X-22 & X-24 LED-Backlit Display
User Manual
TABLE OF CONTENTS
Contents
Safety Information
FCC Declaimers........................................................................................................................................ 4
WEEE........................................................................................................................................................ 5
Precautions
Notice........................................................................................................................................................ 6
Cautions When Setting Up........................................................................................................................ 6
Cautions When Using................................................................................................................................ 7
Cleaning and Maintenance........................................................................................................................ 7
Notice for the LCD Display........................................................................................................................ 8
Chapter 1: Product Description
1.1 Package Contents............................................................................................................................... 9
1.2 Wall Mounting Installation Preparation................................................................................................ 10
1.2.2
Removing the Base Stand....................................................................................................... 10
1.2.1
Wall Mounting........................................................................................................................... 10
1.3 LCD Display Overview........................................................................................................................ 11
1.3.1
Front View and Keypad Buttons............................................................................................... 11
1.3.2
Rear View................................................................................................................................. 12
Chapter 2: Making Connections
2.1 Connecting the Power......................................................................................................................... 13
2.2 Connecting Input Source Signals........................................................................................................ 14
2.2.1
Connecting a Computer........................................................................................................... 14
Using VGA Cables.......................................................................................................................... 14
Using DVI Cables............................................................................................................................ 14
Connecting an Audio Device........................................................................................................... 15
2.2.2
Connecting a Camera or Video Device.................................................................................... 15
Using CVBS Cables........................................................................................................................ 15
Using S-Video Cables..................................................................................................................... 16
Using HDMI Cables......................................................................................................................... 16
Chapter 3: Using the LCD Display
3.1 Turning on the Power.......................................................................................................................... 17
3.2 Selecting the Input Source Signal....................................................................................................... 17
3.3 Adjusting the Volume........................................................................................................................... 18
3.4 Locking the OSD Menu....................................................................................................................... 18
3.5 Using Picture-in-Picture (PIP)............................................................................................................. 19
3.5.1
PIP Options.............................................................................................................................. 19
3.5.2
PIP Swap.................................................................................................................................. 20
3.6 Using ROTATE Function..................................................................................................................... 20
3.7 Using Auto Adjustment Function......................................................................................................... 21
Chapter 4: On Screen Display Menu
4.1 Using the OSD Menu.......................................................................................................................... 22
4.2 OSD Menu Tree.................................................................................................................................. 24
2
TABLE OF CONTENTS
Chapter 5: Adjusting the Settings
5.1 Brightness Setting............................................................................................................................... 27
5.2 Colour Setting...................................................................................................................................... 29
5.3 Image Setting (PC Source only).......................................................................................................... 30
5.4 Image Setting (Video signals)............................................................................................................. 31
5.5 PIP Setting.......................................................................................................................................... 33
5.6 OSD Setting........................................................................................................................................ 35
5.7 Audio Setting....................................................................................................................................... 36
5.8 Other Setting....................................................................................................................................... 37
5.9 Auto Brightness................................................................................................................................... 39
5.9.1 EcoSmart Sensor........................................................................................................................ 39
5.10 Input Select....................................................................................................................................... 40
Chapter 6: Appendix
6.1 Warning Messages.............................................................................................................................. 41
6.2 Troubleshooting................................................................................................................................... 42
6.3 Transporting the LCD Display............................................................................................................. 44
Chapter 7: Specifications
7.1 Display Specifications......................................................................................................................... 45
7.2 Display Dimensions............................................................................................................................. 46
7.2.1
X-22 Dimensions...................................................................................................................... 46
7.2.2
X-24 Dimensions...................................................................................................................... 46
3
SAFETY INFORMATION
This FCC Class-B compliant digital device
complies with the Interference-Causing
Equipment Regulations of Canada.
FCC Declaimers
This device complies with Section 15 of the FCC listing. The
operation procedures must meet the following conditions: (1)
the device must not cause any damaging interference; and (2)
this device must accept any received interference, including any
unpredictable interference that may possibly occur.
Dear users,
This device has passed the Class B digital service regulations and
complies with Section 15 of the FCC listing; these are intended to
provide reasonable warranty against damaging interference for
home use. This device will produce, use, and emit radio frequency
energy; therefore, installation or use without following the instructions
given may cause damaging interference to radio communication.
Nonetheless, it is not possible to state with certainty that interference
will occur from specific installations. If this device has caused
damaging interference to radio or TV signals (simply turn the device
on and off to check if such interference is caused by the device), we
recommend that you fix the interference using the following methods:
• Readjust the direction or location of the antenna.
• Increase the distance between this device and the receiver.
• Consult your local dealer or an experienced radio/TV technician.
Warning:
Making changes or modifications to
the device without the permission
from an authorized dealer may void
the warranty of this device.
4
SAFETY INFORMATION
WEEE
Information for users applicable in European Union countries.
The symbol on the product or its packaging signifies that this product has to be
disposed separately from ordinary household wastes at its end of life. Please
kindly be aware that this is your responsibility to dispose electronic equipment at
recycling centers so as to help conserve natural resources. Each country in the
European Union should have its collection centers for electrical and electronic
equipment recycling. For information about your recycling drop off area, please
contact your local related electrical and electronic equipment waste management
authority or the retailer where you bought the product.
5
PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symbols used in this manual
This icon indicates the existence of a potential hazard that could result in personal injury
or damage to the product.
This icon indicates important operating and servicing information.
Notice
• Read this User Manual carefully before using the LCD display and keep it for future reference.
• The product specifications and other information provided in this User Manual are for reference only. All
information is subject to change without notice. Updated content can be downloaded from our web site at
http://www.agneovo.com.
• To register online, go to http://www.agneovo.com.
• To protect your rights as a consumer, do not remove any stickers from the LCD display. Doing so may
affect the determination of the warranty period.
Cautions When Setting Up
Do not place the LCD display near heat sources, such as a heater, exhaust vent, or in direct
sunlight.
