OEM CCTV, DVR, IP, & NVR SECURITY EQUIPMENT MANUFACTURER

2011 DVR CATALOG

DVR System

Hybrid PC

PC-Based Hybrid Digital Video Recorder

Features:

¾

Powerful, expandable, and easy to use DVR - Built on up-to-date PC hardware and high performance Video

Capture card, together with full feature Windows-based DVR software.

¾

Unique Hybrid design combining Analog CCTV cameras and IP network cameras into the same DVR allows integrated video monitoring.

¾

Special MPEG4+ Compression method makes file size smaller, so is more recording Time.

¾

Multiplexing functions: Live viewing, Record, Playback, Remote access, and Backup simultaneously

¾

Network Protocol supports TCP/IP, IPX, UDP, ISDN, PPPoE, PSTN, etc. Internet connection supports Static IP,

DHCP, and DDNS.

¾

Remote access using provided Client software or Web browser provides remote user full access of Live viewing,

Recording, Search, Backup, System Setup, and 2-way audio communication.

¾

Support Multi-Server to Multi-Client access, which allows multiple users remote access to DVR system at the same time; and for Client program, it can also monitor multiple Servers simultaneously.

¾

Individual camera programmable for various recording type, speed, and scheduling. Both Pre and post alarm recording are also available.

¾

Easy and powerful Search includes calendar-timeline assisted Time search, Event, and Smart Search.

¾

Video Playback speed adjustable in fast or slow mode, also support frame-by-frame playback, Panorama view, and digital zoom function.

¾

Backup Video can be in AVI or proprietary format; also include Watermark function. Backup media can be CD-

RW, DVD-RAM, USB Flash Drive, etc.

¾

Support video activated Motion Detection function, motion zones and sensitivity adjustable by each camera

¾

Powerful Event handling allows event capture video to be sent out through email or FTP, or voice message sent out through modem. Specific cameras can be set up to response the event with faster recording rate or better recording quality.

¾

PTZ camera can be controlled Locally and Remotely. System supports most of name brand Protocols.

¾

Multi-level and multi-person password control with selectable access privilege setup including Remote Access

¾

System auto rebooting with Watchdog function

Models:

4 Channels –

8 Channels –

Model No.

Frame

Speed

Display

Record

Chassis

DV-04P30

30 fps

30 fps

DV-04P12

120 fps

120 fps

Model No.

Frame

Speed

Display

Record

DV-08P60

60 fps

60 fps

16 Channels –

Model No.

Frame

Speed

Display

Record

Chassis

32 Channels –

Model No.

Frame

Speed

Display

Record

Chassis

DV-16P12

120 fps

120 fps

DV-16P2424

240 fps

240 fps

Tower

DV-32P24

240 fps

240 fps

DV-08P12

120 fps

120 fps

Tower

DV-08P24

240 fps

240 fps

DV-16P648 DV-16P1248 DV-16P24 DV-16P48

480 fps

60 fps

480 fps

120 fps

Rack Mount

480 fps

240 fps

480 fps

480 fps

DV-32P48

480 fps

480 fps

DV-32P9624

960 fps

240 fps

Rack Mount

DV-32P9648

960 fps

480 fps

System Configuration*:

Standard – Intel Pentium-4 CPU 3.0GHz or up, 512MB DDR2 Memory, 80GB Hard Drive, CD/RW, LAN Card, Keyboard, Mouse, and Windows

XP Home Operating System

Optional – More Hard Drives, High Speed Modem, DVD-RAM, TV Video-out, Digital I/O, 1-Ch. Audio, Windows XP Pro, or Customize

Logo/Brand

* Configuration for 32Ch and real time recording models may use faster CPU and more memory as needed.

Specifications:

Resolution

Compression

Video Inputs

IP Camera

Video Output

Multiplex Feature

Split Screens

Recording Type

Recording Speed

Pre/Post Alarm Record

Auto Switching

Motion Detection

Search / Playback

Playback Feature

Pan/Tilt/Zoom Control

Password Control

Sensor Input / Output

Event Handling

Backup

Remote Access

Audio

Display Adjustment

Data Storage Structure

720x480, 720x240, and 320x240 Selectable

MPEG, MPEG-4, and MPEG-4+ Selectable

NTSC/PAL, Composite, w/ BNC Connectors

Use one of video input BNC connectors, only Axis and Vivotek brands camera are supported.

1 x PC: Computer Display (PC XGA Display)

1 x TV: NTSC/PAL A/V Monitor

Live Monitoring, Recording, Playback, Back up, Remote Transmit Simultaneously

Full screen, 1 / 4 / 6 / 7 / 9 / 10 / 13 / 16 / 32 Split Screens**

Continuous, Schedule, Motion, and Sensor

Adjustable by each channel

Yes

1, 4, 8 Ch. with adjustable time interval

Up to 10 Rectangular Detection Zones each channel with adjustable sensitivity

Time Search- Random access through Graphic Calendar-assisted search tool (Time/Date/Month),

Event Search, and Smart Search

Play, Forward / Backward, Speed adjustable x1/8, x1/4, x1/2, x2, x4, x8,

Frame-by-Frame play, Panorama view, Digital Zoom, Print, and Video Backup

Yes, Server & Remote site

Multi-level, Multi-user with selectable access privilege setup

Optional

Increase Recording Rate or Picture quality, Auto-email or FTP video clip, Emergency Call

Manual and Schedule Backup in proprietary or AVI format

Storage media: FDD, USB Flash Drive, CD-RW, and DVD-RAM (optional)

Remote Access via PSTN, LAN, xDSL, TCP/IP (Modem/Ethernet)

Provide both Web browser and Client software remote access

Support: Remote User Access Control, Multi-user Access, and Remote Configuration

Multi-server Access capable on Client software

One Channel (Optional)

Brightness/ Contrast/ Saturation/ Hue

Proprietary Data Base Structure

Self Restoration

O/S

Auto Rebooting with Watchdog function

Windows XP Home (Optional Windows XP Professional)

** Based on selected model, some split-screen options are not applicable.

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Premium 16 Ch. H.264 Hybrid Stand-Alone DVR

Model No.

