Motherboard
A55BM-A/USB3
E8511
First Edition
July 2013
Copyright © 2013 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from http://support.asus.com/download
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notification to the email address gpl@asus.com, stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).
ii
Contents
Safety information....................................................................................................... iv
About this guide.......................................................................................................... iv
Package contents........................................................................................................ vi
A55BM-A/USB3 specifications summary.................................................................. vi
Product introduction
1.1
Before you proceed....................................................................................... 1-1
1.2
Motherboard overview.................................................................................. 1-2
1.3
Accelerated Processing Unit (APU)............................................................. 1-4
1.4
System memory............................................................................................. 1-7
1.5
Expansion slots........................................................................................... 1-10
1.6
Jumpers....................................................................................................... 1-11
1.7
Connectors................................................................................................... 1-13
1.8
Software support......................................................................................... 1-21
BIOS information
2.1
Managing and updating your BIOS.............................................................. 2-1
2.2
BIOS setup program...................................................................................... 2-5
2.3
My Favorites.................................................................................................. 2-9
2.4
Main menu.................................................................................................... 2-10
2.5
Ai Tweaker menu......................................................................................... 2-11
2.6
Advanced menu........................................................................................... 2-12
2.7
Monitor menu............................................................................................... 2-12
2.8
Boot menu.................................................................................................... 2-13
2.9
Tools menu................................................................................................... 2-14
2.10 Exit menu..................................................................................................... 2-14
Appendices
Notices...................................................................................................................... A-1
ASUS contact information....................................................................................... A-4
iii
Safety information
Electrical safety
•
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
•
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
•
Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
•
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
•
Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
•
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
•
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
•
Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
•
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
•
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
•
Place the product on a stable surface.
•
If you encounter technical problems with the product, contact a qualified service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and configuring the
motherboard.
How this guide is organized
This guide contains the following parts:
•
Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
•
Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
iv
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1.
ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2.
Optional documentation
Your product package may include optional documentation, such as warranty flyers,
that may have been added by your dealer. These documents are not part of the
standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task
IMPORTANT: Instructions that you MUST follow to complete a task..
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text
Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key>
Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3>
If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS A55BM-A/USB3 motherboard
Cables
2 x Serial ATA 3.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD
Support DVD
Documentation
User Guide
If any of the above items is damaged or missing, contact your retailer.
A55BM-A/USB3 specifications summary
APU
AMD® FM2+ Socket for AMD® A-series/Athlon™ Series processors
AMD® Turbo Core Technology 3.0 support
Supports APU up to 4 cores
• Refer to www.asus.com for the AMD® APU support list.
Chipset
AMD® A55 FCH (Hudson D2)
Memory
2 x DDR3 DIMM, max. 32GB, DDR3 2133(O.C.) / 1866 / 1600 / 1333 MHz,
non-ECC un-buffered memory
Dual-channel memory architecture
Supports AMD Memory Profile (AMP) memory
•The maximum 32GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
•When you install a total memory of 4GB capacity or more, Windows® 32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows® 32-bit operating
system.
Graphics
Integrated AMD® Radeon™ HD 7000 / 8000 Series Graphics in the ASeries APU
Supports HDMI with max. resolution 1920 x 1200@60Hz
Supports Dual-link DVI with max. resolution 2560x1600@60Hz
Supports D-Sub with max. resolution 1920x1600@60Hz
AMD® Dual Graphics technology support*
Maximum shared memory of 2G
Supports AMD® Dual Graphics technology
• Refer to http://www.amd.com/us/products/technologies/dual-graphics/
Pages/dual-graphics.aspx#3 for the discrete GPUs which support Dual Graphics
technology.
Expansion slots
1 x PCIe 3.0/2.0 x16 slot*
1 x PCIe 2.0 x1 slots
1 x PCI slot
• PCIe 3.0 is supported by FM2+ processors only.
(continued on the next page)
vi
A55BM-A/USB3 specifications summary
Storage / RAID
AMD® A55 FCH:
-6 x Serial ATA 3.0Gb/s connectors support RAID 0, RAID 1, RAID 10 and
JBOD configurations
LAN
Realtek® 8111G PCIe Gigabit LAN controller
Audio
Realtek® ALC887-VD 8-channel High Definition Audio CODEC
• Use a chassis with HD audio module in the front panel to support an 8-channel
audio output.
