3300 CITELlink Gateway
for 7000 Series Norstar Phones
M7310N Phone User Guide
NOTICE
The information contained in this document is believed to be accurate in all respects but is not warranted by MITEL NETWORKSJ
Corporation. The information is subject to change without notice and should not be construed in any way as a commitment by MITEL
NETWORKS or any of its affiliates or subsidiaries. MITEL NETWORKS and its affiliates and subsidiaries assume no responsibility for any
errors or omissions in this document. Revisions of this document or new editions of it may be issued to incorporate any such
changes.
Nothing in this document may be reproduced in any manner, either wholly or in part for any use whatsoever, without written
permission from MITEL NETWORKS Corporation.
IMPORTANT! This telephone is NOT suitable for direct connection to the public-switched telephone network. Connect the telephone
to a Mitel Networks system only.
Mitel Networks is a trademark of Mitel Networks Corporation.
CITELlink is a trademark of CITEL Technologies Ltd.
Nortel Networks is a trademark of Nortel Networks Corporation.
Other product names mentioned in this document may be trademarks of their respective companies and are hereby acknowledged.
Contents
1
ABOUT YOUR PHONE
Conventions
Using Your Norstar Phone with the 3300 CITELlink Gateway
TIPS FOR YOUR COMFORT AND SAFETY
Don't cradle the handset!
Protect your hearing
2
3
3
3
3
4
CUSTOMIZING YOUR PHONE
Ringer Control
Handset Receiver Volume Control
Speaker Volume Control
Display Contrast Control
Feature Keys
Language Change
4
4
4
4
5
5
6
MAKING AND ANSWERING CALLS
Make a call
Answer a call
Redial
Redial - Saved Number
Phonebook
Speed Call Keys
Speed Call - Personal
Handsfree Operation
On-Hook Dialing
Auto-Answer
6
6
6
6
7
8
9
10
10
11
-i-
11
CALL HANDLING
Hold
Transfer
Conference
Conference Split
Add Held
Swap
Call Forward
Call Forward - Remote
Call Forward - End Chaining
Call Forward - Forced
Call Forward - Override
Messaging - Advisory
Messaging - Callback
Messaging - Cancel Callback
Messaging - Cancel All Callbacks
11
12
12
12
13
13
14
15
15
16
16
16
17
18
18
19
USING ADVANCED FEATURES
Account Codes
Call Park
Call Pickup
Campon
Do Not Disturb
Override
Paging
Direct Paging
Reminder
Music
Group Paging / Meet Me Answer
Trunk Flash
Record a Call
Tag Call
-ii-
19
19
19
20
20
20
21
21
22
22
23
23
24
25
ABOUT YOUR PHONE
The Mitel Networks 3300 CITELlink Gateway allows your Nortel Networks™
Norstar phone to work on a Mitel Networks 3300 Integrated Communications
Platform (3300 ICP).
When used with a 3300 ICP, your M7310N phone has 13 fixed-function keys
( SUPERKEY, TRANS/CONF, REDIAL, MESSAGE, HOLD, CANCEL,
SPEAKER, UP ARROW, DOWN ARROW, + (Volume Up), - (Volume Down)
and 14 personal keys. Personal key 19 (see Phone Buttons ) is always your
Prime Line; the remaining personal keys can be programmed as:
z
z
z
Feature keys (for example, Swap). You can program feature keys from
your phone. The administrator can also program feature keys.
Speed Call keys. You can program speed call keys from your phone.
Line Appearances. Only the administrator can program line appearances.
Your phone also features display-assisted selection of features and on-hook
dialing.
-1-
Phone buttons
Button Number
1
2
3
4
5
6-11
12
13
14-20
21, 22, 26
23
24
Description
Cancel
Superkey
Hold
Speaker
Prime Line
Personal Keys with indicators
Transfer/Conference
Message
Personal Keys
Unused
Down Arrow
Up Arrow
25
27
Redial
Softkeys
Phone status indicators
When line is
Idle
Busy
Ringing
On hold at your set
On hold at another set
the indicator is
Off
On
Flashing slowly
Flashing rapidly
Flashing slow on/fast off
Conventions
The following conventions are used in this user guide:
z
z
z
Fixed-functions keys are identified by bold uppercase letters (for
example, TRANS/CONF ).