Do not cover or block the ventilation holes in the housing.
Place the LCD display on a stable area. Do not place the LCD display where it may subject
to vibration or shock.
Place the LCD display in a well-ventilated area.
Do not place the LCD display outdoors.
Do not place the LCD display in a dusty or humid environment.
Do not spill liquid or insert sharp objects into the LCD display through the ventilation holes.
Doing so may cause accidental fire, electric shock or damage the LCD display.
6
PRECAUTIONS
Cautions When Using
Use only the power cord supplied with the LCD
display.
The power outlet should be installed near the LCD
display and be easily accessible.
If an extension cord is used with the LCD display,
ensure that the total current consumption plugged
into the power outlet does not exceed the ampere
rating.
Do not allow anything to rest on the power cord. Do
not place the LCD display where the power cord
may be stepped on.
If the LCD display will not be used for an indefinite
Warning:
Unplug the power cord
from the power outlet and
refer to qualified service
personnel under the following
conditions:
♦♦ When the power cord is
damaged.
♦♦ If the LCD display has been
period of time, unplug the power cord from the
dropped or the housing has
power outlet.
been damaged.
To disconnect the power cord, grasp and pull by the
plug head. Do not tug on the cord; doing so may
♦♦ If the LCD display emits smoke
or a distinct odor.
cause fire or electric shock.
Do not unplug or touch the power cord with wet
hands.
Warning:
Cleaning and Maintenance
The LCD display comes with NeoVTM Optical
Glass. Use a soft cloth lightly moistened with a mild
detergent solution to clean the glass surface and the
housing.
Do not rub or tap the surface of the glass with sharp
or abrasive items such as a pen or screwdriver. This
may result in scratching the surface of the glass.
Do not attempt to service the LCD display yourself,
refer to qualified service personnel. Opening or
removing the covers may expose you to dangerous
voltage or other risks.
Ceiling mount or mount
on any other horizontal
surface overhead are not
advisable.
Installation in contravention of
the instructions may result in
undesirable consequences,
particularly hurting people and
damaging property. Users who
have already mounted the
display on the ceiling or any
other horizontal surface overhead
are strongly advised to contact
AG Neovo for consultations and
solutions to help ensure a most
pleasurable and fulfilling display
experience.
7
PRECAUTIONS
Notice for the LCD Display
In order to maintain the stable luminous performance, it is recommended to use low brightness setting.
Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease
with time.
When static images are displayed for long periods of time, the image may cause an imprint on the LCD
display. This is called image retention or burn-in.
To prevent image retention, do any of the following:
• Set the LCD display to turn off after a few minutes of being idle.
• Use a screen saver that has moving graphics or a blank white image.
• Switch desktop backgrounds regularly.
• Adjust the LCD display to low brightness settings.
• Turn off the LCD display when the system is not in use.
Things to do when the LCD display shows image retention:
• Turn off the LCD display for extended periods of time. It can be several hours or several days.
• Use a screen saver and run it for extended periods of time.
• Use a black and white image and run it for extended periods of time.
When the LCD display is moved from one room to another or there is a sudden change from low to high
ambient temperature, dew condensation may form on or inside the glass surface. When this happens, do
not turn on the LCD display until the dew disappears.
Due to humid weather conditions, it is normal for mist to form inside the glass surface of the LCD display.
The mist will disappear after a few days or as soon as the weather stabilizes.
There are millions of micro transistors inside the LCD display. It is normal for a few transistors to be
damaged and to produce spots. This is acceptable and is not considered a failure.
8
CHAPTER 1: PRODUCT DESCRIPTION
1.1 Package Contents
When unpacking, check if the following items are included in
the package. If any of them is missing or damaged, contact your
dealer.
LCD Display
User Manual
Power adapter
Note:
Must use only the supplied power
adapter:
♦♦ Lite-on Technology Corporation
Model no.: PA-1051-0
Rating: 12V/4.16A
Power cord
VGA cable
♦♦ Adaptor Technology Co., Ltd
Model no.: P/N:ATS050-P121
Rating: 12V/4.2A
Audio cable
Note:
♦♦ The pictures are for reference
only. Actual items may vary
upon shipment.
9
PRODUCT DESCRIPTION
1.2 Wall Mounting Installation Preparation
Note:
1.2.1
To protect the glass panel, place a
1
Wall Mounting
towel or soft cloth before laying the
Remove the base stand.
LCD display down.
See procedures below.
2
Wall mount the LCD display.
Screw the mounting bracket to the VESA holes at
the rear of the LCD display.
Warning:
Ceiling mount or mount
100mm
on any other horizontal
surface overhead are not
advisable.
Installation in contravention of
the instructions may result in
100mm
75mm
undesirable consequences,
particularly hurting people and
damaging property. Users who
have already mounted the
display on the ceiling or any
75mm
other horizontal surface overhead
are strongly advised to contact
AG Neovo for consultations and
solutions to help ensure a most
pleasurable and fulfilling display
1.2.2
1
experience.
Removing the Base Stand
Lay the LCD display
face down on a flat
Note:
even surface.
2
Take measures to prevent the
Remove the four
LCD display from falling down
screws securing the
and lessen possible injury and
base stand from the
damage to the display in case of
LCD display.
3
earthquakes or other disasters.
Detach the base
♦♦ Use only the 75 x 75 mm and
stand.
100 x 100 mm wall mount kit
recommended by AG Neovo.
♦♦ Secure the LCD display on a
solid wall strong enough to bear
its weight.
10
PRODUCT DESCRIPTION
1.3 LCD Display Overview
1.3.1
Front View and Keypad Buttons
1
1
2
3
4
AUTO ADJ.
VOL
DOWN
VOL
UP
PIP
SELECT
SWAP/
ROTATE
MENU
INPUT
SELECT
2
3
4
5
6
7
8
Display screen
The LCD display screen is protected by
NeoVTM Optical Glass.
