computing needs and be more productive in your home office
• 24x7 technical assistance via on-line chat, e-mail, or phone
• Parts and labor coverage, including customer-replaceable parts, return of equipment
to HP, and authorized service provider options
• 24x7 toll-free technical and limited software support in English or Spanish at
1.800.474.6836
Maximize your desktop space
The HP Pavilion series has all the power and performance you need to multitask with
ease. And with HP Multi-Display Capable technology to support multiple monitors, you’ll
have more space to work. Compare documents side by side. Quickly drag content from
one application to the next. Stream digital entertainment to one monitor while you work
on the other. It’s easy with HP.
HP Premier Experience
The HP Premier Experience focuses on the things that matter most: a simplified Start
Menu, less interruptions, and exclusive and convenient innovations like HP LinkUp.
Speed is a priority when you are booting up, shutting down, going to or resuming from
sleep. It’s cleaner, faster, intuitive, and only on HP.
HP LinkUp software lets you access the content and programs on your notebook(37) from
your HP desktop PC(38) —without file mix-ups or complex synchronization.
• All of your files and applications stay up to date on your notebook(37), while you access
them from your desktop(38).
• No cables or docking stations required—once you install the free client software on
your notebook PC(37), it links up with your HP desktop(38) through your wireless home
network.
Fine-tuned Windows 7 experience.
• Simplified Start Menu to find and launch applications faster with improved
organization in Windows 7.
• Turbocharge your Windows 7 experience with quicker boot-up, shutdown, sleep, and
resume times.
• Reduced notifications and pop-ups so that you can concentrate on the tasks at hand.
During your limited warranty period you get:
In addition, and at no charge, you get 24x7 access to the HP Support Forum in English,
French, or Spanish (www.hp.com/go/supportforum) and lifetime use of HP Support
Assistant (www.hp.com/go/hpsupportassistant) to help you keep your PC up to date and
get assistance when you need it.
HP Pavilion Slimline s5-1120 PC
HP recommends Windows® 7.
SPECIFICATIONS
WARRANTY AND
SUPPORT
OPERATING SYSTEM • Genuine Windows® 7 Home Premium 64-bit(1)
PROCESSOR
• Intel® Pentium® Processor G630(2)
PROCESSOR SPEED
• 2.70GHz(2)
CACHE
• 3MB Cache
BUS SPEED
• DMI 5.0GT/s
CHIPSET
• Intel® H61 PCH Chipset
MEMORY
• 4GB PC3-10600 DDR3 SDRAM memory(3) (1x4GB) (expandable to
8GB)
HARD DRIVE
• 1TB (Terabyte) 7200RPM Serial ATA hard drive(4)
OPTICAL DRIVE(S)
• SuperMulti DVD Burner(6)
Write: 16x max DVD±R, 12x max DVD±R DL, 8x max DVD+RW,
6x max DVD-RW, 12x max DVD-RAM, 40x max CD-R, 32x max
CD-RW
Read: 16x max DVD-ROM, 40x max CD-ROM
VIDEO GRAPHICS
• Intel® HD Graphics(16)
• Up to 1696MB Total Available Graphics Memory as allocated by
Windows® 7
NETWORK
INTERFACE
• Onboard 10/100/1000Mbps Gigabit Ethernet Support
WIRELESS
CONNECTIVITY
• Wireless LAN 802.11b/g/n(19)
SOUND
• Integrated audio, 6 speaker configurable with up to 5.1 surround
sound capabilities
MEMORY SLOTS
• 2 DIMM (240-pin, DDR3) (one available)
EXPANSION SLOTS
• 3 PCI Express x1 (three available)
• 1 PCI Express x16 (available)
• 1 MiniCard (occupied)
EXPANSION BAYS
• 1 external 5.25" (occupied)
• 1 internal 3.5" (occupied)
EXTERNAL PORTS
• Front panel 6-in-1 memory card reader supports xD, MMC, Secure
Digital (SD, SDHC), Memory Stick, Memory Stick Pro, MMC+
• 4 USB 2.0 ports (Back)
• 2 USB 2.0 ports (Front)
• Headphone (Front)
• 10/100/1000Mbps (Gigabit) Ethernet Support (Back)
MULTI-DISPLAY
CAPABLE
• VGA-out and DVI-out (Back)
MOUSE AND
KEYBOARD
• HP USB keyboard and optical mouse
DIMENSIONS
• Unpackaged: 15.43"(L) x 3.94"(W) x 12.28"(H/D) approx.