Softkeys are identified by bold letters and the word "softkey" (for
example, "Press the Yes softkey.").
Text that appears on the display is identified by double quotes (for
example, "Language?").
-2-
Using Your Norstar Phone with the 3300 CITELlink Gateway
Please note the following differences in the way your phone now operates:
z
z
z
You can program speed call numbers, personal keys as well as
enable/disable features using SUPERKEY. To navigate through the
menus, use the YES and NO softkeys.
Some features require you to dial a feature access code. You can use
feature access codes whenever you have dial tone. The feature access
codes in this user guide may be different from the ones programmed in
your system. Ask your Administrator for the list of feature access codes
you can use.
When you have a message (including new voice mail messages),
"Message" appears on the display, and the MESSAGE key indicator turns
on.
You do not need to select a line before dialing a number. See On-hook
Dialing in the Making and Answering Calls section for more information.
z
TIPS FOR YOUR COMFORT AND SAFETY
Don't cradle the handset!
Prolonged use of the handset can lead to neck, shoulder, or back discomfort,
especially if you cradle the handset between your ear and shoulder.
Protect your hearing
Your phone has a control for adjusting the volume of the handset receiver or
speaker. Because continuous exposure to loud sounds can contribute to
hearing loss, keep the volume at a moderate level.
-3-
CUSTOMIZING YOUR PHONE
Ringer Control
To adjust the Ringer Volume while the phone is ringing:
z
Press + or -.
To adjust the Ringer Pitch or Volume while the phone is idle:
1.
2.
3.
4.
Press SUPERKEY.
Press the No softkey until "Ringer Adjust?" appears.
Press the Yes softkey.
To adjust the ringer pitch, press the Yes softkey. To adjust the ringer
volume, press the No softkey, then the Yes softkey.
5. Press + or - until you hear the desired pitch/volume.
6. Press SUPERKEY.
Handset Receiver Volume Control
To adjust the Handset Receiver Volume when you are using the
handset:
z
Press + or -.
Speaker Volume Control
To adjust the Speaker Volume when making an on-hook call or when
listening to background music:
z
Press + or -.
Display Contrast Control
To adjust the Display Contrast while your phone is idle:
z
Press UP ARROW or DOWN ARROW.
-4-
Feature Keys
To display information about a key:
1. Press SUPERKEY.
2. Press a personal key or REDIAL.
3. Press SUPERKEY.
To re-program a personal key:
Note: Use the personal keys with indicators (see page 2) for features that
need an indicator (such as Do Not Disturb or Call Forward).
1.
2.
3.
4.
5.
6.
7.
8.
Press
Press
Press
Press
Press
Press
Press
Press
SUPERKEY.
the No softkey until "Personal Keys?" appears.
the Yes softkey.
a personal key that isn't a line key.
the Change softkey.
the No softkey until the desired feature appears.
the Yes softkey.
SUPERKEY.
Language Change
To change the display language:
1.
2.
3.
4.
5.
6.
Press
Press
Press
Press
Press
Press
SUPERKEY.
the No softkey until "Language?" appears.
the Yes softkey.
the Change softkey.
the No until the desired language appears.
the Yes softkey.
-5-
MAKING AND ANSWERING CALLS
Make a call
1. Lift the handset.
2. If you want to use a Non-Prime Line, press a Line Appearance key.
3. Dial the number,
-ORPress a Speed Call key.
-ORPress REDIAL.
Answer a call
z
Lift the handset.
-ORPress the flashing Line appearance key and lift the handset.
Redial
To redial the last number that you manually dialed:
1. Lift the handset.
2. Press REDIAL.
Redial - Saved Number
To save the last number that you manually dialed:
1. Lift the handset.
2. Dial **79.
To Redial a saved number:
1. Lift the handset.
2. Dial *6*.
-6-
Phonebook
For each letter in the name, press the appropriate key on the keypad until
the letter is shown in the display; for example, if the letter C is required,
press the digit 2 three times. Use the
softkey to correct errors. If the next
letter in a name is on the same key as the previous letter, press the
softkey before proceeding. If required, use the
softkey to add a space
between the first and last name.
To use Phonebook:
1.
2.