USB
AMD® A55 FCH:
- 2 x USB 3.0/2.0/1.1 ports (at the back panel)
-6 x USB 2.0/1.1 ports (4 ports at the mid-board, 2 ports at the back panel)
ASUS unique
features
ASUS 5X Protection
- ASUS motherboards safeguard your PC with 5X Protection: DIGI+VRM,
DRAM Fuse, ESD Guards, High-Quality 5K-Hour Solid Capacitors,
and Stainless Steel Back I/O to ensure the best quality, reliability, and
durability
ASUS Digital Power Design
- Industry-leading digital 3+1 power design
ASUS DRAM Fuse
- Enhanced DRAM overcurrent protection and short circuit damage
prevention
ASUS ESD Guards
- Strong ESD protection for extended component lifespan
ASUS High-Quality 5K-Hour Solid Capacitors
- 2.5x Longer Lifespan with excellent durability
ASUS Stainless Steel Back I/O
- 3x More durable corrosion-resistant coating
ASUS Exclusive Features
- Network iControl
- ASUS USB 3.0 Boost
- ASUS EPU
- ASUS AI Suite III
- ASUS AI Charger+
- ASUS Anti-Surge Protection
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Stylish Heatsink Solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2™
(continued on the next page)
vii
A55BM-A/USB3 specifications summary
Back Panel I/O
ports
1 x PS/2 mouse port (green)
1 x PS/2 keyboard port (purple)
1 x HDMI port
1 x DVI-D port
1 x D-Sub output port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0/1.1 ports
2 x USB 2.0/1.1 ports
8-channel audio I/O ports (3-jack)
Internal I/O
connectors
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
6 x SATA 3.0Gb/s connectors
1 x COM connector
1 x System panel connector
1 x Internal Speaker connector
1 x CPU fan connector (4-pin)
1 x S/PDIF output connector
1 x Chassis fan connector (4-pin)
1 x Front panel audio connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.6,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFreen
BIOS 3, F12 Printscreen function, F3 Shortcut function and ASUS DRAM
SPD (Serial Presence Detect) memory information
Support DVD
Drivers
ASUS Update
ASUS utilities
Anti-Virus software (OEM version)
Operating System
Support
Windows® 8 / 8 64bit
Windows® 7 / 7 64bit
Windows® Vista / Vista 64-bit
Windows® XP
Form factor
uATX form factor: 8.9 in x 7.2 in (22.6 cm x 18.3 cm)
Specifications are subject to change without notice.
viii
Product introduction
1.1
Before you proceed
1
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
•
Unplug the power cord from the wall socket before touching any component.
•
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
•
Hold components by the edges to avoid touching the ICs on them.
•
Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
•
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
Standby Power LED
The motherboard comes with a standby power LED that lights up to indicate that the system
is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down
the system and unplug the power cable before removing or plugging in any motherboard
component. The illustration below shows the location of the onboard LED.
SB_PWR
A55BM-A/USB3
ON
Standby Power
OFF
Powered Off
A55BM-A/USB3 Onboard LED
ASUS A55BM-A/USB3
1-1
1.2
Motherboard overview
Before you install the motherboard, study the configuration of your chassis to ensure that the
motherboard fits into it.
Ensure that you unplug the power cord before installing or removing the motherboard.
Failure to do so can cause you physical injury and damage motherboard components.
1.2.1
Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.2.2
Screw holes
Place six screws into the holes indicated by circles to secure the motherboard to the chassis.
Do not overtighten the screws! Doing so can damage the motherboard.
Place this side towards
the rear of the chassis
A55BM-A/USB3
1-2
Chapter 1: Product introduction
1.2.3
Motherboard layout
1
2
3
4
5
18.3cm(7.2in)
KBMS
CPU_FAN
DIGI
+VRM
ATX12V
CHA_FAN
ASM
1042
AUDIO
22.6cm(8.9in)
EATXPWR
LAN_USB12
KB_USBWB
USB3_12
DDR3 DIMM_B1 (64bit, 240-pin module)
DDR3 DIMM_A1 (64bit, 240-pin module)
SOCKET FM2+
DVI_VGA
HDMI
2
A55BM-A/USB3
6
AMD®
A55
BATTERY
PCIEX1_1
SPEAKER
SB_PWR
F_PANEL
PCI1
ALC
887
COM
SPDIF_OUT
SATA3G_5
Super
I/O
SATA3G_6
PCIEX16
64Mb
BIOS
USBPWF
CLRTC USB56
USB34
SATA3G_1
SATA3G_2
7
SATA3G_4
RTL
8111G
SATA3G_3
8
AAFP
15 14
13
12
11
10
9
7
Connectors/Jumpers/Slots/LED
Page
1. Keyboard power (3-pin KB_USBPWB)
1-12
2. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
1-16
3. AMD FM2+ socket
1-4
4. CPU and chassis fan connectors (4-pin CPU_FAN and 4-pin CHA_FAN)
1-15
5. DDR3 DIMM slots
1-7
6. Speaker connector (4-pin SPEAKER)
1-18
7. SATA 3.0Gb/s connectors (7-pin SATA3G_1~6)
1-17
8. System panel connector (10-1 pin F_PANEL)
1-18
9. USB 2.0 connectors (10-1 pin USB34, USB56)
1-20
10. Clear RTC RAM (3-pin CLRTC)
1-11
11. USB device wake-up (3-pin USBPWF)
1-12
12. Digital audio connector (4-1 pin SPDIF_OUT)
1-19
13. Serial port connector (10-1 pin COM)
1-20
14. Standby power LED (SB_PWR)
1-1
15. Front panel audio connector (10-1 pin AAFP)
1-19
ASUS A55BM-A/USB3
1-3
1.3
Accelerated Processing Unit (APU)
This motherboard comes with an FM2+ socket designed for AMD® A-series accelerated
processors with AMD® Radeon™ HD 7000/8000 series graphics.
A55BM-A/USB3
A55BM-A/USB3 CPU socket FM2+
Ensure that you use an APU designed for the FM2+ socket. The APU fits in only one
correct orientation. DO NOT force the APU into the socket to prevent bending the pins and
damaging the APU!
1.3.1
1
1-4
Installing the APU
2
Chapter 1: Product introduction
3
1.3.2
4
APU heatsink and fan assembly installation
Apply the Thermal Interface Material
to the APU heatsink and APU before
you install the heatsink and fan if
necessary.
