BYOD - Identification and Authentication Deployment Guide
BYOD—Identification and Authentication
Deployment Guide
February 2012 Series
Preface
Who Should Read This Guide
This Cisco® Smart Business Architecture (SBA) guide is for people who fill a variety of roles:
• Systems engineers who need standard procedures for implementing solutions
• Project managers who create statements of work for Cisco SBA implementations
• Sales partners who sell new technology or who create implementation documentation
• Trainers who need material for classroom instruction or on-the-job training
In general, you can also use Cisco SBA guides to improve consistency among engineers and deployments, as well as to improve scoping and costing of deployment jobs.
Release Series
Cisco strives to update and enhance SBA guides on a regular basis. As we develop a new series of SBA guides, we test them together, as a complete system. To ensure the mutual compatibility of designs in Cisco SBA guides, you should use guides that belong to the same series.
All Cisco SBA guides include the series name on the cover and at the bottom left of each page. We name the series for the month and year that we release them, as follows:
month year
Series
For example, the series of guides that we released in August 2011 are the “August 2011 Series”.
You can find the most recent series of SBA guides at the following sites:
Customer access: http://www.cisco.com/go/sba
Partner access: http://www.cisco.com/go/sbachannel
How to Read Commands
Many Cisco SBA guides provide specific details about how to configure
Cisco network devices that run Cisco IOS, Cisco NX-OS, or other operating systems that you configure at a command-line interface (CLI). This section describes the conventions used to specify commands that you must enter.
Commands to enter at a CLI appear as follows: configure terminal
Commands that specify a value for a variable appear as follows: ntp server
10.10.48.17
Commands with variables that you must define appear as follows: class-map
[highest class name]
Commands shown in an interactive example, such as a script or when the command prompt is included, appear as follows:
Router# enable
Long commands that line wrap are underlined. Enter them as one command: wrr-queue random-detect max-threshold 1 100 100 100 100 100
100 100 100
Noteworthy parts of system output or device configuration files appear highlighted, as follows: interface Vlan64
ip address 10.5.204.5 255.255.255.0
Comments and Questions
If you would like to comment on a guide or ask questions, please use the forum at the bottom of one of the following sites:
Customer access: http://www.cisco.com/go/sba
Partner access: http://www.cisco.com/go/sbachannel
An RSS feed is available if you would like to be notified when new comments are posted.
February 2012 Series
Preface
Table of Contents
Deploy AnyConnect on Windows endpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Configure Mac workstations for 802.1X authentication . . . . . . . . . . . . . . . . . 46
ALL DESIGNS, SPECIFICATIONS, STATEMENTS, INFORMATION, AND RECOMMENDATIONS (COLLECTIVELY, “DESIGNS”) IN THIS MANUAL ARE PRESENTED “AS IS,” WITH ALL FAULTS. CISCO AND ITS SUPPLIERS
DISCLAIM ALL WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITA-
TION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THE DESIGNS, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. THE DESIGNS ARE SUBJECT TO CHANGE WITHOUT NOTICE. USERS ARE SOLELY RESPONSIBLE FOR THEIR APPLICATION OF THE DESIGNS. THE DESIGNS DO NOT CONSTITUTE THE TECHNICAL
OR OTHER PROFESSIONAL ADVICE OF CISCO, ITS SUPPLIERS OR PARTNERS. USERS SHOULD CONSULT THEIR OWN TECHNICAL ADVISORS BEFORE IMPLEMENTING THE DESIGNS. RESULTS MAY VARY
DEPENDING ON FACTORS NOT TESTED BY CISCO.
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
© 2012 Cisco Systems, Inc. All rights reserved.
February 2012 Series
Table of Contents
What’s In This SBA Guide
About SBA
Cisco SBA helps you design and quickly deploy a full-service business network. A Cisco SBA deployment is prescriptive, out-of-the-box, scalable, and flexible.
Cisco SBA incorporates LAN, WAN, wireless, security, data center, application optimization, and unified communication technologies—tested together as a complete system. This component-level approach simplifies system integration of multiple technologies, allowing you to select solutions that solve your organization’s problems—without worrying about the technical complexity.
For more information, see the How to Get Started with Cisco SBA document: http://www.cisco.com/en/US/docs/solutions/Enterprise/Borderless_Networks/
Smart_Business_Architecture/SBA_Getting_Started.pdf
About This Guide
This additional deployment guide includes the following sections:
• Business Overview —The challenge that your organization faces.
Business decision makers can use this section to understand the relevance of the solution to their organizations’ operations.
• Technology Overview —How Cisco solves the challenge. Technical decision makers can use this section to understand how the solution works.
• Deployment Details —Step-by-step instructions for implementing the solution. Systems engineers can use this section to get the solution up and running quickly and reliably.
This guide presumes that you have read the prerequisites guides, as shown on the Route to Success below.
ENT
BN
Route to Success
To ensure your success when implementing the designs in this guide, you should read any guides that this guide depends upon—shown to the left of this guide on the route above. Any guides that depend upon this guide are shown to the right of this guide.
For customer access to all SBA guides: http://www.cisco.com/go/sba
For partner access: http://www.cisco.com/go/sbachannel
February 2012 Series
Prerequisite Guides
Design Overview LAN
Deployment Guide
You are Here
BYOD – Identification and
Authentication
Deployment Guide
What’s In This SBA Guide
1
Introduction
Note
This guide is based on the Cisco SBA Borderless Networks LAN
and WLAN 802.1X Deployment Guide. The goal of this guide is to show you how a BYOD business problem can be solved by using
Cisco Smart Business Architecture. Cisco has previously developed solutions to solve issues that are similar to the various BYOD business problems. Cisco SBA uses 802.1X to solve the BYOD problem of identifying and authenticating devices.
There is a trend in the marketplace that is often referred to as Bring Your
Own Device (BYOD). BYOD is a spectrum of business problems that can be solved in various ways. This ranges from guest wireless access all the way to device authentication and identification. The goal is to provide a common work-environment regardless of the type of device being used. This could be through a virtualized desktop or by allowing users to self-register devices for use on the network.
Organizations are experiencing an unprecedented transformation in the network landscape. In the past, IT typically provided network resources only to corporate-managed PCs, such as laptops and desktops. Today, employees are requiring access from both corporate managed and unmanaged devices including mobile devices like smart phones and tablets. This rapid proliferation of mobile devices capable of supporting applications drastically increases workforce mobility and productivity, but it also presents an enormous challenge to IT organizations seeking to enforce security policies across a growing population of devices, operating systems, and connectivity profiles.
This evolution of mobile device usage and the introduction of mobile devices into the workplace has caused a paradigm shift in how IT views what qualifies as a network “end point device” and also what it means to “be at work.” The distinction between a device used exclusively for “work” and a device used exclusively for “personal use” has evolved.
February 2012 Series
An organization needs to know not only who is accessing their wired and wireless networks, but also when the networks were accessed and from where. In addition, with the wide adoption of nontraditional devices such as smart phones and tablets, and people bringing their own devices to access the network, organizations need to know how many of these devices are connecting. With this information the organization can create policy to prevent connection by nontraditional devices, limit connection to approved devices, or make access to network resources easier for these nontraditional devices. This presents a challenge for IT organizations that seek to provide end users with a consistent network access experience and the freedom to use any device, while still enforcing stringent security policies to protect corporate intellectual property. Further complicating the situation is delivering both consistent access and enforcing proper security policy based on the specific user access scenario (wired, wireless, guest, local, branch, and remote users).
To balance the productivity gains versus the security risks, IT needs to implement a solution that allows for seamless on-boarding of users and devices, simplicity of on-going operations, and the ability to extend enduser applications to any user or any device at any time.
Other SBA Borderless Networks guides addressing BYOD business problems include:
• BYOD—Internal Corporate Access Deployment Guide
• BYOD—Guest Wireless Access Deployment Guide
• BYOD—Remote Mobile Device Access Deployment Guide
Business Overview
With an increasingly mobile workforce and a diverse number of platforms used to gain access to the network, organizations are looking for ways to monitor and control network access. An organization needs to know not only who is accessing their wired and wireless networks, but also when the networks were accessed and from where. In addition, with the wide adoption of nontraditional devices such as smart phones and tablets, and people bringing their own devices to access the network, organizations need to know how many of these devices are connecting. With this information, the organization can create policy to prevent connection by nontraditional devices, limit connection to approved devices, or make access to network resources easier for these non-traditional devices.
Organizations are being driven by industry and regulatory compliance (PCI,
Sarbanes-Oxley) to be able to report on who is accessing the organization’s information, where they are accessing it from, and what type of device
Introduction
2
they are using to access it. Government mandates like Federal Information
Processing Standard (FIPS) and Federal Information Security Management
Act (FISMA) are also requiring agencies and entities working with government agencies to track this information. In some cases, an organization may choose to limit access to certain information to adhere to these regulations.
This information is also key data that can be used to generate advanced security policies. Organizations see this as a daunting task requiring the use of several advanced technologies and often delay implementing a solution simply because they don’t know where to begin.
This guide is the first step in deploying a complete identity-based architecture. Future projects will address additional use cases that will focus on the features that will provide for things like enforcement, guest access, and confidentiality.