3.
4.
5.
6.
Press the Phonebook softkey.
Enter the name of the desired party using the keypad.
Press the Lookup softkey.
If no match exists, edit the original entry.
If the name is not unique, press the Next softkey.
Do one of the following:
„ To make the call, press the Call softkey.
„ To edit the entry, press the Retry softkey.
„ To exit, press SUPERKEY.
-7-
Speed Call Keys
You may use Speed Call Keys to make a call or to send a string of digits
during a call (press a Speed Call Key during a call to send a multi-digit
password, for instance).
To dial a stored Speed Call number:
1. Lift the handset.
2. Press a Speed Call key.
To store a Speed Call number:
1.
2.
3.
4.
5.
Press SUPERKEY.
Press a personal key that isn't a line key.
Press the Change softkey.
Press the Yes softkey.
Do one of the following:
„ To enter a new number, dial the number. Press HOLD between digits
to create a pause during dialing; press HOLD more than once to
lengthen the pause.
„ To enter a trunk flash, press TRANS/CONF. (See Trunk Flash for
more information about the use of this feature.)
„ To enter the last number dialed, press REDIAL.
6. To make the number private, press the Private softkey.
7. Press the Save softkey.
8. Press SUPERKEY to exit, or select another personal key to program
another speed dial number.
-8-
Speed Call - Personal
Note: Personal Speed Call lists must be configured by the Administrator.
To store a personal Speed Call number:
1.
2.
3.
4.
Lift the handset.
Dial 67.
Enter an index number between 00 and 09.
Dial the number to be stored (press Hold between digits to create a
pause during dialing - press Hold more than once to lengthen the
pause).
5. Hang up.
To dial a stored personal Speed Call number:
1. Lift the handset.
2. Dial 58.
3. Enter an index number between 00 and 09.
-9-
Handsfree Operation
To use Handsfree Operation to make calls:
1. If you want to use a Non-Prime Line, press a Line Appearance key.
2. Dial the number.
3. Communicate by using the speaker and the microphone.
To use Handsfree Operation to answer calls:
1. Press the flashing line key.
2. Communicate by using the speaker and the microphone.
To hang up while using Handsfree Operation:
z
Press CANCEL.
To temporarily disable the microphone during Handsfree Operation:
z
Press SPEAKER (the SPEAKER indicator turns off).
To re-enable the microphone and return to the conversation:
z
Press SPEAKER (the SPEAKER indicator turns on).
To disable Handsfree Operation:
z
Lift the handset.
To return to Handsfree Operation:
1. Press SPEAKER.
2. Hang up.
On-Hook Dialing
To dial without lifting the handset:
1. If you want to use a Non-Prime Line, press a Line Appearance key.
2. Dial the number.
3. Lift the handset.
-10-
Auto-Answer
To enable or disable Auto-Answer:
1. Press SUPERKEY.
2. Press the No softkey until "Auto Answer?" appears.
3. Do one of the following:
„ To enable Auto-Answer, press the TurnOn softkey.
„ To disable Auto-Answer, press the TurnOff softkey.
To answer a call when you hear ringback:
z
Communicate by using the speaker and the microphone.
- OR Lift the handset.
To terminate a call:
z
Press CANCEL.
-ORWait for the caller to hang up.
CALL HANDLING
Hold
To place a call on Hold:
z
Press Hold.
To retrieve a call from Hold:
1. Lift the handset.
2. Press the flashing line key.
To retrieve a call from Hold at another station:
z
Press the flashing line key.
-ORDial **1 and the number of the station that placed the call on Hold.
-11-
Transfer
To Transfer an active call:
1. Press TRANS/CONF.
2. Dial the number of the third party.
3. Do one of the following:
„ To complete the Transfer, hang up.
„ To announce the Transfer, wait for an answer, consult, and hang up.
„ To cancel the Transfer, press CANCEL.
Conference
To form a Conference when a two-party call is already in place, or to
add another party to an existing Conference:
1.
2.
3.
4.
Press TRANS/CONF.
Dial the number of the next party.
Wait for an answer.
Press TRANS/CONF.
To leave a Conference:
z
Hang up.
Conference Split
To Split a Conference and speak privately with the original party:
z
Press the Split softkey.