5
UP
6
DOWN
AUTO
• For VGA input signal source, press to
perform auto adjustment.
• During OSD menu selection, press to close
the OSD menu or exit a submenu.
POWER /
LED
9
• Press repeatedly to select PIP option.
• During OSD menu selection, press to move
up a menu or submenu.
• When PIP is on, press to SWAP the PIP
main and sub picture.
• When PIP is off, press to rotate the image
180°.
• During OSD menu selection, press to move
up a menu or submenu.
LEFT
• Press to display the volume screen. Then
press again to decrease the volume.
• During OSD menu selection, press to
adjust the settings.
7
RIGHT
MENU
• Press to display the OSD menu.
• Press again to hide the OSD menu.
8 SOURCE
• Press to select the input signal source.
• Press to increase the volume.
• During OSD menu selection, press to select
an option and adjust the settings.
9
POWER / LED indicator
• Press to turn the power on or off.
Green - Power on
Amber - Standby mode
Off - Power off
11
PRODUCT DESCRIPTION
1.3.2
Rear View
S-VIDEO
6
CVBS-1
CVBS-2
7
AUDIO
L
8
IN
R
DC IN
1
1
HDMI
DVI
VGA
AUDIO IN
2
3
4
5
DC power input
5
Use to connect the power cord.
Audio port
Use to connect an audio cable for the
PC’s audio input.
2
3
4
HDMI connector
6
S-Video connector
Use to connect an input device using
Use to connect AV cables for the
HDMI cable for digital input signal.
S-Video signal.
DVI connector
7
COMPOSITE Video input connectors
Use to connect a PC using DVI cable
Use to connect composite cables for
for digital input signal.
CVBS input signal.
VGA connector
8
COMPOSITE Audio input connectors
Use to connect a PC using a VGA cable for
Use to connect RCA cables for CVBS /
analogue input signal.
S-Video audio signal.
12
CHAPTER 2: MAKING CONNECTIONS
2.1 Connecting the Power
1
Connect the power cord to the power adapter.
2
Connect the power adapter to the DC power input at the rear of the LCD display.
3
Connect the power cord plug to a power outlet or a power supply.
DC IN
Caution:
♦♦ Make sure that the LCD display is
not connected to the power outlet
before making any connections.
Connecting cables while the power
is ON may cause electric shock or
personal injury.
Caution:
♦♦ When unplugging the power cord,
hold the power cord by the plug
head. Never pull by the cord.
13
MAKING CONNECTIONS
2.2 Connecting Input Source Signals
2.2.1
Connecting a Computer
Using VGA Cables
Connect one end of a D-sub cable to the VGA connector of the LCD display and the other end to the D-sub
connector of the computer.
VGA
Using DVI Cables
Connect one end of a DVI cable to the DVI connector of the LCD display and the other end to the DVI
connector of the computer.
DVI
14
MAKING CONNECTIONS
Connecting an Audio Device
Connect one end of an audio cable to the audio port at the rear of the LCD display and the other end to the
audio out port of the computer.
AUDIO IN
2.2.2
Connecting a Camera or Video Device
Using CVBS Cables
Connect one end of a CVBS cable
to the COMPOSITE connectors of
CVBS-1
the LCD display and the other end to
CVBS-2
the COMPOSITE connectors of your
AUDIO
device.
L
IN
For audio input, connect an RCA
R
cable to the audio in connector of
the LCD display and the audio out
connector of your device.
15
MAKING CONNECTIONS
Using S-Video Cables
Connect one end of an S-Video
S-VIDEO
cable to the S-VIDEO connector of
the LCD display and the other end
to the S-VIDEO connector of your
device.
For audio input, connect an RCA
cable to the audio in connector of
the LCD display and the audio out
connector of your device.
Using HDMI Cables
Connect one end of an HDMI cable to the HDMI connector of the LCD display and the other end to the HDMI
connector of your device.
HDMI
16
CHAPTER 3: USING THE LCD DISPLAY
3.1 Turning on the Power
Note:
POWER button
LED indicator
1
2
Plug the power cord to a power outlet or power supply.
Touch the POWER button to turn the LCD display on.
The LED indicator turns GREEN.
When the LCD display is turned on, touch the POWER
♦♦ The LCD display still consumes
power as long as the power
cord is connected to the power
outlet. Disconnect the power
cord to completely cut off
power.
button to turn off the LCD display.
The LED indicator turns off.
3.2 Selecting the Input Source Signal
Notes:
♦♦ After selecting an input source
signal, the input source signal
message appears on the
screen briefly.
SOURCE button
Touch the
button to select the input source signal.
For example, CVBS1 is
selected the following message
is displayed.
CVBS1
INPUT
♦♦ If the selected input source
signal is not connected to the
LCD display or is turned off, the
no signal message is displayed
on the screen.
NO
SIGNAL
♦♦ If the resolution or the graphics
card of the connected computer
is set too high, the input out of
range message is displayed.
INPUT SIGNAL
OUT OF RANGE
17
USING THE LCD DISPLAY
3.3 Adjusting the Volume
VOLUME buttons
1
Touch the
or
2
Touch the
button to increase volume or the
buttons to call out the volume bar.
button to decrease volume.
To mute the audio, set the volume to 0.
3.4 Locking the OSD Menu
Lock the OSD menu to protect the LCD display from unauthorised users or from accidentally pressing the
keypad.
To lock the OSD, press and hold the keypad buttons listed below for at least 5 seconds or until the
OSD
LOCK OUT
message appears.
When the OSD is locked, all keypad buttons are inactivated.
Type of OSD Lock
Lock all buttons
Lock Operation
Touch and hold the
,
, and the
buttons for 5 seconds.
Lock all buttons except
Touch and hold the
the POWER button.
buttons for 5 seconds.
,
Unlock Operation
Touch and hold the
,
, and the
buttons for 5 seconds or until the OSD
menu appears.