:

DV-G616U

(D1) /

DV-G616S

(half-D1)

/ DV-G616

Features:

¾ Tri-Codec Compression - H.264 /

MPEG-4 / MJPEG

¾ Hybrid function: Support Megapixel IP camera recording or up to 8Ch IP

Camera recording

¾ Pentaplex operation – Simultaneous

Record / Live view / Playback / Backup /

Network Access

¾

Embedded Linux operating system

¾ Support VGA and Digital display output (HDMI connector)

¾

Real-time Live view and Real-time Recording (CIF mode) for each channel

¾ Easy to use Graphical User Interface (GUI) or Text mode, both support USB Mouse

¾ Easy and flexible recording setup – Preset record configuration, ezRecord™ for quick recording setting, or per channel configuration for normal and event recording

¾ Support up to 4 internal SATA HDDs / 1 Optical drive + 3 HDDs

¾ USB2.0 ports for video clip exporting, support USB thumb drive, or other external storages

¾ Built-in Pelco Coaxitron Protocol; also support other PTZ camera protocols through RS485 port.

¾ Programmable Call-monitor switching sequence

¾ Export video clip in AVI or DVR format with optional electronic signature

¾ Web browser based Remote monitoring, recording, playback, system setup, and PTZ camera control

¾ Support Mobile View software

¾ CMS for large-scale video management

¾ Network supports Static IP, DHCP, PPPoE, DDNS, WLAN, SMS, and UPnP

¾ Dual-gigabit LAN ports, one can be a NAS port for more recording storage.

¾ 16 Ch Audio recording

¾ Built-in POS integration provides transaction monitoring.

¾ User Management, Two levels of password protection

¾

Support NTP for time synchronization

¾ Easy software upgrade via Network, USB thumb drive, or CD-RW

¾

IR Remote controller

Specifications:

Model

Input

Operation System

Input IP devices

Output

Main Monitor

Call Monitor

Loop Out

Digital Display Output

VGA Output

Picture Refresh Rate

DV-G616U DV-G616S DV-G616

Video

BNC x 16, 1.0Vp-p / 75Ω

Linux Embedded

Up to 8ch

BNC x 1, S-Video, 1.0Vp-p / 75 Ohm

BNC x 1, 1.0Vp-p / 75 Ohm

BNC x 16, 1.0Vp-p / 75Ω

HDMI connector, 800 x 600, 1024 x 768, 1280 x 1024 pixels

D-SUB 15pin connector, 800 x 600, 1024 x 768, 1280 x 1024 pixels

NTSC: 30 fps/ch., PAL: 25 fps/ch.

Input

Output

Compression Method

Data Rate

Audio

Terminal Block, x16 Line-in

RCA x 1, 1 Channel Line-Out

ADPCM, G.726

8Kb/s per ch

Continue …, Please turn over.

Specifications Continued …

Compression Method

Recording Mode

Pre-Alarm

Resolution

& Rate

Recording Quality

Storage Mode

Data Life Time

Playback

720x480

720x240

360x240

Recording

H.264 / MPEG-4 / MJPEG

H.264: Max. 480fps

H.264: Max. 480fps

H.264: Max. 480fps

Schedule, Alarm, Motion

Yes

H.264: Max 120fps

MPEG-4/MJPEG: Max

240fps

H.264: Max. 120fps

MPEG-4/MJPEG: Max

240fps

H.264: Max. 240fps

MPEG-4/MJPEG: Max

480fps

8 levels presets, adjustable

Linear/Circular

Programmable

H.264: Max 60fps

MPEG-4/MJPEG: Max

120fps

H.264: Max 120fps

MPEG-4/MJPEG: Max

120fps

H.264: Max 120fps

MPEG-4/MJPEG: Max

240fps

Playback

Play, Stop, Pause, Single Frame, Rewind, Forward, Search

Playback Speed

Adjustment

Retrieve

Build-in Storage

External Storage

Export

Alarm Input

Motion Detection

Alarm Detection

Video Loss Detection

Alarm Relay Output

1x, 2x, …, 32x

Date/Time, Calendar, and Event

Storage

SATA x 4, up to 3 devices: HDD / CD-RW / DVD+RW

NAS through Gigabit LAN

USB 2.0 x 4, support ThumbDrive, CD-RW, or DVD+RW

Alarm

X16, Terminal Block

16 x 12 Grid Array, Sensitivity, Trig level adjustable

N.C./N.O., Programmable

Programmable x2, Terminal Block

Network Connectivity

Compatible IP Camera

Remote Control Software

Remote Operation

RS-232C

RS485

PTZ Control Protocol

Pelco Coaxitron Protocol

Communication

Ethernet RJ45, 10/100/1000Mbps, support

DHCP/PPPoE/DDNS/WLAN/SMS/UPnP

SONY, AXIS, ACTi, Vivotek, SANYO, Dynacolor

CMS(Central Management Software), Web-Browser based Software

Monitor, Playback, Recording, System Setup, Dome Camera Control, Archive

D-SUB 9 pin, Ready for POS integration

Terminal Block

Pelco D, Pelco P, Fastrax 2, Panasonic, DSCP, AD422, JVC

Yes

General

Power Input &

Consumption

AC 100~240V, 50~60Hz, 200W

Operation Environment

Weight

Dimension (W x H x D)

0°C ~ 40°C (32oF ~ 104oF); 10% ~ 90% Relative Humidity, Non-condensing

7Kg (15.42 lbs), exclude hard drives

440 x 90 x 413mm (17.3 x 3.54 x 16.3in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Premium H.264 Hybrid Stand-Alone DVR

Model No.

:

DV-G608

(8Ch.) /

DV-G604

(4Ch.)

Features:

¾ Tri-Codec Compression - H.264 /

MPEG-4 / MJPEG

¾ Hybrid function: Support Megapixel IP camera recording or 4 / 8Ch IP Camera recording

¾ Pentaplex operation – Simultaneous

Record / Live view / Playback / Backup /

Network Access

¾

Embedded Linux operating system

¾ Support VGA and Digital display output (HDMI connector)

¾

Real-time Live view and Real-time Recording (CIF mode) for each channel

¾ Easy to use Graphical User Interface (GUI) or Text mode, both support USB Mouse

¾ Easy and flexible recording setup – Preset record configuration, ezRecord™ for quick recording setting, or per channel configuration for normal and event recording

¾ Support up to 4 internal SATA HDDs / 1 Optical drive + 3 HDDs

¾ USB2.0 ports for video clip exporting, support USB thumb drive, or other external storages

¾ Built-in Pelco Coaxitron Protocol; also support other PTZ camera protocols through RS485 port.