To return to the conference call:
z
Press TRANS/CONF.
-12-
Add Held
To move a call on Hold to another line appearance:
1. Press an available line key.
2. Press the Addheld softkey.
3. Press the flashing line key.
To add a call on Hold to an existing conversation or conference:
1. Press the Addheld softkey.
2. Press the flashing line key.
Swap
To call another party when you are in an established two-party call:
1. Press TRANS/CONF.
2. Dial the number.
To alternate between the two parties:
z
Press the Trade softkey.
-13-
Call Forward
Call Forward lets you redirect incoming calls to an alternate number. Always
redirects all incoming calls regardless of the state of your phone. B-Int
redirects internal calls when your phone is busy, and B-Ext redirects external
calls when your phone is busy. NA-Int redirects internal calls after several
rings if you don't answer, and NA-Ext redirects external calls after several
rings if you don't answer.
Note: For information about "I Am Here?", see Call Forward - Remote.
To program Call Forward:
1.
2.
3.
4.
5.
6.
7.
8.
9.
0.
Press SUPERKEY.
Press the No softkey until "Call Forwarding?" appears.
Press the Yes softkey.
Press the Next softkey until the desired type of Call Forward appears
(see above).
Press the Review softkey.
If a number is already programmed, press the Change softkey.
Press the Program softkey.
Dial the destination number.
Press the Save softkey.
Press SUPERKEY.
To turn Call Forward on and off (once it has been programmed):
1.
2.
3.
4.
5.
6.
7.
Press SUPERKEY.
Press the No softkey until "Call Forwarding?" appears.
Press the Yes softkey.
Press the Next softkey until the desired type of Call Forward appears.
Press the Review softkey.
Press the Change softkey.
Do one of the following:
„ To turn Call Forward on, press the TurnOn softkey.
„ To turn Call Forward off, press the TurnOff softkey.
8. Press SUPERKEY.
-14-
Call Forward - Remote
To forward calls from a remote station to your current location:
1.
2.
3.
4.
5.
6.
7.
Press SUPERKEY.
Press the No softkey until "Call Forwarding?" appears.
Press the Yes softkey.
Press the Next softkey until "I Am Here" appears.
Press the Yes softkey.
Dial the extension of the remote station.
Press the Save softkey.
To cancel Call Forward - Remote from the station that set the remote
forwarding:
1.
2.
3.
4.
Lift the handset.
Dial **77.
Dial the extension of the remote station.
Hang up.
To cancel Call Forward - Remote from the station that was forwarded:
1.
2.
3.
4.
5.
6.
7.
Press
Press
Press
Press
Press
Press
Press
SUPERKEY.
the No softkey until "Call Forwarding?" appears.
the Yes softkey.
the Review softkey.
the Change softkey.
the TurnOff softkey.
SUPERKEY.
Call Forward - End Chaining
To ensure that calls do not get forwarded again by the destination
number:
1. Lift the handset.
2. Dial 64.
3. Hang up.
To again allow calls to be forwarded by the destination number:
1. Lift the handset.
2. Dial **73.
3. Hang up.
-15-
Call Forward - Forced
To force an incoming call to be forwarded:
z
Press the Forward softkey.
Call Forward - Override
To override Call Forward and ring a station:
1. Lift the handset.
2. Dial *1*.
3. Dial the extension number.
Messaging - Advisory
To turn Messaging - Advisory on:
1.
2.
3.
4.
5.
Press
Press
Press
Press
Press
SUPERKEY.
the No softkey until "Advisory Msgs?" appears.
the Yes softkey.
the Next softkey until the desired message appears.
the TurnOn softkey.
To turn Messaging - Advisory off:
1.
2.
3.
4.
Press
Press
Press
Press
SUPERKEY.
the No softkey until "Advisory Msgs?" appears.
the Yes softkey.
the TurnOff softkey.
-16-
Messaging - Callback
To leave a message waiting indication on a phone when you hear busy
or ringback tone:
z
Press MESSAGE or the Callback softkey.
To respond to a message waiting condition on your phone:
1. Press MESSAGE.
2. If a password is required, dial your password and press the Enter
softkey.
3. Press the Yes softkey. The caller information is displayed.
4. To display the time the message was sent, press the More softkey.
„ To display the number of the caller, press the More softkey twice.
