WE OFFER A RELIABLE PARTNERSHIP
Carl Stahl started in 1880 as a small ropemaker specializing in
agricultural products and has grown to an enterprise with more than
1100 employees operating from over 52 locations around the world.
This stainless Steel wire rope specialist, Carl Stahl Benelux, located
in Zaandam, is not just a supplier of wire rope, we also produce and
stock a complete range of end fittings.
We offer you a full range of lifting and hoisting equipment, Micro- and
TechnoCables for medical, automotive, or general industrial use.
For architectural applications we have our architectural range of
products which includes X-TEND; a stainless steel cable net, I-SYS;
an architectual wire rope system and POSILOCK; an interior design
wire rope suspension system.
Our in-house swaging facilities go up to 32 mm and we have pressing facilities to 30 mm, and of course the whole range of products is
available through all the other Carl Stahl companies.
We also have an extensive range of products presented in our new
“Company Equipment” catalogue.
Innovative products are always being sought, the latest addition to
our range is Nokon; a unique highly efficient “Bowden” cable system
for sports and industrial applications.
In 1997 we decided to open a new subsidiary in Europe specializing in
Stainless Steel wire ropes and hardware.
Our Headquarters
in Süssen, Germany
This new Stainless Steel catalogue offers you an exclusive program
for high quality products.
Influenced by our strong background in yachting we have also included a wide range of synthetic fiber and high performance ropes
together with fittings and blocks.
Don’t hesitate to call us whenever you have any questions about
stainless Steel.
Enjoy the new catalogue.
Index
We offer a reliable partnership
2-5
Stainless Steel Wire Ropes - Monel Wire and Microcables
6- 21
Stainless Steel Wire Rope Tools
Wire Rope Clips - Thimbles and Sleeves
22 - 37
Stainless Steel Shackles - Carbine Hooks
Quicklinks - Swivels and Snapshackles
38 - 65
Eyenuts - Eyebolts - U-Bolts and Rings
66 - 75
Swaging Tools - Swage and Swageless
End Fittings and Rigging Screws (Blue Wave)
76 - 122
Swage and Swageless
End Fittings - Rigging Screws and Insulators (HI-MOD)
123 - 155
Swageless end Fittings (STA-LOK)
156 - 159
Swage end Fittings (SAVA SWAGE)
160 - 162
Guardrail Stanchions and Fittings
163 - 168
Winches - Ratches - Hooks and Hoisting Slings
169 - 173
Stainless Steel Chain - Hooks - Masterlinks - Chain Slings and Wire Rope Slings
174 - 185
Stainless Steel Tie Rod System
186 - 189
Composite Rigging
190 - 194
Fibre Ropes - Fibre Rope Tools (Gleistein)
195 - 248
Rope and Wire Rope Blocks
249 - 265
© Copyright 01/2011 by Carl Stahl GmbH
No part of this catalogue may be reproduced in any form (print, photocopy, microfilm or otherwise) nor edited, copied or distributed using electronic
systems without the written permission of Carl Stahl GmbH. Subject to errors and technical modifications.
3
Mechanical Properties of Stainless Steel
Inch
Millimeter
1/32
0,794
AISI
DIN
1/16
1,588
USA
W-Dld
3/32
2,381
1/8
3,175
5/32
3,968
3/16
4,763
1/4
6,350
5/16
7,938
3/8
9,525
7/16
11,113
1/2
12,700
9/16
14,288
5/8
15,875
3/4
19,050
7/8
22,225
1
25,400
1 1/8
28,575
1 1/4
31,750
1 3/8
34,925
kg
1000
at 20° C
1000
=
N
9810
=
daN
981
=
kN
9,81
DIN
W-Dld
Yield Strength
0,2 % (N/mm2)
at 20° C
Tensile
Strength
(N/mm2)
350
700-950
347
1.4550
205
510-740
303
1.4305
195
500-700
348
1.4546
250
600-700
304
1.4301
195
500-700
403
1.4000
250
400-600
304L
1.4306
180
460-480
405
1.4002
250
400-600
304LN
1.4311
270
550-760
409
1.4512
260
400-600
305
1.4303
185
490-690
410S
1.4000
250
400-600
308
1.4303
185
490-690
410
1.4006
250
450-650
650-750
1)
410
1.4006
-
600-800
1.4005
440
590-780
1)
1.4828
280
309S
1.4833
280
650-750
1)
416
310
1.4841
280
650-750
420
1.4021
450
650-800
-
450
650-800
310S
1.4845
280
650-750
1)
420F
314
1.4841
310
650-750
422
1.4935
875
1015
316
1.4401
205
610-710
430
1.4016
270
450-600
316L
1.4404
190
490-690
430F
1.4104
300
540-740
500-730
1)
430F
1.4104
450
640-840
1.4057
550
750-950
316TI
kp
AISI
USA
1.4310
309
=
Tensile
Strength
(N/mm2)
301
1.4571
210
316LN
1.4429
295
580-800
1)
431
317
1.4449
205
540-740
434
1.4113
270
450-650
317L
1.4438
195
490-690
440B
1.4112
430
740
318
1.4583
225
490-740
440C
1.4125
445
755
1.4542
1000
1070
1.4568
280
900
321
1.4541
200
500-730
2)
630
329
1.4460
490
640-900
631
1) Hardened
4
Yield Strength
0,2 % (N/mm2)
2) After anealing and precipitation hardening at 550°C
5
Stainless Steel Wire Rope (AISI 316)
Stainless Steel Wire Rope (AISI 316)
Construction 1 x 7
ø
Stainless Steel Wire Rope
Heat Resistant up to 300° C
Stainless steel wire ropes are developed for those situations
where there must be no corrosion whatsoever and where high
temperatures occur. Yachting, aviation, and the sun awning,
chemical and food industries are all examples.
The special structure of the basic material (Austeniet) makes
these wire ropes resistant to high temperatures. Unlike ordinary
or galvanised steel wire ropes, stainless steel wire ropes may
be exposed to a temperature of approx. 300°C without any
risk.
The special structure of the basic material (Austeniet) makes
these ropes not only rustproof but also resistant to high temperatures. Where ordinary steel or galvanised wire ropes fall
short, the stainless steel wire rope does the job - up to temperatures of 300 degrees Celsius. Quality coding: A.i.S.I. 316.
Quality
Material of type A.I.S.I. 316 is the most “all round” in terms of
basic characteristics and is therefore used for many purposes.
For this reason, type A.I.S.I. 316 is our standard quality. Where
special requirements are laid down regarding a-magnetic characteristics, a different type of stainless steel may be used, for
instance A.I.S.I. 305. This material is often used for mine
sweeping.
As a basic analysis, we can supply you with the following information:
Max.%C
Max.%Mn.
Max.%P.
Max.%S.
Max.%Si.
Max.%Cr.
Max.%Ni.
Max.%Mo.
0.08
2.00
0.045
0.030
1.00
16-18
10-14
2-3
Due to the high Mo. content, namely 2 to 3%, this material is
extremely corrosion-proof, for example in contact with seawater or halogenic salts.
Quality Coding
We refer to stainless steel wire ropes by the American A.I.S.I.
quality numbers. For completeness, we have listed the corresponding German and French codings.
6
United States
GermanyFrance
A.I.S.I.
304
305
316
D.I.N. Werkstoffno.
A.F.N.O.R.
1.4301Z.6.C.N.18-09
1.4312Z.8.C.N.18-12
1.4401Z.6.C.N.D.17-11
weight
minimum breaking load
Ref. No.
in kg/100 m
in mm
kN
1,0
0,86
88
0,50
0152.10.10
1,5
1,92
196
1,13
0152.10.15
2,0
3,41
348
2,01
0152.10.20
2,5
5,33
544
3,13
0152.10.25
3,0
7,69
784
4,51
0152.10.30
4,0
11,95
1219
8,02
0152.10.40
5,0
18,68
1905
12,55
0152.10.50
kg
Construction 1 x 19
ø
Elasticity
weight
minimum breaking load
in mm
kN
kg
Ref. No.
in kg/100 m
1,0
0,87
99
0,49
0153.10.10
1,25
1,45
148
0,76
0153.10.12
1,5
1,86
190
1,11
0153.10.15
2,0
3,30
337
1,98
0153.10.20
2,5
5,15
525
3,10
0153.10.25
Basic Material
3,0
7,42
757
4,46
0153.10.30
During the cooling process, between 1100°C and 700°C, common steel acquires a special cristaline shape which depends
on the quantity of carbon present in the steel. Below 700°C,
however, this type of steel - for the manufacture of ordinary or
galvanised steel wire rope for example - will acquire a different
structural form, which now becomes permanent. Steel for the
manufacture of stainless steel wire ropes, retains on further
cooling the same structural shape which was acquired between 1100°C and 700°C.
This is mainly due to the content of chromium in this type of
material.
3,5
10,10
1030
6,07
0153.10.35
4,0
13,20
1350
7,93
0153.10.40
5,0
20,60
2100
12,40
0153.10.50
6,0
29,70
3030
17,80
0153.10.60
7,0
37,80
3850
24,30
0153.10.70
8,0
49,40
5040
31,70
0153.10.80
The structure of the basic material also ensures greater elasticity compared with ordinary or galvanised steel wire ropes. The
modulus of elasticity (E) of stainless steel wire ropes is about
10% lower.
Application of
Stainless Steel Wire Rope
Some of the special characteristics of stainless steel makes
the wire ropes manufactured from this material suitable for use
in those situations where no rust may develop and where high
temperatures occur. A few examples: yachting, the sun awning
industry, the chemical industry, machine manufacture, architecture, aviation and the food industry. Roughly in all these applications the use of stainless steel wire ropes guarantees a
smooth progress of many kinds of processing.
10,0
77,20
7870
49,50
0153.11.00
12,0
104,00
10600
71,30
0153.11.20
14,0
131,00
13400
97,10
0153.11.40
16,0
176,00
17940
127,00
0153.11.60
19,0
233,00
23751
176,00
0153.11.90
22,0
299,00
30479
236,00
0153.12.20
26,0
416,00
42405
330,00
0153.12.60
Construction 1 x 37
ø
in mm
weight
minimum breaking load
kN
kg
Ref. No.
in kg/100 m
18,0
227,50
23211
159
0154.11.80
20,0
292,40
29826
204
0154.12.00
22,0
322,00
32844
241
0154.12.20
24,0
387,00
39474
289
0154.12.40
26,0
445,00
45390
333
0154.12.60
28,0
510,00
52025
389
0154.12.80
30,0
595,00
60700
449
0154.13.00
32,0
679,00
69260
504
0154.13.20
7
Stainless Steel Wire Rope (AISI 316)
“Compacted Strand” Construction 1 x 7
ø
weight
minimum breaking load
Ref. No.
in mm
kN
kg
in kg/100 m
2,0
4,11
440
2,2
0152.10.20CS
2,5
6,76
690
3,4
0152.10.25CS
3,0
9,81
1000
4,9
0152.10.30CS
3,5
13,33
1360
6,8
0152.10.35CS
4,0
17,46
1780
8,8
0152.10.40CS
weight
Ref. No.
“Compacted Strand” Construction 1 x 19
ø
minimum breaking load
in kg/100 m
in mm
kN
kg
4,0
17,46
1780
9,1
0153.10.40CS
5,0
25,49
2600
14,2
0153.10.50CS
6,0
35,29
3600
20,5
0153.10.60CS
7,0
49,02
5000
27,9
0153.10.70CS
8,0
61,76
6300
36,5
0153.10.80CS
10,0
98,04
10000
57,0
0153.11.00CS
12,0
142,15
14500
82,1
0153.11.20CS
weight
Ref. No.
“Compacted Strand” Construction 1 x 25
ø
in mm
minimum breaking load
kg
kN
in kg/100 m
14,0
189,33
19300
115
0153.11.40D
16,0
251,14
25600
147
0153.11.60D
“Compacted Strand” Construction 1 x 36 (is far superior on fatigue compared to the 1 x 25 construction)
ø
in mm
weight
minimum breaking load
kN
kg
Ref. No.
in kg/100 m
14,0
194,11
19800
115,9
0153.11.40CS
16,0
253,92
25900
149,9
0153.11.60CS
“Compacted Strand” Construction 1 x 31
ø
in mm
19,0
weight
minimum breaking load
kN
313,92
kg
32000
Ref. No.
in kg/100 m
206
0153.11.90D
FF-95 design Jac de Ridder
8
9
Stainless Steel Wire Rope (AISI 316)
Stainless Steel Wire Rope (AISI 316)
Construction 7 x 7
Construction 6 x 36WS + IWRC
ø
minimum breaking load
weight
ø
Ref. No.
weight
minimum breaking load
Ref. No.
in mm
kN
kg
in kg/100 m
0155.10.10
6,0
20,08
2047
14,6
0164.10.60
0155.10.12
8,0
35,70
3641
26,0
0164.10.80
0,86
0155.10.15
10,0
55,90
5700
40,9
0164.11.00
186
1,30
0155.10.18
12,0
80,50
8210
58,9
0164.11.20
228
1,54
0155.10.20
13,0
94,44
9630
71,6
0164.11.30
3,49
356
2,40
0155.10.25
14,0
110,00
11200
80,2
0164.11.40
3,0
5,03
513
3,46
0155.10.30
16,0
143,00
14600
105,0
0164.11.60
4,0
8,94
912
6,14
0155.10.40
18,0
181,00
18500
133,0
0164.11.80
5,0
14,00
1430
9,60
0155.10.50
20,0
224,00
22800
164,0
0164.12.00
6,0
20,10
2050
13,80
0155.10.60
22,0
271,00
27600
198,0
0164.12.20
7,0
27,40
2790
18,80
0155.10.70
24,0
322,00
32800
236,0
0164.12.40
8,0
35,80
3650
24,60
0155.10.80
26,0
354,00
36100
276,0
0164.12.60
10,0
55,90
5700
38,40
0155.11.00
28,0
410,00
41800
321,0
0164.12.80
12,0
81,10
8270
55,30
0155.11.20
30,0
471,00
48000
368,0
0164.13.00
14,0
109,84
11200
82,32
0155..11.40
16,0
144,16
14700
107,52
0155.11.60
18,0
182,40
18600
131,32
0155.11.80
in mm
kN
1,0
0,56
57
0,38
1,2
1,13
115
0,50
1,5
1,26
128
1,8
1,82
2,0
2,24
2,5
kg
in kg/100 m
Construction 6 x 36WS + pp core
Construction 7 x 19
ø
ø
weight
minimum breaking load
Ref. No.
in mm
kN
kg
in kg/100 m
1,5
1,25
128
0,90
0160.10.15
2,0
2,08
212
1,49
0160.10.20
2,5
3,26
332
2,33
0160.10.25
3,0
4,69
478
3,35
0160.10.30
3,5
6,39
652
4,56
0160.10.35
4,0
8,34
850
5,95
0160.10.40
5,0
13,00
1330
9,30
0160.10.50
6,0
18,80
1920
13,40
0160.10.60
7,0
25,50
2600
18,20
0160.10.70
8,0
33,40
3410
23,80
0160.10.80
10,0
52,10
5310
37,20
0160.11.00
12,0
75,10
7660
53,60
0160.11.20
13,0
88,80
9041
65,20
0160.11.30
14,0
102,00
10100
72,90
0160.11.40
16,0
133,00
13600
95,50
0160.11.60
Construction 6 x 19 + pp core
ø
10
weight
minimum breaking load
Ref. No.
weight
minimum breaking load
Ref. No.
in mm
kN
kg
in kg/100 m
10,0
51,8
5285
36,5
0064.11.00
12,0
74,6
7610
52,8
0064.11.20
14,0
102,0
10400
71,9
0064.11.40
16,0
133,0
13600
94,0
0064.11.60
18,0
168,0
17100
119,0
0064.11.80
20,0
207,0
21100
147,0
0064.12.00
22,0
251,0
25600
178,0
0064.12.20
24,0
298,0
30400
211,0
0064.12.40
26,0
328,0
33400
248,0
0064.12.60
Construction 18 x 7 + IWRC
ø
weight
minimum breaking load
Ref. No.
in mm
kN
kg
in kg/100 m
1,5
1,20
122
0,90
0169.10.15
2,0
2,13
217
1,60
0169.10.20
2,5
3,32
339
2,50
0169.10.25
3,0
4,66
475
3,70
0169.10.30
4,0
8,50
867
6,40
0169.10.40
5,0
12,90
1320
10,00
0169.10.50
in mm
kN
kg
in kg/100 m
3,0
4,34
443
3,1
0060.10.30
6,0
18,50
1890
14,40
0169.10.60
4,0
7,71
786
5,5
0060.10.40
7,0
25,20
2570
19,60
0169.10.70
5,0
12,00
1220
8,6
0060.10.50
8,0
33,00
3370
25,70
0169.10.80
6,0
17,40
1770
12,4
0060.10.60
10,0
51,50
5250
40,10
0169.11.00
7,0
23,60
2410
16,9
0060.10.70
12,0
74,20
7570
57,70
0169.11.20
8,0
30,80
3140
22,0
0060.10.80
14,0
100,90
10289
75,20
0169.11.40
10,0
47,9
4880
34,6
0060.11.00
16,0
129,30
13179
101,50
0169.11.60
11
Coated Stainless Steel Wire Ropes (AISI 316)
Thermoplastic Sheating Materials I PVC Coated Stainless Steel Wire Rope (AISI 316)
Thermoplastic Sheating Materials
material
PA 6 - PA 12 - PE - PP and Hytrel coated wire ropes on request.
permanent
short-time
density
modulus of
indentation
temperature of
temperature of
103 kg/m3
usage (°C)
(20°C)
elasticity
daN/mm2
hardness
N/mm2
(20°C)
(20°C)
-
20-60
usage (°C)
(hours/days)
PVC
-20
1,42
+100
hygroscopicity restistance to
% (20°C)
atmospheric
conditions
-10
abraison
restistance
In following
constructions:
(i.) = inflammable
(n.i.) = not inflammable
0,4
(s.e.)
good
fair
good
+70
PP
combustibility
(s.e.) = selfextingushing
+140
0,91
104
65
0,1
good
(i.)
good
+140
1,13
3 x 104
50-100
4,4
good
(i.)
excellent
+125
1,03
104
80-100
1
good
(i.)
excellent
+180
1,40
3 x 104
100
0,5
good
(i.)
excellent
1x7
100
PA 6
-30
1x19
7x7
7x19
+110
PA 11/12
-30
+105
PETP
-100
+130
PVC Coated Stainless Steel Wire Rope (AISI 316)
Construction 1 x 19
ø
minimum breaking load
Ref. No.
in mm
kN
kg
weight
in kg/100 m
color
2,0-3,0
3,30
337
2,5
clear
1340.20.30
2,0-3,0
3,30
337
2,5
white
1344.20.30
2,0-4,5
3,30
337
3,6
white
1344.20.45
2,5-4,0
5,15
525
4,1
white
1344.25.40
3,0-5,0
7,42
757
5,5
white
1344.30.50
4,0-6,0
13,20
1350
10,2
white
1344.40.60
4,0-6,0
13,20
1350
10,2
red
1341.40.60
weight
in kg/100 m
color
Construction 7 x 7
ø
in mm
12
minimum breaking load
kN
kg
Ref. No.
2,5-3,5
3,49
356
3,4
white
13I4.25.35
2,5-4,0
3,49
356
3,6
red
13I1.25.40
2,5-5,0
3,49
356
4,3
clear
13I0.25.50
3,0-5,0
5,03
513
5,5
clear
13I0.30.50
3,0-5,0
5,03
513
5,5
white
13I4.30.50
3,0-5,0
5,03
513
5,5
black
13I2.30.50
4,0-6,0
8,94
912
8,8
white
13I4.40.60
4,0-6,0
8,94
912
8,8
red
13I1.40.60
4,0-7,0
8,94
912
10,8
white
13I4.40.70
4,0-8,0
8,94
912
12,0
white
13I4.40.80
5,0-7,0
14,00
1430
13,1
white
13I4.50.70
5,0-8,0
14,00
1430
12,5
white
13I4.50.80
5,0-9,0
14,00
1430
13,0
white
13I4.50.90
6,0-8,0
20,10
2050
17,6
clear
13I0.60.80
6,0-8,0
20,10
2050
17,6
white
13I4.60.80
6,0-9,0
20,10
2050
21,5
white
13I4.60.90
8,0-12,0
33,40
3410
27,1
white
13I4.81.20
Wire Rope Cutting Machine
■ Our automatic wire rope cutters realize low priced
and quick to deliver serial productions.
■ Instead of ordering 1 x 2000 meter of wire rope,
you can ask for 2000 x 1 meter or 1000 x 2 meters
of wire rope against an economical price level.
13
Monel Wire
Microcables
Monel locking and seizing single wire
Wire rope
Reel lenght/
Min.
ø in mm
mtr.
packing pcs.
0,90
10
1
0,90
10
20
1,60
bulk
bulk
Product code
Ref. No.
509-0901
monel.090
509-090120
monel.09020
508-1600
monel.160
Monel Wire is made from Bright Annealed Alloy 400 (BS 3075 NA13)
Because we know your problems,
we can help you efficiently!
There is an increasing pressure and responsibility which rests
on you - the technical engineer. This area of responsibility also
includes so called little things like static tensioning or suspending elements and dynamic control and drive assemblies.
Conventional solutions like wires and metal tapes, synthetic
ropes and gears, rods and chains sometimes offer advantages
but they also have immense disadvantages:
they are too expensive or have no dimensional stability, they
fatigue quickly, break or kink, they do not withstand temperature fluctuations, they knot, they are not shock-absorbing or
offer an unsatisfactory strength/weight ratio, they are too bulky
and cannot execute any threedimensional movements or
movements around corners.
Since 1978 microcables and microstrands from Carl Stahl have
proved to be excellent products in many branches of industry
and also in surgery and medical equipment. Due to the extremely small diameter of wire - starting from 0,03 mm - they
offer technical solutions which seemed to be impossible not
long ago.
An increasing number of technical engineers decide for microcables and microstrands from Carl Stahl when static tensioning
or suspending elements or control and drive assemblies are
concerned; because they don’t want to do any more without
the following advantages:
■ small space requirements
■ excellent strength/weight ratio
■ low maintenance requirements
■ reduced fatigue
■ non-rotating and
■ free of tension
■ flexible
■ smooth and easy running
■ long lifetime
■ threedimensional movement into various
directions and around corners
■ from 0,06 to 2 mm diameter
■ standard and special constructions
■ made out of stainless steel, corrosion
resistant steel and aloy steel
■ and other special material like titanum,
tantalum, Monel, Inconel, Hastelloy
■ or copper alloys like brass, tombac etc.
■ galvanized, tinned, plastic coated or with
special surface treatment
■ to be supplied on reels or
■ with terminals
■ and last but not least: economical!
Ask for the Technocables catalogue
where you can find more about
■ end fittings
■ pulleys
■ pressing tools
■ and technical information
Randmeer 14
design: vd Stadt en Partners
15
Stainless Steel Strands 1.4401 (AISI 316) I Stainless Steel Wire Ropes (AISI 316)
Stainless Steel Strands 1.4401 (AISI 316)
Stainless Steel Strands 1.4401 (AISI 316)
Stainless Steel
Strands 1.4401
(AISI 316)
Unless otherwise specified, all strand and ropes are
manufactured with a wire tensile strength of 1770 N/mm2.
Unless otherwise
specified, all strand
and ropes are manufactured with a wire
tensile strength of
1770 N/mm2.
Construction 1 x 7
ø
nominal in mm
minimum breaking load
1770 N/mm2
weight
Ref. No.
kg/1000 m
180 kp/mm2
in N
0,09
6,9
0,040
CG00.70.09
0,12
13,3
0,073
CG00.70.12
0,15
20,0
0,113
CG00.70.15
0,18
30,0
0,163
CG00.70.18
0,21
41,0
0,210
CG00.70.21
0,24
53,0
0,280
CG00.70.24
0,27
70,0
0,360
CG00.70.27
0,30
85,0
0,440
CG00.70.30
0,33
100,0
0,540
CG00.70.33
0,36
120,0
0,640
CG00.70.36
0,39
140,0
0,750
CG00.70.39
0,45
200,0
1,000
CG00.70.45
0,51
280,0
1,250
CG00.70.51
0,57
350,0
1,600
CG00.70.57
0,60
400,0
1,800
CG00.70.60
0,69
520,0
2,400
CG00.70.69
0,75
600,0
2,800
CG00.70.75
Detail of our stranding process
Construction 1 x 19
ø
nominal in mm
nominal in mm
minimum breaking load
1770 N/mm2
weight
weight
Ref. No.
kg/1000 m
180 kp/mm2
in N
Construction 1 x 12
ø
minimum breaking load
1770 N/mm2
Ref. No.
kg/1000 m
0,15
25
0,110
CG01.90.15
0,20
44
0,200
CG01.90.20
0,25
69
0,300
CG01.90.25
0,30
98
0,440
CG01.90.30
0,35
135
0,600
CG01.90.35
0,40
177
0,780
CG01.90.40
0,45
224
0,970
CG01.90.45
0,50
275
1,200
CG01.90.50
0,55
330
1,450
CG01.90.55
0,60
392
1,750
CG01.90.60
0,65
461
2,070
CG01.90.65
0,75
618
2,760
CG01.90.75
0,85
795
3,500
CG01.9.085
1,00
1079
4,900
CG01.91.00
1,25
1765
7,600
0153.10.12
special rope constructions available on request
180 kp/mm2
in N
0,20
43
0,180
CG01.20.20
0,24
62
0,260
CG01.20.24
0,28
84
0,350
CG01.20.28
0,32
111
0,460
CG01.20.32
0,36
140
0,580
CG01.20.36
0,40
173
0,720
CG01.20.40
0,44
209
0,870
CG01.20.44
0,48
248
1,030
CG01.20.48
0,52
291
1,210
CG01.20.52
0,56
338
1,400
CG01.20.56
0,60
387
1,600
CG01.20.60
0,68
499
2,100
CG01.20.68
0,80
691
2,900
CG01.20.80
Stainless Steel
Wire Ropes
1.4401 (AISI 316)
Unless otherwise
specified, all strand
and ropes are manufactured with a wire
tensile strength of
1770 N/mm2.
Should you have
any special
needs, please
ask us we are ready
to help you!
special rope constructions available on request
16
17
Stainless Steel Wire Ropes 1.4401 (AISI 316)
Stainless Steel Wire Ropes 1.4401 (AISI 316) I Coated Stainless Steel Wire Ropes 1.4401 (AISI 316)
Stainless Steel Wire Ropes 1.4401 (AISI 316)
Construction 8 x 19 + 7 x 7
ø
nominal in mm
minimum breaking load
1770 N/mm2
weight
Ref. No.
kg/1000 m
Unless otherwise specified, all strand and ropes are
manufactured with a wire tensile strength of 1770 N/mm2.
180 kp/mm2
in N
247
1,170
CG 819057
0,76
400
2,120
CG 819076
0,95
650
3,200
CG 819095
1,14
946
4,720
CG 819114
180 kp/mm2
1,33
1180
6,400
CG 819133
in N
1,52
1500
8,340
CG 819152
1,71
2100
10,360
CG 819171
Construction 7 x 7
ø
nominal in mm
minimum breaking load
1770 N/mm2
weight
Ref. No.
kg/1000 m
180 kp/mm2
in N
ø
nominal in mm
minimum breaking load
1770 N/mm2
weight
0,44
172
0,760
CG08.70.44
0,55
270
1,200
CG08.70.55
0,66
387
1,700
CG08.70.66
0,77
495
2,300
CG08.70.77
0,88
696
3,000
CG08.70.88
0,99
824
3,900
CG08.70.99
1,10
1010
4,700
CG08.71.10
1,21
1226
5,700
CG08.71.21
1,32
1471
6,800
CG08.71.32
1,43
1716
8,000
CG08.71.43
1,54
1962
9,200
CG08.71.54
10
0,060
CG07.70.12
0,18
15
0,130
CG07.70.18
0,27
59
0,290
CG07.70.27
0,36
103
0,520
CG07.70.36
0,45
162
0,800
CG07.70.45
0,54
235
1,200
CG07.70.54
Coated Stainless Steel Wire Ropes 1.4401 (AISI 316)
Unless otherwise specified, all strand and ropes are manufactured with a wire
tensile strength of 1770 N/mm2.
0,63
324
1,600
CG07.70.63
0,72**
422
2,100
CG07.70.72
0,81**
530
2,600
CG07.70.81
0,90
647
3,200
CG07.70.90
1,00
785
3,900
CG07.71.00
1,20
1128
5,000
CG07.71.20
1,35
1330
7,200
CG07.71.35
1,50
1800
9,200
CG07.71.50
ø
0,45
special rope constructions available on request
Construction 7 x 7 Polyamid coated (PA12)
ø
ø outer
minimum breaking force
weight
in mm
in mm
in N
in kg/1000 m
0,27
0,36
59
0,35
U077.27.36
0,36
0,45
103
0,58
U077.36.45
0,45
0,61
162
0,94
U077.45.61
0,54
0,70
235
1,35
U077.54.70
0,63
0,80
324
1,80
U077.63.80
0,72**
0,90
422
2,35
U077.72.90
0,81
1,00
530
2,90
U077.81.10
0,90
1,20
647
3,70
U077.90.12
180 kp/mm2
1,00
1,60
785
5,00
U077.10.16
in N
1,20
1,60
1128
7,21
U077.12.16
CG71.90.45
1,20
1,80
1128
7,77
U077.12.18
1,35
1,80
1452
8,25
U077.13.18
Construction 7 x 19
nominal in mm
Ref. No.
kg/1000 m
0,12
** AISI 304 (1.4301)
minimum breaking load
1770 N/mm2
152
weight
Ref. No.
kg/1000 m
0,810
Ref. No.
0,60
270
1,440
CG71.90.60
0,75
417
2,100
CG71.90.75
1,50
2,00
1800
10,4
U077.15.20
CG71.90.90
1,80***
2,50
1820
14,8
U077.18.25
3,00
2200
19,3
U077.20.30
0,90
613
3,500
1,00
765
4,400
CG71.91.00
2,00*
1,20
976
5,600
CG71.91.20
2,50*
3,50
3360
28,8
U077.25.35
CG71.91.35
3,00*
4,00
5060
40,2
U077.30.40
4,00*
5,00
9010
68,0
U077.40.50
5,00*
7,00
14100
116,0
U077.50.70
1,35
1227
7,100
1,50
1590
9,000
CG71.91.50
1,75
2099
13,500
CG71.91.75
2,00
2768
17,000
CG71.92.00
2,50
3551
24,500
CG71.92.50
special rope constructions available on request
18
Construction 8 x 7 + 1 x 19
0,57
* Wire tensile strength 1570 N/mm2
** AISI 304 (1.4301)
*** only PA 6 coated available
19
Coated Stainless Steel Wire Ropes 1.4401 (AISI 316)
Construction 7 x 19 Polyamid coated (PA12)
ø
ø outer
minimum breaking force
weight
in mm
in mm
in N
in kg/1000 m
0,45
0,61
152
0,93
U719.45.61
0,60
0,80
270
1,64
U719.60.80
0,75
1,00
417
2,40
U719.75.10
0,90
1,10
613
3,75
U719.90.11
1,00
1,25
765
4,80
U719.10.12
1,20
1,50
976
6,30
U719.12.15
1,35**
1,65
1227
7,80
U719.13.16
1,50
1,75
1590
9,50
U719.15.17
2,00
2,40
2768
18,20
U719.20.24
Ref. No.
2,50*
3,50
3551
29,00
3,00*
U719.25.35
4,00
4690
39,00
4,00*
U719.30.40
5,00
8340
66,80
U719.40.50
5,00*
7,00
13000
112,50
6,00*
U719.50.70
8,00
18800
157,00
U719.61.80
* Wire tensile strength 1570 N/mm2
** AISI 304 (1.4301)
Construction 8 x 7 + 1 x 19 Polyamid coated (PA12)
ø
ø outer
minimum breaking force
weight
in mm
in mm
in N
in kg/1000 m
0,44
0,61
172
0,9
U087.44.61
0,55
0,70
270
1,3
U087.55.70
0,66
0,80
387
1,8
U087.66.80
0,77
1,00
495
2,6
U087.77.10
0,88
1,10
697
3,3
U087.88.11
0,99
1,20
824
4,2
U087.99.12
1,10
1,30
1010
5,0
U087.11.13
1,21
1,50
1226
6,2
U087.12.15
Ref. No.
Ref. No.
Construction 8 x 19 + 7 x 7 Polyamid coated (PA12)
ø
ø outer
minimum breaking force
weight
in mm
in mm
in N
in kg/1000 m
0,57
0,80
247
1,5
U819.57.80
0,76
0,95
400
2,5
U819.76.95
0,95**
1,20
650
3,9
U819.95.12
1,14*
1,45
946
5,8
U819.11.14
1,33
1,55
1180
7,6
U819.13.15
1,52
1,75
1500
9,4
U819.15.17
1,76
2,00
2100
13,0
U819.17.20
2,00
3,00
2580
19,0
U819.20.30
2,50
3,50
4000
29,0
U819.25.35
3,00
4,00
5350
40,0
U819.30.40
4,00
5,00
9100
67,5
U819.40.50
* Wire tensile strength 2050 - 2350 N/mm2
** AISI 304 (1.4301)
special rope constructions available on request
20
21
Wire rope tools I Clips I Thimbles I Sleeves
Wire rope cutters
Felco C 7 wire rope cutter
max. capacity 1 x 19
4 mm
Ref. No.
max. capacity 7 x 19
5 mm
5090.00.20
length
190 mm
weight
0,27 kg
Felco C 9 wire rope cutter
max. capacity 1 x 19
6 mm
Ref. No.
max. capacity 7 x 19
7 mm
5090.00.30
length
325 mm
weight
0,75 kg
Set spare blades for Felco C 9
Ref. No.
5090.00.30S
Felco C 12 wire rope cutter
max. capacity 1 x 19
8 mm
max. capacity 7 x 19
10 mm
length
500 mm
weight
1,50 kg
Set spare blades for Felco C 12
Ref. No.
5090.00.31
Ref. No.
5090.00.31S
Felco C 16 wire rope cutter
max. capacity 1 x 19
10 mm
Ref. No.
max. capacity 7 x 19
12 mm
5090.00.32
length
630 mm
weight
2,30 kg
Set spare blades for Felco C 16
Ref. No.
5090.00.32S
Felco C 108 wire rope cutter
max. capacity 1 x 19
8 mm
max. capacity 7 x 19
10 mm
length
560 mm
weight
1,95 kg
Set spare blades for Felco C 108
Ref. No.
5090.00.33
Ref. No.
5090.00.33S
Felco C 112 wire rope cutter
max. capacity 1 x 19
12 mm
Ref. No.
max. capacity 7 x 19
14 mm
5090.00.34
length
730 mm
weight
3,60 kg
Set spare blades for Felco C 112
Ref. No.
5090.00.34S
22
23
Tension Gauges
Wire rope cutter
Standard Tension Gauge
Underwater Hydraulic Cutter with nickel plating
Ref. No.
LC TPL-S20
■ Lenght 40,6cm.
■ Cutting capacity 16mm.
■ Head rotates 180º for easy positioning.
■ Saltwater resistant, nickel-plated cutter for use in underwater environments.
■ Its recommended uses include: marine nautical cutting, emergency cutting of stainless steel wire rope rigging and hardware, underwater rebar and cable cutting.
■ No need for difficult tools like hacksaws, acetylene cutting torches or pneumatic cutting tools.
■ The TPL-S20 requires only minimum pumping effort to produce specified output tonnage.
■ Especially designed for use by the U.S. Coast Guard, Army Corp of Engineers, offshore drilling companies, longshoremen and port authorities.
NOTE: Flush with fresh water to remove salt after each use.
■ The standard economy tension gauge takes the guesswork out of cable tension adjustment. It’s
especially designed for accurate, repeatable tuning of a sailboat’s standing rigging. Manufactured of
rugged anodized aluminium, the gauge is corrosion-resistant and will provide years of service.
for wire rope size
Product code
Ref. No.
in mm
2,5 - 3 - 4
91 metric
LC91-2540
5-6-7
90 metric
LC90-5070
Professional Tension Gauge
■ Higher accuracy and easier to use than standard models. The cable can be adjusted while the gauge
remains on the cable. „Just watch the pointer move.“
■ All readings are based on 302/304 1x19 S.S. breaking strengths.
for wire rope size
Product code
Ref. No.
in mm
2,5 - 3 - 4
PT-1 metric
LCPT12540
5-6-7
PT-2 metric
LCPT25070
8 - 10
PT-3 metric
LCPT380100
Professional PT-CR Tension Gauge
■ The Professional Model #PT-CR tension gauge is designed to provide an accurate measurement of
the tension in architectural cable railing systems.
■ The Model #PT-CR is designed to measure cable tension in kg for 4mm 1x19 cables.
for wire rope size
Product code
Ref. No.
in mm
4
PT-CR
LCPTCR4000
Rod Rigging Gauge
■ We offer a series of gauges to measure the tension in rods from .172 to .375 inch in diameter over a
range of approximately 5% to 25% of the breaking strength of the rod and provide an accuracy of +
or -5%. The „Professional Model“ RT series provides an increasing durability, accuracy and convenience of use.
■ Manufactured of rugged anodized aluminium, this gauge is corrosive resistant and will give years of
service. Detailed operating instructions are included with each tension gauge. Operates in the same
manner as the Professional Model Series.
24
for rod size
Product code
Ref. No.
in mm
4,4 - 7,1
RT-10M
LCRT10M
7,1 - 9,5
RT-11M
LCRT11M
25
Wire rope clips
Wire rope clips
Stainless Steel wire rope clips AISI 316 same as American Federal Specification
wire rope
A
B1
B2
D
H1
H2
Stainless Steel Simplex Wire Rope Clips AISI 304
I
ø in mm
Min.
weight
packing pcs.
in kg/100 pcs.
Ref. No.
2
9
4
13
M 3
18
11
14
10
0,8
5870.00.02
3
12
5
16
M 4
25
12
17
10
1,5
5870.00.03
4
13
6
18
M 4
25
14
19
10
2,9
5870.00.04
5
15
7
20
M 5
29
15
24
10
3,1
5870.00.05
6
18
8
21
M 6
31
17
27
10
4,0
5870.00.06
8
23
10
27
M 8
41
21
34
10
7,7
5870.00.08
10
28
12
34
M 10
52
25
45
10
17,0
5870.00.10
12
35
14
38
M 12
61
28
51
1
26,5
5870.00.12
14
42
15
43
M 12
68
32
53
1
31,0
5870.00.14
16
42
18
47
M 14
76
36
60
1
50,0
5870.00.16
19
50
20
51
M 14
79
40
62
1
58,0
5870.00.19
22
60
26
61
M 16
98
46
72
1
80,0
5870.00.22
25
62
29
61
M 16
110
49
76
1
108,0
5870.00.25
wire rope
b2
d
h2
i1
ø in mm
Min.
weight
packing pcs.
in kg/100 pcs.
Ref. No.
2
12
M 4
14
15
10
0,46
5855.00.02
3
14
M 4
14
17
10
0,72
5855.00.03
4
18
M 5
18
20
10
1,72
5855.00.04
5
20
M 5
18
25
10
1,46
5855.00.05
6
24
M 6
23
30
1
2,52
5855.00.06
8
30
M 8
25
37
1
5,42
5855.00.08
10
35
M 10
32
48
1
8,80
5855.00.10
Ref. No.
■ Also available in AISI 316
Stainless Steel wire rope clips AISI 316, light type DIN 741
Stainless Steel Duplex Wire Rope Clips AISI 304
wire rope
B
D1
H1
H2
A
T
ø in mm
26
Min.
weight
packing pcs.
in kg/100 pcs.
Ref. No.
2
11
M 3
17,5
10,0
17
10
10
0,7
5871.00.02
3
12
M 3
21,0
11,0
18
10
10
1,2
5871.00.03
4
14
M 4
23,0
13,0
21
11
10
1,4
5871.00.04
5
15
M 5
28,0
15,0
25
12
10
1,5
5871.00.05
6
17
M 6
32,0
17,0
28
16
10
2,1
5871.00.06
8
21
M 6
36,0
20,0
31
18
10
4,1
5871.00.08
10
25
M 8
44,0
23,0
36
19
10
6,8
5871.00.10
13
28
M 10
55,0
25,5
47
26
1
13,0
5871.00.13
16
32
M 12
65,0
28,0
52
26
1
21,0
5871.00.16
19
38
M 12
78,0
32,0
58
30
1
28,0
5871.00.19
22
40
M 12
86,0
43,5
64
32
1
40,0
5871.00.22
25
46
M 14
94,0
43,5
69
32
1
44,0
5871.00.25
wire rope
b2
d
h2
i2
ø in mm
Min.
weight
packing pcs.
in kg/100 pcs.
2
12
M 4
14
30
10
0,97
5865.00.02
3
14
M 4
14
35
10
1,41
5865.00.03
4
18
M 5
18
40
10
2,45
5865.00.04
5
20
M 5
18
50
10
2,91
5865.00.05
6
24
M 6
23
60
1
5,00
5865.00.06
8
30
M 8
25
75
1
10,63
5865.00.08
10
35
M 10
32
95
1
17,13
5865.00.10
■ Also available in AISI 316
27
I-SYS
Clamp Rings Stainless Steel (AISI 316)
Thimbles
Standard Stainless Steel Thimbles AISI 316
b
ld
groove width
a
b
thickness
in mm
ø in mm
max. axial force
b
ld
M3
1,0
10
15
3
M3
1,3
10
15
4
M3
1,6
10
15
5
M4
2,0
10
20
6
M4
2,2
10
20
8
M4
2,2
10
20
10
M6
6,0
15
32
12
M6
7,0
20
40
*
■ Degreasing the parts and the wire rope increases the permissible axial force (kN)!
■ The max. axial force is based on 6 strand wire rope.
* The 8 mm clamp can be used for 7 mm also (axial force is different)
Ref. No.
12
8
1,0
25
0,3
5970.00.02
16
10
1,0
25
0,4
5970.00.25
3,0
16
10
1,0
25
0,4
5970.00.03
4,0
17
11
1,0
25
0,5
5970.00.04
5,0
20
13
1,0
25
0,6
5970.00.05
6,0
25
16
1,2
25
1,0
5970.00.06
7,0
28
18
1,2
10
1,2
5970.00.07
8,0
32
20
1,4
10
1,8
5970.00.08
10,0
40
26
1,6
10
2,9
5970.00.10
I863-0200
12,0
45
28
2,0
10
4,6
5970.00.12
I863-0300
14,0
56
34
2,2
10
9,0
5970.00.14
I863-0400
16,0
62
37
2,5
1
10,4
5970.00.16
I863-0500
Ref. No.
in kN
2
in kg/100 pcs.
2,5
Light 2-Part Clamp Rings S.S. AISI 316
a
weight
pcs.
2,0
a
wire rope
min. packing
18,0
68
42
2,8
1
17,1
5970.00.18
I863-0600
20,0
75
46
3,4
1
27,7
5970.00.20
I863-0800
22,0
85
50
3,6
1
29,7
5970.00.22
I863-1000
24,0
94
58
4,5
1
54,9
5970.00.24
26,0
102
66
4,5
1
60,5
5970.00.26
28,0
115
75
4,5
1
88,0
5970.00.28
32,0
125
80
6,0
1
140,0
5970.00.32
36,0
160
100
6,0
1
185,0
5970.00.36
a
b
thickness
min. packing
weight
pcs.
in kg/100 pcs.
I863-1200
The right way to mount wire rope-clips.
Stainless Steel Thimbles AISI 316
groove width
in mm
28
Ref. No.
2,0
10
7
0,8
50
0,2
5970.00.02EB
2,5
14
8
0,8
50
0,2
5970.00.25EB
3,0
17
10
1,0
50
0,4
5970.00.03EB
4,0
18
11
1,0
50
0,5
5970.00.04EB
5,0
22
13
1,2
50
0,7
5970.00.05EB
6,0
27
15
1,2
50
1,0
5970.00.06EB
8,0
33
18
1,4
50
1,5
5970.00.08EB
10,0
41
22
2,0
25
3,8
5970.00.10EB
12,0
48
27
2,0
25
5,0
5970.00.12EB
29
Thimbles
Thimbles
Stainless Steel Highly Polished Thimbles AISI 316
for wire rope
A1
Stainless Steel Plate Reinforced Thimbles AISI 316
A2
B
L1
S
L2
ø in mm
min.
weight
packing
in kg/100 pcs.
for wire rope
Ref. No.
C
2
3
9,0
4,5
22,5
17
1,0
25
0,2
BW11.00.02
3
4
10,0
5,5
25,0
18
1,0
25
0,3
BW11.00.03
4
5
11,0
7,5
28,0
20
1,2
25
0,5
BW11.00.04
5
6
13,0
8,2
32,0
21
1,2
25
0,7
BW11.00.05
6
7
15,0
9,7
39,0
27
1,5
25
1,2
BW11.00.06
7
8
19,0
11,0
45,0
33
1,5
25
1,5
BW11.00.07
8
9
22,0
13,0
51,0
38
2,0
10
2,7
BW11.00.08
9
10
24,0
14,0
58,0
41
2,0
10
2,9
BW11.00.09
10
11
27,0
15,5
65,0
48
2,5
10
5,2
BW11.00.10
12
14
29,0
18,0
71,0
53
2,5
10
5,5
BW11.00.12
14
16
32,0
21,0
78,0
57
3,0
10
11,0
BW11.00.14
16
18
40,0
22,0
88,0
67
3,0
1
12,0
BW11.00.16
18
20
45,0
26,0
102,0
75
4,0
1
21,5
BW11.00.18
20
22
52,0
30,0
124,0
84
4,0
1
32,0
BW11.00.20
22
24
56,0
34,0
137,0
96
5,0
1
47,0
BW11.00.22
26
28
65,0
40,0
158,0
115
6,0
1
80,0
BW11.00.26
28
30
76,0
42,0
187,0
135
6,0
1
110,0
BW11.00.28
32
34
88,0
46,0
215,0
160
6,0
1
156,0
BW11.00.32
34
36
100,0
48,0
220,0
160
6,0
1
176,0
BW11.00.34
36
38
110,0
50,0
237,0
176
6,0
1
192,0
BW11.00.36
38
40
115,0
56,0
247,0
184
8,0
1
292,0
BW11.00.38
40
42
120,0
58,0
257,0
192
8,0
1
320,0
BW11.00.40
42
45
150,0
61,0
309,0
240
8,0
1
364,0
BW11.00.42
L1
D E
E
L1
min.
weight
packing
in kg/100 pcs.
Ref. No.
24
37
22
11
10
1,2
5970.00.06V
8
32
48
30
15
10
2,0
5970.00.08V
10
40
54
34
20
10
4,2
5970.00.10V
12
42
60
40
25
10
5,9
5970.00.12V
14
51
74
50
30
10
10,0
5970.00.14V
Ref. No.
Stainless Steel Casted Plate Reinforced Thimbles AISI 316
B
C
L1
D E
B
C
D
L1
K
ø in mm
min.
weight
packing
in kg/100 pcs.
6
11,0
24
36
11
7
10
1,4
5970.00.06VC
8
13,8
31
49
16
10
10
2,7
5970.00.08VC
10
14,5
40
54
21
14
10
5,0
5970.00.10VC
12
16,5
42
61
27
16
10
6,2
5970.00.12VC
14
19,5
52
73
30
20
10
10,1
5970.00.14VC
K
Stainless Steel Bar Reinforged Thimbles AISI 316
A1
A2
L2
S
L3
ø in mm
30
D
6
for wire rope
for wire rope
C
ø in mm
min.
weight
packing
in kg/100 pcs.
Ref. No.
8
8
20,0
30
1,5
20,0
40
3,0
BW11.99.08S
9
10
24,0
38
2,0
24,0
10
3,2
BW11.99.09
10
11
27,0
48
3,0
27,0
10
5,9
BW11.99.10
12
14
29,0
53
3,0
29,0
10
6,3
BW11.99.12
14
16
32,0
57
3,0
32,0
10
12,3
BW11.99.14
16
18
40,0
67
3,0
40,0
1
13,6
BW11.99.16
18
20
45,0
75
4,0
45,0
1
24,0
BW11.99.18
20
22
50,0
84
4,0
50,0
1
34,8
BW11.99.20
22
24
56,0
96
5,0
56,0
1
51,8
BW11.99.22
26
28
60,0
115
6,0
60,0
1
85,6
BW11.99.26
31
Thimbles
Oval Sleeves I Stop Sleeves I Hand Tools
Stainless Steel Heavy Duty Thimbles AISI 304
A
B
C
Nicopress Oval Sleeves (Zinc Plated Copper)
D
E
F
G
H
min. packing
weight
Ref. No.
in kg/100 pcs.
pcs.
ø
Nicopress No.
wire rope
Recommended
min. packing
weight
Nicotool jaw
pcs.
in kg/100 pcs.
Ref. No.
in mm
55
41,4
38,1
22,2
10,4
7,11
1,52
5,84
1
3,06
5975.00.06
63
47,8
46,0
26,9
12,7
8,64
2,03
7,11
1
5,10
5975.00.08
0,72-0,8
NT-27-1-B
B
100
0,028
NICO.10.08
5975.00.10
1,0-1,2
NT-28-11-B4
B4
100
0,084
NICO.10.10
1,5-2,0
NT-28-1-C
C
100
0,125
NICO.10.20
73
54,0
54,0
28,7
16,0
10,40
2,79
8,64
11,30
1
92
70,0
70,0
38,1
20,6
13,50
3,65
10,40
1
23,10
5975.00.13
108
82,5
79,5
44,5
24,6
16,80
4,06
12,70
1
34,00
5975.00.16
2,5-2,8
NT-28-2-G
G
50
0,261
NICO.10.25
5975.00.19
3,0-3,5
NT-28-3-M
M
50
0,760
NICO.10.30
4,0-4,5
NT-28-4-P
P
50
1,060
NICO.10.40
5,0
NT-28-6-X
X
50
2,256
NICO.10.50
6,0
NT-28-8-F2
F2
50
2,144
NICO.10.60
7,0
NT-28-10-F6
F6
25
3,580
NICO.10.70
8,0
NT-28-13-G9
G9
25
5,128
NICO.10.80
127
95,5
97,0
51,0
31,0
19,80
5,59
16,80
67,00
1
Stainless Steel Thimbles Closed Shape AISI 316
for wire rope
L1
L2
A2
A1
S
ø in mm
min.
weight
packing
in kg/100 pcs.
Ref. No.
4
26
20
11
4
1,0
10
0,3
5970.00.03E
5
32
25
12
5
1,2
10
0,7
5970.00.05E
6
45
36
17
6
1,5
10
1,4
5970.00.06E
■ Zinc plated copper sleeves can be used on stainless and galvanised wire rope
Nicopress Stop Sleeves (Plain Copper)
ø
Nicopress No.
wire rope
Recommended
min. packing
weight
Nicotool jaw
pcs.
in kg/100 pcs.
Ref. No.
in mm
0,72-0,8
NT-871-32-B
B
10
0,040
NICO.20.08
1,0-1,2
NT-871-12-B4
B4
10
0,068
NICO.20.10
1,5-2,0
NT-871-1-C
C
10
0,096
NICO.20.20
2,5-2,8
NT-871-17-J
J or G
10
0,340
NICO.20.25
3,0-3,5
NT-871-18-J
J or G
10
0,350
NICO.20.30
4,0-4,5
NT-871-19-M
M
10
0,536
NICO.20.40
5,0
NT-871-20-M
M
10
0,472
NICO.20.50
6,0
NT-871-22-M
M
10
0,860
NICO.20.60
Nylon Thimbles
Multi Groove Hand Tools
for wire rope
L1
L2
A2
A1
S
ø in mm
min.
weight
packing
in kg/100 pcs.
Ref. No.
to use for following
3
18
11,0
7,3
3
0,6
10
0,05
5970.00.03N
4
24
14,5
10,0
4
0,8
10
0,08
5970.00.04N
5
30
18,0
12,0
5
1,0
10
0,15
5970.00.05N
6
36
21,8
14,7
6
1,1
10
0,25
5970.00.06N
8
48
29,0
19,5
8
1,5
10
0,50
5970.00.08N
10
60
36,3
24,4
10
1,9
10
0,98
5970.00.10N
12
72
43,5
29,3
12
2,3
10
1,72
Nicopress No.
weight
oval sleeves (in mm)
Ref. No.
(in kg)
1,2-1,5/1,8-2,0/2,5-2,8
NT-33V-CGB4
1,2
NICO.40.33
1,8-2,0/2,5-2,8/3,0-3,5/4,0-4,5
NT-64-CGMP
2,9
NICO.40.64
3,0-3,5/4,0-4,5/5,0 NT-63-XPM
2,9
NICO.40.63
Jaw B4 = 1,2-1,5 mm
Jaw X Jaw C = 1,8-1,5 mm
5970.00.12N
Jaw G
= 2,5-2,8 mm
Jaw M
= 3,0-3,5 mm
14
84
51,0
34,0
14
2,6
10
2,74
5970.00.14N
18
108
65,3
44,0
18
3,4
10
5,68
5970.00.16N
= 5,0 mm
Single Groove Hand Tools
to use for following
32
Nicopress No.
weight
Ref. No.
oval sleeves (in mm)
(in kg)
0,72-1,0
NT-17-BA
0,34
NICO.30.08
3,0-3,5
NT-51-M-850
2,60
NICO.30.30
4,0-4,5
NT-51-P-850
2,60
NICO.30.40
5,0
NT-51-X-850
2,60
NICO.30.50
6,0
NT-51-F2-850
2,80
NICO.30.60
7,0
NT-3-F6-950
6,48
NICO.30.70
8,0
NT-3-G9-950
6,48
NICO.30.80
33
Bench Tools I Dies
Oval Sleeves I Stop Sleeves I Hand Tools
Savapress Oval Sleeves (Zinc Plated Copper)
Small Bench Tool (Without Dies)
Nicopress No.
weight
(in kg)
NT-510
2,95
ø
Ref. No.
Nicopress No.
Recommended
Recommended
min. packing
weight
Savatool jaw
Nicotool jaw
pcs.
in kg/100 pcs.
Ref. No.
in mm
NICO.60.00
Dies For Small Bench Tool
to use for following
Savapress No.
wire rope
0,72-0,8
7030 C
185-D
B
100
0,028
TK72.10.70
1,0-1,2
7047 C
T188 no.1 or T185-B
B4
100
0,084
TK12.15.10
1,5-2,0
7062 C
T188 no.2 or T185-C
C
100
0,125
TK18.20.10
2,5-2,8
7092 C
T188 no.3
G
50
0,261
TK25.01.20
3,0-3,5
7125 C
T188 no.4
M
50
0,760
TK30.01.90
4,0-4,5
7156 C
T188 no.5 or 0-532SC
P
50
1,060
TK40.02.10
5,0
7187 C
T188 no.6 or 0-316SC
X
50
2,256
TK50.03.40
6,0
7218 C
0-732
F2
50
2,144
TK60.02.70
7,0
7250 C
0-14
F6
25
3,580
TK70.03.80
8,0
7312 C
0-516
G9
25
5,128
TK80.04.30
■ Zinc plated copper sleeves can be used on stainless and galvanised wire rope
Ref. No.
oval sleeves (in mm)
1,8-2,0/2,5-2,8/3,0-3,5/4,0-4,5
NT-10-CGMP
NICO.60.64
3,0-3,5/4,0-4,5/5,0
NT-10-XPM
NICO.60.63
5,0
NT-10-X
NICO.60.50
6,0
NT-10-F2
NICO.60.60
Savapress Stop Sleeves (Plain Copper)
ø
Savapress No.
Recommended
Recommended
min. packing
weight
Savatool jaw
Nicotool jaw
pcs.
in kg/100 pcs.
wire rope
Ref. No.
in mm
Big Bench Tool (Without Dies)
0,72-0,8
8030 C
T185-D
B
10
0,040
TK72.10.00
1,0-1,2
8047 C
T188 no.1/T185-B
B4
10
0,068
TK12.15.00
1,5-2,0
8062 C
T188 no.2/T185-C
C
10
0,096
TK18.20.00
2,5-2,8
8092 C
*
J or G
10
0,340
TK25.00.00
3,0-3,5
8125 C
*
J or G
10
0,350
TK30.00.00
4,0-4,5
8156 C
T188 no.4
M
10
0,536
TK40.00.00
5,0
8187 C
T188 no.4
M
10
0,472
TK50.00.00
* Tool for Savapress stop sleeves on request
Nicopress No.
weight
(in kg)
NT-300
8,55
Ref. No.
Multigroove Hand Tool
NICO.70.00
to use for following
Savapress No.
length
weight
(in mm)
(in kg)
T185*
220
0,4
Savapress No.
length
weight
(in mm)
(in kg)
510
2,27
oval sleeves (in mm)
Ref. No.
0,72-1,0/1,2-1,5/1,8-2,0
CGT0.01.85
Jaw A = ____
Jaw B = 1,0-1,2 mm
presses hexacon
Dies For Big Bench Tool
to use for following
= 1,5-2,0 mm
Jaw D
= 0,72-0,8 mm
Multigroove Hand Tool
Nicopress No.
Ref. No.
to use for following
oval sleeves (in mm)
oval sleeves (in mm)
NT-30-CGMP
NICO.70.64
5,0
NT-30-X
NICO.70.50
6,0
NT-30-F2
NICO.70.60
7,0
NT-30-F6
NICO.70.70
Jaw 1 =
NICO.70.80
Jaw 2 = 1,8-2,0 mm
NT-30-G9
Tools for Nicopress stop sleeves with J on request
Ref. No.
1,8-2,0/2,5-2,8/3,0-3,5/4,0-4,5
8,0
34
Jaw C
1,2-1,5/1,8-2,0/2,5-2,8/
T188
CGT0.01.88
3,0-3,5/4,0-4,5/5,0
presses round
1,2-1,5 mm
Jaw 3 =
2,5-2,8 mm
Jaw 4 =
3,0-3,5 mm
Jaw 5 =
4,0-4,5 mm
Jaw 6 = 5,0 mm
35
Single Groove Hand Tools
Talurit Clamps
Single Groove Hand Tool
to use for following
Savapress No.
oval sleeves (in mm)
Talurit Clamps
length
weight
(in mm)
(in kg)
510
2,0
The aluminium talurit clamps are manufactured
acc. DIN 3093 (exept ❷).
Ref. No.
4,0-4,5
0-532SC
They can worked up with a talurit press, but also
with a dies driven swaging machine. For working up
with a swaging machine it is important to know
which dies you have to use. We can give you this
information on request.
CGLC532
Copper and Stainless Steel talurit clamps will be
used on Stainless Steel wire rope.
Aluminium talurit clamps will normally be used on
galvanised and bright steelwire rope and under special conditions on Stainless Steel wire rope.
Single Groove Hand Tool
to use for following
Savapress No.
oval sleeves (in mm)
length
weight
(in mm)
(in kg)
510
2,0
Ref. No.
5,0
0-316SC
CGLC316
No.
Single Groove Hand Tool
to use for following
Savapress No.
oval sleeves (in mm)
length
weight
(in mm)
(in kg)
Ref. No.
6,0
0-732
710
2,35
CGLC732
Single Groove Hand Tool
to use for following
Savapress No.
oval sleeves (in mm)
length
weight
(in mm)
(in kg)
Ref. No.
7,0
0-14
710
2,35
CGLC014
oval sleeves (in mm)
length
weight
(in mm)
(in kg)
710
2,35
Ref. No.
8,0
0-516
CGLC516
Aluminium weight
kg/
Round
100 pcs.
Clamp
Ref. No.
Copper weight
kg/
Round
Clamp 100 pcs.
Ref. No.
T100.54.30
❷
❷
T201.60.42 ❷
0,010
KU50.00.10
0,035
P5E0.00.10
0,04
-
0,023
0,021
KU50.00.15
0,071
P5E0.00.15
0,06
P5R0.00.15
0,020
KU5R.00.10
T151.20.42
KU5R.00.15
0,087
0,024
KU50.00.20
0,080
P5E0.00.20
0,09
P5R0.00.20
0,028
KU5R.00.20
0,100
2,5
P500.00.25
0,050
KU50.00.25
0,167
P5E0.00.25
0,13
P5R0.00.25
0,054
-
-
3
P500.00.30
0,084
KU50.00.30
0,282
P5E0.00.30
0,17
P5R0.00.30
0,093
KU5R.00.30
0,324
3,5
P500.00.35
0,132
KU50.00.35
0,442
P5E0.00.35
0,36
P5R0.00.35
0,147
-
0,710
2
4
P500.00.40
0,181
KU50.00.40
0,606
P5E0.00.40
0,40
P5R0.00.40
0,219
KU5R.00.40
4,5
P500.00.45
0,261
KU50.00.45
0,873
P5E0.00.45
0,71
P5R0.00.45
0,311
-
-
5
P500.00.50
0,357
KU50.00.50
1,194
P5E0.00.50
0,94
P5R0.00.50
0,427
KU5R.00.50
1,420
2,410
6
P500.00.60
0,586
KU50.00.60
1,960
P5E0.00.60
1,60
P5R0.00.60
0,745
KU5R.00.60
6,5
P500.00.65
0,755
KU50.00.65
2,530
-
-
-
P500.00.70
0,953
KU50.00.70
3,190
P5E0.00.70
P5R0.00.70
1,180
-
7
2,20
KU5R.00.70
3,740
8
P500.00.80
1,370
KU50.00.80
4,600
P5E0.00.80
3,60
P5R0.00.80
1,780
KU5R.00.80
5,290
9
P500.00.90
1,980
KU50.00.90
6,650
P5E0.00.90
5,10
P5R0.00.90
2,530
-
-
10
P500.01.00
2,640
KU50.01.00
8,850
P5E0.01.00
7,17
P5R0.01.00
3,460
-
-
11
P500.01.10
3,580
KU50.01.10
12,000
P5E0.01.10
8,27
P5R0.01.10
4,610
-
-
P500.01.20
4,580
KU50.01.20
15,350
P5E0.01.20
12,06
P5R0.01.20
5,980
-
-
13
P500.01.30
5,970
KU50.01.30
20,000
-
-
-
-
-
-
14
P500.01.40
7,350
KU50.01.40
24,600
P5E0.01.40
18,50
P5R0.01.40
9,460
-
-
P500.01.60
11,100
KU50.01.60
37,150
P5E0.01.60
29,00
P5R0.01.60
14,080
-
-
18
P500.01.80
15,900
KU50.01.80
53,150
P5E0.01.80
41,50
P5R0.01.80
20,010
-
-
20
P500.02.00
21,700
KU50.02.00
72,600
P5E0.02.00
56,10
P5R0.02.00
27,480
-
-
P500.02.20
29,100
KU50.02.20
96,900
P5E0.02.20
74,00
P5R0.02.20
36,600
-
-
22
Savapress No.
weight
Stainless
kg/
Steel
Talurit Clamp 100 pcs.
Ref. No.
1
16
to use for following
Copper weight
kg/
Talurit
Clamp 100 pcs.
Ref. No.
1,5
12
Single Groove Hand Tool
Aluminium weight
kg/
Talurit
100 pcs.
Clamp
Ref. No.
P500.02.40
37,500
KU50.02.40
121,800
P5E0.02.40
94,90
P5R0.02.40
47,450
-
-
26
P500.02.60
47,900
KU50.02.60
157,300
P5E0.02.60
123,50
P5R0.02.60
60,250
-
-
28
P500.02.80
62,300
KU50.02.80
204,500
P5E0.02.80
160,50
-
-
-
-
P500.03.00
77,800
KU50.30.00
265,800
P5E0.03.00
208,70
-
-
-
-
24
30
Only in aluminium bigger sizes available
36
37
Shackles I Carbine Hooks I Quick Links I Swivels I Snapshackles
Stainless Steel AISI 304 Strap Shackles
AISI 304 Stainless Steel Highly Polished
D
Breaking
A
L
load in kg
min. packing
weight
pcs.
in kg/100 pcs.
Ref. No.