To install the APU heatsink and fan assembly
1
ASUS A55BM-A/USB3
2
1-5
3
4
5
To uninstall the APU heatsink and fan assembly
1
4
1-6
3
2
5
Chapter 1: Product introduction
1.4
System memory
1.4.1
Overview
The motherboard comes with two Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched
differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for
better performance with less power consumption.
DIMM_A1
DIMM_B1
The figure illustrates the location of the DDR3 DIMM sockets:
Channel
Sockets
Channel A
DIMM_A1
Channel B
DIMM_B1
A55BM-A/USB3
A55BM-A/USB3 240-pin DDR3 DIMM sockets
ASUS A55BM-A/USB3
1-7
1.4.2
Memory configurations
You may install 1GB, 2GB, 4GB, and 8GB unbuffered non‑ECC DDR3 DIMMs into the DIMM
sockets.
1-8
•
You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel configuration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
•
Always install DIMMs with the same CAS latency. For optimal compatibility, we
recommend that you install memory modules of the same version or date code (D/C)
from the same vendor. Check with the retailer to get the correct memory modules.
•
Due to the memory address limitation on 32-bit Windows® OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
-
-
•
This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less.
•
The maximum 32GB memory capacity can be supported with 16GB or above DIMMs.
ASUS will update the memory QVL once the DIMMs are available in the market.
•
The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked
or at a higher frequency, refer to section 2.4 Ai Tweaker menu for manual memory
frequency adjustment.
•
For system stability, use a more efficient memory cooling system to support a full
memory load (2 DIMMs) or overclocking condition.
•
Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
Install a maximum of 3GB system memory if you are using a 32-bit Windows® OS.
Use a 64-bit Windows® OS if you want to install 4GB or more memory on the motherboard.
Chapter 1: Product introduction
1.4.3
Installing a DIMM
1
2
3
To remove a DIMM
B
A
ASUS A55BM-A/USB3
1-9
1.5
Expansion slots
In the future, you may need to install expansion cards. The following sub‑sections describe
the slots and the expansion cards that they support.
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
1.5.1
Installing an expansion card
To install an expansion card:
1.
Before installing the expansion card, read the documentation that came with it and
make the necessary hardware settings for the card.
2.
Remove the system unit cover (if your motherboard is already installed in a chassis).
3.
Remove the bracket opposite the slot that you intend to use. Keep the screw for later
use.
4.
Align the card connector with the slot and press firmly until the card is completely
seated on the slot.
5.
Secure the card to the chassis with the screw you removed earlier.
6.
Replace the system cover.
1.5.2
Configuring an expansion card
After installing the expansion card, configure it by adjusting the software settings.
1.
Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for
information on BIOS setup.
2.
Assign an IRQ to the card.
3.
Install the software drivers for the expansion card.
When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that
the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI
groups, making the system unstable and the card inoperable.
1.5.3
PCI slot
The PCI slot supports cards such as a LAN card, SCSI card, USB card, and other cards that
comply with PCI specifications.
1-10
Chapter 1: Product introduction
1.5.4
PCI Express x1 slot
This motherboard supports PCI Express 2.0 x1 network cards, SCSI cards, and other cards
that comply with the PCI Express specifications.
1.5.5
PCI Express x16 slot
This motherboard supports one PCI Express 3.0/2.0 x16 graphics cards that comply with the
PCI Express specifications.
IRQ assignments for this motherboard
A
B
C
D
E
F
G
H
PCIEx16_1
–
–
shared
–
–
–
–
–
PCIEx1_1
shared
–
–
–
–
–
–
–
PCI1 slot
–
–
–
–
shared
–
–
–
Realtek LAN controller
–
–
shared
–
-
–
–
–
shared
–
–
–
–
–
–
–
SATA controller
–
–
–
shared
–
–
–
–
On Chip USB EHCI 1/2/3
–
shared
–
–
–
–
–
–
On Chip USB OHCI 1/2/3/4
–
–
shared
–
–
–
–
–
HD audio
1.6
Jumpers
Clear RTC RAM (3-pin CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system passwords.
A55BM-A/USB3
1
2
CLRTC
Normal
(Default)
2
3
Clear RTC
A55BM-A/USB3 Clear RTC RAM
ASUS A55BM-A/USB3
1-11
To erase the RTC RAM:
1.
Turn OFF the computer and unplug the power cord.
2.
Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5-10 seconds, then move the cap back to pins 1-2.
3.
Plug the power cord and turn ON the computer.
4.
Hold down the <Del> key during the boot process and enter BIOS setup to reenter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
2.
•
If the steps above do not help, remove the onboard battery and move the jumper
again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the
battery.
•
You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature.
Shut down and reboot the system, then the BIOS automatically resets parameter
settings to default values.
USB device wake-up (3-pin USBPWF)
Set these jumpers to +5V to wake up the computer from S1 sleep mode (CPU stopped,
DRAM refreshed, system running in low power mode) using the connected USB
devices. Set to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU,
DRAM in slow refresh, power supply in reduced power mode).
A55BM-A/USB3
A55BM-E
USBPWF
1
2
+5V
(Default)
2 3
+5VSB
A55BM-A/USB3 USB device wake up
1-12
•
The USB device wake-up feature requires a power supply that can provide 500mA on
the +5VSB lead for each USB port; otherwise, the system would not power up.
