Digital & Wireless Automatic Mixer

Installation and Operation

Contents

Introduction………………………………………………………………………… …………… ..P3

Receiver Installation and Connections… … … … … … … … … … … … … … … … … … … … ….P4

Installation…………………………………………………………………………………………P4

Connections………………………………………………………………………………………..P4

Wireless Automatic Mixer Controls and Functions……………………………………………P5

WAM-400 Front panel……………………………………………………………………………P5

WAM-400 Rear panel… … … … … … … … … … … … … … … … … … … … … … … … … … … … …P6

Option for the wireless transmitters……………………………………………………………P7

Wireless Boundary Microphone UB-200 … … … … … … … … … … … … … … … … … … … ….P7

Wireless Conferencing Microphone ED-3000… … … … … … … … … … … … … … … … … …P8

Wireless Handheld Microphone UH-200……………………………………………………….P9

Wireless Bodypack Transmitter UT-200… … … … … … … … … … … … … … … … … … … …..P10

LCD Display………………………………………………………………………………………P11

Main Display… … … … … … … … … … … … … … … … … … … … … … … … … … … … … … …

P

11

Channel Display … … … … … … … … … … … … … … … … … … … … … … … … … … … … … ….P13

System Setup………………………………………………………………………………………P19

Main System Setup… … … … … … … … … … … … … … … … … … … … … … … … … … … … …

P19

Each Channel Setup… … … … … … … … … … … … … … … … … … … … … … … … … … … P20

Networking Multiple Mixers……………………………………………………………………P20

Optional Functions………………………………………………………………………………P21

Specifications… … … … … … … … … … … … … … … … … … … … … … … … … … … … P23

Thank you for choosing a RELACART professional wireless system. You have joined thousands of other satisfied customers. Our years of professional experience of design and manufacturing to ensure our products' quality, performance and reliability.

Introduction

①UHF band 490 – 860MHz wireless automatic mixer for a maximum of four wireless microphones.

②Bright and easy-to-read LCD display shows RF/AF, level and other operation status.

③Automatic gain adjustment by microprocessor control.

④5-unit daisy chain by accessory link cable to control up to 20 units microphones.

⑤Select the simultaneous open microphones to 1 unit, 2 units, 3 units or 4 units.

⑥Set the Priority Microphone.

⑦Specific circuitry helps control feedback.

⑧Corresponding various kind of application in conference room due to priority-select function and gatehold time setting

⑨Last microphone on selectable for continuous room ambiance.

⑩Microphone hold time for 0.3s to 1.5s.

everal inputs / outputs for audio signals: wo RCA outputs to realize long distance with low noise transmission.

CA iput / output for recordings.

ne balanced line output (6.3mm jack ).

ne 3-pin XLR.

Two RS-485 interface for external auto video tracking system or auto central control system.

Cooperates with RELACART wireless boundary microphone UB-200, wireless conferncing microphone ED-3000, handheld microphone UH-200 or lapel microphone UT-200.

The WAM-400 wireless automatic mixer is ideal for meetings, seminars, teleconferencing, house of worship services, broadcast and conference applications.

Receiver Installation and Connections

Installation:

For better operation the receiver should be at least 3ft. (1m) above the ground and at least 3ft. away from a wall or metal surface to minimize reflections.

Attached a pair of UHF antennas to the antenna input jacks, the antenna are normally positioned in the shape of a “V” (both 45°from vertical) for best reception.

Keep antennas away from noise sources such as computer, digital equipment, motors, automobiles and neon lights, as well as away from large metal objects.

Keep open space between the receiver and transmitter for better reception.

The transmitter should be at least 3ft. from the receiver.

Connections:

The switching power supply is designed to operate properly from any AC power source 100-240V,

50/60Hz without user adjustment. Simply connect the receiver to a standard AC power outlet, using only an IEC-type input cordset approved for the country use. Power to the unit is controlled by the front panel power switch.

There are two audio outputs on the rear panel: an XLR microphone output and a 1/4” (6.3mm) phone jack instrument output. The two isolated audio outputs permit simultaneous feeds to two different inputs. Use the appropriate shielded audio cable for connections between the receiver and the input(s) of the mixer or other equipment.

Wireless Automatic Mixer Controls and Functions

Figure A: WAM-400 Front Panel

Power Switch.