500
M4
10,0
15,0
10
0,5
BW15.00.41
600
M4
11,0
20,0
10
0,6
BW15.00.42
1000
M5
12,0
17,0
10
1,6
BW15.00.51
1000
M5
16,0
24,0
10
1,6
BW15.00.52
1100
M5
16,0
36,0
10
1,8
BW15.00.53
1100
M5
13,5
25,0
10
1,5
BW15.52.51
1400
M6
16,0
23,0
10
1,6
BW15.52.06
2000
M6
14,0
40,0
10
2,9
BW15.00.62
3000
M8
18,0
42,0
10
5,0
BW15.00.82
D
A
L
min. packing
weight
Ref. No.
pcs.
in kg/100 pcs.
AISI 304 Stainless Steel Highly Polished
Breaking
load in kg
500
M4
10,0
15
10
0,5
BW16.00.41
1000
M5
12,0
17
10
1,0
BW16.00.51
1000
M5
16,0
24
10
1,6
BW16.00.52
1100
M5
16,0
36
10
1,8
BW16.00.53
1100
M5
13,5
25
10
1,5
BW16.52.51
1400
M6
16,0
23
10
1,6
BW16.52.06
D
A
L
min. packing
weight
Ref. No.
pcs.
in kg/100 pcs.
Key Pin AISI 304 Stainless Steel Highly Polished
Breaking
load in kg
600
4
11
20
10
0,5
BW18.00.04
1000
5
15
36
10
1,8
BW18.00.05
1000
5
13
26
10
1,5
BW18.52.05
1650
6
15
40
10
2,9
BW18.00.06
2750
8
20
41
10
5,0
BW18.00.08
min. packing
weight
Ref. No.
pcs.
in kg/100 pcs.
Key Pin AISI 304 Stainless Steel Highly Polished
Breaking
D1
D2
A
L1
L2
load in kg
38
700
5
3
12
14
9
10
1,6
BW18.03.52
700
5
3
15
21
12
10
1,9
BW18.03.05
1500
6
3
14
25
12
10
3,0
BW18.03.06
2000
8
3
20
26
12
10
5,1
BW18.03.08
39
Stainless Steel AISI 316 Casted Shackles
Stainless Steel AISI 316 Casted Shackles
Stainless Steel Casted D-Shackle AISI 316
Stainless Steel Casted Twisted D-Shackle AISI 316
A
Breaking
B and D
L1
load in kg
min. packing
weight in
pcs.
kg/100 pcs.
Ref. No.
min.
weight
load
and
packing
in kg/
in kg
R
pcs.
100 pcs.
A
Breaking
B
L1
Ref. No.
550
4
8
16,00
10
0,8
5670.00.04
1000
5
10
20,00
10
1,4
5670.00.05
550
4
8
20
10
1,0
IL22.00.40
1700
6
13
25,00
10
2,7
5670.00.06
1000
5
10
30
10
2,0
IL22.00.50
1700
6
12
35
10
3,5
IL22.00.60
2500
8
16
31,00
10
6,4
5670.00.08
4100
10
20
40,00
10
12,0
5670.00.10
2500
8
16
42
10
8,0
IL22.00.80
5400
12
25
47,00
1
21,0
5670.00.12
4100
10
20
60
10
15,5
IL22.01.00
5400
12
24
62
1
28,0
IL22.01.20
A
B
6100
13
26
53,00
1
28,0
5670.00.13
6500
14
28
49,00
1
35,0
5670.00.14
8800
16
32
64,00
1
50,0
5670.00.16
10000
19
35
75,00
1
88,0
5670.00.19
19000
22
43
88,00
1
140,0
5670.00.22
21000
25
47
96,00
1
208,0
5670.00.25
23000
28
52
108,00
1
250,0
5670.00.28
Breaking
min.
weight
26000
32
64
125,00
1
426,0
5670.00.32
load
packing
in kg/
in kg
pcs.
100 pcs.
Stainless Steel Casted Long D-Shackle AISI 316
Breaking
B and D
A
L2
load in kg
min. packing
weight in
pcs.
kg/100 pcs.
Ref. No.
500
4
8
32,0
10
1,0
IL21.10.40
920
5
10
40,0
10
2,0
IL21.10.50
1560
6
12
48,0
10
3,5
IL21.10.60
2300
8
16
64,0
10
8,0
IL21.10.80
3770
10
20
80,0
10
15,5
IL21.11.00
4970
12
24
96,0
1
28,0
IL21.11.20
Stainless Steel Casted D-Shackle Key Model AISI 316
ø
Ref. No.
850
5
12,5
38,0
5
3,0
IL21.30.50
1275
6
15,5
43,0
5
5,0
IL21.30.60
2550
8
20,5
60,5
5
11,0
IL21.30.80
ø
A
Stainless Steel Casted D-Shackle Key Model With Bar AISI 316
min.
weight
load
packing
in kg/
in kg
pcs.
100 pcs.
Breaking
B
Ref. No.
850
5
13
38
5
3,5
IL21.40.50
1275
6
16
43
5
5,8
IL21.40.60
2550
8
22
60
5
12,5
IL21.40.80
■ Do not use casted shackles for standing rigging.
Stainless Steel Casted Bow Shackle AISI 316
Breaking
A
B and D
L1
R
load in kg
min. packing
weight in
pcs.
kg/100 pcs.
Ref. No.
550
4
8
21,0
17
10
0,9
5671.00.04
1000
5
10
25,0
17
10
1,6
5671.00.05
1700
6
12
27,0
21
10
3,0
5671.00.06
2500
8
16
40,0
28
10
7,0
5671.00.08
4100
10
20
43,0
31
10
12,5
5671.00.10
5400
12
24
54,0
42
1
22,5
5671.00.12
6100
13
26
65,0
45
1
30,0
5671.00.13
6500
14
28
66,0
50
1
37,0
5671.00.14
8800
16
32
72,0
56
1
52,0
5671.00.16
10000
19
38
92,0
61
1
93,0
5671.00.19
19000
22
44
102,0
76
1
150,0
5671.00.22
21000
25
50
112,5
84
1
220,0
5671.00.25
23000
28
56
130,0
94
1
285,0
5671.00.28
26000
32
64
154,0
114
1
326,0
5671.00.32
■ Do not use casted shackles for standing rigging.
40
41
Shackles Forged Stainless Steel AISI 316
Shackles Forged Stainless Steel AISI 316
Stainless Steel Forged D-Shackle Key Model AISI 316
Stainless Steel Forged D-Shackle
Breaking
ø
A
B
load in kg
min. packing
weight in
pcs.
kg/100 pcs.
Ref. No.
Breaking
P
B
J
L
min. packing
weight
pcs.
in kg/100 pcs.
load in kg
Ref. No.
1000
5
13
37
1
3,1
W143.20.00
800
4,0
4,0
8
16
10
0,7
FS01.00.40
1500
6
16
45
1
4,8
W143.30.00
1500
5,0
5,0
10
20
10
1,3
FS01.00.50
2300
8
21
59
1
12,1
W143.40.00
1950
6,0
6,0
13
25
10
2,4
FS01.00.60
3000
8,0
8,0
16
32
10
5,3
FS01.00.80
4800
9,5
9,5
19
38
10
9,7
FS01.00.95
6000
11,0
11,0
22
44
1
15,2
FS01.01.10
7500
12,7
12,7
26
52
1
23,7
FS01.01.27
10000
16,0
14,3
29
58
1
45,0
FS01.01.60
14000
19,0
16,0
32
64
1
58,5
FS01.01.90
B
J
L
min. packing
weight
Ref. No.
pcs.
in kg/100 pcs.
Stainless Steel Forged Long D-Shackle
Breaking
P
load in kg
Stainless Steel Forged D-Shackle Key Model With Bar AISI 316
Breaking
ø
A
B
C
load in kg
c
min. packing
weight in
pcs.
kg/100 pcs.
Ref. No.
1200
5
13
37
12
1
3,1
W814.32.00
1700
6
16
45
15
1
5,2
W814.33.00
12,3
W814.34.00
2500
8
21
59
20
1
1500
5
13
37
12
1
3,1
W914.32.00HR
2200
6
16
45
15
1
5,3
W914.33.00HR
3500
8
21
59
20
1
12,3
W914.34.00HR
4,0
8
24
10
1,2
FS01.10.40
5,0
5,0
10
29
10
1,6
FS01.10.50
1600
6,0
6,0
13
43
10
3,2
FS01.10.60
2400
8,0
8,0
16
49
10
6,9
FS01.10.80
3800
9,5
9,5
19
55
10
11,7
FS01.10.95
Also available with socket head pin.
Breaking
ø
4,0
Stainless Steel Forged Wide D-Shackle
Stainless Steel Forged Thimble Shackle AISI 316
Breaking
600
1200
A
B
load in kg
8
16
41
12
10
20
51
16
1
Ref. No.
weight
pcs.
in kg/100 pcs.
30
1
1,5
FS01.00.50W
32
1
3,1
FS01.00.60W
32
48
1
6,5
FS01.00.80W
40
60
1
11,6
FS01.00.95W
750
5,0
5,0
20
7,6
W149.40.00
6,0
6,0
25
14,2
W149.50.00
2500
8,0
8,0
3300
10,0
10,0
pcs.
L
min. packing
1300
rope diam.
5000
J
kg/100 pcs.
weight in
3000
B
load in kg
min. packing
1
P
Ref. No.
max.
Also available with socket head pin.
42
43
Shackles Forged Stainless Steel AISI 316
Shackles Forged Stainless Steel AISI 316
Stainless Steel Forged Bow-Shackle
Stainless Steel Forged D-Shackle With Socket Head Pin
Breaking
P
B
J
L
W
min. packing
weight
pcs.
in kg/100 pcs.
load in kg
Stainless Steel Forged Twisted D-Shackle
Ref. No.
Breaking
P
B
J
L
load in kg
K
min. packing
weight
(Alan Key Size)
pcs.
in kg/100 pcs.
Ref. No.
600
4,0
4,0
8
18
12
10
0,9
FS00.00.40
1500
5,0
5,0
10
20
2
5
1,3
FS01.30.50
1200
5,0
5,0
10
22
16
10
1,4
FS00.00.50
1950
6,0
6,0
13
25
3
5
2,4
FS01.30.60
1600
6,0
6,0
13
28
19
10
2,8
FS00.00.60
3000
8,0
8,0
16
32
4
5
5,3
FS01.30.80
2400
8,0
8,0
16
35
25
10
5,9
FS00.00.80
4800
9,5
9,5
19
38
4
5
9,7
FS01.30.95
3800
9,5
9,5
19
38
28
10
10,6
FS00.00.95
6000
11,0
11,0
22
44
5
1
15,2
FS01.31.10
4800
11,0
11,0
22
46
33
1
16,1
FS00.01.10
7500
12,7
12,7
26
52
5
1
23,7
FS01.31.27
6000
12,7
12,7
26
52
38
1
27,0
FS00.01.27
10000
16,0
14,3
29
58
6
1
45,0
FS01.31.60
8000
16,0
14,3
29
60
43
1
50,0
FS00.01.60
14000
19,0
16,0
32
64
6
1
58,5
FS01.31.90
10000
19,0
16,0
32
68
50
1
63,0
FS00.01.90
Ref. No.
Breaking
P
B
J
L
min. packing
weight
pcs.
in kg/100 pcs.
load in kg
Ref. No.
Stainless Steel Forged Bow-Shackle With Socket Head Pin
Breaking
P
B
J
K
min. packing
weight
pcs.
in kg/100 pcs.
22
2
5
1,4
FS00.30.50
28
3
5
2,8
FS00.30.60
16
35
4
5
5,9
FS00.30.80
9,5
19
38
4
5
10,6
FS00.30.95
11,0
22
46
5
1
16,1
FS00.31.10
12,7
26
52
5
1
27,0
FS00.31.27
16,0
14,3
29
60
6
1
50,0
FS00.31.60
19,0
16,0
32
68
6
1
63,0
FS00.31.90
0,7
load in kg
1,3
FS02.00.50
1200
5,0
5,0
10
2,4
FS02.00.60
1600
6,0
6,0
13
5
5,3
FS02.00.80
2400
8,0
8,0
31
5
9,7
FS02.00.95
3800
9,5
22
35
1
15,2
FS02.01.10
4800
11,0
12,7
26
41
1
23,7
FS02.01.27
6000
12,7
16,0
14,3
29
45
1
45,0
FS02.01.60
8000
19,0
16,0
32
64
1
58,5
FS02.01.90
10000
4,0
4,0
8
13
5
1200
5,0
5,0
10
16
5
1600
6,0
6,0
13
20
5
2400
8,0
8,0
16
26
3800
9,5
9,5
19
4800
11,0
11,0
6000
12,7
8000
10000
L
(Alan Key Size)
FS02.00.40
600
Also available with socket head pin.
Stainless Steel Forged Long Twisted D-Shackle
Breaking
P
B
J
L
load in kg
min. packing
weight
pcs.
in kg/100 pcs.
Ref. No.
600
4,0
4,0
8
23
5
1,2
FS02.10.40
1200
5,0
5,0
10
26
5
1,6
FS02.10.50
1600
6,0
6,0
13
40
5
3,2
FS02.10.60
2400
8,0
8,0
16
45
5
6,9
FS02.10.80
3800
9,5
9,5
19
50
5
11,7
FS02.10.95
Also available with socket head pin.
J
44
45
S.S. AISI 316 Forged Retained Shake Proof Pin Shackles
Stainless Steel AISI 316 Forged
Retained Shake Proof Pin Shackles
Shackles Forged Stainless Steel AISI 316
The shake proof shackle incorporates the new Smart-Lock pin. This pin
benefits from a unique locking mechanism. When the pin is threaded into the
shackle body the ring acts like viscous liquid and binds itself to the internal
threads in the shackle head. After a short period of time the pin is locked in
position.
A sharp turn by hand or use of a shackle key will release the ring and allow
the pin to be unscrewed very easily. The pin can be re-used without any
deterioration. A practical solution to the problem of losing the shackle pin.
The pin will not fall out, but may be unscrewed from the partially threaded
second head to give unrestricted jaw width.
Shackles Forged Stainless Steel AISI 316
with E Type Safety Pin
■ The special bolt end ensures the nut is positioned correctly
allowing sufficient room for the split pin
■ This range of shackles benefits from full materials traceability, CE marking and test batch identification
■ Safety factor 6:1
■ Supplied with test certificate type EN 102043.1b on request
Forged D-Shackle with E Type Safety Pin
SWL
P
B
J
L
kg
Stainless Steel Forged D-Shackle With Retaining Shake Proof Pin (Dimension J did not change)
Breaking
P
B
J
L
load in kg
min. packing
weight
pcs.
in kg/100 pcs.
5,0
5,0
10
20
5
1,3
FS01.20.50
1950
6,0
6,0
13
25
5
2,4
FS01.20.60
3000
8,0
8,0
16
32
5
5,3
FS01.20.80
4800
9,5
9,5
19
38
5
9,7
FS01.20.95
6000
11,0
11,0
22
44
1
15,2
FS01.21.10
7500
12,7
12,7
26
52
1
23,7
FS01.21.27
10000
16,0
14,3
29
58
1
45,0
FS01.21.60
14000
19,0
16,0
32
64
1
58,5
FS01.21.90
weight
pcs.
in g
Ref. No.
350
M6
6,0
13
25
1
48
56.730.006
500
M8
8,0
16
32
1
75
56.730.008
800
M10
9,5
19
38
1
136
56.730.010
1000
M12
11,0
22
44
1
212
56.730.012
1250
M12
12,7
26
52
1
331
56.730.013
1800
M16
14,3
29
58
1
585
56.730.016
2800
M20
16,0
32
64
1
760
56.730.020
3300
M22
19,0
38
76
1
1180
56.730.022
4500
M24
22,0
44
88
1
1750
56.730.024
5000
M27
25,4
50
100
1
2600
56.730.027
Ref. No.
1500
min. packing
The special bolt end
ensures the nut is
positioned correctly
allowing sufficient
room for the split pin.
Bigger sizes on request.
Forged Bow Shackle with E Type Safety Pin
Stainless Steel Forged Bow-Shackle With Retaining Shake Proof Pin (Dimension J did not change)
Breaking
P
B
J
L
W
load in kg
min. packing
weight
pcs.
in kg/100 pcs.
■ This bow shackle is ideal for submersible water pumps
Ref. No.
SWL
P
B
J
L
W
kg
min. packing
weight
pcs.
in g
Ref. No.
1200
5,0
5,0
10
22
16
5
1,4
FS00.20.50
1600
6,0
6,0
13
28
19
5
2,8
FS00.20.60
280
M6
6,0
13
28
19
1
52
56.740.006
2400
8,0
8,0
16
35
25
5
5,9
FS00.20.80
400
M8
8,0
16
35
25
1
81
56.740.008
600
M10
9,5
19
38
28
1
147
56.740.010
3800
9,5
9,5
19
38
28
5
10,6
FS00.20.95
4800
11,0
11,0
22
46
33
1
16,1
FS00.21.10
800
M12
11,0
22
46
33
1
221
56.740.012
6000
12,7
12,7
26
52
38
1
27,0
FS00.21.27
1000
M12
12,7
26
52
38
1
354
56.740.013
1500
M16
14,3
29
60
43
1
635
56.740.016
2500
M20
16,0
32
68
50
1
805
56.740.020
3000
M22
19,0
38
76
58
1
1250
56.740.022
4000
M24
22,0
44
88
66
1
1820
56.740.024
4500
M27
25,4
50
100
76
1
2700
56.740.027
8000
16,0
14,3
29
60
43
1
50,0
FS00.21.60
10000
19,0
16,0
32
68
50
1
63,0
FS00.21.90
The special bolt end
ensures the nut is
positioned correctly
allowing sufficient
room for the split pin.
Bigger sizes on request.
46
47
S.S. AISI 630 Ind. H.T. Shackles
High Resistance Marine D Shackles
Industrial High Tensile Shackles
Stainless Steel 17/4 PH (= AISI 630)
■ Tested and certified to CE requirements
■ PH Shackles are delivered with pin detail as
follows:
Type A: Forged collar pin with eye-standard length
(see drawing)
Type A Long: Forged collar pin with eye-extra
length plus hole for split pin
Type B: Countersunk socket head pin
■ Safety factor 6:1
■ min. packing pcs. 1
■ Manufactured from 17/4 PH precipitation
hardening martensitic stainless steel (AISI 630)
■ Corrosion resistance approximating to that of
18/8 grade steel, high tensile properties while
avoiding work hardening
P
Type A
Type A
B
J
Breaking
weight
Product
Ref. No.
Ref. No.
Ref. No.
in kg/100 pcs.
Code
Type A
Type A Long
Type B
L
in t
■ Corrosion resistance approximating to that of 18/8 grade
steels, high tensile properties while avoiding work hardening
High Resistance Marine D Shackle
Industrial High Tensile Shackle Stainless Steel AISI 630 D-Type
W.L.L.
■ Manufactured from 17/4PH precipitation hardening martensitic stainless steel
■ The HR Shackles are manufactured from Stainless Steel
grade 17/4PH = AISI 630. After production of the entire
shackle, we process and re-condition the material to ensure
that the mechanics of the shackle reach its optimum levels,
offering high breaking loads and high resistance to stress
corrosion cracking without comprimising the integrity of the
shackle. We consider this to be the optimum condition for
17/4PH for use in a marine application.
P
B
J
L
min. packing
weight
pcs.
in kg/100 pcs.
load in kg
Ref. No.
6,0
6,0
12
20
1
2,4
PSHRD06
10,0
8,0
16
32
8,5
PH1T
5672.00.10
FS11.60.10
2700
1
FS11.70.10
8,0
8,0
16
26
1
5,3
PSHRD08
2
12,7
10,0
20
40
15,0
PH2T
5672.00.13
FS11.60.20
4400
FS11.70.20
10,0
9,5
20
33
1
9,7
PSHRD10
3
16,0
12,7
25
50
35,0
PH3T
5672.00.16
FS11.60.30
7500
FS11.70.30
12,0
12,7
24
39
1
23,7
PSHRD12
19,0
16,0
32
64
55,0
PH5T
5672.00.19
FS11.60.50
10000
5
FS11.70.50
14,0
14,3
28
49
1
36,5
PSHRD14
7
22,2
19,0
38
76
100,0
PH7T
5672.00.22
FS11.60.70
14000
FS11.70.70
16,0
16,0
32
56
1
47,0
PSHRD16
9
25,4
22,2
44
88
190,0
PH9T
5672.00.25
FS11.60.90
19000
FS11.70.90
28000
20,0
19,0
40
70
1
60,5
PSHRD19
11
28,6
25,4
51
102
290,0
PH11T
5672.00.29
FS11.61.10
FS11.71.10
13
31,8
28,6
57
114
310,0
PH13T
5672.00.32
FS11.61.30
FS11.71.30
15
34,9
31,8
64
128
435,0
PH15T
5672.00.35
FS11.61.50
FS11.71.50
18
38,0
34,9
70
140
530,0
PH18T
5672.00.38
FS11.61.80
FS11.71.80
Type A long
Type B
■ All Hi-MOD shackles are available
on retail cards (blister packing).
Ask for samples and prices.
■ All Hi-MOD shackles are available
with standard - shake proof and socket head pin
Shackle Pin Types
Pin
Industrial High Tensile Shackle Stainless Steel AISI 630 Bow-Type
W.L.L.
P
B
J
W
L
in t
Type A
48
weight
Product
Ref. No.
Ref. No.
Ref. No.
in kg/100 pcs.
Code
Type A
Type A Long
Type B
0,8
10,0
8,0
16
24
32
9,5
PHB008T
FS12.50.08
FS12.60.08
FS12.70.08
1,5
12,7
10,0
20
30
40
15,8
PHB015T
FS12.50.15
FS12.60.15
FS12.70.15
2,5
16,0
12,7
25
38
50
36,8
PHB025T
FS12.50.25
FS12.60.25
FS12.70.25
4,0
19,0
16,0
32
48
64
57,8
PHB040T
FS12.50.40
FS12.60.40
FS12.70.40
5,5
22,2
19,0
38
57
76
105,0
PHB055T
FS12.50.55
FS12.60.55
FS12.70.55
7,5
25,4
22,2
44
66
88
199,5
PHB075T
FS12.50.75
FS12.60.75
FS12.70.75
9,0
28,6
25,4
51
76
102
304,5
PHB090T
FS12.50.90
FS12.60.90
FS12.70.90
Type A long
Description
Sizes
Standard
screw pin
4 mm
to 19 mm
Shake proof
retain pin
5 mm
to 16 mm
Socket
head pin
5 mm
to 19 mm
Type B
49
Carbine Hooks Stainless Steel AISI 316
Carbine Hooks Stainless Steel AISI 316
Stainless Steel Carbine Hook With Crack AISI 316
Breaking
Stainless Steel Carbine Hook With Crack Eyelet and Safety nut AISI 316
L
D
A1
E
load in kg
weight
Ref. No.
Breaking
A
ø
B
D
weight
C
load in kg
in kg/100 pcs.
Ref. No.
in kg/100 pcs.
180
4
40
7
6
1,0
IL22.01.04
365
6
60
30
7,8
6,5
2,9
220
5
50
8
7
1,8
5145.00.10
580
8
80
40
10,8
8,5
7,5
272
6
60
9
8
2,8
5145.00.15
870
10
100
50
14,0
10,0
15,0
IL22.02.10LN
364
7
70
10
9
4,6
5145.00.23
1008
11
120
59
18,0
14,5
20,0
IL22.02.12LN
508
8
80
12
10
7,0
5145.00.27
1170
12
140
66
22,0
19,0
28,0
728
10
100
15
12
14,6
5145.00.40
816
11
120
19
16
19,5
5145.00.55
908
12
140
22
21
27,5
IL22.01.14
1000
13
160
22
24
36,3
D
L
IL22.02.08LN
IL22.02.14LN
IL22.01.16
Stainless Steel Carbine Hook With Crack And Eye Let AISI 316
Breaking
IL22.02.06LN
Stainless Steel Spring Hook With Curved Gate AISI 316
E
B
load in kg
weight
Ref. No.
A
in kg/100 pcs.
B
C
weight
Ref. No.
in kg/100 pcs.
IL22.02.04
180
4
40
6
5,0
1,1
220
5
50
7
7,0
1,9
272
6
60
8
7,5
2,9
IL22.02.06
364
7
70
9
8,0
4,7
IL22.02.07
508
8
80
10
10,0
7,3
728
10
100
12
13,5
14,9
IL22.02.10
816
11
120
16
15,0
19,9
IL22.02.12
908
12
140
20
18,0
27,9
1060
13
160
24
22,0
37,0
IL22.02.05
IL22.02.08
60
13
6
2,8
80
18
8
7,0
100
21
10
14,6
120
27
12
26,5
IL22.02.06S
IL22.02.08S
IL22.02.10S
IL22.02.12S
IL22.02.14
IL22.02.16
Dimensions
D, L, E
same as above
50
50
51
51
Key-Lock System
Carbine Hooks Stainless Steel AISI 316
Carbine Hook With Crack And Key Lock System
Patented Key-Lock System The only «no snagging» closure
Breaking
A
B
C
D
E
load in kg
This revolutionary patented locking system draws its name from the
peculiar shape of the connection between the gate and the body of
the carabiner, that looks like the key hole of a lock. The real novelty
of this closure is that it doesn’t need any keeping tooth neither on
the body of the carabiner, nor on the gate, now fully cylindrical.
There are no more possible points of snagging of the rope or of the
web when inserting or removing.
Every sharp edge has been also removed. Millings in the body of
the carabiner and in the gate are no more necessary.
weight
Ref. No.
in kg/100 pcs.
-
50
5
8
5,5
7,5
1,6
KO05.55.05
-
60
6
9
6,5
9,0
2,7
KO05.55.06
-
70
7
10
8,0
9,0
4,4
KO05.55.07
800
80
8
11
8,5
11,0
6,6
KO05.55.08
1200
100
10
15
10,5
15,0
12,8
KO05.55.10
2000
120
11
18
12,0
17,0
18,4
KO05.55.12
2400
160
13
23
17,5
30,0
35,3
KO05.55.16
Carbine Hook With Crack, Eyelet And Keylock System
IMPORTANT:
KEY-LOCK SYSTEM
carabiners are partially
safe also if the gate is
2 mm open!
This doesn’t happen
on a traditional snap.
A
Breaking
B
C
E
weight
load in kg
Ref. No.
in kg/100 pcs.
-
50
5
8
7,5
1,7
KO05.57.05
-
60
6
9
9,0
2,8
KO05.57.06
-
70
7
10
9,0
4,5
KO05.57.07
800
80
8
11
11,0
6,7
KO05.57.08
1200
100
10
15
15,0
12,9
KO05.57.10
2000
120
11
18
17,0
18,5
KO05.57.12
2400
160
13
23
30,0
35,4
KO05.57.16
C
E
weight
Ref. No.
Carbine Hook With Crack, Eyelet And Threaded Locking Sleeve
A
Breaking
B
load in kg
in kg/100 pcs.
1200
100
10
14
13
1,7
KO05.58.10
2000
120
11
17
16
2,8
KO05.58.12
Carbine Hook With Crack And Automatic Sliding Sleeve, External Opening
Breaking
KEY-LOCK SYSTEM
No hooking points
No sharp edges
OLD
2 hooking points
2 sharp edges
OUT-OF-DATE
1 hooking point
2 sharp edges
TRADITIONAL
1 hooking point
2 sharp edges
A
B
C
D
E
load in kg
weight
Ref. No.
in kg/100 pcs.
800
80
8
11
8,5
25
6,9
KO05.60.08
1200
100
10
15
10,5
32
13,5
KO05.60.10
Carbine Hook With Crack, Eyelet And Automatic Sliding Sleeve, External Opening
Breaking
A
B
C
E
load in kg
weight
Ref. No.
in kg/100 pcs.
800
80
8
11
25
7,0
KO05.61.08
1200
100
10
14
32
13,6
KO05.61.10
Different types and sizes see next page
52
53
Snaps I Safety Hooks I S-Hooks
Stainless Steel Quicklinks
Stainless Steel Spring Snap AISI 316
Stainless Steel Quicklink AISI 316
L
Breaking
W
S
D
load in kg
weight
Ref. No.
220
50
24
10
8
2,0
500
69
31
12
12
5,0
900
96
47
20
16
15,0
D
Breaking
in kg/100 pcs.
L
B
S
weight
load in kg
IL22.20.50
IL22.20.70
IL22.21.00
Ref. No.
in kg/100 pcs.
720
4
32
12
5,5
1,1
6585.00.04
960
5
39
13
6,5
2,2
6585.00.05
1280
6
45
14
7,5
3,8
6585.00.06
2240
8
58
18
9,5
8,0
6585.00.08
3360
10
69
22
12,0
14,9
6585.00.10
3840
12
81
24
14,5
22,5
IL21.20.12
6000
14
93
27
17,0
36,0
IL21.20.14
7200
16
109
30
19,0
56,0
IL21.20.16
Stainless Steel Spring Snap Open End AISI 316
A
Breaking
B
L
weight
load in kg
Ref. No.
in kg/100 pcs.
220
7,5
6,5
50
2,0
500
11,0
10,0
65
4,5
900
17,0
13,0
90
14,0
IL22.50.50
IL22.50.65
IL22.50.90
Maxi Tightening Torque (N.m.)
øF
Stainless Steel Double Safety Hook AISI 316
Breaking
B
D
E
M
L
load in kg
1400
weight
Ref. No.
in kg/100 pcs.
22
10
22
19
11
17,2
IL22.31.10
TORQUE
Chemical Composition (%)
øF
TORQUE
2,5
0,15
9,0
4,5
3,0
0,30
10,0
7,0
3,5
0,60
12,0
9,0
4,0
0,70
14,0
12,0
5,0
0,80
16,0
18,0
6,0
1,20
18,0
30,0
7,0
2,50
20,0
40,0
8,0
3,00
-
-
Carbon:
Chromium:
Nickel:
Molybdenum:
0,03
16/18
10/14
2/2,5
Manganese:
Silicon:
Sulphurl:
Phosphorous:
2
1
0,03
0,04
■ We can supply mat. black quicklinks for the entertainment industry
■ Certificates available
Standard Series “N” - Stainless 316 L
Stainless Steel S-Hook AISI 304
WLL
in kg
D
L
W1
S2
weight
Ref. No.
in kg/100 pcs.
54
IL22.40.03
Breaking
load in kg
øF
L. I
A
O
E
øT
weight
in kg
Ref. No.
L. T
Dimensions in mm
100
500
2,5
26,0
21,0
7,0
3,5
8,0
3,5x60
0,310
MRN0.00.25
160
800
3,0
31,0
25,0
8,5
4,0
9,0
4x60
0,530
MRN0.00.30
220
1100
3,5
36,0
29,0
10,0
5,0
11,0
5x80
0,810
MRN0.00.35
280
1400
4,0
39,5
31,5
11,5
5,5
12,5
6x100
1,200
MRN0.00.40
450
2250
5,0
49,5
39,5
13,0
6,5
16,0
7x100
2,100
MRN0.00.50
7,5
19,0
9x125
3,540
MRN0.00.60
3
30
6
5,0
0,3
4
36
11
6,0
0,8
5
43
14
10,0
1,5
IL22.40.05
6
55
16
18,0
2,6
IL22.40.06
650
3250
6,0
57,0
45,0
14,5
7
65
10
19,0
5,0
8
75
23
20,0
6,5
IL22.40.08
900
4500
7,0
66,0
52,0
16,0
8,5
21,5
10x125
5,230
MRN0.00.70
1100
5500
8,0
74,0
58,0
17,5
11,0
24,0
11x125
7,900
MRN0.00.80
1800
9000
10,0
89,0
69,0
20,5
12,0
29,0
13x125
14,050
MRN0.01.00
2500
12500
12,0
104,5
80,5
23,5
15,0
33,0
15x150
23,800
MRN0.01.20
3500
17500
14,0
121,0
93,0
26,5
17,0
38,5
17x150
37,400
MRN0.01.40
4500
22500
16,0
140,0
108,0
29,5
19,0
45,0
19x150
57,600
MRN0.01.60
5400
27000
18,0
157,0
121,0
32,5
23,0
52,0
22x150
81,303
MRN0.01.80
IL22.40.04
IL22.40.07
55
Stainless Steel Quicklinks
Stainless Steel Casted Swivels
Stainless Steel Casted Swivels Eye-Eye AISI 316
Large Mouth Series “GO” - Stainless 316 L
WLL
in kg
Breaking
load in kg
øF
L. I
A
O
E
øT
weight
in kg
Ref. No.
L. T
Dimensions in mm
Breaking
A
L
B
B1
L1
load in kg
weight
Ref. No.
in kg/100 pcs.
90
450
2,5
33,0
28,0
7,0
7,0
12,0
3,5x60
0,360
MRGO.00.25
400
4
50
19
11
13
2,2
5545.00.40
145
725
3,0
39,5
33,5
8,5
8,5
13,5
4x60
0,700
MRGO.00.30
650
5
60
23
14
13
3,4
5545.00.50
200
1000
3,5
46,0
39,0
10,0
10,0
16,0
5x80
1,050
MRGO.00.35
1140
6
66
27
15
15
5,1
5545.00.60
250
1250
4,0
53,0
45,0
11,5
11,5
19,0
6x100
1,540
MRGO.00.40
1600
8
90
36
20
22
13,1
5545.00.80
400
2000
5,0
62,0
52,0
13,0
13,0
22,0
7x100
2,570
MRGO.00.50
2500
10
112
44
24
27
26,0
5545.01.00
580
2900
6,0
70,5
58,5
14,5
14,5
25,0
9x125
4,200
MRGO.00.60
5000
13
149
58
32
35
58,0
5545.01.30
800
4000
7,0
79,0
65,0
16,0
16,0
28,0
10x125
6,150
MRGO.00.70
8500
16
186
70
38
45
105,0
5545.01.60
980
4900
8,0
88,0
72,0
17,5
17,5
31,5
11x125
9,330
MRGO.00.80
10000
19
223
79
41
50
220,0
5545.01.90
1600
8000
10,0
105,0
85,5
20,5
20,5
36,0
13x125
16,100
MRGO.01.00
12000
22
258
92
48
52
285,0
5545.02.20
2200
11000
12,0
124,0
100,0
23,5
23,5
43,0
15x150
27,470
MRGO.01.20
13000
25
290
115
65
67
455,0
5545.02.50
3100
15500
14,0
142,0
114,0
26,5
26,5
49,0
17x150
43,050
MRGO.01.40
18000
28
336
126
70
76
660,0
IL27.40.28
4000
20000
16,0
161,0
129,0
29,5
29,5
54,0
19x150
64,580
MRGO.01.60
26000
32
384
144
80
87
950,0
IL27.40.32
4900
24500
18,0
176,5
140,5
32,5
32,5
62,0
22x150
90,120
MRGO.01.80
A
B1
B
C
weight
Ref. No.
Stainless Steel Casted Swivels Eye-Jaw AISI 316
Breaking
Delta Shaped Series “D” - Stainless 316 L
WLL
in kg
Breaking
load in kg
øF
D
load in kg
Dimensions in mm
L. T
L. I
H. T
H. I
O
70
350
2,5
22,0
17,0
27,0
22,0
3,5
110
550
3,0
27,0
21,0
30,0
24,0
150
750
3,5
31,0
24,0
36,0
29,0
E
R 1-2-3
øT
weight
in kg
Ref. No.
in kg/100 pcs.
6
66
14
12
11
4,9
1600
8
90
20
16
16
15,0
2500
10
111
24
20
21
29,5
IL27.41.10
IL27.41.13
8,0
3,50
3,5x60
0,260
MRD0.00.25
4,0
9,0
4,25
4x60
0,610
MRD0.00.30
5000
13
149
32
26
26
66,7
5,0
11,0
5,00
5x80
0,950
MRD0.00.35
8500
16
188
39
32
36
120,5
10000
19
218
41
38
41
250,0
200
1000
4,0
35,5
27,5
40,0
32,0
5,5
12,5
5,75
6x100
1,390
MRD0.00.40
325
1625
5,0
40,0
30,0
48,0
38,0
6,5
16,0
6,50
7x100
2,360
MRD0.00.50
450
2250
6,0
47,0
35,0
56,0
44,0
7,5
19,0
7,25
9x125
3,950
MRD0.00.60
625
3125
7,0
51,0
37,0
63,0
49,0
8,5
21,5
8,00
10x125
5,900
MRD0.00.70
770
3850
8,0
56,0
40,0
73,0
57,0
10,0
24,0
8,85
11x125
8,820
MRD0.00.80
1250
6250
10,0
66,0
46,0
87,0
67,0
12,0
29,0
10,25
13x125
15,640
MRD0.01.00
1750
8750
12,0
75,0
51,0
104,0
80,0
15,0
33,0
11,75
15x150
26,240
MRD0.01.20
2450
12250
14,0
85,0
57,0
123,0
95,0
17,0
38,5
13,25
17x150
41,360
MRD0.01.40
3150
15750
16,0
93,0
61,0
138,0
106,0
19,0
45,0
14,75
19x150
62,730
MRD0.01.60
4200
21000
18,0
102,0
66,0
155,0
119,0
23,0
52,0
16,25
22x150
86,620
MRD0.01.80
IL27.41.06
1140
IL27.41.08
IL27.41.16
IL27.41.19
Stainless Steel Casted Swivels Jaw-Jaw AISI 316
Breaking
D
A
C
B
load in kg
weight
Ref. No.
in kg/100 pcs.
IL27.42.06
1140
6
65
11
12
4,4
1600
8
87
16
16
16,5
2500
10
111
22
20
33,0
IL27.42.10
5000
13
145
28
26
74,5
IL27.42.13
8500
16
178
37
32
134,5
10000
19
213
45
38
280,0
IL27.42.08
IL27.42.16
IL27.42.19
■ Do not use casted swivels for standing rigging.
Swivel Shackles
56
Ref. No.
ø
Plate Size
Fork Width
clevis pin in mm
in mm
in mm
6
1,5
13
HYE6.12.81
6
2,0
13
HYE6.12.82
8
3,0
21
HYE6.12.83
57
Stainless Steel Casted Snapshackles
Stainless Steel Snapshackles
Stainless Steel Casted Snapshackle With Eye AISI 316
Wichard Snapshackles - High Resistant
Breaking
Yield strength
load in kg
in kg
A
B
L
weight
Ref. No.
in kg/100 pcs.
400
180
11
5
32
0,6
1100
495
12
9
55
4,2
2000
900
20
14
70
9,0
3500
1500
27
16
93
23,5
IL23.10.32
Quick release snap shackles are forged from high resistand “HR” stainless
steel (AISI 630). They open easily under load, even at a distance (with a line
or webbing). Indispensable for spinnakers, they are useful for any application
which requires release under load (towing, lifting or material handling.)
IL23.10.52
IL23.10.66
IL23.10.96
Stainless Steel Snapshackles With Swivel Eye AISI 630 (High Tensile)
Breaking
A
B
C
load in kg
weight
Wichard No.
Ref. No.
in kg/100 pcs.
2000
70
16
11
6,5
2473
W247.30.00
3850
90
21
14
13,6
2475
W247.50.00
8000
120
26
21
35,3
2477
W247.70.00
Wichard No.
Ref. No.
Stainless Steel Casted Snapshackle With Swivel AISI 316
Breaking
Yield strength
load in kg
in kg
A
B
L
weight
Ref. No.
in kg/100 pcs.
1100
495
12
12
69
6,0
2000
900
16
15
86
12,5
3500
1500
22
20
122
31,5
IL23.20.70
IL23.20.87
IL23.21.28
Stainless Steel Quick Release Snapshackles With Small Swivel Eye AISI 630 (High Tensile)
Breaking
A
B
C
load in kg
weight
in kg/100 pcs.
1500
70
14
11,0
5,4
2673
W267.30.00
2000
80
16
12,0
8,8
2674
W267.40.00
3200
90
20
13,5
13,6
2675
W267.50.00
4300
110
25
16,0
23,3
2676
W267.60.00
6300
130
30
20,0
63,0
2677
W267.70.00
9000
150
34
24,0
90,0
2678
W267.80.00
Wichard No.
Ref. No.
Stainless Steel Casted Snapshackle With Fork AISI 316
Breaking
Yield strength
load in kg
in kg
A
B
C
L
weight
Ref. No.
in kg/100 pcs.
1100
495
12
14
11
73
6,0
2000
900
16
19
16
96
12,5
3500
1500
22
23
20
127
31,0
Stainless Steel Quick Release Snapshackles With Large Swivel Eye AISI 630 (High Tensile)
IL23.30.70
IL23.30.87
IL23.31.28
Stainless Steel Casted Snapshackle Body AISI 316
Breaking
A
B
C
load in kg
weight
in kg/100 pcs.
1500
80
14
19,0
5,9
2773
W277.30.00
2000
90
16
23,0
10,0
2774
W277.40.00
3200
110
20
26,5
16,0
2775
W277.50.00
4300
120
25
31,0
27,1
2776
W277.60.00
6300
145
30
35,5
39,6
2777
W277.70.00
8500
160
34
41,0
61,8
2778
W277.80.00
weight
Wichard No.
Ref. No.
Stainless Steel Snapshackles With Fixed Eye AISI 630 (High Tensile)
D
A
L
weight
Ref. No.
in kg/100 pcs.
M6
12
42
4,4
M8
16
55
10,0
M10
22
75
24,0
Breaking
A
B
C
load in kg
IL23.40.06
IL23.40.08
IL23.40.10
in kg/100 pcs.
400
35
8
6
1,2
2470
W247.00.00*
2000
50
16
10
4,2
2471
W247.10.00
3500
70
21
13
9,0
2472
W247.20.00
*W247.00.00 is not HR
58
59
Stainless Steel Snapshackles
Tylaska Snapshackles
Stainless Steel Snapshackles With Thimble Eye AISI 630 (High Tensile)
Breaking
A
B
C
load in kg
Tylaska Snapshackles
weight
Wichard No.
Ref. No.
in kg/100 pcs.
2000
95
16
12
7,6
2493
W249.30.00
2500
110
21
14
15,0
2495
W249.50.00
■ Tylaska snapshackles are available in 7 different types with standard - large
bail or fork.
■ The computer optimized 17-4 PH stainless steel construction gives the
Tylaska shackles the highest in strength-to-weight ratios.
■ The precision engineered U.S. made shackles are constructed to near-military specifications, with every shackle individually tested prior to shipping.
■ Safety factor 1:2
Tylaska Snapshackles with standard bail
Ref. No.
Breaking
Work load
load in kg
in kg
2273
1136
14,2
14,2
13,5
14,2
74,6
59
T5SB
TYL0.00.T5
3636
1818
15,7
16,7
15,1
16,7
87,3
97
T8SB
TYL0.00.T8
5455
2727
19,1
19,8
19,1
19,1
101,0
159
T12SB
TYL0.0T.12
A
B
C
D
E
Weight
Type
in gr
9091
4545
24,6
23,8
23,8
24,6
127,0
338
T20SB
TYL0.0T.20
13636
6818
31,8
28,6
28,6
31,8
161,9
636
T30SB
TYL0.0T.30
18181
9090
45,7
42,6
47,1
45,2
243,0
2820
T40SB
TYL0.0T.40
22727
11364
50,8
47,6
52,4
50,3
270,0
3130
T50SB
TYL0.0T.50
C
D
E
Weight
Type
Tylaska Snapshackles with large bail
Ref. No.
Breaking
Work load
load in kg
in kg
2273
1136
14,2
14,2
20,6
22,2
84,1
74
T5LB
TYL0.00.T5L
3636
1818
17,5
16,7
24,6
25,4
92,1
116
T8LB
TYL0.00.T8L
5455
2727
19,1
19,8
28,6
30,2
114,3
205
T12LB
TYL0.0T.12L
A
B
in gr
9091
4545
24,6
23,8
34,9
38,1
141,3
406
T20LB
TYL0.0T.20L
13636
6818
31,8
28,6
46,9
48,4
182,6
824
T30LB
TYL0.0T.30L
18181
9090
45,7
42,6
72,8
74,0
274.0
3900
T40LB
TYL0.0T.40L
22717
11364
50,8
47,6
81,0
82,3
304,8
4320
T50LB
TYL0.0T.50L
■ Tylaska T50 and T40 snapshackles are the largest trigger-type snap shackles ever made. They can be opened using either
a trigger or a lanyard. A lanyard allows for remote operation - ideal for towing applications. The locking pin provides extra
security from accidental release.
■ All sizes Tylaska snapshackles are available with swivel forks.
■ Ask for specification sheets.
Lock System T40SB and T50SB
Locking Pin
Provides Extra
Security From
Accidental
Release
60
Trip with
Lanyard
or Trigger
61
Tylaska Snapshackles / Fids / Plug fids
Tylaska J-Locks / Headboard Shackles / Swivels
E
Tylaska linked Snapshackles with standard bail
E
Ref. No.
119
T5D
TYL0.00.T5D
193
T8D
TYL0.00.T8D
318
T12D
TYL0.0T.12D
244
676
T20D
TYL0.0T.20D
Breaking
Work load
Rope
302
1273
T30D
TYL0.0T.30D
load in kg
in kg
size
3636
1818
8-10
26,7
26,7
15,2
10,9
53,3
5455
2727
10-12
30,5
30,5
17,3
12,7
70,0
9091
4545
12-16
38,1
38,1
21,5
15,7
13636
6818
14-20
49,3
44,7
26,4
19,1
Work load
in kg
2273
1136
136
3636
1818
164
5455
2727
194
9091
4545
13636
6818
E
Weight
in gr
A D
Tylaska Fids
E
Ref. No.
For
shackle size
170
T5 - T12
TYLF.05.12
170
T5 - T12
TYLTF.05.12*
220
T20 - T30
TYLF.20.30
360
T40 - T50
TYLF.40.50
C
Tylaska J-Locks
■ Safety factor 1:2
E
B
Type
Breaking
load in kg
A
B
C
Type
Ref. No.
54
J8
TYL0.00.J8
82
J12
TYL0.0J.12
76,0
159
J20
TYL0.0J.20
103,0
371
J30
TYL0.0J.30
D
E
Weight
in gr
■ Easily spliced onto Genoa sheets, outhauls and halyards, the new low-profile Tylaska J-Locks fit through most Genoa
A
blocks for fast sheet changes. Unique patented double-lockingD plunger
locks in two directions for the ultimate in flog-free
C
operation.
■ Safety factor 1:2
G
G
E
B
F
A
D
C
B
F
E
G
G
H
I
*TYLTF.05.12 is tapered fid
Pin
H
I
Tylaska Headboard Shackles
Tylaska Plug Fids
Ref. No.
For
Breaking
Work load
Rope
load in kg
in kg
size
2273
1136
8
56,3
25,4
4,6
35,6
23,1
16,1
9,5
19,1
19,1
6,6
3636
1818
10
80,0
33,4
7,1
38,1
21,6
19,3
14,2
25,4
26,9
8,1
5455
2727
12
76,2
38,2
8,0
50,8
30,5
22,4
14,3
30,1
28,6
9,5
9091
4545
14-16
122,9
46,5
10,6
63,5
36,6
25,4
19,1
40,1
38,1
12,7
shackle size
T8
TYLP.F08
T12
TYLP.F12
T20
TYLP.F20
A
B
C
D
E
F
G
H
I
Pin
Type
Ref. No.
36,9
H5
TYL0.00.H5
87,7
H8
TYL0.00.H8
127,8
H12
TYL0.0H.12
H20
TYL0.0H.20
Weight
in gr
■ Lightest halyard shackle available
■ Highest strength to weight ratio
■ Captive cross pin
272,7
■ Can be used as 2:1 purchase
■ Safety factor 1:2
E
Tylaska S.S 20
A
B
Breaking
Work load
load in kg
in kg
E
A
B
Weight
Type
Ref. No.
B
in gr
9132
4566
114
20
26
706
SS10
TYLS.S10
18265
9132
152
28
35
1020
SS20
TYLS.S20
36364
18181
246
44
55
4100
SS40
TYLS.S40
A
Tylaska Standard Swivels Stainless Steel 17-4 PH
E
■ The Tylaska SS Snap Shackles are the standard for the highestload shackle in our line. It relies on an old fashioned piston pin for
those applications that don’t need the ability to be released under
load.
■ Made from the same durable 17-4 PH stainless
■ Safety factor 1:2
Breaking
Work load
load in kg
in kg
A
B
E
Weight
Type
Ref. No.
in gr
2273
1136
14,2
14,2
60,3
51
T5SBSB
TYLS.BS.B05
3636
1818
17,5
16,7
71,4
74
T8SBSB
TYLS.BS.B08
5455
2727
19,8
19,1
83,0
125
T12SBSB
TYLS.BS.B12
9091
4545
27,8
24,6
110,0
281
T20SBSB
TYLS.BS.B20
13636
6818
31,8
31,8
133,0
483
T30SBSB
TYLS.BS.B30
22727
11364
42,1
42,1
178,0
1144
T50SBSB
TYLS.BS.B50
■ Tylaska Swivels are made from 17-4 PH = AISI 630 and therefore a very high yield strength
■ Safety factor 1:2
62
63
Tylaska Ball-Lock Clevis Pins
Tylaska / Headboard Sheaved Shackles / Shine
B
D
A
C
D
Nominal Diameter
5/16"
3/8"
1/2"
5/8"
Grip Length
B
C
A
B
C
C
in mm
in mm
in mm
in mm
Type
Ref. No.
H
9/16"
14.3
21.1
BL313-563
TYL BL 313 563
11/16"
17.5
24.3
BL313-688
TYL BL 313 688
3/4"
19.1
25.9
1"
25.4
1 1/4"
BL313-750
TYL BL 313 750
32.2
BL313-1000
TYL BL 313 1000
31.8
38.6
BL313-1250
TYL BL 313 1250
5/8"
15.9
23.0
BL375-625
TYL BL 375 625
13/16"
20.7
27.7
1"
25.4
32.5
1 1/4"
31.8
1 1/2"
11.0
7.9
BL375-813
TYL BL 375 813
BL375-1000
TYL BL 375 1000
38.8
BL375-1250
TYL BL 375 1250
38.1
45.2
BL375-1500
TYL BL 375 1500
3/4"
19.1
28.6
1"
25.4
35.0
1 1/4"
31.8
1 1/2"
12.6
9.5
BL500-750
TYL BL 500 750
BL500-1000
TYL BL 500 1000
41.3
BL500-1250
TYL BL 500 1250
31.8
47.7
BL500-1500
TYL BL 500 1500
BL625-1000
TYL BL 625 1000
BL625-1250
TYL BL 625 1250
15.7
12.6
1"
25.4
36.6
1 1/4"
31.8
43.0
1 1/2"
38.1
49.3
BL625-1500
TYL BL 625 1500
1 3/4"
44.5
55.7
BL625-1750
TYL BL 625 1750
18.9
15.8
■ Tylaska Marine Hardware’s new patented ball-lock clevis pins provide a direct replacement
for standard clevis pins.
■ Unlike traditional ball lock pins, the Tylaska ball lock clevis pin has no bulky handle and has
a release button on both ends.
■ This revolutionary pin eliminates the need for sharp cotter pins, bulky snap rings, and
messy rigging tape, providing a smooth, snagfree connection that is easy to assemble and
disassemble.
■ The clevis pins are constructed out of a hardened and electro-polished 17-4 stainless steel
alloy, which allows for comparable strength to standard 316 stainless steel clevis pins.
Guide clevis pin into clevis
with hand while applying
pressure to front button with
a fid, screw driver or any
pointed object.
64
Tylaska Headboard Sheaved Shackles
Type
Ref. No.
36,9
H5 S
TYL0.00.H5 S
87,7
H8 S
TYL0.00.H8 S
9,5
127,8
H12 S
TYL0.0H.12 S
12,7
272,7
H20 S
TYL0.0H.20 S
Breaking
Work load
Rope
load in kg
in kg
size
2273
1136
10
25,4
4,6
35,6
23,1
16,1
19,1
6,6
3636
1818
14
33,4
7,1
38,1
21,6
19,3
25,4
8,1
5455
2727
16
38,2
8,0
50,8
30,5
22,4
30,1
9091
4545
22
46,5
10,6
63,5
36,6
25,4
40,1
B
C
D
E
F
H
PIN
Weight
in gr
True 2:1 Sheaved Shackles
■ Using a high strength composite sleave bearing, Tylaska has created true 2-1 halyard shackles capable of handling
the full rated load of the shackle.
■ The size was made to fit standard sail headboards without adding any unnecessary weight.
■ Strength was optimized by computer and then verified by numerous "make and break" destructive tests.
Tylaska Shine
■ Tylaska’s ball-lock clevis pins utilize three ball bearings at the end of the pin to hold the
clevis pin captive. In their at-rest state, the ball bearings are locked in a protruded position,
holding the pin captive in the same way a cotter pin would.
■ Depressing a button recessed in the head of the pin permits the ball bearings to drop into
the pin, allowing the pin to be easily inserted into a clevis.
■ A second button on the opposite end of the pin can be used in the same fashion for easy removal and allows the use of a
hammer and punch to dislodge the pin if it is ever corroded or stuck.
■ A standard fid or other spike can also be used to depress the buttons.
■ The buttons use stiff springs to ensure that the pins will not easily dislodge themselves under heavy flogging or shock.
■ The release buttons are also recessed to ensure that the pins resist accidental release when bumped or struck by other
objects.
INSERTION
E
F
■ Tylaska Marine Hardware has introduced a polish to easily remove
rust stains from stainless steel.
■ TYLASKA SHINE has been formulated to clean, polish, and protect
stainless steel in just one application using very
little paste and a soft cloth.
■ TYLASKA SHINE is non-toxic, non-abrasive, and non-flammable.
It works very well and has no bad odors.
■ Remember, a little goes a long way.
REMOVAL
Once button is sufficiently
depressed, the clevis pin will
slip into place.
Once in place, the ballbearings
will snap into a locked position
and hold the clevis pin captive.
Apply pressure to rear
button on opposite end of
clevis pin with a fid, screw
driver or other pointed tool.
Push pin through until balls
are released.
The pin will slip free.
65
Stainless Steel Wire Rope-Blocks I Eyenuts I Eyebolts I U-Bolts and Rings
Stainless Steel Lashing Points
Ring Bolt Threaded
Type
WLL
A
in t
B
C
E
D
RUD DIN
max.
Dimensions in mm
ø
E'
RUD
DIN
F
G
H
J
K
L
M
R
T
ø
DB
max.
thread
torque
WT.
Ref. No.
kg/
unit
LBG (3) M16 RS 1t
1
46
85
50
–
45
72
–
43
16,5
38
25
95
45
63
16
46
88
45
100 Nm 1
5568.30.16
LBG (3) M20 RS 2t
2
46
85
50
–
45
72
–
42
16,5
38
26
95
45
65
20
46
88
45
200 Nm 1,1
5568.30.20
BG Test Number 935119.
Lashing or lifting point with replaceable hexagon
headed bolt. BG tested. Folding link rotates on all
sides, bears the rated load in all directions.
Only one threaded hole required. Also available
without bolt.
Safety note
Make sure the mounting surface is leveled. The
thread connection on the load must meet the
required load capacity.
The following minimum thread lengths are normally prescribed:
1 x m in steel; 2 x m in aluminium; 1.25 x m in
cast iron; 2.5 x m
in aluminium-magnesium alloys.
100 % electromagnetically crack tested!
Eye Plate Weldable
WLL
Description
in t
Welding
Dimensions in mm
seam
A
B
C
D
E
øF
G
Weight
Ref. No.
in kg
LBS stainless
H
0,5
LBS (1) RS 0,5t
HV 5+3
32
65
36
25
39
13,5
33
85
0,3
5563.10.05
1
LBS (3) RS 1t
HV 8+3
42
85
50
31
50
16,5
46
108
0,6
5563.10.10
2
LBS (5) RS 2t
HV 12+4
61
110
65
44
72
22,5
60
155
1,6
5563.10.20
With spring.
BG tested, test number 935118.
A particularly cost-effective lifting and lashing point.
Particular benefits:
Can be loaded to the WLL in all directions. Link rotates through
180°. Load limit clearly defined.
Stainless Steel LBS ( ) RS-version:
Material of the Stainless Steel version:
X 10 CR Ni Mo Tl 1810 (1.4571), B.S. 320 S 17, AISI 316 Tl.
Due to the Mo contents, increasing the chemical resistance and
the resistance against pitting by chloride media, material 1.4571
is used in chemical industry, petroleum and coaltar chemistry
and textile industry.
The stainless steel version is only delivered without spring.
66
67
Eye Bolts I Eye Nuts
Folding Pad Eyes Forged Stainless Steel AISI 316
Stainless Steel Casted Eye Bolts AISI 316 acc. to DIN 580
Most boat builders have opted for Wichard folding pad eyes. They are drop-forged with no
welding, and in themselves offer remarkable strength.
In addition, by aligning themselves in the forces direction, they can handle higher operating
loads, regardless of the position in question.
When only used intermittently, they can be folded dwon out of the way using a silicon pad
that also eliminates noise and unpleasant vibrations.
The double folding pad eyes were designed to enable several stays or a baby stay and a jib
tack point to be attached to a single point.
Breaking Load
in kg
Folding Pad Eyes Forged Stainless Steel AISI 316
Breaking
B
A
E
øD
load in kg
weight
Wichard No.
Ref. No.
6584
W658.40.00
D
C
B
H
L
L1
D2
weight
Ref. No.
in kg/100 pcs.
420
M 6
6
16
28
41
12
17
2,5
5551.30.06
840
M 8
8
20
36
48
13
20
5,0
5551.30.08
1380
M 10
10
25
45
62
17
25
9,4
5551.30.10
2040
M 12
12
30
54
75
21
30
16,6
5551.30.12
4200
M 16
14
35
63
90
27
35
26,0
5551.30.16
7200
M 20
16
40
72
102
30
40
42,0
5551.30.20
10800
M 24
20
50
90
126
36
50
84,0
5551.30.24
19200
M 30
30
60
109
154
45
60
157,0
5551.30.30
in kg/100 pcs.
1600
40
40
23
6,4
5,6
B E
øD
Stainless Steel Casted Eye Nuts AISI 316 acc. to DIN 582
A
Breaking Load
in kg
Folding Pad Eyes Forged Stainless Steel AISI 316
Breaking
B
A
E
øD
load in kg
B E
weight
Wichard No.
Ref. No.
in kg/100 pcs.
1800
45
27
40
6,4
6,7
6504
W650.40.00
3000
59
35
50
8,5
13,6
6505
W650.50.00
5100
75
45
65
10,5
28,6
6506
W650.60.00
D
C
B
H
D2
weight
Ref. No.
in kg/100 pcs.
420
M 6
6
16
28
17
2,3
5552.30.06
840
M 8
8
20
36
20
4,6
5552.30.08
1380
M 10
10
25
45
25
8,6
5552.30.10
2040
M 12
12
30
54
30
14,4
5552.30.12
4200
M 16
14
35
63
35
23,0
5552.30.16
7200
M 20
16
40
72
40
33,4
5552.30.20
10800
M 24
20
50
90
50
67,5
5552.30.24
19200
M 30
30
60
109
60
130,0
5552.30.30
weight
Ref. No.
øD
A
Stainless Steel Casted Eye Bolts AISI 316 Long Model With Nut And Washer
D1 x A
B
C
D
in kg/100 pcs.
Folding Pad Eyes Forged Stainless Steel AISI 316
Breaking
A
B
E
F
øD
load in kg
F E
øD
weight
Wichard No.
Ref. No.
in kg/100 pcs.
IL26.16.04
M 6 x 40
34
5
16
4,0
M 6 x 60
54
5
16
4,5
M 6 x 80
70
5
16
5,0
IL26.16.08
M 8 x 80
70
6
20
9,0
IL26.18.08
M 8 x 100
90
6
20
9,8
M 10 x 100
88
8
25
14,5
IL26.11.10
IL26.11.12
2700
45
27
90
59
6,4
12,6
6564
W656.40.00
M 10 x 120
105
8
25
15,0
4500
59
35
81
59
8,5
25,2
6565
W656.50.00
M 12 x 120
100
10
30
16,0
10000
75
45
125
78
10,5
49,4
6566
W656.60.00
M 12 x 140
120
10
30
16,5
IL26.16.06
IL26.18.10
IL26.12.12
IL26.12.14
B
A
68
69
Eye Bolts I Eye Nuts
Eye-Bolts
Stainless Steel Forged Eye Bolts AISI 316 acc. to DIN 580
Breaking Load
in kg
D1
C
Eye Bolts AISI 304 Stainless Steel Highly Polished
B
H
WLL
weight
in kg vertical
in kg/100 pcs.
Ref. No.
Breaking
840
M 8
8
20
36
70
5,0
5551.60.08
1380
M 10
10
25
45
230
9,4
5551.60.10
2040
M 12
12
30
53
340
16,6
5551.60.12
Thread
G
L2
L1
L3
B1
B2
D
Load in kg Length in
mm
min.
weight
packing
in kg/100 pcs.
Ref. No.
pcs.
1300
30
M 6
57
46
30
25
5
13
5
1,8
BW37.06.30
1300
40
M 6
66
56
40
25
5
13
5
2,8
BW37.06.40
1300
50
M 6
76
62
50
25
5
13
5
3,0
BW37.06.50
4200
M 16
14
35
62
700
26,0
5551.60.16
7200
M 20
16
40
71
1200
42,0
5551.60.20
10800
M 24
20
50
90
1800
84,0
5551.60.24
1300
60
M 6
87
76
60
25
5
13
5
3,3
BW37.06.60
19200
M 30
30
60
109
3200
157,0
5551.60.30
1300
95
M 6
126
115
100
25
5
13
5
3,7
BW37.06.00
2400
35
M 8
66
53
35
25
6
15
5
3,8
BW37.08.35
2400
50
M 8
80
68
50
25
6
15
5
4,9
BW37.08.50
2400
75
M 8
110
98
80
25
6
15
5
5,5
BW37.08.80
2400
75
M 8
130
118
100
25
6
15
5
6,5
BW37.08.00
3500
50
M 10
85
70
50
30
7
16
5
8,7
BW37.10.50
3500
95
M 10
135
120
100
30
7
16
5
11,0
BW37.10.00
4500
45
M 12
90
74
50
30
9
18
5
10,2
BW37.12.50
4500
85
M 12
140
124
100
30
9
18
5
15,0
BW37.12.10
4500
85
M 12
200
184
160
30
9
18
5
19,0
BW37.12.16
D1
D2
min.
weight
Ref. No.
packing
in kg/100 pcs.
■ Safety factor 1:6
Stainless Steel Forged Eye Nuts AISI 316 acc. to DIN 582
Breaking Load
in kg
D1
C
B
H
WLL
weight
in kg vertical
in kg/100 pcs.
Ref. No.
840
M 8
8
20
36
70
4,6
5552.60.08
1380
M 10
10
25
45
230
8,6
5552.60.10
2040
M 12
12
30
54
340
14,4
5552.60.12
4200
M 16
14
35
63
700
23,0
5552.60.16
7200
M 20
16
40
72
1200
33,4
5552.60.20
10800
M 24
20
50
90
1800
67,5
5552.60.24
19200
M 30
30
60
109
3200
130,0
5552.60.30
■ Safety factor 1:6
Eye Bolts with Ring AISI 304 Stainless Steel Highly Polished
Breaking
Thread
G
L1
L2
L3
B1
B2
Load in kg Length in
pcs.
mm
950
30
M 6
57
46
30
25
5
13
30
5
4,4
BW38.06.30
950
60
M 6
87
76
60
25
5
13
30
5
4,9
BW38.06.60
1500
35
M 8
66
53
35
25
6
15
40
5
7,3
BW38.08.35
1500
75
M 8
111
98
80
25
6
15
40
5
8,8
BW38.08.80
2200
50
M 10
85
70
50
30
7
16
45
5
13,6
BW38.10.50
2200
95
M 10
135
120
100
30
7
16
45
5
16,3
BW38.10.00
3300
85
M 12
140
124
100
30
10
18
50
5
28,2
BW38.12.10
3300
85
M 12
200
184
160
30
10
18
50
5
32,1
BW38.12.16
Shamoun
70
71
U-Bolts
Eye-Straps I Padeyes
U-Bolts AISI 304 Stainless Steel Highly Polished
Stainless Steel Eye Strap AISI 316
D
L2
d
H
Ref. No.
weight
in kg/100 pcs.