¾ Programmable Call-monitor switching sequence

¾ Export video clip in AVI or DVR format with optional electronic signature

¾ Web browser based Remote monitoring, recording, playback, system setup, and PTZ camera control

¾ Support Mobile View software

¾ CMS for large-scale video management

¾ Network supports Static IP, DHCP, PPPoE, DDNS, WLAN, SMS, and UPnP

¾ Dual-gigabit LAN ports, one can be a NAS port for more recording storage.

¾ 4 / 8 Ch Audio recording

¾ Built-in POS integration provides transaction monitoring.

¾ User Management, Two levels of password protection

¾

Support NTP for time synchronization

¾ Easy software upgrade via Network, USB thumb drive, or CD-RW

¾

IR Remote controller

Specifications:

Model

Input

Operation System

Input IP devices

DV-G608 DV-G604

Video

BNC x 8, 1.0Vp-p / 75Ω BNC x 4, 1.0Vp-p / 75Ω

Linux Embedded

Up to 8ch Up to 4ch

Output

Main

Monitor

Call Monitor

Loop Out

Digital Display Output

VGA Output

Picture Refresh Rate

Input

Output

Compression Method

Data Rate

BNC x 1, S-Video, 1.0Vp-p / 75 Ohm

BNC x 1, 1.0Vp-p / 75 Ohm

BNC x 8, 1.0Vp-p / 75Ω BNC x 4, 1.0Vp-p / 75Ω

HDMI connector, 800 x 600, 1024 x 768, 1280 x 1024 pixels

D-SUB 15pin connector, 800 x 600, 1024 x 768, 1280 x 1024 pixels

NTSC: 30 fps/ch., PAL: 25 fps/ch.

Audio

Terminal Block, x8 Line-in Terminal Block, x4 Line-in

RCA x 1, 1 Channel Line-Out

ADPCM, G.726

8Kb/s per ch

Continue …, Please turn over.

Specifications Continued …

Compression Method

Recording Mode

Pre-Alarm

Resolution

& Rate

Storage Mode

Data Life Time

720x480

720x240

360x240

Recording Quality

Recording

H.264 / MPEG-4 / MJPEG

Schedule, Alarm, Motion

Yes

H.264: Max. 60fps

MPEG-4 / MJPEG: Max. 120fps

H.264: Max. 120fps

MPEG-4 / MJPEG: Max. 120fps

H.264: Max. 120fps

MPEG-4 / MJPEG: Max. 240fps

H.264: Max. 60fps

MPEG-4 / MJPEG: Max. 120fps

H.264: Max. 120fps

MPEG-4 / MJPEG: Max. 120fps

H.264: Max. 120fps

MPEG-4 / MJPEG: Max. 120fps

8 levels presets, adjustable

Linear/Circular

Programmable

Playback

Playback Speed

Adjustment

Retrieve

Playback

Play, Stop, Pause, Single Frame, Rewind, Forward, Search

1x, 2x, …, 32x

Date/Time, Calendar, and Event

Build-in Storage

External Storage

Export

Alarm Input

Motion Detection

Alarm Detection

Video Loss Detection

Alarm Relay Output

Storage

SATA x 4, up to 3 devices: HDD / CD-RW / DVD+RW

NAS through Gigabit LAN

USB 2.0 x 4, support ThumbDrive, CD-RW, or DVD+RW

Alarm

x8, Terminal Block x4, Terminal Block

16 x 12 Grid Array, Sensitivity, Trig level adjustable

N.C./N.O., Programmable

Programmable x2, Terminal Block

Communication

Ethernet RJ45, 10/100/1000Mbps, support DHCP/PPPoE/DDNS/WLAN/SMS/UPnP

SONY, AXIS, ACTi, Vivotek, SANYO, Dynacolor

Network Connectivity

Compatible IP Camera

Remote Control

Software

Remote Operation

CMS(Central Management Software), Web-Browser based Software

RS-232C

RS485

Monitor, Playback, Recording, System Setup, Dome Camera Control, Archive

D-SUB 9 pin, Ready for POS integration

Terminal Block

Pelco D, Pelco P, Fastrax 2, Panasonic, DSCP, AD422, JVC

PTZ Control Protocol

Pelco Coaxitron

Protocol

Yes

General

Power Input &

Consumption

AC 100~240V, 50~60Hz, 200W

Operation Environment

Weight

Dimension (W x H x D)

0°C ~ 40°C (32oF ~ 104oF); 10% ~ 90% Relative Humidity, Non-condensing

7Kg (15.42 lbs), exclude hard drives

440 x 90 x 413 mm (17.3 x 3.54 x 16.3in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

H.264 Hybrid Stand-Alone DVR

Model No.

:

DV-G086

(16Ch.) /

DV-G088

(8Ch.) /

DV-G084

(4Ch.)

Features:

¾ Dual-Codec for H.264 / MJPEG recording

¾ Triplex Operation: Live /

Playback, Record, Network

¾ Embedded Linux operating system

¾ Hybrid function: Support recording of Megapixel IP camera

¾ USB Mouse support GUI

¾ Support VGA main output

¾ Real time live view for each channel

¾ Easy and flexible recording setup

– Preset record configuration, ezRecord™ for quick recording setting, or per channel configuration for normal and event recording

¾ Supports up to 3 internal SATA HDDs / 1 Optical drive + 2 HDDs

¾ USB2.0 ports for video clip exporting, support USB thumb drive, or other external storages

¾ Multiple built-in PTZ camera protocol (through RS485): Pelco D, Pelco P, DynaColor, AD422

¾ 2x Digital Zoom on both live and playback modes

¾ Programmable Call-monitor switching sequence

¾

Export video clip includes Player software and can be auto-played in any PC

¾ Remote monitoring, recording, playback, system setup, and PTZ camera control

¾

Supports NTP for time synchronization

¾ Supports Mobile View software

¾ CMS for large-scale video management

¾ Easy software upgrade via Network, USB thumb drive, or CD-RW

¾ IR Remote controller

¾ Two levels of password protection

¾ Network supports Static IP, DHCP, PPPoE and DDNS

Specifications:

Model No.

Video

Input

Operation System

Input IP devices

Video Operation

Outputs

Main Monitor

Call Monitor

VGA Output

Picture Refresh Rate

Digital Zoom

DV-G086

BNC x 16, 1.0Vp-p / 75Ω

DV-G088

BNC x 8, 1.0Vp-p / 75Ω

Linux Embedded

DV-G084

BNC x 4, 1.0Vp-p / 75Ω

Up to 4ch Up to 4ch Up to 2ch

Triplex+ (Live / Playback, Record, and Remote / Internet access)

BNC x 1, 1.0Vp-p / 75 Ohm

BNC x 1, 1.0Vp-p / 75 Ohm

800 x 600, 1024 x 768, 1280 x 1024 pixels @ 60Hz

NTSC: 30 fps/ch., PAL: 25 fps/ch.