CONTROL Knob: Rotate this knob to select function options and edit function choice.

Infrared Data Transfer Window (SYNC): Transmit system data from the receiver to the transmitter, From CH1 to CH4 can use this window.

LCD Window: Liquid Crystal Display indicates control setting and operational readings.

Channel Buttons: Press CH1 / CH2 / CH3 / CH4 button, in conjunction with the CONTROL knob, to step through menus, select operating frequency and infrared data transfer.

Figure B: WAM-400 Rear Panel

1

2

3 4 5 6 7 8 9 10 11

Antenna Input Jack: BNC type antenna connector for tuner ”B”, attached the antenna directly.

RCA Audio Line Input: Can be connected to the input of mixer / MP3 / DVD.

RCA Audio Line Output: Can be connected to the output of mixer / MP3 / DVD.

Balanced Output Jack: XLR type connector. A standard 2 conductor shielded cable can be used to connect the receiver output to a balanced microphone level input on a mixer or integrated amplifier.

Unbalanced Output Jack: 1/4” (6.3mm) phone jack, can be connected to an aux-level input of a mixer, guitar amp or tape recorder.

Link In: Use a Relacart standard connecting cable to connect with the Link Out from another WAM-

400, can link up for 5 units WAM-400.

Link Out: Use a Relacart standard connecting cable.

RS-232 Jack: Can be connected to Automatic Video Tracking System VTS-1000 or the other control systems.

External Control: To connect with the control systems.

DC Power Input: 12V / 700mA.

Antenna Input Jack: BNC type antenna connector for tuner attached the antenna directly.

Option for the wireless transmitters

Wireless Boundary Microphone UB-200

Wireless Conferencing Microphone ED-3000

Power Button a)Power Supply Button: Press power button in 3 seconds to turn on power and the indicator light turns into green, 3 seconds to turn off the power.

b)Mute Button: Once the power is ON, press this button 1 second, it will be mute, and LCD screen display

“MUTE”, you will also find the indicator light turns into orange. Press 1 second more to eliminate “Mute” function, letter “MUTE” disappear on the LCD screen, indicator light is back to green.

LCD Window: Liquid crystal display indicates operational frequency / channel, mute, lock status and battery condition. The transmitter's “fuel gauge” battery indicator displays a maximum of 4 bar segments.

When it leaves 1 bar segment, the batteries should be replaced immediately to ensure continued operation.

Infrared Data Receiving Window (iR): Use to receive the data signal from the receiver.

Battery Door Switch: Open the battery door by sliding the switch.

Battery Compartment: Insert 2 fresh 1.5V AA batteries. (Alkaline type is recommended, always replace both batteries.)

Warn: Observe correct polarity as marked inside the battery compartment to avoid damage to the internal electric parts.

Power Button.

LCD Window: Liquid crystal display indicates operational frequency and battery condition. The transmitter's “fuel gauge” battery indicator displays a maximum of 4 bar segments. When it leaves 1 bar segment, the batteries should be replaced immediately to ensure continued operation.

Infrared Data Receiving Window (iR): Use to receive the channel data from the receiver

Battery Cover: Unscrew it can reveal the battery compartment.

Battery Compartment: Insert 2 fresh 1.5V AA batteries. (Alkaline type is recommended, always replace both batteries.) Observe correct polarity as marked inside the battery compartment.

Wireless Handheld Microphone UH-200

Wireless Bodypack Transmitter UT-200

① Microphone Head: The microphone head is separate to change other microphone head if needed.

LCD Window: Liquid crystal display indicates operational frequency and battery condition. The transmitter's “fuel gauge” battery indicator displays a maximum of 4 bar segments. When it leaves 1 bar segment, the batteries should be replaced immediately to ensure continued operation.

Infrared Data Receiving Window (iR): Use to receive the channel data from the receiver.

Battery Cover: Unscrew it can reveal the battery compartment.

Battery Compartment: Insert 2 fresh 1.5V AA batteries. (Alkaline type is recommended, always replace both batteries.) Observe correct polarity as marked inside the battery compartment.

Power Button.

① Antenna

Power Button

Mute Button: When the transmitter is muted, it products RF with no audio signal modulation; when the transmitter is un-muted, it products both RF and audio.

Audio Input Jack: To connect 4-pin mini-XLR connector.