Breaking
G
L1
L3
L2
L4
B
D
Load in kg
min.
weight
packing
in kg/100 pcs.
Ref. No.
pcs.
750
M 4
66
35
25
30
26
4,0
5
2,1
BW34.04.35
900
M 5
67
35
25
30
25
4,4
5
2,6
BW34.05.35
1250
M 6
67
35
26
30
27
5,3
5
4,5
BW34.06.35
1250
M 6
84
50
26
30
27
5,3
5
5,7
BW34.06.50
1750
M 8
71
35
26
30
25
7,1
5
7,2
BW34.08.35
1750
M 8
86
50
26
30
25
7,1
5
9,7
BW34.08.50
1750
M 8
116
80
26
45
25
7,1
5
11,8
BW34.08.80
1750
M 8
80
40
30
32
42
8,0
5
12,4
BW34.88.40
1750
M 8
90
50
30
32
42
8,0
5
13,2
BW34.88.50
3500
M 10
95
45
40
40
30
10,0
5
18,4
BW34.10.45
3500
M 10
110
60
40
35
30
10,0
5
20,4
BW34.10.60
3500
M 10
150
100
40
85
30
10,0
5
25,0
BW34.10.10
5100
M 12
122
80
30
85
35
10,8
5
29,0
BW34.12.80
IL27.00.04
4
32
16
3,2
0,5
5
40
18
4,2
0,9
6
45
22
5,2
1,3
IL27.00.06
IL27.00.08
IL27.00.05
8
50
23
5,2
2,8
10
62
28
8,2
5,5
IL27.00.10
D
A
B
d
weight
Ref. No.
Stainless Steel Square Padeye AISI 316
U-Bolts AISI 316 Stainless Steel Highly Polished
in kg/100 pcs.
Breaking
G
L1
L3
L2
L4
A
B
D
Load in kg
min.
weight
Ref. No.
packing in kg/100 pcs.
5
30
35
4,3
2,9
pcs.
6
35
40
5,3
4,0
40
50
5,5
7,0
48
60
5,5
13,0
3500
M 8
100
50
40
45
0°
33
8
2
12,5
BW40.85.00
8
3500
M 8
100
50
40
45
8°
33
8
2
12,5
BW40.85.08
10
3500
M 8
100
50
40
45
18°
33
8
2
12,5
BW40.85.18
5100
M 10
120
60
48
55
0°
40
10
2
15,0
BW41.06.00
5100
M 10
120
60
48
55
8°
40
10
2
15,0
BW41.06.08
5100
M 10
120
60
48
55
18°
40
10
2
15,0
BW41.06.18
IL27.10.05
IL27.10.06
IL27.10.08
IL27.10.10
Stainless Steel Diamond Padeye AISI 316
Security U-Bolts
D
High Polished Stainless Steel AISI 316
with hard chromed layer
Breaking
G
D
L1
L2
L3
L4
B
B1
5100
M 12
14
122
65
41
B
C
D
weight
Ref. No.
in kg/100 pcs.
Blue Waves class 3 certified U-bolt is the most sold on the market
because of the high quality and resistance against rust.
Load in kg
A
weight
break
in kg/100 pcs.
NUT
5
23
4
37
59
2,9
6
27
4
40
64
4,0
8
33
5
50
80
7,0
IL27.10.05D
IL27.10.06D
IL27.10.08D
Ref. No.
48
34,5
32,5
31
50 Nm
BW43.12.65
40
30,0
30,0
22
50 Nm
BW43.10.45
CLASS 3 CERTIFIED
3500
M 10
12
95
45
38
CLASS 2 CERTIFIED
72
73
Welded Rings
D-rings I Triangles I Welded Ring Catches
Stainless Steel Welded Rings AISI 316
Stainless Steel D-ring AISI 316
D
H
Ref. No.
ø
A
B
Ref. No.
3
15
IL28.03.15
3
22
26
3
20
IL29.03.26
22
27
3
30
IL28.03.30
4
4
25
30
IL29.04.30
4
20
IL28.04.20
5
22
26
4
30
IL29.05.26
25
30
4
35
IL28.04.35
5
5
30
35
IL29.05.35
5
20
IL28.05.20
5
35
40
5
30
IL29.05.40
30
35
5
40
IL28.05.40
6
8
43
51
IL29.08.51
6
30
IL28.06.30
8
60
70
6
35
IL29.08.70
68
80
6
40
IL28.06.40
8
IL29.08.80
6
50
IL28.06.50
8
30
8
40
IL28.08.40
8
50
IL28.08.50
8
60
10
50
IL28.10.50
10
60
IL28.10.60
10
75
10
100
IL28.10.100
12
70
IL28.12.70
12
100
12
120
IL28.12.120
13
70
IL28.13.70
13
100
13
130
IL28.03.20
IL28.04.30
IL28.05.30
IL28.06.35
IL28.08.30
IL29.04.27
IL29.05.30
IL29.06.35
Stainless Steel Triangle Ring with Welded Cross Bar AISI 316
IL28.08.60
IL28.10.75
IL28.12.100
ø
A
B
C
Ref. No.
5
5
46
41
IL29.15.46
5
5
52
45
6
4
46
53
IL29.16.46
6
5
52
45
IL29.16.52
8
5
46
41
8
5
52
45
8
6
61
54
IL29.15.52
IL29.18.46
IL29.18.52
IL29.18.61
IL28.13.100
IL28.13.130
Stainless Steel Ring Catch AISI 316
74
A
B
C
E
F
Ref. No.
47,9
7,4
4,4
2,6
37,8
IL31.93.044
52,3
7,6
6,0
3,2
41,5
53,6
8,6
7,9
3,4
41,4
52,2
10,7
10,6
3,6
44,0
IL31.96.060
IL31.93.079
IL31.93.106
75
Swaging Tools I Swage Fittings I Swageless Fittings I Rigging Screws and Turnbuckles
Turnbuckles Casted Stainless Steel AISI 316
Stainless Steel Casted Turnbuckle Eye-Eye AISI 316
Breaking
A
L
L1
L2
D
weight
load in kg
Ref. No.
in kg/100 pcs.
430
M4
60
47
98
8
3,2
5781.00.55
610
M5
70
52
115
8
3,8
5781.00.70
1350
M6
90
66
155
11
10,0
5781.00.90
2070
M8
120
94
200
13
17,2
5781.01.20
2790
M10
150
120
235
15
26,0
5781.01.50
3960
M12
200
168
310
18
52,0
5781.02.00
7290
M16
250
210
370
26
110,0
5781.02.50
9900
M20
295
250
480
29
192,5
5781.02.95
Stainless Steel Casted Turnbuckle Hook-Hook AISI 316
Breaking
A
B
L
L2
L1
S
weight
load in kg
Ref. No.
in kg/100 pcs.
80
M4
15
60
47
98
7
3,2
5782.00.55
115
M5
19
70
52
115
7
3,8
5782.00.70
300
M6
23
90
66
155
10
10,0
5782.00.90
500
M8
31
120
94
200
11
17,2
5782.01.20
700
M10
36
150
120
235
12
26,0
5782.01.50
1260
M12
41
200
168
310
12
52,0
5782.02.00
2160
M16
55
250
210
370
16
110,0
5782.02.50
3150
M20
-
295
250
480
20
192,50
5782.02.95
Stainless Steel Casted Turnbuckle Hook-Eye AISI 316
Breaking
A
B
L
L1
L2
D
S
76
weight
Ref. No.
in kg/100 pcs.
load in kg
80
M4
15
60
47
98
8
7
3,2
5780.00.55
115
M5
19
70
52
115
8
7
3,8
5780.00.70
300
M6
23
90
66
155
11
10
10,0
5780.00.90
500
M8
31
120
94
200
13
11
17,2
5780.01.20
700
M10
36
150
120
235
15
12
26,0
5780.01.50
1260
M12
41
200
168
310
18
12
52,0
5780.02.00
2160
M16
55
250
210
370
26
16
110,0
5780.02.50
3150
M20
-
295
250
480
29
20
192,50
5780.02.95
77
Turnbuckles Casted Stainless Steel AISI 316
Wireteknik
Stainless Steel Casted Turnbuckle Fork-Fork AISI 316
Breaking
D
A
B
C
T
load in kg
min.
weight
packing
in kg/100 pcs.
Ref. No.
562
M5
10,5
80
125
5
10
5,1
I8712-050
1050
M6
10,5
92
140
6
10
9,0
I8712-060
1650
M8
11,5
112
170
8
10
15,0
I8712-080
2580
M10
15,5
120
190
10
10
24,0
I8712-100
3750
M12
19,2
150
240
12
5
52,5
I8712-120
4800
M14
16,2
170
270
14
5
63,5
I8712-140
6000
M16
22,8
190
314
16
5
100,0
I8712-160
7800
M20
27,3
220
452
20
5
197,0
I8712-200
■ Do not use casted turnbuckles for standing rigging
The yacht market was where it began. The first
machine was developed in the midseventies. A
machine that did away with convention. All previous concepts of fitting terminals onto full-steel
wire rope and solid rod were turned upside down.
Further, the terminal was also straight, not curved
as was usual hitherto.
The principle is simple. The terminal itself drives
the roller dies. The machine works with a freely
rotating pair of rollers, driven when the terminal is
drawn between them. It is a simple and robust
design with the minimum of movable parts, making
it reliable both in the field and in rational production.
Development was quick. In many fields, the need
for high strength swaged terminals is considerable. The machines perform equally effectively on
solid rod as they do on full-steel wire. The breaking
load is as high as that of the rod or wire
Electricity, Air or Man Power
A big advantage with the swage is their portability.
One man can do the job, whether he uses manual
pump, an electric motor or compressed air. Due to
the portability, a permanent onsite solution can be
achieved in all circumstances. The range is wide,
and the capacity is from 1,5 mm - 44 mm, wire or
rod.
Wireteknik swagingmachine A 100
incl. roller dies 2,5-3-4-5 mm,
handpump, tools and transportbox
Swaging range in mm
Dimensions in mm
weight in kg
Ref. No.
1,6 - 5
L 500 x W 300 x H 100
12
WTA1.00.00
Wireteknik swagingmachine A 200
incl. handpump, tools and transportbox
Swaging range in mm
Dimensions in mm
weight in kg
Ref. No.
1,6 - 8
L 500 x W 290 x H 140
19,5
0,8
Set roller dies 2,5 mm for A 200
Set roller dies 3,0 mm for A 200
0,8
Set roller dies 4,0 mm for A 200
0,8
Set roller dies 5,0 mm for A 200
0,8
Set roller dies 6,0 mm for A 200
0,8
Set roller dies 7,0 mm for A 200
1,7
Set roller dies 8,0 mm for A 200
1,7
78
WTA2.00.00
WTA2.00.02
WTA2.00.03
WTA2.00.04
WTA2.00.05
WTA2.00.06
WTA2.00.07
WTA2.00.08
79
Swaging machines
Swaging machines
Wireteknik swaging machine A 250
incl. handpump and tools
Swaging range in mm
Dimensions in mm
Wireteknik swaging machine A 270
incl. handpump and tools
weight in kg
Ref. No.
Swaging range in mm
Dimensions in mm
weight in kg
Ref. No.
58
WTA2.50.00
2,5 - 12
51
WTA2.70.00
Set roller dies 2,5 mm for A 250
2,7
WTA3.00.02
Set roller dies 2,5 mm for A 270
2,7
WTA3.00.02
Set roller dies 3,0 mm for A 250
2,7
WTA3.00.03
Set roller dies 3,0 mm for A 270
2,7
WTA3.00.03
Set roller dies 4,0 mm for A 250
2,7
WTA3.00.04
Set roller dies 4,0 mm for A 270
2,7
WTA3.00.04
Set roller dies 5,0 mm for A 250
2,7
WTA3.00.05
Set roller dies 5,0 mm for A 270
2,7
WTA3.00.05
Set roller dies 6,0 mm for A 250
2,7
WTA3.00.06
Set roller dies 6,0 mm for A 270
2,7
WTA3.00.06
Set roller dies 7,0 mm for A 250
2,7
WTA3.00.07
Set roller dies 7,0 mm for A 270
2,7
WTA3.00.07
Set roller dies 8,0 mm for A 250
2,7
WTA3.00.08
Set roller dies 8,0 mm for A 270
2,7
WTA3.00.08
Set roller dies 10,0 mm for A 250
5,1
WTA3.00.10
Set roller dies 10,0 mm for A 270
5,1
WTA3.00.10
5,1
WTA3.00.12
Set roller dies 12,0 mm for A 270
5,1
WTA3.00.12
Set roller dies 12,0 mm for Blue Wave E-Size Terminals 5,1
WTA3.00.12E
Set roller dies 12,0 mm for Blue Wave E-Size Terminals 5,1
WTA3.00.12E
2,5 - 12
L 1320 x W 370 x H 177
Set roller dies 12,0 mm for A 250
L 750 x W 420 x H 177
A 270 is a new compact light weight machine.
Roller dies are the same as the A250.
Wireteknik swaging machine A 350
incl. handpump and tools
Swaging range in mm
Wireteknik swaging machine Standard A 300
incl. handpump and tools
Swaging range in mm
Dimensions in mm
Dimensions in mm
weight in kg
Ref. No.
weight in kg
69
WTA3.50.00
Set roller dies 2,5 mm for A 350
2,7
WTA3.00.02
Set roller dies 3,0 mm for A 350
2,7
WTA3.00.03
Set roller dies 4,0 mm for A 350
2,7
WTA3.00.04
Set roller dies 5,0 mm for A 350
2,7
WTA3.00.05
Set roller dies 6,0 mm for A 350
2,7
WTA3.00.06
Set roller dies 7,0 mm for A 350
2,7
WTA3.00.07
Set roller dies 8,0 mm for A 350
2,7
WTA3.00.08
Set roller dies 10,0 mm for A 350
5,1
WTA3.00.10
Set roller dies 12,0 mm for A 350
5,1
WTA3.00.12
Set roller dies 12,0 mm for Blue Wave E-Size Terminals 5,1
WTA3.00.12E
Set roller dies 14,0 mm for A 350
5,1
WTA3.00.14
Set roller dies 16,0 mm for A 350
5,1
WTA3.00.16
2,5 - 12
Ref. No.
L 1117 x W 370 x H 210
67
WTA3.00.00
Set roller dies 2,5 mm for A 300
2,7
WTA3.00.02
Set roller dies 3,0 mm for A 300
2,7
WTA3.00.03
Set roller dies 4,0 mm for A 300
2,7
WTA3.00.04
Set roller dies 5,0 mm for A 300
2,7
WTA3.00.05
Set roller dies 6,0 mm for A 300
2,7
WTA3.00.06
Set roller dies 7,0 mm for A 300
2,7
WTA3.00.07
Set roller dies 8,0 mm for A 300
2,7
WTA3.00.08
Set roller dies 10,0 mm for A 300
5,1
WTA3.00.10
Set roller dies 12,0 mm for A 300
5,1
WTA3.00.12
Set roller dies 12,0 mm for Blue Wave E-Size Terminals 5,1
WTA3.00.12E
Set roller dies 14,0 mm for A 300
5,1
WTA3.00.14
Set roller dies 16,0 mm for A 300
5,1
WTA3.00.16
2,5 - 16
L 1320 x W 370 x H 240
Bigger machines and 220 and 380 Volt powerpacks on request.
A 350 is a new compact light weight machine.
Roller dies are the same as the A300.
80
81
Table of Swage Dimensions | Rig Maintenance
Wire-rope
mm
High quality Marine and rigging components
Inside diameter
in mm
(+/- 0,2)
Outside diameter
in mm
before swaging
Min.
Bore depth
in mm
(+/- 0,2)
Outside diameter
in mm
after swaging
2,0
2,2
5,41 - 5,53
32
4,70 - 4,82
2,5
2,8
5,41 - 5,53
32
4,70 - 4,82
3,0
3,5
6,22 - 6,35
38
5,44 - 5,56
4,0
4,4
7,42 - 7,54
45
6,23 - 6,35
5,0
5,3
9,00 - 9,12
51
7,83 - 7,95
6,0
6,5
12,42 - 12,54
64
10,95 - 11,12
7,0
7,5
14,18 - 14,30
70
12,50 - 12,70
8,0
8,4
16,01 - 16,13
83
14,07 - 14,30
10,0
10,5
17,73 - 17,85
89
15,70 - 15,90
12,0
12,5
20,00 - 20,08
105
17,60 - 17,80
12,0
12,5
21,32 - 21,44
120
18,82 - 19,05
14,0
14,8
24,88 - 25,00
140
22,00 - 22,23
16,0
17,0
28,05 - 28,17
160
25,15 - 25,40
19,0
20,0
34,40 - 34,52
200
31,44 - 31,75
22,0
23,3
40,21 - 40,46
230
36,20 - 36,50
26,0
28,0
45,77 - 46,02
280
40,97 - 41,28
28,0
29,6
50,00
310
44,00 - 44,50
30,0
*
*
*
*
*
*
*
*
E
32,0
■ * sizes on request
■ Minimum length L should be for 1 x 19 and 18 x 7 + IWRC
100 x wire rope diam.
■ Minimum length L should be for 7 x 7 - 7 x 19 - 6 x 36 w.s. + IWRC and compacted strand.
40 x wire rope diam.
■ Rig Maintenance
82
All rigs should be checked and maintained regularly. The rig and sails are your boat’s „engine“ and as with all engines,
the fittings should be checked at least each year. Are your rigging screws starting to fail? Are all treads and pins intact?
Cleaning the fittings and adding fresh lubricant, will extend the lifetime of your rig. A qualified inspector should inspect
a wire rig after 10-15 years. Ask for qualified riggers who can do inspections.
83
Eyes | Machined Forks
Welded Forks
Eye-Terminals AISI 316 Stainless Steel Highly Polished
ø
Breaking
Wire in mm
Load
D1
D2
D3
Welded Fork Terminals AISI 316 Stainless Steel Highly Polished
L1
L2
A
weight
Ref. No.
in kg/100 pcs.
ø
Breaking
Wire in mm
Load
in kg
D2
D3
L1
L2
A
B
PIN
weight
Ref. No.
in kg/100 pcs.
in kg
2,0
800
2,2
5,50
5,5
49,0
32
3
0,9
BW19.00.02
2,0
800
5,50
5,0
58
32
7,5
12,0
2,0
2,5
800
2,8
5,50
5,5
49,0
32
3
0,8
BW19.00.25
2,5
800
5,50
5,0
58
32
7,0
12,0
2,0
BW10.05.25
3,0
1300
3,5
6,35
6,5
58,0
38
4
1,3
BW19.00.03
3,0
800
6,35
5,0
67
38
7,5
12,0
2,3
BW10.05.03
4,0
2350
4,4
7,50
8,5
67,0
45
5
2,3
BW19.00.04
3,0
1250
6,35
6,0
68
38
9,5
13,0
2,8
●BW10.06.03
5,0
3500
5,3
9,00
10,5
79,0
51
6
3,9
BW19.00.05
3,0
1250
6,35
6,3
68
38
9,5
13,0
2,8
▲BW10.63.03
6,0
5600
6,5
12,58
13,0
94,0
64
8
8,7
BW19.00.06
4,0
800
7,50
5,0
71
45
7,5
12,0
2,7
BW10.05.04
6,0
6200
6,5
12,58
13,2
105,0
64
10
13,2
▲BW19.00.06X
4,0
1250
7,50
6,0
73
45
9,5
13,0
3,4
●BW10.06.04
7,0
5600
7,5
14,20
13,0
104,0
70
9
11,5
BW19.00.07
4,0
1250
7,50
6,3
73
45
9,5
13,0
3,4
BW10.63.04
7,0
6200
7,5
14,20
13,2
110,0
70
10
13,5
▲BW19.00.07X
4,0
2350
7,50
8,0
77
45
11
15,0
4,9
▲BW10.08.04
8,0
7600
8,4
16,00
14,5
124,0
83
10
17,0
BW19.00.08
5,0
1300
9,00
6,0
83
51
9,5
13,0
4,1
BW10.06.05
8,0
9800
8,4
16,00
16,5
141,0
83
12
23,5
▲BW19.00.08X
5,0
2350
9,00
8,0
87
51
11
15,0
5,5
●BW10.08.05
10,0
9800
10,5
17,80
16,3
137,0
89
11
25,0
BW19.00.10
5,0
3500
9,00
9,5
91
51
12
19,0
7,2
▲BW10.95.05
10,0
9800
10,5
17,80
16,3
165,0
100
16
38,0
▲BW19.00.10BW
6,0
2350
12,58
8,0
99
64
11
15,0
10,0
BW10.08.06
10,0
13000
10,5
17,80
19,5
165,0
100
16
38,0
BW19.00.10X
6,0
3500
12,58
9,5
104
64
12
19,0
11,3
BW10.95.06
13000
12,5
20,00
19,3
156,0
105
15
41,5
BW19.00.12
E
6,0
4700
12,58
11,0
108
64
13
23,0
13,9
●BW10.11.06
12,0
13000
12,5
21,40
19,3
178,0
120
15
41,9
▲BW19.00.12X
6,0
5100
12,58
12,0
110
64
14
25,0
17,6
▲BW10.12.06
14,0
17000
14,8
25,00
23,0
206,0
140
18
75,6
BW19.00.14
7,0
5100
14,20
12,0
119
70
14
25,0
18,1
BW10.12.07
16,0
24000
17,0
28,00
26,0
232,0
160
20
102,0
BW19.00.16
7,0
5400
14,20
12,7
119
70
14
25,0
18,1
▲BW10.13.07
19,0
27000
20,0
34,50
28,5
302,0
200
25
209,0
BW19.00.19
8,0
5100
16,00
12,0
136
83
14
25,0
21,6
BW10.12.08
22,0
31000
23,5
40,40
33,0
348,0
230
30
314,0
BW19.00.22
8,0
5400
16,00
12,7
136
83
14
25,0
21,6
●BW10.13.08
26,0
43000
27,5
46,00
36,0
400,0
280
30
425,0
BW19.00.26
14,0
7600
16,00
14,0
145
83
18
33,0
22,0
BW10.14.08
▲BW10.16.08
12,0
E
Note: All break loads are determined by eye (D3)
▲= recommended for compacted strand
E type terminal has unswaged outside diameter 20,0 mm.
Machined Fork Terminals AISI 316 Stainless Steel Highly Polished
ø
Breaking
Wire in mm
Load
L1
L2
L3
A
D
D1
PIN
weight
Ref. No.
in kg/100 pcs.
●BW10.05.02
8,0
9600
16,00
16,0
145
83
18
33,0
25,5
10,0
7600
17,80
14,0
151
89
18
40,0
35,0
BW10.14.10
10,0
7600
17,80
14,0
149
89
22
38,0
36,0
BW10.14.10L
10,0
7600
17,80
16,0
151
89
18
33,0
35,0
●BW10.16.10
10,0
7600
17,80
14,0
149
89
22
31,0
36,0
BW10.16.10L
10,0
13000
17,80
19,0
168
89
24
50,5
52,4
BW10.19.10
12,0
E
13000
20,00
19,0
187
105
30
48,0
66,0
BW10.19.12L
E
12,0
E
19000
20,00
19,0
189
105
24
52,0
60,0
BW10.19.12
E
12,0
13000
21,40
19,0
205
120
24
52,0
75,0
●BW10.19.12X
14,0
13000
25,00
19,0
221
140
30
48,0
75,0
BW10.19.14L
14,0
17000
25,00
22,0
232
140
30
57,0
112,7
●BW10.22.14
14,0
24000
25,00
25,4
235
140
30
62,0
125,0
BW10.25.14
16,0
24000
28,00
25,4
264
160
30
62,0
140,0
BW10.25.16
Note: All break loads are determined by clevis pin
● = recommended for yachting
▲= recommended for compacted strand
in kg
12,0
13000
212
45
105
24
19,0
21,4
100
BW72.19.12XB
14,0
17000
239
49
140
22
22,0
25,0
170
BW72.22.14
16,0
24000
271
52
160
25
25,4
28,0
210
BW72.25.16
19,0
25500
327
55
200
30
28,0
34,5
330
BW72.28.19
22,0
31000
377
67
230
35
32,0
40,4
480
BW72.32.22
26,0
43000
434
67
280
35
35,0
46,0
700
BW72.35.26
E
type terminal has unswaged outside diameter 20,0 mm.
Note: All break loads are determined by clevis pin
84
85
Toggle-Terminals
T-Terminals | Backing Plates | T-Forks
Toggle-Terminals AISI 316 Stainless Steel Highly Polished
ø
Breaking
Wire in mm
Load
D2
D3
L1
T-Terminals AISI 316 Stainless Steel Highly Polished
L2
A
B
PIN
weight
Ref. No.
in kg/100 pcs.
ø
L1
A
L2
B
weight
D
Ref. No.
in kg/100 pcs.
Bore-Hole
Wire in mm
in kg
3,0
1300
6,35
6,35
81
38
10
16,0
4,3
BW50.06.03
2,0
6,30
32
83
15,0
5,50
1,5
BW61.00.02
4,0
2350
7,50
8,00
94
45
11
19,0
7,3
BW50.08.04
2,5
6,30
32
83
15,0
5,50
1,5
BW61.00.25
5,0
3500
9,00
9,50
116
51
13
25,0
13,8
BW50.95.05
3,0
6,30
38
88
15,0
6,35
2,0
BW61.00.03
6,0
4100
12,58
11,00
135
64
15
25,0
27,3
BW50.11.06X
4,0
7,50
45
101
16,5
7,50
4,0
BW61.00.04
6,0
6200
12,58
12,70
151
64
18
31,0
33,4
BW50.12.06X
5,0
9,00
51
112
18,5
9,00
6,5
BW61.00.05
7,0
6200
14,20
12,70
157
70
18
31,0
35,7
BW50.12.07X
6,0
12,58
64
138
27,5
12,58
15,0
BW61.00.06
8,0
6200
16,00
12,70
170
83
18
31,0
37,5
BW50.13.08
7,0
14,20
80
144
29,0
14,20
17,0
BW61.00.07
8,0
9800
16,00
15,90
198
83
20
37,0
59,7
BW50.16.08X
8,0
16,00
83
184
34,0
16,00
31,5
BW61.00.08
10,0
9800
17,80
15,90
192
89
20
37,0
64,3
BW50.16.10
10,0
17,80
89
208
35,5
17,80
34,5
BW61.00.10
10,0
13000
17,80
19,00
228
100
24
42,0
100,0
BW50.19.10X
12,0
13000
21,40
19,00
240
120
24
42,0
103,0
BW50.19.12X
14,0
17000
25,00
22,00
277
140
26
46,0
170,2
BW50.22.14
16,0
24000
28,00
25,40
313
160
29
53,0
265,5
BW50.25.16
19,0
25500
34,50
28,00
399
200
34
60,0
512,0
BW50.28.19
22,0
31000
40,40
32,00
463
230
40
70,0
570,0
BW50.32.22
26,0
43000
46,00
36,00
518
280
44
80,0
750,0
BW50.35.26
B
L1
L2
Note: All break loads are determined by clevis pin
Backing Plates for T-Terminals, T-Forks and T-Rope Eyes: AISI 316 Stainless Steel
ø
A
B
C
D
weight
Ref. No.
in kg/100 pcs.
Wire in mm
2,0-3,0
50
12,5
15,0
7,0
0,5
BW61.61.03
4,0-5,0
88
26,0
26,0
9,5
3,5
BW61.61.05
6,0-7,0
123
32,0
38,0
15,0
9,0
BW61.61.07
8,0-10,0
151
41,0
38,0
19,0
23,0
BW61.61.10
T-Forks AISI 316 Stainless Steel Highly Polished
ø
L1
L2
B
L4
L5
D1
D2
Wire in mm
weight
Ref. No.
in kg/100 pcs.
3
83,5
13,0
15,0
9,50
6,35
6,0
6,35
3,8
BW61.34.06
4
93,0
15,0
16,5
11,00
7,50
8,0
7,50
7,4
BW61.34.08
5
104,5
19,0
18,5
12,00
9,00
9,5
9,00
11,5
BW61.34.95
6
130,0
25,5
27,5
14,00
12,58
12,0
12,58
22,3
BW61.34.12
WINNER 1220 vd stadt design
86
87
T-Rope Eyes | Hook-Terminals | Stemball-Terminals
Cups | Stemball-Eyes
T-Rope Eye AISI 316 Stainless Steel Highly Polished
Dyna-one
Breaking
Size
Load
L1
L2
Cups AISI 316 Stainless Steel
L3
L4
D1
B
weight
Ref. No.
ø
in kg/100 pcs.
A
Ref. No.
weight
B
C
in kg/100 pcs.
Wire in mm
in kg
3
800
81,5
27
26,0
15,0
6,35
15,0
3,8
BW61.65.06
3-4
9,00
11,0
26,0
1,0
BW62.62.04
4
1800
85,0
27
26,0
15,0
7,50
16,5
4,1
BW61.65.07
5
11,25
11,0
26,0
1,0
BW62.62.05
5
2800
99,5
38
34,0
22,0
9,00
18,5
8,7
BW61.65.09
6-7
16,00
9,5
26,0
1,0
BW62.62.07
6
4100
109,0
38
34,0
22,0
12,58
27,5
10,2
BW61.65.12
20,00
12,0
34,0
1,5
BW62.62.12
22,00
12,0
34,0
1,5
BW62.62.12X
8-10-12
E
12
E
Hook-Terminals AISI 316 Stainless Steel Highly Polished
ø
A
C
D
E
ø
weight
Radius
in kg/100 pcs.
8,0
1,9
BW63.00.25
F
Wire in mm
Stemball - Eye AISI 316 Stainless Steel Highly Polished
Ref. No.
ø
2,5
68,5
32,0
2,8
6,35
12,0
3,0
73,0
38,0
3,5
6,35
12,0
8,0
2,0
BW63.00.03
4,0
90,0
45,0
4,4
7,50
18,0
11,5
3,3
BW63.00.04
L1
L2
L3
L4
L5
D1
D2
R
Wire in mm
weight
Ref. No.
in kg/100 pcs.
5
83,0
16,0
11,0
21,0
6,0
10,50
26
10
6,9
BW19.62.09.26
6
98,5
15,5
11,0
25,0
8,0
13,00
26
10
12,2
BW19.62.12.26
7
106,0
18,5
10,0
27,0
9,0
13,00
26
10
16,6
BW19.62.14.26
8
128,0
21,5
12,0
30,0
10,0
16,50
34
15
24,9
BW19.62.16.34
Stemball-Terminals AISI 316 Stainless Steel Highly Polished
ø
A
B
C
D
E
F
E
weight
Ref. No.
in kg/100 pcs.
Wire in mm
3,0
58
54
38
3,5
6,35
13,0
1,1
BW62.00.03
4,0
69
63
45
4,4
7,50
16,0
2,4
BW62.00.04
5,0
79
72
51
5,3
9,00
19,0
3,8
BW62.00.05
6,0
90
84
64
6,5
12,58
20,0
7,9
BW62.00.06
7,0
94
87
70
7,5
14,20
21,3
10,0
BW62.00.07
8,0
116
108
83
8,4
16,00
26,3
16,9
BW62.00.08
10,0
129
119
89
10,5
17,80
27,5
23,5
BW62.00.10
10,0
128
117
89
10,5
17,80
31,6
23,5
BW62.00.10A
12,0
E
145
135
105
12,5
20,00
28,0
26,7
BW62.00.12
12,0
E
E
150
138
105
12,5
20,00
35,6
26,7
BW62.00.12A
12,0
152
138
105
12,5
21,40
35,4
38,0
BW62.00.12XA
14,0
195
183
140
14,8
25,00
40,2
58,5
BW62.00.14A
16,0
210
199
160
17,0
28,00
44,6
71,6
BW62.00.16A
E
type terminal has unswaged outside diameter 20,0 mm.
F
WINNER 1010 vd stadt design
88
89
Insidethread-Terminals | Domehead-Terminals
M-thread-Terminals
Insidethread-Terminals AISI 316 Stainless Steel Highly Polished
ø
L1
L2
L3
L4
D1
D2
Thread-Terminals AISI 316 Stainless Steel
A
Wire in mm
G
weight
Ref. No.
Ref. No.
ø
Breaking
Metric
in kg/100 pcs.
Right
Left
Wire in mm
Load in kg
L1
L2
L3
D
G
weight
Ref. No.
Ref. No.
Metric
in kg/100 pcs.
Right
Left
2,5
64
32
15
25
5,50
5,50
2,8
M 4
0,8
BW98.25.04
BW99.25.04
2,0
800
87
32
42
5,50
M 5
1,4
BW90.02.05
BW91.02.05
3,0
77
38
20
30
6,35
7,13
3,5
M 5
1,3
BW98.03.05
BW99.03.05
2,5
800
87
32
42
5,50
M 5
1,5
BW90.25.05
BW91.25.05
3,0
92
38
35
45
6,35
7,13
3,5
M 5
1,6
BW98.03.05L
BW99.03.05L
3,0
1300
100
38
48
6,35
M 6
2,0
BW90.03.06
BW91.03.06
4,0
84
45
20
30
7,50
8,00
4,4
M 6
1,8
BW98.04.06
BW99.04.06
4,0
1300
110
45
48
7,50
M 6
2,4
BW90.04.06
BW91.04.06
4,0
99
45
35
45
7,50
8,00
4,4
M 6
2,1
BW98.04.06L
BW99.04.06L
4,0
2350
117
45
57
7,50
M 8
3,0
BW90.04.08
BW91.04.08
5,0
90
51
20
30
9,00
9,00
5,3
M 6
2,8
BW98.05.06
BW99.05.06
5,0
2350
125
51
57
9,00
M 8
4,0
BW90.05.08
BW91.05.08
5,0
105
51
35
45
9,00
9,00
5,3
M 6
3,2
BW98.05.06L
BW99.05.06L
5,0
3500
130
51
63
9,00
M 10
4,5
BW90.05.10
BW91.05.10
5,0
112
51
40
53
9,00
12,58
5,3
M 8
5,4
BW98.05.08
BW99.05.08
6,0
3500
145
64
63
12,58
M 10
8,4
BW90.06.10
BW91.06.10
6,0
110
64
25
35
12,58
12,58
6,5
M 8
7,2
BW98.06.08
BW99.06.08
6,0
5100
162
64
80
12,58
M 12
11,0
BW90.06.12
BW91.06.12
6,0
126
64
40
50
12,58
12,58
6,5
M 8
8,2
BW98.06.08L
BW99.06.08L
7,0
5100
170
70
80
14,20
M 12
13,3
BW90.07.12
BW91.07.12
6,0
127
64
40
53
12,58
16,00
6,5
M 10
10,5
BW98.06.10
BW99.06.10
7,0
5900
180
70
89
14,20
M 14
16,0
BW90.07.14
BW91.07.14
8,0
140
83
40
50
16,00
16,00
8,4
M 10
15,4
BW98.08.10
BW99.08.10
8,0
5100
185
83
80
16,00
M 12
19,2
BW90.08.12
BW91.08.12
8,0
147
83
40
53
16,00
18,00
8,4
M 12
16,7
BW98.08.12
BW99.08.12
8,0
5900
194
83
89
16,00
M 14
20,0
BW90.08.14
BW91.08.14
10,0
150
89
40
50
17,80
17,80
10,5
M 12
19,4
BW98.10.12
BW99.10.12
8,0
8000
203
83
100
16,00
M 16
23,0
BW90.08.16
BW91.08.16
10,0
152
89
40
53
17,80
22,00
10,5
M 16
20,7
BW98.10.16
BW99.10.16
10,0
8000
210
89
100
17,80
M 16
35,0
BW90.10.16
BW91.10.16
13000
230
89
120
17,80
M 20
35,0
13000
249
105
120
20,00
M 20
45,0
BW90.12.20
12,0
13000
265
120
120
21,40
M 20
50,0
BW90.12.20X
BW91.12.20X
14,0
17000
308
140
140
25,00
M 22
76,8
BW90.14.22
BW91.14.22
16,0
17000
333
160
140
28,00
M 22
97,8
BW90.16.22
BW91.16.22
16,0
23000
363
160
170
28,00
M 24
111,0
BW90.16.24
BW91.16.24
19,0
25900
425
200
180
34,50
M 27
209,0
BW90.19.27
BW91.19.27
22,0
31000
480
230
200
40,50
M 30
314,0
BW90.22.30
BW91.22.30
26,0
43000
550
280
220
46,00
M 36
470,0
BW90.26.36
BW91.26.36
10,0
12,0
E
BW91.10.20
BW90.10.20
E
BW91.12.20
E
Note: All break loads are determined by thread
E type terminal has unswaged outside diameter 20,0 mm.
Domehead-Terminals AISI 316 Stainless Steel Highly Polished
ø
ø
L1
L2
L3
A1
A2
Wire in mm
90
weight
Ref. No.
in kg/100 pcs.
Left
3,0
3,5
52,0
48,5
38
6,35
10,0
1,1
BW66.00.03
4,0
4,4
59,0
55,5
45
7,50
12,0
2,4
BW66.00.04
5,0
5,3
66,5
62,5
51
9,00
14,0
3,8
BW66.00.05
6,0
6,5
79,0
74,0
64
12,58
18,0
7,9
BW66.00.06
91
UNF Thread-Terminals | Wall Toggle Terminal
Threaded Wall Toggles
Thread-Terminals AISI 316 Stainless Steel drilled for split pin
ø
Breaking
G
Wire in mm
Load in kg
UNF
L1
L2
L3
Threaded Wall Toggle (M left handed) AISI 316 Stainless Steel
D
weight
Ref. No.
Ref. No.
Breaking
G
D1
Load in kg
Metric
ø
in kg/100 pcs.
Right
Left
L4
L3
L1
L2
weight
Ref. No.
in kg/100 pcs.
Left
1300
1/4”
100
38
48
6,35
2,2
BW930306A
BW940306A
1250
M 6
6,4
14
40
81,0
47,0
3,8
BW03.15.14.06
1300
1/4”
110
45
48
7,50
2,5
BW930406A
BW940406A
2350
M 8
8,3
18
44
97,0
57,0
6,9
BW03.15.18.08
4,0
2350
5/16”
117
45
57
7,50
3,8
BW930408A
BW940408A
5,0
2350
5/16”
123
51
57
9,00
4,0
BW930508A
BW940508A
5,0
3500
3/8”
130
51
63
9,00
5,3
BW930510A
BW940510A
6,0
3500
3/8”
145
64
63
12,58
8,3
BW930610A
BW940610A
6,0
4700
7/16”
157
64
68
12,58
10,0
BW930611A
BW940611A
7,0
4700
7/16”
162
70
68
14,20
12,7
BW930711A
BW940711A
6,0
5400
1/2”
162
64
80
12,58
10,8
BW930612A
BW940612A
7,0
5400
1/2”
170
70
80
14,20
14,0
BW930712A
BW940712A
8,0
5400
1/2”
185
83
80
16,00
19,2
BW930812A
BW940812A
8,0
8000
5/8”
203
83
100
16,00
25,9
BW930816A
BW940816A
10,0
8000
5/8”
212
89
100
17,80
30,1
BW931016A
BW941016A
10,0
13000
3/4”
230
89
120
17,80
39,1
BW931020A
12,0
13000
3/4”
265
120
120
20,00
48,6
BW931220A
12,0
13000
3/4”
265
120
120
21,40
48,8
BW931220AX
BW941220AX
14,0
17000
7/8”
308
140
140
25,00
78,7
BW931422A
BW941422A
16,0
24000
1”
363
160
170
28,00
126,0
BW931625A
BW941625A
19,0
25500
1-1/8”
425
200
180
34,50
210,0
BW931927A
BW941927A
22,0
31000
1-1/4”
480
230
200
40,50
313,0
BW932230A
BW942230A
26,0
43000
1-3/8”
550
280
220
46,00
470,0
BW932636A
BW942636A
3,0
4,0
BW941020A
E
BW941220A
E
Note: All break loads are determined by thread
E type terminal has unswaged outside diameter 20,0 mm
Wall Toggle Terminal AISI 316 Stainless Steel
ø
Breaking
Wire in mm
Load in kg
L1
L2
L3
L4
D1 ø
D2
weight
Ref. No.
in kg/100
pcs.
92
3,0
1250
74
38
40
14
6,4
6,35
4,0
BW19.15.03
4,0
2350
87
45
44
18
8,3
7,50
6,5
BW19.15.04
93
Removable Eye System
Swageless Terminals
Inside Threaded Eyes right handed UNF
Breaking
G1
G2
L
T
B
D1
D2
weight
① First slide the jaw housing in place on the cable.
➁ Then slide the jaws onto the cable, ensuring there
Ref. No.
is some space between the jaw section.
the brass pressure ring on the end of the
cable. Make sure that the distance from the
pressure ring to the end of the cable end is 5
Slide the jaw housing over the
mm➃
jaws.
➄ The terminal can now be assembled. Screw the
head firmly to the jaw housing with a spanner.
Then tighten the lock nut firmly with a spanner.
➅ Blue Wave recommends sealing with a non acidic
sealing compound when assembling, Sikaflex-221,
for example.
Disassemble the Terminal and fill the jaw housing
and the cavity with sealing compound, then
assemble the terminal. Repeat this until the sealing
compound emerges from the hole through which
the cable is inserted. Clean the terminal. Do not
reuse the jaws.
Make sure that the dimensions of the terminal and
cable match.
in kg/100 pcs.
Load in kg
➂ Place
2350
5/16”
M4
41,0
5,0
17,0
14,0
8,5
46
BW511908A
3500
3/8”
M4
43,0
6,0
23,0
15,0
9,8
51
BW511910A
4700
7/16”
M4
58,0
8,0
24,0
18,0
11,2
97
BW511911A
5400
1/2”
M4
64,0
10,0
30,0
20,0
13,0
127
BW511912A
10000
5/8
M6
78,0
12,0
36,0
28,0
16,5
384
BW511916A
13000
3/4”
M6
90,0
16,0
43,0
30,0
19,5
466
BW511920A
MAINTENANCE
Check the terminal regularly for damage in connection
with longer exposure to concentrated saline solutions
or polluted surroundings. Check the seal, if it is
broken, remove all sealing compound. Then rinse the
terminal with fresh water and treat it with WD40.
Reseal the terminal with non-acidic sealing
compound.
After the first exposure to tensile stress the
terminal should be re-tightened.
Short Thread Terminal (right handed UNF) AISI 316 Stainless Steel
ø
Breaking
G
Wire in mm
Load in kg
UNF
D1
L1
L2
L3
weight
Ref. No.
in kg/100 pcs.
5
2350
5/16”
9,00
81,0
15
51
28
BW510508A
5
3500
3/8”
9,00
82,0
20
51
31
BW510510A
6
4700
7/16”
12,58
104,0
30
64
70
BW510611A
6
5400
1/2”
12,58
104,0
30
64
79
BW510612A
7
5400
1/2”
14,20
115,0
30
70
85
BW510712A
8
5400
5/8”
16,00
123,0
30
83
152
BW510816A
10
8000
3/4”
17,80
155,0
40
89
202
BW511020A
13000
3/4”
20,00
185,0
50
120
307
BW511220A
12
E
The terminal can be used with the following types of
cable: 1x19, 7x19, 7x7, 6x36WS+|WRC, 18x7+|WRC
and compacted strand.
When Swageless Terminals are installed, the breaking
strength of the cable used will be reduced by 0-15%.
E
Note: All break loads are determined by thread
E
type terminal has unswaged outside diameter 20,0 mm
Jaw housing
Jaws
Pressure ring (brass)
1
Head
2
6
3
94
4
5
95
Swageless Terminals
Swageless Terminals
Swageless Toggle-Terminals AISI 316 Stainless Steel Highly Polished
Swageless Eye-Terminals AISI 316 Stainless Steel Highly Polished
D1
Breaking
Wire in mm
Load in kg
A
L1
L2
D2
NV
NV1
weight
Ref. No.
in kg/100 pcs.
3
750
5,5
50
58
6,3
10
12
4,0
BW82.19.03
4
1500
7,0
58
68
8,3
13
14
7,3
BW82.19.04
5
2180
8,0
70
81
10,3
14
16
9,8
BW82.19.05
6
3700
9,0
83
97
13,0
17
19
15,0
BW82.19.06
7
4700
9,0
89
105
13,0
18
22
21,2
BW82.19.07
8
5600
10,0
103
121
14,5
19
24
28,1
BW82.19.08
10
8300
13,0
116
135
16,2
24
27
46,0
BW82.19.10
12
12000
15,0
137
160
19,5
27
32
72,0
BW82.19.12
14
17000
18,0
159
185
22,0
30
36
110,0
BW82.19.14
16
23000
20,0
180
197
25,0
32
41
160,0
BW82.19.16
weight
Ref. No.
D1
Breaking
Wire in mm
Load in kg
3
750
6
55
63
8
6
14
12
5,5
BW84.06.03
4
1500
8
62
73
8
8
19
14
9,0
BW84.08.04
5
2180
10
72
83
10
10
22
16
15,0
BW84.10.05
6
3700
12
82
95
12
12
27
19
23,0
BW84.12.06
7
4700
12
102
115
13
12
29
22
29,0
BW84.12.07
8
5600
14
103
118
14
14
30
24
38,0
BW84.14.08
10
8300
16
117
135
16
16
36
27
63,0
BW84.16.10
12
12000
18
142
162
16
19
42
32
97,0
BW84.19.12
14
17000
21
162
190
19
22
46
36
135,0
BW84.22.14
16
23000
23
184
217
22
25
55
41
215,0
BW84.25.16
L2
L3
L2
L1
L3
A
B
C
D
weight
PIN
in kg/100 pcs.
Ref. No.
3,0
750
71
50
14
8
15,0
12,0
6,0
8,03
BW83.06.03
4,0
1500
90
61
18
10
19,0
15,0
8,0
11,25
BW83.08.04
5,0
2180
108
75
23
12
25,5
21,0
9,5
20,00
BW83.10.05
6,0
3700
125
88
30
15
28,5
23,0
11,0
32,70
BW83.11.06
7,0
4700
140
100
30
18
31,0
24,7
12,7
45,66
BW83.12.07
8,0
5600
148
102
30
18
30,0
23,7
12,7
49,73
BW83.12.08
10,0
8300
176
125
35
20
40,0
32,0
16,0
92,00
BW83.16.10
12,0
12000
206
138
40
24
45,5
36,0
19,0
124,40
BW83.19.12
14,0
17000
230
157
50
26
46,0
35,0
22,2
222,21
BW83.22.14
16,0
23000
261
180
60
29
53,0
40,0
25,4
334,91
BW83.25.16
Swageless Wall Toggle AISI 316 Stainless Steel Highly Polished
Swageless Fork-Terminals AISI 316 Stainless Steel Highly Polished
L1
Breaking
Load in kg
Note: All break loads are determined by clevis pin and wedges.
Note: All break loads are determined by wedges (jaws) and eye (D2)
A
D1
Wire in mm
D2
NV
NV1
in kg/100 pcs.
PIN
D1
Breaking
Wire in mm
Load in kg
D1
D2
D3
L1
L2
ø
weight
Ref. No.
in kg/100 pcs.
3,0
700
14
40
6,4
64
43
5,8
BW83.15.03
4,0
1500
18
44
8,3
79
50
9,2
BW83.15.04
Note: All break loads are determined by wedges (jaws) and clevis pin
96
97
Swageless Terminals
Swageless Terminal Jaws | Spelter Fork Sockets
Swageless-Terminals M Thread AISI 316 Stainless Steel Highly Polished
D1
Breaking
Wire in mm
Load in kg
L1
L2
NV
Jaw and Ring Sets for Swageless Terminals
G
weight
Ref. No.
Ref. No.
ø
Metric
in kg/100 pcs.
Right
Left
Wire rope in mm
NV1
Ref. No.
3,0
BW08.00.03
3
750
79
42
10
12
M 5
4,2
BW80.03.05
BW81.03.05
4,0
BW08.00.04
3
750
85
47
10
12
M 6
4,5
BW80.03.06
BW81.03.06
5,0
BW08.00.05
4
1500
92
47
12
14
M 6
5,6
BW80.04.06
BW81.04.06
6,0
BW08.00.06
4
1500
102
57
12
14
M 8
6,6
BW80.04.08
BW81.04.08
7,0
BW08.00.07
5
2180
111
57
13
16
M 8
9,0
BW80.05.08
BW81.05.08
8,0
BW08.00.08
5
2180
117
63
13
16
M 10
10,0
BW80.05.10
BW81.05.10
10,0
BW08.00.10
6
3700
128
63
16
19
M 10
15,0
BW80.06.10
BW81.06.10
12,0
BW08.00.12
6
3700
145
80
16
19
M 12
17,0
BW80.06.12
BW81.06.12
14,0
BW08.00.14
7
4700
153
80
18
22
M 12
22,0
BW80.07.12
BW81.07.12
16,0
BW08.00.16
7
4700
162
89
18
22
M 14
25,0
BW80.07.14
BW81.07.14
8
5600
162
80
19
24
M 12
28,0
BW80.08.12
BW81.08.12
8
5600
171
89
19
24
M 14
31,0
BW80.08.14
BW81.08.14
8
5600
182
100
19
24
M 16
40,0
BW80.08.16
BW81.08.16
10
8300
190
100
24
27
M 16
48,0
BW80.10.16
BW81.10.16
12
12000
227
120
27
32
M 20
79,0
BW80.12.20
BW81.12.20
14
17000
264
140
30
36
M 22
124,0
BW80.14.22
BW81.14.22
16
23000
308
170
32
41
M 24
175,0
BW80.16.24
BW81.16.24
Note: Break load determined by wedges (jaws) and thread
Spelter Fork Socket
ø
Breaking
Wire in mm
Load in kg
L1
L2
L3
L4
L5
D1
D2
weight
Ref. No.
in kg/100 pcs.
19
25500
258
121
55
37
30
28
70
327
BW842819
22
31000
309
145
67
43
35
32
80
485
BW843222
26
43000
366
154
72
46
35
35
85
685
BW843526
32
76000
435
205
93
56
44
48
110
1405
BW844832
Note: All break loads are determined by clevis pin
■ Other sizes on request
Swageless-Terminals UNF Thread AISI 316 Stainless Steel Highly Polished (incl. split pin hole)
D1
Breaking
G
Wire in mm
Load in kg
UNF
3
750
1/4
85
47
10
4
1500
1/4
92
47
12
4
1500
5/16
102
57
5
2180
5/16
111
5
2380
3/8
117
6
3700
3/8
6
3700
6
3700
7
L1
NV
NV1
weight
Ref. No.
in kg/100 pcs.
Right
12
4,5
BW80.03.06A
14
5,6
BW80.04.06A
12
14
6,6
BW80.04.08A
57
13
16
9,0
BW80.05.0
63
13
16
10,0
8ABW80.05.10A
128
63
16
19
15,0
BW80.06.10A
7/16
133
68
16
19
15,0
BW80.06.11A
1/2
145
80
16
19
17,5
BW80.06.12A
4700
1/2
162
80
18
22
17,5
BW80.07.12A
8
5600
1/2
162
80
19
24
19,5
BW80.08.12A
8
5600
5/8
182
100
19
24
31,5
BW80.08.16A
10
8300
5/8
190
100
24
27
47,2
BW80.10.16A
12
12000
3/4
227
120
27
32
79,0
BW80.12.20A
14
17000
7/8
264
140
30
36
124,0
BW80.14.22A
16
23000
1
308
170
32
41
175,0
BW80.16.25A
Note: Break load determined by wedges (jaws) and thread
98
L2
This stainless steel spelter socket to be used with the well
known and tested method of brooming the wire rope and
glueing it in with wirelock® (ask for assemble instructions)
■ Available with left handed thread on request.
99
Fork-Fork Rigging Screws
Eye-Eye Rigging Screws | Fork-Eye Rigging Screws
Rigging Screws AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
Metric
L1
L2
Eye-Eye Rigging Screws AISI 316 Stainless Steel highly polished
A
D
B
PIN
weight
Ref. No.
in kg/100 pcs.
Breaking
G
Load in kg
Metric
L1
L2
D1
A
D2
Ref. No.
weight
in kg/100 pcs.
800
M 5
180
126
7,5
5,0
12,0
5,1
BW12.00.05
800
M 5
190
131
5,5
3
12
3,5
BW19.19.05
1250
M 6
200
138
7,5
5,0
12,0
9,0
BW12.00.06
1300
M 6
204
136
6,5
4
14
10,7
BW19.19.06
1300
M 6
202
140
9,5
6,0
13,0
14,0
BW12.00.06X
2350
M 8
244
164
8,5
5
17
14,4
BW19.19.08
1300
M 8
234
158
9,5
6,0
13,0
15,0
BW12.00.08
3500
M 10
270
187
10,5
6
22
22,9
BW19.19.10
2350
M 8
240
166
11,0
8,0
15,0
15,0
BW12.00.08X
5100
M 12
334
226
13,0
8
25
37,8
BW19.19.12
2350
M 10
272
188
11,0
8,0
15,0
24,0
BW12.00.10
5900
M 14
376
257
13,0
9
28
51,0
BW19.19.14
3500
M 10
280
196
12,0
9,5
19,0
26,0
BW12.00.10X
8000
M 16
408
279
14,5
10
31
72,5
BW19.19.16
5100
M 12
350
244
14,0
12,0
25,0
52,5
BW12.00.12
13000
M 20
488
334
19,5
15
40
104,5
BW19.19.20
5900
M 14
387
267
14,0
12,0
25,0
63,5
BW12.00.14
17000
M 22
597
416
23,0
18
47
354,0
BW19.19.22✸
5900
M 14
403
283
18,0
14,0
33,0
63,5
BW12.00.14X
20000
M 24
713
480
26,0
20
53
670,0
BW19.19.24
8000
M 16
442
309
22,0
14,0
31,0
100,0
BW12.00.16L
27000
M 27
759
527
28,5
25
65
710,0
BW19.19.27✸
8000
M 16
446
313
18,0
14,0
33,0
100,0
BW12.00.16
31000
M 30
861
581
33,0
30
70
991,0
BW19.19.30✸
43000
M 36
892
618
36,0
30
80
1288,0
BW19.19.36✸
8000
M 16
446
313
18,0
16,0
33,0
100,0
BW12.00.16X
13000
M 20
546
386
30,0
19,0
50,5
197,0
BW12.00.20L
13000
M 20
550
390
24,0
19,0
50,5
197,0
BW12.00.20
17000
M 22
653
472
30,0
22,0
57,5
430,0
BW12.00.22✸
20000
M 24
769
536
30,0
25,4
62,5
638,0
BW12.00.24
Note: All break loads are determined by thread and pin size
✸ Bodies with bronze inserts
Note: All break loads are determined by clevis pin and thread
✸ Bodies with bronze inserts
Fork-Eye Rigging Screws AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
Metric
Machined Rigging Screws AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
Metric
L1
L2
B
A
D
PIN
weight
Ref. No.
M 20
619
453
45
20
19
330
BW74.00.20✸
17000
M 22
637
456
49
22
22
892
BW74.00.22✸
20000
M 24
763
530
52
25
25
1193
BW74.00.24✸
25500
M 27
813
578
55
30
28
1803
BW74.00.27✸
31000
M 30
918
656
67
35
32
2614
BW74.00.30✸
43000
M 36
970
696
67
35
35
3390
BW74.00.36✸
L2
A
A2
B
D1
D2
PIN
weight
Ref. No.
in kg/100 pcs.
800
M 5
188
129
7,5
3
12,0
5,0
5,5
4,2
BW19.12.05
1300
M 6
206
138
7,5
4
12,0
5,0
6,5
6,3
BW19.12.06
2350
M 8
244
164
9,5
5
13,0
6,0
8,5
13,0
BW19.12.08
3500
M 10
271
188
11,0
6
15,0
8,0
10,5
21,9
BW19.12.10
5100
M 12
343
235
14,5
8
25,0
12,0
13,0
44,0
BW19.12.12
5900
M 14
381
262
14,5
9
25,0
12,0
13,0
60,0
BW19.12.14
BW19.12.16
8000
M 16
426
296
18,0
10
33,0
14,0
14,5
85,6
13000
M 20
518
364
24,0
15
50,0
19,0
19,5
169,3
BW19.12.20
17000
M 22
625
444
30,0
18
57,0
22,0
23,0
398,5
BW19.12.22✸
20000
M 24
741
508
30,0
20
62,0
25,4
26,0
580,0
BW19.12.24✸
in kg/100 pcs.
13000
L1
Note: All break loads are determined by clevis pin and thread
Bodies with bronze inserts
✸
Note: All break loads are determined by clevis pin and thread
✸ Bodies with bronze inserts
100
101
Rigging Screws | Stud-Fork
Machined Stud-Fork Rigging Screws Stud-Fork | Stud-Stud Rigging Screws
Machined Fork-Stud Rigging Screws AISI 316 Stainless Steel highly polished
Rigging Screws AISI 316 Stainless Steel highly polished
Breaking
ø
Wire in mm
Breaking
G
Load in kg
Metric
L1
L2
A
D
B
C
weight
Ref. No.
800
M 5
206
152
7,5
5,0
12,0
5,50
4,5
BW12.02.05
2,5
800
M 5
206
152
7,5
5,0
12,0
5,50
4,6
BW12.25.05
3,0
1250
M 6
232
170
7,5
5,0
12,0
6,35
8,5
BW12.03.06
3,0
1300
M 6
233
171
9,5
6,0
13,0
6,35
8,5
BW12.03.06X
4,0
1250
M 6
242
180
7,5
5,0
12,0
7,50
8,7
BW12.04.06
4,0
1300
M 6
242
180
9,5
6,0
13,0
7,50
9,1
BW12.04.06X
4,0
1300
M 8
275
199
9,5
6,0
13,0
7,50
13,0
BW12.04.08
4,0
2350
M 8
277
201
11,0
8,0
16,0
7,50
13,0
BW12.04.08X
5,0
1300
M 8
281
205
9,5
6,0
13,0
9,00
13,2
BW12.05.08
5,0
2350
M 8
284
208
11,0
8,0
15,0
9,00
14,8
BW12.05.08X
5,0
2350
M 10
312
228
11,0
8,0
16,0
9,00
22,5
BW12.05.10
BW12.05.10X
5,0
3500
M 10
316
232
12,0
9,5
19,0
9,00
22,5
6,0
2350
M 10
327
243
11,0
8,0
16,0
12,58
25,6
BW12.06.10
6,0
3500
M 10
330
250
12,0
9,5
19,0
12,58
27,4
BW12.06.10X
6,0
5100
M 12
393
287
14,0
12,0
25,0
12,58
47,5
BW12.06.12
7,0
5100
M 12
401
295
14,0
12,0
25,0
14,20
50,0
BW12.07.12
BW12.07.14
7,0
5900
M 14
439
319
14,0
12,0
25,0
14,20
58,0
7,0
5900
M 14
453
335
18,0
14,0
33,0
14,20
68,8
BW12.07.14X
8,0
5100
M 12
416
310
14,0
12,0
25,0
16,00
53,5
BW12.08.12
8,0
5900
M 14
453
333
14,0
12,0
25,0
16,00
63,5
BW12.08.14
8,0
8000
M 16
499
366
18,0
14,0
33,0
16,00
89,5
BW12.08.16
8,0
8000
M 16
497
364
22,0
14,0
30,0
16,00
89,5
BW12.08.16L
8,0
8000
M 16
499
366
18,0
16,0
33,0
16,00
89,5
BW12.08.16X
10,0
8000
M 16
506
373
18,0
14,0
33,0
17,80
93,0
BW12.10.16
10,0
8000
M 16
504
371
22,0
14,0
33,0
17,80
93,0
BW12.10.16L
10,0
8000
M 16
510
376
18,0
16,0
33,0
17,80
93,0
BW12.10.16X
10,0
13000
M 20
587
427
24,0
19,0
50,0
17,80
170,1
BW12.10.20
12,0
13000
M 20
606
446
24,0
19,0
50,0
20,00
170,1
BW12.12.20
12,0
13000
M 20
622
462
24,0
19,0
50,0
21,40
170,1
BW12.12.20X
14,0
17000
M 22
736
555
30,0
22,0
57,0
25,00
452,0
BW12.14.22✸
14,0
20000
M 24
846
613
30,0
25,4
60,5
25,00
642,0
BW12.14.24
16,0
17000
M 22
696
588
30,0
22,0
57,0
28,00
490,0
BW12.16.22✸
16,0
20000
M 24
874
641
30,0
25,4
60,5
28,00
662,0
BW12.16.24
C
102
A
D
C
weight
Ref. No.
in kg/100 pcs.
Left
21,4
240
BW74.12.20X✸
25,0
649
BW74.14.22✸
22
28,0
670
BW74.16.22✸
25
25
28,0
876
BW74.16.24✸
30
28
34,5
1332
BW74.19.27✸
820
35
32
40,5
1888
BW74.22.30✸
912
35
35
46,0
2484
BW74.26.36✸
weight
Ref. No.
PIN
Wire in mm
13000
12,0
M 20
646
492
20
19
17000
14,0
M 22
720
540
22
22
17000
16,0
M 22
745
565
22
20000
16,0
M 24
863
630
25500
19,0
M 27
963
728
31000
22,0
M 30
1082
43000
26,0
M 36
1186
Note: All break loads are determined by clevis pin and thread
✸ Bodies with bronze inserts
C
Stud-Stud Rigging Screws AISI 316 Stainless Steel highly polished
ø
Wire in mm
E
Breaking
G
Load in kg
Metric
D1
L1
L2
in kg/100 pcs.
2,0
800
M 5
5,50
239
178
3,8
BW12.02.05T
2,5
800
M 5
5,50
239
178
3,6
BW12.25.05T
3,0
1250
M 6
6,35
274
204
6,3
BW12.03.06T
4,0
1250
M 6
7,50
284
214
7,5
BW12.04.06T
4,0
2350
M 8
7,50
312
242
12,6
BW12.04.08T
5,0
2350
M 8
9,00
328
258
14,6
BW12.05.08T
5,0
3500
M 10
9,00
350
267
20,8
BW12.05.10T
6,0
3500
M 10
12,58
380
297
21,4
BW12.06.10T
6,0
5100
M 12
12,58
410
327
42,4
BW12.06.12T
7,0
5100
M 12
14,20
454
346
47,4
BW12.07.12T
7,0
5900
M 14
14,20
488
369
56,6
BW12.07.14T
8,0
5100
M 12
16,00
490
382
55,2
BW12.08.12T
8,0
5600
M 14
16,00
521
402
65,0
BW12.08.14T
8,0
8000
M 16
16,00
548
418
82,7
BW12.08.16T
10,0
8000
M 16
17,80
566
436
86,8
BW12.10.16T
13000
M 20
17,80
620
466
135,2
13000
M 20
20,00
658
504
148,8
BW12.12.20T
12,0
13000
M 20
21,40
658
504
151,7
BW12.12.20XT
14,0
17000
M 22
25,00
820
639
377,8
BW12.14.22T✸
16,0
17000
M 22
25,00
870
689
378,0
BW12.16.22T
16,0
20000
M 24
28,00
979
746
553,2
BW12.16.24T
19,0
27000
M 27
34,50
1114
879
801,2
BW12.19.27T✸
22,0
31000
M 30
40,50
1245
983
1178,6
BW12.22.30T✸
26,0
43000
M 36
46,00
1402
1128
1588,8
BW12.26.36T✸
10,0
Note: All break loads are determined by clevis pin and thread
✸ Bodies with bronze inserts
E type terminal has unswaged outside diameter 20,0 mm.
L2
Metric
in kg/100 pcs.
PIN
2,0
E
L1
G
ø
Load in kg
12,0
E
BW12.10.20T
E
Note: All break loads are determined by thread
✸ Bodies with bronze inserts
E type terminal has unswaged outside diameter 20,0 mm.
103
Rigging Screws Stud-eye
Bodies
Stainless Steel Bodies AISI 316 Stainless Steel Highly Polished
Rigging Screws Stud-Eye AISI 316 Stainless Steel
ø
Wire in mm
Breaking
G
Load in kg
Metric
L1
L2
A
D2
weight
Ref. No.
in kg/100 pcs.
Breaking
G
Load in kg
Metric
L1
D1
KW
weight
Ref. No.
in kg/100 pcs.