2X, Live view & Playback

Audio

Input

Output

Main out

Call Audio

Compression Method

Data Rate

Terminal Block, x16 Line-in Terminal Block, x8 Line-in

RCA x 1, 1 Channel Line-Out

RCA x 1, 1 Channel Line-Out

Proprietary

8Kb/s per ch

Terminal Block, x4 Line-in

Recording

Compression Method

Recording Mode

Pre-Alarm

Resolution

& Rate

720x480

720x240

360x240

Recording Quality

Image Size

Storage Mode

Data Life Time

Playback

Playback

Playback Speed

Adjustment

Retrieve

Storage

Build-in Storage

Export

Alarm

Alarm Input

Motion Detection

Alarm Detection

Video Loss Detection

Alarm Relay Output

Communication

Network Connectivity

Compatible IP Camera

Remote Control Software

Remote Operation

Access Control

RS485

PTZ Control Protocol

General

Power Input &

Consumption

Operation Environment

Dimension (W x H x D)

Max 60fps

Max 120fps

Max 240fps

H.264/ MJPEG

Schedule, Alarm, Motion

1 ~ 30Sec

Max 60fps

Max 120fps

Max 240fps

5 levels presets, adjustable

1K to 20K Byte/Picture

Linear/Circular

Programmable

Play, Stop, Pause, Single Frame, Rewind, Forward, Search

1x, 2x, …, 32x

Date/Time, Event

Max 30fps

Max 60fps

Max 120fps

SATA x 3, up to 3 devices: HDD / CD-RW / DVD+RW

USB 2.0 x 3, support ThumbDrive, CD-RW, or DVD+RW

X16, Terminal Block x8 , Terminal Block x4 , Terminal Block

16 x 12 Grid Array, Sensitivity, Trig level adjustable

N.C./N.O., Programmable

Programmable

X1, Terminal Block

Ethernet RJ45, 10/100Mbps, support DHCP/PPPoE/DDNS

SONY, AXIS, ACTi, Vivotek, Dynacolor

CMS(Central Management Software), Web-Browser based Software

Monitor, Playback, Recording, System Setup, Dome Camera Control, Archive

2 Level Password

Terminal Block

Pelco D, Pelco P, Fastrax 2, Panasonic, DynaColor, AD422

AC 100/240V, 50~60Hz, 84WAdaptor

-5°C ~ 40°C (23oF ~ 104oF); 5% ~ 95% Relative Humidity, Non-condensing

362 x 90 x 350 mm (17.3 x 3.5 x 13.8in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

H.264 Stand-Alone

DVR

Model No.

:

DV-L86

(16Ch.) /

DV-L88

(8Ch.) /

DV-L84

(4Ch.)

Features:

¾ H.264 compression for recording

¾ Triplex Operation: Live / Playback,

Record, Network

¾ Embedded Linux operating system

¾ Support VGA main output

¾ Real time live view for each channel

¾ Easy to use Graphical User Interface

(GUI), also support USB Mouse

¾ Easy and flexible recording setup – Preset record configuration, ezRecord™ for quick recording setting, or per channel configuration for normal and event recording

¾

Support up to 2 internal SATA HDDs

¾ USB2.0 ports for video clip exporting, support USB thumb drive, or other external storages

¾ Multiple built-in PTZ camera protocol (through RS485): Pelco D, Pelco P, DynaColor, AD422

¾ Programmable Call-monitor switching sequence

¾ Export video clip includes Player software and can be auto-played in any PC

¾ Remote monitoring, recording, playback, system setup, and PTZ camera control

¾ Easy software upgrade via Network, or USB thumb drive

¾ IR Remote controller

¾ Two levels of password protection

¾ Network supports Static IP, DHCP, PPPoE and DDNS

Specifications:

Model No.

Input

Operation System

Outputs

Main Monitor

Call Monitor

Video Operation

VGA Output

Picture Refresh Rate

Input

Output

Main out

Call Audio

Compression Method

Data Rate

Compression Method

Recording Mode

Pre-Alarm

Resolution &

Rate

720x480

720x240

360x240

DV-L086

Video

BNC x 16, 1.0Vp-p / 75Ω

DV-L088 DV-L084

BNC x 8, 1.0Vp-p / 75Ω

Linux Embedded

BNC x 1, 1.0Vp-p / 75 Ohm

BNC x 1, 1.0Vp-p / 75 Ohm

Triplex+ (Live / Playback, Record, and Remote / Internet access)

800 x 600, 1024 x 768, 1280 x 1024 pixels @ 60Hz

NTSC: 30 fps/ch., PAL: 25 fps/ch.

D-Sub x16, Line-in

Audio

D-Sub x8, Line-in

RCA x 1, 1 Channel Line-Out

RCA x 1, 1 Channel Line-Out

Proprietary

8Kb/s per ch

Compression Method

Recording

Recording Mode

Pre-Alarm

D-Sub x4, Line-in

Max 60fps

Max 120fps

Max 240fps

Continue …, Please turn over.

Specifications Continued:

Recording Quality

Image Size

Storage Mode

Data Life Time

Playback

Playback Speed Adjustment

Retrieve

Build-in Storage

Export

Alarm Input

Motion Detection

Recording

5 levels presets, adjustable

1K to 20K Byte/Picture

Linear/Circular

Programmable

Playback

Play, Stop, Pause, Single Frame, Rewind, Forward, Search

1x, 2x, …, 32x

Date/Time, Event

Storage

SATA x 2

USB 2.0 x 1, support ThumbDrive, External CD-RW, or DVD+RW

Alarm

X16, D-Sub X8, D-Sub X4, D-Sub

16 x 12 Grid Array, Sensitivity, Trig level adjustable

Alarm Detection

Video Loss Detection

Alarm Relay Output

N.C./N.O., Programmable

Programmable

X1, D-Sub

Communication

Network Connectivity

Remote Control Software

Remote Operation

Access Control

Ethernet RJ45, 10/100Mbps, support DHCP/PPPoE/DDNS

Web-Browser based Software

Monitor, Playback, Recording, System Setup, Dome Camera Control, Archive

2 Level Password

RS485 D-Sub

PTZ Control Protocol

Pelco D, Pelco P,

Fastrax 2, Panasonic

, DynaColor, AD422

IR Remote controller Yes

Power Input & Consumption

General

AC 100/240V, 50~60Hz, 60WAdaptor

Operation Environment

Weight

Dimension (W x H x D)

-5°C ~ 40°C (23 o

F ~ 104 o

F); 5% ~ 95% Relative Humidity, Non-condensing

2.5Kg (5.4lbs), exclude hard drives

300 x 60 x 362 mm (11.8 x 2.3 x 14.2in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Compact H.264 Stand-Alone

DVR

Model No.