Technology Overview
Cisco Identity Services Engine (ISE) is an identity and access control policy platform that enables enterprises to enforce compliance, enhance infrastructure security, and streamline their service operations. Cisco ISE is a core component of Cisco TrustSec. Its architecture allows an organization to gather real-time contextual information from the network, users, and devices to make proactive policy decisions by tying identity into network elements like access switches, wireless controllers, and VPN gateways.
This deployment uses Cisco ISE as the authentication and accounting server for the wired and wireless networks as well as for remote access VPN users who connect using RADIUS. Cisco ISE acts as a proxy to the existing
Active Directory (AD) services to maintain a centralized identity store for all network services.
In addition to authentication, this deployment uses Cisco ISE to profile devices to determine the specific type of devices that are accessing the network. This is done by examining network traffic for certain criteria based on certain characteristics. Cisco ISE currently has probes for Dynamic
Host Configuration Protocol (DHCP), HTTP, RADIUS, Domain Name System
(DNS), Simple Name Management Protocol (SNMP) traps and queries, and
Netflow. To analyze the traffic, the engine can be deployed as an inline policy enforcement device or the traffic can be forwarded to the engine.
As an example, the network infrastructure is configured to send copies of the DHCP requests to Cisco ISE for analysis. The engine then evaluates the DHCP request and can identify the device based off of the data in the request. For example, Cisco IP Phones are identified by their DHCP class identifier.
In the LAN, there are three modes for deploying TrustSec: monitor mode, authenticated mode, and enforcement mode. Cisco recommends a phased deployment model that can allow for limited impact on network access while gradually introducing authentication/authorization on the network. This document covers the deployment of monitor mode both at the headquarters site and the remote sites, with Cisco ISE being centralized in the data center.
The monitor mode deployment in use deploys two features within IOS on the switches in the access layer at both the headquarters sites as well as the remote sites. The first is MAC Authentication Bypass (MAB), which authenticates the device on the switch port by the MAC address. Monitor mode logs the MAC addresses that connect and grant access to any device that connects. The second feature is 802.1X open mode, which allows the switch port to give unrestricted access to the network even though authentication and authorization have not been performed. This enables the deployment of identity without affecting existing connectivity. This phased approach allows us to prepare for moving to another mode (for instance, authenticated or enforcement) in the future. In the organization, these switch configurations will be managed by Cisco LAN Management Solution (LMS) 4.1 and the new Identity WorkCenter. Cisco LMS simplifies the deployment of identity by performing a network readiness assessment for an identity deployment, providing templates for the various modes—monitor, authenticated, enforcement—and providing a step-by-step wizard to configure the various components required.
You accomplish integrating Cisco ISE into the wireless network by using
Cisco ISE as the RADIUS server for wireless 802.1X authentication and accounting. You configure this on every wireless LAN controller (WLC) in the network, at both headquarters and the remote sites. The one exception is for the controller used for guest access. You can also configure the WLCs to forward DHCP requests to Cisco ISE to enable the profiling of wireless endpoints.
February 2012 Series
Introduction
3
Figure 1 - Cisco ISE integration into Cisco SBA
February 2012 Series
Introduction
4
Deployment Details
Procedure 1 Set up initial primary engine
Step 1: Boot the Cisco ISE and then, at the initial prompt, enter setup. The installation begins.
The deployment described here bases all IP addressing off of the SBA for
Enterprise Organizations – Borderless Networks LAN Deployment Guide.
Any IP addresses used in this guide are examples; you should use addressing that is applicable to your architecture.
Device
Primary Cisco ISE
Secondary Cisco ISE
IP address
10.4.48.41
10.4.48.42
Hostname
Ise-1.cisco.local
ise-2.cisco.local
Process
Deploying Identity Services Engine
1. Set up initial primary engine
2. Set up the secondary engine
3. Configure certificate trust list
4. Configure Cisco ISE deployment nodes
6. Configure network devices in Cisco ISE
7. Configure Cisco ISE to use Active Directory
8. Disable IP Phone authorization policy
Step 2: Enter the host name, IP address, subnet mask, and default router of the engine.
Enter hostname[]:
ise-1
Enter IP address[]:
10.4.48.41
Enter IP default netmask[]:
255.255.255.0
Enter IP default gateway[]:
10.4.48.1
Step 3: Enter DNS information.
Enter default DNS domain[]:
cisco.local
Enter primary nameserver[]:
10.4.48.10
Add/Edit another nameserver? Y/N :
n
February 2012 Series
Deployment Details
5
Step 4: Configure time.
Enter primary NTP server[time.nist.gov]:
ntp.cisco.local
Add/Edit secondary NTP server? Y/N :
n
Enter system timezone[UTC]:
PST8PDT
Tech Tip
Timezone abbreviations can be found in the Cisco Identity
Services Engine CLI Reference Guide, Release 1.1: http://www.cisco.com/en/US/docs/security/ise/1.1/cli_ref_guide/ ise_cli_app_a.html#wp1571855
Step 5:
Configure an administrator account.
You must configure an administrator account in order to access to the CLI console. This account is not the same as the one used to access the GUI.
Enter username[admin]:
admin
Enter password:
[password]
Enter password again:
[password]
Cisco ISE completes the installation and reboots. This process takes several minutes. You will be asked to enter a new database administrator password and a new database user password during the provisioning of the internal database. Do not press
Control-C
during the installation, or it will abort the installation.
The primary engine is now installed.
Procedure 2 Set up the secondary engine
The procedure for setting up the secondary engine is the same as the primary, with the only difference being the IP address and host name config-
ured for the engine. To set up the secondary engine, follow Procedure 1 and
use the values supplied in the table for the secondary engine.
Procedure 3 Configure certificate trust list
The two engines use public key infrastructure (PKI) to secure communications between them. Initially in this deployment, you use local certificates and you must configure a trust relationship between the primary and secondary engines. To do this, you need to import the local certificate from the secondary engine into the primary engine.
Step 1: In your browser, connect to the secondary engine’s GUI at http:// ise-2.cisco.local.
Step 2: In Administration > System , select Certificates .
Step 3: In the Local Certificates window, select the local certificate by checking the box next to the name of the secondary engine, ise-2.cisco.
local, and then click Export .
Step 4: Choose Export Certificate Only , and then click Export.
Step 5: When the browser prompts you to save the file to a location on the local machine, choose where to store the file and make a note of it. You will be importing this file into the primary engine.
Step 6: In a browser, access the primary engine’s GUI at http://ise-1.cisco.
local.
Step 7: In Administration > System , select Certificates .
Step 8: In the Certificate Operations pane on the left, click Certificate
Authority Certificates, and then click Add .
February 2012 Series
Deployment Details
6
Step 9: Click Browse next to the Certificate File field, and then locate the certificate exported from the secondary engine. It has an extension of .pem.
Step 10: Click Submit .
Procedure 4 Configure Cisco ISE deployment nodes
You can configure the functions of Cisco ISE—administration, monitoring, and policy service—to run all on a single engine or to be distributed amongst several engines. For this example installation, you will deploy a primary engine that performs all three functions and a secondary engine that acts as a backup for the primary.
Step 1: Connect to http://ise-1.cisco.local.
Step 2: From the Administration menu, choose System , and then choose
Deployment . A message appears notifying you that the node is currently stand-alone.
Step 4: Configure the node group with the node group name ISE-Group and the default multicast address of 228.10.11.12.
Step 5: Click Submit . A pop-up window lets you know the group was created successfully. Click OK .
Step 6: In the Deployment pane on the left, expand Deployment . A list of the current deployment nodes appears.
Step 7: Click ise-1 . This enables you to configure this deployment node.
Step 8: Under the Personas section on the General Settings tab, click Make
Primary , which is next to the Administration Role.
Step 9: Include this node in the ISE-Group node group by choosing it from the pull-down menu.
Step 3: In the Deployment pane, click the gear icon, and then select Create
Node Group .
In order for the two Cisco ISE devices to share policy and state information, they must be in a node group. The nodes use IP multicast to distribute this information so they need to be able to communicate via IP multicast.
Next, you’ll configure which methods will be used to profile network endpoints.
Step 10: Click the Profiling Configuration tab.
February 2012 Series
Deployment Details
7
Step 11: This example uses DHCP and RADIUS. Select the box next to each to enable these methods, use the default parameters, and then click Save .
Step 15: Configure ise-2 to be the secondary engine in the group by making sure that all the boxes are selected to enable all personas and that this unit is the secondary. Choose the node group ISE-Group from the drop-down list.
Step 16: Click Submit . The node registers and a pop-up window displays letting you know that the process was successful. Click OK .
Step 12: In the Edit Node window, click Deployment Nodes List . The
Deployment Nodes window appears.
Step 13: Click Register, and then choose Register an ISE Node .
Step 17: In the Deployment Nodes window, click ise-2, click the Profiling
Configuration tab, and then configure the DHCP and RADIUS options in the same way you did for the primary engine.
Step 18: Click Save .
Both Cisco ISE units are now configured as a redundant pair.
Step 14: Enter the IP address or host name of the secondary Cisco ISE and the credentials for the admin account, and then click Next .
February 2012 Series
Deployment Details
8
Procedure 5 Install Cisco ISE license
Cisco ISE comes with a 90-day demo license for both the Base and
Advanced packages. To go beyond 90-days, you need to obtain a license from Cisco. In a redundant configuration, you only need to install the license on the Primary Administration Node.
Step 1: Mouse over Administration , and then, from the System section of the menu, choose Licensing .