•
The total current consumed must NOT exceed the power supply capability (+5VSB)
whether under normal condition or in sleep mode.
Chapter 1: Product introduction
3.
Keyboard and USB device wake up (3-pin KB_USBPWB)
This jumper allows you to enable or disable the keyboard and USB device wake-up
feature. When you set this jumper to pins 2-3 (+5VSB), you can wake up the computer
by pressing a key on the keyboard. This feature requires an ATX power supply that can
supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS.
A55BM-A/USB3
2
1
2
3
KB_USBPWB
+5V
+5VSB
(Default)
A55BM-A/USB3 Keyboard and USB device wake up
1.7
Connectors
1.7.1
Rear panel connectors
2
1
11
10
9
3
8
7
4 5
6
1.
PS/2 Mouse port (green). This port is for a PS/2 mouse.
2.
Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
3.
LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub.
ASUS A55BM-A/USB3
1-13
LAN port LED indications
Activity/Link LED
Status
Off
Orange
Orange (Blinking)
Orange (Blinking
then steady)
Description
No link
Linked
Data activity
Ready to wake up
from S5 mode
ACT/LINK SPEED
LED
LED
Speed LED
Status
Description
OFF
10Mbps connection
ORANGE 100Mbps connection
GREEN
1Gbps connection
LAN port
4.
Line In port (light blue). This port connects to the tape, CD, DVD player, or other
audio sources.
5.
Line Out port (lime). This port connects to a headphone or a speaker. In the 4, 6, and
8-channel configurations, the function of this port becomes Front Speaker Out.
6.
Microphone port (pink). This port connects to a microphone.
Refer to the audio configuration table below for the function of the audio ports in 2, 4, 6, or
8-channel configuration.
Audio 2, 4, 6, or 8-channel configuration
Headset
4-channel
6-channel
2-channel
Light Blue (Rear panel)
Line In
Rear Speaker Out Rear Speaker Out
Lime (Rear panel)
Line Out Front Speaker Out Front Speaker Out
Pink (Rear panel)
Mic In
Mic In
Bass/Center
Lime (Front panel)
—
—
—
Port
8-channel
Rear Speaker Out
Front Speaker Out
Bass/Center
Side Speaker Out
To configure an 8-channel audio output:
1-14
Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
7.
USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports are for USB
2.0/1.1 devices.
8.
USB 3.0 ports 1 and 2. These two 9-pin Universal Serial Bus (USB) ports are for USB
3.0 devices.
•
DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows®
operating system.
•
Due to USB 3.0 controller limitations, USB 3.0 devices can only be used under a
Windows® OS environment and after USB 3.0 driver installation.
•
USB 3.0 devices can only be used for data storage.
•
We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance from your USB 3.0 devices.
Chapter 1: Product introduction
9.
DVI-D port. This port is for any DVI-D compatible device. DVI-D can’t be converted to
output RGB Signal to CRT and isn’t compatible with DVI-I.
10. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector,
and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected
content.
11.
PS/2 Keyboard port (purple). This port is for a PS/2 keyboard.
1.7.2
1.
Internal connectors
CPU and chassis fan connectors (4-pin CPU_FAN, and 4-pin CHA_FAN)
CPU_FAN
CHA_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
GND
Connect the fan cables to the fan connectors on the motherboard, ensuring that the
black wire of each cable matches the ground pin of the connector.
A55BM-A/USB3
A55BM-A/USB3 Fan connectors
DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside
the system may damage the motherboard components. These are not jumpers! DO NOT
place jumper caps on the fan connectors.
•
The CPU_FAN connector supports a CPU fan of maximum 2A (24 W) fan power.
•
The CPU_FAN and CHA_FAN connectors support the ASUS Fan Xpert feature.
ASUS A55BM-A/USB3
1-15
2.
ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
These connectors are for an ATX power supply. The plugs from the power supply are
designed to fit these connectors in only one orientation. Find the proper orientation and
push down firmly until the connectors completely fit.
GND
GND
+12V DC
+12V DC
ATX12V
A55BM-A/USB3
EATXPWR
+3 Volts
+12 Volts
+12 Volts
+5V Standby
Power OK
PIN 1
GND
+5 Volts
GND
+5 Volts
GND
+3 Volts
+3 Volts
PIN 1
GND
+5 Volts
+5 Volts
+5 Volts
-5 Volts
GND
GND
GND
PSON#
GND
-12 Volts
+3 Volts
A55BM-A/USB3 ATX power connectors
1-16
•
We recommend that you use an ATX 12V Specification 2.0‑compliant power supply
unit (PSU) with a minimum of 300W power rating. This PSU type has 24-pin and 4-pin
power plugs.
•
If you intend to use a PSU with 20-pin and 4-pin power plugs, ensure that the 20-pin
power plug can provide at least 15 A on +12 V and that the PSU has a minimum
power rating of 300W. The system may become unstable or may not boot up if the
power is inadequate.
•
DO NOT forget to connect the 4-pin ATX +12V power plug. Otherwise, the system will
not boot up.
•
We recommend that you use a PSU with higher power output when configuring a
system with more power-consuming devices or when you intend to install additional
devices. The system may become unstable or may not boot up if the power is
inadequate.
•
If you are uncertain about the minimum power supply requirement for your system,
refer to the Recommended Power Supply Wattage Calculator at http://support.asus.
com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details.
Chapter 1: Product introduction
3.