• Packaged: 19.41"(L) x 15.67"(W) x 9.57"(H/D) approx.
WEIGHT
• Unpackaged: 17.00 lbs. approx
• Packaged: 21.60 lbs. approx
• Warranty:
- 1 year limited hardware warranty and 1 year software support
- 24x7 technical assistance available online(10) or toll-free by phone
- Lifetime use of HP Support Assistant
• Service:
- For information on Authorized support providers, replacement
parts, and other service related information, visit
www.hp.com/support
• Support:
- Click the HP Support Assistant icon in your taskbar or desktop for
easy access to automated maintenance, built-in diagnostic tools,
and a choice of assistance options. Learn more at
www.hp.com/go/hpsupportassistant.
- Visit our Consumer Support Forum, available 24 x 7 in English,
French or Spanish at www.hp.com/go/supportforum
- Contact technical support (available 24 x 7, toll-free phone, chat,
or email) at
http://welcome.hp.com/country/us/en/wwcontact.html
SOFTWARE
PRODUCTIVITY &
LIFESTYLE
• HP LinkUp lets you access, edit, and save content on your notebook
PC(37) while using your desktop PC(38)
• Windows Live™ Essentials - Create, connect and share with the
Cloud
• Office 2010 preloaded (purchase of a Product Key required to
activate a full Office 2010 suite)(14b)
SECURITY &
PROTECTION
• Norton Internet Security 2012: Free 60-day subscription helps keep
your PC, identity and personal information safe online(11)
SUPPORT
• HP Support Assistant: Keep your PC up to date and get assistance
when you need it.
• HP Setup Manager: Learn about your new PC and explore key
activities that can help you transition smoothly and easily from your
old PC.
ADDITIONAL INFORMATION
PRODUCT NUMBER
• QU117AA#ABA
AD EMBARGO DATE • 10/2/2011
UPC CODE
• 886111976416
COUNTRY OF
ORIGIN
• China
• Mexico
TARIFF NUMBER
• 8471500085
PALLET
INFORMATION
•
•
•
•
•
Dimensions: 47.24"(L) x 40.16"(W) x 10.13"(H/D) approx.
Total weight: 1311.80 lbs. approx
Layers: 10
Products per layer: 6
Total products per pallet: 60
VISIT WWW.HP.COM FOR MORE DETAILS!
(1)
This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows® 7 software and take full advantage of Windows® 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.
Processor speed 2.70GHz, 3MB cache. Intel’s numbering is not a measurement of higher performance. (3) Up to 256MB of main system memory may be allocated to support video graphics. (4) For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to
14GB of storage space is reserved for the system recovery software. (5) Capacity based on average compressed .jpg size of 5MB/image. Capacity based on standard NTSC recording format. Actual recording times may vary. (6) Actual speeds may vary. Don’t copy
copyright-protected materials. Double Layer is a new technology. Double Layer media compatibility will widely vary with some home DVD players and DVD-ROM drives. Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 GB Double Sided – Version 1.0
media. (10) Internet access required and sold separately. (11) Internet access required. First 60 days included; subscription required for live updates afterwards. (14) Includes reduced functionality versions of Word and Excel. Purchase of Product Key required to activate full
Office 2010 suite available at participating resellers/retailers and www.office.com. (16) Part of the total system memory (RAM) is used for graphics/video performance. System memory dedicated to graphics/video performance is not available for other use by other
programs. (19) Wireless access point and Internet service sold separately. (37) Compatible with any notebook or desktop PC running Windows XP, Vista, or Windows 7. (38) Internet connection and home network required.
Monitor and speakers sold separately. Actual product may vary from image shown on datasheet. ©2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are
set forth in the express warranty statements accompanying such products and services. Nothing shall be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft® and Windows® are registered trademarks of Microsoft Corporation. 08/02_r1 ch Product Number: QU117AA#ABA
(2)