:

DV-L84H

(4Ch.)

Features:

¾ Compact Half-Rack size

¾ H.264 compression for recording

¾ Triplex Operation: Live / Playback, Record,

Network

¾ Embedded Linux operating system

¾ Support VGA main output

¾ Real time live view for each channel

¾ Easy to use Graphical User Interface (GUI)

¾ Easy and flexible recording setup – Preset record configuration, ezRecord™ for quick recording setting, or per channel configuration for normal and event recording

¾ Single USB2.0 port for video clip exporting, support USB thumb drive, or other external storages

¾ Multiple built-in PTZ camera protocol (through

RS485): Pelco D, Pelco P, DynaColor, AD422

¾ Export video clip includes Player software and can be auto-played in any PC

¾ Remote monitoring, recording, playback, system setup, and PTZ camera control

¾ Easy software upgrade via Network, or USB thumb drive

¾ IR Remote controller

¾ Two levels of password protection

¾ Network supports Static IP, DHCP, PPPoE and DDNS

Specifications:

Model No.

Input

Operation System

Output

Video Operation

VGA Output

Picture Refresh Rate

Input

Output

Compression Method

Data Rate

Compression Method

Recording Mode

Pre-Alarm

Resolution &

Rate

720x480

720x240

360x240

DV-L084H

Video

BNC x 8, 1.0Vp-p / 75Ω

Linux Embedded

BNC x 1, 1.0Vp-p / 75 Ohm

Triplex+ (Live / Playback, Record, and Remote / Internet access)

800 x 600, 1024 x 768, 1280 x 1024 pixels @ 60Hz

NTSC: 30 fps/ch., PAL: 25 fps/ch.

Audio

D-Sub x4, Line-in

RCA x 1, 1 Channel Line-Out

Proprietary

8Kb/s per ch

Recording

Compression Method

Recording Mode

Pre-Alarm

Max 30fps

Max 60fps

Max 120fps

Continue …, Please turn over.

Specifications Continued:

Recording Quality

Image Size

Storage Mode

Data Life Time

Playback

Playback Speed Adjustment

Retrieve

Build-in Storage

Export

Alarm Input

Motion Detection

Recording

5 levels presets, adjustable

1K to 20K Byte/Picture

Linear/Circular

Programmable

Playback

Play, Stop, Pause, Single Frame, Rewind, Forward, Search

1x, 2x, …, 32x

Date/Time, Event

Storage

SATA x 1

USB 2.0 x 1, support ThumbDrive, External CD-RW, or DVD+RW

Alarm

X4, D-Sub

16 x 12 Grid Array, Sensitivity, Trig level adjustable

Alarm Detection

Video Loss Detection

Alarm Relay Output

N.C./N.O., Programmable

Programmable

X1, D-Sub

Communication

Network Connectivity

Remote Control Software

Remote Operation

Access Control

Ethernet RJ45, 10/100Mbps, support DHCP/PPPoE/DDNS

Web-Browser based Software

Monitor, Playback, Recording, System Setup, Dome Camera Control, Archive

2 Level Password

RS485 D-Sub

PTZ Control Protocol Pelco D, Pelco P, Fastrax 2, Panasonic, DynaColor, AD422

IR Remote controller Yes

Power Input & Consumption

General

AC 100/240V, 50~60Hz, 60WAdaptor

Operation Environment

Weight

Dimension (W x H x D)

-5°C ~ 40°C (23°F ~ 104°F); 5% ~ 95% Relative Humidity, Non-condensing

1.82Kg (4lbs), exclude hard drives

215 x 57 x 330 mm (8.5 x 2.25 x 13in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Pentaplex Real-Time H.264 Stand-Alone DVR

H-Series

Model No.:

DVP-H0412

(4CH) /

DVP-H0824

(8CH) /

DVP-H1648

(16CH) system

¾ H.264 high quality video

¾ User-friendly GUI Menu and Front Design, operate with USB Mouse or IR Remote controller

¾ New Dual Encoding Technology enables separate controls for local video encoding and network transmission.

¾ Support VGA main output, BNC main output, and BNC Spot monitor output.

¾ 1 Ch Audio inputs, and 1 Ch audio outputs

¾ Remote access through CMS software or Web browser; support Multi-site, Multi-user access.

¾ CMS software features multi site control, up to 64 cameras display, remote setup, remote search, two-way

¾ Support Emergency recording, and Pre-event recording up to 3 hours.

¾ Configurable Normal, Event, and Emergency recording frame rate & picture quality per channel

¾ Easy Playback with Search function or One-touch playback, playback speed up to 64 times

¾ Equipped with DVD-RW and 4 USB ports for video clip exporting.

¾ Archive can be done on Live or Playback mode. It is in EXE file format or JPEG file when it’s a snapshot.

¾ Network supports Static IP, DHCP, PPPoE and DDNS

¾ E-mail Notification with Video Clip, Still Image, or Message

¾ 1 Ch POS and DVR integration included, which allows POS transaction data to be recorded with video. These videos can also be searched and playback by transaction data.

¾ PTZ camera communication through RS485 port, support multiple PTZ camera protocols.

¾ Event setup includes Alarm in, Video Loss, Motion, and Emergency.

¾ Password protection for individual user account; system access configurable in group setting

Operation System

Pentaplex

Operation

Input

Main Monitor

Output

VGA Output

Spot Monitor

Resolution – Live Video

Video Stream

Operation

Linux Embedded

Record, Playback, Monitoring, Back up and Network access at the same time

Front Panel, Remote Controller (Multi-ID support), USB Mouse

Video

4CH, Composite Video, BNC 8CH, Composite Video, BNC 16CH, Composite Video, BNC

BNC x 1

Max. 1024 x 768 pixels

BNC x 1

NTSC: 704x480 pixels

Dual

On/Off (240fps record @ CIF w/ Dual on)

Continue …, Please turn over.