Serial ATA 3.0 Gb/s connectors (7-pin SATA3G 1~6)
These connectors are for the Serial ATA 3.0 Gb/s signal cables for Serial ATA hard
disk drives and optical disc drives. If you installed Serial ATA hard disk drives, you can
create a RAID 0, RAID 1, or RAID 10 configuration through the onboard controller.
SATA3G_6
GND
RSATA_RXP6
RSATA_RXN6
GND
RSATA_TXN6
RSATA_TXP6
GND
SATA3G_5
GND
RSATA_RXP5
RSATA_RXN5
GND
RSATA_TXN5
RSATA_TXP5
GND
SATA3G_1
SATA3G_2
SATA3G_3
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXN2
RSATA_RXP2
GND
GND
RSATA_TXP3
RSATA_TXN3
GND
RSATA_RXN3
RSATA_RXP3
GND
SATA3G_4
A55BM-A/USB3
GND
RSATA_RXP4
RSATA_RXN4
GND
RSATA_TXN4
RSATA_TXP4
GND
A55BM-A/USB3 SATA 3.0Gb/s connectors
•
These connectors are set to AHCI mode by default. If you intend to create a Serial ATA
RAID set using these connectors, set the type of the SATA connectors in the BIOS to
[RAID].
•
You must install Windows® XP Service Pack 3 or later version before using Serial
ATA hard disk drives. The Serial ATA RAID feature is available only if you are using
Windows® XP SP3 or later version.
•
When using hot-plug and NCQ, set the type of the SATA connectors in the BIOS to
[AHCI].
ASUS A55BM-A/USB3
1-17
4.
System panel connector (10-1 pin PANEL)
This connector supports several chassis-mounted functions.
F_PANEL
PWR_LED+
PWR_LEDPWR
GND
PWR_LED PWR_BTN
HDD_LED+
HDD_LEDGround
HWRST#
(NC)
PIN 1
A55BM-A/USB3
+HDD_LED
RESET
A55BM-A/USB3 System panel connector
•
System power LED (2-pin PWR_LED)
This 2-pin connector is for the system power LED. Connect the chassis power LED
cable to this connector. The system power LED lights up when you turn on the system
power, and blinks when the system is in sleep mode.
•
Hard disk drive activity LED (2-pin HDD_LED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable
to this connector. The HDD LED lights up or flashes when data is read from or written
to the HDD.
•
ATX power button/soft-off button (2-pin PWR_BTN)
This 2-pin connector is for the system power button.
•
Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without
turning off the system power.
5.
Speaker connector (4-pin SPEAKER)
The 4-pin connector is for the chassis-mounted system warning speaker. The speaker
allows you to hear system beeps and warnings.
+5V
GND
GND
Speaker Out
SPEAKER
A55BM-E
PIN 1
A55BM-A/USB3 Speaker Out Connector
1-18
Chapter 1: Product introduction
6.
Digital audio connector (4-1 pin SPDIF_OUT)
A55BM-A/USB3
SPDIFOUT
GND
+5V
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port.
SPDIF_OUT
A55BM-A/USB3 Digital audio connector
The S/PDIF module is purchased separately.
7.
Front panel audio connector (10-1 pin AAFP)
HD-audio-compliant
pin definition
NC
AGND
NC
NC
PIN 1
MIC2
MICPWR
Line out_R
NC
Line out_L
A55BM-A/USB3
PIN 1
PORT1 L
PORT1 R
PORT2 R
SENSE_SEND
PORT2 L
AAFP
SENSE2_RETUR
AGND
NC
SENSE1_RETUR
This connector is for a chassis-mounted front panel audio I/O module that supports
either High Definition Audio or AC`97 audio standard. Connect one end of the front
panel audio I/O module cable to this connector.
Legacy ACʼ97
compliant definition
A55BM-A/USB3 Front panel audio connector
•
We recommend that you connect a high-definition front panel audio module to this
connector to avail of the motherboard high-definition audio capability.
•
If you want to connect a high definition front panel audio module to this connector, set
the Front Panel Type item in the BIOS to [HD].
•
The front panel audio I/O module is purchased separately.
ASUS A55BM-A/USB3
1-19
8.
USB 2.0 connectors (10-1 pin USB34, USB56)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specification that supports up to
480Mbps connection speed.
PIN 1
USB+5V
USB_P4USB_P4+
GND
PIN 1
USB+5V
USB_P6USB_P6+
GND
A55BM-A/USB3
USB+5V
USB_P3USB_P3+
GND
NC
USB34
USB+5V
USB_P5USB_P5+
GND
NC
USB56
A55BM-A/USB3 USB2.0 connectors
Never connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
The USB 2.0 module is purchased separately.
9.
Serial port connector (10-1 pin COM)
This connector is for a serial (COM) port. Connect the serial port module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
RXD
DTR
DSR
CTS
COM
DCD
TXD
GN D
RTS
RI
PIN 1
A55BM-A/USB3
A55BM-A/USB3 Serial port connectors
The COM module is purchased separately.
1-20
Chapter 1: Product introduction
1.8
Software support
1.8.1
Installing an operating system
This motherboard supports Windows® Vista / 64-bit Windows® Vista /Windows® XP /
Windows® 7 / 64-bit Windows® 7 / Windows® 8 /64-bit Windows® 8 Operating Systems (OS).