Metric
800
M 5
213
151
5,50
5,5
3,7
BW19.02.05
800
M 5
80
8,0
-
1,3
BW01.12.05
2,5
800
M 5
213
151
5,50
5,5
3,4
BW19.25.05
1300
M 6
92
10,0
-
2,5
BW01.12.06
3,0
1300
M 6
234
166
6,35
6,5
6,3
BW19.03.06
2350
M 8
112
13,5
-
5,8
BW01.12.08
4,0
1300
M 6
244
176
7,50
6,5
6,7
BW19.04.06
3500
M 10
120
17,2
-
8,8
BW01.12.10
4,0
2350
M 8
282
202
7,50
8,5
12,4
BW19.04.08
5100
M 12
150
21,3
-
16,0
BW01.12.12
5,0
2350
M 8
288
208
9,00
8,5
13,4
BW19.05.08
5900
M 14
170
21,3
-
17,9
BW01.12.14
5,0
3500
M 10
311
227
9,00
10,5
19,5
BW19.05.10
8000
M 16
190
26,9
-
28,1
BW01.12.16
6,0
3500
M 10
326
242
12,58
10,5
23,4
BW19.06.10
13000
M 20
220
33,7
-
50,3
BW01.12.20
6,0
5400
M 12
379
271
12,58
13,0
38,5
BW19.06.12
13000
M 20
240
40,0
36
53,0
BW01.23.20✸
7,0
5400
M 12
387
279
14,20
13,0
40,8
BW19.07.12
17000
M 22
270
45,0
41
288,5
BW01.23.22✸
7,0
5600
M 14
432
314
14,20
13,0
46,7
BW19.07.14
20000
M 24
320
43,0
-
340,0
BW01.12.24
8,0
5400
M 12
400
292
16,00
13,0
51,1
BW19.08.12
23000
M 24
325
50,0
46
384,2
BW01.23.24✸
8,0
5600
M 14
446
328
16,00
13,0
55,1
BW19.08.14
27000
M 27
345
55,0
50
507,0
BW01.23.27✸
8,0
7600
M 16
478
350
16,00
14,5
74,6
BW19.08.16
31000
M 30
375
60,0
55
637,0
BW01.23.30✸
10,0
7600
M 16
495
367
17,80
14,5
86,6
BW19.10.16
43000
M 36
410
65,0
60
751,0
BW01.23.36✸
13000
M 20
553
405
17,80
19,3
126,9
BW19.10.20
13000
M 20
573
419
20,00
19,5
136,9
BW19.12.T20
12,0
13000
M 20
599
435
21,40
19,5
152,8
BW19.12.T20X
14,0
17000
M 22
708
527
25,00
23,0
163,8
BW19.14.22X✸
16,0
20000
M 24
846
613
28,00
26,0
233,6
BW19.16.24X
19,0
27000
M 27
934
702
34,50
29,0
394,0
BW19.19.27X✸
22,0
31000
M 30
1057
777
40,50
33,0
1090,4
BW19.22.30X✸
26,0
43000
M 36
1150
873
46,00
36,0
1446,8
BW19.26.36X✸
2,0
10,0
12,0
E
E
Note: All break loads are determined by thread
✸Bodies with bronze inserts
Note: All break loads are determined by thread and pin size
✸ Bodies with bronze inserts
E type terminal has unswaged outside diameter 20,0 mm.
104
105
Threaded Forks | Threaded Eyes
Chromed Bronze Body Rigging Screws Fork-Fork
Welded Threaded Forks AISI 316 Stainless Steel Highly Polished (incl. clevis pin)
Breaking
G
Load in kg
Metric
A
L1
D
L2
weight
Ref. No.
Ref. No.
Breaking
G
in kg/100 pcs.
Right
Left
Load in kg
UNF
L3
PIN
Rigging screws Chromed Bronze Body AISI 316 Stainless Steel Highly Polished
L1
L2
A
D
B
PIN
weight
Ref. No.
in kg/100 pcs.
800
M 5
7,5
5,0
60,0
12,0
41,0
1,9
BW02.12.05B
BW03.12.05B
1300
1/4”
205
143
9,5
6,35
13,0
12,0
BW13.00.06A
1000
M 6
7,5
5,0
67,0
12,0
47,0
2,3
BW02.12.06B
BW03.12.06B
2350
5/16”
244
168
11,0
8,00
15,0
16,0
BW13.00.08A
1300
M 6
9,5
6,0
68,0
13,0
47,0
2,8
BW02.12.06XB
BW03.12.06XB
3500
3/8”
299
197
12,0
9,50
19,0
25,0
BW13.00.10A
1300
M 8
10,0
6,0
79,0
13,0
57,0
3,9
BW02.12.08B
BW03.12.08B
4700
7/16”
312
222
12,0
11,00
23,0
35,0
BW13.00.11A
2350
M 8
11,0
8,0
82,0
15,0
57,0
5,5
BW02.12.08XB
BW03.12.08XB
5400
1/2”
358
248
14,0
12,70
25,0
63,5
BW13.00.12A
2350
M 10
11,0
8,0
90,0
15,0
63,0
6,9
BW02.12.10B
BW03.12.10B
8000
5/8”
450
312
18,0
16,00
33,0
121,0
BW13.00.16AX
3500
M 10
12,0
9,5
94,0
19,0
63,0
8,7
BW02.12.10XB
BW03.12.10XB
13000
3/4”
562
392
24,0
19,00
50,5
218,0
BW13.00.20A
5100
M 12
14,0
12,0
119,0
25,0
80,0
17,0
BW02.12.12B
BW03.12.12B
17000
7/8”
753
559
26,0
22,00
57,5
316,0
BW13.00.22A
5100
M 12
18,0
14,0
129,0
33,0
80,0
26,3
BW02.12.12XB
BW03.12.12XB
24000
1”
888
648
29,0
25,40
62,0
490,0
BW13.00.25A
5100
M 14
14,0
12,0
137,0
25,0
90,0
28,2
BW02.12.14B
BW03.12.14B
5900
M 14
14,0
14,0
137,0
33,0
86,0
30,1
BW02.12.14XB
BW03.12.14XB
8000
M 16
18,0
14,0
151,0
33,0
100,0
35,2
BW02.12.16B
BW03.12.16B
8000
M 16
18,0
16,0
151,0
33,0
100,0
37,3
BW02.12.16XB
BW03.12.16XB
13000
M 20
24,0
19,0
191,0
50,5
119,0
71,9
BW02.12.20B
BW03.12.20B
17000
M 22
30,0
22,0
224,5
57,5
140,0
120,1
BW02.12.22B
BW03.12.22B
20000
M 24
30,0
25,4
258,0
62,5
170,0
180,0
BW02.12.24B
BW03.12.24B
Note: All break loads are determined by clevis pin and thread
Note: All break loads are determined by clevis pin and thread
L3
Threaded Eyes AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
Metric
D1
D2
L1
L2
B
Min.
weight
Ref. No.
Ref. No.
packing pcs.
in kg/100 pcs.
Right
Left
800
M 5
5,5
12,0
63,0
41,0
3,0
25
0,9
BW02.19.05
BW03.19.05
1250
M 6
6,5
14,0
65,0
47,0
4,0
25
1,5
BW02.19.06
BW03.19.06
2000
M 8
8,5
17,0
78,0
57,0
5,0
10
3,1
BW02.19.08
BW03.19.08
3500
M 10
10,5
22,0
90,0
63,0
6,0
10
5,1
BW02.19.10
BW03.19.10
5100
M 12
13,0
25,0
110,0
80,0
8,0
10
10,1
BW02.19.12
BW03.19.12
5900
M 14
13,0
28,0
124,0
90,0
9,0
5
14,1
BW02.19.14
BW03.19.14
BW03.19.16
8000
M 16
14,5
31,0
133,0
100,0
10,0
5
20,4
BW02.19.16
13000
M 20
19,5
40,0
164,0
120,0
15,0
5
40,6
BW02.19.20
BW03.19.20
17000
M 22
23,0
46,0
196,0
140,0
18,0
1
69,0
BW02.19.22X
BW03.19.22X
20000
M 24
26,0
53,0
230,0
170,0
20,0
1
105,0
BW02.19.24X
BW03.19.24X
25500
M 27
28,5
65,0
247,0
180,0
25,0
1
153,0
BW02.19.27X
BW03.19.27X
31000
M 30
33,0
70,0
274,0
200,0
30,0
1
204,0
BW02.19.30X
BW03.19.30X
43000
M 36
36,0
80,0
295,0
220,0
30,0
1
296,0
BW02.19.36X
BW03.19.36X
Note: All break loads are determined by thread
106
107
Chromed Bronze Body Rigging Screws Toggle Stud | Toggle Fork
Chromed Bronze Body Rigging Screws Stud-Fork | Bodies
Rigging Screws Chromed Bronze Body AISI 316 Stainless Steel Highly Polished
Rigging Screws Chromed Bronze body AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
UNF
3,0
1300
1/4”
255
193
8,0
6,35
16,0
6,35
12,7
4,0
1300
1/4”
265
203
8,0
6,35
16,0
7,50
12,8
4,0
2350
5/16”
304
228
10,0
8,00
20,0
7,50
5,0
2350
5/16”
310
234
10,0
8,00
20,0
5,0
3500
3/8”
349
265
12,0
9,50
24,0
6,0
3500
3/8”
364
280
12,0
9,50
6,0
4700
7/16”
397
307
15,0
7,0
4700
7/16”
408
318
15,0
6,0
5400
1/2”
425
319
7,0
5400
1/2”
433
8,0
5400
1/2”
448
8,0
8000
5/8”
10,0
8000
10,0
L1
L2
A
D
B
C
weight
Ref. No.
L1
L2
A
D
B
C
Ref. No.
Breaking
G
Wire in mm
Load in kg
UNF
BW33.03.06A
3,0
1300
1/4”
236
174
9,5
6,35
13,0
6,35
10,7
BW13.03.06A
BW33.04.06A
4,0
1300
1/4”
246
184
9,5
6,35
13,0
7,50
11,0
BW13.04.06A
17,4
BW33.04.08A
4,0
2350
5/16”
280
204
11,0
8,00
15,0
7,50
14,5
BW13.04.08A
9,00
18,5
BW33.05.08A
5,0
2350
5/16”
286
210
11,0
8,00
15,0
9,00
15,5
BW13.05.08A
9,00
28,2
BW33.05.10A
5,0
3500
3/8”
317
233
12,0
9,50
19,0
9,00
23,2
BW13.05.10A
24,0
12,58
32,5
BW33.06.10A
6,0
3500
3/8”
332
248
12,0
9,50
19,0
12,58
26,2
BW13.06.10A
11,00
28,0
12,58
47,5
BW33.06.11AX
6,0
4700
7/16”
365
275
12,0
11,00
23,0
12,58
36,5
BW13.06.11A
11,00
28,0
14,20
47,5
BW33.07.11AX
7,0
4700
7/16”
370
280
12,0
11,00
23,0
14,20
34,5
BW13.07.11A
18,0
12,70
31,0
12,58
74,0
BW33.06.12AX
6,0
5400
1/2”
397
291
14,0
12,70
25,0
12,58
55,0
BW13.06.12A
327
18,0
12,70
31,0
14,20
77,0
BW33.07.12AX
7,0
5400
1/2”
405
299
14,0
12,70
25,0
14,20
55,5
BW13.07.12A
342
18,0
12,70
31,0
16,00
82,0
BW33.08.12AX
8,0
5400
1/2”
420
314
14,5
12,70
25,0
16,60
62,5
BW13.08.12A
536
404
20,0
16,00
37,0
16,00
126,0
BW33.08.16AX
8,0
8000
5/8”
496
364
18,0
16,00
33,0
16,00
109,5
BW13.08.16AX
5/8”
545
413
20,0
16,00
37,0
17,80
135,0
BW33.10.16AX
10,0
8000
5/8”
505
373
18,0
14,00
33,0
17,80
114,0
BW13.10.16A
13000
3/4”
625
465
24,0
19,00
40,0
17,80
190,0
BW33.10.20AX
10,0
13000
3/4”
591
431
24,0
19,00
50,5
17,80
191,0
BW13.10.20A
13000
3/4”
640
480
24,0
19,00
40,0
20,00
200,0
BW33.12.20AX
E
12,0
13000
3/4”
606
446
24,0
19,00
50,5
20,00
194,0
BW13.12.20A
12,0
13000
3/4”
660
500
24,0
19,00
40,0
21,40
200,0
BW33.12.20AXX
12,0
13000
3/4”
626
466
24,0
19,00
50,5
21,40
196,0
BW13.12.20AX
12,0
17000
7/8”
786
592
26,0
22,00
46,0
21,40
309,0
BW33.12.22AX
14,0
17000
7/8”
794
600
26,0
22,00
57,5
25,00
304,0
BW13.14.22A
14,0
17000
7/8”
794
600
26,0
22,00
46,0
25,00
311,0
BW33.14.22AX
16,0
24000
1”
940
700
29,0
25,40
62,0
28,00
445,0
BW13.16.25A
14,0
24000
1”
932
692
29,0
25,40
53,0
25,00
505,0
BW33.14.25AX
16,0
24000
1”
940
700
29,0
25,40
53,0
28,00
512,0
BW33.16.25AX
ø
Wire in mm
12,0
E
PIN
ø
in kg/100 pcs.
E
PIN
weight
in kg/100 pcs.
E
Note: All break loads are determined by clevis pin and thread
E type terminal has unswaged outside diameter 20,0 mm.
Note: All break loads are determined by clevis pin and thread
E type terminal has unswaged outside diameter 20,0 mm.
B
D
C
C
Chromed Bronze Bodies
Rigging Screws Chromed Bronze Body AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
UNF
L1
L2
A1
A2
D
B
PIN
weight
Breaking
G
Load in kg
UNF
1300
1/4”
100
9,0
4,3
BW01.13.06A
2350
5/16”
120
11,0
7,4
BW01.13.08A
3500
3/8”
135
13,0
10,8
BW01.13.10A
4700
7/16”
150
15,0
16,3
BW01.13.11A
5400
1/2”
170
17,4
23,0
BW01.13.12A
8000
5/8”
210
20,7
37,9
BW01.13.16A
13000
3/4”
250
25,4
66,1
BW01.13.20A
17000
7/8”
305
30,0
130,0
BW01.13.22A
24000
1”
366
35,0
190,8
BW01.13.25A
L1
D
weight
Ref. No.
in kg/100 pcs.
Ref. No.
in kg/100 pcs.
1300
1/4”
225
163
8,0
9,5
6,35
16,0
12,8
BW33.00.06A
2350
5/16”
268
192
10,0
11,0
8,00
20,0
20,5
BW33.00.08A
3500
3/8”
313
229
12,0
12,0
9,50
24,0
32,5
BW33.00.10A
4700
7/16”
350
260
15,0
12,0
11,00
28,0
54,0
BW33.00.11AX
5400
1/2”
382
276
18,0
14,0
12,70
31,0
80,0
BW33.00.12AX
8000
5/8”
491
359
20,0
18,0
16,00
37,0
137,0
BW33.00.16AX
13000
3/4”
586
426
24,0
24,0
19,00
40,0
228,0
BW33.00.20AX
17000
7/8”
710
516
26,0
30,0
22,00
46,0
410,0
BW33.00.22AX
24000
1”
835
595
29,0
30,0
25,40
53,0
575,0
BW33.00.25AX
Note: All break loads are determined by thread
Note: All break loads are determined by clevis pin and thread
The Blue Wave Chromed Bronze Body features a number of details that makes it the best choice for
exclusive and durable rigging. The sleek, open Bronze body prevents the threads from seizing up, they
are delivered with laser engraved thread size, Blue Wave logo, and side marking of the left thread.
108
109
Chromed Bronze Body Rigging Screws Stud-Stemball | Threaded Stemballs
F Toggle Forks | Forks
Threaded Toggle Forks AISI 316 Stainless Steel Highly Polished
Rigging Screws Chromed Bronze body AISI 316 Stainless Steel Highly Polished
Breaking
G
Wire in mm
Load in kg
UNF
3,0
1300
1/4”
182
244
5
13
6,35
10,3
BW63.03.06A
4,0
1300
1/4”
192
245
6
13
7,50
10,6
BW63.04.06A
4,0
2350
5/16”
215
305
7
19
7,50
14,6
BW63.04.08A
5,0
2350
5/16”
221
311
7
19
9,00
15,5
BW63.05.08A
5,0
3500
3/8”
240
324
7
19
9,00
21,5
BW63.05.10A
6,0
3500
3/8”
255
339
7
19
12,58
24,6
BW63.06.10A
6,0
4700
7/16”
280
370
7
20
12,58
33,6
BW63.06.11A
7,0
4700
7/16”
285
375
7
20
14,20
36,3
BW63.07.11A
7,0
5400
1/2”
309
415
7
20
14,20
49,6
BW63.07.12A
8,0
5400
1/2”
324
430
7
20
16,00
54,8
BW63.08.12A
8,0
8000
5/8”
367
499
10
25
16,00
88,7
BW63.08.16A
10,0
8000
5/8”
376
508
10
25
17,80
92,9
BW63.10.16A
13000
3/4”
437
597
14
28
20,00
138,8
BW63.12.20A
13000
3/4”
453
613
14
28
21,40
143,8
BW63.12.20AX
ø
12,0
E
12,0
L1
L2
R
D1
D2
weight
Ref. No.
in kg/100 pcs.
Breaking
G
Load in kg
UNF
A
D1
D2
L1
L2
PIN
weight
Ref. No.
in kg/100 pcs.
left
lefthanded
1300
1/4”
8
6,35
14
88
16
4,6
BW03.33.06AB
2350
5/16”
10
8,00
18
105
20
8,3
BW03.33.08AB
3500
3/8”
12
9,50
22
126
24
16,0
BW03.33.10AB
4700
7/16”
15
11,00
30
142
28
25,2
BW03.33.11AXB
5400
1/2”
18
12,70
30
147
31
31,3
BW03.33.12AXB
8000
5/8”
20
16,00
35
199
37
62,9
BW03.33.16AXB
13000
3/4”
24
19,00
40
225
40
110,0
BW03.33.20AXB
17000
7/8”
26
22,00
50
267
46
165,5
BW03.33.22AXB
24000
1”
29
25,40
60
311
53
276,5
BW03.33.25AXB
Note: All break loads are determined by clevis pin and thread
E
7/8” and 1” rigging screws on request.
Note: All break loads are determined by thread
E type terminal has unswaged outside diameter 20,0 mm.
Welded Threaded Forks AISI 316 Stainless Steel Highly Polished
Breaking
G
Load in kg
UNF
1300
1/4”
9,5
6,35
68,0
13,0
2350
5/16”
11,0
8,00
81,0
15,0
3500
3/8”
12,0
9,50
94,0
4700
7/16”
12,0
11,00
5400
1/2”
14,0
12,70
7600
5/8”
18,0
A
weight
Ref. No.
Ref. No.
in kg/100 pcs.
right
left
3,0
BW02.13.06AB
BW03.13.06AB
5,7
BW02.13.08AB
BW03.13.08AB
19,0
8,9
BW02.13.10AB
BW03.13.10AB
104,0
23,0
12,5
BW02.13.11AB
BW03.13.11AB
119,0
25,0
19,0
BW02.13.12AB
BW03.13.12AB
14,00
151,0
33,0
35,9
BW02.13.16AB
BW03.13.16AB
D
L1
L2
PIN
Threaded Stemball for Wire AISI 316 Stainless Steel Highly Polished
G
L1
L2
L3
D1
D2
KW
R
UNF
weight
Ref. No.
in kg/100 pcs.
lefthanded
1/4”
80
50
4,5
13
6,35
5
6
3,9
BWBT01.40.00A
5/16”
92
57
6,5
19
9,00
7
7
4,2
BWBT51.60.00A
3/8”
101
63
5,8
19
9,50
7
7
5,6
BWBT03.80.00A
7/16”
111
70
5,8
20
11,00
9
7
8,0
BWBT71.60.00A
1/2”
129
80
5,8
20
12,70
9
7
12,2
BWBT01.20.00A
5/8”
154
100
8,7
25
16,00
12
10
23,4
BWBT05.80.00A
3/4”
178
120
9,8
28
19,00
15
14
38,4
BWBT03.40.00A
8000
5/8”
18,0
16,00
151,0
33,0
37,0
BW02.13.16AXB
BW03.13.16AXB
13000
3/4”
24,0
19,00
191,0
50,5
72,7
BW02.13.20AB
BW03.13.20AB
17000
7/8”
30,0
22,00
224,5
57,5
124,0
BW02.13.22AB
BW03.13.22AB
24000
1”
30,0
25,40
258,0
62,0
171,0
BW02.13.25AB
BW03.13.25AB
Note: All break loads are determined by clevis pin and thread
7/8” and 1” threaded stemballs on request.
Note: All break loads are determined by clevis pin and thread
110
111
Threaded Eyes
Threaded Eyes | Quick Race Tuning Rigging Screws
Threaded Eyes AISI 316 Stainless Steel Highly Polished
QRT-calibrated Rigging screws
Breaking
G
Load in kg
UNF
weight
Min.
Ref. No.
Wire
Breaking
Thread
in kg/100 pcs.
packing pcs.
left
in mm
Load in kg
inches
1300
1/4”
14
6,5
65
47
4
2350
5/16”
17
8,5
78
57
5
1,5
25
BW03.19.06A
3
1300
5/16”
268
218
11
19
8
16
23,0
BWQRT03.516G2
3,1
25
BW03.19.08A
4
2350
5/16”
271
221
11
19
8
16
23,4
3500
3/8”
22
10,5
89
63
BWQRT04.516
6
5,1
25
BW03.19.10A
5
2350
5/16”
277
227
11
19
8
16
24,2
4700
7/16”
24
11,5
98
BWQRT05.516
70
8
8,9
10
5400
1/2”
25
13,0
BW03.19.11AX
6
4700
7/16”
253
283
11
30
10
31
60,6
BWQRT06.716
110
80
8
10,1
10
BW03.19.12A
7
4700
7/16”
375
305
11
30
10
33
62,7
5400
1/2”
28
BWQRT07.716
13,2
105
80
10
12,0
10
BW03.19.12AX
8000
5/8”
8000
5/8”
31
14,5
134
100
10
20,4
10
BW03.19.16A
36
16,5
141
100
12
25,3
10
13000
BW03.19.16AX
3/4”
40
19,5
164
120
16
47,7
5
BW03.19.20A
17000
7/8”
47
23,0
196
140
18
74,2
1
BW03.19.22AX
24000
1”
52
26,0
230
170
20
108,3
1
BW03.19.25AX
D1
D2
L1
L2
T
L1
L2
A
B
PIN
L4
weight
Ref. No.
in kg/100 pcs.
Size
Note: All break loads are determined by clevis pin and thread
■
■
■
■
The QRT is a top racing rigging screw
Developed specifically for the hardcore racing crews.
It features an adjustment nut in black chromed high quality aluminium bronze
Engraved calibration scale and quick adjust handle for fast and accurate rigtuning.
Note: All break loads are determined by thread
112
113
Mono Race Tuning Calibrated Rigging Screws
Mono Standard Tuning Rigging Screws
Toggle / Stud Terminal Mono Race Tuning - MRT - Calibrated AISI 316 Stainless Steel Highly Polished
Toggle / Stud Terminal Mono Standard Tuning - MST - AISI 316 Stainless Steel Highly Polished
■ A highly sophisticated rigging screw, from the Blue Wave racing line.
■ It features an adjustment nut in black chromed high quality alu bronze
■ Engraved calibration scale for fast and accurate adjustment of the rig tension and an extra length thread terminal.
■ Highly sophisticated rigging screw.
■ A price favourable alternative to the Blue Wave racing line, with all the features except the calibration scale.
■ It features an adjustment nut, in black chromed high quality alu bronze, and an extra length thread terminal.
Breaking
Thread
L
L
Pin
Wire in mm
Load in kg
UNF
min
max
Size
3,0
1300
1/4”
193
233
6,35
8,0
16,0
6,35
11,8
BWMST03.014
4,0
1300
1/4”
216
256
6,35
8,0
16,0
7,50
12,6
BWMST04.014
4,0
2350
5/16”
221
271
8,00
10,0
20,0
7,50
19,7
BWMST04.516
5,0
2350
5/16”
227
277
8,00
10,0
20,0
9,00
20,5
BWMST05.516
5,0
3500
3/8”
263
323
9,50
12,0
24,0
9,00
36,1
BWMST05.038
6,0
4700
7/16”
305
375
11,00
15,0
28,0
12,58
57,5
BWMST06.716
7,0
4700
7/16
305
375
11,00
15,0
28,0
12,58
58,0
BWMST07.716
6,0
5400
1/2”
334
414
12,70
18,0
31,0
12,58
81,7
BWMST06.012
7,0
5400
1/2”
342
422
12,70
18,0
31,0
14,20
82,2
BWMST07.012
BWMRT08.012
8,0
5400
1/2”
356
436
12,70
18,0
31,0
16,00
86,1
BWMST08.012
BWMRT08.058
8,0
8000
5/8”
410
510
16,00
20,0
37,0
16,00
146,9
BWMST08.058
146,4
BWMRT10.058
10,0
8000
5/8”
461
561
16,00
20,0
37,0
17,80
150,5
BWMST10.058
17,80
260,0
BWMRT10.034
10,0
13000
3/4”
478
598
19,00
24,0
40,0
17,80
246,7
BWMST10.034
21,40
273,0
BWMRT12.034
12,0
13000
3/4”
509
629
19,00
24,0
40,0
21,40
277,8
BWMST12.034
47,0
25,00
420,5
BWMRT14.078
14,0
17000
7/8”
568
698
22,00
26,0
46,0
25,00
425,7
BWMST14.078
59,0
28,00
664,0
BWMRT16.110
16,0
24000
1”
660
820
25,40
29,0
53,0
28,00
622,8
BWMST16.110
Breaking
Thread
L
L
Pin
Wire in mm
Load in kg
UNF
min
max
Size
3,0
1300
1/4”
193
233
6,35
8,0
16,0
6,35
11,4
BWMRT03.014
1300
1/4”
216
256
6,35
8,0
16,0
7,50
12,2
BWMRT04.014
4,0
2350
5/16”
221
271
8,00
10,0
20,0
7,50
19,2
BWMRT04.516
5,0
2350
5/16”
227
277
8,00
10,0
20,0
9,00
20,0
BWMRT05.516
3500
3/8”
263
323
9,50
12,0
24,0
9,00
35,1
BWMRT05.038
6,0
4700
7/16”
283
353
11,00
15,0
28,0
12,58
56,3
BWMRT06.716
6,0
5400
1/2”
334
414
12,70
18,0
31,0
12,58
79,9
BWMRT06.012
4700
7/16”
305
375
11,00
15,0
28,0
14,20
60,2
BWMRT07.716
7,0
5400
1/2”
342
422
12,70
18,0
31,0
14,20
80,5
BWMRT07.012
8,0
5400
1/2”
356
436
12,70
18,0
31,0
16,00
84,4
8000
5/8“
410
510
16,00
20,0
40,0
16,00
142,8
10,0
8000
5/8“
461
561
16,00
20,0
40,0
17,80
10,0
13000
3/4“
478
598
19,00
24,0
44,0
13000
3/4“
509
629
19,00
24,0
44,0
17000
7/8“
568
698
22,00
26,0
24000
1“
660
820
25,40
29,0
ø
4,0
5,0
7,0
8,0
12,0
14,0
16,0
A
B
C
weight
Ref. No.
in kg/100 pcs.
Note: All break loads are determined by clevis pin and thread
ø
A
B
C
weight
Ref. No.
in kg/100 pcs.
■ Note: All break loads are determined by clevis pin and thread
■ Stud-Stemball type available on request.
B
A
B
C
A
C
COUPLING NUT BLACK CHROMED ALU- BRONZE
COUPLING NUT BLACK CHROMED ALU- BRONZE
114
115
Long Threaded Terminal
Toggles
Long right handed threaded Terminal AISI 316 Stainless Steel Highly Polished
Double Jaw Toggle AISI 316 Stainless Steel Highly Polished including clevis pins
Breaking
L2
L1
L3
L4
Load in kg
ø
Wire in mm
Breaking
G
Load in kg
UNF
L1
L2
L3
D
KW
weight
Ref. No.
in kg/100 pcs.
right
righthanded
3,0
1300
1/4”
132,0
86,0
38,0
6,4
5,0
2,6
BW05M.03.06A
4,0
1300
1/4”
137,0
81,0
45,0
7,5
6,0
3,0
BW05M.04.06A
4,0
2350
5/16”
147,0
93,0
45,0
7,5
6,0
4,3
BW05M.04.08A
5,0
2350
5/16”
156,0
93,0
51,0
9,0
7,0
5,2
BW05M.05.08A
5,0
3500
3/8”
176,0
115,0
51,0
9,0
7,0
7,7
BW05M.05.10A
6,0
4700
7/16”
206,0
123,0
64,0
12,6
11,0
14,5
BW05M.06.11A
7,0
4700
7/16”
211,0
123,0
70,0
14,2
12,0
16,8
BW05M.07.11A
6,0
5400
1/2”
224,0
149,0
64,0
12,6
11,0
18,7
BW05M.06.12A
7,0
5400
1/2”
232,0
149,0
70,0
14,2
12,0
21,3
BW05M.07.12A
8,0
5400
1/2”
247,0
149,0
84,0
16,0
14,0
25,2
BW05M.08.12A
8,0
8000
5/8”
282,0
184,0
84,0
16,0
14,0
37,4
BW05M.08.16A
10,0
8000
5/8”
292,0
179,0
89,0
17,8
15,0
41,6
BW05M.10.16A
12,0
13000
3/4”
368,0
225,0
120,0
21,4
19,0
72,2
BW05M.12.20A
14,0
17000
7/8”
415,0
255,0
140,0
25,0
22,0
112,0
BW05M.14.22A
16,0
24000
1”
480,0
293,0
160,0
28,0
25,0
164,4
BW05M.16.25A
D1
D2
weight
PIN
PIN
in kg/100 pcs.
Ref. No.
2350
10,0
18,0
5,2
30,0
8,0
8,00
6,0
BW25.00.08
3500
12,0
22,0
6,2
38,0
9,5
9,50
11,9
BW25.00.10
4100
15,0
30,0
9,2
42,0
11,0
11,00
18,0
BW25.00.11
6200
18,0
30,0
11,2
47,5
12,7
12,58
24,0
BW25.00.12
9800
20,0
35,0
13,5
57,0
16,0
16,00
41,0
BW25.00.16
13000
24,0
40,0
17,5
63,0
19,0
19,00
70,0
BW25.00.19
17000
26,0
50,0
19,0
72,0
22,0
22,00
87,0
BW25.00.22
24000
29,0
60,0
22,0
82,0
25,4
25,00
107,0
BW25.00.25
25500
34,0
60,0
28,0
97,0
28,0
28,00
234,0
BW25.00.28
31000
40,0
75,0
34,0
105,0
32,0
32,00
340,0
BW25.00.32
43000
44,0
75,0
34,0
118,0
35,0
35,00
470,0
BW25.00.35
Note: All break loads are determined by clevis pin.
Note: All break loads are determined by thread.
■ The Blue Wave extra long Thread Terminals all features, engraved wire size,
Blue Wave logo and swage depth marking for faster and easier swaging.
■ This extra long thread terminal fits the MRT-MST and QRT Rigging screws
Machined Eye-Jaw Toggle AISI 316 Stainless Steel Highly Polished
Breaking
L1
L2
L3
L4
L5
L6
Load in kg
D1
D2
PIN
weight
Ref. No.
in kg/100 pcs.
1300
28,0
13,0
11,0
6,35
12
5,5
6,35
6,6
1,9
BW14.06.06M
2600
34,5
16,0
13,0
7,90
16
7,0
8,00
8,1
4,3
BW14.08.08M
3500
41,5
19,0
17,0
9,50
19
9,0
9,50
9,7
7,1
BW14.09.09M
4100
48,5
22,0
19,0
11,10
23
9,5
11,00
11,3
12,8
BW14.11.11M
6200
57,0
25,0
24,0
12,70
27
12,5
12,70
12,9
21,1
BW14.13.13M
9800
70,0
32,0
28,0
15,80
33
13,5
16,00
16,3
35,2
BW14.16.16M
13000
89,0
38,0
38,0
19,00
42
18,0
19,00
19,3
74,7
BW14.19.19M
17000
99,0
44,0
41,0
22,20
48
21,0
22,00
22,5
108,2
BW14.22.22M
24000
119,0
51,0
44,0
25,40
53
24,0
25,40
25,8
157,0
BW14.25.25M
Note: All break loads are determined by clevis pin.
116
117
Toggles | Hooks
Locking Nuts
Toggles AISI 316 Stainless Steel Highly Polished including clevis pin
Breaking
A
L
B
Load in kg
Locknuts AISI 316 Stainless Steel
D
weight
PIN
in kg/100 pcs.
Ref. No.
G
NV
H
Metric
Minimum
weight
Ref. No.
Ref. No.
packing
in kg/100 pcs.
Right
Left
1800
25,0
7,5
7,0
6,0
2,3
BW14.00.06
M 5
8
4,0
10
0,10
BW04.12.05
BW05.12.05
3600
30,0
8,5
7,7
8,0
4,0
BW14.00.08
M 6
8
4,0
10
0,10
BW04.12.06
BW05.12.06
4000
40,0
10,5
10,2
9,5
5,9
BW14.00.10
M 8
10
5,0
10
0,15
BW04.12.08
BW05.12.08
4800
45,0
11,5
10,5
11,0
8,5
BW14.00.11
M 10
13
6,5
10
0,25
BW04.12.10
BW05.12.10
5800
50,0
13,5
12,0
12,0
12,4
BW14.00.12
M 12
17
8,0
10
0,70
BW04.12.12
BW05.12.12
8000
55,0
17,0
15,0
16,0
22,5
BW14.00.16
M 14
19
9,5
10
1,30
BW04.12.14
BW05.12.14
13000
60,0
21,0
18,0
19,0
40,7
BW14.00.19
M 16
22
11,0
5
2,00
BW04.12.16
BW05.12.16
17000
100,0
25,0
25,0
22,0
80,9
BW14.00.22
M 20
24
13,0
5
2,25
BW04.12.20
BW05.12.20
M 22
30
16,5
1
3,50
BW04.12.22
BW05.12.22
M 24
36
17,5
1
8,80
BW04.12.24
BW05.12.24
M 27
41
22,0
1
16,00
BW04.12.27
BW05.12.27
M 30
46
24,0
1
17,00
BW04.12.30
BW05.12.30
M 36
55
29,0
1
39,00
BW04.12.36
BW05.12.36
Minimum
weight
Ref. No.
Ref. No.
packing
in kg/100 pcs.
Right
Left
Note: All break loads are determined by clevis pin.
Toggles AISI 316 Stainless Steel Highly Polished including clevis pin
Breaking
B
A
D1
D2
Load in kg
L
weight
PIN
Ref. No.
in kg/100 pcs.
1300
7,5
5
5,5
5,0
26
1,8
BW14.05.06
1800
9,5
6
6,5
6,0
32
3,0
BW14.06.08
3200
11,0
8
8,5
8,0
36
5,5
BW14.08.10
3500
12,5
9
10,0
9,5
45
7,2
BW14.10.11
5200
12,0
9
11,5
11,0
51
12,1
BW14.11.11
5900
14,0
10
13,0
12,0
59
14,5
BW14.12.14
7500
22,0
14
14,5
14,0
78
28,0
BW14.16.16
Note: All break loads are determined by clevis pin.
Locknuts AISI 316 Stainless Steel
Pelican-Hooks AISI 316 Stainless Steel Highly Polished
A
B
C
ø
ø1
D
G
E
F
B2
weight
Ref. No.
in kg/100 pcs.
H
1/4”
8
4,0
10
0,10
BW04.12.06A
BW05.12.06A
5/16”
10
5,0
10
0,15
BW04.12.08A
BW05.12.08A
82
115
140
6
5,3
30
5
40
7,0
4,62
✸ BW45.05.06
3/8”
13
6,5
10
0,25
BW04.12.10A
BW05.12.10A
75
125
142
6
6,4
20
5
35
9,2
4,84
✸ BW45.06.06
8,4
10
0,70
127
142
6
6,8
20
5
35
6,5
11,44
7/16”
14
82
❍ BW45.06.08
BW04.12.11A
BW05.12.11A
1/2”
17
8,0
10
1,20
BW04.12.12A
BW05.12.12A
113
163
192
8
8,7
27
5
42
11,2
12,65
✸ BW45.08.08
5/8”
22
11,0
5
2,00
BW04.12.16A
BW05.12.16A
113
163
192
8
8,5
27
5
42
7,5
19,00
❍ BW45.08.10
13,0
5
2,25
195
235
12
13,4
34
6
54
15,3
52,00
3/4”
24
130
✸ BW45.12.12
BW04.12.20A
BW05.12.20A
30
16,5
1
3,40
140
204
235
12
13,2
34
6
54
15,3
77,00
7/8”
❍ BW45.14.16
BW04.12.22A
BW05.12.22A
1”
36
17,5
1
8,80
BW04.12.25A
BW05.12.25A
✸ = Standard size
1 1/8”
41
22,0
1
16,00
BW04.12.27A
BW05.12.27A
❍ = Special size
1 1/4”
46
24,0
1
17,00
BW04.12.30A
BW05.12.30A
1 3/8”
55
29,0
1
39,00
BW04.12.36A
BW05.12.36A
B2 = eye thickness
B2
118
NV
UNF
For full breaking load on the threaded stud use no locknuts but DIN nuts (full nuts).
119
Clevis Pins
Smart Pins | Splitrings | Splitpins
Smart Pins AISI 316 Stainless Steel
Clevis Pins AISI 316 Stainless Steel
L
Split Pin on Velcro One-Wrap® Strap
D
Minimum
weight
packing
in kg/100 pcs.
Ref. No.
■ The smart pins are a fast and revolutionary new way of securing open body rigging screws.
■ Simply put the pin attached to the Velcro Strap into the split hole and secure the Velcro strap around the rigging screw.
15
5,00
10
0,30
BW06.16.05
Pin
17
6,00
10
0,90
BW06.18.06
Size
16
6,35
10
0,90
BW06.16.63
2,0
150
16
18
8,00
10
1,00
BW06.19.08
2,5
190
16
21
8,00
10
1,10
BW06.20.08
3,2
260
20
23
9,50
10
1,50
BW06.23.95
4,0
370
25
26
11,00
10
2,40
BW06.26.11
28
12,00
10
3,00
BW06.28.12
28
12,70
10
3,50
BW06.28.13
34
12,00
10
4,00
BW06.34.12
33
14,00
10
5,30
BW06.32.14
37
14,00
10
5,50
BW06.37.14
34
16,0
1
6,50
BW06.34.16
40
16,0
1
7,70
BW06.40.16
45
19,0
1
13,00
BW06.44.19
49
19,0
1
14,00
BW06.49.19
46
22,0
1
16,30
BW06.46.22
55
22,0
1
19,00
BW06.55.22
58
22,0
1
20,00
BW06.58.22
56
25,4
1
25,00
BW06.55.25
63
25,0
1
28,00
BW06.63.25
73
28,0
1
40,00
83
32,0
1
88
35,0
1
L
B
H
For
Minimum
weight
Rigging Screws
packing
in kg/100 pcs.
8
1/4
20
0,2
BWVP10.20
BWVP10.20P4
10
5/16 - 3/8
20
0,3
BWVP12.25
BWVP12.25P4
13
7/16 - 1/2
20
0,5
BWVP16.32
BWVP16.32P4
20
5/8 - 3/4
20
1,0
BWVP23.40
BWVP23.40P4
Ref. No.
Ref. No.
Blisterpacking
■ Also available in blisterpacking 4 in each pack.
■ Also available blisterpacking shop display (Ref. No. BWDISPSMART)
Splitrings AISI 316 Stainless Steel
Diameter
D
mm
Minimum
weight
packing
in kg/100 pcs.
Ref. No.
1,00
11
100
0,015
BW07.06.01
1,25
15
100
0,075
BW07.06.02
BW06.73.28
1,50
19
100
0,100
BW07.06.03
60,00
BW06.83.32
2,00
23
100
0,230
BW07.06.04
76,00
BW06.88.35
L
Minimum
weight
Ref. No.
packing
in kg/100 pcs.
Splitpins AISI 316 Stainless Steel
D
Diameter mm
120
1,5
10
100
0,01
BW07.06.09
2,0
12
100
0,03
BW07.06.101
2,0
15
100
0,03
BW07.06.10
2,0
25
100
0,05
BW07.06.11
2,5
16
100
0,07
BW07.06.121
2,5
25
100
0,10
BW07.06.12
3,0
25
50
0,15
BW07.06.13
3,0
32
50
0,20
BW07.06.14
3,2
20
50
0,15
BW07.06.131
4,0
32
1
0,36
BW07.06.151
5,0
40
1
0,75
BW07.06.17
6,3
50
1
1,30
BW07.06.18
121
High quality Marine and rigging components
122
123
Stainless Steel Forged Swage Eye-Terminals
Stainless Steel Machined Swage Eye-Terminals
Swage Terminals - Forged Eyes High Quality Stainless Steel Grade 316
Swage Terminals - Machined Eyes High Quality Stainless Steel Grade 316
weight
Product Code
ø
Breaking
Wire in mm
Load in kN
PS04.01.03
4
17,6
8,3
7,5
45
20
6,5
16
69
PS04.01.04
5
25,6
9,7
9,1
52
26
7,8
19
82
FSE05
PS04.01.05
6
56,6
11,3
12,5
64
31
9,5
25
82
FSE06
PS04.01.06
6
56,6
12,8
12,5
64
35
9,5
120
FSE07
PS04.01.07
7
72,7
12,8
14,3
70
35
11,5
FSE08DS
PS04.01.08DS
8
72,7
12,8
16,0
80
36
FSE08
PS04.01.08
8
92,6
14,3
16,0
80
FSE08US
PS04.01.08US
8
92,6
16,2
16,0
80
FSE10
PS04.01.10
10
101,5
16,2
18,0
442
FSE12
PS04.01.12
12
126,0
19,3
708
FSE14
PS04.01.14
14
174,0
22,3
1005
FSE16
PS04.01.16
16
218,0
19
22
26
ø
Breaking
wire in mm
Load in kN
3
13,3
6,3
6,3
39
18
6,0
14,3
60
12
FSE03
4
17,6
8,3
7,5
45
23
7,0
18,0
72
24
FSE04
5
25,6
9,7
9,1
52
27
8,0
21,0
84
36
6
56,3
11,3
12,5
64
32
9,5
25,0
102
7
72,7
12,8
14,3
70
36
11,0
28,0
113
8
72,7
12,8
16,0
80
36
11,0
28,0
125
120
8
72,7
14,3
16,0
80
40
14,0
32,0
128
170
8
92,6
16,2
16,0
80
45
15,0
34,0
136
195
10
101,5
16,2
18,0
100
45
15,0
34,0
155
234
12
146,2
19,3
21,4
132
53
18,0
42,0
197
14
201,9
22,3
25,0
156
62
22,0
48,0
232
16
218,0
25,5
28,0
176
70
24,0
58,0
262
H
D
B
F
T
OD
L
Ref. No.
in gr
■ All HI-MOD Terminals: Free from structual welds which may reduce the strength and integrity of the product.
■ Electrical Upset forging engenders no kinks or interruption of grain flow thus providing a stronger, high integrity product.
28
■ All HI-MOD Terminals above 10 mm wire rope are highgloss hand polished.
30
32
OD
weight
Product Code
Ref. No.
23
MSE04
PS04.02.04
42
MSE05
PS04.02.05
99
100
MSE06
PS04.02.06
27
110
109
MSE06US
PS04.02.06.US
27
113
129
MSE07
PS04.02.07
11,0
27
123
152
MSE08DS
PS04.02.08DS
40
14,0
32
128
178
MSE08
PS04.02.08
43
14,0
34
128
202
MSE08US
PS04.02.08US
100
45
15,0
34
155
245
MSE10
PS04.02.10
21,4
132
53
18,0
38
197
462
MSE12
PS04.02.12
25,0
156
62
22,0
51
232
721
MSE14
PS04.02.14
25,5
28,2
176
70
24,0
54
262
1090
MSE16
PS04.02.16
341,0
28,6
34,5
210
76
28,0
58
302
1780
MSE19
PS04.02.19
459,8
32,5
40,3
242
86
32,0
71
347
2704
MSE22
PS04.02.22
564,8
35,5
45,9
290
97
34,0
75
408
3955
MSE26
PS04.02.26
45,4
50,0
310
124
42,0
-
464
5768
MSE28
PS04.02.28
-
-
-
-
-
-
-
-
MSE30
PS04.02.30
51,0
-
335
141
50,0
-
507
8720
MSE32
PS04.02.32
-
H
D
B
F
T
L
in gr
■ Exceeds the stated breaking load of relative standard and Compacted Stainless Steel wire.
■ Very high quality finish suitable for prestigous yachts and architectural projects.
■ All HI-MOD Terminals above 10 mm wire rope are highgloss hand polished.
■ Bigger sizes on request.
124
125
Stainless Steel Swage Fork-Terminals
Stainless Steel Swage Strap Toggle Terminals
Swage Terminals - Machined Solid Fork incl. clevis pin High Quality Stainless Steel Grade 316
ø
P
D
F
C
T
B
OD
L
weight
wire in mm
Swage Terminals - Strap Toggle Including Clevis Pin
High Quality Stainless Steel Grade 316
Product Code
Ref. No.
ø
in gr
P
D
F
C
T
B
L
PL
weight
Product Code
Ref. No.
in gr
wire in mm
3
6,0
6,3
7,0
13
6,3
39
14,3
70,0
20
SF03
PS03.01.03
4
8,0
7,5
9,0
16
8,0
45
18,0
83,0
36
SF04
PS03.01.04
3
6,0
6,3
8
16,0
7,7
39
84
19
25
MST03
PS03.04.03
22,2
97,0
64
SF05
PS03.01.05
4
8,0
7,5
12
16,5
9,0
45
103
22
45
MST04
PS03.04.04
5
9,5
9,1
13
20,4
10,3
52
111
25
89
MST05
PS03.04.05
PS03.04.06
5
9,5
9,1
11,0
19
10,0
52
PS03.01.06
6
11,0
12,5
12,0
22
11,0
64
25,4
113,0
142
7
12,0
14,3
15,0
25
12,7
70
28,6
128,0
172
SF07
PS03.01.07
6
11,0
12,5
17
28,0
14,0
64
146
32
230
MST06
8
12,0
16,0
15,0
25
12,7
80
28,6
140,0
196
SF08DS
PS03.01.08DS
7
12,0
14,3
19
30,3
14,2
70
168
34
271
MST07
PS03.04.07
8
12,0
16,0
25
30,3
14,2
80
169
42
295
MST08DS
PS03.04.58DS
SF06
8
14,0
16,0
16,5
28
14,0
80
34,9
144,5
278
SF08
PS03.01.08
10
16,0
18,0
18,0
32
16,0
100
38,1
174,0
376
SF10
PS03.01.10
8
16,0
16,0
25
39,4
17,5
80
200
42
515
MST08
PS03.04.68
12
19,0
21,4
23,0
38
19,0
132
47,6
227,0
1097
SF12
PS03.01.12
10
16,0
18,0
25
39,4
17,5
100
212
42
569
MST10
PS03.04.10
12
19,0
21,4
25
55,0
22,0
132
278
51
1409
MST12
PS03.04.12
14
22,0
25,0
26,0
45
22,2
156
54,0
258,0
1105
SF14
PS03.01.14
16
25,4
28,2
30,6
50
25,4
176
63,5
295,5
1683
SF16
PS03.01.16
14
22,0
25,0
30
60,0
24,0
156
328
62
1912
MST14
PS03.04.14
19
28,0
34,5
33,0
58
28,6
210
69,9
342,0
2580
SF19
PS03.01.19
16
25,4
28,2
30
68,0
28,0
176
364
65
2516
MST16
PS03.04.16
19
28,0
34,5
38
80,0
30,0
210
430
73
4147
MST19
PS03.04.19
3611
SF22
PS03.01.22
451,5
5019
SF26
PS03.01.26
22
32,0
40,3
50
85,0
34,0
242
496
77
6039
MST22
PS03.04.22
514,0
10500
SF28
PS03.01.28
26
35,0
45,9
50
105,0
38,0
290
571
82
8428
MST26
PS03.04.26
-
-
SF30
PS03.01.30
600,0
27450
SF32
PS03.01.32
22
32,0
40,3
39,0
64
32,0
242
76,2
391,0
26
35,0
45,9
43,5
70
35,0
290
82,5
28
45,0
50,0
52,0
91
45,0
305
-
30
-
-
-
-
-
-
-
32
50,0
-
67,0
104
52,0
335
-
■
■
■
■
Exceeds the stated breaking load of relative standard and Compacted Stainless Steel wire.
Manufactured from Solid Bar.
Breaking load same as MSE type.
All HI-MOD Terminals above 10 mm wire rope are highgloss hand polished.
■
■
■
Generously proportioned toggle straps designed to take the full wire breaking load on each side
of the T, avoiding premature failure due to transient unbalanced loads.
Swage section manufactured from solid bar.
Breaking load same as MSE type.
All HI-MOD Terminals above 10 mm wire rope are highgloss hand polished.
■ Bigger sizes on request.
126
127
Stainless Steel Forged Stemball Terminals
Stainless Steel Swage Shackle Toggle Terminals
Swage Terminals Forged Stemballs High Quality Stainless Steel Grade 316
ø
D
B
SD
CD
W
R
Swage Shackle Toggles High Quality Stainless Steel Grade 316
weight
Product Code
Ref. No.
in gr
wire in mm
ø
B
D
L
S
J
P
SB
SL
weight
Product Code
Ref. No.
in gr
wire in mm
3
12,5
39
6,3
7,5
3,4
6,3
11
SB03-065
PS05.01.03
4
17,0
45
7,5
8,5
4,4
8,8
25
SB04-090
PS05.01.04
3
39
6,3
82
3
14
6,0
5,0
14
25
SST03
PS03.03.03
5
17,0
52
9,1
10,0
5,4
8,8
29
SB05-090
PS05.01.05
4
45
7,5
101
4
20
8,0
6,0
16
48
SST04
PS03.03.04
5
52
9,1
118
4
22
9,5
8,0
22
89
SST05
PS03.03.05
43
SB05-110
PS05.01.051
10,8
74
SB06-110
PS05.01.06
6
64
12,7
141
5
25
11,0
9,5
27
179
SST06
PS03.03.06
10,8
102
SB07-110
PS05.01.07
7
70
14,3
158
5
27
12,0
11,0
32
273
SST07
PS03.03.07
8
80
16,0
179
5
29
14,3
12,7
36
407
SST08
PS03.03.08
5
21,0
52
9,1
10,0
5,4
10,8
6
21,0
64
12,5
13,5
6,5
7
21,0
70
14,3
15,0
7,5
7
27,0
70
14,3
15,0
7,5
13,8
119
SB07-140
PS05.01.071
8
27,0
80
16,0
18,5
8,5
13,8
155
SB08-140
PS05.01.08
10
100
18,0
216
6
29
16,0
14,3
42
684
SST10
PS03.03.10
10
31,0
100
18,0
19,5
10,6
15,8
215
SB10-160
PS05.01.10
12
132
21,4
263
6
32
19,0
16,0
45
1027
SST12
PS03.03.12
12
35,0
132
21,4
23,0
12,8
17,8
374
SB12-180
PS05.01.12
14
156
25,0
309
8
38
22,2
19,0
63
1508
SST14
PS03.03.14
16
176
28,2
351
8
45
25,4
22,0
63
2525
SST16
PS03.03.16
■ MULTI-PIVOT action.
■ IDEAL for life lines & aluminium chain plates.
■ INCORPORATES upset forged shackles with socket head pin for extra strength and integrity.
■ Inspection certificate BS EN 10204 3.1B available on request.
This must be specified at the time of order.
■ Breaking load same as MSE types.
■ All HI-MOD Terminals above 10 mm wire rope are highgloss hand polished.
Stainless Steel Forged Shroud Terminals
Swage Forged Shroud Terminals High Quality Stainless Steel Grade 316
ø
T
B
W
HW
SD
weight
Product Code
Ref. No.
in gr
wire in mm
3
6,3
39
3,4
12
6,3
21
SH03
PS07.01.03
4
7,5
45
4,4
16
7,5
29
SH04
PS07.01.04
5
9,1
52
5,4
19
9,1
60
SH05
PS07.01.05
6
12,5
64
6,5
22
12,5
124
SH06
PS07.01.06
7
14,3
70
7,5
28
14,3
190
SH07
PS07.01.07
8
16,0
80
8,5
30
16,0
278
SH08
PS07.01.08
10
17,8
100
10,6
32
18,0
360
SH10
PS07.01.10
12
21,4
132
12,8
38
21,4
654
SH12
PS07.01.12
■ Fits in following backing plates:
- GIBB - Type 840 and 740 - Blue Wave
- Hasselfors - (Selden)
- BSI
128
129
Stainless Steel Swage Stud Terminals
Stainless Steel Swage Stud Terminals
Swage Terminals - Open Body Studs UNF THREAD
High Quality Stainless Steel AISI 316
Swage Terminals - Closed Body Studs UNF THREAD
High Quality Stainless Steel Grade 316
Thread
ø
UNF
wire in mm
1/4”
3
6,3
39
47
5
97
24
D
B
T
A/F
L
weight
Thread
ø
UNF
wire in mm
B
T
_A/F
L
weight
Product Code
Ref. No.
Ref. No.
1/4”
3
6,3
39
42
5
97
24
SO1/4X3R
PS06.02.13R
SC1/4X3R
PS06.01.13R
1/4”
4
7,5
45
42
5
104
30
SO1/4X4R
PSS0.1/4X4R
5/16”
4
7,5
45
49
6
113
36
SO5/16X4R
PS06.02.24R
PSS0.5/16X5R
in gr
in gr
1/4”
4
7,5
45
47
5
104
30
SC1/4X4R
PSSC1/4X4R
5/16”
4
7,5
45
54
6
113
36
SC5/16X4R
PS06.01.24R
5/16”
5
9,1
52
49
6
123
51
SO5/16X5R
5/16”
5
9,1
52
54
6
123
51
SC5/16X5R
PSSC5/16X5R
3/8”
5
9,1
52
63
8
135
60
SO3/8X5R
PS06.02.35R
3/8”
5
9,1
52
68
8
135
60
SC3/8X5R
PS06.01.35R
3/8”
6
12,5
64
63
8
149
85
SO3/8X6R
PSS0.3/8X6R
3/8”
6
12,5
64
68
8
149
85
SC3/8X6R
PSSC3/8X6R
7/16”
6
12,5
64
68
11
154
108
SO7/16X6R
PS06.02.46R
7/16”
6
12,5
64
75
11
154
108
SC7/16X6R
PS06.01.46R
7/16”
7
14,3
70
68
11
161
130
SO7/16X7R
PSS0.7/16X7R
7/16”
7
14,3
70
75
11
161
130
SC7/16X7R
PSSC7/16X7R
1/2”
7
14,3
70
83
12
177
162
SO1/2X7R
PS06.02.57R
1/2”
7
14,3
70
90
12
177
162
SC1/2X7R
PS06.01.57R
1/2”
8
16,0
80
83
14
190
196
SO1/2X8R
PS06.02.58R
1/2”
8
16,0
80
90
14
190
196
SC1/2X8R
PSSC1/2X8R
5/8”
8
16,0
80
93
14
201
260
SO5/8X8R
PS06.02.68R
5/8”
8
16,0
80
100
14
201
260
SC5/8X8R
PS06.01.68R
5/8”
10
18,0
100
93
16
223
306
SO5/8X10R
PS06.02.60R
5/8”
10
18,0
100
100
16
223
306
SC5/8X10R
PS06.01.60R
3/4”
12
21,4
132
111
19
277
550
SO3/4X12R
PS06.02.12R
3/4”
12
21,4
132
120
19
277
550
SC3/4X12R
PS06.01.12R
7/8”
14
25,0
156
130
22
325
874
SO7/8X14R
PS06.02.14R
7/8”
14
25,0
156
140
22
325
874
SC7/8X14R
PS06.01.14R
1”
16
28,2
176
150
25
369
1275
SO1X16R
PS06.02.16R
1”
16
28,2
176
160
25
369
1274
SC1X16R
PS06.01.16R
11/8”
19
34,5
210
168
28
425
2050
SO11/8X19R
PS06.02.19R
1 1/8”
19
34,5
210
180
28
425
2050
SC11/8X19R
PS06.01.19R
11/4”
22
40,3
242
188
32
482
3200
SO11/4X22R
PS06.02.22R
1 1/4”
22
40,3
242
200
32
482
3200
SC11/4X22R
PS06.01.22R
13/8”
26
45,9
290
208
36
557
4000
SO13/8X26R
PS06.02.26R
1 3/8”
26
45,9
290
220
36
557
4000
SC13/8X26R
PS06.01.26R
1 1/2”
28
50,0
297
235
44
580
6992
SC11/2X28R
PS06.01.28R
■ Bigger sizes on request.
■ Replace R for L by Ref. No. for left handed thread.
■ Breaking loads same as Fork - Fork Turnbuckles.
■ Replace R for L by Ref. No. for left handed thread.
■ All HI-MOD Terminals above 10 mm wire rope are highgloss
hand polished.
■ Breaking loads same as Fork - Fork Rigging Screws.
■ All HI-MOD Terminals above 10 mm wire rope are
highgloss hand polished.
Randmeer
130
D
Product Code
Design: vd Stadt en Partners
131
Stainless Steel Swage Stud Terminals
Stainless Steel AISI 316 Swageless Compression Terminals
Swage Closed Body Studs METRIC THREAD
High Quality Stainless Steel Grade 316
Compression Eyes
ø
ø
TH
D
B
L
CT
A/F
wire in mm
weight
Product Code
Ref. No.
P
F
C
L
T
A/F
wire size
weight
Product Code
Ref. No.
in gr
in gr
3
M6
6,3
39
97
47
5
24
SCM6X3
PSSC.M63
4
M6
7,5
45
105
47
6
33
SCM6X4
PSSC.M64
4
M8
7,5
45
113
54
6
36
SCM8X4
PSSC.M84
5
M8
9,1
52
122
54
8
54
SCM8X5
PSSC.M85
5
M10
9,1
52
135
68
8
60
SCM10X5
PSSC.M105
6
M10
12,5
64
154
75
11
108
SCM10X6
PSSC.M106
6
M12
12,5
64
170
90
11
119
SCM12X6
PSSC.M126
7
M12
14,3
70
177
90
12
162
SCM12X7
PSSC.M127
8
M12
16,0
80
190
90
14
196
SCM12X8
PSSC.M128
8
M16
16,0
80
201
100
14
260
SCM16X8
PSSC.M168
10
M16
18,0
100
223
100
16
306
SCM16X10
PSSC.M1610
12
M20
21,4
132
277
120
19
550
SCM20X12
PSSC.M2012
14
M22
25,0
156
325
140
22
874
SCM22X14
PSSC.M2214
16
M27
28,2
176
371
160
25
1275
SCM27X16
PSSC.M2716
19
M30
34,5
210
425
180
28
2050
SCM30X19
PSSC.M3019
22
M36
40,3
242
482
200
32
3200
SCM36X22
PSSC.M3622
26
M42
45,9
290
557
220
36
4000
SCM42X26
PSSC.M4226
■ Bigger sizes on request.
■ Suffix L on Ref no. for left handed thread
■ All HI-MOD Terminals above 10 mm wire rope
are highgloss hand polished.
3
6,3
7
9
22
6,0
9,5
21
CTE03
PS.CTE.03
4
8,0
9
12
28
7,0
11,0
39
CTE04
PS.CTE.04
5
9,5
11
16
32
8,0
14,0
65
CTE05
PS.CTE.05
6
11,0
13
19
38
9,5
17,0
126
CTE06
PS.CTE.06
6
12,7
13
20
43
11,0
17,0
140
CTE06US
PS.CTE.06US
7
12,7
13
20
45
11,0
20,0
165
CTE07
PS.CTE.07
8
12,7
13
20
48
11,0
22,0
235
CTE08DS
PS.CTE.08.DS
8
14,3
16
23
52
13,0
22,0
355
CTE08
PS.CTE.08
8
16,0
19
28
56
15,0
22,0
390
CTE08US
PS.CTE.08.US
10
16,0
19
28
59
15,0
26,0
462
CTE10
PS.CTE.10
10
19,0
22
34
65
18,0
26,0
600
CTE10US
PSCTE10US
12
19,0
22
34
79
18,0
32,0
912
CTE12
PS.CTE.12
14
22,2
26
36
86
22,0
36,0
1344
CTE14
PS.CTE.14
16
25,4
29
41
94
24,0
40,0
1867
CTE16
PS.CTE.16
19
28,6
32
44
98
28,0
44,0
2227
CTE19
PS.CTE.19
22
32,0
36
50
108
32,0
52,0
3440
CTE22
PS.CTE.22
26
35,0
42
55
144
34,0
64,0
5575
CTE26
PS.CTE.26
■ The last development for compression fittings in a termination at least as strong as the rated
breaking loads of the wire rope. The unique star shaped Crown Ring positions and holds the wire
strands in place, eliminating the requirement for awkward wire end bending.
The shallow angled cone establishes direct mechanical grip on the core and all outer strands.
Stainless steel grade EN 10088 1.4404 (316) is used on all parts with the exception of the crown
ring which is manufactured from Aluminium Bronze. No sealant or packing is required.
■
The part codes in the tables are for 1x19 wire rope construction.
Different Cones and Crown Rings are used for 7 strand, Compacted Strand (1 x 19 and 1 x 25)
C Compacted Strand (1 x 36) CS
Add suffix -7, -C or -CS for these assemblies after ref. no.
■ Spare Cones and Crown Rings available.
■ All HI-MOD Swageless Terminals are highgloss hand polished.
132
133
Stainless Steel AISI 316 Swageless Compression Terminals
Stainless Steel AISI 316 Swageless Compression Terminals
Compression Forks
ø
Compression Studs UNF Thread
P
F
C
T
L
wire size
A/F
weight
B
in gr
Product Code
Ref. No.
ø
TH
T
L
wire size
A/F
A/F
weight
S
B
in gr
Product Code
Ref. No.
