Security with System
ASSMANN Presents
New Plug&View Outdoor Cameras
*
The Plug&View-System
What is the Plug&View System?
Focus on everything that is important!
The state-of-the-art concept of the IP-cameras guarantees
fast and uncomplicated security solutions for private users
as well as for commercial use. Contrary to common network
cameras the high-performance Plug&View devices can be
installed quite easily, are ready for use immediately and are
accessible from everywhere via the Internet. Whether during
the day or at night, indoor or outdoor – the possible applications of the cameras have no limits.
The network cameras are equipped with a motion detection
function. When the device registers a motion it records it
automatically and sends the user a message per mail – if
so desired – or stores the data automatically in myDigitusCloud. So that the devices record motions also when it is
dark they are also equipped with Smart-Light-Control. The
recorded information can be called up at any time via the
personal user account. A WLAN connection provides uninterrupted transfer of data.
INSTALL
AT
SY
EA
**
N*
IO
When at work you may want to keep an eye on your four
legged friends at home or monitor your home remotely to
prevent break-ins or theft. The cameras are of course also
suited for commercial use – for instance as protective devices against unauthorized access, vandalism or theft. E.g.
the devices monitor the company site or the car fleet, hotel
facilities, or they secure data centres.
The Plug&View system enables access to the cameras via
all common Internet browsers. Especially convenient is the
access via your own app which guarantees tailored control
of the user account via smartphones and tablets.
***
The Digitus Plug&View System, distinguished with the
Innovation Award IT, is an easy-to-install video surveillance
solution for your home.
3 steps!
in just
**
*
1. Establish network
connection
2. Install app or
register camera under
www.myDIGITUS.net
3. Ready to go!
DIGITUS® Plug&View:
awarded with the
Innovation Award IT 2013
Username
Password
Apply
VIA
APP **
*
The Plug&View-System
Fields of application
DIGITUS® Plug&View Cameras for the private application area
Baby –
Animals –
The elderly –
Homestead –
Always keep an eye on your little
ones. The ideal alternative if the
baby-phone comes to its limits.
Supervise solely living elderly
people from the distance and
use the chance to react to
potential emergencies.
You want to know what your dog
or cat is doing alone at home?
Supervise your animals on the
go.
Observe the incidents at home
from your working place. Protect
your homestead from burglary
and thievery.
DIGITUS® Plug&View Cameras for the commercial application area
Hotels –
Companies –
Data Center –
Car Pool –
The DIGITUS® Plug&View cameras are the ideal solution not
just for your own accommodations, but also for protection of
guests.
Here, the focus lies on safety
– Protect your data center from
unauthorized visitors and thus
defend the most sensible aspect
of your company: namely company
and network data.
Protect your company from
unauthorized entrance or
vandalism as well as your
employees from mobbing and
thus guarantee self-security.
The DIGITUS® Plug&View outdoor
cameras are perfectly suitable
for the surveillance of your
car pool as to defend it from
vandalism.
The Plug&View-System
The New Cameras
**
VIA
APP **
*
The DIGITUS® Plug&View OptiDome belongs to the new DIGITUS® Plug&View
generation. The dome-shaped design of the camera is as elegant as practical,
making it ideal for indoor use. Mounted under the ceiling the indoor camera
convinces with a 2 megapixel video resolution.
The simplistic design allows it to blend in perfectly with your home or office
decoration. With DIGITUS® Plug&View technology the installation of your
OptiDome is done in 3 easy steps. Everything just works with DIGITUS®
Plug&View.
**
*
3 steps!
in just
*
H.264 Manually-controlled focus
VIA
APP **
*
The Digitus® Plug&View OptiVario is a small and inconspicuous model,
which is perfect for monitoring entrances, private garden or small
commercial units thanks to the weatherproof IP66 housing. This
camera model has a manual, optical zoom, which can be adjusted
directly on the camera. The focus can be optimally adjusted to the area
to be monitored.
OptiVario at a glance:
OptiDome at a glance:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DIGITUS® OptiVario
INSTALL
SY
AT
EA
**
N*
IO
in just
OUTDOOR
**
3 steps!