Always install the latest OS version and corresponding updates to maximize the features of
your hardware.
1.8.2
•
Motherboard settings and hardware options vary. Refer to your OS documentation for
detailed information.
•
Ensure that you install Windows® XP Service Pack 3 or later versions before installing
the drivers for better compatibility and system stability.
•
Only motherboards installed with an AMD Trinity APU support Windows® Vista / 64bit
Windows® Vista operaing system.
Support DVD information
The Support DVD that comes with the motherboard package contains the drivers, software
applications, and utilities that you can install to avail all motherboard features.
The contents of the Support DVD are subject to change at any time without notice. Visit the
ASUS website at www.asus.com for updates.
To run the Support DVD
Place the Support DVD into the optical drive. If Autorun is enabled in your computer, the
DVD automatically displays the Specials screen which contains the unique features of ASUS
motherboard. Click Drivers, Utilities, Make Disk, Manual, Contact and Specials tabs to display
their respective menus.
The following screen is for reference only.
Click an icon to display
Support DVD/motherboard
information
Click an item to install
If Autorun is NOT enabled in your computer, browse the contents of the Support DVD to
locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the DVD.
ASUS A55BM-A/USB3
1-21
1-22
Chapter 1: Product introduction
BIOS information
2.1
Managing and updating your BIOS
2
Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to
restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update
utility.
2.1.1
EZ Update
EZ Update is a utility that allows you to automatically update your motherboard’s softwares,
drivers and the BIOS version easily. With this utlity, you can also manually update the saved
BIOS and select a boot logo when the system goes into POST.
To launch EZ Update, click EZ Update on the AI Suite 3 main menu bar.
Model Name: H81-PLUS
Version:0203
Release Date: 05/28/2013
Click to automatically
update your
motherboard’s
driver, software and
firmware
File: H81-PLUS-ASUS-0205.CAP
Model Name: H81-PLUS
Version:0205
Release Date: 06/18/2013
C:\Users\test\Downloads\H81-PLUS-ASUS-02...
Click to find and
select the BIOS
from file
Click to select a
boot logo
Click to update
the BIOS
EZ Update requires an Internet connection either through a network or an ISP (Internet
Service Provider).
ASUS A55BM-A/USB3
2-1
2.1.2
ASUS EZ Flash 2
The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS‑based
utility.
Before you start using this utility, download the latest BIOS file from the ASUS website at
www.asus.com.
To update the BIOS using EZ Flash 2:
1.
Insert the USB flash disk that contains the latest BIOS file to the USB port.
2.
Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select
ASUS EZ Flash 2 Utility and press <Enter> to enable it.
3.
Press <Tab> to switch to the Drive field.
4.
Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS,
and then press <Enter>.
5.
Press <Tab> to switch to the Folder Info field.
6.
Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to perform
the BIOS update process. Reboot the system when the update process is done.
2.1.3
•
This function supports USB flash disks with FAT 32/16 format and single partition only.
•
DO NOT shut down or reset the system while updating the BIOS to prevent system
boot failure!
ASUS CrashFree BIOS 3 utility
The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file
when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS
file using the motherboard support DVD or a USB flash drive that contains the updated BIOS
file.
2-2
•
Before using this utility, rename the BIOS file in the removable device into
A55BMAU3.CAP.
•
The BIOS file in the support DVD may not be the latest version. Download the latest
BIOS file from the ASUS website at www.asus.com.
Chapter 2: Getting started
Recovering the BIOS
To recover the BIOS:
1.
Turn on the system.
2.
Insert the support DVD to the optical drive or the USB flash drive that contains the
BIOS file to the USB port.
3.
The utility automatically checks the devices for the BIOS file. When found, the utility
reads the BIOS file and enters ASUS EZ Flash 2 utility automatically.
4.
The system requires you to enter BIOS Setup to recover BIOS setting. To ensure
system compatibility and stability, we recommend that you press <F5> to load default
BIOS values.
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause
system boot failure!
2.1.4
ASUS BIOS Updater
The ASUS BIOS Updater allows you to update BIOS in DOS environment. This utility also
allows you to copy the current BIOS file that you can use as a backup when the BIOS fails or
gets corrupted during the updating process.
The succeeding utility screens are for reference only. The actual utility screen displays may
not be same as shown.
Before updating BIOS
1.
Prepare the motherboard support DVD and a USB flash drive in FAT32/16 format and
single partition.
2.
Download the latest BIOS file and BIOS Updater from the ASUS website at
http://support.asus.com and save them on the USB flash drive.
NTFS is not supported under DOS environment. Do not save the BIOS file and BIOS
Updater to a hard disk drive or USB flash drive in NTFS format.
3.
Turn off the computer and disconnect all SATA hard disk drives (optional).
ASUS A55BM-A/USB3
2-3
Booting the system in DOS environment
1.
Insert the DOS-bootable USB flash drive with the latest BIOS file and BIOS Updater to
your computer’s USB port.
2.
Boot your computer. When the ASUS Logo appears, press <F8> to show the BIOS
Boot Device Select Menu.
3. Select the USB flash drive as the boot device. The DOS screen appears.
Updating the BIOS file
To update the BIOS file using BIOS Updater:
1.
At the FreeDOS prompt, type bupdater /pc /g and press <Enter>.
2.
The BIOS Updater screen appears as below.