3
6,0
7,0
13
6,3
30
9,5
29
CTF03
PS.CTF.03
3
1/4”
47
67
6
9,5
24
CTS03
PS.CTS.03
4
8,0
9,0
16
8,0
40
11,0
60
CTF04
PS.CTF.04
4
1/4”
47
67
8
11,0
35
CTS04DS
PS.CTS.04DS
5
9,5
11,0
19
10,0
47
14,0
103
CTF05
PS.CTF.05
4
5/16”
54
76
8
11,0
42
CTS04
PS.CTS.04
PS.CTS.05DS
6
11,0
12,0
22
11,0
50
19,0
159
CTF06
PS.CTF.06
5
5/16”
54
80
9
14,0
65
CTS05DS
7
12,0
15,0
25
12,7
58
20,0
239
CTF07
PS.CTF.07
5
3/8”
68
89
9
14,0
75
CTS05
PS.CTS.05
8
12,0
15,0
25
12,7
63
22,0
323
CTF08DS
PS.CTF.08.DS
6
3/8”
68
95
11
17,0
110
CTS06DS
PS.CTS.06DS
8
14,0
16,5
28
14,0
70
22,0
395
CTF08
PS.CTF.08
6
7/16”
75
99
11
17,0
130
CTS06
PS.CTS.06
8
16,0
18,0
32
16,0
72
22,0
490
CTF08US
PS.CTF.08.US
6
1/2”
90
117
11
17,0
145
CTS06US
PS.CTS.06US
10
16,0
18,0
32
16,0
78
26,0
542
CTF10
PS.CTF.10
7
1/2”
90
119
14
20,0
199
CTS07
PS.CTS.07
12
19,0
23,0
38
19,0
93
32,0
918
CTF12
PS.CTF.12
8
1/2”
90
125
16
22,0
297
CTS08DS
PS.CTS.08DS
14
22,0
26,0
45
22,2
106
36,0
1464
CTF14
PS.CTF.14
8
5/8”
100
135
16
22,0
347
CTS08
PS.CTS.08
16
25,4
30,5
50
25,4
126
40,0
2125
CTF16
PS.CTF.16
10
5/8”
100
140
17
26,0
458
CTS10
PS.CTS.10
19
28,0
33,0
58
28,6
133
44,0
2616
CTF19
PS.CTF.19
10
3/4”
120
158
19
26,0
790
CTS10US
PS.CTS.10US
22
32,0
39,0
64
32,0
146
52,0
3890
CTF22
PS.CTF.22
12
3/4”
120
169
22
32,0
892
CTS12
PS.CTS.12
26
35,0
43,5
70
35,0
167
64,0
6393
CTF26
PS.CTF.26
14
7/8”
140
195
24
36,0
1379
CTS14
PS.CTS.14
16
1”
160
227
28
40,0
1970
CTS16
PS.CTS.16
19
1 1/8”
180
245
32
44,0
2699
CTS19
PS.CTS.19
22
1 1/4”
200
270
36
52,0
4240
CTS22
PS.CTS.22
26
1 3/8”
220
311
44
64,0
6675
CTS26
PS.CTS.26
3
M6
47
63
6
9,5
24
CTSM6X03
PS.CTSM.06.03
4
M6
47
68
8
11,0
35
CTSM6X04
PS.CTSM.06.04
4
M8
54
74
8
11,0
42
CTSM8X04
PS.CTSM.08.04
5
M8
54
80
9
14,0
65
CTSM8X05
PS.CTSM.08.05
5
M 10
68
90
9
14,0
75
CTSM10X05
PS.CTSM.10.05
6
M 10
68
95
11
17,0
110
CTSM10X06
PS.CTSM.10.06
6
M 12
90
117
11
17,0
145
CTSM12X06
PS.CTSM.12.06
7
M 12
90
123
14
20,0
199
CTSM12X07
PS.CTSM.12.07
8
M 12
90
129
16
22,0
297
CTSM12X08
PS.CTSM.12.08
■ The part codes in the tables are for 1x19 wire rope construction. Different Cones and Crown Rings are used for 7 strand, Compacted Strand (1x19 and 1x25) C, Compacted Strand (1x36) CS. Add suffix -7, -C or -CS for these assemblies after ref. no
■ All HI-MOD Swageless Terminals are highgloss hand
polished.
Metric Thread
Compression Toggleforks
ø
P
F
C
T
L
A/F
wire size
weight
Product Code
Ref. No.
in gr
3
6,0
8,0
16
7,5
45
9,5
37
CTT03
PS.CTT.03
8
M 16
100
134
16
22,0
340
CTSM16X08
PS.CTSM.16.08
4
8,0
9,5
20
9,0
53
11,0
71
CTT04
PS.CTT.04
10
M 16
100
139
17
26,0
453
CTSM16X10
PS.CTSM.16.10
5
9,5
12,0
25
10,0
64
14,0
125
CTT05
PS.CTT.05
10
M 20
120
158
19
26,0
800
CTSM20X10
PS.CTSM.20.10
6
11,0
17,0
26
14,0
78
19,0
258
CTT06
PS.CTT.06
7
12,0
14,8
29
14,2
89
20,0
327
CTT07
PS.CTT.07
8
12,0
14,8
29
14,2
92
22,0
397
CTT08DS
PS.CTT.08.DS
8
16,0
25,0
40
19,0
116
22,0
700
CTT08US
PS.CTT.08.US
10
16,0
19,0
34
17,5
116
26,0
800
CTT10
PS.CTT.10
12
19,0
25,0
54
22,0
157
32,0
1242
CTT12
PS.CTT.12
14
22,0
30,0
60
24,0
174
36,0
2302
CTT14
PS.CTT.14
16
25,4
32,0
70
28,0
194
40,0
3037
CTT16
PS.CTT.16
19
28,0
38,0
80
30,0
215
44,0
4280
CTT19
PS.CTT.19
22
32,0
50,0
85
34,0
235
52,0
6518
CTT22
PS.CTT.22
26
35,0
50,0
105
38,0
296
64,0
9591
CTT26
PS.CTT.26
■
■
■
■
■
Available up to 26 mm wire on request
Compression studs have right handed thread.
Left handed thread available (add Ref. No. with L)
The part codes in the tables are for 1x19 wire rope construction. Different Cones and Crown Rings are used for 7 strand, Compacted Strand (1x19 and 1x25) C, Compacted Strand (1x36) CS. Add suffix -7, -C or -CS for these assemblies after ref. no.
All HI-MOD Swageless Terminals are highgloss hand polished.
■ The part codes in the tables are for 1x19 wire rope construction. Different Cones and Crown Rings are used for 7 strand, Compacted Strand (1x19 and 1x25) C, Compacted Strand (1x36) CS. Add suffix -7, -C or -CS for these assemblies after
ref. no.
134
135
Stainless Steel Rigging Screws
Stainless Steel Rigging Screws
Rigging Screws - Fork / Fork Including Clevis Pins High Quality Stainless Steel Grade 316
Thread
Breaking
P
Size
Load in kN
PIN
F
C
T
OD
Min
Max
weight
L
L
in gr
Rigging Screws - Fork / Eye Including Clevis Pin High Quality Stainless Steel Grade 316
Product Code
Ref. No.
Thread
P
Size
PIN
PE
F
C
T
OD
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
UNF
UNF
1/4”
15,4
6,0
7
13
6,3
14,3
134
204
80
RSFF03
PS01.01.03
1/4”
6,0
6,3
7
13
6,3
14,3
125
195
67
RSFE03
PS01.02.03
5/16”
24,6
8,0
9
16
8,0
18,0
165
243
170
RSFF04
PS01.01.04
5/16”
8,0
8,4
9
16
8,0
18,0
155
230
135
RSFE04
PS01.02.04
3/8”
37,2
9,5
11
19
10,0
22,2
201
301
282
RSFF05
PS01.01.05
3/8”
9,5
9,8
11
19
10,0
22,2
190
290
235
RSFE05
PS01.02.05
7/16”
50,2
11,0
12
22
11,0
25,4
222
330
398
RSFF06
PS01.01.06
7/16”
11,0
11,5
12
22
11,0
25,4
210
315
332
RSFE06
PS01.02.06
1/2”
58,3
12,0
15
25
12,7
28,6
258
390
614
RSFF07
PS01.01.07
1/2”
12,0
12,7
15
25
12,7
28,6
245
375
521
RSFE07
PS01.02.07
5/8”
92,0
14,3
16
28
14,0
34,1
325
480
1430
RSFF08
PS01.01.08✸
5/8”
14,3
14,5
16
28
14,0
34,1
310
465
1093
RSFE08
PS01.02.08✸
5/8”
93,1
16,0
18
32
16,0
38,0
346
502
1434
RSFF10
PS01.01.10✸
5/8”
16,0
16,5
18
32
16,0
38,0
325
480
1198
RSFE10
PS01.02.10✸
3/4”
135,6
19,0
22
38
19,0
47,6
400
571
2418
RSFF12
PS01.01.12✸
3/4”
19,0
19,5
22
38
19,0
47,6
375
545
1952
RSFE12
PS01.02.12✸
7/8”
185,2
22,0
26
45
22,2
54,0
444
641
3577
RSFF14
PS01.01.14✸
7/8”
22,0
22,2
26
45
22,2
54,0
415
610
3048
RSFE14
PS01.02.14✸
1”
241,1
25,4
29
50
25,4
63,5
518
757
5340
RSFF16
PS01.01.16✸
1”
25,0
25,4
29
50
25,4
63,5
485
725
4407
RSFE16
PS01.02.16✸
1 1/8”
310,9
28,0
32
58
28,6
69,9
586
856
5618
RSFF19
PS01.01.19✸
1 1/8”
28,0
28,6
32
58
28,6
69,9
550
820
4364
RSFE19
PS01.02.19✸
1 1/4”
389,6
32,0
38
64
32,0
76,2
634
918
7711
RSFF22
PS01.01.22✸
1 1/4”
32,0
32,6
38
64
32,0
76,2
595
880
5992
RSFE22
PS01.02.22✸
1 3/8”
477,2
35,0
42
70
35,0
82,5
716
1040
14085
RSFF26
PS01.01.26✸
1 3/8”
35,0
35,8
42
70
35,0
82,5
675
1000
12122
RSFE26
PS01.02.26✸
✸
✸ Bodies with bronze inserts
■ Bigger sizes on request.
■ All threads are precision cut and forged to
BS3643 part 1 & 2 and BS1580 part 1 & 2.
■ All Forks Manufactured From Solid Bar.
■ All HI-MOD rigging screws above 10 mm wire rope
are highgloss hand polished.
■ In the near future the bodies become a spannerflat
instead of a crosshole.
■ Breaking load same as Fork - Fork types.
■ Bigger sizes on request.
■ All HI-MOD rigging screws above 10 mm wire rope
are highgloss hand polished.
Bodies with bronze inserts
■ All HI-MOD rigging screws:
Free from structual welds which may reduce the strength
and integrity of the product.
■
All HI-MOD rigging screws are available in
fork - fork
toggle - fork
fork - eye
toggle - stud
fork - stud
toggle - swageless
eye - eye
eye - swageless
eye - stud
fork - swageless
stud - stud
types (ask for specification sheets)
Rigging Screws - Eye / Eye High Quality Stainless Steel Grade 316
Thread
P
T
Size
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
UNF
1/4”
6,3
6,0
120
190
54
RSEE03
PS01.04.03
5/16”
8,4
7,0
145
220
100
RSEE04
PS01.04.04
3/8”
9,8
8,0
175
275
188
RSEE05
PS01.04.05
7/16”
11,5
9,5
195
300
266
RSEE06
PS01.04.06
1/2”
12,7
11,0
230
365
428
RSEE07
PS01.04.07
5/8”
14,5
14,0
295
450
926
RSEE08
PS01.04.08✸
5/8”
16,5
15,0
305
460
962
RSEE10
PS01.04.10✸
3/4”
19,5
18,0
345
515
1486
RSEE12
PS01.04.12✸
7/8”
22,2
22,0
385
580
2519
RSEE14
PS01.04.14✸
1”
25,4
24,0
450
690
3474
RSEE16
PS01.04.16✸
1 1/8”
28,6
28,0
510
780
4110
RSEE19
PS01.04.19✸
1 1/4”
32,6
32,0
560
840
5273
RSEE22
PS01.04.22✸
1 3/8”
35,5
34,0
630
950
10159
RSEE26
PS01.04.26✸
✸ Bodies with bronze inserts
■ Bigger sizes on request.
136
■ Breaking load same as Fork - Fork types.
■ All HI-MOD rigging screws above 10 mm wire rope
are highgloss hand polished.
137
Stainless Steel Rigging Screws
Stainless Steel Rigging Screws
Rigging Screws - Stud / Fork Including Clevis Pin
High Quality Stainless Steel Grade 316
Thread
ø
P
Size
wire in mm
PIN
1/4”
3
6,0
7
13
6,3
F
C
T
Rigging Screws - Stud / Eye High Quality Stainless Steel Grade 316
OD
Min
Max
weight
L
L
in gr
14,3
125
195
Product Code
Ref. No.
Thread
ø
Size
wire in mm
P
T
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
UNF
UNF
1/4”
3
6,3
6,0
115
185
62
RSSE03
PS01.05.03
79
RSSF03
PS01.03.03
1/4”
4
6,3
6,0
117
187
63
RSSE04DS
PSRS.SE.04DS
5/16”
4
8,4
7,0
140
215
106
RSSE04
PS01.05.04
PSRS.SE.05DS
1/4”
4
6,0
7
13
6,3
14,3
127
197
80
RSSF04DS
PSRS.SF.04DS
5/16”
4
8,0
9
16
8,0
18,0
150
225
151
RSSF04
PS01.03.04
5/16”
5
8,4
7,0
142
217
108
RSSE05DS
5/16”
5
8,0
9
16
8,0
18,0
152
227
153
RSSF05DS
PSRS.SF.05DS
3/8”
5
9,8
8,0
170
270
194
RSSE05
PS01.05.05
3/8”
5
9,5
11
19
10,0
22,2
185
285
257
RSSF05
PS01.03.05
3/8”
6
9,8
8,0
173
273
197
RSSE06DS
PSRS.SE.06DS
3/8”
6
9,5
11
19
10,0
22,2
188
288
261
RSSF06DS
PSRS.SF.06DS
7/16”
6
11,5
9,5
190
295
298
RSSE06
PS01.05.06
7/16”
6
11,0
12
22
11,0
25,4
200
310
386
RSSF06
PS01.03.06
7/16”
7
11,5
9,5
194
299
302
RSSE07DS
PSRS.SE.07DS
7/16”
7
11,0
12
22
11,0
25,4
203
313
391
RSSF07DS
PSRS.SF.07DS
1/2”
7
12,7
11,0
220
350
466
RSSE07
PS01.05.07
1/2“
7
12,0
15
25
12,7
28,6
235
365
591
RSSF07
PS01.03.07
1/2”
8
12,7
11,0
225
355
500
RSSE08DS
PSRS.SE.08DS
1/2“
8
12,0
15
25
12,7
28,6
240
370
625
RSSF08DS
PSRS.SF.08DS
5/8”
8
14,5
14,0
285
410
968
RSSE08
PS01.05.08✸
5/8”
8
14,3
16
28
14,0
34,1
300
455
1185
RSSF08
PS01.03.08✸
5/8”
10
16,5
15,0
290
445
1032
RSSE10
PS01.05.10✸
5/8”
10
16,0
18
32
16,0
38,0
315
470
1340
RSSF10
PS01.03.10✸
3/4”
12
19,5
18,0
335
505
1626
RSSE12
PS01.05.12✸
3/4”
12
19,0
22
38
19,0
47,6
360
530
2218
RSSF12
PS01.03.12✸
7/8”
14
22,2
22,0
375
570
2657
RSSE14
PS01.05.14✸
7/8”
14
22,0
26
45
22,2
54,0
405
600
3376
RSSF14
PS01.03.14✸
1”
16
25,4
24,0
440
680
3694
RSSE16
PS01.05.16✸
1”
16
25,4
29
50
25,4
63,5
475
715
4925
RSSF16
PS01.03.16✸
1 1/8”
19
28,6
28,0
495
765
4670
RSSE19
PS01.05.19✸
1 1/8”
19
28,0
32
58
28,6
69,9
530
800
5318
RSSF19
PS01.03.19✸
1 1/4”
22
32,6
32,0
535
820
5442
RSSE22
PS01.05.22✸
1 1/4”
22
32,0
38
64
32,0
76,2
575
860
7711
RSSF22
PS01.03.22✸
1 3/8”
26
35,8
34,0
615
940
11404
RSSE26
PS01.05.26✸
1 3/8”
26
35,0
42
70
35,0
82,5
655
980
14085
RSSF26
PS01.03.26✸
✸
138
Bodies with bronze inserts
■ Breaking load same as Fork - Fork type.
■ Bigger sizes on request.
■ All HI-MOD rigging screws above 10 mm wire rope
are highgloss hand polished.
✸ Bodies with bronze inserts
■ All HI-MOD rigging screws above 10 mm wire rope
are highgloss hand polished.
■
■
■
Breaking load same as Fork - Fork type.
Bigger sizes on request.
For HI-MOD rigging screws are available
- Bodies
- Threaded plate toggle forksright - and left
- Threaded shackle toggles right - and left
- Threaded studs
right - and left
- Swageless studs
right - and left
- Threaded eyes
right - and left
- Nuts
right - and left
(Ask for specification sheets)
handed
handed
handed
handed
handed
handed
139
Stainless Steel Turnbuckles with aluminium bronze chromed bodies
Stainless Steel Turnbuckles with aluminium bronze chromed bodies
Turnbuckles - Fork / Fork including Clevis Pin
High Quality Stainless Steel AISI 316 and bronze chromed bodies
Thread
Breaking
P
UNF
Load in kN
PIN
F
C
OD
T
Turnbuckles - Fork / Toggle including Clevis Pins
High Quality Stainless Steel AISI 316 and aluminium bronze chromed bodies
Min
Max
weight
L
L
in gr
Ref. No.
Product Code
Thread
P
UNF
PIN
FC
ST
SC
FT
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
1/4”
14
6,0
7
12,5
14,3
6,2
143
215
84
GTFF03
PSGT.FF.03
1/4”
6,0
13
7,7
16,0
6,3
157,5
229,5
79
GTFT03
PSGT.FT.03
5/16“
21
8,0
9
17,0
18,0
7,9
175
255
172
GTFF04
PSGT.FF.04
5/16“
8,0
16
9,0
16,5
8,0
192,0
272,0
181
GTFT04
PSGT.FT.04
3/8“
34
9,5
11
19,0
22,7
9,9
211
315
268
GTFF05
PSGT.FF.05
3/8“
9,5
19
10,3
20,4
10,0
231,5
335,5
293
GTFT05
PSGT.FT.05
7/16“
46
11,0
12
22,0
25,4
10,9
233
345
388
GTFF06
PSGT.FF.06
7/16“
11,0
22
14,0
28,0
11,0
260,5
372,5
476
GTFT06
PSGT.FT.06
1/2“
52
12,0
15
25,0
28,6
12,7
280
420
622
GTFF07
PSGT.FF.07
1/2“
12,0
25
15,0
36,0
12,7
318,0
458,0
721
GTFT07
PSGT.FT.07
5/8“
84
14,0
16
28,0
34,1
13,8
318
468
1178
GTFF08
PSGT.FF.08
5/8“
14,0
28
19,0
39,4
14,0
368,5
518,5
1200
GTFT08
PSGT.FT.08
5/8“
84
16,0
18
32,0
38,0
15,8
342
492
1308
GTFF10
PSGT.FF.10
5/8“
16,0
32
19,0
40,0
16,0
380,5
530,5
1501
GTFT10
PSGT.FT.10
3/4“
120
19,0
22
38,0
47,6
17,8
393
573
2086
GTFF12
PSGT.FF.12
3/4“
19,0
38
22,0
55,0
19,0
443,5
623,5
2548
GTFT12
PSGT.FT12
7/8“
165
22,0
26
45,0
54,0
22,0
450
660
3299
GTFF14
PSGT.FF.14
7/8“
22,0
45
24,0
60,0
22,2
512,0
722,0
4106
GTFT14
PSGT.FT.14
1“
215
25,4
29
50,0
63,5
25,0
514
754
5255
GTFF16
PSGT.FF.16
1“
25,4
50
28,0
70,0
25,4
583,5
823,5
6088
GTFT16
PSGT.FT.16
1 1/8“
280
28,0
32
58,0
69,9
28,2
581
851
7431
GTFF19
PSGT.FF.19
1 1/8“
28,0
58
32,0
80,0
28,6
661,0
931,0
8998
GTFT19
PSGT.FT.19
1 1/4“
350
32,0
38
64,0
76,2
31,8
641
941
9825
GTFF22
PSGT.FF.22
1 1/4“
32,0
64
36,0
85,0
32,0
730,5
1030,5
12253
GTFT22
PSGT.FT.22
1 3/8“
430
35,0
42
70,0
82,5
34,8
692
1021
12766
GTFF26
PSGT.FF.26
1 3/8“
35,0
70
38,0
105,0
35,0
801,5
1121,5
16175
GTFT26
PSGT.FT.26
■
■
■
■
■
This unique Gracilis design lets us machine the bodies from high grade materials
Using this process has allowed us to reduce the weight by 20% without reducing the strength
All forks manufactured from solid bar and above 10 mm wire rope all stainless parts are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
■
■
■
■
■
Breaking load same as fork-fork type
OD size same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
Gracilis Body
Creole
140
141
Stainless Steel Turnbuckles with aluminium bronze bodies
Stainless Steel Turnbuckles with aluminium bronze bodies
Turnbuckles - Stud / Fork including Clevis Pin
High Quality Stainless Steel AISI 316 and aluminium bronze bodies
Thread
ø
P
UNF
wire in mm
PIN
1/4”
3
6,0
14,3
12,5
1/4“
4
6,0
14,3
12,5
5/16“
4
8,0
18,0
5/16“
5
8,0
3/8“
5
9,5
3/8“
6
7/16“
7/16“
OD
C
T
Turnbuckles - Stud / Toggle including Clevis Pin
High Quality Stainless Steel AISI 316 and aluminium bronze bodies
Ref. No.
Thread
ø
P
UNF
wire in mm
PIN
C
weight
L
in gr
8
148,5
220,5
78
GTST03
PSGT.ST.03
8
149,5
221,5
89
GTST04DS
PSGT.ST.04DS
9
177,5
257,5
153
GTST04
PSGT.ST.04
18
9
180,5
260,5
177
GTST05DS
PSGT.ST.05DS
21
11
214,5
318,5
268
GTST05
PSGT.ST.05
9,5
21
11
217,5
321,5
293
GTST06DS
PSGT.ST.06DS
6
11,0
25
13
237,5
349,5
464
GTST06
PSGT.ST.06
7
11,0
25
13
238,0
350,0
698
GTST07DS
PSGT.ST.07DS
1/2“
6
12,0
27
15
286,0
426,0
666
GTST06US
PSGT.ST.06US
PSGT.SF.07
1/2“
7
12,0
27
15
286,0
426,0
698
GTST07
PSGT.ST.07
PSGT.SF.08DS
1/2“
8
12,0
27
15
289,0
429,0
732
GTST08DS
PSGT.ST.08DS
PSGT.SF.08US
5/8“
8
16,0
36
19
339,5
489,5
1361
GTST08US
PSGT.ST.08US
GTSF10
PSGT.SF.10
5/8“
10
16,0
36
19
341,5
491,5
1407
GTST10
PSGT.ST.10
GTSF10US
PSGT.SF.10US
3/4“
10
19,0
45
22
391,5
571,5
2198
GTST10US
PSGT.ST.10US
GTSF12
PSGT.SF.12
3/4“
12
19,0
45
22
393,0
573,0
2348
GTST12
PSGT.ST.12
3098
GTSF14
PSGT.SF.14
7/8“
14
22,0
53
25
457,5
667,5
3905
GTST14
PSGT.ST.14
4040
GTSF16
PSGT.SF.16
1“
16
25,4
62
28
529,0
769,0
5673
GTST16
PSGT.ST.16
7131
GTSF19
PSGT.SF.19
1 1/8“
19
28,0
63
32
588,0
858,0
8698
GTST19
PSGT.ST.19
803,0
9825
GTSF22
PSGT.SF.22
1 1/4“
22
32,0
76
35
662,5
962,5
12253
GTST22
PSGT.ST.22
863,0
12766
GTSF26
PSGT.SF.26
1 3/8“
26
35,0
92
38
727,0
1047,0
16175
GTST26
PSGT.ST.26
weight
L
in gr
6,2
134,0
206,0
83
GTSF03
PSGT.SF.03
1/4”
3
6,0
14
6,2
135,0
207,0
89
GTSF04DS
PSGT.SF.04DS
1/4“
4
6,0
14
17,0
7,9
152,5
232,5
153
GTSF04
PSGT.SF.04
5/16“
4
8,0
18
18,0
17,0
7,9
155,5
235,5
177
GTSF05DS
PSGT.SF.05DS
5/16“
5
8,0
22,2
19,0
9,9
182,0
286,0
268
GTSF05
PSGT.SF.05
3/8“
5
9,5
9,5
22,2
19,0
9,9
185,0
289,0
293
GTSF06DS
PSGT.SF.06DS
3/8“
6
6
11,0
25,4
22,0
10,9
198,0
310,0
464
GTSF06
PSGT.SF.06
7/16“
7
11,0
25,4
22,0
10,9
199,0
311,0
478
GTSF07DS
PSGT.SF.07DS
7/16“
1/2“
6
12,0
28,6
25,0
12,7
239,0
379,0
666
GTSF06US
PSGT.SF.06US
1/2“
7
12,0
28,6
25,0
12,7
239,0
379,0
698
GTSF07
1/2“
8
12,0
28,6
25,0
12,7
242,0
382,0
732
GTSF08DS
5/8“
8
16,0
38,0
32,0
15,8
269,0
419,0
1361
GTSF08US
5/8“
10
16,0
38,0
32,0
15,8
271,0
421,0
1407
3/4“
10
19,0
47,6
38,0
17,8
308,5
488,5
2198
3/4“
12
19,0
47,6
38,0
17,8
310,0
490,0
2036
7/8“
14
22,0
54,0
45,0
22,0
359,0
569,0
1“
16
25,4
63,5
50,0
25,0
409,0
649,0
1 1/8“
19
28,0
69,9
58,0
28,2
456,0
726,0
1 1/4“
22
32,0
76,2
64,0
31,8
503,0
1 3/8“
26
35,0
82,5
70,0
34,8
543,0
Breaking loads same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
Ref. No.
Max
L
Max
L
■
■
■
■
T
Min
Min
Product Code
■
■
■
■
Product Code
Breaking loads same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
Creole
142
143
Stainless Steel Turnbuckles with aluminium bronze chromed bodies
Stainless Steel Turnbuckles with aluminium bronze chromed bodies
Turnbuckles - Stud / Sternball
High Quality Stainless Steel AISI 316 and aluminium bronze chromed bodies
Thread
ø
UNF
wire in mm
■
■
■
■
R
D
Turnbuckles - Stud / Eye including Clevis Pin
High Quality Stainless Steel AISI 316 and aluminium bronze chromed bodies
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
Thread
ø
UNF
wire in mm
H
T
Min
Max
weight
L
L
in gr
Product Code
Ref. No.
1/4”
3
6,30
13,0
127,0
199,0
74
GTSB03
PSGT.SB.03
1/4”
3
6,35
5,0
127,0
199,0
74
GTSE03
PSGT.SE.03
5/16“
4
8,80
17,0
128,0
200,0
212
GTSB04
PSGT.SB.04
1/4“
4
6,35
5,0
128,0
200,0
80
GTSE04DS
PSGT.SE.04DS
3/8“
5
8,80
17,0
182,0
286,0
237
GTSB05
PSGT.SB.05
5/16“
4
8,00
6,5
149,5
229,5
128
GTSE04
PSGT.SE.04
7/16“
6
10,80
21,0
198,0
310,0
332
GTSB06
PSGT.SB.06
5/16“
5
8,00
6,5
152,5
232,5
143
GTSE05DS
PSGT.SE.05DS
1/2“
7
10,80
21,0
244,0
384,0
538
GTSB07
PSGT.SB.07
3/8“
5
9,53
7,8
182,0
286,0
212
GTSE05
PSGT.SE.05
1/2“
8
13,80
27,0
250,0
390,0
572
GTSB08DS
PSGT.SB.08DS
3/8“
6
9,53
7,8
185,0
289,0
237
GTSE06DS
PSGT.SE.06DS
5/8“
8
13,80
27,0
284,0
434,0
1004
GTSB08
PSGT.SB.08
7/16“
6
11,10
9,5
198,5
310,5
332
GTSE06
PSGT.SE.06
5/8“
10
15,80
31,0
287,0
437,0
1050
GTSB10
PSGT.SB.10
7/16“
7
11,10
9,5
-
-
351
GTSE07DS
PSGT.SE.07DS
3/4“
12
17,80
35,0
327,0
507,0
1696
GTSB12
PSGT.SB.12
1/2“
6
12,70
11,5
244,5
384,5
491
GTSE06US
PSGT.SE.06US
1/2“
7
12,70
11,5
244,5
384,5
538
GTSE07
PSGT.SE.07
1/2“
8
12,70
11,5
247,5
387,5
572
GTSE08DS
PSGT.SE.08DS
5/8“
8
14,28
15,0
284,5
434,5
1004
GTSE08US
PSGT.SE.08US
5/8“
10
16,00
15,0
286,5
436,5
1050
GTSE10
PSGT.SE.10
3/4“
10
19,05
17,5
325,5
505,5
1546
GTSE10US
PSGT.SE.10US
3/4“
12
19,05
17,5
327,0
507,0
1696
GTSE12
PSGT.SE.12
7/8“
14
22,20
21,5
378,5
588,5
2759
GTSE14
PSGT.SE.14
1“
16
25,40
23,5
435,0
675,0
4205
GTSE16
PSGT.SE.16
1 1/8“
19
28,58
27,5
488,0
758,0
6271
GTSE19
PSGT.SE.19
1 1/4“
22
32,00
31,0
543,5
843,5
8656
GTSE22
PSGT.SE.22
1 3/8“
26
35,00
33,5
587,0
907,0
11521
GTSE26
PSGT.SE.26
Breaking loads same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
D
■
■
■
■
Breaking loads same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
Windrose
144
145
Stainless Steel Turnbuckles with aluminium bronze chromed bodies
Aluminium bronze chrome bodies
Turnbuckles - Toggle / Blank including Clevis Pin
High Quality Stainless Steel AISI 316 and aluminium bronze chromed bodies
Gracilis bronze chrome bodies
Thread
Thread
P
UNF
PIN
■
■
■
■
■
■
C
T
OD
L
weight
Product Code
Ref. No.
in gr
Size
Ref. No.
Min
Max
weight
L
L
in gr
1/4”
10,9
103
34
GTB 1/4
PSGTB 1/4
7,7
137,5
173,5
54
GTTB03
PSGT.TB.03
5/16”
13,8
119
62
GTB 5/16
PSGTB 5/16
3/8”
15,8
147
98
GTB 3/8
PSGTB 3/8
7/16”
18,8
163
148
GTB 7/16
PSGTB 7/16
21,9
203
252
GTB 1/2
PSGTB 1/2
508
GTB 5/8
PSGTB 5/8
Product Code
UNF
1/4”
6,3
16,0
5/16“
8,0
16,5
9,0
164,0
204,0
126
GTTB04
PSGT.TB.04
3/8“
9,5
20,4
10,3
199,5
251,5
208
GTTB05
PSGT.TB.05
7/16“
11,1
28,0
13,0
225,5
281,5
356
GTTB06
PSGT.TB.06
1/2”
1/2“
12,7
36,0
15,0
279,0
349,0
536
GTTB07
PSGT.TB.07
5/8”
28,0
228
5/8“
16,0
40,0
19,0
323,5
398,5
1101
GTTB10
PSGT.TB.10
3/4“
31,6
265
736
GTB 3/4
PSGTB 3/4
37,7
310
1149
GTB 7/8
PSGTB 7/8
3/4“
19,0
55,0
22,0
379,5
469,5
1798
GTTB12
PSGT.TB.12
7/8“
7/8“
22,2
60,0
24,0
442,0
547,0
3031
GTTB14
PSGT.TB.14
1“
43,6
356
1875
GTB 1
PSGTB 1
1“
25,4
70,0
28,0
504,5
624,5
4398
GTTB16
PSGT.TB.16
1 1/8“
49,5
401
2731
GTB 1 1/8
PSGTB 1 1/8
1 1/8“
28,6
80,0
32,0
571,0
706,0
6648
GTTB19
PSGT.TB.19
1 1/4“
53,8
443
3425
GTB 1 1/4
PSGTB 1 1/4
1 1/4“
32,0
85,0
36,0
631,5
781,5
9053
GTTB22
PSGT.TB.22
1 3/8“
59,8
476
4766
GTB 1 3/8
PSGTB 1 3/8
1 3/8“
35,0
105,0
38,0
693,5
853,5
12175
GTTB26
PSGT.TB.26
The blank side of the body has right handed thread
The open part can be used any of the threaded parts, such as an eye-toggle-fork-stud-shackle toggle or swageless studs
Breaking loads same as fork-fork type
All turnbuckle parts above 10 mm wire rope are highgloss hand polished
For traditional boats bodies are available without chrome
Bigger sizes on request
■
■
■
■
This unique Gracilis design lets us machine the bodies from high grade materials
Using this process has allowed us to reduce the weight by 20% without reducing the strength
For traditional boats bodies are available without chrome
Bigger sizes on request
■
For HI-MOD turnbuckles are available
- threaded plate toggle forks right and
- threaded studs
right and
- swageless studs
right and
- threaded eyes
right and
- threaded forks
right and
- threaded stemballs
right and
Ask for specification sheets
left
left
left
left
left
left
handed
handed
handed
handed
handed
handed
Kings Legend
146
147
Stainless Steel AISI 316 Threaded parts
Stainless Steel AISI 316 Nuts
Hexagon locking nuts
Threaded parts
■ For all sizes of rigging screws and turnbuckles are available right- and lefthanded UNF open and closed body threaded
parts
such as: threaded forks
threaded eyes
threaded toggle forks
threaded shackle toggles
■ Ask for specification sheets
Closed Body
Open Body
Thread
Product Code
weight
Width
in gr
UNF
Ref. No.
Ref. No.
Right
Left
1/4”
3,8
1,0
NUT1/4
PSNUT1/4R
PSNUT1/4L
5/16”
5,4
2,0
NUT5/16
PSNUT5/16R
PSNUT5/16L
3/8”
6,3
4,0
NUT3/8
PSNUT3/8R
PSNUT3/8L
7/16”
7,8
8,0
NUT7/16
PSNUT7/16R
PSNUT7/16L
1/2”
7,8
9,0
NUT1/2
PSNUT1/2R
PSNUT1/2L
5/8”
10,7
19,0
NUT5/8
PSNUT5/8R
PSNUT5/8L
3/4”
13,1
22,0
NUT3/4
PSNUT3/4R
PSNUT3/4L
7/8”
15,4
46,0
NUT7/8
PSNUT7/8R
PSNUT7/8L
1”
17,3
49,0
NUT1
PSNUT1R
PSNUT1L
1 1/8”
17,8
85,0
NUT11/8
PSNUT11/8R
PSNUT11/8L
1 1/4”
21,6
104,0
NUT11/4
PSNUT11/4R
PSNUT11/4L
1 3/8”
23,0
158,0
NUT13/8
PSNUT13/8R
PSNUT13/8L
Round locking nuts
Thread
W
OD
A/F
Product Code
weight
Ref. No.
Ref. No.
in gr
Right
Left
UNF
Closed Body
Closed Body
Open Body
5/8“
11
22
19
RLN5/8
17,1
PSRLN5/8R
PSRLN5/8L
3/4“
13
27
24
RLN3/4
19,8
PSRLN3/4R
PSRLN3/4L
1“
14
38
33
RLN1
4,4
PSRLN1R
PSRLN1L
1 1/8“
16
44
37
RLN11/8
76,5
PSRLN11/8R
PSRLN11/8L
1 1/4“
18
50
40
RLN11/4
93,6
PSRLN11/4R
PSRLN11/4L
1 3/8“
20
54
46
RLN13/8
142,4
PSRLN13/8R
PSRLN13/8L
Open Body
Hexagon full nuts
Thread
d
k
sw
a
Min.
Ref. No.
Ref. No.
packing pcs.
RH thread
LH thread
M4
7,7
3,2
7
10
I892-0400
I893-0400
M5
8,8
4,0
8
10
I892-0500
I893-0500
M6
11,1
5,0
10
10
I892-0600
I893-0600
M8
14,4
6,5
13
10
I892-0800
I893-0800
M10
18,9
8,0
17
5
I892-1000
I893-1000
M12
21,1
10,0
19
2
I892-1200
I893-1200
M14
24,5
11,0
22
2
I892-1400
I893-1400
M16
26,8
13,0
24
2
I892-1600
I893-1600
M20
33,5
16,0
30
2
I892-2000
I893-2000
M22
35,0
18,0
32
1
I892-2200
I893-2200
M24
39,5
19,0
36
1
I892-2400
I893-2400
M30
50,8
24,0
46
1
I892-3000
I893-3000
■ Hexagon full nuts are AISI 304
148
149
Stainless Steel AISI 316 Spherical nuts and washers
Toggles
Spherical nuts (righthanded thread M) incl. washer
Thread
OD
AF
L
Spade & Fork Toggles Including Clevis Pin Stainless Steel AISI 316
ID
size
A
Product Code
Ref. No.
P1
F
S
C
T
OD
P2
L
weight
Product Code
Ref. No.
in gr
max.
metric
M8
M10
M12
22
22
25
17
17
19
18
18
19
15,0
15,0
17,5
7°
7°
7°
SNUT08
SNUT10
SNUT12
PSSNUT08
6,0
7
10
13
6,3
14,3
6,3
42
22
TOG03
PS08.01.03
PSSNUT10
8,0
9
13
16
8,0
18,0
8,0
53
44
TOG04
PS08.01.04
PSSNUT12
9,5
11
15
19
9,5
22,2
9,5
64
84
TOG05
PS08.01.05
11,0
12
17
22
11,1
25,4
11,1
72
100
TOG06
PS08.01.06
12,0
15
21
25
12,7
28,6
12,7
87
180
TOG07
PS08.01.07
14,0
17
22
28
14,3
34,9
14,3
95
292
TOG08
PS08.01.08
16,0
18
24
32
16,0
38,1
16,0
106
424
TOG10
PS08.01.10
19,0
23
30
38
19,1
47,6
19,1
125
724
TOG12
PS08.01.12
22,0
26
36
45
22,2
54,0
22,2
146
825
TOG14
PS08.01.14
25,4
31
39
50
25,4
63,5
25,4
162
1790
TOG16
PS08.01.16
28,0
33
47
58
28,6
69,9
28,6
184
2415
TOG19
PS08.01.19
32,0
39
50
64
32,0
76,2
32,0
207
3229
TOG22
PS08.01.22
35,0
44
54
70
35,0
82,5
35,0
227
5624
TOG26
PS08.01.26
■ This Type of toggle allows a standard fork end to be transformed into a toggle end.
■ Manufactured without welds.
■ Spherical nuts have a rounded off base which fits exactly into the rounded off washer
■ The swage or swageless stud can make an angle from max. 7 degree from the center line
■ When somebody puts his weight on a balustrading wire the stud won’t be damaged (bended)
or when the balustrading part is not exactly vertical the wire will not bend after the stud, but the stud is moving into the
right line
■ The M8 nuts fits on the M8 to 4 studs
M8 to 5 studs
■ The M10 nuts fits on the M10 to 5 studs
M10 to 6 studs
■ The M12 nuts fits on the M12 to 6 studs
M12 to 7 studs
M12 to 8 studs
Spade Fork
Toggle
Swaged
Fork
Terminal
Double Jaw Toggles Including Clevis Pin Stainless Steel AISI 316
P1
P2
W
T
OD
L
weight
Product Code
Ref. No.
in gr
6,0
6,0
7,7
5,5
17
23
24
DJT06
PS.DJT.06
8,0
8,0
9,0
8,0
19
26
57
DJT08
PS.DJT.08
9,5
9,5
10,3
9,5
23
30
86
DJT10
PS.DJT.10
11,0
11,0
14,0
13,0
25
40
134
DJT11
PS.DJT.11
12,0
12,0
14,2
13,0
29
43
220
DJT12
PS.DJT.12
16,0
16,0
17,5
16,0
40
57
408
DJT16
PS.DJT.16
19,0
19,0
22,0
18,5
50
77
728
DJT19
PS.DJT.19
22,0
22,0
24,5
24,5
55
88
1171
DJT22
PS.DJT.22
25,4
25,0
28,5
24,5
60
100
1628
DJT25
PS.DJT.25
28,0
28,0
32,5
30,0
70
116
2463
DJT28
PS.DJT.28
32,0
32,0
36,5
35,0
80
125
3415
DJT32
PS.DJT.32
35,0
35,0
42,0
36,5
90
152
5414
DJT35
PS.DJT.35
■ This Type of toggle allows a standard eye end to be transformed into a toggle end.
■ All HI-MOD toggles are highgloss hand polished
150
151
Toggles
Wire Rigging Insulators
Eye-jaw Toggles. Including Clevis Pin Stainless Steel A1S1 316
P
T
Y
L
OL
Fail Safe Wire Rigging Insulators
W
Weight
Product
in gr.
code
Ref. No.
12,7
13
26
51
81
12,5
81
EJT 1/2
PSEJT 12
16,0
17
32
64
101
16,0
223
EJT 5/8
PSEJT 16
19,0
20
39
74
117
19,0
413
EJT 3/4
PSEJT 19
22,0
24
47
84
137
22,0
708
EJT 7/8
PSEJT 22
25,4
27
51
100
158
25,0
891
EJT 1
PSEJT 25
28,0
29
59
108
173
28,0
1481
EJT 1 1/8
PSEJT 28
32,0
34
66
123
197
32,0
1937
EJT 1 1/4
PSEJT 32
35,0
37
70
150
234
35,0
3164
EJT 1 3/8
PSEJT 35
It is the only fail safe rigging insulator for wire available on the market today. Utilising the same features that have made the
Hi-Mod compression fittings so popular, this insulator has an internal ball-socket in the main body that threads onto the connecting stud. The nut is insulated from the stainless steel body by a TufnolTM socket, preventing electrical transference to the
insulator body or opposite terminal. Should, for any reason, the TufnolTM be compromised, the nut will bottom out against
the stainless housing. While the backstay will loosen, the insulating studs will remain attached to the insulator body-allowing
the rig to be re-tensioned until a repair can be made. The Hi-Mod insulator meets or exceeds current electrical standards for
marine backstay insulators. Available with swageless terminals, swage terminals, eye, fork and toggle ends to suit any application.
The insulator diagrams detailed below are showing only half sections of a complete assembly. This allows the enduser to select the terminations they require. For example, if you want an insulator with a compression stud at one end
and a fork at the other end then the code would be RICF followed by the wire size.
■ All HI-MOD toggles are highgloss polished.
■ All HI-MOD toggles come supplied with clevis pin and splitpen.
T
Y
Ref. No = PSRICC06
P
L
The product codes for rigging insulators are made up by suffixing “RI” with the relevant end fittings followed by the
wire size.
E.g. The diagram below could be coded RICC06 for wire size 6 mm, RICC07 for wire size 7 mm, etc., etc. as productcode.
The ref. no is PS + productcode, for example PSRICC06 for wire size 6 mm (see drawing).
All insulators can be swaged using most types of swaging machines.
WireTeknik machines require a special pulling tool. For SL Parts see table below for the correct puller code.
OL
F-L
C-L
T-L
E-L
S-L
W
ø
Pin
Hole
C-L
E-L
S-L
F-L
T-L
Puller
Code
wire size
5
11,0
11,3
106
107
101
121
147
RIP7/16
6
11,0
11,3
110
107
101
121
147
RIP7/16
7
12,0
12,8
131
129
120
142
169
RIP1/2
8
14,0
14,3
153
151
140
164
212
RIP5/8
10
16,0
16,2
159
155
142
176
212
RIP5/8
12
19,0
19,3
192
180
168
207
258
RIP3/4
14
22,0
22,3
222
207
196
238
297
RIP7/8
16
25,4
25,5
258
237
226
271
337
RIP1
■ CL parts are for 1x19 wire rope construction.
Different Cones and Crown Rings are used for 7 strand Compacted Strand ropes.
Constr. 1 x 19 and 1 x 25 C Compacted Strand constr. 1 x 36 CS
■ Add suffix -7, -C or -CS for these assemblies after ref. no.
■ Larger sizes manufactured to order.
■ The insulator exceeds the rated breaking load of the cable.
■ The 8 mm insulator cannot be swaged on a „Wireteknik A 200“
■ The 14 and 16 mm insulator cannot be swaged on a „Wireteknik A 300“
(ask for information)
152
153
Wire Rigging Insulators
HI-MOD insulators are special because if the boat is struck bij lightning and the inner insulation material is compromised,
they will not shatter and break apart (like other insulators). They will collapse slightly but keeps the stay intact.
■
■
■
Stage 1 shows the insulating material on both sides of the insulator. The insulating material is coloured green.
Stage 2 shows the insulating material on the LH side gone (maybe after lightning or some other incident).
Stage 3 shows the insulator collapsing, showing the retaining nut falling into place and
keeping the insulator intact. The insulation properties are gone and the insulator stops working but the stay does not collapse.
Rod Rigging Insulators
Fail Safe Rod Rigging Insulators
Built around the same design as the award winning Hi-Mod Wire Rigging Insulator, the ROD version of the Hi-Mod insulator
has been adapted to fit most sockets and caps. Utilising the same features that have made the Hi-Mod compression fittings
so popular, this insulator has an internal ball-socket in the main body that threads onto the connecting stud. The nut is insulated from the stainless steel body by a TufnolTM socket, preventing electrical transference to the insulator body or opposite terminal. Should, for any reason, the TufnolTM be compromised, the nut will bottom out against the stainless housing. All
Hi-Mod insulators meet or exceed current electrical standards for marine backstay insulators.
The insulator diagram detailed below shows a complete assembly consisting of 2 Rod Demi parts. The Rod Demi
part can also be used in conjunction with any Wire Rigging Demi. This results in multiple insulator combinations.
For more information on the Wire Insulator Demi parts or contact us for further information.
Rod
Socket / Cap
Thread
L
MBL
weight
size
Thread
mm
mm
kN
in gr
Product Code
Ref. No.
PSRIRR.8.716
UNF RH
-8
7/16”
17
244
67
560
RIRR-8X7/16
-8
1/2”
19
250
67
580
RIRR-8X1/2
PSRIRR.8.12
- 10
1/2”
19
250
67
790
RIRR-10X1/2
PSRIRR.10.12
- 10
9/16”
21
306
72
800
RIRR-10X9/16
PSRIRR.10.916
- 12
5/8”
24
310
108
1360
RIRR-12X5/8
PSRIRR.12.58
- 15
5/8”
24
310
108
1360
RIRR-15X5/8
PSRIRR.15.58
- 15
3/4”
29
320
108
1490
RIRR-15X3/4
PSRIRR.15.34
- 17
5/8”
24
310
108
1360
RIRR-17X5/8
PSRIRR.17.58
- 17
3/4”
29
320
108
1490
RIRR-17X3/4
PSRIRR.17.34
- 22
3/4”
29
356
157
1490
RIRR-22X3/4
PSRIRR.22.34
- 26
7/8”
33
378
215
1690
RIRR-26X7/8
PSRIRR.26.78
- 30
7/8”
33
378
215
1690
RIRR-30X7/8
PSRIRR.30.78
■ Larger sizes manufactured to order.
■ All Rod Insulators are inclusive rod sockets.
154
155
Swageless Eye and Fork Terminals Stainless Steel AISI 316
STA-LOK SWAGELESS TERMINALS
Swageless Eye including 1 x 19 Cone
Swageless terminals are a range of high quality high performance wire rope
fittings for 1x19, 7x7, 7x19 and compacted wire ropes.
Wire in mm
ø
A
B
C
D
H
Product
Ref. No.
Code
The swageless system has proven itself to be the simplest to assemble and
most efficient method of terminating wire ropes. The terminal will work under
constant loading and variable shock loading.
3
17,9
10,0
6,3
5,0
6,5
033-03
SL.33.00.03
4
20,3
14,7
8,0
5,8
8,0
033-04
SL.33.00.04
5
25,9
18,0
10,5
7,5
10,0
033-05
SL.33.00.05
STRONGER THAN THE WIRE ROPE
6
31,0
22,2
12,7
9,4
13,0
033-06
SL.33.00.06
7
32,5
24,6
13,6
10,4
13,0
033-07
SL.33.00.07
8
35,7
27,0
14,4
12,0
13,0
033-08-1/2
SL.33.00.58
The swageless terminal produces 100% of the rated breaking load of the wire
rope and is approved by Lloyds Register of Shipping Certificate No. YSC QA
108.
HAND FITTED INSTEAD OF MACHINE SWAGED
Eyes mate
with forks
Rotating
‘Former’
protects
wires from
grinding
on bottom
The swageless terminal can be fitted on site using very simple hand tools.
Exact length accuracy can be achieved without the need for pre-measurement
or tedious calculation.
8
35,7
27,0
15,9
13,4
16,0
033-08-5/8
SL.33.00.68
Eye holes will
pass both metric
and inch pins
10
41,1
29,2
17,8
13,4
16,0
033-10
SL.33.00.10
12
42,9
33,3
22,5
19,0
19,5
033-12
SL.33.00.12
14
55,6
38,1
25,5
20,0
22,5
033-14
SL.33.00.14
The patent
‘Former’ bends
wires over ‘wedge’
- no hassle!
16
63,8
40,0
27,1
20,0
25,4
033-16-1
SL.33.00.16
19
68,3
49,2
36,5
27,0
28,6
033-19
SL.33.00.19
22
122,2
60,3
39,7
33,3
34,9
033-22
SL.33.00.22
26
128,6
60,3
42,9
33,3
34,9
033-26
SL.33.00.25
D
P
Product
Ref. No.
‘Former’ rotates
for left or right
hand laid cables
REUSABLE
Double thickness
for strength
Manufactured from polished stainless steel 316. All swageless terminals are
reusable* requiring no servicing, providing long life and very low maintenance
costs.
The ‘wedge’ is longer
for positive lock
* It is recommended that a new cone component is used.
Solid support for full load
SWAGELESS Eye, Fork and Stud ends provide standard end fittings for wire
rope and are designed to suit most chain plates, turnbuckles and fixing points.
Swageless Fork including 1 x 19 Cone
Sizes 3-26 mm are listed, larger sizes are available upon request.
ø
When ordering please state clearly if terminals are for use with
compacted wire rope.
FULL FITTING INSTRUCTIONS PACKED WITH EACH TERMINAL
Step 1
Cut Wire Rope
TIP: If using the hacksaw, wind pvc tape
around wire and saw through tape.
Step 4
Slide wedge
component over
central core of wire rope
Step 2
Slide socket component
over wire
TIP: If using pvc tape around wire approx 12”
(300 mm) from end.
Step 5
Reposition outer strands
Turn outer strands either clockwise or anti-clockwise around the
wedge. Ensure approx 1/8” (2-3 mm) of the central core
protrudes from the end of the wedge. Outer strands
should be evenly situated around the wedge.
Care should be taken that a strand does
not slip of the wedge.
TIP: Push the socket towards the end of a wire, while repositioning
outer strands, this will help control. When wire strands are in
position push socket firmly, as indicated to hold wires in position.
156
A
B
C
Wire in mm
Step 3
Unravel outer strands
2” to 3” (50-76 mm)
to expose central core
TIP: Use a penknife to prise
initial strands out of position
Step 6
Final Assembly
Code
3
15,5
10,0
7,8
5,4
5,0
034-03
SL.34.00.03
4
21,1
14,7
8,9
6,3
6,3
034-04
SL.34.00.04
5
24,4
18,0
11,4
8,0
8,0
034-05
SL.34.00.05
6
30,2
22,2
15,8
9,6
10,9
034-06
SL.34.00.06
7
33,9
25,1
16,0
11,1
10,9
034-07
SL.34.00.07
8
37,0
27,4
19,2
13,7
12,5
034-08
SL.34.00.08
10
39,7
29,4
22,6
13,7
15,6
034-10
SL.34.00.10
12
46,0
33,3
25,5
19,4
18,5
034-12
SL.34.00.12
14
54,0
38,1
31,5
20,4
21,5
034-14
SL.34.00.14
16
57,5
40,0
33,6
20,4
25,0
034-16-1
SL.34.00.16
19
73,8
50,0
40,8
27,8
27,0
034-19
SL.34.00.19
22
152,4
60,3
57,1
34,9
33,0
034-22
SL.34.00.22
26
152,4
60,3
57,1
34,9
33,0
034-26
SL.34.00.25
Ensure former component sits in bottom
of end fitting. Screw socket assembly and
tighten with spanners. The assembly
is not complete.
TIP: Undue force is not required
to terminate the wire.
157
Swageless Studs Stainless Steel AISI 316
Swageless Cones and Formers
Swageless Stud Terminal including 1 x 19 Cone
ø
A
B
Wire in mm
1 x 19 Cone
C
Product
UNF
Code
Ref. No.
Compacted Strand Cone
Ref. No.
ø
Product
Wire in mm
Code
3
126-03
SL.12.60.03
3
✸154-03
4
126-04
SL.12.60.04
4
✸154-04
5
126-05
SL.12.60.05
5
6
126-06
SL.12.60.06
7
126-07
SL.12.60.07
8
126-08
10
12
7 Strand Cone
Ref. No.
Ref. No.
ø
Product
Wire in mm
Code
✸SL.15.40.03
3
127-03
SL.12.70.03
5
✸SL.15.40.04
4
127-04
SL.12.70.04
5
154-05
SL.15.40.05
5
127-05
SL.12.70.05
5
6
154-06
SL.15.40.06
6
127-06
SL.12.70.06
5
7
154-07
SL.15.40.07
7
127-07
SL.12.70.07
5
SL.12.60.08
8
154-08
SL.15.40.08
8
127-08
SL.12.70.08
2
126-10
SL.12.60.10
10
154-10
SL.15.40.10
10
127-10
SL.12.70.10
2
126-12
SL.12.60.12
12
154-12
SL.15.40.12
12
127-12
SL.12.70.12
1
14
126-14
SL.12.60.14
14
✸✸154-14
✸✸SL.15.40.14
14
127-14
SL.12.70.14
1
16
126-16
SL.12.60.16
16
✸✸154-16
✸✸SL.15.40.16
16
127-16
SL.12.70.16
1
19
126-19
SL.12.60.19
19
154-19
SL.15.40.19
-
-
-
-
22
126-22
SL.12.60.22
-
-
-
-
-
-
-
26
126-25
SL.12.60.25
-
-
-
-
-
-
-
ø
Product
Wire in mm
Code
Min.
Packing
Right Hand Thread
3
62
56
1/4”
036-03
SL.36.01.03
4
62
56
1/4”
036-04-1/4
SL.36.01.04
4
64
59
5/16’
036-04
SL.36.02.04
5
65
59
5/16’
036-05-5/16
SL.36.02.05
5
78
67
3/8’
036-05
SL.36.03.05
6
84
67
3/8”
036-06-3/8
SL.36.03.06
6
93
75
7/16”
036-06
SL.36.04.06
7
95
75
7/16”
036-07-7/16
SL.36.04.07
7
97
81
1/2”
036-07
SL.36.05.07
8
98
81
1/2”
036-08
SL.36.05.08
8
110
95
5/8”
036-08-5/8
SL.36.06.08
10
111
95
5/8”
036-10
SL.36.06.10
12
139
124
3/4”
036-12
SL.36.07.12
14
170
140
7/8”
036-14
SL.36.08.14
16
172
140
1”
036-16
SL.36.09.16
19
205
171
1 1/8”
036-19
SL.36.10.19
22
281
227
1 1/4”
036-22
SL.36.11.22
26
297
232
1 3/8”
036-25
SL.36.12.25
✸ = for rope construction 1 x 7
✸✸ = for rope construction 1 x 25
■ 14 and 16 mm diam. compacted construction 1 x 36 needs special cones
■ When mounting on Compacted strand use lefthanded rope (easier to mount)
Formers
Swageless Stud Terminal including 1 x 19 Cone
ø
A
B
Wire in mm
C
Product
Metric Thread
Code
Ref. No.
ø
Product
Wire in mm
Code
Ref. No.
Min.
Packing
Right Hand Thread
3
62
56
M6
036-03-M6R
SL.36.01.03M
3
115-03
SL.11.50.03
5
4
62
56
M6
036-04-M6R
SL.36.01.04M
4
115-04
SL.11.50.04
5
4
64
59
M8
036-04-M8R
SL.36.02.04M
5
115-05
SL.11.50.05
5
5
65
59
M8
036-05-M8R
SL.36.02.05M
6
115-06
SL.11.50.06
5
5
78
67
M 10
036-05-M10R
SL.36.03.05M
7
115-07
SL.11.50.07
5
6
84
67
M 10
036-06-M10R
SL.36.03.06M
8
115-08
SL.11.50.08
2
6
93
75
M 12
036-06-M12R
SL.36.04.06M
10
115-10
SL.11.50.10
2
7
97
81
M 12
036-07-M12R
SL.36.04.07M
12
115-12
SL.11.50.12
1
14
115-14
SL.11.50.14
1
8
98
81
M 12
036-08-M12R
SL.36.05.07M
8
110
95
M 16
036-08-M16R
SL.36.05.08M
16
115-16
SL.11.50.16
1
10
111
95
M 16
036-10-M16R
SL.36.06.08M
19
115-19
SL.11.50.19
1
10
129
124
M 20
036-10-M20R
SL.36.06.10M
22
115-22
SL.11.50.22
1
26
115-26
SL.11.50.26
1
12
139
124
M 20
036-12-M20R
SL.36.07.12M
14
170
140
M 22
036-14-M22R
SL.36.08.14M
16
172
140
M 24
036-16-M24R
SL.36.09.16M
19
205
171
M 27
036-19-M27R
SL.36.10.19M
22
281
227
M 30
036-22-M30R
SL.36.11.22M
26
297
232
M 36
036-25-M36R
SL.36.12.25M
Suitable for use with all wire constructions.
■ Suffix L behind Ref. No. for lefthanded thread.
158
159
Swage Eye and Forks Stainless Steel AISI 316
Sava Ball and Shank | Double Shank Ball | Plain Ball Stainless Steel AISI 304
Sava Swage MS-20668 Eye Stainless Steel AISI 316
For cable
C
AS
D
Sava Swage Single Shank Ball Stainless Steel AISI 304
LS
J
U
Sava Part No.
Ref. No.
B
A
For cable
C
inch
Sava
Ref. No.
Part No.
Approx. mm
mm
inch
mm
1/16
1,5
3,50
13,28
4,83
2,24
45,95
9,12
MS-20668-2X
S206.68.02
1/16
1,5
2,84
4,83
3,96
MS20.664.C2
S000.51.0S
3/32
2,5
4,83
17,96
4,83
2,62
54,86
11,13
MS-20668-3X
S206.68.03
3/32
2,5
3,36
6,43
5,94
MS20.664.C3
S000.51.5S
1/8
3,0
5,56
18,75
4,83
4,83
65,86
12,70
MS-20668-4X
S206.68.04
1/8
3,0
4,83
8,00
7,95
MS20.664.C4
S000.52.0S
5/32
4,0
6,35
21,11
6,35
5,00
76,94
16,25
MS-20668-5X
S206.68.05
5/32
4,0
5,64
9,63
9,93
MS20.664.C5
S000.52.2S
3/16
5,0
7,95
22,94
7,95
6,48
80,95
19,84
MS-20668-6X
S206.68.06
3/16
5,0
6,48
11,23
11,94
MS20.664.C6
S000.52.5S
7/32
5,5
9,52
25,58
7,95
7,39
93,42
20,65
MS-20668-7X
S206.68.07
1/4
6,0
8,84
14,40
15,87
MS20.664.C8
S000.53.0S
1/4
6,0
11,13
28,78
9,52
7,80
103,17
24,59
MS-20668-8X
S206.68.08
9/32
7,0
9,70
16,05
19,05
MS20.664.C9
S000.53.2S
9/32
7,0
12,70
31,93
11,12
8,18
114,60
28,17
MS-20668-9X
S206.68.09
5/16
8,0
10,49
17,63
20,57
MS20.664.C10
S000.53.5S
5/16
8,0
14,30
34,87
11,12
8,71
126,21
30,94
MS-20668-10X
S206.68.10
3/8
10,0
15,88
42,87
12,70
9,53
151,59
38,10
MS-20668-12X
S206.68.12
7/16
11,0
17,48
49,99
14,27
9,53
174,42
44,45
MS-20668-14X
S206.68.11
1/2
12,0
19,05
53,72
15,88
11,89
200,30
47,63
MS-20668-16X
S206.68.12
■ Sava Swage Terminals are being used on aircraft cables and starboat rigging.
■ AS and LS is size after swaging
General Notes:
Dimensions shown are after swaging.
Strength - generate full rated breaking strength
of cable.
■ Sava Ball and Shank Terminals are being used as topslot terminal on some one design class boats and stearing cables on
machines like flight simulators
Sava Swage Double Shank Ball Stainless Steel AISI 304
B
A
For cable
C
Sava
Ref. No.
Part No.
inch
Sava Swage MS-20667 Forks Stainless Steel AISI 316
For cable
AS
D
F
G
LS
U
Sava PART No.
Ref. No.
Approx. mm
inch
mm
1/16
1,5
3,50
4,83
5,54
2,36
12,70
44,45
8,74
MS-20667-2X
S206.67.02
3/32
2,5
4,83
4,83
6,45
2,74
17,02
55,32
11,12
MS-20667-3X
S206.67.03
1/8
3,0
5,56
4,83
9,73
4,95
18,67
66,29
13,89
MS-20667-4X
S206.67.04
5/32
4,0
6,35
6,35
10,31
5,13
20,32
76,20
17,47
MS-20667-5X
S206.67.05
3/16
5,0
7,95
7,95
13,79
6,60
22,35
82,30
19,84
MS-20667-6X
S206.67.06
7/32
5,5
9,52
7,95
15,87
7,52
24,64
94,99
23,01
MS-20667-7X
S206.67.07
1/4
6,0
11,13
9,52
17,47
7,95
27,18
104,14
24,61
MS-20667-8X
S206.67.08
9/32
7,0
12,70
11,12
18,26
8,31
29,72
113,79
29,36
MS-20667-9X
S206.67.09
5/16
8,0
14,30
11,12
19,43
8,84
32,21
123,44
32,13
MS-20667-10X
S206.67.10
3/8
10,0
15,88
12,70
21,08
9,65
38,73
145,60
38,10
MS-20667-12X
S206.67.12
7/16
11,0
17,48
14,27
21,08
9,65
45,11
174,42
-
MS-20667-14X
S206.67.11
1/2
12,0
19,05
15,87
26,29
12,01
48,34
200,30
-
MS-20667-16X
S206.67.12
■ AS and LS is size after swaging
1,5
2,84
4,83
3,96
MS20.663.C2
S000.51.0D
3/32
2,5
3,36
6,43
5,94
MS20.663.C3
S000.51.5D
1/8
3,0
4,83
8,00
7,95
MS20.663.C4
S000.52.0D
5/32
4,0
5,64
9,63
9,93
MS20.663.C5
S000.52.2D
3/16
5,0
6,48
11,23
11,94
MS20.663.C6
S000.52.5D
1/4
6,0
8,84
14,40
15,87
MS20.663.C8
S000.53.0D
9/32
7,0
9,70
16,05
19,05
MS20.663.C9
S000.53.2D
5/16
8,0
10,49
17,63
20,57
MS20.663.C10
S000.53.5D
1/16
H
mm
General Notes:
Dimensions shown are after swaging.
Strength - generate full rated breaking strength
of cable.
Sava Swage Plain Ball Stainless Steel AISI 304
For cable
F
Sava
Ref. No.
Part No.
inch
mm
3/32
2,5
6,43
BA3-3
SSBA33
1/8
3,0
8,00
BA3-4
SSBA34
5/32
4,0
9,63
BA3-5
SSBA35
3/16
5,0
11,23
BA3-6
SSBA36
General Notes:
Dimensions shown are after swaging.
160
161
Guardrail Stanchions | Guardrail Fittings | Winches & Ratches
Yellow Rose
162
163
Stainless Steel Stanchions
Stainless Steel Stanchion Bases
Stainless Steel Stanchion Bases
Stainless Steel Stanchions
■ stainless steel AISI 316
■ drilled for 6 mm diameter bolts
■ high quality polished stainless steel AISI 316
■ tube 25 mm outside diameter
■ stainless steel ferrule fitted in lower hole on
■ for stanchions 25 mm outside diameter
■ the bottom hole (to fix into base) is drilled 8 mm
2- and 3-hole stanchions to prevent chafe
Base with square deckplate
Description
Degrees
Ref. No.
tilted
85°
HYE4.21.85
straight
90°
HYE4.21.90
C
diameter and 35 mm from the bottom, square
to the guardrail hole(s)
This is not binding.
On request we can drill this hole deviated.
(Please ask for quantities and prices)
■ by using aluminium stanchion bases,
stanchions are available with plastic socket to
reduce (or prevent as far as possible) a galvanic
action between the different metals.
(Please ask us for quantities and prices)
■ tapered tube
■ solid stainless steel shaped plug welded at top
end, drilled for guardrail
■ by using a stainless pin instead of stanchion
base we can make the stanchion fit on the deck
pin (please ask for quantity and prices)
D
B
A
A
E
Base with tri-angle deckplate
Description
Degrees
Ref. No.
tilted
85°
HYE4.22.85
straight
90°
HYE4.22.90
dim A
dim B
dim C
dim D
dim E
Min.