LCD Window: Liquid crystal display indicates operational frequency, channel and battery condition. The transmitter's “fuel gauge” battery indicator displays a maximum of 4 bar segments. When it leaves 1 bar segment, the batteries should be replaced immediately to ensure continued operation.

Infrared Data Receiving Window (iR): Use to receive the channel data from the receiver.

Battery Door Switch: Open the battery door by sliding the switch.

Battery Compartment: Insert 2 fresh 1.5V AA batteries. (Alkaline type is recommended, always replace both batteries.) Observe correct polarity as marked inside the battery compartment.

AF / GT Audio Input Switch: Connect an audio input device (microphone or guitar cable) to the audio input jack on the top of the body-pack transmitter. Choose AF for microphone input, then GT for guitar cable to connect with guitar or other instruments.

05

LCD display

Main display:

1

2 3

0 1

3 3

0 3

3 4

4

A F

AUTO

6

5

1, Symbol: This symbol will light when the channel is speaking.

2, Channel Display: Channel on use.

3, RF Signal: Show the strength of receiving signal.

4, Main Volume: Show the volume output.

5, Working Status: Display the operating status.

6, Scroll Bar Display.

Channel display:

2

3

RF

AF

1

RX1

4 5 6

7 1 3 . 45 0 M H z

C H 0 1

SYNC

1 / 2

7

9

8

1, Channel number display: Show the operating channel (RX1 means receiving channel 1)

2, RF signal

3, AF signal

4, Channel display

5, Frequency display

6, Linking Multiple WAM-400: If more than one WAM-400 link together, this sign appears and is flashing.

7, Number of Linking WAM-400: ½, 1 means the first wireless mixer, 2 means the total linking mixers.

8, Operating Menu Display: Display the operating menu.

9, Scroll Bar Display.

P13

06

System Setup

Main System Setup

1)Turn on the wireless mixer, the LCD displays the preset data.

0 1

3 3

0 3

3 4

A F

AUTO

2)Rotate the CONTROL knob to view the setting status.

0 1

3 3

0 3

3 4

A F

LAST LOCK

3)To enter the menu mode: Press and hold the CONTROL knob 3 seconds to enter the edit mode, rotate this knob once to select and set MODE, Last Lock, Hold Time, Priority Select, Threshold Level,

Volume Level, Language Select, Speak Number, Work Set, CD Vol Level, PC Vol Level, or Exit.

①, MODE: Selecting “MODE”, then press CONTROL knob to enter edit mode, rotate this knob, the LCD will display “Manual” or “Auto”, if stopping on “Manual”, the Threshold Level will be set by manual; if stopping on “Auto”, the Threshold Level will be set automatically by the sold Level will be set automatically by the system's micro processor ( if MODE is “Auto”, there will be NO

“Threshold Level” setting ). Press CONTROL knob to confirm the desire choice, then LCD move to the next setting.

MODE

②, Last Lock: Lock the last microphone for continuous speaking. Selecting “Last Lock”, then press CONTROL knob to enter edit mode, rotate this knob, the LCD will display “ON” or “OFF”, if stopping on “ON”, the last microphone will be always ON until the a new activated microphone to override it; if stopping on “OFF”, the microphone will be off after the “Hold Time”. Press

CONTROL knob to confirm the desire choice, then LCD move to the next setting.

LAST LOCK

P14

P15

③, Hold Time: Set the activated microphone's hold time after the speaker stop speaking. (Make sure the microphone is unlocked.) Select “Hold Time”, then press CONTROL knob to enter edit mode, rotate this knob, the LCD will display in 0.1S step, providing a 0.1S to 1S range, Press

CONTROL knob to confirm the desire choice, then LCD move to the next setting.

HOLD TIME

④, Priority Select: Set the microphone at priority. Select “Priority Select”, then press CONTROL knob to enter edit mode, rotate this knob, to choose the priority channel, if there are several receivers to link together for use, the LCD will display the first one A, the second one B, until the fifth one E, can set two channels at priority at the most, press CONTROL knob to confirm the desire choice. Finally contrarotate CONTROL knob, until the arrowhead on the lower right corner becomes dotted line, press CONTROL, LCD move to the next setting.

