HAMEG HMS Series Sensitivity Accuracy Quality Simplicity HAMEG The HMS Series is the digital Spectrum Analyzer from HAMEG HAMEG HMS Series Differences and similarities Oscilloscope Spectrum Analyzer Yt-display (Amplitude over time) Yf-display (Amplitude over frequency) X-Axis Linear (Time), FFT (Frequency) Linear (Frequency), Zero Span (Time) Y-Axis Linear (Amplitude) Logarithmic (Power) Display Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 2 HAMEG HMS Series Content Sensitivity Reason’s to buy a HMS Applications for the HMS series Target customers Value proposition Key specifications of the HMS series Extras included Ordering information Suggested options and accessories Competitive positioning Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 3 HAMEG HMS Series Reason’s to buy a HMS - Sensitivity Accuracy Quality - Best price-performance ratio in it’s class First digital Spectrum Analyzer from HAMEG Noiseless design without fan. Very fast boot time (<8 seconds). Available with Tracking Generator (HMS1010 / HMS3010) and upgradable with Preamplifier. Trace memory and mathematic functions for subtraction of constant deviations, incl. VSWR wizard for easy measurement setup. Intuitive Interface: Taking measurements with a HMS is as easy as working with an oscilloscope. 8 Marker with delta marker, noise marker and miscellaneous peak and peak search functions. Built in limit line test. HMS is a Platform where new functions are retrofittable via firmware upgrade. Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 4 HAMEG HMS Series Applications and target customers Applications - EMI Precompliance Measurements - Receivers / Transmitters (frequency response, amplitude, bandwidth, modulation, harmonics) - Cable response (frequency response, loss, equalization) - Amplifier characteristics (frequency response, amplification) - Filter characteristics (pass band, stop band, cut of frequency) - Antennas (resonance, matching, gain, loss) Sensitivity - Frequency and channel allocation on cable TV networks Accuracy Quality - Video and audio carriers on TV Signals - Signal characteristic with built in AM / FM receiver and demodulation Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 5 HAMEG HMS Series Applications and target customers Target customer - Engineers which need to verify pre compliance for CE mark - Developers which need to qualify EMI radiation from systems or circuits or conducted emission in combination with a HM6050-2 - Education customers like universities for education purposes - Service technician who need a light, small but powerful instrument with fast boot time Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 6 HAMEG HMS Series Value proposition Sensitivity Accuracy Quality Very good price/performance ratio Tracking Generator and Preamplifier available Only 890,-€ difference between base and full configuration -6dB EMI filters and EMC test software suite included HMS series save valuable measurement time of the user due to: Fast boot time Easy operation Fast front panel responsiveness Easy documentation with memory stick or free of charge PC software (incl. EMC measurements and report generation) Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 7 HAMEG HMS Series Key specification of the HMS series Sensitivity Accuracy Quality 1GHz and 3GHz frequency range available Amplitude measurement range -114dBm…+20dBm, DANL -135dBm with Preamp. Option HO3011 Sweep time 20ms…1000s Resolution bandwidth 100Hz…1MHz in 1-3 steps, 200kHz (-3dB), additional 200Hz, 9kHz, 120kHz, 1MHz (-6dB) Spectral purity ‹ -100dBc/Hz (@100kHz) Video bandwidth 10Hz…1MHz in 1-3 steps Tracking Generator (HMS1010/HMS3010) -20dBm/0dBm Integrated AM and FM demodulator (int. speaker) Detectors: Auto-, min-, max-peak, sample, RMS, quasi-peak 8 Marker with delta marker, miscellaneous peak functions Crisp 16.5cm (6.5”) TFT VGA display, LED backlight, DVI-D output 3 x USB for mass-storage, printer and remote control, optional IEEE-488 (GPIB) or Ethernet/USB Interface incl. Webserver at Ethernet connection Small form factor but stapable within the HAMEG system Very fast boot time Fanless design Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 8 HAMEG HMS Series Extras included: Sensitivity Accuracy Improved EMI Pre-Compliance measurement software available. Free Windows PC software for screenshot and panel setup capture, save and recall device settings and command line for testing remote control. - 6dB CISPR filter (200Hz, 9kHz, 120kHz, 1MHz) for EMI measurements AM/FM demodulation Quasi-Peak detector for EMI Precompliance measurements Save investments since the Preamplifier can be retrofit by the user for a small amount of money at any time. Very easy to understand and flexible remote commands, due to SCPI based command structure which is compatible to any ASCII sign based software environment. Various accessories available, incl. EMI Field probes and VSWR bridge. Operating system including processor board built a platform, which can be upgraded with new functions via firmware by the user. Extensive context sensitive help is always just one button away. Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 9 HAMEG HMS Series Ordering information Spectrum Analyzer HMS1010 / HMS3010 – 100kHz…1GHz / 100kHz…3GHz, incl. Tracking Generator – Preamplifier (HO3011) available Accessories included: – 2x HZ21 Adapter plug (N plug to BNC) – Dual-Interface USB/RS-232 (HO720) Sensitivity – Operating Manual – Power cord Accuracy – CD-ROM with software, driver, manual and other information Quality – EMI Pre-Compliance measurement Software Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 10 HAMEG HMS Series Ordering information Spectrum Analyzer HMS1000 / HMS3000 – 100kHz…1GHz / 100kHz…3GHz, no Tracking Generator – Preamplifier (HO3011) available Accessories included: – HZ21 Adapter plug (N plug to BNC) – Dual-Interface USB/RS-232 (HO720) Sensitivity – Operating Manual – Power cord Accuracy – CD-ROM with software, driver, manual and other information Quality – EMI Pre-Compliance measurement Software Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 11 HAMEG HMS Series Ordering information Spectrum Analyzer HMS1000E (successor HM5510) – – – – – – 100kHz…1GHz, no Tracking Generator Amplitude Measurement Range -104…+20dBm Resolution Bandwidth 10kHz…1MHz in 1–3 Steps, 200kHz (-3dB) Video Bandwidth 1kHz…1MHz in 1-3 Steps No further options available (no Preamplifier, no Tracking Generator) No EMI measurement software Accessories included: – HZ21 Adapter plug (N plug to BNC) – Dual-Interface USB/RS-232 (HO720) Sensitivity – Operating Manual – Power cord Accuracy – CD-ROM with software, driver, manual and other information Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 12 HAMEG HMS Series Ordering information EMI Precompliance Set 1 (1GHz) – HM6050-2: LISN (Line-Impedance-Stabilisation-Network) – HMS1000: Spectrum Analyzer – HZ530: 1GHz EMI Near-field probe set – 1x E-field probe – 1x H-field probe – 1x High impedance probe – EMI Test Software EMI Precompliance Set 3 (3GHz) Sensitivity – HM6050-2: – HMS3000: Spectrum Analyzer – HZ540: Accuracy LISN (Line-Impedance-Stabilisation-Network) 3GHz EMI Near-field probe set – 1x E-field probe – 1x H-field probe Quality – 1x High impedance probe – 1x SMA to BNC cable 1.2m Simplicity – EMI Test Software HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 13 HAMEG HMS Series Suggested options and accessories optional accessories: – HO3011 Preamplifier -135dBm DANL (100Hz RBW) – HO730 Dual-Interface Ethernet/USB (including web server) – HO740 Interface IEEE-488 (GPIB) ,galvanically isolated – HZ547 3GHz VSWR bridge for HMS1010, HMS3010 – HZ520 Plug-in Antenna with BNC connection – HZ530 Near-Field Probe Set 1GHz for EMI diagnostics – HZ540 Near-Field Probe Set 3GHz for EMI diagnostics Sensitivity – HZ560 Transient limiter Accuracy – HZ575 75/50Ω Converter – HZ46 4RU 19'' Rackmount Kit Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 14 HAMEG HMS Series Competitive landscape for HMS Series Comparison using the traffic light principle Green (Go) – that is what customers want Yellow (Attention) – some customers want more Red (STOP) – will not be accepted by customers Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 15 HAMEG HMS Series HMS 3010 compared to 3 GHz class instruments End Model Quality GW Instek GSP830 TG Rigol DSA1030A HAMEG HMS3000 / HMS3010 Frequency range 9 kHz – 3 GHz 9kHz - 3GHz 9 kHz – 3 GHz 100 kHz – 3 GHz Phase noise -100 dBc/Hz at 100 kHz -80dBc/Hz at 1GHz -100 dBc/Hz at 100 kHz -100 dBc/Hz at 100 kHz Reference level / Measurement range -114 dBm – +20 dBm -110 dBm – +20 dBm -100 dBm – +30 dBm -114 dBm – +20 dBm DANL (Displayed Average Noise Level) -145 dBm with Preamplifier -135 dBm at ≥ -30 dBm -133 dBm with Preamplifier -135 dBm with Preamplifier Resolution Bandwidth 10Hz – 1 MHz in 1-3-10 steps 3kHz, 30kHz, 300kHz, 4MHz (10Hz, 100kHz opt) 10Hz – 1 MHz in 1-3-10 