, and the
Touch and hold the
, and the
buttons for 5 seconds or until the OSD
menu appears.
18
,
USING THE LCD DISPLAY
3.5 Using Picture-in-Picture (PIP)
The Picture-in-Picture (PIP) feature allows viewing of more than one input source signal on the LCD display.
3.5.1
PIP Options
Touch the
button repeatedly to enable and scroll among the PIP options. Options are as follows:
• PIP On: The sub source signal is displayed within the main source signal.
• PAP (Picture-and-Picture): The main source and the sub source signals are displayed side by side with
equal display size.
• PIP Off: PIP function is disabled, only the main source signal is displayed.
PIP On
PAP
PIP Off
Note:
♦♦ The main source and sub
source signals can be set in
PIP Setting, see page 33.
♦♦ Some input source signal
combinations do not support
PIP. See PIP Compatibility
table on page 34.
19
USING THE LCD DISPLAY
3.5.2
PIP Swap
The main and the sub source signals set in PIP Setting can be easily
swapped using the keypad.
Note:
♦♦ PIP Swap can only be executed
if PIP is enabled, see page 33.
Main source
Sub source
button to swap the main source and the sub source
Touch the
signals. See illustration below.
Main source
Sub source
3.6 Using ROTATE Function
The ROTATE function allows you to rotate the screen image at 180°.
Note:
Original screen
♦♦ ROTATE function can only be
executed if PIP is off, see page
33.
Touch the
button to rotate the picture 180º. See illustration below.
After ROTATE
After executing ROTATE, touch the
button again to rotate the
picture back to its normal state.
Back to original
state
20
USING THE LCD DISPLAY
3.7 Using Auto Adjustment Function
Auto Adjustment function automatically tunes the LCD display to its
Note:
optimal setting, including horizontal position, vertical position, clock,
♦♦ Auto Adjustment function is
and phase.
Touch the
available only during VGA input
signals.
button to perform auto adjustment.
♦♦ It is recommended to use the
The message auto adjusting is displayed on the screen.
AUTO
ADJUSTING
auto adjustment function when
using the LCD display for the
first time or after a resolution or
During auto adjustment, the screen will slightly shake for a few
seconds.
When the message disappears, auto adjustment is completed.
21
frequency change.
CHAPTER 4: ON SCREEN DISPLAY MENU
4.1 Using the OSD Menu
Operation
1
Display the main menu screen.
N T S C
Touch
.
6 0 H z
B R I G H T N E S S
5 0
B R I G H T N E S S
C O N T R A S T
C O L O U R
5 0
S E T T I N G
B L A C K
I M A G E
S E T T I N G
A S P E C T
P I P
L E V E L
5 0
R AT I O
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
B R I G H T N E S S
I N P U T
S E L E C T
Navigation Window
L A N G U A G E
I N F O R M AT I O N
E X I T
2
E N T E R
S E L E C T
Select the menu.
N T S C
6 0 H z
B R I G H T N E S S
5 0
B R I G H T N E S S
C O N T R A S T
C O L O U R
5 0
S E T T I N G
B L A C K
I M A G E
S E T T I N G
A S P E C T
P I P
L E V E L
5 0
R AT I O
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
E N T E R
S E L E C T
22
1 Touch the
or
2 Touch the
button to enter the
submenu.
buttons.
ON SCREEN DISPLAY MENU
Operation
3
or
buttons.
or
buttons.
B R I G H T N E S S
5 0
T N E S S
C O N T R A S T
5 0
S E T T I N G
B L A C K
L E V E L
S E T T I N G
C T
5 0
R AT I O
The highlighted item with an orange arrow indicates the active
submenu.
E T T I N G
B U R N - I N
R
Touch the
6 0 H z
U R
E
Select the submenu item.
4
Adjust the settings.
Touch the
5
Exit the submenu.
Touch
6
Close the OSD window.
E T T I N G
S E T T I N G
or
to return to the
previous menu.
S E T T I N G
B R I G H T N E S S
Touch
or
again.
S E L E C T
U A G E
M AT I O N
When settings are modified, all changes are saved when the user does the following:
• Proceeds to the another menu.
• Exits the OSD menu.
A D J U S T
S E L E C T
• Waits for the OSD menu to disappear.
Note: Availability of some menu items depend on the input source signal. If the menu is not available, it is
disabled and grayed out.
23
ON SCREEN DISPLAY MENU
4.2 OSD Menu Tree
N T S C
6 0 H z
B R I G H T N E S S
1
5 0
B R I G H T N E S S
C O N T R A S T
2
C O L O U R
5 0
S E T T I N G
B L A C K
3
I M A G E
4
A S P E C T
5
P I P
6
A N T I - B U R N - I N
S E T T I N G
5 0
R AT I O
S E T T I N G
O S D
7
S E T T I N G
A U D I O
S E T T I N G
8
O T H E R
S E T T I N G
9
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
10
11
L A N G U A G E
12
I N F O R M AT I O N
13
E X I T
E N T E R
Main Menu
1. Brightness
L E V E L
Submenu
• Brightness
S E L E C T
Remarks
See page 27.
• Contrast
• Black Level
2. Colour Setting
• Colour Temperature
See page 29.
3. Image Setting
During PC input signal:
See page 30.
• Sharpness
• Phase
• Clock
• H. Position
• V. Position
24
ON SCREEN DISPLAY MENU
Main Menu
Image Setting
Submenu
During Video input signal:
Remarks
See page 31.
• Sharpness
• Saturation
• Tint
• 3D Comb Filter
• Noise Reduction
• Aspect Ratio
• H. Zoom
• V. Zoom
• H. Position
• V. Position
4. PIP Setting
See page 33.
• PIP
• Main Source
• Sub Source
• Sub Picture Size
• Sub Pic. Pos.
• Swap
5. OSD Setting
• Transparency
See page 35.