Notice that you only see one node here since the secondary node does not require licensing.
Step 2: Click the name of the Cisco ISE server. This enables you to edit the license details.
Step 3: Under Licensed Services, click Add Service.
Step 4: Click Browse to locate your license file, and then click Import .
If you have multiple licenses to install, repeat the process for each.
Tech Tip
When installing a Base license and an Advanced license, the
Base license must be installed first.
Procedure 6 Configure network devices in Cisco ISE
Configure Cisco ISE to accept authentication requests from network devices. RADIUS requires a shared secret key to enable encrypted communications. Each network device that will use Cisco ISE for authentication will need to have this key.
Step 1: Mouse over Administration , and then, from the Network Resources section of the menu, choose Network Devices .
Step 2: In the left pane, click Default Device .
Tech Tip
Each network device can be configured individually, or devices can be grouped by location, by device type, or by using IP address ranges. The other option is to use the Default Device to configure the parameters for devices that aren’t specifically configured. All our network devices have to use the same key, so for simplicity, this example uses the Default Device.
Step 3: Enable Default Network Device Status by choosing Enable from the pull-down menu.
Step 4: Enter the RADIUS shared secret, and then click Save .
February 2012 Series
Deployment Details
9
Procedure 7 Configure Cisco ISE to use Active Directory
Cisco ISE will use the existing Active Directory (AD) server as an external authentication server. First, you must configure the external authentication server.
Step 1: Mouse over Administration , and then, from the Identity
Management section of the menu, choose External Identity Sources .
Step 2: In the left panel, click Active Directory .
Step 3: On the Connection tab, configure the connection to the AD server by entering the AD domain (for example, “cisco.local”) and the name of the server (for example, “AD1”), and then click Save Configuration.
Step 4: Verify these settings by selecting the box next to the node, and then clicking Test Connection and choosing Basic Test .
Step 5: Enter the credentials for a domain user and click OK .
Step 7: Enter the credentials for a domain administrator account. The Cisco
ISE is now joined to the AD domain.
Next, select which groups from AD that Cisco ISE will use for authentication.
Step 8:
Click the
Groups
tab, click
Add,
and then click
Select Groups from
Directory
.
Step 9: Search for the groups you wish to add. The domain field is already filled in. The default filter is a wildcard to list all groups. Click Retrieve
Groups to get a list of all groups in your domain.
Step 10:
Select the groups you want to use for authentication, and then click
OK
. For example, for all users in the domain, select the group
<domain>/Users/Domain Users.
Step 6:
Select the box next each node, and then click
Join
.
February 2012 Series
Step 11: Click Save Configuration .
Deployment Details
10
Procedure 8 Disable IP Phone authorization policy
There is a default policy in place for Cisco IP Phones that have been profiled. This profile applies a downloadable access list on the port to which the phone is connected. Since there is no policy enforcement taking place, this rule should be disabled.
Step 1: On the menu bar, mouse over Policy , and then click Authorization .
Step 2: Click Edit for the Profiled Cisco IP Phones rule, click the green check mark icon, choose Disabled , click Done , and then click Save .
Process
Enabling Visibility to the LAN
1. Configure MAC Authentication Bypass
2. Configure 802.1X for wired users
3. Enable RADIUS in the access layer
5. Disable port security timers
6. Configure profiling for the LAN
Cisco ISE is now configured for identity. The next step is to configure the switches for identity by using Cisco LMS 4.1 and the Identity Workcenter.
Procedure 1 Configure MAC Authentication Bypass
MAC Authentication Bypass (MAB) allows you to configure specific machine
MAC addresses on the switch to bypass the authentication process. For monitor mode, this is required, since you aren’t enforcing authentication.
MAB will be configured to allow any MAC address to authenticate.
Step 1:
Mouse over
Policy
, and then choose
Authentication
. The Policy
Type is Rule-Based.
There are already two default rules in place, MAB and Dot1X.
February 2012 Series
Deployment Details
11
Step 2: Use the default MAB policy. Click the black triangle to the right of the and… of the MAB rule. This brings up the identity store used for the MAB rule.
Next, change the options on the Internal Users database, which is used for profiling.
Step 3:
Click the
+
next to
Internal Endpoints
. In this example deployment, we are allowing all endpoints to authenticate. If the MAC address isn’t found in the database, you need to bypass authentication and continue. For the authentication failed and user not found options, choose
Continue
from the pull-down menu.
Step 4:
Click anywhere in the window to continue, and then click
Save
.
Procedure 2 Configure 802.1X for wired users
There is already a Dot1X rule configured on the engine. Although in this example deployment you aren’t deploying any wired endpoints with 802.1X supplicants at this point, you should still configure this rule to prepare for the next phase of an identity deployment.
Step 1: Mouse over Policy , and then, from the menu, choose
Authentication .
Step 2: To differentiate this from a wireless 802.1X rule, rename the rule
Wired-Dot1X .
Step 3: Click the black triangle to the right of the and… of the Wired-Dot1X rule. This brings up the identity store used for this rule.
The default identity store is the internal user database. For 802.1X, use the
Active Directory server that you defined earlier.
Step 4: Click the + symbol next to Internal Users . This enables you to edit the identity store and the parameters.
Step 5: From the Identity Source drop-down list, choose the previously defined AD server AD1 , use the default options for this identity source, and then click anywhere in the window to continue.
Step 6: Click Save .
February 2012 Series
Deployment Details
12
Procedure 3 Enable RADIUS in the access layer
Step 1: Connect to Cisco LMS with a web browser, for example: https://lms.
cisco.local.
Step 2: Mouse over Workcenters , and then, from the Identity section, choose Getting Started . This shows the network’s Identity Readiness
Assessment, which verifies that the software versions support the identity features and that the switches are capable of running RADIUS.
Step 6: In the pop-up window, enter 10.4.48.41
for the RADIUS server IP address, and then click Save and add another .
Step 7: Enter 10.4.48.42
for the second RADIUS server, and then click
Save. The RADIUS server group has been configured.
Step 8: In the AAA Configuration section, make sure that only Enable for
802.1X / MAB AAA is selected. A warning message about not configuring
AAA for Web authentication appears. Click OK .
Step 9: Click Next to proceed to the next step.
Next, configure identity by enabling RADIUS on the switch.
Step 3: In the RADIUS-capable devices table, select the switches for which you want to enable RADIUS, and then click Configure RADIUS .
Step 4: Select the RADIUS Group button, and then fill in the fields. Enter
ISE-Group for the RADIUS group name, and then use the value used in previous procedures for the Shared Key.
Step 5: In the RADIUS Server Details section, click Add .
February 2012 Series
Tech Tip
You can review the CLI commands that will be pushed to the switch by clicking Preview CLI .
Deployment Details
13
Step 10: Enter a job description, and then click Finish to deploy immediately.
Step 11: When you receive the warning regarding the addition of AAA commands, click Yes , and then click OK on the pop-up window generated after the job is created.
Procedure 4 Enable identity
The identity configuration enables monitor mode on the switch. This enables both 802.1X and MAC Authentication Bypass, (MAB) however no authentication policy is enabled. This allows the ports to be monitored with no disruption to current network activity.
Step 1: Mouse over Work Centers , and then, under the Identity section, choose Configure .
Step 2: In the Navigator pane on the left, click Enable Interfaces .
Step 3: Choose the switch that was previously configured for RADIUS from the list, select All Groups in the port group selector, and then click Next .
Step 4: Select the check box next to the ports for which you want to enable identity, and then click Next .
Next, configure monitor mode.
Step 5:
Move the Security Mode slider to
Monitor
, which is the default.
February 2012 Series
Deployment Details
14
Step 6: In the Authentication Profile section, select 802.1X
, then MAB in the
Define Authentication Profile slider, make sure MultiAuth is selected in the
Define Host Mode section and No Change is selected for Action to be taken on security violation, and then, in the MAC Configuration section, make sure only Enable MAC Move is selected.
Step 8: Give the deployment job a description in the Job Description field, and then click Finish to submit the job. Click OK .
Tech Tip
You can review the CLI commands that will be pushed to the switch by clicking Preview CLI .
Step 7: Click Next . Identity configuration is complete.
Next, you must create a deployment job in order to deliver the configuration to the switch.
February 2012 Series
The global commands added to the switch configuration at the completion of the previous two procedures are as follows.
aaa group server radius ISE-Group
server 10.4.48.41
server 10.4.48.42
aaa authentication dot1x default group ISE-Group aaa authorization network default group ISE-Group aaa authorization configuration default group ISE-Group aaa accounting dot1x default start-stop group ISE-Group authentication mac-move permit dot1x system-auth-control
Deployment Details
15
radius-server host 10.4.48.41
radius-server host 10.4.48.42
radius-server key
[key]
The interface commands added at the completion of this procedure are as follows.
interface
[interface]
authentication host-mode multi-auth
authentication open
authentication order dot1x mab
authentication port-control auto
mab
dot1x pae authenticator
Procedure 5 Disable port security timers
The current Cisco SBA design incorporates the use of port security to provide a level of security and prevent rogue devices from being connected.
However, 802.1X also provides this functionality and there can be conflicts when both are enabled on a port at the same time. This is particularly true of inactivity timers since both port security and 802.1X each have their own set of timers. The conflict causes 802.1X to re-authenticate every time the port security time out is reached. To avoid this issue, port security timers need to be disabled.