ASUSTek BIOS Updater for DOS V1.30
BOARD: A55BM-A/USB3
VER: 0301
DATE: 07/03/2013
A55BMAU3.CAP
2-4
4194304 2013-07-08 17:30:48
Chapter 2: Getting started
3.
Press <Tab> to switch between screen fields and use the <Up/Down/Home/End> keys
to select the BIOS file and press <Enter>. BIOS Updater checks the selected BIOS file
and prompts you to confirm BIOS update.
4.
Select Yes and press <Enter>. When BIOS update is done, press <ESC> to exit BIOS
Updater. Restart your computer.
DO NOT shut down or reset the system while updating the BIOS to prevent system boot
failure!
2.2
•
For BIOS Updater version 1.30 or later, the utility automatically exits to the DOS
prompt after updating BIOS.
•
Ensure to load the BIOS default settings to ensure system compatibility and stability.
Select the Load Optimized Defaults item under the Exit menu. Refer to section 2.10
Exit menu for details.
•
Ensure to connect all SATA hard disk drives after updating the BIOS file if you have
disconnected them.
BIOS setup program
Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS
screens include navigation keys and brief online help to guide you in using the BIOS Setup
program.
Entering BIOS Setup at startup
To enter BIOS Setup at startup:
•
Press <Delete> during the Power-On Self Test (POST). If you do not press <Delete>,
POST continues with its routines.
Entering BIOS Setup after POST
To enter BIOS Setup after POST:
•
Press <Ctrl>+<Alt>+<Del> simultaneously.
•
Press the reset button on the system chassis.
•
Press the power button to turn the system off then back on. Do this option only if you
failed to enter BIOS Setup using the first two options.
ASUS A55BM-A/USB3
2-5
Using the power button, reset button, or the <Ctrl>+<Alt>+<Del> keys to force reset from
a running operating system can cause damage to your data or system. We recommend to
always shut down the system properly from the operating system.
•
The BIOS setup screens shown in this section are for reference purposes only, and
may not exactly match what you see on your screen.
•
Visit the ASUS website at www.asus.com to download the latest BIOS file for this
motherboard.
•
Ensure that a USB mouse is connected to your motherboard if you want to use the
mouse to control the BIOS setup program.
•
If the system becomes unstable after changing any BIOS setting, load the default
settings to ensure system compatibility and stability. Select the Load Optimized
Defaults item under the Exit menu or press hotkey F5. See section 2.10 Exit Menu
for details.
•
If the system fails to boot after changing any BIOS setting, try to clear the CMOS and
reset the motherboard to the default value. See section 1.6 Jumpers for information
on how to erase the RTC RAM.
BIOS menu screen
The BIOS setup program can be used under two modes: EZ Mode and Advanced Mode.
You can change modes from the Exit menu or from the Exit/Advanced Mode button in the EZ
Mode/Advanced Mode screen.
EZ Mode
By default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ
Mode provides you an overview of the basic system information, and allows you to select
the display language, system performance mode and boot device priority. To access the
Advanced Mode, click Exit/Advanced Mode or press F7 for the advanced BIOS settings.
The default screen for entering the BIOS setup program can be changed.
2-6
Chapter 2: Getting started
Selects the display language of the
BIOS setup program
Displays the CPU/motherboard temperature,
CPU/5V/3.3V/12V voltage output,
CPU/chassis fan speed
Exits the BIOS setup program without saving
the changes, saves the changes and resets
the system, or enters the Advanced Mode
CPU Volt.
Displays the
SATA information
Selects the
Advanced mode
boot device
menus
priority
Selects the Advanced
Normal mode
mode functions
Power Saving
mode
Loads optimized default
Selects the boot
device priority
Displays the system
properties of the
selected mode on the
right hand side
•
The boot device options vary depending on the devices you installed to the system.
•
The Boot Menu(F8) button is available only when the boot device is installed to the
system.
ASUS A55BM-A/USB3
2-7
Advanced Mode
The Advanced Mode provides advanced options for experienced end-users to configure the
BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed configurations.
To access the EZ Mode, click Exit, then select ASUS EZ Mode or press F7.
Back button
Menu items
Submenu item
Menu bar
Configuration fields
Pop-up window
General help
Navigation keys
Menu bar
Last modified
settings
Quick note
The menu bar on top of the screen has the following main items:
My Favorites For saving the frequently-used system settings and configuration
Main
For changing the basic system configuration
2-8
Ai Tweaker
For changing the overclocking settings
Advanced
For changing the advanced system settings
Monitor
For displaying the system temperature, power status, and changing the
fan settings
Boot
For changing the system boot configuration
Tool
Exit
For configuring options for special functions
For selecting the exit options and loading default settings
Chapter 2: Getting started
2.3
My Favorites
MyFavorites is your personal space where you can easily save and access your favorite
BIOS items.
Adding items to My Favorites
To add frequently-used BIOS items to My Favorites:
1.
Use the arrow keys to select an item that you want to add. When using a mouse, hover
the pointer to the item.
2.
Press <F4> on your keyboard or right-click on your mouse to add the item to My
Favorites page.
You cannot add the following items to My Favorites:
•
Items with submenu options
•
User-configurable items such as language and boot device order
•
Configuration items such as Memory SPD Information, system time and date
ASUS A55BM-A/USB3
2-9
2.4
Main menu
The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup
program. The Main menu provides you an overview of the basic system information, and
allows you to set the system date, time, language, and security settings.