5. Do one of the following:
„ To call the message sender, press the Call softkey.
„ To delete the message, press the Erase softkey.
„ To view the next message, press MESSAGE.
To answer a Callback:
z
Lift the handset.
To check for messages from a remote station:
1.
2.
3.
4.
5.
6.
Press SUPERKEY.
Press the No softkey until "Remote Msging?" appears.
Press the Yes softkey.
Dial your extension number.
Press the Enter softkey.
If a password is required, enter your password and press the Enter
softkey.
7. Press the Yes softkey.
-17-
To set, change, or clear a password (up to 7 digits, not including 0):
1.
2.
3.
4.
5.
6.
7.
8.
9.
Press SUPERKEY.
Press the No softkey until "Set Password?" appears.
Press the Yes softkey.
Do one of the following:
„ To enter a new password, enter your password.
„ To change or clear your password, enter your current password.
Press the Enter softkey.
If you are changing or clearing your password, do one of the following:
„ To change your password, enter your new password and press the
Enter softkey.
„ To clear your password, enter 0.
Enter your new password again.
If you are setting up or changing a password, press the Enter softkey.
Press SUPERKEY.
Messaging - Cancel Callback
To cancel a Callback:
1.
2.
3.
4.
Lift the handset.
Dial *1#.
Dial the number of the called station.
Hang up.
Messaging - Cancel All Callbacks
To cancel all Callbacks:
1. Lift the handset.
2. Dial #1.
3. Hang up.
-18-
USING ADVANCED FEATURES
Account Codes
To use Forced Account Codes:
1. Lift the handset.
2. Dial the Account Code digits.
3. Press #.
To enter an Account Code during a call:
1.
2.
3.
4.
5.
Press SUPERKEY.
Press the Yes softkey.
Dial the Account Code digits.
Press the Save softkey.
Do one of the following:
„ For a verified account code, press the Yes softkey.
„ For a non-verified account code, press the No softkey.
Call Park
To retrieve a call parked by the attendant:
1. Lift the handset.
2. Dial *23.
3. Dial the console ID and the Hold Slot number.
Call Pickup
To answer a call that is ringing at another station in your Pickup
Group:
1. Lift the handset.
2. Press the Pickup softkey.
To answer a call that is ringing at a station not in your Pickup Group:
1. Lift the handset.
2. Dial **6.
3. Dial the number of the ringing station.
-19-
Campon
To Campon to a busy station:
z
Press the Wait softkey.
To retrieve a call when you hear Campon tone:
z
Press the Trade softkey.
Do Not Disturb
To activate or deactivate Do Not Disturb:
Press the Do Not Disturb feature key.
-ORPress SUPERKEY.
Press the NO softkey until "Do Not Disturb" appears.
Do one of the following:
„ Press TurnOn to activate Do Not Disturb.
„ Press TurnOff to deactivate Do Not Disturb.
z
z
z
z
To activate Do Not Disturb from a remote station:
1.
2.
3.
4.
Lift handset.
Dial **5.
Dial the number of the station to which Do Not Disturb is to apply.
Hang up.
To deactivate Do Not Disturb from a remote station:
1.
2.
3.
4.
Lift handset.
Dial ##5.
Dial the number of the station with Do Not Disturb activated.
Hang up.
Override
To use Override when you encounter busy or DND tone:
z
Press the Intrude feature key.
-20-
Paging
To use Paging:
1.
2.
3.
4.
Lift handset.
Press the Pager feature key.
Dial the Paging zone number (if required).
Make the announcement.
Direct Paging
Direct Paging allows you to page a party through their phone speaker. If the
paged party has Off-Hook Voice Announce enabled, the page will be heard
even when the party is on a handset call.
To page a party:
1.
2.
3.
4.
Lift the handset.
Press the Direct Paging feature key.
Dial the extension number.
Speak to the dialed party after the tone.
If Handsfree Answerback has been turned on at your phone and you receive
a Direct Page while your phone is idle, or while you are on a handset call, a
handsfree call will automatically be established after a single burst of tone.
The following instructions assume that Handsfree Answerback is not enabled
on your phone.
To answer a Direct Page (indicated by a single burst of tone):
z
Lift handset.