• H. Position
• V. Position
• OSD Timer
6. Audio Setting
• Volume
See page 36.
• Audio
7. Other Setting
• Power Saving
See page 37.
• Mode
• DDC/CI
• DCR
• Recall
8. Auto Brightness
See page 39.
• Enable
• Mode
• Level
9. Input Select
See page 40.
• VGA
• DVI
• HDMI
• CVBS1
• CVBS2
• S-Video
25
ON SCREEN DISPLAY MENU
Main Menu
10. Language
Submenu
Select the OSD language:
EN / FR / DE / ES / IT / PY / RO / PL / CS /
NL / 簡中 / 繁中
11. Information
Displays settings information such as
Input, Resolution, Horizontal and Vertical
Frequency, Time mode, and Firmware
version.
26
Remarks
CHAPTER 5: ADJUSTING THE LCD DISPLAY
5.1 Brightness Setting
N T S C
1. Touch
6 0 H z
B R I G H T N E S S
5 0
B R I G H T N E S S
2. Select BRIGHTNESS menu, then
C O N T R A S T
C O L O U R
B L A C K
I M A G E
P I P
L E V E L
S E T T I N G
A S P E C T
touch the
5 0
S E T T I N G
to call out the OSD window.
5 0
3. Touch the
R AT I O
button.
or
buttons to select
an option.
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
Item
Brightness
Contrast
Black Level
A D J U S T
S E L E C T
Function
Operation
Adjusts the luminance of the
screen image.
Touch the
the value.
or
buttons to adjust
Adjusts the difference between the
Touch the
or
buttons to adjust
black level and the white level.
the value.
Adjusts the black level of the
screen image. Low brightness
setting makes black colour darker.
Touch the
the value.
or
buttons to adjust
Note: Backlight setting is disabled
if Auto Brightness is On.
See comparison illustrations on page 28.
27
Range
0 to 100
0 to 100
0 to 100
ADJUSTING THE LCD DISPLAY
Original Setting
High Setting
Brightness
Contrast
Black Level
28
Low Setting
ADJUSTING THE LCD DISPLAY
5.2 Colour Setting
N T S C
1. Touch
6 0 H z
C O L O U R
B R I G H T N E S S
6 5 0 0 K
C O L O U R
9 3 0 0 K
T E M P.
2. Select COLOUR SETTING menu, then
5 4 0 0 K
S E T T I N G
touch the
s R G B
I M A G E
A U T O
S E T T I N G
C O L O U R
3. Touch the
U S E R
A S P E C T
P I P
R AT I O
S E T T I N G
to call out the OSD window.
R
1 2 8
G
1 2 7
B
1 0 6
button.
or
buttons to select an
option.
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
Item
E N T E R
S E L E C T
Function
Operation
Provides several colour
Touch the
adjustment settings.
the setting.
or
buttons to select
Value
6500K, 5400K, 9300K,
sRGB, USER
Colour temperature can be set to:
• 6500K - This is the default colour temperature commonly used for normal lighting
conditions.
• 5400K - Applies a reddish tint for warmer colours.
• 9300K - Applies a bluish tint for cooler colours.
• sRGB - This is the Red, Green, Blue (RGB) colour standard which is used for colour
management in most industries. This setting displays accurate colours and suitable for
Colour
Temperature
viewing images on the Internet.
• AUTO COLOUR - Operates the white balance and automatically adjusts the colour
settings. Available only during VGA input source signal
1 Select AUTO COLOUR.
2 Touch the
button to activate auto colour.
• USER - This allows users to set the colour temperature by adjusting the R, G, B
settings according to one’s preference.
1 Select USER, then touch the
button
2 Touch the
or
buttons to select among R, G, B option.
3 Touch the
or
buttons to adjust the values between 0 ~ 255.
Note: Activate Recall to return the colour to its default setting.
29
ADJUSTING THE LCD DISPLAY
5.3 Image Setting (PC Source only)
Note: Some submenu items are not available in DVI input source signal.
1 0 2 4 x 7 6 8
1. Touch
6 0 H z
S H A R P N E S S
5 0
B R I G H T N E S S
2. Select IMAGE SETTING menu, then
P H A S E
C O L O U R
5 0
S E T T I N G
touch the
C L O C K
I M A G E
S E T T I N G
R AT I O
3. Touch the
5 0
S E T T I N G
or
buttons to select an
option.
V. P O S I T I O N
P I P
button.
5 0
H . P O S I T I O N
A S P E C T
to call out the OSD window.
5 0
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
Item
Sharpness
Phase
Clock
A D J U S T
S E L E C T
Function
Operation
Adjusts the clarity and focus of the
screen image.
Adjusts the phase timing to
synchronise with the video signal.
Note: Phase is only available when
receiving VGA input signal.
Adjusts the frequency timing to
synchronise with the video signal.
Note: Clock is only available when
receiving VGA input signal.
H. Position
Moves the screen image to the left
(Horizontal Position) or right.
V. Position
(Vertical Position)
Range
Moves the screen image up or down.
30
Touch the
or
adjust the value.
buttons to
0 to 100
ADJUSTING THE LCD DISPLAY
5.4 Image Setting (Video signals)
N T S C
1. Touch
6 0 H z
S H A R P N E S S
5 0
B R I G H T N E S S
2. Select IMAGE SETTING menu, then
S
CA
O TN UT R
RA
A TS I TO N
C O L O U R
5 0
S E T T I N G
touch the
T I N T
I M A G E
S E T T I N G
A S P E C T
P I P
5 0
3 D
R AT I O
C O M B F I LT E R
O N
O F F
N O I S E
O F F
S E T T I N G
M I D
3 D
M O T I O N
O N
O F F
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
button.
or
buttons to select an
option.
H I G H
O S D
S E T T I N G
3. Touch the
R E D U C T I O N
L O W
A N T I - B U R N - I N
to call out the OSD window.