Ref. No.
in mm
in mm
in mm
in mm
in mm
Packing
= Option 1
450
-
-
-
-
12
HYE1.64.51
450
225
-
-
-
12
HYE1.64.52
500
-
-
-
-
12
HYE1.65.01
500
250
-
-
-
12
HYE1.65.02
550
275
-
-
-
12
HYE1.65.52
610
305
-
-
-
12
HYE1.66.12
610
305
-
-
-
4
HYE1.66.12R
630
300
-
-
-
12
HYE1.66.32
680
300
-
-
-
12
HYE1.66.82
680
-
225
225
225
12
HYE1.66.83
750
360
-
-
-
12
HYE1.67.52
750
-
250
250
250
12
HYE1.67.53
Double baled base
164
Description
Degrees
Ref. No.
tilted
85°
HYE4.23.85
straight
90°
HYE4.23.90
■ stanchion with roller
■ hole diam 10 mm
■ roller diam 50 mm
■ roller thicknes 8 mm
■ roller from black delrin
■ ref. no. HYE16612R
165
Guard Rail Pelican Hooks
Guard Rail Adjusters
A new concept in Guard Rail adjustment. The design of the Guard Rail Adjuster does away with conventional Turnbuckles and is tested
stronger than the wire rope.
Stainless Steel AISI 316 Guard Rail Pelican Hook
D
L
A
right
Its design provides weight and length reduction on conventional Turnbuckles without compromise on quality or strength.
■ Manufactured from 316 stainless steel.
■ Available in sizes from 4 mm, 5 mm and 6 mm wire ropes.
Weight
Ref. No.
in kg/100 pcs.
M6
75
12
7,0
M8
100
14
13,6
M 12
150
24
52,5
IL24.30.06
IL24.30.08
IL24.30.12
Guard Rail Adjuster
B
D
C
P
ø
Fully
Fully
Wire in mm
Open
Closed
in mm
in mm
4
160
125
14,7
8,8
11,1
8,0
5
160
125
14,7
8,8
11,1
8,0
6
160
125
14,7
8,8
11,1
8,0
✸
Min.
weight
Product
Packing pcs.
in gr
Code
1
11,0
G28-04
1
11,5
G28-05
100
12,0
-
Ref. No.
SLG2.82.04
SLG2.82.05
✸SLG2.82.06S
To be swaged with 5,5 mm dies.
Stainless Steel AISI 316 Guard Rail Pelican Hook M8
D
L
A
right
M8
Weight
Ref. No.
in kg/100 pcs.
100
12
L
A
12,0
BW45.00.08
Weight
Ref. No.
Guard Rail Adjuster
L1
Ref. No.
ø
G
Wire in mm
Metric
4
M6
242
180
92
4,4
8
7,50
5,0
8,7
BW12.04.06
4
M8
275
199
112
4,4
10
7,50
6,0
13,0
BW12.04.08
5
M8
281
205
112
5,3
10
9,00
6,0
13,2
BW12.05.08
5
M 10
312
228
120
5,3
11
9,00
8,0
22,5
BW12.05.10
6
M 10
327
243
120
6,5
11
12,58
8,0
25,6
BW12.06.10
L2
L3
A1
A2
D1
D2
Weight
in kg/100 pcs.
Stainless Steel AISI 316 Guard Rail Pelican Hook M8
D
right
M8
in kg/100 pcs.
100
16
10,6
W28.31.000
D
166
167
Swage Studs | Guardrail Eyes | Guardrail Studs
Stainless Steel Winches
Long Swage Stud Including Nut for Pelican Hooks Stainless Steel AISI 316
L
G
ø
L1
Stainless steel selfbreaking hoisting winches
L2
D
K
Wire Size
Weight
Ref. No.
in kg/100 pcs.
right
4
M6
102
48
41
6
7,50
2,4
BW90.04.06.40N
4
M8
112
50
46
6
7,50
3,0
BW90.04.08N
5
M8
122
50
58
8
9,00
4,0
BW90.05.08N
6
M8
135
50
60
11
12,50
8,0
BW90.06.08.57N
6
M 12
162
80
65
-
12,50
11,0
BW90.06.12N
7
M 12
170
80
70
-
14,20
13,3
BW90.07.12N
8
M 12
185
80
83
-
16,00
19,2
BW90.08.12N
The safety principle featured by this hoisting winches precludes loads from
slipping during hoisting and securing operations.
Confirms to German VBG accident prevention regulations and approved
by TÜV Rhineland, certification N S9310897. Safety factor for haulage 1:5.
Model 4 AFM
Haulage power
450 kg
Transmission ratio
1 : 2,57
Ref. No.
Hoisting power
80 kg
Diam drum
27 mm
04AF.MR.GS
Dimensions L x W x H
125 x 105 x 95 mm
Drum capacity
8 mtr wire rope
Weight
2,1 kg
diam 3 mm
Model 4 AF
Guard Rail Single Eye M8 Stainless Steel AISI 316
D
L
B
C
Ref. No.
Weight
right
Haulage power
500 kg
Transmission ratio
1 : 2,57
Ref. No.
Hoisting power
180 kg
Diam drum
36 mm
04AF.LR.GS
Dimensions L x W x H
125 x 145 x 95 mm
Drum capacity
10 mtr wire rope
Weight
2,5 kg
diam 4 mm
in kg/100 pcs.
M8
20
15
6,5
IL24.40.08
3,0
Model 6 AF
Haulage power
750 kg
Transmission ratio
1 : 3,5
Ref. No.
Hoisting power
240 kg
Diam drum
45 mm
06AF.LR.GS
Dimensions L x W x H
160 x 155 x 130 mm
Drum capacity
13 mtr wire rope
Weight
3,6 kg
diam 5 mm
Model 8 AF
Guard Rail Double Eye M8 Stainless Steel AISI 316
D
L
B
C
Ref. No.
Weight
right
Haulage power
850 kg
Transmission ratio
1 : 4,85
Ref. No.
Hoisting power
270 kg
Diam drum
54 mm
08AF.LR.GS
Dimensions L x W x H
200 x 155 x 170 mm
Drum capacity
16 mtr wire rope
Weight
5,5 kg
diam 6 mm
in kg/100 pcs.
M8
20
37
6,5
IL24.50.08
6,0
Model 12 AF
Haulage power
1500 kg
Transmission ratio
1 : 9,71
Ref. No.
Hoisting power
490 kg
Diam drum
63 mm
12AF.LR.GS
Dimensions L x W x H
210 x 190 x 170 mm
Drum capacity
10 mtr wire rope
Weight
7,5 kg
diam 7 mm
Guardrail Short Swage Stud Stainless Steel AISI 316
ø
G
L
L1
L2
K
D
Wire Size
168
Weight
Ref. No.
in kg/100 pcs.
right
4
M8
71
12
41
6
7,50
2,0
BW51.04.08
5
M8
80
12
52
8
9,00
3,0
BW51.05.08
6
M8
93
12
65
11
12,50
6,0
BW51.06.08
169
Stainless Steel Winches
Stainless Steel Ratches | Polyester Webbing | Hooks for Webbing
Stainless steel selfbreaking hoisting winches for wall mounting
The 25 mm, 35 and 50 mm ratches are manufactured from stainless steel AISI 316.
Model WE300
Hoisting power
300 kg
Transmission ratio
1 : 3,1
Diam drum
60 mm
Drum capacity
29 mtr wire rope diam 4 mm
Weight
5 kg
Ref. No.
7622.13.00
Stainless Steel Ratches
Model WE500
Hoisting power
500 kg
Transmission ratio
1 : 4,5
Diam drum
60 mm
Drum capacity
22 mtr wire rope diam 5 mm
Weight
5 kg
Ref. No.
7622.15.00
Ref. No.
Webbing Size
Lashing Capacity
in mm
daN
25
350
4SS0.00.25L
25
750
4SS0.00.25
35
1000
4SS0.00.35
50
1500
4SS0.00.50
■ Safety factor 1:2 according to EN 12195-2
Stainless steel selfbreaking hoisting winches for table mounting
Model KE300
Hoisting power
300 kg
Transmission ratio
1 : 3,1
Diam drum
60 mm
Drum capacity
29 mtr wire rope diam 4 mm
Weight
5 kg
Ref. No.
7624.13.00
Polyester Webbing
Lashing Capacity
in mm
daN
Colors
25
750
white - black - grey - orange - yellow - blue - green
35
1000
white - black - grey - orange - yellow - blue - green
50
2000
white - black - grey - orange - yellow - blue - green
■ Safety factor 1:3
■ We can offer the stitching.
Model KE500
Hoisting power
500 kg
Transmission ratio
1 : 4,5
Diam drum
60 mm
Drum capacity
22 mtr wire rope diam 5 mm
Weight
5 kg
Ref. No.
7624.15.00
Stainless Steel Hooks for Webbing
Webbing Size
Lashing Capacity
in mm
daN
Ref. No.
25
400
4SS0.01.25
35
1000
4SS0.01.35
50
2000
4SS0.01.50
■ Safety factor 1:2
WE Type
170
KE Type
171
Polyester Webbing Slings
■
■
■
■
■
■
■
■
Sofety factor 1:7
Available in all lenghts
Available with protected soft eyes
Available with triangles
Available with protection covers
Available with lead weight
Available with unique traceability number
Available with CE certificate on request
Polyester Flat Webbing Slings. (according NEN-EN 1492-1)
Product code
W.L.L.
Colour
(straight)
Webbing
width/mm
PDH30 or PEH30
1
Violet
30
PDH60 or PEH60
2
Green
60
PDH90 or PEH90
3
Yellow
90
PDH120 or PEH120
4
Grey
120
PDH150 or PEH150
5
Red
150
PDH180 or PEH180
6
Brown
180
PDH240 or PEH240
8
Blue
240
PDH300 or PEH300
10
Orange
300
■ Bigger sizes on request
Polyester Round Slings. (according NEN-EN 1492-2)
Product code
W.L.L.
Colour
(straight)
Webbing
width/mm
PEH10 or DREH10
1
Violet
42 or 45
PEH20 or DREH20
2
Green
45 or 50
PEH30 or DREH30
3
Yellow
50 or 55
PEH40 or DREH40
4
Grey
65 or 70
PEH50 or DREH50
5
Red
70 or 75
PEH60 or DREH60
6
Brown
80 or 85
PEH80 or DREH80
8
Blue
90 or 95
PEH100 or DREH100
10
Orange
100 or 110
■ Bigger sizes on request
Application
■
■
■
■
■
-40º C tot 100º C (this range can be negatively influenced bij chemicals
Avoid influences of ultra-violet radiation
Avoid contact with alkalic materials
Ice crystals may damage the webbing materials
Webbing can be dried within the temperature range as mentioned above
Inspection
■
■
■
■
■
Damaged or misshapen lifting eyes
Damaged stitching
Cuts and surface chafes
Heat or friction damage
Existence and legibility of the label
Pieter Jan Postma
172
Finn Dingy NED 842
173
Chain | Hooks | Master Links | Chain Slings | Wire Rope Slings
Chains Stainless Steel AISI 316
Stainless Steel Short Link Chain Acc. DIN 766
ø
Inside
W.L.L. in kg
m.b.l.
Weight
Dimension
safety
in kg
in kg/mtr
Ref. No.
factor 1:5
■
■
■
●
■
2
12,0 x 4,0
25
125
0,07
● 6011.00.02
3
15,7 x 5,0
56
280
0,16
● 6011.00.03
4
16,0 x 6,0
120
600
0,32
6011.00.04
5
18,5 x 7,0
200
1000
0,50
6011.00.05
6
18,5 x 8,0
280
1400
0,75
6011.00.06
7
22,0 x 9,0
360
1800
1,00
6011.00.07
8
24,0 x 10,0
500
2500
1,35
6011.00.08
10
28,0 x 14,0
800
4000
2,25
6011.00.10
13
36,0 x 18,0
1280
6400
3,80
6011.00.13
Material Stainless Steel AISI 316.
Far East production.
Standard Packing: Bundles off 50 mtr.
Bundles off 100 mtr.
AISI 304 on request.
Stainless Steel Long Link Chain Acc. DIN 763
ø
■
■
■
■
●
■
174
Ref. No.
Inside
m.b.l.
Weight
Dimension
in kg
in kg/mtr
2
22 x 4,0
125
0,06
● 6021.00.02
3
26 x 6,0
280
0,15
● 6021.00.03
4
32 x 8,0
580
0,27
6021.00.04
5
35 x 10,0
1000
0,43
6021.00.05
6
42 x 12,0
1250
0,63
6021.00.06
7
49 x 14,0
1750
0,86
6021.00.07
8
52 x 16,0
2450
1,10
6021.00.08
10
65 x 20,0
3800
1,75
6021.00.10
13
82 x 24,0
6000
2,95
6021.00.13
Material Stainless Steel AISI 316.
Far East production.
May not be used for lifting.
Standard Packing: Bundles off 50 mtr.
Similar to DIN5685 and bundles off 100 mtr.
AISI 304 on request.
175
Hooks
Chains Stainless Steel AISI 316 L Grade 50
Stainless Steel AISI 316 Casted Swivel Hook With Safety Latch
Stainless Steel Chain AISI 316 L
Similar to DIN 766 A Grade 50
Dimensions in mm
d
■
■
■
■
■
■
■
■
t
b1 min.
b2 max.
Weight
W.L.L. in kg
Breaking Load
kg
factor 1:4
kN
Ref. No.
6
18,5
7,2
20,8
0,75
750
30,0
6011.00.06A
8
24,0
9,6
27,2
1,35
1250
50,0
6011.00.08A
10
28,0
12,0
36,0
2,25
2000
80,0
6011.00.10A
13
36,0
15,6
47,0
3,90
3000
125,0
6011.00.13A
Chain is tested.
Chain is calibrated.
Standard Packing: Bundles off 50 mtr.
Longer lengths on request.
European production.
In AISI 304 L on request.
Ideal as high load anchorchain.
Certificates available.
E
C
Size
in inch
A
B
C
D
L
L1
E
W.L.L. in kg
weight
safety factor 1:5
in kg/100 pcs.
Ref. No.
1/4
21
12
21
7,0
119
22
16
300
19,0
5340.00.03
5/16
28
14
27
8,5
141
28
19
500
33,0
5340.00.05
3/8
28
16
32
10,0
170
28
20
700
53,0
5340.00.07
1/2
32
20
32
13,0
199
36
30
1000
104,0
5340.00.10
5/8
in preparation
1250
5340.00.12
3/4
in preparation
1500
5340.00.15
E-size is between open safety latch and hook.
Stainless Steel AISI 316 Casted Eye Hook With Safety Latch
Size
in inch
B
C
E
R
W.L.L. in kg
weight
safety factor 1:5
in kg/100 pcs.
1/4
12,5
20
15,0
50
300
16,5
5/16
16,0
30
16,5
57
500
28,5
3/8
18,0
32
22,0
65
700
41,5
1/2
23,5
32
30,0
85
1000
94,5
Ref. No.
IL22.11.10
IL22.11.20
IL22.11.30
IL22.11.50
C
E-size is between open safety latch and hook.
Stainless Steel AISI 316 Casted Fork Hook With Safety Latch
Size
in inch
B
C
E
P
R
W.L.L. in kg
weight
safety factor 1:5
in kg/100 pcs.
1/4
10,5
20
13,0
8,5
65
300
17,8
5/16
13,0
26
16,0
10,5
69
500
31,5
3/8
15,0
30
21,0
11,9
83
700
46,5
1/2
19,0
34
30,0
16,0
101
1000
116,0
Ref. No.
IL22.12.10
IL22.12.20
IL22.12.30
IL22.12.50
C
E-size is between open safety latch and hook.
Stainless Steel AISI 316 Casted Grab Hook
Size
in inch
Breaking Load
B
E
R
in kg
weight
Ref. No.
in kg/100 pcs.
1/4
1500
12,7
8,2
38
12,0
5/16
2500
14,0
10,7
42
18,5
3/8
3500
19,0
12,3
48
32,5
1/2
5000
22,0
15,8
60
48,5
IL22.13.10
IL22.13.20
IL22.13.30
IL22.13.50
E-size is between open safety latch and hook.
176
177
Hooks and Underblocks
Stainless Steel Lifting System Grade 50
“SEALIFT”
Stainless Steel Chains Grade 50
Swivelhooks With Springlatch Stainless Steel AISI 316
W.L.L.
A
d
D
C
I
J
W.L.L. in kg
Weight
Vertical
in kg/mtr
M
Ref. No.
1:4
in kg
■
■
■
■
b
t
4
16
13,6
300
0,32
6000.E0.04
5
15
18,5
500
0,54
6000.E0.05
18
22,2
750
0,80
6000.E0.06
500
160
10
82
24
20
25
6
750
185
13
102
27
23
31
7
21
25,9
1000
1,10
6000.E0.07
1000
228
16
115
36
30
40
8
24
29,6
1250
1,40
6000.E0.08
30
37,0
2000
2,20
6000.E0.10
1500
245
16
120
38
30
40
10
2000
275
19
135
45
34
52
13
39
48,1
3200
3,80
6000.E0.13
3200
310
22
150
45
38
52
16
48
59,2
5000
5,70
6000.E0.16
18
54
64,8
6300
7,30
6000.E0.18
5000
360
25
185
8000
410
30
200
Also available as shankhook.
Hooks and blocks high gloss polished.
Dimensions in mm. Safety factor 5:1
Certificates available.
52
42
70
80
48
70
■
■
■
■
■
Material Stainless Steel AISI 316 L.
Round link chains grade 50 similar DIN 5687-1 are non-calibrated, tested chains, which are used as chain-slings.
Round link chains of stainless steel are mainly used in the Food Industry for example:
creameries, dairies, bakeries and slaughter-houses, etc.
And in the Chemical Industry for example: dye works, pickling and hardening plants.
Factor 1:4
Stainless Steel Master Links Grade 50
■
■
■
Material Stainless Steel AISI 316 L.
All master links are equiped with flattened section for use in combination with connection
(e.g.: clevis shackle).
Factor 1:4
For One- and Two-Leg Slings Type NAF
Dimensions
W.L.L. in kg
W.L.L. 2-leg at angle
weight
in mm
vertical
in kg
dxtxb
1:4
to the vertical in kg
0-45o
6
13 x 110 x 60
1000
1000
0,34
5020.E0.07
8
16 x 110 x 60
1250
1400
0,53
5020.E0.12
10
18 x 135 x 75
2000
1700
0,80
5020.E0.20
13
22 x 160 x 90
3200
2800
1,50
5020.E0.32
16
26 x 180 x 100
5000
4500
2,30
5020.E0.50
16
32 x 200 x 110
7100
7100
3,90
5020.E0.71
18
36 x 260 x 140
8000
9000
6,35
5020.E0.80
Size
Underblocks Stainless Steel AISI 316
We produce Stainless steel underblocks up to SWL = 8000 kg.
Please send your enquiryy with the following details:
W.L.L.
Wire rope diameter
Own weight
so that we can make you an offer.
b
For Three- and Four-Leg Slings Type NATF
b
Size
Dimensions
A in mm
dxtxb
A
B
178
Dimensions W.L.L. at an angle
B in mm to the vertical in kg
d1 x t1 x b1 0-45o 45-60o
weight
Ref. No.
Ref. No.
in kg
6
18 x 135 x 75
13 x 54 x 25
2100
1500
1,20
5040.E0.16
8
22 x 160 x 90
16 x 70 x 34
2650
1800
2,30
5040.E0.26
10
26 x 180 x 100 18 x 85 x 40
4250
3000
3,56
5040.E0.42
13
32 x 200 x 110 22 x 115 x 50
6700
4750
6,05
5040.E0.67
16
36 x 260 x 140 26 x 140 x 65
10000
7500
10,00
5040.E1.00
179
Stainless Steel Lifting System Grade 50
Stainless Steel Lifting System Grade 50
Stainless Steel Clevis Hooks Grade 50 With Safety Latch Type NGHF
Size
Stainless Steel Shackle Grade 50 Type NSA
t
g
h
W.L.L.
weight
in kg
in kg
Ref. No.
Size
a
d
b
t
W.L.L.
Weight
in kg
in kg
1:4
■
■
■
■
Ref. No.
1:4
6
78
25
22
750
0,40
6550.E0.06
8
97
32
28
1250
0,76
6550.E0.08
10
121
41
34
2000
1,44
6550.E0.10
13
143
48
47
3200
2,60
6550.E0.13
16
180
69
57
5000
4,90
6550.E0.16
Material Stainless Steel AISI 316 L.
These clevis hooks are a very rugged due to special construction with forged integrated safety latch.
The safety latch is very resistant against side shocks. In case of overloading the hook, the latch will
spring off. The peak of the hook prevents inadmissable use with the chains. Due to the construction
of the hook the gap-opening will not be reduced even with the mounted latch.
Factor 1:4
Spare safety latches available.
■ Material Stainless Steel AISI 316.
■ Factor 1:4
■ See page 47 for Industrial D and Bow shackles
NSA04
4
7
6
23
12
300
0,035
5
9
8
24
17
500
0,070
NSA05
6
11
10
35
20
750
0,135
5670.E0.19
8
13
12
42
25
1250
0,220
5670.E0.23
10
18
16
64
32
2000
0,510
5670.E0.31
13
21
19
76
38
3200
0,910
5670.E0.38
16
19
16
64
32
5000
0,550
5670.E0.45
18
22
19
76
38
6300
1,000
5670.E0.53
20
26
22
88
44
9000
1,900
NSA20
Stainless Steel Shortening Link Type NV
Size
a
b
t
b
W.L.L.
Weight
in kg
in kg
Ref. No.
1:4
Stainless Steel Eye Hooks Grade 50 With Safety Latch type NOHF
Size
t
g
h
b
W.L.L.
weight
in kg
in kg
Ref. No.
t
1:4
■
■
■
■
300
0,185
5180.0E.03
22
750
0,350
5180.0E.07
28
1250
0,790
5180.0E.12
37
34
2000
1,370
5180.0E.20
48
45
3200
3,000
5180.0E.32
66
55
51
5000
4,800
5180.0E.50
66
55
51
7000
4,800
5180.0E.70
4
75
20
17
17
6
100
25
25
8
126
32
27
10
160
39
13
190
51
16
230
18
230
Material Stainless Steel AISI 316 L.
With flat section at eye to permit the use of connectors (e.g. clevis shackle).
Factor 1:4
Spare safety latches available.
t
b
a
W.L.L.
weight
in kg
in kg
Ref. No.
180
10
81
750
0,180
6612.E0.06
70
12
94
1250
0,380
6612.E0.08
10
80
15
120
2000
0,710
6612.E0.10
13
91
20
150
3200
1,180
6612.E0.13
16
100
21
175
5000
2,300
6612.E0.16
Ref. No.
a
6
26
20
7
750
0,15
6561.E0.06
8
30
23
9
1250
0,25
6561.E0.08
10
40
28
11
2000
0,40
6561.E0.10
13
48
38
14
3200
0,50
6561.E0.13
16
50
44
17
5000
1,15
6561.E0.16
Material Stainless Steel AISI 316 L.
The clevis shackle can be mounted in master links and eye hooks as a connector to have
a complete chain sling.
Factor 1:4
Stainless Steel Master Links Grade 50 Type NAG
one- and two leg without flattened section
b
1:4
■
■
■
47
8
■ Material Stainless Steel AISI 316.
■ Factor 1:4
Stainless Steel Clevis Shackle Grade 50 type NGS
Size
6
■ Material Stainless Steel AISI 316.
■ Factor 1:4
Dimensions
W.L.L. in kg
W.L.L. 2-leg at angle
Weight
in mm
vertical
in kg
dxtxb
1:4
to the vertical in kg
0-45o
8 x 54 x 30
300
-
0,07
5020.E0.03B
10 x 80 x 50
500
420
0,15
5020.E0.05B
13 x 110 x 60
1000
1000
0,34
5020.E0.10B
16 x 110 x 60
1250
1400
0,53
5020.E0.12B
18 x 135 x 75
2000
1700
0,80
5020.E0.20B
22 x 160 x 90
3200
2800
1,50
5020.E0.32B
26 x 180 x 100
5000
4500
2,30
5020.E0.50B
32 x 200 x 110
7160
7100
3,90
5020.E0.71B
36 x 260 x 140
8000
9000
6,35
5020.E0.80B
181
Stainless Steel Lifting System Grade 50
Stainless Steel Lifting System Grade 50
Stainless Steel Master Links Grade 50 Type NAK
three- and four leg without flattened section
Dimensions
W.L.L. at an angle
weight
in mm
to the vertical in kg
0-45o
45-60o
in kg
dxtxb
A 10 x 80 x 50
Ref. No.
630
450
0,29
5040.E0.06B
1000
750
0,52
5040.E0.10B
Stainless Steel Grade 50 Lifting Chain Slings With Safety Hook
Chain Size
W.L.L. one-leg
in mm
in kg
B 10 x 80 x 50
A 18 x 135 x 75
A
2100
1,20
1500
5040.E0.16B
B 13 x 54 x 25
A 22 x 160 x 90
B
2650
1800
2,30
5040.E0.26B
4250
3000
3,56
5040.E0.42B
6700
4750
6,05
5040.E0.67B
10000
7500
10,00
5040.E1.00B
B 16 x 70 x 34
A 26 x 180 x 100
B 18 x 85 x 40
A 32 x 200 x 110
■
■
■
■
Ref. No.
0-45o
W.L.L. in kg, factor 1:4
Ref. No.
four-leg at an angle of
45-60o
0-45o
45-60o
6
750
6101.0E.06
1000
750
6201.0E.06
1600
1120
6401.0E.06
8
1250
6101.0E.08
1700
1250
6201.0E.08
2650
1800
6401.0E.08
10
2000
6101.0E.10
2800
2000
6201.0E.10
4250
3000
6401.0E.10
13
3200
6101.0E.13
4500
3200
6201.0E.13
6700
4750
6401.0E.13
16
5000
6101.0E.16
7000
5000
6201.0E.16
10000
7500
6401.0E.16
Stainless Steel Grade 50
Chain: Material Werkstoff No. 1.4404 = AISI 316 L.
Fittings: Material Werkstoff No. 1.4404 = AISI 316 L.
All ref. No. are based on 1 mtr length. An extra price per mtr. is going to be charged if longer is required.
B 22 x 115 x 50
A 36 x 260 x 140
W.L.L. in kg, factor 1:4
two-leg at an angle of
factor 1:4
B 8 x 54 x 30
A 13 x 110 x 60
Ref. No.
6201.0E.
two-leg chain sling
with safety hook
6101.0E.
one-leg chain sling
with safety hook
B 26 x 140 x 65
6401.0E.
four-leg chain sling
with safety hook
L
Stainless Steel Grade 50
Pump Lifting Chains
and endless chains
per enquiry
Work load limit
in dependence of chain temperature
W.L.L.
-40°C to +250°C
over 250°C to 350°C*
over 350°C to 450°C
100 %
75 %
50 %
*1.4462 max. 350°C allowed
Corrosion resistance
Corroding agent
Concentration
Stainless Steel Grade 50 Lifting Chain Slings With Master Links
Temperature
1.4307
AISI 304L
1.4401
AISI 316
1.4404
AISI 316L
1.4462
AISI 318LN
Ethanoic acid
CH3COOH
50 %
20°C
0
0
0
0
Fatty acid
C17H33COOH
100 %
<150°C
0
0
0
0
W.L.L. in kg, factor 1:4
Ref. No.
two-leg at an angle of
factor 1:4
0-45o
W.L.L. in kg, factor 1:4
Ref. No.
four-leg at an angle of
45-60o
0-45o
45-60o
6
750
6102.0E.06
1000
750
6202.0E.06
1600
1120
6402.0E.06
8
1250
6102.0E.08
1700
1250
6202.0E.08
2650
1800
6402.0E.08
4250
3000
6402.0E.10
0
3
0
3
0
3
0
3
10
2000
6102.0E.10
2800
2000
6202.0E.10
Gallic acid
C6H2(OH)3COOH
100 %
20°C
0
0
0
0
13
3200
6102.0E.13
4500
3200
6202.0E.13
6700
4750
6402.0E.13
Luric acid
C5H4O4N3
16
5000
6102.0E.16
7000
5000
6202.0E.16
10000
7500
6402.0E.16
aqueous solution
Urea
CO(NH2)2
100 %
20°C
0
0
0
0
Lactic acid
C3H6O3
10 %
20°C
0
0
0
0
110°C
1
0
0
0
0
0
0
0
0
0
20°C
0
0
0
0
1 = slightly affected by erosive
surface corrosion
<70 %
>70 %
20°C
0
1
Nitric acid
HNO3
<66 %
99 %
20°C
0
1
0
2
0
2
0
2
Hydrochloric acid
HCL
0,5 %
2%
20°C
65°C
1L
3
1L
3
1L
3
1L
3
Sulphuric acid
H2SO4
<5 %
10%
60 %
60 %
20°C
20°C
20°C
70°C
1
2
3
3
0
1
2
3
0
1
2
3
0
1
2
3
Tartaric acid
COOH(CHOH)2COOH
50 %
50 %
20°C
boiling
0
2
0
1
0
1
0
1
182
Ref. No.
20°C
20°C
Phosphoric acid
H3PO4
L = pitting corrosion, crevice
corrosion or stress crack
corrosion possible
in kg
100 %
Nitrating acid
20%H2SO4+5% HNO3
3 = non-resistant to erosive
surface corrosion
W.L.L. one-leg
in mm
Fluorine dry
F
wet
0 = resistant to erosive surface
corrosion
2 = low resistance to erosive
surface corrosion
Chain Size
■
■
■
■
Stainless Steel Grade 50
Chain: Material Werkstoff No. 1.4404 = AISI 316 L.
Fittings: Material Werkstoff No. 1.4404 = AISI 316 L.
All ref. No. are based on 1 mtr length.
An extra price per mtr. is going to be charged if longer is required.
6102.0E.
one-leg chain sling
with master link
6202.0E.
two-leg chain sling
with master link
6402.0E.
four-leg chain sling
with master link
L
183
Stainless Steel Lifting Wire Rope Slings
Stainless Steel Lifting Wire Rope Slings
Stainless Steel Lifting Wire Rope Slings
Stainless Steel Lifting Wire Rope Slings
Rope
W.L.L. in kg 1:4
Part No.
Part No.
Part No.
W.L.L. in kg, factor 1:4
Part No.
Rope
W.L.L. in kg 1:4
Part No.
Part No.
W.L.L. in kg, factor 1:4
Part No.
ø
one-leg in kg
1102.0E
1121.0E
1122.0E
two-leg at an angle of
1219.0E
ø
one-leg in kg
1113.0E
1149.0E
Two-leg at an angle of
1226.0E
in mm
■
■
■
■
single direct
0-45o
single direct
in mm
45-60o
0-45o
45-60o
8
600
1102.0E.08
1121.0E.08
1122.0E.08
840
600
1219.0E.08
8
600
1113.0E.08
1149.0E.08
840
600
1226.0E.08
10
1000
1102.0E.10
1121.0E.10
1122.0E.10
1400
1000
1219.0E.10
10
1000
1113.0E.10
1149.0E.10
1400
1000
1226.0E.10
12
1300
1102.0E.12
1121.0E.12
1122.0E.12
1800
1300
1219.0E.12
12
1300
1113.0E.12
1149.0E.12
1800
1300
1226.0E.12
14
1800
1102.0E.14
1121.0E.14
1122.0E.14
2500
1800
1219.0E.14
14
1800
1113.0E.14
1149.0E.14
2500
1800
1226.0E.14
16
2300
1102.0E.16
1121.0E.16
1122.0E.16
3200
2300
1219.0E.16
16
2300
1113.0E.16
1149.0E.16
3200
2300
1226.0E.16
20
3600
1102.0E.20
1121.0E.20
1122.0E.20
5000
3600
1219.0E.20
20
3600
1113.0E.20
1149.0E.20
5000
3600
1226.0E.20
Rope: material AISI 316.
Safety Hook and master links: material AISI 316 L Grade 50.
Rope connection with stainless steel ferrules similar to DIN 3093.
Rope connection with copper ferrules available.
■
■
■
■
■ Higher load capacities on request.
■ All ref. No. are based on 1 mtr length. If longer is required, please mention length L..
1102.0E.
Wire rope sling
with
two soft eyes
1121.0E.
Wire rope sling
with soft eye and
safety hook
1122.0E.
Wire rope sling
with master link
and safety hook
L
L
Rope: material AISI 316
Master links: material AISI 316 L Grade 50
Rope connection with stainless steel ferrules similar to DIN 3093
Rope connection with copper ferrules available.
■ Higher load capacities on request.
■ All ref. No. are based on 1 mtr length. If longer is required, please mention length L.
1219.0E.
Two-leg wire rope
sling with
safety hook
1113.0E.
Wire rope sling
with soft eye
and master link
L
1149.0E.
Wire rope sling
with master links
L
L
1226.0E.
Two-leg wire rope
sling with
master links
L
L
Applications for stainless steel wire rope slings:
❐
❐
❐
❐
❐
❐
❐
❐
❐
Food and beverages industries
Dairies
Abattoirs
Bakeries
Chemical industries
Dye mills
Pickling plants
Hardening shops
Marine
And everywhere where nothing should be allowed to rust.
184
Applications for stainless steel wire rope slings:
❐
❐
❐
❐
❐
❐
❐
❐
❐
Food and beverages industries
Dairies
Abattoirs
Bakeries
Chemical industries
Dye mills
Pickling plants
Hardening shops
Marine
And everywhere where nothing should be allowed to rust.
■ Also available with stainless steel AISI 316 D-shackles with
E-type safety pin instead of lower master link.
185
Stainless Steel Tie Rod Systems
The system
The standard tie bar system comprises of a bar with a left hand and right hand threaded fork at opposite
ends. Once installed the bar can be rotated to expand or contract the fork’s pin centres. Special spanner
flats can be added at the ends of the bars to facilitate rotation. The ADJ value in the table on the next page
details the amount of adjustment at each fork end. Once installed the forks are locked into position by
tightening the tapered locking nuts using a ‘C’ pin spanner. The special tapered locking nuts also hide
excessive bar threads. The forks benefit from ‘Double Headed’ clevis pins which are fastened into position
using a standard ‘Allen’ key.
Stainless Steel Tie Rod Systems
Adjuster Forks
The forks and pins are manufactures from a Duplex grade of stainless steel which offers higher corrosion
resistance and mechanical properties than marine grade 316 (EN 10088 1 4401). Designed in accordance
with BS 5950-1:2000 and EN 1993-1-8:2005. All components are produced using the latest technology in
CNC equipment. They are manufactured in accordance with our quality systems and finished to a N4 standard (240 grit satin). Bar lengths are available up to 6m. Lengths exceeding 6m are also available by utilising
a bar coupler.
Thread
PIN
Metric
P
in mm
T
C
F
ADJ
OD
L
Yield Load
Ultimate Load
Part
0.2%
kN*
Code
in mm
in mm
in mm
in mm
in mm
in mm
kN*
M10 x 1.50
10
10
20
11,2
20
25
68,7
26,1
40,6
SBFM.10
M12 x 1.75
12
12
24
13,8
24
32
82,8
37,8
58,8
SBFM.12
M16 x 2.00
16
15
32
18,4
32
40
109,9
70,7
109,9
SBFM.16
M20 x 2.50
20
19
40
23,0
40
50
137,5
110,3
171,5
SBFM.20
M24 x 3.00
24
24
48
27,6
48
60
165,6
158,9
247,1
SBFM.24
M27 x 3.00
27
26
54
31,1
54
70
185,9
206,6
321,3
SBFM.27
M30 x 3.50
30
29
60
34,5
60
75
206,5
252,6
485,8
SBFM.30
M33 x 3.50
33
32
66
38,0
66
80
227,3
312,3
571,9
SBFM.33
M36 x 4.00
36
34
72
41,4
72
90
247,4
367,7
638,2
SBFM.36
M39 x 4.00
39
38
78
44,9
78
100
268,7
439,2
784,7
SBFM.39
* In accordance with BS5950-1:2000 and EN 1993-1-8:2005.
Note: If the forks are at maximum adjustment then half a diameter of thread will be visible after the Taper
Nut has been fully tightened.
■ Sizes above M39 also available - please contact us for further details.
■ Suffix partcode with R or L for right or left handed thread.
The Applications
Modern developments in construction technology have focused on the production of light sturdy structures.
Bar-braced structures are a key part of current systems and can be expected to further increase in
relevence. It is our policy to be at the forefront of developing such eonomic and versatile technologies. By
combining an understanding of the relevant aesthetic and scientific principles, we are able to provide
elegant yet reliable solutions to tension member problems. The system is made from high grade materials
resulting in extra strength and at the same time demonstrates design features such as the tapered locking
nut which hides bar threads thus providing a clean cosmetic appearance.
186
187
Stainless Steel Tie Rod Systems
Bars
The range of tie bars are manufactured from a high quality stainless steel grade 316 with rolled threads to
BS3643. Manufactured to order and available up to 6m lengths. Longer lengths are available by using bar
couplers.
Thread
Ultimate
Yield
Metric
Stress kN*
Stress kN*
Stress
Area mm2
Yield
Ultimate
Part
Load kN*
Load kN*
Code
M10 x 1.50
700
450
58
26,1
40,6
SBM.10
M12 x 1.75
700
450
84
37,8
58,8
SBM.12
M16 x 2.00
700
450
157
70,7
109,9
SBM.16
M20 x 2.50
700
450
245
110,3
171,5
SBM.20
M24 x 3.00
700
450
353
158,9
247,1
SBM.24
M27 x 3.00
700
450
459
206,6
321,3
SBM.27
M30 x 3.50
700
450
561
252,6
485,8
SBM.30
M33 x 3.50
700
450
694
312,3
571,9
SBM.33
M36 x 4.00
700
450
817
367,7
638,2
SBM.36
M39 x 4.00
700
450
976
439,2
784,7
SBM.39
* In accordance with BS5950-1:2000 and EN 1993-1-8:2005.
■ Bars are also available from "NITRONIC 50" for higher breaking loads.
Bars are generally used on:
■ Membrane strucures
■ Lightweight steel structures
■ Footbridges
■ Glass facades
Clevis Pin
Taper Lock Nut
L
OD
HD
C/S
Part
in mm
in mm
in mm
Screw
Code
25
10
12,7
M3 x 6
BDHP.10
M10 x 1.50
15
17,0
3,5
TLNM.10
32
12
14,0
M5 x 12
BDHP.12
M12 x 1.75
19
20,4
3,5
TLNM.12
40
16
19,0
M5 x 12
BDHP.16
M16 x 2.00
25
27,2
3,5
TLNM.16
50
20
24,0
M6 x 12
BDHP.20
M20 x 2.50
30
34,0
3,5
TLNM.20
60
24
28,0
M6 x 12
BDHP.24
M24 x 3.00
36
40,8
4,0
TLNM.24
70
27
32,0
M6 x 12
BDHP.27
M27 x 3.00
42
45,9
4,0
TLNM.27
75
30
35,0
M8 x 16
BDHP.30
M30 x 3.50
45
51,0
4,0
TLNM.30
80
33
38,0
M8 x 16
BDHP.33
M33 x 3.50
48
56,1
5,0
TLNM.33
90
36
42,0
M8 x 16
BDHP.36
M36 x 4.00
54
61,2
5,0
TLNM.36
100
39
45,0
M8 x 16
BDHP.39
M39 x 4.00
60
66,3
5,0
TLNM.39
TH
OD
L
C
Part
in mm
in mm
in mm
Code
■ Suffix partcode with R or L for right or left handed thread.
Lemster Aak
188
'Vliegent Hart'
189
Composite Rigging
Composite Rigging
Aramid Fibers - High Modulus Polyethylene Covered (HMPE)
Light and durable high modulus fiber cable can replace metallic rods or wire and is recommended for
straight line applications. This cable comprises parallel laid high modulus fibres such as Kevlar 49® or
Twaron 1055® which are held together and protected by a polyethylene sheath. The parallel construction is
compact and uniform and the orientation of the fibres is in line with the working stress on the cable. This
results in the optimum utilisation of the fibre properties and guarantees a very high modulus and a very low
stretch cable. The polyethylene cover is highly resistant to physical abrasion as well as chemical and
atmospheric attack. The cable which is flexible when off tension offers significant weight savings ans is
primarly used for backstays, running backstays and checkstays in yachting.
■
■
One of the first applications for aramid fibre cables were in the antennae and electrical industries,
as insulating guys, catanaries and support systems, where the tensile properties and resistance
to UV degradation ensure a long and essentially maintenance free life.
Furthermore it is been used in urban transport systems as support cables for tram and trolley bus
overhead conductors.
Black Kevlar 49® Cable (White Kevlar Cable on request)
Strength
Outside ø
Weight
Equivelent
Weight
in tonnes
in mm
in kg/ mtr.
Stainless Steel
in kg/ mtr.
Ref. No.
1 x 19
3,0
7,1
0,040
5,0
0,124
KCB003
5,0
8,9
0,058
6,0
0,178
KCB005
7,0
10,2
0,083
7,0
0,243
KCB007
9,0
11,2
0,112
8,0
0,317
KCB009
12,0
14,7
0,150
10,0
0,495
KCB012
15,0
17,3
0,260
12,5
0,805
KCB015
Bigger sizes on request.
190
191
Composite Rigging
Composite Rigging
Standard Light Weight Socket With Toggle Fork
Standard Light Weight Sockets with Eye
Strength
B
C
A
E
D
C
M
E
P
Weight
Weight
Ref. No.
3,0
10
17,0
19,0
8,5
9,5
0,123
KSE.003095
5,0
12
19,0
24,0
10,0
11,2
0,232
KSE.005111
7,0
15
21,5
28,0
11,0
12,8
0,331
KSE.007127
9,0
17
24,5
32,8
14,0
16,0
0,499
KSE.009158
12,0
17
24,5
32,8
14,0
16,0
0,733
KSE.012158
15,0
26
35,0
44,0
19,5
22,2
1,154
KSE.015222
Ref. No.
in kg/ mtr.
in tonnes
in kg
in tonnes
A
Strength
A range of stainless steel fittings has been developed for terminal bodies and reducers. Standard end fittings
are made from AISI 630 stainless steel. Titanium and anodised aluminium options are also available.
5,0
16,0
37,9
30
14,0
12,7
0,470
KSJ005127S
7,0
21,0
38,7
40
17,5
15,9
0,815
KSJ007158S
9,0
21,0
38,7
40
17,5
15,9
0,917
KSJ009158S
12,0
26,0
52,5
50
21,5
19,1
1,427
KSJ012191S
15,0
32,0
64,6
60
24,0
22,2
2,057
KSJ015222S
■ Bigger sizes on request.
■ Cable should be preloaded 40% of MBL after mounting.
■ Fitting is made of stainless steel AISI 316.
■ Bigger sizes on request.
■ Cable should be preloaded 40% of MBL after mounting.
■ Fitting is made of stainless steel AISI 316.
M
A
C
E
øP
C
B
A
E
Standard Light Weight Socket With Swivel Eye
øD
B
Strength
D
Weight
Ref. No.
in kg
in tonnes
3,0
26,2
8,0
0,150
KSSB003
5,0
29,4
9,0
0,271
KSSB005
7,0
36,0
13,0
0,473
KSSB007
9,0
50,2
16,4
0,905
KSSB009
12,0
50,2
16,4
1,080
KSSB012
15,0
64,4
22,8
1,830
KSSB015
■ Bigger sizes on request.
■ Cable should be preloaded 40% of MBL after mounting.
■ Fitting is made of stainless steel AISI 316.
B
D
FF-95
192
193
Fibre Rope | Fibre Rope Tools
Composite Rigging
Standard Light Weight Socket With T - Terminals
Strength
A
C
B
in tonnes
fits Blue Wave
Weight
Backing Plate
in kg/ mtr.
Ref. No.
3,0
20,1
12,7
31,4
BW616107
0,228
KST003
5,0
20,1
12,7
31,4
BW616107
0,369
KST005
7,0
24,2
16,0
34,5
BW616107
0,532
KST007
■ T-Terminal part is made of stainless steel AISI 316.
■ Cable should be preloaded 40% of MBL after mounting.
C
A
B
194
195
Leoflex X
Rigging Tools
Hotknife 75 Watt 220 Volt
Without Blade
Ref. No.
Blade for Hotknife
5090.90.02
Splicing Spike Stainless Steel
With Wooden Handle
Ref. No.
length
5090.91.75
Ref. No.
5090.92.80
Leoflex X
ø
Minimum
Coillength
Weight
in mm
Breaking Load
in mtr
in kg/ 100 mtr.
280 mm
Splicing Spike Stainless Steel
With Plastic Handle
length
Leoflex is a 3-strand twisted rope produced from special fibrillated and twisted
polypropylene yarns, which results in a rope with higher breaking loads than
expected from polypropylene.
The chafe and UV resistance is excellent.
Colours are tarred hemp and manilla colour.
Leoflex is the ideal rope for traditional yachts and charterboats.
175 mm
Splicing Spike Stainless Steel
With Wooden Handle
length
5090.90.00
in kg
color
8
960
220
2,9
WR01.08.0/8X
/9X
10
1425
220
4,5
WR01.10.0/8X
/9X
12
2030
220
6,5
WR01.12.0/8X
/9X
14
2790
220
9,0
WR01.14.0/8X
/9X
16
3500
220
11,5
WR01.16.0/8X
/9X
5090.93.85
18
4450
220
14,8
WR01.18.0/8X
/9X
20
5370
220
18,0
WR01.20.0/8X
/9X
22
6500
220
22,0
WR01.22.0/8X
/9X
24
7600
220
26,0
WR01.24.0/8X
/9X
26
8850
220
31,0
WR01.26.0/8X
/9X
28
10100
220
35,5
WR01.28.0/8X
/9X
30
11500
220
41,0
WR01.30.0/8X
/9X
32
12800
220
46,0
WR01.32.0/8X
/9X
Ref. No.
5090.93.21
Hand Palm Left Handed
tarred hemp
color
Ref. No.
385 mm
Hand Palm Right Handed
Ref. No.
manilla Only available on full coils
Ref. No.
5090.93.22
Professional Bosuns Chair
New model in preparation
196
Ref. No.
5090.94.00
197
Gleistein was founded in the year 1824 by Captain George Gleistein and his son.
In 1999, Gleistein celebrates its 175th Birthday. The oldest industrial family
enterprise in Bremen can look back on the exciting history of a company that
has developed from an outfitter of large sailing vessels to a specialist manufacturer of many different modern and traditional textile constructions.
What has always counted at Gleistein is the use of existing skills and techniques
to develop new ones. The combination of tradition and progress.
Current Yacht Rope catalogue
The enthusiasm for sailing is an important spur for the development of superior
products which have proven themselves in the toughest of conditions. As a
result of this, you can find everything from a high performance regatta sheet to
a simple whipping twine in our comprehensive yacht rope range.
■ Available are two „Gleistein“ catalogues
- Yacht Ropes
- Geo Marine (ropes for commercial marine)
198
199
Fibre Rope
Fibre Rope
Geosquare Powerplus
Thempest
A general purpose rope with the balanced characteristics of lightness, strength
and flexibility.
Construction
■ 3-Strand, firmly laid construction of
doubled yarns.
■ The soft shiny finish gives the outer
appearance of natural fibre ropes.
■ Raw material mix of polyester and
a special fibrillated polypropylene
with high UV stability.
■ The combination of the two raw
materials gives the best properties
of both fibres.
■ Available in bronze and hemp colour.
■ Manufactured to company norm
■8-strand square plait (4x2) with
inner yarns made of polyolefin and
outer yarns of Gleistein Plus yarns,
in mottled green-white
■Geolan impregnation for minimised
inter-fibre friction, higher break
loads and better abrasion protection
■Very good break load and abrasion
resistance
■Very good UV resistance and moderate elongation Specific gravity
approx. 1g/cm3, neutral buoyancy
■OCIMF-conforming mooring line
for tankers
Good to know
■ Superior abrasion resistance with
very high break loads compared to
other traditional looking man-made
fibre ropes.
■ Very good UV-resistance.
■ Balanced load-elongation properties
make Thempest an excellent rope
for a wide variety of applications on
board.
GeoSquare Powerplus (8-Strand Braided)
ø
Breaking Load
Coillength
Weight
in mm
in kN
in mtr.
in kg/ 100 mtr.
24
107,0
220
27,5
GG37.24.05
26
120,0
220
32,8
GG37.26.05
28
138,0
220
35,5
GG37.28.05
30
164,0
220
42,5
GG37.30.05
32
186,0
220
48,5
GG37.32.05
36
235,0
220
61,5
GG37.36.05
40
287,0
220
76,0
GG37.40.05
Ref. No.
Thempest
Ref. No.
GeoOne Plus (12 Strand Braided)
ø
Breaking Load
Coillength
Weight
in mm
in kN
in mtr.
in kg/ 100 mtr.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Ref. No.
Bronze
Hemp
6
650
220
2,40
GG38.06.0/7
GG38.06/10
8
1100
220
3,70
GG38.08.0/7
GG38.08/10
10
1650
220
5,30
GG38.10.0/7
GG38.10/10
12
27,0
220
5,5
GG36.12.05
14
33,0
220
7,5
GG36.14.05
12
2400
220
8,40
GG38.12.0/7
GG38.12/10
GG36.16.05
14
3100
220
10,60
GG38.14.0/7
GG38.14/10
16
4100
220
14,10
GG38.16.0/7
GG38.16/10
16
43,0
220
9,8
18
60,0
220
12,4
GG36.18.05
20
76,0
220
18,5
GG36.20.05
18
5100
220
18,30
GG38.18.0/7
GG38.18/10
GG36.24.05
20
6250
220
22,60
GG38.20.0/7
GG38.20/10
22
7600
220
27,30
GG38.22.0/7
GG38.22/10
24
105,0
220
27,5
28
135,0
220
35,5
GG36.28.05
30
164,0
220
42,5
GG36.30.05
24
8700
220
32,50
GG38.24.0/7
GG38.24/10
GG36.32.05
26
10250
220
38,20
GG38.26.0/7
GG38.26/10
28
12000
220
44,20
GG38.28.0/7
GG38.28/10
30
13500
220
50,80
GG38.30.0/7
GG38.30/10
32
15500
220
57,80
GG38.32.0/7
GG38.32/10
36
19500
220
73,20
GG38.36.0/7
GG38.36/10
40
24000
220
90,40
GG38.40.0/7
GG38.40/10
32
186,0
220
48,5
36
234,0
220
61,5
GG36.36.05
40
285,0
220
76,0
GG36.40.05
Also available with pliced soft eye, with soft eye cover.
Only available on full coils
■ On reels till 16 mm diameter on request
200
201
Fibre rope
Fibre rope
Geo Twist Hempex
Geo Twist GeoProp
Construction
■ 3-Strand laid construction from
polypropylene staple fibre yarns,
hemp colour.
■4-Strand ropes available up to
26 mm ø.
Construction
■ 3-Strand laid high tenacity
polypropylene multifilament (our
trade name GeoProp), firmly laid in
white, blue, navy blue or black.
Good to know
■ A light, floating material (should
therefore not be used for anchor
warps).
■ The material is manufactured with
traditional fibre spinning procedures
and thus exhibits typical
hemp-like behaviour.
■ Very high break loads compared
to natural fibre ropes.
■ High chemical resistance.
■ Very good UV-resistance gives
excellent service life.
■ Low elongation.
Good to know
■ GeoProp floats.
■ GeoProp fibre rope are UV-stabilised
(dark colour have slightly better
stability than the bright ones).
■ GeoProp lines retain their flexibility
and do not stiffen in use.
■ We can offer spliced moorings.
Geo Twist GeoProp
■ Tradition for the future. For the fitting - out of traditional vessels.
HEMPEX has the appearance, handling and behaviour of hemp ropes whilst
giving
all
the
advantages
of
modern,
synthetic
fibre.
Ref. No.
Geo Twist Hempex
Ref. No.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Hemp
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Navy
Black
4
275
220
0,85
GG16.04.0/1
GG16.04.0/3
GG16.04.0/3N
GG16.04.0/7
5
400
220
1,25
GG16.05.0/1
GG16.05.0/3
GG16.05.0/3N
GG16.05.0/7
6
590
220
1,70
GG16.06.0/1
GG16.06.0/3
GG16.06.0/3N
GG16.06.0/7
8
1000
220
3,00
GG16.08.0/1
GG16.08.0/3
GG16.08.0/3N
GG16.08.0/7
10
1530
220
4,50
GG16.10.0/1
GG16.10.0/3
GG16.10.0/3N
GG16.10.0/7
12
2170
220
6,50
GG16.12.0/1
GG16.12.0/3
GG16.12.0/3N
GG16.12.0/7
14
3000
220
9,00
GG16.14.0/1
GG16.14.0/3
GG16.14.0/3N
GG16.14.0/7
16
3700
220
11,50
GG16.16.0/1
GG16.16.0/3
GG16.16.0/3N
GG16.16.0/7
18
4700
220
14,80
GG16.18.0/1
GG16.18.0/3
GG16.18.0/3N
GG16.18.0/7
20
5700
220
18,00
GG16.20.0/1
GG16.20.0/3
GG16.20.0/3N
GG16.20.0/7
22
7000
220
22,00
GG16.22.0/1
GG16.22.0/3
GG16.22.0/3N
GG16.22.0/7
24
8200
220
26,00
GG16.24.0/1
GG16.24.0/3
GG16.24.0/3N
GG16.24.0/7
6
350
220
1,6
GG18.06.08
8
600
220
2,8
GG18.08.08
26
9500
220
30,50
GG16.26.0/1
GG16.26.0/3
GG16.26.0/3N
GG16.26.0/7
10
900
220
4,3
GG18.10.08
28
10900
220
35,50
GG16.28.0/1
GG16.28.0/3
GG16.28.0/3N
GG16.28.0/7
30
12500
220
40,50
GG16.30.0/1
GG16.30.0/3
GG16.30.0/3N
GG16.30.0/7
6,3
GG18.12.08
220
8,1
GG18.14.08
32
14200
220
46,00
GG16.32.0/1
GG16.32.0/3
GG16.32.0/3N
GG16.32.0/7
220
10,4
GG18.16.08
36
18000
220
58,50
GG16.36.0/1
GG16.36.0/3
GG16.36.0/3N
GG16.36.0/7
40
22000
220
72,00
GG16.40.0/1
GG16.40.0/3
GG16.40.0/3N
GG16.40.0/7
44
26500
220
88,00
GG16.44.0/1
GG16.44.0/3
GG16.44.0/3N
GG16.44.0/7
12
1340
220
14
1740
16
2180
18
2730
220
13,0
GG18.18.08
20
3420
220
16,0
GG18.20.08
22
4100
220
19,0
GG18.22.08
24
4830
220
23,0
GG18.24.08
26
5640
220
27,0
GG18.26.08
28
6500
220
31,0
GG18.28.08
30
7300
220
35,0
GG18.30.08
32
8300
220
40,0
GG18.32.08
36
10400
220
51,0
GG18.36.08
40
12900
220
63,0
GG18.40.08
44
15600
220
77,0
GG18.44.08
Only available on full reels/coils
■ On reels up to 16 mm diam.
Only available on full reels/coils
■ Also available in 16-strand braided construction 3 - 10 mm.
■ On reels up to 16 mm diam.
202
203
Fibre rope
Fibre rope
Geo Square GeoProp
Geo Twist Polyamide
Construction
■ Square plaited high tenacity
polypropylene multifilament (our
trade name GeoProp), firmly laid.
■ Available in white, navy blue or black.
Good to know
■ GeoProp floats.
■ GeoProp lines are UV-stabilised
(dark colour have slightly better
stability than the bright ones).
■ A light, floating material (should
therefore not be used for anchor
warps).
■ GeoProp lines retain their flexibility
and do not stiffen in use.
■ We can offer spliced moorings.
Construction
■ 3-Strand laid Polyamide in white
or black.
■ Thermally stabilised for higher
service life and improved handling.
Ref. No.
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
mooring lines that canotherwise occur through
the influence of weather.
■ Highly suitable as mooring lines, towing springs and anchor warps.
■ We can offer spliced moorings.
Ref. No.
Geo Square GeoProp
ø
Good to know
■ Polyamide mooring lines have
outstanding elasticity and therefore
absorb shock loads very well.
■ Our thermal stabilisation improves
handling considerably and minimi zes the stiffening of Polyamide
ø
Breaking Load
Reel-/Coillength
in mm
in daN
in mtr
Weight
in kg/ 100 mtr.
Black
4
315
220
1,1
GG12.04.0/1
GG12.04.0/7
5
775
220
1,6
GG12.05.0/1
GG12.05.0/7
6
930
220
2,3
GG12.06.0/1
GG12.06.0/7
8
1400
220
4,0
GG12.08.0/1
GG12.08.0/7
10
2200
220
6,2
GG12.10.0/1
GG12.10.0/7
12
3150
220
8,9
GG12.12.0/1
GG12.12.0/7
14
3900
220
12,2
GG12.14.0/1
GG12.14.0/7
16
5500
220
15,8
GG12.16.0/1
GG12.16.0/7
18
7250
220
20,0
GG12.18.0/1
GG12.18.0/7
20
8800
220
24,5
GG12.20.0/1
GG12.20.0/7
22
11200
220
30,0
GG12.22.0/1
GG12.22.0/7
24
12560
220
35,5
GG12.24.0/1
GG12.24.0/7
26
14650
220
42,0
GG12.26.0/1
GG12.26.0/7
Only available on full reels/coils
■ On reels up to 16 mm diam.
White
Navy
Black
6,5
GG17.12.0/1
GG17.12.0/3N
GG17.12.0/7
Geo Square Polyamide
12
2170
220
14
3000
220
9,0
GG17.14.0/1
GG17.14.0/3N
GG17.14.0/7
16
3700
220
11,5
GG17.16.0/1
GG17.16.0/3N
GG17.16.0/7
18
4700
220
14,8
GG17.18.0/1
GG17.18.0/3N
GG17.18.0/7
20
5700
220
18,0
GG17.20.0/1
GG17.20.0/3N
GG17.20.0/7
22
7000
220
22,0
GG17.22.0/1
GG17.22.0/3N
GG17.22.0/7
24
8200
220
26,0
GG17.24.0/1
GG17.24.0/3N
GG17.24.0/7
26
9500
220
30,5
GG17.26.0/1
GG17.26.0/3N
GG17.26.0/7
28
10900
220
35,5
GG17.28.0/1
GG17.28.0/3N
GG17.28.0/7
30
12500
220
40,5
GG17.30.0/1
GG17.30.0/3N
GG17.30.0/7
Breaking Load
Reel-/Coillength
Weight
32
14200
220
46,0
ø
GG17.32.0/1
GG17.32.0/3N
GG17.32.0/7
in mm
in daN
in mtr
in kg/ 100 mtr.
36
18000
220
58,5
GG17.36.0/1
GG17.36.0/3N
GG17.36.0/7
40
22000
220
72,0
GG17.40.0/1
GG17.40.0/3N
GG17.40.0/7
10
2400
220
44
26500
220
88,0
GG17.44.0/1
GG17.44.0/3N
GG17.44.0/7
12
3150
220
14
3900
16
18
Only available on full reels/coils
■ On reels up to 16 mm diam.
White
Construction
■ Square-plaited Polyamide in
white or black.
■ Thermally stabilised for higher
service life and improved handling.
Good to know
■ Polyamide mooring lines have
outstanding elasticity and therefore
absorb shock loads very well.
■ Our thermal stabilisation improves
handling considerably and minimi zes the stiffening of Polyamide
mooring lines that can otherwise occur through
the influence of weather.
■ Square-pleited mooring lines do not kink.
■ Highly suitable as mooring lines, towing springs and anchor warps.
■ We can offer spliced moorings.
Ref. No.
White
Black
5,8
GG13.10.0/1
GG13.10.0/7
8,9
GG13.12.0/1
GG13.12.0/7
220
12,2
GG13.14.0/1
GG13.14.0/7
6260
220
15,8
GG13.16.0/1
GG13.16.0/7
7250
220
20,0
GG13.18.0/1
GG13.18.0/7
20
8800
220
24,5
GG13.20.0/1
GG13.20.0/7
22
11200
220
30,0
GG13.22.0/1
GG13.22.0/7
24
12560
220
35,5
GG13.24.0/1
GG13.24.0/7
26
14650
220
42,0
GG13.26.0/1
GG13.26.0/7
28
16800
220
48,5
GG13.28.0/1
GG13.28.0/7
30
19600
220
55,5
GG13.30.0/1
GG13.30.0/7
32
21000
220
63,0
GG13.32.0/1
GG13.32.0/7
36
27900
220
80,0
GG13.36.0/1
GG13.36.0/7
40
35000
220
99,0
GG13.40.0/1
GG13.40.0/7
Only available on full reels/coils
■ On reels up to 16 mm diam.
204
205
Fibre rope
Fibre rope
Geo One Polyamide
Geo Twist Polyester
Construction
■ 12-Strand round braid from HT
continuous filament polyamide
with GeoGard Marine Finish.
■ Available in solid white and black.
Good to know
■ Excellent break load.
■ Excellent elongation characteristics for comfortable mooring.
■ GeoGard finish minimizes hardening and water absorption due to raw material characteristics.
■ Good abrasion resistance.
■ We can offer spliced moorings.
Construction
■ 3-Strand laid HT continuous filament polyester in white (with blue identifica tion yarn), navy blue or black.
■ Thermally stabilised for higher service
life and improved handling.
Good to know
■ Polyester fibres combine best abrasion resistance with outstanding UV-stability.
■ Remains flexible throughout its usable life.
Ref. No.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
The light resistance of solid colour
versions is even better than that of
the white one.
Highly suitable as mooring line,
towing spring or anchor warp.
We can offer spliced moorings.
Ref. No.
White
Black
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Navy
Black
20
9200
220
24,7
GG40.20.0/1
GG40.20.0/7
22
11400
220
29,9
GG40.22.0/1
GG40.22.0/7
4
290
220
1,03
GG14.04.0/1
GG14.04.0/3N
GG14.04.0/7
24
14100
220
35,5
GG40.24.0/1
GG40.24.0/7
5
400
220
2,51
GG14.05.0/1
GG14.05.0/3N
GG14.05.0/7
6
780
220
2,70
GG14.06.0/1
GG14.06.0/3N
GG14.06.0/7
26
15500
220
41,7
GG40.26.0/1
GG40.26.0/7
28
17800
220
48,4
GG40.28.0/1
GG40.28.0/7
8
1400
220
4,80
GG14.08.0/1
GG14.08.0/3N
GG14.08.0/7
30
20100
220
55,5
GG40.30.0/1
GG40.30.0/7
10
2150
220
7,60
GG14.10.0/1
GG14.10.0/3N
GG14.10.0/7
12
3080
220
11,00
GG14.12.0/1
GG14.12.0/3N
GG14.12.0/7
32
23100
220
63,2
GG40.32.0/1
GG40.32.0/7
36
29000
220
80,0
GG40.36.0/1
GG40.36.0/7
14
3720
220
14,80
GG14.14.0/1
GG14.14.0/3N
GG14.14.0/7
40
35700
220
98,7
GG40.40.0/1
GG40.40.0/7
16
5700
220
19,50
GG14.16.0/1
GG14.16.0/3N
GG14.16.0/7
18
6700
220
24,50
GG14.18.0/1
GG14.18.0/3N
GG14.18.0/7
44
42900
220
119,0
GG40.44.0/1
GG40.44.0/7
48
50800
220
142,0
GG40.48.0/1
GG40.48.0/7
20
8050
220
30,30
GG14.20.0/1
GG14.20.0/3N
GG14.20.0/7
52
59300
220
167,0
GG40.52.0/1
GG40.52.0/7
22
10200
220
36,70
GG14.22.0/1
GG14.22.0/3N
GG14.22.0/7
24
11500
220
43,70
GG14.24.0/1
GG14.24.0/3N
GG14.24.0/7
26
13400
220
51,20
GG14.26.0/1
GG14.26.0/3N
GG14.26.0/7
56
68400
220
192,0
GG40.56.0/1
GG40.56.0/7
60
78000
220
220,0
GG40.60.0/1
GG40.60.0/7
Only available on full reels/coils
■ On reels up to 16 mm diam.
Geo Twin Polyamide
Construction
■ Core 12-Strand continuous filament polyamide (nylon).
■ Flexible braided cover from the same material with GeoGard Marine Finish.
■ Available in white and black.
■ Special colours available to customers request and made to order.
206
■
■
■
Geo Square Polyester
Good to know
■ Excellent break load.