Step 1: Connect to the Cisco LMS server by browsing to https://lms.cisco.
local.
Step 2: Mouse over Configuration , and then choose NetConfig under the
Tools heading. This opens the Job Browser.
Step 3: Click Create.
This enables you to configure a new job.
Step 4: Select Port based , and then click Go .
Step 5: Click the + symbol next to the All Devices tree, select the switch you are configuring, and then click Next .
Tech Tip
In this example, only one switch is being configured, but you can select multiple switches to accommodate a large deployment.
The Group Selector allows you to choose switches by predefined groups or by model.
Step 6:
Select
Define an Ad-Hoc Rule
. This brings up a new screen.
Step 7:
For the ad-hoc rule, select
Port for the object type.
Step 8:
From the Variable drop-down menu, choose
Identity_Security_Mode
.
Step 9:
For the Operator, choose
=, and for the Value, select
Monitor
.
Step 10:
Click
Add Rule Expression
, and then click
Next
.
February 2012 Series
Deployment Details
16
Step 11: In the Task Selector, select Adhoc Task , and then click Next .
Step 12: Click Add Instance , and then, in the new window, add the CLI commands necessary to remove the port security configuration.
no switchport port-security aging time no switchport port-security aging type no switchport port-security violation
Step 13: Click Applicable Devices, select the switch to apply this configuration to, click Close , and then click Save .
Step 14: After returning to the Add Tasks window, click Next .
Step 15: Fill in a description for the job, and then click Next to submit the job for immediate deployment.
Step 16: Click Finish , and then click OK when you receive a notice that the job was submitted successfully.
Procedure 6 Configure profiling for the LAN
One of the ways Cisco ISE profiles endpoints is by examining DHCP requests that are sent from the device. In order to forward these requests to the engine, a helper address needs to be configured on the router interface of the network of the host. A helper address takes the broadcast packet and makes it a directed broadcast to the address specified.
Step 1: Connect to the console of the default router for the endpoint.
February 2012 Series
Deployment Details
17
Step 2: At the CLI, enter the following commands.
Router#ena
Router#conf terminal
Router(config)#interface
[interface]
Router(config-if)#ip helper-address
10.4.48.41
Router(config-if)#ip helper-address
10.4.48.42
Router(config-if)#exit
Router(config)#exit
Router#copy running-config startup-config
Process
Enabling Visibility to the Wireless Network
1. Configure 802.1X for wireless endpoints
2. Disable EAP-TLS on Cisco ISE
3. Add ISE as RADIUS Authentication Server
4. Disable the original RADIUS server
5. Add ISE as RADIUS accounting server
6. Add secondary DHCP server on WLC
To authenticate wireless clients, you need to configure the wireless LAN controllers (WLC) to use the new Cisco ISE servers as RADIUS servers for authentication and accounting. The existing entry is disabled so that if there are any issues after moving to Cisco ISE, you can quickly restore the original configuration. Additionally, you configure the WLCs with Cisco ISE as a secondary DHCP server so that profiling information can be obtained from the DHCP requests from these clients.
Procedure 1 Configure 802.1X for wireless endpoints
To differentiate wireless users in the authentication logs, create a rule to identify when wireless users authenticate.
Step 1: Navigate to the Authentication Policy tab, mouse over Policy , and then, from the menu, choose Authentication .
Step 2: Click the Actions button for the Default Rule, and then choose
Insert new row above . A new rule, Standard Policy 1, is created.
Step 3: Rename Standard Rule 1 to Wireless-Dot1X . Click the + symbol in the Condition(s) box, and then choose Select Existing Condition from
Library .
Step 4: In the Select Condition pull-down list, click the > symbol next to
Compound Condition .
February 2012 Series
Deployment Details
18
Step 5: Choose Wireless_802.1X, and then click anywhere to continue.
Step 10: Use the default options for this identity source, continue by clicking anywhere in the window, and then click Save .
Step 6: Click the Select Network Access pull-down list, click the > symbol next to Allowed Protocols , and then select Default Network Access .
Step 7: Click the black triangle to the right of the and… on the Wireless-
Dot1X rule. This displays the identity store used for this rule.
Step 8: Click the + symbol next to Set Identity Source .
Step 9: In the Identity Source drop-down list, choose the previously defined
AD server, for example. AD1.
Procedure 2 Disable EAP-TLS on Cisco ISE
For wireless deployments that aren’t currently using digital certificates, you need to disable EAP-TLS to allow clients to log in. You will be deploying digital certificates in a later phase of this deployment.
Step 1: On the menu bar, mouse over Policy , and then, from the Policy
Elements section of the menu, choose Results .
Step 2: In the left pane, double-click Authentication.
This expands the options.
Step 3: Double-click Allowed Protocols , and then select Default Network
Access .
February 2012 Series
Deployment Details
19
Step 4: Clear the global Allow EAP-TLS check box and, under the PEAP settings, clear the Allow EAP-TLS check box, and then click Save .
Step 6: Next to Management, clear the Enable box, and then click Apply .
Procedure 3 Add ISE as RADIUS Authentication Server
Perform this procedure for every wireless LAN controller (WLC) in the architecture with the exception of the guest WLC in the demilitarized zone
(DMZ).
Step 1: Navigate to the WLC console by browsing to https://wlc1.cisco.local.
Step 2: On the menu bar, click Security .
Step 3: In the left pane, under the RADIUS section, click Authentication .
Step 4: Click New.
A new server is added.
Step 5: Enter 10.4.48.41
for the IP address of the new server and your
RADIUS shared secret.
Step 7:
Repeat Steps 4 through 6 to add the secondary engine, 10.4.48.42,
to the WLC configuration.
Procedure 4 Disable the original RADIUS server
After adding Cisco ISE as a RADIUS server, disable the current RADIUS server in use. By disabling the server instead of deleting it, you can easily switch back if needed. Perform this procedure for every wireless LAN controller (WLC) in the architecture with the exception of the guest WLC in the DMZ.
Step 1: On the RADIUS Authentication Servers screen, click the Server
Index of the original RADIUS server, and then, for Server Status , select
Disabled . Click Apply .
February 2012 Series
Deployment Details
20
Step 2: On the RADIUS Authentication Servers screen, click Apply .
Step 5:
Repeat Step 4 to add the secondary engine, 10.4.48.42, to the WLC
configuration.
Step 6: On the RADIUS Accounting Servers screen, click the Server Index of the original RADIUS server, and then, for Server Status, select Disabled .
Click Apply .
Step 7: On the RADIUS Accounting Servers screen, click Apply .
Procedure 5 Add ISE as RADIUS accounting server
Perform this procedure for every wireless LAN controller (WLC) in the architecture, with the exception of the guest WLC in the DMZ.
Step 1: On the menu bar, click Security .
Step 2: In the left pane, under the RADIUS section, click Accounting .
Step 3: Click New.
This adds a new server.
Step 4: Enter 10.4.48.41
for the IP address of the new server and your
RADIUS shared secret, and then click Apply.
Procedure 6 Add secondary DHCP server on WLC
You need to add a secondary DHCP server to the WLC configuration in order to send DHCP requests to the engine for endpoint profiling.
Step 1:
On the WLC, navigate to
Controller > Interfaces
. Select the interface for the clients you wish to monitor.
Step 2:
In the DHCP Information section, add the Cisco ISE server as the
Secondary DHCP Server, and then click
Apply
.
February 2012 Series
Deployment Details
21
Step 3: When the warning appears with a message about the WLANs needing to be disabled, click OK .
Step 4: Click Save Configuration , and then click OK .
The network infrastructure is now enabled for monitoring the network to determine what types of devices are connecting. Additionally, authentication using ISE was enabled for the wireless network. This is a good place in the deployment to test the deployment and monitor network access. Some organizations may not need to implement the next phase and choose to stop here.
Process
Deploying digital certificates
1. Install certificate authority
2. Install trusted root certificate for domain
3. Install trusted root on AD server
4. Request a certificate for ISE from the CA
5. Download CA root certificate
7. Install trusted root certificate in ISE
8. Install local certificate in ISE
9. Delete old certificate and request
In the next phase of deployment, you configure the infrastructure to support the use of digital certificates for user and machine authentication. Using digital certificates when deploying 802.1X is a Cisco best practice. In this example deployment, you will be deploying digital certificates to Microsoft
Windows XP and Windows 7 endpoints as well as to Apple Mac OS X devices. The certificate authority (CA) you will be using is the one built into
Windows Server 2008 Enterprise and you will enable it on the existing Active
Directory (AD) server.
February 2012 Series
Deployment Details
22
Procedure 1 Install certificate authority
Step 1: Install an enterprise root certificate authority on the AD server.
Tech Tip
Microsoft Windows Server 2008 Active Directory Certificate
Services Step-by-Step Guide: http://technet.microsoft.com/en-us/library/cc772393%28WS.10%29.
aspx
Step 4: Click Download CA Certificate, and then save the certificate file on the AD controller.
Procedure 2 Install trusted root certificate for domain
Install a trusted root certificate on the AD controller to distribute it to the clients so that certificates from the CA server will be trusted.
Step 1: On the CA console, launch a web browser, and then connect to the certificate authority, https://ca.cisco.local/certsrv.
Step 2: Click Download a CA certificate, certificate chain, or CRL .
Step 3: Make sure the current certificate is selected and the DER encoding method is selected.