steps 100 Hz – 1MHz in1-3-10 steps, 200kHz Video Bandwidth 1Hz - 1MHz in 1-3-10 steps 10Hz - 1MHz in 1-3 steps 1Hz - 3MHz in 1-3-10 steps 10 Hz – 3 MHz in1-3-10 steps, 200kHz -6dB Filters (EMI) 200 Hz, 9 kHz, 120 kHz, 1 MHz 9 kHz , 120kHz (opt) not available 200 Hz,9 kHz,120 kHz, 1MHz Sweep 10 ms – 1000 s 50ms - 25.6s 10 ms – 3000 s 20 ms – 1000 s Span range 100Hz - 3GHz 2kHz - 3GHz in 1-2-5 sequence 100Hz - 3GHz 100Hz - 3GHz Tracking Generator Opt TG3 Opt 02 Opt DSA1030-TG3 Opt HMS3010 Frequency counter Resolution 1 Hz n.a. Resolution 1 Hz Resolution 1 Hz Detectors Max, Min, Sample. Normal, RMS Peak, Maximum hold, Freeze, Average Max, Min, Sample. Normal, RMS, Average Auto, Min, Max-Peak, Sample, RMS, Average, Quasi-Peak Marker 12 10 Marker / 5 Delta Marker 4 Marker / 3 Delta Marker 8 Marker / 7 Delta Marker Delta, Peak, Noise, Peak search, minimum, center Delta, Peak, Noise, Peak search, minimum, center Marker Functions Delta, Peak, Marker list Demodulation AM, FM, ASK, FSK (opt) AM, FM (opt) AM/FM AM, FM Interfaces USB, Ethernet USB, RS-232 USB, Ethernet USB, RS-232 IEEE488 (opt) IEEE488 (opt) (no Ethernet avail.) IEEE488 (opt) IEEE488 (opt.), Ethernet (opt.) Options Preamplifier PA3,Tracking Generator TG3, AM/FM Demod AMA, ASK/FSK Demod DMA, GPIB G01,.EMV Filter EMF Preamplifier GAP-801,Tracking Generator, 1ppm/yr, various RBW settings, AM/FM Demodulator Sensitivity Accuracy Agilent N9320B Delta, Peak, Marker Track Preamplifier HO3011, 135 dBm, opt. Interface, Near-field probes,VSWR bridge HZ547 Display 6.5" 640 x 480 RGB analog 6.4" 640 x 480 color TFT 8.5" 800 x 480 color TFT Base Price 5.767 € 3.920 € 4.085 € 3.300 € Price with similar configuration € 7.908,- incl. TG and Preamplifier € 4.696,- incl. TG and Preamplifier 4.493€ incl. TG € 4.190,- incl. TG and Preamplifier € 8.526,- incl. TG, Preamplifier, AM/FM demod. and EMI Filter €6.890,- incl. TG, Preamp and comp. RBW opt. $ 7.871,- $ 5,800,- $ 5.469,- $ 4.944,- $ 6.349,- $ 5.825,- Base Price Price with similar configuration $ 11.309,- incl. TG and Preamp. $ 8,000,- incl. TG, Preamp and comp. RBW opt. 6.5" 640 x 480 color TFT $ 12.153,- incl. TG, Preamplifier, AM/FM demod. and EMI Filter Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! All information from Datasheet and Internet, status 20.02.2012 16 HAMEG HMS Series HMS 1010 compared to 1 GHz class instruments End Sensitivity Accuracy Quality Model RIGOL DSA815 ATTEN AT6011 HAMEG HMS1000 / HMS 1010 Frequency range 9kHz...1,5GHz 150 kHz - 1 GHz 150 kHz - 1 GHz 100 kHz – 1 GHz Phase noise -80 dBc/Hz at 10 kHz no information available - 77 dBc/Hz at 30 kHz -85 dBc/Hz at 30 kHz Reference level / Measurement range -110 dBm ... +20 dBm -100 dBm ... +13 dBm -100 dBm ... +20 dBm -114 dBm ... +20 dBm DANL (Displayed Average Noise Level) -135 dBm with Preamplifier (typ.) - 90 dBm typ. -100 dBm typ. -135 dBm with Preamplifier Resolution Bandwidth 100 Hz – 1MHz in1-3-10 steps 400kHz, 20kHz 3 kHz, 30kHz, 220 kHz, 4 MHz 100 Hz – 1MHz in1-3-10 steps, 200kHz Video Bandwidth 1 Hz – 3 MHz in1-3-10 steps 4kHz 1.6 kHz, 90kHz (couple with RBW) 10 Hz – 3 MHz in1-3-10 steps, 200kHz -6dB Filters (EMI) 200Hz, 9kHz, 120kHz (opt.) n.a. n.a. 9 kHz,120 kHz, 1MHz Sweep 10ms 20ms 20ms 2 ms – 1000 s Span range 100Hz - 1,5GHz 1 MHz - 1 GHz (1-2-5 steps) 2 kHz - 100 MHz/div in 1-2-5 sequence 1kHz - 1GHz Tracking Generator Optional n.a. Opt 01 Opt HMS1010 Frequency counter no clear information available n.a. no information available Resolution 1 Hz Detectors Auto, Min, Max-Peak, Sample, RMS, Average, Quasi-Peak no information available Max. hold, average(2~32 traces), freeze Auto, Min, Max-Peak, Sample, RMS, Average, Quasi-Peak Marker Optional no information available 2 Marker / No Delta Marker 8 Marker / 7 Delta Marker Marker Functions Optional automeasure functions no information available Absolute, relative, PK->marker, marker->center Delta, Peak, Noise, Peak search, minimum, center Demodulation AM, FM no information available AM / FM (opt) AM, FM Interfaces USB, Ethernet no information available RS-232 only USB, RS-232, Ethernet (opt.) no information available IEEE488 (opt.) Options EMI-Filter & Qpeak Detector, VSWR Kit, Adv.Measurement Kit, Tracking Generator, RF Demo Kit no information available Tracking Generator, Power Meter, Remote control software Preamplifier HO3011, 135 dBm, opt. Interface, Near-field probes,VSWR bridge HZ547 Display 8" 800 x 480 color TFT CRT, 8x 10 divDisplay CRT Display, 8 x 10 graticule, 6-inch