■ Excellent elongation characteristics for com-
fortable mooring.
■ GeoGard finish minimizes hardening and water absorption due to raw material
characteristics.
■ Good abrasion resistance.
■ We can offer splices moorings.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Construction
■ Square-plaited HT continuous filament polyester in white (with blue identifi-
cation yarn), navy blue or black.
■ Thermally stabilised for higher service
life and improved handling.
Good to know
■ Polyester fibres combine best abrasion resistance with outstanding UV-stability.
■ Remains flexible throughout its
usable life.
■
■
■
The light resistance of solid
colour versions is even better
than that of the white one.
Highly suitable as mooring line,
towing spring or anchor warp.
We can offer spliced moorings.
Ref. No.
Ref. No.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Navy
Black
White
Black
10
1680
220
7,5
GG15.10.0/1
GG15.10.0/3N
GG15.10.0/7
GG43.20.0/7
12
3080
220
11,0
GG15.12.0/1
GG15.12.0/3N
GG15.12.0/7
14
3720
220
14,8
GG15.14.0/1
GG15.14.0/3N
GG15.14.0/7
20
8500
220
22,5
GG43.20.0/1
22
11900
220
30,4
GG43.22.0/1
GG43.22.0/7
24
13600
220
35,3
GG43.24.0/1
GG43.24.0/7
16
5700
220
19,5
GG15.16.0/1
GG15.16.0/3N
GG15.16.0/7
26
16000
220
42,0
GG43.26.0/1
GG43.26.0/7
18
6700
220
24,5
GG15.18.0/1
GG15.18.0/3N
GG15.18.0/7
28
18300
220
48,0
GG43.28.0/1
GG43.28.0/7
20
8050
220
30,3
GG15.20.0/1
GG15.20.0/3N
GG15.20.0/7
30
21000
220
56,0
GG43.30.0/1
GG43.30.0/7
22
10400
220
36,7
GG15.22.0/1
GG15.22.0/3N
GG15.22.0/7
32
23500
220
63,5
GG43.32.0/1
GG43.32.0/7
24
12400
220
43,7
GG15.24.0/1
GG15.24.0/3N
GG15.24.0/7
34
26500
220
71,0
GG43.34.0/1
GG43.34.0/7
26
13700
220
51,2
GG15.26.0/1
GG15.26.0/3N
GG15.26.0/7
36
30000
220
80,5
GG43.36.0/1
GG43.36.0/7
28
16000
220
59,4
GG15.28.0/1
GG15.28.0/3N
GG15.28.0/7
40
40000
220
99,0
GG43.40.0/1
GG43.40.0/7
30
18100
220
68,2
GG15.30.0/1
GG15.30.0/3N
GG15.30.0/7
44
43000
220
120,0
GG43.44.0/1
GG43.44.0/7
32
20500
220
77,8
GG15.32.0/1
GG15.32.0/3N
GG15.32.0/7
48
50500
220
142,0
GG43.48.0/1
GG43.48.0/7
36
25800
220
98,2
GG15.36.0/1
GG15.36.0/3N
GG15.36.0/7
52
60000
220
167,0
GG43.52.0/1
GG43.52.0/7
40
31700
220
121,0
GG15.40.0/1
GG15.40.0/3N
GG15.40.0/7
56
69000
220
194,0
GG43.56.0/1
GG43.56.0/7
60
78100
220
222,0
GG43.60.0/1
GG43.60.0/7
Only available on full reels/coils
■ On reels up to 16 mm diam.
207
Fibre rope
Fibre rope
Geo One Polyester
Construction
■ 12-Strand round braid from HT
continuous filament polyamide
with GeoGard Marine Finish.
■ Available in solid white and black.
Bavaria | Dockline
Construction
■ Core 12-strand from HT polyester.
■ Flexible braided cover from the
same material.
■ Bavaria available in white with
blue or black marker yarns.
■ Dockline available in black, red
and navy blue.
Good to know
■ Excellent break load.
■ Excellent elongation characteristics for comfortable mooring.
■ GeoGard finish minimizes hardening and water absorption due to raw material characteristics.
■ Good abrasion resistance.
■ We can offer spliced moorings.
Ref. No.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Bavaria Ref. No.
White
Navy
Black
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Dockline Ref. No.
Navy
Red
Black
Grey
GG11.08.0/7
GG11.08.0/3N
GG11.08.0/44
GG11.08.0/77
GG11.08.0/22
GG11.10.0/7
GG11.10.0/3N
GG11.10.0/44
GG11.10.0/77
GG11.10.0/22
GG11.12.0/3
GG11.12.0/7
GG11.12.0/3N
GG11.12.0/44
GG11.12.0/77
GG11.12.0/22
20
9000
220
30,3
GG39.20.0/1
GG39.20.0/3N
GG39.20.0/7
22
10300
220
36,7
GG39.22.0/1
GG39.22.0/3N
GG39.22.0/7
8
1200
200
4,0
GG11.08.0/3
24
12800
220
43,7
GG39.24.0/1
GG39.24.0/3N
GG39.24.0/7
10
2000
200
6,8
GG11.10.0/3
12
2900
200
9,3
Black
26
14900
220
51,2
GG39.26.0/1
GG39.26.0/3N
GG39.26.0/7
28
17300
220
59,4
GG39.28.0/1
GG39.28.0/3N
GG39.28.0/7
14
3550
200
13,0
GG11.14.0/3
GG11.14.0/7
GG11.14.0/3N
GG11.14.0/44
GG11.14.0/77
GG11.14.0/22
30
18400
220
68,2
GG39.30.0/1
GG39.30.0/3N
GG39.30.0/7
16
4750
200
18,0
GG11.16.0/3
GG11.16.0/7
GG11.16.0/3N
GG11.16.0/44
GG11.16.0/77
GG11.16.0/22
18
6100
200
23,4
GG11.18.0/3
GG11.18.0/7
GG11.18.0/3N
GG11.18.0/44
GG11.18.0/77
GG11.18.0/22
20
8000
200
30,0
GG11.20.0/3
GG11.20.0/7
GG11.20.0/3N
GG11.20.0/44
GG11.20.0/77
GG11.20.0/22
32
22500
220
77,8
GG39.32.0/1
GG39.32.0/3N
GG39.32.0/7
36
28200
220
98,2
GG39.36.0/1
GG39.36.0/3N
GG39.36.0/7
40
34600
220
121,0
GG39.40.0/1
GG39.40.0/3N
GG39.40.0/7
44
41600
220
147,0
GG39.44.0/1
GG39.44.0/3N
GG39.44.0/7
48
49100
220
175,0
GG39.48.0/1
GG39.48.0/3N
GG39.48.0/7
52
57200
220
205,0
GG39.52.0/1
GG39.52.0/3N
GG39.52.0/7
Geo Twin Polyester
Construction
■ 12-Strand round braid from HT
continuous filament polyamide
with GeoGard Marine Finish.
■ Available in solid white and black.
Only available on full reels
■ On reels up to 16 mm diam.
■ Beware of cheap copies on the market with polypropylene inner core.
Geo Twin Geo X-tend
Good to know
■ Excellent break load.
■ Excellent elongation characteristics for comfortable mooring.
■ GeoGard finish minimizes hardening and water absorption due to raw material characteristics.
■ Good abrasion resistance.
■ We can offer spliced moorings.
Construction
■ Core 12-strand from a special
high elongation polyester type.
■ Flexible braided cover from the
same material in Bavaria look.
Ref. No.
ø
Breaking Load
Reel-/Coillength
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
208
Good to know
■ Excellent break load.
■ Balanced elongation
characteristics.
■ Lifetime flexibility without work hardening.
■ Excellent abrasion resistance.
■ Minimum water absorption.
■ We can offer spliced moorings.
Navy
Good
to
know
■ Excellent break load.
■ Excellent elongation characteri-
stics giving comfortable and smooth mooring.
■ Lifetime flexibility without work hardening.
■ Excellent abrasion resistance.
■ Minimum water absorption.
■ We can offer spliced moorings
Black
20
10000
220
30,0
GG44.20.0/1
GG44.20.0/3N
GG44.20.0/7
22
12200
220
37,3
GG44.22.0/1
GG44.22.0/3N
GG44.22.0/7
24
14500
220
43,4
GG44.24.0/1
GG44.24.0/3N
GG44.24.0/7
26
17000
220
51,0
GG44.26.0/1
GG44.26.0/3N
GG44.26.0/7
28
19600
220
59,0
GG44.28.0/1
GG44.28.0/3N
GG44.28.0/7
30
22700
220
68,0
GG44.30.0/1
GG44.30.0/3N
GG44.30.0/7
32
25500
220
78,0
GG44.32.0/1
GG44.32.0/3N
GG44.32.0/7
34
29300
220
88,0
GG44.34.0/1
GG44.34.0/3N
GG44.34.0/7
36
32100
220
99,0
GG44.36.0/1
GG44.36.0/3N
GG44.36.0/7
40
39400
220
121,0
GG44.40.0/1
GG44.40.0/3N
GG44.40.0/7
42
43000
220
133,0
GG44.42.0/1
GG44.42.0/3N
GG44.42.0/7
44
47300
220
147,0
GG44.44.0/1
GG44.44.0/3N
GG44.44.0/7
48
55900
220
177,0
GG44.48.0/1
GG44.48.0/3N
GG44.48.0/7
52
64500
220
204,0
GG44.52.0/1
GG44.52.0/3N
GG44.52.0/7
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White/Black
10
2000
200
6,8
GG47.10.01
12
2900
200
9,3
GG47.12.01
14
3600
200
13,0
GG47.14.01
16
4800
200
18,8
GG47.16.01
18
6100
200
23,4
GG47.18.01
20
8000
200
30,0
GG47.20.01
Only available on full reels
■ On reels up to 16 mm diam.
209
Rope Diameters for Mooring Lines, Anchor Warps and Towing Springs
Fibre rope
Tables
Polyamide 3-Strand
Polyamide Twin
Polyamide One
Thempest
Geo X-Tend
GeoProp 3-Strand
Polyester One
GeoProp Square
Polyester 3-Strand
Bavaria, Dockline
Polyester Twin
Polyester Square
Hempex 3-Strand
Polyamide
GeoProp
Thempest
Hempex
Twist, Square, Twin,
Bavaria, Dockline, One,
GeoX-tend
Twist, Square,
Twin, One
Twist, Square,
Twin, One
Twist
Twist, One
ø
ø
ø
ø
ø
6-8
10
10
12
12
16
10
12
12
14
14
20
12
14
14
16
16
22
14
16
16
20
20
26
16 - 18
18
18
22
22
28
20 - 22
20
20
24
24
32
24 - 26
22
22
28
26
36
28 - 32
24
22
30
28
40
34 - 36
26
24
32
30
40
38 - 40
28
26
36
32
44
Length of Vessel
in m
Load / Elongation curves of “used” mooring lines
50
Load as %-age of Breaking Load
Polyester
40
The length of a vessel has proven to be the most useful reference for the sizing of mooring lines.
Rope diameters mentioned are average figures which results from past experience. Deviations for particular
vessel designs are likely to occur. The rope sizes are valid for a classic mooring layout: one headline, one
sternline and two springs.
A rule-of-thumb for the dimensioning of polyester and polyamide mooring lines is length of vessel in metres
+ 2 = rope diameter in mm. Size for ease of handling should also be considered.
30
20
10
0
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
%-Elongation
„Used“ means after average usage under normal
weather conditions and is simulated in the lab
with 10 loadings at 20 % of the break load.
210
211
Fibre rope
Geo One Geo Prop 8-Strand Braided
Construction
■ Round braids in basic colours,
8- and 16-plait.
Good to know
■ Good break load.
■ Moderate abrasion- and UV resistance.
■ Low weight and price.
■ Ideally suited for numerous
applications.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Red
Green
Yellow
Black
1,5
38
250
0,10
GG22.01.5/1
GG22.01.5/3
GG22.01.5/4
GG22.01.5/5
GG22.01.5/6
GG22.01.5/7
2,0
70
250
0,16
GG22.02.0/1
GG22.02.0/3
GG22.02.0/4
GG22.02.0/5
GG22.02.0/6
GG22.02.0/7
2,5
95
250
0,23
GG22.02.5/1
GG22.02.5/3
GG22.02.5/4
GG22.02.5/5
GG22.02.5/6
GG22.02.5/7
3,0
150
250
0,40
GG22.03.0/1
GG22.03.0/3
GG22.03.0/4
GG22.03.0/5
GG22.03.0/6
GG22.03.0/7
4,0
300
250
0,70
GG22.04.0/1
GG22.04.0/3
GG22.04.0/4
GG22.04.0/5
GG22.04.0/6
GG22.04.0/7
5,0
450
250
1,10
GG22.05.0/1
GG22.05.0/3
GG22.05.0/4
GG22.05.0/5
GG22.05.0/6
GG22.05.0/7
6,0
520
220
1,55
GG22.06.0/1
GG22.06.0/3
GG22.06.0/4
GG22.06.0/5
GG22.06.0/6
GG22.06.0/7
8,0
900
220
2,60
GG22.08.0/1
GG22.08.0/3
GG22.08.0/4
GG22.08.0/5
GG22.08.0/6
GG22.08.0/7
10,0
1300
220
4,00
GG22.10.0/1
GG22.10.0/3
GG22.10.0/4
GG22.10.0/5
GG22.10.0/6
GG22.10.0/7
Only available on full reels
Geo One Geo Prop 16-Strand Braided
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Red
Green
Yellow
Black
1,5
38
250
0,10
GG23.01.5/1
GG23.01.5/3
GG23.01.5/4
GG23.01.5/5
GG23.01.5/6
GG23.01.5/7
2,0
70
250
0,16
GG23.02.0/1
GG23.02.0/3
GG23.02.0/4
GG23.02.0/5
GG23.02.0/6
GG23.02.0/7
2,5
95
250
0,23
GG23.02.5/1
GG23.02.5/3
GG23.02.5/4
GG23.02.5/5
GG23.02.5/6
GG23.02.5/7
3,0
150
250
0,40
GG23.03.0/1
GG23.03.0/3
GG23.03.0/4
GG23.03.0/5
GG23.03.0/6
GG23.03.0/7
4,0
300
250
0,70
GG23.04.0/1
GG23.04.0/3
GG23.04.0/4
GG23.04.0/5
GG23.04.0/6
GG23.04.0/7
5,0
450
250
1,10
GG23.05.0/1
GG23.05.0/3
GG23.05.0/4
GG23.05.0/5
GG23.05.0/6
GG23.05.0/7
6,0
520
220
1,55
GG23.06.0/1
GG23.06.0/3
GG23.06.0/4
GG23.06.0/5
GG23.06.0/6
GG23.06.0/7
8,0
900
220
2,60
GG23.08.0/1
GG23.08.0/3
GG23.08.0/4
GG23.08.0/5
GG23.08.0/6
GG23.08.0/7
10,0
1300
220
4,00
GG23.10.0/1
GG23.10.0/3
GG23.10.0/4
GG23.10.0/5
GG23.10.0/6
GG23.10.0/7
Only available on full reels
Waarschip 725
212
'Timber Toy'
213
Fibre rope
Fibre rope
Geo One Polyamide 8-Strand Braided
Geo One Polyester 16-Strand Braided
Construction
■ Round braid 8- and 16-plait from
polyamide in white or black.
Construction
■ Round braid 16-plait from
polyester white with blue marker
or solid black.
Good to know
■ High break load.
■ High elongation.
■ Good abrasion- and UV resistance.
■ Ideally suited as flag halyard
and whipping twine.
Good to know
■ Very good abrasion resistance.
■ Low elongation.
■ Very good UV-resistance.
■ Multi-purpose rope with a large
variety of possible applications.
Ref. No.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Black
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
White/Blue
Black
1,5
40
220
0,14
GG19.01.5/1
GG19.01.5/3
GG19.01.5/7
2,0
75
220
0,22
GG19.02.0/1
GG19.02.0/3
GG19.02.0/7
2,5
105
220
0,35
GG19.02.5/1
GG19.02.5/3
GG19.02.5/7
3,0
150
220
0,61
GG19.03.0/1
GG19.03.0/3
GG19.03.0/7
1,5
49
220
0,13
GG20.01.5/1
GG20.01.5/7
4,0
270
220
1,10
GG19.04.0/1
GG19.04.0/3
GG19.04.0/7
2,0
93
220
0,18
GG20.02.0/1
GG20.02.0/7
5,0
420
220
1,72
GG19.05.0/1
GG19.05.0/3
GG19.05.0/7
2,5
137
220
0,28
GG20.02.5/1
GG20.02.5/7
6,0
590
220
2,44
GG19.06.0/1
GG19.06.0/3
GG19.06.0/7
3,0
155
220
0,51
GG20.03.0/1
GG20.03.0/7
8,0
1030
220
4,35
GG19.08.0/1
GG19.08.0/3
GG19.08.0/7
4,0
270
220
0,90
GG20.04.0/1
GG20.04.0/7
10,0
1630
220
6,80
GG19.10.0/1
GG19.10.0/3
GG19.10.0/7
5,0
420
220
1,40
GG20.05.0/1
GG20.05.0/7
6,0
618
220
2,00
GG20.06.0/1
GG20.06.0/7
8,0
1090
220
3,60
GG20.08.0/1
GG20.08.0/7
10,0
1650
220
5,60
GG20.10.0/1
GG20.10.0/7
Only available on full reels
Ester Color 16-Strand Braided
Only available on full reels
Construction
■ Round braid 16-plait from
solid colour polyester.
Geo One Polyamide 16-Strand Braided
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Black
1,5
49
220
0,13
GG21.01.5/1
GG21.01.5/7
2,0
93
220
0,18
GG21.02.0/1
GG21.02.0/7
2,5
137
220
0,28
GG21.02.5/1
GG21.02.5/7
3,0
155
220
0,51
GG21.03.0/1
GG21.03.0/7
4,0
270
220
0,90
GG21.04.0/1
GG21.04.0/7
5,0
420
220
1,40
GG21.05.0/1
GG21.05.0/7
6,0
618
220
2,00
GG21.06.0/1
GG21.06.0/7
8,0
1090
220
3,60
GG21.08.0/1
GG21.08.0/7
10,0
1650
220
5,60
GG21.10.0/1
GG21.10.0/7
Good to know
■ Very good abrasion resistance.
■ Low elongation.
■ Very good UV-resistance.
■ Multi-purpose rope with a large
variety of possible applications.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
Green
Yellow
Navy
Hemp
1,5
40
250
0,14
GG34.01.5/3
GG34.01.5/4
GG34.01.5/5
GG34.01.5/6
GG34.01.5/3N
GG34.15/10
2,0
75
250
0,22
GG34.02.0/3
GG34.02.0/4
GG34.02.0/5
GG34.02.0/6
GG34.02.0/3N
GG34.02/10
2,5
105
250
0,35
GG34.02.5/3
GG34.02.5/4
GG34.02.5/5
GG34.02.5/6
GG34.02.5/3N
GG34.25/10
3,0
150
250
0,61
GG34.03.0/3
GG34.03.0/4
GG34.03.0/5
GG34.03.0/6
GG34.03.0/3N
GG34.03/10
4,0
250
250
1,10
GG34.04.0/3
GG34.04.0/4
GG34.04.0/5
GG34.04.0/6
GG34.04.0/3N
GG34.04/10
5,0
400
250
1,72
GG34.05.0/3
GG34.05.0/4
GG34.05.0/5
GG34.05.0/6
GG34.05.0/3N
GG34.05/10
6,0
590
200
2,44
GG34.06.0/3
GG34.06.0/4
GG34.06.0/5
GG34.06.0/6
GG34.06.0/3N
GG34.06/10
Only available on full reels
Only available on full reels
214
215
Fibre rope
Fibre rope
Geo One Polyester Solid Braid
Standard / Standard Solid Color / Standard T
Construction
■ Solid braid from polyester white
with blue marker.
Good to know
■ High elongation.
■ Very stable cross section and hence
an ideal leech line soft and handy.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White / Blue
3
131
250
0,61
GG47.03.01SB
4
220
250
1,10
GG47.04.01SB
5
330
250
1,72
GG47.05.01SB
6
460
220
2,44
GG47.06.01SB
8
780
220
4,35
GG47.08.01SB
10
1230
220
6,80
GG47.10.01SBF
Solid braid also available in GeoProp.
Only available on full reels
Construction
■ Core of braided HT continuous
filament polyester.
■ The 3 coloured marker yarns give
the flexible matt finish polyester
staple fibre cover its identifable
appearance.
■ Also available in plain white or
various solid colours.
■ Gleistein’s orange identification
yarn.
Good to know
■ Standard is an ideal sheet and due
to its wooly grip it does not slip
when handled.
■ The flexible but durable construction combines good abrasion resistance
with excellent handling.
■ Best used on winches with a
smooth drum surface.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Caribic Color
Construction
■ Core 12-strand braid of Dyneema®
SK75 fibre.
■ Cover of HT solid colour Polyester
16-plait braided with marker yam.
Good to know
■ Similar strength and stretch to steel wire rope.
■ Caribic Color can be tapered by the removal of sections of outer cover.
■ Universal rope with a large variety of applica-
tions.
■ Suitable for endless splicing
Ref. No.
Blue
Red
Green
3
100
200
0,30
GG09.03.0/1
GG09.03.0/3
GG09.03.0/4
GG09.03.0/5
4
230
200
1,00
GG09.04.0/1
GG09.04.0/3
GG09.04.0/4
GG09.04.0/5
5
360
200
1,60
GG09.05.0/1
GG09.05.0/3
GG09.05.0/4
GG09.05.0/5
6
500
200
2,55
GG09.06.0/1
GG09.06.0/3
GG09.06.0/4
GG09.06.0/5
8
750
200
3,80
GG09.08.0/1
GG09.08.0/3
GG09.08.0/4
GG09.08.0/5
10
1250
200
6,10
GG09.10.0/1
GG09.10.0/3
GG09.10.0/4
GG09.10.0/5
12
2000
200
8,70
GG09.12.0/1
GG09.12.0/3
GG09.12.0/4
GG09.12.0/5
14
2500
200
12,00
GG09.14.0/1
GG09.14.0/3
GG09.14.0/4
GG09.14.0/5
16
3500
200
17,50
GG09.16.0/1
GG09.16.0/3
GG09.16.0/4
GG09.16.0/5
ø
Breaking Load
Reel Length
Weight
18
4500
200
20,00
GG09.18.0/1
GG09.18.0/3
GG09.18.0/4
GG09.18.0/5
in mm
in daN
in mtr
in kg/ 100 mtr.
20
5900
200
25,90
GG09.20.0/1
GG09.20.0/3
GG09.20.0/4
GG09.20.0/5
Blue
Red
Green
Yellow
Black
Navy
2,0
180
250
0,27
GG33.02.0/3
GG33.02.0/4
GG33.02.0/5
GG33.02.0/6
GG33.02.0/7
GG33.02.0/3N
3,0
300
250
0,74
GG33.03.0/3
GG33.03.0/4
GG33.03.0/5
GG33.03.0/6
GG33.03.0/7
GG33.03.0/3N
4,0
650
250
1,00
GG33.04.0/3
GG33.04.0/4
GG33.04.0/5
GG33.04.0/6
GG33.04.0/7
GG33.04.0/3N
5,0
1100
250
2,10
GG33.05.0/3
GG33.05.0/4
GG33.05.0/5
GG33.05.0/6
GG33.05.0/7
GG33.05.0/3N
6,0
1700
200
2,55
GG33.06.0/3
GG33.06.0/4
GG33.06.0/5
GG33.06.0/6
GG33.06.0/7
GG33.06.0/3N
Only available on full reels
Only available on full reels
Standard Solid Color
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Dyneema Trim
Construction
■ Braided 8- respectively 12-plait
(depending on size) from
Dyneema® SK75, white.
Good to know
■ Ideal trim-, leech- and control line.
■ Very low elongation.
■ Slippery, abrasion resistant surface.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
1,0
100
220
0,08
GG26.01.0/1
1,5
180
220
0,13
GG26.01.5/1
2,0
240
220
0,16
GG26.02.0/1
2,5
280
220
0,27
GG26.02.5/1
3,0
400
220
0,39
GG26.03.0/1
4,0
600
220
0,64
GG26.04.0/1
Standard T
Ref. No.
Red
Ref. No.
Green
Black
Hemp
3
100
200
0,30
GG09.03.0/33
GG09.03.0/44
GG09.03.0/55
GG09.03.0/77
GG09.03/10
4
230
200
1,00
GG09.04.0/33
GG09.04.0/44
GG09.04.0/55
GG09.04.0/77
GG09.04/10
5
360
200
1,60
GG09.05.0/33
GG09.05.0/44
GG09.05.0/55
GG09.05.0/77
GG09.05/10
6
500
200
2,55
GG09.06.0/33
GG09.06.0/44
GG09.06.0/55
GG09.06.0/77
GG09.06/10
8
750
200
3,80
GG09.08.0/33
GG09.08.0/44
GG09.08.0/55
GG09.08.0/77
GG09.08/10
10
1250
200
6,10
GG09.10.0/33
GG09.10.0/44
GG09.10.0/55
GG09.10.0/77
GG09.10/10
12
2000
200
8,70
GG09.12.0/33
GG09.12.0/44
GG09.12.0/55
GG09.12.0/77
GG09.12/10
14
2500
200
12,00
GG09.14.0/33
GG09.14.0/44
GG09.14.0/55
GG09.14.0/77
GG09.14/10
16
3500
200
17,50
GG09.16.0/33
GG09.16.0/44
GG09.16.0/55
GG09.16.0/77
GG09.16/10
18
4500
200
20,00
GG09.18.0/33
GG09.18.0/44
GG09.18.0/55
GG09.18.0/77
GG09.18/10
20
5900
200
25,90
GG09.20.0/33
GG09.20.0/44
GG09.20.0/55
GG09.20.0/77
GG09.20/10
Only available on full reels
Only available on full reels
216
217
Fibre rope
Fibre rope
Tasmania / Tasmania Full Color / Tasmania Solid Color / Tasmania T
Lazy-Jack-Line
Construction
■ 12-strand braid of Polyester
HT yarns.
■ Protective coating of Geothane
■ Available in grey and white
Construction
■ Core of 12-strand braided from HT
polyester.
■ Soft and flexible braided cover
from the same material.
■ Large variety of colours.
■ Gleistein’s orange identification
yarn.
Good to know
■ Because of its low friction often used as Furler-Cover-Line
■For the same reason as
Lazy-Jack-Lines
■ Very easy to splice
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Good to know
■ This double braid construction
shares the load equally between
cover and core.
■ Outstanding flexibility and
handling characteristics.
■ Excellent durability.
■ Highly cost-effective.
■ Universal rope ideal for Guys,
Up/Downhauls, Reefing Lines,
Vang and Cunningham.
■ Tasmania T available in hemp and
bronze colour for traditional vessels.
Grey
5
420
250
1,40
GG39.05.0/1
GG39.05.0/2
6
619
200
2,00
GG39.06.0/1
GG39.06.0/2
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Only available on full reels
White
Blue
Red
Green
Yellow
Black
5
600
200
1,6
GG08.05.0/1
GG08.05.0/3
GG08.05.0/4
GG08.05.0/5
GG08.05.0/6
GG08.05.0/7
6
820
200
2,6
GG08.06.0/1
GG08.06.0/3
GG08.06.0/4
GG08.06.0/5
GG08.06.0/6
GG08.06.0/7
8
1200
200
4,0
GG08.08.0/1
GG08.08.0/3
GG08.08.0/4
GG08.08.0/5
GG08.08.0/6
GG08.08.0/7
10
2000
200
6,8
GG08.10.0/1
GG08.10.0/3
GG08.10.0/4
GG08.10.0/5
GG08.10.0/6
GG08.10.0/7
12
2900
200
9,3
GG08.12.0/1
GG08.12.0/3
GG08.12.0/4
GG08.12.0/5
GG08.12.0/6
GG08.12.0/7
14
3550
200
13,0
GG08.14.0/1
GG08.14.0/3
GG08.14.0/4
GG08.14.0/5
GG08.14.0/6
GG08.14.0/7
16
4750
200
18,8
GG08.16.0/1
GG08.16.0/3
GG08.16.0/4
GG08.16.0/5
GG08.16.0/6
GG08.16.0/7
18
6100
200
23,4
GG08.18.0/1
GG08.18.0/3
GG08.18.0/4
GG08.18.0/5
GG08.18.0/6
GG08.18.0/7
20
8000
200
30,0
GG08.20.0/1
GG08.20.0/3
GG08.20.0/4
GG08.20.0/5
GG08.20.0/6
GG08.20.0/7
Tasmania Full Color
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Ref. No.
Blue
Harkon
Construction
■ Core of 12-strand braided
construction of HT continuous
filament polyester.
■ The 2 coloured marker yarns with
an additional purple tracer give
this tight 16-plait HT continuous
filament polyester rope its
distinctive appearance.
■ Gleistein’s orange identification
yarn.
Good to know
■ The double braided construction
shares the load equally between
core and cover.
■ Good abrasion resistance,
handling characteristics and
longevity.
■ Cost-effective.
Green
Red
Black
Yellow
8
1200
200
4,0
GG08.08.0/33
GG08.08.0/44
GG08.08.0/55
GG08.08.0/66
GG08.08.0/77
10
2000
200
6,8
GG08.10.0/33
GG08.10.0/44
GG08.10.0/55
GG08.10.0/66
GG08.10.0/77
12
2900
200
9,3
GG08.12.0/33
GG08.12.0/44
GG08.12.0/55
GG08.12.0/66
GG08.12.0/77
14
3550
200
13,0
GG08.14.0/33
GG08.14.0/44
GG08.14.0/55
GG08.14.0/66
GG08.14.0/77
16
4750
200
18,8
GG08.16.0/33
GG08.16.0/44
GG08.16.0/55
GG08.16.0/66
GG08.16.0/77
18
6100
200
23,4
GG08.18.0/33
GG08.18.0/44
GG08.18.0/55
GG08.18.0/66
GG08.18.0/77
20
8000
200
30,0
GG08.20.0/33
GG08.20.0/44
GG08.20.0/55
GG08.20.0/66
GG08.20.0/77
Tasmania Solid Color
Tasmania T
Ref. No.
Ref. No.
Picture Suzanne v.d. Horst
ø
in mm
Blue
Ref. No.
Red
Green
Navy
Grey
Black
Bronze
Hemp
ø
Breaking Load
Reel Length
Weight
8
GG08.08.0/333
GG08.08.0/444
GG08.08.0/555
GG08.08.0/3N
GG08.08.0/222
GG08.08.0/777
GG08.08.0/8
GG08.08/10
in mm
in daN
in mtr
in kg/ 100 mtr.
10
GG08.10.0/333
GG08.10.0/444
GG08.10.0/555
GG08.10.0/3N
GG08.10.0/222
GG08.10.0/777
GG08.10.0/8
GG08.10/10
12
GG08.12.0/333
GG08.12.0/444
GG08.12.0/555
GG08.12.0/3N
GG08.12.0/222
GG08.12.0/777
GG08.12.0/8
GG08.12/10
White
Blue
Red
Green
Yellow
6
800
200
2,4
GG32.06.0/1
GG32.06.0/3
GG32.06.0/4
GG32.06.0/5
GG32.06.0/6
14
GG08.14.0/333
GG08.14.0/444
GG08.14.0/555
GG08.14.0/3N
GG08.14.0/222
GG08.14.0/777
GG08.14.0/8
GG08.14/10
8
1500
200
4,8
GG32.08.0/1
GG32.08.0/3
GG32.08.0/4
GG32.08.0/5
GG32.08.0/6
16
-
-
-
-
-
GG08.16.0/777
GG08.16.0/8
GG08.16/10
10
2300
7,7
GG32.10.0/1
GG32.10.0/3
GG32.10.0/5
GG32.10.0/6
18
-
-
-
-
-
-
GG08.18.0/8
GG08.18/10
20
-
-
-
-
-
-
GG08.20.0/8
GG08.20/10
200
GG32.10.0/4
12
3000
200
10,4
GG32.12.0/1
GG32.12.0/3
GG32.12.0/4
GG32.12.0/5
GG32.12.0/6
14
3800
200
14,0
GG32.14.0/1
GG32.14.0/3
GG32.14.0/4
GG32.14.0/5
GG32.14.0/6
16
5000
200
18,5
GG32.16.0/1
GG32.16.0/3
GG32.16.0/4
GG32.16.0/5
GG32.16.0/6
Only available on full reels
■ On reels up to 20 mm diam.
Only available on full reels
218
219
Fibre rope
Fibre rope
Gemini X
Cup / Cup Full Color / Cup Solid Color
High-grade polyester sheet with outstanding performance and optimal abrasion
resistance.
The classic, tried and tested for decades; highest efficiency in a polyester rope
through its unique construction.
Construction
■ Core of 12-strand HT polyester
with Marine finish for higher
strength and better abrasion
resistance.
■ Flexible braided cover from the
same material.
■ Twin pairs of coloured yarns of
plain white.
■ Gleistein’s orange identification
yarn.
Construction
■ Core of parallel HT continuous
filament polyester.
■ Inner braided sheath of coarse
synthetic fibre (8mm diameter and
above) binds the core yarns.
■ Outer cover of HT continuous
filament polyester.
■ Gleistein’s orange identification
yarn.
Good to know
■ Gemini (the Greek word for twin)
shares the load equally between
cover and core.
■ Outstanding flexibility and
handling characteristics.
■ Excellent longevity and durability
due to improved abrasions
resistance.
■ Ideal for Genoa- and mainsheets,
especially for selftailing
winch-systems.
Good to know
■ Cup has the lowest stretch possible
in a polyester fibre rope due to the
zero constructional stretch of its
parallel fibre core.
■ With its compact durable
construction Cup becomes more
flexible in use.
■ Very high life expectancy.
■ No creep.
■ Universal rope ideal for Guys,
Up/Downhauls, Reefing Lines,
Vang and Cunningham.
■ Not spliceable above 14 mm diam.
Cup
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Red
Green
Yellow
Black
Ref. No.
ø
Breaking Load
Reel Length
in mm
in daN
in mtr
Weight
in kg/ 100 mtr.
White
Red/Blue
Blue
Red
Green
Yellow
Black
3
170
200
0,7
GG06.03.0/1
GG06.03.0/2
GG06.03.0/3
GG06.03.0/4
GG06.03.0/5
GG06.03.0/6
GG06.03.0/7
8
1500
200
4,0
GG07.08.0/1
GG07.08.0/3
GG07.08.0/4
GG07.08.0/5
GG07.08.0/6
GG07.08.0/7
4
350
200
1,1
GG06.04.0/1
GG06.04.0/2
GG06.04.0/3
GG06.04.0/4
GG06.04.0/5
GG06.04.0/6
GG06.04.0/7
10
2400
200
6,5
GG07.10.0/1
GG07.10.0/3
GG07.10.0/4
GG07.10.0/5
GG07.10.0/6
GG07.10.0/7
5
600
200
1,8
GG06.05.0/1
GG06.05.0/2
GG06.05.0/3
GG06.05.0/4
GG06.05.0/5
GG06.05.0/6
GG06.05.0/7
12
3600
200
9,3
GG07.12.0/1
GG07.12.0/3
GG07.12.0/4
GG07.12.0/5
GG07.12.0/6
GG07.12.0/7
6
780
200
2,7
GG06.06.0/1
GG06.06.0/2
GG06.06.0/3
GG06.06.0/4
GG06.06.0/5
GG06.06.0/6
GG06.06.0/7
14
4500
200
13,0
GG07.14.0/1
GG07.14.0/3
GG07.14.0/4
GG07.14.0/5
GG07.14.0/6
GG07.14.0/7
8
1300
200
4,5
GG06.08.0/1
GG06.08.0/2
GG06.08.0/3
GG06.08.0/4
GG06.08.0/5
GG06.08.0/6
GG06.08.0/7
16
6500
200
18,3
GG07.16.0/1
GG07.16.0/3
GG07.16.0/4
GG07.16.0/5
GG07.16.0/6
GG07.16.0/7
10
2200
200
7,3
GG06.10.0/1
GG06.10.0/2
GG06.10.0/3
GG06.10.0/4
GG06.10.0/5
GG06.10.0/6
GG06.10.0/7
18
8300
200
23,3
GG07.18.0/1
GG07.18.0/3
GG07.18.0/4
GG07.18.0/5
GG07.18.0/6
GG07.18.0/7
12
3200
200
9,5
GG06.12.0/1
GG06.12.0/2
GG06.12.0/3
GG06.12.0/4
GG06.12.0/5
GG06.12.0/6
GG06.12.0/7
20
10000
200
29,0
GG07.20.0/1
GG07.20.0/3
GG07.20.0/4
GG07.20.0/5
GG07.20.0/6
GG07.20.0/7
14
4600
200
13,5
GG06.14.0/1
GG06.14.0/2
GG06.14.0/3
GG06.14.0/4
GG06.14.0/5
GG06.14.0/6
GG06.14.0/7
22
12200
200
35,0
GG07.22.0/1
GG07.22.0/3
GG07.22.0/4
GG07.22.0/5
GG07.22.0/6
GG07.22.0/7
16
6500
200
18,3
GG06.16.0/1
GG06.16.0/2
GG06.16.0/3
GG06.16.0/4
GG06.16.0/5
GG06.16.0/6
GG06.16.0/7
24
14500
200
42,0
GG07.24.0/1
GG07.24.0/3
GG07.24.0/4
GG07.24.0/5
GG07.24.0/6
GG07.24.0/7
18
7700
200
21,0
GG06.18.0/1
GG06.18.0/2
GG06.18.0/3
GG06.18.0/4
GG06.18.0/5
GG06.18.0/6
GG06.18.0/7
26
17000
200
49,0
GG07.26.0/1
GG07.26.0/3
GG07.26.0/4
GG07.26.0/5
GG07.26.0/6
GG07.26.0/7
28
19600
200
59,0
GG07.28.0/1
GG07.28.0/3
GG07.28.0/4
GG07.28.0/5
GG07.28.0/6
GG07.28.0/7
30
22500
200
68,0
GG07.30.0/1
GG07.30.0/3
GG07.30.0/4
GG07.30.0/5
GG07.30.0/6
GG07.30.0/7
32
25500
200
77,5
GG07.32.0/1
GG07.32.0/3
GG07.32.0/4
GG07.32.0/5
GG07.32.0/6
GG07.32.0/7
34
29000
200
87,0
GG07.34.0/1
GG07.34.0/3
GG07.34.0/4
GG07.34.0/5
GG07.34.0/6
GG07.34.0/7
36
32100
200
98,0
GG07.36.0/1
GG07.36.0/3
GG07.36.0/4
GG07.36.0/5
GG07.36.0/6
GG07.36.0/7
Only available on full reels
■ On reels up to 20 mm diam.
Cup Full Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
Green
Yellow
Black
6
780
200
2,7
GG06.06.0/33
GG06.06.0/44
GG06.06.0/55
GG06.06.0/66
GG06.06.0/77
8
1300
200
4,5
GG06.08.0/33
GG06.08.0/44
GG06.08.0/55
GG06.08.0/66
GG06.08.0/77
10
2200
200
7,3
GG06.10.0/33
GG06.10.0/44
GG06.10.0/55
GG06.10.0/66
GG06.10.0/77
12
3200
200
9,5
GG06.12.0/33
GG06.12.0/44
GG06.12.0/55
GG06.12.0/66
GG06.12.0/77
14
4600
200
13,5
GG06.14.0/33
GG06.14.0/44
GG06.14.0/55
GG06.14.0/66
GG06.14.0/77
Cup Solid Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
Green
Grey
Black
6
780
200
2,7
GG06.06.0/333
GG06.06.0/444
GG06.06.0/555
GG06.06.0/222
GG06.06.0/777
8
1300
200
4,5
GG06.08.0/333
GG06.08.0/444
GG06.08.0/555
GG06.08.0/222
GG06.08.0/777
10
2200
200
7,3
GG06.10.0/333
GG06.10.0/444
GG06.10.0/555
GG06.10.0/222
GG06.10.0/777
12
3200
200
9,5
GG06.12.0/333
GG06.12.0/444
GG06.12.0/555
GG06.12.0/222
GG06.12.0/777
14
4600
200
13,5
GG06.14.0/333
GG06.14.0/444
GG06.14.0/555
GG06.14.0/222
GG06.14.0/777
Only available on full reels
220
221
Fibre rope
Fibre rope
Cup T (Traditional)
Racing cover
High performance sheets/ halyards for traditional yachts.
Construction
■ cover of 50% coloured HT polyester yarns and 50% Technora yarns
■ Inside cover is a messen-
ger to pull DynaOne or DynaOne HS inside cover
Construction
■ Core of parallel HT continuous
filament polyester.
■ Inner braided sheath of coarse
synthetic fibre (8mm diameter and
above) binds the core yarns.
■ Outer cover of bronze and hemp
coloured HT polyester yarns.
Good to know
■ Cup has the lowest stretch possible
in a polyester fibre rope due to the
zero constractional stretch of its
parallel fibre core.
■ With its compact durable
construction Cup becomes more
flexible in use.
■ Very high life expectancy.
■ No creep.
■ Universal rope ideal for Guys,
Up/Downhauls, Reefing Lines,
Vang and Cunningham.
■ Easy to splice.
■ Not spliceable above 14 mm diam.
Good to know
■ The friction from the Techno fibres
overcome slipping the DynaOne
through the cover
■ Specially for making halyards with
low windage
Ref. No.
ø
Reel Length
in mm
in mtr
Technora/
Technora/
Technora/
Technora/
Technora/
Technora/
Technora/
White
Grey
Blue
Red
Green
Yellow
Black
10
200
GG53.10.0/1
GG53.10.0/2
GG53.10.0/3
GG53.10.0/4
GG53.10.0/5
GG53.10.0/6
GG53.10.0/7
12
200
GG53.12.0/1
GG53.12.0/2
GG53.12.0/3
GG53.12.0/4
GG53.12.0/5
GG53.12.0/6
GG53.12.0/7
Only available on full reels
Discover
Take the rough with the smooth: high performance sheet with an extra grip
through the sophisticated fibre-mix.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Bronze
Hemp
8
1300
200
4,5
GG06.08.0/8
GG06.08/10
10
2200
200
7,3
GG06.10.0/8
GG06.10/10
12
3200
200
9,5
GG06.12.0/8
GG06.12/10
14
4600
200
13,5
GG06.14.0/8
GG06.14/10
16
6500
200
18,3
GG06.16.0/8
GG06.16/10
18
7700
200
21,0
GG06.18.0/8
GG06.18/10
Construction
■ 8-Plait, blended from Dyneema®
SK75 and polyester staple fibre.
■ Available in white/red, white/blue and white/grey
Picture Suzanne v.d. Horst
Ref. No.
Only available on full reels
* 222
Good to know
■ Very supple and handy braid with
excellent handle-ability.
■ Excellent in jammers.
■ High knotted strength.
■ Universal rope for a large variety of
applications,
especially
for
Dinghies and main sheets for racing
and
cruising yachts
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Grey
Blue
Red
3
350
200
0,54
-
GG48.03.0/3
GG48.03.0/4
4
500
200
0,73
-
GG48.04.0/3
GG48.04.0/4
5
800
200
1,29
GG48.05.0/2
GG48.05.0/3
GG48.05.0/4
6
1200
200
1,80
GG48.06.0/2
GG48.06.0/3
GG48.06.0/4
8
1800
200
3,60
GG48.08.0/2
GG48.08.0/3
GG48.08.0/4
10
2900
200
5,40
GG48.10.0/2
GG48.10.0/3
GG48.10.0/4
12
3500
200
7,60
GG48.12.0/2
GG48.12.0/3
GG48.12.0/4
*
*
*
With inner core
Only available on full reels
223
Fibre rope
Fibre rope
Dyna Lite / Dyna Lite Full Color / Dyna Lite Solid Color / Dyna Lite T
Mega Twin Dyneema
Economic high performance sheet / halyard for cuising yachts.
The superiour sheet/ halyard for racing and cruising yachts.
Compatability that pays.
The heavier polyester cover on the smaller Dyneema® core gives slightly lower
strength, to match standard fittings.
Dyna Lite is the ideal rope for the most cost-concious competative yachtsman.
Powerful and universal.
The combination of Dyneema® core and firm double cover construction gives
maximum strength and minimum stretch with extraordinary stable shape
refension and abrasion resistance.
Construction
■ Core of 12-strand braid of
Dyneema® SK75 fibres.
■ Intermediate cover of polyester
staple fibres to give frictional hold
between the Dyneema core and
the outer cover.
■ Outer cover of white HT polyester
yarns with various melt dyed
coloured marker yarns. The 24 or
32 strand (depending on rope
size) braided cover gives
exceptional abrasion resistance
whilst maintaining flexibility.
■ Gleistein’s orange identification
yarn.
Construction
■ Core of 12-strand braid of
Dyneema® SK75 fibres.
■ Intermediate cover of polyester
staple fibres to give frictional
hold between the Dyneema core
and the outer cover and stable cross sectional shape.
■ Outer cover of white HT polyester
yarns with various colour coded
melt-dyed yarns. The 24 or 32
strand (depending on the rope
size) braided cover gives
exceptional abrasion resistance
whilst maintaining flexibility.
■ Gleistein’s orange identification
yarn.
Good to know
■ Similar stretch characteristics to
steel wire rope with slight lower
strength make Dyna Lite an ideal
economic choice for cruising
yachtsmen and original equipment
manufacturers (O.E.M.)
■ Exceptional abrasion resistance,
excellent in stoppers.
■ Dyna Lite can be tapered by the
removal of sections of the outer
cover.
■ Even with its lower strength than
full Dyneema the low stretch of
Dyna Lite means that high shock
loads (particularly in Spi halyards)
■
associated fittings such as
spinnaker heads, which should be
reinforced accordingly.
Alternatively a polyester halyard
could be used.
Spliceable using the correct
technique.
Dyna Lite
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Red
Green
Yellow
6
1200
200
2,3
GG31.06.0/1
GG31.06.0/3
GG31.06.0/4
GG31.06.0/5
GG31.06.0/6
8
1650
200
3,8
GG31.08.0/1
GG31.08.0/3
GG31.08.0/4
GG31.08.0/5
GG31.08.0/6
10
3000
200
5,9
GG31.10.0/1
GG31.10.0/3
GG31.10.0/4
GG31.10.0/5
GG31.10.0/6
12
5100
200
8,9
GG31.12.0/1
GG31.12.0/3
GG31.12.0/4
GG31.12.0/5
GG31.12.0/6
14
7500
200
11,6
GG31.14.0/1
GG31.14.0/3
GG31.14.0/4
GG31.14.0/5
GG31.14.0/6
16
9500
200
15,2
GG31.16.0/1
GG31.16.0/3
GG31.16.0/4
GG31.16.0/5
GG31.16.0/6
Dyna Lite Full Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
Green
Yellow
6
1200
200
2,3
GG31.06.0/33
GG31.06.0/44
GG31.06.0/55
GG31.06.0/66
8
1650
200
3,8
GG31.08.0/33
GG31.08.0/44
GG31.08.0/55
GG31.08.0/66
10
3000
12
5100
200
8,9
GG31.12.0/33
GG31.12.0/44
GG31.12.0/55
GG31.12.0/66
14
7500
200
11,6
GG31.14.0/33
GG31.14.0/44
GG31.14.0/55
GG31.14.0/66
GG31.16.0/33
GG31.16.0/44
GG31.16.0/55
GG31.16.0/66
200
5,9
GG31.10.0/33
GG31.10.0/44
Dyna Lite Solid Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Grey
Black
GG31.10.0/55
GG31.10.0/66
Good to know
■ Similar strength and stretch to
steel
wire rope of comparable size.
■ Abrasion resistant outer cover
particularly suitable for stoppers.
■ The creep (non-recoverable
stretch of this fibre) means that
long term halyard re-adjustment
might be necessary.
■ The very low stretch of Dyneema
means that high shockloads
(particularly in Spi halyards) will
be directly transmitted to
associated fittings such as
spinnaker heads which should be
re-inforced accordingly.
Alternatively a polyester halyard
could be used.
■ Dyneema ropes can be tapered
■
■
■
by the removal of sections of
outer cover. For a fully uncovered
Dyneema rope we recommend
DYNA ONE with its coloured
abrasion resistant GEOTHANE
coating.
Universal rope ideal for Guys,
Up/Downhauls, Reefing Lines,
Vang and Cunningham.
Spliceable using the correct
technique.
For smaller sizes than 6 mm use caribic color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
White
Blue
Red
Green
Yellow
Black
6
1650
200
2,6
GG02.06.0/1
GG02.06.0/3
GG02.06.0/4
GG02.06.0/5
GG02.06.0/6
GG02.06.0/7
8
3000
200
4,0
GG02.08.0/1
GG02.08.0/3
GG02.08.0/4
GG02.08.0/5
GG02.08.0/6
GG02.08.0/7
10
5100
200
6,8
GG02.10.0/1
GG02.10.0/3
GG02.10.0/4
GG02.10.0/5
GG02.10.0/6
GG02.10.0/7
12
7500
200
9,9
GG02.12.0/1
GG02.12.0/3
GG02.12.0/4
GG02.12.0/5
GG02.12.0/6
GG02.12.0/7
14
9500
200
13,3
GG02.14.0/1
GG02.14.0/3
GG02.14.0/4
GG02.14.0/5
GG02.14.0/6
GG02.14.0/7
16
12000
200
17,5
GG02.16.0/1
GG02.16.0/3
GG02.16.0/4
GG02.16.0/5
GG02.16.0/6
GG02.16.0/7
18
15000
200
22,3
GG02.18.0/1
GG02.18.0/3
GG02.18.0/4
GG02.18.0/5
GG02.18.0/6
GG02.18.0/7
20
19000
200
28,0
GG02.20.0/1
GG02.20.0/3
GG02.20.0/4
GG02.20.0/5
GG02.20.0/6
GG02.20.0/7
22
23000
200
32,7
GG02.22.0/1
GG02.22.0/3
GG02.22.0/4
GG02.22.0/5
GG02.22.0/6
GG02.22.0/7
24
25500
200
38,9
GG02.24.0/1
GG02.24.0/3
GG02.24.0/4
GG02.24.0/5
GG02.24.0/6
GG02.24.0/7
26
27500
200
44,0
GG02.26.0/1
GG02.26.0/3
GG02.26.0/4
GG02.26.0/5
GG02.26.0/6
GG02.26.0/7
28
31700
200
46,0
GG02.28.0/1
GG02.28.0/3
GG02.28.0/4
GG02.28.0/5
GG02.28.0/6
GG02.28.0/7
30
36000
200
58,0
GG02.30.0/1
GG02.30.0/3
GG02.30.0/4
GG02.30.0/5
GG02.30.0/6
GG02.30.0/7
Only available on full reels
■ On reels up to 16 mm diam.
Dyna Lite T
Ref. No.
Bronze
Hemp
8
1650
200
3,8
GG31.08.0/222
GG31.08.0/777
GG31.08.0/8
GG31.08/10
10
3000
200
5,9
GG31.10.0/222
GG31.10.0/777
GG31.10.0/8
GG31.10/10
12
5100
200
8,9
GG31.12.0/222
GG31.12.0/777
GG31.12.0/8
GG31.12/10
14
7500
200
11,6
-
-
GG31.14.0/8
GG31.14/10
Only available on full reels
224
225
Fibre rope
Fibre rope
Mega Twin Dyneema Full Color / Dyneema Solid Color / Dyneema T
Mega Twin Dyneema HS
The superiour sheet/ halyard for racing and cruising yachts.
The rope for winners with a touch more break load: Heat-set core for even
better strenght and lower elongation.
Full coloured Dyneema has a full red/ blue or green coloured polyester cover with
white tracer yarns
Construction
■ The construction of the Full Color
is the is the same as Mega Twin
Dyneema
Good to know
■ For smaller sizes than 8mm
use caribic color
Dyneema Full Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
Green
Yellow
Black
8
3000
200
4,0
GG02.08.0/33
GG02.08.0/44
GG02.08.0/55
GG02.08.0/66
GG02.08.0/77
10
5100
200
6,8
GG02.10.0/33
GG02.10.0/44
GG02.10.0/55
GG02.10.0/66
GG02.10.0/77
12
7500
200
9,9
GG02.12.0/33
GG02.12.0/44
GG02.12.0/55
GG02.12.0/66
GG02.12.0/77
14
9500
200
13,3
GG02.14.0/33
GG02.14.0/44
GG02.14.0/55
GG02.14.0/66
GG02.14.0/77
Dyneema Solid Color
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Grey
Black
Dyneema T
Ref. No.
Bronze
Hemp
8
3000
200
4,0
GG02.08.0/222
GG02.08.0/777
GG02.08.0/8
GG02.08/10
10
5100
200
6,8
GG02.10.0/222
GG02.10.0/777
GG02.10.0/8
GG02.10/10
12
7500
200
9,9
GG02.12.0/222
GG02.12.0/777
GG02.12.0/8
GG02.12/10
14
9500
200
13,3
GG02.14.0/222
GG02.14.0/777
GG02.14.0/8
GG02.14/10
Only available on full reels
Construction
■ Core of 12-strand braid of
Dyneema® SK75 fibres heat set.
■ Intermediate cover of polyester
staple fibres.
■ 24 or 32-plait cover of HT
continuous filament polyester
yarns.
■ Outer cover grey with red or blue
marker yarns.
■ Gleistein’s orange identification
yarn.
Good to know
■Similar strength and stretch to
steel wire rope.
■ Abrasion resistant outer cover
particularly suitable for stoppers.
■ Very stable cross-section.
■ The creep (non-recoverable
stretch) of Dyneema® SK75
means that long term halyard
re-adjustment might be necessary.
■ The very low stretch of Dyneema
means that high shockloads
(particularly in Spi halyards) will
be directly transmitted to
associated fittings such as
spinnaker heads which should be
re-inforced accordingly.
Alternatively a polyester halyard
could be used.
■ Dyneema ropes can be tapered
by the removal of sections of
outer cover.
■ Universal rope ideal for Guys,
Up/Downhauls, Reefing Lines,
Vang and Cunningham.
Winner 1010
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Blue
Red
8
5000
200
4,6
GG49.08.0/3
GG49.08.0/4
10
7500
200
7,3
GG49.10.0/3
GG49.10.0/4
12
9500
200
9,8
GG49.12.0/3
GG49.12.0/4
14
12000
200
13,8
GG49.14.0/3
GG49.14.0/4
16
15000
200
17,0
GG49.16.0/3
GG49.16.0/4
18
17000
200
22,5
GG49.18.0/3
GG49.18.0/4
20
24000
200
28,0
GG49.20.0/3
GG49.20.0/4
22
28000
200
31,0
GG49.22.0/3
GG49.22.0/4
24
38000
200
37,0
GG49.24.0/3
GG49.24.0/4
26
44000
200
48,0
GG49.26.0/3
GG49.26.0/4
28
51500
200
53,0
GG49.28.0/3
GG49.28.0/4
30
59000
200
58,0
GG49.30.0/3
GG49.30.0/4
Only available on full reels
■ On reels up to 16 mm diam.
“Witte-Woerd”
226
De Ridder One Design
227
Fibre rope
Fibre rope
Mega Twin T4
Mega Twin T4 noveni
Perfection to the very end: an abrasion resistant, flexible high-performance line
without intermediate cover for easy splicing.
Performance that achieves its goal. Flexible, spliceable - and now with even
more strength: The abrasion-resistant, high-performance rope with Dyneema®
SK90.
Construction
■ Core 12-strand braid blended
with Dyneema® SK75 fibres and
a new, special type of fibre for
improved core-cover grip
■ Core additionally features a newly-developed surface coating
enabling relinquishment of intermediate cover
■ Cover solid color, 24-strand
braid from high-twist twine in
various solid colors
■ Gleistein’s orange ID yarn
Construction
■ Core 12-strand braid blended
with Dyneema® SK90 fibres and
a new, special type of fibre for
improved core-cover grip further
increased strength
■ Core additionally features a newly-developed surface coating
enabling relinquishment of intermediate cover
■ Cover solid color, 24-strand
braid from high-twist twine in
various solid colors
■ Gleistein’s orange ID yarn
228
Good to know
■ Outstanding breaking load with
low elongation
■ Excellent abrasion resistance
■ Flexible, easy-to-handle
Dyneema® line
■ Ideal for sheets, up/downhauls
and tack lines
■ Easy to splice
■ Can be used stripped of cover, if
required
Good to know
■ Up to 15% more strength and
optimised elongation, when
compared with MegaTwin T4
■ Ultimate breaking load with low
elongation
■ Excellent abrasion resistance
■ Flexible, easy-to-handle
Dyneema® line
■ MegaTwin T4 noveni works best
where a high breaking load is
required with a uniformly small
deflection radius
■ Ideal for sheets, up/downhauls
and tack lines
■ Easy to splice
■ Can be used stripped of cover, if
required
ø
Breaking Load
Weight
ø
Breaking Load
Weight
in mm
in daN
in kg/ 100 mtr.
in mm
in daN
in kg/ 100 mtr.
4
630
1,05
4
725
1,05
5
1100
1,70
5
1250
1,70
6
1500
3,10
6
1700
3,10
8
2700
4,50
8
3100
4,50
10
4500
6,10
10
5100
6,10
12
6800
8,70
12
7800
8,70
14
8500
12,50
14
9750
12,50
16
10500
16,20
16
12000
16,20
18
13500
21,70
18
15500
21,70
20
17000
28,00
20
19500
28,00
22
20500
33,00
22
23000
33,00
24
23000
39,00
24
26000
39,00
229
Fibre rope
Fibre rope
G2
TaperTwin
Light at the clew handleable in the cockpit
Bespoke racing performance:
feather-light at the clew, handleable at the winch, excellent in stoppers.
Construction
■ Core caribic color
■ Cover 16-strand solid
color Standard sheet
Construction
■ For stripping and tapering.
■ Core 12-plait Dyneema® SK75
heat set with Geothane coating
in green or red.
■ Cover 24 or 32-plait of HT
polyester with matching marker
yarns.
■ Gleistein’s orange identification
yarn.
Good to know
■ G2 is the rope for stripping
and tapering
■ Spinnacker light weather sheets
■ No stretch good handling
■ Color of core and cover are matched
for improved identification on board
G2
Good to know
■ TaperTwin is the rope for stripping
and tapering.
■ The construction of the core braid
is optimized for enhanced
abrasion resistance and improved
UV stability.
■ Highest break load at lowest
weight.
■ Colour of core and cover are
matched for improved
identification on board.
X-35
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
4 - 6,5
650
250
2,6
Red
Green
GGG20.4.0/4
GGG20.4.0/5
Ref. No.
Spliced Versus Knotted Rope Break Strength
Spliced
Knotted Break Strength
Rope Type
ø mm
Break Load
daN
Max. Loss
Break Load
Bowline
daN
Thimber Hitch
daN
Figure Eight
Knot
daN
Gemini X
16
6500
- 39 %
4000
4575
4400
Tasmania
12
2900
- 40 %
1750
2650
1925
Cup
12
3200
- 39 %
1950
2300
2150
Megatwin Dyneema®
16
12000
- 56 %
5250
7650
5875
Dyna Lite
16
9500
- 62 %
3575
6800
4650
Megatwin Vectran®
16
9700
- 67 %
3250
6725
4175
MegaOne DynaOne
16
20500
- 78 %
4500
6515
6450
MegaOne DynaOne
10
8500
- 72 %
2375
4025
2850
MegaOne DynaOne
6
2700
- 67 %
890
1630
1340
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Red
Green
2,5 - 4,0
400
200
1,1
GG51.02.5/4
GG51.02.5/5
3,0 - 5,0
700
200
1,7
GG51.03.0/4
GG51.03.0/5
4,0 - 6,0
1650
200
2,4
GG51.04.0/4
GG51.04.0/5
5,0 - 8,0
2900
200
3,9
GG51.05.0/4
GG51.05.0/5
Only available on full reels
Professionally executed splices are the most efficient end termination of ropes. They ensure that a high
degree of the linear break load of a rope can be achieved in use. Knots can reduce the linear break load by
more than 50%.
X-35
230
231
Fibre rope
Fibre rope
DynaOne / DynaOne T
DynaOne HS
Ultimate performance in its purest form: floating wire rope without the snags.
Optimized: the ultimate light-weight with perfect
performance characteristics.
The choice of a winning boat with 8 times the strength weight ratio of steel
wire rope. DynaOne has the incomparable properties of Dyneema® SK75 fibre
in a unique construction.
Construction
■ 12-Strand braid of 100%
Dyneema® SK75 fibres.
■ Protective coating of coloured
GEOTHANE.
■ Available in a range of solid
colours.
Good to know
■ DynaOne floats.
■ In stoppers and areas of frequent
contact it is suggested to fix an
additional outer sheath of plaited
polyester in place (sewn and
seized).
Alternatively the use of TaperTwin
is suggested.
■ DynaOne should only be used
with fittings and equipments of
comparable strength and
robustness.
■ Fusion abrasion - due to frictional
■
Construction
■ 12-Strand braid of 100%
Dyneema® SK75 fibres heat set.
■ Protective coating of coloured
GEOTHANE.
■ Available in a range of solid
colours.
high temperatures - could be
dramatically reduced by the
copious application of water (or
other liquid substances just as
readily available on many yachts).
Ideal for halyards, Up/Down-hauls,
Reefing Lines or Sheet.
DynaOne
DynaOne T
Ref. No.
ø
in mm
Breaking Load Reel Length
in daN
in mtr
Good to know
■ DynaOne HS has the extra amount
of break load for extreme
applications.
■ Through the heat set process very
stable cross section.
■ The initial stiffness will soften up
severely in use.
Ref. No.
Weight
DynaOne HS noveni
in kg/ 100 mtr.
Grey
White
Blue
Red
Green
Yellow
Hemp
350
200
0,25
GG05.02.0/0
GG05.02.0/1
GG05.02.0/3
GG05.02.0/4
GG05.02.0/5
GG05.02.0/6
GG05.02/10
3,0
706
200
0,48
GG05.03.0/0
GG05.03.0/1
GG05.03.0/3
GG05.03.0/4
GG05.03.0/5
GG05.03.0/6
GG05.03/10
4,0
1200
200
0,80
GG05.04.0/0
GG05.04.0/1
GG05.04.0/3
GG05.04.0/4
GG05.04.0/5
GG05.04.0/6
GG05.04/10
5,0
2300
200
1,45
GG05.05.0/0
GG05.05.0/1
GG05.05.0/3
GG05.05.0/4
GG05.05.0/5
GG05.05.0/6
GG05.05/10
6,0
2700
200
2,00
GG05.06.0/0
GG05.06.0/1
GG05.06.0/3
GG05.06.0/4
GG05.06.0/5
GG05.06.0/6
GG05.06/10
7,0
3915
200
2,90
GG05.07.0/0
GG05.07.0/1
GG05.07.0/3
GG05.07.0/4
GG05.07.0/5
GG05.07.0/6
GG05.07/10
2,0
■
■
■
■
This is the same rope produced
from Dyneema SK90 fibres
Breaking loads are approx. 12%
more
Creep stays unchanged
Available on request
8,0
5000
200
3,50
GG05.08.0/0
GG05.08.0/1
GG05.08.0/3
GG05.08.0/4
GG05.08.0/5
GG05.08.0/6
GG05.08/10
10,0
8500
200
4,80
GG05.10.0/0
GG05.10.0/1
GG05.10.0/3
GG05.10.0/4
GG05.10.0/5
GG05.10.0/6
GG05.10/10
12,0
11500
200
8,20
GG05.12.0/0
GG05.12.0/1
GG05.12.0/3
GG05.12.0/4
GG05.12.0/5
GG05.12.0/6
GG05.12/10
14,0
14200
200
10,50
GG05.14.0/0
GG05.14.0/1
GG05.14.0/3
GG05.14.0/4
GG05.14.0/5
GG05.14.0/6
GG05.14/10
16,0
17000
200
12,00
GG05.16.0/0
GG05.16.0/1
GG05.16.0/3
GG05.16.0/4
GG05.16.0/5
GG05.16.0/6
GG05.16/10
18,0
22000
200
16,50
GG05.18.0/0
GG05.18.0/1
GG05.18.0/3
GG05.18.0/4
GG05.18.0/5
GG05.18.0/6
GG05.18/10
ø
Breaking Load
Reel Length
Weight
20,0
26500
200
20,00
GG05.20.0/0
GG05.20.0/1
GG05.20.0/3
GG05.20.0/4
GG05.20.0/5
GG05.20.0/6
GG05.20/10
in mm
in daN
in mtr
in kg/ 100 mtr.