D E - I N T E R L A C E
O N
O F F
V I D E O M O D E
U S E R
T E X T
M O V I E
G R A P H I C
B R I G H T N E S S
H .
P O S I T I O N
V.
P O S I T I O N
5 0
S E L E C T
L A N G U A G E
5 0
I N F O R M AT I O N
E X I T
A D J U S T
Item
Sharpness
Saturation
Tint
S E L E C T
Function
Operation
Range /
Value
Adjusts the clarity and focus of the
screen image.
Adjusts the colour saturation.
Touch the
Adjusts the colour tint.
adjust the value.
or
buttons to
0 to 100
Note: Available only during NTSC
system under S-Video or CVBS
signals.
Enables the 3D Comb Filter feature,
which eliminates cross-colouring or
3D Comb Filter
rainbow swirl on pictures.
Note: Available only during CVBS
Touch the
or
buttons to
select the value.
signal.
3D Comb Filter Off
3D Comb Filter On
31
On
Off
ADJUSTING THE LCD DISPLAY
Item
Function
Operation
Adjusts the noise reduction to help
Noise Reduction
remove noise from images. This
Touch the
helps produce clearer and crisper
select the value.
or
buttons to
Off
Low
Noise Reduction On
Adjusts the aspect ratio of the screen Touch the
or
image.
select the value.
Aspect Ratio
Value
High
images.
Noise Reduction Off
Range /
buttons to
Overscan
Underscan
Native
Aspect ratio can be set to:
• Overscan: The aspect ratio decreases by 5%.
• Underscan: The aspect ratio increases by 5%.
• Native: The aspect ratio returns to its default size.
H. Zoom
(Horizontal Zoom)
V. Zoom
(Vertical Zoom)
H. Position
(Horizontal
Position)
V. Position
(Vertical Position)
Adjusts the horizontal zoom.
Adjusts the vertical zoom.
Touch the
Moves the screen image to the left
or right.
Moves the screen image up or down.
32
or
adjust the value.
buttons to
0 to 100
ADJUSTING THE LCD DISPLAY
5.5 PIP Setting
N T S C
1. Touch
6 0 H z
B R I G H T N E S S
P I P
O F F P I P
C O L O U R
M A I N S O U R C E
V G A D V I H D M I
S E T T I N G
P A P
2. Select PIP SETTING menu, then touch
S E T T I N G
A S P E C T
P I P
S - V I D E O
S - V I D E O
S U B
O T H E R
S E T T I N G
A U T O
I N P U T
buttons to select an
P I C . S I Z E
1
2
3
S U B P I C . P O S .
L + U R + U
S E T T I N G
S E T T I N G
or
option.
C V B S 1 C V B S 2
A N T I - B U R N - I N
A U D I O
3. Touch the
S U B S O U R C E
V G A D V I H D M I
R AT I O
S E T T I N G
O S D
button.
the
C V B S 1 C V B S 2
I M A G E
to call out the OSD window.
L + D
R + D
S W A P
P R E S S
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
A D J U S T
E X I T
Item
S E L E C T
Function
Range /
Operation
Value
Off
PIP
Allows you to select the PIP setting
Touch the
or disable PIP.
select the value.
or
buttons to
PIP
PAP
PIP can be set to:
• Off - Disables PIP.
• PIP - The sub source image is within the main source image.
• PAP - The main source and sub source images are displayed side by side.
VGA / DVI
Main Source
Allows you to select the main source
Touch the
signal.
select the value.
or
buttons to
/ HDMI /
CVBS1 /
CVBS2 /
S-VIDE0
VGA / DVI
Sub Source
Allows you to select the sub source
Touch the
signal.
select the value.
or
buttons to
/ HDMI /
CVBS1 /
CVBS2 /
S-VIDE0
33
ADJUSTING THE LCD DISPLAY
Note: Any input signal may be set as the main or the sub source signal. However, some input signals are not
supported to be paired together as the main and the sub source signals.
Refer to the following table for compatibility options.
Table 5.1 PIP Compatibility Table
Main
VGA
DVI
HDMI
CVBS1
CVBS2
S-VIDEO
VGA
X
X
X
O
O
O
DVI
X
X
X
O
O
O
CVBS1
O
O
O
X
X
X
CVBS2
O
O
O
X
X
X
S-VIDEO
O
O
O
X
X
X
Sub
Item
Function
Operation
Range /
Value
Allows you to select the size of the
Sub Pic. Size
(Sub Picture
Size)
sub source image. Available only in
PIP mode.
Touch the
• 1 - Small image size.
or
buttons to
select the value.
1
2
3
• 2 - Medium image size.
• 3 - Large image size.
Allows you to select the position of
the sub source image. Available only
Sub Pic. Pos.
(Sub Picture
Position)
in PIP mode.
L+U
Touch the
or
buttons to
adjust the value.
R+U
L+D
R+D
• L+U - Sets the image on the upper left corner of the screen.
• R+U - Sets the image on the upper right corner of the screen.
• L+D - Sets the image on the lower left corner of the screen.
• R+D - Sets the image on the lower right corner of the screen.
Swap
Swaps the main source and sub
Touch the
source signals.
34
button to swap the image sources.
ADJUSTING THE LCD DISPLAY
5.6 OSD Setting
N T S C
1. Touch
6 0 H z
T R A N S PA R E N C Y
5 0
B R I G H T N E S S
2. Select OSD SETTING menu, then touch
H . P O S I T I O N
C O L O U R
5 0
S E T T I N G
S E T T I N G
A S P E C T
P I P
button.
the
V. P O S I T I O N
I M A G E
to call out the OSD window.
5 0
O S D
R AT I O
3. Touch the
T I M E R
1 0 0
or
buttons to select an
option.
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
A D J U S T
Item
Transparency
H. Position
(Horizontal
Position)
S E L E C T
Function
Operation
Range
Adjusts the transparency level of the
OSD screen.