Input

Output

DVR Specifications …

Audio

RCA x 1

RCA x 1

Recording

H.264

Continuous, Schedule, Alarm, Motion, Emergency

Max 60fps Max 120fps

Compression Method

Recording Mode

Resolution

& Rate

704x480 Max 60fps

Event

Record

Pre-event

Duration

Recording Quality

Playback

Playback Speed

Retrieve

Build-in Storage

Back up / Export

Archive File Format

Alarm Input

Motion Detection

Alarm Relay Output

Protocol

Remote Access

Remote Function

Time Setting

Password

PTZ Camera

RS232C

Firmware Update

Power

Operation

Environment

Dimension (W x H x D)

Approval

On / Off

Up to 180min

Super / High / Standard

Playback

Play, Stop, Pause, Reverse, Forward, and Frame by Frame

1x, 2x, …, 32x, 64x

Date/Time, Calendar, Event (Include POS Data)

Storage

SATA x 3, up to 3 devices: HDD / DVD+RW

USB 2.0 x 4, support ThumbDrive, DVD+RW

EXE (Video) / JPEG (Still Image)

Alarm

X4, NO or NC

22 x 15 Grid Array

X4, NO or NC

Network

10/100 Base-T, TCP/IP, UDP, HTTP, SMTP, NTP, DHCP, PPPoE, DDNS

Client program or Web (IE) browse, Multi-user access, Two-way Audio, CMS Software incl.

Easy GUI, Live Monitoring, System setup, Search, Playback, Backup, and PTZ control

Network Time Protocol Support

Communication

Multi-user in separate group with configurable system access

RS485 port, support a variety of camera protocols

D-sub 9 pin female (Ready for POS Connection)

Network, USB 2.0 port, or CD/DVD

General

DC 12V, 5A, AC Adapter included

5oC ~ 40oC (41oF ~ 104oF); 0% ~ 90% Relative Humidity, Non-condensing

350 x 65 x 380mm (13.8 x 2.56 x 15in)

FCC Class A / CE / UL

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Pentaplex Real-Time MPEG4 Stand-Alone DVR

O- Series

system

¾ MPEG-4 ASP high quality video

¾ User-friendly GUI Menu & Front Design, operate with USB Mouse and IR Remote controller

¾ New Dual Encoding Technology enables separate controls for local video encoding and network transmission.

¾ Multiple Video outputs include Main Monitor, Loop-through, Call monitor, and VGA main output

¾ Support video and POS transaction data synchronized recording and retrieve.

¾ External hard drives through eSATA port can extend video storage to longer hours.

¾ 8 Ch / 16 CH Audio inputs, and 1 Ch audio outputs

¾ Remote access through CMS software or Web browser; support Multi-site, Multi-user access.

¾ CMS software features multi site control, up to 64 cameras display, remote setup, remote search, two-way

¾ Support Emergency recording, and Pre-event recording up to 3 hours.

¾ Multiple Search categories: Date/Time, Calendar, and Event

¾ Equipped with DVD Writer and 4 USB ports for video clip exporting.

¾ Archive in EXE file format or JPEG file for still image can be done on Live and Playback modes.

¾ Network supports Static IP, DHCP, PPPoE and DDNS

¾ E-mail Notification with Video Clip, Still Image, or Message

¾ PTZ camera communication through RS485 port, support multiple PTZ camera protocols.

¾ Event setup includes Alarm in, Video Loss, Motion, and Emergency.

Operation

Operation System

Pentaplex

Operation

Video

Input

Output

Main Monitor

Call Monitor

Loop

VGA Output

Resolution – Live Video

Video Stream

Linux Embedded

Record, Playback, Monitoring, Back up and Network access at the same time

Front Panel, Remote Controller (Multi-ID support), USB Mouse

8CH, Composite Video, BNC

BNC x 8

BNC x 1

BNC x 3

16CH, Composite Video, BNC

BNC x 16

Max. 1024 x 768 pixels

NTSC: 704x480 pixels

Dual Switchable

Continued on next page.

Specifications Continued:

Audio

Input

Output

Recording

Compression Method

Recording Mode

Recording Rate

Event Pre-event

Record Duration

Recording Quality

Playback

Playback

Playback Speed

Retrieve

Storage

Primary Storage

External Storage

Back up / Export

Archive File Format

Alarm

Alarm Input

Motion Detection

Alarm Relay Output

Network

Ethernet

Remote Access

Remote Function

Network Trans. Quality

Network BW Control

Time Setting

Communication

Password

PTZ Camera

RS232C

Firmware Update

General

Power

Operation Environment

Dimension (W x H x D)

Approval

RCA x 8

Schedule, Alarm, Motion, Emergency

704x480: 240fps

Play, Stop, Pause, Reverse, Forward, and Frame by Frame

Built-in DVD Writer, 4 USB 2.0 ports, support USB storage devices

EXE (Video) / JPEG (Still Image)

X8, NO or NC

X8, NO or NC

RCA x 1

Advanced MPEG4 ASP

On / Off

Up to 180min

Super / High / Standard

1x, 2x, …, 32x, 64x

Date/Time, Calendar, Event

SATA Hard Drive x 4

22 x 15 Grid Array

704x480: 480fps e-SATA up to 12TB (optional)

10/100/1000 GBE x 2, support TCP/IP, UDP, HTTP, SMTP, DHCP, PPPoE, DDNS

CMS Software or Web (IE) browse, Multi-user access, Two-way Audio

Easy GUI, Live Monitoring, System setup, Search, Playback, Backup, and PTZ control

Standard 1,2,3,4 / High 1,2,3 / Super 1,2,3

56Kps ~ unlimited

NTP - Network Time Protocol Support

Multi-user in separate group with configurable system access

RS485/422 port (Terminal block), support a variety of camera protocols

D-sub 9 pin female

Network, USB 2.0 port, or CD/DVD

RCA x 16

X16, NO or NC

X16, NO or NC

DC 12V, 6.7A, AC Adapter included

5°C ~ 40°C (41°F ~ 104°F); 0% ~ 90% Relative Humidity, Non-condensing

430 x 88 x 400mm (16.9 x 3.46 x 15.7in)

FCC Class A / CE / UL

Design and specifications are subject to change without prior notice.