*
Dome-shaped outdoor camera
INSTALL
SY
AT
EA
**
N*
IO
DIGITUS® OptiDome
**
*
INDOOR
2 megapixel video resolution (UXGA 1600 x 1200, HD720 1280 x 720)
Low-latency video streaming with H.264 compression format
Powerful mobile surveillance supporting iOS and Android devices
Wireless LAN according to the newest 11n standard for fluent
image transmission
Integrated 2GB storage for recording videos and snapshots
Suitable for the most common browsers
Simple and fast installation with P2P support & QR-code-scanning
IR-LEDs and IR cut filter included for day & night surveillance
LAN Speed: 10/100Base-TX Ethernet
Advanced motion detection, record and save events via email/FTP/
Google Drive
Supports up to 25fps video frame rate at HD720 and 15fps at UXGA
Operating temperature: 0°C - 40°C
Power source (±10%): DC12V / 1A
Dimensions (mm): 115 (L) x 115 (W) x 90 (H)
Supports DIGITUS® Plug&View app for smart phone and tablet access
Operating system independent, supports e.g. Windows, Mac OS,
Linux and Sun
Lens: F1.5 f3.6mm
Horizontal viewing angle: 69°
4x digital zoom
Including 2GB of internal memory
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
IP Outdoor camera with 2 Megapixel video resolution
IP66 housing, suitable for outdoor use
Wireless LAN according to the latest 11n Standard
Supports up to 25fps (frames per second) as HD720 and 15fps as UXGA
Including 2GB internal memory for video and image recording
High-performance motion detection, time-controlled automatic
recording and backup of the images via Email/FTP/Google Drive
Supports the Digitus Plug&View App for Smartphones and Tablets
Operating temperature: -20 to +50 °C
Power supply (±10%): DC12V / 1A
PoE - Power over Ethernet
Dimensions (mm): 90 (L) x 70 (B) x 235 (H)
Supports the Digitus Plug&View App for Smartphones and Tablets
IR LEDs & IR Cut Filter - optimal for 24-hour surveillance.
Optical zoom lens: F1.4 / 2.8-12mm
Adjustable horizontal viewing angle: 20° - 65°
4x digital zoom
Including 2GB of internal memory
Available as of 01.12.2013
Available as of 29.11.2013
336396 / DN-16038
336402 / DN-16039
POWER OVER
CONTROL
ETHERNET
The Plug&View-System
The New Cameras
**
VIA
APP **
*
The Digitus® Plug&View OptiDome Pro is a dome camera – perfect
for small hallways or on carport or garage ceilings. The dome-shaped
housing is made of particularly unbreakable plastic. This protects the
camera from sabotage and weather conditions. It can be simply screwed
onto the ceiling in one corner of the room.
**
*
DIGITUS® OptiZoom
3 steps!
in just
*
3 x optical Zoom
INSTALL
SY
AT
EA
**
N*
IO
in just
OUTDOOR
**
3 steps!
*
Dome-shaped outdoor camera
INSTALL
SY
AT
EA
**
N*
IO
DIGITUS® OptiDome Pro
**
*
OUTDOOR
VIA
APP **
*
This camera model has a particularly robust housing made of die-cast
aluminium with a polycarbonate bubble, which protects the camera
from wind, rain and dust as much as from vandalism. This model can
be installed in pretty much any surrounding and give good images, even
under tough conditions. Thanks to the 3 x optical zoom, the recording
area can be set optimally. The horizontal viewing angle can be set from
29 to 76 degrees.
The OptiDome Pro at a glance:
The OptiZoom at a glance:
• IP Outdoor camera with 2 Megapixel video resolution
• IP66 housing, suitable for outdoor use
• Wireless LAN according to the latest 11n Standard
• Supports up to 25fps (frames per second) as HD720
and 15fps as UXGA
• Including 2GB internal memory for video and image recording
• High-performance motion detection, time-controlled automatic
recording and backup of the images via Email/FTP/Google Drive
• Supports the Digitus Plug&View App for Smartphones and
Tablets
• IR LEDs & IR Cut Filter – optimal for 24-hour surveillance.
• Operating temperature: -10°C ~ +50°C
• Power supply (±10%): DC12V / 1A
• Power over Ethernet
• Dimensions (mm): 140 (L) x 140 (B) x 110 (H)
• Optical zoom lens: F1.4 / 2.8-12mm
• Adjustable horizontal viewing angle: 20°- 65°
• 4x digital zoom
• Including 2GB of internal memory
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Available as of 01.12.2013
IP Outdoor camera with 2 Megapixel video resolution
IP66 housing, suitable for outdoor use
Wireless LAN according to the latest 11n Standard
Supports up to 25fps (frames per second) as HD720 and 15fps
as UXGA
Including 2GB internal memory for video and image recording
High-performance motion detection, time-controlled automatic
recording and backup of the images via Email/FTP/Google Drive
IR LEDs & IR Cut Filter - optimal for 24-hour surveillance.