Moves the OSD window to the left or
0 to 100
right of the screen.
Touch the
or
buttons to
adjust the value.
V. Position
Moves the OSD window up or down
(Vertical Position)
the screen.
Sets the length of time (in seconds)
OSD Timer
the OSD screen is displayed. When
the time elapses, the OSD screen is
automatically inactivated.
35
5 to 100
ADJUSTING THE LCD DISPLAY
5.7 Audio Setting
N T S C
1. Touch
6 0 H z
A U D I O
O N
B R I G H T N E S S
C O L O U R
I M A G E
to call out the OSD window.
2. Select AUDIO SETTING menu, then
V O L U M E
5 0
touch the
button.
S E T T I N G
A S P E C T
P I P
S E T T I N G
O F F
3. Touch the
R AT I O
or
buttons to select an
option.
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
A D J U S T
Item
S E L E C T
Function
Operation
Range /
Value
Adjusts the volume level of the builtin speaker.
Volume
Note: If volume is adjusted but Audio
is set to “Off”, no sound comes out
Touch the
or
buttons to
adjust the value.
0 to 100
from the speaker.
Audio
Turns the audio speaker ON or OFF.
36
Touch the
or
select the value.
buttons to
On
Off
ADJUSTING THE LCD DISPLAY
5.8 Other Setting
N T S C
1. Touch
6 0 H z
P O W E R
O N
B R I G H T N E S S
S AV I N G
O F F
2. Select OTHER SETTING menu, then
M O D E
C O L O U R
T E X T
S E T T I N G
G R A P H I C
S E T T I N G
O N
O F F
R AT I O
O N
O F F
buttons to select an
option.
R E C A L L
P I P
or
3. Touch the
D C R
A S P E C T
button.
touch the
D C C / C I
I M A G E
to call out the OSD window.
S E T T I N G
P R E S S
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
Item
A D J U S T
S E L E C T
Function
Operation
Range /
Value
Enables or disables power saving mode.
When the LCD display turns into power
saving mode, the screen turns black and the
LED indicator lights AMBER.
Power Saving
Note: The amount of time for the display
to enter power saving varies depending on
Touch the
the Source Detect setting. If Source Detect
select the value.
or
buttons to
On
Off
is Auto, the display checks all input source
signals before entering power saving mode
if no signal is detected; this takes up more
time. If Source Detect is Manual, the display
enters power saving mode right away.
Sets the current mode for better image
display.
Touch the
or
select the value.
buttons to
Text
Graphic
Available only during computer input signal, when the resolution is either of the following:
640 x 350, 640 x 400, 720 x 350, or 720 x 400.
Mode
For optimal performance, select:
• Text - This mode is suitable for viewing text documents when the resolution is 720 x
400 or 720 x 350.
• Graphic - Graphics mode is suitable for viewing images when the resolution is 640 x
350 or 640 x 400.
37
ADJUSTING THE LCD DISPLAY
Item
Function
Operation
Activates the DDC/CI protocol to allow users
DDC/CI
to configure the monitor by a software using
two wires on the VGA or DVI cables.
Touch the
or
buttons to
Range /
Value
On
Off
select the value.
Activates DCR. This feature provides
DCR
automatic adjustment of picture brightness
(Dynamic
and contrast at high speed and dynamic
Contrast Ratio) contrast range, such as when watching
Touch the
or
buttons to
select the value.
On
Off
movies. DCR is suitable for indoor viewing.
Recall
Use to recall all to default settings, except
Language, PIP, and the input source.
38
Touch the
button.
-
ADJUSTING THE LCD DISPLAY
5.9 Auto Brightness
5.9.1 EcoSmart Sensor
With the built-in EcoSmart sensor, users can enable the Auto Brightness feature to automatically adjust the
LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise
energy efficiency.
N T S C
1. Touch
6 0 H z
E N A B L E
O N
B R I G H T N E S S
O F F
2. Select AUTO BRIGHTNESS menu, then
M O D E
C O L O U R
A U T O
S E T T I N G
U S E R
touch the
L E V E L
I M A G E
S E T T I N G
A S P E C T
P I P
to call out the OSD window.
8 0
3. Touch the
R AT I O
button.
or
buttons to select an
option.
S E T T I N G
A N T I - B U R N - I N
O S D
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
A D J U S T
Item
Enable
S E L E C T
Function
Operation
Enables or disables auto brightness.
or
buttons to
or
On
Off
select the value.
Touch the
Sets the auto brightness mode.
Mode
Touch the
Value
buttons to
Auto
User
select the value.
The mode can be set to:
• Auto - This mode is the default mode. The LCD brightness automatically adjusts to
the ambient brightness.
• User - Allows you to manually adjust the LCD brightness.
Allows you to set the level of LCD
Level
brightness. Available only in USER
mode.
39
Touch the
or
adjust the value.
buttons to
0 to 100
ADJUSTING THE LCD DISPLAY
5.10 Input Select
N T S C
1. Touch
6 0 H z
V G A
P R E S S
B R I G H T N E S S
2. Select INPUT SELECT menu, then touch
D V I
C O L O U R
P R E S S
S E T T I N G
the
H D M I
I M A G E
S E T T I N G
A S P E C T
P I P
button.
P R E S S
3. Touch the
C V B S 1
R AT I O
P R E S S
or
buttons to select an
option.
C V B S 2
S E T T I N G
P R E S S
S - V I D E O
A N T I - B U R N - I N
O S D
to call out the OSD window.
P R E S S
S E T T I N G
A U D I O
S E T T I N G
O T H E R
S E T T I N G
A U T O
I N P U T
B R I G H T N E S S
S E L E C T
L A N G U A G E
I N F O R M AT I O N
E X I T
E N T E R
Item
S E L E C T
Function
Operation
VGA
Sets VGA as the input source signal.
DVI
Sets DVI as the input source signal.