Step 5:
On the CA console, navigate to
Start > Administrative Tools >
Group Policy Management
.
Step 6:
Expand the
Forest
,
Domain
, local domain, and
Group Policy
Objects
.
February 2012 Series
Deployment Details
23
Step 7: Right-click Default Domain Policy, and then choose Edit .
Step 8: Navigate to Computer Configuration > Policies > Windows
Settings > Security Settings > Public Key Policies, right-click Trusted
Root Certification Authorities, and then choose Import . The Certificate
Import Wizard launches.
Step 9:
Click
Next
.
February 2012 Series
Deployment Details
24
Step 10: Click Browse
, locate the trusted root certificate saved in Step 4
and then click Next .
Procedure 3 Install trusted root on AD server
In addition to installing the trusted root certificate on the AD server to be distributed to workstations, you need to install it on the AD server directly. A
GPO update takes care of this automatically. In this procedure, you will force the update to run immediately.
Step 1: On the AD console, navigate to Start > Run .
Step 2: Type cmd , and then press Enter to open a command window.
Step 3: Type gpupdate . The group policy updates.
Step 11: Place the certificate in the Trusted Root Certification Authorities certificate store, and then click Next .
Step 12: Click Finish.
The certificate imports.
Step 13: Click OK .
Procedure 4 Request a certificate for ISE from the CA
In order to obtain a certificate from the CA, Cisco ISE needs to generate a signing request that will be used by the CA to generate a certificate.
Step 1:
Connect to https://ise-1.cisco.local.
Step 2:
Mouse over
Administration
, and then, from the System section of the menu, choose
Certificates
.
Step 3:
Under Certificate Operations, select
Local Certificates
.
February 2012 Series
Deployment Details
25
Step 4: Click Add, and then choose Generate Certificate Signing
Request .
Step 5:
Enter the fully qualified domain name (FQDN) of the Cisco ISE server in the Certificate Subject field after the “CN=”, and then click
Submit
.
Procedure 5 Download CA root certificate
Step 1: Browse to https://ca.cisco.local/certsrv.
Step 2: Click Download a CA certificate, certificate chain, or CRL .
Step 3: Make sure the current certificate is selected and the DER encoding method is selected.
Step 4: Click Download CA Certificate, and then save the certificate file on the local machine.
Step 6: Click OK. This acknowledges the certificate was generated successfully.
Step 7: Click Certificate Signing Requests , select the check box next to the new request, and then click Export .
Step 8: Save the file to your local machine. You will use this file to generate a certificate on the CA for Cisco ISE.
Procedure 6 Issue certificate for ISE
Step 1: Click Home. The CA’s home screen displays.
Step 2: Click Request a certificate .
Step 3: Click advanced certificate request .
Step 4: Open the certificate file saved in Procedure 4, “Request a certificate for ISE from the CA,” in a text editor, such as Notepad. Select all the text and copy it to the clipboard.
February 2012 Series
Deployment Details
26
Step 5: Paste the contents into the text box in the Saved Request section of the certificate request that is open in the browser.
Step 6: From the Certificate Template drop-down list, choose Web Server , and then click Submit .
Step 3: Click Browse, and then locate the root CA certificate saved in
Procedure 5, “Download CA root certificate.”
Step 4: Select Trust for client authentication , and then click Submit .
Step 7: Select DER encoded , and then click Download certificate.
The certificate saves to your local machine.
Procedure 7 Install trusted root certificate in ISE
Step 1: In the Cisco ISE interface, mouse over Administration , and then, from the System section of the menu, choose Certificates .
Step 2: Click Certificate Authority Certificates, and then click Import .
Procedure 8 Install local certificate in ISE
Step 1: In the Cisco ISE interface, mouse over Administration , and then, from the System section of the menu, choose Certificates .
Step 2: Click Local Certificates .
Step 3: Click Add, and then choose Bind CA Certificate .
Step 4: Click Browse
and locate the certificate saved from Step 1, “Issue
certificate for ISE.”
February 2012 Series
Deployment Details
27
Step 5: In the Protocol section, select both the EAP and Management
Interface check boxes. When you receive a warning that checking the
Management Interface box will require the Cisco ISE appliance to restart, click OK , and then click Submit .
Step 3: Select the box next to the self-signed certificate. This is the certificate issued by the Cisco ISE appliance and not the certificate issued by the
CA that was just imported.
Step 4: Click Delete, and then click OK .
Step 5: Click Certificate Signing Requests .
Step 6: Select the box next to the certificate signing request that was created in Procedure 4, “Request a certificate for ISE from the CA.”
Step 6: When you receive a warning that the Cisco ISE appliance will restart, click OK
Procedure 9 Delete old certificate and request
Now that you have imported the local certificate into Cisco ISE, you need to delete the old self-signed certificate as well as the certificate signing request generated previously.
Step 1: In the Cisco ISE interface, mouse over Administration , and then, in the System section, choose Certificates .
Step 2: Click Local Certificates .
Step 7: Click Delete, and then click OK .
February 2012 Series
Deployment Details
28
Process
Enable 802.1X authentication
You will configure ISE policies to support 802.1X authentication using digital certificates for both wired and wireless users.
Procedure 1 Create ISE policies
An authentication profile is used to determine how a certificate will be used for authentication.
Step 1:
In Cisco ISE, mouse over
Administration
, and then, in the Identity
Management section, choose
External Identity Sources
.
Step 2:
In the left pane, click
Certificate Authentication Profile,
and then click
Add
.
Step 3: Give the profile a meaningful name, and then, from the Principal
Username X509 Attribute drop-down list, choose Subject Alternative
Name .
Step 4:
Click
Submit
.
An identity source sequence allows certificates to be used as an identity store and also allows for a backup identity store if a primary identity store is unavailable.
Step 5:
Click
Identity Source Sequences
, and then click
Add
.
Step 6: Give the sequence a meaningful name.
Step 7: In the Certificate Based Authentication section, select Select
Certificate Authentication Profile , and then choose the profile created previously.
Step 8: In the Authentication Search List section, double-click the AD server from the Available list to move it to the Selected list.
February 2012 Series
Deployment Details
29
Step 9: In the Advanced Search List Settings section, select Treat as if the user was not found and proceed to the next store in the sequence .
Step 4: In the Identity Store drop-down list, choose the identity source sequence created in Procedure 1, “Create ISE policies,” use the default options for this identity source, and then click anywhere in the window to continue.
Step 10: Click Submit .
Procedure 2 Enable certificates
Now that you have created a certificate authentication profile and identity source sequence for digital certificates, you need to enable the 802.1X authentication policies for both wired and wireless users.
Step 1: Mouse over Policy , and then, from the drop-down menu, choose
Authentication .
Step 2: Click the black triangle to the right of the and… of the Wired-Dot1X rule. This brings up the identity store used for this rule.
Step 3: Click the + symbol next to the AD1 identity store entry.
For wireless users, you should modify the authentication policy to first check if the client is using EAP-TLS and then, if not, to allow them to use an authentication method like PEAP that uses a user name and password for credentials. This allows users who haven’t gotten certificates yet to still access the network. Once they connect to the network, Windows clients will get their certificates pushed to them and other endpoints can manually obtain a certificate.
Step 5: Click the black triangle to the right of the and… of the Wireless-
Dot1X rule. This brings up the identity store used for this rule.
February 2012 Series
Deployment Details
30
Step 6: In the Actions drop-down list next to the Default rule, choose Insert new rule above .
Step 11: In the second drop-down list, choose Equals, and in the last dropdown list, choose EAP-TLS , and then click OK .
Step 7:
Give the rule a name, and then open the expression builder by clicking the symbol next to the
Enter Condition
box.
Step 8:
Click
Create New Condition (Advance Option)
.
Step 9:
In the Expression drop-down list, click the arrow next to
Select
Attribute.
Step 10:
Click the arrow next to Network Access, and then select
EapAuthentication
.
Step 12: Click the + symbol next to Internal Users.
Step 13: In the Identity Store drop-down list, choose the identity source sequence created in Procedure 1, “Create ISE policies,” use the default options for this identity source, and then click anywhere in the window to continue.
Step 14: Click Save .
February 2012 Series
Deployment Details
31
Procedure 3 Enable EAP-TLS
In a previous section, you disabled EAP-TLS. Now that you are using digital certificates, you need to re-enable it.
Step 1: On the menu bar, mouse over Policy, and then, in the Policy
Elements section, choose Results .
Step 2: In the left pane, double-click Authentication. This expands the options.
Step 3: Double-click Allowed Protocols , and then choose Default Network
Access .
Step 4: Select the global Allow EAP-TLS check box and, under the PEAP settings, select the Allow EAP-TLS check box, and then click Save .
Process
Configure Group Policy Objects
1. Create template for workstations
2. Create template for user auto-enrollment
3. Configure GPOs for wired endpoints
4. Configure GPOs for wireless endpoints
In this deployment you will be using Group Policy Objects (GPOs) to distribute certificates and to configure the native 802.1X supplicant for
Windows XP and later endpoints that are members of the domain. Machine certificates are distributed when the machine joins the domain and user certificates are deployed to the endpoint where the user logs in to the domain. The steps in this example deployment describe how to edit the
Default Domain Policy so that it will apply to all users but you could create a new policy object and apply it to a subset of users if you prefer.