DVR System

External Storage

Disk Box for Digital Video Recorder

Model No.: ARS-3010L

Extend DVR Storage Capacity & Recording

Time

Connect to PC-Based DVR System

Use Low Cost IDE Hard Drives via a SCSI

Interface to reach the highest possible capacity

Convenient, Cost-effective , and Expandable

Storage Equipment

Features:

¾

High capacity of data storage up to 4 IDE hard drives with each Disk Box

¾

48-bit LBA supports Big Drives Technology (exceeding 137GB HDD)

¾

Embedded ACARD SCSIDE engine converting IDE to SCSI

¾

Fully supporting Ultra160 LVD SCSI Features

¾

Expandable up to 15 Disk Boxes, total Hard Disk capacity up to 15 Terabyte by installing 60 pieces of 250GB IDE hard drives

¾

On-board Flash ROM easy for firmware upgrade

¾

Industrial Rack Mount Housing

Specifications:

Host Interface

Controller

Hard Disk Type

HDD Expansion

IDE Bus

Easy Management

Operating Environment

Safety

Power

Dimension

Weight

Ultra160 LVD SCSI up to 160MB/sec transfer rate External SCSI Port for daisy chain up to 15 sets of disk boxes Selectable SCSI

ID sets from 0 to 15

Contains 2 ACARD SCSIDE Processors with 2 dedicated IDs 2 SCSI IDs separately configuring 2 IDE HDDs to be JBOD or normal

Built-in ACARD RISC micro-controller

Supports ATA 133/100/66/33 HDD Supports Ultra DMA mode with data transfer rate up to 133MB/sec

Supports 48-bit LBA with Big Drives Technology Maximum capacity up to 15TB by linking 60 pieces of 250GB hard disks

2 independent channels of IDE bus 4 internal IDE connectors

On-board Flash ROM easy for firmware upgrade JBOD / Normal Mode function selected by dip switch

Operating Temperature: 0oC ~ 50oC (32oF ~ 122oF) Non-operating Temperature: -20oC ~ 70oC (-4oF ~ 158oF)

FCC, CE

Power supply of 162W AC input voltage: 47 ~ 63Hz, 100 ~ 127V / 3A; 200 ~ 240V / 1.5A

1U rack mount 44(H) x 483(W) x 400(D)mm (1.75” x 19” x 15.75”)

6Kg (13.2lb) without hard disks

Hard disk drives are not included. Specifications are subject to change without prior notice.

DVR System

External Storage

IEEE 1394 External Video Storage System

Model No.: DS-100

Features:

¾ Expand your DVR storage space via IEEE 1394A FireWire connection

¾ Daisy chain up to 4 DS-100 units create a stackable storage system (16 HDDs in total) to create a

stackable system.

¾ Compatible with Tayama Stand Alone DVR: DV-204T12 and DV-208T12

¾ Solid body protection and excellent heat dissipation

¾ Active LEDs to indicate power and data access

¾ Supports 3.5” IDE Hard Disk (PATA)

¾ Shock absorbent rubber stands

¾

Stackable design

Specifications:

Model No.

Interface

Interface

Data Transfer Rate

Internal HDD

Interface

Cooling Device Cooling FAN

Power

Supply

Power Input

General

Unit

Dimension(WxHxD)

Weight(w/o any HDD

Operation Temp.

Storage Temp.

DS-100

IEEE1394A(Input & Output Port)

Up to 400 Mbps

3.5” IDE, PATA

2-40x40mm cooling fans

90~240 VAC, 47~63Hz, 200W(Max), active PFC

432X45X410Xmm(17x1.8x16inches)

4.2 Kg (9.3lbs)

32 ~ 104º F(0º~40ºC)

-4 ~158 ºF (-20º~70ºC)

External Video Storage System

Model No.: DS-200

Features:

¾ • Powerful Linux Embedded System

¾ • RAID 0, RAID 1, RAID 5 and JBOD file system

¾ • Compatible with Tayama Stand Alone DVR: DV-216T48, DV-

16T12, DV-216T12

¾ • Remote accessorily for different platform via different protocols(SMB/CIF/NFS)

¾ • Supports up 4x3.5" IDE hard Drives (SATA)

¾ • LCD front panel to indicate the system information

¾ • Web Management Tools

¾ • SNMP supports for advanced network monitor

Design and specifications are subject to change without prior notice.

DVR System

Standalone

4-Ch Triplex Media DVR with Built-in 8” LCD Monitor

Model No.: MDV-LR804-3

Features:

¾

Compact size suitable for Retail and Home Video Surveillance

¾

8” High Contrast LCD Display

JPEG

¾

Triplex operation – Simultaneous Record, Playback, and Network Access

¾

Real time live view for each channel

¾

Record types support continuous, motion, event, and schedule recording, with 5 levels of image quality to choose. Recording rate: Up to 120fps.

¾

Video Playback and Search by date/time, percent, and events. Support multiple playback speeds up to 32x and slower playback as low as 1/16x.

¾

Client software and Web based Remote Viewing program, allow remote Monitoring, Search, and Backup download

¾

Simple backup using an USB Mass-storage Device. Remote viewer backup can be in the format of AVI or

JPEG.

¾

User friendly – operated by Mouse or IR Remote Controller

¾

4 Ch Sensor input; 1 Ch Alarm Output

¾

1 Ch Loop out and Spot Monitor out – provide extra Monitoring view and Event Spot view

¾

Support Auto Sequencing, Picture in Picture, and 2x Digital Zoom

¾

Support PTZ cameras through RS-485 connection and easy control by Mouse

¾

Three levels of password protection

Specifications:

DVR Specifications

Multiplex function

Video Format

Video

Video Input

Video Output

Display Resolution

Recording

Display Speed

Video Display

Auto Sequence

Compression Method

Compression Quality

Recording Rate

Recording Mode

Recording Resolution

Search Mode

Playback

Playback Speed

Alarm

Storage

Alarm Input / Output

Alarm Detection

Alarm Mode

Post Alarm

Motion Detection

Event Spot

Internal Storage

Backup

Remote

Network Connectivity

Remote Operation

Remote Software

PTZ Communication

User Input Interface

PTZ Camera Control

Serial Interface

Access Control

Display

Resolution

Brightness

Contrast Ratio

View Angle

Panel

Power Input

Weight

Dimension (W x H x D)

Triplex (Playback / Recording / Ethernet)

NTSC / PAL Auto detection

BNC x 4, 1.0Vp-p / 75 Ohm

BNC x 2 (Loop-out and Spot), 1.0Vp-p / 75 Ohm

704x240 (NTSC) / 704x288 (PAL)

NTSC: 120PPS (4 CH); PAL: 100PPS (4 CH)