Supports the Digitus Plug&View App for Smartphones and Tablets
Operating temperature: -10°C ~ +50°C
Power supply (±10%): DC12V / 1A
Power over Ethernet
Dimensions (mm): 165 (L) x 195 (B) x 130 (H)
Optical zoom lens with auto focus: F2.0 / 5-15mm
3 x optical zoom
Adjustable horizontal viewing angle: 29° - 76°
4x digital zoom
Including 2GB of internal memory
Available as of 01.12.2013
337348 / DN-16043
339069 / DN-16044
POWER OVER
POWER OVER
ETHERNET
CONTROL
ETHERNET
The Perfect Accessories
**
*
INSTALL
SY
AT
EA
**
N*
IO
The MiniNVR
3 steps!
in just
**
The First Network Video Recorder
for the DIGITUS® Plug&View System!
*
VIA
APP **
*
Video recording of up to 4 Plug&View cameras anytime with access
from anywhere. With the DIGITUS® Plug&View MiniNVR recording
is possible by simply scanning the QR code with your smart phone
in just 3 steps. The network recorder automatically searches and
connects your registered cameras. For installation and recording is
no more manual configuration needed.
1,2 cm
Due to the integrated HDMI interface, the connected cameras can
be shown on your local display. So you always have direct access
to the live images from the cameras and hence the security at any
time to view the videos. With the DIGITUS® Plug&View app you
can remotely access your MiniNVR and see the live image of the
cameras, or look up the records.
3,3 cm
9,0 cm
DIGITUS® MiniNVR
329886 / DN-16150
• Full HD audio/video transmission (1080p)
• Storage capacity max. 2TB over USB port, or max. 32GB over microSD card
• 4 channel Live-view at local display with 1080p Full HD HDMI output
• Record of up to 4 cameras with 20fps @ 640x480
• LAN(RJ45) input jack
• LAN Speed: 10/100Base-TX Ethernet
• IR remote control
• Video compression format MJPEG, audio compression format G.711
• Live-view by remote access: 1CH Live-view via browser on plug-view.com
or DIGITUS® Plug&View app
• 1 CH remote playback via browser on plug-view.com or via DIGITUS® Plug&View app
• Recording: event, scheduled recording
• Registration: QR code scan to register MiniNVR, the MiniNVR auto searches
IP cameras and then auto-bind them under your Plug&View account
• Operating temperature: 0°C - 40°C
• Power source (±10%): DC5V / 2A
• Power consumption: 3.5W (excludes USB storage power consumption)
• Dimensions (mm): 90.3 (L) x 33.15 (W) x 12.1 (H)
• Supports DIGITUS® Plug&View app for smart phone and tablet access
• Operating system independent, supports e.g. Windows, Mac OS, Linux and Sun
Available as of 18.12.2013
Videosupervision tape, store and live consider
Anbindung von bis zu 4 Plug&View IP-Kameras via LAN-Kabel // Wireless LAN
Router
DIGITUS® Plug&View
MiniNVR DN-16150
Lokales Netz
LAN-Kabel // Wireless LAN
Internet
LAN-Kabel
DIGITUS® PLUG&VIEW
IP-Kameras
Smartphone
via App
Laptop
via Browser
HD VideoSchnittstelle
USB 2.0
Externe Festplatte
max. 2 TB
USB 2.0
USB-Stick
Stromversorgung per Micro USB
inkl. IR-Empfänger & Fernbedienung
microSD-Karte
max. 32 GB
Tablet
via App
PC
via Browser
Product Overview
**
*
INSTALL
SY
AT
EA
**
N*
IO
All Cameras at a Glance
3 steps!
in just
**
*
V IA
APP **
*
Indoor cameras
DIGITUS®
OptiView
DIGITUS®
OptiVision
DIGITUS®
OptiArc
DIGITUS®
OptiDome
Beginner‘s IP camera
with VGA resolution
for day and night
2 Megapixel WLAN
IP camera for day and night
WLAN 2 Megapixel
IP camera with pan and tilt
function
2 Megapixel WLAN
IP dome camera
with night view mode
DIGITUS®
OptiVario
DIGITUS®
OptiMax Pro
DIGITUS®
OptiDome Pro
DIGITUS®
OptiZoom
2 Megapixel WLAN
camera with
day and night function
2 Megapixel bullet camera
With day and night function
Against vandalism
protected IP dome camera
with wide-angle lens
Trick & tiltable, WLAN
2 Megapixel IP dome camera
for 360 ° all-round protection
DN-16028
DN-16027
DN-16036
DN-16038
Outdoor cameras
DN-16039
DN-16040
DN-16043
DN-16044