22,0
32500
200
24,00
GG05.22.0/0
GG05.22.0/1
GG05.22.0/3
GG05.22.0/4
GG05.22.0/5
GG05.22.0/6
GG05.22/10
24,0
38000
200
29,50
GG05.24.0/0
GG05.24.0/1
GG05.24.0/3
GG05.24.0/4
GG05.24.0/5
GG05.24.0/6
GG05.24/10
Only available on full reels
■ On reels up to 16 mm diam.
X-35
Ref. No.
Grey
White
Blue
Red
Green
Yellow
3
900
200
0,60
GG05.03.0/0HS GG05.03.0/1HS GG05.03.0/3HS GG05.03.0/4HS GG05.03.0/5HS GG05.03.0/6HS
4
1700
200
0,95
GG05.04.0/0HS GG05.04.0/1HS GG05.04.0/3HS GG05.04.0/4HS GG05.04.0/5HS GG05.04.0/6HS
5
2900
200
1,65
GG05.05.0/0HS GG05.05.0/1HS GG05.05.0/3HS GG05.05.0/4HS GG05.05.0/5HS GG05.05.0/6HS
6
3700
200
2,10
GG05.06.0/0HS GG05.06.0/1HS GG05.06.0/3HS GG05.06.0/4HS GG05.06.0/5HS GG05.06.0/6HS
7
5650
200
3,40
GG05.07.0/0HS
8
7500
200
4,20
GG05.08.0/0HS GG05.08.0/1HS GG05.08.0/3HS GG05.08.0/4HS GG05.08.0/5HS GG05.08.0/6HS
10
9900
200
5,60
GG05.10.0/0HS GG05.10.0/1HS GG05.10.0/3HS GG05.10.0/4HS GG05.10.0/5HS GG05.10.0/6HS
12
17000
200
9,70
GG05.12.0/0HS GG05.12.0/1HS GG05.12.0/3HS GG05.12.0/4HS GG05.12.0/5HS GG05.12.0/6HS
14
24000
200
13,50
GG05.14.0/0HS GG05.14.0/1HS GG05.14.0/3HS GG05.14.0/4HS GG05.14.0/5HS GG05.14.0/6HS
16
28000
200
15,30
GG05.16.0/0HS GG05.16.0/1HS GG05.16.0/3HS GG05.16.0/4HS GG05.16.0/5HS GG05.16.0/6HS
18
38000
200
20,50
GG05.18.0/0HS GG05.18.0/1HS GG05.18.0/3HS GG05.18.0/4HS GG05.18.0/5HS GG05.18.0/6HS
20
44000
200
23,50
GG05.20.0/0HS GG05.20.0/1HS GG05.20.0/3HS GG05.20.0/4HS GG05.20.0/5HS GG05.20.0/6HS
22
51500
200
27,50
GG05.22.0/0HS GG05.22.0/1HS GG05.22.0/3HS GG05.22.0/4HS GG05.22.0/5HS GG05.22.0/6HS
24
59000
200
31,50
GG05.24.0/0HS GG05.24.0/1HS GG05.24.0/3HS GG05.24.0/4HS GG05.24.0/5HS GG05.24.0/6HS
-
GG05.07.0/3HS GG05.07.0/4HS GG05.07.0/5HS
-
Only available on full reels
■ On reels up to 16 mm diam.
232
233
Fibre rope
Fibre rope
DynaOne HS GeoBend
Mega Twin Vectran / Vectran Solid Color
Around the bend: the remarkable strength and low
weight of Dyneema® with up to 15x longer operational life under under flexural stresses
The ultimate halyard / sheet for racing- and large yachts.
0 % Creep under load and 100 % abrasion resistance: the ideal rope for
hydraulically tensioned halyards.
Construction
■ 12-Strand braid from a Dyneema® SK75 fibre
blend incorporating a special internal lubricating
fibre to reduce inner abrasion
■ Newly-developed special coating provides
improved performance for bending and alternating loads
■ Available in grey
Construction
■ Core of 12-strand braided Vectran® HS fibres.
■ Intermediate cover of polyester staple fibres to
give frictional hold between VECTRAN core and
the outer cover and stable cross-sectional shape.
■ Outer cover of melt-dyed gold HT Polyester yarns
(plain white is also available) with various coloured
marker yarns. The 24 or 32 strand (depending on
the size) cover gives exceptional abrasion resistance whilst maintaining flexibility.
■ Gleistein’s orange identification yarn.
Good to know
■ Ideal for application on davit cranes and winches
■ Neutral buoyancy
■ Wire rope replacement enabling smaller bend
radiuses
■ Cleaner due to the absence of metal dust and
wire rope grease
■ Special splicing technique ensures maximum
exploitation of breaking load in the minimum of
space
■ Installation service by Gleistein riggers ensures
safe and sound application
■ DynaOne HS GeoBend is approved by
Germanischen Lloyd (GL) for use in davits
Vectran
Ref. No.
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Grey
10
9600
200
5,55
GG05.10.0/0HSGB
12
16500
200
9,64
GG05.12.0/0HSGB
14
23200
200
13,50
GG05.14.0/0HSGB
16
27000
200
15,30
GG05.16.0/0HSGB
18
37000
200
20,50
GG05.18.0/0HSGB
20
42500
200
23,50
GG05.20.0/0HSGB
22
50000
200
27,50
GG05.22.0/0HSGB
24
57000
200
31,50
GG05.24.0/0HSGB
26
64500
200
35,50
GG05.26.0/0HSGB
28
71500
200
39,50
GG05.28.0/0HSGB
30
79000
200
43,50
GG05.30.0/0HSGB
Load / Elongation curves
50
Load as %-age of BL
Ref. No.
ø
40
30
ø
Breaking
Reel
in mm
Load
Length
in daN
in mtr
Weight
in kg/
100 mtr. White/Blue
White/Red
White/Green
White/Black
Yellow/Blue
Yellow/Red
Yellow/Green Yellow/Black
4
750
200
1,5
GG01.04.0/3
GG01.04.0/4
GG01.04.0/5
GG01.04.0/7
GG01.04.0/36 GG01.04.0/46
GG01.04.0/56 GG01.04.0/76
5
1000
200
2,3
GG01.05.0/3
GG01.05.0/4
GG01.05.0/5
GG01.05.0/7
GG01.05.0/36 GG01.05.0/46
GG01.05.0/56 GG01.05.0/76
6
1300
200
2,5
GG01.06.0/3
GG01.06.0/4
GG01.06.0/5
GG01.06.0/7
GG01.06.0/36 GG01.06.0/46
GG01.06.0/56 GG01.06.0/76
8
2250
200
5,0
GG01.08.0/3
GG01.08.0/4
GG01.08.0/5
GG01.08.0/7
GG01.08.0/36 GG01.08.0/46
GG01.08.0/56 GG01.08.0/76
10
3900
200
7,2
GG01.10.0/3
GG01.10.0/4
GG01.10.0/5
GG01.10.0/7
GG01.10.0/36 GG01.10.0/46
GG01.10.0/56 GG01.10.0/76
12
6000
200
11,0
GG01.12.0/3
GG01.12.0/4
GG01.12.0/5
GG01.12.0/7
GG01.12.0/36 GG01.12.0/46
GG01.12.0/56 GG01.12.0/76
14
7800
200
15,0
GG01.14.0/3
GG01.14.0/4
GG01.14.0/5
GG01.14.0/7
GG01.14.0/36 GG01.14.0/46
GG01.14.0/56 GG01.14.0/76
16
9700
200
19,0
GG01.16.0/3
GG01.16.0/4
GG01.16.0/5
GG01.16.0/7
GG01.16.0/36 GG01.16.0/46
GG01.16.0/56 GG01.16.0/76
18
12300
200
26,4
GG01.18.0/3
GG01.18.0/4
GG01.18.0/5
GG01.18.0/7
GG01.18.0/36 GG01.18.0/46
GG01.18.0/56 GG01.18.0/76
20
14600
200
32,5
GG01.20.0/3
GG01.20.0/4
GG01.20.0/5
GG01.20.0/7
GG01.20.0/36 GG01.20.0/46
GG01.20.0/56 GG01.20.0/76
22
18000
200
35,8
GG01.22.0/3
GG01.22.0/4
GG01.22.0/5
GG01.22.0/7
GG01.22.0/36 GG01.22.0/46
GG01.22.0/56 GG01.22.0/76
24
22000
200
42,6
GG01.24.0/3
GG01.24.0/4
GG01.24.0/5
GG01.24.0/7
GG01.24.0/36 GG01.24.0/46
GG01.24.0/56 GG01.24.0/76
28
29600
200
58,0
GG01.28.0/3
GG01.28.0/4
GG01.28.0/5
GG01.28.0/7
GG01.28.0/36 GG01.28.0/46
GG01.28.0/56 GG01.28.0/76
20
Vectran Solid Color
Ref. No.
10
ø
Breaking
Reel
in mm
Load
Length
in kg/
in daN
in mtr
100 mtr.
■ Bigger sizes up to 64 mm available
0
1
2
3
4
5
6
7
8
9
10
%-Elongation
234
Good to know
■ Elongation equal to steel wire
rope.
■ Non-critical behaviour with
modern sheaves.
■ Ideal for backstays - runners and
checkstays. Unlike wire virtually
no damage to booms and
mainsails.
■ Spliceable using the correct
technique.
234
Weight
White
Black
4
750
200
1,5
GG01.04.0/1 GG01.04.0/77
5
1000
200
2,3
GG01.05.0/1 GG01.05.0/77
6
1300
200
2,5
GG01.06.0/1 GG01.06.0/77
8
2250
200
5,0
GG01.08.0/1 GG01.08.0/77
10
3900
200
7,2
GG01.10.0/1 GG01.10.0/77
12
6000
200
11,0
GG01.12.0/1 GG01.12.0/77
14
7800
200
15,0
GG01.14.0/1 GG01.14.0/77
16
9700
200
19,0
GG01.16.0/1 GG01.16.0/77
18
12300
200
26,4
GG01.18.0/1 GG01.18.0/77
20
14600
200
32,5
GG01.20.0/1 GG01.20.0/77
22
18000
200
35,8
GG01.22.0/1 GG01.22.0/77
24
22000
200
42,6
GG01.24.0/1 GG01.24.0/77
28
29600
200
58,0
GG01.28.0/1 GG01.28.0/77
235
Fibre rope
Fibre rope
VectraOne
RunnerTwin PBO 50, -TEC 50, -VEC 50
No compromise: no creep under load, wire-rope-like elongation, perfect for
static applications.
Take the rough with the smooth: high performance sheet with an extra grip
through the sophisticated fibre-mix.
Construction
■ 12-Plait of 100% Vectran® HS
fibre.
■ Grey Geothane coating for
improved abrasion resistance and
UV stability.
Construction
■ Core of 12-strand braid of
Dyneema® SK75 fibre with
Geothane HD coating.
■ Cover 32-plait in three different
specialized constructions:
❐ PBO 50: 50% Zylon®, 50%
polyester HT;
❐ VEC 50: 50% Vectran®,
50% polyester HT;
❐ TEC 50: 50% Technora®,
50% polyester HT.
■ Basic colours 50% red, blue or
black, 50% Zylon®, Vectran® of
Technora® natural colour.
■ Gleistein’s orange identification
yarn.
Good to know
■ VectraOne can be protected by
the use of an additional polyester
cover in areas of jammers and/or
enhanced friction.
■ No measurable creep.
■ VectraOne should only be used
with fittings and equipment of
comparable strength and
robustness.
■ VectraOne must not be exposed
to sunlight due to the fibre’s
limited UV stability.
■ Ideal for steering systems.
Ref. No.
ø
Breaking Load
Reel Length
Weight
in mm
in daN
in mtr
in kg/ 100 mtr.
Good to know
■ Excellent break load.
■ Ultimate abrasion resistance
through large content of high
modulus fibre in the 32-plait cover
braid.
■ Very stable cross-section.
■ RunnerTwin withstands high
pressure.
■ Minimized “fusing” of the ropes on
winches and sheaves.
■ The rope for backstay runners and
hydraulic/ electric winches.
■ Special manufacture with higher
high modulus fibre content
available on request.
Grey
4
1400
200
1,3
GG52.04.0/0
5
2200
200
2,0
GG52.05.0/0
6
3100
200
2,9
GG52.06.0/0
8
5500
200
5,1
GG52.08.0/0
10
8500
200
8,0
GG52.10.0/0
12
13500
200
12,9
GG52.12.0/0
ø
Breaking Load
Weight
14
16000
200
15,7
GG52.14.0/0
in mm
in daN
in kg/ 100 mtr.
16
20500
200
20,4
GG52.16.0/0
18
25500
200
25,9
GG52.18.0/0
20
200
8
3000
4,0
5100
6,8
7500
9,5
14
9500
13,7
16
12000
17,8
18
15000
22,5
20
19000
28,0
22
23000
33,0
24
25500
39,0
26
27500
42,0
28
31700
46,0
30
36000
53,0
32
41000
60,0
34
46000
68,0
36
51000
76,0
31,9
GG52.20.0/0
10
12
22
37500
200
38,7
GG52.22.0/0
24
44000
200
46,0
GG52.24.0/0
■ Bigger sizes on request
236
31000
PBO
Vectran
Technora
237
Fibre rope
Fibre rope
RunnerTwin noveni PBO 50, -TEC 50, -VEC 50
MegaTwin Zylon®
Running rigging that really makes the running: with Dyneema® SK90. Retains
a cool core - even when subjected to high frictional heat.
A world-champion: ultimate break load and minimum elongation for the
toughest racing applications.
Construction
■ Core 12-plait from Dyneema®
SK90 fibre with Geothane HD
coating
■ Cover 32-plait in three different specialised constructions:
■ PBO 50: 50% Zylon®, 50%
Polyester HT
■ VEC 50: 50% Vectran®, 50%
Polyester HT
■ TEC 50: 50% Technora®,
50% Polyester HT
■ Basic colors 50% violet or
pink, 50% Zylon®, Vectran®
or Technora® natural color
■ Gleistein’s orange ID yarn
Construction
■ Core 12-plait of 100% Zylon®
fibre with Geothane HD coating.
■ Cover 32-plait of high tenacity
polyester with water repellent
coating.
■ Gleistein’s orange identification
yarn.
■ Grey with navy blue marker.
Good to know
■ In comparison to RunnerTwin,
Runner Twin noveni boasts a further
improved breaking load
■ Ultimate abrasion resistance through
high content of high modulus fibre in
the 32-plait cover braid
■ Very stable cross-section
■ RunnerTwin withstands high pressure
■ Minimised „fusing“ of the ropes on
winches and sheaves
■ The rope for backstay runners and
hydraulic/electric winches
■ Special manufacture with higher high
modulus fibre content available on
request
ø
Breaking Load
Weight
in mm
in daN
in kg/ 100 mtr.
4
1200
1,4
5
1800
2,4
6
2600
3,0
Weight
8
4700
5,5
in kg/ 100 mtr.
10
7500
8,7
12
10500
11,5
4,0
14
14000
16,3
16
18500
20,3
PBO
238
Good to know
■ Ultimate break load at lowest
elongation.
■ Excellent abrasion resistance.
■ Very stable cross-section.
■ Water repellent coating prevents
sea water from penetrating the
rope. Life expectancy improved
through reduced crystallization of
salt within the rope.
■ PBO ropes have to be inspected
and replaced regularly due to the
decreasing break load of the
fibres.
ø
Breaking Load
in mm
in daN
8
4500
10
7500
6,5
12
9500
9,5
14
12000
13,5
16
15000
17,5
18
17500
22,5
20
21800
28,0
22
26500
33,0
24
29000
39,0
26
31500
42,0
28
36500
46,0
30
41000
53,0
32
47000
60,0
34
52500
68,0
36
58500
76,0
Vectran
Technora
239
Fibre rope
Fibre rope
The Right Rope
Anti Torque-TWIN
Fibre forestay for furling systems
Construction
■ Core 8-strand from Aramid
■ Cover 16-plait of silver HT
continuous filament polyester
yarns with orange marker
yarns
■ Re-inforcing cover made from
special arming fibres
Good to know
■ Working elongation < 1%
■ Non twisting for efficient transfer
of the furling rotation
■ High break strength
Main Halyard
Gennaker Halyard
a) MegaTwin Zylon ®
b) Dyna Lite
a) TaperTwin
b) Dyna Lite
Genua Halyard
■ Non spliceable
■ As endconnection we can offer a special aluminium talurit covered with
shrink socket and using a reinforced
stainless Blue Wave thimble at the end
a) TaperTwin
b) Dyna Lite
Topmast Backstay
a) MegaOne DynaOne HS
b) MegaOne DynaOne
Spinnaker Halyard
a) TaperTwin
b) Dyna Lite
Running Backstay
Spipole uphaul
a) MegaTwin Vectran®
b) MegaOne DynaOne
a) MegaOne DynaOne
b) Cup
Spinpole Foreguy
Topping Lift
Ref. No.
ø
Breaking Load
Breaking Load
Reel Length
Weight
in mm
in daN
talurited
in mm
in kg/ 100 mtr.
in daN
a) MegaTwin
b) Cup
a) MegaTwin Dyneema® HS
b) Dyna Lite
Dyneema®
Grey
3,5
1000
650
200
2,08
GGAT.T3.5/222
6
2300
1800
200
3,32
GGAT.T0.6/222
8
4300
2350
200
5,15
GGAT.T0.8/222
11
7100
4300
200
10,30
GGAT.T1.1/222
Boom Vang
a) MegaTwin Dyneema®
b) Cup
Reefing Lines
a) MegaTwin Dyneema® HS
b) Cup
Main Outhaul
a) MegaTwin Dyneema®
b) Cup
Main Sheet
a) MegaTwin Dyneema®
b) GeminiX
a) Racing b) Cruising
240
Gennaker Shot
Spi-Gennaker Sheet
a) RunnerTwin
b) Dyna Lite
Genoa Sheet
Cunningham
Spi-Guy
Roller Reefing Line
Gennaker Tack Line
a) RunnerTwin
b) GeminiX
a) MegaTwin Dyneema®
b) Dyna Lite
a) MegaTwin Zylon®
b) Dyna Lite
a) Dyneema® Trimm
b) Dyna Lite
a) MegaTwin Dyneema® HS
b) Dyna Lite
241
Fibre Rope
Fibre rope
Tables
MegaTwin
Dyneema®
HS
TaperTwin
VectraOne
DynaOne
DynaOne HS
Discover
4-5
4-6
4-5
3-4
4-6
6-8
4
4-5
4
3-6
6-8
4-6
5-8
6-8
5-8
4-5
6-8
8 - 10
4-5
4-5
4-5
5-8
8 - 10
30
5-8
6 - 10
8 - 10
6 - 10
4-6
6 - 10
10 - 12
5-6
5-8
5-6
6 - 10
10 - 14
Standard
Tasmania, Harkon
Gemini X
Cup
Discover
MegaOne Dyneema®
Dyna Lite
RunnerTwin
MegaOne DynaOne
MegaOne Zylon®
MegaOne Vectran®
MegaOne VectraOne
MegaOne DynaOne HS
TaperTwin
Load as %-age of Breaking Load
50
40
Cup
MegaTwin
Dyneema®
4-5
20
Sail Area m2
Dyna Lite
MegaTwin Vectran®
10
Rope Type
MegaTwin Zylon®
RunnerTwin
Sail Area / Rope diameter Comparison Chart
Load / Elongation curves of “used” sheets and halyards
40
6-8
8 - 10
10 - 12
8 - 10
5-8
8 - 12
10 - 12
5-8
6-8
5-8
8 - 12
10 - 14
50
8 - 10
10 - 12
10 - 12
10 - 12
6-8
8 - 12
12 - 14
6-8
8 - 10
6-8
8 - 12
12 - 16
60
8 - 10
10 - 12
10 - 14
10 - 12
6-8
10 - 12
12 - 14
8 - 10
8 - 10
6-8
10 - 12
14 - 18
70
8 - 12
10 - 14
12 - 16
10 - 14
6 - 10
12 - 14
12 - 16
8 - 10
8 - 10
8 - 10
14 - 18
80
8 - 12
12 - 14
12 - 16
12 - 14
8 - 10
12 - 14
14 - 16
8 - 12
10 - 12
8 - 10
16 - 18
90
10 - 12
12 - 16
14 - 16
12 - 16
8 - 12
12 - 16
14 - 16
8 - 12
10 - 12
10 - 12
16 - 18
100
10 - 14
12 - 16
14 - 16
12 - 16
8 - 12
12 - 16
14 - 16
10 - 12
10 - 12
10 - 12
125
10 - 14
14 - 18
16 - 20
14 - 18
8 - 12
10 - 16
10 - 14
12 - 14
10 - 12
150
12 - 16
16 - 20
18 - 22
16 - 20
10 - 14
14 - 16
12 - 16
14 - 16
10 - 12
175
18 - 22
18 - 22
18 - 22
10 - 14
16
12 - 16
14 - 16
12 - 14
200
18 - 22
20 - 24
18 - 22
12 - 16
12 - 18
16 - 18
12 - 14
225
20 - 24
20 - 26
20 - 24
12 - 16
14 - 18
16 - 18
14 - 16
250
22 - 26
22 - 28
22 - 26
14 - 18
14 - 20
16 - 20
14 - 18
30
Standard
Harkon
Rope Type
Tasmania
20
Gemini X
Sail Area / Rope diameter Comparison Chart
Sail Area m2
10
0
0
1
2
3
4
5
6
7
8
9
10
%-Elongation in percentage
„Used“ means after average usage under normal
weather conditions and is simulated in the lab
with 10 loadings at 20 % of the break load.
242
10
6-8
6-8
6-8
8 - 10
20
6 - 10
10 - 12
8 - 10
10 - 14
30
10 - 12
10 - 14
12 - 14
12 - 16
40
12 - 16
12 - 16
12 - 16
12 - 16
50
12 - 16
14 - 18
12 - 16
12 - 16
60
14 - 18
14 - 20
14 - 16
12 - 16
70
14 - 18
16 - 20
14 - 16
80
16 - 20
16 - 20
14 - 16
90
18 - 22
100
18 - 22
125
20 - 24
150
24 - 28
175
24 - 32
200
24 - 32
225
26 - 36
250
Our recommandations originate from of a
combination of calculations, comprehensive tests
and customer feedback. They should be used as
guidelines, as rope sizes can also be determined by
personal preferences and the individual technical
requirements of a specific application.
Sail surface (in m2) x wind velocity2 (in knots) x
0,021 = power (in daN) x 5 = breaking force.
243
Fibre rope
Fibre Rope
Gleistein Leaded Anchor Warps
Geopacks
Bavaria mooring line (one end spliced eye 50 cm, other end whipped)
Construction
■ Double braid from polyester in
white with blue markers.
■ Complete with spliced thimble
one end.
■ 10 Metres with inner core of
encapsulated lead.
Ref. No.
ø
Breaking Load
Length
in mm
in daN
in mtr
Black
GG11.10.07GP6
10
2000
6
12
2900
8
GG11.12.07GP8
12
2900
12
GG11.12.07GP12
14
3550
8
GG11.14.07GP8
14
3550
14
GG11.14.07GP14
16
4750
8
GG11.16.07GP8
16
4750
15
GG11.16.07GP15
Dockline mooring line (one end spliced eye 50 cm, other end whipped)
Ref. No.
ø
Breaking Load
Length
in mm
in daN
in mtr
Grey
Navy
Red
Black
ø
Length/
Breaking Load
Suitable for
Weight
in mm
mtr
in daN
Boat Length*
in kg
GG11.14.077GP9
10
35
1250
up untill 8 mtr
5,0
GG45.10.35
GG11.16.077GP6
12
40
1800
10
6,5
GG45.12.40
12
50
1800
10
6,9
GG45.12.50
14
40
2650
12
8,0
GG45.14.40
14
50
2650
12
8,5
GG45.14.50
16
40
3200
14
9,5
GG45.16.40
16
50
3200
14
10,0
GG45.16.50
12
2900
6
GG11.12.022GP6
GG11.12.03NGP6
GG11.12.044GP6
GG11.12.077GP6
12
2900
9
GG11.12.022GP9
GG11.12.03NGP9
GG11.12.044GP9
GG11.12.077GP9
14
3550
6
GG11.14.022GP6
GG11.14.03NGP6
GG11.14.044GP6
GG11.14.077GP6
14
3550
9
GG11.14.022GP9
GG11.14.03NGP9
GG11.14.044GP9
16
4750
6
GG11.16.022GP6
GG11.16.03NGP6
GG11.16.044GP6
16
4750
9
GG11.16.022GP9
GG11.16.03NGP9
GG11.16.044GP9
GG11.16.077GP9
18
6100
11
GG11.18.022GP11
GG11.18.03NGP11
GG11.18.044GP11
GG11.18.077GP11
Geotwist Geoprop mooring line (one end spliced eye 50 cm, other end whipped)
ø
Breaking Load
Length
Min. packing
in mm
in daN
in mtr
pcs.
Good to know
■ Flexible for lifetimme with
excellent abrasion resistance.
■ Very good UV stability.
■ A soft and convenient
construction, no need to use
hard to handle (and noisy) chain
forerunners.
■ Through the leaded core the
anchor can dig itself in properly,
hence safer anchoring.
■ Environmentally sound as the
lead is encapsulated so that no
metal can penetrate the
environment.
■ Complete with spliced eye, hence
ready for immediate and
convenient use.
Ref. No.
Ref. No.
Rope Stands
White
Navy
Black
10
1530
4,5
8
GG16.10.01GP4
GG16.10.03NGP4
GG16.10.07GP4
10
1530
8
8
GG16.10.01GP8
GG16.10.03NGP8
GG16.10.07GP8
12
2170
6
8
GG16.12.01GP6
GG16.12.03NGP6
GG16.12.07GP6
12
2170
10
8
GG16.12.01GP10
GG16.12.03NGP10
GG16.12.07GP10
14
3000
12
8
GG16.14.01GP12
GG16.14.03NGP12
GG16.14.07GP12
■ Available free standing stand.
■ Available wall standing stand.
■ Ask for picture and drawing
Geotwist Geoprop Fender lines (one end spliced eye, other end whipped)
Ref. No.
ø
Breaking Load
Length
Min. packing
in mm
in daN
in mtr
pcs.
White
Navy
8
1040
1,70
8
GG16.08.01GP17
GG16.08.03NGP17
10
1530
1,70
8
GG16.10.01GP17
GG16.10.03NGP17
Flag Halyard Polyester 8-plait (white with blue marker)
Ref. No.
ø
Breaking Load
Reel Length
Min. packing
in mm
in daN
in mtr
pcs.
White/Blue
■
■
Furling lines from Dyneema with
braided poyester outer cover
tapered over 50% of total length.
Colour white with colour markers.
ø
Length/
Colour
Furling Line
Breaking Load
in mm
mtr
Markers
Type
in daN
Ref. No.
5,0 - 10
22
purple
1
1100
GG41.05.10.22
2
75
80
10
GG190203GP80
5,0 - 10
28
green
2
1100
GG41.05.10.28
3
150
60
10
GG190303GP60
6,0 - 11
34
blue
3
1400
GG41.06.11.34
4
250
25
10
GG190403GP25
34
blue
3/1
3000
400
25
10
GG190503GP25
7,5 - 13
GG41.07.11.34
5
8,0 - 13
50
red
4
3000
GG41.08.13.50
8,0 - 13
60
black
5
3000
GG41.08.13.60
■ Other sizes on request
244
Tapered Furling Lines
245
Fibre Rope Tools
Fibre Rope
Stainless Steel Shock Cord Clamps
Gleistein Rigging Yarn
Assortment I
White whipping twines in 1,3 and 1,5 mm diameter
waxed and unwaxed
GG35.00.01
Assortment II
Coloured waxed whipping twines 1 mm ø
Ref. no
GG35.00.00
Min. packing
Ref. No.
3 - 4-5
100
GG27.05.00
6
100
GG27.06.00
8
100
GG27.08.00
9 - 10
100
GG27.10.00
12
100
GG27.12.00
for shock cord
Well presented Gleistein rigging yarn is an essential, fast-moving rigging sales
item. The practical carton serves for both delivery and storage. The natural
tendencies of the raw material are used to increase tension in a seizing by the
application of hot water and the subsequent high shrinkage.
in mm
Ref. no.
Clamp pliers
Ref. No.
for shock cord
in mm
Gleistein Geothane
Gleistein’s water based proprietary polyurethane for rope coating to enhance
abrasion and UV-resistance. Very useful for the protection of cores when
covers are stripped.
Geolink
Rope shackle made of DynaOne (100% Dyneema® SK75
12-plait) in two versions:
2,5 mm ø
break load 700 daN 4,0 mm ø
break load 3500 daN
3-12
GG27.00.00
ø
Ref. No.
3
GG27.03.01
4
GG27.04.01
5
GG27.05.01
6
GG27.06.01
Shock cord
GG27.08.01
8
■ Full color shockcord available
Ref. no
GG35.00.02
Ref. no
GG35.00.03
10
GG27.10.01
12
GG27.12.01
Fids
ø
Ref. No.
6
GG28.06.00
❐ GeoLink will tighten under tension and can be easily
opened again when relaxed.
❐ Non-metallic end termination with remarkable break
load at ultra-low weight.
❐ Available in pairs in a GeoPack.
8
GG28.08.00
10
GG28.10.00
12
GG28.12.00
14
GG28.14.00
■ Bigger sizes on request
16
GG28.16.00
18
GG28.18.00
20
GG28.20.00
22
GG28.22.00
24
GG28.24.00
ø
Ref. No.
6-14
GG29.06.00
16-24
GG29.22.00
Splicebook
The Gleistein Splicebook
An indispensable guide with easy-to-understand
instructions for the splicing of Gleistein ropes with
many useful tips is the GLEISTEIN SPLICE BOOK.
A retail Point-of-Sales aid is also available.
246
Ref. no
GG36.00.00
Pushers
247
Plastic laminated blocks I Nylon blocks I Stainless steel blocks for rope and wire rope
Fibre Rope Tools
Aluminium Long Sleeves for Anti Torque-Twin
Ref. No.
Rope diam
Sleeve Length
Min.
in mm
in mm
Packing
3,5
26
10
P5000035L
6,0
42
10
P5000060L
8,0
70
10
P5000080L
11,0
98
10
P5000110L
Sandbags
■ Black leather Sandbags for heaving lines
Ref. No.
■ Selma stainless steel fids
■ Per set 5 fids for rope diam:
Ref. No.
GGSANDBAG
Splicing Tools
GGSELMA
3-4 / 5-6 / 7-8 / 10 and 12 mm
248
249
Industrial Lifting Blocks
Traditional Plastic Laminated and Stainless Steel Wire Rope Sheaves And Blocks
Blaydon blocks
Wire Rope Sheave
■ This general purpose range of integral becket pulley blocks combines light weight and maximum corrosion resistance
■ All sizes are of bolted construction and can simple be dismantled for replacement of sheaves etc.
■ All proof tested and supplied with test batch ID and full artification
■ CE certified and stamped
■ Cheeks: tufnol (also available in stainless steel)
■ Sheaves: aluminium hard anodised (also available in tufnol or bronze) and wire rope groves
■ Bearings: PTFE low friction
■ External straps and bolts: Stainless steel AISI 316
■ Head swivel: Stainless steel AISI 316
■ Available with stainless steel swivel hook with latch
■ Safety factor 4:1
Traditional Plastic
Laminated Blocks
ø for Wire Rope
ø Sheave
Sheave thickness
ø Hole
Min.
in mm
in mm
in mm
in mm
packing
4,0
25
9
6
4,0
30
9
6
4,0
35
9
4,0
40
5,0
50
5,0
60
6,5
6,5
■ cheeks and
sheaves of
plastic laminate
■ strong frame
construction of
stainless steel AISI
316
■ brass bush
bearings
Single block with swivel and becket
weight
Ref.-Nr.
wire rope
Ref. No.
in kg
rope
diameter
wire rope
34
1,06
BBSB04
6
BBSB04WR
40
1,90
BBSB06
8
BBSB06WR
28
50
5,70
BBSB12
10
BBSB12WR
30
60
7,67
BBSB14
12
BBSB14WR
breaking load
WLL
sheave
sheave
rope
in daN
kg
diameter
width
diameter
4000
1000
83
19
16
17
6000
1500
95
22
19
20
12000
3000
121
30
25
14000
3500
144
36
32
EW
EL
Hye No.
Ref. No.
5
47525
HYE4.75.25
5
47530
HYE4.75.30
6
5
47535
HYE4.75.35
9
6
5
47540
HYE4.75.40
11
8
5
47550
HYE4.75.50
11
8
5
47560
HYE4.75.60
70
13
10
5
47570
HYE4.75.70
80
13
10
5
47580
HYE4.75.80
8,0
90
15
10
5
47590
HYE4.75.90
8,0
100
15
10
5
47600
HYE4.76.00
■ Other sizes on request.
Single Wire Rope Block With Eye
ø for Wire Rope
ø Sheave
Breaking load
WLL
in mm
in mm
in daN
in kg
4
35
1150
5
43
1240
6
50
7
63
Hye No.
Ref. No.
230
40004
HYE4.00.04
240
40005
HYE4.00.05
2040
400
40006
HYE4.00.06
2010
400
40007
HYE4.00.07
Hye No.
Ref. No.
■ Safety factor for hoisting and lifting 1:5
Double block with swivel and becket
Single Wire Rope Block
weight
Ref.-Nr.
wire rope
Ref. No.
ø for Wire Rope
ø Sheave
Breaking load
WLL
in kg
rope
diameter
wire rope
in mm
in mm
in daN
in kg
34
1,50
BBDB04
6
BBDB04WR
4
60
1130
230
40504
HYE4.05.04
40
2,40
BBDB06
8
BBDB06WR
5
75
1200
240
40505
HYE4.05.05
28
50
7,80
BBDB12
10
BBDB12WR
6
90
2040
400
40506
HYE4.05.06
30
60
16,50
BBDB14
12
BBDB14WR
8
100
2010
400
40508
HYE4.05.08
breaking load
WLL
sheave
sheave
rope
in daN
kg
diameter
width
diameter
4000
1000
83
19
16
17
6000
1500
95
22
19
20
12000
3000
121
30
25
14000
3500
144
36
32
EW
EL
■ Safety factor for hoisting and lifting 1:5
Wire Rope Sheave Industrial Blocks
Single Block
ø for
Wire Rope
Triple block with swivel and becket
breaking load
in daN
250
WLL
kg
4000
1000
ø Sheave Breaking WLL Hye No.
in mm
diameter
sheave
width
rope
EW
EL
diameter
weight
in kg
Ref.-Nr.
rope
83
19
16
17
34
1,80
BBTB04
wire rope
diameter
load
in kg
Ref. No.
Breaking WLL Hye No.
single
in daN
in mm
sheave
Double Block
load
Ref. No.
in kg double
in daN
5
50
4370
875
80005 HYE8.00.05
4430
875 85005
HYE8.50.05
Ref. No.
6
63
4210
875
80006 HYE8.00.06
4210
875 85006
HYE8.50.06
wire rope
8
80
7160
1400
80008 HYE8.00.08
7090
1400 85008
HYE8.50.08
10
100
10750
2150
80010 HYE8.00.10 10750
2150 85010
HYE8.50.10
6
BBTB04WR
6000
1500
95
22
19
20
40
2,90
BBTB06
8
BBTB06WR
12000
3000
121
30
25
28
50
9,10
BBTB12
10
BBTB12WR
14000
3500
144
36
32
30
60
12,25
BBTB14
12
BBTB14WR
■
■
■
■
■
■
solid sheaves of plastic laminate
brass bushed bearings
strong construction of stainless steel AISI 316
extremely heavy duty blocks
Standard with becket
without becket on request
(suffix ref. no. with WB for without becket)
■ Safety factor for hoisting and lifting 1:5
251
Traditional Plastic Laminated Rope Blocks
Traditional Plastic Laminated Rope Blocks
Traditional Plastic Laminated Rope Blocks
Single with swivel and becket
■ cheeks and sheaves of plastic laminate
■ strong frame construction of stainless steel AISI 316
■ brass bushed bearings
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
830
10
30
32510
HYE32510
1350
12
35
32512
HYE32512
1210
13
43
32513
HYE32513
2020
14
50
32514
HYE32514
2200
16
63
32516
HYE32516
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
600
10
30
33010
HYE33010
900
12
35
33012
HYE33012
900
13
43
33013
HYE33013
1720
14
50
33014
HYE33014
2000
16
63
33016
HYE33016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
630
10
30
33510
HYE33510
960
12
35
33512
HYE33512
990
13
43
33513
HYE33513
Single with bow
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
880
10
30
30010
HYE30010
1120
12
35
30012
HYE30012
1500
13
43
30013
HYE30013
2010
14
50
30014
HYE30014
2210
16
63
30016
HYE30016
Double with bow
Single with eye
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
880
10
30
30510
HYE30510
1110
12
35
30512
HYE30512
1200
13
43
30513
HYE30513
2000
14
50
30514
HYE30514
2190
16
63
30516
HYE30516
Double with swivel
Single with swivel
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
Ref. No.
810
10
30
31010
HYE31010
1740
14
50
33514
HYE33514
1110
12
35
31012
HYE31012
2030
16
63
33516
HYE33516
1200
13
43
31013
HYE31013
2050
14
50
31014
HYE31014
2140
16
63
31016
HYE31016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
610
10
30
34010
HYE34010
910
12
35
34012
HYE34012
900
13
43
34013
HYE34013
1700
14
50
34014
HYE34014
2040
16
63
34016
HYE34016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Double with bow and becket
Single with bow and becket
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
820
10
30
31510
HYE31510
1250
12
35
31512
HYE31512
1490
13
43
31513
HYE31513
2210
14
50
31514
HYE31514
2800
16
63
31516
HYE31516
Single with eye and becket
252
Double with swivel and becket
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
820
10
30
32010
HYE32010
630
10
30
34510
HYE34510
1210
12
35
32012
HYE32012
970
12
35
34512
HYE34512
1210
13
43
32013
HYE32013
1000
13
43
34513
HYE34513
2020
14
50
32014
HYE32014
1710
14
50
34514
HYE34514
2270
16
63
32016
HYE32016
2010
16
63
34516
HYE34516
253
Traditional Plastic Laminated Rope Blocks
Traditional Plastic Laminated Rope Blocks
Fiddle with bow
Triple with swivel, becket and cleat
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
sheave diameter in mm
Ref.-Nr.
Ref. No.
760
10
42
20
35010
HYE35010
1370
12
48
25
35012
HYE35012
1340
13
59
30
35013
HYE35013
Fiddle with eye
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
2110
16
63
37516
HYE37516
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Triple with bow
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
sheave diameter in mm
Ref.-Nr.
Ref. No.
710
10
42
20
35510
HYE35510
820
13
43
38013
HYE38013
1200
12
48
25
35512
HYE35512
4210
16
63
38016
HYE38016
1210
13
59
30
35513
HYE35513
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Fiddle with swivel
Triple with bow and becket
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
sheave diameter in mm
Ref.-Nr.
Ref. No.
720
10
42
20
36010
HYE36010
800
13
43
38513
HYE38513
1200
12
48
25
36012
HYE36012
4360
16
63
38516
HYE38516
1290
13
59
30
36013
HYE36013
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
1910
16
63
39016
HYE39016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
600
10
30
39510
HYE39510
860
12
35
39512
HYE39512
810
13
43
39513
HYE39513
1500
14
50
39514
HYE39514
1810
16
63
39516
HYE39516
Fiddle with swivel, becket and cleat
Triple with swivel
sheave diameter in mm
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
Ref.-Nr.
Ref. No.
740
10
42
20
36510
HYE36510
1210
12
48
25
36512
HYE36512
1200
13
59
30
36513
HYE36513
Double with swivel, becket and cleat
254
Ref. No.
breaking load
Cheek block
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
2170
16
63
37016
Ref. No.
HYE37016
255
Traditional Plastic Laminated Rope Blocks
Traditional Plastic Laminated Rope Blocks
Single with bow/internally bound
Single with swivel/internally bound
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1420
10
60
41010
1810
13
75
41013
4150
16
90
4520
20
6310
22
Ref. No.
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
HYE41010
3690
16
90
43016
HYE43016
HYE41013
4870
20
100
43020
HYE43020
41016
HYE41016
6580
22
120
43022
HYE43022
100
41020
HYE41020
120
41022
HYE41022
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Single with bow and becket/internally bound
Single with swivel and becket/internally bound
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1500
10
60
41510
HYE41510
3700
16
90
43516
HYE43516
1960
13
75
41513
HYE41513
4830
20
100
43520
HYE43520
4210
16
90
41516
HYE41516
6580
22
120
43522
HYE43522
4680
20
100
41520
HYE41520
6420
22
120
41522
HYE41522
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Double with swivel/internally bound
Double with bow/internally bound
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
4210
16
90
44016
HYE44016
1910
10
60
42010
HYE42010
5110
20
100
44020
HYE44020
2200
13
75
42013
HYE42013
6600
22
120
44022
HYE44022
4800
16
90
42016
HYE42016
5170
20
100
42020
HYE42020
6360
22
120
42022
HYE42022
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Double with bow and becket/internally bound
256
Ref. No.
breaking load
Double with swivel and becket/internally bound
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1810
10
60
42510
HYE42510
4210
16
90
44516
HYE44516
2010
13
75
42513
HYE42513
5110
20
100
44520
HYE44520
4800
16
90
42516
HYE42516
6530
22
120
44522
HYE44522
5200
20
100
42520
HYE42520
6420
22
120
42522
HYE42522
257
Traditional Plastic Laminated Rope Blocks and Cleats
Standard Rope Blocks
Standard Rope Blocks
Cleat
Ref. No.
for rope diameter
base
Ref.-Nr.
in mm
in mm
HYE
8-10
76 x 35
45010
HYE45010
12-14
105 x 45
45014
HYE45014
■ strong frame construction of stainless steel AISI 316
■ designed to use and admire
■ serviceability and reliability for general purposes
■ injection moulded cheeks of black nylon
■ solid sheaves of extruded white poly-acetal
■ brass bushed bearings
Single with bow
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
910
10
30
00510
HYE00510
1180
12
35
00512
HYE00512
1560
13
43
00513
HYE00513
2020
14
50
00514
HYE00514
2000
16
63
00516
HYE00516
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Cleat with bullseye
for rope diameter
base
Ref.-Nr.
in mm
in mm
HYE
8-10
80 x 45
45510
Ref. No.
Single with bow and becket
HYE45510
920
10
30
01010
HYE01010
1100
12
35
01012
HYE01012
1530
13
43
01013
HYE01013
2010
14
50
01014
HYE01014
2030
16
63
01016
HYE01016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Single with swivel
Rope sheave
for rope diameter
sheave diameter
sheave thickness
Min. packing
Ref.-Nr.
in mm
in mm
in mm
pcs.
HYE
Ref. No.
10
25
11
5
47025
HYE47025
10
30
11
5
47030
HYE47030
10
35
11
5
47035
HYE47035
10
30
01510
HYE01510
12
35
01512
HYE01512
1110
13
43
01513
HYE01513
2000
14
50
01514
HYE01514
2030
16
63
01516
HYE01516
Ref. No.
10
40
11
5
47040
HYE47040
12
50
13
5
47050
HYE47050
12
60
13
5
47060
HYE47060
14
70
16
5
47070
HYE47070
14
80
16
5
47080
HYE47080
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
16
90
18
5
47090
HYE47090
in daN
in mm
in mm
HYE
16
100
18
5
47100
HYE47100
Single with swivel and becket
other sizes on request
Flagline block
258
800
1190
900
10
30
02010
HYE02010
1130
12
35
02012
HYE02012
1100
13
43
02013
HYE02013
2010
14
50
02014
HYE02014
2070
16
63
02016
HYE02016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Double with bow
for rope diameter
sheave diameter
Min. packing
Ref.-Nr.
in mm
in mm
pcs.
HYE
5
20
5
61188
Ref. No.
HYE61188
910
10
30
02510
HYE02510
1540
12
35
02512
HYE02512
2120
13
43
02513
HYE02513
3160
14
50
02514
HYE02514
3400
16
63
02516
HYE02516
259
Standard Rope Blocks
Standard Rope Blocks
Double with bow and becket
Double with swivel, becket and cleat
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
Ref. No.
910
10
30
03010
HYE03010
2160
14
50
05514
HYE05514
1520
12
35
03012
HYE03012
2010
16
63
05516
HYE05516
2160
13
43
03013
HYE03013
3120
14
50
03014
HYE03014
3610
16
63
03016
HYE03016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
810
10
30
03510
HYE03510
1100
12
35
03512
HYE03512
1330
13
43
03513
HYE03513
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
2140
14
50
03514
HYE03514
2150
16
63
03516
HYE03516
2260
14
50
06014
HYE06014
2480
16
63
06016
HYE06016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
2140
14
50
06514
HYE06514
2070
16
63
06516
HYE06516
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
Double with swivel
Triple with bow
Double with swivel and becket
800
10
30
04010
HYE04010
1420
12
35
04012
HYE04012
1350
13
43
04013
HYE04013
2070
14
50
04014
HYE04014
2180
16
63
04016
HYE04016
Triple with swivel, becket and cleat
Fiddle with bow
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
sheave diameter in mm
Ref.-Nr.
Ref. No.
900
10
42
20
04510
HYE04510
1080
12
48
25
04512
HYE04512
1520
13
59
30
04513
HYE04513
Cheek block
Fiddle with swivel, becket and cleat
260
Ref. No.
breaking load
for rope diameter
in daN
in mm
primary
secondary
HYE
1310
10
30
07010
HYE07010
920
10
42
20
05010
HYE05010
1630
12
35
07012
HYE07012
1140
12
48
25
05012
HYE05012
1550
13
43
07013
HYE07013
1320
13
59
30
05013
HYE05013
3290
14
50
07014
HYE07014
3470
16
63
07016
HYE07016
sheave diameter in mm
Ref.-Nr.
261
Standard Rope Blocks
Offshore Rope Blocks
Offshore Rope Blocks
Single with snap shackle
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1190
13
43
08013
HYE08013
2040
14
50
08014
HYE08014
2000
16
63
08016
HYE08016
■ unique 3 in 1 head system
■ combination of immense strength and today’s styling
■ permanent serviceability and reliability
■ injection moulded cheeks of black nylon
■ solid sheaves of extruded white poly-acetal
■ brass bushed bearings
■ strong frame construction of stainless steel AISI 316
Three in one System
Inline
Right angle
Swivel
Fixed
position
Released
screwpin
Single with snap shackle and becket
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1110
13
43
08513
HYE08513
2160
14
50
08514
HYE08514
2030
16
63
08516
HYE08516
Fixed
position
Release
screwpin
Turn head
90°
Retighten
screwpin
Single
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1600
13
43
10013
HYE10013
2820
14
50
10014
HYE10014
4100
16
63
10016
HYE10016
5020
20
80
10020
HYE10020
6980
22
100
10022
HYE10022
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
1610
13
43
11013
HYE11013
2840
14
50
11014
HYE11014
4040
16
63
11016
HYE11016
5020
20
80
11020
HYE11020
7020
22
100
11022
HYE11022
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
HYE09513
1630
13
43
12013
HYE12013
2910
14
50
12014
HYE12014
4250
16
63
12016
HYE12016
5480
20
80
12020
HYE12020
7040
22
100
12022
HYE12022
Fiddle with snap shackle
breaking load
for rope diameter
in daN
in mm
sheave diameter in mm
primary
secondary
Ref.-Nr.
HYE
1200
13
59
30
09013
Ref. No.
HYE09013
Double
Fiddle with snap shackle, becket and cleat
262
Single with becket
breaking load
for rope diameter
in daN
in mm
sheave diameter in mm
primary
secondary
Ref.-Nr.
HYE
1520
13
59
30
09513
263
Offshore Rope Blocks
Industrial Rope Blocks
Industrial Rope Blocks
Double with becket
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
1600
13
43
13013
HYE13013
2340
14
50
13014
HYE13014
4010
16
63
13016
HYE13016
5440
20
80
13020
HYE13020
7040
22
100
13022
HYE13022
Double with becket and cleat
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
2860
14
50
14014
HYE14014
4450
16
63
14016
HYE14016
■ solid sheaves of plastic laminate
■ brass bushed bearings
■ strong frame construction of stainless steel AISI 316
■ extremely heavy duty blocks
■ also available with wire rope sheaves see page 57
■ Safety factor for hoisting and lifting 1:5
Single with becket and swivel
Ref. No.
breaking load
WLL
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in kg
in mm
in mm
HYE
4370
850
12
50
80012
HYE80012
4210
850
14
63
80014
HYE80014
7160
1400
16
80
80016
HYE80016
10750
2150
18
100
80018
HYE80018
■ Without becket on request.
■ Suffix ref. no. with WB for without becket.
Double with becket and swivel
Triple
Ref. No.
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in mm
in mm
HYE
2510
14
50
15014
HYE15014
4500
16
63
15016
HYE15016
breaking load
for rope diameter
sheave diameter
Ref.-Nr.
Ref. No.
in daN
in mm
in mm
HYE
2800
14
50
16014
HYE16014
4210
16
63
16016
HYE16016
Ref. No.
Ref. No.
breaking load
WLL
for rope diameter
sheave diameter
Ref.-Nr.
in daN
in kg
in mm
in mm
HYE
4430
850
12
50
85012
HYE85012
4210
850
14
63
85014
HYE85014
7090
1400
16
80
85016
HYE85016
10750
2150
18
100
85018
HYE85018
■ Without becket on request.
■ Suffix ref. no. with WB for without becket.
Triple with becket and cleat
Swivel deck plate
264
for blocks
plate diameter
plate thickness
drilled for bolts
Ref.-Nr.
for rope diameter in mm
in mm
in mm
diameter in mm
HYE
14
80
3
6
18014
HYE18014
16
80
3
6
18016
HYE18016
265
International Offices
German Offices
Austria
Carl Stahl GmbH
Anzengruberstraße 10
A-4600 Wels
Phone: (0043) (72 42) 2 53 85
Fax:
(0043) (72 42) 2 53 71
E-Mail: austria@carlstahl.com
Süßen (Company headquarters)
Carl Stahl GmbH
Tobelstraße 2
73079 Süßen
Phone: (0 71 62) 40 07-3000
Fax:
(0 71 62) 40 07-8810
E-Mail: carlstahl@carlstahl.com
Berlin
Carl Stahl GmbH Velten
Niederlassung Berlin
Kanalstraße 72-74
12357 Berlin
Phone: (0 30) 53 89 88-0
Fax:
(0 30) 53 89 88-88
Your contact: Norbert Wolf
E-Mail: berlin@carlstahl.com
Mannheim
Carl Stahl GmbH & Co. KG Frankfurt
Niederlassung Mannheim
Max-Born-Str. 9
68169 Mannheim
Phone: (06 21) 17 82 78-6
Fax:
(06 21) 17 82 78-70
Your contact: Erich Vetter
E-Mail: mannheim@carlstahl.com
Schwerin
Carl Stahl GmbH
Niederlassung Schwerin
Handelsstraße 6a
19061 Schwerin
Phone: (03 85) 64 48 40
Fax:
(03 85) 61 20 52
Your contact: Sabine Schmidt
E-Mail: schwerin@carlstahl.com
Dresden
Carl Stahl GmbH Dresden
Rothhäuserstraße 9
01219 Dresden
Phone: (03 51) 8 76 87-0
Fax:
(03 51) 8 76 87-22
Your contact: Wolfgang Müller
E-Mail: dresden@carlstahl.com
Munich
Carl Stahl GmbH München
Daglfinger Straße 67–69
81929 München
Phone: (0 89) 93 94 45-0
Fax:
(0 89) 93 94 45-45
Your contact: Regina Schmidt
E-Mail: muenchen@carlstahl.com
Singen
Carl Stahl GmbH
Laubwaldstraße 15
78224 Singen/Hohentwiel
Phone: (0 77 31) 82 00-0
Fax:
(0 77 31) 82 00-50
Your contact: Martin Rösch
E-Mail: singen@carlstahl.com
Düsseldorf
Carl Stahl GmbH
Jahnstraße 117
40215 Düsseldorf
Phone: (02 11) 33 30 80
Fax:
(02 11) 33 35 43
Your contact: Walter Eßlinger
E-Mail: duesseldorf@carlstahl.com
Neckarsulm
Carl Stahl GmbH & Co. KG Neckarsulm
Im Klauenfuß 11
74172 Neckarsulm
Phone: (0 71 32) 97 57-0
Fax:
(0 71 32) 97 57-97
Your contact: Roland Schoch
E-Mail: neckarsulm@carlstahl.com
Stuttgart
Carl Stahl GmbH
Dreifelderstraße 11
70599 Stuttgart
Phone: (07 11) 1 67 72-0
Fax:
(07 11) 1 67 72-24
Your contact: Wolfram Ludmann
E-Mail: stuttgart@carlstahl.com
Frankfurt/Main
Carl Stahl GmbH & Co. KG Frankfurt
Borsigallee 14
60388 Frankfurt/Main
Phone: (0 69) 42 09 95-0
Fax:
(0 69) 42 09 95-40
Your contact: Volker Seifert
E-Mail: frankfurt@carlstahl.com
Hamburg
Carl Stahl GmbH
Niederlassung Hamburg
Borstelmannsweg 109-115
20537 Hamburg
Phone: (0 40) 298 12 64-70
Fax:
(0 40) 298 12 64-79
Your contact: Oliver Lühr
E-Mail: hamburg@carlstahl.com
Nuernberg
Carl Stahl GmbH Nürnberg
Sieboldstraße 11
90411 Nürnberg
Phone: (0911) 95 59 79 11
Fax:
(0911) 95 59 79 29
Your contact: Lothar Braun
E-Mail: nuernberg@carlstahl.com
Süßen
Carl Stahl GmbH
Tobelstraße 2
73079 Süßen
Phone: (0 71 62) 40 07-1000
Fax:
(0 71 62) 40 07-8810
Your contact: Bruno Masching
E-Mail: carlstahl@carlstahl.com
Regensburg
Leonhard Seyboth GmbH
Budapester Str. 2a
93055 Regensburg
Phone: (0941) 79 31 04
Fax: (0941) 79 17 58
Your contact: Rainer Bräu
E-Mail: info@seyboth-gmbh.de
Velten
Carl Stahl GmbH Velten
Am Jägerberg 4
16727 Velten
Phone: (0 33 04) 39 65-0
Fax:
(0 33 04) 39 65 30
Your contact: Thomas Weinreich
E-Mail: velten@carlstahl.com
Reichenbach/Vogtland
Carl Stahl GmbH
Buchenstraße 4
08468 Reichenbach/Vogtland
Phone: (0 37 65) 78 29-0
Fax:
(0 37 65) 78 29-20
Your contact: Frank Kania
E-Mail: reichenbach@carlstahl.com
Würzburg
Carl Stahl GmbH & Co. KG
Friedrich-Bergius-Ring 38
97076 Würzburg
Phone: (09 31) 27 88-30
Fax:
(09 31) 27 88-320
Your contact: Jürgen Feser
E-Mail: wuerzburg@carlstahl.com
Saarbrücken
Carl Stahl GmbH
Küstriner Straße 8 e
66121 Saarbrücken
Phone: (06 81) 8 30 47 66
Fax:
(06 81) 8 30 49 90
Your contact: Helga Nadig
E-Mail: saarbruecken@carlstahl.com
Wunstorf
Carl Stahl GmbH
Niederlassung Wunstorf
Hagenburger Str. 8b
31515 Wunstorf (Hannover)
Phone: (0 50 31) 96 09-0
Fax:
(0 50 31) 96 09-22
Your contact: Thomas Weinreich
E-Mail: hannover@carlstahl.com
Carl Stahl Nordgreif GmbH
Achter de Weiden 12
22869 Schenefeld/Hamburg
Phone: +49 (0 )40-73 60 74-0
Fax:
+49 (0 )40-73 60 74-22
Your contact: Christian Timm
E-Mail: nordgreif@carlstahl.com
Web: www.carlstahl-nordgreif.com
Leipzig
Carl Stahl GmbH Dresden
Niederlassung Leipzig
Rackwitzerstraße 20–22
04347 Leipzig
Phone: (03 41) 23 40 94-0
Fax:
(03 41) 23 40 94-22
Your contact: Kerstin Wegh
E-Mail: leipzig@carlstahl.com
266
Carl Stahl GmbH
Gewerbepark 660
A-6870 Bezau
Phone: (0043) (55 14) 3 01 05-0
Fax:
(0043) (55 14) 3 01 05-90
E-Mail: bezau@carlstahl.com
Brazil
Carl Stahl Aços,
Cabos e Sistemas Ltda.
Rua Silva Bueno, 165 – Ipiranga
04208-050 São Paulo - SP
Phone: 0055 (11) 6914-7100
Fax:
0055 (11) 6914-1129
E-Mail: vendas@carlstahl.com.br
Morsing Cabos de Aco Ltda.
Travessa Morsing, 43 - Centro
26123-020 Belford Roxo - RJ
Phone: 0055 (21) 3663-6666
Fax:
0055 (21) 2661-1200
E-Mail: vendas@carlstahl.com.br
China
Carl Stahl Ningbo Co., Ltd.
Tongtu Rd., Fang Qian, Xiao Gang,
Beilun, Ningbo, P.R. China, 315803
Phone: 0086 (574) 8622 8100
Fax:
0086 (574) 8622 8108
E-Mail: jeffrey@carlstahl.cn
Hangzhou Carl Stahl
Import & Export Co., Ltd.
5F-I, No. 173 Yugu Rd., Xihu District,
Hangzhou, P.R. China, 310007
Phone: 0086 (571) 8993 6192
Fax:
0086 (571) 8993 6167
E-Mail: jeffrey@carlstahl.cn
Czech Republic
Carl Stahl & spol, s. r. o.
Bozanovská 2098
CZ-19300 Praha 9
Phone: (00420) 281 925 977
Fax:
(00420) 281 920 172
E-Mail: info@carlstahl.cz
Denmark
Carl Stahl A/S
Vognmagervej 21
DK-7000 Fredericia
Phone: (0045) 762 402 34
Fax:
(0045) 762 403 45
E-Mail: salg@carlstahl.dk
Carl Stahl A/S
Østerled 28
DK-4300 Holbæk
Phone: (0045) 762 402 34
Fax:
(0045) 594 422 93
Dubai/U.A.E.
Carl Stahl Middle East LLC
Carl Stahl Lifting Equipment
Industries LLC
Carl Stahl Safety & Security Consultancy
P. O. BOX 26607
Ras Al Khor (Industrial 2)
Dubai - U. A. E.
Phone: (00 971) 4-3333 494
Fax:
(00 971) 4-3333 489
E-Mail: stahl@emirates.net.ae
Finland
Carl Stahl Oy
PL/Box 711
Jonkankatu 2
FIN-20361 Turku
Phone: (00 358) 2 275 00 60
Fax:
(00 358) 2 275 00 69
E-Mail: myynti@carlstahl.com
France
Carl Stahl
43, rue des Tuileries
F-67460 Souffelweyersheim
Phone: (0033) (3) 88 18 37 00
Fax:
(0033) (3) 88 20 51 96
E-Mail: info@carlstahl.fr
Great Britain
Carl Stahl Evita Ltd.
Carl Stahl House
Farfield Park, Manvers Estate
S63 5DB Rotherham GB
Phone: (0044) (1) 709-76 30 58
Fax:
(0044) (1) 709-76 30 67
E-Mail: sales@carlstahlevita.co.uk
Hungary
Carl Stahl Hungaria Kft
Jedlik Anyos u. 26
H-2330 Dunaharaszti
Phone: (0036)-24 491 452
Fax:
(0036)-24 460 123
°
E-Mail: janosgill@carlstahl.hu
India
Carl Stahl Craftsman Enterprises Private Ltd.
No. 15 LML Colony
Ammankulam Road
IND-Coimbatore - 641 037
Phone: (0091) 422 661 5100
Fax:
(0091) 422 221 1976
E-Mail: ravishankar@craftsmanautomation.com
Carl Stahl Craftsman Enterprises Private Ltd.
No. 90 Broadway,
Opposite to Canara Bank, George Town
IND-Chennai - 600 108
Phone: (0091) 044-421 599 96
Fax:
(0091) 044-421 599 96
E-Mail: ravishankar@craftsmanautomation.com
Indonesia
PT Rigspek Perkasa
Komplek Kawasan Industri
Sekupang Kav No. 13, Tanjung
Pinggir, Sekupang
RI-Kota Batam
Phone: (0062) (0) 778 324 747
Fax:
(0062) (0) 778 321 388
E-Mail: sales@rigspekperkasa.com
The Netherlands
Carl Stahl Benelux B.V.
Kleine Tocht 5
NL-1507 CB Zaandam
Phone: (0031) 75-6318536
Fax:
(0031) 75-6310968
E-Mail: benelux@carlstahl.com
Norway
Carl Stahl AS
Postboks 314 Nesttun
N-5853 Bergen
Phone: (0047) 55 92 63 60
Fax:
(0047) 55 92 63 70
E-Mail: carlstahl@carlstahl.no
Norway
Carl Stahl AS
Postboks 56
N-3139 Skallestad
Phone: (0047) 33 30 47 15
Fax:
(0047) 33 30 47 16
E-Mail: jan-erik.jansson@carlstahl.no
Carl Stahl AS
Postboks 43
N-4098 Tananger
Phone: (0047) 51 94 49 10
Fax:
(0047) 51 94 49 11
E-Mail: tananger@carlstahl.no
Carl Stahl AS
Postboks 213
N-9750 Honningsvag
Phone: (0047) 78 47 69 00
Fax:
(0047) 78 47 69 10
E-Mail: honningsvag@carlstahl.no
Poland
Carl Stahl Tech Service Sp. z.o.o.
ul. Spokojna 3
74-404 Cychry
Phone: (0048) (0)95-728 88 85
Fax:
(0048) (0)95-728 88 86
E-Mail: biuro@carlstahl.pl
Sweden
Carl Stahl AB
Frysvägen 3
S-556 52 Jönköping
Phone: (0046)-(036) 36 16 40
Fax:
(0046)-(036) 10 09 24
E-Mail: info@carlstahl.se
Carl Stahl AB
Universitetsllèn 32
S-851 71 Sundsvall
Phone: (0046)-(060) 16 95 30
Fax:
(0046)-(060) 16 95 31
E-Mail: info@carlstahl.se
Switzerland
Carl Stahl AG
Stachelhofstrasse 12
CH-8854 Siebnen
Phone: (0041)-(055) 450 50 00
Fax:
(0041)-(055) 450 50 05
E-Mail: info@carlstahl.ch
U.S. + Canada
Carl Stahl Sava Industries Inc.
4 North Corporate Drive
P. O. Box 30
Riverdale, NJ 07457, USA
Phone: (001) 973 835-0882
Fax:
(001) 973 835-0877
E-Mail: sales@savacable.com
Carl Stahl DécorCable, LLC
660 West Randolph Street
Chicago, IL 60661, USA
Phone: (001) 312 474 1100
Fax:
(001) 312 474 1789
E-Mail: sales@decorcable.com
Carl Stahl American Lifting, LLC
21825 Doral Road
Waukesha, WI 53186, USA
Phone: (001) 262 786 2710
Fax:
(001) 262 786 8510
E-Mail: jim@amlift.com
267
Notes
Brands
Blue Wave
Leoflex
Loos en Co
Carl Stahl
Maillon-Rapide
Felco
Nicopress
Gleistein
RUD
Savapress
Hi-Mod
Sta-Lok
Hye
Tylaska
Inox-Line
Wichard
Kong
268
Wireteknik
269
Netherlands
Carl Stahl BENELUX B.V.
Kleine Tocht 5
1507 CB Zaandam
Tel.
+31 (0)75 631 85 36
Fax
+31 (0)75 631 09 68
E-mail benelux@carlstahl.com
www.carlstahl.nl