- OR Press SPEAKER.
To answer a page while using the handset:
z
Press SPEAKER.
To enable or disable Handsfree Answerback:
z
Press SPEAKER while the phone is idle.
-21-
Reminder
To program a Reminder:
1.
2.
3.
4.
5.
Press
Press
Press
Enter
Press
SUPERKEY.
the No softkey until "Timed Reminder?" appears.
the Yes softkey.
the time in 24-hour format.
the Save softkey.
To view, change, and/or cancel a pending Reminder:
1.
2.
3.
4.
Press SUPERKEY.
Press the No softkey until "Timed Reminder?" appears.
Press the Yes softkey.
Do one of the following:
„ To change the Reminder, press the Change softkey, enter the new
time, and press the Save softkey.
„ To cancel the Reminder, press the Clear softkey.
„ To exit without canceling the Reminder, press SUPERKEY.
To acknowledge a Reminder when your phone rings once:
z
Press the Confirm softkey.
Music
To turn Music on and off when the phone is idle:
1. Press SUPERKEY.
2. Press the No softkey until "Music?" appears.
3. Do one of the following:
„ To turn the music on, press the TurnOn softkey.
„ To turn the music off, press the TurnOff softkey.
-22-
Group Paging / Meet Me Answer
Group Paging allows you to page a group of telephones through their built-in
speakers. You can belong to as many as three paging groups with one group
designated as your "prime" group.
When you need to respond to a Group Page but don't know the identity or
extension number of the paging party, use the Meet Me Answer feature. You
have up to 15 minutes after receiving the page to use Meet Me Answer.
To make a Group Page:
1. Lift the handset.
2. Press the Direct Page feature key or dial *37.
3. Do one of the following:
„ To page your prime page group, press #.
„ To page a specific page group, dial the page group directory number.
4. Speak to the dialed party after the tone.
To respond to a Group Page by using Meet Me Answer:
1. Lift handset.
2. Dial *88.
3. Do one of the following:
„ To respond to a page from your prime page group, press #.
„ To respond to a page from a specific page group, dial the page group
directory number.
Trunk Flash
The Trunk Flash feature allows you to access Centrex features (if available)
while you are talking on an outside call.
To flash a trunk while talking on an outside call:
1.
2.
3.
4.
Press TRANS/CONF.
Dial *57 for a single flash or *56 for a double flash.
Wait for dial tone.
Dial the Centrex feature access code.
-23-
Record a Call
This feature uses your voice mail system to record your phone
conversations.
Note: You may be required by law to inform the other party that you are
recording the conversation. For specific instructions, consult your system
administrator.
To start recording while on a two-party call:
z
Press the Record Call feature key. (See Feature Keys for instructions on
programming a Record Call key to your phone.)
Note: Your system may be programmed to automatically begin recording
external calls when you or the other answers.
To pause recording:
z
Press the Pause softkey.
To resume recording after pausing:
z
Press the Resume softkey.
To stop a recording without saving it:
z
Press the Stop&Erase softkey.
To stop and save a recording:
z
z
Press the Stop&Save softkey.
Press the Record Call key.
Putting the call on hold saves the recording; taking the call off hold starts a
new recording. Depending on system programming, hanging up, or pressing
TRANS/CONF or a DSS key, may also save the recording.
To listen to a recording:
1. Lift the handset.
2. Access your voice mailbox.
3. Follow the prompts to retrieve the recording.
-24-
Tag Call
Tag Call allows you to "tag" any threatening call that you receive. Using this
tag, your system administrator can identify the source of the malicious call
and provide this information to appropriate personel or authorities. You can
only tag calls during an active two-party call.
Note: Tagging a call unecessarily may result in fines or other penalties.
To tag a malicious call:
z
Press the Tag Call feature key. See "Feature Keys" elsewhere in this
guide for information on programming a Tag Call feature key on your
phone.
-OR1. Press TRANS/CONF.
2. Dial *55.
If the call was successfully tagged "Thank You" is shown on the display;
otherwise, "Not Allowed" is displayed.
-25-
®,™ Trademark of Mitel Networks Corporation
© Copyright 2004, Mitel Networks Corporation
All rights reserved
Download PDF