Full screen, 4 Split, PIP, Sequence, Digital Zoom

1 ~ 99sec Selectable

MJPEG

Lowest / Low / Normal / High / Highest

Max. 120FPS (NTSC); 100FPS (PAL)

Time Cyclic / Motion / Schedule / Alarm

704x240 (NTSC) / 704x288 (PAL); 352x240 (NTSC) / 352x288 (PAL)

Date & Time search, Event search, and Percent search

Forward & Backward: Fast speed – 1x, 2x, 4x, 8x, 16x, 32x

Slow speed – 1/2x, 1/4x, 1/8x, 1/16x

4 Sensor Input and 1 Relay Out

N.C. / N.O. Programmable

Sensor Input / Video Loss

Alarm Output duration: 1 ~ 99sec Selectable

Multiple configurable detection area and Mask

Switching Interval, Alarm Pop-up, Motion Pop-up, Event Pop-up

3.5” IDE Hard Drive

USB Mass-storage Device backup, Download via IP network

Ethernet RJ45, support DHCP/PPPoE/DDNS

Monitoring, Playback, System Setup, PTZ Camera Control

Web based Viewer included

RS485

PS2 Mouse, USB Mouse, USB storage imput, IR Remote Controller

Support Pan / Tilt / Zoom with Mouse control

D-Sub 9 pins for Alarm I/O and RS-485

3 Level Password, Administrator / Manager / User

LCD Specifications

8” LCD Monitor

800(H) x 600(V)

350 cd/m2

500:1

70° / 70° (L / R); 70° / 70° (U / D)

Up / Down (Volume) / Menu / Source / Power

General

External Adaptor, DC 12V (5A), AC 100/240V in

4.8Kg (10.5lbs), with built-in HDD x 1

193 x 182 x 198mm (7.6 x 7.2 x 7.8in)

Design and specifications are subject to change without prior notice.

DVR System

Standalone

Triplex All-In-One DVR with Built-in LCD Monitor

model, and 19” for 8 Ch model

¾ Triplex operation – Simultaneous Record, Playback,

Sequence mode is user definable.

¾ MPEG4 Compression, image size is as low as 3 ~ 5

¾ Recording rate: Up to 120fps total in CIF mode

¾ Recording can be scheduled with timer, alarm, or individual channel. Other record functions also include Panic recording, Pre and Post event recording.

¾ Remote access through remote software or web browser; Remote functions include Live monitoring,

Calendar and Timeline. Event search covers events such as motion, alarm, video loss, etc.

¾ Recorded picture (including audio) can be archived to USB Flash drive. Playback software is embedded with way Audio Conference also possible through Internet.

¾ 4 Alarm inputs (4Ch model) or 8 Alarm inputs (8Ch model); and1 Relay Output connection; a variety of speed dome protocols are also supported.

¾ IR Remote Controller included for another easy operation

¾ Support Email notification to specific users when events occur

Multiplex function

Video Format

Video Input

Video Output

Video

Display Speed

Video Display

Auto Sequence

Digital Zoom

Video

Covert Cam

Function

Recording

Compression

Method

Image Size

Triplex (Playback / Recording / Ethernet)

NTSC / PAL Auto detection

BNC x 4, 1.0Vp-p / 75 Ohm BNC x 8, 1.0Vp-p / 75 Ohm

BNC x 1 (spot-out), 1.0Vp-p / 75 Ohm

Real time: 30fps (NTSC); 25fps (PAL) per camera

Full screen, 4 Split, Sequence Full / 4 / 6 / 8, Sequence

Multi-view screen and Channel selection programmable

8x Digital zoom with movable zoom area

Programmable

MPEG4

3-5KB (352x240), 5-10KB (704x240), 6-16KB (704x480)

Playback

Audio

Alarm

Storage

Compression

Quality

Recording Rate

Recording

Resolution

Recording Mode

Record

Scheduling

Pre/Post Event

Rec.

Search Mode

Playback Display

Playback Speed

Audio Input

Audio output

Intercom

Alarm Input

Alarm Output

Internal Storage

Backup

Network

Connectivity

Remote Operation

Remote

Remote Software

PTZ

Communication

Motion Detection

Event / Log Search

User Input Interface

PTZ Camera Control

Serial Interface

Access Control

Display

Integrated

Monitor

Resolution

Brightness

Contrast Ratio

General

View Angle

Power Input

Power

Consumption

Operation Temp.

Weight

Dimension (H x W x D)

Low / Standard / High / Highest

Max. 120FPS (NTSC); 100FPS (PAL)

352x240 / 704x240 / 704x480 (NTSC); 352x288 / 704x288 / 704x576 (PAL)

Time Cyclic / Motion / Schedule / Alarm / Panic

Daily, Weekly – adjust specific hour per channel

5 sec (Pre), 3 min (Post), programmable per camera

Time search with Calendar and Timeline display, and Event search

Full or Multi-view screen

Forward & Backward: Fast speed – 1x, 2x, 4x, 8x, 16x, 32x, 64x

4 x line-in, RCA sockets

1 x line-out, RCA socket

2-way Audio Conference

4 x TTL, programmable as N.C. / N.O. 8 x TTL, programmable as N.C. / N.O.

1 x Relay with N.C. / N.O. contact; 30V DC / 1A, 125V AC / 0.5A resistive

1 x 3.5” IDE Hard Drive

2 x USB ports (Flash memory stick or USB HD), Download via IP network

Ethernet RJ45, support DHCP/PPPoE/DDNS

Monitoring, Recording, Playback, Setup, Backup, PTZ Camera Control

Client program (included) or I.E. (web browser)

RS485

16 x 16 grid, Sensitivity levels: 10

Search events for user log in/out, config changes, remote access

USB Mouse, IR Remote Controller

Support Pan / Tilt / Zoom with Mouse control, Front panel, or Remote access

RS-232

3 Level Password, Administrator / Manager / User

17” LCD 19” LCD

1280(H) x 1024(V)

300 cd/m2

800:1

85° / 85° (L / R); 80° / 80° (U / D) 70° / 70° (L / R); 80° / 80° (U / D)

External Adaptor, DC 12V (5A), AC 100/240V in

Approx. 60Watts

0°C ~ 50°C (32°F ~ 122°F); 5% ~ 85% Relative Humidity, Non-condensing

8Kg (17.6lbs), with built-in HDD

315 x 350 x 65mm / 12.4” x 13.8” x 2.6” (Stand not included)

Design and specifications are subject to change without prior notice.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