Procedure 1 Create template for workstations
You need to create a certificate template on the CA to be used to distribute machine certificates to workstations that join the Active Directory (AD) domain.
Step 1:
On the CA console, navigate to
Start > Administrative Tools >
Certification Authority
.
February 2012 Series
Deployment Details
32
Step 2: Expand the CA server, right-click Certificate Templates, and then choose Manage . The Certificate Templates Console opens.
Step 7: Select Requests must use one of the following CSPs and
Microsoft Enhanced Cryptographic Provider v1.0
, and then click OK .
Step 3:
Right-click the Computer template, and then choose
Duplicate
Template
.
Step 4:
For compatibility, make sure that
Windows 2003 Server Enterprise is selected.
Step 5:
In the template properties window, click the
General
tab, and then give the template a name.
Step 6:
On the Request Handling tab, select
Allow private key to be exported,
and then click
CSPs
.
February 2012 Series
Deployment Details
33
Step 8: On the Security tab, click Domain Computers, and then make sure
Allow is selected for both Enroll and Autoenroll .
Step 11: In the Certificate Authority console, right-click Certificate
Templates , and then choose New > Certificate Template to Issue .
Step 9: Use the defaults for the remaining tabs, and then click OK .
Step 10: Close the Certificate Templates Console.
February 2012 Series
Deployment Details
34
Step 12: Choose the previously defined template, and then click OK .
Procedure 2 Create template for user auto-enrollment
This deployment uses Group Policy Objects (GPOs) to have domain users auto-enroll to obtain a certificate when they log in to the domain. You need to create a certificate template for these users to enable auto-enrollment.
Step 1: On the CA console, navigate to Start > Administrative Tools >
Certification Authority .
Step 2: Expand the CA server, right-click Certificate Templates, and then choose Manage . The Certificate Templates Console opens.
When machines join the domain or when the GPO policy is refreshed (the default period is 90 minutes), the machine receives a machine certificate to allow for 802.1X machine authentication.
February 2012 Series
Step 3:
Right-click the User template, and then choose
Duplicate
Template
.
Step 4:
For compatibility with Windows XP, make sure that
Windows 2003
Server Enterprise
is selected.
Step 5:
In the template properties window, click the
General
tab, and then give the template a name.
Deployment Details
35
Step 6: On the Request Handling tab, select Allow private key to be exported , make sure Enroll subject without requiring any user input is selected, and then click CSPs .
Step 7: Select Requests must use one of the following CSPs and
Microsoft Enhanced Cryptographic Provider v1.0
, and then click OK .
Step 8: On the Security tab, click Domain Users , and then make sure Allow is selected for Read , Enroll, and Autoenroll .
Step 9: Use the defaults for the remaining tabs, and then click OK .
Step 10: Close the Certificate Templates Console.
Step 11: In the Certificate Authority console, right-click Certificate
Templates , and then choose New > Certificate Template to Issue .
February 2012 Series
Deployment Details
36
Step 12: Choose the previously defined template, and then click OK .
Step 5: Right-click Wired Network (IEEE 802.3e) Policies, and then choose Create a New Wired Network Policy for Windows Vista and Later
Releases .
Users will have a certificate pushed to them the next time they log in to the domain or after the GPO policy is refreshed. If the user logs in to multiple endpoints, the certificate is deployed to each of them.
Procedure 3 Configure GPOs for wired endpoints
This deployment uses GPOs to configure the 802.1X supplicant on wired endpoints running Windows XP SP3 and higher.
Step 1: On the CA console, navigate to Start > Administrative Tools >
Group Policy Management .
Step 2: Expand the Forest , Domain , local domain , and Group Policy
Objects .
Step 3: Right-click Default Domain Policy.
The Group Policy Management
Editor opens.
Step 4: In the Group Policy Management Editor, navigate to Computer
Configuration > Policies > Windows Settings > Security Settings .
February 2012 Series
Step 6:
On the General tab, give the policy a name and description, and then make sure
Use Windows Wired Auto Config service for clients
is selected.
Step 7:
On the Security tab, make sure
Enable of IEEE 802.1X authentication for network access
is selected.
Step 8:
In the network authentication method drop-down list, choose
Microsoft: Smart Card or other certificate
.
Step 9:
In the Authentication Mode drop-down list, choose
User or computer authentication
.
Step 10:
Click
Properties
.
Step 11:
Make sure the
Use a certificate on this computer
option is selected, and then make sure the
Use simple certificate selection
and
Validate server certificate
check boxes are selected.
Deployment Details
37
Step 12: In the Trusted Root Certification Authorities list, select the check box next to the root certificate for the CA.
Step 13: Click OK , click Apply, and then click OK again.
Procedure 4 Configure GPOs for wireless endpoints
This deployment uses GPOs to configure the 802.1X supplicant for wireless endpoints running Windows XP SP3 and higher.
Step 1: On the CA console, navigate to Start > Administrative Tools >
Group Policy Management .
Step 2: Expand the Forest , Domain , local domain , and Group Policy
Objects .
Step 3: Right-click Default Domain Policy . The Group Policy Management
Editor opens.
Step 4: In the Group Policy Management Editor, navigate to Computer
Configuration > Policies > Windows Settings > Security Settings .
Step 5: Right-click Wireless Network (IEEE 802.11) Policies, and then choose Create a New Wireless Network Policy for Windows Vista and
Later Releases .
Step 6: On the General tab, give the policy a name and description, and then make sure Use Windows WLAN AutoConfig service for clients is selected.
February 2012 Series
Deployment Details
38
Step 7: Click Add, and then choose Infrastructure .
Step 12: In the Authentication Mode drop-down list, choose User or
Computer authentication .
Step 8: Give the profile a name, enter the name of the SSID for the wireless network, and then click Add .
Step 9: Click the Security tab.
Step 10: In the Authentication drop-down list, choose WPA2-Enterprise, and then in the Encryption drop-down list, choose AES .
Step 11: In the Select a network authentication method drop-down list, choose Microsoft: Smart Card or other certificate .
February 2012 Series
Step 13: Click Properties .
Step 14: Make sure the Use a certificate on this computer option is selected, and then make sure the Use simple certificate selection and
Validate server certificate check boxes are selected.
Step 15: In the Trusted Root Certification Authorities list, select the box next to the root certificate for the CA.
Step 16: Click OK , and then click OK again.
Step 17: Click Apply, and then click OK .
You also need to create a policy for Windows XP clients.
Deployment Details
39
Step 18: Right-click Wireless Network (IEEE 802.11) Policies, and then choose Create a New Windows XP Policy .
Step 20: In the Networks to access list, choose Any available network
(access point preferred) .
Step 19: On the General tab, give the policy a name and description, and then make sure Use Windows WLAN AutoConfig service for clients is selected.
February 2012 Series
Step 21:
Click the
Preferred Networks
tab.
Step 22:
Click
Add,
and then select
Infrastructure
.
Step 23:
Enter the SSID for the network and give a description.
Step 24:
Select
WPA2
for Authentication and
AES
for Encryption.
Step 25:
Click the
IEEE 802.1X
tab.
Step 26:
In the EAP type list, choose
Microsoft: Smart Card or other certificate
.
Deployment Details
40
Step 27: In the Authentication Mode list, choose User or Computer authentication .
Step 30: In the Trusted Root Certification Authorities list, select the box next to the root certificate for the CA.
Step 28:
Click
Settings
.
Step 29:
Make sure the
Use a certificate on this computer
option is selected, and then make sure the
Use simple certificate selection
and
Validate server certificate
check boxes are selected.
Step 31: Click OK .
Step 32: Click Apply , and then click OK . The Profile Properties window displays.
February 2012 Series
Deployment Details
41
Step 33: Click Apply, and then click OK .
At this point, all endpoints running Windows XP SP3 and later will have a
802.1X supplicant configuration pushed to them the next time they log in to the domain or after the GPO policy is refreshed.
Process
Deploy AnyConnect on Windows endpoints
Cisco AnyConnect Secure Mobility Client 3.0 can be used as an 802.1X supplicant on Windows endpoints using the Network Access Manager module.
In this example deployment, the Network Access Manager is configured with both wired and wireless profiles using digital certificates.
Procedure 1 Install AnyConnect
To use Cisco AnyConnect Secure Mobility Client 3.0 as your 802.1X supplicant on Windows endpoints, you need to download the latest version from Cisco.com along with the Profile Editor. The client is distributed as an
ISO image and will need to either be burned to a disk or mounted as a disk image by using a utility that provides this function. You need to be logged in as an administrator to install AnyConnect Secure Mobility Client.
Reader Tip
The latest Cisco AnyConnect Secure Mobility client and Profile
Editor can be downloaded from: http://www.cisco.com/cisco/software/release.html?mdfid=28300018
5&flowid=17001&softwareid=282364313&release=3.0.5075&relind=A
VAILABLE&rellifecycle=&reltype=latest
Step 1: Start the installer for the AnyConnect Secure Mobility Client by launching the Setup program on the disk.
February 2012 Series
Deployment Details
42
Step 2: Select AnyConnect Diagnostic and Reporting Tool and
AnyConnect Network Access Manager check boxes.
, and then clear all of the other
Step 3: Click Install Selected, verify the components selected to install, and then click OK .
Step 4: Click Accept to accept the license agreement.
Step 5: After the installation completes, click OK . You may be asked to restart the computer.