2-10
•
If you have forgotten your BIOS password, erase the CMOS Real Time Clock (RTC)
RAM to clear the BIOS password. See section 1.6 Jumpers for information on how to
erase the RTC RAM.
•
The Administrator or User Password items on top of the screen show the default
Not Installed. After you set a password, these items show Installed.
Chapter 2: Getting started
2.5
Ai Tweaker menu
The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
Scroll down to display the following items:
ASUS A55BM-A/USB3
2-11
2.6
Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Be cautious when changing the settings of the Advanced menu items. Incorrect field values
can cause the system to malfunction.
2.7
Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
2-12
Chapter 2: Getting started
Scroll down to display the following items:
2.8
Boot menu
The Boot menu items allow you to change the system boot options.
Scroll down to display the following items:
ASUS A55BM-A/USB3
2-13
2.9
Tools menu
2.10
Exit menu
The Tools menu items allow you to configure options for special functions. Select an item
then press <Enter> to display the submenu.
The Exit menu items allow you to load the optimal default values for the BIOS items, and
save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit
menu.
2-14
Chapter 2: Getting started
Appendices
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
•
This device may not cause harmful interference.
•
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
A55M-E
A-1
IC: Canadian Compliance Statement
Complies with the Canadian ICES-003 Class B specifications. This device complies with RSS
210 of Industry Canada. This Class B device meets all the requirements of the Canadian
interference-causing equipment regulations.
This device complies with Industry Canada license exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Cut appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
Cet appareil est conforme aux normes CNR exemptes de licence d’Industrie Canada. Le
fonctionnement est soumis aux deux conditions suivantes :
(1) cet appareil ne doit pas provoquer d’interférences et
(2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer
un fonctionnement non souhaité de l’appareil.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
VCCI: Japan Compliance Statement
VCCI Class B Statement
KC: Korea Warning Statement
A-2
Appendices
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards
for protecting our environment. We believe in providing solutions for you to be able to
responsibly recycle our products, batteries, other components as well as the packaging
materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling
information in different regions.
A55M-E
A-3
ASUS contact information
ASUSTeK COMPUTER INC.
Address
Telephone Fax E-mail
Web site
Technical Support
Telephone Online support
15 Li-Te Road, Peitou, Taipei, Taiwan 11259
+886-2-2894-3447
+886-2-2890-7798
info@asus.com.tw
www.asus.com.tw
+86-21-38429911
support.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Address
Telephone
Fax
Web site
Technical Support
Telephone Support fax
Online support
800 Corporate Way, Fremont, CA 94539, USA
+1-812-282-3777
+1-510-608-4555
usa.asus.com
+1-812-282-2787
+1-812-284-0883
support.asus.com
ASUS COMPUTER GmbH (Germany and Austria)
Address
Fax
Web site
Online contact
Technical Support
Telephone
Support Fax
Online support
Harkort Str. 21-23, D-40880 Ratingen, Germany
+49-2102-959911
www.asus.de
www.asus.de/sales
+49-1805-010923*
+49-2102-9599-11
support.asus.com
* EUR 0.14/minute from a German fixed landline; EUR 0.42/minute from a mobile phone.
A-4
Appendices
A55M-E
A-5
(510)739-3777/(510)608-4555
800 Corporate Way, Fremont, CA 94539.
Asus Computer International
Signature :
Date :
Representative Person’s Name :
Jul. 17, 2013
Steve Chang / President
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Supplementary Information:
FCC Part 15, Subpart B, Unintentional Radiators
Conforms to the following specifications:
Model Number : A 5 5 BM - A /US B3
Product Name : Motherboard
hereby declares that the product
Phone/Fax No:
Address:
Responsible Party Name:
Per FCC Part 2 Section 2. 1077(a)
DECLARATION OF CONFORMITY
Ver. 120601
Manufacturer:
TAIWAN
ASUS COMPUTER GmbH
HARKORT STR. 21-23, 40880 RATINGEN
GERMANY
Country:
Authorized representative in Europe:
Address, City:
Country:
A55B M-A/USB 3
Model name :
Declaration Date: 17/07/2013
Year to begin affixing CE marking:2013
CE marking
2011/65/EU-RoHS Directive
Regulation (EC) No. 642/2009
Regulation (EC) No. 1275/2008
2009/125/EC-ErP Directive
EN 60950-1 / A12:2011
2006/95/EC-LVD Directive
EN 300 328 V1.7.1(2006-10)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 302 544-2 V1.1.1(2009-01)
EN 302 623 V1.1.1(2009-01)
EN 50360:2001
EN 62479:2010
EN 50385:2002
EN 62311:2008
1999/5/EC-R &TTE Directive
EN 55022:2010
EN 61000-3-2:2006+A2:2009
EN 55013:2001+A1:2003+A2:2006
2004/108/EC-EMC Directive
Name :
Signature : __________
CEO
Jerry Shen
Position :
(EC conformity marking)
Regulation (EC) No. 278/2009
EN 60065:2002 / A12:2011
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.1.1(2009-05)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 55024:2010
EN 61000-3-3:2008
EN 55020:2007+A11:2011
conform with the essential requirements of the following directives:
Motherboard
Product name :
declare the following apparatus:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Address, City:
ASUSTeK COMPUTER INC.
EC Declaration of Conformity
We, the undersigned,
Ver. 130208
Download PDF