PRIORITY SELECT

⑤, Threshold Level: Change the output limiter threshold, under “MODE” is “Manual” (factory preset is “Auto”. Select “Threshold Level”, then press CONTROL knob to enter edit mode, rotate this knob,

LCD will display 1dBm step, providing a 1dBm to 10dBm range. Press CONTROL knob to confirm the desire choice, then LCD move to the next setting.

THRESHOLD LEVEL

⑥, Volume Level: Main volume level output setting. Select “Volume Level”, then press CONTROL knob to enter edit mode, rotate this knob, LCD will display 1dBm step, providing a -60dB to 5dB range. Press CONTROL knob to confirm the desire choice, then LCD move to the next setting.

VOLUME LEVEL

P16

P17

⑦, Language Select, Both “Chinese” and “English” are available.

LANGUAGE SELECT

⑧, Speak Number: Set the simultaneous channels, there are 1 channel, 2 channels, 3 channels and 4 channels are available.

SPEAK NUMBER

⑨, Work Set: Select “Pelegate” there are two or more units to link together for use; select

“Chairman”, there is one unit to use only.

WORKS SET

⑩, CD VOL Level: Volume level setting in 1dBm step, providing a -64dB to 0 dB range.

CD VOL LEVEL

⑾, PC VOL Level: Volume level from computer, 1dBm step, providing a -64dB to 0 dB range.

PC VOL LEVEL

⑿, Exit: To exit the system.

EXIT

P18

P19

WAM-400 Menu Display:

CONTROL

(3 seconds)

Mode

Manual (“Threshold Level” setting)

Auto ( Factory preset, automatic setting by system micro processor)

Last Lock

ON ( the microphone will be always “ON”)

OFF ( the microphone will be OFF after the “Hold Time”)

Hold Time (Set the activated microphone's hold time after the speaker stop speaking)

Priority Select (Set the microphone at priority, 2 units at the most)

Threshold Level (Change the output limiter threshold, under “MODE” is “Manual”)

Volume Level (System main volume output)

Language Select

Chinese

English

Speak Number (Set the simultaneous speaking channels, 4 channel at the most)

Pelegate (Two or more mixers link together for use)

Works Set

Chairman (One mixer use only)

CD Vol Level (CD volume level)

PC Vol Level (Computer volume level)

Exit (Exit the system)

Each Channel Setup

1, Press CH1 button, rotate “CONTROL” knob to select and set Sync, Scan, Channel, SQELCH, or Volume, press “CONTROL” again to enter edit mode:

①Sync: Infrared data transmitting. Let the transmitter's IR window face to “SYNC” window, press “CONTROL”, to receive the data signal from the receiver.

②Scan: Stop at “Scan”, then press “CONTROL” knob, system will auto-scan and lock on to an open, interference-free frequency in 40 S.

③Channel: Stop at “Channel”, then press “CONTROL” knob to select the preset 32 channels manually.

④SQELCH: Stop at “SQELCH”, then press “CONTROL” knob, the squelch level is adjustable in ten 5dB steps, providing a 50dB range. Press “CONTROL” confirm the desired choice. (If interference is a problem, first consider trying a different frequency, either manually or scanning.)

⑤Volume: Volume output of CH1, stop at “Volume”, then press “CONTROL” knob, the volume output is adjustable in sixty-five 5dB steps, providing a -60dB to 5dB range. Press “CONTROL” confirm the desired choice.

2, Same operation as CHI, to set CH2, CH3 and CH4.

Channel Setup Menu Display

CH1-CH2-CH3-CH4

Sync (Infrared data transmitting)

Scan (Automatic frequency scan)

Channel (Select frequency manually)

SQELCH (0dB to 50dB)

Volume (-60dB to 5dB)

P20

P21

07

Networking Multiple Mixers

The first mixer (master)

The second mixer (slave)

The third mixer (slave)

If additional inputs are needed, more

WAM-400 mixers (as many as 5) can be linked using supplied link cables to control up 20 units microphones.

To link multiple mixers, connect the LINK

OUT of the first mixer to the LINK IN of the next mixer, finally connect the LINK OUT jack of the last mixer to the LINK IN jack of the first mixer.

As long as the link jacks of all mixers are connected, set up the master unit, then the automatic mixing functions will be opened, the mater unit can control the other 4 units salve, but each slave's functions of each channel can be used independently. Volume output of these 5 units is from the master unit.