Procedure 2 Install Profile Editor
Step 1: Locate the Profile Editor Installer downloaded previously, and then double-click it. The installation process starts.
The installation requires Java Runtime Environment 1.6 or higher. If you don’t have it installed, you will be prompted to install it.
Step 2: If you are prompted to install Java Runtime Environment 1.6 or higher, click Next . This installs it.
Step 3: Click Next.
The installation of Profile Editor continues.
Step 4: Click Typical, and then click Install .
Step 5: Click Finish . The installation completes.
Procedure 3 Create wired profile
Step 1: Launch the Profile Editor by navigating to Start > All Programs >
Cisco > Cisco AnyConnect Profiler Editor > Network Access Manager
Profile Editor .
Step 2: From the File menu, choose Open, and select C:\ProgramData\
Cisco\Cisco AnyConnect Secure Mobility Client\Network Access
Manager\system\configuration.xml
.
Step 3: Click Networks.
February 2012 Series
Deployment Details
43
Step 4: Select the wired profile, and then click Edit .
Step 11: Select EAP-TLS as the user authentication method, and then click
Next .
Step 12: Enter an unprotected identity pattern for user identity. In this deployment, use [username]@[domain] .
Step 13: In the User Credentials section, select Prompt for Credentials, and then select Remember while User is Logged On .
Step 14: Select Smart Card or OS certificates as the certificate source, and then click Done .
Step 5:
Enter a name for the profile, and then click
Next
.
Step 6:
Select
Authenticating Network,
and then click
Next
.
Step 7:
Select
Machine and User Authentication,
and then click
Next
.
Step 8:
Select
EAP-TLS
as the machine authentication method, and then click
Next
.
Step 9:
Enter an unprotected identity pattern for machine identity. In this deployment, use host.[domain]
.
Step 10:
Click
Next
.
February 2012 Series
Deployment Details
44
Procedure 4 Create wireless profile
Step 1: Click Add . This creates a new wireless profile.
Step 2: Enter a name for the profile, and then, for group membership, select
In all groups (Global) .
Step 3: In the Network Media section, select Wi-Fi (wireless) Network, enter the SSID of the wireless network, and then click Next .
Step 4: Select Authenticating Network, choose WPA2 Enterprise (AES) as the association mode, and then click Next .
Step 5: Select Machine and User Authentication, and then click Next .
Step 6: Select EAP-TLS as the machine authentication method, and then click Next .
February 2012 Series
Step 7: Enter an unprotected identity pattern for machine identity. In this deployment, use host.[domain] .
Step 8: Click Next .
Step 9: Select EAP-TLS as the user authentication method, and then click
Next .
Step 10: Enter an unprotected identity pattern for user identity. In this deployment, use [username]@[domain] .
Step 11: In the User Credentials section, select Prompt for Credentials, and then select Remember while User is Logged On .
Step 12: Select Smart Card or OS certificates as the certificate source, and then click Done .
Step 13: From the File menu, choose Save . This updates the configuration file.
Tech Tip
To deploy the Cisco AnyConnect Secure Mobility Client to multiple workstations with the same policy, you can create a customized installation package. You need to copy all the files from the installation disk to a folder on the hard drive, for example,
C:\AnyConnect. Then, follow the procedure above to edit the profile.
Copy the file (C:\ProgramData\Cisco\Cisco AnyConnect Secure
Mobility Client\Network Access Manager\system\configuration.xml) to C:\AnyConnect\Profiles\nam\configuration.xml.
Copy the contents of C:\AnyConnect to some form of removable media, for instance, CD, DVD, USB drive, etc.
You can then take this new installer package and run the installation on a workstation. The custom configuration file is loaded and ready for use.
At this point, all Windows endpoints now have certificates deployed and are enabled to use 802.1X authentication. On the wireless network, any device that doesn’t have a certificate uses PEAP to gain access to the network.
Deployment Details
45
Monitor mode is running on the wired network, so endpoints that aren’t configured for 802.1X still get access by using MAC Authentication Bypass
(MAB).
Process
Configure Mac workstations for 802.1X authentication
1. Install root certificate on Mac OS X
3. Configure Mac OS X supplicant
If you have Apple Mac endpoints, you have to manually obtain a certificate and configure 802.1X authentication. The example deployment shows how you would do this for Mac OS X 10.6.
Procedure 1 Install root certificate on Mac OS X
To install a trusted root certificate on Mac OS X 10.6, you need to manually request the certificate from the CA and install the certificate in the keychain.
Step 1:
On the Mac, browse to the CA at http://ca.cisco.local/certsrv.
Step 2:
Make sure the current certificate is selected and the
DER
encoding method is selected.
Step 3:
Click
Download CA Certificate,
and then save the certificate file.
Step 4:
Locate the certificate file, and then double-click it. This launches the Keychain Access utility.
Step 5: Click Always Trust .
Tech Tip
You may be prompted for credentials of a user with permission to change the certificate trust settings.
Procedure 2 Request user certificate
Next, you need to obtain a user certificate for the Mac. To do this, first you need to generate a certificate signing request, and then request the certificate from the CA.
February 2012 Series
Deployment Details
46
Step 1: In the Keychain Access utility, from the Keychain Access menu, choose Certificate Assistant > Request a Certificate from a Certificate
Authority .
Step 2: In the Certificate Assistant, enter your email address and common name (typically the user’s first and last names), select Saved to Disk , and then click Continue .
Step 5: On the Mac, browse to http://ca.cisco.local/certsrv. When you authenticate to the CA, be sure to authenticate as the user for which you wish to obtain a certificate.
Tech Tip
If you still have the browser window open from when you downloaded the trusted root certificate, click Home in the upper right corner to go back to the main page of the CA.
Step 6:
Click
Request a certificate
.
Step 7:
Click advanced certificate request
.
Step 8:
Open the certificate request file saved in Step 3 in a text editor,
such as TextEdit, select all the text, and then copy it to the clipboard.
Step 9:
Paste the contents into the text box in the Saved Request section of the certificate request that is open in the browser.
Step 10:
In the Certificate Template drop-down list, choose
User,
and then click
Submit
.
Step 3:
Enter a file name and location, and then click
Save
.
Step 4:
Click
Done
.
February 2012 Series
Step 11: Select DER encoded, and then click Download certificate . This saves the certificate.
Deployment Details
47
Step 12: Locate the saved certificate in Finder, and then double-click it to import it into the Keychain Access utility.
Step 13: In the Keychain drop-down list, choose login , and then click Add .
Step 4: Click the + symbol and select Add User Profile .
Procedure 3 Configure Mac OS X supplicant
Step 1:
On your Mac, launch System Preferences.
Step 2:
Double-click
Network
.
Step 3:
Click
Advanced,
and then click the
802.1X
tab.
Step 5: Give the profile a name, and then enter your user name and password.
Step 6: In the Authentication section, select TLS , and then click Configure .
Step 7: Select the certificate for this user, and then click Continue .
February 2012 Series
Deployment Details
48
Step 8: For wireless connections, choose the wireless network from the list, and then choose WPA2 Enterprise for the Security Type.
Step 9:
Click
OK
, click
Apply
, and then exit System Preferences.
Repeat this process for all Mac OS X endpoints to deploy certificates and to enable 802.1X authentication. On the wireless network, any device that doesn’t have a certificate uses PEAP to gain access to the network. Monitor mode is running on the wired network, so endpoints that aren’t configured for 802.1X still get access by using MAC Authentication Bypass (MAB).
Process
Monitoring
4. Examining the authentication log
5. Create custom authentication reports
The configuration of the network infrastructure is complete. Now it’s time to answer the what/when/where/who questions regarding network access by using the reporting functionality of Cisco ISE to gain a better understanding of current activity on the network .
Cisco ISE is now configured to authenticate users and to profile endpoints based on RADIUS and DHCP information. The reporting capabilities of
Cisco ISE allow you to determine what type of device is connecting to your network, when it connects, and where it connects from. Also, you will know who is connecting to your network and what authentication method was used.
February 2012 Series
Deployment Details
49
Procedure 1 Cisco ISE Dashboard
The first place to view this information is on the Cisco ISE Home Dashboard.
It gives a summary view of the health status of the servers in the group, how devices are authenticating, and what types of devices have been profiled.
Step 1: On the menu bar, click Home . Each section can be expanded by clicking the upper-right corner.
Procedure 2 Configure identity groups
Cisco ISE has more in-depth reporting options to give more details on the devices connecting to the network. To help identify the endpoints, you can use identity groups to classify profiled endpoints and to generate reports.
The example below describes how to do this for an Apple iPad. The procedure for other types of devices is similar.
Step 1: In the menu bar, mouse over Policy , and then choose Profiling .
Step 2: Click Apple-iPad.
This enables you to edit this policy.
Step 3: Select Create Matching Identity Group , and then click Save .
February 2012 Series
You can repeat these steps for other endpoint types as needed. You can also investigate the rules used to profile the endpoint to understand the process. In the case of the Apple iPad, Cisco ISE uses two rules. One is based on DHCP information, and the other is based on HTTP.
Deployment Details
50
Procedure 3 Add a custom profile
Although there are many pre-defined profiles, you may find that a device you want to profile doesn’t have an existing profile. You can create a new one using unique characteristics of the device. Review some of the existing profiles to get an idea of the options and methods available to you for device profiling.
The example below creates a profile for the Cisco Cius using information obtained from the device’s DHCP request.