waveform LCD Display, 4 line x 20 character data screen 6.5" 640 x 480 color TFT Software n.a. no information available Remote control software (opt) HM Screenshot / EMI software incl. Weight 4.3 kg no information available 8.5 kg 3.6 kg Dimensions 362 x 179 x 128 mm no information available 310 x 150 x 455 mm 285 x 175 x 220 mm Accessories supplied Power cord, Quick Guide, CD ROM no information available Manual, Power cord Manual, Power cord, USB/RS-232 Interface HO720, CD ROM, Adapter Base Price Price with similar configuration € 1.259,€ 2.966,- with TG, Filter and Marker € 2.100,€ 2.300,- with TG € 2.200,€ 2.340,- with TG and Remote software € 2.500,€ 3.290,- with TG and Preamplifier Price in US $ appox. $ 3,900,- with TG, Filter and Marker $ 2,586 with TG $ 3,275 with TG and remote software $ 4,502 with TG and Preamp. Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! GW Instek GSP810 All information from Datasheet and Internet, status 20.02.2012 17 HAMEG HMS Series Some impressions of the HMS series Sensitivity Accuracy Quality The picture above shows a AM modulated The picture above introduces the “UNCAL” sine wave signal with 1 peak marker and 2 warning of the HMS series. delta markers. The Instrument will beware the user of The resp. values are displayed at the top settings which are not harmonizing such as screen. wrong sweep time. Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 18 HAMEG HMS Series Some impressions of the HMS series Sensitivity HMS in receiver mode, which is used for EMI Help is always just one button away: measurements Every Button has it’s own context sensitive Accuracy help text for quick reference, available in all supported languages. Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 19 HAMEG HMS Series Some impressions of the HMS series Sensitivity Simple and intuitive user interface including Auto setup features like : Accuracy Auto RBW / VBW Various peak search functions Quality Auto-Tune feature similar to Oscilloscopes VSWR wizard Flexibility trough : Function sensitive soft key buttons Multiple language support, Functions and help expandable via firmware update Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 20 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers VSWR wizard: The VSWR wizard will guide you through the calibration procedure… Sensitivity Accuracy …from the connection of the bridge until the Quality final measurement. Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 21 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Pass / Fail Test: Improved SCPI commands: TRACE:MEM SAVE TRACE:MEM? TRACE:MEM:SHOW ON | OFF | 0 | 1 TRACE:MEM:SHOW? AMPL:TGATT <value> AMPL:TGATT? Sensitivity AMPL:ATT:LEVEL? Easy to use Pass/Fail test MEAS:UNCAL? Accuracy with audio and/or visual feedback SWEEP:STATe? Quality TRACE:DATA? Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 22 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Set up the measurement and the …or use the built-in measurement environment by yourself… wizard. Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 23 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Define your measurement environment… …and your measurement settings Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 24 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Start the Pre Measurement with your preferred detector… …and get the Pre Measurement result. Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 25 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Start automatic peak detection with your preferred settings… …add some custom marker, if you need it… Sensitivity …and hit the Accuracy Button to perform a Quality Qasi-Peak re-measurement Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 26 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Analyze the result with various information like: Delta value from Pre Measurement to Final Measurement Absolute marker level Delta value from marker level to limit line And much much more Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 27 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers Improved EMC Precompliance software: Least but not last, create a EMC Precompliance report with one click: Sensitivity Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 28 HAMEG HMS Series HAMEG innovation in Spectrum Analyzers 3 Traces Max. Sensitivity Average Min. Accuracy Quality Simplicity HAMEG Instruments GmbH – A Rohde & Schwarz Company For internal use! 29