HDMI
CVBS1
CVBS2
S-VIDEO
Value
Sets HDMI as the input source
signal.
Sets CVBS1 as the input source
signal.
Sets CVBS2 as the input source
signal.
Sets S-Video as the input source
signal.
40
Touch the
button to select.
-
CHAPTER 6: APPENDIX
6.1 Warning Messages
Warning Messages
Cause
The resolution or the refresh rate of
INPUT SIGNAL
OUT OF RANGE
Solution
• Change the resolution or the
the graphics card of the computer
refresh rate of the graphics
is set too high.
card.
The LCD display cannot detect the
input source signal.
• Check if the input source is
turned ON.
• Check if the signal cable is
properly connected.
NO
SIGNAL
• Check if any pin inside the
cable connector is twisted or
broken.
OSD
LOCK OUT
The OSD has been locked by the
user.
• Unlock the OSD. Refer to page
18.
41
APPENDIX
6.2 Troubleshooting
Problem
No picture.
• LED indicator is OFF.
Possible Cause and Solution
• Check if the LCD display is turned ON.
• Check if the power cord is properly connected to the LCD display.
• Check if the power cord is plugged into the power outlet.
• LED indicator is
AMBER.
• Check if the computer is turned ON.
• Check if the computer is in standby mode, move the mouse or press
any key to wake up the computer.
Image position is incorrect.
• Adjust the H. POSITION and V. POSITION values. See IMAGE
SETTING on page 30 (for VGA source) or page 31 (for video signals).
The displayed texts are
blurry.
The OSD menu can’t be
• For VGA input, touch
on the keypad to auto-adjust the display.
• Adjust the IMAGE SETTING (see page 30).
• The OSD is locked; unlock the OSD (see page 18).
called out.
Red, blue, green, white
dots appear on screen.
• There are millions of micro transistors inside the LCD display. It is
normal for a few transistors to be damaged and to produce spots. This
is acceptable and is not considered a failure.
No audio output.
• Check if the volume is set to 0 (see page 18 or 36).
• Check if AUDIO is set to OFF (see page 36).
• For VGA or DVI input, check the audio setting of the computer.
PIP mode does not work.
• The main and sub input source signals are not compatible to be
displayed together in PIP mode. Check the PIP Compatibility Table for
details (see page 34).
Cannot adjust Backlight
setting.
The displayed picture looks
• AUTO BRIGHTNESS setting is ON, disable AUTO BRIGHTNESS (see
page 39).
• Adjust the aspect ratio (see page 32).
distorted.
Dew formed on or inside
the LCD display.
• This normally happens when the LCD display is moved a cold room to
a hot room temperature. Do not turn ON the LCD display, wait for the
dew condensation to disappear.
Mist formed inside the
glass surface.
• This happens due to humid weather conditions. This is a normal
occurrence. The mist will disappear after a few days or as soon as the
weather stabilizes.
42
APPENDIX
Problem
Faint shadows from a
static image appear on the
screen.
Possible Cause and Solution
• Turn off the LCD display for extended periods of time.
• Use a screen saver or a black and white image and run it for extended
periods of time.
43
APPENDIX
6.3 Transporting the LCD Display
To transport the LCD display for repair or shipment, place the display in its original packaging carton.
1
Put all the accessories in the box (if necessary). Place the two foam cushions on
each side of the LCD display for protection.
2
Place the LCD display down in the box.
3
Place the accessories box on the designated area (if necessary).
4
Close and tape the box.
44
CHAPTER 7: SPECIFICATIONS
7.1 Display Specifications
X-22
Panel
Panel Size
21.5”
23.6”
Max. Resolution
Audio
FHD 1920 x 1080
Pixel Pitch
0.2482 mm
0.2715 mm
Brightness
250cd/m2
300cd/m2
Contrast Ratio
2,000,000:1 (DCR)
Viewing Angle (H/V)
170°/160° (Typical)
Display Colour
16.7M
Response Time
5ms (Typical)
Frequency (H/V)
Input
X-24
H: 24 kHz - 82 kHz
H: 24 kHz - 82 kHz
V: 50 Hz - 75 Hz
V: 50 Hz - 75 Hz
VGA
15-Pin D-Sub
15-Pin D-Sub
DVI
24-Pin DVI-D
24-Pin DVI-D
CVBS
RCA x 2
RCA x 2
S-Video
4-Pin mini DIN
4-Pin mini DIN
HDMI
HDMI x 1
HDMI x 1
Audio In
1 x stereo audio in for PC (audio jack, 3.5 Ø)
1 x stereo audio in for CVBS (RCA) and S-VIDEO
Power In
Speaker Out
1.5W x 2
Power Supply
External
Power Requirements
DC 12V, 2A
DC 12V, 2.3A
Consumption
< 28W (On)
< 29W (On)
< 0.5W (Stand-by)
< 0.5W (Stand-by)
< 0.5W (Off)
< 0.5W (Off)
Operating
Temperature
0 °C ~ 40 °C (32 °F ~ 104 °F)
Conditions
Humidity
Storage
Temperature
Conditions
Humidity
Weight
Without Base
6.2 kg (13.7 lbs)
7.3 kg (16.1 lbs)
With Base
6.9 kg (15.2 lbs)
7.8 kg (17.2 lbs)
10% ~ 90%
-20 °C ~ 60 °C (-4 °F ~ 140 °F)
5% ~ 95%
Note: All specifications are subject to change without prior notice.
45
SPECIFICATIONS
7.2 Display Dimensions
7.2.1
X-22 Dimensions
282.4mm
53.5mm
32.6mm
368.5mm
100mm
513.2mm
324.3mm
100mm
75mm
75mm
155mm
7.2.2
227.4mm
X-24 Dimensions
282.4mm
53.5mm
32.6mm
396.8mm
100mm
562.4mm
352.6mm
100mm
75mm
75mm
155mm
227.4mm
Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan.
46
Download PDF