The fourth mixer (slave)

The fifth mixer (salve)

08

Optional Functions

Automatic video tracking connection

5

4 3 2 1

Logic connection

5 4 3 2 1

9

RS-232

7 8 6

The pin connections:

1: NC (unconnected)

2: TC (data output)

3: RX (data input)

4: NC (unconnected)

5: GROUND

6: NC (unconnected)

7: NC (unconnected)

8: NC (unconnected)

9: NC (unconnected)

NOTE: The automatic video tracking system VTS-1000 must be connected to the master unit.

9 7 8 6

EXTERNAL CONTROL(RS-232)

Pin connections:

1: CH1 IN

2: CH3 IN

3: CH1 OUT

4: CH3 OUT

5: GROUND

6: CH2 IN

7: CH4 IN

8: CH2 OUT

9: CH4 OUT

The logic functions of the WAM-400 expand the mixer's range of installation and control options.

Control Input (IN): This microphone will be mute when its channel receives low level from external control; this microphone will open when its channel receives high level from external control.

Control Output (OUT): When this microphone is opened, its channel transmits high level; when this microphone is mute, its channel transmit low level.

P22

P23

07

Specifications

WAM-400 Mixer

Power supply: DC12V

Maximum current: 1A

Carrier Frequency Range: 490MHz~860 MHz

Band Width: 32 MHz

Frequency Stability : ± 10 ppm

Modulation Mode: FM

Sensitivity: 5dBuV, S/N>60dB at 25 deviation

Max.Deviation Range : ±45 KHz

Distortion: <0.9%

Frequency Response: 65~16KHz

S/N: 100dB

Audio Output: RCA Jack (X3); 6.3mm Jack (X1); XLR (X1)

Audio Input / Output: RCA Jack (X1); 6.3mm Jack (X1)

Communication Port: RS-485 (X2)

Recording Output Level: LINE Output - 10dBV

Balanced Output Level: LINE Output - 10dBV

Audio Input Leve: lLINE Input- 10Dbv

UB-200 Boundary Microphone

Element: Fixed-charge back plate, permanently polarized condenser

Polar Pattern: Half-cardioid (cardioid in hemisphere above mounting surface)

Carrier Frequency Range: 490MHz~860 MHz

Modulation Mode: FM

Frequency Response: 50-17,000 Hz

Max.Deviation Range: ±45 KHz

Operating Range: 60M typical ( in open space)

Current Consumption: 90mA, typical

RF Power Output: 30mW

Dynamic Range (Typical): > 90 dB,1 kHz at Max SPL

Battery: AA X 2

Battery Current / Life: Approximately 10 hours

UH-200 Handheld Microphone

Carrier Frequency Range: UHF 618-936 MHz

Oscillation: PLL synthesized

Harmonic radiation: <-63dBm

Bandwidth: 32MHz

Max.Deviation Range: ±45KHz

Microphone Element: Cardioid Dynamic / Cardioid Condenser

RF Power Output: 15mW

Battery: AA X 2

Current Consumption: 90mA ( typical)

Battery Current / Life: Approximately 15 hours

Dimension: 52(Φ) X 252 (L)

Weight: 208g ( w/o battery)

P24

P25

UT-200 Body-pack Transmitter

Carrier Frequency Range: UHF 618-936 MHz

Oscillation: PLL synthesized

Harmonic radiation: <-63dBm

Bandwidth: 32MHz

Max.Deviation Range: ±45KHz

Input Connector: 4-pin mini-XLR connector

RF Power Output: 15mW

Battery: AA X 2

Current Consumption: 90mA (typical)

Battery Current / Life: Approximately 15 hours

Dimension: 95(H) X 65(W) X 25(D)

Weight: 165g

ED-3000 Conferencing Microphone

Carrier Frequency Range: UHF 618-936 MHz

Oscillation: Quartz-controlled fixed frequency

Harmonic radiation: <-63dBm

Bandwidth: 32MHz

Max.Deviation Range: ±45KHz

Input Connector: 4-pin mini-XLR connector

RF Power Output: 8mW

Battery: AA X 2

Current Consumption: 85mA, typical

Battery Current / Life: Approximately 13 hours

Dimension: 340mm, 420mm

Weight: 600g ( w/o battery)

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