Step 1: Connect to https://ise-1.cisco.local.
Step 2: Mouse over Policy , and then, from the drop-down menu, and choose Profiling .
Step 3: Click Create .
Step 4: Give the policy the name “Cisco-Cius” and a description.
Step 5: In the rules section, next to Conditions, click the + symbol, and then click Create New Condition (Advance Option) .
Step 6: In the Expression drop-down list, next to DHCP, click the > symbol, and then select dhcp-class-identifier .
Step 7: In the second drop-down list, choose CONTAINS, and then, in the final box, enter Cisco Cius .
Step 8: Choose Certainty Factor Increases, set the value to 20 , and then click Submit .
Procedure 4 Examining the authentication log
Step 1:
On the menu bar, mouse over
Monitor
, and then choose
Authentications
. The authentication log displays. The default option is to display the last 20 records from the last 24 hours.
For devices that authenticated via MAB, the MAC address of the client is listed as the user name and the endpoint. For device that authenticated via
RADIUS over wireless or VPN, the user name is displayed.
If the device was able to be profiled, that information is displayed.
February 2012 Series
Deployment Details
51
Step 2: In the details column of the MAB record, click the “paper with magnifying glass” icon. This displays detailed authentication information for the record.
In the Authentication Summary section, the network device lists the IP address and the port of the switch that the endpoint is connected to.
You can find additional details, such as the Identity Group and Identity
Policy, in the Authentication Details section.
Similar data can be found for endpoints that have authenticated with
RADIUS. The user name is displayed in these records as well the EAP method used.
February 2012 Series
Deployment Details
52
Procedure 5 Create custom authentication reports
The default authentication log view is limited to displaying only the most recent entries. To get in-depth reporting, you need to create a custom report.
Step 1: On the menu bar, mouse over Monitor , and then, in the Reports section, choose Catalog .
Step 2: In the left pane, select AAA Protocol .
Step 3: Select RADIUS Authentication .
Step 4: Click Run . Different time ranges for producing the default report are displayed. For time ranges not listed, choose Query and Run .
Figure 2 - RADIUS report parameters
Step 5:
If you choose
Query and Run
, all the parameters available for the report display. After choosing the parameters you want, click
Run
to generate the report.
Procedure 6 Identify endpoints
Using information gleaned from the RADIUS and DHCP requests, Cisco ISE can identify what types of devices are connecting to the network. This can assist in determining network security policy based on the type of device that is in use.
Step 1: On the menu bar, mouse over Monitor , and then, in the Reports section, choose Catalog .
Step 2: In the left pane, click Endpoint . This displays the available endpoint reports.
Step 3: Select Endpoint Profiler Summary , and then click Run .
February 2012 Series
Deployment Details
53
Step 4: Select the desired time period to run the report.
Figure 4 - Endpoint Details
Step 5:
Once the report is generated, you can view the details of a profiled endpoint by clicking the magnifying glass icon.
The details given in the summary section are the MAC address, the endpoint policy, and the identity group for the endpoint. Additional details such as IP address and network access devices are available in the Endpoint Details section. For wireless and remote access VPN endpoints that authenticated with RADIUS, the user name is also listed.
Figure 3 - Endpoint profile summary
February 2012 Series
Deployment Details
54
Procedure 7 Create device type reports
You can create reports to identify specific devices based on the identity groups configured previously. This example uses the group created to identify Apple iPads.
Step 1: On the menu bar, mouse over Monitor , and then, in the Reports section, choose Catalog .
Step 2: In the left pane, click AAA Protocol .
Step 3: Select RADIUS Authentication .
Step 4: Click Run, and choose Query and Run .
Step 7: Select the group Profiled:AppleiPad , and then click Apply .
Step 8:
Select a time range for the report, and then click
Run.
The report generates.
Figure 5 - Sample report
Step 5: Click Select next to the Identity Group field for the identity group you want to query. A search window appears.
Step 6: Leave the search field empty and click Select to search all groups.
February 2012 Series
Deployment Details
55
Appendix A: Product List
The following products and software versions have been validated for the Cisco Smart Business Architecture.
Functional Area
Network Management
Product
Cisco Identity Services Engine
Virtual Appliance
Part Numbers
ISE-VM-K9=
L-ISE-BSE-2500=
Cisco Identity Services Engine 2500 EndPoint Base License
L-ISE-BSE-3500=
Cisco Identity Services Engine 3500 EndPoint Base License
L-ISE-BSE-5K=
Cisco Identity Services Engine 5000 EndPoint Base License
L-ISE-BSE-10K=
Cisco Identity Services Engine 10000 EndPoint Base License
L-ISE-ADV3Y-2500=
Cisco ISE 2500 EndPoint 3Year Advanced Subscription License
L-ISE-ADV3Y-3500=
Cisco ISE 3500 EndPoint 3Year Advanced Subscription License
L-ISE-ADV3Y-5K=
Cisco ISE 5000 EndPoint 3Year Advanced Subscription License
L-ISE-ADV3Y-10K=
Cisco ISE 10000 EndPoint 3Year Advanced Subscription License
Software Version
1.1.3.659
February 2012 Series
Appendix A: Product List
56
Functional Area
Network Management
Product
Cisco Prime LAN Management
Solution
Part Numbers
LMS-4.1-100-K9
LMS 4.1, networks of up to 100 devices
LMS-4.1-500-K9
LMS 4.1, networks of 100 to 500 devices
LMS-4.1-1K-K9
LMS 4.1, networks of 500 to 1000 devices
Access Layer for PC, phones,
APs, other devices
Catalyst 2960S
Stackable Ethernet 10/100/1000 ports with PoE+ and Stack
Module
LMS-4.1-2.5K-K9
LMS 4.1, networks of 1000 to 2500 devices
WS-C2960S-24PD-L
Catalyst 2960S 24 GigE PoE+, 2 x 10G SFP+ LAN Base
WS-C2960S-48FPD-L
Catalyst 2960S 48 GigE PoE +, 2 x 10G SFP+ LAN Base
WS-C2960S-24PS-L
Catalyst 2960S 24 GigE PoE+, 4 x SFP LAN Base
WS-C2960S-48FPS-L
Catalyst 2960S 48 GigE PoE+, 4 x SFP LAN Base
C2960S-STACK=
Catalyst 2960S Flexstack Stack Module
Software Version
4.1
12.2(58)SE1
February 2012 Series
Appendix A: Product List
57
Functional Area
Access Layer for PC, phones,
APs, other devices
Access Layer for PC, phones,
APs, other devices
Access Layer for PC, phones,
APs, other devices
Product
Catalyst 3560X
Ethernet 10/100/1000 ports with
PoE+ and Uplink Module
Catalyst 3750X
Stackable Ethernet 10/100/1000 ports with PoE+ and Uplink
Module
Catalyst 4507R+E
Dual Supervisors
Dual Power Supplies
Part Numbers
WS-C3560X-24P-S
Catalyst 3750 24 10/100/1000T PoE + and IPB Image
WS-C3560X-48PF-S
Catalyst 3750 48 10/100/1000T Full PoE + and IPB Image
C3KX-NM-1G
Catalyst 3750X 1Gig SFP Uplink Module
C3KX-NM-10G
Catalyst 3750X 10Gig SFP+ Uplink Module
WS-C3750X-24P-S
Catalyst 3750 24 10/100/1000T PoE + and IPB Image
WS-C3750X-48PF-S
Catalyst 3750 48 10/100/1000T Full PoE + and IPB Image
C3KX-NM-1G
Catalyst 3750X 1Gig SFP Uplink Module
C3KX-NM-10G
Catalyst 3750X 10Gig SFP+ Uplink Module
WS-C3750X-24P-S
Catalyst 3750 24 10/100/1000T PoE + and IPB Image
WS-C3750X-48PF-S
Catalyst 3750 48 10/100/1000T Full PoE + and IPB Image
C3KX-NM-1G
Catalyst 3750X 1Gig SFP Uplink Module
C3KX-NM-10G
Catalyst 3750X 10Gig SFP+ Uplink Module
Software Version
12.2(58)SE1
12.2(58)SE1
12.2(54)SG1
February 2012 Series
Appendix A: Product List
58
Functional Area
VPN (Internet Edge 5K)
VPN (Internet Edge 10K)
Wireless LAN
Product
ASA 5510 or ASA 5520 or ASA
5540
Part Numbers
ASA5510-AIP10-SP-K9
ASA5520-AIP20-K9
ASA5540-AIP40-K9
2x ASA 5520 and 500 SSL seats or 2x ASA 5540 and 1000 SSL seats
5508 Wireless LAN Controller
ASA5520-SSL500-K9
ASA5540-SSL1000-K9
AIR-CT5508-100-K9
5508 Wireless LAN Controller with 100 AP license
Software Version
8.4.1
8.4.1
7.0.116.0
February 2012 Series
Appendix A: Product List
59
SMART BUSINESS ARCHITECTURE
Americas Headquarters
Cisco Systems, Inc.
San Jose, CA
Asia Pacific Headquarters
Cisco Systems (USA) Pte. Ltd.
Singapore
Europe Headquarters
Cisco Systems International BV
Amsterdam, The Netherlands
Cisco has more than 200 offices worldwide. Addresses, phone numbers, and fax numbers are listed on the Cisco Website at www.cisco.com/go/offices.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1005R)
B-0000600-1 3/12
* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
